A NEW ERA OF COLOR –
THE CANON COLOR imageRUNNER C4080 SERIES
Unleash power, speed, flexibility, and connectivity in your office
With robust functionality, advanced print engine technology,
superior paper-handling, and professional finishing options,
the Color imageRUNNER C4080 Series models are the ideal
multifunction devices for your office.
The Color imageRUNNER C4080 Series delivers output at speeds
of up to 40 pages per minute (letter) in monochrome and up to
36 ppm (letter) in brilliant color. Fast print speeds and warm-up
times are achieved through Canon’s Twin-Belt Fusing Technology.
And at true 1200 dpi, every word will appear with absolute clarity
with the highly precise four-beam laser scanner.
A fast and reliable 100-sheet Duplexing Automatic Document
Feeder (DADF) enables you to efficiently scan/copy high-volume
documents at up to 70 impressions per minute (ipm) at 300 dpi
in black and white and color.
Two versions of the Color imageRUNNER C4080 Series are
available—an “i” model and a “Base” model. The “i” model,
designed for general office environments, is bundled with features
providing out-of-the-box business productivity. The “Base”
model is highly customizable and offers a selection of options
to best fit demanding color environments.
The Color imageRUNNER C4080 Series provides memory capacity
of up to 1.5GB, an 80GB hard drive, and Canon’s innovative MEAP®
(Multifunctional Embedded Application Platform) technology
for customized workflows. With high-capacity finishing options,
professional output is available for any project.
When it comes to connectivity, the Color imageRUNNER C4080
Series enables efficient document distribution with Canon’s Color
Universal Send technology. Standard on all models, it provides
comprehensive dissemination of information simultaneously to
multiple locations across the hall or around the globe.
COLOR imageRUNNER C4080 SERIES OVERVIEW
Productivity far beyond the norm
EFFICIENCY
HIGH QUALITY
AND PRODUCTIVITY
Canon’s imageCHIP
architecture provides
increased speed, power,
and functionality.
Copy, scan, and print documents
faster, and output them
with professional finishing
options.
SCALABILITY
Create custom applications and
interfaces with MEAP technology
and streamline workflow
productivity for users.
SUPERIOR COMMUNICATION
Create and store documents
with powerful tools and
distribute them easily with
standard Color Universal
Send technology.
POWERFUL IMAGING
Choose options and software
for increased productivity in
corporate or professional
color environments.
INTERNET-READY
Collaborate on your documents
via the Internet or browse and
print Web content right
from the device.
USER-FRIENDLY
Searchable CD-based manuals
and easy-to-use color display
panel with guided help key for
users, and advanced tools for
administrators.
Function
SECURITY AND ACCESSIBILITY
Advanced security features
protect your data, while
accessibility options ensure
access to all users.
Color imageRUNNER C4080
Color imageRUNNER C4080i
Copy
Standard
Mail Box
Standard
Print
Scan
Color Universal
Send
Super G3 Fax
Optional:* UFR II, PCL, PostScript Emulation,**
Standard: UFR II, PCL
Adobe® PostScript® 3™
Optional: PostScript Emulation**
Standard: Color Network ScanGear
Standard: Color Universal Send
Optional: Universal Send PDF Advanced Feature Set
Standard: Universal Send PDF Advanced Feature Set
Optional: Universal Send PDF Security Feature Set
Standard: Universal Send PDF Security Feature Set
Optional: Single-Line or Multi-Line
Web Access
Optional
MEAP
Standard
* Choose one of three print controller options: UFR II/PCL Printer Kit-N2, imagePASS-H1 or ColorPASS-GX200.
** PS Printer Kit-N2 option requires the UFR II/PCL Printer Kit-N2; also requires 512MB RAM.
The Anatomy of an Efficient Performer
Robust Speed
Canon imageCHIP System Architecture
• Up to 70-ipm high-speed color and black-and-white scanning
• Standard 100-sheet Duplexing Automatic Feeder
• Up to 40 ppm* (black and white); up to 36 ppm* (color) printing
• imageCHIP architecture provides more speed
and power for greater productivity
• Up to 1.5GB RAM and 80GB HDD
• Dedicated dual processor design
• Mail Box: local archival solution
• Remote UI device management
Reliable Consumables and Supplies
• Durable Canon OPC Drum
• Easy-to-replace toner cartridges
• Oil-free color S-toners
Accessibility Options
• Voice Operation Kit
• Remote Operator’s Software Kit
• ADF Access Handle
• Braille Label Kit
Finisher-X1
* Letter
Advanced Finishing Options
Superior Paper-Handling
Three types of finishers
• Corner, double, saddle-stitch
• Extensive stacking capacity
Hole-punching
• Two or three holes
• Up to 5,000-sheet paper capacity
• 100-sheet Bypass Tray; Alignment Tray Option
• Up to 140 lb. Index media weights
• Up to 12" x 18" media sizes
Finisher-W1
Saddle
Finisher-W2
Puncher
Unit-AH1
Cassette
Feeding Unit-Z2
Plain
Pedestal-E1
Paper Deck-Y1
High Quality and Productivity
imageCHIP System Architecture
Uncompromising business performance
NEXT-GENERATION IMAGE PROCESSING
The Color imageRUNNER C4080 Series is powered by Canon’s
revolutionary imageCHIP system architecture. This not only
enables simultaneous copying, printing, scanning, sending,
and faxing, but it will change the way you think about using
color in your office.
DIGITAL DYNAMICS
Adding digital data to copies and prints is easy and powerful.
Create ad hoc watermarks, select preset stamps, add page and
copy set numbering, and/or date stamping to any output with
control over size, position, colors, and density. You can also
embed secure watermarks that appear when copies are made
to help prevent security leaks of confidential information.
COMPLEX JOBS MADE SIMPLE
The Color imageRUNNER C4080 Series makes the production of
complicated documents manageable. Users can combine different
sets of documents into one with Job Block Combination. Each set
can be configured to run with unique settings, such as paper type,
finishing, color, and more, then reproduced or stored as a new
document in a Mail Box. From the desktop, individual or groups
of pages in documents can be configured with the Exceptional
Settings tab* in the print driver to control output settings, such
as media type, paper size, input tray, and finishing options.
Secure Watermark
BRILLIANT BUSINESS COLOR
For general office environments, the Color imageRUNNER C4080
Series efficiently tackles print tasks for Microsoft® Office applications. It supports Canon’s UFR II (Ultra Fast Rendering), PCL,
and XPS,** as well as an option for PostScript 3 emulation.
Original document with hidden text
and background color
Hidden text appears on copies
that are made
THE PERFECT FINISHING TOUCHES
The Color imageRUNNER C4080 Series offers professional
finishing options that collate, staple, hole-punch, or saddlestitch to create impressive documents efficiently. And with
Automatic Creep Correction, each page in your large booklets
will be perfectly positioned.
WIRELESS LAN CONNECTIVITY
With Canon’s new Wireless LAN option,*** the Color
imageRUNNER C4080 Series devices can use the latest in
wireless technology to connect to a Local Area Network.
Supported standards include 802.11g and 802.11b for up to
54 Mbps and 11 Mbps transmission speeds, respectively, and
compliance with WPA, WEP, and WEP2 security encryption.
Wireless LAN Kit
Saddle Finisher-W2
* Requires PS Printer Kit-N2 option.
** Please check with your Authorized Canon Dealer for availability.
*** Not supported with imagePASS-H1 or ColorPASS-GX200.
Universal Send
Superior Communication
Enhance your digital world with Color Universal Send
With Canon’s proprietary Universal Send technology, the Canon
Color imageRUNNER C4080 Series enables you to distribute
scanned documents to multiple network destinations—such as
e-mail and Internet fax addresses, local Mail Boxes, fax, network
folders, and document management systems—in one simple
operation. Quickly and easily send documents to user addresses
in a local Address Book, look up users from multiple LDAP
servers on your network, or manually enter a destination. When
Single Sign-On (SSO) or Simple Device Log-in (SDL) authentication modes are used, the time-saving feature enables you to send
documents to yourself in a single click.
Color Universal Send offers powerful options to master creation,
distribution, and archiving of your documents. Universal Send
PDF Advanced Features (standard on the “i” model) provide
additional functionality such as PDF High Compression, Trace
& Smooth PDF, and Searchable PDF modes.
PDF High Compression Mode
PDF HIGH COMPRESSION TECHNOLOGY
To reduce network bandwidth requirements when sending
color documents, Canon’s proprietary PDF High Compression
Mode can significantly reduce the size of PDF files. And with
Canon’s exclusive Trace & Smooth PDF feature, text in PDF files
can be converted to outlines for sharper edges and increased
readability. The outline data can also be manipulated in
Adobe Illustrator® to create elements for other documents.
Trace & Smooth PDF
Send Main Screen
CREATING SEARCHABLE PDF DOCUMENTS
After scanning for PDF creation, the text is then embedded
within the file for extraction or keyword searches with the
Searchable PDF feature. This allows you to easily scan and
convert scanned documents into your electronic workflow.
Internet-ready
Maximize the power of the Web
HIGH-VOLUME FAX CAPABILITY
The Color imageRUNNER C4080 Series supports the option
to add a single- or multi-line Super G3 fax module to further
extend the capabilities of Color Universal Send. Incoming
faxes can also be automatically routed to other devices,
destinations, or users with the Job Forwarding feature for
superior workflow management.
ADVANCED WORKGROUP COLLABORATION
The Color imageRUNNER C4080 Series includes internal Mail
Boxes for document storage and print-on-demand applications.
Documents can be combined and printed as a single job or sent
to multiple destinations in a variety of formats. For files that are
too large for e-mail or require a large distribution list, the URL
Send feature can e-mail a link to notify recipients that they can
remotely preview via PC and, if necessary, print from the device.
The Color imageRUNNER C4080 Series provides more ways
to share information with the world beyond your office than
ever before.
WEB BROWSING AND PRINTING
With the industry’s first Web Access Software option, you can
browse the Web or corporate intranets directly from the device’s
color touch-panel. The Web Access function enables you to print
Web pages or PDF files from the Internet or your network, even
when you don’t have access to a computer.*
WEB-BASED DOCUMENT COLLABORATION
Color Universal Send supports the Web-based Distributed
Authoring and Versioning (WebDAV) protocol, enabling you to
securely send documents to a shared storage service over the
Internet. Collaborate on documents with others, whether they’re
in the office, on the road, or at home–for increased productivity.
DESKTOP INTEGRATION
The Color imageRUNNER C4080 Series is designed to work
seamlessly with Canon’s imageWARE Document Manager
Personal Version 4 as a total end-to-end document solution.
You can capture, archive, retrieve, and manipulate documents
within the imageRUNNER devices’ Mail Boxes right from your
desktop computer, seamlessly integrating your workspace
with the device.
Web Access Software
imageWARE Document Manager Personal Version 4
* When configured on the “Base” model, requires UFR II/PCL Printer Kit-N2 if printing Web pages;
requires PS Printer Kit-N2 on “Base” and “i” models if printing PDF files.
Powerful Imaging
Scalability
Flexible color productivity for your office
Solutions that evolve with your business
Canon offers flexible print controller options developed for the
Color imageRUNNER C4080 “Base” model. The ColorPASS-GX200
and imagePASS-H1 controllers increase productivity and color
quality for corporate and professional color environments.
As your business grows, the Color imageRUNNER C4080 Series
will continue to provide value with features and options designed
to extend your capabilities.
OPERATIONAL EFFICIENCY
Breeze through complex tasks and help to reduce operator
mistakes using the Workflow Composer option. Workflow
Composer enables users to configure one button to perform
multiple actions, such as copying, sending, and storing at the
device in a single step. For even greater convenience, workflow
buttons can also be created and edited from the desktop.
imagePASS-H1 CONTROLLER
The imagePASS-H1 print controller is an
embedded server for Color imageRUNNER
devices that is powered by a 1.5GHz Intel®
Celeron® M processor and 256MB of RAM.
Nearly six times faster than other leading
controllers with 700MHz processors,
the imagePASS-H1 is well-adapted to the
requirements of demanding workgroups
that require high productivity and accurate
color output.
imagePASS-H1
Workflow Composer Screen
EFI Utility
ColorPASS-GX200 CONTROLLER
The ColorPASS-GX200 print controller option for Color
imageRUNNER devices is a stand-alone server powered by
a cutting-edge system architecture, at the heart of which is
a 2.13GHz Intel Core™2 Duo multiprocessor CPU and 1GB
of RAM. Not only is the ColorPASS-GX200 controller built for
production-level speed, but it also features the ultimate in
industrial design to visually convey its multitasking prowess.
Control Panel
Access Management System Screen
User-Friendly
Simplicity for users
…and for administrators
For users, the Color imageRUNNER C4080 Series facilitates
operations with its easy-to-read full-color touch panel, interactive
help menus, insightful documentation and tutorials, and remote
operation capabilities. Streamlined administration is achieved
through powerful features for user access and privileges, and
device management.
SUPPORT TOOLS FOR OPERATORS
Whether you’re a beginner or an advanced user, the Color
imageRUNNER C4080 Series is easy to navigate. An easy
operation guide provides step-by-step instructions on how to
operate the device’s main functions. And the [Help] hard key on
the device provides instructions and explanations for operation.
User tutorials in Macromedia® Flash® format are also available
and can be distributed through your network or corporate
intranet for smooth deployment.
REMOTE UI (USER INTERFACE)
The Color imageRUNNER C4080 Series can be accessed through
a Web browser from any computer on the network. The Remote
UI utility provides the ability to check the status of the device,
track the progress of current jobs, monitor paper and toner
levels, administer the Mail Box, and edit the Address Book.
Instead of bulky manuals, device documentation is CD-based
and features Search tools to find answers quickly and easily.
FLEXIBLE USER ADMINISTRATION
Administrators have a choice of methods to control access
and privileges to the Color imageRUNNER C4080 Series devices.
Authentication schemes include Single Sign-On (SSO) using
network accounts, Simple Device Log-In (SDL), and Department
ID Mode with optional Control Card/Card Reader system. Using
the Access Management System, administrators have powerful
control over access to the Color imageRUNNER C4080 Series and
its functions for even greater security and cost control—at both
the user and group levels.
COMPREHENSIVE DEVICE MANAGEMENT
Canon’s imageWARE Enterprise Management Console (EMC)
is a Web-based utility that facilitates centralized management
of networked devices. Built upon an extensible framework, it
enables remote management of device settings, discovery of
new devices using automated tasks, and device error notifications
via e-mail. Administrators can also easily replicate settings
and Address Books across multiple devices through the Device
Information Delivery Function (DIDF), as well as push-print
drivers to PC-based desktop computers for rapid deployment.
Help Key
imageWARE Enterprise Management Console
Easy Operation Guide and Tutorial CD
Security and Accessibility
DEVICE ACCESS AND DATA SECURITY
The Color imageRUNNER C4080 Series includes features to help
guard against unauthorized access to the device and its data.
In addition to user-level authentication, it can also restrict
access from the network. The series also supports IPv6 for
enhanced network infrastructure management. To protect your
stored, scanned, and printed data, the HDD Data Erase option
permanently removes deleted files by overwriting them up to
three times. The HDD Data Encryption option provides additional
security by encrypting data before it’s written to the hard disk
drive and has achieved Common Criteria (CC) certification.
Document Security
Encrypted Secured Print
Watermark/Secure Watermark
Copy Set Numbering
Encrypted PDF
Digital Signature PDF
FAX Forwarding
FAX Destination Confirmation
Mail Server Security
POP Authentication before SMTP
SMTP Authentication
Network Security
MAC Address Filtering
IP Address Filtering
SSL Encryption
Network Application On/Off
USB Block
Destination Restriction
Internet
HDD Security
HDD Data Erase
HDD Data Encryption
HDD Format
Mail Box Password
Protection
Job Log Conceal
Device Access Security
Department ID (up to 1000 IDs)
User Authentication (SDL/SSO)
Access Management System
Control Card/Card Reader System
Smart Card Authentication
Device Management
DIDF (Device Information Delivery Function)
Key Switch Unit
Device Management and Security Overview
DOCUMENT SECURITY
The Universal Send PDF Security Feature Set option prevents
impersonation or interception of your documents. Digital Device
Signature Mode and the optional Digital User Signature Mode
provide verification of a document’s source. Additionally, you
can password-protect your documents with the Encrypted PDF
feature and securely print them over the network using the
Encrypted Secured Print feature.
Digital Signature PDF
Voice Operation Kit
Encrypted Secured Print Screen
ACCESSIBILITY
Canon offers solutions that go even further to ensure access for
every authorized user of the Color imageRUNNER C4080 Series
devices. The device can be controlled with spoken commands
using the Voice Operation Kit. The first Canon release of its kind
for the U.S. market, the kit provides speech synthesis and voice
recognition for individuals who are blind, or have poor vision or
mobility/dexterity impairments.
Specifications
Finisher-X1
MAIN UNIT
Type:
Copying Method:
Developing System:
Memory:
Hard Disk Drive:
Network Interface
Connections:
Other Interface:
First-Copy Time:
Warm-Up Time:
Copy/Print Speed
(B/W, Color):
Scan Resolution:
Copy Resolution:
Engine Resolution:
Halftone:
Paper Sources
Standard:
Optional:
Paper Sizes
Drawers:
Bypass:
Acceptable Paper Weight
Drawers:
Bypass:
Duplexing:
Finisher-W1
Color Digital Multifunction
Imaging System
Laser Dry Electrostatic Transfer
Dry Dual Component Developing
System
Standard 1GB RAM
Maximum 1.5GB RAM
80GB
10/100Base-TX (RJ-45)
USB 2.0 (Device), USB 2.0 (Host)
9.6 Seconds (Color)
6.7 Seconds (B/W)
4 Minutes and 30 Seconds After
Powering On
Up to 40/36 ppm (Letter)
600 dpi x 600 dpi
600 dpi x 600 dpi
1200 dpi x 1200 dpi
256 Gradations (Continuous-Tone)
Dual 550-Sheet Paper Cassettes
100-Sheet Stack Bypass
Dual 550-Sheet Paper Cassettes
2,700-Sheet Paper Deck
12" x 18", 11" x 17", Legal,
Letter, Letter-R, Statement-R,
Executive
12" x 18", 11" x 17", Legal,
Letter, Letter-R, Statement-R,
Executive, 12-5/8" x 17-11/16",
Irregular size (3-15/16" x 5-7/8"
to 12-7/8" x 18") and Envelopes
17 lb. Bond to 110 lb. Index
17 lb. Bond to 140 lb. Index
Standard Automatic Trayless
Duplexing (Executive to
12" x 18")
Image Reader:
Color Image Reader-F1 (Standard)
Acceptable Originals: Sheet, Book, 3-Dimensional
Objects (up to 4.4 lb.)
Max. Original Size:
11" x 17"
Document Feeding Method: Duplexing Automatic Document
Feeder (Standard)
Acceptable Originals: Statement to 11"x 17"
Paper Capacity:
100 Sheets
Acceptable Paper
Weight of Originals:
Simplex 11 to 32 lb. Bond
(42 to 128 g/m2)
Duplex 13 to 32 lb. Bond
(50 to 128 g/m2)
Scan Speed:
70 ipm (300 dpi)
51 ipm (600 dpi)
Dimensions (H x W x D):
35" x 24-3/8" x 33-1/2"
Weight:
Approximately 295 lb. (134kg)
Power Requirements:
120V AC, 60Hz, 15A
Power Consumption:
1,665W
Saddle
Finisher-W2
Copy Tray-N1
Document Tray-J1
Copy Tray-M1
Stack Bypass
Alignment Tray-B1
Puncher
Unit-AH1
Plug:
Toner (Estimated Yield):
Copy Features
Multiple Copies:
Max. Copy Reservation:
Color Mode:
Copy Exposure:
Magnification
Preset Reduction:
Preset Enlargement:
Zoom Mode:
NEMA 5-15P
Black: 26,000 Images @ 5%
Coverage
Color: 30,000 Images @ 5%
Coverage
1 to 999
10 Jobs
Auto Color, Full Color, Black,
Single Color, Two Colors
Automatic or Manual (9 Levels)
25%, 50%, 64%, 73%, 78%
121%, 129%, 200%, 400%
25% - 400% (1% Increments)
Mail Box Features
Max. Mail Boxes Supported: 100 User Inboxes, 1 Memory
RX Inbox, 50 Confidential Fax
Inboxes
Scan Feature
Network TWAIN Scan:
Network Scan Utility:
Plain
Pedestal-E1
Cassette
Feeding Unit-Z2
Standard
Color Network ScanGear
Color Universal Send Feature (Standard)
Color Mode:
Auto Color Select
(Full Color/Gray Scale)
Auto Color Select (Full Color, B/W)
Full Color, Grayscale, B/W
Address Book Capacity:
Max. 1,800 Destinations
(Includes 200 One-Touch Buttons)
Max. 5 LDAP Servers
Sending Methods:
E-mail, I-fax, SMB, File Server
(FTP, IPX, WebDAV), User Inbox,
Super G3 Fax (Optional)
Communication Protocol
File:
FTP (TCP/IP), SMB (TCP/IP),
NCP (IPX), WebDAV
E-mail/I-fax:
SMTP, POP3, I-fax (Simple, Full)
Data Format
File, E-mail:
TIFF, JPEG, PDF, PDF (Compact),*
PDF (Trace & Smooth)*, PDF (OCR),*
Encrypted PDF,** Digital Signature
PDF (Device,** User***)
I-fax:
B/W: TIFF (MH,MR, MMR)
Color: TIFF (Profile-C)
OPTIONAL ACCESSORIES
Super G3 Fax Board-V3/Super G3 Multi-Line Fax Board-H2
Applicable Line:
Public Switched Telephone
Network (PSTN)
Connection Lines:
One-Line (Super G3 Fax Board-V3),
Two-Lines (Super G3 Multi-Line
Fax Board-H2)
Sending/Original Size:
Statement to 11" x 17"
Recording/Printing Size:
Statement to 11" x 17"
Color UFR II/PCL Printer Kit-N2 (Standard for C4080i)
CPU:
Canon Dual Custom Processor
(Shared)
Memory:
1GB RAM (Std.), 1.5GB RAM (Max.)
(Shared)
Hard Disk Drive
80GB (Shared)
Supported PDL:
Optional PDL Support:
Printer Drivers
UFR II:
PCL 5c:
PCL 6:
XPS:
PS3 (Optional):
imagePASS-H1 v2.0
Connectable Device:
CPU:
System:
Memory:
Hard Disk Drive:
Interfaces (to LAN):
Supported PDL:
Utility Software:
Options:
ColorPASS-GX200
Connectable Device:
CPU:
System:
Memory:
Hard Disk Drive:
DVD-ROM:
Interfaces (to LAN):
Supported PDL:
Options:
Cassette Feeding Unit-Z2
Paper Sizes:
Paper Drawers Capacity:
Dimensions (H x W x D):
Paper Deck-Y1
Paper Size:
Paper Deck Capacity:
Dimensions (H x W x D):
Paper Deck-Y1
UFR II/PCL 5c/PCL 6
PostScript 3 Emulation
(PS Printer Kit-N1)
Windows® (Windows 2000/XP/
Server 2003, Windows Vista®)
Citrix MetaFrame
Macintosh® (OS 10.2.8 or Later)
Windows (Windows 98/Me/2000/
XP/Server 2003, Windows Vista)
Citrix MetaFrame
Windows (Windows 98/Me/2000/
XP/Server 2003, Windows Vista)
Citrix MetaFrame
Windows Vista
Windows (Windows 98/Me/2000/
XP/Server 2003, Windows Vista)
Citrix MetaFrame
Macintosh (OS 10.2.8 or Later)
Color imageRUNNER C4080
Celeron M 1.5GHz
System 8e Release 2
256MB (Std.), 512MB (Max.)
80GB
10/100/1000Base-T (RJ-45)
Adobe® PostScript® 3™, PCL 5c/6
Command WorkStation® for
Windows
Command WorkStation for Mac
256MB RAM, Secure Erase v1.0,
Hot Folders v2.0, Impose v2.7
Color imageRUNNER C4080
Intel® Core 2 Duo E6400, 2.13GHz
System 8 Release 2
1GB (Std.)
160GB
Standard
10/100/1000Base-T (RJ-45)
Adobe PostScript 3
GA Package, GA Premium,
Compose v2.0, Impose v2.7,
ACI Kit, Removable HDD
12" x 18", 11" x 17", Legal,
Letter, Letter-R, Statement-R,
Executive
550 Sheets x 2 Cassettes
[20 lb. Bond (80g/m2)]
12-1/4" x 24-3/8" x 27-3/4"
Letter
2,700 Sheets (20 lb. Bond
80g/m2)
17" x 12-3/4" x 23-1/4"
(Specifications are continued on back cover.)
Finisher-X1
Number of Trays:
Paper Size
Standard:
Non-Standard Size:
Weight:
Paper Capacity Per Tray:
Paper Capacity of
Staple Mode:
Max. Stapling Capacity
Letter, Executive:
11" x 17", Legal,
Letter-R:
Staple Mode:
Dimensions (H x W x D):
Lower Tray:
1 Tray
12" x 18", 11" x 17", Legal,
Letter, Letter-R, Statement-R,
Executive
(3-15/16" x 5-7/8" to
12-7/8" x 18")
17 lb. Bond to 140 lb. Index
1,000 Sheets (Letter, Statement-R,
Executive)
500 Sheets (12" x 18", 11" x 17",
Legal, Letter-R)
1,000 Sheets/30 Sets (Letter,
Executive) 500 Sheets/30 Sets
(11" x 17", Legal, Letter-R)
50 Sheets (17 lb. to 20 lb. Bond)
30 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (28 lb. Bond to 140 lb.
Index)
30 Sheets (17 lb. to 20 lb. Bond)
20 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (28 lb. Bond to 140 lb.
Index)
Corner (11" x 17", Legal, Letter,
Letter-R, Executive)
28-5/8" x 16-1/4" x 24"
Finisher-W1/Saddle Finisher-W2
Number of Trays:
3 Trays
Paper Size
Standard:
12" x 18", 11" x 17", Legal,
Letter, Letter-R, Statement-R,
Executive
Non-Standard Size:
(3-15/16" x 5-7/8" to
12-7/8" x 18")
Paper Weight:
17 lb. Bond to 140 lb. Index
Paper Capacity Per Tray
Non-Collating Tray:
250 Sheets (Letter, Statement-R,
Executive)
125 Sheets (12" x 18", 11" x 17",
Legal, Letter-R)
Upper Tray:
1,300 Sheets (Letter, Statement-R,
Executive)
650 Sheets (12" x 18", 11" x 17",
Legal, Letter-R)
2,450 Sheets (Letter)
1,700 Sheets (Statement-R,
Executive)
650 Sheets (12" x 18", 11" x 17",
Legal, Letter-R)
Paper Capacity of Staple Mode
Upper/Lower Tray:
1,300 Sheets/100 Sets (Letter,
Executive)
650 Sheets/50 Sets (11" x 17",
Legal, Letter-R, Staple with
different paper sizes)
Max. Stapling Capacity
Letter, Executive:
50 Sheets (17 lb. to 20 lb. Bond)
30 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (28 lb. Bond to 140 lb.
Index)
11" x 17", Legal,
Letter-R:
30 Sheets (17 lb. to 20 lb. Bond)
20 Sheets (20 lb. to 28 lb. Bond)
2 Sheets (28 lb. Bond to 140 lb.
Index)
Staple Mode:
Corner (11" x 17", Legal, Letter,
Letter-R, Executive)
Double (11" x 17", Legal, Letter,
Letter-R, Executive)
Saddle-Stitching†
Acceptable Paper Sizes: 12" x 18", 11" x 17", Legal,
Letter-R
Saddle Stitch Capacity: 15 Sheets (17 lb. to 20 lb. Bond)
10 Sheets (20 lb. to 28 lb. Bond)
Tray Capacity:
25 Sets (1 to 5 Sheets)
15 Sets (6 to 10 Sheets)
10 Sets (11 to 15 Sheets)
Folding:
V-Fold
Dimensions (H x W x D):
46-1/4" x 26-3/4" x 25-7/8"
Puncher Unit-AH1††
Paper Size:
11" x 17", Legal, Letter, Letter-R
Max. Paper Weight:
17 lb. Bond to 140 lb. Index
Punch Type:
3 Holes (Letter, 11" x 17")
2 Holes (Legal, Letter-R)
Punch Waste Tray Capacity: When approximately 3,000
Sheets of paper have been
punched
Dimensions (H x W x D):
32-3/4" x 4-1/4" x 24-1/2"
Microsoft, Windows, and Windows Vista are registered trademarks of Microsoft Corporation in the United States
and/or other countries. Macintosh is a trademark of Apple Inc. Command WorkStation is a registered trademark of
Electronics for Imaging, Inc. in the U.S. Patent and Trademark Office and/or certain other foreign jurisdictions.
Adobe, Acrobat, and PostScript are registered trademarks of Adobe Systems Incorporated in the United States
and/or other countries. Intel, Celeron, and Pentium are registered trademarks of Intel Corporation. CANON,
IMAGERUNNER, MEAP, and the GENUINE logo are registered trademarks of Canon Inc. in the United States and
may also be registered trademarks or trademarks in other countries. IMAGEWARE is a registered trademark
of Canon U.S.A., Inc. in the United States and is a trademark of Canon Inc. in certain countries. IMAGEANYWARE is
a trademark of Canon. All referenced product names and other marks are trademarks of their respective owners.
Specifications and availability subject to change without notice.
©2013 Canon U.S.A., Inc. All rights reserved.
Federal Law prohibits copying of certain documents. Violators may be
subject to penalties. We suggest that you check with your own legal counsel.
Canon U.S.A., Inc. and Canon Canada, Inc. intend to cooperate with Law
Enforcement Agencies in connection with claims of unauthorized copying.
1212RA-C4080-PDF-IH
Other Optional Accessories
• Encrypted Secured
Software-C1†††
Print
Printing Kit-A1†††
Access Software-E1L
• Universal Send PDF
Advanced Feature Set-A1LL
• Universal Send PDF Security
Feature Set-A1LL
• Digital User Signature PDF
Kit-A1
• Secure Watermark-A1
• Barcode
• Web
• Super
G3 Fax Board-V3
G3 Multi-Line
Fax Board-H2
• imageRUNNER 512MB
Expansion RAM-C1
• HDD Encryption Kit-B1
• HDD Erase Kit-A1
• Voice Guidance Kit-A2
• Voice Operation Kit-A1
• Super
• Remote
Operator’s Software
Kit-A2
• Plain Pedestal-E1
• Document Tray-J1
• Copy Tray-M1
• Copy Tray-N1
• Stack Bypass Alignment
Tray-B1
• Card Reader-D1
• Key Switch Unit-A2
• Braille Label Kit-A1
• ADF Access Handle-A1
• Stamp Unit-A1
• eCopy Suite
• imageWARE™ Suite
• Access Management System
Kit-A1
• Workflow Composer-B3
• Wireless Network Interface
Adapter NB-W1
Footnotes:
* When configured on C4080, requires Universal Send PDF
Advanced Feature Set-A1.
** When configured on the C4080, requires Universal Send
PDF Security Feature Set-A1.
*** Requires Digital User Signature Kit-A1.
Requires iR 512MB Expansion RAM-C1.
Check with your Authorized Canon Dealer for availability.
† Available with Saddle Finisher-W2 only.
†† Puncher Unit-AH1 can only be installed with either the
Finisher-W1 or Saddle Finisher-W2.
††† Requires UFR II/PCL Printer Kit-N2.
L
When configured on the C4080, requires UFR II/PCL
Printer Kit-N2 if printing Web pages; requires PS Printer
Kit-N1 on C4080/C4080i if printing PDF files.
LL
Standard on C4080i.
Voice Guidance Kit and Voice Operation Kit cannot be
installed together.
Not supported with imagePASS-H1 v2.0 or
ColorPASS-GX200.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Park
Melville, NY 11747
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
