Built by technicians, for technicians

Built by technicians, for technicians

Built by technicians, for technicians

NEW! FX Series Refrigerant Management Center ........................................................4-5

Recover, Recycle, Recharge Equipment ........................................................................6-8

Refrigerant Charging Scales ............................................................................................... 9

Manifolds and Gauges ......................................................................................................10

Charging Hoses .................................................................................................................11

Vacuum Pumps ........................................................................................................... 12-13

Electronic Leak Detectors ................................................................................................14

Specialty Meters ................................................................................................................15

Temperature and System Measurement .........................................................................16

Clutch Tool and Testing Kits .............................................................................................17

Adapter Kits........................................................................................................................18

Valve Core Tools and Couplers ........................................................................................18

Specialty Tools/Hand Tools ........................................................................................ 20-22

Worklights ...........................................................................................................................23

Brazing and Soldering .......................................................................................................24

A/C ExtenDye™ .......................................................................................................... 26-27

LeakGuard ™

................................................................................................................. 28-29

A/C Oils ......................................................................................................................... 30-31

UV Leak Detection Lights ........................................................................................... 32-33

Leak Detection Kits ...........................................................................................................35

Injection Kits .......................................................................................................................36

Dyes ....................................................................................................................................37

MIST In-Vehicle Air Quality ......................................................................................... 38-39

Coolant Service Solutions ................................................................................................40

VacuFill

.............................................................................................................................41

Fuel System ................................................................................................................. 43-44

Dual Fuel System ...............................................................................................................45

Fuel/Engine Chemicals ............................................................................................... 46-47

Diesel System .............................................................................................................. 48-49

Transmission System .................................................................................................. 50-51

Power Steering System ....................................................................................................52

Differential System .............................................................................................................52

Coolant System .................................................................................................................53

HVAC/Evaporator System ................................................................................................54

Brake System .....................................................................................................................55

EGR System .......................................................................................................................56

THE NEW

GOLD

STANDARD

In Refrigerant Management

7” Color

Touch-Screen Control

Patented

Oilless Compressor

Patented

Motor-Controlled

Ball Valves

1-2-5

Warranty

Visit us online at cpsproducts.com

CPS

®

R134A

MANAGEMENT CENTER

CPS

®

R1234YF

MANAGEMENT CENTER

CPS

®

R134A & R1234yf

MANAGEMENT CENTER

Visit us online at cpsproducts.com

Printer Included

3.5” Gauges

CPS Automotive proudly presents the latest in ease and endurance with its FX Series line of

Refrigerant Management Centers that quickly and efficiently recover, recycle, and recharge automotive AC systems.

7” Color Touch

Screen Control

2/3 Hp Oilless

Compressor

FEATURES

• 7” Color touch screen control panel

• 1-2-5 Warranty

• Dual handle bars/hose drapes

• Displays maximum load up to 220 lbs. (up to 100 kg)

• Foam-filled wheels

• Refrigerant Management System monitors filter life and refrigerant usage

• Patented unique, fast and complete refrigerant change over system

SPECIFICATIONS

• Comes standard with thermal printer

• Vehicle database included: Refrigerant and oil data

• 50 lb recovery tank (two with FX3030)

• Recovery rate = Up to 1 lb/min

• 6 CFM vacuum pump/ 50 micron rated

• 3.5” Gauges

• 10’ Power cord

• 115v, 850 W

• Supports multiple languages/UOM

• Quickly access all functions from the main screen

• ‘Car Health’ Mode enables printing a snap-shot of pressures before and after service

2/3 HP Oilless compressor

• Designed and built by CPS for high capacity commercial applications

• Cannot fail due to lack of, or too much, oil as oiled compressors do

Motor-controlled ball valves

• Opens wider for greater flow

• Will not get clogged by debris or sealants

Fully interactive touch-pad

Access database

Part No.

FX134A

FX1234W

without Ref ID

FX1234

FX3030

FX3030X1

LDA1000H

481500

481500yf

Certification

SAE J2788H

SAE J2843

Refrigerant

R-134a

R1234yf

H (in)

47.5

47.5

SPECIFICATIONS

Dimensions (inches)

W (in)

27.5

D (in) Weight (lb)

25 208

27.5

25 208

UPC

750377134012

750377123412

SAE J2843

SAE J3030

R1234yf

R-134a & R1234yf

47.5

60

27.5

27.5

25

25

208

240

FX Series Replacement Parts and Accessories

FX Series Maintenance Kit - Includes Filter, Vacuum Pump Oil and Coupler O-Rings

FX Series Recommended Accessories

SAE Pro-Set

®

electronic refrigerant leak detector

750377123405

750377303012

Spotgun Oil Injection Kit: injection system, R-134a hose, R-12 adapter, 8 oz Cartridge PAG 46 Oil

Spotgun Oil Injection Kit: injection system, R1234yf adapter, 8 oz cartridge PAG 46 HFO oil cartridge

Dual Handle Bars/

Hose Drapes

50 lb

Recovery

Tank

6 CFM

EZ-Fill & Drain™

Vacuum Pump

Foam-filled wheels

Quickly change unit of measurement

HTC

8415.83.90

8415.83.90

8415.83.90

8415.83.90

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

5

A/C Tools and

Equipment

Visit us online at cpsproducts.com

Visit us online at cpsproducts.com

CPS

®

RECYCLE,

RECHARGE

SYSTEM

• Patented flow control

• 2/3 HP oil less compressor

• 50 lb storage tank

• Compliant with SAE

Standards

FA1000

(R134a)

FA1234

(R1234yf)

CPS

®

RECYCLE,

RECHARGE

SYSTEM

• Semi-automatic

• Supports multiple refrigerants

• Includes ‘pumpdown’ feature (clears the machine when changing to another refrigerant to avoid cross contamination)

• 50 lb storage tank

AR2700M

CPS

®

SUPREME

Specially formulated with a proprietary chemistry to remove common system contaminants

AFMSF

CPS

®

A/C FLUSHING MACHINE

Simple 2-step operation with a single connection

• Powered by shop air

• Air purge

• Forward or reverse flush without changing hoses

• Easy to connect quick couplers fit evaporators, condensers and hose connections

• 8’ clear braided hoses

AFM100

AFMXC

AFMXCS

AFMXCSET

AFMXC4

AFMXCS2

AR27XCK

Replacement Parts and Accessories

3/8” SAE fitting w/2-step rubber cone

Flush universal clamp rubber seal 2-step (pack of 2)

Flush universal clamp set 3/8” fitting (pack of 2)

Flush universal clamp 1/4” SAE fitting w/rubber cone

Flush universal clamp small cone rubber seal (pack of 2)

AR2788 condenser accessory kit

AR27XHB115 115V Heater blanket

AR27XHB230 220V Heater blanket

AR27XVGK

ARX134T

Vacuum gauge mounting kit for use w/VG100 or

VG200

R-134a 1/2” ACME 50 lb recovery tank

ARX134TS

ARXC

ARXF

ARXF2

R-134a 1/2” ACME 50 lb recovery tank w/float switch

Nylon cover for AR series

AR212TR/300/400 replacement filter core

AR500/2700/2700M replacement filter

AR2788 / AR2788S filter for FA and FX series

ARXF5

CRX400T

CRXTOS3

FA1234X1

50 lb tank fits FA and FX series equipment

CR overfill sensor cord kit 230V (all models)

50 lb tank kit for additional refrigerants

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

7

PORTABLE CHARGING STATIONS

Everything you need to perform full system evacuation and charging in one compact, mobile unit.

4-Valve manifold R-134a

Large 2.5” (68mm) gauges

6’ Premium Hoses

Couplers

220 lb scale

2 CFM, single stage, dual voltage vacuum pump (VP2D)

CS12DMV4TP6Q

R-134a, R22, R404A

CS12DMV4SP6Q

R-134a

PORTABLE RECOVERY EQUIPMENT

• Complete with 30 lb DOT recovery tank and overflow protection

• Includes R-134a manifold set (#AMB134BUQ)

• Two cylinder oilless reciprocating compressor

• Includes oil separator and 17 cubic filter

• 115 V 50/60 Hz

• 850 W

• Cleanable 100 mesh screen filter integrated into suction port

• Motor thermally protected

• High pressure shut-off: 550 psig

TRA21

TRA21O

includes oil drain bottle

8

A/C STARTER KIT

Includes VPC2SU compact vacuum pump, aluminum manifold with 6 ft hoses and manual couplers, LS780 electronic leak detector and heavy duty canvas bag with rubber bottom.

KTBLM1

Visit us online at cpsproducts.com

A/C STARTER KIT

Automotive starter kit is designed to get you started in A/C repair. Includes a vacuum pump, a 3-in-1 can tap to use on 1 lb refrigerant cans and refrigerant manifold with triple o-ring seal valves and 68mm anti-flutter gauge. Has 6’ color-coded hoses with chrome manual couplers for years of service.

VP2SKIT

(VPC2SU vacuum pump, aluminum manifold)

VP6SKIT

(VP6 vacuum pump, brass manifold dual R-12/R-134a)

Visit us online at cpsproducts.com

CPS

®

COMPUTE-A-CHARGE

®

CHARGING AND RECOVERY SCALES

• The world’s most advanced strain gage bridge load cell technology

• Unparalleled accuracy, precision and reliability

• Calibrated to strict NIST standards

• Ergonomic hand held remote controls with large, high contrast wide angle

LCD displays

• Rugged cast aluminum platform and base assemblies for stability and long life

• Electronic and mechanical overload protected to withstand 150% of capacity

• Environmentally sealed and temperature compensated for reliable operation in extreme environments

• Automatic tare upon every start up and manual zero function

• Magnetic backing on hand held display for mounting to metal services or 360° swivel hanging hook

• Easy to read, fast response measurement on large LCD

• Visual and mechanical overload protection

• Durable protective transport case enables operation of scale in or out of enclosure

Rugged carrying case (included with all models)

Wireless

WIRELESS HIGH CAPACITY SCALE

220 lb (100kg) capacity / 0.25 oz (10g) resolution

Wireless remote, best-in-class accuracy and large capacity

Accommodates 30, 50, 90 and 125 lb cylinders

CC240RF

WIRELESS AND PROGRAMMABLE HIGH

CAPACITY SCALE

220 lb (100 kg) capacity / 0.25 oz (1g) resolution

Fully programmable in charging/recovery mode using the handheld remote

Accommodates 30, 50, 90 and 125 lb cylinders

Four operating modes: Weigh, Set, Handle, Hold

CC840RF

Automatic

Programmable

HIGH CAPACITY SCALE

220 lb (100 kg) capacity / 0.25 oz (1g) resolution

Programmable for automatic charging or recovery via integrated solenoid valve

Accommodates 30, 50, 90 and 125 lb cylinders

CC800A

HIGH CAPACITY SCALE

220 lb (100 kg) capacity / 0.25 oz

(10g) resolution

Our most versatile unit with bestin-class accuracy and enlarged capacity

Accommodates 30, 50, 90 and 125 lb cylinders

CC220

STANDARD SCALE

110 lb (25 kg) capacity / 0.20 oz

(5g) resolution

Accommodates 30 and 50 lb cylinders

CC110

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

9

10

BLACKMAX

®

Black And Chrome Manifold Series

• 2-Valve black anodized aluminum block body

• Triple Seal™ piston valves

• ¼” SAE 45° fittings

• 2 ½” (68mm) Class 1.6 accuracy R-134a gauges with internal silicone dampening cup for flutter-free operation

• Three premium 8’ Black & Chrome hose set

• Manual couplers

• Protective gauge boots

• Hanging hook

• Tin carrying case

MAID8QZ

PRO-SET

®

The Working Man’s Choice Manifold

Series

• 2-Valve aluminum block body

Triple Seal™ piston valves

½” ACME fittings

Large, easy-to-read 3 1/8” (80mm) class 1.0 accuracy R-134a gauges with internal silicone dampening cup for flutter-free operation

Three premium 6’ Pro-Set hoses

Manual couplers

Custom carrying bag

Protective gauge boots

Hanging hook

MT7I7A6Q

CPS

®

Brass Manifold Series

• 2-Valve brass body

2½” (68mm) R-134a gauges with internal silicone dampening cup for flutter-free operation

½” ACME fittings

Protective rubber gauge boot

Three premium 6’ hoses

Premium chrome manual couplers

Hanging hook

AM134BUQ

Part No.

MAID8QZ

Refrigerant Manifold Series

R-134a

BLACKMAX

®

Chrome Series

BLACKMAX

®

MB234

R-12/R-134a

MS134K

MS134Q

R-134a

R-134a

BLACKMAX ®

MV7SA6Q

R-134a

Pro-Set

®

The

Working Man’s

MA1234

R-12/R-134a

MTHFO134

Pro-Set

®

The

Choice Series

MT7I7A6Q

R-134a

AM134BUQ

MG134K

R-134a

CPS

R-12/R-134a CPS

®

®

Body Type Valve Type

Vortech ®

2-Valve brass body Face Seal Valves

Ball valve design

Fittings

¼” SAE

Gauges Hoses Notes

(3) 8ft Manual couplers

2½” Silicon dampened; 1.6 accuracy

(3) 5ft

(3) 5ft

Manual couplers

Snap couplers

Manual couplers

(3) 6ft Manual couplers

(3) 6ft with valves on end

R-134a couplers

(3) 6ft

Visit us online at cpsproducts.com

(3) 6ft

(3) 5ft

Manual couplers

Manual couplers

MGHFO134

MAIA6Q

R-134a

CPS

®

Piston

Manifold Series

2-Valve black anodized manifold

Ball valve design ¼” SAE

Triple Seal™ piston valves

½”

ACME

(3) 6ft Manual couplers

Visit us online at cpsproducts.com

Manifold and Gauge Replacement Parts and Accessories

MVXKC

BLACKMAX Series manifolds with Vortech valves Replacement valve handle (chrome/metal)

MXPKC

BLACKMAX Replacement Valve Handle (Chrome)

M2XHA

M2XRK

Pro-Set/ Vortech valve manifold bodies 2-way hose anchor bracket for

Diaphragm valve repair kit: services two valves

M4XHA

4-Way hose anchor bracket for Vortech valve manifolds

M4XRK

Diaphragm valve repair kit: services four valves

MTXK

Working Man Series manifolds replacement valve handle rubber over metal

MV2XRK

Vortech valve repair kit: services two valves

MVXK

Plastic replacement valve handle with color inserts for Vortech valves

MXBK

CPS Brass Manifold Series Replacement Valve Handle

MXC

Plastic Carrying Case for Manifolds

MXMH

MXPK

MXPV

MXPVO

Chrome Hanging Hook for all Manifolds

Plastic Replacement Valve Handle for Triple Seal Valves

Triple Seal Complete Piston Valve Assembly

Triple Seal piston valve seals only repair kit: services two valves

RGCH

RGI5H

RGIH

RGIHB

RGSH

RGI5L

RGIL

RGILB

RGSL

Gauge High R-12, 22, 502 2.5"/68mm, 1.6%, PSI/˚F w/Metal Case

Gauge High R-134a Only, 2.5" / 68mm, 1.6%, PSI / kgcm2,˚C / ˚F

& Chrome Metal Case

Gauge High R-134a Only, 2.5"/68mm, 1.6%, PSI/kgcm2, ˚C/˚F &

Metal Case

Gauge High R-134a Only, 2.5"/68mm, 1.6%, PSI/kgcm2, ˚C/˚F &

Metal Case & Boot

Gauge High R-134a Only, 3 1/8"/80mm, 1.6%, PSI/kgcm2,˚C/˚F &

Metal Case

Gauge Low R-134a Only, 2.5"/68mm, 1.6%, PSI/kgcm2, ˚C/˚F &

Chrome Metal Case

Gauge Low R-134a Only, 2.5"/68mm, 1.6%, PSI/kgcm2, ˚C/˚F &

Metal Case

Gauge Low R-134a Only, 2.5"/68mm, 1.6%, PSI/kgcm2,˚C/˚F &

Metal Case & Boot

Gauge Low R-134a Only, 3 1/8"/80mm, 1.6%, PSI/kgcm2,˚C/˚F &

Metal Case

RGX68BB

2.5" / 68mm Blue Protective Rubber Gauge Boot

RGX68RB

2.5" / 68mm Red Protective Rubber Gauge Boot

RGX80RB

3 1/8" / 80mm Red Protective Rubber Gauge Boot

RGX80BB

3 1/8" / 80mm Blue Protective Rubber Gauge Boot

RGX68L

2.5" / 68mm Gauge Lens

RGX80L

3 1/8" / 80mm Gauge Lens

¼”

SAE CHARGING HOSES

Size Features 3Pack Blue

3ft

HS3 HS3B

Red

HS3R

Yellow

HS3Y

(ABB) HS3A HS3BA HS3RA HS3YA

(BV) HS3E HS3BE HS3RE HS3YE

5ft

6ft

8ft

HS5 HS5R HS5Y

(ABB) HS5A HS5BA HS5RA HS5YA

(BV) HS5E HS5BE HS5RE HS5YE

(IBV) HS5L

HS6 HS6B HS6R HS6Y

(BV) HS6E HS6BE HS6RE HS6YE

(IBV) HS6L HS6BL HS6RL HS6YL

HS8 HS8B HS8R

(BV) HS8E HS8RE

HS8Y

HS8YE

(IBV) HS8L HS8BL HS8RL HS8YL

½

R-134a CHARGING HOSES

Size Features 3Pack Blue Red Yellow

HA3B HA3R HA3Y

3ft

(ABB) HA3A HA3BA HA3RA HA3YA

5ft

6ft

8ft

HA5

(ABB) *call

(IBV) *call HA5RL

HA6 HA6B HA6R

(ABB) HA6A

HA8 HA8B HA8R

HA5Y

HA5YA

HA6Y

HA6YA

HA8Y

Size

PREMIUM BLACK AND

CHROME CHARGING HOSES

Features Black w/chrome Fittings 1/2” x 1/2” HA8BKAZ

8ft

14mm x 1/2” HA8BKZ

(ABB) = Anti-Blowback

(BV) = Ball Valve

(IBV) = Inline Ball Valve

PREMIUM AUTOMOTIVE HOSES

• Nylon permeation barrier (Meets

SAE J2196)

• Leak-proof 8-sided crimp

• 800 Psi working pressure/ 4000 Psi burst pressure

• All-weather flexibility and strength

• Extra deep knurling on nuts for easy grip

• Adjustable valve core depressor

• Blow off grooves preventing spray back

HX14R

HX38G

HX3G

HXD

HXG

HXGA

HXGB

HXGD

HXGD2

HXKIT

HXTG

Charging Hose Replacement Parts and Accessories

R-134a 14MM Hose O-rings, Pack of 10

3/8” SAE Hose Gaskets, Pack of 10

3/16” Hose Gaskets, Pack of 10

1/4” SAE Hose Core Depressor, Pack of 10

1/4” SAE Replacement Hose Gaskets B426, Pack of 10

Replacement Gaskets for 1/4” SAE ABB Fittings, Pack of 6

1/4” SAE Replacement Hose Gaskets, Pack of 100

1/4” SAE Hose Gaskets & Core Depressors, Pack of 6 ea.

1/2” ACME, 5/16” (1/2”-20 UNF) Gaskets & Core Depressors, Pack of 6 ea.

Charging Hose Maintenance Kit

1/4” SAE Teflon Replacement Hose Gaskets, Pack of 10

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

11

12

DUAL STAGE VACUUM PUMPS

Your solution for obtaining the deepest ultimate vacuum, greatest range of horsepower and free air displacement. Gas ballast valve speeds up vacuum. Offered in single and dual voltages.

Model

Stage

Ultimate Vacuum

Dimensions (Inches)

Weight

Free Air Displacement

Motor Size (HP), RPM @ 50/60Hz

Voltage

Power Cord Connection to Pump

Operating Temperature Range

Pro-Set

®

Vacuum Pump Oil Capacity

Gas Ballast Valve

Intake Fittings

Warranty (Years)

VP6D VP10D

2

VP12D

10 Microns

12.2” x 5” x 9.6”

22.5 lb (10.2 kg)

6 CFM @ 60 Hz

(144 l/m @ 50 Hz)

14.9” x 5.7” x 10.6”

30.3 lb (13.7 kg)

10 CFM @ 60Hz

(240 l/m @ 50Hz)

25 Microns

14.9” x 5.7” x 10.6”

30.9 lb (14.0 kg)

12 CFM @ 60Hz

(288 l/m @ 50Hz)

1 /

2

HP (2880, 3440 RPM) 3 /

4

HP (2880, 3440 RPM)

110-120V Or 220-240V @ 50/60Hz

Universal IEC Socket & Voltage Selector Switch

1 HP (2880, 3440 RPM)

16 oz (470 ml)

32°F to 125°F (0°C to 52°C)

28 oz (830 ml)

Yes

SAE

1

/

4

”,

3

/

8

”,

1

/

2

2

27 oz (800 ml)

COMPACT DUAL OR SINGLE

STAGE VACUUM PUMPS

Features some the smallest, lightest and most compact aluminum housings in the industry.

Model

Stage

Ultimate Vacuum

Dimensions (Inches)

Weight

Free Air Displacement

Motor Size (HP), RPM @ 50/60Hz

Voltage

Power Cord Connection to Pump

Operating Temperature Range

Pro-Set

®

Vacuum Pump Oil Capacity

Gas Ballast Valve

Intake Fittings

Warranty (Years)

VPC2DU

2

15 Microns

VPC2SU

9 oz (250 ml)

No

SAE: 1

/

4

”, ACME: 1

/

2

1

1

100 Microns

VPC4SU

11.3” x 4.5” x 8.0”

12.1 lb (5.5 kg)

9.1” x 4.5” x 8.0”

9.3 lb (4.2 kg)

11.3” x 4.5” x 8.0”

11.0 lb (5 kg)

2 CFM @ 60Hz (48 l/m @ 50Hz)

1 /

4

HP (2880 , 3440 RPM) 1 /

115V @ 60 Hz

5

HP (2880, 3440 RPM)

Hardwired, Nema 115V Plug

1 /

4

HP (2880, 3440 RPM)

220-240V @ 50 Hz

Visit us online at cpsproducts.com

Universal IEC, Schuko Plug

32°F to 125°F (0°C to 52°C)

4 CFM @ 60 Hz (96 l/m @

50 Hz)

10 oz (300 ml)

Legend: VP= Vacuum Pump, VPS = Ignition Proof VP; 2,4,6,8,10,12 = CFM; D = Dual stage; A or E = 220-240VAC 50 Hz; J =

100VAC 50/60 Hz; U=115VAC 60Hz, No Consonant After “D” =Dual Voltage 110-120VAC or 220-240VAC 50/60Hz. Refrigerant

Classes: A1 (non-toxic, non-flammable); A2 (non-toxic, flammable); A3 (non-toxic, explosive)

Visit us online at cpsproducts.com

PUMPS

Dual voltage pumps with voltage selector switch.

Model

Stage

Ultimate Vacuum

Dimensions (Inches)

Weight

Free Air Displacement

Motor Size (HP), RPM @ 50/60Hz

Voltage

Power Cord Connection to Pump

Operating Temperature Range

Pro-Set

®

Vacuum Pump Oil Capacity

Gas Ballast Valve

Intake Fittings

Warranty (Years)

VP2S VP4S

1

50 Microns

VP6S

13.7 lb (6.2 kg)

2 CFM @ 60Hz (48 l/m @ 50Hz)

1

/

4

HP (1440 1720 RPM)

12.2” x 5” x 9.6”

15.0 lb (6.8 kg)

13.1” x 5.5” x 10”

18.3 lb (8.3 kg)

4 CFM @ 60Hz (96 l/m @ 50Hz)

1

/

3

(HP) 2880/3440

Dual (110-120V Or 220-240V @ 50/60Hz)

6 CFM @ 60 Hz (144 l/m @ 50 Hz)

1

/

2

HP (2880, 3440 RPM)

Universal IEC Socket, Voltage Selector Switch, Nema 15 Plug

32°F to 125°F (0°C to 52°C)

16 oz (470 ml)

No

SAE: 1 /

4

” & 3 /

8

”, ACME: 1 /

2

2

19 oz (540 ml)

Pro-Set

®

Premium Vacuum Pump Oil

Extremely high quality, severely hydro-treated vacuum pump oil compatible for use in pumps made by most manufacturers. It is strongly recommended that the vacuum pump oil be changed after each use to improve service and the life of the pump.

VPOQ

(32 oz)

VPOP

(16 oz)

COMPACT SINGLE STAGE

VACUUM PUMPS

Entry level pumps that provide affordable, reliable and dependable service.

Model

Stage

Ultimate Vacuum

Dimensions (Inches)

Weight

Free Air Displacement

Motor Size (HP), RPM @ 50/60Hz

Voltage

Power Cord Connection to Pump

Operating Temperature Range

Pro-Set

®

Vacuum Pump Oil Capacity

Gas Ballast Valve

Intake Fittings

Warranty (Years)

TAVPC48SU TAVPC96SU

1

100 Microns

8.75” x 4.1” x 9.25”

9.5 lbs (4.3 kg)

1.5 CFM @ 60 Hz (48 l/m @ 50 Hz)

1 /

5

HP (2880, 3440 RPM)

8.75” x 4.1” x 9.25”

11 lbs (5.0 kg)

3 CFM @ 60 Hz (96 l/m @ 50 Hz)

1 /

4

HP (2880, 3440 RPM)

115V

@ 50/60 Hz

Hardwired, Nema 115V Plug

32°F to 125°F (0°C to 52°C)

9 oz (250 ml) 14 oz (400 ml)

TAVP144SU

50 Microns

12.62” x 4.8” x 9.62”

14.8 lbs (6.7 kg)

5 CFM @ 60 Hz (144 l/m @ 50 Hz)

1 /

3

HP (2880, 3440 RPM)

No

SAE: 1

/

4

”. ACME: 1

/

2

1

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

13

14

PRO-SET

®

REFRIGERANT LEAK

Microprocessor controlled sensor electronics utilizing a multi channel signal detection method improves sensitivity while reducing false alarms

Software managed sensor rejuvenation mode initiated at start up ensures the highest level of sensitivity every use, for up to 500 hours of detecting leaks of less than .1 oz per year

Certified to meet SAE J2791 for R-134a, meets

US and International standards for automotive use for SAE J2913 for HFO-1234yf, and Euro

Standard EN 14624

Both visual and audible leak indicators

Patent Pending

LDA1000UV

(Comes with mini UV Clip-on Light)

LDA1000H

(Leak Detector only)

CLIP-ON UV LIGHT

LEAK-SEEKER

®

REFRIGERANT LEAK

DETECTOR

A rugged, three position slide switch is used to turn the instrument on and select either

LO or HI sensitivity ranges. Visual indication of the leak size is provided by a high intensity LED varying in brightness with the concentration of the refrigerant.

LS780C

Proprietary “Clip-On” chassis for attachment to electronic leak detectors, video borescopes and extension type devices that measure

¼” to 3/8” in diameter.

UVMINI

T e c h n o l o g y

New E_MOS ® sensor technology incorporates a proprietary pulse modulation design to increase both battery and sensor life.

LEAK-SEEKER

®

REFRIGERANT LEAK

DETECTOR

Combines the most advanced electronic circuitry with Ion-pump ® sensor technology creating a highly sensitive, accurate electronic refrigerant leak detector. Over 100 computer generated tones and a high intensity bar graph display quickly alerts the user to varying halogen concentrations. Patented, automatic calibration design eliminates the need for manual balance or tick rate adjustments.

LS790B

Leak Detector Replacement Parts and Accessories

LS2XF

Replacement sensor filters for the LDA1000 (pack of 10)

LS2XVF Replacement vapor filter sensing tip for LDA1000H

EMOS2 Replacement sensor for the LDA1000H

LSXBC

Replacement battery cover for LS780A, LS780B, LS790A, LS790B

LSXBMK Maintenance kit for LS780B, LS790B; Includes: (2) LSXS & (1) LSXSF

LSXC

Carrying case for LS780A, LS780B, LS790A & LS790B

LSXC3

Plastic carrying case for LS3000 & LS3000B

LSXE

Earphone for LS780A, LS780B, LS790A, LS790B

LSXMK Maintenance kit for LS780A, LS790A; Includes: (2) LSXS & (1) LSXVF

LSXS

Ion-pump sensor for LS780A, LS780B, LS790A & LS790B

LSXS3

Replacement CCD sensor for the LS3000 & LS3000B

LSXSF

Selective filter housing for LS780B & LS790B

LSXVF

Water vapor filter for LS780A & LS790A

GSXS4

Replacement sensor element for GS40

Visit us online at cpsproducts.com

The NITROKIT allows you to test a repair job without using refrigerant and venting to the atmosphere.

The NITROKIT is needed to precheck automotive A/C systems for leaks due to loose mechanical connections, hose leaks, evaporators and condensers.

This kit allows for re-introduction of refrigerant into an A/C system with confidence and preventing unnecessary leakage of refrigerant.

The kit includes a high quality

1-valve manifold with a 0-200 PSIG

3-1/8” gauge, a nitrogen regulator, a

6’ (180cm) premium red ¼” service hose, a 15’ yellow hose assembly with ¼” MPT x ¼” coupler and a high side automotive snap coupler.

NITROKIT

NITROKITG

(Includes NITROKIT with additional nitrogen regulator)

AMP-SEEKER

®

DIGITAL

CLAMP-ON METER

Multi-Functional AC/DC Clamp

Meter hosting an array of enhanced features such as the ability to capture true inrush measurements, non-contact voltage detection and data logging your output readings to a PC (USB connection cable included).

Versatile for testing AC/

DC voltage, AC/DC current, resistance and frequency

True RMS AC measurement

Max/Min value measurement

Audible continuity and diode test

Non-contact voltage detection

Integrated clamp light and LCD

• back-light

Auto zero key for DCA measurement

Auto/Manual range, auto power off

Secondary injection molded case, safety as per IEC1010

CAT.III 600V

AC750

METER

Professional grade sound level indicator designed to measure noise levels from 35 to 130 dB

The unit incorporates a large

LCD, peak and average response settings and A-C weighing for checking compliance with standard safety regulations.

Measures noise levels from 35 to

130 dB

Over and Under range indicator, peak and average response settings

Large LCD with maximum hold function

CE approved and includes carrying case

SM150

HAND-HELD

ELECTRONIC

COMBUSTIBLE GAS

DETECTOR

The GS40 is a self-contained, combustible gas leak detector designed to pinpoint gas leaks in the most demanding applications.

An efficient and sensitive gas sensor is combined with solid state circuitry which provides an audible alarm that increases in pitch as the concentration of the gas increases. A visual indication is also provided as well as provisions for an earphone for use in noisy environments.

GS40

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

15

THERMOMETER WITH

ADJUSTABLE EMISSIVITY

AND LASER SIGHT

High output laser sighting for visual reference to measurement area

Integrated probe port for use with any wired K-type accessory probe

Focused 12:1 distance to spot ratio for accuracy over extended distances

User adjustable emissivity settings for accurate measurement of varied surface materials

Unit displays Min/Max

Average temperature readings

Integrated LED worklight illuminates work area for safety

Measurement display in °F or

°C on a 4-digit back-lit LCD

TMINI12

DIGITAL POCKET

THERMOMETER

User-selectable temperature alarm

Temperature range -58° to

500°F / -50° to 260°C

Countdown timer

Min/Max °F/°C selectable

Highly accurate stainless steel 96mm puncture probe

4ft/122cm cord

Operates on a single AAA alkaline battery

25 hours of battery life

Low battery indicator

TM50

16

DIGITAL POCKET THERMOMETER

Digital pocket thermometer with stainless steel probe and pocket clip. Range: -58° to 302°F /

-50° to 150°C

TMDP

5” (127 mm) analog pocket thermometer with 1” dial and stainless steel probe and pocket clip

TMAP

(Fahrenheit scale 0 - 220˚F)

TMAPC

(Celsius scale -10 to 100˚C)

AUTOMOTIVE A/C CLUTCH TOOL KIT

• Comprehensive variety of A/C clutch hub pullers and installers for use with most GM, Ford, Chrysler and import vehicles

• Complete with CT499 spanner wrench

• All steel construction for durability

• Comes with a comprehensive manual outlining specs for oil gap, compressor ID and troubleshooting tips

CTK1300A

AUTOMOTIVE A/C CLUTCH TOOL KIT

• Complete kit for use with a variety of clutch hubs

• Hub pullers and installers can be used with Ford,

GM, Chrysler and most imports

• Covers Zexel, Sanden, all GM, Ford FS6, Hitachi and

Nippondenso 6P / 10P

CTK9100

Visit us online at cpsproducts.com

RADIATOR TEST KIT

Unit comes complete with adapters, pressure test pump, thermometer and case.

Has all adapters necessary to work with virtually 99% of all vehicles on the road domestic and foreign

Full set of adapters for heavy and light duty trucks

Color-coded adapters

TLRAD

(Adapters are color coded anodized aluminum)

TLRADN

(Adapters are color coded durable nylon)

UNIVERSAL AUTOMOTIVE

ORIFICE TUBE KIT

The kit can be used for most GM,

Ford, and import cycling clutch orifice tube systems

Includes a remover, extender body and damaged tube extractor

TLOTK

UNIVERSAL AUTOMOTIVE

O-RING KIT

Covers the most popular metric and SAE o-rings. A must for today’s busy a/c repair shop.

18 sizes with 180 o-rings.

HNBR and Neoprene

OEM Approved

TLRK

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

17

FLEX HOSE ADAPTER KIT

ADK1234

VACUUM ADAPTER KIT

ADK134

FITTINGS AND ADAPTERS

AB

1/4" SAE male x 1/4" SAE female ABB hose end fitting

AD12

Auto: 1/2" ACME F x Low-Side R-134a

AD14

AD41

AD48

AD48L

14mm male x 1/4" SAE male (Automotive adapter)

125 lb Tank Adapter 3/4"-14 x 1/4" SAE male

1/4" SAE female x 1/2" ACME male adapter

1/4" SAE female x 1/2" ACME left hand male

AD81

AD84

AD84L

AD88L

125 lb tank adapter - 3/4" X 1/2" ACME male

1/4" SAE male x 1/2" ACME F adapter

1/4" SAE male x 1/2" ACME Left hand female HFO tank adapter

1/2" ACME male x 1/2" ACME Left hand female HFO tank adapter

AVC134H R-134a High Side Service Port Caps, Pack of 10

AVC134L

R-134a Low Side Service Port Caps, Pack of 10

AVS1

Valve Cores, pack of 10

BV12

BVXH

1/2" ACME male x 1/2" ACME female straight ball valve

BV Handle with red, blue & yellow inserts

AD41 AB AD12 AD14 AD48

AD81 AD84 AD84L AD88L BV12

AVS1 BVXH AVC134H

Visit us online at cpsproducts.com

18

POCKET VALVE CORE

TOOL

Comes with four spare cores

TLVC1

DUAL VALVE CORE

REMOVER AND INSTALLER

(1/4” SAE Valves and Auto

R-134a Valves)

TLVC2

VALVE CORE REMOVER

AND INSTALLER

R-134a 8/10mm

TLVC810

Visit us online at cpsproducts.com

R-12/R-134A VALVE CORE

AND ORIFICE KIT

The TLK134 is the most complete tool kit on the market for valve core and orifice tube service. Includes an easy to find application chart.

TLK134

R-134A VALVE CORE REMOVER

AND INSTALLER

Fits “high” and ‘low”service with standard size valve cores

Built-in ball valve retains charge and allows access to A/C system

Excellent for replacing valve cores without discharging the system and for speedy recovery and recharging

TLVC134

4-WAY SAE VALVE CORE /

THREAD CHASER

1/4” and 3/16”

TLVC4

TLXVC

(Rebuild kit for TLVC4)

R-134a premium manual coupler set

14mm fittings

Six latching balls provide superior alignment

14mm female thread

QC134SET

QCL134

QCL134

Both

Low Side

High Side

Manual coupler set with AD84L adapter fitting used to convert R-12/R-134a to

HFO1234YF

1/4”SAE male

Six latching balls provide superior alignment

QC123414SET

QCL123414

QCH123414

Both

Low Side

High Side

Manual coupler set with AD88L adapter fitting used to convert R-134a to

HFO1234YF

14mm female

Six latching balls provide superior alignment

QC1214SET

QCL1214MM

QCH1214MM

Low Side

High Side

HFO-1234YF manual coupler set

12mm female

Six latching balls provide superior alignment

QC1234SET

Both

QCL1214MM

Low Side

QCH1214MM

High Side

High and low side

O-Rings for Premium

Couplers QCH90/QCL90

QCXO

R-134a snap coupler set

14mm fittings

QC13490SET

QCL13490

QCH13490

Both

Low Side

High Side

1/2” Male x 1/2” female ABB hose end fitting

AB12

High and low side

O-Rings for Premium

Couplers QCH14/

QCL14

QCXR34

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

19

A/C FLUSH GUN W/REGULATOR AND

UNIVERSAL COUPLER AND BLOW GUN

Used for flushing components on or off the car.

Simple to use with shop air. Just fill the cylinder

• with flush solution

Works well on all condensers and evaporators

Comes complete with cylinder, hose and flush gun

TLFGRA

TLFG

(Regulator, universal coupler, cylinder, hose and flush gun)

(cylinder, hose and flush gun)

VACUUM GAUGE WITH DIGITAL LCD DISPLAY

Calibrated to strict NIST standards for best-in-class accuracy and reliability

Advanced sensor design with self-heated thermistor bridge and automatic temperature compensation

Field cleanable sensor designed to withstand 400 Psi of positive pressure

Continual digital readout of evacuation process on large, easy to read 5-digit LCD display

User selectable units: Microns, Torr, in/hg or mBar

VG200

20

R-134A REFILLABLE

EXPANDABLE SAE OIL DYE

INJECTOR

SAE oil and dye injector is designed to be installed on the low side of the manifold. The injector has a 2-ounce capacity and 1/2” ACME threads for easy installation.

TLJ4

Assembly as pictured above

TLJX4H

Replacement Oil Injector Hose for TLJ4

TLJXR

Oil Injector O-Ring R-12/R-134a

REFRACTOMETER

Antifreeze / Battery / Cleaning Fluids

Tester

This instrument is designed for testing the concentration of battery fluids, antifreeze liquids and cleaning fluids. The percentage indicator indicates the point of freezing for both propylene glycol and ethylene glycol. It can also be used for checking the strength of electrolyte solution in batteries.

TLREF

3-IN-1 SIDE CAN TAP VALVE

Can be used with both R-12, R-134a, and oil cans

Has both ¼” and ½” ACME tee fittings

Permanently attached swiveling inserts

Quick change between can sizes

TLCT1234

TLCTXG

(10 Replacement Gaskets for TLCT12 & TLCT34)

Visit us online at cpsproducts.com

SPRINGLOCK TOOL KIT

TL7238

(Includes all four)

TL7240

TL7241

TL7242

3/8” Fitting Springlock Tool (Red)

1/2” Fitting Springlock Tool (Blue)

5/8” Fitting Springlock Tool (Black)

3/4” Fitting Springlock Tool (Beige)

POCKET DEBURRING TOOL (WITH BLADE STORAGE)

For soft copper and aluminum tubing.

Remove burrs and surface defects from inner/outer straight and hole edges

TLDB

Plastic Handle De-Burring Tool

TLDBX

Replacement Blade for TLDB

TLDB2

Metal Pen Type De-Burring Tool

A/C ALUMINUM DISCONNECT TOOL KIT

Complete A/C and transmission line disconnect tool kit

• Features aluminum durable construction

• Sizes – ½”, 3/8”, 5/8”, ¾”

• For use with all vehicle makes and sizes

TL7881

SOLENOID VALVE TROUBLESHOOTING MAGNET

Designed to manually open solenoid valves by magnetically lifting the stem assembly and plunger. Ideal for trouble shooting/servicing both direct connected or pilot operated 2-way solenoid, 3-way reclaim or

4-way reversing valves.

TLMKC18

SIX-SIDED FIN

COMB

Repair bent fins with this universal 6-sided straightening tool

TLFC6

UNIVERSAL

METAL FIN COMB

TLFC1

FIN STRAIGHTENER

With protective rubber grip handle

TLFC2

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

21

TOOL ORGANIZER

TLBAG2

TOOL BELT TOOL

ORGANIZER

TLBAG3

SQUARE TOOL

ORGANIZER

TLBAG1

22

PINCH-OFF PLIERS

Tool locks onto tubing to prevent loss of refrigerant during service

Rounded jaws to avoid cutting tubing

Fast release mechanism

TLPO

WRENCH SET

Nickel plated

TLSWHM

TLSWT

Metric Hex Wrench Set

Torx Wrench Set

TELESCOPING

MIRROR

1 ¼” diameter

TLMIR1

SERVICE WRENCH

Metal construction with polished chrome finish. Made in USA

TLSWL

Service Wrench: 3/16”, 1/4”, 9/16”, 1/2”

TLSWS

Offset Service Wrench: 3/16”, 1/4”, 3/8”, 5/16”

Service Wrench: 3/16”, 1/4”, 3/8”, 5/16”

TELESCOPING

MIRROR

2 ¼” diameter

TLMIR2

Visit us online at cpsproducts.com

RECTANGULAR

TELESCOPING

MIRROR

3 ½” x 2”

TLMIR3

A difference you can clearly see.

Ordinary 30 LED

narrow coverage

short beam bluish color iview light

5x wider coverage

5x farther beam bright white color

All new “Single Strip” LED technology offers technicians a wider, brighter light. The iView emits over 330 lumens of light, the equivalent of a 75 watt incandescent, at a wide angle without any shadows or hotspots. Three hours of continuous battery life allows you to finish your job with the same bright light you started with.

• Wide angle lens

• Eliminates the hassle of repositioning your light

• No shadows or hotspots

• Comfortable grip and impact resistant housing

• Smart charger never overcharges, preserves battery life

• Emits over 330 lumens of brilliant white light (equivalent to a 75 watt incandescent bulb)

413310

Visit us online at cpsproducts.com

WORKLIGHT AUTOMOTIVE

See under the hood clearly with this ultra-bright

LED worklight. The retractable cords allows limitless mounting possibilities.

• Ultra-bright LED lamps

• Detachable stretch cord ends for flexible attachment options

• Rechargeable battery

• Shatterproof tube

TLWL132R

TLWL132R

TLW132R LED Worklight Replacement Parts and Accessories

Rechargeable underhood LED worklight automotive

TLXWL132BAR

TLXWL132CH110

TLXWL132CH12

TLXWL132CLIP

TLXWL53BAT

TLXWL53CH110

TLXWL53CH12

TLXWL53HOOK

Replacement expandable bar for the TLWL132R

110V wall charger for TLWL132R

12V battery charger for TLWL132R

Light holding clips for TLWL132R

Replacement battery pack for the TLWL53A

110V battery charger for the TLWL53A

12V battery charger for the TLWL53A

Replacement magnetic hook for the TLWL53A

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

23

AUTO-IGNITE POWER TORCH 3-HEAD

Adjustable flame control

For use with propylene (MAPPRO), MAPP and

• propane

CGA600 inlet connection

Reinforced plastic and stainless steel burn tube

Tips and storage case with space for two cylinders

BRHT2

AUTO-IGNITE HAND TORCH

(CAST ALUMINUM)

Adjustable flame control

For use with propylene (MAPPRO), MAPP and propane

CGA600 inlet connection

Cast aluminum and stainless steel burn tube

Flame lock button, precise flame adjustment

BRHT1

24

AUTO-IGNITE HAND TORCH

Adjustable flame control

For use with propylene (MAPPRO),

MAPP and propane

CGA600 inlet connection

Brass regulator, composite handle and stainless steel burn tube

New brass regulator and 5’ hose length

BRHT5

Visit us online at cpsproducts.com

AUTO-IGNITE SWIVEL HAND TORCH

Adjustable flame control

For use with propylene (MAPPRO), MAPP

• and propane

CGA600 inlet connection

Brass regulator and stainless steel burn tube

Torch tube swivels 360 degrees, operates in any position

BRHTS1A

NITROGEN REGULATOR

Enables pressure control of nitrogen tank for A/C pressure testing and transducer calibration

BRRN1

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

Visit us online at cpsproducts.com

BUILT BY

TECHNICIANS

FOR

TECHNICIANS

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

SMALL ADDITIVE PACKAGE.

BIG

DIFFERENCE.

SAME DOSE.

Do more with your dye.

Switch to A/C ExtenDye™ and see the difference!

Super-concentrated

UV dye detects leaks quickly, saving time and money

Advanced friction modifier improves friction coefficient by over 50% and fuel economy

Additional anti-wear chemistry to extend component life

Antioxidant stops the oxidation process, reducing acidity and prolonging oil life

Visit us online at uview.com

Check out our video to learn more here!

Visit us online at uview.com

Visit us online at uview.com

A/C EXTENDYE

Several years of engineering went into creating this all new dye. A/C ExtenDye™ has four unique features:

1. Super-concentrated UV dye detects leaks quickly, saving time and money. A/C

ExtenDye is proven to fluoresce brighter than the competition. And there’s no need to use more. Use the same quantity of A/C

ExtenDye per application as our Universal

A/C dye.

2. Friction modifier increases lubricity (less friction) of the compressor oil, improving efficiency

(friction coefficient) by over 50% and improving fuel economy.

3. Anti-wear additive creates a film that prevents contact between metal parts; reducing friction and heat, thereby extending component life. Effectively quiets noisy compressors.

4. Antioxidant stops the oxidation process, reduces acidity and prolongs oil life.

• SAE J2297 certified for use in

• R-134a and R-1234yf systems

• Hybrid safe

• Solvent-free

When combined, we refer to this exciting new additive package as QuietCool

Technology.

A/C EXTENDYE

CARTRIDGE

Works exclusively with the Spotgun

Jr.™ injection system

399020A

1 oz

1 oz Winged

399006A

0.25 oz

399006AEU

0.25 oz Winged

A/C EXTENDYE

CARTRIDGE

Works exclusively with the Spotgun™ injection system

499108A

A/C EXTENDYE

399020A

399006A

1 oz Bottle

0.25 oz Bottle

A/C EXTENDYE

BOTTLE

Exclusive new bottle design with accurate dosing chamber

499008A

Part# Description

Unit

Size

Std

Pack

A/C ExtenDye ®

499008A

A/C ExtenDye Bottle

B499024A A/C ExtenDye Bottle

B499012A A/C ExtenDye Bottle

499108A

8 oz

1 oz

0.25 oz 12

8 oz

6

6

399020A

399006A

A/C ExtenDye Cartridge

A/C ExtenDye Cartridges

6

4 x

1 oz 1

A/C ExtenDye Cartridge 0.25 oz 6

399020AEU A/C ExtenDye Cartridges Winged 4 x

1 oz 1

399006AEU A/C ExtenDye Cartridge Winged 0.25 oz 6

UPC

Unit (inches & lbs)

Length Width Height Weight

ITF-14 Master

Carton

Case (inches & lbs)

Length Width Height Weight

628604004486 3.75

1.75

6.00

0.62 16286044990106 10.50 4.20

6.50

4.03

628604005162 1.25

1.25

3.00

0.15 16286044990243 4.50

1.75

1.75

0.45

628604005148 1.00

1.00

1.75

0.10 16286044990120 4.50

2.75

3.00

0.12

628604004424 2.00

2.00

9.75

0.75 16286044991103 6.00

4.25 10.00 4.65

628604004448 4.75

1.75

4.75

0.45

NA

628604005100 1.00

1.00

2.00

0.10 16286043990077 6.50

2.20

1.20

0.25

628604004462 4.75

1.75

4.75

0.45

NA

628614005124 1.00

1.75

2.00

0.10 16286043990084 65.00 2.20

2.20

0.25

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

27

SAFELY AND PERMANENTLY

SEALS LEAKS

CONTAINS SUPERIOR A/C

DYE

THE FIRST SEALANT

CERTIFIED TO

MEET SAE J2670

Visit us online at uview.com

Visit us online at uview.com

Visit us online at uview.com

THE SEALANT THAT WORKS

EXCLUSIVELY WITH THE

BEST INJECTION METHOD—

THE SPOTGUN!

LEAKGUARD

PROFESSIONAL

A/C STOP LEAK

• LeakGuard is the first A/C stop leak to be certified to meet the SAE J2670

Standard

• LeakGuard is specifically formulated for slow leaks (up to 0.5mm/0.02”) that can occur over a 6–12 month period

• LeakGuard is endorsed by one of the largest U.S. service providers and used in every A/C service

• Used as a preventive maintenance,

LeakGuard will stay in the system as a high quality lubricant until such time that a leak occurs

• Safely seals leaks in both rubber and metal components

• LeakGuard is an oil based sealant that does not react to moisture and will not harden, crystallize or clog the A/C system

• Safe for use in all systems, and all recovery equipment

• Contains super concentrated UV dye to diagnose leaks and stop them

LeakGuard ™ (illustrated as yellow) seeks out even the smallest leaks and forms a permanent mechanical seal.

LEAKGUARD

Works exclusively with the

Spotgun Jr.™ injection system

480301

LEAKGUARD

Works exclusively with the

Spotgun™ injection system

480308

Part# Description

Unit

Size

LeakGuard™

480308

480300

480301

LeakGuard Cartridge

LeakGuard Injection Kit -

Spotgun Jr.

LeakGuard Cartridge

8 oz

2 x 1 oz

1 x .25 oz

1 oz

Std

Pack

6

1

4

1 oz

1 oz

4

1

A/C Sealants

480000

480200

A/C Stop Leak Plus with

UV Dye

A/C Treatment Cartridge with UV Dye

Replacement Parts

4 oz

1 oz

6

UPC

628604004424

628604004523

628604001577

628604001003

628604003564

628604001904

12 628604004066

Unit (inches & lbs)

Length Width Height Weight

2.00

13.75

1.00

1.00

6.75

3.25

1.00

2.00

8.25

1.00

1.00

4.00

2.75

1.00

9.75

2.13

4.00

4.00

1.50

5.25

4.00

ITF-14 Master

Carton

Case (inches & lbs)

Length Width Height Weight

0.75

16286044803086 6.00

1.50

N/A

0.15

16286044803017 4.75

0.15

0.40

0.50

0.10

N/A

16286044800009

16286044802003

4.75

N/A

8.75

7.75

4.25

10.00

4.65

1.50

1.50

7.00

4.50

4.75

4.75

6.00

2.20

0.40

0.40

3.10

1.30

98010385

R-12 Application Hose for the A/C Stop Leak (0.25” FFL)

98037169

A/C Charge Hose - Low side R-134a

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

29

built by technicians, for technicians

NEW! UVIEW PAG A/C OIL

• Our line of PAG oils is now available in bottles

• Available premixed with A/C ExtenDye ™ , which includes an additive package to extend component life, improve performance and reduce wear

• 46 and 100 viscosities available

488046PB

PAG 46

488046PBD

PAG 46 with A/C ExtenDye™

488100PB

PAG 100

488100PBD

PAG 100 with A/C ExtenDye™

EMERGING TECHNOLOGIES

Be ready for the new R1234yf systems with our specially formulated oil and adapters. Also, our hybrid oil is designed for electrically driven compressors. It is specially packaged to avoid moisture contamination, maintaining excellent resistivity.

Visit us online at uview.com

Visit us online at uview.com

Part# Description

Unit

Size

Std

Pack

UPC

Unit (inches & lbs)

Length Width Height Weight

ITF-14 Master

Carton

Case (inches & lbs)

Length Width Height Weight

A/C Oil Bottles

488046PB NEW! PAG 46 Oil Bottle 8 oz

8 oz

488100PB NEW!

PAG 100 Oil Bottle 8 oz 12

488100PBD

488016E

488016P

499019

NEW!

PAG 100 Oil Bottle with A/C ExtenDye

Universal Ester Oil with Dye and eBOOST

Universal PAG Oil with Dye and eBOOST eBOOST with A/C dye and

Universal Oil Bottle

8 oz

16 oz 12

16 oz 12

1 oz

12

6

A/C Oil Cartridges, for use with Spotgun

488046YF

488046OE

488046P

PAG 46 Oil Cartridge

1234yf

Double-End-Capped

Universal PAG OilCartridge

OEM approved

PAG 46 Oil Cartridge

8 oz

8 oz

8 oz

6

6

6

488100P

6

488104H

488108E

488125P

488150P

PAG 100 Oil Cartridge

Hybrid Ester Oil Cartridge

OEM approved

ESTER 100 Oil Cartridge

PAG 125 Oil Cartridge

Meets GM spec. #9985752

PAG 150 Oil Cartridge

8 oz

4 oz

8 oz

8 oz

8 oz

6

6

6

6

12

12

628604004844

628604004868

628604004882

628604004905

628604003700

628604003724

628604003625

628604004967

628604003403

628604000877

628604000884

628604003427

628604000587

628604000891

628604000907

1.91

1.91

1.91

1.91

2.25

2.25

1.00

1.75

1.91

1.91

1.91

1.91

2.25

2.25

1.00

1.75

6.60

6.60

6.60

6.60

8.25

8.25

3.00

9.75

0.63

16286044880476 8.25

0.63

16286044880483 8.25

0.63

16286044881015 8.25

0.63

16286044881022 8.25

0.70

16286044880490 6.00

6.50

7.75

8.00

6.50

7.75

8.00

6.50

7.75

8.00

6.50

7.75

8.00

1.25

16286044880162 7.75

10.00

9.00 15.30

1.25

16286044880168 7.75

10.00

9.00 15.30

0.10

16286044990199 4.50

3.25

4.25

2.80

0.65

10.00 4.40

1.75

1.75

1.75

4.75

1.75

1.75

1.75

1.75

9.75

0.70

16286044880490 6.00

4.25

10.00 4.40

1.75

1.75

9.75

9.75

0.70

16286044880469 6.00

0.70

16286044881008 6.00

4.25

10.00 4.40

4.25

10.00 4.40

2.00

11.00

0.45

16286044881046 12.00

4.25

12.50 3.35

1.75

9.75

0.70

16286044881084 6.00

4.25

10.00 4.50

1.75

1.75

9.75

9.75

0.70

16286044881251 6.00

0.70

16286044881503 6.00

4.25

10.00 4.50

4.25

10.00 4.50

SPOTGUN PAG A/C OIL

Today’s vehicles require precise amounts of oil. Spotgun™ oil cartridges utilize the Spotgun injection system to inject a precise measured amount of A/C Oil while eliminating moisture contamination in the oil.

Works exclusively with the Spotgun injection system

PAG 46

A/C OIL

488046YF

PAG 46

A/C OIL

488046P

PAG 100

A/C OIL

488100P

Hybrid vehicles air conditioning systems are different and require specific POE oil that is low in moisture and free of any crosscontamination with other oils.

488104H

100

488108E

PAG 125

488125P

PAG 150

488150P

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

31

NOT ALL UV

EQUAL

A/C systems are getting smaller, and leaks are harder to find. UView helps you find more leaks faster, saving you money!

What the lumens index does for visible lighting, the UV PoweRating™ Index does for the UV spectrum by quantifying light output that most effectively fluoresces UV dyes.

UV DETECTION LIGHTS

Part No.

Description Battery UPC

413025

413065

413075

41300

413001

415000

415001

413010

413020

UV Phazer NEO

UV Phazer BLACK

UV Phazer BLACK

Micro-Lite 12V/50W

(w/storage case)

Micro-Lite 12V/50W

Mega-Lite 2V/100W

(w/storage case)

Mega-Lite 2V/100W

LED-Lite (6 LEDs)

Pico-Lite

Rechargeable

Lithium-ion

Rechargeable

Lithium-ion

3 x AAA alkaline

12V (Vehicle)

12V (Vehicle)

90

120

120

NA

NA

628604003908

628604004004

628604004028

628604000068

628604000075

12V (Vehicle)

12V (Vehicle)

3 x AAA alkaline

3 x AAA alkaline

NA

NA

60

60

628604001423

628604001447

628604002581

628604002604

Replacement Parts and Accessories for UV Detection Lights

461102

461105

461107

461111

Mega-Lite 110V / 100W replacement bulb

Micro-Lite / Econo-Lite 12V / 50W replacement bulb

Mega-Lite replacement lens

Micro-Lite replacement lens

461201

Mega-Lite 12V / 100W replacement bulb

98006433

UV Phazer NEO lamp

98027045

3.7V Lithium Ion battery

98027303

Lithium Ion charger 3.7V with port (110V)

98027304

Lithium Ion charger 3.7V with port (220V-EU)

98006475

UV Phazer BLACK lamp (AAA)

98006465

UV Phazer BLACK lamp (Rechargeable)

98007540

Rubber retaining ring lens: Mega-Lite

98007560

Rubber retaining ring lens: Micro-Lite

98027240

MicroLED-Lite battery charger (120V)

Length

10.75

10.75

10.75

12.50

9.00

14

9.00

7.75

7.75

Visit us online at uview.com

Unit (inches & lbs)

Width Height

4.25

3.25

Weight

0.75

4.50

4.50

9.25

9.25

11

9

4.50

4.50

3.25

3.25

3.75

5.50

4

6

2.00

2.00

0.75

0.75

2.40

1.45

2.8

2

0.50

0.50

Visit us online at uview.com

Visit us online at uview.com

UV PHAZER

NEO

NEO™ finds leaks that others miss.

• High Output UV LED

• True UV: Fluoresces dyes brighter than blue LED lights

• Maintains steady power output throughout charge

• Adjustable lens focus allows focusing light intensity

• Rechargeable Lithium Ion battery: Years of trouble free battery life

• Compact design, perfect for use in tight areas

• Durable aluminum construction

413025

True UV Light

1

0.8

0.6

1.6

1.4

1.2

0.4

0.2

0

300 nm

UV LED

DYE

EXCITATION

SPECTRUM

BLUE LIGHT

400 nm

Wavelength (nm)

500 nm 600 nm

UV PHAZER

UV LEAK DETECTION LIGHT

Extreme Performance. Outstanding Value.

• Powerful, true UV LED illuminates up to 11X brighter

• 400nm wavelength fluoresces dyes brighter

• Provides more contrast than blue light, making leaks easier to identify

• Adjustable lens allows quick scans for larger leaks, or a concentration of light for hard-to-find, smaller leaks

• Compact housing allows for access into tight spaces

• Rugged aluminum construction stands up to years of heavy use

413065

(Rechargeable Li-Ion) pictured above

413075

(AAA Batteries) pictured at right

The

rechargeable version

413065

features a Lithium Ion battery, good for two hours of output, charge after charge. An all new charging port eliminates the need to remove the battery for charging.

A smart charger protects the battery from overcharging and extends battery life, for years of trouble free use. The AAA version

413075

is cost effective yet powerful, with two hours of output.

MICRO-LITE

50-WATT INSPECTION LIGHT

Compact and Powerful.

• The most popular 50-watt light. 70-degree angled head allows access into tight areas making leak detection easier

• Includes UV enhancing glasses

413001

413000

(w/storage case)

LED-LITE

(SIX LEDS)

Professional compact leak detection light with six LEDs to illuminate all UV leak detection dyes.

• Includes UV enhancing glasses

• 3 AA batteries included

413010

PICO-LITE

Professional compact leak detection light delivers big performance.

• Utilizing a 1-Watt Luxeon

®

, the latest in high intensity LED technology

• Compatible with all UV leak detection dyes

• Includes UV enhancing glasses

• 3 AA batteries included

413020

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

33

THE CLEANEST,

SIMPLEST

AND MOST

ACCURATE

SYSTEM

AVAILABLE.

No Contamination

Precise Injection

No Waste

34

Award

Winning

Injection

System

Spotgun

• The world’s most popular and professional injection method. Pull the trigger to inject a precise amount of dye into the A/C system and you’re done

• The most economical system per service

• Accurate dye delivery controls costs

• Cleanest delivery method available. No mess, no waste

Spotgun Jr.

“Single-Shot” System

• Professional injection system for those that need to manage their inventory

• Smaller dosage, as low as one cartridge per vehicle

Visit us online at uview.com

ECO-Twist

Outstanding Value.

• Economical injection system

• Perfect for advanced DIY users or low volume shops

Visit us online at uview.com

CHOOSING THE LEAK DETECTION KIT THAT’S RIGHT FOR YOU:

1

YOUR CHOICE OF

INJECTION SYSTEMS.

• The original Spotgun

is versatile and economical

• The Spotgun Jr. is perfect for controlling inventory through the use of single application cartridges

2

YOUR CHOICE OF CHEMISTRY

DEPENDING ON YOUR NEEDS.

• A/C ExtenDye

is formulated with super concentrated UV Dye, plus friction modifiers, anti wear additives and antioxidants.

• Also available with Universal A/C Dye

3

YOUR CHOICE OF UV

DETECTION LIGHT.

Not all UV lights are created equal!

• 12V Mega-Lite provide strong, reliable power any time

• UV Phazer ™

™ and Micro-Lite

BLACK ™

offers extreme performance and outstanding versatility

• LED-Lite

offers an economical UV light

• Pico-Lite ™ offers excellent value

2

1

LEAK DETECTION KITS

Everything you need to find leaks—fast!

• All kits come with the industry’s toughest and most durable UV enhancing glasses

• Storage case

• R-12 and R-134a adapters

3

Unit (inches & lbs)

Part No. Injection System Application UV Light Qnty/Size UPC

414500A

414565A

414565

415400

332005A

332010A

332220A

332005

332220

Spotgun

Spotgun Jr.

A/C ExtenDye

Universal A/C Dye

A/C ExtenDye

Universal A/C Dye

Micro-Lite

Mega-Lite

Pico-Lite

Pico-Lite

Pico-Lite

8 oz / 240 mL

UV Phazer BLACK (Rechargeable) 8 oz / 240 mL

UV Phazer BLACK (Rechargeable) 8 oz / 240 mL

8 oz / 240 mL

UV Phazer Black (AAA Battery) 4 x 1 oz / 30mL

1 oz / 30mL

2 x 1 oz / 30mL

UV Phazer Black (AAA Battery) 4 x 1 oz / 30mL

2 x 1 oz / 30mL

628604004585

628604004608

628604004066

628604001492

628604004561

628604005247

628604005261

628604004042

628604002642

Length Width Height Weight

17.00

17.00

17.00

17.00

14.00

14.00

14.00

14.00

14.00

471111

471112

Spotgun Injection Gun Kit: (3) injection guns, (3) R-134a Hoses and

(1) Hanger Bracket

98007111 Spotgun Hanger Bracket

471535

471536

471539

UV Enhancing Glasses

R-134a Hose / Coupler: Twister & Spotgun injector systems

High Side adapter: R-134a

Spotgun Injection Gun

Replacement Parts and Accessories for Leak Detection Kits

471540

471546

471547

981470

1234yf Spotgun Hose Assembly with coupler

Spotgun Jr. R-134a Hose / Coupler

1234yf Spotgun Hose assembly with coupler

R-12 Aluminum adapter

982564

Service Stickers: strip of 32 service stickers

98000010 Spotgun Jr. Injection Gun

98011025 Spotgun Jr. Hose - High side

11

11

11

11

13

13

13

13

11

4

4

4

4

5

5

5

5

4

3.6

3.6

3.6

3.6

6.55

6.10

6.10

6.80

3.6

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

35

CHOOSING THE INJECTION KIT THAT’S RIGHT FOR YOU:

INJECTION KITS

Everything you need to service A/C systems —fast!

1

YOUR CHOICE OF

INJECTION SYSTEMS.

• The original Spotgun ™ is versatile and economical

• The Spotgun Jr. is perfect for controlling inventory through the use of single application cartridges

• The ECO-Twist ™ system is the perfect entry-level injection tool

2

YOUR CHOICE OF CHEMISTRY

DEPENDING ON YOUR NEEDS.

• A/C ExtenDye ™ is formulated with super concentrated UV Dye, plus friction modifiers, anti wear additives and antioxidants.

• Also available with Universal A/C Dye

• A/C Oil is a perfect companion to SAE

A/C recovery units

• LeakGuard ™ is formulated to safely and permanently stop small leaks

2

1

36

Part No.

Injection System Application Qnty/Size UPC

471500A

481500

481500yf

471500

331500A

330500A

331500

330500

480300

321500A

321500

480310EU

321400H

Spotgun

Spotgun Jr.

ECO-Twist

A/C ExtenDye

PAG 46 A/C Oil

PAG 46 HFO A/C Oil

Universal A/C Dye

A/C ExtenDye

A/C ExtenDye

Universal A/C Dye

Universal A/C Dye

LeakGuard

A/C ExtenDye

Universal A/C Dye

LeakGuard

Hybrid Oil cartridge

8 oz / 240 mL

8 oz / 240 mL

8 oz / 240 mL

8 oz / 240 mL

4 x 1 oz / 30mL

4 x 0.25 oz / 7.5mL

2 x 1 oz / 30mL

6 x 0.25 oz / 7.5mL

2 x 1 oz / 30mL

4 x 1 oz / 30mL

4 x 1 oz / 30mL

1 oz / 30mL

1 oz / 30mL

628604004523

628604005940

628604005964

628604000334

628604005223

628604005209

628604002369

628604000822

628604004523

628604005186

628604003823

628604003564

628604003885

Length

13.75

13.75

13.75

13.75

13.75

13.75

13.75

13.75

2.50

2.50

6.75

2.50

471111

(1) Hanger Bracket

98007111 Spotgun Hanger Bracket

471112

471535

471536

471539

UV Enhancing Glasses

R-134a Hose / Coupler: Twister & Spotgun injector systems

High Side adapter: R-134a

Spotgun Injection Gun

Replacement Parts and Accessories for Injection Kits

471540

471546

471547

981470

1234yf Spotgun Hose Assembly with coupler

Spotgun Jr. R-134a Hose / Coupler

1234yf Spotgun Hose assembly with coupler

R-12 Aluminum adapter

982564

Service Stickers: strip of 32 service stickers

98000010 Spotgun Jr. Injection Gun

98011025 Spotgun Jr. Hose - High side

Unit (inches & lbs)

Width

8.25

8.25

8.25

8.25

8.25

8.25

8.25

8.25

6.50

6.50

4.00

6.50

Height

2.13

2.13

2.13

2.13

2.13

2.13

2.13

2.13

2.13

9.25

9.25

1.50

9.25

Weight

2.86

2.86

2.86

2.86

1.70

1.50

1.70

1.50

1.70

0.85

0.85

0.40

0.85

Visit us online at uview.com

NEW!

CPS

®

VIVID A/C DYE

Provides excellent fluorescence and exceptional value!

• Highly fluorescent formula

• Co-solvent free chemistry

• Certified to meet SAE J2297 for use in R-134a and 1234yf systems

• Compatible with hybrid vehicles

UVIVD8

MULTI-PURPOSE DYE

• Pinpoint leaks in engine oil, transmission, hydraulic, power steering, gasoline, and diesel fuel systems

• Services eight vehicles

483208

B483206

RADIATOR COOLANT DYE

For use with regular (green) coolant

• Pinpoint leaks in cooling systems, including radiator, hoses, fittings, water pumps and head gaskets

483908

Part# Description UPC

Universal A/C Dye

UVIVD8

NEW! CPS Vivid A/C Dye 8 oz

399020

Universal A/C Dye Cartridges 4x 1 oz

6 628604006121

1 628604002383

6 x 0.25 oz 1 628604003960

4x 1 oz 1 628604003984

399006

Universal A/C Dye Cartridges 6 x 0.25 oz 1 628604001652

499385

499387

R-12 Automotive A/C Dye

Capsules

R-134a Automotive A/C Dye

Capsules

499005

Universal A/C Dye Cartridge

6 x 0.03 oz

6 x 0.06 oz

4 oz

1

1

6

628604001805

628604001829

628604001492

499008

Universal A/C Dye Bottle

499009

Universal A/C Dye wth eBOOST Bottle

499012

Universal A/C Dye Packets

8 oz

8 oz

12 x .0 25 oz

6 628604001652

6

1

628604002383

628604004448

B499012 Universal A/C Dye Bottles

B499024 Universal A/C Dye Bottles

6 x 0.25 oz 1 628604001607

6 x 1 oz 1 628604001614

499108

Universal A/C Dye Cartridge

499109

Universal A/C Dye Cartridge with eBOOST

8 oz

8 oz

6

6

628604003861

628604003946

499388

Universal A/C Dye Capsules 6 x 0.05 oz 1 628604001843

499389

Universal A/C Dye Capsules 6 x 0.05 oz 1 628604001867

499390

Universal A/C Dye Capsules 6 x 0.05 oz 1 628604001881

Multi-Purpose Dye

B483206 Multi-Purpose Dye Bottles

483208

Multi-Purpose Dye Bottle

483210

Multi-Purpose Dye for industrial use

Coolant Dye

6 x 1 oz

8 oz

1 gal

1

1

1

628604001638

628604000488

628604003106

B483906 Radiator Coolant Dye Bottles

483908

Radiator Coolant Dye Bottle

Dye Cleaner

481032

UV Dye Cleaner Spray bottle with nozzle

6 x 1 oz

8 oz

32 oz

6 628604001621

1 628604000518

6 628604001393

Unit (inches & lbs)

Length Width Height Weight

3.75

4.75

6.50

4.75

6.50

4.75

4.75

3.25

1.75

2.00

2.00

9.50

3.75

1.75

6.00

3.75

1.75

6.00

4.50

2.75

1.75

4.75

1.75

3.00

2.75

4.50

3.00

2.00

2.00

9.50

2.00

4.75

3.25

1.75

7.75

4.50

2.00

7.75

1.75

1.75

2.20

1.75

2.20

3.25

2.00

4.50

6.00

4.75

2.20

4.75

1.20

1.75

9.50

2.00

4.50

2.75

3.00

3.50

1.75

6.00

5.50

5.50

12.00

7.30

4.50

3.50

4.50

2.75

1.75

2.75

3.00

6.00

9.00

ITF-14 Master

Carton

Case (inches & lbs)

Length Width Height Weight

0.60 16286044990113 10.50 4.20

6.50

4.10

0.45

0.25

0.45

0.25

0.25

0.60

0.70

N/A

N/A

N/A

N/A

N/A

0.30

N/A

0.50 16286044990052 6.00

4.25 10.00 3.50

0.60 16286044990083 10.50 4.20

6.50

4.10

0.60 16286044990090 10.50 4.20

6.50

4.10

0.12

N/A

0.45

0.75

N/A

N/A

0.75 16286044991080 6.00

4.00 10.25 4.65

0.75 16286044991097 6.00

4.00 10.25 4.65

0.30

0.90

0.90

N/A

N/A

N/A

N/A

0.55 16286044832086 10.50 4.20

6.50

4.10

N/A

N/A

0.55 16286044839085 10.50 4.20

2.45 16286044810329 9.25

9.25

6.50

4.10

9.50 15.40

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

37

GIVE YOUR

CAR THE

FLU

SHOT

Treat mold, mildew and bacteria

MiST™ Nano-droplets get directly to the source of the problem

Safe, simple and effective profit generator that targets the health of the driver and occupants, not the vehicle

Start offering every one of your customers this inexpensive treatment…for their health!

Visit us online at uview.com

Visit us online at uview.com

Visit us online at uview.com

AWARD-WINNING COMPLETE IN-CAR SERVICE

MiST

penetrates the entire ventilation system and passenger compartment surfaces to restore interior air quality.

MiST is a safe, simple and effective profit generator that targets the health of the driver and occupants, not the vehicle.

MiST is the perfect preventive maintenance (PM) service because it can be run on any vehicle, leased or owned that comes into your shop, regardless of year, make, model or mileage.

MiST

Ultrasonic Cleaning Unit

• Portable 12V DC ultrasonic machine

• Nano-droplet delivery system of a specially formulated cleaning solution

• Fast service time

• Unattended operation

• Automatic shut-off upon completion

590160

MiST

Starter Pack

Includes:

• Mist Ultrasonic Cleaning Unit

• (2) Cases of 12 MiST Ultrasonic

Cleaning Solution

590160P

• 12 ft with accessory outlet

• Connects directly to vehicle’s battery

• For use when cigarette lighter does not work

590155

MiST

Car Interior

Disinfectant /

Sanitizer Formula

• The new EPA certified solution kills 99.99% of organisms in the car and features a new fresh lemon scent

• EPA#10324-85-84188

• DIN#02354314

590270

MiST

Cleaning

Solution

• MiST service for vehicle interiors and ventilation system

• Designed for exclusive use with

MiST Ultrasonic unit

(Single application)

590250

MiST

Auto

Remarketing

• Specially designed for used cars to treat mold, mildew and bacteria in the HVAC

System and cabin of a vehicle

• Designed for exclusive use with MiST II Ultrasonic unit

(Single application)

590260

MiST

Vent Air

Fresheners

• Clip-on vent. Fragrance leaves vehicle smelling clean and fresh

590235

590236

Summer Breeze

Spicy Apple

590237

Citrus

590238

Vanilla

590239

Clean Car

Part# Description

590160 MiST II Ultrasonic Cleaning Unit

590250 MiST Cleaning Solution

590260 MiST Auto Remarketing Formula

590235 Vent Clip: Summer Breeze Air Freshener

590236 Vent Clip: Spicy Apple Air Freshener

590237 Vent Clip: Citrus Air Freshener

590238 Vent Clip: Vanilla Air Freshener

590239 Vent Clip: Clean Car Air Freshener

NA

NA

NA

NA

NA

NA

Unit

Size

Std

Pack

UPC

Unit (inches & lbs)

Length Width Height Weight

ITF-14 Master

Carton

Case (inches & lbs)

Length Width Height Weight

NA 1 628604003182 16.00 8.25 10.50

5.80

NA

3.38 oz 12 628604002925 2.00

2.00

4.75

0.30 16286045902504 13.00

4.75

3.38 oz 12 628604006107 2.00

2.00

4.75

0.30 16286045902603 13.00

4.75

5.00

5.00

4.15

4.15

NA 12 628604003267 2.00

2.00

4.75

0.30 10628604592706 13.00

4.75

5.00

4.50

12

12

12

12

12

628604002840

628604002864

628604002888

628604002901

628604003342

1 628604002826

NA

NA

NA

NA

NA

NA

6.00

6.00

6.00

6.00

6.00

4.00

4.00

4.00

4.00

4.00

0.50

0.05

0.50

0.05

0.50

0.05

0.50

0.05

0.50

0.05

numbers after 11000)

98002340 Fan with Waterproof Connector

Replacement Parts and Accessories for MIST

98003170 Piezo Ultrasonic Transducer (serial numbers prior to 11000)

98002350 MiST fan repair kit (serial numbers prior to 11000)

98002351 MiST piezo repair kit (serial numbers prior to 11000)

99090560 MiST Point of Sale Easel

99090575 MiST Point of Sale Consumer Cards

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

39

AIRLIFT

KIT

Eliminate airlocks in vehicle cooling systems and refills in seconds. OEM approved worldwide!

Refills the entire cooling system including the heater core!

Eliminates time consuming bleeding and purging

Checks for leaks while under vacuum

Works on: cars, trucks, off road vehicles

Suitable for battery cooling systems in electric and hybrid vehicles

550000

AIRLIFT

II

An inexpensive solution to today’s complex problem of airlocks in vehicle cooling systems.

Refills entire cooling system in seconds, including the heater core!

Eliminates time consuming bleeding and purging

Checks for leaks while under vacuum

Push button valve eliminates the need to change hoses

Works on all cooling systems with “Fits-All” cone adapter

550500

40

AIRLIFT

II HD

Built to remove airlocks in the HD cooling system.

Eliminates the time consuming process of refilling and bleeding cooling systems by creating a vacuum that refills the entire system in seconds, including the heater core, EGR coolers, intercoolers, and aftercoolers

Equipped with a 90 degree angled gauge to accommodate tight fit applications and also checks for leaks while under vacuum. Includes a cone adapter to fit most systems with an extra-long 8’ hose for hard-toreach areas

OEM Approved by International Truck

550500HD

COMBUSTION LEAK TESTER

Dual-chamber for higher accuracy test

Dual-chamber design for higher accuracy to eliminate false readings

First chamber filters out alkaline particles that could result in a false indication of a combustion leak

Test results in the second chamber provide a true indication of a combustion leak

Works on gasoline and diesel engines

560000

550510

550530

550535

550537

Airlift Venturi Assembly

Airlift Fill Hose Assembly

Airlift Rubber adapters (4 sizes)

Airlift Universal Cone adapter

98037000 Airlift Vacuum Gauge Assembly

98037025 Airlift II Vacuum Gauge

98037030 Airlift Ball Valve

98037090 Airlift Quick Connect Coupler male

98037060 Airlift Quick Connect Coupler female

98037070 Airlift Coupler Seal

98037390 Airlift II Rubber Cone adapter

98038015 Airlift II Fill Hose Assembly

98037321 Squeeze Bulb

98037328 Tester

550535

Rubber adapters (4 sizes)

550537

570150

Universal Cone adapter

Rad Neck adapter

98037360 Rad Neck Rubber Stopper

98063000 Fill Tank Cover (30”/ 76.2cm)

98063100 Extraction Hose Assembly

98063150 Fill Tank Filter

98063300 8” Fill Tank Tube

98063450 O-ring - Fill Tank 7.841” OD X 0.177” th

98063451 O-ring - Fill Tank 7.880” OD X 0.197” th

98064600 Drain Valve

98064750 Base Plate

98064950 4” Wheel Assembly (each)

98066850 Vacuum Gauge 2.5”

98071200 Ring Stopper (each)

REPLACEMENT TESTER

FLUID BOTTLE

For Combustion Leak Tester

#560000 (uses +/- 2 oz of fluid per service)

Positive proof a leak is present:

If tester fluid changes from blue to yellow in gasoline engines

If tester fluid changes from blue to green in diesel engines

560500

Visit us online at uview.com

THE VACUFILL IS A PROVEN ENGINE TOOL

THAT REMOVES AND REFILLS COOLANT

LEAK TEST IN LESS TIME THAN TODAY’S

CONVENTIONAL METHODS.

Connects easily to all engine

cooling systems. Simply connect to radiator opening or reservoir tank. No need to cut heater hoses or disconnect upper radiator hoses

Test for leaks. Confirms system integrity, reduces chance of refilling a leaky system

Eliminates potential airlock problems. Refill cooling system using “Patented” vacuum technology. (Refills like OEM’s) Eliminates the need for burping and warm up

Refills in seconds. Quickly refill from used or new coolant reservoir. Accurately pre-mix a 50/50 mixture of coolant in three gallon holding reservoir

Safely store used coolant in large, 12 gallon holding reservoir

No electrical or moving parts

Operates completely on shop air

Easy to operate

Ideal for use with coolant flush chemicals

VACUFILL™

Connects easily to all engine cooling systems

Tests for leaks while under vacuum

Refills the entire system in seconds while eliminating airlocks

Large three gallon new-coolant fill tank

Large 12 gallon waste-coolant reservoir

570000

VACUFILL™ 570000X

with Waste Pump

The most economical coolant exchanger on the market now features an auxiliary pump for emptying the waste coolant reservoir.

570000X

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

41

Your partner in preventive maintenance™

DIFFERENTIAL

SERVICE

MACHINES I CHEMICALS I ADAPTERS

Visit us online at motorvac.com

Visit us online at motorvac.com

Visit us online at motorvac.com

CARBONCLEAN

®

1000

Everything you need to provide The Tune-Up for the 21st Century!

Complete, professional through-rail fuel system decarbonizing service

• Unique time saving adapter system makes connecting to the rail simple and fast

• Premixed detergent solution utilizes MotorVac proprietary CarbonClean chemistry

• Online application guide

500-0220

Power Cord 4.9 m (16 ft)

Adapters

Scan the QR code to view a listing of all adapters.

Power Supply

Hose

Fuel Pressure Gauge

Ship Weight

Ship Height

Ship Width

Ship Depth

Cabinet

Warranty

12 Volt DC Operation

3 m (10 ft) Output

Vehicle and System

20 lbs (8.6 kg)

41” (104 cm)

24” (61 cm)

19” (48 cm)

Rotomolded

One year

CARBONCLEAN

1000

After recognizing the need for fuel cleaning services, the MotorVac team looked at what is currently offered in the market today. Induction services are relatively quick and simple to perform, but fail to distribute product to all cylinders and do not provide a thorough cleaning. Fuel rail hook ups provide the most effective results, but in the past have been overlooked due to complexity of disabling the fuel pump and connecting to the fuel rail. The CarbonClean 1000 was designed to overcome these challenges while providing the thorough cleaning of a fuel rail and engine decarbonizing service, with the convenience of a simple hook up utilizing our online application guide and easy to use fuel adapter connect set. Once the service is near completion a warning buzzer is activated eliminating a check engine light at end of service. Furthermore, the CarbonClean 1000 offers fuel pump performance diagnostic capabilities as well as fuel system functionality.

CARBONCLEAN

®

MV5

Fuel System Cleaner and Engine

Decarbonizer

• Super concentrated detergent package rapidly cleans fuel system including injectors and intake valves

• Exclusive Hydrobond™

Technology uses proprietary chemistry to “steam clean” combustion chamber deposits

• Works exclusively with

CarbonClean® 1000

400-0050

INCLUDED ADAPTERS

063-1311 Spring lock disconnect tool

063-1360 Manifold block assembly

063-1361 Adapter 7/16” female thread 90 º enplated

063-1362 Adapter 5/16” female thread 90 º

063-1363 Adapter 1/4" quick disconnect male 6mm

063-1365 Adapter 1/4" quick disconnect female 6mm

063-1366 Adapter 5/16” female thread st. enplated

063-1367 Adapter 7/16” female thread straight

063-1368 Adapter 8mm quick connect male

063-1369 Adapter 10mm quick connect male

063-1370 Adapter 10mm quick connect female

063-1371 Adapter Ford 9/16” quick connect male

063-1372 Adapter Ford-9/16” quick connect female

063-1376 Adapter Nissan 11mm male

CARBONCLEAN

®

MV6

Fuel System Cleaner and Engine

Decarbonizer

• Super concentrated detergent package rapidly cleans fuel system including injectors and intake valves

• Exclusive Hydrobond™ Technology uses proprietary chemistry to “steam clean” combustion chamber deposits

• Works with any pressurized canister tool with fuel rail connectivity

400-0060

OPTIONAL ADAPTERS

063-1317 Male 14mm x 1.5

063-1318 Female 14mm x 1.5

063-1322 Male Banjo Bolt male 10 x 1.0

063-1332 Female Swivel male 12 x 1.5

063-1333 Male & Female swivel male 14 x 1.5

063-1335 Male & Female swivel male 16 x 1.5

063-1339 Honda Civic quick connect 6mm male

063-1345 Optional - Relay - Honda Fuel Pump Disable

063-1353 Optional fuel nut Honda

063-1354 GM S-bend 7/16" Female Thread

063-1373 Male banjo bolt male 12 x 1.25

063-1374 Male banjo bolt male 12 x 1.5

063-1375 Honda banjo 12mm

063-1377 Hyundai 15 mm male

063-1378 Hyundai 16 mm male

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

43

CARBONCLEAN

®

245

Professional Fuel System Service and Diagnostic Center

• Advanced electronic controls

• Unique safety features allow system to run unattended

• Fuel system diagnostic capabilities allow up to five different tests to be performed

• The CarbonClean 245 comes with the ICS Kit Part#200-8667

500-0245

Power supply

Power Cord

Timer

Fuel Pressure Gauge

Vacuum Gauge

Circuit Protection

Hoses

Hose

Fuel tank

Pump

Filter

Ship Weight

Ship Height

Ship Width

Ship Depth

Cabinet

12 volt DC Operating Range

10’ (3 m) 14 Gauge Heavy Duty Power Leads

0-60 Minutes, Adjustable

0-160 PSI Pressure (0-11 bar) (3.5” diameter)

0-30 in. hg. (-0.1/-1 bar) (2.5” diameter)

8 Amp Fast Blow

10’ Each Reinforced Output and Return

12’ (OD) Vacuum

5 qt Capacity

30 Gallon per Hour (113.55 L)

“Spin-on” (10 micron)

75 lbs. (34.01 kg)

41” (104.14 cm)

24” (60.96 cm)

19” (48.26 cm)

Rotomolded

Adapters

Scan the QR code to view a listing of all adapters.

44

CARBONCLEAN

®

MV3

Fuel System Cleaner Concentrate

• Proprietary gas/petrol detergent concentrate

• Eliminates soft carbon and other contaminants

• Contains no harmful alcohols such as methanol and hexanol which are known to damage seals

400-0020

(8 oz)

400-0126

(32 oz)

CARBONCLEAN

®

MV4

Intake System Cleaning Detergent

• Incorporates a foaming action to decarbonize air intake, plenum, throttle body, intake runners and intake valves

• Applied using the ICS kit or S-Tool canister

• Not harmful to seals

400-0030

ACCESSORIES

200-3025A Adapter kit-gas (standard) -revised

200-3026A Adapter kit-gas (deluxe) -revised

SINGLE ADAPTERS

060-0440 Clamp hose, medium 7/32”-5/8”

060-0450 Clamp hose, large 7/16”-25/32”

060-1000 Tube-M 1/4”

060-1100 Tube-M 5/16”

060-1200 Tube-M 3/8”

060-1300 Female 1/4”

060-1500 Female 3/8”

060-1700 Elbow flared X 5/16” MPT

060-1800 Elbow flared X 3/8” MPT

060-2501 Female quick disconnect

060-2800 Male quick disconnect 1/4’ Ford

060-3100 Inlet-M TBI & PFI

060-3105 Inlet-F TBI & PFI

060-3300 Outlet-TBI & PFI GM

060-3305 TBI & PFI F

060-3500 Male 3/8” Ford

060-3505 Female 3/8” Ford

060-3600 Male 1/2”

060-3605 Female 1/2” Ford

060-3901 Female quick disconnect 3/8” Ford

060-3902 Female quick disconnect1/4” Ford

060-4200 Male 5/16” Metal GM

060-4300 Male 3/8” Ford/GM

060-4501 Adapter, loop for single line fuel system

SINGLE ADAPTERS

INCLUDED W/DELUXE ADAPTER KIT # 200-3026A

060-1600 Banjo 12mm

060-1602 Elbow banjo 12mm

060-1900 Bolt banjo 12mm

060-1901 Washer banjo 12mm copper

060-1902 Nut cap banjo 12mm

060-2402 Banjo 14mm

060-2740 Bolt banjo 14mm

060-2741 Washer 14mm

060-2742 Cap nut 14 mm

060-3304 TBI & PFI-M

060-3400 TBI & PFI w/ 1800

060-3508 Valve Schrader Ford

060-3700 Valve Schrader GM

060-3900 Female quick disconnect 5/16” Ford

060-3901 Female quick disconnect 3/8” Ford

060-4300 Male 3/8” Ford/GM

OPTIONAL ADAPTERS

060-2300 14mm female

060-2310 Adapter female inv flr m14x1.5

060-2315 Adapter male bbl flr m14 x 1

060-2320 Adapter female out flr f14x1.5

060-2325 Adapter male inv flr m14x1.5

060-2600 16mm female

060-2700 Union-M 14mm x 16mm

060-3101 Adapter, gas male w/flg Nissan Quest A/S

060-3102 Adapter, gas female Nissan Quest A/S

060-4800 Adapter Mitsubishi male

060-4805 Adapter Mitsubishi female

Visit us online at motorvac.com

Adapters

Scan the QR code to view a listing of all adapters. Note: Carbonclean

Dual comes with a combination of

Carbonclean 245 and DieselTune adapters.

CARBONCLEAN

®

DUAL

Complete Fuel System Service for both Gasoline and Diesel

Engines

• The CarbonClean Dual services both gasoline and diesel engines to clean the entire fuel system. When used with fuel system cleaning detergents and the Intake Cleaning Kit,

CarbonClean Dual cleans the gasoline engine’s air plenum, throttle body, air bypass valve, injectors, valves, combustion chambers, oxygen sensor and catalytic converters without having to remove any engine components. When used with diesel detergent, CarbonClean Dual cleans the diesel fuel injectors, injector pump and combustion chambers

• Works on port-fuel, TBI, CIS, and carbureted systems

• Safely dissolves contaminants, gum and varnish deposits, capturing them in the built-in 10 micron filter

• Cleans injector screens, intake and exhaust valves, top of pistons, combustion chamber, oxygen sensor and catalytic converter

• Safely dissolves and removes soft carbon deposits and passes them through the exhaust

500-0352

Power Cord

Power Supply

New Fluid Capacity

Shipping Height

Shipping Width

Shipping Depth

9’ (2.7 m)

12 volt DC

2 x (2 L)

41” (104 cm)

24” (61 cm)

19” (48 cm)

CARBONCLEAN

®

MV3 and

DieselTune

MV3D

Fuel System Cleaner and Engine

Decarbonizer

• The CarbonClean Dual works with

MV3 gas/ petrol concentrate and the

MV3D diesel concentrate

400-0020

CarbonClean MV3

400-0010

DieselTune MV3D

200-3025A

Standard Adapters (Included)

200-3026A

Deluxe Adapters (Included)

200-8667

ICS Kit (Included)

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

45

46

YOUR PREVENTIVE

MAINTENANCE

PARTNER IN

GDi

SERVICE

CARBONCLEAN

®

GDI MAINTENANCE KIT

Keep GDI engines clean

• Quickly breaks down and removes all sludge, varnish and deposits, and holds them in suspension until they are drained

• Eliminates ethanol related fuel issues with our exclusive HydroBond™ Technology

• Reduces by up to 85% the oil vapors that contribute to intake valve deposits

400-1205

Part# Description UPC

Weight (lbs)

Per

Unit

Per

Unit (inches) Case (inches)

Case Length Width Height Length Width Height

12 16286044000201 628604006329 0.55

6.95

2.25

2.25

5.63

7.25

9.25

6.25

400-0020

400-0030

400-0050

400-0060

Concentrate

CarbonClean MV4 Intake

Cleaning Detergent

CarbonClean MV5

CarbonClean MV6

12 16286044000300 628604006367 0.55

6.95

6

6

16917340005262 697173000618

16917340005279 697173000625

1.25

1.05

7.90

6.45

2.25

2.25

5.63

7.25

9.25

2.75

2.75

8.50

8.00

5.75

2.75

2.70

7.00

8.00

5.50

6.25

9.00

7.75

400-0126

400-9900

400-9910

400-0270

400-1205

400-2001

400-2018

Part#

400-6220

400-1026

Concentrate

CarbonClean 2 Part Fuel

Kit

CarbonClean Complete

Fuel System Kit

Concentrated Fuel

Treatment

CarbonClean GDi

Maintenance Kit

CarbonClean Fuel System

Cleaner

Cleaner

Description

400-5000EU Engine Oil Cleaner

Engine Treatment

4

11

8

24

16286044001260 628604006343

16286044099007 628604004226

16286044099106 628604004226

16286044002700 628604005407

2.05

1.80

2.15

0.15

8.70

20.37

18.14

3.75

2.88

2.75

2.75

1.25

4.00

6.00

8.00

1.25

8.25

8.25

8.25

4.25

7.00

8.75

13.50 12.50

13.50 12.50

5.50

8.00

9.00

8.50

8.50

5.00

6 16286044012051 628604005384 3.00

18.75

4.38

7.00

8.50

14.00 10.50

9.75

12 16286044020018 628604004165 0.75

9.10

1.75

2.25

7.75

11.50

6.88

8.50

12 16286044020186 628604004189 0.35

4.85

2.13

2.13

5.25

9.50

7.00

6.75

Std

Pack

ITF-14 Master

Carton

UPC

Weight (lbs)

Per

Unit

Per

Unit (inches) Case (inches)

Case Length Width Height Length Width Height

12 16286044050008 628604005049 1.05

12.75

2.75

2.75

6.75 11.25

8.50

7.75

12 16286044062209 628604004202 0.90

10.91

1.75

2.25

7.75

11.50

6.88

8.50

6 16286044010262 628604006466 1.15

7.00

2.75

5.00

6.75

8.75

11.25

7.50

CARBONCLEAN

®

KIT

• Cleans entire fuel system, including intake valves and the combustion chamber

• Smooths rough idle and reduces hesitation

• Eliminates ethanol-related fuel issues

400-9910

CARBONCLEAN

®

FUEL SYSTEM CLEANER

Fuel System Cleaner and Engine

Decarbonizer

• Rapid one tank injector and fuel system clean up

• Eliminates ethanol-related fuel issues

• Enhances combustion by improving fuel atomization

• Catalytic converter and O

2

sensor safe

400-2001

CARBONCLEAN

®

Air Intake Cleaner

• Catalytic converter and O

2

sensor safe

• Cleans intake plenums and manifold runners

• Smooths rough idle

• Reduces hesitation

400-2018

Visit us online at motorvac.com

MOTORVAC

®

CONCENTRATED FUEL

TREATMENT

• Works with gas/petrol and diesel

• Eliminates water in the fuel

• Improves fuel atomization to increase power

400-0270

MOTORVAC

®

ENGINE OIL CLEANER

• MotorVac Engine Oil Cleaner effectively dissolves and suspends sludge and oil deposits so they can be safely and easily removed from the engine

• Formulated to help keep GDi engines clean

• Extra strength cleaner designed for extended oil change intervals

• Works with gas/petrol and diesel engines

400-5000

MOTORVAC

®

ENGINE TREATMENT

• MotorVac Engine Oil Treatment is designed to stabilize your motor oil and reduce intake valve deposits

• Formulated to help keep engine oil from separating

• Restores power and fuel economy

• Reduces sludge caused by ethanol blended fuel

400-6220

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

47

DieselTune

Professional Fuel System Service for Diesel Engines

DieselTune is a 2-line cleaning system that connects to the engine through

OEM specific adapters. DieselTune passes a concentrated mixture of MotorVac cleaning detergent and diesel fuel through the components of the fuel system while the engine is running. The system removes organic and inorganic fuel deposits that build up in fuel injectors, injection pumps and combustion chambers. Carbon, gum and varnish deposits in the entire upper engine are dissolved and removed during combustion, then passed through the exhaust.

• Variable pressure for diesel lift pumps up to 100psi or 6.8 bar

• Safely dissolves carbon deposits on diesel engines through exclusive soak mode

• Microprocessor-based controls for automatic operation

• Automatically maintains correct pressure and flow for worry-free operation

• Safe for use in all diesel engines, including heavy-duty truck applications

• Patented microprocessor for ease of use

• Lowers exhaust opacity and harmful emissions

• Automatically maintains correct pressure and flow for worry-free operation

• Exclusive soak mode for deep cleaning of the fuel delivery system

• Restores fuel economy and horsepower

• Extends fuel injector and fuel pump life

500-4006P

Power Supply

Power Leads

Timer

Hoses

12-24 Volt DC Operation

10’, 14 Gauge Heavy Duty

0-60 Minute Adjustable

10’ Each Nylon Reinforced Output and Return

Wheels

Fuel Tank Capacity

8”

4.6 Gallons

Shipping Weight 85 lbs. (100 lbs.)

Shipping Dimensions 41” x 24” x 19”

Cabinet

Warranty

Plastic Rotomolded

One Year Limited Warranty

Adapters

Scan the QR code to view a listing of all adapters.

48

ACCESSORIES

200-3021A Adapter kit, diesel (basic) - revised

200-3117 Adapter kit, diesel light truck

SINGLE ADAPTERS

Included w/Diesel Light Truck Kit # 200-3117

060-3100

060-3105

060-3300

060-3305

060-3500

060-3505

060-3600

060-3605

060-3900

060-3901

060-4200

060-4300

061-1550

062-2040

Inlet Male TBI & PFI

Inlet Female TBI & PFI

Outlet TBI & PFI GM

TBI & PFI F

Male 3/8” Ford

Female 3/8” Ford

Male 1/2”

Female 1/2” Ford

Female Quick Disconnect-5/16” Ford

Female Quick Disconnect-3/8” Ford

Male 5/16” metal GM

Male 3/8” Ford/GM

Open end-1/2”

Adapter-m 1/2” Chrysler, quick con

OPTIONAL ADAPTERS

060-2402

060-2740

060-2741

060-2742

060-3200

061-0001

061-0004

061-0005

061-0006

061-0008

061-0010

061-0016

061-0026

061-0505

061-0604

061-0605

061-1008

Banjo 14mm

Bolt-banjo 14mm

Washer 14mm

Cap nut 14 mm

Male quick disconnect 1/4”

Fuel siphon

45 flare male 1/4” #4

45 flare male 5/16” #5

45 flare male 3/8” #6

45 flare male 1/2” #8

45 flare male 5/8” #10

Adapter, female flare #6 JIC

Adapter, male flare #6 JIC

Coupler flare female #5 x #5

Coupler flare female #6 x #4

45 Flare male #6 x #5 45

Coupler flare female #10 x #8

061-1210

061-1212

061-3510

061-5500

061-5800

060-0440

060-0450

060-1000

060-1100

060-1200

060-1300

060-1400

060-1500

060-2501

060-3200

45 flare male #12 X #10

Coupler flare female #12 x #12

Open end 3/16”

Conn 1/2” NAB NY

Conn 5/8” NAB NY

Clamp hose, medium 7/32”-5/8”

Clamp hose, large 7/16”-25/32”

Tube male 1/4”

Tube male 5/16”

Tube male 3/8”

Female 1/4”

Female 5/16”

Female 3/8”

Female quick disconnect-loop w/quick discont from

Male quick disconnect-1/4”

Part# Description

400-3012

Diesel Engine Detergent

DieselTune™ Max

UPC

Weight (lbs)

12 16286044000102 628604006305 1.05

12.75

Unit (inches) Case (inches)

Length Width Height Length Width Height

2.75

2.75

6.75

11.25

8.50

7.75

12 16286044030123 628604005421 0.70

8.50

12 16286044030222 628604005445 0.70

8.50

12 16286044002809 628604006503 2.25

28.50

1.75

1.75

3.13

2.25

2.25

3.13

7.75

9.00

7.00

6.00

7.75

11.50

6.88

8.50

9.00

14.00 10.25 10.00

Visit us online at motorvac.com

Adapters

Scan the QR code to view the adapters. Adapters are listed on next page.

TRANSTECH

III+

Inline Automatic Transmission Fluid Exchange System

A complete professional inline automatic transmission fluid exchange system that is now even easier to use with our new automatic flow direction technology and our exclusive inline chemical treatment program. The TransTech III+ advanced electronic interface allows complete, “one touch” control. It even has a quick and easy “Drain

Pan” function for spill free transmission filter changes during ATF exchange. The TransTech III+ connects through transmission cooler lines and provides a clean, environmentally-friendly and systematic approach to servicing automatic transmissions. The unit will flush virtually all of the old transmission fluid and replace it with the new fluid while controlling the flow automatically with the engine running.

• Automatic Inline Exchange

Connect to a transmission cooler line and press one button— walk away until the service is complete

• Drain Pan Feature

Allows operator to drain transmission pan for a convenient and mess-free filter change

• Transmission Cooler Flush Feature

Allows operator to flush transmission cooler and cooler lines

• Patented Level Synchronization

Ensures the transmission cannot be under or overfilled

• Automatic Bypass

Ensures that transmission will not run out of fluid during the exchange process

500-1100B

Power Supply

Power Cord

Hose

Fluid Capacity

Shipping Weight

Shipping Dimensions

Cabinet

12 volt DC Operation

10 ft (3 m)

10 ft (3 m) Output

26 qts or 24.6L

87 lbs

21” x 26” x 45”

Black plastic

TRANSTECH

2-step inline kit

400-0137EU

ATF CLEANER AND

TRANSTECH

INLINE SERVICE KIT

For vehicles with no dipstick.

• New inline starter kit allows the cleaner and protectant to be introduced directly into the transmission cooler system

• Applies service chemicals in the most effective way

• Includes ATF Cleaner and Protectant Cartridges and

Spotgun

300-4110

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

49

Adapters

Scan the QR code to view a listing of all adapters.

TRANSTECH

IV+

Inline and Dipstick Automatic Transmission

Fluid Exchange System

The TransTech IV+ combines both Inline and Dipstick capabilities allowing for the two most common methods of ATF exchange from a single machine. With both Inline and dipstick services together in one cabinet, the TransTech IV+ occupies reduced floor space with minimal investment while providing service to a wider variety of vehicles.

Inline Exchange

This conventional ATF exchange method provides an effective transmission flush by connecting directly to the transmission cooler lines. New fluid flows through the transmission as old fluid is directed into the TransTech

IV+ waste tank in a 1-to-1 ratio.

Dipstick Exchange - The TransTech IV+ features a convenient Dipstick option that allows an effective ATF exchange through the transmission dipstick tube. This useful alternative is suitable when cooler lines are corroded or difficult to access.

• Automatic Inline Exchange - Connect to a transmission cooler line and press one button—walk away until the service is complete

• Dipstick Exchange - A convenient dipstick tube exchange requiring no tools or adapters

• Drain Pan Feature - Allows operator to drain transmission pan for a convenient and mess-free filter change

• Transmission Cooler Flush Feature - Allows operator to flush transmission cooler and cooler lines

• Patented Level Synchronization - Ensures the transmission cannot be under or overfilled

• Automatic Bypass - Ensures that transmission will not run out of fluid during the exchange process

• 26 Quart New Fluid Reservoir - Allows user to service large capacity transmissions

• High Volume Pump - For rapid and efficient service

500-1125B

Power Cord

Power Supply

New Fluid Capacity

Shipping Height

Shipping Width

Shipping Depth

Shipping Weight

10’ (3 m) 12 gauge

12 volt DC

26 Quart (24.6L)

41” (104 cm)

24” (61 cm)

19” (48 cm)

90lbs (40.8 kg)

50

MOTORVAC

®

UNIVERSAL ATF PROTECTANT

By using MotorVac Universal ATF Protectant, a full service facility can service virtually all vehicles by stocking only synthetic

DEXRON III and DEXRON VI.

• Eliminates the need to stock multiple ATF types

• Prolongs transmission life by reducing excessive heat and friction

• Ensures smoother shifting and eliminates transmission shudder

• Conditions and restores seals and O-rings to help eliminate leaks

400-1030AS

Visit us online at motorvac.com

TRANSTECH

TT2K

2-Step Cleaning and Conditioning Kit

• Add the service chemical in through the dipstick

STEP 1

TT1 ATF Cleaner:

Removes varnish, sludge and contaminants that build up in the transmission.

STEP 2

TT2 ATF Conditioner: Rejuvenates seals and reduces the possibility of leaks. The conditioner also reduces oxidation and heat-related breakdowns.

400-0137

Visit us online at motorvac.com

060-0450

060-1000

060-1100

060-1200

060-1300

060-1400

060-1500

060-1700

060-1800

060-3800

061-0605

062-0100

062-0120

062-0170

062-0180

062-1034

062-2060

080-0594

080-0595

CLAMP-HOSE, LARGE 7/16”-25/32”

Tube-M 1/4”

Tube-M 5/16”

Tube-M 3/8”

Female 1/4”

Female 5/16”

Female 3/8”

Elbow flared X 5/16” MPT

Elbow flared X 3/8” MPT

Flared 8MM Volvo

45 Flare M #6 X #5 45

5/16” Deep fitting male

3/8” Deep fitting flare male

90 1/4” NPT 5/16” INVT flare

90 1/4” NPT 3/8” Female INV flare

Adapter 90 º 3/8F flare/Deep Ford

Adapter, F 5/16” Deep thread, elbow

3/8” FPT X MQD

Coupler 1/4” MQD X 3/8” MPT, ZPS

060-2402

060-2600

060-2740

060-2741

060-2742

060-4200

060-4300

061-1550

062-2040

062-2066

062-4401

080-0592

Banjo 14mm

16Mm female

Bolt-banjo 14mm

Washer 14mm

Cap nut 14 mm

Male 5/16” metal GM

Male 3/8” Ford/GM

Open end 1/2”

Adapter, male 1/2” Chrysler, Quick Connect

Adapter, 90 º male 3/8” GM Quick Connect

Adapter, Ford Quick Disconnect 3/8”

Coupler-1/4” MQDX1/4” FPT, STL

ACCESSORIES

010-1052 Bottle 8oz clear, no cap

010-5602

011-5014

Tool caddy 4x4x16 plastic black

Adapter stand for Transtech II or III

200-3100A Adapter kit Transtech (standard) -revised

200-3101A Adapter kit Transtech (deluxe) -revised

200-3120

200-8099

200-8906

Adapter kit European transmissions

Assembly, direction flow adapter

Quick reference card Transtech

OPTIONAL ADAPTERS

060-2000 Adapter Trans GM 7/16” inverted flare male

060-2005

060-2010

060-2015

060-2020

060-2025

060-2030

060-2035

060-2040

060-2045

060-2050

060-2055

060-2060

060-2065

060-2070

060-2075

060-2080

060-2090

060-2095

060-2105

060-2110

060-2300

Adapter Trans GM 7/16” inverted flare female

Adapter Trans GM 1/2” inverted flare male

Adapter Trans GM 1/2” inverted flare female

Adapter Trans GM 1/2” hose

Adapter Trans VW M12 male

Adapter Trans VW M12 with D-ring

Adapter Trans Jeep 5/8-18 male

Adapter Trans Jeep 5/8-18 female

Adapter Trans Jeep SAE 45º flare male

Adapter Trans Jeep SAE 45º flare female

Adapter Trans Ford SAE 45 º flare female

Adapter Trans Ford SAE 45º flare male

Adapter Trans BMW 14mm male

Adapter Trans BMW M18 male

Adapter Trans BMW M18 female

Adapter Trans SAAB/Citroen/Lancia M14 male

Adapter Trans Fiat M12 male

Adapter Trans Audi M22 male

Adapter Trans Audi M22 female

Adapter Trans Opel Corsa male & female

14mm female

062-2010

062-2015

062-2020

062-2061

062-2062

062-2063

062-2064

060-2700

061-0008

061-0010

061-1008

062-0140

062-2000

062-2005

Union male 14mm X 16mm

45 flare M 1/2” #8

45 flare M 5/8” #10

COUPLER-flare F #10 X #8

#6-45 flared tube with nut

Adapter, Trans, BMW M12,M,O-RIN

Adapter, Trans, BMW M12,F,O-RIN

Adapter, Trans, BMW M10,M,M18NU

Adapter, Trans, BMW M10,F,O-RIN

Adapter, Trans, BMW 14mm

Adapter, Trans, Volvo male .587DI

Adapter, Trans, Volvo female 593I

Adapter, male “S” Series Volvo

Adapter, female “S” Series Volvo

062-2090

062-2095

062-3000

062-4400

065-1033

080-0593

200-0062

200-6100

200-6101

062-2065 Adapter, Saturn includes 080-0593/030-3101

062-2068A Adapter, Duramax female for all TT’S

062-2069

062-2070

Adapter, Duramax male for all TT’S

Adapter, female 2004 F350 diesel

062-2071

062-2072

062-2073

062-2074

062-2080

062-2085

Adapter, male 2004 F350 diesel

Cadillac CTS Adapter

Adapter, Mercedes Benz male

Adapter, Mercedes Benz female

Adapter, Trans PSA heat exchange small

Adapter, Trans Citroen XM heat exchanger

Adapter, Trans PSA heat exchange large

Adapter, Trans VAG male

Adapter, Trans VAG female

Adapter, Ford Quick Disconnect 1/2”

Adapter, drain hook for oil flush

Coupler,1/4” MQD X 1/4”MPT, ZP

Assy, transmission flush tool

Assy, press. Reducer regulator

High pressure adapter assembly

Part#

400-0137

Description

TransTech™ TT2K

Conditioning Kit

6

3

UPC

16286044001399 628604006381

16286044001376 628604004622

Weight (lbs) Unit (inches) Case (inches)

Per Unit Per Case Length Width Height Length Width Height

1.05

1.15

6.90

4.00

2.25

2.00

4.50

3.50

5.63

9.50

7.50

4.00

9.25

6.25

5.75 10.00

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

51

52

Part#

400-1045

Description

STEERCLEAN

1000

A Fast and Efficient Power Steering Exchange Machine

• Safe and effective preventive maintenance service to improve steering performance and extend component life

• The service can be performed safely and compatible with all domestic vehicles

500-7050

Power Cord

Power Supply

Circuit Protection

Hoses

Tanks

Pumps

Filter

Ship Weight

Ship Dimensions

Cabinet

Warranty

10’ (3m), 14 Gauge

12 Volt DC Operation

15 Amp Circuit Breaker

Two Service Hoses 9’, Waste Hose 5’ 8”

70 oz Capacity

One @ 1 GPM, One @ 1.8 GPM (Suction)

Internal Screen Mesh (Waste Tank)

85 lbs.

43” x 24” x 19”

Roto-molded

One Year Limited Warranty

6

STEERCLEAN

SCK1000

2-Step Cleaning and Conditioning Kit

STEP 1

SteerClean Power Steering Flush Detergent removes varnish and sludge deposits to increase fluid circulation and extend component life. Promotes a better fluid exchange.

STEP 2

SteerClean Power Steering Fluid Conditioner protects against wear and noise and helps keep the system clean after a service.

Conditions seals to prevent potential leaks.

400-1045

UPC

Weight (lbs) Unit (inches) Case (inches)

Per Unit Per Case Length Width Height Length Width Height

16286044010453 628604006442 1.10

7.25

2.25

4.50

5.63

11.50

6.88

8.50

DIFFERENTIAL

SERVICE

Diff-Vac

1000

Differential and Multi Fluid Exchange System

• Extract or exchange differential, engine oil, transmission, power steering, coolant and transfer case fluids

• Two 5 GPM diaphragm pumps allow for deep vacuum for extraction of high viscosity fluids regardless of temperature conditions

• Air operated – no need to waste time locating and connecting to battery terminals

• Two dedicated pumps – no cross contamination between used and new fluids

• Optional Drain Hose – does not limit the amount of fluid that can be recovered Visit us online at motorvac.com

• Easy to operate – does not require disconnection of lines or hoses

500-9025

Air Supply Requirements

Hose Lengths

New Fluid Tank Capacity

Waste Fluid Tank Capacity

Dimensions

Shipping Dimensions

Shipping Weight

80-150 psi

8 ft long service hoses

2.1 qts

4.2 qts

38.5” x 19.5” x 26.5”

40” x 23.5” x 20”

43 lb

Visit us online at motorvac.com

COOLANTCLEAN

III

WITH FLOW DIRECTION ADAPTER

Professional coolant exchange service in just minutes.

The CoolantClean III exchanges virtually all of the used coolant mixture in a vehicle’s cooling system in a few simple steps. The CoolantClean III coolant flush service can increase a shop’s profits by reducing the time it takes to do a complete fluid exchange to approximately 15 minutes. Simply by connecting to the vehicle’s upper radiator hose, the unit will flush virtually all of the old coolant and replace it with the new coolant

• Static or dynamic fluid exchange

• One switch, multi-function operation with “closed loop” mode at end of service

• Unique “vacuum switch” regulates system depressurization and fluid evacuation

• Complete flow synchronization maintains a 1-to-1 fluid ratio exchange

• Front panel controls all machine functions with pressure gauge and warning lights

• Industrial grade radiator hoses and adapters included to service most vehicles

• Dual pump operation (Air diaphragm pump pnuematic)

• Manual control ball valves

• Pressure is limited to 10 psi – if cap malfunctions, fluid will overflow into reservoir

500-5100P

Hose

Tank

Ship Weight

Ship Height

Ship Width

Ship Depth

Cabinet

Warranty

8 ft (2.43 m.) Output and Return with Quick Coupling

2 - 26 Quart Coolant Fluid: Clean and Waste

70 lbs.

41” (104.14 cm)

24” (60.96 cm)

19” (48.26 cm)

Rotomolded

One Year Limited Warranty

COOLANTCLEAN

CC2K

2-Step Cleaning and Conditioning kit.

STEP 1

CC5 removes rust, scale, and other contaminants.

STEP 2

CC6 contains rust and corrosion inhibitors which help to prevent deposits that can lead to overheating.

400-0138

6

UPC

16286044001383 628604006404

Weight (lbs) Unit (inches) Case (inches)

Per Unit Per Case Length Width Height Length Width Height

1.15

7.35

2.25

4.50

5.63

7.75

9.25

6.25

Part#

400-0138

Description

ACCESSORIES

010-1052

010-5602

200-3106

063-1034

070-2000

070-2001

070-2002

080-7000

080-7001

Bottle 8oz clear, no cap

Tool caddy 4x4x16 plastic black

Adapter kit-coolant clean (standard)

SINGLE ADAPTERS

Adapter, plastic 2-1/4x2-1/2x3 cool

Hose, 2 1/4” OD cut into 5” lengths o/c

Hose, 2 1/2” OD cut into 5” lengths o/c

Hose, 3” OD cut into 5” lengths o/c

Hose clamp 2 1/4” x 2 1/2”

Hose clamp 2 1/2” x 3 1/2”

SINGLE ADAPTERS

Included w/Basic Adapter Kit # 200-3106

010-5408

030-4404

060-1400

063-1030

063-1031

063-1032

063-1033

070-0120

070-0126

070-0127

070-0128

070-0129

080-6005

Clamp large size #36 CT-2100

Fitting step vacuum 1/4” X3 /8”

Female 5/16”

Adapter step 1-1/4” X1-1/2” plastic

Adapter plug 1-1/4” X1-1/2” plastic

Adapter step 1-3/4” x2.0” plastic

Adapter-plug 1-3/4” x2.0” plastic

Hose 3/8” ID 4” rubber hose

Hose 1-1/4” ID rubber NY braid black

Hose 1-1/2” ID rubber NY braid black

Hose 1- 3/4” rubber NY braid black

Hose 2” ID rubber NY braid black

Hose clamp 1-1/16” to 2”

OPTIONAL ADAPTERS

063-1038

063-1039

200-8803

BMW coolant adapter - male

Audi coolant adapter - male

Adapter kit-coolant (heavy duty)

Adapters

Scan the QR code to view a listing of all adapters.

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

53

CarClean

SYSTEM

HVAC and Interior Sanitizing System

• Sanitizes and disinfects the entire HVAC system and passenger cabin

• Restores in-vehicle air quality for a healthier driving environment

• Portable. Operates on 12 volt DC

500-0500

Power Supply 12 volt DC

Shipping Dimensions 13.8” x 8” x 5.5”

MIST

ULTRASONIC

• Cleans and restores the vehicle’s HVAC system and cabin

• Designed to work with the

CarClean™ System

400-0501

Part# Description

MIST

VENT CLIP

• Adds a fresh scent to the vehicle’s ventilation system and cabin

400-0525

UPC

Weight (lbs)

Per Unit

12 16971734005016 697173000489 0.30

3.65

12 16286044005251 628604006428 0.004

0.05

2.00

Unit (inches)

2.00

4.50

12.75

4.00

Case (inches)

Width Height

4.75

6.00

5.00

0.10

COOLSMOKE

®

The next generation of EVAP Leak Detection

• Pressure and vacuum leak diagnostics with smoke solution containing UV enhanced dye

• Instant smoke

• Two ways to spot the leak

• Does not use heat to create smoke

• Improve performance with UV Phazer™ Black™ (#413075)

500-0100

Required voltage

Shipping weight

Shipping dimensions

Power cord length

12 Volt DC

18.5 Lbs / 8 Kg

14” x 14” x 12”

10 Ft / 3M

UPC

Visit us online at motorvac.com

628604001348

54

COOLSMOKE

®

REPLACEMENT FLUID

Designed specifically for use with the MotorVac Cool

Smoke System

• CoolSmoke fluid with UV Dye pin-points leaks faster and more accurate than any other leak detection fluid

• Environmentally friendly

400-1054

Part# Description

400-1054 CoolSmoke Replacement Fluid with Dye 1

UPC

628604001287

Per Unit Length

0.45

1.25

Unit (inches)

Width

3.50

Height

6.00

Visit us online at motorvac.com

BrakeVac

II

Premium Brake Fluid Flush System

The BrakeVac II brake bleeder machine is a simple, user-friendly and efficient way to flush and bleed today’s high-tech brake systems. The BrakeVac II reduces the concerns associated with both air pressure and vacuum style brake bleeding. This system can complete a full brake system flush in 10 minutes with only one operator, thereby lowering labor costs and maximizing profits.

• Performs brake flush using pressure and vacuum simultaneously

• Vacuum pump to easily remove fluid from brake fluid reservoir

• Complete brake system flush in just 10 minutes

• Pressure and vacuum assist, ensuring quick operation

• Adjustable pressure regulator controls operating pressure

• 1 gallon fluid tank and removable waste tank for multiple services

• Drain switch to empty new fluid tank for changing to different brake fluids

• Extra-long 10 foot pressure hose with quick disconnect coupler assures full lift extension

• Easy to view tank allows for fast visual check of fluid in the reservoir

• Pressure and vacuum assist ensuring quick operation.

• Adjustable pressure regulator controls operating pressure

• Portable, operates on 12 volts DC

500-8100

Power Cord

Power Supply

Pressure Gauge

Circuit Protection

Hoses

Tanks

Pumps

Ship Weight

Shipping Dimesions

Cabinet

Warranty

16.5’

12 Volt DC

0-85 PSI / 0-6 Bar

15 AMP Circuit Breaker

11.5’

1 Gallon Clean and 1 Removable Waste Tank

Two 1 GPM

85 lbs.

41” x 24” x 19”

Rotomolded

One Year Limited Warranty

Adapters

Scan the QR code to view a listing of all adapters.

ACCESSORIES

100-8101 Quick reference cards

200-3118M Complete adapter kit

SINGLE ADAPTERS

Included w/ Basic Adapter kit # 200-3118M

066-6000

066-6002

066-6003

066-6004

066-6005

066-6006

066-6007

066-6008

066-6009

066-6010

066-6012

066-6013

OPTIONAL ADAPTERS

Two piece 3 tab with expandable o-rings (Chrysler)

Twist on with 3 tabs & expandable o-ring (Ford)

Twist on with 3 tabs & expandable o-ring (GM)

Threaded screw cap adapter (foreign)

Universal round adapter with chain tension hold down

Expandable o-ring adapter with hold down chain (Honda M/C 2.11” - 2.17”)

Expandable o-ring adapter with hold down chain (Honda M/C 2.91”)

Expandable o-ring with adjustable hold down tabs (Toyota M/C 1.69”)

Expandable o-ring with adjustable hold down tabs (Toyota M/C 2.75”)

Twin cylinders with rubber cones connected together with common hose

Twist on with 2 tabs & expandable o-ring (Ford)

Nissan Altima and Xterra adapter

066-0020

066-1100

066-6011

Adapter, universal 3 3/4” diameter for brake machine

Honda brake adapter

Durable plate adapter with 2 hold down chains (rect. Cast iron m/c)

200-3118M

STANDARD ADAPTERS (INCLUDED)

* BrakeVac II unit may also be purchased without adapters. Part number 500-8105. OEM specific adapters are available.

Call and speak to a specialist. | Toll Free: (877) 776-8486 | Customers outside the USA or Canada: (905) 615-8620

55

DieselTune

EGR CLEANING TOOL

For Diesel EGR System

Cleaning on intake and exhaust sides of EGR valve and cooler.

• Designed for on-vehicle cleaning of the EGR circuit

• Our EGR adapters are field tested and designed to deliver the most effective service

• Designed for many Diesel

EGR applications including

Cummins, Ford, GM, VW and more

500-0170

Shipping weight 10.8 lbs.

Case Dimensions 16½” x 10½” x 11¾” h

Tank Capacity

Max pressure

2L (67 fl oz)

6.8 Bar (100 psi)

EGR Tool operates on shop air.

PASSENGER AND LIGHT DUTY

069-3380 EGR Adapter for Ford 6.0L

069-3381 EGR Adapter for Ford 6.4L

069-3382 EGR Adapter for Duramax Cooler

069-3383 EGR Adapter for Mercedes/Jeep

069-3384 EGR Adapter for Duramax Turbo Boost

069-3385 EGR Manual Opener Cummins

069-3386 EGR Adapter for Cummins 6.7L

069-3387 EGR Adapter for Isuzu BMW

069-3388 EGR Adapter for Mercedes Sprinter 3.0L

069-3389 EGR S-Tool

069-3390 EGR Adapter for Ford 6.7L

069-3391 EGR Adapter for M14 x 1.5 Audi 3.0L

069-3392 EGR Adapter for M12 x 1.5

069-3393 EGR Adapter for M10 x 1.25

069-3394 EGR Adapter for M8 x 1.0

069-3395 EGR Hose Assembly with 1/8 NPT Fitting

069-3396 EGR Adapter for M16 x 1.5

069-3397 EGR Adapter for M18 x 1.5

069-3398 EGR Adapter for Mercedes 3.0L

069-3399 EGR Manifold

069-3502 EGR Adapter for Exhaust (1.75)

069-3503 EGR Adapter for Intake VW 1.6L

069-3504 EGR Adapter for Intake VW Passat 2.0L (2012)

069-3505 EGR Adapter for Intake Mercedes 3.0L (2012-2014)

069-3519 EGR Adapter for VW 1.9L TDI (2004-2006)

069-3520 EGR Adapter for VW 2.0L TDI (2009-1013)

069-3525 EGR Adapter for VW ALH 1.9L

069-3530 EGR Adapter for Mercedes Sprinter 2.1L

069-3535 EGR Adapter for Mercedes GLK 2.1L

HEAVY DUTY

069-3610 EGR Adapter for Cummins ISC 8.3L

069-3615 EGR Adapter for Cummins ISB 07 and 10

069-3620 EGR Adapter for Cummins ISX14

069-3625 EGR Adapter for Cummins ISX15

069-3630 EGR Adapter for Detroit DD13-DD15

069-3635 EGR Adapter for Detroit Series 60

069-3640 EGR Adapter for Mack MP7-11

069-3645 EGR Adapter for MaxxForce 7

069-3650 EGR Adapter for MaxxForce 9-13

069-3655 EGR Adapter for MaxxForce DT466

069-3665 EGR Adapter for Mercedes MBE4000 12.8L

069-3675 EGR Adapter for Mercedes MBE900-904 7.2L

069-3682 EGR Adapter for Isuzu (GM trucks) 4HK1-TC 5.2L

069-3685 EGR Adapter for Volvo D13

069-3690 EGR Adapter for Hino - J05D-TF 4.73L

56

DieselTune

EGR SYSTEM CLEANER

• Cleans the EGR circuit removing stubborn carbon deposits, eliminating the need for tear-down and part replacement

• Cleans variable geometry turbo chargers (VGTs) and vanes

• Lowers emissions and smooths rough idle

400-0280

Not available in Canada

DieselTune

COMPLETE

FUEL SUPPLEMENT

• Raises cetane number four to six points

• Improves cold weather starting

• Eliminates water using exclusive

HydroBond Technology

• Reduces DPF regeneration cycles

• Meets CEC F 098-08 DW10 injector cleaning standard

400-3022

Visit us online at motorvac.com

DieselTune

MAX STRENGTH

FUEL INJECTOR CLEANER

• Exceeds industry injector cleaner standards for Cummins L-10 and CEC

DW10

• Eliminates water using our exclusive

HydroBond Technology

• Increases Cetane by up to three points

400-3012

Visit us online at motorvac.com

CPS Products Canada Ltd. Automotive

1324 Blundell Road, Mississauga, ON, L4Y 1M5

Tel: 905-615-8620, 1-877-776-8486, Fax: 905-615-9745

CPS Products, Inc. U.S.A. (Headquarters)

1010 East 31st Street, Hialeah, Florida 33013, USA

Tel: 305-687-4121, 1-800-277-3808, Fax: 305-687-3743

CPS PRODUCTS N.V

Krijgsbaan 241, 2070 Zwijndrecht, Belgium

Tel: (323) 281 30 40, Fax: (323) 281 65 83

CPS AUSTRALIA PTY. LTD.

109 Welland Avenue, Welland, South Australia 5007

Tel: +61 8 8340 7055, Fax: +61 8 8340 7033

CPS ASIA

89 Short Street #06-06/07 Golden Wall Centre

Singapore 188216

Tel: (65) 63375691, Fax: (65) 63375692

ZMG15-01304

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
