Operation Guide
Please read this manual before using the scanner.
After you finish reading this manual, keep it in a safe place
for future reference.
European Union (and EEA) only.
This symbol indicates that this product is not to be
disposed of with your household waste, according
to the WEEE Directive (2002/96/EC) and your
national law. This product should be handed over
to a designated collection point, e.g., on an
authorized one-for-one basis when you buy a new similar
product or to an authorized collection site for recycling waste
electrical and electronic equipment (EEE). Improper handling
of this type of waste could have a possible negative impact on
the environment and human health due to potentially
hazardous substances that are generally associated with EEE.
At the same time, your cooperation in the correct disposal of
this product will contribute to the effective usage of natural
resources. For more information about where you can drop off
your waste equipment for recycling, please contact your local
city office, waste authority, approved WEEE scheme or your
household waste disposal service. For more information
regarding return and recycling of WEEE products, please visit
www.canon-europe.com/environment.
(EEA: Norway, Iceland and Liechtenstein)
Model Names
The following names may be provided for the safety
regulations in each sales region of the Network Scanner.
ScanFront 220: Model M11058
ScanFront 220P: Model M11062
Trademarks
• Canon and the Canon logo are registered trademarks of
Canon Inc. in the United States and may also be trademarks
or registered trademarks in other countries.
• imageFORMULA is a trademark of Canon Electronics Inc.
• Microsoft, Windows, Internet Explorer, and Active Directory
are registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
• Adobe, Acrobat, and Adobe Reader are registered
trademarks or trademarks of Adobe Systems Incorporated in
the United States and other countries.
• Other product and company names herein may be the
trademarks of their respective owners.
Copyright
libtiff
Copyright (c) 1988-1996 Sam Leffler
Copyright (c) 1991-1996 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this
software and its documentation for any purpose is hereby
granted without fee, provided that (i) the above copyright
notices and this permission notice appear in all copies of the
software and related documentation, and (ii) the names of
Sam Leffler and Silicon Graphics may not be used in any
advertising or publicity relating to the software without the
specific, prior written permission of Sam Leffler and Silicon
Graphics.
THE SOFTWARE IS PROVIDED “AS-IS” AND
WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON
GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE,
DATA OR PROFITS, WHETHER OR NOT ADVISED OF
THE POSSIBILITY OF DAMAGE, AND ON ANY
THEORY OF LIABILITY, ARISING OUT OF OR IN
CONNECTION WITH THE USE OR PERFORMANCE OF
THIS SOFTWARE.
libjpeg
Portions of this software are based in part on the work of the
Independent JPEG Group.
Copyright 2007 by CANON ELECTRONICS INC. All rights
reserved.
No part of this publication may be reproduced or transmitted
in any form or by any means, electronic or mechanical,
including photocopying and recording, or by any information
storage or retrieval system without the prior written
permission of CANON ELECTRONICS INC.
MD5
derived from the RSA Data Security, Inc. MD5 MessageDigest Algorithm
Copyright (c) 1998 - 2002, Paul Johnston & Contributors
All rights reserved.
Redistribution and use in source and binary forms, with or
without modification, are permitted provided that the
following conditions are met:
Redistributions of source code must retain the above
copyright notice, this list of conditions and the following
disclaimer. Redistributions in binary form must reproduce the
above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other
materials provided with the distribution.
Neither the name of the author nor the names of its
contributors may be used to endorse or promote products
derived from this software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT
HOLDERS AND CONTRIBUTORS "AS IS" AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE COPYRIGHT OWNER OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT,
INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT
LIMITED TO, PROCUREMENT OF SUBSTITUTE
GOODS OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY,
WHETHER IN CONTRACT, STRICT LIABILITY, OR
TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGE.
Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN
MERCURY AND MUST BE RECYCLED OR DISPOSED
OF ACCORDING TO LOCAL, STATE OR FEDERAL
LAWS.
Disclaimers
The information in this document is subject to change without
notice.
CANON ELECTRONICS INC. MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
EITHER EXPRESS OR IMPLIED, EXPECT AS
PROVIDED HERE IN, INCLUDING WITHOUT
LIMITATION, THERE OF, WARRANTIES AS TO
MARKETABILITY, MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE OF USE OR NONINFRINGEMENT. CANON ELECTRONICS INC. SHALL
NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OF ANY NATURE, OR
LOSSES OR EXPENSES RESULTING FROM THE USE
OF THIS MATERIAL.
Introduction
Thank you for purchasing the Canon imageFORMULA ScanFront 220/220P network scanner.
Please read this manual thoroughly before using the scanner to familiarize yourself with its capabilities, and to make the most of its
many functions. After reading this manual, store it in a safe place for future reference.
About ScanFront 220/220P
The ScanFront 220/220P is a network scanner that you can use without connecting to a computer.
You can transfer the data of an image scanned with the ScanFront 220/220P to a shared folder on a server PC or client PC on the
network or to an FTP server, or deliver it to a remote location via e-mail. It is also possible to use the image data in a location with
no network environment if you save the image file to USB memory.
Shared Folder
(Server PC, Client PC)
Network
Save File
Save File
Send E-mail
Mail Server
FTP Server
ScanFront 220
Save File
USB Memory
Conceptual Diagram of the ScanFront
* Transfer to an FTP server is possible only for an FTP server that does not require firewall settings.
i
❏ Manuals for the Scanner
The following symbols are used in this manual to explain
procedures, restrictions, handling precautions, and
instructions that should be observed for safety.
Setup Guide
Describes the procedure for setting up the scanner for
scanning. Set up the ScanFront in accordance with the
Setup Guide. For details on the ScanFront, refer to the
Operation Guide* and ScanFront 220/220P
INSTRUCTIONS (electronic manuals).
WARNING
Indicates a warning concerning operations that may lead to
death or injury to persons if not performed correctly. To
use the scanner safely, always pay attention to these
warnings.
Operation Guide*: This Manual
Provides an overview of the functions of the scanner, and
describes the basic operations for using the ScanFront. For
details on the settings of the ScanFront, refer to the
ScanFront 220/220P INSTRUCTIONS (electronic
manual).
CAUTION
Indicates a caution concerning operations that may lead to
injury to persons, or damage to property if not performed
correctly. To use the scanner safely, always pay attention
to these cautions.
* A print version of this guide is supplied in English. PDF files of
the Operation Guide in other languages can be found on the
INSTRUCTIONS CD-ROM.
INSTRUCTIONS (Electronic Manual)
Describes how to use the scanner, and includes
instructions for configuring the scanner settings, as well as
handling, maintenance, and troubleshooting information.
This manual is stored as a PDF file on the supplied
INSTRUCTIONS CD-ROM and requires Adobe Reader
to open. (You can download Adobe Reader from the
Adobe Web site.)
ii
❏ Symbols Used in This Manual
The following manuals are provided with the Canon
ScanFront 220/220P. Be sure to read these manuals
thoroughly before using the scanner.
IMPORTANT
Indicates operational requirements and restrictions. Be
sure to read these items carefully to operate the scanner
correctly, and avoid damage to the scanner.
Hint
Indicates a clarification of an operation, or contains
additional explanations for a procedure. Reading these
notes is highly recommended.
❏ How This Manual is Organized
This manual consists of the following chapters.
Chapter 1 Before Use
This chapter provides an overview of the ScanFront.
Chapter 2 Handling
This chapter describes the types of documents that can be
scanned, and the basic operations of the scanner.
Chapter 3 Operating Procedures
This chapter describes the basic operating procedures for
the scanner.
Chapter 4 Web Menu (User Mode)
This chapter describes the Web menu for the user to
configure settings.
Chapter 5 Troubleshooting
This chapter describes how to respond when problems
occur or warning messages appear.
Chapter 6 Index
iii
❏ Table of Contents
Introduction .............................................................. i
Manuals for the Scanner .......................................... ii
Symbols Used in This Manual .................................. ii
How This Manual is Organized................................ iii
Chapter 1 Before Use
1. Important Safety Instructions ........................... 1-2
Installation Location.............................................. 1-2
Power ................................................................... 1-2
Moving the Scanner.............................................. 1-3
Handling ............................................................... 1-3
About the Fingerprint Sensor
(ScanFront 220P only).......................................... 1-5
Disposal................................................................ 1-5
2. Names and Functions of Parts ......................... 1-6
Front and Document Feed and Eject Trays.......... 1-6
Side and Rear....................................................... 1-7
Chapter 2 Handling
1. Documents ....................................................... 2-2
Plain Paper ........................................................... 2-2
Business Card ...................................................... 2-2
Card...................................................................... 2-3
2. Preparing the Scanner ..................................... 2-4
Preparing the Document Feed Tray and
Eject Tray ............................................................. 2-4
Feed Selection Lever............................................ 2-5
USB Port............................................................... 2-5
Using a PS/2 Keyboard and PS/2 Mouse............. 2-6
3. Placing Documents .......................................... 2-7
Placing a Document ............................................. 2-7
Placing a Card ...................................................... 2-8
4. Clearing a Paper Jam or Double Feed Error.... 2-9
5. Fingerprint Sensor (ScanFront 220P) ............ 2-11
Cautions for Handling the Fingerprint Sensor .... 2-11
Fingerprint Authentication................................... 2-12
iv
Chapter 3 Operating Procedures
1. Flow of Scanner Operations ............................ 3-2
2. Turning the Power ON and OFF ...................... 3-3
Turning the Power ON.......................................... 3-3
Turning the Power OFF ........................................ 3-3
3. Login Screen.................................................... 3-4
Login Screen Types.............................................. 3-4
When Using Server Authentication....................... 3-4
List Type Login ..................................................... 3-5
Key in Type Login................................................. 3-6
Fingerprint Authentication (Only Available
with the ScanFront 220P) ..................................... 3-7
4. Screen Displayed after Login........................... 3-8
Home Screen........................................................ 3-8
Job Button Screen ................................................ 3-8
5. User Settings Screen ....................................... 3-9
Change Password ................................................ 3-9
Fingerprint Registration ........................................ 3-9
6. Fingerprint Registration (Only Available
with the ScanFront 220P) .............................. 3-10
Fingerprint Authentication................................... 3-10
Registering a Fingerprint .................................... 3-11
7. Scanning Procedures..................................... 3-13
Scanning From the Home Screen ...................... 3-13
Scanning From the Job Button Screen............... 3-13
Address Selection Screen .................................. 3-14
USB Memory Screen.......................................... 3-15
Scanning............................................................. 3-16
8. Registering and Editing Addresses................ 3-19
Registering a New Address ................................ 3-19
Modifying an Address ......................................... 3-21
Copying an Address ........................................... 3-22
9. Scan/Delivery Options ................................... 3-23
Scan Settings ..................................................... 3-24
File Formats........................................................ 3-27
Security Settings for PDF Files........................... 3-28
Delivery Options ................................................. 3-29
Chapter 4 Web Menu (User Mode)
1. Web Menu Overview ........................................4-2
2. Logging In to the Web Menu ............................4-3
3. User Settings ....................................................4-4
User Settings ........................................................ 4-5
4. Address Book Settings .....................................4-6
Registering New Addresses ................................. 4-8
Copying Addresses ............................................ 4-10
Exporting and Importing Address Books ............ 4-11
5. Job Button Settings ........................................4-12
Registering New Job Buttons ............................. 4-14
Scan Settings Overview ..................................... 4-15
Copying Job Buttons .......................................... 4-19
Exporting and Importing Job Buttons ................. 4-19
Chapter 5 Troubleshooting
1. Troubleshooting................................................5-2
Chapter 6 Index
v
vi
Chapter 1 Before Use
1. Important Safety Instructions ........................... 1-2
Installation Location ..............................................1-2
Power ....................................................................1-2
Moving the Scanner ..............................................1-3
Handling ................................................................1-3
About the Fingerprint Sensor
(ScanFront 220P only) ..........................................1-5
Disposal ................................................................1-5
2. Names and Functions of Parts......................... 1-6
Front and Document Feed and Eject Trays ..........1-6
Side and Rear .......................................................1-7
1. Important Safety Instructions
To ensure the safe operation of this scanner, be sure to read the safety warnings and precautions described below.
❏ Installation Location
The performance of this scanner is affected by the
environment in which it is installed. Make sure that the
location where the scanner is installed meets the following
environmental requirements.
● Provide adequate space around the scanner for
operation, maintenance, and ventilation.
At least
400 mm
❏ Power
At least
600 mm
● Avoid installing the machine in direct sunlight. If
this is unavoidable, use curtains to shade the
scanner.
● Avoid locations where a considerable amount of
dust accumulates.
● Avoid warm or humid locations, such as in the
vicinity of a water faucet, water heater, or
humidifier, and avoid locations where the fumes
from ammonia, paint thinner, or other volatile
chemicals may be present.
● Avoid locations that are subject to vibration.
1-2
● Avoid exposing the scanner to rapid changes in
temperature. If the room in which the scanner is
installed is cold but rapidly heated, water droplets
(condensation) may form inside the scanner. This
may result in a noticeable degradation in scanning
quality.
The following conditions are recommended for
optimal scanning quality:
Room temperature: 10 °C to 32.5 °C (50 °F to
90.5 °F)
Humidity: 20% to 80% RH
● Avoid installing the scanner near equipment that
generates a magnetic field (e.g. speakers,
televisions, or radios).
● Connect only to a power outlet of the rated voltage
and power supply frequency (220-240 V, 50/60
Hz).
● Do not connect other electrical equipment to the
same power outlet to which the scanner is
connected. Also, when using an extension cord,
make sure that the extension cord is rated for the
current requirements of the scanner.
● Never try to disassemble the AC adapter or modify
it in any way, as this is extremely dangerous.
● The power cord and AC adapter may become
damaged if they are often stepped on or if heavy
objects are placed on them. Continued use of a
damaged power cord and AC adapter can lead to
an accident, such as a fire or electrical shock.
● Do not use the power cord while it is coiled.
❏ Moving the Scanner
● When moving the scanner, always hold it with both
hands to avoid dropping it. The weight of the
scanner unit is approximately 3.4 kg.
● Before moving the scanner, make sure the
document tray is closed and the interface cable
and AC adapter are disconnected. If the scanner is
transported with these items connected, the plugs
and connectors may be damaged due to
excessive force applied to them during movement.
❏ Handling
WARNING
Note the following precautions whenever using the
scanner. Failure to do so may result in a fire or
electric shock.
■ Never use alcohol, benzene, paint thinner, aerosol
sprays, or any other highly flammable substance
near the scanner.
■ Do not cut, damage, or modify the power cord or
AC adapter. Do not place heavy objects on the
power cord or AC adapter, and do not pull or
excessively bend the power cord.
■ Never connect the power cord when your hands
are wet.
■ Do not connect the scanner to a multiplug power
strip.
■ Do not knot or coil the power cord, as this may
result in a fire or electric shock. When connecting
the power cord, make sure that the power plug is
securely and completely inserted into the power
outlet.
■ Do not use power cords and AC adapters other
than the power cord and AC adapter provided with
this scanner.
■ Never try to take the scanner apart or modify it in
any way.
■ Never try to take the AC adapter apart or modify it
in any way, as this is dangerous and may lead to a
fire or electric shock.
■ Do not use flammable aerosol sprays near the
scanner.
■ When cleaning the scanner, turn the power OFF
and disconnect the power cord from the power
supply.
■ Clean the scanner using a slightly dampened cloth
which has been well wrung out. Never use alcohol,
benzene, paint thinner, or any other flammable
substances.
1-3
1
Before Use
● Do not pull directly on the power cord. When
disconnecting the power cord, grasp the plug and
remove it from the outlet.
● Keep the area around the power plug clear of
objects so that the power cord can be
disconnected easily in an emergency.
● Use only the AC adapter provided with this
scanner. Also, do not use the AC adapter provided
with the scanner with any other electrical devices.
Model: MG1-3968
● If you have any questions regarding the power
supply, contact your local authorized Canon dealer
or service representative for further information.
■ If the scanner makes strange noises, or gives off,
smoke, heat, or strange odors, or the scanner
does not function or other abnormalities occur
when you use the machine, immediately turn the
power OFF, and disconnect the power plug from
the power outlet. Then, contact your local
authorized Canon dealer or service representative
for further information.
■ Do not drop the scanner, or subject it to impact or
strong shock. Should the scanner ever become
damaged, immediately turn the power OFF, and
disconnect the power plug from the power outlet.
Then, contact your local authorized Canon dealer
or service representative to have the unit serviced.
■ Before moving the scanner, make sure to turn the
power OFF, and disconnect the power plug from
the power outlet.
CAUTION
■ Do not install the scanner on a surface that is
unstable or tilted, or in an area subject to
excessive vibrations, as this may cause the
scanner to fall, resulting in personal injury or
damage to the scanner.
■ Do not block the ventilation openings. Doing so
could cause the scanner to overheat, creating a
risk of fire.
■ Never place small metal objects such as staples,
paper clips, or jewelry on the scanner. These items
may fall into the scanner, and cause a fire or
electric shock. Should such objects ever fall inside
the scanner, immediately turn the power OFF, and
disconnect the power plug from the power outlet.
Then, contact your local authorized Canon dealer
or service representative to have the unit serviced.
1-4
■ Do not install the scanner in a humid or dusty
location. Doing so may result in a fire or electric
shock.
■ Do not place objects on top of the scanner, as they
may tip over and fall, resulting in personal injury.
■ Do not use the scanner with a power supply
voltage other than 220-240 VAC. Doing so might
cause fire or electric shock.
■ When disconnecting the power cord, grasp it firmly
by its plug. Do not pull directly on the power cord,
as this may damage or expose the cord’s internal
wiring, resulting in a fire or electric shock.
■ Leave sufficient space around the power plug so
that it can be disconnected easily. If objects are
placed around the power plug, you will be unable
to disconnect it in an emergency.
■ Do not allow water or flammable substances
(alcohol, paint thinner, benzene, etc.) to spill into
the scanner, as this may result in a fire or electric
shock.
■ Turn OFF the power for safety when not using the
scanner for a long period of time, such as
overnight. Also, turn OFF the power, and
disconnect the AC adapter from the scanner and
disconnect the power cord from the power outlet
for safety when the machine will not be used for an
extended period of time, such as during
consecutive holidays.
■ Do not wear loose clothing or jewelry that may get
caught in the scanner while you are using it. This
may result in personal injury. Be extra careful of
neckties and long hair. If anything becomes caught
in the scanner, immediately disconnect the power
cord to stop the scanner.
■ Be careful when placing paper in the scanner and
when removing jammed paper. It is possible to cut
your hand on the edge of a sheet of paper.
❏ About the Fingerprint Sensor
(ScanFront 220P only)
● Prior to disposing of the scanner, initialize the
scanner to ensure that the registered data is
deleted.
● When disposing of the scanner, make sure to
follow all local ordinances and laws or consult with
the retailer who sold you the scanner.
1-5
1
Before Use
● The following actions may damage the sensor or
cause it to malfunction:
– Dropping an object on the fingerprint sensor, or
otherwise subjecting it to a strong impact
– Scratching the surface of the fingerprint sensor,
or poking it with a pointed object
– Pressing a hard object such as a fingernail or
metal item against the fingerprint sensor,
resulting in scratches being created on the
surface of the fingerprint sensor
– Touching the fingerprint sensor with dirty hands,
which might scratch or dirty the surface of the
fingerprint sensor
– Placing a sticker on the surface of the fingerprint
sensor, or covering the surface with ink or
another substance
● If fingerprint authentication fails frequently, the
fingerprint sensor may be dirty. Clean the surface
of the fingerprint sensor regulary.
● When cleaning the fingerprint sensor, use a soft
dry cloth to wipe dirt off the surface.
● Do not use a pointed object to remove any dirt that
accumulates around the fingerprint sensor. Doing
so may cause the fingerprint sensor to
malfunction.
● Touching the fingerprint sensor while charged with
static electricity may cause the fingerprint sensor
or scanner unit to malfunction. Before touching the
fingerprint sensor, discharge any static electricity
by touching a piece of metal. Be especially careful
during dry periods, such as the winter season,
when the likelihood of being charged with static
electricity is high.
❏ Disposal
2. Names and Functions of Parts
The names and functions of the parts of the ScanFront 220/220P are shown below.
❏ Front and Document Feed and Eject Trays
ScanFront 220
a Power Switch
Use this to turn the power ON. (See p. 3-3.)
* Use the Power OFF button on the touch panel to turn the
power OFF.
ScanFront 220P
1-6
b Power Indicator
Lights when the power is ON. (See p. 3-3.)
c Lock Lever
Locks the panel unit. Pull the lever toward you to unlock
the panel unit. (See p. 2-10.)
d Document Feed Tray
Pull out the feed tray to match the length of the document.
(See p. 2-4.)
e Document Guides
Adjust these to match the width of the document. (See
p. 2-7.)
f Panel Unit
Open this when there is a paper jam or to perform
maintenance. (See p. 2-10.)
g Touch Panel
Touch this screen to operate the ScanFront.
h Document Eject Tray
Open this tray when using the ScanFront. If scanned
documents are likely to fall out of the tray, open the tray
extension. If scanned documents curl in the document
eject tray, remove the entire tray. (See p. 2-4.)
i Fingerprint Authentication Sensor (Only Available
with the ScanFront 220P)
This fingerprint sensor is for fingerprint registration and
authentication. (See p. 2-11.)
j Feed Selection Lever
Use this lever to change the feed method for documents.
(See p. 2-5.)
❏ Side and Rear
1-7
1
Before Use
k Kensington Slot
This is an anti-theft slot that enables a key chain or lock to
be connected to prevent theft.
l PS/2 Connector (Green)
Connect a PS/2 mouse. (See p. 2-6.)
m PS/2 Connector (Purple)
Connect a PS/2 keyboard. (See p. 2-6.)
n LAN Port (RJ-45)
Connect an RJ-45 (10Base-T/100Base-TX) compatible
network cable.
o USB Ports
Connect a USB1.1/Hi-Speed USB2.0 compatible USB
memory device, USB keyboard, or USB mouse.
p Power Connector (16 VDC)
Connect the plug of the supplied AC adapter.
q Service Switch
This is a service switch. Do not insert any object into this
hole.
r Ventilation Holes
1-8
Chapter 2 Handling
1. Documents....................................................... 2-2
Plain Paper............................................................2-2
Business Card.......................................................2-2
Card ......................................................................2-3
2. Preparing the Scanner ..................................... 2-4
Preparing the Document Feed Tray and
Eject Tray ..............................................................2-4
Feed Selection Lever ............................................2-5
USB Port ...............................................................2-5
Using a PS/2 Keyboard and PS/2 Mouse .............2-6
3. Placing Documents .......................................... 2-7
Placing a Document ..............................................2-7
Placing a Card.......................................................2-8
4. Clearing a Paper Jam or Double Feed Error ... 2-9
5. Fingerprint Sensor (ScanFront 220P) ............ 2-11
Cautions for Handling the Fingerprint Sensor .....2-11
Fingerprint Authentication ...................................2-12
1. Documents
The ScanFront can scan documents in a range of sizes from business cards and checks to A4.
It is possible to feed documents of the following sizes and thicknesses depending on the feeding method used.
❏ Plain Paper
Size
Width: 50.8 mm to 216 mm
Length: 53.9 mm to 355.6 mm
Thickness for Page Separation Feeding
52 g/m2 to 128 g/m2 (0.06 mm to 0.15 mm)
Thickness for Bypass Feeding
42 g/m2 to 157 g/m2 (0.05 mm to 0.20 mm)
IMPORTANT
A document must meet the following criteria to be scannable:
• When scanning a multipage document, pages must be
grouped together so that they have the same size, thickness,
and weight. Scanning different types of paper at one time can
cause the scanner to jam.
• Always make sure that the ink on a document is dry before
scanning it. Scanning documents with the ink still wet may soil
the rollers or scanning glass, cause lines or smudges to
appear on images, or dirty other documents.
• Always clean the rollers or scanning glass after scanning a
document written in pencil. Scanning documents with pencil
written on them may soil the rollers or scanning glass, cause
stripes to appear in images, or dirty other documents.
• When scanning a two-sided document that is printed on thin
paper, the image on the opposite side of each page may show
through. Adjust the brightness in the scanning conditions
before scanning the document.
2-2
• Note that scanning the following types of documents can
cause a paper jam or malfunction. To scan such a document,
make a photocopy of the document and then scan the
photocopy.
Wrinkled or creased
documents
Carbon paper
Curled documents
Coated paper
Torn documents
Extremely thin,
translucent paper
Documents with
paper clips or staples
Document with square
punch holes
❏ Business Card
Size
Width: 50.8 mm and above
Length: 53.9 mm and above
Thickness
300 g/m2 (0.35 mm) and below
IMPORTANT
• If the stack of business cards that you placed is not fed
properly, reduce the number business cards.
• Business cards may sometimes be stacked in the wrong order
when they are ejected, depending on the size and thickness
of the business cards, and the orientation that they are loaded.
❏ Card
Size
53.9 × 85.5 mm (Conforming to ISO Standards)
Thickness
0.76 mm and below
2
Insertion orientation
Landscape
Handling
CAUTION
A card placed into the document feed tray in the portrait
orientation may not be output properly because a load is placed
on it during feeding. Furthermore, removing a card that has
caused a feeding error may damage the card, so make sure to
correctly insert the card.
2-3
2. Preparing the Scanner
When placing a document in the scanner, pull out the document feed tray so that it matches the size of the document, and then move
the feed selection lever to the appropriate position for the desired feed method (page separation feeding or bypass feeding) for the
document.
❏ Preparing the Document Feed Tray and
Eject Tray
Prepare the trays in accordance with the type of document.
1. Open the document eject tray a.
2. Pull out the document feed tray b, c to match the
Hint
If the output documents curl in the eject tray when scanning
particularly thin documents, remove the eject tray.
To remove the document eject tray, push in on the illustrated
portions of the tray on both sides in the direction of the arrows
a and pull out b.
length of the document to be placed in the tray.
Hint
To reattach the eject tray, insert the protrusions on both sides of
the tray into the holes on the scanner.
Open the center tray extension when output documents are
likely to fall out of the tray.
After connecting the tray, make sure that it is attached securely.
2-4
❏ Feed Selection Lever
❏ USB Port
Change the position of the lever to the desired feed method
for the document.
Page Separation Feeding
Move the lever downward to separate a stack of documents
one page at a time in order to continuously feed the
documents.
You can insert a USB memory device to store image files
or connect a USB keyboard or USB mouse to operate the
scanner.
2
Handling
Bypass Feeding
Move the lever upward to feed a document with multiple
pages attached together such as an invoice one page at a
time without separating the pages.
USB Memory
Page separation
feeding
IMPORTANT
Bypass feeding
Feed selection lever
• Insert the USB memory while the scanner is ON. Some USB
memory may not be recognized properly if the power is turned
ON after the USB memory is inserted.
• Use USB memory that is not write-protected for security. If the
USB memory is write-protected, data cannot be written to the
USB memory.
• Make sure that the USB memory has sufficient space to store
images.
IMPORTANT
Moving the lever upward (bypass feeding) and then scanning a
stack of documents will cause multiple pages to be fed at the
same time.
2-5
❏ Using a PS/2 Keyboard and PS/2 Mouse
You can connect a PS/2 keyboard and mouse to the PS/2
port and use them to operate the scanner.
Green (Top):
Mouse
Purple (Bottom):
Keyboard
IMPORTANT
Turn OFF the scanner before connecting or disconnecting the
PS/2 mouse and keyboard.
2-6
3. Placing Documents
When placing documents into the scanner, place them face down into the tray with the top edge of the document at the bottom of
tray.
❏ Placing a Document
Follow the procedure below to place a document.
3. Place the document face down with its top edge at
the bottom of the tray.
2
1. Adjust the document guides to be wider than the
Handling
width of the document.
4. Adjust the document guides to fit the width of the
document.
2. Fan the document to offset the pages so that the top
edge of the first page is the lowest.
2-7
3. Place the card face down in the landscape orientation
IMPORTANT
Up to 50 sheets of ordinary paper can be loaded into the
document feed tray. When placing the document, make sure the
size of stack does not exceed the loading marks on the
document guides.
Loading mark
❏ Placing a Card
with the top edge at the bottom of the tray.
CAUTION
• A card placed into the document feed tray in the portrait
orientation may not be output properly because a load is
placed on it during feeding. Furthermore, removing a card that
has caused a feeding error may damage the card, so make
sure to correctly insert the card.
When you want to scan a card, follow the procedure below
to place the card.
1. Move the feed selection lever upward (bypass
feeding).
IMPORTANT
When scanning cards, set the feed selection lever to bypass
feeding and make sure to scan the cards one at a time.
2. Adjust the document guides to match the width of the
card.
• Pull the lock lever and open the panel unit before removing a
placed card. Inserting a finger into the scanner while the panel
unit is closed may result in an injury.
Lock lever
2-8
4. Clearing a Paper Jam or Double Feed Error
When a paper jam or double feed error is detected, feeding and scanning stops.
1. Check the displayed message.
If a paper jam or double feed error is detected at the first
page of a document, the following messages appear.
If a paper jam or double feed error is detected in the middle
of a document, the following messages appear.
2
Handling
Hint
Hint
• If you want to continue scanning, clear the document first
before touching the screen. After you reset the cleared
document, press [Continue] to resume scanning.
• If you press [Complete], the display returns to the previous
screen.
• If you press [Abort], the scanned images are canceled, and
the display returns to the previous screen.
• If you want to continue scanning, clear the document first
before touching the screen. After you reset the cleared
document, press [Continue] to resume scanning.
• If you press [Complete], the scanned images up until the
paper jam or double feed error are saved and scanning
completes. The display switches to the Send screen.
2-9
4. Pull out the jammed document in the direction that
IMPORTANT
When the message above is displayed and the scanner
transitions to Low Power Mode, all of the data scanned up until
that point is discarded. (See p. 3-3.)
seems the easiest to remove it.
2. Remove the scanned documents from the document
eject tray, and any documents remaining in the
document feed tray.
3. Pull the lock lever toward you and then fully open the
panel unit.
5. Close the panel unit and then place the document
again.
Lock lever
CAUTION
The open/close movement of the panel unit is linked to the up/
down movement of the document eject tray. Do not press on the
document eject tray when you open the panel unit.
6. Press [Continue] to resume scanning.
IMPORTANT
• If double feed errors occur repeatedly, reduce the number of
sheets you place in the document feed tray to about 10.
• A dirty or worn feed roller, or documents stuck together as a
result of static electricity are common causes of paper jams or
double feed errors.
If the feed roller is dirty, clean it. If paper jams or double feed
errors continue to occur even after cleaning, contact the
ScanFront administrator and replace the rollers (feed roller
and retard roller), and document holding guides.
2-10
5. Fingerprint Sensor (ScanFront 220P)
The ScanFront 220P is equipped with a fingerprint sensor for registering fingerprints and authenticating users.
The fingerprint sensor is a precision component. Be careful when handling this sensor.
❏ Cautions for Handling the Fingerprint
Sensor
● The following actions may damage the fingerprint
sensor or cause it to malfunction. Read this
information carefully to avoid damaging the
sensor.
– Dropping an object on the fingerprint sensor, or
otherwise subjecting it to a strong impact
– Scratching the surface of the fingerprint sensor,
or poking it with a pointed object
– Pressing a hard object such as a fingernail or
metal item against the fingerprint sensor,
resulting in scratches being created on the
surface of the fingerprint sensor
– Touching the fingerprint sensor with dirty hands,
which might scratch or dirty the surface of the
fingerprint sensor
– Placing a sticker on the surface of the fingerprint
sensor, or covering the surface with ink or
another substance
● If fingerprint authentication fails frequently, the
fingerprint sensor may be dirty. Clean the surface
of the fingerprint sensor regularly.
2-11
2
Handling
Fingerprint Sensor
● When cleaning the fingerprint sensor, use a soft
dry cloth to wipe dirt off the surface.
● Do not use a pointed object to remove any dirt that
accumulates around the fingerprint sensor. Doing
so may cause the fingerprint sensor to
malfunction.
● Touching the fingerprint sensor while charged with
static electricity may cause the fingerprint sensor
or scanner unit to malfunction. Before touching the
fingerprint sensor, discharge any static electricity
by touching a piece of metal. Be especially careful
during dry periods, such as the winter season,
when the likelihood of being charged with static
electricity is high.
❏ Fingerprint Authentication
● Follow the procedure below to use fingerprint
registration and authentication.
1. Align the first joint of a finger on the sensor and
press the finger on the fingerprint sensor.
2. Keep the finger pressed while slowly sliding it
straight at a constant speed to scan the
fingerprint.
● Authentication performance may improve if the
condition of the fingerprint is improved as a result
of washing your hands or applying hand cream.
● Authentication may not be performed properly
depending on the speed with which you slide your
finger over the sensor. In this case, adjust the
speed with which you slide your finger in
accordance with the message that appears.
● Fingerprint authentication does not necessarily
guarantee the authentication and verification of the
identity of a person.
Hint
For details on the procedures for fingerprint registration and
authentication, see “Fingerprint Registration (Only Available
with the ScanFront 220P)” on p. 3-10.
● Fingerprint authentication uses the unique
information of fingerprints. The fingerprint
authentication function may not work properly for a
finger with a fingerprint that is worn down or has
few distinguishable features.
● The same finger needs to be scanned three times
to register the fingerprint.
● The authentication performance differs depending
on the condition of the fingerprint when it is
registered and when it is authenticated. The
following conditions may cause an error in
fingerprint authentication:
– The finger is wet or sweaty
– The finger is dirty
– The grooves of the fingerprint are filled with
sweat or oil
– The finger is dry (dry skin)
– Part of the fingerprint is missing because of, for
example, a wound or burn injury
– The fingerprint has worn thin
2-12
Chapter 3 Operating Procedures
1. Flow of Scanner Operations .............................3-2
2. Turning the Power ON and OFF.......................3-3
Turning the Power ON.......................................... 3-3
Turning the Power OFF ........................................ 3-3
3. Login Screen ....................................................3-4
Login Screen Types.............................................. 3-4
When Using Server Authentication....................... 3-4
List Type Login ..................................................... 3-5
Key in Type Login................................................. 3-6
Fingerprint Authentication (Only Available
with the ScanFront 220P) ..................................... 3-7
4. Screen Displayed after Login ...........................3-8
Home Screen........................................................ 3-8
Job Button Screen ................................................ 3-8
5. User Settings Screen........................................3-9
Change Password ................................................ 3-9
Fingerprint Registration ........................................ 3-9
6. Fingerprint Registration (Only Available
with the ScanFront 220P) ...............................3-10
Fingerprint Authentication................................... 3-10
Registering a Fingerprint .................................... 3-11
7. Scanning Procedures ..................................... 3-13
Scanning From the Home Screen ...................... 3-13
Scanning From the Job Button Screen............... 3-13
Address Selection Screen .................................. 3-14
USB Memory Screen.......................................... 3-15
Scanning............................................................. 3-16
8. Registering and Editing Addresses ................3-19
Registering a New Address ................................ 3-19
Modifying an Address ......................................... 3-21
Copying an Address ........................................... 3-22
9. Scan/Delivery Options....................................3-23
Scan Settings ..................................................... 3-24
File Formats........................................................ 3-27
Security Settings for PDF Files........................... 3-28
Delivery Options ................................................. 3-29
1. Flow of Scanner Operations
The procedure and screen transitions for the process from turning the scanner ON, to sending an image file are as follows. For
descriptions of the various settings, refer to the appropriate reference pages.
Turn the power ON
(See p. 3-3.)
No user is registered
Users are registered (device/server authentication)
* When no user is registered and only
the Shared Address Book and Shared
Job Button are used
Login screen
(See p. 3-4.)
User Settings screen
(See p. 3-9.)
Home screen
(See p. 3-8.)
Password setting screen
(See p. 3-9.)
Address selection screen
(See p. 3-14.)
Fingerprint registration screen
(See p. 3-10.)
* The User Settings screen enables
setting a password for the user that
logged in, and registration for the
ScanFront 220P.
* Set the screen that appears after login in the user settings.
* When you use server authentication, the user that logged in
is registered automatically.
Job Button screen
(See p. 3-8.)
Scan/Delivery Options screen
(See p. 3-23.)
* Users restricted by [Use only Job
Buttons] in the function
restrictions cannot scan from the
Home screen.
Scanning starts immediately after a
job button is pressed.
Scan (The process after scanning differs depending on the Delivery Options)
(See p. 3-29.)
* Delivery Options
settings are also applied
to job buttons.
Scanning finishes (A document confirmation message appears)
(See p. 3-17.)
Send/Image Confirmation screen
(See p. 3-18.)
The image is sent
without the address
being confirmed.
The document and
image are not checked
Address Confirmation screen
(See p. 3-18.)
Send (The screen displayed after sending differs depending on the Delivery Options)
(See p. 3-29.)
Home screen
3-2
Job Button screen
Login screen
After scanning of the
document ends, the image is
sent as is and the process
ends.
2. Turning the Power ON and OFF
Use the power switch to turn the scanner ON, and press the [Power off] button on the touch panel to turn it OFF.
❏ Turning the Power ON
❏ Turning the Power OFF
Press the power switch to turn the scanner ON. The power
indicator lights, and the Home screen or the login screen
appears.
Press the [Power off] button displayed at the bottom left of
the panel to turn the scanner OFF.
Power switch
Home screen
3
Power
indicator
Hint
• It takes approximately 40 seconds for the Home screen to
appear after the power switch is turned on.
• If users have been registered, the login screen appears. (See
“Login Screen” on p. 3-4.)
• When the power indicator is lit but nothing appears on the
touch panel, Display Off has activated to turn the panel display
off. You can touch the panel to restore the display.
• When the power indicator is flashing but nothing appears on
the touch panel, the Low Power mode has activated to
temporarily stop scanner operations. You can press the power
switch to switch out of Low Power mode.
• Contact the ScanFront administrator for details on the Display
off mode and Low Power mode settings.
3-3
Operating Procedures
IMPORTANT
• When restarting the scanner, wait at least 5 seconds after
turning the power OFF before turning it ON again.
• If the scanner stops responding, press and hold the power
switch to shut down the system, and then press the power
switch to turn the scanner ON again. In such cases, settings
configured immediately before shutting down may be lost.
3. Login Screen
The login screen appears at the startup when the scanner is turned ON.
❏ Login Screen Types
There are two types of login screen: a list type login screen
for selecting from a list of registered users, and a key in
type login screen for entering a user name and password.
List Type Login Screen
Hint
• Set the type of login screen from [Device Operation] of the
Web menu (refer to p. 4-25 on the ScanFront 220/220P
INSTRUCTIONS) or [Login type setting] in the administrator
settings of the ScanFront (refer to p. 3-10 on the ScanFront
220/220P INSTRUCTIONS).
• Fingerprint authentication is enabled when you are using the
ScanFront 220P. (See “Fingerprint Authentication (Only
Available with the ScanFront 220P)” on p. 3-7.)
❏ When Using Server Authentication
The login screen when you use server authentication is a
key in type, and a list box is displayed for selecting Device
Authentication and Server Authentication.
Key in Type Login Screen
IMPORTANT
• When you use server authentication to log in, you are
registered as a new user of server authentication. However,
your e-mail address is not registered in the user information.
You must contact the ScanFront administrator in order to
register your e-mail address.
• Fingerprint authentication cannot be used with server
authentication.
3-4
❏ List Type Login
3. Enter a password and then press [OK].
Use the procedure below to log in to the list type login
screen.
1. Select the user to log in as from the list, and then
press [Next].
3
4. Press [Login] to log in to the scanner.
The password input screen appears.
2. Press [Password].
5. The Home screen (or Job Button screen) appears.
The keyboard screen appears.
3-5
Operating Procedures
IMPORTANT
Passwords are case-sensitive. Make sure to enter the password
correctly.
❏ Key in Type Login
3. Press [Login] to log in to the scanner.
In the key in type login screen, enter your user name and
password to log in.
1. Press [User name] ([Password]).
4. The Home screen (or Job Button screen) appears.
The keyboard screen appears.
2. Enter your user name (password) and then press
[OK].
IMPORTANT
• User names and passwords are case-sensitive. Make sure to
enter the user and password registered during device
authentication correctly.
• If you do not know the user name and password registered for
server authentication, contact the domain server
administrator.
3-6
❏ Fingerprint Authentication (Only
Available with the ScanFront 220P)
Use the procedure below for fingerprint authentication.
For details on fingerprint registration, see “Fingerprint
Registration (Only Available with the ScanFront 220P)”
on p. 3-10.
3. The Home screen (or Job Button screen) appears if
the fingerprint is authenticated correctly.
Hint
If fingerprint authentication fails, try sweeping your finger again.
1. Press [Fingerprint Authentication].
3
Operating Procedures
The authentication mode screen appears.
2. Perform fingerprint authentication using the finger
with the registered fingerprint.
IMPORTANT
Perform finger authentication by gently pressing the finger while
slowly sweeping it at a constant speed to scan the fingerprint.
3-7
4. Screen Displayed after Login
You can set the screen (Home screen or Job Button screen) that is displayed after a user logs in. (See p. 4-4.)
❏ Home Screen
❏ Job Button Screen
This screen enables you to select a job button to scan using
the conditions registered to the job button, and then send
the image file. (See “Scanning Procedures” on p. 3-13.)
a
b
c
a Select destination (E-mail, FTP, Shared folder,
and USB memory) buttons
These buttons open an address selection screen. (See
“Scanning Procedures” on p. 3-13.)
Hint
The USB memory button is enabled when USB memory is
inserted in a USB port.
b [User settings] button
Enables setting of the user password and fingerprint
registration (only with the ScanFront 220P). (See “User
Settings Screen” on p. 3-9.)
c [Administrator setting] button
Opens the Administrator Settings screen.
IMPORTANT
If a user whose use of the Home screen is restricted logs in, the
Home screen is not available. For details, contact the
administrator.
3-8
IMPORTANT
• The document is scanned immediately after you press the job
button. Make sure to place your document before you press
the job button. (See “Placing Documents” on p. 2-7.)
• Perform job button registration and editing via the Web menu.
• If you are unable to edit a job button, the editing of job buttons
has been restricted by the ScanFront administrator. For
details, contact the administrator.
5. User Settings Screen
The User Settings screen enables you to edit the user password and register a fingerprint (only available with the ScanFront 220P).
❏ Fingerprint Registration
Fingerprint registration is enabled when you are using the
ScanFront 220P. For details on fingerprint registration, see
“Fingerprint Registration (Only Available with the
ScanFront 220P)” on p. 3-10.
3
Operating Procedures
❏ Change Password
You can register a new user password or change a user
password registered via the Web menu.
Hint
The old password does not need to be entered in order to
change a password. The new password that you entered is
registered.
3-9
6. Fingerprint Registration (Only Available with the ScanFront 220P)
Fingerprint authentication is a function for registering the fingerprints of users that will log in when the device authentication
method is used, and enables users to log in by authenticating their fingerprints. When fingerprint authentication is used, there is no
need to select a user in the list type login screen or enter a user name and password in the key in type login screen. For details on
handling the fingerprint sensor, see “Fingerprint Sensor (ScanFront 220P)” on p. 2-11.
❏ Fingerprint Authentication
● Follow the procedure below to use fingerprint
registration and authentication.
1. Align the first joint of a finger on the sensor and
press the finger on the fingerprint sensor.
2. Keep the finger pressed while slowly sliding it
straight at a constant speed to scan the
fingerprint.
● Fingerprint authentication uses the unique
information of fingerprints. The fingerprint
authentication function may not work properly for a
finger with a fingerprint that is worn down or has
few distinguishable features.
● The same finger needs to be scanned three times
to register the fingerprint.
3-10
● The authentication performance differs depending
on the condition of the fingerprint when it is
registered and when it is authenticated. The
following conditions may cause an error in
fingerprint authentication:
– The finger is wet or sweaty
– The finger is dirty
– The grooves of the fingerprint are filled with
sweat or oil
– The finger is dry (dry skin)
– Part of the fingerprint is missing because of, for
example, a wound or burn injury
– The fingerprint has worn thin
● Authentication performance may improve if the
condition of the fingerprint is improved as a result
of washing your hands or applying hand cream.
● Authentication may not be performed properly
depending on the speed with which you slide your
finger over the sensor. In this case, adjust the
speed with which you slide your finger in
accordance with the message that appears.
● Fingerprint authentication does not necessarily
guarantee the authentication and verification of the
identity of a person.
❏ Registering a Fingerprint
Register a fingerprint from the User Settings screen
accessed from the Home screen.
3. Scan your fingerprint.
Repeat scanning until the same fingerprint has been
successfully scanned three times.
IMPORTANT
If the Home screen is not displayed, use of the Home screen
has been restricted for the user by the ScanFront administrator.
Confirm this with the administrator.
1. Press [User settings].
3
The User Settings screen appears.
2. Press [Fingerprint Registration].
4. After you have successfully scanned your fingerprint
three times, press [Register/Test].
The Fingerprint Registration screen appears.
The Test Mode screen appears.
3-11
Operating Procedures
IMPORTANT
• If any of the messages below appears, there was an error
scanning the fingerprint. Try scanning your fingerprint again.
– Failed to read fingerprint. Please try again.
– Sweep speed was too fast. Please sweep more slowly.
– Sweep speed was too slow. Please sweep more faster.
• If any of the messages below appears, start fingerprint
registration again from the beginning.
– Can not verify the fingerprint data. Start registration again.
– Time out error has occurred. Start registration again.
5. Perform an authentication test for the registered
fingerprint by scanning your fingerprint.
6. Press [Close] to end fingerprint registration.
IMPORTANT
If you want to change the registered fingerprint, start registration
again from the beginning.
3-12
7. Scanning Procedures
You can perform scanning from the Home screen or the Job Button screen.
❏ Scanning From the Home Screen
Press a destination selection (E-mail, FTP, Shared folder,
or USB memory) button to open an address selection
screen and then select an address to send an image file.
If you press a job button, the Scan/Delivery Options screen
appears. Confirm the address and scanning settings
registered to the job button and then start scanning.
For details on the scanning procedure, read from the
setting of scanning conditions in Step 5.
3
Operating Procedures
If you press the USB memory destination selection button,
press [Downward] and specify the folder in the USB
memory to which you want to save the image file.
❏ Scanning From the Job Button Screen
IMPORTANT
• The settings screen display and the screen displayed after
scanning differ depending on the job button settings. For
details on the overall flow from configuring settings to sending
an image file, see “Flow of Scanner Operations” on p. 3-2.
• It is not possible to save to USB memory from a job button.
If you select an address and then press [Next], the Scan/
Delivery Options screen appears. Set the scanning
conditions and then start scanning.
3-13
❏ Address Selection Screen
From the address selection screen, you can select the address to send an image file and register addresses.
a
b
c
e
d
f
g
a Address Book type
Selects the address book type (Shared Address Book or
My Address Book). If the address book server setting is
enabled, [LDAP Address Book] is added.
b Address type
If you select the type of address (e-mail, shared folder,
FTP, and groups) to display in the address list,
addresses of the selected type are displayed.
c Address List
Displays registered addresses and enables you to select
the address to send an image file.
Hint
• The following icons are used to indicate the types of address.
:E-mail
:Shared folder
:FTP
:Group
• Pressing an address adds a checkmark (
) to the icon and
selects the address. Pressing a selected address again clears
the selection.
• An address is not selected as an address if there is no
checkmark added to the icon, even if the background of the
address is colored and the address appears selected.
• Each time you press an e-mail or group icon, the send
condition changes (To, Cc, Bcc).
:To
:Cc
:Bcc
:Selection cleared
3-14
d Jump Keys
If there are many addresses and the address you want is
not displayed in the address list, you can use these keys
to specify a keyword to search for and display the
address.
e [Clear All] button
Clears all address selections.
f [Edit] button
Enables you to register new addresses and edit
addresses.
g [Details] button
Displays detailed information for the address.
❏ USB Memory Screen
The USB Memory screen enables you to specify the folder in the USB memory to save the image file.
a
b
c
d
3
e
f
Hint
• If you insert two USB memory sticks, the one that was inserted
first is recognized as “USB memory,” and the one that was
inserted after that is recognized as “USB memory2.”
• If you want to remove a USB memory stick and insert a
different one, press the [Back] button to return to the Home
screen and update the USB memory information.
c [Upward] button
Enables you to move to a higher level folder when a
lower level folder is selected in the memory.
d [Downward] button
Enables you to move to a lower level folder in the USB
memory.
e [Edit] button
Enables you to register new folders and edit folders.
f [Format] button
Enables you to format the USB memory.
3-15
Operating Procedures
a Path
Enter the folder path of the USB memory. You can also
press [Downward] to select a folder.
b USB Memory Display
Displays the inserted USB memory.
❏ Scanning
This section describes the procedure for scanning.
If you want to save the image file to USB memory, specify
the folder in the USB memory to save the image file in
Steps 2 to 4. (See “USB Memory Screen” on p. 3-15.)
3. Press a displayed address to select it.
A checkmark (
) is added to the icon for the selected
address. Pressing a selected address again clears the
selection.
1. Select a destination.
Press a destination button to select a destination.
IMPORTANT
An address is not selected as an address to send data to if there
is no checkmark, even if the background is shaded.
4. Make sure the selected address has a checkmark
The address selection screen appears.
and then press [Next].
Hint
When a different type of address is selected, you can confirm
the selected address by pressing [Selected address] in the
Address type drop-down list.
2. Use [Address Book type] and [Address type] to
display the address to send the image file.
The Scan/Delivery Options screen appears.
3-16
6. Press [Start] to start scanning.
Scanning stops after the document has been scanned.
3
5. Set the scan conditions. (See “Scan/Delivery
IMPORTANT
When you use a job button for scanning, the subsequent
procedure varies as follows in accordance with the job button
settings. For details, see “Registering New Job Buttons” on
p. 4-14.
• If [When you select this Job Button] is set to [Skip Scan Setting
Screen] and you press a job button, scanning is started
without displaying the Scan/Delivery Options screen of Step 4.
• If [Send the files immediately after scanning] is set to [ON],
scanning ends without displaying the continue to scan
confirmation screen of Step 7 and then the address
confirmation screen of Step 10 appears.
• If [Confirm addresses before sending] is set to [OFF], the
image is sent without displaying the address confirmation
screen of Step 10 and the operation ends.
IMPORTANT
• If [Send the files immediately after scanning] is set to [ON] in
Delivery Options of the Scan/Delivery Options screen,
scanning ends without displaying the continue to scan
confirmation screen, and the address confirmation screen of
Step 10 appears.
• When the confirmation message is left displayed and the
scanner transitions to Low Power Mode, all of the data
scanned up until that point is discarded. (See p. 3-3.)
7. Check the document and go to the next step.
• Press [Abort] to cancel the scanned images and return to the
Scan/Delivery Options screen.
• Press the [Continue] button to resume scanning.
• Press [Complete] to go to the Send screen.
3-17
Operating Procedures
Options” on p. 3-23.)
8. Check the scanned images.
: Display the image of the next page.
: Display the image of the previous page.
: Move the viewing area around an image
when an enlarged view of the image is shown.
: Rotate the image 90 degrees counterclockwise.
: Rotate the image 90 degrees clockwise.
: Enlarge the image.
: Reduce the image.
IMPORTANT
If [Confirm addresses before sending] is set to [OFF] in Delivery
Options of the Scan/Delivery Options screen, the image is sent
without displaying the address confirmation screen and the
operation ends.
10. Confirm the address and press [OK] to send the
scanned image.
9. Press [Send].
IMPORTANT
If a send error message appears, check the address settings
and send destination and try again.
The address confirmation message appears.
11. Returns to the screen set for [Screen after sending]
in Delivery Options of the Scan/Delivery Options
screen.
3-18
8. Registering and Editing Addresses
If an address to which you want to send an image file is not registered in the address book or the information of a registered address
has not been updated, use the procedure below to register a new address or modify an address in the address book.
❏ Registering a New Address
1. Make selections for [Address Book type] and
[Address type], press [Edit], and then press [New].
• E-mail address
Enter the sender’s address for when image files are sent
by e-mail.
Shared Folder Registration Screen
3
conditions of the address type.
E-mail Registration Screen
• Name
Enter the name to appear in the address book.
• Host name
Enter the name of the computer on which the shared
folder is made public.
• Folder path
Enter the name of the shared folder and the path of the
sub-folder to register.
Hint
• Name
Enter the name to appear in the address book.
If the path of the sub-folder is unknown, use the procedure
below to specify the sub-folder.
1. Enter the host name, user name, password, and domain, and
then click [Browse] to access the computer that is making the
shared folder public.
2. Specify any sub-folder within the displayed folder.
3-19
Operating Procedures
2. Register the address in accordance with the setting
3. Press [Downward] to move to a level lower than the selected
folder, or press [Edit] and [Create a new folder] to create a
new folder.
• User name/Password
Enter the user name and password of an account with
write permission for the shared folder.
• Domain/Workgroup
If the computer containing the shared folder is part of a
domain, enter the domain name.
• Save password
Save the entered password.
FTP Registration Screen
• User name/Password
Enter the user name and password for logging in to the
FTP server.
IMPORTANT
Enter the user name and password of an account with write
permission for the FTP server.
• Port number
Enter the port number. The standard port number is 21.
• Save password
Save the entered password.
• Use passive mode
Use passive mode for sending to the FTP server.
IMPORTANT
Use passive mode when normal communication with the FTP
server cannot be established. However, be aware that
communication may not be possible if the network is not
functioning properly.
Group Registration Screen
• Name
Enter the name to appear in the address book.
• FTP server
Enter the address of the FTP server.
• Folder path
Enter the path of the sub-folder when specifying a subfolder on the FTP server.
Hint
If the path of the sub-folder is unknown, use the procedure
below to specify the sub-folder.
1. Enter the server address, user name, and password, and
click [Browse] to log in to the FTP server.
2. Specify any sub-folder at the level of the displayed folder and
click [OK].
3-20
• Name
Enter the name that you want to appear in the address
book.
• [Add] button
Select addresses to register to the group from [Address
Book type] and [Address type]. The selected addresses
are displayed in the list.
3
Detailed information for the address appears.
Operating Procedures
2. Check the detailed information for the selected
address.
3. Press [Edit], and then press [Modify].
IMPORTANT
• When you add shared folders to groups, do not add multiple
shared folders with different access privileges to one group.
• Using a group to simultaneously send to shared servers and
the like and multiple shared folders with different access
privileges may result in a send error.
❏ Modifying an Address
Modify an address when there is a send error because the
information of the transfer destination registered for the
address is wrong or has been changed.
1. Select the type of the address to modify and press
[Details].
The edit screen for the address appears.
4. Modify the address.
Hint
For details on editing items, see “Registering a New Address”
on p. 3-19.
3-21
❏ Copying an Address
You can copy addresses between My Address Book and
Shared Address Book.
1. Select the address book entry to copy.
2. Select the address, press [Edit], and then press
[Copy].
4. Press [New] and paste the address.
Hint
If the address book already has an address with the same name
as the pasted one, the following message appears.
The selected address is copied to memory.
3. Select the address book type, press [Edit], and then
press [Paste].
• If you select [New], an address with the same name is created
in the address book.
• If you select [Overwrite], the existing address with the same
name is overwritten.
A confirmation message appears.
3-22
9. Scan/Delivery Options
This section describes the scan settings and send settings for the scanner.
c
a
b
e
j
g
h
a Address Display Area
Displays the selection that you made on the address
selection screen or the addresses registered to the job
button.
b Details
Displays detailed information for the address with the
colored background.
c Scan Settings
Sets the scan conditions. (See “Scan Settings” on p. 3-24.)
d Detailed settings
Configures detailed settings for scan conditions. (See
“Detailed Settings” on p. 3-25.)
e File format
Checks the displayed file format and press the [File
format] button to configure the settings. (See “File
Formats” on p. 3-27.)
f Delivery Options
Sets the send conditions. (See “Delivery Options” on
p. 3-29.)
g [Default] button
Resets any modified settings to the default values of the
scanner.
IMPORTANT
If you press [Default] in the Scan/Delivery Options screen
opened from a job button, the settings are reset not to the
setting values registered to the job button, but to the default
values of the scanner.
h [Start] button
Starts scanning.
i [Prescan] button
When scanning starts, the first page of the document is
scanned and then scanning stops. You can view the image
of the first page to check and adjust the brightness and
contrast before scanning the entire document.
Hint
• Scanning pauses after the first page of the document is
scanned, and the image of the first page is displayed.
• Use the displayed image to confirm and adjust the brightness
and contrast. Press [Continue] to confirm the adjusted
brightness and contrast for the first image and continue
scanning.
j [Back] button
Returns the display to the previous screen.
3-23
Operating Procedures
f
3
d
i
❏ Scan Settings
Resolution
The scan settings include basic condition settings (page
size, mode, resolution, scanning side, and brightness) and
detailed settings for scanning.
Basic Condition Settings
Paper size
Mode
Resolution
Select the resolution for scanning.
Scanning Side
Select the method for scanning the document (Simplex,
Duplex, Skip Blank Page).
Hint
Scanning
side
• The Skip Blank Page option scans both sides of a document
and skips saving any image it determines to be a blank page.
• Selecting Skip Blank Page enables the skip blank page setting
in the detailed settings. (See “Skip Blank Page” on p. 3-25.)
Brightness
Adjust the brightness to match the density of the
document.
Hint
Paper Size
Select the size of the document you want to scan.
Hint
Select [Auto size] to automatically detect the size of the
scanned document.
Mode
Select the mode for scanning.
IMPORTANT
The selection of modes is limited depending on the setting set
for File Format (see p. 3-27).
TIFF
3-24
JPEG
PDF
When you want to scan both sides of a document that has front
and back sides of different densities, you can change the
settings for the brightness of the front side and back side
separately in the detailed settings and then perform scanning.
Detailed Settings
Press the [Detailed settings] button to open the Detailed
Settings screen.
Double feed detection by length
The scanner detects by document length when two or more
documents are fed together, and stops feeding when a
double feed is detected.
IMPORTANT
• Using the length of the first page of the document as a
reference, the scanner determines a double feed when it
detects a document with a length at least 35 mm longer or
shorter than the reference length.
• Set [Double feed detection by length] to [OFF] when scanning
a document that contains pages of different lengths.
Skip Blank Page
3
Operating Procedures
When [Skip Blank Page] is selected in the scanning side
settings, this setting is enabled, and you can adjust the
sensitivity level for skipping blank pages.
Double feed detection by Ultrasonic (Only
Available with the ScanFront 220P)
The scanner uses an ultrasonic sensor to detect when two
or more documents are fed together, and stops feeding
when a double feed is detected.
Hint
• The initial value for the Skip Blank Page option is set to “90.”
• As you lower the value from the default setting, pages of the
document with text become more likely to be skipped as well.
• As you raise the value from the default setting, pages of the
document that are blank become less likely to be skipped.
IMPORTANT
• This method is effective when documents overlap by 50 mm
or more. It does not function if only a slight portion of the
document is overlapping.
• When using the ScanFront 220, the [Double feed detection by
Ultrasonic] setting is set to [OFF].
3-25
Document orientation
IMPORTANT
If you select [Prefer Quality], the scanning speed is reduced. If
you are scanning a large number of pages, select [Prefer
Speed] to prevent a decrease in scanning speed.
Bleed-through reduction
Rotates the scanned image a specified amount.
Hint
If you select [Auto], the orientation of text within the document is
detected and the image is rotated so that the orientation of the
text is correct.
Deskew
Eliminates bleed-through images, in which images on the
reverse side of a scanned document appear on the scanned
page, such as when scanning thin documents with text or
images on both sides.
Hint
When using bleed-through reduction, adjust the bleed-through
reduction level to match the type of document.
Contrast
The scanner detects from the scanned image that the
document was fed askew and then straightens the image.
• Prefer Quality
Image processing is performed to minimize the loss of
quality of an image that has deteriorated as result of
deskewing.
• Prefer Speed
The image deteriorates slightly as a result of deskewing.
3-26
Adjust the contrast for the images to scan.
Back side Brightness/contrast
❏ File Formats
You can select from the three available file formats TIFF,
JPEG, and PDF, and the modes available for scanning
vary, depending on the file format setting. (See “Mode” on
p. 3-24.)
TIFF format
3
Front side (Back side) color drop-out
Select [Single page (Front/back separate file)] to save each
side of each page as a separate image file, [Single page
(Front/back same file)] to save each page as a separate
image file, or [Multi page] to save one image file
containing multiple pages when scanning multiple pages.
JPEG format
The color drop-out function has a “drop-out” effect that
leaves out a specified color (red, blue, or green) while
scanning, and a “color enhancement” effect that
emphasizes a specified color. You can set each of these
effects for the front side and back side.
IMPORTANT
The color drop-out settings are disabled when the scanning
mode is set to [Color].
Select the compression rate for JPEG compression.
3-27
Operating Procedures
This is enabled when you scan both sides of a document
and should be used when the document has front and back
sides of different density. Select [Use back side brightness
(contrast)] to change the settings for the brightness and
contrast of the front and back sides of the document.
PDF format
❏ Security Settings for PDF Files
Security is implemented for PDF files with the encryption
and password settings in the security settings.
Configure the following settings for saving in PDF format.
• Compression
Select the compression method.
• Quality
Adjust the quality for the specified compression method.
• Multi page settings
Select [Single page (Front/back separate file)] to save
each side of each page as a separate image file, [Single
page (Front/back same file)] to save each page as a
separate image file, or [Multi page] to save one image
file containing multiple pages when scanning multiple
pages.
• OCR (Character Recognition)
If OCR is set to On, character recognition is performed
for the text within the scanned document, and the text is
embedded in the PDF file as text information.
The [Language setting] button enables you to select the
language for character recognition.
• Encryption (Security)
If you set encryption to On and then press the [Security
settings] button, the Security settings screen appears, and
you can configure the security settings for the PDF file.
For details, see “Security Settings for PDF Files” on
p. 3-28.
3-28
Encryption Level
High (128-bit RC4) and low (40-bit RC4) level encryption
settings are available.
IMPORTANT
Setting encryption to the high (128-bit RC4) level is
recommended. The low (40-bit RC4) encryption level provides
less security.
Requires a password to open the document
Viewing of the document is restricted by a password.
IMPORTANT
Take care not to forget the password once it is set. If you forget
the password, the document can no longer be opened.
Use permissions password to restrict editing
security settings
❏ Delivery Options
The following settings are restricted by the permissions
password.
• Printing allowed
This permits printing of the PDF file with a printer.
• Changes allowed
This permits editing of the PDF file; for example, adding
and deleting pages.
• Enable copying of text, images, and accessibility.
This enables the copying of text information embedded
with OCR software and reading of the PDF file with
voice software.
• Password protection is recommended when the permissions
of the PDF file are restricted.
• You can use applications such as CapturePerfect to change
the permissions or cancel password protection.
• You can change the permissions and cancel password
protection for a password protected PDF file in an application
capable of editing PDF files such as Adobe Acrobat.
E-mail settings (subject, message)
Set the subject and message for sending via e-mail.
File name
Specify a name for the image file to be sent using letters
(A-Z, a-z) and numbers (0-9).
Auto file name
The scanner adds 17 digits that indicate the date and time
to the file name of the image to be sent.
Ex.) May 14, 2007, 3:40:30 p.m.
yyyymmdd: File name + 20070514154030123
mmddyyyy: File name + 05142007154030123
ddmmyyyy: File name + 14052007154030123
* The last three digits indicate the number of milliseconds.
IMPORTANT
• Make sure you set either [File name] or [Auto file name]. A
message appears if you do not enter a file name and then set
[Auto file name] to [None].
• If you select [Single page] of TIFF format, or JPEG format, a
4-digit sequential number starting with “0000” is added
automatically to the end of file names.
3-29
Operating Procedures
IMPORTANT
3
Action when the same named file exists
Screen after sending
Set the action to perform when there is already a file of the
same name at the destination.
• Display a message
Display a message to confirm overwriting of the file.
• Abort sending
Cancel sending.
• Overwrite the file
Overwrite the file at the destination.
Select the screen to display after sending images.
• Home screen (Job Button screen)
Redisplay the Home screen (Job Button screen) after
sending images.
IMPORTANT
• The [Screen after Login] setting that is set via the Web menu
by the user applies to the Home screen (Job Button screen)
setting.
• The Job Button screen is displayed for a user for which use of
the Home screen is restricted by the ScanFront administrator.
• Logout
The user is logged out after sending images.
• Select screen after sending
A dialog box for selecting the screen after sending
images is displayed.
Hint
When no user is registered, the Logout option does not appear.
Send the files immediately after scanning
Send images without checking them when scanning
completes.
Confirm addresses before sending
Confirm the addresses before sending images when
scanning completes.
3-30
Chapter 4 Web Menu (User Mode)
1. Web Menu Overview........................................ 4-2
2. Logging In to the Web Menu............................ 4-3
3. User Settings ................................................... 4-4
User Settings.........................................................4-5
4. Address Book Settings..................................... 4-6
Registering New Addresses..................................4-8
Copying Addresses .............................................4-10
Exporting and Importing Address Books.............4-11
5. Job Button Settings........................................ 4-12
Registering New Job Buttons..............................4-14
Scan Settings Overview ......................................4-15
Copying Job Buttons ...........................................4-19
Exporting and Importing Job Buttons ..................4-19
1. Web Menu Overview
The Web Menu function enables you to access and configure the scanner from the Web browser of a remote computer. From the
Web Menu, you can register address books and job buttons.
Computer (Web Menu)
Settings
Network
ScanFront220
IMPORTANT
• For a Web browser, use Microsoft Internet Explorer 6.0 or later.
• In some cases, settings cannot be changed from the Web Menu when the ScanFront administrator or another user is logged in to the scanner.
• Use the device name or IP address assigned to the scanner as the URL for logging in to the Web Menu. (See p. 4-3.)
Web Menu (User Mode)
a
b
c
a User Settings (See “User Settings” on p. 4-5)
Use to change the user settings.
b Address Book Settings (See “Address Book Settings”
on p. 4-6)
Use to register and manage entries in the Shared Address
Book available to all users, and the My Address Book
provided for each user.
4-2
c Job Button Settings (See “Job Button Settings” on
p. 4-12)
Use to register and manage the Shared Job Button
available to all users, and the My Job Button provided for
each user.
2. Logging In to the Web Menu
You can log in to the Web Menu using the following procedure.
Hint
Use the device name or the IP address assigned to the scanner as the URL for accessing the Web Menu. Contact the ScanFront administrator
for the device name and the IP address.
1. Turn the scanner ON.
2. Confirm the IP address with the administrator.
from an account registered on the scanner (Device
Authentication). For details, consult the ScanFront
administrator.
3. Launch the Web browser on the computer.
4. Enter the device name or the IP address as the URL
to open the Web Menu.
Ex.) http://scanfront220 when the device name is ScanFront220,
and http://172.19.xxx.xxx for the IP address.
4
Menu.
Hint
If the Web Menu is set to Administrator Mode, click [To User
Mode].
IMPORTANT
IMPORTANT
User names and passwords are case-sensitive. Make sure to
enter them correctly.
If [Authentication Method] appears above [User name] on the
login screen, users can log in from an account registered on a
domain server (Server Authentication), instead of logging in
4-3
Web Menu (User Mode)
5. Enter a user name and password to log in to the Web
3. User Settings
From the User Settings screen, you can change the information of a user logged in by Device Authentication.
a
a Setting (See “User Settings” on p. 4-4)
Allows you to edit a user’s settings.
IMPORTANT
• For a user logged in by Server Authentication, you can only select a setting for [Screen after Login].
• E-mail address may not be registered for a user logged in by Server Authentication. For details on e-mail address settings, consult the
ScanFront administrator.
4-4
❏ User Settings
Click [Setting] to edit the user information.
Screen after Login
Select the Home screen or the Job Button screen as the first
screen to appear after the user logs in.
• Home Screen
4
User name
Enter a new user name.
• Job Button Screen
Web Menu (User Mode)
Change Password
Select the [Change Password] check box, and then enter
the new password and confirmation password.
Mail Address (Not Changeable)
To change the e-mail address, contact the ScanFront
administrator.
SMTP/POP Before SMTP Authentication
Appears when [Auth Method] is configured to any setting
other than [SMTP] by the administrator in the mail server
settings. Enter the [User name] and [Password] that will be
used for mail server authentication here.
For details on mail server settings, consult the ScanFront
administrator.
IMPORTANT
• When entering a [Password], select the [Change Password]
check box before entry.
• [Change Password] updates the password information saved
on the scanner, but does not alter the password registered on
the server.
IMPORTANT
• The setting for the startup screen after login also affects which
screen appears after a scanned image is sent. (See “Delivery
Options” on p. 4-15.)
• If the ScanFront administrator has restricted use of the Home
screen, only [Job Button screen] is available for the [Screen
after Login] setting. For details, consult the ScanFront
administrator.
[OK] button
Updates the user information with the changed settings.
4-5
4. Address Book Settings
From the Address Book Settings screen, you can register entries in the Shared Address Book, which is available to all users, and
the My Address Book, which is provided for each user.
a
d
e
b
f
g
c
h i
j
a Type of Address Book
Selects the address book (Shared Address Book or My
Address Book) to edit.
The LDAP Address Book is also selectable if the address
book server settings are enabled and permission to use the
LDAP address book has been granted to the user. The
address type is set to [E-mail] when the LDAP Address
Book is selected.
b Export from ScanFront 220
Exports the address book data as a file in CSV format. (See
“Exporting and Importing Address Books” on p. 4-11.)
c Import to ScanFront 220
Imports a previously exported address book data file. (See
“Exporting and Importing Address Books” on p. 4-11.)
d Address type
Selects the type of addresses (E-mail, FTP Server, Shared
folder, Group, or All) to display.
e [New Address] button
Registers a new address book entry.(See “Registering New
Addresses” on p. 4-8.)
4-6
f [Select All] button
Selects all of the displayed addresses.
g [Except All] button
Deselects all of the displayed addresses.
h [Copy] button
Copies the selected address. Only enabled when an
address is selected. (See “Copying Addresses” on p. 4-10.)
i [Delete] button
Deletes the selected address. Only enabled when an
address is selected.
j Address List
Displays the registered addresses.
• Check box: Select this check box to select an address.
• Address type (icon)
: FTP
: Shared folder
: E-mail
: Group
• Edit: Click to edit an address.
IMPORTANT
If the ScanFront administrator has restricted editing of the address books, the following Address Book settings apply. For details, consult the
ScanFront administrator.
• If editing is restricted for only one address book (either the My Address Book or the Shared Address Book), users can only copy addresses
from the restricted address book and paste them into the unrestricted address book.
4
Web Menu (User Mode)
• If editing is restricted for both the My Address Book and the Shared Address Book, users can only view detailed address information.
4-7
❏ Registering New Addresses
Select the type of address book (Shared Address Book or
My Address Book), and click [New Address] to register a
new address.
Address type: FTP Server
This option registers a network FTP server.
IMPORTANT
FTP servers that require firewall settings cannot be registered.
Hint
• The number of addresses that can be registered to the Shared
Address Book (My Address Book) is up to 1000 in combination
with the total number of addresses included in the Shared Job
Button (My Job Button).
• For the number mentioned above, the count for a group is the
number of addresses registered to the group (maximum of 99
addresses) plus the group name, so a group with 99
addresses registered to it is counted as having 100
addresses.
• The available settings vary, depending on the type of address
(E-mail, FTP Server, Shared folder, Group, or All).
Name
Enter the name to display on the scanner.
Address type: E-mail
This option registers an e-mail address.
FTP server
Enter the IP address or host name of the FTP server.
Folder path
To specify a subfolder on the FTP server, enter the path to
the subfolder.
Hint
Name
Enter the name to display on the scanner.
E-mail Address
If you are unsure of the subfolder’s path, use the following
procedure to specify the subfolder:
1. After entering the [FTP server], [User name], and [Password],
click [Browse] and log in to the FTP server.
2. In the folder that appears, specify any subfolder and click
[OK].
Enter the destination e-mail address.
User name/Password
[OK] button
Enter the user name and password required to log in to the
FTP server.
Registers a new e-mail address with the specified
parameters.
IMPORTANT
Make sure to enter the user name and password of an account
with the authority to write data to the FTP server.
Port number
Enter the port number. The standard port number is 21.
4-8
Save Password
Saves the entered password.
Passive Mode
Uses passive mode to send transmissions to the FTP
server.
IMPORTANT
Use passive mode when normal communication with the FTP
server cannot be established. However, be aware that
communication may not be possible if the network is not
functioning properly.
[OK] button
Registers a new FTP server with the specified parameters.
Address type: Shared folder
This option registers a folder shared publicly on the
network.
Hint
You can display the shared folders using the following
procedure.
1. After entering the computer name, user name, password,
and domain/workgroup, click [Browse]. Access the computer
containing the publicly shared folder.
2. Specify any subfolder from the displayed computer and click
[OK].
IMPORTANT
User name/Password
Enter the user name and password of an account with the
authority to write data to the shared folder.
Domain/Workgroup
Name
Enter the name to display on the scanner.
Computer Name (Host Name)
Enter the name of the computer containing the publicly
shared folder.
Folder path
Enter the path to the subfolder that you want to register as
the name of the shared folder.
If the computer containing the shared folder is part of a
domain, enter the domain name.
IMPORTANT
• If the computer containing the publicly shared folder is part of
a domain, enter the user name and password registered with
the domain, and the domain name.
• If the computer containing the publicly shared folder is not part
of a domain, there is no need to enter a [Domain/Workgroup].
Save Password
Select this check box to save the password to the address.
[Browse] button
Shows a list of computers connected to the network for
you to specify a shared folder.
4-9
4
Web Menu (User Mode)
• If you click [Browse] without entering the user account
information, only computers and workgroups within the same
network address will display.
• When displaying workgroups that are not part of a domain,
you cannot display computers or workgroups with different
network addresses.
• Not all workgroups and computers in the network can be
displayed immediately after the ScanFront is started. If some
workgroups and computers are not displayed, wait a few
minutes and then press [Browse].
• A new folder cannot be created in a specified folder via the
Web Menu. If you want to create a new folder, use the
computer set as the FTP server or the address editing
functions of the ScanFront to create a folder beforehand.
IMPORTANT
If you do not save the password, password entry will be required
each time you send.
[OK] button
Registers a new shared folder with the specified
parameters.
❏ Copying Addresses
You can copy an address and register it as a new address.
You can also copy an address from one address book to
another.
As an example, this section describes how to copy from the
Shared Address Book to the My Address Book.
Hint
Address type: Group
This option registers several registered addresses together
as a group.
Hint
Different types of address, such as e-mail addresses and
shared folders, can be registered as a group, and up to 99
addresses can be registered to 1 group.
Use this function when you want to copy an address between
the Shared Address Book and My Address Book or copy an
address and register it as a different address in the same
address book after changing some of the settings.
1. Select Shared Address Book for the [Type of Address
Book].
2. Add a checkmark to the check box of the address you
want to copy and then click [Copy].
Name
Enter the name to display on the scanner.
Add from Address Book
Allows you to select an address from an address book, add
it to the group, and display it in the list.
[OK] button
Registers a new group with the specified parameters.
4-10
3. Select My Address Book for the copy destination, and
click [OK].
4. Confirm the copied address.
Importing to the Scanner
You can import previously exported address book data to
the scanner.
1. Click [Import to ScanFront 220].
❏ Exporting and Importing Address Books
You can back up your address books as files in CSV
format, and import the backed up address book data to
another ScanFront unit.
Hint
If you have multiple ScanFront units, you can use the same
address books on all of them by importing the address book
settings file registered on one ScanFront unit to the other units.
Exporting from the Scanner
1. Click [Export from ScanFront 220].
address book settings file.
3. Select a processing method for importing the
address book settings file.
• Replaces the whole data: Deletes all currently
registered address book entries and overwrites them with
the imported address book data.
• Appends data: Adds the imported address book data to
the currently registered address book.
4. Click [Execute].
Confirm the message that appears, and click [OK] to
import the data.
2. Click [Save], specify a save location, and save the
address book data.
Hint
• You can open the saved CSV file with software that supports
CSV files such as spread sheet software in order to check the
structure of the file.
• You can match the structure of a CSV file created in another
mailer to that of a CSV file saved on the ScanFront, and then
import the address book of the other mailer and use it on the
ScanFront.
Hint
When importing is completed, the following message appears.
Click [OK] to return to Address Book Settings and confirm the
imported address data.
4-11
4
Web Menu (User Mode)
You can save the address book data to a specified folder.
2. Click [Browse] and specify a previously exported
5. Job Button Settings
From the Job Button Settings screen, you can register the Shared Job Button, which is available to all users, and the My Job Button,
which is provided for each user.
a
d
b
e
f
c
g h
i
a Job Button Type
Select the job button (Shared Job Button or My Job
Button) that you want to edit.
b Export from ScanFront 220
Exports the job button data as a file in DAT format. (See
“Exporting and Importing Job Buttons” on p. 4-19.)
c Import to ScanFront 220
Imports a previously exported job button data file. (See
“Exporting and Importing Job Buttons” on p. 4-19.)
d [New Job Button] button
Registers a new job button. (See “Registering New Job
Buttons” on p. 4-14.)
e [Select All] button
Selects all of the displayed job buttons.
4-12
f [Except All] button
Deselects all of the displayed job buttons.
g [Copy] button
Copies the selected job button. Only enabled when a job
button is selected. (See “Copying Job Buttons” on
p. 4-19.)
h [Delete] button
Deletes the selected job button. Only enabled when a job
button is selected.
i Job Button List
Displays the registered job buttons.
• Check box: Select this check box to select a job button.
• Edit: Click to edit a job button.
IMPORTANT
If the ScanFront administrator has restricted editing of the job buttons, the following Job Button settings apply. For details, consult the ScanFront
administrator.
• If editing is restricted for only one set of job buttons (either the My Job Button or the Shared Job Button), users can copy job buttons from the
restricted set of job buttons and paste them into the unrestricted set.
4
Web Menu (User Mode)
• If editing is restricted for both the My Job Button and the Shared Job Button, users can only view detailed job button information.
4-13
❏ Registering New Job Buttons
Address
Click [New Job Button] to register a new job button.
Job Button Settings
Click [Add from Address Book], open the Address page,
and select the address to send to.
IMPORTANT
Name of Job Button
Enter the job button name to display on the touch panel.
Hint
• Job buttons are sorted and displayed by job button name. If
you want to set to display job buttons in a particular order,
insert sequential letters or numbers before the name when
registering each job button. Ex.) 01_xxxx
• If you enter a job button name that is two lines long, the job
button display will be two lines long.
Color of Job Button
Specify a color for the job button.
When you select this Job Button
• Display Scan Setting Screen
Displays the Scan Setting screen when the job button is
pressed.
• Skip Scan Setting Screen
Starts scanning without displaying the Scan Setting
screen when the job button is pressed.
IMPORTANT
If you select [Skip Scan Setting Screen], scanning starts as
soon as the job button is pressed, whether a document is
inserted or not.
4-14
• You can register up to 100 addresses to a job button.
• For the number mentioned above, the count for a group is the
number of addresses registered to the group (maximum of 99
addresses) plus the group name, so a group with 99
addresses registered to it is counted as having 100
addresses.
Scan Settings/Detailed settings
For details on Scan Settings/Detailed settings, see “Scan
Settings Overview” on p. 4-15.
E-mail settings
Confirm addresses before sending
Subject
• ON
Displays the Address Confirmation screen, and then
starts sending after you confirm the address.
• OFF
Sends the image without confirming the address.
Enter a subject for the e-mail message.
Screen after sending
Message
Select the screen to display after an image is sent.
• Initial Screen
Returns to the startup screen set for [Screen after Login]
in the User Settings.
• Logout
Logs out after the images are sent.
• Select screen after sending
Displays a message dialog for selecting from the above
actions after the images are sent.
Enter the text of the e-mail message.
Delivery Options
Action when the same named file exists
❏ Scan Settings Overview
The scan settings include basic and detailed settings for
scanning parameters and individual settings by file format.
Scan Settings
Send the files immediately after scanning
• ON
Starts sending when scanning completes.
• OFF
Starts sending after you confirm the scanned image when
scanning completes.
Page Size
Select the size of the document to scan from the list.
Hint
The [Auto size] option automatically detects the size of the
scanned document during scanning.
4-15
Web Menu (User Mode)
Select the action to take when a file of the same name
exists at the destination.
• Display a message
Displays a message confirming that the file will be
overwritten.
• Abort sending
Cancels sending.
• Overwrite the file
Overwrites the identically named file without displaying
a confirmation message.
4
Mode
Prescan
Select the scanning mode (Black and White, Error
Diffusion, Text enhance, Gray, Color).
Enables you to preview an image of the first page of the
document before scanning the entire document.
IMPORTANT
Hint
Depending on the selected mode, the file formats available for
saving may be limited. A warning message appears when an
unavailable combination is selected.
Black and White
TIFF
JPEG
PDF
Yes
No
Yes
• Scanning pauses after the first page of the document is
scanned, and the image of the first page is displayed.
• Use the displayed image to confirm and adjust the brightness
and contrast. Press [Continue] to confirm the adjusted
brightness and contrast for the first image and continue
scanning.
Error Diffusion
Yes
No
Yes
File name
Text enhance
Yes
No
Yes
Gray
No
Yes
Yes
Specify a name for the image file to be sent using letters
(A-Z, a-z) and numbers (0-9).
Color
No
Yes
Yes
Resolution (dpi)
Select the scanning resolution (100, 150, 200, 300, 400, or
600 dpi).
Scanning Side
Select the method for scanning the document (Simplex,
Duplex, Skip Blank Page).
Hint
• The Skip Blank Page option scans both sides of a document
and skips saving any image it determines to be a blank page.
• You can adjust the sensitivity of the Skip Blank Page option
under [Contents detection sensitivity].
• The initial value for the Skip Blank Page option is set to “90.”
As you lower the value from the default setting, pages of the
document with text become more likely to be skipped as well.
As you raise the value from the default setting, pages of the
document that are blank become less likely to be skipped.
4-16
Add Date to File name
The scanner adds 17 digits that indicate the date and time
to the file name of the image to be sent.
Ex.) May 14, 2007, 3:40:30 p.m.
yyyymmdd: File name + 20070514154030123
mmddyyyy: File name + 05142007154030123
ddmmyyyy: File name + 14052007154030123
* The last three digits indicate the number of milliseconds.
File format
Select a file format for the image file, and configure the
corresponding settings.
TIFF: Multi page settings
Select [Single page (Front/back separate file)] to save each
side of each page as a separate image file, [Single page
(Front/back same file)] to save each page as a separate
image file, or [Multi page] to save one image file
containing multiple pages when scanning multiple pages.
JPEG: Compression
Encryption (Security)
Use encryption to add security to the PDF file.
IMPORTANT
Using the High (128-bit RC4) encryption level is recommended.
The Low (40-bit RC4) encryption level provides less security.
Protect Document
Select a compression ratio for images saved in JPEG
format.
PDF:
Configure the settings for compression ratio, multi page,
OCR (optical character recognition), and encryption
security.
The ability to view the document is protected by a
password.
IMPORTANT
Take care not to forget the password once it is set. If you forget
the password, the document can no longer be opened.
Protect Permission
Permissions for printing and editing the PDF file are
protected by a password.
Printing allowed
4
Enables the PDF file to be printed from a printer.
Enables editing of the PDF file, such as adding or deleting
pages.
Enable copying of text, images, and
accessibility
Compression Method
Specify a compression level by selecting [Standard] or
[High Compression] as the compression method.
OCR (Optical Character Recognition)
When OCR is set to [ON], the scanner performs character
recognition on textual portions of the document, and
embeds the detected characters as editable text
information in the PDF file.
Enables text information embedded by OCR to be copied
and the PDF file to be read aloud by text-to-speech
software.
IMPORTANT
• Protecting PDF file permissions is recommended when the
permissions have been restricted.
• You can change the permissions and cancel password
protection for a password protected PDF file in an application
capable of editing PDF files such as Adobe Acrobat.
Hint
When you set OCR to [ON], make sure to select the OCR
language that matches the document text.
4-17
Web Menu (User Mode)
Changes allowed
Detailed settings
Double feed detection by length
The scanner detects by document length when two or more
documents are fed together, and stops feeding when a
double feed is detected.
IMPORTANT
• Using the length of the first document page as a reference, the
scanner detects a double feed when a subsequent page is
longer or shorter than the reference page by 35 mm or more.
• Set [Double feed detection by length] to [OFF] when scanning
a document that contains pages of different lengths.
IMPORTANT
The [Double feed detection by Ultrasonic] setting only appears
when using the ScanFront 220P.
Brightness (Front)
Adjusts the brightness of the image to be scanned.
Brightness (Back)
Enabled for duplex scanning. Use this option when the
front and back sides of a document are shaded differently.
To change the brightness settings for the front and back
sides, clear the [Same as front] check box.
Contrast (Front)
Adjusts the contrast of the image to be scanned.
Contrast (Back)
Enabled for duplex scanning. Use this option when the
front and back sides of a document are shaded differently.
To change the contrast settings for the front and back sides,
clear the [Same as front] check box.
Double feed detection by Ultrasonic (Only
available with the ScanFront 220P)
The scanner uses an ultrasonic sensor to detect when two
or more documents are fed together, and stops feeding
when a double feed is detected.
IMPORTANT
This method is effective when documents overlap by 50 mm or
more. It does not function if only a slight portion of the document
is overlapping.
4-18
Document orientation
Rotates the scanned image to the specified angle.
Hint
When [Auto] is selected, the scanner detects text orientation
within the document and rotates the image so that the
orientation of the text is correct.
Deskew
Detects when a document has been fed askew from the
scanned image, and then straightens the image.
• Prefer Quality
Image processing is performed to minimize the loss of
quality of an image that has deteriorated as result of
deskewing.
• Prefer Speed
The image deteriorates slightly as a result of deskewing.
IMPORTANT
If you select [Prefer Quality], the scanning speed is reduced. If
you are scanning a large number of pages, select [Prefer
Speed] to prevent a decrease in scanning speed.
Bleed-through reduction
Eliminates bleed-through images, in which images on the
reverse side of a scanned document appear on the scanned
page, such as when scanning thin documents with text or
images on both sides.
Hint
When using bleed-through reduction, adjust the bleed-through
reduction level to match the type of document.
Color drop-out
The color drop-out function has a “drop-out” effect that
leaves out a specified color (red, blue, or green) while
scanning, and a “color enhancement” effect that
emphasizes a specified color.
3. Select My Job Button for the copy destination, and
click [OK].
IMPORTANT
The color drop-out setting is disabled when the scanning mode
is set to [Color].
Hint
The OCR recognition rate is sometimes improved by deleting
colored ruled lines and other objects with the color drop-out
function.
4. Confirm the copied job button.
❏ Copying Job Buttons
4
Hint
Use this function when you want to copy a job button between
the Shared Job Button and My Job Button or register it as a
different job button after changing some of the settings.
1. Select Shared Job Button for the [Job Button Type].
2. Select the job button you want to copy, and click
[Copy].
❏ Exporting and Importing Job Buttons
You can back up your job button data as a settings file in
DAT format, and import the backed up job button settings
file to another ScanFront unit.
Hint
If you have multiple ScanFront units, you can use the same job
buttons on all of them by importing the job button settings file
registered on one ScanFront unit to the other units.
4-19
Web Menu (User Mode)
You can copy the settings of a job button and register it as
a new job button.
As an example, this section describes how to copy from the
Shared Job Button to the My Job Button.
Exporting from the Scanner
You can save the job button settings file to a specified
folder.
4. Click [Execute].
Confirm the message that appears, and click [OK] to
import the data.
1. Click [Export from ScanFront 220].
Hint
When importing is completed, the following message appears.
Click [OK] to return to Job Button Settings and confirm the
imported job button.
2. Click [Save], specify a save location, and save the job
button settings file.
Importing to the Scanner
You can import a previously exported job button settings
file to the scanner.
1. Click [Import to ScanFront 220].
2. Specify a previously exported job button settings file.
3. Select a processing method for importing the job
button settings file.
• Replaces the whole data: Deletes all currently
registered job buttons and overwrites them with the
imported job buttons.
• Appends data: Adds the imported job buttons to the
currently registered job buttons.
4-20
Chapter 5 Troubleshooting
1. Troubleshooting ............................................... 5-2
1. Troubleshooting
If any of the following problems occurs, solve the problem as described in the corresponding solution.
Cause
Cannot use an LDAP address
book (certain users only)
Solution
Cannot update the settings in
the Web menu
Solution
Cause
Cause
Cannot access the Web menu
Cannot create a new folder
(shared folder/FTP server)
Specifying a mail address as the
address and then starting
scanning results in an error
Cannot edit the address book/
job buttons (certain users only)
Paper jams occur frequently
Can only select certain
destinations. For example, can
only select shared folders
(certain users only)
5-2
The ScanFront is being used or a user has not logged out.
Check the ScanFront status and then try again.
The IP address assigned from the DHCP server has changed.
Contact the administrator of the ScanFront, and check the IP address
assigned to the ScanFront.
Cause
Permission to write to the shared folder has not been granted for the
user name and password that were entered.
Solution
Cause
Solution
Cause
Solution
Solution
Cause
Paper becomes jammed
Contact the administrator of the ScanFront.
Solution
Cause
Streaks appear in images
The administrator has set user function restrictions.
Solution
Cause
Solution
Cause
Solution
Contact the administrator of the shared folder.
The mail server settings have not been registered, or have been deleted.
Contact the administrator of the ScanFront.
The administrator has set user function restrictions.
Contact the administrator of the ScanFront.
The scanning glass is dirty.
Refer to the ScanFront 220/220P INSTRUCTIONS (electronic manual)
and clean the scanning glass. If there are scratches on a scanning glass,
contact your local authorized Canon dealer.
The rollers are dirty.
Refer to the ScanFront 220/220P INSTRUCTIONS (electronic manual)
and clean the rollers.
The rollers (consumable parts) have worn out.
Contact the administrator of the ScanFront and then replace the rollers.
The administrator has set user function restrictions.
Contact the administrator of the ScanFront.
Documents are double fed
Cause
Solution
Cause
Documents are double fed
A stack of documents are fed
together
Cannot connect to an FTP
server that can be accessed
from outside the company
Scanning starts immediately
after I press a job button (certain
users only)
Solution
Cause
Solution
Cause
The feed selection lever is set to bypass feeding. (See p. 2-5.)
Set the feed selection lever to page separation feeding.
The scanner cannot connect to an FTP server that requires firewall
settings to be configured.
The job buttons are designed to work that way. (See p. 4-14.)
Solution
Place the document and then press a job button.
The AC adapter is not connected properly or the power plug is not
inserted.
Check the connections of the AC adapter and power plug. If the
problem is not resolved after checking the connections, contact your
local authorized Canon dealer.
Cause
(1) The date and time settings are incorrect. (2) The time zone is set to a
different country.
Solution
Contact the administrator, and check the “Language/Timezone” setting.
Cause
Solution
The e-mail addresses of the user and administrator have not been
registered.
Contact the administrator, and register the e-mail addresses.
Cause
The IP address that was set is already being used by another device.
Solution
Contact the system administrator of the network, and change the IP
address setting.
Cause
The LAN cable is not connected properly.
Solution
Check the connections of the LAN cable.
5-3
5
Troubleshooting
Cannot connect to the network
(LAN cable connection problem)
Load no more than ten pages of documents. (See p. 2-10.) Use bypass
feeding to scan the pages one by one.
Cause
Solution
Cannot connect to the network
(IP address conflict problem)
The type of paper of the documents is causing a paper feed error.
Use an FTP server that does not require firewall settings to be
configured.
Cannot turn on the power
The sender’s address is not
displayed at the destination of
an e-mail message
Before you load a stack of documents, fan the documents.
Solution
Cause
The wrong send time is
displayed for an e-mail message
received at the destination
Static electricity is causing the pages of the document to stick to each
other.
Cannot connect to the network
(device name conflict problem)
Cannot delete a folder
Cannot delete a folder
Cause
The device name that was set is already being used by another device.
Solution
Contact the system administrator of the network, and change the device
name setting. When you install two or more ScanFront scanners, take
care to ensure duplicate device names are not set.
Cause
Solution
Cause
Solution
Cannot scan from the Home
screen (certain users only)
Cause
Solution
Cause
Cannot log in
Solution
5-4
Data has been saved to the folder.
Contact the administrator of the shared folder.
Permission to change the shared folder has not been granted for the user
name and password that were entered.
Contact the administrator of the shared folder.
The administrator has set user function restrictions.
Contact the administrator of the ScanFront.
Uppercase and lowercase letters were not entered correctly.
(See p. 3-5 and p. 4-3.)
Enter the uppercase and lowercase letters for the user name and
password correctly.
Chapter 6 Index
A
Home Screen .................................................................3-8
AC Adapter ................................................................... 1-7
Address
Copying .......................................................3-22, 4-10
Modifying ............................................................. 3-21
New ................................................................3-19, 4-8
Address Book Settings .................................................. 4-6
Address Selection Screen ............................................ 3-14
Address Type
E-mail ............................................................3-19, 4-8
FTP Server .....................................................3-20, 4-8
Group ...........................................................3-20, 4-10
Shared Folder .................................................3-19, 4-9
I
Card ............................................................................... 2-3
Conceptual Diagram of the ScanFront .............................. i
Copying Job Buttons ................................................... 4-19
L
Installation Location ......................................................1-2
Introduction .......................................................................i
J
Job Button Screen ..........................................................3-8
Job Button Settings ............................................ 4-12, 4-14
Address Settings ....................................................4-14
Delivery Options ...................................................4-15
Detailed Settings ...................................................4-14
E-mail Settings ......................................................4-15
Scan Settings .........................................................4-14
K
C
Key in Type Login .........................................................3-6
List Type Login .............................................................3-5
Loading Mark ................................................................2-8
Lock Lever ...................................................................2-10
Logging In to the Web Menu ........................................4-3
Login Screen
Key in Type .............................................................3-4
List Type .................................................................3-4
Server Authentication ..............................................3-4
D
Delivery Options ......................................................... 3-29
Detailed Settings ................................................3-25, 4-18
Device Authentication ...........................................3-4, 4-3
Disposal ........................................................................ 1-5
Documents .................................................................... 2-2
Double Feed Error ........................................................ 2-9
M
E
Moving the Scanner .......................................................1-3
Eject Tray ...................................................................... 2-4
Exporting and Importing Address Books ................... 4-11
Exporting and Importing Job Buttons ......................... 4-19
F
N
Names and Functions of Parts .......................................1-6
P
Paper Jam .......................................................................2-9
Placing a Card ................................................................2-8
Placing Documents ........................................................2-7
Plain Paper .....................................................................2-2
Preparing the Scanner ....................................................2-4
PS/2 Keyboard ...............................................................2-6
PS/2 Mouse ....................................................................2-6
PS/2 Port ........................................................................2-6
Feed Selection Lever .................................................... 2-5
Feed Tray ...................................................................... 2-4
File Formats .......................................................3-27, 4-16
Fingerprint Authentication ...................................2-12, 3-7
Fingerprint Registration .............................................. 3-10
Fingerprint Sensor ................................................1-6, 2-11
Flow Up Until Sending an Image File .......................... 3-2
H
R
Handling ........................................................................ 1-3
6-2
Registering New Job Buttons ......................................4-14
S
Safety Instructions ........................................................ 1-2
Scan Settings ...................................................... 3-24, 4-15
Basic Condition Settings ...................................... 3-24
Detailed Settings .................................................. 3-25
Scan/Delivery Options ................................................ 3-23
Scanning ..................................................................... 3-16
Security Settings ......................................................... 3-28
Server Authentication ............................................ 3-4, 4-3
T
Troubleshooting ............................................................ 5-2
Turning Off the Power .................................................. 3-3
Turning On the Power .................................................. 3-3
U
USB Memory .............................................................. 3-15
USB Memory Screen .................................................. 3-15
USB Port ....................................................................... 2-5
User Settings ................................................................. 4-4
User Settings Screen ..................................................... 3-9
Change Password ................................................... 3-9
Fingerprint Registration ......................................... 3-9
W
Web Menu
User Mode .............................................................. 4-2
Web Menu Overview .................................................... 4-2
6
Index
6-3
