Network Setup Troubleshooting
Network Setup Troubleshooting
This manual mainly describes problems you may encounter when setting up a network, and the possible
causes and solutions.
Find a description related to your problem and follow the solution.
If you cannot find a description for your problem or if you encounter a problem after setup, refer to the onscreen manual: Basic Guide/Advanced Guide.
The following symbols are used in this manual.
Instructions as notes for operation or additional explanations.
Glossary
Explanation of terminology.
Description for Windows users.
Cannot Connect to the Printer
The Printer is Not Displayed (Detected) on the Canon IJ Network Tool Screen
P.1
P.1
The Printer is Not Displayed (Detected) on the Printers Screen
P.1
The Printer is Not Displayed (Detected) on the Printer Setup Utility Screen
P.1
The Printer is Not Detected after the Network Environment is Changed
P.2
Message is Displayed
during Software Installation
P.2
The Set Printer IP Address Screen is Displayed
P.2
The New port could not be created is Displayed
P.3
Other Troubleshooting Tips
P.3
Specifying the Printer's IP Address
P.3
Changing the Port Name
P.4
Restoring the Printer's Default LAN Setting to Perform Setup Again
P.4
Printing the Printer's Network Setting Information
P.4
Connection Checklist
P.5
Specifications
P.6
Description for Macintosh users.
Cannot Connect to the Printer
The Printer is Not Displayed (Detected) on the Canon IJ Network Tool
Screen
Check
The Printer is Not Displayed (Detected) on the Printer Setup Utility
Screen
Check
Make sure that you follow Check 2 and 3 of "Connection
Checklist" on page 5, then click Update (A).
Mac OS X v.10.5.x
Mac OS X v.10.4.x
Mac OS X v.10.3.9
A
Check 1
The Printer is Not Displayed (Detected) on the Printers Screen
Make sure that you follow Check 1, 2, 4 and 5 of "Connection Checklist" on page 5, then
wait a while until the printer appears.
Check
Check 2
Check 1
Is the printer connected to a network?
Print the network setting information of the printer and make sure that an IP address is
obtained.
Make sure that you follow Check 1, 2, 4 and 5 of
"Connection Checklist" on page 5, then click Update (A).
• For details on how to print the network information of the printer, refer to "Printing the Printer's
Network Setting Information" on page 4.
Check 2
Is the printer connected to a network?
Print the network setting information of the printer and
make sure that an IP address is obtained.
• For details on how to print the network information of the
printer, refer to "Printing the Printer's Network Setting
Information" on page 4.
A
If the printer is not connected to a network, perform setup again by referring to "Wired
LAN Connection" (Windows: P.23) in the printed manual: Getting Started.
If the printer is not connected to a network, perform setup again by referring to "Wired
LAN Connection" (Macintosh: P.32) in the printed manual: Getting Started.
Glossary
• IP address
A numerical identification assigned to each computer or network device connected to a network.
Glossary
• IP address
A numerical identification assigned to each computer or network device connected to a network.
Message is Displayed
The Printer is Not Detected after the Network Environment is Changed
Check
during Software Installation
The Set Printer IP Address Screen is Displayed
Check
Wait until the IP address is assigned to the computer. You may need to restart your
computer.
• Search for the printer again after confirming a valid IP address is assigned to the computer.
Glossary
• IP address
A numerical identification assigned to each computer or network device connected to a network.
A
A
Check 1
Make sure that you follow "Connection Checklist" on page 5, then click Connect (A).
Check 2
Unplug the network device (router, etc.) from the power outlet and plug it in, then click
Connect (A).
Check 3
When obtaining an IP address automatically, make sure that the DHCP function of the
network device (router, etc.) is active.
• For details on how to check settings of the network device, refer to the manual supplied with the
network device or contact its manufacturer.
Activate the DHCP function of the network device, then click Connect (A).
• For details on how to change settings of the network device, refer to the manual supplied with the
network device or contact its manufacturer.
Check 4
If the problem is not solved even after following Check 1 to 3, specify the IP address of
the printer.
• For details on how to specify the IP address, refer to "Specifying the Printer's IP Address" on page 3.
Glossary
• DHCP function
A function that automatically assigns required information (IP address, etc.) to computers connected to
the Internet.
• IP address
A numerical identification assigned to each computer or network device connected to a network.
Other Troubleshooting Tips
The New port could not be created is Displayed
Specifying the Printer's IP Address
Action
Action
Uninstall the drivers, then setup the printer again.
Assign an IP address and other values to the printer manually if, for example, there is no
DHCP function in the environment where the printer is used.
• For the setup procedure, follow the procedures in "Wired LAN
Connection" (P.23) and onward in the printed manual: Getting Started.
A
A
B
B
C
C
1
2
Select Use next IP address (A).
1
2
Select Use following IP address in TCP/IP Setting (A).
Enter the value you want to specify for each of IP Address, Subnet Mask and
Default Gateway (B), then click Connect (C).
Enter the value you want to specify for each of IP Address, Subnet Mask and
Router (B), then click Connect (C).
Glossary
• DHCP function
A function that automatically assigns required information (IP address, etc.) to computers connected to
the Internet.
• IP address
A numerical identification assigned to each computer or network device connected to a network.
• Subnet mask
A number used to distinguish the network and host portions of an IP address.
• Default gateway
A device required to connect to external networks.
• The printer cannot be used on external networks such as the Internet.
Changing the Port Name
Restoring the Printer's Default LAN Setting to Perform Setup Again
Note
Action
By changing the port name, you can change the name of the printer.
Use the RESUME/CANCEL button on the printer to restore the default state.
• When you set up an additional computer to use the printer whose port name you changed, the
printer is displayed with the changed port name. When two or more computers are set up, the
changed name is displayed.
When multiple computers or printers are present, this can be used to change the name to one that
is easy to remember.
1
2
Action
Disconnect the LAN cable.
Hold down the RESUME/CANCEL
button (A) on the printer until
the POWER lamp (B) flashes 10
times, then release the RESUME/
CANCEL button after the tenth
flash.
B
A
The port name can be changed by the following procedure.
1
2
Click Set Port Name in the Setup Completion
dialog box.
• The Set Port Name dialog box is displayed.
Change the port name.
• Port names should consist of alphanumeric characters and be no longer than 21 characters,
excluding the prefix.
• The port name includes the fixed prefix "CNBJNP_", which you do not need to enter.
The LAN setting of the printer is now restored to the default state.
• Perform setup again by following the procedures in "Wired LAN Connection" (Windows: P.23,
Macintosh: P.32) and onward in the printed manual: Getting Started.
<Default State>
TCP/IP setting
Obtain an IP address automatically
Printing the Printer's Network Setting Information
Action
Use the RESUME/CANCEL button on the printer to print the network setting information.
1
Hold down the RESUME/CANCEL
button (A) on the printer until
the POWER lamp (B) flashes 6
times, then release the RESUME/
CANCEL button after the sixth
flash.
Printing will start.
B
A
Connection Checklist
Check
Check 1
Before connecting the printer, are the computer and network device (router, etc.) configured and can the computer connect to the network?
Configure the computer and network device.
• For the procedures, refer to the manuals supplied with the computer and network device, or contact their manufacturers.
Check 2
Are the printer and network device (router, etc.) turned on?
Turn on each device.
If the printer is already turned on, turn it off, then turn it back on.
Check 3
Is the USB cable connected properly? (The USB cable is required for network settings when setting up the printer on the network for the first time.)
If the USB cable is loose, connect it properly.
• For the connection procedure, refer to "Wired LAN Connection" (Windows: P.23, Macintosh: P.32) in the printed manual: Getting Started.
Check 4
When using a router, are the LAN cables of the printer and computer connected to the LAN side of the router?
• For details on how to check the connection, refer to the manual supplied with the router or contact its manufacturer.
If the LAN cable is connected to the WAN side of the router, connect it to the LAN side.
If the LAN cable is loose, connect it properly.
• For the connection procedure, refer to the manual supplied with the router or contact its manufacturer.
Check 5
Is the firewall function of your security software active?
A message may appear on the computer monitor warning that Canon software is attempting to access the network.
If the warning message appears, set the security software to always allow access.
Glossary
• Firewall
A security measure to protect computers connected to the Internet and corporate networks against unauthorized external access.
Specifications
Minimum System Requirements
General Specifications
Printing resolution
(dpi)
Interface
4800* (horizontal) x 1200 (vertical)
* Ink droplets can be placed with a pitch of
1/4800 inch at minimum.
USB Port:
Hi-Speed USB*
Conform to the operating system's requirements when higher than those given here.
Operating System
Processor
RAM
Windows Vista, Vista SP1
1 GHz processor
512 MB
Mac OS X v.10.5
Intel processor, PowerPC G5,
PowerPC G4
(867 MHz or faster)
512 MB
Windows XP SP2, SP3
300 MHz processor
128 MB
Mac OS X v.10.4
Intel processor, PowerPC G5,
PowerPC G4, PowerPC G3
256 MB
LAN Port:
Wired LAN: 100BASE-TX/10BASE-T
*A computer that complies with Hi-Speed USB
standard is required. Since the Hi-Speed
USB interface is fully upwardly compatible
with USB 1.1, it can be used at USB 1.1.
Print width
[Cassette] 11.4 inches/290.2 mm
(for Borderless Printing: 11.7 inches/297 mm)
[Rear Tray] 12.7 inches/322.2 mm
(for Borderless Printing: 13 inches/329 mm)
Operating
Temperature: 5 to 35°C (41 to 95°F)
environment
Humidity: 10 to 90% RH (no condensation)
Storage
Temperature: 0 to 40°C (32 to 104°F)
environment
Humidity: 5 to 95% RH (no condensation)
Power supply
AC 100-240V, 50/60 Hz
Power consumption Printing: Approx. 22 W
Standby (minimum): Approx. 1.7 W
OFF: Approx. 0.7 W
* USB connection to PC
External dimensions Approx. 25.5 (W) x 20.4 (D) x 10.2 (H) inches
Approx. 647 (W) x 519 (D) x 260 (H) mm
*With the Paper Support, Front Tray and Front
Tray Extension retracted.
Approx. 19.8 kg (Approx. 43.7 lb)
Weight
* With the Print Head and ink tanks installed.
Print Head/Ink
Total 3,584 nozzles (BK/Y/PBK each 512
nozzles, C/M each 512 x 2 nozzles)
Additional System Requirements for the On-Screen
Manuals
Browser: Easy Guide Viewer
Note: Internet Explorer 6 or later must be
installed. The on-screen manual may not
be displayed properly depending on your
operating system or Internet Explorer
version. We recommend that you keep
your system up to date with Windows
Update.
Browser: Easy Guide Viewer
Note: The on-screen manual may not be
displayed properly depending on your
operating system or Safari version. We
recommend that you keep your system
up to date.
Windows 2000 Professional SP4 Mac OS X v.10.3.9
300 MHz processor
PowerPC G5, PowerPC G4,
128 MB
PowerPC G3
128 MB
Browser
Internet Explorer 6 or later
Safari
Hard Disk Space
450 MB
600 MB
Note: For bundled software
Note: For bundled software
installation.
installation.
CD-ROM Drive
Required
Display
SVGA 800 x 600
XGA 1024 x 768
• Windows: Operation can only be guaranteed on a PC with Windows Vista, XP or 2000
pre-installed.
• To upgrade from Windows XP to Windows Vista, first uninstall software bundled with
the Canon inkjet printer.
• Macintosh: Hard Disk must be formatted as Mac OS Extended (Journaled) or Mac OS
Extended.
• Internet Explorer 7 or later is required to install Easy-WebPrint EX.
Network Specifications
Communication
protocol
Wired LAN
TCP/IP
Supported Standards: IEEE802.3u (100BASETX)/IEEE802.3 (10BASE-T)
Transfer speed: 10M/100Mbps (auto switching)
Specifications are subject to change without notice.
About Consumables
Consumables (ink tanks / FINE Cartridges) are available for
5 years after production has stopped.
QT5-2706-V01
XXXXXXXX
©CANON INC.2009
PRINTED IN THAILAND
Download PDF

advertising
