16 Σ∆ A/D, 18-bit, 48 kHz - 16 Σ∆ D/A, 18-bit, 48 kHz
SD16
SD16 - High Performance 16-Channel Analog I/O Module
The SD16 module provides 16 channels of 18-bit, 48 kHz sigma-delta A/D
and D/A conversion, ideal for high channel count, precise data acquisition
and audio applications. This low cost, high channel density, high resolution
analog I/O is unrivaled in the industry.
Each input channel employs sigma-delta modulation with 384x
oversampling, providing highly effective digital anti-alias filtering. The
excellent S/N and THD performance of the SD16 precision measurements
with up to 100 dB SFDR.
The output channels include an 8X interpolation filter, digital attenuation
and de-emphasis. This provides spectrally pure analog output waves even
with only 2 points per wave, with a 97 dB dynamic range.
Interface Compatible with all OMNIBUS host products
Consumes one interrupt to host
Power Requirements 5 V @ 150mA; +15 V @ 280mA; -15 V @ 50mA
Physicals OMNIBUS mezzanine card; 2.000" X 4.600"
A/D Converters 8 Burr-Brown PCM3001 SD stereo codecs
Resolution 18-bit
Update Rate (Fs) 32-48 kHz, programmable via host Board DDS
Oversampling 384 X
Analog Input Range +/- 10 V
S/N Ratio 92 dB
THD -95 dB
DC Gain Accuracy 2%
Input Type Unbalanced (single-ended - AC coupled)
Input Impedance 10 kOhm - AC coupled
Digital Filter Passband
.454 x sample rate Fs
Characteristics Passband ripple
.05 dB
Stopband
.583 x Fs min
Group Delay 17.4/Fs seconds
Conversion Trigger Sources Host DDS
Interface to DSP Memory-mapped interface
D/A Converters 8 Burr-Brown PCM3001 SD stereo codecs
Resolution 18-bit
Oversampling 384 X
Output Range +/- 10 V
Output Analog Filter 1 pole; -3 dB at 170 kHz
Update Rate 32-48 kHz, programmable via host Board DDS
S/N Ratio 96 dB
THD + Noise -90 dB
Conversion Trigger Host DDS
Sources
Interface to DSP Memory-mapped interface
Digital Logic
Software examples demonstrating module operation and communication
are included in all Toolsets. A full calibration report ships with every module.
16 Channels A/D
+/-10V
Inputs
Σ∆ A/D
18-bit, 48kHz
+
-
1 of 16
OMNIBUS
16 Channels DAC
Σ∆ D/A
18-bit, 48kHz
+/-10V
output
1 of 16
Timebase
Logic
External
Reset
IDROM
Calibration
Data
In System Performance
0
A/D
-25
S/N= 93.1dB
THD= -99.0dB
-50
-75
dB
OMNIBUS Modules
When coupled with a DSP card, the SD16 module could be used to cancel
echo, feedback and other unwanted signals with adaptive filtering.
-100
-125
Ordering Information
SD16
80020-8
-150
0
88
5
10
15
20
kHz
Innovative Integration | 805.520.3300 | www.innovative-dsp.com
