Main Parts and Controls
1
2
3
4
5
6
11
12 13
17
18
14
15
7
8
9
16
10
19
1. Speaker
2. NFC antenna
3. Flash / AF Assist Lamp
4. Control ring
5. LEICA DC ELMARIT lens /
Outward facing camera
6. Microphone
7. Volume button
8. Power ON/OFF button
9. Camera selector switch
10. Shutter button
11. microUSB terminal
12. Ringtone lamp / Charging lamp
13. Light sensor / Proximity sensor
14. Earpiece
15. Earphone terminal
16. Inward facing camera
17. Display
18. Mouthpiece / Microphone
19. microSIM card slot
20
20. microSD card slot
A New Way to See the World
DMC-CM1 Specifications
LENS
Approx. 135.4 x 68.0 x 21.1 (Body 15.2) mm (5.33 x 2.68 x 0.83 (0.60) inch)
Weight
Approx. 203 g without SIM Card and microSD Memory Card (0.45 lb)
Approx. 204 g with SIM Card and microSD Memory Card (0.45 lb)
Camera Effective Pixels
20.1 Megapixels
Sensor Size /
Total Pixels / Filte
1-inch High Sensitivity MOS Sensor /
Total Pixel Number 20.9 Megapixels / Primary Color Filter
Aperture
F2.8 - 11 / Multistage Iris Diaphragm
Optical Zoom
1x (Fixed focal length)
Focal Length
f = 10.2mm
(31mm in 35mm equiv. in 4:3)
(28mm in 35mm equiv. in 3:2)
(30mm in 35mm equiv. in 16:9)
(36mm in 35mm equiv. in 1:1)
(43mm in 35mm equiv. in 4K video recording)
Extra Optical Zoom (EZ)
Picture Quality M: Max. 1.32x (4:3 / 3:2 / 1:1), Max. 1.41x (16:9)
Picture Quality S: Max. 2.0x
Picture Quality XS: Max. 2.83x (3:2 / 16:9), Max. 4x (4:3 / 1:1)
Intelligent Zoom
2x
Lens
FOCUS
OUT CAMERA
SHUTTER
RECORDING
SYSTEM
RECORDING
SYSTEM
EXPOSURE
CONTROL
OUT CAMERA
SENSOR
Dimensions (W x H x D)
LEICA DC ELMARIT
6 elements in 5 groups (3 Aspherical Lenses / 6 Aspherical Surfaces)
IN CAMERA
DIMENSIONS / WEIGHT
Exposure
4K Video 3840 x 2160 pixels, 15p (4K: 50Mbps / MP4) (Sensor output is 30fps) (AAC)
HD Video
1920 x 1080 pixels, 30p (FHD: 20Mbps / MP4) (Sensor output is 30fps) (AAC)
1280 x 720 pixels, 30p (HD: 10Mbps / MP4) (Sensor output is 30fps) (AAC)
STD Video
640 x 480, 30p (VGA: 4Mbps / MP4) (Sensor output is 30fps) (AAC)
640 x 640, 30p (1:1: 4Mbps / MP4) (Sensor output is 30fps) (AAC)
Program AE, Aperture Priority AE, Shutter Priority AE, Manual
Exposure Compensation
1/3 EV step, +/-3 EV
Auto (AE) Bracketing
3 frames in 1/3, 2/3 or 1 EV step, Max. +/-1 EV
Light Metering
Intelligent Multiple / Center Weighted / Spot
ISO Sensitivity
Auto / i.ISO / 100 (Extended ISO) /125 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 /
25600 (Extended ISO) (Changeable to 1/3 EV step) (Motion picture recording: Auto)
WHITE
BALANCE
White Balance
Auto / Daylight / Cloudy / Shade / Incandescent / White Set / Color Temperature
(White Balance Adjustment)
FLASH
Flash (Included)
Auto, Forced On, Always On, Forced Off
0.6 - 5.3m (ISO Auto)
OTHERS
Digital Red Eye Correction
(Red-Eye Removal)
Yes (On / Off)
Level Gauge
Yes
SENSOR
Camera Effective Pixels
1.07 Megapixels
Picture Size
0.92 Megapixels
File Format
Still Image: JPEG (Exif2.2)
Motion Picture: MP4
Optical Image Stabilizer
-
Digital Zoom
Max. 2x (When Digital Zoom is used simultaneously with Extra Optical Zoom or
Intelligent Zoom, the total zoom ratio is max. 4x.)
Focusing Area
10 cm - infinity
OS
Android™ 4.4(KitKat)
AF Assist Lamp
Yes (On / Off)
CPU
Qualcomm® Snapdragon™801 (MSM8974AB)
Focus
AF / MF
Storage & Memory
AF Metering
Face Detection / Tracking / 23-area / 1-area
Storage 16GB *5, Memory 2GB
(Up to 128GB additional with optional microSDXC Card *6)
SIM Size
microSIM Class B / Class C
FEATURES
Shutter Type
Mechanical Shutter / Auto (Mechanical Shutter + Eerectronic Shutter)
Shutter Speed
Still Image:
Mechanical Shutter : Approx. 60 - 1/2,000 sec
Auto : Approx. 60 - 1/16,000 sec
Self Timer
2 sec / 10 sec
File Format
Still Image: JPEG (DCF/Exif2.3) *1 / RAW *2
Image Quality
RAW / RAW+Fine / Fine / Standard
Motion Picture:
Approx. 1/30 - 1/16,000 sec
WIRELESS
Motion Picture: MP4
Recording Media
microSD Memory Card, microSDHC Memory Card, microSDXC Memory Card
Color Space
sRGB, AdobeRGB
Still Picture Recording
4:3 4864x3648 (18M) (L) / 3456x2592 (9M) (M) / 2432x1824 (4.5M) (S) / 640x480 (0.3M) (XS)
3:2 5472x3648 (20M) (L) / 3888x2592 (10M) (M) / 2736x1824 (5M) (S) / 1920x1280 (2.5M) (XS)
DISPLAY
16:9 472x3080 (17M) (L) / 3840x2160 (8M) (M) / 2560x1440 (3.5M) (S) / 1920x1080 (2M) (XS)
1:1 3648x3648 (13M) (L) / 2592x2592 (7M) (M) / 1824x1824 (3.5M) (S) / 640x640 (0.4M) (XS)
Recording Mode
Intelligent Auto, Intelligent Auto Plus, P, A, S, M, C1 (Custom), C2 (Custom),
Scene Guide, Creative Control, Panorama Shot
INTERFACE
Sensors
Accelerometer, Gyro, Proximity, Compass, Pressure, Luminance
Baseband Supported
Band
4G, 3G, 2G
• Check the website of the Panasonic sales company in your country or region for
details on the products that are available in your market.
NFC
Yes
Wi-Fi
Yes (IEEE 802.11a/b/g/n/ac)
• Check the website of the Panasonic sales company in your country or region for
details on the products that are available in your market.
Bluetooth
Yes (Bluetooth® v4.0)
GPS
Yes (GPS, GLONASS)
Type
TFT LCD Monitor with Static Touch Control, 16.8M Colors
Size
4.7", 16:9 aspect
1920 (W) x 1080 (H) RGB, 6,220k dots
Multi Touch
Yes
Microphone / Speaker
Stereo / Mono
Photo Style
Standard, Vivid, Natural, Monochrome, Scenery, Portrait
microUSB
USB 2.0 ( High Speed )
Picture Adjustment
Contrast, Sharpness, Noise Reduction, Saturation*, Color Tone**,
* Except for Monochrome mode. ** For Monochrome mode only
Headphone Output
φ3.5mm (3-pin / 4-pin)
LANGUAGE
OSD Language
Japanese, English (US/UK), German, French, Spanish, Swedish ,Chinese
(Traditional), Chinese (Simplified), Indonesian
POWER
Battery
Li-ion Battery Pack (3.8V, 2600mAh, 9.9Wh) (Built-in)
AC Adaptor (Input: 110 - 240V AC) *7
Battery Life (Approx.)
Still Image: 300 pictures (CIPA Standard) *8
Filter (Creative Control)
(Still Image)
Expressive, Retro, Old Days, High Key, Low Key, Sepia, Monochrome, Dynamic
Monochrome,Impressive Art, High Dynamic, Cross Process, Toy Effect, Toy Pop,
Bleach Bypass, Miniature Effect, Fantasy, Star Filter, One Point Color (18 filters)
Scene Guide (Still Image)
Clear Portrait / Silky Skin / Backlit Softness / Relaxing Tone / Sweet Child's Face /
Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow /
Glistening Water / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape /
Artistic Nightscape / Glittering Illuminations / Handheld Night Shot / Clear Night
Portrait / Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports
Shot / Monochrome (22 modes)
Continuous Shooting
Mode (Approx.)
H
5 frames/sec (with Live View, max. 6 images in JPEG, max. 3 images in RAW+JPEG)
L
2 frames/sec (with Live View, max. 9 images in JPEG, max. 3 images in RAW+JPEG)
(depending on memory card size, battery power, picture size, and compression)
Communication Camera
Standby: 630 hours (3G), 560 hours (GSM)
Talk: 12 hours (3G), 11 hours (GSM)
10 frames/sec (max. 5 images in JPEG, max. 3 images in RAW+JPEG)
M
Actual Size
Motion Picture *9:
Continuous Recordable Time: 100 min (4K), 130 min (FHD)
Actual Recordable Time: 70 min (4K), 90 min (FHD)
SH 50 frames/sec (max. 5M, max. 23 images in JPEG) *3
*1 Based on “Exif 2.2” standard when taking pictures in Panorama Shot Mode or when recording motion picture.
*2 The software to process RAW file on PC is not bundled with DMC-CM1. To do this, SILKYPIX Developer Studio is available for download
at Ichikawa Soft Laboratory's website using PC connected to the Internet.
*3 SH use Electronic shutter automatically.
*4 - Use a card with SD Speed Class with "Class 4" or higher when recording motion pictures.
- Use a card with SD Speed Class with "Class 10" when recording motion pictures with [MP4] in [4K].
(SD speed class is the speed standard regarding continuous writing.)
(The SD speed class represents the level of performace of microSD cards.
The SD speed class does not serve as a guarantee of performace for all operations.)
- The maximum continuous recordable time of a motion picture is 29 minutes and 59 seconds, which is equivalent to a file size of
approximately 4 GB.
- Maximum time to record motion pictures continuously with [MP4] in [4K] is 10 minutes 50 seconds.
- Maximum time to record motion pictures continuously with [MP4] in [FHD] is 26 minutes 58 seconds.
*5 Operation has been tested and confirmed using Panasonic SD Memory Card with a capacity of up to 2GB, Panasonic SDHC Memory
Card with a capacity of up to 32GB, and Panasonic SDXC Memory Card with a capacity of up to 64GB. Operation on other SD equipment
is not guaranteed.
a
Motion Picture
Recording *4
ACCESSORIES
Battery Charging Time (Approx.)
150 minutes (100% charge) (When charged with the AC Adaptor)* 7
330 minutes (When charged with the USB connection cable (5.0V, 0.5A))
Standard Accessories
AC Adaptor (Quick Charge 2.0) *7, Stereo Headset (EF model only)
*6 Total usable memory will be less depending upon actual system configuration.
*7 The AC Adaptor is not included in the GT model.
*8 Recording conditions by CIPA standard
- Temperature: 23 oC (73.4 oF) / Humidity: 50%RH when LCD monitor is ON.
- Using a Panasonic microSDHC Memory Card
- Starting recording 30 seconds after the camera application is turned on.
- Recording once every 30 seconds with full flash every second recording.
- The number of recordable pictures varies depending on the recording interval time.
- If the recording interval time becomes longer, the number of recordable pictures decreases.
- CIPA is an abbreviation of [Camera & Imaging Products Association].
- If the recording interval time becomes longer, the number of recordable pictures decreases.
- CIPA is an abbreviation of [Camera & Imaging Products Association].
*9 - These are standard times taken at a temperature of 23 oC (73.4 oF) and a humidity of 50%RH.
- The time available for recording varies depending on the environment, the interval between recordings, and the manner of use.
- The actual recordable time is the time of recording possible with repeated start/stop of the camera function, and start/stop of recording
* Actual resolution: 3840 x 2160p
Actual photos taken by LUMIX CM1.
The World’s Slimmest* Camera with Large Sensor
Large, 1-inch Camera Sensor in a Pocked-sized Body
LEICA DC Lens for Impressive Bokeh Expression
The 1-inch 20-megapixel High Sensitivity MOS sensor is larger than that
The LUMIX CM1 features a unique 28mm lens designed by Leica, one of
on a smartphone, and usually only found in higher spec compact cameras.
the foremost optics manufacturers. The lens overcomes the defects
But because of the size, it offers outstanding low light performance with
typically seen in smartphone images. The lens configuration reduces
minimum noise levels — even at high ISO. The LUMIX CM1 produces crisp,
image distortions such as vignettes, flaring, ghosting and chromatic
highly dynamic images full of intricate details and accurately rendered soft
inconsistencies while increasing resolution and edge-to-edge sharpness.
focus.
Venus Engine for Detailed and Clear Pictures
The Venus Engine uses advanced image processing to offer picture
Maximum ISO Sensitivity of 25600
Wider Dynamic Range
The World’s Slimmest* Body
The LUMIX CM1 has an extended ISO
The wide dynamic range offered by the
Panasonic's downsizing and slimming
sensitivity of ISO25600. It also supports
LUMIX CM1 provides rich gradation to
technology has achieved a
low ISO sensitivity of ISO100.
reproduce bright highlights and dark
pocket-size body that measures about
shadows with natural tones.
15.2mm at the thinnest part.
quality far beyond the standard found in most smartphones. Combined
with a highly tuned High performance sensor, the Venus Engine uses a
* As a digital camera with 1-inch sensor, as of 15 September, 2014.
2
combination of noise reduction systems such as Multi Process NR,
Random Filter and Aperture Filter to capture colour and detail in a
natural and accurate manner
• Leica is a registered trademark of Leica Microsystems IR GmbH. • ELMARIT is registered trademark of Leica Camera AG.
• Leica DC lenses are manufactured using measurement instruments and quality assurance systems that have been certified by Leica Camera AG based on the company's quality standards.
3
Shutter Speed
Aperture
ISO Sensitivity
Aperture
*
* Actual resolution: 3840 x 2160p
Full Manual Operation for Expressive Control
4K Video and 4K Photo for New Image Creation
Control Ring with the Operating Feel of a DSLM Lens
4K Pre-Burst App for Capturing the Perfect Moment
The LUMIX CM1 is designed to help you explore and develop your photography. Central
The LUMIX CM1 captures 1.5 seconds of 4K footage before and after pressing the shutter button —
is the manual control ring, giving direct access to key functions such as shutter speed,
taking a total of 45 images for you to scroll through, review and find the exact moment.
aperture and ISO. Compose your images with the 3D level gauge, histogram, auto focus,
* Actual resolution: 3840 x 2160p
manual focus assist and focus peaking.
4K Pre-Burst
Conventional Shooting
Failed!
Shooting Functions That Enhance the Joy of Taking Pictures
Comprehensive Shooting Modes
Press the shutter button.
MF Assist
Shooting opportunities are missed
because the shutter button is
pressed too soon or too late.
Exposure Compensation
±3EV
Select the best image from among 1.5 seconds
before and after you pressed the button.
White Balance
Auto / Daylight / Cloudy / Shade /
Incandescent / White Set /
Color Temperature /
White Balance Adjustment
Level Gauge
Focus Peaking
Never Miss a Picture
Enjoy Rich Detail
with 4K PhotoCapture
with 4K Video
Shoot action scenes using 4K video to find the exact picture that
The LUMIX CM1 records video in Full-HD and even 4K to deliver a
perfectly describes a scene. The LUMIX CM1 lets you review footage,
more intense viewing experience. The native resolution of 3840 x
frame by frame, and then extract it as a picture with an A3 print size.
2160 pixels is four times greater than Full-HD, resulting in much
Pictures are crisp, with minimal blur — even in low light conditions.
higher levels of detail than you’ve ever seen before.
ISO Sensitivity
Auto / i.ISO / 125-12800 /
Extended ISO 100/25600
• When recording videos in 4K, use a microSD Memory Card with SD Speed Class of "Class 10."
4K
[2160]
RAW Format: Just Like a Negative
[1080]
Full-HD
The LUMIX CM1 captures pictures in both JPEG and RAW formats. RAW takes image
data directly from the camera sensor, offering you a greater flexibility in terms of editing
and post-production.
[1920]
[3840]
• The software to process RAW files on a PC is not bundled with the LUMIX CM1. To do this, SILKYPIX® Developer Studio is available for downloading at Ichikawa
Soft Laboratory’s website using a PC connected to the Internet.
4
5
High-speed LTE Communication Capability
Android™ 4.4 KitKat®
The LUMIX CM1 is equipped with LTE communication capability. When
Pre-installed Android™ 4.4 KitKat® lets you download various apps
Internet connection is available, photos, RAW format data and videos can
for Android™ from Google Play™ and use social media and camera /
be quickly stored online or uploaded to social media for sharing.
photo apps. The switch on the top panel allows quick changing between
• High-speed LTE communication may not be supported in some countries / regions.
Android™ and camera functions.
• Android 5.0™ will be available in May 2015.
Photo Search App
Pashadelic App
The Photo Search app uses Google Maps™ and Panoramio data to help you
The Pashadelic app can be used to share shooting locations and shooting
find the best photo opportunities around you.
dates and times of pictures with people all over the world for added
convenience and fun.
• The Pashadelic app is not available in some countries / regions.
Sharing Daily Excitement through Photos
Shooting, Viewing, Retouching and Sharing Pictures Seamlessly
Google Drive™ Supported
Other Functions
Google Drive™ is pre-installed so that photos and videos can be automatically
• Can be used as a smartphone when a SIM card is inserted.
uploaded to a cloud for backup. This lets you concentrate on shooting without
• 2.3-GHz quad-core CPU for high-speed processing.
worrying about the space remaining on the microSD card.
• Qualcomm® Quick Charge™ 2.0 for fast battery charging.
• Requires Internet connection. Note that communication charges will be incurred.
• Equipped with an app to shoot time-lapse video.
The LUMIX CM1 lets you upload pictures of exciting everyday scenes over the Internet. It provides a new experience of sharing not only
information but also emotional excitement through pictures. With the LUMIX CM1, you can easily post pictures on social media and upload
them to a cloud for backup. Dragging & dropping an image is all it takes to quickly share or store a picture.
About SIM Cards
• Requires Wi-Fi® connection or a SIM card for data communication.
An appropriate SIM card must be inserted in the LUMIX CM1 to use its LTE / 3G communication.
Shooting
Viewing / Retouching
Sharing
• Insert a SIM card into the LUMIX CM1.
• A SIM card is not required when using only Wi-Fi® communication.
• A SIM card is usually provided when signing a contract with a telecommunications carrier.
The LUMIX CM1 is a high-performance digital
Gallery app lets you not only view pictures
You can upload your pictures to your social
camera equipped with a high-quality lens
but also retouch images. It makes it possible
networks or back them up to the cloud. By using
The LUMIX CM1 supports microSIM cards.
and large sensor. In addition to taking casual
to adjust parameters, such as contrast and
the "swipe and share" function, you can simply
• If your SIM card is not a microSIM card, one of the following methods must be applied to use the communication function.
snapshots, you can capture images exactly as
tone curve, for creating unique pictures.
drag your pictures to one corner icons on your
you intend by manually adjusting the aperture
Retouching is an easy, one-touch operation.
screen to directly post or upload your pictures to
and shutter speed.
- Follow the necessary procedure to change your SIM card to a microSIM card. (Compatibility varies depending on the telecommunications carrier.)
- Use a commercially available SIM adaptor to insert your card.
your social media networks.
Note Regarding SIM Cards
Use of the LUMIX CM1 as a Smartphone
By inserting a voice call microSIM card, the LUMIX CM1
can be used to make and receive phone calls to and from
fixed phones, feature phones and smartphones worldwide.
A 4.7-inch, Approx. 6,220k-dot
Full-HD Touch Screen
microSIM Card
(3FF)
• The microSIM card and microSD card are optional.
• When a voice call or packet communication is performed, charges set by the
telecommunications carrier will be incurred.
• For details, contact the telecommunications carrier that issued the SIM card.
Communication Camera
DMC-CM1-S
* Actual resolution: 3840 x 2160p
(Silver)
With a high 473ppi resolution, the touch screen displays the subject with
exquisite detail and accuracy. It renders beautiful images when shooting
and viewing, and makes it easy to confirm details when retouching.
6
• microSDXC Logo is a trademark of SD-3C, LLC. • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under licence. Other
trademarks and trade names are those of their respective owners. • Leica is a registered trademark of Leica Microsystems IR GmbH. • ELMARIT is registered trademark of Leica Camera AG. • Leica DC lenses are manufactured
using measurement instruments and quality assurance systems that have been certified by Leica Camera AG based on the company's quality standards. • The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance®.
• The Wi-Fi Protected Setup™ Identifier mark is a certification mark of Wi-Fi Alliance®. • “Wi-Fi®” is a registered trademark of Wi-Fi Alliance®. • “Wi-Fi Protected Setup™”, “WPA™”, and WPA2™” are trademarks of Wi-Fi
Alliance®. • The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. • Google, Android, Google Play and other marks are trademarks of Google Inc. • Qualcommm®
QuickCharge™ 2.0 is a registered trademark of Qualcomm Incorporated. • Other names of systems and products mentioned in this brochure are generally the registered trademarks or trademarks of the manufacturers who
developed the system or product concerned. • Weight and dimensions shown are approximate. • Design, functions, and specifications are subject to change without notice. • Some sample images are simulated. • The use of
recorded or printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe upon the rights of the copyright holder.
7
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
