4 Tool Kit: Metric

Roadtech M3 Tool Kit RTM3

The ultimate roll-up tool kit.

While the M3 is aimed at cruisers, it’s equally at home on tourers, sport bikes, standards, and quads. Put this in your fork bag, tank bag, or saddlebag and you’ll be ready for just about anything the road will throw at you.

Rally Pack Tool Kit DMX1

The ultimate off-road tool kit.

Complementing the long-list of tools and other items is a stout and functional pouch using a super-tough 5040-denier nylon shell, top grade hardware and zippers, plenty of storage (including a unique mesh cash and document pocket), and key clip.

DMX Fender Mount Tool Kit DMX2

The ultimate fender-mounted tool kit.

Complementing the long-list of tools and other items is a stout and functional pouch using a super-tough 5040-denier nylon shell, top grade hardware and zippers, plenty of storage (including a unique mesh cash and document pocket), and key clip.

Includes fender mount and rain fly.

Tool Kit: Metric

Econokit M1 EKM1

A major upgrade from your original

OEM tool kit.

A top quality tool with lots of capability.

Absolutely dependable. Contains exclusive PowerDrive wrenches and loads of other high-quality tools and roadside items, packed in a durable double-panel polyester pouch.

Carrying Sockets And Drivers

Tool Set VT47 l

Two way ¼” square grip. (‘T’ & straight) l

Five 175mm (6 7/8”) long double way bits l

Allen Hex. in 3mm, 4mm, 5mm l

(straight head & ball end)

Slotted 4.0mm x 5.5mm, Phillips #1 x #2 l

Five 180mm (7.1/4’’) long sockets in 6mm, 8mm, 10mm, 12mm and

13mm l

Strong carrying case for easy storage l

Adapter for 1/4” square socket drives l

7mm Torx screwdriver

Outback’R Folding Metric

Tool Set OM14

You’ll get 14 tools - four hex keys (3,

4, 5, 6mm), two screwdrivers, a socket driver with 8, 10, and 12mm sockets,

13 and 14mm open-end wrenches, and three spoke wrenches - all in a nine ounce unit that’s only 3.5” long. Except for the sockets, there’s no loose pieces to put together.

5

6 Tool Kit: Imperial Tool Kit: BMW

Econokit FR1 Imperial Kit EKFR1

A general use kit for a wide range

of inch-based vechicles, including autos, trucks and boats. Includes four combination wrenches, an eight-inch adjustable wrench, a six-in-one screwdriver with an additional two-size bit to handle commonly found square recess fasteners, flashlight, locking pliers and tyre pressure gauge.

Roadtech B1: BMW Tool Kit RTB1

BMW motorcycles are legendary for innovation, and their choice of

fasteners are no exception. Female

Torx fasteners are commonplace, and some models even use rare male Torx screws. Add special wrench and hex key needs, and it becomes clear that a unique tool kit is called for. We’ve exceeded these needs with the new

RoadTech B1 for BMWs, which packs top grade tools and other roadside items into a sturdy roll-up pouch.

BMW Rear Wheel Star Wrench

T50BM

Designed for removal and replacement of rear wheels on single sided swing arm

BMW motorcycles. Professional grade, using heat treated S2 material. Compact enough to fit into a tank bag or saddlebag. Star tips provided on both ends for increased flexibility.

Tool Kit: Harley Davidson

Roadtech H3 Harley Tool Kit RTH3

The ultimate Harley-Davidson tool kit.

Like the H1, it includes top-grade

PowerDrive combination wrenches, an adjustable wrench, locking pliers, LED flashlight, tire gauge, hex and Torx keys, screwdriver and more. But you’ll also love the mini ratchet and socket set, making this the last tool kit you’ll ever need to buy.

Econokit H1 - Harley EKH1

EconoKit H1 for Harley-Davidson.

If you’re on a tight budget but still want a complete tool kit, consider the H1.

Five combination wrenches cover most fasteners, and an eight-inch adjustable wrench handles the rest, including most axle nuts. Locking pliers, an aluminumbody LED flashlight, tyre gauge, hex and Torx keys, and much more will help get you back on the road in no time.

The double-panel 600-denier polyester pouch is designed to last.

Cruztools Roadtech Teardrop

Tool Kit RTTD1

CruzTools tool kit for Harley-Davidson.

Combines road-proven EconoKIT content with a nifty mini ratchet and socket set.

Softail riders can now get the new

RoadTech Teardrop which packs virtually everything from the RoadTech H3 into a compact pouch designed to fit genuine and aftermarket teardrop tool boxes. While the pouch is designed for teardrop boxes, the tool set is equally applicable to all air-cooled models.

7

8 Tool Kit: Harley Davidson Sockets

Folding Hex/Torx Key Set -

H D FHT1

Harley-Davidsons make regular use of hex and Torx fasteners, so we’ve assembled the most common sizes

(5/32”, 3/16”, 1/4”, 5/16”, T25, T27, T40) into a compact fold-up unit. Forged from heat-treated nickel alloy and housed in a tough handle that allows multiple angles of use.

Outback’R Folding Imperial Tool

Set - Harley OH13

The Outback’r H13 is a powerhouse

of functionality.

Included are three hex keys (5/32”,

3/16”, 1/4”), two Torx keys (T25, T27), slotted and Phillips screwdrivers, a socket driver with 3/8”, 7/16”, and 1/2” sockets,

10mm box and 9/16” open-end wrenches, plus a spoke wrench. At only

10 ounces and 3.5” long, even chopper riders won’t have trouble carrying it.

Mini 3 Way ‘’T’’ Type Socket

Driver VT41

A really handy little 3 way socket.

With 8mm, 10mm & 12 mm sockets maybe all you will need for most metric bikes. Measuring just 110mm (4”) long it easily stores in the tool kit or bike.

Sockets

3/8’’Driver Sliding ‘’T’’ Socket

Tool Set TSDS38

A really compact way to have all the main sockets and a Phillips driver together.

8 Piece set with 3/8” sliding T bar.

8mm,10mm,12mm,14mm, & 17mm sockets. 5mm & 6mm hex bits, number

2 Phillips screwdriver bits.

Rotating ‘T’ Driver Tool Set 19

piece 3/8” Drive VT45

‘T’ bar with central grip on ball bearings allowing easy spinning for rapid

operation. The spinning grip can be moved on the bar for perfect grip.

Contents: 300mm (12”) 3/8’’Square drive

‘T’bar Nine socket in 8, 9, 10, 11, 12,

13, 14, 17 & 19mm. Seven hexagon bit socket 3,4,5,6,7,8 &10mm. Two Phillips/

Slotted bit socket (+)#2 &(-)5mm. Store away steel dish with socket clip rail.

Rotating T-Driver -

3/8” Square Drive VT46

Just the T driver on its own without the tool set. The spinning grip can be moved on the bar for perfect grip.

9

10 Sockets

13mm Sliding T Socket TSS13M

13mm Sliding T Socket.

Ideal for garage or pit use, the Cruz Tsocket offers a unique sliding “T” handle to allow extra leverage when needed, or operating in a limited radius area.

Fit and finish is unmatched, and the mechanic-grade sockets are individually forged, then bonded to the handle using a proprietary process. Lifetime guarantee. Absolutely dependable.

Hex Bit Socket Set - 3/8 Inch

Drive IN38HBS l

3/8” Drive socket set - sizes:

5/64, 3/32, 1/8, 9/64, 5/32, 3/16, 7/32,

1/4, 5/16, 3/8 l

Mechanic grade heat-treated chrome l vanadium alloy

Laser imprint showing sizes l

Includes socket rail with handle for l easy storage

Lifetime warranty

1/4” Drive Imperial Socket

Set - 9pc VT80 l

6 Point hexagonal sockets l

AF sizes, 5/32”, 3/16”, 1/4”, 9/32”, l

5/16”, 3/8”, 7/17”, 1/2” & 9/16”.

High quality Chrome Vanadium steel l

Cold forged l

Steel holding rail

Sockets

11

1/4”

3/8”

1/4” Drive Metric Socket Set -

9pcs VT76 l

6 Point hexagonal sockets l

Metric sizes, 4, 5, 6, 7, 8, 10, 12, 13 l and 14 mm

High quality Chrome Vanadium steel l

Cold forged

1/4” And 3/8” Drive Stubby

Ratchet VT75 l

1/4” and 3/8” square drive l

Overall length 130mm ( 5”) l

Ideal for tight spaces l

Forward and reverse switch l

Ergonomic grip

1/4” Square Drive Swivel

Ratchet Handle VT74 l

270 degree Swivel head l

Ideal for tight spaces l

Quick release button l

High strength 72 teeth ratchet l

Chrome alloy forged steel construction l

Overall length 145mm ( 5.70” ) l

Ergonomic grip.

12 Sockets Drivers

Torque Wrench & Imperial

Open End Spanner Set VT86 l

1-Interchangeable Torque Handle l

5-25Nm Scale

1-1/4”Dr.Ratchet Head l

Drive Ended Heads Size: l

9x12mm Square

Open end Size: 1/4”, 5/16”, 3/8”, 7/16”, l

1/2”, 9/16”, 5/8”, 3/4”

Securely stored in a moulded case l

The ¼” drive head enables you to use l your existing sockets as required

Securely stored in a moulded case

Torque Wrench & Metric Open

End Spanner Set VT87 l

1-Interchangeable Torque Handle l

5-25Nm Scale

1-1/4”Dr.Ratchet Head l

Drive Ended Heads Size: l

9x12mm Square

Open end Size: l

7, 8, 9, 10, 11, 12, 13, 14

Securely stored in a moulded case l

The ¼” drive head enables you to use l your existing sockets as required

Securely stored in a moulded case

Handy Carrying Screw Driver

Tool Set VT51

Handy Carrying Screw Driver Tool Set.

Die cast construction. The cross bar has end sockets in 8,9,and 10mm. The second 10mm socket engages the double end bits.

Five double bits including Hex. 2, 2.5, 3,

4, 5,6mm Star bit t25 Phillips #2

Slotted 4mm

Tyres/wheels

13

6-In-1 Spoke Head Spanner VT31

Six sizes: 5.6mm, 6.3mm, 6.8mm,

5.7mm, 6.0mm, 6.6mm.

This spanner is of high quality steel drop forged construction.

Tyre lever set. 200mm VT33

Three piece 200mm (8”) long tire

levers plus hook attachment.

Super strong and Ideal for carrying with you. Drop forged steel construction. The hook attachement fits around the spoke to hold the lever in position.

Tyre lever set. 240mm VT34

Three piece 240mm (9 1/2”) long tire levers plus hook attachment.

Super strong and Ideal for carrying with you. Drop forged steel construction. The hook attachement fits around the spoke to hold the lever in position.

14 Tyres/wheels

Tyre lever set. 350mm VT35

Three piece professional tyre lever.

Two pieces designed with curved end and bolster line, the other end with sharper curve. Overall Length:350mm

(13 3/4”)long. The third lever one straight and one curved overall length

(280mm). All are drop forged steel construction for maximum strength. The hook attachement fits around the spoke to hold the lever in position.

Tyre Pressure Gauge 0-15 PSI

Range VT37

Pressure range: 0-15 psi (0-1 kg/

cmsq). 2” diameter dial gauge with rubber protection. Low pressure range suitable for Trials and Speedway etc.

Flexible braided stainless steel stem. 90 degree chuck with 360 degree rotation. Air bleed button for exact pressure setting. Supplied with tough nylon storage pouch. Accurate and reliable.

Tyre Pressure Gauge 0-60 PSI

Range VT32

Pressure range:0 -60 Psi (0 to 4 Bar)

2” diameter dial gauge.

Flexible braided stainless steel stem. 90 degree chuck with 360 degree rotation.

Air bleed button for exact pressure setting.

Supplied with tough nylon storage pouch. Accurate and reliable. Rubber protection around dial guage.

Tyres/wheels

4-In-1 Front Axle Nut Driver VT36

Made from tough T6 aluminium alloy

70mm long.

Both ends have standard 3/8’’square internal drives. There are 4 sizes in one:

17,19, 22, & 24mm to remove the front wheel axle hex.nuts. Suitable for most popular bikes.

Combo Axle Wrench AW142227

14mm x 22mm x 27mm | YAMAHA

WRF,YZ,YZF; KAWASAKI KX 1993 - 2002;

HONDA CR 1994 - 1999

Combo Axle Wrench AW142232

14mm x 22mm x 32mm; HONDA CR

2000, CRF; KAWASAKI KX 2003, KXF,KLX

2006; SUZUKI RMZ

15

16 Engine

Piston Location Holding Tool VT21

This tool can be screwed into the spark plug aperture to rest on the piston crown and holding it in position.

M14 thread

Timing Gauge Tool VT22

Precision 2 stroke timing gauge tool

suitable for M14 thread.

Micrometer adjustment for high accuracy.

Right Hand Thread Fly-Wheel

Magneto Puller VT23

Right hand thread fly-wheel / magneto puller M30xP1.(R)

We stock a variety of different sizes.

Engine Brakes Essentials

17

Combination Rotor & Flywheel

Puller Driver Set VT24

Ten piece set to serve fifteen different

thread applications. The M27 x p1.0 is a left hand thread. The remaining sizes are right hand threads. All are securely stored in a strong molded case.

Contents: M19xp1.0(R), M14xp1.5(R),

M16xp1.5(R), M18xp1.5(R), M28xp1.5(R),

M27xp1.25(R), M20xP.1.0(R),

M26xP1.5(R), M28xP1.0.(R), M25xP1.5(R),

M27xP1.0(L), M22xP.1.5(R), M26xP.1.0(R),

M22xP.1.0(R), M24xP.1.0(R)

Vampire Vacuum Pump Brake

Bleed Set VWK011

Fast and easy brake bleeding system.

Strong metal body. Simple quick and efficient single handed brake bleeding.

The main pump body has a vacuum gauge and release valve. The complete set includes all accessories to test basic vacuum relative mechanisms in addition to brake bleeding. Instruction manual included. Set packed in a durable moulded case.

Mandrel for making ends on

Powerhose lines VT62

This handy tool is used to open up the braiding when making up DIY

Powerhose and holding banjos when tightening up the socket nut.

18 Essentials

Long Shank Spring Hook VT11

The hook is made from high tensile

steel.

Overall length: 200mm ( 8”).With its narrow shaft and long reach it is a tool box must.

Tool box VT12

Handy tool box with removable clear boxes on top and removable tray

within. A strong and organised way of storing and carrying your tools.

Dimensions:

Length: 440mm

Width: 235mm

Height: 205mm

Cable inner wire bird caging

tool VT13

Tool for forming a ‘Bird cage’ when soldering nipples to control cable

inner wires. Suitable for 1.5mm, 2mm and 2.5mm dia. wire. You will need a vice to hold the jaws and clamp the cable. Then use the supplied punch to form the ‘bird cage’.

Essentials

Nipple Kit

Contains 18 of the most popular cable nipples in current use, made up of ball, barrel and trumpet nipples, all manufactured in brass, some with zinc plating.

Ferrule and Adjuster Kit

This kit contains cable end ferrules as well as popular end adjusters.

Components are manufactured from either brass or mild steel (zinc plated) and can be individually topped up at any time.

Wire & Rope Cutter WC6

High carbon steel parrot nosed

cutters are perfect for cutting cable wire, conduit and brake hose, neatly and quickly.

19

20 Essentials

Stainless Steel Safety Wire

0.6mm O.D VT78 l

For use with pliers part no. VT77 l

0.6mm (.025”) O.D. l

Coil weight 450g

Safety Wire Twister Pliers -

150mm VT77 l

150mm (6”) long l

Specially designed to wire bolts l and nuts

Use with safety wire (part No. VT78)

Chain Breaking & Riveting

Tool Set VT79 l

270’ Swivel head l

Ideal for tight spaces l

Quick release button l

High strength 72 teeth ratchet l

Chrome alloy forged steel construction l

Overall length 145mm ( 5.70” ) l

Ergonomic grip.

Controls

Venhill offer a range of cotrols to complement our cable and hose.

We have levers and twist grips for classic and modern bikes. We have the full range of Magura controls including the excellent hydraulic conversion for cable clutches.

All venhill controls can be bought through your local dealer or on line at

www.venhill.co.uk

Cables/hoses

Venhill offer a range of finished cables and hoses made to measure for your machine. If we don't have it we will make it for you!

In addition to finished cables and hoses, Venhill offer a range of kits to make up your own lines. Our packages cover everything from handy roadside repair kits and individual cable kits to full workshop sets for serious builders.

If you want to make up your own hydraulic hoses we have the

'Powerhose' system. This just bolts together at any length you cut. No crimping or special tools required.

All Venhill tools, cables and hose products can be bought through specialist dealers or on line at

www.venhill.co.uk

Cables/hoses

Venhill offer a range of finished cables and hoses made to measure for your machine. If we don't have it we will make it for you!

In addition to finished cables and hoses, Venhill offer a range of kits to make up your own lines. Our packages cover everything from handy roadside repair kits and individual cable kits to full workshop sets for serious builders.

If you want to make up your own hydraulic hoses we have the

'Powerhose' system. This just bolts together at any length you cut. No crimping or special tools required.

All Venhill tools, cables and hose products can be bought through specialist dealers or on line at

www.venhill.co.uk

About us

Venhill Engineering Limited / 21 Ranmore Rd / Dorking / Surrey RH4 1HE / England

tel

+44 (0) 1306 885111

fax

+44 (0) 1306 740535

e-mail

[email protected]

www.venhill.co.uk

Venhill Engineering Limited

21 Ranmore Rd

Dorking

Surrey

RH4 1HE

England

tel

+44 (0) 1306 885111

fax

+44 (0) 1306 740535

e-mail

[email protected]

www.venhill.co.uk

Venhill Engineering Limited

21 Ranmore Rd

Dorking

Surrey

RH4 1HE

England tel

+44 (0) 1306 885111

fax

+44 (0) 1306 740535

e-mail

[email protected]

www.venhill.co.uk

Exclusively aluminium

ALUMINIUM

GA Balustrade/glass infil:

See page 30

Edition 4 2009

GA Step-up stair nosings:

See page 31

GA bespoke products

GA products

GA materials

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
