Features/Caratteristiche
High performance exciters, compact, reliable and easy maintenance.
Broadcast quality at a value price, can be used as drivers for medium
power FM stations or as stand-alone applications.
Compact, non-deformable and light, 2HE rack unit, stainless steel chassis.
High performance integrated stereo coder, with L&R Mono and MPX inputs
and 2 SCA / RDS signal inputs.
TEX 30
TEX 50
TEX 100/150
Stereo/MPX
FM Exciters
Continuously adjustable output power from 0 to maximum power with
automatic APC control and Foldback protection.
Safe operation in any working conditions.
Completely microprocessor-controlled easy to program from the menu or via
RS232, all main parameters can be read on the LCD display.
Possibility to be monitored through all RVR telemetry systems to guarantee
87.5 - 108 MHz
(OIRT and JPN Band
upon request)
simple remote control of the operating parameters.
Manufactured using SMD technology and composed of only 4 modules. Maximum
operating reliability designed to allow an easy maintenance.
Universal multi-voltage power supply from 80 to 260 V with no preselection.
Modern technology that complies with all
EC, FCC and CCIR standards.
Eccitatori ad alte prestazioni, compatti, affidabili e di semplice
manutenzione.
Qualità di trasmissione senza compromessi ad un prezzo competitivo utilizzabile come driver per stazioni di media potenza o applicazioni stand-alone.
Compatti, indeformabili e leggeri, chassis in inox, in sole 2 unità rack.
Stereo coder integrato ad elevate prestazioni, ingressi L&R, Mono ed MPX e 2
ingressi per segnali SCA / RDS.
Potenza di uscita regolabile con continuità da 0 alla potenza massima con controllo automatico APC e protezione Foldback. Funzionamento sicuro in ogni
condizione di esercizio.
Completamente controllati da microprocessore, facilmente programmabile da
menu o via RS232, lettura su display LCD di tutti i parametri principali.
Perfettamente interfacciabili con tutti i sistemi
facile controllo remoto dei parametri di funzionamento.
Costruiti in tecnologia SMD e costituiti da soli 4
ed estrema facilita' di manutenzione.
Alimentatore universale
selezione.
di telemetria RVR per un
moduli. Elevata sicurezza di esercizio
multitensione da 80 a 260 V senza necessita' di pre-
Tecnologia moderna pienamente rispondente alle norme
EC, FCC ed CCIR.
RVR USA 7782 NW 46 ST Miami, Fl 33178 T: 305-471-9091 F: 305-471-6979
www.rvrusa.com
exciters
Technical specifications TEX
Parameters
Conditions
U.M.
From software, with 10 kHz steps(OIRT and JPN on request)
Continuously variable by software from 0 to maximum
MHz
W
Whithout condensing
WT from -10°C to 50°C
Referred to 100% AM, with no de-emphasis
Referred to 100% AM, FM deviation 75 kHz by 400Hz sine, without de-emphasis
°C
ppm
kHz
mS
dBc
dB
dB
RMS @ ± 75 kHz peak, HPF 20Hz - LPF 23 kHz, 50 mS de-emphasis
Qpk @ ± 75 kHz peak, CCIR weighted, 50 mS de-emphasis
Qpk @ ± 40 kHz peak, CCIR weighted, 50 mS de-emphasis
30Hz ÷ 15kHz
THD+N 30Hz ÷ 15kHz
Measured with a 1 KHz and 1.3 KHz tones, 1:1ratio, at FM 75 kHz
Measured with a 3.18 kHz square wave and a 15 kHz sine wave at 75 kHz FM
dB
dB
dB
dB
%
%
%
RMS @ ± 75 kHz peak, HPF 20Hz - no LPF, 50 mS de-emphasis
30Hz ÷ 53kHz / 53kHz ÷ 100kHz
THD+N 30Hz ÷ 53kHz / THD+N 53kHz ÷ 100kHz
Measured with a 1 KHz and 1.3 KHz tones, 1:1, modulation at FM 75 kHz
Measured with a 3.18 kHz square wave and a 15 kHz sine wave at 75 kHz FM
30Hz ÷ 53kHz
dB
dB
%
%
%
dB
RMS @ ± 75 kHz peak, HPF 20Hz - LPF 23 kHz, 50 mS de-emphasis, L & R demodulated
Qpk @ ± 75 kHz peak, CCIR weighted, 50 mS de-emphasis, L & R demodulated
Qpk @ ± 40 kHz peak, CCIR weighted, 50 mS de-emphasis, L & R demodulated
30Hz ÷ 15kHz
THD+N 30Hz ÷ 15kHz
Measured with 1 KHz and 1.3 KHz tones, 1:1 ratio, modulation at FM 75 kHz
Measured with a 3.18 kHz square wave and a 15 kHz sine wave at 75 kHz FM
dB
dB
dB
dB
%
%
%
dB
40kHz ÷ 100kHz
dB
GENERALS
Frequency range
Rated output power
Modulation type
Operational Mode
Ambient working temperature
Frequency stability
Modulation capability
Pre-emphasis mode
Spurious & harmonic suppression
Asynchronous AM S/N ratio
Synchronous AM S/N ratio
MONO OPERATION
S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
Transient intermodulation distortion
MPX OPERATION
Composite S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
Transient intermodulation distortion
Stereo separation
STEREO OPERATION
Stereo S/N FM Ratio
Frequency Response
Total Harmonic Distortion
Intermodulation distortion
Transient intermodulation distortion
Stereo separation
SCA OPERATION
Frequency response
AUDIO INPUTS
selectable by external jumpers
XLR Female
Impedance / level adjust
XLR Female
Impedance / level adjust
BNC Female
Impedance / level adjust
BNC Female
Impedance / level adjust
Left / MPX balanced
Right
MPX unbalanced
SCA and RDS
Ohm / dBu
Ohm / dBu
Ohm / dBu
Ohm / dBu
OUTPUTS
RF output
RF monitor
Pilot output
MPX output
AUXILIARY CONNECTIONS
N Female / Impedance
BNC Female / Output Level referred to the RF output
BNC Female / Impedance / output level
BNC Female / Output Level
Ohm
dB
Ohm / Vpp
dBu
Type
These are general specifications. They show typical values and are subject to change without notice.
99/5/CE
RVR USA 7782 NW 46 ST Miami, Fl 33178 T: 305-471-9091 F: 305-471-6979
www.rvrusa.com
Rev.: 02/2005
exciters
TEX 30
Value
TEX 50
Value
TEX 100/150
Value
87.5 ÷ 108
30
Direct carrier frequency modulation
Mono, Stereo, Multiplex
-10 to + 50
±1
150 Stereo, 180 Mono/MPX
0, 50 (CCIR), 75 (FCC)
<75 (80 typical)
≥ 65 (typical 70)
≥ 50 (typical 60)
87.5 ÷ 108
50
Direct carrier frequency modulation
Mono, Stereo, Multiplex
-10 to + 50
±1
150 Stereo, 180 Mono/MPX
0, 50 (CCIR), 75 (FCC)
<75 (80 typical)
≥ 65 (typical 70)
≥ 50 (typical 60)
87.5 ÷ 108
100 / 150
Direct carrier frequency modulation
Mono, Stereo, Multiplex
-10 to + 50
±1
150 Stereo, 180 Mono/MPX
0, 50 (CCIR), 75 (FCC)
<75 (80 typical)
≥ 65 (typical 70)
≥ 50 (typical 60)
> 80 (typical 85)
>73
>68
better than ± 0.5 dB (typical ± 0.2)
< 0.1 (Typical 0.07%)
< 0.02
< 0.1 (typical 0.05)
> 80 (typical 85)
>73
>68
better than ± 0.5 dB (typical ± 0.2)
< 0.1 (Typical 0.07%)
< 0.02
< 0.1 (typical 0.05)
> 80 (typical 85)
>73
>68
better than ± 0.5 dB (typical ± 0.2)
< 0.1 (Typical 0.07%)
< 0.02
< 0.1 (typical 0.05)
> 80 (typical 85)
± 0.2 / ± 0.5
< 0.1 / < 0.15
< 0.05
< 0.1 (typical 0.05)
> 50 dB (typical 60)
> 80 (typical 85)
± 0.2 / ± 0.5
< 0.1 / < 0.15
< 0.05
< 0.1 (typical 0.05)
> 50 dB (typical 60)
> 80 (typical 85)
± 0.2 / ± 0.5
< 0.1 / < 0.15
< 0.05
< 0.1 (typical 0.05)
> 50 dB (typical 60)
> 75 (78 typical)
> 65 dB
> 58 dB
± 0.5
< 0.05
≤ 0.03
< 0.1 (typical 0.05)
> 50 (typical 55)
> 75 (78 typical)
> 65 dB
> 58 dB
± 0.5
< 0.05
≤ 0.03
< 0.1 (typical 0.05)
> 50 (typical 55)
> 75 (78 typical)
> 65 dB
> 58 dB
± 0.5
< 0.05
≤ 0.03
< 0.1 (typical 0.05)
> 50 (typical 55)
± 0.5
± 0.5
± 0.5
balanced or externally unbalanced
10 k or 600 / - 13 to +13
balanced or externally unbalanced
10 k or 600 / - 13 to +13
unbalanced
10 k or 50 / -3 to +13
unbalanced
10 k / -3 to +13
balanced or externally unbalanced
10 k or 600 / -13 to +13
balanced or externally unbalanced
10 k or 600 / -13 to +13
unbalanced
10 k or 50 / -3 to +13
unbalanced
10 k / -3 to +13
balanced or externally unbalanced
10 k or 600 / -13 to +13
balanced or externally unbalanced
10 k or 600 / -13 to +13
unbalanced
10 k or 50 / -3 to +13
unbalanced
10 k / -3 to +13
50
approx. -30
>5 k / 1
0
50
approx. -30
>5 k / 1
0
50
approx. -60
>5 k / 1
0
Interlock / Ext ref. 10 MHz / RS232 / RS485
Serial Interface / Service / Modem / I2C /
Remote and Telemetry interface
Interlock / Ext ref. 10 MHz / RS232 / RS485
Serial Interface / Service / Modem / I2C /
Remote and Telemetry interface
Interlock / Ext ref. 10 MHz / RS232 / RS485
Serial Interface / Service / Modem / I2C /
Remote and Telemetry interface
These are general specifications. They show typical values and are subject to change without notice.
99/5/CE
RVR USA 7782 NW 46 ST Miami, Fl 33178 T: 305-471-9091 F: 305-471-6979
www.rvrusa.com
Rev.: 02/2005
exciters
Technical specifications TEX
exciters
Technical specifications TEX
Parameters
POWER REQUIREMENTS
AC Power Input
DC Power Input
MECHANICAL DIMENSIONS
Phisical Dimensions
Conditions
U.M.
AC Supply Voltage (*) Full range (**) Internal switch
AC Apparent and Active Power Consumption
Power Factor
DC Supply Voltage / Current
VAC
VA / W
VDC / ADC
Front panel width
Front panel height
Overall depth
Weight
mm (")
mm (")
mm (")
kg
Input 10 MHz
code
OPTIONS
VARIOUS
Cooling
Acoustic Noise
STANDARD COMPLIANCE
Safety
EMC
Spectrum Optimization
These are general specifications. They show typical values and are subject to change without notice.
dBA
99/5/CE
RVR USA 7782 NW 46 ST Miami, Fl 33178 T: 305-471-9091 F: 305-471-6979
www.rvrusa.com
Rev.: 02/2005
exciters
TEX 30
Value
TEX 50
Value
TEX 100/150
Value
80 ÷ 260 (*)
130 / 70
0,5
24 / 3.5 (*)
80 ÷ 260 (*)
200 / 100
0,5
24 / 4.5 (*)
115 / 230 ±15% (**)
440 / 260
0,6
28 / 8,2 (**)
483 (19")
88 (3 1/2") 2HE
400 (15,7")
6,7
483 (19")
88 (3 1/2") 2HE
400 (15,7")
8,5
483 (19")
88 (3 1/2") 2HE
400 (15,7")
8,5
/10MHz
/10MHz
/10MHz
Forced, with internal fan
< 58
Forced, with internal fan
< 58
Forced, with internal fan
< 58
EN60215:1989
EN 301 489-11 V1, 2, 1
ETS 300 447
EN60215:1989
EN 301 489-11 V1, 2, 1
ETS 300 447
EN60215:1989
EN 301 489-11 V1, 2, 1
ETS 300 447
These are general specifications. They show typical values and are subject to change without notice.
99/5/CE
RVR USA 7782 NW 46 ST Miami, Fl 33178 T: 305-471-9091 F: 305-471-6979
www.rvrusa.com
exciters
Technical specifications TEX
Rev.: 02/2005
