Listen Portable FM System
Personalize. Simplify. Customize.
Whether in a theater, house of worship, or at a sporting venue, individuals want to experience every word and every moment.
That’s what they came for, and they deserve to participate by hearing every single word.
Listen’s line of stationary FM products deliver a carefully tuned system of products that makes the process of specifying,
ordering, installing and using the system simple and straight forward. A Listen FM system is a low power radio station that
broadcasts sound to receivers within the range of the transmitter. A wide range of portable and stationary receivers allow you to
customize your system to your specific needs. Listen products deliver broadcast quality audio and are simple to use.
Don’t miss a single sound. Listen.
Personalize
Listen’s vision is to deliver a personalized, enriching
auditory experience in any setting. Consider attending a
lecture and not being able to fully understand what is being
said. With a Listen system, every word can be heard and
understood. What if the lecture is in English and you can
only understand Spanish? The same technology can deliver
the interpreted language directly to your ears. When you
can hear and understand – the experience truly becomes
personal!
Simplify
Listen is committed to keeping it simple. You will find
products that are easy to use and a company that is easy to
work with. Listen thinks through the finer details in the
design and production of products – for you the customer.
From pre-setting a default frequency on a transmitter so that
it can be used right out of the box to channel displays on
both the transmitter and receiver – the use of Listen’s
products is effortless. Listen’s full-time technical support
team is passionate about what they do and you can depend
on them to solve any equipment issues with confidence.
When you can easily use Listen products with the support
you need – the experience truly becomes simple!
Customize
One size does not fit all. Listen systems are designed to specifically fit your needs. While Listen’s systems are designed for simplicity, feel free to
inter-change or add components to create the right system for you. Listen’s team is ready to assist you with identifying exactly what you need.
When you can build the system that makes sense for your circumstances – the experience truly becomes custom!
1
Don’t miss a single sound. Listen.
A Listen Stationary FM system can do more than you think. While a Listen system can deliver crystal clear sound to a person with a
hearing impairment, it can also be used in other ways including:
• Language interpretation.
• Wireless speaker/receiver in nurseries, locker rooms, offices.
• Wireless audio distribution to remote rooms.
• Remote cueing.
Classrooms
Sports Venues
Whether it’s a 1,000 person high school gym
or a 100,000 person baseball stadium, a Listen
system can deliver sound to every seat in
the facility. Sport enthusiasts, press and the
athletic competitors can all enjoy the benefits
of a Listen system.
When you can hear better, you learn more. A Listen system
can deliver the instructor’s voice or the voice of an interpreter
directly to the student’s ears. The end result is improved grades
and instructors who are less fatigued because they don’t have
to speak loudly.
Theaters
Have you ever been experiencing a live play and asked your
partner “what did she just say?” We all have some level of
hearing impairment and sometimes we sit in a seat where
the sound is not as clear as we would like. A Listen system
delivers the voice of the actor directly to your ears.
Places of Worship
The primary message in a worship service is delivered in
the form of sound. A Listen system can ensure that every
individual can fully experience the service. You can use Listen
products for auditory assistance and for language
interpretation. You can also place a speaker/receiver in the
nursery or in an overflow area.
2
Listen Stationary FM System
Remote Mounted
Antenna Kits are the
single solution for all
of your indoor remote
antenna needs.
(LA-122 72/216 MHz)
(LA-130 863 MHz)
If you can’t run wires, an
LR-100 Listen stationary
receiver (72/216MHz
only) can wirelessly
receive the audio signal
and deliver it to the
remote room sound
system.
3
A Listen receiver allows the office staff
to hear what’s going on in the primary
meeting room.
Staffing the nursery or
overflow area doesn’t mean
missing the service. A Listen
LR-600 speaker/receiver
(72/216MHz only) allows the
service to be heard almost
anywhere.
Portable receivers
with earphones are
worn by guests.
Sound from the
mixing console is
broadcast to the
receiver.
The LT-800 transmitter connects to
the audio output of a mixing console
or any other audio device.
Interpreters listen to the service in
the base language and interpret the
service into a different language.
The interpreted language is
transmitted to individuals in the
room who listen on a portable
receiver with an earphone.
4
LT-800 Stationary FM Transmitter
Thanks to its outstanding audio quality, the Listen LT-800
Stationary Transmitter can be used in a variety of applications.
The LT-800 can be connected to your main audio system to
broadcast a high quality audio signal to belt pack receivers,
stationary receivers, or wireless speaker/receivers (72/216MHz
only). The end result– your audience can hear and understand the
presentation better because of improved speaker placement or
because they have their own belt pack and earphone.
The signature Look&Listen™ LCD shows channel, lock and
programming information. It has multiple audio inputs with level
control and mix level control. It also includes a test tone for tuning.
There are mounting options for racks and antenna.
1
4
2
5
Highlights
• Superior Audio Quality – 80 dB (70 dB with 863 MHz) signal-tonoise ratio, setting the industry’s sound quality standard.
• 57 Channels (72/216MHz), 17 Channels (863MHz) – you’ll
always find interference-free channels.
• Long transmission range ensures coverage for the entire venue.
• Advanced audio processing (can be deactivated) ensures
audio levels are consistent to users.
• Limited Lifetime Warranty with hassle-free support.
3
6
Key Specifications
1. Audio Section The input level of inputs 1 and 2 are adjusted by the INPUT control and are indicated on
the first two VU meters. Final transmit level is adjusted with the MIX LEVEL control. The CONTOUR
control boosts or cuts audio above 5 kHz. Listen’s exclusive technology delivers low noise
performance. A test tone is available to aid in set up.
2. Transmit Section Use the UP and DOWN buttons to select the transmission channel. The LCD
conveniently shows the selected channel, transmitter output power, lock and programming status.
3. Monitor Section You can listen to the transmitted audio using the monitor jack and volume control.
4. RF Section A unit mounted antenna can be directly connected to the RF OUTPUT jack or you can use a
remote antenna. RF power can be selected using the switch for one-quarter, half or full power.
5. Audio Output Section The dual, line level phono connectors provide an output consisting of a mix of
inputs 1 and 2.
6. Audio Input Section Connect your audio sources to inputs 1 and/or 2. Input 1 accepts a mono 3-pin
XLR or phone connector with a balanced selectable mic, phantom mic or line level audio. Input 2
accepts stereo phono connectors and is unbalanced with selectable input levels of -10 and +10dBu.
5
• Coverage: Line of site, 1,500 ft (457 m) / 3,000 ft
(914 m)/ 400 ft (122 m), 72/216/863MHz.
• Number of simultaneous channels: 6/3/8
72/216/863MHz.
• System audio performance: 50Hz - 15KHz
frequency response, >80dB SNR and <2% THD.
Configurations
LT-800-072 - 72 MHz
LT-800-216 - 216 MHz
LT-800-863 - 863 MHz
Accessories
• The LA-326 Universal Rack Mounting Kit can
rack mount one or two LT-800 Stationary FM
Transmitters (includes security cover).
LT-800 Stationary FM Antennas
Antennas
Choosing the right antenna for your application is critical to ensuring adequate transmission coverage. There are two types
of antenna – unit mounted and remote mounted. Unit mounted antennas can be mounted through an opening on top of
the unit or on a rear BNC connector. You need to match the frequency range (either 72 or 216MHz) for your application to
assure the purchase of the right antenna. Use the table below to make your selection. All remote antennas include 25 ft.
(7.6 m) of RG-58 coaxial cable.
LA-101
LA-122
LA-130
The LA-122 Universal Antenna Kit
is our most popular antenna
because it can be mounted in
many different configurations
including dipole, monopole, wall
mount, ceiling mount, and wall
plate. It can be used for 72 or
216MHz.
A solution for your remote antenna needs
for the LT-800 (863 MHz). The kit contains
monopole and dipole antenna options; and
hardware to mount on a wall, electrical box,
and horizontal surface (flat and inverse),
inside a wall or ceiling.
Includes 25 ft. (7.6 m) of RG-58 coaxial cable.
The LA-123 90º Helical antenna is a simple
solution for limited transmission range
applications.
Part Number
Description
Type
Frequency Range
Comments
LA-122
LA-101
LA-102
LA-106
LA-107
LA-116
LA-117
LA-123
LA-124
LA-125
LA-126
LA-131
LA-130
Universel Antenna Kit
Helical Top Mounted Antenna
Telescoping Top Mounted Antenna
Telescoping Top Mounted Antenna
Ground Plane Remote Antenna
Coaxial Dipole Remote Antenna
Coaxial Dipole Remote Antenna
90 Degree Helical
90 Degree Helical
Antenna Kit for Rack Mount
Antenna Kit for Rack Mount
Antenna Kit for Rack Mount
Remote Antenna Kit
Remote
Top Mounted
Top Mounted
Top Mounted
Remote
Remote
Remote
Unit or Remote
Unit or Remote
Rack Mount
Rack Mount
Rack Mount
Remote
72 or 216
72
216
72
216
72
216
72
216
72
216
863
863
Most popular and adaptable antenna.
Low profile for portable applications.
Provides the best coverage for unit mounted.
Provides the best coverage for unit mounted.
Ideal for outdoor applicatons.
Coaxial cable material making it easy to
install above ceiling tiles, etc.
Mount on the rear of unit or on a metal plate
on a wall.
Mount a 90 degree helical to the LA-326 rack
mount kit front panel.
Moun to the LA-326 front panel.
Coaxial Cable and Connectors
If you need to customize your installation, Listen provides a full range of RF connectors andcoaxial cable
available at www.listentech.com
6
FM Receivers
Listen offers three types of portable FM receivers that allow you
to customize your system to your specific needs. All three
receivers offer outstanding audio performance backed by
limited life time warranty. The LR-300 is Listen’s value receiver
and is available only in 72 MHz. Both the LR-400 and LR-500
offer an LCD display so you’ll see what’s going on. The LR-500
offers channel selection buttons for the user and
programmability for multiple channel applications like
language interpretation. In this case, you can program the
LR-500 to only display active channels.
2
Highlights
• Superior Audio Quality – 80 dB (70 dB with 863 MHz) signal-tonoise ratio, setting the industry’s sound quality standard.
• Easy to use.
• Multiple Channels – you’ll always find interference-free channels.
• Look&Listen™ LCD display (LR-400/500 only) shows channel,
battery status, signal strength, lock, and programming
information.
• Advanced battery management.
• SEEK button automatically finds a channel.
• Limited Lifetime Warranty with hassle-free support.
6
9
4
3
1
7
8
7
5
LR-300-072
LR-400-072
8
LR-400-863
Key Specifications
LR-500-216
6
1. Power/Volume On/off and volume control.
2. Earphone Jack 3.5 mm jack accepts either mono or stereo headsets.
3. Multi-Function LED Indicates power or low battery and charging status.
4. LCD Display (LR-400 and LR-500 only) Displays channel section, battery level, signal strength,
channel lock and program features (LR-500 only).
5. Channel Section The seek button allows you to scan for broadcasting channel, while the up/down
button (LR-400 and LR-500 only) allow you to manually change received channel. Buttons are located
inside the cover on the LR-400.
6. Charging Port/Contacts Used with charging cases or power supply to charge
NiMH batteries within the unit.
7. Door Locks Manually lock battery compartment door.
8. Battery Compartment Install alkaline or NiMH batteries to operate unit.
9. Antenna Articulating and flexible for easy storage (863MHz only).
• Receiver range from LT-800 Antenna: Line of site,
1,500 ft (457 m) / 3,000 ft (914 m), 400 ft (122 m),
72/216/863 MHz.
• Number of simultaneous channels: 6/3/8
72/216/863 MHz.
• System audio performance: 50-15KHz 72/863 MHz
50-10 KHz 216 MHz frequency response, >80dB
SNR and <2% THD.
Configurations
LR-300-072 – 72 MHz
LR-400-072 – 72 MHz
LR-400-216 – 216 MHz
LR-400-863 – 863 MHz
LR-500-072 – 72 MHz
LR-500-216 – 216 MHz
LR-500-863 – 863 MHz
Accessories
Accessories for Listen Receivers can be
found on the Receiver Accessories page 10
7
FM Receivers
Amplification anywhere without wires! All-in-one wireless
receiver, 2-channel 10 Watt power amplifier (15 Watt Peak, 10
Watt RMS). Place up to 3,000 feet away (at 216 MHz) from the
stationary transmitter and 150 feet away from a Listen portable
transmitter to receive and amplify the transmission audio.
Perfect for Soundfield applications! This unit is powered by AA
batteries (alkaline or NiMH rechargeables), or 15VAC power
supply or 12 VDC, for 15/10 Watt continuous power. It has
unbalanced auxiliary input and output ports. Listen’s signature
Look&Listen™ LCD display shows channel, lock, and battery
level. Comes with adjustable mounting bracket.
Highlights
• Super Quiet™ Technology provides superior audio quality.
• Easy to use.
• Multiple Channels – you’ll always find interference-free channels.
• 80dB Signal-to-Noise Ratio – best in class noise performance
ensures guests hear the sound and not the noise.
• Look&Listen™ LCD display shows channel, battery status, signal
strength, lock, and programming information.
• SEEK button automatically finds a channel.
• Limited Lifetime Warranty with hassle-free support.
• Unbalanced aux input and output.
• Adjustable 3-band equalizer.
8
2
6
1
4
3
1
5
9
Key Specifications
1. Channel Selector/Volume Change channel from the top or rear. Adjust volume from the top.
2. Charging/Power Port Power unit and/or charge NiMH batteries.
3. Adjustable 3-Band Equalizer Fine-tune audio output.
4. Input/Output Ports Unbalanced/auxiliary phono/input/output ports.
5. LCD Display Displays channel selection, battery level, signal strength, channel lock
and program features.
6. Antenna Use either the internal or optional external antenna.
7. Battery Compartment Unit can be powered by (8) alkaline batteries
or NiMH rechargeable batteries.
8. Adjustable Handle/Mounting Bracket For mounting on wall, ceiling
or microphone stand.
9. Speaker 15/10 watt (peak/RMS) 4 ohm 2-way speaker.
• Receiver range from LT-800 Antenna: Line of site,
1,500 ft (457 m) / 3,000 ft (914 m), 72/216MHz.
• Number of simultaneous channels: 6/3,
72/216MHz.
• System audio performance: 50-15KHz frequency
response, >80dB SNR and <2% THD.
Configurations
LR-600-072 – 72 MHz
LR-600-216 – 216 MHz
NOTE: Not available in 863MHz.
Accessories
Accessories for Listen Receivers can be
found on the Receiver Accessories page 10.
8
FM Receivers
Listen’s LR-100 Stationary Receiver / Power Amplifier is a
stationary auditory assistance receiver with a built-in power
amplifier. When used with a Listen transmitter, the LR-100 can
deliver high quality audio for use in a variety of locations and
applications – most commonly soundfields. This unit has Listen’s
signature Look&Listen™ LCD Display showing channel, lock, and
battery level. A security cover protects auxiliary and receiver
volume and trim controls. It has an adjustable squelch control,
and balanced or unbalanced speaker wire output options.
Multiple input options give this unit great flexibility.
It’s powered by a 16VAC/1000mA power input or 12 VDC
battery. Add an antenna for longer range applications.
1
Highlights
• Super Quiet™ Technology provides superior audio quality.
• Look&Listen™ LCD.
• 57-programmable channels.
• Adjustable squelch control.
• Selectable audio output.
• Multiple input and output options.
2
3
4
6
7
5
6
Key Specifications
1. Audio Section Audio can be adjusted for volume and quality via trim pots and switches. Listen
exclusive technology delivers low noise performance.
2. Receive Section Use the UP and DOWN buttons to select the transmission channel. The LCD
conveniently shows the selected channel, transmitter output power, lock and programming status.
3. Monitor Section You can listen to the transmitted audio using the monitor jack and volume control.
4. Speaker Volume Adjustable volume control for speaker output.
5. Audio Output Section Offers three different output options: unbalanced/phono, balanced male XLR
and Phoenix connector for speaker.
6. Audio Input Section Three different audio inputs: RF signal through the antenna, unbalanced/phono
or balanced/female XLR 1/4 inch combo connector.
7. Power Connect a power supply (included) to the back of the unit.
• Receiver range from LT-800 Antenna: Line
of site, 1,500 ft (457 m) / 3,000 ft (914 m),
72/216MHz.
• Number of simultaneous channels: 6/3,
72/216MHz.
• System audio performance: 63 Hz - 15KHz
frequency response, >80dB SNR and <2% THD.
• Speaker Output: 15/10 wats (peak/RMS) with 4
ohm load.
Configurations
LR-100-072 - 72MHz
LR-100-216 - 216MHz
NOTE: Not available in 863MHz.
Accessories
9
• The LA-326 Universal Rack Mounting Kit can
rack mount one or two LR-100 Stationary FM
Receivers (includes security cover).
FM
Systems
Receiver Accessories and Stationary FM
Systems
Accessories
Listen’s Stationary FM Accessories offer a wide array of options to meet your audio needs. Antennas, Mounting Kits, Connectors/Cables,
Batteries/Power Supplies, Charging/Carrying Cases, Earphones/Speakers, and Microphones all provide the custom support you and your
guests need so that you don’t miss a single sound.
FM Product Cases
Earphones
Antennas
LA-124
LA-321
LA-170
• LA-311
• LA-313
• LA-317
• LA-318
• LA-320
• LA-321
• LA-322
• LA-323
• LA-324
• LA-325
16-Unit Portable Charging/Carrying Case
16-Unit Portable Carrying Case
4-Unit Portable Charging/Carrying Case
4-Unit Portable Carrying Case
Configurable Carrying Case
8-Unit Portable Charging/Carrying Case
8-Unit Portable Carrying Case
4-Unit Portable Charging/Carrying Case w/Removable Lid
8-Unit Portable Charging/Carrying Case w/Removable Lid
16-Unit Portable Charging/Carrying Case w/Removable Lid
• LA-161 Single Ear Bud
• LA-162 Stereo Ear Buds
• LA-164 Earspeaker
• LA-165 Stereo Headphones
• LA-166 Neck Loop
• LA-170 Behind-the-Head
Stereo Headphones
• LA-101 Helical Top Mounted Antenna
• LA-102 or LA-106 Telescoping Top
Mounted Antenna
• LA-107 Ground Plane
• LA-116 or LA-117 Coaxial Dipole
Remote Antenna
• LA-122 Universal Antenna Kit
• LA-123 or LA-124 90 Degree Helical Antenna
• LA-130 Remote Antenna Kit (863 MHz)
• LA-131 Antenna Kit for Rack Mount (863 MHz)
Stationary FM Systems
Listen’s Stationary FM Systems offer a simple foundation for building a custom system that delivers all your audio needs. Each Stationary
FM system can be used for assisted listening, in-ear cueing, and press feeds, while helping public venues to meet government guidelines
such as Americans with Disabilities Act (ADA).
LS-04
Product Description
LT-800 Stationary Transmitter
System Part Number
LS-01
LS-02
LS-03
1
1
1
1
1
1
1
1
LA-326 Universel Rack Mounting Kit
LA-106 Top Mounted Telescoping Antenna
1
1
3
4
LA-122 Univeral Antenna Kit
LR-300 Body Pack Digital FM Receiver
LR-400 Body Pack Display FM Receiver
4
LR-500 Programmable Display FM Receiver
4
LA-361 High Capacity AA Alkaline Batteries (2)
4
LA-362 Rechargeable AA NiMH Batteries (2)
LA-161 Single Ear Bud
4
3
4
LA-164 Ear Speaker
LA-317 4-Unit FM Products Charging/Carrying Case
LA-304 Assistive Listening Notification Signage Kit
Example:
System Designator
Listen System
LS-03-216
Frequency
LS-04
1
1
4
4
1
1
1
Each Stationary FM System delivers Listen’s commitment to
providing you with a customizable solution that is simple to
specify, install, and use. You will enjoy outstanding performance
with exceptional support from the Listen team.
Don’t miss a single sound. Listen.
10
Frequency Chart
72MHz Range:
Channel
Frequency
Channel
216MHz Range
Frequency
Channel
Frequency
Channel
863MHz Range
Frequency
Channel
Frequency
1
72.025
20
72.975
1A
216.0125
2K
216.5250
01
863.050
2
72.075
33
74.625
2A
216.0250
3K
216.5375
02
863.200
A
72.100
34
74.675
3A
216.0375
1L
216.5625
03
863.400
3
72.125
I
74.700
1B
216.0625
2L
216.5750
04
863.550
4
72.175
35
74.725
2B
216.0750
3L
216.5875
05
863.750
K
72.200
36
74.775
3B
216.0875
1M
216.6125
06
863.900
5
72.225
37
75.225
1C
216.1125
2M
216.6250
07
864.100
6
72.275
38
75.275
2C
216.1250
3M
216.6375
08
864.250
B
72.300
J
75.300
3C
216.1375
1N
216.6625
09
864.450
7
72.325
39
75.325
1D
216.1625
2N
216.6750
10
864.600
8
72.375
40
75.375
2D
216.1750
3N
216.6875
11
864.800
N
72.400
R
75.400
3D
216.1875
1P
216.7125
12
864.950
9
72.425
21
75.425
1E
216.2125
2P
216.7250
13
863.300
10
72.475
22
75.475
2E
216.2250
3P
216.7375
14
863.650
C
72.500
F
75.500
3E
216.2375
1R
216.7625
15
864.000
11
72.525
23
75.525
1F
216.2625
2R
216.7750
16
864.350
12
72.575
24
75.575
2F
216.2750
3R
216.7875
17
864.700
O
72.600
S
75.600
3F
216.2875
1S
216.8125
13
72.625
25
75.625
1G
216.3125
2S
216.8250
14
72.675
26
75.675
2G
216.3250
3S
216.8375
D
72.700
G
75.700
3G
216.3375
1T
216.8625
15
72.725
27
75.725
1H
216.3625
2T
216.8750
16
72.775
28
75.775
2H
216.3750
3T
216.8875
P
72.800
T
75.800
3H
216.3875
1U
216.9125
17
72.825
29
75.825
1J
216.4125
2U
216.9250
18
72.875
30
75.875
2J
216.4250
3U
216.9375
E
72.900
H
75.900
3J
216.4375
1V
216.9625
19
72.925
31
75.925
1K
216.5125
2V
216.9750
32
75.975
3V
216.9875
The highlighted rows are wide band channels.
Listen Technologies Corporation
14912 Heritagecrest Way
Bluffdale, Utah 84065-4818, U.S.A.
+1.801.233.8992
+1.800.330.0891 North America
+1.801.233.8995 Fax
www.listentech.com
[email protected]
Listen Technologies GmbH
Jasminstr. 16
905022 Oberasbach, Germany
+49 911 955159 0 Tel
+49 911 955159 40 Fax
www.listentech.de
[email protected]
Printed in the United States of America
© 2007 Listen Technologies Corporation® All Rights Reserved 2007917
12
Don’t miss a single sound.
Don’t miss a single sound. Listen.
Listen Technologies Corporation believes in experiencing
every sound, whether it’s the carefully chosen words of a
presiding judge or the subtleties of expression emanating from an
orchestra’s string section. It’s all a part of the experience, and Listen is
dedicated to making sure every individual hears every sound.
Listen’s line of stationary infrared (IR) products deliver on this promise
by providing a carefully tuned system of products. Listen makes the
process of specifying, ordering, installing, and using the system simple
and straight forward. A Listen IR system fills the room with non-visible
infrared light. Each receiver detects the IR light and turns it into sound
ensuring every individual can be part of the total experience. Because
it’s light, the IR signal never leaves the room and it cannot be received
out of the room, thereby creating a secure environment with no
concern of eavesdropping.
Places of Worship
Members of a congregation come to their places of worship looking for words
of encouragement and enlightenment. A Listen system ensures that each
individual can fully enjoy this experience. Using IR technology ensures that only
those within the sanctuary receive the signal.
Performing Art Centers
Imagine going to a theater performance and not being able
to understand all that is being said. A Listen system delivers
high quality sound to every listener in the theater, while
ensuring the performance is not recorded outside of the
main hall.
Classrooms
Studies prove that students learn more when they can hear
well. A Listen system delivers the voice of the instructor
directly to their ears. Because IR signals are isolated to each
room, the same receiver can be used for every classroom
with the same settings. With a radio (RF) signal, the receiver
must be tuned to different channels for each room.
Language Interpretation
1
The key witness in a case is a
student from Brazil and only
speaks Portuguese. A Listen
system delivers an interpreter’s
English version of the testimony
to each of the jurors. Since the IR
light will not leave the courtroom,
the judge is not concerned about
the testimony being heard outside
of the courtroom.
Listen Stationary IR System
There are three main components involved in the Listen Stationary IR system:
Receivers(s)
The IR light from the radiators is detected by
the receivers and turned into sound. Listen
offers the LR-42 stethoscope and LR-44
lanyard style receivers. The stethoscope is an
“all-in-one” unit, making it easy to keep track of
checked out equipment. The lanyard receiver
accepts any style of 3.5 mm earphone, giving
users more choices.
Radiator(s)/Emitter(s)
The radiator transforms the RF audio signal from the LT-82
transmitters into an IR signal. This is essentially a
“headlight” that illuminates the room with non-visible IR
light. The size and shape of the room will determine how
many radiators or “headlights” you’ll need to fill the room
for adequate signal coverage. It’s powered by either the
LT-82 transmitter or an LA-205 extension/replacement
power supply. Hardware for most types of mounting
configurations, comes standard with each radiator, and is
available in two colors; grey or white.
Transmitter(s)
Highlights
• Simple to specify, install, maintain, and use.
• Secure – the signal will not leave the room.
• Up to four simultaneous mono or stereo channels allows for expanded applications.
• Uses higher modulation (2.3 to 3.8MHz) frequencies thereby decreasing the risk of
light interference from fluorescent lights and other sources.
• Installation is simple using CAT-5 cables for power distribution.
• The radiator mounting hardware is included with each radiator.
• Users will enjoy the simple but refined look and feel of both the stetho and
lanyard receivers.
• Advanced battery management ensures long battery life.
• Uses standard AAA alkaline batteries or an optional rechargeable pack (LA-364).
• Compatible with other manufacturers.
• Limited lifetime warranty (radiator – 3 years and accessories 90 days).
The LT-82 Stationary IR Transmitter accepts audio from
an audio mixing console or other sources. It then turns
this audio signal into an RF signal and delivers it to an
LA-140 radiator via RG-58 coaxial cable. The LT-82 also
provides DC power for up to two LA-140 radiators via
standard CAT-5 cabling. For a single channel system
(mono or stereo) use one LT-82. Add more channels
(up to 4 total) by adding more LT-82 units.
Two cables connect the LT-82 Transmitter to the
radiator(s). CAT-5 cable is used for power, and RG-58
coaxial cable is used for the signal. When more than
one radiator is needed, they can be daisy-chained
using the same type of cable. One LT-82 can power up
to two radiator.
2
LT-82 Stationary IR Transmitter
The Listen LT-82 is the heart of the stationary IR listening
system. It takes the desired audio signal and sends it via coaxial
cable to one or more IR radiator(s) (LA-140). The LT-82 can be
operated in mono or stereo on one of four different carriers;
up to four LT-82 units may be connected to provide up to four
mono or stereo carriers to the radiator(s). The LT-82 generates
DC power to power up to two LA-140 radiators. Two LT-82 units
can be rack mounted in one rack space using the universal rack
mount kit (LA-326). The LT-82 is used for government
compliance (such as ADA), assistive listening, language
interpretation, live theatre, houses of worship, courtrooms,
secure rooms, and auditory description.
1
4
5
2
6
Highlights
• Use up to four LT-82 units to create a 1 to 4
(mono or stereo) channel system.
• The LT-82 will power up to two LA-140 radiators.
• Several audio input configurations to fit most
installations.
• Audio processing can be activated as desired.
3
7
Key Specifications
1 A
udio Section
The input level of inputs 1 and 2 are adjusted by the INPUT control and are indicated on the first two VU
meters. Final transmit level is adjusted with the TRANSMIT LEVEL control. The CONTOUR control boosts or
cuts audio above 5 kHz. The PROCESS indicator is illuminated when the internal audio processor is activated. The STEREO indicator is illuminated when the stereo encoder is activated. A test tone is available to
aid in set up.
2. T
ransmit Section Use the UP and DOWN buttons to select the transmission channel. The LCD
conveniently shows the selected channel, radiation status (on or off ), lock and programming status.
3. Monitor Section You can listen to the transmitted audio using the monitor jack and volume control.
4. RF Section RF is delivered to the radiators using the two RF OUTPUT BNC
connectors. If more than one channel is required, daisy chain multiple LT-82 units together.
5. Power Section Connect the universal power supply (included) to the unit with the POWER INPUT CAT-5
connector. The POWER OUTPUT connectors are used to power up to two LA-140 radiators.
6. Audio Output Section The stereo, line level phono connectors provide an output
consisting of a mix of inputs 1 and 2.
7. A
udio Input Section Connect your audio source to inputs 1 and/or 2. Input 1 accepts a mono 3-pin
XLR or phone connector with balanced, selectable mic, phantom mic or line level audio. Input 2 accepts
stereo phono connectors and is unbalanced with selectable input levels of -10 and +10dBu.
3
• Input voltage 100-240VAC, 47-63Hz
• System audio performance 63-15KHz
frequency response, >60dB signal to
noise ratio (SNR) and <2% total
harmonic distortion (THD).
Configurations
• LT-82-01 North America
• LT-82-02 Asia, UK
• LT-82-03 Europe
Accessories
• The LA-326 Universal Rack Mounting Kit can
rack mount one or two LT-82 Stationary IR
Transmitters (Includes security cover).
LA-140 Stationary IR Radiator/Emitter
The LA-140 IR radiator/emitter packs high infrared power in a
small and attractive design, with your choice of grey or white
packaging. Designed for easy installation using standard
components, the LA-140 is powered via CAT-5 cabling while the
RF modulated carriers are delivered via standard RG-58 coaxial
cable. Mounting brackets are included for wall, ceiling, desk, mic
stand, and tripod mounting. Power can be supplied by the LT-82
transmitter or from a separate power supply (LA-205). Built-in
delay compensation prevents signal cancellation (multi-path)
problems and eliminates the piled-up cabling that is required
with other systems. The LA-140 is used for government
compliance (such as ADA), assistive listening, language
interpretation, live theatre, houses of worship, courtrooms,
secure rooms, and auditory description.
Highlights
• Architecturally friendly design with white or grey color options.
• Simple to install using CAT-5 and RG-58 cables.
• Mounting hardware included makes every installation simple.
• Double radiator mounting options for twice the power.
• Delay compensation adjustments built in.
• 25 feet (7.6 m) of coaxial cable are included with the radiator.
Key Specifications
1
3
2
4
• 10,000 ft2 (929 m2) coverage (one
channel) when used with Listen receivers
( half coverage per radiator with two
c hannels, quarter coverage with
four channels).
• CAT-5 and RG-58 maximum cable length:
1,000 ft (305 m).
• One LT-82 or one LA-205
Extended/Replacement Power Supply can
power up to two LA-140 radiators.
Configurations
• LA-140-GY Grey
• LA-140-WH White
with LA-205-01 North America
LA-205-02 Asia, UK
LA-205-03 Europe
1. L
ED Indicators The three colored LEDs provide visual indication of power, connectivity,
and the presence of a signal. These LEDs can be deactivated in light sensitive rooms.
2. Mounting Hardware and Cable Installation is quick and easy with the included
mounting hardware for wall, ceiling, desk (shown), mic stand or tripod. Listen also
includes 25 feet (7.6 m) of CAT-5 and RG-58 cables (including connectors).
3. RF Section RF from the LT-82 or another radiator is accepted at the RF INPUT BNC. The
RF OUTPUT jack feeds RF to additional LA-140 radiator(s). The delay compensation
adjustment ensures that all RF signals are transmitted by the radiator at the same time,
thereby eliminating receiver drop outs created when signals are out of phase. The
TERMINATION switch terminates the coaxial cable on the last radiator in the daisy chain.
4. P
ower Section The CAT-5 POWER INPUT connector accepts power from the LT-82
transmitter, from an optional LA-205 power supply or from another LA-140 radiator. The
POWER OUTPUT connector provides power for up to one additional radiator. The dip
switches are for setting options.
Accessories
• LA-342 Dual IR Radiator Mounting Bracket
• LA-205 Extension/Replacement Power Supply
C
able accessories available at: www. listentech.com
4
LR-42/44 Infrared Receivers
Users will love the comfortable, easy to use Listen LR-42 and
LR-44 Receivers with the ability to receive up to four channels
in mono or stereo. They use standard AAA alkaline batteries for
more than 30 hours of operation, or a NiMH rechargeable
battery pack that delivers 15 hours of use per charge. The unit
features auto shut-off after 30 minutes of no audio
carrier, further extending battery life. The LR-42/44 boasts high
performance audio specs in a small package and is
compatible with other manufacturers’ products. The LR-42/44
is used for government compliance (such as ADA), assistive
listening, language interpretation, live theatre, houses of
worship, courtrooms, secure rooms, and auditory description.
Highlights
• Easy to use with outstanding audio performance.
• Users have the option of either the LR-42 stetho receiver, or the
LR-44 lanyard receiver which is compatible with a variety of
earphones.
• Auto-shut off extends battery life.
• Outstanding battery life (up to 30 hours).
• Uses standard AAA alkaline non-proprietary batteries, or
rechargeable battery pack.
• LA-350 and LA-351 charging/storage platforms make it simple
and easy to charge batteries, store and distribute units.
• Programmable options expand applications and simplify
channel selection for users.
Key Specifications
•3
0/15 hours battery life AAA
alkaline/rechargeable batteries.
• 63-15kHz frequency response,
60dB SNR, <2% total
harmonic distortion (THD).
Configurations
2
3
• LR-42 IR Stethoscope 4-Channel Receiver
• LR-44 IR Lanyard 4-Channel Receiver
Accessories
4
1
1. U
ser Buttons Press the POWER button to turn the unit on or to check battery status after power
up. The SEL button changes the channel.
2. LED Indicators When the SEL is pressed the LED indicators indicate which of the four channels is
selected. If the POWER is pressed, the battery status is indicated.
3. Volume Control The user adjusts this to set the volume on the earphones.
4. Battery A removable battery compartment houses two AAA alkaline batteries, or a sealed NiMH
rechargeable battery pack
• LA-350 8-unit IR Charging/Storage Station.
(Includes a tidy rack)
Configurations:
• LA-350-01 North America
• LA-350-02 Asia, UK
• LA-350-03 Europe
• LA-351 8-unit IR Storage Station, not shown
(looks the same as the LA-350, but does not
charge the batteries.)
5
Stationary IR Accessories and Systems
Accessories
LA-151 (shown)
• LA-364 NiMH Rechargeable Battery Pack
• LA-363 AAA Alkaline Batteries
LA-164 (shown)
• LA-161 Single Ear Bud for LR-44
• LA-162 Stereo Ear Buds for LR-44
• LA-164 Earspeaker for LR-44
• LA-165 Stereo Headphones for LR-44
• LA-166 Neck Loop for LR-44
• LA-151 Replacement Ear Tips for LR-42.
• LA-150 Replacement Lanyard for LR-44
Stationary IR Systems
Listen’s Stationary IR Systems meet the needs of the
novice to the advanced user, offering a range of options
for both budget and applications. The Basic Stationary IR
System (LS-80-SIR) includes four stetho receivers ideal for
venues wishing to comply with regulated assistive
listening requirements. Our Performance Stationary
IR System (LS-81-SIR) is designed for installations that
require mounting of the transmitter and the radiator.
The Advanced Installed IR System (LS-82-SIR) is ideal for
frequent use with great signal coverage. Eight stetho
receivers, NiMH rechargeable battery packs and a
charging station are included.
An itemized listing for each IR System is described below:
Product Description
System Part Number
LT-82 Stationary IR Transmitter
LS-80-SIR
LS-81-SIR
LS-82-SIR
LS-83-SIR
LS-84-SIR
LS-85-SIR
1
1
1
4
2
1
1
1
2
1
1
LA-326 Universal Rack Mounting Kit
LA-140 Stationary IR Radiator
1
2
2
8
1
1
LR-42 IR Stethoscope 4-Channel Receiver
4
4
8
48
5
3
LR-44 IR Lanyard 4-Channel Receiver
1
LA-166
1
LA-363 High Capacity AAA Alkaline Batteries (2)
4
4
LA-364 NiMH Rechargeable Battery Pack
LA-350 8-Unit Charging/Storage Station
LA-351 8-Unit Storage Station
4
8
48
5
1
6
1
1
2
1
1
LA-304 Assistive Listening Signage Kit
1
1
1
• To designate white or grey colors for the radiators add designators -WH or -GY.
• For power cords add the following designators for selected region configuration:
North America -01
Asia, UK -02
Europe-03
Example:
System Designator
Listen System
Color
LS-82-SIR-GY-01
Product Type
Configuration
Each Stationary IR System delivers Listen’s commitment to
providing you with a customizable solution that is simple to
specify, install, and use. You will enjoy outstanding performance
with exceptional support from the Listen team.
Don’t miss a single sound. Listen.
6
Listen Technologies Corporation
14912 Heritagecrest Way
Salt Lake City, Utah 84065-4818, U.S.A.
801.233.8992
800.330.0891 North America
801.233.8995 fax
www.listentech.com
[email protected]
Printed in the United States of America
© 2006 Listen Technologies Corporation® All Rights Reserved 2006 2006829
Don’t miss a single sound.
Don’t miss a single sound. Listen.
Listen Technologies Corporation believes your audience is there to learn or to be
entertained, and that they ought to enjoy a personalized, enriching auditory
experience. Many environments present challenges for the listener to clearly hear,
appreciate, and understand what is being communicated. Listen is committed to
ensuring that our products provide the auditory experience your audience deserves.
Language Interpretation
Listen’s line of portable FM products deliver on this commitment by providing a
carefully tuned system of products that makes the process of specifying, ordering,
and using the system simple and straight forward. A Listen FM system functions like a
low power radio station that broadcasts sound to receivers within range of the
transmitters. The Portable FM system is a great way to deliver interference-free, clear
sound directly to each individual, dramatically enhancing their individual experience
and ensuring that they get the full experience they desired.
Don’t miss a single sound. Listen.
Imagine being in a foreign country to do business, but unable
to understand what your business partners are saying.
A portable FM system delivers high quality sound to every
listener in your group, allowing your interpreter to facilitate
communication in even the loudest of environments.
Press Conferences
Tour Group
Have you ever been on a tour and not been able to hear the
information being provided by the tour guide? When you are
on a tour you are there to not only see what is being shown, but
also to hear what is being said. Unfortunately, sometimes the
environment itself poses hearing difficulties. Listen can help by
ensuring visitors get a clear and interference-free experience.
A press conference can be an atmosphere charged with
excitement and commotion. When news is being reported, you
want to be sure you are hearing the message clearly and without
disruption. Your ability to do that relies on your ability to
understand what you are hearing. A Listen system brings the
information directly to your ears as if the speaker is giving you
the inside scoop on the news.
Employee Training
1
When you are trying to learn, hearing the message is
imperative. A Listen system can deliver an instructors
voice directly to the student’s ears providing them
with the ability to understand and process the
information more effectively. The end result is more
effective training and instructors who are less
fatigued because they don’t have to speak loudly.
Listen Portable FM System
Provide your guests with a
thorough visit of your operations.
Placing Listen’s LR-600 Receiver in
strategic areas allows your guests
to fully tour your facility, even in
areas where access is limited or in
overflow areas.
Deliver your message clearly, even
in the noisiest environment! Listen’s
hands-free equipment allows you
to deliver key information clearly
and safely while moving around
your operation.
Customize tours for your international guests,
by providing a system for delivering
simultaneous language interpretation.
Your message will be heard clearly and in your
guest’s own language.
Listen’s wide range of channels
means you can use one or more
systems in one area without
interference. Conduct up to six
simultaneous tours, the LCD
Display makes it easy to tune to
the correct audio presentation.
Highlights
• 57 Channels – you’ll always find interference-free channels.
• Conduct up to 6 simultaneous tours and offer language interpretation.
• Minimal interruptions to others not on the tour.
• Limited Lifetime Warranty with hassle-free support.
• Look&Listen™ LCD display shows channel, battery status, signal strength, lock, and
programming information.
• Uses standard AA alkaline batteries or optional NiMH rechargeable batteries.
• Compatible with other manufacturers.
• Easy to use and manage inventory.
2
LT-700 Portable Transmitter
The LT-700 Portable Transmitter will broadcast your interpreter or
tour guide’s voice to everyone in the audience, without having to
carry a microphone or be plugged into the wall. Excellent for factory
tours, outdoor events, wireless microphone applications, classroom,
training, or personal use -- anywhere you need to amplify sound
but don’t have (or want) an installed sound system. The signature
Look&Listen™ LCD shows channel, lock and battery level. It takes AA
batteries (alkaline or NiMH rechargeable). SmartCharge™
capabilities prevent overcharging of batteries. The antenna is in the
mic cord and has an adjustable mic sensitivity switch.
• Super Quiet™ Technology provides superior audio quality.
• Look&Listen™ LCD shows channel, battery status,
and programming information.
• Mic or line level inputs.
• 57-Channel selection.
• 80dB Signal-to-Noise Ratio – best in class noise performance
ensures guests hear the sound and not the noise.
• Standard Alkaline or NiMH bateries.
• Mute button.
• Limited Lifetime Warranty with hassle-free support.
1
3
2
Highlights
7
4
8
8
6
5
9
7
9
Key Specifications
• Range: Line of site, up to 50m.
• Number of simultaneous channels: 6/3,
72/216MHz (TBD at 863MHz).
• Audio performance: 63 Hz-15KHz frequency
response, >80dB SNR and <2% THD.
1. Mute Switch Easy access mute/talk switch.
2. Microphone Jack 3.5mm mic jack for microphone or line level audio source.
3. Multi-function LED Indicates when unit is muted, batteries are low, and charging status.
4. LCD Display Displays channel selection, battery level, and channel lock for programming.
5. Channel Section Allows you to manually change the broadcast channel.
6. Power Turns the unit On/Off.
7. Charging Port/Contacts Used with charging cases or power supply to charge NiMH
batteries within the unit.
8. Door Locks Manually lock battery compartment door.
9. Battery Compartment Install alkaline or NiMH batteries to operate unit.
3
Configurations
LT-700-072 - 72MHz
LT-700-216 - 216MHz
LT-700-863 - 863-865MHz
Accessories
Accessories for the LT-700 can be found on
the Portable Product Accessories page 6.
FM Receivers
Listen offers two types of portable FM receivers that allow
you to customize your system to your specific needs. Both
receivers offer 57 channels for outstanding audio
performance backed by limited lifetime warranty.
The LR-400 and LR-500 offer Listen’s Look&Listen™ LCD
display so you’ll see what’s going on. The LR-500 offers
channel selection buttons for the user and programmability
for multiple channel applications like language
interpretation. In this case, you can program the LR-500 to
only display active channels limiting the number of
channels your guests have to seek through.
2
3
Highlights
• Super Quiet™ Technology provides superior audio quality.
• Easy to use.
• Multiple Channels – you’ll always find interference-free channels.
• 80dB Signal-to-Noise Ratio – best in class noise performance
ensures guests hear the sound and not the noise.
• Look&Listen™ LCD display shows channel, battery status, signal
strength, lock, and programming information.
• SEEK button automatically finds a channel.
• Limited Lifetime Warranty with hassle-free support.
1
4
6
7
7
5
8
8
LR-400 (shown)
LR-400
LR-500
6
1. P
ower/Volume On/off and volume control.
2. Earphone Jack 3.5 mm jack accepts either mono or stereo headsets.
3. Multi-function LED Indicates power or low battery and charging status.
4. LCD Display Displays channel selection, battery level, signal strength,
channel lock and program features (LR-500 only).
5. C
hannel Section The seek button allows you to scan for the broadcasting channel, while the
up/down button allows you to manually change the receive channel. Buttons are located inside
the cover on the LR-400.
6. Charging Port/Contacts Used with charging cases or power supply to charge
NiMH batteries within the unit.
7. Door Locks Manually lock battery compartment door.
8. Battery Compartment Install alkaline or NiMH batteries to operate unit.
Key Specifications
•R
eceiver range from LT-700: Line of site, 150 ft
(45.7 m), 72/216MHz. (TBD at 863MHz).
• Number of simultaneous channels: 6/3,
72/216MHz. (TBD at 863MHz).
• System audio performance: 50-15KHz
frequency response, >80dB SNR and <2% THD.
Configurations
LR-400-072 – 72 MHz
LR-400-216 – 216 MHz
LR-400-863 – 863-865 MHz
LR-500-072 – 72 MHz
LR-500-216 – 216 MHz
LR-500-863 – 863-865 MHz
Accessories
Accessories for Listen Receivers can be found
on the Portable Product Accessories page 6.
4
FM Receivers
Amplification anywhere without wires! All-in-one wireless
receiver, 2-channel 10 Watt power amplifier. Place up to 150 feet
away from a Listen portable transmitter to receive and amplify
the transmission audio. This unit is powered by AA batteries
(alkaline or NiMH rechargeables), or 15VAC power supply or 12
VDC, for 15/10 Watt continuous power. It has unbalanced
auxiliary input and output ports. Listen’s signature
Look&Listen™ LCD display shows channel, lock, and battery
level. Comes with adjustable mounting bracket/handle.
Highlights
• Super Quiet™ Technology provides superior audio quality.
• Easy to use.
• Multiple Channels – you’ll always find interference-free channels.
• 80dB Signal-to-Noise Ratio – best in class noise performance
ensures guests hear the sound and not the noise.
• Look&Listen™ LCD display shows channel, battery status, signal
strength, lock, and programming information.
• SEEK button automatically finds a channel.
• Limited Lifetime Warranty with hassle-free support.
• Unbalanced aux input and output.
• Adjustable 3-band equalizer.
8
2
6
1
4
3
1
5
9
Key Specifications
1. C
hannel Selector/Volume Change channel from the top or rear. Adjust volume from the top.
2. Charging/Power Port Power unit and/or charge NiMH batteries.
3. Adjustable 3-Band Equalizer Fine-tune audio output.
4. Input/Output Ports Unbalanced/auxiliary phono/input/output ports.
5. LCD Display Displays channel selection, battery level, signal strength, channel lock
and program features.
6. A
ntenna Use either the internal or optional external antenna.
7. Battery Compartment Unit can be powered by (8) alkaline batteries or NiMH rechargeable batteries.
8. Adjustable Handle/Mounting Bracket For mounting on wall, ceiling or microphone stand.
9. Speaker 15/10 watt (peak/RMS) 4 ohm 2-way speaker.
•Receiver range from LT-700: Line of site, 150 ft
(45.7 m), 72/216MHz. (TBD at 863MHz).
• Number of simultaneous channels: 6/3,
72/216MHz. (TBD at 863MHz).
• System audio performance: 50-15KHz frequency
response, >80dB SNR and <2% THD.
Configurations
LR-600-072 – 72 MHz
LR-600-216 – 216 MHz
LR-600-863 – 863 - 865 MHz (request availability)
Accessories
Accessories for Listen Receivers can be found
on the Protable Product Accessories page 6.
5
Portable Product Accessories and Systems
Accessories
Listen provides a variety of accessories to meet your Portable FM needs. Choose from Connectors/Cables,
Batteries/Power Supplies, Charging/Carrying Cases, Earphones/Speakers, and Microphones all providing outstanding
performance for crisp, clear sound.
Microphones
FM Product Cases
Earphones
LA-321 (shown)
LA-165 (shown)
LA-278 (shown)
• LA-261 Lavalier Microphone
• LA-262 Over-the-Head Microphone
• LA-270 Noise Cancelling Microphone
• LA-272 Over-the-Head Microphone with Earphone
• LA-274 Hand Held Microphone
• LA-276 Collar Microphone
• LA-277 Conference Microphone
• LA-278 Behind-the-Head Microphone
• LA-279 Over-the-Ear Microphone
Portable FM Systems
• LA-311
• LA-313
• LA-317
• LA-318
• LA-320
• LA-321
• LA-322
• LA-323
• LA-324
• LA-325
16-Unit Portable Charging/Carrying Case
• LA-161 Single Ear Bud
16-Unit Portable Carrying Case
• LA-162 Stereo Ear Buds
4-Unit Portable Charging/Carrying Case
• LA-164 Earspeaker
4-Unit Portable Carrying Case
• LA-165 Stereo Headphones
• LA-166 Neck Loop
Configurable Carrying Case
• LA-170 Behind-the-Head
8-Unit Portable Charging/Carrying Case
Stereo Headphones
8-Unit Portable Carrying Case
4-Unit Portable Charging/Carrying Case w/Removable Lid
8-Unit Portable Charging/Carrying Case w/Removable Lid
16-Unit Portable Charging/Carrying Case w/Removable Lid
Listen’s Portable FM Systems are designed for use by an individual or multiple individuals. The Personal FM System is a great
system to take to school, a house of worship, training facility, etc. The multi-person systems are ideal for organizations that want to
ensure that their visitors hear and understand every word. These systems can be used indoors or outdoors and are a terrific mobile
solution for language interpretation.
LS-07 (shown)
Product Description
System Part Number
LS-05
LS-06
LS-07
LS-08
LS-13
LS-14
LT-700 Portable FM Display Transmitter
1
1
1
1
1
1
LA-261 Lavalier Microphone
1
1
LA-278 Behind-the-Head Microphone
1
1
1
7
15
LA-164 Ear Speaker
1
7
15
LA-306 Soft Case
1
LR-400 Portable Digital Display FM Receiver
LR-500 Portable Programmable Digital Display FM Receiver
System Designator
Listen System
LS-05-863
Frequency
30
120
1
2
8
16
31
121
1
LA-311 16-Unit Portable FM Products Charging/Carrying Case
Example:
15
1
LA-313 16-Unit Portable FM Products Carrying Case
LA-362 Rechargable AA NiMH Batteries (2)
1
120
15
LA-322 8-Unit Portable FM Products Carrying Case
LA-361 High Capacity AA Alkaline Batteries (2)
1
30
2
8
16
Each Portable FM System delivers Listen’s commitment to
providing you with a customizable solution that is simple to
specify, install, and use. You will enjoy outstanding performance
with exceptional support from the Listen team.
Don’t miss a single sound. Listen.
6
Listen Technologies GmbH
Jasminstr.16
905022 Oberasbach, Germany
Tel +49 911 955159-0
Fax +49 911 955159-40
www.listentech.de
[email protected]
© 2006 Listen Technologies Corporation® All Rights Reserved 2006 20061026
Don’t miss a single sound.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
