PRODUCT CATALOGUE 2007
Broadband Sound Reversing Alarms
Reversing Alarms
Blind Spot Mirrors
Vehicle CCTV Systems
Satellite Navigation
Digital Recorders and Dome Cameras
Ultrasonic Reversing Sensors
Ultrasonic Side Scanning Sensors
Pulsed Radar Reversing Sensors
Work Lights and Beacons
Warranties
Brigade Electronics – the leader in
2
Introduction
For over 30 years, Brigade Electronics has single-handedly promoted the cause of
‘Reversing Safety’, helping to save thousands of lives and prevent many times more
accidents through its efforts.
Today, the company commands more than 65 per cent of the reversing alarm market
in Europe and exports its range of vehicle safety alarms and CCTV systems to many
countries as far a field as Australia, Africa and the Americas.
Philip and Christopher Hanson-Abbott
(managing director and chairman)
From its global HQ in Kent, the company markets its products via subsidiary
companies in Germany, Italy and the USA, as well as in partnership with over
50 specialist distributors worldwide. Brigade’s R & D team has built up a range of
products that covers the complete spectrum of reversing safety systems and CCTV
solutions for ‘all round visibility’ plus parking sensors, digital video recorders, heavy
duty work lamps, beacons and mirrors.
Safety doesn’t cost – it pays
Accidents are costly and traumatic events that transport and mobile plant fleets can ill afford. The average cost
of a reversing accident, excluding personal injury and other hidden costs, was judged to be £469 in 1999 when
the ‘Accident Analysis and Prevention Journal’ undertook its study into the problem. Today the costs are likely to
be considerably higher. The cost/benefit analysis for a 1,200 truck transport company with a vehicle life of eight
years, revealed that rear end damage costs were £521 per vehicle, per annum – that’s £625,000 per annum
– or nearly £5 million in total over the eight year life of the fleet! So investing in a Brigade safety system can
significantly reduce this cost, with the savings going directly on the operating company’s profits.
Brigade House, South Darenth, Kent
vehicle safety solutions
3
Pioneers in reversing safety
Brigade has worked hard to pioneer ways to reduce the
25 per cent of all work related road deaths that the HSE
estimates are caused by reversing vehicles. We produced
the first ever reversing alarm and rear detection system in
Europe and the first rear view CCTV system in the UK.
All-round visibility, navigation and mobile surveillance
According to Brake, the road safety charity, vehicle ‘blind
spots’ were a contributory factor in over 1,500 crashes in
2005, 21 of which were fatal! To help reduce this figure
Brigade has developed a range of blind-spot cameras
and mirrors, to help give drivers of buses and trucks
a clear view of pedestrians and cyclists on all sides of the
vehicle. In public service and commercial vehicles, CCTV
systems are playing an important role in security, insurance
claim management and navigation as well as safety.
Brigade can offer a range of camera systems, mobile digital
recording units and navigation solutions to meet this
growing need.
Better reversing safety
Brigade has also pioneered the development of an
innovative reversing alarm that provides clearer and more
accurate warning than traditional alarms. Unlike traditional
narrowband alarms it uses broadband sound, which is
instantly and unambiguously locatable. Also, unlike
narrowband alarms, it does not cause a noise nuisance
Award winning products
Over the last three decades, Brigade Electronics
has been presented with numerous awards for its
pioneering technology. More recently the
company has received the following accolades:
2003
The John Connell Award for Innovation
awarded by the Noise Abatement
Society
2004
Supplier of the Year from Hella
2005
Noise Management Innovations
Award from the Society of Automotive
Engineers
2006
Fleet Safety Forum Award for
Vehicle Safety
as the sound is confined to the danger area.
We have not only taken an active role in promoting
awareness of reversing safety but also campaigned for
improvements to relevant legislation.
Contents
4
PRODUCT
PAGES
Broadband Sound Reversing Alarms
5-7
Reversing Alarms
8
Self-Adjusting Smart Reversing Alarms
NIGHTSHIFT Reversing Alarms
Fixed Volume Reversing Alarms
Dual and Constant Tone Alarms
Speaking Alarms
Switches and Timers
9
10
11-12
13
14-15
15
Blind Spot Mirrors
16-17
Vehicle CCTV Systems
18
Monitors
Cameras
Cables
Multi-camera Module and Supplementary Brackets
Monitor/Camera Compatibility Chart
Complete Standard Systems
Articulated Truck/Trailer Connection Options
19-21
22-24
25
26
27
28-37
38
Satellite Navigation
including Low Bridge Warning System
39-41
Digital Recorders and Dome Cameras
42-45
Ultrasonic Reversing Sensors
46
Two Sensor Systems
Four Sensor Systems
Ultrasonic Side Scanning Sensors
Sidescan
47
48-50
51
51
Pulsed Radar Reversing Sensors
52
Work Lights and Beacons
54
HID
HID Xenon and Halogen
Beacons
Warranties
55
56-58
59
60
Broadband Sound Reversing Alarms
5
‘Noiseless’ reversing alarms.
Reversing alarms are vital for vehicle safety yet their very
use can cause noise nuisance and irritation to workers
and local residents, especially when used out of normal
working hours.
The bbs-tek® alarm emits a unique “shh… shh…” sound
which solves the problem. Its broadband sound is
multi-frequency, replacing the narrow frequency band
of conventional alarms. Its sound is instantly locatable
so you immediately know which vehicle is reversing
and where it is coming from. So it is much safer than
conventional narrowband alarms. It is directional,
concentrating the sound in the danger area so reducing
noise nuisance. Broadband sound also dissipates more
quickly beyond the danger zone, so it is much less of a
nuisance to local residents and is less likely to be ignored
by workers due to over exposure to the warning sound.
Many major commercial organisations and government
bodies have already recognized the dual benefits of
fitting bbs-tek® to their public service vehicles, mobile
plant and trucks.
AS SEEN AND APPROVED BY
THE NOISE ABATEMENT SOCIETY
Broadband Sound Reversing Alarms
6
All Broadband Sound Reversing Alarms have a LIFETIME WARRANTY.
Heavy Duty
Ideal for dump trucks, bulldozers, loading shovels and all heavy earthmoving machinery.
BBS-107
BBS-102
• Tough, durable, guaranteed waterproof (IP68)
• Conform to SAE J994 environmental standards
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BBS-107
BBS-102
24
24
107
102
1.0
1.0
Driver
Driver
173x79x95
173x79x95
153
153
Medium Duty
Ideal for trucks, buses and coaches, light mobile plant, forklift trucks and industrial vehicles.
BBS-97
BBS-92
• Tough, durable, guaranteed waterproof (IP68)
• Conform to SAE J994 environmental standards
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BBS-97
BBS-92
BBS-87
BBS-82
NIGHTSHIFT
BBS-90(NSR)
PETROL TANKERS
BBS-92(ADR)
12–24
12–24
12–24
12–24
97
92
87
82
0.5
0.5
0.5
0.5
Speaker
Speaker
Speaker
Speaker
127x65x76
127x65x76
91x55x45
91x55x45
98-108
98-108
76
76
12–24
90-78
0.5
Speaker
127x65x76
98-108
12–24
92
0.5
Speaker
127x65x76
98-108
Electric Forklift Truck
Medium Duty
BBS-87
BBS-82
• Tough, durable, guaranteed waterproof (IP68)
• Conform to SAE J994 environmental standards
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BBS-97HV
BBS-92HV
BBS-87HV
BBS-82HV
36–80
36–80
36–80
36–80
87
82
87
82
0.15
0.15
0.15
0.15
Speaker
Speaker
Speaker
Speaker
127x65x76
127x65x76
127x65x76
127x65x76
98-108
98-108
98-108
98-108
Broadband Sound Reversing Alarms
Medium Duty Broadband Alarms have a LIFETIME WARRANTY, Backchat and Constant Tone Alarms have a
TWO YEAR WARRANTY.
7
Medium Duty – Movement Indicators
• Tough, durable, guaranteed waterproof (IP68)
• Conform to SAE J994 environmental standards
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BBS-77
BBS-72
BBS-67
BBS-62
12–24
12–24
12–24
12–24
77
72
67
62
0.5
0.1
0.1
0.1
Speaker
Speaker
Speaker
Speaker
91x55x45
91x55x45
91x55x45
91x55x45
76
76
76
76
BBS-77
BBS-72
BBS-67
BBS-62
bbs-tek® BACKCHAT ® Speaking Reversing Alarms
The reversing aid that speaks for itself! “Shh! Stand well clear, vehicle reversing...”
Produces real speech with unrivalled quality and clarity. The voice is directional and commands attention,
especially from children.
•
•
•
•
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Dust/waterproof to IP68
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
BBS-BC-01
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BBS-BC-01
12-24
90
0.4
Speaker
122x84x50
102
Constant Tone Alarms – Ideal as Forward Horns,
In-Cab Warnings and other specialist applications
Medium Duty
Ideal for use as forward horn or other warning on a wide variety of specialist vehicles, forklift trucks and electric
vehicles. Safer than a conventional horn, and eliminates noise nuisance and complaints. See page 5 for more
information on the advantages of bbs-tek broadband sound alarms over conventional pure tone alarms.
•
•
•
•
•
Tough, durable, guaranteed waterproof (IP68)
Conform to SAE J994 environmental standards
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
CT-BBS-97
12-24
CT-BBS-92
12-24
HIGH VOLTAGE FORKLIFT TRUCK
CT-BBS-97HV
36-80
CT-BBS-92HV
36-80
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
97
92
0.3
0.3
Speaker
Speaker
127x65x76
127x65x76
98-108
98-108
97
92
0.3
0.3
Speaker
Speaker
127x65x76
127x65x76
98-108
98-108
CT-BBS-97
CT-BBS-92
CT-BBS-97HV
CT-BBS-97HV
Reversing Alarms
8
Brigade Electronics – World leader in
reversing alarms for over 30 years!
Brigade is pushing back the boundaries of reversing safety with
its comprehensive range of reversing, speaking and constant
tone alarms. The company that pioneered reversing safety in
Europe leads the way with innovative technological and design
advances.
The BACKALARM range is packed with product features
that deliver true benefits to the user. These include improved
reliability, increased sound pressure level accuracy, quicker
and more accurate adjustment to ambient noise levels, easier
and neater installation plus longer life.
Not all reversing bleepers are the same!
Of the four types of sounder (Dome Speaker, Driver, Conventional
Cone Speaker and Piezo) our unique and patented Dome
Speaker design is the best option for high sound pressure level
(SPL) models. It offers superb sound quality from a relatively low
current consumption unit. It is tough, durable and guaranteed
waterproof (IP68).
Lifetime Warranty
Most heavy duty and medium duty
Brigade BACKALARMS come with
a “no-quibble, fuss-free” lifetime
warranty that covers the alarm for
the life of the vehicle.
See page 60 for further details
of Brigade Warranties across
our product range.
Next come Driver models. These are also tough, durable and
guaranteed waterproof offering good sound quality for high
SPLs. Conventional Cone Speakers are a good option for
medium and low SPL models, but are unsuitable for high
SPL models over 102dB(A). Most budget and light duty alarms
use Piezo sounders, which are good for light duty applications
but are not so tough or reliable and the SPL may reduce in low
temperatures. Their piercing, high frequency sound may cause
irritation and noise nuisance.
Self-Adjusting Smart Reversing Alarms
9
All Self-Adjusting Backalarms have a LIFETIME WARRANTY.
Self-Adjusting Smart BACKALARM® –
Digital Self-Adjusting Volume
Takes the guesswork out of sound pressure level (SPL) selection. Ideal for vehicles or machines working in
areas with widely differing ambient noise levels, where a fixed-volume reversing alarm will be either too quiet
in loud environments (very hazardous), or too noisy in quiet environments (irritating and a nuisance).
Self-Adjusting Smart BACKALARMS, featuring digital sound sampling and a listening profile matched to
worksite noise, are the world’s most technically advanced self-adjusting reversing alarms. Continuous
self-adjustment of their SPL reduces unnecessary loudness and irritation to operators and local communities.
Self-Adjusting Smart BACKALARMS feature a small hidden and highly robust microphone by which they
measure the ambient SPL. They then self-adjust their own SPL, up or down, to maintain just 5-10 dB louder.
Loud enough to be heard, but not so loud as to cause a nuisance.
Heavy Duty
Ideal for dump trucks, bulldozers, loading shovels and all heavy earthmoving machinery. Features our unique
and patented dome speaker. Double-reflex flared horn design for extra strength, durability, sound quality and
constant sound pressure level (SPL), even under extreme temperatures.
•
•
•
•
•
Tough, durable, guaranteed waterproof (IP68)
Conform to SAE J994 environmental standards
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
SA-800
SA-801
SA-600
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
SA-800
SA-801
SA-600
12-24
12-24
12-24
87-112
87-112
82-107
0.3
0.3
0.3
Dome Speaker
Dome Speaker
Dome Speaker
156x85x108
180x85x108
127x80x80
111-114
78-156
92-112
Medium Duty
For trucks, buses and coaches, light mobile plant and industrial vehicles. Carefully optimised frequency/loudness
characteristics make these units clearly audible under typical working conditions without being a nuisance in
the urban/highway environment.
•
•
•
•
•
Tough, durable, guaranteed waterproof (IP68)
Conform to SAE J994 environmental standards
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
SA-400
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
SA-400
12-24
82-102
0.2
Speaker
100x72x32
76-82
NIGHTSHIFTTM Reversing Alarms
10
All NIGHTSHIFT™ Alarms have a TWO YEAR WARRANTY.
NIGHTSHIFT™ Technology
NIGHTSHIFT technology is our built-in override which enables reversing in built-up areas at night without
disturbing local residents. Simply double-engage reverse gear quickly and the reversing alarm will either
reduce in volume, or cut-out completely – depending upon the model selected. Resets automatically when
reverse gear disengaged.
®
NIGHTSHIFT™ BACKALARM Reversing Bleeper
BA-32(NS)
BA-42(NS)
BA-42(NS)ADR
For trucks, buses and coaches, light mobile plant and industrial vehicles. Carefully optimised frequency/loudness
characteristics make these units clearly audible under typical working conditions without being a nuisance in
the urban/highway environment.
•
•
•
•
•
Tough, durable, guaranteed waterproof (IP68)
Conform to SAE J994 environmental standards
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BA-32(NS)
BA-42(NS)
PETROL TANKERS
12-24
12-24
90/0
90/78
0.2
0.2
Speaker
Speaker
91x49x41
91x49x41
76
76
BA-42(NS)ADR
12-24
90/78
0.2
Speaker
91x49x41
76
®
NIGHTSHIFT™ BACKCHAT Speaking Reversing Alarm
The reversing aid that speaks for itself! “BLEEP! Stand well clear, vehicle reversing...” It reproduces real
speech with unrivalled quality and clarity. The voice is directional and commands attention, especially from
children. Ideal for all road vehicles.
BC-01(NS)
•
•
•
•
Dust/waterproof to IP68
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BC-01(NS)
12-24
90/0
0.4
Speaker
122x84x50
102
NIGHTSHIFT™ BACKALERT™ Combined Bleeper and Light
The BACKALERT combined bleeper and light is as easy to install as changing a light bulb, giving the added
safety of a reversing bleeper without the time, complication and cost of wiring and fitting. It uses a miniature
20 watt long-lasting halogen bulb with a silver-plated reflector and one of the smallest reversing bleepers
available anywhere. Simply replace one of your existing reversing light bulbs with a BACKALERT.
BLT-20(NS)
BLT-20L(NS)
• Ideal for vans, minibuses and motorhomes
MODEL
BLT-20(NS)
BLT-20L(NS)
VOLTS
DC
SOUND
LEVEL dB(A)@1m
12
24
87/0
97/0
LIGHT
20 watt Halogen Bulb
20 watt Halogen Bulb
NIGHTSHIFT™ Override Switches
Can be used with any Brigade reversing alarm that does not already feature NIGHTSHIFT technology.
NS-2
NS-3
MODEL
VOLTS
DC
SIZE (mm)
(WxHxD)
LIGHT
NS-2
NS-3
12-24
12-24
51x29x40
51x29x40
For manual gear boxes
For auto gear boxes
Fixed Volume Tonal Reversing Alarms
Heavy and Medium Duty Fixed Volume Backalarms have a LIFETIME WARRANTY
(except BA-32 which has a TWO YEAR WARRANTY).
11
BACKALARM® – Fixed Volume
Heavy Duty
Ideal for dump trucks, bulldozers, loading shovels and all heavy earthmoving machinery. Features our unique
and patented dome speaker (see page 8 for details). Double-reflex flared horn design for extra strength,
durability, sound quality and constant sound pressure level (SPL), even under extreme temperatures.
BA-890
BA-891
Sound frequency of 1.9kHz is optimised for construction equipment. Lower frequency alarms are more likely
to be masked by construction site noise, which is mainly lower frequencies of around 1.0kHz.
•
•
•
•
•
Conform to SAE J994 environmental standards
Tough, durable, guaranteed waterproof (IP68)
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BA-890
BA-891
BA-680
12-24
12-24
12-24
112
112
107
0.5
0.5
0.3
Dome Speaker
Dome Speaker
Dome Speaker
156x85x108
180x85x108
127x80x80
111-114
78-156
92-112
BA-680
Medium Duty
BA-470
BA-460
For trucks, buses and coaches, light mobile plant and industrial vehicles. Carefully optimised frequency/loudness
characteristics make these units clearly audible under typical working conditions without being a nuisance in
the urban/highway environment.
•
•
•
•
•
•
•
•
Conform to SAE J994 environmental standards
Tough, durable, guaranteed waterproof (IP68)
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
NightSilent model available (BA-165)
Single bolt fitting available (BA-760)
Can be steam-cleaned and pressure-hosed
100 v/m immunity (EMC)
CE and ‘e’ marked (EMC)
BA-170
BA-160
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BA-470
BA-460
BA-170
BA-160
BA-165
BA-130
BA-13
BA-32
12-24
12-24
12-24
12-24
12-24
12-24
12-24
12-24
102
97
102
97
97
87
90
90
0.3
0.2
0.3
0.2
0.2
0.2
0.3
0.2
Speaker
Speaker
Speaker
Speaker
Speaker
Speaker
Speaker
Speaker
100x72x32
100x72x32
105x65x32
105x65x32
105x65x32
105x65x32
66x74x96
91x49x41
76-82
76-82
75-85
75-85
75-85
75-85
Single Bolt
76
97
0.2
Speaker
68x68x63
Single Bolt
BA-165
BA-130
BA-13
SINGLE (REAR) BOLT FITTING
BA-760
12-24
BA-32
BA-760
Fixed Volume Tonal Reversing Alarms
12
BA-13PT has a LIFETIME WARRANTY, other models on this page have a TWO YEAR WARRANTY.
ADR / Petroleum Tanker Specification
BA-13PT
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BA-13PT
BA-13PT
BA-32ADR
12
24
12-24
90
95
90
0.2
0.2
0.2
Speaker
Speaker
Speaker
64x70x101
64x70x101
91x49x41
Single Bolt
Single Bolt
76
Note: BA-13PT AND BA-32ADR models features special cable with braided armoured conduit to meet regulations.
Light Duty
BA-32ADR
Suitable for most light vehicles and small forklift trucks. Includes an optional night-silent feature which
automatically cuts out the bleeper when the vehicle lights are on.
• Electronics potted in epoxy against mud, water and vibration
• Dust proof/water resistant (IP66)
• CE and ‘e’ marked (EMC)
BA-57
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BA-57
12-24
90
0.03
Piezo
48x60x48
Single Bolt
Value Reversing Alarms
VRA-260
• Water resistant (IP67)
• ‘e’ marked (EMC)
• Mylar plastic speaker
VRA-260(S), VRA-230(S)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
VRA-260
VRA-260(S)
VRA-230(S)
12-80
12-80
12-80
97
97
87
0.08
0.08
0.08
Speaker
Speaker
Speaker
102x71x40
102x71x40
102x71x40
76-82
76-82
76-82
Budget Reversing Alarms
VRA-390, VRA-390HV
VRA320NSR
• Water resistant (IP66)
• ‘e’ marked (EMC)
• Piezo ceramic sounder
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
VRA-390
12-24
90
0.05
Piezo
48x48x37
Single Bolt
36-80
90
0.5
Piezo
48x48x37
Single Bolt
90-78
90
90-78
0.2
0.03
0.03
Piezo
Piezo
Piezo
42x42x32
40x40x31
40x40x31
Single Hole
Single Hole
44
FORKLIFT TRUCKS
VRA-390HV
LIGHT CLUSTER FITTING
VRA-320NSR
VRA-320
VRA-320NS/NR
VRA-320
VRA-320NS/NR MODULE
24
12-24
24
Note: VRA-320NSR has an inbuilt NIGHTSHIFT sound reduction feature. VRA-320NS/NR module
can be coupled with VRA-320 to provide NIGHTSHIFT sound reduction feature.
Dual and Constant Tone Alarms
13
All Dual and Constant Tone Alarms have a TWO YEAR WARRANTY.
Dual Function and Dual Tone Warning Alarms – Ideal
for manlifts and specialist vehicles / machines
Dual tone alarms provide audible warning in hazardous areas associated with vehicles and mobile equipment. Dual
tone sound warns of dangers specific to certain machines or equipment (lowering scissor lifts, rotating drive shafts,
extending outriggers, etc.). Dual function alarms have two trigger wires and give both a conventional ‘bleep’ tone for
reversing and either a dual tone or constant tone (depending on the model) warning for other dangers.
DT-32
Medium Duty
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
• Conform to SAE J994 environmental standards
• Tough, durable, guaranteed waterproof (IP68)
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
DT-160
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
DT-32
DT-160
DT-460
DF-116
DF-470
12-24
12-24
12-24
24
12-24
90
97
97
90
102
0.2
0.2
0.2
0.3
0.3
Speaker
Speaker
Speaker
Speaker
Speaker
91x49x41
105x65x32
100x72x32
105x65x32
100x72x32
76
75-85
76-82
75-85
82
DT-460, DF-470
Constant Tone Alarms – Ideal as Forward Horns,
In-Cab Warnings and other specialist applications
DF-116
Medium Duty
• Can be steam-cleaned and pressure-hosed
• CE and ‘e’ marked (EMC)
• Conform to SAE J994 environmental standards
• Tough, durable, guaranteed waterproof (IP68)
• Solid-state, spark-free electronics, epoxy-sealed
against mud, water and vibration
CT-470
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
CT-470
12-24
102
0.3
Speaker
100x72x32
76-82
Light Duty
CT-57TCA-2
•
•
•
•
PCB fully potted in epoxy against mud, water and vibration
Water resistant (IP66)
CE and ‘e’ marked (EMC)
Two metre twin core cable
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
CT-57TCA-2
12-24
90
0.02
Piezo
48x60x47
Single Bolt
VCT-320
Value Constant Tone Alarms and Forward Horns
VCT-02
• Water resistant (IP66)
• CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
VCT-320
VCT-02
VCT-012
VCT-024
12-24
24
12
24
90
90
85
85
0.05
0.05
0.05
0.05
Piezo
Piezo
Piezo
Piezo
40x40x31
60x60x80
50x50x35
50x50x35
Single Bolt
Single Bolt
Single Bolt
Single Bolt
VCT-012/VCT-024
Speaking Alarms
14
All BACKCHAT and BACKALERT Alarms have a TWO YEAR WARRANTY.
®
BACKCHAT Speaking Reversing Alarms
The reversing aid that speaks for itself! “BLEEP! Stand well clear, vehicle reversing...” It reproduces real
speech with unrivalled quality and clarity. The voice is directional and commands attention, especially from
children. Ideal for all road vehicles.
BC-01(NS) – Nightshift
BC-01 – single message
BC-01HP – single message
BC-02HP – twin message
•
•
•
•
Dust/waterproof to IP68
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SOUNDER
UNIT
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BC-01(NS)
BC-01
BBS-BC-01
BC-01HP
BC-02HP
12-24
12-24
12-24
12-24
12-24
90
90
90
110
110
0.4
0.4
0.4
0.4
0.4
Speaker
Speaker
Speaker
Speaker
Speaker
122x84x50
122x84x50
122x84x50
122x84x50
122x84x50
102
102
102
102
102
Single message = Reversing
Twin message = Reversing and tail-lift lowering
®
BACKCHAT Speaking Attack Alarms
In moments of danger, the ATTACK ALARM is activated by a panic button. Its high sound level siren is
followed by an urgent spoken message requesting assistance. The message is repeated continuously until
deactivated by pressing the hidden ‘off’ switch.
BC-AA
BC-AA(BUS)
•
•
•
•
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
Dust/waterproof to IP67
CE and ‘e’ marked (EMC)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BC-AA
BC-AA(BUS)
12-24
12-24
110
110
0.4
0.4
115x115x120
115x115x120
48
48
Bespoke Messages
Your own message eg: “Stand well clear Brigade vehicle
reversing...” can be inexpensively incorporated into BACKCHAT
Reversing Alarms and Attack Alarms.
Bespoke messages can be up to eight seconds long.
Maximum speech quality is achieved with four
seconds maximum messages.
MODEL
DESCRIPTION
BC-01(NS-B)
BC-01(B)
BC-02(B)
BC-01HP(B)
BC-02HP(B)
BBS-BC-01(B)
BC-AA(B)
NIGHTSHIFT double-engage reverse gear single message (90dB)
Single bespoke message (90dB)
Two bespoke messages (90dB)
Single bespoke message (110dB)
Two bespoke messages (110dB)
bbs-tek Broadband Sound single bespoke message (90dB)
Single bespoke attack alarm message (110dB)
®
BACKCHAT Handbrake Warning Alarms
BC-01(H/Brake)
BC-01(4W)(H/Brake)
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
BC-01(H/Brake)
BC-01(4W)(H/Brake)
12-24
12-24
90
90
0.4
0.4
122x84x50
122x84x50
102
102
Message – “BLEEP, HANDBRAKE NOT APPLIED.”
Speaking Alarms
15
All BACKCHAT and BACKALERT Alarms have a TWO YEAR WARRANTY.
®
BACKCHAT Vehicle Intercom
A two-way communication system, operating in either simplex (one way at a time) or duplex (two way) form.
Master unit includes volume control. Provides clear, reliable communication and can be mounted internally or
externally. Ideal for any vehicle where the driver needs to communicate with others not in the cab; eg, refuse
collection vehicle, horsebox, security vehicle, custodial transport, etc.
•
•
•
•
•
Special circuitry to minimise background noise
Solid-state, spark-free electronics, epoxy-sealed against mud, water and vibration
Can be steam-cleaned and pressure-hosed
Dust/waterproof to IP67
CE and ‘e’ marked (EMC)
BC-VI
BC-VI-2
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
CURRENT
AMPS
SIZE (mm)
(WxHxD)
HOLE
CENTRE (mm)
OPERATING
SYSTEM
BC-VI
BC-VI-2
12-24
12-24
80-95
80-95
0.4
0.4
122x84x50
122x84x50
102
102
Simplex
Duplex
Vehicle Intercom – Separate components
MODEL
DESCRIPTION
BC-VI MASTER
BC-VI SLAVE
BC-V2 MASTER
BC-VI-2 SLAVE
12-24 Master unit
Slave unit + 25 metres cable
12-24 Master unit
Slave unit + 25 metres cable
®
BACKALERT Combined Bleeper and Light
The BACKALERT combined bleeper and light is as easy to install as changing a light bulb, giving the added
security of a reversing bleeper without the time, complication and cost of wiring and fitting. It uses a miniature
20 watt long-lasting halogen bulb with a silver-plated reflector and one of the smallest reversing bleepers
available anywhere. Simply replace one of your existing reversing light bulbs with a BACKALERT.
• Ideal for vans, minibuses, motorhomes, MPVs and cars
MODEL
VOLTS
DC
SOUND
LEVEL dB(A)@1m
BLT-20
BLT-20L
12
24
87
97
LIGHT
BLT-20
BLT-20L
20 watt Halogen Bulb
20 watt Halogen Bulb
1
Also see NIGHTSHIFT models on page 10
Switches and Timers
MODEL
VOLTS
DC
DESCRIPTION
TCO-47
SW-16
PS/003
SS/11/M
EC-009
NS-2
NS-3
VRA-320NS/NR
12-24
–
–
–
12-24
12-24
12-24
12-24
Auto-reset cut-out
Pigtail microswitch - electro-mechanical
Magnetic proximity switch
Mechanical 'swinging arm' switch
In-Line timer, 4 or 8 seconds to cut-out
Cut-out switch
Cut-out switch for auto gear box
Sound reduction module for BA-320
2
3
1 TC0-47 Auto-reset Backalarm cut-out. Dash-mounted single-touch timed relay. Allows driver to cut-out
Backalarm if reversing on highway between 11.30pm-7.00am. Auto-resets after 3-4 mins. time delay.
2 SW-16 ‘Pigtail’ microswitch. Easy installation adjacent to gearshift lever/linkage so that ‘pigtail’ tip is
moved 1 inch.
3 PS/003 Magnetic Proximity Switch. Operates when magnet (fixed to gear linkage) is moved to within
0.5 inches or less of switch. 3 amps max rating.
4 EC-009 In-line timer. Allows Backalarm to sound for first few seconds only of reversing manoeuvre.
(Choice of four or eight seconds.) Epoxy-sealed against mud, water and vibration.
5 NS-2/NS-3 NIGHTSHIFT Backalarm cut-out switch. Simply double-engage reverse gear quickly to
deactivate the Backalarm. Re-sets when reverse gear disengaged. NS-3 has longer time delay for
auto gear boxes. Epoxy-sealed against mud, water and vibration. Can be fitted in minutes alongside
Backalarm at back of vehicle. NO WIRING NECESSARY TO CAB.
4
5
Blind Spot Mirrors
16
Blind Spot Mirrors
Dobli wide view blind spot mirrors are specifically designed to
provide truck drivers with clear visibility of the area on the
nearside of the vehicle. Fitted to the front of the truck they are
viewed through the windscreen. They meet the requirements of
the latest EU legislation for blind spots in trucks (2003/97/EC)
and a single Dobli mirror will cover not only the expanded Class
IV and Class V mirror areas, but also a large area to the
nearside of the cab that otherwise remains ‘blind’ to the driver –
even after meeting the requirements of 2003/97/EC. Dobli
mirror kits are designed to fit all leading truck brands.
Brigade also offers a range of half-moon and full-moon bubble
mirrors for maximum visibility on forklift trucks and mobile
machinery.
Blind Spot Mirrors
17
All Blind Spot Mirrors have a ONE YEAR WARRANTY.
Dobli wide view, near side front, blind spot mirrors
Complete right hand drive kits (mirror head, mounting bracket, fixings).
Size (mm) 168 x 250 x 50.
UNHEATED MIRROR KITS
HEATED MIRROR KITS
MODEL
TRUCK MODEL
MODEL
TRUCK MODEL
DMK-017
DMK-001
DMK-016
DMK-009
DMK-010
DMK-002
DMK-018
DMK-006
DMK-019
DMK-007
DMK-003
DMK-011
DMK-013
DMK-012
DMK-021
DMK-022
DMK-023
DMK-020
DMK-014
DMK-015
DMK-004
DMK-005
DMK-008
DAF 1100-3600
DAF CF, XF, 65, 75, 85, 95
DAF LDV/400
DAF LF
Iveco Eurocargo
Iveco Stralis
MAN F
MAN L/M Series
MAN TGA
Mercedes Actros
Mercedes Atego, Axor
Mercedes SK/Ecoliner
Mercedes Sprinter <2006
Mercedes Vario
Renault Magnum
Renault Mascot
Renault Master
Renault Premium/Midlum
Scania 3-Series
Scania 4-Series
Scania R
Volvo FM/FH <2002
Volvo FM/FH >2002
DMK-517
DMK-501
DMK-516
DMK-509
DMK-510
DMK-502
DMK-518
DMK-506
DMK-519
DMK-507
DMK-503
DMK-511
DMK-513
DMK-512
DMK-521
DMK-522
DMK-523
DMK-520
DMK-514
DMK-515
DMK-504
DMK-505
DMK-508
DAF 1100-3600
DAF CF, XF, 65, 75, 85, 95
DAF LDV/400
DAF LF
Iveco Eurocargo
Iveco Stralis
MAN F
MAN L/M Series
MAN TGA
Mercedes Actros
Mercedes Atego, Axor
Mercedes SK/Ecoliner
Mercedes Sprinter <2006
Mercedes Vario
Renault Magnum
Renault Mascot
Renault Master
Renault Premium/Midlum
Scania 3-Series
Scania 4-Series
Scania R
Volvo FM/FH <2002
Volvo FM/FH >2002
Dobli mirror
Half moon bubble mirror
Separate mounting brackets and mirror heads are available,
please consult the Brigade price list for details.
Full moon bubble mirror
EYEBALL wide view bubble mirrors
Ideal for forklift trucks and mobile machinery.
MODEL
FULL OR HALF MOON
VBM-053
EB06S-B
EB45S-B
EB10S-B
Half
Full
Full
Full
SIZE
300mm (12")
150mm (6")
200mm (8")
250mm (10")
Universal clamp bracket
EYEBALL Brackets
MODEL
DESCRIPTION
BKT-010
BKT-011
BKT-012
BKT-013
BKT-014
Universal clamp bracket, for 15-25mm tube
Universal clamp bracket, for 25-32mm tube
Universal clamp bracket, for 38-40mm tube
210mm extension for BKT-010 + BKT-011
Forklift truck bracket and overhead cage clamp
Extension
Forklift truck bracket and
overhead cage clamp
Vehicle CCTV Systems
18
Vehicle CCTV solutions for
safety and security.
We have over 30 years experience of providing reversing safety
systems for all kind of commercial vehicles and mobile plant
machinery – from trucks and buses up to loading shovels and
dump trucks. So we know what it takes to build robust CCTV
systems that really deliver the performance and reliability that
you expect. That goes for both our renowned Professional 800
Series models with extensive features and long-life warranties,
and our ‘Value’ models that offer outstanding quality and
performance at really affordable prices.
Traditionally known as BACKEYE ‘reversing camera’ systems, our
range now affords greater visibility in any direction (rear, side and
front, both high and low views) which results in comprehensive
coverage of the vehicle to enhance vehicle, passenger and
pedestrian safety as well as enhanced vehicle security.
As well as separate cameras, monitors, cables and
accessories, Brigade offers a range of inclusive kits that meet
the needs of most standard applications – whether it be rigid
vehicle, articulated truck or truck and trailer. A selection of
these kits is featured here. Please consult the price list for
all standard kits or talk to our Sales Advisors about the
availability of bespoke kits to suit all needs.
Monitors – Professional Range
19
All Professional Range Monitors and Systems have a THREE YEAR WARRANTY.
BE-870FM TFT LCD flat screen monitor
Top of the range widescreen monitor that is ideal for trucks, buses and coaches, especially if needing
multi-camera systems for all-round safety and security. Compatible with satellite navigation, DVD, digital
recorders and other multi-media systems. New LED backlighting gives a much brighter picture, improved
colour definition and double the life.
•
•
•
•
•
•
•
•
•
Split, triple, quad screen functionality built-in
7" wide screen – ideal for split image use
On-screen display
Mirror/normal switching from menu
100G mechanical shock
Built-in speaker
12-24Vdc
Auto dimmer function
5 auto-trigger signals
MODEL
BE-870FM
•
•
•
•
•
•
•
•
4 camera inputs + 1 AV input
PAL and NTSC compatible
15 watt power consumption
Electronic distance markers
Low reflector coating on screen
-20°C to +65°C operating temperature
Backlit control buttons
Auto on when reverse gear engaged
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
7" (178mm)
15G
1.25
Yes
Yes
197x138x32
WIDESCREEN
IN-BUILT IMAGE OPTIONS
BE-870EM TFT LCD flat screen monitor
Ideal for commercial vehicles and mobile plant wanting all-round safety and security. Compatible with satellite
navigation, DVD and TV. New LED backlighting gives a much brighter picture, improved colour definition and
double the life.
•
•
•
•
•
•
•
•
•
7" wide screen format
On screen display
Mirror/normal switching from the menu
100G mechanical shock
Built-in speaker
Sun shield
12-24Vdc
Auto dimmer function
2 auto trigger signals
MODEL
BE-870EM
•
•
•
•
•
•
•
•
2 camera inputs
PAL and NTSC compatible
15 watt power consumption
Electronic distance markers
Low reflector coating on screen
-20°C to +65°C operating temperature
Backlit control buttons
Auto on when reverse gear engaged
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
7" (178mm)
15G
1.25
Yes
Yes
197x138x32
All Brigade 800 and 300 series CCTV systems are HALT tested and RoHS compliant.
WIDESCREEN
Monitors – Professional Range
20
All Professional Range Monitors and Systems have a THREE YEAR WARRANTY.
BE-856EM TFT LCD flat screen monitor (no control box)
Ideal for commercial vehicles and mobile plant wanting all-round safety and security. Compatible with satellite
navigation, DVD and TV. New LED backlighting gives a much brighter picture, improved colour definition and
double the life.
•
•
•
•
•
•
•
On screen display
2 camera inputs
Built-in speaker
Auto dimmer function
Low reflector coating on screen
Sun shield
100G mechanical shock
•
•
•
•
•
•
•
-10°C to +50°C operating temperature
12-24Vdc
Backlit control buttons
Universal mounting bracket
12 watt power consumption
Electronic distance markers
Auto on when reverse gear engaged
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
BE-856EM
5.6" (142mm)
4G
1
Yes
Yes
172 x115 x28
BE-856DM TFT LCD flat screen monitor (with control box)
Ideal for commercial vehicles and mobile plant wanting all-round safety and security. Compatible with satellite
navigation, DVD and TV. New LED backlighting gives a much brighter picture, improved colour definition and
double the life.
•
•
•
•
•
•
•
On screen display
3 camera inputs + AV
Built-in speaker
Auto dimmer function
Low reflector coating on screen
Sun shield
100G mechanical shock
•
•
•
•
•
•
•
-10°C to +50°C operating temperature
12-24Vdc
Backlit control buttons
Universal mounting bracket
12 watt power consumption
Electronic distance markers
Auto on when reverse gear engaged
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
BE-856DM
5.6" (142mm)
4G
1
Yes
Yes
172 x115 x28
BE-850M TFT LCD colour monitor
A colour TFT LCD monitor that is ideal for commercial vehicles. Compatible with satellite navigation and other
systems.
• On-screen display (menu & functions)
• 100G mechanical shock
• Integral speaker
• Two camera inputs
• NTSC & PAL compatible
• 10 watts (max) power consumption
• -10°C to +50°C operating temperature
• Auto-on when reverse gear engaged
• Takes inputs from Sat Nav, DVD and other inputs
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
BE-850M
5.0" (127mm)
4G
1
Yes
Yes
170x115x30
BE-835M TFT LCD colour monitor
An attractive high resolution monitor that fits into even the tightest of spaces. Compatible with satellite
navigation systems.
• Low reflection coating on screen
• One camera input
• Built-in speaker
• Automatic picture display whenever trigger is engaged
• On screen display
• AV input for Sat Nav, DVD and other inputs
• Auto dimmer function
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
BE-835M
3.5" (89mm)
5.5G
1
Yes
Yes
130x82x50
Monitors – Value and Budget Range
21
All Value Range Monitors and Systems have a TWO YEAR WARRANTY.
VBV-750BM TFT LCD flat screen monitor
Neat and attractive colour monitor with three camera inputs that is ideal for all types of vehicle applications
even when space is limited. Comes with a universal mounting bracket for quick and easy installation.
Compatible with satellite navigation systems.
•
•
•
•
•
•
•
Up to 3 camera inputs
Auto dimmer function
Mirror/normal image switching
Anti-glare screen
Sun shield
100G mechanical shock
-10°C to +60°C operating temperature
•
•
•
•
•
12-24Vdc
Backlit control buttons
Colour and tint controls
Brightness and contrast control
Plug and Play ready to accept DVD, satellite
navigation or other add-ons
• Screen menu available in 11 languages
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
VBV-750BM
5.0" ( 127mm)
5G
0.65
No
Yes
147x109x26
All Budget Range Monitors and Systems have a ONE YEAR WARRANTY.
VBV-155M monochrome monitor
A conventional black and white CRT monitor that includes the functionality that you would expect from more
expensive models. Two camera inputs as standard, a day/night dim switch and manual/auto switch,
brightness and contrast control are all included.
• Night time dim switch
• 12-24Vdc universal voltage
• Sun shield
• 100G mechanical shock
• Contrast and brightness control
• Two camera inputs
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
VBV-155M
5.5" (138mm)
5G
1
No
Yes x 2
154x143x190
VBV-545M monochrome monitor
Without doubt the most stylish, and compact monochrome monitor available. Neat, attractive and easy-to-fit the
monitor can either take one or two camera inputs as standard. Backlit control buttons for ease of use at night.
•
•
•
•
4.5" monochrome screen
Night time dim switch
12-24Vdc universal voltage
Sun shield
• 100G mechanical shock
• Contrast and brightness controls
• Two camera inputs
MODEL
SCREEN SIZE
MECHANICAL
VIBRATION
CURRENT
AMPS
AUDIO
MIRROR/NORMAL
IMAGE SWITCHES
SIZE (mm)
(WxHxD)
VBV-545M
4.5" (115mm)
5G
1.2
No
Yes x 2
128x118x158
Cameras – Professional Range
22
All Professional Range Cameras and Systems have a THREE YEAR WARRANTY.
BE-800C
Top-of-the-range colour camera with six infrared LEDs for ultra-low light performance.
Delivers fantastic picture quality.
• Ultra-low light performance
• Solid aluminium case
• 320,000 pixels
• Integral sunshield
• Integral microphone
• -20ºC to +70ºC operating temperature
• Automatic electronic iris
• 100G mechanical shock
• NTSC and PAL options available
• Also available narrow-view (78 degrees and
• 12Vdc (from monitor)
40 degrees) models
MODEL
BE-800C
BE-800C (78)
BE-800C (40)
MECHANICAL
VIBRATION
AUDIO
10G
10G
10G
Yes
Yes
Yes
H
VIEWING ANGLE
V
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
105
65
32
80
50
25
130
78
40
1/3" CCD
1/3" CCD
1/3" CCD
75x52x75
75x52x75
75x52x75
BE-810C – Shutter camera
Top-of-the-range shutter camera with six infrared LEDs for ultra-low light performance.
Delivers fantastic picture quality.
•
•
•
•
•
•
Motorised shutter
Ultra-low light performance
320,000 pixels
Integral microphone
12Vdc (from monitor)
Automatic electronic iris
MODEL
BE-810C
•
•
•
•
•
MECHANICAL
VIBRATION
AUDIO
5G
Yes
H
NTSC and PAL options available
Solid aluminium case
Integral sunshield
-20ºC to +70ºC operating temperature
100G mechanical shock
VIEWING ANGLE
V
92.5
68.8
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
115
1/3" CCD
94x44x64
BE-820C
A top quality ultra compact colour camera with extra wide field of view.
• Automatic electronic iris
• -30ºC to +50ºC operating temperature
• Vandal resistant waterproof housing
• 100G mechanical shock
• 12Vdc (from monitor)
• BE-822C is forward image version
MODEL
BE-820C
BE-822C
MECHANICAL
VIBRATION
AUDIO
10G
10G
Yes
Yes
H
VIEWING ANGLE
V
150
150
120
120
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
90
90
1/3" CCD
1/3" CCD
33x25x36
33x25x36
BE-840C – Tilting camera
Motorised tilt lens camera gives a panoramic rear view when driving forwards and close-up rear view when
reversing. With ultra low-light performance from four built-in infrared LEDs.
• Adjustable vertical angle by manual or auto
tilt control
• Angle of view set at 92º standard
• Can be set to 40º when reverse gear engaged
• Ultra-low light performance
• 320,000 pixels
• Integral microphone
MODEL
BE-840C
MECHANICAL
VIBRATION
AUDIO
10G
Yes
•
•
•
•
•
•
•
12Vdc (from monitor)
Automatic electronic iris
Vandal resistant and waterproof housing
Extra-wide field of view
-30ºC to +50ºC operating temperature
100G mechanical shock
Compatible with BE-856DM and BE-870FM monitors
H
VIEWING ANGLE
V
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
53
71
92
1/3" CCD
91x53x78
All Brigade 800 and 300 series CCTV systems are HALT tested and RoHS compliant.
Cameras – Professional Range
All Professional Range Cameras and Systems have a THREE YEAR WARRANTY.
BE-300 Series – Compact, flush mount cameras –
front view, side view, rear view, internal view
Compact cameras for all-round visibility and safety. Flush mounted to the vehicle the cameras streamlined
compact design means they can be easily placed anywhere on the vehicle. 300 series cameras can be used
with any BE-800 and VBV series monitors.
Meets the requirements of the European Mirrors Directive (EC2003/97).
The 300 Series easily tackles the problem of blind spots and offers a comprehensive solution to all-round visibility.
• Wide field of vision
• Can be linked to the MDR-200 digital video
recorder systems for added vehicle security
• Stay clean lens coating
• Sony CCD for improved picture quality
MODEL
BE-300C
BE-301C
BE-302C
BE-303C
BE-304C
MECHANICAL
VIBRATION
AUDIO
10G
10G
10G
10G
10G
No
No
No
No
No
• Flush mount for improved aesthetics
• 290,000 pixels
• Robust casing for outstanding protection from
dust and water
• 100G mechanical shock
H
VIEWING ANGLE
V
125
125
125
125
125
97
97
97
97
97
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
73
73
73
73
73
1/3" CCD
1/3" CCD
1/3" CCD
1/3" CCD
1/3" CCD
62x42x45
62x42x45
62x42x45
62x42x45
62x42x45
BE-200C
An ultra-low light monochrome camera with six infrared LEDs.
•
•
•
•
•
Ultra-low light performance
100G mechanical shock
290,000 pixels
Integral microphone
Sun shield
MODEL
BE-200C
•
•
•
•
MECHANICAL
VIBRATION
AUDIO
10G
Yes
H
0.05 lux minimum illumination
Extra-wide field of view
Automatic electronic iris
-30ºC to +50ºC operating temperature
VIEWING ANGLE
V
120
90
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
150
1/3" CCD
94x48x38.4
BE-210C – Shutter camera
An ultra-low light monochrome camera with six infrared LEDs.
•
•
•
•
•
Ultra-low light performance
100G mechanical shock
290,000 pixels
Integral microphone
Sun shield
MODEL
BE-210C
•
•
•
•
MECHANICAL
VIBRATION
AUDIO
5G
Yes
H
0.05 lux minimum illumination
Extra-wide field of view
Automatic electronic iris
-30ºC to +50ºC operating temperature
VIEWING ANGLE
V
120
90
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
150
1/3" CCD
94x48x38.4
23
Cameras – Value Range
24
All Value Range Cameras have a TWO YEAR WARRANTY.
VBV-700C
Ultra-low light colour camera fitted with no less than 18 infrared LEDs for a clear picture even in the darkest
of surroundings.
• 100G mechanical shock
• Ultra-low light performance
• Sun shield
• Automatic electronic iris
• -20ºC to +70ºC operating temperature
• 270,000 pixels
MODEL
MECHANICAL
VIBRATION
AUDIO
10G
No
BE-700C
H
VIEWING ANGLE
V
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
88
66
110
1/3" CCD
70x44x54
VBV- 485C
A high quality bumper fit camera with 12 infrared LEDs for ultra-low light performance. Suitable for flush
mount installation and supplied with fixation nuts and ‘angle spacers’ for mounting on sloping surfaces.
• Waterproof (IP67)
• 298,000 pixels
• Operating temperature -20°C to +70°C
• Wide field of view
• 100G mechanical shock
• Automatic electronic iris
• 1.0 lux minimum illumination
MODEL
MECHANICAL
VIBRATION
AUDIO
10G
No
VBV-485C
H
VIEWING ANGLE
V
110
82.5
D
PICK-UP
ELEMENT
SIZE (mm)
(Diam x D)
130
1/3" CCD
35x50
VBV- 475C
A neat, compact bumper fit camera with aluminium housing. Suitable for flush mount installation and supplied
with fixation nuts and ‘angle spacers’ for mounting on sloping surfaces.
• Waterproof (IP67)
• 298,000 pixels
• Operating temperature -20°C to +70°C
• Wide field of view
• 100G mechanical shock
• Automatic electronic iris
• 0.9 lux minimum illumination
MODEL
VBV-475C
MECHANICAL
VIBRATION
AUDIO
10G
No
H
VIEWING ANGLE
V
110
82.5
D
PICK-UP
ELEMENT
SIZE (mm)
(Diam x D)
130
1/3" CCD
30x62
VBV-110C – Compatible with VBV-750BM
Great ultra-low light performance delivered from 6 built-in infrared LEDs. Compact monochrome
camera with sun shield.
• Waterproof (IP67)
• 290,000 pixels
• Operating temperature -30°C to +50°C
• Extra wide field of view
• 100G mechanical shock
• Automatic electronic iris
• 0.1 lux minimum illumination
MODEL
VBV-110C
MECHANICAL
VIBRATION
AUDIO
10G
No
H
VIEWING ANGLE
V
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
88
66
110
1/3" CCD
70x44x54
VBV-100C – Compatible with VBV-155M and VBV-545M
Great ultra-low light performance delivered from 6 built-in infrared LEDs. Compact monochrome
camera with sun shield.
• Waterproof (IP67)
• 290,000 pixels
• Operating temperature -30°C to +50°C
• Extra wide field of view
• Mirror/normal switching
• Automatic electronic iris
• 100G mechanical shock
• 0.1 lux minimum illumination
MODEL
VBV-100C
MECHANICAL
VIBRATION
AUDIO
10G
No
H
VIEWING ANGLE
V
D
PICK-UP
ELEMENT
SIZE (mm)
(WxHxD)
88
66
110
1/3" CCD
70x44x54
Cables
25
For full details of warranties see page 60.
CAMERA CABLES FOR PROFESSIONAL 800 SERIES AND 300 SERIES
MODEL
DESCRIPTION
BE-L130
BE-L120
BE-L115
BE-L110
BE-L105
BE-X003
BE-X005
BE-X010
BE-X015
BE-X020
BE-X025
BE-XM005
30m camera cable
20m camera cable
15m camera cable
10m camera cable
5m camera cable
3m extension cable
5m extension cable
10m extension cable
15m extension cable
20m extension cable
25m extension cable
5m monitor extension cable (All BE-800 series models, except BE-835)
Camera cable
3m extension cable
CAMERA CABLES FOR VALUE SERIES
MODEL
DESCRIPTION
VBV-L430
VBV-L420
VBV-L410
VBV-L405
VBV-L4025
VBV-L402PC
VBV-L403PC
30m camera or extension cable
20m camera or extension cable
10m camera or extension cable
5m camera or extension cable
2.5m camera or extension cable
2m Y-Piece cable for 12Vdc power and camera cable connection to monitor
3m Y-Piece cable for 12Vdc power and camera cable connection to monitor
20m extension cable
Camera or extension cable
BACKEYE VEHICLE CCTV ADAPTOR CABLES
MODEL
DESCRIPTION
AC-001
AC-002
AC-003
AC-004
AC-005
AC-006
AC-007
AC-008
AC-009
AC-010
AC-011
AC-012
AC-013
A2094
AC-015
AC-016
Replace BE-700C/600C camera with VBV-700C/110C camera
Replace 12Vdc System BE-740M/756M monitor With VBV-750M monitor
Connects BE-200/800 series camera to BE-455/650 cable
Connect BE-200/800 series monitor to BE-455 cable
Connect VBV-750M/545AM/155M monitor to BE-756/740 cable
Connect VBV-700C/110C camera to BE-800 series cable
Connect VBV-750M/545AM/155M monitor to BE-800 series cable
Replace VBV-500C (5-Pin) camera with VBV-110C (4-Pin) camera
Replace VBV-545M monitor with VBV-545AM/155M/750M monitor
VBV-545M to VBV-545AM Power cable adaptor
Upgrade from BE-856A monitor to BE-856D monitor
Connect 2 BE-800 series monitors to BE-800 series camera
Replace Clarion monitor with BE-800 series monitor
Value series camera for BE-800 or BE-300 series camera
Connect VBV-750AM to VBV-700CM
Male 4-Pin DIN to AV Phono Plugs (Yellow and White). To plug AV
equipment (eg DVD, Satellite Navigation) into BE-856EM or BE-850M
Y-piece cable
Adaptor cable
Multi-camera Module and Supplementary Brackets
26
EDM-50 has a THREE YEAR WARRANTY.
EDM-50 multi-camera module and screen splitter
A highly flexible, heavy duty multi-control box that takes up to 4 camera inputs plus AV input and output.
Camera selection can be either manual or automatic (5 triggering functions). It provides multiple picture
display – single, split, triple and quad and can be used to enhance the capability of the BE-800 series of
vehicle CCTV systems.
EDM-50
•
•
•
•
•
•
•
•
•
•
10-32Vdc
Four camera inputs plus AV input
Adjustable dwell time for each camera
Individual auto triggering for each camera
Individual audio volume controls
Manual triggering for each camera
Mirror/Normal image switch for each camera
NTSC or PAL compatible
-10ºC to +50ºC operating temperature
Auto scanning function
MODEL
VOLTS
DC
CURRENT
AMPS
SIZE (mm)
(WxHxD)
EDM-50
10-32
Max 24 Watt
154x28x105
Low speed trigger module
STOCK
CODE
MODEL
A1543
LS-20
DESCRIPTION
24Vdc, Low speed trigger module, 0-20 mph (0-32 kph) adjustable
Supplementary brackets
A variety of special brackets is available to meet specific requirements.
BE-800 Series LCD monitor heavy duty bracket
MODEL
DESCRIPTION
BMM-011
Heavy duty LCD monitor mount – for BE-800 series monitors (except BE-835)
BMM-011
CRT monitor supplementary brackets
MODEL
DESCRIPTION
BSB-003
BSB-004
BSB-005
ROPS bracket, 54mm jaw
ROPS bracket, 82mm jaw
ROPS bracket, 108mm jaw
Note: A variety of special brackets is available to suit specific makes/models of vehicle/machine.
BSB-003
BSB-004
BSB-005
Camera security box
BSM-006
MODEL
DESCRIPTION
BSM-006
BSM-003
Heavy duty universal camera security box + 4 security bolts and wrench
Spare set of security box bolts + socket key wrench
Vehicle CCTV Kit Examples
27
For full details of warranties see page 60.
Monitor/Camera Compatibility Chart
MONITOR
MODEL
CAMERA MODEL
BE-300 SERIES,
COLOUR, LOW
LIGHT, MINI
BE-800C,
COLOUR,
ULTRA-LOW
LIGHT, AUDIO
BE-810C,
COLOUR,
ULTRA-LOW
LIGHT, SHUTTER
+ AUDIO
BE-840C,
COLOUR,
MOTORISED
TILT + AUDIO
BE-820C,
COLOUR
MINI
BE-200C,
MONO, ULTRA
LOW LIGHT,
AUDIO
BE-210C,
MONO, ULTRA
LOW LIGHT
SHUTTER
VBV-700C,
COLOUR,
ULTRA-LOW
LIGHT
VBV-485C,
COLOUR,
ULTRA-LOW
LIGHT
VBV-475C,
COLOUR,
ULTRA-LOW
LIGHT
VBV-110C,
MONO,
ULTRA-LOW
LIGHT
VBV-100C,
MONO,
ULTRA-LOW
LIGHT
(1): Only on CA1
BE-835EM VBV-750BM VBV-155M VBV-545M
BE-870EM BE-870FM BE-856DM BE-856EM BE-850M
7" COL
5.6" COL
5.6" COL
5.0" COL
3.5" COL
5.0" COL
5.5" MONO 4.5" MONO
7" COL
TFT + AUDIO TFT + AUDIO TFT + AUDIO TFT + AUDIO TFT + AUDIO TFT + AUDIO TFT
CRT
CRT
(1)
(1)
(1)
(1)
(1)
(1)
Vehicle CCTV – Examples of Complete Standard Systems
28
For full details of warranties see page 60.
SINGLE CAMERA REAR VIEW SYSTEM for small to medium rigid vehicles
Motorhome
Van
Mini sweeper
Minibus
3.5" colour monitor, flush mount colour camera plus cable
3.5" colour monitor, digital mini colour camera plus cable
MODEL BE-835-312
MODEL BE-835-010
BE-835M
BE-L110
BE-302C
BE-835M
BE-L110
BE-820C
5" Value colour monitor, reversing colour camera plus cable
5" Value colour monitor, flush mount colour camera plus cable
MODEL VBV-750B-010
MODEL VBV-750B-312
VBV-750BM
VBV-L410
VBV-700C
VBV-750BM
VBV-L410
BE-302C
5" Value colour monitor, bumper-fit colour camera plus cable
5" Value monitor, monochrome reversing camera plus cable
MODEL VBV-750B-610
MODEL VBV-750B-224
VBV-L410
VBV-750BM
VBV-L410
VBV-485C
VBV-750AM
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
VBV-110C
Vehicle CCTV – Examples of Complete Standard Systems
29
For full details of warranties see page 60.
SINGLE CAMERA REAR VIEW SYSTEM for large rigid trucks/coaches/loading shovels, etc.
Rigid truck
Coach
Dump truck
Loading shovel
7" colour monitor, reversing colour camera plus cable
7" colour monitor, flush mount colour camera plus cable
MODEL BE-870-000
MODEL BE-870-320
BE-870EM
BE-L120
BE-800C
BE-870EM
BE-L120
BE-302C
7" colour monitor, reversing shutter camera plus cable
5.6" colour monitor, reversing colour camera plus cable
MODEL BE-870-100
MODEL BE-856-000
BE-870EM
BE-L120
BE-810C
BE-856EM
BE-L120
BE-800C
5.6" colour monitor, flush mount colour camera plus cable
5.6" colour monitor, reversing shutter camera plus cable
MODEL BE-856-320
MODEL BE-856-100
BE-856EM
BE-L120
BE-302C
BE-856EM
BE-L120
BE-810C
5" Value colour monitor, reversing colour camera plus cable
5" Value colour monitor, flush mount colour camera plus cable
MODEL VBV-750B-000
MODEL VBV-750B-320
VBV-750BM
VBV-L420
VBV-700C
VBV-750BM
VBV-L420
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
BE-302C
Vehicle CCTV – Examples of Complete Standard Systems
30
For full details of warranties see page 60.
SINGLE CAMERA REAR VIEW SYSTEM for articulated trucks
Articulated truck
Articulated tanker
7" colour monitor, reversing camera and cable plus
rectractable link section and connectors for artics
7" colour monitor, flush mount camera and cable plus
rectractable link section and connectors for artics
MODEL BE-870-001
MODEL BE-870-321
BE-870EM
SK-31E
SK-31E
BE-800C
BE-870EM
BE-302C
7" colour monitor, reversing shutter camera and cable plus
rectractable link section and connectors for artics
5.6" colour monitor, reversing camera and cable plus
rectractable link section and connectors for artics
MODEL BE-870-101
MODEL BE-856-001
BE-856-00
BE-870EM
SK-31E
BE-856EM
SK-31E
BE-800C
BE-810C
5.6" colour monitor, flush mount camera and cable plus
rectractable link section and connectors for artics
5.6" colour monitor, reversing shutter camera and cable plus
rectractable link section and connectors for artics
MODEL BE-856-321
MODEL BE-856-101
BE-856EM
SK-31E
BE-302C
BE-856EM
SK-31E
BE-810C
5" Value colour monitor, reversing camera and cable plus
rectractable link section and connectors for artics
5" Value colour monitor, flush mount camera and cable plus
rectractable link section and connectors for artics
MODEL VBV-750B-001
MODEL VBV-750B-321
VSK-30E
VSK-30E
VBV-750BM
VBV-700C
VBV-750BM
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
BE-302C
Vehicle CCTV – Examples of Complete Standard Systems
31
For full details of warranties see page 60.
SINGLE CAMERA FRONT VIEW (OR HIGH-MOUNT SIDE VIEW) SYSTEM
for trucks, buses and coaches
Truck
Coach
7" colour monitor, flush mount colour camera plus cable
5" Value colour monitor, flush mount colour camera plus cable
MODEL BE-870-303
MODEL VBV-750B-303
BE-870EM
BE-303C
BE-L105
BE-303C
VBV-L405
VBV-750BM
TWIN CAMERA REAR VIEW + LEFT SIDE VIEW (LOW-MOUNT) SYSTEM
for trucks, buses and coaches
Truck
Coach
7" colour monitor, one reversing and one flush mount colour
camera plus cables
7" colour monitor, two flush mount colour cameras
plus cables
MODEL BE-870-402
MODEL BE-870-432
BE-L120
BE-L120
BE-800C
BE-302C
BE-870EM
BE-870EM
BE-L105
BE-300C
BE-300C
BE-L105
5.6" colour monitor, one reversing and one flush mount
colour camera plus cables
5" Value colour monitor, one reversing and one flush mount
colour camera plus cables
MODEL BE-856-402
MODEL VBV-750B-402
BE-L120
VBV-L405
BE-800C
VBV-700C
VBV-750BM
BE-856EM
BE-L105
BE-300C
VBV-L420
BE-300C
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Vehicle CCTV – Examples of Complete Standard Systems
32
For full details of warranties see page 60.
TWIN CAMERA REAR VIEW + LEFT SIDE VIEW (LOW-MOUNT) SYSTEM
for articulated trucks
Articulated truck
Articulated tanker
7" colour monitor, one reversing and one flush mount colour
camera plus cables
7" colour monitor, two flush mount colour cameras
plus cables
MODEL BE-870-403
MODEL BE-870-433
BE-L105
BE-800C
BE-L105
SK-31E
SK-31E
BE-300C
BE-870EM
BE-302C
BE-300C
BE-870EM
5.6" colour monitor, one reversing and one flush mount
colour camera plus cables
5.6" colour monitor, two flush mount colour cameras
plus cables
MODEL BE-856-403
MODEL BE-856-433
BE-L105
BE-800C
BE-L105
SK-31E
SK-31E
BE-300C
BE-856EM
BE-302C
BE-300C
BE-856EM
5" Value colour monitor, one reversing and one flush mount
colour camera plus cables
5" Value colour monitor, two flush mount cameras
plus cables
MODEL VBV-750B-403
MODEL VBV-750B-433
VBV-L405
VBV-L405
BE-302C
VBV-700C
VSK-30E
VSK-30E
VBV-750BM
BE-300C
VBV-750BM
BE-300C
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Vehicle CCTV – Examples of Complete Standard Systems
For full details of warranties see page 60.
33
TWIN CAMERA REAR VIEW + FRONT VIEW (OR HIGH-MOUNT SIDE VIEW) SYSTEM
for large rigid trucks, coaches and dump trucks
Truck
Dump truck
Coach
7" colour monitor, one reversing and one flush mount colour
camera plus cables
7" colour monitor, two flush mount colour cameras plus cables
MODEL BE-870-400
MODEL BE-870-430
BE-L120
BE-L120
BE-800C
BE-302C
BE-870EM
BE-870EM
BE-L105
BE-303C
BE-L105
BE-303C
5.6" colour monitor, one reversing and one flush mount
colour camera plus cables
5.6" colour monitor, two flush mount colour cameras plus cables
MODEL BE-856-400
MODEL BE-856-430
BE-L120
BE-L120
BE-800C
BE-302C
BE-856EM
BE-856EM
BE-L105
BE-303C
BE-L105
BE-303C
5" Value colour monitor, one reversing and one flush mount
colour camera plus cables
5" Value colour monitor, two flush mount colour cameras
plus cables
MODEL VBV-750B-400
MODEL VBV-750B-430
VBV-L405
BE-302C
BE-L105
VBV-700C
VBV-750BM
VBV-750BM
VBV-L420
BE-303C
VBV-L420
BE-303C
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Vehicle CCTV – Examples of Complete Standard Systems
34
For full details of warranties see page 60.
TWIN CAMERA REAR VIEW + FRONT VIEW (OR HIGH-MOUNT SIDE VIEW) SYSTEM
for articulated trucks
Articulated truck
Articulated tanker
7" colour monitor, one reversing and one flush mount colour
camera plus cables
7" colour monitor, two flush mount colour cameras plus cables
MODEL BE-870-401
MODEL BE-870-431
BE-L105
BE-800C
BE-L105
BE-302C
SK-31E
SK-31E
BE-303C
BE-870EM
BE-303C
BE-870EM
5.6" colour monitor, one reversing and one flush mount colour
camera plus cables
5.6" colour monitor, two flush mount colour cameras
plus cables
MODEL BE-856-401
MODEL BE-856-431
BE-L105
BE-800C
BE-L105
BE-302C
SK-31E
SK-31E
BE-856EM
BE-856EM
BE-303C
BE-303C
5" colour monitor, one reversing and one flush mount colour
camera plus cables
5" colour monitor, two flush mount colour cameras
plus cables
MODEL BE-850-401
MODEL BE-850-431
BE-L105
BE-L105
BE-302C
BE-800C
SK-31E
SK-31E
BE-850M
More examples on next page.
BE-303C
BE-850M
BE-303C
Vehicle CCTV – Examples of Complete Standard Systems
35
For full details of warranties see page 60.
5" Value colour monitor, one reversing and one flush mount
colour camera plus cables
5" Value colour monitor, two flush mount colour cameras
plus cables
MODEL VBV-750B-401
MODEL VBV-750B-431
VBV-L405
VBV-L405
BE-302C
VBV-700C
VSK-30E
VSK-30E
BE-303C
VBV-750BM
BE-303C
VBV-750BM
TWIN CAMERA REAR VIEW SYSTEMS for trucks with drawbar trailers
Drawbar truck
7" colour monitor, two reversing shutter colour cameras
plus cables
5.6" colour monitor, two reversing shutter colour cameras
plus cables
MODEL BE-870-104
MODEL BE-856-104
BE-856EM
BE-870EM
BE-810C
BE-810C
SK-50E
SK-50E
5" colour monitor, two reversing colour cameras plus cables
5" Value colour monitor, two flush mount colour cameras
plus cables
MODEL BE-850-004
MODEL VBV-750B-004
BE-850M
BE-800C
SK-50E
VBV-750BM
VBV-700C
VSK-50E
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Vehicle CCTV – Examples of Complete Standard Systems
36
For full details of warranties see page 60.
TRIPLE CAMERA REAR VIEW + LEFT SIDE VIEW (LOW-MOUNT) SYSTEM
for trucks with drawbar trailers
Drawbar truck
7" colour monitor, two reversing colour cameras, one flush
mount colour camera plus cables
7" colour monitor, three flush mount colour cameras
plus cables
MODEL BE-870-506
MODEL BE-870-536
BE-302C
BE-800C
BE-870EM
BE-870EM
SK-50E
SK-50E
BE-300C
BE-300C
5.6" colour monitor, two reversing colour cameras, one flush
mount colour camera plus cables
5.6" colour monitor, three flush mount colour cameras
plus cables
MODEL BE-856-506
MODEL BE-856-536
BE-302C
BE-800C
BE-856EM
BE-856EM
SK-50E
SK-50E
BE-300C
BE-300C
5" Value colour monitor, two reversing colour cameras, one
flush mount colour camera plus cables
MODEL VBV-750B-506
VBV-700C
5" Value colour monitor, three flush mount colour cameras
plus cables
MODEL VBV-750B-536
BE-302C
VBV-750BM
VBV-750BM
VSK-50E
VSK-50E
BE-300C
BE-300C
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Vehicle CCTV – Examples of Complete Standard Systems
37
For full details of warranties see page 60.
TRIPLE CAMERA REAR VIEW + FRONT VIEW (OR HIGH-MOUNT SIDE VIEW) SYSTEM
for trucks with drawbar trailers
Drawbar truck
7" colour monitor, two reversing colour cameras, one flush
mount colour camera plus cables
7" colour monitor, three flush mount colour cameras
plus cables
MODEL BE-870-507
MODEL BE-870-537
BE-302C
BE-800C
BE-870EM
BE-870EM
SK-50E
SK-50E
BE-303C
BE-303C
5.6" colour monitor, two reversing colour cameras, one flush
mount colour camera plus cables
5.6" colour monitor, three flush mount colour cameras
plus cables
MODEL BE-856-507
MODEL BE-856-537
BE-800C
BE-856EM
BE-302C
BE-856EM
SK-50E
SK-50E
BE-303C
BE-303C
5" Value colour monitor, two reversing colour cameras, one
flush mount colour camera plus cables
5" Value colour monitor, three flush mount colour cameras
plus cables
MODEL VBV-750B-507
MODEL VBV-750B-537
BE-302C
VBV-700C
VBV-750BM
VBV-750BM
VSK-50E
VSK-50E
BE-303C
BE-303C
Many other rear view systems for vehicles are possible. Simply check monitor/camera
compatibility chart on page 27 and choose cable from page 25.
Articulated Truck/Trailer Connections
38
For further information call 0870 774 1500.
BE-800 Series
VBV-700, VBV-500, VBV-100
MODEL
DESCRIPTION
MODEL
DESCRIPTION
SK-30E
30m cable + retractable link section and connectors for artics:
BE-L110 10m cable for cab section
BE-X020 20m extension cable for trailer section
SP-07C 7-Pin bulkhead plug + Pigtail and truck/cab-end connector
SP-07T 7-Pin bulkhead plug + Pigtail and trailer-end connector
SC-07 retractable cable with 7-Pin sockets
VSK-30E
30m cable + retractable link section and connectors for artics:
VBV-L410 10m cable for cab section
VBV-L420 20m cable for trailer section
VSP-47A 7-Pin bulkhead plug + Pigtail and truck/cab-end connector
VSP-47B 7-Pin bulkhead plug + Pigtail and trailer-end connector
SC-07-24S retractable cable with type 24S 7-Pin sockets
SK-31E
30m cable + retractable link section and connectors for artics:
BE-L110 10m cable for cab section
BE-X020 20m extension cable for trailer section
SP-7A 7-Pin bulkhead plug + Pigtail and cab-end connector
SP-7B 7-Pin bulkhead plug + Pigtail and trailer-end connector
SC-7 retractable cable with 7-Pin sockets – unique pin layout
VSK-31E
SK-50E
All cables + retractable link section and connectors for twin-camera
truck + trailer combination:
BE-L115 15m cable for truck
BE-X020 20m extension cable for trailer camera
BE-X005 5m extension cable for truck camera
CS-020 two-way camera selector
SP-7A 7-Pin bulkhead plug + Pigtail and truck-rear connector
SP-7B 7-Pin bulkhead plug + Pigtail and trailer-front connector
SC-7 retractable cable with 7-Pin sockets – unique pin layout
30m cable + retractable link section and connectors for artics:
VBV-L410 10m cable for cab section
VBV-L420 20m cable for trailer section
VSP-47A 7-Pin bulkhead plug + Pigtail and truck/cab-end connector
VSP-47B 7-Pin bulkhead plug + Pigtail and trailer-end connector
AC-014 adaptor cable (VBV-L410 to VSP-47A)
AC-006 adaptor cable (VSP-47B to VBV-L420)
SC-7 retractable cable with 7-Pin sockets - unique pin layout
VSK-50E
All cables + retractable link section and connectors for twin-camera
truck + trailer combination:
VBV-L420 20m cables (2)
VBV-L405 5m cable for truck camera
VCS-020 two-way camera selector
VSP-47A 7-Pin bulkhead plug + Pigtail and truck-rear connector
VSP-47B 7-Pin bulkhead plug + Pigtail and trailer-front connector
SC-07-24S retractable cable with 7-Pin sockets
VSK-50E-A
All cables + retractable link section and connectors for truck-only
section of twin-camera truck + trailer combination:
VBV-L420 20m cable for truck
BVB-L405 5m cable for truck camera
VCS-020 two-way camera selector
VSP-47A 7-Pin bulkhead plug + Pigtail and truck-rear connector
SC-07-24S retractable cable with 7-Pin sockets
Trailer only section of SK-30E:
BE-X020 20m extension cable for trailer section
SP-07T 7-Pin bulkhead plug + Pigtail and trailer-end connector
VSK-30E-T
Trailer only section of VSK-30E and VSK-50E:
VBV-L420 20m cable for trailer section
VSP-47B 7-Pin bulkhead plug + Pigtail and trailer-end connector
Trailer only section of SK-31E and SK-50E:
BE-X020 20m extension cable for trailer section
SP-7B 7-Pin bulkhead plug + Pigtail and trailer-end connector
VSK-31E-T
Trailer only section of VSK-31E:
VBV-L420 20m cable for trailer section
AC-006 adaptor cable (VSP-47B to VBV-L420)
VSP-47B 7-Pin bulkhead plug + Pigtail and trailer-end connector
VSP-47A
VSP-47B
SC-07-24S
VCS-020
7-Pin Bulkhead plug + Pigtail and truck/cab-end connector
7-Pin Bulkhead plug + Pigtail and trailer-end connector
Retractable cable with type 24S 7-Pin sockets
Two-way camera selector for trucks with drawbar trailers
SK-50E-A
SK-30E-T
SK-31E-T
CS-020
CS-032
SP-07C
SP-07T
SP-7A
SP-7B
SC-7
SC-7(5S)
SC-07
SC-07(5S)
SC-07(0.3S)
SP-10
SC-10
SP-15
SC-15
SJB-01
BKT-15
All cables + retractable link section and connectors for truck-only
section of twin-camera Truck + trailer combination:
BE-L115 15m cable for truck
BE-X005 5m extension cable for truck camera
CS-020 two-way camera selector
SP-7A 7-Pin bulkhead plug + Pigtail and truck-rear connector
SC-7 retractable cable with 7-Pin sockets - unique pin layout
Two-way camera selector for trucks with drawbar trailers
3-camera switcher including auto-switching timer for cameras 2 and 3
7-Pin bulkhead plug + Pigtail and truck/cab-end connector
7-Pin bulkhead plug + Pigtail and trailer-end connector
Note: Use extension cable BE-X020 for camera
7-Pin bulkhead plug + Pigtail and truck/cab-end connector
(unique pin layout)
7-Pin bulkhead plug + Pigtail and trailer-end connector (unique pin layout)
Note: Use extension cable BE-X020 for camera
Retractable cable with 7-Pin sockets (unique pin layout)
5m straight cable with 7-Pin sockets (unique pin layout)
Retractable cable with 7-Pin sockets
5m straight cable with 7-Pin sockets
0.3m straight cable with 7-Pin sockets
10-Pin bulkhead plug with protective boot
Retractable cable with 10-Pin sockets
15-Pin bulkhead plug
Retractable cable with 15-Pin sockets, with cable
Junction box with terminal block
7/10-Pin bulkhead plug mounting bracket
Satellite Navigation
39
Navigation
Add navigation to your Brigade CCTV system to provide
travel/route information in addition to visibility in and around the
vehicle. On engaging reverse gear the rear view camera will
replace the satellite navigation information on screen.
Either connect a navigation system to your existing
Brigade CCTV or use our special splitter cable to connect
a Brigade reversing camera to your existing Siemens VDO
navigation system.
Low bridge warning system
Avoid bridge strikes with the Bridgeclear low bridge warning
system. Bridgeclear uses GPS together with its own database
to provide an early in-cab, audio and visual warning on the
Brigade monitor if the vehicle is approaching a bridge that is too
low for it. Simple to install, the system can be hidden away
under the driver’s seat.
Satellite Navigation
40
For full details of warranties see page 60.
GSN-001 Navigation Computer with pre-loaded detailed
European maps. Powered by Garmin
A remote black box unit designed to be connected to any Brigade CCTV monitors to provide route
information, points of interest and mapping with a spoken text voice prompt that can announce streets by name.
GSN-001
• 12 parallel channel GPS
• Preloaded maps for the UK and Europe (street level)
• SD card slot for loading custom POIs and
additional map data
• Composite video output
• Announces streets by name to help you keep your
eyes on the road
• Arrange destinations to minimize trip distance
• Proximity alert feature to warn of upcoming custom
POI such as safety cameras
• View the map in either a 3D perspective or
top-down, track-up or north-up view
MODEL
VOLTS
DC
CURRENT
AMPS
SIZE (mm)
(WxHxD)
OPERATING
TEMPERATURE
GSN-001
12-24
1.0
113x30x120
-20°C to +60°C
RDS TMC (Traffic Message Channel) – for GSN-001
Navigation System
NB: Traffic warning services are provided free outside the UK. This includes France, where a chargeable
premium service is also available.
MODEL
DESCRIPTION
GTM-10
GTM-10F
GSD-EUMAP
T-Piece cable/sensor fitted in-line with radio aerial, including lifetime subscription to Traffic Master in UK
T-Piece cable/sensor fitted in-line with radio aerial, including lifetime subscription to French Premium Traffic Warning Service
Updates to Garmin European detailed maps – via SD card
BE-PC5200 Siemens VDO Navigation Computer with
Integrated RDS TMC Receiver
Say goodbye to CDs and DVDs to hold road network information. The PC5200 holds the entire European
road network on compact SD cards which is cheaper and takes up considerably less installation space.
It offers optimum operation ergonomics, extremely fast route calculation and brilliant map display.
BE-PC5200
•
•
•
•
•
12-channel GPS
Secure digital (SD) card
2D/3D map view
Extensive destination input possibilities
Integrated RDS-TMC receiver
MODEL
BE-PC5200
• Dynamic navigation
• Pictogram and voice guidance
• Status LEDs
VOLTS
DC
CURRENT
AMPS
SIZE (mm)
(WxHxD)
OPERATING
TEMPERATURE
12
1.0
132x120x37
-20°C to +60°C
MODEL
DESCRIPTION
PV12s-A
BE-PC-5200 EUMAP
24Vdc down to 12Vdc dual output voltage dropper
SD card with detailed European maps
Splitter cables
NAV-001, NAV-002
MODEL
DESCRIPTION
NAV-001
Splitter cable to add BE-800 Series camera to VDO Siemens navigation system.
Includes reverse gear connection for auto activation.
NAV-002
Splitter cable to add VBV-700C camera (with AC-006 cable adapter) to VDO Siemens navigation system.
Includes reverse gear connection for auto activation.
Satellite Navigation
41
For full details of warranties see page 60.
Bridgeclear – low bridge warning system
Over 2,000 bridge strikes take place every year in the UK, costing more than £50million. A single bridge
strike could cost you many thousands of pounds in repair costs to the bridge and your vehicle, but this
disastrous situation is preventable by adding the Bridgeclear module to any Brigade vehicle CCTV system.
Bridgeclear uses GPS together with a comprehensive database of low bridges in Great Britain to provide
drivers of tall vehicles with audible and visual warnings of potential bridge strikes. This enables the driver to
take a safe alternative route.
MODEL
VOLTAGE
SIZE (mm)
(WxHxD)
DESCRIPTION
BW-001
12Vdc
110x125x50
Bridgeclear kit for the 800 series, comprising: Bridgeclear ECU,
including BACKEYE cable connections; audio/visual display and control
button and GPS aerial
MODEL
VOLTAGE
SIZE (mm)
(WxHxD)
DESCRIPTION
BW-002
12Vdc
110x125x50
Bridgeclear kit for the VBV-750, comprising: Bridgeclear ECU, including
vehicle CCTV cable connections; AC-011, pair of VBV-750 cable adaptors;
audio/visual display and control button and GP
MODEL
DESCRIPTION
PV3-S
24Vdc down to 12Vdc voltage dropper
Bridgeclear system
Digital Recorders and Dome Cameras
42
Digital video
recording systems
The MDR-200 series offers robust and reliable video
surveillance systems designed to provide high-quality video
surveillance and recording for the demanding truck, bus and
PSV markets. It offers you the choice of 4, 8, 12 or 16
camera inputs on the same vehicle recording images at the
rate of up to 25 frames per second, meeting the demands
of most transport applications. Used in conjunction with
Brigade’s CCTV systems the MDR-200 helps protect
drivers, passengers, pedestrians and vehicles plus helping
to refute false claims and discourage frivolous lawsuits.
An optional GPS sensor adds a record of location
and speed. Video and audio recordings are stored on a
removable hard disk that can be connected to a PC
via USB interface or by wireless download. Alternatively the
recordings can be viewed ‘in-situ’, using the hand-held
X201 reviewer, or by using a GSM modem in conjunction
with remote link software.
Mobile Digital Video Recording Systems
43
MDR-200 Series
• Small size, low power consumption
• Up to 25 frames/second
• 4 levels of resolution
• Removable hard disk cartridges up to 120Gb
• GPS, LAN/WLAN
• Normal, alarm, timer, movement or stills recording
• Watermarked images
• Flexible menu system with help screens
• Rapid search of recordings
• 3 year warranty (30 months on Hard Drive)
• Up to 58 hours of video can be stored on the hard disk,
at normal recording speeds
Downloading recordings to a PC
Removable hard disk cartridge can be connected to a PC to
analyse, copy or archive video/audio recordings.
MODEL
SIZE (mm)
(WxHxD)
VOLTS
DC
OPERATING
TEMPERATURE
MDR-200
Series
220x116x52
12
-40ºC to +65ºC
How to make up a typical kit
Download via WLAN
A Wireless Local Area Network (WLAN) system can be used to
download recordings from a vehicle to a PC.
Programming the system
This can be done via:
• either a MDR-200 programmer/reviewer – for on-site
configuration and reviewing of recordings
• or through a ‘virtual’ programmer/reviewer – using a laptop
1. Decide how many and what model Brigade cameras
(dome, mini or flush mount) you want to fit (see page 45).
2. Select the appropriate MDR unit for 4, 8, 12 or 16
camera inputs (see page 44).
3. Select BE-800 series cable lengths required for
each camera (see page 25).
4. Select hard disk size (80GB most popular).
5. Order at least 1 x PCLink200 programming and
reviewing software per site. This includes a ‘virtual
reviewer/programmer’, which can be used on a
laptop, and a USB cable to connect hard drive to
PC/laptop.
6. Options:
a) X201 dedicated hand-held programmer and
reviewer (not necessary if using virtual
reviewer/programmer).
b) GPS-sensor to add location and speed data.
c) Wireless download.
d) Various cables for special configuration.
Mobile Digital Video Recording Systems
44
For further information call 0870 774 1500.
Mobile Digital Video/Data Recorders
MODEL
DESCRIPTION
MDR-204
Digital Recording system comprising: X200 4-channel digital video and data recorder; AVM-200 anti-vibration digital recorder
mounting kit; VCU-01 12-24Vdc 4-camera power and video distribution box; 4 x BNC-90-01 1 metre cable with 90° BNC
Plug to BNC Plug
Digital Recording system comprising: X200-16 16-channel digital video and data recorder; AVM-200 anti-vibration digital
recorder mounting kit; 2 x VCU-01 12-24Vdc 4-camera power and video distribution box; BNC-16-8 – 8 x BNC Plugs
connected to 25-way D connector
Digital Recording system comprising: X200-16 16-channel digital video and data recorder; AVM-200 anti-vibration digital
recorder mounting kit; 3 x VCU-01 12-24Vdc 4-camera power and video distribution box; BNC-16-12 – 12 x BNC Plugs
connected to 2 x 25-way D connectors
Digital Recording system comprising: X200-16 16-channel digital video and data recorder; AVM-200 anti-vibration digital
recorder mounting kit; 4 x VCU-01 12-24Vdc 4-camera power and video distribution box; BNC-16-16 – 16 x BNC Plugs
connected to 2 x 25-way D connectors
MDR-208
X-200
X-200-16
MDR-212
MDR-216
Separate components for above kits
MHD-200 Hard drive
VCU-01 Video distribution box
MODEL
DESCRIPTION
X200
X200-16
AVM-200
VCU-01
BNC-90-01
BNC-16-8
BNC-16-12
BNC-16-16
4-channel digital video & data recorder
16-channel digital video & data recorder
Anti-Vibration X200/X200-16 digital recorder mounting kit
12-24Vdc 4-camera power and video distribution box
1 metre cable with 90º BNC plug to straight BNC plug
8 x BNC plugs connected to 25-way D connector for X200-16
12 x BNC plugs connected to 2 x 25-way D connectors for X200-16
16 x BNC plugs connected to 2 x 25-way D connectors for X200-16
Removable mobile hard drives for mobile digital video/data recorders
MODEL
DESCRIPTION
MHD-200-40
MHD-200-80
MHD-200-100
MHD-200-120
40Gb for X200 & X200-16
80Gb for X200 & X200-16
100Gb for X200 & X200-16
120Gb for X200 & X200-16
Programming and reviewing software and hardware – for X200 and X200-16
X201 Hand held reviewer
MODEL
DESCRIPTION
PCLink200
Software for on-site programming and reviewing (via laptop) and back office reviewing and image/data analysis (on PC or laptop)
with hard drive power supply and connection to PC/laptop USB socket
Dedicated hand-held on-site programmer & reviewer (instead of using laptop). NB: PCLink200 software still required for
back office reviewing and image/data analysis (on PC)
X201
Wireless download options - for X200 and X200-16 mobile digital video/data recorders
VMA-001External aerial
MODEL
DESCRIPTION
X200-LANLink
VMA-001
VMT-001
Software to enable wireless download of recorded images and data
Vehicle-mounted external aerial
Vehicle-mounted wireless transmitter (Gateway)
Optional connecting cables
VMT-001Wireless transmitter
MODEL
DESCRIPTION
X200-TFT-003
X200-TFT-010
3m BNC to phono cable. Connect X200 direct to monitor A/V input
10m BNC to phono cable. Connect X200 direct to monitor A/V input
Mobile Digital Video Recording Systems
45
For full details of warranties see page 60.
GPS Sensor
GPS-16 is a complete GPS Sensor including embedded receiver and antenna for accurate positioning,
time and date data for reporting with video data. GPS-16 includes an embedded receiver and antenna for
accurate positioning. It adds to recorded data details of the location and speed.
MODEL
GPS-16-LVS
SIZE (mm)
(DIAxH)
91x91.5
GPS Sensor
Mini-Dome Camera
Brigade offers a wide range of compatible cameras, including mini-dome and digital mini as well as any of
Brigade’s interior or exterior mounting vehicle CCTV cameras (see pages 22-24). AC-006 adaptor cables
are required for ‘Value’ and ‘Budget’ cameras.
MODEL
DESCRIPTION
MD-50
MD-50SM
MD-50AM
Mini dome camera with 1/3"CCD (76x26 dia x d)
Surface mounting adaptor (raises housing 20mm off surface to allow for single cable hole in surface)
Angled surface mounting adaptor (adds approx. 15 degrees to the vertical/horizontal view)
MD-50
MD-50SM surface
mounting adaptor
MD-50AM angled
mounting adaptor
Digital Mini-Cameras
MODEL
DESCRIPTION
DMC1025
DMC1036
Mini-camera with 2.5mm lens and BE-L100 cable connector
Mini-camera with 3.6mm lens and BE-L100 cable connector
DMC-1025
Camera Cables
Brigade mobile digital recorders and associated mini-dome cameras and digital mini cameras are all
compatible with Brigade’s ‘Professional’ 800 Series cables. See page 25.
BE-L100 cable
Ultrasonic Reversing Sensors
46
Ultrasonic Reversing Sensors
Reversing and parking in confined spaces can be tricky and
hazardous, demanding considerable awareness and skill from
the driver. Using proven ultrasonic technology BACKSCAN
informs the driver of the distance between the vehicle and
any obstacle at the rear. As soon as reverse gear is engaged
BACKSCAN starts scanning to the rear of the sensors and
a three stage warning is given to the driver.
Those models with the additional visual warning also display
to the driver the distance between the vehicle and the
object behind. Any driver who has multiple-drop collections
or deliveries or who is required to park or reverse in tight
situations will find BACKSCAN invaluable. The product range
minimises damage and gives greater protection to people and
objects behind the vehicle, whether moving or stationary, and
can create favourable effects on insurance premiums. There
are BACKSCAN systems designed for all types of vehicle
from small cars up to large vans or trucks.
DSM (Dynamic Scanning Memory) is included in all
systems. Our unique and patented DSM feature prevents ‘false
alarms’ from tow-hooks, rear-mounted tyres and other ancillary
equipment that intrude into the first 40cm of each sensor’s
detection zone.
Ultrasonic Reversing Sensors – Two Sensor Systems
47
F-Class – Budget Two Sensor Systems for vehicles up to 1.5m wide
•
•
•
•
•
•
•
•
Flush mount, slimline sensors
Dynamic Scanning Memory
Warning buzzer
Fully waterproof sensors (IP68)
CE and ‘e’ marked
RoHS compliant
12-24 Vdc
Operating temperature -25°C to +80°C
Detection range
ECU and buzzer
Model selector
SENSOR TYPE
WITHOUT DISPLAY
WITH DISPLAY
KMMA
7° upward angle
Not suitable for metal bumpers
BS-200F-KMMA
BS-210F-KMMA
KB
7° upward angle
Suitable for metal or plastic bumpers
and bodywork
BS-200F-KB
BS-210F-KB
Optional visual display
Ultrasonic Reversing Sensors – Four Sensor Systems
48
For further information call 0870 774 1500.
F-Class – Budget Four Sensor Systems, 1.5m Range
ECU and buzzer
•
•
•
•
•
•
•
•
Flush mount, slimline sensors
Dynamic Scanning Memory
Warning buzzer
Fully waterproof sensors (IP68)
CE and ‘e’ marked
RoHS compliant
12-24Vdc
Operating temperature -25°C to +80°C
Detection range
Model selector
Optional visual display
ENSOR TYPE
WITHOUT DISPLAY
WITH DISPLAY
WITHOUT DISPLAY
with 15m extension
cable
WITH DISPLAY
with 15m extension
cable
KMMA
7° upward angle
Not suitable for metal bumpers
BS-400F-KMMA
BS-410F-KMMA
BS-415F-KMMA
BS-420F-KMMA
KB
7° upward angle
Suitable for metal or plastic
bumpers and bodywork
BS-400F-KB
BS-410F-KB
BS-415F-KB
BS-420F-KB
15m cable
Ultrasonic Reversing Sensors – Four Sensor Systems
49
For full details of warranties see page 60.
A-Class – Professional Four Sensor Systems, 2.5m Range
• Self diagnostic function
• Interchangeable sensors
• Dynamic Scanning Memory
• Warning buzzer
• LED + digital visual warning
• Fully waterproof sensors (IP68)
• CE and ‘e’ marked
• RoHS compliant
• 12-24Vdc
• Operating temperature -25°C to +80°C
Detection range
ECU and buzzer
Model selector
SENSOR TYPE
KMP
Inbuilt PCB for instant interchangeability
Not suitable for metal bumpers
WITHOUT DISPLAY
with 15m extension cable
WITH DISPLAY
with 15m extension cable
BS-415A-KMP
BS-420A-KMP
Optional visual display
KBP
7° upward angle
Inbuilt PCB for instant interchangeability
Suitable for metal bumpers
BS-415A-KBP
BS-420A-KBP
KXP
Underslung sensor with inbuilt PCB for
instant interchangeability
BS-415A-KXP
BS-420A-KXP
15m cable
Ultrasonic Reversing Sensors – Four Sensor Systems
50
For further information call 0870 774 1500.
AW-Class – Professional Four Sensor Systems with waterproof
control box, suitable for large trucks and buses, 2.5m Range.
Waterproof ECU and buzzer
• Self diagnostic function
• Interchangeable sensors
• Dynamic Scanning Memory
• Warning buzzer
• 4-row coloured LED + digital readout
• Fully waterproof control box (IP68)
• Fully waterproof sensors (IP68)
• CE and ‘e’ marked
• RoHS compliant
• 12-24Vdc
• Operating temperature -25°C to +80°C
Detection range
Model selector
Visual display
SENSOR TYPE
WITHOUT DISPLAY
with 15m cable
WITH DISPLAY
with 15M cable, plus 0.5m warning zone
to compensate for sensor mounted
in-board of the rear
BS-430AW-KMP
BS-435AW-KMP
KBP
Inbuilt PCB for instant interchangeability
7° angled sensor. Suitable for metal bumpers
BS-430AW-KBP
BS-435AW-KBP
KXP
Underslung sensor with inbuilt PCB for
instant interchangeability
BS-430AW-KXP
BS-435AW-KXP
KMP
Inbuilt PCB for instant interchangeability
Not suitable for metal bumpers
15m cable
BS-435 models feature a 0.5m warning zone to compensate for sensors being mounted
in-board of the rear of the vehicle.
Ultrasonic Side Scanning Sensors
51
For further information call 0870 774 1500.
Sidescan side detection and warning system
ECU
Four hundred people are killed every year in Europe by near-side turning collisions. Most such accidents
happen at low speeds, typically as the vehicle is turning after traffic lights, at a roundabout or turning
into/out of a side road. These can easily be avoided with Sidescan.
Audio/visual
display
* KBP sensor drill-through type
SS-400 4 sensor system
• Four sensor system to warn driver when turning
MODEL
DESCRIPTION
SS-400
BS-430A-ECU waterproof electronic control box
BS-VDM-04 audio/visual display module
BS-15MCA 15m main cable
BS-KBP sensors with 2.5m cables
SS-400ECU side-turn indicator sensor/ECU
SS-BC-08 BACKCHAT side turn warning message
Drivers’ direct
field of view
Pulsed Radar Reversing Sensors
52
BACKSENSE radar detection system
Backsense utilises pulsed radar technology to detect people
and objects at a longer range than is typical with ultrasonic
reversing aids, which makes it ideal for heavy goods vehicles,
construction vehicles and mobile plant machinery. Designed
to work on the front, side or rear of vehicles, a single sensor is
sufficient to cover each zone on all but the largest machines.
Because pulsed radar travels through plastic, ruggedness and
reliability are ensured by sealing the sensor head inside the
sensor housing.
Pulsed radar reversing sensors
53
Backsense – standard systems
•
•
•
•
•
•
•
•
Conforms to SAE1455 (environmental)
Resistant to moisture, dust, vibration, heat, cold, glare
LED visual warning
3 levels of audio warning
-40°C to +85°C operating temperature
Fully waterproof (IP68)
CE and ‘e’ marked
Choice of models with detection ranges from 3m to 6m
Standard
MODEL
VOLTS
DC
POWER
CONSUMPTION
DETECTION
RANGE
SENSOR
SIZE (cm)
BS-1030
BS-1045
BS-1060
12-24
12-24
12-24
[email protected]
[email protected]
[email protected]
3.0m
4.5m
6.0m
13.3 (Dia)
13.3 (Dia)
13.3 (Dia)
Display
Separate components
MODEL
DESCRIPTION
BS-L300
BS-L450
BS-L750
3.0m standard Backsense extension cable
4.5m standard Backsense extension cable
7.5m standard Backsense extension cable
Backsense – heavy duty systems
Heavy duty
Detection zones are programmable via a laptop. Can be set to ignore fixed objects, bodywork
and attachments that are in the detection zone. Multiple sensors can be networked together to
provide the greatest area of coverage.
•
•
•
•
•
•
•
•
Conforms to SAE1455 (environmental)
Resistant to moisture, dust, vibration, heat, cold, glare
LED visual warning
3 levels of audio warning
-40°C to +85°C operating temperature
Fully waterproof (IP68)
CE and ‘e’ marked
Choice of models with detection ranges from 3m up to 8m
MODEL
VOLTS
DC
POWER
CONSUMPTION
DETECTION
RANGE
SENSOR
SIZE (cm)
BSHD-2030
BSHD-2045
BSHD-2060
BSHD-2080
12-24
12-24
12-24
12-24
200mA
200mA
200mA
200mA
3.0m
4.5m
6.0m
8.0m
200x210x65
200x210x65
200x210x65
200x210x65
Separate components
MODEL
DESCRIPTION
BSHD-L450
4.5m heavy duty Backsense extension cable
Work Lights and Beacons
54
HID Xenon and Halogen Work Lights
Nordic work lights are supremely tough and durable.
Designed and manufactured for use in the most difficult
and demanding conditions, they will not let you down in
situations where working safety depends on good visibility.
Nordic Xenon HID (High Intensity Discharge) lights are four
times brighter than ordinary halogen lights and provide a
‘white’ light that is very similar to daylight, so they are much
easier on the eye, cause less strain and are safer. The Xenon
tubes typically last 10 times longer than a halogen bulb and
use far less power.
Beacons
Brigade offers Strobe warning beacons for forklift trucks and
electric vehicles. Some models feature fully potted electronic
circuitry for longer life as a result of high resistance to shock
and vibration.
Work lights – HID Xenon
55
HID – High Intensity Discharge.
N200D HID – including Xenon tube
For use in mining and construction where the ‘daylight like’ luminosity increases driver safety through
improved visibility and reduced eye strain. Extreme shock and vibration resistance.
•
•
•
•
Integrated deutsch + 1,000mm wires
Wide or narrow flood
Shock (60G) and vibration (20G)
Fully waterproof (IP68)
MODEL
•
•
•
•
Aluminium housing and hardened glass lens
-40°C to +85°C operating temperature
3,000 hours warranty on Xenon tube
4 point anti-shock and vibration mounting
WATTS
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
35
35
35
35
Wide flood
Narrow flood
Wide flood
Narrow flood
140x140x192
140x140x192
140x140x192
140x140x192
X200-0110
X200-0111
X200-0210
X200-0211
N200D HID
N400D HID – including Xenon tube
For use in mining and construction where the ‘daylight like’ luminosity increases driver safety through
improved visibility and reduced eye strain. Extreme shock and vibration resistance.
•
•
•
•
Integrated deutsch + 1,000mm wires
Shock (50G) and vibration (12G)
Fully waterproof (IP67)
Reinforced glass fibre housing and
hardened glass lens
MODEL
• -40°C to +85°C operating temperature
• 3,000 hours warranty on Xenon tube
• 4 point anti-shock and vibration mounting
WATTS
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
35
35
35
35
Wide flood
Narrow flood
Wide flood
Narrow flood
140x140x150
140x140x150
140x140x150
140x140x150
X400-0110
X400-0111
X400-0210
X400-0211
N400D HID
N25D HID – including Xenon tube
For use in mining, construction and agriculture. Extreme shock and vibration resistance.
• 900mm wires
• Shock (50G) and vibration (12G)
• Glass fibre reinforced plastic housing and
hardened glass lens
MODEL
•
•
•
•
•
Fully waterproof (IP67)
-40°C to +85°C operating temperature
3,000 hours warranty on Xenon tube
Separate ballast unit
3 point anti-shock and vibration mounting
WATTS
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
35
35
35
35
Wide flood
Narrow flood
Wide flood
Narrow flood
100x100x132
100x100x132
100x100x132
100x100x132
X250-0150
X250-0151
X250-0250
X250-0251
N25D HID
N100F 0°HID
For mounting flush to the vehicle body in locations that require wide illumination.
• Hardened glass lens
• Wide flood light pattern
• 0° angle
MODEL
X100-3150
X100-3151
VOLTS
SIZE (mm) (WxHxD)
12
24
152x100x30
152x100x30
N100F 0°HID
Work lights – Halogen
56
All Halogen lights supplied without bulb, unless specified.
N300D + N300D Twinpower
General purpose, heavy duty work lights for use in tough conditions in field, forest or on the road.
• Vibration dampened
• Hardened glass lens
MODEL
N300D
H320-0002
H300-0002
• Twin bulb or handle options
• Integrated amp
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
FUNCTION
Flood
Flood
170x150x103
160x171x102
Twin bulb
Single bulb
N300D + N300D Twinpower with handle
General purpose, heavy duty work lights for use in tough conditions in field, forest or on the road.
• Vibration dampened
• Hardened glass lens
• Twin bulb or handle options
• Integrated amp
N300D Twinpower
MODEL
H360-0002
H350-0002
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
FUNCTION
Flood
Flood
160x171x102
160x171x102
Twin bulb + handle
Single bulb + handle
N200D
General purpose, heavy duty work lights for use in tough conditions in construction or forestry.
N300D Twinpower and Handle
• Vibration dampened
• Hardened glass lens
• Integrated amp
MODEL
H200-0000
H200-0001
N200D
LIGHT
PATTERN
Wide flood
Narrow flood
SIZE (mm)
(WxHxD)
140x140x108
140x140x108
N25D
General purpose, heavy duty work lights.
• Vibration dampened
• Hardened glass lens
• Integrated amp
MODEL
N25D
N25
H250-0000
H250-0001
LIGHT
PATTERN
Wide flood
Narrow flood
SIZE (mm)
(WxHxD)
14x140x108
140x140x108
N25
General purpose work lights for where space is limited.
• Hardened glass lens
• Integrated amp
Anti-vibration mounting
MODEL
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
H252-0000
Wide flood
100x100x94
Work lights – Halogen
57
All Halogen lights supplied without bulb, unless specified.
N100D
For applications that require wide illumination.
• Vibration dampened
• Hardened glass lens
• Integrated amp
MODEL
H100-0000
H100-0001
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
Wide flood
Narrow flood
150x98x89
150x98x89
N100D
N100
For applications that require wide illumination.
• Hardened glass lens
• Integrated amp
MODEL
H102-0000
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
Wide flood
150x98x89
N100
N100S
Side-mounted work light for locations that require wide illumination.
• Hardened glass lens
• Integrated amp
• Side-mounted
MODEL
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
H102-2000
Wide flood
150x98x89
N100S
N500 Headlight – Headlight combination
For locations that require wide illumination.
• 6 pin AMP connection
• LED indicator and parking light unit
• Hardened glass lens
MODEL
H502-8185
H502-8186
LIGHT
PATTERN
SIZE (mm)
(WxHxD)
Wide flood
Narrow flood
230x160x150
230x160x150
N500
Work lights – Halogen
58
All Halogen lights supplied without bulb, unless specified.
N100F 0° – Flush mount
For mounting flush to the vehicle body in locations that require wide illumination.
• Hardened glass lens
• Wide flood light pattern
• 0° angle
N100F
MODEL
H102-3090
DESCRIPTION
SIZE (mm)
(WxHxD)
Halogen
152x100x30
HID Xenon replacement light tubes
XO-D1S
XO-D2S
MODEL
CONNECTION
X0-D1S
X0-D2S
For N400HID, N25HID, N100HID
For N200HID
Beacons
59
Strobe warning beacons
Ideal for forklift trucks
VSB-064E + VSB-062 feature epoxy potted circuitry for extra vibration and shock resistance.
• 12-110Vdc universal
• Reverse polarity protected
• Voltage spike protected
MODEL
VOLTS
DC
JOULES
VSB-064
VSB-064E
VSB-064MG
VSB-062
12-110
12-110
12-110
12-110
1.5
1.5
1.5
1.5
VSB-064, VSB-064E
DESCRIPTION
SIZE (mm)
(WxHxD)
Beacon with replaceable tube and lens
Beacon with replaceable tube and lens, potted (epoxy) circuitry
Beacon with replaceable tube and lens, mag-mount and curly lead
Beacon with replaceable tube and lens, potted (epoxy) circuitry
130(d)x95
130(d)x95
130(d)x95
98x71x132
VSB-064MG
Branch guards
MODEL
DESCRIPTION
VSB-064BG
VSB-062BG
Branch guard for VSB-064
Branch guard for VSB-062
Replacement flash tubes and lenses
MODEL
DESCRIPTION
VSB-064FT
VSB-062FT
VSB-064LA
VSB-062LA
Replacement flash tube for VSB-064
Replacement flash tube for VSB-062
Replacement amber lens for VSB-064
Replacement amber lens for VSB-062
VSB-062
Branch guard
Warranties
60
Peace of mind from Brigade
The quality of our product range is the cornerstone on which the continuing relationship
with our customers is built. To reflect our confidence in the reliability of our products,
some have a ‘lifetime’ warranty. Many others have a 3 year warranty and the rest have a
2 year warranty, (excludes light bulbs and Xenon tubes). The following quick reference
chart indicates the warranty available on Brigade products.
Lifetime Warranty (covers the alarm for the life of the vehicle)
bbs-tek® reversing alarms (all models except Backchat and Constant Tone),
Self-adjusting Backalarms (SA-400/600/800 ranges),
Fixed volume Backalarms (BA-100/400/600/800 ranges, BA13).
3 Year Warranty
Backeye CCTV range (all monitors and cameras with a BE prefix,
MDR digital recorder).
2 Year Warranty
All other products (excluding bulbs and Xenon tubes).
CCTV Extended Warranty
All VBV CCTV models are provided with a standard 2 year ‘New for old’ warranty.
You can extend this warranty up to 3 years, simply by opting for an additional 1 year
extended warranty.
CCTV Standard On-Site Warranty Upgrade
The on-site warranty upgrade is available only as an upgrade to product warranty of
at least the same period. This means an engineer will visit your site to repair/replace
(at our discretion) the faulty CCTV part. For faults reported on weekdays by 1.00pm an
engineer will visit within three working days. For faults reported on weekdays after
1.00pm an engineer will visit within four working days.
Note: ‘weekdays’ and ‘working days’ are 9.00am to 5.00pm Monday to Friday inclusive,
excluding public holidays. Call outs will incur charge if it is found that the Brigade
product is not at fault (e.g. vehicle wiring or switching fault).
Warranty Terms and Conditions
Brigade warrants all goods to be free from defect in material and workmanship in normal use provided that
they have been installed and operated in accordance with the instruction supplied. The commencement date
of all warranties is the date of delivery to the purchaser unless otherwise agreed in writing by Brigade.
The period during which the warranty applies is stated above. Brigade make no other warranty, express or
implied, with respect to the goods, their marketability, quality or fitness for any particular use or purpose.
In particular, but without prejudice to the general provisions of the conditions of sale, no responsibility is
assumed for incidental or consequential damage by reason of any warranty express or implied. Full details
of Brigade’s Terms and Conditions are contained in the Price List.
Brigade Electronics PLC reserves the right to change terms, conditions and specifications shown
in this catalogue at any time.
Notes
61
Notes
62
www.brigade-electronics.com
www.bbs-tek.com
Head Office
Brigade Electronics plc
Brigade House
The Mills
Station Road
South Darenth
DA4 9BD
Tel: +44 (0)870 774 1500
Fax: +44 (0)870 774 1502
email: [email protected]
Brigade Elettronica srl
Via Lucio 111 Papa 6
55100 Lucca Italia
Telefono: 329 9484702
email: [email protected]
Brigade Elektronik GmbH
Haberstr. 36 A
24537 Neumünster Germany
Telefon: 04321 555 362
Fax: 04321 555 361
email: [email protected]
Brigade Electronics Inc
1 Liberty Plaza
23rd Floor
New York NY10006 USA
Tel: (212) 201-6823
Fax: (212) 201-6109
email: [email protected]
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
