Core Essentials manual

Core Essentials manual

Training Series

core essentials

e ActivClassroom by Promethean

creates successful, 360-degree educational environments by connecting technology to human ingenuity, and teachers to their peers, to students, and to a whole new world of learning.

ActivLearning is only one part of an integrated system of hardware, software, training and resources designed by educators for educators to support teacher efforts at instruction and assessment, improve student participation and strengthen performance for all types of learners.

To learn more, visit

www.PrometheanPlanet.com/ActivLearning

ActivClassroom Training Series by Promethean Professional Development

©2009 Promethean. All Rights Reserved

The reproduction by any means of any part of this book for an entire school or school system or for commercial use is strictly prohibited.

No form of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, in any form, by any means without the written permission of Promethean.

ActivInspire® and the Promethean design mark are registered trademarks. Other brands and trademarks are the property of their respective owners.

Welcome to the Promethean

ActivLearning Training Series

Core Essentials

In the Core Essentials workshop, you will be introduced to the Promethean

ActivClassroom. You will discover how to use ActivInspire to create an atmosphere of inspiration and learning. You will be introduced to the toolboxes included in ActivInspire and learn how to use several of the basic tools within these toolboxes. You will be able to create, save, and print a flipchart. Finally, you will realize how to gain access to the thousands of resources found on

Promethean Planet, the world’s largest online teacher community.

Copyright 2009 Promethean. One printed copy allowed per code

Learning objectives

Participants will be able to:

Connect and calibrate the ActivBoard

Navigate the Dashboard to easily access various ActivInspire functions

Create engaging, interactive lessons using ActivInspire’s tools and resources

Use the Camera Tool to create nonlinguistic visuals to represent student understanding

Navigate the Resource Library to incorporate resources in flipcharts

Use shared sounds and the sound recorder tool in creating flipcharts to capture students’ attention

Navigate and manipulate flipchart pages through the software easily using the Page Browser

Use Page Notes as a way to share lessons with others effectively

Learn various ways to stimulate student interest using tools found within ActivInspire such as Focus Tools

Use Desktop Annotation to interact with other Windows applications and files

Incorporate digital media as a means to bring subject matter alive and create virtual experiences for students

Make use of Connector Tool to help students see relationships in visual form

Utilize the Object Browser to manipulate objects in a flipchart

Import from existing digital resources such as PowerPoint

TM

, PDF, SMART and other supported files

Activate, determine settings, and apply the Ruler, Protractor, Compass, Calculator and Dice Tools to lessons

Copyright 2009 Promethean. One printed copy allowed per code

Table of contents

ActivClassroom

Foundational Tools

Resource Browser

Page Browser

Notes Browser

Presentation Tools

Math Tools

Dice

Calculator

Ruler

Protractor

Compass

XY Origin

Desktop Annotation

Object Browser

More Presentation Tools

Index

102

105

106

115

92

94

96

99

118

126

70

73

76

91

6

20

47

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 5

ActivClassroom

Welcome to the Promethean ActivClassroom

You are about to begin an exciting learning experience. The ActivLearning series has been designed to support you as you learn how to use ActivInspire as a dynamic lesson-building tool.

In Core Essentials, you will learn to develop lessons using the main features of the ActivInspire software. You will discover ways to use ActivInspire with the abundant resources available through Promethean Planet.

In the Beyond the Essentials workshop, you will discover how to enhance the use of other software you may be using in your classroom and incorporate your existing digital media.

Advanced Techniques will expand your skills to include more advanced features that offer additional opportunities for interaction with your students.

Copyright 2009 Promethean. One printed copy allowed per code

What is an ActivClassroom?

The ActivClassroom helps achieve student focus and motivation by creating a collaborative classroom environment in which teachers have the opportunity to produce and deliver truly interactive teaching materials for their students.

Promethean’s ActivClassroom can consist of:

Intelligent tools to engage students and help to keep them on task

Interactive whiteboards that bring images and sounds front and center to change the way students see education

Student Response Systems to provide a means to communicate with students and provide teachers with assessment data

Audio tools to ensure that every student will be able to

Promethean Planet to hear the teacher clearly connect teachers to an online community where they can share insights, knowledge and lessons

ActivInspire software to build lessons to inspire learning

This manual is designed as a reference for you as you work with ActivInspire Software.

ActivInspire software has been developed by listening to the needs of the teachers and learners who use our software. ActivInspire allows teachers to create lessons that come to life in full-color video, sound and graphics.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 7

What are the benefits?

Tailors lessons to suit the learning needs of individual students

Supports a broad range of learning styles

Brings the subject matter alive with interaction

Helps students visualize key concepts with imagery

Encourages students to construct meaning through play and experimentation

ActivClassrooms make learning fun!

‘Flipchart’ is the name given to an ActivInspire lesson. Like a traditional paper-based flipchart, an ActivInspire flipchart can contain as many pages as you wish to create. However, unlike a traditional flipchart, your

ActivInspire flipcharts can contain much more than just notes and images.

You can incorporate a number of different media forms into your flipcharts including sound files, videos, animations, interactive activities and web-links. Additionally, the extensive Resource Library is full of items for you to use if you don’t have the time to source your own. You may easily save, print and even share your flipchart with other teachers. The only real limitation is your imagination!

Visit Promethean Planet, our teacher community (www.prometheanplanet.com), where you will find a multitude of free downloadable and editable flipcharts created by teachers just like you.

You can even make your flipcharts available for other teachers to use by uploading them to Promethean Planet.

8 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

The Hardware

ActivBoard

Your ActivBoard is constructed of extremely durable, Formica-like material, engineered to withstand day-to-day use within any classroom. ActivBoards are designed for student interaction!

Maintenance Tips

Do not use abrasive powders, soaps, detergents or petroleum-based cleaners or solvents.

Scratches cannot be repaired or removed and will make ink and stain removal in that area difficult.

Due to the high quality of the projection surface, it is not recommended that anything but the

ActivPen be used on the ActivBoard.

If the surface needs cleaning after the accidental use of dry erase or permanent markers, we recommend using dry erase marker board cleaner sparingly.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 9

10 ActivLearning Training Series

ActivPen

An ActivPen is a self-powered, battery free, wireless device that communicates with your computer through an

ActivBoard. The ActivPen acts as a mouse; it performs the same left and right-click functions and enables you to control the cursor in the same way. The ActivPen is just like a mouse.

Moving the cursor

Hold the pen nib lightly on the board; don’t push in the pen nib. Move the pen around. The cursor will follow your pen.

Left-click

Tap the pen nib firmly but quickly on the ActivBoard.

Right-click

Hover the pen nib over the ActivBoard; be sure not to push in the pen nib. Press the button on the side of the pen. The right-click options will appear.

Click and drag

Press and hold the pen nib down on the board over the object you want to move, and then move the pen. The object you have chosen will move with the pen.

Double-click

Two firm but quick taps against the board with the ActivPen’s nib performs the same action as a double-click with a mouse.

Copyright 2009 Promethean. One printed copy allowed per code

The ActivPens “tune” themselves to the board and are not designed to operate alternately. The pen has a removable tip, called a nib. This nib can become worn with use and may be replaced by removing the worn tip and inserting the replacement nib.

Calibrating

Calibrating the ActivBoard is a simple and quick procedure that can be performed at any time.

Method 1

Hover your ActivPen over the Promethean icon at the top, left corner of your ActivBoard until you hear an audible beep.

You will be prompted to ’Click on surface to begin’.

Precisely click the center of each of the five calibration crosses as they appear on the board.

Method 2

Right-click on the ActivManager

Select Calibrate.

icon in the bottom right-hand corner of the screen.

Once the calibration program starts, move to the board and follow the on-screen instructions.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 11

12 ActivLearning Training Series

After calibrating, check that the tip of your ActivPen lines up with the cursor on the ActivBoard.

Note: Should you have difficulty calibrating your board, reset the board by unplugging or turning it off for thirty seconds.

Then turn it on and try calibrating again.

If your ActivBoard and projector are mounted, you will only need to recalibrate after any adjustment affecting the projected image is made, or if a different computer is used. In a non-permanent setup, should the projector or the ActivBoard be moved, you will have to recalibrate.

Getting Started with ActivInspire

Launching ActivInspire

To launch ActivInspire, double-click the icon on your Desktop/Dock or find ActivInspire in the

Start Menu/Applications folder.

When you open ActivInspire, the ActivInspire window opens behind the Dashboard. What this window looks like depends on several things:

Your preferences at startup

Whether you are using ActivInspire Professional or Personal

Note: The directions and images included in this series are based on the Professional Edition of ActivInspire Studio.

Copyright 2009 Promethean. One printed copy allowed per code

Dashboard

When you launch ActivInspire, a blank flipchart opens ready for your input. You will also see the

Dashboard displayed to the front of the workspace.

The Dashboard helps you to make the most of ActivInspire and your ActivBoard. It offers a range of actions which can be performed by clicking on the option.

The Dashboard will remain open until you close it. To close the Dashboard, click on Close in the bottom right of the Dashboard, or the close box (X) in the upper right corner.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 13

14 ActivLearning Training Series

The ActivInspire Dashboard has six options on the left side and subheadings for each option are accessed on the right side.

Flipcharts

Annotate over Desktop

ExpressPoll

Promethean Planet

Configure

Training and Support

Quick links for working with flipcharts

Opens a Desktop Flipchart

Opens the ExpressPoll

Opens Promethean Planet with one click

Quick links for profiles, device registration, updating software

Opens Promethean’s Web Support site

ActivInspire incorporates both ActivInspire Studio and ActivInspire Primary into one piece of software. You can now switch between the two.

To switch between the ActivInspire Studio and Primary interfaces:

Option 1

• Check the box ‘Launch next time using the Primary look and feel’.

Option 2

• Check the box ‘Launch next time using the Studio look and feel’.

The switch becomes effective the next time you start ActivInspire.

Copyright 2009 Promethean. One printed copy allowed per code

Choosing Your ActivInspire Interface

Profiles

You can adapt ActivInspire to suit your needs. When ActivInspire is launched, you are presented with tools and options based on a profile. There are five default profiles from which you can choose:

At the Board

Authoring

Languages

Mathematics

Media

The Profile used in the ActivLearning Series is the Authoring Profile. This profile offers the authoring tools you will need for quick lesson development.

Profiles may be changed to fit your needs. As you use ActivInspire, it will make note and the next time you open it, it will look and act the way you left it.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 15

16 ActivLearning Training Series

To change between profiles:

• In the Main Toolbox, click ‘Switch Profile’.

• Choose the desired profile from the Popup Menu.

• The chosen profile is immediately active.

To make changes to a profile:

• From the Edit Menu, select ‘Profiles’.

• The Edit Profiles Dialog Box will be displayed.

Each category of the active profile can be accessed by clicking on the desired tab at the top of the Edit Profiles Dialog Box.

Choose the desired category tab to be presented with the available options.

Layout – Position, visibility and behavior of Main

Toolbox, menus, flipchart trashcan/bin, flipchart workspace and document tabs.

Commands – Add and remove tools and commands.

User defined buttons – Create shortcuts to files or programs.

Settings – Customize the preferences for tools, multimedia, Learner Response Systems and other general application preferences.

Note: Later in the course, you will learn to create different profiles for different circumstances and save your preferences in as many profiles as you wish.

Copyright 2009 Promethean. One printed copy allowed per code

Pin View Options

As you work with ActivInspire, you can alter how the flipchart workspace is displayed.

The View Menu allows several options. Based on your preference, you can choose to hide or view the Browser, Menubar, Document Tabs,

Flipchart Trashcan/Bin and Dashboard.

The View Menu is available through the Main Menu on the Main

Toolbox, or from the Menubar.

Note: You can work with several flipcharts at the same time. Each flipchart will open within its own tab in the ActivInspire window. Move between flipcharts by clicking on the tab across the top of the flipchart window.

The Browser and/or Main Toolbox can be pinned into place or automatically hidden when not being used.

Click the Pin toolbox icon on the top right of the Browser or Main Toolbox to pin or unpin.

When pinned, the Browser and Main Toolbox will remain visible and the Pin icon will be highlighted yellow.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 17

When unpinned, they will remain hidden to the side of the page until the ActivPen is moved to the edge of the flipchart where the Browsers or Main Toolbox are hidden. The Browsers or Main Toolbox will appear on the page and can be used normally until the pen is moved away to another place on the board.

18 ActivLearning Training Series

Note: The Browser may be closed by clicking the close box in the top left corner.

To view the Browser, choose

View>Browsers.

Click the Toolbox Options Menu on the Main Toolbox to choose how it displays.

From the Popup Menu choose to place the toolbox at the top or bottom of your flipchart workspace or to display it as a floating tool palette.

Options to roll up the floating toolbox or to roll in and out the Quick Access

Toolbar are also available.

Copyright 2009 Promethean. One printed copy allowed per code

Page Scale Options

The Page Scale Menu allows you to scale your flipchart within the window. Click on the down arrow and choose from the drop-down list.

Clicking the Fullscreen tool will cause the flipchart window to display over the entire screen, preventing access to the operating system’s menus. The Fullscreen tool is a toggle, so clicking it again will exit the fullscreen mode.

Note: Fullscreen can be accessed through the

View Menu.

F5 will toggle the Fullscreen view

.

Fullscreen

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 19

20 ActivLearning Training Series

Foundational Tools

Using the Pen Tool

You can use the Pen tool to write on your flipchart page as you would with a regular pen.

To activate the Pen tool:

Click on the pen icon in the Main Toolbox. When the tool is active, its background will be highlighted.

Choose the color of your pen by clicking on your choice in the color palette.

Change the width of your pen by clicking on one of the standard preset width numbers in the Main

Toolbox or by sliding the pen width slider.

Objects created with the Pen tool are called annotations.

Using the Highlighter Tool

The Highlighter tool works in much the same way as the Pen tool, except the Highlighter places a layer of translucent color on the flipchart page.

This tool is great for pointing out specific dialog in a story or difficult or interesting words in a current event selection, or highlighting directions.

Copyright 2009 Promethean. One printed copy allowed per code

To activate the Highlighter tool:

Click on the Highlighter icon.

Select the color and width in the same way as you did with the Pen tool.

Objects created with the Highlighter tool are called annotations.

Note: You can change a profile to display 8, 16 or 24 colors in the color palette. Choose

Edit>Profiles>Layout

and choose the desired number of colors from the drop-down menu next to ‘Main Toolbox’.

Choose the arrow and choose number of colors to display.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 21

Flipchart Structure

As you work with ActivInspire to create your lessons, you will find it helpful to understand how a flipchart is constructed.

A flipchart is built in four layers. Objects that are placed on a flipchart page will automatically be applied to their default layer.

As you know, objects created by the Pen and Highlighter tools are annotations. Annotations always display over other types of objects on a flipchart page. This is because their default layer is the Top layer.

As you work through the Core Essentials Course, you will learn how to create textboxes, add images, shapes and other media to your flipchart and apply backgrounds to your pages. The default layer for objects, other than annotations, is the Middle layer.

There is a Bottom layer that is not assigned as the default for any object type, and a Background layer which is a color (white by default) or can be an image.

22 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

You will learn in the Object Browser section of this manual to easily manipulate objects within their default layer and to move objects between layers.

The illustration below demonstrates the layers of a flipchart page. It may help you to understand why annotations will appear over other object types regardless as to where they are located.

Top Layer

Middle Layer

Bottom Layer

Background Layer

We will go in depth about layers later in the Object Browser section of the ActivLearning Series.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 23

24 ActivLearning Training Series

Undo and Redo

These tools can be a teacher’s best friend.

The Undo tool reverses the last action performed in ActivInspire on your active flipchart. You may undo all the way back to your last save. Click the Undo tool as many times as needed to remove items from your flipchart page.

The Redo tool reapplies an action that has been undone by the Undo tool. You may click the Redo tool until there are no further actions to redo.

Deleting and Manipulating Objects on a Flipchart Page

Each time you draw with the pen or highlighter, you place an annotation object on the flipchart page. As we progress through the ActivLearning Series, you will discover how to add other objects such as textboxes, images and shapes. As you learn to build flipchart lessons, you will find the ability to select and move objects around the page will offer opportunities for student interaction.

Select Tool

The tool used to select and move objects is the Select Tool.

Copyright 2009 Promethean. One printed copy allowed per code

Eraser tool

The Eraser tool deletes any Annotation Object. You can delete the annotation completely, or break it into separate objects and keep the remaining parts.

To delete using the Eraser tool:

Click the Eraser tool to cause it to be the active tool.

Select the width of the eraser with the slider.

Click and drag over the annotation to delete all or part of it.

Note: The Eraser tool only deletes annotation objects; it will have no effect on other object types.

Clear tool

To activate the Clear tool:

Click on the clear tool.

Select an object from the Popup Menu.

All objects from the chosen category will be cleared from the page.

Note: If you want to bring back work that you have cleared, use the Undo tool.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 25

Select and move objects with the Select tool

To activate the Select tool:

Click on the Select tool. The cursor will change to a small arrow head with a cross.

Click on the object to be moved and drag it to the desired position.

Note: If you wish to remove the object from the flipchart page, you can drag it to the Flipchart Trashcan/Bin.

Size objects

Once an object is placed on the flipchart page, it can be changed, moved, rotated and edited using the Marquee Handles and Sizing Handles. Place the Select tool over the desired object and click to display the Marquee and Sizing Handles.

Sizing Handle

Marquee Handles

Size Object

(Maintain Aspect)

26 ActivLearning Training Series

To size an object:

Move the Select tool over the object and select with a click. A box appears around the object. The circles at the corners and in the center of each of the sides are the Sizing Handles.

Click and drag the Sizing Handles to alter the object’s shape and size.

Note: There is a special Sizing Handle that, when used, will resize the object proportionally, without distortion.

This handle can be identified by the diagonal line.

Copyright 2009 Promethean. One printed copy allowed per code

To select multiple objects:

Click and drag across the items to be selected using the Select tool. A box will appear surrounding all the selected objects along with the Marquee and Sizing Handles.

Size the objects within the selection by manipulating the Sizing Handles.

Automatic Annotation Grouping

Annotations created in close proximity to one another are automatically grouped together.

To ungroup grouped annotation objects:

Click the Group icon in the

Marquee Handles.

Click away from the selection to deselect the group.

Move each annotation individually.

Group/Ungroup Icon

Resize

Size Object

(Maintain Aspect)

Note: You can change the Settings for annotation objects. Automatic grouping of annotations may be disabled by removing the check from the option in the Flipchart Objects Setting. Select

Edit>Profiles>Settings>Flipchart Objects.

Remove the check next to

Automatic Annotation Grouping.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 27

28 ActivLearning Training Series

Manipulate and Edit Objects with the Marquee Handles

The Marquee Handles offer a number of options for manipulating and editing objects. The following are the default Marquee Handles that display when an object is selected.

Freely Move Object - Allows an object to be dragged anywhere on the page or into trashcan/bin, even if its properties have been restricted.

Rotate Object - Rotates the object.

Object Edit Menu - Opens the Object Edit Menu.

Translucency Slider - Increases or decreases the object’s translucency.

Toggle Grouped - Group and ungroup selected objects.

Bring Forward/Send Backward - Brings objects forward or sends them backward by

one position within the stack.

Duplicate - Duplicates the selected object(s).

Increase/Decrease Object Size - Increases or decreases the size of selected object(s).

Copyright 2009 Promethean. One printed copy allowed per code

The Object Edit Menu offers the editing options you have become familiar with in other applications such as cut, copy, paste, and delete. You will also find options for transforming objects and arranging them on the flipchart page.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 29

The locked option, when chosen, will cause the selected object to lock into place to prevent accidental moving by students as they work with a flipchart lesson.

Once an object is locked, it cannot be moved until it is unlocked or Design Mode is selected.

When activated, Design Mode turns off settings that have been applied to objects on a flipchart page to allow the objects to be edited.

Click the Design Mode tool at the top right of the flipchart window to access Design Mode. The tool will switch from blue to red to indicate Design Mode is active.

30 ActivLearning Training Series

Design Mode Tool

Blue Indicates Design

Mode is off

Design Mode Tool

Red Indicates Design

Mode is on

Another choice from the Object Edit Menu teachers find helpful is ‘Drag a Copy’. This feature, when applied to an object, allows multiple copies to be created with a simple click and drag.

To set ‘Drag a Copy’:

Select the object(s). The Marquee Handles Toolbar will appear.

Choose the Object Edit Menu.

Select ‘Drag a Copy’.

Click and drag the object. Rather than moving, the object will duplicate and a copy will be created.

Copyright 2009 Promethean. One printed copy allowed per code

Note: It is easy to identify objects that have been set to ‘Drag a copy’. You have learned to identify when the Select tool is positioned over an object which can be manipulated because it changes to include a plus next to the arrowhead. If ‘Drag a copy’ is active, the cursor will change to an icon of a hand with a plus next to it.

Creating a Flipchart

When ActivInspire is launched, you are presented with a blank flipchart. Each flipchart opens in its own tab.

Multiple flipcharts can be opened simultaneously.

A tab for each open flipchart will be located at the top of the Flipchart Window. New or existing flipcharts can be opened from the File Menu or the Dashboard.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 31

To open a new flipchart from the Dashboard, choose

Flipcharts>Create a new flipchart

or

File>New Flipchart.

32 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

The new flipchart will display in the tab as ‘Untitled’ until it is named and saved.

To save a flipchart:

Choose ‘Save’ or ‘Save As’ from the File Menu.

Name and save your flipchart.

Note: Saved flipcharts can be opened using the Open command from the Dashboard or File Menu. Recently used flipcharts will be displayed on the Dashboard and can be easily accessed from the File Menu by choosing ‘Open Recent’.

Shape Tool

There are many different types of objects that can be added to a flipchart. The Shape tool will help you to create specific shapes. The shape objects created with the Shape tool will be applied to the Middle layer of the flipchart page.

To create shapes with the Shape tool:

Click on the Shape tool to select it.

Choose a shape from the Shapes Menu.

Choose the outline color of the shape from the color palette on the Main Toolbox.

Choose the outline width with the Pen Slider or presets.

Choose Fill Options (color fill or no fill) from the color palette within the Shapes Menu.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 33

• Move to the flipchart page; click and drag to draw the shape to the desired size.

Fill Colors

No Fill

Option

Outline

Color

Outline

Width

Shape

Tool

34 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Click to display all shape options

Editing Shapes

To edit a shape object, first select it. The Marquee and Sizing Handles will appear. Like other flipchart objects, shapes can be resized using the Sizing Handles and moved, rotated, and edited with the Marquee Handles.

Edit

Shape

Points

When a shape is selected, the Marquee Handles will include Edit Shape Points, in addition to the default set of command icons. This command allows for more complex changes to a shape object.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 35

To use Edit Shape Points:

Select the shape.

Click the Edit Shape Points icon. This will activate the object’s shape points which will appear as a series of squares around the object.

Click and drag any shape point to alter the shape.

36 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Working with Text

The Text tool is used to add text to your flipcharts. Textboxes may be created away from the board using your computer keyboard or while at the board using the On-Screen Keyboard tool.

To add text to your flipchart page while at your computer:

Select the Text tool. The cursor will change to a small bar with letters next to it to indicate the Text tool is chosen.

The Text Edit toolbar will appear across the top of your flipchart. You may choose the font, size, color, etc. of your text.

Click on the flipchart page in the area where you wish to place the text.

Begin typing.

Symbols

Cursor changes to indicate Text Tool is active.

On-screen

Keyboard

Select All

Clicking on the flipchart page outside the textbox while the Text tool is active will create a new textbox.

Note: It is possible to simply click with the Select tool where you want the text to begin and start typing. The Text tool will be automatically selected.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 37

There are a number of specialty symbol fonts available from symbols in the Text Edit toolbar.

To use a specialty symbol:

Click the Symbols icon on the toolbar.

From the drop-down menu, choose the symbols category that meets your need.

From the chosen symbol set, click the symbol you wish to use and it will appear in your textbox.

38 ActivLearning Training Series

The On-Screen Keyboard tool works like the keyboard on your computer. You can enter text in a flipchart or in other Windows applications. This is particularly helpful when you need to add information to a document or enter URL’s into a Search Engine while at the board. Using the on-screen keyboard eliminates the need to run back and forth to your computer.

The Text Edit toolbar displays the On-Screen Keyboard tool.

Copyright 2009 Promethean. One printed copy allowed per code

To add text with the on-screen keyboard:

Click the Keyboard tool icon in the Text Edit toolbar and the on-screen keyboard will appear, allowing you to type while at the ActivBoard.

Move your ActivPen over the on-screen keyboard. The cursor will change to a hand with a pointing finger.

Tap the keys on the keyboard with the ActivPen to type.

You can choose to display four different types of on-screen keyboards.

Small Adult Keyboard

Large Adult Keyboard

Small Child Keyboard

Large Child Keyboard

To change the keyboard, right-click on the on-screen keyboard and click on the desired choice from the

Popup Menu.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 39

To close the keyboard, click the close box on the Adult Keyboard or the door icon on the

Child’s Keyboard.

Note: You can choose to open the keyboard using the

Tools Menu.

Tools Menu>More Tools>On-Screen Keyboard

40 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Editing text

To edit an existing textbox, use one of the following options:

Option 1

• Select the textbox and from the Marquee Handles, choose ‘Text Edit’.

Edit Text

Option 2

Select the Text tool and click on the textbox.

Double-click on the textbox.

Each of these options will open the textbox for editing and display the Text Edit toolbar.

Repositioning Text

You may find that your textbox is not sized as you would like.

To reposition text:

Select the textbox.

Use the Sizing Handles to change its size. The text will automatically wrap.

To change the position of the textbox, simply click and drag it to a new location on the page.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 41

Using the On-Screen Keyboard with other applications

To type in another application using the On-Screen Keyboard:

Click the Desktop tools icon on the Main toolbox. They will appear in the form of a

‘Wonderwheel’ and the ActivInspire Window will minimize.

Click the center of the ‘Wonderwheel’ to view the available tools.

Click the On-Screen Keyboard tool.

Click in the Windows application at the point where you wish to insert text.

Click the keys on the On-Screen Keyboard. Your text will be entered into the application.

When the Desktop tools are no longer needed, click the Restore ActivInspire icon.

Note: To move the Desktop tools, click in the center of the ‘Wonderwheel’ and drag the tools to the desired location.

Restore

ActivInspire

On-Screen

Keyboard

42 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Spellchecker

You can choose to spell check the entire flipchart or a single textbox.

To spell check a single textbox:

Select the textbox.

Click the Object Edit Menu icon.

Choose ‘Spellcheck Text’ from the Popup Menu.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 43

The Spell Checker Dialog Box opens. Possible spelling errors will appear in red. Accept, reject or ignore spelling suggestions.

Continue to accept or reject suggestions until the notification that spell check is complete appears.

To spell check the entire flipchart from the Tools Menu choose

Tools>More Tools>Spellcheck Flipchart.

Note: You can stop the spell check at anytime by clicking ‘Done’ on the Spell Checker Dialog Box.

44 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Using the Fill Tool to Add Color

Add interest to your flipchart pages by replacing the white background with any color of your choice!

To use the Fill tool to change the background color:

Click on the Fill tool.

Choose a color from the color palette.

Click in a blank area of your flipchart page.

The fill tool makes it easy to change the color of a single word in a textbox. This offers another way to highlight important words when presenting your lessons to your students.

To use the Fill tool to change text color:

Click on the Fill tool.

Choose a color from the color palette.

Click the word you wish to change.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 45

You can also use the Fill tool to change the fill color of shape objects or to fill closed shapes drawn with the pen or highlighter with color.

To use the Fill tool to change the color of objects:

Click on the Fill tool.

Choose a color from the color palette.

Click inside the shape.

In this example, the flipchart page has two sections.

The top section contains two shapes with a portion of them filled in. Students write the decimal which represents the filled portion of the shape underneath it. They then use the Fill tool to change the top portion of the page to another color. The correct answer is revealed.

In the bottom section, students use the Fill tool to shade a designated portion of the shape.

46 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Resource Browser

ActivInspire contains thousands of ready-made resources to help you build your flipcharts.

To access the Resource Library, from the main toolbar menu, select

View>Browsers

and click on the Media icon.

The Resource Library window is divided into three sections – Where, What and How.

Understanding these sections will make it simple to locate and include the resources you need to create your lessons.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 47

48 ActivLearning Training Series

Where – The location where the file is saved

The icons at the top of the Resource Browser indicate the location for the resources.

Shared Resources

My Resources These are resources that you personally find or create and store in the Resource

Library. (This will be explained later in the ActivLearning

Training Series.)

Other Resource Folder Use this option to browse for resources stored on your computer.

Search Tool

This is where you will find thousands of resources that are included in your

ActivInspire software.

To aid you with finding resources, ActivInspire has a search feature.

Copyright 2009 Promethean. One printed copy allowed per code

To search for items using the Resource Library Search Tool:

• Type your key word in the finder box.

• Select the Show Search Options icon.

• Choose the type(s) of resources you need.

Click on the arrow next to the finder box.

Results will be displayed in the bottom of the

Resource Browser window.

An additional option is available to search

Promethean Planet resources by selecting the Search Resources on the Promethean

Planet icon.

Note: To activate the Search feature, you must first index your resources. This will take some time.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 49

Other Resource folder – This feature allows you to browse for resources in your computer folders or anywhere on your network.

• Click on the browse button to navigate and browse for resources located in folders on your computer.

• Click on the folder containing the needed resource then click

‘OK’. The folder contents will be displayed in the Resource

Browser’s thumbnail window .

50 ActivLearning Training Series

What – Resource Browser library contents

Thousands of resources are organized into categories and easily accessed to incorporate into your flipcharts. You will find backgrounds, images, sounds, grids and an assortment of other resources to make your flipcharts interactive and engaging within the Resource Library.

How – The method for placing the resource on a flipchart page

In the middle of the Resource Browser window, you may choose how to place resources on your flipchart page .

The default method is to click on the thumbnail image and drag it onto the flipchart.

Copyright 2009 Promethean. One printed copy allowed per code

Rubber Stamp

This feature allows you to drag the object to the page and rubber stamp it on to the page as many times as you would like. Each time you click the page, the object will drop. You can discontinue this feature by doing one of the following:

Click and drag another resource to be rubber stamped.

Choose an ActivInspire tool from a toolbox.

Note: After using the Rubber Stamp option, it is a good idea to click on another tool in the toolbar. This will avoid confusion as the

Rubber Stamp tool will be active until you choose something else.

Resource Library settings

You can choose how you would like your images to be displayed by clicking on the Resource Library

Settings icon in the Resource Browser.

View Mode gives alternate ways of looking at resources.

Copyright 2009 Promethean. One printed copy allowed per code

Resource Libray

Settings

ActivLearning Training Series 51

‘View as list’ allows for the name of the resource to be visible if the Thumbnail Large option is selected.

‘View as grid’ allows all objects to be seen.

Names are revealed as you mouse over the objects.

52 ActivLearning Training Series

Thumbnail Size allows you to select the size of images in the

Resource Browser.

Transparency You can make the image object background transparent by selecting this option.

Copyright 2009 Promethean. One printed copy allowed per code

Incorporate Backgrounds From the Resource Library

The resources in the Backgrounds folder of the Resource Library change your flipchart page from a plain, colored background to an image. The backgrounds can be used to turn your page into graph paper, music paper, graphic organizers, sports fields, or one of the hundreds of other options.

To place a background on a flipchart page:

• Open the Resource Browser.

• Choose the Backgrounds Folder.

• Choose the folder containing the background of your choice.

• Click and drag the background image from the

Resource Browser to your flipchart page.

Note: Backgrounds may be placed on your page at anytime. They reside on the Background layer and always display beneath all objects on your flipchart page.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 53

To remove or change a background:

Option 1

• Click and drag a different background onto the page. It will replace the current background.

Option 2

• Use the Clear tool to clear the background.

54 ActivLearning Training Series

Using The Camera Tool

The Camera tool allows you to capture, as an image, anything displayed on your desktop.

The photograph becomes an image object you can add to your flipchart page, Resource

Library, or the clipboard, and allows you to manipulate it like any other object.

To capture an image with the Camera tool:

Display on your computer screen the image you want to capture.

Select the Camera Tool selecting

Tools>Camera.

From the Popup Menu, choose how you would like to capture the image.

Copyright 2009 Promethean. One printed copy allowed per code

Area

Point to Point

Freehand

Window

Fullscreen

Allows you to choose a rectangular area to be captured.

Move and resize the rectangle so the image you wish to capture is contained inside of it.

Allows you to define an irregular shape to be captured.

To begin, click to start the shape of the area to be captured, move to the next point and click.

Each time you click, you may move the line in another direction.

Close the shape by clicking at the point you began.

Note: Click the x on the toolbox if you wish to cancel the image and

try again.

Allows you to draw freehand to define the image to be captured.

Click and drag the cursor. A line will define the photograph and the area not captured will be grayed out.

Note: Click the x on the toolbox if you wish to cancel the image and

try again.

Allows you to capture the screen image without the task bar showing.

Allows you to capture the entire screen, including the task bar.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 55

• After the picture is taken, you will need to choose from the five options on the Photograph toolbox.

56 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Current Page

New Page

Clipboard

My Resources

Copies the image and places it on the current page of your active flipchart.

Copies the image and places on a new page at the end of your current flipchart.

Copies the image and places it on the clipboard to be pasted at a later time.

Copies the image and places it in the folder of your choosing in your My Resources Folder. It can be used in the same way as other objects in the Image Library.

Shared Resources Copies the image and places it in a folder of your choosing in the

Shared Resources Folder. It can be used in the same way as other objects in the Image Library.

Note: You will hear the Camera tool sound and the image will be placed according to your choice.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 57

Using the Camera tool from the Desktop tools toolbox

The Camera tool can be opened using Desktop tools. When you click on the Desktop tools icon, the flipchart is minimized and the floating Desktop tools toolbox is displayed.

Return to flipchart

This toolbox can be moved around the desktop by dragging it to the desired location. It will remain on your desktop showing over any application displayed there. The Camera tool, when accessed from the Desktop tools, will capture anything displayed on the desktop.

58 ActivLearning Training Series

To capture an image with

Desktop

Tools>Camera:

Open Desktop tools.

Move the cursor over the Desktop tools Icon to display the available tools.

Move the cursor over the Camera tool icon to display the capture options.

Click the desired capture option.

Define the image to be captured.

Choose how to apply the captured image from the five options on the Photograph toolbox.

Note: To close the Desktop tools, click the Return to Flipcharts icon on the Desktop tools toolbar.

Copyright 2009 Promethean. One printed copy allowed per code

Incorporate Sounds into Your Flipchart

ActivInspire includes sounds you can use to enhance your flipcharts or you can create your own recordings.

To add sounds to your flipchart from the Resource Browser:

• Open the Resource Browser.

Select the Sounds folder.

Choose a sound and drag its icon to the flipchart page.

A sound icon will appear on the page.

Click to play.

When a sound is being played, a Stop

Sound icon will appear in the top right side of the flipchart window. Clicking this icon will stop the sound.

By default, the Sound Controller appears each time a sound is played. You may choose not to have the Sound

Controller appear when sounds are played.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 59

To change the setting:

• Select

Edit>Profiles>Settings>Multimedia.

• Deselect ‘Show sound controller’.

• Click ‘Done’.

Note: To view the Sound Controller as needed, add the Sound Controller tool to your toolbox using

Edit>Profiles>Commands.

Recording Sounds

If you have microphone input on your computer, you may record your own sounds to incorporate into your flipcharts. Teachers or students may record read alouds, music, or other sounds to make flipcharts more engaging for instruction.

60 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

To record sound:

• Select

Tools>More Tools>Sound Recorder.

• The Sound Recorder Control will appear.

Click the record button (red circle) to immediately begin recording the sound.

Click the stop button (black square) to stop recording.

The sound icon will appear on the flipchart page.

You may choose to save the recording as a file to be used as a resource.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 61

To save a sound recording:

• Select

Edit>Profiles>Settings>Recordings.

• From the drop-down menu choose from one of the following:

62 ActivLearning Training Series

Add to Flipchart

Save to Disk

Both

Places the sound icon on the current flipchart page

(the default).

You will be presented with a ‘Save as’ Dialog Box. Name and save the sound. The sound will not be placed on the flipchart page.

You will be presented with a ‘Save as’ Dialog Box. Name and save the sound. An icon will be placed on the current page for immediate use.

Note: To remove a sound from a flipchart page, click and drag the sound icon into the Flipchart Trashcan/Bin.

Copyright 2009 Promethean. One printed copy allowed per code

Incorporate Resource Library

Activities and Templates

ActivInspire has included a resource folder ‘Activities and templates’ with flipchart pages and activities for you to use or manipulate to suit your classroom needs. This folder contains manipulative activities in content areas, learner response templates, commonly used layouts, and thematic pages. Take time to familiarize yourself with the pages in the

Resource Library to save time when creating your flipcharts.

The pages in this section can be added to your flipchart by simply dragging the thumbnail image and dropping it on your flipchart page.

Basic templates can be modified to meet your curriculum. The page on the left is a timeline template from

Activities and

Templates>Templates.

The page on the right shows an activity for ordering fractions using this template.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 63

Incorporate Grids Into Your Flipchart

The resources in the Grids folder of the Resource Library change the appearance of the flipchart page to one of several grid options.

To Add a Grid:

Open the Resource Browser.

Choose the Grids folder.

Choose the folder containing the grid of your choice.

Click and drag the grid image of your choice from the Resource Library to the flipchart page.

Note: Grids from the Grids folder may be placed on your page at anytime and will always display beneath any objects on your flipchart page and above the background color or image.

64 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

To edit the grid currently on your flipchart page:

Select

Edit>Grid.

The Grid Designer Window will open. Choose to:

Change the grid size.

Hide the grid from view.

Cause items on the page to snap to the grid when they are moved.

The Grid Designer offers several options for altering and creating custom grids. These options are covered in the ‘Beyond the Essentials’ section of the ActivLearning Series.

Increase/

Tools Decrease

Increases or decreases the grid size in increments of 10%.

Visible

Allow Snap

On top

When selected, the grid is no longer visible. If Snap to Grid has been activated, it will remain active.

Causes objects placed on the page to snap to grid points. This is helpful when you want to align objects in your flipchart.

Causes grid to appear above all flipchart objects.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 65

66 ActivLearning Training Series

Note: The Visible and Allow Snap commands can also be accessed by right-clicking on the

flipchart page and activating these options from the Page Menu.

To remove or change a grid:

Option 1

• Click and drag a different grid onto the page.

Option 2

• Use the Clear tool to remove the grid.

Copyright 2009 Promethean. One printed copy allowed per code

In this example, a grid from the Grid Folder has been placed on the page.

The grid has been set to Visible and Allow Snap.

The squares were made with the Shape tool and have Drag a Copy enabled.

Students interact with the flipchart page by dragging and dropping the squares into the shapes.

Note: The teacher could have first unchecked Visible and allowed students to predict how many squares would fill each space.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 67

Importing Resource Packs from

Promethean Planet

Resource packs are collections of vibrant images, videos and more that will liven up your lessons and make students sit up and take notice! These packs cover a variety of curriculum areas and topics, and are easily installed into your ActivInspire Resource Library.

68 ActivLearning Training Series

To download a Resource Pack to your computer:

Log in to Promethean Planet.

Click on Resources.

Fill in the blanks with your search criteria.

Select the Resource Pack radio button.

Click on Search.

Select the desired file and download to your computer.

Copyright 2009 Promethean. One printed copy allowed per code

To import a Resource pack to your Resource Library, use one of the following options:

Option 1

• From the File Menu:

• Choose

Import>Resource Pack

to My

Resources or to Shared Resources as desired.

Option 2

• From the Resource Browser Menu:

• Click on My Resources or Shared Resources as desired.

• Select ‘Import Resource Pack Here’.

• Resource Pack will be saved in Resource

Pack folder.

Imported Resources are immediately available for your use in ActivInspire.

Copyright 2009 Promethean. One printed copy allowed per code

Properties icon

ActivLearning Training Series 69

70 ActivLearning Training Series

Page Browser

When presenting a flipchart, it is easy to access any page quickly by using the Page Browser. This Browser helps you to quickly put together the foundations of your flipchart.

Use the Page Browser to:

View the entire flipchart as page thumbnails.

Navigate flipchart pages.

Set the backgrounds and grids for pages.

Organize your flipchart pages using drag and drop reordering.

Use the Popup Menu on a page thumbnail to access the page edit options. From the Popup Menu you can access commands such as Cut,

Copy, Paste, Delete and Duplicate.

If the Browser is closed, select

View>Browsers.

The Browser will open.

Click on the Page Browser icon.

You may leave the Page Browser open while you work on a flipchart.

The Page Browser will display a thumbnail of each of your flipchart pages.

Use the slider to change the size of thumbnail. You can resize the Page

Browser to view and arrange pages within your flipchart.

Copyright 2009 Promethean. One printed copy allowed per code

Slide

• To copy a flipchart page from one flipchart to another, simply drag the thumbnail of the page you want to copy from the Page Browser to the tab of the flipchart where you want the page to be.

Click and drag

Thumbnail to flipchart tab.

The Popup Menu icon in the top right corner of a page thumbnail indicates the current page of the flipchart.

Use the Popup Menu of a selected page’s thumbnail to access menu options for working with pages.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 71

72 ActivLearning Training Series

Insert Page

Blank page before current

Adds a blank page before the current page.

Blank page after current

Adds a blank page after the current page.

Desktop Snapshot Takes a snapshot of your desktop and inserts it as a new page in your flipchart.

More Page Templates Opens the Resource Library to the Activities and

Templates folders.

Add to Resource Library

Add Page

Add Background

Add Grid

Adds the entire current page to the open folder in your Resource Library. All items retain properties as set on original page.

Saves the background of the current page to the open folder in your Resource Library.

Saves the grid of the current page to the open folder in your Resource Library.

Copyright 2009 Promethean. One printed copy allowed per code

Notes Browser

The Notes Browser is an ActivInspire feature that allows you to attach additional information to each page of your flipchart. Use this to offer instructions and other helpful information to make the flipchart easy to share and reuse.

The flipchart will be completely visible when the Notes Browser is open, so students can have the directions available when completing an activity.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 73

74 ActivLearning Training Series

If a note is included for a page, the Page Notes icon will appear in the top of the flipchart window.

Clicking this icon will open the Notes Browser if it is not already open.

To create a page note:

In the Browser window click the Notes Browser icon.

Type in the desired text.

Note: If the Browser window is not open, select

View>Browsers

.

To format a page note:

Click on the Format Toolbar box at the bottom of the Notes Browser Window.

A standard text editing toolbar will appear below the Main Menu.

Note: You can perform common editing functions such as cut, copy, paste, and delete by right-clicking on the Page Note to display a Popup menu.

Copyright 2009 Promethean. One printed copy allowed per code

To paste text from the page note onto the flipchart page:

• Highlight the text you wish to paste to the flipchart and drag it onto the flipchart page.

To print, select

File>Print.

The Flipchart print Dialog Box will be displayed.

Make desired changes to print options.

Note: Page notes may be exported to PDF or sent to your printer. They may be included with a printed flipchart or printed alone.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 75

Presentation Tools

ActivInspire provides tools to help you focus your students’ attention when presenting a flipchart. The Focus

Tools, like other ActivInspire tools, can also be used with other applications, including digital material, web pages, PowerPoint Presentations, etc.

Spotlight Tool

To use the Spotlight tool:

Click on

Tools>Spotlight.

From the Popup Menu choose which type of Spotlight you wish to use.

76 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Circular Spotlight Solid Circular Spotlight

Square Spotlight

Solid Square Spotlight

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 77

To manipulate the Spotlight:

When the cursor is placed outside the revealed area, it will appear as a cross-hairs icon.

Click and drag the cross-hairs to change the spotlight’s position.

When the cursor is placed on the outline of the spotlight, it will appear as a double-headed arrow.

Click and drag the arrow to change the size and shape of the spotlight.

Displayed alongside the spotlight is a menu icon. Click the icon to view the Spotlight Popup Menu. You can:

Change the type of Spotlight. The currently chosen spotlight will be identified with a check icon.

Take a snapshot.

- When the Circular or Square Spotlight is chosen, the image captured will be the revealed area within the spotlight.

- When the Solid Circular or Square Spotlight is chosen, the image captured will be the revealed area outside the spotlight.

Close the Spotlight.

78 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

An example of how the Spotlight snapshot could be used:

Note: You can continue to interact as normal with the visible portions of the flipchart.

Image created with

Round Spotlight

Image created with

Square Spotlight

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 79

Revealer Tool

The Revealer tool in ActivInspire can hide information to be presented in stages.

To access the Revealer tool from the Main Menu:

Select

Tools>Revealer.

The page will be masked.

Move your cursor to any edge of the page.

(top, bottom, left or right)

The cursor will turn into a blind pull shape.

Click and drag away from the edge to reveal a section of the page.

The Reveal tool will remain active until you close it using the

Revealer Menu. This is true even when moving backwards or forward to a new page.

80 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

You can also move the Revealer to a point and save the position. The next time the Revealer is used with that page, it will open at the saved position. On subsequent pages it will return to its default position.

Note: You may interact with the revealed portion of the flipchart page using the ActivInspire tools.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 81

Clock

The clock is opened in a separate window that may be placed anywhere on the screen.

It will always display on top of the desktop and any applications which may be open.

To access the clock, select

Tools>More Tools>Clock.

82 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Clock display and toolbar

Analog Time will be displayed in analog format.

Digital Time will be displayed in digital format.

Both formats will be displayed. This is the default setting.

Both Digital and Analog

Pause

Count Down

Count Up

Show/Hide

Stops and starts the clock or counter.

The timer will count down from a time entered.

The timer will count up to a time entered.

Bottom toolbar will be shown or hidden.

Close

Analog

Show/Hide Toolbar

Count Up

Digital

Pause

Both

Analog and

Digital

Count

Down

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 83

To move the clock:

Click on the title bar of the clock window, and drag to the desired position.

Release the click.

To resize the clock:

Move the cursor to the edge of the window.

When you see the double-headed resize arrow, click and drag to the preferred size.

Release the click.

Clock Timer

The Clock Timer is useful in a classroom setting for timed quizzes, transition to a new activity, etc.

To set the count down or count up timer:

Open the Clock.

Click the desired option’s button on the clock window.

The options will display in the Clock Counter window for you to specify the time.

84 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Set the time: hours: minutes: seconds

Navigate to sound files

Actions after timeout

You may also choose from the following optional items:

• Check the Repeat box to repeat the Count Down or Count Up Timer until the clock is closed.

• Choose to set actions to be performed at the end of the defined time, such as:

After timeout, play the following sound:

• A drop-down menu will offer a number of sounds from which to choose. You can also navigate to a sound file on your computer.

Click ‘OK’.

After timeout, perform the following action:

• A drop-down menu will offer a number of actions.

The Count Down or Count Up clock will appear on your flipchart or screen and begin the count.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 85

Clock tool settings

Clock settings will allow you to make changes in the way the clock is displayed.

To change the default settings, choose

Edit>Profile>Settings

and select Clock tool.

Define how you wish for the Analog Clock to appear.

Define how you would like the Digital Clock to appear.

Click ‘Done’.

Note: This change will affect only the currently selected profile.

86 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Tickertape

With the Tickertape tool you can create messages to scroll across the screen. This message will be displayed over all applications. Once a message is created, you can save and edit it. You may wish to create tickertapes for any number of tasks:

Homework assignment

Get permission slip signed

Directions for an assignment

Answer key

Essential Question for the lesson you are teaching, etc.

To create a tickertape:

Select

Tools>More Tools>Tickertape.

The Tickertape Dialog Box opens.

From the dialog box you may choose:

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 87

88 ActivLearning Training Series

Create new tickertape Create a new tickertape.

Open a Tickertape File Open from a location on your computer.

Save Tickertape File Save Tickertape to a location on your computer.

Save Tickertape File As Save Tickertape to a different location or change the name of the current tickertape.

• In the ‘Enter the Tickertape message’ box, type the message you wish to appear.

• Use the editing tools in the Tickertape Dialog Box to choose a

• font style and color.

• drop shadow width and color (optional).

• background color for the message (optional).

• The Position drop-down menu allows you to choose where the tickertape will appear on the screen. There are three choices: Top, Middle, or Bottom.

• Click on ‘Show Tickertape’ to see a preview of your tickertape.

• Once the message is finished, click ‘OK’.

• The tickertape will begin to scroll across the screen in the location you chose.

Copyright 2009 Promethean. One printed copy allowed per code

Editing a Tickertape

You must first open a tickertape before this option is available:

In the ‘Enter the Tickertape message’ box, the current text will appear.

Edit and position the tickertape using the Tickertape options.

Once the message is entered, click ‘OK’.

The edited tickertape will begin to scroll across the screen.

Manipulating the Tickertape

Stop

Open

Tickertape

Menu

To stop the tickertape, click the Stop button.

To pause and start the tickertape, click the Stop/Start Icon.

Time Bar Pause/

Play

To change the speed, move the slider to the left for a slower speed and to the right for a faster speed.

Click and hold on the tickertape with the ActivPen to hold it in place.

Click and drag on the tickertape with the ActivPen to move it forward and backward.

Release the click to continue scrolling the tickertape.

Note: You can use the ActivPen to manipulate the tickertape.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 89

The tickertape is used in this example to display the Essential Question.

90 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Math Tools

ActivInspire includes a set of powerful interactive tools to enhance your lessons.

To access the Math tools:

Select

Tools>Maths Tools.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 91

Dice Roller

The Dice tool generates random numbers. You may choose to roll between one and five dice.

To access the Dice Roller:

Select

Tools>Maths Tools>Dice Roller.

Click on the Dice Roller.

Click on the drop-down arrow to select the number of dice.

Use the slider on the speed control to set the speed that the dice will roll.

Click on the Roll button. An animation of dice rolling to a stop will be displayed. Each time you click, the dice will roll again.

Click on the ‘Output to Flipchart’ button.

The sum of the displayed die will be pasted to the center of the current flipchart page.

To put the Dice Roller away, click the close button (x) in the upper right corner of the

Dice Roller window.

92 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Use the Dice Roller to generate random numbers for review and reinforcement of your lesson on mean, median and mode. Students will roll the dice, add the dice total to the flipchart page and calculate the mean, median and mode for the set of numbers. Have a student come to the board and calculate the answers using the

Calculator tool.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 93

Calculator

The Calculator tool functions in the same way as a standard handheld calculator.

94 ActivLearning Training Series

Child Calculator

Adult Calculator

To access the Calculator tool:

Select

Tools>Maths Tools>Calculator.

Click on the Calculator tool. The type of calculator used last will appear on the page.

Right-click on the calculator to choose between the Adult Calculator and the Child Calculator.

You may move the Calculator anywhere on your page. Click anywhere other than on the display screen or buttons and drag it to the location you choose.

Release the click.

To put the Calculator away, click the close box (x) in the upper right corner of the Calculator or click again on the Calculator tool.

Copyright 2009 Promethean. One printed copy allowed per code

Input at top of Calculator

Answer displayed in window

Input in top window

Answer displayed in window

More Math Tools

ActivInspire includes fully functioning Ruler, Protractor and Compass tools.

Both the protractor and ruler are translucent. Each of these tools can be positioned over any object to do physical measurements.

To access the Math tools:

Select

Tools>Maths Tools.

Choose the tool you wish to use. You may have multiple instances of the ruler, protractor or compass if you have a need for this.

Note: If you are teaching Math, you may wish to change your profile to Mathematics.

All available Math tools will now appear on the Main Toolbox.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 95

To display a Math tool, click on the tool you wish to use.

The tool will remain displayed and ready for use until you close the tool or move it to the Flipchart Trashcan/Bin.

Ruler Tool

To access the ruler tool, select

Tools>Maths Tools>Ruler.

When you click on the Ruler tool, click on the menu icon which will allow you to choose the type of measurement for the top and the bottom of the ruler that best suits your needs. You may choose from centimeters, millimeters, inches, or none.

Change the length of the ruler

Click on the right or left edge of the ruler.

The cursor will turn into a double headed arrow.

Drag to the desired length.

Measurement scale will change accordingly.

96 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Place the ruler anywhere on the flipchart or desktop

Click in the middle of the ruler.

The cursor will turn into a cross-hairs icon.

Drag the ruler to the appropriate place.

Release the click when the tool is in the location of choice.

Rotate the ruler

Place your ActivPen along the top or bottom edge of the ruler.

The cursor will change to the rotate arrow.

Click and drag to rotate to the desired angle.

You will see that the angle of rotation is displayed in the center of the ruler.

The angle is based on the 0 mark at the bottom of the ruler.

Release the click when the ruler is at the correct angle.

Angle of Rotation

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 97

Draw a straight line using the ruler

Select the Pen or Highlighter tool.

Choose the color and width that you desire.

Move the cursor near the top or bottom edge of the ruler.

The cursor will be displayed as a pen or highlighter.

Click and drag the pen along the ruler to draw a straight line.

Release the click when you have drawn the line to the desired length.

The line will be drawn in the selected pen color and width.

Note: The Ruler tool will also work with Magic Ink tool.

In this example, the students will use the Ruler Tool and Calculator to find the area of the rectangle.

98 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Protractor Tool

To access the Protractor Tool, select

Tools>Maths Tools>Protractor.

When you click on the Protractor tool, click on the menu which will allow you to choose:

Type of protractor:

• Full protractor

• Half protractor

Type of Arc:

• Arc

• Closed arc

• Filled arc

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 99

Angle:

• Show/Hide Angle

Change the size of the protractor

Click on the curved edge of the protractor.

The cursor will turn into a double headed arrow.

Drag to the desired size.

Place the protractor anywhere on the flipchart or desktop

Click in the middle of the protractor.

The cursor will turn into a cross-hairs icon.

Drag the protractor to the appropriate place.

Release the click when the tool is in the location of choice.

100 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Rotate the protractor

Place your ActivPen along the center of the protractor.

The cursor will change to the rotate arrow.

The center of the protractor is at the zero mark.

Click and drag to rotate to the desired angle.

You will see the angle of rotation is displayed in the center of the protractor.

Release the click when the protractor is at the correct angle.

Draw an arc using the protractor

Choose the type of arc you wish to draw.

Select the Pen or Highlighter tool.

Choose the color and width that you desire.

Move the cursor near the top edge of the protractor.

The cursor will be displayed as a pen or highlighter.

Click and drag the pen along the outside edge of the protractor.

Release the click when you have drawn the desired segment.

ActivInspire will draw or fill the arc with the currently selected pen color.

Note: The Protractor tool will also work with the Magic Ink tool.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 101

In this activity, the Protractor and Highlighter tool are used to highlight each angle in a different color.

The angles are then moved one on top of the other. The students describe how the angles are different.

The angles are labeled and the students write a comparison statement.

102 ActivLearning Training Series

Compass Tool

To access the Compass Tool, select

Tools>Maths Tools>Compass.

When you click on the Compass tool, click on the menu which will allow you to choose:

Display

Reflected (places pen on the opposite side of the compass)

Show Angle

Show Radius

Mark Centre

Copyright 2009 Promethean. One printed copy allowed per code

Size

Increase Length

Decrease Length

Reset Length

Close

Place the compass anywhere on the flipchart or desktop

Click in the middle of the Point Arm.

The cursor will turn into a cross-hairs icon.

Drag the compass to the appropriate place.

Release the click when the tool is in the location of choice.

Rotate the compass (without drawing)

Place your ActivPen along the part of the

Pen Arm.

The cursor will change to the rotate arrow.

Click and drag to rotate to the desired angle.

You will see the angle of rotation is displayed in the center of the compass if the “Show Angle” option is selected.

Release the click when the compass is at the correct angle.

Point

Arm

Top

Center Marked

Pen Arm

Pen holder

Pen

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 103

Draw a circle with the compass

To open or close the compass points, click and drag the Pen Holder.

Select the Pen or Highlighter tool.

Select a color and width.

Place your ActivPen on the Compass Pen.

The cursor will turn into a pen.

Click and drag the pen to draw the circle.

On this flipchart page, the students will draw a circle with the radius of 4 cm.

Begin this page by reviewing the definition of radius. Students will find the appropriate size ruler. Then using the Compass tool, the students will create a circle with a radius of 4cm.

104 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

XY Origin tool

When using the Marquee Select Rotate, the object spins around its own center point by default. To select a different point of rotation, you may set a page origin point using the XY Origin tool. This allows for such activities as having the earth rotate around the sun or demonstrating math concepts.

Using the XY Origin tool to set a page origin point

To access the XY Origin tool:

Select

Tools>Maths Tools>XY Origin.

The origin point will appear on the page.

Click on the origin point and drag it to the desired position to become the new center of rotation.

Release the click.

Note: The XY Origin tool will appear at the last used position when it is turned on. When the origin point is placed on a flipchart page, the Marquee

Handles Rotate Object icon will rotate the selected object around the new center of rotation. All objects on the page will rotate, flip, and mirror based on the location of the origin point.

In the illustration when the image ‘M’ is mirrored in the Y axis, it does so based on the location of the origin point, placing it over the image identified as ‘a’.

To remove the page origin point:

• Uncheck the XY Origin tool to remove the origin point from the page.

XY Origin

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 105

106 ActivLearning Training Series

Desktop Annotation

From allowing quick access to frequently used applications and documents to copying and pasting from documents created in other applications, ActivInspire helps teachers to take full advantage of the digital resources they have.

Teachers often have access to multiple types of digital media ranging from web pages, movies and

PowerPoint

TM

to PDF’s, Word and Excel documents. This digital media can be used to create interactive lessons using copy and paste. Or, the digital media can be displayed on the Interactive Whiteboard and

ActivInspire’s tools can be used to interact with the media.

Desktop Annotation

An easy way to present existing teaching material used in your classroom is to simply present it on the ActivBoard.

Anything that you can access with your computer: web pages, Microsoft Office Applications, PDF’s or textbook material in digital format, can be shown on the ActivBoard. The ActivBoard serves as an excellent presentation tool for your existing digital media. By using ActivInspire with your digital media, you can make it much more interactive and interesting!

Use the Desktop Annotate button when you want to use ActivInspire tools, such as the Pen, Highlighter, and

Eraser tools with any application you have open on your desktop.

When Desktop Annotate is chosen, the standard ActivInspire flipchart is hidden, and a Desktop Flipchart is created. This flipchart consist of a clear transparent background, exposing the live desktop, rather than the default white background of a standard flipchart. Your current desktop is visible behind the transparent flipchart ActivInspire has created.

Copyright 2009 Promethean. One printed copy allowed per code

Open and close documents, activate web links and otherwise interact with the digital media displayed behind the Desktop Flipchart using the Select tool. All other ActivInspire tools and functions can be used on the transparent desktop flipchart in the same way as a standard flipchart.

Note: When an object is placed on the desktop flipchart, the Select tool, when moved over the object, will perform as is normal in a standard flipchart.

When a desktop flipchart is saved, only the objects created on the invisible flipchart pages will be saved. An image of the desktop underneath the desktop flipchart is not automatically captured and does not, by default, form a part of the flipchart.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 107

Creating a Desktop Flipchart

Click the Desktop Flipchart tool on the Main Toolbox or choose it from

Tools>Desktop Annotate.

The standard ActivInspire flipchart will hide.

A desktop flipchart with a transparent background will be created.

Use the Select tool to interact with the applications displayed behind the flipchart.

Use all other ActivInspire tools and functions as normal.

To return to the standard ActivInspire flipchart, click the Desktop Flipchart tool on the Main toolbox.

108 ActivLearning Training Series

Note: The background of the flipchart is transparent.

Desktop

Annotate

• The Menubar will show a tab for the desktop flipchart which was created. The default name given to this flipchart is ‘Desktop Flipchart’.

Copyright 2009 Promethean. One printed copy allowed per code

• Toggle to and from the desktop flipchart by clicking the Desktop Annotate tool or the ‘Desktop

Flipchart’ tab in the Menubar.

Use the Desktop Flipchart Tab or the Annotate Desktop Tool to toggle back and forth between a desktop flipchart and a standard flipchart.

Note: The Next Page tool will create a new page with a transparent background. Pages can be viewed in the Page Browser.

Only the objects created with ActivInspire tools will be a part of a desktop flipchart page.

A desktop flipchart can be saved in the same way as a standard ActivInspire flipchart using the

File>Save

or

Save As

. . . command.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 109

110 ActivLearning Training Series

Setting a background image to a Desktop Flipchart

The desktop can be captured as an image and inserted as a background on a desktop flipchart page.

The background will cause the Select tool to no longer interact with the Window or Mac application until the page is turned to a transparent page.

Select

Edit>Page Background.

The ‘Set Background Dialog Box’ opens.

Click the ‘Desktop Snapshot’ radio button.

Click the ‘Take Snapshot’ icon.

Click ‘Done’.

The transparent Background layer will be replaced by an image of the desktop.

Note: The transparent background has been replaced with a snapshot of the current desktop using Edit>Page

Background

Copyright 2009 Promethean. One printed copy allowed per code

Importing Files

Teaching materials come in many different formats. Activinspire provides an import function that allows you to import files from other applications such as Acrobat, Microsoft PowerPoint and SMART Notebook.

The following file types can be imported using

File>Import:

PDF

PowerPoint files

ExamView XML files

IMS QTI XML files

SMART Notebook files

SMART Gallery items

1

To import a Powerpoint file:

Choose

File>Import.

Choose from the two Powerpoint import options:

As Images

As Objects

From the ‘Select a Powerpoint File’ Dialog Box, navigate to the file you want to import.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 111

• Click Open. ActivInspire displays a progress bar and the selected file is imported to a new

‘Untitled’ flipchart.

Note: The ‘As Images’ option imports each slide of the Powerpoint as a single image. The ‘As Objects’ option allows each

object within the imported Powerpoint to be selected, manipulated and edited.

3

2

112 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

To import other file types:

Choose

File>Import.

Choose from one of the following:

• ExamView XML file

• IMS QTI XML file

SMART Notebook File (v8, v9, v9.5 v10)

SMART Gallery File

From the ‘Select a *** File’ Dialog Box, navigate to the file you want to import.

Click Open. ActivInspire displays a progress bar and the selected file is imported to a flipchart of the same name as the original file.

You can select, manipulate and edit the objects imported from the file.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 113

To import a PDF:

Choose

File>Import>PDF.

From the ‘Select a PDF File’ Dialog Box, navigate to the file you want to import.

Click Open. The ‘Import from PDF‘ Dialog Box opens.

Apply changes as desired to the options in the ‘Import from PDF’ Dialog Box.

• Page Size - Import the original page size, or change width and height as required.

Pages - Import all or a range of pages.

Import To - Choose the destination. You can choose to create a new flipchart, or add the imported page(s) to the currently active flipchart.

114 ActivLearning Training Series

• Click Import. ActivInspire displays a progress bar and the selected page(s) of the PDF is imported to the chosen destination.

Copyright 2009 Promethean. One printed copy allowed per code

Object Browser

The Object Browser allows a user to view objects on the page and to manipulate them.

To access the Object Browser from the Main Menu:

• Select

View>Browsers.

• Click on the Object Browser icon.

All the objects on the page will be listed.

The order and layer of each object will be displayed. The Browser will indicate the object type by the displaying the icon of the tool which created it next to the object’s name. Also displayed will be an indicator of objects which are hidden and/or locked.

Hidden objects

Locked objects

Note: Once an object is locked, it cannot be unlocked using the Select tool. It can be unlocked using the Object Browser

Popup Menu.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 115

116 ActivLearning Training Series

The Object Browser can be used to work with objects in the following ways:

Reorder or change the layer of objects by dragging and dropping within the Object Browser.

All objects can be locked or unlocked on the page by clicking the word ‘Locked’ at the top of the Object Browser.

Copyright 2009 Promethean. One printed copy allowed per code

• All objects can be hidden or shown on the page by clicking the word ‘Hidden’ at the top of the Object Browser.

• Edit objects within the Object Browser by selecting the object and using the Popup

Menu to make changes.

• Individual objects can be locked or hidden by selecting the desired setting on the

Popup Menu.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 117

118 ActivLearning Training Series

Locking an object to the Background layer

To lock an object to the Background layer, select the object in the Object Browser and drag it to the

Background layer.

Once an object is on the Background layer, it is no longer editable.

To remove the object from the Background layer or to edit the object, select the object in the Object

Browser and drag it to any of the other layers.

More Presentation Tools

Magic Ink

The Magic Ink tool in ActivInspire reveals hidden objects by allowing you to “see through” objects ordered below it on the top layer of the flipchart.

To access the Magic Ink Tool:

Select

Tools>Magic Ink.

Click and drag the Magic Ink tool over objects located on the Top layer of the flipchart page. It will appear that the objects are being deleted, and you will be able to view any objects that were beneath them on the Middle, Bottom or Background layers of your flipchart page.

Copyright 2009 Promethean. One printed copy allowed per code

• The Magic Ink tool does not erase or delete objects. It creates a transparent object which allows you to “see through” objects created or placed on the Top layer of the flipchart page to objects created or placed on the Middle, Bottom or Background layers.

Objects created with the Magic Ink tool are called annotations and are placed on the Top layer.

You may change the width of the Magic Ink tool by using the width slider or the preset widths.

Since the Magic Ink tool doesn’t affect objects that have not been moved to the Top layer, such as textboxes and images, it can be used in the classroom by students to uncover hidden answers or information on a page.

In this example, students can use the Magic Ink tool to reveal the structure of the inside of a volcano.

Magic Ink

Tool reveals diagram underneath

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 119

120 ActivLearning Training Series

To create this page:

Select a background from the Resource Library.

Use the Shape tool to place a rectangle on the page.

Place the rectangle on the Bottom layer.

From the Resource Library, place the volcano diagram and photo of ‘Mt Mayon’.

(

Subjects>Geography>Geology>Volcano

) on the page.

Place ‘Mt. Mayon’ on the Top layer.

Objects created with the Magic Ink tool will “look through” all items on the Top layer, allowing items below to be visible.

Note: To see the text ‘Look inside a Volcano’ it must be placed to the front of the ‘Mt. Mayon’ image on the Top layer.

In this example, students use the Magic Ink tool to make the connection by looking through the real photograph to the diagram of the components underneath.

It is important to note that the

Magic Ink creates an annotation object. This object may be selected, sized, edited and moved in the same way as an annotation created by the pen or highlighter.

Copyright 2009 Promethean. One printed copy allowed per code

Customizing Your Main Toolbox

ActivInspire provides the option for frequently used tools to be added to the Main Toolbox for easy access.

To do this, go to

Edit>Profiles>Commands.

Choose the Command you would like on the Main Toolbox.

Select ‘Add ‘and the tool icon will appear at the bottom of the right window of the Commands screen and on

Main Toolbox.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 121

To change the position of the icon on the

Main Toolbox, click on the icon on the right side of the Commands screen and select ‘Move Up’ or ‘Move Down’. You will be able to see where it is positioned by looking at the Main Toolbox in your flipchart window as you click.

To remove a Tool from the Main Toolbox, click on the icon in the right window of the

Command screen and select ‘Remove.’

When finished, click ‘Done’. Your changes will now be available in the current profile.

122 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Connector Tool

The Connector tool is used to draw connections between objects on the flipchart page. For instance, it could be used to create concept maps or to organize information into categories. The connecting line adapts automatically and keeps the objects connected when they are moved.

To activate the Connector tool:

Click on the Connector tool.

Choose a connector style from the Connector Menu.

Choose the line color from the color palette on the

Main Toolbox.

Choose the line width with the pen slider or presets.

Move to the flipchart page, press and draw the line from one object to another.

The Connect lines will be placed on the Top layer.

Note: Objects to be connected must be on the flipchart page before the

Connector tool is activated.

In this example the steps for a scientific investigation can be put into order by the students.

Choose

Connector

Style

Choose

Connector

Style

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 123

Step 1

Create objects on the flipchart page.

Step 2

Connect the objects with the proper headings.

124 ActivLearning Training Series

Copyright 2009 Promethean. One printed copy allowed per code

Step 3

Arrange the page by moving connected objects in a logical, easy to follow order.

Copyright 2009 Promethean. One printed copy allowed per code

ActivLearning Training Series 125

Index

ActivBoard

ActivClassroom

ActivInspire

ActivPen

Adding Commands to Toolbar

Annotate over the Desktop

Annotations

Automatic Annotation Grouping

Benefits

Board Maintenance

Bring Forward and Backward

Calculator

Calibrating

Camera Tool

Clear Tool

Clock

Compass Tool

Configure other Devices

Connector Tool

Creating a Flipchart

Customizing Toolbar

Dashboard

Deleting Commands from Toolbar

Design Mode

Desktop Flipchart

Desktop Flipchart as Background Image

Dice Roller

Drag a Copy

Page

82-86

102-104

14

123-125

31-33

121-122

13-14

122

30

14, 106-110

110

92-93

30-31

9

7

12

9, 10, 11, 12

121, 122

14, 106-109

20-25, 27, 119-120

27

8

9

28

94-95

11-12

54-58

25, 54, 66

Duplicate

Edit Shape Points

Editing Text

Eraser Tool

Express Poll

Fill Tool

Flipchart

Flipchart Structure

Freely-Move Object

Fullscreen

Grid Designer

Grouping objects

Highlighter Tool

Import other files

Import PDF

Import PowerPoint

Importing Resource Packs

Increase/Decrease Size

Insert page

Interface

Launching ActivInspire

Layers of a Flipchart

Locking objects

Locking to background

Magic Ink

Manipulating objects

Marquee Handles

Notes Browser

Copyright 2009 Promethean. One printed copy allowed per code

126 ActivLearning Training Series

Page

28, 70

35-36

41

25, 106

14

45-46

8

22-23

28

19

65-66

27-28

20-21

111-114

114

111-112

67-68

28

72

14, 15-19

12

22-23, 118-119

30

118

118-120

24-31

26-30, 35, 41, 105

73-75

Object Browser

Object Edit Menu

On-Screen Keyboard

Page Browser

Page Scale Options

Pen Tool

Pin View options

Profiles

Protractor Tool

Recording Sounds

Redo

Repositioning Text

Resize objects

Resource Browser

Resource Library -Activities and Templates

Resource Library-Background

Resource Library-Grids

Resource Library-Search

Resource Library-Settings

Resource Library-Sounds

Restore ActivInspire

Revealer Tool

Rotate Object

Ruler Tool

Saving a Flipchart

Select Tool

Selecting Multiple Objects

Page

63

53

64-67

48-50

51-52

59-60

42

80-81

26, 28, 35

96-98

33, 107-109

24, 26

27

115-118

28-30, 43

37-41, 42

70-72, 109

19

9-11, 20

17

14, 15-16, 21, 27, 60,

61, 62, 121

99-102

60-62

24

41

26-27

47-54

Copyright 2009 Promethean. One printed copy allowed per code

Shape Tool

Sizing Objects

Spellchecker

Spotlight Tool

Switching between the ActivInspire Studio

and Primary interface

Symbols

Text Tool

Tickertape

Toggle Group

Training and Support

Translucency Slider

Undo

View Menu

XY Origin Tool

Page

33-36

26-27

43-44

76-79

14

28

14

28

24

37-38

37

87-90

17, 19

105

ActivLearning Training Series 127

Learning objectives

Once an educator opens the door to the ActivClassroom, the

ActivClassroom is everywhere. Promethean Planet makes it possible, connecting teachers with their peers and the world through an online networking community dedicated to sharing, training, and, most importantly, support.

Exciting, ever-growing content from industry- leading curriculum and software companies

Download ActivPacks and

ActivLessons to supplement lesson planning

Available at Promethean

Planet www.PrometheanPlanet.com/shop

A complete training and support system for

ActivClassroom users

Flexible series of professional development courses available 24/7 on the web, or in person at your place or ours

Sign up for free introductory courses and in-depth workshops at Promethean Planet

Courses Include:

Introduction to ActivInspire

Migrating to ActivInspire

Core Skills

Advanced Skills Workshop

Curriculum Developer

Training & Resource Developer

Developing IWB Pedagogies www.PrometheanPlanet.com/ActivLearning

Offers teachers, publishers and developers the tools to create new products and content to interface with the ActivClassroom

Software Developer

Toolkit (SDK) offers support to innovative developer-partners, producing ever-evolving content for users

Download our SDK at

Promethean Planet www.PrometheanPlanet.com/PDN

Copyright 2009 Promethean. One printed copy allowed per code

Table of contents

Half of a million users worldwide

10,000 resources, completely free

Expand

your

ActivClassroom with low cost, time-saving

ActivPacks and

ActivLessons

Browse

lessons by subject and curriculum standard

Discover

ActivClassroom tips and tricks

Discover

online and in person training from

ActivLearning at

Promethean Planet

Learn

from the industry's foremost thought leaders

Copyright 2009 Promethean. One printed copy allowed per code

www.PrometheanPlanet.com

ActivLearning Training Series 129

Promethean

1165 Sanctuary Parkway, Suite 400

Alpharetta, GA 30009

1.888.625.2848

www.PrometheanWorld.com

Copyright 2009 Promethean. One printed copy allowed per code

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
