CUSTOM OPTIONS
WE’RE HERE TO HELP!
Customized for you
CONTACT US IF YOU HAVE
S H E L T E R D E S I G N S strives to provide an optimal home environment
ANY QUESTIONS ABOUT
or guest retreat to serve your needs for comfortable and sustainable
OUR CUSTOM OPTIONS.
living. We offer custom options for windows, walls, doors, and items
that will improve your yurt’s livability and comfort. We are happy to
work with you on any ideas you may have about customizing your yurt.
Please contact us for more details:
Call 406.721.9878 or email [email protected]
THE FOLLOWING CUSTOM OPTIONS CAN BE ADDED TO
SINGLE DOOR , SHOWN WITH SOLID
WOOD OPTION AND SCREEN DOOR
BOTH THE BIG SKY AND ECO YURT MODELS.
DOORS
Shelter Designs uses high quality solid wood or steel exterior doors for your yurt, not
plywood and plexiglass! The base price of your yurt includes a solid wood or steel door
with a half light thermal pane window. We also offer 6 panel doors with no window for
maximum security.
FRENCH DOORS
If you desire multiple entrances we can add another door. A 48” wide french door is one
of our more popular options. We also offer a full light screen door for our standard 36”
entryway and a screen curtain for the french door.
A D D I T I O N A L O R N O N - S TA N D A R D W I N D O W S
All Shelter Designs’ yurts come standard with removable, flexible 48” x 48” vinyl
REMOVABLE VINYL
windows. A removable fine mesh screen is included with every vinyl window to keep
out the smallest of insects. You can add additional windows to meet your needs.
Shelter Designs also offers an opening thermal pane glass window. Choose from 3’ x 3’,
3’ x 4’ or 3’ x 5’. This single hung window comes attractively set in its own frame and is
easily and efficiently installed. Our energy star glass windows come completely trimmed
and cased, there is no additional work required from you!
A very popular option is our 8’ screen roll up wall, with or without a clear vinyl window.
8’ WINDOW SECTION
This screen section provides maximum ventilation and views.
I N S U L AT I O N PA C K A G E & I N T E R I O R F A B R I C L I N E R
Shelter Designs’ insulation package will keep you warm in the winter and cool in the
summer. We use an effective, reflective product that has proven itself through many
extreme Montana seasons. Our wall insulation comes in a panelized form with the
insulation sewn directly to the liner material to maximize adjustability for window
GLASS WINDOWS
openings. Our roof insulation and liner are separate pieces.
S H E L T E R D E S I G N S . N E T | 406.721.9878 | [email protected]
A R C T I C I N S U L AT I O N
THIS IS A SHELTER DESIGNS’ EXCLUSIVE FEATURE, offering comfort and warmth
for the most extreme weather environments. Our Arctic Insulation package adds 1/2”
thick flexible foam to our regular insulation package. Boost your R-value by adding
Arctic Insulation to your yurt.
INSULATION OFFERED:
STANDARD AND ARCTIC
SNOW & WIND KIT
The snow and wind kit consist of upright supports under each roof rafter, and a cable
blocking system in the rafters. The upright supports are attached to the rafters, lattice
and floor. These structural components increases the yurt’s ability to withstand extreme
load conditions. Rafter size can be increased up to a 2x10 for extreme loading situations.
By increasing rafter size along with the snow and wind kit, we offer the highest snow
load ratings in the industry.
SNOW AND WIND KIT TAILORED TO
MEET YOUR ENVIRONMENTAL NEEDS
R O O F FA B R I C O P T I O N S
CHOOSE BETWEEN TWO QUALITY, VINYL-COATED FABRICS
All choices come in a wide variety of colors. Please contact us for samples!
• ProShield is our standard roof fabric and carries a 8-year warranty.
• Duro Last is our premier roof fabric and carries a 15-year warranty.
WA L L FA B R I C O P T I O N S
LONG LASTING FABRICS STAND UP
AGAINST WIND AND WEATHER
CHOOSE BETWEEN TWO QUALITY EXTERIOR FABRICS
All choices come in a wide variety of colors. Please contact us for samples!
• Starfire: our standard wall covering is an acrylic top-coated polyester. It carries a
5-year warranty and has sewn seams.
• Star800: our premier wall fabric is a vinyl-coated polyester. It carries an 8-year
warranty, offers easy cleaning, and has welded seams.
EASY TO INSTALL, REPLACE AND REPAIR
B O T T O M H O O K A N D L O O P AT TA C H M E N T
Every Shelter Designs yurt wall comes with grommets spaced every foot around the
bottom of the exterior wall to securely anchor the fabric to the floor frame. Take the next
step to fully seal the bottom of your wall and keep out stray drafts and those creepy
crawlies! This SD exclusive feature connects the wall to the floor frame with 2” hook and
loop around the entire bottom perimeter, providing the ultimate seal from the elements.
ADD AESTHETIC PROTECTION WITH
OUR BOTTOM BAND OPTION
BOTTOM SPLASH BAND
Spruce up the look of your yurt while adding extra protection from splashing water and
snow accumulation! This 18” band of Duro-Last is welded to the bottom of your exterior
wall, adding an attractive look and practical protection from the elements.
STOVEPIPE FLASHING KIT
Our easy to install flashing kit will be made to fit the size of pipe that you need (up to 8”
WE CAN BUILD CUSTOM FLASHING OR
ANY VENTILATION/HEATING SYSTEM
in diameter). Easily vent your wood, pellet or gas stove through the sidewall of the yurt.
I N S U L AT E D C O N N E C T I N G T U N N E L S
Connect any yurts together with our insulated tunnel for a multi yurt living environment.
W AT E R C AT C H M E N T S Y S T E M
This feature offers fabric gutters that are attached with grommets to the sidewall of your
yurt. Bulkhead fittings are installed to easily connect downspouts to a cistern. Catch the
INSULATED MATCHING HALLWAY
rainwater off your yurt roof for all of your non-potable water needs.
CENTER RING SCREEN INSERT
Maintain a bug free environment in your yurt while still benefiting from an open skylight
for maximum ventilation.
DOME OPENER & TINTED DOME
These are our most popular options. Opening the skylight allows for maximum
COMPRESSION RING
ventilation, drawing hot air out of your living space. The tinted dome provides a
significant shield from the hot sun, keeping your yurt cooler, while still providing a
view the blue sky, white clouds, and trees.
S TA I N L E S S S T E E L H A R D W A R E
Upgrade your hardware to stainless steel for extreme maritime conditions.
BANNER SYSTEM
DOME OPENER FOR VENTILATION
Advertise your business on your yurt! Your name and logo can be placed on the valance
or roof for maximum visibility. One color and up to 5’ x 5’. Contact us for more details.
I N S U L AT E D W I N D O W C O V E R I N G S
These window coverings will maximize the efficiency of your yurt’s insulation in
G I V E U S A C A L L TO
DISCUSS WHAT OPTIONS
WILL BEST SUIT YOUR
extremely cold climates.
FA N M O U N T
Keep the air circulating in your yurt by installing a ceiling fan. This attractive mount has
an electrical box mortised into it for mounting most types of ceiling fans.
INDIVIDUAL YUR T NEEDS.
C AT P O L E ( C ATA S T R O P H I C S I T U AT I O N P O L E )
406.721.9878
This is a central pole designed to support the roof in extreme loading conditions.
This option is ideal when the yurt is mostly unoccupied or is not maintained during
harsh winter conditions. Please call to see if this option is right for you.
CONNECT WITH US
101 North Johnson Street | Missoula, MT 59801
406.721.9878 | shelterdesigns.net | [email protected]
L E A R N M O R E on our YouTube Channel: Shelter Designs Yurts
