“Patriot” Series USA Made Outdoor LED Lighting

APPLICATIONS

The RDISE LED is a specification grade, Volumetric Recessed LED Luminaire which provides smooth and uniform ambient lighting for all commercial and industrial buildings with recessed configurations. Reflected light from matte surfaces provide a softened appearance to the modern office environment.

FEATURES & BENEFITS

s

Volumetric recessed luminaire provides a low glare light source s

Matte white reflective surface for soft, uniform light distribution s

0-10V dimming driver standard s

Easy access plate for quick wiring s

ETL Listed for damp locations

Series RDISE LED

LED Volumetric Recessed Luminaire

SPECIFICATIONS

Housing is die-formed and embossed code 22 gauge steel. Luminaire body finish is high reflectance baked white enamel, with matte white reflectors. Wiring knockouts are provided on the back of housing. Center diffuser snaps into place; no tools are required for removal.

ORDERING DATA

EXAMPLE: RDISE24-LED48FRDMV40

RDISE

Series

RDISE

Family

Blank

Standard

VL

Value

Line

14

22

24

Size

1x4

2x2

2x4

Gear

LED

* Emergency Drivers may be remote mounted on 2x2 fixtures

Lumens are subject to a tolerance of ±10%

Wattage is approximate and subject to a tolerance of ±5%

Wattage / Lumens

1x4 & 2x4 Value Line

45

45 Watts 5000 Lumens

15

1x4 Standard

15 Watts 1880 Lumens

24

24 Watts 3145 Lumens

30

30 Watts 4015 Lumens

35

35 Watts 4580 Lumens

40

40 Watts 5140 Lumens

48

48 Watts 6025 Lumens

57

57 Watts 7020 Lumens

2x4 Standard

15

15 Watts 1990 Lumens

20

20 Watts 2565 Lumens

23

23 Watts 3145 Lumens

25

25 Watts 3440 Lumens

28

28 Watts 3805 Lumens

30

30 Watts 4095 Lumens

35

35 Watts 4535 Lumens

40

40 Watts 5245 Lumens

48

48 Watts 6155 Lumens

57

57 Watts 7210 Lumens

2x2 Standard

15

15 Watts 1599 Lumens

18

18 Watts 2115 Lumens

20

20 Watts 2535 Lumens

24

24 Watts 3015 Lumens

30

30 Watts 3605 Lumens

Diffuser

FR

Frosted Lens

Driver Type

Color Temp

DMV

120-277VAC

0-10V

Dimmable

FIDMV

120-277VAC

Factory installed

0-10 V Dimming

SDMV

120-277VAC

Step Dimmable

100%-40%

30 3000K

35

50

3500K

40 4000K

5000K

Options

EM

Emergency Battery Pack

10W ~1300 Lumens

EM4F

Emergency Battery Pack

4W ~450 Lumens

EM5

Emergency Battery Pack

5W ~650 Lumens

EM7

Emergency Battery Pack

7W ~900 Lumens

SS

Occupancy Sensor

Internal Microwave

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 11/22/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

1x4 VIEW

Series RDISE LED

LED Volumetric Recessed Luminaire

2x2 VIEW

2x4 VIEW

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 11/22/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RGLED

LED Recessed Grid Troffer

APPLICATIONS

Premium quality low profile troffer with an almost limitless range of applications.

Ideal for all commercial and industrial buildings requiring general illumination with recessed configurations.

FEATURES & BENEFITS

s

Min 80 CRI s

Corrosion and scratch resistant s

Smooth edges for easy handling s

Ends are secured by snap-in interlocking system s

.100 acrylic prismatic lens is standard s

Exclusive “Light Lock” frame reduces light leaks s

Flush steel door with rotary action cam latches and hinges from either side s

Easy access plate for quick wiring s

Equipped with Integral Earthquake Clips s

ETL

listed for damp location s

DLC listed in certain models - consult DLC QPL for verification

SPECIFICATIONS

Housing is die-formed and embossed from cold rolled steel. Wiring access plate and knockouts are provided on back of housing allowing for flexible greenfield attachment. Driver cover snaps easily into place eliminating the need for tools when accessing the driver. Prismatic lens is held within a hinged steel frame door. The heavy gauge door frame hinges downward on either side and is held in the closed position by two positive cam latches. Knockouts are provided on ends for continuous wiring. Listed by and bears ETL label.

ORDERING DATA

EXAMPLE: RG22-LED35DMV40

RG

Series

RG

LED Grid

Notes:

14

22

24

Size

1x4

2x2

2x4

Gear

LED

1. Consult factory for Triac Dimming Options.

DLC Listed

RG22-LED20DMVxx xx=30,35,40,50

RG22-LED24DMVxx

RG22-LED28DMVxx

RG22-LED35DMVxx

RG22-LED45DMVxx

RG24-LED35DMVxx

RG24-LED45DMVxx xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=35,40,50 xx=30,35,40,50 xx=30,35,40,50

RG24-LED48DMVxx

RG24-LED52DMVxx

RG24-LED52FRDMVxx

RG24-LED57DMVxx xx=30,35,40,50 xx=35,40 xx=35,40 xx=30,35,40,50

Wattage & Lumens

Standard 1x4

22 22 Watts 2810 Lumens

30 30 Watts 3585 Lumens

35 35 Watts 4090 Lumens

40 40 Watts 4590 Lumens

48 48 Watts 5385 Lumens

57 57 Watts 6370 Lumens

Standard 2x2

20 20 Watts 2300 Lumens

24 24 Watts 2600 Lumens

28 28 Watts 3000 Lumens

35 35 Watts 3600 Lumens

45 45 Watts 4470 Lumens

Standard 2x4

32 32 Watts 3970 Lumens

35 35 Watts 4345 Lumens

45 45 Watts 4765 Lumens

48 48 Watts 5900 Lumens

52 52 Watts 5300 Lumens

57 57 Watts 6735 Lumens

62 62 Watts 7000 Lumens

Driver Type

1

DMV 120-277VAC

Multivolt

0-10V Dimming

FIDMV 120-277VAC

Input Factory

Installed

0-10V Dimming

SDMV Step dimming

Multivolt

Dimensions and specifications subject to change without notice.

30

35

40

50

Color Temp

3000K

3500K

4000K

5000K

Options

See Below

Options

EM

EM5

EM7

EM12K

Blank

125

156

CL

CL125

SW

S5

S75

S15

W5

NL

NFL

FR

G3

FA

10W, 1300 lumen, battery backup

5W, 650 lumen, battery backup

7W, 900 lumen, battery backup

1200 Board Lume LED Emergency Kit

A12 .100 think lens

A12 .125 thick lens

A19 .156 thick lens

Clear .100 thick lens

Clear .125 thick lens

Smooth White .100 thick lens

Specular Parabolic Louver (1/2”x1/2”x3/8”)

Specular Parabolic Louver (3/4”x3/4”x3/8”)

Specular Parabolic Louver (1 1/2”x1 1/2”x1”)

White Parabolic Louver (1/2”x1/2”x3/8”)

No Lens

No Frame and Lens

High Optic Frosted

Triple Gasketing

Flush Aluminum

800-444-WATT

REV 11/01/16 www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

DIMENSIONS

TOP VIEWS

SERIES RGLED

LED Recessed Grid Troffer

MODEL

CONFIGURATION

1’ x 4’

2’ x 2’

2’ x 4’

A

12”

23 3/4”

23 3/4”

SIDE VIEW

47 7/8”

23 3/4”

47 3/4”

B

3 3/4”

END VIEW

9”

2.38”

3 3/4”

19.5”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 11/01/16

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MFPEL

LED Edgelit Flat Panel

t t t t t t t t t t t t t t t t t t t t t t

APPLICATIONS

The Mobern MFPEL Edge Lit LED Flat Panel is a cleanly designed, high brightness lighting panel, made with high performance LED chips. This panel is ideal for replacing traditional fluorescent fixtures and is simple to fit and install. The MFPEL Edge Lit LED Flat Panel is a perfect choice for many applications including commercial, industrial, healthcare, hospitality and many more.

FEATURES & BENEFITS

SPECIFICATIONS

Housing is white aluminum that is sealed and Non-IC type fixture. Lens is evenly diffused frosted material. The driver is a Class 2 compliant design, featuring low voltage, limited power and is capable of 0-10V dimming as standard. Fixture is 80CRI minimum, multiple color temperatures, sizes and wattages are available. 5 year limited system warranty. Listed by and bears cULus label.

ORDERING DATA

MFPEL

EXAMPLE: MFPEL22-LED35DMVWH40

Series

MFPEL

LED Slim

Flat Panel

14

22

24

Type

1 x 4

2 x 2

2 x 4

Gear

LED

DLC Listed

MFPEL14-LED37DMVWHxx xx=30,35,40,50

MFPEL14-LED35DMVWHxx xx=30,35,40,50

MFPEL14-LED54DMVWHxx xx=30,35,40,50

MFPEL14-LED50DMVWHxx xx=30,35,40,50

MFPEL14-LED75DMVWHxx xx=35,40,50

Wattage/Lumens

1x4 only

37 37 Watts 3630 Lumens

2x2 only

35 35 Watts 4000 Lumens

54 54 Watts 4860 Lumens*

2x4 only

50 47 Watts 5245 Lumens

75 75 Watts 6850 Lumens*

*Special Order

Driver

DMV 120-277VAC

Dimming Multivolt

0-10V

Frame Color

WH White

Color Temperature

30

35

40

50

3000K

3500K

4000K

5000K

ACCESSORIES: Sold Separately

Surface Mounting Kits:

(sold separately)

SMKT14-MFPEL - 1x4

SMKT22-MFPEL - 2x2

SMKT24-MFPEL - 2x4

Consult for other options.

DIMENSIONS:

1x4 - 300mm x 1200mm x 12mm + Driver (11.8” x 47.25” x 0.5”)

2x2 - 600mm x 600mm x 12mm + Driver (23.625” x 23.625” x 0.5”)

2x4 - 600mm x 1200mm x 12mm + Driver (23.625” x 47.25” x 0.5”)

Driver - 10.625” x 3.0” x 1.7”

Wiring Diagram

To LED

Boards

To Dimmer +

(Purple)

To Dimmer +

(Gray)

V+ (Red)

V+ (Black)

DIM + (Brown)

DIM + (Yellow)

Not all color temperatures and wattages are stocked.

Dimensions and specifications subject to change without notice.

Consult factory for EM

Black ACL

White ACN

Hanging Kit:

A-MFPEL-Cable kit 35 inches - aircraft cable kit

Shroud for surface mounting

800-444-WATT

REV. 10/06/2016 www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES FHBCLED

LED Premier High Bay

APPLICATIONS

The FHBC LED is a high efficiency premier high bay fixture engineered for premium performance. A precision-formed reflector system available in enhanced white reflector is designed to achieve maximum light output for ceilings from 15 feet to 40 feet. Based on ceiling height, these fixtures can replace a fluorescent or traditional HID high bay while using up to 50% less energy. Pendant, chain or stem mounting are available. The fixture is ideal suited for warehouses, manufacturing plants, sports facilities and retail spaces.

FEATURES & BENEFITS

s

0-10V Dimming Driver standard s

Pendant,stem or chain hanging available s

Options and accessories include: Wireguard, lens, occupancy sensors, emergency packs and more s

DLC Model: FHBC-48LEDH118DMV50 s

L70 >60,000 hrs.

s

80+ CRI s

ETL Listed

SPECIFICATIONS

Housing is 22 gauge pre-painted steel. High reflective enhanced white reflectors are computer designed to maximize photometric performance and put the light where you need it. Access plate in the back makes wiring fast and hassle-free. Back of fixture is designed with built in mounting holes for tong hanger or cable kit. The fixture is not designed to be surface mounted to the ceiling or wall. Integral Occupancy Sensor is optional and is ideal for wire guard applications.

ORDERING DATA

EXAMPLE: FHBC24LED48DMV40

FHBC

Series

FHBC

LED Premier

High Bay

Size

24 24” Length

48 48” Length

Gear

LED

Wattage & Lumens

High Performance

24”

48 48 Watts

57 57 Watts

72 72 Watts

90 90 Watts

100 100 Watts

118 118 Watts

6400 Lumens

7640 Lumens

10440 Lumens

12060 Lumens

48”

97 97 Watts

100 100 Watts

114 114 Watts

H118 H118 Watts

144 144 Watts

166 166 Watts

180 180 Watts

208 208 Watts

270 270 Watts

352 352 Watts

13480 Lumens

16600 Lumens

10440 Lumens

13480 Lumens

14900 Lumens

16600 Lumens

19500 Lumens

22710 Lumens

24120 Lumens

29300 Lumens

36180 Lumens

47440 Lumens

Driver Type

DMV 0-10V Dimming

Multiviolt

120-277VAC

D480TF 480V with transformer

0-10V Dimming

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

Options & Accessories

See Options and

Accessories

Section

Wattage and Lumens are calculated at 25°C

ambient temp and 5000K.

A tolerance of ± 10% is standard for both wattage and lumens.

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Drive, Ste. 500. Jessup, MD 20794

Rev. 11/18/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES FHBCLED

LED Premier High Bay

SUPER HIGH PERFORMANCE 150+ LPW

FHBC

ORDERING DATA

EXAMPLE: FHBC242R-LEDSH48DMV30

Series

FHBC

LED Premier

High Bay

Size

24 24” Length

48 48” Length

TECHNICAL INFORMATION

OPTIONS-Factory Installed

EM5

EM7

EM

EM12

OS

OSD

DH

CS

CS8

CS12

CS8TL277

WP

WP12

WG

5 Watts, 800 Lumens Battery Backup

7 Watts, 1100 Lumens, Battery Backup

10 Watts, 1600 Lumens Battery Backup

12 Watts, 1900 Lumens, Battery Backup

Occupancy Sensor - On/Off

Occupancy Sensor w/Dimming

Daylight Harvesting

6ʼ Cord 18/3

8ʼ Cord 18/3

12ʼ Cord 18/3

8ʼ Cordset 277V, 3-WIRE, NEMA L7-15P

6ʼ Whip-MC

12ʼ Whip-MC

Wraparound Wire Guard

Wattage & Lumens

24”

4R-LEDSH48

4R-LEDSH57

6R-LEDSH87

8R-LEDSH121

48 Watts

57 Watts

87 Watts

121 Watts

48”

7400 Lumens

8600 Lumens

13050 Lumens

18220 Lumens

3R-LEDSH87

4R-LEDSH121

5R-LEDSH131

6R-LEDSH161

8R-LEDSH195

8R-LEDSH230

87 Watts

121 Watts

131 Watts

161 Watts

195 Watt

s

230 Watts

13050 Lumens

18220 Lumens

20030 Lumens

24290 Lumens

30030 Lumens

34500 Lumens

Wattage and Lumens are calculated at 25°C

ambient temp and 5000K.

A tolerance of ± 10% is standard for both wattage and lumens.

Driver Type

DMV 0-10V Dimming

Multiviolt

120-277VAC

D480TF 480V with transformer

0-10V Dimming

ACCESSORIES

L1080

A-FHBC6WG

L1080-2ft

FHBC Lens Wraparound for 48” Body

Wireguard - No door frame

FHBC Lens Wraparound for 24” Body

MOUNTING

A144-XX

AC120-Toggle-2pk

AC180-Toggle-2pk

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

Footage - Tong hangers, End Mount (Pair) with footage of chain (xx=footage of chain) yhook - 10’ Cable Mounting Kit and 2 Spring Clips yhook - 15’ Cable Mounting Kit and 2 Spring Clips

Options & Accessories

See Options and

Accessories

Section

.312

1.88”

11.08”

3.62”

6.31

35.44”

16.39”

48.06”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Drive, Ste. 500. Jessup, MD 20794

Rev. 11/18/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES LHBIP

LED High Bay High Performance

APPLICATION

The LHBI LED is a high efficiency I-Beam style high bay fixture engineered for premium performance. A precision-formed silver reflector is designed to achieve maximum light output for ceilings from 15 feet to 40 feet.

Based on ceiling height, these fixtures can replace a fluorescent or traditional HID high bay while using up to 50% less energy. Surface or chain mounting systems are available. The fixture is ideally suited for warehouses, manufacturing plants, sports facilities and retail spaces.

FEATURES & BENEFITS

s

22 Gauge White Steel Vented Housing s

Chain kit included s

Environmentally Friendly - Mercury Free s

Rated at 50,000 hrs of L70 Life s

RoHS Compliant s

5 Year Limited Warranty s

High Power Factor s

L70>50,000 hrs; L90>36,000 hrs s

ETL Listed s

DLC Premium Listed

SIZE

110W - 11.80W x 21.50L x 2.00H

170W - 16.00W x 21.50L x 2.00H

230W - 11.80W x 43.00L x 2.00H

SPECIFICATIONS

Housing is 22 gauge prepainted steel. Air vents surround the drivers in the back of the fixture to maximize LED and driver performance, reliability and life. Highly efficient silver reflectors are compter designed to maximize photometric performance and put the light where you need it. Back access plate allows for fast and hassle-free wiring. Back of fixture is designed with built-in mounting holes for tong hangers, cable kit, or surface mounting ( with additional brackets). Chain kit included. 5 year limited system warranty. ETL Listed.

MOUNTING OPTIONS

Designed for surface or chain hanging. Mounting holes are provided for simple fast installation. Chain kit included.

ORDERING DATA

LHBIP LED MV

EXAMPLE: LHBIP-LED230MV50

Series

LHBIP

Gear

LED

Wattage / Lumens

110 110 Watts 14,680 Lumens

170 165 Watts 22,020 Lumens

230 220 Watts 29,370 Lumens

Driver

MV 120-277VAC

Color Temp

40 4000K

50 5000K

EM

OS

ACCESSORIES

FL-LHBI2x4-MW Door frame and matte white lens

FL-LHBI2x2-MW Door frame and matte white lens

FL-LHBI1x2-MW Door frame and matte white lens

A-LHBI2x4-WG Wireguard

A-LHBI1x2-WG Wireguard

A-LHBI1x2-WG Wireguard

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 09/17/2016

CAT#

JOB NAME

Options

10 Watt Emergency

Pack

Occupancy Sensor

TYPE

© 2008-16 Mobern Lighting Company

Lens Installation Instructions:

SERIES LHBIP

Premiere LED High Bay

Installation Steps:

1. Take out the door frame (1), put the poles (2) through the holes (3), secure it to the fixture body with thumb screw (4) and nuts (5)

2. The same way to install the other door frame. See fig 2 when installation is completed.

A-LHBI1x2WG:

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 09/17/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

A-LHBI2x4WG:

A-LHBI2x2WG:

SERIES LHBIP

Premiere LED High Bay

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 09/17/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MLHB LED

LED Illuminator High Bay

t t t t t t t t t t t t t t t t

APPLICATIONS

Introducing our LED industrial high bay fixtures styled to match conventional HID high bays.

These fixtures not only provide great glare free, wide area lighting, but also provides a stylish and modern industrial look.

FEATURES & BENEFITS

SPECIFICATIONS

High purity aluminum alloy housing for reduced weight. Excellent thermal conductivity and fast cooling. Very low lumen deprecation and high light purity with a choice of 45 degree beam angle or a 90 degree beam angle.

ORDERING DATA

MLHB LED MV

Series

MLHB

Gear

LED

Wattage & Lumens

60 60 watts 4650 Lumens

100 100 watts 9950 Lumens

150 150 watts 13500 Lumens

200 200 watts 19300 Lumens

ALUMINUM REFLECTOR

Driver Type

MV 120-277V

50

EXAMPLE: MLHBLED60MV50C

Color Temperature

50 5000K

Reflector Type

C

D

CLD

FRD

ALD

Cone (45°)

Dome (90°)

Clear Dome

Frosted Dome

Faux Alabaste Dome

DLC Listed

MLHBLED60MV50C

MLHBLED100MV50C

MLHBLED150MV50C

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 08/31/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MLHB LED

LED Illuminator High Bay

ACRYLIC REFLECTORS

GENERAL DESCRIPTION

The acrylic reflectors are a remote optic intended for use with POD style LED highbays and induction sources. Unlike traditional reflectors, it is shallow so as to allow high beam angles. Its large flat top allows it to be easily adapted to most any fixture without the need for expensive collars. The lower flange mimics traditional reflectors allowing for a wide range of bottom lenses and standard clamp bands.

t t t yet low profile appearance t maximum brightness control t t

Conical Drop lens and flat lenses. Bottom lenses are primarily for lowbay applications where brightness control is paramount. Bottom lenses also enhance uplight.

DIMENSIONS

9”H x 16”Diameter

ACCESSORIES/OPTIONS

A-MLHB816CDL: Conical Drop Lens

A-MLHB816SFL: Smooth Flat Lens

A-MLHB816CB: Clamp Band

A-MLHB816WG: Wire Guard

A-MLHB816TDL: Tapered Drop Lens

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 08/31/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

44 SERIES

LED Premium Channel

APPLICATIONS

Premium grade LED strip fixture. For use in indoor applications such as factories, warehouses, workshops, utility areas, coves and public buildings where industrial grade, ultimate energy savings is required.

FEATURES & BENEFITS

s

Snap-on components for easy assembly and maintenance s

Versatile end plate doubles as coupler for continuous row mounting s

Available in 24”, 48”, and 96” (2’, 4’, & 8’ lengths). Consult for 3’ and 6’ s

Surface, stem or chain mountable s

CRI 80+ s

ETL Listed for damp location s

Made in USA s

DLC listed in certain models

SPECIFICATIONS

Housing is die-formed from cold rolled steel. Finish is high reflectance baked white enamel. Single wireway cover on non-tandem units. Knockouts are provided for flexible conduit attachment. Knockouts are provided for stem mounting. Mounting holes are provided.

44

ORDERING DATA

LED

EXAMPLE: 44-48LED48DMV40

Series

44

LED Premium

Channel

Length

24 24”

48 48”

96 96”

Consult for 3’ & 6’

Gear

LED

DLC Listed

44-48LED28DMVxx xx=30

44-48LED32DMVxx

44-48LED48DMVxx

44-48LED57DMVxx

44-48LED61DMVxx

Wattage / Lumens

2 ft.

24 24 Watts 2800 Lumens

28 28 Watts 3200 Lumens

4 ft.

32 32 Watts 4050 Lumens

48 48 Watts 5650 Lumens

57 57 Watts 6400 Lumens

61 61 Watts 6850 Lumens

8 ft.

48 48 Watts 5650 Lumens

61 61 Watts 6850 Lumens

97 97 Watts 11300 Lumens

114 114 Watts 12800 Lumens

Driver*

DMV Dimmable

120-277VAC

0-10V

SDMV Step Dimming

120-277VAC

100%-40%

*Consult for Triac dimming

Color Temperature

30 3000K

35 3500K

40 4000K

50 5000K

Options

LR Lens ready

(Lens must be ordered on

separate line)

WP 6’ Whip 3 Wire

EM Emergency Battery Pack

10W ~1300 Lumens

EM7 Emergency Battery Pack

7W ~900 Lumens

EM5 Emergency Battery Pack

5W ~650 Lumens xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=30

DIMENSIONS ACCESSORIES

A69 - Wireguard per 4 ft.

A144 - (2) V-Hook & (2) 2 ft chain

L1085 - 4 ft. (Order 2 for tandem)

M39-LED - (ends to add lens; need

2 per fixture)

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 10/24/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES 770

LED Premium Specification Wraparound

APPLICATIONS

Economically designed narrow wraparound provides reliable and efficient lighting.

Ideal for use in indoor applications such as homes, modular homes, mobile homes, stores and public building where low glare and ease of installation is required.

FEATURES & BENEFITS

s

0-10V Dimming Driver standard s

Corrosion and scratch resistant s

Nominal 9” width with a shallow design s

Clear acrylic diffuser with prismatic bottom and ribbed linear sides s

Diffuser self-aligns and hinges from either side for easy maintenance s

Available in lengths from 24 to 48 inches - (2’ & 4’ lengths) s

Single or continuous row mounting capability s

Surface, stem or chain mountable s

ETL Listed for damp location

SPECIFICATIONS

Housing and ends are die-formed and embossed from cold rolled steel. Inspection knockouts provided for mounting to junction box. Driver cover snaps into place eliminating the need for tools when accessing. Diffuser hinges from either side in a lift and shift manner and is self-centering. End caps may be butted together for continuous row mounting. Knockouts are provided for stem mounting.

770

ORDERING DATA

EXAMPLE: 770-48LED48DMV40

Series

770

LED Premium

Wrap

24

48

Nominal Size

24 inch

48 inch

Gear

LED

Wattage & Lumens

24”

23 23 Watts 2650 Lumens

28 28 Watts 2950 Lumens

35 35 Watts 3800 Lumens

48”

23 23 Watts 2650 Lumens

35 35 Watts 3800 Lumens

48 48 Watts 5100 Lumens

56 56 Watts 6000 Lumens

Driver Type

DMV Dimming

Multivolt

120-277V

0-10V

1

FIDMV 120-277V Input

Factory installed

0-10 V Dimming

Notes:

1.Consult factory for step dimming and

Triac dimming options

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

Options

WP 6’ whip, 3 wire

EM 10W, 1200 Lumen

Battery backup

EM5 5W, 600 Lumen

Battery backup

EM7 7W, 840 Lumen

Battery backup

DLC Listed

770-48LED23DMVxx xx=30,35,40,50

770-48LED35DMVxx

770-48LED48DMVxx

770-48LED56DMVxx xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 06/27/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES VW

LED Vaportight

APPLICATIONS

Introducing the Mobern VW-LED Premium grade enclosed and gasketed vaportight fixture. This Energy-Saving High Performance

LED Vaportight is ideal for both indoor and outdoor applications where dust and water resistance is required. Ideal for parking garages, cold storage, marinas, barns, canopies, car washes, poultry farms, agricultural applications and other areas susceptible to corrosive and wet conditions.

FEATURES & BENEFITS

t t

Designed for easy assembly t t

Ease of Installation and Maintenance t t

Visually familiar light sourcing t t

Poured in place gasket seals the enclosures from most hostile t environments t

Economical Mounting System can provide dramatic savings on installation labor, thus reducing costs t t

Very tough diffusers resist breakage and reduce replacement and t maintenance costs t

Available in 2’, 4’ & 8’ lengths. t t

Frosted lens for reducing direct glare and image of the LED t t

Optional durable stainless steel mounting hardware t t

No need to drill through the housing for installation t t

Optional stainless steel bail for chain/cable hung installations t t

CRI-Min 84 t t

Calculated Life: L70 >93,000 hrs t t

ETL listed for wet location t t

Consult for other options t t

DLC listed in certain models

SPECIFICATIONS

High quality enclosed fiberglass fixture features a unique continuous poured gasket which completely fills channel for maximum seal integrity. Diffuser is held in place with POM retaining latches. Stainless steel latches are recommended for the following applications: agriculture, car washes. food processing and swimming pools. Hole is 7/8” diameter and is provided with a plastic plug on one end for conduit attachment. Offset mounting pads which keeps luminaire level and slightly off of mounting surface are formed within the housing. Standard diffuser is high impact acrylic with textured pattern designed for high efficiency while providing reduced glare. Listed by and bears ETL label.

ORDERING DATA

EXAMPLE: VW2WDLED28DMVSF40

VW LED

Series

VW

LED

Vaportight

Length

2’

4’

8’

Distribution

Blank Std.

WD Wide

Fixture

LED

Wattage & Lumens

2 Ft

24 24W 2700 Lumens

28 28W 3300 Lumens

35 35W 4200 Lumens

4 Ft

23 23W 3160 Lumens

35 35W 4500 Lumens

48 48W 5570 Lumens

57 57W 6790 Lumens

8 Ft

48 48W 5570 Lumens

70 70W 9000 Lumens

97 97W 11140 Lumens

114 114W 13580 Lumens

Lens Material

Blank High Impact

Acrylic

P Polycarbonate

Voltage

DMV 120-277V

Multivolt

0-10V Dimmable

FIDMV 120-277V

Factory installed

0-10 V Dimming

Lumens are subject to a tolerance ±10%

Wattage is approximate and subject to a tolerance of ±5%

Dimensions and specifications subject to change without notice.

800-444-WATT

REV 9/20/2016 www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

CAT#

JOB NAME

Lens

RF

RC

SF

SC

SSF

Ribbed Frosted

Ribbed Clear

Smooth Frosted

Smooth Clear

SSC

Shallow, smooth frosted*

Shallow, smooth clear*

* 4 ft only

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

CS

OS

OSW

OSD

SS

PC120

PC277

EM

EM4F

EM5

EM7

Options

Cord 18/3 6”

Occupancy Sensor

Occupancy Sensor - Wet

Location

Occupancy Sensor -

0-10V Dimmable

Occupancy Sensor -

Internal Microwave

Photocell 120V

Photocell 277V

Emergency Battery Pack

10W ~1300 Lumens

Emergency Battery Pack

4W ~450 Lumens

Emergency Battery Pack

5W ~650 Lumens

Emergency Battery Pack

7W ~900 Lumens

TYPE

© 2008-16 Mobern Lighting Company

SERIES VW

LED Vaportight

Side View

DIMENSIONS

4’ = 13.2 mm =51.85”

End View

56.8 mm

2.236”

172 mm

8.77”

ACCESSORIES

Clips and Hangers Accessories

SSF Lens

SSC Lens

4.13”

6.40 in

6.77”

7.33”

RC

RF

SC

SF

DLC Listed

VW4-LED23DMVSSFxx

VW4-LED35DMVSSFxx

VW4-LED48DMVSSFxx

VW4-LED57DMVSSFxx xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 t t t t t t t t t t t bracket t t t t bracket w/bail t t t hanging)

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 9/20/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

155LED SERIES

Ceiling/Wall Mount Luminaire

APPLICATIONS

Stylish ceiling/wall mounted luminaire in either white or walnut finish with a variety of LED combinations and sizes enhanced by linear sided acrylic diffuser. Designed for baths, kitchens, rec rooms, corridors, aisles, stairwells, over or beside mirrors, over bulletin boards, in vanities, in displays.

FEATURES & BENEFITS

s

Back plate provided with adequate knockouts and mounting holes for either wall or ceiling installation s

Enhanced by linear sided acrylic diffuser s

White with a variety of LED combinations s

Overlapping end caps for uniformity and dimensional stability s

Made in USA s

CRI 80+ s

ETL Listed for damp locations

SPECIFICATIONS

All metal parts are die formed from heavy gauge cold roll steel with overlapping end caps.Diffuser is a linear sided prismatic lens of extruded acrylic for controlled light.

155

ORDERING DATA

LED

EXAMPLE: 155-24LED24DMVWH40

Series

155

Size

24 24 inches

48 48 inches

Gear

LED

Wattage /Lumens

2 ft.

24 24 Watts 2900 Lumens

28 28 Watts 3400 Lumens

4 ft.

30 30 Watts 4065 Lumens

48 48 Watts 5985 Lumens

57 57 Watts 6855 Lumens

Driver Type*

DMV Dimmable

120-277VAC

0-10V

SDMV Step Dimming

120-277VAC

100%-40%

*Consult for Triac dimming

Finish

WH White

(Standard)

**Consult factory for other finish options

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

Options

WP 6’ Whip 3 Wire

Consult factory for other options

DLC Listed (4 ft DMV only)

155-48LED30DMVWHxx XX=30, 35,40, 50

155-48LED48DMVWHxx

155-48LED57DMVWHxx

XX=30, 35,40, 50

XX=30, 35,40, 50

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 11/072016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES VW4LB-PG LED

LED Vaportight

APPLICATIONS

Introducing the Mobern VW-LED Premium grade enclosed and gasketed vaportight fixture. This Energy-Saving High Performance

LED Vaportight is ideal for both indoor and outdoor applications where dust and water resistance is required. Ideal for parking garages, cold storage, marinas, barns, canopies, car washes, poultry farms, agricultural applications and other areas susceptible to corrosive and wet conditions.

FEATURES & BENEFITS

t t t t t t t t t t t t t t t t t t t t t t t environments t t installation labor, thus reducing costs t maintenance costs t t

SPECIFICATIONS

High quality enclosed fiberglass fixture features a unique continuous poured gasket which completely fills channel for maximum seal integrity. Diffuser is held in place with POM retaining latches. Stainless steel latches are recommended for the following applications: agriculture, car washes. food processing and swimming pools. Hole is 7/8” diameter and is provided with a plastic plug on one end for conduit attachment. Offset mounting pads which keeps luminaire level and slightly off of mounting surface are formed within the housing. Standard diffuser is high impact acrylic with textured pattern designed for high efficiency while providing reduced glare. Listed by and bears ETL label.

VW4

ORDERING DATA

LED

UD

MV

EXAMPLE: VW4LBLED51UDMVSF40

MV

Series

VW4

LED 4’

Vaportight

Type*

Fixture

LB Low Bay

PG Parking

Garage

*PG Fixtures must use either SF or SC Lens

LED

DLC Listed Models

Models

VW4PG-LED51UDMVSF40

VW4PG-LED84UDM11VSF40

VW4LB-LED84UDMV11RF40

VW4LB-LED84UDMV11SF40

Wattage

51

51 Watts

84 84 Watts

Dimming

UD 0-10V

Universal Step

Dim

Voltage

MV

120-277V

Driver

Blank 1 Driver

11

2 Driver

Lens

RF

RC

SF

SC

Ribbed Frosted

Ribbed Clear

Smooth Frosted

Smooth Clear

Kelvin Temperature

30

3000K

35

3500K

40 4000K

50

5000K

Accessories

See

Accessories

Page

Input Watts Color Temp(K) Initial Lumens (lm) Efficacy (lm/W)

51 4000 5014 98.31

84

84

84

4000

4000

4000

7648

8083

8670

91.05

96

103

CRI

>80

>80

>80

>80

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 01/04/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES VW4LB-PG LED

LED Vaportight

Side View

DIMENSIONS

End View

56.8 mm

2.236”

172 mm

8.77”

ACCESSORIES

Clips and Hangers Accessories

4’ = 13.2 mm =51.85”

6.40 in t t t t t t t t

Occupancy Sensor and Photo Cell Accessories

OS

PC120

PC277

Occupancy Sensor

Photo Cell, 120V

Photo Cell, 277V

t t t bracket t t t t bracket w/bail t t t hanging)

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 01/04/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES CPY

LED Low Profile Canopy

APPLICATIONS

Energy efficient fixture for applications that are used frequently for long periods of time. Ideal for use for security, entryway and perimeter lighting, parking garages, shopping area walkways and exterior canopies.

FEATURES & BENEFITS

s

Easy installation s

Typical Mounting Height: 10 to 20 feet s

Typical Spacing: 1 to 1.5 times the mounting height s

Estimated 172,000 hours of maintenance-free operation to L70 at 25˚C (77°F) s

Universal voltage (120V through 277V 50/60HZ) s

Minimum starting temperature -40°C (-40°F) s

Non Dimmable s

UL/cUL Listed for wet locations s

DLC Listed (40W version)

SPECIFICATIONS

Low profile dark-bronze housing and ends are die-formed with decorative fins for heat dissipation. Durable polyester powder coat finish. Acrylic prismatic refractor lens.

MOUNTING OPTIONS

Can be surface or pendant mounted via 3/4” conduit on top. 1/2” threaded conduit entries on two sides

ORDERING DATA

CPY 10

Series

CPY

LED Low

Profile

Canopy

Size

10 10” x 10”

MV

EXAMPLE: CPY10LED40MV50

50 LED

Gear

LED

Wattage & Lumens

20 20 Watts 2040 Lumens

40 40 Watts 3100 Lumens*

58 58 Watts 5500 Lumens

*DLC Listed

Driver Type

MV 120-277V

Color Temperature

50 5000K

10”

4”

10”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 10/06/16

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RKDIS LED

LED Troffer Retrofit Kit

APPLICATIONS

This unique LED Retrofit Kits are an energy efficient, easy to install solution to upgrade your fluorescent troffers to LED. Compatible with both standard and narrow T-grids, they offer a simple retrofit that will improve the look of your ceiling with its architectural styling without the need to actually break the ceiling plenum. This kit offers a true Indirect/Direct solution that not only provides a more energy efficient solution but also the true comfortable performance of an indirect/direct fixture designed especially for workspaces with CRTs. The main diffuser and slanted troffer help reduce glare and create a pleasant, uniform throw of light. This unique kit works with either a perforated basket or a highly efficient specially desinged acrylic diffuser.

With this kit, you will get the energy savings and performance of the latest technology without the fuss and mess of changing out fixtures completely.

FEATURES & BENEFITS

s

Constant current LED drive programmable s

Input voltage 120-277V s

ETL Listed s

0-10V Dimmable s

5 year warranty s

THD <10% s

PF >0.95

s

<85 CRI

RKDIS 22 Series

SPECIFICATIONS

The RKDIS retrofit kits are compatible with both standard and narrow T-grids. A great upgrade solution for fluorescent troffers to LED. Provides a stylish architectural look without breaking the ceiling plenum, also provides a more efficient solution with greater energy savings and performance of the latest technology without the fuss and mess of changing out fixtures completely.

RKDIS

ORDERING DATA

LED FR

EXAMPLE: RKDIS24-LED48FRDMV35

Series

RKDIS

Size

14 1x4

22 2x2

24 2x4

Gear

LED

Wattages & Lumens

1x4

15 15 Watts 1950 Lumens

20 20 Watts 2750 Lumens

24 24 Watts 3205 Lumens

28 28 Watts 3590 Lumens

32 32 Watts 4305 Lumens

40 40 Watts 5150 Lumens

48 48 Watts 5860 Lumens

57 57 Watts 6600 Lumens

2x2

15 15 Watts 1925 Lumens

20 20 Watts 2690 Lumens

24 24 Watts 3080 Lumens

28 28 Watts 3360 Lumens

35 35 Watts 4325 Lumens

40 40 Watts 4765 Lumens

45 45 Watts 5090 Lumens

Lens Material

FR Frosted lens

2x4

15 15 Watts 2270 Lumens

20 20 Watts 2855 Lumens

24 24 Watts 3375 Lumens

28 28 Watts 4040 Lumens

32 32 Watts 4670 Lumens

48 48 Watts 6780 Lumens

57 57 Watts 7800 Lumens

62 62 Watts 8130 Lumens

Driver

DMV 120-277V 0-10V

Dimmable Feld installed

dimming leads

FI DMV 120-277V 0-10V

Dimmable Factory installed

dimming leads

S DMV 120-277V 50%

Step Dimming

*Consult for Triac

Dimming Options

Color Temp

30 3000K

35 3500K

40 4000K

50 5000K

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 10/28/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RKDIW LED

LED Troffer Retrofit Kit

APPLICATIONS

These unique LED Retrofit Kits are an energy efficient, easy to install door frame solution to upgrade your fluorescent troffers to LED. Compatible with both standard and narrow T-grids, they offer a simple retrofit that will improve the look of your ceiling with its architectural styling without the need to actually break the ceiling plenum. This kit offers a true Indirect/Direct solution that not only provides a more energy efficient solution but also the true comfortable performance of an indirect/direct fixture designed especially for workspaces with CRTs. The main diffuser and slanted troffer help reduce glare and create a pleasant, uniform throw of light. With this kit, you will get the energy savings and performance of the latest technology without the fuss and mess of changing out complete fixtures.

FEATURES & BENEFITS

s

Constant current LED drive s

Input voltage 120-277V s

High efficiency 130+ Lumens per Watt s

5 year warranty s cULus Listed for Damp Locations

SPECIFICATIONS

The RKDIW retrofit kits are compatible with both standard and narrow T-grids. A great upgrade solution for fluorescent troffers to LED. Provides a stylish architectural look without breaking the ceiling plenum, also provides a more efficient solution with greater energy savings and performance of the latest technology without the fuss and mess of changing out fixtures completely.

RKDIW

ORDERING DATA

LED GW

EXAMPLE: RKDIW-24LED36FRDMV35

DMV

Series

RKDIW

Size

22 2x2

24 2x4

Gear

LED

Wattages & Lumens

2x2

25 25 Watts 3365 Lumens*

30 30 Watts 3900 Lumens*

36 36 Watts 4600 Lumens

2x4

36 36 Watts 4950 Lumens

50 50 Watts 6360 Lumens*

*Special order

Lens

GW Gloss white

Driver

DMV 120-277VAC

0-10V

Dimmable

Color Temperature

30 3000K

35 3500K

40 4000K

50 5000K

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 8/11/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RKT LED

LED Universal Troffer/Parabolic Retrofit Kit

APPLICATIONS

This kit is designed to convert most recessed fluorescent 1x4, 2x2 and 2x4 troffers and parabolics to long-life and efficient LED technology. These kits provide everything required to enhance the performance and energy savings of your recessed fixture while minimizing labor, clean up and expense. Kits include highreflectance reflector with driver, LED boards and tek screws for easy assembly.

Kits install with simple hand tools in minutes.

FEATURES & BENEFITS

s

Constant Current LED Driver s

Input Voltage: 120-277V AC s

Input Frequency: 50/60Hz s

Reflectors are precision formed and high performance s

ETL Listed for damp locations s

DLC listed in certain models

SPECIFICATIONS

The RKT-LED retrofit kits mount easily, requiring only simple hand tools. The process includes removal of the existing ballast cover(s) and removal of the existing socket brackets and ballast. The driver is attached to the backside of the reflector.

ORDERING DATA

RKT

Series

RKT

Retrofit Kit

LED

14

22

24

Troffer/Parabolic Size

1x4 Troffer/Parabolic

2x2 Troffer/Parabolic

2x4 Troffer/Parabolic

Gear

LED

DLC Listed

RKT22-LED20DMVxx xx=30,35,40,50

RKT22-LED24DMVxx

RKT22-LED28DMVxx

RKT22-LED35DMVxx

RKT22-LED45DMVxx

RKT24-LED35DMVxx

RKT24-LED48DMVxx xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50 xx=30,35,40,50

RKT24-LED57DMVxx

RKT22-LED20DMVxx xx=30,35,40,50 xx=35,40

9”

~ Wattage & Lumens*

Standard 1x4

35 35 Watt 4320 Lumens

48 48 Watt 5680 Lumens

57 57 Watt 6500 Lumens

Standard 2x2

20 20 Watt 2300 Lumens

24 24 Watt 2800 Lumens

28 28 Watt 3200 Lumens

35 35 Watt 4100 Lumens

45 45 Watt 4470 Lumens

Standard 2x4

35 35 Watt 4320 Lumens

48 48 Watt 5680 Lumens

57 57 Watt 6500 Lumens

* ~Wattage & Lumens

EXAMPLE: RKT24-LED48DMV40

DMV

Driver Type

DMV

0-10V

Dimmable

Multivolt 120-

277VAC

Color Temperature

30

35

40

50

3000 K

3500 K

4000 K

5000 K

2.38”

19.5”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 06/27/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RKBC LED

48 & 96 in. LED Retrofit Kit

APPLICATIONS

LED retrofit kit, converts an existing strip to carry excellent light output. Material is die-formed 22 gauge steel, with high reflectance baked white enamel finish

DLC PENDING

Frosted lens accessory reduces LED brightness

EXAMPLE: RKBC48424DMV30

ORDERING DATA

RKBC

Series Length

RKBC

48 48 inch

96 96 inch

Width

4 4.25” inch

5 5.00” inch

* 4 Foot, 24 Watt & H35 Watt - 1 row LED module only

* 8 Foot, 48 Watt & H72 Watt - 1 row LED module only

Wattage

4 ft.

24

H35

48

57

H72

8 ft.

48

60

H72

97

114

H144

Driver

DMV 0-10V Dimming

Kelvin Temperature

30 3000K

35 3500K

40 4000K

50 5000K

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 08/18/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

48 Inch

SERIES RKBC

48 & 96 in. LED Retrofit Kit

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 08/31/2015

CAT#

JOB NAME TYPE

© 2008-15 Mobern Lighting Company

96 Inch

SERIES RKBC

48 & 96 in. LED Retrofit Kit

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 08/18/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES RKREOS LED

LED Light Engine

FEATURES & BENEFITS

t t t t t t t t t t t t t t t t t t t t electrical protection

ORDERING DATA

RKREOS 10 LED

Series

RKREOS

Size

10 9.75 dia.

Gear

LED

120V

EXAMPLE: RKREOS10LED12D12040

40

12

15

22

Wattage

12 Watts

15 Watts

22 Watts

D120

Voltage

Kelvin Temperature

120 Volts

40

4000K

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 01/26/2015

CAT#

JOB NAME TYPE

© 2008-15 Mobern Lighting Company

SERIES MLEDRT

LED 6” Recessed Downlight Kit

APPLICATIONS

The Mobern MLEDRT6 is a six-inch LED recessed downlight kit creating high performing white light and is optimized for new construction and retrofit applications. This downlight is an ideal choice for healthcare, hospitality, office, property management, residential and retail environments.

FEATURES & BENEFITS

t t t t t t t t t t t t

– 700 lumens @ 10 watts

– 900 lumens @ 13 watts t t t t t t t t t t t t t stable lamp to lamp color

Meets California Title 24 fixture requirements for high efficacy luminaire t t t base socket adapter (included) for direct replacement

Adjustable Gimbal feature (35° tilt)

The Mobern MLEDRT6 is a six-inch LED recessed downlight kit creating high performing white light and is optimized for new construction and retrofit applications. Installation is done quickly and easily in most standard six-inch Insulated Ceiling

(IC) housings, Airtight (AT) housings and non-IC housings.

The adjustable gimbal features a smooth travel from nadir to a 35° tilt, making it suitable for slanted ceilings and wall wash.

The gimbal’s friction blade design allows the downlight to be installed in any position within the housing aperture (360°).

Dimming

The Mobern MLEDRT Series downlight kit is dimmable to 10% with standard 120V electronic low voltage dimmers (recommended), incandescent or magnetic low voltage dimmers. In some cases, standard incandescent dimmers require a minimum load of typically

>40 watts on the circuit for full range dimming performance (four

LED modules). For dimming with digital (smart) multi-location dimmers or when dimming fewer than four LED modules, electronic low-voltage (ELV) dimmers are required (some ELV dimmers need a neutral connection in the wallbox).

Quality of Light

The Mobern MLEDRT Series provides excellent color rendering

(82+ CRI), and a selection of color temperatures (2700K, 3000K).

LEDs have virtually no UV or infrared radiation to damage or fade furnishings, art or other objects.

Optical Design

Optical design efficiently directs light output in an 80° beam angle with low glare.

Accessories

Assorted color retrofit trims, GU24 socket adapter, push wire adapter, retrofit band.

ORDERING DATA

MLEDRT 6

Series

MLEDRT

LED

Recessed

Downlight

EXAMPLE: MLEDRT67027WFL

WFL

Housing

6 6” Housing

Gimbal

G Gimbal Ring

70

90

Lumens

700

900

Kelvin Temperature

27

30

2700K

3000K

Reflector

WFL

White

Accessories

See

Accessories

Page

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 100, Laurel, MD 20723

REV. 04/27/2014

CAT#

JOB NAME TYPE

© 2008-14 Mobern Lighting Company

SERIES MLEDRT

LED 6” Recessed Downlight Kit

TECHNICAL INFORMATION

Model Number

MLEDRT6727K

MLEDRT6730K

MLEDRT6927K

MLEDRT6930K

MLEDRT69G27KWRFLWTR

MLEDRT69G30KWRFLWTR

Recessed

Housing

6in.

6in.

6in.

6in.

6in.

6in.

Replaced

Incandescent

Wattage

65W

65W

100W

100W

100W

100W

Nominal

Wattage

(W)

10

10

13

13

13

13

Delivered

Light

Output

(lm)

700

700

900

900

900

900

Color

Temperature

2700K

3000K

2700K

3000K

2700K

3000K

*LED Lamp life is defined as the number of hours when 50% of an average group of identical lamps reached 70% of its initial lumens.

CRI

83

84

82

84

84

84

Avg. Rated

Life (hrs)*

50,000

50,000

50,000

50,000

50,000

50,000

SPECIFICATIONS

Energy Data

t t t t t t t t

Input Frequency: 60Hz t

Class B t t

Power Factor: >0.90

t

THD: <20% t t

Input Power: 10W & 13W t t

Input Current: 0.08A & 0.1A

t t

Maximum Ambient Operating Temperature for

Gimbal (Insulated Ceiling or Non-Insulated

Ceiling): 95°F (35°C) t t

non-Gimbal (Insulated Ceiling or Non-Insulated

Ceiling): 104°F (40°C)

Lighting Data

t t t

Lumens per Watt: 70 for 700lm & 69 for

900lm

Color

t t

2700K & 3000K t t t t

ENERGY SAVINGS

Basic Product

Description

Lumens Life

MLEDRT6 10W 700 50,000

MLEDRT6 13W 900 50,000

*Based on $0.11/kWh over 50,000 hours life.

Traditional Lamp Types

Incandescent 65BR30

Halogen 50WBR30/SS/HAL

Halogen 50WPAR30LN/WFL

Compact Fluorescent 15WBR30

Incandescent 100BR40

Halogen 80WBR40/SS/HAL

Halogen 75WPAR38/WFL

Compact Fluorescent 20WBR40

Lumens

640

585

660

600

935

1080

1060

900

Life

2000

2500

2500

8000

2000

2000

2500

8000

Watts

Saved With

MLEDRT6

87

67

62

7

55

40

40

5

MLEDRT6

Energy

Savings*

$302

$220

$220

$27

$478

$368

$341

$38

MLEDRT6

Life Benefit

25X

20X

20X

6X

25X

25X

20X

6X

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 100, Laurel, MD 20723

REV. 04/27/2014

CAT#

JOB NAME TYPE

© 2008-14 Mobern Lighting Company

SERIES MLEDRT

LED 6” Recessed Downlight Kit

DIMENSIONS

112.5mm

[4.43in]

26.0mm

[1.02in]

34.2mm

[1.35in]

229.0mm

[9.02in]

TOP VIEW

187.0mm

[7.37in]

SIDE VIEW

SIDE VIEW

ACCESSORIES

GU24 Socket Adaptor

MLED/ADAPTOR/GU24 (for non-Gimbal, sold separately)

MLED/CRT6/GU24/SOCKET/ADAPTOR (for Gimbal, sold separately)

Push Wire Adaptor

MLED/ADAPTOR/PUSHWIRE (for non-Gimbal, sold separately)

MLED/CRT6/RETROFIT/ADAPTOR (for Gimbal, sold separately)

Retrofit Band (For 6" housing models Progress Lighting P87-AT and Lightolier 1104IC)

MLEDRT6/RETROFITBAND (sold separately)

[11mm]

0.43in

[45.6mm]

1.80in

[69.6mm]

2.74in

[6.5mm]

0.25in

[24.6mm]

0.97in

[6.5/6.75mm]

Ø165.1/171.5in

Retrofit Trim (For non-Gimbal only, can not be used with Gimbal)

MLEDRT6/TRIM/BLK

MLEDRT6/TRIM/ORBZ

MLEDRT6/TRIM/SN

MLEDRT6/TRIM/BLKBAFFLE

MLEDRT6/TRIM/WHTBAFFLE

MLEDRT6/TRIM/ALZAK

27.5mm

[1.08in]

11.0mm

[0.43in]

8.3mm

[0.33in]

[24.6mm]

0.97in

[95.5mm]

Ø3.76in

[189.6mm]

Ø7.465in

BLK

BRONZE WHITE BAFFLE

BLACK BAFFLE

SATIN NICKEL

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 100, Laurel, MD 20723

REV. 04/27/2014

CAT#

JOB NAME

ALZAK

TYPE

© 2008-14 Mobern Lighting Company

SERIES MLEDRT

LED 6” Recessed Downlight Kit

PHOTOMETRICS

Polar Chart

0 cd

150 cd

300 cd

60°

450 cd

30°

600 cd

Maximum Intensity: 567 cd

90°

2 ft

4 ft

6 ft

8 ft

10 ft

12 ft

Illuminance at Distance

Edge

Illuminance

Center

V

Beam Diameter

H

35.0 fc 141.8 fc

8.8 fc

3.9 fc

2.2 fc

1.4 fc

35.4

fc

15.8 fc

8.9 fc

5.7 fc

1.0 fc

3.9

Vert. Spread: 75.5° fc

3.1 ft

3.1 ft

6.

2 ft

9.3 ft

12.4 ft

15.5 ft

18.6 ft

6.1 ft

9.2 ft

12.3 ft

15.4 ft

18.

4 ft

Horiz. Spread: 75.1°

Zonal Lumen Distribution

Zone Lumens

0-30 393.6

0-40 589.4

0-60 828.9

60-90 81.7

0-90 910.6

90-180 0.0

0-180 910.6

% Fixture

43.2

64.7

91.0

9.0

100.0

0.0

100.0

Spacing to Mounting Height Ratio

Spacing Criteria (0-180°)

Spacing Criteria (90-270°)

Spacing Criteria (Diagonal)

1.02

1.04

1.10

Note: Photometric data for MLEDRT6 900 lumen version.

Application Notes

1. Operating temperature range between -4°F and 104°F (-20°C and 40°C).

2. Suitable for indoor and outdoor dry, damp and wet locations.

3. Suitable for dimmers or in housings controlled by a dimmer. For a list of compatible dimmers, please refer to www.mobern.com.

4. Not intended for use with emergency light fixtures or exit lights.

5. For use in housings that can structurally support a lamp weighing one pound.

6. Designed to install in standard 4" insulated and non-insulated housings. For a list of compatible housings, please refer to www.mobern.com.

7. For detailed warranty information, please refer to www.mobern.com.

WARRANTY

Mobern Lighting Company warrants to the purchaser that this LED Fixture will be free from defects in material or workmanship for a period of 5 years from date of manufacture, when operated at a maximum ambient temperature of 104°F or 40°C, when properly installed and under normal conditions of use.

C U S

Can be used for

T24

2008

California Title 24

High Efficacy

Compliance

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Laurel, MD 20794

REV. 02/18/2015

CAT#

JOB NAME TYPE

© 2008-15 Mobern Lighting Company

SERIES MWPKFLL LED

LED Wallpack/Flood Light

t t t t t t t t t t t t t t

APPLICATIONS

This newly designed luminaire featuring its versatility that can be served as wall light, flood light and etc. Incorporated with high performance LED module along with high quality optical reflector, this fixture performs efficiently and steadily against harsh outdoor environment.

FEATURES & BENEFITS

SPECIFICATIONS

Solid construction and low lumen depreciation die-cast aluminum body standard bronze finish. IP65. Low Tj for long life.

ORDERING DATA

MWPKFLL

EXAMPLE: MWPKFLL-LED87MV50BZ

Series

MWPKFLL

Gear

LED

Wattage & Lumens

87 87 watts 7150 Lumens

150 150 watts 13106 Lumens

Driver Type

MV 120-277V

Color Temperature

50 5000K

Finish

BZ Bronze (std)

WC-BRKT

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 01/07/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MWPKFLS LED

LED Wallpack/Flood Light

APPLICATIONS

This newly designed luminaire featuring its versatility that can be served as wall light, flood light and etc. Incorporated with high performance LED module along with high quality optical reflector, this fixture performs efficiently and steadily against harsh outdoor environment.

FEATURES & BENEFITS

t t t t t t t t t t t t t t t t t t

SPECIFICATIONS

Solid die-cast aluminum housing, architectural bronze, UV resistant outdoor powder coat finish. IP65, Low Tj for long life, low lumen depreciation.

ORDERING DATA

MWPKFLS

EXAMPLE: MWPKFLS-LED40MV50BZ

Series

MWPKFLS

Gear

LED

Wattage & Lumens

40 40 watts 3250 Lumens

Driver Type

MV 120-277V

Color Temperature

50 5000K

Housing Color

BZ Bronze

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 01/07/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

MISMCOWPK LED SERIES

Architectural LED Wall Light

APPLICATIONS

The MISMCOWPK LED Architectural wall pack is a beautifully designed wall light that is suitable for indoor and outdoor use. The design is innovative and stylish. This LED wall pack is suitable for condos, apartments, hospitality, walkways and commercial buildings.

FEATURES & BENEFITS

t t t t t t t t t t t t t prevent water and bugs t t

UL and cUL listed for wet locations t

IP66, dust and waterjet tight t

DLC Listed

13W

Replaces

Up to 35HPS

ORDERING DATA

MISMCOWPK LED

Series

MISMCOWPK

LED Wall Pack

Gear

LED

13 120/240

13

Wattage

13 Watts

Ballast Type

120/240 120/240V

EXAMPLE: MISMCOWPKLED13120/24050PC

50

Kelvin Temperature

50

5000K

PC

Accessories

Photocell - 120V

Only

TECHNICAL INFORMATION

Model

MISMCOWPK

Input Watts

13W

Initial

Lumens (lm)

850

* Data per lm79/lm80/tm21 available upon request

DIMENSIONS

CRI

72

Color

Temp (K)

5000

Efficacy

(lm/W)

65.38

Life

Rating

60,000

Operating

Temperature

-40˚c (-40˚f) to +40˚c (105˚f)

LINE ART

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 01/07/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

MISMCOWPKLED SERIES

Architectural LED Wall Light

SPECIFICATION

Quick Mount

Installation

Heavy duty die-casting aluminum housing

Stainless Steel

Hardware

Prismatic Lens

Optional Photocontrol

Inside

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 01/07/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES WPL

LED Wall Pack

FEATURES & BENEFITS

 

High quality die cast housing

Durable chip and fade resistant powder coat fi nish



Sealed borosilicate glass lens

High specular forward throw refl ector

Gasket sealed driver enclosure

90° adjustability of beam angle with full cut off option

High power Citizen COB LEDs (73W)

Ultimate versatility allows wall, post or bollard and horizontal fl oodlight

installations

Includes 120V photo cell

UL/ cUL listed

ORDERING DATA

Series

WPL

WPL

WPL

EXAMPLE: WPL 29W 1164L 50K BZ

Wattage

14W 14 Wattage

20W 20 Wattage

29W 29 Wattage

Lumens

1164L 1164 Lumens

1848L 1848 Lumens

2346L 2346 Lumens

Color Temperature

50K 5000K

50K 5000K

50K 5000K

Fixture Color

BZ Bronze

BZ Bronze

BZ Bronze

Dimensions and specifi cations subject to change without notice.

800-444-WATT

www.mobern.com

8200 Stayton Dr., Ste. 500, Laurel, MD 20723

REV. 01/07/2015

CAT#

JOB NAME TYPE

© 2008-15 Mobern Lighting Company

SERIES MIMDCOWPK

Decorative LED Wall Pack

APPLICATIONS

The MIMDCOWPK Decorative Full Cut-off Wall Pack is ideal for security, accent and perimeter lighting. Applications include entrance ways, garages, and commercial buildings.

FEATURES & BENEFITS

t t t t t t t t t t t t t t t t t t t t

28W - 42W

Replaces

Up to 175WMH

SPECIFICATIONS

The MIMDCOWPK utlizes High-Power LEDs which produce no UV rays; are instant on/off are mounted on an aluminum heat sink. The driver is multivolt and constant current design - solid state - high shock / vibration resistant. The housing is made of a die-cast aluminum. The Lens is a glass optical diffuser. Standard finish is bronze. Back plate with cast-in knockouts for alignment with all standard recessed boxes. Listed by and bears cETLus or UL label.

ORDERING DATA

MIMDCOWPK LED

MV

EXAMPLE: MIMDCOWPKLED35MV50

Series

MIMDCOWPK

Decorative LED

Wall Pack

Gear

LED 28

35

42

Wattage

28 Watts

35 Watts

42 Watts

Ballast Type

MV

120 - 277

30

40

50

55

Kelvin Temperature

3000K

4000K

5000K

5500K

PC120

PC277

EM

Accessories

Photo Cell, 120V

Photo Cell, 277V

Emergency

*See Chart below

DIMENSIONS

NOTES

1) 35W unit is UL Listed for Wet Locations.

2) 35W unit is available in 5000K only.

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 10/06/16

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MIMDCOWPK

Decorative LED Wall Pack

SPECIFICATIONS

Technical Data

Input Voltage

Lumen Maintenance

Life Expenctancy

LED Brand

LED TMP Temperature

Driver Efficiency

Power [email protected]

THD @277V

Driver TMP temp @25°C Ambient

Noise

EMI

Max Operating Temperatue (-22°F)

Min Operation Temperature (+158°F)

Specification

120-277V, 50/60Hz

≥70% @5 years

Up to 50,000

CREE

@25°C 61.9°C

88%

0.999

8%

48.2°C

<24dB

FCC part 15

45°C

-40°C

LED Array

Model

MIMDCOWPK

Total

System

Watts

28

System

Lumens

2560

Lumens

Per Watt

(lpW)

91.43

35

42

2526

3840

73

91.43

80

75

80

CRI

Color

Temperature

Voltage Replaces Made In USA

3000, 4000, 5000,

5500

5000

3000, 4000, 5000,

5500

120 - 277V

120 - 277V

120 - 277V

Up to

150MH

Up to

150MH

Up to

150MH

Assembled in

USA

Made in the

USA

Made in the

USA

Note: LM79 and ies files are available upon request.

EM

No

Yes

No

WARRANTY

Mobern Lighting Company warrants to the purchaser that this LED Fixture will be free from defects in material or workmanship for a period of 5 years from date of manufacture, when operated at a maximum ambient temperature of 110°F or 45°C, when properly installed and under normal conditions of use.

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 10/06/16

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES WLL

LED Wall Light

APPLICATIONS

Introducing an innovative LED fixture. The intelligent design and flexible features will replace conventional wall packs. A multipurpose wall fixture that will meet specific requirements.The adjustable head makes it unique by giving precise aiming.

FEATURES & BENEFITS

s

High quality die cast housing s

Durable chip and fade resistant powder coat finish s

Tempered glass lens s

Efficient design separates the driver from the LEDs to minimize heat s

Adjustable head for precise aiming s

High power Philips Rebel LEDs (29W & 56W) s

High power Citizen COB LEDs (73W) s

Includes 120V photo cell s

UL/ cUL listed s

DLC listed

ORDERING DATA

Series

WLL10L

WLL15L

WLL 15L

Wattage

29W 29 Wattage

56W 56 Wattage

73W 73 Wattage

Lumens

2100L 2100 Lumens

3980L 3980 Lumens

6231L 6231 Lumens

EXAMPLE: WLL 29W2100L 57K BZ

Color Temperature

57K 5700K

57K 5700K

50K 5000K

Fixture Color

BZ Bronze

BZ Bronze

BZ Bronze

Option for finish:

WH - White

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 06/22/2016

CAT#

JOB NAME

TYPE

© 2008-16 Mobern Lighting Company

SERIES MPL LED

LED Flood and Area Light

t t t t t t t t t t t t t t t t t t t t

APPLICATIONS

The Mobern MPL LED is a great choice for your flood and area lighting requirements. This fixture provides an even distribution of light with good efficiency, long life and lower operating and maintenance costs. This fixture has multiple mounting options to suit your needs.

FEATURES & BENEFITS

SPECIFICATIONS

5 year limited system warranty. Listed by and bears cULus label.

ORDERING DATA

MPLLED

Series

MPLLED

Gear

LED

Wattage/Lumens

120 120 Watts 12560 Lumens

150

150 Watts 14850 Lumens

180

180 Watts 17882 Lumens

240

240 Watts 20649 Lumens

Driver

MV

120-277V

480

480V

EXAMPLE: MPLLED120MV50

Color Temperature

50

5000K

Consult factory for more options.

MIA41

U-Bracket

MI2AF

Adjustable slip fitter

MPLARM6

Mounting Arm 6”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 7/25/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES MAFCO

LED Wall Pack

t t t t t t t t t t t t t t t t t t

APPLICATIONS

The MAFCOLED is an energy conserving powerful wall pack. Proenvironment,Green, Long life LED lighitng fixture. Adapting the most dependable CREE LED Light source. This wall pack has a cast aluminum heat sync to ensure long life of the LED source. The MAFCO is ideal for security, accent and perimeter lighting. Applications include parking lots, garages, and commercial buildings.

FEATURES & BENEFITS

ORDERING DATA

MAFCO LED

Series

MAFCO

Wall Pack

Gear

LED

58 MV 47

58

Wattage

58 Watts

MV

Ballast Type

120-277

Kelvin Temperature

47

4700K

Replaces

Up to 200WMH

EXAMPLE: MAFCOLED58MV47

SPECIFICATIONS

Item

t t t

System Watts t t

Fixture Lumens t t

Fixture Efficacy t t

Rated Life t t t

Driver t t

Fixture CRI t t t t t t

Input Voltage

LED Quantity (Brand: Cree XTE R2) 30

LED Color Temperature

Starting Temperature

Specification

120-277V, 50/60Hz

58.3

4005

69 Lumen/Watt

50,000

500MA

75+

4700K

-30°C

TECHNICAL INFORMATION

WARRANTY

Mobern Lighting Company warrants to the purchaser that this LED Fixture will be free from defects in material or workmanship for a period of 5 years from date of manufacture, when operated at a maximum ambient temperature of 110°F or 45°C, when properly installed and under normal conditions of use.

Inside

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 10/29/2015

CAT#

JOB NAME TYPE

© 2008-15 Mobern Lighting Company

SERIES MLFL10 LED

LED Flood Lighting

APPLICATIONS

This compact but powerful flood light is a true innovation combining practicality and aesthetics. With highly efficient LED engine and precise optical control, greater lighting performance adds the value to its exterior appearance. Multiple mounting methods enable this fixture to be installed in any given environment.

t t t t t t t t t t t t

FEATURES & BENEFITS

SPECIFICATIONS

Solid construction die-cast aluminum body standard bronze finish. UV Stabilized powder coated finish. IP65 and custom finish available.

ORDERING DATA

MLFL 10 LED

Series

MLFL

Size

10 10 inch

Gear

LED

52

EXAMPLE: MLFL10-LED52MV50BZPC

MV 50 BZ PC

Wattage & Lumen

52 52 Watts 5522 Lumens

Driver

MV 120-277V

Color Temp

50 5000K

Finish

BZ Bronze

Options

PC Photocell

6.53”

10”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV 02/01/2016

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

SERIES CPY

LED Low Profile Canopy

APPLICATIONS

Energy efficient fixture for applications that are used frequently for long periods of time. Ideal for use for security, entryway and perimeter lighting, parking garages, shopping area walkways and exterior canopies.

FEATURES & BENEFITS

s

Easy installation s

Typical Mounting Height: 10 to 20 feet s

Typical Spacing: 1 to 1.5 times the mounting height s

Estimated 172,000 hours of maintenance-free operation to L70 at 25˚C (77°F) s

Universal voltage (120V through 277V 50/60HZ) s

Minimum starting temperature -40°C (-40°F) s

Non Dimmable s

UL/cUL Listed for wet locations s

DLC Listed (40W version)

SPECIFICATIONS

Low profile dark-bronze housing and ends are die-formed with decorative fins for heat dissipation. Durable polyester powder coat finish. Acrylic prismatic refractor lens.

MOUNTING OPTIONS

Can be surface or pendant mounted via 3/4” conduit on top. 1/2” threaded conduit entries on two sides

ORDERING DATA

CPY 10

Series

CPY

LED Low

Profile

Canopy

Size

10 10” x 10”

MV

EXAMPLE: CPY10LED40MV50

50 LED

Gear

LED

Wattage & Lumens

20 20 Watts 2040 Lumens

40 40 Watts 3100 Lumens*

58 58 Watts 5500 Lumens

*DLC Listed

Driver Type

MV 120-277V

Color Temperature

50 5000K

10”

4”

10”

Dimensions and specifications subject to change without notice.

800-444-WATT www.mobern.com

8200 Stayton Dr., Ste. 500, Jessup, MD 20794

REV. 10/06/16

CAT#

JOB NAME TYPE

© 2008-16 Mobern Lighting Company

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
