Cleaning the trimmer
1Switch off the product and disconnect
the charging stand from the wall outlet.
2Rinse the handle of the product and
wipe the handle dry with a dry cloth.
3Remove the trimming comb by sliding it
off the product. Shake and/or blow out
the hair or clean it under the tap.
4Push the middle part of the trimming
unit upwards with your thumb until it
opens (Fig. 16).
5Clean the hair chamber with the
cleaning brush supplied (Fig. 17). You
may also rinse the hair chamber under
warm running tap water to remove any
residual debris.
6Rinse the trimming unit with warm
running tap water (Fig. 18).
7Leave the trimming unit open to air dry
completely.
8Close the trimming unit and reattach the
trimming comb (Fig. 19). You will hear a
click.
Cleaning the shaving unit
1 Switch off the product and disconnect
the charging stand from the wall outlet.
2Rinse the handle of the product and
wipe dry with a dry cloth.
3Remove the shaving foil head by pulling
it off the product (Fig. 20).
-- Hold the shaving foil head by the
plastic housing only.
4Rinse the shaving foil head with warm
running tap water (Fig. 21).
-- Do not use the cleaning brush to
clean the shaving foil head as this
may cause damage to the foil or
cutters.
5Allow the shaving foil head to air dry
completely.
-- Never dry trimmer or shaving foil
head with a towel or tissue, as this
may cause damage.
6Clean the hair chamber with the
cleaning brush supplied. You may also
rinse the hair chamber under warm
running tap water to remove any
residual debris (Fig. 22).
7Reattach the shaving foil head by
snapping it back onto the product
(Fig. 23). You will hear a click.
This product has no other user-serviceable
parts. For assistance call 1-800-243-3050.
Storage
-- Fold the charging stand for easy
travelling or storage (Fig. 24).
-- Be sure the product is turned off.
Remove cord from outlet and charging
stand before storing in a safe, dry
location where it will not be crushed,
banged, or subject to damage.
-- Do not wrap cord around the product
when storing.
-- Store cord in a safe location where it
will not be cut or damaged.
-- Do not place or store the product/
charging stand where it can fall or be
pulled into a tub or sink, water or other
liquid while plugged in.
Replacement
Replacing the shaving foil head
For maximum shaving performance, we
advise you to replace the shaving foil head
and cutters every year.
If shaving head foil and cutters are worn
or damaged, do not use the product and
replace immediately.
Always replace the shaving foil head
and cutters with original Philips Norelco
shaving foil head (see ‚Accessories‘).
1 Switch off the product and disconnect it
from the wall outlet.
2Remove the shaving foil head by pulling
it off the product (Fig. 20).
Note: The foil is a precision part. Handle
with care.
3Place the new shaving foil head on the
product by snapping it into place
(Fig. 23). You will hear a click.
4After replacing the shaving foil head,
check that the shaving head is firmly
attached before using product.
Accessories
Replacement parts may be purchased on
our website www.philips.com/store.
For maximum product performance,
replace shaving foil head once a year.
-- Model BG2000 Philips Norelco
Replacement Shaving Foil Head
Assistance
For assistance, visit our website:
www.philips.com/support or call toll free
1-800-243-3050.
Online information is available 24 hours a
day, 7 days a week.
Disposal
-- This appliance contains a rechargeable
nickel metal hydride battery which must
be disposed of properly (Fig. 25).
-- The built-in battery should not be
disposed of with normal household
waste
-- Contact your local town or city officials
for battery disposal information.
You can also call 1-800-822-8837 or
visit www.call2recycle.org for battery
drop-off locations.
-- For assistance, visit our website
www.philips.com/support or call
1-800-243-3050 toll free.
-- Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused. For recycling
information, please contact your local
waste management facilities or visit
www.recycle.philips.com
Full Two-Year Warranty
Philips Electronics North America
Corporation warrants this new product
(except foil, cutters and guards) against
defects in materials or workmanship for
a period of two years from the date of
purchase, and agrees to repair or replace
any defective product without charge.
IMPORTANT: This warranty does not
cover damage resulting from accident,
misuse or abuse, lack of reasonable
care, the affixing of any attachment not
provided with the product or loss of parts
or subjecting the product to any but the
specified voltage or batteries.*
NO RESPONSIBILITY IS ASSUMED
FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
In order to obtain warranty service, simply
go to www.philips.com/norelco or call
1-800-243-3050 for assistance. It is
suggested that for your protection you
return shipments of product by insured
mail, insurance prepaid. Damage occurring
during shipment is not covered by this
warranty.
NOTE: No other warranty, written or oral,
is authorized by Philips Electronics North
America Corporation.
This warranty gives you specific legal
rights, and you may also have other rights
which vary from state to state. Some states
do not allow the exclusion or limitation of
incidental or consequential damages, so
the above exclusion and limitations may
not apply to you.
*Read enclosed instructions carefully.
45-DAY MONEY BACK GUARANTEE
If you are not fully satisfied with your
product send the product back and we’ll
refund you the full purchase price.
The product must be shipped prepaid
by insured mail, insurance prepaid, have
the original sales receipt, indicating
purchase price and date of purchase,
and the money-back guarantee return
authorization form enclosed.
We cannot be responsible for lost mail.
The product must be postmarked no later
than 45 days after the date of purchase.
Philips reserves the right to verify the
purchase price of the product and limit
refunds not to exceed suggested retail
price.
To obtain money-back guarantee return
authorization form, call 1-800-243-3050
for assistance.
Delivery of refund check will occur
6–8 weeks after receipt of returned
product.
1
2
1
7
BG2039
3
4
5
6
8
9
10
11
12
Manufactured for:
Philips Consumer Lifestyle
A division of Philips Electronics
North America Corporation
P.O. Box 10313, Stamford, CT 06904
This symbol on the product’s nameplate means
it is listed by Underwriters’ Laboratories, Inc.
Norelco is a registered trademark of
Philips Electronics North America Corporation.
PHILIPS is a registered trademark of
Koninklijke Philips N.V.
©2016 Philips Electronics North America
Corporation. All rights reserved.
www.philips.com
4222.002.8113.1
2
3
4
5
6
7
8
9
10
1
2
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
ENGLISH
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric product, basic
precautions should always be followed,
including the following:
Read all instructions before using this
product.
IMPORTANT: The power plug contains a
transformer. Do not cut off the power plug
to replace it with another plug, as this will
cause a hazardous condition.
Introduction
Congratulations on your purchase and
welcome to Philips Norelco!
To fully benefit from the support that
Philips Norelco offers, register your
Bodygroom system at
www.norelco.com/register.
1
DANGER
To reduce the risk of electric shock:
-- Do not reach for a corded charging
stand that has fallen into water. Unplug
immediately.
-- Power plug and the accessories
connected to it are not for immersion or
for use in shower.
-- Do not use an extension cord with this
product.
-- Do not place or store the charging
stand where it can fall or be pulled
into a tub or sink. Do not place or drop
the charging stand into water or other
liquid.
-- Always unplug this product from the
electrical outlet immediately after use,
except when the product is (re)charging.
-- Unplug and remove power supply cord
from the product before cleaning.
1
Charging takes approx. 8 hours. Charge the
product before you use it for the first time
and when the display indicates that the
battery is almost empty.
-- Charging, recharging, or using the
product at temperatures below 40°F
(4,5°C) or higher than 95°F (35°C)
adversely affects lifespan of the battery.
-- If the product is subjected to a major
change in temperature, pressure or
humidity, let the product acclimatize for
30 minutes before using.
1 Make sure the product is switched off.
2Put the small plug in the charging stand
(Fig. 2) and put the power plug in any
120V AC outlet.
Note: The small plug is easiest to insert
when the charging stand is folded.
7
3
4
6
8
9
10
11
12
WARNING
To reduce the risk of burns, fire, electric
shock, or injury to persons:
-- Close supervision is required when this
product is used by, on, or near children,
or persons with limited physical,
sensory, or mental capabilities or
invalids.
-- Use this product for its intended
household use as described in this
manual. Do not use attachments not
recommended by Philips Electronics
North America Corporation.
-- This product is only intended for
shaving and trimming body parts below
the neckline.Do not use it to shave or
trim facial or scalp hair.
-- Never operate this product if it has a
damaged cord or charging plug, if it
is not working properly, if it has been
dropped or damaged, or dropped into
water while plugged in. For assistance
call 1-800-243-3050.
-- Keep the product, cord, charging stand,
charging plug and any attachments
away from heated surfaces.
-- Never drop or insert any object into any
opening.
-- Do not use the adapter in or near a
power outlet that contains an electric
air freshener to prevent damage to the
adapter.
-- Never operate the product with the air
openings blocked or while on a soft
surface,such as a bed or couch, where
the air openings may be blocked. Keep
the air openings free of lint, hair, and
the like.
-- Do not operate, charge, clean or plug in
product outdoors where aerosol (spray)
products are being used or where
oxygen is being administered.
-- Always check foil, cutters, cutting unit
and combs before using the product.
Do not use the product if foil, cutters,
cutting unit or combs are damaged,
as injury may occur.
-- Always attach plug to charging stand
first, then to outlet. To disconnect, turn
on/off switch to „OFF“ position, then
remove plug from outlet.
-- Use only the cord and charging stand
provided to charge and (re)charge the
product.
-- Never put the product in direct sunlight
or store at a temperature above 140°F
(60°C).
-- Product is water-safe and can be rinsed
under running tap water or used in
shower. Do not submerge product in
water.
-- To prevent possible damage to the
cord, do not wrap cord around the
product.
-- Always store the product, attachments
and power plug in a moisture-free area.
Make sure the cord is disconnected
from the product.
-- Do not attempt to open the product to
remove/replace the battery.
-- Only use the power plug and other
accessories supplied with the product.
SAVE THESE
INSTRUCTIONS
General description (Fig. 1)
1 Charging and battery low indicator light
2 Shaving unit
3 Shaving unit on/off button
4 Trimming unit on/off button
5 Hair length selector
6 Trimming unit with body comb
7 Beard comb
8 Charging stand
9 Socket for small plug
10Power plug
11 Small plug
12Pouch
Cleaning brush (not shown)
This symbol indicates that the product can
be used in the bath or shower.
2
5
8
3
4
6
9
7
10
1
2
11
12
13
14
15
16
17
20
23
18
21
24
Battery status indications
-- When the battery is almost empty,
the battery charge indicator flashes
orange (Fig. 5).
-- When the product is charging, the
battery charge indicator flashes green.
-- When the battery is fully charged, the
battery charge indicator lights up green
continuously.
Note: After approx. 30 minutes the light
switches off automatically.
Charging
Note: The product can only be charged in
the charging stand. Only use the power
cord and charging stand provided.
2
5
Charging
19
22
25
3 Unfold the charging stand (Fig. 3).
4Put the product in the charging stand
with the shaving unit pointing upwards
(Fig. 4).
-- Make sure the charging contacts on
each side of the product fit into the
charging stand correctly.
-- When placed correctly, the charging
light will flash green to indicate the
product is (re)charging (Fig. 5).
5After charging, remove the power plug
from the wall outlet and pull the small
plug out of the charging stand.fawl
Note: An adapter plug may be necessary
for cord usage in some foreign countries.
Use an attachment plug adapter of the
proper configuration for power outlet.
Optimize the working life of the battery
-- After the product has been charged
for the first time, do not recharge the
product between grooming sessions.
Continue using it until the battery is
completely empty.
-- Discharge the battery completely twice
a year by letting the motor run until it
stops.
-- Do not keep plug permanently plugged in.
Operating time
When the product is fully charged,
it has a cordless operating time of up to
50 minutes.
Using the product
Always check the product and all its
accessories before you use it. Do not
use the product or any accessory if it
is damaged, as this may cause injury.
Always replace a damaged part with one
of the original type.
-- Use this product for its intended
household use as described in this
manual.
-- For hygienic reasons, the product
should only be used by one person.
-- Trimming is easier when the skin and
hair are dry.
Note: This product is for cordless use.
Switching the product on and off
Shaver
1 Press the shaving on/off button once to
switch the product on or off (Fig. 6).
Trimmer
1 Press the trimming on/off button once
to switch the product on or off (Fig. 7).
Attaching and detaching the combs
Attaching the comb
1 Slide the beard or body comb into the
guiding grooves on both sides of the
handle.
2 Press the length selector and then slide
it up or down to select the desired hair
length setting (Fig. 8).
Detaching the comb
1 Press the length selector and then slide
the comb upwards off the product.
Trimming length settings
The trimming combs allow you to cut hair
to 5 different lengths:
Hair length
setting
Hair length after trimming
1
1/8 in. / 3 mm
2
3/16 in. / 5 mm
3
9/32 in. / 7 mm
4
3/8 in. / 9 mm
5
7/16 in. / 11 mm
-- If you are trimming for the first time,
be careful. Do not move the product
too fast. Make smooth and gentle
movements.
-- When you trim for the first time, start at
the highest length setting to familiarize
yourself with the product.
-- Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards,
downwards, or across). Practice is best
for optimum results.
-- Always make smooth and gentle
movements and be sure the surface of
the comb always stays in contact with
your skin.
-- For body trimming, make sure hair
is clean and dry as wet hair tends to
stick to the body and, when trimming
sensitive areas, always use the body
comb.
1Hold the product in the trimming
position, with the trimming unit pointing
upwards and the shaving unit pointing
downwards (Fig. 9).
2Slide the beard or body comb into the
guiding grooves on both sides of the
handle.
3Press the length selector and then slide
it up or down to select the desired hair
length setting (Fig. 10).
-- The two lines next to the setting
selector show which setting you have
selected (Fig. 11).
4 Switch on the product (Fig. 7).
5Hold product as shown and move the
trimmer against the direction of hair
growth making sure the tips of the comb
point in the same direction as you are
moving the product (Fig. 12).
6Switch off and clean the product after
each use (see ‚Cleaning‘).
Shaving
Do not use this shaving unit to shave or
trim facial or scalp hair (Fig. 15).
The shaving unit should only be used on
skin below the neckline.
-- When shaving sensitive areas for
the first time, you may feel some
discomfort, irritation or reddening of the
skin. This is normal as your skin needs
time to adjust to shaving.
-- If your hair is longer than
13/32 in./10 mm, trim hair using a
trimmer first for optimum shaving
results.
-- For dry use, be certain that your skin is
clean and dry before using the shaving
unit.
-- For wet use, prepare your skin with
lathered soap or shaving foam before
using the shaving unit.
1 Hold the product in the shaving
position, with the shaving unit pointing
upwards and the trimming unit pointing
downwards (Fig. 13).
2 Switch on the shaver (Fig. 6).
3 Stretch your skin taut with your free hand
(Fig. 14). Gently press shaving unit to skin
and move it slowly and smoothly against
the direction of hair growth (Fig. 15).
-- Do not press too hard. Too much
pressure can distort the foil and
cause skin irritation.
-- Make sure the shaving unit is always
in full contact with your skin
4Switch off and clean the product after
each use (see ‚Cleaning‘).
Cleaning
Never use scouring pads, abrasive
cleaning agents or aggressive liquids
such as gasoline or acetone to clean the
product.
Never dry trimmer or shaving foil head
with a towel or tissue, as this may cause
damage.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
