ITEM #
MODEL #
NAME #
ecostore Premium
2 Door Dual Digital
Refrigerator, 1430lt (-2/-2)
SIS #
AIA #
Main Features
ecostore Premium
2 Door Dual Digital Refrigerator, 1430lt
(-2/-2)
727268 (ESP142FDR)
Eco Store Premium Dual
Refrigerator-1430 lt 2 doors
(-2/-2°C)- 230 V/1N/50Hz
Item No.
Two full door refrigerator entirely constructed in 304 AISI stainless steel
with bottom panel in anti-corrosive material. Large digital display featuring
humidity selection button (3 preset level), cabinet temperature display and
setting, manual activation of defrost cycle and turbo frost cycle (to rapidly
cool warm loads). HACCP-compliant control with alarms and history. Frost
Watch Control to defrost only when required with automatic evaporation of
defrost water. Three probes to constantly monitor the working conditions
of the appliance. Optiflow: back to front forced air flow and removable air
conveyors provides even temperature distribution and fast cooling in any
conditions. Fitted with 75 mm-thick cyclopentane insulating foam. Door
features lock and door microswitch to switch off the fan when the door is
opened. Hidden evaporator to guarantee higher storage capacity and less
corrosion problems. Built-in refrigeration unit; ventilated operation; Internal
LED light. Dual operating temperature: -2/+10°C -2/+10°C. For ambient
temperatures up to 43 °C. CFC and HCFC free. R134a gas in refrigeration
circuit.
Supplied with n. 8x2/1GN Rilsan coated grids and n. 8 sets of 2 stainless
steel grid runners. Prearranged to fit RS485 port to facilitate connection to
a remote computer and integrated HACCP systems.
Construction
• Constructed from the highest quality AISI 304 Stainless
steel.
• Interior base with corners, pressed from a single sheet.
• The rounded internal corners, the easily removable runners,
grids and air conveyors allow for ease of cleaning and high
hygiene standards.
• Stainless steel runners and supports easily disassembled.
• Anti-corrosion bottom avoids any damage that may be
caused to the cabinet by aggressive detergents employed
to clean the floors.
• Easy access to the main components for an easy
maintenance.
• Lockable door.
• Door switch stops the fan when door is opened to avoid cold
air exiting the cell, thus saving energy.
APPROVAL:
Electrolux Professional
www.electrolux.com/foodservice
foodservice@electrolux.com
ecostore Premium
2 Door Dual Digital Refrigerator, 1430lt (-2/-2)
Short Form Specification
• Large digital white-digit display with humidity selection
button (3 preset level), cabinet temperature display and
setting, manual activation of defrost cycle and turbo frost
cycle (to rapidly cool warm loads).
• Fully compliant HACCP digital control: when temperature
exceeds critical limits, acoustic and visual alarms are
activated. Up to two months of event are kept in memory.
• Large storage area suitable to contain 2/1 GN grids or
shelves on anti-tilt runners.
• Optiflow: back to front forced air flow and removable air
conveyors provide even temperature distribution and fast
cooling in any conditions.
• Frost Watch Control: fully automatic defrost, driven by 3
probes, starts only when ice is actually building-up in the
evaporator.
• Improved defrost and evaporator fan management – defrost
type changes with temperature set-point: electric below +2°
C while air convection defrost above +2°C, thus saving
energy.
• Internal structure with numerous charging positions
available to host grids, ensuring higher net capacity and a
greater storage space.
• Dual temperature type: -2 +10 °C/-2 +10 °C.
• Performance guaranteed at ambient temperatures of 43 °C.
• Cabinet fitted with up to 75 mm thickness of cyclopentane
insulation for best insulating performance with 100%
environmental protection.
• Removable triple-chamber balloon magnetic gasket to
improve insulation and reduce energy consumption.
• Automatic evaporation of the defrosting water by hot gas on
the top for energy saving.
• 60 mm-thick insulation covering the evaporator can be easily
removed with a single operation.
• Interior LED light to save energy.
• Prearranged to fit RS485 port to facilitate connection to a
remote computer and integrated HACCP systems.
• Rilsan coated grids for improved protection.
• Cleaning-free condenser: the structure of the wire frame
condenser prevents dust and grease accumulation thus
avoiding periodical cleaning operations and reducing energy
consumption.
ecostore Premium
2 Door Dual Digital
Refrigerator, 1430lt (-2/-2)
• Refrigerant type: R134a.
• CFC and HCFC-free insulation.
Included Accessories
• 8 of 2/1GN grey rilsan grid with 2 runners
PNC 881020
Optional Accessories
• 2/1GN grey rilsan grid
• 2/1GN aisi 304 stainless steel grid
• Printer for HACCP basic version (for cabinets
and counters with digital control)
PNC 881004 ❑
PNC 881016 ❑
PNC 881457 ❑
ecostore Premium
2 Door Dual Digital Refrigerator, 1430lt (-2/-2)
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2012.09.28
ecostore Premium
2 Door Dual Digital
Refrigerator, 1430lt (-2/-2)
Front
Electric
Supply voltage:
727268(ESP142FDR)
Connected load:
230 V/1 ph/50 Hz
0.52 kW
Key Information:
Door hinges:
External dimensions, Height:
External dimensions, Width:
External dimensions, Depth:
External dimensions, Depth with
Doors Open:
Number and type of doors:
Gross capacity:
Number and type of grids
(included):
Type of external material:
Type of internal material:
Internal panels material:
Number of positions & pitch:
Top
1 Left+1 Right
2050 mm
1441 mm
837 mm
1480 mm
2 Full
1430 lt
8 - GN 2/1
304 AISI
304 AISI
304 AISI
44; 30 mm
Refrigeration Data
Control type:
Refrigerant type:
Second Unit - Refrigerant Type:
Refrigeration power at
evaporation temperature:
Operating temperature - First Unit
(min-max):
Operating temperature - Second
Unit (min-max):
Operating mode:
Digital
R134a
R134a
-10 °C
-2°C / 10°C
-2°C / 10°C
Ventilated
EI = Electrical connection
Side
ecostore Premium
2 Door Dual Digital Refrigerator, 1430lt (-2/-2)
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2012.09.28
