MagicDraw Report Wizard User Guide

MagicDraw Report Wizard User Guide
MAGICDRAW REPORT
WIZARD
version 17.0.1
user guide
No Magic, Inc.
2011
All material contained herein is considered proprietary information owned by No Magic, Inc. and is not to be
shared, copied, or reproduced by any means. All information copyright 1998-2011 by No Magic, Inc. All Rights
Reserved.
CONTENTS
REPORT WIZARD
12
1. MagicDraw Report Wizard Overview 12
1.1 Report Wizard Dialog
12
1.1.1 Control Buttons 13
1.1.2 Content Management Pane 13
1.1.2.1 Template Management Pane 13
1.1.2.2 Report Data Management Pane 25
1.1.2.3 Select Element Scope Pane 46
1.1.2.4 Generate Output Pane 47
1.2 MRZIP File Automatic Deployment 49
2. Report Wizard Template Language 51
2.1 Velocity Template Language 51
2.2 Report Wizard Custom Language
51
2.2.1 #forrow Directive 51
2.2.2 #forpage Directive 51
2.2.2.1 OpenDocument Specific Usage 52
2.2.3 #forcol Directives 53
2.2.4 #includeSection Directive 54
2.2.5 #include, #parse, and #includeSection: A Comparison 54
3. Template Variables 56
4. Helper Modules 59
4.1 $report
59
$report.containsStereotype(element, stereotypeName) 59
$report.createValueSpecificationText(specification) 59
$report.filterDiagram(diagramList, digramTypes) 59
$report.filterElement(elementList, humanTypes) 59
$report.filter(elementList, propertyName, propertyValue) 60
$report.findElementInCollection(elementList, name) 60
$report.findRelationship(modelPackage) 60
$report.findRelationship(modelPackage, recursive) 61
$report.getAppliedStereotypeByName(element, stereotypeName) 61
$report.getBaseClassAssociations(classifier) 61
$report.getBaseClassInheritableAttributes(classifier) 61
$report.getBaseClassInheritableOperations(classifier) 61
$report.getBaseClassPorts(classifier) 62
$report.getBaseRealizedInterfaces(behavioredClassifier) 62
$report.getBaseRelations(classifier) 62
$report.getBaseClassifiers(child) 62
$report.getClientElement(element) 62
$report.getComment(element) 63
$report.getDerivedClassifiers(parent) 63
$report.getDiagramElements(diagram) 63
$report.getDiagramType(diagram) 63
$report.getDSLProperty(element, propertyName) 63
$report.getElementComment(element) 64
$report.getElementName(element) 64
$report.getIconFor(element) 64
$report.getIconFor(type) 64
$report.getIncludeUseCase(useCase) 64
$report.getInnerElement(element) 65
$report.getInteractionMessageType(message) 65
$report.getMetaClass(stereotype) 65
$report.getPresentationDiagramElements(diagram) 65
$report.getPresentationElementBounds(diagram, element) 65
3
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
$report.getPresentationElementRectangle(diagram, element) 66
$report.getQualifiedName(namedElement, separator) 66
$report.getPackageQualifiedName(namedElement, separator) 66
$report.getRecievingOperationalNode(element) 67
$report.getRelationship(element) 67
$report.getRelationship(element, recursive) 67
$report.getRelativeActor(element) 67
$report.getSendingOperationalNode(element) 67
$report.getStereotypeProperty(element, stereotypeName, propertyName) 68
$report.getStereotypePropertyString(element, stereotypeName, propertyName) 68
$report.getStereotypes(element) 68
$report.getSupplierElement(element) 68
$report.getUsageElements(usagesMap, element) 69
$report.getUsages(selectedObjects) 69
$report.hasStereotype(element) 69
$report.containsStereotype(element, stereotypeName) 69
$report.isDerivedClassifier(parent, child) 69
$report.isNamedElement( element) 70
$report.isNull(obj) 70
$report.isRelationship(element) 70
$report.serialize(hyperlink) 70
$report.getUsedBy(element) 70
$report.hasProperty(element, propertyName) 71
$report.findElementByName(source, regex) 71
$report.getPresentationElements(diagram) 72
$report.getUsageRepresentationText(baseElement, bool) 72
$report.getUseCaseNumber(element) 72
4.2 $project
73
$project.getName() 73
$project.getTitle() 73
$project.getFileName() 73
$project.getExtension() 73
$project.getDirectory() 73
$project.getVersionList() 74
$project.getType() 74
$project.getDiagrams() 74
$project.getDiagrams(type) 75
$project.getPresentationDiagrams() 75
$project.getPresentationDiagrams(type) 76
$project.isRemote() 76
$project.isDirty() 76
$project.getElementByID(id) 76
$project.getAllElementId() 77
$project.getXmiVersion() 77
$project.getVersion() 77
$project.getModel() 77
$project.getModuleList() 77
$project.getSharedModule(module) 77
4.3 $iterator
78
$iterator.wrap( list ) 78
$<IteratorTool instance>.hasMore() 78
$<IteratorTool instance>.more() 78
$<IteratorTool instance>.remove() 79
$<IteratorTool instance>.reset() 79
4
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
$<IteratorTool instance>.stop() 79
$<IteratorTool instance>.toString() 79
4.4 $list
79
$list.contains(list, element) 79
$list.get(list, index) 80
$list.isArray(object) 80
$list.isEmpty(list) 80
$list.isList(object) 80
$list.set(list, index, value) 80
$list.size(list) 80
4.5 $bookmark
81
$bookmark.openURL(url, content) 81
$bookmark.openURL(url, content) 81
$bookmark.openURL(url, content) 81
$bookmark.open(content) 81
$bookmark.open(bookmarkId, content) 82
$bookmark.create(bookmarkObject) 82
$bookmark.create(bookmarkId, bookmarkObject) 82
$bookmark.create(bookmarkId, bookmarkObject, elementType) 82
$bookmark.getBookmarkId(id) 82
4.6 $sorter
83
$sorter.sort(Collection, fieldName) 83
$sorter.sort(Collection) 83
$package is a collection to sort 83
$sorter.sortByFirstNumber(Collection, fieldName) 83
$sorter.sortByFirstNumber(Collection) 84
$sorter.sortByLocale(Collection, String) 84
$sorter.sortByLocale(Collection, String, String) 85
$sorter.humanSort(collection, fieldName) 85
$sorter.humanSort(collection) 86
4.7 $template
86
$template.getName() 86
$template.getResourcesLocation() 86
$template.getTemplateFile() 86
$template.getTemplateLocation() 87
$template.getOutputFile() 87
$template.getOutputFileNoExt() 87
$template.getOutputLocation() 87
4.8 $file
87
$file.silentCreate(template) 87
$file.silentCreate(template, importObject) 87
$file.silentCreate(template, outputFileName, importObject) 88
$file.silentCreate(templateType, template, outputname, importObject) 88
$file.create(template) 88
$file.create(template, importObject) 89
$file.create(template, outputFileName, importObject) 89
$file.create(templateType, template, outputname, importObject) 89
$file.copy(inputFilename) 89
$file.copy(inputFilename, outputFilename) 90
$file.exists(pathname) 90
$file.computeName(directory, name) 90
$file.computeName(directory, name, fileType) 90
4.9 $array
91
$array.createArray() 91
5
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
$array.createArray(collection) 91
$array.subList(list, size) 91
$array.addCollection(parent, child) 91
$array.createHashSet() 92
4.10 $group
92
$group.create() 92
$group.init() 92
$group.groupNames() 92
$group.contains(groupName) 92
$group.put(groupName, object) 92
$group.get(groupName) 93
$group.remove(groupName) 93
$group.removeAll() 93
$group.clear() 93
4.11 $map
93
$map.createHashMap() 93
4.12 $date
94
$date 94
$date.long 94
$date.full_date 94
$date.get('format') 94
4.13 $profiling
96
$profiling.getGeneralizationName(modelName) 96
$profiling.getDeclaringElementName (modelName, propertyName) 96
$profiling.getPropertyTypeName (modelName, propertyName) 96
$profiling.getPropertyTypeName (element, propertyName) 96
$profiling.getElementProperties(modelName) 96
$profiling.getElementProperties(element) 96
$profiling.getElementProperty(element, propertyName) 97
$profiling. getHumanPropertyName(element, propertyName) 98
4.14 $image
98
4.14.1 Scaling 98
4.14.1.1 (i) $image.scale(image, scaleWidth, scaleHeight) 98
4.14.1.2 (ii) $image.scale(image, scaleFactor) 98
4.14.1.3 Scaling Quality 99
4.14.2 Rotating 102
4.14.2.1 (i) $image.rotateRight(image) 102
4.14.2.2 (ii) $image.rotateLeft(image) 102
4.14.3 Fixed-Pixels Resizing 103
4.14.3.1 (i) $image.setSize(image, sizeWidth, sizeHeight) 104
4.14.3.2 (ii) $image.setHeight(image, size) 104
4.14.3.3 (iii) $image.setHeight(image, size, keepRatio) 104
4.14.3.4 (iv) $image.setWidth(image, size) 105
4.14.3.5 (v) $image.setWidth(image, size, keepRatio) 105
4.14.4 Fixed-Measurement Resizing 106
4.14.4.1 (i) $image.setSize(image, measureWidth, measureHeight) 106
4.14.4.2 (ii) $image.setHeight(image, measureSize) 107
4.14.4.3 (iii) $image.setHeight(image, measureSize, keepRatio) 107
4.14.4.4 (iv) $image.setWidth(image, measureSize) 107
4.14.4.5 (v) $image.setWidth(image, measureSize, keepRatio) 107
4.14.4.6 (iv) $image.setDPI(dotsPerInches) 108
4.14.5 Include Image 110
4.14.5.1 (i) $image.include(location) 110
5. Report Wizard Template Editor 112
5.1 Installation
6
112
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
5.2 Opening Template Editor 112
5.3 Data File 114
6. Generating Reports from Report Wizard
118
6.1 Concepts 118
6.2 Default Templates 118
6.3 Architecture Templates 119
6.3.1 Behavioral Report 119
6.3.2 Environment Report 119
6.3.3 Implementation Report 119
6.3.4 Structural Report 119
6.3.5 Use Case Report 119
6.4 Generating Use Case Description Reports
6.5 Web Publisher 2.0 Reports 129
120
6.5.1 Generating Reports 129
6.5.2 Web Publisher 2.0 Features 132
6.5.2.1 Report Layout 132
6.5.2.2 Containment Menu 133
6.5.2.3 Contents Layout 134
6.5.2.4 Quick Search Box 139
6.5.2.5 Changing a Homepage Image 140
6.5.2.6 Element Description 142
6.5.2.7 Shortcut to Homepage 142
6.5.2.8 Property Visibility 143
6.5.2.9 Showing or Hiding Context Menu 144
6.5.2.10 Opening an Activity, State Machine, Collaboration, or Interaction Diagram 144
6.5.2.11 Opening the Sub-diagrams of a State with Submachine 145
6.6 Web Publisher Collaboration Reports
146
6.6.1 Generating Reports 146
6.6.2 Web Publisher Collaboration Feature 148
6.6.2.1 Adding Comments 148
6.6.2.2 Altering Model Contents 149
6.6.3 XML Integration 150
6.7 Uploading Reports to Remote Locations
151
6.7.1 Quick Guide 151
6.7.2 Detailed Explanations 156
6.7.2.1 Using Profile Management Dialog 156
6.7.2.2 Upload Problems 158
6.8 FAQs
159
7. Generating Reports from the Containment Tree 164
8. Generating Reports from the Command Line 166
8.1 Generate - the Command to Generate Reports
166
8.1.1 Synopsis 166
8.1.2 Description 167
8.2 Options 167
8.3 Properties Filename
168
8.3.1 XML Properties File 169
8.4 Using Command Line
8.5 Syntax Rules 170
169
9. Report Wizard Quick Print 171
10. Report Wizard Environment Options
174
10.1 Configuring Report Engine Properties 175
10.2 Configuring Template Mappings 177
10.3 Monitor Template Folder Option 179
10.4 Reset to Defaults Option 179
7
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
11. Debug Report Template
181
11.1 Invalid Property 181
11.2 Invalid Reference 181
11.3 Invalid Method Reference
11.4 Exception 182
11.5 Invalid Syntax 182
182
11.5.1 Enabling or Disabling Warning Messages 183
11.5.1.1 Modifying config.xml 183
11.5.1.2 Adding Tags and Values 183
12. Use Case Driven 184
12.1 Use Case Specification Report 184
12.2 Method Specification Report 184
12.3 Use Case Project Estimation Report 184
12.3.1 Classifying Actors 185
12.3.2 Unadjusted Actor Weights 185
12.3.3 Determining Scenarios and Transactions of Use Cases 186
12.3.4 Unadjusted Use Case Weights 186
12.3.5 Unadjusted Use Case Point 186
12.4 Project Characteristics
187
12.4.1 Technical Factors 187
12.4.1.1 Technical Factor Value 188
12.4.1.2 Technical Complexity Factor 188
12.4.2 Environmental Factors 188
12.4.2.1 Environmental Factor Value 189
12.4.2.2 Environmental Factor 190
12.4.3 Project Estimation 190
12.4.3.1 Adjusted Use Case Points 190
12.4.3.2 Estimated Effort in Person Hours 190
12.4.3.3 Estimated Effort in Scheduled Time 190
12.4.3.4 Estimated Effort in Working Days 191
13. Javadoc Syntax Tool
192
13.1 Javadoc Syntax 194
13.2 Javadoc Tool API 196
13.2.1 JavaDocTool 196
13.2.1.1 Document 196
13.2.1.2 DocumentImpl 197
13.2.1.3 Tag 197
13.2.1.4 TagImpl 197
13.2.1.5 ParamTag 197
13.2.1.6 ThrowsTag 197
13.2.1.7 SeeTag 197
13.2.1.8 SerialFieldTag 197
14. Import Tool
200
14.1 Import Syntax 200
14.2 Import Usage 201
14.2.1 Preparatory Step 201
14.2.2 Usage in Example 1 201
14.2.3 Usage in Example 2 202
14.2.4 Usage in Example 3 202
15. JavaScript Tool
204
15.1 JavaScript Tool API
204
15.1.1 'eval' Method 204
15.1.2 'execute' Method 205
15.1.3 'call' Method 207
8
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
15.2 References to Elements
16. Groovy Script Tool
208
209
16.1 Groovy Script Tool API
209
16.1.1 'eval' Method 209
16.1.2 'execute' method 210
16.2 References to Elements
17. Dialog Tool
211
212
17.1 Dialog Tool API
212
17.1.1 ‘message’ Method 212
17.1.2 ‘confirm’ Method 213
17.1.3 ‘input’ Method 213
17.1.3.1 Input Dialogs with Text 213
17.1.3.2 Input Dialogs with Text and Initial Value 214
17.1.3.3 Input Dialog with Text and Initial Value Array 214
17.1.4 ‘sort’ Method 215
17.1.4.1 Sort and Enable Dialogs 215
17.1.4.2 Sort and Enable Dialogs with Text 215
18. Text Tool
217
18.1 Text Tool API
217
19. Appendix A: Report Extensions 221
19.1 Custom Tool
221
19.1.1 Context Name 222
19.1.2 Context Object 222
19.2 Tool Interface
222
19.2.1 Class Tool 224
19.2.2 Concurrent Tool 224
19.3 Creating Custom Tool 225
19.3.1 Developing a Tool Class 225
19.3.2 Creating an Extension Package 225
19.4 Installing Custom Tool 226
19.5 Importing Custom Tool to Template
226
19.5.0.1 Attributes 226
20. Appendix B: Office Open XML Format Template
227
20.1 Microsoft Office Word Document (DOCX) 227
20.1.1 Limitations 227
20.2 Microsoft Office Excel Worksheet (XLSX) 228
20.2.1 Multi-line Statements in XLSX 228
20.2.2 Creating Data for Multiple Row 230
20.2.3 Creating Data for Multiple Columns 231
20.2.4 Displaying Content in Cell 231
20.2.5 Limitation 232
20.3 Microsoft Office PowerPoint Presentation (PPTX)
233
20.3.1 Multi-line Statements in PPTX 233
20.3.2 Creating Data for Multiple Slides 235
20.3.3 Creating Page with Conditions 236
20.3.4 Limitation 237
21. Appendix C: OpenDocument Format Template 238
21.1 OpenDocument Text 238
21.2 OpenDocument Spreadsheet 238
21.2.1 Creating Data for Multiple Rows 240
21.2.2 Creating Data for Multiple Columns 240
21.3 OpenDocument Presentation
241
21.3.1 Creating Data for Multiple Slides 243
9
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
21.3.2 Creating Page with Conditions 244
21.4 OpenDocument Conversion Tool
245
21.4.1 Microsoft Office ODF Extensions 245
21.4.2 OpenOffice.org 245
22. Appendix D: HTML Tag Support
22.1 Supported HTML Tags
247
247
22.1.1 Font Tags 247
22.1.1.1 Size 247
22.1.1.2 Face 248
22.1.1.3 Color 248
22.1.2 Font Style Tag 249
22.1.3 Phrase Elements 250
22.1.4 Ordered and Unordered Lists, and List Item Tags 250
22.1.4.1 Ordered Lists 250
22.1.4.2 Nested Ordered Lists 251
22.1.4.3 Unordered Lists 252
22.1.4.4 Nested Unordered Lists 252
22.1.5 Definition List Tags 253
22.1.6 Line and Paragraph Tags 253
22.1.7 Preformatted Text 254
22.1.8 Heading Tags 255
22.1.9 Link Tags 256
22.1.10 Table Tags 256
22.1.10.1 Table Elements 256
22.1.10.2 Row Elements 258
22.1.10.3 Cell Elements 260
22.1.10.4 Header Elements 262
22.1.11 Image Tags 263
22.1.11.1 src 263
22.1.11.2 Width 263
22.1.11.3 Height 263
22.2 Supported CSS
264
22.2.1 Background 264
22.2.1.1 Color Specification 264
22.2.1.2 Supported Tags 265
22.2.2 Border 266
22.2.2.1 Border Width 266
22.2.2.2 Length Specification 266
22.2.2.3 Border Color 266
22.2.2.4 Border Style 267
22.2.2.5 Supported Tags 267
22.2.3 Margin 268
22.2.3.1 Supported Tags 268
22.2.4 Padding 269
22.2.4.1 Supported Tags 270
22.2.5 Color 270
22.2.5.1 Supported Tags 271
22.2.6 Display 271
22.2.6.1 Supported Tags 271
22.2.7 Font 272
22.2.7.1 Font Family 272
22.2.7.2 Font Style 272
22.2.7.3 Font Variant 272
22.2.7.4 Font Weight 272
22.2.7.5 Font size 272
22.2.7.6 Supported Tags 272
10
Copyright © 1998-2011 No Magic, Inc..
CONTENTS
22.2.8 Text Align 273
22.2.8.1 Supported Tags 273
22.2.9 Text Transform 273
22.2.9.1 Supported Tags 274
22.2.10 White-space 274
22.2.10.1 Supported Tags 274
22.2.11 Width 275
22.2.12 Text Decoration 276
22.2.12.1 Supported Tags 277
22.2.13 Vertical Align 277
11
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
1. MagicDraw Report Wizard Overview
Report Wizard is a report engine for MagicDraw version 14.0 and greater. It is designed to solve several problems of the old report engines (XSL/XSLT and JPython).
The Report Wizard report engine is built on top of Velocity Engine (Open Source Templating engine) and is
integrated with the MagicDraw application. To make the best of Report Wizard, you need to understand the
Report Wizard UI, the Velocity Template Language (VTL), the application's Open API, and the helper modules.
Report Wizard supports text-based templates to generate reports. Each report file format depends on the type
of the templates. The type of template files that Report Wizard supports includes plain text, RTF, HTML, Office
Open XML (ISO/IEC 29500:2008), OpenDocument format (ISO/IEC 26300), and XML template (DocBook or
FO).
All commercial MagicDraw editions will have full use of all the features within Report Wizard. The MagicDraw
Community edition allows you to generate output with watermarks.
Before generating reports you need to open Report Wizard.
To open Report Wizard:
• On the Tools menu, click Report Wizard. The Report Wizard dialog will appear.
1.1 Report Wizard Dialog
The Report Wizard dialog (Figure 1) consists of 2 panes: (1.1.1) Control buttons and (1.1.2) Content Management pane.
12
Copyright © 1998-2011 No Magic, Inc.
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 1 -- Report Wizard Dialog
1.1.1 Control Buttons
There are 4 control buttons:
(i) The Back button is used for going back to the previous content management pane.
(ii) The Next button is used for going to the next content management pane.
(iii) The Generate button is used for generating a report.
(iv) The Cancel button is used for cancelling the report generation process.
1.1.2 Content Management Pane
This pane is used for managing the template content and includes the following panes:
(1.1.2.1) Template Management pane
(1.1.2.2) Report Data Management pane
(1.1.2.3) Select Element Scope pane
(1.1.2.4) Generate Output pane
Click the Back or Next button to go to a specific pane.
1.1.2.1 Template Management Pane
This pane consists of the Select Template pane (Figure 2).
13
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 2 -- Select Template Pane
Report Wizard provides predefined templates such as Use Case, Model Extension, Data Dictionary, IEEE
1233, Class Specification Diagram, Business Process Diagram, and Web Publisher templates. Choose the relevant template to manage or generate a report.
To select a template:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. In the Select Template pane (Figure 2), select a template. A template description will be
displayed in the lower part of the Select Template pane.
You can manage the template from the Template Management pane or click the Next button to go to the next
step for generating the report.
This pane contains 8 buttons: (a) New, (b) Edit, (c) Delete, (d) Open, (e) Variable, (f) Clone, (g) Import, and
(h) Export.
(a) New button
Click the New button (Figure 2) to create a new template.
14
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
To create a new template:
1. In the Report Wizard dialog, click the New button. The New Template dialog will open
(Figure 3).
Figure 3 -- New Template Dialog
2. Enter the template name, description, and location of the new template in the New Template
dialog.
Table 1 -- New Template Dialog Fields and Buttons
Field Name
Description
Default
Value
Possible
Value
Required
Name
Enter a new template name.
Blank
Text
Yes
Description
Enter a template description.
Blank
Text
No
Template file
Select an RTF template.
Blank
Text
Yes
Create
Create a new template under the
Template tree.
Disable
Disable/
Enable
-
Cancel
Close the dialog.
Enable
-
-
Category
Choose the existing category or enter
a new category name.
-
Text
No
3. Click the "…" button. The Select Location dialog will appear (Figure 4).
15
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 4 -- Selecting Template File in the Select Location Dialog
4. Select the template file location and type. Enter the filename and click Select.
(b) Edit button
Click the Edit button (Figure 2) to edit a template.
To edit a template:
1. In the Report Wizard dialog, select a template and click the Edit button. The Edit Template
dialog will appear (Figure 5).
Figure 5 -- Edit Template Dialog
2. Edit the template name, description, and locate the template file location.
16
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Table 2 -- Edit Template Dialog Fields and Buttons
Field Name
Description
Default Value
Possible
Value
Required
Name
Edit the template name.
Existing name
Text
Yes
Description
Edit the template description.
Existing description
Text
No
Template file
Change the RTF template.
Existing template file
Text
Yes
Save
Save the edited template
under the Template Tree.
Enable
Enable/
Disable
-
Cancel
Close the dialog.
Enable
Enable/
Disable
-
Category
Choose the existing category
Existing Category
or enter a new category name.
Text
No
(c) Delete button
Click the Delete button (Figure 2) to delete a template.
To delete a template:
1. In the Report Wizard dialog, select a template and click the Delete button. The Confirm
delete dialog will appear (Figure 6).
Figure 6 -- Confirm Delete Dialog
2. Click either Yes to delete the selected template from the template list or No to cancel the
operation.
(d) Open button
Click the Open button (Figure 2) to open a template file in the default editor.
To open a template field in the default editor:
• In the Report Wizard dialog, select a template and click the Open button. The template file will open in
the default editor.
(e) Variable button
Click Variable button (Figure 2) to create a new template variable, modify or delete an existing template variable, using the Template Variables dialog (Figure 7).
17
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 7 -- Variables Dialog
Table 3 -- Variables Dialog Fields and Buttons
Field Name
Function
Default
Value
Possible
Value
Required
Name
To enter the variable name.
Blank
Text
Yes
Value
To enter the variable description.
Blank
Text
No
New
To create a new template description.
Enable
Enable/
Disable
-
Cancel
To close the dialog.
Enable
Enable/
Disable
-
The Variables dialog (Figure 7) has the (i) Variable pane and (ii) Control buttons.
(i) Variable Pane
This pane consists of a report description table and the Variable Value text box. The first column of the table is
the variable name and the second column is the variable value. Use the Variable Value text box to view and
edit the value of a selected variable.
(ii) Control Buttons
There are two control buttons: OK and Cancel.
18
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
To create a new variable:
1. In the Report Wizard dialog, select a template and click the Variable button. The New
Variable dialog will appear (Figure 8).
Figure 8 -- New Variable Dialog
2. Type the variable name and value and click Create. You will see the newly created variable
name and value in the Variable pane.
3. In the Variables dialog, click OK.
You can modify a variable value by using either the (i) Variable pane or (ii) Value pane.
(i) To modify a value by using the Variable pane:
• Click a variable name column in the table in the Variable pane and modify the value in the table
(Figure 9).
19
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 9 -- Modifying Value in Field Value
(ii) To modify a variable value through the Value pane:
1. Click a variable value column in the table in the Variable pane and click the “...” button
(Figure 10). The Value pane will appear.
2. Modify the value and click OK (Figure 11).
20
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 10 -- Modifying Variable Value by Clicking the “...” Button
Figure 11 -- Variable Value Pane
3. When you finish modifying variables and their values in the Variables dialog, click either OK
to confirm the changes or Cancel to discard them.
21
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
To delete a variable:
1. Select a variable in the table and click the Delete button. The Confirm delete dialog will
appear.
2. Click Yes to delete the selection (Figure 12).
Figure 12 -- Confirm Delete Dialog
(f) Clone button
Click the Clone button (Figure 2) to clone a template.
To clone a template:
1. In the Report Wizard dialog, select a template and click the Clone button. The Clone
Template dialog will appear (Figure 13).
Figure 13 -- Clone Template Dialog
2. Enter the name and description. The name of a clone template should begin with Copy of
(the name).
3. Click the Create button to clone the template.
22
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Table 4 -- Clone Template Dialog Fields and Buttons
Field Name
Description
Default Value
Possible
Value
Required
Name
Enter a new template name.
Copy of the selected
template name
Text
Yes
Description
Enter the template description.
Existing description
Text
No
Create
Create a template.
Enable
Enable/
Disable
No
Cancel
Close the dialog.
Enable
Enable/
Disable
No
(g) Import button
Click the Import button (Figure 2) to import a template.
To import a template:
1. In the Report Wizard dialog, click the Import button. The Select Location dialog will appear
(Figure 14).
Figure 14 -- Select Location Dialog
2. Select a Report Wizard template with the filename extension *.mrzip and click Open. The
following Message dialog will open (Figure 15).
23
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 15 -- Message Dialog of Successful Import
(h) Export button
Click the Export button (Figure 2) to export a template.
To export a template:
1. In the Report Wizard dialog, select a template and click the Export button. The Select
Location dialog will open (Figure 16).
Figure 16 -- Select Location Dialog
2. Select the template destination where to export, type the filename, and click Save.
3. The following Message dialog will open (Figure 17). Click OK.
24
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 17 -- Message Dialog of Successful Export
1.1.2.2 Report Data Management Pane
Report Wizard allows you (i) to create a report data and (ii) organize its variables. You can now create a report
data as an element in the containment tree inside a MagicDraw project by using profiles. By doing so, you will
be able to commit the report data to Teamwork Server and share it with other users.
You can also create child variables under any variables. This will help you organize information into groups,
keep revision history, etc.
(i) Creating a Report Data
A report data is a collection of variables.
(ii) Organizing Its Variables
Variables are created because some information is not “naturally” contained in a model, for example, the company's name, author's name, revisions, etc. Although you can put all the information in a model's specification
(Document/Hyperlinks in the Specification dialog), it is very hard and tedious to get data from the model's specification as this results in more lines of codes and scripts in the report templates. So instead of writing lines of
codes, you can simply create a variable, give it a name, and call it directly from the template. For example, you
can create a variable called “Author” in Report Wizard, and just write $Author in the template, and then the
report will show the value inside “Author.” In short, a variable is something which you want in the report but also
something which is not or is not supposed to be in the model.
Figure 18 below shows the Select Report Data pane.
25
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 18 -- Report Data Management Pane
Use the Report Data Management pane to select and organize a report data and its variables. Report Wizard
provides a built-in report data for every predefined template. A detailed description of the report data will be displayed in the lower part of the Select Report Data pane.
You can:
• create, edit, delete, and clone a report data
• use the Variable button to organize variables in a report data.
The Select Report Data pane (Figure 18) has (a) New, (b) Edit, (c) Delete, (d) Clone, and (e) Variable buttons.
(a) New button
Click the New button to create a new report (Figure 18).
To create a new report:
1. Click the New button. The New Report Data dialog will appear (Figure 19).
26
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 19 -- New Report Data Dialog
2. Enter the new report name and description, and then click Create.
Table 5 -- New Report Data Fields and Buttons
Field Name
Description
Default Value
Possible Value
Required
Name
Enter the report name.
Blank
Text
Yes
Description
Enter the report description.
Blank
Text
No
Create
Create the report.
Disable
Enable/Disable
-
Cancel
Close the dialog.
Enable
-
-
(b) Edit button
Click the Edit button to edit a report data (Figure 18).
To edit a report data:
1. Click the Edit button. The Edit Report Data dialog will appear (Figure 20).
Figure 20 -- Edit Report Dialog
2. Edit the report name and description, and then click Save.
27
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Table 6 -- Edit Report Data Dialog Fields and Buttons
Field Name
Description
Default Value
Possible Value
Required
Name
Edit the report name.
Existing Name
Text
Yes
Description
Edit the report description. Existing
Description
Text
No
Save
Save the report.
Enable
Enable/Disable
-
Cancel
Close the dialog.
Enable
Enable/Disable
-
(c) Delete button
Click the Delete button to delete a report (Figure 18).
To delete a report:
1. Click the Delete button. The Confirm delete dialog will appear (Figure 21).
Figure 21 -- Confirm Delete Dialog
2. Click either Yes to delete the selected data or No to cancel the operation.
(d) Clone button
Click the Clone to clone a report button (Figure 18).
To clone a report:
1. Click the Clone button. The Clone Report dialog will appear (Figure 22).
Figure 22 -- Clone Report Dialog
28
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
2. Enter the name and description of the report. The name should begin with Copy of (clone
report name).
3. Click the Create button. The cloning report data will then be created (Figure 23).
Table 7 -- Clone Report Dialog Fields and Buttons
Field Name
Description
Default Value
Possible
Value
Required
Name
Enter the report name.
Copy of the selected
report name
Text
Yes
Description
Enter the report description.
Existing Description
Text
No
Create
Create the clone report.
Enable
Enable/
Disable
-
Cancel
Close the dialog.
Enable
Enable/
Disable
-
NOTE
Whenever a clone report data is created, a copy of the report data (variable) will also be
created.
Figure 23 -- Copy of My Report is Created in Report Data Management Pane
(e) Variable button
Click the Variable to create a new variable button (Figure 18).
29
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
To create a new variable:
1. Click the Variable button. The New Variable dialog will then open.
2. Type the variable name and value, and then click Create.
Creating Report Data and Its Variables
You can create a report data either (i) in Report Wizard where all data will be saved into an XML file or (ii) in a
MagicDraw project, in which case the report data will be saved alongside with the project itself. Saving a report
data in a project will enable you to commit the report to Teamwork Server.
(i) Creating a Report Data in Report Wizard
To create a report data in Report Wizard:
1. Open the Select Report Data pane.
2. Click the New button (Figure 24).
Figure 24 -- Creating Report Data
3. Enter the new report name and description in the New Report Data dialog (Figure 25).
30
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 25 -- Entering Report Name and Description
4. Click Create.
(ii) Creating a Report Data in a MagicDraw Project
Before creating a report data in a MagicDraw project, you need to use a report profile, Report Profile.mdzip, which is located in the <install.root>\profiles folder.
To use a report profile (Report Profile.mdzip):
1. Click File > Use Module... on the MagicDraw main menu (Figure 26). The Use Module
dialog will open (Figure 27).
Figure 26 -- Use Module Menu
31
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 27 -- Use Module Dialog
2. Click the From predefined location button in the Select module file pane (Figure 28).
32
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 28 -- Selecting Module File
3. Select <install/root>\profiles as the project module path (Figure 29).
33
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 29 -- Selecting Project Module Path
4. Select Report Profile.mdzip and click Finish. The “Report Profile” profile will open in the
Containment tree as a read-only profile. You can now use it in your project.
To create a report data in a MagicDraw project:
1. Use Report Profile.mdzip in your MagicDraw project (see "To use a report profile (Report
Profile.mdzip):", on page 31).
2. Right-click a data model the Containment tree and select New Element > Report Profile >
Report Data from the shortcut menu (Figure 30).
Figure 30 -- Creating Report Data in MagicDraw Project
34
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
3. Type the name of the report data element in the Containment tree.
You can right-click a data model, package, or profile in the Containment tree to create a report data.
NOTE
Table 8 -- Tag Values of Report Data
Tag Values
Function
autoImageSize
To change the image size.
imageFormat
To select an image format, either JPEG or PNG.
emptyText
To store a string value that will be replaced with an empty variable.
data
Contains elements that will be published by Report Wizard.
template
To determine which template to use a particular report data.
generateRecursively
To determine whether or not a report will be generated recursively.
Creating Variables for Report Data
Variables contain information that you want to store in a project, for example names and dates.
To create a variable for a report data:
• Right-click a report data in the Containment tree and select New Element > Variable (Figure 31). The
variable will appear inside the report data.
Figure 31 -- Creating Variable for Report Data
Creating, Editing, and Deleting Variables
You can create, edit, and delete variables through the Variables dialog in Report Wizard.
35
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
To open the Variables dialog:
1. Click Tools > Report Wizard... on the MagicDraw main menu.
2. Select a report template and click Next (Figure 32).
Figure 32 -- Opening Report Wizard Dialog
3. Either create or select a report data and click the Variable button (Figure 33). The Variables
dialog will open (Figure 34)
36
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 33 -- Opening Variable Dialog
37
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 34 -- Variables Dialog
To create a variable in Report Wizard:
1. Open the Variables dialog (see "To open the Variables dialog:", on page 36 above).
2. Click New. The New Variable dialog will open, fill in the variable name and description
(Figure 35). You can create either (i) a parent variable or (ii) a child variable in the Owner
box.
38
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 35 -- New Variable Dialog
(i) To create a parent variable, type the variable name in the Name box, enter the description,
select an empty value in the Owner box, and then click Create (Figure 36).
39
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 36 -- Creating a Parent Variable
(ii) To create a child variable, type the variable name in the Name box, enter the description,
select Parent in the Owner box, and then click Create (Figure 37).
Figure 37 -- Creating a Child Variable
3. The variable will appear in the table in the Variables dialog.
4. Click OK to save the variables in the report data.
To edit a variable in Report Wizard:
1. Open the Variables dialog (see "To open the Variables dialog:", on page 36 above).
40
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
2. Double-click the column next to the variable name column and click the
button
(Figure 38). A dialog will open for you to edit the variable value.
Figure 38 -- Editing Variables
3. Click OK. The new variable value will appear in the column next to the variable name column.
To delete a variable in Report Wizard:
1. Open the Variables dialog.
2. Click a variable in the table, and then click Delete. A dialog will open prompting you to click
either Yes or No (Figure 39).
41
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 39 -- Deleting Variable
3. Click Yes and the variable will then be deleted.
Including Variables in Templates
When you include the variables you have created in a template, the generated report will print each variable
value. This section will use the following Report Data as an example (Figure 40).
Figure 40 -- Sample of Report Data
To get the value of a top-level variable:
1. Open a blank document in Microsoft Word.
2. Type: $Parent (Figure 41).
42
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 41 -- Referencing to Parent Variable in the Template
3. Save the file as “sampletemplate.rtf”. Choose Rich Text Format (*.rtf) as the file type
(Figure 42).
Figure 42 -- Saving Template as .rtf File in Microsoft Word
4. Open the Report Wizard dialog and create a new template by clicking the New button. The
New Template dialog will open.
43
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
5. Type the name and description of the new template, and select “sampletemplate.rtf” as the
template file.
6. Click Create > Next. The Select Report Data pane will open.
7. Select My Report Data and click Generate to generate a report.
8. The output of the generated report will be as shown in Figure 43:
Figure 43 -- Output of $parent after Report Generation
To get the value of the child of a variable:
1. Open a blank document in Microsoft Word.
2. Type any the following to print a child variable (Figure 44):
(i) $Parent.get(1): to get a child value by referencing its name (in this case “Child”)
(ii) $Parent.get(“Child”): to get a child value by name comparison.
(iii) $Parent.Child: to get a child value by index.
44
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 44 -- Referencing to Child Variable in the Template
3. Save the file as “sampletemplate.rtf”. Choose Rich Text Format (*.rtf) as the file type.
4. Open the Report Wizard dialog and create a new template by clicking the New button. The
New Template dialog will open.
5. Type the name and description of the new template, and select “sampletemplate.rtf” as the
template file.
6. Click Create > Next. The Select Report Data pane will open.
7. Select My Report Data and click Generate to generate a report.
8. The output of the generated report will be as shown in Figure 45:
Figure 45 -- Output of $Parent.Child, $Parent.get("Child"), and $Parent.get(0)
45
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
1.1.2.3 Select Element Scope Pane
The Select Element Scope pane (Figure 46) allows you to select the scope of MagicDraw data to generate
reports.
Figure 46 -- Select Element Scope Pane
The table below describes the detail of each component in the Select Element Scope pane.
Table 9 -- Components in the Select Element Scope Pane
Component Name
Action
All data tree
Select the desired packages from the All Data tree, then add them to the
Selected Objects tree.
Selected objects
tree
Select packages and click the Add, Add All, or Add Recursive button. The
selected packages will be added to the Selected Objects tree.
Add button
Select packages and click Add. The selected packages will be added to the
Selected Objects tree.
Add All button
Select packages and click Add All. The selected packages and one level
inside the package will be added to the Selected Objects tree.
Add Recursive
button
Select packages and click Add Recursive. The selected packages and its
recursive packages will be added to the Selected Objects tree.
Remove button
Select packages and click Remove. The selected packages will be
removed from the Selected Objects tree.
Remove All button
Click Remove All and all packages in the Selected objects tree will be
removed.
You can perform the following operations in the Select Element Scope pane:
46
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
(i) Add packages into the selected object tree.
(ii) Remove a selected package from the selected object tree.
(iii) Select or clear the Generate Recursively option.
(iv) Show auxiliary resources.
(v) Show only package elements.
(i) To add packages:
• In the Select Element Scope pane (Figure 46), select the packages from the All data tree and click
Add, Add All, or Add Recursively to add them into the Selected objects tree.
(ii) To remove packages:
• In the Select Element Scope pane (Figure 46), select the packages from the Selected objects tree
and click Remove or Remove All to remove them from the Selected objects tree.
(iii) To select or clear the Generate Recursively option:
• Select or clear the Generate Recursively check box in Figure 46.
(iv) To show auxiliary resources:
• Select or clear the Auxiliary Resources check box in Figure 46.
(v) To show only package elements:
• Select or clear the Show Only Package Element check box in Figure 46.
NOTE
Figure 46 shows the UML 2 Elements package and the Generate Recursively check box
were selected. It means that the UML 2 Elements package and its subpackages will be
generated in the report.
1.1.2.4 Generate Output Pane
The Generate Output pane in Report Wizard allows you to configure report files, for example, to select the
report files output location, image format, and to display the report in the viewer (Figure 47).
47
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 47 -- Generate Output Pane
48
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Table 10 -- Components in Generate Output Pane
Component Name
Function
Report File
To show the report file location and name. The default report location will
be \data\template_folder\reports\. The default report name will be the
same as the report name defined by the user.
... button
To open the Select Location dialog in order to locate the report file.
Report Image
Format
To select an image format for your report: JPG, PNG, SVG, EMF, or WMF.
Note:
• Use *.JPG and *.PNG for any template format.
• Use *.SVG for text and HTML templates.
• Use *.EMF and *.WMF for text and Microsoft Office templates
(RTF, DOCX, XLSX, and PPTX).
Auto image size
To change the size and orientation of an image before inserting it into a
document. There are 4 options available:
• No Resize: image will not be resized or rotated.
• Fit image to paper (large only): large image will be fitted into the
paper size.
• Fit and rotate (clockwise) image to paper (large only): large
image will be fitted into the paper size and rotated clockwise.
• Fit and rotate (counter-clockwise) image to paper (large
only): large image will be fitted into the paper size and rotated
counter-clockwise.
Display empty
value as
• Empty text: to empty the value of the report output.
Display in viewer
after generating
report
To display a complete report in the viewer. Otherwise, the report will be
created and kept in the selected location.
Generate
To generate a report.
Cancel
To cancel the report generation process and close the Report Wizard dialog.
• Custom text as: to enter a custom value. The default value is NA.
1.2 MRZIP File Automatic Deployment
An MRZIP file is a report template package file. You can place an MRZIP file into your template folder “<user
folder>/data/reports” and MagicDraw will automatically deploy the template into the Report Wizard dialog.
Figures 48, 49, and 50 below will show you how Report Wizard can automatically deploy the MRZIP file.
49
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
MagicDraw Report Wizard Overview
Figure 48 -- Copying MRZIP File into a Template Folder
Figure 49 -- Automatic Deployment of MRZIP File
Figure 50 -- Report Template Installed in the Report Wizard Dialog
50
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Language
2. Report Wizard Template Language
Report Wizard is built on Velocity Engine. Knowledge of the Velocity Template Language and the Report Wizard Custom Language used within the Report Wizard template is necessary for understanding, editing, or creating templates.
2.1 Velocity Template Language
The user guide for Velocity (VTL) can be found at: http://velocity.apache.org/engine/devel/user-guide.html.
NOTE
• The formal reference such as ${hello} is not supported in RTF templates.
• A macro cannot be used as any macro parameter in RTF report template. This is a
limitation of VTL itself: Velocity treats a macro like copy-and-paste content defined in
the macro (between #macro and #end) at the inserted position.
• In an RTF report template, the style and formatting defined on a directive will have no
effect on the report output. In addition, the paragraph symbol at the end of line will
also be removed.
2.2 Report Wizard Custom Language
2.2.1 #forrow Directive
The Velocity Template Language does not support loops inside a table structure. However, the Report Wizard
engine introduces a new custom syntax that allows for looping inside the table structure in order to clone the
table rows.
The syntax: #forrow <query data> #endrow
For example:
Name
Owner
#forrow ($uc in $UseCase) $uc.name
$uc.owner.humanName #endrow
The output will be:
Name
Owner
UC1
Package Requirement
UC2
Package Requirement
2.2.2 #forpage Directive
The #forpage directive is used to provide a loop over the codes within a page. This directive provides implementation like #forrow, but it creates a loop over a page instead of a row.
Example:
#forpage($uc in $UseCase)
$uc.name
#endpage
The report will contain a UseCase name for each document page.
51
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Language
2.2.2.1 OpenDocument Specific Usage
When this directive appears in the OpenDocument Presentation template, it will create a loop over all directives
that are present on the current page. All directives on this page will be included inside #forpage (Figure 52).
Figure 51 -- OpenDocument Presentation #forpage Template
Figure 52 -- OpenDocument Presentation #forpage Template - UseCase
Figures 51 and 52 are sample templates that generated the same output. For more information, see the OpenDocument Presentation template section.
Figure 53 -- OpenDocument Spreadsheet for #forpage Template
Figure 53 displays an example of the #forpage directive inside an ODS file. When this directive is used in an
ODS template, it will create a sheet for codes within the template sheet.
Figure 54 shows the output produced from the template.
Figure 54 -- OpenDocument Spreadsheet Output for #forpage Template
52
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Language
2.2.3 #forcol Directives
This directive is designed only for the Spreadsheet templates, which are ODS and XLSX. This directive provides looping over the column.
Figure 55 -- OpenDocument Spreadsheet #forcol Template
Based on the sample in Figure 55, the engine will generate a report with different columns for each Use Case
name. The output from this sample will be as follows:
Figure 56 -- OpenDocument Spreadsheet #forcol Output
You can combine both #forrow and #forcol and produce a more complex output report (Figure 57).
Figure 57 -- OpenDocument Spreadsheet #forrow and #forcol Templates
Figure 58 is the output generated from the Magic Library sample project.
Figure 58 -- OpenDocument Spreadsheet #forrow and #forcol Output Report
Since the #forrow syntax is similar to the #foreach syntax, the #foreach syntax can then be used in
#forrow.
More samples about the usage of #forrow and #forcol can be found in the Report Wizard dialog “Other
Document” templates.
53
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Language
2.2.4 #includeSection Directive
The original Velocity Engine provides two include directives: (i) #include and (ii) #parse.
(i) #include allows you to import another template. The contents of the file will not be rendered through the
template engine.
(ii) #parse allows you to import another template. The contents of the file will be rendered through the template
engine. However, the file being included will be inserted with all contents.
Report Wizard introduces a statement, which allows a template to include any section of a document from
another template. This statement requires the template to define the beginning and the end of the section.
The logical concept of the #includeSection and #parse directives is similar. Both directives allow a template to include another template and render it through the template engine. However, #includeSection
can be used to specify only the section that you would like to include.
To declare a section:
#sectionBegin (sectionName)
...
#sectionEnd
To include a section:
#includeSection (templateFilename, sectionName)
2.2.5 #include, #parse, and #includeSection: A Comparison
The #include and #parse directives are built-in directives provided by Velocity. The #includeSection
directive is a custom directive implemented by MagicDraw. Table 11 on page 54 below shows the differences
among these three directives.
Table 11 -- Directives Differences
#include
#parse
#includeSection
Execution
Time
Executed at runtime.
Executed as a separate
template at runtime.
Executed at translation
time.
Variable
Scope
Variables declared in the
parent template are not
accessible in the
included page.
Variables declared in
the parent template can
be accessed in the
included page.
Variables declared in the
parent template can be
accessed in the included
page.
Rendering
The Include template is
not rendered through the
template engine.
The Include template is
rendered through the
template engine as a
separate process.
The Include template is
rendered through the
template engine as a
single process.
Include only
required
section
No
No
Yes
Size of parent
template
The size of the parent
template remains
unchanged.
The size of the parent
template remains
unchanged.
The size of the parent
template is increased by
the included section.
54
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Language
#include
#parse
#includeSection
Processing
overhead
The #include directive
increases the processing
overhead with the
necessity of an additional
call to the template
engine.
The #parse directive
increases the
processing overhead
with the necessity of an
additional call to the
template engine.
The #includeSection
directive does not
increase the processing
overhead.
Support RTF
template
No
No
Yes
Support ODF
template
No
No
Yes
Support DOCX
template
No
No
Yes
Support XLSX
template
No
No
No
Support PPTX
template
No
No
No
55
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Template Variables
3. Template Variables
The variables imported to the template are collected by the type of the element selected on the package scope.
Use the fourth step of Report Wizard dialog to select the package scope (see subsection 1.1.2.3 above).
If we take, for example, a class diagram with the class name Customer, (Figure 59), to print.
Figure 59 -- Class Diagram: Customer
To print the attribute of the Customer class in a report:
• Right-click and open the Specification dialog. The element type will appear on the dialog title and the
attribute name will appear on the right-hand side of the dialog box (Figure 60).
Figure 60 -- Specification Dialog
56
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Template Variables
You can print other attributes of a Class element by using the following VTL code:
#foreach ($class in $Class)
Name: $class.name
Owner: $class.owner.name
Visibility: $class.visibility
Is Abstract: $class.isAbstract
#end
The output will be:
Name: Customer
Owner: com
Visibility: public
Is Abstract: false
There are additional properties, which are not part of the UML specifications, but retrievable by Report Wizard
(Table 12).
Table 12 -- Additional Properties Retrievable by Report Wizard
Element Owner
Property Name
Function
Diagram
to output the diagram image.
Diagram
diagramType
the diagram type.
Element
to output the element image or to print an empty text if
the element does not refer to any diagram.
Element
elementType
to return the name of the type (metaclass / stereotype)
of an element, in lowercase, without space format. For
example,
• return "usecase" for a Use Case,
• return "class" for a Class,
• return "callbehavioraction" for a Call Behavior Action,
• return "flowport" for a Flow Port (a stereotype defined
in SysML).
Element
humanName
texts representing an element object. In general, a
human name consists of a string concatenation
between the human element type and element name.
Element
humanType
text representing the element type.
Element
appliedStereotype
the applied stereotype.
Element
activeHyperlink
the active hyperlink.
Element
hyperlinks
all hyperlinks attached to this element.
Element
toDo
the element to do text.
Element
elementID
the element ID.
Element
documentation
the element comment/documentation.
Element
presentationElement
the OpenAPI presentation element.
Element
typeModifier
the element type modifier.
Element
tags
a list of element tags.
57
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Template Variables
Element Owner
Property Name
Function
Element
text
Return a text representation of the element. In general,
the 'text' property returns a string which "textually represents" this element. The string may be different,
depending on symbol properties and environment
options.
This property returns the result from OpenAPI RepresentationTextCreator.getRepresentedText(Element
element)
Classifier
baseClassifier
the base classifier element.
BehavioredClassifier
realizedInterface
the Classifier Realized Interface.
Package
appliedProfile
a list of profiles applied to the package.
Stereotype
metaClass
the Meta Class for the stereotype.
DurationConstraint
min
the min value.
DurationConstraint
max
the max value.
TimeConstraint
min
the min value.
TimeConstraint
max
the max value.
MultiplicityElement
multiplicity
the multiplicity value.
Property
navigable
the navigable value.
Property
ownedBy
the property owner.
Lifeline
type
the lifeline type.
Message
event
the message event.
Message
operation
the message operation.
Message
signal
the message signal.
Message
number
the message number.
Trigger
eventType
to trigger the event type.
RequirementsUseCase
number
the use case number.
Some predefined variables, which are not part of the UML specifications, but usable in templates:
• $elements: contains a list of all the elements selected from the element scope.
• $packageScope: contains a selected package from the element scope.
• $empty: contains a String for empty value, which is specified from the output option pane.
NOTE
58
humanName and humanType are locale specific text. If you plan to generate a report on
different language, try to avoid humanType and humanName. Instead, use elementType
for non locale specific report.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
4. Helper Modules
For more details on element types, see OpenAPI.
4.1 $report
This module is a utility module enabling a template to get MagicDraw data.
$report.containsStereotype(element, stereotypeName)
Returns true if the element contains a stereotype for the specified stereotype name.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr The element to be checked.
aw.classes.mdkernel.Element
stereotypeName
java.lang.String
The stereotype name to be
tested.
-
boolean
True, if the element contains a
stereotype for the specified
stereotype name.
$report.createValueSpecificationText(specification)
Creates texts representing the ValueSpecification element.
Name
Parameter(s) specification
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A given ValueSpecification.
aw.classes.mdkernel .ValueSpecification
java.lang.String
A String value for ValueSpecification.
$report.filterDiagram(diagramList, digramTypes)
Returns a collection of diagrams from the diagram list filtered by types.
Name
Type
Description
java.util.Collection
A collection of diagrams.
digramTypes
java.util.Collection
A collection of diagram types
used as filters.
-
java.util.Collection
A collection of filtered diagrams.
Parameter(s) diagramList
Return
Example:
#foreach($diagram in
$report.filterDiagram($Diagram,["Class
Diagram","Communication Diagram"]))
$diagram.name : $diagram.diagramType
#end
$report.filterElement(elementList, humanTypes)
59
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns a collection from the element list filtered by types.
Name
Type
Description
java.util.Collection
A collection of elements.
humanTypes
java.util.Collection
A collection of human types
used as filters.
-
java.util.Collection
A collection of filtered elements.
Parameter(s) elementList
Return
Example:
#foreach($element in $report.filterElement($elements,
["Use Case", "Actor"]))
$element.name : $element.humanType
#end
$report.filter(elementList, propertyName, propertyValue)
Returns a collection of elements filtered by a specified property name.
Name
Parameter(s) elementList
Type
Description
java.util.Collection
A collection of elements.
propertyName java.lang.String
A property name.
propertyValue
java.util.Collection
A collections of property
names used as filters.
java.util.Collection
A collection of filtered elements.
Return
For example:
#foreach ($e in $report.filter($elements, "name",
["foo", "bar"]))
$e.name
#end
$report.findElementInCollection(elementList, name)
Finds an element in the collection by name.
Name
Type
Description
java.util.Collection
A collection of elements.
name
java.lang.String
An element name.
-
com.nomagic.uml2.ext.magicdr An element instance, if it canaw.classes.mdkernel.Element
not find the element, it will be
returned as null.
Parameter(s) elementList
Return
$report.findRelationship(modelPackage)
60
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Searches and returns a collection of relationship elements inside the package.
Name
Parameter(s) modelPackReturn
Type
Description
age
com.nomagic.uml2.ext.magicdr A package element.
aw.classes.mdkernel.Package
-
java.util.Collection
A collection of relationships in
a package.
$report.findRelationship(modelPackage, recursive)
Searches and returns a collection of relationship elements inside the package.
Name
Parameter(s) modelPack-
Return
Type
Description
age
com.nomagic.uml2.ext.magicdr A package element.
aw.classes.mdkernel.Package
recursive
boolean
If true, performs recursively.
-
java.util.Collection
A collection of relationships in
a package.
$report.getAppliedStereotypeByName(element, stereotypeName)
Returns the stereotype assigned to the element.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
stereotypeName
java.lang.String
A stereotype name.
-
com.nomagic.uml2.ext.magicdr An assigned stereotype with
aw.mdprofiles.Stereotype
the specified name.
$report.getBaseClassAssociations(classifier)
Gets associations of the classifier.
Name
Parameter(s) classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A classifier.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of associations.
$report.getBaseClassInheritableAttributes(classifier)
Gets inheritable attributes of the classifier.
Name
Parameter(s) classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A classifier.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of attributes.
$report.getBaseClassInheritableOperations(classifier)
61
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Gets inheritable operations of the classifier.
Name
Parameter(s) classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A classifier.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of operations.
$report.getBaseClassPorts(classifier)
Gets ports of the classifier.
Name
Parameter(s) classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A classifier.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of ports.
$report.getBaseRealizedInterfaces(behavioredClassifier)
Gets realized interfaces of the behaviored classifier.
Name
Parameter(s) behaviored-
Classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A BehavioredClassifier.
aw.commonbehaviors.mdbasicbehaviors.BehavioredClassifier
java.util.Collection
A collection of RealizedInterfaces.
$report.getBaseRelations(classifier)
Gets relations of the classifier.
Name
Parameter(s) classifier
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A classifier.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of relations.
$report.getBaseClassifiers(child)
Returns based elements of the classifier.
Name
Parameter(s) child
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A child class.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of base elements
(classifiers).
$report.getClientElement(element)
Returns the client of the relationship.
Name
Parameter(s) element
62
Type
Description
com.nomagic.uml2.ext.magicdr A relationship model element.
aw.classes.mdkernel.Element
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
com.nomagic.uml2.ext.magicdr The relationship’s client.
aw.classes.mdkernel.Element
$report.getComment(element)
Returns the documentation of the given element.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.lang.String
The documentation of the element.
$report.getDerivedClassifiers(parent)
Returns derived elements of the classifier.
Name
Parameter(s) parent
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A parent class.
aw.classes.mdkernel.Classifier
java.util.Collection
A collection of derived elements (classifiers).
$report.getDiagramElements(diagram)
Gets elements from a diagram.
Name
Parameter(s) diagram
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A diagram instance.
aw.classes.mdkernel.Diagram
java.util.Collection
A collection of elements in the
diagram.
$report.getDiagramType(diagram)
Returns a diagram type.
Name
Parameter(s) diagram
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A diagram instance.
aw.classes.mdkernel.Diagram
java.lang.String
A diagram type.
$report.getDSLProperty(element, propertyName)
Returns the DSL Property.
Name
Parameter(s) element
Return
63
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
propertyName java.lang.String
A property name.
-
A property value.
java.lang.Object
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$report.getElementComment(element)
Returns a comment attached to an element. If the comment is not attached, it will null.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
com.nomagic.uml2.ext.magicdr A comment instance of the
aw.classes.mdkernel.Comment element.
$report.getElementName(element)
Gets an element name. If the name is empty, it will return "<unnamed>". This method performs the following
procedures:
1. If the element is generalized from NamedElement, it will return $element.name
2. If the element is generalized from Slot, it will return $element.definingFeature.name
3. If the element is a UML element, it will return $element.humanName
4. Else return $element.toString()
Name
Parameter(s) element
Return
-
Type
Description
java.lang.Object
An element.
java.lang.String
An element name.
$report.getIconFor(element)
Returns an image icon for an element.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.magicdraw.uml.B A MagicDraw element.
aseElement
com.nomagic.magicreport.Image
An image object for the element's icon.
$report.getIconFor(type)
Returns an image icon for an element.
Name
Parameter(s) type
Return
-
Type
Description
java.lang.String
The type name.
com.nomagic.magicreport.Image
An image object for the element icon.
$report.getIncludeUseCase(useCase)
Returns included elements of a UseCase.
Name
Parameter(s) useCase
64
Type
Description
com.nomagic.uml2.ext.magicdr A UseCase instance.
aw.mdusecases.UseCase
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
java.util.Collection
A collection of included UseCases.
$report.getInnerElement(element)
Returns a collection of inner elements.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.util.Collection
A collection of inner elements.
$report.getInteractionMessageType(message)
Returns an interaction message type.
Name
Parameter(s) message
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An message instance.
aw.interactions.mdbasicinteractions.Message
java.lang.String
A message type.
$report.getMetaClass(stereotype)
Returns a stereotype meta class.
Name
Parameter(s) stereotype
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A stereotype instance.
aw.mdprofiles.Stereotype
java.util.Collection
A collection of Meta Classes.
$report.getPresentationDiagramElements(diagram)
Returns presentation elements in a diagram.
Name
Parameter(s) diagram
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr A diagram instance.
aw.classes.mdkernel.Diagram
java.util.Collection
A collection of elements.
$report.getPresentationElementBounds(diagram, element)
Returns bounds of an element in the form of Polygon objects. The bounds specify the component coordinates
to its diagram.
Name
Parameter(s) diagram
element
65
Type
Description
com.nomagic.uml2.ext.magicdr A target diagram.
aw.classes.mdkernel.Diagram
com.nomagic.uml2.ext.magicdr A presentation element on the
aw.classes.mdkernel.Element
given diagram.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
java.util.List
Returns the bound of an element as a Polygon. If the element is not found in the
diagram, it will return null.
$report.getPresentationElementRectangle(diagram, element)
Returns bounds of an element in the form of a Rectangle object. The bounds specify the component coordinates to its diagram.
Name
Parameter(s) diagram
Return
Type
Description
com.nomagic.uml2.ext.magicdr A target diagram.
aw.classes.mdkernel.Diagram
element
com.nomagic.uml2.ext.magicdr A presentation element on the
aw.classes.mdkernel.Element
given diagram.
-
java.util.List
Returns the bound of an element as a Rectangle. If the
element is not found in the
diagram, it will return null.
$report.getQualifiedName(namedElement, separator)
Get a qualified name. Qualified is a name that allows the NamedElement to be identified within a hierarchy of
nested Namespaces. It is constructed from the names of the containing namespaces starting at the root of the
hierarchy and ending with the name of the NamedElement itself.
Name
Type
Description
NamedElement
A NamedElement.
separator
java.lang.String
Separator symbol. If the value
is null or an empty string, the
'::' will be used.
-
java.lang.String
A qualified name.
Parameter(s) namedEle-
ment
Return
$report.getPackageQualifiedName(namedElement, separator)
Get a qualified name by considering only Packages and the given element. Models and Profiles will not be
included on the qualified name.
For example, given the element hierarchy:
Design : Model -> com : Package -> nomagic : Package -> ui -> Package -> BaseDialog
: Class
and the template code:
$report.getPackageQualifiedName($class, ".")
If $class is “BaseDialog” element, the result from the above template code will be:
66
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
com.nomagic.ui.BaseDialog
Name
Type
Description
NamedElement
A NamedElement.
separator
java.lang.String
Separator symbol. If the value
is null or an empty string, the
'::' will be used.
-
java.lang.String
A qualified name.
Parameter(s) namedEle-
ment
Return
$report.getRecievingOperationalNode(element)
Gets the needline association ends.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
com.nomagic.uml2.ext.magicdr A needline association
aw.classes.mdkernel.Element
instance.
$report.getRelationship(element)
Returns an element’s relationship.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.util.Collection
A collection of relationships.
$report.getRelationship(element, recursive)
Returns a collection of element relationships.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.element
recursive
boolean
If true, performs recursively.
-
java.util.Collection
A collection of relationships.
$report.getRelativeActor(element)
Returns an element’s relative actor.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.util.Collection
A collection of actors.
$report.getSendingOperationalNode(element)
67
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns the needline association ends.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
com.nomagic.uml2.ext.magicdr A needline association
aw.classes.mdkernel.Element
instance.
$report.getStereotypeProperty(element, stereotypeName, propertyName)
Gets a stereotype property.
Name
Parameter(s) element
stereotypeName
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.lang.String
A stereotype name.
propertyName java.lang.String
A property name.
-
A property value.
java.lang.Object
$report.getStereotypePropertyString(element, stereotypeName, propertyName)
Returns a stereotype property as String value.
Name
Parameter(s) element
stereotypeName
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element instance.
aw.classes.mdkernel.Element
java.lang.String
A stereotype name.
propertyName java.lang.String
A property name.
-
A property value.
java.lang.String
$report.getStereotypes(element)
Returns all stereotypes applied to an element. This method is replaced by $element.appliedStereotype.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
java.util.List
A list of stereotype instances.
$report.getSupplierElement(element)
Returns the supplier of a relationship.
Name
Parameter(s) element
Return
68
-
Type
Description
com.nomagic.uml2.ext.magicdr A relationship model element.
aw.classes.mdkernel.Element
com.nomagic.uml2.ext.magicdr The relationship’s supplier.
aw.classes.mdkernel.Element
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$report.getUsageElements(usagesMap, element)
Returns the usage of a specified element.
Name
Parameter(s) usagesMap
Return
Type
Description
java.util.Map
The Usage Map of MD.
element
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
-
java.util.Collection
A collection of element
usages.
$report.getUsages(selectedObjects)
Returns the Usage Map of MD. Use the getUsageElements method to return the usage of a specified element.
Name
Parameter(s) selectedOb-
Type
Description
java.lang.Object
An element.
java.util.Map
A Map instance of element
usages.
jects
Return
-
$report.hasStereotype(element)
Checks if an element has stereotypes.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element to check.
aw.classes.mdkernel.Element
boolean
True, if it has a stereotype.
$report.containsStereotype(element, stereotypeName)
Returns true if the element contains a stereotype for the specified stereotype name.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element to check.
aw.classes.mdkernel.Element
stereotypeName
java.lang.String
A stereotype name to be
tested.
-
boolean
True, if the element contains a
stereotype for the specified
stereotype name.
$report.isDerivedClassifier(parent, child)
Checks if a child is derived from the parent by generalization.
Name
Parameter(s) parent
child
69
Type
Description
com.nomagic.uml2.ext.magicdr A parent.
aw.classes.mdkernel.Classifier
com.nomagic.uml2.ext.magicdr A possible parent.
aw.classes.mdkernel.Classifier
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
boolean
True, if it is derived by generalization.
$report.isNamedElement( element)
Returns whether an element is a NamedElement.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element to test.
aw.classes.mdkernel.Element
boolean
True, if the given element is a
NamedElement; otherwise
false.
$report.isNull(obj)
Tests and returns true if an object is null.
Name
Parameter(s) obj
Return
-
Type
Description
java.lang.Object
An object being tested.
boolean
True, if the object is null.
$report.isRelationship(element)
Tests and returns true if an element is a relationship.
Name
Parameter(s) element
Return
-
Type
Description
com.nomagic.uml2.ext.magicdr An element being tested.
aw.classes.mdkernel.Element
boolean
True, if the object is a relationship.
$report.serialize(hyperlink)
Converts com.nomagic.magicdraw.hyperlinks.Hyperlink to com.nomagic.magicdraw.plugins.impl.magicreport.helper.Hyperlink. Report Wizard needs the com.nomagic.magicdraw.plugins.impl.magicreport.helper.Hyperlink class wrapper to return com.nomagic.magicdraw.hyperlinks.Hyperlink data.
Name
Parameter(s) hyperlink
Return
-
Type
Description
com.nomagic.magicdraw.hyper
links.Hyperlink
A MagicDraw hyperlink.
com.nomagic.magicdraw.plugins.impl.magicreport.helper.Hyperlink
A Report Wizard hyperlink
instance.
$report.getUsedBy(element)
Return a list of element(s) used by this element (except diagrams).
Name
Parameter(s) element
70
Type
Description
com.nomagic.uml2.ext.magicdr An element you like to find its
aw.classes.mdkernel.Element
usage.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
java.util.Collection
A collection of elements used
by an input element.
$report.hasProperty(element, propertyName)
Returns true when a property with a given name is specified in this element, otherwise returns false.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
propertyName java.lang.String
A property name.
-
Returns true when a property
with a given name is specified
in this element, otherwise
returns false.
java.lang.Boolean
Example:
Figure 61 -- Sample of $report.hasProperty(element, propertyName)
• $element is an element.
• “data” is the name of a property.
$report.findElementByName(source, regex)
Searches and returns elements from names by a regular expression.
Name
Type
Description
java.util.Collection
A collection of elements.
regex
java.lang.String
A regular expression with
which the name is to be
matched.
-
java.util.Collection
A collection of matched elements.
Parameter(s) source
Return
Example:
Figure 62 -- Sample of $report.findElementByName(source, regex)
• $elements is a collection of elements to be found.
• “[A]+.*” is a regular expression to find which name is to be matched. For this example, the following
names are matched names: Auxiliary, AppServer, Alternative Fragment, etc.
71
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$report.getPresentationElements(diagram)
Gets the presentation element in a diagram. This method is equivalent to $report.getPresentationDiagramElements(diagram).
Name
Type
Parameter(s) diagram
Return
Description
com.nomagic.uml2.ext.magicdr A diagram instance.
aw.classes.mdkernel.Diagram
-
java.util.Collection
A collection of elements.
Example:
Figure 63 -- Sample of $report.getPresentationElements(diagram)
• $diagram is a diagram instance.
$report.getUsageRepresentationText(baseElement, bool)
Formats the usage subject. The output string is the same as the Result column of Used by table in Magic Draw.
Name
Parameter(s) baseElement
Return
Type
Description
com.nomagic.magicdraw.uml.B A model element to be formataseElement
ted.
bool
java.lang.Boolean
True if a full path is used, otherwise false.
-
java.lang.String
A formatted element.
Example:
Figure 64 -- Sample of $report.getUsageRepresentationText(baseElement, bool)
• $baseElement is a model element to be formatted.
• False if a full path is not used. For this example do not use a full path.
$report.getUseCaseNumber(element)
Return the use case number of the element.
Name
Parameter(s) element
72
Type
Description
com.nomagic.uml2.ext.magicdr A model element.
aw.classes.mdkernel.Element
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
java.lang.String
An use case number
Example:
#foreach ($uc in $RequirementsUseCase)
$report.getUseCaseNumber($uc) $uc.name
#end
Figure 65 -- Sample of $report.getUseCaseNumber(element)
4.2 $project
This module is a project reference enabling a template to return the project information.
$project.getName()
Returns a project name.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
A project name.
Type
Description
-
-
java.lang.String
A project title.
Type
Description
-
-
java.lang.String
A project filename.
$project.getTitle()
Gets a project title.
Name
Parameter(s) Return
-
$project.getFileName()
Gets a project filename.
Name
Parameter(s) Return
-
$project.getExtension()
Gets a project filename extension.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
A project filename extension.
Type
Description
-
-
$project.getDirectory()
Gets a project directory name.
Name
Parameter(s) -
73
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
java.lang.String
A project directory name.
$project.getVersionList()
Returns a list of version information from an open Teamwork Server project.
Return
NOTE
Name
Type
Description
-
java.util.List<Version>
A list of com.nomagic.teamwork.common.projects.Version.
Version information consists of the following attributes:
• comment: a version committed comment.
• date: a committed date
• dateAsString: a committed date as text
• number: a committed version
• numberAsString: a committed version as text
• user: a committer’s name
Sample of code:
Current version : $project.version
All version:
----------------#foreach ($version in $project.versionList)
Date : $version.date
Number : $version.number
Number as String : $version.numberAsString
User : $version.user
Comment : $version.comment
----------------#end
$project.getType()
Returns a file type. A file type is one of following values:
• 0 – UNDEF
• 2 – XML_NATIVE
• 3 – UNSIYS_XMI
Return
Name
Type
Description
-
int
The value of a file type.
$project.getDiagrams()
74
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns all existing diagrams stored in a particular project.
Return
Name
Type
Description
-
java.util.Collection A collection of diagram instances.
$project.getDiagrams(type)
Returns existing diagrams of a given type stored in a particular project.
Name
Type
Description
Parameter(s)
type
java.lang.String
A diagram type.
Return
-
java.util.Collection
A collection of diagram instances.
Example:
Figure 66 -- Sample of $project.getDiagrams(type)
• “Class Diagram” is a diagram type
$project.getPresentationDiagrams()
Returns all existing presentation diagrams stored in a particular project.
Return
75
Name
Type
Description
-
java.util.Collection A collection of diagram views.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$project.getPresentationDiagrams(type)
Returns existing presentation diagrams of a given type stored in a particular project.
Name
Type
Description
Parameter(s)
type
java.lang.String
A diagram type.
Return
-
java.util.Collection A collection of diagram views.
Example:
Figure 67 -- Sample of $project.getPresentationDiagrams(type)
• “Class Diagram” is a diagram type.
$project.isRemote()
Returns the remote or non-remote state of a project.
Return
Name
Type
Description
-
java.lang.Boolean
Returns true if a project is a remote
project, otherwise false.
$project.isDirty()
Returns true if that particular project was modified after it was last saved or loaded.
Return
Name
Type
Description
-
java.lang.Boolean
Returns true if a project was modified after it was last saved/loaded,
otherwise false.
$project.getElementByID(id)
Returns an element with a given ID.
Name
Type
Description
Parameter(s)
ID
java.lang.String
An element ID.
Return
-
com.nomagic.magic
draw.uml.BaseElement
An element with a given ID or null if
the element with such ID is not registered in the project.
Example:
Figure 68 -- Sample of $project.getElementByID(id)
76
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
• “_9_0_62a020a_1105704887361_983947_8206” is an element ID.
$project.getAllElementId()
Returns a collection of all element IDs in a project.
Return
Name
Type
Description
-
java.util.Collection A collection of all element IDs in a
project.
$project.getXmiVersion()
Returns the XMI version of a project.
Return
Name
Type
Description
-
int
An XMI version.
$project.getVersion()
Returns a project version number.
Return
Name
Type
Description
-
long
A project version number.
$project.getModel()
Returns a model. The root container of all model structures.
Return
Name
Type
Description
-
com.nomagic.uml2.ext. A model.
magicdraw.auxiliaryconstructs.mdmodels.Model
$project.getModuleList()
Returns a list of ModuleDescriptors from an open Teamwork Server project.
Return
Name
Type
Description
-
java.util.Collection
A list of
com.nomagic.magicdraw.core.
modules.ModuleDescriptor.
$project.getSharedModule(module)
Returns a list of shared modules from a specified module.
Name
Type
Description
Parameter(s)
module
com.nomagic.magicdra A module.
w.core.modules.ModuleDescriptor
Return
-
java.util.Collection
A list of
com.nomagic.magicdraw.core.
modules.ModuleDescriptor.
Example:
77
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Figure 69 -- Sample of $project.getSharedModule(module)
• “$module” is a module from Teamwork Server.
4.3 $iterator
This module is used with the #foreach loops. It wraps a list to let you specify a condition to terminate the loop
and reuse the same list in a different loop. The following example below shows how to use $Iterator.
#set ($list = [1, 2, 3, 5, 8, 13])
#set ($numbers = $iterator.wrap($list))
#foreach ($item in $numbers)
#if ($item < 8) $numbers.more()#end
#end
$numbers.more()
Output
-----1 2 3 5
8
$iterator.wrap( list )
Wraps a list with the tool.
Name
Parameter(s) list
Return
-
Type
Description
java.util.List
An array or list instance.
IteratorTool
Returns the IteratorTool
instance.
$<IteratorTool instance>.hasMore()
Checks if the iteration has more elements.
Name
Parameter(s) Return
-
Type
Description
-
-
boolean
Returns true if there are more
elements in the wrapped list.
$<IteratorTool instance>.more()
78
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Asks for the next element in the list.
Name
Parameter(s) -
-
Return
Type
Description
-
-
java.lang.Object
An element instance.
$<IteratorTool instance>.remove()
Removes the current element from the list.
$<IteratorTool instance>.reset()
Resets the wrapper so that it starts over at the beginning of the list.
$<IteratorTool instance>.stop()
Puts a condition to break out of the loop.
$<IteratorTool instance>.toString()
This method will return an object as a string.
4.4 $list
This module is the list module used to work with lists and arrays in the templates. It provides a method to get
and set specified elements. It also provides methods to perform the following actions for a list or an array:
• Checks if it is empty.
• Checks if it contains certain elements.
Example:
-> new int[] {2, 3, 5, 7}
$primes
$list.size($primes)
-> 4
$list.get($primes, 2)
-> 5
$list.set($primes, 2, 1)
-> (primes [2] becomes 1)
$list.get($primes, 2)
-> 1
$list.isEmpty($primes)
-> false
$list.contains($primes, 7)
-> true
$list.contains(list, element)
Checks if a list or array contains certain elements.
Name
Type
Description
-
A list or array instance.
element
-
An element instance.
-
boolean
-
Parameter(s) list
Return
Returns true, if a list or array contains certain elements. Otherwise, returns false.
79
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$list.get(list, index)
Returns a specified element of the List/array.
Name
Type
Description
-
A list or array instance.
index
-
The index of objects in the list.
-
object
Returns an object in the list.
Type
Description
-
An object
boolean
Returns true, if the object is an
array. Otherwise, returns
false.
Parameter(s) list
Return
$list.isArray(object)
Checks if an object is an array.
Name
Parameter(s) object
Return
-
$list.isEmpty(list)
Checks if a list or array is empty.
Name
Parameter(s) list
Return
-
Type
Description
-
A list of objects
boolean
Returns true, if the list/array is
empty. Otherwise, returns
false.
Type
Description
-
An object
boolean
Returns true, if the object is a
List. Otherwise, return false.
$list.isList(object)
Checks if an object is a list.
Name
Parameter(s) object
Return
-
$list.set(list, index, value)
Sets a specified element of the List/array.
Name
Type
Description
-
A list of objects.
index
-
An index of objects in the list.
value
-
An object that will be set in the
list.
-
object
An object previously at the
specified position.
Parameter(s) list
Return
$list.size(list)
80
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns the size of a List/array.
Name
Parameter(s) list
Return
-
Type
Description
-
A list of objects.
Integer
Returns the size of the list as
an Integer instance.
4.5 $bookmark
This module contains utility functions for a bookmark. The functions of this module are accessible from the templates by using $bookmark.
NOTE
In RTF reports, the default style of bookmarks depends on the RTF editor used. For
example, Microsoft Word 2003 displays hyperlinks in blue color.
$bookmark.openURL(url, content)
Creates a hyperlink to open a URL. For example, $bookmark.openURL("http://www.nomagicasia.com","NoMagic Asia").
Name
Type
Description
java.lang.String
A URL text.
content
java.lang.Object
The text content.
-
com.nomagic.magicreport.Link
The content with a hyperlink in
the RTF format.
Parameter(s) url
Return
$bookmark.openURL(url, content)
Creates a hyperlink to open a URL. For example, $bookmark.openURL($url, "NoMagic Asia").
Name
Type
Description
java.net.URL
A URL instance.
content
java.lang.Object
The text content.
-
com.nomagic.magicreport.Link
The content with a hyperlink in
the RTF format.
Parameter(s) url
Return
$bookmark.openURL(url, content)
Creates a hyperlink to open a URL. For example, $bookmark.openURL($url, "NoMagic Asia").
Name
Type
Description
java.net.URL
A URL instance.
content
java.lang.Object
The text content.
-
com.nomagic.magicreport.Link
The content with a hyperlink in
the RTF format.
Parameter(s) uri
Return
$bookmark.open(content)
81
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Creates a hyperlink for a bookmark. The bookmark ID will be automatically generated from the content.
Name
Parameter(s) content
Return
-
Type
Description
java.lang.Object
The text content.
com.nomagic.magicreport.Link
The content with a hyperlink in
the RTF format.
$bookmark.open(bookmarkId, content)
Creates a hyperlink for a bookmark. The bookmark ID value must match the parameter bookmark ID that
passes into the link.
Name
Type
Description
java.lang.String
The bookmark ID.
content
java.lang.Object
The text content.
-
com.nomagic.magicreport.Link
The content with a hyperlink in
the RTF format.
Parameter(s) bookmarkId
Return
$bookmark.create(bookmarkObject)
Creates a bookmark. The bookmark ID will be automatically generated from the bookmark object.
Name
Parameter(s) bookmarkOb-
Type
Description
java.lang.Object
A bookmark object or content.
com.nomagic.magicreport.Bookmark
The content with a bookmark
in the RTF format.
ject
Return
-
$bookmark.create(bookmarkId, bookmarkObject)
Creates a bookmark. The default element type for this function is "label".
Name
Type
Description
java.lang.String
The bookmark ID.
bookmarkObject
java.lang.Object
A bookmark object or content.
-
com.nomagic.magicreport.Bookmark
The content with a bookmark
in the RTF format.
Parameter(s) bookmarkId
Return
$bookmark.create(bookmarkId, bookmarkObject, elementType)
Creates a bookmark with a specified element type.
Name
Type
Description
java.lang.String
The bookmark ID.
bookmarkObject
java.lang.Object
A bookmark object or content.
elementType
java.lang.String
An element type name, for
example, html tag.
-
com.nomagic.magicreport.Bookmark
The content with a bookmark
in the RTF format.
Parameter(s) bookmarkId
Return
$bookmark.getBookmarkId(id)
82
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns a bookmark ID from the given string.
Name
Parameter(s) id
Return
-
Type
Description
java.lang.String
An original string value.
com.nomagic.magicreport.Bookmark
The bookmark ID.
4.6 $sorter
This module is used to sort a collection of report templates.
$sorter.sort(Collection, fieldName)
The sort function for report templates. The context name of this class is "sorter". Use $sorter to access public
functions of this class through the templates.
Name
Type
Description
java.util.Collection
A collection to be sorted
fieldname
java.lang.String
A fieldName to be sorted and
the sort direction.
-
java.util.Collection
A sorted collection.
Parameter(s) collection
Return
Example:
#foreach ($rel in $sorter.sort($package, "name"))
$rel.name
#end
• $package is the collection to be sorted.
• "name:desc" is separated by ":" in two parts:
• The first part is to identify fieldName to be sorted.
• The second part is the option to identify the sort direction. Sometimes, the direction is not
identified. It is ascending by default.
$sorter.sort(Collection)
The sort function for report templates. The context name of this class is "sorter". Use $sorter to access public
functions of this class through the templates.
Example:
#foreach ($rel in $sorter.sort($package))
$rel.name
#end
$package is a collection to sort
Name
Parameter(s) collection
Return
-
Type
Description
java.util.Collection
A collection to be sorted.
java.util.Collection
A sorted collection.
$sorter.sortByFirstNumber(Collection, fieldName)
83
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
The sort by the first number function for report templates. The context name of this class is "sorter". Use
$sorter to access public functions of this class through the templates.
Name
Type
Description
java.util.Collection
A collection to be sorted.
fieldname
java.lang.String
A fieldName to be sorted and
the sort direction.
-
java.util.Collection
A sorted collection.
Parameter(s) collection
Return
Example:
#foreach ($rel in $sorter.sortByFirstNumber($package,
"name:desc"))
$rel.name
#end
• $package is a collection to be sorted by the first number.
• "name:desc" is separated by ":" in two parts:
• The first part is to identify fieldName to be sorted.
• The second part is the option to identify the sort direction. Sometimes, the direction is not
identified. It is ascending by default.
$sorter.sortByFirstNumber(Collection)
The sort by the first number function for report templates. The context name of this class is "sorter". Use $sorter
to access public functions of this class through the templates.
Name
Parameter(s) collection
Return
-
Type
Description
java.util.Collection
A collection to be sorted.
java.util.Collection
A sorted collection.
Example:
#foreach ($rel in $sorter.sortByFirstNumber($package))
$rel.name
#end
• $package is a collection to be sorted by the first number.
$sorter.sortByLocale(Collection, String)
The sort function for report templates. The context name of this class is "sorter". Use $sorter to access public
functions of this class through the templates. To sort the given collection by native language, specify the language by identifying the country code.
Name
Type
Description
java.util.Collection
A collection to be sorted.
countryCode
java.lang.String
The country code to be sorted.
-
java.util.Collection
A sorted collection.
Parameter(s) collection
Return
Example:
#foreach ($p in $sorter.sortByLocale($package, "DE"))
$p.name
#end
84
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
• $package is the collection to be sorted.
• "DE" is the country code for GERMANY (ISO country code).
NOTE
This method performs a sort by the “name” attribute of each element by default.
$sorter.sortByLocale(Collection, String, String)
This is the sort function for report templates. The context name of this class is "sorter". Use $sorter to access
public functions of this class through the templates. To sort the given collection by native language, specify the
language by identifying the country code and field name.
Name
Type
Description
java.util.Collection
A collection to be sorted.
fieldName
java.lang.String
A fieldName to be sorted.
countryCode
java.lang.String
The country code to be sorted.
-
java.util.Collection
A sorted collection.
Parameter(s) collection
Return
Example:
#foreach ($p in $sorter.sortByLocale($package, "name",
“DE”))
$p.name
#end
• $package is the collection to be sorted.
• “name” is the field name to be sorted.
• "DE" is the country code for GERMANY (ISO country code).
$sorter.humanSort(collection, fieldName)
This is a special sort function with human order, which says to split text to be sorted into numeric and nonnumeric chunks, then sort so that the numeric chunks are treated as numbers. This makes "foo10" sorted after
"foo2".
Parameter(s)
Return
Name
Type
Description
collection
java.util.Collection
A collection to be sorted.
fieldName
java.lang.String
A fieldName to be sorted and the
sort direction.
java.util.Collection
A sorted collection.
Example:
Figure 70 -- $sorter.humanSort(collection, fieldName)
• $package is the collection to be sorted.
85
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
• "name:desc" is separated by ":" in two parts:
• The first part is to identify fieldName to be sorted.
• The second part is the option to identify the sort direction. Sometimes, the direction is not
identified. It is ascending by default.
$sorter.humanSort(collection)
A special sort function with human order, which says to split the text to be sorted into numeric and non-numeric
chunks, then sort so that the numeric chunks are treated as numbers. This makes "foo10" sorted after "foo2".
Name
Type
Description
Parameter(s)
Collection
java.util.Collection
A collection to be sorted.
Return
-
java.util.Collection
A sorted collection.
Example:
Figure 71 -- Sample of $sorter.humanSort(collection)
• $package is the collection to be sorted.
4.7 $template
This module is the tool for getting template information.
$template.getName()
Returns the name of the template.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
Returns a template name.
$template.getResourcesLocation()
Returns the folder location of the resource file.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
The location of the resource file
folder.
$template.getTemplateFile()
Returns a template filename.
Name
Parameter(s) Return
86
-
Type
Description
-
-
java.lang.String
Returns a template filename.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$template.getTemplateLocation()
Returns the folder location of a template file.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
The location of a template file
folder.
Type
Description
-
-
java.lang.String
Returns the output filename.
Type
Description
-
-
java.lang.String
The output name.
$template.getOutputFile()
Returns the output filename.
Name
Parameter(s) Return
-
$template.getOutputFileNoExt()
Returns the output name.
Name
Parameter(s) Return
-
$template.getOutputLocation()
Returns the folder location of the output file.
Name
Parameter(s) Return
-
Type
Description
-
-
java.lang.String
Returns the location of an output
file folder.
4.8 $file
This module allows for generating an output report file in a template file.
$file.silentCreate(template)
A shortcut to create a file, the output filename of which is the template name, not an import context object. For
example, $file.silentCreate('overview.html').
Name
Parameter(s) template
Return
-
Type
Description
java.lang.String
The input template name.
void
-
$file.silentCreate(template, importObject)
A shortcut to create a file, the output filename of which is the template name. For example, $file.silentCreate('overview.html','').
87
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Name
Type
Description
java.lang.String
The input template name.
importObject
java.lang.Object
An object reference, which will be
$importer in the template file. You
can use the $importer variable in
the template file to get data.
-
void
-
Parameter(s) template
Return
$file.silentCreate(template, outputFileName, importObject)
Generates a report output from a given template name. For example, $file.silentCreate('overview.html','overview.html','').
Name
Type
Description
java.lang.String
The input template name.
outputFileName
java.lang.String
The output filename.
importObject
java.lang.Object
An object reference, which will be
$importer in the template file. You
can use $importer in the template
file to get data.
-
void
-
Parameter(s) template
Return
$file.silentCreate(templateType, template, outputname, importObject)
Generates a report output from a given template name. For example, $file.silentCreate('html','overview','overview','').
Name
Type
Description
java.lang.String
A template type such as rtf, html,
or htm.
template
java.lang.String
The input pathname string without a filename extension.
outputFileName
java.lang.String
The output filename without a filename extension.
importObject
java.lang.Object
An object reference, which will be
$importer in the template file. You
can use $importer in the template
file to get data.
-
void
-
Parameter(s) templateType
Return
$file.create(template)
A shortcut to create a file, the output filename of which is the template name, not an import context object. For
example, $file.create('overview.html').
Name
Parameter(s) template
Return
88
-
Type
Description
java.lang.String
The input template name.
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$file.create(template, importObject)
A shortcut to create a file, the output filename of which is the template name. For example, $file.create('overview.html','')
Name
Type
Description
java.lang.String
The input template name.
importObject
java.lang.Object
The object reference, which will be
importer in the template file. You
can use the importer variable in
the template file to get data.
-
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Parameter(s) template
Return
$file.create(template, outputFileName, importObject)
Generates a report output from a given template name. For example, $file.create('overview.html','overview.html','').
Name
Type
Description
java.lang.String
The input template name.
outputFileName
java.lang.String
The output filename.
importObject
java.lang.Object
An object reference, which will be
$importer in the template file. You
can use $importer in the template
file to get data.
-
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Parameter(s) template
Return
$file.create(templateType, template, outputname, importObject)
Generates a report output from a given template name. For example: $file.create('html','overview','overview','').
Name
Type
Description
java.lang.String
A template type such rtf, html, htm.
template
java.lang.String
The input pathname string without
a filename extension.
outputname
java.lang.String
The output filename without a filename extension.
importObject
java.lang.Object
An object reference, which will be
$importer in the template file. You
can use $importer in the template
file to get data.
-
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Parameter(s) templateType
Return
$file.copy(inputFilename)
89
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Copies an input file to an output file using the same name in the binary format. For example:
$file.copy('icon.gif').
Name
Type
Description
Parameter(s) inputFilename
java.lang.String
The input filename
-
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Return
$file.copy(inputFilename, outputFilename)
Copies an input file to an output file in the binary format. For example: $file.copy('icon.gif','icon.gif').
Name
Type
Description
java.lang.String
The input filename.
outputFilename:
java.lang.String
The output filename.
-
java.lang.String
The output pathname. It will return
an empty string, if there is an error.
Parameter(s) inputFilename
Return
$file.exists(pathname)
Test whether a file denoted by a specific pathname exists. By default, the current directory will be referred to the
template location.
For example:
$file.exists("$template.resourcesLocation/myimage.png")
$file.exists("C:/myfolder/myimage.png")
$file.exists("mytemplate.txt")
Name
Parameter(s) pathname
Return
-
Type
Description
java.lang.String,
A pathname string.
java.lang.String
True if and only if a file or directory
denoted by the abstract pathname
exists; otherwise, false.
$file.computeName(directory, name)
Creates a pathname string from a given directory and name.
Name
Type
Description
java.lang.String
A parent directory of a file.
name
java.lang.String
A filename (excludes the filename
extension).
-
java.lang.String
A pathname from the given directory and name.
Parameter(s) directory
Return
Example:
$file.computeName('actors', $ac.ID, 'html')
output: 'actor/_123456789.html'
$file.computeName(directory, name, fileType)
90
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Creates a pathname string from a given directory, name, and file type.
Name
Type
Description
java.lang.String
A parent directory of a file.
name
java.lang.String
A filename (excluding extension).
fileType
java.lang.String
A file type, for example rtf, txt, or
html.
-
java.lang.String
A pathname from the given directory, name, and file type.
Parameter(s) directory
Return
4.9 $array
Use $array to create an Array or HashSet instance.
$array.createArray()
Creates an empty ArrayList.
Name
Parameter(s) Return
-
Type
Description
-
-
java.util.List
An instance of ArrayList.
$array.createArray(collection)
Constructs an ArrayList containing elements of the specified collection, in the order they are returned by the
collection's iterator. Returns a zero size ArrayList if the given collection is null.
Name
Parameter(s) collection
Return
-
Type
Description
java.util.Collection
A collection of instances whose
elements are to be placed into a
list.
java.util.List
An ArrayList containing elements
of the specified collection.
$array.subList(list, size)
Creates an ArrayList of a portion of the list in the given size.
Name
Type
Description
java.util.List
An original list.
size
int
A view size of the given list.
-
java.util.List
An ArrayList of a specified view
size within the given list.
Parameter(s) list
Return
$array.addCollection(parent, child)
Adds a child list into a parent collection. It helps the template to handle if the child is null.
Name
Parameter(s) parent
child
91
Type
Description
java.util.Collection
A parent collection.
java.util.Collection
A child collection.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
void
-
Type
Description
-
-
java.util.Set
An instance of HashSet.
$array.createHashSet()
Creates a HashSet instance.
Name
Parameter(s) Return
-
4.10 $group
$group.create()
Create the new instance of a group tool.
Name
Parameter(s) Return
-
Type
Description
-
-
GroupTool
An instance of a group tool.
Type
Description
-
-
void
-
Type
Description
-
-
java.util.Set
A set of group names.
$group.init()
Initializes a group tool.
Name
Parameter(s) Return
-
$group.groupNames()
Returns a set of group names.
Name
Parameter(s) Return
-
$group.contains(groupName)
Tests whether a group name is contained in a set of group names.
Name
Parameter(s) groupName
Return
-
Type
Description
java.lang.String
A group name.
-
True if it contains a group name,
otherwise false.
$group.put(groupName, object)
92
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Adds an object into a group.
Name
Type
Description
java.lang.String
A group name.
object
java.lang.Object
An object being added.
-
void
-
Type
Description
java.lang.String
A group name.
java.util.List
A list of group objects.
Parameter(s) groupName
Return
$group.get(groupName)
Returns a list of group objects.
Name
Parameter(s) groupName
Return
-
$group.remove(groupName)
Removes a group for the specifed group name.
Name
Type
Description
java.lang.String
A group name.
java.util.List
A previous list of group objects
associated with a group name, or
null if there is no group for the key.
Type
Description
-
-
void
-
Type
Description
-
-
void
-
Type
Description
-
-
java.util.HashMap
An instance of HashMap.
Parameter(s) groupName
Return
-
$group.removeAll()
Removes all groups.
Name
Parameter(s) Return
-
$group.clear()
Removes all mappings.
Name
Parameter(s) Return
-
4.11 $map
$map.createHashMap()
Creates a HashMap instance.
Name
Parameter(s) Return
93
-
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
4.12 $date
A tool for accessing and formatting the “current” date.
$date
Displays the current date and time, for example, Oct 19, 2003 and 9:54:50 PM respectively.
$date.long
Displays the current date and time in long format, for example, October 19, 2003 and 9:54:50 PM. respectively.
$date.full_date
Displays the current date in full format for example, Sunday, October 19, 2003.
$date.get('format')
Displays the current date in a specific format, for example, $date.get('yyyy-M-d H:m:s') is displayed as 200310-19 21:54:50.
Table 13 -- Date and Time Format
Letter
Date or Time Component
Example
G
Era designator
AD
y
Year 1996
96
M
Month in year
July; Jul; 07
w
Week in year
27
W
Week in month
2
D
Day in year
189
d
Day in month
10
F
Day of week in month
2
E
Day in week
Tuesday; Tue
a
Am/pm marker
PM
H
Hour in day (0-23)
0
k
Hour in day (1-24)
24
K
Hour in am/pm (0-11)
0
h
Hour in am/pm (1-12)
12
m
Minute in hour
30
s
Second in minute
55
S
Millisecond
978
z
Time zone
Pacific Standard Time; PST; GMT-08:00
Z
Time zone
Time zone -0800
Year
• If the number of pattern letters is 4 or more, a calendar specific long form is used.
• Otherwise, a calendar specific short or abbreviated form is used.
94
Date and Time Pattern
Result
yy
10
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Date and Time Pattern
Result
yyyy
2010
Month
• If the number of pattern letters is less than 3, the number form is used.
• If the number of pattern letters is 3 a short or abbreviated form is used.
• If the number of pattern letters is 4 or more, the full form is used.
Date and Time Pattern
Result
m
4
mm
04
mmm
Apr
mmmm
April
Day in week
• If the number of pattern letters is 4 or more, the full form is used.
• Otherwise, a calendar specific short or abbreviated form is used
95
Date and Time Pattern
Result
E
Mon
EEEE
Monday
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
4.13 $profiling
A tool for accessing MagicDraw meta-model information.
$profiling.getGeneralizationName(modelName)
Returns a generalization model of modelName.
Name
Parameter(s) modelName
Return
-
Type
Description
java.lang.String
A meta-model name.
java.util.Collection<String>
A list of generalization model
names.
$profiling.getDeclaringElementName (modelName, propertyName)
Retrieves the meta-model name which is the declared property name.
Name
Type
Description
java.lang.String
A meta-model name.
propertyName
java.lang.String
A property name.
-
java.lang.String
A meta-model name.
Parameter(s) modelName
Return
$profiling.getPropertyTypeName (modelName, propertyName)
Retrieves property types.
Name
Type
Description
java.lang.String
A meta-model name.
propertyName
java.lang.String
A property name.
-
java.lang.String
A property type name.
Parameter(s) modelName
Return
$profiling.getPropertyTypeName (element, propertyName)
Retrieves property types.
Name
Parameter(s) element
Return
Type
Description
com.nomagic.uml2.ext.magicdr An element.
aw.classes.mdkernel.Element
propertyName java.lang.String
A property name.
-
A property type name.
java.lang.String
$profiling.getElementProperties(modelName)
Retrieves a collection of element property names from meta-model names.
Name
Parameter(s) modelName
Return
-
Type
Description
java.lang.String
A meta-model name.
java.util.Collection<String>
A collection of element property names.
$profiling.getElementProperties(element)
96
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Retrieves a collection of element property names from elements.
Name
Parameter(s) modelName
Return
-
Type
Description
java.lang.String
A meta-model name.
java.util.Collection<String>
A collection of element property names.
$profiling.getElementProperty(element, propertyName)
Retrieves property values of specified elements and property names.
Name
Parameter(s) element
Return
97
Type
Description
com.nomagic.uml2.ext.magicd
raw.classes.mdkernel.Element
An element.
propertyName java.lang.String
A property name.
-
A property object.
java.lang.Object
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$profiling. getHumanPropertyName(element, propertyName)
Returns text representing a property name.
Name
Type
Description
Parameter(s) propertyName
java.lang.String
A property name.
-
java.lang.String
Text representing a property
name.
Return
4.14 $image
$image is an image tool that provides a rich set of image manipulation methods that enable you to transform
images during report generation. Images can be scaled, rotated, and resized.
Syntax
These manipulation methods can be broadly divided into four categories:
4.14.1 Scaling
4.14.2 Rotating
4.14.3 Fixed-Pixels Resizing
4.14.4 Fixed-Measurement Resizing
4.14.5 Include Image
Multiple image transformations will have cumulative effects. Desired sizes can be specified either as pixel
counts or as measurements in inches, centimeters, or millimeters. While the parameters for resizing an image
with a specific measurement (in, cm, mm, pt, or px) must be quoted, all other size parameters do not need to be
quoted.
The keepRatio parameter takes either a true or false value; true will resize the image and keep the original
image height/width ratio; false will only resize one axis, as set by the method name, resulting in a stretched
image.
4.14.1 Scaling
There are two scaling methods that can scale an image using a given factor (for example, 1.5). Method (i) provides height and width parameters (scaleWidth and scaleHeight), while Method (ii) provides a single parameter that will scale both axes equally (scaleFactor). These three parameters must be positive real numbers.
(i) $image.scale(image, scaleWidth, scaleHeight)
Returns an image icon for an element.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
scaleWidth
java.lang.Double
The width parameter of the
image.
scaleHeight
java.lang.Double
The height parameter of the
image.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(ii) $image.scale(image, scaleFactor)
98
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns an image icon for an element.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
scaleFactor
java.lang.Double
The scaling parameter of the
image.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
Use $image.scale($diagram.image, 0.5), for example, to scale down the image to half the original size. The
following photos show the result.
Use $image.scale($diagram.image, 0.8, 0.6)To scale the image’s width down by 80% and height by 60%. The
following photos show the result.
Scaling Quality
The image tool provides several methods for scaling images. The quality of scaled image depends on the algorithm uses. To set the image scaling quality, $image.setScalingQuality() code must be inserted before scaling
images. For example:
99
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$image.setScalingQuality(5)
$image.scale(0.5)
The above code will set the image scaling quality to ‘highest’. The possible values are 1 to 5, where 5 is ‘highest’ and 1 is ‘lowest’.
Value
Description
1
lowest' – Use one step interpolation nearest neighbor.
2
'low' – Use one step interpolation bi-cubic.
3
'medium – Use multi-steps interpolation bi-linear.
4
'high' – Use area average image scaling algorithm.
5
'highest' – Use lossless transformation when template is ODF, DOCX or RTF; otherwise
area average image will be used.
Sample outputs from different image scaling qualities when scaling the image size down by 50%:
100
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
101
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
4.14.2 Rotating
There are two rotating methods that can rotate a given image by 90 degrees: (i) rotateRight for clockwise rotation and (ii) rotateLeft for counterclockwise rotation.
(i) $image.rotateRight(image)
Returns an image icon for an element.
Name
Parameter(s) image
Return
-
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
com.nomagic.magicreport.Ima
ge
The rotated image object for
the element icon.
(ii) $image.rotateLeft(image)
Returns an image icon for an element.
Name
Parameter(s) image
Return
-
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
com.nomagic.magicreport.Ima
ge
The rotated image object for
the element icon.
Use $image.rotateRight($diagram.image), for example, to rotate the image 90 degrees clockwise. The following photos show the result.
102
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Use $image.rotateLeft($diagram.image), for example, to rotate the image 90 degrees counterclockwise. The
following photos show the result.
NOTE
RTF Image rotation when scaling quality is set to 'highest' is not supported in any
RTF document, opened by OpenOffice.org.
4.14.3 Fixed-Pixels Resizing
There are five methods to resize an image by specifying the resulting dimensions in pixel size (the size parameters must be positive numbers or -1 number). If the value is -1, it will resize an image to the document paper
dimensions. For example:
103
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
$image.setWidth($diagram.image, -1)
As shown by the example, the image will be resized to a paper width by maintaining the aspect ratio. The value
-1 applies only to certain template types such as RTF, ODT, and DOCX.
If the value is -2, it will resize an image to document paper bounds if and only if image bounds are larger than
paper bounds. For example:
$image.setWidth($diagram.image, -2)
Using the value -2 also maintains the image aspect ratio. However it can only be applied to certain template
types such as RTF, ODT, and DOCX.
(i) $image.setSize(image, sizeWidth, sizeHeight)
Returns an image icon for an element. This method is used to resize the image to an exact size; width and
height in pixels..
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
sizeWidth
java.lang.Integer
The width of the image in pixels.
sizeHeight
java.lang.Integer
The height of the image in pixels.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(ii) $image.setHeight(image, size)
Returns an image icon for an element. This method is used to resize the image to a specific height (in pixels),
while maintaining the image aspect ratio.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
size
java.lang.Integer
The height of the image in pixels.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(iii) $image.setHeight(image, size, keepRatio)
Returns an image icon for an element. This method is used to resize the image to a specific height (in pixels),
while either maintaining the image aspect ratio, or not (depending on the keepRatio parameter).
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
size
java.lang.Integer
The height of the image in pixels.
keepRatio
java.lang.Boolean
Flag to maintain the image
aspect ratio
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
104
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
(iv) $image.setWidth(image, size)
Returns an image icon for an element. This method is used to resize the image to a specific width (in pixels),
while maintaining the image aspect ratio.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
size
java.lang.Integer
The width of the image in pixels.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(v) $image.setWidth(image, size, keepRatio)
Returns an image icon for an element. This method is used to resize the image to a specific width (in pixels),
while maintaining or not maintaining the image aspect ratio (depending on the keepRatio parameter).
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
size
java.lang.Integer
The width of the image in pixels.
keepRatio
java.lang.Boolean
A flag to maintain the image
aspect ratio
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
Use $image.setSize($diagram.image, 200, 200), for example, to resize the image’s width and height to 200
pixels. The following photos show the result.
Use either $image.setWidth($diagram.image, 150) or $image.setWidth($diagram.image, 150, true), for
example, to resize the image’s width to 150 pixels and maintain the image aspect ratio. The following photos
show the result.
105
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Use $image.setWidth($diagram.image, 150, false), for example, to resize the image’s width to 150 pixels and
ignore the image aspect ratio. The following photos show the result.
4.14.4 Fixed-Measurement Resizing
There are six methods to resize an image by specifying the resulting dimensions in terms of measurements, for
example, inch (in), centimeter (cm), millimeter (mm), point (pt), or pixel (px)], and specifying the dot per inch
(DPI) value. Every measurement parameter must be quoted.
(i) $image.setSize(image, measureWidth, measureHeight)
Returns an image icon for an element. This method is used to resize the image to an exact size; width and
height in terms of measurements.
Name
Parameter(s) image
106
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
measureWidth java.lang.String
The width of the image in a
term of measurement.
measureHeight
The height of the image in a
term of measurement.
java.lang.String
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Return
Name
Type
Description
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
(ii) $image.setHeight(image, measureSize)
Returns an image icon for an element. This method is used to resize the image to a specific height in a term of
measurement, while maintaining the image aspect ratio.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
measureSize
java.lang.String
The height of the image in a
term of measurement.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(iii) $image.setHeight(image, measureSize, keepRatio)
Returns an image icon for an element. This method is used to resize the image to a specific height (a term of
measurement), while either maintaining or not maintaining the image aspect ratio (depending on the keepRatio
parameter).
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
measureSize
java.lang.String
The height of the image in a
term of measurement.
keepRatio
java.lang.Boolean
Flag to maintain the image
aspect ratio
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(iv) $image.setWidth(image, measureSize)
Returns an image icon for an element. This method is used to resize the image to a specific width in a term of
measurement, while maintaining the image aspect ratio.
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
measureSize
java.lang.String
The width of the image in a
term of measurement.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(v) $image.setWidth(image, measureSize, keepRatio)
107
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Returns an image icon for an element. This method is used to resize the image to a specific width (a term of
measurement), while either maintaining or not maintaining the image aspect ratio (depending on the keepRatio
parameter).
Name
Type
Description
com.nomagic.magicreport.Ima
ge
An image object for the element icon.
measureSize
java.lang.String
The width of the image in a
term of measurement.
keepRatio
java.lang.Boolean
The flag to maintain the image
aspect ratio.
-
com.nomagic.magicreport.Ima
ge
The resized image object for
the element icon.
Parameter(s) image
Return
(iv) $image.setDPI(dotsPerInches)
This method is used to set the resolution (dpi) of images. The default value is 96 dpi. The dpi value will only
affect the methods that take inches, centimeters, and millimeters as their parameters.
Name
Parameter(s) dotsPerInches
Return
-
Type
Description
java.lang.Integer
The resolution (dpi) of images
-
-
Use $image.setSize($diagram.image, ‘1.5in’, ‘2in’), for example, to resize the image’s width to 1.5 inches
and height to 2 inches. The following photos show the result.
Use either $image.setHeight($diagram.image, ‘45mm’) or $image.setHeight($diagram.image, ‘45mm’,
true), for example, to resize the image’s height to 45 millimeters and maintain the image aspect ratio. The following photos show the result.
108
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
Use $image.setHeight($diagram.image, ‘45mm’, false), for example, to resize the image’s height to 45 millimeters and ignore the image aspect ratio. The following photos show the result.
Use $image.setDPI(192) and then $image.setSize($diagram.image, ‘0.9in’, ‘1.1in’), for example, to set the
resolution (dpi) of the image to 192 dots per inch, and then resize the image width to 0.9 inches and height to
1.1 inches. The resulting image size will become 173x211 pixels. The following photos show the result.
109
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
If you set the resolution (dpi) to 144 using $image.setDPI(144), the resulting image size will become 130x158
pixels. The following photos show the result.
4.14.5 Include Image
You can include images from an external source in a report. The supported image types are BMP, JPG, WBMP,
GIF, and PNG.
(i) $image.include(location)
Includes an external image from a local file or URL in a report.
Name
Parameter(s) location
Return
110
-
Type
Description
java.lang.String
An image location. The location format can be either a
URL or a system file.
com.nomagic.magicreport.Ima
ge
A report image.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Helper Modules
For example:
$image.include("c:/my document/logo.gif")
$image.include("http:/www.magicdraw.com/images/
product_boxes/MD.gif")
111
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
5. Report Wizard Template Editor
Template Editor is a Microsoft Word Add-In. It provides a list of all fields that can be used in a Report Wizard
template.
5.1 Installation
To install Report Wizard Template Editor in Microsoft Word:
1. Download and install Microsoft XML Services (MSXML) from the following (you can skip this
step if the latest version of MSXML is already installed in your system):
http://www.microsoft.com/downloads/details.aspx?FamilyID=d21c292c-368b-4ce1-9dab3e9827b70604&DisplayLang=en
2. Copy all files and subdirectory from the
<install.dir>\plugins\com.nomagic.magicdraw.reportwizard\vba folder to
%APPDATA%\Microsoft\Word\STARTUP (%APPDATA% is the location where user data
is stored), for example,
• On Windows 2000 or Windows XP: C:\Documents and Settings\User
Name\Application Data\Microsoft\Word\STARTUP
• On Windows Vista:
C:\Users\UserName\AppData\Roaming\Microsoft\Word\STARTUP
3. Restart Microsoft Word.
5.2 Opening Template Editor
After installation has been completed, the Template Editor menu will appear on the Microsoft Word menu bar
(Figure 72).
Figure 72 -- Microsoft Word 2003 Template Editor Menu
To open Template Editor:
• On the Microsoft Word 2000 – 2003 menu, click ReportWizard > Template Editor (Figure 72) or
• On the Microsoft Word 2007 menu, click Add-Ins > ReportWizard > Template Editor (Figure 73).
112
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
Figure 73 -- Microsoft Word 2007 Template Editor Menu
NOTE
The macro enabled option in Microsoft Word is required to open Template Editor.
Figure 74 -- Report Wizard Template Editor Dialog
113
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
Table 14 -- Report Wizard Template Editor
Name
Function
Search box
To filter a list of fields. Only fields that have a keyword of search in
part of the name can be shown in the (4) List of fields.
Clear search results
To clear the current search result.
Categories combo box
To select the categories of fields. The fields are shown in (4) List
of fields according to their categories.
List of fields
To show a list of fields. Double-click a field name to insert the
code.
Display all available fields
check box
To show all fields, otherwise it will show only common used
fields.
Insert button
To insert the code for selected field into the document.
Show/Hide description button To show or hide (8) description pane.
Description pane
To show the description of a selected field.
Import button
To import data file.
5.3 Data File
Template Editor allows you create a new data file and import it to the Template Editor dialog. Click the Import
button to import the data file.
114
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
Data file is written in XML format.
<?xml version="1.0" encoding="utf-8"?>
<xs:schema elementFormDefault="qualified" xmlns:xs="http://www.w3.org/2001/XMLSchema">
<xs:element name="data">
<xs:complexType>
<xs:sequence>
<xs:element minOccurs="0" maxOccurs="1" name="elements">
<xs:complexType>
<xs:sequence>
<xs:element minOccurs="0" maxOccurs="unbounded" name="element">
<xs:complexType>
<xs:all>
<xs:element minOccurs="1" maxOccurs="1" name="name" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="description" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="members">
<xs:complexType>
<xs:sequence>
<xs:element minOccurs="0" maxOccurs="unbounded" name="function">
<xs:complexType>
<xs:sequence>
<xs:element minOccurs="1" maxOccurs="1" name="name" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="description" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="unbounded" name="param">
<xs:complexType>
<xs:all>
<xs:element minOccurs="1" maxOccurs="1" name="name" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="description" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="type" nillable="true" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="direction">
<xs:simpleType>
<xs:restriction base="xs:string">
<xs:enumeration value="in" />
<xs:enumeration value="out" />
</xs:restriction>
</xs:simpleType>
</xs:element>
</xs:all>
</xs:complexType>
</xs:element>
</xs:sequence>
</xs:complexType>
</xs:element>
<xs:element minOccurs="0" maxOccurs="unbounded" name="attribute">
<xs:complexType>
<xs:all>
<xs:element minOccurs="1" maxOccurs="1" name="name" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="description" type="xs:string" />
<xs:element minOccurs="0" maxOccurs="1" name="type" nillable="true" type="xs:string" />
</xs:all>
</xs:complexType>
</xs:element>
</xs:sequence>
</xs:complexType>
</xs:element>
</xs:all>
<xs:attribute name="often" type="xs:boolean" />
</xs:complexType>
</xs:element>
</xs:sequence>
</xs:complexType>
</xs:element>
</xs:sequence>
<xs:attribute name="name" type="xs:string" />
</xs:complexType>
</xs:element>
</xs:schema>
Figure 75 -- XML Data File Schema
115
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
Element
Attribute / Element
Description
The root element.
data
name : string
Data name. This value will be used as category
name (3) Category.
elements : complexType
Group of <element> element.
elements
Group of <element> element.
element
Element display on (4) List of fields.
name : string
Element name.
description : string
Element description.
often : boolean
If an attribute is true, the element will be managed as a suggested element.
members : complexType
Group of <function> or <attribute>
The function member.
function
name : string
Function name.
description : string
Function description.
param : complexType
Group of function parameters.
Function parameter.
param
name : string
Parameter name.
description : string
Parameter description.
type : string
Parameter type.
direction : simpleType
A direction of parameter.
in - indicates this parameter is an input
out - indicates this parameter is an output
The attribute member.
attribute
116
name : string
Attribute name.
description : string
Attribute description.
type : string
Attribute type.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Template Editor
<?xml version="1.0" encoding="UTF-8"?>
<data name="Built-in Tools" xmlns:xsi="http://www.w3.org/2001/XMLSchemainstance"
xsi:noNamespaceSchemaLocation="fields.xsd">
<elements>
<element often="true">
<name>array</name>
<description>Use for creating the Array or HashSet instance.</description>
<members>
<function>
<name>subList</name>
<description>Create ArrayList of the portion of list in given size.</
description>
<param>
<name>list</name>
<direction>in</direction>
<type>List</type>
<description>a original list.</description>
</param>
<param>
<name>size</name>
<direction>in</direction>
<type>int</type>
<description>view size of given list</description>
</param>
<param>
<name>list</name>
<direction>out</direction>
<type/>
<description>a of view of the specified size within given list.</description>
</param>
</function>
</members>
</element>
</elements>
</data>
Figure 76 -- Sample XML Data File
117
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
6. Generating Reports from Report Wizard
In addition to default document templates, Report Wizard allows you to create customized specification document templates. Templates may contain your own custom fields not related to model elements, as well as fields
that correspond to model elements. Once customized, a Report Wizard template can be used with data from
any project.
You can also format your template to create the style you want including tables of contents, headers and footers, and page numbers. You can apply most character and paragraph formatting available from your rtf editor
for rtf template or specify with html tags in the HTML template, including keywords. Once the template has been
completed, you can run Report Wizard to create a report in a format that corresponds to the template.
Report Wizard templates can be in txt, rtf, html, odt, odf, odp, docx, xlsx, pptx and xml for DocBook or FO files.
If you prefer, you can work in Report Wizard Template Editor until you have finished the template file and use
the Report Wizard template windows to save it in the template folder. The default templates are located in the
<MagicDraw home>/plugins/com.nomagic.magicdraw.reportwizard/data folder.
6.1 Concepts
Report Wizard includes the following concepts:
• Template: specifies the document layout, format, corresponding model elements, and custom defined
fields.
• Report Data: specifies a set of custom fields and data in the selected template. A template can have a
number of different customs defined fields for a project or different projects organized in a report.
• Report: a generated user document with data from the project displayed in the selected template style.
6.2 Default Templates
There are 13 default templates that come with the report engine.
(i) Class Specification Report: describes the specification of class, interface, and enumeration type of the
project.
(ii) Data Dictionary Report: enables you to print elements of MagicDraw data dictionary.
(iii) IEEE 1233: the standard template based on the IEEE 1233 recommendation.
(iv) Model Extension: describes common UML model extension mechanisms (stereotypes, tagged values,
and constraints). It is useful for reporting custom UML profiles.
(v) Use Case (Simple): describes system functionalities and actors in a simple format.
(vi) Use Case (Modern): describes system functionalities and actors that are useful in support of use case
driven analysis.
(vii) Web Publisher (Simple HTML): enables you to publish MagicDraw models (including diagrams) in simple
HTML. The report is viewable using a standard browser such as Internet Explorer or Firefox.
(viii) Web Publisher 2.0: enables you to publish MagicDraw models (including diagrams) in HTML with rich
features. The report is viewable using a standard browser such as Internet Explorer or Firefox.
(ix) Activity Diagram: provides a standard report for activity diagrams. The content of the report is a list of all
the nodes (ordered by nodes hierarchy in each activity diagram).
118
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
(x) Activity Diagram Specification: provides a standard report for activities. The content of the report is a list
of all the nodes in each activity.
(xi) Sequence Diagram: provides a report that shows sequence diagrams and a list of all the messages in the
diagrams.
(xii) Sequence Diagram Specification: provides a report that show sequence diagrams, and a list of all the
messages and lifelines in the diagrams.
(xiii) Web Publisher Collaboration: is implemented based on the Web Publisher 2.0 template. It improves
features for text editing, element review, and XML messages. The J2EE compliance server is required to run
the generated report.
6.3 Architecture Templates
There are five architecture report templates that come with the Report engine: (i) Behavioral, (ii) Environment,
(iii) Implementation, (iv) Structural, and (v) Use Case report templates.
6.3.1 Behavioral Report
A Behavioral report is a standard report for the Behavioral view. This report will be generated by a selected
package that consists of Sequence, Communication, State Machine, and Activity diagrams. The contents of the
report is a list of all packages which are ordered by a package hierarchy in the project. Each package consists
of the specification of messages in the Sequence diagram, the specification of lifelines in the Communication
diagram, the specification of states in the State Machine diagram, and the actions in the Activity diagram. All
elements in the report are ordered by their names.
6.3.2 Environment Report
An Environment report is a standard report for the Environment view. The report will be generated by a selected
package that consists of an Implementation diagram (Deployment diagram). The contents of the report is the
list of all packages which are ordered by a package hierarchy. Each package describes the specification of
nodes, interfaces, components, and artifacts which are ordered by the element name.
6.3.3 Implementation Report
An Implementation report is a standard report for the Implementation view. The report will be generated by a
selected package which consists of an Implementation diagram (Component diagram). The contents of the
report is a list of all packages which are ordered by a package hierarchy in the project. Each package consists
of a list of interfaces, components, and artifacts. All elements in the report are ordered by their names.
6.3.4 Structural Report
A Structural report is standard report for the Structural view. This report will be generated by a selected package
which consists of a Class diagram. The report consists of a list of packages which are ordered by a package
hierarchy. Each package describes the specification of interfaces, classes, and enumerations which are
ordered by the element name.
6.3.5 Use Case Report
A Use Case report is a standard report for the Use Case view. This report will be generated by a selected package which consists of Use Case diagrams. The contents of the report is a list of packages which are ordered by
a package hierarchy. Each package describes the specification of actors and use case. All elements in the
report are ordered by their names.
119
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
6.4 Generating Use Case Description Reports
The Use Case Description document template is designed to capture all the Use Case-related artifacts, for
example, UseCases, actors, Use Case descriptions, etc. In this template all the Use Case diagram-related keywords are included. Therefore, when you select the highest level of the packages (the highest level of the packages in MagicDraw is Data), only Use Case diagrams and their related elements will be added to the
document.
To generate the Use Case description document:
1. Open the Magic Library.mdzip sample project from the <MagicDraw_home>/samples/
case studies directory (Figure 77).
NOTE
This step is only necessary for illustration purposes (as well as other steps within this
scenario).
Figure 77 -- The Magic Library.mdzip Project File
2. On the Tools menu, select the Report Wizard command. The Report Wizard dialog will
open. Select a template, for example, UseCase (Classic) and click Next (Figure 78).
120
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 78 -- Report Wizard Dialog
3. Select the built-in report data (Figure 79) or create a new one (Figure 80), and then click
Next.
121
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 79 -- The Select Report Data Pane
122
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 80 -- Selecting My Report Data
4. Click the Variable button (Figure 79) to create a new report variable, modify or delete an
existing report variable. Using the Report Variable dialog (Figure 81).
123
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 81 -- The Variable Pane
5. Select the scope of the report in the open package tree. In this case it will be the
MagicLibrary Requirements model package, because all requirement use cases are stored
in this package. Click Next (Figure 82).
124
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 82 -- Selecting the Scope of the Report
6. Click the “...” button to locate the report file location (Figure 83). The Save as dialog will open.
7. Select the file location, enter the filename, and click Save. The report file format will depend
on the template file format. For example, if the template file format is *.rtf, the report file
format will be *.rtf as well.
125
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 83 -- Selecting the Report File Location
8. Select the report image format, either *.png or *.jpg, and select an image size option
(Figure 84).
126
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 84 -- Selecting an Image Format
9. Select an option to display empty value information, either Empty text or Custom text
(Figure 85).
NOTE
127
In some cases the query may return an empty value that causes blank fields in the
report. The Display empty value as option is useful when you have a standard representation for blank fields.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 85 -- Selecting a Display Empty Value Option
10. Select the Display in viewer after generating report check box to open the report
document with the default editor (Figure 86).
128
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 86 -- Selecting the Display in Viewer After Generating Report Option
11. Click Generate.
6.5 Web Publisher 2.0 Reports
6.5.1 Generating Reports
Web Publisher is a Java Doc like report with clickable navigation and image map for all diagrams and elements.
To generate a Web Publisher 2.0 report:
1. Open the Magic Library.mdzip sample project from the <MagicDraw_home>/samples/
case studies directory (see Figure 77 on page 120).
2. On the Tools menu, click Report Wizard. The Report Wizard dialog will open (Figure 87).
3. In the Select Template pane, select the Web Publisher 2.0 template and click Next
(Figure 87).
129
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 87 -- Selecting Web Publisher 2.0 Template
4. Click New. The New Template dialog will open. Type the report name and description, and
select the location of the template file. Click Next.
5. In the Select Report Data pane, select the built-in report data and click Next.
NOTE
In the Select Report Data pane, you can create a new set of report data for the Web
Publisher template. The report data is a container for a set of custom-defined fields in
the template. It can be used to group different report versions.
6. In the Variable pane, enter information for predefined custom fields or create a new one
(Figure 88). Click Next.
130
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 88 -- The Variable Pane
7. Select the scope of the report in the open package tree. In this case it will be the Data model
package, because you want to have a web-based report of your entire project. Click Next
(Figure 89).
131
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 89 -- Selecting the Scope of the Web Publisher 2.0 Report
8. Click the “...” button to locate the report file location (see Figure 83 on page 126). The Save
as dialog will open.
9. Select the file location, type the report name, and click Save. The generated web report will
include a number of folders and files.
10. Select the report image format: *.png, *.jpg or *.svg (see Figure 84 on page 127).
11. Select an option to display empty value information, either Empty text or Custom text.
NOTE
In some cases, the query may return an empty value that creates blank fields in the
report. The Display empty value as option is useful when you have a standard representation for blank fields. (See Figure 85 on page 128).
12. Select the Display in viewer after generating report check box to open the report
document with the default editor (see Figure 86 on page 129).
13. After all options have been selected, click Generate.
6.5.2 Web Publisher 2.0 Features
6.5.2.1 Report Layout
The Web Publisher report consists of 3 panels (see Figure 90):
(i) Containment panel: this panel shows the containment tree.
(ii) Content panel: this panel shows an element's contents
(iii) Search panel: this panel contains a quick search box.
132
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 90 -- Web Publisher 2.0 Report Layout
6.5.2.2 Containment Menu
To hide or show the containment menu:
• Click and re-click the “CONTAINMENT” menu to hide and show it (see Figure 91).
133
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 91 -- Containment Menu
To expand or collapse the containment tree:
• Click the “+” button on the containment tree to expand it or click the “-” button to collapse it (see
Figure 92).
Figure 92 -- Containment Tree
6.5.2.3 Contents Layout
Web Publisher contains two tabs: (i) Diagram and (ii) Specification tabs.
134
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
(i) The Diagram tab shows diagram images (see Figure 93)
Figure 93 -- DIagram Tab
(ii) The Specification tab shows elements specification (see Figure 94).
135
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 94 -- Specification Tab
To show or hide element contents:
• Click and re-click the arrow button to show and hide the contents (see Figure 95).
Figure 95 -- Showing and Hiding Element Contents
136
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
To show an element specification, Active Hyperlink, Hyperlink, submachine of state, or behavior of
the call behavior action:
• Click a diagram's element to show the context menu for opening its specification, Active
Hyperlink, Hyperlink, submachine of state, or behavior of the call behavior action (see
Figure 96).
137
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 96 -- Web Publisher 2.0 Context Menu
To add an Active Hyperlink to a model:
• Double-click a diagram's element to open the Active Hyperlink and add it to a model element (see
Figure 97).
138
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 97 -- Adding Active Hyperlink
6.5.2.4 Quick Search Box
You can search for an element in a project by typing a specific keyword in the Quick Search box. You can also
use regular expressions as the keyword (see Figure 98).
139
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 98 -- Searching for an Element
6.5.2.5 Changing a Homepage Image
Report Wizard enables you to change a homepage image by entering a specific image value in the HomeImage user-defined variable in the Report Variable dialog (see Figure 99).
140
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 99 -- The Variable Pane
See Table 15 for the possible values of the “HomeImage” variable.
Table 15 -- “HomeImage” User-defined Variable
Possible Value
Result
(not specified)
MagicDraw logo image will be displayed as the homepage
image.
Diagram Name
(plain text)
Enter a diagram name (in plain text) to display the diagram as
the homepage image.
Element ID
(mdel://)
Enter “mdel://” followed by a model element ID to display the
element as the homepage image. For example, “mdel://
_10_0EAPbeta2_8740266_1126593738250_35764_172”.
Local Image
(file://)
Enter the location of an image file on your computer to display
the image as the homepage image. For example, “file://d://picture//image.jpg”.
Web Image
(http://)
Enter the location of an image on the Web to display the
image as the homepage image. For example, “http://
www.photobucket.com/image.jpg”.
Figure 100 demonstrates an example of specifying a diagram name (in plain text), in this case “Software Development Process”, in the “HomeImage” variable.
141
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 100 -- Example of Specifying Diagram Name (Plain Text) in “HomeImage” Variable
6.5.2.6 Element Description
The Specification tab shows a brief description of elements in a tooltip. Move your mouse over an element to
see the description (see Figure 101).
Figure 101 -- Showing Element Description
6.5.2.7 Shortcut to Homepage
You can click The MagicDraw Web Publisher 2.0 to go to the index page (see Figure 102).
142
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 102 -- Shortcut to Homepage
6.5.2.8 Property Visibility
The property visibility in the Specification tab has 3 mode types: (i) Standard, (ii) Expert, and (ii) All. The mode
that will be shown in the property visibility depends on the mode that you have selected in MagicDraw (see Figure 103).
Figure 103 -- Property Visibility Mode Types
143
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
6.5.2.9 Showing or Hiding Context Menu
To show or hide a context menu:
1. Open the Report Variable dialog (Figure 104).
2. Change the value of the“UseContextMenu” user-defined variable to “true” or “false”.
Figure 104 -- “UseContextMenu” User-defined Variable
UseContextMenu Value
Function
TRUE
To show the context menu on a right mouse
click on a diagram element.
FALSE
To show an element specification or open an
element/diagram/page specified in the existing
active hyperlink, if any, on a right mouse click
on a diagram element.
6.5.2.10 Opening an Activity, State Machine, Collaboration, or Interaction Diagram
Click an Activity, State Machine, Collaboration, or Interaction to open a sub-diagram associated with the element.
144
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 105 -- Opening Activity, State Machine, Collaboration, or Interaction Diagram
6.5.2.11 Opening the Sub-diagrams of a State with Submachine
Double-click a state with Submachine and Call behavior action with behavior to open its sub-diagram. For
example, double-clicking the state “a1” (Figure 106) with the submachine “sub1” will show a diagram of the
state machine “sub1” (Figure 107).
Figure 106 -- Double-clicking State with Submachine
145
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 107 -- Diagram of State Machine “sub1”
6.6 Web Publisher Collaboration Reports
The Web Publisher Collaboration report is implemented based on the Web Publisher 2.0 report. The Web Publisher Collaboration report improves text editing, model review, and XML message features. The J2EE compliance server requires a running generated report.
6.6.1 Generating Reports
The Web Publisher Collaboration template is located under the Default Template category.
To generate a Web Publisher Collaboration template report:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select Web Publisher Collaboration (Figure 108).
146
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 108 -- Selecting the Web Publisher Collaboration Template
• There are 3 user-defined variables ready for the default report data.
(i) Author: the author of the report
(ii) Title: the title of the web page
(iii) UseElementLink: if “true”, it will allow the element hyperlink to work with diagrams. If
“false”, the element specification will be shown on the web page.
3. Before generating a report, choose the option to upload the generated report to the server
(Figure 109). (See 6.7 Uploading Reports to Remote Locations for details).
147
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 109 -- Selecting the Server to Upload the Report
6.6.2 Web Publisher Collaboration Feature
The main feature of the Web Publisher Collaboration report is for reviewing tasks. The generated report will
allow you to (6.6.2.1) add comments and (6.6.2.2) alter model contents including documentation.
6.6.2.1 Adding Comments
To add comments:
• Click Add Review to add review text (Figure 110). Review text can be in a rich text format, for
example, bold, italic, text color, etc. You cannot modify review text, but you can remove it by clicking
Remove.
148
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 110 -- Web Publisher Collaboration Page
6.6.2.2 Altering Model Contents
To alter model contents:
• Click the field to open an input box (Figure 111). You can modify only the fields with a text value. Field
editing will be completed once you have pressed enter or text input is out of focus. Press ESC to
cancel the editing process.
149
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 111 -- Editing Field
6.6.3 XML Integration
Web Publisher Collaboration opens an interface for retrieving model contents through XML or web services
(Figure 112).
XML?refid=elementID
The endpoint service is “XML” with a query string for “refid”, for example:
http://127.0.0.1:8080/house/
XML?refid=_16_5beta1_2104050f_1233137219765_123064_4025
Figure 112 -- Example of Data Return from XML Service
150
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
6.7 Uploading Reports to Remote Locations
This feature allows you to upload a generated report to a predefined remote location. Each remote location is
described in a “Profile” that holds all necessary information. You can use the Profile Management dialog to add,
edit, or delete profiles.
This section contains (6.7.1) Quick Guide and (6.7.2) Detailed Explanations. In the Quick Guide section, you
will learn how to create a step-by-step profile and how to use the created profile to upload a report to a remote
server. The Detailed Explanations section describes what a valid Profile is and some of the palatial mistakes or
errors when uploading a report.
6.7.1 Quick Guide
To create a profile:
1. In the Report Wizard dialog, click the "..." button (Figure 113). The Profile Management
dialog will open (Figure 114). You can add, edit, or remove profiles.
Figure 113 -- Dialog for Uploading Report to Remote Server
151
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 114 -- Profile Management Dialog
2. Click the New button to create a new Profile. The New Server Profile dialog will open
(Figure 115). Enter the name of the Profile to be created. The name must neither be empty
nor already be used in the existing set of Profiles. Click OK.
152
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 115 -- New Server Profile Dialog
3. Fill in the details of the profile by choosing a Protocol and filling in a URL address. The User
Name and Password fields can be left empty if desired.
4. Click the Save Profiles button to save the newly-added Profile and close the Profile
Management dialog (Figure 116).
153
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 116 -- Enter Server Details
5. You are now back to the Report Wizard dialog and are ready to select the newly-created
Profile (Figure 117). Once the report has been generated, it will be uploaded to the location
specified in the Profile created earlier.
154
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 117 -- Selecting Server Profile
6. Enter authentication information in the Authentication dialog and click OK (Figure 118).
Figure 118 -- Authentication Dialog
7. If the report has been successfully uploaded, a message dialog will open showing the
following message (Figure 119). Click OK.
155
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 119 -- Successful Report Upload
6.7.2 Detailed Explanations
This section contains two parts: (6.7.2.1) describes how the Profile Management dialog (Figure 114) works
and (6.7.2.2) illustrates problems that may arise when attempting to upload a report to a remote location.
6.7.2.1 Using Profile Management Dialog
This section contains (i) Profile Management dialog buttons and (ii) Profile Management dialog fields, describing the dialog in Figure 114.
(i) Profile Management Dialog Buttons
The Profile Management dialog contains 5 buttons:
(a) New: to add a new profile to the list of existing Profiles. You cannot create a blank name profile or
with a profile name that has already been used. You can add and edit multiple Profiles. However, these
profiles will not be saved until you click the Save Profiles button.
(b) Remove: to remove the currently selected profile. Note that you cannot remove the "No Upload" profile.
(c) Save Profiles: to save all profiles. If new profiles were added or existing Profiles were modified, then
these changes will be saved. All profiles will be checked for consistency or information correctness. You
will be asked to fix issues, if any. It is not possible to save profiles as long as invalid information
detected. See Section (ii) Profile Management Dialog Fields below for the description of "valid profile".
(d) Cancel: to abandon all newly-added profiles and all changes made to existing profiles. If no changes
were made, clicking this button will simply bring you back to the Output Options pane of the Report
Wizard dialog. If changes are found, the Confirm Cancel dialog (Figure 120) will open. In this dialog,
you will see with all profile names whose content has been changed. You can choose to either abandon
all changes or return to the Profile Management dialog and save the changes.
Figure 120 -- Confirm Cancel Dialog
156
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
(e) Exit: this button
is located in the upper-right corner of the Profile Management pane. It works in
a manner similar to the Cancel button.
(ii) Profile Management Dialog Fields
Profiles describe information necessary for sending a report to a remote location. The report will be saved
remotely with the same name as the locally-generated report and will overwrite any file with the same name on
the remote location.
The Address field is URL sensitive, and can hold protocol as well as username information. If the protocol or
username information is found in the Address field, then the corresponding fields, namely the Protocol and
Username fields, will be updated with the values from the Address field. At the very least, a profile must have a
hostname in the Address field.
You cannot save a profile unless this condition is met. The Username and Password fields contain sensitive
data and therefore are optional. If these fields are empty in a profile, then you will be prompted for the username and password when the server asks for your authentication.
• Profile name : This drop-down list holds all the existing Profiles. They are alphabetically sorted. The
"No upload" profile is always available and you can neither modify nor remove it. Select the"No
Upload" profile if you do not want to upload a report.
• Protocol : Five different protocols are supported: FTP, FTP over SSL (Secure Socket Layer), Webdav,
Webdav over SSL, and SSH (Secure Shell). You can either choose to select a protocol from the
protocol drop-down list or fill in the scheme in the address part of the profile. Certificates that are sent
by servers using secure traffic (FTP over SSL, Webdav over SSL, and SSH) are silently accepted.
The scheme identifiers and default port numbers of the five supported protocols are listed in the
following table.
Table 16 -- Scheme Identifier and Default Port Numbers of Five Supported Protocols
Protocol Name
Scheme
Default Port Number
Traffic Mode
1
ftp
ftp://
21
Plain text
2
webdav
http://
80
Plain text
3
ftp + ssl
ftps://
990
Encrypted & Secure
4
webdav + ssl
https://
443
Encrypted & Secure
5
ssh
ssh://
22
Encrypted & Secure
• Address : The Address field is the central part of a profile. Other fields, except the Password field, can
be set by it. An Address contains five different parts: scheme, username, hostname, port (number),
and (remote) path. Except hostname, every part is optional. Depending on the circumstances, you
might need to add a special port number and/or the remote path where you have write access. Even
though an address is valid without the path part, most servers will require a path and will not let you
write to the root directory. In every case, scheme and username parts will take precedence over the
selection in the Protocol Field or the content in the Username field. The following is the basic pattern
for the address field.
[scheme://][[email protected]]hostname[:port][path]
• scheme: The supported protocols are ftp, ftps, http, https or ssh. Must be followed by “://”.
Optional.
• username: The username needed for authentication. Must be followed by “@”. Optional.
157
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
• hostname: Must be either an IP address (eg. 10.1.1.195) or a human readable URL (eg.
www.ftpserver.com). Must be present to be a valid address.
• port: The port number where the server is listed. It is only necessary if the port number is
different from the default port for well-known services. It must be preceded by ":". Optional.
• path: The remote location where the report will be saved. Paths are Unix style paths and
therefore use “/” (forward-slash) as a delimiter. Optional.
Examples of valid addresses :
• 10.1.1.195 (hostname only)
• 10.1.1.195/companyDav (hostname and path)
• 10.1.1.195:80/companyDav (hostname, port number, and path)
• ftp://www.ftpserver.com (scheme and hostname)
• [email protected] (username and hostname)
• [email protected]/users/john/reports (username, hostname, and path)
• ssh://[email protected]:22/reports (all parts )
• Username : This field specifies the name used for authentication. If the address contains a username
part, then the content of the Username field will be ignored. It will be either filled in or overwritten with
the username from the Address. A Profile with an empty username field is valid, but you will be
prompted for a username and password every time you upload to the server using this profile.
• Password : A profile with a password must always be accompanied by a username. A Profile with a
password but no username is invalid, and cannot be saved. The password field is echoing password
characters as '*'. Saving a profile with a password will save the password in an encrypted form. For
example, lets assume our password is 'test', this might result in an encrypted password like this
'0013BCA5590DE'. A Profile with an empty password field is valid, but you will be prompted for a
password every time you upload to the server in this profile.
6.7.2.2 Upload Problems
There are three main problems that can arise when uploading reports to a remote location.
(i) The server that you are trying to connect is not responding, or the valid address you entered in the Profile is
not the address of the server that responds to your request (Figure 121).
Figure 121 -- Connection Error Message Dialog
(ii) Your username and/or password are incorrect and the server does not allow you to proceed (Figure 122).
158
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 122 -- Authentication Error Message Box Dialog
(iii) Various causes can lead to an unsuccessful attempt to upload a report. For example, the server runs out of
space and thus cannot save the report, or the connection could have been interrupted, etc. Whatever the cause
might be, the report HAS NOT BEEN transmitted sucessfully (Figure 123). For more details on error messages,
see MagicDraw logs.
Figure 123 -- Unsuccessful Upload Error Message Dialog
6.8 FAQs
To generate an output report document from Report Wizard:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select the template or create a new one. Click Next.
3. Specify Report Data and in the next step add information for the variables. Click Next.
4. Select the document scope from the corresponding packages. Click Next.
5. Select the output location, images format, and text for blank fields.
6. Click Generate.
To add a new report template:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Click New. The New dialog will open.
3. Enter the template name and description. Click the “...” button to specify the template file
location.
4. Click Create.
NOTE
159
Once a new template has been created, Report Wizard will add a folder with the
entered template name and save the selected template in this folder.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
To remove a template:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template from the list and click Delete.
NOTE
Once removed, the selected template with its folder and reports cannot be recovered.
To modify a template file:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template from the list and click Open. The default editor and a template file for
editing will open.
3. Modify the template and perform the save command in the editor.
NOTE
A different editor will be used for each template format. For example, MS Word could be
used for *.rtf template modification, or Macromedia Dreamweaver could be used for
*.html template editing.
To add a report data into the template:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template or create a new one. Click Next. The Select Report Data pane will appear.
3. Click New. The New dialog will appear.
4. Enter the report data name and description. Click Create. A new report data will be created.
In the next step, you may add new fields or delete the existing ones.
To remove report data from the template:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template or create a new one. Click Next. The Select Report Data pane will appear.
3. Select the report data from the list and click Delete.
To set the default viewer option for the report file:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template, report data, and specify the variables and package scope. Click the Next
button to proceed with the steps.
3. At the last wizard step, select the Display in viewer after generating report check box. The
report output will be displayed in the default editor or browser.
To change an output image format:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template, report data, and specify the variables and package scope. Click the Next
button to proceed with the steps.
3. At the last wizard step, select the output image format from the Report Image Format box.
NOTE
Supported image formats include:
• *.PNG and *.JPG: for all supported report templates.
• *.SVG: for HTML, XML and Text report templates.
• *.EMF and *.WMF: for RTF, OOXML and Text report templates.
160
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
To change an empty value configuration:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template, report data, specify the variables and package scope each time, click the
Next button to proceed with the steps.
3. At the last wizard step, select an option for output on blank fields:
• select Display empty value or Display value as, and select NA or
• just enter the text to represent other than null value when the template query fields return
empty.
To add a new variable:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template and report data. Click the Next button to proceed with the steps.
3. Click the New button when the Variable pane opens. The Variables dialog will open.
4. Enter the name of a new variable and its value (the value can be modified later after the
variable has been created).
5. Click Create.
To delete a variable:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template and report data. Click the Next button to proceed with the steps.
3. Select a field and click Delete when the Variable step opens.
NOTE
A deleted report data cannot be recovered.
To modify a variable:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template and report data. Click the Next button to proceed with the steps.
3. Select a field and modify its value when the Variable step opens. The value can be modified
in the properties list or in the Field Value box below the properties list.
To select a package for report generation:
1. On the Tools menu, click Report Wizard. The Report Wizard dialog will open.
2. Select a template, report data, and specify the variables. Click the Next button to proceed
with the steps.
3. The package tree will open. Select the package of the project and click the Add button to add
the elements from the package to the report.
NOTE
Clicking the Add button will add only the selected element, not its children, to the report
scope. In order to include all children, click the Add Recursively button instead.
To generate a normal text output format:
1. Create the MagicDraw query in the text file using the text editor (Figure 124).
161
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
Figure 124 -- Entering Query in the Normal Text Template
2. Create a New Template in the Report Wizard dialog (Figure 125).
Figure 125 -- Creating New Text Template
3. Select Text Template (Figure 126) and generate the output report (Figure 127).
162
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from Report Wizard
.
Figure 126 -- Selecting Text Template to Generate Report Output
Figure 127 -- Text Output
163
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Containment Tree
7. Generating Reports from the Containment Tree
You can generate reports directly from the Containment tree in MagicDraw.
To generate reports from the Containment tree:
1. Either:
Right-click a package in the Containment tree to open the shortcut menu, as
displayed in Figure 128. Select Generate Report..., and then select a template from
the category list or template item.
or
Right-click a report data in the Containment tree to open the shortcut menu, as
displayed in Figure 129. Select Quick Generate Report....
NOTE
You must specify the template and data in the report data before using
the Quick Generate Report... shortcut menu.
Figure 128 -- Containment Tree Shortcut Menu - Generate Report
164
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Containment Tree
Figure 129 -- Containment Tree Shortcut Menu - Quick Generate Report
2. Select the save location and type the filename.
3. A dialog will open asking if you want to open the report in the default viewer after the report
generating process is complete (Figure 130).
Figure 130 -- Question Dialog - View Generated Report
NOTE
• You can open the Report Wizard dialog and modify the data or
output properties by clicking the Report Wizard... on the shortcut
menu.
• By default, the quick generate report command will select the default
settings from the last changes saved to the report data.
165
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Command Line
8. Generating Reports from the Command Line
Generating reports and scheduling reports printing can be done by typing the command in the terminal. This
feature allows you to generate reports without opening the MagicDraw application and using Report Wizard.
8.1 Generate - the Command to Generate Reports
To generate a report from the package scope:
• generate - project projectFileName -output outputFileName -template
templateName -package packageNameList
To generate a report from the element scope:
• generate -project projectFileName -output outputFileName -template
templateName -element elementNameList
To generate a report from the option specified in the properties file:
• generate -properties propertiesFileName
To generate a Teamwork password for a properties file:
• generate -generatepassword password
8.1.1 Synopsis
• -project projectFileName
This command specifies a filename with the MagicDraw project path.
• -output outputFileName
This command specifies a filename with the output file path.
• -template templateName
This command specifies a template name to be used for generating a report document. The
template must exist in MagicDraw prior to using this command, otherwise an error will occur. If
the template name is not specified, the template specified in the report data (specified in -report
reportName, see Section 8.2 Options) will be used instead.
• -package packageNameList
This command specifies the name of one or more packages from a MagicDraw project that will
be included in the report. Package entries must be separated by a semicolon (;).
• -element elementNameList
This command specifies the name of one or more elements from a MagicDraw project that will
be included in the report. Element entries must be separated by a semicolon (;).
• [options]
The command-line options. See Section 8.2 Options for more detail.
• -properties propertiesFileName
This command specifies the name of a properties file to utilize. Use only with -properties.
• -generatepassword password
This command generates an encrypted password to be used with a properties file.
166
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Command Line
8.1.2 Description
8.1.2.1 Generating a Report
The Generate command creates a report document by receiving a set of information from arguments and
parameters. The information will then be generated as a report document to the specified output file. By default,
an argument is the specified data of the parameters that are invoked. If specifying the -properties option,
the argument is the name of a properties file. A properties file contains other parameters with the specified data
of each parameter.
8.1.2.2 Generating a Report from Teamwork Server
The following are command arguments to generate a report from Teamwork Server:
• -server, -login, and -password are key arguments to log on to Teamwork Server.
• You will be prompted for a password when trying to enter -server and -login without -password.
• If -spassword is used with a properties file, an encrypted password must be used for this property.
8.2 Options
The command line feature supports a set of options that are useful in adding more configuration possibilities.
• -report reportName
This command specifies the name of a report data file or report data element. The report data file
must exist in MagicDraw prior to using this command, otherwise an error will occur. If the
reportName is not specified, the previous report data will be set and used instead.
• -autoImage 0|1|2|3
This command specifies how an image will be shown in a report document. The default value for
this argument is 1.
0 – No resize.
1 – Fit image to paper (large only).
2 – Fit and rotate image (clockwise) to paper (large only).
3 – Fit and rotate image (counter-clockwise) to paper (large only)
• -imageFormat jpg|png|svg|emf|wmf
This command specifies an image format in a report document. The default value for this
argument is jpg.
jpg – Joint Photographic Expert Group
png – Portable Network Graphics
svg – Scaling Vector Image
emf – Microsoft Windows Enhanced Metafile
wmf – Windows Metafile
• -recursive true|false
This command specifies how to select a package in a MagicDraw project. The default value for
this argument is true.
true – select the specified package and its recursive package.
false – select only the specified package.
• -includeAuxiliary <true|false>
This command is used to select packages including auxiliary packages. The default value is
false.
167
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Command Line
• -outputOnBlankField stringValue
This command will show a string value in a blank field in a report document. The default value
for this argument is “”.
• -category categoryName
This command specifies a template category.
• -fields[name=value]
This command specifies a variable.
• -server serverName|IPAddress
This command specifies the name or IP Address of a Teamwork Server project.
• -login loginName
This command specifies the login name to log on to Teamwork Server.
• -password password
This command specifies the password to log on to Teamwork Server.
• -spassword encryptedPassword
This command specifies the encrypted password (Teamwork password) to log on to Teamwork
Server. This option is available only in a properties file.
8.3 Properties Filename
When –properties is used, other command actions are not necessary anymore. The configuration information is contained in the properties file. The information in the properties file is the same as you would put in the
command line.
There are four parameters needed to specify data for a report: (i) project, (ii) output, (iii) template, and (iv) package. There are also other five parameters called options which are additional configuration information such as
report, autoImage, imageFormat, recursive, and outputOnBlankField. These nine parameters are described in
the previous sections 8.1 Generate - the Command to Generate Reports and 8.2 Options.
A properties file is a simple text file. You can create and maintain a properties file with just about any text editor,
for example:
Figure 131 -- Sample of Properties File
In Figure 131, the command lines begin with a pound sign (#). The other lines contain key-value pairs. The key
is on the left side of the equal sign and the value is on the right. For instance, template is the key that corresponds to the value of Class Specification Report.
168
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Command Line
The string that represents the key and value in the properties file has a special character. The special character
is an escape character and needs to be used to prevent interpretation errors. Each escape character starts with
a backslash.
Table 17 -- Available Character Sequences
Escape Sequence
Character
\n
new line
\t
tab
\b
backspace
\f
form feed
\r
return
\”
“ (double quote)
\’
‘ (single quote)
\\
\ (backslash)
\uDDDD
character from the Unicode character set (DDDD is four hex digits)
8.3.1 XML Properties File
J2SE version 1.5 and Report Wizard version 15.5 allow you to use XML files to load and save key-value pairs.
Properties DTD:
<?xml version="1.0" encoding="UTF-8"?>
<!-- DTD for properties -->
<!ELEMENT properties ( comment?, entry* ) >
<!ATTLIST properties version CDATA #FIXED "1.0">
<!ELEMENT comment (#PCDATA) >
<!ELEMENT entry (#PCDATA) >
<!ATTLIST entry key CDATA #REQUIRED>
Example:
Figure 132 -- Sample of XML Property
8.4 Using Command Line
You can use the command line on Windows, Linux, or Unix.
To use the command line on Windows:
1. Run a command line console. In the Console window, go to the local installation of the
MagicDraw application.
169
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Generating Reports from the Command Line
2. Go to the plugins\com.nomagic.magicdraw.reportwizard folder and type the
command line there.
To use the command line on Linux or Unix:
1. Run a terminal (command line console). In the Console window, go to the local installation of
the MagicDraw application.
2. Go to the plugins\com.nomagic.magicdraw.reportwizard folder and type the
command line there.
Examples:
Figure 133 -- Samples of Command Line
8.5 Syntax Rules
• Command parameters containing spaces must be enclosed in quotes, for example, "UML Standard
Profile".
• Command parameters are case sensitive, except project, imageFormat and recursive which
are not case-sensitive.
• Blank spaces ( ) separate commands and parameters.
• To specify a package name that contains a semicolon (;), you can use a backslash (\). For example,
the package name “com;nomagic” can be typed by using “com\;nomagic”. The backslash followed
by a semicolon (\;) is not considered to be a character separator.
• For a parameter that contains unicode characters such as Thai language, you can use the xml
properties file to generate a report. The properties file does not support the unicode encoding.
• A field entry consists of a name-value pair. The name and value formats are specified by [name=value]
pattern strings. A valid name must start with a letter (a-z or A-Z) and can be followed by any letter,
digit, or underscore.
• You can specify a field name that consists of brackets ( [ ] ) by using backslashes ( \ ). For example,
"[author=NoMagic][Revision=[1.0]]" will be typed as "[author=NoMagic][Revision=\[1.0\]]".
• Either -package or -element can be used with the Generate command. For example, you can use -
package without -element.
170
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Quick Print
9. Report Wizard Quick Print
Report Wizard provides 5 keyboard shortcuts to create a report, with last used options, from a recently-used
template.
Table 18 -- The predefined keyboard shortcuts
Keyboard Shortcut
Quick Print Template
Alt + 1
Template's name A
Alt + 2
Template's name B
Alt + 3
Template's name C
Alt + 4
Template's name D
Alt + 5
Template's name E
To change a keyboard shortcut:
1. On the main menu, click Options > Environment to open the Environment Options dialog.
2. Select Category: Tools in the Keyboard pane.
3. Press the New key and click Assign.
4. For more details, see MagicDraw User Manual, Setting Environment Options.
To use Report Wizard Quick Print:
1. After a report has been generated, a new menu will appear below the Report Wizard... menu
(Figure 134). The name of the new menu is the name of the recently generated template.
Figure 134 -- Newly-generated Report as a Quick Option in Main Menu
2. Either click this menu or press Alt+1 to generate this template with the last used options.
3. Select the save location and filename (Figure 135).
171
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Quick Print
Figure 135 -- Select the Location to Save the Report
4. A message box will open, asking if you want to open the report in the default viewer once the
generating process has been completed (Figure 136).
Figure 136 -- Question Dialog - View Report.
5. The next time you generate a report, a new menu will create and map the keyboard shortcuts
until the keyboard shortcuts list is full. The number of keyboard shortcuts is limited to 5 only.
6. If the keyboard shortcuts list is full and the new template has been generated, the keyboard
shortcuts will be reused.
For example, Report Wizard Quick Print provides the following keyboard shortcuts:
172
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Quick Print
Table 19 -- Sample of Report Wizard Quick Print Keyboard Shortcuts
Shortcut Key
Template Name
Alt + 1
Tutorial 01 – Print Element
Alt + 2
Tutorial 02 – Print Diagram
Alt + 3
Tutorial 03 – Print Project
Alt + 4
Tutorial 04 – Print Report Data
Alt + 5
Tutorial 05 – Macro
Table 20 shows that the Tutorial 01 – Print Element keyboard shortcut is the most outdated template and the
following report has been completed using the Business Process Diagram template. Report Wizard Quick Print
will reuse the keyboard shortcut of the most outdated template.
Table 20 -- Reusing Keyboard Shortcuts
Shortcut Key
Template Name
Alt + 1
Tutorial 01 – Print Element
Alt + 2
Tutorial 02 – Print Diagram
Alt + 3
Tutorial 03 – Print Project
Alt + 4
Tutorial 04 – Print Report Data
Alt + 5
Tutorial 05 – Macro
If the next template to be generated has already been in the Quick Print list, the list will not change.
173
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
10. Report Wizard Environment Options
The Report Wizard environment options in the MagicDraw Environment Options dialog allow you to configure
the report engine. There are three things that you can configure: (i) Report engine properties, (ii) Template
mappings, and (iii) Template folder.
(i) Report Engine Properties
The properties that you can configure are as follows:
a. Template process size (int). This value defines the size of allocated memory for processing a template. If the template is larger than the allocated size, the engine will create temporary files on a local
disk and process the template from these files.
b. Template pool size (int). The number of processing threads for evaluating a template. An increase in
the number of threads may improve the performance of the engine, which will also depend on your
hardware and JVM.
c. Velocity properties. These properties are a key-value pair. You can add any number for these properties. You will need a basic knowledge of Velocity to enter the value. (See http://velocity.apache.org/
engine/devel/apidocs/org/apache/velocity/runtime/RuntimeConstants.html)
d. Debug report template. You can enable or disable any invalid properties, references, or exception
messages on the message window of MagicDraw. (See 11 Debug Report Template)
(ii) Template Mapping
Template mappings associate a template type with the template engine. The Report engine allows you to determine how to handle different types of files, such as JS or DOCBOOK file. All you have to do is specify a filename extension and select an engine name. The Report engine also allows developers to add a user custom
engine into this option.
(iii) Template Folder
You can either select or clear the Monitor template folder check box (Figure 137) in the Report Wizard environment options in the MagicDraw Environments Options dialog to enable or disable the option to automatically
deploy an MRZIP template file. If you select the check box, Report Wizard will automatically deploy the MRZIP
template file to the Report Wizard dialog whenever the file is added to your folder. (See 1.2 MRZIP File Automatic Deployment)
174
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
Figure 137 -- Report Wizard GUI Configuration in MagicDraw Environment Options Dialog
10.1 Configuring Report Engine Properties
Figure 138 shows the Configure report properties pane.
175
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
Figure 138 -- Configure Report Properties Pane
This pane contains 3 buttons: (i) Add, (ii) Edit, and (iii) Remove.
(i) Add button
To create a new report property:
1. Click the Add button in the Configure report properties pane. The Report properties dialog
will open (Figure 139).
Figure 139 -- Creating a New Report Property in the Report Properties Dialog
2. Enter the property name and value.
Table 21 -- Report Engine Properties Dialog Fields
Field Name
Function
Default Value
Possible Value
Required
Name
To enter the property
name
Blank
Text
Yes
Value
To enter the property
value
Blank
Text
No
176
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
(ii) Edit button
To edit a report engine property:
1. Select a property in the Configure report properties pane and click the Edit button. The
Report properties dialog will appear (Figure 140).
Figure 140 -- Editing a Report Property in the Report Properties Dialog
2. Edit the property name and value. (See Table 21 Report Engine Properties Dialog Fields)
(iii) Remove button
To delete a report property:
1. Select a property in the Configure report properties pane and click the Remove button.
10.2 Configuring Template Mappings
Figure 141 shows the Configure template mappings pane.
Figure 141 -- Configure Template Mappings Pane
This pane contains 3 buttons: (i) Add, (ii) Edit, and (iii) Remove.
(i) Add button
177
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
To create a new template mapping:
1. Click the Add button in the Configure template mappings pane. The Template mappings
dialog will open (Figure 142).
Figure 142 -- Adding Template Mapping in the Template Mappings Dialog
2. Enter a filename extension and template type.
Table 22 -- Template Mappings Dialog Fields
Field Name
Function
Default Value
Possible Value
Required
File extension
To enter a filename extension.
The filename extension is
case-insensitive
Blank
Text
Yes
Template type
To enter a template type. The
template type is case-sensitive
Blank
Text
Yes
(ii) Edit button
To edit a template mapping:
1. Select a template mapping in the Configure template mappings pane and click the Edit
button. The Template mappings dialog will open (Figure 143).
178
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
Figure 143 -- Editing Template Mapping in the Template Mappings Dialog
2. Edit the filename extension and template type. (See Table 22 Template Mappings Dialog
Fields)
(iii) Remove button
To delete a template mapping:
1. Select a template mapping in the Configure template mappings pane and click the Remove
button.
NOTE
When template mapping is removed from environment option, the file
extension mapping will be removed from MagicDraw. To restore default
setting, you have to restart MagicDraw.
10.3 Monitor Template Folder Option
You can either enable or disable the MRZIP template file automatic deployment option in the Report Wizard
environment options (See 1.2 MRZIP File Automatic Deployment) by selecting or clearing the Monitor template
folder check box (Figure 144).
Figure 144 -- Monitor template folder pane.
10.4 Reset to Defaults Option
Click the Reset to Defaults button to reset data to the default settings (Figure 145).
Figure 145 -- Reset to Defaults Button
179
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Report Wizard Environment Options
NOTE
• MagicDraw allows you to configure the report engine settings to
three levels: (i) environment option, (ii) global config.xml, and (iii)
template config.xml.
• The template config.xml configuration settings will override the
environment option configuration settings, which will override the
global config.xml configuration settings.
180
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Debug Report Template
11. Debug Report Template
The Debug Report template features warning messages that describe template errors. A warning message will
appear in Messages Window as the report template is being processed. All warning messages have no effect
on the output report, thus can be ignored. They are intended for informative purpose only.
There are 5 warning message types:
11.1 Invalid Property
11.2 Invalid Reference
11.3 Invalid Method Reference
11.4 Exception
11.5 Invalid Syntax
11.1 Invalid Property
The warning (Figure 146) will open when an invalid propery is encountered during report generation. For example, getting a text property from the $package variable whereas the text property is not a valid property for
$package is a variable invalid property and it will trigger a warning.
Figure 146 -- Invalid Property
11.2 Invalid Reference
The warning will open (Figure 147) whenever using a variable, for example, $empty, that has not been specified.
Figure 147 -- Invalid Reference
181
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Debug Report Template
11.3 Invalid Method Reference
A warning message will open (Figure 148) when an invalid method use from a variable, such as using the “getStereotypeProperty” method from the $report variable whose “getStereotypeProperty” method is not a valid
method for $report, is encountered during report generation.
Figure 148 -- Invalid Method Reference
11.4 Exception
A warning message (Figure 149) will open whenever an exception, for example, IndexOutOfBoundException,
occurs during report generation.
Figure 149 -- Exception
11.5 Invalid Syntax
A warning message (Figure 150) will open whenever a template contains any invalid syntax, for example, using
#forrow without #endrow.
Figure 150 -- Invalid Syntax
182
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Debug Report Template
11.5.1 Enabling or Disabling Warning Messages
You can enable or disable any invalid properties, references, and exception messages except invalid syntax
messages by editing the config.xml file and tags and values. Invalid syntax messages are always enabled.
11.5.1.1 Modifying config.xml
To modify the config.xml file:
• Either (i) edit the config.xml file in the ...\plugins\com.nomagic.magicdraw.reportwizard\data
folder to enable or disable all templates’ warning messages or (ii) edit the config.xml file or create a
file in the ...\plugins\com.nomagic.magicdraw.reportwizard\data\templatefolder folder for each
template.
For example, to enable or disable a warning message of Class Specification Report you need to edit the config.xml file in the ...\plugins\com.nomagic.magicdraw.reportwizard\data\Class Specification Report folder.
11.5.1.2 Adding Tags and Values
Figure 151 -- tag : tag for Warning Message Type
Table 23 -- Warning Message Types
Warning Message Type
Tag
Invalid Property
<template.warn.invalid.property>
Invalid Reference
<template.warn.invalid.reference>
Invalid Method
Reference
<template.warn.invalid.method>
Exception
<template.warn.exception>
The value is a boolean value:
• the boolean value is “true” when enabling warning messages
• the boolean value is “false” when disabling warning messages
An example of how an Invalid Reference warning message of Class Specification Report can be enabled is
shown in Figure 152.
Figure 152 -- File config.xml
183
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
12. Use Case Driven
Report Wizard provides a set of templates to support the Use Case Driven approach methodology. A
MagicDraw project that creates the Use Case Driven approach development steps can generate a report to
capture elements.
Report Wizard provides 3 templates for the Use Case Driven approach:
12.1 Use Case Specification Report
12.2 Method Specification Report
12.3 Use Case Project Estimation Report
You can create a new MagicDraw project using the Use Case Driven approach either as:
(i) a blank project by using the UseCase_Profile.xml module, or
(ii) a Use Case project
(i) To create a new project as a blank project using UseCase_Profile.xml:
1. On the main menu, click File.
2. Click Use Module… . The Use Module dialog will open.
3. Select the UseCase_Profile.xml module.
4. Click Finish. The MagicDraw project will apply the Use Case Description profile.
(ii) To create a new project as a Use Case Project:
• A MagicDraw project will apply the Use Case Description profile automatically.
12.1 Use Case Specification Report
The Use Case Specification report shows the details of actors and use cases in the project. The first part, which
is the actor summary, shows the list of all actors and their associated use cases. The second part presents the
use case specification in general information relations and scenarios. The report supports use case and SysML
use case diagrams.
12.2 Method Specification Report
The purpose of the Method Specification report is to show the method design and its related use cases in
details to developers.
The report shows a class diagram and a list of all classes in the diagram. The list contains attributes and methods for each class. The report also shows the method specification, parameters, and algorithms.
12.3 Use Case Project Estimation Report
The use case project estimation or 'Use Case Points' is a method for sizing and estimating projects developed
with the object-oriented method, developed by Gustav Karner of Objectory (now Rational Software). The
method is an extension of Function Point Analysis and Mk II Function Point Analysis (an adaption of FPA
mainly used in the UK).
The Use Case Project Estimation report is intended to estimate the project size and duration per man per hour
based on the use case model. The report supports use case and SysML use case diagrams.
184
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
The use case point technique is applied to reestimate the project size. All the use cases used in the example
below are based on the use case diagram. The following weight criteria are used:
12.3.1 Classifying Actors
Table 24 -- Actors Classification
Actor complexity
Litmus Test to recognize classifications
Weight
Low complexity
An external system with a well-defined API.
1
Average complexity
Either a human with a command line interface or an
external system via some protocol or a database.
2
High complexity
A human with a GUI or a web page.
3
Figure 153 -- Use Case Driven - Actor Classification
12.3.2 Unadjusted Actor Weights
Unadjusted Actor Weights (UAW) is obtained by counting how many actors there are in each category, multiplying each total by its weight, and adding up the products.
185
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
12.3.3 Determining Scenarios and Transactions of Use Cases
Table 25 -- Use Case Complexity
Use Case complexity
Litmus Test to decide classifications
Weight
Low complexity
1 - 3 transactions
5
Average complexity
4 - 7 transactions
10
High complexity
> 7 transactions
15
Figure 154 -- Use Case Driven - Use Case Complexity
12.3.4 Unadjusted Use Case Weights
A transaction is a set of activities, which is either performed entirely or not at all. Determining the number of
transactions can be done by counting the use case steps. Next multiply each use case type by the weighting
factor and add up the products to get Unadjusted Use Case Weights (UUCW).
12.3.5 Unadjusted Use Case Point
Add UAW and UUCW to get Unadjusted Use Case Point (UUCP): UUCP = UAW + UUCW.
186
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
Reference Documents
• The Estimation of Effort Based on Use Cases, publish by Rational software
ftp://ftp.software.ibm.com/software/rational/web/whitepapers/2003/finalTP171.pdf
• COCOMO II
http://sunset.usc.edu/csse/research/COCOMOII/cocomo_main.html
12.4 Project Characteristics
The Technical and Environmental factors are associated with the weight of the project. You have to assign a
value to each factor. The value assigned to a particular factor depends on the degree of influence a factor has.
The relevance values range from 0 to 5, where 0 means no influence, 3 is the average level of influence, and 5
means a strong influence throughout.
12.4.1 Technical Factors
Table 26 -- Technical Factors
Factor
Technical Factors
Weight
Description
T1
Distributed system
2.0
The system distributed architecture or centralized
architecture.
T2
Response adjectives
1.0
The response time is one of the important criteria.
T3
End-user efficiency
1.0
The end-user efficiency.
T4
Complex processing
1.0
The business process is very complex.
T5
Reusable code
1.0
The project maintains high reusability. The design
is complex.
T6
Easy to install
0.5
The project requires simple installation.
T7
Easy to use
0.5
User-friendly is one of the important criteria.
T8
Portable
2.0
The project is cross platforms implementation.
T9
Easy to change
1.0
The project is highly customizable in the future.
The architecture design is complex.
T10
Concurrent
1.0
The project has a large numbers of users working
with locking support. The architecture increases
the project complexity.
T11
Security features
1.0
The project has heavy security.
T12
Access for third parties
1.0
The project is dependent on a third party control.
Studying and understanding the third party is
required.
T13
Special training
required
1.0
The application is so complex for the user that
training must be provided.
187
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
Figure 155 -- Use Case Driven Model Data T1
12.4.1.1 Technical Factor Value
Technical Factor Value (TFactor) is obtained by multiplying the value of each Technical factor by its weight.
TFactor = value x weight
12.4.1.2 Technical Complexity Factor
Technical Complexity Factor (TCF) is obtained by adding 0.6 to the sum of TFactor multiplied by 0.01.
TCF = 0.6 + (0.01 * TFactor)
12.4.2 Environmental Factors
Table 27 -- Environmental Factors
Factor
Enviromental Factors
Weight
Description
E1
Familiar with RUP
1.5
Staffs in the project are familiar with domain
and technical details of the project.
188
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
Factor
Enviromental Factors
Weight
Description
E2
Application experience
0.5
The application experience level.
E3
Object-oriented experience
1.0
Staffs in the project have basic knowledge of
the OOP concepts. The project is implemented
on the object oriented design.
E4
Lead analyst capability
0.5
The analyst who is leading the project has
enough domain knowledge.
E5
Motivation
1.0
The project motivates staff to work. Including
how the software industry is going on?
E6
Stable requirements
2.0
The requirements are clear, stable, and
unlikely to change in the future.
E7
Part-time workers
-1.0
Part-time staffs are working on the project.
E8
Difficult programming language
-1.0
Programming language complexity.
Figure 156 -- Use Case Driven Model Data E2
12.4.2.1 Environmental Factor Value
Environmental Factor Value (EFactor) is obtained by multiplying the value of each Environmental factor by its
weight.
189
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
12.4.2.2 Environmental Factor
Environmental Factor (EF) is obtained by adding 1.4 to the sum of EFactor multipled by -0.03.
EF = 1.4 + (-0.03 * EFactor)
12.4.3 Project Estimation
Figure 157 -- Variables of Use Case Project Estimation
12.4.3.1 Adjusted Use Case Points
The Adjusted Use Case Point (UCP) is determined by multiplying Unadjusted Use Case Point (UUCP) by Technical Complexity Factor (TCF) and Environmental Factor (EF).
UCP = UUCP * TCF * EF
12.4.3.2 Estimated Effort in Person Hours
The person hours multiplier or X hours is a ratio of the number of man hours (PHM) per Use Case Point based
on past projects. If no historical data has been collected, a figure between 15 and 30 is suggested by industry
experts. A typical value is 20.
X hours = UCP * PHM
12.4.3.3 Estimated Effort in Scheduled Time
Divide X hours by the number of developers working on the project and working hours per day to determine
Estimated Effort in Scheduled Time or Y days. This means that with nDev developers, it would take Y days to
complete the project.
190
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Use Case Driven
Y days = X / nDev / hay
12.4.3.4 Estimated Effort in Working Days
Divide Y days by working days per month to get the estimated effort in working days or Z months. This means
that with nDev developers, it would take Z month to complete the project.
Z months = Y / d Month
191
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
13. Javadoc Syntax Tool
Javadoc is the industry standard for documenting Java classes. Javadoc can be documented inside the documentation field (Figure 158).
Figure 158 -- Documentation Field
Report Wizard provides a template tool for translating Javadoc text into Javadoc properties. Javadoc Tool will
be loaded and used inside the template upon the user’s request.
An example of Javadoc text:
192
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
/**
* A base class realizing from interface {@link ITool}.
* This class provides default implementation for
* {@link ITool}. The extended class from this class may
* send message or object to observer class by invoke
* {@link #notifyObservers(Object)} of class <code>
* Observable</code>. The observer class such as
* {@link AbstractTemplateEngine} or graphical user
* interface can catch notified object and interact with
* user.
*
* @author Siri Chongasamethaworn ([email protected])
* @since Aug 3, 2007
*/
Print the Javadoc comment and author inside the template:
#import ("javadoc",
"com.nomagic.reportwizard.tools.doc.JavaDocTool")
#set ($doc = $javadoc.create($class.documentation))
Comment:
$doc.comment
Author:
$doc.author
The output from this example will be:
Comment:
A base class realizing from interface ITool. This class
provides default implementation for ITool. The extended
class from this class may send message or object to
observer class by invoke #notifyObservers(Object) of class
Observable. The observer class such as
AbstractTemplateEngine or graphical user interface can
catch notified object and interact with user.
Author:
Siri Chongasamethaworn ([email protected])
The Javadoc Syntax Tool is implemented based on Custom Tool (See Appendix A: Report Extensions).
193
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
13.1 Javadoc Syntax
A doc comment consists of characters between the characters /** that begin the comment and the characters */
that end it. Leading asterisks are allowed on each line and are described below. Text in a comment can continue on to multiple lines.
• Leading asterisks
When Javadoc Tool parses a doc comment, leading asterisk (*) characters on each line are
discarded.
• First sentence
The first sentence of each doc comment is a summary sentence. This sentence can be retrieved
from $doc.firstSentenceTags. The first sentence tags are a collection of inline tags until full
stops (.).
• Comment and tag sections
A comment is the main description which begins after the starting delimiters /** and continues
until the tag section. A tag section starts with the first block tag. The comment can be retrieved
by $doc.comment
• Comments are written in HTML
Text is written in HTML and will be rendered as HTML support before being printed to a report.
(See Appendix D: HTML Tag Support)
• Block and in-line tags
A tag is a special keyword within a doc comment that Javadoc Tool can process. There are two
kinds of tags:
(i) Block tags
They can be placed only in the tag section. The block tag form is @tag. The block tag can be
accessed directly from the root document, for example, $doc.param and $doc.author.
The $doc.tags will provide a collection of all the tags appearing in this Javadoc.
(ii) Inline tags
They can be placed anywhere in the main description or in the block tags. The inline tag form is
{@tag}.
194
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
Table 28 -- Current Supported Tags
Tag
JDK
Report Wizard Support
@author
1.0
Yes
{@code}
1.5
Render as <code>text</code>
{@docRoot}
1.3
Not supported
@deprecated
1.0
Yes
@exception
1.0
Yes
{@inheritDoc}
1.4
Not Supported
{@link}
1.2
Yes, with conditions (external link and model support, class/
method link will be ignored)
{@linkplain}
1.4
Yes, see {@link link}
{@literal}
1.5
Yes
@param
1.0
Yes
@return
1.0
Yes
@see
1.0
Yes, with condition (external link and model support, class/
method link will be return as plain text)
@serial
1.2
Yes
@serialData
1.2
Yes
@serialField
1.2
Yes
@since
1.1
Yes
@throws
1.2
Yes
{@value}
1.4
Not Supported
@version
1.0
Yes
195
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
13.2 Javadoc Tool API
Figure 159 -- Javadoc Tool API
13.2.1 JavaDocTool
JavaDoc Tool is a custom tool class used for creating a Document node.
• create() - return a new instance of a Document node. Each JavaDoc comment must be started with /**
and ended with */.
• createForText() - return a new instance of a Document node. This method allows in-complete JavaDoc
(comments without /** and */) to be loaded with JavaDocTool.
13.2.1.1 Document
Document is an interface representing a Comment Document.
• getRawComment() - return the full unprocessed text of the comment.
• getTags() - return all tags in this document item.
• getTags(tagName : String) - return tags of the specified kind of this document item.
• get(tagName : String) - return a tag of the specified kind of this document item. If tags with the same
kinds are found, the first tag of this kind will be returned.
196
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
13.2.1.2 DocumentImpl
DocumentImpl is a default JavaDoc document implementation.
• getComment() - return formatted text for this document.
• getInlineTags() - return comment as a collection of tags.
• getFirstSentenceTags() - return the first sentence of the comment as a collection of tags.
13.2.1.3 Tag
Tag is an interface representing a simple documentation tag, such as @since, @author, @version
• getKind() - return the kind of this tag.
• getText() - return the text of this tag.
• getInlineTags() - return a collection of tags. For a documentation comment with embedded {@link}
tags.
13.2.1.4 TagImpl
TagImpl is a default tag implementation.
• getRawText() - return the full unprocessed text of this tag.
• toString() - return the text of this tag. Usually call getText().
13.2.1.5 ParamTag
ParamTag represents a @param documentation tag.
• getName() - return the name of the parameter associated with this tag.
• getComment() - return the parameter comment.
13.2.1.6 ThrowsTag
ThrowsTag represents a @throws or @exception documentation tag.
• getName() - return the name of the exception associated with this tag.
• getComment() - return the exception comment.
13.2.1.7 SeeTag
SeeTag represents a user-defined cross-reference to related documentation. The reference can either be inline
with the comment, using {@link}, or a separate block comment, using @see.
• getLabel() - return the label of the @see tag.
• getReference() - return the MODEL or URL of the @see reference.
• getLink() - return the Link object represent this tag.
13.2.1.8 SerialFieldTag
SerialFieldTag represents a @serialField tag.
• getFieldName() - return the serial field name.
• getFieldDescription() - return the field comment.
• getFieldType() - return the field type string.
For examples:
197
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
• Import the Javadoc tool and create an instance of Javadoc document:
#import ("javadoc",
"com.nomagic.reportwizard.tools.doc.JavaDocTool")
#set ($doc = $javadoc.create($comment))
• Print a Javadoc comment:
$doc.comment
• Print the first encountered author:
$doc.author
• Print all authors:
#foreach ($author in $doc.getTags("author"))
$author.text
#end
• Print the first sentence:
#foreach ($tag in $doc.firstSentenceTags)
$tag.text
#end
• Print the inline tags:
#foreach ($tag in $doc.inlineTags)
$tag.kind
$tag.text
#end
• Print a raw comment: (plain text without document parser or HTML renderer)
$doc.rawComment
• Print all block tags:
#foreach ($tag in $doc.tags)
$tag.kind : $tag.text
#end
• Print all param tags:
#foreach ($author in $doc.getTags("param"))
$param.name – $param.comment
#end
• Print all throws tags:
#foreach ($author in $doc.getTags("throws"))
$param.name – $param.comment
#end
• Print all see tags:
#foreach ($author in $doc.getTags("see"))
$param.label – $param.reference
#end
Reference Documents
• Javadoc specification
http://java.sun.com/j2se/1.5.0/docs/tooldocs/windows/javadoc.html#javadoctags
• Writing Javadoc
198
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Javadoc Syntax Tool
http://java.sun.com/j2se/javadoc/writingdoccomments/index.html
• Javadoc Tool API
<install.dir>/plugins/com.nomagic.magicdraw.reportwizard/api/javadoc.zip
199
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Import Tool
14. Import Tool
Import Tool enables you to dynamically import documents or parts of them into reports, giving you greater flexibility when generating reports that require dynamic resources. You can now include documents whose location
is only known at the actual translation time.
Import Tool allows you to:
• parse and import RTF, DOCX, HTML and text templates from any location in the file system;
• reuse the #sectionBegin and #sectionEnd syntax to import any part of a document. ImportTool
makes use of the predefined syntax: #sectionBegin and #sectionEnd, which were introduced with
the #includeSection directive. (See #includeSection Directive in the Report Wizard Custom
Language section for #sectionBegin and #sectionEnd usage)
14.1 Import Syntax
To use the Import tool syntax:
1. Declare Import Tool in the template by typing: #import ('import',
'com.nomagic.reportwizard.tools.ImportTool'). The directive #import will load Import
Tool so that it can be accessed inside the template.
• The first parameter 'import' is for identifying the alias of Import Tool (in this case,
'import', but it can be named anything).
• The second parameter 'com.nomagic.reportwizard.tools.ImportTool' has to be copied
as it is (do not rename it). Otherwise, Import Tool will not be loaded. For further details,
see Dialog Tool.
2. You can then import any content from a child template by typing:
• $import.include('child.rtf') to import a complete document at the current position of the
template, and/or
• $import.includeSection('child.rtf', 'Section A') to include only the text contained in the
named section of the document.
$import
This part names the alias assigned to Import Tool when declaring it to the template.
200
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Import Tool
$import.include(FileName)
A 'FileName' specifies the location of a file in the file system. This filename can be either an absolute or a relative path. The 'FileName' parameter can be set either statically or dynamically. See the Import Usage section
for an illustration on how to use it.
$import.includeSection( FileName, SectionName)
A ‘FileName' functions the same as in the sub-section above. A 'SectionName' denotes a paragraph in the document named 'FileName', which is delimited by the #sectionBegin(SectionName) and #sectionEnd identifiers. The SectionName variable can also be set either statically or dynamically. See the Import Usage section
for an illustration on how to use it.
14.2 Import Usage
14.2.1 Preparatory Step
Define a child template that you will use in examples 1, 2, and 3. This child template contains the following
header line and named sections ('Section A' and 'Section B') :
This is the child template.
#sectionBegin(Section A)
This is Section A.
#sectionEnd
#sectionBegin(Section B)
This is Section B.
#sectionEnd
14.2.2 Usage in Example 1
This example shows how to statically include the complete child template as shown in the Preparatory Step. To
include it, call the $import.include('child.rtf') method. Note that there is no specified path, this path to the child
template tells you that the master and child templates reside in the same directory.
#import ('import', 'com.nomagic.reportwizard.tools.ImportTool')
This is the 1st master template
Include child template
$import.include('child.rtf')
The output right below will include the entire text from the master template (right above) and from the child template (see the Preparatory Step) minus the template directives. The included content will be then parsed and
stripped of all velocity directives. The output is as follows:
201
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Import Tool
This is the 1st master template
Include child template
This is the child template.
This is Section A.
This is Section B.
14.2.3 Usage in Example 2
This example shows how to statically include a section of the child template as shown in the Preparatory Step.
To include the section, named 'Section A', from the child template, call the $import.includeSection('templates/child.rtf', 'Section A') method. In this example, the master and child templates reside in different directories, which means that the child template will reside in a subdirectory called 'templates'. This 'templates'
directory will thus reside in the same directory as the master template.
#import ('import', 'com.nomagic.reportwizard.tools.ImportTool')
This is the 2nd master template
Include Section A
$import.includeSection('templates/child.rtf', 'Section A')
The output will be:
This is the 2nd master template
Include Section A
This is Section A.
14.2.4 Usage in Example 3
This example shows how to dynamically include the section of a child template as shown in the Preparatory
Step. Before dynamically including the section of the child template, named 'Section B', set a variable for the file
location of the child template [#set ($child = "C:/ImportTool/child.rtf")] and another one for the section name
to be included [#set ($section = "Section B")]. To include the ‘Section B’ section from the child template, call
the $import.includeSection($child, $section) method. In this example, the child's template location is provided by an absolute path. Note that dynamic values must not be quoted, otherwise the section will not be
included.
#import ('import', 'com.nomagic.reportwizard.tools.ImportTool')
This is the 3rd master template
Include Section B
#set ($child = "C:/ImportTool/child.rtf")
#set ($section = "Section B")
$import.includeSection($child, $section)
The output will be:
202
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Import Tool
This is the 3rd master template
Include Section B
This is Section B.
NOTE
203
Import Tool supports RTF, HTML, XML, and text files only.
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
JavaScript Tool
15. JavaScript Tool
JavaScript Tool enables report templates to evaluate or run JavaScript codes from templates and external
JavaScript files (Figure 160).
The general concept behind this JavaScript feature is to separate complex business logic from presentation
logic. Complex logic should be executed by JavaScript and presentation logic by Velocity code.
Figure 160 -- Class Diagram: JavaScript Tool
JavaScript Tool includes 3 methods:
(i) 'eval' Method: this method will evaluate JavaScript text, and then return the result.
(ii) 'execute' Method: this method will execute a JavaScript file, and then return the result.
(iii) 'call' Method: this method will call a JavaScript function, and then return the result.
Like any other Custom Tools, JavaScript Tool (jstool.jar and js.jar) must be installed in the 'extensions' folder of
the Report Wizard plugin. For further information on Custom Tool and installation, see 19.1 Custom Tool, Text
Tool.
To import JavaScript Tool to a template type, for example:
#import('js', 'com.nomagic.reportwizard.tools.script.JavaScriptTool')
15.1 JavaScript Tool API
15.1.1 'eval' Method
eval(String script)
This method will evaluate a JavaScript code from a string and return the result.
$js.eval('script')
204
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
JavaScript Tool
eval(String script, Object bindingObject)
This method will evaluate a JavaScript code with a single binding object. The code will be evaluated from a
string. The "importer" name will be used as a binding name for this object.
#foreach ($class in $Class)
$js.eval('importer.getName()', $class)
#end
eval(String script, String bindingName, Object bindingObject)
This method will evaluate a JavaScript code with a single binding object and specified binding name. The code
will be evaluated from a string. The binding name will be used as the name for this object.
#foreach ($class in $Class)
$js.eval('cls.getName()', 'cls', $class)
#end
eval(String script, Map bindingMap)
This method will evaluate a JavaScript code with a set of binding arguments (name and object). The code will
be evaluated from a string. The binding map consists of key-value pairs for this binding name and binding
object.
#set ($map = $map.createHashMap())
#set ($void = $map.put("first", "foo"))
#set ($void = $map.put("last", "bar"))
$js.eval("first + ' ' + last", $map
15.1.2 'execute' Method
execute(String filename)
This method will execute a JavaScript file. The filename parameter is a file path to the JavaScript file.
$js.execute('filename.js')
execute(String filename, Object bindingObject)
This method will execute a JavaScript file with a single binding object. The filename parameter is a file path to
the JavaScript file. The "importer" name will be used as the binding name for this object.
205
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
JavaScript Tool
#foreach ($class in $Class)
$js.execute('filename.js', $class)
#end
// filename.js
importer.getName();
execute(String filename, String bindingName, Object bindingObject)
This method will execute a JavaScript file with a single binding object and specified binding name. The filename
parameter is a file path to the JavaScript file. The binding name will be used as the name for this object.
#foreach ($class in $Class)
$js.execute('filename.js', 'cls', $class)
#end
// filename.js
cls.getName();
execute(String filename, Map bindingMap)
This method will execute a JavaScript file with a set of binding arguments (name and object). The filename
parameter is a file path to the JavaScript file. The binding map consists of key-value pairs for this binding name
and binding object.
#set ($map = $map.createHashMap())
#set ($void = $map.put("first", "foo"))
#set ($void = $map.put("last", "bar"))
$js.execute('filename.js', $map)
// filename.js
first + ' ' + last;
NOTE
• Absolute Path: If a 'filename' is provided with an absolute path, JavaScript Tool will
read the JavaScript file from an absolute location [for example, $js.execute('c:/
mycode/readclass.js')].
• Relative Path: If a 'filename' is provided with a relative path, JavaScript Tool will read
the template from a relative location. This relative location starts from the current
directory in which the template is located [for example, $js.execute('readclass.js')].
206
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
JavaScript Tool
15.1.3 'call' Method
call(String function)
This method will provide a short and reusable method to call a JavaScript function. This function must be
defined before calling this method. This function can be defined by 'eval' or 'execute'.
$js.execute('javascript.js')
$js.call('calc(1, 3)')
// javascript.js
function calc(var1, var2)
{
return var1 + var2;
}
call(String function, Object bindingObject)
This method will provide a short and reusable method to call a JavaScript function with a single binding object.
The "importer" name will be used as the binding name for this object. This function must be defined before calling this method. This function can be defined by 'eval' or 'execute'.
$js.execute('javascript.js')
$js.call('calc(1, 3)', 10)
// javascript.js
function calc(var1, var2)
{
var f = Number(importer ? importer : 0);
return f + var1 + var2;
}
call(String function, String bindingName, Object bindingObject)
This method will provide a short and reusable method to call a JavaScript function with a single binding object
and specified binding name. This binding name will be used as the name for this object. This function must be
defined before calling this method. This function can be defined by 'eval' or 'execute'.
$js.execute('javascript.js')
$js.call('calc(1, 3)', 'factor', 10)
// javascript.js
function calc(var1, var2)
{
var f = Number(factor ? factor : 0);
return f + var1 + var2;
}
207
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
JavaScript Tool
call(String function, Map bindingMap)
This method will provide a short and reusable method to call a JavaScript function with a set of binding arguments (a name and an object). The binding map consists of key-value pairs for this binding name and binding
object.
#set ($map = $map.createHashMap())
#set ($void = $map.put("first", "foo"))
#set ($void = $map.put("last", "bar"))
$js.call('hello()', $map)
// filename.js
function hello()
{
return 'hello ' + first + ' ' + last;
}
15.2 References to Elements
References to elements are implicitly inserted into the JavaScript context when calling eval(), execute(), or
call(). Examples of implicit variables include, for instance, $Class, $UseCase, $sorter, etc.
Example:
// variable $Dependency and $sorter can be accessed directly inside
JavaScript
function getSupplier()
{
var supplierList = new ArrayList();
for (var i=0; i<$sorter.sort($Dependency.size()); i++)
{
var dependency = $Dependency.get(i);
supplierList.add(dependency.getSupplier());
}
return supplierList;
}
Reference Documents
• Mozilla JavaScript Tool
http://developer.mozilla.org/en/Rhino_documentation
• Sun JavaScript programming guide
http://java.sun.com/javase/6/docs/technotes/guides/scripting/programmer_guide/index.html
208
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Groovy Script Tool
16. Groovy Script Tool
Groovy Script Tool enables report templates to evaluate or run Groovy codes from templates and external
Groovy files.
The Groovy Tool includes 3 methods:
(i) 'eval' method: this method will evaluate Groovy text, and then return the result.
(ii) 'execute' method: this method will execute a Groovy file, and then return the result.
Like any other Custom Tool, the Groovy Sript Tool (groovytool.jar and groovy-all-1.7.9.jar) must be installed in
the 'extensions' folder of the Report Wizard plugin. For further information on Custom Tool and installation, see
19.1 Custom Tool.
To import Groovy Script Tool to a template, type the following code:
#import ('groovy',
'com.nomagic.reportwizard.tools.script.GroovyScriptTool')
16.1 Groovy Script Tool API
16.1.1 'eval' Method
eval(String script)
This method will evaluate a Groovy code from a string and return the result.
$groovy("println 'Hello World!'")
eval(String script, String bindingName, Object bindingObject)
This method will evaluate a Groovy code with a single binding object and specified binding name. The code will
be evaluated from a string. The binding name will be used as the name for this object.
#foreach ($c in $Class)
$groovy.eval("println '$classname'", "classname", $c.name)
#end
eval(String script, Map bindingMap)
This method will evaluate a Groovy code with a set of binding arguments (name and object). The code will be
evaluated from a string. The binding map consists of key-value pairs for the binding name and the binding
object.
209
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Groovy Script Tool
#set ($map = $map.createHashMap())
#set ($void = $map.put("first", "foo"))
#set ($void = $map.put("last", "bar"))
$groovy.eval("println first + last", map)
Or
$groovy.eval("println first + last", {"first":"foo", "last":"bar"})
NOTE
The second code contains curly brackets; '{' and '}' characters, which are not allowed to
be used in any RTF template. For an RTF template, use the first code instead.
16.1.2 'execute' method
execute(String filename)
This method will execute a Groovy file. The 'filename' parameter refers to a name of the Groovy file or an absolute path to the Groovy file.
$groovy.execute("filename.groovy")
execute(String filename, String bindingName, Object bindingObject)
This method will execute a Groovy file with a single binding object and specified binding name. The 'filename'
parameter is a file path to the Groovy file. The binding name will be used as the name for this object.
#foreach ($c in $Class)
$groovy.execute("filename.groovy", 'c', $c)
#end
execute(String filename, Map bindingMap)
This method will execute a Groovy file with a set of binding arguments (name and object). The 'filename'
parameter is a file path to the Groovy file. The binding map consists of key-value pairs for the binding name and
the binding object.
#set ($map = $map.createHashMap())
#set ($void = $map.put("first", "foo"))
#set ($void = $map.put("last", "bar"))
$groovy.execute("filename.groovy", map)
210
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Groovy Script Tool
NOTE
• Absolute Path: If the 'filename' is provided with an absolute path, Groovy Tool will read
the Groovy file from an absolute location, for example, $groovy.execute('c:/mycode/
readclass.groovy').
• Relative Path: If the 'filename' is provided with a relative path, Groovy Tool will read
the template from a relative location. This relative location starts from the current
directory in which the template is located, for example,
$groovy.execute('readclass.js').
16.2 References to Elements
References to elements are similar to ones in JavaScript Tool. The elements are implicitly inserted into the
Groovy context when calling “eval()”, or “execute()”. Examples of implicit variables include, for instance, $Class,
$UseCase, $sorter, etc.
File 'AllAbstractClass.groovy'
// variable $Class can be accessed directly inside Groovy script
def list = []
for (c in $Class) {
if (c.isAbstract()) {
list.add(c)
}
}
return list
The report template code:
#import ('groovy',
'com.nomagic.reportwizard.tools.script.GroovyScriptTool')
#set ($abstractClassList = $groovy.execute('AllAbstractClass.groovy'))
#foreach ($cls in $abstractClassList)
$cls.name
#end
211
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Dialog Tool
17. Dialog Tool
The purpose of Dialog Tool is to enable report templates to call functions for creating dialogs to interact with
users during the report generation process. You can also modify the report templates by using Dialog Tool.
Figure 161 -- Class Diagram: Dialog Tool
Dialog Tool uses 4 methods:
(i) ‘message’: this method will create message dialogs.
(ii) ‘confirm’: this method will create confirmation dialogs and return the Boolean value ‘true’ when you click
the OK button or return ‘false’ when you click the Cancel button.
(iii) ‘input’: this method will create input dialogs and return the input value as a string.
(iv) ‘sort’: this method will create sort and enable dialogs and return a collection of new sorted results.
Like any other Custom Tools, Dialog Tool (dialogtool.jar) must be installed in the ‘extensions’ folder of the
Report Wizard plugin.
To import Dialog Tool to a template type, for example:
#import('dialog','com.nomagic.reportwizard.tools.DialogTool')
17.1 Dialog Tool API
17.1.1 ‘message’ Method
message(String message) : void. This method will create messages into message dialogs, for example:
$dialog.message("Click OK to close dialog")
212
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Dialog Tool
The output will be:
Figure 162 -- Message Dialog
17.1.2 ‘confirm’ Method
confirm(String message) : boolean. This method will create messages into confirmation dialogs and
return the Boolean value ‘true’ when you click the OK button or ‘false’ when you click the Cancel button in the
dialog, for example:
#if($dialog.confirm("Do you want to geanerate section A?"))
#end
The output will be:
Figure 163 -- Confirmation Dialog
17.1.3 ‘input’ Method
17.1.3.1 Input Dialogs with Text
input(String message) : String. This method will create input dialogs from messages, and then return
the input value as a string when you click the OK button or ‘null’ when you click the Cancel button in the dialog,
for example:
#set ($userText = $dialog.input("Enter your name"))
#if ($userText)
Your name is $userText
#else
Please specify your name
#end
213
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Dialog Tool
The output will be:
Figure 164 -- Input Dialog with Text
17.1.3.2 Input Dialogs with Text and Initial Value
input(String message, String initialValue) : String. This method will create messages and
initial values into input dialogs and return the input value as a string when you click the OK button or ‘null’ when
you click the Cancel button in the dialog, for example:
#set ($userText = $dialog.input("Enter a date",
“July10,2009”))
Date is $userText
The output will be:
Figure 165 -- Input Dialog with Text and Initial Value
17.1.3.3 Input Dialog with Text and Initial Value Array
input(String message, Collection options) : String. This method will create messages and initial value arrays into input dialogs and return the input value as a string when you click the OK button or ‘null’
when you click the Cancel button in the dialog, for example:
#set ($selectedOption = $dialog.input("Choose your favorite
fruit", ["Apple", "Orange", "Banana"]))
Your favorite fruit is $selectedOption
The output will be:
Figure 166 -- Input Dialog with Text and Initial Value Array
214
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Dialog Tool
17.1.4 ‘sort’ Method
17.1.4.1 Sort and Enable Dialogs
sort(Collection list) : Collection. This method will create sort and enable dialogs from collections
and return a collection of the newly sorted results when you click the OK button or return the original collection
when you click the Cancel button in the dialog, for example:
#foreach ($diagram in $dialog.sort($Diagram))
$diagram.name
#end
The output will be:
Figure 167 -- Sort and Enable Dialog
17.1.4.2 Sort and Enable Dialogs with Text
sort(String message, Collection list). This method will create the Sort and Enable dialogs from
text and collections and return a collection of the newly sorted results when you click the OK button or return
the original collection when you click the Cancel button in the dialog, for example:
#foreach ($diagram in $dialog.sort("Rearrange diagram for presentation report",$Diagram))
$diagram.name
#end
The output will be:
215
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Dialog Tool
Figure 168 -- Sort and Enable Dialog with Text
216
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Text Tool
18. Text Tool
Text tool provides extra functions to convert or format text.
Figure 169 -- Class Diagram: Text Tool
Like any other Custom Tools, Text Tool (text.jar) must be installed in the 'extensions' folder of the Report Wizard
plugin. For further information on Custom Tool and installation, see 19.1 Custom Tool, Text Tool.
To import Text Tool to a template type, for example:
#import('text', 'com.nomagic.reportwizard.tools.TextTool')
18.1 Text Tool API
noLineBreak(String text)
This method will remove all control characters such as U+0009 (Tab), U+000A (Line Feed), and U+000D (Carriage Return) from a given text. This method will also filter text under the category "Cc" in the Unicode specification. An example of a use case that contains multiple lines, the code will be:
$usecase.name
The output will be:
Line 1
Line 2
Line 3
With the $text.noLineBreak() method, the code will be:
$text.noLineBreak($usecase.name)
The output will be:
217
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Text Tool
Line 1 Line 2 Line 3
toInteger(String text)
Converts a string argument to a signed decimal integer, for example:
#set ($int = $text.toInteger('2'))
#set ($result = $int + 1)
Result is $result
toDouble(String text)
Converts a string argument to a signed decimal double, for example:
#set ($d = $text.toDouble('10.1'))
#set ($result = $d + 2)
Result is $result
italic(String text)
Forces a report to render a given text in italics, for example:
The $text.italic($class.name) must provide interface for web
services.
The output will be:
The BusinessServices must provide interface for web services.
bold(String text)
Forces a report to render a given text in bold, for example:
Method $text.bold($operator.name) must be implemented by
implementation class.
The output will be:
Method doService must be implemented by implementation class.
underline(String text)
218
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Text Tool
Forces a report to render a given text in underline, for example:
Attribute $text.underline($attribute.name) contains a service
name.
The output will be:
Attribute serverName contains a service name.
html(String text)
Forces a report to render a given text as HTML, for example:
$text.html('<ul><li>A</li><li>B</li></ul>')
The output will be:
·A
·B
For more information on the supported HTML tags, see Appendix D: HTML Tag Support.
getString(String text)
Converts text from RTF to a Java String, for example:
#set ($str = $text.getString("Übersetzer"))
$str
The output will be:
Übersetzer
equals(String str1, String str2)
Compares two strings. The result will be true if and only if str1 represents the same sequence of characters as
str2 does. This method supports RTF text comparison. For example:
219
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Text Tool
#set ($str = $text.getString("Übersetzer"))
#if ($text.equals($str, "Übersetzer"))
true
#end
220
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
19. Appendix A: Report Extensions
Report Wizard has been enhanced with an extension that provides additional functionalities (for example, Custom Tool that encapsulates Java functions in context). The report extensions are Java class and related
resources collected into JAR archives, which are just ZIP files that contain a specially formatted “manifest” file
describing the contents of the archive.
To install the extension, copy the .jar file into the extensions directory under the Report Wizard plugin directory or template directory. The archives stored within subdirectories will not be loaded in Report Wizard (Figure 170).
Figure 170 -- Report Wizard Plug-in Directory Structure.
The extension deployed under the global extensions directory will affect all templates, which means you can
use the deployed Custom Tool in all templates. Extensions deployed under a template package will affect only
the specific template.
19.1 Custom Tool
Custom Tool is a template library written in Java for the purpose of encapsulating functions in context. Custom
Tool (Figure 171) is extended from the report API. The tool can be used to develop custom context properties
that are presentation centric or that can take advantage of the existing ‘Tool’ extensions or by document authors
familiar with Java.
Report Wizard uses the word 'Tool' to mean an object encapsulating dynamic functions on the JavaBean. A
Tool is a "carrier" of data between the Java and template layers. In other words, the Tool simplifies template
development and maintenance.
221
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
Figure 171 -- Custom Tool API Structure.
19.1.1 Context Name
A Context name is a name for variables or references in the template. Report Wizard uses the Velocity Template Language (VTL) as a standard syntax for the template. VTL uses “$” as a leading character followed by
an identifier for the variable.
Example:
$UseCase
$foo.name
19.1.2 Context Object
A Context object is a Java Object representing a variable. A Context object is modeled on the JavaBean specifications defined by Sun Microsystems.
For example, if a String represents the variable $foo.name in context, the value of the String will be printed out
in the output report.
Foo Name
19.2 Tool Interface
Custom Tool is written in Java language. The tool implements a specialized interface, called ITool. The Report
API provides both an interface and a class for supporting interface realization and class generalization. As
mentioned earlier, a Tool is modeled on the JavaBean specifications. Functions implemented in this class must
be defined in a series of setter or getter methods. Sample 1 shows the source code for the ITool interface that
you must implement:
222
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
public interface ITool extends IBean
{
// attributes
Void VOID = new Void();
// inner classes
public class Void{}
public class RetainedString implements CharSequence{}
// methods
void setContext(IContext context);
String getContext();
void setProperties(Properties properties);
Properties getProperties();
}
All tools must implement the ITool interface (or one of its subclasses) as it defines the methods the template
engine calls to execute. Table 29 provides a description of the methods in the ITool interface.
Table 29 -- Description of Methods in ITool interface.
Method
Description
setContext(Context context)
Once the class has been initialized, this method is
called by the template engine runtime to set the template context. Overriding the current context will affect
the code after this tool.
getContext()
Return the template context that is assigned to the current runtime.
setProperties(Properties properties)
This method is called by the template engine runtime,
once the class has been initialized, to set the template
properties. Overriding the current properties will not
affect the engine.
getProperties()
Return the current template properties.
VOID
Represents the Void class. VOID is used to make sure
that returning data from the setter method is absolutely
nothing. In general, Velocity considers return void
from the setter method as a ‘null’ value. This causes the
word 'null' to be printed out in the report. To avoid this
problem, the setter method may use VOID as a return
object.
class Void
A void class is used as a return in Tool when you want
to be sure that nothing is returned to context.
class RetainedString
A direct command report formatter to keep the referenced String format. The formatter and other reference
insertion handler should maintain Strings directed by
this class.
Other classes which can be extended are Tool and ConcurrentTool.
223
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
Figure 172 -- ITool Interface And Related Class.
19.2.1 Class Tool
Class Tool is a base class realizing the interface ITool. This class provides the default implementation for
ITool.
This class also provides methods derived from the java.util.Observable class, which can be used to notify the
observers. An observer class, such as a template engine or a graphical user interface class, can receive the
notification message from the tool and manage to display or interact with the user.
19.2.2 Concurrent Tool
Concurrent Tool provides concurrent task running in the template engine. This class implements an unbounded
thread-safe queue, which arranges the elements by first-in-first-out order. New tasks are inserted at the tail of
the queue, and the queue retrieval operations obtain elements at the head of the queue.
The tool extends from this class and is ideal for processing a long task that does not want other tasks to wait
until the process is complete. Sample 2 shows the sample usage of Concurrent Tool.
import com.nomagic.magicreport.engine.ConcurrentTool;
public class LongTaskTool extends ConcurrentTool
{
public String longTask() {
// enqueue object
offer(new ConsumeObject(referent));
}
public void consume(ConsumeObject consumeObject) {
Object referent = consumeObject.get();
// process long task
}
}
An example of Concurrent Tool is FileTool. The root template that calls the file tool method will create a subprocess, offer the subprocess into queue, and continue the root template until finish. The template engine will
later call the consume method to complete the subprocess once the consumer queue is available. The number
of concurrent process available for execution is declared in the template engine property. (See TemplateConstants.TEMPLATE_POOL_SIZE for detail.)
224
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
19.3 Creating Custom Tool
There are a few steps involved in developing a custom tool. These steps can be summarized as follows:
(16.3.1) Developing a Tool Class
(16.3.2) Creating an Extension Package
19.3.1 Developing a Tool Class
A Developing Tool class requires setting a class path to magicreport.jar. You can find magicreport.jar from
the library folder under the Report Wizard plugin directory. Sample 3 shows the source code for Hello.java.
package mytool;
import com.nomagic.magicreport.engine.Tool;
public class HelloTool extends Tool
{
public String getHello() {
return "Hello World";
}
public String getHello(String name) {
return "Hello " + name;
}
}
The sample shows two methods following the getter concept defined by the JavaBean specification.
19.3.2 Creating an Extension Package
The extension package is delivered in a JAR file. JAR (Java ARchive) is a file format based on the popular ZIP
file format and is used for aggregating many files into one. You can create a JAR file by storing *.class with
the Java package folder structure in a ZIP file format or creating from a JAR tool.
To combine files into a JAR file, for example:
jar cf MyTool.jar *.class
In this example, all the class files in the current directory are placed in the file named "MyTool.jar". A manifest file entry named META-INF/MANIFEST.MF is automatically generated by the JAR tool. The manifest file is
the place where any meta-information about the archive is stored as name: value pairs. Refer to the JAR file
specification for details.
jar cf MyTool.jar mytool
Another example, all the class files in the directory mytool are placed in the file named "MyTool.jar".
A complete JAR tool tutorial can be found at:
• http://java.sun.com/docs/books/tutorial/deployment/jar/
225
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix A: Report Extensions
• http://java.sun.com/javase/6/docs/technotes/tools/windows/jar.html
19.4 Installing Custom Tool
To install the extension, just copy the JAR file containing a custom tool class into the extensions directory under
the Report Wizard plugin directory or template directory. Report Wizard will automatically load a new JAR file
when a new report is generated.
19.5 Importing Custom Tool to Template
Report Wizard uses the import directive for importing a Custom Tool to a template.
An example of a directive:
#import('prefix', 'name')
The import directive declares that the template uses the custom tool, names the tool that defines it, and specifies its tag prefix before the custom tool is used in a template page. You can use more than one import directive
in a template, but the prefix defined in each must be unique.
19.5.0.1 Attributes
• name (type:String)
The uniform or full qualified class name that locates the Tool class, for example,
mytool.HelloTool
• prefix (type:String)
The prefix that precedes the custom tool name, for example, a string in $hello.getHello().
Empty prefixes are not allowed. When developing or using custom tools, do not use tag prefixes
such as bookmark, sorter, template, file, array, group, map, iterator, list, date, report, exporter,
profiling, and project, as they are reserved by Report Wizard.
Sample 4: Declares a custom tool
#import('hello', 'mytool.HelloTool')
Get Hello
$hello.getHello()
Get Hello Foo
$hello.getHello('foo')
The output from the above template is:
Get Hello
Hello World
Get Hello Foo
Hello foo
226
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
20. Appendix B: Office Open XML Format Template
Office Open XML (also referred to as OOXML or Open XML) refers to standardized file formats for representing
spreadsheets, charts, presentations and word processing documents for Microsoft Office. These standardized
file formats become free and open as ECMA-376 Office Open XML File Formats - 2nd edition (December
2008) and ISO/IEC 29500:2008.
The most common Open XML file formats are supported by Report Wizard, including:
• DOCX - for word processing (text) documents
• XLSX - for spreadsheets
• PPTX - for presentations
20.1 Microsoft Office Word Document (DOCX)
Report Wizard supports most DOCX features. You can place the VTL codes inside core (properties) and content of any DOCX file. All syntax usable in RTF can also be used in DOCX.
Figure 173 -- Sample of DOCX, Converted from RTF Document
20.1.1 Limitations
1. Cannot use #forcol in DOCX. If you try to use #forcol in a DOCX report template (Figure 174),
227
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 174 -- Using #forcol in DOCX
the error message in Figure 175 will then be shown.
Figure 175 -- Error Message When Using #forcol in DOCX
2. Cannot use multi-line statements in different object. If you try to use multi-line statements in
DOCX (Figure 176),
Figure 176 -- Invalid Usage of Multi-line Statement in DOCX
the error message in Figure 177 will then be shown.
Figure 177 -- Error Message of Invalid Usage of Multi-line Statement in DOCX
20.2 Microsoft Office Excel Worksheet (XLSX)
20.2.1 Multi-line Statements in XLSX
228
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
All multi-line directives such as #if-#else-#elseif, #foreach and #macro, must be used with the following
conditions.
1. The begin and end statements must be declared within a single cell. Figure 178 and 179
below show samples of invalid usage of the #if and #foreach statements between cells
respectively.
Figure 178 -- Invalid Usage of Multi-line #if Statement in XLSX
Figure 179 -- Invalid Usage of Multi-line #foreach Statement in XLSX
In Figure 178, since the body of the #if statement ($e.name) resides in the A2 cell, not in
the A1 cell, the body will not be generated when generating a report, regardless of the
evaluation of the #if statement.
In Figure 179, this code will break the structure of spreadsheet document.
Figure 180 and 181 demonstrate samples of valid usage of the #if and #foreach
statements, respectively.
Figure 180 -- Valid Usage of Multi-line #if Statement in XLSX
Figure 181 -- Valid Usage of Multi-line #foreach Statement in XLS
229
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
2. VTL Macro must be declared within a single cell. Do not insert the multi-cell recorded macros
in a single cell (Figure 182).
Figure 182 -- Invalid Usage of #macro Statement in XLSX
The macro will copy all contents between #macro and #end. Cells and rows will be included
in the macro as well. Once this record has been inserted, the macro content will break the
document structure.
Figure 183 demonstrates a sample of valid usage of #macro statement.
Figure 183 -- Valid Usage of #macro Statement in XLSX
20.2.2 Creating Data for Multiple Row
The #foreach directive can only be used in a single cell record. To create data for multiple rows, use the #forrow directive instead (Figure 184).
230
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 184 -- Usage of #forrow in XLSX
The output of the above code is shown in Figure 185.
Figure 185 -- Output of #forrow in XLSX
20.2.3 Creating Data for Multiple Columns
#forcol is used for creating data for multiple columns (Figure 186). This statement can be used in conjunction
with the #forrow statement.
Figure 186 -- Usage of #forcol in XLSX
The output of the above code is shown in Figure 187.
Figure 187 -- Output of #forcol in XLSX
20.2.4 Displaying Content in Cell
Texts in any generated report are always wrapped. Also, the cells’ width in the generated report depends on the
cells’ width in the report template used. For example, an XLSX report template in Figure 188 will generate an
output report as shown in Figure 189.
231
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 188 -- Sample of Wrapped Text (Column B) in XLSX Report Template
Figure 189 -- Wrapping Text Output in XLSX
20.2.5 Limitation
#sectionBegin and #includeSection cannot be used in XLSX. If you try to use #sectionBegin (or
#includeSection) in an XLSX report template (Figure 190),
Figure 190 -- Using #sectionBegin in XLSX
the error message in Figure 191 will then be shown.
232
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 191 -- Error Message When Using #sectionBegin in XLSX
20.3 Microsoft Office PowerPoint Presentation (PPTX)
A presentation document requires a special document template. This template does not contain any content
order, and each text content is always placed inside a text box. A text box is an image structure (an image
structure keeps the position of each image in x, y coordinates). Text box positions can be changed. Text boxes
can also be placed in the same positions as others (Figure 192).
Figure 192 -- Sample of PPTX Template
20.3.1 Multi-line Statements in PPTX
Similar to XLSX, all multi-line directives such as #if-#else-#elseif, #foreach and #macro, must be used
with the following conditions.
1. The begin and end statements must be declared within a single text box. Figure 193 below
shows the sample of invalid usage of the#foreach statement between text boxes.
233
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 193 -- Invalid Usage of Multi-line Statement #foreach in PPTX
Since the PPTX template does not provide the statement order, the template will not be
interpreted as the order of the displayed images (text boxes). For example, $uc.name may
be processed after #foreach($uc in $UseCase) has been completely processed.
Figure 194 below demonstrates a sample of valid usage of the #foreach statement.
Figure 194 -- Valid Usage of Multi-line Statement #foreach in PPTX
2. VTL Macro must be declared within a single text box. Do not insert the multi-cell recorded
macros in a single text box (Figure 195).
Figure 195 -- Invalid Usage of #macro Statement in PPTX
234
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Since, each text box does not have any sequence order; therefore, the macro cannot record any content
between the text boxes. Figure 196 demonstrates a valid usage of the #macro statement.
Figure 196 -- Valid Usage of #macro Statement in PPTX
20.3.2 Creating Data for Multiple Slides
In PPTXreport templates, you can use the #forpage directive to create additional slide(s) in your presentation.
You can use #forpage and #endpage directives in any text box. However, the #endpage directive must be in
same slide as the #forpage directive is or in the following slide, but not before the slide which contains the
#forpage directive. All directives contained in the slides between the slide the #forpage directive appears and
the slide the #endpage directive appears will be included within #forpage statement. For example, the template in Figure 197 will produce the output in Figure 198.
Figure 197 -- Sample of Valid Usage of #forpage in PPTX
235
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 198 -- Sample Output of Valid Usage of #forpage in PPTX
20.3.3 Creating Page with Conditions
Since directive in PPTX report template does not provide any statement order (unless residing in the same text
box), the #if directive cannot be used with the #forpage directive (Figure 199).
Figure 199 -- Sample of Looping With Condition in General Style
The code in Figure 199 will not produce the output report as expected, because the #forpage directive automatically covers all directives in the current page regardless of statement order. Consequently, the #if directive
may not be interpreted after the #forpage directive.
To avoid this problem, you can use the $report.filterElement($elements, $types) method. This helper
method provides the element filter for the specified type. For example, use the following code (Figure 200).
236
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix B: Office Open XML Format Template
Figure 200 -- Sample of Looping With Conditional Filter
For more details on $report.filterElement($elements, $types), see Section 4 Helper Modules.
20.3.4 Limitation
#sectionBegin, #includeSection, #forrow and #forcol cannot be used in any PPTX report template. If
you try, for example, to use #sectionBegin in a PPTX report template (Figure 201),
Figure 201 -- Using #sectionBegin in PPTX
the error message in Figure 202 will then display.
Figure 202 -- Error Message When Using #sectionBegin in PPTX
237
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
21. Appendix C: OpenDocument Format Template
The OpenDocument format (ODF) is an open file format for office documents, such as spreadsheets, presentations, and word processing documents. The standard was developed by the Open Office XML technical committee of the Organization for the Advancement of Structured Information Standards (OASIS) consortium.
The version 1.0 manifestation was published as an ISO/IEC International Standard, ISO/IEC 26300:2006
Open Document Format for Office Applications (OpenDocument) v1.0.
The most common files supported by Report Wizard are:
• ODT - for word processing (text) documents
• ODS - for spreadsheets
• ODP - for presentations
21.1 OpenDocument Text
Report Wizard supports most OpenDocument Text (ODT) features. It enables you to input the VTL codes inside
meta-data, styles, and text content. All syntax usable inside RTF can be used with ODT.
Figure 203 -- Sample of OpenDocument Text Converted From RTF Document
21.2 OpenDocument Spreadsheet
All multiline directives such as #if-#else-#elseif, #foreach, and #macro, must be used with the following conditions.
238
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
1. The begin and end statements must be declared within a single cell. Figures 204 and 205
below show a sample of invalid usage of the #if statement between cells.
Figure 204 -- Invalid Usage of Multiline Statement in ODS
Figure 205 -- Invalid Usage of Multiline Statement in ODS
Since the body of the #if statement contains cell A2, this cell will not be generated if the
condition is not true (the element type is not “usecase”). Due to the constraints of
spreadsheet document structure, the number of cells in a column must be equal to the
number of cells in all columns, and the number of cells in a row must be equal to the
number of cells in all rows.
The codes in Figure 205 will break the structure of a spreadsheet document. Figures 206
and 207 demonstrate a sample of valid usage of the #if statement.
Figure 206 -- Valid Usage of Multiline Statement in ODS
Figure 207 -- Valid Usage of Multiline Statement in ODS
2. VTL Macro must be declared within a single cell. Do not insert the multi-cell recorded macros
in a single cell (Figure 208).
239
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
Figure 208 -- Invalid Usage of Macro Statement in ODS
The macro will copy all contents between #macro and #end. Cells and rows will be
included in the macro as well. Once this record has been inserted, the macro content will
break the document structure.
21.2.1 Creating Data for Multiple Rows
The #foreach directive can only be used in a single cell record. To create data for multiple rows, use the
#forrow directives instead (Figure 209).
Figure 209 -- Usage of #forrow
As shown in Figure 209, the output will be:
Figure 210 -- Output of #forrow
21.2.2 Creating Data for Multiple Columns
#forcol is used to create data for multiple columns (Figure 211). This statement can be used with #forrow
(see sample from the “Other Document” template).
Figure 211 -- Usage of #forcol
240
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
As shown in Figure 211, the output will be:
Figure 212 -- Output of #forcol
21.3 OpenDocument Presentation
A presentation document is a special document template. This template does not contain a content order. The
text content used within this document is inserted inside a text box. A text box is an image structure (an image
structure keeps the position of each image in x, y coordinates).
Text box positions can be changed. Text boxes can also be placed in the same position as others (Figure 213).
Figure 213 -- Sample of ODP Template
Using the same concept as ODS, all multi-line directives such as #if-#else-#elseif, #foreach, and
#macro must be used with conditions.
To create a presentation document:
1. The begin and end statements must be declared within a single text box. Figure 214 below
shows the sample of invalid usage of the #if statement between text boxes.
241
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
Figure 214 -- Invalid Usage of Multiline Statement in ODP
Since the ODP template does not provide the statement order, the template will not be
interpreted in the order of the display of the image. For example, $uc.name may be
processed after #foreach($uc in $UseCase) has been completed.
Figure 215 below shows the sample of valid usage of the #foreach statement.
Figure 215 -- Valid Usage of Multiline Statement in ODP
2. VTL Macro must be declared within a single text box. Do not insert the multi-cell recorded
macros in a single text box (Figure 216).
242
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
Figure 216 -- Invalid Usage of Macro Statement in ODP
The text box does not have a sequence order; therefore, macro cannot record any content
between the text boxes (Figure 217).
Figure 217 -- Valid Usage of Macro Statement in ODP
21.3.1 Creating Data for Multiple Slides
ODP uses the #forpage directive to create a slide for each data. The #forpage directive does not contain
any order. You can use #forpage and #endpage in any text box. All directives inside the slide will be included
within #forpage (Figure 218).
243
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
Figure 218 -- Sample of #forpage Usage
The output from the code in Figure 219 is an ODP with a single use case name for each slide.
Figure 219 -- Sample Output from #forpage
For more samples of ODP report, see the “Other Document” template.
21.3.2 Creating Page with Conditions
244
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
The ODP directive does not provide any statement order; therefore, the #if directive will not be attached to
#forpage (Figure 220).
Figure 220 -- Sample of Looping with Condition in General Style
The codes in Figure 220 may not produce the report exactly as expected. #forpage automatically covers all
directives in the current page without any statement order. So the #if directive may not be interpreted after
#forpage.
To solve this problem you can use the $report.filterElement($elements, $types) method. This
helper method provides the element filter for the specified type. The codes will be:
Figure 221 -- Sample of Looping with Conditional Filter
For more details on $report.filterElement($elements, $types), see Section 4 Helper Modules.
21.4 OpenDocument Conversion Tool
The following tools can convert RTF documents to ODF documents.
21.4.1 Microsoft Office ODF Extensions
This Microsoft Office add-on allows Microsoft Office to open and save Microsoft Office documents to the
OpenDocument format.
Download Microsoft Office ODF Extensions from http://odf-converter.sourceforge.net/
21.4.2 OpenOffice.org
OpenOffice.org is an office suite that can open and save documents in many formats. This tool can also open
RTF documents and save them as ODF documents.
245
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix C: OpenDocument Format Template
Download OpenOffice.org from http://www.openoffice.org
246
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22. Appendix D: HTML Tag Support
Report Wizard supports HTML code conversion to RTF, ODF and OOXML file formats. The HTML code is created from the Element Documentation pane (Figure 222).
Figure 222 -- MagicDraw Documentation Pane
The element documentation can also be retrieved by the following VTL code:
#foreach ($e in $elements)
$e.documentation
#end
Whenever the report engine encounters an HTML content, it will automatically convert the content into a valid
output format style.
22.1 Supported HTML Tags
22.1.1 Font Tags
A font tag consists of three attributes: (22.1.1.1) Size, (22.1.1.2) Face, and (22.1.1.3) Color.
22.1.1.1 Size
The Size attribute determines the font size. Possible values are integers from 1 to 7. The default base font size
is 3. The greater the value, the larger the size.
• The base font size for RTF documents is 24 dot (equivalent to 12 pt).
• The base font size for ODF documents is 12 pt.
• The base font size for OOXML documents is 12 pt.
• The base font size for HTML documents is determined by the web browser.
247
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Each value will be multiplied by two. An example of a size attribute:
<font size="3">
It will be rendered as font size 12 pt
<font size="5">
It will be rendered as font size 16 pt
<font size="1">
It will be rendered as font size 8 pt
If the size attribute is specified without the face attribute, the default font will be determined by the template or
document editor, unless the font tag is covered by other HTML elements such as <code> or <tt>.
22.1.1.2 Face
The Face attribute defines the font name. If the face attribute is specified without the size attribute, the default
size will be determined by the template or the document editor.
22.1.1.3 Color
The Color attribute specifies the text color. A color value can be either a hexadecimal number (prefixed with a
hash mark) or one of the following sixteen colors. Colors are case-insensitive.
Table 30 -- Font Colors
Color
Hexadecimal code
Black
#000000
Silver
#C0C0C0
Gray
#808080
White
#FFFFFF
Maroon
#800000
Red
#FF0000
Purple
#800080
Fuchsia
#FF00FF
Green
#008000
Lime
#00FF00
Olive
#808000
Yellow
#FFFF00
Navy
#000080
Blue
#0000FF
Teal
#008080
Aqua
#00FFFF
Example:
248
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 223 -- Sample of Font Tags
As shown in Figures 224, the outputs in RTF, ODFor HTML will be:
Figure 224 -- Sample of RTF, ODF or HTML Document Output
22.1.2 Font Style Tag
Table 31 -- Font Style Elements
Tag name
Description
TT
Renders teletyped or monospaced text.
I
Renders italic text.
B
Renders bold text.
BIG
Renders text in large font.
SMALL
Renders text in small font.
STRIKE and S
Renders strikethrough text.
U
Renders underlined text.
• TT – This tag will be rendered as <font face=”Courier New”>
• I – This tag is supported by the existing HTML conversion component.
• B – This tag is supported by the existing HTML conversion component.
• BIG – This tag will be rendered as <font size=”5”>
• SMALL – This tag will be rendered as <font size=”1”>
• STRIKE and S – This tag will be rendered as strikethrough text.
• U – This tag is supported by the existing HTML conversion component.
249
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.1.3 Phrase Elements
Table 32 -- Phrase Elements
Tag name
Function
EM
Indicates emphasis.
STRONG
Indicates stronger emphasis.
CITE
Contains a citation or a reference to other sources.
DFN
Indicates that this is the defining instance of the enclosed term.
CODE
Designates a fragment of computer code.
SAMP
Designates a sample output from programs, scripts, etc.
KBD
Indicates the text to be entered by the user.
VAR
Indicates an instance of a variable or program argument.
ABBR
Indicates an abbreviated form, for example, WWW, HTTP, URI, Mass, etc.
ACRONYM
Indicates an acronym, for example, WAC, radar, etc.
• EM – This tag will be rendered as <i>
• STRONG – This tag will be rendered as <b>
• CITE – This tag will be rendered as <i>
• DFN – This tag will be rendered as <i>
• CODE – This tag will be rendered as <font face=”Courier New”>
• SAMP – This tag will be rendered as <font face=”Courier New”>
• KBD – This tag will be rendered as <font face=”Courier New”>
• VAR – This tag will be rendered as <i>
• ABBR – This tag will be rendered as normal text.
• ACRONYM – This tag will be rendered as normal text.
22.1.4 Ordered and Unordered Lists, and List Item Tags
Ordered and unordered lists are rendered in an identical manner, except that ordered list items are numbered.
The report engine supports both unordered and ordered lists without attributes. The list tag attributes will be
ignored in the report output. The list tag attributes are type, start, value, and compact.
Both unordered and ordered lists are not supported in both XLSX and ODS templates.
22.1.4.1 Ordered Lists
An Ordered List is defined by the OL element. The element contains one or more LI elements that define the
actual items of the list.
Unlike unordered lists (UL), items in an ordered list have a definite sequence. A conversion will render items of
each ordered list with number. All OL attributes will be ignored in the report output. An example of Ordered List
tag:
250
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 225 -- Sample of Ordered List Tag
As shown in Figures 226, the outputs in RTF, ODFor HTML will be:
Figure 226 -- Sample of RTF, ODF or HTML Document Output
22.1.4.2 Nested Ordered Lists
HTML conversion will indent nested lists with respect to the current level of nesting. A number for each level will
restart at value 1. An example of Nested Ordered List tag:
Figure 227 -- Sample of Nested OL Tags
As shown in Figures 228, the outputs in RTF, ODFor HTML will be:
Figure 228 -- Sample of RTF, ODF or HTML Document Output
251
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.1.4.3 Unordered Lists
An Unordered List is defined by the UL element. The element contains one or more LI elements that define the
actual items of the list.
A conversion will render UL with a bullet preceding each list item. All UL attributes will be ignored in the report
output. Figure 229 shows an example of an Unordered List tag:
Figure 229 -- Sample of UL Tags
As shown in Figures 230, the outputs in RTF, ODF or HTML will be:
Figure 230 -- Sample of RTF, ODF or HTML Document Output
22.1.4.4 Nested Unordered Lists
Lists can also be nested. HTML conversion will indent nested lists with respect to the current level of nesting.
HTML conversion should attempt to present a small filled-in circle to first level, a small circle outline to second
level, and a filled-in square to third level. Bullets after third level are filled-in squares. An example of Nested
Unordered List tag:
Figure 231 -- Sample of Nested UL Tags
As shown in Figures 232, the outputs in RTF, ODF or HTML will be:
252
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 232 -- Sample of RTF, ODF or HTML Document Output
22.1.5 Definition List Tags
A Definition List is defined by the DL element. An entry in the list is created using the DT element for the term
being defined and the DD element for the definition of the term.
A definition list can have multiple terms for a given definition as well as multiple definitions for a given term.
Authors can also give a term without a corresponding definition, and vice versa, but such a structure rarely
makes sense.
A conversion will render DT as a non-indent item and DD as a single indent item. Definition List tag is not supported in XLSX template. Figure 233 shows an example of a Definition List tag:
Figure 233 -- Sample of DL Tags
As shown in Figures 234, the outputs in RTF, ODF or HTML will be:
Figure 234 -- Sample of RTF, ODF or HTML Document Output
22.1.6 Line and Paragraph Tags
A line is defined by the <BR> element. The element inserts a single line break. It is an empty tag. This means
that it has no end tag. The line attributes will be ignored in the report output.
A paragraph is defined by the <P> element. The element automatically creates some space before and after
itself. The paragraph attributes will be ignored in the report output. Figure 235 shows an example of a Line and
Paragraph tag:
253
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 235 -- Sample of Line and Paragraph Tags
As shown in Figures 236, the outputs in RTF, ODF or HTML will be:
Figure 236 -- Sample of RTF, ODF or HTML Document Output
22.1.7 Preformatted Text
A preformatted text is defined by the <PRE> element. All the space and carriage returns are rendered exactly
as you type them. The preformatted attributes will be ignored in the report output. Figure 237 shows an example of a preformatted text:
Figure 237 -- Sample of Preformatted Text
As shown in Figures 238 and 239 respectively, the outputs in RTF/ ODF and HTML will be:
Figure 238 -- Sample of RTF / ODF Document Output
254
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 239 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
22.1.8 Heading Tags
A heading is defined by the <H1>, <H2>, <H3>, <H4>, <H5>, or <H6> element. In this report all heading tags
will be rendered as <b> for ODT, RTF and OOXML document outputs. The heading attributes will be ignored in
the report output. Figure 240 shows an example of a Heading tag:
Figure 240 -- Sample of Heading Tags
As shown in Figures 241 and 242 respectively, the outputs in RTF / ODF and HTML will be:
Figure 241 -- Sample of RTF / ODF Document Output
Figure 242 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
255
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.1.9 Link Tags
A Link tag is defined by the <A> element. This element is used to create a link to another document by using
the href attribute. The href attribute specifies the destination of a link. Link tag is not supported in XLSX template. Figure 243 shows an example of a Link tag:
Figure 243 -- Sample of Link Tags
As shown in Figures 244, 245, and 246 respectively, the outputs in RTF, ODF, and HTML will be:
Figure 244 -- Sample of RTF Document Output
Figure 245 -- Sample of ODF Document Output
Figure 246 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
22.1.10 Table Tags
A table is defined by the <TABLE> element. A table consists of multi-dimensional data arranged in rows and
columns.
22.1.10.1 Table Elements
The <TABLE> element takes a number of optional attributes to provide presentational hints in document. The
table attributes will be ignored in the report output except the following attributes:
(i) border - specifies the width in unit of the border around a table.
(ii) bgcolor - specifies table background color. Apply background color here will affect whole table.
Table elements are not supported in XLSX, PPTX, ODS and ODP templates.
256
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 247 shows an example of a table tag:
Figure 247 -- Sample of Table Tags
As shown in Figures 248 and 249 respectively, the outputs in RTF / ODF and HTML will be:
Figure 248 -- Sample of RTF Document Output
Figure 249 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
(i) Border
Border width in HTML is specified in pixels. When convert into RTF, ODF or OOXML, 1 pixel equals to 1 pt.
(ii) Color
The attribute value type "bgcolor" refers to color definitions as specified in [SRGB]. A color value may be either
a hexadecimal number (prefixed by a hash mark) or one of the following sixteen colors. Colors are case-insensitive.
257
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Table 33 -- Table Element Colors
Color
Hexadecimal Code
Black
#00000000
Silver
#C0C0C0
Gray
#808080
White
#FFFFFF
Maroon
#800000
Red
#FF0000
Purple
#800080
Fuchsia
#FF00FF
Green
#008000
Lime
#00FF00
Olive
#808000
Yellow
#FFFF00
Navy
#000080
Blue
#0000FF
Teal
#008080
Aqua
#00FFFF
22.1.10.2 Row Elements
The <TR> elements act as a container for a row of table cells. The <TR> elements must be contained within
<TABLE>.
<TR> contains <TH> or <TD> elements, which in turn contain the actual data of the table. <TR> takes presentational attributes for specifying the alignment of cells within the row and the row's background color. The row
attributes will be ignored in the report output, except for the following attributes:
(i) align - specifies the horizontal alignment for each cell in the row.
(ii) valign - specifies the vertical position of a cell's contents.
(iii) bgcolor - specifies the table background color. A background color will apply to rows only. (See Color in
22.1.10.1 Table Elements for details)
Row elements are not supported in XLSX, PPTX, ODS and ODP templates.
(i) Align
This attribute specifies the alignment of data and the justification of text in a cell. Possible values are:
• left - Left-flush data/Left-justify text. This is the default value for table data.
• center - Center data/Center-justify text. This is the default value for table headers.
• right - Right-flush data/Right-justify text.
• justify - Double -justify text.
• char - No text alignment set.
(ii) Valign
258
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
This attribute specifies the vertical position of data within a cell. Possible values are:
• top: Cell data is flush with the top of the cell.
• middle: Cell data is centered vertically within the cell. This is the default value.
• bottom: Cell data is flush with the bottom of the cell.
• baseline: No text alignment set.
Figure 250 shows an example:
Figure 250 -- Sample of TR Tags
As shown in Figures 251 and 252 respectively, the outputs in RTF / ODF and HTML will be:
Figure 251 -- Sample of RTF Document Output
Figure 252 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
259
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.1.10.3 Cell Elements
The <TD> elements define a data cell in a table. <TD> elements are contained within a <TR> element (a table
row). The cell attributes will be ignored in the report output except for the following attributes:
• align - specifies the horizontal alignment for each cell in the row. (See Align in 22.1.10.2 Row Elements
for details)
• valign - specifies the vertical position of a cell's contents. (See Valign in 22.1.10.2 Row Elements for
details)
• bgcolor - specifies the table background color. A background color will apply only to cells. (See Color in
22.1.10.1 Table Elements for details)
• rowspan - rows spanned by the cell
• colspan - columns spanned by the cell
Cell elements are not supported in XLSX, PPTX, ODS and ODP templates.
Row Span
This attribute specifies the number of rows spanned by the current cell. The default value of this attribute is one
("1"). For an RTF output, the result of row span (*.rtf) is readable only in MS Word and Word on Mac.
Column Span
This attribute specifies the number of columns spanned by the current cell. The default value of this attribute is
one ("1"). Figure 253 shows an example of a column span:
Figure 253 -- Sample of TD Tags
As shown in Figures 254 and 255 respectively, the outputs in RTF / ODF and HTML will be:
260
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 254 -- Sample of RTF / ODF Document Output
Figure 255 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
261
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.1.10.4 Header Elements
The <TH> elements define a header cell in a table. <TH> elements are contained within a <TR> element (a
table row). The header attributes will be ignored in the report output, except for the following attributes:
• align - specifies the horizontal alignment for each cell in the row. (See Align in 22.1.10.2 Row Elements
for details)
• valign - specifies the vertical position of a cell's contents. (See Valign in 22.1.10.2 Row Elements for
details)
• bgcolor - specifies the table background color. A background color will apply to the whole table. (See
Color in 22.1.10.1 Table Elements for details)
• rowspan - rows spanned by the cell. (See Row span in 22.1.10.3 Cell Elements for details)
• colspan - columns spanned by the cell. (See Column span in 22.1.10.3 Cell Elements for details)
The default alignment for <TH> is center and the default font style for <TH> is bold. Header elements are not
supported in XLSX, PPTX, ODS and ODP templates. Figure 256 shows an example of header elements:
Figure 256 -- Sample of TH Tags
As shown in Figures 257 and 258 respectively, the outputs in RTF / ODF and HTML will be:
Figure 257 -- Sample of RTF / ODF Document Output
262
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 258 -- Sample of HTML Document Output (Open in Internet Explorer 7.0)
22.1.11 Image Tags
The <img> tag embeds an image in a document. The <img> tag consists of three attributes: (22.1.11.1) src,
(22.1.11.2) width and (22.1.11.3) height
22.1.11.1 src
The src attribute specifies the location of an image resource. The value of this attribute can be one of the following types:
• An URL, the recognized scheme type are HTTP, HTTPS, and FILE
• An absolute path, for example, c:/user/image.png. The path separator can be either /(slash) or
\(blackslash)
An output image format will depend on the image format source.
22.1.11.2 Width
The width attribute specifies the width of an image in pixel units, for example, width = “100” or width = “100px”
22.1.11.3 Height
The height attribute specifies the height of an image in pixel units, for example, height = “100” or height =
“100px”
NOTE
If the width or height attribute of an image is not specified, the size of
the image will be calculated according to the following rules:
• For an image file that contains the width and height properties, for
example, JPG, PNG, or GIF, the size of the image output will be
calculated from the size of the image.
• For an image file that has no width and height properties, for
example, SVG, EMF, or WMF, the size of the image output will be
calculated from the size of the paper.
If the HTML code, for example, is:
The image will be:
263
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 259 -- Sample of IMG Tags
References
ISO/IEC 26300:2006 Information Technology - Open Document Format for Office Applications
(OpenDocument) v1.0.
• http://www.iso.org/iso/iso_catalogue/catalogue_tc/catalogue_detail.htm?csnumber=43485
Application Supports for the OpenDocument Format
• http://opendocumentfellowship.com/applications
Microsoft expands List of Formats Supported in Microsoft Office
• http://www.microsoft.com/Presspass/press/2008/may08/05-21ExpandedFormatsPR.mspx
OpenOffice.org
• http://www.openoffice.org/
Microsoft Office ODF Extensions
• http://odf-converter.sourceforge.net/
22.2 Supported CSS
22.2.1 Background
The shorthand property for the background property is 'background', which is used for setting an individual
background style. Only the ‘background-color’ attribute is supported. Such attribute can be used in RTF, ODT,
and DOCX report templates.
22.2.1.1 Color Specification
Color attributes, for example, background-color, can be specified by either a keyword or a numerical RGB
specification. The list of color keywords is displayed in Table 34.
264
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Table 34 -- Color Keywords and Corresponding RGB Specification
Color
RGB Specification Hexadecimal Code
Maroon
#800000
Red
#ff0000
Orange
#ffA500
Yellow
#ffff00
Olive
#808000
Purple
#800080
Fuchsia
#ff00ff
White
#ffffff
Lime
#00ff00
Green
#008000
Navy
#000080
Blue
#0000ff
Aqua
#00ffff
Teal
#008080
Black
#000000
Silver
#c0c0c0
Gray
#808080
The format of an RGB specification value in hexadecimal notation is a '#' immediately followed by either three
or six hexadecimal characters. The three-digit RGB notation (#rgb) is converted to the six-digit form (#rrggbb)
by replicating digits. For example, #fb0 is converted to #ffbb00.
Example:
<p style = “background-color:#fb0”>
<p style = “background-color:#ffbb00”>
22.2.1.2 Supported Tags
The ‘background-color’ property can be used in the following tags: b, i, u, h1, h2, h3, h4, h5, h6,
tt, code, samp, kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font,
a, dl, dt, dd, ul, ol, li, table, tr, td, th, p, div, and span.
Example:
Figure 260 -- Sample of background style
265
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 261 -- Sample of Document Output
22.2.2 Border
The shorthand property for the border property is 'border', which is used for setting the same width, color, and
style of all four borders of a box. Border can be used in RTF, ODTand DOCX report templates.
22.2.2.1 Border Width
Border width properties specify the width of border areas. The value of the border property is length. The border
width properties that can be used with a longhand property are as follows:
• 'border-top-width'
• 'border-right-width'
• 'border-bottom-width'
• 'border-left-width'
22.2.2.2 Length Specification
The format of a length value is a real number immediately followed by a unit identifier. There are two types of
length units: relative and absolute. Relative length units specify a length relative to another length property.
Relative units are:
• px: pixels, relative to the viewing device.
Absolute units are:
• in: inches - 1 inch is equal to 2.54 centimeters.
• cm: centimeters.
• mm: millimeters.
• pt: points - the points used by CSS 2.1 are equal to 1/72nd of an inch.
• pc: picas - 1 pica is equal to 12 points.
22.2.2.3 Border Color
Border color properties specify the border colors of a box. The value of the border color has two meanings:
1. Color: specify a border color. See 22.2.1.1 Color Specification on page 264 for more detail on
color.
2. Transparent: a transparent border.
The border color properties that can be used with a longhand property are as follows:
• 'border-top-color'
• 'border-right-color'
• 'border-bottom-color'
• 'border-left-color'
266
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
22.2.2.4 Border Style
Border style properties specify the style of a box's border lines. The border style may take one of the following
10 values:
1. none: this value will create no borders because the computed border width is zero.
2. hidden: the same as 'none'.
3. dotted: this value will create a dotted border.
4. dashed: this value will create a dashed border.
5. solid: this value will create a single line segment border.
6. double: this value will create a two solid line border.
7. groove: this value will create a border that looks as though it were carved into the rendering
surface.
8. ridge: the opposite of 'groove'. This value will create a border that looks as though it were
coming out of the rendering surface.
9. inset: this value will create a border that looks as though it were embedded in the rendering
surface.
10. outset: the opposite of 'inset'. This value will create a border that looks as though it were
coming out of the rendering surface.
NOTE
• The supported border values for ODF documents are none, hidden, solid, and
double.
• The supported border values for RTF documents are none, hidden,dotted, dashed,
solid, and double.
• The supported border values for DOCX documents are none, hidden,dotted,
dashed, solid, double, outset, and inset (groove and ridge will be rendered as
solid).
The border style properties that can be used with a longhand property are as follows:
• 'border-top-style'
• 'border-right-style'
• 'border-bottom-style'
• 'border-left-style'
22.2.2.5 Supported Tags
Border properties can be used in the following tags: h1, h2, h3, h4, h5, h6, td, th, p, and div.
Example:
If you want to have a red border, for example, type (Figure 262):
Figure 262 -- Border Style Example
The result of using the above example, will be (Figure 263)
267
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 263 -- Red Border Output
22.2.3 Margin
Margin properties specify the width of margin areas of a box. The 'margin' property is a shorthand property for
setting the margin of all four sides while the other margin properties only set their respective side. The value of
the margin property is length. See 22.2.2.2 Length Specification on page 266 for more detail. Margin can be
used in RTF, ODT, ODP, DOCX and PPTX report templates.
The margin properties that can be used with a longhand property are as follows:
• 'margin-top'
• 'margin-right'
• 'margin-bottom'
• 'margin-left'
22.2.3.1 Supported Tags
The supported tags for margins are: h1, h2, h3, h4, h5, h6, table (support only RTF, ODT and
DOCX), p, and div.
Example:
If you want to set a specific margin width for your cells, for example, type (Figure 264):
268
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 264 -- Margin Style Example
The result of using the above example will be (Figure 265):
Figure 265 -- Margin Style Output
22.2.4 Padding
269
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Padding properties specify the width of padding areas of a box. The 'padding' property is a shorthand property
for setting the padding for all four sides while the other padding properties only set their respective side. The
value of the padding property is length. See 22.2.2.2 Length Specification on page 266 for more detail. Padding
can be used in RTF, ODT and DOCX report templates.
The padding properties that can be used with a longhand property are as follows:
• 'padding-top'
• 'padding-right'
• 'padding-bottom'
• 'padding-left'
22.2.4.1 Supported Tags
The supported tags for padding are: h1, h2, h3, h4, h5, h6, td, th, p, and div.
NOTE
• The supported border values of table tags for RTF documents are margin-left and
margin-right.
• The supported border values of table tags for DOCX documents are margin-left
and margin-right.
• The supported border values of all tags for PPTX documents are margin-left,
margin-top and margin-bottom.
Example:
If you want to create specific padding styles for your cells, for example, type (Figure 266):
Figure 266 -- Padding Style Example
The result of using the above example will be (Figure 267):
Figure 267 -- Padding Style Output
22.2.5 Color
270
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
The 'color' property specifies the foreground color of an element's text contents. Only color values are allowed
in this property. See 22.2.1.1 Color Specification on page 264 for more detail on color.
22.2.5.1 Supported Tags
The supported tags for colors are: b, i, u, h1, h2, h3, h4, h5, h6, tt, code, samp, kbd,
pre, big, small, strike, s, em, cite, dfn, var, strong, font, a, dl, dt, dd, ul,
ol, li, table, tr, td, th, p, div, and span.
Example:
If you want to have a green text color, for example, type (Figure 268)
Figure 268 -- Color Style Example
The result of using the above example will be (Figure 269):
Figure 269 -- Color Style Output
22.2.6 Display
The 'display' property specifies how text will be displayed. The possible display values are:
1. block: this value will make an element appear in the output report.
2. none: this value will make an element disappear from the output report.
22.2.6.1 Supported Tags
The supported tags for the display property are: br, b, i, u, h1, h2, h3, h4, h5, h6, tt, code,
samp, kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font, a, dl,
dt, dd, ul, ol, li (support only RTF, DOCX and PPTX), table, tr, p, div, and span.
Example:
If you want to display an element but do not want to display the other, for example, type (Figure 270):
Figure 270 -- Display Style Example
The result of using the above example will be (Figure 271)
271
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 271 -- Display Style Output
22.2.7 Font
The 'font' property is, except as described below, a shorthand property for setting:
• 'font-style'
• 'font-variant'
• 'font-weight'
• 'font-size'
• 'font family'
22.2.7.1 Font Family
Specify a prioritized list of font family names and/or generic family names.
22.2.7.2 Font Style
Specify either normal or italic face (within the specified font family).
22.2.7.3 Font Variant
Specify either normal or small-caps of variant (within the specified font family). Font variant is not supported in
XLSX report templates.
22.2.7.4 Font Weight
Specify the weight of the font. The following values are defined:
1. normal, lighter, 100, 200, 300 and 400 will be rendered as normal.
2. bold, bolder, 500, 600, 700, 800 and 900 will be rendered as bold.
22.2.7.5 Font size
Specify the font size. Possible values include xx-small, x-small, small, medium, large, xx-large, and the integer number from 1 to 7.
22.2.7.6 Supported Tags
The supported tags for the font property are: b, i, u, h1, h2, h3, h4, h5, h6, tt, code, samp,
kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font, a, dl, dt, dd,
ul, ol, li, table, tr, td, th, p, div, and span.
Example:
If you want to have bold fonts in small caps, for example, type (Figure 272):
272
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 272 -- Font Style Example
The result of using the above example will be (Figure 273):
Figure 273 -- Font Style Output
22.2.8 Text Align
The 'text align' property describes how inline contents of a block is aligned. Possible values of the text align
property include: left, right, center and justify. The ‘text align’ property can be used in RTF, ODT, ODP, DOCX
and PPTX report templates.
22.2.8.1 Supported Tags
The supported tags for the text align property are: table, tr, td, th, p, and div.
Example:
If you want to align your paragraph to the right, for example, type (Figure 274):
Figure 274 -- Text-align Style Example
The result of using the above example will be (Figure 275):
Figure 275 -- Text-align Output
22.2.9 Text Transform
The 'text transform' property controls capitalization effects of an element's text. Possible values of the 'text
transform' property include:
1. capitalize: this will begin a word's first character in an uppercase letter; other characters will
not be affected.
273
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
2. uppercase: this will put all characters of each word in uppercase.
3. lowercase: this will put all characters of each word in lowercase.
4. none: this will not create any capitalization effects.
22.2.9.1 Supported Tags
The supported tags for the text transform property are: b, i, u, h1, h2, h3, h4, h5, h6, tt, code,
samp, kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font, a, dl,
dt, dd, ul, ol, li, table, tr, td, th, p, div, and span.
Example:
If you want to make all letters in a paragraph into uppercase, for example, type (Figure 276):
Figure 276 -- Text-transform Style Example
The result of using the above example will be (Figure 277):
Figure 277 -- Text-transform Style Output
22.2.10 White-space
The 'white-space' property affects the vertical position of white-space inside a line box of the boxes generated.
White-space can be used in RTF, ODT, DOCX and PPTX report templates. Possible values of the 'white-space'
property include:
1. normal: for collapsing sequences of white space, and breaking lines as necessary to fill line
boxes.
2. pre: for preventing from collapsing sequences of white space. Lines are only broken at
newlines in the source, or at occurrences of "\A" in generated content. Report Wizard will
render this value as the <pre> tag.
3. nowrap: for collapsing white space as for 'normal', but suppressing line breaks within text.
4. pre-wrap: for preventing user agents from collapsing sequences of white space. Lines are
broken at newlines in the source, at occurrences of "\A" in generated content, and as
necessary to fill line boxes. This value will not be rendered as pre.
5. pre-line: for directing user agents to collapse sequences of white space. Lines are broken at
newlines in the source, at occurrences of "\A" in generated content, and as necessary to fill
line boxes. This value will not be rendered as pre.
22.2.10.1 Supported Tags
The supported tags for the 'white-space' property are: b, i, u, h1, h2, h3, h4, h5, h6, tt, code,
samp, kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font, a, table,
tr, td, th, p, div, and span.
Example:
If you want to preserve white-space, for example, type (Figure 278):
274
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 278 -- White-space Style Example
The result of using the above example will be (Figure 279):
Figure 279 -- White-space Style Output
22.2.11 Width
The 'width' property specifies the contents width of boxes generated by a block-level. The value of the width
property is length. See 22.2.2.2 Length Specification on page 266 for more detail. Width can be used in RTF,
ODT and DOCX report templates.
The supported tag for the width property includes table.
Example:
If you want to have a specific table width, for example, type (Figure 280):
275
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 280 -- Width Style Example
The result of using the above example will be (Figure 281):
Figure 281 -- Width Style Output
22.2.12 Text Decoration
The 'text decoration' property describes decorations that are added to text. Possible values of the text decoration property include:
1. none: for producing no text decoration.
2. underline: for underlining each line of text.
3. overline: for adding a line above each line of text.
4. line-through: for adding a line that strikes through the each line of text.
5. blink: for adding the blinking effect to text (alternates between visible and invisible). The blink
text decoration supports only ODT report template.
276
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
NOTE
Report Wizard does not currently support an overline text decoration.
22.2.12.1 Supported Tags
The supported tags for the text decoration property are: b, i, u, h1, h2, h3, h4, h5, h6, tt,
code, samp, kbd, pre, big, small, strike, s, em, cite, dfn, var, strong, font, a,
dl, dt, dd, ul, ol, li, table, tr, td, th, p, div, and span.
Example:
If you want to create a line-through text, for example, type (Figure 282):
Figure 282 -- Text-decoration Style Example
The result of using the above example will be (Figure 283):
Figure 283 -- Text-decoration Style Output
22.2.13 Vertical Align
The 'vertical align' property affects the vertical position of an element inside a line box of the boxes generated.
This property can be used in RTF, ODT and DOCX report templates. Possible values of the vertical align property include:
1. baseline: this value will align the baseline of a box with the baseline of the parent box. Leave
the vertical alignment to default when you encounter this value.
2. middle: this value will align the vertical midpoint of a box.
3. top: this value will align the top of the aligned sub-tree with the top of a line box.
4. bottom: this value will align the bottom of the aligned sub-tree with the bottom of a line box.
The supported tags for the vertical align property are: table, tr, td, and th.
Example:
277
Copyright © 1998-2011 No Magic, Inc..
REPORT WIZARD
Appendix D: HTML Tag Support
Figure 284 -- Vertical-align Style Example
The result of using the above example will be (Figure 285):
Figure 285 -- Vertical-align Style Output
278
Copyright © 1998-2011 No Magic, Inc..
