Electrolux | MSV35G | User's Manual | Electrolux MSV35G User's Manual

Item
Model
ProjectName
The range of vertical slicers
provides a rational solution to the
slicing problems of restaurants,
canteens, butcher's and
supermarkets. Those appliances
are particularly ideal for slicing raw
meat, salamis and pressed meat in
general.The models detailed on
this sheet are vertical slicers with
gear transmissions.
601143
FEATURES
Base and main components in
sanitary burnished aluminium thus
guaranteeing durability, high sanitary
standards and ease of cleaning.
V Sharpened blades in tempered
forged steel.
V Removable and easy to use top
mounted stone blade sharpener.
V Removable carriage system.
V Gear drive system for heavy and
V
continuative daily operations.
V Cover blade and product deflector
easily removable without tools.
V Cover blade full covering for
improved slicing and movement during
manual operations.
V Carriage rollers and self-lubrification
bushes for ease of movements during
operation.
V Gauge plate interlock allows the
removal of carriage for cleaning only
when the appliance is switched off.
Food slicers
Gear transmission
Permanently mounted blade guard ring
aids protection from cutting blades while
operating and cleaning.
V Feeding carriage with tightening arm for
slicing of large products like ham (available
as special execution).
V Feeding carriage for slicing of soft
products like raw meat and roast beef
V Blade drive motor ventilated.
V
Gauge knob provides precise control of
slicing.
V CE approved.
V IP42 water protection.
V
Specifications
MODEL
External dimensions - mm
width
depth
height
Electrical power - kW
Net weight - kg.
MSV30G
601142
MSV35G
601143
680
580
480
0.375
40
770
750
510
0.375
53
Installation drawings
XXX
300 *415
480 *510
320 *340
570 *670
440 *490
680 *770
MSV30G
601142
230 V, 1N, 50
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
MSV35G
601143
400 V, 3, 50
www.dito-electrolux.com
AMBB010
MODEL
I - Electrical connection
580 *750
Food slicers
601142, 601143
