Orbitrap Elite Hardware Manual

Orbitrap Elite Hardware Manual

Part of Thermo Fisher Scientific

Thermo Fisher Scientific

Orbitrap Elite

Hardware Manual

Revision A - 1288170

© 2011 Thermo Fisher Scientific Inc. All rights reserved.

Alconox is a registered trademark of Alconox, Inc. Convectron is a registered trademark of Helix

Technology Corporation. Dremel is a registered trademark of the Robert Bosch Tool Corporation.

Edwards and the Edwards logo are trademarks of Edwards Limited. HiPace is a trademark of Pfeiffer

Vacuum Technology AG. Microsoft and Windows are registered trademarks of Microsoft

Corporation. PEEK polymer is a trademark of Victrex plc. PEEKSil is a trademark of SGE

International Pty. Ltd. SEQUEST is a registered trademark of University of Washington. Swagelok is a registered trademark of the Crawford Fitting Company. Teflon is a registered trademark of E. I. du

Pont de Nemours & Co. Tygon is a registered trademark of Saint-Gobain Performance Plastics

Company. Viton is a registered trademark of DuPont Performance Elastomers LLC.

All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.

Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the product operation. This document is copyright protected and any reproduction of the whole or any part of this document is strictly prohibited, except with the written authorization of Thermo

Fisher Scientific Inc.

The contents of this document are subject to change without notice. All technical information in this document is for reference purposes only. System configurations and specifications in this document supersede all previous information received by the purchaser.

Thermo Fisher Scientific Inc. makes no representations that this document is complete, accurate or error-free and assumes no responsibility and will not be liable for any errors, omissions, damage or loss that might result from any use of this document, even if the information in the document is followed properly.

This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a purchaser. This document shall in no way govern or modify any Terms and Conditions of Sale, which

Terms and Conditions of Sale shall govern all conflicting information between the two documents.

Release History: Revision A released in June 2011.

For Research Use Only. Not for use in diagnostic procedures.

Place Declaration of Conformity here

Regulatory Compliance

Thermo Fisher Scientific performs complete testing and evaluation of its products to ensure full compliance with applicable domestic and international regulations. When the system is delivered to you, it meets all pertinent electromagnetic compatibility (EMC) and safety standards as described in the next section or sections by product name.

Changes that you make to your system may void compliance with one or more of these EMC and safety standards.

Changes to your system include replacing a part or adding components, options, or peripherals not specifically authorized and qualified by Thermo Fisher Scientific. To ensure continued compliance with EMC and safety standards, replacement parts and additional components, options, and peripherals must be ordered from Thermo Fisher Scientific or one of its authorized representatives.

Velos Pro Mass Spectrometer (April 2011)

EMC Directive 2004/108/EEC

EMC compliance has been evaluated by TUV Rheinland of North America, Inc.

EN 61326-1: 2006

EN 55011: 2007, A2: 2007

CFR 47, FCC Part 15, Subpart B, Class A: 2009

EN 61000-3-2: 2006

EN 61000-3-3: 1995, A1: 2001, A2: 2005

EN 61000-4-2: 1995, A1: 1999, A2: 2001

EN 61000-4-3: 2006

EN 61000-4-4: 2004

EN 61000-4-5: 2005

EN 61000-4-6: 2007

EN 61000-4-11: 2004

Low Voltage Safety Compliance

This device complies with Low Voltage Directive 2006/95/EEC and harmonized standard EN 61010-1:2001.

Velos Pro/ETD System (April 2011)

EMC Directive 2004/108/EEC

EMC compliance has been evaluated by TUV Rheinland of North America, Inc.

EN 61326-1: 2006

EN 55011: 2007, A2: 2007

CFR 47, FCC Part 15, Subpart B, Class A: 2009

EN 61000-3-2: 2006

EN 61000-3-3: 1995, A1: 2001, A2: 2005

EN 61000-4-2: 1995, A1: 1999, A2: 2001

EN 61000-4-3: 2006

EN 61000-4-4: 2004

EN 61000-4-5: 2005

EN 61000-4-6: 2007

EN 61000-4-11: 2004

Low Voltage Safety Compliance

This device complies with Low Voltage Directive 2006/95/EEC and harmonized standard EN 61010-1:2001.

FCC Compliance Statement

THIS DEVICE COMPLIES WITH PART 18 OF THE FCC RULES.

WEEE Compliance

This product is required to comply with the European Union’s Waste Electrical & Electronic

Equipment (WEEE) Directive 2002/96/EC. It is marked with the following symbol:

Thermo Fisher Scientific has contracted with one or more recycling/disposal companies in each EU

Member State, and this product should be disposed of or recycled through them. Further information on Thermo Fisher Scientific’s compliance with these Directives, the recyclers in your country, and information on Thermo Fisher Scientific products which may assist the detection of substances subject to the RoHS Directive are available at www.thermo.com/WEEERoHS.

WEEE Konformität

Dieses Produkt muss die EU Waste Electrical & Electronic Equipment (WEEE) Richtlinie

2002/96/EC erfüllen. Das Produkt ist durch folgendes Symbol gekennzeichnet:

Thermo Fisher Scientific hat Vereinbarungen getroffen mit Verwertungs-/Entsorgungsanlagen in allen EU-Mitgliederstaaten und dieses Produkt muss durch diese Firmen wiederverwertet oder entsorgt werden. Mehr Informationen über die Einhaltung dieser Anweisungen durch Thermo

Fisher Scientific, die Verwerter und Hinweise die Ihnen nützlich sein können, die Thermo Fisher

Scientific Produkte zu identifizieren, die unter diese RoHS Anweisung fallen, finden Sie unter www.thermo.com/WEEERoHS.

Conformité DEEE

Ce produit doit être conforme à la directive européenne (2002/96/EC) des Déchets d'Equipements

Electriques et Electroniques (DEEE). Il est marqué par le symbole suivant:

Thermo Fisher Scientific s'est associé avec une ou plusieurs compagnies de recyclage dans chaque état membre de l’union européenne et ce produit devrait être collecté ou recyclé par celles-ci. Davantage d'informations sur la conformité de Thermo Fisher Scientific à ces directives, les recycleurs dans votre pays et les informations sur les produits Thermo Fisher Scientific qui peuvent aider la détection des substances sujettes à la directive RoHS sont disponibles sur www.thermo.com/WEEERoHS.

Read This First

About This Guide

Who Uses This Guide

This Orbitrap Elite Hardware Manual contains a description of the modes of operation and principle hardware components of your

Orbitrap Elite instrument. In addition, this manual provides step-by-step instructions for cleaning and maintaining your instrument.

This Orbitrap Elite Hardware Manual is intended for all personnel that need a thorough understanding of the instrument (to perform maintenance or troubleshooting, for example). This manual should be kept near the instrument to be available for quick reference.

Scope of This Guide

Welcome to the Thermo Scientific Orbitrap Elite system! The Orbitrap

Elite is a member of the family of LTQ™ mass spectrometer (MS) hybrid instruments.

All information in this guide concerning the Orbitrap Elite mass spectrometer also applies to the Orbitrap Elite ETD system where the

ETD Module is physically coupled to the back of the Orbitrap Elite mass spectrometer.

Thermo Fisher Scientific

This manual includes the following chapters:

Chapter 1: “Functional Description” describes the principal

components of the Orbitrap Elite mass spectrometer.

Chapter 2: “Basic System Operations”

provides procedures for shutting down and starting up the Orbitrap Elite mass spectrometer.

Chapter 3: “User Maintenance” outlines the maintenance

procedures that you should perform on a regular basis to maintain optimum instrument performance.

Chapter 4: “Replaceable Parts”

lists the replaceable parts for mass spectrometer and data system.

Appendix A: “Fluoranthene” describes properties of the reagent that

is used in the ETD Module portion of the Orbitrap Elite ETD mass spectrometer.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

i

Read This First

Related Documentation

Related Documentation

In addition to this guide, Thermo Fisher Scientific provides the following documents for Orbitrap Elite mass spectrometer and Orbitrap

Elite ETD mass spectrometer:

LTQ Orbitrap Series Preinstallation Requirements Guide

Orbitrap Elite Getting Started Guide

Velos Pro manual set

You can access PDF files of the documents listed above and of this guide from the data system computer. The software also provides Help.

To view product manuals

1. From the Microsoft™ Windows™ taskbar, choose Start > Programs

> Thermo Instruments > LTQ > Manuals > model.

2. Click the PDF file that you want to view.

ii

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Read This First

Contacting Us

Contacting Us

There are several ways to contact Thermo Fisher Scientific.

Assistance

Customer Information Service

cis.thermo-bremen.com

is the Customer Information Service site aimed at providing instant access to

Latest software updates

Manuals, application reports, and brochures

Thermo Fisher Scientific recommends that you register with the site as early as possible.

To register, visit register.thermo-bremen.com/form/cis and fill in the registration form. Once your registration has been finalized, you will receive confirmation by e-mail.

Changes to the Manual

For technical support and ordering information, visit us on the Web: www.thermoscientific.com/ms

Service contact details for customers in Europe are available under: www.thermoscientific.com/euservicecontact

To suggest changes to this manual

Please send your comments (in German or English) to:

Editors, Technical Documentation

Thermo Fisher Scientific (Bremen) GmbH

Hanna-Kunath-Str. 11

28199 Bremen

Germany

Send an e-mail message to the Technical Editor at [email protected]

You are encouraged to report errors or omissions in the text or index.

Thank you.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

iii

Read This First

Typographical Conventions

Typographical Conventions

This section describes typographical conventions that have been established for Thermo Fisher Scientific manuals.

Data Input

Throughout this manual, the following conventions indicate data input and output via the computer:

Messages displayed on the screen are represented by capitalizing the initial letter of each word and by italicizing each word.

Input that you enter by keyboard is identified by quotation marks: single quotes for single characters, double quotes for strings.

For brevity, expressions such as “choose File > Directories” are used rather than “pull down the File menu and choose Directories.”

Any command enclosed in angle brackets < > represents a single keystroke. For example, “press <F1>” means press the key labeled

F1.

Any command that requires pressing two or more keys simultaneously is shown with a plus sign connecting the keys. For example, “press <Shift> + <F1>” means press and hold the <Shift> key and then press the <F1> key.

Any button that you click on the screen is represented in bold face letters. For example, “click Close”.

Topic Headings

The following headings are used to show the organization of topics within a chapter:

Chapter 1

Chapter Name

Second Level Topics

Third Level Topics

Fourth Level Topics iv

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Read This First

Safety and EMC Information

Safety and EMC Information

In accordance with our commitment to customer service and safety, this instrument has satisfied the requirements for the European CE Mark including the Low Voltage Directive.

Designed, manufactured and tested in an ISO9001 registered facility, this instrument has been shipped to you from our manufacturing facility in a safe condition.

This instrument must be used as described in this manual. Any use of this instrument in a manner other than described here may result in instrument damage and/or operator injury.

Notice on Lifting and Handling of Thermo Scientific Instruments

For your safety, and in compliance with international regulations, the physical handling of this Thermo Scientific instrument requires a team

effort for lifting and/or moving the instrument. This instrument is too heavy and/or bulky for one person alone to handle safely.

Notice on the Proper Use of Thermo Scientific Instruments

In compliance with international regulations: If this instrument is used in a manner not specified by Thermo Fisher Scientific, the protection provided by the instrument could be impaired.

Notice on the Susceptibility to Electromagnetic Transmissions

Your instrument is designed to work in a controlled electromagnetic environment. Do not use radio frequency transmitters, such as mobile phones, in close proximity to the instrument.

Safety and Special Notices

Make sure you follow the precautionary statements presented in this guide. The safety and other special notices appear different from the main flow of text. Safety and special notices include the following:

Warning

Warnings highlight hazards to human beings. Each Warning is accompanied by a Warning symbol.

Thermo Fisher Scientific

Caution

Cautions highlight information necessary to protect your instrument from damage.

Note Notes highlight information that can affect the quality of your data. In addition, notes often contain information that you might need if you are having trouble.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

v

Read This First

Safety and EMC Information

Identifying Safety Information

This guide contains precautionary statements that can prevent personal injury, instrument damage, and loss of data if properly followed.

Warning symbols alert the user to check for hazardous conditions. These appear throughout the manual, where applicable. The most common warning symbols that appear in Thermo Fisher Scientific manuals are shown below.

In addition, every instrument has specific hazards. So, be sure to read and comply with all precautions described in this guide. They will help to ensure the safe and long-term use of your system.

Warning

General Hazard. This general symbol indicates that a hazard is present that could result in injuries if it is not avoided.

The source of danger is described in the accompanying text.

Warning

Electric Shock Hazard. High voltages capable of causing personal injury are used in the instrument. The instrument must be shut down and disconnected from line power before service is performed. Do not operate the instrument with the top cover off. Do not remove protective covers from PCBs.

Warning

Burn Hazard. Treat heated zones with respect. Parts of the instrument might be very hot and might cause severe burns if touched.

Allow hot components to cool before servicing them.

Warning

Corrosive Material. Wear gloves when handling toxic, carcinogenic, mutagenic, or corrosive/irritant chemicals. Use approved containers and procedures for disposal of waste solution.

General Safety Precautions

Observe the following safety precautions when you operate or perform service on your instrument:

The system should be operated by trained personnel only. Read the manuals before starting the system and make sure that you are familiar to the warnings and safety precautions!

Accurate results can be obtained only, if the system is in good condition and properly calibrated.

vi

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

Read This First

Safety and EMC Information

Service by the customer should be performed by trained qualified personnel only and should be restricted to servicing mechanical parts! Service on electronic parts should be performed by Thermo

Fisher Scientific field service engineers only!

Before plugging in any of the instrument modules or turning on the power, always make sure that the voltage and fuses are set appropriately for your local line voltage.

Only use fuses of the type and current rating specified. Do not use repaired fuses and do not short-circuit the fuse holder.

The supplied power cord must be inserted into a power outlet with a protective earth contact (ground). When using an extension cord, make sure that the cord also has an earth contact.

Do not change the external or internal grounding connections.

Tampering with or disconnecting these connections could endanger you and/or damage the system.

The instrument is properly grounded in accordance with regulations when shipped. You do not need to make any changes to the electrical connections or to the instrument’s chassis to ensure safe operation.

Never run the system without the housing on. Permanent damage can occur. When leaving the system, make sure that all protective covers and doors are properly connected and closed, and that heated areas are separated and marked to protect for unqualified personnel!

Do not turn the instrument on if you suspect that it has incurred any kind of electrical damage. Instead, disconnect the power cord and contact a Thermo Fisher Scientific field service engineer for a product evaluation. Do not attempt to use the instrument until it has been evaluated. (Electrical damage may have occurred if the system shows visible signs of damage, or has been transported under severe stress.)

Damage can also result if the instrument is stored for prolonged periods under unfavorable conditions (for example, subjected to heat, water, etc.).

Always disconnect the power cord before attempting any type of maintenance.

Capacitors inside the instrument may still be charged even if the instrument is turned off.

Never try to repair or replace any component of the system that is not described in this manual without the assistance of your Thermo

Fisher Scientific field service engineer.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

vii

Read This First

Safety and EMC Information

Do not place any objects upon the instrument—especially not containers with liquids—unless it is requested by the user documentation. Leaking liquids might get into contact with electronic components and cause a short circuit.

Safety Advice for Possible Contamination

Hazardous Material Might Contaminate Certain Parts of Your

System During Analysis.

In order to protect our employees, we ask you to adhere to special precautions when returning parts for exchange or repair.

If hazardous materials have contaminated mass spectrometer parts,

Thermo Fisher Scientific can only accept these parts for repair if they have been properly decontaminated. Materials that due to their structure and the applied concentration might be toxic or that are reported in publications to be toxic are regarded as hazardous. Materials that will generate synergetic hazardous effects in combination with other present materials are also considered hazardous.

Your signature on the Health and Safety Form confirms that the returned parts have been decontaminated and are free of hazardous materials. Download the form from decon.thermo-bremen.com

or order it from the Thermo Fisher Scientific field service engineer.

Parts contaminated by radioisotopes should not be returned to Thermo

Fisher Scientific—neither under warranty nor within the exchange part program. If unsure about parts of the system possibly being contaminated by hazardous material, please make sure the Thermo

Fisher Scientific field service engineer is informed before the engineer starts working on the system.

viii

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Contents

Thermo Fisher Scientific

Chapter 1 Functional Description.............................................................1-1

General Description .......................................................... 1-2

Mechanical Characteristics ............................................. 1-3

Specifications ................................................................. 1-4

Control Elements.............................................................. 1-5

System Status LEDs ....................................................... 1-5

Control Panels ............................................................... 1-6

Linear Ion Trap............................................................... 1-12

Curved Linear Trap ........................................................ 1-13

Orbitrap Analyzer ........................................................... 1-14

Extraction of Ion Packets ............................................. 1-14

Measuring Principle ..................................................... 1-15

Ion Detection............................................................... 1-16

Active Temperature Control ........................................ 1-17

HCD Cell ....................................................................... 1-18

HCD and ETD ........................................................... 1-18

ETD System ................................................................... 1-19

Principle of Operation ................................................. 1-21

ETD Module ............................................................... 1-21

Vacuum System .............................................................. 1-30

Turbomolecular Pumps................................................ 1-31

Forepumps of the Linear Trap ..................................... 1-33

Forepump of the ETD Module.................................... 1-34

Vacuum System Controls............................................. 1-35

Vacuum System Heating during a System Bakeout ...... 1-36

Gas Supply...................................................................... 1-37

Gas Supply for the Mass Analyzers ............................... 1-37

Gas Supply of the Reagent Ion Source ......................... 1-40

Cooling Water Circuit .................................................... 1-42

Recirculating Chiller .................................................... 1-43

Properties of Cooling Water......................................... 1-43

Printed Circuit Boards .................................................... 1-44

Linear Ion Trap Electronics.......................................... 1-45

Electronic Boards on the Right Side of the

Instrument ................................................................... 1-46

Electronic Boards on the Left Side of the Instrument ... 1-59

Chapter 2 Basic System Operations ........................................................2-1

Shutting Down the System in an Emergency .................... 2-2

Behavior of the System in Case of a Main Failure........... 2-2

Placing the Instrument in Standby Condition................... 2-4

Placing the ETD Module in Standby Condition ............ 2-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

ix

Contents

Placing the MS in Standby Condition............................ 2-6

Shutting Down the Orbitrap Elite Mass Spectrometer

Completely ....................................................................... 2-7

Shutting Down the Instrument ...................................... 2-7

Starting Up the System after a Shutdown.......................... 2-9

Starting Up the Instrument ............................................ 2-9

Setting Up Conditions for Operation........................... 2-10

Starting the ETD Module After a Complete

Shutdown .................................................................... 2-11

Resetting the System ....................................................... 2-12

Resetting Tune and Calibration Parameters to their

Default Values ................................................................ 2-13

Turning Off the Reagent Ion Source: What to Expect .... 2-14

Chapter 3 User Maintenance.................................................................... 3-1

General Remarks............................................................... 3-2

Returning Parts .............................................................. 3-3

Cleaning the Surface of the Instrument .......................... 3-3

Maintenance of the Vacuum System ................................. 3-4

Baking Out the System .................................................. 3-4

Maintenance of the Forepumps...................................... 3-5

Maintenance of the Turbomolecular Pumps ................ 3-11

Maintenance of the ETD Module ................................... 3-12

Handling and Cleaning Reagent Ion Source Parts........ 3-13

Removing the Access Panels ......................................... 3-18

Maintenance of the Reagent Ion Source ....................... 3-20

Replacing Inlet Valve Components .............................. 3-45

Replacing the Reagent Vials ......................................... 3-48

Cleaning the Fan Filters of the ETD Module............... 3-57

Maintenance of the Cooling Circuit................................ 3-58

Maintenance for the Recirculating Chiller.................... 3-58

Replacing the Water Filter Cartridge............................ 3-58

Chapter 4 Replaceable Parts .................................................................... 4-1

Ion Sources ....................................................................... 4-2

Parts for the Basic System.................................................. 4-3

Parts Lists for the ETD System ......................................... 4-5

ETD Reagent Kit ........................................................... 4-7

Appendix A Fluoranthene ............................................................................ A-1

Glossary ................................................................................... G-1

Index ........................................................................................... I-1

x

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Figures

Thermo Fisher Scientific

Orbitrap Elite MS front view ................................................................ 1-2

Schematic of the Orbitrap Elite MS ...................................................... 1-3

Top lid of MS portion opened .............................................................. 1-4

System status LEDs ............................................................................... 1-5

Right side of the Orbitrap Elite MS ...................................................... 1-6

Upper control panel .............................................................................. 1-7

Power control panel with power control LEDs and switches ................. 1-8

Main power switch ................................................................................ 1-9

External connections to the Orbitrap Elite MS ................................... 1-10

Layout of the Orbitrap Elite MS, also showing the applied voltages ............................................................................................... 1-13

Schematic of Orbitrap cell and example of stable ion trajectory ........... 1-14

Principle of electrodynamic squeezing of ions in the Orbitrap analyzer as the field strength is increased ............................................. 1-15

Approximate shape of ion packets of different m/z after

stabilization of voltages ........................................................................ 1-16

Orbitrap Elite ETD MS front view ..................................................... 1-19

Schematic of the Orbitrap Elite ETD MS ........................................... 1-20

Orbitrap Elite ETD MS, rear side ....................................................... 1-22

Rear view of the ETD Module, with major component locations ........ 1-22

ETD Module functional block diagram .............................................. 1-23

Right side of the Orbitrap Elite ETD MS ........................................... 1-24

ETD Power Module panel .................................................................. 1-24

Reagent Ion Source dialog box ............................................................ 1-27

Reagent ion source schematics ............................................................. 1-29

Schematic of Orbitrap analyzer vacuum system (CLT compartment and Orbitrap chamber not shown) ...................................................... 1-30

Vacuum components on the left instrument side ................................ 1-31

Vacuum components on the right instrument side .............................. 1-32

Forepumps cabinet .............................................................................. 1-33

Forepump for ETD Module ............................................................... 1-34

Schematic of gas supply for Orbitrap Elite ETD MS ........................... 1-37

Proper orientation of the Swagelok-type nut and two-piece ferrule ...... 1-38

Gas regulators ..................................................................................... 1-39

ETD reagent carrier gas port at the ETD Module ............................... 1-40

Schematic of cooling water circuit ....................................................... 1-42

Electronic connections to linear trap ................................................... 1-45

Electronic boards on the right side of the Orbitrap Elite MS ............... 1-46

ETD Ion Optic Supply board ............................................................. 1-47

Preamplifier ........................................................................................ 1-48

Data Acquisition unit .......................................................................... 1-49

Data Acquisition Digital PCI board .................................................... 1-50

Data Acquisition Analog board ........................................................... 1-51

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

xi

Figures

Instrument Control board ................................................................... 1-52

Power Distribution board ................................................................... 1-54

Power Supply 1 board ......................................................................... 1-57

Electronic boards on the left side of the instrument ............................. 1-59

Ion Optic Supply board ...................................................................... 1-60

Central Electrode Pulser board ............................................................ 1-61

Temperature Controller board ............................................................ 1-62

CLT RF unit (cover removed) ............................................................. 1-64

Central Electrode Power Supply board ................................................ 1-65

High Voltage Power Supply board (cover removed) ............................ 1-67

High Voltage Power Supply board with SPI Bus Termination board ................................................................................................... 1-68

Main power switch in Off position ....................................................... 2-2

Tune Plus window (Orbitrap Elite ETD), toolbar ................................. 2-4

Reagent Ion Source dialog box with Reagent Ion Source On box and Actual condition circled .................................................................. 2-5

Placing the reagent ion source in Standby condition ........................... 2-14

Bakeout timer ....................................................................................... 3-4

Schematic of ETD forepump ................................................................ 3-6

Accessing the ETD Forepump: Removing the panel ............................. 3-7

Hooks (left) and top side of detached bottom panel (right) ................... 3-7

Lugs for fixing the bottom panel ........................................................... 3-8

Gas ballast control positions .................................................................. 3-9

Routine maintenance sequence for ETD system .................................. 3-12

Rear view of the ETD Module ............................................................ 3-18

Ion source components (left view) ....................................................... 3-21

Tune Plus window (Orbitrap Elite ETD) ............................................ 3-22

Ion volume tool components ............................................................... 3-23

Guide bar being inserted into guide bar opening ................................. 3-23

Guide bar insertion complete .............................................................. 3-24

Rear view of the ETD Module, showing the inlet valve ....................... 3-24

Ion volume tool handle in the unlock position .................................... 3-25

Ion volume tool guide bar first stop ..................................................... 3-25

Reagent Ion Source dialog box, Open Probe Interlock button. ............ 3-26

Instrument Message box: The Ball Valve can now be opened .............. 3-26

Ion volume tool inserted into the inlet valve ........................................ 3-27

Detail of ion volume tool fully inserted into the inlet valve ................. 3-27

Ion volume tool handle in the locked position .................................... 3-28

Ion volume assembly ........................................................................... 3-29

Separating ion volume and ion volume holder .................................... 3-29

Placing the ion volume on the ion volume tool ................................... 3-30

Ion volume tool handle in the unlock position .................................... 3-31

Ion volume tool handle in the locked position .................................... 3-32

Inlet valve components (ion volume tool not shown) .......................... 3-34

Valve shield (1) covering the vacuum manifold probe plate ................. 3-35

Removing the foreline hose from its connection .................................. 3-35

Unscrewing the vacuum manifold probe plate ..................................... 3-36

Removing the vacuum manifold probe plate ....................................... 3-36

Interior of vacuum manifold ............................................................... 3-37

xii

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Figures

Removing the ion source assembly from the vacuum manifold ........... 3-38

Ion source assembly ............................................................................. 3-39

Ion source assembly exploded view ...................................................... 3-39

Ion source, exploded view ................................................................... 3-41

Ion source lens assembly and ion source .............................................. 3-43

Filament wire as seen from the bottom of the filament through the electron lens hole ........................................................................... 3-44

Inlet valve components ........................................................................ 3-45

Inlet valve seal tool .............................................................................. 3-46

Inlet valve seal tool inserted in the inlet valve ...................................... 3-46

Inlet valve seal on the inlet valve seal tool ............................................ 3-47

Inlet valve seal disengaged from tool .................................................... 3-47

Reagent Ion Source dialog box ............................................................ 3-50

ETD Module with back panel removed .............................................. 3-52

Reagent vials with holders ................................................................... 3-53

ETD Module with vial heater cover removed ...................................... 3-53

Reagent inlet assembly ........................................................................ 3-56

ETD Module, top panel ...................................................................... 3-57

Installed water filter ............................................................................. 3-59

Removing the filter cartridge ............................................................... 3-60

Filter cartridge with Quick couplers .................................................... 3-60

ETD Reagent (fluoranthene radical anion) generation from fluoranthene ..........................................................................................A-1

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

xiii

Tables

System status LEDs of the Orbitrap Elite MS ....................................... 1-5

Circuit breakers of the Orbitrap Elite MS ............................................. 1-7

Typical pressure readings in the ETD Module .................................... 1-35

Diagnostic LEDs on the ETD Ion Optic Supply board ....................... 1-47

Diagnostic LEDs on the Preamplifier board ........................................ 1-49

Diagnostic LEDs of the Data Acquisition Digital PCI board .............. 1-50

Diagnostic LEDs of the Data Acquisition Analog board ...................... 1-51

Diagnostic LEDs of the Power Supply 2 board ................................... 1-52

Diagnostic LEDs of the Instrument Control board ............................. 1-53

Software status LEDs of the Instrument Control board ....................... 1-53

Status LEDs of the Power Distribution board ..................................... 1-55

Working modes of the Power Distribution board ................................ 1-56

Operating states of the Power Distribution board ............................... 1-56

Diagnostic LEDs of the Power Supply 1 board ................................... 1-58

Diagnostic LEDs of the Ion Optic Supply board ................................. 1-60

Diagnostic LEDs of the Central Electrode Pulser board ...................... 1-62

Diagnostic LEDs of the Temperature Controller board ....................... 1-63

Diagnostic LEDs of the CLT RF Main board ..................................... 1-64

Diagnostic LEDs of the Central Electrode Power Supply board .......... 1-66

Diagnostic LEDs of the High Voltage Power Supply board ................ 1-68

User maintenance procedures ................................................................ 3-2

Indications requiring maintenance of the ETD system ........................ 3-13

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

xv

Procedures

To view product manuals...........................................................................ii

To suggest changes to this manual.............................................................iii

To connect the nitrogen source to the Orbitrap Elite mass spectrometer......................................................................................... 1-38

To connect the helium source to the Orbitrap Elite mass spectrometer......................................................................................... 1-38

To place the ETD Module in Standby condition ................................... 2-4

To place the Orbitrap Elite system in Standby condition ....................... 2-6

To shut down the instrument completely............................................... 2-7

To shut down the Orbitrap Elite system ................................................ 2-7

To start up the Orbitrap Elite mass spectrometer ................................... 2-9

To set up your Orbitrap Elite mass spectrometer for operation ............ 2-10

To start up the ETD Module after a complete shutdown ..................... 2-11

To reset the Orbitrap Elite MS tune and calibration parameters........... 2-13

To perform a system bakeout ................................................................. 3-4

To remove the panel .............................................................................. 3-8

To add oil to the ETD forepump........................................................... 3-8

To purge the rotary-vane pump oil......................................................... 3-9

To change the ETD forepump oil ........................................................ 3-10

To clean reagent ion source stainless steel parts .................................... 3-15

To clean the non-stainless-steel portions of hybrid parts....................... 3-17

To remove the ETD main access panel ................................................ 3-18

To remove the ETD side access panel .................................................. 3-19

To clean the ion volume with an inlet valve ......................................... 3-22

To reinsert the ion volume ................................................................... 3-29

To clean the ion source lens assembly................................................... 3-33

To clean the ion source block............................................................... 3-40

To replace the ion source filament........................................................ 3-43

To replace inlet valve components........................................................ 3-45

To place the Orbitrap Elite ETD mass spectrometer in Off

Condition and Service mode and to verify that the vials are safe to handle .............................................................................................. 3-49

To install or exchange the reagent vials................................................. 3-51

To change the reagent ion source flow restrictors ................................. 3-54

To clean the fan filters of the ETD Module ......................................... 3-57

To replace the water filter cartridge ...................................................... 3-59

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

xvii

Chapter 1

Functional Description

This chapter provides an overview of the functional elements of the

Orbitrap Elite mass spectrometer. It contains the following topics:

“General Description” on page 1-2

“Control Elements” on page 1-5

“Linear Ion Trap” on page 1-12

“Curved Linear Trap” on page 1-13

“Orbitrap Analyzer” on page 1-14

“ETD System” on page 1-19

“Vacuum System” on page 1-30

“Gas Supply” on page 1-37

“Cooling Water Circuit” on page 1-42

“Printed Circuit Boards” on page 1-44

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-1

Functional Description

General Description

General Description

The Orbitrap Elite mass spectrometer is a hybrid mass spectrometer incorporating the Velos Pro™ dual cell linear trap and the high-field

Orbitrap™ analyzer.

Figure 1-1

shows a front view of the instrument.

System status LEDs of linear trap System status LEDs of Orbitrap Elite MS

Orbitrap Analyzer

Linear Trap

Forepumps cabinet

Figure 1-1. Orbitrap Elite MS front view

The Orbitrap Elite mass spectrometer consists of four main components

(See Figure 1-2 on page 1-3

.), which are described in the following topics:

Dual cell linear ion trap (Thermo Scientific Velos Pro) for sample ionization, precursor ion selection, fragmentation, and AGC™.

Intermediate storage device (curved linear trap) that is required for short pulse injection.

High-field Orbitrap analyzer for Fourier transformation based analysis.

Collision cell for performing higher energy CID experiments.

The Orbitrap Elite ETD mass spectrometer has an additional reagent ion source for performing Electron Transfer Dissociation (ETD)

experiments. See “ETD System” on page 1-19

.

1-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Electrospray Ion Source S-Lens

Velos Pro MS

Square Quadrupole with neutral blocking

Octopole High Pressure Cell Low Pressure Cell

Functional Description

General Description

Multipole

Orbitrap analyzer

C-Trap HCD Cell

High-field Orbitrap Mass Analyzer

Figure 1-2. Schematic of the Orbitrap Elite MS

Mechanical Characteristics

Wheels at the bottom side of the instrument facilitate positioning the

Orbitrap Elite mass spectrometer at the intended place in the laboratory.

The mains inlet as well as a power outlet for peripheral devices are located at the right side of the instrument. The forepumps for the vacuum system of the linear trap and the Orbitrap analyzer are hidden under the linear trap and accessible from the front. The forepump for the ETD Module is accessible after removing the bottom panel of the rear side. The left side panel and the front panel of the MS portion are mounted on hinges and the right side panel is removable. The top lid of the MS portion opens upwards to allow easy access for Thermo Fisher

Scientific field service engineers from the top. See Figure 1-3

.

In the Orbitrap Elite ETD mass spectrometer, after removing the cables the top lid of the ETD Module is also removable to allow accessing its electronic components.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-3

Functional Description

General Description

Specifications

Figure 1-3. Top lid of MS portion opened

A stand-alone recirculating water chiller is shipped with the instrument.

It is connected to the right side of the instrument.

The Orbitrap Elite mass spectrometer has the following measuring specifications:

Resolution

60000 (FWHM) at m/z 400 at a scan rate of 4 Hz, minimum resolution 15000 (FWHM) maximum resolution > 240000 (FWHM) at m/z 400

Cycle Time

> 4 scans at 60000 (FWHM) resolution @ m/z 400 per second

m/z 50–2000; m/z 200–4000

Mass Range

Mass Accuracy

<3 ppm RMS for 2 h period with external calibration using defined conditions,

<1 ppm RMS with internal calibration

Dynamic Range >10000 between mass spectra,

>5000 between highest and lowest detectable ion signal in one spectrum

MS/MS

MS/MS and MS n

scan functions

1-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Control Elements

System Status LEDs

Functional Description

Control Elements

The Orbitrap Elite mass spectrometer is mainly operated from the desktop computer (data system). Some control elements for important system functions are located directly on the instrument. They are described in the following sections.

Figure 1-4 shows the system status LEDs at the front of the instrument.

Five LEDs indicate the main functions of the system. (See also

Figure 1-5 on page 1-6 .) The Power LED is directly controlled by the

3 × 230 V input and all other LEDs are controlled by the power distribution board (See

“Power Distribution Board” on page 1-53 ).

Table 1-1

explains the function of the various LEDs.

Thermo Fisher Scientific

Figure 1-4. System status LEDs

The system status LEDs at the front panel of the linear ion trap are described in the LTQ Series Hardware Manual.

Table 1-1. System status LEDs of the Orbitrap Elite MS

LED

Power

Status

Green

Off

Vacuum a

Green

Yellow

Communication Green

Information

Main switch on

Main switch off

Operating vacuum reached

Insufficient vacuum or Vacuum Pumps switch off

Yellow

Communication link between instrument and data system established

Communication link starting up or Vacuum Pumps switch off

System a

Green

Yellow

System ready

FT Electronics switch off or Vacuum Pumps switch off

Detect Blue

Off

Orbitrap analyzer is scanning

Orbitrap analyzer is not scanning a

These LEDs are flashing when a system bakeout is performed. See “Baking Out the System” on page 3-4

.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-5

Functional Description

Control Elements

Control Panels

Power panel of linear trap

Figure 1-5

shows the right side of the Orbitrap Elite mass spectrometer.

Located here are the control panels, switches, and the ports for the external connections (mains supply, gases, Ethernet communication, and cooling water).

Bakeout timer

Forepumps cabinet

Cover lid for bakeout controls

Switches and control LEDs

Main power switch

Power connector

Figure 1-5. Right side of the Orbitrap Elite MS

For more information about the external connections, see “External

Connections” on page 1-9

.

Upper Control Panel

The upper instrument control panel comprises the bakeout timer, the bakeout control buttons, and three circuit breakers. To access the upper control panel, swing open the small lid (opens from left to right). See

Figure 1-5

and

Figure 1-6 on page 1-7 .

The timer allows setting the duration for the bakeout of the system.

After the duration is set, the bakeout procedure is started by pressing the green button on the right. A running bakeout procedure can be stopped by pressing the orange button on the left side. For instructions about performing a bakeout, see

“Baking Out the System” on page 3-4

.

1-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Control Elements

Bakeout timer

Bakeout control buttons

Circuit breakers

Cover lid

Power Control Panel

Thermo Fisher Scientific

Figure 1-6. Upper control panel

Note The buttons themselves have no indicator function. A running bakeout procedure is indicated by flashing Vacuum and System LEDs at the front side of the instrument. See

Figure 1-4 on page 1-5 .

Three circuit breakers are located at the bottom of this control panel.

Table 1-2

shows the parts of the Orbitrap Elite mass spectrometer that are protected by the respective circuit breaker. The proper function of each circuit breaker is signaled by a dedicated LED in the power control panel (for example, F1 corresponds to L1).

Table 1-2. Circuit breakers of the Orbitrap Elite MS

F2

F3

Circuit breaker Ampere LED Instrument parts

F1 10 L1 Power Distribution

15

15

L2

L3

Linear ion trap

Multiple socket outlets (Peripherals, LC, heater, etc.)

In addition to the system status LEDs at the front side (see Figure 1-4 on page 1-5 ), the Orbitrap Elite mass spectrometer has three power

control LEDs above the Vacuum Pumps switch at the right side. See

Figure 1-7 . They indicate whether the corresponding circuit breaker is

closed and the respective parts of the instrument have power. (See

Table 1-2 on page 1-7

.)

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-7

Functional Description

Control Elements

Power control LEDs

Vacuum Pumps switch

FT Electronics switch

Figure 1-7. Power control panel with power control LEDs and switches

The use of the switches below the power control LEDs changes the working mode of the power distribution. (See “Working Modes of the

Power Distribution” on page 1-48 .)

The Vacuum Pumps switch can be set into the positions ON or OFF.

When the switch is in the OFF position, everything but the multiple socket outlet is switched off.

The FT Electronics switch can be set into the operating position (ON) or into the service position (OFF). When the switch is in the service position, all components are switched off with exception of the following:

Fans

Heater control

Power distribution (See

“Power Distribution Board” on page 1-53 )

Pumps (See “Vacuum System” on page 1-30 )

Temperature controller (See

“Temperature Controller Board” on page 1-62 )

Vacuum control

The linear ion trap also remains on because it has a separate Service switch.

1-8

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Main Power Switch

Functional Description

Control Elements

The main power switch must be turned 90° clockwise/anti-clockwise to

switch on/off the instrument (see Figure 1-8

). Placing the main power switch in the Off position turns off all power to the Orbitrap Elite mass spectrometer, the linear ion trap, and the vacuum pumps. In the

Orbitrap Elite ETD mass spectrometer, power to the ETD Module is also turned off.

On

External Connections

Thermo Fisher Scientific

Off

Figure 1-8. Main power switch

Note When the main power switch is in the Off position, you can secure it with a padlock or a cable tie (to prevent unintended re-powering when performing maintenance, for example).

Figure 1-9 on page 1-10 shows the lower right side of the instrument

with the external connections for mains supply, gases, cooling water, and

Ethernet communication.

Located at the top are two ports for Ethernet cables for connecting the

Orbitrap Elite mass spectrometer and the linear ion trap via an Ethernet hub with the data system computer.

The power outlet for peripheral devices is located below the Ethernet ports. In the Orbitrap Elite mass spectrometer, the outlet provides the mains supply for the data system. In the Orbitrap Elite ETD mass spectrometer, the outlet provides the mains supply for the ETD Module whereas the data system is connected to a wall outlet.

The power connector for the mains supply is located at the center. The

Orbitrap Elite mass spectrometer is designed to operate at a nominal voltage of 230 V AC, 50/60 Hz. Line voltages can vary between a minimum of 207 V AC and a maximum of 253 V AC.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-9

Functional Description

Control Elements

1

Caution

Systems installed in areas with 208 V power experience voltage sags during high use periods that might place the line voltage below the operating parameters discussed in this section. In this case, you must protect your instrument by using a buck/boost transformer to ensure that power is within the specified parameters at all times.

Ethernet ports

Power outlet for peripheral devices

Power connector

Helium gas inlet

Collision gas inlet

1

Nitrogen gas inlet

Cooling water inlet port

Cooling water outlet port

Figure 1-9. External connections to the Orbitrap Elite MS

The cooling water ports are located below the power connector. (See also

“Cooling Water Circuit” on page 1-42 .)

The port for nitrogen gas allows connecting a Teflon® hose from the gas supply of the laboratory to the instrument. The required gas pressure for nitrogen is 690 ± 140 kPa (6.9 ± 1.4 bar, 100 ± 20 psi). Helium

(40 ±10 psi [275 ±70 kPa], 99.999% [ultra-high] purity) enters the instrument through a 1/8 inch port. Metal tubing from the helium gas supply must be terminated with 1/8 inch, female, Swagelok-type

connectors. See “Gas Supply” on page 1-37

for information about connecting the gas supplies to the instrument.

Caution

Do not connect other gases than nitrogen or helium to the

Orbitrap Elite mass spectrometer! The maximum pressure for the nitrogen gas inlet is 830 kPa (8.3 bar, 120 psi); the maximum pressure for the helium inlet is 345 kPa (3.45 bar, 50 psi).

1

The port named Collision Gas is not used in the Orbitrap Elite MS.

1-10

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Control Elements

In the Orbitrap Elite ETD mass spectrometer, the ETD reagent carrier gas supply of the laboratory is connected via metal tubing to an1/8 inch inlet port at the rear side of the instrument. Metal tubing from the gas supply must be terminated with 1/8 inch, female, Swagelok-type connectors. The required gas pressure is 690 ± 140 kPa (6.9 ± 1.4 bar,

100 ± 20 psi). See

“Gas Supply of the Reagent Ion Source” on page 1-40

.

The exhaust hose from the rotary pumps comes out the back of the instrument, and connects the pumps to the exhaust system in the laboratory.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-11

Functional Description

Linear Ion Trap

Linear Ion Trap

The Orbitrap Elite system can utilize a variety of ionization techniques such as ESI, APCI, or APPI. Maintenance of the Ion Max API source, as well as switching between ionization methods, is vent-free. Ions are transferred by octapole and “square” quadrupole lenses into an ion trap that is optimized for axial ion ejection into the curved linear trap. (See

Figure 1-2 on page 1-3

.)

The linear ion trap is an independent MS detector (Thermo Scientific

Velos Pro), which can store, isolate, and fragment ions and then send them either to the Orbitrap analyzer for further analysis or to an

SEM detector. The linear ion trap is a unique ion preparation and injection system for Orbitrap MS, because it has greater ion storage capacity than conventional 3D ion trap devices. The linear ion trap is completely described in the LTQ Series Hardware Manual.

All the ion handling, selection and excitation capabilities of the ion trap can be used to prepare ions for analysis in the Orbitrap analyzer. These features include storage and ejection of all ions, storage of selected

m/z ranges, as well as ion isolation. Isolated ions can be excited and then fragmented as necessary for MS/MS and MS n

experiments. The patented Automatic Gain Control (AGC) provides extended dynamic range and insures optimized overall performance of the ion trap and

Orbitrap MS.

The application of a supplementary RF voltage on the end lenses of the linear trap allows ions of opposite polarity to be trapped in the same space at the same time (charge-sign independent trapping—CSIT). This allows performing ion-ion reactions of previously isolated precursor cations with ETD reagent anions.

The linear ion trap and the transfer chamber are mounted on a table.

See Figure 1-1 on page 1-2

. The table also serves as a housing for the forepumps. See

Figure 1-26 on page 1-33 . The Orbitrap Elite mass

spectrometer provides power for the linear ion trap. The Orbitrap

Elite ETD mass spectrometer also provides the power for the

ETD Module.

The linear ion trap is delivered with power connector, gas lines (He,

N

2

), and vacuum tube lines extending to the ESI source. On the rear side of the Velos Pro ion trap is a flange with an O-ring seal. When the flange is removed, the Orbitrap transfer chamber is mounted to the flange of the linear ion trap. The transfer chamber is held with supports on the table. The components of the ion optics and the Orbitrap analyzer are fixed to the transfer chamber.

1-12

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Curved Linear Trap

Functional Description

Curved Linear Trap

On their way from the linear trap to the Orbitrap analyzer, ions move through the gas-free RF-only octapole into the gas-filled curved linear trap (C-Trap). See

Figure 1-10 . Ions entering the C-Trap loose their

kinetic energy in collisions with nitrogen bath gas emanating from the

HCD cell and get collected near the middle part of the C-Trap. The nitrogen collision gas (bath gas) is used for dissipating the kinetic energy of injected ions to cool them down to the axis of the C-Trap.

Voltages on the end apertures of the curved trap (entrance and exit apertures) are elevated to provide a potential well along its axis. These voltages may be later ramped up to squeeze ions into a smaller package along this axis. The RF to the C-Trap (“Main RF”) is provided by the

CLT RF main board. (See page 1-63 .) Entrance and exit DC voltages as

well as RF voltages to the transfer multipole are all provided by the ion

optic supply board. (See page 1-59 .) High voltages to the lenses are

provided by the high voltage power supply board. (See

page 1-66 .)

Multipole Entrance C-Trap Exit Collision Cell

Static

Pulsing from Velos Pro

Squeezing in C-Trap

Figure 1-10. Layout of the Orbitrap Elite MS, also showing the applied voltages

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-13

Functional Description

Orbitrap Analyzer

Orbitrap Analyzer

The heart of the Orbitrap™ analyzer is an axially-symmetrical mass analyzer. It consists of a spindle-shape central electrode surrounded by a

pair of bell-shaped outer electrodes. See Figure 1-11

. The Orbitrap analyzer employs electric fields to capture and confine ions.

r z

Figure 1-11. Schematic of Orbitrap cell and example of stable ion trajectory

Extraction of Ion Packets

For ion extraction, the RF on the rods of the C-Trap is ramped off and extracting voltage pulses are applied to the electrodes, pushing ions orthogonally to the curved axis through a slot in the inner electrode.

Because of the initial curvature of the C-Trap and the subsequent lenses, the ion beam converges on the entrance into the Orbitrap analyzer. The lenses that follow the C-Trap (Z-lens) form also differential pumping slots and cause spatial focusing of the ion beam into the entrance of the

Orbitrap analyzer. Ions are electrostatically deflected away from the gas jet, thereby eliminating gas carryover into the Orbitrap analyzer.

Owing to the fast pulsing of ions from the C-Trap, ions of each mass-to-charge ratio arrive at the entrance of the Orbitrap analyzer as short packets only a few millimeters long. For each mass-to-charge population, this corresponds to a spread of flight times of only a few hundred nanoseconds for mass-to-charge ratios of a few hundred

Daltons/charge. Such durations are considerably shorter than a half-period of axial ion oscillation in the trap. When ions are injected into the Orbitrap analyzer at a position offset from its equator (See

Figure 1-12

.), these packets start coherent axial oscillations without the need for any additional excitation cycle.

1-14

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Orbitrap Analyzer

Measuring Principle

Figure 1-12. Principle of electrodynamic squeezing of ions in the Orbitrap analyzer as the field strength is increased

The evolution of an ion packet during the increase of the electric field is

shown schematically on Figure 1-12

. When the injected ions approach the opposite electrode for the first time, the increased electric field

(owing to the change of the voltage on the central electrode) contracts the radius of the ion cloud by a few percent. The applied voltages are adjusted to prevent collision of the ions with the electrode. A further increase of the field continues to squeeze the trajectory closer to the axis, meanwhile allowing for newly arriving ions (normally, with higher m/z) to enter the C-Trap as well. After ions of all m/z have entered the

Orbitrap analyzer and moved far enough from the outer electrodes, the voltage on the central electrode is kept constant and image current detection takes place.

In the mass analyzer shown in

Figure 1-11 on page 1-14 , stable ion

trajectories combine rotation around an axial central electrode with harmonic oscillations along it. The frequency ω of these harmonic oscillations along the z-axis depends only on the ions’ mass-to-charge ratios m/z and the instrumental constant k:

w

=

z m

×

k

Two split halves of the outer electrode of the Orbitrap analyzer detect the image current produced by the oscillating ions. By Fast Fourier

Transformation (FFT) of the amplified image current, the instrument obtains the frequencies of these axial oscillations and therefore the mass-to-charge ratios of the ions.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-15

Functional Description

Orbitrap Analyzer

Ion Detection

During ion detection, the central electrode and the additional electrode, which deflects ions during injection and compensates electric field imperfections during the measurement (See

Figure 1-12 on page 1-15 .),

are maintained at very stable voltages so that no mass drift can take place. The outer electrode is split in half at z=0, allowing the ion image current in the axial direction to be collected. The image current on each of half of the outer electrode is differentially amplified and then undergoes analog-to-digital conversion before processing using the

Fourier transform algorithm.

Lower m/z Higher m/z

Figure 1-13. Approximate shape of ion packets of different m/z after stabilization of voltages

As mentioned above, stable ion trajectories within the Orbitrap analyzer combine axial oscillations along the z-axis with rotation around the central electrode and vibrations in the radial direction. (See

Figure 1-11 on page 1-14 .) For any given m/z, only the frequency of axial oscillations

is completely independent of initial ion parameters, whereas rotational and radial frequencies exhibit strong dependence on initial radius and energy. Therefore, ions of the same mass-to-charge ratio continue to oscillate along z together, remaining in-phase for many thousands of oscillations.

1-16

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Orbitrap Analyzer

In contrast to the axial oscillations, the frequencies of radial and rotational motion will vary for ions with slightly different initial parameters. This means that in the radial direction, ions dephase orders of magnitude faster than in the axial direction, and the process occurs in a period of only 50–100 oscillations. After this, the ion packet of a given

m/z assumes the shape of a thin ring, with ions uniformly distributed along its circumference. (See

Figure 1-13 .) Because of this angular and

radial smearing, radial and rotational frequencies cannot appear in the measured spectrum. Meanwhile, axial oscillations will persist, with axial thickness of the ion ring remaining small compared with the axial amplitude. Moving from one half outer electrode to the other, this ring will induce opposite currents on these halves, thus creating a signal to be detected by differential amplification.

Active Temperature Control

Active temperature control is achieved by monitoring temperature directly on the Orbitrap analyzer assembly and compensating any changes in ambient temperature by a thermoelectric cooler (Peltier element) on the outside of the UHV chamber. A dedicated temperature

controller board is used for this purpose. See page 1-62 .

Peltier Cooling

To allow stable operating conditions in the UHV chamber, it can be cooled or heated (outgassing) by means of a Peltier element located on the outside. A second Peltier element is located on the back of the

CE power supply board. See

Figure 1-43 on page 1-59 .

The Peltier cooling is based on the Peltier Effect, which describes the effect by which the passage of an electric current through a junction of two dissimilar materials (thermoelectric materials) causes temperature differential (cooling effect). The voltage drives the heat to flow from one side of the Peltier element to the other side, resulting in cooling effects on one side and heating effects on the other side.

To remove the heat from the hot side of the Peltier elements, they are connected to the cooling water circuit of the Orbitrap Elite mass spectrometer. See

“Cooling Water Circuit” on page 1-42 for further

information.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-17

Functional Description

HCD Cell

HCD Cell

HCD and ETD

The HCD cell consists of a straight multipole mounted inside a metal tube, which is connected in direct line-of-sight to the C-Trap. It is supplied with collision gas to provide increased gas pressure inside the multipole. See

“Gas Supply” on page 1-37 for details. The ETD Ion

Optic Supply board provides the voltages for the HCD cell. (See

page 1-46 .)

For HCD (Higher Energy Collisional Dissociation), ions are passed through the C-Trap into the HCD cell. The offset between the C-Trap and HCD is used to accelerate the precursor ions into the gas-filled cell.

A potential gradient is applied to the HCD cell to provide fast extraction of ions, such that it returns ions at a reliable rate.

The fragment spectra generated in the HCD cell and detected in the

Orbitrap analyzer show a fragmentation pattern comparable to the pattern of typical triple quadrupole spectra. See the Orbitrap Elite

Getting Started manual for more information.

In the Orbitrap Elite ETD mass spectrometer, ETD reagent anions can efficiently pass through the high pressure region of the HCD cell. This is an important prerequisite to allow for a fast switching (that is, scan to scan) between HCD and ETD fragmentation, thus making comparative measurements possible. When compared with the standard Orbitrap

Elite mass spectrometer, HCD performance is not in any way compromised by the addition of the ETD Module.

1-18

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

ETD System

Functional Description

ETD System

In the Orbitrap Elite ETD mass spectrometer, an ETD Module is physically coupled to the back of the Orbitrap Elite mass spectrometer.

See

Figure 1-14 . A quadrupole mass filter replaces the octapole of the

Orbitrap Elite MS. See Figure 1-2 on page 1-3 . The linear trap provides

the voltages for the quadrupole mass filter. A tube, which contains the transfer multipole, connects the HCD housing to the ETD Module. See

Figure 1-23 on page 1-30 . The ETD Ion Optic Supply board is

mounted on top of the data acquisition unit on the right side of the instrument. See

Figure 1-35 on page 1-47 .

ETD Module

Orbitrap

Analyzer

Linear Trap

Thermo Fisher Scientific

Figure 1-14. Orbitrap Elite ETD MS front view

Protein or peptide analyte ions may also be fragmented in the linear trap by negatively charged reagent ions (fluoranthene radical anions) from the reagent ion source (ETD Module). These negatively charged ions transfer electrons to protein or peptide analyte ions and cause them to fragment at their peptide bonds to produce c and z type fragments

(versus the y and b fragments produced by CID). The resulting analyte fragment ions provide another way of analyzing these molecules as compared to CID and PQD. Electron Transfer Dissociation (ETD) improves the identification of important post-translational modification

(PTM) for characterization.

Note Among others, the ETD system is also available as an upgrade on existing Velos Pro and Orbitrap Elite systems.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-19

Electrospray Ion Source S-Lens

Velos Pro MS

Square Quadrupole with neutral blocking

Octopole

Orbitrap analyzer

High Pressure Cell Low Pressure Cell Quadrupole Mass Filter C-Trap HCD Cell

ETD System

Transfer Multipole Reagent Ion Source e

-

High-field Orbitrap Mass Analyzer

Reagent 1

Heated Inlet

Reagent 2

Heated Inlet

Figure 1-15. Schematic of the Orbitrap Elite ETD MS

1-20

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Principle of Operation

Functional Description

ETD System

During a typical ETD MS/MS scan, analyte cations are injected into the linear trap for subsequent precursor cation isolation. Then,

ETD reagent anions are generated in the CI ion source and are transferred into the linear trap via RF-only ion guides (transfer multipoles), the gas-filled HCD cell, and the C-Trap. (See

Figure 1-15 on page 1-20 .)

The reagent ions pass a quadrupole mass filter between C-Trap and linear trap. This ion guide works as a low pass mass filter to remove the adduct ions of the fluoranthene radicals and molecular nitrogen at

m/z 216. These adduct ions favor proton transfer reactions instead of electron transfer.

The application of a supplementary RF voltage on the end lenses of the linear trap allows ions of opposite polarity to be trapped in the same space at the same time (charge-sign independent trapping—CSIT).

During ion-ion reactions in the linear trap, electrons are transferred from the reagent anions to the precursor cations. The resulting product ions are mass-to-charge (m/z) analyzed in either the linear trap (if speed and sensitivity are important) or the Orbitrap analyzer (if mass resolution and mass accuracy are important).

ETD Module

Figure 1-16 on page 1-22 shows the rear side of the ETD Module. It

consists of the reagent ion source, ETD Module electronics,

ETD Module power supply, ETD Module forepump, and the hardware that connects the ETD Module to the mass detectors.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-21

Functional Description

ETD System

Fan filter

Control elements of inlet valve

Inlet port for ETD reagent carrier gas

Figure 1-16. Orbitrap Elite ETD MS, rear side

Cabinet for

ETD forepump

15 14

Labeled components: 1=power module, 2=connector to Interface Board

(Interface Board is behind the ETD Control PCB, item #4), 3=DC HV Supply

PCB, 4=ETD Control PCB, 5=Heater Control PCB, 6=ion gauge,7=inlet valve solenoid, 8=inlet valve lever in closed (down) position, 9=reagent heater 1,

10=reagent heater 2, 11=ion volume tool handle, 12=guide bar, 13=TMP,

14=Convectron™ gauge, 15=vacuum manifold (contains ion source and ion volume)

Figure 1-17. Rear view of the ETD Module, with major component locations

1-22

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

ETD System

Orbitrap Elite

ETD Module

Peripherals

Power Outlet

Orbitrap Analyzer

Instrument Control Board

Orbitrap Vacuum System,

see Figure 1-23 on page 1-30

ETD Forepump

Power Module

Interface

Board

ETD Control PCB

DC HV Supply PCB

Heater Control PCB

ETD TMP

4

Ion Gauge

Ion Source

H1

H2

Reagent

Heaters

3

Flow

Control

Convectron Gauge

ETD Reagent

Carrier Gas

3 = Transfer line

4 = Ion volume

Figure 1-18. ETD Module functional block diagram

The following sections describe the major ETD Module components

that are shown in Figure 1-17 on page 1-22

and Figure 1-18.

ETD Power Module

ETD Ion Optic

Supply Board

The ETD power module (item #1 in Figure 1-17 ) receives 220 V, 10 A,

from the peripherals power outlet. See

Figure 1-9 on page 1-10 . It

distributes appropriate voltages and currents to the ETD components. It also contains DC power supplies.

ETD Module Power Panel

The external receptacles and switches for the power module are located on the ETD power module panel at the right side of the ETD Module.

See

Figure 1-19 .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-23

Functional Description

ETD System

ETD Module

ETD Module power panel

Figure 1-19. Right side of the Orbitrap Elite ETD MS

Figure 1-20

shows a close up picture of the ETD Power Module panel.

Power In is connected to the peripherals power outlet of the

MS portion. See

Figure 1-9 on page 1-10 . Forepump is a receptacle to

power the ETD forepump (220 V AC, 5 A).

ETD Module Service switch

ETD Module Power switch

ETD Module Forepump receptacle

ETD Module Power receptacle

ETD Module Power Panel

Figure 1-20. ETD Power Module panel

1-24

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

ETD Module Interface Board

Functional Description

ETD System

The ETD power module panel contains the main breaker and the service switch for the ETD Module. During normal operation, the

ETD Power switch is left On and the service switch is left in the

Operating Mode position. As a safety feature, both components of the

Orbitrap Elite ETD system (the mass spectrometer and the

ETD Module) are shut down with one set of switches, the mass spectrometer switches. When you perform maintenance on components

inside the ETD Module as described in “Maintenance of the ETD

Module” on page 3-12

, you set the mass spectrometer’s service switch to the Service position. The service switch turns On or Off power to all

ETD Module components except turbomolecular pump and forepump.

The ETD Module Interface board (item #2 in

Figure 1-17 on page 1-22

) provides an electronic interface between the ETD Module and the MS. This board also allows the power to both the MS and the

ETD Module to be controlled by the MS power control panel switches:

The MS Main Power switch controls the power supply to all components in both the MS and the ETD Module.

The MS FT Electronics switch controls the power supply to all mass spectrometer and ETD Module components except the pumps that are connected to the MS and the ETD Module.

Note The ability to control the power to both components of the

Orbitrap Elite ETD mass spectrometer at one point (the power control panel switches of the MS) is a safety feature.

ETD Control PCB

Thermo Fisher Scientific

The ETD Control PCB (item #4 in Figure 1-17

) controls most of the

ETD Module functions. The ETD Control PCB consists of circuits that control:

ETD Module operating logic

Ion source (filament, ion source heater, lenses)

Heater temperature and readback logic (for reagent heaters, transfer line heater, and the restrictor oven heater)

Reagent gas flow

Oven cooling gas control

Ion gauge

Convectron™ gauge

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-25

Functional Description

ETD System

The DC HV Supply PCB (item #3 in Figure 1-17 on page 1-22

) is plugged in to the ETD Control PCB.

ETD Heater Control PCB

The ETD Module Heater Control PCB (item #6 in

Figure 1-17 )

contains the power source and temperature sensing circuitry for the four heaters in the reagent ion source. The heaters are H1 and H2 (the two reagent heaters,

Figure 1-18 on page 1-23 , and items #9 and #10 in

Figure 1-17

), the transfer line heater (#3 in

Figure 1-17 ), and the

restrictor oven heater (not shown in

Figure 1-17 ). The Heater Control

PCB reports temperature information to the heater temperature and readback logic on the ETD Control PCB. The heater temperature and readback logic controls how the Heater Control PCB applies power to the ETD Module heaters.

Reagent Carrier Gas Flow Control for ETD

The ETD Module contains a digital flow control for the chemical ionization (CI) gas/reagent carrier gas provided by the ETD Control

PCB (See

Figure 1-17 on page 1-22 .) and an electronic pressure

regulator. The gas serves two functions in the ETD Module:

As a carrier gas, the nitrogen sweeps the reagent (fluoranthene) from the vial to the ion source where the reagent radical anions are formed.

As a chemical ionization (CI) vehicle, the nitrogen undergoes collisions with 70 eV electrons from the filament in the ion volume.

These 70 eV electrons from the filament knock electrons off of the nitrogen molecules (nitrogen ions are created). The secondary electrons resulting from these collisions have near thermal kinetic energies. These thermal electrons are captured by the fluoranthene to form reagent radical anions that react with the analyte.

Thermo Fisher Scientific strongly recommends a mixture of

25% helium and 75% nitrogen. The helium in this mixture serves as a tracer gas to enable leak checking of gas connections using conventional thermal conductivity-based leak detectors, which are widely used to

check leaks in gas chromatography equipment. See “Gas Supply of the

Reagent Ion Source” on page 1-40

for detailed information.

The reagent carrier gas supply in the laboratory is connected to the

ETD reagent carrier gas port at the rear side of the ETD Module. See

Figure 1-31 on page 1-40

.

1-26

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Reagent Heaters

Functional Description

ETD System

The reagent heaters (items #9 and #10 in

Figure 1-17 on page 1-22 , H1

and H2 in Figure 1-18 on page 1-23

) heat the reagent to obtain a sufficient amount of reagent vapor in the carrier gas. The reagent heaters are powered by the Heater Control PCB which, in turn, is controlled by the ETD Control PCB.

The reagent heaters are turned on by selecting the Reagent Ion Source

On check box in the Reagent Ion Source dialog box. See

Figure 1-21

.

Thermo Fisher Scientific

Figure 1-21. Reagent Ion Source dialog box

When you deselect the Reagent Ion Source On check box, the reagent heaters and filament immediately turn off and the reagent ion source goes into Standby mode.

When the reagent ion source is placed in Off mode, cooling nitrogen

(high-purity nitrogen) will turn on. This is confirmed by an audible rush (hissing noise) of nitrogen from the reagent ion source area in the back of the ETD Module. This is normal operation. See also

“Turning

Off the Reagent Ion Source: What to Expect” on page 2-14

.

Warning

Burn Hazard. When the reagent ion source is in Off mode, restrictor oven, transfer line, and ion source remain at 160 °C.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-27

Functional Description

ETD System

The nitrogen cooling gas turns off when the reagent heaters reach 70 °C.

If it is necessary to install or replace the reagent vials, follow the

procedure in “Replacing the Reagent Vials” on page 3-48

.

Note The rushing or hissing noise of the nitrogen coming from the back of the ETD Module will stop when the cooling nitrogen turns off.

On

Reagent Ion Source

Off

Warning

Burn Hazard. Do not attempt to handle the vials or vial holders when the cooling nitrogen stops. They are still too hot to handle when the cooling nitrogen stops at a vial temperature of 70 °C. Follow

the procedures in “Replacing the Reagent Vials” on page 3-48 if it is

necessary to install or replace the reagent vials.

When the reagent heaters are in Standby mode, they are immediately turned on by selecting the Reagent Ion Source On check box

(

Figure 1-21 on page 1-27 ). When starting from room temperature, it

takes up to ten minutes for the reagent heaters and vials to stabilize at

108 °C and reagent to delivered to the ion source.

Note When you switch on a cold reagent ion source, the Tune Plus software warns you that the vial temperature is not sufficient. The filament is automatically switched on after the temperature has stabilized.

Standby

When you click the Standby button in the Tune Plus window (shown in the left margin), you initiate a Standby process. It delays turning off the reagent heaters and the start of nitrogen cooling for one hour after the system is placed in Standby. This method of placing the system in

Standby permits a quick return to operation after a break (lasting one hour or less) rather than waiting up to ten minutes for the heaters to return to temperature and reagent delivery to be fully restored.

In summary:

The reagent heaters turn off immediately when the Reagent Ion

Source On check box is deselected in the Reagent Ion Source dialog

box. (See Figure 1-21 on page 1-27

.)

The reagent heaters turn off one hour after the system is placed in

Standby by clicking the Standby button in the Tune Plus window.

The ion source ( Figure 1-17 on page 1-22

and inside of the vacuum manifold, see item #14 in

Figure 1-17 ) is where the reagent ions are

formed. The ion source contains the filament, the reagent ion volume, and the ion source heater. The filament is the source of electrons that

1-28

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

ETD System react with the reagent to form reagent ions. The reagent ion volume is the space where this reaction takes place. See

Figure 1-22 . The ion

source heater is controlled by the ETD Control PCB.

Filament

Changeable Ion Volume

Heated Transfer Line

Fused Silica

Heated Dual Restrictor

Enclosure

Thermo Fisher Scientific

Figure 1-22. Reagent ion source schematics

The reagent ion source contains two reagent vials, CI/carrier gas

(nitrogen) handling hardware and flow restrictors, ion volume and filament, ion optics, and heaters for these components. The flow restrictors keep the internal pressure of the reagent vials below atmospheric pressure. This prevents the contents of the reagent vials from being expelled to the laboratory atmosphere.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-29

Functional Description

Vacuum System

Vacuum System

HCD Housing

Figure 1-23

shows a schematical overview of the Orbitrap analyzer vacuum system.

UHV Chamber Vacuum Chamber

Linear Trap

ETD Module

Vacuum System, see

Figure 1-18 on page 1-23

TMP 4

Pirani Gauge

TMP 2

Cold Ion Gauge

TMP 3 TMP 1

Forepump Forepump

Figure 1-23. Schematic of Orbitrap analyzer vacuum system (CLT compartment and Orbitrap chamber not shown) a a

For an abridged version of the parts list, see page 4-3

.

The Orbitrap Elite mass spectrometer has the following vacuum compartments:

CLT compartment in the aluminum vacuum chamber (pumped by the same pump as the linear trap)

Vacuum chamber (pumped by a water-cooled 60 L/s—for

N

2

—turbomolecular pump HiPace™ 80, TMP 1, manufacturer:

Pfeiffer)

Ultra high vacuum chamber (UHV chamber, pumped by a water-cooled 60 L/s turbomolecular pump HiPace 80, TMP 2, manufacturer: Pfeiffer)

1-30

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Vacuum System

Orbitrap chamber (pumped by a 260 L/s—for N

2

—water-cooled turbomolecular pump HiPace 300, TMP 3, manufacturer: Pfeiffer)

HCD housing (pumped by a water-cooled 60 L/s turbomolecular pump HiPace 80, TMP 4, manufacturer: Pfeiffer)

The forepumps of the linear trap provide the forevacuum for the turbomolecular pumps TMP 1 to TMP 4.

Turbomolecular Pumps

All parts of the system except for the Orbitrap analyzer are mounted in a aluminum vacuum chamber that is evacuated by a 60 L/s turbomolecular pump (TMP 1, see

Figure 1-24

). The rotary vane

pumps of the linear trap (see page 1-33

) provide the forevacuum for this pump. This chamber is bolted to a stainless steel welded UHV chamber, which accommodates Orbitrap analyzer, lenses, and corresponding electrical connections.

TMP 4 TMP 1

Thermo Fisher Scientific

Gas Regulator for Vent Valve

Pirani Gauge

Figure 1-24. Vacuum components on the left instrument side

The UHV chamber is evacuated down to 10

-8 mbar pressure range by a

60 L/s UHV turbomolecular pump (TMP 2, see Figure 1-25 on page 1-32

). The Orbitrap analyzer itself is separated from the

UHV chamber by differential apertures and is evacuated down to

10

-10 mbar by a 260 L/s turbomolecular pump (TMP 3, see

Figure 1-25 ). The HCD housing is evacuated by a 60 L/s

UHV turbomolecular pump (TMP 4, see Figure 1-24 ) that is mounted

to its bottom via an elbow. This dedicated pump for the HCD cell protects the low pressure cell of the linear trap from gas overload.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-31

Functional Description

Vacuum System

In the Orbitrap Elite ETD mass spectrometer, a tube that contains the transfer multipole (flatapole) connects the HCD housing to the

ETD Module.

Preamplifier

HCD housing

Cooling water supplies for

Peltier element and Preamplifier

Cold ion gauge

TMP 3

TMP 2

Figure 1-25. Vacuum components on the right instrument side

All turbomolecular pumps are equipped with TC 110 control units

(manufacturer: Pfeiffer). A 24 V switch mode power supply provides the electric power for all four turbomolecular pumps of the system.

Linear Trap Turbomolecular Pump

A separate turbomolecular pump provides the high vacuum for the linear ion trap. It it is mounted to the bottom of the vacuum manifold of the linear ion trap. For more information, refer to the LTQ Series

Hardware Manual.

ETD Module Turbomolecular Pump

In the Orbitrap Elite ETD mass spectrometer, a dedicated turbomolecular pump (Edwards EXT75DX) provides the high vacuum for the ETD reagent ion source. See

Figure 1-17 on page 1-22 . It is

backed up by a dedicated rotary vane pump at the bottom of the

ETD Module. See

Figure 1-27 on page 1-34 . This air-cooled

turbomolecular pump contains no user-serviceable parts.

1-32

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Vacuum System

Forepumps of the Linear Trap

The rotary vane pumps from the linear trap serve as forepumps for the three smaller turbomolecular pumps (TMP 1, TMP 2, and TMP 4).

The exhaust hose from the forepumps is led to the back of the instrument and connects them to the exhaust system in the laboratory.

The forepumps are located on a small cart in the forepumps cabinet below the linear trap. See

Figure 1-26 .

Oil mist filters

Thermo Fisher Scientific

Forepumps

Figure 1-26. Forepumps cabinet

To minimize the ingress of pump oil into the exhaust system, the outlets

of the forepumps are fitted to oil mist filters. See page 3-11

on instructions about returning the collected oil to the forepumps.

The forepumps of the linear trap are powered by the power panel of the linear ion trap.

Warning

Health Hazard. Hazardous materials may be present in the effluent of the forepumps. The connection to an adequate exhaust system is mandatory!

Leave the switches of the forepumps always in the On position to provide the control from the vacuum control panel. Before starting the pumps, however, make sure that:

The forevacuum pumps are filled with oil,

They are connected to the power supply, and

The gas ballast is shut.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-33

Functional Description

Vacuum System

For a detailed description of the forepumps, refer to the handbook of the manufacturer.

Forepump of the ETD Module

In the Orbitrap Elite ETD mass spectrometer, a rotary vane pump

(Edwards RV 3) provides the forevacuum for the ETD turbomolecular

pump. (See “ETD Module Turbomolecular Pump” on page 1-32

.) It is located in a cabinet at the bottom of the ETD Module. The

ETD forepump is equipped with an oil mist filter and stands on a drip

pan. See Figure 1-27 on page 1-34

.

An exhaust hose connects the forepump to the exhaust system in the laboratory. A forevacuum tube connects the ETD forepump to the

ETD TMP. The forepump electrical cord is plugged into the Forepump

receptacle on the ETD Module power panel. See Figure 1-20 on page 1-24 .

For maintenance instructions for the ETD forepump, see

“Maintenance of the ETD Forepump” on page 3-5 and the manual that came with the

forepump.

Exhaust hose

Forevacuum tube

Oil mist filter

Drip pan

Forepump electrical cord

Figure 1-27. Forepump for ETD Module

1-34

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Vacuum System

Vacuum System Controls

The power distribution board controls all turbomolecular pumps via voltage levels. See

“Power Distribution Board” on page 1-53 . An

interface for RS485 data via the instrument control board connects the

turbomolecular pumps with the linear ion trap. (See “Instrument

Control Board” on page 1-52 .) The turbomolecular pump of the linear

ion trap and the ETD turbomolecular pump have individual controllers.

Vacuum Gauges

Several vacuum gauges monitor the vacuum within the instrument:

The forevacuum of the Orbitrap Elite mass spectrometer is monitored by an Active Pirani gauge (TPR 280, manufacturer:

Pfeiffer) connected to the forevacuum line. See

Figure 1-24 on page 1-31

.

The high vacuum of the Orbitrap Elite mass spectrometer is monitored by a Cold Ion Gauge (IKR 270, manufacturer: Pfeiffer) connected to the UHV chamber. See

Figure 1-25 on page 1-32 .

Because the gauge would be contaminated at higher pressures, it is turned on only when the forevacuum has fallen below a safety threshold (<10

-2 mbar).

The linear ion trap vacuum is monitored by a Convectron™ gauge and an ion gauge. Refer to the LTQ Series Hardware Manual for more information.

In the Orbitrap Elite ETD mass spectrometer, two dedicated vacuum gauges monitor the vacuum in the ETD Module. A

Convectron gauge (see

Figure 1-17 on page 1-22 and

Figure 1-18 on page 1-23 ) monitors the pressure in the ETD forevacuum line

and an ion gauge (see

Figure 1-17 ) monitors the pressure in the

reagent ion source.

Table 1-3

shows typical pressure readings in the

ETD Module.

Table 1-3. Typical pressure readings in the ETD Module

Conditions Convection Gauge Reading

CI gas pressure set to 20 psi 0.1–0.01 Torr

Ion Gauge Reading

20–35×10

-5

Torr

The vacuum gauges of the Orbitrap Elite mass spectrometer are connected to the power distribution board that directly responds to the

pressure values. (See “Power Distribution Board” on page 1-53 .) The

analog values are digitized by the instrument control board. (See

“Instrument Control Board” on page 1-52 .) They are then sent as

readout values to the data system.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-35

Functional Description

Vacuum System

Switching on the Vacuum System

When the vacuum system is switched on, the following occurs:

1. After the Vacuum Pumps switch is switched On, the pumps of the linear ion trap and the Orbitrap Elite mass spectrometer are run up.

The Pirani gauge (see above) controls the Orbitrap Elite MS low vacuum pressure as well as the pressure at the forevacuum pumps.

Within a short time, a significant pressure decrease must be observed. The goodness of the vacuum can be estimated by means of the rotation speed of the turbomolecular pumps (for example,

80% after 15 minutes).

2. If the working pressure is not reached after the preset time, the complete system is switched off. At the status LED panel of the power distribution board, an error message (Vacuum Failure) is put out (see below).

3. The Cold Ion Gauge is only switched on after the low vacuum is reached. It is then used to monitor the vacuum in the Orbitrap analyzer region.

Vacuum Failure

In case the pressure in the Orbitrap Elite mass spectrometer or the linear ion trap exceeds a safety threshold, the complete system including linear ion trap, electronics, and pumps is switched off. However, the power distribution is kept under current and puts out an error message at the

LED panel. (See “Power Distribution Board” on page 1-53 .) It can be

reset by switching the main power switch off and on. (See

“Main Power

Switch” on page 1-9 .)

Upon venting, the vent valves of the turbomolecular pumps on the

Orbitrap analyzer stay closed. Only the vent valve of the linear ion trap

is used. (See “Vent Valve of the Linear Ion Trap” on page 1-39 .)

Vacuum System Heating during a System Bakeout

After the system has been open to the atmosphere (for example, for maintenance work), the vacuum deteriorates due to contaminations of the inner parts of the vacuum system caused by moisture or a power outage. These contaminations must be removed by heating the vacuum system: a system bakeout. See

“Baking Out the System” on page 3-4

.

1-36

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Gas Supply

Gas Supply

This section describes the gas supplies for the mass analyzers of the

Orbitrap Elite mass spectrometer and the reagent ion source of the

Orbitrap Elite ETD mass spectrometer.

Gas Supply for the Mass Analyzers

ETD reagent carrier gas

Figure 1-28 shows a schematical view of the gas supply for the

instrument. The gas supply of the ETD system is highlighted in gray.

Helium (He)

1

Nitrogen (N

2

)

Collision gas

1

ETD Module Linear Trap

Regulator with manometer

Analyzer

TMP 2

TMP 3

C-Trap

TMP 1

Cooling Gas

N

2

venting TMP 4

Figure 1-28. Schematic of gas supply for Orbitrap Elite ETD MS a a

For parts lists of the gas supply, see page 4-4 and

page 4-5 .

HCD Cell

Gas Inlet Ports of the Instrument

Vent valve

On its right side (See Figure 1-9 on page 1-10 .), the instrument provides

three gas inlet ports for the gas supply of the mass analyzers:

Nitrogen: The linear trap requires high-purity (99%) nitrogen for the API sheath gas and auxiliary/sweep gas. The required gas pressure is 690 ± 140 kPa (6.9 ± 1.4 bar, 100 ± 20 psi).

Thermo Fisher Scientific

1

The port named Collision Gas is not used in the Orbitrap Elite MS.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-37

Functional Description

Gas Supply

In the Orbitrap Elite ETD mass spectrometer, the ETD system uses the high-purity nitrogen for cooling the reagent vials when the reagent ion source is turned off.

Helium: The linear trap requires ultra-high purity (99.999%) helium for the collision gas. The required gas pressure is

275 ± 70 kPa (2.75 ± 0.7 bar, 40 ±10 psi).

Warning

Danger of Asphyxiation. Accumulation of nitrogen gas could displace sufficient oxygen to suffocate personnel in the laboratory.

Ensure that the laboratory is well ventilated.

To connect the nitrogen source to the Orbitrap Elite mass spectrometer

1. Connect an appropriate length of Teflon™ tubing to the nitrogen source in the laboratory. The Installation Kit contains 6 m (20 ft) of suitable Teflon tubing (OD 6 mm, P/N 0690280). The connection for the Teflon hose to the nitrogen gas supply is not provided in the kit; you have to supply this part.

2. Connect the opposite end of the Teflon tubing to the press-in fitting labeled Nitrogen, which is located at the right side of the

instrument. See Figure 1-9 on page 1-10

. To connect the tubing, align the Teflon tubing with the opening in the fitting and firmly push the tubing into the fitting until the tubing is secure.

To connect the helium source to the Orbitrap Elite mass spectrometer

1. Connect an appropriate length of 1/8-in. ID copper or stainless steel tubing with a brass Swagelok-type 1/8-in. nut (P/N 00101-15500) and a 2-piece brass 1/8-in. ID ferrule [P/N 00101-08500 (front),

P/N 00101-2500 (back)] to the Helium gas inlet. See

Figure 1-29

for the proper orientation of the fitting and ferrule.

2. Connect the opposite end of the tubing to the helium gas source, using an appropriate fitting.

Gas hose Front ferrule

Swagelok-type nut Back ferrule

Figure 1-29. Proper orientation of the Swagelok-type nut and two-piece ferrule

1-38

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Gas Supply

Gas Distribution Within the Instrument

Helium gas is led from the helium port through a stainless steel capillary to the right rear side of the linear trap. See

Figure 1-28 on page 1-37 .

High purity nitrogen gas is led from the nitrogen port via Teflon tubing to the right side of the Orbitrap Elite mass spectrometer. Here, two

T-pieces divide the nitrogen gas flow into three parts.

The first part of the high purity nitrogen gas flow is directed through

Teflon tubing via a pressure regulator to the vent valve of the linear trap.

(See

Figure 1-30 on page 1-39

.) The second part of the nitrogen flow is directed through Teflon tubing to the API source. The third part of the nitrogen flow enters a gas regulator with manometer, which keeps the gas pressure to the C-Trap and HCD cell constant. (See

Figure 1-30 ,

background.) From the regulator, the collision gas is led through red

PEEKSil™ tubing (100 mm ID silica capillary in 1/16 inch

PEEK tubing) to the collision octapole next to the curved linear trap

(flow rate: ~0.5 mL/min). The nitrogen gas leaking from the

HCD collision cell (3–5 mbar) is used for ion trapping and cooling in the C-Trap.

Gas for HCD and C-Trap

Gas for Vent Valve

Figure 1-30. Gas regulators

In the Orbitrap Elite ETD mass spectrometer, nitrogen is also directed through Teflon tubing to the ETD Module to be used for cooling the reagent vials when the reagent ion source is turned off.

Vent Valve of the Linear Ion Trap

Thermo Fisher Scientific

If the system and pumps are switched off, the system is vented. The vent valve is controlled by the linear ion trap. The LTQ Series Hardware

Manual contains further information about the vent valve.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-39

Functional Description

Gas Supply

The instrument is vented with high purity nitrogen from the same tubing that supplies the Velos Pro MS sheath gas. See

Figure 1-28 on page 1-37 . The vent valve of the Velos Pro mass spectrometer is supplied

via a pressure regulator that is set to a venting pressure of 3–4 psi. The pressure regulator is located at the left side of the Orbitrap Elite mass

spectrometer. (See Figure 1-30

, front.)

Gas Supply of the Reagent Ion Source

In addition to high purity nitrogen for cooling, the reagent ion source of the Orbitrap Elite ETD mass spectrometer uses a mixture of 25% helium and 75% nitrogen gas as carrier gas and chemical ionization (CI) vehicle. This gas mixture must be ultra high-purity (minimum purity

99.999%) with less than 3.0 ppm each of water, oxygen, and total hydrocarbons. The required gas pressure is 690 ± 140 kPa

(6.9 ± 1.4 bar, 100 ± 20 psi). The ETD carrier gas supply of the laboratory is connected via metal tubing to the inlet port at the rear side

of the instrument. See Figure 1-31

.

Figure 1-31. ETD reagent carrier gas port at the ETD Module

The helium in this mixture serves as a tracer gas to enable leak checking of gas connections using conventional thermal conductivity-based leak detectors, which are widely used to check leaks in gas chromatography equipment.

Note If the helium/nitrogen mixture is not available, then use a nitrogen supply that is ultra high-purity (99.999%) with less than 3.0 ppm each of water, oxygen, and total hydrocarbons.

1-40

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Triple Gas Filter

Functional Description

Gas Supply

A triple (oxygen/water/hydrogen) gas filter is installed between the regulator on the reagent carrier gas source and the ETD module to ensure that the reagent carrier gas (either nitrogen or helium/nitrogen) is better than 99.999% pure with much less than 1 ppm of oxygen, water, and hydrocarbons.

Refer to the filter manufacturer’s instructions for information about how to monitor the color changes in the filters that indicated when the filters need to be replaced, as well as information about where to order new filters. If there are no leaks in the reagent carrier gas plumbing, you can expect the filters to last a year or more. Thermo Fisher Scientific strongly recommends that a Thermo Fisher Scientific field service engineer replace the gas filters.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-41

Functional Description

Cooling Water Circuit

Cooling Water Circuit

Figure 1-32 on page 1-42

shows a schematical view of the cooling water circuit in the Orbitrap Elite mass spectrometer. For a parts list of the cooling water circuit, see

page 4-4 . Cooling water at a temperature of

20 °C enters and leaves the instrument at the bottom of the right side.

See Figure 1-9 on page 1-10

. First, the fresh water passes through the turbomolecular pumps in the order TMP 3 → TMP 1 → TMP 4 →

TMP 2. Then it passes through the heating element (Peltier element) that maintains (±0.5 °C) the preset temperature of the analyzer. After that, the cooling water passes through the preamplifier cooling unit.

Before it leaves the instrument, the water passes through the other

Peltier element at the back of the central electrode power supply board.

A flow control sensor is connected to the power distribution board and allows displaying the current flow rate of the cooling water in the software. An inline filter, which is installed upstream, protects the

sensor. It must be replaced annually, see page 3-58

for instructions.

Recirculating chiller

Power Distribution Board

Linear Trap

Water filter

Flow control sensor

Peltier element Central Electrode

Power Supply Box

TMP 4

TMP 2

Figure 1-32. Schematic of cooling water circuit

Water cooler for TMP

1-42

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

Preamplifier cooling

Heating element

(Peltier element)

TMP 3

Analyzer

TMP 1

Thermo Fisher Scientific

Functional Description

Cooling Water Circuit

Recirculating Chiller

A recirculating chiller (Thermo Scientific NESLAB ThermoFlex™ 900) is shipped with the instrument, making the mass spectrometer independent from any cooling water supply. A wall receptacle provides the electric power for the chiller. Two water hoses (black), internal diameter 9 mm, wall thickness 3 mm, length approx. 3 m (~10 ft) are shipped with the instrument.

For instruction about performing maintenance for the chiller, see

“Maintenance of the Cooling Circuit” on page 3-58

. See also the manufacturer’s manual for the chiller.

Properties of Cooling Water

The water temperature is not critical, but should be in the range of 20 to

25 °C (68 to 77 °F). Lower temperatures could lead to a condensation of atmospheric water vapor. It is recommended to use distilled water rather than de-ionized water due to lower concentration of bacteria and residual organic matter.

The water should be free of suspended matter to avoid clogging of the cooling circuit. In special cases, an in-line filter is recommended to guarantee consistent water quality.

The cooling water should meet the following requirements:

Hardness:

Resistivity:

Total dissolved solids: pH:

<0.05 ppm

1–3 MΩ/cm

<10 ppm

7–8

Warning

Burn Hazard. If the water circuit fails, all parts of the water distribution unit may be considerably heated up. Do not touch the parts! Before disconnecting the cooling water hoses, make sure the cooling water has cooled down!

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-43

Functional Description

Printed Circuit Boards

Printed Circuit Boards

The Orbitrap Elite mass spectrometer is controlled by a PC running the

Xcalibur™ software suite. The software controls all aspects of the instrument. The main software elements are the communication with the linear ion trap, the control of ion detection, and the control of the

Orbitrap analyzer.

The following pages contain a short overview of the electronic boards in the MS portion of the Orbitrap Elite mass spectrometer. For each board, its respective location and function are given. If applicable, the diagnostic LEDs on the board are described. For a description of the

printed circuit boards in the ETD Module, see “ETD Module” on page 1-21 .

The electronics of the Orbitrap Elite mass spectrometer contains complicated and numerous circuits. Therefore, only qualified and skilled electronics engineers should perform servicing.

A Thermo Fisher Scientific field service engineer should be called if servicing is required. It is further recommended to use Thermo Fisher

Scientific spare parts only. When replacing fuses, only use the correct type. Before calling a service engineer, please try to localize the defect via errors indicated in the software or diagnostics. A precise description of the defect will ease the repair and reduce the costs.

Warning

Electrical Shock Hazard. Parts of the printed circuit boards are at high voltage. Shut down the instrument and disconnect it from line power before performing service. Opening the electronics cabinet is only allowed for maintenance purposes by qualified personnel.

Note Many of the electronic components can be tested by the Orbitrap

Elite MS diagnostics, which is accessible from the Tune Plus window.

1-44

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Linear Ion Trap Electronics

The linear ion trap is connected to the Orbitrap Elite MS main power

switch. The linear ion trap has a sheet metal back cover. Figure 1-33

shows the electronic connections at the rear side of the linear trap.

Cold Ion Gauge

Figure 1-33. Electronic connections to linear trap

The linear ion trap electronics has two connections with the Orbitrap

Elite MS electronics:

Data communication with the internal computer of the Orbitrap

Elite mass spectrometer. See

“Electronic Boards on the Right Side of the Instrument” on page 1-46 .

Signal communication (SPI bus) with supply information for the instrument control board. See

“Instrument Control Board” on page 1-52

.

For further information about the linear ion trap electronics, refer to the

LTQ Series Hardware Manual.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-45

Functional Description

Printed Circuit Boards

Electronic Boards on the Right Side of the Instrument

Figure 1-34

shows the parts of the instrument when the right side panel is opened. A transparent cover protects the lower part.

ETD Ion Optic Supply board housing

Preamplifier

Computer housing

(data acquisition unit)

Instrument Control board housing

Power Supply 1 board

Power Distribution board

Ground wire for side panel

Figure 1-34. Electronic boards on the right side of the Orbitrap Elite MS

The side panel is connected to the instrument frame by two

green/yellow ground wires. See bottom of Figure 1-34

. The connectors on the panel are labeled with green-yellow PE (for Protective Earth) signs. See photo left. Do not forget to reconnect them before closing the panel!

ETD Ion Optic Supply Board

The ETD Ion Optic Supply board is mounted on top of the data acquisition unit. See

Figure 1-35 . It supplies the voltages for the

HCD cell. In the Orbitrap Elite ETD mass spectrometer, this board also supplies the RF voltage and the DC voltages for the ETD Module: an

RF voltage with DC offset, three DC voltages with ±250 V, and a

DC voltage with ±12 V.

1-46

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Thermo Fisher Scientific

Figure 1-35. ETD Ion Optic Supply board

The diagnostic LEDs on the ETD ion optic supply board are listed in

Table 1-4 on page 1-47

. The positions of the diagnostic LEDs on the

board are indicated by white rectangles in Figure 1-36

.

Table 1-4. Diagnostic LEDs on the ETD Ion Optic Supply board

No.

Name Color Description

LD1 +275 V

LD2 -275 V

Green +275 V input voltage present

Green -275 V input voltage present

LD3 RF Supply Green RF input voltage (22 V) present

LD4 +24 V Green +24 V input voltage present

LD5 +15 V

LD6 -15 V

LD7 RF1_ON

Green

Green

Blue

+15 V input voltage present

-15 V input voltage present

RF-generator switched on

Normal Operating

Condition

On

On

On

On

On

On

On/Off, depending on active application

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-47

Functional Description

Printed Circuit Boards

Preamplifier

The preamplifier is located in a housing next to the Cold Ion Gauge. See

Figure 1-36

. It is water cooled to protect it during a system bakeout.

Cooling water supply for Preamplifier

Cooling water supply for Peltier element

Cold Ion Gauge

Figure 1-36. Preamplifier

This board is a broadband preamplifier with differential high-impedance inputs. It serves as a detection amplifier and impedance converter for the image current created by the oscillating ions. The output current is transferred to the data acquisition board. It has an amplification factor of about 60 dB and covers the frequency range from

15 kHz to 10 MHz.

The diagnostic LEDs on the preamplifier are listed in

Table 1-5 on page 1-49 . The positions of the diagnostic LEDs on the board are

indicated by white rectangles in

Figure 1-36 .

1-48

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Internal Computer

Functional Description

Printed Circuit Boards

Table 1-5. Diagnostic LEDs on the Preamplifier board

No.

Name Color Description

LD1 Overload Yellow RF output is overloaded

LD2 +5 V Green +5 V input voltage present

LD3 +15 V

LD4 -5 V

Green

Green

+15 V input voltage present

-5 V input voltage present

LD5 Input off Yellow RF inputs are shortened

(protection)

Normal Operating

Condition

Off

On

On

On

On, off during

Detect

Figure 1-37 shows the components of the data acquisition unit. The

unit is mounted in a housing located at the right side of the instrument.

ETD Ion Optic Supply board housing

Computer housing with

Data Acquisition Analog board, Data Acquisition

Digital PCI board, and

Power Supply 2 board

Thermo Fisher Scientific

Instrument Control board housing

Figure 1-37. Data Acquisition unit

The internal computer contains a computer mainboard with an

ATX power supply. The data acquisition digital PCI board is directly plugged into the mainboard. The data acquisition analog board is mounted on top of the computer mainboard.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-49

Functional Description

Printed Circuit Boards

Data Acquisition Digital PCI Board

Figure 1-38

shows the data acquisition digital PCI board. It is an add-on board to the internal computer. (See

Figure 1-37 on page 1-49 .)

Figure 1-38. Data Acquisition Digital PCI board

This board is used to convert detected ion signals to digital form and to interface to the computer mainboard. The board has two 16 bit parallel connections to the DAC and the ADC on the data acquisition analog board, which are used for controlling and reading-back signals. A high-speed link port channel is also on the board that is used to communicate with the electronics in the linear ion trap.

Precision timing is derived from the data acquisition analog board and events with lower requirements use the timer in the internal computer.

This timer is used to check at regular intervals whether the foreground process works as expected.

Communication takes place not only between the linear ion trap and the internal computer of the Orbitrap Elite system, but also between the linear ion trap and the data system computer. For further information about the data system, refer to the LTQ Series Hardware Manual.

The diagnostic LEDs listed in Table 1-6

show the status of the board.

The position of the LEDs on the board is indicated by a red rectangle in

Figure 1-38

.

Table 1-6. Diagnostic LEDs of the Data Acquisition Digital PCI board

Name Color

+5 V Green

+3.3 V Green

+2.5 V Green

Description

+5 V voltage present

+3.3 V voltage present

+2.5 V voltage present

Normal Operating Condition

On

On

On

1-50

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Data Acquisition Analog Board

Figure 1-39 shows the data acquisition analog board. This board is an

add-on board to the mainboard of the internal computer. See

Figure 1-37 on page 1-49 . It is used to convert analog to digital signals

for Orbitrap analyzer experiments, especially for detecting the ions. The board contains an ADC for the detection of the transient signal, with a frequency range from 10 kHz to 10 MHz. Three anti-aliasing filters for the low, middle and high mass range are automatically selected by the software.

The data acquisition board provides precision timing to control the acquisition. Events with lower timing requirements on accuracy are controlled by the linear ion trap.

Power Supply 2 Board

Thermo Fisher Scientific

Figure 1-39. Data Acquisition Analog board

The diagnostic LEDs listed in Table 1-7 on page 1-51

show the status of the voltages applied to the board. The position of the LEDs on the

board is indicated by a white rectangle in Figure 1-39

.

Table 1-7. Diagnostic LEDs of the Data Acquisition Analog board

Name Color

+5 V Green

-5 V

+3.3 V

Green

Green

Description

+5 V voltage present

-5 V voltage present

+3.3 V voltage present

Normal Operating Condition

On

On

On

The power supply 2 board provides the supply voltages for the data acquisition analog board. It is mounted to the back inside the housing of the internal computer. See

Figure 1-37 on page 1-49 .

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-51

Functional Description

Printed Circuit Boards

Instrument Control Board

The diagnostic LEDs listed in Table 1-8

show the status of the voltages applied to the board.

Table 1-8. Diagnostic LEDs of the Power Supply 2 board

Name Color

+5.1 V Green

-5.1 V Green

+3.3 V Green

Description

+5.1 V voltage present

-5.1 V voltage present

+3.3 V voltage present

Normal Operating Condition

On

On

On

Figure 1-40 shows the instrument control board. The instrument

control board is located in a housing next to the internal computer. It is connected to the Orbitrap Elite MS main power.

Diagnostic LEDs

Figure 1-40. Instrument Control board

Status LEDs

The instrument control board is used to interface the Velos Pro MS control electronics to the Orbitrap analyzer control electronics. Three signal lines are passed from the Velos Pro MS: a digital, parallel (DAC) bus, a serial SPI bus, and a Link Port Signal line. The instrument control board contains a micro controller, digital and analog converters, and serial port connectors.

1-52

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Power Distribution Board

Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

On the instrument control board, analog signals from vacuum gauges are converted to digital signals and passed to the data system as well as to the power distribution board. (See

page 1-53

.) Turbomolecular pumps

(See

“Vacuum System” on page 1-30

.) are attached to a serial port connector and this is connected via the signal lines to the linear ion trap.

The diagnostic LEDs listed in

Table 1-9 show the status of applied

voltages to the board. The position of the diagnostic LEDs on the board is indicated by a white rectangle in

Figure 1-40 on page 1-52 .

Table 1-9. Diagnostic LEDs of the Instrument Control board

No.

LD1

LD2

Name

2.5 V

3.3 V

Color Description Normal

Operating Condition

Green 2.55 V Input voltage present On

Green 3.3 V Input voltage present On

LD3 5 V

LD4 -15 V

Green

Green

5 V Input voltage present

-15 V Input voltage present

On

On

LD5 +15 V Green +15 V Input voltage present On

Additionally, the board has four green LEDs that are directly connected to the micro controller. They indicate the state of the micro controller and possible error bits and can be used for software debugging. See

Table 1-10

. The position of the status LEDs on the board is indicated

by a white oval in Figure 1-40 on page 1-52

.

Table 1-10. Software status LEDs of the Instrument Control board

No.

Description

6.1

Micro controller is working properly

6.2

CAN bus connection to power distribution board enabled

6.3

Connection to internal computer and Velos

Pro SPI bus enabled

6.4

Orbitrap analyzer SPI bus enabled

Normal Operating Condition

Permanent flashing of LED

On

On

On

Flashing on error

Figure 1-41 on page 1-54 shows the power distribution board. It is

located at the bottom of the right side of the instrument.

The power distribution board controls the vacuum system and the system power supplies, including the linear ion trap. Depending on the quality of the vacuum and the status of the turbo molecular pumps, it switches the vacuum gauges, the pumps, and the 230 V relays. It controls external relays with 24 V DC connections. In case of a vacuum failure, it initiates an automatic power down of the instrument.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-53

Functional Description

Printed Circuit Boards

Figure 1-41. Power Distribution board

The power distribution board indicates all system states and error

messages by status LEDs (See Table 1-11 on page 1-55

.) in the middle of the left side of the board. A green LED indicates that the status is

OK. An orange LED indicates a status that differs from normal. The position of the LEDs on the board is indicated by a white oval in

Figure 1-41

.

The system status LEDs on the front side of the instrument (See

Figure 1-4 on page 1-5

.) are controlled by the power distribution board.

The information partially comes from external boards (for example, the

Communication LED is controlled by the instrument control board).

(See “Instrument Control Board” on page 1-52 .)

Diagnostic LEDs show the status of voltages applied from the board to other devices. The positions of the diagnostic LEDs on the board are indicated by white rectangles in

Figure 1-41 .

1-54

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Table 1-11. Status LEDs of the Power Distribution board

LED green

Vacuum

Comm.

System

LED orange

High vacuum failure

No communication with instrument control board

System is not ready

Information given by orange LED

High vacuum pressure > 10

-8 mbar

CAN bus problem or instrument control board not working

FT Electronics switch off or

Vacuum Pumps switch off

Scan

Electr. On

Vac. Units OK

Pirani Orbitrap analyzer OK

Pirani LT OK

Ion Gauge On

Ion Gauge OK

Turbo P. 1 On

Rotation 1 OK

Service mode

Vacuum measurement failure

No function, at present

Instrument is not scanning

FT Electronics switch off

Vacuum gauge defective

Pirani Velos Pro MS failure Control signal < 0.5 V

Penning Orbitrap Elite MS

Off

Forevacuum > 10

-2

mbar

Penning Orbitrap Elite MS failure

Control signal < 0.5 V

LT Vacuum Work Velos Pro MS vacuum failure

Vac. <10

-3

Vac. <10

-5

Forevacuum failure

High vacuum failure

Pumps OK

Rough P. 1 On

Pumps Off

Forepump #1 failure

TMP 1 failure

TMP 1 failure

Vacuum forepump Velos Pro MS

>10

-1 mbar

Forevacuum > 10

-3

High vacuum > 10

-5 mbar mbar

Pump down; leakage

Forepump defective

TMP defective/error a

Turbo P. 2 On

Rotation 2 OK

Heater Off

LAN Conn. OK

EI On

A

B

TMP 2 failure

TMP 2 failure

Heater enabled

LAN connection failure

No function, at present

System reset

80% rotation speed of TMP not reached

TMP defective/error a

80% rotation speed of TMP not reached

Heater enabled

LAN interrupted (Option)

System reset has occurred

Micro controller idle a

An error of

TMP

3 is indicated by an LED directly located on the pump controller. An error of TMP 4 is indicated in the software.

Depending on user actions, the power distribution is switched to various

working modes by the hardware. See Table 1-12 on page 1-56

.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-55

Functional Description

Printed Circuit Boards

Table 1-12. Working modes of the Power Distribution board

Action

a.

Main switch off

Consequences

Complete system including linear ion trap and multiple socket outlets (ETD Module, for example) are without power

Everything is switched off b.

Vacuum Pumps switch off c.

FT Electronics switch off

All components are switched off with exception of the following ones:

Heater control

Multiple socket outlets

Power distribution board

Pumps

Vacuum control

Velos Pro MS (has a separate Service switch)

Table 1-13 shows the possible operating states of the power distribution.

Table 1-13. Operating states of the Power Distribution board

Action

1.

Main switch on, Vacuum Pumps switch off

2.

Vacuum Pumps switch on and FT

Electronics switch on

3.

Check linear ion trap and Orbitrap Elite

MS forevacuum pumps:

10

-0

mbar after 30 s.

4.

After the system has started, the Pirani gauge returns a vacuum < 10

-2 mbar and both TMPs reach 80% rotation speed

5.

Vacuum and 80% rotation speed of

TMPs not reached after preset time

(< 8 min, otherwise the pumps automatically switch off).

6.

One or more vacuum gauges defective

(control signal < 0.5 V).

7.

After the operating status is reached, the pressure at one gauge exceeds the security threshold for more than the preset time period:

Pirani gauge Orbitrap Elite MS

>10

-1 mbar

Penning gauge Orbitrap Elite MS

>10

-3 mbar

Pirani gauge Velos Pro MS forepump

>10

-1 mbar

Consequences

Everything is switched off

System starts up: pumps and electronics switched on

If not ok: switch off system and light error LED a

; power distribution remains switched on

Switch on Penning gauge

Switch off system (including linear ion trap) and light error LED

*

; power distribution remains switched on

Light error LED only, otherwise ignore

System is shut down with exception of power distribution (light error LED).

Rebooting of the system by switching off/on of the main switch.

1-56

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Power Supply 1 Board

Functional Description

Printed Circuit Boards

Table 1-13. Operating states of the Power Distribution board, continued

8.

Rotation speed of a TMP falls below

9.

10.

11.

12.

Action

80%

Service switch linear ion trap off

FT Electronics switch Orbitrap Elite MS off

Failure of linear ion trap or Orbitrap Elite

MS (for example, fuse is opened).

Mains failure

Consequences

Shut down system (see 7.); light LED

*

of corresponding pump.

Linear ion trap electronics switched off, pumps keep on running;

Orbitrap Elite MS without data link, keeps on running

Orbitrap Elite MS electronics switched off, pumps keep on running;

Orbitrap Elite MS without data link, keeps on running

If the vacuum in one part deteriorates, the complete system is shut down.

System powers up after the electricity is available again. All devices reach the defined state. Linear ion trap and internal computer must reboot.

a

After the shutdown, the LED flashes that represents the reason for the shutdown.

Figure 1-42 shows the power supply 1 board. This board is located next

to the power distribution board. It provides the power for the ion optic supply board (See

“Ion Optic Supply Board” on page 1-59

.) and the

instrument control board. (See “Instrument Control Board” on page 1-52

.)

Thermo Fisher Scientific

Figure 1-42. Power Supply 1 board

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-57

Functional Description

Printed Circuit Boards

Warning

Electrical Shock Hazard. Parts of the power supply 1 board are at high voltage. Shut down the instrument and disconnect it from line power before performing service.

The diagnostic LEDs listed in

Table 1-14 show the status of the voltages

applied to the board. The position of the LEDs on the board is indicated by the white rectangles in

Figure 1-42

.

Table 1-14. Diagnostic LEDs of the Power Supply 1 board

Name Color Description

+285 V

-285 V

Green

Green

Over Current +285 V Red

+285 V Output voltage present

-285 V Output voltage present

Over Current -285 V Red

LED lit dark red: I out

> 80 mA

LED lit bright red: output is short-circuited

LED lit dark red: I out

> 80 mA

LED lit bright red: output is short-circuited

+18 V

-18 V

+8.5 V

Green

Green

Green

+18 V Output voltage present

-18 V Output voltage present

+8.5 V Output voltage present

On

On

On

Normal Operating

Condition

On

On

Off

Off

1-58

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Electronic Boards on the Left Side of the Instrument

Figure 1-43 shows the left side of the instrument with the panel opened.

This side of the instrument contains mostly boards that are part of the

Orbitrap analyzer control.

Ion Optic Supply board housing

Central Electrode Pulser board housing

Temperature

Controller board

CLT RF Main board housing with RF Off & Feedback board and CLT Offset Connector

Central Electrode

Power Supply board housing

High Voltage Power Supply board housing

Figure 1-43. Electronic boards on the left side of the instrument

The main components on this side are described starting from the top.

Ion Optic Supply Board

Figure 1-44 on page 1-60 shows the ion optic supply board. The board

is located in a housing on top of the left instrument side of the instrument. This board supplies the voltages and the radio frequency for the ion guides and interoctapole lenses of the Orbitrap Elite mass spectrometer. It has an RF detector for the RF output control. The

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-59

Functional Description

Printed Circuit Boards board also provides the trap voltage, the gate voltage, and the reflector

DC voltages as well as the RF voltages to the octapole of the Orbitrap

analyzer. See “Orbitrap Analyzer” on page 1-14 for further information.

Figure 1-44. Ion Optic Supply board

The diagnostic LEDs listed in Table 1-15

show the status of applied voltages to the board. The position of the LEDs on the board is indicated by white rectangles in

Figure 1-44 .

Warning

Electrical Shock Hazard. Parts of the board are at high voltage. Shut down the instrument and disconnect it from line power before performing service.

Table 1-15. Diagnostic LEDs of the Ion Optic Supply board

No.

Name Color Description

LD1 +275 V Green +275 V Input voltage present

LD2 -275 V Green -275 V Input voltage present

LD3 +29 V

LD5 +15 V

LD6 -15 V

Green

Green

Green

+29 V Input voltage present

+15 V Input voltage present

-15 V Input voltage present

On

On

On

Normal Operating

Condition

On

On

1-60

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Table 1-15. Diagnostic LEDs of the Ion Optic Supply board, continued

No.

Name Color Description

LD7 RF1_ON Blue RF1 generator switched on

LD8 RF2_ON Blue RF2 generator switched on

Normal Operating

Condition

depending on application;

LED flashes during scanning depending on application;

LED flashes during scanning

Central Electrode Pulser Board

The central electrode pulser board is located in a housing that is

mounted to the flange of the UHV chamber. See Figure 1-45

.

Thermo Fisher Scientific

Figure 1-45. Central Electrode Pulser board

The board switches the injection and measurement voltages for the central electrode and the detection electrodes of the Orbitrap analyzer.

Resistor-capacitor circuits on the board convert the switching pulse into a smooth transition between the voltages.

The diagnostic LEDs listed in

Table 1-16 on page 1-62 show the status

of the voltages applied to the board as well as some operating states. The position of the LEDs on the board is indicated by the white rectangles in

Figure 1-45 .

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-61

Functional Description

Printed Circuit Boards

Table 1-16. Diagnostic LEDs of the Central Electrode Pulser board

No.

Name Color Description

LD1 TRIG Green Trigger signal indicator

LD2 PS

Normal Operating Condition

Flashing when scanning

Green 24V Power Supply is OK On

Temperature Controller Board

The temperature controller board is located on the top left side of the instrument, next to the CLT RF main board. See

Figure 1-43 on page 1-59 . The temperature controller board keeps the temperature of

the analyzer chamber to a preset value. A Peltier element that can be used for heating as well as for cooling is used as an actuator. Activation is done via the serial SPI (Serial Peripheral Interface) bus.

Figure 1-46. Temperature Controller board

The diagnostic LEDs listed in Table 1-17 on page 1-63

show the status of the voltages applied to the board as well as some operating states. The positions of the LEDs on the board are indicated by the white rectangles in

Figure 1-46 .

1-62

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

CLT RF Unit

Functional Description

Printed Circuit Boards

Table 1-17. Diagnostic LEDs of the Temperature Controller board

No.

Name Color Description

LD1 +15 V

LD2 -15 V

Green +15 V Input voltage present

Green -15 V Input voltage present

LD3

LD4

TEC >60C

Unit >60C

Yellow Temperature of cold side Peltier element above 60 ºC

Yellow Temperature of UNIT heat sink above 60 ºC

Yellow Control switched off LD5 Reg Off

LD6 No Term Yellow SPI bus termination board missing

LD7 SDT enable Green Interface has been addressed and sends/receives data

LD8 SEL Green Board has been addressed

LD9 Heating

LD10 Cooling

LD11 UR>0

Yellow Peltier element is heating

Yellow Peltier element is cooling

Normal Operating

Condition

On

On

Off

Off

Off

Off

Flashing on SPI bus data transfer

Flashing on SPI bus data transfer

Depending on system state

Depending on system state

Off when adjusted

LD12 UR<0

Yellow Summation voltage controller

>0 V

Yellow Summation voltage controller

<0 V

Off when adjusted

The CLT RF unit comprises the CLT RF main board and the RF off & feedback board. The unit operates the curved linear trap (CLT) with four phases RF voltage and three pulsed DC voltages (PUSH, PULL, and OFFSET).

The CLT RF main board is located in a housing in the center of the left side of the instrument. See

Figure 1-43 on page 1-59 . This board

provides an RF voltage (“Main RF”) for the curved linear trap. It allows switching off the RF and simultaneous pulsing of each CLT electrode.

See

“Orbitrap Analyzer” on page 1-14

for further information. The board communicates with the instrument control board via an SPI bus.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-63

Functional Description

Printed Circuit Boards

CLT Offset Connector RF Off & Feedback board

Figure 1-47. CLT RF unit (cover removed)

The diagnostic LEDs listed in

Table 1-18 show the status of the voltages

applied to the board as well as some operating states. The position of the

LEDs on the board is indicated by the white rectangles in Figure 1-47

.

Table 1-18. Diagnostic LEDs of the CLT RF Main board

No.

Name Color Description

LD1 NO TERM Yellow SPI bus termination board missing

LD2 SEND Yellow Interface has been addressed and sends/receives data

LD3 SEL Green Board has been addressed

LD4 RF ON

LD6 OVL

LD7 OVHEAT

Green RF voltage on

LD5 NO LOCK Yellow PLL has been not locked

Yellow

Red

RF Amplifier overload

Heatsink temperature > 73 °C

Normal Operating

Condition

Off

Flashing on SPI bus data transfer

Flashing on SPI bus data transfer

On

50% intensity

Off

Off

The RF off & feedback board is an add-on board to the CLT RF main board. It is located in the same housing. See

Figure 1-47 on page 1-64 .

The CLT Offset connector, which removes interfering signals from the circuit, is also mounted in the housing.

1-64

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards

Central Electrode Power Supply Board

The central electrode power supply board is mounted in a housing on

the bottom left side of the instrument. See Figure 1-48

.

Figure 1-48. Central Electrode Power Supply board

The board supplies four DC voltages to the Orbitrap analyzer:

Two central electrode (CE) voltages: CE HIGH and CE LOW.

Two deflector electrode (DE) voltages: DE HIGH and DE LOW.

For positive ions, the CE voltages are negative and the DE voltages are positive. The maximum CE voltage is 3 kV and the maximum

DE voltage is 1 kV. The board communicates via the SPI bus.

In addition to a ventilator on the bottom right side, a water-cooled

Peltier element on the rear side of the board serves as means of heat dissipation.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-65

Functional Description

Printed Circuit Boards

The diagnostic LEDs listed in

Table 1-19 show the status of the voltages

applied to the board as well as some operating states. The position of the

LEDs on the board is indicated by the red rectangles in

Figure 1-48 on page 1-65 .

Table 1-19. Diagnostic LEDs of the Central Electrode Power Supply board

No.

Name Color Description

LD1 OVL DE HIYellow Negative side of Deflector High

Supply has been overloaded

LD2 OVL DE HI+ Yellow Positive side of Deflector High

Supply has been overloaded

LD3 No Term Red SPI bus termination board missing

LD4 Send

LD5 Sel

Yellow Interface has been addressed and sends/receives data

Green Board has been addressed

Normal Operating

Condition

Off when HV is switched on

Off when HV is switched on

Off

Flashing on SPI bus data transfer

Flashing on SPI bus data transfer

Off (positive mode)

Off when HV is switched on

LD6 Polarity Blue Positive/negative ion mode

LD7 OVL CE LO+ Yellow Positive side of Central

Electrode Low Supply has been overloaded

LD8 OVL CE LOYellow Negative side of Central

Electrode Low Supply has been overloaded

LD9 OVL CE HI+ Yellow Positive side of Central

Electrode High Supply has been overloaded

LD10 OVL CE HIYellow Negative side of Central

Electrode High Supply has been overloaded

LD11 OVL DE LO+ Yellow Positive side of Deflector Low

Supply has been overloaded

LD12 OVL DE LOYellow Negative side of Deflector Low

Supply has been overloaded

LD13 HV ON Green High voltage switched on

Off when HV is switched on

Off when HV is switched on

Off when HV is switched on

Off when HV is switched on

Off when HV is switched on

On when HV is switched on

High Voltage Power Supply Board

The high voltage power supply board is mounted in a housing on the

bottom left side of the instrument. See Figure 1-43 on page 1-59

. This board provides five DC voltages for the ion optics of the Orbitrap Elite mass spectrometer. Two voltages supply the lenses of the instrument.

Three voltages are applied to the RF CLT main board to be used as

1-66

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Functional Description

Printed Circuit Boards focusing potentials for the curved linear trap. See

“Orbitrap Analyzer” on page 1-14 for further information. The board communicates via the

SPI bus.

Warning

Electrical Shock Hazard. The high voltage power supply board creates voltages up to 3.5 kV! Shut down the instrument and disconnect it from line power before performing service.

Figure 1-49. High Voltage Power Supply board (cover removed)

The diagnostic LEDs listed in

Table 1-20 on page 1-68 show the

operating states of the board. The position of the LEDs on the board is

indicated by the white rectangles in Figure 1-49 .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

1-67

Functional Description

Printed Circuit Boards

SPI Bus Termination Board

Table 1-20. Diagnostic LEDs of the High Voltage Power Supply board

No.

Name Color Description Normal Operating

Condition

Off LD1

LD2

LD3

NO TERM

SEND

SEL

Red SPI bus termination board missing

Yellow Interface has been addressed and sends/receives data

Green Board has been addressed

LD4 HV ON Green High voltage is switched on

LD5 POLARITY Green Positive/negative ion mode

Flashing on SPI bus data transfer

Flashing on SPI bus data transfer

On

Off (positive mode)

Various boards communicate via the SPI bus, a serial RS485-based bus system. The SPI Bus Termination board reduces unwanted signal reflections. The boards indicate a missing termination (after maintenance, for example) by LEDs.

The SPI Bus Termination board is located below the High Voltage

Power Supply board, at the bottom left side of the instrument. See

Figure 1-50

.

SPI bus termination board

Figure 1-50. High Voltage Power Supply board with SPI Bus Termination board

1-68

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Chapter 2

Basic System Operations

Many maintenance procedures for the Orbitrap Elite system require that the mass spectrometer be shut down. In addition, the Orbitrap Elite system can be placed in Standby condition if the system is not to be used for 12 hours or more.

The following topics are described in this chapter:

“Shutting Down the System in an Emergency” on page 2-2

“Placing the Instrument in Standby Condition” on page 2-4

“Shutting Down the Orbitrap Elite Mass Spectrometer Completely” on page 2-7

“Starting Up the System after a Shutdown” on page 2-9

“Resetting the System” on page 2-12

“Resetting Tune and Calibration Parameters to their Default Values” on page 2-13

“Turning Off the Reagent Ion Source: What to Expect” on page 2-14

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-1

Basic System Operations

Shutting Down the System in an Emergency

Shutting Down the System in an Emergency

If you need to turn off the mass spectrometer in an emergency, place the main power switch (located on the power panel at the right side of the

Orbitrap Elite mass spectrometer) in the Off (0) position. This turns off all power to the instrument, including the linear ion trap, multiple socket outlets, and the vacuum pumps. The main power switch must be turned 90° anti-clockwise to switch off the instrument. See

Figure 2-1 .

On

Off

Figure 2-1. Main power switch in Off position

The instrument is automatically vented by the vent valve of the linear ion trap. The vent valve vents the system 30 seconds after power is switched off.

Although removing power abruptly will not harm any component within the system, this is not the recommended shutdown procedure to

follow. See “Shutting Down the Instrument” on page 2-7 for the

recommended procedure.

Note To separately turn off the recirculating chiller or computer in an emergency, use the On/Off switches on the chiller and computer, respectively.

Behavior of the System in Case of a Main Failure

A main power failure has the same consequence as switching off via the main power switch. If the power is available again, the system starts up automatically: the pumps are switched on and the instrument is pumped down. If the system has been vented during the mains failure, it is necessary to bake out the system to obtain the operating vacuum. See

“Baking Out the System” on page 3-4

.

It is not possible to check whether the system was vented. The log file of the data system indicates a reboot of the system. In case of frequent but short power failures we recommend installing an uninterruptible power

2-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Shutting Down the System in an Emergency supply (UPS). If main power failures occur frequently while the system is not attended (for example, in the night), we recommend installing a power fail detector.

Note The intentional venting of the system is performed with the vent valve of the linear ion trap.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-3

Basic System Operations

Placing the Instrument in Standby Condition

Placing the Instrument in Standby Condition

The Orbitrap Elite system should not be shut down completely if you are not going to use it for a short period of time, such as overnight or over the weekend. When you are not going to operate the system for

12 hours or more, you can leave the system in Standby condition.

In case of an Orbitrap Elite ETD mass spectrometer, first place the

ETD Module in Standby condition. Then place the mass spectrometer in Standby condition according to the procedures described in the following topics.

Placing the ETD Module in Standby Condition

To place the ETD Module in Standby condition

1. If the Tune Plus window is not already open, choose Start >

Programs > Thermo Instruments > LTQ > LTQ Tune from the taskbar. The Tune Plus window will open.

On/Standby button Reagent Ion Source instrument control icon

Figure 2-2. Tune Plus window (Orbitrap Elite ETD), toolbar

On Off Standby

You can determine the state of the mass spectrometer by observing the state of the On/Off/Standby button on the Control/Scan Mode toolbar. See

Figure 2-2 . The three different states of the On/Standby

button are shown at the left.

2. Click the Reagent Ion Source portion of the instrument control

graphic at the top of the Tune Plus window. (See Figure 2-2

.) The

Reagent Ion Source dialog box appears. (See Figure 2-3 .)

3. In the Reagent Ion Source dialog box, clear the Reagent Ion Source

On box to place the Reagent Ion Source in Standby condition. See

Figure 2-3 on page 2-5

. This places the Reagent Ion Source in

Standby condition as indicated by the Actual condition shown to the right of the Reagent Ion Source On box.

When the reagent ion source is placed in Standby condition, the filament and vial heaters turn off. Simultaneously, a valve opens to allow the nitrogen gas to cool the reagent vials. This cooling

2-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Placing the Instrument in Standby Condition nitrogen runs until the reagent vials reach 70 °C. The audible rush

(hissing noise) of nitrogen from the reagent ion source area in the back of the ETD Module is normal operation.

Thermo Fisher Scientific

Figure 2-3. Reagent Ion Source dialog box with Reagent Ion Source On box and Actual condition circled

If the reagent ion source is on when you place the Orbitrap

Elite ETD mass spectrometer in Standby mode, the filament turns off immediately. In contrast, the vial heaters stay on for 60 minutes before they turn off and the cooling gas begins. Because the filament is turned off, you can perform minor maintenance procedures on the ETD Module without cooling the reagent inlet.

Warning

Burn Hazard. Install or exchange the reagent vials by

following the procedure in “Replacing the Reagent Vials” on page 3-48.

The reagent vials will be too hot to touch after the cooling nitrogen turns off at 70°C. Verify that the reagent vials are cool to the touch before handling them.

More information about turning on and off the reagent heaters is

given in “Reagent Heaters” on page 1-27 .

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-5

Basic System Operations

Placing the Instrument in Standby Condition

Warning

Burn Hazard. The restrictor, the transfer line, and the ion source heater operate at 160 °C. Do not attempt to touch them unless

the Orbitrap Elite mass spectrometer is shut down (See “Shutting Down the Orbitrap Elite Mass Spectrometer Completely” on page 2-7.) and

these heaters have had sufficient time to cool down to room temperature.

Placing the MS in Standby Condition

To place the Orbitrap Elite system in Standby condition

1. Wait until data acquisition, if any, is complete.

2. Turn off the flow of solvent from the LC (or other sample introduction device).

Note For instructions on how to operate the LC from the front panel, refer to the manual that came with the LC.

On Off Standby

3. From the Tune Plus window, choose Control > Standby (or click on the On/Standby button to toggle it to Standby) to put the instrument in Standby condition. The consequences of this user action are described in the LTQ Series Hardware Manual. The

System LED on the front panel of the Velos Pro mass spectrometer turns yellow when the system is in Standby condition.

4. Leave the LC power on.

5. Leave the autosampler power on.

6. Leave the data system power on.

7. Leave the Orbitrap Elite MS main power switch in the On position.

2-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Shutting Down the Orbitrap Elite Mass Spectrometer Completely

Shutting Down the Orbitrap Elite Mass Spectrometer Completely

The Orbitrap Elite mass spectrometer does not need to be shut down completely if you are not going to use it for a short period of time, such as overnight or over weekends. Shut down ETD Module and MS system completely only if you do not want to use them for an extended period or if you want to perform a maintenance or service procedure.

To shut down the instrument completely

1. Place the ETD Module in Standby condition as described in

“Placing the ETD Module in Standby Condition” on page 2-4 .

2. Shut down the instrument as described in

“Shutting Down the

Instrument“ below. This also shuts down the ETD Module because

its power controls are linked to the Orbitrap Elite MS power controls through the ETD Module Interface board. See

“ETD Module Interface Board” on page 1-25 .

Shutting Down the Instrument

To shut down the Orbitrap Elite system

1. Wait until data acquisition, if any, is complete.

2. Turn off the flow of solvent from the LC (or other sample introduction device).

Note For instructions on how to operate the LC from the front panel, refer to the manual that came with the LC.

3. From the Tune Plus window, choose Control > Off to put the instrument in Off condition. When you choose Control > Off, all high voltages are shut off, as are the flows of the sheath gas and the auxiliary gas.

4. Put the FT Electronics switch to the Off position. See Figure 1-7 on page 1-8

.

5. Put the Vacuum Pumps switch to the Off position. See

Figure 1-7 .

When you place the switch in the Off position, the following occurs: a. All power to the instrument, including the turbomolecular pumps and the rotary-vane pumps, is turned off.

b. After 30 s, power to the vent valve solenoid of the ion trap is shut off. The vent valve opens and the vacuum manifold is vented with nitrogen to atmospheric pressure through a filter.

You can hear a hissing sound as the gas passes through the filter.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-7

Basic System Operations

Shutting Down the Orbitrap Elite Mass Spectrometer Completely

6. Leave the main power switch of the Orbitrap Elite mass spectrometer in the On position.

7. During service or maintenance operations that require opening the vacuum system of the Velos Pro MS or the Orbitrap Elite MS, always put the main switch (main circuit breaker) to the Off position. You can secure the main switch with a padlock or tie-wrap to prevent unintended re-powering.

Warning

Burn Hazard. Allow heated components to cool down before you service them (the ion transfer tube is operated at about 300 °C, for example).

Note If you are planning to perform routine or preventive system maintenance on the Orbitrap Elite mass spectrometer only, you do not need to turn off the recirculating chiller, LC, autosampler, or data system. In this case, the shutdown procedure is completed. However, if you do not plan to operate your system for an extended period of time, you might want to turn off the recirculating chiller, LC, autosampler, and data system.

2-8

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Starting Up the System after a Shutdown

Starting Up the System after a Shutdown

To start up the Orbitrap Elite mass spectrometer after it has been shut down, you need to do the following:

1. Start up the instrument.

2. Set up conditions for operation.

Starting Up the Instrument

Note The recirculating chiller and data system must be running before you start up the instrument. The instrument will not operate until it has established a communication link to the data system.

To start up the Orbitrap Elite mass spectrometer

1. Start up the (optional) LC and autosampler as is described in the manual that came with the LC and autosampler.

2. Start up the data system and the chiller.

3. Turn on the flows of helium and nitrogen at the tanks, if they are off.

4. Make sure that the main power switch of the Velos Pro MS is in the

On position and the electronics service switch of the Velos Pro MS is in the Operating position.

5. Place the main power switch at the right side of the Orbitrap Elite mass spectrometer in the On position.

6. Put the Vacuum Pumps switch to the On position. See

Figure 1-7 on page 1-8

. The rotary-vane pumps and the turbomolecular pumps are started.

Note Pumping the system after a complete shut down takes hours and requires overnight baking of the system.

7. Put the FT Electronics switch to the On position. See Figure 1-7

.

When you place the FT Electronics switch to the On position, the following occurs: a. Power is provided to all electronic boards. (The electron multiplier, conversion dynode, 8 kV power to the API source, main RF voltage, and quadrupole RF voltage remain off.) b. The internal computer reboots. After several seconds, the

Communication LED on the front panel turns yellow to

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-9

Basic System Operations

Starting Up the System after a Shutdown indicate that the data system has started to establish a communication link.

c. After several more seconds, the Communication LED turns green to indicate that the data system has established a communication link. Software for the operation of the instrument is then transferred from the data system to the instrument.

d. After three minutes, the System LED of the ion trap turns yellow to indicate that the software transfer from the data system is complete and that the instrument is in Standby condition.

Note The Vacuum LED on the front panel of the Velos Pro turns green only if the pressure in the vacuum manifold is below the maximum allowable pressure (5×10

-4

Torr in the analyzer region, and 2 Torr in the

S-lens region), and the safety interlock switch on the API source is pressed down (that is, the API flange is secured to the spray shield).

8. Press the Reset button on the Velos Pro to establish the communication link between Velos Pro and internal computer.

If you have an LC or autosampler, start it as is described in the manual

that came with the LC or autosampler. Then, proceed to “Setting Up

Conditions for Operation“ . If you do not have either, go to the topic

directly.

Setting Up Conditions for Operation

To set up your Orbitrap Elite mass spectrometer for operation

1. Before you begin data acquisition with your Orbitrap Elite system, you need to allow the system to pump down for at least eight hours.

Operation of the system with excessive air and water in the vacuum manifold can cause reduced sensitivity, tuning problems, and a reduced lifetime of the electron multiplier.

Note The vacuum in the analyzer system can be improved by an overnight baking of the system. See

“Baking Out the System” on page 3-4 .

2. Ensure that the gas pressures are within the operational limits:

Helium: 275 ± 70 kPa (2.75 ± 0.7 bar, 40 ±10 psi),

Nitrogen: 690 ± 140 kPa (6.9 ± 1.4 bar, 100 ± 20 psi).

2-10

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Starting Up the System after a Shutdown

In case of an Orbitrap Elite ETD mass spectrometer, also check the pressure of the reagent carrier gas: 690 ± 140 kPa (6.9 ± 1.4 bar,

100 ± 20 psi).

Note Air in the helium line must be purged or given sufficient time to be purged for normal performance.

3. Click the Display Status View button in the Tune Plus window.

Check whether the pressure measured by the ion gauge is

5 × 10

-9 mbar, and the pressure measured by the Pirani gauge is around 1 mbar. Compare the values of the other parameters in the status panel with values that you recorded previously.

4. In case of an Orbitrap Elite ETD mass spectrometer, start up the

ETD Module as described in “Starting the ETD Module After a

Complete Shutdown“ . In case of an Orbitrap Elite mass

spectrometer, continue to set up for ESI or APCI operation as described in Orbitrap Elite Getting Started.

Starting the ETD Module After a Complete Shutdown

On Off Standby

To start up the ETD Module after a complete shutdown

1. Start the Orbitrap Elite ETD mass spectrometer according to the start up procedures given in

“Starting Up the System after a

Shutdown“

above. This also turns on the ETD Module as the

ETD Module power controls are linked to the MS power controls

(see

“ETD Module Interface Board” on page 1-25

).

2. If the Tune Plus window is not already open, choose Start >

Programs > Thermo Instruments > LTQ > LTQ Tune from the taskbar. The Tune plus window will open.

You can determine the state of the MS detector by observing the state of the On/Off/Standby button on the Control/Scan Mode

toolbar. (See Figure 2-2 on page 2-4

.) The three different states of the On/Standby button are shown at the left.

3. Click the Display Status View button in the Tune Plus window.

Check the reagent vacuum parameters:

Reagent ion gauge pressure: 20 to 35 × 10

-5

Torr

Reagent Convectron gauge pressure: <0.08 Torr

Reagent turbomolecular pump speed : > 90%

4. Continue to set up the instrument for operation as described in

Orbitrap Elite Getting Started manual.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-11

Basic System Operations

Resetting the System

Resetting the System

If the communication link between Orbitrap Elite mass spectrometer and data system computer is lost, it may be necessary to reset the system using the Reset button of the Velos Pro mass spectrometer.

The procedure given here assumes that the Orbitrap Elite mass spectrometer and data system computer are both powered on and are operational. If the instrument, data system computer, or both are off, see

“Starting Up the System after a Shutdown” on page 2-9

.

To reset the Orbitrap Elite mass spectrometer, press the Reset button of the Velos Pro. See the LTQ Series Hardware Manual for the location of the Reset button. When you press the Reset button, the following occurs:

1. An interrupt on the mainboard of the internal computer causes the internal computer to reboot. All LEDs on the front panel are off except the Power LED.

2. After several seconds, the Communication LED turns yellow to indicate that the data system and the instrument are starting to establish a communication link.

3. After several more seconds, the Communication LED turns green to indicate that the data system and the instrument have established a communication link. Software for the operation of the instrument is then transferred from the data system to the instrument.

4. After three min, the software transfer is complete. The System LED turns either green to indicate that the instrument is functional and the high voltages are on or yellow to indicate that the instrument is functional and it is in Standby condition.

2-12

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Resetting Tune and Calibration Parameters to their Default Values

Resetting Tune and Calibration Parameters to their Default Values

You can reset the Orbitrap Elite system tune and calibration parameters to their default values at any time. This feature may be useful if you have manually set some parameters that have resulted in less than optimum performance.

To reset the Orbitrap Elite MS tune and calibration parameters

In the Tune Plus window,

Choose File > Restore Factory Calibration to restore the default calibration parameters, or

Choose File > Restore Factory Tune Method to restore the default tune parameters.

Note Make sure that any problems you might be experiencing are not due to improper API source settings (spray voltage, sheath and auxiliary gas flow, ion transfer capillary temperature, etc.) before resetting the system parameters to their default values.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-13

Basic System Operations

Turning Off the Reagent Ion Source: What to Expect

Turning Off the Reagent Ion Source: What to Expect

In the Orbitrap Elite ETD mass spectrometer, the reagent ion source

controls can be accessed as described in “Placing the ETD Module in

Standby Condition” on page 2-4 . When you deselect the Reagent Ion

Source On check box in the Reagent Ion Source dialog box (See

Figure 2-4

.), the ETD source and reagent heaters are placed in Standby condition.

Figure 2-4. Placing the reagent ion source in Standby condition

When the ETD Module is placed in Standby condition, the filament and vial heaters are turned off. Simultaneously a valve opens to allow nitrogen gas to cool the reagent vials. This cooling nitrogen runs until the vials reach 70 °C. The audible rush (hissing noise) of nitrogen from the reagent ion source area in the back of the ETD Module is normal operation.

Warning

Burn Hazard. The reagent vials are too hot to handle after the cooling nitrogen turns off at a vial temperature of 70 °C. Verify that the reagent vials have cooled down to a safe temperature before handling them. This can take up to 90 minutes after the cooling nitrogen has turned off.

Other conditions that will cause the ETD Module to remain in

Standby:

Attempting to turn on the reagent ion source when the restrictor heater, transfer line heater, and the source heater are not at their target temperatures.

2-14

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Basic System Operations

Turning Off the Reagent Ion Source: What to Expect

Whenever either the mass spectrometer or the ETD Module goes into Standby mode. Reagent vial nitrogen cooling will turn on if the vials are at an elevated temperature.

Exception: If the Orbitrap Elite ETD mass spectrometer is placed in

Standby by clicking the Standby button in Tune Plus (see Standby icon in the margin), there is an hour delay before the cooling nitrogen turns on.

Whenever the pressure in the mass spectrometer or the

ETD Module exceeds its protection limit. Reagent vial nitrogen cooling will turn on if the vials are at an elevated temperature.

Whenever the abundance of reagent ions becomes insufficient as determined by the AGC setting. When this occurs, the Orbitrap

Elite ETD mass spectrometer completes the Xcalibur Sequence step in progress before going into Standby mode.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

2-15

Chapter 3

User Maintenance

This chapter describes routine maintenance procedures that must be performed to ensure optimum performance of the Orbitrap Elite mass spectrometer.

For instructions on maintaining the Velos Pro linear trap, refer to the

LTQ Series Hardware Manual. For instructions on maintaining LCs or autosamplers, refer to the manual that comes with the LC or autosampler.

Note It is the user’s responsibility to maintain the system properly by performing the system maintenance procedures on a regular basis.

The following topics are described in this chapter:

“General Remarks” on page 3-2

“Baking Out the System” on page 3-4

“Maintenance of the Vacuum System” on page 3-4

“Maintenance of the ETD Module” on page 3-12

“Maintenance of the Cooling Circuit” on page 3-58

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-1

User Maintenance

General Remarks

General Remarks

Preventive maintenance must commence with installation, and must continue during the warranty period to maintain the warranty. Thermo

Fisher Scientific offers maintenance and service contracts. Contact your local Thermo Fisher Scientific office for more information. Routine and infrequent maintenance procedures are listed in

Table 3-1 .

Table 3-1. User maintenance procedures

MS Component

Analyzer

Rotary-vane pumps

Turbomolecular pumps

Cooling water circuit

ETD Module

Procedure

System bakeout

Add oil

Change oil

Replace operating fluid reservoir and pump bearings

Change rotary-vane pump oil

Clean rear cooling fans

Frequency

If necessary (for example, after performing maintenance work on the vacuum system)

If oil level is low

Every three months or if oil is cloudy or discolored

Every four years

Check cooling fluid level

Check cooling fluid filter

Check air inlet filter

See manufacturer’s documentation

Replace filter cartridge

Clean ion volume

Annually

As needed

Replace inlet valve components

As needed a

a

Clean ion source lenses

Clean ion source

As needed a

As needed a

Replace ion source filament

Replace reagent vials

As needed a

As needed a

Check rotary-vane pump oil and add when needed

Every month

Every four months

Every four months

Procedure Location

page 3-4

Manufacturer’s documentation

Manufacturer’s documentation

page 3-5

Manufacturer’s documentation

page 3-11

Manufacturer’s documentation

page 3-58 page 3-58

page 3-21

page 3-45

page 3-33

page 3-40

page 3-42

page 3-48

page 3-8

page 3-9

page 3-57

a

As needed depends on how close the component is to the electron transfer reagent introduction point. For example, the ion volume is closer to the fluoranthene introduction point than any other component and requires the most frequent cleaning.

To successfully carry out the procedures listed in this chapter, observe the following rules:

Proceed methodically.

Always wear clean, lint-free, and powder-free gloves when handling the components of the API source, ion optics, mass analyzer, and ion detection system.

3-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

General Remarks

Thermo Fisher Scientific recommends the following gloves: white nitrile clean room gloves (Fisher Scientific P/N 19-120-2947B [size medium] or P/N 19-120-2947C [size large]; Thermo Scientific

P/N 23827-0008) [size medium] or P/N 23827-0009 [size large]).

Never re-use gloves after you remove them because the surface contaminants on them will re-contaminate clean parts.

Always wear protective eye wear when you clean parts.

Always place the components on a clean, lint-free, and powder-free surface.

Always cover the opening in the top of the vacuum manifold with a large, lint-free tissue whenever you remove the top cover plate of the vacuum manifold.

Never overtighten a screw or use excessive force.

Dirty tools can contaminate your system. Keep the tools clean and use them exclusively for maintenance and service work at the

Orbitrap Elite mass spectrometer.

Never insert a test probe (for example, an oscilloscope probe) into the sockets of female cable connectors on PCBs.

Returning Parts

To protect our employees, we ask you for some special precautions when returning parts for exchange or repair to the factory. Your signature on the Repair Covering letter confirms that the returned parts have been de-contaminated and are free of hazardous materials. See

”Safety Advice for Possible Contamination” on page viii

for further information.

Cleaning the Surface of the Instrument

Clean the outside of the instrument with a dry cloth. For removing stains or fingerprints on the surface of the instrument (panels, for example), slightly dampen the cloth (preferably made of microfiber) with distilled water.

Caution

Prevent any liquids from entering the inside of the instrument.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-3

User Maintenance

Maintenance of the Vacuum System

Maintenance of the Vacuum System

This section contains instructions for performing a system bakeout and for performing pumps maintenance.

Baking Out the System

Collected or remaining gases and molecules as well as moisture can lead to an increased number of collisions with sample ions in the high vacuum region of the instrument. The bakeout procedure removes these contaminations. Therefore, we recommend to bake out the instrument if the high vacuum decreases noticeably during routine operation.

Bakeout is mandatory after maintenance or service work is performed in the analyzer region where the system is vented.

Note Pumping down the system after venting takes at least eight hours, and usually requires overnight baking of the system.

In case the system has been vented during a power failure, it is necessary to bake out the system to obtain the operating vacuum. See

“Behavior of the System in Case of a Main Failure” on page 2-2 .

Bakeout Procedure

To perform a system bakeout

1. Place the system in Standby condition as described in

“Placing the

Instrument in Standby Condition” on page 2-4

.

2. Put the FT Electronics switch at the power control panel into the

On position.

Elapsed time display

Set time display

Up keys

Down keys

Bakeout start button Bakeout stop button

Figure 3-1. Bakeout timer

3-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the Vacuum System

3. Set the bakeout time by entering the desired time (hh:mm) with the up/down keys of the bakeout timer. See

Figure 3-1 on page 3-4 .

4. Start the bakeout procedure by pressing the green start button on the right. The Orbitrap Elite mass spectrometer indicates a running bakeout procedure by the flashing Vacuum and System LEDs on the

front side of the instrument. See Figure 1-4 on page 1-5

.

You can stop a running bakeout procedure by pressing the orange reset/stop button on the left side. Also press this button after you have changed the preset bakeout time.

5. The bakeout procedure is terminated because of two reasons:

The preset duration has expired, or

The vacuum has risen above a preset value.

The termination of the baking process is indicated by the status LEDs

(System and Vacuum) on the front side that have stopped flashing.

Maintenance of the Forepumps

Rotary-vane pumps require minimal maintenance. All that is required to maintain the rotary-vane pump is to inspect, add, purge, and change the pump oil.

For maintenance of the forepumps of the MS portion, refer to the

LTQ Series Hardware Manual or the pump manufacturer’s manual.

Note The manuals of the pump manufacturers give detailed advice regarding safety, operation, maintenance, and installation. Please note the warnings and precautions contained in these manuals!

Maintenance of the ETD Forepump

Rotary-vane pump oil (P/N A0301-15101) is a translucent light amber color and it should be checked often. During normal operation, oil must always be visible in the oil level sight glass between the MIN and

MAX marks. If the oil level is below the MIN mark, add oil. If the oil is cloudy or discolored, purge the oil to decontaminate dissolved solvents.

If the pump oil is still discolored, change it. You should change the pump oil every 3000 hours (about four months) of operation.

The rotary-vane pump major components are shown in Figure 3-2 on page 3-6

.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-5

User Maintenance

Maintenance of the Vacuum System

1

2

3

3

14

4

5

6

7

13

8

12

11

9

10

Labeled components: 1=Foreline Vacuum Hose, 2=Electrical Inlet Connector,

3=Voltage Indicator, 4=Inlet Port, 5=Gas Ballast Control, 6=Oil Filler Plugs,

7=Outlet Port, 8=MAX Marks, 9=Oil Drain Plug, 10=MIN Marks, 11=Oil Level

Sight Glass, 12=Mode Selector, 13= On/Off Switch, 14=Lifting Handle

Figure 3-2. Schematic of ETD forepump

Note During normal operation, the mode selector switch is set to high-vacuum mode (turned fully clockwise) and the gas-ballast control is closed (0).

Accessing the ETD Forepump

As described in

“Forepump of the ETD Module” on page 1-34 , the

ETD forepump is located in a cabinet at the bottom of the

ETD Module. To access the ETD forepump, you have to remove the lower panel as indicated in

Figure 3-3 on page 3-7

.

3-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the Vacuum System

Pull to remove panel

Loosen screws on both sides

Figure 3-3. Accessing the ETD Forepump: Removing the panel

Two pairs of hooks under the top panel hold the bottom panel. They mount into corresponding openings at the top side of the bottom panel.

Figure 3-4 shows the details for the right side of the instrument. The

panel hangs on the hooks and comes off if lifted up a little and getting pulled on into the backwards direction.

Figure 3-4. Hooks (left) and top side of detached bottom panel (right)

On the bottom of the rear side of the MS portion, two Allen screws fix the panel to the instrument frame by means of fork-like extensions

(lugs). See

Figure 3-5 on page 3-8 .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-7

User Maintenance

Maintenance of the Vacuum System

Figure 3-5. Lugs for fixing the bottom panel

To remove the panel

1. Use a 6 mm Allen wrench to loosen the screws that fix the bottom panel. Take care not to loosen the screws completely.

2. Pull the panel horizontally away from the instrument until it comes clear from the hooks.

3. Remove the panel from the instrument and store it at a safe place.

To reattach the panel, proceed in the reverse order.

Adding Oil to the ETD Forepump

The pump oil level must be between the MIN and MAX marks on the oil level sight glass for the pump to operate properly. Pump oil

(P/N A0301-15101) is added as needed when the oil level is below the

MIN mark on the oil level sight glass.

You can check the oil level by looking at the oil level sight glass, which is shown in

Figure 3-2 on page 3-6 . If the ETD forepump oil level is low,

follow these steps to add more oil.

To add oil to the ETD forepump

1. Shut down and vent the Orbitrap Elite ETD mass spectrometer.

Caution

Shut down and unplug the instrument before adding oil.

2. Remove the lower panel at the rear side of the ETD Module as

described on page 3-8

.

3. Remove one of the oil filler plugs from the rotary-vane pump.

Caution

To maintain optimal performance and prevent damage to the

ETD forepump, only use factory-approved rotary-vane pump oil.

4. Add fresh oil to the reservoir until the oil is half way between the

MIN and MAX level marks. If the oil level goes above the

3-8

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

User Maintenance

Maintenance of the Vacuum System

MAX level mark, remove the drain plug and drain the excess oil into a suitable container.

5. Insert the oil filler plug back into the rotary-vane pump.

6. Reattach the lower panel at the rear side of the ETD Module.

7. Plug in the instrument.

8. Restart the system.

Purging the Rotary-Vane Pump Oil

When the rotary-vane pump oil becomes cloudy or discolored, purge the oil. Purging (or decontaminating) the oil removes dissolved gases and low boiling-point liquids. You can purge the oil without interrupting system operation, but do not purge it during an acquisition or while the electron multiplier or filament is powered on.

To purge the rotary-vane pump oil

1. Remove the lower panel at the rear side of the ETD Module as described on

page 3-8 .

2. Set the gas ballast control (See Figure 3-2 on page 3-6

.) to Low

Flow (I).

3. Operate the pump for 10 minutes or until the oil is clear. If the oil remains cloudy or discolored after 10 minutes, replace the oil.

4. Set the gas ballast control to Closed (0), as shown in Figure 3-6

.

High Flow (Position II)

Low Flow (Position I)

Closed (Position 0)

Figure 3-6. Gas ballast control positions

5. Reattach the lower panel at the rear side of the ETD Module.

Changing the Rotary-Vane Pump Oil

You should change the ETD forepump oil every four months (about

3000 hours of operation).

Supplies needed for changing the ETD forepump oil:

Rotary-vane pump oil (P/N A0301-15101)

Suitable container for removing spent or excess oil

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-9

User Maintenance

Maintenance of the Vacuum System

Note For best results, change the oil while the ETD forepump is still warm after operation. Be careful, however, as the oil can still be very hot at this time.

Warning

Burn Hazard. Handle hot pump oil carefully to avoid being burned or injured.

To change the ETD forepump oil

1. Shut down and vent the Orbitrap Elite ETD mass spectrometer.

Caution

Shut down and unplug the instrument before adding oil.

2. Remove the lower panel at the rear side of the ETD Module as

described on page 3-8

.

3. Disassemble the rotary-vane pump.

a. Disconnect the foreline vacuum hose. (See Figure 3-2 on page 3-6 .)

b. Disconnect the exhaust vacuum hose.

c. Place the rotary-vane pump on a bench.

Warning

Lifting Hazard. Use the proper lifting technique to lift the

ETD forepump. It weighs approximately 23 kg (50 lb).

4. Drain the spent oil.

a. Remove one of the oil filler plugs.

b. Remove the oil drain plug and allow the oil to drain into a suitable container.

c. Dispose of the spent oil according to local environmental regulations.

d. Replace the oil drain plug.

5. Add fresh oil.

a. Add oil into oil filler reservoir half way between the MIN and

MAX level marks.

b. If the oil level goes above the MAX level mark, remove the drain plug and drain the excess oil from the pump.

3-10

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the Vacuum System

6. Reassemble the rotary-vane pump.

a. Replace the oil filler plug.

b. Return the rotary-vane pump to the floor.

c. Reconnect the foreline vacuum hose to the rotary-vane pump.

d. Reconnect the exhaust vacuum hose to the rotary-vane pump.

e. Plug in the rotary-vane pump.

7. Reattach the lower panel at the rear side of the ETD Module.

8. Plug in the instrument.

9. Restart the system.

Maintenance of the Turbomolecular Pumps

The turbomolecular pumps in the MS portion of the Orbitrap Elite mass spectrometer need maintenance work by the user that is briefly outlined below. In contrast, the turbomolecular pump in the

ETD Module of the Orbitrap Elite ETD mass spectrometer contains no user-serviceable parts.

Note The manuals of the pump manufacturers give detailed advice regarding safety, operation, maintenance, and installation. Please note the warnings and cautions contained in these manuals!

Replacing the Operating Fluid Reservoir of the Turbomolecular Pumps

The manufacturer recommends replacing the operating fluid reservoirs of the turbomolecular pumps at least every four years. The storage stability of the operating fluid is limited. The specification of durability is given by the pump manufacturer. The disposal of used oil is subject to the relevant regulations.

Replacements for the operating fluid reservoirs including Porex rods

(HiPace™ 80: P/N 1275740; HiPace™ 300: P/N 1275730) are available from Thermo Fisher Scientific.

Note The pump bearings have also to be replaced at least every four years. This maintenance operation requires special training and additional equipment. Therefore, Thermo Fisher Scientific recommends calling a Thermo Fisher Scientific field service engineer to replace both the operating fluid reservoir and the pump bearings.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-11

User Maintenance

Maintenance of the ETD Module

Maintenance of the ETD Module

This section describes routine ETD Module maintenance procedures that must be carried out to ensure optimum performance of the system.

Some of the procedures describe how to clean components of the

ETD Module. Others involve replacing components or replenishing the electron transfer reagent. See also the ETD Module Hardware Manual for additional information.

Figure 3-7

illustrates the sequence in which to perform routine maintenance on the ETD system.

Start

Remove

Ion Volume

Clean

Ion Volume

Clean

Ion Source

Lenses

?

No

Replace

Ion Volume

Yes

End

Vent

MS/ETD System

Remove

ETD Module

Covers

Remove

Vacuum Manifold

Cover

Remove

Ion Source from

Vacuum Manifold

Remove

Lenses

Clean

Lenses

Remove

Reagent Ion Source

Block Assembly

Disassemble

Reagent Ion Source

Block Assembly

Clean

Reagent Ion Source

Block Assembly

Reassemble

Reagent Ion Source

Block Assembly

Clean

Reagent Ion Source

Block Assembly

?

No

Yes

Clean

Remaining

Reagent Ion Source

Components

?

No

Yes

Disassemble

Remaining

Reagent Ion Source

Components

Clean

Remaining

Reagent Ion Source

Components

Reassemble

Remaining

Reagent Ion Source

Components

Reinstall

Reagent Ion Source

Block Assembly

Reinstall

Lenses

Reinstall

Reagent Ion Source

Replace

Vacuum Manifold

Cover

Reinstall

ETD Module

Covers

Start Up

MS/ETD System

Figure 3-7. Routine maintenance sequence for ETD system

Table 3-2 on page 3-13 gives advice for correcting frequent problems

with the ETD system.

3-12

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Table 3-2. Indications requiring maintenance of the ETD system

Symptom

No ions at m/z 202 with the emission current at the correct level.

The m/z 202 signal intensity drops slowly over several days when the emission current is at the correct level.

A system error message advising that the maximum injection time has been reached for the ETD AGC.

Sudden and complete drop of m/z 202 level, low emission current.

Cause

The m/z 202 is outside the mass range.

Fix

Set the starting mass lower.

The ion volume needs to be cleaned or replaced.

Clean or replace the ion volume when the injection time is over 100 ms. See

page 3-21 .

The AGC target has not been reached within the specified time limit. The ion volume needs to be cleaned or replaced.

Clean the ion volume. Increase the maximum injection time limit.

The filament may just have blown out.

Check the filament. Replace it if necessary.

See

page 3-42 .

Handling and Cleaning Reagent Ion Source Parts

A large part of maintaining your reagent ion source consists of making sure that all the components are clean. Use the cleaning procedures listed in this section to clean stainless steel and non-stainless steel parts.

However, use caution when doing so, because some components can be damaged by exposure to liquids.

How often you clean the reagent ion source depends on the amount of reagent introduced into the system. In general, the closer a component is to where the reagent ion is introduced, the more rapidly it becomes

dirty (see the footnote in Table 3-1 on page 3-2 ). For example, the ion

volume needs to be cleaned more often than other parts.

Many parts can be removed and disassembled by hand. Make sure you have all the necessary tools before carrying out a procedure. See below for a list of the tools and supplies generally needed for maintenance of the reagent ion source. Tools should be used only for the maintenance of the reagent ion source and be free of grease or other residues. Handle parts in a manner that maintains their cleanliness.

Note It is crucial that the cleanliness of the parts be maintained when they are handled. Wear gloves and place the parts on surfaces that are clean if the parts are not returned directly to the instrument. If clean surfaces are not available, place the parts on fresh lint free wipes or cloths or aluminum foil that has not been used for any other purpose.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-13

User Maintenance

Maintenance of the ETD Module

The following tools and supplies are needed for reagent ion source maintenance:

Clean, dry gas (air or nitrogen)

New, white nitrile clean room gloves (Fisher Scientific

P/N 19-120-2947B [size medium] or P/N 19-120-2947C [size large]; Thermo Scientific P/N 23827-0008 ) [size medium] or

P/N 23827-0009 [size large])

Lint-free cloth or paper

Nut driver, 5.5 mm

Protective eyewear

Screwdriver, Phillips #2

Screwdriver, flat blade

Wrench, adjustable

Wrench, Allen, 2 mm, 2.5 mm, 3 mm, 4 mm, 5/32-in., 5/64-in.,

1/16-in

Wrench, open-ended, 1/4-in., 5/16-in., 7/16-in. (2), 1/2-in.,

9/16-in.

Wrench, socket, 1/2-in.

Cleaning Stainless Steel Parts

The reagent ion source, ion volume assembly, ion source block, and lenses are made from stainless steel. To clean these parts, follow the procedure described in this topic. Use this procedure with caution because some components can be damaged when exposed to liquids.

The following tools and supplies are needed for cleaning stainless steel parts in the reagent ion source:

Acetone, analytical grade (or other suitable solvent)

Aluminum oxide abrasive, number 600 (P/N 32000-60340)

Applicators, cotton-tipped

Beaker, 450 mL

Clean, dry gas

De-ionized water

Detergent (Alconox®, Micro, or equivalent)

Dremel® rotary tool or equivalent (recommended)

3-14

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Foil, aluminum

Forceps

New, white nitrile clean room gloves

Glycerol, reagent grade

Lint-free cloth

Protective eyewear

Tap water

Toothbrush, soft

Ultrasonic cleaner

Caution

Do not use this procedure to clean ceramic, aluminum, or gold

plated parts. See page 3-17 for the method for cleaning ceramic,

aluminum, or gold plated parts.

Caution

Follow the subsequent instructions precisely. If done wrong, the cleaning procedure could damage the ion source lenses.

Warning

Hand and Eye Hazard. Wear impermeable laboratory gloves and eye protection when performing these cleaning procedures.

To clean reagent ion source stainless steel parts

1. Remove contamination from the surfaces being cleaned.

a. Use a slurry of number 600 aluminum oxide in glycerol and a cleaning brush or cotton-tipped applicator. Contamination often appears as dark or discolored areas, but may not be visible.

The heaviest contamination is usually found around the apertures, such as the electron entrance hole on the ion volume.

b. Clean each part thoroughly, even if no contamination is visible.

c. Use the wooden end of an applicator that is cut at an angle to clean the inside corners.

d. Use a Dremel® tool with the polishing swab at its lowest speed.

This will increase the cleaning efficiency and decrease the time required to clean the part.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-15

User Maintenance

Maintenance of the ETD Module

Warning

Injury Hazard. To prevent personal injury, be sure to keep the

Dremel tool away from possible hazards, such as standing water or flammable solvents.

2. Rinse the parts with clean water.

3. Use a clean applicator or toothbrush to remove the aluminum oxide slurry. Do not let the slurry dry on the metal because dried aluminum oxide is difficult to remove.

4. Place the parts in a warm detergent solution in an ultrasonic bath and sonicate them.

a. Make a solution of detergent and warm tap water in a 400 mL glass beaker.

b. Using forceps, place the parts in a beaker containing the warm detergent solution.

c. Place the beaker and contents in an ultrasonic bath for five minutes.

d. Rinse the parts with tap water to remove the detergent.

5. Sonicate the parts in deionized water.

a. Using forceps, place the parts in a beaker containing deionized water.

b. Place the beaker and contents in an ultrasonic bath for five minutes.

c. If the water is cloudy after sonicating, pour off the water, add fresh water, and place the beaker and its contents in a ultrasonic bath again for five minutes. Repeat until the water is clear.

6. Sonicate the parts in acetone.

a. Using forceps, place the parts in a beaker containing fresh acetone.

b. Place the beaker and contents in an ultrasonic bath again for five minutes.

7. Blow-dry the parts immediately. Use clean, dry gas (air or nitrogen) to blow the acetone off the parts.

8. Complete the drying process, doing one of the following:

Using forceps, place the parts in a 500 mL glass beaker, cover the beaker with aluminum foil, and put the beaker in an oven set at

100 °C for 30 minutes.

3-16

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Lay the parts on clean aluminum foil (dull side up) and allow to dry for 30 minutes.

9. Allow the parts to cool before reassembling them.

Cleaning Non-Stainless Steel or Hybrid Parts

To clean the stainless-steel portion of hybrid parts, follow step 1 and step 2 of the instructions on page 3-15 . Perform these steps only on the stainless-steel surfaces of hybrid parts. Do not allow the aluminum oxide slurry to contact the aluminum, ceramic, or gold plated portions of these parts.

Warning

Hand and Eye Hazard. Wear impermeable laboratory gloves and eye protection when performing these cleaning procedures.

The reagent ion source heater ring, filament spacer, lens holder, and spacers are non-stainless steel parts that are made from aluminum, ceramic, or are gold plated.

To clean the non-stainless-steel portions of hybrid parts

1. Scrub all of the parts with a warm detergent solution.

a. Make a solution of detergent and warm tap water in a 500 mL glass beaker.

b. Dip a clean cotton-tipped applicator in the detergent mixture and use the applicator to scrub the parts.

Note Do not soak or sonicate the parts in detergent.

▲ c. Using forceps, rinse the parts thoroughly with tap water to remove the detergent.

Caution

Do not leave aluminum parts, such as the heater ring, in the detergent. Basic solutions, like detergent, damage the surface of aluminum.

2. Rinse the parts in deionized water. Using forceps, dip the parts in a beaker of deionized water. Change the water if it becomes cloudy.

Do not soak or sonicate the parts.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-17

User Maintenance

Maintenance of the ETD Module

3. Rinse the parts with acetone. Using forceps, dip the parts in a beaker of acetone. Change the acetone if it becomes cloudy. Do not soak or sonicate the parts.

4. Blow-dry the parts immediately. Use clean, dry gas (air or nitrogen) to blow the acetone off the parts.

Removing the Access Panels

During some ETD Module maintenance activities, it is necessary to remove either the ETD main access panel, or the side access panel, or both (see

Figure 3-8 ). Follow the subsequent procedures to remove these

panels.

7

8

6

9

5

4

3

2

1

Labeled components: 1=ETD main access panel, 2=side access panel, 3=inlet valve knob, 4=inlet valve lever (down is closed, up is open), 5=inlet valve plug, 6, 7, 8, 9=panel fasteners.

Figure 3-8. Rear view of the ETD Module

Removing the ETD Main Access Panel

To remove the ETD main access panel

1. Place the ETD Module to Service mode as directed in

“Placing the

Instrument in Off Condition and Service Mode” on page 3-48 .

3-18

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Note In Service mode, all power to the Orbitrap Elite ETD MS electronics is turned off. There are no user accessible components that carry a voltage in this mode. However, the vacuum pumps continue to operate.

Warning

Burn Hazard. The reagent vial heaters can be 108 °C (or set point); the transfer line, the restrictor, and the ion source can be at

160 °C. These components may be too hot to touch. Verify that all of these components are safe to touch before handling them.

Note The ETD main access panel is interlocked with the ETD Module power. When the ETD main access panel is removed, all power to the

ETD Module will be turned off. However, the mechanical pump and turbo pump will continue operating.

2. Remove the inlet valve lever (item 4 in Figure 3-8 on page 3-18

) by pulling it down and away from the ETD Module main access panel.

Do not rotate the lever upwards. It must remain in its down (closed) position to avoid catastrophic venting of the system.

Caution

Rotating the inlet valve lever upwards (to the open position) without the inlet valve plug (item 5 in

Figure 3-8 ) or the ion volume

tool in place will cause a catastrophic venting of the system.

3. Unscrew the inlet valve knob (item 3 in Figure 3-8

) and remove the inlet valve plug (item 5 in

Figure 3-8 ), the inlet valve knob, and the

internal ferrule.

4. Loosen the four panel fasteners (items 6, 7, 8, and 9 in Figure 3-8 ).

5. The top panel rests on hooks pointing into the upward direction.

Tilt the top panel towards you and lift it up and away from the

ETD Module.

Removing the ETD Side Access Panel

To remove the ETD side access panel

1. If it is not already in Service mode, place the ETD Module in

Service mode as directed in

“Placing the Instrument in Off

Condition and Service Mode” on page 3-48

.

Note In Service mode, all power to the Orbitrap Elite ETD MS electronics is turned off. There are no user accessible components that carry a voltage in this mode. However, the vacuum pumps continue to operate.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-19

User Maintenance

Maintenance of the ETD Module

Warning

Burn Hazard. The reagent vial heaters can be at 108 °C (or set point); the flow restrictor, the transfer line heaters, and the ion source heater can be at 160 °C. These components may be too hot to touch.

Verify that all of these components are safe to touch before handling them.

Note The ETD side access panel is interlocked with the ETD Module power. When the ETD side access panel is removed, all power to the

ETD Module will be turned off. However, the mechanical pump and turbomolecular pump will continue operating.

2. Using an Allen wrench, loosen the captive screws at the top and remove the screws at the bottom of gray plastic side panel and remove the panel.

3. Using a #2 Phillips screwdriver, loosen the three captive screws on

the metal side access panel (item 2 in Figure 3-8 on page 3-18

) and remove the panel.

Warning

Burn Hazard. Reagent vial heaters, ion source heater, flow restrictor, and transfer lines are accessible under the ETD side access panel. These are heated components. Verify that they are safe to touch before handling them.

Replace the panels by following the above steps in reverse order and reversing the instructions in each step.

Maintenance of the Reagent Ion Source

The reagent ion source consists of an ion volume, filament, and ion source lenses. Because the ion volume is exposed directly to samples introduced into the reagent ion source, it requires the most frequent cleaning. You can access the ion volume assembly with or without an inlet valve.

To restore system performance, always clean the ion volume first, then the ion source lenses. If cleaning either of these components does not restore system performance, try cleaning the entire reagent ion source.

This section contains these maintenance procedures:

“Cleaning the Ion Volume With an Inlet Valve” on page 3-21

“Cleaning the Ion Source Lens Assembly” on page 3-33

“Cleaning the Ion Source Block” on page 3-40

“Replacing the Ion Source Filament” on page 3-42

3-20

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

“Replacing Inlet Valve Components” on page 3-45

The ion source, the ion trap, and their components are shown in

Figure 3-9 .

2

3

4

1

6

5

Labeled components: 1=ion source lenses, 2=filament assembly, 3=ion source block, 4=magnet support, 5=magnets, 6=ion volume (inside the ion source block, 3)

Figure 3-9. Ion source components (left view)

Cleaning the Ion Volume With an Inlet Valve

The ion volume is where molecules interact with energetic electrons to form ions. Because the ion volume is exposed directly to reagents introduced into the reagent ion source, you will have to clean it more frequently than other parts. How often you have to clean the ion volume assembly will depend on the types and amounts of reagents used.

For cleaning the ion volume with an inlet valve, the following tools and supplies are needed:

Cleaning supplies for stainless steel parts (See “Cleaning Stainless

Steel Parts” on page 3-14 .)

Gloves (clean, lint-free, and powder-free)

Ion volume tool and guide bar

Lint-free cloth

Using the ion volume tool allows you to access the ion volume by entering the vacuum manifold through the inlet valve without venting the instrument.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-21

User Maintenance

Maintenance of the ETD Module

On

On/Standby button

Off Standby

To clean the ion volume with an inlet valve

1. Click the On/Standby button in the Tune Plus window to place the

Orbitrap Elite ETD mass spectrometer in Standby mode. See

Figure 3-10

.

Reagent Ion Source instrument control icon

Status View

Figure 3-10. Tune Plus window (Orbitrap Elite ETD)

2. Open the Reagent Ion Source dialog box (

Figure 3-17 on page 3-26

) in Tune Plus by clicking the Reagent Ion Source instrument control icon.

3. Place the guide bar handle (item 13 in

Figure 3-11 on page 3-23

) to the 3 o’clock position (

Figure 3-12 on page 3-23 ).

3-22

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

1

2

3

4

5

12

11

10

9

8

13

7

6

Labeled components: 1=alignment line, 2=lock position, 3=unlock position,

4=ion volume tool, 5=bayonet lock, 6=second stop, 7=guide ball track, 8=first stop, 9=guide bar, 10=guide ball hole, 11=guide ball, 12=ion volume tool handle, 13=guide bar handle

Figure 3-11. Ion volume tool components

4. Insert the guide bar (item 9 in Figure 3-11

) into the guide bar opening in the back of the ETD Module (

Figure 3-12 ).

Inlet valve lever in down (closed) position

Guide bar handle Guide bar opening

Figure 3-12. Guide bar being inserted into guide bar opening a a

Guide bar handle is facing to the right. The inlet valve is closed when the inlet valve lever is in the down position and open when it is in the up position.

5. Push the guide bar in as far as it will go, then rotate it 90° clockwise to lock in the guide bar (

Figure 3-13 on page 3-24 ). The guide bar

handle faces the floor at the completion of this step.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-23

User Maintenance

Maintenance of the ETD Module

Inlet valve lever in down (closed) position

Guide bar handle

Figure 3-13. Guide bar insertion complete a a

Guide bar handle is facing the floor. The inlet valve is closed when the inlet valve lever is in the down position and open when it is in the up position.

6. Prepare the inlet valve and ion volume tool for insertion.

3

4

5

1

2

Labeled components: 1=inlet valve knob, 2=inlet valve plug, 3=inlet valve lever (down is closed, up is open), 4= guide bar opening, 5=main access panel

Figure 3-14. Rear view of the ETD Module, showing the inlet valve

Make sure the inlet valve is closed (inlet valve lever is down, as shown in

Figure 3-13

) and remove the inlet valve plug (item 2 in

Figure 3-14

). Do this by rotating (loosening) the inlet valve knob

3-24

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

(item 1 in Figure 3-14 on page 3-24

) until the inlet valve plug will slide out easily. The inlet valve plug prevents air from entering the vacuum manifold in case the inlet valve is inadvertently opened.

7. Turn the ion volume tool handle to the unlock position, which indicates that the ion volume tool is in position to accept the ion

volume. See Figure 3-15

.

Thermo Fisher Scientific

Figure 3-15. Ion volume tool handle in the unlock position

8. Insert the ion volume tool and evacuate the inlet valve: a. Insert the guide ball into the guide ball hole.

5

7

1

2

6

4

3

Labeled components: 1=ion volume tool entry housing, 2=inlet valve opening,

3=first stop, 4=guide bar, 5=ion volume tool, 6=inlet valve lever, 7=inlet valve knob

Figure 3-16. Ion volume tool guide bar first stop

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-25

User Maintenance

Maintenance of the ETD Module b. Slide the ion volume tool forward in the guide bar track until the guide ball is at the guide bar’s first stop, which is shown in

Figure 3-11 on page 3-23

and

Figure 3-16 on page 3-25 .

c. Slide the ion volume tool so the guide ball is in the groove at the first stop (

Figure 3-11 and

Figure 3-16

). This prevents the probe from being pulled forward when the inlet valve is evacuated.

d. Tighten the inlet valve knob ( Figure 3-16 ) to ensure that a

leak-tight seal is made.

e. Click Open Probe Interlock in the Reagent Ion Source dialog

box ( Figure 3-17 ). A message box appears stating that the probe

interlock is being pumped down. The target pressure is

<0.1 mTorr. If a pressure of 0.1 mTorr or less is not obtained, replace the inlet valve seal as described in

“Replacing Inlet Valve

Components” on page 3-45

. When the target pressure is achieved, a message appears stating that the ball valve can be opened (

Figure 3-18

).

Open Probe Interlock

Figure 3-17. Reagent Ion Source dialog box, Open Probe Interlock button.

Figure 3-18. Instrument Message box: The Ball Valve can now be opened

3-26

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module f. Once evacuation is complete, push up the inlet valve lever to open the inlet valve (

Figure 3-19 ).

9. Remove the ion volume: a. Slide the ion volume tool into the vacuum manifold until the tip of the ion volume tool is fully inserted into the ion volume holder, as shown in

Figure 3-19 .

1

6

5

2

4

3

Labeled components: 1=ion volume tool, 2=inlet valve opening, 3=guide bar,

4=second stop, 5=inlet valve lever in open (up) position, 6=inlet valve knob

Figure 3-19. Ion volume tool inserted into the inlet valve

Thermo Fisher Scientific second mark second stop first mark Guide Ball

Figure 3-20. Detail of ion volume tool fully inserted into the inlet valve

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-27

User Maintenance

Maintenance of the ETD Module

You will know that the ion volume tool is fully inserted into the

ion volume holder because the guide ball (item #11, Figure 3-11 on page 3-23

) will be just past the first mark on the guide bar as shown in

Figure 3-20 on page 3-27 .

b. Turn the ion volume tool handle counterclockwise to the lock position, See

Figure 3-21 . Listen for a click indicating that the

handle is fully engaged in the lock position and is holding the ion volume.

Figure 3-21. Ion volume tool handle in the locked position c. Withdraw the ion volume tool (the ion volume is attached) until the guide ball reaches the first stop (see

Figure 3-11 on page 3-23 and

Figure 3-16 on page 3-25 for the first stop

position).

d. Close the inlet valve by pushing the lever down.

Caution

Do not withdraw the ion volume tool beyond the point where the guide ball reaches the first stop in the guide bar. Close the inlet valve before withdrawing the ion volume tool past the first stop. Otherwise, the system will vent to the atmosphere and cleaning the components that are under vacuum will be required.

e. Loosen the inlet valve knob ( Figure 3-19 on page 3-27

).

f. Continue withdrawing the ion volume tool completely from the inlet valve by sliding the ion volume tool through the guide ball track in the guide bar.

Warning

Burn Hazard. The ion volume will be too hot to touch. Let it cool to room temperature before handling it.

3-28

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

10. Clean the ion volume: a. Turn the ion volume tool handle to the unlock position

( Figure 3-15 on page 3-25

). The ion volume tool handle unlock position icon is shown at the left.

b. Remove the ion volume from the ion volume tool. Using clean gloves, press the ion volume into the tip of the ion volume tool and rotate it to disconnect the bayonet pins from the pin guides.

Pull the ion volume out of the ion volume tool, as illustrated in

Figure 3-22 .

Bayonet Pin

Bayonet Pin Guide

Ion Volume Tool

Ion Volume Holder

Spring Washer

Ion Volume

Figure 3-22. Ion volume assembly c. Press the ion volume into the ion volume holder and rotate the ion volume to remove it from the ion volume holder See

Figure 3-23 .

Thermo Fisher Scientific

Figure 3-23. Separating ion volume and ion volume holder d. Clean ion volume and ion volume holder according to the instructions in

“Cleaning Stainless Steel Parts” on page 3-14 .

To reinsert the ion volume

1. Press the ion volume into the ion volume holder and rotate the ion volume to secure it to the ion volume holder.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-29

User Maintenance

Maintenance of the ETD Module

2. Place the clean ion volume on the ion volume tool: a. Place the ion volume into the bayonet lock located on the ion volume tool. Make sure that the alignment arrows on the ion volume and ion volume tool are facing each other. See

Figure 3-24

.

Caution

To avoid damage to the ion source, ensure that the arrows on the ion volume tool and ion volume are aligned.

4

1

2

3

5

6

7

Labeled components: 1=ion volume alignment arrow, 2=bayonet pin,

3=bayonet lock, 4=ion volume tool alignment arrow, 5=bayonet guide, 6=ion volume tool, 7=ion volume

Figure 3-24. Placing the ion volume on the ion volume tool

Note Wear clean, lint-free, and powder-free gloves when you handle parts inside the vacuum manifold.

▲ b. Turn the ion volume tool handle to the lock position. (See

Figure 3-21 on page 3-28

.)

3. Insert the ion volume tool and evacuate the inlet valve: a. Insert the guide ball into the guide ball hole and slide the ion volume tool forward in the guide bar track until the guide ball is at the guide bar’s first stop (see

Figure 3-11 on page 3-23 and

Figure 3-16 on page 3-25

).

b. Turn the ion volume tool so that the guide ball is in the groove at the first stop (

Figure 3-16 on page 3-25 ). This prevents the

3-30

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module probe from being pulled forward when the inlet valve is evacuated.

c. Tighten the inlet valve knob to ensure a leak-tight seal

( Figure 3-19 on page 3-27

).

d. Click Open Probe Interlock in the Reagent Ion Source dialog

box ( Figure 3-17 on page 3-26

). A message box will appear stating that the probe interlock is being pumped down. The target pressure is <0.1 mTorr. If a pressure of 0.1 mTorr or less is not obtained, the inlet valve seal must be replaced as described

in “Replacing Inlet Valve Components” on page 3-45 . When the

target pressure is achieved, a message will appear stating that the ball valve can be opened. See

Figure 3-18 on page 3-26 .

e. Once evacuation is complete, push the inlet valve lever up to open the inlet valve. See

Figure 3-19 on page 3-27 .

4. Reinsert the ion volume: a. Slide the ion volume tool into the vacuum manifold, as illustrated in

Figure 3-19 .

b. Listen for a click indicating that the ion volume has connected with the ion source block. The guide ball will be slightly beyond the second stop on the guide bar. See

Figure 3-20 on page 3-27 .

c. Turn the ion volume tool handle to the unlock position. See

Figure 3-25 .

Thermo Fisher Scientific

Figure 3-25. Ion volume tool handle in the unlock position i.

Withdraw the ion volume tool away from the ion volume about 2.5 cm (1 in) and turn the ion volume tool handle to

the lock position. See Figure 3-26 on page 3-32

.

ii. Slide the ion volume tool back into the vacuum manifold until the end of the ion volume tool just touches the ion volume.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-31

User Maintenance

Maintenance of the ETD Module iii. If the ion volume tool does not go into the inlet valve completely, the ion volume is not seated properly.

d. Withdraw the ion volume tool until the guide ball reaches the first stop (see

Figure 3-11 on page 3-23 and

Figure 3-16 on page 3-25 ).

Figure 3-26. Ion volume tool handle in the locked position e. Close the inlet valve by pushing down on the inlet valve lever

(

Figure 3-14 on page 3-24 ).

Caution

Do not withdraw the ion volume tool beyond the point where the guide ball reaches the first stop in the guide bar. Close the inlet valve before withdrawing the ion volume tool past the first stop. Otherwise, the system vents to the atmosphere.

f. Loosen the inlet valve knob (item 6 in Figure 3-19 on page 3-27 ).

g. Continue withdrawing the ion volume tool completely from the inlet valve by sliding the ion volume tool through the guide ball track in the guide bar.

5. Remove the ion volume tool and guide bar from the vacuum manifold: a. Remove the guide bar by rotating it 90 degrees counter-clockwise and sliding it out of the entry housing.

b. Replace the inlet valve plug and tighten the inlet valve knob

(item 6 in

Figure 3-19 on page 3-27 ).

c. Click Close in the message stating that the ball valve can be opened. (See

Figure 3-18 on page 3-26 .)

6. Re-tune the MS detector.

3-32

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Note Tune Plus provides an evaluation procedure for CI gas pressure under Diagnostics > Diagnostics > Tools > System evaluation >

Reagent CI gas pressure evaluation. Thermo Fisher Scientific recommends performing this procedure after replacing the filament and/or the ion volume.

Cleaning the Ion Source Lens Assembly

If cleaning the ion volume did not restore system performance, try cleaning the ion source lens assembly. The ion source lens assembly comes in direct contact with reagent ions introduced into the

ETD Module and needs to be cleaned periodically (though not as often as the ion volume).

To clean the ion source lens assembly

1. Prepare the ETD Module for maintenance: a. Prepare a clean work area by covering the area with a clean lint-free cloth.

b. Shut down and vent the ETD Module. (See

“Shutting Down the Instrument” on page 2-7 .)

Caution

Shut down and unplug the Orbitrap Elite ETD mass spectrometer before proceeding with the next steps of this procedure.

Note Wear clean, lint- and powder-free gloves when you handle parts inside the vacuum manifold.

Warning

Burn Hazard. The ion source may be too hot to touch even if the cooling nitrogen has completed its cycle. Be sure that the ion source has cooled to room temperature before handling it.

2. Remove the ion source assembly: a. Remove the main access panel of the ETD Module (item 1 in

Figure 3-8 on page 3-18 ). Follow the procedures in “Removing the ETD Main Access Panel” on page 3-18 .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-33

User Maintenance

Maintenance of the ETD Module

Caution

It is good practice to keep the inlet valve lever in the down

(closed) position whenever it is not explicitly required to be in the up position (open), even if the vacuum manifold is at atmospheric pressure.

This is to be consistent with maintenance procedures that rely on the inlet valve lever being closed at the appropriate step to prevent the accidental loss of vacuum. If the vacuum is accidently lost the system may be damaged. At a minimum, the components that were under vacuum might have to be cleaned.

Labeled components: 1=inlet valve plug, 2=vacuum manifold, 3=inlet valve lever, 4=guide bar, 5=entry housing, 6=inlet valve knob, 7=inlet valve block,

8=foreline hose connection, 9=12 pin feedthrough, 10=vacuum manifold probe plate, 11=ball valve housing, 12= inlet valve solenoid

Figure 3-27. Inlet valve components (ion volume tool not shown) b. Remove all connectors between the components on the vacuum manifold probe plate (item #10,

Figure 3-27 on page 3-34 ) and

the ETD Control PCB (

Figure 1-17 on page 1-22 ).

c. Remove the valve shield from the vacuum manifold probe plate

(

Figure 3-28 ) by loosening the four screws at the corners of the

shield.

3-34

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

1

Figure 3-28. Valve shield (1) covering the vacuum manifold probe plate d. Remove the foreline hose on the source from its connection

( Figure 3-29

and item 8 in Figure 3-27

).

Thermo Fisher Scientific

Figure 3-29. Removing the foreline hose from its connection e. Remove the four screws holding the vacuum manifold probe

plate ( Figure 3-30

and item 10 in Figure 3-27 on page 3-34

).

Support the plate with your hand as shown in

Figure 3-30 .

Arrows point to the four hex screw locations (items 1–4).

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-35

User Maintenance

Maintenance of the ETD Module

1 2

4 (at lower left corner of manifold probe plate)

3

Figure 3-30. Unscrewing the vacuum manifold probe plate f. Remove the vacuum manifold probe plate (

Figure 3-31 on page 3-36 ).

Figure 3-31. Removing the vacuum manifold probe plate g. Unplug the 12-pin feedthrough harness from the feedthrough

(

Figure 3-32 ).

3-36

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

1 2 3

User Maintenance

Maintenance of the ETD Module

4 2

Labeled components: 1=unplugged 12 pin feedthrough, 2=thumbscrews,

3=transfer line bellows, 4=ion source assembly

Figure 3-32. Interior of vacuum manifold h. Remove the ion source assembly from the vacuum manifold

( Figure 3-33 on page 3-38

) by first loosening the ion source thumbscrews (item 2 in

Figure 3-32 ).

i.

Second, as you remove the ion source assembly (item 1 in

Figure 3-33 ) gently shift it to the left (arrow 2 in Figure 3-33

) before and while pulling it out. This will allow the ion source assembly to disengage from the transfer line bellows (item 3 in

Figure 3-33 ) as it is removed. Alternatively, gently depress the

transfer line bellows (

Figure 3-32 on page 3-37 ) to disengage it

from the ion source assembly.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-37

User Maintenance

Maintenance of the ETD Module

1 3

2

Figure 3-33. Removing the ion source assembly from the vacuum manifold a a

The ion source assembly (item 1) is gently shifted to the left (arrow 2) to allow the ion source assembly to disengage from the transfer line bellows (item 3) as it is removed.

The ion source assembly is held together with a clip (item 8 in

Figure 3-34 on page 3-39

). However, it is necessary to keep the tips of your gloved fingers on both the front edge of the ceramic lens holder

(item 11 in

Figure 3-34 ) and the back of the magnet yoke (item 3 in

Figure 3-34

) when you handle the ion source assembly. This prevents unsecured components inside of the ceramic lens holder from falling out.

Caution

When handling the ion source assembly, it is important to handle it with gentle finger pressure on each end (as instructed above) to keep unsecured components from falling out of the assembly.

3-38

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

1 2 3 4 5 6

User Maintenance

Maintenance of the ETD Module

11

10 1 2 3 5 9 8 7

Labeled components: 1=thumbscrew, 2=springs, 3=magnet yoke, 4=Ion

Source PCB, 5=magnets, 6=ion source block, 7=ceramic lens holder, 8=spring clip, 9=spring clip thumb screw, 10=12 pin feedthrough harness, 11=finger over front edge of ceramic lens holder to keep unsecured components from falling out of the ion source assembly.

Figure 3-34. Ion source assembly

An exploded view of the ion source assembly is shown in Figure 3-35

.

5 4 3

2

1

8 7 6 5 3

Labeled components: 1=thumbscrews, 2=springs, 3=E-clips , 4=magnet yoke,

5=magnets, 6=ion source, 7=ion source lens assembly, 8=ceramic lens holder

Figure 3-35. Ion source assembly exploded view

3. Separate the magnet yoke and the ion source.

4. Remove the ion source lens assembly from the ceramic lens holder

( Figure 3-35

).

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-39

User Maintenance

Maintenance of the ETD Module

5. Clean the ion source lens assembly according to the procedure in

“Cleaning Stainless Steel Parts” on page 3-14 . Pay particular

attention to the areas inside the tube and around the holes in the lens assembly.

6. Replace the ion source assembly: a. Insert the lens assembly into the ceramic lens holder.

b. Reassemble the ion source assembly.

c. Reinstall the ion source assembly into the vacuum manifold by following step 2 in reverse order.

7. Restore the ETD Module to operational status. See

“Starting Up the

System after a Shutdown” on page 2-9

.

Cleaning the Ion Source Block

If cleaning the ion volume and ion source lens assembly does not restore system performance, you might need to clean the ion source block.

Generally, you need to clean the ion source block no more than once every six months.

Supplies needed for cleaning the ion source:

Cleaning supplies

Gloves (clean, lint-free, and powder-free)

Lint-free cloth

To clean the ion source block

1. Prepare the ETD Module for maintenance: a. Prepare a clean work area by covering the area with lint-free cloth.

b. Shut down and vent the Orbitrap Elite ETD mass spectrometer.

(See “Shutting Down the Orbitrap Elite Mass Spectrometer

Completely” on page 2-7 .)

Caution

Shut down and unplug the Orbitrap Elite ETD mass spectrometer before proceeding with the next steps of this procedure.

▲ c. Remove the ion source assembly by following the procedures in step 2

in “Cleaning the Ion Source Lens Assembly” on page 3-33 .

Note Wear clean, lint- and powder-free gloves when you handle parts inside the vacuum manifold.

3-40

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

2. Disassemble the ion source assembly ( Figure 3-34 on page 3-39 and

Figure 3-35 on page 3-39 ), remove and disassemble the ion source

( Figure 3-36

).

a. Remove the magnet yoke and the ion source block with the ion source lens assembly.

b. Remove the ion source lens assembly.

c. Remove the ion source.

1

3

2

14

13

12

9

5

4

2

6

8

7

10

11

Labeled components: 1=ion source filament, 2=cartridge heaters, 3=base studs (3×), 4=Ion Source PCB, 5=temperature sensor, 6=ion source block,

7=ion volume key thumbscrew, 8=ion volume pin, 9=ion volume, 10=spring clip, 11=spring clip thumb screw, 12=heater ring, 13=sample inlet aperture (in side of item 6), 14=ceramic spacer

Figure 3-36. Ion source, exploded view

d. Remove the three base studs (item 3 in Figure 3-36

). Be careful not to damage the leads on the Ion Source PCB (item 4 in

Figure 3-36 ).

e. Gently remove the Ion Source PCB (item 4 in

Figure 3-36 ) from

the ion source by loosening the spring clip thumbscrew (item 11 in

Figure 3-36 ) and the spring clip (item 10 in Figure 3-36 ) and

sliding the three cartridge heaters and the temperature sensor

(items 2 and 5 in

Figure 3-36 ) off the ion source and pulling the filament (item 1 in Figure 3-36 ) straight away from the three

filament connectors on the Ion Source PCB. Do not bend or twist the cartridge heaters or temperature sensor.

f. Remove the filament and ceramic spacer (items 15 and 1 in

Figure 3-36 ) from the ion source block (item 6 in Figure 3-36 ).

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-41

User Maintenance

Maintenance of the ETD Module

g. Remove the ion volume key thumbscrew (item 7 in Figure 3-36 on page 3-41

).

Note It is not necessary to remove the ion volume pin (item 8 in

Figure 3-36 ). If you remove it, you should reinsert it just far enough so

the ball will keep an ion volume (item 9 in

Figure 3-36 ) from falling

out. If the ball extends too far, the ion volume will be difficult to remove.

3. Clean the ion source parts and replace the ion source assembly: a. Clean each component of the ion source, as described in

“Cleaning Stainless Steel Parts” on page 3-14 and

“Cleaning

Non-Stainless Steel or Hybrid Parts” on page 3-17

.

b. Reassemble the ion source block.

c. Reassemble the ion source assembly.

d. Reinstall the ion source assembly into the vacuum manifold by following step 2

of “Cleaning the Ion Source Lens Assembly” on page 3-33 in reverse order.

4. Restore the ETD Module to operational status. See

“Starting Up the

System after a Shutdown” on page 2-9

.

Replacing the Ion Source Filament

The number of ions produced in the ion source is approximately proportional to the filament emission current. If you notice that ion production is low, this might indicate that the filament has failed and needs to be replaced. If the measured emission current is substantially less than the value that the emission current is set to, or if the measured emission current is decreasing over time, then the filament has failed or is failing and needs to be replaced. The ion source filament assembly is shown in

Figure 3-37 on page 3-43 .

Supplies needed for replacing the ion source filament:

Filament Assembly DSQ II (P/N 120320-0030)

Gloves, clean, lint-free, and powder-free

Protective eyewear

Lint-free cloth

Forceps or dental pick

3-42

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Thermo Fisher Scientific

5

User Maintenance

Maintenance of the ETD Module

3

4

1

2

Labeled components: 1=ion source lens assembly, 2=ion source block, 3=Ion

Source PCB, 4=base studs (3x), 5=ion source filament

Figure 3-37. Ion source lens assembly and ion source

To replace the ion source filament

1. Prepare the ETD Module for maintenance.

a. Prepare a clean work area by covering the area with lint-free cloth.

b. Shut down and vent the Orbitrap Elite ETD mass spectrometer.

(See

“Shutting Down the Orbitrap Elite Mass Spectrometer

Completely” on page 2-7

.)

Caution

Shut down and unplug the Orbitrap Elite ETD mass spectrometer before proceeding with the next steps of this procedure.

▲ c. Remove the ion source assembly by following the procedures in step 2 in

“Cleaning the Ion Source Lens Assembly” on page 3-33

.

Note Wear clean, lint- and powder-free gloves when you handle parts inside the vacuum manifold.

2. Disassemble the ion source assembly ( Figure 3-34 on page 3-39 and

Figure 3-35 on page 3-39 ), remove and disassemble the ion source

( Figure 3-36 on page 3-41

).

a. Remove the ion source lens assembly (item 1 in Figure 3-37

).

b. Remove the three base-studs (item 3 in Figure 3-36

, item 4 in

Figure 3-37 ).

c. Remove the filament assembly (items 1 and 15 in

Figure 3-36

,

item 5 in Figure 3-37 ) and ion source block (item 2 in

Figure 3-37 ) from the three filament connectors and cartridge

heaters (item 2 in

Figure 3-36 ) on the Ion Source PCB (item 4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-43

User Maintenance

Maintenance of the ETD Module in

Figure 3-36 ) according to the procedure in step e

of

“Cleaning the Ion Source Block“ on

page 3-41 .

Note Now is a good time to clean the ion volume and ion source lenses.

3. Inspect and install a new filament assembly: a. Turn the filament assembly over and, using a strong light and a magnifying glass, verify that the filament wire is centered in the electron lens hole. If necessary, carefully use forceps (or a dental pick) to adjust the filament wire.

Figure 3-38 shows the centered

filament wire as seen from the bottom of the filament through the electron lens hole.

Note A bent filament can lead to a low or absent anion signal. If the filament wire is bent, not centered, or otherwise damaged, you must replace the filament assembly.

Centered wire

Direction of light source

Figure 3-38. Filament wire as seen from the bottom of the filament through the electron lens hole b. Insert the filament into the ceramic spacer of the ion source

block (item 14 in Figure 3-36 on page 3-41

).

c. Align the filament leads with the Ion Source PCB connectors and gently press the leads into the connectors. Normally, there is a small gap (about 0.020 in or 0.50 mm) between the filament and the connectors. The gap allows the ceramic filament centering ring (spacer) to properly position and align the electron lens hole with the ion volume.

d. Reinstall the three base-studs (item 3 in

Figure 3-36

, item 4 in

Figure 3-37 on page 3-43

).

4. Reassemble ion source and ion source assembly.

5. Insert the ion source assembly into the vacuum manifold.

3-44

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

6. Restore the ETD Module to operational status. See “Starting Up the

System after a Shutdown” on page 2-9 .

Note Tune Plus provides an evaluation procedure for CI gas pressure under Diagnostics > Diagnostics > Tools > System evaluation >

Reagent CI gas pressure evaluation. Thermo Fisher Scientific recommends performing this procedure after replacing the filament and/or the ion volume.

Replacing Inlet Valve Components

This topic provides the procedure for replacing inlet valve components.

Perform this procedure when the inlet valve seal or the inlet valve is being replaced.

Tools and supplies needed for replacing inlet valve components:

Inlet Valve Seal Kit (P/N 119265-0003)

Lint-free cloth

Wrench, open-ended, 5/16-in

Wrench, Allen, 4 mm

To replace inlet valve components

1. Pull down the inlet valve lever to close the inlet valve. See

Figure 3-39 .

Inlet valve knob

Thermo Fisher Scientific

Inlet valve plug

Inlet valve lever in the down (closed) position

Guide bar opening

Figure 3-39. Inlet valve components

2. Rotate the inlet valve knob counter-clockwise until you can easily remove the inlet valve plug.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-45

User Maintenance

Maintenance of the ETD Module

3. Continue to rotate the valve knob until you can remove it.

The inlet valve knob has a stainless-steel ferrule inside. Keep the inlet valve knob and ferrule together.

4. Pull out the knob on the inlet valve seal tool (P/N 119283-0001)

1

, so that the knob is loose. See

Figure 3-40

.

Knob

Figure 3-40. Inlet valve seal tool

5. Insert the tool straight into the inlet valve. See

Figure 3-41 .

Figure 3-41. Inlet valve seal tool inserted in the inlet valve

Caution

Do not scratch the surface of the seal. Use only the inlet valve seal tool to remove or install an inlet valve seal.

6. Press in the knob on the tool until it stops.

7. Remove the tool. The inlet valve seal should be on the tool. See

Figure 3-42 on page 3-47

.

1

Item contained in Inlet Valve Seal Kit (P/N 119265-0003).

3-46

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Figure 3-42. Inlet valve seal on the inlet valve seal tool

8. Loosen the knob to disengage the seal. See

Figure 3-43 .

Inlet valve seal with O-rings

Inlet valve seal

Figure 3-43. Inlet valve seal disengaged from tool

9. Discard the seal with its O-rings in place.

10. Place one O-ring (P/N 3814-6530)

1

into each of the two slots on the inlet valve seal (P/N 119683-0100)

1

.

11. Place the new inlet valve seal onto the inlet valve seal tool.

12. Insert the inlet valve seal tool into the inlet valve into it stops.

13. Remove the tool. The O-rings on the valve seal secure the inlet valve seal in the opening.

14. Reinstall the ferrule, knob, and plug into the inlet valve opening.

Thermo Fisher Scientific

1

Item contained in Inlet Valve Seal Kit (P/N 119265-0003).

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-47

User Maintenance

Maintenance of the ETD Module

Replacing the Reagent Vials

A significant drop of the m/z 202 signal within one hour with the mission current at the correct level indicates a low reagent supply. In this case, you should replace the fluoranthene vial.

Changing the reagent vials requires that the Orbitrap Elite ETD mass spectrometer be placed in Service mode after the vials have cooled. (Vial cooling is done in Off condition.) See the following sections for procedures to be used to change the reagent vials:

“Placing the Instrument in Off Condition and Service Mode” on page 3-48

“Installing/Exchanging the Reagent Vials” on page 3-51

The ETD reagent vials are designed to keep the ETD reagent out the lab environment. Removal and replacement of the ETD reagent vials when they are not empty causes excessive puncturing of the septums and reduces their integrity. This could result in ETD reagent (fluoranthene) entering the lab environment. Prevent this from occurring by removing and replacing the ETD reagent vials only when they are empty.

Caution

To preserve the integrity of the ETD reagent vial septums, remove and replace the ETD reagent vials only when they are empty. Do not reinstall used vials.

Note Store and handle all chemicals in accordance with standard safety procedures. The Material Safety Data Sheet (MSDS) describing the chemicals being used should be freely available to lab personnel for them to examine at any time. Material Safety Data Sheets (MSDSs) provide summarized information on the hazard and toxicity of specific chemical compounds.

MSDSs also provide information on the proper handling of compounds, first aid for accidental exposure, and procedures for cleaning spills or dealing with leaks. Producers and suppliers of chemical compounds are required by law to provide their customers with the most current health and safety information in the form of an MSDS.

Read the MSDS for each chemical you use. Dispose of all laboratory reagents in the appropriate manner (see the MSDS).

Safety information about fluoranthene is given in

Appendix A:

“Fluoranthene” .

Placing the Instrument in Off Condition and Service Mode

The power switches control power to the Orbitrap Elite ETD mass spectrometer (MS and ETD Module). The ETD Module power switches control the power to the ETD Module only. When the

3-48

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Orbitrap Elite ETD MS is fully operational (all systems On), the MS

Main Power switch is in the On position and the FT Electronics switch is in the operating (On) position.

Normally, the ETD Module Power and Service switches remain On. Use the FT Electronics switch on the MS unit to place the Orbitrap

Elite ETD mass spectrometer in Service mode. Turn On and Off the instrument (both ETD Module and MS) with the MS Main Power switch.

Warning

Burn Hazard. When mass spectrometer and ETD Module system are turned On, the flow restrictor, the transfer line heaters, and the ion source heater can be at 160 °C. The vial heaters can be at 108 °C

(or set point). Do not attempt to replace reagent vials or to service heated components until you have determined that they have cooled to a safe temperature for handling.

On Off

Note The instructions that follow assume that no analyte is flowing into the API source.

Standby

To place the Orbitrap Elite ETD mass spectrometer in Off Condition and

Service mode and to verify that the vials are safe to handle

1. If the Tune Plus window is not already open, choose Start >

Programs > Thermo Instruments > LTQ > LTQ Tune from the taskbar. The Tune Plus window appears. (See

Figure 3-10 on page 3-22

.)

You can determine the state of the MS detector by observing the state of the On/Standby button on the Control/Scan Mode toolbar.

The three different states of the On/Standby button are shown at the left.

2. Choose Control > Off from the Tune Plus pull-down menu to place the system in Off condition. When the mass spectrometer is in Off condition, the Orbitrap Elite ETD MS turns off the ion source sheath gas, auxiliary gas, high voltage, and all of the ETD Module heaters.

Note It is important to choose Control > Off from the Tune Plus pull-down menu in order to shut down all of the ETD Module heaters.

3. Click the reagent ion source portion of the instrument control icon at the top of the Tune Plus window. The Reagent Ion Source dialog

box appears ( Figure 3-44

).

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-49

User Maintenance

Maintenance of the ETD Module

Observe the temperature of Vial 1 in the Actual column of the

Reagent Ion Source dialog box ( Figure 3-44

). Nitrogen cooling gas

will flow until the vial reaches 70 °C. (See “Turning Off the Reagent

Ion Source: What to Expect” on page 2-14

.) Allow up to 90 minutes for the vial temperature to reach ambient temperature (about

30 °C).

actual vial temperature in °C

Figure 3-44. Reagent Ion Source dialog box

Warning

Burn Hazard. Do not attempt to handle the vials or vial holders when the cooling nitrogen stops. They are still too hot to handle when the cooling nitrogen stops at a vial temperature of 70 °C.

Allow the vials to cool to about 30 °C (allow up to 90 minutes after the cooling gas stops) before proceeding with the next step and handling the vials.

4. Toggle the FT Electronics switch to Service mode (Off ) when the vial has reached a temperature that is safe for handling (about

30 °C). Toggling the FT Electronics switch to Service mode turns off all components except the turbomolecular pumps and the forepumps in both the mass spectrometer and the ETD Module.

3-50

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Note Do not place the ETD Module Service switch into its Service mode (Off ) position while the MS switches are left in their On positions. This could cause communication problems between the MS and the ETD Module. The ability to control the Service mode for both the MS and the ETD Module at one point (at the FT Electronics switch) is a safety feature.

Warning

Burn Hazard. Do not place the system in Service mode until the vials reach a safe temperature (about 30 °C). System temperature monitoring will stop when the system is placed in Service mode. Do not attempt to handle the vials, the vial holders, or the heater assembly until a safe temperature is reached (about 30 °C).

The Orbitrap Elite ETD mass spectrometer is now in Service mode and the vials are at a safe temperature for handling.

Installing/Exchanging the Reagent Vials

After the reagent vial heaters have cooled to room temperature, the reagent vials are ready to be installed or exchanged.

To install or exchange the reagent vials

1. Remove the back panel from the ETD Module. (See

“Removing the

ETD Main Access Panel” on page 3-18

.) This exposes the reagent

inlet source heating unit, which has its own cover ( Figure 3-45 on page 3-52

).

Warning

Burn Hazard. Follow the procedures described in “Placing the

Instrument in Off Condition and Service Mode” on page 3-48 before

removing the back panel of the ETD Module. Removing the back panel before the system is placed in Service mode will open the panel electrical interlocks and stop all system activity including temperature monitoring. In the absence of temperature monitoring, you might attempt to handle the vials before it is safe to do so.

2. Make sure that the vial heater cover is cool to the touch.

Warning

Burn Hazard. The vial heaters can be at 108 °C (or set point).

Allow sufficient time for the vials to cool (up to 90 minutes) and then

place the system in Service mode. (See “Placing the Instrument in Off

Condition and Service Mode” on page 3-48.) Verify that the vial heater

cover is safe to handle before attempting to remove the vial holders and reagent vials.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-51

User Maintenance

Maintenance of the ETD Module

Reagent Inlet

Source Unit

Vial Heater Cover

Figure 3-45. ETD Module with back panel removed

3. Put on a pair of new, white nitrile clean room gloves and protective eye wear.

4. Using a Phillips screwdriver, remove the screws in the vial heater cover. The vial heater cover is located on the right side of the

ETD Module as you view it from the back of the Orbitrap

Elite ETD mass spectrometer ( Figure 3-45 ).

5. Remove the vial holder by gently pulling it out of the vial heater.

6. Remove the empty vial if it is present. The vial holder is a cylindrical tube with a handling knob at one end and ribs along its length. See

Figure 3-46

. These ribs prevent the vial holder from rotating once it

is placed into the vial heater. Figure 3-47 on page 3-53 shows the tab

and ribs of a vial holder in the vial heater.

Note Dispose of an empty fluoranthene vial in accordance with its

MSDS.

Warning Avoid exposure to potentially harmful materials.

Always wear protective gloves and safety glasses when you handle solvents or corrosives. Also contain waste streams and use proper ventilation. Refer to your supplier's Material Safety Data Sheet (MSDS) for proper handling of a particular compound.

3-52

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Figure 3-46. Reagent vials with holders

7. Take a vial containing the ETD reagent (fluoranthene) from its box and remove the aluminum tab from the top of the vial’s crimp seal.

8. Put the vial into a vial holder.

Vial Heater ribs

Vial 1 Heater

Vial Holder Knob

Vial 2 Heater

Figure 3-47. ETD Module with vial heater cover removed

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-53

User Maintenance

Maintenance of the ETD Module

9. Place this ETD reagent vial and its vial holder into the Vial 1 heater

(top vial heater). Gently slide the vial holder into the vial heater.

10. Place the empty vial from the box into the other vial holder if an empty vial is not already installed.

11. Place this empty vial and its vial holder into the Vial 2 heater

(bottom vial heater) if an empty vial is not already installed.

Warning

Health Hazard. The empty vial in the Vial 2 heater is an integral part of the carrier/CI gas system. It is necessary to keep the carrier/CI gas system closed to the laboratory. If no vial is placed in the

Vial 2 heater, the carrier/CI gas containing the reagent might escape to the laboratory causing a safety problem.

Caution

If no vial is placed in the Vial 2 heater, the ETD Module will not operate correctly and the filament will burn out.

12. Reinstall the vial heater cover over the vial heaters.

13. Reinstall the back panel of the ETD Module. See “Removing the

ETD Main Access Panel” on page 3-18 . The ETD Module will not

turn on unless the back panel is installed.

14. Start the system: a. Toggle the FT Electronics switch to the On position.

The system will boot to Standby mode. Then ion source heater, flow restrictor, and transfer line heaters will start heating.

Monitor these temperatures in the Status View on the right side of the Tune Plus window. (See

Figure 3-10 on page 3-22

.) They will have green check marks when they have reached their operating temperatures.

b. Select the Reagent Ion Source On check box in the Reagent Ion

Source dialog box when the ion source heater, flow restrictor, and transfer line heaters are at their operating temperatures. (See

Figure 3-44 on page 3-50

.)

The Orbitrap Elite ETD mass spectrometer is now ready for use.

Changing the Reagent Ion Source Flow Restrictors

To change the reagent ion source flow restrictors

1. Shut down completely the instrument according to the procedures in

“Shutting Down the Orbitrap Elite Mass Spectrometer

Completely” on page 2-7 .

3-54

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

Warning

Burn Hazard. The reagent vial heaters can be 108 °C (or set point), the flow restrictor, the transfer line heaters, and the ion source heater can be at 160 °C. These components may be too hot to touch.

Verify that all of these components are safe to touch before handling them.

2. Remove the ETD side access panel according to the instructions in

“Removing the ETD Side Access Panel” on page 3-19 .

Caution

The ETD side access panel is interlocked with the

ETD Module power. When the ETD side access panel is removed, all power to the ETD Module will be turned off.

3. Remove the four screws that hold the reagent inlet cover in place.

Warning

Burn Hazard. The reagent inlet cover may be too hot to touch. Verify that the reagent inlet cover is at or near room temperature before handling it.

4. Remove the five screws that hold the restrictor oven cover in place.

Warning

Burn Hazard. The restrictor oven cover may be too hot to touch. Verify that the restrictor oven cover is at or near room temperature before handling it.

5. Replace both fused silica restrictors and their ferrules by removing

their Swagelok® nuts. See Figure 3-48 .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-55

User Maintenance

Maintenance of the ETD Module

6 5 4 3 2

7

8

9 10 1

Labeled components: 1=PEEKsil

®

tubing, 2=fused silica tubing from lower oven, 3=transfer line inlet, 4=Swagelok fitting with two hole ferrule, 5=fused silica tubing from upper oven, 6=upper oven Swagelok fitting with a single hole ferrule, 7=vial 1 (upper) and vial 2 (lower) heaters, 8=lower oven

Swagelok fitting with a single hole ferrule, 9=Tee below reagent inlet assembly, 10=gas valves

Figure 3-48. Reagent inlet assembly

6. Thread two pieces of fused silica tubing (P/N 98000-20060) into the two hole ferrule (P/N 00101-08-00006) from the Installation

Kit for the Reagent Inlet Module (P/N 98000-62006). Place a

Swagelok fitting over the ferrule.

7. Insert the two hole ferrule and Swagelok fitting from step 6

onto the

transfer line inlet (item 3 in Figure 3-48

) and tighten the Swagelok fitting.

8. Thread the opposite end of one of the pieces of fused silica tubing into a single hole ferrule. Place a Swagelok fitting over the ferrule.

9. Insert the ferrule and Swagelok fitting from step 8 on to one of the

oven outlets (items 6 or 8 in Figure 3-48

) and tighten the Swagelok fitting.

Caution

Do not overtighten the ferrules. The ferrules may loosen after they are first heated. If this occurs retighten them if necessary.

10. Repeat step 9 for the other oven.

3-56

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the ETD Module

11. Replace the restrictor oven cover and reagent inlet cover removed in step 3 and step 4 .

12. Loosen the Swagelok fitting connecting the PEEKsil® tubing (item 1 in

Figure 3-48

) to the Tee below the reagent inlet assembly (item 9 in

Figure 3-48 ) and from the gas valves (item 10 in Figure 3-48 ).

13. Replace the old PEEKsil tubing with new PEEKsil tubing

(P/N 00109-02-00020) from the Installation Kit for the Reagent

Inlet Module (P/N 98000-62006).

14. Close the ETD Module and restart the instrument. Follow the

procedures given in “Starting Up the System after a Shutdown” on page 2-9

.

Cleaning the Fan Filters of the ETD Module

You need to clean the fan filters every four months. The fan filters are located at the rear of the ETD Module on the left side (as viewed from the back of the ETD Module). See

Figure 3-49

.

Thermo Fisher Scientific

Fan filters

Figure 3-49. ETD Module, top panel

To clean the fan filters of the ETD Module

1. Remove the fan filter from the rear of the ETD Module by pulling it out of the fan filter bracket.

2. Wash the fan filters in a solution of soap and water.

3. Rinse the fan filters with tap water.

4. Squeeze the water from the fan filters and allow them to air dry.

5. Reinstall the fan filter in the fan filter bracket.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-57

User Maintenance

Maintenance of the Cooling Circuit

Maintenance of the Cooling Circuit

The recirculating chiller and the water filter require maintenance on a regular basis.

Maintenance for the Recirculating Chiller

For the NESLAB ThermoFlex™ 900 recirculating chiller, the checks described in this section should be carried out on a regular basis.

Note For further information and maintenance instructions, refer to the manufacturer’s manual supplied with the instrument.

Reservoir

Periodically inspect the fluid inside the reservoir. If cleaning is necessary, flush the reservoir with a cleaning fluid compatible with the circulating system and the cooling fluid.

The cooling fluid should be replaced periodically. Replacement frequency depends on the operating environment and amount of usage.

Warning

Burn Hazard. Before changing the operating fluid, make sure it is at safe handling temperature.

Fluid Bag Filter

The ThermoFlex 900 recirculating chiller installed in the cooling circuit of the instrument is equipped with a fluid bag filter, which needs to be replaced on a regular basis. Replacement bags are available from Thermo

Fisher Scientific.

Condenser Filter

To prevent a loss of cooling capacity and a premature failure of the cooling system, clean the condenser filter regularly. If necessary, replace it.

Replacing the Water Filter Cartridge

The filter removes particulate matter in the cooling system that might damage the flow sensor. The filter cartridge should be replaced annually or as necessary. A replacement is available from Thermo Fisher Scientific

(P/N 1284050).

3-58

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

User Maintenance

Maintenance of the Cooling Circuit

To replace the water filter cartridge

1. Place the system in Standby condition as described on page 2-4

.

2. Turn off the chiller.

3. The filter is installed on the left instrument side, in the cooling lines of the Orbitrap system between the Peltier element and the flow sensor. See

Figure 3-50 . Quick couplings connect the filter assembly

to the hoses of the cooling lines. Press the thumb latch of each quick coupling to release it; valves in the couplings prevent the water from leaking out. Then remove the complete filter assembly.

Thumb latch

Thumb latch

Figure 3-50. Installed water filter

4. Remove the filter from the assembly by using a 5/16 inch wrench and pressing against the gray ring on the quick coupling, away from the filter. See

Figure 3-51

.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

3-59

User Maintenance

Maintenance of the Cooling Circuit

Gray ring

Figure 3-51. Removing the filter cartridge

5. Insert the new filter into the quick couplings. See

Figure 3-52 .

Figure 3-52. Filter cartridge with Quick couplers

Caution

Pay special attention to the direction of flow. Reversing the flow can damage both the flow sensor and the filter.

6. Connect the filter assembly to the hoses of the cooling lines.

7. Switch on the chiller system. Check for leaks and check the water level in the chiller. Refill as appropriate.

8. Set the instrument to operating condition.

3-60

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Chapter 4

Replaceable Parts

This chapter contains part numbers for replaceable and consumable parts for the mass spectrometer, data system, and kits. To ensure proper results in servicing the Orbitrap Elite system, order only the parts listed or their equivalent.

Note Not all parts are available for purchase separately. Some parts may only be available for purchase as part of a kit or assembly.

For information on how to order parts, see

“Contacting Us”

in the front section of this guide.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

4-1

Replaceable Parts

Ion Sources

Ion Sources

ESI probe, for Ion Max source. . . . . . . . . . . . . . . . . . . . . . . . OPTON-20011

Low flow metal needle for API 2 probes . . . . . . . . . . . . . . . . OPTON-30004

Nanospray II Ion Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON-20050

Static Nanospray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON-20051

Dynamic Nanospray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON-97017

APCI probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON-20012

APPI probe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON-20026

HESI-II Probe Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . OPTON 20037

High-flow needle insert assembly. . . . . . . . . . . . . . . . . . . . . . OPTON-53010

Low-flow needle insert assembly . . . . . . . . . . . . . . . . . . . . . . OPTON-53011

4-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Replaceable Parts

Parts for the Basic System

Parts for the Basic System

Orbitrap Analyzer Installation Kit

Tube, 1/8” × 2.1- 1.4301 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0261000

Ferrule, stainless steel; R. 1/8” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0520950

Ferrule, stainless steel; V. 1/8” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0522520

Cap nut, stainless steel; 1/8“. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0520890

Fitting KJH06-00. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1221620

Pumping System

For a schematical overview of the pumping system, see Figure 1-23 on page 1-30

.

T-piece 13 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0512360

Hose 13 × 3.5; PVC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0690720

Turbomolecular pump HiPace 300. . . . . . . . . . . . . . . . . . . . . . . . . . .1272910

Turbomolecular pump; HiPace 80 . . . . . . . . . . . . . . . . . . . . . . . . . . .1272920

UHV gauge IKR 270; short . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1181380

Compact Pirani Gauge TPR280. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1156400

Water cooling for HiPace 300. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1272930

Water cooling for HiPace 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0794742

PVC hose, with steel helix; ID=45 mm, L=1.6 m . . . . . . . . . . . . . . . .1184330

Hose nipple, DN 40, ISO-KF-45. . . . . . . . . . . . . . . . . . . . . . . . . . . .1159230

Venting flange; DN 10, KF-G1/8” . . . . . . . . . . . . . . . . . . . . . . . . . . .1184400

Splinter shield for TMPs, with DN 100 CF-F flange . . . . . . . . . . . . .1198590

Centering ring, with integrated splinter shield; DN 63 ISO . . . . . . . .1198600

Anti-magnetic cover for IKR 270 . . . . . . . . . . . . . . . . . . . . . . . . . . . .1181390

Gasket; NW 100 CF, copper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0552440

Hose, metal; KF16-KF25 - 250mm . . . . . . . . . . . . . . . . . . . . . . . . . .1154130

Gasket; copper, NW 35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0550480

Metal tube, KF NW16×250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0524260

KF Tee piece; NW 16 KF, stainless steel . . . . . . . . . . . . . . . . . . . . . . .0524230

Centering ring with o-ring; DN 16, Viton . . . . . . . . . . . . . . . . . . . . .0522140

Centering ring with o-ring; DN 25, Viton . . . . . . . . . . . . . . . . . . . . .0522150

Centering ring; NW 16/10, aluminum-Viton . . . . . . . . . . . . . . . . . .0522200

Clamping ring; NW 10/16, KF . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0521830

Clamping ring; NW 20/25, KF . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0521560

Reducing cross piece; DN40/DN16 KF . . . . . . . . . . . . . . . . . . . . . . .1184310

Metal tube; DN40x500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1184350

Metal tube; DN40x750 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1181290

Hose clamp; NW 40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1181320

Centering ring; NW 40 KF, aluminum-Viton . . . . . . . . . . . . . . . . . .0522260

Tension ring; NW 32/40 KF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1181250

Clamping screw; DN63-100 ISO, aluminum. . . . . . . . . . . . . . . . . . .1042670

Flexible metal hose KF NW 16x500. . . . . . . . . . . . . . . . . . . . . . . . . .0534500

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

4-3

Replaceable Parts

Parts for the Basic System

Water Supply

For a schematical overview of the cooling water circuit, see Figure 1-32 on page 1-42

.

Quick coupling insert; 9.6 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1141640

Quick coupling body; 9.6 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1138960

Hose; 9 x 3, black, PVC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1049540

Hose; 6 x 1, Teflon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1042660

Quick coupling insert; Delrin Acetal, NW 6.4 . . . . . . . . . . . . . . . . . 1185030

Quick coupling body; Delrin Acetal, NW 6.4 . . . . . . . . . . . . . . . . . . 1185020

Clamping piece 8/16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0370130

Adaptor hose nipple; male, 1/2 x 10 . . . . . . . . . . . . . . . . . . . . . . . . . 1185840

Flow control sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1191740

Filter cartridge; 50 μm DIF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1284050

Gas Supply

For a schematical overview of the gas supply, see

Figure 1-28 on page 1-37 .

Bulkhead union; 1/16”, for hose 4 x 1 (for P/N 069 1130) . . . . . . . . 1153660

Bulkhead union; 1/8”×1/8” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0523450

Hose; 4 x 1, Teflon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0690280

Hose; 4 x 1, polyurethane, blue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0691130

Capillary 1/16” ID-SS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0605470

Plug-in T-piece; 3 x 6mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1128140

Regulator + manometer f. Orbitrap analyzer . . . . . . . . . . . . . . . . . . . 1257670

Capillary; 1/16”x0.13x400mm (red), PEEK . . . . . . . . . . . . . . . . . . . 1253830

Coupling; 1/16”, SS-100-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0524340

Ferrule; 1/16” GVF 16-000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1121110

Reducer Swagelok; 1/8” × 1/16”, stainless steel . . . . . . . . . . . . . . . . . 0662880

Ferrule; 1/16” GVF/16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0674800

Connector 1/8”, for hose OD 4 mm . . . . . . . . . . . . . . . . . . . . . . . . . 1128680

Cap nut; 1/16”, stainless steel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0520880

Hose; 2 x 1, PTFE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1091650

Sleeve; Ø 6 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1047320

Capillary; PEEKsil, 1/16”, 0.1 × 500 mm . . . . . . . . . . . . . . . . . . . . . 1223420

Plug, KQ2P-06 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1185620

Cap, KQ2C-06 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1258220

4-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Replaceable Parts

Parts Lists for the ETD System

Parts Lists for the ETD System

This section contains parts lists for the components of the ETD System of the Orbitrap Elite ETD mass spectrometer.

Quadrupole Orbitrap analyzer, complete . . . . . . . . . . . . . . . . . . . . . .1239200

Housing HCD/ETD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231740

Separating plate HCD/ETD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231770

Screw M 4 x 8 DIN912 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1044420

O-ring 129 X 4 A Viton. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1240520

Lid HCD/ETD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231760

Screw-in connector; 1/16” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1186150

Gasket; NW 63 ISO, aluminum/Viton . . . . . . . . . . . . . . . . . . . . . . .0554060

Blank flange; stainless steel, NW 63 . . . . . . . . . . . . . . . . . . . . . . . . . .0652620

Clamping screw; DN63-100, aluminum . . . . . . . . . . . . . . . . . . . . . .1028380

Washer 8.4; stainless steel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0470070

Screw, hexagonal; M 8 x 35, stainless steel . . . . . . . . . . . . . . . . . . . . .0454400

Washer 8.4 x 11 x 1.5, stainless steel. . . . . . . . . . . . . . . . . . . . . . . . . .0470860

Screw M8 x 35; stainless steel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0454250

Centering ring NW 16 Viton. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0522140

Feedthrough; 8-fold 1,5kV DN16KF. . . . . . . . . . . . . . . . . . . . . . . . .1231750

O-ring; 118 X 5 A, Viton. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1168240

Box f. feedthrough; KF16 / Sub-D9 . . . . . . . . . . . . . . . . . . . . . . . . . .1231800

Cylindrical Screw ISO4762-M6X12-A4. . . . . . . . . . . . . . . . . . . . . . .0453300

Vacuum system ETD

Flange clamp; KF16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1145860

PUMP, TURBO, EDWARDS EXT75DX ISO100, TNR . . 00108-01-00016

Splinter guard, DN_63_ISO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1198600

Metal hose, DN 16 ISO-KF x500 . . . . . . . . . . . . . . . . . . . . . . . . . . .1181410

Centering ring with o-ring; DN 16, Viton . . . . . . . . . . . . . . . . . . . . .0522140

Clamping ring; NW 10/16, KF . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0521830

Hose flange; NW 25 KF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1042330

Centering ring, with o ring; DN 25, Viton . . . . . . . . . . . . . . . . . . . .0522150

Clamping ring, DN 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0521560

Flange, KF16 - hose OD 19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1239340

Reducer; DN 16/DN 25, aluminum . . . . . . . . . . . . . . . . . . . . . . . . .0522160

PUMP, ROTARY VANE, EDWARDS RV3. . . . . . . . . . . . . . 00108-01-0008

KIT, ACCESSORY, MECHANICAL PUMP, RV3 . . . . . . . . . 98000-620007

Gas Supply ETD

Plug-in T-piece; 3 x 6mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1128140

Sleeve 6 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1047320

Reducing hose connector, 3.2−>6. . . . . . . . . . . . . . . . . . . . . . . . . . .1239220

Hose cutter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1239280

T-piece 13 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0512360

Hose 9 X 3; PVC, black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1049540

Clamping piece 8/16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0370130

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

4-5

Replaceable Parts

Parts Lists for the ETD System

Hose; 4 X 1, Teflon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0690280

Clamping ring; stainless steel, NW10/16. . . . . . . . . . . . . . . . . . . . . . 1149200

PEEK capillary; 1/16” x 0.040. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1245940

Ferrule, 1/16”, for GVF/16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0674800

Ferrule 1/16” - CTFE, collapsible . . . . . . . . . . . . . . . . . . . . . . . . . . . 1224700

Electronic Parts ETD

Cable Y-ADAPTER/T.PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2108630

Coupling; RJ45 BU/2BU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2075210

Patch cable; 0.51MT RJ45 gray SFTP. . . . . . . . . . . . . . . . . . . . . . . . 2080870

Cable POWER DIS./T-PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2081200

Cable CLT-OFFSET-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2108710

Cable IOS ETD/ION OPTIC-S . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2108820

UNIT_ION OPTIC SUPPLY ETD . . . . . . . . . . . . . . . . . . . . . . . . . 2108920

PCB LTQ CABLE DRIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2097780

PCB ORBITRAP CABLE RECEIVER. . . . . . . . . . . . . . . . . . . . . . 2097830

PCB ETD CABLE RECEIVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2097800

Cable ETD/LTQ/ORBITRAP-INTERCONNECT 60 . . . . . . . . . . 2108940

Cable ETD/LTQ/ORBITRAP-INTERCONNECT 36 . . . . . . . . . . 2108950

Cable ETD/LTQ/ORBITRAP-INTERCON SUPPLY . . . . . . . . . . 2108960

Coaxial cable; ETD IOS/ANALOG CTRL, J5554 . . . . . . . . . . . . . 2108990

Coaxial cable; ETD IOS/ANALOG CTRL, J5555 . . . . . . . . . . . . . 2109000

Coaxial cable; ETD IOS/ANALOG CTRL, J5556 . . . . . . . . . . . . . 2109010

Cable ANALOG CTRL / ETD IOS . . . . . . . . . . . . . . . . . . . . . . . . 2108970

Cable ETD IOS/HCD multipole . . . . . . . . . . . . . . . . . . . . . . . . . . . 2108980

Extension cable; 16A C20-C19 2M . . . . . . . . . . . . . . . . . . . . . . . . . 2097050

ADAPTER_IOS/MULTIPOLE-HCD . . . . . . . . . . . . . . . . . . . . . . 2100410

Reagent Inlet Module

ASSY, TOOL, ION VOLUME INSERTION/REMOVAL . . . 98000-60028

TUBING, PEEKsil, 1/16” OD, 100mm LONG, RoHS. . . .00109-02-00020

FRLE, 1HOLE, 1/16 OD, 0.4mm ID, VESP/GRPHT, RO .00101-08-00005

FRLE, 2HOLS, 1/16 OD, 0.4mm ID, VESP/GRPHT, RO .00101-08-00006

Inlet Valve Seal Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119265-0003

Inlet valve seal removal tool. . . . . . . . . . . . . . . . . . . . . . . . . 119283-0001

Spool inlet valve seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119683-0100

O-ring Viton, 0530 ID × 0.082 W . . . . . . . . . . . . . . . . . . . . . 3814-6530

4-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

ETD Reagent Kit

Replaceable Parts

Parts Lists for the ETD System

ETD Reagent Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98000-62008

Angiotensin I, 1mg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 00301-15517

Fluoranthene, 150mg . . . . . . . . . . . . . . . . . . . . . . . . . . . 00301-01-0013

The fluoranthene in your ETD Reagent Kit is Sigma/Aldrich Supelco

#48535. The fluoranthene MSDS is obtained from the MSDS link at: www.sigmaaldrich.com/catalog/search/ProductDetail/SUPELCO/48535

Thermo Fisher Scientific supplies fluoranthene as a two vial kit. One vial contains 150 mg of fluoranthene and the other is the required empty vial.

The angiotensin I in your ETD Reagent Kit is Angiotensin I human acetate hydrate (Sigma/Aldrich #A9650). Angiotensin I is potentially hazardous. Handle it in accordance with its MSDS. The angiotensin I

MSDS is obtained from the MSDS link at: www.sigmaaldrich.com/catalog/search/ProductDetail/SIGMA/A9650

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

4-7

Appendix A

Fluoranthene

Fluoranthene is used as the Electron Transfer Dissociation (ETD) reagent in the ETD Module portion of the Orbitrap Elite ETD mass spectrometer. The fluoranthene radical anion is generated according to

the reaction shown in Figure A-1.

Thermo Fisher Scientific

Fluoranthene

Figure A-1. ETD Reagent (fluoranthene radical anion) generation from fluoranthene

Fluoranthene is potentially hazardous. Use it in accordance with its

Material Safety Data Sheet (MSDS).

Note Store and handle all chemicals in accordance with standard safety procedures. The MSDS describing the chemicals being used should be freely available to lab personnel for them to examine at any time.

Material Safety Data Sheets (MSDSs) provide summarized information on the hazard and toxicity of specific chemical compounds. The MSDS also provides information on the proper handling of compounds, first aid for accidental exposure, and procedures for cleaning spills or dealing with leaks. Producers and suppliers of chemical compounds are required by law to provide their customers with the most current health and safety information in the form of an MSDS. Read the MSDS for each chemical you use. Dispose of all laboratory reagents in the appropriate way (see the MSDS).

The fluoranthene contained in the ETD Reagent Kit

(P/N 98000-62008, see

page 4-7 ) is Sigma/Aldrich Supelco #48535.

The fluoranthene MSDS is obtained from the MSDS link at: www.sigmaaldrich.com/catalog/search/ProductDetail/SUPELCO/48535

Thermo Fisher Scientific supplies fluoranthene as a two vial kit. One vial contains 150 mg of fluoranthene and the other is the required empty vial.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

A-1

Glossary

This section lists and defines terms used in this guide. It also includes acronyms, metric prefixes, symbols, and abbreviations.

A

B C

D E

F

G H I

J

K L

M N O

P Q R

S

T U V

W X

Y Z

A

A ampere

AC alternating current

ADC analog-to-digital converter; a device that converts data from analog to digital form.

adduct ion An ion formed by the joining together of two species, usually an ion and a molecule, and often within the ion source, to form an ion containing all the constituent atoms of both species.

AGC™ See

Automatic Gain Control™ (AGC)

.

APCI See atmospheric pressure chemical ionization

(APCI) .

APCI corona discharge current The ion current carried by the charged particles in the APCI source.

The voltage on the APCI corona discharge needle supplies the potential required to ionize the particles.

The APCI corona discharge current is set; the APCI corona discharge voltage varies, as required, to maintain the set discharge current.

See also corona discharge and

APCI corona discharge voltage .

APCI corona discharge voltage The high voltage that is applied to the corona discharge needle in the APCI source to produce the APCI corona discharge. The corona discharge voltage varies, as required, to maintain the set APCI spray current.

See also APCI spray current .

APCI manifold The manifold that houses the APCI sample tube and nozzle, and contains the plumbing for the sheath and auxiliary gas.

APCI needle, corona discharge A needle to which a sufficiently high voltage (typically ±3 to ±5 kV) is applied to produce a chemical ionization plasma by the corona discharge mechanism.

See also chemical ionization (CI) , chemical ionization

(CI) plasma ,

atmospheric pressure chemical ionization

(APCI) , and

corona discharge

.

APCI nozzle The nozzle in the APCI probe that sprays the sample solution into a fine mist.

See also atmospheric pressure chemical ionization

(APCI) .

APCI sample tube A fused silica tube that delivers sample solution to the APCI nozzle . The APCI sample tube extends from the sample inlet to the

APCI nozzle.

See also atmospheric pressure chemical ionization

(APCI) , and

API stack .

APCI source Contains the APCI probe assembly,

APCI manifold, and API stack.

See also atmospheric pressure chemical ionization

(APCI) ,

APCI manifold , and API stack .

APCI spray current The ion current carried by the charged particles in the APCI source. The APCI corona discharge voltage varies, as required, to maintain the set spray current.

APCI vaporizer A heated tube that vaporizes the sample solution as the solution exits the sample tube and enters the atmospheric pressure region of the

APCI source.

See also atmospheric pressure chemical ionization

(APCI) .

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-1

Glossary: API–atmospheric pressure chemical ionization (APCI)

API See atmospheric pressure ionization (API)

.

API atmospheric pressure region The first of two chambers in the API source. Also referred to as the spray chamber.

API capillary-skimmer region The area between the capillary and the skimmer, which is surrounded by the tube lens. It is also the area of first-stage evacuation in the API source.

API heated capillary A tube assembly that assists in desolvating ions that are produced by the ESI or

APCI probe.

See also API heated capillary voltage .

API heated capillary voltage The DC voltage applied to the heated capillary. The voltage is positive for positive ions and negative for negative ions.

See also API source and API heated capillary .

API ion transfer capillary A tube assembly that assists in desolvating ions that are produced by the ESI, NSI, or APCI probe.

See also API ion transfer capillary offset voltage and

API ion transfer capillary temperature .

API ion transfer capillary offset voltage A DC voltage applied to the ion transfer capillary. The voltage is positive for positive ions and negative for negative ions.

See also API source and API ion transfer capillary .

API ion transfer capillary temperature The temperature of the ion transfer capillary, which should be adjusted for different flow rates.

See also API source and API ion transfer capillary .

API source The sample interface between the LC and the mass spectrometer. It consists of the API probe

(ESI or APCI) and API stack.

See also

atmospheric pressure ionization (API) ,

ESI source , APCI source , ESI probe , and API stack .

API spray chamber The first of two chambers in the

API source. In this chamber the sample liquid exits the probe and is sprayed into a fine mist (ESI or NSI) or is vaporized (APCI) as it is transported to the entrance end of the ion transfer capillary.

G-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

API spray shield A stainless steel, cylindrical vessel that, in combination with the ESI or APCI flange, forms the atmospheric pressure region of the

API source.

See also atmospheric pressure ionization (API) .

API stack Consists of the components of the

API source that are held under vacuum and includes the API spray shield , API ion transfer capillary ,

API tube lens ,

skimmer

, the ion transfer capillary mount, and the tube lens and skimmer mount.

See also atmospheric pressure ionization (API)

and

API source .

API tube lens A lens in the API source that separates ions from neutral particles as they leave the ion transfer capillary. A potential applied to the tube lens focuses the ions toward the opening of the skimmer and helps to dissociate adduct ions.

See also API tube lens offset voltage , API source ,

API ion transfer capillary , and

adduct ion

.

API tube lens and skimmer mount A mount that attaches to the heated capillary mount. The tube lens and skimmer attach to the tube lens and skimmer mount.

API tube lens offset voltage A DC voltage applied to the tube lens. The value is normally tuned for a specific compound.

See also API tube lens ,

adduct ion , and

source CID .

AP-MALDI See atmospheric pressure matrix-assisted laser desorption/ionization (AP-MALDI) .

APPI See

Atmospheric Pressure Photoionization

(APPI)

.

ASCII American Standard Code for Information

Interchange

atmospheric pressure chemical ionization (APCI) A soft ionization technique done in an ion source operating at atmospheric pressure. Electrons from a corona discharge initiate the process by ionizing the mobile phase vapor molecules. A reagent gas forms, which efficiently produces positive and negative ions of the analyte through a complex series of chemical reactions.

See also electrospray ionization (ESI) .

Thermo Fisher Scientific

Glossary: atmospheric pressure ionization (API)–consecutive reaction monitoring (CRM) scan type

atmospheric pressure ionization (API) Ionization performed at atmospheric pressure by using

atmospheric pressure chemical ionization (APCI)

,

electrospray ionization (ESI)

, or

nanospray ionization

(NSI) .

atmospheric pressure matrix-assisted laser

desorption/ionization (AP-MALDI) Matrix-assisted laser desorption/ionization in which the sample target is at atmospheric pressure.

See also matrix-assisted laser desorption/ionization

(MALDI)

.

Atmospheric Pressure Photoionization (APPI) A soft ionization technique in which an ion is generated from a molecule when it interacts with a photon from a light source.

atomic mass unit Atomic Mass Unit (u) defined by taking the mass of one atom of carbon12 as being

12u; unit of mass for expressing masses of atoms or molecules.

Automatic Gain Control™ (AGC) Sets the ion injection time to maintain the optimum quantity of ions for each scan. With AGC on, the scan function consists of a prescan and an analytical scan.

See also ion injection time

.

auxiliary gas The outer-coaxial gas (nitrogen) that assists the sheath (inner-coaxial) gas in dispersing and/or evaporating sample solution as the sample solution exits the APCI, ESI, or H-ESI nozzle.

auxiliary gas flow rate The relative rate of flow of

auxiliary gas (nitrogen) into the API source reported

in arbitrary units.

auxiliary gas inlet An inlet in the API probe where auxiliary gas is introduced into the probe.

See also auxiliary gas and atmospheric pressure ionization (API)

.

auxiliary gas plumbing The gas plumbing that delivers outer coaxial nitrogen gas to the ESI or APCI nozzle.

auxiliary gas valve A valve that controls the flow of auxiliary gas into the API source.

B

b bit

B byte (8 b)

baud rate data transmission speed in events per second

BTU British thermal unit, a unit of energy

C

°C degrees Celsius

CE central electrode (of the Orbitrap analyzer);

European conformity. Mandatory European marking for certain product groups to indicate conformity with essential health and safety requirements set out in

European Directives.

cfm cubic feet per minute

chemical ionization (CI) The formation of new ionized species when gaseous molecules interact with ions. The process can involve transfer of an electron, proton, or other charged species between the reactants.

chemical ionization (CI) plasma The collection of ions, electrons, and neutral species formed in the ion source during chemical ionization.

See also chemical ionization (CI) .

CI See

chemical ionization (CI) .

CID See

collision-induced dissociation (CID) .

cm centimeter

cm

3

cubic centimeter

collision gas A neutral gas used to undergo collisions with ions.

collision-induced dissociation (CID) An ion/neutral process in which an ion is dissociated as a result of interaction with a neutral target species.

consecutive reaction monitoring (CRM) scan type A scan type with three or more stages of mass analysis and in which a particular multi-step reaction path is monitored.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-3

Glossary: Convectron™ gauge–ESI flange

Convectron™ gauge A thermocouple bridge gauge that is sensitive to the pressure as well as the thermal conductivity of the gas used to measure pressures between X and Y.

corona discharge In the APCI source, an electrical discharge in the region around the corona discharge needle that ionizes gas molecules to form a chemical ionization (CI) plasma, which contains CI reagent ions.

See also

chemical ionization (CI) plasma and

atmospheric pressure chemical ionization (APCI) .

CPU central processing unit (of a computer)

CRM See consecutive reaction monitoring (CRM) scan type .

C-Trap curved linear trap

<Ctrl> control key on the terminal keyboard

D

d depth

Da dalton

DAC digital-to-analog converter

damping gas Helium gas introduced into the ion trap mass analyzer that slows the motion of ions entering the mass analyzer so that the ions can be trapped by the RF voltage fields in the mass analyzer.

data-dependent scan A scan mode that uses specified criteria to select one or more ions of interest on which to perform subsequent scans, such as MS/MS or

ZoomScan.

DC direct current

divert/inject valve A valve on the mass spectrometer that can be plumbed as a divert valve or as a loop injector.

DS data system

DSP digital signal processor

E

ECD See electron capture dissociation (ECD)

.

EI electron ionization

electron capture dissociation (ECD) A method of fragmenting gas phase ions for tandem mass spectrometric analysis. ECD involves the direct introduction of low energy electrons to trapped gas phase ions.

See also electron transfer dissociation (ETD)

and

infrared multiphoton dissociation (IRMPD)

.

electron multiplier A device used for current amplification through the secondary emission of electrons. Electron multipliers can have a discrete dynode or a continuous dynode.

electron transfer dissociation (ETD) A method of fragmenting peptides and proteins. In electron transfer dissociation (ETD), singly charged reagent anions transfer an electron to multiply protonated peptides within the ion trap mass analyzer. This leads to a rich ladder of sequence ions derived from cleavage at the amide groups along the peptide backbone.

Amino acid side chains and important modifications such as phosphorylation are left intact.

See also fluoranthene .

electrospray ionization (ESI) A type of atmospheric pressure ionization that is currently the softest ionization technique available to transform ions in solution into ions in the gas phase.

EMBL European Molecular Biology Laboratory

<Enter> Enter key on the terminal keyboard

ESD ElectroStatic Discharge. Discharge of stored static electricity that can damage electronic equipment and impair electrical circuitry, resulting in complete or intermittent failures.

ESI See

electrospray ionization (ESI)

.

ESI flange A flange that holds the ESI probe in position next to the entrance of the heated capillary, which is part of the API stack. The ESI flange also seals the atmospheric pressure region of the API source and, when it is in the engaged position against the spray shield, compresses the high-voltage safety-interlock switch.

G-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

ESI probe A probe that produces charged aerosol droplets that contain sample ions. The ESI probe is typically operated at liquid flows of 1 μL/min to

1 mL/min without splitting. The ESI probe includes the ESI manifold, sample tube, nozzle, and needle.

ESI source Contains the ESI probe and the API stack.

See also electrospray ionization (ESI)

, ESI probe , and

API stack .

ESI spray current The flow of charged particles in the

ESI source. The voltage on the ESI spray needle supplies the potential required to ionize the particles.

ESI spray voltage The high voltage that is applied to the spray needle in the ESI source to produce the

ESI spray current. In ESI, the voltage is applied to the spray liquid as it emerges from the nozzle.

See also ESI spray current .

ETD See

electron transfer dissociation (ETD) .

eV Electron Volt. The energy gained by an electron that accelerates through a potential difference of one volt.

Extensible Markup Language See XML (Extensible

Markup Language) .

external lock mass A lock that is analyzed in a separate

MS experiment from your sample. If you need to run a large number of samples, or if accurate mass samples will be intermingled with standard samples, you might want to use external lock masses. These allow more rapid data acquisition by eliminating the need to scan lock masses during each scan.

See also internal lock mass .

F

f femto (10

-15)

°F degrees Fahrenheit

.fasta file extension of a SEQUEST™ search database file

ft foot

Glossary: ESI probe–FWHM

Fast Fourier Transform (FFT) An algorithm that performs a Fourier transformation on data. A Fourier transform is the set of mathematical formulae by which a time function is converted into a frequency-domain function and the converse.

FFT See

Fast Fourier Transform (FFT)

.

fluoranthene A reagent anion that is used in an

electron transfer dissociation (ETD)

experiment.

firmware Software routines stored in read-only memory. Startup routines and low-level input/output instructions are stored in firmware.

forepump The pump that evacuates the foreline. A rotary-vane pump is a type of forepump.

Fourier Transform - Ion Cyclotron Resonance Mass

Spectrometry (FT-ICR MS) A technique that determines the mass-to-charge ratio of an ion by measuring its cyclotron frequency in a strong magnetic field.

fragment ion A charged dissociation product of an ionic fragmentation. Such an ion can dissociate further to form other charged molecular or atomic species of successively lower formula weights.

fragmentation The dissociation of a molecule or ion to form fragments, either ionic or neutral. When a molecule or ion interacts with a particle (electron, ion, or neutral species) the molecule or ion absorbs energy and can subsequently fall apart into a series of charged or neutral fragments. The mass spectrum of the fragment ions is unique for the molecule or ion.

FT Fourier Transformation

FT-ICR MS See Fourier Transform - Ion Cyclotron

Resonance Mass Spectrometry (FT-ICR MS) .

FTMS Fourier Transformation Mass Spectroscopy

full-scan type Provides a full mass spectrum of each analyte or parent ion. With the full-scan type, the mass analyzer is scanned from the first mass to the last mass without interruption. Also known as single-stage full-scan type.

FWHM Full Width at Half Maximum

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-5

Glossary: g–ion optics

G

g gram

G Gauss; giga (10

9

)

GC gas chromatograph; gas chromatography

GC/MS gas chromatography / mass spectrometer

GUI graphical user interface

H

h hour

h height

handshake A signal that acknowledges that communication can take place.

HCD See

higher energy collision-induced dissociation

(HCD) .

header information Data stored in each data file that summarizes the information contained in the file.

H-ESI probe Heated-electrospray ionization (H-ESI) converts ions in solution into ions in the gas phase by using

electrospray ionization (ESI) in combination

with heated auxiliary gas .

higher energy collision-induced dissociation (HCD)

Collision-induced dissociation that occurs in the

HCD cell of the

Orbitrap mass analyzer

. The

HCD cell consists of a straight multipole mounted inside a collision gas-filled tube. A voltage offset between C-Trap and HCD cell accelerates parent ions into the collision gas inside the HCD cell, which causes the ions to fragment into product ions. The product ions are then returned to the Orbitrap analyzer for mass analysis. HCD produces triple quadrupole-like product ion mass spectra.

high performance liquid chromatography (HPLC)

Liquid chromatography in which the liquid is driven through the column at high pressure. Also known as high pressure liquid chromatography.

HPLC See

high performance liquid chromatography

(HPLC) .

HV high voltage

G-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

Hz hertz (cycles per second)

I

ICR ion cyclotron resonance

ID inside diameter

IEC International Electrotechnical Commission

IEEE Institute of Electrical and Electronics Engineers

in. inch

infrared multiphoton dissociation (IRMPD) In infrared multiphoton dissociation (IRMPD), multiply charged ions consecutively absorb photons emitted by a infrared laser until the vibrational excitation is sufficient for their fragmentation. The fragments continue to pick up energy from the laser pulse and fall apart further to ions of lower mass.

See also electron capture dissociation (ECD) .

instrument method A set of experiment parameters that define Xcalibur operating settings for the autosampler, liquid chromatograph (LC), mass spectrometer, divert valve, syringe pump, and so on.

Instrument methods are saved as file type .meth.

internal lock mass A lock that is analyzed during the same MS experiment as your sample and is contained within the sample solution or infused into the

LC flow during the experiment. Internal lock masses provide the most accurate corrections to the data.

See also external lock mass .

I/O input/output

ion gauge Measures the pressure in the mass analyzer region (high vacuum region) of the vacuum manifold.

ion injection time The amount of time that ions are allowed to accumulate in the ion trap mass analyzer when AGC is off. With AGC on, the ion injection time is set automatically (up to the set maximum ion injection time) based on the AGC target value.

See also: Automatic Gain Control™ (AGC) .

ion optics Focuses and transmits ions from the

API source to the mass analyzer.

Thermo Fisher Scientific

ion source A device that converts samples to gas-phase ions.

ion sweep cone A removable cone-shaped metal cover that fits on top of the API ion transfer capillary and acts as a physical barrier to protect the entrance of the capillary.

ion sweep gas Extra nitrogen gas that flows along the axis of the API ion transfer capillary (between the ion sweep cone and the capillary block) towards the API spray. The sweep gas flow is thus countercurrent to the flow of the ions.

See also ion sweep gas pressure .

ion sweep gas pressure The rate of flow of the sweep gas (nitrogen) into the API source. A measurement of the relative flow rate (in arbitrary units) to provide the required flow of nitrogen gas out from the Ion Sweep cone towards the API spray.

See also ion sweep gas

.

IRMPD See infrared multiphoton dissociation

(IRMPD) .

K

k kilo (10

3

, 1000)

K kilo (2

10

, 1024)

KEGG Kyoto Encyclopedia of Genes and Genomes

kg kilogram

L

l length

L liter

LAN local area network

lb pound

LC See

liquid chromatography (LC)

.

LC/MS See liquid chromatography / mass spectrometry

(LC/MS)

.

LED light-emitting diode

LHe liquid helium

Thermo Fisher Scientific

Glossary: ion source–min

liquid chromatography (LC) A form of elution chromatography in which a sample partitions between a stationary phase of large surface area and a liquid mobile phase that percolates over the stationary phase.

liquid chromatography / mass spectrometry

(LC/MS) An analytical technique in which a high-performance liquid chromatograph (LC) and a mass spectrometer (MS) are combined.

LN2 liquid nitrogen

lock mass A known reference mass in the sample that is used to correct the mass spectral data in an accurate mass experiment and used to perform a real-time secondary mass calibration that corrects the masses of other peaks in a scan. Lock masses with well-defined, symmetrical peaks work best. You can choose to use

internal lock mass

or

external lock mass

.

log file A text file, with a .log file extension, that is used to store lists of information.

M

μ micro (10 -6

)

m meter; milli (10

-3

)

M mega (10

6

)

M

+

molecular ion

MALDI See matrix-assisted laser desorption/ionization

(MALDI)

.

matrix-assisted laser desorption/ionization

(MALDI) A method of ionizing proteins where a direct laser beam is used to facilitate vaporization and ionization while a matrix protects the biomolecule from being destroyed by the laser.

MB Megabyte (1048576 bytes)

MH

+

protonated molecular ion

microscan One mass analysis (ion injection and storage or scan-out of ions) followed by ion detection.

Microscans are summed, to produce one scan, to improve the signal-to-noise ratio of the mass spectral data. The number of microscans per scan is an important factor in determining the overall scan time.

min minute

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-7

Glossary: mL–Orbitrap mass analyzer

mL milliliter

mm millimeter

MRFA A peptide with the amino acid sequence methionine–arginine–phenylalanine–alanine.

MS mass spectrometer; mass spectrometry

MS MS n

power: where n = 1

MS scan modes Scan modes in which only one stage of mass analysis is performed. The scan types used with

the MS scan modes are full-scan type

and

selected ion monitoring (SIM) scan type

.

MSDS Material Safety Data Sheet

MS/MS Mass spectrometry/mass spectrometry, or tandem mass spectrometry is an analytical technique that involves two stages of mass analysis. In the first stage, ions formed in the ion source are analyzed by an initial analyzer. In the second stage, the mass-selected ions are fragmented and the resultant ionic fragments are mass analyzed.

MS n

scan mode The scan power equal to 1 to 10, where the scan power is the power n in the expression

MS n

. MS n

is the most general expression for the scan mode, which can include the following:

• The scan mode corresponding to the one stage of mass analysis in a single-stage full-scan experiment or a selected ion monitoring (SIM) experiment

• The scan mode corresponding to the two stages of mass analysis in a two-stage full-scan experiment or a selected reaction monitoring (SRM) experiment

• The scan mode corresponding to the three to ten stages of mass analysis (n = 3 to n = 10) in a multi-stage full-scan experiment or a consecutive reaction monitoring (CRM) experiment

See also

MS scan modes and MS/MS .

multipole A symmetrical, parallel array of (usually) four, six, or eight cylindrical rods that acts as an ion transmission device. An RF voltage and DC offset voltage are applied to the rods to create an electrostatic field that efficiently transmits ions along the axis of the multipole rods.

m/z Mass-to-charge ratio. An abbreviation used to denote the quantity formed by dividing the mass of an ion (in u) by the number of charges carried by the ion.

For example, for the ion C

7

H

7

2+

, m/z=45.5.

N

n nano (10

-9

)

nanospray ionization (NSI) A type of electrospray ionization (ESI) that accommodates very low flow rates of sample and solvent on the order of 1 to

20 nL/min (for static nanospray) or 100 to 1000 nL/min (for dynamic nanospray).

NCBI National Center for Biotechnology Information

(USA)

NIST National Institute of Standards and Technology

(USA)

NMR Normal Mass Range

NSI See nanospray ionization (NSI) .

O

octapole An octagonal array of cylindrical rods that acts as an ion transmission device. An RF voltage and

DC offset voltage applied to the rods create an electrostatic field that transmits the ions along the axis of the octapole rods.

OD

outside diameter

Orbitrap mass analyzer The Orbitrap™ mass analyzer consists of a spindle-shape central electrode surrounded by a pair of bell-shaped outer electrodes.

Ions inside the mass analyzer orbit in stable trajectories around the central electrode with harmonic oscillations along it.

r z

Two detection electrodes record an image current of the ions as they undergo harmonic oscillations. A

Fourier transformation extracts different harmonic frequencies from the image current. An ion's

G-8

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

mass-to-charge ratio m/z is related to the frequency f of its harmonic oscillations and to the instrumental constant k by:

m/z = k/f

2

OT Orbitrap

See

Orbitrap mass analyzer

.

OVC outer vacuum case

ohm

P

p pico (10

-12

)

Pa pascal

parent ion An electrically charged molecular species that can dissociate to form fragments. The fragments can be electrically charged or neutral species. A parent ion can be a molecular ion or an electrically charged fragment of a molecular ion. Also called a precursor ion.

parent mass The mass-to-charge ratio of a parent ion.

The location of the center of a target parent-ion peak in mass-to-charge ratio (m/z) units. Also known as precursor mass.

See also: parent ion .

PCB printed circuit board

PDA detector Photodiode Array detector is a linear array of discrete photodiodes on an integrated circuit chip. It is placed at the image plane of a spectrometer to allow a range of wavelengths to be detected simultaneously.

PE protective earth

PID proportional / integral / differential

P/N part number

p-p peak-to-peak voltage

ppm parts per million

PQD pulsed-Q dissociation

Glossary: OT–retention time (RT)

precursor ion An electrically charged molecular species that can dissociate to form fragments. The fragments can be electrically charged or neutral species. A precursor ion (PR) can be a molecular ion or an electrically charged fragment of a molecular ion. Also known as parent ion.

precursor mass Mass of the corresponding precursor

(or parent) ion or molecule.

psig pounds per square inch, gauge

PTM posttranslational modification

pulsed Q dissociation (PQD) Collision-induced dissociation that involves precursor ion activation at high Q, a time delay to allow the precursor to fragment, and then a rapid pulse to low Q where all fragment ions are trapped. The fragment ions can then be scanned out of the ion trap mass analyzer and detected. PQD eliminates the “1/3 Rule” low mass cut-off for MS/MS data.

Q

quadrupole A symmetrical, parallel array of four hyperbolic rods that acts as a mass analyzer or an ion transmission device. As a mass analyzer, one pair of opposing rods has an oscillating radio frequency (RF) voltage superimposed on a positive direct current

(DC) voltage. The other pair has a negative DC voltage and an RF voltage that is 180 degrees out of phase with the first pair of rods. This creates an electrical field (the quadrupole field) that efficiently transmits ions of selected mass-to-charge ratios along the axis of the quadrupole rods.

R

RAM random access memory

raw data Uncorrected liquid chromatograph and mass spectrometer data obtained during an acquisition.

Xcalibur and Xcalibur-based software store this data in a file that has a .raw file extension.

resolution The ability to distinguish between two points on the wavelength or mass axis.

retention time (RT) The time after injection at which a compound elutes. The total time that the compound is retained on the chromatograph column.

Thermo Fisher Scientific Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-9

Glossary: RF–SIM

RF radio frequency

RF lens A multipole rod assembly that is operated with only radio frequency (RF) voltage on the rods. In this type of device, virtually all ions have stable trajectories and pass through the assembly.

RF voltage An AC voltage of constant frequency and variable amplitude that is applied to the ring electrode or endcaps of the mass analyzer or to the rods of a multipole. Because the frequency of this AC voltage is in the radio frequency (RF) range, it is referred to as

RF voltage.

RMS root mean square

ROM read-only memory

rotary-vane pump A mechanical vacuum pump that establishes the vacuum necessary for the proper operation of the turbomolecular pump. (Also called a roughing pump or forepump.)

RS-232 An accepted industry standard for serial communication connections. This Recommended

Standard (RS) defines the specific lines and signal characteristics used by serial communications controllers to standardize the transmission of serial data between devices.

RT An abbreviated form of the phrase

retention time

(RT)

. This shortened form is used to save space when the retention time (in minutes) is displayed in a header, for example, RT: 0.00-3.75.

S

s second

scan mode and scan type combinations A function that coordinates the three processes in the

MS detector: ionization, mass analysis, and ion detection. You can combine the various scan modes and scan types to perform a wide variety of experiments.

selected ion monitoring (SIM) scan type A scan type in which the mass spectrometer acquires and records ion current at only one or a few selected mass-to-charge ratio values.

See also selected reaction monitoring (SRM) scan type .

selected reaction monitoring (SRM) scan type A scan type with two stages of mass analysis and in which a particular reaction or set of reactions, such as the fragmentation of an ion or the loss of a neutral moiety, is monitored. In SRM a limited number of product ions is monitored.

SEM secondary electron multiplier

Serial Peripheral Interface (SPI) hardware and firmware communications protocol

serial port An input/output location (channel) for serial data transmission.

sheath gas The inner coaxial gas (nitrogen), which is used in the API source to help nebulize the sample solution into a fine mist as the sample solution exits the ESI or APCI nozzle.

sheath gas flow rate The rate of flow of sheath gas into the API source. A measurement of the relative flow rate (in arbitrary units) that needs to be provided at the sheath gas inlet to provide the required flow of

sheath gas

to the ESI or APCI nozzle.

sheath gas inlet An inlet in the API probe where

sheath gas is introduced into the probe.

sheath gas plumbing The gas plumbing that delivers

sheath gas

to the ESI or APCI nozzle.

sheath gas pressure The rate of flow of sheath gas

(nitrogen) into the API source. A measurement of the relative flow rate (in arbitrary units) that needs to be provided at the sheath gas inlet to provide the required flow of inner coaxial nitrogen gas to the ESI or APCI nozzle. A software-controlled proportional valve regulates the flow rate.

See also sheath gas

.

sheath gas valve A valve that controls the flow of

sheath gas into the API source. The sheath gas valve is

controlled by the data system.

signal-to-noise ratio (S/N) The ratio of the signal height (S) to the noise height (N). The signal height is the baseline corrected peak height. The noise height is the peak-to-peak height of the baseline noise.

SIM See selected ion monitoring (SIM) scan type .

G-10

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

skimmer A vacuum baffle between the higher pressure capillary-skimmer region and the lower pressure region. The aperture of the skimmer is offset with respect to the bore of the ion transfer capillary.

source CID A technique for fragmenting ions in an

atmospheric pressure ionization (API)

source.

Collisions occur between the ion and the background gas, which increase the internal energy of the ion and stimulate its dissociation.

SPI See

Serial Peripheral Interface (SPI) .

SRM See selected reaction monitoring (SRM) scan type .

sweep gas Nitrogen gas that flows out from behind the sweep cone in the API source. Sweep gas aids in solvent declustering and adduct reduction.

See also sweep gas flow rate .

sweep gas flow rate The rate of flow of sweep gas into the API source. A measurement of the relative flow rate (in arbitrary units) to provide the required flow of nitrogen gas to the sweep cone of the API source.

See also sweep gas

.

syringe pump A device that delivers a solution from a syringe at a specified rate.

T

T Tesla

target compound A compound that you want to identify or quantitate or that a specific protocol (for example, an EPA method) requires that you look for.

Target compounds are also called analytes, or target analytes.

TIC See total ion current (TIC)

.

TMP See

turbomolecular pump

.

Torr A unit of pressure, equal to 1 mm of mercury and

133.32 Pa.

total ion current (TIC) The sum of the ion current intensities across the scan range in a mass spectrum.

tube lens offset The voltage offset from ground that is applied to the tube lens to focus ions toward the opening of the skimmer.

Thermo Fisher Scientific

Glossary: skimmer–vacuum manifold

See also source CID

.

Tune Method A defined set of mass spectrometer tune parameters for the ion source and mass analyzer. Tune methods are defined by using the instrument software’s tune window and saved as tune file.

A tune method stores tune parameters only.

(Calibration parameters are stored separately, not with the tune method.)

tune parameters Instrument parameters whose values vary with the type of experiment.

turbomolecular pump A vacuum pump that provides a high vacuum for the mass spectrometer and detector system.

TWA time weighted average

U

u atomic mass unit

UHV ultra high vacuum

ultra-high performance liquid chromatography

(U-HPLC) See

high performance liquid chromatography (HPLC) .

Ultramark 1621 A mixture of perfluoroalkoxycyclotriphosphazenes used for ion trap calibration and tuning. It provides ESI singly charged peaks at m/z 1022.0, 1122.0, 1222.0, 1322.0, 1422.0,

1522.0, 1622.0, 1722.0, 1822.0, and 1921.9.

UMR Universal Mass Range

V

V volt

V AC volts alternating current

V DC volts direct current

vacuum manifold A thick-walled, aluminum chamber with machined flanges on the front and sides and various electrical feedthroughs and gas inlets that encloses the API stack, ion optics, mass analyzer, and ion detection system.

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

G-11

Glossary: vacuum system–XML (Extensible Markup Language)

vacuum system Components associated with lowering the pressure within the mass spectrometer. A vacuum system includes the vacuum manifold, pumps, pressure gauges, and associated electronics.

vent valve A valve that allows the vacuum manifold to be vented to air or other gases. A solenoid-operated valve.

vol volume

W

w width

W watt

WEEE European Union Waste Electrical and

Electronic Equipment Directive. Provides guidelines for disposal of electronic waste.

X

XML (Extensible Markup Language) A general-purpose markup language that is used to facilitate the sharing of data across different information systems, particularly via the Internet.

G-12

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) Thermo Fisher Scientific

Index

Numerics

00101-08-00006

3-56

00101-08500

1-38

00101-15500

1-38

00101-2500

1-38

00109-02-00020

3-57

00301-01-0013

4-7

00301-15517

4-7

0690280

1-38

119265-0003

3-45

119283-0001

3-46

119683-0100

3-47

12 pin feedthrough harness

3-39

location

3-34 ,

3-37

120320-0030

3-42

1275730

3-11

1275740

3-11

1284050

3-58

23827-0008

3-3

23827-0009

3-3

32000-60340

3-14

3814-6530

3-47

98000-20060

3-56

98000-62006

3-56

3-57

98000-62008

4-7

, A-1

A

A0301-15101

3-5

Active Pirani gauge (APG)

1-35

active temperature control

1-17

actual vial temperature

3-50

aluminum oxide abrasive, number 600

3-14

analog signals

1-53

analyzer chamber temperature

1-62

system

2-10

temperature

1-42

angiotensin I

4-7

anti-aliasing filters

1-51

API source safety interlock switch

2-10

settings

2-13

applicators, cotton-tipped

3-14

Automatic Gain Control (AGC)

1-12 ,

2-15

autosampler

2-8

2-9

auxiliary gas

1-37

Thermo Fisher Scientific axial ion ejection

1-12

axial oscillations

1-15 –

1-16

B

bakeout controls

1-6

– 1-7

timer

1-7

,

3-4 –

3-5

bakeout procedure indication

1-7

starting

1-6

, 3-5

stopping

1-6

,

3-5

base studs

3-41 ,

3-43

bath gas

1-13

bayonet guide

3-30

bayonet lock

3-30

bayonet pin

3-30

buck/boost transformer

1-10

burnout, of filament

3-54

buttons

Display Status View

2-11

On/Standby

2-6

system bakeout

1-6

C

cable tie

1-9

calibration parameters

2-13

CAN bus

1-55

cartridge heaters

3-41

central electrode location

1-14

power supply box

1-42

voltages

1-15

,

1-65

central electrode power supply board cooling

1-17

diagnostic LEDs

1-66

location

1-59

, 1-65

central electrode pulser board diagnostic LEDs

1-62

location

1-59

, 1-61

ceramic lens holder

3-39

ceramic spacer

3-41

charge-sign independent trapping (CSIT)

1-12

,

1-21

circuit breakers

1-6 –

1-7

cleaning instrument surface

3-3

ion source block

3-40

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) I-1

Index: D–E ion source lens assembly

3-33

ion volume

3-21

CLT compartment

1-30

CLT Offset connector

1-59 ,

1-64

CLT RF main board diagnostic LEDs

1-64

, 1-66

function

1-13

location

1-59

,

1-63

CLT RF unit

1-63

CLT RF voltage

1-13

Cold Ion Gauge

1-30

,

1-32

, 1-35 –

1-36 ,

1-45

, 1-48

collision gas

C-Trap

1-13

HCD

1-13

inlet

1-10

linear trap

1-38

Communication LED

1-54

communication link

1-5

condenser filter, of recirculating chiller

3-58

connector, to ETD Interface board

1-22

control elements inlet valve

1-22

instrument

1-5

control panel

1-6

control unit, for turbopumps

1-32

Convectron gauge

ETD Module

1-22

– 1-23 ,

1-25 ,

1-35

linear trap

1-35

cooling water circuit

1-17

, 1-42

flow control sensor

1-42

properties

1-43

temperature

1-42

cover lid, for bakeout controls

1-7

C-Trap description

1-13

gas supply

1-39

cycle time

1-4

D

data acquisition analog board diagnostic LEDs

1-51

layout

1-50

location

1-49

,

1-51

data acquisition digital PCI board diagnostic LEDs

1-50

layout

1-50

location

1-49

1-50

data acquisition unit

1-49

data communication

1-45

data system communication

1-5 ,

2-12

connection

1-9

log file

2-2

I-2

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

DC HV Supply PCB

1-22

– 1-23 ,

1-26

default values, of tune and calibration parameters

2-13

deflector electrode (DE) voltages

1-65

Display Status View button

2-11

distilled water

3-3

drip pan, of ETD forepump

1-34

dynamic range, of instrument

1-4

E

E-clips

3-39

electric power, for recirculating chiller

1-43

electrodynamic squeezing

1-15

electronic boards data acquisition analog

1-51

data acquisition digital PCI

1-50

instrument control

1-52

ion optic supply

1-59

left side

1-59

power distribution

1-53

right side

1-46

electronic connections, to linear trap

1-45

emergency shutdown

2-2

entry housing

3-34

error messages

1-36

, 1-54 ,

1-56

ETD main access panel

3-24

maintenance

3-12

reagent carrier gas supply

1-11

ETD Control PCB

1-22

– 1-23 ,

1-25 –

1-27

ETD forepump cabinet

1-22

connections

1-23 ,

1-34

electrical cord

1-34

power supply

1-24

weight

3-10

ETD Ion Optic Supply board

1-18

1-19

, 1-23 ,

1-46 ,

1-49

ETD Module forepump receptacle

1-24

Heater Control PCB

1-26

Interface board

1-23

,

1-25

ion gauge

1-23

location

1-19

maintenance

3-12

power panel

1-24

power receptacle

1-24

power supply

1-9

power switch

1-24

service switch

1-24

Standby condition

2-4

ETD power module function

1-23

panel

1-23

, 1-25

ETD Reagent Kit

4-7

ETD side access panel

Thermo Fisher Scientific

interlocks

3-55

removing

3-19

ETD turbopump connections

1-23

, 1-34

controller

1-35

function

1-32

location

1-22

maintenance

3-11

Ethernet

1-9 –

1-10

evacuating, after a complete shutdown

3-4

Exactive Installation Kit

1-38

exhaust hose

1-11 ,

1-34

system

1-11

, 1-33 –

1-34

external calibration

1-4

external connections

1-10

extracting voltage

1-14

extraction, of ion packets

1-14

F

fan filters

1-22 ,

3-57

ferrules, tightening

3-56

filament assembly

3-21

,

3-42

burnout

3-54

emission current

3-42

function

1-26

, 1-28

wire

3-44

filter, for cooling water

1-42

fingerprints, removing

3-3

flatapole

1-32

flow control sensor

1-42

UHP nitrogen

1-23

,

1-26

flow rates cooling water

1-42

HCD collision gas

1-39

flow restrictors

1-29

fluid bag filter, of chiller

3-58

fluoranthene

4-7 ,

A-1

focusing potentials

1-67

foreline hose connection

3-34

forepump electrical cord

1-34

forepumps cabinet

1-2 ,

1-6

, 1-33

effluent

1-33

linear trap

1-30

1-31 ,

1-33

location

1-6 ,

1-12

,

1-33

oil level

1-33

oil mist filters

1-33 ,

3-11

power supply

1-33

switches

1-33

forevacuum tube

1-34

front panel

1-3

Thermo Fisher Scientific

Index: F–H front side, LEDs

1-5

FT Electronics switch functions

1-56

location

1-8

fused silica tubing from lower oven

3-56

from upper oven

3-56

in ETD Module

1-29

G

gas ballast

1-33

gas pressures

2-10

gas supply

C-Trap

1-39

helium

1-10

nitrogen

1-10

schematics

1-37

gas valves

3-56

gate voltage

1-60

gloves

3-2

ground wires

1-46

guide bar function

1-22

,

3-34

handle

3-23 –

3-24

opening

3-23 –

3-24 ,

3-45

H

handling, hot pump oil

3-10

harmonic oscillations, in Orbitrap

1-15

hazardous materials

1-33

HCD collision gas port

1-37

flow rate, of collision gas

1-39

fragment spectra

1-18

housing

1-30 ,

1-32

HCD cell description

1-18

supply voltages

1-46

heated dual restrictor enclosure

1-29

heated transfer line

1-29

heater control

1-56

Heater Control PCB

1-22

1-23

, 1-27

heater ring

3-41

heating element

1-42

helium gas capillary

1-39

gas pressure

1-38

inlet

1-10 ,

1-37

purging the line

2-11

supply

1-10

high voltage power supply board diagnostic LEDs

1-68

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

I-3

Index: I–L function

1-13

layout

1-67

location

1-59

,

1-66

voltages

1-67

high voltage, at PCBs

1-44

I

image current

1-15 –

1-16

,

1-48

inlet port, for UHP nitrogen

1-22

inlet valve block

3-34

knob

3-24

,

3-34 ,

3-45

lever

1-22

, 3-23 –

3-24 ,

3-34

,

3-45

plug

3-24 ,

3-34

,

3-45

seal kit

3-45

seal tool

3-46

solenoid

1-22 ,

3-34

installation kit, for the reagent inlet module

3-56

instrument controls

1-6

diagnostics

1-44

forevacuum measurement

1-35

high vacuum measurement

1-35

operating voltage

1-9

parts

4-2

rear side

1-6

right side

1-9

shutdown

1-53

switching off

1-9 ,

2-2

instrument control board diagnostic LEDs

1-53

location

1-46

,

1-49

,

1-52

software status LEDs

1-53

internal calibration

1-4

internal computer add-ons

1-50

– 1-51

data communication

1-45

location

1-46

,

1-49

rebooting

2-12

timer

1-50

ion dephasing

1-17

ion gauge, for ETD Module

1-22

ion optic supply board diagnostic LEDs

1-60

location

1-59

ion optics

1-12

ion oscillation

1-14

ion packets

1-14 ,

1-16

ion source assembly

3-37

block

3-21

,

3-39

, 3-41 ,

3-43

filament

3-41 ,

3-43

filament assembly

3-42

lens assembly

3-39 ,

3-43

lenses

3-21

I-4

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

PCB

3-39 ,

3-41

,

3-43

schematics

1-23

springs

3-39

ion trajectory

1-14

ion volume alignment arrow

3-30

cleaning

3-21

key thumbscrew

3-41

location

1-23 ,

1-29

temperature

3-28

ion volume assembly, cleaning frequency

3-21

ion volume tool alignment arrow

3-30

components

3-23

handle

1-22

,

3-25

usage

3-21

,

3-27

ionization techniques

1-12

ions detection

1-16

electrodynamic squeezing

1-15

image current

1-16

packet shape

1-16

– 1-17

L

laboratory exhaust system

1-33 –

1-34

gas supplies

1-10

ventilation

1-38

LC

2-6 –

2-7

leak checking

1-26 ,

1-40

LEDs power control

1-7

system status

1-5

, 1-7

vacuum

1-5

left side panel, of instrument

1-3

lens voltages

1-66

line power

1-9

linear trap collision gas

1-38

Communication LED

2-9

, 2-12

connections

1-53

description

1-12

electronics

1-45

forepumps

1-31

,

1-33

LEDs

1-5

location

1-2

,

1-19

maintenance

3-1

Power LED

2-9

,

2-12

power panel

1-6 ,

1-33

Reset button

2-12

System LED

2-10 ,

2-12

turbopump

1-32

Vacuum LED

2-10

vacuum measurement

1-35

vent valve

1-36

, 1-39 ,

2-2

2-3

Thermo Fisher Scientific

Link Port Signal line

1-52

log file

2-2

lower oven

3-56

M

magnet support

3-21

magnet yoke

3-39

magnets, in ion source

3-21 ,

3-39

main circuit breaker

2-8

main power switch function

1-9 ,

1-56

location

1-6

Off position

2-2

securing

1-9

status

1-5

main RF supply

1-63

mains failure

1-57

,

2-2 ,

3-4

mains supply for ETD Module

1-9

for instrument

1-9

maintenance

API source

1-12

cooling circuit

3-58

linear trap

3-1

procedures

3-2

reagent ion source

3-20

recirculating chiller

3-58

vacuum system

3-4

mass accuracy

1-4

mass range

1-4

Material Safety Data Sheet (MSDS)

3-48

micro controller

1-52

– 1-53

MS/MS

1-4

multiple socket outlets

1-7 ,

1-56 ,

2-2

N

nitrogen

CLT

1-37

connection to source

1-38

cooling gas

1-28

gas flow

1-39

inlet

1-10

pressure

1-39

pressure regulator

1-39

– 1-40

supply

1-10

tubing

1-39

venting

1-37

O

octapole RF voltages

1-60

oil

Thermo Fisher Scientific

Index: M–P level

1-33

mist filters

1-33 –

1-34 ,

3-11

On/Standby button

2-4 ,

2-6

, 3-22

operating vacuum

1-5

Orbitrap applied voltages

1-13

central electrode

1-61

chamber

1-31

control LEDs

1-6

detection electrodes

1-61

differential pumping

1-14

electrodes

1-15

Instrument Control board

1-23

ion extraction

1-14

ion trajectories

1-16

layout

1-13

lenses

1-14

measuring principle

1-14

– 1-15

voltages

1-13

,

1-16

output current, of preamplifier

1-48

P

padlock, for main power switch

1-9

parameters calibration

2-13

default values

2-13

tune

2-13

part numbers

4-1

Peltier elements function

1-17

,

1-42

, 1-62

location

1-42

, 1-65

temperature

1-63

water supply

1-32 ,

1-48

Penning gauge

1-56

peripherals power outlet

1-23

– 1-24

Pirani gauge

1-30 –

1-31

,

1-36

,

1-56

position, of inlet valve lever

3-34

power connector

1-6 ,

1-10

connector for linear trap

1-12

control LEDs

1-8

control panel

1-7

– 1-8

panel

1-6

supply for linear trap

1-12

power distribution operating states

1-56

resetting

1-36

working modes

1-56

power distribution board control

1-8

function

1-42

layout

1-54

location

1-46

, 1-53

power supply

1-7

, 1-56

status LEDs

1-55

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A)

I-5

Index: Q–S power fail detector

2-3

Power LED

1-5

power module

1-22

power outlet, for peripheral devices

1-9

1-10

power supply data system

1-9

ETD Module

1-9

power supply 1 board diagnostic LEDs

1-58

layout

1-57

location

1-46

,

1-57

power supply 2 board diagnostic LEDs

1-52

location

1-49

preamplifier cooling

1-42

diagnostic LEDs

1-47

, 1-49

location

1-32

,

1-46

,

1-48

pressure readings, in ETD Module

1-35

pressure regulator location

1-40

nitrogen

1-39

– 1-40

preventive maintenance

2-8

, 3-2

printed circuit boards

1-44

proton transfer reactions

1-21

pumping, the system

2-9

, 3-4

pumps exhaust

1-11

forevacuum

1-33

manuals

3-5 ,

3-11

oil mist filters

1-33

purging, helium line

2-11

Q

quadrupole mass filter

1-21

quality, of vacuum

1-53

R

reagent heaters

1-22 –

1-23 ,

1-26

– 1-28

reagent inlet cover

3-55

reagent inlet source heating unit

3-51

location

3-52

reagent ion source cleaning frequency

3-13

description

1-28 –

1-29

flow restrictors

3-54

maintenance

3-20

maintenance tools

3-14

Reagent Ion Source dialog box

1-27

, 2-4

Reagent Ion Source instrument control icon

2-4 ,

3-22

Reagent Ion Source On check box

1-27 –

1-28

I-6

Orbitrap Elite Hardware Manual (P/N 1288170, Revision A) reagent vapor, in the carrier gas

1-27

reagent vials

1-29

rebooting, of instrument

2-2

recirculating chiller condenser filter

3-58

connections

1-4

description

1-43

fluid bag filter

3-58

maintenance

3-58

reflector DC voltages

1-60

removing

ETD main access panel

3-18

ETD side access panel

3-19

gases

2-10 ,

3-4

stains

3-3

repair covering letter

3-3

replacing chiller operating fluid

3-58

filter cartridge

3-58

inlet valve components

3-45

ion source filament

3-42

operating fluid reservoir of turbopumps

3-11

reagent vials

3-48

turbopump operating fluid

3-11

reservoir, of recirculating chiller

3-58

resetting instrument

2-12

system parameters

2-13

tune and calibration parameters

2-13

resolution, of instrument

1-4

restrictor oven cover

3-55

oven heater

1-26

RF CLT main board

1-66

RF off & feedback board

1-59 ,

1-64

RF output control

1-59

RF voltage supply

1-63

right side panel, of instrument

1-3

S

safety features

1-25

interlock switch

2-10

problem

3-54

sample inlet aperture

3-41

secondary electrons

1-26

SEM detector

1-12

serial port connector

1-53

service switch, of linear trap

1-8

setting up, conditions for operation

2-10

sheath gas

1-37

shutdown

1-57

,

2-7 ,

2-9

signal communication

1-45

software

Thermo Fisher Scientific

debugging

1-53

function

1-42

, 1-44

status LEDs of the instrument control board

1-53

Tune Plus window

2-6

specifications, of instrument

1-4

spectrum

1-17

SPI bus function

1-45

termination board

1-63 –

1-64

,

1-66

,

1-68

spring clip thumb screw

3-39 ,

3-41

stainless steel parts, cleaning

3-14

stains, removing

3-3

Standby condition

1-28 ,

2-4

starting up

ETD Module

2-11

instrument

2-9

status LEDs, of power distribution board

1-55

Status View

3-22

sweep gas

1-37

switches forepumps

1-33

FT Electronics

1-8 ,

3-4

linear trap

1-8

main power

1-9

vacuum pumps

1-8

switching on, the vacuum system

1-36

system bakeout

1-5

– 1-6 ,

1-36

, 1-48

, 2-9

,

3-4

bakeout timer

1-6

buttons for bakeout

1-6

heating

1-36

pump down time

2-10

rebooting

2-2

resetting

2-12

shutdown

2-2

Standby

2-4

starting up

2-9

status LEDs

1-5

,

1-54

timing

1-50

venting

1-39

,

2-2

system status LEDs linear trap

1-2

Orbitrap Elite

1-2

T

temperature analyzer chamber

1-62

control

1-17

differential

1-17

monitoring

3-51

sensor

3-41

temperature controller board diagnostic LEDs

1-63

function

1-17

layout

1-62

Thermo Fisher Scientific

Index: T–V location

1-59

, 1-62

thermoelectric elements

1-17

thumbscrews

3-37 ,

3-39

tools cleanliness

3-3

for cleaning stainless steel parts

3-14

for cleaning the ion volume

3-21

reagent ion source

3-14

top lids

ETD Module

1-3

MS

1-3 –

1-4

transfer chamber

1-12

transfer line bellows

3-37

heater

1-26

inlet

3-56

location

1-23

transfer multipole

1-19 –

1-21 ,

1-32

trap voltage

1-60

triple gas filter

1-41

tune parameters

2-13

Tune Plus window buttons

2-6

, 2-11

diagnostics

1-44

turbopumps connections

1-53

controllers

1-32 ,

1-35

error

1-55

HiPace 300

1-30 ,

1-37

,

1-42

HiPace 80

1-30

, 1-37 ,

1-42

linear trap

1-32 ,
