Electrolux | WT420 | User's Manual | Electrolux WT420 User's Manual

REPAIR PARTS MANUAL
MODEL NO. WT420 (PWT420A)
Wheeled Weed Trimmer
532 18 64-85 Rev. 1 06.18.03 BY
Printed in U.S.A.
WEED TRIMMER - - MODEL NUMBER WT420 (PWT420A)
PRODUCT NUMBER 964 77 74-00
29
6
30
19
5
34 35
28
20
33
21
16
7
18
11
26
10
12
27
9
15
15
23
8
9
26
27
1
24
23
24
22
2
38
36
2
3
37
WEED TRIMMER - - MODEL NUMBER WT420 (PWT420A)
PRODUCT NUMBER 964 77 74-00
KEY
NO.
1
2
3
5
6
7
8
9
10
11
12
15
16
18
19
20
21
22
23
24
26
27
28
29
30
33
34
35
36
37
38
----
PART
NO.
--532 15 04-06
532 17 94-66
532 18 17-01
532 17 42-74
532 17 40-30
532 18 67-54
532 15 00-78
532 18 67-55
532 17 09-80
532 13 63-76
532 17 97-51
532 17 95-85
532 06 64-26
532 17 69-83
532 17 49-34
532 15 87-55
532 18 67-56
532 15 00-78
532 05 21-60
532 17 02-58
532 08 39-23
532 18 16-99
532 17 40-34
532 17 83-03
532 13 20-04
532 12 52-03
532 75 06-34
532 85 10-84
532 85 02-63
532 85 10-74
532 18 74-78
532 18 74-79
532 18 64-85
DESCRIPTION
Engine, Tecumseh, Model Number LEV120
(Order parts from Engine Manufacturer)
Bolt, Engine Mounting 3/8-16
Pulley, Engine (Includes Setscrew, Key #4)
Cover, Engine, with Screen
Knob, Engine Cover
Stud, Engine Cover
Handle, Lower
Screw, Hex Washer Head 5/16-18 x .75
Handle, Upper
Bolt, Handle
Knob, Handle
Handle Adjuster Assembly
Guide, Rope
Wire Tire
Control Bar
Throttle Control
Screw, Hex Washer Head
Axle Shaft Assembly
Screw, Hex Washer Head 5/16-18 x .75
Washer, Axle
Wheel, 14 x 2
Hex Flange Locknut 3/8-16
Drive Control Cable
Decal, Warning
Decal, Engine Cover
Nut
Bracket, Upstop
Screw, Thd. Roll. #10-24 x 5/8
Screw, Hex Head 3/8-24 x 1
Washer, Lock
Washer, Flat, Hardened
Operator’s Manual, European
Operator's Manual, Scandanivan
Repair Parts Manual
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
3
WEED TRIMMER - - MODEL NUMBER WT420 (PWT420A)
PRODUCT NUMBER 964 77 74-00
51
52
42
14
20 44
21
43
1
17
4
40
15
8
12
5
41
6
45
7
10
13
11
9
19
22
23
24
25
26
27*
28
29
16
30*
18
3
32
34
27
31
33
46
37
27
38
2
39
36
4
35
WEED TRIMMER - - MODEL NUMBER WT420 (PWT420A)
PRODUCT NUMBER 964 77 74-00
KEY
NO.
PART
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
532 18 67-60
532 17 40-40
532 17 37-15
532 18 43-54
532 18 67-51
532 16 60-42
532 17 37-16
532 75 15-92
532 16 60-43
532 16 08-29
532 15 55-52
532 17 37-17
532 17 47-19
532 14 52-12
532 17 38-11
532 18 02-68
532 05 78-08
532 17 88-48
532 18 73-36
532 17 83-90
532 14 97-46
873 80 06-00
810 04 06-00
532 05 17-85
532 18 03-40
532 17 25-51
532 17 45-49
532 17 25-20
532 18 67-52
532 17 45-43
31
32
33
34
35
532 17 45-81
532 17 69-73
532 17 25-19
532 18 03-38
532 18 22-17
36
37
38
39
40
532 17 25-16
532 17 45-80
532 17 25-23
532 18 03-34
532 18 03-33
41
42
43
44
45
46
47
51
52
532 17 40-29
532 18 22-04
532 17 40-42
532 17 82-16
532 18 67-53
817 06 04-08
532 18 22-05
532 17 98-75
532 17 88-48
DESCRIPTION
Chassis Assembly
Line, Trimmer .155 diameter x 18.75 long
Screw, Self-Tapping 5/16-18 x 1
V-Belt
Bracket, Idler
Pulley, Idler, V-Groove
Bolt, Hex Head 3/8-16 x 1.25
Locknut, Hex 3/8-16
Pulley, Idler, Flat
Bolt, Shoulder
Locknut 5/16-18
Spacer
Bolt, Shoulder
Locknut, Flange
Spring, Return
Deflector, Bottom
Screw 1/4-20 x 1/2
Screw #10-24 x 3/4
Belt Keeper
Cover, Chassis, Top
Screw #10-24 x 1-3/4
Nut, Hex 3/8-24 UNF
Washer, Lock 3/8
Washer, Flat 3/8
Pulley, Driven
Spacer, Pulley
Bearing
Jackshaft
Cover, Chassis, Bottom
Spindle Housing Assembly
(* Includes Upper Bearing, Key Number 27)
Ring, Retaining, External, 17mm
Spring, Locking Plate
Locking Plate
Carrier Plate Assembly
Mow Ball Assembly
(Includes Key Numbers 27, 37 and 38)
Cover, Bearing
Ring, Retaining, Internal, 40mm
Mow Ball
Bolt, Mow Ball
Spindle Assembly, Complete
(Includes Key Numbers 22-28 and 30-39)
Spacer
Decal, Safety
Decal, Instruction
Decal, Chassis Cover
Belt Keeper, Bottom
Screw, Self-Tapping
Decal, Instruction
Deflector, Rear
Screw
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
5
SERVICE NOTES
6
SERVICE NOTES
7
LIMITED WARRANTY
The Manufacturer warrants to the original consumer purchaser that this product as
manufactured is free from defects in materials and workmanship. For a period of
two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing
parts, any part which we find to be defective due to materials or workmanship. This
Warranty is subject to the following limitations and exclusions.
1. This warranty does not apply to the engine. Please refer to the applicable
manufacturer's warranty on these items.
2. Transportation charges for the movement of any power equipment unit or attachment are the responsibility of the purchaser. Transportation charges for any parts
submitted for replacement under this warranty must be paid by the purchaser
unless such return is requested by your dealer.
3. The Warranty period for any products used for rental or commercial purposes is
limited to 45 days from the date of original purchase.
4. This Warranty applies only to products which have been properly assembled,
adjusted, operated, and maintained in accordance with the instructions furnished.
This Warranty does not apply to any product which has been subjected to alteration, misuse, abuse, improper assembly or installation, delivery damage, or to
normal wear of the product.
5. Exclusions: Excluded from this Warranty are belts, rotating lines, rotating line
adapters, normal wear, normal adjustments, standard hardware and normal
maintenance.
6. In case of any problem within the boundaries of this warranty, contact the nearest department store, indicate the model number, serial number and the date of
purchase of your machine. This warranty does not apply to accidental damages.
All implicit warranties are limited to the same time frames. Or contact:
E.M. Services
54 Rue Lambrechts
92400 Courbevoie
France
Telephone: (1) 46678078
Fax: (1) 46678095
THIS WARRANTY DOES NOT APPLY TO INCIDENTAL OR CONSEQUENTIAL DAMAGES.
ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME PERIODS STATED
HEREIN.
