APC Series Pure Sine Wave Inveter
APC pure sine wave inveter is the latest model presented by Zhejiang Eifesun Energy Technology Co., Ltd.. Developed on the base of our previous PSW 7
series, the APC charger has Achieved significant improvements on battery charging, AC transfer,ect. By adopting DIP(dual in-line package)switch,the APC pure
sine wave inverter provides more smart options for users to customize the performance of the device.
Features of APC Pure Sine Wave Inverter,Charger
1. High overload ability of our APC charger is up to 300% rated power(20sec.)
2. APC pure sine wave inverter adopts low quiescent current, and power saver mode to reduce power consumption to 10W(3s sensing cycle)/3W( 30s sensing
cycle)*. It can extract max.power from various batteries with different protections, and low voltage trip can be selected(9.5V/10V or 10V/10.5V)
3. Uses PFC(power factor correction)for charger,which has less power comsumption than conventional units.
4. It has 15s delay before transfer when AC resumes, and overload protection when our APC pure sine wave inverter equips with generator.
5.10ms typical transfer time between battery and AC, which guarantees power continuity of APC charger. Uses selectable input AC voltage(184-253V or 154253V)for different kinds of loads.
6. Our APC charger allows start up and through power with depleted batteries. Its powerful charge rates up to 90amp**.
7. It can offer 3-step intelligent battery charging, and equipped with 8 preset battery type selector for totally flat batteries.
8. LCD status display,battery/AC priority switch,USB communication port are available for our APC pure sine wave inverter, it also has 17 alrms/warnings for
easier operation and trouble-shooting, and ability to switch the unit on/off. In addition,selected/deselected power saver mode can be used too.
Note:*For 1KW one. ** For some models
Electrical Specifications of the APC Series Pure Sine Wave Inverter
Model
APC 1000W
APC 1500W
APC 2000W
APC 3000W
Continuous Output Power
1000W
1500W
2000W
3000W
4000W
5000W
6000W
Surge Rating(20s)
3000W
4500W
6000W
9000W
12000W
15000W
18000W
1HP
1.5HP
2HP
3HP
4HP
5HP
6HP
Capable of Starting Electric Motor
Inverter
Output
Output Waveform
Pure Sine Wave/same as input(Bypass Mode)
Nominal Efficiency
>88%(Peak)
Line Mode Efficiency
Power Factor
100-110-120Vac/220-230-240Vac
±10% RMS
Output Frequency
50/60HZ±0.3HZ
Short Circuit Protection
Yes, Current Limit Function(Fault after 1sec)
Typical Transfer Time
10ms(Max)
THD
<10%
12.0Vdc
Nominal Input Voltage
(*2for 24Vdc,*4 for 48Vdc)
Minimum Start Voltage
10.0Vdc
Low Battery Alarm
10.5Vdc/11.0Vdc
Low Battery Trip
10.0Vdc/10.5Vdc
High Voltage Alrm & Fault
16.0Vdc
High DC Input Recovery
15.5Vdc
Low Battery Voltage Recovery
13.0Vdc
Idle Consumption-Search Mode
<25w when Power Saver On
Input Voltage Range
Wide:90-135Vac/164-243Vac; Narrow:100-135Vac/194-243Vac
Output Voltage
Charger
Depends on Battery Type
10A
10A
10A
20A
20A
30A
Max Charge Rate
35A/70-90A Max(Charger Current Control)
Over Charge Protection Shutdown
15.7V for 12Vdc(*2 for 24Vdc,*4 for 48Vdc)
Charger Curve(4 stage constant
current) 4 step digital control
Battery Types(*2 for 24 Vdc, *4 for 48 Vdc
Battery Type
APC 6000W
0.9-1.0
Norminal Output Voltage RMS
Charger Breaker Rating
APC 5000W
>95%
Output Voltage Regulation
DC Input
APC 4000W
Fast Vd
Float Vdc
30A
Charger
Gel USA
14.0
13.7
A.G.M 1
14.1
13.4
A.G.M 2
14.6
13.7
Sealed Lead Acid
14.4
13.6
Gel Euro
14.4
13.8
Open Lead Acid
14.8
13.3
Calcium
15.1
13.6
De-sulphation
15.5 for 4hrs
Remmote Control
Yes,Optional
Input Voltage Waveform
Sine Wave(Grid or Generator)
Nominal Voltage
120Vac
230Vac
Low Voltage Trip
80V/90V±4%
184V/154V±4%
Low Voltage Re-engage
90V/100V±4%
194V/164V±4%
High Voltage Trip
140V±4%
253V±4%
High Voltage Re-engage
135V±4%
243V±4%
150Vac
270Vac
Max Input AC Voltage
Bypass & Nominal Input Frequency
Protection Low Freq. Trip
50HZ or 60HZ(Auto Detect)
47±0.3HZ for 50HZ, 57±0.3HZ for 60HZ
Low Freq. Re-engage
48±0.3HZ for 50HZ, 58±0.3HZ for 61HZ
High Freq Trip
55±0.3HZ for 50HZ, 65±0.3HZ for 62HZ
High Freq.Re-engage
54±0.3HZ for 50HZ, 64±0.3HZ for 63HZ
Output Short Cuicuit Protection
Bypass Breaker Rating
Curcuit Breaker
10A
Transfer Switch Rating
15A
20A
Disply
Standard Warranty
40A
40amp for UL
30amp
40amp
Mounting
Mechanical Inverter Weight
Specificatio Shipping Dimensions(L*W*H)
n
Shipping Weight
30A
30amp for UL &TUV
Max. Bypass Current
Inverter Dimentions(L*W*H)
30A
40A
Wall Mount
382*218*179mm
16kg
17kg
520*315*300mm
18kg
19kg
422*218*179mm
20kg
24kg
598*218*179mm
35kg
580*315*300mm
22kg
26kg
45kg
740*315*300mm
37kg
Status LEDs/Status LEDs+LCD
1 Year
45kg
47kg
47kg
