Exam Ref 70-247
Configuring and
Deploying a Private
Cloud
Orin Thomas
PUBLISHED BY
Microsoft Press
A Division of Microsoft Corporation
One Microsoft Way
Redmond, Washington 98052-6399
Copyright © 2014 by Orin Thomas
No part of the contents of this book may be reproduced or transmitted in any form or by any means without
the written permission of the publisher.
Library of Congress Control Number: 2014946866
ISBN: 978-0-7356-8618-2 Printed and bound in the United States of America.
First Printing
Microsoft Press books are available through booksellers and distributors worldwide. If you need support related
to this book, email Microsoft Press Book Support at [email protected] Please tell us what you think of
this book at http://aka.ms/tellpress.
This book is provided “as-is” and expresses the author’s views and opinions. The views, opinions and information
expressed in this book, including URL and other Internet Web site references, may change without notice.
Some examples depicted herein are provided for illustration only and are fictitious. No real association or
connection is intended or should be inferred.
Microsoft and the trademarks listed at http://www.microsoft.com on the “Trademarks” Web page are trademarks
of the Microsoft group of companies. All other marks are property of their respective owners.
Acquisitions Editor: Alison Hirsch
Developmental Editor: Karen Szall
Editorial Production: Troy Mott, Martin Murtonen
Technical Reviewer: Telmo Sampaio
Copyeditor: Christina Rudloff
Indexer: Judy Hoer
Cover: Twist Creative • Seattle
Contents at a glance
Introductionxi
Preparing for the exam
xv
CHAPTER 1
Design and deploy System Center
1
CHAPTER 2
Configure System Center infrastructure
CHAPTER 3
Configure the fabric
153
CHAPTER 4
Configure System Center Integration
217
CHAPTER 5
Configure and deploy virtual machines and services
267
83
Index309
This page intentionally left blank
Contents
Introduction
xi
Microsoft certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Free ebooks from Microsoft Press. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Errata, updates, & book support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
We want to hear from you . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Stay in touch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Preparing for the exam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Chapter 1: Design and deploy System Center
1
Objective 1.1: Design a scalable System Center architecture. . . . . . . . . . . . 1
Understanding System Center 2012 R2 products
2
Examining System Center 2012 R2 high availability
5
Backing up and recovering VMM
6
Objective summary
15
Objective review
15
Objective 1.2: Install the System Center infrastructure . . . . . . . . . . . . . . . . 16
Understanding hardware requirements
17
Software prerequisites
21
Installing System Center 2012 R2 products
29
Objective summary
64
Objective review
65
Objective 1.3: Upgrade System Center components. . . . . . . . . . . . . . . . . . 66
Upgrading or migrating from versions prior to
System Center 2012
66
What do you think of this book? We want to hear from you!
Microsoft is interested in hearing your feedback so we can continually improve our
books and learning resources for you. To participate in a brief online survey, please visit:
www.microsoft.com/learning/booksurvey/
v
Upgrading between System Center 2012,
System Center 2012 SP1, and 2012 R2
72
Objective summary
77
Objective review
77
Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Objective 1.1: Thought experiment
78
Objective 1.1: Review
78
Objective 1.2: Thought experiment
79
Objective 1.2: Review
79
Objective 1.3: Thought experiment
80
Objective 1.3: Review
81
Chapter 2: Configure System Center infrastructure
83
Objective 2.1: Configure System Center components. . . . . . . . . . . . . . . . . 83
Understanding Data Protection Manager
84
Understanding System Center agents
92
Run As accounts and Run As profiles
109
Assigning user roles
114
Understanding Operations Manager watcher nodes
122
Operations Manager gateway servers
123
Objective summary
125
Objective review
126
Objective 2.2: Configure portals and dashboards. . . . . . . . . . . . . . . . . . . . 127
Using App Controller
127
Using Service Manager Self-Service Portal
132
Creating Operations Manager dashboards
133
Application Performance Monitoring
142
Objective summary
148
Objective review
148
Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
vi
Contents
Objective 2.1: Thought experiment
150
Objective 2.1: Review
150
Objective 2.2: Thought experiment
151
Objective 2.2: Review
152
Chapter 3: Configure the fabric
153
Objective 3.1: Configure the storage fabric. . . . . . . . . . . . . . . . . . . . . . . . . 153
Understanding VMM storage
153
Understanding storage classifications
155
Understanding file shares and VMM
156
Creating storage pools from physical disks
160
Provisioning storage logical units
162
Objective summary
163
Objective review
163
Objective 3.2: Configure the network fabric. . . . . . . . . . . . . . . . . . . . . . . . 164
Understanding VMM logical networks
164
Applying logical switches
166
Network virtualization
170
Virtual machine networks
171
Understanding MAC address pools
172
Creating static IP address pools
173
Implementing private VLANS
177
Windows Server Gateway
178
Objective summary
180
Objective review
181
Objective 3.3: Configure and manage the deployment
and update servers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Adding a PXE server to VMM
182
Adding an WSUS server to VMM
193
Objective summary
197
Objective review
198
Objective 3.4: Configure clouds and virtualization hosts . . . . . . . . . . . . . 199
Creating VMM host groups
199
Understanding VMM private clouds
204
Objective summary
209
Objective review
210
Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Objective 3.1: Thought Experiment
211
Objective 3.1: Review
211
Objective 3.2: Thought experiment
212
Contents
vii
Objective 3.2: Review
212
Objective 3.3: Thought Experiment
213
Objective 3.3: Review
213
Objective 3.4: Thought experiment 214
Objective 3.4: Review
214
Chapter 4: Configure System Center Integration
217
Objective 4.1: Configure private cloud integration. . . . . . . . . . . . . . . . . . . 217
Integrating Operations Manager
218
Orchestrator integration packs
227
Configuring other System Center connectors
242
Integrating IPAM with VMM
245
Objective summary
248
Objective review
249
Objective 4.2: Configure integration of private and public clouds . . . . . 250
Understanding Service Provider Foundation
250
Deploying Service Provider Foundation
251
Understanding Microsoft Azure Pack for Windows Server
256
Objective summary
261
Objective review
262
Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
Objective 4.1: Thought experiment
263
Objective 4.1: Review
263
Objective 4.2: Thought experiment
264
Objective 4.2: Review
264
Chapter 5: Configure and deploy virtual machines and services
267
Objective 5.1: Configure profiles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
viii
Contents
Creating hardware profiles
267
Creating guest operating system profiles
272
Creating application profiles
275
Configuring SQL Server profiles
278
Objective summary
280
Objective review
280
Objective 5.2: Create and configure Server App-V packages. . . . . . . . . . 281
Server App-V
281
Understanding Server App-V packages
283
Sequencing applications
283
Deploying a Server App-V package
284
Objective summary
286
Objective review
287
Objective 5.3: Configure and deploy a service . . . . . . . . . . . . . . . . . . . . . . 288
Configuring virtual machine templates
288
Creating service templates
292
Understanding Web Deploy packages
294
SQL DAC packages
294
Objective summary
295
Objective review
296
Objective 5.4: Update a service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
Updating Services in VMM
297
Scaling out a service tier
299
Objective summary
300
Objective review
301
Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Objective 5.1: Thought experiment
302
Objective 5.1: Review
302
Objective 5.2: Thought experiment
303
Objective 5.2: Review
303
Objective 5.3: Thought experiment
305
Objective 5.3: Review
305
Objective 5.4: Thought experiment
306
Objective 5.4: Review
306
Index309
What do you think of this book? We want to hear from you!
Microsoft is interested in hearing your feedback so we can continually improve our
books and learning resources for you. To participate in a brief online survey, please visit:
www.microsoft.com/learning/booksurvey/
Contents
ix
This page intentionally left blank
Introduction
T
he 70-247 exam deals with advanced topics that require candidates to have an excellent
working knowledge of both Windows Server 2012 R2 and the products in the System
Center 2012 R2 suite. Much of the exam comprises topics that even experienced systems
administrators may rarely encounter unless they work with Virtual Machine Manager, Orchestrator, Service Manager, Data Protection Manager, and Operations Manager on a day-to-day
basis. To be successful in taking this exam, a candidate not only needs to know how each of
these products works when used by itself, but how the products in the System Center suite
work together when used to monitor and operate a private cloud.
Candidates for this exam are Information Technology (IT) Professionals who want to validate their advanced Windows Server 2012 R2 operating system and System Center 2012 R2
management skills, configuration skills, and knowledge. To pass this exam, candidates require
strong understanding of how to design a System Center deployment, configure System Center infrastructure, configure fabric resources, configure System Center integration, and how to
configure and deploy virtual machines and services. To pass, candidates require a theoretical
understanding, as well as meaningful practical experience implementing the technologies
involved.
This book covers every exam objective, but it does not cover every exam question. Only
the Microsoft exam team has access to the exam questions themselves and Microsoft
regularly adds new questions to the exam, making it impossible to cover specific questions.
You should consider this book a supplement to your relevant real-world experience and
other study materials. If you encounter a topic in this book that you do not feel completely
comfortable with, use the links you’ll find in text to find more information and take the time
to research and study the topic. Great information is available on TechNet, through MVA
courses, and in blogs and forums.
Microsoft certifications
Microsoft certifications distinguish you by proving your command of a broad set of skills and
experience with current Microsoft products and technologies. The exams and corresponding
certifications are developed to validate your mastery of critical competencies as you design
and develop, or implement and support, solutions with Microsoft products and technologies
both on-premises and in the cloud. Certification brings a variety of benefits to the individual
and to employers and organizations.
Introduction xi
MORE INFO ALL MICROSOFT CERTIFICATIONS
For information about Microsoft certifications, including a full list of available certifications, go to http://www.microsoft.com/learning/en/us/certification/cert-default.aspx.
Free ebooks from Microsoft Press
From technical overviews to in-depth information on special topics, the free ebooks from Microsoft Press cover a wide range of topics. These ebooks are available in PDF, EPUB, and Mobi
for Kindle formats, ready for you to download at:
http://aka.ms/mspressfree
Check back often to see what is new!
Errata, updates, & book support
We’ve made every effort to ensure the accuracy of this book and its companion content. You
can access updates to this book—in the form of a list of submitted errata and their related
corrections—at:
http://aka.ms/ER247/errata
If you discover an error that is not already listed, please submit it to us at the same page.
If you need additional support, email Microsoft Press Book Support at [email protected]
microsoft.com.
Please note that product support for Microsoft software and hardware is not offered
through the previous addresses. For help with Microsoft software or hardware, go to
http://support.microsoft.com.
We want to hear from you
At Microsoft Press, your satisfaction is our top priority, and your feedback our most valuable
asset. Please tell us what you think of this book at:
http://aka.ms/tellpress
The survey is short, and we read every one of your comments and ideas. Thanks in advance for your input!
xii Introduction
Stay in touch
Let’s keep the conversation going! We’re on Twitter: http://twitter.com/MicrosoftPress.
Introduction xiii
This page intentionally left blank
Preparing for the exam
Microsoft certification exams are a great way to build your resume and let the world know
about your level of expertise. Certification exams validate your on-the-job experience and
product knowledge. While there is no substitution for on-the-job experience, preparation
through study and hands-on practice can help you prepare for the exam. We recommend
that you round out your exam preparation plan by using a combination of available study
materials and courses. For example, you might use this Exam Ref and another study guide for
your ‟at home” preparation and take a Microsoft Official Curriculum course for the classroom experience. Choose the combination that you think works best for you.
Note that this Exam Ref is based on publically available information about the exam and
the author’s experience. To safeguard the integrity of the exam, authors do not have access to
the live exam.
Introduction xv
This page intentionally left blank
This page intentionally left blank
CHAPTER 4
Configure System Center
Integration
T
he System Center products integrate with one another. You can leverage the functionality of one product, such as Operations Manager’s performance and availability
monitoring, with the automation capabilities of Orchestrator, and the incident and problem
management functionality of Service Manager. In this chapter you’ll learn how to integrate
several different System Center products, allowing them to build off each other’s functionality. You’ll also learn about Service Provider Foundation, and Microsoft Azure Pack for Windows Server, which allow you to customize the way that users of your private cloud interact
with the infrastructure.
Objectives in this chapter:
■■
Objective 4.1: Configure private cloud integration
■■
Objective 4.2: Configure integration of private and public clouds
Objective 4.1: Configure private cloud integration
This objective deals with integrating Operations Manager with Service Manager, and Virtual
Machine Manager. You’ll also learn about the Orchestrator integration packs (IPs), which
allow you to use each System Center product’s functionality when building automation
runbooks. You’ll learn about other non-Operations Manager connectors that are available,
as well as how to integrate VMM with the new IP address management feature of Windows
Server 2012.
This section covers the following topics:
■■
Integrating Operations Manager
■■
Orchestrator integration packs
■■
Other System Center connectors
■■
Integrating IPAM with VMM
217
Integrating Operations Manager
Operations Manager is Microsoft’s enterprise monitoring solution. When integrated with other products in the System Center suite, you can use it as a source of incidents and problems
for Service Manager, and to extend the management and monitoring functionality of VMM.
You can also use Operations Manager events to trigger Orchestrator runbook automation.
Integrating Operations Manager with Service Manager
The Operations Manager alert connector for Service Manager allows you to automatically
create Service Manager incidents based on Operations Manager alerts. An Operations Manager alert is created in Operations Manager when an object that Operations Manager monitors experiences a change that is deemed worthy of attention, such as a hardware or software
failure occurring on a monitored server. There are two types of Operations Manager connectors for Service Manager: the alert connector, and the configuration item (CI) connector.
The CI connector imports objects that Operations Manager has discovered into the Service
Manager database. Alert connectors bring alert information into Service Manager.
To create the alert connector, perform the following steps:
1. In the Administration workspace of the Server Manager console, click Connectors.
2. On the Tasks pane, click Create Connector, and then click Operations Manager Alert
Connector.
3. On the General page of the Operations Manager Alert Connector Wizard, provide a
name for the alert connector.
4. On the Server Details page, shown in Figure 4-1, specify the name of the Operations
Manager server and a Run As account that has permission to connect to Operations
Manager. Ensure that you use the Test Connection button to verify that the account
works and has appropriate permissions.
FIGURE 4-1 Alert connector configuration
218 Chapter 4
Configure System Center Integration
5. On the Alert Routing Rules page, click Add to add an alert routing rule. An alert rout-
ing rule allows you to specify which Service Manager incident template will be used to
create an incident based on an Operations Manager alert.
6. In the Add Alert Routing Rule dialog box, shown in Figure 4-2, provide the following
information:
■■
■■
■■
■■
Rule Name The name of the alert routing rule.
Template The Service Manager incident template that will be used when creating
the Service Manager incident.
Criteria Type Here you can select the conditions that trigger the alert routing
rule. You can choose between the alert being generated by a specific Operations
Manager management pack, being generated by a specific computer or security
group, a custom field, or an Operations Manager monitoring class.
Select Alert Severity And Priority Allows you to specify the alert priorities and
severities that will trigger the alert routing rule.
FIGURE 4-2 Alert routing rule
Objective 4.1: Configure private cloud integration
Chapter 4
219
7. As Figure 4-3 shows, alerts that don’t match any of your configured rules will automati-
cally be created as incidents using the Operations Manager Incident Template.
FIGURE 4-3 Routing rules
8. On the Schedule page, select the frequency at which Service Manager will query the
Operations Manager server for alerts. You can also configure the connector so that
alerts within Operations Manager will be closed when the incident that relates to the
alert is resolved or closed in Service Manager. You can also configure Service Manager
to automatically mark incidents as Resolved if the incident that triggered the alert in
Operations Manager is closed. Figure 4-4 shows these settings.
220 Chapter 4
Configure System Center Integration
FIGURE 4-4 Schedule settings
9. On the Summary page, review the connector setup, and then create the connector.
10. Once the connector is created, you can modify the alert routing rules by editing the
properties of the connector, as shown in Figure 4-5.
FIGURE 4-5 Connector properties
Objective 4.1: Configure private cloud integration
Chapter 4
221
MORE INFO OPERATIONS MANAGER CONNECTOR FOR SERVICE MANAGER
You can learn more about the Operations Manager Connector for Service Manager at
http://technet.microsoft.com/en-us/library/hh524325.aspx.
Integrating Operations Manager with Virtual Machine Manager
To be able to monitor your organization’s virtualization layer when you are using a System
Center 2012 and System Center 2012 R2 managed private cloud, you need to integrate Operations Manager with Virtual Machine Manager.
Integrating Operations Manager with Virtual Machine Manager provides you with the following dashboards and views, as shown in Figure 4-6:
■■
Cloud Health
■■
Application Health
■■
Application Hosts Health
■■
Host Cluster Health
■■
Host Health
■■
IP Address Pool Health
■■
Library Server Health
■■
Load Balancer Health
■■
MAC Address Pool Health
■■
Service Health
■■
Storage Pool Health
■■
User Role Health
■■
Virtual Machine Health
■■
Virtual Machine Manager Server Health
222 Chapter 4
Configure System Center Integration
FIGURE 4-6 Virtualization dashboards and views
The Virtual Machine Health dashboard is shown in Figure 4-7.
FIGURE 4-7 Virtual Machine Health
Objective 4.1: Configure private cloud integration
Chapter 4
223
Integrating Operations Manager and Virtual Machine Manager also allows you to view the
following performance information:
■■
Cloud Performance
■■
Host Cluster Performance
■■
Host Performance
■■
IP Address Pool Performance
■■
MAC Address Pool Performance
■■
Service Performance
■■
Storage Pool Performance
■■
Virtual Machine Performance
Figure 4-8 shows the Virtual Machine Performance view.
FIGURE 4-8 Virtual Machine Performance
To integrate Operations Manager with Virtual Machine Manager, you need to configure
the connector between VMM and Operations Manager. Prior to configuring the connection
between VMM and Operations Manager, you need to ensure that you perform the following
prerequisite configuration steps:
■■
Install the Operations Manager console on to the VMM server.
224 Chapter 4
Configure System Center Integration
■■
Install the following Operations Manager management packs on the Operations Manager server:
■■
SQL Server Core Library version 6.0.5000.0 or later
■■
Windows Server Internet Information Services Library version 6.0.5000.0 or later
■■
Windows Server Internet Information Services 2003 version 6.0.5000.0 or later
■■
Windows Server 2008 Internet Information Services 7 version 6.0.6539.0 or later
To link VMM and Operations Manager, you need the credentials of an account that is a
member of the Operations Manager Administrators user role, and the credentials of an account that is a member of the VMM Administrator user role. These can be separate accounts
or the same accounts. To configure a connection between VMM and Operations Manager,
perform the following steps:
1. In the Settings workspace of the VMM console, click System Center Settings, and then
click Operations Manager Server.
2. On the ribbon, click Properties.
3. On the Connection To...page of the Add Operations Manager Wizard, type the name
of the Operations Manager server and a Run As account that has the appropriate permissions, as shown in Figure 4-9.
FIGURE 4-9 Connection to Operations Manager
Objective 4.1: Configure private cloud integration
Chapter 4
225
4. On the Connection To VMM page, specify the credentials of the account that will be
used by Operations Manger to connect to the VMM server.
5. Complete the wizard.
Configuring the connection between Operations Manager and VMM automatically loads
the Management Packs, shown in Figure 4-10, which allow you to monitor the health and
performance of your private cloud’s virtualization layer.
FIGURE 4-10 Management packs
MORE INFO OPERATIONS MANAGER INTEGRATION WITH VMM
You can learn more about configuring Operations Manager integration with VMM at
http://technet.microsoft.com/library/hh427287.aspx.
226 Chapter 4
Configure System Center Integration
Orchestrator integration packs
Orchestrator integration packs are collections of tasks that allow you to automate activities with different System Center products. You can download the integration packs for the
System Center 2012 R2 suite of products from Microsoft’s website. Once you’ve downloaded
the integration packs and extracted them to a temporary directory, you can install them by
performing the following steps:
1. In the Orchestrator Deployment Manager, select the Integration Packs node.
2. Right-click the Integration Packs node and click Register IP With The Orchestrator
Management Server. This will launch the Integration Pack Registration Wizard.
3. On the Select Integration Packs Or Hotfixes dialog, click Add.
4. Navigate to the location where you extracted the integration packs. You’ll need to add
one at a time as you can’t add multiple integration packs using this interface. Figure
4-11 shows the integration packs that are available for the System Center 2012 R2
products.
FIGURE 4-11 Integration packs
5. Complete the wizard to add the integration packs. This will involve agreeing to the
license terms for each integration pack.
Objective 4.1: Configure private cloud integration
Chapter 4
227
Once the integration packs have been registered, you need to deploy them to the runbook
server. To deploy integration packs to the runbook server, perform he following tasks.
1. In the Deployment Manager console, select the Integration Packs node and then select
all of the integration packs that you want to deploy to the runbook server.
2. Right-click on the selected integration packs and click Deploy IP To Runbook Server Or
Runbook Designer. This will launch the Integration Pack Deployment Wizard.
3. On the Deploy Integration Packs Or Hotfixes page, select all of the integration packs
that you want to deploy to the runbook server, as shown in Figure 4-12.
FIGURE 4-12 Integration pack deployment
4. On the Computer Selection Details page, specify the address of the runbook server or
Runbook Designer to which you wish to deploy the integration packs.
5. On the Installation Options page, specify when to perform the installation. The default
option, shown in Figure 4-13, is to install the integration packs immediately upon
completion of the wizard.
228 Chapter 4
Configure System Center Integration
FIGURE 4-13 Installation Options
6. Complete the wizard to deploy the integration packs.
Operations Manager integration pack
You can configure Orchestrator to integrate with Operations Manager by configuring a connection to the Operations Manager server from the Orchestrator Management server. When
you do this, you can monitor and collect information from Operations Manager alerts, which
you can use when building Orchestrator runbooks. To integrate Orchestrator with Operations Manager, first install the Operations Manager integration pack. You can download this
integration pack from Microsoft’s website. You’ll also need to install the Operations Manager
console on the server that hosts the Runbook Designer, and verify that you can use it to make
a connection to the Operations Manager server.
Once you’ve performed that step, you configure a connection from the Orchestrator Management server to the Operations Manager Management Group by performing the following
steps:
1. In the Runbook Designer’s Options menu, click SC 2012 Operations Manager.
2. On the Connections tab of the SC 2012 Operations Manager dialog box, click Add.
3. In the Connection dialog box, shown in Figure 4-14, type the name of the connection,
IP address or FQDN of the Operations Manager server, and then provide the credentials of an account that has access to the Operations Manager server.
Objective 4.1: Configure private cloud integration
Chapter 4
229
FIGURE 4-14 Connection configuration
4. On the SC 2012 Operations Manager dialog box, shown in Figure 4-15, click Finish.
FIGURE 4-15 Operations Manager connections
230 Chapter 4
Configure System Center Integration
Once you have configured the connection, you’ll be able to use the activities that are
included in the Operations Manager integration pack when building Orchestrator runbooks.
These activities are shown in Figure 4-16, and have the following functionality:
■■
■■
■■
■■
■■
■■
■■
■■
Create Alert This activity allows you to create an alert in Operations Manager.
Get Alert This activity allows you to extract data from an Operations Manager alert.
Use this activity as the basis of creating runbooks that create incidents in Service Manager by extracting relevant information from alerts and using that information when
creating incidents.
Get Monitor Use this activity to collect monitoring data. You can take the data extracted from this activity and use it to populate incidents in Service Manager.
Monitor Alert Use this activity to watch for specific new or updated Operations
Manager alerts. You might use this when configuring a runbook to have additional
steps taken when specific alerts are raised in Operations Manager during runbook
execution.
Monitor State Use this activity to monitor and run when an object managed by
Operations Manager has its state changed to Warning or Critical. You might use this
when configuring a runbook to have additional steps taken when the state of specific
Operations Manager monitored objects changes during runbook execution.
Start Maintenance Mode This activity allows you to put an Operations Manager
managed object into maintenance mode. Maintenance mode is a special state that
suppresses alerting. For example, you would put a server into maintenance mode when
applying software updates so that Operations Manager alerts aren’t generated by the
software update process.
Stop Maintenance Mode This activity allows you to take an Operations Manager
managed object out of maintenance mode, so that Operations Manager alerts are no
longer suppressed.
Update Alert Use this activity to update an Operations Manager alert with data. For
example, you could update an Operations Manager alert with information provided in
a Service Manager incident.
FIGURE 4-16 Operations Manager activities
Objective 4.1: Configure private cloud integration
Chapter 4
231
Service Manager integration pack
You configure integration between Orchestrator and Service Manager by performing the following steps:
1. Ensure that the Service Manager integration pack is installed on the management
server.
2. Click SC 2012 Service Manager in the Options menu of the Orchestrator Runbook
Designer console.
3. On the Connections tab of the SC 2012 Service Manager dialog box, click Add.
4. In the Connection dialog box, shown in Figure 4-17, provide the following informa-
tion. Ensure that you click Test Connection to verify that the connection to the Service
Manager server functions correctly.
■■
Name Name of the connection to the Service Manager server
■■
Server FQDN of the Service Manager server
■■
Credentials Credentials of an account that has permission to access the Service
Manager server
FIGURE 4-17 Connection properties
5. On the SC 2012 Service Manager dialog box, shown in Figure 4-18, click Finish.
232 Chapter 4
Configure System Center Integration
FIGURE 4-18 Service Manager connection
Once the connection between the Orchestrator and Service Manager server is established,
you can use the integration pack activities, shown in Figure 4-19, to build workflows.
FIGURE 4-19 Service Manager integration pack activities
Objective 4.1: Configure private cloud integration
Chapter 4
233
These activities allow you to do the following:
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
Create Change With Template Use this activity to create a change record using an
existing change template. When you use this activity, mandatory fields in the service
manager change record need to be configured using Orchestrator.
Create Object This activity allows you to create a Service Manager object based on
a defined class. For example, you could use this activity to create a Service Manager
incident, change, or problem record.
Create Incident With Template You can use this activity to create a Service Manager incident based on an existing template. When you use this activity, mandatory fields
in the Service Manager incident record need to be configured using Orchestrator.
Create Related Object You use this activity to create new Service Manager objects
that have relationships to existing Service Manager objects.
Create Relationship This activity allows you to create relationships between Service
Manager elements. For example, you could use it to create a relationship between an
incident and a computer or user. You can also use it to relate multiple incidents with a
Service Manager problem record.
Delete Relationship Use this activity to remove a relationship between Service Manager elements.
Get Activity Allows an Orchestrator runbook to collect activity records based on
specific criteria.
Get Object Use this activity to search for a Service Manager activity, incident, or
change records based on specific criteria.
Get Relationship Allows Orchestrator to generate a list of objects from separate
classes that are related by specific criteria.
Monitor Object Allows you to configure Orchestrator to find new and updated
records based on specific criteria.
Update Activity Allows you to update Service Manager activity records.
Upload Attachment Use this activity to upload a file to an existing Service Manager
object. For example, you might use this activity to upload a log file so that it can be
stored with the incident generated automatically by an Operations Manager alert.
Update Object You can use this activity to modify the values of a Service Manager
object’s properties.
234 Chapter 4
Configure System Center Integration
VMM integration pack
As shown in Figure 4-20, the VMM integration pack contains 45 activities.
FIGURE 4-20 VMM activities for Orchestrator
These activities allow you to do the following:
■■
■■
■■
■■
■■
■■
■■
■■
Apply Pending Service Update Apply a pending service update to a VMM service.
Configure Service Deployment Configure a VMM service for deployment. Requires
the service configuration name, service template name, and deployment target.
Create Checkpoint Create a VM checkpoint. Requires the GUID of the VM.
Create New Disk Creates a new virtual hard disk. Requires you specify IDE/SCSI,
Dynamic or Fixed, File Name, Size, and VM GUID of VM to which the disk should be
attached.
Create New Disk From VHD Creates a new virtual hard disk from an existing virtual
hard disk. Requires you specify IDE/SCSI, Dynamic or Fixed, file name of new disk, path
to original disk, VM GUID of VM to which the disk should be attached.
Create Network Adapter Creates a new network adapter and attaches it to a VM.
Requires the VM GUID. You can also configure additional network adapter properties
such as MAC Address, MAC Address Pool, Network Tag, Virtual Network ID, VLAN ID,
and Logical Network.
Create User Role Creates a VMM user role. Requires that you specify a role name
and the VMM user role profile that the role will use.
Create VM From Template Allows you to create a VM from an existing VMM
template. Requires the Type Of VM, Destination, Path, Source Template Name, Cloud
Capability Profile, and VM Name.
Objective 4.1: Configure private cloud integration
Chapter 4
235
■■
■■
■■
■■
■■
■■
■■
■■
■■
Create VM From VHD Use this activity to create a VM from an existing virtual hard
disk. Requires you to specify IDE or SCI, name of destination VHD, path, location of
VHD from which you will be creating the VM, the name of the VM host, and the VM
name.
Create VM From VM Use this activity to create a new VM from an existing VM.
Requires that you specify the type of VM to create, destination, VM path, the VM GUID
of the source VM, and the name to apply to the newly created VM.
Deploy Service Use this activity to create a VMM service using a VMM service template. Requires that you specify the new service’s name, and the VMM template name.
Get Checkpoint Use this activity to retrieve VM checkpoint information.
Get Cloud Get information to view information about clouds on the VMM management server.
Get Network Adapter View information about VMM virtual network adapters.
Get Service Use this activity to return data on all services on the VMM management
server.
Get Service Configuration You use this activity to generate information about service configurations on the VMM management server.
Get Service Template This activity allows you to generate a list of all VMM service
templates.
■■
Get Tier Provides information about all VMM tiers.
■■
Get User Role Use this activity to extract information about VMM user roles.
■■
Get User Role Quota Use this activity to return information about all user role quotas on VMM management server.
■■
Get VM This activity provides information on a specific VM.
■■
Get VM Host Use this activity to extract information about a virtualization host.
■■
■■
■■
Get VM Network This activity allows you to extract information about a VMM VM
network.
Get VM Subnet Use this activity to provide Orchestrator with information about a
VMM VM subnet.
Manage Checkpoint You can use this activity in an Orchestrator runbook to revert
a VMM VM to a specific checkpoint, or to remove checkpoints that are no longer
required.
■■
Move VM This activity allows you to move a VM to a new location.
■■
Remove User Role This activity deletes a user role from VMM.
■■
■■
Remove VM Use this activity to delete a VM. This activity can only target a VM that
is in a shutdown state.
Repair VM Use this activity to issue a retry, undo, or dismiss action on a VMM VM.
236 Chapter 4
Configure System Center Integration
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
■■
Resume VM This activity allows Orchestrator to resume a VM that is in a paused
state.
Run VMM PowerShell Script Use this activity to trigger a PowerShell script.
Scale Tier In This activity allows Orchestrator to remove a virtual machine instance
from a specific service tier.
Scale Tier Out This activity allows Orchestrator to add a virtual machine instance to
a specific service tier.
Set Pending Service Update Use this activity to set a specific VMM service template
as the pending service update.
Shut Down VM This activity allows Orchestrator to shut down a stopped VM, taking
the VM offline.
Start VM Use this activity in an Orchestrator runbook to start a VM that has been
paused, shut down, or stopped.
Stop Service This activity will stop a VMM service.
Stop VM Use this activity in an Orchestrator runbook to place a VM into a stopped
state.
Suspend VM This activity will place a VM into a suspended state.
Update Disk This activity allows an Orchestrator runbook to change the properties
of an existing disk.
Update Network Adapter Use this activity to update the properties of an existing
network adapter.
■■
Update User Role Property Updates the properties of a VMM user role.
■■
Update User Role Quota Updates the quota for a user role.
■■
Update VM Use this activity in an Orchestrator runbook to update a VM.
MORE INFO VMM INTEGRATION PACK
Learn more about the VMM integration pack for Orchestrator by consulting the following
article at http://technet.microsoft.com/en-us/library/hh830704.aspx.
Objective 4.1: Configure private cloud integration
Chapter 4
237
To create Orchestrator runbooks that can use activities that perform tasks in VMM, you
configure VMM integration for Orchestrator. To configure the VMM connector for Orchestrator, perform the following steps:
1. Ensure that the VMM integration pack is installed on the Orchestrator server.
2. Ensure that the VMM Administration console is installed on the Orchestrator server. It
is possible to configure the connector without a local deployment of the VMM console,
but this is a more complicated process than installing the console on the Orchestrator
server.
3. Ensure that the Windows PowerShell execution policy on the Orchestrator server is set
to Remote Signed.
4. In the Options menu of the Orchestrator Runbook Designer, click SC 2012 Virtual Ma-
chine Manager.
5. On the SC 2012 Virtual Machine Manager dialog box, click Add.
6. On the Add Configuration dialog box, specify the name of the connection. Next to
type, click the ellipsis (…).
7. On the Item Selection page, click System Center Virtual Machine Manager.
8. In the Properties section of the Add Configuration dialog box, shown in Figure 4-21,
configure the following settings:
■■
VMM Administrator Console Address of the server with the VMM console.
■■
VMM Server Address of the VMM server.
■■
User User account of the user with permissions to the VMM server.
■■
Domain Domain that hosts the user account.
■■
Password Password associated with the account.
■■
■■
■■
■■
238 Chapter 4
Authentication Type (Remote Only) Needs to be configured if the VMM Administrator console is not installed on the Orchestrator server. You need to enable
the authentication method for WinRM using Group Policy.
Port (Remote Only) Only required if the Orchestrator runbook server doesn’t
have an instance of the VMM Administrator console.
Use SSL (Remote Only) Only required if the Orchestrator runbook server doesn’t
have an instance of the VMM Administrator console.
Cache Timeout Amount of time in minutes before the session times out.
Configure System Center Integration
FIGURE 4-21 Connect VMM to Orchestrator
9. Click OK on the Add Configuration dialog box, and the SC 2012 Virtual Machine Man-
ager dialog box.
DPM Orchestrator integration pack
You can use the DPM integration pack for Orchestrator, shown in Figure 4-22, to create DPMspecific runbook automation. These activities allow you to automate the following tasks when
creating an Orchestrator runbook:
■■
■■
■■
■■
■■
Create Recovery Point Use this activity to create a recovery point for a specific data
source.
Get Data Source Use this activity to determine information about available data
sources.
Get Recovery Point Use this activity to determine which recovery points exist for a
specific protected data source.
Get DPM Server Capacity Use this activity to determine a DPM server’s capacity.
Protect Data Source Use this activity to put a data source into protection. Use the
Get Data Source activity to determine the identity of eligible data sources.
■■
Recover SharePoint Use this activity to recover SharePoint data.
■■
Recover SQL Use this activity to recover SQL data.
■■
Recover VM Use this activity to recover a protected virtual machine.
Objective 4.1: Configure private cloud integration
Chapter 4
239
■■
Run DPM PowerShell Script Use this activity to run a DPM PowerShell script. You
can use the information returned from this script in the Orchestrator runbook.
Figure 4-22 DPM activities for Orchestrator
MORE INFO DPM INTEGRATION PACK
You can learn more about the DPM integration pack at http://technet.microsoft.com/en-us/
library/hh830694.aspx.
Configuration Manager integration pack
The Configuration Manager integration pack includes a number of activities that allow you to
automate Configuration Manager processes using Orchestrator. The integration pack is shown
in Figure 4-23.
FIGURE 4-23 Configuration Manager integration pack activities
240 Chapter 4
Configure System Center Integration
The Configuration Manager integration pack includes the following activities:
■■
Add Collection Rule This activity allows you to add membership rules to a collection.
■■
Create Collection Use this activity to automate the creation of a collection.
■■
Delete Collection This activity allows you to remove a collection.
■■
Delete Collection Rule This activity allows you to delete a collection rule.
■■
Deploy Application Use this activity to deploy an application to a collection.
■■
■■
■■
Deploy Configuration Baseline This activity allows you to deploy an existing configuration baseline to an existing collection.
Deploy Program Use this activity to deploy an existing program, including a script
that you want to run, to a collection.
Deploy Software Update Use this activity to deploy an existing software update to
a collection.
■■
Deploy Task Sequence This activity assigns an existing task sequence to a collection.
■■
Get Collection Members Use this activity to view the membership of a collection.
■■
■■
■■
■■
Get Deployment Status This activity allows you to view the deployment status of an
application, program, task sequence, or software update deployment.
Perform Client Action This activity allows you to trigger client actions such as the
Machine Policy Retrieval & Evaluation Cycle or File Collection Cycle.
Query ConfigMgr Use this activity to query the Configuration Manager database.
Update Collection Membership Use this activity to trigger an update of a collection’s membership.
MORE INFO CONFIGURATION MANAGER INTEGRATION PACK
You can learn more about the Configuration Manager integration pack at http://technet.
microsoft.com/en-us/library/hh967525.aspx.
Objective 4.1: Configure private cloud integration
Chapter 4
241
Configuring other System Center connectors
While this objective focuses on connecting Operations Manager with other System Center
products and Orchestrator integration packs, it’s also possible to configure integration between other products in the System Center suite.
Orchestrator and Service Manager
Earlier in this chapter you learned how to connect Orchestrator to Service Manager, which
allows you to use Orchestrator runbooks to perform tasks in Service Manager. You can also
configure a connector that works the other way, between Service Manager and Orchestrator, which allows Service Manager to make reference to and utilize Orchestrator runbooks. To
configure the connector between Service Manager and Orchestrator, perform the following
steps:
1. In the Administration workspace of the Service Manager console, click Connectors.
2. In the Tasks pane, click Create Connector, and then click Orchestrator Connector.
3. On the General page of the Orchestrator Connector Wizard, enter a name for the con-
nector.
4. On the Connection page, specify the Orchestrator Web Service URL as shown in Figure
4-24, and the operational database account. The URL of the Orchestrator web service
will be http://computer.fqdn:81/Orchestrator2012/Orchestrator.svc. The Run As account
you use must have the right to connect to Orchestrator. Ensure that you click Test Connection to verify that the connection is successful.
FIGURE 4-24 Orchestrator connector
242 Chapter 4
Configure System Center Integration
5. On the Sync Folder page, select a Sync Folder, and click Next.
6. On the Web Console URL page, shown in Figure 4-25, specify the URL for the Orches-
trator web console. The URL will be http://computer.fqdn:92.
FIGURE 4-25 Web console URL
7. On the Summary page, review the settings, and click Create.
You will be able to verify that the process has worked by navigating to the Library workspace, and clicking the Runbooks node. Any runbooks that you’ve created on the Orchestrator will be present in this node. Figure 4-26 shows this node with a runbook present.
Objective 4.1: Configure private cloud integration
Chapter 4
243
FIGURE 4-26 Synchronized runbooks
MORE INFO CREATING ORCHESTRATOR CONNECTOR
You can learn more about creating a connector between Service Manager and Orchestrator
at http://technet.microsoft.com/en-us/library/hh519779.aspx.
VMM Connector for Service Manager
Configuring the VMM connector for Service Manager will provide Service Manager with
information about the VMM environment. To configure the VMM connector for Service Manager, perform the following steps:
1. In the Administration workspace of the Service Manager console, click Connectors.
2. In the Tasks pane, click Create Connector, and then click Virtual Machine Manager
Connector.
3. On the General page of the Virtual Machine Manager Connector Wizard, type the con-
nector name.
4. On the Connection page, shown in Figure 4-27, type the FQDN of the VMM server, and
specify a Run As account. This account needs to have permissions to access VMM. Click
Test Connection to verify this account.
244 Chapter 4
Configure System Center Integration
FIGURE 4-27 VMM connector
5. On the Summary page, review the configuration information, and click Create.
Integrating IPAM with VMM
IPAM is a Windows Server 2012 and Windows Server 2012 R2 role service that allows you
to centralize the management of DHCP and DNS servers. You can use a single IPAM server
to manage up to 150 separate DHCP servers, and up to 500 individual DNS servers. A single
IPAM server is able to manage 6,000 separate DHCP scopes and 150 separate DNS zones.
You can perform tasks such as creating address scopes, configuring address reservations, and
managing DHCP and DNS options globally, rather than having to perform these tasks on a
server-by-server basis.
You can integrate the IPAM role with VMM. When you do this, VMM synchronizes IP address settings associated with logical networks and virtual machine networks with the IPAM
database. After you integrate IPAM with VMM, VMM administrators use IPAM to configure
and monitor logical networks and their associated network sites and IP address pools. Tenants, however, must continue to use VMM to manage and configure any virtual machine
networks that use network virtualization. Put another way, you cannot use IPAM to manage
the tenant address space.
Objective 4.1: Configure private cloud integration
Chapter 4
245
To add the IPAM server to VMM, perform the following steps:
1. In the Fabric workspace of the VMM console, click Network Services under Network-
ing.
2. On the Home tab of the VMM console ribbon, click Add Resources, and then click
Network Services.
3. On the Name page, provide a name that identifies the IPAM deployment.
4. On the Manufacturer and Model page, in the list of manufacturers click Microsoft, and
in the model list select Microsoft Windows Server IP Address Management, as shown
in Figure 4-28.
FIGURE 4-28 Add Network Service Wizard
5. On the Credentials page, select a Run As account that is a member of the IPAM ASM
Administrators and Remote Management Users security groups.
6. On the Connection String page, provide the FQDN of the IPAM server.
7. On the Provider page, ensure that Microsoft IP Address Management Provider is se-
lected, as shown in Figure 4-29, and click Test.
246 Chapter 4
Configure System Center Integration
FIGURE 4-29 Provider page
8. On the Host Group page, select which host groups you want to have IPAM manage the
address space for.
9. Complete the wizard.
MORE INFO IPAM AND VMM
You can learn more about integrating IPAM and VMM at http://technet.microsoft.com/enus/library/dn249418.aspx.
EXAM TIP
Understand the steps required to configure integration between Operations Manager and
VMM.
Objective 4.1: Configure private cloud integration
Chapter 4
247
Thought experiment
Integrating Operations Manager with VMM at Contoso
In this thought experiment, apply what you’ve learned about this objective. You can
find answers to these questions in the “Answers” section at the end of this chapter.
You are preparing to configure the Operations Manager connector for VMM
for your System Center deployment at Contoso. You have two separate servers,
OM.contoso.internal and VMM.contoso.internal. Each server has its respective management console installed. When configuring the connector, you will use a single
Active Directory user account. With this information in mind, answer the following
questions:
1. Which console must you install prior to configuring the Operations Manager
connector for VMM?
2. Which roles must the account use to configure the Operations Manager connector for VMM in Operations Manager and VMM?
Objective summary
■■
■■
■■
■■
■■
■■
The Operations Manager alert connector for Service Manager allows you to automatically create Service Manager incidents based on Operations Manager alerts.
Integrating Operations Manager with Virtual Machine Manager allows you to monitor
your organization’s virtualization layer when you are using a System Center 2012 and
System Center 2012 R2 managed private cloud.
The Operations Manager connector for VMM prerequisite requirements include the
Operations Manager console to be installed on the VMM server and the installation of
several management packs.
To link VMM and Operations Manager, you need the credentials of an account that is a
member of the Operations Manager Administrators user role, and the credentials of an
account that is a member of the VMM Administrator user role.
Orchestrator integration packs are collections of tasks that allow you to automate
activities with different System Center products.
You can import integration packs for Service Manager, Operations Manager, VMM,
DPM, and Configuration Manager.
248 Chapter 4
Configure System Center Integration
Objective review
Answer the following questions to test your knowledge of the information in this objective.
You can find the answers to these questions and explanations of why each answer choice is
correct or incorrect in the “Answers” section at the end of this chapter.
1. Which of the following Operations Manager integration pack tasks would you use
to extract data from an existing Operations Manager alert for use in an Orchestrator
runbook?
A. Create Alert
B. Get Alert
C. Get Monitor
D. Monitor Alert
2. Which of the following activities from the VMM Orchestrator integration pack would
you use to create a clone of an existing virtual machine hosted on a VMM managed
virtualization host? (Choose the best answer.)
A. Deploy Service
B. Create VM From VM
C. Create VM From VHD
D. Create VM From Template
3. Which of the following activities from the DPM integration pack for Orchestrator could
you use in an Orchestrator runbook to create a recovery point for a virtual machine
hosted on a protected Hyper-V host?
A. Recover VM B. Create Recovery Point C. Get Recovery Point D. Protect Data Source 4. Which of the following activities from the Configuration Manager integration pack for
Orchestrator would you use to deploy a script to a virtual machine that has the Configuration Manager client installed? (Choose the most correct answer.)
A. Deploy Application
B. Deploy Configuration Baseline
C. Deploy Program
D. Deploy Task Sequence
Objective 4.1: Configure private cloud integration
Chapter 4
249
Objective 4.2: Configure integration of private and
public clouds
This objective deals with Service Provider Foundation and Microsoft Azure Pack for Windows
Server, which are add-ons that allow you to extend your organization’s private cloud infrastructure. Service Provider Foundation allows you to build a multi-tenant self-service private
cloud. Microsoft Azure Pack for Windows Server allows you to use the Microsoft Azure public
cloud interface as a way of allowing your on-premises users to interact with your organization’s private cloud.
This section covers the following topics:
■■
Understanding Service Provider Foundation
■■
Deploying Service Provider Foundation
■■
Understanding Microsoft Azure Pack for Windows Server
Understanding Service Provider Foundation
Service Provider Foundation allows you to build a multi-tenant self-service private cloud that
includes the following features:
■■
■■
■■
Multi-Tenancy Supports multiple separate tenants. Each tenant is isolated from
other tenants.
Usage Monitoring Monitor how cloud resources are being utilized through Operations Manager.
Usage Billing Service Provider Foundation supports chargeback, which is where
organizations charge tenants fees based on how they utilize resources.
■■
Usage Metering Measure resource utilization.
■■
Management Stamps A scalable unit of virtualized platform infrastructure.
A management stamp represents a unit of virtualized platform infrastructure that includes
a VMM deployment, one or more virtualization hosts, the VMs that are managed by VMM,
and the unique service accounts and user roles that are individual to that stamp.
Stamps are monitored through Operations Manager, though one instance of Operations
Manager may monitor many stamps. Stamps allow service providers to spread tenants and
services across System Center elements in separate datacenters. For example, if your organization has datacenters in Melbourne, Sydney, and Brisbane, a stamp can be configured to
allow a tenant seamless access to resources in all three locations.
250 Chapter 4
Configure System Center Integration
Stamps are scalable. This means that as a tenant’s capacity requirements increase, additional stamps can be allocated to meet that demand. For example, if a tenant needs 10,000
additional VMs in the Melbourne datacenter, additional stamps can be allocated to the tenant.
Service Provider Foundation allows organizations to use industry standard web service
interfaces to connect their own web based management interfaces to a System Center cloud
through the REST (Representational State Transfer) web service and the Odata (Open Data
Protocol) API. Service Provider Foundation provides a programmatic web-based management
interface to a large number of VMM scenarios. Rather than being restricted to using one of
Microsoft’s self-service portal implementations, a tenant can use their own Self-Service Portal
to interface with the System Center backend resources.
Service Provider Foundation has the following elements:
■■
Web Services These provide tenants with portal applications and administration
tools and include the following:
■■
■■
■■
Admin Web Service This web service generates User Roles, Servers, management
stamps and other objects required for administrative tasks
VMM Web Service This web service interacts with VMM to create and manage
virtual machines, virtual networks, and tenants
Usage Web Service This web service collects usage data from tenant virtual machines and other parts of the fabric such as storage and networking MORE INFO SERVICE PROVIDER FOUNDATION
You can learn more about Service Provider Foundation at http://technet.microsoft.com/
en-us/library/jj642895.aspx.
Deploying Service Provider Foundation
The Service Provider Foundation installation files are located on the System Center 2012 R2
Orchestrator installation media. Service Provider Foundation has the following prerequisites
as shown in Figure 4-30:
■■
Windows Server 2012 or Windows Server 2012 R2
■■
PowerShell 4.0
■■
IIS Version 7.5 or later
■■
IIS Management Scripts and Tools role service
■■
IIS Security Basic Authentication
Objective 4.2: Configure integration of private and public clouds
Chapter 4
251
■■
IIS Security Windows Authentication
■■
IIS Application Development ASP.NET 4.5
■■
WCF Data Services 4.0 for OData V3
■■
ASP.NET MVC 4
■■
Management OData IIS Extension
■■
Virtual Machine Manager 2012 R2 Administrator Console
FIGURE 4-30 SPF prerequisites
You deploy Service Provider Foundation from the Orchestrator installation media. To deploy Service Provider Foundation, perform the following steps:
1. On the System Center 2012 R2 Orchestrator Setup dialog box, shown in Figure 4-31,
click Service Provider Foundation.
252 Chapter 4
Configure System Center Integration
FIGURE 4-31 Installation splash screen
2. On the Service Provider Foundation dialog box, click Install.
3. On the License Terms page, agree to the license terms.
4. On the Prerequisites page, verify that all prerequisites are available.
5. On the Configure The Database page, review the database settings. Figure 4-32 shows
the default database name is SCSPFDB.
Objective 4.2: Configure integration of private and public clouds
Chapter 4
253
FIGURE 4-32 Database server settings
6. On the Specify A Location For The SPF Files, specify the port number and the server
certificate details. Figure 4-33 shows a certificate issued from an internal CA.
FIGURE 4-33 SPF file location
254 Chapter 4
Configure System Center Integration
7. On the Configure The Admin Web Service page, specify the domain credentials of the
System Center Administrator web service and the credentials of the related application
pool service account.
8. On the Provider Web Service page, you specify domain credentials for the System
Center Provider web service and the application pool credentials for the related application pool.
9. On the VMM Web Service page, specify domain credentials for the VMM web service
and service account credentials for the VMM web service application pool.
10. On the Usage Web Service page, specify domain credentials for the Usage web service
and service account credentials for the Usage web service.
11. On the CEIP and Microsoft Update page, choose whether to opt in to the Customer
Experience Improvement Program, and whether to enable Microsoft Update.
12. On the Installation Summary page, review the installation settings, and click Install.
Verify that Setup Is Complete, as shown in Figure 4-34.
FIGURE 4-34 Verify setup is complete
MORE INFO DEPLOY SERVICE PROVIDER FOUNDATION
You can learn more about Service Provider Foundation deployment at http://technet.
microsoft.com/en-us/library/jj642900.aspx.
Objective 4.2: Configure integration of private and public clouds
Chapter 4
255
Understanding Microsoft Azure Pack for Windows Server
Microsoft Azure Pack provides an on-premises replica of Microsoft Azure services that you
can deploy in your datacenter, including Virtual Machine and website provisioning. The
advantage of Microsoft Azure Pack is that it provides a replica of the experience that a user
would get if they used the online Microsoft Azure portal to perform tasks.
Microsoft Azure Pack provides Self-Service IT through a Self-Service Portal that allows
hybrid cloud scenarios. A hybrid cloud is spread across private, public, and hosted clouds.
Microsoft Azure Pack includes the following:
■■
■■
■■
■■
■■
■■
■■
■■
■■
End User Portal The end user portal is designed to replicate the Microsoft Azure
portal. Like the Microsoft Azure portal, the end user portal allows end users to access
their resources in the private cloud. Administrators can configure separate offerings for
each tenant.
Management Portal This portal is for cloud administrators. It allows them to manage the offerings and services that end users access through the end user portal.
Management API Web service that handles requests from the management portal.
Can also be used by third party management portals through OData REST standards.
Service Management API Database Stores configuration data.
Web Sites Provides a scalable shared web hosting platform. Supports sites that host
ASP.NET, PHP, and Node.js applications.
Virtual Machines Supports the deployment of any VM that can be managed using
VMM. Supports software defined networking and remote access connections to each
VM’s console.
Databases Supports Microsoft SQL 2008/2012 and MySQL 5.x in Platform as a Service configuration.
Service Management Automation Allows the building of automation based on
Orchestrator and PowerShell 3.0 workflows.
Service Bus Provides a messaging service between applications running in the private cloud.
VMM is able to collect usage data, such as CPU, memory, storage, and network utilization, for all of the VMs and virtualization hosts it manages. VMM stores this data in the VMM
database for 30 days. If you’ve integrated VMM with Operations Manager, this data can be
transferred across to the Operations Manager data warehouse.
256 Chapter 4
Configure System Center Integration
The Service Provider Foundation element of Microsoft Azure Pack is able to utilize this
data when stored in the Operations Manager data warehouse, providing it to authorized
users to view through interfaces such as the management portal for administrators. Service
Provider Foundation is able to collect metric data from multiple VMM instances and aggregate them so that you can use that data for billing, or for overall infrastructure analysis.
MORE INFO MICROSOFT AZURE PACK FOR WINDOWS SERVER
You can learn more about Microsoft Azure Pack for Windows Server at http://technet.
microsoft.com/en-au/library/dn296432.aspx.
Microsoft Azure Pack VM clouds
To add a VMM cloud to Microsoft Azure Pack, perform the following general steps:
1. On the server that hosts the Microsoft Azure Pack Management Portal for Administra-
tors, start the Management Portal by navigating to https://localhost:30091.
2. In the Management Portal, click VM Cloud.
3. Click Register System Center Service Provider Foundation Server. This will be in the
form https://server.fqdn:8090. You’ll need to provide the credentials used for the following Application Pool identities on the Service Provider Foundation server:
■■
VMM
■■
Usage
■■
Admin
■■
Provider
4. Once registration is complete, all of the VMM instances (or stamps) associated with the
Service Provider Foundation endpoint will be listed.
All clouds present on the VMM server (or stamp) will be listed under the Clouds tab of the
portal. You can add stamps or VMM servers in the management portal for Administrators by
clicking New, click VM Clouds, and click Connect to, and specify the FQDN of the VMM server
or stamp.
Microsoft Azure Pack web clouds
A Microsoft Azure Pack web cloud deployment has the following roles:
■■
■■
Web Sites Controller This role is used by Microsoft Azure Pack to provision and
manage other web sites role.
Management Server This role hosts a REST endpoint. It routes management traffic
to the Microsoft Azure Pack Web Sites Management API.
Objective 4.2: Configure integration of private and public clouds
Chapter 4
257
■■
■■
■■
■■
■■
■■
■■
Web Workers The web servers that will process client web requests. Can be configured as either Shared or Reserved. One of each is required. Reserved web workers are
categorized as small, medium, and large.
Front End This role accepts client web requests, provides clients with responses
from web workers, routes web worker requests, and provides load balancing and SSL
termination.
File server Hosts web site content for every web site that runs on the web cloud.
Publisher Allows content publishing to the web sites in the cloud for FTP clients,
Visual Studio, and WebMatrix through the Web Deploy and FTP protocols.
Web Sites Runtime Database Database that Microsoft Azure Pack web clouds uses
for operations.
Service Management API Database Stores configuration data for the Microsoft
Azure Pack Service Management API. This role will have already been installed during
the deployment of Microsoft Azure Pack.
Application Databases If supported usage scenarios include providing back end
database functionality for the websites hosted through Microsoft Azure Pack for Windows Server, it’s necessary to install databases instances for one or both of Microsoft
SQL Server or MySQL.
MORE INFO AZURE PACK WEB CLOUDS
You can learn more about Microsoft Azure Pack web clouds at http://technet.microsoft.
com/en-us/library/dn457747.aspx.
Microsoft Azure Pack SQL clouds
The SQL Server and MySQL resource providers for Microsoft Azure Pack enable users to have
the use of Microsoft SQL and MySQL databases. To support this usage scenario, it is necessary
for you to install the separate SQL server and MySQL databases that underpin this service. It is
only necessary to install MySQL if you want to offer MySQL through Microsoft Azure Pack.
To install a SQL Server or MySQL resource provider:
1. Sign on to the computer on which you are going to install the SQL Server or MySQL
resource provider, and launch the Web Platform Installer.
2. On the Products tab of the Web Platform Installer, click Microsoft Azure.
3. Depending on whether you are deploying a SQL Server provider or MySQL provider,
click Add next to one of the following, and then click Install:
■■
Microsoft Azure Pack: SQL Server Extension
■■
Microsoft Azure Pack: MySQL Extension
258 Chapter 4
Configure System Center Integration
4. When the installation completes, click Continue. This will launch the Configuration
site. On this site, enter the following information using the settings specified when you
deployed Microsoft Azure Pack for Windows Server:
■■
Address of the database server configured when you deployed Microsoft Azure
Pack
■■
Azure Pack database authentication details
■■
Azure Pack Configuration Store passphrase.
5. Once these steps are complete, you’ll be able to register the database endpoints for
the Microsoft SQL or the MySQL instances you have deployed.
Once you have registered the appropriate resource provider, you can register database
endpoints. You’ll need to have deployed the database instance prior to attempting endpoint
registration.
REGISTER MICROSOFT SQL DATABASE ENDPOINT
To register a Microsoft SQL database endpoint, perform the following steps:
1. Sign on to the server that hosts the Microsoft Azure Pack Management Portal for Ad-
ministrators, and launch the portal.
2. Click SQL Servers in the navigation pane, and then click New or Add. Click Connect.
3. Provide the following SQL Server instance name:
■■
■■
■■
■■
■■
Group Name The name of the group that you want the instance to belong to in
Microsoft Azure Pack.
Server Name The name of the server that hosts the instance. Usually this will
be just the name of the server, but can also include the instance name in the
Servername\instancename format if you have deployed multiple instances on a
computer.
Administrator User Name Name of a user with administrative privileges on the
instance.
Administrator Password Password of the user account specified that has administrative privileges on the instance.
Size Of The Hosting Server (GB) Specify the amount of disk space available on
the hosting server.
4. Click Connect to register the Microsoft SQL instance.
Objective 4.2: Configure integration of private and public clouds
Chapter 4
259
REGISTER MYSQL INSTANCE
To connect an existing MySQL instance to Microsoft Azure Pack, perform the following steps:
1. Sign on to the server on which you deployed the Microsoft Azure Pack Management
Portal for Administrators and launch the management portal.
2. In the Microsoft Azure Pack Management Portal for Administrators, click MySQL Serv-
ers, click New or Add, and then click Connect.
3. Provide the following information about the MySQL instance:
■■
■■
■■
■■
■■
Group Name Name of the Microsoft Azure Pack group to which you want to add
the MySQL server.
Server Name Name of the MySQL server instance.
Administrator User Name Name of a user account that has administrative privileges on the MySQL instance.
Administrator Password Password of the user account that has administrative
privileges on the MySQL instance.
Size Of The Hosting Server (in GBs) Provide the amount of available space.
4. Click Connect to register the MySQL instance.
■■
■■
Enter the MySQL server instance information: group name, server name, administrator user name, administrator password, and the size of the hosting server (in GBs).
Click Connect. When you receive a message indicating that registration was successful, close the message.
MORE INFO SQL CLOUDS WITH MICROSOFT AZURE PACK
You can learn more about Microsoft Azure Pack SQL clouds at http://technet.microsoft.
com/en-us/library/dn469317.aspx.
EXAM TIP
Remember that Service Provider Foundation provides a framework for multi-tenant selfservice clouds where custom portals are used. Microsoft Azure Pack for Windows Server
provides portals that replicate the Microsoft Azure experience, though these can also be
customized.
260 Chapter 4
Configure System Center Integration
Thought experiment
Microsoft Azure Pack for Windows Server at Tailspin Toys
In this thought experiment, apply what you’ve learned about this objective. You can
find answers to these questions in the “Answers” section at the end of this chapter.
You are the private cloud administrator at Tailspin Toys. You are investigating the
benefits of deploying Microsoft Azure Pack for Windows Server. Stakeholders at
the organization want to know about the functionality of Microsoft Azure Pack and
have forwarded you the following questions:
1. Which VM operating systems can be requested through the portal after Microsoft Azure Pack for Windows Server is deployed and operational?
2. Which database servers can be used to host databases used to store the data for
web applications deployed in a Microsoft Azure Pack for Windows Server web
cloud?
Objective summary
■■
■■
■■
■■
■■
■■
■■
Service Provider Foundation allows you to build a multi-tenant self-service private
cloud.
Service Provider Foundation clouds support multi-tenancy, usage monitoring, usage
billing, usage metering, and management stamps.
A management stamp represents a unit of virtualized platform infrastructure that
includes a VMM deployment, one or more virtualization hosts, the VMs that are managed by VMM, and the unique service accounts and user roles that are individual to
that stamp.
Stamps allow service providers to spread tenants and services across System Center
elements in separate datacenters.
As a tenant’s capacity requirements increase, additional stamps can be allocated to
meet that demand.
Microsoft Azure Pack provides an on-premises replica of Microsoft Azure services that
you can deploy in your datacenter, including Virtual Machine and website provisioning.
When deploying Microsoft Azure Pack, you need to provide credentials for the VMM,
Usage, Admin and Provider Application Pool identities on the Service Provider Foundation server.
Objective 4.2: Configure integration of private and public clouds
Chapter 4
261
Objective review
Answer the following questions to test your knowledge of the information in this objective.
You can find the answers to these questions and explanations of why each answer choice is
correct or incorrect in the “Answers” section at the end of this chapter.
1. You are installing Microsoft Azure Pack for Windows Server. Service Provider Founda-
tion is already deployed in your organization’s environment. During the installation of
Service Provider Foundation, you used domain accounts when configuring each application pool service account. Which of these credentials are required when deploying
Microsoft Azure Pack for Windows Server? (Choose all that apply.)
A. Provider web service application pool.
B. Admin web service application pool.
C. VMM web service application pool.
D. Orchestrator web service application pool.
2. Which of the following database products can you install to provide as a service to us-
ers after installing Microsoft Azure Pack for Windows Server.
A. PostgreSQL.
B. MySQL.
C. Microsoft SQL Server.
D. Oracle.
3. Which of the following elements are included in a Service Provider Foundation man-
agement stamp? (Choose all that apply.)
A. One or more virtualization hosts.
B. Orchestrator runbook server.
C. Operations Manager management group.
D. VMs managed by VMM.
262 Chapter 4
Configure System Center Integration
Answers
This section contains the solutions to the thought experiments and answers to the objective
review questions in this chapter.
Objective 4.1: Thought experiment
1. You must install the Operations Manager console on the VMM server.
2. To link VMM and Operations Manager, you need the credentials of an account that is a
member of the Operations Manager Administrators user role, and the credentials of an
account that is a member of the VMM Administrator user role.
Objective 4.1: Review
1. Correct answer: B
A. Incorrect: This activity allows you to extract data from an Operations Manager
alert.
B. Correct: This activity allows you to extract data from an Operations Manager alert.
C. Incorrect: Orchestrator integration packs are collections of tasks that allow you to
automate activities with different System Center products.
D. Incorrect: Orchestrator integration packs are collections of tasks that allow you to
automate activities with different System Center products.
2. Correct answer: B
A. Incorrect: Use this activity to create a VMM service using a VMM service template.
B. Correct: You use this activity to create a new VM from an existing VM that is on a
VMM managed virtualization host.
C. Incorrect: Use this activity to create a VM from an existing virtual hard disk in the
VMM library.
D. Incorrect: This cmdlet allows you to create a VM from an existing VMM template.
3. Correct answer: B
A. Incorrect: You use this activity to recover a protected virtual machine.
B. Correct: You use this activity to create a recovery point for a specific data source.
C. Incorrect: You use this activity to determine which recovery points exist for a
specific protected data source.
D. Incorrect: You use this activity to put a data source into protection. Use the Get
Data Source activity to determine the identity of eligible data sources.
Answers
Chapter 4
263
4. Correct answer: C
A. Incorrect: You use this activity to deploy an application to a collection. In Configu-
ration Manager, you use a Program rather than an Application to deploy scripts.
B. Incorrect: This activity allows you to deploy an existing configuration baseline to
an existing collection.
C. Correct: You use this activity to deploy an existing program, including a script that
you want to run, to a collection.
D. Incorrect: This activity assigns an existing task sequence to a collection. While task
sequences can run scripts, the “more correct” answer is to use a Program to deploy
the script. Task sequences are most commonly used in Operating System Deployment (OSD) type activities.
Objective 4.2: Thought experiment
1. Microsoft Azure Pack for Windows Server supports any operating system that can be
managed through VMM. This means that it is possible to deploy VMs running supported versions of the Windows and Linux operating systems.
2. Both Microsoft SQL Server and MySQL can be used to host the databases that store
the data for web applications deployed in a Microsoft Azure Pack for Windows Server
web cloud.
Objective 4.2: Review
1. Correct answers: A, B and C
A. Correct: You need to specify credentials for the VMM, Provider, Admin, and Usage
web service application pool when installing Microsoft Azure Pack for Windows
Server.
B. Correct: You need to specify credentials for the VMM, Provider, Admin, and Usage
web service application pool when installing Microsoft Azure Pack for Windows
Server.
C. Correct: You need to specify credentials for the VMM, Provider, Admin, and Usage
web service application pool when installing Microsoft Azure Pack for Windows
Server.
D. Incorrect: You do not need to specify credentials for the Orchestrator web service
application pool when installing Microsoft Azure Pack for Windows Server.
264
Chapter 4
Configure System Center Integration
2. Correct answers: B and C
A. Incorrect: You cannot provision PostgreSQL database to users through Microsoft
Azure Pack for Windows Server.
B. Correct: You can install MySQL databases and provide them as a service to users
through Microsoft Azure Pack for Windows Server.
C. Correct: You can install Microsoft SQL Server databases and provide them as a
service to users through Microsoft Azure Pack for Windows Server.
D. Incorrect: While it is possible to deploy Oracle in the cloud version of Microsoft
Azure, Oracle is not supported for deployment through Microsoft Azure Pack.
3. Correct Answers: A and D
A. Correct: A management stamp represents a unit of virtualized platform infrastruc-
ture that includes a VMM deployment, one or more virtualization hosts, the VMs
that are managed by VMM, and the unique service accounts and user roles that
are individual to that stamp.
B. Incorrect: While a Service Provider Foundation management stamp may utilize
Orchestrator and Service Provider Foundation is installed from the Orchestrator
installation media, there is no direct relationship between a management stamp
and Orchestrator.
C. Incorrect. A single Operations Manager management group can monitor multiple
Service Provider Foundation management stamps.
D. Correct: A management stamp represents a unit of virtualized platform infrastruc-
ture that includes a VMM deployment, one or more virtualization hosts, the VMs
that are managed by VMM, and the unique service accounts and user roles that
are indi
Answers
Chapter 4
265
This page intentionally left blank
This page intentionally left blank
Index
A
account credentials
needed to link Operations Manager and VMM 225
when integrating Orchestrator with
Operations Manager 229
ACS (Audit Collection Services) database, backing up 9
Active Directory Container dialog box 100
Active Directory System Discovery Properties
dialog box 100
Active Directory System Discovery, triggering 101
Add Alert Routing Rule dialog box 219
Add Collection Rule activity in
Configuration Manager 241
Add Configuration dialog box 238
Add Disks To Storage Pool dialog box 84
Add Network Service Wizard 246–248
Add Operations Manager Wizard 225
Add Properties page of the Scale Out Tier Wizard 300
Add PXE Server dialog box 188
Add Resource Wizard 107–109
Add Roles And Features Wizard 184
Add-ServerAppvPackage Windows PowerShell
cmdlet 284
Add Storage Devices Wizard 156–158
Add-VmNetworkAdapterRoutingDomain Windows
PowerShell cmdlet 179
Add Windows Server Update Services Server
dialog box 195
Administrator Account page of Computer And Device
Management Wizard 95
Admin Password setting, specifying for guest
OS profile 274
Admin Web Service in Service
Provider Foundation 251, 255
agents
DPM (Data Protection Manager) 102–105
Operations Manager 93–98
VMM (Virtual Machine Manager) 106–109
alert connectors, Operations Manager, creating 218–221
alert routing rules 219, 221
All Hosts node, creating host groups 199
Allocate Storage Capacity dialog box 162
Analysis Services configuration in Service Manager 49
Answer File setting, specifying for guest OS profile 275
APM (Application Performance Monitoring) 142–147
App Controller 2
backing up and recovering 8
configuring 127–132
hardware requirements for 18
high availability options 6
installing 33–36
Self-Service Portal 127–132
software prerequisites for 23
SQL Server requirements for 22
user roles 115
App Controller AES key, backing up 8
App Controller Installation Wizard 8
App Controller Setup dialog box 33–35
Application Catalog web service point,
software requirements for 27
Application Catalog website point,
software requirements for 27
Application Configuration page of the
Create VM Template Wizard 291
Application Configuration page of the New Application
Profile dialog box 276
Application Databases role in Microsoft Azure Pack 258
Application element of Server App-V 282
Application Performance Monitoring (APM) 142–147
Application Pool identities 257
application profiles
creating 275–277
using Web Deploy packages with 294
applications, sequencing, using Server App-V 281–285
Apply Pending Service Update activity in VMM 235
309
Asset Intelligence synchornization point software requirements
Asset Intelligence synchronization point,
software requirements for 27
Audit Collection Services (ACS) database, backing up 9
automatic client upgrade, configuring 75
automatic discovery of storage, supported by VMM 154
Auto Or Advanced page of Computer
And Device Management Wizard 94
availability groups, deploying databases on 5
Availability setting, specifying for hardware profile 271
Available Setup Options page of Configuration Manager
Setup Wizard 57
B
backing up VMM (Virtual Machine Manager) 6–15
Backup-ServerAppvPackageState Windows PowerShell
cmdlet 284
BACKUP SERVICE MASTER KEY TO FILE Transact SQL
statement 8
Backup Site Server Properties dialog box 11
bare metal hardware chassis
deploying virtualization hosts to 182–184
physical computer profile and 190–193
best practices when sequencing applications 283
block storage, used by VMM 154
BMC (Baseboard Management Controller) 183
C
capability profiles, choosing 268
Capability Profiles page of Create Cloud Wizard 208
Capacity page of Create Cloud Wizard 207
Capturing extension for logical switches 167
C:\ConfigMgrPostRecoveryActions.html file 14
CEIP and Microsoft Update page in Service Provider
Foundation wizard 255
Certificate registration point, software
requirements for 28
chaining, DPM 87
Change Service Template Wizard 299
child host groups 199
Choose Replica Creation Method page of Create New
Protection Group wizard 91
Choose Restart Method page of Protection Agent
Installation Wizard 104
CI (configuration item) connectors,
Operations Manager 218
classifications, storage 155
310
client, Configuration Manager 98–102
client push installation method, configuring 99–102
Client Push Installation Properties dialog box 99
Cloud Capability Profiles setting, specifying for hardware
profile 268
clustered virtualization hosts
and dynamic optimization 202
COM 1 Port settings, specifying for hardware profile 270
COM 2 Port settings, specifying for hardware profile 270
compatibility options for creating new
application profiles 276
Computer And Device Management Wizard 93–97
computer discovery, configuring 100
configuration item (CI) connectors,
Operations Manager 218
Configuration Manager 4
backing up and recovering 11–14
hardware requirements for 20
high availability options 6
installing 57–64
integrating with Orchestrator 240
migrating from pre-System Center 2012 versions 70
Run As accounts 114
site servers
hardware requirements for 20
recovering 13
software prerequisites for 27–29
upgrading from System Center 2012 or
System Center 2012 SP1 74
user roles 115
Configuration Manager Backup Site Server Properties
dialog box 11
Configuration Manager client 98–102
Configuration Manager setup
downloader application 28
Configure Analysis Services For OLAP Cubes page of
Service Manager Setup Wizard 49
Configure Hardware page of the Create VM
Template Wizard 289
Configure Operating System page of the Create VM
Template Wizard 290
Configure Operations Manager Accounts page of
Operations Manager Setup 44
Configure Orchestrator Users Group page of
Orchestrator Setup 39
Configure Service Account And Distributed Key
Management page of VMM Setup Wizard 31
Configure Service Deployment activity in VMM 235
Configure The Database page of Orchestrator Setup 39
Data Base Protection Manager (DPM)
Configure The Database Server page of
Orchestrator Setup 38
Configure The Database Server page of Service Provider
Foundation wizard 253
Configure The Data Warehouse Databases page of
Service Manager Setup Wizard 48
Configure The Data Warehouse Management Group
page of Service Manager Setup Wizard 48
Configure The Operational Database page of Operations
Manager Setup 42
Configure The Ports For The Web Services page of
Orchestrator Setup 40
Configure The Service Account page of
Orchestrator Setup 37
Configure The Service Manager Database page of
Service Manager Setup Wizard 46
Configure The Service Manager Management Group
page of Service Manager Setup Wizard 46
Configure The Service Manager SharePoint Web Site
page of the Service Manager Setup Wizard 53
Configure The Services page of App Controller Setup 34
Configure The SQL Server Database page of App
Controller Setup 35
Configure The Website page of App Controller Setup 34
Connection dialog box in Operations Manager 229
Connection dialog box in Service Manager 232
Connection page of Orchestrator Connector Wizard 242
Connection page of Virtual Machine Manager
Connector Wizard 244
Connection To.. page of Add Operations
Manager Wizard 225
connectors, Operations Manager, for
Service Manager 218–221
Consistency Check Options page of Create New
Protection Group wizard 91
control panel item, Configuration Manager 98
CPU Priority setting, specifying for hardware profile 272
Create Alert activity in Operations Manager 231
Create Change With Template activity in
Service Manager 234
Create Checkpoint activity in VMM 235
Create Cloud Wizard 204–206
Create Collection activity in Configuration Manager 241
Create Incident With Template activity in
Service Manager 234
Create Logical Network Wizard 164
network virtualization, configuring 170
private VLANs, implementing 177
Create Logical Switch Wizard 167
Create Logical Unit dialog box 162
Create Network Adapter activity in VMM 235
Create New Disk activity in VMM 235
Create New Disk From VHD activity in VMM 235
Create New Protection Group wizard 86–91
Create Object activity in Service Manager 234
Create Recovery Point activity in DPM 239
Create Related Object activity in Service Manager 234
Create Relationship activity in Service Manager 234
Create Static IP Address Pool Wizard 173–177
Create Storage Pool dialog box 161
Create User Role activity in VMM 235
Create VM From Template activity in VMM 235
Create VM From VHD activity in VMM 236
Create VM From VM activity in VMM 236
Create VM Network Wizard 172
Create VM Template Wizard 289–291
credentials of accounts
needed to link Operations Manager and VMM 225
when integrating Orchestrator with
Operations Manager 229
Credentials page of Add Resource Wizard 108
custom management packs, backing up 9
custom report definition files, backing up 9
custom reporting services reports, protecting 12
D
DAC (data-tier application) packages 294
dashboards, Operations Manager 133–141, 222
database configuration in App Controller 35
database configuration in Orchestrator 38
database configuration in Service Manager 46
Database Configuration page of VMM Setup Wizard 30
database endpoints, MS SQL, registering 259
Database Engine Services And Management Tools Complete features 23
Database Information page of Configuration Manager
Setup Wizard 60
database recovery, options for 13
databases in Microsoft Azure Pack 256
Data Protection Manager (DPM) 4
agents 102–105
backing up and recovering 10
chaining 87
hardware requirements for 19
high availability options 6
311
Data Protection Manager Setup Wizard
installing 55
integrating with Orchestrator 239
protection groups 88–91
secondary servers 85–87
software prerequisites for 26
SQL Server requirements for 22, 26
storage pools 84
understanding 84–91
upgrading from pre-System Center 2012 versions 69
upgrading from System Center 2012 or
System Center 2012 SP1 73
user roles 116
Data Protection Manager Setup Wizard 55
