User manual
=+7: Ԛ͂ʹ˫
KO
⚻⵵#❃῏✻
MCD183
1 Important
Safety
Important Safety Instructions
Hearing safety
Notice
2 Your DVD Micro Theater
Introduction
What’s in the box
Overview of the main unit
Overview of the remote control
4
4
4
5
6
7
7
7
8
9
3 Connect
12
Place the unit
12
Connect speakers and subwoofer
12
Connect FM antenna
12
Connect TV
13
Connect video cables
13
Option 1: Connect through component
video
13
Option 2: Connect through S-Video
13
Option 3: Connect through composite
video
14
Connect audio cables
14
Connect power
14
4 Get started
Prepare the remote control
Set clock
Turn on
Switch to standby mode
Find the correct viewing channel
Select the correct TV system
Change system menu language
Turn on Progressive Scan
15
15
15
15
15
15
16
16
16
18
18
18
18
18
18
19
19
19
19
Play a disc
Use the disc menu
Select an audio language
Select a subtitle language
Play from USB
Play DivX video
Play MP3/WMA/picture files
Play control
Select repeat/shuffle play options
Repeat A-B (DVD/VCD/CD/MP3/
WMA)
20
Search forward/backward
20
Search by time or chapter/track
number
20
Resume video play from last stopped
point
20
Play options
20
Display play information
20
Program
20
Zoom in/out image
21
Slow-motion play
21
Change the audio channel
21
Select a camera angle
21
Picture view options
21
Preview pictures
21
Select a slide show play mode
21
Rotate picture
21
6 Adjust settings
22
22
22
23
23
General setup
Audio setup
Video setup
Preference setup
7 Tune to FM radio stations
Program radio stations automatically
Program radio stations manually
Tune to a preset radio station
EN
25
25
25
25
3
English
5 Play
Contents
8 Adjust volume level and sound effect
Adjust volume level
Select a sound effect
Select a preset sound effect
Enhance bass
Select automatic loudness control
Mute sound
Listen through headphone
9 Other features
Activate demonstration mode
Adjust brightness of display panel
Set the alarm timer
Set the sleep timer
Connect other devices
Listen to an audio player
Record to a digital recorder
10 Product information
Specifications
Amplifier
Disc
Tuner (FM)
Speakers
General information
Supported disc formats
USB playability information
11 Troubleshooting
4
EN
26
26
26
26
26
26
26
26
27
27
27
27
27
27
27
28
29
29
29
29
29
29
29
30
30
31
Safety
Know these safety symbols
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specified by the manufacturer.
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fire or electric
shock, this apparatus should not be exposed to
rain or moisture and objects filled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
k Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
EN
5
English
1 Important
•
Do not mix batteries (old and new or
carbon and alkaline, etc.).
Remove batteries when the unit is not
used for a long time.
•
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid filled objects,
lighted candles).
q This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Warning
•
•
•
•
•
•
•
Never remove the casing of this unit.
Never lubricate any part of this unit.
Place this unit on a flat, hard and stable surface.
Never place this unit on other electrical equipment.
Only use this unit indoors. Keep this unit away from
water, moisture and liquid-filled objects.
Keep this unit away from direct sunlight, naked flames
or heat.
Never look into the laser beam inside the unit.
Warning
• Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall
remain readily operable.
6
EN
Hearing safety
Listen at a moderate volume.
• Using headphones at a high volume can
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute. The
higher decibel ranges are offered for those
that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even at
normally ‘safe’ levels, can also cause hearing
loss.
• Be sure to use your equipment reasonably
and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume as your
hearing adapts.
• Do not turn up the volume so high that
you can’t hear what’s around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
DivX, DivX Certified, and associated logos are
trademarks of DivX, Inc. and are used under
license.
English
Notice
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
This apparatus includes this label:
Note
• The type plate is located on the bottom of the
apparatus.
The making of unauthorized copies of copyprotected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
‘DVD Video’ is a trademark of DVD Format/
Logo Licensing Corporation.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
EN
7
2 Your DVD
Micro Theater
DVD region code Countries
Asia Pacific, Taiwan, Korea
Australia, New Zealand
Congratulations on your purchase, and
welcome to Philips! To fully benefit from the
support that Philips offers, register your product
at www.Philips.com/welcome.
What’s in the box
Introduction
With this unit, you can:
• watch video from DVD/VCD/SVCD or
USB devices
• enjoy audio from discs or USB devices
• view pictures from discs or USB devices
• Listen to FM radio
You can enrich sound output with these
sound effects:
• Digital Sound Control (DSC)
• Dynamic Bass Boost (DBB)
• Bass/treble enhancement
The unit supports these media/disc formats:
Recordable
ReWritable
You can play DVD discs with the following
region codes:
8
EN
Check and identify the contents of your
package:
• Main unit
• 2 speakers
• Subwoofer
• Remote control with battery
• Composite video cable (yellow)
• Power cord
• FM wire antenna
• MP3 Link cable
• User manual
• Quick start guide
m
n
a
b
c
d
e
d
a
•
b SOURCE
• Select a source.
c VOL -/+
• Adjust volume.
• Adjust time.
• During timer setting, select a source.
j
g
h
f
i
/
•
•
Turn on the apparatus; switch to
standby mode.
l k
English
Overview of the main unit
•
Skip to the previous/next track.
Skip to the previous/next title or
chapter.
Select a preset radio station.
e Disc compartment
f
•
Headphone socket.
g MP3-LINK
• Jack for an external audio device.
EN
9
h USB DIRECT
• USB socket.
i
•
Overview of the remote
control
Open or close the disc compartment.
j MODE
• Select repeat play modes.
• Select shuffle play modes.
a
k Remote control sensor
b
l
•
Start or pause play.
m
•
•
•
Stop play.
Erase a program.
In demo mode, activate or deactivate
demonstration.
x
c
w
v
d
e
u
f
n Display panel
• Display current status.
g
t
s
h
r
i
q
j
k
p
l
m
n
o
a
•
Turn on the apparatus; switch to
standby mode.
b Source selection keys
• Select a source.
10
EN
d DISC MENU
• For video discs: access or exit the disc
menu.
• For video discs with playback
control(PBC): turn on/off PBC.
e AUDIO
• For VCD, select stereo, mono-left or
mono-right channel.
• For DVD/DivX video, select an audio
language.
f
/
•
•
•
•
•
g
Search within a track.
Tune to a radio station.
For menus, navigate left/right.
Move an enlarged picture left/right.
Rotate or invert pictures.
SLOW/ ZOOM
• For menus, navigate up/down.
• Move an enlarged picture up/down.
• Rotate or invert pictures.
• ( SLOW) For video discs: select a
slow play mode.
• ( ZOOM) For pictures or video:
zoom in/out.
h LOUD/DBB
• Turn on or off automatic loudness
adjustment.
• Turn on or off dynamic bass
enhancement.
i VOL +/• Adjust volume.
• Adjust time.
• During timer setting, select a source.
j MUTE
• Mute or restore volume.
k CLOCK
• Set the clock.
l SLEEP/TIMER
• Set the sleep timer.
• Set the alarm timer.
English
c DISPLAY/RDS (RDS function unavailable
for this version)
• Display play information on a
connected TV.
m SUBTITLE
• Select a subtitle language.
n GOTO
• During disc play, specify a position to
start play.
o ANGLE/PROG
• Select a DVD camera angle.
• Program tracks.
• Program titles/chapters for DVD play.
• Program radio stations.
p Numeric keypad
• Select a title/chapter/track directly.
q
•
•
r
Stop play.
Erase a program.
/
•
•
•
Skip to the previous/next track.
Skip to the previous/next title or
chapter.
Select a preset radio station.
•
Start or pause play.
s
t DSC
• Select a preset sound setting.
u OK
• Confirm a selection.
v A-B
• Repeat a specific section within a
track/disc.
w SYSTEM MENU
• Access or exit the system setup menu.
x MODE/DIM
• Select repeat play modes.
• Select shuffle play modes.
• Select a brightness level for the display
screen.
EN
11
3 Connect
Connect speakers and
subwoofer
Place the unit
Note
• Ensure that the colors of the speaker wires and
terminals are matched.
• For optimal sound, use the supplied speakers only.
• Connect only speakers with impedance that is the
same or higher than the supplied speakers. Refer to the
Specifications section of this manual.
1
2
1
2
3
Place the unit near to the TV.
Place the left and right speakers at equal
distance from the TV and at an angle
of approximately 45 degrees from the
listening position.
Place the subwoofer at the corner of the
room or at least one meter away from the
TV.
3
Hold down the socket flap.
Insert the stripped part of the wire
completely.
• Insert the right speaker wires to “R”,
left speaker wires to “L”.
• Insert the subwoofer wires to “SW”.
• Insert the red wires to “+”, black wires
to “-”.
Release the socket flap.
a
b
Note
• To avoid magnetic interference or unwanted noise,
•
•
•
12
never place this apparatus and speakers too close to
any radiation devices.
Place this unit on top of a table or mount it on the wall.
Never place this unit in an enclosed cabinet.
Install this unit near the AC outlet where the AC power
plug can be easily reached.
EN
Connect FM antenna
c
Tip
• For optimal reception, fully extend and adjust the
•
•
position of the antenna.
For better FM stereo reception, connect an outdoor
FM antenna to the FM AERIAL jack.
The unit does not support MW radio reception.
English
Note
• The progressive scan video quality is only available
when a progressive scan TV is connected.
• If your TV does not support progressive scan, you
cannot view the picture.
• For how to activate progressive scan on your TV, refer
to the TV user manual.
1
Connect the supplied FM wire antenna to
the FM AERIAL socket on the unit.
Connect a progressive scan TV through
component video for higher quality video.
1
Connect TV
Connect video cables
With this connection, you can watch video from
the unit on the TV screen.
You can select the best video connection that
your TV supports.
• Option 1: connect through
component video (for a standard TV
or Progressive Scan TV).
• Option 2: connect through S-Video
(for a standard TV).
• Option 3: connect through composite
video (CVBS) (for a standard TV).
Connect component video cables (red/
blue/green - not supplied) to:
• the VIDEO OUT (Pr/Cr Pb/Cb Y)
sockets on this unit.
• the component input sockets on the
TV.
Option 2: Connect through S-Video
TV
S-VIDEO IN
Option 1: Connect through
component video
Connect a progressive scan TV through
component video for higher quality video.
TV
1
Connect an S-video cable (not supplied)
to:
• the S-Video socket on this unit.
• the S-Video socket on the TV.
Pr/Cr
Pb/Cb
Y
COMPONENT VIDEO IN PUT
EN
13
Option 3: Connect through
composite video
Connect power
TV
1
Connect the supplied composite video
cable to:
• the VIDEO OUT socket on this unit.
• the video input socket on the TV.
Caution
Connect audio cables
• Risk of product damage! Ensure that the power supply
TV
L LINE IN R
1
To play sound from the TV through this
unit, connect audio cables (red/white - not
supplied) to:
• the AUX IN L/R sockets on this unit.
• the audio output sockets on the TV.
14
EN
•
1
voltage corresponds to the voltage printed on the back
or the underside of the unit.
Before connecting the AC power cord, ensure you have
completed all other connections.
Connect the AC power cord to the wall
socket.
Set clock
1
In the standby mode, press and hold
CLOCK to activate the clock setting
mode.
» The hour digits are displayed and begin
to blink.
2
Press + VOL - to set the hour.
» The minute digits are displayed and
begin to blink.
3
4
Press + VOL - to set the minute.
Caution
• Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
bottom of the apparatus. Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Press CLOCK to confirm the clock setting.
Turn on
1
Prepare the remote control
Press .
» The unit switches to the last selected
source.
Switch to standby mode
Caution
1
• Risk of explosion! Keep batteries away from heat,
sunshine or fire. Never discard batteries in fire.
Press again.
» The clock (if set) appears on the
display panel.
For first-time use:
1
Remove the protective tab to activate the
remote control battery.
To replace the remote control batteries:
1
2
3
Open the battery compartment.
Insert one lithium CR2025 battery with
correct polarity (+/-) as indicated.
Close the battery compartment.
Note
• Before you press any function button on the remote
•
control, first select the correct source with the remote
control.
If you are not going to use the remote control for a
long time, remove the battery.
Find the correct viewing
channel
1
2
3
Press
to turn on the unit.
Press DISC to switch to disc mode.
Turn on the TV and switch to the correct
video-in channel in one of the following
ways:
• Go to the lowest channel on your TV,
then press the Channel Down button
until you see the Philips screen.
• Press the source button repeatedly on
the remote control of your TV.
EN
15
English
4 Get started
•
Tip
1
2
• The video-in channel is between the lowest and highest
channels and may be called FRONT, A/V IN, VIDEO etc.
See the TV user manual on how to select the correct
input on the TV.
3
4
5
6
Select the correct TV system
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
1 Press SYSTEM MENU.
2 Select [Preference Page].
3 Select [TV Type] and then press .
4 Select a setting and then press OK.
• [PAL] - For TV with PAL color system.
• [Auto] - For TV that is compatible
with both PAL and NTSC.
• [NTSC] - For TV with NTSC color
system.
5
To exit the menu, press SYSTEM MENU.
Press SYSTEM MENU.
Select [General Setup Page].
Select [OSD Language] and then press
Select a setting and then press OK.
To exit the menu, press SYSTEM MENU.
Turn on Progressive Scan
Progressive scan displays twice the number of
frames per seconds than interlaced scanning
(ordinary TV system). With nearly double the
number of lines, progressive scan offers higher
picture resolution and quality.
Before you turn on this feature, ensure that:
• The TV supports progressive scan
signals.
16
EN
8
9
To proceed, select [OK] and press OK.
» The progressive setup is complete.
Note
• If a blank/distorted screen is displayed, wait for 15
seconds for auto recovery or turn off progressive scan
manually.
10 Turn on the progressive scan mode on the
Change system menu
language
1
2
3
4
5
7
You have connected this unit with the
TV through component video.
Turn on the TV.
Ensure that the TV progressive scan mode
is deactivated (see the TV user manual).
Switch the TV to the correct viewing
channel for this unit.
Press DISC.
Press SYSTEM MENU.
Press / to select [Video Setup Page]
in the menu, then press .
Select [Component] > [Pr/Cr Pb/Cb Y],
then press OK.
Select [TV Mode] > [Progressive], then
press OK.
» A warning message is displayed.
TV.
.
Note
• With some disc/file types, play may differ.
To access or exit the menu manually:
1
Press DISC MENU.
For VCD with PlayBack Control (PBC) feature
(version 2.0 only):
With the PBC feature, you can play VCD
interactively according to the menu screen.
1
During play, press DISC MENU to enable/
disable PBC.
» When PBC is enabled, the menu
screen is displayed.
» When PBC is disabled, normal play is
resumed.
Play a disc
Caution
• Never look at the laser beam inside the unit.
• Risk of product damage! Never play discs with
•
1
2
3
4
•
accessories such as disc stabilizer rings or disc
treatment sheets.
Never put any objects other than discs into the disc
compartment.
Press DISC to select the DISC source.
Press on the front panel.
» The disc tray opens.
Place a disc onto the tray and press .
» Ensure that the label faces up.
Play starts automatically.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next title/
chapter/track, press / .
If play does not start automatically:
Select a title/chapter/track and then press
.
Select an audio language
You can select an audio language on DVDs,
DiVx video or VCDs.
1
During disc play, press AUDIO.
» The language options appear. If the
selected audio channels is unavailable,
the default disc audio channel is used.
Note
• For some DVDs, the language can only be changed
from the disc menu. Press DISC MENU to access the
menu.
Select a subtitle language
You can select a subtitle language on DVDs or
DivX® Ultra discs.
• During play, press SUBTITLE.
Tip
• To play a locked DVD, enter the 4-digit parental control
password.
Use the disc menu
When you load a DVD/(S)VCD disc, a menu
may be displayed on the TV screen.
EN
17
English
5 Play
Tip
• For some DVDs, the language can only be changed
from the disc menu. Press DISC MENU to access the
menu.
Play from USB
Play DivX video
You can play DivX files copied onto a CD-R/
RW, recordable DVD or USB device.
1
2
3
Note
• Ensure that the USB device contains playable music,
pictures or video.
1
Insert a disc or connect a USB device.
Select a source:
• For discs, press DISC.
• For USB devices, press USB.
Select a file to play and press
.
• To stop play, press .
• To pause or resume play, press
.
• To change a subtitle language, press
SUBTITLE.
Note
Insert the USB device.
• You can only play DivX videos rented or purchased
through the DivX registration code of this unit.
• Subtitle files with the following filename extensions (.srt,
•
.smi, .sub, .ssa, .ass) are supported but do not appear on
the file navigation menu.
The subtitle filename has to be the same as the file
name of the video.
Play MP3/WMA/picture files
You can play MP3/WMA/picture files copied
onto a CD-R/RW, recordable DVD or USB
device.
2
3
4
5
6
18
1
2
Press USB to select the USB source.
Insert a disc or connect a USB device.
Select a source:
• For discs, press DISC.
• For USB devices, press USB.
Press DISC MENU until the folder is
displayed.
3
Press / to select a folder, then press OK
to confirm.
Press DISC MENU until the folder is
displayed.
4
Press / to select a folder, then press OK
to confirm.
5
6
Press / to select a file from the folder.
Press / to select a file from the folder.
Press
to start play.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next file, press
/ .
EN
Press
to start play.
• To stop play, press .
• To pause or resume play, press
.
• To skip to the previous/next file, press
/ .
Play starts automatically at your
selected point.
Select repeat/shuffle play options
1
During play, press MODE/DIM repeatedly
to select a repeat option or the shuffle play
mode.
• To resume normal play, press MODE/
DIM repeatedly until no option is
displayed.
Repeat A-B (DVD/VCD/CD/MP3/
WMA)
1
2
During music or video play, press A-B at
the start point.
Press A-B at the end point.
» The selected section starts to play
repeatedly.
•
Resume video play from last stopped
point
Note
• This feature is only available for DVD/VCD play.
1
In stop mode and when the disc has not
been removed, press
.
To cancel resume mode and stop play
completely:
1
In stop mode, press
.
Play options
To cancel repeat play, press A-B again.
Display play information
Note
1
• The section A and B can be set only within the same
During play, press DISPLAY/RDS
repeatedly to display play information.
track/title.
Program
Search forward/backward
1
During play, press / repeatedly to
select a search speed.
• To resume play at normal speed, press
.
Search by time or chapter/track
number
1
During video/audio play, press GOTO
until a time field or chapter/track field is
displayed.
• For the time field, enter the play
position in hours, minutes and
seconds.
• For the chapter/track field, enter the
chapter/track.
Note
• You cannot program picture files/discs.
For video discs/audio CDs:
1
During play or in stop mode, press
ANGLE/PROG to access the program
menu.
2
Enter the tracks/chapters to add to the
program.
3
Repeat step 2 until the program is
complete.
4
to play the
1
During play or in stop mode, press DISC
MENU until the file list is displayed.
Select [Start], then press
program.
For Divx/MP3/WMA files:
EN
19
English
•
Play control
2
Select a file, then press ANGLE/PROG to
add the file to the program list.
3
Repeat steps 2 until the program is
complete.
4
Select a camera angle
Note
• This feature is only available for DVDs recorded with
multiple camera angles.
Press
to play the program.
To delete a file from the [Program List]:
1
Press DISC MENU until the program list is
displayed.
2
Select a file, then press ANGLE/PROG to
delete the file from the program list.
1
During play, press ANGLE/PROG
repeatedly to select a camera angle.
Picture view options
Zoom in/out image
1
During video/picture play, press
(ZOOM) repeatedly to zoom in/out the
image.
• When the image is zoomed in, you
can press / / / to pan through
the image.
Preview pictures
1
During play, press .
» The thumbnails of 12 pictures are
displayed.
2
Select one of the following:
• a picture
• the slide show option
• the menu option
• the next/previous page (if available)
3
Press OK to:
• play the selected picture
• start slide show of all pictures
• enter the menu where each remote
key function is explained
• turn to the next/previous page (if
available)
Slow-motion play
1
During video play, press (SLOW)
repeatedly to select a slow play option.
» The sound is muted.
» To resume play at normal speed, press
.
Change the audio channel
Note
• This feature is only available for VCD/DivX play.
1
20
During play, press AUDIO repeatedly to
select an audio channel available on the
disc:
• Mono Left
• Mono Right
• Stereo
EN
Select a slide show play mode
1
During play, press ANGLE/PROG
repeatedly to select a slide-show play
mode.
Rotate picture
1
During play, press / to rotate the
picture anti-clockwise/clockwise.
1
2
3
4
Select a setup page.
Select an option and then press
.
Select a setting and then press OK.
• To return to the previous menu, press
.
• To exit the menu, press SYSTEM
MENU.
General setup
•
•
•
Tip
• Enter this DivX registration code when you rent or
purchase video from http://vod.divx.com/. The DivX
videos rented or purchased through the DivX® VOD
(Video On Demand) service can be played only on the
device to which it is registered.
Audio setup
On [General Setup Page], you can set the
following options:
[TV Display]
The TV format determines the aspect ratio of
display according to the type of TV you have
connected.
4:3 Letter Box (LB)
[On] – Enable the screen saver.
[Off] – Disable the screen saver.
[DIVX (R) VOD]
Display the DivX® registration code.
Press SYSTEM MENU.
4:3 Pan Scan (PS)
•
•
English
6 Adjust settings
16:9 (Wide Screen)
[4:3 Pan Scan] – For 4:3 screen TV:
full-height display with the trimmed
sides.
[4:3 Letter Box] – For 4:3 screen TV:
wide-screen display with black bars on
the top and bottom of the screen.
[16:9] – For wide-screen TV: display
ratio 16:9.
[OSD Language]
Select the preferred language for on-screen
display.
[Screen Saver]
The screen saver protects the TV screen
damage due to prolonged exposure to a static
image.
On [Audio Setup Page], you can set the
following options:
[Analog Audio Setup] > [Analog Audio Setup
Page] > [Downmix]
Select audio signals output to speakers.
• [L/R] – If the connected device
supports the Dolby Pro Logic
decoder, select this option.
• [Stereo] –If the sound is delivered
from the two front speakers only,
select this option.
• [3D Surround] – To apply the virutal
surround sound effect, select this
option.
[Analog Audio Setup] > [Digital Output]
Select audio formats supported by the
connected device.
• [SPDIF Off] – Turn off the digital
output.
• [All] – If the connected device
supports multi-channel audio formats,
select this option.
• [PCM Only] – If the connected
device cannot decode multichannel
audio, select this option.
[3D] >[3D Processing Page] > [Reverb Mode]
Select a virtual surround sound mode.
EN
21
[HDCD] > [HDCD Setup Page] > [Filter]
When you play a HDCD (High Definition
Compatible Digital) disc, select the audio output
cutoff frequency.
[Night Mode]
Make loud sound level softer and soft sound
level louder so that you can watch the DVD
movies at a low volume, without disturbing
others.
• [On] – enjoy quiet viewing at night
(DVDs only).
• [Off] – enjoy surround sound with its
full dynamic range.
Video setup
On [Video Setup Page], you can set the
following options:
[Component]
Set the video output according to the video
connection. If the composite connection is used,
this setting is not required.
• [CVBS] – If the S-Video connection is
used, select this option.
• [Pr/Cr Pb/Cb Y] – If the component
connection is used, select this option.
[TV Mode]
Select the video output mode. To select the
progressive scan mode, ensure that you have
connected a progressive scan TV and set
[Component] to [Pr/Cr Pb/Cb Y].
• [Progressive] – For progressive scan
TV: turn on the progressive scan
mode.
• [Interlace] – For ordinary TV: turn on
the interlace mode.
[Picture Setting] > [Picture Setting Setup]
Customize picture color settings.
[TV Type]
Change this setting if the video does not appear
correctly. By default, this setting matches the
most common setting for TVs in your country.
• [PAL] - For TV with PAL color system.
• [Auto] - For TV that is compatible
with both PAL and NTSC.
• [NTSC] - For TV with NTSC color
system.
[Audio]
Select the preferred audio language for disc play.
[Subtitle]
Select the preferred subtitle language for disc
play.
[Disc Menu]
Select the preferred disc menu language.
Note
• If the language you have set is not available on the disc,
the disc uses its own default language.
• For some discs, the subtitle/audio language can only be
changed from the disc menu.
[Parental]
Restricts access to discs that are unsuitable for
children. These types of discs must be recorded
with ratings.
Press OK.
Select a rating level, then press OK.
Press the numeric keys to enter the password.
Note
• Rated discs above the level you set in [Parental]
require a password to be played.
• The ratings are country-dependent. To allow all discs to
play, select [8 ADULT].
• Some discs have ratings printed on them but are not
recorded with ratings. This function has no effect on
such discs.
Preference setup
On [Preference Page], you can set the following
options:
22
EN
English
Tip
• You can set or change the password.
[Default]
Resets all the settings of this unit to factory
default, except for the password and parental
settings.
[Password Setup] > [Password Setup Page] >
[Password Mode]
This setting allows you to enable/disable the
password for parental control. If the password
is enabled, when you play a prohibited disc, this
4-digit password is required.
• [On] - Enable the password for
parental control.
• [Off] - Disable the password for
parental control.
[Password Setup] > [Password Setup
Page] > [Password]
You can change password here. The
default password is 1234.
• [Change]
1) Press the numeric keys to enter ‘1234’ or
your last set password at [Old Password] field.
2) Enter the new password at [New
Password] field.
3) Enter the new password again at [Confirm
PWD] field.
4) Press OK to exit the menu.
Note
• If you forget the password, enter ‘1234’ before you set
a new password.
EN
23
7 Tune to FM
radio stations
Program radio stations
manually
Note
1
Ensure that you have connected and fully
extended the supplied FM antenna.
2
3
4
Press TUNER.
Press and hold
/
.
When the frequency indication starts to
change, release the button.
» The FM tuner tunes to a station with
strong reception automatically.
• You can program a maximum of 20 preset radio
stations.
1
2
Program radio stations
automatically
Press ANGLE/PROG to activate
programming.
3
Press / to allocate a number from
1 to 20 to this radio station, then press
ANGLE/PROG to confirm.
» The preset number and the frequency
of the preset station are displayed.
4
Repeat the above steps to program other
stations.
5
Repeat steps 3-4 to tune to more stations.
To tune to a weak station:
Press / repeatedly until you find optimal
reception.
Tune to a radio station.
Note
• To overwrite a programmed station, store another
station in its place.
Note
• You can program a maximum of 20 preset radio
stations.
1
Press / to select a preset number to
start programing.
2
Press and hold ANGLE/PROG for
2 seconds to activate automatic
programming.
» [AUTO] (auto) is displayed briefly.
» All available stations are programmed
in the order of waveband reception
strength.
» The last programed radio station is
broadcast automatically.
24
EN
Tune to a preset radio station
1
Press / to select a preset number
that you want.
Tip
• You can also use the numerical keypad to select a
preset station directly.
Select automatic loudness control
Automatic loudness control increases the treble
and bass effect at low volume levels (the higher
the volume, the lower the treble and bass
levels).
1
Adjust volume level
1
During play, press VOL +/- to increase/
decrease the volume level.
Select a sound effect
To turn on automatic loudness control,
press LOUD/DBB during play until the
loudness icon is displayed.
• To turn off automatic loudness
control, press LOUD/DBB until the
loudness icon disappears.
Mute sound
1
Note
During play, press MUTE to mute/unmute
sound.
• You cannot use different sound effects at the same
time.
Listen through headphone
Select a preset sound effect
1
1
Plug a headphone into the
the unit.
socket on
During play, press DSC repeatedly to
select:
• [ROCK] (rock)
• [JAZZ] (jazz)
• [POP] (pop)
• [CLASSIC] (classic)
• [FLAT] (flat)
Enhance bass
1
To turn on bass enhancement, press
LOUD/DBB repeatedly during play until
the DBB logo is displayed.
• To turn off bass enhancement, press
LOUD/DBB repeatedly until the DBB
logo disappears.
EN
25
English
8 Adjust volume
level and sound
effect
» To deactivate the alarm timer, select
[OFF] (off) at step 6.
9 Other features
Activate demonstration mode
You can see an overview of all features.
1
In standby mode, press on the main unit
to activate the demonstration mode.
» A demonstration of major available
features starts.
Set the sleep timer
1
When the unit is turned on, press SLEEP/
TIMER repeatedly to select a set period of
time (in minutes).
» The unit turns off automatically after
the set period of time.
To deactivate the demonstration mode:
1
Press
on the main unit again.
Connect other devices
Adjust brightness of display
panel
1
Listen to an audio player
You can listen to audio player through this unit.
In standby mode, press MODE/DIM
repeatedly to select different levels of
brightness for the display panel.
Set the alarm timer
1
Ensure that you have set the clock
correctly.
2
In standby mode, press and hold SLEEP/
TIMER.
» The hour digits are displayed and begin
to blink.
3
Press + VOL - to set the hour.
» The minute digits are displayed and
begin to blink.
4
5
6
Press + VOL - to set the minute.
Press SLEEP/TIMER to confirm.
To activate the wake-up timer, press + VOL
- to select [ON] (on).
» A clock icon appears on the display.
» The unit turns on automatically at
the set time and switches to the last
selected source.
26
EN
1
Connect the audio player.
• For audio players with red/white
audio output sockets:
Connect a red/white audio cable (not
supplied) to the AUX IN L/R sockets
and to the audio output sockets on
the audio player.
2
3
For audio players with headphone
sockets:
Connect the supplied MP3 Link cable
to the MP3 LINK socket and to the
headphone socket on the audio player.
English
•
Select the MP3 Link/AUX source.
Start play on the audio player.
Record to a digital recorder
You can record audio from this unit to a digital
recorder.
1
Connect a coaxial cable (not supplied) to:
• the COAXIAL socket
• the digital input socket on the digital
recorder
2
3
Play audio to be recorded.
Begin to record on the digital recorder
(see the digital recorder user manual).
EN
27
10 Product
information
Note
• Product information is subject to change without prior
notice.
Tuner (FM)
Tuning Range
Tuning grid
Sensitivity - Mono, 26dB
S/N Ratio
Sensitivity - Stereo, 46dB
S/N Ratio
Search Selectivity
Total Harmonic Distortion
Signal to Noise Ratio
87.5 - 108MHz
50KHz
<22 dBf
>43 dBf
>28dBf
<3%
>55dB
Specifications
Speakers
Amplifier
Speaker Impedance 2X4ohm + 8ohm
Speaker Driver
4”
Sensitivity
>80dB/m/W±4dB/m/W
Rated Output Power
Frequency Response
Signal to Noise Ratio
Aux Input
2X25 + 50W RMS
20 -20000 Hz, ±3dB
>65dB
0.5 V RMS 20kohm
General information
AC power
Disc
Laser Type
Disc Diameter
Video Decoding
Video DAC
Signal System
Video Format
Video S/N
Audio DAC
Total Harmonic
Distortion
Frequency
Response
S/N Ratio
28
EN
Semiconductor
12cm/8cm
MPEG-1 / MPEG-2 /
DivX
12Bits
PAL / NTSC
4:3 / 16:9
>48dB
24Bits / 96kHz
<0.1% (1 kHz)
4Hz - 20kHz (44.1kHz)
4Hz - 22kHz (48kHz)
4Hz - 24kHz (96kHz)
>65dBA
110 - 240V,
~50/60 Hz
30W
Operation Power
Consumption
Standby Power
<4W
Consumption
Composite Video Output 1.0Vp-p, 75ohm
Coaxial Output
0.5Vpp ± 0.1Vpp
75ohm
Headphone Output
2X15mW 32ohm
USB Direct
Version 2.0
Dimensions
- Main Unit (W x H x D) 200 x 125 x
270mm
135 x 255 x 150
- Speaker Box (W x H
mm
x D)
160 x 245 x 260
- Subwoofer (W x H x
mm
D)
Weight
9.25 kg
- With Packing
2.05 kg
- Main Unit
2 x 1.25 kg
- Speaker Box
2.7 kg
- Subwoofer
•
•
•
•
Digital Video Discs (DVDs)
Video CDs (VCDs)
Super Video CDs (SVCDs)
Digital Video Discs + Rewritable
(DVD+RW)
• Compact Discs (CDs)
• Picture (Kodak, JPEG) files on CDR(W)
• DivX(R) disc on CD-R(W):
• DivX 3.11, 4.x and 5.x
• WMA
Supported MP3-CD formats:
• ISO 9660
• Max. title/album name: 12 characters
• Max. title number plus album: 255.
• Max. nested directory: 8 levels.
• Max. album number: 32.
• Max. MP3 track number: 999.
• Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
• Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
• The following formats are not supported:
• Files like *.VMA, *.AAC, *.DLF, *.M3U,
• *.PLS, *.WAV
• Non-English Album/Title name
• Discs recorded in Joliet format
• MP3 Pro and MP3 with ID3 tag
•
•
•
•
•
•
•
•
•
•
•
WMA v9 or earlier
Directory nesting up to a maximum
of 8 levels
Number of albums/ folders: maximum
99
Number of tracks/titles: maximum 999
ID3 tag v2.0 or later
File name in Unicode UTF8
(maximum length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an
album that does not contain MP3/
WMA files, and is not be shown in the
display.
Unsupported file formats are skipped.
For example, Word documents (.doc)
or MP3 files with extension .dlf are
ignored and not played.
AAC, WAV, PCM audio files
DRM protected WMA files (.wav,
.m4a, .m4p, .mp4, .aac)
WMA files in Lossless format
USB playability information
Compatible USB devices:
• USB flash memory (USB 2.0 or
USB1.1)
• USB flash players (USB 2.0 or USB1.1)
• memory cards (requires an additional
card reader to work with this
apparatus)
•
•
Supported formats:
USB or memory file format FAT12,
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate
EN
29
English
Supported disc formats
11 Troubleshooting
Caution
• Never remove the casing of this unit.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this unit,
check the following points before requesting
service. If the problem remains unsolved, go to
the Philips web site (www.Philips.com/support).
When you contact Philips, ensure that your
unit is nearby and the model number and serial
number are available.
No power
•
Ensure that the AC cord of the apparatus
is connected properly.
•
Ensure that there is power at the AC
outlet.
•
As a power-saving feature, the system
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
No disc detected
•
Insert a disc.
•
Check if the disc is inserted upside down.
•
Wait until the moisture condensation at
the lens has cleared.
•
Replace or clean the disc.
•
Use a finalized CD or correct format disc.
No picture
•
Check the video connection.
•
Turn on the TV to the correct Video-In
channel.
•
Progressive scan is activated but the TV
does not support progressive scan.
Black and white or distorted picture
•
The disc does not match the TV color
system standard (PAL/NTSC).
•
Sometimes a slight picture distortion may
appear. This is not a malfunction.
•
Clean the disc.
30
EN
•
A distorted picture may appear during
progressive scan setup.
The aspect ratio of the TV screen cannot be
changed even though you have set the TV
display format.
•
The aspect ratio if fixed on the loaded
DVD disc.
•
The aspect ratio may not be changed for
some TV systems.
No sound or poor sound
•
Adjust the volume.
•
Disconnect the headphones.
•
Check that the speakers are connected
correctly.
•
Check if the stripped speaker wires are
clamped.
Remote control does not work
•
Before you press any function button, first
select the correct source with the remote
control instead of the main unit.
•
Reduce the distance between the remote
control and the unit.
•
Insert the battery with its polarities (+/–
signs) aligned as indicated.
•
Replace the battery.
•
Aim the remote control directly at the
sensor on the front of the unit.
Disc does not play
•
Insert a readable disc and ensure that the
label side faces up.
•
Check the disc type, color system and
regional code. Check for any scratches or
smudges on the disc.
•
Press SYSTEM MENU to exit the system
setup menu.
•
Disable the password for parental control
or change the rating level.
•
Moisture has condensed inside the system.
Remove the disc and leave the system
turned on for about an hour. Disconnect
and reconnect the AC power plug, and
then turn on the system again.
•
As a power-saving feature, the system
turns off automatically 15 minutes after
disc play reaches the end and no control is
operated.
English
Poor radio reception
•
Increase the distance between the unit and
your TV or VCR.
•
Fully extend the FM antenna.
•
Connect an outdoor FM antenna instead.
Unable to select Progressive Scan
•
Ensure the video output mode is set to
[Pr/Cr Pb/Cb Y].
Audio or subtitle languages cannot be set
•
The disc is not recorded with sound or
subtitles in multiple languages.
•
The audio or subtitle language setting is
prohibited on the disc.
Cannot display some files in USB device
•
The number of folders or files in the USB
device has exceeded a certain limit. This
phenomenon is not a malfunction.
•
The formats of these files are not
supported.
USB device not supported
The USB device is incompatible with the unit.
Try another one.
Timer does not work
•
Set the clock correctly.
•
Switch on the timer.
Clock/timer setting erased
•
Power has been interrupted or the power
cord has been disconnected.
•
Reset the clock/timer.
EN
31
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: MCD183_98_UM_V2.0
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
