Redbox RB-DA6
Redbox RB-DA6
6 Way Stereo Distribution Amplifier
2014-15
Catalogue
Audio & Video Interfaces - Audio Distribution Amplifiers
RB-DA6 6 Way Stereo Distribution Amplifier
The RB-DA6 is a 1U rack-mount high
performance 6 way stereo distribution
amplifier for splitting a source into a
number of different outputs.
The RB-DA6 has 1 stereo input and 6 stereo
outputs. It can also be configured so that 1
mono input can be distributed to 12 outputs
by use of a switch which is recessed on the
front panel to prevent it being accidentally
knocked.
The XLR-3 inputs and outputs are
electronically balanced and can be wired
unbalanced. Each output is individually
buffered so that a short circuit on one
output won’t affect the others.
The left and right input gain controls
(normalising) are pre-set potentiometers
accessible through the front panel.
The output gain may be varied from -8dB
to 18dB which is useful for normalising
consumer and professional signals to give
outputs of -15dBu and 0dBu respectively.
Category: Audio Distribution Amplifiers.
Product Function: Audio distribution to
multiple destinations.
Typical Applications: Distribute line level
signals to multiple reporters in a broadcast
centre, distribute main programme output
from a mixer to other studios.
Features: Input level adjustment,
mono/stereo switch, Neutrik XLR audio
connectors.
Specification For RB-DA6
Connections
Audio Specification
Inputs:
Maximum
Input Level:
+28dBu
2 x XLR 3 pin female (balanced, can
be unbalanced)
Outputs:
Maximum
Output Level:
+28dBu
12 x XLR 3 pin male (balanced, can
be unbalanced)
Mains Input:
&ƌĞƋƵĞŶĐLJ
Response:
ϮϬ,njƚŽϮϬŬ,njцϬ͘ϭĚ;ϲϬϬɏůŽĂĚ͕
ref 1kHz)
Filtered IEC, switchable 110-120V, or
220-240V, fused, 6W max
Fuse Rating:
Gain Range:
Adjustable 8dB loss to 18dB gain
(L & R adjust)
Anti-surge fuse 100mA 20 x 5mm
(230VAC)
Anti-surge fuse 250mA 20 x 5mm
(115VAC)
Common
>66dB typically
Mode Rejection:
Equipment Type
/ŶƉƵƚ
impedance:
хϮϬŬɏďƌŝĚŐŝŶŐ
Physical Specification
KƵƚƉƵƚ
impedance:
фϱϬɏ
Dimensions
(Raw):
48cm (W) x 10.8cm (D) x 4.2cm (H) (1U)
19” (W) x 4.3” (D) x 1.7” (H) (1U)
Distortion:
0.01% THD @ 1kHz, ref +8dBu output
Noise:
-100dB unity gain, ref +8dBu output
Dimensions
(Boxed):
58.5cm (W) x 22.5cm (D) x 7cm (H)
23” (W) x 8.9” (D) x 2.8” (H)
Weight:
Nett: 1.3kg Gross: 1.9kg
Nett: 2.9lbs Gross: 4.2lbs
RB-DA6:
6 way stereo distribution amplifier
