Android Developer Tools

Essentials

Mike Wolfson

Android Developer Tools Essentials

by Mike Wolfson

Copyright © 2013 Mike Wolfson. All rights reserved.

Printed in the United States of America.

Published by O’Reilly Media, Inc., 1005 Gravenstein Highway North, Sebastopol, CA 95472.

O’Reilly books may be purchased for educational, business, or sales promotional use. Online editions are also available for most titles (http://my.safaribooksonline.com). For more information, contact our corporate/ institutional sales department: 800-998-9938 or [email protected].

Editors:

Andy Oram and Rachel Roumeliotis

Production Editor:

Rachel Steely

Copyeditor:

Gillian McGarvey

Proofreader:

Charles Roumeliotis

Indexer:

Ellen Troutman

Cover Designer:

Randy Comer

Interior Designer:

David Futato

Illustrator:

Rebecca Demarest

August 2013: First Edition

Revision History for the First Edition:

2013-08-13: First release

See http://oreilly.com/catalog/errata.csp?isbn=9781449328214 for release details.

Nutshell Handbook, the Nutshell Handbook logo, and the O’Reilly logo are registered trademarks of O’Reilly

Media, Inc. Android Developer Tools Essentials, the image of a cassowary, and related trade dress are trade‐ marks of O’Reilly Media, Inc.

Many of the designations used by manufacturers and sellers to distinguish their products are claimed as trademarks. Where those designations appear in this book, and O’Reilly Media, Inc., was aware of a trade‐ mark claim, the designations have been printed in caps or initial caps.

While every precaution has been taken in the preparation of this book, the publisher and author assume no responsibility for errors or omissions, or for damages resulting from the use of the information contained herein.

ISBN: 978-1-449-32821-4

[LSI]

Table of Contents

Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

1. Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Minimum Requirements 1

Installing Java 2

Installing the Android Software Development Kit 3

Installing the ADT Bundle 3

Developing Without Eclipse 5

Command-Line Usage 6

Using a Different IDE 6

Configuring a Device for Development 7

2. Essential Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

SDK Manager 11

SDK Components 11

Starting the SDK Manager 12

Viewing Installed and Available Components 13

ADT Preview Channel 15

Android Debug Bridge (ADB) 17

Starting ADB 17

Querying for Device Instances 18

Issuing Commands 19

The Shell Command 20

ADB Does a Lot More 22

Resetting the ADB Server 23

Additional Resources 24

3. Configuring Devices and Emulators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Using a Physical Device for Development 25

iii

Capabilities and Limitations 25

Configuring a Physical Device for Development 26

Using an Emulator for Development 26

Supported Features 27

Android Virtual Devices 28

Creating AVDs 28

Emulator Options 32

Advanced Emulator Configuration 33

Using Hardware Acceleration 33

Disabling the Boot Animation 37

On Windows: Dedicating a Core to the Emulator 37

4. Using Devices and Emulators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Using the Emulator 39

Starting the Emulator 40

The Emulator Application 47

The Devices Tool 48

Keyboard Shortcuts 50

File Explorer 50

Developer Tools Application 52

5. Developing with Eclipse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Anatomy of the Eclipse Workspace 55

Uncovering Additional Tools and Views 57

Quick Button 59

Code Templates 59

Properties Editors 65

XML Formatter 67

The Android Key 67

Quick Outline for XML 68

Other Essential Eclipse Shortcuts 69

Refactor Menu 70

6. Developing with Android Studio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Installing Android Studio 71

Bundled SDK 72

Default Project Location 74

Anatomy of the Android Studio IDE 74

Panels 74

Toolbars 75

Useful Actions in Android Studio 76

Navigation 76

iv | Table of Contents

The New Structure of an Android Project 77

A Tour Around the New Structure 77

Running and Debugging an Android Project 78

Creating New Android Components 79

Layout Designer and Layout Preview 80

Layout Designer 80

Layout Preview 81

Generating an APK 82

Interacting with Maven and Gradle 83

Interacting with Maven 83

Interacting with Gradle 84

Version Control Integration 85

Migrating from Eclipse 86

Android Studio Tips and Tricks 86

Refactoring and Code Generation 87

Miscellaneous Shortcuts 87

7. Testing Your Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Logcat 89

Viewing the Logcat File 89

Anatomy of a Log Message 89

Filtering Based on Logging Level 91

Using Tags to Filter Output 92

Getting the Most Out of Logcat 92

Viewing Alternative Log Buffers 93

Predefined Output Formats 93

Logcat Viewer in Eclipse 93

Logcat Example 94

Debugging 98

Setting Your App to Debuggable 99

Setting a Debug Point 99

The Eclipse Debug Perspective 100

Debugging Example 101

Lint 107

Command-Line Usage 108

Running in Eclipse 110

8. Simulating Events. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Simulating Location and Routes 115

Simulating Telephony Operations 118

Changing Networking Parameters 121

Using a Device with Sensor Emulation 122

Table of Contents | v

Advanced Sensor Testing 122

Supported Sensors 123

Simulating Sensor Events in Real Time 123

Recording Sensor Scenarios 124

Developer Options Menu 126

9. Build Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Compiling Your Code 129

Packaging an APK for Release 130

Signing Your App 130

Building from the Command Line Using Ant 133

Setting Up Your Project 135

Building in Debug Mode 136

Building an App to Release to the Play Store 136

Additional Ant Commands 138

Advanced Packaging Steps 139

ProGuard 139

Zipalign 144

Gradle-Based Build Tools 144

Installing Gradle 144

Creating Multiple Build Variations 145

Build File 147

Build Tasks 148

Generating a Gradle Build from Eclipse 148

Using the Maven Tools 149

10. Monitoring System Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Memory Usage in Android 151

Dalvik Debug Monitor Server (DDMS) 152

Launching the DDMS Perspective 152

Analyzer Tool 154

Threads 155

Heap 156

Traceview 157

Memory Analyzer Tool (MAT) 159

Generating an HPROF File 160

HPROF File 160

Installing MAT into Eclipse 160

Launching MAT from Within Eclipse 160

Using MAT to Analyze HRPOF Files 161

The MAT Overview Screen 162

vi | Table of Contents

Viewing a Report 162

11. Working with the User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Android Layout Basic Concepts 165

Defining Layouts Using XML 165

Views and ViewGroups 167

Resources 170

Leveraging ADT to Build Great UIs 171

Editing XML Files Directly 172

Using Templates 172

Editing XML Directly 173

Working with Graphics 182

The Asset Tool 183

Using Nine-Patch Images 185

Asset Studio Website 187

12. Using the Graphical Editor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Generating Layouts Using the Graphical Layout Editor 189

Palette 191

Canvas 192

Layout Actions 194

Context-Sensitive Menu 194

Outline View 196

Properties Editor 196

Configuration Chooser 197

13. Optimizing the User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Introduction to UI Performance 201

How Android Draws Views, and How It Affects UI Performance 201

Hierarchy Viewer 203

Starting the Hierarchy Viewer 203

Loading the View Hierarchy into the Tools 203

Navigating the Tree Hierarchy 203

Gathering View Information 205

Gathering View Rendering Details 207

Example: Debugging a UI Using the Hierarchy Viewer 208

Fixing Problems Using Lint 218

Application Exerciser Monkey 219

Grooming the Monkey 220

Monkeyrunner 221

Using Python to Create the Script 221

Table of Contents | vii

Thanks for Reading! 222

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

viii | Table of Contents

Preface

If you are reading this book, it’s likely that you already know a little about Android development and how challenging it can be. Learning to effectively use the standard

Android Developer Tools (ADT) can make the development process easier and improve the quality of your code, thereby producing a more refined and robust end product.

Requirements for Android Developer Tools

Android is very different from other mobile platforms currently available. It is not managed by a single organization, but by a group of companies named the “Open

Handset Alliance,” which is committed to providing a mobile OS that is free, complete, and open source. While this approach ensures decentralized control of the platform, it does create some complexities. These include:

Multiple screen sizes

Android devices come in a multitude of different screen sizes. Success of your app can hinge upon how your app looks across devices.

Fragmentation

It is up to the carrier and manufacturer to update their devices when a new version of the OS and runtime are released, which doesn’t always happen in a timely manner.

It is therefore necessary to support older versions of the OS and runtime.

Different hardware capabilities

Android phones come in all shapes, sizes, and capabilities. It is necessary to ensure that you degrade unsupported features gracefully when the hardware is limited.

Another important consideration is the particular hardware components on which you can or cannot rely (for instance, some devices don’t have cameras, GPS sensors, or keyboards).

ix

Resource limitations

Developing applications targeted to the mobile environment is different from de‐ veloping for the desktop. CPU speed and memory are limited compared to desktops or servers. Mobile device users don’t put up with apps that tie up their devices

(blocking the UI), consume too many resources, or crash their devices.

Development Process for Android Developer Tools

Google manages ADT development, as well as the standard Android platform. However, the two products are managed very differently, particularly in regards to the opensource nature of the products. The ADT project is developed by a different group from the one that manages the main platform. The tools are released separately from the standard SDK and follow their own release cycle, which is frequently (but not always) tied to the platform release.

The standard OS is developed behind closed doors—contributions are not accepted to the current code base. The source code is released to the public at some point after the group releases it to manufacturers and other insiders.

The first line on the ADT website makes it clear that this project is different. It reads:

“The Developer Tools for Android are being developed entirely in the open and [the project] is accepting contributions.” ADT is developed as a series of open source projects with publicly accessible Git repositories and a public bug tracker . The management group solicits contributions from the community and considers them for implemen‐ tation in current releases. You can find information on how to contribute on their website .

Development on a Variety of OS Platforms

Just as Android is designed to run on many different devices, it is also possible to use many different computer configurations when developing Android applications. This book provides examples based on the Windows 7 64-bit OS and Mac OS X, using the

Eclipse Integrated Development Environment (IDE). One chapter introduces the new

Gradle-based Android Studio. But you should be able to follow along with any OS and

IDE, as the tools have been ported to work on a large variety of platforms. It is also worth noting that it is possible to develop for the Android platform without using an IDE at all, as most of the tools can be run directly from the command line.

Conventions Used in This Book

The following typographical conventions are used in this book:

Italic

Indicates new terms, URLs, email addresses, filenames, and file extensions.

x | Preface

Constant width

Used for program listings, as well as within paragraphs to refer to program elements such as variable or function names, data types, and XML keywords.

Constant width bold

Shows commands or other text that should be typed literally by the user.

Constant width italic

Shows text that should be replaced with user-supplied values or by values deter‐ mined by context.

This icon signifies a tip, suggestion, or general note.

This icon indicates a warning or caution.

Using Code Examples

This book is here to help you get your job done. In general, if this book includes code examples, you may use the code in your programs and documentation. You do not need to contact us for permission unless you’re reproducing a significant portion of the code.

For example, writing a program that uses several chunks of code from this book does not require permission. Selling or distributing a CD-ROM of examples from O’Reilly books does require permission. Answering a question by citing this book and quoting example code does not require permission. Incorporating a significant amount of ex‐ ample code from this book into your product’s documentation does require permission.

We appreciate, but do not require, attribution. An attribution usually includes the title, author, publisher, and ISBN. For example: “Android Developer Tools Essentials by Mike

Wolfson (O’Reilly). Copyright 2013 Mike Wolfson, 978-1-449-32821-4.”

Supplemental material (code examples, exercises, etc.) is available for download at

https://github.com/mwolfson/ToolsDemo

.

If you feel your use of code examples falls outside fair use or the permission given above, feel free to contact us at

[email protected]

.

Preface | xi

Safari® Books Online

Safari Books Online (

www.safaribooksonline.com

) is an ondemand digital library that delivers expert content in both book and video form from the world’s leading authors in technology and business.

Technology professionals, software developers, web designers, and business and crea‐ tive professionals use Safari Books Online as their primary resource for research, prob‐ lem solving, learning, and certification training.

Safari Books Online offers a range of product mixes and pricing programs for organi‐ zations , government agencies , and individuals . Subscribers have access to thousands of books, training videos, and prepublication manuscripts in one fully searchable database from publishers like O’Reilly Media, Prentice Hall Professional, Addison-Wesley Pro‐ fessional, Microsoft Press, Sams, Que, Peachpit Press, Focal Press, Cisco Press, John

Wiley & Sons, Syngress, Morgan Kaufmann, IBM Redbooks, Packt, Adobe Press, FT

Press, Apress, Manning, New Riders, McGraw-Hill, Jones & Bartlett, Course Technol‐ ogy, and dozens more . For more information about Safari Books Online, please visit us online .

How to Contact Us

Please address comments and questions concerning this book to the publisher:

O’Reilly Media, Inc.

1005 Gravenstein Highway North

Sebastopol, CA 95472

800-998-9938 (in the United States or Canada)

707-829-0515 (international or local)

707-829-0104 (fax)

We have a web page for this book, where we list errata, examples, and any additional information. You can access this page at

http://oreil.ly/Android_Essentials

.

To comment or ask technical questions about this book, send email to

bookques [email protected]

.

For more information about our books, courses, conferences, and news, see our website at

http://www.oreilly.com

.

Find us on Facebook:

http://facebook.com/oreilly

Follow us on Twitter:

http://twitter.com/oreillymedia

Watch us on YouTube:

http://www.youtube.com/oreillymedia

xii | Preface

Acknowledgments

Special thanks to my wife Dana. Without your support and encouragement, this book

(and many other things in my life) wouldn’t be possible. I love you and appreciate ev‐ erything you do for me.

Thanks to the tech reviewers who stuck with me and provided great feedback through‐ out the long writing process: Jason Douglas, Maija Mednieks, Charlie Meyersohn, and especially Peter Van Der Linden, whose thorough review and excellent comments im‐ proved the quality of the book and made my job much easier. I couldn’t have done it without you.

Thanks to Donn Felker for your last-minute help on Android Studio. Your content really improves the quality of this book. Looking forward to shipping more products together!

Shout-out to Heatsync Labs in Mesa, AZ and CO+HOOTS in Phoenix, AZ for providing spaces that foster creativity.

Preface | xiii

CHAPTER 1

Getting Started

It’s fairly easy to set up the Android developer environment. The steps are basically the same for all supported platforms (with small variations on each OS). I’ll describe them in detail so you can be sure you have everything configured correctly.

Installation instructions might change over time. These basic steps are consistent with the latest release. However, they might change, so you should always check the online documentation to make sure you are installing and using the most up-to-date version.

The basic steps are:

1. Make sure your computer meets minimum requirements.

2. Install the Java Development Kit (JDK).

3. Install the Android SDK.

4. Install the Eclipse Integrated Development Environment (IDE).

5. Install the Android Developer Tools (ADT) plug-in for Eclipse.

Minimum Requirements

To develop for Android, you’ll need a reasonably responsive computer. You will likely be running a few memory-intensive processes (including emulators) and IO-intensive things (such as building your code or packaging a release artifact). The published base requirements for Android make it possible to develop on a variety of very low-powered devices (such as netbooks), but for practical purposes I suggest using a development environment with more widely available resources. Guidelines for practical minimum requirements are listed in

Table 1-1 .

1

Table 1-1. Practical minimum hardware requirements

Windows Linux Mac OS X

OS Version Windows XP (32-bit) Ubuntu, RedHat, and others OS X (10.4.9 +)

Hard Disk Space 25GB 25GB 25GB

System Memory 3GB

Processor Dual Core +

USB USB 2.0+

2GB

Dual Core +

USB 2.0+

4GB x86 Only

USB 2.0+

Installing Java

The Android development platform is built on the standard Java framework. Android applications are built on top of the Java platform, so you will need to install it in order to do anything with Android. Make sure you get the Java Developer Kit (JDK) as op‐ posed to the Java Runtime Environment (JRE) (which may already be installed on your system). The JDK has the compiler, debugger, and other tools you will use to develop software; the JRE is a runtime for executing those tools. Download the latest version, choosing the default settings (it is not necessary to have any of the optional packages that are available).

Currently, Android is designed to target Java version 1.6. If you down‐ load a version newer than this (which is likely), you will need to set the Java Compiler level to be compliant with 1.6. In Eclipse, a Java

Compiler option in the properties of your Android project allows you to set this.

You can download the JDK installation packages for each supported OS from the Java download site .

Optionally, if you are on Linux, you can use a package manager (such as apt or yum) to download and install Java. For instance, on Ubun‐ tu or Debian, use the following command: sudo apt-get install sun-java6-jdk

In general, Mac OS X developers aren’t required to install Java manually. On the Mac

OS, Java comes preinstalled, with a custom packaged version directly from Apple.

Updating to newer versions of Java is only possible when Apple releases an update through their own channels. To confirm that the correct version of Java is installed, the following command can be run from any terminal window to display this information:

2 | Chapter 1: Getting Started

java -version

More information about Java on Mac OS X is available here: Mac OS Java site .

Installing the Android Software Development Kit

The Android Software Development Kit (SDK) is the collection of libraries, tools, doc‐ umentation, and samples that are required to run and develop Android apps and to use the tools. It is not a complete development environment, and contains only the base tools needed to download the rest of the necessary components. Downloading tools and

components will be discussed in detail in the section about using the “SDK Manager” on page 11

.

In order to get started, you will need to download the “ADT Bundle.” This is a new packaging style (as of ADT version 21) that includes all the components required to develop for Android packaged as a single, integrated download. Previous to this release, it was necessary to download and install each of the required components separately, and then set them up to work together. This manual approach is more error-prone, but is still supported, particularly if you wish to use an IDE other than Eclipse. The manual procedure is described on the Android Developers web page titled Setting Up an Ex‐ isting IDE . I strongly recommend you use the ADT Bundle to install the tools. It streamlines the process, minimizes the chances of error, and creates a standard directory structure for the tools. The bundle includes each of these components:

• The Eclipse IDE, including the ADT plug-ins, and all the required extensions

• The SDK Tools

• The Platform Tools

• The latest Android Platform

• A CPU image compatible with the latest platform

Installing the ADT Bundle

The most recent release of the tools provides a convenient single package containing everything necessary to develop Android. It makes installation easy.

Downloading the ADT bundle

On the main page of the SDK site , you will notice a button to download the package,

which currently looks like Figure 1-1

. This link will automatically download the version for the OS you are using. Make sure you have good Internet connectivity (it is a large download—at the time of this writing, over 400MB).

Installing the Android Software Development Kit | 3

Figure 1-1. Downloading the ADT Bundle

Extracting the tools to Android Home

The next step in the installation is to extract the artifacts to an appropriate location on your filesystem. You will need to select the location to install the tools, which can be wherever you wish. I suggest placing this directory at a high level in the filesystem, in order to make it easier to reference, locate, and back up. Here are some suggestions:

If you are on a single-user machine or want to put everything in a common location, you could use the following locations:

• Windows: C:\android

• Linux or Mac OS X: /usr/dev/android

It is common and perfectly acceptable to put Android in your home directory. For instance:

4 | Chapter 1: Getting Started

• Windows: C:\Users\youruserid\android

• Mac OS X: /Users/youruserid/android

• Linux: /home/youruserid/android

Unzip the downloaded artifact to the Android folder

Use the appropriate utility (such as WinZip on Windows, tar on Linux, or just doubleclick the file on Mac OS X) to extract the Bundle into the folder you chose in the previous step. If you do this correctly, you should see the android-sdk folder in the Android

Home

folder you created in the previous section. On Windows, this is C:\android\sdk, and on Mac OS X or Linux, it’s /usr/dev/android/sdk.

Setting your PATH variable

Next, you will need to append the location of the Android executables to your PATH environment variable. This is not strictly required, but makes it much easier to use the

Android tools from anywhere on your system (and will be assumed in the examples in this book). All the executables we want to use from the command line can be found in the platform-tools and the tools directories in your Android installation.

Setting your PATH is different on each OS. Instructions about how to do this can be found on the help pages of each operating system, or in this article, which contains a great overview of how to set and use PATH and other environment variables.

You can verify that your path is set correctly by opening a new terminal window and typing android at the command prompt. This will launch the SDK Manager, which signifies you did everything correctly and that you have successfully installed the An‐ droid SDK. You will use the SDK Manager to download additional components, but won’t need to use it now, since the ADT Bundle already has the current platform included.

Validating the installation

To validate that everything was installed correctly, launch the Eclipse executable by clicking on or running ${android.sdk}\eclipse\eclipse. Eclipse will start, and prompt you to enter the location of the workspace. This is the location where your project-specific assets (source code, images, build scripts, and so on) will be stored. You can select whatever location you prefer, or just use the default value supplied. Eclipse will start, and you will see a customized version of the tool (named the Android Developer

Tools – ADT). Congrats, your installation was successful.

Developing Without Eclipse

Although it is recommended that you use an IDE to help in the development process, the tools provided in the SDK can also be used on the command line or with other IDEs.

Developing Without Eclipse | 5

You will be able to do almost anything you need (including compiling, building and packaging artifacts, launching emulators, and using the tools) strictly using the com‐ mand line or other tools.

Command-Line Usage

To start using the tools from the command prompt, simply start a terminal window, and type the name of the tool you want to start at the command prompt. If you set your

PATH variable properly (according to the instructions in

“Setting your PATH vari‐ able” on page 5

), you will be able to execute the various command from anywhere on your filesystem. Some examples of command-line usage can be found in

“Android De‐ bug Bridge (ADB)” on page 17 . The main way you will access the tools is through Eclipse,

but you can also access them from the command line. This is useful for scripting or automation. It is not recommended to use them exclusively, as the tools integrated into

Eclipse are excellent, make a lot of tasks simpler, and will likely make your coding more efficient.

Windows users can use Explorer to navigate to their

C:\android\sdk

\tools

folder, highlight the full address, and simply replace it with cmd.

Press Enter, and the command prompt starts at the location.

Using a Different IDE

It is not strictly necessary to use Eclipse for development. Many people have had success using Netbeans or IntelliJ. At the time of this writing, the officially supported IDE is

Eclipse, which is the tool we will focus on for this book. In general, I suggest using the officially supported tools. This will ensure that you are able to get the latest updates and are using the most stable tool. Another important reason to stick with the suggested tools is that you will be using the same tools as a majority of the development community, so bugs you come across will likely be easier to fix because they’ll be encountered by a larger community of users.

The open-source nature of the Tools projects means that they are designed to be platform- and tool-agnostic. This means the development team takes care to ensure the tools run well everywhere. If you do have a preference for other development tools, you most likely will be able to use them for your Android projects. There are robust com‐ munities supporting various platforms, and in many cases, the alternate tools do things better than Eclipse.

At Google I/O 2013, the Android tools team announced support for a new IDE named

“Android Studio” ( Chapter 6

describes how to use it). This looks like an exciting alter‐ native for the future. However, it is currently a very early release, so it is not ready for production usage.

6 | Chapter 1: Getting Started

The NetBeans IDE also supports Android development. Information about using this can be found on the Android Plug-in for NetBeans page on the Kenai website.

Configuring a Device for Development

The simplest way to test your applications is often by using an Android device. You can use almost any Android device for development, as long as you make a few changes in order to enable communication with the development tools.

1. Configuring a Physical Device for Development.

The instructions for setting up your device to be used as a development device are covered in

“Configuring a Physical Device for Development” on page 26

.

2. Change phone settings.

Launch the Settings app on your phone, then select Applications → Development

→ USB-Debugging. Check the box next to “USB debugging” to enable this func‐

tionality. The result should look like Figure 1-2 .

3. Download the ADB driver.

In order to connect an Android-powered device for testing on Windows machines, it is necessary to install the appropriate USB driver. This is not necessary on Mac

OS X or Linux.

You can find drivers at the website of the manufacturer of your phone. You may be able to find a driver through the Android Document website , which contains a list of links to software for many original equipment manufacturers (OEMs).

4. Validate debugging on the phone.

Connect your device to your computer. If everything went well, you will see a no‐ tification ( ) from your operating system, indicating that the device is installed and ready to use.

You will also notice two new entries in the notification drawer of your device (shown

in Figure 1-3

). These will show that you are successfully connected. You can select them to launch the Settings application.

Configuring a Device for Development | 7

Figure 1-2. Debugging enabled for testing apps on a phone

8 | Chapter 1: Getting Started

Figure 1-3. Debugging notification

Congratulations! You have successfully installed everything you need to develop and test Android applications.

Configuring a Device for Development | 9

CHAPTER 2

Essential Tools

This chapter describes the fundamental tools that you need in order to start developing

Android applications. In it, I will show you how to use the SDK Manager to download various development resources, and discuss using the command-line tools (in particular the Android Debug Bridge – ADB).

SDK Manager

The SDK Manager is a GUI tool designed to make it easy to download and install the required components. It is likely the first tool you will encounter, and the one you will use most often. The SDK Manager allows you to update the Android SDK and install additional components.

SDK Components

The Android SDK has a modular structure, which means that the major components of the SDK are collected into separate packages. This makes it easy to install only the components you need for your particular unique use case. The packages you install are determined by the version of the OS you are targeting, if you use third-party services

(like Google Maps or Analytics), and if you plan to support specific hardware (like a particular chipset or a dual screen). The modular structure has two important benefits.

The first is that disk storage is not wasted on downloading unnecessary components.

This is important because each platform requires at least 100MB of space, and this can grow rapidly when optional packages are included. The other advantage is that man‐ aging dependencies within a project is streamlined because it is possible to control exactly which software you are working with, and install only the components you require.

It is important to understand the various components that are available. They are or‐ ganized into categories:

11

SDK Tools

These include the various utility tools you will use to develop apps. These are es‐ sential tools required by all developers. You can think of them as the core system tools of the platform. These include android, ddms, apkbuilder, and emulator, among others. You can find these in the android-sdk/tools directory.

Platform Tools

These are additional tools that are developed alongside the core platform, and are typically updated in concert with the release of a new version of the platform. These include adb, fastboot, dx, aidl, and others. You can find these in the android-sdk/

platform-tools

directory.

Android Platform

An SDK platform is released for every version of Android. Each release includes a compliant library, system image, emulator skins, and platform-specific tools. Patch‐ es and point releases to the platform are also located here .

Google APIs

The additional libraries required to use Google-specific services such as Google

Cloud Messaging or Maps.

Drivers

This contains driver files that allow an Android device to communicate with a computer. USB drivers here can be or downloaded from here.

Samples and documentation

Here you’ll find the sample code and documentation for each platform release. This includes example projects containing documented code that can and should be used when designing your own code. As with the SDK, it is generally a good idea to use the latest release because updates include the best examples with the least bugs.

Third-party add-ons

This category includes tools and libraries for third-party add-ons, including the

Android support package and the Analytics SDK. This also includes third-party add-ons such as a Samsung Galaxy Tab skin, Motorola SDK add-ons, and the Nook

Color SDK add-ons. You can also find customized, fully compliant Android system images representing particular devices.

Starting the SDK Manager

The SDK Manager can be launched as an independent application, directly from the

OS or from inside Eclipse. Follow these steps depending on how you will be launching the SDK Manager:

12 | Chapter 2: Essential Tools

Windows

Start → All Programs → Android SDK Tools → SDK Manager

Linux/Mac OS X

Open a terminal, and run android.

Eclipse (all platforms)

Look for the icon in your Eclipse toolbar. Click on it to launch the SDK Manager.

On all platforms, you can also launch directly from the menu: Window → Android

SDK Manager.

The SDK Manager GUI launches, as shown in Figure 2-1

.

Figure 2-1. SDK Manager

Viewing Installed and Available Components

After launch, the SDK Manager will present a list of all the packages available for down‐ load from the SDK repository. The components are organized into those defined in

SDK Manager | 13

“SDK Components” on page 11 . You can click on the white triangle ( ) next to any

particular platform to expand the tree and see more detail about the compatible re‐

sources available. Figure 2-1

shows the Android 4.2 and 4.1.2 sections expanded to expose more details about the compatible downloads available. In this view, you will see additional information about a particular package (this is the column on the right). This includes version information and install status. If there is a newer version of a compo‐ nent available, it will appear in the status column. In

Figure 2-1 , you will notice that

there is an update available for the Tools.

Selecting packages

Next, select the packages you want to download. Place a checkmark next to each indi‐ vidual component that interests you, or select every package in a release by marking the top-level package. After you have selected the packages you want to download, you are ready to proceed. The button on the bottom right (marked “Install X packages...”) now indicates the number of selected packages. Confirm that this number matches what you expect, as it is common to have packages marked for download that you didn’t expect, and this is not always obvious (especially if something is marked in a platform that is not expanded).

The various packages can take up a lot of space on your computer (for instance, each of the core platforms are around 100MB, without the docs or samples). It is important to decide which packages you want to support, and limit your downloads to those that are important to you. There are a lot of things to consider when making this decision, and a discussion of this is outside the scope of this book. This discus‐ sion covers it well, and is recommended reading.

Installing packages

Click the Install Packages button to finalize your selections and start the installation process. You are then prompted to accept the “Terms Of Service” for the software you are downloading. Make sure to click the Accept All button, or else all the components may not install. After you have accepted them, the downloads will begin.

The packages are downloaded to your computer and automatically stored in the ap‐

propriate folder in the location where you installed Android (see “Extracting the tools to Android Home” on page 4

). The components are downloaded into the following subdirectories:

14 | Chapter 2: Essential Tools

Platforms

Add-ons

Samples

platforms/android-

API_level add-ons samples/android-

API_level

Documentation docs (there is only one copy, because old docs are replaced)

In some cases (such as when installing device drivers), you need to run the software you downloaded to complete the installation. Other components, including the Platform components, are automatically installed during the download process and don’t require additional installation steps.

Deleting and updating components

In order to delete a package, follow the same process as you did when you installed it.

Select the packages to delete, and then click the Delete Packages button. If there are packages that need to be updated, select them and click the Install Packages button.

Don’t forget to confirm that the number of packages shown on the button is correct, so you don’t accidentally remove something you need.

Managing dependencies

For the most part, Android developers don’t need to worry about package dependencies too much. For the most part, the components are designed to run independently of each other. As long as you are extra careful and double-check which packages you are in‐ stalling or removing, you shouldn’t have many problems managing installed compo‐ nents. If you do make an error, you now know how easy it is to use this tool to manage your installed components.

ADT Preview Channel

The ADT team releases new code frequently. This can include bug fixes, or previews of new features. You may want to try a particular release if it has a particular bug fix you require or new tools that you would like to try. The ability to download and install a

preview is integrated directly into the “SDK Manager” on page 11

, which makes switch‐ ing to it very simple. For the most part, you should use the officially released tools, because they are more stable, but having the ability to switch to the newest tools can be useful in some situations.

Enable the Preview Channel

The Preview Channel is not enabled by default. You can access this setting (as shown

in Figure 2-2

) from the following menu: Tools → Options → Check “Enable Preview

Tools.”

SDK Manager | 15

Figure 2-2. Enabling the Preview Channel

Installing Preview Tools

After enabling this option, you will see the Preview Channel option, shown in

Figure 2-3 , appear in the list under the “Tools (Preview Channel)” heading. To install

it, select it, then click the Install Packages button to use that version of the tools.

16 | Chapter 2: Essential Tools

Figure 2-3. Verifying that the Preview Channel is enabled

Reverting to released tools

If you would like to revert to the released version, simply reinstall that version by se‐ lecting it and then clicking the Install Packages button again.

Android Debug Bridge (ADB)

ADB is the main tool that allows you to interact with your emulator or a connected device. The ADB process is actually a client/server program. The server component communicates with a variety of clients (such as the command line or DDMS). The daemon process on the device facilitates communication of activities such as:

• Push/pull of data or apps

• Issuing shell commands

• Restarting the device

• Reading system logs

Starting ADB

Start the ADB client using the command line. To start the process, simply execute the following command: adb

Android Debug Bridge (ADB) | 17

Querying for Device Instances

The ADB server automatically connects to all of the devices or emulators that are cur‐ rently connected to your computer. If you have only one device connected, it will au‐ tomatically connect to that single instance. If you have more than once device connected, you will need to direct commands to a specific instance.

Find connected devices

You can get a list of all devices that ADB is able to communicate with by issuing the following command: adb devices

The response will include:

Serial number

The unique ID of each connected device. You will need the serial number to connect directly. The format of the serial number includes information about the device itself (namely, the type of device and the port on which it is listening).

State

The connection state of the device. This will be offline if the device is connected but not responding. It will be device if is available and connected. Otherwise, the re‐ sponse will be no devices, which indicates there are no active devices that ADB can communicate with currently.

Directing a command to a specific device

Now that you know what devices are on your system, you can direct a command to a specific instance by issuing the following command: adb -s serialNumber

command

The example below shows how you would target a command to a particular device, when more than one is connected. The first step is to issue the devices command to display a list of connected devices. The list shows two connected devices: the first is a physical device, and the second is an emulator (which is clear from the name). The next step is to use the -s option to target the preferred device. In this example, we are using

ADB to find the ADB version number of the attached emulator.

$

adb devices

List of devices attached emulator-5556 device emulator-5554 device

$

adb -s emulator-5556 version

Android Debug Bridge version 1.0.31

$

18 | Chapter 2: Essential Tools

If there is only one device connected, ADB automatically defaults to use that instance. I usually keep only one device connected at a time.

This makes issuing ADB commands simpler because I don’t need to specify a device argument anymore (ADB will default to the only run‐ ning device). For example, you can eliminate the targeting step dur‐ ing the deploy cycle, which speeds up this common task.

Issuing Commands

Now that ADB knows which device to target, we can interact with it. It is possible to do a variety of useful things with this interface. Let’s walk through a few examples:

Transferring files

It is very easy to transfer files between your computer and your device using the push and pull commands. push goes from your computer to the device, whereas pull does the opposite. You can include additional path parameters if you would like to specify a particular location for the files. If a path is not specified, the commands will use the current directory of your computer for the local location and the data folder on the device for the remote location. push and pull can also copy complete directories

(recursively), which can be very useful.

The syntax of push is: adb push

local -directory

remote

An example of using this command is shown here. We are using ADB to push a file named foo.txt from the current directory to the SD card. The syntax for this is: adb push foo.txt /sdcard/foo.txt

To move the file off the SD card and back onto your machine, in a new directory and with a new name, type: adb pull /sdcard/foo.txt C:/tmp2/foo2.txt

This looks like this, when executed from the command line:

$

adb push foo.txt /sdcard/

0 KB/s ( 8 bytes in 0.019s

)

$

adb pull /sdcard/foo.txt /tmp/foo2/txt

1 KB/s ( 8 bytes in 0.004s

)

$

Managing applications on a device

A very common process is to install or remove applications from a device. This is easy to accomplish using ADB. Simply issue the install command and supply a valid APK file. This installs the app on your device.

Android Debug Bridge (ADB) | 19

The syntax of the command is: adb install foo.apk

The syntax is similar to remove an app, except that you need to supply the package name instead of the APK filename as an argument.

The syntax of the command is: adb uninstall com.example.masterd

$

adb install foo.apk

2134 KB/s ( 222527 bytes in 0.101s

)

pkg: /data/local/tmp/foo.apk

Success

$

adb uninstall com.tools.demo

Success

$

The Shell Command

The Android Framework is built upon a modified Linux kernel. The creators of Android added their own middleware, libraries, and APIs to the Linux kernel to develop the framework. This means that it includes a command-line interface that will look familiar to Linux users. The shell interface will have many of the same tools developers are used to, but not all of them. Additionally, the tools themselves may be different, and likely won’t support every operation you expect. For instance, the ls -l command works, but

ls -x

does not.

The binaries for the included tools are stored on the device in the /system/bin folder. I suggest you look in that folder to familiarize yourself with the commands that are avail‐ able. Some frequently used commands that are not available include more, less, cp, and

file

. Some common tools that are included are ls, ps, and rm. It is definitely worth re‐ viewing the contents of the /system/bin/ directory. It contains not just the standard command-line tools, but also a variety of additional tools designed specifically for An‐ droid development (like monkey, logcat, dumpstate, etc.). You may get frustrated by the limitations of the Android shell, especially if you are used to the more feature-rich options available in full Linux distributions. You should spend some time learning how to use these tools effectively; they may be limited, but they still are still very useful.

You can use ADB to access the command shell of a device directly. You can issue com‐ mands as one-line executables, or interact with the shell interactively by issuing a series of commands.

Interactive mode

Interactive mode allows you to execute more than one command successively on the device. To start interactive shell mode, type: adb shell

20 | Chapter 2: Essential Tools

You will see a # symbol, which indicates that you are in shell mode. When you are ready to exit the remote shell, you can use Ctrl+D or type exit to end the shell session.

The example belows shows accessing the shell, using common Linux commands to navigate the directory structure, reading the contents of a file, and finally, exiting the shell back to the command prompt.

$

adb shell

[email protected]:/

#

pwd

/ [email protected]:/

#

cd /system/etc

[email protected]:/system/etc

#

pwd

/system/etc [email protected]:/system/etc

#

cat ./hosts

127.0.0.1 localhost [email protected]:/system/etc

#

exit

$

One-off mode

It is also possible to execute commands noninteractively. To do this, type the command you want to execute after the shell keyword.

adb shell

command

The next example shows how you would read the /system/etc/hosts file by issuing a single command that executes, but does not maintain, an open connection to the remote shell.

$

adb shell cat /system/etc/hosts

127.0.0.1 localhost

$

Retrieving system data

There are many cases in which you need detailed information about the various systems on your device. Some useful commands can dump huge amounts of information about the system, including service status, system statistics, and error logs. You may want to collect these statistics if you are trying to analyze trends or specific details about your application.

adb shell dumpsys

Outputs data about specific system services to the screen. For example, adb shell

dumpsys alarm

will output details about all the alarms currently registered on the system.

adb shell dumpstate

Detailed system data representing a device at a particular state in time (includes dumpsys information as well).

adb shell dmesg

Outputs the contents of the kernel’s ring buffer to the screen. This output is quite verbose, and contains a lot of key information from the system kernel, including

Android Debug Bridge (ADB) | 21

information about the CPU, memory, OS version, system mount points, and lots more. It can be useful, especially when trying to debug hardware issues, or when writing software that interacts directly with the system hardware.

adb shell logcat -b radio

This command provides access to the cellular radio log. This information is useful when interacting with the networking stack. Some of the information available in this log includes time of events, a listing of commands used by the system to com‐ municate, SMS information, IP information, and cellular network data.

Using the Activity Manager

Shell access allows much more granular access to the device. You can use this to start applications or even single activities in a controlled way. This can be very useful if you need to test different entry points to an application that may be hard to simulate by stepping through the UI. Use the Activity Manager to launch a specific screen with a specific set of Intent parameters.

An example of starting an activity named com.foo.FooActivity directly would be: adb shell am start -n com.foo/.FooActivity

In

Figure 2-4 , I start my app at a particular activity (MemDemoActivity), which is not

the activity defined in the manifest as the main launcher activity.

adb shell am start com.tools.demo/.MemDemoActivity

ADB Does a Lot More

The ADB tool has a variety of additional functionality that is beyond the scope of this book. It is worth becoming familiar with these additional features, as they provide a lot of useful and important functionality.

Some functionality worth highlighting includes:

• Modify network configuration options like port forwarding (example: adb forward

tcp:7101 tcp:8101

)

• Access your device as the root user (example: adb shell su)

• Restart the device in alternate modes, such as recovery mode (example: adb reboot

recovery

)

• View system logs, such as the radio or event buffers (example: adb logcat -b events)

• Show kernel debug info (example: adb shell dmesg)

• Examine system utilization (example: adb shell tail | top)

22 | Chapter 2: Essential Tools

Figure 2-4. Activity Manager example

There is a lot of other functionality we aren’t able to cover. For a complete list of all available commands and their parameters, type adb -help without any additional argu‐ ments to get a listing of all options.

Resetting the ADB Server

There will be times when ADB loses connectivity, or encounters other issues that require resetting the process. To do so, stop the existing ADB process, and then restart it by issuing the following two commands in order:

1.

2.

adb kill -server adb start-server

$

adb kill -server

$

adb start-server

Android Debug Bridge (ADB) | 23

* daemon not running. starting it now on port 5037 *

* daemon started successfully *

$

adb devices

List of devices attached emulator-5554 device

$

Additional Resources

There are many features of the ADB tool that I am not able to cover in this chapter. If you would like to learn more about the advanced capabilities of this tool, there are a few excellent resources.

Command Reference

The command reference on the official Android page has a listing of all the com‐ mands and their options.

XDA Devs ADB Guide

The XDA Devs website has a very complete explanation of how to get started using the advanced features of ADB, and is targeted towards people wanting to root their devices.

Embedded Android Book

This book by Karim Yaghmour contains in-depth explanations relating to the in‐ ternals of the ADB tool and using it to control embedded environments.

24 | Chapter 2: Essential Tools

CHAPTER 3

Configuring Devices and Emulators

When developing mobile applications, it is necessary to test your code on many different devices. Because there is such a large variety available for Android (at the time of this writing, there are over 3,000 devices supported in the Google Play Store), this can be particularly challenging. It is necessary to test your app to ensure it runs well on the majority of devices; you also need to test out a few different screen sizes. You may also need to account for different hardware capabilities, including OS levels, existence of sensors, amount of memory, or CPU. Fortunately, ADT provides tools that make han‐ dling these challenges easier. I’ll describe how to test on real devices, and also how to use emulators when the devices you need aren’t available.

Using a Physical Device for Development

For many activities, it’s important not to rely completely on an emulator, but to check your app on an actual device. For instance, this is particularly useful when you are testing advanced graphics rendering, utilizing location services, or making use of advanced sensors. It is not strictly necessary to own an Android device to develop for Android

(see

“Using Hardware Acceleration” on page 33 for details), but it is a common and simple

way to start testing with minimal effort. This section will go through the steps required to use an Android device as a development aid.

If you don’t already have a device, it is easy to acquire a cheap used handset; check

Craigslist or eBay for older devices. Other alternatives are outlined later in this chapter

(including HAXM and Genymotion).

Capabilities and Limitations

As I mentioned, there are reasons to use a physical device instead of an emulator. Here is an overview of the most important capabilities and limitations:

25

Capabilities

• Making real phone calls and sending real SMS text messages.

• Using multitouch on a screen.

• Having access to actual location data, in multiple locations and when in motion.

• Using advanced sensors, such as a compass, gyroscope, or barometer.

Limitations

• Certain core services of a phone might be locked down by the device manufacturer or service provider. It might be difficult to change networking parameters or access resources as the root user.

• Testing on a device, particularly if it is one you rely on, could mess up your phone.

• Simulating distant locations is a no-go (for example, if you want to test a location in Egypt and your device is in Belize).

Configuring a Physical Device for Development

Almost any Android phone can be used for development. In order to configure a device, enable the option in the Settings app on the device. To do this, open the Settings app, then select Applications → Development. Place a checkmark next to USB debugging (if you are running a device with OS 4.0+, the setting is located in a slightly different place within the Settings app, namely “Developer options”). The result should look like

Figure 3-1

.

Using an Emulator for Development

We all agree that it is necessary to test Android apps on a variety of different devices and hardware. As it is practically impossible to own every physical device, you will need to use an emulator to check configurations of hardware you don’t have. Some of the important reasons to use emulators include:

• Testing on different hardware configurations

• Validating on different versions of the Android OS

• Simulating load or other stress tests

• Viewing your UI on various screen sizes and resolutions

26 | Chapter 3: Configuring Devices and Emulators

Figure 3-1. Enable USB debugging on a physical device

Supported Features

The emulator included in the standard toolkit is feature-rich, however there are some constraints.

Supported features

• Simulating telephony, including latency and connectivity

• Simulating text messaging

Using an Emulator for Development | 27

• Simulating both a single location or a path

• Simulating a variety of hardware configurations (see “Emulator Options” on page

32

for options)

• Modifying networking (including port redirection, DNS settings, and proxy set‐ tings)

• Simulating various processor types, including ARM and Intel (see

“Using Hardware

Acceleration” on page 33

)

• Using multimedia (video only, not audio)

Unsupported features

• Cannot make real phone calls or send real text messages

• No accessing of Google services such as Gmail, Google Play Store, and other

Google-specific applications

• No advanced graphics support without using native x86 processor support; see

“Using Hardware Acceleration” on page 33

for a workaround

• No simulating of touch events (in particular multitouch, or gestures); see

Chap‐ ter 4

for a workaround that allows you to use a device to simulate sensors

• No accessory integration (USB, headphones, or other peripherals)

• No support for performance-sensitive applications—the standard emulator does not reliably perform as a real device would in all situations

Android Virtual Devices

To test a variety of devices, you will want to create different emulator images (to represent different devices). These configurations are stored in files with the avd extension, which stands for Android Virtual Device (AVD). It allows you to specify hardware and software options that will be used by the emulator to model an actual device.

Creating AVDs

There are two primary ways to create AVDs. The easiest way is to use the graphical AVD manager. It is also possible to configure AVDs from the command line by passing con‐ figuration parameters to the android tool. For the most part, you will likely want to use the graphical tool, as it is simple to use. You would use the command-line option when working with scripts or other noninteractive operations (for instance, if you are creating emulator images on a build server, or using a batch operation to test your code on multiple device configurations).

28 | Chapter 3: Configuring Devices and Emulators

AVD Manager

Next, let’s look at the AVD Manager, a GUI tool designed to make configuring AVDs simple. Start it by clicking on the icon or running the android tool from the command

line. The first time you launch it, you will see something similar to Figure 3-2 . The screen

will display a list of existing emulator configurations. You will be able to create, edit, repair, start, or see details of the various AVDs you have configured.

Figure 3-2. AVD Manager

To create a new emulator configuration, click the New button to launch the “Create new

Android Virtual Device (AVD)” wizard (see Figure 3-3 ). You will then use this simple

form to set the various configuration options necessary.

Android Virtual Devices | 29

Figure 3-3. Create AVD wizard

To configure an AVD, you need to supply a variety of configuration parameters. They will be used to define the specific hardware parameters you wish to emulate. The options include:

Name

Identifies your current configuration image. This can be anything you like, but you should choose a name that lets you identify the specific options offered by the AVD.

I usually name these according to the device I am trying to emulate, e.g., Galaxy‐

Nexus, SamsungS4, or HTCOne.

Device

Allows you to select a preconfigured image based on a variety of common devices.

Target

Specifies the version of the platform the device will run. The tool will allow you to specify only those platforms that you have downloaded to your environment. In

other words, if you have not used the SDK Manager ( Chapter 1

) to install the API you wish to use, you will not be able to create an emulator running that version.

30 | Chapter 3: Configuring Devices and Emulators

CPU/ABI

Specifies a particular hardware configuration to use (currently either ARM or Intel

Atom). See “Using Hardware Acceleration” on page 33 for information on how to

enable it.

SD Card

Simulates an SD card. You can specify the size and location on your local disk (the default is the ~/.android folder).

Snapshot

Enabling this feature gives you the ability to save and restore an emulator’s state to a “snapshot” file. This can be useful for saving the state of an emulator, allowing you to quickly boot to a specific state, avoiding lengthy boot times. For more informa‐ tion, see

“Using the Emulator” on page 39 .

Skin

Allows you to specify a particular screen size and resolution. It provides a set of standard screen configurations for a particular platform, or you can specify custom values.

Creating AVDs from the command line

It can be useful to generate AVD images from the command line when you are scripting or using an environment where employing the GUI isn’t practical. To create AVDs using this method, you need to pass command-line parameters to the android tool.

To create an AVD, run the android create avd command and include parameters that specify the particular configurations. Required parameters are a name for the AVD and the system image that should run on the emulator when it is invoked. If you want, you can also specify other options, such as SD card size, OS platform, skin, or a specific location in which to store user data files. The syntax of the command is: android create avd -n name -t targetID/ [option value] ...

As an example, if we wanted to create an AVD named ToolsAvd, targeting the Android

2.3 Platform

, with a WVGA800 display, the command would look like this: android create avd -n ToolsAvd -t 5 --skin WVGA800

Location of the AVD files

When you create an AVD image (regardless of whether you do it using the GUI tool or command line), a variety of files are stored on your system in a default directory named .android. This directory contains the AVD configuration files, the user data image, the SD card image (if configured), and any other relevant files. The root of this directory will also contain a file named AVD_name.ini. This file contains the location of the directory containing the AVD files.

The default location of this directory is:

Android Virtual Devices | 31

~/.android/avd on Linux or a Mac

C:\Documents and Settings\user\.android on Windows XP

C:\Users\user\.android on Windows 7 or Vista

If you would like to specify a different default location for this directory, you can create an environment variable named ANDROID_HOME and set it to the new default loca‐ tion. It is also possible to specify a different location for a specific AVD by including

-p path as an option when you create the AVD. If you do set a custom location for the .android folder, make sure you put it on a local directory and not a network drive.

Emulator Options

There are many options available when creating an AVD. I will describe a few of the most common ones you will likely want to set for each emulator you create. If you want to learn about all the available options, this AVD Command Reference is an excellent source.

Device RAM size

Sets the amount of physical RAM available on a device (in MB or megabytes). The default value is 96, which is quite low. I suggest increasing this value substantially to improve emulator performance. I generally set it to 512, but you can set it higher if your hardware can support it.

Keyboard support

Defines whether the device will support the physical keyboard on your computer.

I always set this to “yes,” because it makes interacting with the device easier. You will be able to use your computer keyboard to interact directly with the Android

OS, which makes typing much easier than trying to use the onscreen keyboard with your mouse.

Camera support

Defines whether your emulator will support camera functionality. If your app re‐ quires a camera, make sure to set this value, as the default is “no.” You can specify if your emulator will support front, back, or both cameras.

GPS support

Will allow your device to support location functionality. The default for this is “yes,” so you will need to change it only if you specifically want to disable this functionality.

Cache partition size

This value is used by the Google Play Store to determine whether a device can download an app from the market. This value differs greatly between devices (for instance on an HTC Wildfire, it is 30 MB, and on the Nexus S, the size is 500 MB).

It is worth testing with a variety of settings to make sure your app will work on

32 | Chapter 3: Configuring Devices and Emulators

many different devices. I suggest setting this to 1024 MB, especially if you see

Installation error: INSTALL_FAILED_INSUFFICIENT_STORAGE

messages when trying to install an app.

Advanced Emulator Configuration

Working with the emulator can be frustrating. Some of the most common tasks (like starting or deploying an app) can take a long time. There are a few simple things you can do to make it faster, including using VM hardware acceleration, eliminating un‐ necessary functionality, and dedicating a CPU core to the emulator.

Using Hardware Acceleration

People running development machines on Intel processors can use the Hardware Ac‐ celerated Execution Manager (Intel HAXM) to speed up the Android emulator on the host computer. Using it can improve performance significantly, but there are also lim‐ itations to consider.

Benefits

Key benefits of HAXM include:

• Improved emulator performance, in particular, quicker startup and shorter deploy times.

• Better performance of graphics-intensive applications, particularly those that make use of OpenGL.

• Better use of native hardware: if your development computer is robust, using

HAXM will allow you to use it to its full potential.

Limitations

There are also some limitations to consider:

• HAXM doesn’t support Google APIs, which means you can’t test apps (such as Maps or Cloud Messaging) using this code.

• The performance characteristics of the emulator are not the same as you would find in the real world, because most current Android devices use different (ARM-based) processors.

• HAXM offers support only for certain API levels: currently only APIs 10, 15, 16, and 17.

• It has very specific hardware requirements: your processor must support VT-x,

EM64T, and the Execute Disable Bit.

Advanced Emulator Configuration | 33

Downloading the components

In order to use HAXM, you need to install some software on your host computer. The easiest way to do this is using the SDK Manager (see

“SDK Manager” on page 11 ).

Download and install the following components:

• Android SDK Platform that supports HAXM (the only supported API levels are 10 and anything over 15)

• Intel Atom x86 System Image (consistent with the platform version)

• Intel Hardware Accelerated Execution Manager Driver (from the Extras section)

As an example, if you want to create a HAXM enable emulator compliant with API 16,

you need to ensure your selections look like those in Figure 3-4 .

Installing the HAXM software

It is not enough to just download the tool; you also need to install it. On Windows and

Mac OS X, you can do this by running the executable available in the ${android.sdk}/

extras/intel/Hardware_Accelerated_Execution_Manager

directory. You need to launch the installer process and accept the license agreement to complete the installation.

In order to use this functionality on Linux, you also need to install the KVM software package. Instructions for this vary based on the particular version of the OS being used.

The official documentation, HAXM Linux Install Guide , describes the additional steps required for running on Linux.

Configuring an AVD

Once you have downloaded and installed the correct components, follow the usual procedure to creating an AVD. You will see additional options for using the Intel-based system for your emulator. When you create an AVD and specify a compatible Target (in this case API 16), you will be able to specify a particular CPU/ABI image to use. Select the “Intel Atom (x86)” option to enable HAXM. The dialog should look like

Figure 3-5

.

34 | Chapter 3: Configuring Devices and Emulators

Figure 3-4. Example of selecting necessary components to run HAXM

Advanced Emulator Configuration | 35

Figure 3-5. Configuring an AVD to use HAXM

Select the “Use Host GPU” option for your image. HAXM executes most CPU instruc‐ tions natively in the processor, so this option enables OpenGL to be accelerated by the host GPU.

Do not select the Snapshot option. Snapshots are not supported for emulators with graphics acceleration enabled.

Validating that HAXM is running

After you have installed all the correct components and started your correctly config‐ ured AVD, you can easily validate that everything is running correctly. If it is, a notifi‐ cation indicating success is displayed in the console during startup (

Figure 3-6

).

36 | Chapter 3: Configuring Devices and Emulators

Figure 3-6. Validating that HAXM is running

Disabling the Boot Animation

When the emulator starts up, it displays a boot animation. Generally this isn’t something you need to see, and it’s preferable not to waste precious seconds while it displays. You can disable the boot animation by adding the -no-boot-anim option to your AVD start command. For example: emulator -avd myAvd.ini -no-boot-anim

On Windows: Dedicating a Core to the Emulator

If you are running on a Windows machine and have a multicore processor, it is possible to dedicate one of the CPU cores to a running emulator process. This prevents it from contending for a CPU with other resource-intensive processes (such as Eclipse). To do this, start the Windows Task Manager, select the Processes tab, right-click on the running emulator process, and click on “Set Affinity option ().” Then you will be able to check or uncheck the CPU processor core(s) on which you want to run the application (see

Figure 3-7

). Finally, click OK to finish the setup.

Advanced Emulator Configuration | 37

Figure 3-7. Dedicating a core to the emulator

38 | Chapter 3: Configuring Devices and Emulators

CHAPTER 4

Using Devices and Emulators

Using the Emulator

In the previous chapter, we learned how to create emulators. Now we’ll discuss their use. An emulator is a very powerful tool that makes testing easier and allows the de‐ veloper to simulate a variety of things that would be difficult to accomplish under realworld conditions. For instance, if you are writing a mapping application, you might need to test locations all over the world, and it would be impractical (although quite a bit of fun) to actually travel to each of these locations. The emulator provides the ca‐ pability to simulate networking configurations, hardware/software configurations, and sensor events. It eliminates the need to have physical devices to represent each config‐ uration that you need to test. For instance, you will use emulators to mock various screen sizes and memory configurations. This chapter describes how to use the emulator to effectively test various parameters.

For the most part, emulators and physical devices interact with the ADT tools in the exact same way. In other words, the operations we discuss in this chapter perform the same way on an emulator as they will on a physical device. In most cases, a physical device is more limited, because options (such as changing network configurations) are locked down by the service provider.

You will likely use many different combinations of physical devices and emulators to test thoroughly. You can run as many different emulators and devices as you like. If you plan on running a lot of emulator instances, you will need a powerful computer to support it (depending on configuration, each emulator can require 1 GB+ of dedicated memory). It is common for a developer to have many different emulator and physical devices running at the same time, then use each of them throughout the test cycle. It is worth noting that the emulator doesn’t support certain actions, such as simulating ac‐ celerometer activity, or simulating some sensor activity (such as the magnetometer).

39

You should review the “Capabilities and Limitations” on page 25

discussion to determine whether the emulator suits your needs.

Starting the Emulator

In the previous chapter, we discussed using the AVD Manager to create AVDs (

“Creating

AVDs” on page 28 ). This tool is also used to start the emulator instances as well. It

provides options to control runtime parameters of the emulators you created.

To start it from within Eclipse, click the icon from the main toolbar.

Or start it from the command line with the following command: android avd

When you launch the AVD Manager, you will see a screen similar to

Figure 4-1

. This screen displays a list of all the AVDs you have configured on your system, and some options for managing them. To start an emulator, select a particular AVD and click the

Start button.

Figure 4-1. AVD Manager tool

You are then presented with a secondary screen ( Figure 4-2

) that has a variety of options specific to running an emulator instance.

40 | Chapter 4: Using Devices and Emulators

Figure 4-2. AVD launch options

AVD launch options

It is important to understand the launch options, and what they do. Using them allows you to change the size, performance, and data of your emulator.

Scale factor

This allows you to adjust the size of the emulator on your computer screen. To specify a particular screen size, place a checkmark in the Scale Factor box. Next, click the ? next to the dpi option to set the particular resolution of your computer.

Enter the resolution and size of your display. Then type a number in the Screen Size box. Your emulator will be started with the screen size you entered.

Snapshot

This lets you save an emulator’s state to a snapshot file and restore it later. This can be useful if you would like to preconfigure an emulator to start in a particular state every time, or would like to avoid the lengthy boot process when starting from scratch. This is a great way to speed up the time to boot an emulator, and will save a lot of time. Emulator boot times can be reduced from many minutes to just seconds.

Starting an emulator from the command line

It’s not absolutely necessary to use the AVD Manager to start an emulator. You can also start it from the command line. This is useful when using scripts, or if you would like to run an emulator without the overhead of Eclipse. There are a variety of configuration options you can use when starting an emulator this way. There are options relating to networking, graphics acceleration, sensor abilities, and more. To see a complete list of options, type: emulator -help

Using the Emulator | 41

The command to start an emulator has the following syntax: emulator -avd avd_name

[

option

[

value

] ] ...

For example, you could start an emulator with graphics acceleration turned on and boot animation disabled (two good options you can use to improve performance). This would look like:

emulator -avd Nexus7 -gpu on -no-boot-anim

Using snapshots to improve performance

The snapshot is a view of your emulator including all data, the current UI being dis‐ played, or any other sensor or data currently being used. This snapshot can be very useful if you wish to start your emulator with a certain configuration or state multiple times. In order to use snapshots with a particular AVD, it needs to be configured ap‐ propriately. Reread

“Creating AVDs” on page 28 to review how to do this.

You will notice three options in the snapshot section of the launch configuration tool.

Wipe user data

Refreshes your emulator image to remove all data and resets it to a clean configu‐ ration (just as if it were started for the very first time).

Launch from snapshot

Allows you to restore your emulator to the state it was in when the last snapshot was taken. If there is no snapshot in memory, this option is not enabled.

Save to snapshot

Triggers the system to save a snapshot of the current state of the emulator when you close it.

I use snapshots as a way to save a clean emulator that I can recover quickly. I save a snapshot the first time I start the emulator, right af‐ ter it has completed the boot sequence. From that point forward, I make sure I don’t check the “Save Snapshot” box. If I need a clean emulator image, I can just restart this emulator and thanks to snap‐ shots, I will have a fully booted clean emulator ready to go.

Saving and retrieving a snapshot

Snapshots are such a great way of speeding up your emulator usage, it is worth going through an example to show exactly how they work. Let’s step through setting up an emulator using snapshots so you can actually see it for yourself.

42 | Chapter 4: Using Devices and Emulators

The first step when using this functionality is to enable it for the AVD you are using. If you haven’t done this already, review

“Creating AVDs” on page 28

to do it.

When you start your emulator, the options for snapshots will be enabled. The first time you start your emulator, you should select the “Wipe user data” and “Save to snapshot” options (as shown in

Figure 4-3

). This starts the emulator with a brand new image, and allows you to save your state when you close it down. Once you have these checkmarks selected, you can press the Launch button to start the emulator. Depending on the speed of your hardware, this can take a long time (anywhere from 90 seconds to many mi‐

nutes). After the wait, you have an emulator booted to its clean state ( Figure 4-4

).

Figure 4-3. Enabling the options to save the initial snapshot

Using the Emulator | 43

Figure 4-4. AVD snapshot initial instance

44 | Chapter 4: Using Devices and Emulators

Now configure your device to a state you would like. In this example, the state we’ll save

is the emulator started with the main Activity of an app displayed (see Figure 4-5 ). Now

close the process; in this case, that means clicking the red circle on the top left to kill the window. This will take a little bit of time (maybe up to a minute) because a “snapshot” of the current state of the emulator is being saved, which will allow you to recover to this state easily.

Figure 4-5. AVD snapshot saved state

Using the Emulator | 45

The next time you start your emulator, you can select the middle selection: “Launch from snapshot” (see

Figure 4-6 ). When you select this option, and press the Launch

button, instead of the emulator starting from scratch (which takes many minutes), it starts up to the state we saved when we shut down the emulator in the previous step.

Because the emulator doesn’t need to go through the entire boot process, startup time is drastically improved (the emulator will start to a snapshot state in around 10 seconds).

You will see your emulator booted right to the same place (as shown in Figure 4-7 ).

Figure 4-6. Enabling the options to launch from snapshot

46 | Chapter 4: Using Devices and Emulators

Figure 4-7. AVD after loading snapshot state

The Emulator Application

The emulator you start will look similar to the one in Figure 4-8 . The emulator consists

of a screen and optionally a keyboard or navigation buttons, if they were enabled when you created your AVD (

“Creating AVDs” on page 28 ). The emulator runs like a native

application in your operating system, and can be closed or minimized just like any other window (by clicking an X or red button at the top of the window).

Using the Emulator | 47

Figure 4-8. Emulator anatomy

The Devices Tool

So how do you keep track of the emulators or devices you have hooked to your com‐ puter? You can use the Devices tool (shown in

Figure 4-9

), which allows you to see and control the various devices or emulators connected to your computer. This will be the central location where you control your devices. You will start a variety of important operations from this window (including memory inspection, location and network simulation, and UI inspection). I cover these operations in the DDMS section (

“Dalvik

Debug Monitor Server (DDMS)” on page 152

).

I’ll also highlight frequently used, essential functionality you that you will access directly from this tab.

The primary way to access the Devices tool is from a tab at the bottom of your screen

(see

Figure 4-9

). The devices tab should be there by default. If it is not there, you can add it from the menu: Window → Show View → Other → Android → Select Devices from list.

48 | Chapter 4: Using Devices and Emulators

Figure 4-9. Viewing running devices using the Devices tool

There is also a version of the tool that can be run from the com‐ mand line without Eclipse. This is particularly useful for team mem‐ bers that might not have the full development suite installed, but could still benefit from using these tools. The tool is named Android Debug

Monitor, and can be started with the following command:

{$android.sdk}\tools $ monitor

The upper left corner contains the Devices view. This will show you all the devices (both physical devices and emulators) that are currently connected and available. You can use the arrow on the left to collapse or expand a particular device tree in order to see details about the current running processes. In

Figure 4-9

, you’ll see different devices connec‐ ted. The first two are emulators (the icon and their name both signify this), and the last one in the list (with the funny name that is a mix of letters and numbers) is a physical device.

There are a variety of useful operations that can be launched from this tab, including:

Debugging

The first button on the top ( ) allows you to enter debugging mode. In this mode, you can attach the debugger to an application that is already running. This means that you can start an application, run it until it gets to the place you would like to test, and then start debugging from that point. This can be an efficient way to directly debug exactly the code you want and avoid other code paths.

Using the Emulator | 49

Heap

The second set of buttons allows you to start inspection of the memory (heap) of a

running application. See Chapter 10 for more information.

Device screen capture

The next button ( ) launches a utility that allows you to take a screenshot of what is currently displayed on your device. Pressing this will launch the dialog in

Figure 4-10

. The dialog shows an image of whatever is currently displayed on the screen of your device, along with buttons across the top that will enable you to save, rotate, or refresh the image.

Reset ADB

The upside-down triangle ( ) is a particularly important button. Pressing this al‐ lows you to access the controls to reset the ADB process. This resets connectivity between the computer and the devices. You can use it if you encounter connectivity issues between your computer and device.

Keyboard Shortcuts

If you enabled keyboard support when you created your AVD (see “Emulator Op‐ tions” on page 32

), a variety of keys will be mapped between your computer keyboard and the emulator. I have listed some of the more useful mappings in

Table 4-1 . A de‐

scription of each option can be found in the emulator documentation on the Android developer website.

Table 4-1. Popular shortcuts

Key

Home

Effect

Android Home

F2

Esc

Menu

Back

Ctrl-F11 (Cmd-F11 on Mac) Rotate landscape/portrait

Keypad 4/6/5/8/2 D-Pad: left/right/center/up/down

Ctrl-F8 Toggle Cell Network On/Off

File Explorer

ADT provides a GUI tool that makes exploring and interacting with the files on the device very easy. It allows you to navigate the file system to discover which files are on the device, move files onto and off the device, and modify the file system by adding and rearranging folder locations. To use this tool, open the DDMS perspective, select a de‐ vice, and select the File Explorer ( ) tab. This allows you to do a variety of things, including:

50 | Chapter 4: Using Devices and Emulators

Figure 4-10. Capturing a screenshot using the Devices tool

• Push files to a device ( )

• Pull files from the device ( )

File Explorer | 51

• Delete a file from the device ( )

• Create a new directory/folder ( )

Developer Tools Application

One more important tool that we need to explore is the “Developer Tools” application.

It is installed by default on all system images included with the SDK, and is preinstalled on your emulator.

This application allows you to enable various settings on your device that will make it easier to test and debug.

The application incudes some of the basic items you might expect (such as “Stay Awake

When Connected” or “Allow Mock Location”).

In addition to the standard debugging options, there are many other tools designed to help debug applications by enabling visuals when certain events occur (such as touch events, or the UI thread being locked). These tools are very useful when you are testing on a real device, as you can quickly visualize many system operations.

You can find the icon (labeled “Developer Tools”) to launch the application in the main app drawer. It allows you to do a large variety of activities relating to testing, instru‐ menting, and inspecting the state of various systems on your device. A brief list of some of the core functions follows:

If you are running a device with Android 4.2 and up, the developer options are hidden by default. You will need to know the “secret” way to enable them.

To enable them, open the Settings app, scroll to the bottom, then click

“About phone” (or “About tablet”) and then tap on the Build number at the bottom of the screen seven times. After doing this, you will see a message that says “Congratulations, you are now a developer,” and the “Developer options” will be available.

Accounts Tester

Allows you to access and configure a variety of user accounts on the emulator. Very useful if you need to test logins or similar authorization functionality.

Bad Behavior

Allows you to simulate a variety of issues, like creating ANR (Activity Not Re‐ sponding) events, or crashing key systems (like the main app thread or the system server).

52 | Chapter 4: Using Devices and Emulators

Configuration

Displays the current configuration values for the keyboard and display parameters.

You can also see things like system locale, keyboard type, and display metrics (such as density). This can be extremely useful when trying to determine how your app looks on different resolution devices.

Connectivity

Allows you to modify the networking parameters or modify the WiFi connectivity of the device. This is useful when you need to test connectivity issues or how your app will perform without connectivity.

Development Settings

Does a variety of things such as enable debugging, show system statistics (such as running processes, CPU, and memory usage) or display UI hints (like showing the coordinates of touch points or flashing the screen during updates).

Instrumentation

Runs unit tests directly on the device.

Media Scanner

Scans the media folder of your SD card and identifies any media available for use.

Package Browser

This tool should look familiar, as it is the same tool you use to manage apps from the Android Settings app installed on your device. It serves the same purpose

(managing applications) here as well.

Pointer Location

Displays visible lines and coordinates that allow the developer to closely determine specific touch points.

Running Processes

Presents a list of processes currently running.

Sync Tester

Tests third-party sync adapters.

Terminal Emulation

Opens a terminal, allowing command-line access to the Linux shell.

Developer Tools Application | 53

This application relies on many system-level permissions that aren’t available to third parties. If you would like to run this on an actual physical device, it is necessary to build a custom system image and sign the Dev Tools APK with the same key as the system image. After signing the app correctly, you will be able to install it and run it on a device. This means that you can only run it on a rooted device, or on a device for which you built the system image. The system image signing key is generally only available to the hardware manufacturer.

54 | Chapter 4: Using Devices and Emulators

CHAPTER 5

Developing with Eclipse

ADT provides a robust and powerful development environment in which to build An‐ droid applications. Designed as a plug-in to the Eclipse IDE, it leverages many Eclipse features including code completion, syntax highlighting, and JUnit integration. There is also a rich ecosystem of plug-ins and additional features available to download and install from third-party developers. In addition to the standard IDE, there are a variety of Android-specific tools that have been integrated. These include wizards for resource creation, the logcat Viewer, the Hierarchy Viewer, and the Visual GUI Builder, among others.

The close integration makes developing easier, so I recommend ADT as the fastest way to get started with Android development. Throughout this section (and this book), I highlight many of the ways you can leverage the IDE to improve your experience writing

Android code.

Anatomy of the Eclipse Workspace

You will be spending a lot of your development time within Eclipse, so you’ll need to

familiarize yourself with how it is organized. Figure 5-1 shows the standard Eclipse

layout. Let’s look at a few key areas:

55

Figure 5-1. Standard Eclipse layout

Package Explorer

The window on the far left allows you to view all the code components included in your project. You can click on the small triangles ( ) to expand or minimize a particular tree, which will expand or minimize that section of the code appropriately.

Code Editor

Seen in the middle of the screen, this is the area where you make changes to your code. The source code is color-coded to highlight different elements of syntax. For instance, variable definitions are displayed in blue, and method modifiers are dis‐ played in purple.

Outline

The view on the far right displays the main sections of the code in a structured way.

You can click on the triangles to expand and minimize certain sections, just as in the Package Explorer view. Refer to

“Quick Outline for XML” on page 68 for an

alternate way to view this.

56 | Chapter 5: Developing with Eclipse

Problems

This tab appears at the bottom of the screen and displays any warnings or errors in your project. If there is an error in your code, it will be listed here (in red). You can click on any of the messages that appear here. This will open the code with the error and place the cursor at the location where the problem exists.

Uncovering Additional Tools and Views

The default layout for Eclipse likely won’t have all the components you need to use.

Several additional tools are available, as well as a few different ways to customize what

is displayed ( Figure 5-2

).

Figure 5-2. Adding views to Eclipse layout

Anatomy of the Eclipse Workspace | 57

You can display the additional Android tools by selecting Window → Show View →

Other → Android.

This displays a long list of tools under the Android section, as shown in

Figure 5-3 . To

add one of these to your Eclipse layout, select it from the list. Once it is placed in your screen, you can drag and drop the tab to move it wherever you would like.

Figure 5-3. Viewing the options available in the Android menu

The perspectives concept in Eclipse is a collection of tabs and tools organized in a pre‐ defined way. Android comes with a few preconfigured perspectives: DDMS, the Hier‐ archy Viewer, and the Pixel Perfect View. We will cover each of these in detail later in the book.

The steps to open a perspective (shown in Figure 5-4

) are:

1. Select Window → Open Perspective.

2. Select the perspective you would like to display.

58 | Chapter 5: Developing with Eclipse

Figure 5-4. Eclipse perspectives

Quick Button

There is a small button at the top of the menu bar ( ) that is easy to overlook. This button is a shortcut to run your project. It has the same functionality that is executed by invoking the Run as... menu (which you can access by right-clicking on your project).

This button is the simplest way to run your app, as it is just a single button click (as opposed to navigating a menu). It is important to note that this works only if you are editing a Java file. If you are editing an XML file, nothing happens when you click the button (not even an error dialog).

Code Templates

It can be difficult to understand the proper way to create Android classes. You need to know the proper naming standards, which methods are required, how to tie various resources together, and other patterns for creating proper classes.

Code Templates | 59

ADT now provides the “Code Templates and Wizards” tools to assist in creating these base resources so the developer doesn’t need to start from scratch. This ensures that the basic format of the classes is correct and that they match the standard style for Android.

The different templates make it easy to get started quickly and are available for a variety of different classes. You should use these to create your initial classes to ensure that you are starting with properly designed code.

Generating code this way has a few important benefits. The first is that the code is written to Android and Java coding standards, so you are starting with the best code possible.

The second is that generating this code automatically is generally faster than writing it from scratch, which can be tedious and error-prone. The last benefit is that the generated code works properly from the start, so you won’t need to spend time fixing errors and can start implementing your business-specific code sooner.

There are a variety of templates available, ranging from the template for creating a new project to templates for creating individual resource components.

To access a menu of code templates ( Figure 5-5 ), select File → New → Other → Android.

This displays many options for creating a variety of resources and code. You can create

a new Application Project, Icon Set (see “Working with Graphics” on page 182

for details on using this), or code snippets. This tool allows you to launch wizards that will guide you through creating these various components. After the wizard walks you through the process, the system generates all the required code, resources, and dependencies and puts them directly in your project.

As an example, I will show how you would use a code template to generate a master/ detail flow. This is a common UI pattern where there is a list of items on one side of the screen and a detail view of that item is displayed in a panel on the other side when it is selected.

1. First, select the desired option from the templates option screen.

60 | Chapter 5: Developing with Eclipse

Figure 5-5. Viewing Code Templates menu

2. Enter the details about your code in the wizard (

Figure 5-6 ).

Code Templates | 61

Figure 5-6. Using a code template to generate a Master/detail flow

3. Review and confirm the data you have entered. Accept your entries to complete the wizard (as shown in

Figure 5-7 ).

62 | Chapter 5: Developing with Eclipse

Figure 5-7. Confirming the generated code

4. The system then automatically generates the appropriate code. For the master/detail flow, quite a bit of code is created. All of the activities, fragments, layouts, and

resources that are shown in Figure 5-8

were created using this template.

Code Templates | 63

Figure 5-8. Viewing the code generated from the Master/detail

You should explore each of the code templates that are available. There are many dif‐ ferent possibilities including various activity types, Android-specific XML files, and unit testing assistance. Having the ability to create framework code that is written correctly and works is something I can’t recommend enough. It will eliminate time spent debug‐ ging and ensure that your code is written to standards.

64 | Chapter 5: Developing with Eclipse

You are not limited to using only the existing templates. There is a syntax that allows you to create your own templates. There is a good article by Roman Nurik titled ADT Template Format Documentation that outlines how to do this.

Properties Editors

ADT includes editors designed to create XML files without requiring direct editing of the file. You can use these editors to enter values into a form, which is easier than trying to enter the properly formatted XML tags manually.

A good example of this is the Manifest Editor. Every Android application has a manifest file (which must be named AndroidManifest.xml). This file contains information about the application that the Android system must have before it can execute the code. The manifest file contains information about application permissions, the components of the application (activities, services, etc.), API level, instrumentation classes used by profilers, and a variety of other important data. This file is critically important to An‐ droid development, and is modified frequently.

The Manifest Editor tool makes editing this file easy, and less error-prone. This tool is launched when you edit AndroidManifest.xml (which is located in your project root directory). The tools will look like

Figure 5-9 .

The manifest wizard groups common elements together. Each can be accessed by click‐ ing its tab on the bottom of this window. The tabs are organized as follows:

Manifest

Allows you to change general information about your app (like OS level, screen support, package name, version number, etc.)

Application

Describes application-level components, as well as general application attributes.

You will list the components you use (activities, services, etc.) here, and can specify a variety of parameters specific to the app execution: for instance, whether it is debuggable, or information relating to optional backup configurations.

Permissions

Lists the Android permissions your app requires. For instance, android.permis

sion.INTERNET

grants the app the ability to send or receive data over the Internet in your application.

Properties Editors | 65

Figure 5-9. Android Manifest Editor

Instrumentation

Allows a developer to designate a class that will be instantiated before any other component in the application. This class can be used to monitor an app’s interaction with the system, or set up test functionality.

AndroidManifest.xml

Allows you to edit the XML directly, if you prefer that.

66 | Chapter 5: Developing with Eclipse

XML Formatter

You probably know that the layout files in Android are designed using a hierarchy of

XML tags to describe the various views in your interface. These files can get complicated quickly, and often become disorganized and difficult to read. ADT provides a very useful key sequence that allows you to quickly format XML files. In addition to aligning the whitespace, the tools go a step further, and reorder the attributes within each tag.

On Windows or Linux, you will use the keys Ctrl+Shift+F and on Mac OS X, you will use Command+Shift+F.

By default, this will reorder the attributes to a default standard that the Android team has determined is best for a wide variety of developers. This default order should work for most people, but it is possible to specify your own order if you prefer. You can specify your own preferences in the following location: Window → Preferences → XML →

XML Files → Editor.

You can learn more about this in “XML formatting” on page 178 .

The Android Key

This keyboard combination is worth mentioning because it provides quick access to a few operations that are frequently used. Using this shortcut makes performing these tasks quicker, and speeds up the development workflow. You can access these shortcuts with the following keystrokes: on Windows and Linux, use Alt+Shift+A, and on Mac

OS X, use Option+Shift+A.

When you use this key combo, a small dialog opens at the bottom right of your IDE (as

seen in Figure 5-10 ) that contains three shortcuts allowing you to do the following

things:

Figure 5-10. Using the Android key to access shortcuts

XML Formatter | 67

Run Android Application

Launches your app to a running emulator (or starts one if necessary).

Debug Android Application

Launches your app in debug mode.

Extract Android String

Launches a dialog allowing you to extract a string out of any file and place it in the

strings.xml

file.

Quick Outline for XML

Use this key sequence to launch a UI (as shown in Figure 5-11

) that shows the structure of the current XML document or Java class you are editing inline with your editor. You can then quickly navigate to any location in the file. This is a giant time saver, and is my primary way of navigating within my files. On Windows and Linux, use Ctrl+O, and on Mac OS X, use Command+O.

Figures 5-11 and 5-12 show how the outline looks in XML and Java classes.

Figure 5-11. Viewing the Quick Outline in an XML file

68 | Chapter 5: Developing with Eclipse

Figure 5-12. Viewing the Quick Outline in a Java class

Other Essential Eclipse Shortcuts

It is worth mentioning a few other key shortcuts that make development easier, but aren’t Android-specific.

Ctrl/Command+Shift+R

Open any file quickly without browsing using the package manager or navigator.

Ctrl/Command+Q

Go to the last location you edited (particularly useful for going right back to the last place you were working).

Ctrl/Command+F6

Quickly navigate to any open editor.

There are a lot more than I have space to mention here. You can access the full list of shortcuts from the following menu: Help → Help Contents → Java Development User

Guide → Reference → Menus and Actions.

Other Essential Eclipse Shortcuts | 69

Refactor Menu

There is one more top-level menu with some useful options that I want to mention in this chapter. As the name implies, this allows you to do a variety of useful refactors to your project. These are great shortcuts to help rearrange or clean up your code. For example, one provides a way to extract strings and there are convenience utilities that allow you to modify your layout when you are editing a layout file. You should use these shortcuts to modify your layouts. This can be much less error-prone and quicker than editing the XML directly. You can access this feature from the menu by selecting

Refactor → Android → Extract Style.

“Extract Style” is an example of a useful feature available through this menu. This is a useful pattern in Android, which allows you to keep your style independent of your layouts. This convenient shortcut makes it simple to extract elements from your layout

into styles.xml ( Figure 5-13 ).

Figure 5-13. Using the tools to extract style information

ADT version 21.1 included some additional functionality that makes it easier to rename item IDs. Previously this was challenging, as the developer was responsible for manually changing the names in each file where it occurs. This makes it easier to rename a resource

XML file, drawable name, field name, or ID. If you are using the layout editor, renaming any of these resources will automatically launch a refactoring routine that updates all resource references.

70 | Chapter 5: Developing with Eclipse

CHAPTER 6

Developing with Android Studio

Donn Felker

Android Studio (shown in

Figure 6-1

) is the IDE for Android that was announced in

May 2013 at the Google I/O developers event, and is intended as an alternative to Eclipse.

At the time of this writing, Android Studio is currently in Early Access Preview, with the most recent version being 0.0.5. At this time, Android Studio is not ready for full end-to-end Android application development, but should be ready in the coming months. I highly advise you review this chapter, as this is where Android development is migrating to in the future. Android Studio is based on the Java IDE called IntelliJ. If you’ve worked with other products by JetBrains (developer of IntelliJ), such as RedMine,

PyCharm, PhpStorm, WebStorm, or AppCode, you will find yourself at home. All In‐ telliJ products share the same shell IDE, which you’ll see as soon as you open up Android

Studio. In this chapter, I intend to familiarize you with Android Studio and show how you can use it for Android development.

Although Android Studio is a brand new IDE, it is important to note that most of your

IDE skills from Eclipse apply to Android Studio as well. Most of the tooling in Android

Studio is very similar to Eclipse, such as shortcuts, designers, and code editors. You’ll still export signed APKs, view logcat, and edit code virtually the same way in Android

Studio as if you were in Eclipse. Think of Android Studio like this: if Eclipse were a trusty old power drill used in construction, Android Studio is the new cordless highpowered version of that same drill. Android Studio has some of the same options, and some new ones that you’ll need to familiarize yourself with. In the end, you’ll still feel comfortable enough to use the tool to get the desired result—an Android app.

Installing Android Studio

Google has made installing Android Studio as simple as possible. Just visit the Android

Studio page and download the installer for your platform. Supported platforms include

Windows, Mac OS X, and Linux. Follow the installation instructions for your platform

71

Figure 6-1. Android Studio with the Editor, Project, and Android panels

to install the application. Installation instructions are not provided in this chapter be‐ cause installation instructions change often. If you encounter issues, please visit the

Android Studio installation page .

Bundled SDK

Android Studio comes bundled with its own version of the Android SDK, which is preconfigured to be used with Android Studio upon installation. On Mac OS X, it is located in the package contents for the application, as I determined by choosing Android

Studio → Show Package Contents (see Figure 6-2 ) and checking the resulting screen (as

shown in

Figure 6-3

). This means that if you already have an SDK installed, Android

Studio will not use the previously installed SDK by default. If you would like to use the existing SDK on your machine, follow these steps from Stack Overflow .

72 | Chapter 6: Developing with Android Studio

Figure 6-2. Showing the package contents of the Android Studio application

Installing Android Studio | 73

Figure 6-3. The SDK folder in the Android Studio package contents

Default Project Location

After installing Android Studio, you can create a new project and define a destination location for the project files. If you don’t explicitly define a location for your project,

Android Studio will place your files into the ~/AndroidStudioProjects folder in the cur‐ rent user’s folder on your machine.

Anatomy of the Android Studio IDE

The Android Studio IDE is comprised of a vast array of panels, tools, and functions to help you become as productive as possible at developing Android applications. I’ll cover the most common panels, windows, and toolbars with which you’ll be interacting.

Panels

The main panels that you will interact with during your day-to-day development of

Android apps appear in

Table 6-1

.

Table 6-1. Important panels in Android Studio

Panel

Project Panel

File Editor

Description

Allows you to navigate through the file hierarchy of your project and select, open, edit, and perform various other actions on your files.

The main editing window in Android Studio. This is where you write your code.

74 | Chapter 6: Developing with Android Studio

Panel

Android Panel

Description

Presents the devices (emulators and physical devices) connected to your system, and allows you to view the logcat output, filter the output, and view ADB logs.

Messages Panel Here you’ll find any important messages that the IDE presents, such as compilation errors.

TODO Panel Shows all the TODO comments sprinkled throughout your project’s code.

Find Results Panel Here you can examine the results of any find command that you execute. Examples include the Find

Results command (Edit

→ Find → Find) and the Find Usages command (Edit → Find → Find Usages).

Maven Panel

Gradle Panel

If your project is Maven-based, interact with this panel to perform Maven activities.

If you’re utilizing the new Gradle build system, you can find the tools necessary to interact with Gradle here.

Event Log Panel At times, the Android Studio IDE may encounter an unexpected error or have important events that need to be visible to you, the developer. This panel will show you these events.

The final area, which is of utmost importance, is the status bar at the bottom of Android

Studio, shown in

Figure 6-4 . This is where the majority of status updates will occur when

background processes run. Some of these background processes include updating in‐ dices on the files, Maven or Gradle background processing, and event errors. The rightmost box shows the IDE’s memory usage.

Figure 6-4. The Android Studio status bar

Toolbars

Android Studio ships with a highly customizable toolbar that is easily accessible from the top of the display. The default toolbar that ships with Android Studio is shown in

Figure 6-5

.

Figure 6-5. The default toolbar in Android Studio

Table 6-2

describes each set of tools from left to right.

Table 6-2. Tools in the default toolbar

Tool

File Actions

Undo/Redo

Cut/Copy/Paste

Description

Actions such as Open, Save, and Synchronize.

Undo and redo the previous action.

Quickly cut, copy, and paste from the toolbar.

Anatomy of the Android Studio IDE | 75

Tool

Find/Replace

Navigation

Build/Run/Debug/

Attach

Settings

Android Actions

Help

Description

Find and replace values in the project files.

Navigate forward and backward in the most recent files that you’ve accessed or edited recently.

These buttons are some of the most common buttons that you will use in Android Studio, as they allow you to build, run, debug, and attach to a running Android process for debugging.

These access the IDE Preferences and Project Structure.

The Android Action Group allows you to sync your project with the Gradle files, open the AVD or

SDK Manager, and open the Android Monitor application.

Where you can go for help in using Android Studio.

Useful Actions in Android Studio

In addition to the various panels and toolbars, Android Studio has a wide feature set that is accessible via the top menu and various contextual menus.

Table 6-3

shows a few of the common actions that you’ll want to familiarize yourself with.

Table 6-3. Common actions

Action

New Module/

Library/Java

Library

Description

You can easily add a new Android Module, Android Library, or Java Library to your application by simply choosing the File

→ New Module or File → Import Module file option and following the wizard through the process.

Preferences At times, you may want to customize Android Studio. You can do this by accessing the Preferences through the Android Studio

→ Preferences menu. Some options you can edit are the theme of the IDE, font sizes, keymap, toolbars, and many other options.

Project Structure An Android project is comprised of modules and libraries, and at times you may need to edit the settings for these modules and libraries. To do so, you’ll need to enter the project structure by visiting the File

Project Structure menu.

Showing

Additional

Windows

Right-Click to

Explore

Although the default windows that ship with Android Studio are usually sufficient for day-to-day Android development, there may come a time when you need to get into the gritty details of the IDE. To explore the various other windows that are available to you (such as file structure, commander, VCS changes, etc.), visit the View

→ Tool Windows menu.

Anytime you’re unaware of the actions you can perform in the IDE, simply right-click the area in which you would like to see the various options. Android Studio will present you with the array of options (if available) that are possible in the given context of the IDE panel in which you’re working.

Navigation

Navigation shortcuts are used for navigating around your code base at the speed of light.

Master the shortcuts in Table 6-4

and you’ll increase your productivity immensely.

76 | Chapter 6: Developing with Android Studio

Table 6-4. Keystroke shortcuts in Android Studio

Action

Go to Class

Go to File

Shortcut on Mac OS X

Command + O

Command + Shift + O

Shortcut on Windows\Linux

Ctrl + O

Ctrl + Shift + O

Go to Definition

Back / Forward

Command + B

Command + [ or ]

Ctrl + B

Ctrl + [ or ]

Code Editor Tab Nav Command + Alt + Left or Right Ctrl + Alt + Left or Right

File Switcher

Find Usages

Find

Ctrl + Tab

Alt + F7

Command + F

Ctrl + Tab

Alt + F7

Ctrl + F

Replace

Find in Path

Replace in Path

Command + R

Command + Shift + F

Command + Shift + R

Ctrl + R

Ctrl + Shift + F

Ctrl + Shift + R

The New Structure of an Android Project

When you first open up Android Studio and create your first new project in the IDE, you’ll notice that Android Studio introduces a new paradigm in regards to folder and file placement that is not congruent with what you may be used to in Eclipse. Almost all of your files are located in the src directory. The new file structure is in place in order to support the new Gradle build system.

A Tour Around the New Structure

As noted, the new file structure puts the majority of your files in the src folder, as shown

in Figure 6-6

. The files in this folder are the source files for your project. These are the files you’ll be editing the majority of the time. This file structure provides more flexibility and will eventually provide the ability to provide multiple build variants (different types of builds with the same project). Everything in your project will still behave the same for the most part.

The New Structure of an Android Project | 77

Figure 6-6. An example of the Android folder structure in Android Studio

Build variants are not implemented at the time of this writing.

Running and Debugging an Android Project

When you’re ready to deploy your app to a device or an emulator to test and/or debug it (see

“Debugging” on page 98

), you can easily do so with Android Studio. The three various methods for this are Run, Debug, and “Attach Debugger to Android Process.”

All three of these commands are available via the Run menu or the main toolbar in

Android Studio, as shown in Figures

6-7

1

and 6-8 .

1. The “Attach Debugger to Android Process” item is at the very bottom of this long menu and has been removed from this screenshot for brevity.

78 | Chapter 6: Developing with Android Studio

Figure 6-7. The Run menu

Figure 6-8. The toolbar run actions

To run an Android app on the currently connected device, select Run from the Run menu or press the Run button in the toolbar. This command will build the Android application and deploy it to the currently attached device.

To debug an Android app on the currently connected device, select Debug from the

Run menu or click the debug icon in the toolbar. This command will build the Android app and deploy it to the currently attached device, and attach the debugger to it. At this point, if any breakpoints are set, Android Studio will stop execution so that you can inspect your runtime environment for debugging.

Another wildly useful tool is the “Attach Debugger to Android Process” command. This is mainly used when you need to start your app and navigate through a series of steps before attaching the debugger at a particular execution point (perhaps right before you click a button or before you navigate to a new screen). This tool allows you to quickly flow through your app and then set the breakpoint, instead of having the debugger running the entire time. To attach the debugger to your currently running app, install the app with the run command as outlined earlier and then select Run → Attach De‐ bugger to Android Process or press the “Attach Debugger to Android Process” icon in the toolbar.

Creating New Android Components

A very common task during Android development is to create new components for the app. You can quickly accomplish this in Android Studio by right-clicking on the package name and selecting New → Android Component, as shown in

Figure 6-9

, or by pressing

Command+N on Mac OS X, or Ctrl+N on Windows\Linux while your package name is highlighted in the src directory.

Creating New Android Components | 79

Figure 6-9. New Android component creation

Layout Designer and Layout Preview

Android Studio ships with two graphical tools to help you lay out your user interface:

Layout Designer

and Layout Preview. Layout Designer lets you arrange Views on the screen by dragging and dropping, while Layout Preview lets you see how your screen looks while you are editing your XML resources. I’ll provide a brief introduction to both tools in this section.

Layout Designer

When you first open an Android layout file, you’ll see the Android designer with the

Design tab selected, as shown in

Figure 6-10

. The other tab is Text, which allows you to hop into the XML that defines the layout. I will cover that in the next section.

Figure 6-10. The Android Layout Designer

80 | Chapter 6: Developing with Android Studio

Android Studio’s Layout Designer allows you to easily drag and drop controls onto the layout surface to quickly create a prototype of the layout that you need. Select one of the controls from the palette and drag it to the layout. Once the control is in place, you can edit the various properties of the control by selecting the control and editing the

properties on the right, as shown in Figure 6-10 . Layout Designer automatically creates

the underlying XML code that represents the layout you created. The component tree shows you how the layout is organized in a hierarchical fashion.

To view the XML of a particular control, simply select it in the designer and click

Command+B on Mac OS X, or Ctrl+B on Windows\Linux. You can also right-click and choose “Go To Definition.” This will open the Text tab of the layout designer and you are navigated to the XML snippet that defines that control.

In Layout Designer, you can select various devices to emulate, themes, API levels, and orientations. I highly advise you to peruse the various options in the designer, as it is a very powerful tool.

If you love graphical editors, the Layout Designer is great for whipping up a user inter‐ face quickly. However, some of us love to get as close to the metal as possible, and in order to do that you need to edit the XML. To edit the XML, click the Text tab at the bottom of the Layout Designer.

Layout Preview

As soon as you enter the XML layout, you will notice that the control palette, component tree, property editor, and drag-and-drop designer are gone and replaced with a slew of

XML code and a layout preview. This is shown in

Figure 6-11

. The preview shown here is the Layout Preview tool. You can turn this panel on and off by selecting the Preview button on the right side of the screen. This panel is shown only when the XML editor is in use.

The Layout Preview will update any time you make changes to the layout XML. As an example, if you change a TextView or Button to a bold font style, the Layout Preview will show the bolded text. If you like being closer to the XML, this is the view for you.

I often hop back and forth between the Layout Designer and Layout Preview tools during my day-to-day Android development.

Layout Designer and Layout Preview | 81

Figure 6-11. The Layout Preview with the XML layout editor

Generating an APK

Generating an APK in Android Studio is a snap. Follow these steps:

1. Select Generate Signed APK from the Build menu. This will display the Generate

Signed APK Wizard.

2. Select your module and click Next.

3. Either supply the path to your keystore that you’re currently using for your Android application, or create a new keystore.

4. (Optional) Once your keystore values are provided, click “Remember Password” and Android Studio will keep track of your entered password in a local password database so you don’t have to enter it again. You will be required to provide a master password for this password database, so be sure you remember this password. Tools like LastPass.com

are very useful for keeping track of numerous passwords safely.

The remember password feature is very useful if you create or maintain a lot of

Android applications.

5. Click Next.

6. At this point you can define the destination for your APK. You can also specify

whether you’d like to run ProGuard (described in “ProGuard” on page 139 ), and

where the ProGuard configuration file is located.

7. Click Finish and your APK will be generated in the destination folder.

82 | Chapter 6: Developing with Android Studio

Interacting with Maven and Gradle

Maven (see “Using the Maven Tools” on page 149 ) and Gradle (see

“Gradle-Based Build

Tools” on page 144 ) are build systems that are very popular within the Android commu‐

nity. Android Studio ships with support for Maven and Gradle right out of the box. This is great considering that in Eclipse you had to use a plug-in that was often buggy and not entirely reliable. Given that Android Studio ships with support for both tools, you can easily work with projects that use either technology via a panel in Android Studio.

Interacting with Maven

Projects that use Maven are easy to open in Android Studio. Simply start Android Studio and open the pom.xml file. Android Studio walks you through the Maven project import process. Once the import is complete, you can open pom.xml and edit it if needed for any reason, or you can open the Maven panel. The Maven panel is now populated with various options, as shown in

Figure 6-12

.

Figure 6-12. The Maven panel expanded

Once the Maven panel is expanded, you will be able to explore the lifecycle, various plug-ins, and dependencies. To refresh the Maven project, click the refresh icon in the top right of the panel. This loads all of the dependencies, plug-ins, etc., that are defined in the pom.xml file. To execute a lifecycle goal, simply select it and then press the play button in the top part of the panel. I recommend that you explore the panel and its options, because you can configure Maven and perform various other actions within it.

Interacting with Maven and Gradle | 83

You can build a Maven project in Android Studio in a couple of ways. One way is to execute and build the task you want through the Maven panel. You can also set up a

Maven build configuration (Run/Debug Configuration). Finally, you can build through the Build menu. I prefer to build through the Build menu because Android Studio caches the files and only builds off of changesets, so I’m not running through an entire Android

Maven build every time (which can be very time consuming).

Interacting with Gradle

As with Maven, projects that use the Gradle build system are very easy to work with in

Android Studio. There are a couple of panels that you should be familiar with. These panels include the Gradle panel and the Build Variants panel as shown in Figures

6-13 and 6-14

. Once your project is loaded, you can open the Gradle panel and interact with the various tasks. You can also open the build.gradle file in the editor and edit anything necessary.

Figure 6-13. The Gradle task panel

84 | Chapter 6: Developing with Android Studio

Figure 6-14. The Gradle Build Variants panel

Building your application is quite easy with Gradle. I recommend that you use the Build menu to build your application because it is the simplest way. If for any reason your application Gradle files become out of sync with your Android application, you can select the “Sync Project with Gradle Files” option from the toolbar, as shown in

Figure 6-15 . This will update your project with the settings defined in the Gradle file.

Figure 6-15. Sync Project with Gradle Files

Version Control Integration

Android Studio ships with numerous built-in Version Control System (VCS) integra‐ tions. These integrations allow you to perform VCS operations (commit, pull, push, update, etc.) within Android Studio:

Git

GitHub

Mercurial

Version Control Integration | 85

SVN (Subversion)

CVS

If you’re using something that is not listed here, plug-ins are available for various other

VCS systems such as Team Foundation Server, Perforce, and others.

To configure your VCS system, select “Enable Version Control Integration” from the

VCS menu and follow the steps. Once it is set up, you will be able to perform various

VCS commands for all the files in Android Studio.

Migrating from Eclipse

Although Android Studio is not ready for prime time yet, it will be shortly and I’m sure a lot of folks are going to be moving to Android Studio from Eclipse. When the time comes for you to make the move, you can easily export your project from Eclipse using the Gradle export tool, and import it into Android Studio. The Android team has written an easy-to-follow guide on how to migrate from Eclipse.

Android Studio Tips and Tricks

Android Studio is packed with great keyboard shortcuts that allow you to be much more productive than previous Android development environments (except for IntelliJ, which is what Android Studio is based on). In this section, I’m going to show you some of the most common keyboard shortcuts that you’ll use on a daily basis while developing

Android applications.

When in doubt about what you can do in a particular scenario, place your cursor in the area of interest and press Alt+Enter to see the various options, as shown in

Figure 6-16

.

Figure 6-16. Context-specific options

86 | Chapter 6: Developing with Android Studio

Errors can also be refactored and edited. To do so, place your cursor on the error in the

Android Studio file editor and press Alt+Enter (on all platforms) to view the available options.

Refactoring and Code Generation

Many of the important code refactoring options available in Eclipse (see “Refactor

Menu” on page 70

) are also available in Android Studio. I advise you to review the

“Refactor This …” option in Table 6-5 as well as the other options in the Refactor menu

in Android Studio. Learning common refactorings, such as generating getters and setters, will save you valuable time and ensure the code you generate is standardscompliant.

Table 6-5. Refactoring options

Action

Refactor This …

Rename

Shortcut on Mac OS X

Ctrl + T (after placing cursor on area of interest)

Shift + F6 (to rename files, resources, variables—anything)

Command + N in a file

Shortcut on Windows\Linux

Ctrl + T (after placing cursor on area of interest)

Shift + F6 (to rename files, resources, variables—anything)

Ctrl + N in a file Generate: Create Constructor,

New File, Layout, Getters/

Setters, Override Methods,

Copyright

Miscellaneous Shortcuts

Table 6-6

shows a few other miscellaneous shortcuts that I use day to day.

Table 6-6. Other useful shortcuts

Action Shortcut on Mac OS X

Go to Line Command + L

Reformat Code Alt + Command + L

Run/Debug Ctrl + R or D

Shortcut on Windows\Linux

Ctrl + L

Alt + Ctrl + L

Ctrl + R or D

Hiding Panels Make sure the panel is active, then press Shift + Esc Make sure the panel is active, then press Shift + Esc

Android Studio Tips and Tricks | 87

Android Studio is packed with a ton of great features. Having used IntelliJ for Android for the last two years, I can honestly say I’m twice as fast at developing Android appli‐ cations and I’ve become a better developer because of it. I believe that Android Studio will be an extension of that same strength and I hope you feel the same way about it after you use it for a while.

Additional training resources are available on my website, Donn Felker—Android

Studio Training . I will update these tutorials as Android Studio evolves, so I encourage you to check it out if you would like to learn more.

88 | Chapter 6: Developing with Android Studio

CHAPTER 7

Testing Your Code

Logcat

The Android platform provides a logging mechanism called logcat for collecting and viewing system information. Logs from the system and various apps are output to a series of buffers, which can then be filtered with the logcat command. If you have ex‐ perience working with Log4J or the java.util.logging package, this will seem very fa‐ miliar. You can review output from many different systems in a single location and filter it to view information relevant to your application. It is worth getting a good under‐ standing of all the options, as this tool will make your life much easier.

Android logs pretty much everything in the system to a common log file. Information about garbage collection, various system activities, and app output are all sent to the same file. This provides a central location to gather a broad range of information in a single place. It is also important to note that this single file is shared by all apps installed on the device. Therefore, you should be careful not to output sensitive information to the logs. You can use the Proguard utility to obfuscate your code and hide certain details.

It can also be used to remove log statements when packaging your app for release (details about using this tool can be found in

“ProGuard” on page 139 .

Viewing the Logcat File

To view the entire log file (without any filters), issue the command: adb logcat

This outputs a very verbose log, which includes information about all processes on the system.

Anatomy of a Log Message

Each log message includes a variety of metadata that can be used to filter the output.

89

Log level

Indicates the severity of the message being reported from the app’s point of view.

Log tag

Defines a process or ID associated with a message.

Log message

The content being reported.

Reading logcat output

Each line in the logcat contains a variety of important information. I want to highlight what they mean, so you can understand where to find relevant information in the statement.

Here are a few lines from a logcat file:

E/PowerManagerService ( 170 ) : Excessive delay setting brightness: 101ms, mask = 2

V/PhoneStatusBar ( 308 ) : setLightsOn ( true )

I/ActivityManager ( 170 ) : No longer want com.android.contacts ( pid 598 ) : hidden

I/ActivityManager ( 170 ) : Displayed com.tools.demo/.LogcatDemoActivity: +955ms

D/UI ( 897 ) : The user has pressed the button

D/UI ( 897 ) : The user entered a value: value from the call is: 24324

Let’s look at one statement to get an understanding of exactly what information it con‐ tains. The first statement we will look at is one generated from the system (remember both system and custom messages are output to the same file). This statement comes from the Android component that manages activity interaction with the core OS, and records how long the Activity Manager took to render the LogcatDemoActivity:

I/ActivityManager ( 170 ) : Displayed com.tools.demo/.LogcatDemoActivity: +955ms

I

This statement can be broken down to understand the exact information it contains:

This is the severity level (see

“Filtering Based on Logging Level” on page 91

). This log statement was marked to be output when the Info level is being output.

ActivityManager

This is the tag (see “Using Tags to Filter Output” on page 92

) used when creating the log message. It tells us which system (in this case, Activity Manager) was responsible for generating this message.

(170)

This is the “Process ID” of the application that originated this message. This is a unique identifier assigned to an application during runtime, and can be a great way to filter messages.

Displayed com.tools.demo/.LogcatDemoActivity: +955ms

This is the custom content entered in the log statement. In this case, the message tells us that an activity was started, and how many milliseconds it took to be created.

90 | Chapter 7: Testing Your Code

To be clear, all this content was entered as custom text by the application that gen‐ erated original log statement.

We can look at another statement; this time, it is output as a result of a statement I placed in my code. You can see the output from a custom statement looks exactly like a system message and contains the same information.

D/UI ( 897 ) : The user entered a value: value from the call is: 24324

The information in a custom statement is exactly the same as the system messages:

D

Using the Debug severity level for this message.

UI

A tag I created to keep track of user interaction events.

( 897)

The ID assigned to my application by the OS.

The user entered a value: value from the call is: 24324

Tracks that the user entered 24324 into a form field.

There is a lot of information in the logcat, which can be difficult to manage. Next I will discuss some strategies for generating and filtering logs that will make this easier.

Filtering Based on Logging Level

It is possible to filter logging output based on the severity of a message. Log messages are displayed based on their debug priority. You can specify a minimum level, and the output will be filtered to include only messages with that level or higher.

It is important to know the different log levels. You want to ensure that the level you are

viewing is appropriate for the type of message you are looking for. Refer to Table 7-1

for a breakdown of the log levels.

Table 7-1. Logging levels shown by priority

E

F

S

I

W

Identifier (ID) Name

V

D

Priority

Verbose (show everything) 1 (lowest)

Debug 2

Info

Warning

Error

Fatal

Silent (Show Nothing)

3

4

5

6

7

Logcat | 91

To view all of the messages with a certain level (and everything with a higher priority), enter: adb logcat *:Identifier

( ID )

As an example, if you wanted to see everything with a priority of Error or higher, enter: adb logcat *:E

It is a good idea to use the D level for most of your log statements. As the Android Log API states: “Debug logs are compiled in but strip‐ ped at runtime.” This means that any logs you create with the D level will not be output in your production app. Therefore, it is safest to use this level for most of your log statements, in order to make sure that sensitive data doesn’t accidentally get output into the field.

Using Tags to Filter Output

It is possible to apply filter expressions from logcat so you see only the messages that are most interesting to you. The filter expressions have the format tag:level. You can apply more than one filter at a time to isolate the specific information you need.

The procedure for finding messages of interest to you, therefore, is to create custom tags in your Java code and filter using these tags. The syntax for this follows:

Log.level ( "

CustomTag

", "

Log message

" )

An example of this in use is:

Log.D

( "UI" , "User entered a value: " + myEditText.getText

()) ;

You can then view only the specific messages you’re interested in by typing: adb logcat UI:D *:S

Getting the Most Out of Logcat

As you have seen, there are many ways to filter the logcat output, making it easy to ensure you are seeing the messages you need to see. You can apply as many different filter expressions to your logcat command as you need to fine-tune what is being displayed.

To apply multiple filter expressions, simply append them to your logcat command in the following format: adb logcat TAG1:level

TAG2:level

TAG3:level

92 | Chapter 7: Testing Your Code

For instance, if you want to see all statistics from the Activity Manager, use the Activi tyManager:* tag. To see only messages with a severity level of Error or higher from the

Power Manager component, use the PowerManagerService:E tag. To see messages about the custom User Interface tag, use: UI:*. Don’t forget to silence the other messages with the tag *:s (this means silence everything else). The combination of filters in this paragraph would look like this: adb logcat ActivityManager:* PowerManagerService:E UI:D *:s

Viewing Alternative Log Buffers

The logging system keeps multiple buffers for log messages. For certain content (such as the radio or events), output will be left in an alternative buffer instead of the default one. To see the additional log messages, start logcat with the -b option and specify the alternate buffer you wish to view. For example, to view the radio buffer, enter: adb logcat -b radio

Predefined Output Formats

Log messages include a variety of metadata fields, such as level, time, process ID, ap‐ plication, tag, and the error text. There are a variety of predefined output formats that can be specified in order to include the specific metadata field you want to see in the display. You can do this by including the -v option and one of these predefined output formats.

brief

Displays the tag and the PID of process raw

Displays just the raw log message without other metadata time

Displays date, time information, tag, and the PID long

Displays all of the metadata fields and puts blank lines between messages.

For example, to generate output data in the time format, enter: adb logcat -v time

Logcat Viewer in Eclipse

In the standard Java perspective in Eclipse, you will notice a logcat tab ( ) in the col‐ lection of tabs on the bottom of the screen (see

Figure 7-1

). This tool allows you to navigate the logcat of the currently connected device using some additional UI assistance.

Logcat | 93

There can be a lot of noise in the system log files. To make things easier, you can create an exclusion filter to exclude common system infor‐ mation that you don’t want to see. To create a filter:

1. Select the plus icon ( ) icon to create a new filter.

2. Specify a “Filter Name.”

3. Enter your filter value in the “by Log Tag” section: ^(?!exclude‐

term1|excludeterm2|excludeterm3).*$

.

4. I use the following filter as a good starting point: ^(?!dalvikvm|

ActivityManager|SystemServer|BackupManagerService).*$

.

Figure 7-1. The Logcat tool

Logcat Example

Logcat is a very powerful Android feature, but it can be hard to find what you need in it sometimes due to the amount of information that is output to the common log. Let’s step through a simple example to demonstrate how to filter verbose system logs to find the information you want and get a better understanding of your code output.

For this example, I created code that takes an input value from the user in US dollars and sends this value to a web service, which returns the value in Euros. Finally, the value is converted to a custom formatted style and displayed on the user interface.

Determining areas to monitor

It is important to think about the specific characteristics of the code you are logging.

You want to separate your logic into distinct areas (which will be represented with custom tags). This will make it easy to concentrate on specific areas because you will be able to isolate log statements based on functionality. In this case, there are a few

94 | Chapter 7: Testing Your Code

particular functional areas, which should be tracked independently. The areas I want to monitor include:

User Interface

Check the values entered by the user, check the values actually displayed on the screen, monitor when the user presses a button, etc.

Network

Validate the URL I’m sending, monitor connectivity errors, display request/ response values, etc.

JSON Parsing

Output JSON values at various points during the parsing, etc.

Formatting

Check the algorithm I use to format the values for my application.

AsyncTasks

Track a call through the lifecycle of this code.

Creating log statements

After determining the categories I want to log, I create custom tags to represent each of them, in this case:

• UI

• NETWORK

• JSON

• FORMAT

• ASYNC

I create a utility class with constants (e.g., public static final

String TAG_UI = "my_tag_ui"; ) to represent common categories I use. Then I use this tag in my code (e.g., Log.d(LogUtil.TAG_UI, "UI

Log message"); ). That way, I can easily look at a particular subsys‐ tem even across multiple activities, by filtering for that particular tag.

Then I put log statements in my code and use the custom tags as appropriate. The following code snippet shows how I used custom tags to track Web, JSON, and format‐ ting functionality:

public static

String ConvWebCall ( String amount ) {

// To save space, I removed code not important to the example

try

{

Logcat | 95

HttpClient client =

new

DefaultHttpClient ();

HttpGet request =

new

HttpGet ();

...

sb .

append ( amount );

Log .

d ( "NETWORK" , "The URL we are sending is: " + sb .

toString ()); request .

setURI (

new

URI ( sb .

toString ()));

HttpResponse response = client .

execute ( request );

Log .

d ( "NETWORK" , "Response received" );

...

Log .

d ( "NETWORK" , "The return String is: " + retStr .

toString ());

String page = retStr .

toString ();

}

catch

( URISyntaxException e ) {

Log .

e ( "NETWORK" , "URISyntaxException" , e ); e .

printStackTrace ();

...

}

Log .

d ( "NETWORK" , "Return value is: " + page );

return

page ;

}

public static

String parseConvedValue ( String page ) {

String curr = "" ;

try

{

JSONObject jso =

new

JSONObject ( page );

Log .

d ( "JSON" , "JSON Value: " + jso ); curr = jso .

optString ( "v" );

}

catch

( JSONException e ) {

Log .

e ( "JSON" , "Parsing exception: " , e );

}

Log .

d ( "JSON" , "JSON Value: currency element is " + curr );

return

curr ;

}

private

String formatEuroForDisplay ( String amount , String name ) {

String euro = "Euro 00.00" ;

Log .

d ( "FORMAT" , "Before formatEuroForDisplay: " + amount );

if

( amount !=

null

) {

int

index = amount .

indexOf ( "." );

String euros = amount .

substring ( 0 , index + 3 );

Log .

d ( "FORMAT" , "Euros back from NETWORK: " + amount ); euro = "Euro " + euros ;

}

Log .

d ( "FORMAT" , "After formatEuroForDisplay: " + euro );

String euroString = euro ;

return

euroString ;

}

96 | Chapter 7: Testing Your Code

Verbose logging

You can run the logcat tool without any filters (using the command adb logcat) to view the unfiltered output. As the following printout shows, this output can contain a lot of information and be difficult to understand. The following output is what you would see from a single execution of our currency conversion workflow. You can look at the tags to see how the process progresses: first the UI messages, then the FORMAT ones, then the NETWORK ones, and so on.

I/ActivityManager ( 170 ) : START { cmp = com.tools.demo/.LogcatDemoActivity u = 0 } from pid 897

W/WindowManager ( 170 ) : Failure taking screenshot

for

( 328x583 ) to layer 21010

D/dalvikvm ( 170 ) : WAIT_FOR_CONCURRENT_GC blocked 0ms

D/dalvikvm ( 170 ) : GC_EXPLICIT freed 114K, 39% free 13611K/22023K, paused 10ms

+9ms, total 267ms

I/Choreographer ( 897 ) : Skipped 35 frames! The application may be doing too much work on its main thread.

E/PowerManagerService ( 170 ) : Excessive delay setting brightness: 101ms, mask = 2

V/PhoneStatusBar ( 308 ) : setLightsOn ( true )

I/ActivityManager ( 170 ) : No longer want com.android.contacts ( pid 598 ) : hidden

I/ActivityManager ( 170 ) : Displayed com.tools.demo/.LogcatDemoActivity: +955ms

D/UI ( 897 ) : The user has pressed the button

D/UI ( 897 ) : The user entered a value: value from the call is: 24324

D/FORMAT ( 897 ) : formatForWebcall () before: 24324

D/FORMAT ( 897 ) : formatForWebcall () after: 243.24

D/ASYNC ( 897 ) : onPreExecute ()

D/NETWORK ( 897 ) : URL to send: http://rate-exchange.appspot.com/currency?

from = USD&to = EUR&q = 243.24

D/dalvikvm ( 897 ) : GC_CONCURRENT freed 121K, 2% free 11063K/11271K, paused 17ms

+32ms, total 78ms

D/NETWORK ( 897 ) : Response received

D/NETWORK ( 897 ) : The

return

String is: { "to" : "EUR" , "rate" : 0.756258035,

"from" : "USD" , "v" : 183.9522044334

}

D/ASYNC ( 897 ) : doInBackground () : { "to" : "EUR" , "rate" : 0.756258035, "from" :

"USD" , "v" : 183.9522044334

}

D/JSON ( 897 ) : Json Object is:

{ "to" : "EUR" , "v" :183.9522044334, "from" : "USD" , "rate" :0.756258035

}

D/JSON ( 897 ) : Json parsed currency value: 183.9522044334

D/ASYNC ( 897 ) : onPostExecute () : result is: 183.9522044334

D/FORMAT ( 897 ) : Before formatEuroForDisplay: 183.9522044334

D/FORMAT ( 897 ) : Euros back from call: 183.9522044334

D/FORMAT ( 897 ) : After formatEuroForDisplay: Euro 183.95

D/UI ( 897 ) : Setting value on screen to: Euro 183.95

I/ActivityManager ( 170 ) : START { act = android.intent.action.MAIN cat =[ android.intent.category.HOME

] flg = 0x10200000 cmp = com.android.launcher/com.android.launcher2.Launcher u = 0 } from pid 170

W/WindowManager ( 170 ) : Failure taking screenshot

for

( 328x583 ) to layer 21015

W/IInputConnectionWrapper ( 897 ) : showStatusIcon on inactive InputConnection

I/Choreographer ( 489 ) : Skipped 42 frames! The application may be doing too much work on its main thread.

Logcat | 97

Filtering the logcat

I use the unfiltered view to get an overview of my entire process, but I often need to get a more granular view. To do this, I use the custom tags I created to view the specific categories I want to see. Because only the information I care about is displayed, it is much easier to understand the specific operations I am interested in.

For instance, if I wanted to see only information related to user interactions, I could filter based on the UI tag. In this case, I have an * next to the UI tag (specifying I want to see all messages), and an *:s to specify that I want to silence all other messages:

$

adb logcat UI:* *:s

D/UI ( 897 ) : The user has pressed the button

D/UI ( 897 ) : The user entered a value: value from the call is: 24324

D/UI ( 897 ) : Setting value on screen to: Euro 183.95

Another example of something I need to track is the logic related to making the web call and parsing the response. For this, I use a combination of NETWORK and JSON categories to see the logic:

$ adb logcat JSON:* NETWORK:* *:s

D/NETWORK ( 897): URL to send: http://rate-exchange.appspot.com/currency?

from=USD&to=EUR&q=243.24-->

D/NETWORK ( 897): Response received

D/NETWORK ( 897): The return String is: {"to": "EUR", "rate": 0.756258035,

"from": "USD", "v": 183.9522044334}

D/JSON ( 897): Json Object is:

{"to":"EUR","v":183.9522044334,"from":"USD","rate":0.756258035}

D/JSON ( 897): Json parsed currency value: 183.9522044334

Debugging

Debugging is an important step in the development process, and can often take longer than actually writing the code. Debugging Android apps can be particularly difficult due to the various subsystems integrated into the OS. The ADT tools provide an inte‐ grated debug environment that makes this process easier.

A common method for debugging code is to create “breakpoints” that are triggered when code takes a certain execution path. The program execution pauses at that point, allowing you to inspect the state of the system (including current variable values and application status). You can use this information to analyze how code operates and locate errors.

98 | Chapter 7: Testing Your Code

Setting Your App to Debuggable

In order to debug an app, it is necessary to specify that your app is debuggable in the application manifest. If you are deploying your app using the ADT tools (from Eclipse or another IDE), this is done for you automatically. If you aren’t building your project using those tools, you need to set this value manually. To specify that your app is de‐ buggable, add the android:debuggable="true" attribute to the application element in your AndroidManifest.xml file. It should look similar to this:

<application

android:icon= "@drawable/ic_launcher" android:label= "@string/app_name" android:debuggable= "true"

>

If you set the debug flag manually, don’t forget to remove it before releasing the app to production. You don’t want this enabled in pro‐ duction, as it will negatively impact your performance. If you forget to

remove it, there is a Lint checker (see “Lint” on page 107 ) that warns you

that this is set when you are doing a release build.

Setting a Debug Point

The starting place in debugging is usually to set a breakpoint in the source code of your app. In Eclipse, this is done by clicking in the “alley” next to a code path and selecting

“Toggle Breakpoint.” You can also set the breakpoint by pressing Ctrl+Shift+B on

Windows or Linux, or Command+Shift+B on a Mac. Either way, this triggers your IDE to show the “Debug perspective” when that particular code path is reached during ex‐ ecution. For example, in

Figure 7-2

, we set a breakpoint in the onCreate() method of the LogcatDemoActivity. The small caret next to line 12 shows the location of the breakpoint. During the execution of this code, when this code path is executed (in this example, when the intializeView() method is reached), the Debug perspective will automatically be launched, and the code execution will pause at this statement.

Debugging | 99

Figure 7-2. Setting a debug breakpoint

The Eclipse Debug Perspective

After you have successfully configured your environment and set a breakpoint, the

Debug perspective will automatically be launched. It can also be launched manually by selecting Window → Open Perspective → Debug. The Debug perspective will look sim‐ ilar to

Figure 7-3

. Some sections on the screen are worth highlighting:

Debug

Shows the Android app that is being debugged and its currently running threads.

Variables

Shows the values of variables during code execution at the particular breakpoint.

Breakpoints

Contains a list of all breakpoints currently set in your app. In this view, you are able to control them, including enabling or disabling them.

100 | Chapter 7: Testing Your Code

Logcat

Displays the system log messages.

Code and outline tabs

Displays the currently executing source code, and an outline view.

Figure 7-3. The Debug perspective

Debugging Example

Let me take you through an example to show you exactly how to debug a specific element of code. I created a very simple bit of code (see

Figure 7-4

) demonstrating how to use the debugger to inspect a value at different points in the execution cycle. The function‐ ality of the code is simple. It takes a value input by the user, stores the value to an internal variable, and displays it back to the screen after a button has been pressed. Running the app will look similar to

Figure 7-5 .

Debugging | 101

Figure 7-4. Debug example source code

Setting the debug points

The first step in debugging the app is to determine the appropriate points in the code to create debug points. For this example, I would like to know the value of the VALUE variable at two execution points. The first is before the user has entered anything, which in this case is Line 28. I would also like to check the value after it has been set, so I’ll set another debug point at Line 30. Remember, to set a breakpoint, just right-click on the

line number and select “Toggle Breakpoint.” Notice (in Figure 7-4

) the little blue indi‐ cators next to each line number: these show that the debug points have been set.

102 | Chapter 7: Testing Your Code

Figure 7-5. Running the debug example

Starting the debugger

After setting the debug points, I start the debugger by right-clicking on my project and

selecting Debug As → Android Application (see Figure 7-6

).

Figure 7-6. Starting debugging with the right-click menu

Debugging | 103

This is basically the normal routine I use to run my app. I must select a device from the

Android Device Chooser, and will navigate through my app to the point where I want to start debugging. At this point, I am presented with a dialog (see

Figure 7-7

) asking if it is OK to launch the Debug perspective. I click yes (and also select the checkbox on the bottom to authorize this for next time). This launches the Debug perspective.

Figure 7-7. Debug confirmation dialog

Stepping through the code

At this point, the Debug perspective is displayed, and the debugger has paused execution at my first breakpoint (see

Figure 7-8

). Notice the first debug point (Line 28) is high‐ lighted. I can now use the other tools to learn more about my code at this point. In particular, I will use the Variables tab (on the top right) to determine the current state of my VALUE variable. At this point, it is null because I have not entered the value as a user.

To proceed to the next debug point, I need to tell the debugger to proceed. To do this,

I use the debug toolbar ( ) to Resume (see

Figure 7-9

) and move to the next debug point.

If you hover your mouse pointer over these buttons, their functional‐ ity will be displayed and you can discover advanced options for step‐ ping through your code.

104 | Chapter 7: Testing Your Code

Figure 7-8. First debug point

Figure 7-9. Debug toolbar

After I press the Resume button, the debugger executes the code and stops at the next

debug point (in this case, Line 30). The view has changed (see Figure 7-10

), because the code has executed to the next debug point. Execution stops at this point, and I can inspect my code again to determine how the values of my components have changed.

Looking at the Variables tab now, I see that the contents of the VALUE variable have changed, and it now has the value New Text Entered.

Debugging | 105

Figure 7-10. Second debug point

I can inspect other values at this point as well. If I click the “tv” component in the

Variables tag (representing the TextView from our code), I can get a variety of infor‐ mation about this component (see

Figure 7-11 ). I can get information about Android

attributes (such as padding, animations, or formatting) or state information (such as the text content currently displayed). It is very useful to explore the various values at different execution points in order to understand detailed properties of your components.

106 | Chapter 7: Testing Your Code

Figure 7-11. Inspect other values

Lint

Lint is a static analysis tool introduced in ADT 16 that scans your source code and identifies potential bugs. You can run it from the command line, use it directly with the

Java or XML editors, and use it with your build tools. It is intended to identify potential issues based on established rules and patterns. Lint highlights these problems, and in many cases provides suggestions for remediation or quick fixes. It is a powerful tool and an easy way to improve the code quality with minimal effort.

Lint checks for a variety of different issues. Examples include:

• Accessibility and internationalization, such as missing translations

• User interface optimization, such as highlighting unused views

• Security, such as highlighting that you are not using HTTPS

• Code errors, such as inconsistent array sizes across classes

• Resource problems, such as missing densities for certain icons

You can get a list of every issue currently enabled by issuing the lint --list command.

This outputs a list of the categories currently in use and a complete list of every issue with a short description of its purpose. It looks like this:

Lint | 107

$

lint --list

Valid issue categories:

Correctness

Correctness:Messages

Security

Performance

Usability:Typography

Usability:Icons

Usability

Accessibility

Internationalization

Valid issue id ' s:

"ContentDescription" : Ensures that image widgets provide a contentDescription

"LabelFor" : Ensures that text fields are marked with a labelFor attribute

"FloatMath" : Suggests replacing android.util.FloatMath calls with

java.lang.Math

"FieldGetter" : Suggests replacing uses of getters with direct field access

within a class

...

Command-Line Usage

The simplest way to get started with Lint is to run it on your project, and then examine all the errors it reports back to you. This gives you a good overview of the kind of errors

Lint finds.

To run the tool, just execute the lint command, specifying the directory where you have the source code of an Android project. If you specify a directory that contains multiple projects, Lint will recursively check every project in the path.

Here’s an excerpt from a sample Lint report I ran on a project of mine. You can get an idea of some of the items identified:

$

lint ./ToolsDemo

Scanning ToolsDemo: ................................

Scanning ToolsDemo ( Phase 2 ) : .................

res/layout/gooduidemo.xml:15: Warning: Should use "sp" instead of "dp"

for

text sizes [ SpUsage ]

android:textSize = "20dp" />

~~~~~~~~~~~~~~~~~~~~~~~ res/layout/baduidemo.xml:167: Warning: [ I18N ] Hardcoded string "Text will go here" , should use @string resource [ HardcodedText ]

android:hint = "Text will go here"

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ res/layout/baduidemo.xml:120: Warning: Duplicate id @+id/imageView2, already defined earlier in this layout [ DuplicateIds ]

android:id = "@+id/imageView2"

~~~~~~~~~~~~~~~~~~~~~~~~~~~~

108 | Chapter 7: Testing Your Code

res/layout/imagesdemo.xml:23: Warning: [ Accessibility ]

Missing contentDescription attribute on image [ ContentDescription ]

>ImageView

^ res/layout/baduidemo.xml:89: Warning: This tag and its children can be replaced by one >TextView/< and a compound drawable [ UseCompoundDrawables ]

>LinearLayout

^

...

0 errors, 80 warnings

$

The example I’ve included is only an excerpt, and doesn’t show every error Lint found on my project. You can see in the last line that Lint found 0 errors—but 80 warnings, and this project is pretty small. You should run Lint on your own project often, as you are likely to see a variety of things that will improve the quality of your code.

Excluding issues

You likely will want to omit certain errors from being checked (perhaps you don’t sup‐ port internationalization, so do not need to be warned about those issues). You can do this from the command line by including the --disable list argument. The list is a comma-separated list of issue IDs or categories you wish to exclude.

For example, I might want to eliminate any errors relating to the Internationalization category (perhaps my app uses English only), as well as the specific ContentDescription error (if I’m not worried if my images don’t appear). When I run the same report as before, but with the --disable argument in my command, Lint produces fewer items:

26 warnings, which is much fewer than the 80 reported before. This practice allows you to narrow down the list of issues so you can concentrate on the particular ones that are most important to you.

$

lint ./ToolsDemo --disable Internationalization,ContentDescription

Scanning ToolsDemo: ................................

Scanning ToolsDemo ( Phase 2 ) : .................

res/layout/gooduidemo.xml:15: Warning: Should use "sp" instead of "dp"

for

text sizes [ SpUsage ]

android:textSize = "20dp" />

~~~~~~~~~~~~~~~~~~~~~~~

...

0 errors, 26 warnings

$

It is important to mention that the --disable command is permanent, and not per session. The issues will not be reported on your entire project, even when you test from within Eclipse, or start a new terminal session. If you intend to disable the options temporarily, make sure to enable them when you are finished. Simply issue the same command as before, but use the --enable option instead. This will rerun the Lint check and re-enable these issues for future tests. The output will look like:

Lint | 109

$

lint ./ToolsDemo --enable Internationalization,ContentDescription

Scanning ToolsDemo: ................................

Scanning ToolsDemo ( Phase 2 ) : .................

res/layout/gooduidemo.xml:15: Warning: Should use "sp" instead of "dp"

for

text sizes [ SpUsage ]

android:textSize = "20dp" />

~~~~~~~~~~~~~~~~~~~~~~~ res/layout/baduidemo.xml:167: Warning: [ I18N ] Hardcoded string "Text will go here" , should use @string resource [ HardcodedText ]

android:hint = "Text will go here"

~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

...

0 errors, 80 warnings

$

Running in Eclipse

Inside Eclipse, it is very easy to start Lint. Just right-click on your project folder, then choose Android Tools → Run Lint: Check for Common Errors.

After launching Lint, you will notice a new tab named Lint Warnings (see Figure 7-12 ).

This is the Lint UI you will use to track and fix the errors. It contains a tree of errors, organized by issue type. This makes it easy to concentrate on a specific category. The toolbar has a variety of actions for manipulating the list and options for customizing the display.

Figure 7-12. Lint Warnings tab

110 | Chapter 7: Testing Your Code

Lint toolbar menu

When you highlight an error, the toolbar (

Figure 7-13 ) on the top of the tab becomes

enabled. This is the Lint Warnings toolbar, which provides a central place to disable issues.

Figure 7-13. Lint Warnings toolbar

The buttons, from left to right, offer the following tasks:

Refresh

Reruns the Lint tests and displays new results.

Fix

Launches the XML or Java editor and modifies the source code to fix the issue.

Suppresses the selected error with an annotation/attribute

Suppresses the warning for the selected single instance, by placing the appropriate notation in the source file.

Ignore in this file

All instances of the selected issue will be suppressed for the entire file.

Ignore in this project

All instances of the selected issue will be suppressed for the entire project.

Always ignore

You will not see the selected error reported from any project or file.

Remove

Deletes the selected issue from this view, but does not disable the issue, so it will reappear the next time you run Lint.

Remove all

Deletes all issues from this view, but they will reappear the next time you run Lint.

Expand all

Expands every node in the issue tree so you can see every independent issue reported.

Collapse all

Collapses the issue tree so the items are grouped into categories.

Lint | 111

Options

Launches a dialog (see Figure 7-14

) that contains a few important options. This dialog provides another way to enable or disable issues and examine the issues that are enabled. This is also where you set your preferences for how and when Lint runs.

Figure 7-14. Lint options

Java and XML editor integration

By default, Lint runs automatically, so you have likely already seen the errors it flags.

Depending on the option you specified, you will see the errors flagged when you are typing or when you save your file. When Lint encounters an error, it places a marker at the line of code with the problem. To learn more about the issue, hover your mouse over the warning icon, or the line of code (underlined in yellow) to learn more. Figures

7-15

and 7-16 show how this looks in both the XML and Java editors.

112 | Chapter 7: Testing Your Code

Figure 7-15. Lint warnings in XML file

Figure 7-16. Lint warnings in Java file

Quick Fix tool

It is likely that you will want to do more than just learn about the errors in your code— you probably want to fix the problems! There is a “Quick Fix” tool that makes fixing errors very easy.

The best way to invoke this feature is to select the code with the error, and press Ctrl+1 on Windows or Linux, or Command+1 on Mac OS X.

After you launch the “Quick Fix” dialog, you will be prompted with a variety of options for handling the particular warning. These are the same options provided by the Lint toolbar (see

“Lint toolbar menu” on page 111

). The options will look like Figures

7-17

and 7-18 in Java, respectively.

It is possible that this functionality won’t work for every issue you have. In cases where the system is unable to provide a “Quick Fix,” you need to debug the code yourself and determine the way to fix your problem.

Lint | 113

Figure 7-17. Lint Quick Fix in XML

Figure 7-18. Lint Quick Fix in Java

114 | Chapter 7: Testing Your Code

CHAPTER 8

Simulating Events

There are a variety of occurrences you will want to test that are difficult to replicate as they would happen in real life. In these cases, tools are available that will allow you to simulate events so you can test effectively.

Simulating Location and Routes

For instance, testing location can be challenging. It is impractical or impossible to travel to remote locations or simulate the exact same track over and over again. Fortunately, the DDMS tool provides a way to specify a location you would like your emulator to simulate (as latitude/longitude coordinates), or a path you would like to simulate (in the form of GPX or KML).

To simulate location, you need to open the DDMS tool (see

“Launching the DDMS

Perspective” on page 152 ). To launch the Eclipse perspective, select:Window → Open

Perspective... → Other... → DDMS → OK.

Next, open the Emulator Control tab (which looks like

Figure 8-1 ). In this tab, you can

see a section marked Location Controls, where you can enter location attributes. When you are done entering your personalized data, hit the Send, Load GPX, or Load KML button (depending on which type of data you are working with). This causes your em‐ ulator to simulate the location you specified.

115

Figure 8-1. Simulating location with the emulator

The following steps demonstrate how to simulate a particular location on your device.

The same process can be used to simulate a path using KML or GPX.

1. Launch the DDMS perspective in Eclipse.

2. Locate a device or emulator you want to work with, and highlight it in the Devices tab.

3. Select the Emulator Control tab in the right-side pane (as shown in Figure 8-2

).

4. In the Telephony Actions section, scroll to the bottom section labeled Location

Controls. In this section, select the Manual tab, and enter a valid latitude and lon‐ gitude in the form. The default value (which is the default value that is set) is

Mountain View, California.

116 | Chapter 8: Simulating Events

Figure 8-2. Setting up a location simulation

5. You might need to enable Location Settings on your device if it hasn’t been done

already (see Figure 8-3

). You will be prompted the first time you try to access your location if you need to do it.

6. Press the Send button to simulate this location of your device. Your device now reflects this location.

Simulating Location and Routes | 117

Figure 8-3. Viewing a location simulation

Simulating Telephony Operations

The Emulator Control tab has another section called Telephony Actions (see

Figure 8-4

), which can simulate telephone events and radio connectivity functionality.

This is a useful way to interact with the emulator if you need to simulate phone calls or

SMS messaging. It is also useful to adjust radio settings in order to learn your app’s effectiveness in situations where connectivity is less than optimal. The top of the tab has a section titled Telephony Status. If you would like to simulate connectivity issues

(such as latency or packet loss), you can adjust these settings. The other section, named

Telephony Actions, is where you simulate phone calls or messages. To simulate either of these actions, enter a value for the return phone number, select the operation you want to perform (either phone call or SMS), enter your SMS message content (if ap‐ propriate), and click the Send button.

118 | Chapter 8: Simulating Events

Figure 8-4. Emulator telephony simulation

The following steps demonstrate how to generate an SMS message. This is the same process used to simulate phone calls.

1. Launch the DDMS perspective in Eclipse.

2. Locate a device or emulator you want to work with, and highlight it in the Devices tab.

3. Select the Emulator Control tab in the right-side pane ( Figure 8-5 ).

Simulating Telephony Operations | 119

Figure 8-5. Setting up SMS simulation

4. (Optional) Adjust the Speed and Latency settings if you want to test how your app will perform with poor connectivity.

5. In the Telephony Actions section, enter a phone number (without dashes) and your example message text.

6. Press the Send button to send your simulated message, which will show up on your device or emulator. Your device shows an SMS has come into the system (as shown

in Figure 8-6 ).

120 | Chapter 8: Simulating Events

Figure 8-6. Viewing SMS simulation

Changing Networking Parameters

You likely will want to change the networking parameters of your device. This can be useful when you want to forward requests from your computer to your emulator or device (perhaps you want to test a configuration of the local network on the Android system).

It is pretty easy to do this using ADB. The syntax will look like this example: adb forward tcp:9222 tcp:9333

Then, the next time you ping localhost:9333 from your local desktop, your command will be forwarded directly to your Android device.

Changing Networking Parameters | 121

Using a Device with Sensor Emulation

It is difficult to simulate certain activities using the emulator, such as when simulating multi-touch or interacting with motion-based sensors such as the gyroscope. To work around this challenge, ADT provides the capability to connect a physical device to your emulator and use the sensors on that device to interact with your emulator. The app running on the emulator monitors changes in the device sensors, which are transmitted to the emulator and injected into the system image. This allows you to generate various sensor events using your physical device, and transmit them to your running emulator.

In order to use this feature, you need the system image for Android version 4.0, release

2 or greater running in your emulator.

The steps to enable sensor emulation are:

1. Edit the AVD you will be using. Add the hardware property “Multi-touch screen support,” and set it to true.

Chapter 3

describes how to do this.

2. Install the SdkControllerSensor application on the device. You can find the source code for this application in the $SDK/tools/apps/SdkController folder.

3. Enable “USB debugging” on your device, and connect it to your computer.

4. Run the SdkControllerSensor application on the device.

5. Select the particular sensors you wish to emulate using the application.

6. Enable port forwarding by running adb forward tcp:1968 tcp:2068 from the device’s shell command line.

7. Start the emulator that you plan to test with.

Port forwarding can be unreliable. If you are not seeing sensor events in the emulator, run the adb forward tcp:1968 tcp:2068 command again to restore the connection.

Advanced Sensor Testing

If you are writing an app that makes extensive use of sensors, you will likely face many challenges when testing them. Testing different scenarios can be difficult, even impos‐ sible in many situations. It can be impractical to test extreme situations. For instance, if you need to test extreme temperatures, you can’t put your phone in the oven or freezer.

It is also difficult to test the exact precision of other sensors (try holding your phone still for a long period when testing the gyroscope for instance). SensorSimulator , an open source project managed by OpenIntents.org, makes sensor testing much more practical.

SensorSimulator is a series of applications, including a desktop component and multiple

APKs. You can use the desktop component to send real-time sensor events to your

122 | Chapter 8: Simulating Events

device. Having the precise control and ability to reliably trigger sensor interactions is extremely valuable when writing apps that make use of sensors. This tool also provides the ability to record a series of sensor events that can be played back on a device. You can create a scenario (using the desktop app, or by recording events on your device), then save it to play back. This is an extremely valuable regression tool, as it allows you to trigger consistent sensor actions over and over.

Supported Sensors

The SensorSimulator project currently supports a variety of sensors including acceler‐ ometer, compass, orientation, temperature, light, proximity, pressure, gravity, linear acceleration, rotation vector, and gyroscope sensors. You can control how each of the sensors are being simulated using the Sensors tab (the right side of

Figure 8-7 shows

this). Sensors can be enabled or disabled in this window (they will be highlighted in blue when enabled). Only enable the sensors you are testing so you only see the particular data in which you’re interested. If you want to modify the values of some of these sensors, you can do that in the Quick Settings and Sensors Parameters tabs.

Figure 8-7. Optional sensors

Simulating Sensor Events in Real Time

You will download, install, and run this tool the same as any other native application

(the simple instructions are on the project website). Run a desktop Java application (bin/

SensorSimulator.jar

) on your computer, install, and run an APK on your device (bin/

SensorSimulatorSettings-x.x.x.apk

), and then connect the two processes together using

Advanced Sensor Testing | 123

your WiFi connection. Once connected, use the desktop application to send sensor

events and view them on your device. Figure 8-8 shows an example of what it would

look like to use the accelerometer sensor to simulate moving the phone. You move the mouse in the desktop to “move” the phone, and can see these interactions on your device.

Figure 8-8. SensorSimulator accelerometer example

Recording Sensor Scenarios

In addition to simulating events, you can also use this tool to record a series of sensor events to play back on a device or emulator—called a scenario. This is extremely valuable, as it enables repeating the exact same sensor events over and over. This makes regression testing easier. For example, you could record the exact interactions required to pass a level of your gyroscope controlled game—then play it back against a build to validate it for production.

The easiest way to create scenarios is to use the Java app to generate them. The righthand

section of Figure 8-9 has a Scenario Simulator tab. To create a scenario, create a sensor

event representing a particular sensor state. You can then create more events, and string them together to play out a scenario (using the controls on the bottom of the tab).

124 | Chapter 8: Simulating Events

Figure 8-9

shows how this would look if you were trying to simulate rotating the phone.

You can use the simulator to set up your sensors, or modify the values directly by typing preferred values in the middle tab. After you create a scenario you like, save it, and load it later to play it back on any device.

Figure 8-9. SensorSimulator recording scenarios

It is worth mentioning that you can record sensor interactions on a physical device. For complex scenarios, this is a simple way to record a series of UI actions that you can play back in the simulator later. Install and run an app on your device (SensorRecordFrom

Device.apk

, available in the bin directory) that allows you to record sensor activities.

You can then play back the recorded scenario using the desktop application in the same manner as if it were created using the tool itself. This makes mapping a complex UI interaction pretty simple because you can simply record your interactions and reliably play them back over and over. For complex scenarios, this might be a more efficient way to record a series of events than creating them using the Java tool.

Advanced Sensor Testing | 125

Developer Options Menu

The Android 4.0 release included a revamped Developer tool that introduced some very interesting features. The tool can be accessed by opening the Settings app on your phone, then selecting “Developer Options” (if you are on a version 4.1 or newer device, see Tip to enable this option). The app (see

Figure 8-10 ) includes a variety of advanced options

that can help you understand your UI and app performance on a deeper level. These options include:

Strict mode enabled

This flashes the screen when an app is doing a long operation on the UI thread.

This is useful to help identify UI freezes and discover times when the UI is unre‐ sponsive. Mobile users perceive very small delays, so you need to minimize these whenever possible. This option makes pinpointing these long-running processes easier so they can be moved to the background and off the UI thread (where they won’t cause your app to freeze).

Pointer location

Figure 8-11

shows how you can highlight a specific location on the screen. You can place your finger or mouse at any place on the screen to determine the exact location of that touch point. This is useful when you need to identify items that are hard to touch, determine optimal spacing between targets, or otherwise fine-tune touch interactivity. You can gather exact locations on your UI based on pixel measure‐ ments, which can be useful if you are trying to map your UI components to a very exact location on the screen (which can be critical in certain types of applications including games or other graphic-intensive apps).

Show screen updates

This feature flashes independent areas of the screen to highlight when different components of the screen are repainted. This is useful when trying to improve performance. You can identify large screen redraws and try to reduce them by selectively refreshing certain views instead of the entire screen.

Don’t keep activities

Enabling this option forces the Android system to destroy activities as soon as the user leaves them (under the normal activity lifecycle, they probably would be moved to the background, but kept alive). This can be useful when trying to debug an issue that is isolated to a single activity. Normally, if you want to test an activity that is initialized to a new state, you would be required to quit your application completely

(using the system menu). Using this option allows you to destroy your current activity, ensuring that when you start it again it is initialized from a clean state.

126 | Chapter 8: Simulating Events

Figure 8-10. Viewing the Developer options

Force GPU rendering

This makes the system use hardware acceleration to render graphics. Enabling this option will offload graphics rendering to the GPU, which frees up the CPU for other operations. In many cases, this will improve your application performance, but in some cases this may cause issues. I suggest you enable this feature, and if your app performs as expected leave it enabled. If you are testing an app that makes extensive use of graphics, enabling this option should give you a better idea of how your app will perform on a modern device (that has a GPU).

Developer Options Menu | 127

Figure 8-11. Highlighting a specific location with the display pointer

128 | Chapter 8: Simulating Events

CHAPTER 9

Build Tools

When building apps, at some point it will be necessary to compile your code, and pack‐ age it into a deployable artifact. This chapter outlines the tools used to do this.

The automated build tools can also package Android applications. There is support for a variety of tools, including Ant, Maven, and most recently Gradle . It is beyond the scope of this book to go into a lot of detail about using these tools, but let’s go through some basic concepts to get you started.

Compiling Your Code

When writing computer applications, it is necessary to translate the computer language you are using (in our case Java) to a different computer language that the computer can understand (in this case, Dalvik Compatible executables, or DEX files). This process is called compiling. You will need to do this during the coding process in order to validate your code, and also when you are packaging your code for release.

If you are running the most current version of Java (or anything newer than version

1.6), it is necessary to set the compliance level of your project in order to get Android to build correctly. To do this:

1. Right-click on your Android project.

2. Select Properties → Java Compiler.

3. Check the “Enable project specific settings” option.

4. Choose either 1.5 or 1.6 from “Compiler compliance settings.”

The code will then be compiled if you are using Eclipse and have the “Build Automat‐ ically” setting selected. To select it, make sure Project → Build Automatically is checked.

129

Packaging an APK for Release

In order to release your app to the Android market you need to create an Android application package file (APK). This is a specially formatted ZIP file that contains the various components of your app (including compiled code, static resources, library code, and the manifest file). To create an APK, source code is compiled into DEX files, which are packaged together with the other components, and then signed. The output of this process will be a file with the .apk extension. This file can then be deployed to your test devices, or uploaded to the Google Play Store for distribution.

Signing Your App

The Android system requires you to digitally sign all apps with a certificate before deploying them to the Google Play Store. Android uses the certificate to verify the identity of the developer, which is used to establish trust relationships between apps and the framework.

There are some important things to know about these certificates:

• You must sign your app to install it on an emulator or device.

• When you are developing your app, the build tools will sign your app with a debug key. This key cannot be used to sign an app for release to end users.

• Self-signed certificates are allowed. They do not need to be signed by a signing authority such as Verisign.

• It is important to ensure that your key is valid for the entire expected lifespan of your application. The Android docs specify that you should use 25 years for the validity term (it must expire after October 22, 2033 if you plan to deploy to the Play

Store).

It is extremely important to keep track of the key you are using to sign your app if you plan to deploy to the Play Store. You will need to use the same key for all updates to your app. If you are not able to sign your app with the same key, they will never allow you to update it.

130 | Chapter 9: Build Tools

You can take care of these tasks through either a wizard or the command line. I’ll show the wizard first because it’s easier.

An Export wizard in the tools can walk you through the process of creating a signed

APK for deployment. It automates a variety of steps and is easy to use. Launch the wizard by right-clicking on your project and choosing Android Tools → Export Signed Appli‐ cation Package. You are presented with a series of screens that walk you through the process of creating a Java keystore, and building an APK for deployment.

1. Project checks. The wizard performs a variety of checks to ensure the project is valid and able to be exported. If the checks pass, the user is presented with the initial

screen (see Figure 9-1

).

Figure 9-1. Launching the Build wizard

Packaging an APK for Release | 131

2. Keystore selection. This screen allows you to select a valid keystore to be used to sign the app. If a valid keystore doesn’t already exist, you can choose the Create New

Keystore selection to generate a new one (

Figure 9-2 ).

Figure 9-2. Selecting a keystore and entering credentials

3. Keystore creation. If you want to create a new keystore for signing your app, enter

all the required information into this form ( Figure 9-3 ). The wizard then generates

the key for you. This is easier than using the Java keytool to generate the key.

132 | Chapter 9: Build Tools

Figure 9-3. Confirming keystore information

4. Keystore check. The next step in the process is to validate the keystore to ensure it is valid for the amount of time necessary. If the keystore is valid, the APK is gen‐ erated and placed in the location you specify (

Figure 9-4 ).

At this point, you have successfully generated a signed APK that can be deployed to the

Play Store or Android devices.

Instead of using the wizard, you can sign an APK using the standard Java tools, then use the command line to sign the app. To do this, first compile your project and generate an APK file (yourApp.apk in the example). Then enter the following command: jarsigner -keystore your-key.keystore yourApp.apk alias_name

Building from the Command Line Using Ant

Ant is a standard Java build tool that Android uses to build projects under the covers.

Although the ADT team is replacing Ant with Gradle (discussed later in this chapter),

Ant is still the most full-featured build tool for Android. It includes a variety of scripts that can easily be modified to suit your individual needs. This build tool is very robust, and can be extended to do many useful things (such as running automated tests or static analysis tools). You can learn more about it at the Apache Ant home page .

Building from the Command Line Using Ant | 133

Figure 9-4. Defining destination location for APK

Ant comes preinstalled with ADT, and will automatically be available if you have cor‐ rectly set your PATH (review

“Setting your PATH variable” on page 5 ). There are two

main types of builds you can do.

Debug mode

Used for testing and debugging your app.

Release mode

Used when creating a package for release.

Building an Android app (regardless of the type of build you are doing) involves the following steps:

1. Compiling the Java code into DEX bytecode.

2. Building the Android project into a deployable APK file.

3. Signing the APK, so it can be deployed to an emulator or device—remember, all apps must be signed before they can be deployed to a device.

If you are building from Eclipse, these steps are automatically performed by the tool. If you are using Ant to build from the command line, some of these steps need to be done manually.

134 | Chapter 9: Build Tools

Setting Up Your Project

In order to build, you need to create a build.xml file that provides Ant with the infor‐ mation it needs to build the project. This file is where we will set up information about signing our app, running Lint, or mapping project dependencies.

Creating the Ant build.xml file

Anyone who has experience with Ant knows that these build files aren’t always the easiest to work with. Build files become large and disorganized quickly.

Fortunately, ADT provides a tool that creates build.xml automatically. To execute this command, open a command prompt at the base directory of your project, and execute the Android update command. Its syntax is: android update project --name project_name --target target_api_id

--path path_to_project

Although you can omit some of the command-line options and leave as-is the command settings in the existing project files, it is often useful to override these settings in order to specify support for certain platforms, or to specify path values. For example: android update project --name YourProject --target 17 --path /Users/yourUserId/ workspace/YourProject

If you don’t want to specify custom values, and are working from the base directory of your project, you can simply enter: android update project -path .

Building applications from multiple source libraries

It is very common to use open source libraries and other external sources of code when writing Android apps. In some cases, you can simply compile that library into a JAR file and include it directly in your project. In other cases, the library should be compiled as part of your build process. This is easy to accomplish using the Android tools if you follow some simple steps.

1. Define your project dependencies and target API. You should have a file in your project home directory named project.properties. This file contains the listing of each of the libraries you have as dependencies. A sample file follows.

# This file is automatically generated by Android Tools.

# Do not modify this file -- YOUR CHANGES WILL BE ERASED!

#

# This file must be checked in Version Control Systems.

#

# To customize properties used by the Ant build system edit

# "ant.properties", and override values to adapt the script to your

# project structure.

#

# To enable ProGuard to shrink and obfuscate your code, uncomment this

Building from the Command Line Using Ant | 135

(available properties: sdk.dir, user.home):

# proguard.config=${sdk.dir}/tools/proguard/proguard-android.txt:

proguard-project.txt

# Project target.

target = android-17 android.library.reference.1

= ../shared/libs/android/ActionBarSherlock-4.2.0/ library android.library.reference.2

= ../CustomLibrary/YourLibraryName

You will notice that the header mentions that this file is automatically generated. If you have used the Eclipse tools to create your project, this file should already have everything you need, but you may want to validate the dependencies or their order.

2. Run the android update project command, discussed in the previous section, in each folder you are including as a dependency.

3. Issue the ant command to start the build: ant debug

This compiles each of the specified libraries, before compiling the application code or carrying out other build operations.

Building in Debug Mode

This method creates an APK for deployment, signed by the debug key. This app cannot be deployed to the Play Store, or other places. This mode can be used for quick debugging or testing when it is not necessary to create a real signing certificate.

The steps to building with this method are:

1. Open a command prompt, and navigate to the base directory of your project.

2. Issue the ant command to start the build: ant debug

3. This creates an .apk file with the name of your project inside the bin directory of your project home. The file will be signed with a debug key that is automatically generated during the build process. This means that the key is different with each build, so it will restrict you from installing over old instances of your app (because the signing certificate will not always be the same).

Building an App to Release to the Play Store

The Release mode creates an APK that can be released to the Play Store and installed on other Android devices. This mode allows you to specify the keystore to use when signing your app. This is very similar to building in Debug mode, except that you use a real keystore during the signing process.

136 | Chapter 9: Build Tools

Signing an app with a custom keystore

In order to sign with a custom certificate, you need to specify the following information so the build system knows which parameters to use during the build.

1. Copy your keystore file to a location on your build machine and note the location.

If you have not already created a custom certificate for signing, review “Signing

Your App” on page 130

for instructions on how to create a valid certificate.

2. Create a new file in your project home directory named build.properties.

3. Insert the key.store and key.alias variables into this file to tell the build system about your custom keystore location and keystore alias. The contents of this file should look like: key.store

= /path_to_location_of/my.keystore key.alias

=

my_key_alias

4. After creating this file and setting these values, issue the ant release command to start the process.

5. At the appropriate point in the build process, you will be prompted to enter your keystore and alias passwords. Enter the information to complete the build.

This creates an application file inside your bin directory. It will be signed properly and named project_name-release.apk. Because it is signed using a real certificate, you will be able to release this APK for public consumption.

Storing the password information

It is likely that you will want to store your password information so that your build can run automatically without requiring human intervention. In order to do this, you need to store your keystore and keystore alias password information.

You might be tempted to include this information in the build.properties file we already created. While this works technically, it’s a bad idea. It is generally not suggested that you check secure information into source control. In fact, many corporate security pol‐ icies prohibit doing so. You generally want to control access to these sensitive files by storing them locally on the build system, and ensuring read permissions are secured on the file.

1. Create a new file named secure.properties. This will be used to store the password information, and thus should be stored someplace secure where the information is not available publicly. The name and location of this file are completely up to you.

Keep track of this information because we will use it in the following steps.

2. Insert two variables into this file to tell the build system about your keystore and alias passwords. You will use the key.store and key.alias variables for this. The contents of this file should look like:

Building from the Command Line Using Ant | 137

key.store.password

= keystore_password key.alias.password

=

keystore_alias_password

3. Now you need to create yet another file to tie this all together, and inform the build system where it can get the password information. The new file is named

custom_rules.xml

and will be discovered automatically during the build. It should look like:

<?xml version="1.0" encoding="UTF-8"?>

<project

name= "custom_rules" default= "help"

/>

<property

file= "/path_to_secure_location/secure.properties"

/>

</project>

4. At this point, you can issue the ant release command again. This time however, instead of stopping to wait for the password information to be entered, the build finishes without interruption.

5. This application file inside the bin subdirectory of our project home directory will be signed with your custom key, and named project_name-release.apk. It is signed, and thus can be released to the public.

Additional Ant Commands

There are a variety of things you can do with Ant. The documentation does a great job of explaining them. I highlight some of the more useful options here, but I suggest checking the documentation to learn more about the advanced options available. Many of these tags can be combined to perform multiple operations in a single build.

ant emma debug

Builds a test project with instrumentation turned on. This is designed to generate code coverage information during a run.

ant installd

Installs an already compiled debug package to a running device or emulator.

ant test

Runs the tests in your project. This works only if the test .apk files are already installed.

ant emma debug install test

This is an example of running multiple operations in a single operation. The com‐ mand shown will build a test project, install .apk files, and run the tests with code coverage enabled.

138 | Chapter 9: Build Tools

Advanced Packaging Steps

At some point, it will be necessary to do some additional things to prepare your artifact to be released to the public. These things include obfuscating your code, minimizing the size of the artifact, and signing the app with a correct certificate. The steps to ac‐ complish these tasks are outlined in the following sections.

ProGuard

ProGuard is a free Java tool that shrinks, optimizes, and obfuscates your code in prep‐ aration for deployment. It does this by removing unused code, replacing class or method names with semantically distinct ones, and optimizing bytecode. This makes your ap‐ plication smaller, more efficient, and harder to reverse engineer. The process protects against reuse of your code and protects your confidential data.

Enabling Proguard

It is very easy to run this tool, and mostly automatic, especially if you package your APK

using the Export Signed Application Package wizard shown in “Signing Your App” on page 130

. If your build target is higher than 2.3, this tool is automatically run as part of the packaging process. A default configuration file is placed in the root directory of your project, and looks similar to the following example. It is placed at the root level of your project home and named proguard-project.txt.

# To enable ProGuard in your project, edit project.properties

# to define the proguard.config property as described in that file.

# # Add project specific ProGuard rules here.

# By default, the flags in this file are appended to flags specified

# in ${sdk.dir}/tools/proguard/proguard-android.txt

# You can edit the include path and order by changing the ProGuard

# include property in project.properties.

#

# For more details, see

# http://developer.android.com/guide/developing/tools/proguard.html

# Add any project specific keep options here:

# If your project uses WebView with JS, uncomment the following

# and specify the fully qualified class name to the JavaScript interface

# class:

# -keepclassmembers class fqcn.of.javascript.interface.for.webview {

# public *;

# }

You can enter specific configurations and rules for your project in this file. To enable

ProGuard to run automatically as part of a build, modify the file to remove the # comment symbol before the following statement: proguard.config

=

${

sdk .dir

}

/tools/proguard/proguard-android.txt: proguard-project.txt

Advanced Packaging Steps | 139

Your file should then look like:

# This file is automatically generated by Android Tools.

# Do not modify this file -- YOUR CHANGES WILL BE ERASED!

#

# This file must be checked in Version Control Systems.

#

# To customize properties used by the Ant build system edit

# "ant.properties", and override values to adapt the script to your

# project structure.

#

# To enable ProGuard to shrink and obfuscate your code, uncomment this

( available properties: sdk.dir, user.home

) : proguard.config

=

${

sdk .dir

} \t

ools

\p

roguard

\p

roguard-android.txt: proguard-project.txt

# Project target.

target = android-10

Next time you do a release build, Proguard will automatically be run, and your code will be obfuscated. This means all your error reports (including reports you receive through the Play Store) will be modified to a format that is hard to read.

Configuring ProGuard

Default ProGuard rules are defined in a file that is external to your project (${an

droid.home}/tools/proguard/proguard-android.txt

). These standard rules are defined by the Android tools team, and should work for most cases. The standard rules include basic configurations designed to accommodate most users. You may need to override these defaults. You should not do this by modifying this file directly, as it will get updated with the rest of the tools and your changes will not persist. Instead, if you need to define custom rules, define them in the proguard-project.txt file mentioned in the previous section, as they will be persisted and won’t be overwritten.

There are many different possible rule combinations. The following listing includes a good starting point. It provides a “safe” configuration that should not break your code execution, but will still allow you to get the other benefits of ProGuard (including pack‐ aging optimization and code obfuscation).

#Does a 5 step optimization

-optimizationpasses 5

#Support for systems - such as Windows that don't care about capitalization

-dontusemixedcaseclassnames

#Don't ignore non-public library classes. Is default on newer ADT builds

-dontskipnonpubliclibraryclasses

# The Dex tool does its own optimizations, so we shouldn't do them with Proguard

-dontoptimize

-dontpreverify

140 | Chapter 9: Build Tools

-dontwarn android.support.**

#Verbose option - will print stacktrace if build fails

-verbose

#To repackage classes on a single package

#-repackageclasses ''

#Keep annotations (if this is uncommented)

#-keepattributes *Annotation*

#Keep classes with references from the AndroidManifest

-keep public class * extends android.app.Activity

-keep public class * extends android.app.Application

-keep public class * extends android.app.Service

-keep public class * extends android.content.BroadcastReceiver

-keep public class * extends android.content.ContentProvider

-keep public class * extends android.app.backup.BackupAgentHelper

-keep public class * extends android.preference.Preference

-keep public class com.google.vending.licensing.ILicensingService

-keep public class com.android.vending.licensing.ILicensingService

#Keep classes from the Support library

-keep public class * extends android.support.v4.app.Fragment

-keep public class * extends android.app.Fragment

#To maintain custom components names that are used on layouts XML.

#Uncomment if having any problem with the approach below

#-keep public class custom.components.package.and.name.**

# In Views, keep getters and setters so that animations still work.

-keepclassmembers public class * extends android.view.View {

void set * ( *** ) ;

*** get* () ;

}

#To not obfuscate names of methods invoked in a layout's onClick method.

# Uncomment and add specific method names if using onClick on layouts

#-keepclassmembers class * {

# public void onClickButton(android.view.View);

#}

#Remove debug, verbose, and warning error messages from Logcat

-assumenosideeffects class android.util.Log {

public static *** d ( ...

) ;

public static *** v ( ...

) ;

public static *** w ( ...

) ;

}

#Keep native Java methods

-keepclasseswithmembernames class * {

native <methods>;

Advanced Packaging Steps | 141

}

#Keep custom components names layouts

-keep public class * extends android.view.View {

public <init> ( android.content.Context

) ;

}

-keep public class * extends android.view.View {

public <init> ( android.content.Context, android.util.AttributeSet

) ;

}

-keep public class * extends android.view.View {

public <init> ( android.content.Context, android.util.AttributeSet, int ) ;

}

#Keep enums

-keepclassmembers enum * {

public static ** [] values () ;

public static ** valueOf ( java.lang.String

) ;

}

#Keep parcelable classes (when used to serialize objects sent through Intents)

-keep class * implements android.os.Parcelable {

public static final android.os.Parcelable

$Creator *;

}

#Keep the R

-keepclassmembers class **.R

$* {

public static <fields>;

}

#Uncomment if using Serializable

#-keepclassmembers class * implements java.io.Serializable {

# private static final java.io.ObjectStreamField[] serialPersistentFields;

# private void writeObject(java.io.ObjectOutputStream);

# private void readObject(java.io.ObjectInputStream);

# java.lang.Object writeReplace();

# java.lang.Object readResolve();

#}

Viewing obfuscated code

The ProGuard technique of renaming variables makes it very difficult to read and debug your code. This is great when you are trying to keep other people from viewing your code, but presents challenges if you need to read the code yourself (from a stacktrace or logs). ProGuard provides a tool named retrace that allows you to switch the non‐ sensical names back the real ones.

After ProGuard runs, you will notice some new files in the proguard subdirectory of your project home directory. These files manage the obfuscation process and the con‐ sequent restoration of meaningful names. The files contain:

142 | Chapter 9: Build Tools

dump.txt

Includes information relating to the internal structure of the class files in your project.

mapping.txt

Maps the original names to the obfuscated names. This file will be used to decode obfuscated messages back into readable format (as described in the following section).

seeds.txt

Contains a list of all the classes and members that were not obfuscated.

usage.txt

Contains a list of all classes that were stripped from the APK.

In particular, you can use the mapping.txt file to de-obfuscate a stacktrace and read the output. To decode a stacktrace, run the retrace script with two arguments: the name of the mapping file, and the name of the text file containing the stacktrace. On Windows, for example, enter:

{ $android .sdk

} /tools/proguard/retrace.bat mapping.txt obfuscated_stacktrace.txt

On a Mac or Linux, the command is slightly different:

{ $android .sdk

} /tools/proguard/retrace.sh mapping.txt obfuscated_stacktrace.txt

As an example, the following error comes from the logcat file of an APK that has been built using Proguard.

E/AndroidRuntime ( 1655 ) : FATAL EXCEPTION: main

E/AndroidRuntime ( 1655 ) : java.lang.NullPointerException

E/AndroidRuntime ( 1655 ) : at com.tools.demo.f.onClick

( Unknown Source )

E/AndroidRuntime ( 1655 ) : at android.view.View.performClick

( View.java:4084 )

E/AndroidRuntime ( 1655 ) : at android.view.View

$PerformClick .run

( View.java:

16966 )

...

Notice on the third line that the location in the code that encountered the null pointer is not shown. It has been obfuscated to look like com.tools.demo.f.onClick(Unknown

Source) . We are not able to see the name of the file or the line number where the error is being reported.

Use the mapping.txt file to restore the correct information through a command like:

{ $android .sdk

} /tools/proguard/bin/retrace.sh

{ $project .root

} /proguard/mapping.txt proguarded_log.txt

After running this command, you will be able to read the output and determine exactly where your error is. The output from this command looks like:

E/AndroidRuntime ( 1584 ) : FATAL EXCEPTION: main

E/AndroidRuntime ( 1584 ) : java.lang.NullPointerException

Advanced Packaging Steps | 143

E/AndroidRuntime ( 1584 ) : at com.tools.demo.ToolsDemoActivity

$1 .onClick

( ToolsDemoActivity.java:36 )

E/AndroidRuntime ( 1584 ) : at android.view.View.performClick

( View.java:4084 )

E/AndroidRuntime ( 1584 ) : at android.view.View

$PerformClick .run

( View.java:

16966 )

...

Zipalign

Zipalign is a tool that optimizes APK archives by aligning all uncompressed data within the archive relative to the start of a file. This allows the app to consume less RAM when running. The tool should be run on all APKs before releasing them to the end user. If you are using the Export wizard to package your code, Zipalign will be run automatically.

It is also possible to run it on the command line. It should only be run after the .apk file has been signed with your private key. Otherwise, the signing will mess up the alignment.

zipalign inFile.apk alignedFile.apk

Gradle-Based Build Tools

Official support has recently been added in ADT for Gradle, a build tool that many developers are using to replace such classic utilities as Ant (the original build tool used in ADT) and Maven (which was never officially supported by the Android team). The

ADT team chose Gradle as the foundation of a new tool set because it embodied many principles to meet their goals of supporting the reuse of code and resources, creating multiple specialized variants of applications, and ensuring that the build system is ex‐ tensible. The Gradle project works hard to create high-quality documentation . Docu‐ mentation about its integration with ADT can be found at the ADT project site .

The Ant build system will be deprecated in Android, and the Tools team has stated that

Gradle is their build tool of choice moving forward. It is strongly suggested that devel‐ opers migrate their builds to this tool.

Installing Gradle

In order to use this tool, make you have the proper version downloaded and installed.

You need version 1.6, which you can get from here: Gradle download site . Put Gradle in your PATH (see

“Setting your PATH variable” on page 5 ) and you will be ready to go.

144 | Chapter 9: Build Tools

Key Concepts and Terms

There are a few definitions you need to know to understand building with Gradle.

Product flavor

This specifies a customized version of the application build by the project. The concept helps manage small variations, such as changing SDK support, version number, or release signing information.

Build type

This determines how an application is packaged. It’s where you do things such as specify debug flags, enable ProGuard, or specify native compilation settings. The system provides two default build types, debug and release, but you can create your own as well.

Build variant

This is combination of a product flavor and a build type. In fact, this is the only way to define the output of a build.

Flavor group

This allows you to add even more dimensions to your build. You would use this if you wanted to package differently for different target environments, such as dif‐ ferent GL texture formats based on the chipset you are targeting.

Sourceset

This term is used to define the different source folders you will create for each build type or product flavor.

Task

This represents an atomic element of work performed during a build. This might be packaging an APK, signing a JAR, or publishing an archive to a repository.

Creating Multiple Build Variations

The concept of Gradle is that you will put files (Java class files, image resources, XML, etc.) in a particular folder designed to represent a particular “Product Flavor.” The dif‐ ferent source folders (known as sourcesets) represent different build variations.

Gradle follows the concept of convention over configuration, which means that if you don’t explicitly override something, the system defaults to a standard configuration.

This means it is only necessary to include the particular item that is specific to your build and let the system handle the defaults.

Gradle-Based Build Tools | 145

Example

I will show a few examples that demonstrate how easy it is to customize build types in

Gradle by putting unique files in appropriate directories.

Let’s say you want to change the flavor1 build to contain custom icons and translations for the app you plan to distribute only to Mexico. You need to replace the launch


, and the strings.xml file (containing my translations), and use the rest of the defaults from the “main” build. This would look like this: src/

main/ - standard Android Project files

AndroidManifest.xml

aidl/ - ex. my_interface.aidl

assets/ - ex. database_preload.db

java/ - ex. com.project.SomeActivity

jni/ - ex. jni_file.c

res/ - ic_launcher.png, main_layout.xml, strings.xml

flavor1/ - files specific to 'flavor1' build

res/ic_launcher.png - (custom icon for Mexico)

res/strings.xml - Spanish translations

...

As another example, you could provide a unique function that would be available only for a certain user base (such as to enable an advanced feature available only in a “Pro” build.). To do this, place your unique activity and its appropriate manifest entry in the correct sourcesets, which look like this: src/

main/ - standard Android Project files

AndroidManifest.xml

aidl/

assets/

java/

jni/

res/

proVersion/ - files specific to 'Pro' build

AndroidManifest.xml - contain entry for Activity

source/com/myapp/pro/ProActivity.java - class for 'Pro' function

res/pro_activity.xml - the layout file for ProActivity.java

...

One final example is if you wanted to preload different database data (perhaps to support different default datasets for different target audiences). To handle this, you would place specific database resources in each folder, which looks like: src/

main/ - standard Android Project files

AndroidManifest.xml

aidl/

assets/db_preload.db - default database file

java/

146 | Chapter 9: Build Tools

jni/

res/

dev/ - files specific to 'Developer' build

assets/db_preload.db - database for 'Developer' release

qa/ - files specific to 'Developer' build

assets/db_preload.db - database for 'Quality Assurance' release

prod/ - files specific to 'Developer' build

assets/db_preload.db - contains for 'Production' release

...

Build File

To use the build tool, you need to configure it in a file called build.gradle in the root folder of the project. The build file is written using the Groovy syntax.

As I mentioned, Gradle is designed to use convention over configuration. This is why the basic gradle.build file is actually very simple and provides sensible default options.

The most basic file defines:

• Repositories used to hold build artifacts and dependencies

• Dependencies within your project

• Basic information (API level, etc.) specific to your Android build

• Optional parameters specific to your Android build

The most basic build file looks like: buildscript { repositories { mavenCentral ()

} dependencies { classpath 'com.android.tools.build:gradle:0.3'

}

} apply plugin: 'android'

// Note: do not also use the Java Plug-in

// which will break the build

android { compileSdkVersion 18

//Optional: Set parameters for a particular buildType

buildTypes { release { runProguard

true

proguardFile getDefaultProguardFile ( 'proguard-android.txt' )

}

}

Gradle-Based Build Tools | 147

//Optional: Define specific parameters for a flavor

productFlavors { flavor1 { proguardFile 'flavor1_rules.txt'

}

}

}

Build Tasks

You can execute Gradle tasks from the command line, similar to how you would run an Ant task. Enter the gradle command followed by the task you wish to execute, such as: gradle build

You can define your own task, or use one of the common default ones:

assemble

Create the output of a project.

check

Run the tests to ensure the validity of the build.

build

Performs both the check and assemble tasks.

clean

Removes files created by a build.

To see a list of all possible tasks and their dependencies, run: gradle tasks --all

Just as with Ant, you can issue multiple tasks in a single command and they will be executed in order: gradle clean build

Generating a Gradle Build from Eclipse

It is possible to generate a Gradle build from your existing Eclipse project. This will not change your existing project, but will add the appropriate Gradle build files. The steps to do this are:

148 | Chapter 9: Build Tools

If you use the new Android Studio IDE, you can import a project without generating the Gradle build file. It will successfully build and run within Android Studio, but you will not be able to use build var‐ iants or other advanced features in the future. It is strongly suggested that you generate a Gradle build file (or write your own) if you plan to use Android Studio.

1. Update your ADT Plug-in to version 22.0 or higher.

2. Select File → Export.

3. In the next dialog, select Android → Generate Gradle build files.

4. Select the projects you want to export, and click Finish.

Using the Maven Tools

As with most things Android, the developer is not stuck using the supported tools. There is good support for using other build tools, including Maven.

To learn more about Maven integration, I suggest checking out the great free resources at Sonatype, and in particular, the Android-specific chapter: Android Application De‐ velopment with Maven .

Using the Maven Tools | 149

CHAPTER 10

Monitoring System Resources

It is important to monitor resource usage on mobile devices because memory is limited.

In this chapter, I show how to use the profiling tools to help you understand your application’s memory usage.

Memory Usage in Android

Android programmers don’t explicitly allocate free memory, as they do in other lan‐ guages like C++. It is still possible to create a “memory leak.” This is when code keeps a reference to an object that is no longer used, which can prevent a large set of objects from being garbage-collected. This can be a result of improper scoping of variables, not closing handles to system resources after using them, or long-running processes that may not expire.

The Dalvik runtime is garbage-collected, which means that unused memory is auto‐ matically recovered by the system at certain intervals. This might lead you to think that you can ignore memory usage entirely because the system will eventually take care of it. This is not true, as memory issues can manifest in many different ways. Some may be obvious, such as getting an OutOfMemory exception due to not recycling your bit‐ maps correctly.

There are other issues related to memory usage that are far more difficult to debug and that can impact performance more significantly. These are issues related to inefficient garbage collection as a result of frequent or large collections that manifest themselves in ways that aren’t as obvious. Instead of your app force closing with an OutOfMemo‐

ry

exception, your app continues to run, but with degraded performance, pauses, con‐ tinues, or stutters. Garbage collection is an expensive operation for the system to run.

It is best to manage memory efficiently in your code so the process runs less frequently.

Memory issues are very common in Android, so you will likely encounter a variety of issues throughout your development.

151

Dalvik Debug Monitor Server (DDMS)

The main tool you will use to analyze memory is called the Dalvik Debug Monitor Server

(DDMS). This tool is used to analyze memory consumption over a given time period.

You will use this tool to understand how the footprint of your app grows over time (in particular relating to memory and thread usage). It offers fine-grained information about your app in relation to performance by providing statistics about memory and thread usage. The tool itself will likely look familiar to you by this point, as we already

covered some of its usage earlier in the book (see “The Devices Tool” on page 48

). I am going highlight some of the other tools you might not have used that are particularly useful for diagnosing resource issues and eliminating performance problems.

Launching the DDMS Perspective

It is useful to have a single view of all the DDMS tools in one place. Fortunately, ADT has already created this for us. The DDMS perspective organizes the most important device tools into a single view, which is useful when analyzing performance and device functionality. To launch this perspective, select: Window → Open Perspective... → Oth‐ er... → DDMS → OK.

There is also a version of the tool that can be run from the com‐ mand line without Eclipse. This is particularly useful for team mem‐ bers that might not have the full development suite installed, but could still benefit from using these tools. The tool is named Android Debug

Monitor and can be started with the following command:

{$android.sdk}\tools $ monitor

After launching the DDMS or the Device Monitor (see Figure 10-1 ), you will see a screen

with a few important tools:

152 | Chapter 10: Monitoring System Resources

Figure 10-1. Android Debug Monitor

Analyzer Tool

Used primarily to track memory over a specific time period. You will be able to track allocation order, size, where the allocation occurred, and a stacktrace showing the specific classes associated with the memory allocation.

Threads

Offers information about thread usage within your process. You can get informa‐ tion about current status, utime, name, and a stacktrace listing all the classes being accessed by that thread.

Heap

Used to track general information about your heap usage, including its size, how much space is used, and the number of objects allocated.

Traceview

Tool for tracing method calls, including timing and resource allocation.

Each of these tools serves a unique purpose and has its own usage nuances. I will describe details about each one.

Dalvik Debug Monitor Server (DDMS) | 153

Analyzer Tool

This tool allows you to track individual memory allocations in an Android app. This can be extremely useful when analyzing how a particular application flow is consuming memory.

Running the tool

The steps to run the Analyzer Tool are straightforward:

1. Launch the app you want to profile on a device.

2. If you want to test a particular code path, navigate through your UI until you are at the point just before the code is executed.

3. In the Devices tab of DDMS, highlight the process you want to track.

4. Select the Analyzer Tool tab ( ).

5. Press the Start Tracking button.

6. Exercise your application to execute the code you wish to analyze.

7. Click the Get Allocation button to gather metrics. This generates allocation infor‐ mation based on that time. You can press this button as many times as you want, to refresh the allocation information.

8. Click the Stop Tracking button when you are done to finish the process.

Viewing the results of Analyzer Tool

After running the tool, you will see details about the memory allocations that occurred

(see

Figure 10-2

). This shows the objects that were allocated and a variety of information about them. The information includes the allocation order, the amount of memory allocated, and the type of object created. If you select one of the elements in the list, you can see the stacktrace containing the names of the classes that were allocated.

If you would like to find a specific class in the list, you can type the name into the Filter box. The search will happen as you are typing.

154 | Chapter 10: Monitoring System Resources

Figure 10-2. Viewing output from the Analyzer Tool

To see even more detail about a particular object, highlight it to display a stacktrace in the second table. This view has more details about the object, including the file, object, and method where it was created and the stacktrace that led to the allocation.

Threads

When you start an application, the Android system launches a new Linux process with a single thread of execution. In general, all components of an app run within the same process and thread, which is commonly called the UI Thread. Because everything runs off this single process, it is important to identify particular processes that are blocking execution (and thus locking up the rest of the app). Fortunately, the Threads tool makes it easy to track a variety of statistics about thread usage.

Running the Threads tool

To run the Threads tool:

1. Launch the application you want to profile on a device.

2. In the Devices tab, highlight the process you would like to track.

3. Click the Update Threads icon ( ) to enable profiling (you will click this again after you are done to stop tracking).

4. Select the Threads tab ( ) on the right.

5. Click the Refresh ( ) button once to ensure that you are viewing current threads.

Dalvik Debug Monitor Server (DDMS) | 155

Viewing thread information

The output from running this process should appear as in

Figure 10-3 . The top tab

includes a variety of information regarding thread status and execution time.

The information on the bottom tab is a stacktrace related to a single thread. To see this detailed information, highlight a single thread in the top pane.

Figure 10-3. Viewing information about Heap execution

Heap

The Heap tool makes it easy to view how much heap memory a process is using. This is useful to track memory usage at certain execution points.

Running the Heap tool

To run the Heap tool:

1. Launch the application you would like to profile on a device.

2. In the Devices tab, navigate to your application and highlight the process you plan to track.

3. Click the Update Heap icon ( ) to enable profiling (you will click this again after you are done to stop tracking).

4. Click the Cause GC button ( ) to collect the current heap information.

5. Select the Heap tab ( ) on the right.

156 | Chapter 10: Monitoring System Resources

Viewing heap information

The output from running this process should look like Figure 10-4

.

Figure 10-4. Heap view

The heap information is displayed in three sections:

• The top section contains overview information about the heap, including size and how much memory is allocated.

• The center section contains more detail about the objects that are in the heap, in‐ cluding details about how much memory they are consuming.

• The bottom panel, “Allocation count per size,” is a graphical representation that shows when specific objects were created in relation to the overall size of the heap.

Traceview

Traceview is a tool that gives very fine details about the execution path of an application, including when a method or thread was started, what methods or threads were accessed while it was running, and when it stopped. This can be useful if you are working on optimizing particular code paths, as it allows you to track very fine details about your performance (and understand if your optimizations are effective). The tool includes

Dalvik Debug Monitor Server (DDMS) | 157

support for saving the files it creates, which makes it possible to track optimizations over time because it is easy to keep a historical record.

To generate a traceview, press the button ( ) in the Devices tab. You will be shown a dialog with a few options (location of the file, duration to run, max size of the file).

Specify your options and click OK to generate the file. After the traceview has been generated, the viewer (

Figure 10-5 ) launches automatically.

You can start Traceview from the command line (if you wish to look at an existing file) using the following command: traceview filename.trace

Figure 10-5. Example output from Traceview

Traceview output—timeline panel (top section)

The timeline panel (see

Figure 10-5

) allows you to see detailed information about the execution path and order of methods within your app. It shows the threads and resources the app consumes across the time period you were tracking. This includes the classes and methods that are being used, how often, and how much time is spent in each call.

You can get finely grained detail about parent/child relationships and CPU utilization metrics. There are two sections of the view, showing different types of information.

158 | Chapter 10: Monitoring System Resources

The timeline is color coded to coordinate with specific process names in the lower pane.

Each method is displayed in its own color-coded column. You can look at this chart and quickly determine which methods are taking the most time to execute by looking for areas in the graph with the most color (which represents more time spent in that meth‐ od). You might notice some small lines beneath these columns. These are designed to show the extent (entry to exit) of the calls to the method being tracked.

Profile panel

This panel is designed to show more detailed information about the time spent in a method, so that you can get fine details about the timing of your method execution. You can track entry and exit times and the time actually spent in the method. It is even possible to track executions between methods by clicking on the triangle ( ) next to the method to expand and see its children.

This table includes a few different columns including information about CPU time, and actual time spent in a method. You can gather exact times (in milliseconds) or percen‐ tages (%, which indicates the ratio of time spent in relation to total execution time.)

There are a few different columns representing different data. The tool shows the data in two distinct ways:

Exclusive time (Excl)

Time spent within the method

Inclusive time (Incl)

Time spent in the method and time spent in any functions called by that method

The Traceview tool is useful for determining nuanced details about the execution order of your app, which is useful when debugging applications with complex execution paths.

It is also a great tool for tracking your application performance over time, since you can easily archive the output files to compare historical data.

Memory Analyzer Tool (MAT)

Another great way to analyze memory is to generate snapshots of the application’s heap at certain points in time. The Android tooling will generate these files into a common format named HPROF. The file contains binary data that can be used to find perfor‐ mance problems that result from inefficient memory usage in your application. There are tools available (such as MAT) that allow you to browse the allocated objects when you supply a valid HPROF file. Having a collection of these files makes it easy to analyze them, track trends, and identify issues.

Memory Analyzer Tool (MAT) | 159

Generating an HPROF File

There are two primary ways to generate a new HPROF file.

1. Include the code android.os.Debug.dumpHprofData() in your application to trig‐ ger a dump at a specific execution point.

2. Use the “Dump HPROF file” button ( ), which generates a dump file when you press it.

HPROF File

Both of these methods generate a file that is slightly different than what the Android tooling requires. It is necessary to convert the file before it can be analyzed.

To convert it, use the provided conversion tool from the command line. For instance: hprof-conv dump.hprof dump-converted.hprof

After completing the conversion, you will be able to analyze the dump file in any of the applications designed to handle this kind of file—like jhat , or MAT, the Eclipse Memory

Analyzer Tool .

Installing MAT into Eclipse

MAT is not available by default and needs to be installed separately. The MAT update site includes directions on how to install it into Eclipse.

You might see a “Duplicate Location Exists” warning when you enter the update site URL. In this case, you will find the MAT update site as a subcategory to your main update site. To install MAT, in the Work

With:

box, select your main update site (for instance “Eclipse Indigo

Update Site”). Then find “Memory Analyzer” in the list. Place a check‐ mark next to it here, and proceed to install as normal.

Launching MAT from Within Eclipse

If you are using Eclipse, there is a DDMS preference that automatically converts the

HPROF file and starts the MAT tool (if it is installed). This happens automatically when you press the “Dump HPROF file” button ( ). If you want to set this as the default behavior, go to Window → Preferences → Android → DDMS.

If you would like to view historical heap data, you can maintain copies of the HPROF files (which could be triggered during automated testing or manually).

160 | Chapter 10: Monitoring System Resources

Using MAT to Analyze HRPOF Files

Using the MAT tool can be somewhat complicated. It is very feature rich and provides many ways to identify memory problems. I will discuss the three most commonly used options. If you would like to learn about other options, the official site is a great resource.

When you launch the MAT wizard, the first screen to appear looks like Figure 10-6

. It provides you three options for viewing your data:

Leak Suspects Report

Analyzes your file to detect leaks automatically. It also reports which objects are kept alive, and what is stopping them from being garbage-collected.

Component Report

Allows you to analyze certain objects, and to find duplicate strings, unused collec‐ tions, weak references, and other memory issues.

Reopen previously run reports

Use the tools to review previously run reports.

Figure 10-6. Launching the MAT wizard

Memory Analyzer Tool (MAT) | 161

If you would like to learn more details about using MAT, the docu‐ mentation for the tool does a great job. It details different memory scenarios and describes ways to use MAT to find them. It is available at Eclipsepedia .

There is also a great Android-specific write-up on the developers blog.

It is worthwhile reading.

The MAT Overview Screen

The first screen (see

Figure 10-7 ) that appears provides an overview of the memory

footprint of your app, and links to other tools (like Histogram or Top Consumers) that allows you to learn more about your memory usage. You can get some general infor‐ mation about your heap from this screen such as total size, and how many objects and classes are allocated. This is a great way to get a general overview of your heap, which you can then use to learn more about specific areas.

Viewing a Report

The reports generated by MAT are very detailed. It is useful to see an example report to get an idea of the format and kind of information you can get from this tool. I have

included an example Leak Suspects Report ( Figure 10-8 ) to show how easy it is to view

information.

Notice the tool lists information about each of the Problem Suspect classes it has iden‐ tified. It outlines very clearly how many instances of the class are causing memory issues, including how much memory (actual bytes and percentage of total heap), information about the type of memory (for instance, in Problem Suspect 1 it is a byte array), and more details about specific locations in code where execution is called.

It is important to note that the items reported in this tool are not necessarily issues, as there are instances where it makes sense for classes to be instantiated and retained for a long time. You will notice that Problem Suspect 2 identifies a variety of instances of

java.lang.Class

. In many cases, instances of this class are not leaks, but are instantiated and retained as part of normal program flow.

162 | Chapter 10: Monitoring System Resources

Figure 10-7. The MAT Overview screen

Memory Analyzer Tool (MAT) | 163

Figure 10-8. MAT Leak Suspects Report

164 | Chapter 10: Monitoring System Resources

CHAPTER 11

Working with the User Interface

The user interface (UI) of any mobile application is important, and Android’s wide‐ spread use requires that your software run well on a variety of different target devices.

Generally, the wider range of devices you can support, the larger your potential customer base.

In almost all mobile applications, the elegance and usability of the user interface are more important than anything else. Your app has to look good to succeed in today’s market. However, creating an attractive UI is made more difficult by the vast profusion of screen sizes and resolutions in Android. You can’t finesse the problem by restricting your app to work on only one or a small range of devices; at least, you can’t do that without giving up a very large number of potential customers.

This is where the Android framework comes to the rescue. From the beginning, Android was designed to support various devices and has thus offered simple ways for the de‐ veloper to support them. The developer tools are also designed to make supporting multiple devices easier.

Android Layout Basic Concepts

In order to leverage all the features of the UI, it is important to understand the funda‐ mental concepts of the framework.

Defining Layouts Using XML

Android layouts are conventionally created using XML syntax to define the user inter‐ face (UI) of an app. These XML files contain descriptions of various interface widgets, which could be TextViews, Buttons, or ImageViews (don’t confuse these with “Desktop

Widgets,” which are a different thing). The files contain information defining the widgets

165

you wish to display and detailed information about them (for example, orientation, spacing, or the specific location of an element on the screen).

The advantage of placing the layout into XML is that it separates the presentation of your application from the business logic. Your layout definitions are separate from your application code, so you can modify the layout without needing to change your source code or recompile. You can create different layouts for multiple device orientations, screen sizes, or locations.

It is worth noting that almost everything you do in XML can also be done in Java code, or by using a combination of both. For instance, you might define the placement and size of a button in XML and then use Java to set the text at runtime, depending on a particular code path execution.

Terminology

There are a few definitions you need to know to follow the next few chapters.

Widgets

Native controls available to be used by the developer. These include a variety of elements, such as TextViews, ListViews, Buttons, and other UI components you will use to create layouts. These built-in components are commonly found in the android.widget

package and are frequently subclasses of the class an droid.view.View

. If the native controls don’t provide the capabilities you need, it is possible to use custom components imported from libraries or developed as part of your codebase.

Layout Files

XML files that describe the widgets making up your UI. These are located in the

res

folder of your project.

Layout

A class whose primary purpose is to contain other controls. These classes (such as

LinearLayout , TableLayout , and FrameLayout ) organize widgets (such as Text‐

Views, Buttons, etc.) on the screen.

Attributes

Control specific behavior in your components. They have the format ( name space : name = value ), which allows you to specify characteristics of your compo‐ nents. Some examples of these with which you are probably familiar include android:width="48dp" , android:color="@colors/text_color" , and android: text="Text Value" .

Themes and Styles

Allow the developer to define the specific look and feel of a layout in external files.

This is a common way to apply color or text attributes in a single file to apply them to multiple widgets, and also make changes to multiple screens from a single file.

166 | Chapter 11: Working with the User Interface

Resource Qualifiers

The most common way to support multiple devices in Android is to use different folders for different resources (described later in

“Resources” on page 170 ). This term

is used to describe the name you add to a folder, which allows this to work.

Views and ViewGroups

Layouts in Android are constructed by combining these two base objects into hierarchies.

Views

This is the base class for many widgets (such as TextView or Button). It is the base class (classes.android.view.View) for almost all UI components in android.classes.android.view.View

.

ViewGroups

This is a view that contains other views. The ViewGroup class (android.view.View

Group ) is the base class for many layouts in Android or other specialized compo‐ nents such as ListView and WebView.

The first step in visualizing your layout is to define a simple hierarchy. This might look

like Figure 11-1 .

Figure 11-1. Layout basics: view hierarchy

Android Layout Basic Concepts | 167

The next step in creating a layout is to describe your hierarchy in code. To do this, create a layout file and insert the appropriate XML tags describing your Views and View‐

Groups. The following XML file below shows a basic layout. It contains two View‐

Groups, (the LinearLayout elements) that contain other Views (in this case the Buttons and a TextView). The order in the XML file matters: it lays out two buttons side-by-side, with text below them, and then another button below that. The screenshot (see

Figure 11-2 ) shows how this would look on a device.

Example 11-1. XML file that produces screen in

Figure 11-2

<?xml version="1.0" encoding="utf-8"?>

< Layout

xmlns:android= "http://schemas.android.com/apk/res/android"

android:layout_width="match_parent"

android:layout_height="match_parent"

android:orientation="vertical" >

<LinearLayout

android:id="@+id/button_linear"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:orientation="horizontal" >

<Button

android:id="@+id/button1"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:text="Button1" />

<Button

android:id="@+id/button2"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:text="Button2" />

</LinearLayout>

<TextView

android:id="@+id/textView1"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:text="Lorem ipsum dolor sit amet, consectetur adipisicing elit" />

<Button

android:id="@+id/button3"

android:layout_width="wrap_content"

android:layout_height="wrap_content"

android:text="Button3" />

</LinearLayout>

168 | Chapter 11: Working with the User Interface

Figure 11-2. Layout basics: rendered UI

The outermost layout, filling the screen. The other layout, the TextView, and the final button are nested inside it.

The vertical orientation ensures that the other layout, the TextView, and the final button are stacked up in the order in which they are specified from the top down.

We include a second layout, nested in the first, so that we can arrange some things horizontally in it.

This orientation specifies that the buttons will be side-by-side.

The first button, at the top left of the screen. This is within the second, innermost layout.

Android Layout Basic Concepts | 169

The second button, to the right of the first. This also is within the second, innermost layout.

This line ends the innermost layout, the one containing two buttons.

The TextView, which is within the outermost layout but outside the innermost layout. It is therefore oriented vertically under the first two buttons.

The third button, which like the TextView is within the outermost layout and therefore oriented vertically.

This line ends the outermost layout.

Resources

An Android application consists of much more that just Java files. A variety of other files (such as images, videos, and colors) are also used to create your interface. These are known collectively as resources and resource files. The Android framework supports an easy way to tie different versions of a resource (a different resolution image, or a different size of icon, or text in a different natural language) to different configurations on the device (no keyboard, French locale, hi-res screen). For example, in order to support different screen resolutions, it is necessary to include multiple copies of the same image, in various resolutions.

Using resources has many advantages, including:

• Source code is separate from resources, which makes customization easier.

• Resources are static and compiled into the application, which means they can be checked for availability before runtime.

• It is easy to support additional functionality (localization, for instance) by simply adding the appropriate resources without requiring modification to existing source code.

Android specifies that you put these items in the res folder at the base level of your

project (see Figure 11-3 ). You will put resources in unique folders that are determined

by the features you want to support. At compile time, Android scans the folders and uses the appropriate resource. For instance, when your app is run, the system will know to use the appropriately sized image and retrieve it from the res folder.

Figure 11-3 shows how to supply a graphic resource that supports different resolutions.

To do this, put a resource with the same name (in this case, ic_launcher.png) in the folder appropriate for each resolution you support (mdpi for medium resolution, hdpi for high resolution, etc.). When your app is run, that image will be used by the system automatically.

170 | Chapter 11: Working with the User Interface

Figure 11-3. Using multiple graphic resources

In the same way that you provide alternate image resources, you can supply layouts, strings, colors, dimensions, and much more to support specific device configurations.

There are many nuances to externalizing application resources, and understanding them can really help the development process. The official documentation describes all the different ways you can customize your application using alternative resources and is worth reading.

Leveraging ADT to Build Great UIs

Generating Android applications that support multiple devices is one of the more chal‐ lenging aspects of working with the platform. Fortunately, ADT provides a robust set of tools to aid the developer (or designer) in creating the UI layer. There are tools to create layouts using a drag-and-drop editor, generate code templates, extract resources, refactor XML, and much more. This chapter (and the next few) will highlight all the great tools available, and show how you can leverage them to make responsive interfaces that work well and look good on a variety of devices.

The documentation describing how to handle multiple devices does an excellent job of explaining what the different resolution formats are, as well as specific strategies for making the most of this feature. I suggest reading it.

Android Layout Basic Concepts | 171

Editing XML Files Directly

In

“Code Templates” on page 59 , we discussed using the tools to generate code. There

are also a lot of templates you can use to generate XML files. There is support for creating a variety of different XML files, which makes creating them simple.

Using Templates

The XML templates can be accessed by choosing File → New → Other → Android →

Android XML File. You will be presented with a menu (similar to Figure 11-4

) showing a list of XML files available. There is support for a variety of file types, so it is worthwhile to know which ones the system can create for you.

Figure 11-4. XML editor: code templates

172 | Chapter 11: Working with the User Interface

Editing XML Directly

Editing XML files can be challenging. You have to be careful to match tags, and always use correct attribute values. Many times, errors don’t show up until compile time or runtime, which makes the debug cycle long and inefficient. The XML editor that is built into the tools includes functionality to simplify manually editing layout files. Using these features makes it easy to write valid XML, use correct attributes, and refactor layouts without syntax errors.

Code completion

You have probably already used the code completion facilities available when editing

Java files. ADT provides similar capabilities when editing layout XML files. You will be able to use this functionality to insert UI widget definitions, look up attribute values, and identify resources (such as drawables, layout elements, string values, or style defi‐ nitions). These tools make it much easier to generate XML layout files correctly, so you won’t spent time fixing syntax errors or searching APIs to find acceptable values.

The key combination that launches code completion is the same one you use in Java and the same on all platforms: Ctrl+Space. It provides different options depending on the code you have highlighted.

Inserting new layouts or widgets

If you place your cursor on a blank line or outside an existing tag, when you press this key combination, you will be provided with a list of elements you can insert (like in

Figure 11-5 ). Selecting one of the items from the list as shown will create a stubbed item,

which you can extend with your own custom attribute values.

Editing XML Files Directly | 173

Figure 11-5. XML editor: inserting new element

Attribute values

If you place your cursor inside an XML attribute definition (i.e., between the quotation marks), you will be provided with a list of appropriate entries. There are two different possibilities for these values, depending on the particular attribute you are defining.

The first allows you to fill in API options to define elements from the system (such as width attributes or buffer). For example, in

Figure 11-6

I am using code completion to define the width attribute for a TextView.

174 | Chapter 11: Working with the User Interface

Figure 11-6. XML editor: adding a new element

The second allows you to locate local or system resources for your UI. These things might include color definitions, string values, style definitions, or other layout elements.

The example in Figure 11-7

shows how the tool provides you with a list of values available.

Editing XML Files Directly | 175

Figure 11-7. XML editor: adding a new API attribute

Refactor menu

This tool allows you to quickly complete refactoring operations. These include remov‐ ing layout elements, wrapping multiple widgets in a container, or extracting XML to be shared by multiple resources. To launch this menu, highlight the starting tag of the element you want to refactor, then select the Refactor menu from the top menu bar. It offers a variety of options, some of which we already covered in the IDE section

( “Refactor Menu” on page 70

). It is worth discussing the layout-specific options here:

176 | Chapter 11: Working with the User Interface

Change layout

This lets you change the layout and then re-renders the canvas automatically. You might need this if you need to convert to another container type because of a lim‐ itation with your current type (for instance, you needed finer control over place‐ ment than a LinearLayout provides).

Change widget

This allows you to change the type of one or more widgets. It automatically removes incompatible attribute types, and includes default values for any new ones that are required.

Extract as include

This allows you to extract views into a separate layout file. It creates the new external layout file and includes the appropriate reference in your XML. This is a simple way to reuse common view components, which avoids duplications and creates cleaner code.

Wrap in container

You can use this menu to select one of more siblings and wrap them in a new layout container. The tool transfers layout attributes from the sibling to the new parent container. This can be useful if you need to group UI components, perhaps to apply common gravity.

You can use the Quick Assistant if you aren’t sure which refactor you need to use. This is a great way to allow the system to provide sugges‐ tions depending on the current context. In either editor (Java or

XML), highlight a field and press Ctrl+1 on Windows\Linux or

Command+1 on Mac OS X. This will bring up a list of refactor pos‐ sibilities, and is the quickest way to access these common options.

Editing XML Files Directly | 177

The example in

Figure 11-8 shows how you would use the Refactor menu to remove a

layout container. After highlighting the LinearLayout to remove, select the Remove

Container menu item and a screen appears (

Figure 11-9 ) allowing you to review the

changes before clicking OK to commit them.

Figure 11-8. Accessing the refactor menu from the XML editor

XML formatting

Layout files can get complicated fast. You will likely use many different attributes to specify unique parameters for your different UI elements. The XML files can become particularly difficult to follow when attributes are not spaced uniformly or when they are out of order. You can use the following keys to quickly format your code:

Ctrl+Shift+F on Windows\Linux or Command+Shift+F on Mac OS X.

It automatically adjusts tab spacing and organizes the attributes into a specific prede‐ fined order. Having correctly formatted XML makes it easier to understand element relationships and find particular attributes you may need to modify.

178 | Chapter 11: Working with the User Interface

Figure 11-9. XML editor: options shown by Refactor menu

The default formatting style matches the conventions used in official Android docu‐ mentation, tutorials, and source code, so your code will match standards. The system automatically applies custom formatting rules depending on which type of file is being edited. This means that custom formatting rules will be applied to standard layout files, resource definition files (such as strings.xml), or AndroidManifest.xml. This makes a big difference in the readability (and maintainability of your code). The XML files can become particularly difficult to follow when attributes are not spaced uniformly or when they are out of order (as seen in

Figure 11-10 ).

Editing XML Files Directly | 179

Figure 11-10. XML editor: before reformat

Having correctly formatted XML (like that shown in Figure 11-11

) makes it easier to understand element relationships and find particular attributes you may need to modify.

180 | Chapter 11: Working with the User Interface

Figure 11-11. XML editor: after reformat

Editor Preferences menu

The Editor Preferences menu, shown in

Figure 11-12 , allows you to change the format

that the editor uses. This is valuable, for instance, if your company has unique coding standards. Another important setting causes the system to automatically format your code when you save it. I recommend you set this value, so you can ensure you are performing the formatting operations on all of your files.

Editing XML Files Directly | 181

Figure 11-12. XML editor: preferences

There are two preferences worth highlighting. You can access them from Window →

Preference → Android → Editor on Windows and Linux, and from ADT → Prefer‐ ence → Android → Editor on Mac OS X.

This menu contains a variety of useful options that allow you to customize Editor func‐ tionality further. Some of the more useful ones include:

• Configure style (spacing, line wrapping, etc.) of formatting

• Modify the default order of the attributes (there are a few alternate options, and you can create a custom sort order as well)

• Specify if you would like the format operation to be run on every save

Working with Graphics

In the beginning of the chapter, I described how Android uses multiple resources to support different device resolutions. Supplying each of the proper resolution images is one of the most important ways to ensure that your app looks good everywhere. If the system is not able to find an image resource matching its preferred resolution, it will

182 | Chapter 11: Working with the User Interface

find the next closest resolution and scale it to fit. This can result in unexpected visual artifacts, and can significantly effect the responsiveness of your app, as image rescaling can be memory and CPU intensive.

It can be difficult to understand what size each of the images can be, the names of the folders, and other information associated with this way of doing things. In my experi‐ ence, this is one of the bigger frustrations for designers and developers.

There are two great ways of dealing with the complexities of manipulating image re‐ sources: the Android Asset tool, and the use of Nine-patch images.

The Asset Tool

The Asset tool automatically creates the appropriate resolution resources and places them in your project. Launch it by entering Ctrl+N on Windows or Linux and

Command+N on Mac OS X.

From the New wizard launcher, expand the Android section and select Android Icon

Set, as shown in Figure 11-13

.

Figure 11-13. Launching the Android Icon Set generator

Working with Graphics | 183

A screen ( Figure 11-14 ) prompts you to specify the type of resource you want to gen‐

erate. There are different sizes for images, depending on whether they are intended to be used in notifications, on the Action Bar, or elsewhere on the screen. You will need to specify the type of icon that should be created.

Figure 11-14. Specifying options to customize icons

Next, you will specify the name of the icon, and the project where you would like it created. When the tool is done, it will create all the appropriate images and place them in the correct folders in this project.

The last screen ( Figure 11-15 ) is where you can actually generate the icon asset. You can

generate an icon with text, modify the appearance of it, and change the colors of the foreground or background. You can even use clip art (either your own, which you can import, or icons supplied in the tool itself) to generate specific designs. When you have configured the look of your icon, click the Finish button. The res folder in your project will now have PNG files with your design at the correct resolution.

184 | Chapter 11: Working with the User Interface

Figure 11-15. Creating an icon set

I have found an excellent way to work with my design team. When I create my source code, I use the Asset Studio to create sample icons.

Then, when I request real icons from the graphic artists, I just copy the

res

folder out of my projects and give it to them. I ask them to replace the sample images with their own. Since they know the names and sizes of each of the resources they need to supply, this eliminates communication errors. The best part is that, when it is time to inte‐ grate the real images back into the project, all I have to do is copy the

res

folder with the correct resources back into my code, and I’m done!

Using Nine-Patch Images

Android lets you supply your image assets as Nine-patch images. This format allows you to define lines along the edges of an image, which control how it is scaled by the system. The placement of black lines informs the framework whether that section of the image will be grown/shrunk by zooming it, or should be kept unchanged. A good example of when it’s useful to provide this type of image is when creating a styled button

Working with Graphics | 185

to use throughout your app. If you use a NinePatchDrawable as the background for your buttons, it will stretch and scale to look uniform across all of them.

To use a NinePatchDrawable, you must slice your image resource into nine regions.

There is a center container for your content, then four corners and four sides that will be scaled by the system. It can be a little challenging to understand this concept at first so if you would like to brush up on the topic, the drawable documentation is a great place to start.

Specify how the Nine-patch image is scaled by drawing black lines on the sides of the image. These specify two things:

Stretch regions

Defines which pixels of the image will be copied to stretch the image. These lines are drawn on the top and left.

Content padding

Defines the area within the image that the contents will occupy. These will be the lines on the bottom and right.

The draw9patch command-line tool makes it easy to create and edit these images. Just type draw9patch at the command line to bring up the “Draw 9-patch” tool, which pro‐ vides a way to visualize the effects of scaling on your image when you are defining it.

Start by dragging and dropping an image on the palette. This launches the editor (see

Figure 11-16

).

Then use the mouse to draw the lines that specify the various regions. Check the “Show patches” and “Show content” options at the bottom of the screen to visualize exactly how the system will scale your image. You can change the black lines to show:

Stretch regions

Shown by the pink box in the center of the pane on the left.

Content padding

Shows how much space is available for your content, via the purple box in the right side pane.

186 | Chapter 11: Working with the User Interface

Figure 11-16. Editing Nine-patch drawables using the visual editor

Asset Studio Website

It is worth noting an excellent open source project called Asset Studio that automates many of the procedures we discussed in this section. The home page (shown in

Figure 11-17

) shows some of the things you can do. This site automates many of the things the tools do, including generating multiple image resources, editing Nine-patch images, and others. It also has some additional functionality not available elsewhere, including generating screenshots such as device frames for marketing, or generating styles for commonly used resources—specifically the Action Bar.

Working with Graphics | 187

Figure 11-17. Android Asset Studio website

188 | Chapter 11: Working with the User Interface

CHAPTER 12

Using the Graphical Editor

By far the easiest and most productive way to design a user interface (UI) in Android apps is to use the Graphical Layout tools. In the past, these have been difficult to use, sometimes creating code that was hard to understand and had other practical limita‐ tions. But the tools have improved over successive releases. They are getting close to the standard set used by GUI builders for Windows or iOS, and now work better than the Android alternative (manually editing XML files). They make it easy to generate the user interface, refactor existing layouts, visualize your UI on multiple environments, and much more. They can make development more efficient and ensure that you are creating well-formed layout code.

Generating Layouts Using the Graphical Layout Editor

If editing XML isn’t your thing, there is a graphical tool that allows you to drag and drop

UI components to construct a layout. You will use this to create your basic layouts, then modify the XML to fine-tune your layouts.

The Graphical Layout editor (see Figure 12-1 ) can be accessed by selecting the appro‐

priate tab (on the bottom left) of any Android layout.xml file. Selecting this tab presents you with a perspective containing the tools you can use to construct your interface.

Switch back to the XML view by selecting the tab showing the layout filename. The two views are kept in sync when you save the file.

189

Figure 12-1. Visual editor, full view

This tool has a few different components that work together to provide a comprehensive visual editing environment. We will discuss each in detail in this chapter.

Palette

On the left is the panel that contains the widgets you can drag onto the canvas. The palette contains rendered views of the components available, making it easy to find the component you want.

Canvas

This is the component in the middle of the screen. When you drag elements onto this canvas, a view will be rendered to show how it will look. There are many dif‐ ferent options available in this tool that allow you to determine how your UI will look on different devices. XREF discusses these in detail.

Outline

This panel (on the top right) provides a hierarchical view of your layout, displayed as an ordered list.

Properties editor

This window (on the bottom right) allows you to modify attributes of your widgets.

190 | Chapter 12: Using the Graphical Editor

Configuration chooser

The list of menus on the top of the canvas allow you to configure how the view is rendered. These allow you to render different views of your UI, right in the tool.

This is easier and quicker than trying to duplicate UI in different configurations using emulators.

Palette

On the left side of the tool is the palette. It contains categories of widgets and UI com‐ ponents that are available to drag onto the canvas. You can select a category heading to display the view types in that group.

You will notice that the widgets are rendered according to the currently defined style.

The dark bottom part contains any custom views you have defined in your project (see

Figure 12-2

). ADT automatically makes them available via this tool (you may have to press the Refresh button if they don’t display automatically).

Figure 12-2. Palette

The palette contains a large variety of components that are preconfigured to perform certain actions. Find the appropriate component and drag it to your canvas to place a properly configured UI component on your interface. For example, if you wanted to

Palette | 191

add a Password field to a form, you would locate the component from the Text Fields category (see

Figure 12-3

) and drag it onto your canvas. When you look at the XML, you will see that a default value is defined for ems (which is a property used to control text size), and the inputType is set to textPassword (which masks the values the user enters).

Figure 12-3. Graphical editor: password example

Canvas

This is where you can drag widgets from the palette and drop them to create your UI.

The canvas renders a preview of your app in real time based on the widgets you add.

You can then modify the preview to visualize your app on multiple screen sizes, orien‐

tations, and other ways using the configuration chooser (see “Configuration Chooser” on page 197 ).

To add a view to your UI, find it in the palette and drag it onto the canvas. You can also add Views to other Views (see

“Views and ViewGroups” on page 167

) by dropping them onto the Outline part of the screen. After a component is placed on the canvas, you can drag it around to reposition it, assuming the Parent view supports the move.

192 | Chapter 12: Using the Graphical Editor

Just as when you are editing the XML directly, you can use Ctrl/Command+Z to undo your last operation. You can do the same thing from the Edit → Undo menu. Because it is easy to undo any operations, you can be comfortable that any changes you make are not permanent (so feel free to experiment a little).

When you drag and drop a component from the palette onto the canvas, indicators appear that show you the alignment and approximate location of the widget on your

UI. This allows you to control how the view is placed in the parent. Depending on the type of parent container, you can control the alignment and placement of the view you

are creating. In Figure 12-4

, for instance, you are placing a Button into a RelativeLayout.

A pop-up in the figure shows the alignment (in this case, centerHorizontal="true") with an arrow tying the component to its parent. Understanding the relationships among views helps you a great deal in controlling layouts, and getting this feedback visually is much easier than trying to decipher XML files.

Figure 12-4. Viewing extents while dragging items onto the canvas

Canvas | 193

Layout Actions

At the top of the canvas are two rows of buttons. The top one is the configuration chooser

(see “Configuration Chooser” on page 197 ), and the bottom one is the layout actions bar

(see

Figure 12-5 ). This bar offers context-sensitive options (meaning they will change

based on what you currently have selected) relating to the currently selected view and its parent.

Some of the common options available here include changing the gravity, lay out_width , and layout_margins. For example, in

Figure 12-5 I selected a Button in a

LinearLayout. The bar shows actions related to the LinearLayout, such as a toggle to change the orientation from vertical to horizontal. Some other available options might include a control to specify how children are aligned, actions to control the child’s layout attributes (like layout_width), or a button to change the layout’s margins.

Figure 12-5. Viewing the layout options available

Context-Sensitive Menu

You might be surprised by the functionality hiding when you right-click on any element in the canvas. You are presented with a menu of context-sensitive options (see

Figure 12-6 ). These provide a variety of shortcuts to useful functionality, including:

• Changing widget properties, including a menu to navigate based on Java package structure within Android source code (as an alternative to the full-blown properties

editor, “Properties Editor” on page 196 ).

• Creating or previewing animations. If you have enabled animation on a component, this allows you to view it from the canvas.

194 | Chapter 12: Using the Graphical Editor

• Performing most of the refactor operations we discussed in “Refactor menu” on page 176

.

• Exporting a screenshot that contains a preview of your app, rendered to appear on the device you are currently showing.

Figure 12-6. Launching the context-sensitive menu

Canvas | 195

Outline View

This tool (shown in Figure 12-7 ) provides a visual representation of your layout ele‐

ments. It organizes them into a clear hierarchy that is easy to navigate. This view offers additional functionality that allows you to drag and drop the elements within the outline.

It has a lot of the same functionality as the canvas, but provides a different view that makes it easier to use for ordering, along with selection operations.

Figure 12-7. Viewing the Outline

Properties Editor

In addition to the right-click approach to changing view properties, you can also use the View Properties tab. This tab on the bottom right will list context-sensitive properties you can use to set various attributes on the view you have selected. This is generally easier than editing the XML directly, because the editor provides lookup tools to help you find the attribute you need to set.

The properties editor shows a list of all the various properties options available for the currently selected view. If a property is already set, the value will be listed in the column on the right. If you would like to change the value, or add a new one, click within the cell to launch a list of options or a dialog to select your new value.

In the example in Figure 12-8

, I show how I could change the color property for the text of the Button I selected. When I click on the property, a dialog is presented that allows me to locate a system or project resource that defines a new color. I can then start to type the name of a color to search for a resource I have defined.

196 | Chapter 12: Using the Graphical Editor

Figure 12-8. Viewing the Properties editor

Configuration Chooser

This set of tools ( Figure 12-9 ), which appears at the top of the editor, allows you to see

a visual rendering of your layout in various configurations. This is a great way to test your layouts against a variety of different configurations, and is much easier that creating emulators or finding devices for each of these options. While this won’t replace real testing across different devices, it’s a great way to get instant feedback about your UI while you are creating it.

Figure 12-9. Viewing the Configuration chooser

There are a variety of options for changing the way your UI is rendered. It is worth exploring each of the options, as there are a lot of different ways to customize your canvas.

Configuration Chooser | 197

Configuration menu

This button ( ) lets you save a particular configuration of the tool itself. In ad‐ dition to defining a custom configuration, there are existing configurations, such as “Preview All Screen Sizes,” which will show how the screen will look on every device you have configured, and “Preview All Locales,” which shows how it will look in the various languages and local settings you have configured.

Screen

You can control the screen size using this button ( detail following this list.

). I cover this in more

Orientation

This option ( ) allows you to change screen orientation, or change to special modes (such as Car Dock or Night Mode).

Theme

This selection ( ) applies a theme to your UI. It presents a list of all theme resources available (both from the system and your project). Selecting any of them applies the styling to your UI.

Activity

This selection ( text for your layout.

) changes the Activity class that would provide con‐

Localization

This option ( ) applies any changes supported by your project for internation‐ alization. If you have alternative resources (strings in strings.xml, images, etc.) for multiple countries, you will be provided with a list of these and be able to switch between them.

SDK

This selection ( ) show how your app looks on devices with different versions of the Android OS. This option is important to test because the UI changes a lot with each release. The SDK you select does not need to be the one you are targeting.

The option for changing the screen size is a great example of how useful this tool can be. As you know, Android applications need to run on a large variety of different devices, and it can be challenging to test each of these configurations. This tool provides the capability to check multiple resolutions of your layout. You can quickly switch between different device configurations, and instantly see how your UI will render.

To change the screen size and resolution in the visual editor, use the option in the top

bar (see Figure 12-10 ) that allows you to view your layout on a variety of preset screen

sizes. The list includes any AVDs you’ve created at the top, then a variety of other devices

198 | Chapter 12: Using the Graphical Editor

below. You can select any of the devices from the list, and the rendering of your UI will be updated to show how it would appear in that configuration.

Figure 12-10. Setting screen resolution in the visual editor

I already mentioned the option at the bottom named Preview All Screens. It renders, in

one view, your UI the way it will look on a variety of different devices ( Figure 12-11 ).

The tool actually updates each of the various views in real time, which means that you can see the impact of any changes you make on a variety of different screen sizes at the same time. In the example below, I adjusted the top Button to move it to the left. You will notice that the smaller screens on the right are updated to reflect this UI change.

Configuration Chooser | 199

Figure 12-11. Previewing all screen sizes

If you are using resource qualifiers (see

“Resources” on page 170 ) to

enable different layouts (for size or orientation-specific UIs), you need to modify each one independently. The changes you make in this tool will take effect only on the

layout.xml

file you are currently editing. You need to edit each of your alternate layouts independently and make your changes in each of those files.

200 | Chapter 12: Using the Graphical Editor

CHAPTER 13

Optimizing the User Interface

Earlier chapters presented aids for creating dynamic and efficient layouts. The tools can make your UI good, but you’ll probably need to do some additional work to make your

UI great. This chapter discusses the various tools that help you improve the efficiency of your interface code. I will show you how to use the tools to eliminate:

• Slow or jittery redraw rates

• A nonresponsive, poorly performing UI

Introduction to UI Performance

In addition to the content covered in Chapter 11 , there are a few concepts relating to

how Android builds user interfaces that are important to understand.

How Android Draws Views, and How It Affects UI Performance

When an activity gets started, it asks the framework to draw its UI from its layout definitions. The UI is drawn by walking the View tree and rendering each ViewGroup.

Then each ViewGroup requests each of its children to be drawn until all Views in the hierarchy have been rendered. The tree is traversed in order, which means that parents are drawn before their children, with the final order determined by where they appear in the tree.

Two-pass layout

The runtime draws the layout through a two-pass process via the View tree, visualized

in Figure 13-1 . For each View rendering, the system must perform two operations: a

measure pass

and a layout pass. The measure pass collects dimension specifications and the layout pass positions the Views on the screen.

201

Measure pass

This pass traverses the entire View tree to determine dimension specifications for each View. The size and position of a ViewGroup depends on the number and size of the Views it contains. The measure pass calculates sizes based on the relationships between a ViewGroup and its related Views. The system will do a series of meas‐ urement passes. At the end, the system knows the size required for each View, and validates that they can be placed on the layout.

Layout Pass

After the system has determined the proper dimensions for a requested layout, it renders the items to the screen.

Figure 13-1. Two-pass layout process

Nested layouts reduce performance

Nested layouts can be a big source of performance issues. Overhead is involved with each redraw of a ViewGroup. When Android redraws a component on the screen, it must redraw every component and hierarchy it contains. The OS does a variety of com‐ plicated measurement and placement calculations for each screen draw. Complex nested components and unnecessary items impact performance and diminish the user expe‐ rience with a slow response.

There are a few tools designed to help isolate Views with inefficient hierarchies. You can use the Developer Tools (see

“Developer Tools Application” on page 52 ) to visualize

problems, Lint (see

“Lint” on page 107

) to find and fix the errors in XML or Java, or the

Hierarchy Viewer (see “Hierarchy Viewer” on page 203 ) to visualize your View organi‐

zation and determine possible optimizations.

202 | Chapter 13: Optimizing the User Interface

Hierarchy Viewer

It is important to have a good understanding of the View elements in your application.

Fortunately, ADT provides a collection of tools called the Hierarchy Viewer that allows the developer to visualize these elements and quickly identify problems.

Dealing with complicated layouts can be very challenging. It can be hard to understand deeply nested layouts, or find and remove unused layouts. We will use these tools to create a diagram of the View hierarchy of a layout, which allows us to get a clearer understanding of the nature of all the components in our layouts and how their rela‐ tionships might be optimized. We optimize the layouts by removing unused layouts and flattening the View hierarchy (which has a positive impact on performance). These tools are also useful when debugging slow UIs, as you can navigate to a specific point in your

UI and get measurements about the actual render times of the individual widgets in your apps.

Starting the Hierarchy Viewer

To start the tool, you first need to deploy your application to a running device. Then use the preconfigured Eclipse perspective that organizes a collection of tools into a single dashboard. Start it from the menu through: Window → Open Perspective → Other →

Hierarchy View. You will see something that looks like

Figure 13-2 .

Loading the View Hierarchy into the Tools

To begin analyzing your UI, navigate in your test app to the specific view you want to inspect. Then:

1. Highlight the Window tab ( ) on the top left.

2. Find your app activity in the list and highlight it.

3. If your app is not showing up, press the Refresh button ( ) to renew the list of views.

4. Generate the View by pressing Tree View button ( ).

A progress dialog on the bottom right corner will indicate that the View is being gen‐

erated. When complete, your view will look similar to Figure 13-3 .

Navigating the Tree Hierarchy

Notice that the two tabs on the right side of Figure 13-3

now have content in them.

There are two different ways to navigate using these tools:

Hierarchy Viewer | 203

Figure 13-2. Initial Hierarchy View perspective

Tree Overview ( )

You might remember from “Nested layouts reduce performance” on page 202 that

unused views can be detrimental to performance. Figure 13-3 shows a high-level

overview of how each View in the UI is being rendered. This is a good place to identify unnecessary components, because you can look for instances where a component has only one descendant (and hence you can drop the container, and just use the View directly). I highlight how to find these in the example at the end of this section.

Layout View ( )

This section shows a wire-frame rendering of your Views. You can click any indi‐ vidual component in this display to highlight it in the center Tree View.

204 | Chapter 13: Optimizing the User Interface

Figure 13-3. Hierarchy loaded into tools

Gathering View Information

The center column named Tree View ( ) is the main tool used to gather detailed in‐ formation about your UI. To start getting details, click on any View within your hier‐ archy to bring up the detailed information about the View, which will look like

Figure 13-4 . We will dig into each of the things you can do here.

The information displayed when you click on the node contains a variety of details about the View’s rendering characteristics (and its children when appropriate). This display contains a lot of great information, so I want to take a moment to explain what the values mean.

Hierarchy Viewer | 205

Figure 13-4. Hierarchy View: Tree View

Measurement information

The middle section (see

Figure 13-5 ) has two important items:

• The number of Views in this container. This example shows 24, which is a lot be‐ cause this happens to be the main node in the tree.

• Measure, Layout, and Draw times for this node (and all of its children). Keep in mind that high times are not necessarily evidence of an issue, especially for screens with a lot of objects, which naturally take longer to render.

Identification and performance indicators

The bottom part of the node information display (see

Figure 13-6

) has some other useful information that you can use to quickly identify objects within your hierarchy. It also includes performance indicators that you can scan to quickly understand how the View performs (in relation to all other Views in the same layout). Information you can find here includes:

206 | Chapter 13: Optimizing the User Interface

Figure 13-5. Hierarchy View: node measurements

• Class type of this view (in this case, the component is FrameLayout).

• The internal ID (i.e., how this View is referenced in the R class) for this View.

• The android:id used when the element was created in the XML.

• The three colored balls indicate the rendering speed of this View relative to other objects in the tree. The left ball shows the measure time, the middle one shows the layout time, and the right ball represents the draw time. If the ball is red, it means that View is the slowest one in the tree; if the ball is yellow, that View is slower than

50% of the other Views. If the ball is green, it means that the View renders faster than 50% of the other Views on the screen. You should use these indicators to quickly scan your UI to identify the problems you should look at first.

• The number on the bottom right indicates the index of this View within its parent.

In this case, the node has one parent, so its index is one (if this were the top node in the hierarchy, it would be zero).

Figure 13-6. Hierarchy View: node identification and performance indicators

Gathering View Rendering Details

The Tree View contains detailed information about exact rendering times. You will see the exact times (in milliseconds) it takes to measure, lay out, and draw a component.

Notice the three colored balls at the bottom of the screen. This is a quick way to identify particular view groups that may not be rendering efficiently. The balls represent the same cycles (Measure, Layout, and Draw, in order) as detailed in the Tree View in the

Hierarchy Viewer | 207

previous section. A ball will be green if everything looks good, yellow if there might be reason for concern, and red if there is definitely something to fix.

In addition to gathering metrics about rendering, there are a variety of operations you can do on a selected component:

• Save as a PNG ( ).

• Capture window layers as a Photoshop document ( ).

• Reload the View Hierarchy ( ).

• Display the selected View image in a new window ( ).

• Invalidate the View layout for the current window ( ). This marks the View as invalid, and it will be redrawn the next time the layout view is refreshed.

• Request the View to lay out ( ). This marks the View and its children as invalid, so they will be redrawn the next time the layout view is refreshed.

• Request the View to output its display list to logcat ( ).

Example: Debugging a UI Using the Hierarchy Viewer

Examples in this section show how to find common problems, reveal a poorly imple‐ mented UI, and identify issues. This section compares two different screens that achieve the exact same UI result. They look exactly the same, but have significantly different performance characteristics due to some design decisions. I am going to step through how you would use the Hierarchy Viewer to analyze their performance and identify issues.

Different ways to design a UI

As an example, I have created two different XML layouts. They have the exact same output on the screen, but one of them performs significantly worse than the other due to implementation differences. The key difference is:

• The “bad” layout nests many different LinearLayouts. It is not unusual for devel‐ opers to use LinearLayouts for complex layouts, but this often creates overly com‐ plex layout files and poorly performing UIs.

• The “good” layout was written using a single RelativeLayout, and all the other Views are laid out within this single container. This creates simpler layouts, and makes them perform better.

Let’s use the Outline tool to show the format of the code. This is a good way to show that the bad outline has a much more complex and deeply nested structure than the good outline.

208 | Chapter 13: Optimizing the User Interface

The “bad” layout nests many different LinearLayouts. It is not unusual for developers to use LinearLayouts for complex layouts, but this often creates overly complex layout files and poorly performing UIs. You can see this complexity in the Outline view

( Figure 13-7

).

Figure 13-7. Hierarchy View: bad outline

Figure 13-8

shows the result of creating simpler layouts and making them perform better: a much cleaner Outline view.

Figure 13-8. Hierarchy View: good outline

Hierarchy Viewer | 209

Despite the big difference in design, the “bad” screen (see

Figure 13-9

) and the “good”

screen (see Figure 13-10

) look and operate in exactly the same way.

Figure 13-9. Hierarchy View: bad layout

Using the Tree View to get timing information

To understand the UI, let’s use the Tree View described in

“Gathering View Informa‐ tion” on page 205

to discover how long it is taking to render our View. Use the steps

described in “Loading the View Hierarchy into the Tools” on page 203

to load the display and determine how the UI is performing. For the most part, you need to get a feel for the optimal performance number, which varies based on the complexity of the particular screen. You will learn what the optimal numbers are through experience, and you gen‐ erally will want to compare the layout times for the same layout, before and after opti‐ mizations (to determine whether your changes are beneficial).

In our example, it is easy to see that the “bad” layout is a poor performer. We select the top element in the Tree View and look at the measurement on the bottom. This shows

210 | Chapter 13: Optimizing the User Interface

Figure 13-10. Hierarchy View: good layout

the time it takes to draw this View. In this case, it takes 24.483 ms for the bad UI (see

Figure 13-11

), and only 19.640 ms for the good one (see

Figure 13-12

). There is a 20% difference between the two, and they both look exactly the same.

It is worth getting multiple measurements, as they will vary each time you generate the

Hierarchy View.

Reviewing the structure with the Tree Overview

So now that we have identified the poor performance of the UI, let’s next take a look at its general structure. Tree Overview makes it easy to look at a high-level overview of the tree hierarchy, and understand when a View has a complicated structure. The more complicated structures take longer to render. You will also use this View to identify when a hierarchy is too deep. Having deep hierarchies causes significant performance impact, as it increases the time it takes the system to measure the components before laying them out.

Hierarchy Viewer | 211

Figure 13-11. Hierarchy View: bad timing

Looking at the two different structures, it is easy to see why one might perform better

than the other. The “good” layout is basically completely flat (see Figure 13-13 ), without

any deep hierarchies. The “bad” layout (see Figure 13-14 ) has a lot of different hierar‐

chies, and some of them are even a few levels deep. You will use this View to quickly identify overly complicated structures by looking at how organized they appear.

212 | Chapter 13: Optimizing the User Interface

Figure 13-12. Hierarchy View: good timing

Hierarchy Viewer | 213

Figure 13-13. Hierarchy View: good tree

214 | Chapter 13: Optimizing the User Interface

Figure 13-14. Hierarchy View: bad tree

Hierarchy Viewer | 215

Using the Tree tool to inspect the bad UI

To help identify the exact View components that are causing slow render performance, use the Tree tool (

Figure 13-15

) to check the different nodes, inspecting their perfor‐ mance indicators. Concentrate on the nodes with red or yellow performance indicators, which can indicate slower performance.

The View Hierarchy window also helps you pinpoint performance issues. By looking at the performance indicators for each node, you can quickly identify the objects that are the slowest to draw. This helps to identify the elements to focus on.

It is worth noting that red or yellow indicators are not always indica‐ tive of a problem. This is particularly true for ViewGroup objects, which have more children and are more complex (and thus take more time to render).

When I look at the bad UI, I see red and yellow dots on many different nodes (in this figure, there are red and yellow dots on a variety of different places in no discernible order). On a high level, this tells me the entire UI is problematic and that the issues aren’t isolated to one particular ViewGroup. At this point, I know this layout is probably overly complex and is a candidate for a complete redesign. Next, I will inspect the par‐ ticular elements with red dots (in this case, there is the TextView that is second from the top, and the EditText that is on the bottom to the very right). In this case, both these elements are simple object types, using an Android base class (TextView). If these were custom Views (i.e., MyCustomTextView), red and yellow dots would point to good places to spend time optimizing. In this case, because these are Android base classes, I know I probably should spend my time elsewhere.

You can also use this tool to identify unused layouts (if you didn’t catch them earlier using Lint, described in

“Fixing Problems Using Lint” on page 218 ). Unused layouts in

your hierarchy are a common problem with potentially big performance impacts, as

each additional ViewGroup makes the measure pass described in “Two-pass layout” on page 201

take more time (and it’s already the bulk of the time required to render the screen). It is reasonably easy to identify unused layouts. In this case, there is one Line arLayout (in the middle towards the left) that doesn’t show any performance metrics

(there is just a blank space where the colored balls and timing information would be).

This indicates that it is not being rendered and should be removed.

216 | Chapter 13: Optimizing the User Interface

Figure 13-15. Hierarchy View: bad detail

Using the Tree tool to inspect the good UI

The performance indicators in the good UI look much better than the bad one in the

Tree View. Most of the indicators in

Figure 13-16 are green. The concentration of all

the red indicators on my single layout indicates that I don’t need to worry about them

—the tool has just identified that this path takes the most time to render, which is appropriate because it is the only path.

There are clearly no unused layouts, so that looks great as well. Overall, this layout is much better, which is easy to visualize using this tool.

Hierarchy Viewer | 217

Figure 13-16. Hierarchy View: good detail

Fixing Problems Using Lint

ADT includes a static code analysis tool designed to check source code for potential issues and identify optimization opportunities. It automatically analyzes source code for a variety of criteria. You have likely encountered it before, as it is involved in other aspects of Android development, including writing the business logic (Java classes).

Lint is launched by pressing the little red button on the far right of the Graphical Editor toolbar ( ), which we discussed in the previous chapter (

Chapter 12

). This number indicates the number of issues Lint has identified. Clicking it will launch the Lint tool

( Figure 13-17

). You can use this tool to organize and navigate to the various issues it identifies. When you click on an item, the bottom will show additional information about the issue (and offer suggestions about possible fixes).

218 | Chapter 13: Optimizing the User Interface

The right side provides a few buttons that allow you to take action on the item. You can opt to fix it, or if it isn’t important to your particular use case, you can tell the tool to ignore it. You can remove instances from the display, specifying whether you would like to remove just one instance (“Suppress Issue”), all instances in this file (“Suppress in

Layout”), or all instances in your entire project (“Disable Issue Type”).

Figure 13-17. Visual Editor using Lint

Application Exerciser Monkey

The Monkey is a tool you run on your device to generate a pseudorandom stream of user interactions and system-level events. It is used to stress-test applications by pro‐ viding a way to simulate lots of random interactions in a repeatable manner while col‐ lecting metrics about crashes or memory issues. This is a great way to test for user interactions that aren’t the “normal” ones that you expect (and are already testing for).

You can think of it as a tiny virtual primate, whose sole job is to punch and prod your application in an effort to break it.

Monkey runs on your device, which means we will use ADB (see

“Android Debug Bridge

(ADB)” on page 17 ) and shell commands to run it remotely. When starting it, you need

to provide your package name and the number of events you want to trigger. So if you wanted to run 500 events against the MyPackage app, the command would look like:

$

adb shell monkey -p com.foo.MyPackage 500

A real example of running this looks like:

Application Exerciser Monkey | 219

$ adb shell monkey -p com.tools.demo 500

// activityResuming(com.tools.demo)

// activityResuming(com.tools.demo)

Events injected: 500

## Network stats: elapsed time=36972ms (36972ms mobile, 0ms wifi,

0ms not connected)

$

When you run this test, you can watch your device or emulator. You will notice random elements of your UI being exercised as if an imaginary monkey were pressing on your app at random.

Grooming the Monkey

There are a variety of ways to customize the Hierarchy Viewer’s test and report. I will go through some of the most important ones in this section. You can see a complete list of all options by typing:

$

adb shell monkey --help

Letting the Monkey free

The Monkey starts in the default application of the package you specified, and by default is contained within that package. Any event that launches something external will be dropped. This is generally a desired behavior, but there might be times when you want to be able to launch other packages. This can be done by providing an additional package argument to the command:

$

adb shell monkey -p com.foo.MyPackage -p com.foo.MyPackage2 500

Specifying event types and frequency

It is possible to isolate the types of events that are triggered. You can specify the per‐ centage of a particular event that should be run. This is done with the event parameters.

So, for instance, if you want to ensure that 50 percent of the events are touch events (a down-up event in a single place on the screen), enter a command like:

$

adb shell monkey --pct-touch 50 -p com.foo.MyPackage 500

Verbosity level

Depending on your needs, you may want to get back different levels of information from a test run. It is possible to set the verbosity level to indicate how much information you wish to receive. There are three possible levels, based on how many v’s you set.

Putting a single v (the default) provides the least information—basically just informa‐ tion about startup, test completion, and final results. Putting vv will also output information during the test run. Lastly, entering vvv provides the most information, including details about activities selected or not selected for testing.

220 | Chapter 13: Optimizing the User Interface

If that isn’t enough information for you, you can also include the hprof argument on the command line. This will dump a large (~5MB) file that can be used by traceview (see

Chapter 10 ) for memory profiling.

So to see the most verbose output, enter:

$

adb shell monkey -vvv -hprof -p com.foo.MyPackage 500

Setting a seed value

A seed value allows you to generate the same set of random events over and over. This can be useful when you need to duplicate the same set of random events predictably to isolate a particular bug. If you rerun the Monkey with the same seed number, the same exact events will be executed in the same sequence. The seed can be any value, and determines where Monkey starts in its generation of pseudorandom events. So we could choose the seed number 334422 as follows:

$

adb shell monkey -seed 334422 -p com.foo.MyPackage 500

Monkeyrunner

This tool (which despite the similar name to the tool we just discussed is completely different) is designed to control an Android device from outside of code, simulating how a real user would interact. It provides an API so you can simulate user interactions by issuing commands through a script, or from the command line. This is a powerful tool for simulating and running a consistent set of UI interactions in a repeatable fashion.

The monkeyrunner tool is a Java program that can be found with the rest of the tools in the ${android.home}/tools folder. To run it, create a set of instructions you would like to simulate and feed to the tool. This is a scripted application, so we need to give the tool a list of commands in order for it to run. You can either type the commands one at a time in interactive mode or create a script to run a collection of commands together.

You can do a lot with monkeyrunner, which provides a robust automated tooling plat‐ form. This tool makes repeating a specific UI easy. This makes it easy to standardize functional tests, which can be run across a variety of devices.

Using Python to Create the Script

Rather than inventing a scripting language for this tool, the creators chose to use an existing language named Python. Python was the logical choice because it is very pow‐ erful and popular. It is a dynamic programming language that was designed to focus on creating clear, readable code that is modular and extensible. Python combines functional and object-oriented programming concepts to make it easy to express procedural pro‐ grams. It is beyond the scope of this book to explain the details of the Python language

Monkeyrunner | 221

but we can step through a simple monkeyrunner script to show how it can be used. Even if you don’t know Python, you should be able to follow along.

Let’s step through a simple example that shows how to install an application, launch an activity, take a screenshot of the menu options, and then store the screenshot for later review.

#menu_script.py

# Import the monkeyrunner modules we need from com.android.monkeyrunner

import MonkeyRunner

,

MonkeyDevice

# Connect to a device

device = MonkeyRunner .

waitForConnection ()

# Install an application to the device

device .

installPackage ( '../ToolsDemo.apk' )

# Run a component

device .

startActivity ( component = 'com.tools.demo/.MainActivity' )

# Press and hold the 'MENU' button

device .

press ( 'KEYCODE_MENU' , MonkeyDevice .

DOWN )

# Take a screenshot

screen1 = device .

takeSnapshot ()

# Store the screenshot to the filesystem

screen1 .

writeToFile ( 'screens/menu_buttons.png' , 'png' )

# Release the 'MENU' button

device .

press ( 'KEYCODE_MENU' , MonkeyDevice .

UP )

You can run this script by starting monkeyrunner from the command line with this script as a parameter:

$ {android.home}\tools\monkeyrunner menu_script.py

When you execute this command, you will be able to watch the actions you scripted on your device as they are happening.

Thanks for Reading!

Well, that’s the end of this chapter on UI performance, and the end of the book. With any technology that changes as rapidly as Android does, there will frequently be updates and new information. There’s a website with pointers on that at

http://www.mikewolf

son.com

. And finally, I’d like to thank you for choosing this book and reading it all the way to the end. In the final analysis, programmers don’t write books for fame or financial reward. We write them to share our hard-won knowledge and make the path of other programmers a little bit easier. I hope that this book fulfills that goal for you (and that you recommend it to all your developer friends!).

222 | Chapter 13: Optimizing the User Interface

Index

Symbols

*:s, silencing all other log messages, 98

A

accelerometer, SensorSimulator accelerometer example,

124

actions

Android Actions, in Android Studio default

toolbar, 75

common, in Android Studio, 76

Telephony Actions, Emulator Control tab,

118

activities

Activity option in Configuration Chooser,

198

Don’t keep activities option, 126

log messages on, 90

Activity Manager, 22

ActivityManager:* tag, 93

ADB (Android Debug Bridge), 17

– 24

functionality, additional, 22

issuing commands,

19

managing applications on a device,

19 transferring files, 19

querying for device instances, 18

directing command to specific device,

18 finding connected devices, 18

resetting the server,

23

resources for learning more about,

24

shell command,

20 –

22

interactive mode, 20

one-off mode,

21 retrieving system data, 21

using Activity Manager,

22

starting, 17

ADB driver, downloading, 7

adb logcat command,

97

ADB process, resetting from Devices tool,

50

ADT (Android Developer Tools), ix

, 5

ADT Preview Channel,

15

development process,

x

File Explorer, 50

Gradle integration, documentation on,

144

leveraging to build great UIs, 171

Lint, 107

requirements for, ix

ADT Template Format Documentation,

65

ADT website, x

Analyzer Tool,

153 –

155

running, 154

viewing results,

154

Android Attributes, getting information about,

106

android create avd command, 31

Android Debug Bridge (see ADB)

Android Debug Monitor,

152

Android Developer Tools (see ADT)

We’d like to hear your suggestions for improving our indexes. Send email to [email protected]

223

Android devices (see devices)

Android Document website,

7

Android key, 67

Android Manifest Editor,

65 tabs, 65

Android platforms

SDK component,

12

selecting and downloading packages for,

14

Android Plugin for NetBeans,

7

Android Software Development Kit (SDK)

bundled with Android Studio, 72

components, 11

installing,

3

– 5

extracting tools to Android home, 4

installing ADT Bundle, 3

setting PATH variable,

5

unzipping download artifact,

5

Android Studio,

6

, 71

– 88

anatomy of, 74

navigation,

76

panels, 74

status bar,

75

toolbars,

75

useful actions,

76

creating new Android components,

79

generating an APK, 82

installing,

72 bundled SDK, 72

default project location,

74

interacting with Gradle, 84

interacting with Maven, 83

Layout Designer,

80

Layout Preview, 81

migrating to, from Eclipse,

86

new structure for Android project, 77

refactoring and code generation, 87

running and debugging Android projects,

78

tips and tricks,

86

miscellaneous shortcuts, 87

refactoring and code generation short‐

cuts, 87

training resources, additional, 88

Version Control System (VCS) integrations,

85

android update project command, 135 ,

136

Android Virtual Devices (see AVDs)

Ant,

129

building from command line with,

133

– 138

building app to release to Play Store, 136

building in Debug mode,

136

more Ant commands,

138

setting up your project, 135

ant debug command, 136

ant release command,

137 ,

138

Apache Ant home page,

133

APKs (Android package files) generating in Android Studio,

82

packaging for release, 130 –

133

Asset Studio project, 187

Asset tool, 183

186

creating images, 184

selecting icon type,

184

AsyncTasks, monitoring with logcat,

95

attributes defined,

166

editing attribute values in XML files,

174

AVD Command Reference,

32

AVD Manager starting the emulator,

40

AVD launch options, 41

AVDs (Android Virtual Devices), 28

creating,

28

AVD Manager, 29

from command line,

31 location of AVD files, 31

emulator options,

32

setting up emulator using snapshots, 42

snapshots saved state,

45

starting the emulator from command line,

41

launch from snapshot, 46

B

boot animation, disabling on emulator,

37 ,

42

breakpoints

setting a debug point in source code, 99

setting debug points, 102

build file (Gradle),

147

build tools, 129 –

149

advanced packaging steps, 139 –

144

ProGuard,

139

– 144

Zipalign,

144

Android Studio interacting with Gradle,

84

Android Studio interacting with Maven,

83

building from command line using Ant,

133 –

138 additional Ant commands, 138

building app to release to Play Store,

136

224 | Index

building in Debug mode, 136

setting up your project,

135

compiling your code, 129

Gradle-based,

144

– 149

build file,

147

build tasks,

148

creating multiple build variations,

145

generating Gradle build from Eclipse,

148

installing Gradle,

144

Maven, 149

packaging APK for release, 130 –

133

signing your app, 130 –

133

build type (Gradle),

145

build variant (Gradle),

145

build.xml file (Ant), creating,

135

building Android apps from multiple source libraries,

135

steps in process,

134

C

canvas (Graphical Layout editor),

192

– 196

context-sensitive menu,

194

layout actions,

194

certificates, 130

code completion, XML editor, 173

Code Editor (Eclipse),

56

code examples from this book, xi

code generation and refactoring in Android

Studio, 87

code templates, 60

– 65

accessing menu in Eclipse, 60

creating Master/detail flow,

60 –

65

code template confirmation, 62

Master/detail wizard, 61

viewing results, 63

creating your own,

64

XML editor, 172

command line

building from, using Ant, 133 –

138

creating AVDs from,

31

draw9patch tool, 186

starting an emulator from, 41

using development tools from,

6

using lint from, 108

excluding issues, 109

compiling your code,

129

Configuration Chooser, 197

200

Preview all screens, 199 setting screen resolution, 199

configuration parameters for AVDs, 30

context-sensitive menu, Graphical Layout edi‐

tor, 194

context-specific options in Android Studio, 86

convention over configuration, 145

Create AVD wizard,

29

custom content entered in log statement, 91

D

Dalvik Compatible executables (DEX files), 129

Dalvik Debug Monitor Server (see DDMS)

DDMS (Dalvik Debug Monitor Server), 152 –

159

Analyzer Tool,

154

– 155

Heap tool,

156

launching DDMS perspective, 152

specifying location for emulator to simulate,

115

Threads tool,

155

Traceview tool,

158

– 159

DDMS perspective,

58

debug key, 130

Debug mode, 134

building in, using Ant,

136

Debug toolbar, Resume button,

104

Debug.dumpHprofData( ) method,

160

debuggable, setting app to,

99

debugging, 98

– 107

DDMS (Dalvik Debug Monitor Server),

152 –

159

Eclipse Debug Perspective, 100

enabled for testing apps on a phone,

7

example, 101

– 107

setting debug points,

102

starting the debugger, 103

stepping through the code, 104 –

107

launched from Devices tool,

49

setting app to debuggable,

99 setting debug point, 99

validating on phone, 7

dependencies defining project dependencies and target

API,

135

listing tasks and dependencies in Gradle,

148

managing for packages selected in SDK

Manager,

15

Developer Settings application, 126 –

127

Developer Tools application,

52

Index | 225

development tools (see tools)

development, configuring a device for, 7

Device Screen Capture (Devices tool),

50

devices

configuring for development, 7

querying for device instances in ADB, 18

directing command to specific device,

18 finding connected devices, 18

recording sensor interactions on physical de‐

vice, 125

using physical device for development, 25 capabilities and limitations, 25

configuring device for development,

26

devices command (ADB), 18

-s option, 18

Devices tool

Devices tab, 48

operations launched from devices tab, 49 physical device shown in, 49

tracking emulators or devices hooked to your computer,

48

documentation

Ant commands, 138

Gradle, 144

in Android SDK,

12

using alternative resources, 171

using NinePatchDrawables, 186 draw9patch command-line tool, 186

drawable documentation,

186

drivers,

12

Dump HPROF file button, 160

E

Eclipse IDE,

x ,

3 ,

55 –

70

Android Key,

67

Android Studio and,

71

Build Automatically setting, 129

code templates,

60 –

65

DDMS perspective, launching,

115

, 152

Debug Perspective,

100

developing without using,

6

generating Gradle build from,

148

Initial Hierarchy View perspective, 203

launching, 5

logcat viewer, 93

MAT, installing and launching,

160

moving to Android Studio from Eclipse, 86

other essential shortcuts, 69

properties editors,

65

Android Manifest Editor, 65

quick outline for XML or Java class,

68

69

Refactor menu,

70

running Lint, 110

Java and XML editor integration, 112

Lint Options dialog,

112

Lint toolbar menu,

111

Quick Fix tool, 113

starting SDK Manager, 13

starting the emulator,

40

workspace layout,

55 –

59

Code Editor,

56

Outline,

56

Package Explorer, 56

Problems tab, 57

Quick button, 59

uncovering additional tools and views,

57

– 59

XML formatter,

67

Editor Preferences menu (XML editor),

181

Emulator Documentation,

50

emulators, 39

advanced configuration,

33

dedicating core to emulator on Windows,

37 disabling boot animation, 37

using hardware acceleration,

33 –

37

Android Virtual Devices (see AVDs)

emulator application, 47

emulator options for AVDs, 32

keyboard shortcuts,

50

location simulation, 115 –

118

starting the emulator,

40

47

AVD launch options, 41

enabling options to launch from snap‐ shot,

46

from command line,

41

saving and retrieving a snapshot, 42

using AVD Manager,

40

using snapshots to improve performance,

42

tracking using Devices tool,

48

using for development,

26

supported and unsupported features, 27

events, simulating,

115

– 127

advanced sensor testing, 122 –

125

recording sensor scenarios, 124

SensorSimulator, supported sensors, 123

226 | Index

simulating sensor events in real time,

124

changing networking parameters, 121

location and routes,

115

telephony operations, 118 –

121

using Developer Settings application,

126

127

using device with sensor emulation, 122

example code in Android SDK,

12

Export wizard,

131

F

File Explorer, 50

files

File Actions in Android Studio,

75

transferring between your computer and de‐

vices, 19

filtering applying multiple filter expressions to logcat

command, 92

logcat output using custom tags, 98

logging output filter based on log tags, 92

logging output filter based on logging level,

91

flavor group (Gradle), 145

Force GPU Rendering option, 127

formatting

monitoring with logcat, 95

XML files, using XML editor,

178

G

garbage collection, 151

Google APIs (in Android SDK),

12

GPU rendering, forcing,

127

Gradle, 83 ,

129 ,

144

– 149

build file,

147

build tasks, 148

creating multiple build variations, 145

documentation, 144

generating Gradle build from Eclipse, 148

installing,

144

interacting with, using Android Studio,

84

key concepts and terms, 145

gradle command,

148

graphical editor, using, 189 –

200

canvas, 192 –

196

context-sensitive menu, 194

layout actions,

194

Configuration Chooser, 197 –

200

generating layouts with Graphical Layout editor,

189

Lint, 218

Outline view, 196

palette, 191

Properties editor, 196 –

197

graphics acceleration, starting emulator with,

42

graphics, working with, in Android UI,

183

– 187

Asset Studio website,

187

Asset tool, 183

using Nine-patch images, 186

H

Hardware Accelerated Execution Manager (In‐ tel HAXM),

33 –

37

benefits and limitations of, 33

configuring an AVD,

34 downloading components, 34 installing software, 34

validating that it’s running, 36

hardware capabilities, Android phones, ix

heap

Heap tool,

153

, 156

information displayed in 3 sections,

157

inspecting with Devices tool, 50

Hierarchy Viewer,

203

example, debugging a UI using, 208 –

218

different ways to design a UI,

208

getting timing information with Tree

View, 210

inspecting bad UI with Tree tool, 216

inspecting good UI with Tree tool, 217

reviewing structure with Tree Overview,

211

gathering view information,

205

identification and performance indica‐ tors,

206

measurement information,

206

gathering view rendering details,

207

loading view hierarchy into tools, 203 navigating tree hierarchy, 203 starting up, 203

Hierarchy Viewer perspective, 58

home directory, Android,

4

HPROF file,

159

analyzing using MAT,

161

Index | 227

I

IDEs (Integrated Development Environments),

x ,

1

(see also Android Studio; Eclipse IDE) developing without using,

6

Eclipse IDE or other IDE, 3

using IDE other than Eclipse, 6

install command (ADB),

19

J

Java

compiling your code, 129

Lint Quick Fix in, 114

Lint warnings in Java file, 112

signing APK with standard Java tools, 133

Java keystore, 131 –

133

JDK (Java Developer Kit),

2

JRE (Java Runtime Environment), 2

JSON parsing, monitoring with logcat, 95

JSON:* tag, 98

K

keyboard shortcuts

Android key,

67

Eclipse Quick Outline,

68

emulator, 50

in Android Studio, 76

, 86

miscellaneous shortcuts in Android Studio,

87

navigating within XML files, 68

other Eclipse shortcuts,

69

Quick Fix feature in Eclipse,

113

refactoring and code generation in Android

Studio,

87

setting breakpoints in code, 99

keystore

checking or validating in Build wizard, 133

creating in Build wizard, 132

password information, storing in Ant,

137

selection, in Build wizard, 132

signing app with custom keystore,

137

L

layout

Android, basic concepts,

165

defining layouts using XML, 166

defining layouts using XML/layout basics rendered,

168

leveraging ADT to build UIs, 171

resources, 170

Views and ViewGroups,

167

bad and good layouts for Android UI, 208

defined,

166

generating using Graphical Layout editor,

189 –

196

inserting new layouts into XML files,

173

nested layouts reducing performance, 202

two-pass layout process,

201

layout actions bar (Graphical Layout editor),

194

Layout Designer (Android Studio),

80

layout files,

166

Layout Preview (Android Studio), 81

Layout View (Hierarchy Viewer),

204

link suspects report (MAT),

162

Lint,

107

command-line usage, 108

--disable command as permanent,

109

--enable option, 109

excluding issues,

109

fixing UI performance problems, 218

listing issues currently enabled, using lint -list command,

107

running in Eclipse,

110

Java and XML editor integration, 112

Lint Options dialog,

112

Lint toolbar menu,

111

Quick Fix tool, 113

Linux

Android Framework and,

20

Android home directory, 4

keyboard shortcuts in Android Studio, 87

,

87

minimum requirements for Android devel‐

opment, 1

navigation shortcuts in Android Studio,

76

setting breakpoints, keyboard shortcut, 99

starting SDK Manager, 13

XML formatter,

67

localization,

198

locations, simulating, 115 –

118

log tags,

90

creating custom tags to represent logging

categories, 95

228 | Index

using in multiple filters on logcat command,

93

using to filter output,

92

logcat, 89

filtering output based on logging level, 91

filtering output using log tags,

92

filtering verbose system logs to find needed

information, 94

– 98

creating log statements,

95

determining areas to monitor,

95

filtering output,

98

verbose logging,

97

getting the most out of,

92

log messages,

89

logcat tool in Eclipse, 93 predefined output formats, 93

reading output, 90

viewing alternative log buffers, 93

viewing logcat file,

89

logging level, 90

example in testing of ActivityManager,

90

filtering based on,

91

M

Mac OS X, x

Android home directory,

4

minimum requirements for Android devel‐ opment,

1

navigation shortcuts in Android Studio, 76

setting breakpoints, keyboard shortcut,

99

starting SDK Manager,

13

XML formatter, 67

Manifest Editor, 65 tabs, 65

Master/detail flow, generating with code tem‐ plate,

60

– 65

MAT (Memory Analyzer Tool), 159 –

162

HPROF file,

160

installing into Eclipse,

160

launching from Eclipse,

160

Overview screen,

162

using to analyze HPROF files,

161

viewing a report,

162

MAT wizard, launching,

161

Maven,

129

interacting with, using Android Studio,

83

learning more about integration with An‐ droid,

149

memory

Analyzer Tool,

153

usage in Android,

151

Memory Analyzer Tool (see MAT) memory leaks,

151

monitoring system resources (see system re‐ sources, monitoring)

Monkey tool,

219

monkeyrunner, 221

N

navigation shortcuts in Android Studio, 76

NetBeans IDE,

7

network, monitoring with logcat,

95

NETWORK:* tag, 98

networking parameters, changing, simulation of,

121

Nine-Patch images,

186

Nurik, Roman, 65

O

obfuscation of code, with Proguard,

89

Openintents.org, SensorSimulator project,

122

operating systems

Android development on, x

minimum hardware requirements for An‐

droid development, 1

optimizing the UI (see UI, optimizing) orientation,

198

Outline view

in Eclipse, 56

in graphical editor,

196

OutOfMemory exception,

151

Overview screen (MAT),

162

P

Package Explorer (Eclipse), 56

packaging steps, advanced,

139

– 144

ProGuard, 139 –

144

Zipalign, 144

palette (Graphical Layout editor), 191

panels in Android Studio,

74

passwords

Graphical editor, password example, 192

keystore for app built in Ant, 137

PATH environment variable, 5

Index | 229

performance, UI, 201

(see also UI, performance) introduction to,

201

– 202

perspectives (Eclipse),

58

Pixel Perfect View, 58

Platform Tools, 12

Play Store building app in Ant to release to Play Store,

136

packaging an APK for release on,

130

– 133

Pointer Location, 126

port forwarding, 122

PowerManagerService:E tag, 93

Problems tab (Eclipse), 57

process ID of application originating log mes‐

sage, 90

product flavor (Gradle),

145

Profile panel (Traceview),

159

ProGuard tool,

89 ,

139

– 144

configuring,

140

– 142

enabling, 139

viewing obfuscated code, 142

project files, Android Studio, default location,

74

project.properties file, 135

projects

new file structure in Android Studio, 77

running and debugging in Android Studio,

78

properties editors,

65

Android Manifest Editor, 65

Properties editor in Graphical Layout editor,

196

– 197

push and pull commands (ADT), 19

Python, using to create monkeyrunner script,

222

Q

Quick button (Eclipse),

59

Quick Fix tool, Lint running in Eclipse,

113

Quick Outline for XML,

68

in Java class,

69

R

Refactor menu, 70

Extract Style, 70 renaming item IDs, 70

refactoring

in Android Studio, 87

Refactor menu of XML editor,

176

Release mode, 134

building in, using Ant,

136

Reset ADB (Devices tool), 50

resource files,

170

resource qualifiers, 167

modifying each independently,

200

resources,

151

, 170

(see also system resources, monitoring)

resource limitations for mobile apps, x

S

sample code in Android SDK, 12

scale factor (AVD launch option),

41

scenarios, recording sensor scenarios,

124

screen resolutions

setting in visual editor, 199

supporting multiple,

170

screens controlling screen size in visual editor,

198

multiple screen sizes for Android devices,

ix

Preview All Screens in graphical editor, 199

Show screen updates, Developer Options

menu, 126

SDK Manager, 11

– 17

ADT Preview Channel,

15

enabling,

15

installing Preview Tools,

16

reverting to released tools,

17

starting, 12

viewing installed and available components,

14

deleting and updating components,

15

installing packages,

14

managing dependencies,

15

selecting packages,

14

SDK option, Configuration Chooser, 198

SDK Tools, 12

SdkControllerSensor app, 122

secure.properties file, 137

self-signed certificates,

130

sensor emulation, using device with, 122

SensorRecordFromDevice.apk, 125

SensorSimulator, 122

accelerometer example,

124

recording sensor scenarios,

124

supported sensors, 123

230 | Index

Settings app

Developer Options, 126

enabling developer options, 52

USB Debugging, 7 ,

26

shell interface (ADB),

20

– 22

interactive mode, 20

one-off mode, 21 retrieving system data, 21

using Activity Manager,

22

Show screen updates, 126

signing apps,

130

– 133

simulating events (see events, simulating)

SMS messaging, simulating,

118 –

121

snapshots

AVD launch option,

41

AVD snapshots saved state,

45

using to improve emulator performance,

42

saving and retrieving a snapshot,

42

Software Development Kit (see Android Soft‐ ware Development Kit; entries beginning with SDK)

Sonatype, resources on Maven, 149

sourceset (Gradle),

145

stacktrace, 155

related to a single thread, 156

Strict Mode Enabled,

126

styles

defined, 166

Extract Style in Refactor menu, 70

syncing Gradle files with Android app,

85

system data, retrieving with ADB shell com‐ mand,

21

system resources, monitoring,

151

– 162

DDMS (Dalvik Debug Monitor Server),

152

– 159

MAT (Memory Analyzer Tool),

159

– 162

memory usage in Android,

151

T

tasks (Gradle), 145 ,

148

telephony operations, simulating, 118 –

121

testing code,

89 –

114

debugging, 98

– 107

Eclipse Debug Perspective, 100

example,

101

– 107

setting app to debuggable,

99 setting debug point, 99

filtering logging output based on logging

level, 91

filtering logging output on log tags, 92 getting the most out of logcat, 92

log messages, 89

logcat example, 94

– 98

creating log statements, 95 determining areas to monitor, 95

filtering logcat output, 98

verbose logging with logcat, 97

predefined output formats for log messages,

93

reading logcat output,

90

using Lint,

107

command-line usage,

108

running Lint in Eclipse, 110

using logcat viewer in Eclipse,

93

viewing alternative log buffers,

93

viewing logcat files, 89

themes, 166

Theme option in Configuration Chooser,

198

third-party add-ons, 12

Threads tool, 153 ,

155 running, 155

viewing thread information,

156

Timeline panel (Traceview), 158

toolbars in Android Studio, 75

tools

displaying additional tools in Eclipse, 57

essential,

11

ADB (Android Debug Bridge), 17

– 24

SDK Manager, 11 –

17

Traceview tool, 153 ,

158

– 159

output, Timeline panel,

158

Profile panel,

159

training resources for Android Studio,

88

Tree Overview (Hierarchy Viewer), 204

U

UI (user interface), 165 –

187

Android layout, basic concepts,

165

defining layouts with XML, 166

leveraging ADT to build UIs, 171

resources, 170

Views and ViewGroups,

167

designing using Graphical Layout tools,

189 –

200

editing XML files directly,

172

– 183

monitoring with logcat,

95

Index | 231

optimizing,

201

– 222

application exerciser Monkey,

219

debugging UI with Hierarchy Viewer,

208 –

218

fixing problems using Lint,

218

Hierarchy Viewer,

203

– 208

UI performance,

201

– 202

using monkeyrunner, 221

working with graphics,

183 –

187

Asset Studio,

187

Asset tool, 183 –

186 using Nine-patch images, 186

UI Thread, 155

UI:* tag,

93 ,

98

uninstall command (ADB), 20

USB Debugging

enabling on Android phone, 7

enabling on physical device,

26

USB drivers, 12

V

Version Control System (VCS) integrations with

Android Studio,

85

ViewGroups, 167

views adding to Eclipse layout,

58

drawing of Views and its effect on UI perfor‐ mance,

201

Views base class, Android layouts,

167

W

web page for this book, xii

widgets, 166

inserting into XML files, 173

Windows

Android home directory,

4

connecting Android-powered device for

testing with ADB driver, 7

dedicating a core to the emulator,

37

keyboard shortcuts in Android Studio, 87

minimum requirements for Android devel‐

opment, 1

navigation shortcuts in Android Studio,

76

setting breakpoints, keyboard shortcut, 99

starting SDK Manager, 12

Windows 7 64-bit OS, x

XML formatter,

67

X

XML automatically created by Android Studio

Layout Designer,

81

defining Android layouts, 166

editing XML files directly,

172

– 183

code completion, 173

editor preferences,

181

formatting, 178

inserting new layouts or widgets,

173

Refactor menu of XML editor, 176

using templates, 172

formatter,

67

layout editor in Android Studio Layout Pre‐

view, 81

Lint Quick Fix in,

113

Lint warnings in XML file, 112

quick outline for,

68

XML files editing directly

attribute values, 174

Z

Zipalign, 144

232 | Index

About the Author

Mike Wolfson is a passionate mobile designer/developer working out of Phoenix, AZ.

He has been in the software field for almost 20 years, and with Android since its intro‐ duction. Currently, he develops Android applications for the health care field. He has written a variety of successful apps, and is best known for the “Droid Of The Day” App.

Mike has spent his career helping others learn technology. He currently runs the local

Google Developer Group, and has been a lifelong supporter of a variety of other group learning activities. He has spoken about Android and mobile development at a variety of conferences and user groups.

When he is not geeking out about phones, he enjoys the outdoors (snowboarding, hik‐ ing, scuba diving), collecting PEZ dispensers, and chasing his young (but quick) daughter.

Colophon

The animal on the cover of Android Developer Tools Essentials is a cassowary (genus

Casuarius

), a large, flightless bird that is native to the rainforests of New Guinea and

Australia. This genus consists of three species: one is extinct and the rest are living but endangered. It is estimated that only 1,500 cassowaries exist in the entirety of Australia.

Like the ostrich and the emu, the cassowary is a ratite, or flightless bird. Although the three species of cassowary differ slightly in size, the Southern cassowary is the largest, with females reaching heights of six and a half feet. Despite their enormous size, cas‐ sowaries subsist mainly on fruits that have fallen from trees and will occasionally eat fungus or insects if necessary. They swallow their food whole, sometimes taking in entire bananas or mangos in one gulp.
