TREADMILL USER’S GUIDE
INTRODUCTION
IN T R O D U C T I O N
IMPORTANT
PRECAUTIONS
CONGRATULATIONS and THANK YOU for your purchase of this Freespirit treadmill!
ASSEMBLY
Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Freespirit treadmill can
help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics
and innovative features you need to get stronger and healthier, faster. Because we're committed to
designing fitness equipment from the inside out, we use only the highest quality components. It's a
commitment we back with one of the strongest frame-to-motor warranty packages in the industry.
You want exercise equipment that offers the most comfort, the best reliability and the highest quality
in its class.
BEFORE
YOU BEGIN
Freespirit Treadmils deliver.
Assembly
6
Before You Begin
13
Treadmill Operation
16
Conditioning Guidelines
27
Troubleshooting & Maintenance
35
Limited Warranty
38
Back Panel
LIMITED
WARRANTY
CONTACT INFORMATION
CONDITIONING
GUIDELINES
4
TROUBLESHOOTING
& MAINTENANCE
Important Precautions
TREADMILL
OPERATION
TABLE OF C O N T E N T S
INTRODUCTION
I M P O R TA N T PRECAUTIONS
SAVE THESE INSTRUCTIONS
IMPORTANT
PRECAUTIONS
Read all instructions before using this treadmill. When using an electrical product, basic precautions
should always be followed, including the following: Read all instructions before using this treadmill. It is the
responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings
and precautions. If you have any questions after reading this manual, contact Customer Tech Support at the
number listed on the back panel of this manual.
ASSEMBLY
WARNING
Connect this exercise product to a properly grounded outlet only. See grounding
instructions.
BEFORE
YOU BEGIN
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown, grounding provides a path
of least resistance for electrical current to reduce the risk of electrical shock. This product is equipped with
a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with local codes and ordinances.
TREADMILL
OPERATION
WARNING
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt
as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
This product is for use on a nominal 110-volt circuit
and has a grounding plug that looks like the illustration
to the right. This product must be used on a dedicated
circuit. To determine if you are on a dedicated circuit,
shut off the power to that circuit and observe if any other
devices lose power. If so, move devices to a different
circuit. Note: There are usually multiple outlets on one
circuit. It is recommended that the treadmill be used
with a 20 amp circuit for optimal performance.
LIMITED
WARRANTY
3-Pole Grounded Outlet
GROUNDED
TREADMILL
POWER CORD
INTRODUCTION
IMPORTANT
PRECAUTIONS
WARNING To reduce the risk of burns, fire, electrical shock or injury to persons:
TREADMILL
OPERATION
BEFORE
YOU BEGIN
ASSEMBLY
• Never use the treadmill before securing the safety tether clip to your clothing.
• If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness
of breath, stop exercising immediately and consult your physician before continuing.
• Do not wear clothes that might catch on any part of the treadmill.
• Always wear athletic shoes while using this equipment.
• Do not jump on the treadmill.
• Keep power cord away from heated surfaces.
• Do not insert or drop any object into any opening.
• Unplug treadmill before moving or cleaning it. To clean, wipe surfaces down with soap and slightly damp
cloth only; never use solvents. (See MAINTENANCE)
• At no time should more than one person be on treadmill while in operation.
• The treadmills should not be used by persons weighing more than 325 pounds. Failure to comply will
void the warranty.
• The treadmill is intended for in-home use only. Do not use this treadmill in any commercial, rental, school
or institutional setting. Failure to comply will void the warranty.
• Do not use treadmill in any location that is not temperature controlled, such as but not limited to garages,
porches, pool rooms, bathrooms, car ports or outdoors. Failure to comply may void the warranty.
• Use the treadmill only as described in this manual.
CONDITIONING
GUIDELINES
At NO time should pets or children under the age of 12 be closer to the treadmill than 10 feet.
At NO time should children under the age of 12 use the treadmill.
Children over the age of 12 should not use the treadmill without adult supervision.
other safety tips for your treadmill
TROUBLESHOOTING
& MAINTENANCE
To reduce the risk of damaging important components on your treadmill, it is strongly
recommended that your treadmill is plugged into a dedicated 20 amp circuit, without
the use of an additional extension cord and/or power strip. Failure to comply may void
the warranty.
IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets.
It is essential that your treadmill is used only indoors, in a climate controlled room. If your treadmill has been
exposed to colder temperatures or high moisture climates, it is strongly recommended that the treadmill is
warmed up to room temperature before first time use. Failure to do so may cause premature electronic failure.
LIMITED
WARRANTY
WARNING
OPERATION
INTRODUCTION
AS S E M B LY
IMPORTANT
PRECAUTIONS
IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE!
WARNING
ASSEMBLY
During the assembly process of the treadmill there are several areas that special attention must be paid.
It is very important to follow the assembly instructions correctly and to make sure all parts are firmly
tightened. If the assembly instructions are not followed correctly, the treadmill could have frame parts that
are not tightened and will seem loose and may cause irritating noises. There should be no side-to-side play
in the console masts or any forward and back play in the console assembly or handlebars. If there is any
play in these areas, the treadmill has not been properly assembled. To prevent damage to the treadmill, the
assembly instructions must be reviewed and corrective actions should be taken.
BEFORE
YOU BEGIN
UNPACKING
TREADMILL
OPERATION
Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on
your floor. Take CAUTION when handling and transporting this unit. Never open box when it is on its side.
Once the banding straps have been removed, do not lift or transport this unit unless it is fully assembled
and in the upright folded position, with the lock latch secure. Unpack the unit where it will be used. Never
grab hold of any portion of the incline frame and attempt to lift or move the treadmill. FAILURE TO FOLLOW
THESE INSTRUCTIONS COULD RESULT IN INJURY!
CONDITIONING
GUIDELINES
Before proceeding, find your treadmill’s serial number
and model name located under the deck on the frame
crossbar and enter it in the space provided below.
TROUBLESHOOTING
& MAINTENANCE
enter your serial number and
model name in the boxes below:
SERIAL NUMBER:
MODEL NAME:
LIMITED
WARRANTY
* Refer to the serial number and model name when calling for service.
* Also enter this serial number on your Warranty Card.
INTRODUCTION
DISPLAY AREA
12 MPH
11 MPH
10 MPH
9 MPH
NG
CKI
TRA
NCE
MA
FOR
PER
10%
9%
TCH
TOTAL
WEEKLY
TOTAL
MONTLY
TOTAL
LIFETIME
CLOCK
8 MPH
6 MPH
5 MPH
4 MPH
3 MPH
PAC E
CALO
RIES
/ PULS
E
TIME
PROG
ADJU ST
INCL INE
RAM SETT
INGS
EN
PRESS SET
TO
SPEED
TO BEGIN
PRESS
RT
S T A GRAM
2 MPH
1 MPH
SPEE
D
PRO
TER
+0. 5
SPEE D
8%
starting.
READING RACK
CONSOLE
7 MPH
SPEE D
E
DIST ANC
DATE
WORKOUT
CURRENT
OUT
GE WORK
AVERA
OUT
LAST WORK
11%
SWI
before
side rails from
on the
away
stand
injury,
Keep childen
To avoid operating. reach of children.
before
out of
before
store
!
to clothing all instructionsin use and
WARNINGsafety key clip Read and followkey when not
7%
SELE CT
6%
5%
SELE CT
4%
USER
(OPTION
PROG RAM
WEIGHT
LOSS
K
QUIC RT
STA
USER
PRESS
TO SET
E
INCLIN
3%
USE
P / P A ET
S T O HOLD TO RES
this
2%
WATER BOTTLE HOLDER
safety
Attach treadmill.
Remove
starting
this equipment.
5K
IN
MOUNTA
CLIMB
AL)
USER
using feel
!
if you
CAUTIONa physician before
exercising
Consult
Stop short of breath.
equipment. dizzy or
pain, faint,
1%
INCL
INE
+0. 5 NE
INCLI
HANDLEBAR EXTENTIONS
(CST 4.6 SHOWN)
IMPORTANT
PRECAUTIONS
GRIP PULSE HANDRAILS
12%
PR
TO
ESS
SAFETY KEY PLACEMENT
CONSOLE MAST
ON/OFF SWITCH
MOTOR COVER
ASSEMBLY
CIRCUIT BREAKER
RUNNING BELT / RUNNING DECK
POWER CORD
BEFORE
YOU BEGIN
SIDE RAIL
ROLLER END CAP
FOOT LOCK LATCH
REAR ROLLER
ADJUSTMENT BOLTS
TREADMILL
OPERATION
TOOLS INCLUDED
5 mm Allen Wrench
6 mm T-wrench
Screwdriver
CONDITIONING
GUIDELINES
PARTS INCLUDED
TROUBLESHOOTING
& MAINTENANCE
1 Safety Key
1 Console Assembly (located under treadmill deck)
1 Power Cord
4 Hardware Bags
2 Handlebar Extensions
2 End Caps
2 Console Masts
1 Heartrate Chest Strap
If you have questions or if there are any missing parts, contact Customer Tech Support.
contact information is located on the back panel of this manual.
LIMITED
WARRANTY
TRANSPORT WHEEL
INTRODUCTION
P R E - A S S E M B LY
Disassemble box and remove the cardboard packaging that is not beneath the treadmill. Do not attempt to
lift the treadmill at this time. Remove plastic wrap from console masts.
IMPORTANT
PRECAUTIONS
note: During each assembly step, ensure that ALL nuts and bolts are in place and partially threaded in before
completely tightening any ONE bolt. NOTE: A light application of grease may aid in the installation of hardware.
Any grease, such as lithium bike grease is recommended.
AS S E M B LY S T E P 1
ASSEMBLY
HARDWARE BAG 1 CONTENTS :
FLAT WASHER (B)
8 mm
Qty: 4
BOLT (A)
65 mm
Qty: 4
BEFORE
YOU BEGIN
LEAD WIRE
CONSOLE CABLE
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
A
Open HARDWARE BAG 1.
B
Pull LEAD WIRE through RIGHT
CONSOLE MAST to drag upward.
C
Place RIGHT CONSOLE MAST
into upright position using 2
BOLTS (A) and 2 WASHERS (B)
and tighten. Be sure to hold the
console mast firmly, as it will
not stay in the upright
position on its own.
D
Repeat on the left side. Note:
There is no wire in the LEFT
CONSOLE MAST.
FLAT WASHER (B)
BOLT (A)
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
INTRODUCTION
AS SEMBLY S T E P 2
IMPORTANT
PRECAUTIONS
NOTE: There is no hardware bag for this step.
A Lift the running deck until
lock latch on side of treadmill is
fully engaged.
ASSEMBLY
B Remove console from box
and place out of the way.
BEFORE
YOU BEGIN
Lower the treadmill running
C deck from the folded position
by stepping on LOCK LATCH on
the bottom left side of the deck.
3
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
TREADMILL
OPERATION
2
LIMITED
WARRANTY
1
INTRODUCTION
AS S E M B LY S T E P 3
HARDWARE BAG 3 CONTENTS :
IMPORTANT
PRECAUTIONS
SCREW (C)
12 mm
Qty: 2
ROLLER END CAP
ASSEMBLY
BEFORE
YOU BEGIN
MAIN FRAME
SCREW (C)
TREADMILL
OPERATION
A Open HARDWARE BAG 3.
B Slide left ROLLER END CAP onto MAIN FRAME and attach with SCREW (C).
C. Repeat on other side.
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
10
INTRODUCTION
ASSEMBLY S T E P 4
HARDWARE BAG 4 CONTENTS :
FLAT WASHER (E)
8 mm
Qty: 6
IMPORTANT
PRECAUTIONS
top view
BOLT (D)
15 mm
Qty: 6
A. Open HARDWARE BAG 4
ASSEMBLY
B. With running deck in lowered position,
place console on upright masts.
MAST
* Be sure to tighten bolts after all are lined up.
ASSEMBLED IN STEP 4-C
D. Gently lift right side of the console
to connect the console cable.
Carefully tuck wires in mast to avoid
damage. Note: Do not pinch console
cable. Be sure the console cable
prongs are aligned and the ends are
tightly seated into each other.
TREADMILL
OPERATION
FLAT WASHER (E)
BOLT (D)
E. Repeat step C above to assemble the
right side upright mast and console.
CONDITIONING
GUIDELINES
BOLT (F)
BEFORE
YOU BEGIN
C. Secure console by partially inserting
3 bolts (D) and 3 FLAT WASHERS
(E) into side of left upright mast.
Remember to partially install
these bolts.
F. Tighten all bolts completely.*
G. Once BOLTS (D) have been
TROUBLESHOOTING
& MAINTENANCE
completely tightened, insert BOLTS
(F) into the back of the mast and
completely tighten.
* Note: Be careful not to pinch any
wires while assembling the masts.
11
LIMITED
WARRANTY
top view
BOLT (F)
25 mm
Qty: 2
Qty: 4
INTRODUCTION
top view
ASSE M B LY S T E P 5
HARDWARE BAG 5 CONTENTS FOR CST3.6:
HARDWARE BAG 5 CONTENTS FOR CST4.6:
IMPORTANT
PRECAUTIONS
ARC
WASHER (H)
Qty: 2
BOLT (G)
12 mm
Qty: 2
BOLT (G)
12 mm
Qty: 4
top view
BOLT (I)
115 mm
Qty: 2
top view
12 MPH
11 MPH
10 MPH
9 MPH
NG
CKI
TRA
CST4.6
CST3.6
PRE
E
NC
MA
FOR
PER
12%
10%
ASSEMBLY
9%
INC LIN
TO
SWI
TCH
CLOC
K
8 MPH
7 MPH
CAL ORI
ES / PUL
4 MPH
3 MPH
SE
TIM E
ADJU
GRA
ST PRO
7%
SELE CT
6%
SELE CT
BOLT (G)
12 mm
Qty: 2
ARC
WASHER (H)
Qty: 2
PRESS
TO SET
INCLINE
3%
USE R
(OPTIO
PRO GRA
M
TAIN
MOUN
CLIMB
T
WEIGH
LOSS
5K
NAL)
K
QUIC RT
STA
USER
USER
M SETT
IN
TO BEG
PRESS
RT
S T A GRAM
INGS
ENT
PRESS SET
TO
SPEED
2 MPH
1 MPH
SPEE
D
PRO
ER
+0 .5
SPEE D
before
side rails from
on the
away
stand
injury, . Keep childenchildren.
of
To avoid
of reach
starting. ns before operating
before
store out
G!
to clothing all instructio in use and
WARNINsafety key clip. Read and followkey when not
safety
Attach treadmill
t. Remove
starting
this equipmen
8%
4%
5 MPH
CE
PAC E
E
5%
6 MPH
SPE ED
DIS TAN
DATE
WORKOUT
CURRENT
WORKOUT
AVERAGE
KOUT
LAST WOR
11%
SS
TOTAL
WEEKLY
TOTAL
MONTLY
TOTAL
LIFETIME
USE
P / P A ET
S T O HOLD TO RES
this
2%
using feel
N!
if you
CAUTIO a physician before
exercising
Consult t. Stop short of breath.
equipmen dizzy or
pain, faint,
1%
INCL
INE
+0 .5
INCL INE
top view
BOLT (I)
115 mmFRAME
CONSOLE
BEFORE
YOU BEGIN
CONSOLE FRAME
HANDLEBAR EXTENSION
Qty: 2
BOLT (G)
HANDLEBAR EXTENSION
BOLT (G)
BOLT (I)
ARC WASHER (H)
TREADMILL
OPERATION
A Open HARDWARE BAG 5.
B Slide left HANDLEBAR EXTENSION onto CONSOLE FRAME. Attach using BOLT (G).
CONDITIONING
GUIDELINES
C Connect bottom of HANDLEBAR EXTENSION to the CONSOLE MAST using 2 BOLTS (I) and
2 ARC WASHERS (H). Note: CST3.6 skips this step.
TROUBLESHOOTING
& MAINTENANCE
E. Connect power plug to the treadmill and connect the cord to a power outlet. The on/off switch
is located next to the power cord. Flip this switch to the 'ON' position, so that the switch is lit.
You will hear a beep and the console will light up.
D Repeat on other side.
LIMITED
WARRANTY
YO U ’ R E F I N I S H E D !
12
INTRODUCTION
BEFORE YOU BEGIN
IMPORTANT
PRECAUTIONS
CONGRATULATIONS! on choosing your treadmill. You’ve taken an important step in developing and
sustaining an exercise program! Your treadmill is a tremendously effective tool for achieving your personal
fitness goals. Regular use of your treadmill can improve the quality of your life in so many ways.
Here are just a few of the health benefits of exercise:
ASSEMBLY
• Weight Loss
• A Healthier Heart
• Improved Muscle Tone
• Increased Daily Energy Levels
LOCATION OF THE TREADMILL
1 foot
3 feet
3 feet
TREADMILL
OPERATION
Place the treadmill on a level surface. There should be 6 feet of clearance
behind the treadmill, 3 feet on each side and one foot in front for folding
and the power cord. Do not place the treadmill in any area that will block
any vent or air openings. The treadmill should not be located in a garage,
covered patio, near water or outdoors.
BEFORE
YOU BEGIN
The key to reaping these benefits is to develop an exercise habit. Your new treadmill will help you eliminate
obstacles that prevent you from exercising. Inclement weather and darkness won't interfere with your
workout when you use your treadmill in the comfort of your home. This guide provides you with basic
information for using and enjoying your new machine.
6 feet
TROUBLESHOOTING
& MAINTENANCE
While you are preparing to use the treadmill, do not stand on the belt.
Place your feet on the side rails before starting the treadmill. Start
walking on the belt only after the belt has begun to move. Never start the
treadmill at a fast running speed and attempt to jump on!
SAFETY KEY
Your treadmill will not start unless the safety key is placed in position. Attach the clip end securely to your
clothing. This safety key is designed to cut the power to the treadmill if you should fall. Check the operation
of the safety key every 2 weeks.
WARNING
NEVER USE THE TREADMILL WITHOUT SECURING THE SAFETY KEY CLIP TO YOUR
CLOTHING. PULL ON THE SAFETY KEY CLIP FIRST TO MAKE SURE IT WILL NOT
COME OFF YOUR CLOTHING.
13
LIMITED
WARRANTY
DO NOT STAND ON THE BELT
CONDITIONING
GUIDELINES
WARNING
INTRODUCTION
PROPER USAGE
IMPORTANT
PRECAUTIONS
Your treadmill is capable of reaching high speeds. Always start off using a slower speed and adjust the speed in
small increments to reach a higher speed level. Never leave the treadmill unattended while it is running. When
not in use, remove the safety key, turn the on/off switch to off and unplug the power cord. Make sure to follow
the MAINTENANCE schedule in this manual. Keep your body and head facing forward. Do not attempt to turn
around or look backwards while the treadmill is running. Stop your workout immediately if you feel pain, faint,
dizzy or are short of breath.
ASSEMBLY
WARNING
Do not operate the treadmill if the power cord or plug is damaged.
If the treadmill appears to not be working properly, do not use the treadmill.
FOLDING
BEFORE
YOU BEGIN
Firmly grasp the back end of the treadmill. Carefully
lift the end of the treadmill deck into the upright
position until the foot lock latch engages and
securely locks the deck into position. Make sure the
deck is securely latched before letting go. To unfold,
firmly grasp the back end of the treadmill. Gently
press down on the foot lock latch with your foot until
the lock latch disengages. Carefully lower the deck
to the ground. NOTE: The foot lock latch is located
on the bottom left side of the deck.
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
MOVING
Your treadmill has a pair of transport wheels built
into the frame. To move, make sure the treadmill is
folded and securely latched. Then firmly grasp the
handlebars, tilt the treadmill back and roll.
TROUBLESHOOTING
& MAINTENANCE
WARNING
LIMITED
WARRANTY
14
Our Treadmills are heavy, use care and additional help if necessary when moving.
Do not attempt to move or transport treadmill unless it is in the upright, folded
position with the lock latch secured. Failure to follow these instructions could
result in injury.
INTRODUCTION
­TENSIONING THE RUNNING BELT
IMPORTANT
PRECAUTIONS
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment.
BEFORE
YOU BEGIN
CENTERING THE RUNNING BELT
The running belt has been properly adjusted at the
factory before it was shipped. At times the belt can
move off-center during shipment. Before operating the
treadmill, make sure the belt is centered and remains
centered to maintain smooth operation.
TREADMILL
OPERATION
If you can feel a slipping sensation when running on the
treadmill, the running belt must be tightened. In most
cases, the belt has stretched from use, causing the
belt to slip. This is a normal and common adjustment.
To eliminate this slipping, turn the treadmill off
and tension both the rear roller bolts using the
supplied Allen wrench, turning them 1/4 TURN to the
right as shown. Turn the treadmill on and check for
slipping. Repeat if necessary, but NEVER TURN the
roller bolts more than 1/4 turn at a time. Belt is properly
tensioned when the slipping sensation is gone.
ASSEMBLY
CAUTION: Running belt should NOT be moving during
tensioning. Over-tightening the running belt can
cause excessive wear on the treadmill as well as its
components. Never over-tighten the belt.
CAUTION: Do not run belt faster than 1/2 mph while
centering. Keep fingers, hair and clothing away from
belt at all times.
If the running belt is too far to the right side:
CONDITIONING
GUIDELINES
With the treadmill running at 1/2 mph, turn the right
adjustment bolt clockwise 1/4 turn at a time (using
the supplied Allen wrench). Check the belt alignment.
Allow belt to run a full cycle to gauge if more adjustment
is needed. Repeat if necessary, until the belt remains
centered during use.
Belt is too far to the left side
TROUBLESHOOTING
& MAINTENANCE
If the running belt is too far to the left side:
With the treadmill running at 1/2 mph, turn the right
adjustment bolt counter-clockwise 1/4 turn at a time
(using the supplied Allen wrench). Check the belt
alignment. Allow belt to run a full cycle to gauge if more
adjustment is needed. Repeat if necessary, until the
belt remains centered during use.
15
LIMITED
WARRANTY
Belt is too far to the right side
INTRODUCTION
TR E A D M I L L O PERATION
L
M
W
C
D
A
B
Q
P
IMPORTANT
PRECAUTIONS
12 M PH
12%
P E R F O R M A N C E
11%
T R A C K I N G
PRESS
10%
T O
CURRENT WORKOUT
10 M PH
WEEKLY TOTAL
AVERAGE WORKOUT
9%
11 M PH
S W ITCH
CL O C K
DATE
LAST WORKOUT
MONTLY TOTAL
9 M PH
LIFETIME TOTAL
8 M PH
8%
I NC LINE
7%
TIME
CALO R I ES / PULSE
PA CE
DISTA NCE
SP EE D
7 M PH
6 M PH
6%
5 MPH
5%
4 MPH
ASSEMBLY
4%
3%
PRESS
TO SET
INCLINE
2%
SELECT USER (OPTIONAL)
USER
SELECT PROGRAM
USER
ADJUST PROGRAM SETTINGS
MOUNTAIN
CLIMB
WEIGHT
LOSS
S TA RT
ENTER
5K
PRESS TO BEGIN
PROGRAM
3 MPH
PRESS
TO SET
SPEED
2 MPH
1 MPH
1%
SPEED
INCLINE
QUICK
START
CAUTION!
+0.
Consult a physician before using this
equipment. Stop exercising if you feel
pain, faint, dizzy or short of breath.
INCLIN E
STOP/PAUSE
WARNING!
Attach safety key clip to clothing before starting. To avoid injury, stand on the side rails before
starting treadmill. Read and follow all instructions before operating. Keep childen away from
this equipment. Remove safety key when not in use and store out of reach of children.
HOLD TO RESET
+0.5
SPEED
BEFORE
YOU BEGIN
N
O
G
U
H
E
T
F
I
J
K
S
R
TREADMILL
OPERATION
Note: A thin protective sheet of clear plastic is on the overlay of the console and should be removed.
A) eTRak™ button: Used to scroll through eTRAK™ display modes.
B) etrak™ DISPLAY MODEs: Light indicates active eTRAK™ display mode (CST3.6 has fewer modes).
CONDITIONING
GUIDELINES
C) lEd displays: Incline, Time, Calories, Pulse, Pace, Distance, Speed, Date, and Clock (Pace, Date, and Clock on
CST4.6 only).
D) Monitor Display: Shows Program Profiles.
e) QUICK sTART: Simply press to begin exercising.
TROUBLESHOOTING
& MAINTENANCE
f) STOP: Press to pause/end your workout. Hold for 3 seconds to reset the treadmill.
g) USER keys: Press to select user (CST4.6 only).
h) Quick program keys: Press to select program. Press enter to confirm selection.
i) program setting keys: Press to adjust Time, Incline, Speed, and Level.
j) enter: Press to set Time, Incline, Speed, and Level.
k) start program: Press to begin program.
LIMITED
WARRANTY
L) Quick INCLINE KEYS: Press to reach desired incline more quickly. Select before pressing SET INCLINE key.
16
INTRODUCTION
n) incline arrow keys: Press to adjust incline (0.25% increments).
o) +0.5 INCLINE: Press to increase incline by 0.5%.
IMPORTANT
PRECAUTIONS
P) quick speed KEYS: Press to reach desired speed more quickly. Select before pressing SET SPEED key.
Q) Set speed: Press to accept speed selected with quick speed keys.
R) speed arrow keys: Press to adjust speed (0.1mph increments).
S) +0.5 speed: Press to increase speed by 0.5%.
ASSEMBLY
T) safety key position: Enables treadmill operation when safety key is in place.
U) WATER BOTTLE / Cd / MP3 HOLDER: Holds personal workout equipment.
V) TRIP (not shown): Functions similar to a vehicle trip odometer. Hold for 5 seconds to reset trip (CST3.6 only).
W) READING RACK: Holds reading material.
CLOCK
TREADMILL
OPERATION
DATE
BEFORE
YOU BEGIN
MONITOR D I S P L AY
date • Date format is month: day (CST4.6 only).
/ PULSE
CE (speed during speed based DISTANCE
PAused
CALORIES
program profiles
• Represents
the profile of the program being
CONDITIONING
GUIDELINES
programs and incline during incline based programs).
TROUBLESHOOTING
& MAINTENANCE
clock • The clock displays the time in the 12-hour system (CST4.6 only).
17
LIMITED
WARRANTY
ME
M) Set incline: Press to accept incline selected with quick incline keys.
INTRODUCTION
TIME
INCLINE
CALORIES / PULSE
IMPORTANT
PRECAUTIONS
incline • Shown as Percent. Indicates the incline of your walking or running surface.
time • Shown as Minutes:Seconds. View the time remaining or the time elapsed in your workout.
ASSEMBLY
Calories • Total Calories burned during your workout.
CLOCK
pulse • Shown as Beats Per Minute. Used to monitor your heart rate (displayed when contact is made with
both pulse grips).
BEFORE
YOU BEGIN
PULSE
PA CE
DISTANCE
SPEE D
TREADMILL
OPERATION
PACE • Shown as Minutes. Tenths of a Minute. Indicates the time to run a mile at the current speed
(CST4.6 only).
distance • Shown as Miles. Indicates distance traveled during your workout.
CONDITIONING
GUIDELINES
speed • Shown as MPH. Indicates how fast your walking or running surface is moving.
TROUBLESHOOTING
& MAINTENANCE
HE A R T R AT E
PULSE GRIPS
LIMITED
WARRANTY
Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip the bars for your
heart rate to register. It takes 5 consecutive heart beats (15-20 seconds) for your heart rate to register. When
gripping the pulse handlebars, do not grip tightly. Holding the grips tightly may elevate your blood pressure.
Keep a loose, cupping hold. You may experience an erratic readout if consistently holding the grip pulse
handlebars. Make sure to clean the pulse sensors to ensure proper contact can be maintained.
18
INTRODUCTION
GETTING S TA R T E D / S E L E C T I N G A P R O G R A M
IMPORTANT
PRECAUTIONS
1) Check to make sure nothing is on or will hinder the movement of the treadmill.
2) Plug in the power cord and turn the treadmill ON.
3) Stand on the side rails of the treadmill.
4) Attach the safety key clip to part of your clothing.
ASSEMBLY
5) Insert the safety key into the safety keyhole in the console.
6) You have two options to start your workout:
A) quick start up
Simply press the start key to begin working out. OR...
BEFORE
YOU BEGIN
B) SELECT A PROgram
Select a Program using the program +/- or QUICK PROGRAM keys.
Once a program has been chosen, press enter.
SELECT A LEVEL
TREADMILL
OPERATION
Select a program level using the program +/- keys.
Once a program level has been chosen, press enter.
SELECT A TIME
Select a Time using the program +/- keys or use the default time.
Once a time has been chosen, press Start.
finishing YOUR WORKOUT
CONDITIONING
GUIDELINES
When your workout is complete, the monitor display will flash and beep. Your workout information will stay
displayed on the console for 30 seconds and then reset.
CLEAR CURRENT SELECTION
19
LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
To clear the current program selection or screen, hold the Stop button for 4-5 seconds.
INTRODUCTION
PR O G R A M I N F O R M AT I O N
IMPORTANT
PRECAUTIONS
PMANUAL
ROGRAM: MANUAL
Allows ‘On TheINTERVALS
Fly’ manual speed and incline changes. Time-based goal.
MANUAL
ROLLING
INTERVALS
PWEIGHT
R OLOSSG R A M : I N T E R VA L S
ASSEMBLY
Walk or run a GOLF
series
of alternating speed levels. Time-based goal with 10 difficulty levels to choose from.
ROLLING
COURSE
INTERVALS Program Segments
WEIGHT LOSS
RACE
(peak segments last 30 seconds, valley segments last 90 seconds)
1
2
3
4
1.0
1.5
2.0
4.0
2.0
4.0
WARM-UP
Level 2
1.0
1.5
2.0
4.5
2.0
4.5
CUSTOM 2 Level 3
1.3
1.9
2.5
5.0
2.5
5.0
Level 4
CUSTOM 1
Level 5
THR ZONE 1
Level 6
1.3
1.9
2.5
5.5
2.5
5.5
1.5
2.3
3.0
6.0
3.0
6.0
1.5
2.3
3.0
6.5
3.0
6.5
CUSTOM 2Level 7
THR ZONE 2Level 8
1.8
2.6
3.5
7.0
3.5
7.0
1.8
2.6
3.5
7.5
3.5
7.5
Level 9
THR ZONE 1
VALLEY Level 10
2.0
3.0
4.0
8.0
4.0
8.0
2.0
3.0
4.0
8.5
4.0
8.5
BEFORE
YOU BEGIN
RACE
TREADMILL
OPERATION
MANUAL
THR ZONE 2
TOUR
INTERVALS
PEAK
VALLEY
INTERVALS
COOL DOWN
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
GOLF COURSE
MPH
CUSTOM 1
Level 1
1.5
1.0
1.5
1.0
1.9
1.3
1.9
1.3
2.3
1.5
2.3
1.5
2.6
1.8
2.6
1.8
3.0
2.0
3.0
2.0
(warm-up and cool-down last 4:00 minutes each and are included in program times)
CONDITIONING
GUIDELINES
PROLLING
ROGRAM: ROLLING HILLS
MOUNTAIN
TOUR
CLIMB
Motivates withWEIGHT
different
LOSS combinations of speed. Time-based goal with 10 difficulty levels to choose from.
PEAK
INTERVALS
2
3
4
5
6
7
8
1.0
RACE
1.3
1.5
2.0
2.5
3.0
3.5
4.0
3.5
3.0
2.5
1.9
2.5
3.0
3.5
4.0
4.5
4.0
3.5
3.0
2.3
3.0
3.5
4.0
4.5
5.0
4.5
4.0
3.5
Level 4
1.5
CUSTOM 1
1.8
2.6
3.5
4.0
4.5
5.0
5.5
5.0
4.5
4.0
Level 5
2.0
3.0
4.0
4.5
5.0
5.5
6.0
5.5
5.0
4.5
Level 6
2.3 2
CUSTOM
2.5
3.4
4.5
5.0
5.5
6.0
6.5
6.0
5.5
5.0
3.8
5.0
5.5
6.0
6.5
7.0
6.5
6.0
5.5
2.8
4.1
THR ZONE 1
3.0
4.5
5.5
6.0
6.5
7.0
7.5
7.0
6.5
6.0
6.0
6.5
7.0
7.5
8.0
7.5
7.0
6.5
6.5
7.5
7.5
8.0
8.5
8.0
7.5
7.0
Level 1
TROUBLESHOOTING
& MAINTENANCE
Level 2
Level 3
Level 7
Level 8
Level 9
LIMITED
WARRANTY
Level 10
3.3
THR ZONE 2
20
Program Segments (all segments last 30 seconds)
VALLEY
TOUR
4.9
(warm-up and cool-down last 4:00 minutes each and are included in program times)
SEGMENTS ARE REPEATED UNTIL SELECTED
TIME IS REACHED
MPH
GOLF COURSE ROLLING
MOUNTAIN
WARM-UP
1
CLIMB
COOL-DOWN
2.3
1.5
2.6
1.8
3.0
2.0
3.4
2.3
3.8
2.5
4.1
2.8
4.5
3.0
4.9
3.3
5.3
3.5
5.6
3.8
INTRODUCTION
TOUR
PEAK
INTERVALS
MOUNTAIN
PROG
R A M : M O U N TA I N C L I M B
CLIMB
1
2
3
4
5
6
7
8
9
10
WARM -UP 1
2
3
4
5
6
7
8
9
10
COOL-DOWN
Incline
0.0
0.0
1.0
1.5
2.0
2.5
3.0
3.0
2.5
2.0
1.5
1.0
0.0
0.0
0.0
0.0
1.5
2.0
2.5
3.0
3.5
3.5
3.0
2.5
2.0
1.5
0.0
0.0
0.0
1.0
2.0
2.5
3.0
3.5
4.0
4.0
3.5
3.0
2.5
2.0
1.0
0.0
0.0
1.5
2.5
3.0
3.5
4.0
4.5
4.5
4.0
3.5
3.0
2.5
1.5
0.0
0.0
1.5
3.0
3.5
4.0
4.5
5.0
5.0
4.5
4.0
3.5
3.0
1.5
0.0
0.0
1.5
3.5
4.0
4.5
5.0
5.5
5.5
5.0
4.5
4.0
3.5
1.5
0.0
0.0
1.5
4.0
4.5
5.0
5.5
6.0
6.0
5.5
5.0
4.5
4.0
1.5
0.0
0.0
2.0
4.5
5.0
5.5
6.0
6.5
6.5
6.0
5.5
5.0
4.5
2.0
0.0
0.0
2.0
MANUAL 2.0
0.0
5.0
5.5
6.0
6.5
7.0
7.0
6.5
6.0
5.5
5.0
2.0
0.0
5.5
6.0
6.5
7.0
7.5
7.5
7.0
6.5
6.0
5.5
2.0
0.0
ASSEMBLY
Level
IMPORTANT
PRECAUTIONS
Simulates climbing and descending a mountain by automatically varying incline. 10 difficulty levels to
choose from.
(warm-up and cool-down last 4:00 minutes each and are included in program times)
BEFORE
YOU BEGIN
INTERVALS
ROLLING
WEIGHT LOSS R A M : W E I G H T L O S S
PROG
Level 4
Level 5
Level 6
Level 7
Level 8
Level 9
Level 10
4
5
6
7
8
COOL-DOWN
Elevation
0.0
CUSTOM 1 1.0
Speed
0.5
1.5
1.5
1.0
0.5
0.5
0.5
1.0
1.5
0.5
0.0
1.5
2.0
2.5
3.0
3.5
4.0
3.5
3.0
2.5
2.3
1.5
Elevation
0.5
0.0
2.6
1.8
1.0
0.5
3.0
2.0
1.0
0.5
3.4
2.3
1.5
1.0
3.8
2.5
1.5
1.0
4.1
2.8
2.0
1.5
4.5
3.0
2.0
1.5
4.9
3.3
0.0
0.5
1.5
1.5
1.0
0.5
1.0
0.5
1.0
1.5
Speed
CUSTOM 2 1.3
Elevation
0.5
1.9
2.5
3.0
3.5
4.0
4.5
4.0
3.5
3.0
1.0
2.0
2.0
1.5
1.0
1.0
1.0
1.5
2.0
Speed
1.5
THR
ZONE
1
Elevation
0.5
2.3
3.0
3.5
4.0
4.5
5.0
4.5
4.0
3.5
1.0
2.0
2.0
1.5
1.0
1.0
1.0
1.5
2.0
1.8
2.6
3.5
4.5
4.5
5.0
5.5
5.0
4.5
4.5
THR ZONE 1.5
2
Elevation
Speed
1.5
2.5
2.5
2.0
1.5
1.5
1.5
2.0
2.5
2.0
3.0
4.0
4.5
5.0
5.5
6.0
5.5
5.0
4.5
1.5
1.5
2.5
2.5
2.0
1.5
1.5
1.5
2.0
2.5
2.3
3.4
4.5
5.0
5.5
6.0
6.5
6.0
5.5
5.0
Elevation
1.5
TOUR
Speed
2.5
PEAK
Elevation
1.5
INTERVALS
Speed
2.8
2.0
3.0
3.0
2.5
2.0
2.0
2.0
2.5
3.0
3.8
5.0
5.5
6.0
6.5
7.5
6.5
6.0
5.5
2.0
3.0
3.0
2.5
2.0
2.0
2.0
2.5
3.0
4.1
5.5
6.0
6.5
7.0
7.5
7.0
6.5
6.0
MOUNTAIN2.0
Elevation
CLIMB
Speed
3.0
2.5
3.5
3.5
3.0
2.5
2.5
2.5
3.0
3.5
2.5
2.0
4.5
6.0
6.5
7.0
7.5
8.0
7.5
7.0
6.5
5.3
3.5
Elevation
2.0
2.5
3.5
3.5
3.0
2.5
2.5
2.5
3.0
3.5
2.5
2.0
Speed
3.3
4.9
6.5
7.0
7.5
8.0
8.5
8.5
7.5
7.0
5.6
3.8
Speed
Elevation
VALLEY
Speed
CONDITIONING
GUIDELINES
Level 3
3
TROUBLESHOOTING
& MAINTENANCE
Level 2
2
SEGMENTS ARE REPEATED UNTIL SELECTED TIME IS REACHED
Level 1
1
(warm-up and cool-down last 4:00 minutes each and are included in program times)
21
LIMITED
WARRANTY
WARM-UP
TREADMILL
OPERATION
Challenges with
various combinations of hills and valleys (incline & SPEED levels). Time-based goal with 10
GOLF COURSE
difficulty levels to choose from.
WEIGHT LOSS Program Segments (all segments last 30 seconds)
RACE
INTRODUCTION
WEIGHT LOSS
GOLF COURSE
PRACE
R O G R A M : 5k ( C S T 4 . 6 o n l y )
IMPORTANT
PRECAUTIONS
Walk a series of
alternating
INCLINE levels. Distance based goal with 10 difficulty levels to choose from.
CUSTOM
1
Segments equal 0.16 km
Level
Segments 1-15 repeated until selected distance is reached.
CUSTOM 2
Warm Up
1
ASSEMBLY
BEFORE
YOU BEGIN
1
0.0
0.5
2
0.0
0.5
3
0.5
1.0
4
0.5
1.0
5
1.0
1.5
6
1.0
1.5
7
1.5
2.0
8
1.5
2.0
9
2.0
2.5
10
2.0
2.5
2
Cool Down
3
4
5
6
7
8
9
10
11
12
13
14
15
1.0
3.0
THR ZONE 1
1.0
MANUAL3.0
1.0
3.0
2.0
3.0
2.0
3.5
2.0
3.0
2.0
3.0
1.0
3.0
1.0
0.5
0.0
2.0
3.0
2.0
3.0
2.5
3.5
2.5
3.0
2.0
3.0
2.0
3.0
1.0
0.5
0.0
1.5
3.5
THR ZONE 2
INTERVALS
1.5
3.5
1.5
3.5
2.5
3.5
2.5
4.0
2.5
3.5
2.5
3.5
1.5
3.5
1.5
1.0
0.5
2.5
3.5
2.5
3.5
3.0
4.0
3.0
3.5
2.5
3.5
2.5
3.5
1.5
1.0
0.5
2.0
4.0
VALLEY
ROLLING4.0
2.0
2.0
4.0
3.0
4.0
3.0
4.5
3.0
4.0
3.0
4.0
2.0
4.0
2.0
1.5
1.0
3.0
4.0
3.0
4.0
3.5
4.5
3.5
4.0
3.0
4.0
3.0
4.0
2.0
1.5
1.0
2.5
TOUR 4.5
WEIGHT LOSS
2.5
4.5
PEAK
INTERVALS
3.0
5.0
GOLF COURSE
3.0
5.0
MOUNTAIN
CLIMB
RACE
2.5
4.5
3.5
4.5
3.5
5.0
3.5
4.5
3.5
4.5
2.5
4.5
2.5
2.0
1.5
3.5
4.5
3.5
4.5
4.0
5.0
4.0
4.5
3.5
4.5
3.5
4.5
2.5
2.0
1.5
3.0
5.0
4.0
5.0
4.0
5.5
4.0
5.0
4.0
5.0
3.0
5.0
3.0
2.5
2.0
4.0
5.0
4.0
5.0
4.5
5.5
4.5
5.0
4.0
5.0
4.0
5.0
3.0
2.5
2.0
Note: WARM-UP and COOL-DOWN are not included in the 5k distance.
CUSTOM 1
TREADMILL
OPERATION
CUSTOM 2
PROGRAM:
CUSTOM 1 & 2 (CUSTOM 2 = CST4.6 only)
Lets you createTHRand
a perfect workout for you with specific speed, incline and time combination.
ZONEreuse
1
The ultimate in personal programming. Time-based goal.
THR ZONE 2
1. Once the CUSTOM 1 or 2 program has been chosen, press enter.
VALLEY
CONDITIONING
GUIDELINES
2. Choose the desired time using the program +/- keys and press enter.
TOUR
3. Choose
the desired speed for each segment, using the program +/- keys and
PEAK
press
enter. Note: You will need to press enter after each segment.
INTERVALS
MOUNTAIN
CLIMB the desired incline for each segment, using the program +/- keys
4. Choose
TROUBLESHOOTING
& MAINTENANCE
5. Press Start to begin your program. At this time, your program has been
LIMITED
WARRANTY
and press enter. Note: You will need to press enter after each segment.
• While using your saved program, you are able to adjust the speed or incline, but
any changes will not be saved.
successfully saved into memory, and can be used for future workouts.
• To reset your program information and delete it from memory, press and
hold the enter key for 5 seconds (after you have selected the CUSTOM 1 or 2
program).
22
INTRODUCTION
PROGRAM I N F O R M AT I O N
Using etrak ™ Performance tracker
IMPORTANT
PRECAUTIONS
Introduction
Research shows that those who journal their fitness routines or workouts, on average, achieve greater
success than those who do not. Because your new treadmill is equipped with Horizon’s exclusive
eTRAK™ Performance Tracker, you’ve taken an important step towards achieving your fitness goals.
Congratulations!
BEFORE
YOU BEGIN
CS T3.6: e trak™ operation
TREADMILL
OPERATION
SET UP: To activate eTRAK™ for the first time, simply press and hold the eTRAK™ button for 5 seconds. From
this point on, your information will be automatically saved. Note: There is no need to perform this step
again unless resuming operation after being deactivated.
DEACTIVATE: To temperarily stop eTRAK™ from accumulaing data, press and hold the eTRAK™ button for 5 seconds. To resume, repeat SET UP instructions.
CONDITIONING
GUIDELINES
RESET: To reset accumulated data, press and hold the eTRAK™ button for 10 seconds. Note: This step is permanent and will delete ALL previously accumulated data.
ACCUMULATED DATA: Once eTRAK™ is activated, you can scroll through your accumulated data in multiple
formats by pressing the eTRAK™ button. A workout is saved when: the program ends, the consile is
paused and not resumed after 10 minutes, or the STOP button is held to reset the console.
2) LAST WORKOUT: This option allows you to view your accumulated data from your last workout. The Current Workout becomes the Last Workout once a program has ended or the console has been reset. The following information will be shown in each display window:
INCLINE- Average incline of last workout.
TIME - Total time of last workout.
CALORIES - Total calories burned during last workout.
DISTANCE - Total distance of last workout.
SPEED - Average speed of last workout.
TROUBLESHOOTING
& MAINTENANCE
1) CURRENT WORKOUT: The console automatically defaults to Current Workout, displaying your progress in real time.
23
LIMITED
WARRANTY
ASSEMBLY
eTRAK™ is an innovative new software, integrated into your treadmill console, that will allow you to
track your fitness progress over time, without the need for paper journals or logs. eTRAK™ allows you to
easily compare your current workout to your last, average or lifetime workout totals. With quick access to
feedback like time of workout or calories burned during previous workouts, you’ll be able to quickly and
easily see the progress you’ve made. Read further to learn about how eTRAK™ can help motivate you to
enhance your performance.
INTRODUCTION
CS T 3 . 6 : etrak™ operation
IMPORTANT
PRECAUTIONS
ASSEMBLY
3) AVERAGE WORKOUT: This option allows you to see your average accumulated data for the last 100 workouts.
The following information will be shown in each display window:
INCLINE - Average incline level.
TIME - Average workout time.
CALORIES - Average calories burned.
DISTANCE - Average workout distance.
SPEED - Average speed of workout.
BEFORE
YOU BEGIN
4) TRIP: Functions similar to a vehicle trip odometer. View your accumulated data since the trip feature was last
reset. Hold Trip button for 5 seconds to reset Trip. The following information will be shown in each
display window:
INCLINE - Average incline of current trip.
TIME - Total time of trip. Note: If time is greater than 99:59, the time will no longer display minutes and will display hours only.
CALORIES - Average calories burned.
DISTANCE - Total trip distance.
SPEED - Average speed of current trip.
5) LIFETIME TOTAL: This option allows you to view the the total accumulated data from your first workout to your last saved workout. The following information will be shown in each display window:
INCLINE - Average incline level.
TIME - Total accumulated time. Note: If time is greater than 99:59, the time will no longer display minutes and will display hours only.
CALORIES - Average calories burned.
DISTANCE - Total accumulated distance.
SPEED - Average speed.
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
24
INTRODUCTION
CST4.6: DAT E & C L O C K S E T U P
Enter Setup Mode: Press and hold MANUAL and INTERVALS program buttons for 3 seconds.
Once in setup mode, use the PROGRAM SETUP +/- KEYS to scroll through settings.
Use the ENTER button to confirm settings.
Settings include: MONTH, DAY, YEAR, HOUR, MINUTE, and AM/PM.
Review Settings: You can review your settings at any time while in Setup Mode. Use the ENTER button to
scroll through settings.
6) Exit Setup Mode: To confirm the Date and Time, press and hold ENTER for 5 seconds.
7) To Reset: Simply reenter Setup Mode and adjust Date and Time to the correct setting.
IMPORTANT
PRECAUTIONS
1)
2)
3)
4)
5)
ASSEMBLY
CST4.6: e trak™ operation
SETUP: To activate eTRAK™ a user MUST be chosen before the program begins. To select a user, simply press
the User 1 or User 2 button. To deselect a user, press User button again. All accumulated data specifically
relates to the user that is chosen. Note: If no user is selected, no data will be tracked.
BEFORE
YOU BEGIN
RESET: Reset all recorded information for User 1 or User 2 by selecting the user and then holding down the
user button for 10 seconds. Note: This step is permanent and will delete ALL previously accumulated data
for the chosen user.
ACCUMULATED DATA: Once eTRAK™ is activated, you can scroll through your accumulated data in multiple
formats by pressing the eTRAK™ button. A workout is saved when: the program ends, the consile is
paused and not resumed within 10 minutes, or the STOP button is held to reset the console.
TREADMILL
OPERATION
1) CURRENT WORKOUT: The console automatically defaults to Current Workout, displaying your progress in real time.
CONDITIONING
GUIDELINES
2) AVERAGE WORKOUT: This option allows you to see your average accumulated data for the last 100 workouts. The following information will be shown in each display window:
INCLINE - Average incline level.
TIME - Average workout time.
CALORIES - Average calories burned.
PACE - Average pace of workout.
DISTANCE - Average workout distance.
SPEED - Average speed of workout.
25
LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
3) LAST WORKOUT: This option allows you to view your accumulated data from your last workout. The Current Workout becomes the Last Workout once a program has ended or the console has been reset. The
following information will be shown in each display window:
INCLINE- Average incline of last workout.
TIME - Total time of last workout.
CALORIES - Total calories burned during last workout.
PACE - Average pace of last workout.
DISTANCE - Total distance of last workout.
SPEED - Average speed of last workout.
INTRODUCTION
CS T 4 . 6 : etrak™ operation
IMPORTANT
PRECAUTIONS
4) WEEKLY TOTAL: View your accumulated data from the last Sunday to the present day. Note: This data is based on week to date NOT the previous seven days. For instance, if you have not used the machine since Sunday, the console will read zeros. The following information will be shown in each display window:
INCLINE- Average incline of weekly workout.
TIME - Total time of workout.
CALORIES - Average calories burned.
PACE - Average pace of of weekly workout.
DISTANCE - Total distance of workout.
SPEED - Average speed of weekly workout.
Note: If the Date and Clock are not set, Weekly Total will default to the Last Workout data.
ASSEMBLY
BEFORE
YOU BEGIN
5) MONTHLY TOTAL: View your accumulated data from the 1st day of the month to the present day. Note:
This data is based on month to date NOT the previous thirty days. For instance, if you have not used
the machine since the 1st of the month, the console will read zeros. The following information will be
shown in each display window:
INCLINE- Average incline of monthly workout.
TIME - Total time of monthly workout.
CALORIES - Average calories burned.
PACE - Average pace of monthly workout.
DISTANCE - Total distance of workout.
SPEED - Average speed of monthly workout.
Note: If the Date and Clock are not set, Monthly Total will default to equal the Last Workout data.
TREADMILL
OPERATION
CONDITIONING
GUIDELINES
6) LIFETIME TOTAL: This option allows you to view the the total accumulated data from your first workout to your last saved workout. The following information will be shown in each display window:
INCLINE- Average incline.
TIME - Total accumulated time. Note: If time is greater than 99:59, the time will no longer display minutes and will display hours only.
CALORIES - Average calories burned.
PACE - Average pace.
DISTANCE - Total accumulated distance.
SPEED - Average speed.
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
26
INTRODUCTION
CO N D I T I O N I N G G U I DELINES
IMPORTANT
PRECAUTIONS
Always consult your physician before beginning an exercise program.
HOW OFTEN? (Frequency of Workouts)
ASSEMBLY
The American Heart Association recommends that you exercise at least 3 to 4 days per week to maintain
cardiovascular fitness. If you have other goals such as weight or fat loss, you will achieve your goal faster with
more frequent exercise. Whether it’s 3 days or 6 days, remember that your ultimate goal should be to make
exercise a lifetime habit. Many people are successful staying with a fitness program if they set aside a specific
time of day to exercise. It doesn’t matter whether it’s in the morning before breakfast, during lunch hour or while
watching the evening news. What’s more important is that it’s a time that allows you to keep a schedule, and a
time when you won’t be interrupted. To be successful with your fitness program, you have to make it a priority in
your life. So decide on a time, pull out your day planner and pencil in your exercise times for the next month!
HOW LONG? (Duration of Workouts)
BEFORE
YOU BEGIN
For aerobic exercise benefits, it’s recommended that you exercise from between 24 and 60 minutes per session.
But start slowly and gradually increase your exercise times. If you’ve been sedentary during the past year, it may
be a good idea to keep your exercise times to as little as five minutes initially. Your body will need time to adjust
to the new activity. If your goal is weight loss, a longer exercise session at lower intensities has been found to
be most effective. A workout time of 48 minutes or more is recommended for best weight loss results.
HOW HARD? (Intensity of Workouts)
CONDITIONING
GUIDELINES
TREADMILL
OPERATION
How hard you workout is also determined by your goals. If you use your treadmill to prepare for a 5K run, you will
probably work out at a higher intensity than if your goal is general fitness. Regardless of your long term goals,
always begin an exercise program at low intensity. Aerobic exercise does not have to be painful to be beneficial!
There are two ways to measure your exercise intensity. The first is by monitoring your heart rate (using the grip
pulse handlebars or a wireless chest transmitter - may be sold separately), and the second is by evaluating your
perceived exertion level (this is simpler than it sounds!).
PERCEIVED EXERTION LEVEL
27
LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
A simple way to gauge your exercise intensity is to evaluate your perceived exertion level. While exercising, if you
are too winded to maintain a conversation without gasping, you are working out too hard. A good rule of thumb
is to work to the point of exhilaration, not exhaustion. If you cannot catch your breath, it’s time to slow down.
Always be aware of these warning signs of overexertion.
INTRODUCTION
TA R G E T H E A R T R AT E Z O N E C H A R T
IMPORTANT
PRECAUTIONS
What is Target Heart Rate Zone?
10
0%
75
BEFORE
YOU BEGIN
60
%
%
15
12
0
0
TREADMILL
OPERATION
BEATS PER MINUTE
ASSEMBLY
Target Heart Rate Zone tells you
the number of times per minute
your heart needs to beat to
achieve a desired workout effect.
It is represented as a percentage
of the maximum number of times
your heart can beat per minute.
Target Zone will vary for each
individual, depending on age,
current level of conditioning,
and personal fitness goals. The
American Heart Association
recommends working-out at a
Target Heart Rate Zone of between
60% and 75% of your maximum
heart rate. A beginner will want to
workout in the 60% range while
a more experienced exerciser will
want to workout in the 70-75%
range. See chart for reference.
AGE
14
6
14
3
T A 139 1
35
R
13
11
1
7
G
11
E
4
T
11
1
10
8
12
8
12
4
Z O 120
10
5
NE
10
2
9
9
20
25
30
35
40
45
50
55
97
60
11
93
65
CONDITIONING
GUIDELINES
example:
TROUBLESHOOTING
& MAINTENANCE
For a 42-year-old user: Find age along the bottom of the chart (round to 40), follow age column up to
the target zone bar. Results: 60% of maximum Hear Rate = 108 Beats Per Minute, 75% of maximum
Heart Rate = 135 Beat Per Minute.
Always consult your physician before beginning an exercise program.
LIMITED
WARRANTY
28
6
INTRODUCTION
STRETCHING
IMPORTANT
PRECAUTIONS
STRETCH FIRST
ASSEMBLY
Before using your product, it is best to take a few minutes doing a few gentle stretching exercises.
Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into
each of these stretches with a slow gentle motion. Do not stretch to the point of pain. Make sure not to
bounce while doing these stretches.
1. STANDING CALVE MUSCLE STRETCH
BEFORE
YOU BEGIN
Stand near a wall with the toes of tour left foot about 18" from the wall, and
the right foot about 12" behind the other foot. Lean forward, pushing against
the wall with your palms. Keep your heels flat and hold this position for a
count of 15 seconds. Make sure that you do not bounce while stretching.
Repeat on the other side.
TREADMILL
OPERATION
2. STANDING QUADRICEPS STRETCH
CONDITIONING
GUIDELINES
Using a wall to provide balance, grasp your left ankle
with your left hand and hold your foot against the back
of your thigh for 15 seconds. Repeat with your right
ankle and hand.
3. SITTING HAMSTRING & LOWER BACK MUSCLE STRETCH
TROUBLESHOOTING
& MAINTENANCE
Sit on the floor with your legs together and straight out in front of you. Do
not lock your knees. Extend your fingers towards your toes and hold for a
count of 15 seconds. Make sure that you do not bounce while stretching. Sit
upright again. Repeat one time.
29
LIMITED
WARRANTY
TIPS
INTRODUCTION
TIPS
THE IMPORTANCE OF WARM UP & COOL DOWN
IMPORTANT
PRECAUTIONS
WARM UP
The first 2 to 5 minutes of a workout should be devoted to warming up. The warm-up will limber your
muscles and prepare them for more strenuous exercise. Make sure that you warm-up on your product at a
slow pace. The warm up should gradually bring your heart rate into your Target Heart Rate Zone.
COOL DOWN
ASSEMBLY
Never stop exercising suddenly! A cool-down period of 3-5 minutes allows your heart to readjust to the
decreased demand. Make sure that your cool down period consists of a very slow pace to allow your heart
rate to lower. After the cool-down, repeat the stretching exercises listed above to loosen and relax your
muscles.
TIPS
ACHIEVING YOUR FITNESS GOALS
BEFORE
YOU BEGIN
An important step in developing a long term fitness program is to determine your goals. Is your primary
goal for exercising to lose weight? Improve muscle? Reduce stress? Prepare for the spring racing schedule?
Knowing what your goals are will help you develop a more successful exercise program. Below are some
common exercise goals:
TREADMILL
OPERATION
• Weight Loss - lower intensity, longer duration workouts
• Improve Body Shape and Tone - interval workouts, alternate between hi and low intensities
• Increased Energy Level - more frequent daily workouts
• Improved Sports Performance - high intensity workouts
• Improved Cardiovascular Endurance - moderate intensity, longer duration workouts
CONDITIONING
GUIDELINES
If possible try to define your personal goals in precise, measurable terms, and then put your goals in writing.
The more specific you can be, the easier it will be to track your progress. If your goals are long term, divide
them up into monthly and weekly segments. Longer term goals can lose some of the immediate motivation
benefits. Short term goals are easier to achieve. Your console provides you with several readouts that can
be used to record your progress. You can track Distance, Calories or Time.
TROUBLESHOOTING
& MAINTENANCE
KEEPING AN EXERCISE DIARY
To make your personal exercise log book, photocopy the weekly and monthly log sheets, which are located
on the following pages, or you can print them off of your computer by going to:
www.horizonfitness.com/guides/weeklylog.pdf
www.horizonfitness.com/guides/monthlylog.pdf
LIMITED
WARRANTY
As your fitness improves, you can look back and see how far you’ve come!
30
INTRODUCTION
W E E K LY L O G S H E E T S
DAY
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
IMPORTANT
PRECAUTIONS
WEE K #
COMMENTS
SUND AY
MON D AY
TUES D AY
WED N E S D AY
ASSEMBLY
THUR S D AY
FRID AY
SATU R D AY
WEE K #
DAY
BEFORE
YOU BEGIN
WEE K LY T O TA L S :
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
COMMENTS
SUND AY
MON D AY
TREADMILL
OPERATION
TUES D AY
WED N E S D AY
THUR S D AY
FRID AY
SATU R D AY
WEE K #
DAY
CONDITIONING
GUIDELINES
WEE K LY T O TA L S :
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
COMMENTS
TROUBLESHOOTING
& MAINTENANCE
SUND AY
MON D AY
TUES D AY
WED N E S D AY
THUR S D AY
FRID AY
WEE K LY T O TA L S :
31
LIMITED
WARRANTY
SATU R D AY
INTRODUCTION
W E E K LY L O G S H E ETS
IMPORTANT
PRECAUTIONS
WEEK #
D AY
WEEKLY GOAL
DATE
DISTANCE
CALORIES
TIME
COMMENTS
S U N D AY
M O N D AY
T U E S D AY
W E D N E S D AY
T H U R S D AY
ASSEMBLY
F R I D AY
S AT U R D AY
W E E K LY T O TA L S :
BEFORE
YOU BEGIN
WEEK #
D AY
WEEKLY GOAL
DATE
DISTANCE
CALORIES
TIME
COMMENTS
S U N D AY
M O N D AY
T U E S D AY
TREADMILL
OPERATION
W E D N E S D AY
T H U R S D AY
F R I D AY
S AT U R D AY
W E E K LY T O TA L S :
CONDITIONING
GUIDELINES
WEEK #
D AY
WEEKLY GOAL
DATE
TROUBLESHOOTING
& MAINTENANCE
S U N D AY
M O N D AY
T U E S D AY
W E D N E S D AY
T H U R S D AY
F R I D AY
S AT U R D AY
LIMITED
WARRANTY
W E E K LY T O TA L S :
32
DISTANCE
CALORIES
TIME
COMMENTS
INTRODUCTION
W E E K LY L O G S H E E T S
DAY
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
IMPORTANT
PRECAUTIONS
WEE K #
COMMENTS
SUND AY
MON D AY
TUES D AY
WED N E S D AY
ASSEMBLY
THUR S D AY
FRID AY
SATU R D AY
WEE K #
DAY
BEFORE
YOU BEGIN
WEE K LY T O TA L S :
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
COMMENTS
SUND AY
MON D AY
TREADMILL
OPERATION
TUES D AY
WED N E S D AY
THUR S D AY
FRID AY
SATU R D AY
WEE K #
DAY
CONDITIONING
GUIDELINES
WEE K LY T O TA L S :
WEEKLY GOAL
D ATE
DISTANCE
CALORIES
TIME
COMMENTS
TROUBLESHOOTING
& MAINTENANCE
SUND AY
MON D AY
TUES D AY
WED N E S D AY
THUR S D AY
FRID AY
WEE K LY T O TA L S :
33
LIMITED
WARRANTY
SATU R D AY
INTRODUCTION
M O N T H LY L O G S H EETS
IMPORTANT
PRECAUTIONS
MONTH
WEEK #
ASSEMBLY
D I S TANCE
MONTHLY GOAL
CALORIES
TIME
D I S TANCE
MONTHLY GOAL
CALORIES
TIME
D I S TANCE
MONTHLY GOAL
CALORIES
TIME
M O N T H LY T O TA L S :
BEFORE
YOU BEGIN
MONTH
WEEK #
TREADMILL
OPERATION
M O N T H LY T O TA L S :
CONDITIONING
GUIDELINES
MONTH
WEEK #
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
M O N T H LY T O TA L S :
34
INTRODUCTION
TROUBLESHOOTING
IMPORTANT
PRECAUTIONS
COMMON PRODUCT QUESTIONS
ARE THE SOUNDS MY TREADMILL MAKES NORMAL?
All treadmills make a certain type of thumping noise due to the belt riding over the rollers, especially new
treadmills. This noise will diminish over time, although may not totally go away. Over time, the belt will
stretch, causing the belt to ride smoother over the rollers.
WHY IS THE TREADMILL I PURCHASED LOUDER THAN THE ONE AT THE STORE?
ASSEMBLY
All fitness products seem quieter in a large store showroom because there is generally more background noise
than in your home. Also, there will be less reverberation on a carpeted concrete floor than on a wood overlay
floor. Sometimes a heavy rubber mat will help reduce reverberation through the floor. If a fitness product is
placed close to a wall, there will be more reflected noise.
WHEN SHOULD I BE WORRIED ABOUT A NOISE?
BEFORE
YOU BEGIN
As long as the sounds your treadmill makes are no louder than a normal conversational tone of voice, it is
considered normal noise.
TROUBLESHOOTING - TREADMILL
Your treadmill is designed to be reliable and easy to use. However, if you experience a problem, please reference the
troubleshooting guide listed below.
TREADMILL
OPERATION
PROBLEM: The console does not light up and/or the belt does not move.
SOLUTION: Verify the following:
35
LIMITED
WARRANTY
TROUBLESHOOTING
& MAINTENANCE
CONDITIONING
GUIDELINES
Does the red light on the ON/OFF switch light up?
If yes:
• Double check that all connections are secure, especially the console cable. Unplug and reconnect the console
cable to verify.
• Make sure the console cable is not pinched or damaged in any way.
• Turn the power off, unplug the power cable and wait 60 seconds. Remove motor cover. Wait until all red LED
lights have gone off on the motor control board before proceeding. Next, verify that none of the wires connected
to the lower board are loose or disconnected.
If no:
• Verify that the outlet the machine is plugged into is functional. Double check that the breaker has not tripped,
it is on a dedicated 20-amp circuit, it is not on a GFCI equipped outlet, and it is not plugged into a power
strip/surge protector or extension cord.
• The power cord is not pinched or damaged and is properly plugged into the outlet AND the machine.
• The power switch is turned to the ON position.
INTRODUCTION
PROBLEM: The treadmill circuit breaker trips during a workout.
SOLUTION: Verify the following:
• Make sure the treadmill is plugged into a dedicated 20-amp circuit.
• Verify that you do not have the machine on an extension cord or surge protector.
• Confirm that the machine is not plugged into a GFCI-equipped outlet or on a circuit that has a GFCI‑equipped outlet on it.
IMPORTANT
PRECAUTIONS
PROBLEM: The running belt does not stay centered during a workout.
SOLUTION: Verify the following:
• Make sure the treadmill is on a level surface.
• Verify that the belt is properly tightened and centered (Refer to the Adjustment section for detailed directions).
PROBLEM: Operating speed appears inaccurate.
SOLUTION: Auto-calibrate the treadmill:
ASSEMBLY
• Power on the treadmill and have the safety key in position on the
console. Press and hold the elevation “+” and speed “-” buttons for
approximately 5 seconds to enter the Engineering Mode. The console
will beep and “ENG0” appears in the display.
• Press the Speed “+” or “-” button until “ENG2” appears in the display.
• Press, “ENTER” to select. Press, “START” to begin. The treadmill
running belt will begin to move automatically and the auto-calibration
sequence will properly set and store the speed values.
• Upon successful calibration, the treadmill will beep several times. The
console will automatically exit Engineering Mode and return to the
start-up screen.
WARNING
DO NOT stand on running belt while
BEFORE
YOU BEGIN
calibrating – stand on the guide
rails. Treadmill will fluctuate between
low and high speeds for several
minutes until calibration is complete.
TROUBLESHOOTING - HEART RATE
Check your exercise environment for sources of interference such as fluorescent lights, computers, underground fencing, home
security systems or appliances containing large motors. These items may cause erratic heart rate readouts.
TREADMILL
OPERATION
You may experience an erratic readout under the following conditions:
• Gripping the heart rate handlebars too tight. Try to maintain moderate pressure while holding onto the heart rate handlebars.
• Constant movement and vibration due to constantly holding the heart rate handlebars while exercising. If you are receiving
erratic heart rate readouts, try to only hold the grips long enough to monitor your heart rate.
• When you are breathing heavily during a workout.
• When your hands are constricted by wearing a ring.
• When your hands are dry or cold. Try to moisten your palms by rubbing them together to warm.
• Anyone with heavy arrhythmia.
• Anyone with arteriosclerosis or peripheral circulation disorder.
• Anyone whose skin on the measuring palm is especially thick.
CONDITIONING
GUIDELINES
If the above troubleshooting section does not remedy the problem, discontinue use and turn the power off.
PLEASE CALL CUSTOMER TECH SUPPORT AT THE NUMBER ON THE BACK PANEL.
TROUBLESHOOTING
& MAINTENANCE
The following information may be asked of you when you call. Please have these items readily available:
• Model Name
• Serial Number
• Date of Purchase (receipt or credit card statement)
LIMITED
WARRANTY
In order for Customer Tech Support to service your treadmill they may need to ask detailed questions about the symptoms that are
occurring. Some troubleshooting questions that may be asked are:
• How long has this problem been occurring?
• Does this problem occur with every use? With every user?
• If you are hearing a noise, does it come from the front or the back? What kind of noise is it (thumping, grinding, squeaking,
chirping etc.)?
• Has the machine been lubricated and maintained per the maintenance schedule?
36
Answering these and other questions will give the technicians the ability to send proper replacement parts and the service necessary
to get you and your Horizon Fitness treadmill running again!
INTRODUCTION
MA I N T E N A N C E
IMPORTANT
PRECAUTIONS
Cleanliness of your treadmill and its operation environment will keep maintenance problems and service calls to a
minimum. For this reason, we recommend that the following preventive maintenance schedule be followed.
ASSEMBLY
AFTER EACH USE (DAILY)
Clean and inspect, following these steps:
• Turn off the treadmill with the on/off switch, then unplug the power cord at the wall outlet.
• Wipe down the running belt, deck, motor cover, and console casing with a damp cloth. Never use solvents, as they
can cause damage to the treadmill.
• Inspect the power cord. If the power cord is damaged, contact Horizon Fitness.
• Make sure the power cord is not underneath the treadmill or in any other area where it can become pinched or cut.
• Check the tension and alignment of the running belt. Make sure that the treadmill belt will not damage any other
components on the treadmill by being misaligned.
BEFORE
YOU BEGIN
EVERY WEEK
Clean underneath the treadmill, following these steps:
• Turn off the treadmill with the on/off switch, then unplug the power cord at the wall outlet.
• Fold the treadmill into the upright position, making sure that the lock latch is secure.
• Move the treadmill to a remote location.
• Wipe or vacuum any dust particles or other objects that may have accumulated underneath the treadmill.
• Return the treadmill to its previous position.
CONDITIONING
GUIDELINES
LUBRICATION
Please contact Horizon Fitness with questions about applying lubricant to your treadmill.
RUNNING BELT
TROUBLESHOOTING
& MAINTENANCE
• Turn off the treadmill with the on/off switch, then unplug the
power cord at the wall outlet.
• Loosen both the rear roller bolts. (For best results, place two removable
marks on both sides of the frame and note roller position). Once
the belt is loosened, take the bottle of lubricant and apply it to the
entire top surface of the running deck. Tighten both rear roller bolts
(matching up the marks for proper position) to original position. After
you have applied lubricant, plug in the power cord, insert the safety
key, start the treadmill and walk on the belt for two minutes to spread
the lubricant.
• Lubricate the air shocks with Teflon based spray.
• Once lubrication is complete, reset the console by pressing and holding
‘STOP’ and Speed ‘+’ buttons for 5 seconds.
RUNNING DECK
37
LIMITED
WARRANTY
EVERY 6 MONTHS OR 150 MILES
It is necessary to lubricate your treadmill running deck every six months
or 150 miles to maintain optimal performance of your treadmill. Once the
treadmill reaches 150 miles, the console will prompt you to lubricate the
treadmill. Only use lubricant provided by Horizon Fitness!
TREADMILL
OPERATION
EVERY MONTH - IMPORTANT!
• Turn off the treadmill with the on/off switch, then unplug the power cord at the wall outlet.
• Inspect all assembly bolts of the machine for proper tightness.
• Turn off the treadmill and wait 60 seconds.
• Remove the motor cover. Wait until ALL LED lights turn off.
• Clean the motor and lower board area to eliminate any lint or dust particles that may have accumulated. Failure to
do so may result in premature failure of key electrical components.
• Vacuum and wipe down the belt with a damp cloth. Vacuum any black/white particles that may accumulate around
the unit. These particles may accumulate from normal treadmill use.
INTRODUCTION
L I M I T E D H O M E-USE WARRANTY
IMPORTANT
PRECAUTIONS
FRAME • LIFETIME
Horizon Fitness warrants the frame against defects in
workmanship and materials for the lifetime of the original
owner. (The frame is defined as the welded metal base of the
unit and does not include any parts that can be removed.)
ASSEMBLY
CST3.6: (Weight Capacity = 300 LBS)
DRIVE MOTOR/ELEVATION • 12 YEARS
Horizon Fitness warrants the drive/elevation motors
against defects in workmanship and materials for a period
of twelve years from the date of purchase, so long as the
device remains in the possession of the original owner.
CST4.6: (Weight Capacity = 325 LBS)
DRIVE MOTOR/ELEVATION • 15 YEARS
Horizon Fitness warrants the drive/elevation motors
against defects in workmanship and materials for a period
of fifteen years from the date of purchase, so long as the
device remains in the possession of the original owner.
BEFORE
YOU BEGIN
ELECTRONICS & PARTS • 1 YEAR
Horizon Fitness warrants the electronic components, finish
and all original parts for a period of one year from the date
of original purchase, so long as the device remains in the
possession of the original owner.
TREADMILL
OPERATION
LABOR • 1 YEAR
Horizon Fitness shall cover the labor cost for the repair
of the device for a period of one year from the date of the
original purchase, so long as the device remains in the
possession of the original owner.
EXCLUSIONS AND LIMITATIONS
CONDITIONING
GUIDELINES
Who IS covered:
• The original owner and is not transferable.
TROUBLESHOOTING
& MAINTENANCE
LIMITED
WARRANTY
38
What IS covered:
• Repair or replacement of a defective motor, electronic component, or
defective part and is the sole remedy of the warranty.
What IS NOT covered:
• Normal wear and tear, improper assembly or maintenance, or
installation of parts or accessories not originally intended or
compatible with the equipment as sold.
• Damage or failure due to accident, abuse, corrosion, discoloration of
paint or plastic, neglect, theft, vandalism, fire, flood, wind, lightning,
freezing, or other natural disasters of any kind, power reduction,
fluctuation or failure from whatever cause, unusual atmospheric
conditions, collision, introduction of foreign objects into the covered
unit, or modifications that are unauthorized or not recommended by
Horizon Fitness.
• Incidental or consequential damages. Horizon Fitness is not
responsible or liable for indirect, special or consequential damages,
economic loss, loss of property, or profits, loss of enjoyment or use,
or other consequential damages of whatsoever nature in connection
with the purchase, use, repair or maintenance of the equipment.
• Equipment used for commercial purposes or any use other than a
single family or Household, unless endorsed by Horizon Fitness for
coverage.
• Equipment owned or operated outside the US and Canada.
• Delivery, assembly, installation, setup for original or replacement
units or labor or other costs associated with removal or replacement
of the covered unit.
• Any attempt to repair this equipment creates a risk of injury. Horizon
Fitness is not responsible or liable for any damage, loss or liability
arising from any personal injury incurred during the course of, or as
a result of any repair or attempted repair of your fitness equipment
by other than an authorized service technician. All repairs attempted
by you on your fitness equipment are undertaken AT YOUR OWN RISK
and Horizon Fitness shall have no liability for any injury to the person
or property arising from such repairs.
SERVICE/RETURNS
• In-home service is available within 150 miles of the nearest
authorized repair center (Mileage beyond 150 miles from an
authorized service center is the responsibility of the consumer).
• All returns must be pre-authorized by Horizon Fitness.
• Horizon Fitness’ obligation under this warranty is limited to
replacing or repairing, at Horizon Fitness’ option, the same or
comparable model at one of its authorized service centers.
• A Horizon Fitness authorized service center must receive all
equipment for which a warranty claim is made. This equipment must
be received with all freight and other transportation charges prepaid,
accompanied by sufficient proof of purchase.
• Replacement units, parts and electronic components reconditioned
to As-new Condition by Horizon Fitness or its vendors may sometimes
be supplied as warranty replacement and constitute fulfillment of
warranty terms.
• This warranty gives you specific legal rights, and your rights may
vary from state to state.
C U S T O M ER TECH SUPPORT
For fast and friendly service, please contact one of our
trained customer technicians via phone, email or our website.
Customer Tech Support Hotline: 1 - 8 0 0 - 2 4 4 - 4 1 9 2
Email: [email protected]
Website: www.horizonfitness.com
Every employee at Horizon Fitness takes pride in providing you with a high quality product.
We want to know if you have a problem and we want to have an opportunity to correct it for you.
Note: Please read the troubleshooting section before contacting Customer Tech Support.
To receive additional product information, visit us at www.horizonfitness.com
1620 Landmark Drive,
Cottage Grove WI, 53527
Tel: 1.800.244.4192
Fax: 608.839.1260
Club Series. Rev. 2.0 | © 2006 Horizon Fitness Products | Designed & Engineered in the U.S.A. | Made in China
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
