ERK 19" Stand - Alone Enclosures ERK Rear Rail Kits ERK Caster

ERK 19" Stand - Alone Enclosures ERK Rear Rail Kits ERK Caster
Search
Products
Configured ERK audio/video enclosures available to simplify ordering and save installation time.
Click here.
ERK 19" Stand - Alone Enclosures
Quality. Aggressively Priced.
?
?
?
?
?
?
?
?
?
?
?
?
?
Fully welded construction, solid sides
2,500 lb. weight capacity
UL Listed in the US and Canada
Seismic certified (UBC 1997 & CBC 1998 Zone 4; IBC 2000, IBC 2003,-ASCE
02, 7
NFPA 5000 Seismic Use Group III) for protecting 650 lbs. of essential equipment
when used in conjunction with our ERK
-Z4 brackets
1/2", 3/4", 1" and -11/2" electrical knockouts found on
NEW! removable split rear
plates, top knockout plate additionally includes UHF/VHF antenna knockouts
16-gauge steel tops, bottoms, & sides
Laser-cut 1/8" thick internal steel braces for strength
1 pair fully-adjustable front rackrail
Large cable entry in bottom
Grounding and bonding stud installed in base
Configurable top (44, 40, 35 sp.), solid top with fan’sKO
(27, 21, 18 sp.)
Laser KO’s in side panels for cable pass
-through (44, 40, 35 sp. only)
Finished in a durable black textured powder coat
click to enlarge
?
universal cabinet options
?
vertical AC power strips
?
PDT thin power strips - NEW
?
cable lacing bars
?
security doors
?
AXS system
?
equip. mounting hdwr.
Click HEREto Download the
Thermal Management White Paper
Grounding/Bonding Studs have been provided in all
welded vertical floor standing racks to help you
electrically ground and bond equipment, per NEBS and
NEC standards.
click for more
#96-038 Download or viewPDF file
20" Depth
Part #
25" Depth
Part #
Racking Height
Overall
Height
ERK-4420
ERK-4425
77" (44 Space)
81-1/8"
ERK-4020
ERK-4025
70" (40 Space)
74-1/8"
ERK-3520
ERK-3525
61-1/4" (35 Space)
65-3/8"
ERK-2720
ERK-2725
47-1/2" (27 Space)
51-3/8"
ERK-2120
ERK-2125
36-3/4" (21 Space)
40-7/8"
31-1/2" (18 Space)
35-5/8"
ERK-1820
ERK-1825
* Accommodates vertical power strips
Power Strip*
ERK Rear Rail Kits
11-gauge, 10
-32 threaded, sold in pairs. All
mounting hardware included.
Part #
Description
ERK-RR44
44 space additional rail kit
ERK-RR40
40 space additional rail kit
ERK-RR35
35 space additional rail kit
ERK-RR27
27 space additional rail kit
ERK-RR21
21 space additional rail kit
ERK-RR18
18 space additional rail kit
ERK Caster Bases
ERK caster bases are equipped with
” diameter
3
swivel wheels available in commercial grade
and aNEW fine floor version featuring a soft rubber wheel constructed from Dynatread TPR
to protect against damaging decorative flooring. Skirted for aesthetics, each base comes with
its wheels preinstalled. Raises total rack height by 3 3/4".
Part #
CBS-ERK-20
commercial grade caster base
for 20" depth model
fine floor caster base
for 20" depth model
NEW CBS-ERK-20R
CBS-ERK-25
Weight
Capacity
Description
700 lbs.
commercial grade caster base
for 25" depth model
fine floor caster base
for 25" depth model
NEW CBS-ERK-25R
1300 lbs.
1300 lbs.
CBS- ERK - 20
700 lbs.
Rack Rulersimplifies rackspace math.
NEW! Configured ERK Series Enclosures
Configured Audio/Video Enclosure includes
…
?
?
?
?
?
?
?
?
?
Integrated fan top
Configurable rear door with bottom vent, solid locking front door
Welded side panels with vent blockers to control airflow
3-1/4” wide vertical lacer strip
Six horizontal lacer bars
Twelve 8” Velcro® cable management straps
Thin power strip(s), 20 Amps
Leveling feet
100 qty. 10
-32 mounting hardwar
25” Outside Depth
(23-15/32” Useable)
Part #
©copyright 2000/2005 Middle Atlantic Products, Inc.
Racking
Height
Description
ERK-4425-AV
77" (44 space)
with 20 outlet thin power strip
ERK-4025-AV
70" (40 space)
with two 10 outlet thin
power strips
ERK-3525-AV
61-1/4" (35 space)
with two 10 outlet thin
power strips
