HP 1100A, LaserJet 1100 All-in-One Printer series User's manual

HP 1100A, LaserJet 1100 All-in-One Printer series User's manual
HP
HP LaserJet 1100A User Guide
Copyright© 1999
Hewlett-Packard Co.
Printed in Germany
Manual Part No.
C4218-90962
Printed on
Recycled Paper
*C4218-90962*
*C4218-90962*
C4218-90962
LaserJet
1100A
User
Guide
HP LaserJet 1100A
Printer•Copier•Scanner
User Guide _________________
© Copyright HewlettPackard Company 2002
All Rights Reserved.
Reproduction,
adaptation, or translation
without prior written
permission is prohibited,
except as allowed under
the copyright laws.
Publication number:
C4218-90962
Second Edition: January,
2002
Warranty
The information
contained in this
document is subject to
change without notice.
Hewlett-Packard makes
no warranty of any kind
with respect to this
information.
HEWLETT-PACKARD
SPECIFICALLY
DISCLAIMS THE
IMPLIED WARRANTY
OF MERCHANTABILITY
AND FITNESS FOR A
PARTICULAR
PURPOSE.
Hewlett-Packard shall not
be liable for any direct,
indirect, incidental,
consequential, or other
damage alleged in
connection with the
furnishing or use of this
information.
Trademark Credits
Adobe is a trademark of
Adobe Systems
Incorporated.
CompuServe is a U.S.
trademark of
CompuServe, Inc.
Windows and Windows
NT are U.S. registered
trademarks of Microsoft
Corporation.
ENERGY STAR is a U.S.
registered service mark
of the U.S. Environmental
Protection Agency.
Hewlett-Packard Company
11311 Chinden Boulevard
Boise, Idaho 83714 U.S.A.
Contents
1 Getting to know the printer
Printer features and benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Print with excellent quality. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Save money . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Create professional documents . . . . . . . . . . . . . . . . . . . . . . . .2
Printer components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Printer control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Printer paper input trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Printer paper guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Printer paper output paths . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Printer door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Choosing paper and other media . . . . . . . . . . . . . . . . . . . . . . . . . .8
Loading paper into the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Specific types. . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Turning the power off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Voltage conversions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Accessing printer properties (driver) and help. . . . . . . . . . . . . . . .11
Printer properties (driver) . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Printer online help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Printing a self-test page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2 Getting to know the Copier/Scanner
Scanner features and benefits . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Getting to know the software. . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Document Assistant (Windows 9x & NT 4.0) . . . . . . . . . . . . .18
LaserJet Document Desktop
(Windows 3.1x, 9x, NT 4.0) . . . . . . . . . . . . . . . . . . . . . . .19
Quick Copy settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Copier Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
LaserJet Toolbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Copier/Scanner components. . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Scanner control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Scanner paper input tray, guides, and output path . . . . . . . . .23
Scanner door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Supported paper sizes and types (media). . . . . . . . . . . . . . . . . . .24
Precautions for copying and scanning . . . . . . . . . . . . . . . . . . . . .25
Loading Copier/Scanner originals . . . . . . . . . . . . . . . . . . . . . . . . .26
Accessing the online help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
EN
Contents i
3 Printing media
Printing transparencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Printing envelopes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Printing labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Printing letterhead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Printing cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
4 Printing tasks
Printing with manual feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Printing on both sides of the paper (manual duplexing) . . . . . . . .37
Manual duplex using the paper output bin (standard). . . . . . .38
Manual duplex (special) heavy-media, card stock . . . . . . . . .39
Printing watermarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Accessing the watermark feature . . . . . . . . . . . . . . . . . . . . . .40
Printing multiple pages on a single sheet of paper
(N-up printing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Accessing the multiple pages per sheet feature . . . . . . . . . . .41
Printing booklets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Canceling a print job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Changing print quality settings . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Print using EconoMode (save toner) . . . . . . . . . . . . . . . . . . . . . . .45
5 Scanning tasks
Scanning to fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Using the Fax feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Scanning to e-mail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Using the E-Mail feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Editing scanned text (OCR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Using the OCR feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Storing scanned text or images. . . . . . . . . . . . . . . . . . . . . . . . . . .52
Using the Store feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Acquiring an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Contrast sensitive originals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Accessing the contrast feature . . . . . . . . . . . . . . . . . . . . . . . .53
Enhancing the scanned image . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Accessing image enhancement features . . . . . . . . . . . . . . . .54
Adding annotations to scanned images . . . . . . . . . . . . . . . . . . . .55
Accessing the annotation features . . . . . . . . . . . . . . . . . . . . .55
Canceling scan or copy jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
ii
Contents
EN
6 Copying tasks
Copy overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Making Quick Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Quick Copy settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Using the Copier Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . .60
Accessing the Copier Control Panel . . . . . . . . . . . . . . . . . . . .60
Canceling copy jobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
7 Managing the toner cartridge
HP toner cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
HP policy on non-HP toner cartridges. . . . . . . . . . . . . . . . . . .62
Toner cartridge storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Toner cartridge life expectancy. . . . . . . . . . . . . . . . . . . . . . . .62
Recycling toner cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Saving toner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Redistributing toner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Changing the toner cartridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
8 Troubleshooting the printer
Finding the solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Pages did not print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Pages printed; however . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Printer light patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Error messages on screen . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Paper handling problems . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Printed page is different than what appeared on screen . . . .72
Improving print quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Image defect examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Correcting print defects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Cleaning the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Cleaning the toner cartridge area . . . . . . . . . . . . . . . . . . . . . .80
Cleaning the printer paper path . . . . . . . . . . . . . . . . . . . . . . .81
Clearing printer paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Removing a jammed page . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Paper jam: removing torn pieces of paper . . . . . . . . . . . . . . .85
Changing the pickup roller . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Cleaning the pickup roller . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Resetting the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
EN
iii
9 Troubleshooting the Copier/Scanner
Finding the solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Scanning problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Copying problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
The scanner did nothing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
No preview appeared on screen . . . . . . . . . . . . . . . . . . . . . . .95
Scanned image is of poor quality . . . . . . . . . . . . . . . . . . . . . .96
Part of the image did not scan or is missing text . . . . . . . . . .97
The text cannot be edited . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
The scan takes too long . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Error messages appear on the screen . . . . . . . . . . . . . . . . .100
No copy came out or the scanner did nothing . . . . . . . . . . .101
Copies are blank, missing images, or faded . . . . . . . . . . . . .102
Improving scan/copy quality . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Preventative steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Image defect examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Correcting scan/copy defects . . . . . . . . . . . . . . . . . . . . . . . .105
Calibrating the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Accessing the Calibration utility . . . . . . . . . . . . . . . . . . . . . .107
Cleaning the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Clearing scanner jams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Clearing jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Clearing hard-to-reach jams . . . . . . . . . . . . . . . . . . . . . . . . .111
Removing the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
10 Service and support
Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Obtaining hardware service. . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Guidelines for repacking the printer . . . . . . . . . . . . . . . . . . . . . .115
Guidelines for repacking the scanner . . . . . . . . . . . . . . . . . . . . .116
Service information form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
HP Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Customer Support and product repair assistance
(U.S. and Canada) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
European Customer Support Center . . . . . . . . . . . . . . . . . .119
Online services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Obtaining software utilities and electronic information . . . . .123
HP direct ordering for accessories or supplies . . . . . . . . . . .124
HP Support Assistant compact disc . . . . . . . . . . . . . . . . . . .124
HP service information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
HP SupportPack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
HP FIRST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Worldwide sales and service offices . . . . . . . . . . . . . . . . . . . . . .126
iv
Contents
EN
Appendix A Printer specifications
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
FCC compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Environmental Product Stewardship Program . . . . . . . . . . . . . .135
Protecting the Environment. . . . . . . . . . . . . . . . . . . . . . . . . .135
Material safety data sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137
Regulatory statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . .138
Laser safety statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Canadian DOC regulations . . . . . . . . . . . . . . . . . . . . . . . . . .139
Korean EMI statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Laser statement for Finland . . . . . . . . . . . . . . . . . . . . . . . . .140
Appendix B Scanner specifications
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
FCC compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
Environmental product stewardship . . . . . . . . . . . . . . . . . . . . . .146
Protecting the Environment. . . . . . . . . . . . . . . . . . . . . . . . . .146
Regulatory statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Laser safety statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Canadian DOC regulations . . . . . . . . . . . . . . . . . . . . . . . . . .148
Korean EMI statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Laser statement for Finland . . . . . . . . . . . . . . . . . . . . . . . . .149
Appendix C Paper specifications
Printer paper specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Supported paper sizes (printer). . . . . . . . . . . . . . . . . . . . . . . . . .152
Guidelines for using paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Transparencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155
Card stock and heavy media . . . . . . . . . . . . . . . . . . . . . . . .157
Appendix D Memory (DIMMs)
Installing DIMMs (memory) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
Test DIMM installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
Removing DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
Appendix E Warranty and licensing
Hewlett-Packard software license agreement . . . . . . . . . . . . . . .166
Hewlett-Packard limited warranty statement . . . . . . . . . . . . . . . .168
Limited warranty for toner cartridge life . . . . . . . . . . . . . . . . . . . .170
EN
v
Appendix F Accessories and ordering information
Appendix G Scanner resolution and gray scale
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Resolution and gray-scale guidelines . . . . . . . . . . . . . . . . . . . . .179
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180
Gray scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181
Index
vi
Contents
EN
1
Getting to know the
printer
This chapter provides information on the following topics:
Note
EN
●
Printer features and benefits
●
Printer components
●
Choosing paper and other media
●
Loading paper into the printer
●
Turning the power off
●
Voltage conversions
●
Accessing printer properties (driver) and help
●
Printing a self-test page
For installation instructions, see the “HP LaserJet Quick Reference
Guide” that came with your printer.
1
Printer features and benefits
Congratulations on the purchase of your new printer. You can . . .
Print with excellent quality
●
Print at 600 dots per inch (dpi) with Resolution Enhancement
technology (REt).
Save money
●
Use EconoMode to save toner.
●
Print on both sides of the paper to save paper (manual
duplexing).
●
Print multiple pages on a single sheet of paper to save paper
(N-up printing).
Create professional documents
●
Protect your documents by using Watermarks such as
“confidential.”
●
Print Booklets. This feature enables you to easily print the pages
required to create cards or books. Once printed, all you have to
do is fold and staple the pages.
●
Print the first page on different paper/media than the following
pages.
2 Chapter 1 Getting to know the printer
EN
Printer components
2
1. Printer control panel
2. Paper supports
3. Paper input tray
4. Single-sheet paper input tray (priority feed)
5. Paper guides
6. Paper-output lever
7. Straight-through output path
8. Printer door
9. Paper output bin
1
3
4
9
5
8
7
6
1. Power switch (220-240 volt printers)
2. Power receptacle
3. Memory door
4. Parallel port
1
EN
2
3
4
Printer components 3
Printer control panel
The printer control panel is comprised of two lights and one lighted
button. These lights produce patterns that identify the status of your
printer.
Go button and light
Ready light
Attention light
Note
●
Go button and light: Press and release to print a self-test page
or when in manual-feed mode, or press and hold for 5 seconds to
reset the printer.
●
Ready light: Indicates the printer is ready to print.
●
Attention light: Indicates printer initialization, reset, and errors.
See “Printer light patterns” for functional descriptions of all the light
patterns.
4 Chapter 1 Getting to know the printer
EN
Printer paper input trays
Rear paper input tray
The paper input tray located closest to the back of the printer can hold
up to 125 sheets of 20 lb. paper or it can hold multiple envelopes.
Front (single-sheet) paper input tray
The single-sheet paper input tray should be used when feeding single
pages or media such as envelopes. You can print the first page on
different media than the rest using the single-sheet paper input tray.
Note
The printer will automatically (priority feed) print from the single-sheet
paper input tray before printing from the paper input tray.
Printer paper guides
Both input trays have paper guides. Paper guides are used to ensure
the paper is correctly fed into the printer and that the print is not
skewed (crooked text on the page). When loading paper, adjust the
paper guides to match the width of the paper being printed.
EN
Printer components 5
Printer paper output paths
Paper output bin
The paper output bin is located on the front of the printer. Printed
paper will be collected here in the correct sequence when the paperoutput lever is in the up position. Use the output bin when printing
large, collated documents or when copying documents so that the
original is separated from the copies.
Straight-through paper output path
The straight through paper output path is useful when printing
envelopes, transparencies, heavy media, or anything that tends to
curl when printed. Printed paper will stack in reverse order with the
paper-output lever down.
6 Chapter 1 Getting to know the printer
EN
Printer door
Open the printer door to access the toner cartridge, clear jams, and
clean the printer. The printer door is located on the front of the printer.
Open and close the printer door by firmly grasping the top left and
right sides of the printer door and pulling it towards you.
Note
EN
If the scanner is attached, it may be necessary to move the printer to
the edge of your workstation before opening the printer door in order
to get the full range of motion.
Printer components 7
Choosing paper and other media
HP LaserJet printers produce excellent print quality documents. You
can print on a variety of print media, such as paper (including up to
100% recycled fiber content paper), envelopes, labels,
transparencies, and custom-sized media. Properties such as weight,
grain, and moisture content are important factors, affecting printer
performance and quality. To achieve the best possible print quality,
use only high-quality paper designed for laser printers. See “Printer
paper specifications” for detailed paper and media specifications.
Note
Always test a sample of paper before purchasing large quantities.
Your paper supplier should understand the requirements specified in
the HP LaserJet Printer Family Paper Specification Guide (HP part
number 5021-8909). See “Printer paper specifications.”
●
Maximum supported paper size: 216 by 356 mm (8.5 by 14 in.)
●
Minimum supported paper size: 76 by 127 mm (3 by 5 in.)
8 Chapter 1 Getting to know the printer
EN
Loading paper into the printer
Paper should be loaded with the top down and the side-to-be printed
facing forward. Always adjust the paper guides to prevent jams and
skewing.
CAUTION
Attempting to print on paper that is wrinkled, folded, or damaged in any
way may cause a jam to occur. See “Printer paper specifications.”
Note
Always remove all paper from the paper input tray and straighten
the stack when new paper is added. This helps prevent multiple
sheets of paper from feeding through the printer at one time and
reduces paper jams. See the sticker which you placed on the printer
while setting up the hardware.
Specific types. . .
EN
●
Transparencies: Load transparencies with the top down and the
side-to-be-printed facing toward the front of the printer. See
“Printing transparencies.”
●
Envelopes: Load with the narrow, stamp side down and the sideto-be-printed facing toward the front of the printer. See “Printing
envelopes.”
●
Labels: Load with the top down and the side-to-be-printed facing
toward the front of the printer. See “Printing labels.”
●
Letterhead: Load with the top down and the side-to-be-printed
facing toward the front of the printer. See “Printing letterhead.”
●
Cards: Load with the narrow side down and the side-to-beprinted facing toward the front of the printer. See “Printing cards.”
Loading paper into the printer 9
Turning the power off
Printers that require 100-127 volts of power must be unplugged to
turn the power off. Printers that require 220-240 volts can be switched
off (the switch is located on the left side of the power plug) or
unplugged.
Note
To ensure safety when working inside the printer for any reason, it is
best to unplug the printer.
Voltage conversions
HP LaserJet printers are manufactured to different specifications for
different countries. Because of these differences, HP does not
recommend transporting products sold within the United States to
another country.
In addition to the concerns about the differing power system voltages,
the country of final destination may have different import and export
restrictions, power frequencies, and regulatory requirements.
Note
The HP LaserJet family printers must be serviced by an authorized
repair depot or reseller within the country where the printer was
originally purchased.
Because of the different specifications and warranty coverage
limitations, Hewlett-Packard does not offer a conversion, or support
the conversion, of U.S. version HP LaserJet family printers for foreign
use. We advise those customers planning to transport equipment
outside the United States to purchase the products in the country of
final destination.
10 Chapter 1 Getting to know the printer
EN
Accessing printer properties (driver) and help
This section provides information on the following topics:
●
Printer properties (driver)
●
Printer online help
Printer properties (driver)
Printer properties control the printer and allow you to change default
settings, such as paper size, printing on both sides of the page
(manual duplexing), printing multiple pages on a single sheet of paper
(N-up printing), resolution, watermarks, and printer memory. You can
access the printer properties in two ways:
Note
●
Through the software application from which you are printing.
(Change settings for current software application use.)
●
Using the Windows® operating system. (Change default settings
for all future print jobs.)
Because many software applications use a different method of
accessing the printer properties, we will describe common methods
used in Windows 9x & NT® 4.0, and Windows 3.1x.
Windows 9x & NT 4.0
●
Change settings for current software application use: From
the File menu within the software application, click Print, and
then click Properties. (The steps can vary between software
applications; this is the most common method.)
●
Change defaults for all future print jobs: Click the Start button,
click Settings, and then click Printers. Right-click the printer icon
for which you would like to change properties, and then choose
Properties. Many of the features in Windows NT are also located
on the Document Defaults menu.
Windows 3.1x
EN
●
Change settings for current software application use: From
the File menu within the software application, click Print,
Printers, and then click Options. (The steps can vary between
software applications; this is the most common method.)
●
Change defaults for all future print jobs: From the Windows
control panel, double-click Printers, highlight the printer, and then
click Setup.
Accessing printer properties (driver) and help 11
Printer online help
Printer properties online help
The printer properties (driver) online help includes information
specific to the functions within the printer properties. This online help
will guide you when changing default settings for your printer.
Access the printer properties help system by opening the printer
properties and then clicking on the Help button.
Online help
The HP LaserJet 1100 online help includes information for all of the
printing, copying, and scanning software applications.
See “Accessing the online help.”
12 Chapter 1 Getting to know the printer
EN
Printing a self-test page
Among other items, a self-test page provides all of the printer
configuration settings, scanner attachment verification, a sample of
the print quality, and provides information for printer page counts as
well as scan and copy page counts. A self-test page can also help
you verify the printer is printing correctly.
To print a self-test page, press and release the Go button on the
printer control panel while the printer is in the Ready state. If the
printer is in PowerSave mode, press and release the Go button once
to awaken it, and then press and release the Go button a second
time.
EN
Printing a self-test page 13
14 Chapter 1 Getting to know the printer
EN
2
Getting to know the
Copier/Scanner
This chapter provides information on the following topics:
Note
EN
●
Scanner features and benefits
●
Getting to know the software
●
Copier/Scanner components
●
Supported paper sizes and types (media)
●
Precautions for copying and scanning
●
Loading Copier/Scanner originals
●
Accessing the online help
For hardware and software installation instructions, see the
“HP LaserJet Quick Reference Guide” that came with your scanner.
15
Scanner features and benefits
Scan
Use HP software to simplify your office tasks:
●
Faxing
●
E-Mailing
●
Editing text (OCR)
●
Storing documents electronically
Copy
Make Quick Copies when copying your most frequent type of original.
Use the Copier Control Panel to customize and make multiple copies.
●
Simple and convenient (Quick Copy)
• Load the original and press a single button
●
Powerful copier software (Copier Control Panel)
• Make multiple copies
• Remove speckles
• Straighten
• Adjust contrast
16 Chapter 2 Getting to know the Copier/Scanner
EN
Getting to know the software
Bring the world to your fingertips by using the full-featured software
solution included with your
HP LaserJet 1100A Printer•Copier•Scanner.
LASERJET TOOLBOX
- Document Assistant properties
- LaserJet Document Desktop
- Quick Copy settings
- Online help
- Online user guide
EN
CONVENIENT
SCAN
- Document Assistant
- Quick Copy
- E-Mail
- Fax
- Edit text (OCR)
- Store and manage
COPY
FULL FEATURED
- LaserJet Document Desktop
- Copier Control Panel
- Quick Copies
- Full-featured copies
Getting to know the software 17
Document Assistant (Windows 9x & NT 4.0)
The Document Assistant is quick and convenient, and can facilitate
many of your routine office tasks:
●
Copying
●
Storing or managing scanned text and images
●
Scanning to e-mail
●
Scanning to fax
●
Editing scanned text (OCR)
Take full advantage of the Document Assistant.
Note
The Document Assistant is not available for Windows 3.1x operating
systems.
Accessing the Document Assistant
Note
1
Click Start, located in the system tray.
2
Click Programs.
3
Click HP LaserJet 1100.
4
Click Document Assistant.
5
An HP icon will appear in your system tray. Click on the HP icon to
display the Document Assistant on your computer screen.
To close the Document Assistant, right click on the HP icon and click
Close Document Assistant.
18 Chapter 2 Getting to know the Copier/Scanner
EN
LaserJet Document Desktop
(Windows 3.1x, 9x, NT 4.0)
The LaserJet Document Desktop is a full-featured desktop application
for your scanning and copying capabilities of HP LaserJet 1100. From
the HP 1100 Document Desktop, you can perform the following tasks
and more:
Note
●
Copy
●
Scan images (or acquire an image from a TWAIN-compliant
device)
●
Store and manage scanned images
●
Send scanned images to fax (a fax software application must be
installed on your PC)
●
Send scanned images to e-mail (an e-mail software application
must be installed on your PC)
●
Send scanned text to a word processing application to edit (OCR)
●
Make image enhancements
●
Add annotations
You can print (electronically) to the LaserJet Document Desktop from
any software application. This feature allows you to use any of the
functions within the LaserJet Document Desktop on documents
created in your favorite desktop publishing or word processing
application, saving you the time of first printing and then scanning a
hard copy version. The online help provides more information about
the LaserJet Document Desktop. See “Accessing the online help.”
Accessing the LaserJet Document Desktop
(Windows 9x & NT 4.0)
1
Click Start, located in the Windows system tray.
2
Click Programs.
3
Click HP LaserJet 1100.
4
Click LaserJet Document Desktop.
Accessing the LaserJet Document Desktop
(Windows 3.1x)
EN
1
From the Program Manager, double-click the HP LaserJet 1100
icon.
2
Double-click LaserJet Document Desktop.
Getting to know the software 19
Quick Copy settings
The Quick Copy feature enables you to make consistent and
convenient copies. Your PC does not even have to be turned on.
Adjust the settings to reflect the most common type of original that
you copy, and you do not have to change them again.
For instructions on making Quick Copies and adjusting the default
Quick Copy settings, see “Making Quick Copies.”
Copier Control Panel
Use the Copier Control Panel when full-featured copying capabilities
are necessary or when your original differs from your most frequent
copy job. Consider the Copier Control Panel as your personal copy
machine. You can have the copy machine at your fingertips with the
Copier Control Panel.
For instructions on accessing and using the Copier Control Panel, see
“Using the Copier Control Panel.”
20 Chapter 2 Getting to know the Copier/Scanner
EN
LaserJet Toolbox
The LaserJet Toolbox enables you to customize your software
solution to meet your needs.
●
Change the Quick Copy settings
●
Configure properties for the Document Assistant
●
Configure properties for the LaserJet Document Desktop
●
Connect network scanner
The LaserJet Toolbox also enables you to do the following:
Note
●
Calibrate the scanner
●
Access the online user guide (this guide)
●
Access the online help
The LaserJet Toolbox is not available for Windows 3.1x operating
systems. However, many of the features within the LaserJet Toolbox
can be accessed through the HP LaserJet 1100 Program Group.
Accessing the LaserJet Toolbox
(Windows 9x & NT 4.0)
You can access the LaserJet Toolbox from the Document Assistant:
Click Tools.
EN
Getting to know the software 21
Copier/Scanner components
1. Scanner control panel
2. Paper input tray
3. Paper guides
4. Paper support
5. Door release button
6. Paper output path
7. Scanner attachment lever
8. Scanner door
3
1
8
7
6
Note
4
2
5
To remove the scanner from the printer, see “Removing the scanner.”
Scanner control panel
●
Copy: Press the Copy button to perform Quick Copies—your PC
does not have to be turned on.
●
Scan: Press the Scan button to launch the software. If configured
correctly, you can perform the following tasks:
• Scan to fax
• Scan to e-mail
• Store documents electronically
• Edit text (OCR)
• Make multiple and customized copies
Note
To cancel a scan or copy job, press both buttons simultaneously.
Copy
Scan
22 Chapter 2 Getting to know the Copier/Scanner
EN
Scanner paper input tray, guides, and output
path
The scanner paper input tray is located on the front, top side of the
scanner. The paper guides are located inside the paper input tray and
are used to ensure that the paper or media is correctly fed into the
scanner and to prevent skewing (crooked image).
CAUTION
Paper and media can jam if not correctly loaded, causing damage to
the original you are scanning or copying. See “Loading Copier/Scanner
originals.”
Scanner door
Open the scanner door to remove jams or clean the scanner. The
scanner door is located on the front of the scanner. Open the scanner
door by first pressing the button located on the upper-right side to
release the latch, and then gently grasping the door and pulling it
towards you. To close the door, simply push the door up and towards
the scanner until it clicks.
EN
Copier/Scanner components 23
Supported paper sizes and types (media)
The Copier/Scanner for the HP LaserJet 1100 can handle a broader
range of paper sizes and more types of media than the printer:
●
Maximum: 216 by 762 mm (8.5 by 30 in.)
●
Minimum: 50.8 by 90 mm (2 by 3.5 in.)
In addition, you can scan and copy many different types of paper and
media that are typically not used for printing, such as news print,
photographs, business receipts, and business cards.
Note
Small or delicate originals, such as business cards or newsprint, may
require a carrier sheet to correctly feed through the Copier/Scanner.
You can make a carrier sheet by simply taping the leading edge of the
original to a standard sheet of paper.
See “Precautions for copying and scanning.”
24 Chapter 2 Getting to know the Copier/Scanner
EN
Precautions for copying and scanning
You should not put anything in the Copier/Scanner that could get
stuck in or damage the feed mechanism. Observe the following
precautions to minimize the possibility of jamming or damaging the
feed mechanism:
●
Remove self-stick notes.
●
Remove staples and paper clips.
●
Straighten any curls or wrinkles in the original to be scanned.
●
Do not scan or copy any original with glue, correction fluid, or wet
ink on it.
●
Do not scan or copy gummed-backed paper, labels, or originals.
●
Avoid scanning or copying originals with tears, perforations, or
any defect that may cause a jam.
●
Feed irregularly-sized originals one at a time.
●
Do not scan originals that are larger or smaller than the
supported size. See “Supported paper sizes and types (media).”
Note
Small or delicate originals, such as business cards or newsprint, may
require a carrier sheet to correctly feed through the Copier/Scanner.
You can make a carrier sheet by simply taping the leading edge of the
original to a standard sheet of paper.
Note
Scanning or copying with the correct resolution and gray scale settings
for your job is important in order to obtain good results. To learn more
about resolution and gray scale, see “Scanner resolution and gray
scale.”
EN
Precautions for copying and scanning 25
Loading Copier/Scanner originals
1
Load the original with the narrow side down and the side-to-bescanned facing toward the front of the scanner.
2
Adjust the paper guides.
3
Press the Scan button on the scanner or press the Copy button
for a Quick Copy.
Note
Always remove all originals from the input tray and straighten the stack
when new originals are added.
CAUTION
Small originals will cause a jam if not loaded correctly.
Note
If editing text (OCR), the original must be loaded with the text positioned
horizontally and upside down. See “Editing scanned text (OCR)” for
more information.
26 Chapter 2 Getting to know the Copier/Scanner
EN
Accessing the online help
To access the HP LaserJet 1100 Online Help, use any of the three
methods below:
●
Program Group:
• Windows 9x & NT 4.0: Click Start, Programs, HP LaserJet
1100, and then LaserJet 1100 Online Help.
• Windows 3.1x: From the Program Manager, double-click the
HP LaserJet 1100 icon, and then double-click LaserJet 1100
Online Help.
Note
EN
The Document Assistant is not available for Windows 3.1x operating
systems.
●
Document Assistant: Click Tools, and then click Help.
●
LaserJet Document Desktop: Click Help from the main menu.
Accessing the online help 27
28 Chapter 2 Getting to know the Copier/Scanner
EN
3
Printing media
This chapter provides information on the following topics:
EN
●
Printing transparencies
●
Printing envelopes
●
Printing labels
●
Printing letterhead
●
Printing cards
29
Printing transparencies
Only use transparencies recommended for use in laser printers, such
as HP transparency film. See “Printer paper specifications.”
CAUTION
Inspect the transparencies to ensure they are not wrinkled or curled,
and that they do not have any torn edges.
1
Adjust the paper-output lever to the down position.
2
Load with the top down and the side-to-be-printed (rough side)
facing toward the front of the printer. Adjust the paper guides.
3
Print, and then remove the transparencies from the front of the
printer to prevent them from sticking together. Place the printed
transparencies on a flat surface.
30 Chapter 3 Printing media
EN
Printing envelopes
CAUTION
EN
Only use envelopes recommended for laser printers. See “Printer paper
specifications.”
1
Adjust the paper output-lever to the down position.
2
Load with the narrow, stamp-side down and the side-to-beprinted facing toward the front of the printer. Adjust the
paper guides to fit the envelope.
3
Select the correct envelope size in the software application. This
setting can be accessed through the printer properties. See
“Printer properties (driver).”
4
Print.
Printing envelopes 31
Printing labels
Only use labels recommended for laser printers, such as HP LaserJet
labels. See “Printer paper specifications.”
CAUTION
Do not use labels that are separating from the backing sheet, wrinkled,
or damaged in any way. Do not feed a sheet of labels through the printer
twice. The adhesive backing is designed for one pass through the
printer. Also, do not use continuous feed labels or labels that require
moisture to stick.
1
Adjust the paper output-lever to the down position.
2
Load with the top down and the side-to-be-printed facing
toward the front of the printer. Adjust the paper guides to fit
the width of the label sheet.
3
Print, and then remove the printed label sheets from the front of
the printer as they are printed to prevent them from sticking
together.
32 Chapter 3 Printing media
EN
Printing letterhead
1
Load with the top down and the side-to-be-printed facing toward
the front of the printer. Adjust the paper guides to fit the width of
the paper.
2
Print.
To print a single page cover letter, using letterhead, followed by a
multi-page document, load the letterhead in the single-sheet paper
input tray and load the standard paper in the multi sheet paper input
tray. By default, the printer prints from the single sheet paper input
tray first.
Cover letter followed by document.
Use both input trays.
EN
Printing letterhead 33
Printing cards
The HP LaserJet 1100 does not support paper smaller than 76 by
127 mm (3 by 5 in.). Verify cards are not stuck together before
loading.
1
Adjust the paper output-lever to the down position.
2
Load with the narrow side down and the side-to-be-printed
facing toward the front of the printer. Adjust the paper guides
to fit the card.
3
Select the correct card size in the software application being
used. (Software settings can override printer properties.)
4
Print.
34 Chapter 3 Printing media
EN
4
Printing tasks
This chapter provides information on the following topics:
EN
●
Printing with manual feed
●
Printing on both sides of the paper (manual duplexing)
●
Printing watermarks
●
Printing multiple pages on a single sheet of paper
(N-up printing)
●
Printing booklets
●
Canceling a print job
●
Changing print quality settings
●
Print using EconoMode (save toner)
35
Printing with manual feed
Use manual feed when printing mixed media; for example, an
envelope, then a letter, then an envelope, and so forth. Load an
envelope in the single sheet paper input tray and load letterhead in
the multiple-page paper input tray. Also, use manual feed to protect
your privacy when printing to a network printer.
To print using manual feed, you must access the printer properties or
printer setup in your software application and select Manual Feed
from the Source drop down list. See “Printer properties (driver).” After
the setting has been enabled, you must press the Go button (blinking)
each time to print.
36 Chapter 4 Printing tasks
EN
Printing on both sides of the paper
(manual duplexing)
To print on both sides of the paper (manual duplexing), you must run
the paper through the printer twice. You can print using the paper
output bin or the straight-through output path. HP recommends using
the paper output bin for light-weight paper. Use the straight-through
output path for any heavy media or media that tends to curl when
printed, such as envelopes and card stock.
Note
EN
●
Manual duplex using the paper output bin (standard)
●
Manual duplex (special) heavy-media, card stock
Manual duplexing can cause the printer to become dirty more quickly
and reduce print quality. See “Cleaning the printer” if the printer
becomes dirty.
Printing on both sides of the paper (manual duplexing) 37
Manual duplex using the
paper output bin
(standard)
1
1
Adjust the paper-output lever to the
up position.
2
Access the printer properties. See
“Printer properties (driver).” On the
Finishing tab, click Manual Duplex
(standard), and then click OK. Print
the document.
3
After side one has been printed,
remove the remaining paper from
the paper input tray and set it aside
until after you finish your manual
duplexing job.
4
Gather up the printed pages from
side one, rotate the stack clockwise,
and then straighten the stack before
placing it back in the paper input tray.
Once reloaded, page one should be
oriented upside down and located
closest to the back of the printer.
(The printed side should be facing
toward the back of the printer.)
2
3
Click OK (on screen), and then wait
for the pages to print.
4
38 Chapter 4 Printing tasks
EN
Manual duplex (special)
heavy-media, card stock
For heavy media (card stock, etc.), use
the straight-through output path.
1
1
Adjust the paper-output lever to the
down position.
2
Access the printer properties. See
“Printer properties (driver).” On the
Finishing tab, click Manual Duplex
(special), and then click OK. Print
the document.
3
After side one has been printed,
remove the remaining paper from
the paper input tray and set it aside
until after you finish your manual
duplexing job.
4
Gather up the printed pages from
side one, flip the stack, and then
straighten the stack before placing it
back in the paper input tray. Once
reloaded, page one should be
oriented upside down and located
closest to the front of the printer.
(The printed side should be facing
toward the back of the printer.)
2
3
Click OK (on screen), and then wait
for the pages to print.
4
EN
Printing on both sides of the paper (manual duplexing) 39
Printing watermarks
The watermark option allows you to print text “underneath” (in the
background) of an existing document. For example, you may want to
have large gray letters reading “draft” or “confidential” printed
diagonally across the first page or all pages of a document.
Accessing the watermark feature
1
From your software application, access the printer properties.
See “Printer properties (driver).”
2
On the Finishing tab, you can specify the type of Watermark you
would like to have printed on your document.
40 Chapter 4 Printing tasks
EN
Printing multiple pages on a single sheet of paper
(N-up printing)
You can select the number of pages you want to print on a single
sheet of paper. If you choose to print more than one page per sheet,
the pages will appear decreased in size and will be arranged on the
sheet in the order that they would otherwise be printed. Specify up to
9 pages per sheet of paper.
Accessing the multiple pages per sheet
feature
EN
1
From your software application, access the printer properties.
See “Printer properties (driver).”
2
On the Finishing tab and Document Options, you can specify
the number of Pages per sheet that you would like to have
printed.
Printing multiple pages on a single sheet of paper (N-up printing) 41
Printing booklets
You can print booklets on letter, legal,
executive, or A4 size paper.
1
2
1
Load the paper, and then adjust the
paper-output lever to the up position.
2
From your software application,
access the printer properties. See
“Printer properties (driver).” On the
Finishing tab click Booklet
printing, and then click OK. Print
the document.
3
After side one has been printed,
remove the remaining paper from
the paper input tray, and set it aside
until your booklet job is complete.
4
Gather up the pages from side one,
rotate them clockwise, and then
straighten the stack of paper.
Continued on next page.
3
4
42 Chapter 4 Printing tasks
EN
5
5
Place the pages from side one back
in the paper input tray. The printed
text should be oriented sideways
and facing toward the back of the
printer. Click OK (on screen). The
printer will finish printing.
6
Fold and staple the pages.
6
EN
Printing booklets 43
Canceling a print job
A print job can be canceled from a software application or a print
queue:
●
Remove remaining paper from the printer: This will stop the
printer immediately. Use either of the next two options after the
printer is stopped.
●
Software application: Typically, a dialog box will briefly appear
on your screen allowing you the option to cancel the print job.
●
Print queue: If a print job is waiting in a print queue (PC memory)
or print spooler, delete the job there. Go to your Printer screen,
either though the Windows Control Panel (Windows 3.1x) or
through Start, Settings, Printers in Windows 9x & NT 4.0. Doubleclick on the HP LaserJet 1100 icon to open the window, select
your print job, and then press Delete.
If the control panel status lights continue to blink after a print job has
been canceled, the computer is still sending the job to the printer.
Either delete the job from the print queue or wait until the computer
has finished sending data. The printer will return to the Ready state.
44 Chapter 4 Printing tasks
EN
Changing print quality settings
Print quality settings affect such things as how light or dark the print
on the page is and the style in which you would like graphics printed.
You can change the settings in printer properties to accommodate the
types of jobs you are printing. The possible settings are as follows:
●
Best Quality
●
Faster Printing
●
LaserJet III Compatibility
●
Custom
●
EconoMode (Save Toner)
These settings can be accessed on the Finishing tab under Print
Quality settings in the printer properties.
Note
To change the print quality settings for all future print jobs, access the
properties through the Start menu in your system tray. To change the
print quality settings only for the current software application use,
access the properties through the Print Setup menu in the application
from which you are printing. See “Printer properties (driver).”
Print using EconoMode (save toner)
An excellent way to extend the life of your toner cartridge is by using
EconoMode. EconoMode uses substantially less toner than normal
printing. The printed image is much lighter, but is adequate for
printing drafts or proofs.
To enable EconoMode, access the printer Properties. On the
Finishing tab under Print Quality, click EconoMode.
Note
EN
To enable EconoMode for all future jobs, see “Printer properties
(driver).”
Changing print quality settings 45
46 Chapter 4 Printing tasks
EN
5
Scanning tasks
This chapter provides information on the following topics:
Note
EN
●
Scanning to fax
●
Scanning to e-mail
●
Editing scanned text (OCR)
●
Storing scanned text or images
●
Acquiring an image
●
Contrast sensitive originals
●
Enhancing the scanned image
●
Adding annotations to scanned images
●
Canceling scan or copy jobs
Scanning with the correct resolution and gray scale settings for your
job is important in order to obtain good results. To learn more about
scanner resolution and gray scale, see “Scanner resolution and gray
scale.” Also, see the online help: “Accessing the online help.”
47
Scanning to fax
Scan to fax using the Document Assistant or the LaserJet Document
Desktop. You can change the properties for this feature within the
LaserJet Toolbox. See “LaserJet Toolbox.”
Using the Fax feature
1
Load the original with the narrow-side down and the side-to-bescanned facing toward the front of the scanner.
2
Adjust the paper guides.
3
Press the Scan button on the scanner.
Windows 9x & NT 4.0
The Document Assistant will launch automatically after the Scan
button is pressed.
1
Click Fax in the Document Assistant.
2
The original will scan, and your PC fax software application will
launch automatically and prompt for a sending address. Once
specified, the fax software application will then print
(electronically) the document to the fax port on your PC.
Windows 3.1x
After the Scan button is pressed, the LaserJet Document Desktop will
launch automatically and the original will scan.
Note
1
Change the image if necessary: crop, scale, add annotations, and
etc.
2
Click on the image and drag it to the fax icon, or click File, Send
to, and then Fax. Your PC fax software application will launch and
prompt for a sending address. Once specified, the fax software
application will then print (electronically) the document to the fax
port on your PC.
If the fax icon is not present or is not active, either you do not have a
fax software application installed on your PC or the application was not
recognized by the scanner software during installation. See the online
help to create a link to your fax software application: “Accessing the
online help.”
48 Chapter 5 Scanning tasks
EN
Scanning to e-mail
Scan to e-mail using the Document Assistant or the LaserJet
Document Desktop. You can change the properties for this feature
within the LaserJet Toolbox. See “LaserJet Toolbox.”
Using the E-Mail feature
1
Load the original with the narrow-side down and the side-to-bescanned facing toward the front of the scanner.
2
Adjust the paper guides.
3
Press the Scan button on the scanner.
Windows 9x & NT 4.0
The Document Assistant will launch automatically after the Scan
button is pressed.
1
Click E-Mail in the Document Assistant.
2
The original will scan, and your PC e-mail software application
will launch with the scanned image automatically attached as a
file.
Windows 3.1x
After the Scan button is pressed, the LaserJet Document Desktop will
launch automatically and the original will scan.
Note
EN
1
Change the image if necessary: crop, scale, add annotations, and
etc.
2
Click on the image and drag it to the e-mail icon or click File,
Send to, and then E-Mail. Your e-mail software application will
launch with the scanned image automatically attached as a file.
If the e-mail icon is not present or is not active, either you do not have
an e-mail software application installed on your PC or the application
was not recognized by the scanner software during installation. See
the online help to create a link to your e-mail software application:
“Accessing the online help.”
Scanning to e-mail 49
Editing scanned text (OCR)
Use the “Edit” feature to edit text. You can edit faxes, letters, meeting
notes, newspaper clippings, and many other documents. When
editing scanned text, an Optical Character Recognition (OCR)
application will read the text and enable you to import it into a word
processing program where you can make your edits. You can change
the properties for this feature within the LaserJet Toolbox. See
“LaserJet Toolbox.”
Using the OCR feature
1
Load the original with the narrow-side down and the side-to-bescanned facing toward the front of the scanner. If possible, load
so that the text is positioned horizontally and upside down;
otherwise, you will need to rotate the image.
2
Adjust the paper guides.
3
Press the Scan button on the scanner.
Windows 9x & NT 4.0
The Document Assistant will launch automatically after the Scan
button is pressed.
1
Click OCR in the Document Assistant.
2
The original will scan, and your word processing software
application will launch automatically with the scanned image
optically read and ready to edit.
3
Check the spelling in your document.
50 Chapter 5 Scanning tasks
EN
Windows 3.1x
After the Scan button is pressed, the LaserJet Document Desktop will
launch automatically and the original will scan.
Note
EN
1
Rotate the image, if necessary.
2
Click on the image and drag it to the word processing icon or click
File, Send to, and then the name of your word processing
application. Your word processing software application will launch
with the scanned image optically read and ready to edit.
3
Check the spelling in your document.
If the word processing icon is not present or is not active, either you do
not have a word processing software application installed on your PC
or the application was not recognized by the scanner software during
installation. See the online help to create a link to your word processing
software application: “Accessing the online help.”
Editing scanned text (OCR) 51
Storing scanned text or images
Your HP software enables you to quickly store scanned images in a
directory of your choice, saving you time by providing direct access to
your file management system. Store scanned images using the
Document Assistant or the LaserJet Document Desktop. You can
change the properties for this feature within the LaserJet Toolbox.
See “LaserJet Toolbox.”
Using the Store feature
1
Load the original with the narrow-side down and the side-to-bescanned facing toward the front of the scanner.
2
Adjust the paper guides.
3
Press the Scan button on the scanner.
Windows 9x & NT 4.0
The Document Assistant will launch automatically after the Scan
button is pressed.
1
Click Store in the Document Assistant.
2
The original will scan, and your word processing software
application will launch automatically with the scanned image
stored on the desktop.
Continued on next page.
3
Change the image if necessary: crop, scale, add annotations, and
etc.
4
Drag the image to the directory of your choice located on the left
side of the LaserJet Document Desktop, or click File, Move, and
then select a directory to store the file.
Windows 3.1x
After the Scan button is pressed, the LaserJet Document Desktop will
launch automatically and the original will scan.
1
Change the image if necessary: crop, scale, add annotations, and
etc.
2
Click on the image and drag it to the directory of your choice
located on the left side of the LaserJet Document Desktop, or
click File, Move, and then select a directory to store the file.
52 Chapter 5 Scanning tasks
EN
Acquiring an image
You can start a scan from the HP LaserJet Document Desktop. You
can also acquire an image from any TWAIN-compliant device, such
as a TWAIN-compliant digital camera or scanner (other than the
Copier/Scanner). The online help provides more information on how
to acquire an image. See “Accessing the online help.”
Contrast sensitive originals
If scanning or copying an original that has a
colored background and text that does not stand
out very well, you may need to adjust the contrast.
For example, if you scan or copy a yellow receipt
with light-gray print, the text may not be legible.
Increase the contrast (darken the text) to make the
text more legible.
Accessing the contrast feature
Scanning
●
Using the Document Assistant: Click the More >> button.
●
Using the LaserJet Document Desktop: Select the Tools tab,
select Image Enhancement, and then Contrast.
Copying
EN
●
Quick Copies: From the Document Assistant click the Tools
button, and then click Quick Copy Settings. These settings will
remain for all Quick Copies until changed.
●
Full featured copies: Open the Copier Control Panel.
Acquiring an image 53
Enhancing the scanned image
You can make enhancements to scanned images using the LaserJet
Document Desktop:
Note
●
Rotate and flip
●
Straighten
●
Invert
●
Sharpen
●
Clean
●
Convert to gray scale
●
Adjust contrast
●
Crop
The online help provides instructions on how to use these features. See
“Accessing the online help.”
Accessing image enhancement features
From the LaserJet Document Desktop, click Tools, and then click
Image Enhancement.
54 Chapter 5 Scanning tasks
EN
Adding annotations to scanned images
HP software enables you to modify and create annotations on your
scanned images. You can do any of the following to your scanned
image:
Note
●
Add text
●
Add sticky notes
●
Highlight text or graphics
●
Rubber stamp the image (for example: “confidential”)
●
Draw lines and arrows
The online help provides instructions on how to use these features. See
“Accessing the online help.”
Accessing the annotation features
From the LaserJet Document Desktop, click Tools, and then click
Annotations.
Note
To change the annotations settings, click Tools, and then click
Annotation Properties.
Canceling scan or copy jobs
EN
●
Cancel copy jobs by pressing both buttons on the scanner control
panel simultaneously.
●
Click cancel in the dialog box on the PC screen.
Adding annotations to scanned images 55
56 Chapter 5 Scanning tasks
EN
6
Copying tasks
This chapter provides information on the following topics:
EN
●
Copy overview
●
Making Quick Copies
●
Using the Copier Control Panel
●
Canceling copy jobs
57
Copy overview
There are two methods you can use to make copies:
●
Making Quick Copies
●
Using the Copier Control Panel
Each method is intended to be used for different purposes.
Making Quick Copies
Quick Copies enable you to quickly make a single copy of a document
(up to 20 pages), and your PC does not have to be turned on. You can
change the default Quick Copy settings, if necessary, to yield the best
looking copies for the type of original you copy most. These settings
will be applied to every Quick Copy job until you change them.
Note
For making multiple copies or copies that differ from your most common
type of original, use the Copier Control Panel. See “Using the Copier
Control Panel.”
See “Quick Copy settings” or the online help for more information on
changing the default Quick Copy settings. See “Accessing the online
help.”
1
Ensure the printer is loaded with paper.
2
Load the original document (up to 20 pages) in the scanner paper
input tray with the narrow side down and the side-to-becopied facing toward the front of the scanner. Adjust the
paper guides to fit the original. See “Loading Copier/Scanner
originals.”
3
Adjust the paper output lever on the printer to accommodate the
copy job. Use the paper output bin (lever up) if you are copying to
standard weight media. Use the straight-through output path
(lever down) if you are copying heavy media.
4
Press the Copy button on scanner.
58 Chapter 6 Copying tasks
EN
Quick Copy settings
You can change the default Quick Copy settings. Quick Copy settings
will remain the same for all future Quick Copy jobs, even when the PC
is turned off, until you change the defaults again (the PC must be
turned on to change the settings). Quick Copy settings include the
following:
●
Type of originals (combination, text, or photograph)
●
Paper size (select the size of your most common original to be
copied)
●
Contrast
Accessing the Quick Copy settings
●
WIndows 9x & NT 4.0:
• Document Assistant: Click Tools, and then Quick Copy
Settings.
• Program Group: Click Start, Programs, HP LaserJet 1100,
and then Quick Copy Settings.
●
EN
Windows 3.1x: From the Program Manager, double-click the
HP LaserJet 1100 icon, and then double-click Quick Copy
Settings.
Making Quick Copies 59
Using the Copier Control Panel
Use the Copier Control Panel when you wish to do any of the
following tasks with your original to be copied:
Note
●
Print multiple copies of the same document (load up to 20 pages)
●
Deskew
●
Remove speckles
●
Specify the type of original (the software automatically selects
optimum settings for the type of original you specified)
●
Scale the image
●
Adjust the contrast
The online help provides instructions on how to use these features. See
“Accessing the online help.”
Accessing the Copier Control Panel
Access the Copier Control Panel from the following locations:
Windows 9x & NT 4.0
●
Document Assistant: Click Copy.
●
Program Group: Click Start, Programs, HP LaserJet 1100, and
then Copier Control Panel.
Windows 3.1x
●
LaserJet Document Desktop: Click Tools, and then Copier
Utility.
Canceling copy jobs
Cancel copy jobs by pressing both buttons on the scanner control
panel simultaneously.
60 Chapter 6 Copying tasks
EN
7
Managing the toner
cartridge
This chapter provides information on the following subjects:
EN
●
HP toner cartridges
●
Redistributing toner
●
Changing the toner cartridge
61
HP toner cartridges
HP policy on non-HP toner cartridges
Hewlett-Packard Company cannot recommend use of non-HP toner
cartridges, either new, refilled, or remanufactured. Since they are not
HP products, HP cannot influence their design or control their quality.
Note
Warranty does not apply to defects resulting from software, interfacing,
parts, or supplies not supplied by HP.
Toner cartridge storage
Do not remove the toner cartridge from its package until you are
ready to use it. The shelf life of a cartridge in an unopened package is
approximately 2.5 years. The shelf life of a cartridge in an opened
package is approximately 6 months.
CAUTION
To prevent damage to the toner cartridge, do not expose it to light for
more than a few minutes.
Toner cartridge life expectancy
The life of the toner cartridge depends on the amount of toner that
print jobs require. When printing text at 5% coverage, an
HP LaserJet 1100 toner cartridge lasts an average of 2,500 pages.
This assumes the print density is set to 3 and EconoMode is off.
(These are the default settings.)
Recycling toner cartridges
To install a new HP toner cartridge, see “Changing the toner
cartridge” or follow the instructions included in the toner cartridge
box. Also, see the recycling information on the toner cartridge box
and “HP Cartridge Recycling Program information.”
Saving toner
To save toner, select the EconoMode option in your printer properties
settings. EconoMode (Save Toner) allows the printer to use less toner
on each page. Selecting this option will extend the life of the toner
cartridge and reduce your cost per page, but will reduce print quality.
See “Print using EconoMode (save toner).”
62 Chapter 7 Managing the toner cartridge
EN
Redistributing toner
When toner is low, faded or light areas
may appear on a printed page. You may
be able to temporarily improve print
quality by redistributing the toner. The
following procedure may allow you to
finish the current print job before
replacing the toner cartridge.
Note
If the scanner is attached, it may be
necessary to move the printer to the
edge of the work space before opening
the printer door in order to get the full
range of motion.
1
1
Open the printer door and remove
the toner cartridge from the printer.
CAUTION
To prevent damage, do not expose the
toner cartridge to light for more than a
few minutes. Cover it with a sheet of
paper.
2
2
Gently shake the toner cartridge
from side-to-side to redistribute the
toner.
CAUTION
If toner gets on your clothing, wipe it off
with a dry cloth and wash clothing in cold
water. Hot water sets toner into fabric.
3
3
Reinsert the toner cartridge into the
printer and close the printer door.
If the print remains light, install a new
toner cartridge. See “Changing the toner
cartridge.”
EN
Redistributing toner 63
Changing the toner cartridge
1
To change the toner cartridge, follow the
instructions below:
Note
If the scanner is attached, it may be
necessary to move the printer to the
edge of the work space before opening
the printer door in order to get the full
range of motion.
2
1
Open the printer door and remove
the old toner cartridge. See
“Recycling toner cartridges” for
recycling information.
2
Remove the new toner cartridge
from the packaging, and then gently
shake it from side to side in order to
distribute the toner evenly inside the
cartridge.
3
CAUTION
To prevent damage, do not expose the
toner cartridge to light for more than a
few minutes. Cover it with a piece of
paper.
4
3
Bend the tab on the right side of the
cartridge to break it loose.
CAUTION
If toner gets on your clothing, wipe it off
with a dry cloth and wash clothing in cold
water. Hot water sets toner into fabric.
5
64 Chapter 7 Managing the toner cartridge
4
Pull the tab until all the tape is
removed from the cartridge.
5
Insert the toner cartridge in the
printer. Be certain that the toner is
firmly in position, and then close the
printer door.
EN
8
Troubleshooting the
printer
This chapter provides information on the following subjects:
Note
EN
●
Finding the solution
●
Improving print quality
●
Cleaning the printer
●
Clearing printer paper jams
●
Resetting the printer
See HP’s Web site for software and printer driver updates, frequently
asked questions, and additional troubleshooting information. See
“Online services” for your specific Web address.
65
Finding the solution
Use this section to find the solution to common printer problems. For
copying or scanning problems, see “Finding the solution” in the
scanner troubleshooting chapter.
Pages did not print . . .
●
Light patterns: What light pattern is displayed on the printer
control panel? See “Printer light patterns.”
●
Error messages on screen: Is there a message on the screen?
See “Error messages on screen.”
●
Paper handling: Is paper being pulled into the printer
incorrectly? Are there paper jams? See “Paper handling
problems.”
Pages printed; however . . .
●
The print quality was poor: See “Improving print quality.”
●
The printed pages do not always appear the same as the
screen (print preview): See “Printed page is different than what
appeared on screen.”
66 Chapter 8 Troubleshooting the printer
EN
Printer light patterns
Light status legend
Symbol for “light off”
Symbol for “light on”
Symbol for “light blinking”
Control panel light messages
Light status Condition of the printer
PowerSave mode
(or the printer is off)
The printer uses PowerSave
mode to conserve energy.
Action
Pressing the Go button on the printer control
panel or printing will awaken the printer from
PowerSave mode. Check the power cord if
the above actions do not generate a
response (and the power switch if your
printer is powered with 220-240 volts).
Ready
The printer is ready to print.
No action is necessary; however, if you press
and release the Go button on the printer
control panel, a self-test page will print.
Processing
The printer is receiving or
processing data.
Wait for the job to print.
Buffered data
Press and release the Go button on the
The printer memory is retaining printer control panel to print the remaining
unprinted data.
data.
Manual feed
The printer is in manual feed
mode.
EN
Check that you have loaded the correct
paper, then press and release the Go button
on the printer control panel to print. Manual
feed is controlled by the software. If you do
not want to be in manual feed mode, change
the setting from your printer properties. See
“Printer properties (driver).”
Finding the solution 67
Control panel light messages (continued)
Light status Condition of the printer
Action
Door open, no toner cartridge,
or paper jam
The printer is in an error state.
Check the following:
● The printer door is closed.
● The toner cartridge is correctly installed
in the printer. See “Changing the toner
cartridge.”
● There are no paper jams. See “Clearing
printer paper jams.”
Paper out
The printer is out of paper.
Load paper into the printer. See “Loading
paper into the printer.”
Memory out
The page being printed may have been too
The printer ran out of memory in complex for the memory capacity of the
the middle of a print job.
printer.
● See “Memory (DIMMs)” to add memory.
● Press and release the Go button to print.
Reset/Printer initialization
No action is necessary. However, you can
The printer memory is being
reset the printer if you press and hold the Go
reset and all previously sent
button for 5 seconds.
print jobs are being purged. Or,
a printer initialization is taking
place. All lights blink for 1/2 of a
second or longer if initializing.
Fatal error
All lights are on.
●
●
●
68 Chapter 8 Troubleshooting the printer
Reset the printer.
Turn the printer off and then back on.
Contact HP Support. See “HP Support.”
EN
Error messages on screen
Error messages on screen
Error Message
Solution
Printer not responding/
error writing to LPT1
Verify the following:
● Ready light is on.
● Power cord and parallel cable are correctly
connected.
Try the following:
Disconnect and reconnect the power cord
and parallel cable at both ends.
● Use another IEEE-1284 compliant parallel
cable.
●
Cannot access port (in
use by another
application)
There is a device conflict. This can occur if
another printer connected to your computer is
running status software. The status software
dominates the parallel port on the computer and
will not allow the HP LaserJet 1100 to access the
port.
Try the following:
● Disable all status windows for other printers.
● Verify the port setting is correct for the
printer. Access the printer properties; see
“Printer properties (driver).” The port settings
can be accessed under the properties
Details tab in the Printer Properties screen.
EN
Finding the solution 69
Error messages on screen (continued)
Error Message
Solution
Illegal operation/General This error indicates that a problem occurred in
protection fault/Spool 32 Windows with your computer system resources
error
(memory or hard disk).
To clear this error, restart your PC.
To help prevent this error from occurring in the
future, use some or all of the following
recommendations:
● Run fewer applications at the same time.
Close (rather than minimize) the applications
that you are not using at the current time.
Programs such as screen savers, virus
checkers, status software, fax/answering
software, and menu programs use the
resources that you might need in order to
print.
● Avoid performing memory intensive tasks
such as sending a fax or running a video clip
while printing.
● Delete all temp (“file_name.tmp”) files from
the Temp subdirectories. For example, the
subdirectory C:\Windows\Temp.
● Print at 300 dpi rather than 600 dpi.
● Use an alternate print driver (printer
software), such as software for the
HP LaserJet III. Note: Using a different driver
will remove access to some product features.
70 Chapter 8 Troubleshooting the printer
EN
Paper handling problems
Paper handling problems
Problem
Solution
Paper jam
●
●
●
Print is skewed
(crooked )
●
●
Adjust the paper guides to the width of the
paper being printed and try reprinting. See
“Printer paper guides” or “Loading paper into
the printer.”
See “Page skew.”
More than one sheet of ●
paper feeds through
the printer at one time
The paper input tray may be overfilled. See
“Loading paper into the printer.” Verify the paper
is not wrinkled, folded, or damaged.
●
Verify the printer is not in Manual Feed mode.
See “Printer light patterns.”
The pickup roller may be dirty or damaged. See
“Cleaning the pickup roller” or “Changing the
pickup roller.”
Printer does not pull
paper from the paper
input tray
●
Printer made my paper ●
curl
●
The printer does not
output the printed
paper to the correct
path
EN
Verify you are printing with paper that meets
specifications. See “Printer paper
specifications.”
Verify you are printing with paper that is not
wrinkled, folded, or damaged.
See “Clearing printer paper jams.”
Adjust the paper output lever to the down
position to print using the straight-through
output path. See “Printer paper output paths” or
“Printing media.”
See “Curl or wave.”
Adjust the paper output lever to reflect your desired
paper output path. See “Printer paper output paths.”
Finding the solution 71
Printed page is different than what appeared
on screen
Printed page problems
Problem
Solution
Print job prints
extremely slow
The maximum speed of the printer is 8 pages per minute,
which cannot be exceeded. This speed is measured using
“Letter” sized paper. “Letter” is a U.S. standard paper size,
which is smaller than European A4. Your print job may be
very complex. Try the following:
● Reduce the complexity of your document (reduce the
number of multiple graphics, and etc.).
● Change setting in the printer properties to “Faster
Printing.” See “Printer properties (driver).”
● Add printer memory. See “Installing DIMMs
(memory).”
Garbled,
incorrect, or
incomplete text
The parallel cable may be loose or defective. Try the
following:
● Disconnect the parallel cable and reconnect it.
● Try printing a print job that you know works.
● If possible, attach the cable and printer to another
computer and try printing a print job that you know
works.
● Try using a new IEEE-1284 compliant parallel cable.
See “Accessories and ordering information.”
The wrong printer driver may have been selected while
installing the software. Verify the HP LaserJet 1100 is
selected in the printer properties.
The software application may be malfunctioning. Try
printing from another software application.
72 Chapter 8 Troubleshooting the printer
EN
Printed page problems (continued)
Problem
Solution
Missing graphics The file may have blank pages. Try the following:
or text
● Check the file to make sure that your file does not
contain blank pages.
The graphic settings in the printer properties may not be
correct for the type of job you are printing:
● Try a different graphic setting in the printer properties.
To access the printer properties, see “Printer
properties (driver).”
The printer driver may not work for the type of job you are
printing.
● Try using a different printer driver (software) such as
the driver for the HP LaserJet III. Note: Using a
different driver will remove access to some product
features.
Page format
changed
If the document was created while using an older or
different printer driver (printer software) or the printer
properties settings in the software are different, the page
format may change when trying to print using your new
printer driver or settings. To help eliminate this problem,
try the following:
● Create documents and print them using the same
printer driver (printer software) and printer property
settings regardless of the HP LaserJet printer to
which you are printing.
● Change your printer property settings. Try changing
resolution, paper size, font settings, and other
settings. See “Printer properties (driver).”
Graphics quality The graphics settings may be unsuitable for your print job.
● Check graphic settings in the printer properties and
adjust them as necessary, such as resolution. See
“Printer properties (driver).”
● Try using a different printer driver (software) such as
the driver for the HP LaserJet III. Note: Using a
different driver will remove access to some product
features.
EN
Finding the solution 73
Improving print quality
This section provides information on the following topics:
●
Image defect examples
●
Correcting print defects
Image defect examples
Light print or fade
Toner specks
Vertical lines
Gray background
74 Chapter 8 Troubleshooting the printer
Dropouts
Toner smear
EN
EN
Loose toner
Vertical repetitive
defects
Misformed
characters
Page skew
Curl or wave
Wrinkles or
creases
Improving print quality 75
Correcting print defects
Light print or fade
●
The toner supply is low. You may be able to temporarily extend
the toner cartridge life. See “Managing the toner cartridge.”
●
The paper may not meet HP’s paper specifications (for example,
the paper is too moist or too rough). See “Printer paper
specifications.”
●
If the whole page is light, the print density adjustment is too light
or EconoMode may be on. Adjust the print density and disable
EconoMode within the printer properties. See “Print using
EconoMode (save toner).”
Toner specks
●
The paper may not meet HP’s paper specifications (for example,
the paper is too moist or too rough). See “Printer paper
specifications.”
●
The printer may need to be cleaned. See “Cleaning the printer” or
“Cleaning the printer paper path.”
Dropouts
Note
●
A single sheet of paper may be defective. Try reprinting the job.
●
The moisture content of the paper is uneven or the paper has
moist spots on its surface. Try printing with new paper. See
“Printer paper specifications.”
●
The paper lot is bad. The manufacturing processes can cause
some areas to reject toner. Try a different kind or brand of paper.
●
The toner cartridge may be defective. See “Managing the toner
cartridge.”
If these steps do not correct the problem, contact an HP-authorized
dealer or service representative.
Vertical lines
●
The photosensitive drum inside the toner cartridge has probably
been scratched. Install a new HP toner cartridge. See “Changing
the toner cartridge.”
76 Chapter 8 Troubleshooting the printer
EN
Gray background
●
Decrease the print density setting. This will decrease the amount
of background shading. Access this setting under “Printer
properties (driver).”
●
Change the paper to a lighter basis weight. See “Printer paper
specifications.”
●
Check the printer’s environment; very dry (low humidity)
conditions can increase the amount of background shading.
●
Install a new HP toner cartridge. See “Changing the toner
cartridge.”
Toner smear
●
If toner smears appear on the leading edge of the paper, the
paper guides may be dirty. Wipe the paper guides with a dry, lintfree cloth. See “Printer components” or “Cleaning the printer.”
●
Check the paper type and quality.
●
Try installing a new HP toner cartridge. See “Changing the toner
cartridge.”
Loose toner
●
Clean the inside of the printer. See “Cleaning the printer.”
●
Check the paper type and quality. See “Printer paper
specifications.”
●
Try installing a new HP toner cartridge. See “Changing the toner
cartridge.”
Vertical repetitive defects
EN
●
The toner cartridge may be damaged. If a repetitive mark occurs
at the same spot on the page, install a new HP toner cartridge.
See “Changing the toner cartridge.”
●
Internal parts may have toner on them. See “Cleaning the
printer.” If the defects occur on the back of the page, the problem
will likely be corrected after a few more printed pages.
Improving print quality 77
Misformed characters
●
If characters are improperly formed, producing hollow images, the
paper stock may be too slick. Try a different paper. See “Printer
paper specifications.”
●
If characters are improperly formed, producing a wavy effect, the
laser scanner may need service. Verify that characters are
improperly formed on a self-test page. If so, contact an HPauthorized dealer or service representative. See “Service and
support.”
Page skew
●
Make sure the paper or other media is loaded correctly and that
the guides are not too tight or too loose against the paper stack.
See “Loading paper into the printer.”
●
The paper input bin may be too full. See “Loading paper into the
printer.”
●
Check the paper type and quality. See “Printer paper
specifications.”
Curl or wave
●
Check the paper type and quality. Both high temperature and
humidity will cause paper to curl. See “Printer paper
specifications.”
●
The paper may have sat for too long in the paper input tray. Turn
over the stack of paper in the tray. Also, try rotating the paper
180° in the paper input tray.
●
Try printing using the straight-through output path. See “Printer
paper output paths.”
Wrinkles or creases
●
Make sure that paper is loaded properly. See “Loading paper into
the printer.”
●
Check the paper type and quality. See “Printer paper
specifications.”
●
Try printing using the straight-through output path. See “Printer
paper output paths.”
●
Turn over the stack of paper in the tray or try rotating the paper
180° in the input tray.
78 Chapter 8 Troubleshooting the printer
EN
Cleaning the printer
During the printing process, paper, toner, and dust particles can
accumulate inside the printer. Over time, this buildup can cause print
quality problems, such as toner specks or smearing. The printer has
two cleaning modes that can correct and prevent these types of
problems:
EN
●
Cleaning the toner cartridge area
●
Cleaning the printer paper path
Cleaning the printer 79
Cleaning the toner
cartridge area
1
2
3
Cleaning the toner cartridge area is not
necessary on a regular basis. Before
cleaning, look for excessive toner in the
compartment.
WARNING!
Before cleaning the printer, turn the
printer off by unplugging the power cord,
and then wait for the printer to cool.
1
Turn the printer off by unplugging it,
and then wait for the printer to cool.
2
Open the printer door and remove
the toner cartridge.
CAUTION
To prevent damage, do not expose the
toner cartridge to light for more than a
few minutes. Cover it if necessary. Also,
do not touch the black-sponge, transfer
roller inside the printer. By doing so, you
can damage the printer.
3
With a dry, lint-free cloth, wipe any
residue from the paper path area
and the toner cartridge cavity.
4
Replace the toner cartridge and
close the printer door.
5
Plug the power cord back into the
printer.
4
5
80 Chapter 8 Troubleshooting the printer
EN
Cleaning the printer paper path
This process uses copier-grade paper to remove dust and toner from
the paper path. Do not use bond or rough paper. Use this process if
you are experiencing toner specks or dots on printouts. This process
will produce a page with toner debris, which should be discarded.
Note
EN
1
Ensure the printer is loaded with paper.
2
Ensure the printer is in the Ready state.
3
Press and hold the GO button for 20 seconds (if released before
20 seconds the printer will perform a reset). Paper will feed
through the printer.
After holding the GO button for 20 seconds, each of the three printer
lights will blink until the cleaning process is complete.
Cleaning the printer 81
Clearing printer paper jams
Occasionally, paper becomes jammed during a print job. Some of the
causes include the following:
Note
●
The paper input trays are loaded improperly or overfilled. See
“Loading paper into the printer.”
●
The paper output path is changed during rather than before a
print job.
●
Media that does not meet HP specifications is used. See “Printer
paper specifications.”
Always remove all paper from the paper input tray and straighten
the stack when new paper is added. This helps prevent multiple
sheets of paper from feeding through the printer at one time and
reduces paper jams. See the sticker which you placed on the printer
while setting up the hardware.
You will be notified of a paper jam by an error in the software and the
printer control panel lights. See “Printer light patterns.”
Typical paper jam locations
Note
●
Toner cartridge area: See “Removing a jammed page.”
●
Paper input tray areas: If the page is still sticking out of the
paper input tray, pull the page from the paper input tray until it is
fully removed. If the page cannot be removed in this way, see
“Removing a jammed page.”
●
Paper output paths: If the page is sticking out of the paper
output bin or path, pull it until it is fully removed. If the page
cannot be removed in this way, see “Removing a jammed page.”
Loose toner may remain in the printer after a paper jam. This will clear
after a few sheets have printed.
82 Chapter 8 Troubleshooting the printer
EN
Removing a jammed page
If the scanner is attached to the printer,
you may need to pull the printer to the
edge of the work space so the door
hangs over the edge to enable full door
extension.
1
2
1
Open the printer door. If the paper
can be removed without removing
the toner cartridge, do so; see step
3. Otherwise, continue with step 2.
2
Remove the toner cartridge and
place it aside, covering it with a
sheet of paper.
CAUTION
Paper jams in this area may result in
loose toner on the page. If you get any
toner on your clothes, wash them in cold
water. Hot water will permanently set the
toner into fabric.
CAUTION
To prevent damage to the toner
cartridge, do not expose it to light for
more than a few minutes. Cover it with a
sheet of paper.
Continued on next page.
EN
Clearing printer paper jams 83
3
3
With both hands, grasp the side of
the paper that is most visible (this
includes the middle) and then
carefully pull it free from the printer.
Note
If the paper tears, see “Paper jam:
removing torn pieces of paper.”
4
4
When the jammed paper has been
removed, replace the toner cartridge
and close the printer door.
Note
If you had to move the printer to the edge
of the desk to accommodate the
scanner, check the printer cable and
power connections to ensure they are
securely fastened.
You may need to reset the printer after
clearing a paper jam. See “Resetting the
printer.”
Note
Remove all paper from the paper input
tray and straighten the stack when new
paper is added.
84 Chapter 8 Troubleshooting the printer
EN
Paper jam: removing torn
pieces of paper
1
Sometimes a piece of jammed paper can
tear when being removed. Use the
following procedure to remove any small
pieces of paper left in the printer.
1
Make sure the toner cartridge is
installed and the printer door is
closed.
2
Turn the printer off and then back on.
As the printer restarts, the rollers will
advance the piece(s) of paper.
2
Note
Printers powered by 220-240 volts can
be turned off and on with the switch. See
“Turning the power off.”
3
3
Open the printer door and remove
the toner cartridge.
4
Remove the piece(s) of paper.
5
Reinstall the toner cartridge and
close the printer door.
If the paper does not come out, repeat
steps 1 through 5.
4
5
EN
Clearing printer paper jams 85
Changing the pickup roller
If the printer regularly mispicks (no paper
is fed through or more than one sheet
feeds through), you may need to change
or clean the pickup roller. See
“Accessories and ordering information”
to order a new pickup roller.
1
2
1
Unplug the power cord from the
printer, and then allow the printer to
cool.
2
Open the door and remove the toner
cartridge.
3
Locate the pickup roller.
4
Rotate the bottom of the pickup roller
towards the front of the printer.
Continued on next page.
3
4
86 Chapter 8 Troubleshooting the printer
EN
5
6
5
Gently pull the pickup roller straight
out.
6
Position the new part within the slot
of the old pickup roller.
7
Rotate the bottom of the new pickup
roller towards the back of the printer
until it snaps into place.
8
Use the eraser end of a pencil to
press the spring arm behind the
white cam roller.
WARNING!
Failure to complete this procedure can
cause damage to the printer.
7
9
Reinstall the toner cartridge and
close the printer door.
Note
Plug the printer in to turn it back on.
8
9
EN
Clearing printer paper jams 87
Cleaning the pickup roller
If you wish to clean the pickup roller
rather than replace it, follow the
instructions below:
Remove the pickup roller as described in
“Changing the pickup roller.”
1
1
Dab a lint-free cloth in isopropyl
alcohol, and then scrub the roller.
WARNING!
Alcohol is flammable. Keep the alcohol
and cloth away from open flame. Allow
alcohol to dry completely before closing
the printer and plugging in the power
cord.
2
2
Using a dry, lint-free cloth, wipe the
pickup roller to remove loosened
dirt.
3
Allow the pickup roller to completely
dry before reinstalling it in the
printer.
3
88 Chapter 8 Troubleshooting the printer
EN
Resetting the printer
To reset the printer, press and hold the Go button on the printer
control panel for 5 seconds.
EN
Resetting the printer 89
90 Chapter 8 Troubleshooting the printer
EN
9
Troubleshooting the
Copier/Scanner
This chapter provides information on the following subjects:
EN
●
Finding the solution
●
Improving scan/copy quality
●
Calibrating the scanner
●
Cleaning the scanner
●
Clearing scanner jams
●
Removing the scanner
91
Finding the solution
Use this section to find the solution to common scanner problems.
Scanning problems
●
The scanner did nothing
●
No preview appeared on screen
●
Scanned image is of poor quality
●
Part of the image did not scan or is missing text
●
The text cannot be edited
●
The scan takes too long
●
Error messages appear on the screen
Copying problems
●
No copy came out or the scanner did nothing
●
Copies are blank, missing images, or faded
92 Chapter 9 Troubleshooting the Copier/Scanner
EN
The scanner did nothing
Is the scanner correctly connected and latched to the printer?
The scanner must be connected and the attachment lever latched.
See the Quick Reference Guide for attachment instructions. See
“Removing the scanner” for instructions on removing the scanner.
CAUTION
To prevent damage, unplug the printer before checking the scanner
connection.
Have you printed a self-test page to verify the scanner is
recognized by the printer?
Verify the scanner is installed by printing a self-test page. See
“Printing a self-test page.” On the lower-left hand corner of the selftest page, the text will read: “Scanner Installed: Yes.” If the text reads
“No” instead, reboot your PC. If that does not work, reinstall the
HP LaserJet 1100 software. See the Quick Reference Guide included
with the HP LaserJet 1100A Printer•Copier•Scanner for software
installation instructions.
Is the wrong printer selected?
Verify the HP LaserJet 1100 is selected as the current printer when
you print. You may have to click Setup in the print screen to see
which printer is being used. Specify HP LaserJet 1100 if necessary.
Did you send a print or copy job before attempting to scan?
If a print or copy job was sent before attempting to scan, the scan will
occur after the other job is finished. The print job may still be in the
queue. Check the light status on the printer. See “Printer light
patterns.”
Is the printer parallel cable working and connected correctly?
The parallel cable may be defective. Try the following:
EN
●
Disconnect and then reconnect the parallel cable.
●
Try printing a print job you know prints.
●
If possible, attach the cable and printer to another PC and print
the job that you know prints.
●
Try using a new IEEE-1284 compliant parallel cable. See
“Accessories and ordering information.”
Finding the solution 93
Do you have other devices running on your computer?
The HP LaserJet 1100A Printer•Copier•Scanner may not share a
parallel port. If you have a sound card, external hard drive, or network
switchbox connected to the same parallel port as the
HP LaserJet 1100A, the other devices may be interfering. You must
disconnect the other devices to connect and use the
HP LaserJet 1100A or you must use two parallel ports on the
computer. You may need to add another parallel interface card. An
ECP parallel interface card is strongly recommended. Please see the
documentation that came with your PC for information on installing an
additional parallel interface card or resolving device conflicts.
94 Chapter 9 Troubleshooting the Copier/Scanner
EN
No preview appeared on screen
Are you currently copying or printing?
Wait for the copy or print job to be completed before scanning.
Is the original loaded correctly?
Verify the original is loaded correctly: narrow side first, top down in the
scanner paper input tray with the side-to-be scanned facing forward.
See “Loading Copier/Scanner originals.”
Is the scanner correctly connected and latched to the printer?
The scanner must be connected and the attachment lever latched.
See the Quick Reference Guide included with your scanner for
attachment instructions. See “Removing the scanner” for instructions
on removing the scanner.
CAUTION
To prevent damage, unplug the printer before checking the scanner
connection.
Is the wrong printer selected?
Verify the HP LaserJet 1100 is selected as the current printer when
you print.
EN
Finding the solution 95
Scanned image is of poor quality
Is the original a second generation photo or picture?
Reprinted photographs, such as in newspapers or magazines, are
printed using tiny dots of ink that make an interpretation of the original
photograph; thus, the quality is dramatically decreased. Often, the ink
dots form unwanted patterns that, when scanned and reprinted or
displayed, can be detected. If the following suggestions do not
provide a solution, you may need to use a better-quality version of the
original.
●
Try to eliminate the patterns by reducing the scanned image size.
See “Enhancing the scanned image.”
●
Print the scanned image to see if the quality is better. See below.
●
Try recalibrating the scanner. See “Calibrating the scanner.”
●
Verify your resolution and gray-scale settings are correct for the
type of scan job you are performing. See “Scanner resolution and
gray scale.”
Is the image quality better when printed?
The image displayed on screen is not always an accurate
representation of the quality of the scan.
●
Try adjusting the settings on your PC monitor to display more
colors (or levels of gray). Typically, this is adjusted by selecting
“Display” found in the Control Panel. See the documentation that
came with your PC.
●
Try adjusting the resolution and gray-scale settings in the scanner
software. To learn more about these settings, see “Scanner
resolution and gray scale.”
Is the image skewed (crooked)?
The original may have been loaded incorrectly. It is important to use
the paper guides when loading originals. See “Loading Copier/
Scanner originals.”
Does the scanned image have unwanted blots, lines, vertical
white stripes, or any other defect?
See “Improving scan/copy quality.”
Is the scanner dirty?
If the scanner is dirty, the image produced will not have optimum
clarity. See “Cleaning the scanner.”
Do graphics appear different from the original?
The graphics settings may not be suitable for the type of scan job you
are performing. Try changing the graphics settings. Access these
settings through the printer properties (driver). See “Printer properties
(driver).”
96 Chapter 9 Troubleshooting the Copier/Scanner
EN
Part of the image did not scan or is missing
text
Was the original loaded correctly?
Verify you loaded the original correctly. See “Loading Copier/Scanner
originals.”
Does the original have a colored background?
Colored backgrounds can cause images in the foreground to blend
too much. Try adjusting the settings before scanning or enhancing the
image after it has been scanned. See “Contrast sensitive originals.”
Also see “Scanner resolution and gray scale.”
Is the original longer than 762 mm (30 in.)?
The maximum scannable length is 762 mm (30 in.). If the page
exceeds the maximum length, the scanner will stop.
CAUTION
Do not try to pull the original out of the scanner, or you may damage
the scanner or your original. See “Clearing scanner jams.”
Is the original too small?
The minimum size supported in the Copier/Scanner for the HP 1100
is 50.8 by 90 mm (2 by 3.5 in.). The original may be jammed. See
“Clearing scanner jams.”
Are you using the Document Assistant?
Your default property settings for the Document Assistant may be set
to automatically perform a specific task other than the one you are
attempting. For example, the Document Assistant can be set to
automatically perform a scan to e-mail; thus your image will not show
up on screen but instead will be attached to an e-mail message as a
file. See the online help for instructions on changing the Document
Assistant properties. See “Accessing the online help.”
EN
Finding the solution 97
The text cannot be edited
Have you specified either the Document Assistant or the
LaserJet Document Desktop to Edit text (OCR)?
Text remains as a single image until it is run through the OCR (Optical
Character Recognition) application, which will convert the single
image into text you can edit. See “Editing scanned text (OCR).”
Is the correct word-processing application linked with the OCR
application?
Your OCR application may be linked to a word processing application
that does not perform this task. See the HP online help for information
on linking applications.
Does the original have text that is tightly spaced?
The OCR application may have difficulty recognizing text that is tightly
spaced. For example, the text run through the OCR application may
have combined characters such as rn appearing as m or letters may
be left out.
Is the original of poor quality?
The accuracy of the OCR application depends on the quality, size,
and structure of the original and the quality of the scan itself. Verify
your original is of good quality.
Does the original have a colored background?
Colored backgrounds can cause images in the foreground to blend
too much. Try adjusting the settings before scanning or enhancing the
image after it has been scanned. See “Contrast sensitive originals.”
Also see “Scanner resolution and gray scale.”
98 Chapter 9 Troubleshooting the Copier/Scanner
EN
The scan takes too long
Do you have your resolution and gray scale set too high?
Having the resolution and gray scale set high will cause the scan job
to take longer and will result in larger files. Scanning or copying with
the correct resolution and gray scale settings for your job is important
to obtain good results. To learn more about resolution and gray scale,
see “Scanner resolution and gray scale.”
Did you send a print or copy job before attempting to scan?
If a print or copy job was sent before attempting to scan, the scan will
occur after the other job is finished.
Is your printer set for bi-directional communication?
See the documentation that came with your PC to change bios
settings.
EN
Finding the solution 99
Error messages appear on the screen
Unable to activate TWAIN source
●
If you are acquiring an image from another device, such as a
digital camera or another scanner, make sure the other device is
TWAIN compliant. Non-TWAIN-compliant devices do not work
with the HP LaserJet 1100A Printer•Copier•Scanner software.
●
Be sure that you have connected the parallel cable that came in
your package to the correct parallel port on the back of your PC. If
you have another parallel port, try attaching the parallel cable to
the other port. Make sure you have an SPP-(bi-directional) or
ECP-compliant parallel port on your computer. An SPP parallel
port is the minimum; an ECP parallel port is strongly
recommended. For more information on your parallel port, please
see the documentation that came with your PC.
●
The HP LaserJet 1100A Printer•Copier•Scanner may not share a
parallel port. If you have a sound card, external hard drive, or
network switchbox connected to the same parallel port as the
HP LaserJet 1100A, the other device may interfere. You must
disconnect the other device to connect and use the
HP LaserJet 1100A or you must use two parallel ports on the PC.
You may need to add another parallel interface card. An ECP
parallel interface card is strongly recommended. Please see the
documentation that came with your PC for information on
installing an additional parallel interface card or resolving device
conflicts.
100 Chapter 9 Troubleshooting the Copier/Scanner
EN
No copy came out or the scanner did nothing
Is paper loaded in the printer paper input tray?
Load paper in the printer. See “Loading paper into the printer.”
Is the original loaded correctly?
Verify the original is loaded correctly: narrow side first and top down in
the scanner paper input tray. See “Loading Copier/Scanner originals.”
Is the scanner correctly connected and latched to the printer?
The scanner must be connected and the attachment lever latched.
See the Quick Reference Guide for attachment instructions. See
“Removing the scanner” for instructions on removing the scanner.
CAUTION
To prevent damage, unplug the printer before checking the scanner
connection.
Is the wrong printer selected?
Verify that the HP LaserJet 1100 is selected as the current printer
when you print. You may have to click Setup in the print screen to see
which printer is being used. Specify HP LaserJet 1100 if necessary.
Have you printed a self-test page to verify the scanner is
recognized by the printer?
Verify the scanner is installed by printing a self-test page. See
“Printing a self-test page.” On the lower-left hand corner of the selftest page, the text will read: “Scanner Installed: Yes.” If the text reads
“No” instead, reboot your PC. If that does not work, reinstall the
HP LaserJet 1100 software. See the Quick Reference Guide included
with the HP LaserJet 1100A Printer•Copier•Scanner for software
installation instructions.
Did you send a print job before attempting to copy?
If a print job was sent before the copy job, the copy will be made after
the print job is finished.
EN
Finding the solution 101
Copies are blank, missing images, or faded
Are you making a Quick Copy when you should be using the
Copier Control Panel?
The Quick Copy settings may not produce good results for the type of
copy job you are attempting. See “Copy overview.”
Is the protective tape still on the printer toner cartridge?
Each new toner cartridge is packaged with protective plastic tape.
See “Changing the toner cartridge” to verify the protective tape has
been removed.
Is the toner cartridge low on toner?
Copies are made using the printer, so if the toner cartridge is low on
toner, the copies will be faded. The life of the toner cartridge may be
extended. See “Redistributing toner.”
Is the wrong printer selected?
Verify the HP LaserJet 1100 is selected as the current printer when
you print. You may have to click on Setup in the print screen to see
which printer is being used. Specify HP LaserJet 1100 if necessary.
If the problem is software related, access the online help. See
“Accessing the online help.”
Is the original of poor quality?
The accuracy of the copy depends on the quality and size of the
original. If your original is too light, the copy may not be able to
compensate, even if the contrast is adjusted. Try adjusting the
contrast with the Copier Control Panel. See “Using the Copier Control
Panel.”
Does the original have a colored background?
Colored backgrounds can cause images in the foreground to blend
too much or the background to appear in a different shade. Try
adjusting the settings before copying or enhancing the image after it
has been copied with the Copier Control Panel. See “Using the
Copier Control Panel.” Also see “Scanner resolution and gray scale.”
Is the original longer than 762 mm (30 in.)?
The maximum scannable length is 762 mm (30 in.). If the page
exceeds the maximum length, the scanner will stop.
CAUTION
Do not try to pull the original out of the scanner because you may
damage the scanner or your original. See “Clearing scanner jams.”
Is the original too small?
The minimum size supported in the HP 1100 Copier/Scanner is 50.8
by 90 mm (2 by 3.5 in.). The original may be jammed. See “Clearing
scanner jams.”
102 Chapter 9 Troubleshooting the Copier/Scanner
EN
Improving scan/copy quality
This section provides information on the following topics:
●
Preventative steps
●
Image defect examples
●
Correcting scan/copy defects
Preventative steps
There are a few, simple steps you can take to improve scan quality:
EN
●
Load the paper or media correctly. If the paper is loaded
incorrectly, it may skew, causing unclear images and problems
with the OCR application. See “Loading Copier/Scanner
originals.”
●
Adjust the software settings according to the end use of the
image you will receive from scanning or copying. See “Enhancing
the scanned image” and “Scanner resolution and gray scale.”
●
Use quality originals.
Improving scan/copy quality 103
Image defect examples
Vertical white
stripes
Blank pages
Too light or dark
Unwanted lines
Black dots or
streaks
Unclear text
Image prints at
reduced size
104 Chapter 9 Troubleshooting the Copier/Scanner
EN
Correcting scan/copy defects
Vertical white stripes
●
The scanner may need recalibrated. See “Calibrating the
scanner.”
●
The paper may not meet HP’s paper specifications (for example,
the paper is too moist or too rough). See “Printer paper
specifications.”
Blank pages
●
The original may have been loaded backwards. Load the original
with the narrow side down and the side-to-be-scanned facing
toward the front of the scanner. See “Loading Copier/Scanner
originals.”
●
The paper may not meet HP’s paper specifications (for example,
the paper is too moist or too rough). See “Printer paper
specifications.”
Too light or dark
●
Try adjusting the settings.
• Copier Control Panel: see “Using the Copier Control Panel.”
• Quick Copy settings: see “Quick Copy settings.”
• Verify you have the correct resolution and gray-scale settings.
See “Scanner resolution and gray scale.”
●
You may need to change the properties settings for the
associated function in the Document Assistant or the
HP Document Desktop. Learn about these settings in the online
help. See “Accessing the online help.”
●
See “Calibrating the scanner.”
Unwanted lines
EN
●
There may be ink, glue, correction fluid, or an unwanted
substance on the scanner sensor. Try cleaning the scanner. See
“Cleaning the scanner.”
●
The scanner may need recalibrated. See “Calibrating the
scanner.”
Improving scan/copy quality 105
Black dots or streaks
●
There may be ink, glue, correction fluid, or an unwanted
substance on the scanner sensor. Try cleaning the scanner. See
“Cleaning the scanner.”
Unclear text
●
Try adjusting the settings.
• Copier Control Panel: see “Using the Copier Control Panel.”
• Quick Copy settings: see “Quick Copy settings.”
• Verify you have the correct resolution and gray-scale settings.
See “Scanner resolution and gray scale.”
●
You may need to change the properties settings for the
associated function in the Document Assistant or the
HP Document Desktop. Learn about these settings in the online
help. See “Accessing the online help.”
Image prints at reduced size
●
The HP software settings may be set to reduce the scanned
image. See the following:
• “LaserJet Toolbox” to change the settings in the Document
Assistant and the LaserJet Document Desktop.
• “Quick Copy settings” to change the settings for Quick Copies.
• “Using the Copier Control Panel” to change the settings for the
Copier Control Panel.
106 Chapter 9 Troubleshooting the Copier/Scanner
EN
Calibrating the scanner
If images are showing defects, the scanner may need to be
calibrated. First verify the problem is not printer related. If the problem
is not printer related, clean the scanner. See “Cleaning the scanner.”
If image defects persist, then calibrate the scanner. To access the
calibration utility, see “Accessing the Calibration utility.”
Note
1
Create a page that measures 219 mm by at least 153 mm (8.6 in.
by at least 6 in.). Use bright, white paper.
2
Insert the page into the paper input tray, wide side first, and begin
the calibration.
For more information about calibration, see the online help.
Accessing the Calibration utility
WIndows 9x & NT 4.0
From the Document Assistant, click Tools, and then Calibration.
Windows 3.1x
From the Program Manager, double-click the HP LaserJet 1100
icon, and then double-click Calibrate Scanner.
EN
Calibrating the scanner 107
Cleaning the scanner
You may need to clean the scanner after
scanning or copying items that have ink
which smudges or that have excessive
amounts of dirt or dust.
To clean the scanner, follow the
instructions below:
1
1
Unplug the printer to turn the power
off, and then wait for the scanner to
cool.
2
Open the scanner door.
3
Dampen a clean, cotton cloth with
rubbing alcohol (pH7 or neutral pH)
or glass cleaner. Gently rub back
and forth on the white CIS roller with
the damp cloth while slowly turning
the CIS roller.
2
WARNING!
Alcohol is flammable. Keep the alcohol
and cloth away from open flame. Allow
alcohol to dry completely before
plugging in the power cord.
3
4
4
WARNING!
Ensure the scanner is completely dry
before plugging in the printer power
cord.
Spray glass cleaner on another
piece of clean, cotton cloth and
carefully clean the glass on the
image sensor.
108 Chapter 9 Troubleshooting the Copier/Scanner
EN
Clearing scanner jams
Occasionally, paper becomes jammed during a scan or copy job.
Some of the causes include the following:
●
The paper input trays are loaded improperly. See “Loading
Copier/Scanner originals.”
●
The original is too small or large to be correctly fed through the
scanner. See “Supported paper sizes and types (media).”
●
The original exceeds the maximum page length. See “Supported
paper sizes and types (media).”
●
Media that does not meet HP specifications is used. See “Printer
paper specifications.”
An error message will appear on your PC screen when a jam occurs.
EN
Clearing scanner jams 109
Clearing jams
1
1
Open the scanner door.
2
Locate and grasp the original on the
top or bottom side, whichever side
sticks out further, and then pull
gently and steadily.
3
If necessary, roll the white wheel in
the opposite direction you are pulling
the original. For example, if you are
pulling the original from the bottom,
roll the wheel up.
If the jammed original is not visible, see
“Clearing hard-to-reach jams.”
2
Note
Always remove all originals from the
input tray and straighten the stack when
new originals are added.
3
110 Chapter 9 Troubleshooting the Copier/Scanner
EN
Clearing hard-to-reach
jams
Remove the scanner from the printer.
See “Removing the scanner.”
CAUTION
Removing the scanner without first
unplugging the printer may damage your
printer and scanner. The printer must
also be unplugged before reinstalling the
scanner on the printer.
1
1
Rotate the scanner so the top is
facing toward the ground.
2
Gently shake the scanner until the
original falls out the top.
2
EN
Clearing scanner jams 111
Removing the scanner
To remove the scanner from the printer, follow the instructions below:
CAUTION
Removing the scanner without first unplugging the printer may damage
your printer and scanner. The printer must also be unplugged before
reinstalling the scanner on the printer.
1
Unplug the printer to turn it off.
2
Move the scanner lever, located under the scanner, from the left
to the right to disengage the connector.
3
Grasp the scanner on each side, rotate the bottom portion
away from the printer, and then lift the entire scanner up and
clear from the printer.
112 Chapter 9 Troubleshooting the Copier/Scanner
EN
10
Service and support
This chapter provides information on the following topics:
EN
●
Availability
●
Obtaining hardware service
●
Guidelines for repacking the printer
●
Guidelines for repacking the scanner
●
Service information form
●
HP Support
●
Worldwide sales and service offices
113
Availability
HP provides a variety of service and support options around the
world. Availability of these programs will vary depending upon your
location.
Obtaining hardware service
If your hardware should fail during the warranty period, HP offers the
following support options:
●
HP repair services: HP will arrange to pick up the unit, repair it,
and return it to you within 5-10 days, depending on your location.
●
HP authorized service provider: You can return the unit to a
local authorized service dealer.
●
Express Exchange: HP provides a reconditioned permanent
replacement printer to you on the next working day for calls
received before 2 p.m. Pacific Standard Time (U.S. and Canada
only).
114 Chapter 10 Service and support
EN
Guidelines for repacking the printer
CAUTION
●
If possible, include print samples and 5-10 sheets of paper or
other media that did not print correctly.
●
Remove and retain any DIMMs (memory) installed in the printer.
See “Removing DIMMs.”
●
Remove the scanner. See “Removing the scanner.”
●
Remove and retain any cables and optional accessories installed
in the printer.
Static electricity can damage DIMMs. When handling DIMMs, either
wear a grounded antistatic wrist strap or frequently touch the surface
of the DIMMs’ antistatic package, then touch bare metal on the printer.
●
CAUTION
EN
Remove and retain the toner cartridge.
To prevent damage to the toner cartridge, store the cartridge in its
original packing material or store it so that it is not exposed to light.
●
Use the original shipping container and packing material, if
possible. Shipping damage as a result of inadequate packing is
your responsibility. If you have already disposed of the printer’s
packing material, contact a local mailing service for information
on repacking the printer.
●
Include a completed copy of the Service information form. See
“Service information form.”
●
HP recommends insuring the equipment for shipment.
Guidelines for repacking the printer 115
Guidelines for repacking the scanner
●
Remove the scanner from the printer. See “Removing the
scanner.”
●
Use the shipping container and packing material in which the
replacement unit came, if possible. Shipping damage as a result
of inadequate packing is your responsibility. If you have already
disposed of the scanner’s packing material, contact a local
mailing service for information on repacking the scanner.
●
Include a completed copy of the Service information form. See
“Service information form.”
●
HP recommends insuring the equipment for shipment.
116 Chapter 10 Service and support
EN
Service information form
Service information form
Who is returning the equipment?
Date:
Person to contact:
Phone:
Alternate contact:
Phone:
Return shipping address:
Special shipping
instructions:
What is being sent?
Model number:
Serial number:
Please attach any relevant printouts when returning equipment. Do not ship
accessories that are not required to complete the repair (manuals, cleaning supplies,
etc.)
What needs to be done?
1. Describe the conditions of the failure (What was the failure? What were you doing
when the failure occurred? What software were you running? Can you make the
failure reoccur?)
2. If the failure is intermittent, how much time elapses between failures?
3. Is the unit connected to any of the following? (Please provide manufacturer and
model numbers.)
Personal Computer:
Modem:
Network:
4. Additional comments:
EN
Service information form 117
HP Support
Thank you for your purchase. Along with your product, you receive a
variety of support services from Hewlett-Packard and our support
partners that are designed to give you the results you need, quickly
and professionally.
Please have the model number, serial number, date of purchase, and
description of the problem ready for your HP Support representative.
The following support information is available:
●
Customer Support and product repair assistance (U.S. and
Canada)
●
European Customer Support Center
●
Online services
●
Obtaining software utilities and electronic information
●
HP direct ordering for accessories or supplies
●
HP Support Assistant compact disc
●
HP service information
●
HP SupportPack
●
HP FIRST
Customer Support and product repair
assistance (U.S. and Canada)
Call (1) (208) 323-2551 Monday through Friday from 6 am to 10 pm
and Saturday from 9 am to 4 pm (Mountain Time) free of charge
during the warranty period. However, your standard long-distance
phone charges still apply. Have your system nearby and your serial
number ready when calling.
Post-warranty telephone assistance is available to answer your
product questions. Call (1) (900) 555-1500 ($2.50* per minute,
maximum charge of $25.00 per call, U.S. only) or call 1-800-999-1148
($25* per call, Visa or MasterCard, U.S. and Canada) Monday
through Friday from 6 am to 10 pm and Saturday from 9 am to 4 pm
(Mountain Time). Charges begin only when you connect with a
support technician. *Prices subject to change.
118 Chapter 10 Service and support
EN
European Customer Support Center
language and in-country options available
Open Monday through Friday 8:30–18:00 CET
HP provides a free telephone support service during the warranty
period. By calling a telephone number listed below, you will be
connected to a responsive team waiting to help you. If you require
support after your warranty has expired, you can receive support for a
fee through the same telephone number. The fee is charged on a
per-incident basis. When calling HP, have the following information
ready: product name and serial number, date of purchase, and
description of the problem.
English
Ireland:
(353) (1) 662-5525
U.K.:
(44) (171) 512-5202
Dutch
International:
(44) (171) 512-5202
Belgium:
(32) (2) 626-8806
Netherlands:
(31) (20) 606-8751
French
France:
(33) (01) 43-62-3434
Belgium:
(32) (2) 626-8807
Switzerland:
(41) (84) 880-1111
German
Germany:
(49) (180) 525-8143
Austria:
(43) (1) 0660-6386
Norwegian
Norway:
(47) 2211-6299
Danish
Denmark:
(45) 3929-4099
Finnish
Finland:
(358) (9) 0203-47288
Swedish
Sweden:
EN
(46) (8) 619-2170
HP Support 119
Italian
Italy:
(39) (2) 264-10350
Spanish
Spain:
(34) (90) 232-1123
Portuguese
Portugal:
(351) (1) 441-7199
In-country/region support numbers: If you require support after
your warranty has expired, additional product repair services, or if
your country/region is not listed below, see “Worldwide sales and
service offices.”
Argentina
787-8080
Australia
(61) (3) 272-8000
Brazil
022-829-6612
Canada
(1) (905) 206-4663
China
(86) (10) 65053888-5959
Chile
800-360999
Czech Republic
(42) (2) 471-7321
Greece
(30) (1) 689-6411
Hong Kong
(852) 800-96-7729
Hungary
(36) (1) 343-0310
India
(91) (11) 682-6035
(91) (11) 682-6069
Indonesia
(62) (21) 350-3408
Korea
(82) (2) 3270-0700
Korea outside Seoul, call
(82) (080) 999-0700
Malaysia
(60) (3) 295-2566
Mexico (Mexico City)
01 800-22147
Mexico (outside Mexico City)
01 800-90529
New Zealand
(64) (9) 356-6640
Philippines
(63) (2) 894-1451
Poland
(48) (22) 37-5065
Portugal
(351) (1) 301-7330
120 Chapter 10 Service and support
EN
EN
Russia
(7) (95) 923-5001
Singapore
(65) 272-5300
Taiwan
(886) (02) 717-0055
Thailand
66 (2) 661-4011-4
Turkey
(90) (212) 224-5925
HP Support 121
Online services
For 24-hour access to information over your modem, we suggest
these services:
World Wide Web URL
Printer drivers, updated HP printer software, plus product and support
information may be obtained from the following URLs:
in the U.S.
http://www.hp.com/support/lj1100
in Europe
http://www2.hp.com
Printer drivers may be obtained from the following sites:
in Korea
http://www.hp.co.kr
in Taiwan
http://www.hp.com.tw
or the local driver website
http://www.dds.com.tw
America Online
America Online/Bertelsmann is available in the U.S., France,
Germany, and U.K. - Printer drivers, updated HP printer software, and
support documentation to help answer your questions about which
HP products are available. Use Keyword HP to start your tour or call
1-800-827-6364 preferred customer # 1118 to subscribe. In Europe,
call the appropriate number below:
Austria
0222 58 58 485
France
++353 1 704 90 00
Germany
0180 531 31 64
Switzerland
0848 80 10 11
United Kingdom
0800 279 1234
CompuServetm
Printer drivers, updated HP printer software, and interactive sharing
of technical information with other members is available on
CompuServe’s “HP User’s forums” (GO HP), or call 1-800-524-3388
and ask for representative #51 to subscribe. (CompuServe is also
available in the U.K., France, Belgium, Switzerland, Germany, and
Austria.)
122 Chapter 10 Service and support
EN
Obtaining software utilities and electronic
information
Obtain printer drivers.
U.S. and Canada
Phone:
(1) (805) 257-5565
Mail:
Hewlett-Packard Co.
P.O. Box 907
Santa Clara, CA 91380-9007
U.S.A.
Asia-Pacific countries/regions
Contact Fulfill Plus at (65) 740-4477 (Hong Kong, Indonesia,
Philippines, Malaysia, or Singapore). For Korea, call (82) (2)
3270-0805 or (82) (2) 3270-0893.
Australia, New Zealand, and India
For Australia and New Zealand, call (61) (2) 565-6099.
For India, call (91) (11) 682-6035.
Europe
Call (44) (142) 986-5511.
EN
HP Support 123
HP direct ordering for accessories or supplies
Call 1-800-538-8787 (U.S.) or 1-800-387-3154 (Canada).
HP Support Assistant compact disc
This support tool offers a comprehensive online information system
designed to provide technical and product information on HP
products. To subscribe to this quarterly service in the U.S. or Canada,
call 1-800-457-1762. In Hong Kong, Indonesia, Malaysia, or
Singapore, call Fulfill Plus at (65) 740-4477.
HP service information
To locate HP-Authorized Service Providers, call 1-800-243-9816
(U.S.) or 1-800-387-3867 (Canada).
HP SupportPack
Call 1-800-835-4747 (U.S. only)
All other locations, contact your authorized dealer.
HP FIRST
HP FIRST fax will deliver detailed troubleshooting information on
common software and troubleshooting tips for your HP product. Call
from any touch tone phone and request up to three documents per
call. These documents will be sent to the fax of your choice.
Australia
(61) (0) 3 9272 2627
Austria
0660-8128
Belgium (Dutch)
0800 1 1906
Belgium (French)
0800 1 7043
Canada
1-800-333-1917
China
+86 (0) 10 6505 5280
Denmark
800-10453
English (outside of U.K.)
+31 20 681 5792
Finland
800-13134
France
0800-905900
Germany
0130-810061
124 Chapter 10 Service and support
EN
EN
Hong Kong
(852) 2506-2422
Hungary
(36) (1) 252-4647
India
+91 (0) 11 682 6031
Indonesia
+62 (0) 21 352 2044
Italy
1678-59020
Korea
+82 (0) 02 769 0543
Malaysia
+60 (0) 3 298 2478
Netherlands
0800-0222420
New Zealand
+64 (0) 09 356 6642
Norway
800-11319
Portugal
05 05 313342
Philippines
+65 275 7251
Singapore
+65 275 7251
Spain
900-993123
Sweden
020-79-5743
Switzerland (German)
0800-551527
Switzerland (French)
0800-551526
Taiwan
(886) (2) 719-5589
Thailand
+66 (0) 2 661 3511
United Kingdom
0800-960271
United States
1 (800) 333-1917
HP Support 125
Worldwide sales and service offices
Before calling an HP Sales and Service office, be sure to contact the appropriate
Customer Support Center number listed in the “HP Support” section. Products should
not be returned to the following offices.
Argentina
Canada
Hewlett-Packard Argentina S.A.
Montañeses 2140/50/60
1428 Buenos Aires
Phone: (54) (1) 787-7100
Fax: (54) (1) 787-7213
Hewlett-Packard (Canada) Ltd.
17500 Trans Canada Highway
South Service Road
Kirkland, Québec H9J 2X8
Phone: (1) (514) 697-4232
Fax: (1) (514) 697-6941
Australia
Hewlett-Packard Australia Ltd.
31-41 Joseph Street
Blackburn, VIC 3130
Phone: (61) (3) 272-2895
Fax: (61) (3) 898-7831
Hardware Repair Center:
Phone: (61) (3) 272-8000
Extended Warranty Support:
Phone: (61) (3) 272-2577
Customer Information Center:
Phone: (61) (3) 272-8000
Hewlett-Packard (Canada) Ltd.
5150 Spectrum Way
Mississauga, Ontario L4W 5G1
Phone: (1) (905) 206-4725
Fax: (1) (905) 206-4739
Chile
Hewlett-Packard de Chile
Avenida Andres Bello 2777 of. 1
Los Condes
Santiago, Chile
Austria
China
Hewlett-Packard GmbH
Lieblgasse 1
A-1222 Vienna
Phone: (43) (1) 25000-555
Fax: (43) (1) 25000-500
China Hewlett-Packard Co. Ltd.
Level 5, West Wing Office
China World Trade Center
No. 1, Jian Guo Men Wai Avenue
Beijing 100004
Phone: (86) (10) 6505-3888,x. 5450
Fax: (86) (10) 6505-1033
Hardware Repair Center and Extended
Warranty Support:
Phone: (86) (10) 6262-5666x. 6101/2
(86) (10) 6261-4167
Belgium
Hewlett-Packard Belgium S.A. NV
Boulevard de la Woluwe-Woluwedal 100102
B-1200 Brussels
Phone: (32) (2) 778-31-11
Fax: (32) (2) 763-06-13
Brazil
Edisa Hewlett-Packard SA
Alameda Rio Negro 750
06454-050 Alphaville - Barueri-SP
Phone: (55) (11)- 7296-8000
126 Chapter 10 Service and support
Colombia
Hewlett-Packard Colombia
Calle 100 No. 8A -55
Torre C Oficina 309
Bogotá, Colombia
EN
Czech Republic
Germany
Hewlett-Packard s. r. o.
Novodvorská 82
CZ-14200 Praha 4
Phone: (42) (2) 613-07111
Fax: (42) (2) 471-7611
Hewlett-Packard GmbH
Herrenberger Straße 130
71034 Böblingen
Phone: (49) (180) 532-6222
(49) (180) 525-8143
Fax: (49) (180) 531-6122
Denmark
Hewlett-Packard A/S
Kongevejen 25
DK-3460 Birkerød
Denmark
Phone: (45) 3929 4099
Fax: (45) 4281-5810
Hewlett-Packard Hellas
62, Kifissias Avenue
GR-15125 Maroussi
Phone: (30) (1) 689-6411
Fax: (30) (1) 689-6508
Far East Region
Hungary
Hewlett-Packard Asia Pacific Ltd.
17-21/F Shell Tower, Times Square
1 Matheson Street, Causeway Bay
Hong Kong
Phone: (852) 2599-7777
Fax: (852) 2506-9261
Hardware Repair Center:
Phone: (852) 2599-7000
Extended Warranty Support:
Phone: (852) 2599-7000
Customer Information Center:
Phone: (852) 2599-7066
Hewlett-Packard Magyarország Kft.
Erzsébet királyné útja 1/c.
H-1146 Budapest
Phone: (36) (1) 461-8111
Fax: (36) (1) 461-8222
Hardware Repair Center:
Phone: (36) (1) 343-0312
Customer Information Center:
Phone: (36) (1) 343-0310
Finland
Hewlett-Packard Oy
Piispankalliontie 17
FIN-02200 Espoo
Phone: (358) (9) 887-21
Fax: (358) (9) 887-2477
France
Hewlett-Packard France
42 Quai du Point du Jour
F-92659 Boulogne Cedex
Phone: (33) (146) 10-1700
Fax: (33) (146) 10-1705
EN
Greece
India
Hewlett-Packard India Ltd.
Paharpur Business Centre
21 Nehru Place
New Delhi 110 019
Phone: (91) (11) 647-2311
Fax: (91) (11) 646-1117
Hardware Repair Center and Extended
Warranty Support:
Phone: (91) (11) 642-5073
(91) (11) 682-6042
Italy
Hewlett-Packard Italiana SpA
Via Giuseppe di Vittorio, 9
Cernusco Sul Naviglio
I-20063 (Milano)
Phone: (39) (2) 921-21
Fax: (39) (2) 921-04473
Worldwide sales and service offices 127
Korea
New Zealand
Hewlett-Packard Korea
25-12,
Yoido-dong, Youngdeungpo-ku
Seoul 150-010
Phone: (82) (2) 769-0114
Fax: (82) (2) 784-7084
Hardware Repair Center:
Phone: (82) (2) 3270-0700
(82) (2) 707-2174 (DeskJet)
(82) (2) 3270-0710 (Hardware)
Extended Warranty Support:
Phone: (82) (2) 3770-0365 (Bench)
(82) (2) 769-0500 (Onsite)
Hewlett-Packard (NZ) Limited
Ports of Auckland Building
Princes Wharf, Quay Street
P.O. Box 3860
Auckland
Phone: (64) (9) 356-6640
Fax: (64) (9) 356-6620
Hardware Repair Center and Extended
Warranty Support:
Phone: (64) (9) 0800-733547
Customer Information Center:
Phone: (64) (9) 0800-651651
Latin American
Headquarters
5200 Blue Lagoon Drive Suite 950
Miami, FL 33126,USA
Phone: (1) (305) 267-4220
México
Hewlett-Packard de México, S.A. de C.V.
Prolongación Reforma No. 700
Lomas de Santa Fe
01210 México, D.F.
Phone: 01-800-22147
Outside Mexico City
Phone: 01 800-90529
Norway
Hewlett-Packard Norge A/S
Postboks 60 Skøyen
Drammensveien 169
N-0212 Oslo
Phone: (47) 2273-5600
Fax: (47) 2273-5610
Poland
Hewlett-Packard Polska
Al. Jerozolimskic 181
02-222 Warszawa
Phone: (48-22) 608-77-00
Fax: (48-22) 608-76-00
Russia
Middle East/Africa
ISB HP Response Center
Hewlett-Packard S.A.
Rue de Veyrot 39
P.O. Box 364
CH-1217 Meyrin - Geneva
Switzerland
Phone: (41) (22) 780-4111
Netherlands
Hewlett-Packard Nederland
BV Startbaan 16
NL-1187 XR Amstelveen
Postbox 667
NL-1180 AR Amstelveen
Phone: (31) (020) 606-87-51
Fax: (31) (020) 547-7755
128 Chapter 10 Service and support
AO Hewlett-Packard
Business Complex Building #2
129223, Moskva, Prospekt Mira VVC
Phone: (7) (95) 928-6885
Fax: (7) (95) 974-7829
Singapore
Hewlett-Packard Singapore
(Sales) Pte Ltd
450 Alexandra Road
Singapore (119960)
Phone: (65) 275-3888
Fax: (65) 275-6839
Hardware Repair Center and Customer
Information Center:
Phone: (65) 272-5300
Extended Warranty Support:
Phone: (65) 272-5333
EN
Spain
Turkey
Hewlett-Packard Española, S.A.
Carretera de la Coruña km 16.500
E-28230 Las Rozas, Madrid
Phone: (34) (1) 626-1600
Fax: (34) (1) 626-1830
Hewlett-Packard Company
Bilgisayar Ve ölçüm Sistemleri AS
19 Mayis Caddesi Nova
Baran Plaza Kat: 12
80220 Sisli-Istanbul
Phone: (90) (212) 224-5925
Fax: (90) (212) 224-5939
Sweden
Hewlett-Packard Sverige AB
Skalholtsgatan 9
S-164 97 Kista
Phone: (46) (8) 444-2000
Fax: (46) (8) 444-2666
United Kingdom
Hewlett-Packard Ltd.
Cain Road
Bracknell
Berkshire RG12 1HN
Phone: (44) (134) 436-9222
Fax: (44) (134) 436-3344
Switzerland
Hewlett-Packard (Schweiz) AG
In der Luberzen 29
CH-8902 Urdorf/Zürich
Phone: (41) (084) 880-11-11
Fax: (41) (1) 753-7700
United States
Taiwan
Hewlett-Packard Taiwan Ltd.
8th Floor
337, Fu-Hsing North Road
Taipei, 10483
Phone: (886) (02) 717-0055
FAX: (886) (02) 514-0276
Hardware Repair Center, call:
North (886) (02) 717-9673
Central (886) (04) 327-0153
South (886) (080) 733-733
Extended Warranty Support Contact:
Phone: (886) (02) 714-8882
Hewlett-Packard Company
11311 Chinden Blvd.
Boise, ID 83714
USA
Phone: (208) 323-2551
HP FIRST fax: (800) 333-1917 or (208)
334-4809
Authorized repair: (800) 243-9816
Venezuela
Hewlett-Packard de Venezuela S.A.
Los Ruices Norte
3A Transversal
Edificio Segre Caracas 1071
Phone: (58) (2) 239-4244
Fax: (58) (2) 239-3080
Thailand
Hewlett-Packard (Thailand) Ltd.
23-25/f Vibulthani Tower II
3199 Rama 4 Rd, Klongtan
Klongtoey, Bangkok 10110
Thailand
Phone: (66) (2) 661-3900-34
Fax: (66) (2) 661-3935-37
Hardware Repair Center:
Phone: (66) (2) 661-3900 ext. 6001/ 6002
Customer Information Center:
Phone: (66) (2) 661-3900 ext. 3211, 3232
EN
Worldwide sales and service offices 129
130 Chapter 10 Service and support
EN
A
Printer specifications
This chapter provides information on the following topics:
EN
●
Specifications
●
FCC compliance
●
Environmental Product Stewardship Program
●
Material safety data sheet
●
Regulatory statements
131
Specifications
Printer specifications
Environmental specifications
Operating environment
Storage environment
Printer plugged into an AC outlet:
● Temperature: 10 °C to 32.5 °C (50 °F to 90.5 °F)
● Humidity: 20%–80% (no condensation)
Printer unplugged from an AC outlet:
Temperature: 0 °C to 40 °C (32 °F to 104 °F)
● Humidity: 10%–90% (no condensation)
●
Acoustics
Noise level
During printing: 6.1 Bels sound power level
(per ISO 9296)(HP LaserJet 1100 tested at 8 ppm)
● Sound pressure level (bystander position): 46 dB
● Sound pressure level (operator position): 55 dB
During standby and sleep mode: silent
Electrical specifications
Power requirements
●
100-120v (+/-10%), 50/60 Hz (+/-2); 127v, 60Hz NOM
or
●
●
Power consumption
●
●
220v (+/-10%), 50/60 Hz (+/-2 Hz)
220-240v (+/-10%), 50 Hz (+/-2 Hz)
During printing: 170 watts (average)
During standby and power save: 6 watts
Minimum recommended circuit 4.5A @ 115v; 2.3A @ 230v
capacity
132 Appendix A Printer specifications
EN
Printer specifications (continued)
Physical specifications
Dimensions
●
●
●
Weight (cartridge installed)
Width: 367 mm (14.5 in.)
Depth: 325 mm (12.8 in.)
Height: 378 mm (14.9 in.)
7.3 kg (16.1 lb)
Printer capacities and ratings
Print speed
8 pages per minute (“letter” size paper)
Paper input bin capacity
125 sheets of regular weight 20 lb (75 g/m2) paper or up to 10
envelopes
Paper output bin capacity
125 sheets of regular weight 20 lb (75 g/m2) paper
Minimum paper size
76 x 127 mm (3 x 5 in.)
Maximum paper size
216 x 356 mm (8.5 x 14 in.)
Base memory
4 MB of ROM and 2 MB of RAM
Upgrade memory expansion
One DIMM slot available for a 4, 8, or 16 MB RAM DIMM
Print resolution
600 dots per inch (dpi)
Duty cycle
7,000 single-sided pages per month
EN
Specifications 133
FCC compliance
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If it is not
installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Note
●
Reorient or relocate the receiving antenna.
●
Increase separation between equipment and receiver.
●
Connect equipment to an outlet on a circuit different from that to
which the receiver is located.
●
Consult your dealer or an experienced radio/TV technician.
Any changes or modifications to the printer that are not expressly
approved by HP could void the user’s authority to operate this
equipment.
Use of a shielded interface cable is required to comply with the Class
B limits of Part 15 of FCC rules.
134 Appendix A Printer specifications
EN
Environmental Product Stewardship Program
Protecting the Environment
Hewlett-Packard Company is committed to providing quality products
in an environmentally sound manner. This HP LaserJet printer has
been designed with several attributes to minimize impacts on our
environment.
This HP LaserJet printer eliminates:
Ozone production
The printer uses charging rollers in the electrophotographic process
and therefore generates no appreciable ozone gas (O3).
This HP LaserJet printer design reduces:
Energy consumption
Energy usage drops to as little as 6 W while in low-power
(PowerSave) mode. Not only does this save natural resources, but it
also saves money without affecting the high performance of this
printer. This product qualifies for ENERGY STAR. ENERGY STAR is a
voluntary program established to encourage the development of
energy-efficient office products. ENERGY STAR is a U.S. registered
service mark of the U.S. EPA.
As an ENERGY STAR partner, Hewlett-Packard Company has
determined that this product meets ENERGY STAR Guidelines for
energy efficiency.
Toner consumption
EconoMode uses significantly less toner which may extend the life of
the toner cartridge.
Paper use
Depending on the type of software program in use, you can request
for a number of pages of your document to be printed on one page of
paper. This N-up printing practice and the printer’s manual duplexing
feature, which provides two-sided printing, can reduce paper usage
and the resulting demands on natural resources.
EN
Environmental Product Stewardship Program 135
The design of this HP LaserJet printer facilitates the
recycling of:
Plastics
Plastic parts have markings according to international standards that
enhance the ability to identify plastics for recycling purposes at the
end of the printer’s life.
HP toner cartridges
In many countries/regions, this product’s toner cartridge/drum can be
returned to HP through the HP Planet Partners Toner Cartridge
Recycling Program. This easy to use program is available in over 20
countries/regions. Multi-lingual program information and instructions are
included in every new HP Toner Cartridge box.
HP Cartridge Recycling Program information
Since 1990, the HP LaserJet Toner Cartridge Recycling Program has
collected more than 12 million used toner cartridges that otherwise
may have been discarded in the world’s landfills. The HP LaserJet
toner cartridges go to a collection center and then they are bulk
shipped to our recycling partners who disassemble the cartridge
parts for recycling. After a thorough quality inspection, minor parts
such as nuts, screws, and clips are reclaimed for use in new
cartridges. Remaining materials are separated and converted into
raw materials for use by other industries to make a variety of useful
products. Over 95% by weight of each returned cartridge is reclaimed
for recycling. For more information in the U.S., call (1) (800) (3402445) or visit the HP LaserJet Supplies website at http://
www.ljsupplies.com/planetpartners/. Non-US customers can call the
local HP Sales and Service Office for further information regarding
the HP Planet Partners LaserJet Toner Cartridge Recycling Program.
Paper
This printer is suited for the use of recycled papers when the paper
meets the guidelines outlined in the HP LaserJet Printer Family Paper
Specifications Guide. See “Accessories and ordering information” for
HP LaserJet Printer Family Paper Specifications Guide ordering
information. This printer is suitable for the use of recycled paper
according to DIN 19 309.
136 Appendix A Printer specifications
EN
Material safety data sheet
The Toner Cartridge/Drum MSDS can be obtained by contacting the
HP LaserJet Supplies website at http://www.ljsupplies.com/
planetpartners/datasheets.htm. If you do not have access to the
internet, try calling the U.S. HP FIRST (Fax Information Retrieval
Support Technology) at (1) (800) 231-9300. Use Index number 7 for a
listing of the Toner Cartridge/Drum Material/Chemical Safety Data
Sheets. Non-US customers should refer to the front of this manual for
appropriate phone numbers and information.
EN
Material safety data sheet 137
Regulatory statements
Declaration of Conformity
according to ISO/IEC Guide 22 and EN45014
Manufacturer's Name:
Hewlett-Packard Company
Manufacturer's Address:
11311 Chinden Boulevard
Boise, Idaho 83714-1021, USA
declares that the product
Product Name:
HP LaserJet 1100
Model Number:
C4224A
Product Options:
ALL
conforms to the following Product Specifications:
Safety:
IEC 950:1991+A1+A2+A3+A4 / EN 60950:1992+A1+A2+A3+A4
EMC:
IEC 825-1:1993 / EN 60825-1:1994 Class 1 (Laser/LED)
CISPR 22:1993+A1 / EN 55022:1994 Class B1
EN 50082-1:1992
IEC 801-2:1991 / prEN 55024-2:1992 -
4 kV CD, 8 kV AD
IEC 801-3:1984 / prEN 55024-3:1991 -
3 V/m
IEC 801-4:1988 / prEN 55024-4:1992 -
0.5 kV Signal Lines
1.0 kV Power Lines
IEC 1000-3-2:1995 / EN61000-3-2:1995
IEC 1000-3-3:1994 / EN61000-3.3:1995
FCC Title 47 CFR, Part 15 Class B2) / ICES-003, Issue 2 / VCCI-21)
AS / NZS 3548:1992 / CISPR 22:1993 Class B1)
Supplementary Information:
The product herewith complies with the requirements of the following Directives and carries the CEmarking accordingly:
the EMC directive 89/336/EEC
the Low-Voltage Directive 73/23/EEC
The product was tested in a typical configuration with Hewlett-Packard Personal Computer Systems.
This Device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
For Compliance Information ONLY, contact:
Australia Contact:
Product Regulations Manager, Hewlett-Packard Australia Ltd.,
31-41 Joseph Street, Blackburn, Victoria 3130, Australia
European Contact:
Your Local Hewlett-Packard Sales and Service Office or
Hewlett-Packard GmbH, Department HQ-TRE / Standards
Europe, Herrenberger Straße 130, D-71034 Böblingen
(FAX: +49-7031-14-3143)
USA Contact:
Product Regulations Manager, Hewlett-Packard Company,
PO Box 15 Mail Stop 160, Boise, ID 83707-0015
(Phone: 208-396-6000)
138 Appendix A Printer specifications
EN
Laser safety statement
The Center for Devices and Radiological Health (CDRH) of the U.S.
Food and Drug Administration has implemented regulations for laser
products manufactured since August 1, 1976. Compliance is
mandatory for products marketed in the United States. The printer is
certified as a “Class 1” laser product under the U.S. Department of
Health and Human Services (DHHS) Radiation Performance
Standard according to the Radiation Control for Health and Safety Act
of 1968.
Since radiation emitted inside the printer is completely confined within
protective housings and external covers, the laser beam cannot
escape during any phase of normal user operation.
WARNING!
Using controls, making adjustments, or performing procedures other
than those specified in this user’s guide may result in exposure to
hazardous radiation.
Canadian DOC regulations
Complies with Canadian EMC Class B requirements.
«Conforme á la classe B des normes canadiennes de compatibilité
électromagnétiques. «CEM».»
Korean EMI statement
EN
Regulatory statements 139
Laser statement for Finland
LASERTURVALLISUUS
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
HP LaserJet 1100 -laserkirjoitin on käyttäjän kannalta turvallinen
luokan 1 laserlaite. Normaalissa käytössä kirjoittimen suojakotelointi
estää lasersäteen pääsyn laitteen ulkopuolelle.
Laitteen turvallisuusluokka on määritetty standardin EN 60825-1
(1993) mukaisesti.
VAROITUS!
Laitteen käyttäminen muulla kuin käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än i bruksanvisning
specificerats, kan användaren utsättas för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
HUOLTO
HP LaserJet 1100 -kirjoittimen sisällä ei ole käyttäjän huollettavissa
olevia kohteita. Laitteen saa avata ja huoltaa ainoastaan sen
huoltamiseen koulutettu henkilö. Tällaiseksi huoltotoimenpiteeksi ei
katsota väriainekasetin vaihtamista, paperiradan puhdistusta tai
muita käyttäjän käsikirjassa lueteltuja, käyttäjän tehtäväksi
tarkoitettuja ylläpitotoimia, jotka voidaan suorittaa ilman
erikoistyökaluja.
VARO!
Mikäli kirjoittimen suojakotelo avataan, olet alttiina näkymättömälle
lasersäteilylle laitteen ollessa toiminnassa. Älä katso säteeseen.
VARNING!
Om laserprinterns skyddshölje öppnas då apparaten är i funktion,
utsättas användaren för osynlig laserstrålning. Betrakta ej strålen.
Tiedot laitteessa käytettävän laserdiodin säteilyominaisuuksista:
Aallonpituus 770-795 nm
Teho 5 mW
Luokan 3B laser
140 Appendix A Printer specifications
EN
B
Scanner
specifications
This chapter provides information on the following topics:
EN
●
Specifications
●
FCC compliance
●
Environmental product stewardship
●
Regulatory statements
141
Specifications
HP LaserJet 1100A Printer•Copier•Scanner specifications
Environmental specifications
Operating environment
Printer plugged into an AC outlet:
● Temperature: 10 °C to 32.5 °C (50 °F to 90.5 °F)
● Humidity: 20%–80% (no condensation)
Storage environment
Printer unplugged from an AC outlet:
● Temperature: 0 °C to 40 °C (32 °F to 104 °F)
● Humidity: 10%–80% (no condensation)
Acoustics
Noise level
During Quick Copying: 6.5 Bels sound power level (ISO 9296)
(HP LaserJet 1100A tested at 7 ppm)
● Sound pressure level (bystander position): 53 dB
● Sound pressure level (operator position): 61 dB
During printing: 6.1 Bels sound power level (per ISO 9296)
(HP LaserJet 1100A tested at 7 ppm)
● Sound pressure level (bystander position): 46 dB
● Sound pressure level (operator position): 55 dB
During standby and sleep mode: silent
Electrical specifications
Power requirements
●
100-120v (+/-10%), 50/60 Hz (+/-2); 127v, 60Hz NOM
or
●
●
Power consumption
●
●
●
220v (+/-10%), 50/60 Hz (+/-2 Hz)
220-240v (+/-10%), 50 Hz (+/-2 Hz)
During Quick Copying: 185 watts (average)
During printing: 170 watts (average)
During standby and power save: 7 watts
Minimum recommended circuit 4.5A @ 115v; 2.3A @ 230v
capacity
142 Appendix B Scanner specifications
EN
HP LaserJet 1100A Printer•Copier•Scanner specifications (continued)
Physical specifications
Dimensions
●
●
●
Weight (including scanner
module and toner cartridge
installed)
Width: 367 mm (14.5 in.)
Depth: 402 mm (15.8 in.)
Height: 378 mm (14.9 in.)
8.7 kg (19.2 lb)
Printer capacities and ratings
Print speed
8 pages per minute (“letter” sized paper)
Paper input bin capacity
125 sheets of regular weight 20 lb (75 g/m2) paper or up to 10
envelopes
Paper output bin capacity
125 sheets of regular weight 20 lb (75 g/m2) paper
Minimum paper size
76 x 127 mm (3 x 5 in.)
Maximum paper size
216 x 356 mm (8.5 x 14 in.)
Base memory
4 MB of ROM and 2 MB of RAM
Upgrade memory expansion
One DIMM slot available for a 4, 8, or 16 MB RAM DIMM
Resolution
600 dots per inch (dpi)
Duty cycle
7,000 single-sided pages per month
EN
Specifications 143
HP LaserJet 1100A Printer•Copier•Scanner specifications (continued)
Copier\Scanner capacities and ratings
Speed
7 pages per minute
Input bin capacity
Approx. 20 sheets of regular weight 20 lb (75 g/m2) paper
Minimum paper size
50.8 x 90 mm (2 x 3.5 in.)
Maximum paper size
216 x 762 mm (8.5 x 30 in.)
Resolution
300 dots per inch (optical resolution)
Duty cycle
2,000 pages per month
144 Appendix B Scanner specifications
EN
FCC compliance
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If it is not
installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Note
●
Reorient or relocate the receiving antenna.
●
Increase separation between equipment and receiver.
●
Connect equipment to an outlet on a circuit different from that to
which the receiver is located.
●
Consult your dealer or an experienced radio/TV technician.
Any changes or modifications to the printer that are not expressly
approved by HP could void the user’s authority to operate this
equipment.
Use of a shielded interface cable is required to comply with the Class
B limits of Part 15 of FCC rules.
EN
FCC compliance 145
Environmental product stewardship
Protecting the Environment
Hewlett-Packard Company is committed to providing quality products
in an environmentally sound manner. This HP scanner has been
designed with several attributes to minimize impacts on our
environment.
The design of this HP scanner facilitates the recycling
of:
Plastics
Plastic parts have markings according to international standards that
enhance the ability to identify plastics for recycling purposes at the
end of the scanner’s life.
146 Appendix B Scanner specifications
EN
Regulatory statements
Declaration of Conformity
according to ISO/IEC Guide 22 and EN45014
Manufacturer's Name:
Hewlett-Packard Company
Manufacturer's Address:
11311 Chinden Boulevard
Boise, Idaho 83714-1021, USA
declares that the product
Product Name:
HP LaserJet 1100A Printer•Copier•Scanner
Model Number:
C4218A
Product Options:
ALL
conforms to the following Product Specifications:
Safety:
IEC 950:1991+A1+A2+A3+A4 / EN 60950:1992+A1+A2+A3+A4
EMC:
IEC 825-1:1993 / EN 60825-1:1994 Class 1 (Laser/LED)
CISPR 22:1993+A1 / EN 55022:1994 Class B1
EN 50082-1:1992
IEC 801-2:1991 / prEN 55024-2:1992 -
4 kV CD, 8 kV AD
IEC 801-3:1984 / prEN 55024-3:1991 -
3 V/m
IEC 801-4:1988 / prEN 55024-4:1992 -
0.5 kV Signal Lines
1.0 kV Power Lines
IEC 1000-3-2:1995 / EN61000-3-2:1995
IEC 1000-3-3:1994 / EN61000-3.3:1995
FCC Title 47 CFR, Part 15 Class B2) / ICES-003, Issue 2 / VCCI-21)
AS / NZS 3548:1992 / CISPR 22:1993 Class B1)
Supplementary Information:
The product herewith complies with the requirements of the following Directives and carries the CEmarking accordingly:
the EMC directive 89/336/EEC
the Low-Voltage Directive 73/23/EEC
The product was tested in a typical configuration with Hewlett-Packard Personal Computer Systems.
This Device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
For Compliance Information ONLY, contact:
EN
Australia Contact:
Product Regulations Manager, Hewlett-Packard Australia Ltd.,
31-41 Joseph Street, Blackburn, Victoria 3130, Australia
European Contact:
Your Local Hewlett-Packard Sales and Service Office or
Hewlett-Packard GmbH, Department HQ-TRE / Standards
Europe, Herrenberger Straße 130, D-71034 Böblingen
(FAX: +49-7031-14-3143)
USA Contact:
Product Regulations Manager, Hewlett-Packard Company,
PO Box 15 Mail Stop 160, Boise, ID 83707-0015
(Phone: 208-396-6000)
Regulatory statements 147
Laser safety statement
The Center for Devices and Radiological Health (CDRH) of the U.S.
Food and Drug Administration has implemented regulations for laser
products manufactured since August 1, 1976. Compliance is
mandatory for products marketed in the United States. The printer is
certified as a “Class 1” laser product under the U.S. Department of
Health and Human Services (DHHS) Radiation Performance
Standard according to the Radiation Control for Health and Safety Act
of 1968.
Since radiation emitted inside the printer is completely confined within
protective housings and external covers, the laser beam cannot
escape during any phase of normal user operation.
WARNING!
Using controls, making adjustments, or performing procedures other
than those specified in this user’s guide may result in exposure to
hazardous radiation.
Canadian DOC regulations
Complies with Canadian EMC Class B requirements.
«Conforme á la classe B des normes canadiennes de compatibilité
électromagnétiques. «CEM».»
Korean EMI statement
148 Appendix B Scanner specifications
EN
Laser statement for Finland
LASERTURVALLISUUS
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
HP LaserJet XXXX -laserkirjoitin on käyttäjän kannalta turvallinen
luokan 1 laserlaite. Normaalissa käytössä kirjoittimen suojakotelointi
estää lasersäteen pääsyn laitteen ulkopuolelle.
Laitteen turvallisuusluokka on määritetty standardin EN 60825-1
(1993) mukaisesti.
VAROITUS!
Laitteen käyttäminen muulla kuin käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än i bruksanvisning
specificerats, kan användaren utsättas för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
HUOLTO
HP LaserJet XXXX -kirjoittimen sisällä ei ole käyttäjän huollettavissa
olevia kohteita. Laitteen saa avata ja huoltaa ainoastaan sen
huoltamiseen koulutettu henkilö. Tällaiseksi huoltotoimenpiteeksi ei
katsota väriainekasetin vaihtamista, paperiradan puhdistusta tai
muita käyttäjän käsikirjassa lueteltuja, käyttäjän tehtäväksi
tarkoitettuja ylläpitotoimia, jotka voidaan suorittaa ilman
erikoistyökaluja.
VARO!
Mikäli kirjoittimen suojakotelo avataan, olet alttiina näkymättömälle
lasersäteilylle laitteen ollessa toiminnassa. Älä katso säteeseen.
VARNING!
Om laserprinterns skyddshölje öppnas då apparaten är i funktion,
utsättas användaren för osynlig laserstrålning. Betrakta ej strålen.
Tiedot laitteessa käytettävän laserdiodin säteilyominaisuuksista:
Aallonpituus 770-795 nm
Teho 5 mW
Luokan 3B laser
EN
Regulatory statements 149
150 Appendix B Scanner specifications
EN
C
Paper specifications
This chapter provides information on the following topics:
EN
●
Printer paper specifications
●
Supported paper sizes (printer)
●
Guidelines for using paper
151
Printer paper specifications
HP LaserJet printers produce excellent print quality. This printer
accepts a variety of media, such as cut-sheet paper (including
recycled paper), envelopes, labels, transparencies, vellum, and
custom-size paper. Properties such as weight, grain, and moisture
content are important factors affecting printer performance and output
quality.
The printer can use a variety of paper and other print media in
accordance with the guidelines in this manual. Paper that does not
meet these guidelines may cause the following problems:
●
Poor print quality
●
Increased paper jams
●
Premature wear on the printer, requiring repair
For best results, use only HP brand paper and print media. HewlettPackard Company cannot recommend the use of other brands.
Because they are not HP products, HP cannot influence or control
their quality.
It is possible for paper to meet all of the guidelines in this manual and
still not produce satisfactory results. This might be the result of
improper handling, unacceptable temperature and humidity levels, or
other variables over which Hewlett-Packard has no control.
Before purchasing a large quantity of paper, make sure it meets the
requirements specified in this user guide and in the HP LaserJet
Printer Family Paper Specification Guide. (To order the guide, see
“Accessories and ordering information.”) Always test paper before
purchasing a large quantity.
CAUTION
Using paper outside HP specifications may cause problems for the
printer, requiring repair. This repair is not covered by the HewlettPackard warranty or service agreements.
Supported paper sizes (printer)
●
Maximum supported paper size: 216 by 356 mm (8.5 by 14 in.)
●
Minimum supported paper size: 76 by 127 mm (3 by 5 in.)
152 Appendix C Paper specifications
EN
Guidelines for using paper
For best results, use conventional 20 lb (75 g/m2) paper. Make sure
the paper is of good quality, and free of cuts, nicks, tears, spots, loose
particles, dust, wrinkles, voids, and curled or bent edges.
If you are unsure what type of paper you are loading (such as bond or
recycled), check the label on the package of paper.
Some paper causes print quality problems, jamming, or damage to
the printer.
Symptom
Problem with Paper
Solution
Poor print quality or toner
adhesion.
Problems with feeding.
Too moist, too rough, too
smooth, or embossed; faulty
paper lot.
Try another kind of paper,
between 100-250 Sheffield,
4-6% moisture content.
Dropouts, jamming, curl.
Stored improperly.
Store paper flat in its moistureproof wrapping.
Increased gray background
shading.
Too heavy.
Use lighter paper.
Excessive curl.
Problems with feeding.
Too moist, wrong grain
direction or short-grain
construction.
Use long-grain paper.
Print using the straightthrough ouput path.
Jamming, damage to printer.
Cutouts or perforations.
Do not use paper with cutouts
or perforations.
Problems with feeding.
Ragged edges.
Use good quality paper.
Note
Do not use letterhead paper that is printed with low-temperature inks,
such as those used in some types of thermography.
Do not use raised letterhead.
The printer uses heat and pressure to fuse toner to the paper. Make
sure that any colored paper or preprinted forms use inks that are
compatible with the printer temperature (392 °F or 200 °C for
0.1 second).
EN
Guidelines for using paper 153
Labels
Label construction
When selecting labels, consider the quality of each component:
●
Adhesives: The adhesive material should be stable at 392 °F
(200 °C), the printer’s maximum temperature.
●
Arrangement: Only use labels with no exposed backing between
them. Labels can peel off sheets with spaces between the labels,
causing serious jams.
●
Curl: Prior to printing, labels must lie flat with no more than 13
mm (0.5 in.) of curl in any direction.
●
Condition: Do not use labels with wrinkles, bubbles, or other
indications of separation.
Transparencies
Transparencies used in the printer must be able to withstand 392 °F
(200 °C), the printer’s maximum temperature.
154 Appendix C Paper specifications
EN
Envelopes
Envelope construction
Envelope construction is critical. Envelope fold lines can vary
considerably, not only between manufacturers, but also within a box
from the same manufacturer. Successful printing on envelopes
depends upon the quality of the envelopes. When selecting
envelopes, consider the following components:
●
Weight: The weight of the envelope paper should not exceed
28 lb
(105 g/m2), or jamming may result.
●
Construction: Prior to printing, envelopes should lie flat with less
than 6 mm (0.25 in.) curl and should not contain air. (Envelopes
that trap air may cause problems.)
●
Condition: Make sure envelopes are not wrinkled, nicked, or
otherwise damaged.
●
Sizes: From 90 by 160 mm (3.5 by 6.3 in.) to 178 by 254 mm (7
by 10 in.).
Envelopes with double-side-seams
Double-side-seam construction has vertical seams at both ends of
the envelope rather than diagonal seams. This style may be more
likely to wrinkle. Be sure the seam extends all the way to the corner of
the envelope as illustrated below.
Acceptable
Unacceptable
EN
Guidelines for using paper 155
Envelopes with adhesive strips or flaps
Envelopes with a peel-off adhesive strip or with more than one flap
that folds over to seal must use adhesives compatible with the heat
and pressure in the printer: 392 °F (200 °C). The extra flaps and
strips might cause wrinkling, creasing, or jams.
Envelope storage
Proper storage of envelopes helps contribute to good print quality.
Envelopes should be stored flat. If air is trapped in an envelope,
creating an air bubble, the envelope may wrinkle during printing.
156 Appendix C Paper specifications
EN
Card stock and heavy media
Many types of card stock can be printed from the paper input tray,
including index cards and postcards. Some card stock performs
better than others because its construction is better suited for feeding
through a laser printer.
For optimum printer performance, do not use paper heavier than 42 lb
(157 g/m2). Paper that is too heavy might cause misfeeds, stacking
problems, paper jams, poor toner fusing, poor print quality, or
excessive mechanical wear.
Note
Printing on heavier paper may be possible if the tray is not filled to
capacity, and paper with a smoothness rating of 100-180 Sheffield is
used.
Card stock construction
●
Smoothness: 36-42 lb (135-157 g/m2) card stock should have a
smoothness rating of 100-180 Sheffield. 16-36 lb (60-135 g/m2)
card stock should have a smoothness rating of 100-250 Sheffield.
●
Construction: Card stock should lie flat with less than 5 mm (0.2
in.) of curl.
●
Condition: Make sure card stock is not wrinkled, nicked, or
otherwise damaged.
●
Sizes: Use only card stock within the following size ranges:
• Minimum: 76 by 127 mm (3 by 5 in.)
• Maximum: 312 by 470 mm (12.28 by 18.5 in.)
Card stock guidelines
EN
●
If cards curl or jam, print using the straight-through output path.
●
Set margins at least 2 mm (0.08 inch) away from the edges of the
paper.
Guidelines for using paper 157
158 Appendix C Paper specifications
EN
D
Memory (DIMMs)
This chapter provides information on the following topics:
EN
●
Installing DIMMs (memory)
●
Test DIMM installation
●
Removing DIMMs
159
Installing DIMMs (memory)
Adding memory (RAM only) to the
HP LaserJet 1100 will enable you to print
more complex print jobs.
To install DIMMs, follow the instructions
below:
CAUTION
Handling a DIMM chip (memory) without
wearing a grounded, anti-static device
can damage the DIMM chip.
1
2
1
Unplug the printer.
2
Open the printer memory door by
gently pulling out and upward on the
bottom edge until the door supports
itself.
3
Remove the DIMM chip from the
anti-static bag in which it came by
grasping the chip on the top edge.
Continued on next page.
3
160 Appendix D Memory (DIMMs)
EN
4
5
4
Position the DIMM chip over the slot
located inside the printer memory
door. The gold contacts should be
pointing down and the cutouts
should be on the left side.
5
Carefully press the DIMM chip into
the slot, ensuring it is straight and all
the way down. The cam latches
should rotate inward.
6
Lock the cam latches into place by
pressing the handles towards each
other.
6
EN
Installing DIMMs (memory) 161
Test DIMM installation
Test the DIMM installation by printing a self-test page and checking
the “memory available” specified on the page. See “Printing a self-test
page.”
162 Appendix D Memory (DIMMs)
EN
Removing DIMMs
To remove DIMMs, follow the instructions
below:
CAUTION
Handling a DIMM chip (memory) without
wearing a grounded, anti-static device
can damage the DIMM chip.
1
2
1
Unplug the printer.
2
Open the printer memory door by
gently pulling out and upward on the
bottom edge until the door supports
itself.
3
Unlock the cam latches by pressing
them outward.
4
Grasp the DIMM chip on the top
edge, gently pull straight up, and
then remove the chip from the
printer.
Note
Store the DIMM chip in an antistatic bag.
3
4
EN
Removing DIMMs 163
164 Appendix D Memory (DIMMs)
EN
E
Warranty and
licensing
This chapter provides information on the following topics:
EN
●
Hewlett-Packard software license agreement
●
Hewlett-Packard limited warranty statement
●
Limited warranty for toner cartridge life
165
Hewlett-Packard software license agreement
ATTENTION: USE OF THE SOFTWARE IS SUBJECT TO THE
HP SOFTWARE LICENSE TERMS SET FORTH BELOW. USING
THE SOFTWARE INDICATES YOUR ACCEPTANCE OF THESE
LICENSE TERMS.
HP SOFTWARE LICENSE TERMS
The following License Terms govern your use of the accompanying
Software unless you have a separate signed agreement with HP.
License Grant. HP grants you a license to use one copy of the
Software. "Use" means storing, loading, installing, executing, or
displaying the Software. You may not modify the Software or disable
any licensing or control features of the Software. If the Software is
licensed for “concurrent use,” you may not allow more than the
maximum number of authorized users to Use the Software
concurrently.
Ownership. The Software is owned and copyrighted by HP or its
third-party suppliers. Your license confers no title to, or ownership in,
the Software and is not a sale of any rights in the Software. HP's thirdparty suppliers may protect their rights in the event of any violation of
these License Terms.
Copies and Adaptations. You may only make copies or adaptations of
the Software for archival purposes or when copying or adaptation is
an essential step in the authorized Use of the Software. You must
reproduce all copyright notices in the original Software on all copies
or adaptations. You may not copy the Software onto any public
network.
No Disassembly or Decryption. You may not disassemble or
decompile the Software unless HP's prior written consent is obtained.
In some jurisdictions, HP's consent may not be required for limited
disassembly or decompilation. Upon request, you will provide HP with
reasonably detailed information regarding any disassembly or
decompilation. You may not decrypt the Software unless decryption is
a necessary part of the operation of the Software.
166 Appendix E Warranty and licensing
EN
Transfer. Your license will automatically terminate upon any transfer of
the Software. Upon transfer, you must deliver the Software, including
any copies and related documentation, to the transferee. The
transferee must accept these License Terms as a condition to the
transfer.
Termination. HP may terminate your license upon notice for failure to
comply with any of these License Terms. Upon termination, you must
immediately destroy the Software, together with all copies,
adaptations, and merged portions in any form.
Export Requirements. You may not export or re-export the Software
or any copy or adaptation in violation of any applicable laws or
regulations.
U.S. Government Restricted Rights. The Software and any
accompanying documentation have been developed entirely at
private expense. They are delivered and licensed as “commercial
computer software” as defined in DFARS 252.227-7013 (Oct 1988),
DFARS 252.211-7015 (May 1991), or DFARS 252.227-7014
(Jun 1995), as a “commercial item” as defined in FAR 2.101(a)
(Jun 1987), or as “Restricted computer software” as defined in FAR
52.227-19 (Jun 1987) (or any equivalent agency regulation or
contract clause), whichever is applicable. You have only those rights
provided for such Software and any accompanying documentation by
the applicable DFARs or FAR clause or the HP standard software
agreement for the product involved.
EN
Hewlett-Packard software license agreement 167
Hewlett-Packard limited warranty statement
DURATION OF WARRANTY:
One year from date of purchase.
1. HP warrants to you, the end-user customer, that HP hardware, accessories, and
supplies, will be free from defects in materials and workmanship after the date of
purchase, for the period specified above. If HP receives notice of such defects
during the warranty period, HP will, at its option, either repair or replace products
which prove to be defective. Replacement products may be either new or like-new.
2
HP warrants to you that HP software will not fail to execute its programming
instructions after the date of purchase, for the period specified above, due to
defects in material and workmanship when properly installed and used. If
HP receives notice of such defects during the warranty period, HP will replace
software media which does not execute its programming instructions due to such
defects.
3
HP does not warrant that the operation of HP products will be uninterrupted or
error free. If HP is unable, within a reasonable time, to repair or replace any
product to a condition as warranted, you will be entitled to a refund of the
purchase price upon prompt return of the product.
4
HP products may contain remanufactured parts equivalent to a new in
performance or may have been subject to incidental use.
5
Warranty does not apply to defects resulting from (a) improper or inadequate
maintenance or calibration, (b) software, interfacing, parts or supplies not supplied
by HP, (c) unauthorized modification or misuse, (d) operation outside of the
published environmental specifications for the product, or (d) improper site
preparation or maintenance.
6
HP MAKES NO OTHER EXPRESS WARRANTY OR CONDITION WHETHER
WRITTEN OR ORAL. TO THE EXTENT ALLOWED BY LOCAL LAW, ANY
IMPLIED WARRANTY OR CONDITION OR MERCHANTABILITY,
SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE IS
LIMITED TO THE DURATION OF THE EXPRESS WARRANTY SET FORTH
ABOVE. Some countries, states or provinces do not allow limitations on the
duration of an implied warranty, so the above limitation or exclusion might not
apply to you. This warranty gives you specific legal rights and you might also have
other rights that vary from country to country, state to state, or province to
province.
168 Appendix E Warranty and licensing
EN
7
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS
WARRANTY STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDIES.
EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL HP OR ITS SUPPLIERS
BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR OTHER
DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some
countries, states or provinces do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion may not apply to
you.
FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND; THE
WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE
EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY
AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS
APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.
EN
Hewlett-Packard limited warranty statement 169
Limited warranty for toner cartridge life
Note
The warranty below applies to the toner cartridge that came with this
printer.
HP toner cartridges are warranted to be free from defects in materials
and workmanship until the HP toner is depleted. The warranty covers
any defects or malfunctions in a new Hewlett-Packard toner cartridge.
How long does the coverage last?
The coverage lasts until the HP toner is depleted, at which time the
warranty expires.
How do I know when the HP toner is running out?
The HP toner is depleted when faded or light type appears on the
printed page.
What will HP do?
HP will, at HP’s option, either replace products which prove to be
defective or refund the purchase price. If possible, please attach a
printout sample illustrating what the defective cartridge is printing.
What does this warranty not cover?
The warranty does not cover cartridges which have been refilled, are
emptied, are abused, are misused, or are tampered with in any way.
170 Appendix E Warranty and licensing
EN
How do I return the faulty cartridge?
In the event the cartridge proves to be defective, complete the
Service Information Form and attach a print sample illustrating the
defect. Return the form and cartridge to the place of purchase, where
the cartridge will be replaced.
How does State, Province or Country Law apply?
This limited warranty gives you specific legal rights, and you may also
have other rights which vary from state to state, province to province,
or country to country. This limited warranty is the sole warranty on the
HP toner cartridge and supersedes any other warranty relating to this
product.
IN NO EVENT SHALL HEWLETT-PACKARD COMPANY BE
LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL,
INDIRECT, PUNITIVE, OR EXEMPLARY DAMAGES OR LOST
PROFITS FROM ANY BREACH OF THIS WARRANTY OR
OTHERWISE.
FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW
ZEALAND; THE WARRANTY TERMS CONTAINED IN THIS
STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED,
DO NOT EXCLUDE, RESTRICT OR MODIFY AND ARE IN
ADDITION TO THE MANDATORY STATUTORY RIGHTS
APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.
EN
Limited warranty for toner cartridge life 171
172 Appendix E Warranty and licensing
EN
F
Accessories and
ordering information
You can increase the capabilities of the printer with optional
accessories and supplies. Use accessories and supplies
specifically designed for the HP LaserJet 1100 Printer and the
HP LaserJet 1100A Printer•Copier•Scanner to ensure optimum
performance.
EN
173
Ordering information
Item
Printer
memory
Cables and
interface
accessories
Printing
supplies
Toner
cartridge
Description or Use
Dual in-line memory Boosts the ability of the printer to
module (DIMM)
handle complex print jobs.
● Maximum add on: 16 MB
● Available DIMMs:
4 MB
8 MB
16 MB
Order Number
C4135A
C4136A
C4137A
Parallel cables
Method of connectivity from printer to
PC.
● 2 Meter IEEE-1284 cable
C2945A
C2946A
● 3 Meter IEEE-1284 cable
Copier/Scanner for
the HP LaserJet
1100
Attachable scanner exclusively for the C4221A
HP LaserJet 1100 printer.
HP Multi-purpose
paper
HP brand paper for a variety of
HPM1120
uses (1 box of 10 reams, 500 sheets
each). To order a sample, in the U.S.,
call 1-800-471-4701.
HP LaserJet paper
Premium HP brand paper for use with HPJ1124
HP LaserJet printers (1 box of
10 reams, 500 sheets each). To order
a sample, in the U.S., call
1-800-471-4701.
Toner cartridge
Replacement toner cartridge for the
HP LaserJet 1100.
C4092A
Replacement HP precision toner
cartridge.
C4092A
174 Appendix F Accessories and ordering information
EN
Ordering information (continued)
Supplementary
documentation
Replacement
parts
EN
Item
Description or Use
Order Number
HP LaserJet Printer
Family Paper
Specification Guide
A guide to using paper and other print 5021-8909
media with HP LaserJet printers.
HP LaserJet 1100A
Printer•Copier•Scan
ner hard-copy user
guide
A printed and bound user guide for
the HP LaserJet 1100A
Printer•Copier•Scanner. (use=printer
and copier/scanner)
Paper pick-up roller
Used to pick the paper from the paper RF5-2826input tray and advance it through the 000CN
printer.
Input paper support
for the printer
Used to stabilize the paper once it is
loaded into the paper input tray.
C4218-90937
RB2-4020000CN
Output paper support Used to stabilize paper once it is
for the printer
printed.
RB2-4021000CN
Input paper support
for the scanner
RB2-4021000CN
Used to stabilze paper once it is
loaded into the scanner.
175
176 Appendix F Accessories and ordering information
EN
G
Scanner resolution
and gray scale
This chapter provides information on the following topics:
EN
●
Overview
●
Resolution and gray-scale guidelines
●
Resolution
●
Gray scale
177
Overview
If you are printing a scanned image or copying an image and the
quality is not as you expected, you may have selected a resolution or
gray-scale setting in the Copier/Scanner software that does not match
your needs. Resolution and gray scale affect scanned and copied
images in the following ways:
●
Image clarity
●
Texture of gradations (smooth or rough)
●
Scan and copy time
●
File size
Resolution is measured in dots per inch (dpi) while gray scale is
measured by the number of grays possible to create a transition from
black to white. You can adjust the scanner resolution up to 300 dpi.
Gray scale can be set at 1 (black and white) or 8 (256 levels of gray).
Listed in the table, “Resolution and gray-scale guidelines,” are simple
tips you can follow to meet your scanning and copying needs. Also
see “Resolution” and “Gray scale” to learn more about these topics.
Note
Setting the resolution and gray scale high can create large files that
take up disk space and slow the scanning or copying process. It is
important to determine how the scanned image is going to be used.
178 Appendix G Scanner resolution and gray scale
EN
Resolution and gray-scale guidelines
Resolution and gray-scale guidelines
Intended use for scan
Recommended
resolution setting
Recommended grayscale setting
Fax
150 dpi
1
E-Mail
150 dpi
●
●
Edit text
300 dpi
1
Print (graphics or text)
●
●
●
Display on screen
300 for text and complex
graphics
150 for simple graphics
and photos
75 dpi
●
●
●
EN
1 if the image does not
require smooth gradation
8 if the image requires
smooth gradation
1 for text and line art
8 for shaded or colored
graphics and photos
1 for text
8 for graphics and photos
Resolution and gray-scale guidelines 179
Resolution
Generally, the ideal scanning resolution is 150 dots per inch (dpi).
Changing the size of the image after it has been scanned affects the
resolution. Therefore, before setting the scanner resolution, it is
helpful to determine what the final image size will be. For example,
you might want to scan an original that is 76 x 127 mm (3 x 5 in.), but
there is only room for a 38 x 63.5 mm (1.5 x 2.5 in.) picture in your
document. Set the scanner resolution to 75 dpi.
Resolution
Size of original
76 x 127 mm
(3 x 5 in.)
Size after scanned and
altered
Recommended scanner
resolution
38 x 63.5 mm
(1.5 x 2.5 in.)
75 dpi
76 x 127 mm
(3 x 5 in.)
150 dpi
152 x 254 mm
(6 x 10 in.)
300 dpi
180 Appendix G Scanner resolution and gray scale
EN
Gray scale
You can set the gray scale to either 1 or 8 in your Copier/Scanner
software.
Usage table
Uses for 1 bit setting
Uses for 8 bit setting
●
Black text on white background
●
Colored text or colored background
●
Images that require grainy gradients
●
Images that require smooth gradients
●
Small file is required: diskette, e-mail, fax
●
Large file size acceptable
●
Scan or copy must happen quickly
●
Image quality is more important than time
and file size
EN
Gray scale 181
182 Appendix G Scanner resolution and gray scale
EN
Index
A
Accessories and ordering
information 173
part numbers 174
Acquire an image 53
B
Best quality
printer setting 45
Booklets
printing 42
C
Calibration
Scanner 107
Cancel
copy job 60
print job 44
scan job 55
Cards
printing 34
Carrier sheet 24
Cleaning
printer 79– 81
printer paper path 81
Scanner 108
Compatibility
LaserJet III 45
Components
Copier/Scanner 22– 23
printer 3– 7
Contrast
adjust 53, 54
contrast sensitive originals 53
Control panel
printer 4
scanner 22
Copier Control Panel 20
Copier/Scanner
components 22– 23
software 17
specifications 142– 144
Copying
cancel copy job 60
contrast sensitive originals 53
precautions 25
receipts 53
Crop image 54
EN
Customer support 121
D
Default settings
print quality 45
printer properties (driver) 11
Quick Copy 59
DIMM
installation 160
removal 163
Document Assistant
accessing 18
features 18
Duplexing 37
Duplexing, card stock 39
E
EconoMode 45
Edit scanned text (OCR) 50
Edit text feature
Windows 3.1x 51
Edit text feature (OCR) 50
Windows 9x & NT 4.0 50
E-Mail feature
Windows 3.1x 49
Windows 9x & NT 4.0 49
E-Mail, scan to 49
Envelopes
printing 31
Error messages
printer
light patterns 67
on screen 69
F
Faster printing
printer setting 45
Fax feature
Windows 3.1x 48
Windows 9x & NT 4.0 48
Fax, scan to 48
G
Gray scale 177, 181
guidelines 179
Index 183
H
Help, online 12
accessing 27
HP FIRST 124
Light patterns
printer 67
Loading
Copier/Scanner originals 26
I
M
add annotations 55
defects
Copier/Scanner 104
printer 74
enhancements 54
Image defects
Copier/Scanner
black dots or streaks 106
blank pages 105
reduced image 106
too light or dark 105
unclear text 106
unwanted lines 105
vertical white stripes 105
printer
dropouts 76
gray background 77
light print or fade 76
loose toner 77
misformed characters 78
page skew 78
toner smear 77
toner specks 76
vertical lines 76
vertical repetitive defects 77
wrinkles or creases 78
Import images 53
Installation
printer 1
scanner 15
Manual duplexing 37
Manual duplexing, card stock 39
Manual feed 36
Media
cards, printing 34
Copier/Scanner
supported sizes and types 24
envelopes, printing 31
labels, printing 32
letterhead, printing 33
printer
choosing 8
specifications 8, 24, 151
transparencies, printing 30
Memory
DIMM
available 162
installation 160
removal 163
testing 162
Multiple pages per sheet
printing 41
J
Jams
printer 82
scanner 109
L
Labels
printing 32
LaserJet Document Desktop
accessing 19
features 19
LaserJet Toolbox 21
accessing 21
features 21
Letterhead
printing 33
184
Index
N
N-up printing 41
O
OCR
Windows 3.1x 51
Windows 9x & NT 4.0 50
OCR feature 50
Online help
printer 12
Online help, accessing 27
P
Paper
choosing 8, 151
loading
Copier/Scanner 26
printer 9
specifications
printer 152– 157
supported sizes and types
Copier/Scanner 24
printer 8
Paper handling
printer
troubleshooting 71
EN
Paper jam
printer
clearing 82
scanner
clearing 109
Power
printer
turn off 10
voltage conversions 10
Precautions
copying 25
printer
paper jams 82
scanner
jams 109
scanning 25
Print quality
settings 45
troubleshooting 74– 78
Printer
components 3– 7
control panel 4
default settings 11
driver 11
features and benefits 2
installation 1
light patterns 67
loading paper (media) 9
online help 12
paper input options 5
paper jam 82
paper output options 6
power
turn off 10
voltage conversions 10
properties (driver) 11
specifications 132– 133
Printer properties
booklet printing 42
manual duplexing 37
multiple pages per sheet 41
print quality settings 45
watermarks 40
Printing
booklets 42
cancel print job 44
printing on media
cards 34
envelopes 31
labels 32
letterhead 33
transparencies 30
watermarks 40
with EconoMode (save toner) 45
EN
Printing tasks
multiple pages per sheet 41
N-up printing 41
print booklets 42
print on both sides of paper 37
print on both sides of paper, card stock
39
print watermarks 40
Q
Quick Copy 20
settings 59
R
Resolution 177, 180
guidelines 179
S
Sales
office locations 126
Save toner
EconoMode 45
Scan/copy quality
troubleshooting 103– 106
Scanner
calibration 107
control panel 22
installation 15
paper input tray 23
paper jam 109
Scanning
cancel scan job 55
contrast sensitive originals 53
precautions 25
receipts 53
Scanning tasks
add annotations 55
edit text (OCR) 50
enhancing scanned images 54
scan an image 53
scan to e-mail 49
scan to fax 48
store scanned images 52
Screen messages
printer 69
Service
agreements 124
availability 114
hardware 114
information form 117
office locations 126
providers 124
Service and support
availability 114
see also Support 113
Index 185
Settings
print quality 45
printer properties (driver) 11
Quick Copy, changing 59
Software
Copier Control Panel 20
Document Assistant 18
LaserJet Document Desktop 19
LaserJet Toolbox 21
license agreement 166
printer properties (driver) 11
Quick Copy settings 20
Specifications
Copier/Scanner 142– 144
printer 132– 133
paper 152– 157
Store scanned images 52
Windows 3.1x 52
Windows 9.x & NT 4.0 52
Support 118
America Online 122
availability 114
CompuServe 122
HP FIRST 124
HP Support Assistant CD 124
online services 122
Web 122
V
Voltage conversions
printer 10
W
Warranty 168
toner cartridge 170
Watermarks 40
T
Toner
EconoMode (save toner) 45
redistributing 63
Toner cartridge
changing 64
managing 61
recycling 62
save toner, EconoMode 62
Transparencies
printing 30
Troubleshooting
Copier/Scanner
finding the solution 92
image defects 104
print quality 74– 78
printer 65
error messages 69
finding the solutions 66
image defects 74
light patterns 67
paper handling 71
paper jams 82
scan/copy quality 103– 106
scanner
paper jams 109
186
Index
EN
Copyright© 2002
Hewlett-Packard Co.
Manual Part No.
C4218-90962
*C4218-90962*
*C4218-90962*
C4218-90962
