Color Copier 210/210LX
User’s Guide
© Copyright HewlettPackard Company 1997
All rights are reserved. No part
of the document may be
photocopied, reproduced, or
translated to another language
without the prior written
consent of Hewlett-Packard
Company.
Publication number:
C5302-90000
First Edition,
March, 1997
Printed in U.S.A.
Notice
WARNING
The information contained in
this document is subject to
change without notice and
should not be construed as a
commitment by the HewlettPackard Company.
The Warning label calls
attention to a procedure,
practice, or the like, which, if
not correctly performed or
adhered to, could result in
personal injury. Do not
proceed beyond a Warning
label until the indicated
conditions are fully understood and met.
Hewlett-Packard assumes no
responsibility for any errors
that may appear in this
document nor does it make
expressed or implied warranty
of any kind with regard to this
material, including, but not
limited to, the implied
warranties of merchantability
and fitness for a particular
purpose. The Hewlett-Packard
Company shall not be liable
for incidental or consequential
damages in connection with,
or arising out of the furnishing,
performance, or use of this
document and the program
material which it describes.
CAUTION
The Caution label calls
attention to an operating
procedure, practice, or the
like, which, if not correctly
performed or adhered to,
could result in damage to or
destruction of part or all of the
product. Do not proceed
beyond a Caution label until
the indicated conditions are
fully understood and met.
It is not lawful in many places
to make copies of the
following items. When in
doubt, check with a legal
representative first.
• Governmental paper or
documents
– Passports
– Immigration papers
– Selective service papers
– Identification badges,
cards, or insignias
• Governmental stamps
– Postage stamps
– Food stamps
• Checks or drafts drawn on
Governmental agencies
• Paper currency, traveler’s
check, or money orders
• Certificates of deposit
• Copyrighted works
Regulatory information can
be found in the “Technical
Information” chapter of this
User’s Guide.
Owner’
Owner’ss Information
Please complete the following for future reference.
HP Color Copier 210: ______
Serial Number:
Date of Purchase:
Place of Purchase:
Address:
Phone Number:
Service Contract Number:
Date of Contract Expiration:
Hewlett-Packard Company
San Diego Printer Division
16399 W. Bernardo Drive
San Diego, CA 92127-1899 U.S.A.
HP Color Copier 210LX: ______
User’
User’ss Guide
HP Color Copier 210/210LX
Safety symbols
!
If present, this symbol is placed on the copier
where it is necessary for you to refer to the
manual in order to understand a hazard.
If present, this symbol is placed on the copier
within the area where hazardous voltage is
present. Only trained service persons should
perform work in this area.
If present, this symbol is placed on the copier
within the area where electrostatic discharge
(ESD) may occur. ESD can damage the copier’s
electronic components. Avoid touching electronic components or circuit paths. Use proper
grounding devices when circuits are open to
outside areas.
If present, this symbol is placed on the product
within the area where hot surfaces are present.
Allow the product to cool before performing
work in this area.
ii
Contents
Chapter 1 Getting Started
Features ......................................................................................................................................................................................... 1-2
Copier Location and Environment ............................................................................................................................................. 1-3
Ten Easy Steps to Set Up Your HP Color Copier 210 or 210LX .............................................................................................. 1-4
Unpack Your HP Color Copier 210 ....................................................................................................................................... 1-4
Attach the Front-Panel Overlay ........................................................................................................................................... 1-6
Unlock the Scanner ............................................................................................................................................................... 1-7
Load the Print Cartridges ...................................................................................................................................................... 1-8
Load the Paper ..................................................................................................................................................................... 1-10
Check the paper-width selector .................................................................................................................................. 1-10
Check the output tray .................................................................................................................................................... 1-10
Load the paper ................................................................................................................................................................ 1-11
Install the Optional Automatic Document Feeder .......................................................................................................... 1-12
Connect the Power Cord ..................................................................................................................................................... 1-14
Turn the Copier On ............................................................................................................................................................... 1-15
Set the Front-Panel Language and Default Paper Size ................................................................................................. 1-16
Test the Copier ...................................................................................................................................................................... 1-17
Product Registration .................................................................................................................................................................. 1-18
Chapter 2 Using Print Cartridges and Different Paper TTypes
ypes
What You Need to Know About Print Cartridges .................................................................................................................... 2-1
Determining ink color (for users with color-vision deficiencies) ............................................................................ 2-2
Reading the ink-level indicator ...................................................................................................................................... 2-2
Out-of-ink sensing ............................................................................................................................................................ 2-2
What You Need to Know About Paper ..................................................................................................................................... 2-3
Paper Specifications ....................................................................................................................................................... 2-4
Papers to Avoid ................................................................................................................................................................ 2-4
Specifying the paper type ............................................................................................................................................... 2-5
Copying on HP Premium InkJet Paper ......................................................................................................................... 2-6
Copying on HP Glossy Paper .......................................................................................................................................... 2-6
Copying on HP Premium Transparency Film ............................................................................................................... 2-6
Chapter 3 Copying
Start Copying ................................................................................................................................................................................. 3-1
Copier Front Panel ....................................................................................................................................................................... 3-2
Setting Copy Quality .................................................................................................................................................................... 3-3
Reduce or Enlarge Copies .......................................................................................................................................................... 3-4
Make Copies Lighter or Darker .................................................................................................................................................. 3-5
Change Color Intensity ................................................................................................................................................................ 3-6
Clear/Stop ...................................................................................................................................................................................... 3-6
Menu Items ................................................................................................................................................................................... 3-7
Self-Test Page ................................................................................................................................................................... 3-7
Align Cartridges ................................................................................................................................................................ 3-7
Change Copy Paper Size ................................................................................................................................................. 3-7
TE (Text Enhancement) .................................................................................................................................................... 3-8
ELC (Enhance Light Colors) ............................................................................................................................................ 3-8
Setting Defaults ............................................................................................................................................................................ 3-8
Factory Defaults ........................................................................................................................................................................... 3-9
Copy Controllers ........................................................................................................................................................................... 3-9
Chapter 4 Automatic Document Feeder
Using the Automatic Document Feeder ................................................................................................................................... 4-2
Clearing a Paper Jam .................................................................................................................................................................. 4-3
Chapter 5 Copy Access Controllers
Installing a Copy Controller ........................................................................................................................................................ 5-2
Using a Copy Controller .............................................................................................................................................................. 5-2
Chapter 6 Troubleshooting and Maintenance
Using this Section ........................................................................................................................................................................ 6-1
Check the basics first ...................................................................................................................................................... 6-1
Front-Panel Messages ................................................................................................................................................................ 6-3
Print-Cartridge Problems .......................................................................................................................................................... 6-16
Clearing the print-cartridge nozzles ........................................................................................................................... 6-16
Clearing Jammed Paper in the Copier ................................................................................................................................... 6-20
Clearing Jammed Paper in the Automatic Document Feeder ........................................................................................... 6-23
Maintenance ............................................................................................................................................................................... 6-24
Cleaning the exterior case ........................................................................................................................................... 6-24
Cleaning the copy glass ................................................................................................................................................ 6-24
Cleaning inside the printer area .................................................................................................................................. 6-25
Cleaning under the copy glass .................................................................................................................................... 6-26
Reassembling the copier .............................................................................................................................................. 6-28
Getting Help ................................................................................................................................................................................. 6-29
HP Support Services ..................................................................................................................................................... 6-29
HP Audio Tips/HP FIRST ................................................................................................................................................ 6-30
CompuServe .................................................................................................................................................................... 6-31
Internet ............................................................................................................................................................................. 6-31
HP Customer Support ................................................................................................................................................................ 6-31
Calling in the U.S. and Canada during warranty ...................................................................................................... 6-31
Calling in the U.S. and Canada post warranty .......................................................................................................... 6-31
Calling in Europe ............................................................................................................................................................ 6-32
Calling in Australia and New Zealand ........................................................................................................................ 6-32
Calling elsewhere in the world .................................................................................................................................... 6-32
Returning Your HP Color Copier 210 for Service ................................................................................................................... 6-33
Prepare your HP Color Copier 210 for shipment ....................................................................................................... 6-34
Ordering accessories and supplies ........................................................................................................................................ 6-35
Chapter 7 Hewlett-Packard Limited W
arranty
Warranty
Extent of Limited Warranty ......................................................................................................................................................... 7-1
Limitations of Warranty ............................................................................................................................................................... 7-3
Limitations of Liability .................................................................................................................................................................. 7-4
Warranty Service ......................................................................................................................................................................... 7-4
Express service ................................................................................................................................................................ 7-4
Warranty Upgrades ..................................................................................................................................................................... 7-4
Index
chapter one
Getting Started
1
Congratulations! You have just entered a new era in copying freedom. The HP
Color Copiers 210 and 210LX produce high-quality, color and black-and-white
copies on a variety of paper types and sizes:
✦
Letter-sized paper
✦
A4 (European standard)
✦
Legal-sized paper
✦
Plain paper
✦
Inkjet paper
✦
Glossy paper
✦
Transparencies for overhead display
This user’s guide will get you set up and copying and will show you how to get
the most from your HP Color Copier 210.
WARNING Do not lift the HP Color Copier 210 by yourself. The box weighs 70 lbs (32 kgs)
(210LX: 85 lbs (39 kgs)) and requires at least two people to lift it.
HP Color Copier 210/210LX User’s Guide 1-1
document cover
lid
front panel
paper-width selector
lid release button
paper-length adjuster
paper tray
out tray
switch
Features
Your HP Color Copier 210 provides:
✦
Professional-quality color and black-and-white copies.
✦
A simple, easy-to-use control panel.
✦
A port (on the back of the copier) to connect an optional copy
access controller.
✦
In addition, the Color Copier 210LX includes an automatic document
feeder for loading up to 40 sheets at a time.
NOTE You can also purchase the automatic document feeder (C5305A) as a separate
item and add it to the HP Color Copier 210.
1-2
Getting Started
Copier Location and Environment
✦
Use only within normal office temperature and humidity ranges. The
recommended range is 59-95°F (15-35°C) and 20-80% relative humidity.
✦
Avoid direct sunlight or locations where a quick change in temperature might
cause condensation inside the machine.
✦
Make sure the location is well ventilated. Dust, gasses, or fumes (such as
ammonia or paint thinner) can damage the machine.
✦
Choose a site that is level, flat, and stable. The copier will produce some
shaking and needs to be on a sturdy surface.
✦
Be sure a grounded outlet is nearby and easily accessible.
WARNING Do not lift the HP Color Copier 210 by yourself. The box weighs 70 lbs (32 kgs)
(210LX: 85 lbs (39 kgs)) and requires at least two people to lift it.
HP Color Copier 210/210LX User’s Guide
1-3
Ten Easy Steps to Set Up YYour
our HP Color Copier 210 or 210LX
To properly set up your copier, you must follow these ten steps.
TIP If you’ve purchased a copy access controller, refer to Chapter 5, “Copy Access
Controllers,” for installation instructions.
1 Unpack YYour
our HP Color Copier 210
WARNING Do not lift the HP Color Copier 210 by yourself. The box weighs 70 lbs (32 kgs)
(210LX: 85 lbs (39 kgs)) and requires at least two people to lift it from its box
and place it on the surface where it will be used.
Carefully unpack and inspect your HP Color Copier 210 and its accessories.
Save the carton and packing materials in case you ever need to ship your HP
Color Copier 210. Be sure to check local, state, and national recycling laws
governing the disposal of any material associated with this product.
1 Remove all packing and shipping material from the copier.
2 With someone else, lift the copier to its final location.
1-4
Getting Started
3 Remove all the yellow/orange packing tape.
4 Check that the following items are included with your HP Color
Copier 210:
✦ power cord
✦ four print cartridges
✦ front-panel overlay (has text on it)
✦ user’s guide
✦ help card
✦ Color Copier 210LX: automatic document feeder
If any of the items are missing or damaged, contact the dealer from whom
you purchased your HP Color Copier 210.
HP Color Copier 210LX with automatic
document feeder attached
HP Color Copier 210
front-panel overlay (has text on it)
automatic document feeder
power cord
four color print cartridges
help card and user's guide
HP Color Copier 210/210LX User’s Guide
1-5
2 Attach the Front-Panel Overlay
1 Align the front-panel overlay with the front-panel buttons.
2 Press down firmly on the outside ends, and then on the middle to snap the
overlay into place.
Reduce/
Enlarge
Paper Type
Color Intensity
1-6
Getting Started
Select/
Resume
Lighter/
Darker
-
+
Black/
White
Menu
Best
Normal
Fast
Clear/
Stop
Color
3 Unlock the Scanner
1 Hold the top of the copier and firmly press the blue lid-release button on
the right side and allow the top of the machine to gently rise.
If you have trouble opening the copier, use your thumb and press the blue
button hard.
2 The scanner lock is on the left side of the lid near the hinge. To unlock the
scanner, slide the scanner lock toward the front of the copier.
NOTE Leave the scanner unlocked unless you need to move your HP Color Copier
210. Locking the scanner protects it during moving. (Refer to “Returning your HP Color
Copier 210 for Service,” in Chapter 6, for locking instructions.)
3 Leave the copier lid open.
HP Color Copier 210/210LX User’s Guide
1-7
4 Load the Print Cartridges
IMPORT
ANT Users with color-vision deficiencies can refer to Chapter 2, “Using Print
IMPORTANT
Cartridges and Different Paper Types,” for help in installing print cartridges
in the proper color sequence.
CAUTION Hold the cartridge by the black areas only. The color of the ink in the print
cartridge must match the color of the dot above the cartridge stall.
1 If you haven’t already done so, remove the shipping tape from the print
cartridge carriage.
2 Remove the print cartridge from the carton.
3 Remove the green tab and the blue tape by pulling the green tab and
peeling it and the tape off as shown in the following illustration:
Remove and discard green
tab and blue tape.
The colored area around the
edge of the label shows you the
color of ink in the cartridge.
1-8
Getting Started
4 Push the print cartridge firmly down into the correct carriage stall. The color
of the label must match the color of the dot above the stall. The following
illustration shows the yellow cartridge being installed:
5 Snap the print cartridge toward the back of the copier (until the cartridge can
go no further).
6 When all four print cartridges are securely in place, close the lid of your HP
Color Copier 210.
HP Color Copier 210/210LX User’s Guide
1-9
5 Load the Paper
Check the paper-width selector
✦
If you are loading U.S. letter- or legal-sized paper, move the paper-width
selector toward the back of the tray.
✦
If you are loading A4-sized paper, move the paper-width selector toward
the front of the tray.
For letter- or legal-sized paper, move the selector
toward the back of the tray.
For A4-sized paper, move the selector toward the
front of the tray.
Check the output tray
Make sure the notches on the left and right sides of the bottom of the output
tray are securely inside the slots on the top of the lower tray.
If the output paper tray is loose,
set the left and right notches into
the slots and press down gently.
1-10 Getting Started
Load the paper
1 Pull the paper-length adjuster from the lower tray until it comes to a stop.
2 Insert up to a ¾-inch (19 mm) stack of paper into the lower tray, print side
down, until it stops.
3 Push in the paper-length adjuster until the paper is fully inserted in the tray.
HP Color Copier 210/210LX User’s Guide 1-11
6 Install the Optional Automatic Document Feeder
If you have an HP Color Copier 210LX with the 40-sheet automatic document feeder, or if you have purchased the automatic document feeder
separately, install it next.
CAUTION Make sure the copier is turned off before installing the automatic document feeder.
1 If necessary, raise the document cover and pull it up to remove it.
IMPORT
ANT Do not discard the document cover. Store it in a safe place.
IMPORTANT
2 Insert the two hinges of the automatic document feeder into the slots on the
top of the copier.
1-12 Getting Started
3 Make sure that the automatic document feeder is securely in place.
4 Plug in the automatic document feeder.
HP Color Copier 210/210LX User’s Guide 1-13
7 Connect the Power Cord
The copier comes with the power cord for the country to which it is
shipped. If the plug on your power cord doesn’t look familiar, contact your
dealer or local HP Sales and Support Office.
WARNING In case of emergencies, be sure that the plug in the outlet is readily accessible.
Power is present in the copier even if the switch is off. To completely shut off
power, you must disconnect the power cord. To avoid electric shock, be sure to
use the power cord with a properly grounded outlet.
■ Insert the connector on the power cord into the power socket on the back of
the copier and the other end into a properly grounded power outlet.
1-14 Getting Started
8 TTurn
urn the Copier On
The switch is located on the right side, lower-front corner of the copier. When
the switch is in the off position, the machine is in a “standby” condition. This
means that although it is not functional, power is still applied.
When the machine is turned on, it must complete an initialization sequence
before it will be ready to make copies. If you open the lid during the initialization, the message Close lid will appear. You will not be able to use the
copier until you close the lid and allow the initialization to finish.
Push down the left side of the switch
to turn on the HP Color Copier.
If a new print cartridge was installed while the copier was off, the copier
automatically aligns the print cartridges . This procedure takes about 60 seconds.
The alignment procedure prints a page, so paper needs to
be loaded in the copier when it is turned on. Discard the page.
■ If the message Unlock scanner. Move green scanner lock on left side under lid
to unlocked position, and turn power off then on. appears, return to Step 3 to
for instructions on unlocking the scanner.
■ If the message Remove and check xxxx cartridge. appears (where xxxx is a
color), verify that the print cartridges are snapped all the way back in
their stalls. Return to Step 4 for instructions.
HP Color Copier 210/210LX User’s Guide 1-15
9 Set the Front-Panel Language and Default Paper Size
The copier is initially set to English and to Letter-sized paper (8.5 by 11
in.). To change the language displayed on the front panel and the default
paper size, follow these steps:
1 While holding down the Select/Resume button, press the Color Intensity
button.
2 Release both buttons. The current language is displayed.
3 Press the Plus (+) and Minus (–) buttons to scroll through the available
languages.
4 Press the Select/Resume button to select the displayed language.
After you have selected a language, you will be prompted to select Letter
(8.5 by 11 in.), A4 (210 by 297 mm), or Legal (8.5 by 14 in.) as the default
paper size.
5 Press the Plus (+) or Minus (–) button to see the paper sizes.
6 Press the Select/Resume button to select the displayed paper size.
1-16 Getting Started
10 TTest
est the Copier
Use the copier’s built-in self test to verify that the copier is operating
properly. A sample of the self test is shown below.
HP Color Copier 210 Self Test page
Model:
Serial:
Control:
Auto Doc Feed:
Copy Controller:
C5302A
xxxxxxxxxxx
4.1
YES
NO
1 Make sure that the Best, Normal, or Fast light is on and not blinking.
2 Press the Menu button until Self Test Page appears in the panel display.
3 Press the Select/Resume button.
The test-page printout has a set of four colored bars and lines, which should
appear solid, as shown in the sample. The intensity of the colors will vary
depending on the type of paper used (plain paper, HP Premium Inkjet paper,
HP Premium Glossy Paper, or HP Premium Transparency Film).
If thin, random streaks appear in the color bars when the test page is printed,
they indicate a copy-quality problem. For help solving copy-quality problems,
see the section titled “Print-Cartridge Problems” in Chapter 6, “Troubleshooting and Maintenance.”
4 If you installed an automatic document feeder, Auto Doc Feed: Yes should be
printed on the self-test page. (If you installed a feeder, but the self-test page
reads Auto Doc Feed: No, return to Step 8 of the Ten Easy Steps to Set Up
Your Copier, and verify that you plugged in the automatic document feeder
properly.)
5 To verify proper functioning of your HP Color Copier 210, make a copy of
the self-test page.
HP Color Copier 210/210LX User’s Guide 1-17
Product Registration
Please help us serve you better by filling out the product registration form
enclosed with your product.
1-18 Getting Started
chapter two
Using Print Cartridges and
Different Paper TTypes
ypes
2
What YYou
ou Need to Know About Print Cartridges
Your HP Color Copier 210 operates with four print cartridges: yellow,
magenta, cyan, and black. Except when printing the self-test page, all
four cartridges must be installed before you can make copies. Each time a
new print cartridge is installed, the copier automatically aligns the print
cartridges. A page is printed during cartridge alignment, so paper needs to
be loaded when the copier is turned on. Discard the page.
When printing black text only (about 5% density) on Letter/A4-sized paper,
ink lasts about 900 pages.
When printing graphics on Letter/A4-sized paper, using equivalent amounts
of each color, ink lasts approximately
✦
1850 pages per set of color cartridges at 15% density
✦
275 pages per set of color cartridges at 80% density
Remember, you must remove the protective tape from each print cartridge and
the print cartridge must be snapped fully down and forward in its stall.
HP Color Copier 210/210LX User’s Guide
2-1
Determining ink color (for users with color-vision deficiencies)
The copier uses four print cartridges. The colors, as installed from left to right,
are yellow, magenta, cyan, and black. Each cartridge has a part number that uses
a letter designation for the color of the ink. This part number is located on the
front label of the print cartridge (shown below).
1st Cartridge
2nd Cartridge
3rd Cartridge
4th Cartridge
Yellow
Magenta
Cyan
Black
51640Y
51640M
51640C
51645A
Reading the ink-level indicator
To check the amount of ink in each cartridge, look at the ink-level indicator on
the front of the cartridge. As ink is dispensed from the cartridge, the green area
in the ink-level indicator (all green when full) decreases, and you will see more
black area.
The ink-level indicator is only an approximation of the amount of ink remaining in the cartridge.
Color of ink in cartridge
Ink level will look like this
when cartridge is full (all
green).
Ink level will look like this
when cartridge is low or
empty (all black).
Ink-level indicator
Ink level (green area) will
decrease as ink is dispensed.
Out-of-ink sensing
When the HP Color Copier 210 senses that a print cartridge is out of ink, it
displays a message on the front panel. The copier then completes copying
the current page and stops. To continue your copy job, replace the affected
print cartridge and press the Select/Resume button. To continue using the
same print cartridge, press Select/Resume.
2-2 Using Print Cartridges and Different Paper Types
What YYou
ou Need to Know About Paper
The HP Color Copier 210 has been designed to copy on plain paper such as
photocopier or letterhead. For maximum color brilliance, use HP Premium
Inkjet paper. HP Premium Transparency Film and Glossy Papers provide the
highest print quality for finished presentations. Refer to the ordering information at the end of this manual for paper sizes, types, and part numbers.
CAUTION Do not use paper that has been preprinted by devices (such as laser printers and
copiers) that use toner. This includes some preprinted forms and letterheads.Toner will damage
your copier.
You can copy on letter-sized, A4-sized, and legal-sized paper. Color photocopy,
bond, and letterhead paper can be used in the copier; however, you cannot
copy on envelopes, labels, cards, and custom-sized letterhead or stationery.
Be sure that all paper is free of tears, dust, wrinkles, and curled or bent edges.
Handle all paper types by the edges only. (Oil from fingerprints can prevent ink
from adhering to the page.)
Always load paper print-side down and letterhead first in the lower tray.
Copying on the correct side will make a significant difference in quality with
most paper types.
IMPORT
ANT Do not load mixed sizes of paper in the lower tray. This could cause a jam in
IMPORTANT
the copier.
HP Color Copier 210/210LX User’s Guide
2-3
Paper Specifications
The way you feed paper (through the tray or through the document feeder)
dictates which kind of paper you can use. The following are the valid paper
types for each method.
Paper tray
✦
16- to 24-lb (60- to 90-g/m2) range
✦
Plain paper (white and color) and letterhead
✦
HP Premium Inkjet Paper
✦
HP Premium Glossy Paper
✦
HP Premium Transparency Film
Automatic document feeder
✦
16- to 28-lb (60- to 135-g/m2) range
✦
Plain paper (white and colored) and letterhead
✦
HP Premium Inkjet Paper
IMPORT
ANT Do not load glossy paper, photo paper, or transparency film in the automatic document feeder.
IMPORTANT
Papers to Avoid
These papers can cause a paper jam or adversely affect copy quality:
✦
Paper heavier than 24 lb (90 g/m2) or lighter than 16 lb (60 g/m2) in the
lower paper tray. The automatic document feeder can accept paper up to
28 lbs (105 g/m2).
✦
Paper with cutouts or perforations.
✦
Multiple-part forms.
✦
Inkjet or glossy paper other than HP Bright White Inkjet, Premium Inkjet, or
Premium Glossy Paper.
✦
Transparency film other than HP PremiumTransparency Film.
✦
Any size paper other than Letter, Legal, or A4.
✦
Label stock or envelopes.
2-4 Using Print Cartridges and Different Paper Types
Specifying the paper type
Each time you load a different type of paper in the paper tray, use the frontpanel Paper Type button to specify the new type.
1 To browse through the paper types, press the Paper Type button on the front
panel. The paper type with the black dot to the right side of the display is
the currently selected setting.
2 To select the paper type that matches the paper loaded in the paper tray,
press Select/Resume:
Paper
Paper Type Setting
Copier paper or letterhead
Plain Paper
HP Bright White Inkjet Paper
Plain Paper
HP Premium Inkjet Paper
Premium Inkjet
HP Premium Glossy Papers
Glossy Paper
HP PremiumTransparency Film
Transparency
HP Color Copier 210/210LX User’s Guide
2-5
Copying on HP Premium Inkjet Paper
HP Premium Inkjet Paper has an arrow in the upper-right corner of the
nonprinting side of the paper. Place the paper arrow-side up in the paper tray.
Copying on HP Glossy Paper
Be sure to load the glossy side down in the paper tray. Always have 5 to 10
sheets in the paper tray. (If necessary, place the glossy sheets on top of plain
paper in the paper tray.)
Copying on HP Premium Transparency Film
HP Premium Transparency Film has a white strip at the top of each sheet.
Optical sensors in the copier use this strip to determine that transparency
film is loaded.
IMPORT
ANT Use only HP Premium Transparency Film when copying on transparencies. Other
IMPORTANT
transparency film can jam in the copier.
■ Insert the transparency with the white strip physically on top and on the end
going into the copier first. You can load a maximum of 80 transparencies
into the paper tray.
2-6 Using Print Cartridges and Different Paper Types
chapter three
Copying
3
Start Copying
1 Place the original face-down on the glass along the two green borders.
NOTE To copy successfully, you should place all originals, including small photographs,
in the corner along the two green borders.
2 Press the Plus (+) and Minus (–) buttons until the number of copies you want
to make is displayed on the front panel.
HP Color Copier 210/210LX User’s Guide
3-1
3 Press the Copy Quality button until the light appears next to the speed and
quality of the copy you want to make.
Black/
White
Color
Best
Normal
Fast
Copy Quality button
4 Press one of the following buttons to start copying:
✦ Black/White for black and white documents
✦ Color for color documents
Copier Front Panel
The rest of this chapter covers the buttons and menu items on the copier
front panel.
Reduce/
Enlarge
Paper Type
Color Intensity
3-2 Copying
Select/
Resume
Lighter/
Darker
-
+
Black/
White
Menu
Best
Normal
Fast
Clear/
Stop
Color
Setting Copy Quality
Use the Copy Quality button to change the speed and quality of the copy. You
can choose from the following three quality settings: Best, Normal,
and Fast.
Best: Produces the highest copy quality for all paper types and eliminates
the banding effect that sometimes occurs in solid areas. Note that for most
documents, the Best setting copies more slowly than the Normal setting.
Normal: Delivers high-quality output and is the recommended setting for
most copying. Normal is the default copy-quality setting for most paper
types.
Fast: Copies faster than the Normal setting and produces draft quality. Using
Fast also cuts down on the frequency of replacing your print cartridges because
it uses less ink.
To select the copy quality you want, press the Copy Quality button. The
light next to your selection turns on.
IMPORT
ANT If you consistently use a setting on the front panel other than the default—for
IMPORTANT
example, if you use Best rather than Normal—you can establish that setting as
the default for your copier. For details, refer to the “Setting Defaults” section later in this
chapter.
NOTE The default setting is indicated by a black dot (●).
HP Color Copier 210/210LX User’s Guide
3-3
Reduce or Enlarge Copies
The HP Color Copier 210 contains predefined settings for reducing and
enlarging copies. Using these settings, you can enlarge standard photograph
sizes to letter/A4, or take advantage of a special feature called Auto Fit.
Auto Fit does a pre-scan of the item on the glass and automatically sizes it to
fit the current copy paper size. The pre-scan makes Auto Fit a bit slower than
the standard copy procedure, but it ensures that the edges of your original
always appear on the copy.
NOTE To copy successfully using Auto Fit, you must place all originals, including small
photographs, in the corner along the two green borders.
When enlarging, Auto Fit enlarges the item to the largest size that can fit on
the page without distorting the image.
NOTE If the list of photograph sizes (e.g., 4x6 → Ltr or 13x20cm → A4) doesn’t look
familiar, verify that the correct copy paper size has been set for your copier. Refer to
“Change Copy Paper Size” later in this chapter.
1 Press the Reduce/Enlarge button.
2 To scroll through the list of settings, press the Plus (+) or Minus (–) buttons.
Refer to the Help Card for the list of options.
3-4 Copying
3 To confirm your selection, press the Select/Resume button.
NOTE To reduce and enlarge 1% at a time, press and hold down the Reduce/Enlarge
button, and then use the Plus (+) and Minus (–) buttons to change the Reduce/
Enlarge percentage.
The default setting is indicated by a black dot (●).
IMPORT
ANT If you consistently use a setting on the front panel other than the default, you can
IMPORTANT
establish that setting as the default. For example, you can change Reduce/Enlarge to Auto
Fit. For details, refer to the “Setting Defaults” section later in this chapter.
Make Copies Lighter or Darker
To adjust the lightness and darkness of copies, follow these steps:
1 Press the Lighter/Darker button. The range of lightness/darkness values
appears on a scale on the display.
2 To make the copy darker, press the Plus (+) button. (The dot moves to the
right.) To make the copy lighter, press the Minus (–) button. (The dot
moves to the left.)
3 To confirm your selection, press the Select/Resume button.
IMPORT
ANT If you consistently use a setting on the front panel other than the default, you can
IMPORTANT
establish that setting as the default. For example, you can change Lighter/Darker to a
lighter setting. For details, refer to the “Setting Defaults” section later in
this chapter.
HP Color Copier 210/210LX User’s Guide
3-5
Change Color Intensity
Use the Color Intensity button to make colors more vivid or more subtle.
1 Press the Color Intensity button. The range of color intensity values appears
on a scale on the display.
2 To produce copies with more intense or vivid colors, press the Plus (+)
button. (The dot moves to the right.) To produce copies with paler, more
subtle colors, press the Minus (–) button. (The dot moves to the left.)
3 To confirm your selection, press the Select/Resume button.
NOTE You can also use the Enhance Light Colors (ELC) setting to enhance the light-color
backgrounds of documents (such as maps and invoices). Press the Menu button
repeatedly until ELC appears on the front panel display. Press the Plus (+) or
Minus (–) button to turn ELC on (noted by a dot). Then press the Select/Resume
button.
IMPORT
ANT If you consistently use a setting on the front panel other than the default, you can
IMPORTANT
establish that setting as the default. For example, you can change the Color
Intensity default to a more vivid setting. For details, refer to the “Setting Defaults”
section later in this chapter.
The default setting is indicated by a black dot (●).
Clear/Stop
■ To stop copying or to return front panel settings to their default values, press
the Clear/Stop button.
3-6 Copying
Menu Items
Self-Test Page
Use the self-test page to check the print cartridges and to determine whether
you have the automatic document feeder or a copy controller successfully
installed.
■ To print the self-test page, make sure that Self Test is displayed on the front
panel display. Then press Start. Refer to Chapter 1, “Getting Started,” for
more information on the Self Test.
Align Cartridges
Print cartridges are automatically aligned when they are installed. However,
if you are experiencing print-quality problems (for example, if white lines
appear between adjacent black and colored areas), it is a good idea to align
the cartridges again.
■ To align the print cartridges, make sure that Align Cartridges is displayed on
the front panel display. Then press Select/Resume.
Change Copy Paper Size
With the HP Color Copier 210, you can copy on Letter, Legal, and A4 paper.
To change the copy paper size, follow these steps:
1 Press the Menu button repeatedly until Copy Paper Size appears on the front
panel display. To display the current default paper size, press the Select/
Resume button.
2 To scroll through the paper sizes, press the Plus (+) or Minus (–) button.
3 When the paper size you want appears in the front panel display, press the
Select/Resume button to confirm your selection. The paper size you select
must correspond to the size of the paper in the lower tray.
NOTE To cancel without making a selection, press the Clear/Stop button.
HP Color Copier 210/210LX User’s Guide
3-7
TE (Text Enhancement)
The TE (Text Enhancement) setting sharpens the edges of black text. It
should be turned on in most situations. Turn off TE if
✦
stray dots of color surround some text
✦
large, black typefaces have a splotchy (not smooth) appearance
✦
thin, colored objects or lines contain black spots
1 With TE displayed on the front panel display, use the Plus (+) and Minus (–)
buttons to cycle between o (off ) and ● (on).
2 To confirm your selection, press Select/Resume.
ELC (Enhance Light Colors)
Use ELC (Enhance Light Colors) to copy very pale colors. Turn on ELC if
very pale colors are printing as white.
1 With ELC displayed on the front panel display, use the Plus (+) and Minus
(–) buttons to cycle between o (off) and ● (on).
2 To confirm your selection, press Select/Resume.
Setting Defaults
If you consistently use a setting on the front panel other than the default,
you can establish that setting as the default.
NOTE The default setting is always indicated by a black dot (●).
For example, to set Reduce/Enlarge to Auto Fit, follow these steps:
1 Press the Reduce/Enlarge button until Auto Fit is displayed, and then press
Select/Resume.
2 Press the Menu button until Set Defaults is displayed.
3 Press Select/Resume. Current settings saved as defaults is displayed.
3-8 Copying
Factory Defaults
To return all the settings on the control panel to their factory defaults follow
this step:
■ With Factory Defaults displayed on the menu, press Select/Resume. Returned
to factory defaults is displayed.
Copy Controllers
This menu setting is used only if you have a copy access controller for
your HP Color Copier 210. Refer to Chapter 5, “Copy Access Controllers,”
for information.
HP Color Copier 210/210LX User’s Guide
3-9
3-10 Copying
chapter four
Automatic Document Feeder
4
With the automatic document feeder you can feed up to 40 sheets of paper at
a time. You can copy on A4, letter-sized, and legal-sized paper.
NOTE To prevent paper jams, use plain and inkjet paper only. Do not feed glossy paper, transparencies, labels, or envelopes.
For complete instructions on installing the automatic document feeder, refer
to Chapter 1, “Getting Started.”
HP Color Copier 210/210LX User’s Guide
4-1
Using the Automatic Document Feeder
You can feed up to 40 sheets of paper at a time.
1 If it is not already on, turn on the HP Color Copier 210 using the switch
located on the lower-right side toward the front of the copier.
2 Adjust the paper size selector: letter, A4, or legal.
3 Insert the originals faceup in the feeder. Notice the symbol on the feeder tray.
Make sure that you insert the paper all the way in the back of the automatic
document feeder.
4 When the originals are in place, Document loaded. will appear. Press the Start
Copy button.
4-2
Automatic Document Feeder
Clearing a Paper Jam
If paper jams in the automatic document feeder, follow these steps:
1 Raise the automatic document feeder cover.
2 Gently remove the paper.
3 Close the automatic document feeder cover by pressing it in the center
(as opposed to one side). It clicks into place.
HP Color Copier 210/210LX User’s Guide
4-3
4-4
Automatic Document Feeder
chapter five
Copy Access Controllers
5
Copy access controllers provide security and accounting for your HP Color
Copier 210. Depending on the type of controller, users might be assigned a
code, have a card (sometimes called a “smartcard” or “swipecard”), or require
coins (or other means) for access to the copier. Some copy controllers can
also separately track the numbers of black and white and color pages copied.
Consult your copy access controller documentation for instructions on using
your copy controller. Make sure that your copy controller supplier provides
you with the specific cable to connect your copy controller to an HP Color
Copier 210.
HP Color Copier 210/210LX User’s Guide
5-1
Installing a Copy Controller
1 Turn off the HP Color Copier 210.
2 Plug the copy controller into the port in the back of the HP Color
Copier 210.
3 Turn on the copy controller and then the HP Color Copier 210.
4 Press the menu button until Copy Controller is displayed on the front panel
display.
CAUTION After you have activated a copy controller, you will be able to make copies only
if the copy controller is attached.
5 To activate the copy controller, press Select/Resume.
6 To confirm, press Select/Resume again. Pressing any other key will cancel
activating the copy controller.
Using a Copy Controller
After a copy controller has been activated, the only way to make copies is
through the copy controller. If a person tries to make a copy without using
the copy controller, the following message will appear:
Cannot copy. Access through copy controller.
If the copy controller is turned off, disconnected, or otherwise disabled, the
following message will appear:
Cannot copy. Copy controller disconnected.
5-2 Copy Access Controllers
chapter six
Troubleshooting and
Maintenance
6
Using this Section
The troubleshooting tables in this section provide solutions for
✦
Copier and copy-quality problems
✦
Copier-operation problems
Check the basics first
✦
Make sure the copier has power and is turned on.
✦
Be sure that the lid is closed.
✦
Check the front-panel display for messages telling you to take a specific
action (for example, Out of Paper).
NOTE If the display is in a language you do not understand, refer to “Set the Front Panel
Language and Default Paper Size” in Chapter 1.
HP Color Copier 210/210LX User’s Guide 6-1
If the indicated problem is with the print cartridges...
✦
Look at the ink-level indicator to make sure none of the print
cartridges is out of ink. (Refer to “Reading the ink-level indicator”
in Chapter 2.)
✦
Make sure that all tape has been removed from the print-cartridge
nozzles.
✦
Make sure that all print cartridges are snapped fully forward in the
carriage. If they are not properly installed, the front panel will display
an error message instructing you to remove and check a cartridge.
After you fix this problem, close the lid and press either the Black/
White or Color Start button. (Refer to “Load the Print Cartridges” in
Chapter 1.)
If the indicated problem is with the loaded paper...
✦
Push the paper-length adjuster forward to make sure the paper is
loaded fully forward in the lower tray. Be careful not to bend the paper.
✦
Make sure that the paper-width selector is set for the paper width you
are using (to the back of the copier for A4 and to the front of the copier
for Letter/Legal).
If your copier has a paper jam, make sure that...
✦
The lid is closed.
✦
The paper-width selector is set for the paper width you are using.
✦
The proper size paper is being used.
✦
Paper is loaded fully forward in the tray.
If you see the message Turn Power off and then on again, do so. If you see
the message Error #### (Error followed by a number), write down the
error number and call for service.
6-2 Troubleshooting and Maintenance
Front-Panel Messages
Message
Possible cause
Solution
Paper Jam.
Paper has jammed in copier or automatic
document feeder.
If only one or two sheets of paper are in the
paper tray, the copier might not pick the
paper properly, causing a paper jam in the
copier.
Refer to “Clearing Jammed Paper” later
in this chapter.
Remove the paper jam and install more
paper in the paper tray.
HP Premium Transparency Film was loaded
with the wrong end going in first, causing a
paper jam. The jam is caused by the sensor
not finding the paper strip; therefore it finds
no paper. You can also get an Out of Paper
message.
Remove the paper jam and load HP
Premium Transparency Film in the paper
tray with the white strip going in first and
on top.
Out of paper
Paper tray is out of paper or the paper is not
fully inserted into the tray.
Load paper into paper tray.
Remove and check
[black or color] cartridge
A print cartridge is either incorrectly
installed, the wrong type, or defective.
Reseat or replace the print cartridge into
correct cartridge stall. Make sure the tape
has been removed from the print cartridge
nozzles. Be sure cartridges are inserted
fully forward and snapped into place.
ADF Paper Jam.
Paper is jammed in the automatic
document feeder.
Refer to “Clearing Jammed Paper in the
Automatic Document Feeder” later in this
chapter.
Unlock scanner.
The scanner was not unlocked when the
copier was set up.
Turn off the copier. Press the blue button
on the right side of the copier to open the
machine. On the left side near the hinge is
a green scanner lock. Move it to the open
position.
Refer to “Unlock the Scanner” in Chapter
1 for directions with pictures.
[Black or color] Ink Low.
Print cartridge is running out of ink.
Replace print cartridge. (You might be
able to copy some more pages. Press
Select/Resume to continue.)
Lid Open.
After pressing the blue button to open the
machine, the lid was not closed securely.
Close lid.
HP Color Copier 210/210LX User’s Guide 6-3
Front-Panel Messages
Message
Possible cause
Solution
Can’t Copy.
Copy controller problem.
Refer to Chapter 5 for details.
The paper size loaded does not
match the paper size selected.
The paper currently loaded in the copier
does not match the size set in the front
panel display. For example, the front panel
display is set to A4 paper, and Letter is
loaded in the copier.
Set the correct Paper Size using the front
panel display.
No Cartridge. Insert [black or
color] cartridge.
A print cartridge is missing from the copier.
Unless you are printing a self-test page, all
four cartridges must be present.
Load the missing cartridge.
Scanner bulb failing.
The scanner bulb is becoming too dim to
work properly.
Call for service. Refer to “Getting Help”
later in this chapter.
6-4 Troubleshooting and Maintenance
A blank page came out of the HP Color Copier 210
Possible Causes
Solutions
Protective tape is still on the print cartridge.
Each new print cartridge is packaged with protective plastic tape
covering the ink nozzles. Remove the print cartridge from its stall
and, being careful to touch only the black plastic, gently remove any
tape covering the nozzles. Replace the print cartridge in its stall.
Original not placed in corner along green edges
and Auto Fit is turned on.
Place all originals on glass along green borders.
Original placed print-side up on the glass.
Be sure the document you are copying is placed print-side down on
the glass.
Print cartridges need to be replaced.
The best way to check this is to print a self-test page. Press the Menu
button until Self Test Page appears on the display. Press the Select/
Resume button to print the self-test page. If any of the colored bars
are missing (cyan, magenta, yellow, or black), the appropriate print
cartridge must be replaced.
HP Color Copier 210/210LX User’s Guide 6-5
Placement on the page is wrong or the edges are cut off
Possible Causes
Solutions
Auto Fit doesn’t enlarge to full size.
Note: Auto Fit will make the copy as big as possible, without
distorting it.
Make sure the copy paper size is correct.
Clean the glass and document cover. Any dirt or smudges on either
the glass or cover will be sensed by the scanner and cause the
enlargement to be inaccurate.
Check to make sure the copy paper size is correct.
Make sure the original is placed in the corner along the two
green borders.
Edges of the copy get cut off.
Press the Reduce/Enlarge button repeatedly until Entire 93%
appears on the display. You can also press the Plus (+) or Minus (-)
buttons to scroll through the available Reduce/Enlarge options. Press
the appropriate Start Copy button to make the copies.
Auto Fit will automatically reduce the copy to completely fit on the
page. Press the Reduce/Enlarge button until Auto Fit appears. Press
Start Copy.
The copy image seems to have shifted or jumped.
Either the document cover was lifted or uneven
pressure was applied to the document cover during
copying.
Copy again and be sure not to lift or press down on the document
cover.
When using A4-sized paper, the last few lines on
original do not appear on the copy. The paper size
settings are not correct.
Set the paper-width selector on the paper tray toward the front
of the tray (for A4-sized paper). Refer to Chapter 1 for these
instructions.
6-6 Troubleshooting and Maintenance
Colors are incorrect
Possible Causes
Solutions
One of the color ink chambers might be running
out of ink, or the nozzles in the print cartridge might
be clogged.
Print a self test by pressing the Menu button until
Self Test Page appears on the display. Press the Select/Resume
button and the self-test page is printed.
If any of the colored bars are missing (cyan, magenta, yellow, or
black), the appropriate print cartridge must be replaced. If streaks
or white lines appear in any of the colored bars, the cartridges need
to be cleared.
Follow the cartridge clearing instructions later in this chapter.
You might have a defective print cartridge.
Print a self test by pressing the Menu button until
Self Test Page appears on the display. Press the Select/Resume
button and the self test page is printed.
If any of the colored bars are missing (cyan, magenta, yellow, or
black), the appropriate print cartridge must be replaced. If streaks
or white lines appear in any of the colored bars, the cartridges need
to be cleared.
Follow the cartridge clearing instructions later in this chapter.
Copies are too vivid or bright
Possible Causes
Solutions
Color intensity is too high.
Press the Color Intensity button. Press the Minus (–) button to
minimize the color intensity and make your copy more pale. The
dot moves to the left. Press Select/Resume to confirm your selection.
HP Color Copier 210/210LX User’s Guide 6-7
Pages did not come out of the HP Color Copier 210, or it seems to copy very slowly
Possible Causes
Solutions
No paper, or paper is loaded in the wrong tray.
The HP Color Copier 210 might be out of paper or the paper
might be in the wrong tray. Be sure the paper is in the bottom tray.
The scanner may be locked.
A locking mechanism holds and protects the scanner optics during
shipment. You must unlock it before you use the HP Color Copier
210. The lock is located on the left side, under the lid. Refer to
Chapter 1 for unlocking instructions.
Note: If the scanner is locked, you will hear a loud noise when you try
to make a copy.
The HP Color Copier 210 might not be
turned on.
The power switch is located on the bottom right side of the copier,
toward the front. A light, located next to the Copy Quality button,
lights up when the HP Color Copier 210 is turned on. As the
HP Color Copier 210 is initializing, the green light blinks and
Initializing appears on the display. When the HP Color Copier 210
is ready, 1 Copy / 100% appears on the display.
You are using the Best copy quality setting while
making copies.
You can change the speed and quality of your copy using the Copy
Quality button. Best is the slowest setting but has the highest quality.
Fast is the fastest setting and has the lowest quality. The Normal
setting is in between Best and Fast and is the recommended setting
for most copy jobs.
Press the Copy Quality button until the light is next to the setting
you want, and then press the Select/Resume button to confirm your
selection. Start your copy by pressing the appropriate Start Copy
button.
You are copying onto transparency or glossy paper types.
When you are copying onto transparencies and glossy papers, the
copying process slows down to allow the ink to dry.
You turned off the HP Color Copier 210 when you
were not using it.
The scanner bulb shuts off if it remains idle for 12 hours. It must
warm up the first time it is used. To shorten the warm-up time, leave
the product turned on.
6-8 Troubleshooting and Maintenance
Copies are faded or colors are dull
Possible Causes
Solutions
Incorrect paper-type setting.
Make sure that the paper type selected on the front panel display
reflects the type of paper actually loaded in your HP Color
Copier 210.
Light colors print as white.
Turn on ELC (Enhance Light Colors) on the front panel display by
pressing the Menu button repeatedly until ELC appears. Press the
Plus (+) button to turn on ELC. The dot becomes solid. Press the
Select/Resume button, then press the Color Start Copy button to
make a copy.
The lamp is too dim.
If Scanner bulb failing appears on the front panel display, the lamp
needs to be replaced. Refer to the section “HP Customer Support,”
later in this chapter, for information on getting customer service.
The glass is dirty.
Clean the glass and underside of the document cover with a soft,
damp cloth.
The Color Intensity setting is too low.
Press the Color Intensity button. Press the Plus (+) button to
intensify the color and make your copy more vivid. The dot moves
to the right. Press the Select/Resume button, and then press the
appropriate Start Copy button.
The Lighter/Darker setting is too low.
Press the Lighter/Darker button. Press the Plus (+) button to darken
your copy. The dot moves to the right. Press the Select/Resume
button, and then press the appropriate Start Copy button.
HP Color Copier 210/210LX User’s Guide 6-9
Paper wrinkles and is very wet
Possible Causes
Solutions
You are copying a page with very dark colors.
Press the Lighter/Darker button. To lighten your copy, press the
Minus (–) button. The dot moves to the left. Press the Select/Resume
button, and then press the appropriate Start Copy button.
You can also press the Color Intensity button to lighten your copy.
Press the Minus (–) button to minimize the color intensity and
make your copy more pale. The dot moves to the left. Press the
Select/Resume button, and then press the appropriate Start Copy
button.
Ink bleeds on the paper or the print seems fuzzy. The
paper becomes excessively wrinkled.
You might be using the wrong paper. Use paper supported and
recommended by HP.
You might be copying on the wrong side of the paper. Verify you
have loaded paper with the print side down in the paper tray.
You might be copying on plain paper in Glossy or Transparency
mode. Press the Paper Type button until Plain Paper appears in
the display, and then press Select/Resume.
You might not be copying within the specified environmental
conditions. Move the copier to a room where you can better
control the humidity.
6-10
Troubleshooting and Maintenance
Copy quality is poor
Possible Causes
Solutions
Print cartridges need to be replaced or the nozzles
are clogged.
Print a self-test page by pressing the Menu button until
Self Test Page appears on the display. Press the Select/Resume
button to print the self test page.
If any of the colored bars are missing (cyan, magenta, yellow, or
black), the appropriate print cartridge must be replaced. If the page
streaks or white lines appear in any of the colored bars, the cartridges
need to be cleared.
The original is of poor quality.
Moiré patterns, such as bands, checks or stripes in the picture after it
is copied, are caused by copying a picture of poor quality, such as a
newspaper photo. To reduce moiré patterns, try placing one or more
clear plastic sheet protectors directly on the glass, and then place the
original face down on top of the plastic sheet. You can also try
reducing the copy by 3%. To reduce or enlarge copies in 1%
increments, press and hold down the Reduce/Enlarge button and
press the Plus (+) and Minus (–) buttons. To confirm the setting, press
Select/Resume.
Copy quality is set to Fast.
Press the Copy Quality button until the light is next to Normal
or Best.
HP Color Copier 210/210LX User’s Guide 6-11
Repetitive patterns are visible on the copy
Possible Causes
Solutions
The original is of poor quality.
Moiré patterns, such as bands, checks or stripes in the picture after it
is copied, are caused by copying a picture of poor quality, such as a
newspaper photo. To reduce moiré patterns, try placing the picture at
an angle on the glass. Or try placing one or more clear plastic sheet
protectors directly on the glass, and then place the original face down
on top of the plastic sheet. You can also try reducing the copy by 3%.
To reduce or enlarge copies in 1% increments, press and hold down
the Reduce/Enlarge button and then press the Plus (+) and Minus (–)
buttons. To confirm the setting, press Select/Resume.
The incorrect paper type is selected.
If you are using special papers, such as glossy, premium, or
transparencies, make sure the Paper Type you selected reflects the type
of paper in the bottom tray. Press the Paper Type button until the
correct paper type appears in the display and press Select/Resume.
The nozzles in the print cartridge might be clogged.
Print a self test page by pressing the Menu button until Self Test Page
appears on the display. Press the Select/Resume button to print the
self test page.
If any of the colored bars are missing (cyan, magenta, yellow, or
black), the appropriate print cartridge must be replaced. If streaks or
white lines appear in any of the colored bars, the cartridges need to
be cleared.
Follow the cartridge clearing instructions later in this chapter.
Image density and paper quality contribute to banding.
Banding might also indicate that the print cartridge
ink is getting low.
6-12
Troubleshooting and Maintenance
Banding can sometimes be improved by setting Best quality on the
front panel.
Copy quality is streaked, smeared, or has white horizontal lines
Possible causes
Solutions
The incorrect paper type is selected.
If you are using special papers, such as glossy, inkjet, or
transparencies, make sure the Paper Type you selected matches
the type of paper you have in the bottom tray. Press the Paper Type
button to make your selection.
Copying on the wrong side of the paper.
Be sure to put the paper print side down. Glossy paper should be
placed glossy side down. Gray arrows on Premium Inkjet paper
should be facing up. Blue arrows on transparencies should be
facing up.
Nozzles on print cartridges are clogged.
Print a self test page by pressing the Menu button until Self Test Page
appears on the display. Press the Select/Resume button to print the
self test page.
If any of the colored bars are missing (cyan, magenta, yellow, or
black), the appropriate print cartridge must be replaced. If streaks
or white lines appear in any of the colored bars, the cartridges need to
be cleared.
Follow the cartridge clearing instructions later in this chapter.
HP Color Copier 210/210LX User’s Guide 6-13
Miscellaneous Problems
Symptoms
Solutions
Back of newspaper print shows through. The copy has
picked up part of an image from the wrong side of the
original.
Press the Lighter/Darker button. Press the Minus (–) button to
lighten your copy. The dot moves to the left. Press the Select/Resume
button.
Thin, colored objects or lines contain black spots.
Turn off TE (Text Enhancement). Press the Menu button until
TE appears on the display. Press the Plus (+) or Minus (–) button
to turn TE off and then press the Select/Resume button.
White lines appear between adjacent black and
colored areas.
The print cartridges might need to be aligned. Press the Menu button
until Align Cartridges appears on the display. Press the
Select/Resume button. Discard the printed page when alignment
is complete.
Unwanted dots appear in the background.
This might occur if you’re copying from a gray or pastel original.
Do one of the following:
• Press the Lighter/Darker button. Press the Minus (–) button
to lighten your copy. The dot moves to the left. Press the
Select/Resume button.
• Press the Color Intensity button. Press the Minus (–) button
to make your copy paler. The dot moves to the left. Press the
Select/Resume button.
A halo effect, with dark splotchy patches, occurs in
dark areas such as black hair.
Press the Lighter/Darker button. Press the Minus (–) button to
lighten your copy. The dot moves to the left. Press the
Select/Resume button.
Thin, white, vertical lines appear in my copy.
Call HP Support Services. Refer to “HP Support Services” later in
this chapter for more information.
I want to Reduce/Enlarge something to a specific
percentage.
Press and hold down the Reduce/Enlarge button and then press
the Plus (+) or Minus (–) buttons until the specific percentage
appears. Press the Select/Resume button.
I want to use Reduce/Enlarge in English sizes, but
metric sizes are displayed.
Press the Menu button until Copy Paper Size appears on the display.
Press the Plus (+) or Minus (–) buttons until Letter or Legal appears,
and then press the Select/Resume button.
6-14
Troubleshooting and Maintenance
Miscellaneous Problems
Symptoms
Solutions
I want to use Reduce/Enlarge in metric sizes, but
English sizes are displayed.
Press the Menu button until Copy Paper Size appears on the display.
Press the Plus (+) or Minus (–) buttons until A4 appears, and then
press the Select/Resume button.
I choose the settings on the front panel, and they always
get reset when I press the Clear/Stop button or turn
off the HP Color Copier 210.
You can set your current settings as defaults. Choose the appropriate
settings on the front panel. Press the Menu button until Set Defaults
appears, and then press the Select/Resume button.
I selected Reduce/Enlarge, Lighter/Darker, Paper Type,
or Color Intensity button. How do I return to the
display where I can enter number of copies?
Press the Select/Resume button.
A white line (or two) prints on the copy.
The original probably has been folded. The paper reflects light away
from both sides of the fold, creating the white line. Place a book on
top of your original to minimize the fold.
The copy has noticeable streaks of ink down the page.
Ink has accumulated on the shim or on pinch rollers inside the
machine. Refer to “Cleaning the inside the printing area” later in
this chapter.
Paper repeatedly jams or copier tears the paper corner.
• The wrong size paper is loaded or the paper size selector is set
incorrectly. Be sure the paper-width selector on the lower tray
is set for your paper size.
• The leading edge is damaged or bent. Replace damaged or curled
paper.
• Your copier might have a hardware problem. Refer to “Getting
Help” later in this chapter.
Glossy paper curls excessively.
The Paper Type is not set for HP Premium Glossy paper. Press the
front-panel Paper Type button until Glossy appears in the display,
and then press the Select/Resume button. Be sure to load the
glossy side down in the tray.
Popping sounds are coming from the copier.
Stop copying immediately! You could be using paper that has been
preprinted with toner. Toner can damage the copier. Do not use
paper that has been preprinted with toner. (Toner is used in devices
such as laser printers and copiers.) If you want to use preprinted
forms or letterhead, be sure they are preprinted with ink.
HP Color Copier 210/210LX User’s Guide 6-15
Print Cartridge Problems
IMPORT
ANT If one or more print cartridges are not printing, you could have one of the
IMPORTANT
following problems:
✦
The print cartridge(s) might have a faulty circuit connection with
the copier.
✦
The print nozzles might still be covered with tape.
✦
The print cartridge(s) might be clogged.
✦
The print cartridge(s) might be out of ink.
Faulty circuitry can sometimes cause streaks or faded colors to appear
in your print job. Try reseating each cartridge to ensure good electrical
connection between the print cartridges and copier, and then print the
self test page. (See Chapter 1, “Getting Started,” for instructions.)
Air bubbles or paper dust can occasionally clog one or more nozzles on
a print cartridge. To clear the nozzles and restore print quality, first print
the self test page.
Clearing the print-cartridge nozzles
If a print cartridge is clogged (and printing the self test page does not
clear it), try to clear it manually. (Manual clearing can often clear nozzles
more effectively than a self test.) If the print cartridge is still clogged after
completing this procedure, replace the clogged print cartridge. Follow
these steps:
1 Print a self test page. (Refer to “Getting Started,” in Chapter 1 for complete
instructions on printing the self test page.)
6-16
Troubleshooting and Maintenance
2 Four solid color bars and lines on the test page should appear as shown
below. (The intensity of the colors will vary depending on the type of paper
used.)
If any color bar has streaks, print cartridge nozzles might be clogged, and the
corresponding cartridge needs to be cleared.
Streaks appear in bars due to clogged cartridge nozzles.
Gaps also appear in lines.
If streaks appear in the same area of all four bars, faulty print cartridge
circuitry might exist in just one print cartridge. Printing a self test page with
one print cartridge at a time can isolate the bad print cartridge (which
should then be replaced).
HP Color Copier 210/210LX User’s Guide 6-17
3 Open the lid by firmly pressing the blue button on the right side of
the machine.
4 Slide the cartridge selector to the print cartridge you want to clear.
6-18
Troubleshooting and Maintenance
5 Press the plunger on the side of the cartridge carriage down gently—but
firmly—once, and then release.
6 Print the self-test page again to see if the four bars appear solid.
If streaks still appear on your printout, the print cartridge might be out
of ink. Replace the print cartridge.
If the ink level indicator still shows that ink remains inside the print
cartridge, turn off the machine and remove the print cartridge. Using a
cloth dampened with water, clean the nozzles and contact plates (metal
parts of the cartridge). Reseat the print cartridge and repeat steps 4 and 5
above. Turn on the machine and print a self-test page to check the results.
If streaks still appear, have your copier serviced. Refer to the “Getting Help”
section in this chapter.
HP Color Copier 210/210LX User’s Guide 6-19
Clearing Jammed Paper in the Copier
Paper can get jammed inside the copier when
✦
You try to copy labels.
✦
The paper is improperly aligned in the paper tray.
✦
The wrong type, size, or weight of paper is loaded.
✦
You are using the wrong paper type.
✦
You are using the wrong paper size or weight.
✦
The paper-width selector on the front of the copier is incorrectly set.
✦
Paper is wrinkled or bent.
✦
The copier has failed mechanically.
WARNING The preheater and heater guard inside the copier are hot. To prevent injury,
allow the heaters to cool before you attempt to remove paper by hand.
1 Turn off the copier and open the lid by pressing the blue button on the right
side of the copier. (Opening the lid releases the pinch rollers, making it easier to
clear a paper jam.)
2 Remove the output tray and try to pull out the jammed paper.
If paper is still jammed, reinsert the output tray (matching the notches to the
slots on the top of the paper tray) and go to the next step.
6-20
Troubleshooting and Maintenance
3 Look inside the machine. If the jammed paper can be removed without
bending any of the metal parts, then remove the paper. If you cannot
remove the paper, go to the next step.
CAUTION Do not forcefully pull the paper; you might damage the paper-loading
mechanism.
4 Open the rear panel.
HP Color Copier 210/210LX User’s Guide 6-21
5 Grasp the paper plug by squeezing the green ring towards the thumb rest,
and then pull outward.
WARNING The preheater and heater guard inside the copier are hot. To prevent injury,
allow the heaters to cool before you attempt to remove paper by hand.
CAUTION Use extreme care when reaching inside the back of the machine to remove
jammed paper. (Never use tools to remove jammed paper.) Be sure to take hold
of the jammed paper only; the heater guard is thin and flexible and can easily
be damaged.
6 Carefully remove the jammed paper from the back of the copier.
7 Replace the paper plug.
8 Close the rear panel.
6-22
Troubleshooting and Maintenance
Clearing Jammed Paper in the Automatic Document Feeder
If you experience a paper jam in the automatic document feeder, follow
these steps:
1 Raise the automatic document feeder cover.
2 Gently remove the paper.
3 Close the automatic document feeder cover. (It clicks into place.)
HP Color Copier 210/210LX User’s Guide 6-23
Maintenance
Maintenance is limited to periodic cleaning. Clean inside the machine at least
once a year.
Cleaning the exterior case
Use a soft, damp, lint-free cloth to wipe dust, smudges, and stains off
the case.
Cleaning the copy glass
CAUTION Do not use abrasives, acetone, benzene, or carbon tetrachloride on the glass; these can cause
damage.
WARNING Turn off the machine and remove the power cord before cleaning. Even
though the machine is off, power is still being applied and electric shock could
occur.
1 Turn off the HP Color Copier 210 and raise the document cover.
2 Clean the glass with a soft cloth or sponge moistened with warm water and
a mild soap or detergent.
3 Rinse the soft cloth or sponge with clean water, wring out excess water, and
wipe any remaining soap or detergent from the glass.
4 Dry the glass with a chamois or cellulose sponge to prevent water spotting.
If soap or detergent does not clean the glass sufficiently, use isopropyl
alcohol as a cleaning agent.
6-24
Troubleshooting and Maintenance
Cleaning inside the printing area
1 Press the Start button. (No original needs to be on the copy glass.)
2 When the copier has taken a piece of paper and you hear the print cartridge
carriage start to move, turn off the power.
3 Lift the lid by pushing the blue button on the right side of the copier and
push the print cartridge carriage to the right.
WARNING The metal platen between the pinch rollers has a sharp edge that could cause
injury. Use care when cleaning this item.
4 Using a damp, lint-free cloth, wipe the platen located between the pinch
rollers. Also wipe the upper pinch rollers.
Clean pinch rollers.
Clean platen.
5 Repeat steps 1 and 2 using a dry, lint-free cloth.
6 Lower the lid and turn on the machine. (The paper will be ejected
automatically.)
7 Print the self test page to clean up any residual ink.
HP Color Copier 210/210LX User’s Guide 6-25
Cleaning under the copy glass
CAUTION Use care when removing and reassembling the copyboard so you do not damage
the glass.
1 Turn off the HP Color Copier 210.
2 Remove the document cover or automatic document feeder.
3 Using a screwdriver or a coin, slightly twist each of the screw caps in each
corner of the copyboard counterclockwise. Set the screw caps aside in a
safe place.
4 Remove each screw and place each one with the screw caps.
6-26
Troubleshooting and Maintenance
5 From the back of the machine, remove the three screws on the lid.
6 Grasp both sides of the copyboard (front and back) and carefully lift it off.
7 Refer to “Cleaning the copy glass” earlier in this chapter for glass-cleaning
instructions. Then reassemble the machine.
HP Color Copier 210/210LX User’s Guide 6-27
Reassembling the copier
CAUTION Use care when reinstalling the copyboard so you do not damage the glass.
1 Carefully lower the copyboard onto the lid of the machine.
2 Replace and tighten the three screws holding the copyboard to the back of the
machine.
3 Replace and tighten the screws at each corner of the top of the copyboard.
4 Return the screw caps to their places at each corner and use a flat screwdriver
or a coin to slightly twist each of the screw caps clockwise.
5 Replace the document cover or automatic document feeder.
6-28
Troubleshooting and Maintenance
Getting Help
Hewlett-Packard has support services available to help you in case you have
a problem with your HP Color Copier 210 copier.
Before you call for customer support, make sure you do the following:
1 Review this chapter.
2 Print the self-test page and save it in case you need to speak with a customer
support representative.
If you still have difficulty, begin by contacting the person who sold you
your copier. Your sales representative or dealer is familiar with your needs
and equipment and should be able to provide you with the information
you want.
HP Support Services
If you can’t find the answer you need in this book, contact one of the HP
support services listed in the following pages.
Some support services are available only in the U.S. and Canada, while
others are available in many countries worldwide. If a support service
number is not listed for your country, contact your nearest authorized HP
dealer for help.
HP Color Copier 210/210LX User’s Guide 6-29
CompuServe
Support information and interactive sharing of technical information is available on CompuServe’s HP Peripherals forum GO HPPER. To subscribe, call
CompuServe, Inc. at (800) 848-8199 and ask for representative #51. (Note:
This service is not operated by HP.)
Internet
For support information and documentation, visit the Hewlett-Packard home
page at http://www.hp.com.
HP Customer Support
If you still need help, call the HP Customer Support Center. Before calling,
have your date of purchase and serial number and be sitting near your copier.
Calling in the U.S. and Canada during warranty
Call (208) 323-2551 Monday through Friday from 6 a.m. to 10 p.m. Mountain
Standard Time (MST) and Saturdays from 9 a.m. to 4 p.m. MST. This service is
free during the warranty period of the HP Color Copier 210; however, your
standard long-distance phone charges still apply.
Calling in the U.S. and Canada post warranty
If your copier is not under warranty, you can call (800) 999-1148. A per-call
out-of-warranty support fee will be charged to your credit card. You can also
call (900) 555-1500 ($2.50 per minute) from 7 a.m. to 6 p.m. MST and Saturdays from 9 a.m. to 3 p.m. MST. Charges begin only when you connect with a
support technician. (Prices are subject to change without notice.)
HP Color Copier 210/210LX User’s Guide 6-31
Calling in Europe
You can call the support center in the following countries:
✦ Europe (English): 44 171 512 5202
✦ United Kingdom: 0171 512 5202
✦ Austria: 0660 6386
✦ Belgium (Dutch): 02 626 8806
✦ Belgium (French): 02 626 8807
✦ Denmark: 3929 4099
✦ Finland: 0203 47288
✦ France: 04 50 43 9853
✦ Germany: 0180 5 25 81 43
✦ Ireland: 01 662 5525
✦
✦
✦
✦
✦
✦
✦
✦
Italy: 02 26410350
Netherlands: 020 606 8751
Norway: 22 11 6299
Portugal: 01 441 7199
Spain: 902 321 123
Sweden: 08 619 2170
Switzerland (French): 0848 80 11 11
Switzerland (German: 0848 80 11 12
Calling in Australia and New Zealand
Call (03) 272-8000 in Australia or (09) 356 6640 in New Zealand. This service is
free for 12 months from the date of original purchase; however, your standard
long-distance phone charges still apply. For technical assistance after the free
period, a $25 flat fee per single incident will be charged.
6-32
Troubleshooting and Maintenance
Calling elsewhere in the world
Contact your local dealer or nearest HP Sales and Support Office for information on obtaining technical assistance or hardware repair services.
Returning YYour
our HP Color Copier 210 for Service
After obtaining authorization for hardware service from HP Customer Support Center, be sure to pack your HP Color Copier 210 in a protective carton.
We recommend you save the original shipping container for this purpose.
NOTE In-transit damage is not covered by the warranty, so always insure your shipment.
Use these guidelines before returning your HP Color Copier 210 for service:
1 Use the troubleshooting instructions to make certain the problem is in your HP
Color Copier 210 product and is not the result of configuration problems or
inappropriate settings. If possible, identify the defective function.
2 If repair is required, follow the steps in “Prepare your HP Color Copier 210
for shipment,” below. Please include these items in the box:
✦ A brief description of symptoms for service personnel. (Samples of print
quality problems are helpful.)
✦ A copy of the sales slip or other proof of purchase to establish the warranty
coverage period.
✦ Your name, address, and a phone number where you may be reached during
the day.
HP Color Copier 210/210LX User’s Guide 6-33
Prepare your HP Color Copier 210 for shipment
1 Turn on the HP Color Copier 210.
2 Open the copier lid by pressing the blue button on the right side of the copier.
Be sure to place your hand on top of the copier because the lid will pop open
quickly.
3 Remove all print cartridges.
CAUTION Print cartridges that remain inside can cause damage.
4 To minimize shipment damage to the HP Color Copier 210, lock the scanner
by sliding the scanner lock under the left side of the lid to the
locked position.
5 Turn off the HP Color Copier 210.
6-34
Troubleshooting and Maintenance
Ordering accessories and supplies
In the U.S., you can order copier supplies by calling HP Direct at (800) 5388787 to get the name of your local authorized HP dealer.
Outside the U.S., call your local authorized HP dealer.
Supplies/Accessories
HP Reorder
Number
Automatic Document Feeder
C5305A
Print cartridges
Black print cartridge
Cyan print cartridge
Magenta print cartridge
Yellow print cartridge
51645A
51640C
51640M
51640Y
Paper
HP Premium InkJet Paper, Letter
(200 sheets, 8.5 by 11 in.)
51634Y
HP Premium InkJet Paper, A4
(200 sheets, 210 by 297 mm)
51634Z
HP Premium Glossy Paper, Letter
(50 sheets, 8.5 by 11 in.)
(10 sheets, 8.5 by 11 in.)
C3836A
C3833A
HP Premium Glossy Paper, A4
(50 sheets, 210 by 297 mm)
(10 sheets, 210 by 297 mm)
C3837A
C3831A
HP Premium Transparency Film, Letter
(50 sheets, 8.5 by 11 in.)
(20 sheets, 8.5 by 11 in.)
C3834A
C3828A
HP Premium Transparency Film, A4
(50 sheets, 210 by 297 mm)
(20 sheets, 210 by 297 mm)
C3835A
C3832A
HP Color Copier 210/210LX User’s Guide 6-35
Supplies/Accessories
HP Reorder
Number
Customer Replaceable Parts
Call for service before ordering any of these parts.
Copier Wiper Frame Assembly
C3540-60034
Complete Document Cover
C5302-60004
Document Cover Inside Foam
C5302-60073
Document Cover Hinge Assembly
C5302-60074
Output Paper Tray Assembly
C5302-60025
Color Copier 210 Shipping Package
C5302-60075
ADF Top Cover Assembly
C5305-60018
ADF Paper Feeding Friction Pad
C5305-40069
ADF Shipping Package
C5305-60035
Front panel text overlay (call your dealer for the correct part
number for your language)
Power cord (call your dealer for the correct part number for
your country)
6-36
Troubleshooting and Maintenance
chapter seven
Hewlett-Packard
Limited Warranty
7
Product Number: C5302A/C5305A
Duration of Limited Warranty (Hardware): 1 Year
Duration of Limited Warranty (Software): 90 Days
Duration Limited Warranty (Print Cartridges): 90 Days
Extent of Limited Warranty
1 Hewlett-Packard (HP) warrants to the end-user customer that HP products
will be free from defects in materials and workmanship, for a specified time
after the date of purchase by the customer. The duration of this limited
warranty is stated above. Certain additional conditions and limitations
of HP’s warranty are stated in this User’s Guide. Those conditions and
limitations include:
(a) For software products, the warranty applies only to the media upon
which the product is recorded; and
(b) HP does not warrant the operation of any product to be uninterrupted
or error free.
HP Color Copier 210/210LX User’s Guide 7-1
2 HP’s limited warranty covers only those defects which arise as a result of
normal use of the product, and do not apply to any:
(a) Improper or inadequate maintenance;
(b) Software or interfacing not supplied by HP;
(c) Unauthorized modification or misuse;
(d) Operation outside the product’s environmental specifications, including
duty cycle abuse or use of a mechanical switchbox without a designated
surge protector;
(e) Use of non-supported printing media; or
(f ) Improper site preparation or maintenance.
3 For HP copier/printer products, the use of a non-HP or refilled print
cartridge does not affect either the warranty to the customer or any HP
support contract with the customer; print cartridge includes both toner
cartridges and print cartridges. However, if copier/printer failure or damage
is attributable to the use of a non-HP or refilled print cartridge, HP will
charge its standard time and materials charges to service the copier/printer
for the particular failure or damage.
4 If any software media product or print cartridge product proves defective
during the applicable warranty period, and if the product is covered by HP’s
warranty, the customer shall return the product for replacement.
5 If HP receives, during the applicable warranty period, notice of a defect in
hardware product which is covered by HP’s warranty, HP shall either repair
or replace the product, at its option. Any replacement product may be either
new or like-new, provided that it has functionality at least equal to that of
the product being replaced.
6 If HP is unable to repair or replace, as applicable, a defective product which
is covered by HP’s warranty, HP shall, within a reasonable time after being
notified of the defect, refund the purchase price for the product, provided
the customer returns the product.
7 On-site warranty and return to HP warranty services are available from any
authorized HP service facility or repair depot worldwide. Specific information regarding product returns is contained in Chapter 6.
8 This Limited Warranty Statement gives the customer specific legal rights.
The customer may also have other rights which vary from state to state in
the United States, from province to province in Canada, and from country
to country elsewhere in the world.
7-2
Hewlett-Packard Limited Warranty
Limitations of Warranty
1 NEITHER HP NOR ANY OF ITS THIRD PARTY SUPPLIERS MAKES
ANY OTHER WARRANTY OF ANY KIND, WHETHER EXPRESS OR
IMPLIED, WITH RESPECT TO ITS PRODUCTS. HP AND ITS THIRD
PARTY SUPPLIERS SPECIFICALLY DISCLAIM THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
2 To the extent that this Limited Warranty Statement is inconsistent with the
law of the locality where the customer uses the HP product, this Limited
Warranty Statement shall be deemed modified to be consistent with such
local law. Under such local law, certain limitations of this Limited Warranty
Statement may not apply to the customer. For example, some states in the
United States, as well as some governments outside the United States (including provinces in Canada) may:
(a) Preclude the disclaimers and limitations in this Warranty Statement
from limiting the statutory rights of a consumer (e.g., Australia and the
United Kingdom);
(b) Otherwise restrict the ability of a manufacturer to make such disclaimers
or impose such limitations; or
(c) Grant the customer additional warranty rights, specify the duration of
implied warranties which the manufacturer cannot disclaim, or not allow
limitations on how long an implied warranty lasts.
3 To the extent allowed by local law, the remedies provided in this Warranty
Statement are the customer’s sole and exclusive remedies.
4 Installation and warranty services are available outside the country of
initial purchase only if the customer pays HP international prices (“HP
international price” is equal to any non-U.S. dollar price). If the customer
transports a product from the country of initial purchase without having
paid HP international prices, any remaining warranty covers parts and
labor only and applies only if the product is returned to the country of
initial purchase.
HP Color Copier 210/210LX User’s Guide 7-3
Limitations of Liability
EXCEPT FOR THE OBLIGATIONS SPECIFICALLY SET FORTH
IN THIS WARRANTY STATEMENT, IN NO EVENT SHALL HP
BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY AND WHETHER
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Warranty Service
Express service
To obtain HP Express service, the customer must contact an HP service office
or an HP customer support center for basic troubleshooting first.
If a customer unit needs a minor part replacement and these parts can
normally be replaced by the customer, the customer replaceable components
may be serviced through expedited part shipment. In this event, HP will
prepay shipping charges, duty and taxes; provide telephone assistance on
replacement of the component; and pay shipping charges, duty and taxes for
any part that HP asks to be returned.
For some repairs, the HP Customer Support Center may direct customers to
designated Authorized Service Providers who are certified by HP to service
the HP Color Copier 210.
If a customer unit needs to be returned to HP for repair, HP will expedite
the repair or provide a replacement unit and will utilize an express delivery
service, when available by courier or by mail system to expedite the return
of the repaired or replacement unit.
Warranty Upgrades
Extended warranties and service option upgrades may be obtained through
your local HP authorized dealer or HP service centers.
In the U.S. and Canada, extended warranties may also be obtained by calling
HP at 1 (800) 835-4747.
7-4
Hewlett-Packard Limited Warranty
chapter eight
Technical Information
Speed Specifications
Power Specifications
Copy speed is related to the complexity of the document.
Source voltage
100–240V
Black Copy Speed (letter-sized, text)
Draft mode: 10 pages per minute
Normal mode: 9 pages per minute
Best mode: 6 pages per minute
Color Copy Speed
(letter-sized: mixed text and graphics)
Draft mode: 8 pages per minute
Normal mode: 3 page per minute
Best mode: 1.6 page per minute
(full page, full color graphics)
Draft mode: 4 pages per minute
Normal mode: 1.2 pages per minute
Best mode: .3 pages per minute
8
Frequency
50–60 Hz
Environmental Specifications
Operating ranges
5°–40°C (41°–104°F)
Recommended ranges
15°–35°C (59°–95°F)
Humidity
15%–80% RH non-condensing
Non-operating ranges
-40°–70°C (-104°–140°F)
HP Color Copier 210/210LX User’s Guide 8-1
Regulatory Notices
FCC Statement (U.S.A.)
The United States Federal Communications Commission
(in 47 CFR 15.105) has specified that the following notice be
brought to the attention of users of this product.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, any cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encourages to try to correct the interference by one or more
of the following measures:
• reorient the receiving antenna
• increase the separation between the equipment and the
receiver
• connect the equipment into an outlet on a circuit
different from that to which the receiver is connected
• consult the dealer or an experienced radio/TV technician for help
The user may find the following booklet prepared by the
Federal Communications Commission helpful: How to
Identify and Resolve Radio-TV Interference Problems. This
booklet is available from the US Government Printing
Office, Washington DC, 20402. Stock No. 004-000-00345-4.
CAUTION: Pursuant to Part 15.21 of the FCC Rules, any
changes or modifications to this equipment not expressly
approved by the Hewlett-Packard Company, may cause
harmful interference and void the FCC authorization to
operate this equipment.
8-2
Technical Information
Telecommunications General Approval (UK)
Pursuant to Section 22 of Telecommunications Act of 1984
this product is approved for secondary attachment to
approved primary attachment devices connected to the
telecommunication network under the General Approval
(NS/G/1234/5/100003).
DOC Statement (Canada)
Le présent appareil numérique n'émet pas de bruits
radioélectriques dépassant les limites applicables aux appareils
numériques de la classe B prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.
This digital apparatus does not exceed the Class B limits for
radio noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian Department of Communications.
Geräuschemission
LpA < 70 dB
am Arbeitsplatz
im Normalbetrieb
nach DIN 45635T. 19
VCCI-2
Declaration of Conformity
(According to ISO/IEC Guide 22 and EN45014)
Hewlett-Packard Company, 16399 West Bernardo Drive, San
Diego, California 92127-1899, USA
AND
Hewlett-Packard Singapore Pte. Ltd, 1 Clementi Loop #401/12, Margatio Districentre, ClementiWest Distripart,
Singapore 129808, Republic of Singapore
declares, that the product, HP Color Copier 210/210LX,
model number C5302A/C5303A conforms to the following
Product Specifications:
Safety: EN60950:1992 +A1 & A2
IEC 950:1991 +A1, A2 & A3
UL1950, 3rd Edn:1995
CSA22.2 No.950 3rd Edn.:1995
NON-016-SCFI-1993
EMKO TSE(74-SEC)207/1994
EMC: CISPR22:1993/EN55022:1994 - Class B
EN50082-1:1992
IEC 1000-4-2:1995 / EN61000-4-2:
1995 - 4kV CD, 8kV AD
IEC 1000-4-3:1995 / prEN55024-3:
1991 - 3V/m
IEC 1000-4-4:1995 / EN61000-4-4:
1995 - 1.0 KV Power Line
FCC Part 15 - Class B / ICES-003,
Issue 2 / VCCI-2*
IEC 1000-3-2:1995 / EN61000-3-2:1995
IEC 1000-3-3:1994 / EN61000-3-3:1995
Supplementary Information: LED'S IN THIS PRODUCT
ARE CLASS I IN ACCORDANCE TO IEC825-1.
The Product herewith complies with the requirements of
the Low Voltage Directive 73/23/EEC and EMC Directive
89/336/EEC, and carries the CE marking accordingly.
HP Color Copier 210/210LX User’s Guide 8-3
8-4
Technical Information
index
A
A4-sized paper 1-10, 1-16, 3-7
access controllers, copy 5-1–5-2, 6-4
accounting 5-1
alignment, print cartridges 1-15, 3-7
audio tips 6-31
Auto Fit 3-4
automatic document feeder 1-2,
1-12–1-13, 1-17, 2-4,
4-1–4-3, 6-3, 6-23
avoiding paper types 2-4
B
background dots 6-14
Best quality 3-3
black 2-2
blank page 6-5
bulb, scanner 6-4
C
cartridges, print
alignment 1-15, 3-7
cleaning 6-16–6-18
color of 2-2
ink level 2-2
loading 1-8–1-9
messages 6-3, 6-4
ordering 6-36
pages per set 2-1
problems 6-16–6-18
troubleshooting 6-2
case, cleaning 6-24
cleaning
copier 6-24–6-30
print cartridges 6-16–6-18
clearing settings 3-6, 3-9
color
incorrect 6-7
ink 2-2
intensity 1-17, 3-6, 6-7, 6-9
self test page 1-17
streaks 1-17
CompuServe support 6-32
controllers, copy access 5-1–5-2, 6-4
copier
cleaning 6-24–6-30
environment 1-3
features 1-2
locating 1-3
moving 1-7
reassembling 6-29
service 6-34–6-35, 7-4
setup 1-4
shipping 6-34–6-35
turning on 1-15
weight 1-1
copies
Auto Fit 3-4
blank page 6-5
clearing 3-6
color intensity 3-6, 6-7, 6-9
darkness 3-5
edges cut off 6-6
enlarging 3-4–3-5
faded 6-9
incorrect color 6-7
lightness 3-5
multiple 3-1, 6-15
newpaper 6-14
none print 6-3, 6-8
patterns on 6-12
placement wrong 6-6
placing originals 3-1
quality 3-2, 3-3, 6-11, 6-13, 6-15
reducing 3-4–3-5
speed 3-2, 3-3, 6-8
stopping 3-6
copy access controllers 5-1–5-2, 6-4
copy glass, cleaning 6-24, 6-26
cord, power 1-14
curling paper 6-15
customer support 6-32–6-34
cutout paper 2-4
cyan 2-2
D
damaged parts 1-5
darkness 3-5
defaults
color intensity 3-6
copy quality 3-3
darkness 3-5
enlarging 3-5
factory 3-9
front panel 6-15
language 1-16
lightness 3-5
paper size 1-16
reducing 3-5
setting 3-8
document feeder, automatic 1-2,
1-12–1-13, 1-17, 2-4,
4-1–4-3, 6-3, 6-23
dots, background 6-14
E
ELC (Enhance Light Colors) 3-6, 3-8
English language, front panel 1-16
English sizes 6-14, 6-15
Enhance Light Colors (ELC) 3-6, 3-8
enlarging 3-4–3-5, 6-14
envelopes 2-4
environment, copier 1-3
error messages. See messages
express service 7-4
exterior case, cleaning 6-24
F
Fast quality 3-3
fax support 6-31
feeder, automatic document 1-2,
1-12–1-13, 1-17, 2-4,
4-1–4-3, 6-3, 6-23
film. See transparency
FIRST support 6-31
forms, multiple-part 2-4
forms, preprinted 2-3
Index
I-1
front panel
about 3-2–3-9
defaults 6-15
language 1-16
messages 6-3–6-4
overlay 1-6
paper type setting 2-5
lines on copies 6-13
loading
paper 1-10–1-11, 2-3
print cartridges 1-8–1-9
location, copier 1-3
lock, scanner 1-7
locking scanner 6-35
G
M
glass, cleaning 6-24, 6-26
glossy paper 1-17, 2-4, 2-6, 6-15
magenta 2-2
maintenance 6-24–6-30
menus 3-7–3-8
messages. See also
problems; troubleshooting; specific
problems
can't copy 6-4
copy controller 5-2
error 6-1–6-4
front panel 6-3–6-4
ink low 6-3
lid open 6-3
out of paper 6-3
paper jams 6-3
power 6-2
print cartridges 1-15, 6-3, 6-4
scanner bulb failing 6-4
unlock scanner 1-15, 6-3
metric sizes 6-14, 6-15
missing parts 1-5
moving copier 1-7
multiple copies 3-1, 6-15
multiple-part forms 2-4
H
halo effect 6-14
help 6-30–6-34
HP support services 6-30–6-34
humidity 1-3
I
incorrect color 6-7
initialization 1-15
ink cartridges
alignment 1-15, 3-7
cleaning 6-16–6-18
color or 2-2
ink level 2-2
loading 1-8–1-9
messages 6-3, 6-4
ordering 6-36
pages per set 2-1
problems 6-16–6-18
troubleshooting 6-2
InkJet paper 1-17, 2-4, 2-6
intensity, color 1-17, 3-6, 6-7, 6-9
Internet support 6-32
J
jams, paper 4-1, 4-3, 6-2, 6-3,
6-15, 6-20–6-24
L
labels 2-4
language, front panel 1-16
legal-sized paper 1-10, 1-16, 3-7
letter-sized paper 1-10, 1-16, 3-7
letterhead 2-3
lid open message 6-3
lifting copier 1-1
lightness 3-5
I-2
Index
N
newspaper, copying 6-14
Normal quality 3-3
O
originals
feeding 4-2
placing 3-1, 3-4
output tray 1-10
overlay, front panel 1-6
P
packing materials 1-4
pages, number per print cartridge 2-1
paper
A4-sized 1-10, 1-16, 3-7
about 2-3–2-6
avoiding types 2-4
blank 6-5
jams 4-1, 4-3, 6-2, 6-3, 6-15,
6-20–6-24
legal-sized 1-10, 1-16, 3-7
letter-sized 1-10, 1-16, 3-7
loading 1-10–1-11, 2-3
ordering 6-36
out of, message 6-3
settings 2-5
size 1-10, 1-16, 2-3, 3-7, 6-4
specifications 2-4
torn 6-15
tray 2-4
troubleshooting 6-2
types 1-17, 2-4, 2-5, 2-6, 4-1, 6-15
wet 6-10
wrinkled 6-10
parts
damaged 1-5
missing 1-5
patterns on copies 6-12
perforated paper 2-4
photo paper 2-4
photographs, sizes 3-4
placing originals 3-1, 3-4
plug, power cord 1-14
popping sounds 6-15
power cord 1-14
preprinted forms 2-3
print cartridges
alignment 1-15, 3-7
cleaning 6-16–6-18
color of 2-2
ink level 2-2
loading 1-8–1-9
messages 6-3, 6-4
ordering 6-36
pages per set 2-1
problems 6-16–6-18
troubleshooting 6-2
printer area, cleaning 6-25
printing self-test page 3-7
problems. See also
messages; troubleshooting; specific
problems
background dots 6-14
black spots 6-14
blank page 6-5
color intensity 6-7, 6-9
copy quality 6-11, 6-13
copy speed 6-8
copying newspaper 6-14
curling paper 6-15
default settings 6-15
English sizes 6-14, 6-15
enlarging 6-14
faded copies 6-9
halo effect 6-14
incorrect color 6-7
metric sizes 6-14, 6-15
no copies print 6-8
paper jams 6-2, 6-15, 6-20–6-24
paper, loaded 6-2
patterns on copies 6-12
placement of copy 6-6
popping sounds 6-15
print cartridges 6-2, 6-16–6-18
reducing 6-14
wet paper 6-10
white lines 6-14, 6-15
wrinkled paper 6-10
product registration 1-18
Q
quality, copy 3-2, 3-3, 6-11, 6-13, 6-15
R
reassembling copier 6-29
recycling 1-4
reducing 3-4–3-5, 6-14
registration, product 1-18
S
scanner
bulb 6-4
lock 6-35
unlocking 1-7, 1-15, 6-3
security 5-1
self test 1-17, 3-7
service, copier 6-34–6-35, 7-4
settings
Auto Fit 3-4
clearing 3-6, 3-9
color intensity 3-6
copy quality 3-3
darkness 3-5
defaults 3-8, 6-15
Enhance Light Colors (ELC) 3-6, 3-8
enlarging 3-4
lightness 3-5
paper type 2-5
reducing 3-4
TE (Text Enhancement) 3-8
setup
automatict document feeder 1-12–1-13
defaults 1-16
front panel language 1-16
front panel overlay 1-6
loading paper 1-10–1-11
loading print cartridges 1-8–1-9
missing parts 1-5
paper size 1-16
power cord 1-14
test 1-17
turning on copier 1-15
unlocking scanner 1-7
unpacking 1-4–1-5
shipping copier 6-34–6-35
size
paper 1-10, 1-16, 2-3, 3-7, 6-4
photographs 3-4
smeared copies 6-13
sounds, popping 6-15
specifications, paper 2-4
speed, copy 3-2, 3-3, 6-8
spots, black 6-14
standby condition 1-15
stopping copying 3-6
streaked copies 6-13, 6-15
streaks, color 1-17
support
audio tips 6-31
CompuServe 6-32
customer 6-32–6-34
fax 6-31
Internet 6-32
telephone 6-31
T
TE (Text Enhancement) 3-8
telephone support 6-31
temperature 1-3
test 1-17, 3-7
Text Enhancement (TE) 3-8
toner 2-3
torn paper 6-15
transparency film 1-17, 2-4, 2-6
tray
output 1-10
paper 2-4
troubleshooting 6-1. See also
messages; problems; specific problems
U
unlocking scanner 1-7, 1-15, 6-3
unpacking copier 1-4–1-5
upgrades, warranty 7-4
V
ventilation 1-3
W
warranty 7-1–7-4
weight, copier 1-1
wet paper 6-10
white lines 6-13, 6-14, 6-15
wrinkled paper 6-10
Y
yellow 2-2
Index
I-3
I-4
Index
HP Color Copier 210/210LX
Reduce/Enlarge
Increases or decreases size of copies
Normal 100%
Entire 93%
Auto Fit
5x7 → LTR 147%
18x26cm → A4 107%
4x6 → LTR 172%
15x20cm → A4 131%
3.5x5 → LTR 206% 13x230cm → A4 140%
2.5x3.5 → LTR 295% 10x15cm → A4 186%
9x14cm → A4 200%
Max 400%
Min 50%
• Make a selection and press Select/
Resume
• To reduce/enlarge in 1% steps, hold
down the Reduce/Enlarge button and
press Plus (+) or Minus (–). Press Select/
Resume to confirm.
• Auto Fit scans the item on the glass and
enlarges (or reduces) it to fill as much of
the page as possible without distortion.
Menu
Display
Shows the information you specify for
making copies and status messages.
Select/Resume
Acts as an Enter button when you make
a selection.
Lighter/Darker
Lightens or darkens the copies. Make a
selection and press Select/Resume.
Provides copy paper size setting and
maintenance tasks.
Self Test Page
Align Cartridges
Copy Paper Size
TE (Text Enhancement)
ELC (Enhance Light Colors)–Turn on to
copy light backgrounds.
Set Defaults–Saves current settings
as defaults.
Factory Defaults–Returns to factory
settings.
Clear/Stop
Clears copy settings or stops a copy job.
Color
Makes color copies.
Paper TType
ype
Make a selection and press Select/Resume.
Plain Paper
Premium InkJet
Glossy Paper
Color Intensity
Transparency
Makes copies more vivid or paler. Make
a selection and press Select/Resume.
Copy Quality
Black/White
Makes black-and-white or gray scale
copies.
Minus (–) or Plus (+)
Selects the number of copies and scrolls
through available settings.
Changes copy quality settings.
Best:
highest quality for all paper
Best
types but is slower
Normal
Normal: high-quality, recommended for
most documents
Fas
Fastt :
draft quality, faster, uses less ink
HP Color Copier 210/210LX
Change Print Cartridges
1. Press blue button (hard) on the
right side of the copier to open the
top of the machine.
2. Remove old cartridge.
3. Insert new cartridge.
Load Paper
1. Slide the paper width and length
adjusters to their outermost positions.
2. Insert up to a 3/4-inch (19 mm) stack
of paper into the bottom tray, print
side down, until it stops.
*C5302-90040*
C5302-90040
3. Slide the paper width and length
adjusters in until they stop at the
edges of the paper.
