HP StorageWorks arrays: Bridging
the gap between data explosion
and storage infrastructure
Regardless of the size of your organisation, it is likely
that you are facing daunting challenges regarding
data storage. You not only require immediate access
to the exploding volumes of data, but government
regulations and corporate governance are dictating
what must be kept, for how long and when you need
to gain access to it. Adding that to today’s economic
situation, you need to cut your near term capital and
operating costs without sacrificing quality. Therefore,
it is critical that you invest in a cost-effective, long-term
solution that can support your business now and well
into the future, and that all of the different components
and options are compatible with one another.
HP StorageWorks’ family of disk arrays reduces the
complexity of your storage environment and helps
to lower costs because they are easy to install, easy
to manage and easy to support. All of your storage
needs are addressed – whether it is an entry-level
modular array, an enterprise-class disk array or
intelligent management software. Our simplified
array and user interface designs mean that you will
spend less time installing, configuring and managing
your storage management tasks.
The HP StorageWorks disk array family includes:
•All-in-One (AiO) Storage Systems: Providing
simple, affordable networked storage; specifically,
network-attached storage (NAS) and Internet
small computer system interface (iSCSI), with
integrated data protection features and simplified
management
•Modular Smart Arrays (MSAs): Enabling
low-cost, scalable, high-performance storage
consolidation through SANs to meet entry-level
to midrange requirements
•Enterprise Virtual Arrays (EVAs): An ideal
storage solution for midrange to enterprise-class
environments that require high performance,
high capacity and high availability
•XP Disk Arrays: The HP StorageWorks XP24000/
XP20000 Disk Arrays are large enterprise-class
storage systems designed for organisations that
simply cannot afford any downtime or tolerate any
data loss
We also offer a range of complementary options
to help you tackle from the most basic to the
most complex storage challenges. These include
everything from a single tape drive to an automated
tape library as well as enterprise-wide SANs with
arrays flexible enough to manage gigabytes to
petabytes of storage.
Our server family consists of the HP Integrity and
HP ProLiant server families as well as HP BladeSystem.
When you combine HP StorageWorks solutions with
HP servers, the advantages multiply still further –
hardware and software integrates seamlessly, systems
are easy to manage, change is simplified and you are
prepared for future challenges. You can learn more
about our server family on page 11.
3
Why should you choose HP storage with
your HP server? There are many reasons why
HP StorageWorks is your best storage option with
your HP server. Here are just a few:
•Do you need a single interface to monitor,
automate and control your complex IT environment?
Is pooling and sharing of resources important
for increasing your IT utilisation? Do you need to
reduce business risk from unplanned downtime?
Our software allows you to manage, virtualise
and protect IT resources to simplify and optimise
your infrastructure. For example, HP Systems
Insight Manager can lower costs and simplify with
common storage and server management.
•How efficiently do your storage and servers
work together?
We spend hundreds of hours rigorously testing our
storage and servers together so you can deploy
our solutions with confidence.
•How important is it that your service partner
provides a single point of ownership and
accountability? Do they meet your service needs
throughout your business? Have you reached the
mission-critical reliability you require to meet your
business needs?
From training and basic product support to
selective outsourcing, our services help you realise
the full potential of your technology to meet your
business requirements.
•Do you have everything you need to meet your
infrastructure needs?
Our server and storage options – including
memory, disk drives, processors, racks, operating
system software, array-based software, power and
cooling – help optimise your solution by enhancing
system performance and functionality.
Storage matters more than ever and the demands
on your storage and server infrastructure will only
•Do you need to save time when deploying storage continue to grow. Over the next several pages,
you’ll see how HP StorageWorks solutions have
and servers?
been designed to answer your unique needs and
Accelerate deployment with solutions that are
requirements – and promote greater business
ready to run. With Factory Express you can choose
outcomes – now and into the future.
how your solution is built, tested, integrated,
shipped and deployed, which means you know
your solutions will work from Day One.
4
HP StorageWorks All-in-One Storage Systems
Unified solutions combining shared iSCSI storage and customised NAS file serving with
integrated data protection, designed to be deployed and managed by IT generalists with
no storage expertise.
Entry-level
New
HP StorageWorks 400t All-in-One
Storage System (AiO400t)
HP StorageWorks 400r All-in-One
Storage System (AiO400r)
HP StorageWorks 1200r All-in-One
Storage System (AiO1200r)
HP StorageWorks All-in-One
SB600c Storage Blade (AiO SB600c)
Processor type and description
Dual-Core Intel® Pentium® E2160
1.8 GHz with 1x1 MB L2 cache
Quad-Core Intel® Xeon® processor
E5405 (2.00 GHz, 80W, 1333
MHz FSB) (One processor
standard; up to 2 supported)
Quad-Core AMD OpteronTM
Model 2354 2.2 GHz
One Quad-Core Intel® Xeon®
E5410 (2.33 GHz, 1333 FSB, 80w)
Memory standard/max
2 GB/4 GB
2 GB/4 GB
2 GB or 4 GB/4 GB
2 GB/4 GB
Storage included
4 non-Hot-Plug drives:
4 Hot-Plug drives:
Up to 12 Hot Plug drives:
1 TB SATA (250 GB)
584 GB SAS (146 GB)
1 TB SATA (250 GB)
2 TB SATA (500 GB)
1.2 TB SAS (300 GB)
3 TB SATA (12 X 250 GB)
6 TB SATA (8 X 750 GB)
9 TB SATA (12 X 750 GB)
12 TB SATA (12 X 1 TB)
2.4 TB SAS (8 X 300 GB)
3.6 TB SAS (12 X 300 GB)
5.4 TB SAS (12 X 450 GB)
292 GB 2x146 GB 10K SFF SAS
have the OS pre-installed on
the server
Choose up to 6 SFF drives:
146 GB 10K SAS SFF
250 GB 5.4K SATA SFF
Storage controller
Smart Array E200/128 MB Controller with BBWC
Smart Array P800/512 MB
Controller (RAID 0/1/5/6) with
BBWC and 2 external SAS
expansion ports
Smart Array E200i
Network controller
Embedded NC105i PCIe Gigabit
Ethernet Server Adapter plus
additional NC360T dual-port
Gigabit Ethernet Server Adapter
Embedded NC326i PCIe Dual
Port Gigabit Server Adapter
Integrated single port
NC373i Multifunction Gigabit
Server Adapter
Integrated application data
storage (iSCSI SAN)
iSCSI support for Windows 2000, Windows Server 2003, Windows Server 2008 (including Hyper-V), VMware ESX Server 3/3.5, Novell
SUSE Linux Enterprise Server 10, Red Hat Enterprise Linux 5 and Qlogic 40xx series iSCSI hardware HBAs
Integrated file serving (NAS)
Heterogeneous file serving with support for SMB/CIFS, NFS, AppleTalk, Novell, HTTP, FTP
Integrated data protection
File and array snapshots (64/volume for files and 512/volume for iSCSI). Full copy of HP Data Protector Express software for backup and
recovery to disk or tape. Supports replication through HP StorageWorks Storage Mirroring
Operating system
Microsoft Windows Storage Server 2003 R2 (Standard Edition)
Hardware warranty
1-year parts exchange, 1-year labour, 1-year on-site next business day response
3-year parts, 3-year labour and
3-year on-site limited global warranty
QuickSpec URLs
http://h18000.www1.hp.com/
products/quickspecs/12913_
div/12913_div.html
http://h18000.www1.hp.com/
products/quickspecs/12913_
div/12913_div.html
http://h18000.www1.hp.com/
products/quickspecs/12866_
div/12866_div.pdf
http://h18000.www1.hp.com/
products/quickspecs/12789_
div/12789_div.pdf
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Hardware Installation
HP Proactive Select Service
3 years Support Plus 24
Installation and Startup Service
for HP BladeSystem c-Class
Infrastructure (OS + ICE)
HP Proactive Select Service
Embedded NC320i PCIe Dual
Port Gigabit Server Adapter
HP related services
Recommended services
Software
HP StorageWorks Storage Mirroring to replicate iSCSI array and file data to another system
HP StorageWorks Data Protector Express Options to protect servers connected to the AiO
Tape
SAS Ultrium tape drives
SCSI Ultrium tape drives
USB, SCSI and SAS DAT
tape drives
1/8 G2 Autoloader with
Ultrium 448/920 Tape Drive(s)
For more information, visit: www.hp.com/go/AiOStorage
1/8 G2 Autoloader with
Ultrium 920/1760 Tape Drive(s)
MSL2024 tape library with 920
SAS or Ultrium 960 4Gb Fibre
MSL2024 Tape Library with Ultrium
920/960/1760 Tape Drive(s)
MSL4048 tape library with 920
SAS or Ultrium 960 4Gb Fibre
5
HP StorageWorks Modular Smart Arrays
The HP StorageWorks Modular Smart Array (MSA) family is ideal for
organisations looking for entry-level/midrange SANs and low-cost DAS solutions.
Entry-level
HP StorageWorks 20 Modular Smart Array (MSA20)
SATA drive enclosure; capacity for direct attach
HP StorageWorks 50 Modular Smart Array (MSA50)
SAS storage enclosure supporting SAS and SATA
Maximum storage
Up to 12 TB with SATA drives
Up to 3 TB with SAS drives
Up to 2.5 TB with SATA drives
Host interface
Ultra320 SCSI
SAS
Maximum number of drives
Up to 12 SATA Large Form Factor (LFF) drives
Up to 10 SAS and/or SATA Small Form Factor (SFF) drives
Hard drives supported
1 TB 3G 7.2K 3.5-inch SATA
750 GB 3G 7.2K 3.5-inch SATA
500 GB 3G 7.2K 3.5-inch SATA
250 GB 3G 7.2K 3.5-inch SATA
Note: 3G drives only function at 1.5G
300 GB 3G 10K 2.5-inch Dual Port SAS
146 GB 3G 10K 2.5-inch Dual Port SAS
36 GB 3G 15K 2.5-inch Dual Port SAS
72 GB 3G 15K 2.5-inch Single Port SAS
36 GB 3G 15K 2.5-inch Single Port SAS
146 GB 3G 10K 2.5-inch Single Port SAS
72 GB 3G 10K 2.5-inch Single Port SAS
250 GB 3G 5.4K 2.5-inch SATA
120 GB 3G 5.4K 2.5-inch SATA
60 GB 1.5G 5.4K 2.5-inch SATA
Operating systems supported
Microsoft ® Windows® Server 2003; Microsoft Windows Server 2000
Microsoft Windows Storage Server 2003
Novell NetWare 6.5
Red Hat Enterprise Linux 2.1
Red Hat Enterprise Linux
SUSE Linux Enterprise 9 (SLES9)
SCO OpenServer 6.0.0
SCO UnixWare 7.1.3; SCO UnixWare 7.1.4; VMware
Microsoft Windows Server 2000; Microsoft Windows Server 2003
Microsoft Windows Storage Server 2003
Microsoft Windows 2008
Novell Open Enterprise Server; Novell NetWare 6.5 SPS
SCO OpenServer 5.0.7, 6
SCO UnixWare 7.1.3, 7.1.4
Red Hat Enterprise Linux
Solaris 10; SUSE Linux Enterprise Server 9, 10; VMware ESX 3.5
Rack height
2U
1U
Warranty
3 years parts only
3 years parts only
3 years Support Plus 24
HP StorageWorks MSA Family Disk Array Installation and Startup Service
HP Proactive Select Service
3 years Support Plus 24
HP StorageWorks MSA Family Disk Array Installation and Startup Service
HP Proactive Select Service
HP Systems Insight Manager (SIM)
HP Array Configuration Utility (ACU)
HP Systems Insight Manager (SIM)
HP Array Configuration Utility (ACU)
HP related services
Recommended services
Software
For additional information on related software for these products, see page 13.
For more information, visit: www.hp.com/go/msa
6
HP StorageWorks Modular Smart Arrays (continued)
The HP StorageWorks Modular Smart Array (MSA) family is ideal for
organisations looking for entry-level/midrange SANs and low-cost DAS solutions.
Entry-level
HP StorageWorks 60 Modular Smart Array (MSA60)
SAS/SATA drive enclosure for direct attach
HP StorageWorks 70 Modular Smart Array (MSA70)
SAS/SATA drive enclosure for direct attach
Maximum storage
Up to 5.4 TB with SAS drives
Up to 12 TB with SATA drives
Up to 12 TB with SAS Dual Port Midline (MDL) drives
Up to 7.5 TB with SAS drives
Up to 6.2 TB with SATA drives
Host interface
SAS
SAS
Maximum number of drives
Up to 12 SATA and/or SAS LFF drives
Up to 25 SAS or SATA SFF drives
Hard drives supported
450 GB 3G 15K 3.5-inch Dual Port SAS
300 GB 3G 15K 3.5-inch Dual Port SAS
146 GB 3G 15K 3.5-inch Dual Port SAS
72 GB 3G 15K 3.5-inch Dual Port SAS
300 GB 3G 15K 3.5-inch Single Port SAS
146 GB 3G 15K 3.5-inch Single Port SAS
72 GB 3G 15K 3.5-inch Single Port SAS
1 TB 3G 15K 3.5-inch Dual Port MDL SAS
750 GB 3G 15K 3.5-inch Dual Port MDL SAS
1 TB 3G 7.2K 3.5-inch SATA
750 GB 3G 7.2K 3.5-inch SATA
500 GB 3G 7.2K 3.5-inch SATA
250 GB 3G 7.2K 3.5-inch SATA
300 GB 3G 10K 2.5-inch Dual Port SAS
146 GB 3G 10K 2.5-inch Dual Port SAS
36 GB 3G 15K 2.5-inch Dual Port SAS
146 GB 3G 10K 2.5-inch Single Port SAS
72 GB 3G 15K 2.5-inch Single Port SAS
72 GB 3G 10K 2.5-inch Single Port SAS
36 GB 3G 15K 2.5-inch Single Port SAS
250 GB 1.5G 5.4K 2.5-inch SATA
120 GB 1.5G 5.4K 2.5-inch SATA
60 GB 1.5G 5.4K 2.5-inch SATA
Operating systems supported
Microsoft Windows 2003; Microsoft Windows 2008
HP-UX 11i v2, 11i v3; HP OpenVMS 8.31H
Novell Open Enterprise Server; Novell NetWare 6.5 SPS
SCO OpenServer 5.0.7, 6
SCO UnixWare 7.1.3, 7.1.4
Red Hat Enterprise Linux 3, 4, 5
SUSE Linux Enterprise Server 9, 10; Solaris 10; VMware ESX 3.5
Microsoft Windows 2003; Microsoft Windows 2008
HP-UX 11i v2, 11i v3; HP OpenVMS 8.31H
Novell Open Enterprise Server; Novell NetWare 6.5 SPS
SCO OpenServer 5.0.7, 6
SCO UnixWare 7.1.3, 7.1.4
Red Hat Enterprise Linux 3, 4, 5
SUSE Linux Enterprise Server 9, 10; Solaris 10; VMware ESX 3.5
Rack height
2U
2U
Warranty
3 years parts only
3 years parts only
3 years Support Plus 24
HP StorageWorks MSA Family Disk Array Installation and Startup Service
HP Proactive Select Service
3 years Support Plus 24
HP StorageWorks MSA Family Disk Array Installation and Startup Service
HP Proactive Select Service
HP Systems Insight Manager (SIM)
HP Array Configuration Utility (ACU)
HP Systems Insight Manager (SIM)
HP Array Configuration Utility (ACU)
HP related services
Recommended services
Software
For additional information on related software for these products, see page 12 and 13.
For more information, visit: www.hp.com/go/msa
7
HP StorageWorks Modular Smart Arrays (continued)
The HP StorageWorks Modular Smart Array (MSA) family is ideal for
organisations looking for entry-level departmental or remote SAN solutions.
Entry-level
HP StorageWorks 2000fc G2
Modular Smart Array (MSA2000fc G2)
4 Gb Fibre Channel connected, 2U storage
area network (SAN) solution designed for
small to medium-size deployments or remote
locations needing high-performance
HP StorageWorks 2000i
Modular Smart Array (MSA2000i)
iSCSI connected, 2U storage area
network (SAN) solution designed for
small to medium-size deployments or
remote locations
HP StorageWorks 2000sa
Modular Smart Array (MSA2000sa)
SAS connected, modular, reliable,
affordable and easy-to-manage shared
storage array solution
Maximum capacity
29.7 TB SAS; 60 TB SATA
21.6 TB SAS; 48 TB SATA
21.6 TB SAS; 48 TB SATA
Host interface
4 Gb Fibre Channel
1 Gb Ethernet iSCSI
3 Gb Serial Attached SCSI (SAS)
Number of hosts supported
64
16
4 hosts with SAS direct connect
32 hosts (BladeSystem servers) using 3 GB
SAS BL switch
Number of drives
(maximum including expansion)
60 (3.5-inch LFF drives)
99 (2.5-inch SFF drives)
48 (3.5-inch LFF drives)
48 (3.5-inch LFF drives)
Storage Expansion option/s
MSA2000 3.5-inch disk enclosure
MSA70 2.5-inch disk enclosure
MSA2000 3.5-inch disk enclosure
MSA2000 3.5-inch disk enclosure
Hard drives supported
Supported SAS and SATA 3.5-inch LFF
hard disk drives
MSA2 146 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 300 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 450 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 500 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 750 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 1 TB 3G 7.2K 3.5-inch Dual-port SATA
Supported SAS and SATA 2.5-inch SFF
hard disk drives
36 GB 3G 15K 2.5-inch Dual-port SAS
72 GB 3G 10K 2.5-inch Dual-port SAS
72 GB 3G 15K 2.5-inch Dual-port SAS
146 GB 3G 10K 2.5-inch Dual-port SAS
300 GB 3G 10K 2.5-inch Dual-port SAS
120 GB 3G 5.4K 2.5-inch SATA
MSA2 146 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 300 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 450 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 500 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 750 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 1 TB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 146 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 300 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 450 GB 3G 15K 3.5-inch Dual-port SAS
MSA2 500 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 750 GB 3G 7.2K 3.5-inch Dual-port SATA
MSA2 1 TB 3G 7.2K 3.5-inch Dual-port SATA
Operating systems supported
Microsoft Windows 2008 IA32
Microsoft Windows 2008 x64
Microsoft Windows 2003 R2
Microsoft Windows 2003 x64
Red Hat Enterprise Linux 4, 5
SUSE Linux Enterprise Server 9, 10
HP-UX 11i v3, HP-UX 11i v2; OpenVMS 8.3,
OpenVMS 8.3-1H1; VMware ESX 3.0.1, 3.0.2, 3.5
Integrated Citrix XenServer HP Enterprise
Microsoft Windows 2003 R2
Microsoft Windows 2003 x64
Red Hat Enterprise Linux 4, 5
SUSE Linux Enterprise Server 9, 10
VMware ESX 3.0.1, 3.0.2, 3.5
Microsoft Windows 2008 IA32*
Microsoft Windows 2008 x64*
Integrated Citrix XenServer HP Enterprise
Microsoft Windows 2008 IA32
Microsoft Windows 2008 x64
Microsoft Windows 2003 R2
Microsoft Windows 2003 x64
Red Hat Enterprise Linux 5
SUSE Linux Enterprise Server 10
VMware ESX 3.5
Rack height
2U
2U
2U
Warranty
3 years parts
3 years parts
3 years parts
QuickSpec URL
http://h18000.www1.hp.com/products/
quickspecs/13187_div/13187_div.pdf
http://h18000.www1.hp.com/products/
quickspecs/12992_div/12992_div.pdf
http://h18000.www1.hp.com/products/
quickspecs/13045_div/13045_div.pdf
HP related services
Recommended services
3 years Support Plus 24
HP StorageWorks MSA Family Disk Array Installation and Startup Service
HP Proactive Select Service
Software
HP StorageWorks MSA2000 Snapshot and Volume Copy Software
HP StorageWorks Storage Mirroring
*Check http://www.hp.com/storage/spock for required supporting firmware version.
For additional information on related software for these products, see page 12 and 13.
For more information, visit: www.hp.com/go/msa
8
HP StorageWorks Enterprise Virtual Arrays
HP StorageWorks Enterprise Virtual Arrays (EVAs) provide
outstanding TCO to support business-critical processes.
Midrange
HP StorageWorks 4400 Enterprise Virtual Array
HP StorageWorks 6400/8400 Enterprise Virtual Array
Number of drives
96
216/324
Note: EVA6400 and EVA8400 support up to 216 and 324 drives
respectively.
Storage capacity
(Including expansion)
96 TB maximum
216 TB EVA6400
324 TB EVA8400
Drives per enclosure
12 maximum
12 maximum
Servers supported
HP servers (HP-UX, ProLiant, AlphaServers); x86 servers; Dell servers;
Sun servers; IBM servers; Alpha XsApple servers (PowerPC and Intel);
Fujitsu Siemens and Primergy servers (Bx6x0, Rx and Tx)
HP servers (HP-UX, ProLiant, AlphaServers); x86 servers; Dell servers;
Sun servers; IBM servers; Alpha XsApple servers (PowerPC and Intel);
Fujitsu Siemens and Primergy servers (Bx6x0, Rx and Tx)
Disk Drive Types (Capacity,
Port type, Speed, Form factor,
Technology)
72 GB Solid State Disk
146 GB 15K Fibre Channel
300 GB 15K Fibre Channel
450 GB 15K Fibre Channel
400 GB 10K Fibre Channel
1 TB FATA
72 GB Solid State Disk
146 GB 15K Fibre Channel
300 GB 15K Fibre Channel
450 GB 15K Fibre Channel
400 GB 10K Fibre Channel
1 TB FATA
Note: Supported within the same enclosure.
Cache
4 GB
8 GB for EVA6400, and 14 GB or 22 GB for EVA8400
Fault-tolerant features
Dual Redundant Controllers
Power Supplies
Fans
Power Distribution Units
Embedded switches (optional)
Dual Redundant Controllers
Power Supplies
Fans
Power Distribution Units
Hot Plug support
Hot pluggable power supplies, fans, cache batteries, I/O modules, environmental monitoring units, disks
Type and number of controllers
Number of Controllers: 2
Controller Name: HSV300
Number of controllers: 2
Controller name: HSV400 or HSV450
Type and number of enclosures
Up to 8 M6412A enclosures
EVA6400 supports up to 18 M6412A enclosures
EVA8400 supports up to 27 M6412A enclosures
Supported operating systems
HP-UX; HP OpenVMS; Linux; Sun Solaris; Windows Server 2003;
Windows Server 2008; IBM AIX; Apple Mac OS X; XenServer;
VMware; Novell NetWare
HP-UX; HP OpenVMS; Windows 2003; Windows Server 2008;
Sun Solaris; Linux – Red Hat, SUSE/SLES (including OES) and Oracle
Enterprise Linux; IBM AIX; VMware; Apple Mac OS X; Xen – Citrix
Xen, RHEL Virtualisation and Oracle Virtual Machine
Warranty (parts-labour-on site)
2/2/2
3/3/3
Warranty (abbreviated description)
2 year parts, 2 year labour, 2 year on-site 9x5 hardware support,
with next business day (NBD) support
3-year, 9x5 next business day
QuickSpec URL
http://h18000.www1.hp.com/products/quickspecs/12893_
div/12893_div.pdf
http://h18000.www1.hp.com/products/quickspecs/13206_
div/13206_div.pdf
HP Support Plus 24 Service
HP StorageWorks EVA 4400 Disk Array Installation and Startup Service
HP Proactive Select Service
HP Proactive 24 (P24)
HP SAN Solution Service
HP Data Migration Service
HP StorageWorks Business Copy EVA
HP StorageWorks Continuous Access EVA
HP StorageWorks SmartStart EVA
HP StorageWorks Business Copy EVA
HP StorageWorks Continuous Access EVA
HP related services
Recommended services
Software
For additional information on related software for these products, see page 12 and 13.
Or visit www.hp.com/storage/evasoftware
For more information, visit: www.hp.com/go/eva
9
HP StorageWorks XP Disk Arrays
The HP StorageWorks XP Disk Array family provides outstanding reliability, availability,
performance and capacity to address your mission-critical applications.
High-end
HP StorageWorks XP24000 Disk Array
HP StorageWorks XP20000 Disk Array
Number of drives
1,152
240
Minimum frames (Cabinets)
1
1
Maximum frames (Cabinets)
5
2
Capacity (Raw)
1.13 PB
236 TB
Capacity (Useable)
851 TB
177 TB
External storage capacity
247 PB
96 PB
Maximum shared memory
24 GB
14 GB
Interface
(224) 4 Gb Fibre Channel
(112) 1 Gb ESCON
(112) 4 Gb FICON
(48) 4 Gb Fibre Channel
(24) 1 Gb ESCON
(24) 4 Gb FICON
Disk Drive types (Capacity,
Port Type, Speed, Form Factor,
Technology)
146 GB 15K Fibre Channel
300 GB 15K Fibre Channel
400 GB 10K Fibre Channel
450 GB 15K Fibre Channel
1 TB 7.2K SATA
73 GB Solid State Disk
146 GB Solid State Disk
Note: All drives are dual-ported, 4 Gb/s Fibre Channel
Arbitrated Loop (FC-AL)
146 GB 15K Fibre Channel
300 GB 15K Fibre Channel
400 GB 10K Fibre Channel
450 GB 15K Fibre Channel
1 TB 7.2K SATA
73 GB Solid State Disk
146 GB Solid State Disk
Note: All drives are dual-ported, 4 Gb/s Fibre Channel
Arbitrated Loop (FC-AL)
Cache
512 GB
128 GB
Supported operating systems
HP-UX; HP Tru64; HP OpenVMS; HP NonStop; Sun Solaris; IBM AIX;
Microsoft Windows; Linux; Mainframe; VMware
HP-UX; HP Tru64; HP OpenVMS; HP NonStop; Sun Solaris; IBM AIX;
Microsoft Windows; Linux; Mainframe; VMware
RAID support
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
RAID
1
1
5
5
5
5
6
(2D + 2D)
(4D + 4D)
(3D + 1P)
(7D + 1P)
(14D + 2P)
(28D + 4P)
(6D + 2P)
Warranty (parts-labour-on site)
2/2/2
QuickSpec URL
http://h18000.www1.hp.com/products/quickspecs/12711_div/12711_div.pdf
1
1
5
5
5
5
6
(2D + 2D)
(4D + 4D)
(3D + 1P)
(7D + 1P)
(14D + 2P)
(28D + 4P)
(6D + 2P)
2/2/2
HP related services
Recommended services
HP Critical Service (CS)
HP Data Replication Solution
HP Data Migration Service
HP Critical Service (CS)
HP Data Replication Solution
HP Data Migration Service
HP StorageWorks XP Thin Provisioning
HP StorageWorks XP External Storage
HP StorageWorks XP Thin Provisioning
HP StorageWorks XP External Storage
Software
For additional information on related software for these products, see page 12 and 13.
Or visit www.hp.com/storage/xpsoftware
For more information, visit: www.hp.com/go/storage/xparrays
10
HP StorageWorks arrays
Supported and recommended HP servers
x
x
x
x
x
x
x
x
x
x
x
ML115 G5
x
x
x
x
x
ML150 G5
x
x
x
x
x
DL160 G5
DL185 G5
DL360 G5
DL365 G5
DL380 G5
DL385 G5
ML350 G5
ML370 G5
DL580 G5
DL585 G5
DL785 G5
BL20p G4
•
•
•
•
•
•
•
•
•
•
•
•
•
•
x
•
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
•
•
•
•
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
•
x
BL25p G2
BL45p G2
x
BL260c G5
•
•
•
x
x
x
x
x
x
x
BL465c G5
x
BL480c G1
x
BL680c G5
x
BL685c G5
BL2x220c G5
c-Class
BL860c
Entry-class
rx2660
rx3600
rx6600
rx7640
rx8640
Superdome
•
•
•
•
•
•
•
•
•
•
x
•
•
•
BL460c G1
HP Integrity servers
High-end
x
x
x
DL180 G5
Midrange
x
x
x
DL165 G5
c-Class
x
x
x
•
•
•
•
•
•
•
•
•
•
•
•
•
•
x
XP24000
Disk Array
•
x
x
•
•
•
•
•
•
•
•
•
•
•
•
•
•
x
XP20000
Disk Array
•
EVA8400
MSA2000fc
x
EVA6400
MSA2000i
x
x
ML310 G5
p-Class
x
x
ML110 G5
High-end
•
•
•
•
x
DL320S
Midrange
•
•
•
•
High-end
EVA4400
DL320 G5P
•
•
•
•
Midrange
MSA2000sa
DL320 G5p
MSA70
DL120 G5
MSA60
HP ProLiant servers
Entry-class
MSA50
Entry-level
x
x
•
•
x
x
x
x
x
HP Integrity NonStop servers
Entry-class
NS1000
High-end
NS14000
NS16000
•
•
•
•
•
•
•
•
•
•
x
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
•
•
•
•
•
•
•
•
•
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
•
•
•
•
•
•
•
•
•
•
•
x
Key: • = recommended starting point, × = supported
Supported servers for MSA2000sa through 3Gb BL Switch:
HP ProLiant BL2x 220c G5; HP ProLiant BL460c; HP ProLiant BL465c; HP ProLiant BL465c G5; HP ProLiant BL480c;
HP ProLiant BL495c G5; HP ProLiant BL680c G5; HP ProLiant BL685c; HP ProLiant BL685c G5
11
HP related services
To gain the fullest value from your array investment, you can benefit from intelligent
software and expert services throughout the IT life-cycle.
HP software
HP provides software that allows you to align IT with business needs, automate error-prone processes and fine-tune your infrastructure.
Storage resource management
Storage Essentials Enterprise Edition
HP Storage Essentials suite delivers integrated heterogeneous functionality for network (DAS, SAN, NAS) management, storage resource
management, provisioning, backup reporting and application infrastructure monitoring. The suite consists of HP Storage Essentials
Enterprise Edition and features a range of value-added plug-ins.
Storage Essentials Standard Edition
Storage Resource Management
(SRM) Software
HP Storage Essentials Standard Edition helps midsize business with limited IT staff see the big picture, reduce complexity and gain control
of their SAN infrastructure inventory for small to medium HP storage-based SANs – consisting of HP EVA, HP MSA and HP NAS; HP EML
E-series Tape; HBAs and switches – and affordably enjoy the benefits of storage resource management software.
Systems Insight Manager
HP Systems Insight Manager (SIM), our unified server-storage management tool, helps increase IT staff efficiency and hardware platform
availability for small and large server deployments alike. It is designed for end-user setup, and its modular architecture enables systems
administrators to plug in additional functionality as needed.
Command View EVA
HP StorageWorks Command View EVA is a comprehensive software suite designed to simplify array provisioning and management
of the high-performance HP StorageWorks Enterprise Virtual Array (EVA) family of storage array products. For managing EVA with
heterogeneous networked SAN devices, including servers and infrastructure, you can use HP Systems Insight Manager to do the job.
EVA Dynamic Capacity
Management Software
HP StorageWorks EVA Dynamic Capacity Management Software is a comprehensive software solution that automates storage
provisioning and improves capacity utilisation on the HP StorageWorks Enterprise Virtual Array (EVA) family. Designed for the enterprise
market, EVA Dynamic Capacity Management Software uses advanced automation to automatically ‘right-size’ the file system and storage
volumes to provide the highest levels of capacity utilisation while reducing ongoing storage administration needs.
XP Command View Advanced Edition
HP StorageWorks XP Command View Advanced Edition Software provides centralised, Web-based management for multiple XP Disk Arrays.
It reduces the total cost of XP array ownership by increasing the efficiency of storage administrators and saves time in the management of
external storage.
XP Thin Provisioning
HP StorageWorks XP Thin Provisioning Software reduces the cost, accelerates return on investment and reduces environmental impact of
your HP StorageWorks XP24000 and XP20000 Disk Arrays. Allocate anticipated future storage capacity needs from a pool of virtual
disk storage and reduce the physical disk capacity initially required. As utilisation of disk space increases over time, purchase more disk
capacity as it is needed and install it without affecting your applications. Accelerate return on investment by using the virtualised storage
pool to quickly deploy more applications and servers per storage system. And because you are more efficiently using your storage
resources, you enjoy the green effect of reduced floor space, power and cooling requirements and also a reduced carbon footprint.
XP Array Manager
HP StorageWorks XP Array Manager Software improves efficiency and data security by allowing you to manage volumes, allocate
disk array resources, control access to the data and protect the data on HP StorageWorks XP24000 and XP20000 Disk Arrays.
Configure and manage data volumes for most effective use of the XP Disk Array. Partition array resources to isolate applications and
reserve cache memory for the most frequently accessed data. Configure security to prevent unauthorised servers from accessing the data.
Create read-only volumes for archiving and data retention and then securely delete the data when it is no longer needed.
Remote replication software
Continuous Access EVA
HP StorageWorks Continuous Access EVA Software is an array-based application that utilises a powerfully simple graphical user interface
(GUI) to create, manage and configure remote replication on the whole EVA product family.
XP Continuous Access
HP StorageWorks XP Continuous Access Software products are high-availability remote replication and disaster recovery solutions that
deliver host-independent, real-time remote data replication between HP StorageWorks XP Disk Arrays. With seamless integration into a
full spectrum of remote replication-based solutions, HP XP Continuous Access Software can be deployed in solutions ranging from data
migration to high-availability server clustering.
Storage Mirroring
HP StorageWorks Storage Mirroring provides host-based, real-time, nearly continuous replication for small and midsize business
customers seeking a low-cost alternative to expensive fabric or array-based solutions. Patented replication and failover technology
continuously captures byte-level changes as they happen and replicates those changes to one or more target servers at any location
without geographic limitations.
Local replication software
Business Copy EVA
HP StorageWorks Business Copy EVA Software is an array-based application that utilises a powerfully simple HP StorageWorks
Replication Solutions Manager user interface to create, manage and configure local replication on the full EVA product family to meet
business continuity and regulatory requirements.
XP Business Copy
HP StorageWorks XP Business Copy Software creates local copies of data for businesses that are concerned about business continuity
and that need to reduce the cost of backups, accelerate recovery from failures and simplify development and testing.
Data protection and recovery software
Data Protector
HP Data Protector Software automates high-performance backup and recovery, from disk or tape, over unlimited distances, to enable
24x7 business continuity and increase IT resource utilisation. Data Protector simplifies the use of complex backup and recovery
procedures with fast installation, automated routine tasks and easy-to-use features.
Data Protector Express
HP Data Protector Express Software provides a simple and reliable backup and recovery solution for file servers, application servers and
desktops that is suitable for organisations without dedicated IT staff.
For more information, visit: www.hp.com/go/storageworks/software
12
HP related services (continued)
To gain the fullest value from your array investment, you can benefit from intelligent
software and expert services throughout the IT life-cycle.
HP software (continued)
HP provides software that allows you to align IT with business needs, automate error-prone processes and fine-tune your infrastructure.
Business continuity software
Fast Recovery Solutions
HP StorageWorks Fast Recovery Solutions (FRS) enables the instant recovery of Microsoft Exchange 2003 databases. Ideal for
environments that require the highest level of availability, FRS is designed to allow application administrators to utilise the automated
disaster recovery technologies built into HP StorageWorks Disk Array systems, without extensive storage training.
Cluster Extension EVA and XP
HP StorageWorks Cluster Extension EVA and XP Software continues your critical applications within minutes or seconds after an event.
It offers disaster tolerance against application downtime from fault, failure or site disaster by extending clusters between data centres. It
works seamlessly with your open-system clustering software and XP storage systems to automate fail-over and fail-back between sites.
Storage device management software
XP External Storage
HP StorageWorks XP External Storage Software decreases the stress and reduces the cost of owning heterogeneous data storage by
simplifying and centralising common SAN management tasks through storage virtualisation. In addition, it simplifies movement of data
between dissimilar arrays. HP XP External Storage Software provides these benefits by giving you the ability to access, monitor and
manage data residing on a variety of different disk arrays as if all of the data were residing on an HP StorageWorks XP Disk Array.
XP Disk/Cache Partition
This software can reduce storage costs by dividing a large HP StorageWorks XP Disk Array into smaller segments suitable for
departmental usage, while retaining superb performance and high availability.
HP technology services
Reactive support services
Support Plus Service
Improves system performance and uptime
Support Plus 24 Service
Increases availability of your IT infrastructure with comprehensive 24x7 hardware and software services
Proactive support services
Proactive 24 Service
Improves uptime with responsive hardware and software services available 24x7
Proactive Select Service
Improves IT performance and manageability through the use of cost-effective flexible proactive services
Mission critical services
Critical Service
Reduces impact of unplanned downtime and improves IT operational efficiency
Mission Critical Partnership
Helping you successfully deliver your services at an affordable cost to the business
Deployment services
HP StorageWorks Disk Array
Installation and Startup Service
Proper installation of your storage hardware is crucial to help realise improved return on investment (ROI)
HP StorageWorks MSA Family Disk
Array Installation and Startup Service
MSA Disk Array start-up, this service provides hardware and software installation
HP StorageWorks EVA 4400 Disk
Array Installation and Startup Service
EVA 4400 Disk Array start-up, this service provides hardware and software installation
HP StorageWorks EVA/XP Disk Array
Installation and Startup Service
EVA/XP Disk Array start-up, this service provides hardware and software installation
Data Replication Solution Service
Enables an optimal environment, which keeps your mission-critical data safe, more secure and highly available
SAN Solution Service
End technology services make the most of your investment
Other services
Data Migration Service
Migrating your data ‘on line’ to align to your specific cost, availability and business needs while your business operation continues
Data Sanitisation Service
Protects your business from the risk of important information being retrieved from retired hard disk media by unauthorised parties
HP Assessment for SANs Service
Optimises availability levels and ongoing management of your storage and SAN environment
HP Performance Analysis for the
StorageWorks XP/EVA Disk Arrays
Increases performance, stability and availability by identifying potential bottlenecks
HP StorageWorks EVA Firmware
Update Service
A one-time, one-day deployment service designed to upgrade the firmware on one HP StorageWorks EVA disk array to the latest
specification of firmware for both controllers and disk drives
HP vDisk LUN Design and
Implementation Service
When redeploying an HP StorageWorks disk array, the HP Vdisk/LUN Design and Implementation Service assures proper configuration
of storage hardware to help maximise the effectiveness of your storage
For more information, visit: www.hp.com/hps/storage
13
HP Services: Scalable, flexible and
reliable – like your storage
Your technology infrastructure has become the
business infrastructure – where delivering successful
business outcomes is the key goal. No other company
in the industry matches HP range of service breadth
and depth, resources and commitment to optimise
storage support in a heterogeneous infrastructure.
The integrated end-to-end storage solutions of HP
are intentionally designed to help businesses address
today’s tough technology challenges associated with
the explosion of rich digital content, mobility and
security requirements as well as the need for efficient
storage of data and access to real-time information
when and where they need it.
To capitalise fully on your HP storage solution,
you need a service partner who thoroughly
understands your storage technology and systems
environment. With HP Services you gain the
advantage of established methodologies and one of
the industry’s broadest family of integrated storage
solutions for enhanced information management
and optimisation – services that scale to enhance
availability, performance, deployment and support.
For more information about HP services and
support, contact your HP sales representative or
HP-authorised Channel Partner, or visit
www.hp.com/hps/storage
Factory Express
HP Factory Express is designed to help you get a
better return from your IT investment by providing
customisation, integration and deployment services
along with your storage and server purchases. It
provides predictable, trusted and tested IT solutions
tailored to your business needs. We allow you to
customise hardware to your exact specifications in
the factory – helping to speed up deployment and
free up internal resources. For more information on
these services, please contact your HP representative
or visit www.hp.com/go/factoryexpress
Customer Technical Training
Consider education as an integral part of your
strategy to get the best return on investment for your
HP storage solution. HP offers a variety of training
classes on storage software, networking, archiving
and disk storage systems. Our classes are available
in the form that suits you best – from traditional
instructor-led classes at one of our 80 training centres
worldwide to on-site training customised to your needs
or on line classes. For more information on these
services, please contact your HP representative or visit
www.hp.com/learn/storage
HP Financial Services
HP Financial Services provides innovative financing
and financial asset management programmes to help
you cost-effectively acquire, manage and ultimately
retire your HP solutions. For more information on
these services, please contact your HP representative
or visit www.hp.com/go/hpfinancialservices
14
HP server family
You make HP storage products better
What kind of server best fits your needs? What
level of high availability and performance do you
require? How many users will be supported? What
operating system will you be using? Whether it’s a
departmental server, an enterprise data centre or
anything in between, HP is committed to meeting
your exact needs. This commitment has resulted in
more customers choosing HP servers than any other
vendor’s servers.*
Throughout the development of HP StorageWorks
arrays, end-user customers and channel partners
participate in usability reviews that influence
hardware and software design. Over the past few
years, such feedback has helped HP StorageWorks
reduce array design complexity. Users now
spend less time managing their storage due to the
simplification of storage management tasks and
easy-to-understand user interface designs. Array
installation, configuration and repairs also take less
time due to the use of more intuitive actions.
Our product family:
•HP ProLiant server family: ProLiant servers offer a
superior platform for your mainstream 32-bit and
emerging 64-bit x86 applications and are the
world’s top-selling x86 industry-standard servers
since 3Q 1996.*
•HP Integrity systems family: The most trusted brand
for mission-critical applications. A multi-OS ecosystem
running on HP-UX 11i, OpenVMS, Microsoft
Windows Server 2003, Linux and NonStop, Integrity
systems provide a unique combination of scalability,
virtualisation and availability, enabling you to
optimise your business outcomes while decreasing
costs and reducing risk.
•HP Integrity NonStop servers: Real-time, all-the-time
business solutions for the organisation.
For more information about our User Centered
Design program, visit www.hp.com/storage/ucd
For more information
To learn more about HP StorageWorks arrays, contact
your local HP representative or your authorised
HP reseller, or visit www.hp.com/go/arrays
To learn more about HP server families, contact
your local HP representative or your authorised
HP reseller, or visit:
•www.hp.com/go/proliant
•www.hp.com/go/integrity
•www.hp.com/go/nonstop
What can you do to simplify a growing, multi-server
environment? How do you integrate all the moving
parts and deliver business solutions on time and
under budget?
You can also visit our other related server family guides:
•HP BladeSystem: A simple, modular infrastructure
that is consolidated up-front to save you more time,
energy and money – regardless of what you put
inside. In one consolidated box, an HP BladeSystem
supports ProLiant and Integrity server blades,
StorageWorks storage services and a variety of
virtual desktop and workstation solutions. With the
essential IT elements built-in – compute, network,
storage, management and power and cooling –
the BladeSystem is a more efficient way to deliver
reliable, cost-effective services to your business.
For more information on the HP BladeSystem, visit
www.hp.com/go/bladesystem
•ProLiant: www.hp.com/go/proliant/familyguide
•Integrity: www.hp.com/go/integrityserverfamilyguide
•BladeSystem: www.hp.com/go/bladesystem/familyguide
To quickly find the HP storage products that fit your
specific needs, visit www.hp.com/go/product-selector
*Source: IDC Worldwide Quarterly Server Tracker, May 2008.
15
This is an HP Indigo print.
Technology for better business outcomes
To learn more, visit www.hp.com/go/storageworks
© Copyright 2008 – 2009 Hewlett-Packard Development Company, L.P. The information contained
herein is subject to change without notice. The only warranties for HP products and services are set forth
in the express warranty statements accompanying such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
AMD and Opteron are trademarks of Advanced Micro Devices, Inc. Microsoft and Windows are
U.S. registered trademarks of Microsoft Corporation. Intel, Pentium, and Xeon are trademarks of Intel
Corporation in the United States and other countries. UNIX is a registered trademark of The Open Group.
4AA0-7118EEW Rev. 6, February 2009
Download PDF

advertising
