HP | 4550HDN | User's Manual | HP 4550HDN User's Manual

learn
copyright © 2000
Hewlett-Packard Company
user guide
www.hp.com/support/lj4550
english
hp color LaserJet 4550
4550n • 4550dn • 4550hdn
6.5" x 9" BACK COVER
6.5" x 9" FRONT COVER
Quick access to printer information
World Wide Web links
•
Product support
•
Supplies
•
Product information
User guide links
•
How to use this online user guide
•
Where to look for more information . . .
•
Locating printer components
•
Locating consumables
•
HP Customer Care
•
Worldwide Sales and Service Offices
•
Contents
•
Index
HP Color LaserJet 4550,
4550N, 4550DN, 4550HDN Printer
User Guide _________________
Copyright and License
Warranty
Trademark Credits
© Copyright Hewlett-Packard
Company 2000
The information contained in
this document is subject to
change without notice.
Adobe®, Acrobat®, PostScript®,
and Adobe Photoshop® are
trademarks of Adobe Systems
Incorporated.
All Right Reserved. Except as
allowed by copyright laws or
herein, reproduction,
adaptation, or translation
without prior written permission
is prohibited.
A user of the Hewlett-Packard
printer associated with this user
guide is granted a license to: a)
print hard copies of this user
guide for PERSONAL,
INTERNAL or COMPANY use
subject to the restriction not to
sell, re-sell or otherwise
distribute the hard copies; and
b) place an electronic copy of
this user guide on a network
server provided access to the
electronic copy is limited to
PERSONAL, INTERNAL users
of the Hewlett-Packard printer
associated with this user guide.
Publication number
C7085-online
Edition 5,
4/2009
Hewlett-Packard Company
11311 Chinden Boulevard
Boise, Idaho 83714-1021 U.S.A.
Hewlett-Packard makes no
warranty of any kind with
respect to this information.
HEWLETT-PACKARD
SPECIFICALLY DISCLAIMS
THE IMPLIED WARRANTY OF
MERCHANTABILITY AND
FITNESS FOR A PARTICULAR
PURPOSE.
Hewlett-Packard shall not be
liable for any direct, indirect,
incidental, consequential, or
other damage alleged in
connection with the furnishing or
use of this information.
Arial® is a U.S. registered
trademark of the Monotype
Corporation.
CompuServe™ is a U.S.
trademark of CompuServe, Inc.
CorelDRAW™ is a trademark of
Corel Corporation or Corel
Corporation Limited.
Microsoft® is a U.S. registered
trademark of Microsoft
Corporation.
Netscape Navigator is a U.S.
trademark of Netscape
Communications Corporation.
PANTONE®* *Pantone, Inc.’s
check-standard trademark for
color.
TrueType™ is a U.S. trademark
of Apple Computer, Inc.
UNIX® is a registered trademark
of the Open Group.
Windows®, MS Windows®, and
Windows NT® are U.S.
registered trademarks of
Microsoft Corporation.
Contents
Quick access to printer information . . . . . . . . . . . . . . . . . . . . . . . . . .2
World Wide Web links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
User guide links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Contents
Where to look for more information . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting up the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
How to use this online user guide . . . . . . . . . . . . . . . . . . . . . . . . . .14
Features of Acrobat Reader 4.0 . . . . . . . . . . . . . . . . . . . . . . . .14
1 The HP Color LaserJet 4550 Series Printer
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Printer features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Factors affecting printer performance . . . . . . . . . . . . . . . . . . . .20
Locating printer components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Controlling print jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Managing memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Printer software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
HP Resource Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Printer drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Other components and utilities . . . . . . . . . . . . . . . . . . . . . . . . .29
Printer supplies and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .31
2 Using the printer control panel
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
When to use the printer control panel . . . . . . . . . . . . . . . . . . . . . . .34
Locating printer control panel features . . . . . . . . . . . . . . . . . . . . . . .35
Using printer control panel keys . . . . . . . . . . . . . . . . . . . . . . . .36
Using the printer online Help system . . . . . . . . . . . . . . . . . . . . .36
Interpreting control panel indicator lights . . . . . . . . . . . . . . . . . .37
Control panel menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Menu locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Information menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Paper handling menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Printing menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Configuration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
I/O menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
EN
Contents 5
Calibration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Resets menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Hard disk dependent menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Quick Copy Jobs menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Private/Stored Jobs menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
EIO menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Printer information pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Printer configuration page . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Supplies status page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Usage page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Event log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Using the printer control panel in shared environments . . . . . . . . . .57
Changing printer control panel configuration settings . . . . . . . . . . .58
Changing PowerSave settings. . . . . . . . . . . . . . . . . . . . . . . . . .59
Switching printer personalities . . . . . . . . . . . . . . . . . . . . . . . . . .60
Setting the I/O timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Disabling the high-speed parallel interface . . . . . . . . . . . . . . . .62
Setting advanced functions . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Resetting printer memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Resetting the printer to factory default settings . . . . . . . . . . . . .64
3 Common printing tasks
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Selecting print media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Supported media weights and sizes . . . . . . . . . . . . . . . . . . . . .67
Media to avoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Printing on special media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Transparencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Glossy paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Colored paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Heavy paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Preprinted forms and letterhead . . . . . . . . . . . . . . . . . . . . . . . .73
Recycled paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Controlling print jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Selecting output bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Selecting media by type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Configuring input trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Configuring Tray 1 as a cassette . . . . . . . . . . . . . . . . . . . . . . . .76
Configuring Trays 2 and 3 by media type . . . . . . . . . . . . . . . . .77
Tray priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Printing from Tray 1 (multipurpose tray) . . . . . . . . . . . . . . . . . . . . . .78
Loading media into Tray 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Loading envelopes into Tray 1. . . . . . . . . . . . . . . . . . . . . . . . . .80
6
Contents
EN
Printing from Tray 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Loading media into Tray 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Printing from Tray 3 (optional 500-sheet paper feeder) . . . . . . . . . .84
Loading media into Tray 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Using the optional duplex printing accessory for two-sided printing.89
Control panel settings for duplex printing . . . . . . . . . . . . . . . . .91
Options for binding duplex printing jobs. . . . . . . . . . . . . . . . . . .92
Special printing situations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Printing a different first page . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Printing on custom-size media. . . . . . . . . . . . . . . . . . . . . . . . . .93
Stopping a print request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Job retention features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Quick copying a job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Proofing and holding a job . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Printing a private job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Storing a print job. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Printing with the optional HP Fast InfraRed Receiver . . . . . . . . . .103
Setting up to print with Windows 9x/NT . . . . . . . . . . . . . . . . . .103
Printing a job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Interrupting and resuming printing . . . . . . . . . . . . . . . . . . . . . .104
4 Using color
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Matching colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
HP ColorSmart II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Color management options . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Four-color printing (CMYK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Matching PANTONE®* colors . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Automatic PANTONE®* calibration . . . . . . . . . . . . . . . . . . . . .111
5 Using fonts
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Using internal TrueType fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Understanding printer default fonts . . . . . . . . . . . . . . . . . . . . . . . .117
Font selection priority. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Selecting fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Selecting fonts from software applications . . . . . . . . . . . . . . .118
Selecting PCL fonts through the printer control panel . . . . . . .119
Printing a list of available printer fonts . . . . . . . . . . . . . . . . . . . . . .121
Interpreting the font lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Using fonts in PostScript Emulation . . . . . . . . . . . . . . . . . . . . . . . .123
Using fonts on a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Guidelines for printing with different fonts . . . . . . . . . . . . . . . .124
Adding support for accessory fonts to a printer driver . . . . . . . . . .125
Using special type effects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Hewlett-Packard custom font services . . . . . . . . . . . . . . . . . . . . . .126
EN
Contents 7
6 Printer Interfaces
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Parallel configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Enhanced I/O (EIO) configuration . . . . . . . . . . . . . . . . . . . . . . . . .129
HP JetDirect print servers . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Available enhanced I/O interfaces . . . . . . . . . . . . . . . . . . . . . .130
NetWare networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
Windows and Windows NT networks. . . . . . . . . . . . . . . . . . . .130
AppleTalk Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
UNIX/Linux networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Setting network security on the printer. . . . . . . . . . . . . . . . . . .132
Configuring the printer for the network at the printer
control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133
Configuring Novell NetWare frame type parameters . . . . . . . .133
Configuring TCP/IP parameters. . . . . . . . . . . . . . . . . . . . . . . .135
Disabling network protocols (optional) . . . . . . . . . . . . . . . . . . .138
7 Consumables and cleaning
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
Making room around the printer for replacing consumables . . . . .142
Consumable replacement guidelines. . . . . . . . . . . . . . . . . . . .143
Approximate replacement intervals for consumable items . . . . . . .144
Locating consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146
Environmental collection program . . . . . . . . . . . . . . . . . . . . . . . . .147
Cleaning the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Cleaning excess toner from the printer . . . . . . . . . . . . . . . . . .148
Cleaning the toner density sensor . . . . . . . . . . . . . . . . . . . . . .149
8 Printer control panel messages
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
Message types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Status messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Attention messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Critical error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
Printer control panel messages . . . . . . . . . . . . . . . . . . . . . . . . . . .153
Control panel messages for external devices . . . . . . . . . . . . .170
9 Solving problems with the printer
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
Basic troubleshooting checklist . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Paper jam locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
Paper jam recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176
Common causes of paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . .177
8
Contents
EN
Clearing paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Clearing jams in the middle front drawer area . . . . . . . . . . . . .178
Clearing jams in the Tray 2 area . . . . . . . . . . . . . . . . . . . . . . .180
Clearing jams in the optional Tray 3 area . . . . . . . . . . . . . . . .181
Clearing jams in the rear door areas . . . . . . . . . . . . . . . . . . . .182
Clearing jams in the front duplex drawer area . . . . . . . . . . . . .184
Media-handling problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185
Printer response problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189
Printer control panel problems . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Print quality troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194
Repetitive image defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . .194
Image defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196
Background scatter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197
Banding and horizontal lines . . . . . . . . . . . . . . . . . . . . . . . . . .197
Banding — horizontal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Banding — vertical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Black lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Blank pages or missing a color . . . . . . . . . . . . . . . . . . . . . . . .199
Character voids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .199
Distorted image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200
Dropouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200
Faded print, faded areas, or faded vertical streaks . . . . . . . . .201
Toner smear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .202
Ghosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
Gray streaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
Irregular, raised streaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
Light, dark, or faded print . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204
Non-adhering toner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .204
Marbled output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Random spots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Sharkskin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Sunburn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Imaging drum defects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .206
Overhead transparency defects . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Dull or dark transparencies . . . . . . . . . . . . . . . . . . . . . . . . . . .208
Rippled or wavy transparencies. . . . . . . . . . . . . . . . . . . . . . . .208
Incorrect image on transparencies . . . . . . . . . . . . . . . . . . . . .208
Repetitive defects on transparencies. . . . . . . . . . . . . . . . . . . .209
Streaking or smudges on transparencies . . . . . . . . . . . . . . . .209
Color printing problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .210
Incorrect printer output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212
Software application problems . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
EN
Contents 9
Appendix A DIMM Installation
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215
DIMM configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .216
Installing DIMMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .217
Verifying DIMM installation . . . . . . . . . . . . . . . . . . . . . . . . . . .220
Resource saving/permanent resources . . . . . . . . . . . . . . . . . .221
Installing EIO cards/mass storage . . . . . . . . . . . . . . . . . . . . . .222
Appendix B PCL commands
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
Interpreting PCL printer command syntax . . . . . . . . . . . . . . . . . . .225
Combining escape sequences in PCL Printer command
syntax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226
Entering escape characters . . . . . . . . . . . . . . . . . . . . . . . . . . .227
Selecting PCL fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .228
Common PCL commands . . . . . . . . . . . . . . . . . . . . . . . . . . . .229
Appendix C Specifications
Electrical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .235
Operating environment specifications . . . . . . . . . . . . . . . . . . . . . .236
Acoustic emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .236
Environmental product stewardship program . . . . . . . . . . . . . . . . .237
Regulatory statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240
FCC regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .240
Canadian DOC regulations . . . . . . . . . . . . . . . . . . . . . . . . . . .241
VCCI statement (Japan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241
Korean EMI statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .241
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . .242
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
Laser Statement for Finland. . . . . . . . . . . . . . . . . . . . . . . . . . .244
Material Safety Data Sheet (MSDS) . . . . . . . . . . . . . . . . . . . .246
Appendix D Warranty and support information
Hewlett-Packard Warranty Statement . . . . . . . . . . . . . . . . . . . . . .247
HP Maintenance Agreements . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
On-site service agreements . . . . . . . . . . . . . . . . . . . . . . . . . . .249
Support information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250
HP Customer Care options worldwide . . . . . . . . . . . . . . . . . . .252
Worldwide Sales and Service Offices . . . . . . . . . . . . . . . . . . . . . .254
10
Contents
EN
Appendix E Embedded Web server
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .259
Using the embedded Web server. . . . . . . . . . . . . . . . . . . . . . . . . .260
To access the embedded Web server . . . . . . . . . . . . . . . . . . .260
Embedded Web server page sets . . . . . . . . . . . . . . . . . . . . . .261
Index
EN
Contents
11
Where to look for more information . . .
Several references are available for use with this printer. For
additional copies of the guides below, contact your HP-authorized
dealer.
WWW
Additional information is available at http://www.hp.com/support/lj4550.
Setting up the printer
Getting Started Guide
Step-by-step instructions for
installing and setting up
the printer.
HP JetDirect Print Server
Administrator’s Guide*
Instructions to configure and
troubleshoot the HP JetDirect print
server.
*Accompanies printers that include an HP JetDirect print server (network
card).
Accessory and Consumable
Installation Guides
Step-by-step instructions, supplied with
the printer’s optional accessories and
consumables, for installing the printer’s
accessories and consumables.
12 Contents
EN
Using the printer
Online User Guide
Detailed information on using and
troubleshooting the printer. Available on
the CD-ROM that came with the printer.
Online Help
Information on printer options that are
available from within printer drivers. To
view a Help file, access the online Help
through the printer driver.
EN
Contents
13
How to use this online user guide
This user guide is provided online in an Adobe® Acrobat® portable
document format (PDF). This section will help familiarize you with
using PDF documents in Acrobat Reader version 4.0. For complete
instructions on how to view PDF documents, see the documentation
included with Acrobat Reader.
Features of Acrobat Reader 4.0
Finding topics in the online user guide
There are two primary ways to navigate to the information you need:
●
Click the topic you want to read about in the Bookmarks section
of the screen.
●
Click Contents or Index in the Bookmarks section of the screen,
and then click the topic you want to read about from the list of
items displayed on the page.
Finding words
Use the Find command to find part of a word, a complete word, or
multiple words in the document.
Click the Find button or choose Find from the Edit menu.
14
Contents
EN
Magnifying the page view
Acrobat Reader offers several magnification choices that control how
the page fits on-screen:
●
the zoom-in tool
●
the magnification button in the status bar
●
the toolbar buttons
Once you zoom in on a document, you can select the hand tool or use
the scroll bars to move the page.
To increase magnification: Select the zoom-in tool and click on the
document page to double the current magnification.
To decrease magnification: Select the zoom-in tool while holding
down Ctrl (Windows and UNIX) or Option (Macintosh), and click the
center of the area you want to reduce.
Click the magnification button to select how large or small to make
the page. Select from preset magnification levels and page views.
Actual Size scales the page to fit within the main window.
Fit in Window fills the window with the page’s content area only.
Fit Width scales the page to fit the width of the main window.
EN
Contents
15
Paging through a document
The following options are available for paging through a document.
To go to the next page: Click the Next Page button in the toolbar or
status bar, or press Page Up or Page Down on your keyboard.
To return to the previous page: Click the Previous Page button in
the toolbar, or press the Left Arrow or Up Arrow.
To go to the first page: Click the First Page button in the toolbar.
To go to the last page: Click the Last Page button in the toolbar.
To jump to a specific numbered page: Click the page number box
in the status bar at the bottom of the main window, type the page
number, and click OK.
Browsing with thumbnails
A thumbnail is a miniature view of each document page. Click a page
in the Thumbnails section of the window to jump quickly to that page.
Printing the document
To print selected pages: From the File menu, choose Print. Choose
Pages. In the From and To boxes type the range of pages you wish to
print. Then click OK.
To print the whole document: From the File menu, choose Print.
Choose All n pages (n represents the total number of pages in the
document), and then click OK.
WWW
16
Contents
Go to http://www.adobe.com/ for the latest versions and additional
languages of Adobe Acrobat Reader.
EN
1
The HP Color
LaserJet 4550 Series
Printer
Overview
This chapter describes the features and specifications of the
HP Color LaserJet 4550, 4550N, 4550DN, and 4550HDN
printers. The chapter includes the following sections:
●
Printer features
●
Locating printer components
●
Controlling print jobs
●
Managing memory
●
Printer software
●
Printer supplies and accessories
Information on using the printer to perform common tasks is
presented throughout this guide. Links to specific tasks are listed
below.
EN
●
Using the printer control panel
●
Loading media into the printer
●
Optimizing color quality
●
Using fonts
●
Printer Interfaces
●
Consumables and cleaning
●
Printer control panel messages
●
Clearing paper jams
Chapter 1
17
Printer features
This printer combines the quality and reliability of Hewlett-Packard
printing with the features listed below. For more information on printer
features, see the Hewlett-Packard website at http://www.hp.com.
Performance
Memory
Supported
printer
personalities
Fonts
Paper handling
(input)
Paper handling
(output)
18
●
16 pages per minute (ppm) in black and white
●
4 ppm in color
●
Transparencies and glossy paper, 8 ppm in black and white, 2 ppm in
color. For more information, see “Supported media weights and sizes.”
●
64 megabytes (MB) of random access memory (RAM)
(128 MB in the HP Color LaserJet 4550DN and 4550HDN printers)
●
Can be expanded to 192 MB
●
Optional 6 GB hard disk drive (included with the HP Color LaserJet
4550HDN printer)
●
Memory Enhancement Technology (MEt), which automatically
compresses data to use RAM more efficiently
●
HP PCL 6
●
PostScript 3 emulation
●
HP PCL 5c
●
Automatic language switching
●
80 internal fonts available for both PCL and PostScript emulation
●
80 printer matching screen fonts in TrueType™ format on CD-ROM
●
150-sheet multipurpose tray. Use for paper, transparencies, labels,
heavy media, and envelopes
●
250-sheet standard cassette
●
Optional 500-sheet paper feeder (included with the HP Color LaserJet
4550DN and 4550HDN printers)
●
Top output bin holds up to 250 sheets of standard paper
●
Rear output bin holds up to 100 sheets of standard paper
The HP Color LaserJet 4550 Series Printer
EN
Duplex printing
●
Duplex printing accessory mounts directly beneath the printer for
two-sided printing (included with the HP Color LaserJet 4550DN and
4550HDN printers)
Connectivity
●
Bidirectional parallel port (requires a “C” connector)
●
Two Enhanced Input/Output (EIO) slots
●
HP JetDirect print server (EIO network card) (included with the
HP Color LaserJet 4550N, 4550DN, and 4550HDN printers)
●
Paper handling accessory port
●
Infrared receiver port
●
Embedded Web server
Optional storage ●
features
Environmental
features
EN
RIP Once Technology (included with the HP Color LaserJet 4550HDN
printer)
●
Job retention (included with the HP Color LaserJet 4550HDN printer)
●
Flash DIMM
●
PowerSave setting
●
High content of recyclable components and materials
Chapter 1
19
Factors affecting printer performance
Several factors affect the time it takes to print a job. Among these is
maximum printer speed, measured in pages per minute (ppm). Other
factors that affect printing speed include the use of special media
(such as transparencies, glossy media, heavy media, and customsize media), printer processing time, and download time.
The time required to download a print job from the computer to the
printer and then have the printer process the job depends on the
following variables:
Note
20
●
the complexity and size of graphics
●
color versus black and white
●
the printer’s I/O configuration (network versus parallel speed)
●
the speed of the computer you are using
●
the amount of printer memory installed
●
the network operating system and configuration (if applicable)
●
printer personality (PCL or PostScript 3 emulation)
Adding additional printer memory may resolve memory problems,
improve how the printer handles complex graphics, and improve
download times, but will not increase maximum printer speed (ppm
rating).
The HP Color LaserJet 4550 Series Printer
EN
Locating printer components
The following illustrations identify the locations and names of key
components of this printer.
Figure 1-1
Front view (shown with 500-sheet paper feeder and duplex printing accessory)
1
Top output bin
2
Printer control panel
3
Power switch (standby button)
4
Optional duplex printing accessory drawer
5
Tray 3 (optional 500-sheet paper feeder)
6
Tray 2 (250 sheets of standard paper)
7
Middle front drawer (transfer belt access)
8
Tray 1 (150-sheet multipurpose tray)
9
Upper front drawer (imaging drum access)
10 Top cover door release button
11 Top cover door (toner cartridge access)
EN
Chapter 1
21
8
9
10
1
2
7
3
6
5
Figure 1-2
4
Rear view (shown with 500-sheet paper feeder and duplex printing accessory)
1
Rear door (fuser access)
2
Rear output bin door
3
Optional duplex printing accessory cover
4
Optional duplex printing accessory power receptacle
5
Printer power receptacle
6
Parallel connector (“C” connector)
7
EIO slots
8
Paper handling accessory port
9
Memory access (remove the formatter)
10 FIR port
22
The HP Color LaserJet 4550 Series Printer
EN
Controlling print jobs
There are several options available for controlling print jobs:
●
select printer settings through your software application or the
printer driver (recommended method)
●
select printer settings using the printer control panel
●
select printer settings using the new embedded Web server
●
enter printer commands directly into files
●
HP Web JetAdmin
Select printer settings through your software
application or the printer driver
The optimal way to control the printer is through your software
application or the printer driver. Changing these settings affects only
your print job. Most software applications allow you to choose printing
selections from menus within the software application. These
selections override the selections on the printer control panel.
Select printer settings using the printer control panel
You can also control the printer through the keys and menus of the
printer control panel. Changing these settings affects all print jobs. If
you are sharing the printer, coordinate control panel changes with
other users. For more information, see Chapter 2.
Note
EN
Software application and printer driver settings override printer control
panel settings.
Chapter 1
23
Select printer settings remotely with the embedded
Web server
If you have a Web browser, you can use the printer embedded Web
server to control printer settings. To access the embedded Web
server, open your browser and enter the printer IP address or the
printer host name. You can print a configuration page from the control
panel to determine the printer address or hostname.
The embedded Web server allows complete remote control panel
functionality. Refer to Appendix E for details on how to use the
embedded Web server.
Note
To use the embedded Web server, you must have an IP-based network
and a Web browser. The embedded Web server can be used with
Microsoft® Internet Explorer 4 or above, and with Netscape Navigator 4
and above. IPX-based printer connections are not supported by the
embedded Web server.
Enter printer commands directly into files
Some software applications allow you to enter printer commands (for
example, escape sequences) directly into files. However, this method
of controlling your printer requires that you learn printer PCL
commands. For information on PCL printer commands, see
Appendix C or the PCL/PJL Technical Reference Package for this
printer. (See page 32 for ordering information.)
24
The HP Color LaserJet 4550 Series Printer
EN
Managing memory
This printer supports up to 192 MB of memory. You can add additional
memory by installing Dual Inline Memory Modules (DIMMs). To allow
for memory expansion, the printer has three DIMM slots, which
accept 64 or 128 MB of RAM each. For information on installing
printer memory, see Appendix A.
The printer features Memory Enhancement Technology (MEt), which
automatically compresses page data to provide the most efficient use
of the printer’s RAM.
The printer uses 168-pin, nonparity, synchronous DRAM memory
modules. Extended data output (EDO) DIMMs are not supported.
Note
If memory problems occur when you are printing complex graphics, you
can make more memory available by removing downloaded fonts, style
sheets, and macros from printer memory. Reducing the complexity of
a print job from within an application can help in avoiding memory
problems.
This printer also includes HP Resource Manager, a new software
utility to assist with managing memory. For a full description of this
feature, see “HP Resource Manager” on page 27.
EN
Chapter 1
25
Printer software
Included with the printer is a CD-ROM containing the printing system
software. The software components and printer drivers on this
CD-ROM help you use the printer to its fullest potential. See the
getting started guide for installation instructions.
Note
For the latest information about the printing system software
components, view the ReadMe files on the CD-ROM.
This section summarizes the software included on the CD-ROM. The
printing system includes software for end users and network
administrators operating in the following operating environments:
●
Microsoft Windows 9x and 2000
●
Microsoft Windows NT 4.0
●
Apple Mac OS, version 7.5.3 or greater
●
AutoCAD drivers, versions 12-15
Note
For a list of the network environments supported by the network
administrator software components, see page 130.
Note
The CD-ROM also includes the drivers and font installer for
Windows 3.x, but there is no printing system for Windows 3.x.
26
The HP Color LaserJet 4550 Series Printer
EN
HP Resource Manager
This network administration software utility allows you to control the
hard disk and flash memory features that are not found in the
software drivers. Use HP Resource Manager to do the following:
Note
●
Initialize the hard disk
●
Initialize flash memory
●
Download, delete, and manage fonts and macros across
networks
To download Type 1 fonts, you must have Adobe® Type Manager loaded
on the computer and turned on.
HP Resource Manager is included on CD-ROM with the HP Color
LaserJet 4550HDN printer. However, if you order the hard disk as an
optional accessory, you can download the HP Resource Manager
utility from the Web. The HP Resource Manager utility is not available
for the Macintosh.
WWW
EN
Download the HP Resource Manager utility from http://www.hp.com/
cposupport, and type HP Resource Manager in the Quick Find box.
Chapter 1
27
Printer drivers
Printer drivers access the printer features and allow the computer to
communicate with the printer. The following printer drivers are
included with the printer.
Operating systema
PCL 5c
PCL 6
PS
Windows 3.1x
✓
✓
Windows 9x
✓
✓
✓
Windows NT 4.0
✓
✓
✓
Windows 2000
✓
✓
✓
Macintosh OS
a.
✓
Not all printer features are available from all drivers or OSs. See the online
Help in your driver for availability of features.
Note
The OS/2 drivers are available from IBM and are packaged with OS/2.
They are not available for Traditional Chinese, Simplified Chinese,
Korean, and Japanese.
WWW
If your system didn’t automatically check the Internet for the latest
drivers during the installation of the software, download them from
http://www.hp.com/support/lj4550. Once connected, select
Downloads and Drivers to find the driver you wish to download.
Additional drivers
The following drivers are not included on the CD-ROM, but are
available from the Internet or from HP Customer Care. (See “HP
Customer Care” on page 250.)
28
●
OS/2 PCL 5c/6 printer driver
●
OS/2 PS printer driver
●
Windows NT 3.51 PCL 5c, Windows NT 3.51 PS
●
UNIX and Linux Model Scripts
The HP Color LaserJet 4550 Series Printer
EN
Other components and utilities
This printer ships with several helpful software applications for
Windows and Mac OS users, as well as for Network Administrators.
These programs are summarized below.
Printing system software
Windows
Mac OS
Network Administrator
●
Software installer —
automates the printing
system installation
●
●
Online Web registration
●
HP Reorder assistance
software
PostScript Printer
●
Description files (PPDs) —
for use with the Apple
LaserWriter 8 driver that
comes with the Mac OS
●
HP LaserJet Utility — a
printer management utility
●
for Mac OS users
●
HP Web JetAdmin — a
browser-based system
management tool. Go to
http://www.hp.com/go/
webjetadmin for the latest
HP Web Jetadmin
software.
HP Resource Manager —
a new network
management tool
described on page 27.
HP JetDirect Printer
Installer for UNIX —
available for download
from http://www.hp.com/
support/net_printing.
HP JetSend communications
HP JetSend is a technology from Hewlett-Packard that allows devices
to communicate with each other simply and directly. HP JetSend is
built into your printer, allowing it to receive information from any
HP JetSend-enabled sending device anywhere on your network,
whether it is in the same office or at a remote location. When you use
the HP InfraRed Receiver accessory, your printer also can receive
information from any HP JetSend-enabled infrared device. Examples
of HP JetSend sending devices include digital cameras, computers or
laptops running HP JetSend software, or scanners with HP JetSend
built in. HP JetSend uses simple IP addressing between networked
devices and cableless communication between infrared devices.
WWW
EN
To enable HP JetSend on your computer or laptop, visit the HP JetSend
website at http://www.jetsend.hp.com/products.
Chapter 1
29
With the software, you will be able to exchange intra-company
documents directly between two or more computers and between any
HP JetSend-enabled printers, without the problems of incompatible
software applications or versions. HP JetSend software will allow your
colleagues to create documents on their computers and send copies
directly to this printer without any device-specific drivers or
configuration difficulties.
You can visit the HP JetSend website to learn which other devices are
available to communicate easily and directly with your HP JetSendenabled printer.
Note
30
HP JetSend software is not supported for Traditional Chinese,
Simplified Chinese, Korean, and Japanese.
The HP Color LaserJet 4550 Series Printer
EN
Printer supplies and accessories
You can increase the capabilities of your printer by adding
accessories.
WWW
To order printer accessory products, go to the HP website at
U.S. – http://www.hp.com/go/supplies or
Worldwide – http://www.hp.com/ghp/buyonline.html.
If you don’t have Internet access, contact your qualified HP dealer, or
call Hewlett-Packard at (800) 538-8787 (U.S.). (See Appendix D for
phone numbers.)
Accessory
Product
number
Description
Additional information
Memory (DIMMs)
C7848A
C7850A
64 MB
128 MB
This printer uses 168-pin
dual inline memory modules
(DIMMs) exclusively (SDRAM
only).
500-sheet paper
feeder
C4082A
Optional 500-sheet input tray
Duplex printing
accessory
C4083A
Optional two-sided printing
accessory
Printer cabinet
C4235A
HP Color LaserJet 4550
Printer Cabinet
Toner supplies
C4191A
C4192A
C4193A
C4194A
Black
Cyan
Magenta
Yellow
U.S. – http://www.hp.com/go/
ljsupplies or
Worldwide – http://
www.hp.com/ghp/
buyonline.html.
Consumables
C4195A
C4196A
C4197A
C4198A
Drum Kit
Transfer Kit
Fuser Kit (110V)
Fuser Kit (220V)
U.S. – http://www.hp.com/go/
supplies or
Worldwide – http://
www.hp.com/ghp/
buyonline.html.
Media
C2934A
C2936A
C4179A
C4179B
HP Transparency Film (letter)
HP Transparency Film (A4)
HP Soft Gloss Paper (letter)
HP Soft Gloss Paper (A4)
U.S. – http://www.hp.com/go/
ljsupplies or
Worldwide – http://
www.hp.com/ghp/
buyonline.html.
Network connectivity
J3110A
J3111A
HP JetDirect 600N for Ethernet (10Base-T [RJ-45])
HP JetDirect 600N for Ethernet (10Base-T [RJ-45] and
10Base-2 [BNC]) and LocalTalk (DIN-8)
HP JetDirect 600N for Token Ring (DB9, RJ-45)
HP JetDirect 610N for Fast Ethernet (10/100 Base-TX [RJ-45])
Infrared receiver dongle
HP JetDirect connectivity card (EIO) for USB, Serial, LocalTalk
J3112A
J4169A
C4103A
J4135A
EN
Chapter 1
31
Accessory
Product
number
Description
Cables
C2947A
10 m (30 ft) parallel cable (IEEE-1284 compliant) with a 25-pin
DB male to a (IEEE-1284C) male “C” connector
LocalTalk Cable Kit
DIN-8 printer cable (for Macintosh computers)
92215N
92215S
Additional information
U.S. – http://www.hp.com/go/supplies or
Worldwide – http://www.hp.com/ghp/buyonline.html.
Reference materials
5090-3392
5021-0337
5967-0831
HP LaserJet Printer Family Paper Specification Guide
PCL/PJL Technical Reference Package
HP JetDirect Print Server Administator’s Guide
For downloadable manuals, go to http://www.hp.com/support/
lj4550. When you connect, select Manuals.
Localized font
DIMMs
Hard disk drive
YS-90210
C2985B
Optional hard disk drive for additional storage.
C4286A
C4287A
Permanent storage for fonts and forms:
2 MB
4 MB
Flash DIMM
32
1 MB
Greek
Hebrew
Cyrillic
Arabic
Traditional Chinese
Simplified Chinese
Hangul (Korean, includes
KS/KSSM)
Japanese
5062-4667
5062-4668
5062-4669
5062-4670
C4292A
C4293A
C2419A
The HP Color LaserJet 4550 Series Printer
8 MB
EN
2
Using the printer
control panel
Overview
This chapter helps you use the printer control panel to maximize
printer performance. This chapter includes the following sections:
Note
EN
●
When to use the printer control panel
●
Locating printer control panel features
●
Control panel menus
●
Hard disk dependent menus
●
Printer information pages
●
Using the printer control panel in shared environments
●
Changing printer control panel configuration settings
Unless otherwise specified, “control panel” refers to the printer’s
control panel. Keys on the control panel are indicated by the KEY font.
Chapter 2
33
When to use the printer control panel
Hewlett-Packard has designed the printer control panel to facilitate
setting up default printer settings and to make printing selections
when your software does not provide them.
Use the printer control panel for overall configuration requirements, to
obtain printer status information, and to perform the following
procedures:
●
configure input trays for media type and size
●
take the printer online or offline
●
print configuration pages and menu maps
●
change printer default settings
●
verify available fonts
Software applications that provide print option commands allow you
to control print jobs through the software application rather than by
changing the printer control panel settings. The degree of control
varies among applications. Software commands override printer
control panel settings for all Printing Menu and most Configuration
Menu items.
Note
For information about controlling the printer in a network environment,
see the HP JetDirect Print Server Administrator’s Guide.
WWW
For downloadable manuals, go to http://www.hp.com/support/lj4550.
When you connect, select Manuals.
34
Using the printer control panel
EN
Locating printer control panel features
11
10
1
2
9
8
3
4
5
7
Figure 2-1
6
Printer control panel
1
Attention indicator light
2
Menu key*
3
Item key*
4
Printer online Help
5
Value key*
6
Select key
7
Cancel Job key
8
Go key
9
Data indicator light
10 Ready indicator light
11 Printer control panel display
*Rocker keys
Note
EN
The ITEM key is also used to navigate through the online [?] Help
system.
Chapter 2
35
Using printer control panel keys
The following table summarizes the function of each printer control
panel key.
Key
Function
GO
Depends on the status of the printer. Normally, GO activates printing using
current settings or directs the printer to proceed with the process
designated on the control panel. If the printer is offline, pressing GO will
return the printer to the READY state.
CANCEL JOB
Terminates the job that is currently printing. The printer completes the
current page and purges all input until a new job is detected (may take
several seconds depending on the size of the job).
MENU
Displays a menu system for obtaining printer status information or changing
the printer’s configuration settings.
ITEM
Cycles through items in the selected menu. Menu items vary depending on
the options installed and on the configuration of other menu choices. The
ITEM key is also used to navigate through the printer’s online Help system.
VALUE
Cycles through the value choices for a particular menu item.
SELECT
Selects the value that is currently shown on the display.
Using the printer online Help system
This printer features an online Help system that provides instructions
for resolving most printer errors. Certain control panel error
messages alternate with instructions on accessing the online Help
system.
Whenever a ? appears in an error message, or a message alternates
with FOR HELP PRESS THE ? KEY, press the right side of the ITEM
key to navigate through a sequence of instructions.
Note
36
To exit the online Help system, press either GO or SELECT.
Using the printer control panel
EN
Interpreting control panel indicator lights
The following table explains the meaning of the printer control panel
indicator lights (see page 35).
Indicator
On
Off
Flashing
Ready
(green)
Printer is online (able to
accept and process
data).
Printer is offline.
Printer is attempting to
stop printing and go
offline.
Data
(green)
Processed data is
present in the printer,
but more data is
needed to complete the
job.
No data is being
received or processed.
Data is being received
and processed by the
printer.
Attention
(amber)
A critical error has
occurred. Printer
requires attention.
No conditions exist that
require attention.
An error has occurred.
Printer requires
attention.
EN
Chapter 2
37
Control panel menus
The printer control panel menus allow you to change printer settings
and to access printer status information. This section outlines the
printer control panel menus and the selections available within each
menu.
Menu locking
Menu selections can be locked out by a system administrator. If you
are unable to access a particular menu, contact your system
administrator.
Menu map
The menu map helps you navigate through control panel menus. See
the menu map sample on page 39 for details.
To print a menu map
38
1
On the printer control panel, press MENU until INFORMATION
MENU displays.
2
Press ITEM until PRINT MENU MAP displays.
3
Press SELECT to print the menu map. After printing the menu
map, the printer will return to the READY state.
Using the printer control panel
EN
Interpreting the menu map
The following sample illustrates a menu map. Each menu and the
associated menu items are described on the pages following the
graphic.
Note
Figure 2-2
Note
EN
In the menu descriptions, menu items followed by an asterisk (*) denote
default values.
1
2
4
5
3
6
7
Menu map
1
Information menu
2
Paper handling menu
3
Printing menu
4
Configuration menu
5
I/O menu
6
Calibration menu
7
Resets menu
8
Quick Copy Jobs menu (only shown if a hard disk or RAM disk is
installed)
9
Private/Stored Jobs menu (only shown if a hard disk or RAM disk
is installed)
Some menus only appear when the hard disk is installed. See the Hard
disk dependent menus section for descriptions of these menus.
Chapter 2
39
Information menu
The Information menu selections are used for accessing and printing
specific printer information.
40
Menu item
Description
PRINT MENU MAP
Prints the control panel menu map.
PRINT
CONFIGURATION
Prints the printer configuration page.
PRINT
FONT LIST
Prints the available PCL and PS (emulated
PostScript) font samples.
PRINT
FILE DIRECTORY
Prints the name and directory of files
stored in the printer on an optional hard
disk or RAM memory module.
PRINT
EVENT LOG
Prints a historical list of printer events.
SHOW
EVENT LOG
Displays a historical list of printer events on
the control panel.
PRINT
PAPER PATH TEST
Prints a test of the paper path for the printer
to make sure there are no media jams.
PRINT
USAGE PAGE
Prints a count of all media sizes that have
passed through the printer. Also lists
whether they were simplex, duplex,
monochrome, or color.
PRINT
SUPPLIES STATUS PAGE
Prints the estimated remaining life for the
toner cartridges, transfer belt, fuser, and
imaging drum.
PRINT
LASERJET DEMO
Prints a demonstration page for the printer.
PRINT ACCESSORIES LIST
Prints a list of optional accessories that
have been installed on the printer.
PRINT COLOR GUIDE
Prints a one-page guide with hints on using
color effectively.
Using the printer control panel
EN
Paper handling menu
The Paper handling menu allows you to configure input trays by size
and type. This menu can also be used to set the default media size
and type.
Note
The default mode for Tray 1 is TRAY 1 MODE=FIRST. In this mode, the
printer will pull media from Tray 1 regardless of the size or type of media
loaded. To configure Tray 1 by size or type, it must be configured as
TRAY 1 MODE=CASSETTE.
Menu item
Values
TRAY 1 MODE
FIRST*
CASSETTE
TRAY 1 SIZE
(appears only if Tray 1 mode is set to
TRAY 1 MODE=CASSETTE)
LETTER*/A41
LEGAL
EXEC
JIS B5
A5
CUSTOM
B5
COM10
C5
DL
MONARCH
TRAY 1 TYPE
(appears only if Tray 1 mode is set to
TRAY 1 MODE=CASSETTE)
PLAIN*
PREPRINTD
LTRHEAD
TRNSPRNCY
GLOSS
PREPUNCHD
LABELS
BOND
RECYCLED
COLOR
HEAVY
CARDSTOCK
TRAY 2 TYPE
(same choices as TRAY 1 TYPE except
LABELS and CARDSTOCK)
TRAY 3 TYPE
(same choices as TRAY 1 TYPE except
LABELS and CARDSTOCK)
MANUAL FEED
ON
OFF
1In
EN
some countries/regions, A4 is the default setting.
Chapter 2 41
Printing menu
The Printing menu is used to set default settings for a specific print
job.
Menu item
Values
Description
COPIES
1 to 999 (default: 1)
Number of copies.
CONFIGURE CUSTOM PAPER
YES*
NO
Specifies the dimension of
custom sized paper.
UNIT OF MEASURE
INCHES
MM
Set the unit of
measurement.
X DIMENSION
Determine the length of
the custom size media.
Y DIMENSION
Determine the width of the
custom size media.
ORIENTATION
PORTRAIT*
LANDSCAPE
Determines the default
page orientation.
PCL FONT SOURCE
INTERNAL*
SOFT
SLOT n (n = 1,2,3)
Instructs the printer where
to look for PCL fonts.
PCL FONT NUMBER
0 to 999 (default: 0)
Specifies a default PCL
font number from the
printer font list.
PCL FONT PITCH1
0.44 to 99.99
(default: 10)
Specifies a default pitch
for scalable PCL fonts.
PCL FONT
POINT SIZE2
4 to 999.75
(default: 12)
Specifies a default font
size for scalable PCL
fonts.
PCL SYMBOL SET
PC-8 (default)
Used to select an
appropriate symbol set.
See Appendix B.
WIDE A4
NO*
YES
Sets the printer to allow
wide-A4 type media.
APPEND CR TO LF
NO*
YES
Appends a carriage return
to each line feed character
in the data stream. (UNIX)
1Displays
2Displays
42
only when a fixed space font is specified
only when a proportional space font is specified
Using the printer control panel
EN
Configuration menu
The Configuration menu is used to set general printer default settings.
CAUTION
Hewlett-Packard recommends that configuration settings only be
changed by a system administrator. Configuration settings seldom
need to be changed.
Menu item
Values
Description
POWERSAVE TIME
1 MIN
15 MIN
30 MIN*
1 HR
2 HRS
4 HRS
The length of time before the
printer goes into power-saving
mode.
CLEARABLE
WARNINGS
JOB*
ON
If ON, message is displayed until
GO is pressed. If JOB, message is
displayed until end of print job.
AUTO CONTINUE
ON*
OFF
Determines whether the printer
continues printing when certain
errors occur. If ON, printer returns to
the READY state. If OFF, printer
remains offline until GO is pressed.
JAM RECOVERY
AUTO*
MANUAL
Printer attempts to recover from
jams and reprints affected pages. If
AUTO, printer returns to the READY
state. If MANUAL, printer remains
offline until GO is pressed.
Enabling this feature consumes
printer memory.
PRINT PS ERRORS
OFF*
ON
Prints out an error page when
emulated PostScript errors occur. If
ON, printer returns to the READY
state. If OFF, printer remains offline
until GO is pressed.
RAM DISK
OFF*
ON
Determines if a RAM disk is
installed and whether or not it is
activated.
RAM DISK SIZE=
Displays the size (in MB or GB) of
the activated RAM disk (if
installed).
QUICK COPY
JOBS=
Displays the number of Quick Copy
jobs saved in printer memory.
HELD JOB
TIMEOUT
OFF*
ON
Sets the length of time the printer
will save a held job in memory prior
to deleting it.
PERSONALITY
AUTO*
PCL
PS
The personality (language) the
printer uses to process a print job.
*Denotes default setting
EN
Chapter 2
43
I/O menu
The I/O menu allows you to make changes to printer interface
settings. The following table lists the selections that appear for each
item in this menu. (See Chapter 6 for additional information.)
44
Menu item
Values
Description
PARALLEL HIGH
SPEED
YES*
NO
Allows faster parallel
communications supported by
newer computers.
Using the printer control panel
EN
Calibration menu
This printer features automatic, internal calibration to produce
optimum color for most print jobs. The Calibration menu provides
fine-tuning for critical color-matching requirements.
For more information on using this menu for setting toner densities,
see Chapter 4.
CAUTION
Calibrating toner densities changes the color balance of your printer by
altering halftones. It affects all print jobs. Notify your network
administrator before performing this procedure.
Menu item
Values
PRINT
CALIBRATION PAGE
Prints out the color calibration
page.
CYAN
DENSITY
-5 to +5
(default: 0)
Used for increasing or decreasing
cyan toner density.
MAGENTA
DENSITY
-5 to +5
(default: 0)
Used for increasing or decreasing
magenta toner density.
YELLOW
DENSITY
-5 to +5
(default: 0)
Used for increasing or decreasing
yellow toner density.
BLACK
DENSITY
-5 to +5
(default: 0)
Used for increasing or decreasing
black toner density.
RESTORE DEFAULT
DENSITY VALUES
EN
Description
Resets density values to default
settings. Press SELECT to reset
values.
Chapter 2
45
Resets menu
The Resets menu is used for resetting the printer memory and for
returning the printer to its factory default settings. It is also used to
clear maintenance messages following the replacement of certain
consumable items.
46
Menu item
Description
NEW [COLOR]
CARTRIDGE
Resets the toner gauge for the printer and allows
printing to continue.
NEW TRANSFER KIT
SELECT IF DONE
Clears the maintenance message after the transfer kit
has been replaced. (Only prompted when transfer kit is
low.)
NEW FUSER KIT
SELECT IF DONE
Clears the maintenance message after the fuser kit has
been replaced. (Only prompted when fuser kit is low.)
RESET MEMORY
Resets the printer and control panel menus to userspecified default settings.
RESTORE FACTORY
SETTINGS
Resets the printer and control panel menus to factory
default settings.
POWERSAVE
Allows PowerSave feature to be turned on or off.
Using the printer control panel
EN
Hard disk dependent menus
Quick Copy Jobs menu
This menu provides a list of the quick copy jobs stored on the printer
hard disk. The user can print or delete these jobs from the control
panel. See “Job retention features” on page 95 and “Proofing and
holding a job” on page 97 for more information about using this menu.
Note
If there are no quick copy jobs stored on the printer’s hard disk, this
menu is not displayed on the control panel.
Menu Item
Values
[JOBNAME]
COPIES=1
EN
Description
The name of the quick copy job
defined by the sender.
1 to 999
DELETE
The number of additional copies
the user wants to print.
1-999: Prints the requested
number of copies of the job.
DELETE: Deletes the job from the
printer’s hard disk.
Chapter 2
47
Private/Stored Jobs menu
This menu provides a list of the private and stored jobs on the
printer’s hard disk. The user can print or delete these jobs from the
control panel. See “Printing a private job” on page 99 and “Storing a
print job” on page 101 for more information about using this menu.
Note
If there are no private or stored jobs on the printer’s hard disk, this menu
is not displayed on the control panel.
Menu item
Values
Description
[JOBNAME]
The name of the job defined by the
sender stored on the printer’s hard
disk.
PIN:0000
To print the job, the user must enter
the Personal Identification Number
(PIN) that was assigned to the job
in the driver.
COPIES=1
1 to 999
DELETE
The number of copies the user
wants to print.
1-999: Prints the requested
number of copies of the job.
DELETE: Deletes the job from the
printer’s hard disk.
EIO menu
If an Enhanced Input Output (EIO) card (for example, an HP JetDirect
Print Server) has been installed in the printer, an additional menu is
available. This additional menu provides a way to configure the EIO
accessory and to adjust network interface settings.
WWW
48
For information on HP JetDirect EIO menus, see the HP JetDirect Print
Server Administrator’s Guide. This guide is included with the HP Color
LaserJet 4550N, 4550DN, and 4550HDN printers and is available
through HP Customer Care online at http://www.hp.com/support/
net_printing.
Using the printer control panel
EN
Printer information pages
Printer configuration page
Printing a printer configuration page can help you verify that the
printer is configured properly. This can be useful in troubleshooting
printer problems.
To print a printer configuration page
Note
EN
1
On the printer control panel, press MENU until INFORMATION
MENU displays.
2
Press ITEM until PRINT CONFIGURATION displays.
3
Press SELECT to print the configuration page. After the process is
completed, the printer will return to the READY state.
If the printer is configured with EIO cards (for example, an HP JetDirect
Print Server) or an optional hard disk drive, an additional configuration
page will print that provides interface configuration information.
Chapter 2
49
Interpreting the printer configuration page
The following sample illustrates a printer configuration page.
1
2
3
4
7
8
9
10
5
6
Figure 2-3
50
Printer configuration page
1
Printer information—Lists the printer serial number,
PCL/Emulated PostScript firmware revision, total number of
pages printed during the life of the printer, and total number of
color pages printed during the life of the printer.
2
Event log—Lists the last five printer events, including printer
jams, service errors, and other printer conditions.
3
Installed personalities and options—Lists installed options
such as EIO cards, DIMMs, duplex printing accessory, and 500sheet paper feeder.
4
I/O menu—Lists the current settings of the I/O menu items.
5
Configuration menu—Lists the current settings of the
configuration menu items.
6
Printing menu—Lists the current settings of the printing menu
items.
Using the printer control panel
EN
7
Memory—Shows the total memory installed and the total
memory available in the printer. Also lists the memory allocation
settings.
8
Security—Shows whether the printer control panel is locked or
unlocked. Also shows whether the printer control panel password
is enabled or disabled.
9
Paper trays—Lists the size and type of media currently
configured for each input tray. Also lists the current Tray 1 mode,
A4/letter override setting, and default size setting.
10 Density settings—Lists the current density settings.
EN
Chapter 2
51
Supplies status page
The supplies status page illustrates the remaining life for the following
printer consumables and kits:
●
toner cartridges (all colors)
●
drum kit
●
transfer kit
●
fuser kit
It also lists useful printer information including the total number of
pages printed (in monochrome and in color), the printer serial
number, and the part numbers for the supplies.
To print the supplies status page
52
1
On the printer control panel, press MENU until INFORMATION
MENU displays.
2
Press ITEM until PRINT SUPPLIES STATUS PAGE displays.
3
Press SELECT to print the supplies status page. After the process
is completed, the printer will return to the READY state.
Using the printer control panel
EN
Interpreting the supplies status page
The following sample illustrates a supplies status page.
1
5
2
6
3
7
4
8
Figure 2-4
Supplies status page
Print cartridge information
1
Black TonerGauge
2
Cyan TonerGauge
3
Magenta TonerGauge
4
Yellow TonerGauge
Other supplies information
5
Imaging drum kit
6
Transfer kit
7
Fuser kit
Printer information
8
EN
Printer usage totals
Chapter 2
53
Usage page
The usage page lists a page count for each size of media that has
passed through the printer. This page count includes the number of
pages that were printed on one side, the number that were printed on
two sides (duplexed), and totals of the two printing methods for each
media size. It also lists the average percentage of page coverage for
each toner color.
To print the usage page
54
1
On the printer control panel, press MENU until INFORMATION
MENU displays.
2
Press ITEM until PRINT USAGE PAGE displays.
3
Press SELECT to print the usage page. After the process is
completed, the printer will return to the READY state.
Using the printer control panel
EN
Interpreting the usage page
The following sample illustrates a usage page.
1
2
3
4
5
Figure 2-5
EN
Usage page
1
Usage totals (all media sizes)
2
Black coverage
3
Cyan coverage
4
Yellow coverage
5
Magenta coverage
Chapter 2
55
Event log
To print an event log
1
On the printer control panel, press MENU until INFORMATION
MENU displays.
2
Press ITEM until PRINT EVENT LOG displays.
3
Press SELECT to print the event log. After the process is
completed, the printer will return to the READY state.
Interpreting the event log
The following sample illustrates an event log.
Figure 2-6
Printer event log
The printer event log lists the printer events, including printer jams,
service errors, and other printer conditions.
56
Using the printer control panel
EN
Using the printer control panel in
shared environments
The printer control panel functions essentially the same in shared
printer environments as it does when connected to a standalone
computer. If problems occur, contact your network administrator.
Because your printer is shared with other users, adhering to the
following guidelines will help ensure successful printer operation:
Note
EN
●
Consult your system administrator before making changes to
control panel settings. Changing control panel settings could
affect other print jobs.
●
Coordinate with other users before changing the default printer
font or downloading soft fonts. Coordinating these operations
conserves memory and avoids unexpected printer output.
●
Be aware that switching printer personalities, such as Emulated
PostScript or PCL, affects the printed output of other users.
Your network operating system may automatically protect each user’s
print job from the effects of other print jobs. Consult your system
administrator for more information.
Chapter 2
57
Changing printer control panel configuration
settings
By using the printer control panel, you can make changes to general
printer configuration default settings such as PowerSave Time, printer
personality (language), and jam recovery.
CAUTION
Hewlett-Packard recommends that configuration settings be changed
only by a system administrator. Configuration settings very seldom
need to be changed.
To change printer control panel configuration settings
58
1
Press MENU until CONFIGURATION MENU displays.
2
Press ITEM until the item that you want to change displays.
3
Press VALUE until the appropriate setting displays.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Using the printer control panel
EN
Changing PowerSave settings
The adjustable PowerSave Time feature reduces power consumption
when the printer has been inactive for an extended period. The printer
display dims when the printer is in PowerSave Time mode. You can
set the length of time before the printer goes into PowerSave Time
mode to 1 minute, 15 minutes, 30 minutes, or to 1, 2, or 4 hours. The
default setting is 30 minutes.
To change the PowerSave setting
EN
1
Press MENU until CONFIGURATION MENU displays.
2
Press ITEM until POWERSAVE TIME displays.
3
Press VALUE until the appropriate setting displays.
4
Press SELECT to save the setting.
5
Press GO. The printer will return to the READY state within a few
minutes.
Chapter 2
59
Switching printer personalities
This printer features automatic personality (printer language)
switching. In AUTO mode, the printer automatically detects the type of
print job and configures its personality to accommodate that job. You
also can change the personality mode to default to using PCL or
PostScript Emulation (PS) exclusively.
To switch printer personality
60
1
Press MENU until CONFIGURATION MENU displays.
2
Press ITEM until PERSONALITY displays.
3
Press VALUE until the appropriate setting displays.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Using the printer control panel
EN
Setting the I/O timeout
I/O Timeout sets the number of seconds that the printer waits to
receive additional data from the computer before switching I/O ports.
The default setting for the printer is 15 seconds.
Note
Setting the I/O Timeout too high may cause a single I/O port to remain
active and prohibit data from being received through other ports.
Setting I/O Timeout too low may result in missing characters,
out-of-order print jobs, or other print problems.
To set the I/O timeout
EN
1
Press MENU until I/O MENU displays.
2
Press ITEM until I/O TIMEOUT displays.
3
Press VALUE to increase or decrease the I/O Timeout value.
Holding the key down will change the value more quickly.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Chapter 2
61
Disabling the high-speed parallel interface
This printer features a high-speed, bidirectional parallel interface. The
interface supports high- and low-speed access. The high-speed
access may not be compatible with some computers. Through the
I/O Menu, you can enable and disable the high-speed parallel
interface. The default setting is enabled.
To disable the high-speed parallel interface
62
1
Press MENU until I/O MENU displays.
2
Press ITEM until PARALLEL HIGH SPEED displays.
3
Press VALUE until NO displays. (To enable high-speed parallel
interface, set the value to YES.)
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Using the printer control panel
EN
Setting advanced functions
This printer supports bidirectional parallel communication. You can
turn this feature on and off through the I/O Menu.
To enable bidirectional parallel communication
1
Press MENU until I/O MENU displays.
2
Press ITEM until PARALLEL ADV COMMUNICATN displays.
3
Press VALUE until ON displays.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Resetting printer memory
CAUTION
Resetting memory clears the page buffer, removes downloaded fonts
and macros, and returns all print menu settings to user-selected
defaults.
To reset printer memory
EN
1
Press MENU until RESETS MENU displays.
2
Press ITEM until RESET MEMORY displays.
3
Press SELECT. RESETTING MEMORY appears on the printer
control panel display and the printer automatically returns to the
READY state.
Chapter 2
63
Resetting the printer to factory default
settings
Resetting the printer to factory default settings can be useful when
you are troubleshooting the printer.
CAUTION
Resetting factory defaults clears the page buffer, removes downloaded
fonts and macros, and returns all print menu settings to factory defaults.
To reset the printer to factory default settings
1
Press MENU until RESETS MENU displays.
2
Press ITEM until RESTORE FACTORY SETTINGS displays.
3
Press SELECT until the following message appears:
RESTORING
FACTORY SETTINGS
This message displays until the printer has completed the
initialization process. The printer automatically returns to the READY
state.
64
Using the printer control panel
EN
3
Common
printing tasks
Overview
This chapter helps you perform common printing tasks. The
chapter includes the following sections:
EN
●
Selecting print media
●
Printing on special media
●
Controlling print jobs
●
Configuring input trays
●
Printing from Tray 1 (multipurpose tray)
●
Printing from Tray 2
●
Printing from Tray 3 (optional 500-sheet paper feeder)
●
Using the optional duplex printing accessory for two-sided
printing
●
Special printing situations
●
Stopping a print request
●
Job retention features
●
Printing with the optional HP Fast InfraRed Receiver
Chapter 3
65
Selecting print media
You can use many types of paper and other print media with this
printer. This section provides guidelines and specifications for
selecting and using different print media.
Before purchasing any media or specialized forms in quantity, verify
that your paper supplier obtains and understands the print media
requirements specified in the HP LaserJet Family Paper Specification
Guide.
WWW
See Appendix D for HP LaserJet Family Paper Specification Guide
ordering information.
For downloadable manuals, go to http://www.hp.com/support/lj4550.
When you connect, select Manuals.
It is possible that media could meet all of the guidelines in this chapter
and still not print satisfactorily. This may be due to abnormal
characteristics of the printing environment or to other variables over
which Hewlett-Packard has no control (for example, extremes in
temperature and humidity).
Hewlett-Packard recommends testing any media before buying it
in large quantities.
CAUTION
66
Using media that does not conform to the specifications listed here or
in the paper specification guide can cause problems that require
service. This service is not covered by the Hewlett-Packard warranty
or service agreements.
Common printing tasks
EN
Supported media weights and sizes
For optimum results, use conventional 75 g/m2 (20 lb) photocopy
paper. Verify that the paper is of good quality and is free of cuts, nicks,
tears, spots, loose particles, dust, wrinkles, curls, or bent edges.
Tray
Supported media
Tray 1
Paper
A4/Letter
Legal
Executive
JIS B5
A5
Custom
Minimum Size:
76 x 127 mm (3 by 5 in)
Maximum Size:
216 x 356 mm
(8.5 by 14 in)
Media
specifications
Capacity
Single-sided:
150 sheets of 75 g/m2
(20 lb) paper
If less than or equal
to 148 mm wide:
60 to 176 g/m2
(16 to 47 lb bond)
Do not load more than
the maximum stack
height of 15 mm (0.6 in).
If more than or equal
to 148 mm wide:
60 to 176 g/m2
(16 to 36 lb bond)
Two-sided:
64 to 105 g/m2
(17 to 28 lb bond)
Transparencies
Glossy (semi-gloss) paper
0.13 mm (5 mil)
120 g/m2
(32 lb/80 lb text)
Limit of 50
Limit of 50 sheets
Envelopes
(Tray 1 only)
Com10
Monarch
C5
DL
B5 (JIS)
Maximum weight:
90 g/m2
(24 lb bond)
Limit of 10
Labels
(Tray 1 only)
Cardstock (Postcards)
(Tray 1 only)
EN
Limit of 50
Maximum weight:
176 g/m2
(47 lb bond)
Maximum size:
200 x 148 mm
(7.87 x 5.82 in)
Do not load more than
the maximum stack
height of
15 mm (0.6 in)
Chapter 3
67
Media
specifications
Tray
Supported media
Tray 2
Paper
A4/Letter
Legal
Executive
JIS B5
A5
Custom (B5 ISO)*
Single-sided:
60 to 105 g/m2
(16 to 28 lb bond)
Transparencies
Glossy Paper
0.13 mm (5 mil)
120 g/m2
(32 lb/80 lb text)
Limit of 50
Limit of 200 sheets
Paper
A4/Letter
Legal
Executive
JIS B5
Custom (B5 ISO)*
Single-sided:
60 to 105 g/m2
(16 to 28 lb bond)
500 sheets of 75 g/m2
(20 lb) paper
Transparencies
Glossy (semi-gloss) paper
0.13 mm (5 mil)
120 g/m2
(32 lb/80 lb text)
Paper
A4/Letter
Legal
Executive
JIS B5
64 to 105 g/m2
(17 to 28 lb)
Tray 3
(optional)
Duplex
Printing
Accessory
(optional)
Capacity
250 sheets of 75 g/m2
(20 lb) paper
Two-sided:
64 to 105 g/m2
(17 to 28 lb bond)
Two-sided:
64 to 105 g/m2
(17 to 28 lb bond)
Limit of 50
Limit of 500 sheets
*Trays 2 and 3 use “Custom” size specifically for B5 ISO. Trays 2 and 3 do not support the range of custom
sizes available in Tray 1.
68
Common printing tasks
EN
Media to avoid
Use the following guidelines to avoid poor print quality or damage to
your printer:
WWW
EN
●
Do not use paper that is too rough.
●
Do not use paper that is embossed or coated unless it is
specifically recommended for use in this printer.
●
Do not use paper with cutouts or perforations other than standard
3-hole punched paper.
●
Do not use multipart forms.
●
Do not use paper with irregularities such as tabs or staples.
●
Do not use letterhead paper with low temperature dyes or
thermography. Preprinted forms or letterhead must use inks that
can tolerate temperatures of 190° C (374° F) for 0.1 second.
●
Do not use any media that produces hazardous emissions, or that
melts, offsets, or discolors when exposed to 190° C (374° F) for
0.1 second.
●
Do not use paper that has already been printed on or that has
been fed through a photocopier.
●
Do not use paper with a watermark if you are printing solid
patterns.
●
Do not use transparencies that are not specified for use with
HP Color LaserJet printers.
To order HP Color LaserJet printing supplies on the Web, go to
U.S. – http://www.hp.com/go/ljsupplies or
Worldwide – http://www.hp.com/ghp/buyonline.html.
Chapter 3
69
Printing on special media
Use these guidelines when printing on special types of media.
WWW
To order HP Color LaserJet printing supplies on the Web, go to
U.S. – http://www.hp.com/go/ljsupplies or
Worldwide – http://www.hp.com/ghp/buyonline.html.
Transparencies
When printing on transparencies, use the following guidelines:
●
To prevent transparencies from bonding together, always send
them to the top output bin.
●
Handle transparencies using the edges. Oils from your fingers
that are deposited on the transparency can cause print quality
problems.
●
Use only overhead transparencies recommended for use in this
printer. Hewlett-Packard recommends using HP Color LaserJet
Transparencies with this printer. HP products are designed to
work together for optimum printing results.
Glossy paper
When printing on glossy paper, select the glossy print setting in the
printer driver. You can also use the printer control panel to set the
media type to GLOSS for the input tray you are using. Because this
affects all print jobs, it is important to return the printer back to its
original settings once your job has printed. See “Configuring input
trays” on page 76 for more information.
Note
70
Hewlett-Packard recommends using HP Color LaserJet Soft Gloss
paper with this printer. HP products are designed to work together for
optimum printing results. If you choose not to use HP Color LaserJet
Soft Gloss paper with this printer, print quality may be compromised.
Common printing tasks
EN
Colored paper
Colored paper should be of the same high quality as white
xerographic paper. Pigments used must be able to withstand the
printer’s fusing temperature of 190° C (374° F) for 0.1 second without
deterioration. Do not use paper with a colored coating that was added
after the paper was produced.
The printer creates colors by printing patterns of dots, overlaying and
varying their spacing to produce various colors. Varying the shade or
color of your paper will affect the shades of your printed colors.
Envelopes
Note
Envelopes can only be printed from Tray 1. Hewlett-Packard
recommends configuring Tray 1 as a cassette and setting the tray’s
media size to the specific envelope size. See “Loading envelopes into
Tray 1” on page 80.
Adhering to the following guidelines will help ensure proper printing of
envelopes and help prevent printer jams:
EN
●
Do not load more than 10 envelopes into Tray 1.
●
The weight rating of envelopes should not exceed
90 g/m2 (24 lb bond).
●
Envelopes should be flat.
●
Do not use envelopes with windows or clasps.
●
Envelopes must not be wrinkled, nicked, or otherwise damaged.
●
Envelopes with peel-off adhesive strips must use adhesives that
can withstand the heat and pressures of the printer’s fusing
process.
●
Envelopes should be loaded with the flaps facing away from the
printer and toward the right side of the printer.
Chapter 3
71
Labels
Note
For printing labels, Hewlett-Packard recommends configuring Tray 1 as
a cassette and setting the tray’s media type to LABELS in the printer
control panel. See “Configuring input trays” on page 76.
When printing labels, use the following guidelines:
●
Verify that the labels’ adhesive material can tolerate temperatures
of 190° C (374° F) for 0.1 second.
●
Verify that there is no exposed adhesive material between the
labels. Exposed areas can cause labels to peel off during
printing, which can cause printer jams. Exposed adhesive can
also cause damage to printer components.
●
Do not re-feed a sheet of labels.
●
Verify that labels lie flat.
●
Do not use labels that are wrinkled, bubbled, or otherwise
damaged.
Heavy paper
Use Tray 1 for paper that is heavier than 105 g/m2 (28 lb bond up to
42 lb bond). For optimum results when printing on heavy paper, use
the printer control panel to configure Tray 1 as a cassette and then set
the media type for the tray to HEAVY. Because this affects all print jobs,
it is important to return the printer back to its original settings once
your job has printed. See “Configuring input trays” on page 76.
CAUTION
72
Do not use paper that is heavier than the media specification
recommended for this printer. Doing so can cause misfeeds, paper
jams, reduced print quality, and excessive mechanical wear.
Common printing tasks
EN
Preprinted forms and letterhead
Observe the following guidelines for best results with preprinted forms
and letterhead:
●
Forms and letterhead must be printed with heat-resistant inks
that will not melt, vaporize, or release hazardous emissions when
subjected to the printer’s fusing temperature of approximately
190° C (374° F) for 0.1 second.
●
Inks must be non-flammable and should not adversely affect any
printer rollers.
●
Forms and letterhead should be sealed in a moisture-proof
wrapping to prevent changes during storage.
●
Before you load preprinted paper such as forms and letterhead,
verify that the ink on the paper is dry. During the fusing process,
wet ink can come off of preprinted paper.
Recycled paper
This printer supports the use of recycled paper. Recycled paper must
meet the same specifications as standard paper. See the
HP LaserJet Family Paper Specification Guide. Hewlett-Packard
recommends that recycled paper contain no more than 5 percent
ground wood.
WWW
See Appendix D or http://www.hp.com/support/lj4550 for HP LaserJet
Family Paper Specification Guide ordering information.
For downloadable manuals, go to http://www.hp.com/support/lj4550.
When you connect, select Manuals.
EN
Chapter 3
73
Controlling print jobs
Among the aspects of a print job that you can control are the tray from
which the printer pulls media, the bin to which you send the job, and
the configuration for type and size of media for each tray. You can
control print jobs through the printer driver, your software application,
or the printer control panel.
CAUTION
To avoid affecting print jobs of other users, whenever possible, make
printer setup changes through your software application or the printer
driver. Printer setup changes made through the control panel become
default settings for subsequent jobs. Changes made through an
application or printer driver affect only that specific job.
Selecting output bins
This printer has two media output bins. The position of the door to the
rear output bin determines the bin used: If the door to the rear output
bin is open, media is directed to that bin. If it is closed, media is
directed to the top output bin. There are no driver or software options
for selecting an output bin. Figure 3-1 illustrates the top and rear
output bins.
Note
●
The top output bin holds up to 250 sheets of standard paper in
correct order, facing down. When the bin is full, a sensor directs
the printer to stop printing. Printing resumes when you remove
paper from the bin.
●
The rear output bin holds up to 100 sheets of standard paper in
reverse order, facing up. Use this bin when printing on small
media sizes. Because there is no sensor at this output bin, you
should monitor the bin and empty it when it is full.
If the rear output bin is open, duplex printing is not possible. Close the
rear output bin when duplex printing.
When printing on transparencies, close the rear output bin. This causes
the transparencies to be sent to the top output bin and reduces the risk
of jamming.
74
Common printing tasks
EN
1
2
Figure 3-1
Rear view (shown with the optional 500-sheet paper feeder and duplex printing
accessory)
1
Top output bin
2
Rear output bin
Selecting media by type
If you want to select media for your job by type of media rather than by
the input tray (source), you must first configure a printer tray for the
media type you are using, and then specify that media type in the
printer driver.
Selecting media by type rather than source is similar to locking out
trays and helps protect special media from accidental use. For
example, if a tray is configured for letterhead, and you specify in your
driver to print on plain paper, the printer will not pull the letterhead
from that tray. Instead, it will pull from a tray that has plain paper
loaded and that has been configured for plain paper on the printer
control panel.
EN
Chapter 3
75
Configuring input trays
This printer allows you to configure input trays by type and size. This
allows you to load different media types and sizes in the printer’s input
trays and then request media by type or size.
Note
●
When the printer is used as a standalone printer, it might be
beneficial to configure the printer as TRAY 1 MODE=FIRST. In this
mode, if media is loaded in Tray 1 and no other tray is specified,
media will be pulled from Tray 1 regardless of the type or size of
media loaded in the tray.
●
When the printer is used in a network environment, it might be
beneficial to configure Tray 1 as TRAY 1 MODE=CASSETTE. In this
mode, the tray acts as a cassette-style tray and can then be
configured for media type and size.
If using the duplex printing accessory when Tray 1 is in FIRST mode,
be sure that the media loaded meets the specifications for duplex
printing. (See “Supported media weights and sizes” on page 67.)
Configuring Tray 1 as a cassette
Tray 1 is designed to accommodate printing on a variety of media
types.
To configure Tray 1 as a cassette
1
Press MENU until PAPER HANDLING MENU displays.
2
Press ITEM until TRAY 1 MODE displays.
3
Press VALUE until CASSETTE displays.
4
Press SELECT to save the setting.
5
Press ITEM until TRAY 1 SIZE displays.
6
Press VALUE until the proper media size displays.
7
Press SELECT to save the setting.
8
Press ITEM until TRAY 1 TYPE displays.
9
Press VALUE until the proper media type displays.
10 Press SELECT to save the setting.
11 Press GO to return the printer to the READY state.
76
Common printing tasks
EN
Configuring Trays 2 and 3 by media type
Trays 2 and 3 are cassette-style trays. You can select them by media
size and type through your software application or the printer driver.
Note
Tray 2 has an internal media-size sensor and does not need to be
configured on the printer control panel for media size. The media-size
knob on the side of Tray 3 must be set to the correct media size.
To configure Trays 2 or 3
1
Press MENU until PAPER HANDLING MENU displays.
2
Press ITEM until TRAY 2 TYPE (or TRAY 3 TYPE when
configuring Tray 3) displays.
3
Press VALUE until the proper media type displays.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
Tray priority
When all trays have the same size and type media loaded, the printer
pulls media from input trays in the following order:
When Tray 1 is configured as TRAY 1 MODE=FIRST
●
Tray 1
●
Tray 3 (if attached)
●
Tray 2
When Tray 1 is configured as TRAY 1 MODE=CASSETTE
EN
●
Tray 3 (if attached)
●
Tray 2
●
Tray 1
Chapter 3
77
Printing from Tray 1 (multipurpose tray)
Tray 1, the multipurpose tray, can print on all supported sizes and
types of media and envelopes. (See “Supported media weights and
sizes” on page 67.)
Loading media into Tray 1
To load media into Tray 1
1
CAUTION
To avoid jams, never add or remove
media from a tray during printing. To
avoid damaging the printer, place labels
and paper heavier than 105 g/m2 (28 lb
up to 42 lb bond) only in Tray 1.
2
1
Pull up the tray extension.
2
Slide the media-width guides all the
way open.
3
Load media into the tray with the
side to be printed facing the printer.
Slide the media in until it sits
squarely in the bottom of the tray.
3
78
Common printing tasks
EN
4
4
Slide the media-width guides in until
they hold the media firmly in place
without bending it.
Note
For proper paper feeding, custom media
must be at least 76 mm (3 in) wide and
127 mm (5 in) long.
Note
Load prepunched paper with the holes
toward the side of the printer as
illustrated. For two-sided printing, load
media with the front side facing away
from the printer.
EN
Chapter 3
79
Loading envelopes into Tray 1
Envelopes can be printed only from Tray 1. This tray holds up to 10
envelopes. For envelope specifications, see “Supported media
weights and sizes” on page 67.
To load envelopes into Tray 1
1
CAUTION
To avoid jams, do not remove or insert
envelopes during printing.
1
Pull up the tray extension.
2
Slide the media-width guides all the
way open.
3
Load up to 10 envelopes into Tray 1
with their back flap facing away from
the printer. Slide the envelopes in
until they sit squarely in the bottom
of the tray as illustrated.
4
Slide the media-width guides in until
they hold the envelopes firmly in
place without bending them.
2
3
4
80
Common printing tasks
EN
Printing envelopes when TRAY 1 MODE=CASSETTE
For the best results when printing envelopes, Tray 1 should be
configured as TRAY 1 MODE=CASSETTE and the media size should be
set to the size corresponding to the correct envelope size.
Note
1
Set the media size for Tray 1 in the printer control panel. (See
“Configuring Tray 1 as a cassette” on page 76.)
2
Specify Tray 1 or select the media source by size (for example,
COM 10 or DL) in the printer driver.
3
If your software does not automatically format an envelope,
specify Landscape for page orientation in your software
application or printer driver. Use the following guidelines to set
margins for return and destination addresses on Commercial #10
or DL envelopes.
Address Type
Left Margin
Top Margin
Return
15 mm (0.6 in)
15 mm (0.6 in)
Destination
102 mm (4.0 in)
51 mm (2.0 in)
For envelopes of other sizes, adjust the margin settings appropriately.
4
Select Print from the software application or printer driver.
Printing envelopes when TRAY 1 MODE=FIRST
If Tray 1 is configured as TRAY 1 MODE=FIRST (default), select
Tray 1 or use autoselect and then print the file from your software
application or the printer driver. In this mode, the printer will pull
media from the tray regardless of the size and type of media loaded. If
your software does not automatically format an envelope, follow the
instructions provided in the previous section.
EN
Chapter 3
81
Printing from Tray 2
Tray 2 holds up to 250 sheets of standard paper. The tray adjusts for
Letter, Legal, A4, A5, JIS B5, Custom (B5 ISO), and Executive paper.
The printer automatically detects the media size in Tray 2 based on
the tray’s paper guide configuration. (See “Supported media weights
and sizes” on page 67.)
Loading media into Tray 2
To load media into Tray 2
1
CAUTION
Do not print cardstock, labels,
envelopes, or unsupported sizes of
media from Tray 2. These media types
should be printed only from Tray 1.
Do not overfill the input tray. Overfilling
trays can cause jams in the printer.
2
To avoid causing jams, never open the
tray while it is in use.
1
Remove Tray 2 from the printer and
place it on a flat surface.
2
Set the rear media-length guide by
squeezing the guide adjustment
latch and sliding the back of the tray
to the length of media you are
loading.
3
Slide the media-width guides all the
way open by squeezing the release
latch.
3
82
Common printing tasks
EN
4
5
4
Load the media with the print side
facing down into the tray.
5
Verify that the media lies flat in the
tray and that it fits under the metal
tabs.
6
Slide the media-width guides in until
they hold the media firmly in place
without bending it.
7
Insert Tray 2 into the printer.
Note
Load prepunched paper as illustrated.
For two-sided printing, load the media
with the front side facing up.
6
7
EN
Chapter 3
83
Printing from Tray 3 (optional 500-sheet paper
feeder)
The printer supports an optional 500-sheet paper feeder (Tray 3).
Tray 3 attaches to the bottom of the printer and serves as the printer’s
base. When the optional duplex printing accessory is installed, the
duplex unit must be positioned between the printer and the 500-sheet
paper feeder. The printer’s internal sensors detect the presence or
absence of Tray 3, and the printer control panel options automatically
adjust to reflect the current configuration.
Figure 3-2
84
Tray 3 (optional 500-sheet paper feeder)
Common printing tasks
EN
The following are features of the 500-sheet paper feeder (Tray 3):
Note
EN
●
The tray has a capacity of 500 sheets of standard paper. (See
“Supported media weights and sizes” on page 67.)
●
It is adjustable for specific media sizes, with corresponding stop
positions.
●
The printer detects media size based on Tray 3’s physical
configuration and the position of the media-size knob located on
the side of the tray.
●
A user-configurable control panel menu settings identifies the
media type that the printer expects to be loaded in Tray 3.
●
An internal sensor automatically detects when Tray 3 is empty.
●
A paper level indicator is provided on the front face of the tray.
The paper path for the 500-sheet paper feeder passes through Tray 2.
If Tray 2 is partially pulled out or removed, media from the paper feeder
cannot feed into the printer. This causes the printer to go offline and
generates a message that Tray 2 must be installed.
Chapter 3
85
Loading media into Tray 3
Tray 3 adjusts for the following media sizes:
●
●
Letter
● Legal
● A4
JIS B5
● Custom (B5 ISO)
● Executive
The printer automatically detects the media size in Tray 3 based on
the tray’s physical configuration and the position of the media-size
knob.
To load media into Tray 3
1
CAUTION
Do not print cardstock, labels, and
envelopes from Tray 3. This media
should be printed only from Tray 1.
Do not overfill the input tray. Overfilling
trays can cause jams in the printer.
2
3
86
Common printing tasks
1
Remove Tray 3 and place it on a flat
surface.
2
Set the rear media-length guide by
squeezing the release latch and
sliding the guide to the length of
media you are loading.
3
For special-size media, flip up the
special media guide in the center of
the tray.
EN
4
4
Squeezing the release latch, slide
the media-width guides all the way
open.
5
Load the media into Tray 3 with the
print side facing down. Do not overfill
the tray.
6
Slide the media-width guides in until
they hold the media firmly in place
without bending it.
7
Verify that the media lies flat in the
tray and that it fits under the metal
tabs.
5
6
7
EN
Chapter 3
87
8
8
Set the media-size knob on the side
of the tray to the size of the media
loaded in the tray.
9
Insert Tray 3 into the printer.
10 Verify that the printer driver is
configured to recognize Tray 3. (For
instructions, see the online Help for
the printer driver.)
9
Note
Load prepunched paper with holes
toward the side of the tray as illustrated.
For two-sided printing, load media with
the front side facing up.
88
Common printing tasks
EN
Using the optional duplex printing accessory for
two-sided printing
The optional duplex printing accessory (figure 3-3), enables you to
print on both sides of a page. In two-sided printing, known as duplex
printing or duplexing, the back side of the page is printed first. Then
the page is sent through the duplex printing accessory, where it is
flipped over and sent back through the printer for printing on the front.
Note
Although the printer detects the presence of the duplex printing
accessory, you must still specify duplex options in your software
application or in the printer driver in order to print on both sides of the
page.
Figure 3-3
Optional duplex printing accessory
EN
Chapter 3
89
To use the optional duplex printing accessory:
90
●
Be sure that the optional duplex printing accessory is installed
correctly. If the 500-sheet paper feeder (Tray 3) is installed, the
duplex unit must be positioned between the printer and Tray 3.
●
Verify that the printer driver is configured to recognize the duplex
printing accessory. (For instructions, see the online Help for the
printer driver.)
●
Close the door to the rear output bin. The rear output bin is
located at the back of the printer.
●
Select the appropriate duplex options in the printer driver
software. Duplex options include the page and binding
orientation.
●
Duplex printing is not supported for certain media types, including
transparencies, labels, and cardstock.
Common printing tasks
EN
Control panel settings for duplex printing
Many software applications allow you to change duplex printing
settings. If your software application or printer driver does not allow
you to adjust duplex printing settings, you can adjust these settings
through the control panel. Do not leave DUPLEX set to ON if
transparencies or labels are used with the printer or serious damage
may result.
CAUTION
Do not open the door to the rear output bin during duplex printing. Doing
so can cause jams or misprints.
To set duplex printing from the printer control panel
Note
Changing duplex settings through the printer control panel affects all
print jobs. Whenever possible, change duplex settings through your
software application or printer driver.
1
Press MENU until PRINTING MENU displays.
2
Press ITEM until DUPLEX displays.
3
Press VALUE until ON displays.
4
Press SELECT to save the setting.
5
Press ITEM until BINDING displays.
6
Press VALUE to select either LONG EDGE or SHORT EDGE
binding (see figure 3-4).
7
Press SELECT to save the setting.
8
Press GO to return the printer to the READY state.
9
From your software application or printer driver, select duplex
printing if possible.
10 Print the job.
Note
EN
To select duplex printing from the printer driver, the driver must first be
configured to recognize the duplex printing accessory. (For instructions,
see the online Help for the printer driver.)
Chapter 3
91
Options for binding duplex printing jobs
Before printing in duplex mode, decide on which edge you will be
binding your finished document. The binding setup options are:
Figure 3-4
92
●
Long-edge (book) binding, which is the conventional layout used
in book binding. (See 1 in figure 3-4.)
●
Short-edge (tablet) binding, which is the type often used with
calendars. (See 2 in figure 3-4.)
Binding options
1
Long-edge binding
2
Short-edge binding
Common printing tasks
EN
Special printing situations
Use these guidelines when printing on special types of media.
Printing a different first page
Use the following procedure to print the first page of a document on a
different media type than the rest of the document. One example is
printing the first page of a letter on letterhead paper and the rest of
the letter on plain paper.
1
From your application or printer driver, specify a tray for the first
page (letterhead) and another tray for the remaining pages.
2
Load the letterhead into the tray that you specified in step 1.
3
Load the paper for the remaining pages of the document into
another tray.
You can also print on a different first page by using the printer control
panel or printer driver to set the types of media that are loaded in the
trays and then selecting the first and remaining pages by media type.
Printing on custom-size media
The printer supports single-sided printing on custom-size media. Tray
1 supports media sizes from 76 by 127 mm (3 by 5 in) to 216 by
356 mm (8.5 by 14 in), including B5 ISO. The only custom size
supported by Trays 2 and 3 is B5 ISO.
When printing on custom-size media, if Tray 1 is configured in the
printer control panel as TRAY 1 MODE=CASSETTE, you must set the
media size for Tray 1 to CUSTOM in the printer control panel. If Tray 1 is
configured as TRAY 1 MODE=FIRST, the printer will print on whatever
media is loaded in the tray. When printing on custom size (B5 ISO)
media from Trays 2 or 3, adjust the paper guides on the tray to the
Custom (B5 ISO) marking.
Some software applications and printer drivers allow you to specify
custom paper-size dimensions. Be sure to set the correct paper size
in both the page setup and print dialog boxes.
If your software application requires you to calculate margins for
custom-size paper, see the online Help for that application.
EN
Chapter 3
93
Stopping a print request
You can stop a print request either from the printer control panel or
from your software application. To stop a print request from a
computer on a network, see the online Help for the specific network
software.
Note
It may take some time for all printing to clear after a print job is canceled.
To stop the current print job from the printer control
panel
Press CANCEL JOB on the printer control panel to cancel the job that is
currently printing. Pressing CANCEL JOB does not affect subsequent
print jobs that are stored in the printer buffer.
To stop the current print job from your software
application
If several requests have been sent to the printer through your
software, they may be waiting in a print queue (in Windows Print
Manager, for example). See your software documentation for specific
instructions on canceling a print request from the computer.
94
Common printing tasks
EN
Job retention features
To use the Job retention features listed below, you must install a hard
disk in the printer and properly configure the printer drivers. All Job
retention features are selected in the printer driver. Some Job
retention features require you to use the printer control panel menus
to release the print job.
CAUTION
Make sure to identify your jobs in the printer driver before printing. Using
default names may override previous jobs with the same default name
or cause the job to be deleted.
Note
Adding additional printer memory may resolve memory problems,
improve how the printer handles complex graphics, and improve
download times, but will not increase maximum printer speed (ppm
rating).
Quick copying a job
The quick copy feature prints the requested number of copies of a job
and stores a copy on the printer’s hard disk. Additional copies of the
job can be printed later. This feature can be turned off from the driver.
For more information about specifying the number of quick copy jobs
that can be stored, see the QUICK COPY JOBS control panel item
described on page 47.
Printing additional copies of a quick copy job
To print additional copies of a job stored on the printer’s hard disk
from the control panel:
Note
EN
1
Press MENU repeatedly until QUICK COPY JOBS MENU appears.
2
Press ITEM until the desired user or job name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. COPIES=1 appears.
4
Press - VALUE + until the desired number of copies appears.
5
Press SELECT to print the job.
Chapter 3
95
Deleting a stored quick copy job
When a user sends a quick copy job, the printer overwrites any
previous jobs with the same user and job name. If there is not a quick
copy job already stored under the same user and job name and the
printer needs additional space, the printer may delete other stored
quick copy jobs starting with the oldest job. The default number of
quick copy jobs that can be stored is 32. The number of quick copy
jobs that can be stored is set from the control panel (see page 47).
Note
If you turn the printer off and then back on, all quick copy, proof and
hold, and private jobs are deleted.
A stored quick copy job can also be deleted from the control panel.
Note
96
1
Press MENU repeatedly until QUICK COPY JOBS MENU appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. COPIES=1 appears.
4
Press - VALUE until DELETE appears.
5
Press SELECT to delete the job.
Common printing tasks
EN
Proofing and holding a job
The proof and hold feature provides a quick and easy way to print and
proof one copy of a job and then print the additional copies.
To permanently store the job and prevent the printer from deleting it
when space is needed for something else, select the Stored Job
option in the driver.
Printing the remaining copies of a held job
The user can print the remaining copies of a job held on the printer’s
hard disk from the control panel.
Note
EN
1
Press MENU repeatedly until QUICK COPY JOBS MENU appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. COPIES=1 appears.
4
Press - VALUE + until the desired number of copies appears.
5
Press SELECT to print the job.
Chapter 3
97
Deleting a held job
When a user sends a proof and hold job, the printer automatically
deletes that user’s previous stored proof and hold job. If there is not a
proof and hold job already stored for that job name and the printer
needs additional space, the printer may delete other stored proof and
hold jobs starting with the oldest one.
Note
Note
98
If you turn the printer off and then back on, all quick copy, proof and
hold, and private jobs are deleted. A stored proof and hold job can also
be deleted from the control panel.
1
Press MENU repeatedly until QUICK COPY JOBS MENU appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. COPIES=1 appears.
4
Press - VALUE until DELETE appears.
5
Press SELECT to delete the job.
Common printing tasks
EN
Printing a private job
The private printing feature lets a user specify that a job is not printed
until that user releases it using a 4-digit personal identification
number (PIN) through the printer control panel. The user specifies the
PIN in the driver and it is sent to the printer as part of the print job.
Specifying a private job
To specify that a job is private from the driver, select the Private Job
option in the printer driver and type a 4-digit PIN.
Releasing a private job
The user can print a private job from the control panel.
Note
EN
1
Press MENU repeatedly until PRIVATE/STORED JOBS MENU
appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT PIN:0000 appears.
4
Press - VALUE + to change the first number of the PIN, and then
press SELECT. An * appears in place of the number. Repeat these
steps to change the remaining three numbers of the PIN.
COPIES=1 appears.
5
Press - VALUE + until the desired number of copies appears.
6
Press SELECT to print the job.
Chapter 3
99
Deleting a private job
A private job is automatically deleted from the printer’s hard disk after
the user releases it for printing, unless the user selects the Stored Job
option in the driver.
Note
If you turn the printer off and then back on, all quick copy, proof and
hold, and private jobs are deleted.
A private job can also be deleted from the printer control panel before
it is ever printed.
Note
100
1
Press MENU repeatedly until PRIVATE/STORED JOBS MENU
appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. PIN:0000 appears.
4
Press - VALUE + to change the first number of the PIN, and then
press SELECT. An * appears in place of the number. Repeat these
steps to change the remaining three numbers of the PIN.
COPIES=1 appears.
5
Press - VALUE until DELETE appears.
6
Press SELECT to delete the job.
Common printing tasks
EN
Storing a print job
The user can download a print job to the printer’s hard disk without
printing it. The user can then print the job at any time through the
printer control panel. For example, a user may want to download a
personnel form, calendar, time sheet, or accounting form that other
users can access and print.
To store a print job permanently on the hard disk, select the Stored
Job option in the driver when printing the job.
Printing a stored job
The user can print a job stored on the printer’s hard disk from the
control panel.
Note
EN
1
Press MENU repeatedly until PRIVATE/STORED JOBS MENU
appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job name. COPIES=1 appears.
4
Press - VALUE + until the desired number of copies appears.
5
Press SELECT to print the job.
Chapter 3
101
Deleting a stored job
Jobs stored on the printer’s hard disk can be deleted from the control
panel.
Note
102
1
Press MENU repeatedly until PRIVATE/STORED JOBS MENU
appears.
2
Press ITEM until the desired user name appears.
If you are using a Macintosh computer, the user name appears on the
first line of the display and the job name appears on the second line of
the display. After you have selected the desired user name using ITEM,
press VALUE until the desired job name appears.
3
Press SELECT to select the job. COPIES=1 appears.
4
Press - VALUE until DELETE appears.
5
Press SELECT to delete the job.
Common printing tasks
EN
Printing with the optional HP Fast InfraRed
Receiver
The HP Fast InfraRed Receiver enables wireless printing from any
IrDA-compliant portable device (such as a laptop computer) to the
HP Color LaserJet 4550, 4550N, 4550DN, or 4550HDN printer.
The printing connection is maintained by positioning the sending
infrared (FIR) port within operating range. Note that the connection
can be blocked by objects such as a hand, paper, direct sunlight, or
any bright light shining into either FIR port.
Note
For more information, see the user guide that came with the HP Fast
InfraRed Receiver.
Setting up to print with Windows 9x/NT
Before launching the InfraRed Driver, complete the following steps:
1
From the Printers folder, select the HP Color LaserJet 4550,
4550N, 4550DN, or 4550HDN as your default printer.
2
Choose Properties/Details for the HP Color LaserJet 4550,
4550N, 4550DN, or 4550HDN printer, and make sure that Virtual
Infrared LPT Port is selected.
3
Select the file to print.
Printing a job
1
Align your laptop computer (or other portable device equipped
with an IrDA-compliant FIR window) within 2 to 3 feet (1 meter)
maximum of the HP Fast InfraRed Receiver. The FIR window
angle must be within +/- 15 degrees to ensure an effective
connection for printing.
2
Print the job. The status indicator on the HP Fast InfraRed
Receiver lights up, and, after a short delay, the printer status
panel displays PROCESSING JOB.
If the status indicator does not light up, realign the HP Fast InfraRed
Receiver with the FIR port on the sending device, resend the print job,
and maintain the alignment of all devices. If you have to move the
equipment (for example, to add paper), make sure that all devices
remain within the range of operation to maintain the connection.
EN
Chapter 3
103
If the connection is interrupted before your print job is complete, the
HP Fast InfraRed Receiver status indicator turns off. You have up to
40 seconds to correct the interruption and continue the job. If the
connection is resumed within this time, the status indicator lights up
again.
Note
The connection is permanently broken if the sending port is moved out
of operating range or if anything passing between the ports blocks
transmission for more than 40 seconds. (This block could be a hand,
paper, or even direct sunlight.) Depending on the size of the job, printing
with the HP Fast InfraRed Receiver may be slower than printing with a
cable connected directly to the parallel port.
Interrupting and resuming printing
The job interrupt and resume feature lets a user temporarily stop a job
that may be currently printing in order to print another job using the
FIR port. When the new job is finished printing, the interrupted job
resumes printing.
A user can only interrupt jobs that are printing and collating multiple
copies by connecting to the infrared (FIR) port on the printer and
sending a job to the printer. The printer stops printing the current job
when it reaches the end of the copy it is printing. The printer then
prints the job sent over the FIR connection. When the printer is done
printing that job, it resumes printing the original job with multiple
copies where it left off.
104
Common printing tasks
EN
4
Using color
Overview
The HP Color LaserJet 4550 series printer, through a
combination of great technology and excellent engineering, offers
great color right out of the box. It provides a powerful blend of
automatic color features to generate superb color results.
This chapter explains the following topics:
EN
●
Matching colors
●
HP ColorSmart II
●
Four-color printing (CMYK)
●
Matching PANTONE®* colors
Chapter 4
105
Matching colors
The process of matching printer output color to your monitor is quite
complex because printers and computer monitors use different
methods of producing color. Monitors display colors by light pixels
using an RGB (red, green, blue) color process, but printers print
colors using a CMYK (cyan, magenta, yellow, and black) process.
Several factors can influence your ability to match printed colors to
those on your monitor. These factors include:
●
Print media
●
Printer colorants (inks or toners for example)
●
Printing process (inkjet, press or laser technology for example)
●
Overhead lighting
●
Personal differences in perception of color
●
Software applications
●
Printer drivers
●
PC operating system
●
Monitors
●
Video cards and drivers
For most users, the best method for matching colors on your screen
to your printer is to print sRGB colors. The HP Color LaserJet 4550
uses HP ColorSmart II, which uses sRGB and automatically
optimizes color output. Keep in mind the above factors when colors
on your screen do not perfectly match your printed colors.
106
Using color
EN
HP ColorSmart II
HP ColorSmart II is a set of technologies that enables optimal color
output automatically for diverse types of documents.
HP ColorSmart II utilizes object tagging and Standard RGB (sRGB)
color technologies. Object tagging allows optimal color and halftone
settings to be used for different objects on a page (text, graphics and
photos). The printer analyzes the page (what objects it contains) and
intelligently uses halftone and color settings that provide the best print
quality for each object. Object tagging, combined with optimized
default settings, produces great color out of the box.
In the Windows environment, you will find the HP ColorSmart II
Automatic and Manual settings on the Color tab in the printer driver.
Color management options
Print in Grayscale
Selecting the Print in Grayscale option from your printer driver prints
your document in black and white. This option is useful for previewing
preliminary copies of slides and hardcopy output quickly for color
document that will be photocopied or faxed.
Automatic color adjustment
The Automatic color adjustment feature of HP ColorSmart II (the
default setting) optimizes the color and halftones used for each
element in a document. Automatic also provides additional color
options for application and operating systems that support color
management systems. For more information, see your printer driver
online Help.
Note
EN
Automatic is the default setting and is recommended for printing all
color documents.
Chapter 4
107
Manual color adjustment
The Manual color adjustment feature of HP ColorSmart II allows you
to adjust the color and halftone modes for text, graphics and
photographs. To access the Manual color options from the Color tab,
select Manual, then Options.
Halftone options
Halftone options affect the resolution and clarity of your color output.
You can select halftone settings for text, graphics, and photos
independently. The two halftone options are Smooth and Detail.
●
The Smooth option provides better results for large, solid-filled
print areas. It also enhances photos by smoothing out fine color
gradations.
●
The Detail option is useful for text and graphics that require sharp
distinctions among lines or colors, or images that contain a
pattern or a high level of detail.
Color map
The color map settings in the printer driver tell the printer how to
interpret the data sent from a software application into the final colors
that the printer will output. The color map settings can be adjusted to
Screen match or Vivid.
●
Screen Match (sRGB — standard red-green-blue) prints colors
that are optimized to match RGB monitor colors. Use this setting
to more closely match the colors on your screen.
sRGB is a world-wide color standard originally developed by HP
and Microsoft as a common color language for monitors, input
devices (scanners, digital cameras), and output devices (printers,
plotters). It is the default color space used for HP products,
Microsoft Operating Systems, the World Wide Web, and most
office software sold today. sRGB is representative of the typical
Windows PC monitor today and the convergence standard for
High-Definition Television.
Note
108
Factors such as the type of monitor you use and the room’s lighting can
affect the appearance of colors on your screen. For more information,
see the “Matching colors” section earlier in this chapter.
Using color
EN
The latest versions of Adobe PhotoShop, CorelDRAW™,
Microsoft Office, and many other applications use sRGB to
communicate color. Most importantly, as the default color space
in Microsoft Operating Systems, sRGB has gained broad
adoption as a means to exchange color information between
applications and devices using a common definition that assures
typical users will experience greatly improved color matching.
sRGB combined with HP ColorSmart II improves the user's ability
to match colors between the printer, the PC monitor and also
other input devices (scanner, digital camera) automatically,
without the need to become color experts.
●
EN
Vivid enhances the saturation of the printed colors to produce a
vivid color appearance. For more information, see your printer
driver online Help.
Chapter 4
109
Four-color printing (CMYK)
Cyan, magenta, yellow and black (CMYK) are the inks used by a
printing press. It is often called four-color printing. CMYK data files
are typically used by and originate from graphic arts (printing and
publishing) environments. The HP Color LaserJet 4550 series printer
is optimized to print RGB colors for a good match to the screen, but
will also accept CMYK colors through the PostScript printer driver.
By default, the HP Color LaserJet 4550 series printer interprets
CMYK data according to the Standard Web Offset Press (SWOP)
standard. This standard defines how a particular set of CMYK inks
should behave. The printer performs a SWOP color map and internal
half-tones to emulate a SWOP CMYK press. Emulations for
Dainippon Press (DIC) and Euro-standard CMYK inks used in the
Far East and Europe are also available, and can be selected from the
printer driver.
110
Using color
EN
Matching PANTONE®* colors
The PANTONE® * Matching System colors are specified as CMYK
colors as supported in many graphics software applications. This
color-matching system is useful for matching printer output to a
specific color (for example, a logo). See the documentation for your
software application for instructions on using PANTONE® * colors.
For more information on using PANTONE® * colors, see the Readme
file for the PANTONE® * color-matching system included on the
printing system CD-ROM.
Note
Color settings, halftone settings, and print media affect the appearance
of PANTONE® * colors. To optimize PANTONE® *-certified colors, use
the default PostScript 3 emulation driver settings and HP LaserJet
paper.
Automatic PANTONE®* calibration
Automatic PANTONE® * calibration generates high-quality
PANTONE® * colors from the PANTONE® * color name automatically,
providing the best possible color calibration in the HP Color LaserJet
4550 printers. An example of a PANTONE® * name is: PANTONE® *
286CVC. When printing PANTONE® colors, Automatic PANTONE® *
calibration is the default setting for HP Color LaserJet 4550 printers.
This feature automatically converts PANTONE® * colors to optimal
color values for the HP Color LaserJet 4550 using the PANTONE® *
color name in the data stream sent to the printer.
Most application programs that support the use of PANTONE® * colors
for graphic objects will include the PANTONE® *name in the
PostScript output, along with the color values assigned to the object.
The HP Color LaserJet 4550 printer will recognize the PANTONE® *
name and substitute the optimum color values for the printer based
on color tables developed to provide the best possible match for each
specific PANTONE® * color within the printer’s color gamut.
No special actions are necessary in the application program or the
driver to enable this feature. You have the option of turning off
Automatic PANTONE® * calibration if you want to use applicationgenerated color values rather than HP-generated color values.
EN
Chapter 4
111
To turn off Automatic PANTONE®* calibration
●
In Windows, go to Properties, Advanced, and then Printer
Features.
●
On a Macintosh, go to the CMYK Inks page of the driver
interface.
Applications known to generate PostScript files with graphic objects
preserving the PANTONE® * name are listed below:
Note
●
Adobe Illustrator 7 and 8
●
Adobe PageMaker 6.5
●
CorelDRAW 7, 8, and 9
●
Deneba Canvas 5*
●
Macromedia Freehand 7 and 8
●
Micrografx Designer
●
QuarkXpress 3 and 4
*Subsequent versions of Deneba Canvas no longer generate
compatible PANTONE® * names
Microsoft Publisher 2000 adds support for PANTONE® * colors but does
not preserve the PANTONE® * name necessary for this feature to work.
The Automatic PANTONE® * calibration feature only applies to
vector graphics, not picture (raster) data such as scanned images and
TIFF files. Adobe PhotoShop® , for example, being a raster image
editor, is not on the above list of applications that support the
Automatic PANTONE® * calibration feature.
WWW
PANTONE® * palettes for some raster image editor applications, such
as Adobe PhotoShop, are available on the Web at
http://www.hp.com/support/lj4550.
Once connected, select Downloads and Drivers. ICC color profiles,
sRGB color swatches, and printer drivers are also available at this Web
address.
112
Using color
EN
PANTONE® * Application Palettes are available for:
●
Adobe Illustrator 4–8
●
PageMaker 5, 6, and 6.5
●
PhotoShop 3–5.5
●
CorelDRAW 6–9
●
Micrographics Designer 6–7
●
Macromedia Freehand 4–8
●
QuarkXpress (as EPS files) 3.3–4.04
●
Deneba Canvas 3.5–6.1
●
Fractal Design Painter 2–5.5
●
EPSF Charts
●
TIFF Charts
●
PANTONE® * Color Drive
●
Text Format (ASCII)
●
Raw PostScript File
●
Adobe Acrobat
Vector graphics such as company logos created in one of the above
applications (using palettes or applications preserving the
PANTONE® * name) can be imported into Microsoft Word, PowerPoint
or other MS Office applications. To do this, the color application must
create an Encapsulated PostScript (EPS) file of the image for
insertion as a file into the Office document using the insert file
function.
Note
EN
Cutting and pasting from the clipboard will not work. These tasks do
not preserve the PANTONE® * name or the CMYK palette value.
Chapter 4
113
Some of the PANTONE® * colors will not match exactly. There are over
945 PANTONE® * colors in the PANTONE® * Matching System. These
colors were created using sixteen inks on a lithographic printing
press. Not all of these colors are reproducible by a laser color printer
because they are out of a laser printer's 4-color range (gamut).
PANTONE® * calibrates HP printers to provide the closest match for all
the colors we can reproduce and provide the colors closest to those
we cannot reproduce.
Note
114
This feature requires the use of the PostScript 3 Emulation printer
driver. It utilizes a function in the PostScript language for describing
custom colors like PANTONE® * that is unique to PostScript and not
present in the PCL data stream. PANTONE® * colors are used mostly
in publishing environments by applications such as QuarkXpress and
Adobe InDesign that tend to use PostScript only.
Using color
EN
5
Using fonts
Overview
This chapter provides information on various fonts. The chapter
includes the following sections:
EN
●
Using internal TrueType fonts
●
Understanding printer default fonts
●
Selecting fonts
●
Printing a list of available printer fonts
●
Using fonts in PostScript Emulation
●
Using fonts on a network
●
Adding support for accessory fonts to a printer driver
●
Using special type effects
●
Hewlett-Packard custom font services
Chapter 5
115
Using internal TrueType fonts
TrueType is a font format developed jointly by Microsoft Corporation
and Apple Computer, Inc. Hewlett-Packard has included 80 TrueType
fonts with this printer, and matching screen fonts for use within
Windows.
You do not need to download these TrueType fonts because they are
already installed in your printer. The printer driver automatically uses
internal fonts when it can. This results in increased printing
performance.
See the Microsoft Windows documentation for specific instructions on
using TrueType fonts with Windows.
116
Using fonts
EN
Understanding printer default fonts
The default font for this printer is 12-point Courier in the PC-8 symbol
set. The printer uses the default font only if another font has not been
specified.
Changing the default font
You can select a different default font from the printer control panel.
See “Selecting PCL fonts through the printer control panel” on
page 119.
Selecting a font other than the default
●
You can request a font from within most software applications.
●
You can send a PCL printer command requesting a font different
from the default. For information on printer PCL commands, see
Appendix B or the PCL/PJL Technical Reference Package for this
printer. (See page 32 for ordering information.)
Font selection priority
The printer selects printer fonts in the following order:
1
soft fonts (downloaded fonts)
2
fonts on DIMMs
3
internal fonts
In order to select a font, the font must be available from one of these
sources. If the font you request is not available, the printer selects the
closest match based on individual font characteristics (PCL only).
EN
Chapter 5
117
Selecting fonts
You can select fonts either from a software application or through the
printer control panel.
Note
A font request from a software application or printer driver overrides
font settings in the printer control panel.
Selecting fonts from software applications
For information on changing font selection, base font, printer setup,
print options, and font appearance from a software application, see
the documentation for your application.
Selecting symbol sets
If you want to print a symbol such as Ω while the printer is in
PCL mode, you must first select the symbol set that contains that
character. See the PCL/PJL Technical Reference Package for a
complete listing of available symbol sets and printer commands. (See
page 32 for ordering information.)
Symbol set availability
Many software applications allow you to specify a symbol set from the
printer setup menu. You should consider two things when using
symbol sets:
●
Software applications may not support all of the printer’s symbol
sets.
●
Typefaces are designed to work with specific symbol sets.
Entering symbols into text
The documentation for your software application should contain
instructions for entering special symbols into text. See the
documentation’s index for phrases such as compose feature,
composite characters, symbol sets, character sets, code pages, and
extended characters.
118
Using fonts
EN
Selecting PCL fonts through the
printer control panel
If your software application does not allow you to select fonts through
its menus, you can select PCL (TrueType) fonts through the printer
control panel. Only one font can be selected for a particular print job.
Note
A font selected through the printer control panel becomes the default
font for all subsequent print jobs.
You must specify several items when selecting a font through the
printer control panel. These items are listed on the printer’s font page
and include:
Note
EN
●
the font source
●
the font number
●
the point size or pitch
●
a symbol set
A font request from a software application overrides font settings in the
printer control panel.
Chapter 5
119
To select PCL default fonts through the printer control
panel
1
Print a list of available PCL printer fonts. (For instructions, see
“Printing a list of available printer fonts” on page 121.)
2
On the printed font list, locate the font source and number that
correspond to the font you wish to use.
3
Press MENU until PRINTING MENU displays.
4
Press ITEM until PCL FONT SOURCE displays.
5
Press VALUE until the font source displays. The following sources
are available:
• INTERNAL
• SOFT
• DIMM SLOT n (n = 1,2,3)
6
Press SELECT to save your selection. An asterisk (*) appears next
to your selection.
7
Press ITEM until PCL FONT NUMBER displays.
8
Press VALUE until the correct font number displays.
9
Press SELECT to save your selection. An asterisk (*) appears next
to your selection.
10 Press ITEM until PCL FONT POINT SIZE displays (or, for
proportional fonts, until PITCH displays). This selection is not
available for bitmapped fonts.
11 Press VALUE until the correct point size or pitch displays.
12 Press SELECT to save your selection. An asterisk (*) appears next
to your selection.
13 Press GO to return the printer to the READY state.
120
Using fonts
EN
Printing a list of available printer fonts
You can use the Information Menu on the printer control panel to print
a list of available fonts.
To print a list of available fonts
Note
1
Press MENU until INFORMATION MENU displays.
2
Press ITEM until PRINT FONT LIST displays.
3
Press SELECT to print the font list.
4
After the list has printed, the printer returns to the READY state.
Temporary soft fonts (fonts that your software downloaded for a specific
document) do not appear on the printout. Permanent soft fonts do
appear on the printout.
The font list displays all available typefaces for installed cards
(DIMMs), permanent downloaded soft fonts, and internal fonts.
Figure 5-1
EN
Font list
Chapter 5
121
Interpreting the font lists
The PCL font list displays samples of available fonts. The following is
a description of the elements of the font list:
1
Font
The name of the typeface family.
2
Pitch/Pt
Pitch indicates the number of characters per inch of a fixed-space
font. Point Size is the height of the font, measured in points, and
is used to describe scalable fonts.
3
ESC Sequence
Escape Sequence (a PCL command) is used to select the
designated font. Fill in Pitch or Point Size and Symbol Set in the
boxes as required. The escape sequence contains a shaded box
followed by “v” or “h.” This indicates that you must enter the point
size (for example, 14.25v) or pitch (for example, 12.00h).
4
Font #
The number you use to select internal or downloaded soft fonts
from the control panel. The source of the font is also listed.
Note: Do not confuse the font number with the soft font ID.
5
Font ID
The identification number you assign to soft fonts when you
download them through your software.
See the PCL/PJL Technical Reference Package for instructions on
downloading fonts. (See page 32 for ordering information.)
The font list for PostScript Emulation displays all fonts installed in the
printer’s firmware. Although the characters are listed in only one size,
you can scale the typefaces to any size.
122
Using fonts
EN
Using fonts in PostScript Emulation
The printer is configured with 80 scalable fonts that are available for
PCL and PostScript Emulation. The printing system installer on the
CD-ROM installs 80 fonts on your PC for use by any software
application.
EN
Chapter 5
123
Using fonts on a network
Consult with your network administrator or with other network users
before using the printer control panel to change the default font and
before downloading or removing soft fonts and typefaces.
To conserve memory and avoid unexpected printer output, use the
guidelines that follow. Your network operating system might
automatically protect each user’s print job from the effects of other
print jobs in the network. Consult a network administrator for more
information.
Guidelines for printing with different fonts
124
●
The 80 internal fonts are available in PostScript Emulation (PS)
and PCL mode.
●
To conserve printer memory, download only those fonts that are
needed.
●
If you require several downloaded fonts, consider installing
additional printer memory.
●
Some software applications automatically download fonts at the
beginning of each print job. It might be possible to configure those
applications to download only soft fonts that are not already
resident in the printer. See your software application’s
documentation for more information.
Using fonts
EN
Adding support for accessory fonts to a printer
driver
When you are using typefaces on DIMMs, your printer driver will
require information about the size, shape, and style of the type
characters so that it can format your text correctly.
Using special type effects
The printer can create special type effects, such as patterns, reverse
printing, mirrored text, and font rotation. See the user guide for your
application to verify that the application supports these features.
Developers can find complete instructions for using special type
effects in the PCL Technical Reference Package. (See page 32 for
ordering information.)
EN
Chapter 5
125
Hewlett-Packard custom font services
Hewlett-Packard offers fonts on disk, cartridge, or DIMMs. You can
design a custom font package to fit your particular needs. The items
below are examples of available custom fonts:
●
fonts or typefaces from any Hewlett-Packard standard font
product or typeface collection
●
bar codes, including 3 of 9, 128, Interleaved 2 of 5, UPC, USPS
Zip, and others
●
custom symbol set mappings
●
signatures and logos
For custom fonts (such as signature fonts and logos) and also
discontinued font products (such as Barcodes & More, Tax 1, and
Pro Collection), contact:
Hewlett-Packard LaserJet Font Solutions
(541) 715-5757
Outside the U.S., contact your local HP dealer.
126
Using fonts
EN
6
Printer Interfaces
Overview
This chapter provides information on available printer interfaces.
The chapter includes the following sections:
EN
●
Parallel configuration
●
Enhanced I/O (EIO) configuration
●
Configuring the printer for the network at the printer control
panel
Chapter 6
127
Parallel configuration
If your printer is not configured with a network interface card, connect
the printer to your computer using a bidirectional parallel cable
(IEEE-1284C compliant) with a “C” connector (see figure 6-1)
plugged into the printer’s parallel port. The cable can be a maximum
of 10 meters (30 feet) long. For ordering information, see “Printer
supplies and accessories” on page 31.
When used to describe a parallel interface, the term bidirectional
indicates that the printer is able to both receive data from the
computer and to send data to the computer through the parallel port.
Figure 6-1
Parallel cable “C” connector
Note
To use the enhanced capabilities of the bidirectional parallel interface,
such as bidirectional communication between the computer and printer,
faster transfer of data, and automatic configuration of printer drivers,
your printer driver must support these capabilities.
When you are using multiple ports, you can adjust automatic I/O
switching to maximize performance by using the timeout feature. If
data from other ports appears in the middle of your print job, increase
the I/O Timeout value. (See “Setting the I/O timeout” on page 61.)
128
Printer Interfaces
EN
Enhanced I/O (EIO) configuration
This printer comes equipped with two enhanced input/output (EIO)
slots. These slots hold compatible external devices such as the
HP JetDirect print server network cards. Plugging EIO network cards
into the slots increases the number of network interfaces available to
the printer.
EIO network cards can maximize printer performance when you are
printing from a network. In addition, they provide the ability to place
the printer anywhere on a network. This eliminates the need to attach
the printer directly to a server or a workstation and enables you to
place the printer closer to your network users.
The printer control panel will have an additional menu (EIO Menu) if
the printer is configured with EIO network cards.
HP JetDirect print servers
HP JetDirect print servers (network cards) can be installed in one of
the printer’s EIO slots. These cards support multiple network
protocols and operating systems. HP JetDirect print servers facilitate
network management by allowing you to connect a printer directly to
your network at any location. HP JetDirect print servers also support
the Simple Network Management Protocol (SNMP), which provides
network managers with remote printer management and
troubleshooting through HP Web JetAdmin software.
Note
EN
Installation of these cards and network configuration should be
performed by a network administrator.
Chapter 6
129
Available enhanced I/O interfaces
HP JetDirect print servers (network cards) provide software solutions
for:
WWW
●
Novell NetWare
●
Microsoft Windows and Windows NT networks
●
Apple Mac OS (LocalTalk)
●
UNIX (HP-UX and Solaris)
●
Linux (Red Hat and SuSE)
●
Internet printing
For a summary of available network software solutions refer to the
HP JetDirect Print Server Administrator’s Guide, or visit HP Customer
Care online at http://www.hp.com/support/net_printing.
NetWare networks
When using Novell NetWare products with an HP JetDirect print
server, Queue Server Mode provides improved printing performance
over Remote Printer Mode. The HP JetDirect print server supports
Novell Directory Services (NDS) as well as bindery modes. For more
information, see the HP JetDirect Print Server Administrator’s Guide.
For Windows 9x, Windows NT 4.0, and Windows 2000 systems, use
your printer installation utility for printer setup on a NetWare network.
Windows and Windows NT networks
For Windows 9x, Windows NT 4.0, and Windows 2000 systems, use
your printer installation utility for printer setup on a Microsoft Windows
network. The utility supports printer setup for either peer-to-peer or
client-server network operation.
130
Printer Interfaces
EN
AppleTalk Networks
Use the HP LaserJet Utility to set up your printer on an EtherTalk or
LocalTalk network. For more information, refer to the HP JetDirect
Print Server Administrator’s Guide included with the printers equipped
with the HP JetDirect print server.
LocalTalk configuration
The LocalTalk interface enables you to print directly from a
standalone Apple Macintosh computer or from a Macintosh computer
on a LocalTalk network. For specific information on configuring your
computer and printer to print through a LocalTalk interface, refer to
the printer’s getting started guide and the HP JetDirect Print Server
Administrator’s Guide.
Macintosh DIN-8 cable
To connect a Macintosh computer directly to this printer, use a
standard Macintosh DIN-8 printer cable. This cable cannot be used in
a network configuration.
Note
For LocalTalk configuration, the DIN-8 printer cable must be plugged
into the printer port of your Macintosh computer.
LocalTalk network configuration
To connect the printer to a Macintosh computer on a LocalTalk
network, use the HP LocalTalk Cable Kit. You will need a kit for each
printer and an additional kit for each Macintosh computer on your
network.
EN
Chapter 6
131
UNIX/Linux networks
Use the HP JetDirect printer installer for UNIX utility to set up your
printer on HP-UX or Sun Solaris networks.
For installation and management on UNIX or Linux networks, use
HP Web JetAdmin.
WWW
To obtain HP software for UNIX/Linux networks, visit the HP Customer
Care online at http://www.hp.com/support/net_printing. For other
installation options supported by the HP JetDirect print server, refer to
the HP JetDirect Print Server Administrator’s Guide included with the
printers equipped with the HP JetDirect print server.
Setting network security on the printer
This printer features control panel locking which allows network
administrators to prevent users from changing certain settings in the
printer control panel. When a menu of the printer control panel is
locked, unauthorized users trying to change printer control panel
settings will receive the following message:
ACCESS DENIED
MENUS LOCKED
You can use the HP Web JetAdmin software, the HP LaserJet Utility
for Macintosh, or an ASCII escape sequence to perform this
procedure. For instructions on locking the printer control panel using
either the HP Web JetAdmin software or the HP LaserJet Utility for
Macintosh, see their online Helps.
132
Printer Interfaces
EN
Configuring the printer for the network
at the printer control panel
You might need to configure certain network parameters on the
printer. You can configure these parameters from the printer control
panel, the embedded Web server, or for most networks, from the
HP Web JetAdmin software (or the HP LaserJet Utility for Macintosh).
The utilities are provided on the printing software CD-ROM that
comes with the printer.
Note
The embedded Web server is a new printer feature from HP. For more
information about using the embedded Web server, see Appendix E.
For a complete list of supported networks and for instructions on
configuring network parameters from software such as the HP Web
JetAdmin software, see the HP JetDirect Print Server Administrator’s
Guide. The guide comes with printers in which an HP JetDirect print
server is installed.
This section contains the following instructions for configuring
network parameters from the printer control panel:
●
configuring Novell NetWare frame type parameters
●
configuring TCP/IP parameters
●
configuring the Apple EtherNet phase parameters
●
disabling unused network protocols
Configuring Novell NetWare frame type
parameters
The HP JetDirect print server automatically selects a NetWare frame
type. Select a frame type manually only when the print server selects
an incorrect frame type. To identify the frame type chosen by the
HP JetDirect print server, print a configuration page from the printer
control panel.
EN
Chapter 6
133
To configure the Novell NetWare parameters from the
printer control panel
1
Press MENU until HP EIO 1 or 2 MENU displays.
2
Press ITEM until CFG NETWORK=NO displays.
3
Press VALUE until CFG NETWORK=YES displays.
4
Press SELECT once. CFG NETWORK=YES displays.
5
Press ITEM until CFG IPX/SPX=NO displays.
6
Press VALUE until CFG IPX/SPX=YES displays.
7
Press SELECT once. CFG IPX/SPX=YES displays.
8
Press ITEM until FRAME=AUTO displays.
9
To configure the frame type setting protocol, press VALUE to select
one of the frame types from the following table:
Frame type
Description
AUTO (default)
All listed Novell frame types will be allowed.
EN_8023
Limits frame types to IPX over IEEE 802.3 frames.
All others will be counted and discarded.
EN_II
Limit frame types to IPX over Ethernet II frames.
All others will be counted and discarded.
EN_8022
Limit frame types to IPX over IEEE 802.2 with
Ethernet frames. All others will be counted and
discarded.
EN_SNAP
Limit frame types to IPX over SNAP with Ethernet
frames. All others will be counted and discarded.
10 Press SELECT to save the value. An asterisk (*) displays.
11 If you are finished, press GO to return the printer to the READY
state.
– OR –
See the appropriate sections for other protocols that will be used.
134
Printer Interfaces
EN
Configuring TCP/IP parameters
You can use the printer control panel to configure the following
TCP/IP parameters:
Note
●
usage of the BOOTP file for configuration parameters (the default
is to use the BOOTP file)
●
IP address (4 bytes)
●
subnet mask (4 bytes)
●
default gateway (4 bytes)
●
TCP/IP connection timeout (in seconds)
Do not disable BOOTP if you will be using RARP or DHCP to configure
TCP/IP parameters.
To configure TCP/IP parameters from the printer
control panel
EN
1
Press MENU until HP EIO 1 or 2 MENU displays.
2
Press ITEM until CFG NETWORK=NO * displays.
3
Press VALUE until CFG NETWORK=YES displays.
4
Press SELECT once. CFG NETWORK=YES * displays.
5
Press ITEM until CFG TCP/IP=NO * displays.
6
Press VALUE once. CFG TCP/IP=YES displays.
7
Press SELECT once. CFG TCP/IP=YES * displays.
8
Press ITEM to configure TCP/IP parameters manually.
BOOTP=YES * displays.
Chapter 6
135
9
If you keep BOOTP=YES *, the values for the TCP/IP parameters
will be provided by the BOOTP file, RARP, or DHCP and no other
TCP/IP configuration is necessary. Skip to step 17.
– OR –
Press VALUE to change the value of the BOOTP= parameter.
BOOTP=NO displays.
10 Press SELECT to save the selection. BOOTP=NO * appears, and
you are prompted to configure each of the TCP/IP parameters.
11 Press ITEM to continue configuring. IP BYTE 1=<value>> *
displays.
12 Press VALUE until the value of the first byte of the IP address
displays.
13 Press SELECT to save the value.
14 Repeat steps 12 and 13 to configure the remaining bytes of the IP
address.
15 Press ITEM to continue.
16 Repeat steps 12-15 to configure the subnet mask bytes (SM),
default gateway (GW), and timeout (TIMEOUT).
17 If you are finished, press GO to return the printer to the READY
state.
– OR –
See the appropriate sections for other protocols that will be used.
136
Printer Interfaces
EN
To configure Apple AppleTalk parameters from the
printer control panel
1
Press MENU until HP EIO 1 MENU displays.
2
Press ITEM until CFG NETWORK=NO * displays.
3
Press VALUE until CFG NETWORK=YES displays.
4
Press SELECT once. CFG NETWORK=YES * displays.
5
Press ITEM until CFG ETALK=NO * displays.
6
Press VALUE until CFG ETALK=YES displays.
7
Press SELECT once. CFG ETALK=YES * displays.
8
Press ITEM. PHASE=1 or PHASE=2 displays.
9
Press ITEM to retain the value and continue, or press VALUE to
change the phase parameter.
10 Press SELECT to save the new value.
11 If you are finished, press GO to return the printer to the READY
state.
– OR –
See the appropriate sections for other protocols that will be used.
EN
Chapter 6
137
Disabling network protocols (optional)
By factory default, all supported network protocols are enabled.
Disabling unused protocols has the following benefits:
●
decreases printer-generated network traffic
●
prevents unauthorized users from printing to the printer
●
provides only pertinent information on the configuration page
●
allows the printer control panel to display protocol-specific error
and warning messages
To reach network protocols
1
Press MENU until HP EIO 1 MENU displays.
2
Press ITEM until CFG NETWORK=NO * displays.
3
Press VALUE until CFG NETWORK=YES displays.
4
Press SELECT once. CFG NETWORK=YES * displays.
In the sections that follow, find the protocol that you want to disable.
To disable IPX/SPX
Note
138
Do not disable this protocol if Windows 95/98 or Windows NT clients
will be printing to the printer.
1
Press ITEM until IPX/SPX=ON * appears.
2
Press VALUE to change to IPX/SPX=OFF.
3
Press SELECT to save the new status. IPX/SPX=OFF * appears.
4
To disable another protocol, find the appropriate section.
– OR –
Press GO to return the printer to the READY state.
Printer Interfaces
EN
To disable DLC/LLC
1
Press ITEM until DLC/LLC=ON * displays.
2
Press VALUE to change to DLC/LLC=OFF.
3
Press SELECT to save the new status. DLC/LLC=OFF * displays.
4
To disable another protocol, find the appropriate section.
– OR –
Press GO to return the printer to the READY state.
To disable TCP/IP
Note
1
Press ITEM until TCP/IP=ON * displays.
2
Press VALUE to change to TCP/IP=OFF.
3
Press SELECT to save the new status. TCP/IP=OFF * displays.
4
To disable another protocol, find the appropriate section.
– OR –
Press GO to return the printer to the READY state.
You cannot access the printer using the embedded Web server if
TCP/IP is disabled.
To disable Apple AppleTalk
EN
1
Press ITEM until ETALK=ON * displays.
2
Press VALUE to change to ETALK=OFF.
3
Press SELECT to save the new status. ETALK=OFF * displays.
4
To disable another protocol, find the appropriate section.
– OR –
Press GO to return the printer to the READY state.
Chapter 6
139
140
Printer Interfaces
EN
7
Consumables and
cleaning
Overview
This chapter provides an overview of the printer’s consumable
items. The chapter includes the following sections:
●
Making room around the printer for replacing consumables
●
Approximate replacement intervals for consumable items
●
Locating consumables
●
Environmental collection program
●
Cleaning the printer
For complete instructions on installing consumables, see the
installation guides supplied with each consumable item.
EN
Chapter 7
141
Making room around the printer for replacing
consumables
The following illustration shows the clearance necessary around the
printer for replacing consumables.
Figure 7-1
142
Consumable replacement clearance diagram
1
Top view
2
Side view
Consumables and cleaning
EN
Consumable replacement guidelines
To facilitate consumable replacement, keep the following guidelines in
mind when setting up the printer.
EN
●
Sufficient space is required in the front and rear of the printer for
removing consumable items.
●
The printer should be located on a flat, sturdy surface.
●
102 mm (4 in) of space is required on the sides of the printer to
ensure proper ventilation.
Chapter 7
143
Approximate replacement intervals for
consumable items
You can identify consumable items by their labeling and their blue
plastic handles.
WWW
For instructions on installing consumables, see the installation guides
supplied with each consumable item or visit http://www.hp.com/
support/lj4550. When you connect, select Solve a Problem.
CAUTION
Hewlett-Packard recommends the use of HP products in this printer.
Use of non-HP products may cause problems requiring service that is
not covered by the Hewlett-Packard warranty or service agreements.
144
Consumables and cleaning
EN
The following table lists the replacement intervals for printer
consumable items and the control panel messages that prompt you
when to replace each item.
Consumable
Printer message
Page count
Approximate
time period2
Black toner
cartridge
BLACK TONER LOW
or
BLACK TONER OUT
9,000 pages1
4 months
Cyan toner
cartridge
CYAN TONER LOW
or
CYAN TONER OUT
6,000 pages1
2.5 months
Magenta toner
cartridge
MAGENTA TONER LOW
or
MAGENTA TONER OUT
6,000 pages1
2.5 months
Yellow toner
cartridge
YELLOW TONER LOW
or
YELLOW TONER OUT
6,000 pages1
2.5 months
Drum kit
DRUM LIFE OUT
REPLACE KIT
or
WASTE TONER FULL
REPLACE DRUM KIT
6,250 color pages3 or
25,000 black and white
only pages.
3 months for color
pages, or 12.5 months
for black and white
only pages.
Transfer kit
TRANSFER KIT OUT
REPLACE KIT
25,000 color pages, or
100,000 black and
white only pages.
12.5 months for color
pages, or 50 months
for black and white
only pages.
Fuser kit
FUSER LIFE OUT
REPLACE KIT
50,000 color pages, or
100,000 black and
white only pages.
25 months for color
pages, or 50 months
for black and white
only pages.
1 Approximate average A4/letter-size page count based on 5% coverage of individual toner colors. Page
counts are only estimations, and usage conditions and print patterns may cause results to vary.
2 Approximate lifes are based on 2,000 pages per month.
3 6,250 color pages or 25,000 black-only pages; based on two-page, A4/letter-sized print jobs. Actual
number of pages will vary depending on individual customer usage. Factors impacting page yield include
color versus black-only printing mix, paper size, typical job length and complexity, and automatic
duplexing.
EN
Chapter 7
145
Locating consumables
The following figure illustrates the location of each consumable item.
1
2
6
3
4
5
Figure 7-2
146
Consumable item locations
1
Toner cartridges
2
Imaging drum cartridge
3
Transfer belt
4
Air filters
5
Fuser
6
Transfer roller
Consumables and cleaning
EN
Environmental collection program
Hewlett-Packard encourages responsible disposal of HP LaserJet
printer supplies through its Planet Partners Program. For details
on this program, see the recycling instruction guide enclosed with
each consumable item. This program may not be available in all
countries/regions.
The following consumable items can be disposed of through the
Planet Partners Program:
EN
●
Toner cartridge
●
Imaging drum cartridge
●
Transfer belt
●
Fuser
Chapter 7
147
Cleaning the printer
Cleaning excess toner from the printer
Toner from the yellow, magenta, and cyan toner cartridges will
accumulate on the flaps that cover the toner cartridges. Although this
accumulation of toner does not cause any print defect, the excess
toner needs to be cleaned from the flap occasionally. Clean the flap
covering the toner cartridge and other excess toner from the printer
when you are replacing toner cartridges. There is a toner cloth
provided with each replacement toner cartridge to clean the toner
from the printer. See the instructions included with the replacement
toner cartridge for more information about cleaning the printer.
CAUTION
Do not use the toner cleaning cloth on the drum, developer sleeves in
the toner cartridge, or transfer rollers. Doing so can damage these units
and cause other print quality problems.
If toner has built up on the toner cartridge, it may fall onto the transfer
roller, which causes streaking on the media being printed. To clean
the toner from the transfer roller, print several blank pages until the
streaking stops.
148
Consumables and cleaning
EN
Cleaning the toner density sensor
1
2
The toner density sensor should be
cleaned whenever the imaging drum is
replaced or whenever the control panel
message DENSITY SENSOR OUT OF
RANGE displays.
CAUTION
To avoid scratching the sensor, do not
clean it with any paper products.
To clean the toner density
sensor
3
1
Open the lower front drawer and
remove the cleaning brush mounted
inside. Then close the drawer.
2
Pull open the top front drawer.
3
Remove the imaging drum by the
blue handle.
4
Use the cleaning brush to remove all
dust and toner particles from the
sensor. as illustrated.
4
EN
Chapter 7
149
5
5
Re-insert the imaging drum.
6
Close the top front drawer.
7
Replace the cleaning brush and
firmly close the lower front drawer.
6
7
150
Consumables and cleaning
EN
8
Printer control panel
messages
Overview
This chapter lists printer control panel messages and explains
their meaning. The control panel displays four types of
messages. These message types are:
EN
●
Status messages
●
Warning messages
●
Attention messages
●
Critical error messages
Chapter 8
151
Message types
Status messages
Status messages reflect the current state of the printer. They inform
the user of normal printer operation and do not require user
interaction to clear them. They change as the state of the printer
changes. Whenever the printer is ready, not busy, and has no pending
warning messages, the status message READY is displayed if the
printer is online. If the printer is offline, the message OFFLINE is
displayed.
Warning messages
Warning messages inform you of data and print errors. These
messages typically alternate with the READY or OFFLINE messages
and remain displayed until you press GO. If CLEARABLE WARNING is
set to JOB in the printer’s configuration menu, then these messages
are cleared by the next print job.
Attention messages
Attention messages inform you that some action must be taken, such
as adding paper or clearing a paper jam. For certain errors, the
printer continues printing without user intervention. If AUTO CONTINUE
is set to ON in the configuration menu, the printer will automatically
attempt to return online.
Critical error messages
Critical error messages inform you of a device failure. You can clear
some of these messages by turning the printer off and then on. These
messages are not affected by the AUTO CONTINUE setting. If a
condition persists, service is required.
152
Printer control panel messages
EN
Printer control panel messages
The following table lists the printer control panel messages for this
printer. Printer messages with numeric prefixes are listed in numerical
order. Printer messages without numeric prefixes are listed in
alphabetical order.
Note
Except when the printer is initially turned on, messages are displayed
in the display language selected in the printer control panel (such as
English, French, or Spanish).
Printer control panel messages
Message
Description
ACCESS DENIED
MENUS LOCKED
Displayed for approximately
No action required.
5 seconds when a user attempts to
modify a menu value while control
panel locking is enabled.
BAD DUPLEXER
CONNECTION
The duplex printing accessory is not Verify that the power cord is
correctly installed.
connected to the duplex
printing accessory and that the
short power cord from the
duplex printing accessory is
connected to the printer.
If the error continues, verify that
the duplex printing accessory is
correctly installed.
CALIBRATING
The printer is executing an internal
color calibration. This process
should take approximately 90
seconds.
CANCELING JOB
The printer is in the process of
No action required.
canceling a print job. Incoming data
for the current job will be discarded.
CANNOT DUPLEX
CHECK REAR BIN
The printer cannot duplex because
the rear output bin is open or the
media is not supported by the
alternates with
CANNOT DUPLEX CHECK duplex printing accessory.
PAPER
CANNOT DUPLEX
CLOSE REAR BIN
EN
Recommended action
No action required.
Close the rear output bin. If the
bin is closed, verify that the
media is supported by the
duplex printing accessory. See
“Supported media weights and
sizes” on page 67.
The printer cannot duplex because Close the rear output bin.
the rear output bin is open.
Chapter 8
153
Printer control panel messages (continued)
Message
Description
Recommended action
CHECKING PAPER
PATH
The printer is performing an internal When the test has finished,
test. When finished, the printer
press GO to return the printer to
remains offline.
the READY state.
CHECKING
PRINTER
The printer is performing an internal When the test has finished,
test. This process should take
press GO to return the printer to
approximately 30 seconds. When
the READY state.
finished, the printer remains offline.
CLEARING PAPER
FROM PRINTER
The printer has jammed or was
No action required.
turned on and media was detected
in the paper path. The printer is
attempting to clear these pages.
CLOSE FRONT DUPLEX The duplex drawer is not completely Close the duplex drawer.
closed.
DRAWER
CLOSE MIDDLE FRONT The middle front drawer is not
completely closed.
DRAWER
Close the middle front drawer.
CLOSE UPPER
REAR DOOR
The upper rear door is not
completely closed.
Close the upper rear door.
CLOSE
TOP COVER
The top cover is not completely
closed.
Close the top cover.
CLOSE UPPER
FRONT DRAWER
The upper front drawer is not
completely closed.
Close the upper front drawer.
[COLOR] TONER LOW
The toner cartridge specified is low Printing will continue until a
on toner.
TONER OUT message appears.
To change the toner cartridge
now, press SELECT.
[COLOR] TONER OUT
The toner cartridge specified is out Change the specified toner
of toner.
cartridge now to ensure print
quality. See “Printer supplies
and accessories” on page 31.
[COLOR] TONER LOW
PRESS SELECT
TO CHANGE TONER
The toner cartridge specified is low Press SELECT to enter the toner
on toner and must be replaced now. replacement menu.
See “Printer supplies and
accessories” on page 31.
CONTINUING
INTERRUPTED JOB
The printer is continuing the print
job that was interrupted.
DATA RECEIVED
The printer has received and
Press GO to initiate a form
processed data and is waiting for a feed.
form feed.
alternates with
154
Printer control panel messages
No action required.
EN
Printer control panel messages (continued)
Message
Description
DENSITY SENSOR
OUT OF RANGE
A density sensor out of range error The density sensor may be
was detected during a color
dirty. Inspect and clean the
calibration.
sensor (see “Cleaning the toner
density sensor” on page 149
for cleaning instructions).
alternates with
CLEAN
DENSITY SENSOR
Recommended action
DRUM ERROR
REPLACE KIT
An error has been detected with a
component of the print drum kit.
DRUM LIFE LOW
ORDER KIT
The imaging drum is near the end of Order a replacement drum kit,
its expected life.
and continue printing. See
“Printer supplies and
accessories” on page 31.
DRUM LIFE OUT
REPLACE KIT
The imaging drum has reached the Replace the drum kit.
end of its expected life. See “Printer
supplies and accessories” on
page 31.
DUPLEX ERROR
CHECK DUPLEXER
An error has occurred in the duplex Verify that the duplex printing
printing accessory.
accessory is correctly installed.
EIO DISK X
NOT FUNCTIONAL
The EIO disk is not working
correctly.
EIO X
INITIALIZING YYY
No action required.
The EIO device in slot X is
initializing. The YYY value will
increment every 10 seconds during
this process.
alternates with
DO NOT
POWER OFF
Replace the print drum kit.
Remove the EIO disk from the
slot indicated. Call HP Support.
EIO X
NOT FUNCTIONAL
The EIO slot specified does not
have a card installed or is not
functional.
EIO X DISK
SPINNING UP
The disk accessory is initializing.
No action required.
The first parameter is the accessory
slot number for this accessory card.
EVENT LOG
EMPTY
SHOW EVENT LOG was selected
from the Information Menu, but the
event log has no entries.
No action required.
FLASH DIMM X
INITIALIZING
The new Flash DIMM installed in
slot X is initializing.
No action required.
No action required.
alternates with
DO NOT POWER OFF
[FS
] DEVICE
FAILURE
EN
The hard disk, flash DIMM, or RAM Remove the flash DIMM and
disk had a critical failure and no
replace it with a new one.
longer can be used.
Chapter 8
155
Printer control panel messages (continued)
Message
Description
[FS
] FILE
OPERATION FAILED
The requested operation could not No action required.
be performed. You might have
attempted an illegal operation, such
as trying to download a file to a nonexistent directory.
[FS
] FILE
SYSTEM IS FULL
The hard disk, flash DIMM, or RAM Delete files from the device.
disk is full.
Use HP Resource Manager to
download or delete files and
fonts. (See the software help
for more information.)
[FS
] IS
WRITE PROTECTED
The hard disk, flash DIMM, or RAM Disable the write protection
disk is protected and no new files
through HP Resource
can be written to it.
Manager.
[FS
] NOT
INITIALIZED
The hard disk, flash DIMM, or RAM Re-initialize the device using
disk has been initialized by another HP Resource manager or
HP printer product.
HP Web JetAdmin (see the
online help for more
information).
FUSER LIFE LOW
ORDER KIT
The fuser is near the end of its
expected life.
FUSER LIFE OUT
REPLACE KIT
The fuser has reached the end of its Replace the fuser kit.
expected life. See “Printer supplies
and accessories” on page 31.
INCORRECT PIN
PLEASE TRY AGAIN
The personal identification number
(PIN) was not entered correctly.
INITIALIZING
This message is displayed when the No action required.
printer is initially turned on.
INSTALL [COLOR]
TONER
The color toner cartridge indicated
has been removed.
The toner cartridge has been
removed and must be replaced
for printing to continue.
INSTALL
DRUM KIT
The drum kit is not installed or is
incorrectly installed.
Verify that the drum kit is
correctly installed.
INSTALL TRAY
Tray 2 is not installed or is not
completely closed, preventing
media from being printed from
Tray 3.
Verify that Tray 2 is completely
closed.
INTERRUPTING JOB
PLEASE WAIT
The print job currently processing is No action required.
being interrupted by a higher priority
print job.
156
Printer control panel messages
Recommended action
Order a replacement fuser kit,
and continue printing. See
“Printer supplies and
accessories” on page 31.
Re-enter the PIN.
EN
Printer control panel messages (continued)
Message
Description
Recommended action
MANUALLY FEED
[SIZE]
Load the requested paper into
Tray 1.
Press GO if the desired paper is
already loaded in Tray 1.
MANUALLY FEED
TRAY 1 ENVELOPE
Load envelopes into Tray 1.
Press GO if envelopes are
already loaded in Tray 1.
MANUALLY FEED
[TYPE] [SIZE]
Load the requested paper into
Tray 1.
Press GO if the desired paper is
already loaded in Tray 1.
MEMORY FULL
STORED DATA LOST
The printer has no available
memory. The current job may not
print correctly. Some downloaded
fonts may have been deleted.
Try printing simplified pages. If
this does not resolve the
problem, add printer memory.
MEMORY SETTINGS
CHANGED
The I/O buffering settings were
changed by the printer because
there is not enough memory
available to use the previous
settings.
No action required. Adding
printer memory may prevent
this from occurring.
MEMORY SHORTAGE
JOB CLEARED
The available memory was not
Adding printer memory may
enough to continue printing. The
prevent this from occurring.
remainder of the job was canceled.
MEMORY SHORTAGE
PAGE SIMPLIFIED
The image was too large for
Adding printer memory may
available printer memory. Therefore, prevent this from occurring.
the printer compressed the image,
resulting in lost data.
MOPY PAGE TOO
COMPLEX
The print job sent to the printer was No action required.
too complex.
alternates with
PRESS GO TO
CONTINUE
NO JOB TO CANCEL
CANCEL JOB was pressed but there No action required.
is no active job or buffered data to
cancel. The printer automatically
returns to the READY state.
OFFLINE
The printer is offline and there are
no error messages pending.
Press GO to return the printer
to the READY state.
OUTPUT BIN FULL
The top output bin is full.
Remove media from the top
output bin.
alternates with
CLEAR PAPER FROM
[BIN NAME]
EN
Chapter 8
157
Printer control panel messages (continued)
Message
Description
PAGE CANNOT
PRINT NOW
Request the internal page
An internal page has been
requested while the printer is
when the printer is in the READY
processing an incoming job. Internal state.
pages are not permitted to interrupt
and can only be printed when the
printer is in the READY state.
alternates with
RETRY WHEN
PRINTING STOPS
Recommended action
PLEASE WAIT
The printer is in the process of
No action required.
purging data so that it can go offline
or into the menus.
POWERSAVE ON
The printer is in PowerSave mode. No action required.
This message is cleared by
pressing any key or by the receipt of
a print job.
PRESS GO TO
PRINT
The top cover was opened and
closed when the printer was not in
toner cartridge replacement mode.
alternates with
Press GO to resume printing or
press SELECT to enter the toner
replacement menu.
PRESS SELECT TO
CHANGE TONER
PRINTER LANGUAGE
NOT AVAILABLE
alternates with
The printer received a request for a No action required.
language (personality) that does not
exist in the printer.
PRINT JOB
CANCELLED
PRINTING
ACCESSORIES
No action required.
The accessories page is being
generated. The printer returns to
the READY state upon completion of
this page.
PRINTING
CALIBRATION PAGE
The color calibration page is being No action required.
generated. The printer returns to
the READY state upon completion of
this page.
PRINTING
COLOR GUIDE
The color guides page is being
No action required.
printed. The printer returns to the
READY state upon completion of this
page.
PRINTING
CONFIGURATION
The configuration page is being
No action required.
printed. The printer returns to the
READY state upon completion of this
page.
158
Printer control panel messages
EN
Printer control panel messages (continued)
Message
Description
PRINTING
DEMONSTRATION 1
The printer’s LaserJet demo page is No action required.
being generated. The printer will
return to the online READY state
upon the completion of the page.
PRINTING
ENGINE TEST
The engine test page is being
No action required.
printed. The printer returns to the
READY state upon completion of this
page.
PRINTING
EVENT LOG
The event log is being printed. The
printer returns to the READY state
upon completion of the page.
No action required.
PRINTING
FILE DIRECTORY
The file directory is being printed.
The printer returns to the READY
state upon completion of the page.
No action required.
PRINTING
FONT LIST
A typeface list for the available
personalities is being printed. The
printer returns to the READY state
upon completion of these pages.
No action required.
PRINTING
MENU MAP
The printer menu map is being
No action required.
printed. The printer returns to the
READY state upon completion of this
page.
PRINTING
PAPER PATH TEST
The paper path test page is being No action required.
printed. The printer returns to the
READY state upon completion of this
page.
PRINTING
REGISTRATION
The registration page is being
No action required.
generated. The printer will return to
the READY state upon the
completion of the page.
PRINTING
USAGE PAGE
The printer usage page is being
No action required.
printed. The printer returns to the
READY state upon completion of this
page.
PROCESSING COPY
X OF Y
The printer is processing one of
several copy jobs.
PROCESSING JOB
The printer is processing the current No action required.
job.
PROCESSING JOB
FROM TRAY X
The printer is processing the current No action required.
job from a particular tray.
EN
Recommended action
No action required.
Chapter 8
159
Printer control panel messages (continued)
Message
Description
Recommended action
READY
The printer is online and ready to
receive data, and no status or
device attendance messages are
pending.
No action required.
REINSTALL
TRANSFER BELT
The transfer belt is broken or
incorrectly installed.
Remove the transfer belt.
Inspect the transfer belt for
damaged areas and replace it if
necessary.
Check for broken connectors in
the middle front drawer.
Check for paper jammed inside
the connectors in the middle
front drawer.
Turn the white knobs on the
transfer belt until little windows
are visible. Tap the windows to
shake any toner loose. If the
toner does not shake loose,
reach under the window with a
Q-tip and remove the toner
from the window.
REMOVE PAPER JAM
Printer media has become jammed Ensure that all jammed paper
somewhere in the paper path.
is removed from the paper
path. See “Paper jam locations”
on page 175.
REQUEST ACCEPTED
PLEASE WAIT
The printer is executing a request.
The printer returns to the READY
state upon completion of this
process.
RESETTING
MEMORY
The printer is executing a memory No action required.
reset. The printer returns to the
READY state upon completion of this
process.
RESETTING VALUES
FINISHED
The color calibration density values No action required.
have been reset to their default
values.
RESTORING
FACTORY SETTINGS
The printer is executing a RESTORE No action required.
FACTORY SETTINGS or a COLD
RESET.
160
Printer control panel messages
No action required.
EN
Printer control panel messages (continued)
Message
Description
Recommended action
TONER [COLOR] OUT
The toner cartridge specified is out
of toner. If the TONER OUT setting in
the CONFIGURATION MENU is set to
OVERRIDE, pressing GO will resume
printing.
Press SELECT to enter the toner
replacement menu. Press GO
to resume printing without
changing the cartridge.
alternates with
PRESS SELECT
TO CHANGE TONER
TONER POSITION
[COLOR] = [STATE]
Indicates the current state of a
If necessary, replace the
particular toner cartridge. This
specified toner cartridge.
message is displayed when SELECT
is pressed while a TONER LOW/OUT
message is displayed.
TRANSFER KIT LOW
ORDER KIT
The transfer kit is near the end of its Order a replacement transfer
expected life.
kit and continue printing. See
“Printer supplies and
accessories” on page 31.
TRANSFER KIT OUT
REPLACE KIT
The transfer kit has reached the end Replace the transfer kit.
of its expected life. See “Printer
supplies and accessories” on
page 31.
TRAY 1 LOAD
[SIZE]
Tray 1 does not contain the
specified media size.
Load the specified media size
into Tray 1.
TRAY 1 LOAD
[TYPE] [SIZE]
Tray 1 does not contain the
specified media size and type.
Load the specified media size
and type into Tray 1.
TRAY X CONTAINS
UNKNOWN MEDIA
The media type in the specified tray Remove the unknown media
cannot be determined.
from the specified tray.
TRAY X EMPTY
[TYPE] [SIZE]
The specified tray is empty but the
current job does not need this tray
to complete the job.
No action required.
TRAY X LOAD
[SIZE]
The specified tray requires the
necessary media size.
Load the media size into the
specified tray.
TRAY X LOAD
[TYPE] [SIZE]
The specified media type and size
need to be loaded into the
requested tray.
Load the specified media type
and size into the requested
tray. Press GO to override this
request and cause the page to
be printed on different media.
TRAY X OPEN
The specified tray is not completely Close the specified tray.
closed.
EN
Chapter 8
161
Printer control panel messages (continued)
Message
Description
Recommended action
TRAY X SIZE=
[SIZE]
Media has been loaded into the
specified tray.
The most recently configured
media size will be displayed
with an asterisk next to it.
Press -VALUE+ to view all the
possible media sizes.
Press SELECT to display the
current media size.
Press GO to remove the
message.
TRAY X TYPE=
[TYPE]
Media has been loaded into the
specified tray
The most recently configured
media type will be displayed
with an asterisk next to it.
Press -VALUE+ to view all the
possible media types.
Press SELECT to display the
current media type.
Press GO to remove the
message.
UNABLE TO
MOPY JOB
Memory or file system failures
Only one copy will be
would not allow a mopy job to occur. produced.
UNABLE TO
STORE JOB
Memory or file system failures
would not allow a stored job to
occur.
UNSUPPORTED SIZE
IN TRAY XX
There is unsupported print media in Remove the unsupported
the specified tray.
media size from the specified
tray.
WAIT FOR PRINTER
TO REINITIALIZE
The printer is reinitializing. The
printer returns to the READY state
upon completion of this process.
WARMING UP
The printer fuser is heating up.
No action required.
Printing will continue when the fuser
reaches the proper temperature.
WASTE TONER FULL
REPLACE DRUM KIT
The waste toner receptacle in the
drum kit is full.
162
Printer control panel messages
Install additional memory in the
printer.
Install a hard disk in to the
printer
If a hard disk is installed, delete
previously stored print jobs.
No action required.
Replace the drum kit.
EN
Printer control panel messages (continued)
Message
Description
Recommended action
13.XX PAPER JAM
A jam has occurred. XX specifies
the type of paper jam.
See “Clearing paper jams” on
page 178 for instructions.
alternates with:
CHECK ALL
REAR DOORS
or
CHECK MIDDLE
FRONT DRAWER
or
CHECK FRONT
DUPLEX DRAWER
13.XX PAPER JAM
IN INPUT DEVICE
XX
0
1
2
3
4
5
6
7
8
9
10
11
Description
Paper jam in paper feed area
Paper jam in fusing unit area
Paper jam in fusing unit area
Paper jam in reversing area
Paper jam in reversing area
Paper jam in path to duplexer
area
Paper jam in path to duplexer
area
Paper jam in paper path area
Door open jam
Unexpected media type
Unexpected media type
Unexpected media type
Open the rear duplex cover (if
installed) and remove any
jammed media. Open the
upper rear door and remove
any jammed media from the
rear paper path and fuser area.
Open the middle front drawer
and remove any jammed
media.
Open the front duplex drawer
and remove any jammed
media.
A jam has occurred where XX is the See “Clearing paper jams” on
page 178 for instructions.
location of the media jam.
alternates with
CHECK TRAY X
AND FRONT DRAWER
13.1 JAM: OPEN
MIDDLE DRAWER
alternates with
A jam has occurred inside the
middle front drawer area. The jam
may be located in the fuser area.
Open the middle front drawer
and carefully inspect for any
media. Be sure to inspect the
fusing area You may need to
access the fusing area through
the rear door. Remove any
jammed media.
More data has been received from
the computer than fits in the
printer’s internal memory.
To continue printing, press GO.
Only the amount of data that
fits in the printer’s internal
memory is printed. Adding
more memory should resolve
this problem.
CHECK IN REAR
OF DRAWER
20 INSUFFICIENT
MEMORY
alternates with
PRESS GO TO
CONTINUE
21 PAGE TOO
COMPLEX TO PRINT
alternates with
PRESS GO TO
CONTINUE
EN
The data sent to the printer was too Press GO to print the
complex.
transferred data, some data
might be lost. If this message
persists, call HP Support.
Chapter 8
163
Printer control panel messages (continued)
Message
Description
Recommended action
22 EIO X
BUFFER OVERFLOW
The I/O buffer for the EIO card in
slot X has overflowed.
Press GO to resume printing
and then resend the job.
The printer’s parallel buffer has
overflowed.
Press GO to resume printing
and then resend the job.
A connection with the card in the
specified slot has been broken.
Press GO to continue printing.
alternates with
PRESS GO TO
CONTINUE
22 PARALLEL I/O
BUFFER OVERFLOW
alternates with
PRESS GO TO
CONTINUE
40 EIO X BAD
TRANSMISSION
alternates with
PRESS GO TO
CONTINUE
41.3 UNEXPECTED
PAPER SIZE
alternates with
LOAD TRAY X
<TYPE> <SIZE>
41.5 UNEXPECTED
PAPER TYPE
alternates with
A tray is configured for a specific
Load the proper size paper in
paper size, but the sheet loaded is a the tray or reconfigure the tray
different size.
for the paper size it contains.
Then press GO to continue
printing.
A tray is configured for a specific
media type, but a different media
type is loaded.
Load the proper media type in
the tray or reconfigure the tray
for the media type it contains.
LOAD TRAY X
<TYPE> <SIZE>
41.X
PRINTER ERROR
alternates with
PRESS GO TO
CONTINUE
164
A temporary printing error occurred. Press GO. The page containing
the error will automatically be
reprinted if jam recovery is
enabled. If the error does not
clear, turn the printer off, then
turn the printer on. If this
message persists, call
HP Support.
Printer control panel messages
EN
Printer control panel messages (continued)
Message
Description
Recommended action
49 ERROR (XXXX)
CYCLE POWER
A communication error has
occurred.
Turn the printer off and then on
to clear the error. If this does
not solve the problem try the
following:
1) Cancel the current print job
from your PC or server. Resend
the print job. If this does not
work, try sending a different
job.
2) If your computer is
connected to the printer
through a parallel cable, verify
that the cable is connected
correctly and is of good quality.
3) If the problem persists, call
HP Support.
50.X FUSER ERROR
A fusing error has occurred.
Clear the error by turning the
X indicates the error type as follows: printer off and then on. If the
problem persists, call
HP Support.
X Description
1 Low fuser temperature
For 50.5 fuser errors (fuser
2 Fuser warm up service
voltage mismatch), verify that
3 High fuser temperature
the fuser is the same voltage
4 Faulty fuser
type as the printer.
5 Fuser voltage mismatch
6 Fuser heater cutoff
7 Fuser motor malfunction
51.X
PRINTER ERROR
A laser error has occurred due to a Clear the error by turning the
beam detect error or laser failure.
printer off and then on. If the
problem persists, call
HP Support.
alternates with
CYCLE POWER TO
CONTINUE
52.X
PRINTER ERROR
alternates with
CYCLE POWER TO
CONTINUE
EN
A scanner failure has occurred.
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
Chapter 8
165
Printer control panel messages (continued)
Message
Description
Recommended action
53.XY.ZZ ERROR
BASE MEM BANK B
Indicates a memory error. If a DIMM
caused the error, the DIMM will not
be recognized. Values of X, Y, and Z
are as follows:
Clear the error by turning the
printer off and then on. Verify
that the DIMM is correctly
installed. If the DIMM is
correctly installed, replace the
DIMM. See “Installing DIMMs”
on page 217. If the problem
persists, call HP Support.
or
53.XY.ZZ ERROR
DIMM A BANK B
alternates with
PRESS GO TO
CONTINUE
alternates with
NO MORE ERRORS
CONTINUING
54.X PRINTER
ERROR
X
0
1
Memory Type
ROM
RAM
Y
0
1
2
3
Device Location
On board
DIMM Slot 1
DIMM Slot 2
DIMM Slot 3
ZZ
0
1
3
Error Number
Unsupported memory
Unrecognized memory
Failed RAM test
An error has occurred where X is
indicated below.
X
1
2
3
4
5
6
166
Description
Internal power failure
Carousel rotation failure
Density sensor out of range
Optional equipment not
available
Waste toner sensor
malfunction
OHT sensor malfunction
Printer control panel messages
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
EN
Printer control panel messages (continued)
Message
Description
Recommended action
54.2 PRINTER
ERROR
A toner cartridge has been
incorrectly installed.
Turn off the printer, and open
the top cover.
Locate the carousel brake
release and press the metal tab
with the end of a pen. With your
other hand push the carousel
around to the position required
to remove the toner cartridge.
If the carousel is still blocked
after releasing the carousel
break, open the front drawers
and push the carousel.
Remove the toner cartridge. If
the toner cartridge cannot be
removed, move the carousel
until it comes loose.
Replace or reinstall the toner
cartridge.
For instructions, see
U.S. – http://www.hp.com/go/
ljsupplies or
Worldwide – http://
www.hp.com/ghp/
buyonline.html.
55 DC CONTROLLER
ERROR
The print engine is not
communicating with the formatter.
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
55.X
PRINTER ERROR
A temporary printing error occurred. Press GO. The page containing
the error will automatically be
reprinted if jam recovery is
enabled. If the error does not
clear, turn the printer off and
then on. If this message
persists, call HP Support.
alternates with
PRESS GO TO
CONTINUE
56.X
PRINTER ERROR
alternates with
CYCLE POWER TO
CONTINUE
EN
A temporary printing error occurred. Clear the error by turning the
printer off and then on. If this
message persists, call
HP Support.
Chapter 8
167
Printer control panel messages (continued)
Message
Description
Recommended action
57.X
PRINTER ERROR
An error has occurred where X is
indicated below:
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
alternates with
CYCLE POWER TO
CONTINUE
X
1
2
57.3 FAN ERROR
The upper front drawer may not be
completely closed preventing a
connection to fan motor 3.
alternates with
CLOSE UPPER
FRONT DRAWER
58.X
PRINTER ERROR
alternates with
CYCLE POWER TO
CONTINUE
59.X
PRINTER ERROR
alternates with
CYCLE POWER TO
CONTINUE
Description
Fan motor 1 malfunction
Fan motor 2 malfunction
Verify that the upper front
drawer is completely closed.
A temporary printing error occurred. Clear the error by turning the
printer off and then on. If this
message persists, call
HP Support.
A temporary printing error occurred. Clear the error by turning the
printer off and then on. If this
message persists, call
HP Support.
62 NO SYSTEM
There is a printer firmware error.
62.X
PRINTER ERROR
Indicates a problem with internal
Clear the error by turning the
memory. X indicates the location as printer off and then on. If the
problem persists, call
follows:
HP Support.
X Description
0 Internal memory
1 Memory in DIMM slot 1
2 Memory in DIMM slot 2
3 Memory in DIMM slot 3
64 PRINTER ERROR
A temporary printing error occurred. Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
alternates with
CYCLE POWER
168
Printer control panel messages
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
EN
Printer control panel messages (continued)
Message
Description
66.00.XX
SERVICE ERROR
A failure has occurred in an external Make sure the cables from the
paper handling output device.
external paper handling output
device are securely plugged
into the printer. Clear the error
by turning the printer off and
then on.
alternates with
CHECK CABLES
AND CYCLE POWER
68 NVRAM ERROR
CHECK SETTINGS
alternates with
PRESS GO TO
CONTINUE
68 NVRAM FULL
CHECK SETTINGS
alternates with
PRESS GO TO
CONTINUE
69.X
PRINTER ERROR
One or more settings saved in the
non-volatile storage device are
invalid. Some settings may have
been reset to factory defaults.
Recommended action
Check printer settings to
determine which values have
changed. Clear the message
by pressing GO. If the problem
persists, call HP Support.
Indicates that a non-volatile storage Check printer settings to
device is full. Some settings may
determine which values have
have been reset to factory defaults. changed. Clear the message
by pressing GO. If the problem
persists, call HP Support.
An error has occurred in X, where X
is:
X Description
0 Duplex mechanism has failed
1 Duplexer slide adjust has failed
Clear the error by turning the
printer off and then on. If the
problem persists, call
HP Support.
79.XXXX
PRINTER ERROR
The printer has detected an error.
The numbers (XXXX) indicate the
specific type of error.
Turn the printer off, and then
on. Try printing a job from a
different software application. If
the job prints, go back to the
first application and try printing
a different file. If the message
appears with a specific
software application or print
job, contact the software
vendor for assistance. If the
message persists with different
software applications and print
jobs, record the numbers that
appear for XXXX, and call
HP Support.
8X.YYYY
EIO ERROR
The EIO accessory card in slot X
has encountered a critical error as
specified by YYYY.
Record the numbers that
appear for YYYY, and call
HP Support.
alternates with
CYCLE POWER TO
CONTINUE
EN
Chapter 8
169
Control panel messages for external devices
Some control panel messages will only occur if an external device
attached to the printer has caused or created an error. The following
table contains these control panel messages. For more information
regarding the external device error, see the documentation that came
with the device.
Control panel messages for external devices
Message
Description
CHECK FINISHER
DEVICE
A finishing device, such as a Clear the specified paper jam.
stapler, a binder, or a 3-hole
punch device has a paper jam.
alternates with
Recommended action
CLEAR JAM
CHECK FINISHER
DEVICE
alternates with
FINISHER ALIGN
ERROR
CHECK INPUT
DEVICE
alternates with
PAPER PATH OPEN
PLEASE CLOSE IT
CHECK OUTPUT
DEVICE
This messaged indicates an
Clear the specified paper jam
alignment error occurred in the and the finisher’s paper path.
external paper handling
finishing device.
The optional input tray cannot Check the doors and paper
feed paper to the printer
guides.
because a door or paper guide
is open.
The optional output device is
not properly connected to the
printer.
A proper connection must be
made for printing to continue.
EXTERNAL DEVICE
INITIALIZING
When an external paper
handling device is connected
to the printer, it must initialize
after the printer boots or after
coming out of PowerSave
mode.
No action required.
INPUT DEVICE
CONDITION XX.YY
An input paper handling
See the documentation that
device has a condition that
came with the paper handling
needs attention before printing device for assistance.
can resume.
OUTPUT DEVICE
CONDITION XX.YY
An external output device has See the documentation that
a condition that needs
came with the paper handling
attention before printing may device for assistance.
resume.
alternates with
CLOSE OUTPUT
DELIVERY PATH
170
Printer control panel messages
EN
Control panel messages for external devices (continued)
Message
Description
TOO MANY PAGES
IN JOB TO FINISH
The finisher device attempted Remove the excess pages and
to finish a job that contained
retry finishing the print job.
more pages than the finisher
device was capable of
processing.
66.XX.YY
FINISHER FAILURE
A failure has occurred in an
Make sure the cables from the
external paper handling output external paper handling output
device.
device are securely plugged
into the printer. Clear the error
by turning the printer off and
then on.
alternates with
CHECK CABLES
AND CYCLE POWER
66.00.XX INPUT
DEVICE FAILURE
alternates with
CHECK CABLES
AND CYCLE POWER
66.00.XX OUTPUT
DEVICE FAILURE
alternates with
CHECK CABLES
AND CYCLE POWER
FINISHER LOW ON
FINISHING AGENT
EN
Recommended action
A failure has occurred in an
Make sure the cables from the
external paper handling output external paper handling input
device.
device are securely plugged
into the printer. Clear the error
by turning the printer off and
then on.
A failure has occurred in an
Make sure the cables from the
external paper handling output external paper handling output
device.
device are securely plugged
into the printer. Clear the error
by turning the printer off and
then on.
The finishing devices is
running out of its finishing
material
Refill the finishing device with
the specified finishing agent.
Chapter 8
171
172
Printer control panel messages
EN
9
Solving problems
with the printer
Overview
This chapter provides information on solving and preventing
printer problems such as paper jams and image defects. The
chapter includes the following sections:
EN
●
Basic troubleshooting checklist
●
Paper jam locations
●
Paper jam recovery
●
Common causes of paper jams
●
Clearing paper jams
●
Media-handling problems
●
Printer response problems
●
Printer control panel problems
●
Print quality troubleshooting
●
Overhead transparency defects
●
Color printing problems
●
Incorrect printer output
●
Software application problems
Chapter 9
173
Basic troubleshooting checklist
If you are experiencing problems with the printer, this checklist may
help identify the cause of the problem.
●
Is the printer connected to power?
●
Is the printer in the READY state?
●
Are all necessary cables connected?
●
Are any messages displayed on the control panel?
●
Were recently replaced toner cartridges installed correctly? Was
the pull tab on the cartridge removed?
●
Were recently installed consumable items (fuser kit, transfer kit,
imaging drum kit) installed correctly?
●
Is the power switch (standby button) pushed in?
If you cannot find solutions to printer problems in this guide, contact
an HP service and support center. (See “Support information” on
page 250.)
For additional information on installation and setup of the printer, see
the getting started guide for this printer.
174
Solving problems with the printer
EN
Paper jam locations
Use this illustration to troubleshoot paper jams in the printer. For
instructions on clearing paper jams, see “Clearing paper jams” on
page 178.
8
1
7
2
3
6
4
5
Figure 9-1
Paper jam locations (shown with the optional 500-sheet paper feeder and
duplex printing accessory installed)
EN
1
Input Tray 1 area
2
Transfer belt area
3
Input Tray 2 area
4
Front duplex drawer area
5
Tray 3 (500-sheet paper feeder) area
6
Rear duplex cover area
7
Fuser area
8
Rear paper path area
Chapter 9
175
Paper jam recovery
This printer provides Paper Jam Recovery, a feature that allows you to
set whether the printer should attempt to automatically recover from
paper jams. If Paper Jam Recovery is enabled, when a paper jam
occurs, all pages affected by the jam will be reprinted. The options
are:
ON
OFF
Note
Printer will attempt to reprint jammed pages.
Printer will not attempt to reprint jammed pages.
During the recovery process, the printer may reprint several good
pages that were printed before the paper jam occurred. Be sure to
remove any duplicated pages.
To enable Paper Jam Recovery
1
Press MENU until CONFIGURATION MENU displays.
2
Press ITEM until JAM RECOVERY displays.
3
Press VALUE until ON displays.
4
Press SELECT to save the setting.
5
Press GO to return the printer to the READY state.
To improve print speed and increase memory resources, you may
want to disable Paper Jam Recovery. To disable Paper Jam Recovery,
select OFF in step 3 above. If Paper Jam Recovery is disabled, the
pages involved in a jam will not be reprinted.
176
Solving problems with the printer
EN
Common causes of paper jams
The following table lists common causes of paper jams and
suggested solutions for resolving them.
Cause
Solution
Print media does not meet HP-recommended See “Selecting print media” on page 66.
media specifications.
A consumable item is installed incorrectly,
causing repeated jams.
Verify that the consumable item is correctly
installed.
You are reloading paper that has already
passed through a printer or copier.
Do not use media that has been printed or
copied.
An input tray is loaded incorrectly.
Remove any excess media from the input tray.
Press media down in the input tray so it fits
below the tabs, and within the media width
guides. See Chapter 3 for instructions on
loading media.
Print media is skewed and jams.
Input tray guides are not adjusted correctly.
Adjust input tray guides so they hold media
firmly in place without bending it.
Print media is binding or sticking together.
Remove media, flex it, rotate it 180 degrees or
flip it over. Reload media into the input tray.
Do not fan media.
Media size specified in software does not
Verify that the media size selected in your
match the input tray’s media size configuration. software application or printer driver matches
the media size specified in the printer control
panel for the tray you are printing from.
Print media is in poor condition.
Replace the print media.
Printer consumable items have reached the
end of their useful life.
Check the printer control panel for messages
prompting you to replace consumable items, or
print a configuration page to verify the
remaining life of the consumable items. See
Chapter 3 for information on consumable
items.
Media was not stored correctly.
Replace the print media. Media should be
stored in its original packaging in a controlled
environment.
Note
EN
If the printer still continues to jam, contact HP Customer Support or
your authorized HP service provider. See “HP Customer Care options
worldwide” on page 252.
Chapter 9
177
Clearing paper jams
Clearing jams in the middle front drawer area
1
1
Pull open the middle front drawer to
access the media.
Note
When removing the transfer belt
assembly, do not touch the transfer belt
material.
2
Remove the transfer belt assembly
by lifting up on its blue handles.
3
Remove any jammed or torn media.
Be sure to lift the metal flap by its
green tab and remove any media.
Note
Be sure to inspect the rear area inside
the drawer and remove jammed or torn
media.
3
178
2
Solving problems with the printer
EN
4
5
EN
4
Reinstall the transfer belt.
5
Close the drawer. The printer will
warm up and return to the READY
state.
Note
If this action does not resolve the
problem, the printer will display an
alternate message.
Chapter 9
179
Clearing jams in the Tray 2 area
1
Note
It is a good idea to inspect the input trays
when clearing paper jams. However,
opening and closing input trays has no
effect on clearing paper jam messages.
2
1
Pull out Tray 2 and place it on a flat
surface.
2
Inspect the rollers and remove any
partially fed media. Be sure to
remove all pieces of media.
3
Inspect inside the printer and
remove all media.
4
Close Tray 2.
3
4
180
Solving problems with the printer
EN
Clearing jams in the optional Tray 3 area
1
2
Note
It is a good idea to inspect the input trays
when clearing paper jams. However,
opening and closing input trays has no
effect on clearing paper jam messages.
1
Pull out Tray 3 and place it on a flat
surface.
2
Inspect the rollers and remove any
partially fed media. Be sure to
remove all pieces of media.
3
Inspect inside the printer and
remove all jammed or torn media.
4
Close Tray 3.
3
4
EN
Chapter 9
181
Clearing jams in the rear door areas
1
WARNING!
Do not touch the fuser: it is hot and could
cause burns! The fuser’s operating
temperature is 190° C (374° F). Wait 30
minutes to allow the fuser to cool down
before touching the fuser.
1
If the duplex printing accessory is
installed, open the rear duplex cover.
2
Open the upper rear door.
3
Inspect the upper paper path area
inside the rear door and remove any
jammed or torn media.
4
Open the fuser door and remove any
media.
2
3
4
182
Solving problems with the printer
EN
5
6
5
Close the fuser door.
6
Close the upper rear door.
7
Close the rear duplex cover if it was
opened. The printer will warm up
and return to the READY state.
Note
If these actions do not resolve the
problem, the printer will display an
alternate jam message.
7
EN
Chapter 9
183
Clearing jams in the front duplex drawer area
1
1
Pull out the duplex drawer and place
it on a flat surface.
2
Remove media from the duplex
drawer. Rotate the thumbwheel to
eject media. Be sure to remove any
torn pieces of media.
3
Inspect inside the printer and
remove media. Be sure to remove
any torn pieces of media.
4
Close the duplex drawer. The printer
will return to the READY state within a
few minutes.
2
Note
If these actions do not resolve the
problem, the printer will display an
alternate jam message.
3
4
184
Solving problems with the printer
EN
Media-handling problems
Use only media that meets the specifications outlined in the
HP LaserJet Printer Family Paper Specification Guide.
For media specifications for this printer, see “Supported media
weights and sizes” on page 67.
Printer feeds multiple sheets
Cause
Solution
The input tray is overfilled.
Remove excess media from the input tray.
The media is not under the tabs in the input
tray (Trays 2 and 3).
Open the input tray and verify that the media is
seated under the metal tabs.
Print media is sticking together.
Remove media, flex it, rotate it 180 degrees or
flip it over, and then reload it into the tray.
Note: Do not fan media. Fanning can cause
static electricity, which can cause media to
stick together.
Media does not meet the specifications for this Only use media that meets the media-use
printer.
specifications for this printer (see “Supported
media weights and sizes” on page 67).
Printer feeds incorrect page size
Cause
Solution
The correct media size is not loaded in the
input tray.
Load the correct size media in the input tray.
The correct media size is not selected in your
software application or printer driver.
Select the correct media size from your
software application or printer driver.
The correct media size for Tray 1 is not
selected in the printer control panel.
From the control panel, select the correct
media size for Tray 1 (only available with
TRAY=CASSETTE).
Media-size knob is incorrectly set (Tray 3).
Verify that the media-size knob on the side of
Tray 3 is set to the proper media size.
EN
Chapter 9
185
Media does not feed automatically
Cause
Solution
Manual feed is selected in the software
application.
This printer does not support manual feed.
Do not select manual feed in your software
application.
The correct size of media is not loaded.
Load the correct size of media.
The input tray is empty.
Load media into the input tray.
Media from a previous jam has not been
completely removed.
Open the printer and remove any media in the
paper path. Closely inspect the fuser area for
jams. See “Clearing paper jams” on page 178.
Media does not feed from Input Trays 2 or 3
Cause
Solution
Manual feed is selected in the software
application.
This printer does not support manual feed.
Do not select manual feed in your software
application.
The correct size of media is not loaded.
Load the correct size of media.
The input tray is empty.
Load media in the input tray.
The correct media type for the input tray is not From the printer control panel, select the
selected in the printer control panel.
correct media type for the input tray.
Media from a previous jam has not been
completely removed.
Open the printer and remove any media in the
paper path. Closely inspect the fuser area for
jams. See “Clearing paper jams” on page 178.
Tray 3 (500-sheet paper feeder) does not
appear as an input tray option.
Tray 3 only displays as an option if it is
installed. Verify that Tray 3 is correctly
installed. Verify that the printer driver has been
configured to recognize Tray 3.
The tray is incorrectly installed.
Reinstall Tray 3.
Print a configuration page to confirm that
Tray 3 is configured properly.
186
Solving problems with the printer
EN
Transparencies or glossy paper will not feed
Cause
Solution
The correct media type is not specified in your Verify that the correct media type is selected in
software or printer driver.
your software or printer driver.
The input tray is overfilled.
Remove excess media from the input tray.
Do not load more than 50 transparencies in
any tray.
Media in another input tray is the same size as Make sure that the input tray containing the
the transparencies and the printer is defaulting transparencies or glossy paper is selected in
to the other tray.
your software application or printer driver. Use
the printer control panel to configure the tray to
the media type loaded.
Envelopes jam or will not feed in the printer
Cause
Solution
Envelopes are loaded in an unsupported tray. Load envelopes into Tray 1.
Envelopes should only be printed from Tray 1.
Envelopes are curled or damaged.
Try using different envelopes.
Envelopes are sealing because the moisture
content is too high.
Try using different envelopes.
Envelope orientation is incorrect.
Verify that the envelope is loaded correctly.
See “Loading envelopes into Tray 1” on
page 80.
The envelopes being used are not supported
by this printer.
See “Supported media weights and sizes” on
page 67 or the HP LaserJet Printer Family
Paper Specification Guide.
EN
Chapter 9
187
Output is curled or wrinkled
Cause
Solution
Media does not meet the specifications for this Only use media that meets the media-use
printer.
specifications for this printer (see “Supported
media weights and sizes” on page 67).
Media is damaged or in poor condition.
Remove media from the input tray and load
media that is in good condition.
Printer is operating in an excessively humid
environment.
Verify that the printing environment is within
humidity specifications.
You are printing large, solid-filled areas.
Large, solid-filled areas can cause excessive
curl. Try using a different pattern.
Media used was not stored correctly and may Remove media and replace it with media from
have absorbed moisture.
a fresh, unopened package.
Media has poorly cut edges.
Remove media, flex it, rotate it 180 degrees or
turn it over, and then reload it into the input
tray. If the problem persists, replace the media.
You are printing to the top output bin.
Use other output bin.
Printer will not duplex
Cause
Solution
Printer is not recognizing the duplex printing
accessory.
Print a configuration page to verify
configuration. Set up the printer driver to
recognize the duplex printing accessory. Verify
that the duplex printing accessory power cord
is plugged in.
You are trying to duplex on an unsupported
media.
Verify that the media you are using is
supported for duplex printing.
The door to the rear output bin is open.
Close the door to the rear output bin.
188
Solving problems with the printer
EN
Printer response problems
No display message
Cause
Solution
The printer’s power switch (standby button) is
in the standby position.
Verify that the printer is on. Fans may run while
the printer is in standby mode (off).
The printer’s memory DIMMs are defective or
installed incorrectly.
Verify that the printer’s memory DIMMs are
correctly installed and are not defective. See
“Installing DIMMs” on page 217.
The power cord is not firmly plugged into both Turn off the printer and then disconnect and
the printer and the power receptacle.
reconnect the power cord. Turn the printer
back on.
The line voltage is incorrect for the printer
power configuration.
Connect the printer to a proper voltage source,
as specified on the Power Rating Label on the
back of the printer.
The power cord is damaged or excessively
worn.
Replace the power cord.
The power source receptacle is not working
correctly.
Connect the printer to a different power
receptacle.
EN
Chapter 9
189
Printer is on, but nothing prints
Cause
Solution
The printer’s READY indicator light is not lit.
Press GO to return the printer to the READY
state.
The top cover is not closed properly.
Close the top cover firmly, verifying that it is
properly latched.
The DATA indicator is flashing.
The printer is probably still receiving data. Wait
for the DATA indicator to stop flashing.
[COLOR] TONER OUT appears on the printer
display.
Replace the toner cartridge specified on the
printer display.
A printer message other than READY appears
on the printer control panel.
See Chapter 8 for an explanation of printer
control panel messages.
Your parallel port may have a DOS timeout
error.
Add a MODE command to your
AUTOEXEC.BAT file. See your DOS manual
for additional information.
The PS (PostScript Emulation) personality is
not selected.
Select PS or AUTO for the printer language (see
Chapter 2).
The correct driver is not selected in your
software application or printer driver.
Select the driver for PostScript Emulation for
this printer in your software application or
printer driver.
The printer is not properly configured.
See Chapter 6 for configuration information.
The computer port is not configured or is not
working properly.
Run another peripheral connected to this port
to verify that the port is working properly.
The printer has not been correctly named for
your network or for a Macintosh computer.
Use the appropriate utility to name the printer
on the network. For Macintosh computers,
name the printer from within the Chooser
menu.
190
Solving problems with the printer
EN
Printer is on, but is not receiving data
Cause
Solution
The printer’s READY indicator light is not lit.
Press GO to return the printer to the READY
state.
The top cover is not closed properly.
Close the top cover firmly.
A printer message other than READY appears
on the printer control panel.
See Chapter 8 for troubleshooting information.
The interface cable is not correct for this
configuration.
Select the correct interface cable for your
configuration. See Chapter 6 for more
information on printer interfaces.
The interface cable is not securely connected
to both the printer and the computer.
Disconnect and reconnect the interface cable.
The printer is not configured correctly.
See Chapter 6 for configuration information.
The interface configurations on the printer’s
configuration page do not match the
configurations on the host computer.
Configure the printer to match your computer
configuration.
Your computer is not working properly.
Try using an application that you know works
properly to check your computer, or, in DOS,
type Dir > Prn at the DOS prompt.
The computer port that the printer is
connected to is not configured or is not
working properly.
Run another peripheral connected to this port
to check the port operation.
The printer has not been correctly named for
your network or Macintosh computer.
Use the appropriate utility to name the printer
on the network. For Macintosh computers,
name the printer from within the Chooser
menu.
EN
Chapter 9
191
Unable to select the printer from the computer
Cause
Solution
If you are using a switch box, the printer may
not be selected for your computer.
Select the correct printer through your switch
box.
The printer’s READY indicator light is not lit.
Press GO to return the printer to the READY
state.
The input tray specified is empty.
Load the correct size media into the input tray.
A printer message other than READY appears
on the printer control panel.
See Chapter 8.
The correct printer driver is not installed in
your computer.
Install the correct printer driver.
The correct printer and port are not selected
on your computer.
Select the correct printer and port.
Your network is not configured properly for this Use your network software to verify the
printer.
printer’s network configuration, or consult with
your network administrator.
The power source receptacle is not working
correctly.
192
Solving problems with the printer
Connect the printer to a different power
receptacle.
EN
Printer control panel problems
Control panel settings work incorrectly
Problem
Solution
The printer control panel display is blank or is
not lit, even when the fan is running.
Fans may run while the printer is in standby
mode (off). Press the printer’s power switch to
turn the printer on.
Printer settings in your software application or Settings in your software application or printer
printer driver are different from the printer
driver override printer control panel settings.
control panel settings.
Verify that the settings in your software
application or printer driver are correct.
Control panel settings were not correctly saved Reselect the control panel settings and then
after they were changed.
press SELECT. An asterisk (*) should appear to
the right of the setting.
The Data indicator is lit and there are no pages Buffered data exists in the printer. Pressing GO
printing.
prints the buffered data using current control
panel settings and then activates the new
control panel settings.
If you are on a network, another user may
have changed printer control panel settings.
Consult your network administrator to
coordinate changes to printer control panel
settings.
Unable to select Tray 3 (optional 500-sheet paper feeder)
Problem
Solution
Tray 3 (500-sheet paper feeder) does not
appear as an input tray option.
Tray 3 only displays as an option if it is
installed. Verify that Tray 3 is correctly
installed. Verify that the printer driver has been
configured to recognize Tray 3.
EN
Chapter 9
193
Print quality troubleshooting
Unless otherwise specified, all references in this section to horizontal
or vertical directions of print quality problems refer to problems found
on letter and A4-sized media in portrait orientation.
Additional defect information is found in the following sections:
●
Repetitive defects troubleshooting (see page 194)
●
Image defects troubleshooting (see page 196)
●
Overhead transparency defects (see page 207)
Repetitive image defects
Repetitive defects are defects that occur on the page. Most repetitive
defects are caused by problems with one of the following:
CAUTION
●
Developer roller
●
Fuser
●
Charge roller
●
Imaging drum
●
Cleaning roller
●
Transfer belt
●
Transfer roller
Do not expose the imaging drum to light, and be careful not to scratch
or get fingerprints on the drum surface during cleaning. Do not blow on
the imaging drum.
Image defect ruler
The image defect ruler is a tool that can be used to find the printer
component that is causing a repeating image defect. To use the
image defect ruler, print it on a transparency, Then place the ruler
over the printed page containing the image defect.
194
Solving problems with the printer
EN
Image defect ruler
First occurrence of print defect
Color toner cartridge 30 mm (1.2 in)
Black toner cartridge 37 mm (1.5 in)
Transfer belt 40 mm (1.6 in)
Transfer roller 53 mm (2.1 in)
Fuser 131 mm (5.2 in)
Imaging drum 152 mm (6 in)
EN
Chapter 9
195
Image defects
For more information on a specific image defect, see the page
numbers below each image in the table below.
Image defect table
Background scatter
(see page 197)
Banding and
horizontal lines
(see page 197)
Black lines
(see page 198)
Blank page(s or
missing color)
(see page 199)
Character voids
(see page 199)
Distorted image
(see page 200)
Dropouts
(see page 200)
Faded print, random
faded areas
(see page 201)
No image
available
Toner smear
(see page 202)
Ghosting
(see page 203)
No image
available
Gray streaks
(see page 203)
Irregular raised spots
or stray toner
(see page 203)
No image
available
Light, dark, faded print
(see page 204)
No image
available
Sharkskin
(see page 205)
196
Non-adhering toner
(see page 204)
Marbled output
(see page 205)
Random black spots
(see page 205)
No image
available
Sunburn
(see page 205)
Solving problems with the printer
Imaging drum defects
(see page 206)
EN
Background scatter
●
The media does not meet HP specifications. Use media that
meets HP specifications (see page 67).
●
The toner cartridge is defective, replace the toner cartridge.
●
There is excess toner inside of the printer. Clean the printer (see
page 148).
●
The transfer roller is dirty or worn.
Banding and horizontal lines
Banding occurs when solid fill areas show streaks or bands of shade
variations. This can be caused by:
●
Consumables that are beyond their life.
●
Improper consumable storage.
If the problem persists:
●
Print a configuration page to check the life of the consumables.
Replace any consumable that is past its rated life.
●
Banding is more visible in some halftone patterns than others. If
the defect occurs only once on a letter- or A4-size sheet, try
printing the pattern on a legal- or A3-size sheet.
●
Observe the following from the test sample:
• Check to see if the defect spans all color planes.
• If the defect is in all color planes, does the defect produce a
straight line through all color planes, or does it move from one
color plane to the next?
• If the defect moves from one color plane to the next, measure
the amount it moves. This movement amount is called the
“procession.” Keep in mind the print order is K-M-C-Y. Measure
the procession from K to M or M to C, not K to C.
CAUTION
EN
Do not expose the imaging drum to light for more than 15 seconds. The
drum is light sensitive, and exposure to light can cause permanent
damage.
Chapter 9
197
Banding — horizontal
No image
available
●
The imaging drum may have been exposed to light, and will need
to be replaced.
●
The transfer belt may accumulate excess toner on its rollers
causing a random mechanical banding. If you notice buildup on
the rollers, replace the transfer kit.
Banding — vertical
No image
available
The blade on the toner cartridge can develop notches over time. If
you observe severe notching, replace the toner cartridge.
As the imaging drum gets older, the charge roller doesn’t charge the
imaging drum as well as it used to. If you notice buildup or
contamination on the charge roller, replace the imaging drum.
Black lines
198
●
The toner cartridge is defective, and should be replaced.
●
The toner cartridge is not installed properly. Reinstall the toner
cartridge.
●
The fusing assembly is contaminated or damaged. Replace the
fuser kit.
●
The imaging drum is damaged or the waste toner collection in the
drum is full. Replace the imaging drum.
Solving problems with the printer
EN
Blank pages or missing a color
●
Your software application is sending an extra page-eject
command.
• Verify that a separator page is not enabled in the printer driver
by accessing the driver properties.
• Check to verify that an extra page has not been inserted within
the document.
●
There is a problem with the network configuration. Some sharing
devices on networks may generate a blank page as a separator.
• Check with the network administrator.
●
The printer may be feeding two or more pages at once because
the paper is difficult to separate.
●
The sealing tape has been left in the toner cartridge. Remove the
sealing tape from the toner cartridge color that is missing from
the printed image.
●
The toner cartridge is empty or defective. Replace the toner
cartridge color that is missing from the printed image.
Character voids
●
Use paper that meets HP paper specifications (see page 67).
• The surface of the media is too rough or the media’s surface is
too smooth for proper toner adhesion.
• The media you are using is to heavy for the printer, and the
toner is not fusing to the media.
• Printing is on the wrong side of the paper.
• The transparencies are not designed for proper toner
adhesion. Only use transparencies designed for HP Color
LaserJet printers.
• The humidity content of your media is too high or too low. Try a
freshly opened ream or try a different type of paper.
EN
Chapter 9
199
Distorted image
●
The paper does not meet HP paper specifications or is stored
improperly (see page 67).
●
The printer operating environment does not meet HP
specifications (see page 235).
Dropouts
200
●
The paper does not meet HP paper specifications (see page 67).
●
The printer’s operating environment does not meet specifications
(see page 235).
●
The print density is set incorrectly. Change to a darker setting and
retry printing.
●
The humidity content of your media is too high or too low. Try a
freshly opened ream or try a different type of paper.
Solving problems with the printer
EN
Faded print, faded areas, or faded vertical
streaks
EN
●
The message TRANSFER KIT LOW ORDER KIT appears on the
printer control panel. Print out a configuration page to verify the
remaining life of the transfer belt. Replace the transfer belt if
necessary.
●
The moisture content of your paper is uneven or too low. Use
paper from a different source or from an unopened ream of paper.
●
Some areas of the paper reject toner. Use paper from a different
source or from an unopened ream of paper.
●
Your paper is excessively rough. Use a smoother, xerographic
paper.
●
The letterhead you are using is printed on rough paper. Use a
smoother, xerographic paper. If this solves your problem, consult
with the printer of your letterhead to verify that the paper used
meets the specifications for this printer (see page 67).
●
Media does not meet the specifications for this printer (see
page 67).
●
The printer is operating in excessively humid or dry conditions.
Verify that the printing environment is within humidity
specifications (see page 235).
●
If a TONER LOW or TONER OUT message is displayed on the
printer control panel, replace the appropriate toner cartridge. If
the problem persists, call for service.
●
Excess toner may have been deposited on the transfer belt. Use
a lint-free cloth to clean any excess toner from the transfer belt
surface.
●
The cap on the ITB lift mechanism might be missing.
Chapter 9
201
Toner smear
202
●
There is excess toner on the paper. Reprint the page.
●
The fusing rollers have excess toner on them. Print 5 to 10 pages
to clean the excess toner from the rollers.
●
The media does not meet HP specifications (see page 67). Use
media that meets HP media specifications.
●
The toner cartridge is defective. Replace the toner cartridge for
the color that is smearing.
●
The fusing assembly is defective. Replace the fuser kit.
●
There is excess toner in the printer. Print 5 to 10 pages to clear
the excess toner, and clean the printer (see page 148).
●
The transfer roller is not seated correctly. Remove and reseat the
transfer roller.
●
A label or a piece of paper may be stuck to the transfer belt or a
roller on the transfer belt. Remove the label or piece of paper.
Solving problems with the printer
EN
Ghosting
No image
available
Full-page ghosting occurs when an image prints in full color on one
page, but a faded copy of it is also seen on the following page.
●
Replace the transfer kit.
●
If the imaging drum is near end of life, replace it.
●
If the toner cartridge is near end of life, replace it.
●
The media you are using is not within specifications. Try a
different type of paper.
Gray streaks
No image
available
●
The paper does not meet HP paper specifications or is stored
improperly.
●
The printer operating environment does not meet specifications.
●
The toner cartridge is defective. Replace the black toner
cartridge.
●
There is excess toner inside of the printer. Clean the printer (see
page 148).
●
The imaging drum is defective or at the end of its life. Replace the
drum kit.
Irregular, raised streaks
To diagnose this print quality problem, lay the printed page on a hard
smooth surface, and feel the streaks of toner. The spots or streaks will
not look raised, but will feel raised to the touch.
EN
●
Make sure that all media is cleared from the paper path (see
page 176).
●
The fuser roller is damaged. Replace the fuser kit.
●
If one toner color is streaking, that toner cartridge has been
damaged. Replace the toner cartridge for the streaking color.
●
The paper does not meet HP paper specifications (see page 67).
Use media that meets HP media specifications.
Chapter 9
203
Light, dark, or faded print
●
The message TRANSFER KIT LOW REPLACE TRANSFER KIT
appears on the printer control panel. Print out a configuration
page (see page 49) to verify the remaining life of the transfer belt.
Replace the transfer belt if necessary.
●
The moisture content of your paper is uneven or too low. Use
paper from a different source or from an unopened ream of paper.
●
Some areas of the paper reject toner. Use paper from a different
source or from an unopened ream of paper.
●
Your paper is excessively rough. Use a smoother, xerographic
paper.
●
The letterhead you are using is printed on rough paper. Try a
smooth xerographic paper. If this solves your problem, consult
with the printer of your letterhead to verify that the paper used
meets the specifications for this printer (see page 67).
●
Media does not meet the specifications for this printer. Only use
media that meets the media specifications for this printer (see
page 67).
●
The printer is operating in excessively humid or dry conditions.
Verify that the printing environment is within humidity
specifications (see page 235).
●
If a TONER LOW or TONER OUT message is displayed on the
printer control panel, replace the appropriate toner cartridge. If
the problem persists, call for service.
●
Excess toner may have been deposited on the transfer belt. Use
a lint-free cloth to clean any excess toner from the transfer belt
surface.
Non-adhering toner
204
●
There is excess toner in the printer. Clean the printer (see
page 148).
●
The toner cartridge is defective. Replace the toner cartridge color
that is not adhering to the media.
●
The paper is too smooth. Use media that meets HP media
specifications (see page 67).
●
The driver setting is set incorrectly. Change the paper type setting
to heavy or glossy.
●
The fuser is defective. Replace the fuser kit.
Solving problems with the printer
EN
Marbled output
No image
available
●
Print a configuration page(see page 49), and refer to the color
blocks at the bottom of the page. Replace the toner cartridge of
the color or colors that are marbled.
Random spots
●
The media does not meet HP media specifications (see page 67).
Use paper that meets HP media specifications.
●
The printer requires cleaning (see page 148).
●
If the random spot are one color, replace the toner cartridge for
that color. If the random spots are multiple colors, replace the
drum kit.
Sharkskin
Images with sharkskin have a rough, mottled finish.
No image
available
●
Use media that meets HP media specifications (see page 67).
●
Make sure the humidity and temperature are within specifications
(see page 235).
●
Do not use automatic duplex mode. Duplex manually or not at all.
Sunburn
No image
available
CAUTION
EN
The imaging drum might have been exposed to light. Characteristics
of sunburn are streaked or blurred lines across the length of the page
(side-to-side on portrait, or top-to-bottom on landscape).
●
Print 50 to 100 pages on the imaging drum to remove the
sunburn.
●
If sunburn characteristics are still occurring, allow the imaging
drum to sit in a dark place for two to three days.
●
If sunburn is severe (the characteristics don’t go away), replace
the imaging drum.
Do not expose the imaging drum to light for more than 15 seconds. The
drum is light sensitive, and exposure to light can cause permanent
damage.
Chapter 9
205
Imaging drum defects
Causes:
●
Damage such as scratches or dents on the imaging drum. These
usually appear as black or white marks on the page.
●
Paper dust adhering to the imaging drum. These usually appear
as white marks in the dark printed areas of the page.
●
Exposure of portions of the imaging drum to light. This causes
light sections in the printed output. The life of the imaging drum is
shortened by exposure to light.
Actions:
Note
206
●
Print at least four configuration pages to determine if the defect
repeats in the same horizontal orientation.
●
Inspect the imaging drum for scratches, dents, or other damage.
Replace if needed.
●
If the problem is dust, remove the dust with isopropyl alcohol
applied with a lint-free, static-free wipe. Try this only if the print
defect is unacceptable and the only other alternative is replacing
the imaging drum.
●
Defects caused by exposure to light might clear up over time. If
severe, replace the imaging drum.
In certain areas of California, air pollution control regulations restrict
the use of liquid Isopropyl Alcohol (IPA) as a cleaning agent. In those
areas of California, please disregard the previous recommendations
and use a dry, lint-free cloth. The cloth may be moistened with water
if desired.
Solving problems with the printer
EN
Overhead transparency defects
Overhead transparencies may display any of the image quality
defects shown in the previous samples. In addition, because
transparencies are pliable while in the print path, they are subject to
being marked by the media-handling components.
Note
WWW
Allow transparencies to cool at least 30 seconds before handling them.
●
Make sure that “transparency” is checked as the media type in
the Paper Tab in the printer driver. Also, make sure that the media
input tray is correctly configured for transparencies. When
Transparency is selected as the media type and ColorSmart II is
selected on the Color tab, the printer will use a color treatment
optimized for projection.
●
If transparencies show lines and creases in the media and/or the
printed output, compare the defect against the repetitive defect
ruler (page 195) to help isolate the cause to a particular
component.
●
Check that the transparencies meet the specifications listed in the
HP LaserJet Family Paper Specification Guide.
See Appendix D or http://www.hp.com/support/lj4550 for HP LaserJet
Family Paper Specification Guide ordering information.
For downloadable manuals, go to http://www.hp.com/support/lj4550.
When you connect, select Manuals.
●
If the transparencies have spots or smudges, reprint them being
careful not to touch the surface of the media. Skin oils can
contaminate transparencies, causing spots and smudges.
●
Small random dark areas on the trailing edge of solid fill pages
may be caused by transparencies sticking together in the face up
bin. Try printing the job in smaller batches.
●
Send transparencies only to the face-down output bin.
Transparencies created on the printer may look rough, but they can
still be used successfully on reflective-type (portable) transparency
projectors.
EN
Chapter 9
207
Dull or dark transparencies
●
If the transparency colors are dull or dark, ensure the
transparencies meet the specifications for this printer (part
number C2934A for letter, and C2936A for A4).
●
The selected colors are undesirable when printed. Select different
colors in your software application or printer driver.
●
Spots and smudges appear in the background areas of
transparencies when they are projected. Oil from your hands can
cause spots or smudges on transparencies. Reprint the
transparencies, being careful not to touch the surface of the
transparencies.
●
You are using a reflective overhead projector. Use a standard
overhead projector.
Rippled or wavy transparencies
No image
available
You are using transparencies that do not meet the specifications for
this printer. Use only transparencies that meet the media
specifications for this printer (see page 67).
Incorrect image on transparencies
No image
available
208
This might occur even though the correct media is loaded in the
correct tray. Toner might not adhere to the media and an image might
show up on pages where it isn’t meant to appear. For more
information see “Ghosting” on page 203.
Solving problems with the printer
EN
Repetitive defects on transparencies
●
Unwanted marks of the same size and shape appear in the same
vertical area on most pages. Print out a configuration page to
verify the remaining life of the imaging drum. If the printer control
panel displays DRUM LIFE OUT REPLACE KIT, replace the
imaging drum.
●
Unwanted marks of the same size and shape appear more than
once in the same vertical area on transparencies or glossy media
only. The fuser roller is damaged or the fuser is beyond its useful
life. Print out a configuration page to verify the remaining life of
the fuser. If the printer control panel displays FUSER LIFE OUT
REPLACE KIT, replace the fuser.
●
Repetitive defects appear only in one color. Check the
corresponding toner cartridge.
Streaking or smudges on transparencies
EN
●
The printer recently jammed. Print 5 to 10 pages to clean the
printer.
●
You recently changed to a different media size. Print 5 to 10
pages to clean the printer.
●
You are using transparencies that do not meet the media
specifications for this printer. Use only transparencies that meet
the media specifications for this printer (see page 67).
●
The imaging drum has exceeded its useful life. Print out a
configuration page to verify the remaining life of the imaging
drum. If the printer control panel displays DRUM LIFE OUT
REPLACE KIT, replace the imaging drum.
Chapter 9
209
Color printing problems
Printing black instead of color
Problem
Solution
Color mode is not selected in your software
application or printer driver.
Select color mode instead of grayscale or
monochrome mode in your software
application or printer driver.
The correct printer driver is not selected in
your software application.
Select the correct printer driver.
The printer is not properly configured.
Verify the printer configuration by printing a
configuration page.
No color appears on the configuration page.
Consult your service representative.
Missing color or incorrect shade
Problem
Solution
Your media does not meet the specifications
for this printer.
See the HP LaserJet Printer Family Paper
Specification Guide.
See Appendix D or http://www.hp.com/
support/lj4550 for HP LaserJet Family Paper
Specification Guide ordering information.
For downloadable manuals, go to http://
www.hp.com/support/lj4550. When you
connect, select Manuals.
You are operating the printer in excessively
humid conditions.
Verify that the printer’s environment is within
humidity specifications.
The toner density sensor may need cleaning.
Clean the toner density sensor (see “Cleaning
the toner density sensor” on page 149).
210
Solving problems with the printer
EN
Inconsistent colors after loading toner
Problem
Solution
Another toner color may be low.
Check the printer control panel for a TONER LOW
message and replace the toner cartridge if
necessary.
Toner cartridges may be improperly installed.
Verify that each toner cartridge is installed
properly.
Printed colors do not match screen colors
Problem
Solution
Extremely light screen colors are not being
printed.
Your software application may interpret
extremely light colors as white. If so, avoid
using extremely light colors.
Extremely dark screen colors are being printed Your software application may interpret
in black.
extremely dark colors as black. If so, avoid
using extremely dark colors.
The colors on your computer monitor differ
from the printer output.
Try selecting Screen Match in the color control
tab of your printer driver.
The toner density sensor may need cleaning.
See “Cleaning the toner density sensor” on
page 149.
Note
EN
Several factors can influence your ability to match printed colors to
those on your monitor. These factors include print media, overhead
lighting, software applications, operating system palettes, monitors,
and video cards and drivers.
Chapter 9
211
Incorrect printer output
Incorrect fonts are printed
Problem
Solution
The font has not been correctly selected in
your software application.
Re-select the font in your software application.
The font is not available to the printer.
Download the font to the printer or use another
font. (In Windows, the driver does this
automatically.)
The correct printer driver is not selected.
Select the correct printer driver.
Unable to print all characters in a symbol set
Problem
Solution
The correct font is not selected.
Select the correct font.
The correct symbol set is not selected.
Select the correct symbol set.
The selected character is not supported by
your software application.
See the documentation for your software
application.
The selected symbol is not supported by the
font.
Use a font that supports the selected symbol.
Drifting text between printouts
Problem
Solution
Your software application is not resetting the
printer to the top of the page.
See the user guide for your software
application or the PCL/PJL Technical
Reference Package for specific information.
(See page 32 for ordering information.)
212
Solving problems with the printer
EN
Erratic, missing characters or interrupted printout
Problem
Solution
The interface cable is of poor quality.
Try using a different, higher-quality, IEEEcompliant cable. Parallel cables can be no
longer than 10 meters (30 feet).
The interface cable is loose.
Disconnect and reconnect the interface cable.
The interface cable is damaged or bad.
Try using a different interface cable.
The power cable is loose.
Disconnect and reconnect the power cable.
You are attempting to print a PCL job with the From the printer control panel, select the
printer configured for PostScript Emulation.
correct printer personality and then resend the
print job.
You are attempting to print a PostScript job
with the printer configured for PCL.
From the printer control panel, select the
correct printer personality and then resend the
print job.
Partial printout
Problem
Solution
A memory error message appears on the
printer control panel.
1) Free up printer memory by deleting
unneeded downloaded fonts, style sheets, and
macros from printer memory; or
2) Add more memory to the printer.
The file you are printing contain errors.
Check your software application to verify that
the file does not contain errors. To do so:
1) Print another file that you know is error-free
from within the same application; or
2) Print the file from another application.
EN
Chapter 9
213
Software application problems
Unable to change system selections through software
Cause
Solution
System software changes are locked out by
the printer control panel.
See Chapter 6 “Printer Interfaces”. Consult
with your network administrator.
Your software application does not support
system changes.
See the documentation for your software
application.
The correct printer driver is not loaded.
Load the correct printer driver.
The correct application driver is not loaded.
Load the correct application driver.
Unable to select a font from the software
Cause
Solution
The font is not available in your software
application.
See the documentation for your software
application.
Unable to select colors from the software
Cause
Solution
Your software application does not support
color.
See the documentation for your software
application.
Color mode is not selected in your software
application or printer driver.
Select color mode instead of grayscale or
monochrome mode.
The correct printer driver is not loaded.
Load the correct printer driver.
Printer driver does not recognize Tray 3 or the Duplex Printing Accessory
Cause
Solution
The printer driver has not been configured to
recognize Tray 3 or the duplex printing
accessory.
See the online Help for the printer driver for
instructions on how to configure the driver to
recognize printer accessories.
The accessory may not be installed.
Verify that the accessory is properly installed.
214
Solving problems with the printer
EN
A
DIMM Installation
Overview
The printer is designed for easy installation of additional memory.
This chapter provides information on installing memory.
EN
Appendix A
215
DIMM configuration
This printer supports up to 192 MB of memory. You can add additional
Random Access Memory (RAM) to this printer by installing Dual
Inline Memory Modules (DIMMs). The printer uses 168-pin,
non-parity, synchronous DRAM memory modules. Extended Data
Output (EDO) DIMMs are not supported.
You can install 64 or 128 MB DIMMs into either of the printer’s
available 168-pin DIMM slots.
CAUTION
Do not attempt to remove the DIMM in slot #1 (see figure A-1). The
DIMM in slot #1 is part of the printer’s firmware. Removing it will affect
printer operation.
Figure A-1
Do not remove the DIMM in slot #1.
216
DIMM Installation
EN
Installing DIMMs
To install a DIMM
1
CAUTION
To reduce the possibility of damage
caused by static electricity, always wear
an electrostatic discharge (ESD) wrist
strap or touch the surface of the
antistatic package before handling
DIMMs. When handling the formatter
board, wear an antistatic wrist strap or
frequently touch bare metal on the
printer.
1
Turn the printer off and wait for the
fans to stop. This will take a few
minutes.
2
CAUTION
Wait for the printer’s fans to turn off
before unplugging the printer.
3
EN
2
Disconnect all power and interface
cables.
3
Locate the formatter board in the
upper-left corner of the rear of the
printer and loosen the six screws.
Appendix A
217
4
5
4
Slide out the formatter board and set
it on a clean, flat, grounded surface.
5
Align the connectors on the DIMM
with the notches in the DIMM slot.
Insert the DIMM into the slot and
then firmly push the DIMM lift locking
levers into position.
Note
Repeat step 5 for each DIMM you are
installing.
6
Insert the formatter board into the
printer.
6
218
DIMM Installation
EN
7
7
Tighten the screws.
8
Reconnect the power and interface
cables.
9
Turn the power on. The printer
automatically updates the memory
configuration to include the newly
installed DIMMs.
8
9
EN
Appendix A
219
Verifying DIMM installation
To verify that the DIMM installation was successful, print out a
configuration page (see Chapter 2). If the DIMM has been installed
properly, the figure in the Memory section of the configuration page
will reflect the new total amount of memory. If the DIMM contains
resources such as fonts or macros, those will be displayed on the
printer’s test pages.
If the printer control panel displays an error message, see Chapter 8
for descriptions of printer control panel messages.
220
DIMM Installation
EN
Resource saving/permanent resources
Utilities or jobs that you download to the printer sometimes include
resources (for example, fonts, macros, or patterns). Resources that
are internally marked as permanent remain in the printer’s memory
until you turn the printer’s power off.
Use the following guidelines if you make use of the PDL (page
description language) ability to mark resources as permanent. For
technical details, see an appropriate PDL reference for PCL or PS.
Note
EN
●
Mark resources as permanent only when it is absolutely
necessary that they remain in memory while the printer's power is
turned on.
●
Send permanent resources to the printer only at the beginning of
a print job and not while the printer is printing.
Overusing permanent resources or downloading them while the printer
is printing might decrease the printer’s performance or its ability to print
complex pages.
Appendix A
221
Installing EIO cards/mass storage
Turn off the printer before installing the EIO card or mass storage
device.
See the following figure for orientation and location of the EIO card or
optional mass storage device, such as a hard disk.
Use HP Resource Manager to manage fonts on a mass storage
device (page 27). For more information, see the printer software help.
HP is constantly introducing new software tools for use with your
printer. These tools are available from the Internet free of charge. See
page 12 for how to visit the HP website for more information.
After you have installed a new device, print a configuration page (see
page 49).
222
DIMM Installation
EN
B
PCL commands
Overview
This printer supports the use of the Printer Control Language
(PCL). Most software applications provide the printer with
necessary language information. However, some applications do
not provide the printer with language information and require the
user to enter printer commands. See your software application
documentation for instructions on entering printer commands.
This appendix is not intended to provide comprehensive
information about PCL commands. Rather, it provides a quick
reference for users who are already familiar with the PCL
command structure.
WWW
EN
For more information, see the PCL/PJL Technical Reference
Package. See page 32 for ordering information or visit
http://www.hp.com/support/lj4550.
Appendix B
223
PCL commands
PCL printer commands instruct the printer which tasks to perform or
which fonts to use for specific print jobs.
PJL commands
The HP Printer Job Language (PJL) provides control above PCL and
other printer languages. The four major functions provided by PJL
are:
●
printer language switching
●
job separation
●
printer configuration
●
status feedback from the host
PJL commands can be used to change printer default settings.
224
PCL commands
EN
Interpreting PCL printer command syntax
Before using printer commands, compare the following characters:
Note
Lowercase L:
l
Uppercase O:
O
Number one:
1
Number zero:
0
You must use the exact character and case specified for PCL printer
commands.
Many printer commands use the lowercase letter L (l) and the
number one (1), or the uppercase letter O (O) and the number zero
(0). These characters may not appear on your screen as shown here.
Figure B-1 shows the elements of a typical printer command (in this
example, a command for page orientation).
Figure B-1
EN
Printer command elements
1
Escape character (begins the escape sequence)
2
Value field (contains both alpha and numeric characters)
3
Category of command
4
Uppercase letter (terminates the escape sequence)
Appendix B
225
Combining escape sequences in PCL Printer
command syntax
Escape sequences can be combined into one escape-sequence
string. There are three important rules to follow when combining
code:
●
The first two characters after the <esc> character must be the
same.
●
When combining sequences, change the uppercase (termination)
character in each individual escape sequence to lowercase.
●
The final character of the escape sequence must be in
uppercase.
The following escape sequence would be sent to the printer to select
legal paper, landscape orientation, and eight lines per inch:
<esc>&l3A<esc>&l1O<esc>&l8D
The following escape sequence sends the same printer commands
by combining them into a shorter sequence:
<esc>&l3a1o8D
226
PCL commands
EN
Entering escape characters
Note
PCL printer commands always begin with the escape character
(<esc>).
The following table lists the escape character entries for various
applications.
Application
Escape Character Entry
What Appears
Lotus 1-2-3 and Symphony
Type \027
027
Microsoft Word for DOS
Hold down ALT and type 027
<—
WordPerfect for DOS
Type <27>
<27>
MS-DOS Editor
Hold down CTRL-P then ESC
<—
MS-DOS Edlin
Hold down CTRL-V then [
^[
dBase
?? CHR(27)+“command”
?? CHR(27)+“ ”
UNIX VI Editor
Hold down CTRL-V then ESC
^[
EN
Appendix B
227
Selecting PCL fonts
The printer font list provides PCL printer commands for selecting
fonts. (See “Printing a list of available printer fonts” on page 121.) A
sample section of a font list is shown below.
There is one variable box for entering symbol sets and one for
entering point size. Unless these variables are entered, the printer will
use defaults. For example, if you want a symbol set that contains linedraw characters, select the 10U (PC-8) or 12U (PC-850) symbol set.
Other common symbol set codes are listed in the “Common PCL
Printer Commands” section of this chapter.
Figure B-2
228
Font list
1
Symbol set
2
Point size
PCL commands
EN
Note
Fonts are either fixed or proportional in spacing. This printer supports
fixed fonts (Courier, Letter Gothic, and Lineprinter) and proportional
fonts, including CG Times, Arial®, and Times New Roman.
Fixed-space fonts are best used in applications such as spreadsheets
and databases, where it is important for columns to line up vertically.
Proportional-spaced fonts are generally used in word processing
applications.
Common PCL commands
The following table lists the most common PCL commands.
PCL Commands
Function
Command
Option(s)
Reset
<esc> E
n/a
Number of Copies
<esc> &l#X
1 to 999
Duplex/Simplex
<esc> &l#S
0 = Simplex (single-sided) printing
1 = Duplex (two-sided) with long-edge
binding
2 = Duplex (two-sided) with short-edge
binding
Job Control Commands
EN
Appendix B
229
PCL Commands (continued)
Page Control Commands
Paper Destination
<esc> &l#G
0 = Automatic Selector
1 = Top Output Bin (face-down)
2 = Rear Output Bin (face-up)
Paper Source
<esc> &l#H
0 = Prints or ejects current page
1 = Tray 2
4 = Tray 1
5 = Tray 3 (500-sheet paper feeder)
Paper Size
<esc> &l#A
1 = Executive
2 = Letter
3 = Legal
25 = A5
26 = A4
100 = B5
101 = Custom
80 = Monarch
81 = Commercial 10
90 = DL
91 = International CS
Paper Type
<esc> &n#
5WdBond = Bond
6WdPlain = Plain
6WdColor = Color
7WdLabels = Labels
9WdRecycled = Recycled
10WdCardstock = Cardstock
11WdLetterhead = Letterhead
11WdPrepunched = Prepunched
11WdPreprinted = Preprinted
13WdTransparency = Transparency
#WdCustompapertype = Custom
7WdRough = Rough
6WdVellum = Vellum
6WdHeavy = Heavy
6WdGloss = Gloss
8WdDefault = Default
230
PCL commands
EN
PCL Commands (continued)
Orientation
<esc> &l#O
0 = Portrait
1 = Landscape
2 = Reverse Portrait
3 = Reverse Landscape
Top Margin
<esc> &l#E
# = Number of lines
Text Length (bottom margin)
<esc> &l#F
# = Number of lines from top margin
Left Margin
<esc> &a#L
# = Column number
Right Margin
<esc> &a#M
# = Column number from left margin
Horizontal Motion Index
<esc> &k#H
1/120 inch increments (compresses print
horizontally)
Vertical Motion Index
<esc> &l#C
1/48 inch increments (compresses print
vertically)
Line Spacing
<esc> &l#D
# = lines per inch (1, 2, 3, 4, 5, 6, 12, 16,
24, 48)
Perforation Skip
<esc> &l#L
D = Disable
1 = Enable
Vertical Position (Rows)
<esc> &a#R
# = Row number
Vertical Position (Dots)
<esc> *p#Y
# = Dot number (300 dots = 1 inch)
Vertical Position (Decipoints)
<esc> &a#V
# = Decipoint number (720 decipoints =
1 inch)
Cursor Positioning
Horizontal Position (Columns) <esc> &a#C
# = Column number
Horizontal Position (Dots)
<esc> *p#X
# = Dot number (300 dots = 1 inch)
Horizontal Position
(Decipoints)
<esc> &a#H
# = Decipoint number (720 decipoints =
1 inch)
EN
Appendix B
231
PCL Commands (continued)
Programming Hints
End of Line Wrap
<esc> &s#C
0 = Enable
1 = Disable
Enter PCL Mode
<esc> %#A
0 = Use previous PCL cursor position
1 = Use current HP-GL/2 pen position
Enter HP-GL/2 Mode
<esc> %#B
0 = Use previous HP-GL/2 pen position
1 = Use current PCL cursor position
Symbol Sets
<esc> (#U etc.
8U = HP Roman-8 Symbol Set
10U = IBM Layout (PC-8) (code page 437)
Default Symbol Set
12U = IBM Layout for Europe (PC-850)
(code page 850)
8M = Math-8
19U = Windows 3.1 Latin 1
9E = Windows 3.1 Latin 2 (commonly
used in Eastern Europe)
5T = Windows 3.1 Latin 5 (commonly
used in Turkey)
579L = Wingdings Font
Primary Spacing
<esc> (s#P
0 = Fixed
1 = Proportional
Vector Graphics Switching
Font Selection
232
PCL commands
EN
PCL Commands (continued)
Primary Pitch
<esc> (s#H
# = Characters/Inch
Set Pitch Mode
<esc> &k#S
0 = 10
4 = 12 (elite)
2 = 16.5 - 16.7 (compressed)
Primary Height
<esc> (s#V
# = Points
Primary Style1
<esc> (s#S
0 = Upright (solid)
1 = Italic
4 = Condensed
5 = Condensed Italic
Primary Stroke Weight1
<esc> (s#B
0 = Medium (book or text)
1 = Semi-bold
3 = Bold
4 = Extra Bold
Color Text
<esc> *r3U
<esc> *v#S
(*r3U - selects
RGB palette, *v#S
- selects
foreground color)
0 = Black
1 = Red
2 = Green
3 = Yellow
4 = Blue
5 = Magenta
6 = Cyan
Typeface1
<esc> (s#T
Print the font list to find the command for
each internal font.
1Order the PCL/PJL Technical Reference Package if you require symbol sets or want additional
information.
EN
Appendix B
233
234
PCL commands
EN
C
Specifications
Electrical specifications
110-Volt Models
220-Volt Models
Power Requirements
100-127V (+/- 10%)
50/60 Hz (+/- 2 Hz)
220-240V (+/- 10%)
50/60 Hz (+/- 2 Hz)
Minimum recommended
circuit capacity for typical
product
10.2 Amps at 120V
5.1 Amps at 220V
470 W
80 W
28 W
0W
480 W
90 W
28 W
0W
Average power consumption
(Watts)
During printing
During standby
PowerSave Time mode
Off
Note
PowerSave default activation time is 30 minutes.
This information is preliminary. See http://www.hp.com/support/lj4550
for current information.
EN
Appendix C
235
Operating environment specifications
Temperature
Recommended
Allowed
20 to 26° C/68 to 79° F
15 to 30° C/59 to 86° F
Humidity
Recommended
Allowed
20 to 50% RH
10 to 80% RH
Altitude
Allowed
0 to 3100 m (0 to 10,000 ft)
Acoustic emissions
Operation Position
Printing
Standby
Per ISO 9296, DIN 45635,T.19
LPA 56 dB(A)
LPA 48 dB(A)
Bystander 1m
Printing
Standby
Per ISO 7779, DIN 45635,T.19
LPA 52 dB(A)
LPA 44 dB(A)
Sound Power
Printing
Standby
Per ISO 9296
LWAD=6.7 bels(A)
LWAD=6.0 bels(A)
236
Specifications
EN
Environmental product stewardship program
Protecting the environment
Hewlett-Packard Company is committed to providing quality products
in an environmentally sound manner. This HP LaserJet printer has
been designed with several attributes to minimize impacts on our
environment.
This HP LaserJet printer design eliminates:
●
Ozone Emissions— This product has been designed to minimize
ozone emissions and avoid the need for an ozone filter.
●
CFC Usage— Class I U.S. Clean Air Act stratospheric ozonedepleting chemicals (chlorofluorocarbons [CFCs], for example)
have been eliminated from the manufacturing sites that produce
this printer. This practice coincides with the 1987 M
“ ontreal
Protocol on Substances that Deplete the Ozone Layer” and its
subsequent amendments. CFCs are not used in manufacturing of
the packaging.
This HP LaserJet printer design reduces:
●
Energy Consumption— Energy usage drops significantly from
printing mode to PowerSave mode.
●
Paper Use— The printer’s optional duplex printing accessory
provides two-sided printing, reducing paper usage and the
resulting demands on natural resources.
The design of this HP LaserJet printer facilitates the
recycling of:
EN
●
Plastics— Major plastic parts have markings that enhance the
ability to identify plastics for recycling purposes at the end of the
printer’s life.
●
HP Toner Cartridges/Photoconductive Drum— In many
countries/regions, this product’s toner cartridge/drum can be
returned to HP at the end of its useful life. A prepaid shipping
label and instructions on how to return the toner cartridge/drum
are included with the replacement toner cartridge/drum. If your
country/region is not listed in the replacement’s brochure, call
your local HP Sales and Service Office for further instructions.
Appendix C
237
HP recycling program information:
This HP LaserJet printer also contributes to protecting the
environment in the following ways:
WWW
238
●
HP LaserJet printing supplies— In many countries/regions,
this product's printing supplies (e.g., toner cartridge, drum, fuser)
can be returned to HP through the HP Planet Partners Printing
Supplies Environmental Program. An easy-to-use takeback
component of the program is available in over 25 countries/
regions. Multilingual program information and instructions are
included in every new HP LaserJet Toner Cartridge and
Consumables box.
●
HP Planet Partners printing supplies environmental
program— Since 1990, the HP LaserJet Toner Cartridge
Recycling Program has collected more than 39 million used
LaserJet toner cartridges that otherwise might have been
discarded in the world’s landfills. The HP LaserJet toner
cartridges go to a collection center and are bulk-shipped to our
recycling partners who disassemble the cartridge parts for
recycling. Materials are separated and converted into raw
materials for use by other industries to make a variety of useful
products.
●
U.S. Recycling Returns— For a more environmentally
responsible return of used cartridges and consumables,
HP encourages the use of bulk returns. Simply bundle two or
more cartridges together and use a single, prepaid, and
pre-addressed UPS label that is supplied in the package.
For more information, call (800) 340-2445 (U.S. only) or visit the
HP LaserJet Supplies website at http://www.hp.com/ljsupplies/
planet_index.html.
●
Non-U.S. Recycling Returns— Non-U.S. customers should call
the local HP Sales and Service Office for further information
regarding availability of the HP Planet Partners LaserJet Toner
Cartridge and Consumables Recycling Program.
●
Paper— This printer is suited for the use of recycled papers
(according to DIN 19 309) when the paper meets the guidelines
outlined in the HP LaserJet Printer Family Paper Specification
Guide.
Specifications
EN
WWW
See Appendix D for HP LaserJet Family Paper Specification Guide
ordering information.
For downloadable manuals, go to http://www.hp.com/support/lj4550.
When you connect, select Manuals.
The user guide is provided on CD-ROM, which allows the same
high-quality information to be provided without consuming the
large quantities of energy and natural resources required to
produce traditional paper manuals.
To ensure longevity of your HP LaserJet printer,
HP provides the following:
●
WWW
Information on HP SupportPack is available on the Web at
http://www.hp.com/ under the HP Services and Support section.
International customers can contact the nearest HP-authorized reseller
about this service.
●
EN
Extended Warranty—HP SupportPack provides coverage for the
HP hardware product and all HP-supplied internal components.
The hardware maintenance covers a three-year period from date
of the HP product purchase. HP SupportPack must be purchased
by the customer within 90 days of the HP product purchase.
Spare Parts and Consumables Availability—Spare parts and
consumable supplies for this product will be made available for at
least five years after production has stopped.
Appendix C
239
Regulatory statements
FCC regulations
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If it is not
installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Note
●
reorient or relocate the receiving antenna.
●
increase separation between equipment and receiver.
●
connect equipment to an outlet on a circuit different from that to
which the receiver is located.
●
consult your dealer or an experienced radio/TV technician.
Any changes or modifications to the printer that are not expressly
approved by HP could void the user’s authority to operate this
equipment.
Use of a shielded interface cable is required to comply with the Class A
limits of Part 15 of FCC rules.
240
Specifications
EN
Canadian DOC regulations
Complies with Canadian EMC Class A requirements.
« Conforme à la classe A des normes canadiennes de compatibilité
électromagnétiques (CEM). »
VCCI statement (Japan)
Korean EMI statement
EN
Appendix C
241
Declaration of Conformity
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name:
Manufacturer’s Address:
Hewlett-Packard Company
11311 Chinden Boulevard
Boise, Idaho 83714-1021 USA
declares that the product
HP Color LaserJet 4550/4550N/4550DN/4550HDN Printer
Including 500 sheet-feeder and Duplexer Accessory
C7085A / C7086A / C7087A / C7088A Printer
C4082A 500 sheet-feeder, C4083A Duplexer Accessory
Product Name:
Model Number:
Product Options:
ALL
conforms to the following Product Specifications:
Safety:
IEC 60950:1991+A1+A2+A3+A4 / EN 60950:1992+A1+A2+A3+A4
IEC 60825-1:1993/EN 60825-1:1994 Class 1 (Laser/LED)
EMC:
CISPR 22:1993 /EN 55022:1994+A1+A2 Class A1
EN 50081-1:1992
EN 50082-1:1992
IEC 801-2:1991 / prEN 55024-2:1992 4 kV CD, 8 kV AD
IEC 801-3:1984 / prEN 55024-3:1991 3 V/m
IEC 801-4:1988 / prEN 55024-4:1992 1.0 kV Power Lines
0.5 kV Signal Lines
FCC Title 47 CFR, Part 15 Class A2 / ICES-002, Issue 2
AS / NZS 3548:1995
Supplementary Information:
The product herewith complies with the requirements of the EMC Directive 89/336/EEC and
the Low Voltage Directive 73/23/EEC, and carries the CE-Marking accordingly
1 The product was tested in a typical configuration with Hewlett-Packard Personal Computer Systems.
2 This Device complies with Part 15 of the FCC Rules. Operation is subject to the following two Conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Hewlett-Packard Company
Boise, Idaho USA
June 1, 2000
For regulatory topics only:
Australia Contact: Product Regulations Manager, Hewlett-Packard Australia Ltd., 31-41 Joseph Street,
Blackburn, Victoria 3130, Australia.
European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH,
Department HQ-TRE / Standards Europe, Herrenberger Straße 130, D-71034 Böblingen, Germany
(FAX: +49-7031-14-3143).
USA Contact: Product Regulations Manager, Hewlett-Packard Company, P.O. Box 15, Mail Stop 160,
Boise, ID 83707-0015 (Phone: 208-396-6000).
242
Specifications
EN
Safety information
Laser safety
The Center for Devices and Radiological Health (CDRH) of the U.S.
Food and Drug Administration has implemented regulations for laser
products manufactured since August 1, 1976. Compliance is
mandatory for products marketed in the United States. This printer is
certified as a “Class 1” laser product under the U.S. Department of
Health and Human Services (DHHS) Radiation Performance
Standard according to the Radiation Control for Health and Safety Act
of 1968. Since radiation emitted inside this printer is completely
confined within protective housings and external covers, the laser
beam cannot escape during any phase of normal user operation.
WARNING!
EN
Using controls, making adjustments, or performing procedures other
than those specified in this guide may result in exposure to hazardous
radiation.
Appendix C
243
Laser Statement for Finland
LASERTURVALLISUUS
Luokan 1 laserlaite
Klass 1 Laser Apparat
HP LaserJet 4550 -laserkirjoitin on käyttäjän kannalta turvallinen
luokan 1 laserlaite. Normaalissa käytössä kirjoittimen suojakotelointi
estää lasersäteen pääsyn laitteen ulkopuolelle.
Laitteen turvallisuusluokka on määritetty standardin EN 60825-1
(1994) mukaisesti.
VAROITUS !
Laitteen käyttäminen muulla kuin käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
VARNING !
Om apparaten används på annat sätt än i bruksanvisning
specificerats, kan användaren utsättas för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
HUOLTO
HP LaserJet 4550 -kirjoittimen sisällä ei ole käyttäjän huollettavissa
olevia kohteita. Laitteen saa avata ja huoltaa ainoastaan sen
huoltamiseen koulutettu henkilö. Tällaiseksi huoltotoimenpiteeksi ei
katsota väriainekasetin vaihtamista, paperiradan puhdistusta tai
muita käyttäjän käsikirjassa lueteltuja, käyttäjän tehtäväksi
tarkoitettuja ylläpitotoimia, jotka voidaan suorittaa ilman
erikoistyökaluja.
244
Specifications
EN
VARO !
Mikäli kirjoittimen suojakotelo avataan, olet alttiina näkymättömälle
lasersäteilylle laitteen ollessa toiminnassa. Älä katso säteeseen.
VARNING !
Om laserprinterns skyddshölje öppnas då apparaten är i funktion,
utsättas användaren för osynlig laserstrålning. Betrakta ej strålen.
Tiedot laitteessa käytettävän laserdiodin säteilyominaisuuksista:
Aallonpituus 765-795 nm
Teho 5 mW
Luokan 3B laser
EN
Appendix C
245
Material Safety Data Sheet (MSDS)
WWW
Go to the HP LaserJet Supplies website to obtain the Toner
Cartridge/Drum material safety data sheet (MSDS). The address is
http://www.hp.com/go/msds. Once at the site, select the HP LaserJet
icon.
If you do not have access to the Internet, call the HP FIRST (fax
on-demand service) for material safety data sheets:
●
Within the U.S. and Canada call (800) 231-9300 from your touchtone phone.
●
Outside the U.S. and Canada call (404) 329-2009 from your fax
machine.
Select an Index to view a listing of the available documents.
246
Specifications
EN
D
Warranty and
support information
Hewlett-Packard Warranty Statement
HP Color LaserJet 4550,
4550N, 4550DN, 4550HDN
Printer
One-year limited warranty
1
HP warrants HP hardware, accessories and supplies against defects in materials
and workmanship for the period specified above. If HP receives notice of such
defects during the warranty period, HP will, at its option, either repair or replace
products which prove to be defective. Replacement products may be either new or
like-new.
2
HP warrants that HP software will not fail to execute its programming instructions,
for the period specified above, due to defects in material and workmanship when
properly installed and used. If HP receives notice of such defects during the
warranty period, HP will replace software media which does not execute its
programming instructions due to such defects.
3
HP does not warrant that the operation of HP products will be uninterrupted or
error free. If HP is unable, within a reasonable time, to repair or replace any
product to a condition as warranted, customer will be entitled to a refund of the
purchase price upon prompt return of the product.
4
HP products may contain remanufactured parts equivalent to new in performance
or may have been subject to incidental use.
5
The warranty period begins on the date of delivery or on the date of installation if
installed by HP. If customer schedules or delays HP installation more than 30 days
after delivery, warranty begins on the 31st day from delivery.
6
Warranty does not apply to defects resulting from (a) improper or inadequate
maintenance or calibration, (b) software, interfacing, parts or supplies not supplied
by HP, (c) unauthorized modification or misuse, (d) operation outside of the
published environmental specifications for the product, or (e) improper site
preparation or maintenance.
EN
Appendix D
247
7
TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES ARE
EXCLUSIVE AND NO OTHER WARRANTY OR CONDITION, WHETHER
WRITTEN OR ORAL, IS EXPRESSED OR IMPLIED AND HP SPECIFICALLY
DISCLAIMS THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY, SATISFACTORY QUALITY, AND FITNESS FOR A
PARTICULAR PURPOSE.
8
HP will be liable for damage to tangible property per incident up to the greater of
$300,000 or the actual amount paid for the product that is the subject of the claim,
and for damages for bodily injury or death, to the extent that all such damages are
determined by a court of competent jurisdiction to have been directly caused by a
defective HP product.
9
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS
WARRANTY STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE
REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL HP OR ITS
SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR DIRECT, SPECIAL,
INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR
OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.
10 FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: THE
WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE
EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY
AND ARE IN ADDITION TO THE MANDATORY STATUTORY RIGHTS
APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.
248
Warranty and support information
EN
HP Maintenance Agreements
HP has several types of maintenance agreements that meet a wide
range of support needs.
On-site service agreements
To provide you with the support level best suited to your system
usage and support budget, HP has on-site service agreements with
three response times:
Priority On-Site Service is designed for production-critical
applications, giving you four-hour service response to your site for
calls made during normal HP business hours.
Next Day On-Site Service provides on-site support by the next
working day following your service request. Extended coverage hours
and extended travel beyond HP designated service zones are
available for additional charges on most on-site service agreements.
Weekly (Volume) On-Site Service Agreement, for organizations with
many HP LaserJet printers, provides economical, scheduled on-site
coverage. Designated for customer sites using 25 or more
workstation products, this service provides scheduled weekly repair
visits to your central location. HP can write an agreement for any
combination of 25 or more workstation products including printers,
plotters, computers, and disk drives.
Note
EN
See “HP Service Agreements” on page 251 for HP service agreements
phone numbers.
Appendix D
249
Support information
HP Customer Care
Online Services: for 24-hour
access to information over your
modem, we suggest these
services:
World Wide Web URL—Printer drivers, updated HP printer
software, plus product and support information may be obtained from
the following URLs:
in the U.S.
http://www.hp.com/support/lj4550
in Europe
http://www2.hp.com
Printer drivers may be obtained from the following sites:
in Japan
ftp://www.jpn.hp.com/drivers/
in Korea
http://www.hp.co.kr
in Taiwan
http://www.hp.com.tw
or the local driver website http://www.dds.com.tw
America Online America Online/Bertelsmann is available in the
U.S.,France, Germany, and U.K.—Printer drivers, updated HP printer
software, and support documentation to help answer your questions
about HP products are available. Use Keyword HP to start your tour
or call 1-800-827-6364 preferred customer # 1118 to subscribe. In
Europe, call the appropriate number below:
Austria
0222 58 58 485
France
++353 1 704 90 00
Germany
0180 531 31 64
Switzerland
0848 80 10 11
United Kingdom
0800 279 1234
CompuServe—Printer drivers, updated HP printer software, and
interactive sharing of technical information with other members is
available on CompuServe’s “HP User’s forums” (GO HP), or call
1-800-524-3388 and ask for representative #51 to subscribe.
(CompuServe is also available in the U.K., France, Belgium,
Switzerland, Germany, and Austria.)
Obtaining software
utilities and electronic
information for U.S.
Phone:
(805) 257-5565
Fax:
(805) 257-6995
Mail:
Hewlett-Packard Co.
P.O. Box 907
Santa Clarita, CA 91380-9007
U.S.A.
HP website: http://www.hp.com/
For Canada
Phone: (905) 206-4663
For Asia-Pacific
countries/regions
Contact Mentor Media at (65) 740-4477 (Hong Kong SAR, Indonesia,
Philippines, Malaysia, or Singapore). For Korea, call
(82) (2) 3270-0805 or (82) (2) 3270-0893.
For Australia, New
Zealand, and India
For Australia and New Zealand, call (61) (2) 565-6099.
For India, call (91) (11) 682-6035.
For European English
For U.K., call (44) (142) 986-5511. For Ireland and outside U.K.,
call (44) (142) 986-5511.
250
Warranty and support information
EN
HP Customer Care
HP direct ordering for
accessories or supplies
Call 1-800-538-8787 (U.S.) or 1-800-387-3154 (Canada) or link to
U.S. – http://www.hp.com/go/ljsupplies or
Worldwide – http://www.hp.com/ghp/buyonline.html to order supplies
online.
HP Support Assistant
compact disc
This support tool offers a comprehensive online information system
designed to provide technical and product information on
HP products. To subscribe to this quarterly service in the U.S. or
Canada, call 1-800-457-1762. In Hong Kong SAR, Indonesia,
Malaysia, or Singapore, call Mentor Media at (65) 740-4477.
HP Service Information
To locate HP-authorized Dealers, call 1-800-743-8305 (U.S.) or
1-800-387-3867 (Canada)
HP Service Agreements
Call 1-800-835-4747 (U.S.) or 1-800-268-1221 (Canada).
Extended Service 1-800-446-0522
EN
Appendix D
251
HP Customer Care options worldwide
In addition to the phone numbers listed below, this guide contains
worldwide sales and service addresses and phone numbers for
countries/regions not listed here.
HP Customer Care Centers Worldwide
Customer Support
and Product Repair
Assistance for the
U.S. and Canada:
Call 1-208-323-2551 Monday through Friday from 6 am to 6 pm (Mountain
Time) free of charge during the warranty period. However, your standard
long-distance phone charges still apply. Have your system nearby and your
serial number ready when calling.
If you know your printer needs repair, call 1-800-243-9816 to locate your
nearest HP-authorized service provider, or call 1-208-323-2551 for HP
centralized service dispatch.
Post-warranty telephone assistance is available to answer your product
questions. Call 1-900-555-1500 ($2.50* per minute, U.S. only) or call
1-800-999-1148 ($25* per call, Visa or MasterCard, U.S. and Canada)
Monday through Friday from 7 am to 6 pm (Mountain Time). Charges begin
only when you connect with a support technician. *Prices subject to change.
European Customer Care Center Language and In-Country Options Available
Open Monday through Friday 8:30 to 18:00 CET
HP provides a free telephone support service during the warranty period. By calling a telephone number
listed below, you will be connected to a responsive team waiting to help you. If you require support after
your warranty has expired, you can receive support for a fee through the same telephone number. The fee
is charged on a per-incident basis. When calling HP, have the following information ready: product number
and serial number, date of purchase, and description of the problem.
English
Dutch
French
252
Ireland:
U.K.:
International:
Belgium:
Netherlands:
France:
Belgium:
Switzerland:
(353) (0) (1) 662-5525
(44) (0) (171) 512-5202
(44) (0) (171) 512-5202
(32) (0) (2) 626-8806
(31) (0) (20) 606-8751
(33) (0) (1) 43-62-3434
(32) (0) (2) 626-8807
(41) (0) (84) 880-1111
Warranty and support information
German
Norwegian
Danish
Finnish
Swedish
Italian
Spanish
Portuguese
Germany
Austria:
Norway:
Denmark:
Finland:
Sweden:
Italy:
Spain:
Portugal:
(49) (0) (180) 525-8143
(43) (0) 7114 201080
(47) 22 11-6299
(45) 39 29-4099
(358) (0) 203-47-288
(46) (0) (8) 619-2170
(39) (0) (2) 264-10350
(34) (90) 232-1123
(351) (0) (1) 317-6333
EN
Customer Care Centers Worldwide (continued)
In-country/region support numbers: HP provides a free telephone support service during the
warranty period. By calling a telephone number listed below, you will be connected to a responsive team
waiting to help you. If you require support after your warranty has expired, you can receive support for a fee
through the same telephone number. The fee is charged on a per-incident basis. When calling HP, have
the following information ready: product number and serial number, date of purchase, and description of
the problem.
Argentina
(54) (1) 778-8380
Malaysia
Australia
(61) (3) 8877-8000
Mexico
01 800-472-6684
Brazil
(011) 829-6612
New Zealand
(64) (9) 356-6640
Canada
(1) (208) 323-2551
Philippines
(63) (2) 867-3551
China
(86) (0) (10) 6564-5959
Poland
(48) (22) 519-0600
Chile
800-360-999
Portugal
(351) (0) (1) 317-6333
Czech Republic
(420) (2) 6130-7310
Russia
(7) (0) (95) 797-3520
Greece
(30) (0) (1) 689-6411
Singapore
(65) 272-5300
Hong Kong SAR
(852) 800-96-7729
South Africa
(27) (86) 000-1030
Hungary
(36) (0) (1) 382-1111
Taiwan
(886) (2) 2717-0055
India
(91) (11) 682-6035
Thailand
(66) (2) 661-4000
Indonesia
(62) (21) 350-3408
Turkey
(90) (212) 224-5925
Israel
(972) (0) (9) 952-4848
Venezuela
800-47-888
Japan
(81) (3) 3335-8333
Venezuela (Caracas)
207-8488
Korea
(82) (2) 3270-0700
Vietnam
(84) (0) 8 823-4530
Korea (outside Seoul)
(82) (080) 999-0700
EN
(60) (3) 295-2566
Appendix D
253
Worldwide Sales and Service Offices
Note
Before calling an HP Sales and Service office, be sure to contact
the appropriate Customer Care Center number listed in the
“ HP Customer Care” section. Products should not be returned to
these offices. Product return information is also available through the
appropriate Customer Care Center listed in the “ HP Customer Care”
section.
Argentina
Brazil
Hewlett-Packard Argentina S.A.
Montañ eses 2140/50/60
1428 Buenos Aires
Phone: (54) (1) 787-7100
Fax:
(54) (1) 787-7213
Hewlett-Packard Brasil SA
R. Aruana 125
Tambore - Barueri-SP
06460-010
Phone: (55) (0) (11)- 829-6612
Fax:
(55) (0) (11)- 829-0018
Australia
Hewlett-Packard Australia Ltd.
31-41 Joseph Street
Blackburn, VIC 3130
Phone: (61) (3) 272-2895
Fax:
(61) (3) 898-7831
Hardware Repair Center:
Phone: (61) (3) 272-8000
Extended Warranty Support:
Phone: (61) (3) 272-2577
Customer Information Center:
Phone: (61) (3) 272-8000
Austria
Hewlett-Packard GmbH
Lieblgasse 1
A-1222 Vienna
Phone: (43) (1) 25000-555
Fax:
(43) (1) 25000-500
Belgium
Hewlett-Packard Belgium S.A. NV
Boulevard de la Woluwe-Woluwedal
100-102
B-1200 Brussels
Phone: (32) (2) 778-31-11
Fax:
(32) (2) 763-06-13
254
Warranty and support information
Canada
Hewlett-Packard (Canada) Ltd.
17500 Trans Canada Highway
South Service Road
Kirkland, Québec H9J 2X8
Phone: (1) (514) 697-4232
Fax:
(1) (514) 697-6941
Hewlett-Packard (Canada) Ltd.
5150 Spectrum Way
Mississauga, Ontario L4W 5G1
Phone: (1) (905) 206-4725
Fax:
(1) (905) 206-4739
Chile
Hewlett-Packard de Chile
Avenida Andres Bello 2777 of. 1
Los Condes
Santiago, Chile
China
China Hewlett-Packard Co. Ltd.
Level 5, West Wing Office
China World Trade Center
No. 1, Jian Guo Men Wai Avenue
Beijing 100004
Phone: (86) (10) 6505-3888,x. 5450
EN
Fax:
(86) (10) 6505-1033
Hardware Repair Center and Extended
Warranty Support:
Phone: (86) (10) 6262-5666x. 6101/2
(86) (10) 6261-4167
Colombia
Hewlett-Packard Colombia
Calle 100 No. 8A -55
Torre C Oficina 309
Bogota, Colombia
Czech Republic
Hewlett-Packard s. r. o.
Novodvorská 82
CZ-14200 Praha 4
Phone: (420) (2) 613-07111
Fax:
(420) (2) 471-7611
Greece
Hewlett-Packard Hellas
62, Kifissias Avenue
GR-15125 Maroussi
Phone: (30) (1) 689-6411
Fax:
(30) (1) 689-6508
Hong Kong SAR
Hewlett-Packard Asia Pacific Ltd.
17-21/F Shell Tower, Times Square
1 Matheson Street, Causeway Bay
Hong Kong SAR
Phone: (852) 2599-7777
Fax:
(852) 2506-9261
Hardware Repair Center:
Phone: (852) 2599-7000
Extended Warranty Support:
Phone: (852) 2599-7000
Customer Information Center:
Phone: (852) 2599-7066
Denmark
Hewlett-Packard A/S
Kongevejen 25
DK-3460 Birkerø d
Denmark
Phone: (45) 3929 4099
Fax:
(45) 4281-5810
Finland
Hewlett-Packard Oy
Piispankalliontie 17
FIN-02200 Espoo
Phone: (358) (9) 887-21
Fax:
(358) (9) 887-2477
France
Hewlett-Packard France
42 Quai du Point du Jour
F-92659 Boulogne Cedex
Phone: (33) (146) 10-1700
Fax:
(33) (146) 10-1705
Hungary
Hewlett-Packard Magyarorszá g Kft.
Erzsé bet kirá lyné ú tja 1/c.
H-1146 Budapest
Phone: (36) (1) 343-0550
Fax:
(36) (1) 122-3692
Hardware Repair Center:
Phone: (36) (1) 343-0312
Customer Information Center:
Phone: (36) (1) 343-0310
India
Hewlett-Packard India Ltd.
Paharpur Business Centre
21 Nehru Place
New Delhi 110 019
Phone: (91) (11) 647-2311
Fax:
(91) (11) 646-1117
Hardware Repair Center and Extended
Warranty Support:
Phone: (91) (11) 642-5073
(91) (11) 682-6042
Germany
Hewlett-Packard GmbH
Herrenberger Strasse 130
71034 Bö blingen
Phone: (49) (180) 532-6222
(49) (180) 525-8143
Fax:
(49) (180) 531-6122
EN
Appendix D
255
Italy
Middle East/Africa
Hewlett-Packard Italiana SpA
Via Giuseppe di Vittorio, 9
Cernusco Sul Naviglio
I-20063 (Milano)
Phone: (39) (2) 921-21
Fax:
(39) (2) 921-04473
ISB HP Response Center
Hewlett-Packard S.A.
Rue de Veyrot 39
P.O. Box 364
CH-1217 Meyrin - Geneva
Switzerland
Phone: (41) (22) 780-4111
Japan
Hewlett-Packard Japan, Ltd.
3-29-21 Takaido-higashi
Suginami-ku, Tokyo 168
Phone: (81) (3) 3335-8333
Fax:
(81) (3) 3335-8338
Hardware Repair Center:
Phone: (81) (4) 7355-6660
Fax:
(81) (4) 7352-1848
Hewlett-Packard Nederland
BV Startbaan 16
NL-1187 XR Amstelveen
Postbox 667
NL-1180 AR Amstelveen
Phone: (31) (020) 606-87-51
Fax:
(31) (020) 547-7755
Korea
New Zealand
Hewlett-Packard Korea
25-12,
Yoido-dong, Youngdeungpo-ku
Seoul 150-010
Phone: (82) (2) 769-0114
Fax:
(82) (2) 784-7084
Hardware Repair Center:
Phone: (82) (2) 3270-0700
(82) (2) 707-2174 (DeskJet)
(82) (2) 3270-0710 (Hardware)
Extended Warranty Support:
Phone: (82) (2) 3770-0365 (Bench)
(82) (2) 769-0500 (Onsite)
Hewlett-Packard (NZ) Limited
Ports of Auckland Building
Princes Wharf, Quay Street
P.O. Box 3860
Auckland
Phone: (64) (9) 356-6640
Fax:
(64) (9) 356-6620
Hardware Repair Center and Extended
Warranty Support:
Phone: (64) (9) 0800-733547
Customer Information Center:
Phone: (64) (9) 0800-651651
Latin American
Headquarters
5200 Blue Lagoon Drive Suite 950
Miami, FL 33126,USA
Phone: (1) (305) 267-4220
México
Hewlett-Packard de México, S.A. de C.V.
Prolongación Reforma No. 700
Lomas de Santa Fe
01210 México, D.F.
Phone: 01-800-22147
Outside Mexico City
Phone: 01 800-90529
256
Netherlands
Warranty and support information
Norway
Hewlett-Packard Norge A/S
Postboks 60 Skøyen
Drammensveien 169
N-0212 Oslo
Phone: (47) 2273-5600
Fax:
(47) 2273-5610
Poland
Hewlett-Packard Polska
Al. Jerozolimskic 181
02-222 Warszawa
Phone: (48-22) 608-7700
Fax:
(48-22) 608-76-00
EN
Russia
AO Hewlett-Packard
129223, Moskva, Olimpiyskiy prospekt, 16
Phone: (7) (95) 916-9811
Fax:
(7) (95) 974-7829
Hardware Repair Center, call :
North (886)(02) 717-9673
Central (886)(04) 327-0153
South (886)(080)733-733
Extended Warranty Support Contact :
Phone: (886)(02) 714-8882
Singapore
Thailand
Hewlett-Packard Singapore
(Sales) Pte Ltd
450 Alexandra Road
Singapore (119960)
Phone: (65)275-3888
Fax:
(65)275-6839
Hardware Repair Center and
Customer Information Center:
Phone: (65) 272-5300
Extended Warranty Support:
Phone: (65) 272-5333
Hewlett-Packard (Thailand) Ltd.
23-25/f Vibulthani Tower II
2199 Rama 4 Rd, Klongton
Klintoey, Bangkok 10110
Thailand
Phone: (66) (2) 666-3900-34
Fax:
(66) (2) 666-3935-37
Hardware Repair Center and Extended
Warranty Support Contact:
Phone: (66) (2) 661-3900 ext. 6001/
6002
Customer Information Center:
Phone: (66) (2) 661-3900 ext. 3211
Fax:
(66) (2) 661-3943
Spain
Hewlett-Packard Española, S.A.
Carretera de la Coruña km 16.500
E-28230 Las Rozas, Madrid
Phone: (34) (1) 626-1600
Fax:
(34) (1) 626-1830
Sweden
Hewlett-Packard Sverige AB
Skalholtsgatan 9
S-164 97 Kista
Phone: (46) (8) 444-2000
Fax:
(46) (8) 444-2666
Switzerland
Hewlett-Packard (Schweiz) AG
In der Luberzen 29
CH-8902 Urdorf/Zürich
Phone: (41) (084) 880-11-11
Fax:
(41) (1) 753-7700
Warranty Support:
0800-55-5353
Taiwan
Hewlett-Packard Taiwan Ltd.
8th Floor
337, Fu-Hsing North Road
Taipei, 10483
Phone: (886)(02)717-0055
FAX : (886)(02)514-0276
EN
Turkey
Hewlett-Packard Company
Bilgisayar Ve ölçüm Sistemleri AS
19 Mayis Caddesi Nova
Baran Plaza Kat: 12
80220 Sisli-Istanbul
Phone: (90) (212) 224-5925
Fax:
(90) (212) 224-5939
United Kingdom
Hewlett-Packard Ltd.
Cain Road
Bracknell
Berkshire RG12 1HN
Phone: (44) (134) 436-9222
Fax:
(44) (134) 436-3344
Venezuela
Hewlett-Packard de Venezuela S.A.
Los Ruices Norte
3A Transversal
Edificio Segre Caracas 1071
Phone: (58) (2) 239-4244
Fax:
(58) (2) 239-3080
Appendix D
257
258
Warranty and support information
EN
E
Embedded Web
server
Introduction
This printer is equipped with an embedded Web server, which
allows you to access information about printer and network
activities. This chapter explains the features and functionality of
the embedded Web server.
EN
Appendix E
259
Using the embedded Web server
The embedded Web server allows you to view printer and network
status and to manage printing functions from your PC instead of from
the printer control panel. This service is designed for offices using an
IP network and a standard Web browser. Below are examples of what
you can do using the embedded Web server:
●
view printer control panel messages
●
determine the remaining life on all consumables
●
order consumables
●
view and change tray configurations
●
view and change the printer control panel menu configuration
●
view and print internal pages
●
receive notification of printer events
●
view and change network configuration
To use the embedded Web server, you must have an IP-based
network and a Web browser. The embedded Web server can be used
with Microsoft Internet Explorer 4 or above, and with Netscape
Navigator 4 and above. IPX-based printer connections are not
supported by the embedded Web server.
To access the embedded Web server
1
Open your Web browser.
2
Type the IP address assigned to the printer into the Address or
Location field.
If you do not know the IP address for the printer, it is listed on the
printer configuration page. For more information about printing a
configuration page, see “Printer configuration page” on page 49.
260
Embedded Web server
EN
Embedded Web server page sets
The embedded Web server has three sets of internal Web pages for
collecting information about the printer and for changing configuration
options. These sets are:
●
Home pages
●
Device pages
●
Networking pages
When the embedded Web server is active, each set of pages is listed
on the browser screen. Click on the set that you want to view, and the
selection expands to display a list of frequently accessed Web links.
Note
Each page in the embedded Web server has access to online Help.
For more information regarding a particular page, click the Help button.
Home page set
The home pages of the embedded Web server are the informational
pages for the printer. These include:
EN
●
Printer Status page
This page displays printer capabilities, control panel messages,
and status lights that currently appear on the printer control
panel. From here, you can set the frequency at which the
embedded Web server will check the printer status. This page
also displays consumable life levels and the input tray
configurations.
●
Configuration page
This page displays the printer configuration page. For more
information about interpreting and printing the configuration page,
see page 49.
●
Supplies status page
This page displays the levels of the consumables for the printer.
For more information about interpreting and printing the supplies
status page, see page 53.
●
Usage page
This page displays the amount of each media type that has been
used by the printer. For more information about interpreting and
printing the usage page, see page 55.
●
Event Log page
This page displays the printer’s event log. For more information
about interpreting and printing the event log, see page 56.
Appendix E
261
●
Device Identification page
This page displays the name, asset number, network address,
model number, and serial number for this printer. To set the name
and asset number, see the description of the “Device
Identification page” under “Device page set”.
Device page set
The device pages of the embedded Web server allow you to configure
the printer from your PC. The device pages can be password
protected. Always consult with your network administrator before
changing the printer’s configuration.
●
Configure Printer page
Configure all printer settings from this page.
●
Alerts page
Input a list of recipients for electronic notification of various printer
events.
●
E-Mail page
Configure the incoming and outgoing mail servers.
●
Security page
Set a password for the embedded Web server. Passwords and
features configuration should only be determined by the network
administrator. If a password is set, users will require a password
for entry into the device sections of the embedded Web server.
●
Other Links page
Add or customize links to other websites. These links are
displayed on the navigational bar throughout the embedded Web
server pages.
There are two permanent links, “Ask a question” where the user
can get help with the printer, and “Order Supplies” where you can
order printer supplies. Order Supplies is only available from the
Device page set.
262
●
Language page
Determine the language in which to display the embedded Web
server information.
●
Device Identification page
Name the printer and assign an asset number to it. Input the
name and email address of the primary point of contact for
information about the printer. This page also shows the printer’s
network names, addresses, and printer model information.
Embedded Web server
EN
Networking page set
This set of pages allows the network administrator to configure the
HP JetDirect card for the printer. Refer to the online Help and to the
HP JetDirect Print Server Administrator’s Guide for more information.
WWW
EN
To download the HP JetDirect Print Server Administrator’s Guide, go to
http://www.hp.com/support/lj4550. When you connect, select
Manuals.
Appendix E
263
264
Embedded Web server
EN
Index
Numerics
500-sheet paper feeder
See also Tray 3
ordering 31
A
accessories
See also consumables
description 31
duplexer 89
ordering 31, 251
Tray 3 85
acoustic emissions 236
Adobe Acrobat Reader
using 14
advanced functions, setting 63
attention light, interpreting 37
attention messages 152
auto continue 43
B
bidirectional parallel cable
specifications 128
C
Calibration Menu
description 45
items 45
values 45
Canadian DOC regulations 241
Cancel Job 36
cartridge
See toner cartridges
color
See color printing
color printing
control options 108
Detail option 108
halftones 108
PANTONE®* colors 111
problems 210
Screen Match 108
colored paper
using 71
commands 223
components, printer 21
Configuration Menu
description 43
EN
items 43
values 43
configuration settings, changing 58
configuring
DIMMs 216
input trays 76
LocalTalk 131
consumables
availability 239
disposing 147
drum kit 145
error messages 145
fuser kit 145
overview 141
replacing 145
toner cartridges 145
transfer kit 145
control panel
indicator lights 37
PowerSave settings 59
printer personalities 60
control panel menus
Calibration Menu 45
Configuration Menu 43
I/O Menu 48
Information Menu 40
menu map 38
Paper Handling Menu 41
Resets Menu 46
using 38
control panel, printer
configuration 58
default settings 58
features 35
help with 36
I/O Timeout, setting 61
indicator lights 37
keys 36
locking 132
menu locking 38
menu map 38
menus, descriptions 40
messages, description 153
messages, troubleshooting 153
messages, types 152
options 34
problems 193
selecting PCL fonts 119
settings 23, 193
Index
265
shared environments 57
stopping a print job 94
using 36
controlling print jobs 23, 74
critical error messages, defining 152
customer support 252
obtaining software 250
worldwide 252
custom-size media 93
environmental features 19
Environmental Product Stewardship
Program 237
error messages
action 153
blank display panel 189
consumables 145
description 153
interpreting 145
D
F
data light, interpreting 37
Declaration of Conformity 242
default settings
changing 58
resetting 64
defects
image 194
density sensor 155
DIMMs (Dual Inline Memory Modules)
adding 25
configuring 216
installing 218
verifying installation 220
DIN-8 printer cable 131
display panel
See control panel 193
driver
See printer driver
Dual Inline Memory Modules (DIMMs)
See DIMMs
duplex printing
accessory 89
settings 91
factory default settings, resetting 64
FCC regulations 240
Finnish laser statement 244
font #, description 122
fonts
adding support 125
custom 126
default font 117
list of 122
on a network 124
PCL fonts 119
pitch 122
PostScript emulation, using 123
printing font list 121
printing guidelines 124
problems 212
selecting 118
selecting default font 117
TrueType, internal 116
typeface 122
E
EIO (Enhanced Input Output)
configuring 48
electrical specifications 235
embedded Web server 259
accessing 260
device page set 262
home page set 261
networking page set 263
energy consumption 237
Enhanced Input Output (EIO)
configuring 48, 129
envelopes
avoiding printer jams 81
jamming 187
precautions 71
printing on 71, 80
using 71
weight 71
wrinkled 71
266
Index
G
glossy paper
ordering 31
using 70
H
heavy paper
using 72
HP custom font services 126
HP JetDirect print server 129, 130, 131
HP Service Agreements 251
HP Service Information 251
HP Worldwide Sales and Service Offices
254– 257
I
I/O cards 129
I/O Menu 44
description 44
setting bidirectional communication
63
I/O Timeout, setting 61
EN
defect table 196
defects 194
indicator lights, interpreting 37
input trays, configuring 41, 76
interfaces, printer
Enhanced I/O configuration 129
J
Japanese VCCI statement 241
job cancel 36
K
Korean EMI statement 241
L
laser safety 243
letterhead
precautions 73
printing on 93
loading
500-sheet paper feeder 86
Tray 1 78
Tray 2 82, 83
Tray 3 86
LocalTalk interface 131
locating control panel features 35
locking 75
M
Macintosh
DIN-8 printer cable 131
LocalTalk interface 131
LocalTalk Network Configuration 131
maintenance
space required for 142
Material Safety Data Sheet (MSDS) 246
media
See also paper
colored paper 71
configuring input trays 76
curled output 188
custom-size, printing on 93
envelopes jamming 187
envelopes, printing on 71
glossy paper 70
heavy paper 72
letterhead 73
loading Tray 1 78
loading Tray 2 82
loading Tray 3 86
ordering 31
precautions 73
EN
preprinted forms 73
printing guidelines 69
problems 177
selecting 66, 75
sizes, setting 41
types to avoid 69
weights 67
memory 18
adding 215
managing 25
Memory Enhancement Technology
(MEt) 25
Menu
EIO 48
I/O Menu 44
Printing 42
Resets 46
menu
Calibration 45
Configuration 43
locking 38, 132
Paper Handling 41
menu map, printing 38
messages
control panel 152
error 152
service 152
warning 152
MEt (Memory Enhancement
Technology) 25
MSDS (Material Safety Data Sheet) 246
N
network
securing 132
network interface settings, adjusting 48
O
online help 36
operating environment specifications
236
ordering
500-sheet paper feeder 31
accessories 31
cables 32
media 31
memory 31
network connectivity 31
reference materials 32
toner 31
output bins
capacity 74
selecting 74
output, incorrect 212
Index
267
P
PANTONE® colors 111
paper
See also media
curled output 188
custom-size, printing 93
glossy 70
handling 18
heavy 72
input trays, configuring 76
jams, locating 175
loading Tray 1 78
loading Tray 2 82
loading Tray 3 86
ordering 31
output 18
precautions 66
printing guidelines 69
recycling 239
selecting 66
sizes 67
trays, configuring 41
types to avoid 69
weights 68
Paper Handling Menu
values 41
paper handling menu
items 41
Paper Jam Recovery
enabling 176
paper jam recovery
description 176
paper jams
causes 177
front duplex drawer 184
locating 175
upper rear door 182
parallel cable
connecting 128
illustration 128
ordering 32
specifications 128
parallel configuration 128
parallel interface, disabling 62
parts, ordering 31, 250
PCL (Printer Control Language) 223
command syntax 225
commands 229
escape sequences 226
fonts, selecting 228
PCL fonts, selecting 119
permanent resources 221
pitch 122
PJL (Printer Job Language) 224
point size 122
268
Index
PostScript Emulation
typefaces 123
PostScript emulation
font list 122
power requirements 235
PowerSave
changing settings 59
description of 43
prepunched paper
loading 79
print
quality problems 194
print jobs
controlling 23, 74
output bins, selecting 74
stopping 94
print media
See envelopes
See media
See paper
See transparencies
printer
accessories 31
adding memory 25
commands 24
components 21, 22
configuration page, interpreting 50
configuration page, printing 49
connectivity 19
control panel 33
default settings 64
driver, ordering 250
energy consumption 237
environmental features 19
feeding problems 185
fonts 18
in shared environment 18
incorrect output 212
input 18
interface settings, changing 44
languages 60
maintenance 141
memory 18, 20, 95
memory, adding 25, 216
memory, managing 25
memory, resetting 63
messages 145, 153
network security 132
output problems 212
paper handling 18
parallel cable 128
parallel interface, disabling 62
PCL commands 223, 229
performance 18
personalities, supported 18
personalities, switching 60
EN
power requirements 235
resetting factory defaults 64
response problems 189
settings 43
settings, selecting 23
shared environment 18
shared environments 57
software, ordering 250
supplies 31
troubleshooting 49
warranty 247
Printer Control Language (PCL)
command syntax 225
commands 223, 229
escape sequences 226
fonts, selecting 228
printer driver
settings 23
verifying 125
printer fonts
See fonts
printer interfaces
parallel configuration 128
Printer Job Language (PJL) 224
printer messages
See error messages
printer personalities 60
printer problems
See troubleshooting
printing
See also color printing
See also duplex printing
color, using 105
controlling print jobs 23
envelopes 80
font guidelines 124
internal TrueType fonts 116
on custom-size media 93
on letterhead 93
printer default fonts 117
problems 210
selecting fonts 118
selecting symbol sets 118
stopping a print job 94
using Tray 3 84
using type fonts 116
Printing Menu
descriptions 42
items 42
selections 42
problems
See error messages
See troubleshooting
product 237
acoustic emissions 236
customer support 252
EN
extended warranty 239
features 18
maintenance agreements 249
recycling 238
safety 243
stewardship 237
warranty 247
worldwide sales and service 254
R
RAM (random access memory) 18
random access memory (RAM) 18
ready light, interpreting 37
recycled paper, using 239
recycling toner cartridges 237
reference materials, ordering 32
regulatory information 240
repairs 249, 252
Resets Menu
description of 46
items 46
resource saving 221
S
safety information
laser safety 243
toner material safety 243
sales and service offices 254– 257
saving permanent resources 221
Screen Match 108
securing network 132
selecting
default font 117
fonts 118
media 66, 75
output bins 74
PCL fonts 119
printer settings 23
service agreements
customer support
types 249
sizes
media 67
paper 67
soft fonts, availability 126
software application problems 214
software, ordering 250
specifications
acoustic emissions 236
electrical 235
operating environment 236
stopping a print job 94
supplies, ordering 31, 251
Index
269
270
Index
T
W
throughput 20
toner
See also toner cartridges
densities, setting 45
density sensor 149
ordering 31
toner cartridges
replacement intervals 145
toner cartridges, recycling 237
transparencies
feeding problems 187
ordering 31
tray capacities 68
tray
capacities 67
priority, configuring 77
Tray 1
configuring 76
loading 78
printing from 78
Tray 2
configuring 77
feeding problems 186
loading 82
Tray 3
configuring 77
feeding problems 186
illustration 85
loading 86
ordering 31
troubleshooting 188
trays 75
locking 75
multipurpose 78
troubleshooting
See also paper jams 175
checklist 174
color printing problems 210
control panel problems 193
envelopes jamming 187
image defects 196
paper jam recovery 176
paper jams 175
printer output 212
printer response problems 189
slow print speed 20
Tray 2 186
Tray 3 186, 188
type
See also fonts
available printer fonts 121
Postscript typefaces 123
printer default fonts 117
special effects 125
warning messages, defining 152
warranty 247
worldwide sales and service 254
EN
