ROBO-8921VG2R Dual/Quad CoreTM Xeon® processor
About Portwell
Portwell, Inc. was founded in 1993 and entered the Industrial PC
market in 1995 by developing single-board computers. Today, our
continuous development of leading-edge products has resulted in
VWURQJJURZWKLQPDUNHWVKDUHVDQGUHYHQXHD¿UPSODFHRQWKH
Taipei stock exchange (TAISDAQ), and has established Portwell
as a major worldwide supplier of specialty computing application
platforms and services. Portwell, Inc. is a Premier member of the
Intel® Intelligent Systems Alliance. From modular components
to market-ready systems, Intel and the 200+ global member
companies of the Alliance provide the performance, connectivity,
manageability, and security developers need to create smart,
connected systems. Close collaboration with Intel and each other
enables Alliance members to innovate with the latest technologies,
KHOSLQJGHYHORSHUVGHOLYHU¿UVWLQPDUNHWVROXWLRQV3RUWZHOO,QF
is also a member of the selected group of Intel® Applied Computing
Platform Providers (IACPP), as well as Advanced Telecom
Computing Architecture (ATCA) and an executive member
of PCI Industrial Computer Manufacturing group (PICMG).
Portwell Engine (PE) Building
Portwell, Inc. has worldwide operations in the U.S.A., Taiwan,
Japan, China, Netherlands, United Kingdom, and India. Whether
you are working on a computer board or turnkey system, Portwell
is the perfect partner to help you deliver your products to the
market on time as well as maintain longevity of product. With 18
years experience in the design and manufacturing of specialty
computer boards and systems, Portwell not only provides a onestop resource for off-the-shelf products, but also supplies custombuilt solutions and a global logistics services to suit your needs.
Portwell OEM and ODM solutions satisfy your needs in
retail automation, medical equipment, industrial automation,
infotainment, communication, and network security markets.
(QFRXUDJHG E\ RXU ÀH[LEOH EXVLQHVV VXSSRUW PDQXIDFWXULQJ
excellence, and compliance with high quality and environmental
01
About Portwell
standards such as ISO 9001/14000/13485, OHSAS and RoHS,
customers have taken advantage of our dedicated and sophisticated
engineering resource to satisfy their requirements for the design,
PDQXIDFWXULQJ DQG ORJLVWLFV RI DSSOLFDWLRQVSHFL¿F FRPSXWHU
ERDUGV FXVWRPL]HG FRPSXWHU FKDVVLV DQG VSHFL¿F FRPSXWHU
V\VWHP FRQ¿JXUDWLRQV :KHWKHU \RX DUH ZRUNLQJ RQ D 0HGLFDO
Single Board Computer or Internet Security Appliance, Portwell
is, again, the perfect partner to help you deliver your products to
the market on time and stay one step ahead of the competition.
3RUWZHOOLVIDPRXVIRUKHUSODWIRUPVHUYLFHWKDWFRXOGRIIHUWKHIROORZLQJEHQH¿WVWRFXVWRPHUV
„ Complete Product Portfolio
Select from our full range of both off-the-shelf and versatile
custom solutions to scale your products. Portwell provides not
only board-level products but also peripheral-level and complete
system solutions.
„ Implement Latest Intel Technology
Portwell delivers cutting-edge solutions not only to meet and
exceed the demand for the newest technologies, but also the
need for greater product life cycles. Since partnering with Intel in
1999, and with streamline access to the latest Intel technologies
and roadmaps, Portwell delivers superior products to meet your needs.
„ Faster Time-to-Market
JOREDORSHUDWLRQDQGÀH[LEOHEXVLQHVVVHUYLFHKHOS\RXPHHWWKH
time-to-market requirement and reduce your new product
introduction cycles as well as the costs of conducting business.
„ Leading Edge Innovator
Portwell is committed to product and solution innovation. We
have a complete variety of proof-of-concept designs with Intel and
we are also a leader in offering the latest technologies to the market.
„ Committed to Customer Satisfaction
Portwell maintains high expectations in a determined pursuit
of commitment to continuously improve our products and
services in order to satisfy and exceed our customers' needs.
Portwell's experienced engineers, complete product solutions,
Consulting
Design
Product
Manufacturing
Logistics
Portwell is proud of the technology service it provides to our partners. These services include complete
service-demand consulting, product development, advanced design, quality production and global logistics.
Share for Success
Portwell is eager to share its industrial know-how with customers
via our online consulting. This feature enables customers to
REWDLQVXLWDEOHRUFXVWRPL]HGVROXWLRQVTXLFNO\DQGHI¿FLHQWO\
Design, Develop, and Deliver
„ We design, develop and deliver our customer requirements,
such as production, reliability, stability, cost-effectiveness, and
longevity of product.
„ Our experienced and sophisticated engineering capabilities
LQFOXGHHOHFWURQLFPHFKDQLFDO¿UPZDUHDQGV\VWHP
integration expertise.
Portwell Manufacturing Excellence
„ We supply component inventory management with
automation.
„ In-house SMT lines and PCB assembly and functional testing.
„ In-house system integration and testing.
„ ,62DQG,62FHUWL¿HGPDQXIDFWXULQJIDFLOLWLHV
(89,000 sq. ft. in Taipei).
„ Flexible production capability.
Portwell Global Presence
„ Single contact window, global support.
„ Sales and technical support teams are available through
3RUWZHOOZRUOGZLGHRI¿FHVLQWKH86$7DLZDQ-DSDQ
China, Netherland, United Kingdom, and India.
„ Customer-centric service and support.
About Portwell
02
Board Production Flow - SMT
Material Baking
The SMD components tend to be thin,
hence, can’t endure high temperature.
Raw Material Inspection
Materials in the production line are prepared based
on the packing list provided by the warehouse staff
and are stored in the WIP buffer area.
Material
Baking
Solder
Paste
Printing
Raw Material
Inspection
IPQC
Our IPQC personnel examine all products according to
the IPC-610D magnifying glass standards to determine
DQGFRQ¿UPHG(&2%20DQGDVVXUHWKHSURGXFWLRQ
contents are without defects.
Receiving
Board Producti
DIP
IPQC
In-Circuit Testing (ICT)
ICT
The ICT automated test system can check the assembly circuit wafer, short circuits,
abruptions, resistors, capacitors, inductor components values, as well as diode, transistor,
FET, SCR, TRIAC, IC for anomallies. Upon completion, reports regarding production and
statistics aid in identifying errors in the production process and ensure product quality.
Visual Inspection
Visual inspection stations are equipped with computers with
Standard Operating Procedures (SOP) for each product. The
SOPs are composed of diagrams which allow our technicians
WRUXQWKHLULQVSHFWLRQHIIRUWOHVVO\DQGHI¿FLHQWO\
&HUWL¿FDWLRQV
WL
&HUWL¿FDWLRQV
3RUWZHOOKDVEHHQFHUWL¿HGZLWK,62DQG7$)FRPSOLDQFHE\
789125'DQG8&6RUJDQL]DWLRQVVLQFH7KLVFHUWL¿HVWKDW
Portwell implements an ISO-9001 quality system and is committed to
continuous improvement.
3RUWZHOOKDVEHHQFHUWL¿HGZLWK,62FRPSOLDQFHE\789125'
since 2010. Portwell follows the ISO 14001 standard as a fundamental
principle. The overall goal is the concept of continuous improvement as
well as commitment to the Plan-Do-Check-Act methodology.
03
Board Production Flow - SMT
AOI - Soldering Paste
Solder Paste Printing
One-hundred percent automatic inspection of the PCB after
solder paste printing detects defects and improves quality
WKH¿UVWWLPH
A stencil plate is used to print the soldering
paste thru the plate holes onto the PCB.
AOI
Solder
Paste
Chips Mounting
High Speed Mounting pertains to different tiny
components such as resistors, capacitors and ICs. This
is a widely used procedure to achieve high precision
production.
Chip
Mounting
Visual
Inspection
on Flow - SMT
Visual Inspection & Repair
Our visual technicians utilize magnifying glass
H[DPLQDWLRQWRFKHFNIRUPDWHULDOÀDZVWKDWFDXVHV
undesirable tendency.
Reflow
Soldering
AOI
Visual
Mounting
Inspection
& Repair
5HÀRZ6ROGHULQJ
5HÀRZXWLOL]DWLRQXVHVDQLQWHUQDOKHDWF\FOHV\VWHPZKLFKDOORZVWKH
soldered components on the PCB to be soldered after cooling.
AOI - Mounting
The AOI machine uses an optical inspection method to verify that the
SULQWLQJPRXQWLQJDQGUHÀRZSURFHVVHVZHUHFRPSOHWHGZLWKRXWGHIHFWV
&HUWL¿FDWLRQV
&HUWL¿FDWLRQV
QV
3RUWZHOOKDVEHHQ,62FHUWL¿HGE\789125'VLQFH,Q
DGGLWLRQWR3RUWZHOO¶VKHDGTXDUWHUVLQ7DLZDQKHUEUDQFKRI¿FHLQWKH
86KDVDOVRDFKLHYHGWKHVDPHFHUWL¿FDWLRQZKLFKUHÀHFWV3RUWZHOO¶V
dedication to continuous improvement in the design and manufacturing of
medical computing devices.
3RUWZHOOLVDSSO\LQJIRU,62FHUWL¿FDWLRQZKLFK
VSHFL¿HVWKHSULQFLSOHVDQGUHTXLUHPHQWVQHFHVVDU\DWWKH
RUJDQL]DWLRQOHYHOIRUTXDQWL¿FDWLRQDQGUHSRUWLQJRIJUHHQKRXVH
gas (GHG) emissions and removals. This includes requirements for
WKHGHVLJQGHYHORSPHQWPDQDJHPHQWUHSRUWLQJDQGYHUL¿FDWLRQ
of an organization’s GHG inventory.
Board Production Flow - SMT
04
System Production Flow
IPQC
9HUL¿HVWKDWDOOWKHSURGXFWLRQSURFHVVHV
are completed correctly and accordingly to
VSHFL¿FDWLRQ
Visual Inspection
Once systems have been assembled, they will have
already been visually inspected. Our inspectors ensure
all components and accessories are assembled properly
and follow MFG before testing.
Assembly
Makes certain that all the system
components were assembled properly (Main
board, Cable, Fan, HDD, etc.)
Visual
Inspection
Assembly
Kiting
Material
System P
Shipping
Shipping
In order to meet the demands of storage, transportation, loading and unloading the products
PHFKDQLFDOO\RXUSDOOHWVWUHWFKZUDSPDFKLQHLVGHVLJQHGWRHQKDQFHSURGXFWLRQHI¿FLHQF\
and prevent damage to the products during transportation.
OQC
OQC
To implement QC inspection procedure on packaged and
¿QLVKHGJRRGV24&KDVWKH0,/±67'(7DEOH4&
staff conducts sampling according to required sampling by
quantity.
„ &HUWL¿FDWLRQ5R+6
6
certa
ain hazardous
haza
The directive that restricts the use of certain
substances
in electrical and electronic equipment (commonly referred to as the
Restriction of Hazardous Substances Directive 2002/95/EC or RoHS)
was adopted in February 2003 by the European Union. This directive
restricts the use of six hazardous materials in the manufacture of
various types of electronic and electrical equipment:
4. Hexavalent Chromium (Cr6+)
1. Lead (Pb)
5. Polybrominated Biphenyls (PBB)
2. Mercury (Hg)
6. Polybrominated Diphenyl Ether (PBDE)
3. Cadmium (Cd)
05
System Production Flow
,Q-XO\RI3RUWZHOOEHFDPH5R+6DQG/HDGIUHHFRPSOLDQW3RUWZHOO
teamed with their industry peers and suppliers to ensure standards
and processes to eliminate lead were met. Furthermore, by May 2005,
Portwell was recognized by the Republic of China Industrial Development
Bureau and Ministry of Economic Affairs as a proactive industry leader
DQGZDV¿UVWWRUHFHLYHJRYHUQPHQWIXQGLQJWRLPSOHPHQWWKHFOHDQHU
production project in the industrial computer industry. While working
closely with industry consortia through WEEE and RoHS transformation,
Portwell established the best administration, R&D team and production
process to include a fastidious commitment to quality. The “green” supply
chain is well established at Portwell and develops green products that
meet or exceed expected requirements.
Basic Function Test
In order to ensure the system product is able to boot up by
Dynamic Burn-In, 100% of the system products are tested
for electronic functionality via a Basic Function Testing after
assembly.
Dynamic Burn In Test
IPQC
Basic
Function Test
Dynamic
Burn In
o
on Flow
DBI is the test used before the product is
shipped out. The purpose is to screen possible
weaknesses and failures which affect its reliability
under different environments.
Advanced
Function Test
Advanced Function Test
This procedure is to ensure the quality
and functionality of the system product
after the Burn-in test.
Packing
In
Warehouse
FQC
Packing
We inspect the product for external defectiveness.
Once they have passed, we then collocate all
accessories into plastic bags then proceed with
boxing and labeling.
FQC
Finished and packed goods are placed in this area for
LQVSHFWLRQWKH)4&GHSDUWPHQWZLOOLQVSHFW¿QLVKHGJRRGV
based on standard procedures.
„ &HUWL¿FDWLRQ2+6$6
$6
&HUWL¿FDWLRQV
3RUWZHOODFKLHYHG2+6$6FHUWL¿FDWLRQE\WKH2+6$6
organization in 2010 and also TOSHMS: 2007 during the same year.
%RWKFHUWL¿FDWLRQVUHSUHVHQWDKLJKUHJDUGIRUODERUVDIHW\FRPPLWPHQW
to employees’ health management and continuous improvement for
the company and society.
OHSAS (Occupational Health and Safety Assessment Series) 18001 is a
VWDQGDUGZKLFKGH¿QHVDVHWRIUHTXLUHPHQWVIRUDVDIHW\PDQDJHPHQWV\VWHP
OHSAS 18001 is compatible with ISO 9001 and ISO 14001. It covers
issues such as:
3ODQQLQJIRUKD]DUGLGHQWL¿FDWLRQ
2. Risk assessment/control
3. OHS (Occupational Health and Safety) management, awareness
and competence, training, communication, emergency preparedness
and response, performance measuring and improvement.
OHSAS 18001 is compatible with ISO 9001 and ISO 14001. It covers
issues such as:
3ODQQLQJIRUKD]DUGLGHQWL¿FDWLRQ
2. Risk assessment/control
3. OHS (Occupational Health and Safety) management, awareness
and competence, training, communication, emergency preparedness
and response, performance measuring and improvement .
System Production Flow
06
What We Focus on
„ ESD Protection
„ Corrective and Preventive Action (CAPA)
ESD is usually caused by HBM (Human-Body Model), MM (Machine
Model), CDM (Charged-Device Model) and FIM (Field-Induced
Model). The advantages of preventing ESD in the factory include
better product reliability, extended usage life, cost savings and
increased yields.
In order to ensure that the products will not be affected by ESD during
production, an ESD control procedure is in place to meet standards.
For operator:
Wear anti-static suits and wrist straps in the factory.
For equipment:
Each device and working area is grounded and tested periodically
WRFRQ¿UPWKDWWKH(6'PHDVXUHPHQWLVQRUPDO
For ESD Area:
(1) Cover the anti-static tape on cables and test tools which are
used in board functional testing.
(2) Use acrylic shelves which may prevent electrostatic charge
build-up.
(3) Cover keyboards with an anti-static membrane to protect
units under test from electrostatic damage.
In order to ensure Portwell offers world-class manufacturing services,
the corrective and preventive processes are implemented to manage
abnormalities and potential problems.
The QA member in charge of a quality issue involves the supplier to
provide corrective actions upon discovering issues. A Supplier Corrective
Action form is sent to the supplier to document the root cause, corrective
action and Portwell’s approval. Once the supplier’s corrective actions are
returned and approved by the QA team, the document is signed which
closes the request in Portwell’s quality system.
Portwell reviews open issues monthly to track issues in order to resolve
and provide closure. We provide a complete check on all of unresolved
issues and establish a time line to close them.
Portwell ensures customer care by identifying and communicating
abnormalities. It is for this reason that corrective and preventive action
LVWDNHQ±WR¿QGRXWWKHURRWFDXVHDQGFRQWLQXRXVO\PRQLWRUWKH
effectiveness of the quality system after solutions are implemented to
ensure issues do not recur.
Submit Analysis
report and
Corrective and
Prevent Action
Procedure
Analyze and
judge which
unit should
be in charged
Abnormality
Discovered
For component:
(1) Suppliers of ESD sensitive components are required to handle
and ship them in a protective manner.
(2) Anti-static packaging is designed to prevent failures due to
electrostatic charge build-up.
NO
Filing
Confirm the
Effective
YES
Improvement
proposal
Execution
QC Audit
„ Employee Training
„ Quality Control
As an integral part of the overall quality system, Portwell
emphasizes quality during the entire manufacturing process, from
WKHDFTXLVLWLRQRIPDWHULDOWRWKHGHOLYHU\RI¿QLVKHGJRRGV
In practice, documents are attached with materials from the
Receiving department to IQC inspection or to IQC return if rejected.
The internal audit checklist ensures that requirements are met
for each process. In addition, Portwell periodically maintains and
calibrates equipment. Per the standard process, if any equipment
LVIRXQGRXWRIVSHFL¿FDWLRQWKHODVWWKUHHORWVRISURGXFWVZLOOEH
UHWHVWHGXVLQJFRQ¿UPHGFDOLEUDWHGHTXLSPHQW0RVWLPSRUWDQWO\
for quality control, all procedures include a checklist for inspection
ZLWKLQLQFRPLQJLQSURFHVVDQG¿QDORXWJRLQJ4&WRHQVXUHWKDW
correct documents and revisions are in place before assembly.
MES software is used to ensure that each assembly station and
process step is completed before moving to next step.
In Portwell MOC, each operator’s professional skills are improved by
training before jobs and re-training periodically as necessary. By paying
particular attention to the human aspects of production, MOC ensures
stable and reliable quality which directly decreases the costs of poor
quality and increase customer satisfaction.
Individual training needs to be established based upon job
requirements, and re-established whenever new equipment, processes
or products are introduced. Training ensures that employees
understand the consequences of performing their jobs incorrectly, and
is conducted prior to assigning employees, contractors, or temporary
personnel to a new task. Training records are maintained according to
the quality system.
In the meantime, competency is measured relative to quality trends
and retraining is provided where necessary.
Quality Assurance
Flow Chart
IQC
t
Ration
Control
07 What We Focus on
IPQC
tion
Par
Audit
FQC
Production
Pre-employment
Training
On-the-Job
Training
Regular
Assessment
Regular
Training
Table of Contents
SINGLE BOARD COMPUTER
PAGE
1-2
About Portwell
8-13
Table of Contents
3-4
Board Production Flow - SMT
14
Portwell Solutions
5-6
System Production Flow
15-18
SBC Reference Table
7
What We Focus On
19 ROBO-8120VG2R
27 ROBO-8912VG2AR
Intel® Xeon® C5500/C3500 series processor
ROBO-8120VG2R
based on PICMG 1.3 SHB with DDR3 SDRAM,
VGA, Dual Gigabit Ethernet and USB
ROBO-8912VG2AR
20 ROBO-8921VG2R
28 ROBO-8210VG2AR
Dual/Quad Core™ Xeon® processor based on
ROBO-8921VG2R
PICMG 1.3 SHB with DDR2 ECC SDRAM, VGA
& Dual Gigabit Ethernet
ROBO-8210VG2AR
21 ROBO-8111VG2AR
ROBO-8111VG2AR
Intel® Xeon® C5500/C3500 series processor based
on PICMG 1.3 SHB with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
ROBO-8111VG2AR-Q77
ROBO-8780VG2A
ROBO-8110VG2AR
ROBO-8779VG2AR
ROBO-8110VG2AR-Q67
ROBO-8777VG2A
Intel® CoreTM 2 Duo processor based on PICMG 1.0
SBC with DDR2 SDRAM, VGA, Dual Gigabit Ethernet,
Audio and USB
32 ROBO-8719VG2AR
ROBO-8719VG2AR
Intel® latest 45nm CoreTM 2 Duo or Celeron® M
processor based on PICMG 1.0 SBC with DDR2
SDRAM, VGA, Dual Gigabit Ethernet and Audio
33 ROBO-6712VGA
25 ROBO-8914VG2AR
ROBO-8914VG2AR
Intel® CoreTM 2 Quad processor based on PICMG
1.0 SBC with DDR3 SDRAM, VGA, DVI, Dual Gigabit
Ethernet, Audio and USB
31 ROBO-8777VG2A
24 ROBO-8110VG2AR-Q67
Intel® CoreTM i7 and i5 processor based on PICMG 1.3
SHB with DDR3 SDRAM, VGA, Dual Gigabit Ethernet,
Audio and USB
Intel® CoreTM i3/i5/i7 processor based on PICMG 1.0
SBC with DDR3 SDRAM, VGA, Dual Gigabit Ethernet,
Audio and USB
30 ROBO-8779VG2AR
23 ROBO-8110VG2AR
Intel® Xeon® and CoreTM i3 processor based on
PICMG 1.3 SHB with DDR3 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
Intel® CoreTM i7/i5 processor based on PICMG
1.3 SHB with DDR3 SDRAM, DVI-I, Dual
Gigabit Ethernet, Audio and USB
29 ROBO-8780VG2A
22 ROBO-8111VG2AR-Q77
Intel® CoreTM i7/i5 processor based on PICMG
1.3 SHB with DDR3 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB3.0
Intel® CoreTM 2 Duo processor based on
PICMG 1.3 SHB with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
Intel® AtomTM D525 processor based on PICMG 1.0
half size SBC with DDR3 SODIMM, VGA, single
Gigabit Ethernet, Audio and USB
Intel® CoreTM 2 Quad processor based on
PICMG 1.3 SHB with DDR3 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
ROBO-6712VGA
26 ROBO-8913VG2AR
ROBO-8913VG2AR
Intel® CoreTM 2 Quad processor based on
PICMG 1.3 SHB with DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
Table of Contents
08
Table of Contents
INDUSTRIAL BACKPLANE
PAGE
34-35 PICMG 1.0 Backplane
38
PCI & ISA Backplane
36-37 PICMG 1.3 Backplane
INDUSTRIAL MAIN BOARD
PAGE
39-41 IMB Reference Table
48 RUBY-9719VG2AR
42 RUBY-M710VG2AR
Intel® Core™ i5/i7/P4500 processor based ATX with
DDR3 SDRAM, Dual Display, Dual Gigabit Ethernet
and USB Ports
RUBY-M710VG2AR
RUBY-9719VG2AR
43 RUBY-D714VG2AR
Intel® CoreTM i5/i7 processor based ATX with DDR3
SDRAM, Triple display, Dual Gigabit Ethernet, and USB
Ports
RUBY-D714VG2AR
49 RUBY-9718VG2AR
RUBY-9718VG2AR
44 RUBY-D715VG2AR
Intel® CoreTM i3 and Xeon® processor based ATX with
DDR3 SDRAM, Dual Display, Dual Gigabit Ethernet and
USB Ports
RUBY-D715VG2AR
RUBY-D712VG2AR
RUBY-9717VGAR
RUBY-D711VG2AR
Intel® Core™ 2 Quad processor based Micro-ATX
Industrial Mainboard with onboard DVI/VGA Dual-display,
DDR2 SDRAM, Gigabit Ethernet, Audio and USB
51 RUBY-9716VG2AR
RUBY-9716VG2AR
46 RUBY-D711VG2AR
Intel® CoreTM i3 and Xeon® processor based ATX with
DDR3 SDRAM, Dual Display, Dual Gigabit Ethernet and
USB Ports
Intel® Core™ 2 Quad processor based ATX Industrial
Mainboard with onboard DVI/VGA Dual-Display, DDR2
SDRAM, VGA, Dual Gigabit Ethernet, Audio and USB
50 RUBY-9717VGAR
45 RUBY-D712VG2AR
Intel® CoreTM i5 and i7 processor based ATX with DDR3
SDRAM, Dual Display, Dual Gigabit Ethernet and USB
Ports
Intel® Core™ 2 Duo/Core™ 2 Quad processor based
ATX Motherboard with DDR2, VGA, Dual Gigabit
Ethernet, Audio and USB
Intel® Core™ 2 Quad processor based ATX Industrial
Mainboard with DDR2 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
52 RUBY-9716VGAR
RUBY-9716VGAR
Intel® CoreTM 2 Quad processor based ATX Motherboard
with DDR2 SDRAM, VGA, Gigabit Ethernet, Audio and
USB
47 RUBY-9911
/HDGLQJ,QWHO® Core™ 2 Quad / Core™ 2 Duo
processor based ATX motherboard with Dual Display,
Dual Gigabit Ethernet, Four SATA Ports, Four COM
Ports, and Eight USB Ports
RUBY-9911
INDUSTRIAL CHASSIS
PAGE
53
About Chassis
54 RPC-500NC/L
56 AREMO-4196
19” 4U industrial rack-mount chassis
53&1&/
09
Table of Contents
AREMO-4196
The Best Cost-Performance 19” 4U Height
Pentium® 4 processor Based Rack-mount
Computer
Table of Contents
59 AREMO-3194
19” 3U rack-mount chassis for ATX M/B
platform
AREMO-3194
68 AREMO-8164
8-slot full-sized industrial node chassis(Shoe-box)
AREMO-8164
61 AREMO-2173P
70 AREMO-4184
19” 2U industrial rack-mount chassis for
PICMG backplane
AREMO-2173P
AREMO-4184
63 AREMO-2173MX
72 AREMO-6182
19” 2U industrial rack-mount chassis for
Micro-ATX or mini-ITX mother board
AREMO-2173MX
19” 4U Height rack-mount chassis with dual
AREMO-6182 node chassis
6-slot full-size industrial node chassis (Shoe-box)
AREMO-6182
65 PRC-1194
74 EZDRV-400
19” 1U Height industrial rack-mount P4
chassis
PRC-1194
EZDRV-400
5.25” compact drive set with slim type DVD-ROM,
SD/CF card reader, 2 USB ports and space for
2.5” HDD
66 AREMO-6163
75-76 Chassis Reference Table
6-slot full-sized industrial node chassis(Shoe-box)
AREMO-6163
3.5” & ECX FORM FACTOR
PAGE
77
ESB Reference Table
78 PEB-2772
PEB-2772
Intel® Cedar Trail AtomTM processor based 3.5’
embedded Board with DDR3 SDRAM,Gigabit Ethernet,
Two SATA Ports, Four COM ports and 12V DC input
82 PEB-2738I
PEB-2738I
79 PEB-2771/2781
PEB-2771/2781
3.5” Embedded size, based on Intel®QP/RZ
Power Pineview processor with DDR3 SODIMM,
GXDOGLVSOD\E\9*$/9'6'XDO*E($XGLR
COM and USB
83 PEB-2737VLA
3(%9/$
80 PEB-2770/2780
PEB-2770/2780
3.5” Embedded size, based on Intel®QP/RZ
Power Pineview processor with DDR2 SODIMM,
GXDOGLVSOD\E\9*$/9'6'XDO*E($XGLR
COM and USB
Intel® QP8OWUD/RZ3RZHU0HQORZ;/SURFHVVRU
and chipset based 3.5” embedded board with dual
display, Audio, USB and SDIO
Intel®QP8OWUD/RZ3RZHU$WRPTM processor based
´HPEHGGHGERDUGZLWK9*$/9'6*LJDELW
Ethernet, Audio, USB and SDIO
84 PEB-2131VG2A
PEB-2131VG2A
3.5” Embedded size, based on Intel® AtomTM N270
processor with DDR2 SDRAM, Dual Display by VGA/
/9'6*LJDELW(WKHUQHW)RXU3RZHU&203RUWVDQG
Audio
81 PEB-2739I
PEB-2739I
Intel® QP8OWUD/RZ3RZHU0HQORZ;/SURFHVVRU
and chipset based 3.5” embedded board with dual
display, Audio, USB, SDIO and SATA
Table of Contents
10
Table of Contents
NANO-ITX FORM FACTOR
PAGE
85
NANO Reference Table
86 NANO-5050
Intel® AtomTM D2550 processor based NANO-ITX Board
with dual display, Gigabit Ethernet, Audio, USB, CFSATA and SATA
NANO-5050
88 NANO-8050
NANO-6040
/HDGLQJIntel® ODWHVW8/90RELOH6))QP&RUHTM 2
Duo or Celeron® M processor based NANO-ITX with
DDR2 SODIMM, Dual Displays, Gigabit Ethernet, Audio,
USB
87 NANO-6040
Intel® AtomTM E6X0T processor based NANO-ITX Board
with dual display, Gigabit Ethernet, Audio, USB, CAN,
SD and SATA
NANO-8050
MINI-ITX FORM FACTOR
PAGE
89
About Mini-ITX Platform
90-93
94 WADE-8020
WADE-8020
Intel® CoreTM i5/i7 processor based Mini-ITX with DDR3
SDRAM, Dual Display, Dual Gigabit Ethernet and USB
Ports
101 WADE-8070
WADE-8070
95 WADE-8067
WADE-8067
/HDGLQJIntel® 45nm CoreTM 2 Duo processor
or Celeron® M processor based Mini-ITX with
DDR3 SDRAM, HDMI, Dual Gigabit Ethernet,
Audio and USB
WADE-8066
WADE-8072
WADE-8170
WADE-8013
WADE-8014
99 WADE-8075/76
WADE-8075/76
Intel® Dual CoreTM AtomTM D525 1.8GHz/N455 1.67GHz
processor based Mini-ITX with DC12V input, DDR3
SDRAM, Dual Display, Dual Gigabit Ethernet, Three
SATA, Four COM and Six USB
WADE-8071
11
Table of Contents
Intel® Next-Gen Dual/Quad processor based Mini-ITX
Board with dual Gigabit Ethernet, Four SATA Ports,
Six COM Ports, One PCI-Express x16 expansion slot
and one Mini-PCIe slot support mSATA interface
106 WADE-8012
WADE-8012
100 WADE-8071
Intel®/RZ3RZHU$WRPTM N270 1.6GHz processor
based Mini-ITX Board with DC12V input, dual
display, Gigabit Ethernet, Two SATA Ports, Two COM
ports and Six USB Ports support thin client application
Intel® Next-Gen Dual/Quad processor based Mini-ITX
Board with dual Gigabit Ethernet, Four SATA Ports,
Six COM Ports, One PCI-Express x16 expansion slot
and one Mini-PCIe slot support mSATA interface
105 WADE-8014
98 WADE-8077
WADE-8077
Intell® AtomTM N270 processor based Mini-ITX Board
with Dual Display, Dual Gigabit Ethernet, Two SATA
Ports, Two COM ports and Eight USB Ports
104 WADE-8013
/HDGLQJ0RELOH,QWHO® CoreTM 2 Duo processor
Mini-ITX with DDR2 SDRAM, Dual Displays, Two
*E(/$1SRUWV)RXU&203RUWV/37DQG86%
Intel® Next-Gen AtomTM processor based Mini-ITX Board
with dual display, dual Gigabit Ethernet, Two SATA
Ports, Two COM Ports (optional up to 4 COM ports) and
Six USB Ports
Intel®/RZ3RZHU$WRPTM N270 1.6GHz
processor based Mini-ITX Board with dual
display, Gigabit Ethernet, Two SATA Ports, Four
COM ports and Six USB Ports
103 WADE-8170
97 WADE-8068
WADE-8068
Intel®/RZ3RZHU$WRPTM N270 1.6GHz
processor based Mini-ITX Board with dual
display, Gigabit Ethernet, Two SATA Ports, Four
COM Ports and Six USB Ports
102 WADE-8072
96 WADE-8066
/HDGLQJ,QWHO® CoreTM 2 Duo processor based
Mini-ITX Board with DDR2 SDRAM, Dual Displays,
7ZR*E(/$1SRUWV$XGLRDQG86%
Mini-ITX Reference Table
Intel® CoreTM i5/ i7 processor based Mini-ITX with dual
displays, DDR3 SDRAM, Two COM Ports and Eight
USB Ports
107 WADE-8011
Intel® i3 and Xeon® processor based Mini-ITX with
dual displays, DDR3 SDRAM, Two COM Ports and
Eight USB Ports
WADE-8011
108 WADE-8180
WADE-8180
/HDGLQJ,QWHO® Core™ 2 Quad/Core™ 2 Duo
processor based Mini-ITX embedded board
with Dual Display, Dual Gigabit Ethernet,
SATA, COM and USB
112 WADE-2221A
WADE-2221A
Rugged and Stylish Industrial Mini-ITX
Bare Bone Chassis
113 WADE-1120A
109 WADE-8056
WADE-8056
/HDGLQJ,QWHO® CoreTM 2 Quad processor
based Mini-ITX Board with Dual Displays
and One GbE
WADE-2231Q
/HDGLQJ,QWHO® CoreTM 2 Quad processor
based Mini-ITX Board with Dual Displays and
One GbE
111 WADE-8656
/HDGLQJ,QWHO® CoreTM 2 Quad processor
based Mini-ITX Board with PCIe expansion
and Two GbE
Rugged and Stylish Industrial Mini-ITX
Bare-Bones Chassis
115 WADE-2232Q
WADE-2232Q
WADE-8656
The fan-less compact Mini-ITX Bore Bone
Chassis
114 WADE-2231Q
110 WADE-8556
WADE-8556
WADE-1120A
Rugged and Stylish Industrial Mini-ITX
Bare-Bones Chassis
116 ARTO-220-ITX
ARTO-220-ITX
1.5U Advanced, Stylish and Compact
Mini-ITX Bare-Bones Chassis
117 WADE-1042
WADE-1042
1U Height Bare Bone server with four
drive bays for RAID and two expansion
slots
118 Riser Card Selection Guide
EMBEDDED COMPUTING SYSTEM
PAGE 119
About WEBS
120-121 Quality Assurance
122-123 WEBS Reference Table
124 Brick concept
125 WEBS-1320
WEBS-1320
130 WEBS-1330
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based 3.5" ECX board
WEBS-1330
131 WEBS-1341
126 WEBS-2121
WEBS-2121
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based NANO-ITX board
WEBS-1341
127 WEBS-3330
WEBS-3330
Embedded compact fan-less system with Intel®
AtomTM N270 based MINI-ITX board
Embedded slim fan-less system with Intel® AtomTM
N270 based MINI-ITX board
Embedded rugged fan-less system with Intel®
Atom™ Z510PT/Z520PT based 3.5” ECX board
Embedded rugged fan-less system with Intel®
AtomTM N270 based MINI-ITX board
133 WEBS-3560B
WEBS-3560B
129 WEBS-1312
WEBS-1312
Embedded rugged fan-less system with Intel®
Atom™ N455/D525 based 3.5” ECX board
132 WEBS-3332
WEBS-3332
128 WEBS-3331
WEBS-3331
Embedded rugged fan-less system with Intel®
Atom™ N270 based 3.5” ECX board
Embedded rugged fan-less system with Intel®
i7/i5 based MINI-ITX board
134 WEBS-4330
WEBS-4330
Embedded rugged fan-less system with
Intel® AtomTM N270 based MINI-ITX board
135 WEBS Mounting Solution
Table of Contents
12
Table of Contents
INDUSTRIAL PSU
PAGE 136 PSU Reference Table
137
146
138
146
139
147
140
141
148
141
148
142
149
142
149
143
150
143 ORION-B4001
150
400W 2U ATX power supply
with active PFC
ORION-B4001
144
150
144
150
APH-3028-150W
APH-3028-150W
145
151
152
145
13
Table of Contents
153-154 Further Contact
Portwell
Embedded Board Solutions
Portwell Embedded Solutions
meet your demand perfectly
3RUWZHOO(PEHGGHGSURGXFWOLQHVSURYLGHDZLGHUDQJHRIVHOHFWLRQVIURPVHUYHUJUDGHWRHQHUJ\HI¿FLHQF\VFDOHLQFOXGLQJ
Modules, 3.5’’, NANO-ITX, Mini-ITX, μATX, ATX, SBC, and Backplane. According to the form factors listed below, Portwell
offers diverse products from high computing power to low power consumption devices. Products with high performance
DUHHTXLSSHGZLWKQRWRQO\WKHODWHVWGHVLJQEXWDOVRYDULRXVIHDWXUHVZKLFKFDQSUHFLVHO\IXO¿OOVWDQGDUGDQGFXVWRPL]HG
GHPDQGV,QDQRWKHUZD\ZKHQHQHUJ\VDYLQJLVWKHSULPDU\FRQFHUQHQHUJ\HI¿FLHQF\LVDOZD\VWKH¿UVWWDUJHWZHDUH
dedicated to. Therefore, in terms of power budget and green technology, Portwell’s designs are still able to perform with a
PLQLPXPRISRZHUFRQVXPSWLRQVXLWDEOHIRUQXPHURXV¿HOGV
'XHWRRXUH[SHULHQFHZLWKFXVWRPL]HGSURMHFWVRXUUHOLDEOHVROXWLRQVFDQEHDGRSWHGDQGDSSOLHGWRPXOWLSOHDSSOLFDWLRQV
such as ATM, Kiosk, Digital Signage, POS (Point-Of-Sale), Lottery, Vending, Gaming, Factory automation, Industrial control, Transportation, Medical and Energy.
Form factor comparison of embedded computer boards
Board Size (inch/mm)
Expansion
Board Size
(inch2)
95.89
Module
13.42
90.17
95.89
Module
13.42
3.55
95.89
90.17
Carrier Board
13.42
4.49
3.74
114.00
95.00
Carrier Board
16.79
COM Express
4.92
3.74
125.00
95.00
Carrier Board
18.40
NANO-ITX
4.72
4.72
120.00
120.00
On Board
22.28
3.5'' Embedded
5.75
4.02
146.00
102.00
Cables
23.12
3.5'' ECX
5.75
4.13
146.00
105.00
Module
23.75
EPIC
6.50
4.53
165.00
115.00
Module
29.45
PICMG 1.3 Half-size
6.60
4.98
167.64
126.39
Backplane
32.87
PCI Half-size
7.28
4.80
185.00
122.00
Backplane
34.94
ISA Half-size
7.28
4.80
185.00
122.00
Backplane
34.94
PICMG 1.2 Half-size
7.52
4.80
191.03
121.92
Backplane
36.10
Mini-ITX
6.69
6.69
170.00
170.00
On Board
44.76
5.25''Embedded
5.75
8.00
146.05
203.20
Cables
46.00
EBX
5.75
8.00
146.05
203.20
Module
46.00
PICMG 1.0 Full-size
13.33
4.80
338.58
121.92
Backplane
63.98
PICMG 1.2 Full-size
13.33
4.80
338.58
121.92
Backplane
63.98
PICMG 1.3 Full-size
13.33
4.98
338.58
126.39
Backplane
66.38
Flex ATX
9.00
7.50
228.60
190.50
On Board
67.50
Micro-ATX
9.60
9.60
243.84
243.84
On Board
92.16
Embedded ATX
9.60
9.60
243.84
243.84
On Board
92.16
ATX
12.00
9.60
304.80
243.84
On Board
115.20
Form Factor
L (inch)
W (inch)
L (mm)
W (mm)
PC/104
3.55
3.78
90.17
PC/104+
3.55
3.78
STX
3.78
ETX
SBC Reference Table
14
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
15
MODEL
ROBO8120VG2R
ROBO8921VG2R
ROBO-8111VG2AR
ROBO8111VG2AR-Q77
Form Factor
PICMG 1.3
PICMG 1.3
PICMG 1.3
PICMG 1.3
CPU
Intel® Dual/Quad
CoreTM Xeon®
Intel® Dual/Quad
CoreTM Xeon®
Intel® Xeon® E3-1200v2/
CoreTM i3
Intel® CoreTM i5/i7
Chipset
Intel® 3420
Intel® 5100
Intel® C216 PCH
Intel® Q77
BIOS
AMI UEFI
AMI Core 8
Phoenix UEFI
Phoenix UEFI
Memory
4x DDR3 ECC, REG DIMM up 4x DDR2 ECC, REG DIMM up 2x DDR3 ECC DIMM up to
to 32GB
to 32GB
16GB
Expansion
4x
1x
2x
4x
Display
VGA/DVI-D
VGA/DVI-D
VGA/DVI-D/HDMI
VGA/DVI-D/HDMI
Audio
No
No
Realtek ALC 886-GR HD
Audio codec
Realtek ALC 886-GR HD Audio
codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
USB
12x USB 2.0
10x USB 2.0
10x USB 2.0
4x USB 3.0
10x USB 2.0
4x USB 3.0
Storage Devices
6x SATA
1x FDD
6x SATA
1x FDD
6x SATA
1x FDD
6x SATA
1x FDD
GPIO
8-bit
8-bit
8-bit
8-bit
Others
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
Dimension
338.5 x 126.39mm
338.5 x 126.39mm
338.5 x 126.39mm
338.5 x 126.39mm
Page
19
20
21
22
SBC Reference Table
PCI slots
PCIe x16 slot
PCIe x8 slots
PCIe x4 slots
4x
1x
1x
3x
PCI slots
PCIe x16 slot
PCIe x8 slot
PCIe x4 slots
4x
1x
1x
1x
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
2x DDR3 DIMM up to 16GB
4x
1x
2x
1x
PCI slots
PCIe x16 slot
PCIe x8 slots
PCIe x8 slot+2x PCIe x4 slots
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8110VG2AR
ROBO8110VG2AR-Q67
ROBO-8914VG2AR ROBO-8913VG2AR
Form Factor
PICMG 1.3
PICMG 1.3
PICMG 1.3
PICMG 1.3
CPU
Intel® Xeon® E3-1200/
Intel® CoreTM i3
Intel® CoreTM i5/i7
Intel® CoreTM 2 Quad/CoreTM
2 Duo/Celeron®
Intel® CoreTM 2 Quad/ CoreTM
2 Duo/Celeron®
Chipset
Intel® C206 PCH
Intel® Q67 PCH
Intel® Q45+ICH10DO
Intel® Q35+ICH9DO
BIOS
AMI UEFI
AMI UEFI
AMI Core 8
AMI Core 8
Memory
2x DDR3 ECC DIMM up to
16GB
2x DDR3 DIMM up to 16GB
4x DDR3 DIMM up to 8GB
2x DDR2 DIMM up to 4GB
Expansion
4x
1x
1x
1x
4x PCI slots
1x PCIe x16 slot
4x PCIe x1 slots
4x PCI slots
1x PCIe x16 slot
4x PCIe x1 slots
4x PCI slots
1x PCIe x16 slot
4x PCIe x1 slots
Display
DVI-I/HDMI
DVI-I/HDMI
VGA
VGA
Audio
Realtek ALC 662 HD Audio
codec
Realtek ALC 662 HD Audio
codec
Realtek ALC 662 HD Audio
codec
Realtek ALC 262 HD Audio
codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
USB
14x USB 2.0
14x USB 2.0
12x USB 2.0
12x USB 2.0
Storage Devices
6x SATA
1x FDD
6x SATA
1x FDD
6x SATA
1x FDD
6x SATA
1x FDD
GPIO
8-bit
8-bit
8-bit
8-bit
Others
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
IrDA 1.0
Dimension
338.5 x 126.39mm
338.5 x 126.39mm
338.5 x 126.39mm
338.5 x 126.39mm
Page
23
24
25
26
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
SBC Reference Table
16
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
17
MODEL
ROBO-8912VG2AR ROBO-8210VG2AR
ROBO8780VG2A
ROBO-8779VG2AR
Form Factor
PICMG 1.3
PICMG 1.0
PICMG 1.0
CPU
Intel® CoreTM 2 Duo/ Pentium®
Intel® CoreTM 2 Duo/ Celeron® Intel® Dual CoreTM
D/Pentium® 4/ Celeron® D
Intel® CoreTM 2 Quad/CoreTM
2 Duo/Celeron®
Chipset
Intel® Q965+ICH8DO
Intel® QM57
Intel® H61
Intel®G41+ICH7R
BIOS
AMI Core 8
AMI UEFI
AMI UEFI
AMI Core 8
Memory
2x DDR2 DIMM up to 4GB
2x DDR3 DIMM up to 8GB
2x DDR3 DIMM up to 16GB
2x DDR3 DIMM up to 4GB
Expansion
4x PCI slots
1x PCIe x16 slot
4x PCIe x1 slots
4x
1x
2x
1x
4x PCI slots
4x PCI slots
1x ISA
Display
VGA
DVI-I
DVI-D
VGA/ DVI-D
Audio
Realtek ALC 262 HD Audio
codec
Realtek ALC 662 HD Audio
codec
Realtek ALC 886-GR HD
Audio codec
Realtek ALC 662 HD Audio
codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
USB
10x USB 2.0
12x USB 2.0
2x USB 3.0
10x USB 2.0
8x USB 2.0
Storage Devices
6x SATA
1x FDD
6x SATA
1x FDD
4x SATA
1x FDD
6x SATA
1x CF
1x FDD
GPIO
8-bit
8-bit
8-bit
8-bit
Others
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
Dimension
338.5 x 126.39mm
338.5 x 126.39mm
338.5 x 122mm
338.5 x 122mm
Page
27
28
29
30
SBC Reference Table
PICMG 1.3
PCI slots
PCIe x16 slot
PCIe x8 slots
Mini-PCIe socket
SBC Reference Table
FULL-SIZE SINGLE BOARD COMPUTER
MODEL
ROBO-8777VG2A
ROBO-8719VG2AR
ROBO6712VGA
Form Factor
PICMG 1.0
PICMG 1.0
PICMG 1.0 half size
CPU
Intel® CoreTM 2 Duo/ Pentium® Intel® Mobile CoreTM 2 Quad/
Intel® AtomTM D525
CoreTM 2 Duo/ Celeron®M
D/Pentium® 4/ Celeron® D
Chipset
Intel® Q965+ICH8
Intel® GM45+ICH9ME
ICH8M
BIOS
Award
Award
Phoenix UEFI
Memory
2x DDR2 DIMM up to 4GB
2x DDR2 DIMM up to 4GB
1x DDR3 SODIMM up to 2GB
Expansion
4x PCI slots
1x ISA
4x PCI slots
1x ISA
4x PCI slots
Display
VGA
VGA/LVDS
VGA/LVDS
Audio
Realtek ALC 262 HD Audio
codec
Realtek ALC 262 HD Audio
codec
Realtek ALC 662 HD Audio
codec
LAN
2x GbE
2x GbE
1x GbE
Serial Port
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
USB
6x USB 2.0
6x USB 2.0
6x USB 2.0
Storage Devices
4x SATA
1x FDD
3x SATA
1x CF
1x FDD
3x
1x
1x
1x
GPIO
8-bit
8-bit
8-bit
Others
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
Dimension
338.5 x 122mm
338.5 x 122mm
185 x 122mm
Page
31
32
33
SATA
IDE
CF
FDD
SBC Reference Table
18
ROBO-8120VG2R
Four 240-pin DDR3 DIMM sockets
LGA1366 socket
Intel® Xeon® C5500/C3500 series processor
based on PICMG 1.3 SHB with DDR3 SDRAM,
VGA, Dual Gigabit Ethernet, Audio and USB
Four SATA II ports
One RS232/422/485
selectable port
FDD port
Parallel port
BIOS
SATA
3Gb
DDR 3
Watch DOG
PS/2 keyboard & mouse
Dual USB ports
One RS232 port
Dual GbE ports
Giga
53.41
5.99
0
1.60
VGA port
Six USB Ports
LGA1366 socket
ROBO-8120VG2R is based on Intel® 3420
chipset and dual Xeon® processors. It’s a server
grade SHB built with high computing power and
ÀH[LEOH3&,H[SUHVVH[SDQVLRQVXSSRUWLW¶VVXLWable for military, industrial automation, and digital
signage applications.
FEATURES
„ Supports Intel® Dual/Quad CoreTM Xeon®
processors with LGA1366 package
„ Delivers up to 32GB DDR3 maximum ECC
registered memory assured the computer
UHOLDELOLW\DQGEHQH¿WHGWKHGDWDVZDSSLQJ
process
„ Adopts the XGI Z11 graphics engine and offers
solid 2D performance
„ Supports VGA display on bracket and optional
2nd VGA or DVI-D interface
Intel® 3420
XGI Z11 DVI-D port
(optional)
„ Rich I/O connectors such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0,
and SATA ports
ORDERING GUIDE
AB1-3479
ROBO-8120VG2R
PICMG 1.3(PCI-E+PCI). LGA1366.Jasper Forest
Single/Dual/Quad Core processors.SHB.w/VGA/
Dual GbE
H/W Monitor
USB 3.0
GPIO
2nd VGA port
(optional)
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
- Intel® Single/Dual/Quad CoreTM Xeon® C5500/C3500 series processor up to
*+]a:ZLWKa0%//&&DFKHLQ/*$SDFNDJH
(Only support single processor on C3500 series)
- Intel® QPI transfer rates: 4.8 and 5.87 GT/s (depends on CPU sku)
- DMI x4 Link: 2.5 GT/s
- Supports Intel®+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7HFKQRORJ\97[DQG
QuickPath Technology
- Intel®:
- Supports Intel® Rapid Storage Technology
AMI UEFI BIOS
Supports up to 32GB DDR3 1333/1066/800 SDRAM on four 240-pin DIMM
sockets, support ECC, rigistered
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 2x PCI Express x8 Gen 1 up to 2.5 GT/s
- 4x PCI Express x4 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]
(Optional for PCI Express Gen 2 support)
„ Rich & powerful I/O expansion covers PCIe
Gen 2.0 for one PCI Express x16 or two PCI
Express x8 or four PCI Express x4
„ High speed dual Gigabit Ethernet based on
3&,([SUHVV[LQWHUIDFHSURYLGHV:DNH2Q
LAN function
Giga LAN
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:'+*
N/A
- Intel®:*/JLJDELWHWKHUQHWFRQWUROOHU[
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 port on rear I/O
- 1x Selectable RS232/422/485 on board box header
- 12x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
PACKING LIST
Standard
Optional
B6900960 cable kit for 1 serial + 1 parallel
port w/ bracket
B6900074 FDD Cable
B6901990 SATA II cable
B8981980 PICMG SBC Handling and Installation
Notice
B3751380 Installation CD
B8303921 single processor cooler
B6901970 two USB port cable w/bracket
B6901610 one DVI-D + one VGA cable with bracket
DISPLAY
Graphic Controller
Display Interface
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
19
SBC-ROBO-8120VG2R
XGI Z11
9*$RQEUDFNHW5HVROXWLRQXSWR[#0FRORXUV+]
- Optional second VGA or DVI-D display interface
/[:PP/[:
- PCB: 12 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&)RU:&38OLPLWDWLRQ
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
ROBO-8921VG2R
Four 240-pin DDR2 DIMM sockets
Four SATA II ports
Dual/Quad CoreTM Xeon® processor
based on PICMG 1.3 SHB with DDR2 ECC
SDRAM, VGA & Dual Gigabit Ethernet
Parallel port
Four USB ports
Dual COM ports
FDD port
DDR 2
Watch DOG
Dual USB ports
Giga
Dual GbE ports
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
USB 3.0
VGA
Intel® 82575 Gigabit Ethernet
XGI Z11
48.40
8
0
1.60
VGA port
Intel® Dual/Quad Core
Xeon® processor
ROBO-8921VG2R has adopted the 5100 chipset and dual Xeon® processors. By high conputLQJSRZHUDQGDÀH[LEOH3&,H[SUHVVH[SDQsion support, it’s suitable for military, industrial
automation, and digital signage applications.
FEATURES
Intel® 5100
Intel® ICH9R
GENERAL
Processor
Chipset
R2%2RIIHUVÀH[LEOH0+]
selection of Intel® Dual/Quad CoreTM Xeon®
processors with LGA771 package
BIOS
„
Flexible design of dual PCI Express x8 could
be aggregated as one PCI Express x16 for
Graphic card
Storage Devices
„
Rich & powerful I/O expansion covers dual PCI
Express x8, one PCI Express x4 and four PCI
devices
„
„
Up to 32GB, ECC registered memory ensure
WKHFRPSXWHU¶VUHOLDELOLW\DQGEHQH¿WHGWKH
data swapping process
„
Relative high performance graphic engine, XGI
Z11 provides solid 2D for the server grade market
„
Dual PCI Express x4 based Gigabit Ethernet
VXSSRUW,3Y,3YRIÀRDGLQJ9/$1:DNH
On-LAN functions
ORDERING GUIDE
AB1-3147
ROBO-8921VG2R
PICMG 1.3(PCI-E+PCI).Socket 771.Xeon
LV.SHB.w/VGA/Dual GB LAN
PACKING LIST
Standard
Optional
B6900960 cable kit for 1 serial + 1 parallel port
w/ bracket
B6900074 FDD cable
B6901990 SATAI II cable
B8301761 2 in 1 CPU cooler
B8981980 PICMG SBC Handling and Installation
Notice
B3751110 Installation CD
B6901620 keyboard and mouse cable with bracket
B6901610 one DVI +one VGA cable with bracket
B6901970 two USB port cable with bracket
B6902000 two serial port cable with bracket
TMDS port 2nd VGA port
(optional)
(optional)
Memory
- Intel® Dual/Quad CoreTM Xeon®VHULHVSURFHVVRUXSWR*+]a:
ZLWK0%a0%/&DFKHGHSHQGVRQ&38VNXLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®+\SHU7KUHDGLQJ9LUWXDOL]DWLRQDQG6SHHG6WHS7HFKQRORJ\
- Intel®:
,&+5:
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\
AMI Core 8 BIOS
Supports up to 32GB DDR2 533/667 SDRAM on four 240-pin DIMM sockets,
supports ECC, rigistered
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 1x PCI Express x8 Gen 1 up to 2.5 GT/s
- 3x PCI Express x4 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:'+*
N/A
- Intel® JL82575EB dual port gigabit ethernet controller
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x4 interface based on Gigabit Ethernet
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 10x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
Display Interface
XGI Z11
9*$RQEUDFNHW5HVROXWLRQXSWR[#0FRORXUV+]
- Optional second VGA or DVI-D display interface
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 12 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&)RU:&38OLPLWDWLRQ
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
SBC-ROBO-8921VG2R
20
ROBO-8111VG2AR
Dual 240-pin DDR DIMM socket
HDMI port
Intel® Xeon® E3-1200v2/CoreTM i3 series
processor based on PICMG 1.3 SHB with
DDR3 SDRAM, VGA, Dual Gigabit Ethernet,
Audio and USB
PS/2 B and Mouse
One RS2 2 port
One RS2 2/422/485 selectable port
Parallel port
FDD port
T o USB .0 ports
BIOS
USB 3.0
Dual USB .0 ports
DDR 3
DVI-I
Dual GbE ports
Giga
Giga LAN
H/W Monitor
SATA
6Gb
GPIO
DVI-I port
(DVI-D VGA)
71
.4
0
1.60
12V po er connector
GA1155 socket
ROBO-8111VG2AR is based on the Intel® C216
chipset and workstation processor sku. Built with
ÀH[LEOH3&,H[SUHVVH[SDQVLRQLW¶VVXLWDEOHIRU
medical, Factory Automation, and Digital Signage
applications.
T o SATA II ports
Si USB 2.0 ports
Intel® C216
T o SATA III ports
GENERAL
Processor
- Intel® Xeon® E3-1200v2 series and CoreTM i3 processor in LGA1155 package
- IDMI x4 Link: 5.0 GT/s
- Supports Intel® 7XUER%RRVW+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7KHUPDO
Monitoring, Trusted Execution and SpeedStep Technology (depends on CPU sku)
Chipset
Intel® C216 PCH
BIOS
Phoenix UEFI BIOS
„ Supports Intel® Xeon® E3-1200v2 series/
CoreTM i3 processors in LGA1155 package
Memory
„ Delivers up to 16GB maximum DDR3
1333/1600 ECC SDRAM on two DIMM sockets
Storage Devices
- Supports up to 16GB DDR3 1333/1600 SDRAM on two 240-pin ECC DIMM sockets
- Supports ECC
- Suppors 2x SATA III drives and 4x SATA II drives
(Dual SATA II ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan Speed and Temperature)
FEATURES
„ Supports multiple display by DVI-I (DVI-D+VGA)
and HDMI
:DWFKGRJ7LPHU
Hardware Monitoring
„ Supports iAMT 8.0 on Intel® Xeon® E3-1200v2
series processors
Expansion Interface
- From CPU (Xeon/Core i3): 1x PCI Express x16 or 2x PCI Express x8 or
[3&,([SUHVV[[3&,([SUHVV[E\MXPSHUVHWWLQJ
- From PCH: 1x PCI Express x4 or 4x PCI Express x1 by different bios support
[3&,GHYLFHVDWELW0+]
„ High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„ Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0/3.0
„ On-board two SATA II and two SATA III ports
support RAID 0,1,5,10
ORDERING GUIDE
AB1-2329
ROBO-8111VG2AR
PICMG 1.3(PCI-E+PCI).LGA1155.
Xeon /i3 processors.SHB.w/VGA/Dual GbE/Audio
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
PACKING LIST
Standard
Optional
B6901990 SATA II cable
B6902930 SATA III cable (Black)
B690021S cable kit for FDD+PRN with bracket
B6900270 dule head COM port cable with bracket
B6902890 DVI-D + VGA cable with bracket
B8981980 PICMG SBC Handling and Installation Notice
B3751500 Installation CD
B6902980 PS/2 Keyboard / Mouse Cable with bracket
B6902230 USB port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
GPIO
Others
ITE IT8728F
- Intel®%'&3&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec, 7.1 channels
- Intel® 82579LM+82574L gigabit ethernet controller
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x1 interface based on gigabit ethernet
- Dual RJ-45 connector with two LED indicators
- 1x RS232 and 1x selectable RS232/422/485 on board
- 10x USB 2.0 ports (four ports through backplane)
- 480Mb/s bus capable of high-speed/full-speed/low-speed data ranges
- 4x USB 3.0 ports pn board (two ports on board, two ports on bracket)
- 5Gbps bus capable of high-speed/ full-speed/low-speed data ranges
2x USB 3.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port
DISPLAY
Graphic Controller
Display Interface
- Intel® Xeon® and CoreTM i3 processors integrated graphics engine
- Provides improved 3D multimedia capabilities including Microsoft DirectX 11,
Shader Model 4.0, MPEG-2 and OpenGL 3.1
&57RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'XSWR[#+]
+'0,XSWR[#+]&57'9,'RQEUDFNHWE\'9,,SRUW
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
21
SBC-ROBO-8111VG2AR
/[:PP/[:
- PCB: 12 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&)RU:&38OLPLWDWLRQ
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
ROBO-8111VG2AR-Q77
PS/2 B and Mouse
Dual 240-pin DDR DIMM socket
HDMI port
Intel® CoreTM i7/i5 processor based
on PICMG 1.3 SHB with DDR3
SDRAM, VGA, Dual Gigabit Ethernet,
Audio and USB3.0
One RS2 2 port
One RS2 2/422/485 selectable port
Parallel port
FDD port
T o USB .0 ports
BIOS
USB 3.0
Dual USB .0 ports
DDR 3
DVI-I
Dual GbE ports
Giga
71
.4
0
1.60
DVI-I port
(DVI-D VGA)
12V po er connector
GA1155 socket
ROBO-8111VG2AR-Q77 is based on Intel® Q77
chipset and CoreTM i7/i5 sku processor. It’s suitable for Medical, Factory Automation, and Digital
Signage applications.
FEATURES
„ Supports Intel® CoreTM i7/i5 processors in
LGA1155 package
Intel® Q77
T o SATA II ports
Si USB 2.0 ports
T o SATA III ports
„ Supports iAMT 8.0 on Intel® CoreTM i7/i5
processors
„ High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
Chipset
Intel® Q77 PCH
BIOS
Memory
Phoenix UEFI BIOS
Storage Devices
- Suppors 2x SATA III drives and 4x SATA II drives
(Dual SATA II ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan Speed and Temperature)
:DWFKGRJ7LPHU
Hardware Monitoring
Expansion Interface
Ethernet
PACKING LIST
Standard
Optional
B6901990 SATA II cable
B6902930 SATA III cable (Black)
B690021S cable kit for FDD+PRN with bracket
B6900270 dule head COM port cable with bracket
B6902890 DVI-D + VGA cable with bracket
B8981980 PICMG SBC Handling and Installation Notice
B3751500 Installation CD
B6902980 PS/2 Keyboard / Mouse Cable with bracket
B6902230 USB port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
- Supports up to 16GB DDR3 1333/1600 SDRAM on two 240-pin DIMM sockets
- From CPU: 1x PCI Express x16
- From PCH: 1x PCI Express x4 or 4x PCI Express x1 by different bios support
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
„ On-board two SATA II and two SATA III ports
support RAID 0,1,5,10
ROBO-8111VG2AR-Q77
PICMG 1.3(PCI-E+PCI).LGA1155.
i7/i5 processors.SHB.w/VGA/Dual GbE/Audio
GPIO
- Intel® CoreTM i7/i5 processor in LGA1155 package
- IDMI x4 Link: 5.0 GT/s
- Supports Intel® 7XUER%RRVW+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7KHUPDO
Monitoring, Trusted Execution and SpeedStep® Technology (depends on CPU sku)
Super I/O
Audio
AB1-2330
SATA
6Gb
Processor
„ Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0/3.0
ORDERING GUIDE
H/W Monitor
GENERAL
„ Delivers up to 16GB maximum DDR3
1333/1600 SDRAM on two DIMM sockets
„ Supports multiple display by DVI-I (DVI-D+VGA)
and HDMI
Giga LAN
Serial Port
USB
Keyboard & Mouse
GPIO
Others
ITE IT8728F
- Intel®%'&3&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec, 7.1 channels
- Intel® 82579LM+82574L gigabit ethernet controller
- Dual 10BASE-T/100BASE-TX/1000BASE-T Ethernet
- PCI Express x1 interface based on gigabit ethernet
- Dual RJ-45 connector with two LED indicators
- 1x RS232 and 1x selectable RS232/422/485 on board
- 10x USB 2.0 ports (four ports through backplane)
- 480Mb/s bus capable of high-speed/full-speed/low-speed data ranges
- 4x USB 3.0 ports pn board (two ports on board, two ports on bracket)
- 5Gbps bus capable of high-speed/ full-speed/low-speed data ranges
2x USB 3.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port
DISPLAY
Graphic Controller
Display Interface
- Intel® CoreTM i7/i5 processors integrated graphics engine
- Provides improved 3D multimedia capabilities including Microsoft DirectX 11,
Shader Model 4.0, MPEG-2 and OpenGL 3.1
&57RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'XSWR[#+]
+'0,XSWR[#+]&57'9,'RQEUDFNHWE\'9,,SRUW
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 12 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&ZLWKKLJKHVWSHUIRUPDQFHRQƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
SBC-ROBO-8111VG2AR-Q77
22
ROBO-8110VG2AR
Dual 240-pin DDR DIMM sockets
Intel® Xeon® and Core™ i3 processor based
on PICMG 1.3 SHB with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
PS/2 B and Mouse
One RS2 2 port
HDMI port
One RS2 2/422/485
selectable port
Parallel port
FDD port
BIOS
USB 3.0
Eight USB ports
Dual USB ports
DVI-I
DDR 3
Dual GbE ports
Giga
Giga LAN
H/W Monitor
SATA
6Gb
GPIO
DVI-I port
(DVI-D VGA)
GA1155 socket
.4
0
1.60
ROBO-8110VG2AR is based upon the Intel®
C206 chipset and workstation processor sku
like Xeon® and CoreTML%XLOWZLWKÀH[LEOH3&,
express expansion, it’s suitable for medical,
industrial automation, and digital signage applications.
FEATURES
„
Supports Intel Xeon E3-1200 series and
CoreTM i3 processors in LGA1155 package
„
Delivers up to 16GB maximum DDR3
1333/1066 ECC SDRAM on two DIMM sockets
„
Supports multiple display with DVI-I (DVI-D+
VGA) and HDMI
®
®
„
Supports iAMT 7.0 on Xeon® E3-1200 series
processors
„
High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„
„
Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0
On-board two SATA II and two SATA III ports
support RAID 0,1,5,10
ORDERING GUIDE
AB1-3600
ROBO-8110VG2AR
PICMG 1.3(PCI-E+PCI). LGA1155.Core 2 Quad.
SHB.w/VGA/Dual GbE/Audio
PACKING LIST
Standard
Intel® C206
71
12V po er connector
B6901990 SATA II cable
B6902930 SATA III cable (Black)
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6902890 DVI-D + VGA cable with bracket
B8981980 PICMG SBC Handling and Installation Notice
T o SATA III ports
T o SATA II ports
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
- Intel® CoreTM i3 and Xeon®(VHULHVSURFHVVRUXSWR*+]a:
ZLWKa0%&DFKHLQ/*$SDFNDJH
- DMI x4 Link: 5.0 GT/s
- Supports Intel®7XUER%RRVW+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7KHUPDO
Monitoring,Trusted Execution and SpeedStep Technology (depends on CPU sku)
Intel®&3&+:
AMI UEFI BIOS
- Supports up to 16GB DDR3 1066/1333 SDRAM on two 240-pin ECC DIMM sockets
- 2x SATA III drives and 4x SATA II drives (Dual SATA II ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- From CPU (Xeon/Core i3): 1x PCI Express x16 or 2x PCI Express x8 or
[3&,([SUHVV[[3&,([SUHVV[E\MXPSHUVHWWLQJ
- From PCH: 1x PCI Express x4 or 4x PCI Express x1 by different bios support
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
ITE IT8728F
- Intel®%'&3&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Intel® 82579LM+82574L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators
- 1x RS232 on bracket
- 1x Selectable RS232/422/485 on bracket
- 14x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
Display Interface
- Intel® Xeon® and CoreTM i3 processors integrated graphic engine P3000
- Provided improved 3D multimedia capabilities including Microsoft DirectX
6KDGHU0RGHO03(*DQG2SHQ*/
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'XSWR[#+]
+'0,XSWR[#+]
(VGA + DVI-D on bracket by DVI-I port)
B3751400 Installation CD
Optional
B6902980 PS/2 Keyboard/Mouse Cable with bracket
B6902230 USB port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
23
SBC-ROBO-8110VG2AR
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&ZLWKEHWWHUSHUIRUPDQFHRQƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
ROBO-8110VG2AR-Q67
Dual 240-pin DDR DIMM socket
PS/2 B and Mouse
Intel® Core™ i7 and i5 processor
based on PICMG 1.3 SHB with
DDR3 SDRAM, VGA, Dual Gigabit
Ethernet, Audio and USB
One RS2 2 port
One RS2 2/422/485 selectable port
Parallel port
FDD port
BIOS
USB 3.0
Eight USB ports
Dual USB ports
DDR 3
Dual GbE ports
DVI-I
Giga
DVI-I port
(DVI-D VGA)
ROBO-8110VG2AR-Q67 is based on the Intel®
Q67 chipset and desktop processor sku like
Intel® CoreTMLDQGL%XLOWZLWKÀH[LEOH3&,
express expansion, it’s suitable for Medical,
Industrial Automation, and Digital Signage applications.
FEATURES
„
Supports Intel® CoreTM i7 and i5 processors in
LGA1155 package
„
Delivers up to 16GB maximum DDR3
1333/1066 SDRAM on two DIMM sockets
„
Supports multiple display with DVI-I (DVI-D+
VGA) and HDMI
„
Supports iAMT 7.0 on CoreTM i7 and i5
processors
„
High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„
„
Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0
On-board two SATA II and two SATA III ports
support RAID 0,1,5,10
ORDERING GUIDE
AB1-3774
ROBO-8110VG2AR-Q67
PICMG 1.3(PCI-E+PCI).LGA1155.Core 2 Quad.
SHB.w/VGA/Dual GbE/Audio
PACKING LIST
Standard
Intel® Q67
HDMI port
T o SATA III ports
T o SATA II ports
H/W Monitor
SATA
6Gb
GPIO
71
.4
0
1.60
12V po er connector
GA1155 socket
Giga LAN
B6901990 SATA II cable
B6902930 SATA III cable (Black)
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6902890 DVI-D + VGA cable with bracket
B8981980 PICMG SBC Handling and Installation Notice
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
- Intel® CoreTMLDQGLSURFHVVRUXSWR*+]a:ZLWKa0%
Cache in LGA1155 package
- DMI x4 Link: 5.0 GT/s
- Supports Intel®7XUER%RRVW+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7KHUPDO0RQLWRULQJ
Trusted Execution and SpeedStep® Technology (depends on CPU sku)
Intel®43&+:
AMI UEFI BIOS
- Supports up to 16GB DDR3 1066/1333 SDRAM on two 240-pin DIMM sockets
- 2x SATA III drives and 4x SATA II drives (Dual SATA II ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan Speed and Temperature)
Expansion Interface
- From CPU: 1x PCI Express x16
- From PCH: 1x PCI Express x4 or 4x PCI Express x1 by different bios support
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
ITE IT8728F
- Intel®%'43&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Intel® 82579LM+82574L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators
- 1x RS232 on bracket
- 1x Selectable RS232/422/485 on bracket
- 14x USB 2.0 ports (four ports through backplane)
- 480 Mb/s bus capable of high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
Display Interface
- Intel® CoreTM i7 and i5 processors integrated graphic engine P3000
- Improved 3D multimedia capabilities including Microsoft DirectX
6KDGHU0RGHO03(*DQG2SHQ*/
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'XSWR[#+]
+'0,XSWR[#+]
(VGA + DVI-D on bracket by DVI-I port)
B3751400 Installation CD
Optional
B6902980 PS/2 Keyboard / Mouse Cable with bracket
B6902230 USB port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&ZLWKEHWWHUSHUIRUPDQFHRQƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
SBC-ROBO-8110VG2AR-Q67
24
ROBO-8914VG2ARR
Intel® Core™ 2 Quad processor based on
PICMG 1.3 SHB with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
12V Po er connector
Four 240 pin DDR DIMM sockets Four SATA II ports
One RS2 2/422/485
selectable port
Parallel port
FDD port
One RS2 2 port
PS/2 ke board
ouse
Dual USB ports
DDR 3
Watch DOG
Giga
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
USB 3.0
VGA
Dual GbE ports
57
0
1.60
5.16
VGA port
GA775 socket
ROBO-8914VG2AR is based on Intel® 82Q45
GMCH and ICH10DO. It supports four DDR3
memory for higher capacity. By supporting
PCI-Express x16, it’s applied more faster rate to
Image Processing and Industrial Automation.
FEATURES
„
Supports Intel® CoreTM 2 Duo and CoreTM 2
4XDGSURFHVVRUVDQGRIIHUVÀH[LEOH
0+])6%VHOHFWLRQ
„
Delivers up to 8GB maximum DDR3 1066/800
on four long DIMM sockets
„
Supports Intel® Q45 integrated GMA 4500
JUDSKLFHQJLQHGHOLYHUVRSWLPL]HG'JUDSKLFV
performance
„
Supports iAMT 5.0 and iTPM function
„
High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„
Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port, USB 2.0
„
Four on-board SATA ports support RAID
0,1,5,10
ORDERING GUIDE
AB1-3486
ROBO-8914VG2AR
PICMG 1.3(PCI-E+PCI).LGA775.Core 2 Quad.
SHB.w/VGA/Dual GbE/Audio
PACKING LIST
Standard
Optional
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6901990 SATA II cable
B8981980 PICMG SBC Handling and Installation Notice
B3751250 Installation CD
B6902230 USB port cable with bracket
B6901442 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
Intel® Q45
Intel® ICH10DO
Si USB Ports
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
- Intel® Core™ 2 Quad/Core™ 2 Duo/Celeron®3URFHVVRUXSWR*:a:
ZLWK.a0%/&DFKHLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
- Intel®4*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+'2:
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\IRU'LUHFWHG,297G
AMI Core 8 BIOS
Supports up to 8GB DDR3 1066/800 SDRAM on four 240-pin DIMM sockets
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 4x PCI Express x1 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:7+*5YHUVLRQ:'+*375YHUVLRQ
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Intel® 82567LM+82574L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 12x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
Display Interface
- GMCH integrated Intel Graphic Media Accelerator (GMA) 4500
- Provided improved 3D multimedia capabilities including Microsoft DirectX 10,
Shader Model 4.0, MPEG-2 and OpenGL 2.1
- Intel Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to 1GB
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
25
SBC-ROBO-8914VG2AR
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
ROBO-8913VG2AR
Dual 240-pin DDR2 DIMM sockets
FDD port
Intel® Core™ 2 Quad processor based on
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
One RS2 2 port
One RS2 2/422/485
selectable port
Parallel port
PS/2 ke board
ouse
Si USB ports
Dual USB ports
DDR 2
Watch DOG
Giga
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
USB 3.0
VGA
Dual GbE ports
57
0
1.6
5.16
VGA port
GA 775 socket
12V po er connector
ROBO-8913VG2AR is built with the Intel® Q35,
ICH9DO chipset up to CoreTM 2 Quad processors. It supports DDR2 memory, and two Intel®
Gigabit Ethernet. It’s an ideal solution for Image
Processing and Industrial Automation applications.
FEATURES
Intel® Q 5
Intel® ICH9DO
GENERAL
Processor
Chipset
„
Supports Intel® CoreTM 2 Quad processor up to
)6%0+]
BIOS
Memory
„
/RZSUR¿OHSURFHVVRULPSURYHVVWDELOLW\DQG
reliability of whole system
Storage Devices
„
Supports eSATA that can communicate with
multiple drives via port multiplier
„
Lockable cable-latched notches of SATA
connector secure connection in vibration
condition
„
„
„
Embedded Intel® Active Management
Technology (iAMT) remotely locates, repairs
and protects networked computing assets
using third-party management and security
applications
System noise and heat are reduced through
more intelligent fan speed control algorithms by
integrated Intel® Quiet System Technology
Flexible design of four external PCI Express
x1 could aggregate as one PCI Express x4 for
storage device through backplane
AB1-3072
ROBO-8913VG2AR
PICMG 1.3(PCI-E+PCI).Socket T.Core 2 Duo.
SBC.w/VGA/Dual GbE/Audio
PACKING LIST
Standard
Optional
- Intel®4*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+'2:
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\IRU'LUHFWHG,297G
AMI Core 8 BIOS
Supports up to 4GB DDR2 800/667 SDRAM on dual 240-pin DIMM sockets
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 4x PCI Express x1 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
GPIO
Others
:LQERQG:+*$:
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2.1 channels
- Intel® 82566DM+82573L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 12x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header, IrDA 1.0
DISPLAY
Graphic Controller
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6901990 SATA II cable
B8981980 PICMG SBC Handling and Installation Notice
B3751110 Installation CD
B6902230 USB port cable with bracket
B6901442 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
- Intel® Core™ 2 Quad/Core™ 2 Duo/Celeron® Processor up to 3G
:a:ZLWK.a0%/&DFKHLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
:DWFKGRJ7LPHU
Hardware Monitoring
Keyboard & Mouse
ORDERING GUIDE
Four SATA II ports
Display Interface
- GMCH integrated Intel Graphic Media Accelerator (GMA) 3100
- Provides improved 3D multimedia capabilities including Microsoft DirectX 9,
Shader Model 2.0, MPEG-2 hardware acceleration
- Intel Dynamic Video Memory Technology (DVMT) 4.0 shares system memory
up to 256MB
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
BIOS
SBC-ROBO-8913VG2AR
26
ROBO-8912VG2AR
12V po er connector
Intel® Core™ 2 Duo processor based on
PICMG 1.3 SHB with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
One RS2 2/422/485 selectable port
Dual 240-pin DDR2 DIMM sockets
Four SATA II ports
One RS2 2 port
Parallel port
FDD port
PS/2 ke board
DDR 2
Watch DOG
ouse
Dual USB ports
Giga
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
USB 3.0
VGA
Dual GbE ports
VGA port
Intel® ICH8DO
Intel® Q965
Four USB ports
57.40
1.60
4.75
0
GA775 socket
ROBO-8912VG2AR is based on the Intel®
Q965, ICH8DO chipset. It supports DDR2
PHPRU\DQGWZR*LJDELW(WKHUQHW:LWK3&,
Express, Image Processing, Industrial Automation, and Digital Signage applications are able to
run at faster rates.
GENERAL
- Intel® Core™ 2 Duo/Pentium D/Pentium 4/Celeron® Processor up to 2.93G
:a:ZLWK.a0%/&DFKHLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
Processor
- Intel®4*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+'2:
AMI Core 8 BIOS
Supports up to 4GB DDR2 800/667/533 SDRAM on dual 240-pin DIMM sockets
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
Chipset
FEATURES
„
Supports 45nm Intel® CoreTM 2 Duo processor
WKDWJHQHUDWHVDPD[LPXP:7'3/RZHU
TDP than socket 775 Pentium® 4 processor
makes the vertical mount slot board more
reliable
„
More features, such as EM64T, EIST, XD & VT,
can be easily applied to system by changing
processors
„
Integrated Intel® GMA 3000 graphics engine
built with high grade display capability
„
Flexible design of four external PCI Express
x1 can aggregate as one PCI Express x4 for
storage device through backplane
ORDERING GUIDE
AB1-3042
ROBO-8912VG2AR
PICMG 1.3(PCI-E+PCI).Socket T.P4.SBC.w/VGA/
Dual GbE/Audio
PACKING LIST
Standard
Optional
B6900270 dual head COM port cable with
bracket
B6900643 PRN cable
B6901990 SATA II cable
B6900600 FDD cable
B8981980 PICMG SBC Handling and Installation Notice
B3751110 Installation CD
B6901442 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
B6902230 USB port cable with bracket
B6901870 PS/2 Keyboard/Mouse Cable and one
USB with bracket
BIOS
Memory
Storage Devices
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 4x PCI Express x1 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
:LQERQG:(+*$&
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2.1 channels
- Intel® 82566DM+82573L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 10x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
- GMCH integrated Intel Graphic Media Accelerator (GMA) 3000
- Provides improved 3D multimedia capabilities including Microsoft DirectX 9, Shader
Model 3.0,OpenGL 1.5, Advanced De-interlacing, MPEG-2 hardware acceleration
- Intel Dynamic Video Memory Technology (DVMT) 4.0 shares system
memory up to 256MB
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
Display Interface
Mechanical & Environment
Dimension
/[:PP/[:
- PCB: 6 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
Power Supply
Environment
MTBF
DDR 3
27
SBC-ROBO-8212VG2AR
SATA 3.0
USB 2.0
Giga LAN
Watch DOG
H/W Monitor
GPIO
ROBO-8210VG2AR
Dual 240-pin DDR DIMM sockets
12V po er connector
TPM port
Intel® CoreTM i7/i5 processor based on
PICMG 1.3 SHB with DDR3 SDRAM, DVI-I,
Dual Gigabit Ethernet, Audio and USB
One RS2 2/422/485 selectable port
FDD port
One RS2 2 port
Parallel port
PS/2 ke board
Si USB ports
BIOS
ouse
USB 3.0
Dual USB ports
DDR 3
DVI-I
MiniPCIe
H/W Monitor
SATA
3Gb
GPIO
Dual GbE ports
5.60
5
0
1.60
DVI-I port
(DVI-D VGA)
rPGA 989 CPU socket
ROBO-8210VG2AR adopts the QM57 chipset
and Intel® CoreTM i7/i5 and Celeron® processors.
Bulit with high performance and lower power
consumption than desktop platform, it’s suitable
for Medical, Industrial Automation and Kiosk
applications.
FEATURES
Intel® QM57
Four SATA II ports Mini PCIe socket
GENERAL
Processor
Chipset
BIOS
Memory
- Intel®&RUHŒL0L033URFHVVRUVXSWR*:ZLWK
0%a0%&DFKHLQU3*$SDFNDJH
- DMI x4 Link: 2.5 GT/s
- Supports Intel®+\SHU7KUHDGLQJ9LUWXDOL]DWLRQ7HFKQRORJ\97[
Intel®%'403&+:
AMI UEFI BIOS
Supports up to 8GB DDR3 1066/800 SDRAM on dual 240-pin DIMM sockets
- 6x SATA II drivers (Dual SATA ports via Backplane)
- RAID 0,1,5,10
- 1x FDD channel on board box header
„
Supports Intel® i7-620M/i5-520M/P4500
processors in rPGA988 package
Storage Devices
„
Delivers up to 8GB maximum DDR3
1066/800 on two DIMM sockets
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
„
Supports dual display by DVI-I port on bracket
„
Supports iAMT 6.0 and external TPM via TPM
module
Expansion Interface
- 1x PCI Express x16 Gen 1 up to 2.5 GT/s
- 2x PCI Express x8 Gen 1 up to 2.5 GT/s
[3&,GHYLFHVDWELW0+]2SWLRQIRU3&,([SUHV*HQVXSSRUW
- 1x Mini-PCIe socket
„
High speed dual Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„
Rich I/O connections such as FDD, two
Gigabit Ethernet, serial ports, parallel port,
USB 2.0
„
Four on-board SATA ports support RAID
0,1,5,10
ORDERING GUIDE
AB1-3521
ROBO-8210VG2AR
PICMG 1.3(PCI-E+PCI).rPGA988A package. Intel
QM57 w/ PGA type Core i7/i5 processors.SHB.w/
VGA/Dual GbE/Audio
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
ITE IT8721F
- Intel®%'40EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Intel® 82577LM + 82583V gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 12x USB 2.0 ports (Four ports through backplane)
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
PACKING LIST
Standard
Optional
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6901990 SATA II cable
B8981980 PICMG SBC Handling and Installation Notice
B6902890 DVI-D + VGA cable with bracket
%&38FRROHUXSWR:
B3751340 Installation CD
B6901442 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
B6902230 USB port cable with bracket
DISPLAY
Graphic Controller
Display Interface
- GMCH integrated Intel Graphic Media Accelerator (GMA) HD
- Provides improved 3D multimedia capabilities including Microsoft DirectX 10,
Shader Model 4.0,OpenGL 2.1, MPEG-2 hardware acceleration
- Intel Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to 1Gb
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'5HVROXWLRQXSWR[#+]
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
SBC-ROBO-8210VG2AR
28
ROBO-8780VG2A
Dual 240-pin DDR DIMM sockets
One RS2 2 port
Intel® CoreTM i7/i5/i3 processor based on
PICMG 1.0 SBC with DDR3 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
One RS2 2/422/485 selectable port
Parallel port
FDD port
Dual USB .0 ports
DDR 3
Watch DOG
Dual USB 2.0 ports
Giga
Dual GbE ports
1.60
0
2 .09
60.91
VGA port
GA1155 socket
12V Po er Connector
ROBO-8780VG2A is based on Intel® H61
chipset and Intel® CoreTM i3/i5/i7 processors. It
supports VGA and on board DVI-D display. It’s
suitable for Medical, Industrial automation, and
digital signage applications.
FEATURES
Intel® H61
DVI-D connector
Eight USB 2.0 ports
Four SATA II ports
AMI EFI BIOS
- Supports up to 16GB DDR3 1333/1066 MT/s SDRAM on 2x 240-pin
non-ECC DIMM sockets (dual channel)
- 4x SATA support 3Gb/s data transfer rate on board
6XSSRUWVELW,6$YLDJROGHQ¿QJHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
System monitor (fan, temperature, voltage)
„
Supports dual display by VGA and on board
DVI-D
Expansion Interface
[3&,GHYLFHVDWELW0+]
„
Supports two USB 3.0 ports on board
„
High speed Intel® Dual Gigabit Ethernet
82579LM and 82583V based on PCI Express
x1, high bandwidth I/O interface
ORDERING GUIDE
AB1-3798
ROBO-8780VG2A
PICMG 1.0(PCI+ISA).LGA1155.SBC.up to CoreTM
i7 processors. w/VGA/Dual GbE/Audio/USB 3.0
VGA
- Intel®%'+3&+:
:DWFKGRJ7LPHU
Hardware Monitoring
On-board four SATA II ports and ten USB 2.0
ports (dual ports on bracket)
USB 3.0
set
BIOS
Memory
Delivers up to 16GB maximum DDR3 1333/1066
non-ECC SDRAM on two DIMM sockets
„
GPIO
- Intel® CoreTMLLLSURFHVVRUXSWR*+]a:ZLWKa0%&DFKH
in LGA1155 package
- DMI x4 Link: 5.0 GT/s
„
Rich I/O connections such as FDD, two Gigabit
Ethernet, serial ports, parallel port
SATA
3Gb
GENERAL
Storage Devices
„
H/W Monitor
Processor
Supports Intel® Core™ i7/i5/i3 processors in
LGA1155 package
„
Giga LAN
I/O INTERFACE
Super I/O
Audio
ITE IT8728F
- Intel®%'+3&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec
- Intel® 82579LM and Intel® 82583V dual gigabit ethernet controllers
- Dual RJ-45 connectors with two LED indicators on bracket
- 1x RS232 on board box header
- 1x RS232/422/485 on board box header
- 1x internal FDD connector
Ethernet
Serial Port
USB
- 2x USB 3.0 ports on board (5Gbps)
- 10x USB 2.0 ports on borad (480 Mb/s)
- Capable of high-speed/full-speed/low-speed data ranges
Two USB 2.0 on bracket dedicated to keyboard & mouse
Keyboard & Mouse
GPIO
Others
One 10-pin header for 8 programmable input/output
- 1x parallel port on board box header
PACKING LIST
Standard
Optional
B6901990 SATA II cable
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B8981980 PICMG SBC Handling and Installation Notice
B3751540 Installation CD
B6902980 PS/2 Keyboard/Mouse Cable with bracket
B6903090 USB 3.0 port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
DISPLAY
Graphic Controller
- Intel® CoreTM i processors integrated Graphics Engine
3URYLGLQJGHOLYHUVRSWLPL]HG'JUDSKLFVSHUIRUPDQFHDQGVXSSRUWIRU
Microsoft DirectX 10.1, Shader Model 4.0, MPEG-2 and OpenGL 3.0
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
'9,'RQERDUG5HVROXWLRQXSWR[#+]
Display Interface
Mechanical & Environment
Dimension
/[:PP´/[´:
- PCB: 8 layers
9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&ZLWKEHWWHUSHUIRUPDQFHRQƒ&
6WRUDJH7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
Power Supply
Environment
MTBF
DDR 3
29
SBC-ROBO-8780VG2A
SATA 3.0
USB 2.0
Giga LAN
Watch DOG
H/W Monitor
GPIO
ROBO-8779VG2AR
+12V power connector
One RS232/422/485 selectable port
Dual 240-pin DDR3 DIMM sockets
One RS232 port
Intel® CoreTM 2 Quad processor based on
PICMG 1.0 SBC with DDR3 SDRAM, VGA,
DVI, Dual Gigabit Ethernet, Audio and USB
CF socket
Parallel port
FDD port
PS/2 K/B & Mouse
Six USB ports
Dual USB ports
DDR 3
Watch DOG
Giga
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
USB 3.0
VGA
Dual GbE ports
57.60
0
1.60
6.66
VGA port
LGA775 socket
Intel® G41
Intel® ICH7R
DVI-D connector SDVO connector
Four SATA II ports
ROBO-8779VG2AR is based on the Intel® G41,
ICH7R chipset and supports CoreTM 2 Quad
sku processors. It supports DDR3 memory up
to 4GB. It’s the entry level product and suitable
for Digital Signage, Kiosk, and Multimedia applications.
FEATURES
„ Supports Intel® CoreTM 2 Duo and CoreTM
4XDGSURFHVVRUVDQGRIIHUVÀH[LEOH
0K])6%VHOHFWLRQ
„ Deliver up to 4GB maximum DDR3 1066/800
on two DIMM sockets
„ Supports Intel® G41 integrated GMA X4500
JUDSKLFHQJLQHGHOLYHUVRSWLPL]HG'JUDSKLFV
performance
„ Supports dual display VGA and DVI-D
interface,and SDVO connector for other types
GLVSOD\E\SURMHFW
„ Supports one CF socket up to UDMA5 mode
„ Equipped with I/O connections such as FDD,
two Gigabit Ethernet, serial ports, parallel port,
USB 2.0, and SATA ports
ORDERING GUIDE
AB1-3349
AB1-3428
(R).ROBO-8779VG2AR
PICMG 1.0(PCI+ISA).LGA775.Core 2 Quad.
SBC.w/VGA/Dual GbE/Audio
(R).ROBO-8779VG2A
PICMG 1.0(PCI+ISA).LGA775.Core 2 Quad.
SBC.w/VGA/Dual GbE/Audio. w/o RAID
PACKING LIST
Standard
Optional
B690021S cable kit for FDD+PRN with bracket
B6900270 dual head COM port cable with bracket
B6901990 SATA II cable
B690003S Cable Assy 4F-4F
B8981980 PICMG SBC Handling and Installation Notice
B3751250 Installation CD
B6901442 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
AB9-3076 PA-G1D SDVO to DVI-D Output
Accessory Board
B6902230 USB port cable with bracket
B6902300 Audio cable with line in/out/Mic in
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
:DWFKGRJ7LPHU
Hardware Monitoring
Expansion Interface
- Intel® Core™ 2 Quad/Core™ 2 Duo/Celeron®3URFHVVRUXSWR*:a:
ZLWK.a0%/&DFKHLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Support Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
- Intel®**UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+5:
AMI Core 8 BIOS
Supports up to 4GB DDR3 1066/800 SDRAM on dual 240-pin DIMM sockets
- 6x SATA II drivers (RAID 0,1,5,10)
:LWK5$,'RQ52%29*$5ZR5$,'RQ52%29*$
- 1x Type II CompactFlash® socket supports Ultra DMA133/100/66/33 MB/s
- 1x FDD channel
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Keyboard & Mouse
:LQERQG:7+*
- Intel®*EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Intel® 82574L gigabit ethernet controller x2
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 8x USB 2.0 ports
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
GPIO
Others
1x parallel port on board box header
Ethernet
Serial Port
USB
On board programmable 8-bit Digital I/Os
DISPLAY
Graphic Controller
Display Interface
- GMCH integrated Intel Graphic Media Accelerator (GMA) x4500
- Provides improved 3D multimedia capabilities including Microsoft DirectX 10,
Shader Model 4.0, OpenGL 2.0
- Intel Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to 1GB
- VGA on bracket: Resolution up to 2048x1536
- DVI-D: up to 2048x1536
- SVDO: Optional DVI-D output card via SDVO
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
SBC-ROBO-8779VG2AR
30
ROBO-8777VG2A
Intel® CoreTM 2 Duo processor based on
PICMG SBC with DDR2 SDRAM, VGA,
Dual Gigabit Ethernet, Audio and USB
One RS2 2/422/485 selectable port
Dual 240-pin DDR2 DIMM sockets
Four SATA II ports
One RS2 2 port
Parallel port
FDD port
PS/2 ke board
BIOS
USB 3.0
ouse
Dual USB ports
DDR 2
Watch DOG
Dual GbE ports
Giga
GA775 socket
12V po er connector
57.40
1.60
0
4.75
VGA port
ROBO-8777VG2A adopts the Intel® Q965, ICH8
chipset and Intel® Core™ 2 Duo technologies. It
supports DDR2 memory and two Gigabit Ethernet. It’s suitable for Digital Signage, Kiosk, and
Multimedia applications.
FEATURES
Intel® Q965
Intel® ICH8
Four USB ports
ISA Bus
Processor
Chipset
/RZSUR¿OHSURFHVVRUFRROHULPSURYHVVWDELOLW\
and reliability of whole system
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
„
More features, such as EM64T, EIST, XD & VT,
can be easily applied to system by changing
processor
Expansion Interface
[3&,GHYLFHVDWELW0+]
„
Integrated Intel® GMA 3000 graphics engine
built with high grade display capability
„
Lockable cable-latched notches of SATA
connector secure connection in vibration
condition
„
Supports ISA expansion
AB1-3057
ROBO-8777VG2A
PICMG 1.0(PCI/ISA).Socket T.P4.SBC.w/VGA/
Dual GbE/Audio
GPIO
- Intel®4*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+:
Award BIOS
Supports up to 4GB DDR2 800/667/533 SDRAM on dual 240-pin DIMM sockets
- 4x SATA II drivers
- 1x FDD channel on board box header
„
ORDERING GUIDE
SATA
3Gb
- Intel® Core™ 2 Duo/Pentium D/Pentium 4/Celeron® Processor up to 2.93G
:a:ZLWK.a0%/&DFKHLQ/*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
BIOS
Memory
TM
H/W Monitor
GENERAL
Supports Intel Core 2 Duo processor that
JHQHUDWHVDPD[LPXP:7'3/RZHU7'3
than socket 478 Pentium® 4 processor makes
the vertical mount slot board more reliable
„
®
Giga LAN
Storage Devices
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:'+*
4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2 channels
- Intel® Realtek 8111B gigabit ethernet controller x2
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 6x USB 2.0 ports
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
PACKING LIST
Standard
Optional
B6900074 FDD Cable
B6901990 SATA II cable
B690003S Cable Assy 4F-4F
B8981980 PICMG SBC Handling and Installation Notice
B3751110 Installation CD
B7869400 One COM Port Cabel
B6900643 PRN cable
B6902000 dual serial port cable with bracket
B6901090 USB cable
B6902300 Audio cable with line in/out/Mic in
B6902010 PS/2 Keyboard/Mouse Cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
DISPLAY
Graphic Controller
Display Interface
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
31
SBC-ROBO-8777VG2A
- GMCH integrated Intel Graphic Media Accelerator (GMA) 3000
- Provided improved 3D multimedia capabilities including Microsoft DirectX 9, Shader
Model 3.0,OpenGL 1.5, Advanced De-interlacing, MPEG-2 hardware acceleration
- Intel Dynamic Video Memory Technology (DVMT) 4.0 shares system memory
up to 256MB
9*$RQEUDFNHW5HVROXWLRQXSWR[#+]
/[:PP/[:
- PCB: 6 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
ROBO-8719VG2AR
Intel® latest 45nm CoreTM 2 Duo or Celeron®
M processor based on PICMG SBC with
DDR2 SDRAM, VGA, Dual Gigabit Ethernet
and Audio
One RS2 2 port
Dual 240-pin DDR2 DIMM sockets
Additional po er source
FDD
One RS2 2/422/485
selectable port
CF socket
Parallel port
PS/2 /B Mouse
DDR 2
Watch DOG
Four USB ports
Giga
Dual USB ports
Giga LAN
LVDS
SATA
3Gb
GPIO
USB 3.0
VGA
Dual GbE ports
VGA port
.82
2.80
0
1.60
12V po er connector
Intel® GM45
VDS connector
ROBO-8719VG2AR is based on GM45 and
ICH9ME chipset, supporting mobile processors
up to CoreTM 2 Quad sku. It’s the ideal solution
for Medical, Industrial Automation and Kiosk
applications.
FEATURES
„
„
„
„
52%29*$5RIIHUVÀH[LEOH)6%XS
WR0+]VHOHFWLRQRI,QWHO® 45nm Mobile
CoreTM 2 Quad, CoreTM 2 Duo or Celeron® M
processor that features high computing power
with low heat
Integrated 5th generation graphic engine Mobile
Intel® GMA 4500MHD built with max. graphics
FRUHVSHHGVXSWR0+]WRLPSURYHJUDSKLFV
and 3D rendering performance
Supports two on-board display output options,
LQFOXGLQJ9*$DQGELW/9'6IRUÀH[LEOH
display choice. An optional DVI-D output card
supports via board to board SDVO connector
E\SURMHFW
Supports integrated Intel® Trusted Platform
Module (iTPM) for more secure platforms
ORDERING GUIDE
AB1-3252
ROBO-8719VG2AR
PICMG 1.0(PCI+ISA).Socket mPGA479M.SBC.w/
VGA/Dual GbE/Audio
Intel® ICH9ME
Three SATA II ports
SDVO connector
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
- Intel® Mobile Core™ 2 Quad/Core™ 2 Duo/Celeron® M Processor up to 2.53G
:ZLWK0%a0%/&DFKHLQP)&3*$SDFNDJH
)6%0+]
- DMI x4 Link: 2.5 GT/s
- Supports Intel®9LUWXDOL]DWLRQ7HFKQRORJ\97[
- Intel®*0*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:
,&+0(:
Award BIOS
Support up to 4GB DDR2 800/667 SDRAM on dual 240-pin DIMM sockets
- 3x SATA II drivers (RAID 0,1)
- 1x Type II CompactFlash socket supports Ultra DMA133/100/66/33 MB/s
- 1x FDD channel
:DWFKGRJ7LPHU
Hardware Monitoring
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
Expansion Interface
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:'+*
- Intel®*0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2 channels
- Intel® 82567LM+82574L gigabit ethernet controller
- Dual RJ-45 connector with two LED indicators on bracket
- 1x RS232 on board box header
- 1x Selectable RS232/422/485 on board box header
- 6x USB 2.0 ports
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
2x USB 2.0 ports on bracket dedicated to keyboard & mouse
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
PACKING LIST
Standard
Optional
B6900600 FDD Cable
B6900064 PRN cable
B6901990 SATA II cable
B690027S serial port cable
B690003S Cable Assy 4F-4F
B3751110 Installation CD
%&38FRROHUXSWR:
B6902230 USB port cable with bracket
B6902300 Audio cable with line in/out/Mic in
AB9-2066 PA-M1AU Multiple Media kit
AB9-3076 PA-G1D SDVO to DVI-D Output
Accessory Board
B6901442 PS2 Keyboard and Mouse cable with bracket
DISPLAY
Graphic Controller
Display Interface
- GMCH integrated Intel Graphic Media Accelerator (GMA) 4500MHD
- Provided improved 3D multimedia capabilities including Microsoft DirectX 10,
OpenGL 2.0, MPEG-2 hardware acceleration
- Intel Dynamic Video Memory Technology (DVMT) 5.0 shares system memory
up to 256MB
- VGA on bracket: Resolution up to 2048x1536
- LVDS: Dual channel 24-bit LVDS
- SDVO: Optional DVI-D output card via SDVO
(Two display streams supported in above combination)
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
DDR 3
SBC-ROBO-8719VG2AR
32
ROBO-6712VGA
Six USB ports
Intel® ICH8M
Intel® AtomTM D525 processor based on
PICMG 1.0 half size SBC with DDR3 SODIMM,
VGA, single Gigabit Ethernet, Audio and USB
204-pin DDR3 SODIMM socket
LVDS connector
CF socket
44-pin IDE connector
FDD
Parallel port
BIOS
USB 3.0
VGA port
DDR 3
VGA
PS/2 K/B & Mouse
Giga
Single GbE port
Giga LAN
H/W Monitor
SATA
3Gb
GPIO
One RS232 port
Three SATA II ports
FEATURES
„ Supports Intel® AtomTM D525 processor and
ICH8M chipset
„ One 204-pin SODIMM support DDR3 800
SDRAM up to 2GB
„ Supports Dual independent display: VGA/18bit LVDS
„ High speed single Gigabit Ethernet based on
PCI Express x1, high bandwidth I/O interface
„ Equipped with I/O connections such as FDD,
two serial ports, parallel port, USB 2.0, three
SATA II and one CF socket
ORDERING GUIDE
AB1-3684Z
ROBO-6712VGA
+DOIVL]HG3&,6%&,QWHO$720'SURFHVVRU
DDR3.w/LVDS/VGA/GbE/Audio
PACKING LIST
Standard
Optional
B6900600 FDD Cable
B6900224 IDE cable
B6901990 SATA II cable
B6900960 cable kit for 1 serial + 1 parallel port
w/ bracket
B690003S Cable Assy 4F-4F
B3751460 Installation CD
B8304630 CPU cooler
B6902230 USB port cable with bracket
AB9-2066 PA-M1AU Multiple Media kit
GENERAL
Processor
Chipset
BIOS
Memory
Storage Devices
:DWFKGRJ7LPHU
Hardware Monitoring
Expansion Interface
1.60
0
7.90
ROBO-6712VGA has a built in Intel® AtomTM
D525 and ICH8M chipset which enhances
performance and supports a better graphics
engine, making it most suitable for Industrial
Automation, Lottery, and Digital Signage applications.
Intel Atom D525 processor
TM
28.80
One RS232/422/485
selectable port
®
- Intel® AtomTM'XSWR*+]:ZLWK0%/&DFKHLQ)&%*$SDFNDJH
- DMI x4 Link: 2.5 GT/s
- Supports Intel® Hyper-Threading Technology
Intel®,&+0:
Phoenix UEFI BIOS
Supports up to 2GB DDR3 800 SDRAM on one 204-pin SODIMM sockets
- 3x SATA II drivers
- 1x 44-pin IDE device
- 1x Type II CompactFlash® socket supports Ultra DMA133/100/66/33 MB/s
- 1x FDD channel on board box header
3URJUDPPDEOHYLD6:IURPVHFWRVHF
System monitor (Voltage, Fan speed and Temperature)
[3&,GHYLFHVDWELW0+]
I/O INTERFACE
Super I/O
Audio
Ethernet
Serial Port
USB
Keyboard & Mouse
GPIO
Others
:LQERQG:8+*
- Intel®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-VC2 LQFP48 codec, 5.1 channels
- Intel® 82567V gigabit ethernet controller
- One RJ-45 connector with two LED indicators on bracket
- 1x RS232 on bracket
- 1x RS232/422/485 selectable on board box header
- 6x USB 2.0 ports
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
One 6-pin mini-DIN connector for keyboard & mouse on bracket
On board programmable 8-bit Digital I/Os
1x parallel port on board box header
DISPLAY
Graphic Controller
Display Interface
- Intel® ICH8M Integrated GMA 3150 Graphics supports full hardware
acceleration of video decode standards MPEG-2
- Intel® Dynamic Video Memory Technology (Intel® DVMT 4.0)
- VGA on bracket: Resolution up to 2048x1536 (QXGA)
- LVDS: One channel 18-bit LVDS
Mechanical & Environment
Dimension
Power Supply
Environment
MTBF
33
SBC-ROBO-6712VGA
/[:PP/[:
- PCB: 8 layers
7\SLFDO9#$9#$
- Supports AT, ATX mode
2SHUDWLRQ7HPSHUDWXUHaƒ&
6WRUDJH7HPSHUDWXUHaƒ&
5HODWLYH+XPLGLW\aQRQFRQGHQVLQJ
2YHUKRXUVDWƒ&
PICMG 1.0 Backplane
PICMG GENERAL DESCRIPTION
PICMG Backplanes in this section are Single Board Computers (SBCs) and Single Host Board (SHB) companions that
feature expansion slots such as ISA, PCI, PCI-X or PCI Express interface. In addition, the backplane also features several
power connectors that draw power from power supply to devices on it. Some LEDs are designed on board to indicate status
of each power rail.
PICMG 1.0 supports both ISA & PCI, PICMG 1.2 supports dual PCI or PCI-X, and PICMG 1.3 supports PCI Express and
PCI expansion. Some bridges or switches can be applied to the backplane to support more devices or different kinds of
expansion interfaces. However, PICMG 1.0, 1.2, and 1.3 are not compatible with each other.
PICMG 1.0 BACKPLANE
Passive Backplane: Backplane that only support up to four PCI master
32-bit PCI/16-bit ISA
18-slot Dual-system PICMG Backplane
155.35
155.35
19-slot (4x PCI) PICMG Backplane
71.25
79.5
71.25
79.5
- Fit for 20-slot chassis
- Designed for fault-tolerant computing
- ATX power connector support
265.2
265.2
- Fit for 20-slot chassis
- ATX power connector support
- Sufficient ISA slots for CTI application
PBP-18D4
10.16
10.16
PBP-19P4
18.6
52.11
140.49
99.61
40.6
101.6
27.14
72.47
140.49
159.44
18.6
69.94
317
PBP-13D4
10.16
155.35
34.9
212.96
13-slot Dual-system PICMG Backplane
257
71.25
71.25
53.6
- Fit for 14-slot chassis
- Special design for full-length PCI cards
- ATX power connector support
79.5
257
155.35
13-slot (4x PCI) PICMG Backplane
18.6
69.14
212.96
69.94
- Fit for 14-slot chassis
- Design for fault-tolerant computing
- ATX power connector support
79.5
10.16
PBP-13R4
69.94
317
317
PBP-08P3
18.6
96.61
18.6
96.61
PBP-08P4
8-slot (4x PCI) PICMG Backplane
71.25
10.16
79.5
8-slot (3x PCI) PICMG Backplane
- Fit for node chassis and
desktop case
212.96
217.96
212.96
217.96
- Fit for node chassis and
desktop case
- ATX power connector support
71.25
155.35
10.16
79.5
257
155.35
257
PBP-06P3
PBP-06P4
6-slot (3x PCI) PICMG Backplane
- Fit for node chassis
- ATX power connector support
15
55.5
- Fit for node chassis
- ATX power connector support
96
121.2
140.7
55.50
96.00
121.20
140.20
6-slot (4x PCI) PICMG Backplane
4.39
15.0
10.10
25.33
- Fit for 14-slot chassis
- 2.4 mm PCB thickness
- ATX power connector support
69.14
212.96
69.94
317
88.38
14-slot (4x PCI) Active PICMG Backplane
257
- Fit for 14-slot chassis
- ATX power connector support
- The most popular and reliable
PICMG backplane
67.16
71.25
79.5
257
155.35
14-slot (4x PCI) PICMG Backplane
69.14
212.96
ACTI-14P4
10.16
10.16
PBP-14P4
18.6
40.6
101.6
415.4
415.4
75.41
18.6
165.1
253.1
165.60
254.10
263.10
263.1
PICMG Backplane
34
PICMG 1.0 Backplane
PBP-02V1X
33.7
PBP-06V4
84
Vertical 6-slot (4x PCI) PICMG Backplane
331.9
Left View
Right View
Left View
Right View
33.7
- Fit for 2U chassis
- ATX and AT power connector support
327.9
Vertical 2-slot (1x PCI) PICMG Backplane
- Fit for 1U chassis
- ATX power connector support
327.9
84
331.9
39.5
PBP-03P2X
Vertical 3-slot (2x PCI) PICMG Backplane
337.11
Left View
Right View
39.5
- Fit for Portwell’s 1U chassis
- ATX power connector support
337.11
64-bit PCI/16-bit ISA
PBP-06P464
PBP-06V464
83.95
15
10.1
Vertical 6-slot (4x 64-bit PCI)
PICMG Backplane
- Fit for node chassis
- ATX and AT power connector support
55.5
96.1
121.21
140.21
6-slot (4x 64-bit PCI) PICMG Backplane
166.3
331.98
Left View
Right View
170.75
83.95
295.84
310.19
- Fit for 2U chassis
- ATX power connector
331.98
Active Backplane: Backplane that utilizes a bridge to support PCI master beyond four
PBP-19AC
265.2
265.2
19-slot (12x PCI) Active PICMG
Backplane
155.35
155.35
19-slot (18x PCI) Active PICMG
Backplane
10.16
10.16
PBP-19AI
71.25
79.5
89.69
71.25
79.5
89.69
18.6
18.6
27.17
52.11
88.38
88.38
40.6
101.57
72.47
27.17
52.11
72.47
101.57
40.6
415.4
ACTI-14AA
6.87
PBP-14AC-B
33.06
155.35
8
257.18
68.95
212.79
68.15
257
10.16
155.35
18.6
69.94
96.61
317
45.37
70.98
317
71.25
10.16
155.35
257
PICMG Backplane
8-slot (7x PCI) Active PICMG
Backplane
217.96
212.96
18.6
96.61
PBP-08A7
14-slot (12x PCI) Active PICMG
Backplane
257
71.25
10.16
155.35
14-slot (7x PCI) Active PICMG
Backplane
79.5
71.25
PBP-14AC
PBP-14A7
69.14
212.96
35
- Fit for 14-slot chassis
- 2.4 mm PCB thickness
- ATX power connector support
316.87
18.6
79.5
74.98
66.87
18.66
15.99
61
108
317
34.9 35.04
79.5
141.01
72.56
89.86
12.06
16.51
14-slot (10x PCI) Active PICMG Backplane
162.68
14-slot (12x PCI) Active PICMG
Backplane
260
10.16
415.4
PICMG 1.3 Backplane
PICMG 1.3 Selection Guide
Model
PBPE-19AG64
PCIEx16
PCIEx8
1 (x8 signal)
1 (x4 signal)
PBPE-14AD64
Server
Grade
1
PBPE-06V464
PBPE-08P41
2 (x8 signal)
PBPE-06A364
2 (x8 signal)
PBPE-06P2
2 (x8 signal)
PBPE-13A8
1
PBPE-12A9
1
PBPE-12AA64
1
PBPE-06V3
1
Non-Server
PBPE-06V
Grade
PCIEx4
PCIEx1
1
PBPE-05A364
1
1
8
ROBO8914VG2AR
ROBO8913VG2AR
ROBO8912VG2AR
1
4
3
1 (x4 signal)
4
2
1
1 (x4 signal)
2
3
8
1 (x4 signal)
9
8
2
1 (x4 signal)
3
4
1
4
2
PBPE-06P4
1
1 (x4 signal)
PBPE-06P3
ROBO8921VG2R
PCI
16
1
PBPE-07P4
PCI-X
1
4
1
3
PICMG 1.3 BACKPLANE
Server Grade Backplane
10.16
327
24.13
21.59
203.2
273
65.41
17.78
139.7
239.96
302.26
- Fit for 4U up chassis
- Four PCI-X buses support 16 PCI-X
expansion slots
232.49
14-slot [PCIe x4 (1), PCIe x8 (1), PCI-X (8),
PCI (3)]
196.93
PBPE-14AD64
19-slot [PCIe x16 (1, x8 signal),
PCIe x8 (1, x4 signal), PCI-X (16)]
160.10
154.94
PBPE-19AG64
- Fit for 4U chassis
- Four PCI-X buses support eight PCI-X
expansion slots
63.5
416.56
78.74
176.61
195.58
224.72
259.62
317
10.16
PBPE-06V464
8-slot [PCIe x8 (1, x4 signal), PCIe x16
(2, x8 signal), PCI (4)]
Vertical 6-slot [PCIe x4 (1), PCI-X (4)]
84
160.10
PBPE-08P41
331.94
327
- Fit for Node chassis
- Four USB ports
Left View
Right View
- Fit for 2U chassis
- Dual PCI-X buses support four PCI-X slots
79.5
84
76.99
331.94
18.6
78.01
45.37
70.98
217
88.5
88.5
- Fit for Node chassis
- Four USB ports
327
327
61.36
61.36
10.13
40.5 25.2
55.5
140.20
6-slot [PCIe x8 (1, x4 signal), PCIe x16
(2, x8 signal), PCI (2)]
155
155
6-slot [PCIe x16 (2, x8 signal), PCI-X (2),
PCI (1)]
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support two PCI-X
expansion slot
PBPE-06P2
10.10
10.10
PBPE-06A364
10.13
40.5 25.2
55.5
140.20
PICMG Backplane
36
PICMG 1.3 Backplane
Non-Server Grade Backplane
239.96
273
327
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
- 24-pin ESP12V power connector
196.93
12-slot [PCIe x16 (1), PCIe x8 (1, x4
signal), PCI (9)]
160.10
PBPE-12A9
13-slot [PCIe x1 (3), PCIe x16
(1), PCI (8)]
317
234.80
327
311.84
267.84
191.77
154.94
PBPE-13A8
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
78.74
78.74
176.61
176.61
195.58
224.72
259.62
317
195.58
224.72
259.62
317
7-slot [PCIe x4 (1), PCIe x16 (1), PCI (4)]
155.35
- Fit for 4U chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support eight
PCI-X expansion slot
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
327
327
317
273
239.96
196.93
160.10
12-slot [PCI-X (8), PCIe x16 (1),
PCI (2)]
79.5
156.49
78.74
PBPE-07P4
10.16
PBPE-12AA64
78.01
49.38
45.37
176.61
195.58
224.72
259.62
317
PBPE-06V3
Vertical 6-slot [PCIe x1 (4),
PCIe x16 (1)]
Vertical 6-slot [PCIe x8 (1, x4 signal),
PCIe x16 (1), PCI (3)]
84
84
PBPE-06V
331.94
Left View
Right View
331.94
Left View
Right View
84
84
- Fit for 2U chassis
- Four USB ports
- Dual SATA ports
- 24-pin ESP 12V power connector
149.86
88.5
88.5
149.86
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
327
327
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
10.13
40.5 40.5 25.2
140.2
140.2
10.10
234.80
191.77
327
327
13-slot [PCIe x16(1), PCIe
x16(2, x1 signal), PCIe x4(5, x1
signal), PCI(4)]
311.84
5-slot [PCIe x16 (1), PCI-X (2),
PCI (1)]
267.84
PBPE-13A4
154 94
154.94
155
PBPE-05A364
- Fit for Node chassis
- Four USB ports
- Dual SATA ports
- Two PCI-X buses support two
PCI-X expansion slot
149.86
88.5
- Fit for 4U chassis
- Four USB 2.0 ports
- Dual SATA II ports
78 74
78.74
140.2
6-slot [PCIe x8 (1, x4 signal),
PCI (4)]
155
155
6-slot [PCIe x16 (1), PCIe x4
(1), PCI (3)]
10.13
40.5 40.5 25.2
PBPE-06P4
10.10
10.10
PBPE-06P3
10.13
40.5 40.5 25.2
PICMG Backplane
- Fit for 2U chassis
- Four USB ports
- Dual SATA ports
331.94
331.94
37
70.98
194.36
217.96
176.61
195.58
224.72
259.62
317
PCI & ISA Backplane
PCI GENERAL DESCRIPTION
„
Compact size backplane for half size PCI SBC
„
PICMG 1.0 Rev 2.1 Compliant (PCI golden finger only)
„
Support AT or ATX type power connector
„
4-layer PCB with power and ground planes to reduce
power noise and maintain a lower impedance
„
Frame rated PCB at 94-V0
„
User friendly design supports external K/B
connector, power for chassis fan and power indicator
PBP-05P
PBP-04P
5-slot Passive PCI Backplane
4-slot Passive PCI Backplane
36.11
10.6
22.43
59.31
104.08
66.2
140.00
85.85
33.76
46.91
124.35
83.35
85.85
44.35
44.35
170
37.01
160.00
170.00
ISA GENERAL DESCRIPTION
„
4-layer PCB with ground and power planes
for reducing noise and keeping lower impedance
„
Frame Rated PCB at 94-V0
„
LED power indicator for +5V, +12V, -5V and 12V
„
Easy cut for dual or multi systems(*)
„
Plug-in sockets of termination resistors for high-
14.4
15.24
5
6
6.35
43.18
Equipped with gold-plated socket for good contact
170
165.1
182
169
83.83
90
„
4-slot Passive ISA Backplane
44
72
Heavy duty terminal block connector for
industrial power supply wiring(*)
PBP-04I
3-slot Passive ISA Backplane
11
„
PBP-03I
speed signal.(*)
“*”means for most part of products
PBP-06I
PBP-08I
PBP-14I
6-slot Passive ISA Backplane
8-slot Passive ISA Backplane
14-slot Passive ISA Backplane
318.9
175.3
165
152.4
77.266
69.78
10.16
25.4
15.4
46.114
70.98
57
10.16
180.5
97.3
122.5
135
53.6
155.35
174.6
16
55.5
69.78
70.98
220.6
Backplane-PCI & ISA
38
IMB Reference Table
39
MODEL
RUBYM710VG2AR
RUBYD714VG2AR
RUBYD715VG2AR
RUBYD712VG2AR
Form Factor
ATX
ATX
ATX
ATX
CPU
Intel® Core i5/i7
Intel® Core i5/i7
Intel® Core i3/Xeon® E3
series
Intel® Core i5/i7
Chipset
Intel® QM57 PCH
Intel® Q77 PCH
Intel® C216 PCH
Intel® Q67 PCH
BIOS
AMI UEFI
Phoenix UEFI
Phoenix BIOS
AMI UEFI
Memory
2x DDR3 DIMM up to 8GB
4x DDR3 DIMM up to
32GB
4x DDR3 DIMM up to
32GB
4x DDR3 DIMM up to
32GB
Expansion
4x
1x
1x
1x
1x
4x PCI slots
2x PCIe x16 slots
1x PCIe x4 slot
4x
4x PCI slots
1x
2x PCIe x16 slots, Gen3.0
1x
1x PCIe x4 slot
1x
Display
VGA/ DVI-D/ LVDS/ HDMI VGA/DVI-D/HDMI
VGA/DVI-D/HDMI support
VGA/DVI-D/HDMI
triple display
Audio
Realtek ALC888-GR HD
Audio codec
Realtek ALC886-GR HD
Audio codec
Realtek ALC886-GR HD
Audio codec
Realtek ALC662-GR HD
Audio codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
5x RS232
1x RS232/422/485
4x RS232
2x RS232/422/485
4x RS232
2x RS232/422/485
4x RS232
2x RS232/422/485
USB
8x USB 2.0
4x USB 3.0
6x USB 2.0
4x USB 3.0
6x USB 2.0
8x USB 2.0
Storage
Devices
6x SATA
5x SATA
1x CFEX
3x SATA II
2x SATA III
1x CFEX
6x SATA
GPIO
16-bit
8-bit
8-bit
16-bit
Others
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
Dimension
304.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
Page
42
43
44
45
IMB-Reference Table
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
Mini-PCIe socket
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
IMB Reference Table
MODEL
RUBYD711VG2AR
RUBY-9911
RUBY9719VG2AR
RUBY9718VG2AR
Form Factor
ATX
ATX
ATX
ATX
CPU
Intel® Core i3/Xeon® E3
series
Intel® CoreTM 2 Quad/
CoreTM 2 Duo
Intel® CoreTM 2 Quad/
CoreTM 2 Duo
Intel® CoreTM 2 Quad/
CoreTM 2 Duo/Pentium® D/
Pentium® 4/Celeron® D
Chipset
Intel® C206 PCH
Intel® Q45+ICH10DO
Intel® G41+ICH7R
Intel® Q965+ICH8DO
BIOS
AMI UEFI
AMI Core 8
AMI Core 8
Award
Memory
4x DDR3 ECC DIMM up
to 16GB
2x DDR3 DIMM up to 4GB 2x DDR2 DIMM up to 4GB 4x DDR2 DIMM up to 8GB
Expansion
4x
1x
1x
1x
4x PCI slots
1x PCIe x16 slot
1x PCIe x4 slot
6x PCI slots
1x PCIe x16 slot
4x PCI slots
2x PCIe x1 slots
1x ADD2 slot
Display
VGA/DVI-D/HDMI
VGA/ DVI-D
VGA
VGA/DVI-D
Audio
Realtek ALC662-GR HD
Audio codec
Realtek ALC888-GR HD
Audio codec
Realtek ALC662-GR HD
Audio codec
Realtek ALC262-VC2 HD
Audio codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
4x RS232
2x RS232/422/485
3x RS232
1x RS232/422/485
5x RS232
1x RS232/422/485
3x RS232
1x RS232/422/485
USB
8x USB 2.0
8x USB 2.0
8x USB 2.0
10x USB 2.0
Storage
Devices
6x SATA
4x SATA
1x IDE
1x FDD
4x SATA
1x IDE
1x FDD
6x SATA
1x FDD
GPIO
16-bit
8-bit
8-bit
12-bit
Others
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
Dimension
304.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
Page
46
47
48
49
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
IMB-Reference Table
40
IMB Reference Table
41
MODEL
RUBY9717VGAR
RUBY9716VG2AR
RUBY9716VGAR
Form Factor
μATX
ATX
ATX
CPU
Intel® CoreTM 2 Quad/
Intel® CoreTM 2 Quad/
Intel® CoreTM 2 Quad/
CoreTM 2 Duo/Pentium® D/ CoreTM 2 Duo/Pentium® D/ CoreTM 2 Duo/Pentium® D/
Pentium® 4/Celeron® D
Pentium® 4/Celeron® D
Pentium® 4/Celeron® D
Chipset
Intel® Q965+ICH8DO
Intel® Q965+ICH8DO
Intel® Q965+ICH8DO
BIOS
Award
Award
Award
Memory
4x DDR2 DIMM up to 8GB 4x DDR2 DIMM up to 8GB 4x DDR2 DIMM up to 8GB
Expansion
2x PCI slots
1x PCIe x4 slot
1x ADD2 slot
4x PCI slots
1x PCIe x16 slot
1x PCIe x4 slot
4x
1x
1x
1x
Display
VGA/DVI-D
VGA
VGA
Audio
Realtek ALC262-VC2 HD
Audio codec
Realtek ALC262-VC2 HD
Audio codec
Realtek ALC262-VC2 HD
Audio codec
LAN
1x GbE
2x GbE
1x GbE
Serial Port
3x RS232
1x RS232/422/485
3x RS232
1x RS232/422/485
3x RS232
1x RS232/422/485
USB
10x USB 2.0
8x USB 2.0
8x USB 2.0
Storage
Devices
6x SATA
1x FDD
5x
1x
1x
1x
5x
1x
1x
1x
GPIO
12-bit
10-bit
10-bit
Others
1x Parallel
PS/2 KB&MS
1x Parallel
IrDA 1.0
PS/2 KB&MS
1x Parallel
IrDA 1.0
PS/2 KB&MS
Dimension
243.8 x 243.8mm
304.8 x 243.8mm
304.8 x 243.8mm
Page
50
51
52
IMB-Reference Table
SATA
IDE
CF
FDD
PCI slots
PCIe x16 slot
PCIe x4 slot
PCIe x1 slot
SATA
IDE
CF
FDD
RUBY-M710VG2AR
One PCIe x1 slot
One PCIe x4 slot
One PCIe x16 slot
Four PCIe slots
Intel® CoreTM i5/i7/P4500 processor based
ATX with DDR3 SDRAM, Dual Display,
Dual Gigabit Ethernet and USB Ports
16 bits GPIO
CPU socket 989
Mini-PCIe Socket
Intel® QM57
Four USB ports
Two 240-pin
DDR3 DIMM sockets
LPC pin header
Six SATA II ports
ATX 24P power connector
Built with latest mobile Intel® QM57 Express
chipset which supports Intel® CoreTM i5/ i7
processor, RUBY-M710VG2AR is based on
the industrial ATX mother board making it the
ideal solution for a Green PC. It can also be
adopted in POS, medical, gaming, lottery, digital
signage, surveillance security monitoring and
kiosk.
FEATURES
„
Intel® CoreTM i7/i5/P4500 Processor (Quad
Core CPU support)
„
37.12
33.48
1.60
0
5.57
Four RS232 ports
GENERAL
Processor
- Intel® Core™ i7/i5/P4500 (1.6GHz/35W) Processor with 4/3/2MB L2 Cache in
socket 989
- Supports Intel® Virtualization Technology (VT-x), Enhanced Intel SpeedStep®
Technology, Thermal Monitoring Technologies, Intel® Fast/Flex Memory
Access (P4500 only), Execute Disable Bit, Intel® HT Technology (i7/ i5 only)
Chipset
BIOS
Memory
Intel® QM57 PCH (3.5W)
Storage Devices
AMI UEFI BIOS
Supports up to 8GB DDR3 800/1066 MHz SDRAM on two 240-pin DIMM
sockets with dual channel mode
- 6x SATA support 3Gb/s data transfer rate
- RAID 0,1,5,10
Programmable via S/W from 0.5 sec. to 254.5 min.
Intel QM57 Chipset
Watchdog Timer
Hardware Monitoring
„
Two Long-DIMMs support dual channel DDR3
SDRAM up to 8GB
Expansion Interface
„
Dual Display by VGA/DVI/HDMI/LVDS
„
Intel® Active Management Technology (Intel®
AMT 6.0)
- 1x PCI Express x16 slot (Gen1, 2.5 GT/s)
- 1x PCI Express x4 slot (Gen1, 2.5 GT/s)
- 1x PCI Express x1 slot (Gen1, 2.5 GT/s)
- 1x Mini-PCI Expressx1 socket (Gen1, 2.5 GT/s)
- 4x PCI 32-bit slots
®
I/O INTERFACE
REAR I/O
RS232/422/485
Gigabit Ethernet
VGA
RS232
HDMI
USB
DVI-D
Audio
ORDERING GUIDE
AB1-3586
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
RUBY-M710VG2AR.ATX IMB.QM57 w/o ECC
PGA989.w/DDR3 DIMMs/VGA/LVDS/DVI/HDMI/Dual
GbE/COM/Audio/USB
PACKING LIST
Super I/O
Audio
ITF IT8721F
Ethernet
- Intel® 82574L&82577LM dual Gigabyte Ethernet Controller Intel® 82574L &
82577LM
- 2X RJ-45 connectors with two LED indicators
Serial Port
- 1x RS232/422/485 port on rear I/O
- 1x RS232 on rear I/O and 4x RS232 on board
USB
- 4x USB 2.0 ports on rear I/O
- 4x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
GPIO
1x PS/2 Keyboard & Mouse on board
- Intel®40EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC888-GR LQFP48 codec, 7.1 channels
- Audio Jack DIP Light Pink/Lime/Light Blue"
On board programmable 16-bit Digital I/Os
DISPLAY
Graphic Controller
- Intel® QM57 Graphics and Memory Controller Hub integrated Intel® Gen 6.0
integrated Graphics
- Chrontel: HDMI level shifter
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1920x1200 @60Hz
- LVDS: up to 1600x1200 @66Hz
- HDMI: up to 1920x1200 @60Hz
One RUBY-M710VG2AR ATX Main Board
One SATA II Cable
One Installation CD
Mechanical & Environment
BIOS
DDR 3
Giga
Giga LAN
HDMI
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
iAMT
6.0
Dimension
Power Supply
305(L) x 244(W)mm; 12"(L) x 9.6"(W)
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 90%, non-condensing
MTBF
Over 80,000 hours at 40°C
- Typical: +12V(CPU)@3.5A; +12V(System)@2A; [email protected]; [email protected]
- Supports ATX mode
IMB-RUBY-M710VG2AR
42
RUBY-D714VG2AR
Intel® CoreTM i5/i7 processor based ATX
with DDR3 SDRAM, Triple display, Dual
Gigabit Ethernet, and USB Ports
Four PCI slots
One PCIe x4 slot (x1 signal)
One PCIe x16 slot (x4 signal)
One PCIe x16 slot
Intel® Q77
LGA1155 socket
RUBY-D714VG2AR is based on Intel Q77
chipset and desktop processor sku like CoreTM i7
DQGL%XLOWZLWKÀH[LEOH3&,H[SUHVVH[SDQVLRQ
and bifurcation feature, it can support two I/O
interface cards and can also suitable for Medical,
Industrial Automation, and Digital Signage applications.
FEATURES
1.60
0
ATX 24-pin power connector
Three SATA II ports
37.12
CF-SATA socket
TPM slot
Two SATA III ports
67.20
Four 240-pin
DDR3 DIMM sockets
Six USB 2.0
GENERAL
Processor
- Intel® Core™ i7/i5 processor up to 3.4GHz (65~95W)
with (3~8MB) Cache in LGA1155 package
- DMI x4 Link: 5.0 GT/s
- Supports Intel® Turbo Boost, Hyper-Threading, Virtualization, Thermal
Monitoring and Trusted Execution (depend on CPU sku)"
Chipset
Intel® Q77 PCH chipset
BIOS
Pheonix UEFI BIOS
„
Intel® CoreTM i7 and i5 Processors support
Memory
„
Four Long-DIMMs support dual channel DDR3
non-ECC SDRAM up to 32 GB
Supports up to 32GB DDR3 1333/1600 SDRAM on four 240-pin DIMM sockets
(dual channel)
Storage Devices
„
Triple display by VGA/DVI-D/HDMI
„
Rich I/O, USB 2.0/3.0, dual Gigabit Ethernet,
COM ports and SATA II/III ports support Intel®
RAID 0,1,5,10
- 2x SATA support 6Gb/s data transfer rate
- 3x SATA support 3Gb/s data transfer rate
- Supports RAID 0,1,5,10
- 1x CF-SATA (support CF and CF-SATA card)
Watchdog Timer
Programmable via S/W from 0.5 sec. to 255 sec.
Hardware Monitoring
On board fan connector (CPU Cooler x1, System Fan x1); temperature and
voltages monitoring
Expansion Interface
- 1x PCI Express x16 slot (Gen3, 8.0 GT/s)
- 1x PCI Express x16 slot (with x4 signal Gen 2, 5.0 GT/s)
- 1x PCI Express x4 slot (with x1 signal Gen 2, 5.0 GT/s)
- 4x PCI devices at 32-bit 33 MHz
„
One PCIe x16 (Gen 3), one PCIe x16 (Gen 2,
x4 signal), one PCIe x4 (Gen 2, x1 signal), and
four PCI slots
„
One CF-SATA slot (supports both CF and CFSATA card)
„
Intel® Active Management Technology 8.0
REAR I/O
VGA
RS232
Dual GbE
HDMI DVI-D
RS232/422/485
Audio
Super I/O
ITE IT8783F
Audio
- Intel®43&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec, 5.1 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82579LM and 82583V dual gigabit ethernet controllers
- PCI Express x1 interface based on gigabit ethernet
- Dual RJ-45 connectors with two LED indicators at rear I/O panel
Serial Port
- 3x RS232 and 1x Selectable RS232/422/485 on board
- 1x RS232 and 1x Selectable RS232/422/485 on rear I/O
USB
- 4x USB 3.0 ports on rear I/O (5 Gbps)
- 6x USB 2.0 ports on board (480 Mb/s)
Keyboard & Mouse
PS/2 on board dedicated to keyboard & mouse
GPIO
On board programmable 8-bit Digital I/Os
Four USB 3.0
ORDERING GUIDE
AB1-3847
I/O INTERFACE
RUBY-D714VG2AR. ATX IMB. LGA1155 CPU. Q77.
DDR3/VGA/DVI/HDMI/Dual GbE/COM/Audio/USB
PACKING LIST
DISPLAY
One RUBY-D714VG2AR ATX Industrial Main Board
One SATA III Cable
One Installation CD
One I/O shield
Graphic Controller
- Quad CoreTM Processor with Intel® HD Graphics 4000 and Integrated
Memory Controller
- Provided improved 3D multimedia capabilities including Microsoft
DirectX 11, Shader Model 4.0, MPEG-2 and OpenGL 3.1
Display Interface
- VGA: Resolution up to 2560x1600 @60Hz
- DVI-D: up to 1920x1200 @60Hz
- HDMI: up to 1920x1200 @60Hz
Mechanical & Environment
DDR 3
SATA
6Gb
USB 3.0
Watch DOG
H/W Monitor
DVI-D
43
IMB-RUBY-D714VG2AR
HDMI
VGA
Dimension
- 304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
- PCB: 6 layers
Power Supply
ATX 24-pin power input
Environment
- Operation Temperature: 0~60 °C (with highest performance on 50 °C)
- Storage Temperature: -20~80 °C
- Relative Humidity: 5~95%, non-condensing
MTBF
Over 120,000 hours at 40°C
RUBY-D715VG2AR
Intel® CoreTM i3 and Xeon® processor based
ATX with DDR3 SDRAM, Dual display, Dual
Gigabit Ethernet, and USB Ports
Four PCI slots
One PCIe x4 slot
Two PCIe x16 slots
(x16 signal or 2 x8 signal)
LGA1155 socket
Intel® C216
RUBY-D715VG2AR is based on Intel® C216 chipset and workstation sku like CoreTM i3 and Xeon®
(VHULHVSURFHVVRUV%XLOWZLWKÀH[LEOH3&,
express expansion and bifurcation feature, it can
support two I/O interface cards and can also suitable for Medical, Industrial Automation, and Digital
Signage applications.
FEATURES
„
„
Intel® CoreTM i3 and Xeon® E3-1200 series
processors support
Four Long-DIMMs support dual channel DDR3
ECC and non-ECC SDRAM up to 32 GB
1.60
0
ATX 24-pin power connector
Three SATA II ports
37.12
CFEX
TPM slot
Two SATA III ports
67.20
Four 240-pin
DDR3 DIMM sockets
Six USB 2.0
GENERAL
Processor
- Intel® Core™ i3 and Xeon® E3-1200 series processor up to 3.4GHz
(65~95W)
with (3~8MB) Cache in LGA1155 package
- DMI x4 Link: 5.0 GT/s
- Supports Intel® Turbo Boost, Hyper-Threading, Virtualization, Thermal
Monitoring and Trusted Execution (depend on CPU sku)"
Chipset
Intel® C216 PCH chipset
BIOS
Pheonix UEFI BIOS
Memory
Supports up to 32GB DDR3 ECC and non-ECC 1333/1600 SDRAM on four
240-pin DIMM sockets (dual channel)
Storage Devices
- 2x SATA support 6Gb/s data transfer rate
- 3x SATA support 3Gb/s data transfer rate
- Supports RAID 0,1,5,10
- 1x CFEX (supports CFEX card)
„
Dual display by VGA/DVI-D/HDMI
„
Rich I/O, USB 2.0/3.0, dual Gigabit Ethernet,
COM ports and SATA II/III ports support Intel®
RAID 0,1,5,10
Watchdog Timer
Programmable via S/W from 0.5 sec. to 255 sec.
Hardware Monitoring
Two PCIe x16 slots (Gen 3, x16 signal or 2
x8 signal), one PCIe x4 (Gen 2), and four PCI
slots
On board fan connector (CPU Cooler x1, System Fan x1); temperature and
voltages monitoring
Expansion Interface
- 2x PCI Express x16 slots (Gen 3, 8.0 GT/s, x16 signal or 2 x8 signal)
- 1x PCI Express x4 slot (Gen 2, 5.0 GT/s)
- 4x PCI devices at 32-bit 33 MHz
„
„
One CFEX socket (supports CFEX card)
„
Intel® Active Management Technology 8.0
I/O INTERFACE
REAR I/O
VGA
RS232
Audio
Four USB 3.0
ORDERING GUIDE
AB1-3925
RUBY-D715VG2AR. ATX IMB. LGA1155 CPU. C216
DDR3/VGA/DVI/HDMI/Dual GbE/COM/Audio/USB
Standard
One SATA II cable
One SATA III cable (Black)
One Installation CD
One I/O shield
DVI-D + VGA cable with bracket
PICMG SBC Handling and Installation Notice
Installation CD
One RUBY-D715VG2AR ATX Industrial Main Board
One SATA III Cable
One Installation CD
One I/O shield
DDR 3
USB 3.0
Audio
- Intel®&3&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec, 5.1 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82579LM and 82583V dual gigabit ethernet controllers
- PCI Express x1 interface based on gigabit ethernet
- Dual RJ-45 connectors with two LED indicators at rear I/O panel
Serial Port
- 3x RS232 and 1x Selectable RS232/422/485 on board
- 1x RS232 and 1x Selectable RS232/422/485 on rear I/O
USB
- 4x USB 3.0 ports on rear I/O (5 Gbps)
- 6x USB 2.0 ports on board (480 Mb/s)
Keyboard & Mouse
PS/2 on board dedicated to keyboard & mouse
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
PACKING LIST
SATA
6Gb
ITE IT8783F
Dual GbE
HDMI DVI-D
RS232/422/485
Super I/O
H/W Monitor
HDMI
VGA
DVI-D
Graphic Controller
- Quad CoreTM Processor with Intel® HD Graphics 4000 and Integrated
Memory Controller
- Provided improved 3D multimedia capabilities including Microsoft
DirectX 11, Shader Model 4.0, MPEG-2 and OpenGL 3.1
Display Interface
- VGA: Resolution up to 2560x1600 @60Hz
- DVI-D: up to 1920x1200 @60Hz
- HDMI: up to 1920x1200 @60Hz
Mechanical & Environment
Dimension
- 304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
- PCB: 6 layers
Power Supply
ATX 24-pin power input
Environment
- Operation Temperature: 0~60 °C (with highest performance on 50 °C)
- Storage Temperature: -20~80 °C
- Relative Humidity: 5~95%, non-condensing
MTBF
Over 120,000 hours at 40°C
IMB-RUBY-D715VG2AR
44
RUBY-D712VG2AR
Intel® CoreTM i5 and i7 processor based
ATX with DDR3 SDRAM, Dual Display,
Dual Gigabit Ethernet and USB Ports
One PCIe x4 slot (x1 signal)
One PCIe x8 slot (x4 signal)
One PCIe x16 slot
Four PCI slots
LGA1155 socket
16 bits GPIO (8 in/8 out)
Intel® Q67
TPM
Four 240-pin
DDR3 DIMM sockets
Four USB ports
One RS232/422/485 selectable port
Three RS232 ports
Four SATA II ports
Two SATA III ports
With the Intel® Q67 chipset on board, the RUBYD712VG2AR supports the latest quad-core
2nd Generation Intel® CoreTM i7 and CoreTM i5
processors. This model is also ideal for Factory
Automation, Medical, Gaming, Digital Signage,
Surveillance Security Monitoring and Kiosk with
high performance requiring various I/O connectors.
FEATURES
Chipset
Intel® Q67 PCH chipset (6.1W)
BIOS
AMI UEFI BIOS
Memory
Supports up to 32GB DDR3 1333/1066 MT/s SDRAM on 4x 240-pin non-ECC
DIMM sockets (dual channel)
Storage Devices
- 2x SATA support 6Gb/s data transfer rate
- 4x SATA support 3Gb/s data transfer rate
- RAID 0,1,5,10
„
Four Long-DIMMs support dual channel DDR3
non-ECC SDRAM up to 32GB
Watchdog Timer
Programmable via S/W from 0.5 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x PCI Express x4 slot (Gen2, 5.0 GT/s)
- 1x PCI Express x8 slot (Gen2, 5.0 GT/s)
- 1x PCI Express x16 slot (Gen2, 5.0 GT/s)
- 4x PCI 32-bit slots
Dual Display by VGA/DVI/ HDMI
„
SATA ports support Intel® RAID 0,1,5,10
„
One PCIe x16, one PCIe x8 (x4 signal), one
PCIe x4 (x1 signal) and four PCI slots
„
Intel® Active Management Technology 7.0
RS232
I/O INTERFACE
HDMI DVI-D
Four USB Audio
RS232/422/485 S l abl
ORDERING GUIDE
AB1-3634
RUBY-D712VG2AR. ATX IMB. LGA1155 CPU. Q67.
DDR3/VGA/DVI/HDMI/Dual GbE/COM/Audio/USB
PACKING LIST
One RUBY-D712VG2AR ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
Giga
DDR 3
SATA
6Gb
Watch DOG
SMBus
Super I/O
ITE IT8728F
Audio
- Intel®%'43&+EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5&KDQQHO+LJK'H¿QLWLRQ$XGLR&RGHF
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82574L and Intel® 82579LM dual gigabit ethernet controllers
- 2x RJ-45 connectors with two LED indicators at rear I/O panel
Serial Port
- 3x RS232 on board and 1x RS232/422/485 selectable on board
- 1x RS232 on rear I/O and 1x RS232/422/485 selectable on rear I/O
USB
- 4x USB 2.0 ports on rear I/O 4x USB 2.0 ports on borad with pitch 2.54 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
PS/2 on board dedicated to keyboard & mouse
GPIO
On board programmable 16-bit Digital I/Os
Dual GbE
VGA
H/W Monitor
HDMI
IMB-RUBY-D712VG2AR
GPIO
1.60
0
2.81
- Intel® Core™ i7/i5 processor up to 3.4GHz (65~95W) with (3~8MB) Cache in
LGA1155 package
- DMI x4 Link: 5.0 GT/s
- Supports Intel® Turbo Boost, Hyper-Threading, Virtualization, Thermal
Monitoring and Trusted Execution (depend on CPU sku)"
Intel® CoreTM i7 and i5 Processors (Quad Core
CPU support)
REAR I/O
45
GENERAL
Processor
„
„
36.82
67.20
ATX 24-pin power
connector
Giga LAN
DISPLAY
Graphic Controller
- Intel® HD Graphics 2000/3000 integrated Graphics Engine, provides a
visually stunning experience optimized for Blu-ray and HD video HDMI
- Chrontel: CH7318B QFN-48
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1920x1200 @60Hz
- HDMI: up to 1920x1200 @60Hz
Mechanical & Environment
Dimension
243.8(L) x 304.8(W)mm; 9.6"(L) x 12"(W)
Power Supply
- Typical: +12V(CPU)@3.81A; +12V(System)@2.21A; [email protected]; [email protected]
- Supports ATX mode
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
RUBY-D711VG2AR
Intel® CoreTM i3 and Xeon® processor based
ATX with DDR3 SDRAM, Dual Display, Dual
Gigabit Ethernet and USB Ports
One PCIe x4 slot (x1 signal)
One PCIe x8 slot (x4 signal)
One PCIe x16 slot
Four PCI slots
LGA1155 socket
16 bits GPIO (8 in/8 out)
Intel® C206
TPM
Four USB ports
On the basis of Intel® C206 Chipset, RUBYD711VG2AR supports the latest quad-core 2nd
Generation Intel® CoreTM i3 and Xeon® processors and provides numerous I/O connectors and
also applies high performance in such areas as
factory automation, medical, gaming, digital signage, surveillance security monitoring and kiosk.
FEATURES
GENERAL
Processor
- Intel® Core™ i3 and Xeon® E3-1200 series processor up to 3.4GHz (65~95W)
with (3~8MB) Cache in LGA1155 package
- DMI x4 Link: 5.0 GT/s
- Supports Intel® Turbo Boost, Hyper-Threading, Virtualization, Thermal
Monitoring and Trusted Execution (depend on CPU sku)
Chipset
BIOS
Memory
Intel® C206 PCH chipset (6.6W)
AMI UEFI BIOS
Supports up to 32GB DDR3 1333/1066 MT/s SDRAM on 4x 240-pin ECC/nonECC DIMM sockets (dual channel)
„
Intel® CoreTM i3 and Xeon® E3-1200 series
Processors (Quad Core CPU support)
Storage Devices
- 2x SATA support 6Gb/s data transfer rate
- 4x SATA support 3Gb/s data transfer rate
- RAID 0,1,5,10
„
Four Long-DIMMs support dual channel DDR3
ECC SDRAM up to 32GB
Watchdog Timer
Programmable via S/W from 0.5 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x PCI Express x4 slot (Gen2, 5.0 GT/s)
- 1x PCI Express x8 slot (Gen2, 5.0 GT/s)
- 1x PCI Express x16 slot (Gen2, 5.0 GT/s)
- 4x PCI 32-bit slots
„
Dual Display by VGA/DVI/HDMI
„
SATA ports support Intel® RAID 0,1,5,10
„
One PCIe x16, one PCIe x8 (x4 signal), one
PCIe x4 (x1 signal) and four PCI slots
„
Intel® Active Management Technology 7.0
I/O INTERFACE
Super I/O
Audio
REAR I/O
VGA
RS232
Dual GbE
HDMI DVI-D
RS232/422/485
S l abl
Four USB
Audio
ORDERING GUIDE
AB1-3633
RUBY-D711VG2AR. ATX IMB. C206 w/ECC
LGA1155.w/DDR3 DIMMs/ VGA/LVDS/DVI/HDMI/Dual
GbE/COM/Audio/USB
One RUBY-D711VG2AR ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
Watch DOG
H/W Monitor
GPIO
SMBus
Giga LAN
- Intel®%'&EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5&KDQQHO+LJK'H¿QLWLRQ$XGLR&RGHF
- Audio Jack DIP Light Pink/Lime/Light Blue
- Intel® 82574L and Intel® 82579LM dual gigabit ethernet controllers
- 2x RJ-45 connectors with one LED indicators at rear I/O panel
Serial Port
- 3x RS232 on board and 1x RS-232/422/485 selectable on board
- 1x RS232 on rear I/O and 1x RS-232/422/485 selectable on rear I/O
USB
- 4x USB 2.0 ports on rear I/O and 4x USB 2.0 ports on board with pitch 2.54 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
GPIO
PS/2 on board dedicated to keyboard & mouse
On board programmable 16-bit Digital I/Os
DISPLAY
Graphic Controller
- Intel® HD Graphics 2000/3000 integrated Graphics Engine provides a
visually stunning experience optimized for Blu-ray* and HD video HDMI
- Chrontel: CH7318B QFN-48
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1920x1200 @60Hz
- HDMI: up to 1920x1200 @60Hz
Mechanical & Environment
Dimension
Power Supply
243.8(L) x 304.8(W)mm; 9.6"(L) x 12"(W)
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
Giga
SATA
6Gb
ITE IT8728F
Ethernet
PACKING LIST
DDR 3
1.60
0
2.81
67.20
ATX 24-pin power
connector
36.82
Four 240-pin
DDR3 DIMM sockets
One RS232/422/485 selectable port
Three RS232 ports
Four SATA II ports
Two SATA III ports
- Typical: +12V(CPU)@3.81A; +12V(System)@2.21A; [email protected]; [email protected]
- Supports ATX mode
HDMI
IMB-RUBY-D711VG2AR
46
RUBY-9911
Leading Intel® Core™ 2 Quad/Core™ 2 Duo Processor based
ATX motherboard with Dual Display, Dual Gigabit Ethernet,
Four SATA Ports, Four COM Ports, and Eight USB Ports
Four PCI slots
Dual RS232 ports
One PCIe x4 slot
Parallel port
One PCIe x16 slot
LGA775 socket
IEEE1394a port (optional)
Four USB ports
Two 240-pin DDR3 DIMM
sockets
Intel® ICH10DO
Intel® Q45
FDD port
IDE connector
Four SATA II ports
The RUBY-9911 is based on the industrial ATX
motherboard and can be used in applications
such as Automation, Multimedia, Kiosk and
industrial controls that require a variety of I/O
connectors.
GENERAL
Processor
- Intel® Core™ 2 Quad/Core™ 2 Duo Processor with 2MB L2 Cache in LGA775 package
- FSB:1333/1066/800MHz
- Supports Enhanced Intel SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Intel® Q45 Graphics and Memory Controller Hub (17W) and ICH10DO
„
Intel Core 2 Quad/Core™ 2 Duo processor
Chipset
BIOS
Memory
„
Intel® Q45 Express and ICH10DO chipsets
Storage Devices
„
Two 240-pin DIMM sockets support dual
channel DDR3 SDRAM up to 4GB
- 4x SATA support 3Gb/s data transfer rate
- 1x EIDE supports Ultra DMA100/66/33MB/s
- RAID 0,1,5,10
- 1x FDD channel
Dual display: VGA/DVI-D, 3rd display via PCI
or PCI-Express expansion slot
Watchdog Timer
Hardware Monitoring
Programmable via S/W from 1 sec. to 255 min.
„
„
Four SATA ports and One IDE connector
Supports RAID 0,1,5,10 function
Expansion Interface
„
- 1x PCI Express x16 slot (Gen1, 2.5 GT/s)
- 1x PCI Express x4 slot (Gen1, 2.5 GT/s)
- 4x PCI 32-bit slots
„
One PCI-Express x16, One PCI-Express x4
and Four PCI slots
„
TPM 1.2 and iAMT 5.0 supported
FEATURES
®
TM
Gi abi E
VGA
B/MS DVI-D RS232
r
USB Audio
ORDERING GUIDE
AB1-3256
RUBY-9911VG2A.ATX.LGA775.SingleCore2Quad/
Duo.w/DVI-D/VGA/DualGbE/Audio
Supports up to 4GB DDR3 800/1066 MHz SDRAM on two 240-pin DIMM
sockets with dual channel mode
- System monitor (fan,temperature,voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Winbond 83627UHG
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC888-GR LQFP48 codec, 7.1 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82567LM and Intel® 82574L dual gigabit ethernet controllers
- Dual RJ-45 connectors with two LED indicators at rear I/O panel
Serial Port
- 2x RS232 on rear I/O and 1x RS232 on board
- 1x RS232/422/485 selectable on board and 1x IEEE1394a port on board
USB
- 4x USB 2.0 ports on rear I/O and 4x USB 2.0 ports on borad
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on rear I/O
GPIO
On board programmable 8-bit Digital I/Os
Other
1x prallel port on board box header
DISPLAY
Graphic Controller
- IIntel® Q45 Graphics and Memory Controller Hub integrated Intel® GMA
4500 delivers Microsoft DirectX 10 and Shader Model 4.0and OpenGL 1.5,
enabling support for the highest levels of the Windows Vista experience
- Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0)
Display Interface
- VGA: Resolution up to 2048x1536 (QXGA) @75Hz
- DVI-D: up to 2560x1600 @60Hz
PACKING LIST
One RUBY-9911 ATX Main Board
One LGA775 Cooler
One Installation CD
AMI Core 8 BIOS
I/O INTERFACE
Super I/O
Audio
REAR I/O
1.60
0
3
60.10
ATX 24-pin power connector
Mechanical & Environment
Dimension
Power Supply
304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 10% to 90%, non-condensing
MTBF
Over 170,000 hours at 40°C
Giga
DDR 3
47
SATA
3Gb
Watch DOG
H/W Monitor
IMB-RUBY-9911
GPIO
Giga LAN
USB 2.0
- Typical: +12V(CPU)@9.25A; +12V(System)@3.68A; [email protected]; [email protected]
- Supports ATX mode
RUBY-9719VG2AR
Intel® CoreTM 2 Duo/CoreTM 2 Quad Processor
based ATX Motherboard with DDR2, VGA, Dual
Gigabit Ethernet, Audio and USB
One PCIe x16 slot
ISA slot
Six PCI slots
LGA775 socket
Intel® G41
Intel® ICH7R
Header for TPM
Four power RS232 ports
Two 240-pin DDR2
DIMM sockets
Four SATA II ports
ATX 24P power connector
Equipped with the Intel® G41 and ICH7R chipset, RUBY-9719VG2AR supports a wide range
of Intel processors including CoreTM 2 Quad,
CoreTM 2 Duo, Pentium® and Celeron®. In addition, this model is based on the industrial ATX
motherboard and particularly designed for multiple applications such as Industrial control and
Automation, Multimedia, Gaming, Kiosk, Digital
Signage, Print Imaging, Digital Surveillance and
Network Security.
FEATURES
„
Intel® CoreTM 2 Quad/CoreTM 2 Duo Processor
and Intel® G41 Chipset, FSB up to 1333MHz
„
Two 240-pin DIMMs support dual channel
DDR2 SDRAM up to 4GB
„
Dual Gigabit Ethernet port
„
Six 32-bit PCI slots/Five PCI slots and One
ISA slot
Four SATA II ports support Intel® Matrix
Storage Technology with RAID 0,1,5,10
„
One 44-pin IDE and one CompactFlash share
the same channel
„
PCIe x16 slot can support x1, x4, x8 or x16
cards
REAR I/O
Parallel
COM
Dual GbE
Four USB
VGA
ORDERING GUIDE
AB1-3364
GENERAL
Processor
- Intel® Core™ 2 Quad/Core™ 2 Duo Processor with 2MB L2 Cache in
LGA775 package
- FSB:1333/1066/800MHz
- Supports Enhanced Intel SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Chipset
BIOS
Memory
Intel® G41 Graphics and Memory Controller Hub (25W)+ICH7R
Storage Devices
- 4x SATA support 3Gb/s data transfer rate
- 1x IDE 44-pin connector supports Ultra DMA100/66/33MB/s
- 1x CompactFlash connector supports Ultra DMA100/66/33MB/s (share with
IDE channel)
- RAID 0,1,5,10
Watchdog Timer
Hardware Monitoring
Programmable via S/W from 1 sec. to 255 min.
Expansion Interface
- 1x PCI Expressx16 slot (Gen1, 2.5 GT/s)
- 5x PCI 32-bit slots and 1x ISA slot or 6x PCI 32-bit slots
RUBY-9719VG2AR.ATX.LGA775.Intel Core 2 Quad/
Duo.G41 w/VGA/Dual GbE/Audio
Super I/O
Audio
H/W Monitor
GPIO
Winbond W83627UHG
- Intel®*EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR LQFP48 codec, 5.1 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82583x2 dual gigabit ethernet controllers
- 2x RJ-45 connectors with two LED indicators at rear I/O panel
Serial Port
- 5x RS232 (5V/12V) on board
- 1x RS232/422/485 selectable on rear I/O
USB
- 4x USB 2.0 ports on rear I/O and 4x USB 2.0 ports on borad
- 480 Mb/s bus encompasses the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
GPIO
Other
1x PS/2 Keyboard & Mouse on rear I/O
On board programmable 8-bit Digital I/Os
1x parallel port on rear I/O
Graphic Controller
- Intel® G41 Graphics and Memory Controller Hub integrated Intel GMA 4500
delivers Microsoft DirectX 10, Shader Model 4.0, and OpenGL 1.5
- Intel® Dynamic Video Memory Technology (Intel® DVMT 5.0)
Display Interface
VGA: Resolution up to 2048x1536(QXGA) @75Hz
Dimension
Power Supply
305(L) x 244(W)mm; 12"(L) x 9.6"(W)
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 10% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
Giga
Watch DOG
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Mechanical & Environment
One RUBY-9719VG2AR ATX Main Board
One SATA II Cable
One Installation CD
SATA
3Gb
Supports up to 4GB DDR2 667/800MHz SDRAM on two 240-pin DIMM sockets
with dual channel mode
DISPLAY
Audio
PACKING LIST
DDR 2
AMI Core 8 BIOS
I/O INTERFACE
„
PS/2 Keyboard & Mouse
39.35
37.12
1.60
0
2.10
8 bits GPIO
One Power RS232 port
Compact flash socket
IDE connector
Four USB ports
Giga LAN
- Typical: +12V(CPU)@3.57A; +12V(System)@0.63A; [email protected]; [email protected]
- Supports ATX mode
USB 2.0
IMB-RUBY-9719VG2AR
48
RUBY-9718VG2AR
Intel® CoreTM 2 Quad processor based ATX
Industrial Mainboard with onboard DVI/VGA
Dual-Display, DDR2 SDRAM, VGA, Dual
Gigabit Ethernet, Audio and USB
ADD2 slot
Two PCIe x1 slots
Four PCI slots
LGA775 socket
Intel® Q965
Intel® ICH8DO
Four 240-pin DDR2
DIMM sockets
Six SATA II ports
On the basis of Intel® Q965 chipset, RUBY9718VG2AR supports the Intel® CoreTM 2 Quad
processor that provides the ideal solution for
multiple applications such as Industrial control
and Automation, Multimedia, Gaming, Kiosk,
Digital Signage, Print Imaging, Digital Surveillance and Network Security.
FEATURES
„
CoreTM 2 Quad, CoreTM 2 Duo, Pentium® D,
Pentium® 4, Celeron® D processor in LGA775
package
„
%HQH¿WVVXFKDV+\SHU7KUHDGLQJ(07
dual-core, EIST, XD & VT of processor can
be easily applied to system by changing
processor
„
Onboard dual independent display: VGA and DVI-D
„
One ADD2 graphics slot for ADD2 card
„
Two PCI Express x1 slots and four 32-bit PCI
expansion slots
„
Six SATA II ports, Intel® Matrix Storage
Technology with RAID 0,1,5,10 support
REAR I/O
S/2
board
Mou
arall l or
VGA
USB 4
GbE 2
Audio
DVI-D
ORDERING GUIDE
AB1-3064
RUBY-9718VG2AR.ATX.LGA775.Single P4.SBC.w/
DVI/CRT VGA/Dual Giga LAN
GENERAL
Processor
- Intel® Core™ 2 Quad/Core™ 2 Duo/Pentium® D/Pentium® 4/Celeron® D
Processor with 2MB L2 Cache in LGA775 package
- FSB:1066/800MHz
- Supports Enhanced Intel SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Chipset
Intel® Q965 Graphics and Memory Controller Hub (28W)+ICH8DO
BIOS
Award BIOS
Memory
Supports up to 8GB DDR2 533/667/800MHz SDRAM on four 240-pin DIMM sockets
Storage Devices
- 6x SATA support 3Gb/s data transfer rate
- RAID 0,1,5,10 (supported by Intel® Matrix Storage Technology)
- 1x FDD channel
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x ADD2 slot (single SDVO bus)
- 2x PCI Express x1 slots (Gen1, 2.5 GT/s)
- 4x PCI 32-bit slots
I/O INTERFACE
Super I/O
Winbond W83627HG-AW
Audio
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2+2 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82573L and Intel® 82566DM dual gigabit ethernet controllers
- 2x RJ-45 connectors with two LED indicators at rear I/O panel
- PCI Express x1 interface based Gigabit Ethernet
Serial Port
- 2x RS232 power selectable on board
- 1x RS232/422/485 selectable on board and 1x RS232 on board
USB
- 4x USB 2.0 ports on rear I/O and 6x USB 2.0 ports on borad
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on rear I/O
GPIO
On board programmable 12-bit Digital I/Os
Other
1x parallel port on rear I/O
DISPLAY
Graphic Controller
- Intel® Q965 Graphics and Memory Controller Hub integrated Intel Graphics
Media Accelerator 3000 (Intel GMA 3000), providing a visually stunning
experience optimized for Blu-ray and HD video
- ADD2 graphic slot for ADD2 card
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1600x1200 @60Hz
PACKING LIST
One RUBY-9718VG2AR ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
Giga
DDR 2
49
Watch DOG
SATA
3Gb
H/W Monitor
GPIO
IMB-RUBY-9718VG2AR
Giga LAN
2.40
37.10
25.30
1.60
0
ATX 24-pin power connector
Mechanical & Environment
Dimension
304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
Power Supply
- Typical: +12V(CPU)@8.75A; +12V(System)@3.6A; [email protected]; [email protected]
- Supports ATX mode
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 90%, non-condensing
MTBF
Over 70,000 hours at 40°C
RUBY-9717VGAR
Intel® CoreTM 2 Quad processor based Micro-ATX
Industrial Mainboard with onboard DVI/VGA
Dual-display, DDR2 SDRAM, Gigabit Ethernet,
Audio and USB
ADD2 slot
One PCIe x4 slot
Two PCI slots
One RS232/422/485 selectable port
LGA775 socket
One RS232 port
Intel® Q965
Intel® ICH8DO
Four 240-pin DDR2
DIMM sockets
FDD port
Eight USB ports
ATX 24-pin power connector
Supported by the Intel® Q965, the RUBY9717VGAR is based on industrial uATX
motherboard provides multiple I/O connectors
and applies high performance in the Medical
ultrasound equipment, Data Communications,
Multimedia, POS and Gaming markets.
FEATURES
„ Industrial mainboard with a μATX form factor
that supports all Intel® mainstream desk top
processors - CoreTM 2 Quad, CoreTM 2 Duo,
Pentium® D, Pentium® 4, Celeron® D processor
in LGA775 package
„ Onboard dual independent display: VGA and DVI-D
„ One ADD2 graphics slot for ADD2 card
GENERAL
Processor
- Intel® Core™ 2 Quad/Core™ 2 Duo Pentium® D/Pentium® 4/Celeron® D
Processor with 2MB L2 Cache in LGA775 package
- FSB: 1066/800MHz
- Supports Enhanced Intel SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Chipset
Intel® Q965 Graphics and Memory Controller Hub (28W)+ICH8DO
BIOS
Memory
Award BIOS
Storage Devices
- 6x SATA support 3Gb/s data transfer rate
- RAID 0,1,5,10 (supported by Intel® Matrix Storage Technology)
- 1x FDD channel
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage)
- Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x ADD2 slot(single SDVO bus)
- 1x PCI Express x4 slot (Gen1, 2.5 GT/s)
- 2x PCI 32-bit slots
„ One PCI Express x4 slot and two 32-bit PCI
expansion slots
„ Six SATA II ports support Intel® Matrix Storage
Technology with RAID 0,1,5,10
REAR I/O
board
Mou
GbE
arall l or
VGA
o
r d RS232 2
DVI-D
Audio
USB 2
ORDERING GUIDE
RUBY-9717VGAR.Micro-ATX.LGA775.Single P4.w/
VGA/GbE/Audio/RAID
AB1-3055
PACKING LIST
One RUBY-9717VGAR Micro-ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
Giga
DDR 2
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
Supports up to 8GB DDR2 533/667/800MHz SDRAM on four 240-pin DIMM sockets
I/O INTERFACE
„ Six 32-bit PCI expansion slots for most
industrial I/O cards
S/2
1.60
0
2.10
38.71
33.90
12 bits GPIO ports
Six SATA II ports
GPIO
Super I/O
Winbond W83627HG-AW
Audio
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2+2 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82566DM single gigabit ethernet controller
- 1x RJ-45 connectors with two LED indicators at rear I/O panel
- PCI Express x1 interface based Gigabit Ethernet
Serial Port
- 2x RS232 Power selectable on rear I/O
- 1x RS232/422/485 selectable on board and 1x RS232 on board
USB
- 2x USB 2.0 ports on rear I/O and 8x USB 2.0 ports on borad
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on rear I/O
GPIO
On board programmable 12-bit Digital I/Os
Other
1x parallel port on rear I/O
DISPLAY
Graphic Controller
- Intel® Q965 Graphics and Memory Controller Hub integrated Intel® Graphics
Media Accelerator 3000 (Intel® GMA 3000), providing a visually stunning
experience optimized for Blu-ray and HD video
- ADD2 graphic slot for ADD2 card
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1600x1200 @60Hz
Mechanical & Environment
Dimension
243.8(L) x 243.8(W)mm; 9.6"(L) x 9.6"(W)
Power Supply
- Typical: +12V(CPU)@3.31A; +12V(System)@5.82A; [email protected]
- Supports ATX mode
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 90%, non-condensing
MTBF
Over 100,000 hours at 40°C
IMB-RUBY-9717VGAR
50
RUBY-9716VG2AR
Intel® CoreTM 2 Quad processor based ATX
Industrial Mainboard with DDR2 SDRAM,
VGA, Dual Gigabit Ethernet, Audio and USB
One PCIe x16 expansion slot
One PCIe x4 expansion slot
LGA775 socket
Intel® Q965
One RS232 selectable port
Four PCI expansion slots
Intel® ICH8DO
Four USB ports
Two RS232 Power selectable ports
Five SATA II ports
Ten programmable GPIO ports
CompactFlash socket
Front panel I/O
ATX V2.2 24-pin power connector
Four 240-pin
DDR2 DIMM sockets
40.10
23.14
1.60
0
3.65
IDE connector
FDD port
RUBY-9716VG2AR is based upon the Intel®
4FKLSVHWZLWK¿YH6$7$,,SRUWVWRJHWKHU
one IDE channel and CF socket which is a perfect combination for storage interfaces for kinds
of applications; supports Intel® Matrix Storage
Technology.
FEATURES
„
„
CoreTM
Intel mainstream desktop processors 2 Quad, CoreTM 2 Duo, Pentium® D, Pentium®
4,Celeron® D processor in LGA775 package
®
One PCI Express x16 slot features high-end
graphics card connection interface or dual
independent display with ADD2+ media card
that provides TV tuner, video capture in and
DVI, TV-out
„
One PCI Express x4 slot for storage add-in
card which provides reliable and safer data
storage with adequate I/O throughput
„
Five SATA II ports together with one IDE
channel and CF socket are perfect combination
REAR I/O
S/2
M
GbE 2
or
VGA or
USB 4
Audio
ORDERING GUIDE
RUBY-9716VG2AR.Socket LGA775.Intel Q965.Core 2
Duo.IMB.w/VGA/2xGbE/Audio
PACKING LIST
One RUBY-9716VG2AR ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
DDR 2
51
- Intel® Core™ 2 Quad/Core™ 2 Duo Pentium® D/Pentium® 4/Celeron® D
Processor with 2MB L2 Cache in LGA775 package
- FSB: 1066/800MHz
- Supports Enhanced Intel® SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Chipset
Intel® Q965 Graphics and Memory Controller Hub (28W)+ICH8DO
BIOS
Award BIOS
Memory
Supports up to 8GB DDR2 533/667/800MHz SDRAM on four 240-pin DIMM sockets
Storage Devices
- 1x EIDE connector supports Ultra DMA100/66/33MB/s
- 5x SATA support 3Gb/s data transfer rate and 1x FDD channel
- 1x CompactFlash connector supports Ultra DMA100/66/33MB/s (share with
IDE channel)
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage) and Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x PCI Express x4 slot for x1 or x4 card (Gen 1, 2.5 GT/s)
- 1x PCI Express x16 slot for PCIe x16 or PCIe x1 or ADD2/+ card (Gen 1, 2.5 GT/s)
- 4x PCI 32-bit slots
I/O INTERFACE
Super I/O
Winbond W83627HG-AW
Audio
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2+2 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82573L and Intel® 82566DM dual gigabit ethernet controllers
- 2x RJ-45 connectors with two LED indicators at rear I/O panel
- PCI Express x1 interface based Gigabit Ethernet
Serial Port
- 1x RS232/TTL selectable on rear I/O panel
- 2x RS232 Power selectable on board and 1x RS232/422/485 selectable on board
USB
- 4x USB 2.0 ports on rear I/O and 4x USB 2.0 ports on borad
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on rear I/O
GPIO
On board programmable 10-bit Digital I/Os
Other
1x parallel port on rear I/O
board Mou
arall l or
AB1-3041
GENERAL
Processor
SATA
3Gb
Watch DOG
H/W Monitor
IMB-RUBY-9716VG2AR
GPIO
2
GbE
DISPLAY
Graphic Controller
- Intel® Q965 Graphics and Memory Controller Hub integrated Intel® Graphics
Media Accelerator 3000 (Intel GMA 3000), providing a visually stunning
experience optimized for Blu-ray and HD video
- Supports dual independent display with ADD2/+ card
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1600x1200 @60Hz
Mechanical & Environment
Dimension
304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
Power Supply
- Typical: [email protected]; [email protected]; [email protected]
- Supports ATX mode
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 90%, non-condensing
MTBF
Over 150,000 hours at 40°C
RUBY-9716VGAR
Intel® CoreTM 2 Quad processor based ATX
Motherboard with DDR2 SDRAM, VGA, Gigabit
Ethernet, Audio and USB
One PCIe x16 expansion slot
One PCIe x1 expansion slot
One PCIe x4 expansion slot
One RS232 selectable port
Four PCI expansion slots
LGA775 socket
Intel® Q965
Intel® ICH8DO
Four USB ports
Two RS232 power selectable ports
Five SATA II ports
Ten programmable GPIO ports
CompactFlash socket
Front panel I/O
ATX V2.2 24-pin power connector
Four 240-pin
DDR2 DIMM
sockets
Built with Intel® Q965 chipset, RUBY-9716VGAR
supports Intel® CoreTM 2 Duo processor based
ATX Industrial Mainboard with DDR2 SDRAM,
VGA, Gigabit Ethernet, Audio and USB. In adGLWLRQ¿YH6$7$,,SRUWVRQH,'(FKDQQHODQG
CF socket are perfect storage interfaces for
all kinds of applications; supports Intel® Matrix
Storage Technology.
FEATURES
„
Intel® mainstream desktop processors - CoreTM
2 Quad, CoreTM 2 Duo, Pentium® D, Pentium®
4,Celeron® D processor in LGA775 package
„
One PCI Express x16 slot features high-end
graphics card connection interface or dual
independent display with ADD2+ media card
that provides TV tuner, video capture in and
DVI, TV-out
„
„
One PCI Express x4 slot for storage add-in
card which provides reliable and safer data
storage with adequate I/O throughput
Five SATA II ports together with one IDE
channel and CF socket are perfect combination
REAR I/O
S/2
board
Mou
arall l or
M
or
Dual USB or
GbE
USB 2
VGA or
Audio
ORDERING GUIDE
AB1-3018
RUBY-9716VGAR.Socket LGA775.Intel Q965.Core 2
Duo.IMB.w/VGA/GbE/Audio
40.10
23.14
1.60
0
3.65
IDE connector
FDD port
GENERAL
Processor
- Intel® Core™ 2 Quad/Core™ 2 Duo Pentium® D/Pentium® 4/Celeron® D
Processor with 2MB L2 Cache in LGA775 package
- FSB: 1066/800MHz
- Supports Enhanced Intel SpeedStep® Technology, Intel® 64 architecture,
Execute Disable Bit (Core™ 2 Duo only)
Chipset
Intel® Q965 Graphics and Memory Controller Hub (28W)+ICH8DO
BIOS
Award BIOS
Memory
Supports up to 8GB DDR2 533/667/800MHz SDRAM on four 240-pin DIMM sockets
Storage Devices
- 1x EIDE connector supports Ultra DMA100/66/33MB/s
- 5x SATA support 3Gb/s data transfer rate and 1x FDD channel
- 1x CompactFlash connector supports Ultra DMA100/66/33MB/s (share with
IDE channel)
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Hardware Monitoring
- System monitor (fan, temperature, voltage) and Temperature (CPU & System)
- Voltage (CPU Vcore, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x PCI Express x4 slot for x1 or x4 card (Gen 1, 2.5 GT/s)
- 1x PCI Express x1 slot (Gen 1, 2.5 GT/s)
- 1x PCI Express x16 slot for PCIe x16 or PCIe x1 or ADD2/+ card (Gen 1, 2.5 GT/s)
- 4x PCI 32-bit slots
I/O INTERFACE
Super I/O
Winbond W83627HG-AW
Audio
- Intel®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2 LQFP48 codec, 2+2 channels
- Audio Jack DIP Light Pink/Lime/Light Blue
Ethernet
- Intel® 82566DM single gigabit ethernet controller
- 1x RJ-45 connectors with two LED indicators at rear I/O panel
- PCI Expressx1 interface based Gigabit Ethernet
Serial Port
- 1x RS232/TTL selectable on rear I/O panel
- 2x RS232 Power selectable on board and 1x RS232/422/485 selectable on board
USB
- 4x USB 2.0 ports on rear I/O and 4x USB 2.0 ports on borad
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on rear I/O
GPIO
On board programmable 10-bit Digital I/Os
Other
1x parallel port on rear I/O
DISPLAY
Graphic Controller
- Intel® Q965 Graphics and Memory Controller Hub integrated Intel Graphics
Media Accelerator 3000 (Intel GMA 3000), provides a visually stunning
experience optimized for Blu-ray and HD video
- Supports dual independent display with ADD2/+ card
Display Interface
- VGA: Resolution up to 2048x1536 @75Hz
- DVI-D: up to 1600x1200 @60Hz
PACKING LIST
One RUBY-9716VGAR ATX Industrial Main Board
One SATA II Cable
One Installation CD
One I/O shield
One IDE cable
Mechanical & Environment
Dimension
304.8(L) x 243.8(W)mm; 12"(L) x 9.6"(W)
Power Supply
- Typical: [email protected]; [email protected]; [email protected]
- Supports ATX mode
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 90%, non-condensing
MTBF
Over 100,000 hours at 40°C
Giga
DDR 2
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
Giga LAN
IMB-RUBY-9716VGAR
52
About Chassis
FLEXIBLE AND UNIQUE
At Portwell, we take care of our customers’ needs. Portwell has pledged to remain customer centric -- even amid the
relative challenges of the rack-mount chassis market. Unlike most chassis suppliers, whose focus is cost-down, our priority
LVTXDOLW\DQGWKLVLVUHÀHFWHGLQWKHFRQFHSWVRIRXUQHZO\GHYHORSHGFKDVVLVGHVLJQV
1. NEW INDUSTRIAL DESIGN (ID)
2XU QHZ LQGXVWULDO GHVLJQ LV GH¿QLWHO\ DQ H\HFDWFKHU DQG WKH FKDVVLV KDV OLQHV WKDW PDNH LW HDV\ WR ZRUN ZLWK :H
have invested heavily in our industrial design. Consequently, our rack-mount chassis is not just attractive, it is also built
practically. This enhances the product outlook and strengthens the unity of our customers’ systems.
2. ADVANCED FUNCTIONALITY INSIDE
6LQFH WKH\ ¿UVW HYROYHG IURP WKH 3& WKH JURZLQJ QHZ WHFKQRORJLHV KDYH FKDQJHG WKH DSSOLFDWLRQV RI WKH UDFNPRXQW
chassis tremendously. New devices, such as USB and IEEE1394, have been completely adopted in the market. The
advanced functionality inside of a Portwell chassis is consistently updated in order to meet changing trends, and assures
Portwell of a position as a market leader.
3. MODULIZED DESIGN TO ENABLE SYSTEM DIFFERENTIATION AND SUITABILITY FOR
FUTURE DEMANDS
The modularized, state-of-the-art design of our chassis enables Portwell to meet system differentiation and the suitability
for future demands. At Portwell, we understand that our rack-mount chassis are not for use by application controllers alone.
They could also be fault-tolerant systems. Therefore, some hot-swappable devices, such as Mirror or RAID disks, might be
integrated into the system. Portwell keeps an eye on future demands to build the capability inside the chassis to work with
your system now and in the future.
&RQWDFW\RXUORFDO3RUWZHOORI¿FHIRUPRUHLQIRUPDWLRQRQWKHVWDWHRIWKHDUWGHVLJQRIDOO
new Portwell chassis
-The First Priority for Customers
Advanced
Ruggedized
Enhanced
Modulized
Optimized
PORTWELL HQJLQHHUVFXVWRPPDNHSURGXFWVIRUFXVWRPHUVTXLFNO\DQGHI¿FLHQWO\
Our Expertise:
„Experienced
and well-trained design team.
„,QWHJUDWLRQRI,QGXVWULDO'HVLJQ,'ÀH[LELOLW\DQGIXQFWLRQDOLW\
„)DVWVDPSOHRIIHULQJIRUFXVWRPHUFODVVL¿FDWLRQDQGDSSURYDO
„Collaborative
design with customers.
„Fast response to customers’ urgent demands:
Concept Design (3D): 2 working days
Mechanical Design: 5 working days
Samples Building: 14 working days
An outstanding chassis for all your needs.
53
About Chassis
RPC-500NC/L
FEATURES
19” 4U industrial rack-mount chassis
GENERAL
Construction
Heavy-duty steel with aluminum front panel
Drive Bay
External: 5.25” x3, 3.5” FDD x1
Internal: 3.5” HDD x1
„
5.25” x3 + 3.5” x2 drive bays for RAID 0, 1, 5 &
CD-ROM
„
Two ball-bearing cooling fans for better
ventilation
Card Retainer
Two locations for one card retainer
Air Filter
2QHUHSODFHDEOH¿OWHU
„
Traditional rack-mount handles
Cooling Fan
One 12cm and one 8cm ball-bearing cooling fans
„
Two card retainer positions
Indicator
Power on/off x1, HDD x1
„
Two USB ports on the control panel
Switch
Power on/off x1, System reset x1, K/B lock x1
One PS/2 K/B connector cap included
Connector
2 USB ports on the front panel
Standard Color
Beige, Black
Dimension
RPC-500NC: 482(W) x 450(D) x 177(H) mm; 19”(W) x 17.7”(D) x 7”(H)
RPC-500L: 482(W) x 515(D) x 177(H) mm; 19”(W) x 20.3”(D) x 7”(H)
M/B applicable, especially for big-AT sized
M/B (RPC-500L)
Weight
RPC-500NC: Net: 14 kg (30.9 lb); Gross: 15 kg (33.1 lb)
RPC-500L: Net: 17.5 kg (38.6 lb); Gross: 18.5 kg (40.8 lb)
PS/2 reduncant power supply installable
Backplane
PBP-14I: 14-slot ISA backplane
PBP-14AC: 14-slot (12xPCI) active PICMG backplane
PBP-14A7: 14-slot (7xPCI) active PICMG backplane
PBP-14P4: 14-slot (4xPCI) PICMG backplane
PBP-13D4: 13-slot dual-system PICMG backplane
„
„
One modularized function panel for single
(default) and dual (optional) systems
„ ATX
„
ORION-D3501P optional
POWER SUPPLY
RPC-500NC/L
Except the rack-mount handle, RPC-500N is
the same as RPC-500NC. It’s the best selling
4U rack-mount chassis for CTI, industrial, sciHQWL¿FHQJLQHHULQJDQGVHUYHUDSSOLFDWLRQV
ORDERING GUIDE
„RPC-500NC
19” 4U rack-mount chassis for PICMG backplane
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
„RPC-500NC-MX
19” 4U rack-mount chassis for ATX M/B
„RPC-500L
19” 4U rack-mount chassis for PICMG backplane
(Long size)
„RPC-500L-MX
19” 4U rack-mount chassis for server board
(Long size)
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
0 to +70°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-RPC-500NC/L
54
RPC-500NC/L
FEATURE
„A lockable
19” 4U industrial rack-mount chassis
BENEFITS
front door with thumb lock
„One
power on/off switch with LED indicator, one reset and one K/B
lock switches inside the lockable door
„Good
for dust-proof & Running status visible
„Avoid
accidental reset for better running security
„)URQWUHSODFHDEOHDLU¿OWHU
„For
installing dual systems and redundant power supplies more easily
„Two
USB ports on the front panel
„For
easy access
„One
PS/2 K/B connector on the front panel
„Convenient
„One
K/B connector cap
„Good
for dust-proof for the front accessible K/B connector
„Two
ball-bearing cooling fans
„Better
ventilation to provide the system with higher reliability
„Enhanced
drive bracket to hold 3 x 5.25” + 1 x 3.5” (external) and
1 x 3.5” drives (internal)
„Shock-resistant
„Two
cushion for the drive bracket
adjustable positions for hold-down card retainers
„Changeable
modularized back panel for 14-slot ISA/PICMG
backplane or ATX M/B
„Field
replaceable power supply bracket for both normal PS/2 power
supply and PS/2 type redundant power supply
to connect to the keyboard
„)RULQWHJUDWLQJYDULHGV\VWHPVZLWKKLJKHUÀH[LELOLW\
„Suitable
for installing RAID and CD-ROM drive
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Only
„Easy
„Only
„Only
one minutes to change the back panel
to change to different backplanes and keep stock
three minutes to change defective power supply
30 seconds to change the defective PSU module
ENGINEERING DRAWING
Unit: mm
55
Chassis-RPC-500NC/L
AREMO-4196
FEATURES
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
GENERAL
Construction
Heavy-duty steel with aluminum front panel
Drive Bay
Internal: 5.25” x3, 3.5” HDD x1
Internal: 3.5” x2
„
Three 5.25” and one external 3.5” HDD drive
bays for RAID 0, 1, 5 & CD-ROM
„
Two USB ports on the front panel
Card Retainer
Three locations for one card retainer
„
Dual 12cm ball-bearing cooling fans for better
ventilation
Air Filter
7ZRUHSODFHDEOHDLU¿OWHU
Cooling Fan
Two 12cm ball-bearing cooling fans
„
Two card retainer positions
Indicator
Power on/off x1, HDD x1
„
PS/2 or redundant power supply installable
Switch
Power on/off x1, System reset x1
M/B applicable, especially for big-ATX
size M/B
Speaker
One 8K speaker
Connector
Two USB ports on the front panel
(DVLO\GHWDFKHGDQGZDVKDEOHDLU¿OWHU
Standard Color
Silver, Black
Equipped with fan control card to detect fan
failure
Dimension
482(W) x 481(D) x 177(H) mm; 19”(W) x 18.1”(D) x 7”(H)
Weight
Net: 13.5 kg (29.8 lb); Gross: 14.5 kg (32 lb)
Backplane
PBP-14I: 14-slot ISA backplane
PBP-14AC: 14-slot (12xPCI) active PICMG backplane
PBP-14A7: 14-slot (7xPCI) active PICMG backplane
PBP-14P4: 14-slot (4xPCI) PICMG backplane
PBP-13D4: 13-slot dual-system PICMG backplane
„ ATX
„
„
ORDERING GUIDE
„AREMO-4196
19” 4U rack-mount chassis for PICMG version
„AREMO-4196-MX
19” 4U rack-mount chassis for M/B version
„AREMO-4196-MX-D3501P
19” 4U rack-mount chassis for ATX motherboard
with active 350W ATX, Active PFC power supply
„AREMO-4196-00-D3501P
19” 4U rack-mount chassis for PICMG version and
350w ATX, Active PFC power supply Hot Swap
SA/A Mobil Rack
Note: 3-in-2 mobile rack Drive is optional
ORION-D3501P optional
POWER SUPPLY
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-4196
56
AREMO-4196
FEATURE
BENEFITS
„A lockable
front door with thumb lock
„One
power on/off switch and one system reset botton on the
front panel behind the lockable door
„Fan
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
control board
„Good
for dust-proof & security
„Avoid
accidental reset for better running security
„Detect
fan fail and Alarm
„)URQWUHSODFHDEOHDLU¿OWHU
„For
„Equipped
„(I¿FLHQW$FFHVV
„Dual
two USB ports
12cm ball-bearing cooling fans
„Better
„Enhanced
drive bracket to hold three 5.25” and two 3.5” HDD
drives (internal)
„Shock-resistant
„Two
cushion for the drive bracket
adjustable positions for hold-down card retainers
„Changeable
modularized back panel for 14-slot ISA/PICMG
backplane or ATX motherboard
„Field
easy cleaning and install
replaceable power supply bracket for both normal PS/2 power
supply and PS/2 type redundant power supply
ventilation to provide the system with higher reliability
„)RULQWHJUDWLQJYDULHGV\VWHPVZLWKKLJKHUÀH[LELOLW\
„Suitable
for installing RAID and CD-ROM drive
„Suitable
for harsh industrial environment
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Only
„
one minute to change the back panel
Easy to change to different backplanes and keep stock
„Only
„Only
three minutes to change the defective power supply
thirty seconds to change the defective PSU module
WHAT’S NEW
57
PCI based RAID kits, supporting up to three SATA
HDDs with RAID 0, 1, 5 selections. The Disk bus is
E-IDE with Ultra DMA support. The RAID kits provide
a GUI manager for installation and maintenance. Hotswap and hot-spare capabilities are also supported.
Friendly design of handles, you can lift and
unstall AREMO-4196 comfortably and easily.
Power switch, RESET switch, HDD / Power
/ Fan-fail / LAN LEDs and two USB 2.0 ports
are on the front panel.
Flexible design to install power supply, the
bracket can be adapt to PS/2 type or miniredundant power supply.
AREMO-4196 enhances the drive bracket to
integrate up to three 5.25” and one 3.5” disk drives
within a limited space. (extra two 3.5” HDD drives
for AREMO-4196-MX)
Equipped with dual 12cm ball bearing fans,
AREMO-4196 provides the best ventilation up
to 208CFM to expire heat from the system.
AREMO-4196 adopts the newly designed
card retainer to hold both the PCI and ISA
type add-on-cards more tightly.
AREMO-4196 is equipped with two USB 2.0
connectors on the front panel to have a better
security control.
7KHZDVKDEOHIDQ¿OWHUFDQEHHDVLO\WDNHQ
off to make an easier maintenance.
LED indicators include power, HDD, Fan-fail
and LAN functions.
The thumb lock offers easy operation. Users
can choose to lock it or not.
7KHZDVKDEOHIDQ¿OWHUFDQEHHDVLO\WDNHQ
out for easier maintenance.
Chassis-AREMO-4196
AREMO-4196
AREMO-4196
The Best Cost-Performance 19” 4U
Height Pentium® 4 Processor Based
Rack-mount Computer
AREMO-4196-MX
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-4196
58
AREMO-3194
FEATURES
19” 3U rack-mount chassis for
ATX M/B platform
GENERAL
IEEE 1394 port and two USB ports on the
front panel
Construction
Heavy-duty steel
Drive Bay
External: 5.25”x2+3.5”x1; Internal: 3.5”x1
Dedicated cooling fans for expiring the heat
on the hot spots within the chassis
Air Filter
7ZRUHSODFHDEOHDLU¿OWHUVDWWKHIURQW
Cooling Fan
Two 8 cm ball-bearing cooling fans
'XVWSURRIIURQWDFFHVVDLU¿OWHUIRUHDV\
cleaning and replacing
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
„
Lockable front door provides greater security
Speaker
One 8K speaker
„
Thumb lock for greater security and to operate
system more easily
Connector
Two USB ports and 1 IEEE 1394 port on the front panel
Standard Color
Silver, Black
Dimension
481.6(W) x 487.8(D) x 132.6(H) mm ; 19”(W) x 19.2”(D) x 5.22”(H)
Weight
Net: 16 kg (35.3 lb) ; Gross: 18 kg (39.7 lb)
M/B
Micro-ATX, ATX
„
„
„
ORDERING GUIDE
„AREMO-3194-MX-B3501P
19” 3U rack-mount chassis with 2U 350W ATX,
W/active PFC power supply for ATX M/B
„AREMO-3194E-MX-D3501P
19” 3U rack-mount chassis with PS/2 350W ATX,
with active PFC power supply for ATX M/B
ORION-B3501P optional
POWER SUPPLY
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
Holdup Time
16 ms. at full load
Over Voltage Protection
+3.3V:4.5V; +5V:6.5V; 12V:14.5V
Over Power/Load Protection
Output power over 110%~150%
MTBF
100,000 hrs
EMI & Safety Approval
UL, cUL, TUV, CCC, CB, CE, FCC, BSMI
Temperature/Humidity
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
Dimension (WxDxH)
100x200x70 mm; 3.94”x8.3”x2.8”
ENVIRONMENT
59
Chassis-AREMO-3194
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-3194
19” 3U rack-mount chassis for
ATX M/B platform
FEATURE
BENEFITS
„350W
„6XI¿FLHQWSRZHUVRXUFHIRU,QWHO®
Active PFC power sopply
„Cooling
„More
„Two
tunnel design
„Better
expansion slots
„Support
USB and one IEEE 1394 ports on the front panel
„Lockable
front door
„)URQWUHSODFHDEOHDLU¿OWHUV
„Easy
up to six expansion and one AGP slots for higher expansibility
to operate the system
„Provide
„For
Pentium® 4 processor
ventilation to enhance system reliability
better security
easy cleaning
WHAT’S NEW
Excellent In-System Cooling
PCI and AGP Expansion
Front Replaceable Air Filters
Two 8cm ball-bearing fans provide better
YHQWLODWLRQDQGNHHSVPRRWKDLUÀRZ
Six PCI and one AGP expansion slots for
adding more functions to the system
&RQYHQLHQWWRFKDQJHDLU¿OWHUV
when needed
Lockable Front Door and
Thumb Lock
Protection Cap and Touch-Free
Reset Switch
Excellent Cooling System
Provide better security and operate the
system more easily
Avoid abnormal operation and increase
system reliability
New slot cover and air holes for
better ventilation
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-3194
60
AREMO-2173P
FEATURES
19” 2U industrial rack-mount chassis
for PICMG backplane
GENERAL
One slim CD-ROM and two hot-swap 3.5”
HDD (SATA) Drive bays
Construction
Heavy-duty steel
Drive Bay
External: Slim type CD-ROM x1, Hot-swap 3.5” HDD x2
„
Two USB ports on the front panel
Air Filter
2QHH[WHUQDOUHSODFHDEOHDLU¿OWHU
„
Two 7cm ball-bearing cooling fans for
better ventilation
Cooling Fan
Two 7cm ball-bearing fans
Indicator
HDD x1+ Power on/off x1
One power On/Off switch with protection cap
and one touch free reset for secure access
Switch
Power on/off (with a protection cap) x1, System reset x1
Speaker
One 8K speaker
Connector
Two USB ports equipped on the front panel
Standard Color
Silver, Black
Dimension
482(W) x 429.2(D) x 88.6(H) mm; 19”(W) x 16.9”(D) x 3.5”(H)
Weight
Net: 11.0 kg (23.1 lb); Gross: 12.0 kg (25.3 lb)
„
„
ORDERING GUIDE
„AREMO-2173P-06V4-D3501P
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane and 350W ATX, active
PFC power supply
„AREMO-2173P-06V4
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane
„AREMO-2173P-06V4-3502P
19” 2U rack-mount chassis with vertical 6-slot (4x
PCI) PICMG backplane and 350W active PFC
redundant power supply
ORION-D3501P optional
POWER SUPPLY
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
61
Chassis-AREMO-2173P
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-2173P
19” 2U industrial rack-mount chassis
for PICMG backplane
FEATURE
BENEFITS
„350W
„6XI¿FLHQWSRZHUVRXUFHIRU,QWHO®
Active PFC power supply
„Two
7cm high speed fans
„Better
„Two
swappable SATA HDD drive bays
„Easy
„)RXU/RZSUR¿OH3&,H[SDQVLRQVORWV
„For
„)URQWUHSODFHDEOHDLU¿OWHUV
„Easy
Pentium® 4 processor
ventilation to enhance system reliability
to access HDD drives
system function expansion
cleaning
WHAT’S NEW
Thumb Lock
Two Swappable SATA HDD Drives
Front Replaceable Air Filters/Fans
Convenient to operate or protect the system
Easy to access HDD drives
&RQYHQLHQWWRFKDQJHDLU¿OWHUVRUIDQVZKHQ
needed
Rear View
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-2173P
62
AREMO-2173MX
FEATURES
19” 2U industrial rack-mount
chassis for Micro-ATX or miniITX mother board
GENERAL
One slim CD-ROM and two hot-swap 3.5”
HDD (SATA) Drive bays
Construction
Heavy-duty steel
Drive Bay
External: Slim type CD-ROM x1, Hot-swap 3.5” HDD x2
„
Two USB ports on the front panel
Air Filter
2QHH[WHUQDOUHSODFHDEOHDLU¿OWHU
„
Two 7cm ball-bearing cooling fans for
better ventilation
Cooling Fan
Two 7cm ball-bearing fans
Indicator
HDD x1+ Power on/off x1
One power On/Off switch with protection cap
and one touch free reset for secure access
Switch
Power on/off (with a protection cap) x1, System reset x1
Speaker
One 8K speaker
Connector
Two USB ports equipped on the front panel
Standard Color
Silver, Black
Dimension
482(W) x 429.2(D) x 88.6(H) mm; 19”(W) x 16.9”(D) x 3.5”(H)
Weight
Net: 11.0 kg (23.1 lb); Gross: 12.0 kg (25.3 lb)
„
„
ORDERING GUIDE
„AREMO-2173MX-D3501P
19” 2U rack-mount chassis for micro-ATX or miniITX M/B with 350W ATX, active PFC power
supply
„AREMO-2173MX
19” 2U rack-mount chassis for micro-ATX or miniITX M/B
„AREMO-2173MX-3502P
19” 2U rack-mount chassis for micro-ATX or miniITX M/B and 350W active PFC redundant power
supply
ORION-D3501P optional
POWER SUPPLY
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
63
Chassis-AREMO-2173MX
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-2173MX
19” 2U industrial rack-mount
chassis for Micro-ATX or miniITX mother board
FEATURE
BENEFITS
„350W
„6XI¿FLHQWSRZHUVRXUFHIRU,QWHO®
Active PFC power supply
„Two
7cm high speed fans
„Better
„Two
swappable SATA HDD drive bays
„Easy
„)RXU/RZSUR¿OH3&,H[SDQVLRQVORWV
„For
„)URQWUHSODFHDEOHDLU¿OWHUV
„Easy
Pentium® 4 processor
ventilation to enhance system reliability
to access HDD drives
system function expansion
cleaning
WHAT’S NEW
Thumb Lock
Two Swappable SATA HDD Drives
Front Replaceable Air Filters/Fans
Convenient to operate or protect the system
Easy to access HDD drives
&RQYHQLHQWWRFKDQJHDLU¿OWHUVRUIDQVZKHQ
needed
Rear View
ENGINEERING DRAWING
Unit: mm
Chassis-AREMO-2173MX
64
PRC-1194
FEATURES
„
Single power supply with higher +12V output
for Pentium® 4 processor
„
Cooling tunnel design for expiring heat
generated by CPU
„
„
19" 1U Height industrial rack-mount P4
chasis
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: NB CD-ROM x1 (or equivalent CD-RW / DVD-ROM) + NB FDD x1
Internal: 3.5” HDD x2
Air Filter
N/A
Power cable routed beneath the cooling tunnel
to avoid disturbance of air path
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
Two PCI expansion slots for adding more
functions to system
Switch
Power on/off x1, System reset x1
Speaker
N/A
Connector
Two USB connectors on the front panel, reserved one COM port cutout
Standard Color
Black
Dimension
481(W) x 429(D) x 44(H) mm; 19”(W) x 18.7”(D) x 1.7”(H)
Weight
Net: 10 kg (22.05 lb); Gross: 13 kg (28.67 lb)
Backplane
PBP-03P2X: 3-slot (2xPCI) PICMG backplane
ORION-A2501 optional
POWER SUPPLY
ORDERING GUIDE
„PRC-1194-03P2X-2501
19” 1U rack-mount chassis with 3-slot (2xPCI)
PICMG backplane and 250W PFC power supply
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 65%
Holdup Time
16 ms. at full load @25oC
Over Voltage Protection
[email protected]~6.5A; [email protected]~4.4V; [email protected]~15.6V
Over Power/Load Protection
Output power over to 110%~160%
MTBF
105,405 hrs
EMI & Safety Approval
UL, cUL, TVU, CE, FCC
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -20 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
100x190x40.5 mm; 5.9”x5.5”x3.4”
ENVIRONMENT
65
Chassis-PRC-1194
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
AREMO-6163
FEATURES
„
„
One external 5.25” and two internal 3.5” HDD
drive bays
Two USB ports on the front panel
Internal: 3.5” HDD x2
2QHUHSODFHDEOHDLU¿OWHUDWWKHIURQWGRRU
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
Speaker
One 8K speaker
Connector
Two USB ports on the front panel
Standard Color
Silver, Black
Wall-mounting bracket equipped
Dimension
260(W) x 420.5(D) x 172(H) mm; 10.24”(W) x 16.56”(D) x 6.77”(H)
Both 6-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Weight
Net: 8.5 kg (18.7 lb); Gross: 9.5 kg (20.9 lb)
Backplane
PBP-06I: 6-slot ISA bus PICMG backplane
PBP-06P4: 6-slot (4xPCI) PICMG backplane
PBP-06P3: 6-slot (3xPCI) PICMG backplane
One 12cm ball-bearing cooling fan for
better ventilation
„
2QHUHSODFHDEOHDLU¿OWHUIRUHDV\FOHDQLQJ
„
External: 5.25” x1
Two locations for one card retainer
„
„
Heavy-duty steel
Drive Bay
Air Filter
Can be vertically or horizontally mounted,
HDV\WR¿WLQWRVSDFHOLPLWHGHQYLURQPHQW
„
GENERAL
Construction
Card Retainer
„
„
6-slot full-size industrial node
chassis (Shoe-box)
Two adjustable positions for hold-down card
retainers provide better protection from
vibration
Field replaceable power supply bracket for
both normal PS/2 and PS/2 redundant
power supply, easy for changing defected
power supply
ORDERING GUIDE
„AREMO-6163-06P3-D3501P
6-slot full-size industrial node chassis with
6-slot (3xPCI) PICMG backplane and 350W
active PFC ATX power supply
„AREMO-6163-06P4-D3501P
6-slot full-size industrial node chassis with
6-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
ORION-D3501P optional
POWER SUPPLY
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-6163
66
AREMO-6163
FEATURE
BENEFITS
„5.25”
„Easy
to install software
„Easy
to operate the system
„Two
drive space for CD-ROM or mobile rack
USB ports at the front
„2QHUHSODFHDEOHDLU¿OWHU
6-slot full-size industrial node
chassis (Shoe-box)
„Easy
„Two
cleaning
USB ports equipped
„Can
be vertically or horizontally mounted
„(DV\WR¿WLQWRGLIIHUHQWVSDFHOLPLWHGHQYLURQPHQWV
„Two
adjustable positions for hold-down card retainer
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Both
6-slot ISA and PICMG backplane applicable
„Easy
to change to different backplane and keep in stock
„Easy
maintenance
„Field
replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
WHAT’S NEW
Two Adjustable Card Retainer Positions
Plastic Fan Filter
New HDD Drive Design
)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
For easy cleaning and replace
Easy to install HDD drives
ENGINEERING DRAWING
Unit: mm
67
Chassis-AREMO-6163
AREMO-8164
FEATURES
8-slot full-size industrial node
chassis (Shoe-box)
GENERAL
Two 5.25” and two internal 3.5” HDD drive
bays for CD-ROM or mobile rack, easy to
install software and mirror disk (RAID1)
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x2
Two USB ports on the front panel
Card Retainer
Two locations for one card retainer
Air Filter
2QHUHSODFHDEOHDLU¿OWHUDWWKHIURQWGRRU
Cooling Fan
One 12cm ball-bearing fan
One 12cm ball-bearing cooling fan for
better ventilation
Indicator
Power on/off x1, HDD x1
Switch
Power on/off x1, System reset x1
„
2QHUHSODFHDEOHDLU¿OWHUIRUHDV\FOHDQLQJ
Speaker
One 8K speaker
„
Two adjustable positions for hold-down
card retainers provide better protection
from vibration
Connector
2 USB ports on the front panel
Standard Color
Silver, Black
Dimension
330(W) x 420.8(D) x 172(H) mm; 12.99”(W) x 16.56”(D) x 6.77”(H)
„
Wall-mounting bracket equipped
Weight
Net: 10 kg (22.1 lb); Gross: 9.5 kg (20.9 lb)
„
Both 8-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Backplane
PBP-08I: 8-slot ISA backplane
PBP-08P4: 8-slot (4xPCI) PICMG backplane
PBP-08P3 : 8-slot (3xPCI) PICMG backplane
„
Field replaceable power supply bracket for
both normal PS/2 and PS/2 redundant
power supply, easy for changing defected
power supply
„
„
Can be vertically or horizontally mounted,
HDV\WR¿WLQWRVSDFHOLPLWHGHQYLURQPHQW
„
„
ORDERING GUIDE
„AREMO-8164
8-slot full-size industrial node chassis
„AREMO-8164-08P4-00
8-slot full-size industrial node chassis with
8-slot (4xPCI) PICMG backplane
Internal: 3.5” HDD x2
ORION-D3501P optional
POWER SUPPLY
Maximum output
350W active PFC
Output Voltage & Current
[email protected]; [email protected]; [email protected]; [email protected], [email protected], [email protected]
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 68%
MTBF
75,145 hrs
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
Dimension (WxDxH)
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
„AREMO-8164-08P4-D3501P
8-slot full-size industrial node chassis with
8-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-8164
68
AREMO-8164
8-slot full-size industrial node chassis
(Shoe-box)
FEATURE
BENEFITS
„5.25”
„Easy
to install software and mirror disk (RAID 1)
„Easy
to operate the system
„2QHUHSODFHDEOHDLU¿OWHU
„Easy
cleaning
„Can
be vertically or horizontally mounted
„(DV\WR¿WLQWRGLIIHUHQWVSDFHOLPLWHGHQYLURQPHQWV
„Two
adjustable positions for hold-down card retainer
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Both
8-slot ISA and PICMG backplane applicable
„Easy
to change to different backplane and keep in stock
„Easy
maintenance
„Two
drive bays for CD-ROM or mobile rack
USB ports on the front panel
„Field
replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
WHAT’S NEW
Two Adjustable Card Retainer Positions
Plastic Fan Filter
Excellent Cooling System
)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
For easy cleaning and replacing
New slot cover for better ventilation
ENGINEERING DRAWING
Unit: mm
69
Chassis-AREMO-8164
19" 4U Height rack-mount
chassis with dual AREMO-6182
node chassis
AREMO-4184
FEATURES
GENERAL
Construction
Heavy-duty steel
External: 5.25” x1 *
„
Magic design for wall-mount, desk-top and
rack-mount application
Drive Bay
„
Ruggedized steel node chassis suitable for
harsh environment
Card Retainer
Two locations for one card retainer *
Air Filter
2QHUHSODFHDEOHDLU¿OWHUDWWKHIURQWGRRU
„
One built-in 12cm ball-bearing fan for better
ventilation
Cooling Fan
One 12cm ball-bearing fan *
Indicator
Power on/off x1, HDD x1 *
Internal: 3.5” x1 *
„
Built-in 1U ATX type power supply
Switch
Power on/off (with a protection cap) x1, System reset x1 *
„
Support one external 5.25” and one internal
3.5” disk drive
Speaker
One 8K speaker *
2 USB ports *
„
Optional one external 5.25” and one internal
3.5” disk drive
Connector
Standard Color
Black, Silver
Optional kit to combine two AREMO-6182 for
the rack-mount application, AREMO-4184
Dimension
AREMO-4184: 482(W) x 448(D) x 177(H) mm; 19”(W) x 17.6”(D) x 7”(H)
„
Weight
AREMO-6182: Net: 6.5 kg (14.3 lb); Gross: 8.0 kg (17.6 lb)
AREMO-4184: Net: 15.5 kg (34.2 lb); Gross: 17.5 kg (38.6 lb)
Backplane
PBP-06P3: 6-slot (3xPCI) PICMG backplane
PBP-06P4: 6-slot (4xPCI) PICMG backplane
PBP-06I: 6-slot (6xISA) PICMG backplane
* each system
FSP350-601UA optional
POWER SUPPLY
AREMO-6182
ORDERING GUIDE
„AREMO-4184-06P3-350X
Two sets of AREMO-6182 with rack-mount kit,
6-slot (3xPCI) PICMG backplane and 350W
1U ATX, active PFC power supply
„AREMO-6182-06P3-350X
6-slot node chassis with 6-slot (3xPCI) PICMG
backplane and 350W 1U ATX, active PFC power
supply
Input Voltage
90V ~ 135V, 180V ~ 265V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 70%
Holdup Time
18m Sec
Over Voltage Protection
+3.3V: 4.5V; +5V: 6.5V; +12V: 15.6V
Over Power/Load Protection
+3.3V: 45A; +5V: 45A; +12V: 20A
MTBF
100,000 hrs
EMI & Safety Approval
UL, CSA, VDE, FCC, CE, NEMKO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 80%RH
Storage: -40 ~ 70°C, 10 ~ 90%RH
Dimension (WxDxH)
100x190x40 mm; 3.9”x7.5”x1.6”
ENVIRONMENT
Operating Temperature Range
0 to +50°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-4184
70
AREMO-4184
FEATURE
BENEFITS
„One
„For
5.25” drive bay for EZDRV
19" 4U Height rack-mount
chassis with dual AREMO-6182
node chassis
both CD-ROM and FDD support or Hot-swappable HDD
„)URQWUHSODFHDEOHDLU¿OWHU
„Easy
„Two
adjustable positions for hold-down card retainer
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Both
6-slot ISA and PICMG backplane applicable
„Easy
to change to different backplane and keep in stock
„Save
the space inside the chassis
„1U
350W ATX power supply
„Special
kit to combine dual systems into 4U space
„Can
cleaning & replacing
be integrated as a fault tolerant system
WHAT’S NEW
6SHFLDO&RQ¿JXUDWLRQZLWK(='59
Easy to Mount
Two become One
AREMO-6182 adopts EZDRV-300NCF or mobile rack
for 3.5” HDD
AREMO-6182 can be easily mounted on the
supporter
Combine two AREMO-6182 as a dual
system 4U chassis
ENGINEERING DRAWING
Unit: mm
71
Chassis-AREMO-4184
AREMO-6182
FEATURES
„
„
One external 5.25” and one internal HDD
drive bay
2QHUHSODFHDEOHDLU¿OWHUIRUHDV\FOHDQLQJ
Can be vertically or horizontally mounted,
HDV\WR¿WLQWRVSDFHOLPLWHGHQYLURQPHQW
„
6-slot full-size industrial
node chassis (Shoe-box)
GENERAL
Construction
Heavy-duty steel
Drive Bay
External: 5.25” x1
Internal: 3.5” HDD x1
Card Retainer
Two locations for one card retainer
Air Filter
2QHUHSODFHDEOHDLU¿OWHUDWWKHIURQWGRRU
Cooling Fan
One 12cm ball-bearing fan
Indicator
Power on/off x1, HDD x1
„
One 12cm ball-bearing cooling fan for
better ventilation
„
7KHIDQ¿OWHUSDQHOFDQEHLQVWDOOHGLQ
different directions
Switch
Power on/off x1, System reset x1
Speaker
One 8K speaker
Two adjustable positions for hold-down
card retainers provide better protection
from vibration
Connector
2 USB ports
Standard Color
Black, Silver
Dimension
219(W) x 448(D) x 160(H) mm; 8.6”(W) x 17.6”(D) x 6.3”(H)
„
Wall-mounting bracket equipped
Weight
Net: 6.5 kg (14.3 lb); Gross: 8.0 kg (17.6 lb)
„
Both 6-slot ISA and PICMG 1.0 or 1.3
backplane applicable; easy to change
different backplanes
Backplane
PBP-06P3: 6-slot (3xPCI) PICMG backplane
PBP-06P4: 6-slot (4xPCI) PICMG backplane
PBP-06I: 6-slot (6xISA) PICMG backplane
„
FSP350-601UA optional
POWER SUPPLY
ORDERING GUIDE
„AREMO-6182-06P3-350X
6-slot full-size industrial node chassis with
6-slot (3xPCI) PICMG backplane and 1U 350W ATX,
Active PFC power supply
„AREMO-6182-06P4-350X
6-slot full-size industrial node chassis with
6-slot (4xPCI) PICMG backplane and 350W
active PFC ATX power supply
Input Voltage
90V ~ 135V, 180V ~ 265V AC
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
> 70%
Holdup Time
18m Sec
Over Voltage Protection
+3.3V: 4.5V; +5V: 6.5V; +12V: 15.6V
Over Power/Load Protection
+3.3V: 45A; +5V: 45A; +12V: 20A
MTBF
100,000 hrs
EMI & Safety Approval
UL, CSA, VDE, FCC, CE, NEMKO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 80%RH
Storage: -40 ~ 70°C, 10 ~ 90%RH
Dimension (WxDxH)
100x190x40 mm; 3.9”x7.5”x1.6”
ENVIRONMENT
Operating Temperature Range
0 to +50°C
Storage Temperature Range
-20 to +80°C
Relative Humidity
5% to 95%, non-condensing
Vibration
5~7 Hz: 0.5” double amplitude displacement
7~2000 Hz: 1.5g acceleration
Chassis-AREMO-6182
72
AREMO-6182
6-slot full-size industrial
node chassis (Shoe-box)
FEATURE
BENEFITS
„One
„For
both CD-ROM and FDD support or Hot-swappable HDD
„2QHUHSODFHDEOHDLU¿OWHU
„For
easy cleaning
„Can
be vertically or horizontally mounted
„(DV\WR¿WLQWRGLIIHUHQWVSDFHOLPLWHGHQYLURQPHQW
„Two
adjustable positions for hold-down card retainer
„)RU¿[LQJDOOWKHFDUGVPRUHÀH[LEO\DQGWLJKWO\
„Both
6-slot ISA and PICMG backplane applicable
„Easy
5.25” drive bay for EZDRV
„Field
replaceable power supply bracket for both normal PS/2
power supply and PS/2 type redundant power supply
„Removable
fan kit
„For
to change to different backplane and keep stock
ease of maintenance
„Easy
to replace the broken fan
WHAT’S NEW
Plastic Fan Filter
Can be Mounted in Different Styles
Dual Card Retainers
For easy cleaning and replacing
AREMO-6182 can be either vertically or
horizontally installed
It has two positions for card clamps to
hold both PCI and ISA cards tightly
ENGINEERING DRAWING
Unit: mm
73
Chassis-AREMO-6182
EZDRV-400
5.25" compact drive set with slim type
DVD-ROM, SD/CF card reader, 2 USB
ports and space for 2.5" HDD
External: 1xslim type DVD-ROM
SD Reader and 2 USB ports
Internal: 1xNB 2.5” HDD
CF Reader and LED for HDD
FEATURES
GENERAL
drive set can hold:
- one slim type DVD-ROM
- SD card reader
- CF card reader
- 2 USB ports
- 2.5” HDD (internal)
Construction
Heavy-duty steel with plastic front cover
Drive Bay
-External: Slim type DVD-ROM x1 + 2-in-1 reader + USB ports x2
One LED for internal HDD
„ All-in-one
„
ORDERING GUIDE
„(='59'5
5.25” compact drive bracket with slim type DVDROM, SD/CF reader, 2 USB ports and space for
2.5” HDD
-Internal: NB 2.5” HDD x1
Indicator
HDD x1
Standard Color
Black
Dimension
149(W) x 185(D) x 43(H) mm; 5.9”(W) x 7.3”(D) x 1.7”(H)
Weight
Net: 0.9 kg (2 lb); Gross: 1.3 kg (2.9 lb)
ENVIRONMENT
Operating Temperature Range
0 to +55°C
Storage Temperature Range
0 to +70°C
Relative Humidity
5% to 95%, non-condensing
„(='59'5:
5.25” compact drive bracket with slim type DVDRW, SD/CF reader, 2 USB ports and space for
2.5” HDD
Chassis-EZDRV-400
74
Chassis Reference Table
AREMO-4196
AREMO-3194
AREMO-2173P
RPC-500NC/L
TYPE
SLOT
MODEL
ORDERING
INFO
Model Name
ISA
PCI/PCI-X
PICMG
4U
14-slot
RPC-500NC
RPC-500NC-14P4-3501P
PBP-14P4
9
4
1
4U
ATX M/B
RPC-500NC-MX
RPC-500NC-MX-D3501P
--
--
7
--
14-slot
AREMO-4196
AREMO-4196-14P4-D3501P
PBP-14P4
9
4
1
ATX M/B
AREMO-4196-MX
AREMO-4196-MX-D3501P
--
--
7
--
AREMO-3194-MX-350X
--
--
7
--
AREMO-3194E-BX-D3501P
--
--
7
--
PBP-06V4
1
4
1
--
--
4
--
RPC-1194-03P2X-2501
PBP-03P2X
--
2
1
AREMO-6163-06P3-D3501P
PBP-06P3
2
3
1
AREMO-6163-06P4-D3501P
PBP-06P4
1
4
1
BACKPLANE
4U
3U
ATX M/B
AREMO-3194
AREMO-2173P-06V4-D3501P
2U
6-slot
AREMO--2173P
AREMO-2173P-06V4-D3502P
AREMO-2173MX-D3501P
2U
uATX M/B
AREMO-2173MX
AREMO-2173MX-3502P
1U
3-slot
RPC-1194
Node
6-slot
AREMO-6163
Node
8-slot
AREMO-8164
AREMO-8164-08P4-D3501P
PBP-08P4
3
4
1
Node
/4U
12-slot
AREMO-4184
AREMO-4184-06P3-350X
PBP-06P3
2
3
1
AREMO-6182-06P3-350X
PBP-06P3
2
3
1
AREMO-6182-06P4-350X
PBP-06P4
1
4
1
Node
75
6-slot
Chassis Reference Table
SREMO96182
Chassis Reference Table
AREMO-6163
TYPE
AREMO-8164
SLOT
AREMO-4184
PSU
MODEL
Model Name
4U
14-slot
RPC-500NC
AREMO-6182
ORION-D3501P
Power Range
PRS-1174
Dimension
(W)x (D)x(H)
350W ATX, PFC, P4
482(W) x 450(D) x 177(H) mm
19”(W) x 18”(D) x 7”(H)
4U
ATX M/B
RPC-500NC-MX
ORION-D3501P
350W ATX, PFC, P4
14-slot
AREMO-4196
ORION-D3501P
350W ATX, PFC, P4
4U
3U
2U
2U
482(W) x 481(D) x 177(H) mm
19”(W) x 19”(D) x 7”(H)
ATX M/B
AREMO-4196-MX
ATX M/B
AREMO-3194
6-slot
uATX M/B
ORION-D3501P
350W ATX, PFC, P4
ORION-B3501P
350W ATX, PFC, P4
ORION-D3501P
350W ATX, PFC, P4
ORION-D3501P
350W ATX, PFC, P4
AREMO-2173P
ORION-D3502P
350W ATX, PFC, redundant
ORION-D3501P
350W ATX, PFC, P4
482(W) x 488(D) x 133(H) mm
19”(W) x 19.2”(D) x 5.24”(H)
482(W) x429.2(D) x 88.6(H) mm
19”(W) x 16.9”(D) x 3.5”(H)
482(W) x 429.2(D) x 88.6(H) mm
19”(W) x 17.4”(D) x 3.5”(H)
AREMO-2173MX
ORION-D3502P
350W ATX, PFC, redundant
1U
3-slot
PRC-1194
ORION-A2501
250W ATX PFC, P4
482(W) x 474(D) x 44(H) mm
19”(W) x 18.7”(D) x 1.75”(H)
Node
6-slot
AREMO-6163
ORION-D3501P
350W ATX, PFC, P4
260(W) x 420.5(D) x 172(H) mm
10.24”(W) x 16.56”(D) x 6.77”(H)
Node
8-slot
AREMO-8164
ORION-D3501P
350W PFC, ATX, P4
330(W) x 420.8(D) x 172(H) mm
12.99”(W) x 16.56”(D) x 6.77”(H)
Node
/4U
12-slot
AREMO-4184
FSP350-601UA
350W PFC, ATX, P4
482(W) x 448(D) x 177(H) mm
19”(W) x 17.6”(D) x 7”(H)
Node
6-slot
AREMO-6182
FSP350-601UA
350W PFC, ATX, P4
219(W) x 446(D) x 160(H) mm
8.6”(W) x 17.6”(D) x 6.3”(H)
Chassis Reference Table
76
ESB Reference Table
PEB-2772
MODEL
77
PEB-2771/2781
PEB-2770/2780
PEB-2739I
PEB-2738I
PEB-2737VLA
PEB-2131VG2A
Form
Factor
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
3.5" Embedded
CPU
Intel® AtomTM
D2550
Intel® AtomTM D525
Intel® AtomTM
processor D510/Z450
Intel® AtomTM
Z510PT/ Z520PT
Intel® AtomTM
Z510PT/520PT
Intel® AtomTM Z510/
Z530
Intel® AtomTM N270
Chipset
Intel® NM10
Intel® ICH8M
Intel® ICH8M
Intel® US15WPT
Intel® US15WPT
Intel® US15W
Intel® 945GSE+
ICH7M
BIOS
Phoenix
AMI Core 8
AMI Core 8
AMI Core 8
AMI Core 8
AMI Core 8
Phoenix Award
Memory
1x DDR3 SODIMM
up to 4GB
1x DDR3 SODIMM
up to 2GB
1x DDR2 SODIMM
up to 2GB
1x DDR2 SODIMM
up to 2GB
1x DDR2 SODIMM
up to 2GB
1x DDR2 SODIMM
up to 2GB
1x DDR2 SODIMM
up to 2GB
Expansion
1x Mini-PCIe x1
socket
1x Mini-PCIe x1
socket
1x PCIe x1 slot
SDVO (with
PCIe x1+USB)
connector/SDIO/
TPM header
SDVO (with
PCIe x1+USB)
connector/SDIO/
TPM header
N/A
1x Mini-PCIe x1
socket
Display
VGA/HDMI/LVDS
VGA/LVDS
VGA/LVDS
SDVO/LVDS
SDVO/LVDS
VGA/LVDS
VGA/LVDS
Audio
Realtek ALC886
Audio codec
Realtek ALC892GR HD Audio
codec
Realtek ALC262VC2-GR HD Audio
codec
Realtek ALC662GR HD Audio
codec
Realtek ALC662GR HD Audio
codec
Realtek ALC262VC2-GR HD Audio
codec
Realtek ALC662GR HD Audio
codec
LAN
1x GbE
2x GbE
2x GbE
1x GbE
1x GbE
1x GbE
2x GbE
Serial Port
2x RS232
2x RS232/422/485
2x RS232
2x RS232/422/485
2x RS232
2x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
2x RS232
4x RS232
USB
6x USB 2.0
6x USB 2.0
6x USB 2.0
6x USB 2.0
6x USB 2.0
6x USB 2.0
7x USB 2.0
Storage
Devices
2xSATA
2x SATA
1x IDE
1x CF
1x SATA
1x CF
1x SDIO
1x IDE
1x CF
1x SDIO
2x SATA
1x IDE
1x CF
1x SD
2x SATA
1x CF
GPIO
8-bit
8-bit
8-bit
8-bit
8-bit
8-bit
8-bit
Others
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
Dimension
146 x 102mm
146 x 102mm
146 x 102mm
146 x 102mm
146 x 102mm
146 x 102mm
146 x 102mm
Page
78
79
80
81
82
83
84
ESB Reference Table
2x SATA
1x CF
PEB-2772
Intel® Cedar Trail AtomTM Processor based 3.5’ embedded Board with DDR3 SDRAM,Gigabit Ethernet,
Two SATA Ports, Four COM ports and 12V DC input
Winbond W83627UHG
Mini-PCIe x1 slot
PEB-2772 takes advantage of the processor’s
performance and furthermore Portwell design
the CPU/chipset on the backside of the board
which is good for system thermal design. Customer could take this advantage to have an
easy and perfect thermal solution which could
solve the thermal of CPU.
FEATURES
Intel® Atom D2550 processor
„ Intel® NM10 Chipset
„ One 204-pin SODIMM supports single channel
DDR3 SDRAM up to 4GB
„ Dual display: VGA/LVDS(24-bit)/HDMI
„ One Mini-PCIe slot
„ Two SATA 3Gb ports
„ Four COM ports (3x RS232, 1x RS232/422/485)
„ 12V DC input
„
REAR/IO
RS232
GbE
VGA
Audio
ORDERING GUIDE
(R).PEB-2772VGATM.Intel Cedar Trail 1.86G
D2550+NM10 on Board.EBC.w/DDR3/VGA/HDMI/
GbE/COM/Audio/USB
3.07
GENERAL
Processor
- Intel® AtomTM D2550(1.86GHz, 10W) processor in FCBGA559 package
- Supports Intel® Hyper-Threading Technology, Intel® 64
Chipset
Intel® NM10 Express chipset
BIOS
Phoenix BIOS (SPI ROM)
Memory
Supports up to 4GB DDR3 800/1066 MHz SDRAM on one 204-pin SODIMM socket
Storage Devices
2x SATA II supporting up to 3.0Gb/s data transfer rate
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x Mini-PCIe slot (Gen 1, 2.5 GT/s)
I/O INTERFACE
Super I/O
Winbond W83627UHG
Audio
- Intel®10EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886, 7.1+2 channel
- Audio Jack on rear I/O (Line out)
- Line in /Line out /Mic in on board pin header
Ethernet
- Intel® 82583V Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
- 1x RS232 port with DB9 connector on rear I/O
- 2x RS232 with on board pin headers
- 1x RS232/422/485 with on board pin header
USB
- 1x USB 2.0 ports on rear I/O
- 5x USB 2.0 ports on board with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on board header
GPIO
On board programmable 8-bit Digital I/Os
USB DC 12V
HDMI
AB1-3791
21.46
SODIMM socket
14.50
10
0
22.66
Intel® D2550
Intel® NM10
DISPLAY
Graphic Controller
- Intel® Graphics Technology provides a visually stunning experience
optimized for Blu-ray and HD video with Windows Vista suppor
- Supports Directx 9 compliant Pixel Shader v3.0 and OGL 3.0
Display Interface
- VGA: analog resolution up to 1920x1200 on rear I/O
- HDMI: resolution up to 1920x1200 on rear I/O
- LVDS: Digital 24-bits LVDS resolution up to 1440x900 on board
PACKING LIST
Mechanical & Environment
One PEB-2772 Main Board
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
One Thermal Kit
Power Supply
DC-12V input
One Installation CD
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 100,000 hours at 40°C
One SATA Cable
DDR 3
SATA
3Gb
HDMI
USB 2.0
MiniPCIe
VGA
LVDS
ESB-PEB-2772
78
3.5” Embedded size, based on Intel® 45nm
Low Power Pineview processor with DDR3
SODIMM, dual display by VGA/LVDS, Dual
GbE, Audio, COM and USB
PEB-2771/2781
One RS232/422/485
selectable port
Two RS232 ports
Mini-PCIe socket
TPM header
USB x 4
Audio header
SODIMM socket
LVDS
The PEB-2771/2781 takes advange of the
latest Intel® AtomTM technologies. It supports
DDR3 SDRAM, dual gigabit ethernet and one
expansion Mini PCI Express x1 socket. Based
on Intel® AtomTM solutions, the fanless PEB2771/2781 executes high performance with
low power dissipation. Therefore, it’s applied
to Panel PC, Kiosk, DS, Medical, Military and
industrial automation.
FEATURES
„
Intel® AtomTM processor D525 and ICH8M
chipset
Intel® ICH8M
GENERAL
Processor
- Intel® AtomTM Processor D525 (1.80Ghz, 13W)/N455 (1.66Ghz, 6.5W) with
1M/512K L2 Cache in FCBGA559 package
- DMI: 2.5 GT/s
- Supports Intel® Hyper-Threading Technology, Intel® 64 Architecture, SpeedStep®
Technology (N455 only) ,Thermal Monitoring Technology (N455 only)
Chipset
Intel® ICH8M (2.4W) supports Intel® AHCI Technology.
BIOS
AMI Core 8 BIOS
Memory
Supports up to 2GB DDR3 800 MHz SDRAM on one 204-pin SODIMM socket
Storage Devices
- 2x SATA II support 3.0Gb/s data transfer rate
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
Watchdog Timer
Programmable via S/W from 1 sec. to 255 sec.
204-pin SODIMM supports DDR3 800
SDRAM up to 2GB
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
„
Dual independent display: VGA/24-bit LVDS
Expansion Interface
1x Mini PCIExpress x1 socket (Gen 1, 2.5 GT/s)
„
Dual Gigabit Ethernet
„
Storage: One Compact Flash/Two SATA ports
„ One
„
„
I/O INTERFACE
12V DC input
Super I/O
Winbond W83627UHG
One Mini-PCIe socket
Audio
- Intel®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC892-GR HDA codec, 7.1+2 channels
- Audio on board header with Line-out and Mic-in
Ethernet
- Intel® WG82567V gigabit phy and 82583V Gigabit Ethernet controllers
- 2x RJ45 connectors on rear I/O
Serial Port
- 1x RS232/422/485 port with DB9 connector on rear I/O
- 2x RS232 with on board pin headers
- 1x RS232/422/485 with on board pin header
USB
- 2x USB 2.0 ports on rear I/O
- 4x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on board header
GPIO
On board programmable 8-bit Digital I/Os
REAR/IO
Dual Gigabit
CF socket
Ethernet
12V DC-in
VGA
RS232
USB x2
ORDERING GUIDE
AB1-3563
AB1-3564
PEB-2771VG2ATM.Intel Pineview 1.8G D525 on
Board.EBC.w/DDR3/VGA/Dual GbE/COM/Audio/
USB
PEB-2781VG2ATM.Intel Pineview 1.66G N455 on
Board.EBC.w/DDR3/VGA/Dual GbE/COM/Audio/
USB
PACKING LIST
DISPLAY
Graphic Controller
- Intel® ICH8M Integrated GMA 3150 Graphics supports full hardware
acceleration of video decode standards MPEG-2
- Supports Intel® Dynamic Video Memory Technology (Intel® DVMT 4.0)
- XILINX XC3S200AN LVDS Transmitter
Display Interface
- LVDS: Dual channel 24-bit LVDS
- CRT: One DB-15 connector on rear I/O, resolution up to 2048 x 1536 (QXGA)
Mechanical & Environment
One PEB-2771/2781 Main Board
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
One Thermal Kit
Power Supply
DC-12V input
One Installation CD
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One SATA Cable
One ATX Power Cable
DDR 3
79
Intel® Atom™ D525
CF Socket
17.76
17
1.60
0
7.90
Two SATA II ports
Two SATA Power
ESB-PEB-2771/2781
Watch DOG
H/W Monitor
GPIO
Fanless
4
COM
Giga
Giga LAN
MiniPCIe
3.5” Embedded size, based on Intel® 45nm Low
Power Pineview processor with DDR2 SODIMM,
dual display by VGA/LVDS, Dual GbE, Audio, COM
and USB
PEB-2770/2780
8 bits GPIO
One RS232/422/485
selectable port
Two RS232 ports
IDE
Two SATA II ports
The PEB-2770/2780 takes advange of the latest
Intel® AtomTM technologies. It supports DDR2
SDRAM, dual gigabit ethernet and one expansion PCI Express x1 female header. Based
on Intel® AtomTM solutions, the fanless PEB2770/2780 executes high performance with low
power dissipation. Therefore, it’s applied to Panel
PC, Kiosk, DS, Medical, Military and industrial
automation.
FEATURES
Intel® AtomTM processor D510/N450 and
ICH8M chipset
„
MPEG2 Decode in HW; Dual independent display:
VGA/18-bit LVDS
„ Dual Gigabit Ethernet
„ Customization (Extension card): BTB
connector with PCIe x1 signal
„ Storage: One SATA/One CompactFlash/
Two SATA ports
„ 12V DC input
CF socket
VGA
RS232
Dual Gigabit
Ethernet
12V DC-in
USB x2
ORDERING GUIDE
AB1-3588
PEB-2770VG2A.Intel Pineview 1.66G D510 on Board
without Thermal module.EBC.w/VGA/Dual GbE/
COM/Audio/USB
AB1-3589
PEB-2780VG2A.Intel Pineview 1.66G N450 on Board
without Thermal module.EBC.w/VGA/Dual GbE/
COM/Audio/USB
PACKING LIST
One PEB-2770/2780 Main Board
Intel® ICH8M
Intel® AtomTM N450
GENERAL
- Intel® AtomTM Processor D510 (1.66Ghz, 13W)/N450 (1.66Ghz, 5.5W) with
1M/512K L2 Cache in FCBGA437 package
- DMI: 2.5 GT/s
- Supports Intel® Hyper-Threading Technology, Intel® 64 Architecture, SpeedStep®
Technology (N450 only), Thermal Monitoring Technology (N450 only)
Chipset
Intel® ICH8M (2.4W) supports Intel® AHCI Technology.
BIOS
AMI Core 8 BIOS
Memory
Supports up to 2GB DDR2 667 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 2x SATA II supports 3.0Gb/s data transfer rate
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
- 1x IDE connector supports Ultra DMA100/66/33 MB/s
Watchdog Timer
Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x PCIExpressx1 female header (Gen 1, 2.5 GT/s)
I/O INTERFACE
Super I/O
Winbond W83627UHG
Audio
- Intel®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2-GR HDA codec, 5.1 channels
- Audio on board header with Line-in, Line-out and Microphone
Ethernet
- Intel® WG82567V gigabit phy and 82583V Gigabit Ethernet controllers
- 2x RJ45 connectors on rear I/O
Serial Port
- 1x RS232/422/485 port with DB9 connector on rear I/O
- 2x RS232 with on board pin headers
- 1x RS232/422/485 with on board pin header
USB
- 2x USB 2.0 ports on rear I/O
- 4x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on board header
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
Graphic Controller
- Intel® D510/N450 integrated Generation 3.5/2.5 graphics, supports DX9
Graphics up to 400MHz/200MHz
- Supports Intel® Dynamic Video Memory Technology (Intel® DVMT 3.0)
Display Interface
- LVDS: Single channel 18-bit LVDS, resolution up to 1366x768, 18bpp
- CRT: One DB-15 connector on rear IO, resolution up to 2048 x 1536 (QXGA)
Mechanical & Environment
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One Thermal Kit
One Installation CD
CF socket
Processor
„
REAR/IO
1.60
0
6.80
LVDS
17.76
USB x4
SODIMM socket
One SATA Cable
One ATX Power Cable
BIOS
DDR 2
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
Fanless
4
COM
Giga
Giga LAN
ESB-PEB-2770/2780
80
PEB-2739I
Intel® 45nm Ultra Low Power Menlow-XL processor and chipset based 3.5’’ embedded board
with dual display, Audio, USB, SDIO and SATA
LVDS
SDVO & PCIe x1
connector
Intel® 45 nm Ultra Low
Power Menlow-XL
processor and chipset
One RS232 port
SDIO port
The PEB-2739I takes advange of the latest Intel®
AtomTM technologies. It supports DDR2 SDRAM,
one gigabit ethernet and one expansion Multi
function connector. Based on Intel® AtomTM solutions, the fanless PEB-2739I executes high performance with low power dissipation. Therefore, it’s
applied to Panel PC, Kiosk, Medical, and industrial
automation.
FEATURES
„ Intel® AtomTM processor
Z500PT series and
System Controller Hub US15WPT
„ One 200-pin SODIMM supports DDR2
SDRAM up to 2GB
„ Dual independent display: SDVO (by VGA/
DVI/LVDS daughter card) and 24bit LVDS
„ One Gigabit Ethernet
„ Trusted Platform Module (TPM) ready (addition
to board is optional)
„ Customization (Extension card): BTB connector
with SDVO/USB/PCIe x1 signal and SDIO pin
header
„ Storage: One SATA II/One CompactFlash/One
USB Flash/One SDIO
„ 12V DC input
REAR/IO
GbE
12V DC-in
ORDERING GUIDE
AB1-3557
PEB-2739I-1100.Intel Atom Z510PT 1.1G on Board.
EBC.w/SDVO/COM/Audio/USB/LAN/SATA/DC-12V
AB1-3558
PEB-2739I-1330.Intel Atom Z520PT 1.33G on Board.
EBC.w/SDVO/COM/Audio/USB/LAN/SATA/DC-12V
PACKING LIST
Processor
- Intel® AtomTM Processor Z510PT (1.1GHz, 2.2W)/Z520PT (1.33GHz, 2.2W) with
512K L2 Cache in FCBGA437 package
- FSB: 400/533MHz
- Supports Enhanced Intel SpeedStep®, Thermal Monitoring Technology
Chipset
- Intel® System Controller Hub US15WPT (2.3W)
BIOS
AMI Core 8 BIOS
Memory
- Supports up to 2GB DDR2 400/533 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 1x SATA II supports 3.0Gb/s data transfer rate by 88SA8052B1 PATA to
SATA Bridge
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
- 1x SDIO box header supports 24MHz (SDIO Revesion 1.1)
Watchdog Timer
- Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x Multi function connector supports SDVO/PCI Express x1/USB
I/O INTERFACE
Super I/O
Winbond W83627DHG
Audio
- Intel®86:37EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Audio Jacks on rear I/O with Line-out and Mic-in
Ethernet
- Intel® WG82574IT Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
- 1x RS232/422/485 port with DB9 connector on rear I/O
- 1x RS232 with on board pin header
USB
- 4x USB 2.0 ports on rear I/O
- 2x USB 2.0 ports on borad with pitch 2.0 header
- 1x Client USB port on borad edge
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
Graphic Controller
Intel® System Controller Hub US15WPT integrated Intel® GMA 500 supports
full hardware acceleration of video decode standards, such H.264, MPEG2,
MPEG4 and WMV9
Display Interface
LVDS: Single channel 24-bit LVDS
Mechanical & Environment
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: -40°C to 80°C
- Storage Temperature: -40°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One PEB-2739I Main Board
One 2-in-1 Heatsink
One Installation CD
Giga
One SATA Cable
81
ESB-PEB-2739I
SODIMM socket
GENERAL
Line-out and Mic-in RS232/422/485
Four USB
CF Socket
1.60
0
7.90
20.20
Client USB
KB/MS header
SATA with power
Wide
DDR 2
Giga LAN
Watch DOG
H/W Monitor
GPIO
Temperature
Fanless
MiniPCIe
PEB-2738I
Intel® 45nm Ultra Low Power Menlow-XL processor
and chipset based 3.5’’ embedded board with dual
display, Audio, USB and SDIO
One RS232/422/485
selectable port
HDD Power connector
LVDS port
SDVO & PCIe x 1
connector
Intel® 45nm Ultra LOW
Power Menlow-XL
processor and Chipset
PEB-2738I takes advange of the latest Intel®
AtomTM technologies. It supports DDR2 SDRAM,
one gigabit ethernet and one expansion Multi
fuction connector. Based on Intel® AtomTM solutions, the fanless PEB-2738I executes high performance with low power dissipation. Therefore,
it’s applied to Panel PC, Kiosk, Medical, and
industrial automation.
FEATURES
Z500PT series and
System Controller Hub US15WPT
One 200-pin SODIMM supports DDR2
SDRAM up to 2GB
„
Dual independent display: SDVO (by VGA/DVI/
LVDS daughter card) and 24-bit LVDS
„
One Gigabit Ethernet
„
Trusted Platform Module (TPM) ready (addition
to board is optional)
„
Customization (Extension card): BTB connector
with SDVO/USB/PCIe x1 signal and SDIO
pin header
„
Storage: One PATA/One CompactFlash/One
USB Flash/One SDIO
„
12V DC input
REAR/IO
Line-out and Mic-in
Four USB ports
DC in
GENERAL
- Intel® AtomTM Processor Z510PT (1.1GHz, 2.2W)/Z520PT (1.33GHz, 2.2W) with
512K L2 Cache in FCBGA437 package
- FSB: 400/533MHz
- Supports Enhanced Intel SpeedStep®, Thermal Monitoring Technology
Chipset
- Intel® System Controller Hub US15WPT (2.3W)
BIOS
AMI Core 8 BIOS
Memory
- Supports up to 2GB DDR2 400/533 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 1x IDE connector supports Ultra DMA100/66/33 MB/s
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
- 1x SDIO box header supports 24MHz (SDIO Revesion 1.1)
Watchdog Timer
- Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x Multi function connector supports SDVO/PCI Express x1/USB
I/O INTERFACE
Super I/O
Winbond W83627DHG
Audio
- Intel® 86:37EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Audio Jacks on rear I/O with Line-out and Mic-in
Ethernet
- Intel® WG82574IT Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
- 1x RS232/422/485 port with DB9 connector on rear I/O
- 1x RS232 with on board pin header
USB
- 4x USB 2.0 ports on rear I/O
- 2x USB 2.0 ports on board with pitch 2.0 header
- 1x Client USB port on board edge
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse on board header
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
GbE
COM port
ORDERING GUIDE
AB1-3278
PEB-2738I-1100.Intel Atom Z510PT 1.1G on Board.
EBC.w/SDVO/COM/Audio/USB/LAN/DC-12V
AB1-3406
PEB-2738I-1330.Intel Atom Z520PT 1.33G on Board.
EBC.w/SDVO/COM/Audio/USB/LAN/DC-12V
PACKING LIST
Graphic Controller
Intel® System Controller Hub US15WPT integrated Intel® GMA 500 supports
full hardware acceleration of video decode standards, such H.264, MPEG2,
MPEG4 and WMV9
Display Interface
LVDS: Single channel 24-bit LVDS
Mechanical & Environment
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: -40°C to 80°C
- Storage Temperature: -40°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One PEB-2738I Main Board
One 2-in-1 Heatsink
One Installation CD
Giga
One IDE Cable
DDR2 SODIMM socket
Processor
„ Intel® AtomTM processor
„
CF socket
20.28
16.60
1.60
0
6.90
SDIO port
Client USB port IDE port
One RS232 port
KB/MS header
Wide
DDR 2
Giga LAN
Watch DOG
H/W Monitor
GPIO
Temperature
Fanless
MiniPCIe
ESB-PEB-2738I
82
PEB-2737VLA
Intel® 45nm Ultra Low Power AtomTM processor based 3.5’’ embedded board with VGA,
LVDS, Gigabit Ethernet, Audio, USB and SDIO
Power Connector
LVDS Interface
8 bits GPIO
Intel Atom Z510/Z530
processor and System
Controller Hub US15W
®
TM
PEB-2737VLA takes advange of the latest Intel®
AtomTM technologies. It supports DDR2 SDRAM,
and one gigabit ethernet. Based on Intel® AtomTM
solutions, the fanless PEB-2737VLA executes
high performance with low power dissipation.
Therefore, making it the ideal solution for Panel
PCs, Kiosks, and Industrial Automation.
FEATURES
„
Intel® AtomTM processor Z510/Z530 and System
Controller Hub US15W (TDP<5W)
„ One
200-pin SODIMM supports DDR2 SDRAM
up to 2GB
„
One Type II CompactFlash, one IDE & two SATA
ports
„
Dual independent display: VGA and 24-bit LVDS
„
One Gigabit Ethernet
REAR/IO
GbE port
COM port
PS/2 KB/MS
Four USB ports
CF socket
1.60
0
6.90
IDE Connector
33.12
SDIO socket
17.10
Two SATA II ports
DDR2 SODIMM socket
GENERAL
Processor
- Intel® AtomTM Processor Z510 (1.1GHz, 2.2W)/Z530 (1.5GHz, 2W) with 512K
L2 Cache in PBGA441 package
- FSB: 400/533MHz
- Supports Enhanced Intel SpeedStep®, Thermal Monitoring Technology
Chipset
Intel® System Controller Hub US15W (2.3W)
BIOS
AMI Core 8 BIOS
Memory
- Supports up to 2GB DDR2 400/533 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 2x SATA II support 3.0Gb/s data transfer rate by JMB362 SATA Host
- 1x IDE connector supports Ultra DMA100/66/33 MB/s
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
- 1x SD socket supports 24MHz (SDIO Revesion 1.1)
Watchdog Timer
- Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
I/O INTERFACE
Super I/O
Winbond W83627DHG
Audio
- Intel®86:EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2-GR HDA codec, 2.1 channels
- Audio Jack on rear IO with Line-out and Mic-in
Ethernet
- Realtek RTL8111C-VC-GR Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
- 1x RS232 port with DB9 connector on rear I/O
- 1x RS232 with on board pin header
USB
4x USB 2.0 ports on rear I/O
2x USB 2.0 ports on borad with pitch 2.0 header
480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
1x PS/2 Keyboard & Mouse connector on rear I/O
GPIO
On board programmable 8-bit Digital I/Os
Audio VGA port
DISPLAY
ORDERING GUIDE
AB1-3218
PEB-2737VLA-1100.Intel Atom 1.1G on Board.
EBC.w/VGA/LAN/COM/Audio/USB
AB1-3241
PEB-2737VLA-1600.Intel Atom 1.6G on Board.
EBC.w/VGA/LAN/COM/Audio/USB
Graphic Controller
- Intel® System Controller Hub US15W integrated Intel® GMA 500 supports
full hardware acceleration of video decode standards, such H.264, MPEG2,
MPEG4 and WMV9
- Chrontel CH7317A-TF/CH7317B SDVO to RGB DAC
Display Interface
- LVDS: Single channel 24-bit LVDS
- CRT: One DB-15 connector on rear I/O, resolution up to 1920x1200 (WUXGA)
Mechanical & Environment
PACKING LIST
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One PEB-2737VLA Main Board
One 2-in-1 Heatsink
One Installation CD
One ATX Power Cable
EC
83
ESB-PEB-2737VLA
DDR 2
SATA
3Gb
USB 2.0
Watch DOG
H/W Monitor
GPIO
Fanless
3.5” Embedded size, based on Intel® AtomTM
N270 Processor with DDR2 SDRAM, Dual Display
by VGA/LVDS, Gigabit Ethernet, Four Power COM
Ports and Audio
PEB-2131VG2A
Line-out
Line-out, Line-in
& Mic header
DC 12V Input
24-bit LVDS port
CF socket
Intel® AtomTM N270
Four RS232 ports
Intel® 945GSE
Intel® ICH7M
HDD Power connector
29.60
Two SATA II Ports
Mini-PCIe socket
PEB-2131VG2A takes advange of the latest
Intel® AtomTM technologies. It supports DDR2
SDRAM, dual gigabit ethernet and one expansion Mini PCI-Express x1 socket. Based on the
leading Intel® AtomTM solution, PEB-213VG2A
has low power dissipation with high performance necessary for fanless models making it
perfect for applications such as the Panel PCs
and Kiosks as well as in Industrial Automation.
FEATURES
„
Intel Atom N270 and 945GSE platform that
provides cost effective solution
®
storage
Dual Gigabit Ethernet (10/100/1G) with RJ-45
connector
„ +LJK'H¿QLWLRQDXGLRZLWKFKDQQHO
DPSOL¿HU#:
„
DDR2 SODIMM socket
GENERAL
- Intel® AtomTM N270 processor 1.6 GHz (2.5W) and 512KB Cache in FC-BGA package
- FSB 533 MHz
- Supports Intel® Hyper-Threading and SpeedStep Technology
Chipset
- Intel® 945GSE Graphics and Memory Controller Hub (6W), Intel® Gen 3.5
Integrated Graphics Engine.
- Intel® ICH7M (2.5W), Intel® AHCI Technology.
BIOS
Phoenix Award BIOS
Memory
Supports up to 2GB DDR2 400/533 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 2x SATA II support 3.0Gb/s data transfer rate
- 1x CompactFlash socket supports Ultra DMA100/66/33 MB/s
Watchdog Timer
Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x Mini-PCI Express socket (Gen 1, 2.5 GT/s)
Supports one SODIMM socket and up to 2GB
memory size
„ Mini-PCI Express and power COM ports
SURYLGHÀH[LELOLW\
„
Mini-PCIe socket
Processor
TM
„ 6$7$DQG&)LQWHUIDFHVSURYLGHFRVWHI¿FLHQW
„
1.60
0
7.90
KB/MS header
/RZSUR¿OHUHDU,2VXSSRUWVWKLQ
client application
REAR/IO
Dual Gigabit Ethernet ports
DC in
I/O INTERFACE
Super I/O
Winbond W83627UHG
Audio
- Intel®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC662-GR HDA codec, 5.1 channels
- Audio Jack on rear I/O with Line-out
- Audio on board box header with Line-in, Line-out and Mic-in
Ethernet
- Realtek RTL8111C-VC-GR Gigabit Ethernet controller
- 2x RJ45 connectors on rear I/O
Serial Port
4x RS232 ports on board pin header
USB
- 2x USB 2.0 ports on rear I/O
- 5x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
Keyboard & Mouse
PS/2 Keyboard & Mouse with on board pin header
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
Two USB ports
Line-out
Graphic Controller
- Intel® 945GSE integrated Intel® GMA 950 supports dynamic video memory
technology (Intel® DVMT 3.0), Microsoft DirectX 9.1 operating system
- Chrontel CH7308B-TF SDVO to LVDS Transmitter
Display Interface
- LVDS: Dual channel 24-bit LVDS, resolution up to 1600x1200 (UXGA)
- CRT: One DB-15 connector on rear I/O, resolution up to 2048x1536 (QXGA)
VGA port
ORDERING GUIDE
AB1-3324
PEB-2131VG2A.ESB.N270.945GSE.ICH7.w/DDRII
SDRAM/VGA/LVDS/Dual GbE/Audio
PACKING LIST
Mechanical & Environment
Dimension
146(L) x 102(W)mm; 5.75"(L) x 4.02"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
One PEB-2131VG2A 3.5” Main Board
One Installation CD
One SATA Cable
One SATA Power Cable
BIOS
DDR 2
Watch DOG
H/W Monitor
GPIO
Fanless
4
COM
6
USB
2
GbE
ESB-PEB-2131VG2A
84
NANO-ITX Reference Table
MODEL
NANO-5050
NANO-6040
NANO-8050
NANO-ITX
NANO-ITX
NANO-ITX
Form Factor
CPU
85
NANO-ITX Reference Table
Intel® AtomTM D2550
Intel® AtomTM E6X0T
Intel® CoreTM 2 Duo
Chipset
Intel® NM10
Intel® EG20T
Intel® GS45+ICH9M
BIOS
Phoenix UEFI
AMI UEFI
AMI Core 8
Memory
1x DDR3 SODIMM up
to 4GB
DDR2 on board up to
2GB
1x DDR2 SODIMM up
to 2GB
Expansion
1x PCIe x1 slot
1x Mini-PCIe x1 socket
1x PCIe x1 slot
1x Mini-PCIe x1 socket
1x PCIe x1 slot
Display
VGA/LVDS/DP
VGA/LVDS
SDVO/LVDS
Audio
Realtek ALC886-GR
HD Audio codec
Realtek ALC892-GR
HD Audio codec
Realtek ALC262-VC2GR HD Audio codec
LAN
1x GbE
1x GbE
1x GbE
Serial Port
1x RS232/422/485
1x RS232/422/485
1x RS232/422/485
USB
6x USB 2.0
6x USB 2.0
6x USB 2.0
Storage
Devices
1x SATA
1x CF-SATA
2x SATA
1x SD
2x SATA
1x CF
GPIO
8-bit
8-bit
8-bit
Dimension
120 x 120mm
120 x 120mm
120 x 120mm
Page
86
87
88
NANO-5050
Intel® AtomTM D2550 processor based NANOITX Board with dual display, Gigabit Ethernet,
Audio, USB, CF-SATA and SATA
VGA connector
4-pin power connector
One PCIe x1 slot
Intel® D2550 Processor
Intel® NM10
Mini-PCIe socket
One 204-pin
SODIMM socket
LVDS connector
One SATA II port
NANO-5050 adopts latest Intel® AtomTM D2550
CPU and NM10 chipset which is for the low
power compact size system. The new architecture integrates the 3D graphics engine and
memory controller. It’s suitable for Medical and
Networking applications.
FEATURES
Intel® AtomTM D2550 1.86GHz processor
based on Intel® NM10 platform
„ One 204-pin SODIMM supports DDR3 up to 4GB
„ Multiple display by VGA, DP, single channel
24 bit LVDS
„ Supports one CF-SATA socket and one SATA port
„ One Mini-PCIe socket and PCIe x1 slot for
expansion
„ Supports DC 12V input
„
REAR/IO
USB
DC 12V
DP
Audio
GbE
ORDERING GUIDE
AB1-3863
(R).NANO-5050. Nano-ITX ESB. Intel ATOM D2550
1.86GHz.w/DDR3 SDRAM/VGA/LVDS/DP/GbE LAN/
CF-SATA
13.61
0
16.16
CF-SATA socket
GENERAL
Processor
- Intel® Atom™ Processor D2550 (1.86GHz, 10W) with 1MB L2 Cache in
FCBGA559 package
- FSB: 400/533MHz
- Supports Intel® Hyper-Threading Technology
Chipset
Intel® NM10 Express chipset
BIOS
Phoenix uFEI BIOS (SPI ROM)
Memory
Supports up to 4GB DDR3 800/1066 MHz SDRAM on one 204-pin SODIMM socket
Storage Devices
- 1x CF-SATA (supports CF and CF-SATA card)
- 1x SATA supports 3Gb/s data transfer rate
Watchdog Timer
- Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
- 1x PCI Expressx1 slot (Gen 1, 2.5 GT/s)
- 1x Mini-PCIe slot (Gen 1, 2.5 GT/s)
I/O INTERFACE
Super I/O
Winbond W83627DHG-PT
Audio
- Intel®10EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC886-GR HDA codec, 7.1+2 channels Audio Jack on rear I/O with
Line-out and Mic-in
Ethernet
- Intel® 82583V Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
1x RS232/422/485 on board connector
USB
- 2x USB 2.0 ports on rear I/O
- 4x USB 2.0 ports on board with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
Graphic Controller
- Intel® AtomTM D2550 integrated Intel® GMA 3650 supports full hardware
acceleration of video decode standards, such as DirectX 9
Display Interface
- LVDS: Single channel 24bit LVDS on board connector, resolution up to 1440x900
- CRT: One on-board DB-15 connector, resolution up to 1920x1200 (WUXGA)
- DP: One DP port on rear I/O, resolution up to 2560x1600
PACKING LIST
One NANO-5050 NANO-ITX Main Board
One passive Heatsink
One Installation CD
Mechanical & Environment
Dimension
120(L) x 120(W)mm; 4.72"(L) x 4.72"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 85°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
Over 120,000 hours at 40°C
Giga
SATA
3Gb
USB 2.0
Giga LAN
Watch DOG
H/W Monitor
GPIO
Fanless
CFSATA
DDR 3
NANO-ITX-NANO-5050
86
NANO-6040
Intel® AtomTM E6X0T processor based NANOITX Board with dual display, Gigabit Ethernet,
Audio, USB, CAN, SD and SATA
LVDS connector
4-pin power connector
Intel® EG20T
One PCIe x1 slot
Intel® E6x0T Processor
On-Board Memory
Mini-PCIe socket
SD socket
NANO-6040 adopts Intel’s latest wide temperature AtomTM processors, which is for the small
ultra low power form factor. The new architecture
integrates the 3D graphics engine and memory
controller making it suitable for critical environments. The board also comes equipped with a
CAN bus connector for vehicle application.
FEATURES
Intel® AtomTM E6X0T processor based on Intel®
EG20T platform
„ Dual independent display: VGA and single
channel 18/24-bit LVDS
„ One SD socket, two SATA II ports, one
Gigabit Ethernet
„ Supports iTPM function for more secure
platforms
„ One Mini-PCIe socket and PCIe x1 slot for
Expansion
„ Supports DC 12V input
„
1.60
0
11
32.80
Two SATA II ports
GENERAL
Processor
- Intel® Atom™ E620T (600MHz,3.3W), E640T (1.0GHz, 3.6W), E660T(1.33GHz,
3.6W), E680T (1.6GHz, 4.5W) with 512K L2 Cache in FCBGA676
- FSB: 400MHz
- Supports Intel® Virtualization Technology (VT-x), Intel® Thermal Monitoring
Technology, Enhanced Intel SpeedStep® Technology, Hyper-Threading Technology
Chipset
Intel® Platform Controller Hub EG20T (1.55W)
BIOS
AMI UEFI BIOS
Memory
Supports up to 2GB DDR2 667/800 MHz on-borad SDRAM
Storage Devices
- 2x SATA II support 3.0Gb/s data transfer rate
- 1x SD socket supports 24MHz (SDIO Revesion 1.1)
Watchdog Timer
Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x PCI Expressx1 slot (Gen 1, 2.5 GT/s)
1x Mini PCI Express socket (Gen 1, 2.5 GT/s)
I/O INTERFACE
Super I/O
ITE IT8783F
Audio
- Intel®SURFHVVRUEXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC892-GR HDA codec, 7.1 channels
- Audio Jack on rear I/O with Line-out and Mic-in (NANO-6040)
- Audio Jack on rear I/O with Line-out (NANO-6040L)
- Audio on board header with Line-out and Mic-in
Ethernet
- Intel® WG82574IT Gigabit Ethernet controller
- 1x RJ45 connector on rear I/O
Serial Port
- 1x RS232/422/485 port with DB-9 connector on rear I/O (NANO-6040)
- W/o serial port on rear I/O (NANO-6040L)
USB
- 2x USB 2.0 ports on rear I/O
- 4x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus handles high-speed/full-speed/low-speed data ranges
GPIO
On board programmable 8-bit Digital I/Os
Others
TPM header, I2C header, CAN bus header
REAR/IO
RS232/422/485
USB
DC 12V
VGA
Audio
Gigabit Ethernet
ORDERING GUIDE
AB1-3745
(R).NANO-6040-1600-1024.Nano-ITX ESB.Intel
Tunnel Creek E680T 1.6GHz.w/1GB SDRAM/VGA/
LVDS/GbE LAN/Audio/USB
AB1-3746
(R).NANO-6040L-1000-1024.Nano-ITX ESB.Low
SUR¿OHW\SH,QWHO7XQQHO&UHHN(7*+]Z*%
SDRAM/VGA/LVDS/GbE LAN/Audio/USB
Graphic Controller
- Intel® processors integrated graphic engine supports frequency up to
400MHz, OpenGL ES2.0, OpenVG 1.1
- Chrontel CH7317B-TF SDVO to RGB DAC
AB1-3747
(R).NANO-6040L-1600-1024.Nano-ITX ESB.Low
SUR¿OHW\SH,QWHO7XQQHO&UHHN(7*+]Z*%
SDRAM/VGA/LVDS/GbE LAN/Audio/USB
Display Interface
- LVDS: single channel 18/24-bit LVDS up to 1280x768 (WXGA)
- CRT: resolution up to 1280 x1024 (SXGA)
DISPLAY
Mechanical & Environment
PACKING LIST
One NANO-6040 NANO-ITX Main Board
Dimension
120(L) x 120(W)mm; 4.72"(L) x 4.72"(W)
Power Supply
DC-12V input
Environment
- Operation Temperature: -40°C to 80°C
- Storage Temperature: -40°C to 80°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
126,104 hours at 40°C
One passive Heatsink
One Installation CD
Giga
BIOS
87
NANO-ITX-NANO-6040
Wide
DDR 3
Giga LAN
Watch DOG
H/W Monitor
GPIO
Temperature
LVDS
Fanless
MiniPCIe
Leading Intel® latest ULV Mobile SFF 45nm
CoreTM 2 Duo or Celeron® M Processor based
NANO-ITX with DDR2 SODIMM, Dual Displays,
Gigabit Ethernet, Audio, USB
NANO-8050
LVDS connector
One PCIe x1 slot
Intel® ICH9M SFF
8-pin power connector
Intel® GS45
Intel® Core 2 Duo or
Celeron® processor
One 200-pin
SODIMM socket
TM
Two SATA II ports
NANO-8050 adopts Intel® Small Form Factor
(SFF) mobile chipset and takes advantage of
leading Intel® CoreTM 2 Duo/Celeron® M technologies with high performance, built-in graphics media
accelerator (GMA) 4500MHD graphics engine.
NANO-8050 supports 3D performance and dual
display by VGA and LVDS. This compact, low heat
model is ideal for Medical and DS applications.
FEATURES
Intel® Ultra Low Voltage Mobile 45nm CoreTM 2
Duo or Celeron® M Processor
„ One 200-pin SODIMM supports DDR2
800/667MHz up to 2GB
„ Dual Display: VGA and 24-bit LVDS
„ One Intel® Gigabit Ethernet port
„ Supports iTPM function for more secure platforms
„
REAR/IO
Gigabit Ethernet
Audio
USB
ORDERING GUIDE
AB1-3266
NANO-8050-1200.Nano-ITX ESB.Intel Core 2 Duo
SU9300 1.2GHz.w/DDR2 SDRAM/VGA/LVDS/Dual
Display/GbE LAN/Audio
AB1-3280
NANO-8050-2260.Nano-ITX ESB.Intel Core 2 Duo
SP9300 2.26GHz.w/DDR2 SDRAM/VGA/LVDS/Dual
Display/GbE LAN/Audio
AB1-3281
NANO-8050-1860.Nano-ITX ESB.Intel Core 2 Duo
SL9400 1.86GHz.w/DDR2 SDRAM/VGA/LVDS/Dual
Display/GbE LAN/Audio
AB1-3355
NANO-8050-C1203.Nano-ITX ESB.Intel Celeron
ULV723 1.2GHz.w/DDR2 SDRAM/VGA/LVDS/Dual
Display/GbE LAN/Audio
AB1-3373
NANO-8050-C1202.Nano-ITX ESB.Intel Celeron
ULV722 1.2GHz.w/DDR2 SDRAM/VGA/LVDS/Dual
Display/GbE LAN/Audio
AA1-3078
GENERAL
Processor
- Intel® CoreTM 2 Duo, and Celeron® mobile processors up to 2.26GHz
- FSB: 800MHz
- Supports Intel® Virtualization Technology (VT-x), Intel® Trusted Execution
Technology, Enhanced Intel SpeedStep® Technology (SP9300)
Chipset
- Intel® 82GS45 Graphics and Memory Controller Hub (12W)
- Intel® ICH9M SFF I/O Controller Hub (2.5W)
BIOS
AMI Core 8 BIOS
Memory
Supports up to 2GB DDR2 667/800 MHz SDRAM on one 200-pin SODIMM socket
Storage Devices
- 1x Type II CompactFlash socket supports Ultra DMA133/100/66/33 MB/s by
JMD330 SATA to PATA Bridge
- 2x SATA II support 3.0Gb/s data transfer rate
Watchdog Timer
Programmable via S/W from 1 sec. to 255 sec.
Hardware Monitoring
- Temperature (CPU & System)
- Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
Expansion Interface
1x PCI Expressx1 Gen 1 (2.5 GT/s)
I/O INTERFACE
RS232/422/485
VGA
1.60
0
6.50
32.80
29.60
CF socket
PER-4110R.1 Slot Riser Card.PCIEx1 to PCIEx1
PACKING LIST
Super I/O
Winbond W83627THG
Audio
- Intel®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
- Realtek ALC262-VC2-GR HDA codec, 2.1 channels
- Audio Jack on rear I/O with Line-out and Mic-in
Ethernet
- Intel® WG82567LM Gigabit Ethernet Phy
- 1x RJ45 connector on rear I/O
Serial Port
1x RS232/422/485 port with DB-9 connector on rear I/O
USB
- 4x USB 2.0 ports on rear I/O
- 2x USB 2.0 ports on borad with pitch 2.0 header
- 480 Mb/s bus comprehends the high-speed/full-speed/low-speed data ranges
GPIO
On board programmable 8-bit Digital I/Os
DISPLAY
Graphic Controller
Intel® GMCH integrated Intel® GMA 4500MHD supports DVMT 5.0, Microsoft
DX 10, hardware acceleration of MPEG2
Display Interface
- LVDS: Dual channel 24-bit LVDS
- CRT: One DB-15 connector on rear I/O resolution up to 2048x1536 (QXGA)
Mechanical & Environment
Dimension
120(L) x 120(W)mm; 4.72"(L) x 4.72"(W)
Power Supply
+5V, +12V input
Environment
- Operation Temperature: 0°C to 55°C
- Storage Temperature: -20°C to 85°C
- Relative Humidity: 5% to 95%, non-condensing
MTBF
105,924 hours at 40°C
One NANO-8050 NANO-ITX Main Board
One Active or Passive Heatsink depends on CPU sku
One Installation CD
One 8 pin ATX Power Cable
Giga
LVDS
DDR 2
VGA
SATA
3Gb
USB 2.0
Giga LAN
Watch DOG
H/W Monitor
GPIO
NANO-ITX-NANO-8050
88
Mini-ITX Platform
7KH0LQL,7;IRUPIDFWRUGH¿QHGE\WKHFKLSVHWPDQXIDFWXUHUVLQ7DLZDQ
LVDKLJKO\LQWHJUDWHGDOOLQRQH[EDVHGHPEHGGHGFRPSXWHUERDUGWKDW
PHDVXUHVDPHUHPP[PP,WVFRPSDFWVL]HDQGDOOLQRQHGHVLJQ VLPSOL¿HV DQG DFFHOHUDWHV WKH LPSOHPHQWDWLRQ RI DQ HPEHGGHG 3&
V\VWHP3RUWZHOO¶V0LQL,7;FRPSXWHUERDUGVDQGEDUHERQHVV\VWHPVRIIHUDZLGHVHOHFWLRQRIPLFURSURFHVVRUVSRZHUHI¿FLHQWWHFKQRORJLHVSHULSKHUDO,2VH[SDQVLRQVDQGPHFKDQLFDOIRUPIDFWRUV
:KHWKHU\RX¶UHZRUNLQJRQPHGLFDOLQVWUXPHQWVWKLQQHWZRUNGHYLFHVRU
GLJLWDOPHGLDV\VWHPV3RUWZHOO¶V0LQL,7;ERDUGVDQGEDUHERQHV\VWHPV
DUHWKHSHUIHFWVROXWLRQVWRKHOS\RXWRGHOLYHU\RXUSURGXFWVRQWLPHDQG
VWD\RQHVWHSDKHDGRIWKHFRPSHWLWLRQ
:LWK \HDUV RI H[SHULHQFH LQ WKH GHVLJQ DQG PDQXIDFWXUH RI VLQJOH ERDUG FRPSXWHUV 3RUWZHOO SURYLGHV
QRWRQO\RQHVWRSVKRSSLQJIRURIIWKHVKHOISURGXFWVEXWDOVRFXVWRPEXLOWVROXWLRQVWDLORUPDGHWRVXLW\RXU
QHHGV
Portwell’s WADE series
3RUWZHOODOUHDG\SURYLGHVDYDULHW\RISURGXFWVEDVHGRQWKH0LQL,7;IRUPIDFWRUVXFKDV'HVNWRS0RELOHDQG
/RZ3RZHUVROXWLRQV
Desktop
(TXLSSHGZLWK,QWHO¶VODWHVWJHQHUDWLRQ,QWHO®&RUHTMLLLSURFHVVRULWQRWRQO\PHHWV\RXUKLJKSHUIRUPDQFHUHTXLUHPHQWVEXWLWDOVRSURYLGHVTXDOLW\DQGUHOLDELOLW\DVVXSSRUWHGE\RXUVWDQGDUGDQGFXVWRPL]HGVHUYLFH:LWKLWVULFK
GLVSOD\LQWHUIDFHLWLVFDSDEOHRIVXSSRUWLQJVHYHUDOPXOWLPHGLDGHYLFHVWRPHHW\RXUGLIIHUHQWQHHGV
Product list: WADE-8013, WADE-8012, WADE-8011, WADE-8180, WADE-8056, WADE-8556, WADE-8656
Mobile
6WULNLQJDEDODQFHEHWZHHQHQHUJ\HI¿FLHQF\DQGSHUIRUPDQFH3RUWZHOO¶VPRELOH,QWHO®&RUHTM'XRSURGXFWLVEDVHG
RQPRELOHSURFHVVRUVEXLOWZLWKH[FHOOHQWSRZHU,WLVDPRELOHSODWIRUPWKDWFDQEHHDVLO\DGDSWHGWRTXLWHWKHV\VWHP
DQGDYDLODEOHIRUQXPHURXVXVDJHLQWKHVPDOOVL]H
Product list: WADE-8020, WADE-8067, WADE-8066, WADE-8068, WADE-8046, WADE-8065
Low Power
:LWKDORZSRZHUFRQVXPSWLRQWDUJHWWKH,QWHO® AtomTMSURFHVVRURIIHUVFXVWRPHUVPRUHWKDQDGHTXDWHFRPSXWLQJ
SRZHU)XUWKHUPRUHLWVIDQOHVVGHVLJQDOVRRIIHUVQRLVHUHGXFWLRQDQGHI¿FLHQWKHDWGLVVLSDWLRQLQNHHSLQJZLWK3RUWZHOO¶VGHYRWLRQWRJUHHQHQYLURQPHQWV
Product list: WADE-8077, WADE-8075/76, WADE-8071, WADE-8070, WADE-8072, WADE-8170
89 0LQL,7;3ODWIRUP
Mini-ITX Reference Table
MODEL
WADE-8020
WADE-8067
WADE-8066
WADE-8068
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Intel® CoreTM i5/i7
Intel® CoreTM 2 Duo/
Celeron® M
Intel® CoreTM 2 Duo/
Celeron® M
Intel® CoreTM 2 Duo/
Celeron® M
Chipset
Intel® QM57 PCH
Intel® GM45 + ICH9ME
Intel® GME965 + ICH8ME
Intel® GME965 + ICH8ME
BIOS
AMI UEFI
AMI Core 8
Award
Award
Memory
2x DDR3 SODIMM up to 8GB
2x DDR3 SODIMM up to 8GB
2x DDR2 SODIMM up to 4GB
2x DDR2 SODIMM up to 4GB
Expansion
1x PCI slot
1x PCIe x1 slot
1x Mini PCIe socket
1x PCIe x4 slot
1x PCI slot
1x PCIe x1 slot
1x PCI slot
1x PCIe x1 slot
Display
VGA/DVI/LVDS/HDMI
VGA/DVI/LVDS/HDMI
VGA/DVI/LVDS
VGA/LVDS
Audio
Realtek ALC888 HD Audio codec
Realtek ALC262-VC2-GR HD
Audio codec
Realtek ALC883-GR HD Audio
codec
Realtek ALC888 HD Audio codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
3x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
1x RS232
1x RS232/422/485
3x RS232
1x RS232/422/485
USB
8x USB 2.0
6x USB 2.0
8x USB 2.0
8x USB 2.0
Storage Device
6x SATA
4x SATA
2x SATA
1x CF
2x SATA
1x CF
GPIO
16-bit
8-bit
8-bit
16-bit
Others
SMBus pin header
1x TV out
PS/2 KB&MS
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
Dimension
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
Page
94
95
96
97
0LQL,7;5HIHUHQFH7DEOH 90
Mini-ITX Reference Table
MODEL
91
WADE-8077
WADE-8075/76
WADE-8071
WADE-8070
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Intel® AtomTM D2550
Intel® AtomTM D525/N455
Intel® Atom™ N270
Intel® Atom™ N270
Chipset
Intel® NM10
Intel® ICH8M
Intel® 945GSE + ICH7M
Intel® 945GSE + ICH7M
BIOS
Phoenix
AMI UEFI
Award
Award
Memory
1x DDR3 SODIMM up to 4GB
2x DDR3 SODIMM up to
4GB/2GB
1x DDR2 SODIMM up to 2GB
1x DDR2 SODIMM up to 2GB
Expansion
1x PCIe x1 slot
1x Mini-PCIe x1 socket
1x PCI slot
1x PCIe x1 slot
1x Mini-PCIe socket
1x PCIe x1 slot
1x PCIe x1 slot
1x Mini PCI socket
Display
VGA/HDMI/LVDS
VGA/LVDS
VGA/LVDS
VGA/DVI/LVDS
Audio
Realtek ALC662-GR HD Audio
codec
Realtek ALC892 HD Audio codec
Realtek ALC662-GR HD Audio
codec
Realtek ALC662-GR HD Audio
codec
LAN
2x GbE
2x GbE
1x GbE
2x GbE
Serial Port
2x RS232
3x RS232
1x RS232/422/485
2x RS232
3x RS232
1x RS232/422/485
USB
6x USB 2.0
6x USB 2.0
6x USB 2.0
6x USB 2.0
Storage Device
2x SATA
3x SATA
1x CF
1x FDD
2x SATA
1x CF
1x IDE
2x SATA
1x CF
1x IDE
GPIO
8-bit
16-bit
8-bit
8-bit
Others
PS/2 KB&MS
1x Parallel
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
Dimension
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
Page
98
99
100
101
0LQL,7;5HIHUHQFH7DEOH
Mini-ITX Reference Table
MODEL
WADE-8072
WADE-8170
WADE-8013
WADE-8014
WADE-8012
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Intel® AtomTM N270
Intel® AtomTM N270
Intel® Dual CoreTM/
Quad CoreTM
Intel® Dual CoreTM/
Quad CoreTM
Intel® Dual Core™/Quad
Core™
Chipset
Intel® 945GSE + ICH7M
Intel® 945GSE + ICH7M
Intel® Q77
Intel® C216 PCH
Intel® Q67 PCH
BIOS
Award
Award
Phoenix
Phoenix
AMI UEFI
Memory
1x DDR2 SODIMM up to
2GB
1x DDR2 SODIMM up
to 2GB
2x DDR3 DIMM up to
16GB
2x DDR3 DIMM up to
16GB
2x DDR3 DIMM up to
16GB
Expansion
1x PCI slot
1x PCIe x1 slot
1x Mini-PCIe socket
1x PCI slot
1x PCIe x1 slot
1x PCIe x16 slot
1x Mini-PCIe socket
1x PCIe x16 slot
1x Mini-PCIe socket
1x PCIe x16 slot
Display
VGA/LVDS
VGA/DVI/LVDS
VGA/DVI-D/HDMI
VGA/DVI-D/HDMI
VGA/DVI/HDMI
Audio
Realtek ALC662-GR HD
Audio codec
Realtek ALC888 HD
Audio codec
Realtek ALC886-GR HD
Audio codec
Realtek ALC886-GR HD
Audio codec
Realtek ALC662-GR HD
Audio codec
LAN
2x GbE
2x GbE
2x GbE
2x GbE
2x GbE
Serial Port
3x RS232
1x RS232/422/485
2x RS232
4x RS232
2x RS232/422/485
4x RS232
2x RS232/422/485
1x RS232
1x RS232/422/485
USB
6x USB 2.0
8x USB 2.0
4x USB 3.0
6x USB 2.0
4x USB 3.0
6x USB 2.0
8x USB 2.0
Storage
Device
2x SATA
1x IDE
2x SATA
1x IDE
1x CF
4x SATA
4x SATA
6x SATA
GPIO
8-bit
8-bit
16-bit
16-bit
16-bit
Others
1x TPM
1x Parallel
PS/2 KB&MS
1x S-Video
1x Parallel
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
Dimension
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
Page
102
103
104
105
106
0LQL,7;5HIHUHQFH7DEOH
92
Mini-ITX Reference Table
MODEL
93
WADE-8011
WADE-8180
WADE-8056
WADE-8556
WADE-8656
Form Factor
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
MINI-ITX
CPU
Intel® Dual Core™/
Quad Core™
Intel® Core™ 2 Quad/
Core™ 2 Duo
Intel® CoreTM 2 Quad/
CoreTM 2 Duo/Pentium® 4/
Celeron® D
Intel® CoreTM 2 Quad/
CoreTM 2 Duo/Pentium® 4/
Celeron® D
Intel® CoreTM 2 Quad/
CoreTM 2 Duo/Pentium® 4/
Celeron® D
Chipset
Intel® C206 PCH
Intel® Q45+ICH10DO
Intel® Q965+ICH8DO
Intel® Q965+ICH8DO
Intel® Q965+ICH8DO
BIOS
AMI UEFI
AMI Core 8
Award
Award
Award
Memory
2x DDR3 ECC DIMM up
to 16GB
2x DDR3 DIMM up to 4GB
2x DDR2 DIMM up to 4GB
2x DDR2 DIMM up to 4GB
2x DDR2 DIMM up to 4GB
Expansion
1x PCIe x16 slot
1x PCIe x16 slot
1x PCI slot
1x Mini-PCIe socket
1x PCI slot
1x Mini-PCI socket
1x PCIe x16 slot
Display
VGA/DVI/HDMI
VGA/DVI
VGA/DVI
VGA/DVI
VGA
Audio
Realtek ALC662-GR HD
Audio codec
Realtek ALC888 HD Audio
codec
Realtek ALC262-VC2-GR
HD Audio codec
Realtek ALC262-VC2-GR
HD Audio codec
Realtek ALC262-VC2-GR
HD Audio codec
LAN
2x GbE
2x GbE
1x GbE
1x GbE
2x GbE
Serial Port
1x RS232
1x RS232/422/485
2x RS232
4x RS232
4x RS232
1x RS232
1x RS232/422/485
USB
8x USB 2.0
8x USB 2.0
6x USB 2.0
6x USB 2.0
8x USB 2.0
Storage
Device
6x SATA
4x SATA
4x SATA
4x SATA
6x SATA
GPIO
16-bit
8-bit
8-bit
8-bit
8-bit
Others
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
PS/2 KB&MS
Dimension
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
170 x 170mm
Page
107
108
109
110
111
0LQL,7;5HIHUHQFH7DEOH
Intel® CoreTM i5/i7 processor based
Mini-ITX with DDR3 SDRAM, Dual
Display, Dual Gigabit Ethernet and
USB Ports
WADE-8020
Dual RS232 Ports
PGA 989 socket
Mini PCIe x1 slot
7KH:$'(LVEXLOWZLWKWKH,QWHO®PRELOH
40FKLSVHWZKLFKZRUNVZHOOZLWK,QWHO®&RUHTM
LLPRELOHSURFHVVRUWHFKQRORJLHVFDSDEOHRI
VXSSRUWLQJGXDOFKDQQHO''5PHPRU\7KHVH
IHDWXUHVPDNHWKH:$'(WKHLGHDOVROXWLRQIRU326/RWWHU\0HGLFDO*DPLQJ+LJK
5HVROXWLRQ'LJLWDO6LJQDJH6XUYHLOODQFH6HFXULW\
0RQLWRULQJDQG.LRVNDSSOLFDWLRQV
FEATURES
„,QWHO®&RUHTMLLSURFHVVRU4XDG&RUH&38
VXSSRUW
„,QWHO®403&+
„7ZRSLQ62',00VVXSSRUWGXDOFKDQQHO
GENERAL
SURFHVVRU
,QWHO®&RUH™LLRU&HOHURQ®SURFHVVRUZLWK0%/&DFKHLQ3*$
SDFNDJHVXSSRUWV,QWHO®9LUWXDOL]DWLRQ7HFKQRORJ\97[(QKDQFHG,QWHO
6SHHG6WHS®7HFKQRORJ\7KHUPDO0RQLWRULQJ7HFKQRORJLHV
&KLSVHW
,QWHO®%'403&+:
%,26
$0,8(),%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''50+]6'5$0RQWZRSLQ
62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWVXSWR*EVGDWDWUDQVIHUUDWH
5$,'
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
0RQLWRULQJ7HPSHUDWXUH9ROWDJHDQGFRROLQJIDQVWDWXV
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
[3&,ELWVORWDW0+]
[0LQL3&,HVORW
''56'5$0XSWR*%
„2QH3&,([SUHVV[DQGRQH3&,([SDQVLRQVORW
„2QH0LQL3&,HVRFNHWZLWK86%3&,H[VLJQDO
„7KUHH56SRUWVDQGRQH56SRUW
„6L[6$7$,,SRUWV
„'XDO'LVSOD\E\9*$'9,+'0,/9'6ELWV
„,QWHO®$FWLYH0DQDJHPHQW7HFKQRORJ\,QWHO®
$07
REAR I/O
RS232/422/485
RS232
VGA
HDMI
I/O INTERFACE
6XSHU,2
,7(,7)
$XGLR
,QWHO®40EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®/DQG,QWHO®/0'XDO*LJDELW(WKHUQHWFRQWUROOHUVVXSSRUW
L$07
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
[56SRUWRQSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVLVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
Gigabit Ethernet
DVI-D
USB
Audio
ORDERING GUIDE
AB1-3587
:$'(0LQL,7;(6%40ZR(&&
3*$Z''562',009*$/9'6'9,+'0,
'XDO*E(&20$XGLR86%
AA1-3050
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,)RU:$'(&
1.60
0
6.65
37.12
33.40
LVDS
One PCI slot
Intel® QM57
16 bits GPIO
Two SODIMM sockets
One PCIe x1 slot
Four USB Ports
Six SATA II ports
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®40LQWHJUDWHG,QWHO®+'*UDSKLFV*0$+'VXSSRUWVIXOOKDUGZDUH
DFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGVVXFK03(*03(*
6XSSRUWV,QWHO®*HQLQWHJUDWHG*UDSKLFV(QJLQH
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELW9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6GXDOFKDQQHOELW/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
+'0,GXDOFKDQQHOELW+'0,'LJLWDO+'0,UHVROXWLRQXSWR[:8;*$
'9,GXDOFKDQQHOELW'9,'LJLWDO'9,UHVROXWLRQXSWR[:8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
7\SLFDO&38#$96\VWHP#$9#$
6XSSRUWV$7;PRGH
One WADE-8020 Mini-ITX Main Board
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
One Installation CD
07%)
2YHUKRXUVDWƒ&
PACKING LIST
One SATA Cable
One I/O shield
BIOS
DDR
DDR 33
SATA
SATA
3.0
3Gb
LAN
USB
2.0DOG Giga
GPIO
H/W
MonitorWatch DOG
Watch
iAMT
6.0
H/W Monitor
2
GbE
GPIO
HDMI
0LQL,7;:$'( 94
Leading Intel® 45nm CoreTM 2 Duo processor or
Celeron® M processor based Mini-ITX with DDR3
SDRAM, HDMI, Dual Gigabit Ethernet, Audio and USB
WADE-8067
Dual RS232 Ports
16 bits GPIO
LVDS
One PCIe x4 slot
Intel® GM45
Intel® ICH9M-E
SODIMM socket
SODIMM socket
Two USB ports
%XLOWZLWKWKHODWHVWPRELOH,QWHO®*0([SUHVV
FKLSVHWWKH:$'(WDNHVDGYDQWDJHRI,QWHO®
&RUHTM'XRWHFKQRORJLHVZKLFKKDYHKLJKSHUIRUPDQFHDQGH[FHOOHQWSRZHUPDQDJHPHQWIHDWXUHV
,QDGGLWLRQLWVGLVSOD\HQULFKHGLQWHUIDFHFDQVXSSRUWYDULRXVPXOWLPHGLDGHYLFHV7KH:$'(
LVDQLQGXVWULDOJUDGHHPEHGGHG0LQL,7;PRWKHUERDUGLGHDOIRU326/RWWHU\0HGLFDO*DPLQJ
'95'LJLWDO6LJQDJHDQG.LRVNDSSOLFDWLRQV
FEATURES
„,QWHO®&RUHTM'XR&HOHURQ®0SURFHVVRUV
„,QWHO®*0DQG,&+0(&KLSVHW
„7ZR62',00VVXSSRUWGXDOFKDQQHO''5
6'5$0XSWR*%
„'XDO'LVSOD\9*$'9,+'0,/9'679RXW
UG'LVSOD\YLD3&,([SUHVVJUDSKLFFDUG
„6XSSRUW,QWHO®$FWLYH0DQDJHPHQW
7HFKQRORJ\
„,QWHJUDWHGODWHVW7UXVWHG3ODWIRUP0RGXOH
L730
REAR I/O
VGA
RS232/422/485
RS232
HDMI
Gigabit Ethernet
DVI-D
USB
Audio
ORDERING GUIDE
AB1-3164
AA1-3086
:$'(3(0LQL,7;(6%6RFNHW7\SH,QWHO&RUH
'XR3HQU\QZ9*$'9,+'0,'XDO*E($XGLR
3&,([
1.60
0
5.20
37.12
33.21
PGA 478 socket
Four SATA II ports
GENERAL
SURFHVVRU
- InteOŠ&RUHTM'XR&HOHURQ®0SURFHVVRUZLWK0%/&DFKHLQ3*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*0*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:DQG,&+0(
%,26
$0,&RUH%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''50+]6'5$0RQWZR
SLQ62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
5$,'
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP
7HPSHUDWXUH&386\VWHP
9ROWDJH&DVHRSHQIXQFWLRQ
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
I/O INTERFACE
6XSHU,2
:LQERQG:7+*
$XGLR
,QWHO®*0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&9&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®DQG,QWHO®/'XDO*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVLVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
2WKHU
[79RXWKHDGHU
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*0*0&+,QWHJUDWHG*UDSKLFV0HGLD$FFHOHUDWRU*0$0+'
VXSSRUWVIXOOKDUGZDUHDFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGV03(*$9&
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$DQDORJUHVROXWLRQXSWR[
'9,GLJLWDO'9,UHVROXWLRQXSWR[
/9'6GXDOFKDQQHOELW/9'6
+'0,UHVROXWLRQXSWR[
3(3$;6ORW5LVHU&DUGIRU5LJKW([SDQVLRQ2QH
3&,([6ORW)RU:$'(
Mechanical & Environment
PACKING LIST
One WADE-8067 Mini-ITX Main Board
One Installation CD
One SATA Cable
One I/O shield
One CPU Fan
95 0LQL,7;:$'(
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJH7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
BIOS
DDR 3
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
2
GbE
HDMI
Leading Intel® CoreTM 2 Duo processor based
Mini-ITX Board with DDR2 SDRAM, Dual
Displays, Two GbE LAN ports, Audio and USB
WADE-8066
Two SATA II ports
16 bits GPIO
Intel® ICH8ME
Four USB ports
LVDS
One PCI slot
PGA 478 socket
Intel® GME965
CF socket
SODIMM socket
One PCIe x1 slot
%DVHGRQWKHODWHVWODWHVWPRELOH,QWHO® *0(
FKLSVHWWKH:$'(WDNHVDGYDQWDJHRI
,QWHO®&RUHTM'XRWHFKQRORJLHV7KHJUDSKLF
PHGLDDFFHOHUDWRU*0$;SURYLGHVERWK
IDVWYLGHRUHVSRQVHWLPHDQGKLJKTXDOLW\LPDJHV:LWKLWVGLVSOD\HQULFKHGLQWHUIDFHWKH
:$'(FDQVXSSRUWYDULRXVPXOWLPHGLD
GHYLFHV
FEATURES
„,QWHO®&RUHTM'XRDQG&HOHURQ®0SURFHVVRU
„,QWHO®*0(DQG,&+0(FKLSVHW
„7ZRSLQ62',00VVXSSRUWGXDOFKDQQHO
''56'5$0XSWR*%
„'XDO'LVSOD\'9,,/9'6792XWUG'LVSOD\
YLDH[SDQVLRQVORW
„2QH3&,VORWDQGRQH3&,H[VORWZLWK3&,H
[VLJQDO
REAR I/O
RS232/422/485
KB/MS RS232
Gigabit Ethernet
DVI-I
USB
AB1-3179
GENERAL
SURFHVVRU
,QWHO®&RUHTM 'XR&HOHURQ®0SURFHVVRUZLWK0%/&DFKHLQ3*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH([HFXWH
'LVDEOH%LW
&KLSVHW
,QWHO®*0(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0(
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''50+]6'5$0RQWZRSLQ
62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
6\VWHPWHPSHUDWXUHYROWDJHDQGFRROLQJIDQPRQLWRULQJ
$XWRWKURWWOLQJFRQWUROZKHQ&38RYHUKHDWV
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7VZLWK3&,H[VLJQDO
[3&,ELWVORW
I/O INTERFACE
6XSHU,2
:LQERQG:7+*
$XGLR
,QWHO®*0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®00DQG0DUYHOO('XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVLVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
Audio
ORDERING GUIDE
:$'(0LQL,7;(6%,QWHO3HQWLXP0'XDO
&RUHZ''56'5$09*$/9'6'XDO'LVSOD\'XDO
*E($XGLR
AA1-3049
3(356ORWV5LVHU&DUGIRU5LJKW([SDQVLRQ
2QH3&,DQG2QH3&,([)RU:$'(
AA1-3072
3(556ORW5LVHU&DUGIRU5LJKW([SDQVLRQ
2QH3&,([)RU:$'(
1.60
0
7.90
37.10
33.62
SODIMM socket
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*0(,QWHJUDWHG*0$;*UDSKLFVGHYLFHVXSSRUWVKDUGZDUH
DFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGVVXFK0&
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELW9*$DQDORJUHVROXWLRQXSWR[4;*$
'9,GXDOFKDQQHOELW'9,'LJLWDO'9,UHVROXWLRQXSWR[8;*$
/9'6GXDOFKDQQHOELW/9'6
Mechanical & Environment
PACKING LIST
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
7\SLFDO96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
One Installation CD
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
One SATA Cable
07%)
2YHUKRXUVDWƒ&
One WADE-8066 Mini-ITX Main Board
One I/O shield
One CPU Fan
DDR 2
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
6
USB
2
GbE
0LQL,7;:$'( 96
WADE-8068
Leading Mobile Intel® CoreTM 2 Duo processor
Mini-ITX with DDR2 SDRAM, Dual Displays, Two
GbE LAN ports, Four COM Ports, LPT and USB
Two SATA II ports
Dual RS232 Ports
Intel® ICH8ME
Four USB ports
16 bits GPIO
LVDS
CF socket
One PCI slot
PGA 478 socket
Intel® GME965
One PCIe x1 slot
SODIMM socket
7KH:$'(EXLOWZLWK,QWHO®PRELOH*0(
FKLSVHWWDNHVDGYDQWDJHRI,QWH®&RUHTM'XR
WHFKQRORJLHV%DVHGRQDQLQWHJUDWHGJUDSKLF
PHGLDDFFHOHUDWRU*0$;JUDSKLFGHYLFH
WKH:$'(ZLWKLWVGLYHUVHVHULDOSRUWV
PDNHVLWLGHDOIRUDSSOLFDWLRQVVXFKDV3DQHO
3&V/RWWHU\0HGLFDO*DPLQJDQG'LJLWDO
6LJQDJH
1.60
0
6.50
33.82
SODIMM socket
GENERAL
SURFHVVRU
,QWHO®&RUHTM'XR&HOHURQ®0SURFHVVRULQ3*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*0(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0(
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''50+]6'5$0RQWZR
SLQ62',00VRFNHW
„,QWHO®&RUHTM'XRDQG&HOHURQ®0SURFHVVRUV
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
„,QWHO®*0(DQG,&+0(&KLSVHW
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„7ZRSLQ62',00VVXSSRUWGXDOFKDQQHO
''56'5$0XSWR*%
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH&DVH
RSHQIXQFWLRQ
„'XDO'LVSOD\9*$ELW/9'6UG'LVSOD\YLD
H[SDQVLRQVORW'XDO*LJDELW(WKHUQHWSRUWV
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7VZLWK3&,H[VLJQDO
[3&,ELWVORW
FEATURES
„7ZR6$7$,,SRUWVDQG2QH7\SH,,&RPSDFW)ODVK
I/O INTERFACE
„2QH3&,VORWDQGRQH3&,H[VORWZLWK3&,H
[VLJQDO
6XSHU,2
:LQERQG:8+*
„7KUHH56SRUWVDQGRQH56SRUW
$XGLR
,QWHO®*0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH
Ethernet
,QWHO®00DQG5HDOWHN&'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56RQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
[56RQSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVLVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
2WKHU
[SDUDOOHOSRUWRQERDUGSLQKHDGHU
REAR I/O
RS232/422/485
KB/MS
RS232
Gigabit Ethernet
VGA
USB
Audio
ORDERING GUIDE
AB1-3233
:$'(0LQL,7;(6%,QWHO&RUH'XR&HOHURQ
0Z''56'5$09*$/9'6'XDO*E($XGLR
AA1-3027
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,
AA1-3050
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,
AA1-3049
3(356ORWV5LVHU&DUGIRU5LJKW([SDQVLRQ
2QH3&,DQG2QH3&,([
PACKING LIST
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*0(,QWHJUDWHG*0$;*UDSKLFVGHYLFHVXSSRUWVKDUGZDUH
DFFHOHUDWLRQRIYLGHRGHFRGHVWDQGDUGVVXFK0&
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELW9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6GXDOFKDQQHOELW/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
Mechanical & Environment
One WADE-8068 Mini-ITX Main Board
'LPHQVLRQ
/[:PP/[:
One Installation CD
3RZHU6XSSO\
7\SLFDO96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
One SATA Cable
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One I/O shield
One CPU Fan
One COM Cable
One LPT Cable
97
0LQL,7;:$'(
DDR 2
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
6
USB
2
GbE
®
Intel Next-Gen AtomTM processor based Mini-ITX
Board with dual display, dual Gigabit Ethernet, Two
SATA Ports, Two COM Ports (optional up to 4 COM
ports) and Six USB Ports
WADE-8077
3&,H[VORW
:,1%21'
:
:
:'+*
,QWHO® 10
,,QWHO® '
7ZR6$7$SRUWV
6
62',00VRFNHW
:$'(LVGHVLJQHGWRSURYLGHKLJKSHUIRUPDQFH DQG IOH[LELOLW\ IRU IXQFWLRQDO H[SDQVLRQ
DQG LV LGHDO IRU DSSOLFDWLRQV LQ *DPLQJ .LRVN
'LJLWDO 6LJQDJHDQG ,QGXVWULDO$XWRPDWLRQ DQG
FRQWURO
0LQL3&,H[VORW
GENERAL
SURFHVVRU
,QWHO® AtomTM'*+]:SURFHVVRULQ)&%*$SDFNDJH
&KLSVHW
,QWHO®10([SUHVVFKLSVHW
%,26
- 3KRHQL[%,2663,520
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQRQH
SLQ62',00VRFNHW
„,QWHO®10&KLSVHW
6WRUDJH'HYLFHV
[6$7$,,VXSSRUWLQJXSWR*EVGDWDWUDQVIHUUDWH
„2QHSLQ62',00VXSSRUWVVLQJOH
FKDQQHO''56'5$0XSWR*%
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
- )$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH
- %HHSDODUPVIRU¿HOGIDQRXWRYHUXQGHUYROWDJHRI'&
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
[0LQL3&,HVORW*HQ*7V
FEATURES
„,QWHO® AtomTM'SURFHVVRU
„'XDOGLVSOD\9*$/9'6ELWGXDO
FKDQQHO+'0,
„2QH0LQL3&,HDQGRQH3&,([SUHVV[
H[SDQVLRQVORW
„7ZR6$7$,,SRUWV
I/O INTERFACE
„7ZR&20SRUWVRSWLRQDOXSWR&20SRUWV
6XSHU,2
:,1%21':'+*
„:$03IXQFWLRQRSWLRQDO
$XGLR
,QWHO®10EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
57/)'XDO*LJDELW(WKHUQHW
6HULDO3RUW
[56RQUHDU,2
[56ZLWKKHDGHURSWLRQDO
[56VHOHFWDEOHZLWKKHDGHURSWLRQDO
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
REAR I/O
Gigabit Ethernet
RS232
VGA
HDMI
USB
Audio
ORDERING GUIDE
AB1-3799
5:$'(0LQL,7;(6%,QWHO&HGDU7UDLO
*'RQ%RDUG10Z''562',00
9*$+'0,ELWV/9'6'XDO*E(&20$XGLR86%
PACKING LIST
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*UDSKLFV7HFKQRORJ\SURYLGHVDYLVXDOO\VWXQQLQJH[SHULHQFH
RSWLPL]HGIRU%OXUD\DQG+'YLGHRZLWK:LQGRZV9LVWDVXSSRUW
6XSSRUWV'LUHFW;FRPSOLDQW3L[HO6KDGHUYDQG2*/
'LVSOD\,QWHUIDFH
9*$DQDORJUHVROXWLRQXSWR[RQUHDU,2
+'0,UHVROXWLRQXSWR[RQUHDU,2
/9'6'LJLWDOELWV/9'6UHVROXWLRQXSWR[RQERDUG
One WADE-8077 Mini-ITX Main Board
One Installation CD
One SATA Cable
One I/O shield
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
$7;SLQSRZHULQSXW
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJHWHPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
DDR 3
SATA
3Gb
HDMI
USB 2.0
MiniPCIe
VGA
LVDS
0LQL,7;:$'(
98
Intel® Dual CoreTM AtomTM D525 1.8GHz/N455
1.67GHz processor based Mini-ITX with DC12V
input, DDR3 SDRAM, Dual display, Dual Gigabit
Ethernet, Three SATA, Four COM and Six USB ports
WADE-8075/76
Two USB ports
16 bits GPIO
One PCI slot
LVDS
Intel® ICH8M
Intel® D525/N455
Mini PCIe x1 slot
CF socket
%DVHGRQ,QWHO® PRELOH,&+0FKLSVHWWKH
:$'(WDNHVDGYDQWDJHVRI,QWHO® AtomTM
'1WHFKQRORJLHV:$'(ZKLFK
IHDWXUHVORZSRZHULVFDSDEOHRISURYLGLQJGXDO
GLVSOD\VVXFKDV/9'6DQG9*$,QDGGLWLRQWKH
IDQOHVVORZSRZHU:$'(LVWKHEHVW
VROXWLRQIRU3260HGLFDO*DPLQJDQG'LJLWDO
6LJQDJHDSSOLFDWLRQV
1.60
0
7.80
33.14
28.93
One PCIe x1 slot
Two SODIMM socket
Two SATA power connector
One SATA II ports
GENERAL
SURFHVVRU
,QWHO® AtomTM'*+]:1*+]:SURFHVVRULQ3*$SDFNDJH
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\,QWHO®([HFXWH'LVDEOH%LW
(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\1RQO\
&KLSVHW
,QWHO®,&+0*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0
%,26
$0,8)(,%,26
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQWZRSLQ
62',00VRFNHW:$'(VXSSRUWVXSWR*%''5
6WRUDJH'HYLFHV
„,QWHO® AtomTM'*+]1*+]
SURFHVVRU
[6$7$SRUW*EVGDWDWUDQVIHUUDWH
[6$7$SRUWVZLWKSRZHUVXSSRUW
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„,QWHO®,&+0&KLSVHW
+DUGZDUH0RQLWRULQJ
„7ZRSLQ62',00VVXSSRUWVLQJOHFKDQQHO
''56'5$0XSWR*%
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH$XWR
WKURWWOLQJFRQWUROZKHQ&38RYHUKHDWV
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
[3&,ELWVORW
[0LQL3&,HVORW*HQ*7V
FEATURES
„'XDO'LVSOD\E\9*$/9'6ELWVRUELWV
„2QH3&,([SUHVV[RQH3&,H[SDQVLRQVORW
DQGRQH0LQL3&,HVRFNHWZLWK86%3&,H[
VLJQDO
6XSHU,2
:LQERQG:'*
„ 7KUHH56SRUWVDQGRQH56SRUW
$XGLR
,QWHO®,&+0EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH
Ethernet
57/'['XDO*LJDELW(WKHUQHW
6HULDO3RUW
[5699VHOHFWDEOHSRUWRQUHDU,2
[5699VHOHFWDEOHZLWKKHDGHU
[5699VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
2WKHU
[SDUDOOHUSRUWRQERDUGER[KHDGHU
REAR I/O
RS232
RS232/422/485
DC-in
Gigabit Ethernet
VGA
Audio
USB
ORDERING GUIDE
AB1-3584
:$'(0LQL,7;(6%,QWHO3LQHYLHZ*'
RQ%RDUG,&+0Z''562',009*$ELWV
/9'6'XDO*E(&20$XGLR86%
AB1-3585
:$'(0LQL,7;(6%,QWHO3LQHYLHZ*
1RQ%RDUG,&+0Z''562',00
9*$ELWV/9'6'XDO*E(&20$XGLR86%
AA1-3102Z
3(3&5;2QH3&,([6ORW5LVHU&DUGIRU
5LJKW([SDQVLRQ3&,QRVLJQDO3&,HFRQQHFWRUV
PACKING LIST
I/O INTERFACE
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®,&+0,QWHJUDWHG*0$*UDSKLFVVXSSRUWVIXOOKDUGZDUH
DFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGV03(*
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHOŠ'907
'LVSOD\,QWHUIDFH
'XDO&KDQQHOELW:$'(
6LQJOH&KDQQHOELW:$'(
9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
One WADE-8075/76 Mini-ITX Main Board
3RZHU6XSSO\
'&9LQSXW
One Installation CD
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Cable
One SATA Power Cable
One I/O shield
BIOS
99
0LQL,7;:$'(
DDR 3
SATA
3Gb
Watch DOG
DOG
H/WWatch
Monitor
H/W
Monitor
GPIO
Fanless
4
COM
6
USB
2
GbE
Intel® Low Power AtomTM N270 1.6GHz processor based
Mini-ITX Board with DC12V input, dual display, Gigabit
Ethernet, Two SATA Ports, Two COM ports and Six USB
Ports support thin client application
WADE-8071
KB/MS
8 bits GPIO
One PCIe x1 slot
Intel® ICH7-M
Intel® 945GSE
SODIMM socket
LVDS
Intel® N270
Two SATA II ports
CF socket
17.76
1.60
0
8.30
Two USB ports
IDE connector
6XSSRUWHGE\WKH,QWHO®PRELOH*6(FKLSVHW
:$'(WDNHVDGYDQWDJHRI,QWHO® AtomTM
1WHFKQRORJLHV:$'(IHDWXUHVORZ
SRZHUZKLOHSURYLGLQJGXDOGLVSOD\VVXFKDV
/9'6DQG9*$,QDGGLWLRQWKHIDQOHVVORZ
SRZHU:$'(LVWKHPRVWVXLWDEOHFKRLFH
IRU3260HGLFDO*DPLQJDQG'LJLWDO6LJQDJH
DSSOLFDWLRQV
FEATURES
„,QWHO® AtomTM1*+]SURFHVVRU
„,QWHO®*6(DQG,&+0FKLSVHW
„2QHSLQ62',00VXSSRUWVVLQJOHFKDQQHO
''56'5$0XSWR*%
„'XDOGLVSOD\9*$/9'6UGGLVSOD\YLD3&,
([SUHVV[JUDSKLFFDUG
„2QH3&,([SUHVV[H[SDQVLRQVORW
„PPKHLJKWVXSSRUWVWKLQFOLHQWDSSOLFDWLRQ
GENERAL
SURFHVVRU
,QWHO® AtomTM1*+]:SURFHVVRULQ3%*$SDFNDJH/
&DFKH.%
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHS®
7HFKQRORJ\7KHUPDO0RQLWRULQJ7HFKQRORJLHV([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*6(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQRQH
SLQ62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$SRUW*EVGDWDWUDQVIHUUDWH
[,'(FRQQHFWRUVXSSRUWV8OWUD'0$0%V
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH&DVH
RSHQIXQFWLRQ
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
I/O INTERFACE
6XSHU,2
:LQERQG:+*
$XGLR
,QWHO®*6(EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH
Ethernet
5HDOWHN57/&*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56SRUWRQSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
REAR I/O
DC-in COM port
USB
Audio
VGA Gigabit Ethernet
ORDERING GUIDE
AB1-3284
AA1-3078
:$'(0LQL,7;(6%*6(1
SURFHVVRU9'&,QSXWZ''56'5$09*$
/9'6[*E($XGLR
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*6(,QWHJUDWHG*UDSKLFV0HGLD$FFHOHUDWRU*0$VXSSRUWV
KDUGZDUHDFFHOHUDWLRQRIYLGHRGHFRGHVWDQGDUGV0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHO9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6GXDOFKDQQHOELWDQGELWRXWSXW'LJLWDO/9'6UHVROXWLRQXSWR
[8;*$
3(556ORW5LVHU&DUG3&,([WR3&,([
PACKING LIST
One WADE-8071 Mini-ITX Main Board
Mechanical & Environment
One Installation CD
'LPHQVLRQ
/[:PP/[:
One SATA Cable
3RZHU6XSSO\
'&9LQSXW
One SATA Power Cable
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One USB Cable
One IDE Cable
One I/O shield
Giga
DDR 2
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
6
USB
0LQL,7;:$'(
100
Intel® Low Power AtomTM N270 1.6GHz processor based
Mini-ITX Board with dual display, Gigabit Ethernet, Two
SATA Ports, Four COM ports and Six USB Ports
WADE-8070
Two RS232 ports
8 bits GPIO
IDE connector
One PCIe x1 slot
LVDS
Intel® ICH7-M
Intel® 945GSE
SODIMM socket
Two USB ports
Two SATA II ports
Intel® N270
CF socket
33.19
18.58
1.60
0
8
Mini-PCI socket
%XLOWZLWKWKH,QWHO®PRELOH*6(FKLSVHW
:$'(WDNHVDGYDQWDJHRI,QWHO® AtomTM
1WHFKQRORJLHV7KLVORZSRZHUIDQOHVV
:$'(PDNHVLWPRVWVXLWDEOHIRU326
0HGLFDO*DPLQJDQG'LJLWDO6LJQDJHDSSOLFDWLRQV
FEATURES
„,QWHO® AtomTM1*+]SURFHVVRU
GENERAL
SURFHVVRU
- ,QWHO® AtomTM1*+]:SURFHVVRULQ3%*$SDFNDJH/&DFKH.%
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHS®
7HFKQRORJ\7KHUPDO0RQLWRULQJ7HFKQRORJLHV([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*6(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQRQH
SLQ62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$SRUW*EVGDWDWUDQVIHUUDWH
[,'(FRQQHFWRUVXSSRUWV8OWUD'0$0%V
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH&DVH
RSHQIXQFWLRQ
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
[0LQL3&,VRFNHW
„,QWHO®*6(DQG,&+0FKLSVHW
„2QHSLQ62',00VXSSRUWVVLQJOHFKDQQHO
''56'5$0XSWR*%
„'XDOGLVSOD\9*$/9'6'9,UGGLVSOD\YLD
3&,([SUHVV[JUDSKLFFDUG
„2QH0LQL3&,DQGRQH3&,([SUHVV[
H[SDQVLRQVORW
„7ZR6$7$RQH&RPSDFW)ODVKVRFNHWRQH
IDE connector
REAR I/O
RS232/422/485
KB/MS RS232
VGA Gigabit Ethernet
DVI-I
USB
Audio
ORDERING GUIDE
AB1-3242
:$'(0LQL,7;(6%*6(1
SURFHVVRUZ''56'5$09*$/9'6'XDO*E(
(WKHUQHW$XGLR
AA1-3089Z
3(3%;6ORW5LVHU&DUGIRU5LJKW([SDQVLRQ
2QH3&,([6ORW)RU:$'(
PACKING LIST
I/O INTERFACE
6XSHU,2
:LQERQG:8+*
$XGLR
,QWHO®*6(EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH
Ethernet
5HDOWHN&'XDO*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHRQUHDU,2
[56SRUWRQSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*6(,QWHJUDWHG*UDSKLFV0HGLD$FFHOHUDWRU*0$VXSSRUWV
KDUGZDUHDFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGV0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELW9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6GXDOFKDQQHOELW/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
'9,,2QHFRQQHFWRURQUHDU,2
One WADE-8070 Mini-ITX Main Board
One Installation CD
Mechanical & Environment
One SATA Cable
'LPHQVLRQ
/[:PP/[:
One COM Cable
3RZHU6XSSO\
7\SLFDO9&38#$9#$9#$9#$
6XSSRUWV$7;PRGH
One USB Cable
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One IDE Cable
One I/O shield
Giga
DDR 2
101
0LQL,7;:$'(
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
Fanless
4
COM
6
USB
WADE-8072
Intel® Low Power AtomTM N270 1.6GHz processor based
Mini-ITX Board with dual display, Gigabit Ethernet, Two
SATA Ports, Four COM ports and Six USB Ports
Dual RS232 ports
Two USB ports
LVDS
IDE connector
One PCI slot
Intel® 945GSE
Intel® ICH7-M
SODIMM socket
CF socket
Two SATA II ports
One PCIe x1 slot
Intel® N270
34.01
1.60
0
5.60
Mini PCIe x1 socket
%DVHGRQWKH,QWHO®PRELOH*6(FKLSVHW
:$'(WDNHVDGYDQWDJHRI,QWHO® AtomTM
1WHFKQRORJLHV7KLVORZSRZHUIDQOHVV
PRGHO:$'(PDNHVLWPRVWVXLWDEOH
IRU3260HGLFDO,QGXVWULDO&RQWURODQG'LJLWDO
6LJQDJHDSSOLFDWLRQV
GENERAL
SURFHVVRU
,QWHO® AtomTM1*+]:SURFHVVRULQ3%*$SDFNDJH/
&DFKH.%
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHS®
7HFKQRORJ\7KHUPDO0RQLWRULQJ7HFKQRORJLHV([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*6(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQRQH
SLQ62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$SRUW*EVGDWDWUDQVIHUUDWH
[,'(FRQQHFWRUVXSSRUWV8OWUD'0$0%V
„,QWHO®*6(DQG,&+0FKLSVHW
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„2QHSLQ62',00VXSSRUWVVLQJOHFKDQQHO
''56'5$0XSWR*%
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH&DVH
RSHQIXQFWLRQ
„'XDOGLVSOD\9*$/9'6UGGLVSOD\YLD
H[SDQVLRQVORW
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7V
[3&,ELWVORW
[0LQL3&,HVRFNHW*HQ*7V
FEATURES
„,QWHO® AtomTM1*+]SURFHVVRU
„7ZR6$7$RQH&RPSDFW)ODVKVRFNHWRQH
IDE connector
„2QH3&,VORWRQH3&,H[H[SDQVLRQVORWDQG
RQH0LQL3&,HVRFNHW
„7KUHH56SRUWVDQGRQH56
SRUW
REAR I/O
RS232/422/485
KB/MS RS232
AA1-3027
VGA
USB
Audio
:$'(0LQL,7;(6%*6(1
SURFHVVRUZ''56'5$09*$/9'6'XDO*E(
(WKHUQHW&20$XGLR
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,)RU:$'(
PACKING LIST
One WADE-8072 Mini-ITX Main Board
One Installation CD
One SATA Cable
One COM Cable
:LQERQG:8+*
$XGLR
,QWHO®*6(EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH
Ethernet
5HDOWHN&'XDO*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHRQUHDU,2
[56SRUWRQSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
2WKHU
[730SLQKHDGHU
[SDUDOOHOSRUWRQSLQKHDGHU
Gigabit Ethernet
ORDERING GUIDE
AB1-3353
I/O INTERFACE
6XSHU,2
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*6(,QWHJUDWHG*UDSKLFV0HGLD$FFHOHUDWRU*0$VXSSRUWV
KDUGZDUHDFFHOHUDWLRQRIYLGHRGHFRGHVWDQGDUGV0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELW9*$DQDORJUHVROXWLRQXSWR[4;*$
/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
7\SLFDO96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One LPT Cable
One I/O shield
Giga
DDR 2
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
Fanless
4
COM
6
USB
MiniPCIe
0LQL,7;:$'(
102
Intel® AtomTM N270 processor based Mini-ITX Board
with Dual Display, Dual Gigabit Ethernet, Two SATA
Ports, Two COM ports and Eight USB Ports
WADE-8170
Realtek
RTL8111DL
Intel® 945GSE
Four USB ports
SODIMM socket
Two SATA II ports
Intel® ICH7-M
One PCI slot
IDE connector
One PCIe x1 slot
CF socket
Intel® N270
%XLOWZLWKWKH,QWHO®PRELOH*6(FKLSVHW
:$'(WDNHVDGYDQWDJHRI,QWHO® AtomTM
1WHFKQRORJLHV:$'(IHDWXUHVORZ
SRZHUZKLOHSURYLGLQJPXOWLSOHGLVSOD\VVXFK
DV/9'69*$79RXWDQG'9,%DVHGRQ
99a9'&SRZHULQSXWGHVLJQWKH
:$'(ZRXOGEHWKHEHVWVROXWLRQIRU
3260HGLFDO*DPLQJDQG'LJLWDO6LJQDJH
DSSOLFDWLRQV
1.60
0
3.30
40.10
33.58
ITE IT8712F
GENERAL
SURFHVVRU
,QWHO® AtomTM1*+]:SURFHVVRULQ3%*$SDFNDJH/
&DFKH.%
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHS®
7HFKQRORJ\7KHUPDO0RQLWRULQJ7HFKQRORJLHV([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®*6(*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+0
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVVLQJOHFKDQQHOXSWR*%''50+]6'5$0RQRQHSLQ
62',00VRFNHW
6WRUDJH'HYLFHV
[6$7$SRUWVXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
[SLQ,'(FRQQHFWRUVXSSRUWV8OWUD'0$0%V
[&RPSDFW)ODVKVRFNHWVXSSRUWV8OWUD'0$0%V
„,QWHO® AtomTM1*+]SURFHVVRU
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„,QWHO *6(DQG,&+0FKLSVHW
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH&DVH
RSHQIXQFWLRQ
([SDQVLRQ,QWHUIDFH
[3&,ELWVORW
[3&,([SUHVV[VORW*HQ*7VWKURXJKULVHUFDUG
FEATURES
®
„99a9'&3RZHU,QSXW
„2QHSLQ62',00VXSSRUWVVLQJOHFKDQQHO
''56'5$0XSWR*%
„'XDOGLVSOD\9*$/9'6'9,792XWUG
GLVSOD\YLDULVHUFDUG
„2QH3&,H[SDQVLRQVORW7ZR3&,RQH3&,
([SDQVLRQ[VORWVYLDULVHUFDUG
„7ZR6$7$RQH&RPSDFW)ODVKVRFNHWRQH
IDE connector
REAR I/O
VGA
KB/MS
RS232
DVI-D
USB
Audio
AB1-3269
:$'(0LQL,7;(6%*6(1
SURFHVVRUZ''56'5$09*$/9'6'XDO*E(
(WKHUQHW$XGLR9'&,QSXW
AA1-3102Z
3(3&5;2QH3&,([6ORW5LVHU&DUGIRU
5LJKW([SDQVLRQ3&,QRVLJQDO3&,HFRQQHFWRUV
PACKING LIST
One WADE-8170 Mini-ITX Main Board
One SATA Cable
,7(,7)
$XGLR
,QWHO®*6(EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
5HDOWHN&'XDO*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKKHDGHU
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
2WKHU
[69LGHRKHDGHU
Gigabit Ethernet
ORDERING GUIDE
One Installation CD
I/O INTERFACE
6XSHU,2
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®*6(,QWHJUDWHG*UDSKLFV0HGLD$FFHOHUDWRU*0$VXSSRUWV
KDUGZDUHDFFHOHUDWLRQRIYLGHRGHFRGLQJVWDQGDUGV0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$GXDOFKDQQHOELWV/9'6DQDORJUHVROXWLRQXSWR[4;*$
/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
'9,'LJLWDO'9,UHVROXWLRQXSWR[8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
'&9LQSXW
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Power Cable
Giga
One I/O shield
103
0LQL,7;:$'(
DDR 2
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
Fanless
USB 2.0
Giga LAN
Intel® Next-Gen Dual/Quad processor based Mini-ITX
Board with dual Gigabit Ethernet, Four SATA Ports,
Six COM Ports, One PCI-Express x16 expansion slot
and one Mini-PCIe slot support mSATA interface
WADE-8013
,7(,7)
0LQL3&,H[VORW
,QWHO® 43&+
/*$VRFNHW
3&,H[VORW
7ZR6$7$,,SRUWV
'XDO''5',00VRFNHWV
:$'( VXSSRUWV WKH ODWHVW UG JHQHUDWLRQ
,QWHO®&RUHTMSURFHVVRUSODWIRUPLQDQ/*$
SDFNDJH LQWHJUDWHG ZLWK WKH PHPRU\ DQG 3&,
([SUHVVFRQWUROOHUVXSSRUWLQJWZRFKDQQHO''5
PHPRU\ DQG 3&, ([SUHVV ODQHV WR SURYLGH
JUHDWJUDSKLFVSHUIRUPDQFH
FEATURES
„,QWHO® QH[W*HQ'XDO4XDGSURFHVVRULQ
/*$SDFNDJH
„,QWHO® 4&KLSVHW
„7ZRSLQ/RQJ',00VXSSRUWV''5
6'5$0XSWR*%
„'XDOGLVSOD\9*$'9,+'0,
„2QH3&,([SUHVV[H[SDQVLRQVORW
„)RXU6$7$SRUWV[6$7$,,[6$7$,,,
„6L[&20SRUWV
„2QH0LQL3&,HVORWVXSSRUWVP6$7$LQWHUIDFH
REAR I/O
RS232/422/485
Audio
RS232
VGA
DVI-D
Gigabit Ethernet
HDMI
USB3.0
GENERAL
SURFHVVRU
,QWHO®'XDO&RUHTM4XDG&RUHTMSURFHVVRULQ/*$SDFNDJH
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\,QWHO®9LUWXDOL]DWLRQ7HFKQRORJ\
97[,QWHO®$GYDQFHG9HFWRU([WHQVLRQV$9;
&KLSVHW
,QWHO®43&+
%,26
- 3KRHQL[%,2663,520
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQ
WZRSLQDQGVRFNHWV
6WRUDJH'HYLFHV
[6$7$,,VXSSRUWLQJXSWR*EVGDWDWUDQVIHUUDWH
[6$7$,,,VXSSRUWLQJXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP
%HHSDODUPVIRU¿HOGIDQRXWRYHUXQGHUYROWDJHRI'&YROWDJHVDQGRYHU
WHPSHUDWXUHWKUHVKROG
([SDQVLRQ,QWHUIDFH
- [3&,([SUHVV[VORW*HQ*7VVXSSRUW3&,H[[[[PRGH
- [0LQL3&,HVORW
I/O INTERFACE
6XSHU,2
,7(,7)
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHO
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®9VXSSRUWL$07DQG,QWHO® /'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
[56ZLWKKHDGHU
[56ZLWKKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
)RU86%0EVEXVFRPSUHKHQGVWKHKLJKVSHHGIXOOVSHHGORZ
VSHHGGDWDUDQJHV
)RU86%*ESVEXVFRPSUHKHQGVWKHKLJKVSHHGIXOOVSHHGORZ
VSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
ORDERING GUIDE
AB1-3709
5:$'(0LQL,7;(6%4ZR(&&
3*$Z''56'5$09*$'9,'+'0,'XDO
*E(&20$XGLR86%
PACKING LIST
7ZR6$7$,,,SRUWV
DISPLAY
One WADE-8013 Mini-ITX Main Board
*UDSKLF&RQWUROOHU
,QWHO®4,QWHJUDWHG'*0$VXSSRUW';2SHQ*/03(*
6KDGHU0RGHO
One Installation CD
'LVSOD\,QWHUIDFH
9*$2QHFRQQHFWRU'%RQUHDU,2DQDORJUHVROXWLRQXSWR[
+'0,2QHFRQQHFWRURQUHDU,2VXSSRUWXSWR[UHVROXWLRQ
'9,'2QHFRQQHFWRURQUHDU,2'LJLWDO'9,UHVROXWLRQXSWR[
One SATA Cable
One I/O shield
Mechanical & Environment
Watch DOG
VGA
GPIO
DVI-D
DDR 3
SATA
6Gb
USB 3.0
2
GbE
HDMI
MiniPCIe
'LPHQVLRQ
- /[:PP/[:
3RZHU6XSSO\
- $7;SLQSRZHULQSXW
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJHWHPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
- 2YHUKRXUVDWƒ&
0LQL,7;:$'(
104
WADE-8014
Intel® Next-Gen Dual/Quad processor based Mini-ITX
Board with dual Gigabit Ethernet, Four SATA Ports,
Six COM Ports, One PCI-Express x16 expansion slot
and one Mini-PCIe slot support mSATA interface
,7(,7)
0LQL3&,H[VORW
,QWHO® &3&+
/*$VRFNHW
3&,H[VORW
7ZR6$7$,,SRUWV
'XDO''5/RQJ',00VRFNHWV
:$'( VXSSRUWV WKH ODWHVW UG JHQHUDWLRQ
,QWHO®&RUHTMSURFHVVRUSODWIRUPLQDQ/*$
SDFNDJH LQWHJUDWHG ZLWK WKH PHPRU\ DQG 3&,
([SUHVVFRQWUROOHUVXSSRUWLQJWZRFKDQQHO''5
PHPRU\ DQG 3&, ([SUHVV ODQHV WR SURYLGH
JUHDWJUDSKLFVSHUIRUPDQFH
FEATURES
„,QWHO® QH[W*HQ'XDO4XDGSURFHVVRULQ
/*$SDFNDJH
„,QWHO® &&KLSVHW
„7ZRSLQ/RQJ',00VXSSRUWV''5
6'5$0XSWR*%
„'XDOGLVSOD\9*$'9,+'0,
„2QH3&,([SUHVV[H[SDQVLRQVORW
„)RXU6$7$SRUWV[6$7$,,[6$7$,,,
„6L[&20SRUWV
„2QH0LQL3&,HVORWVXSSRUWVP6$7$LQWHUIDFH
REAR I/O
RS232/422/485
Audio
RS232
VGA
DVI-D
Gigabit Ethernet
HDMI
USB3.0
GENERAL
SURFHVVRU
,QWHO®'XDO&RUHTM4XDG&RUHTMSURFHVVRULQ/*$SDFNDJH
)6%0+]
6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\,QWHO®9LUWXDOL]DWLRQ7HFKQRORJ\
97[,QWHO®$GYDQFHG9HFWRU([WHQVLRQV$9;
&KLSVHW
,QWHO®&3&+
%,26
- 3KRHQL[%,2663,520
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQ
WZRSLQDQGVRFNHWV
6WRUDJH'HYLFHV
[6$7$,,VXSSRUWLQJXSWR*EVGDWDWUDQVIHUUDWH
[6$7$,,,VXSSRUWLQJXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP
%HHSDODUPVIRU¿HOGIDQRXWRYHUXQGHUYROWDJHRI'&YROWDJHVDQGRYHU
WHPSHUDWXUHWKUHVKROG
([SDQVLRQ,QWHUIDFH
- [3&,([SUHVV[VORW*HQ*7VVXSSRUW3&,H[[[[PRGH
- [0LQL3&,HVORW
I/O INTERFACE
6XSHU,2
,7(,7)
$XGLR
,QWHO®&EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHO
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®9VXSSRUWL$07DQG,QWHO® /'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
[56ZLWKKHDGHU
[56ZLWKKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
)RU86%0EVEXVFRPSUHKHQGVWKHKLJKVSHHGIXOOVSHHGORZ
VSHHGGDWDUDQJHV
)RU86%*ESVEXVFRPSUHKHQGVWKHKLJKVSHHGIXOOVSHHGORZ
VSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQERDUG
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
ORDERING GUIDE
AB1-3709
5:$'(0LQL,7;(6%&Z(&&
3*$Z''56'5$09*$'9,'+'0,'XDO
*E(&20$XGLR86%
PACKING LIST
7ZR6$7$,,,SRUWV
DISPLAY
One WADE-8014 Mini-ITX Main Board
*UDSKLF&RQWUROOHU
,QWHO®&,QWHJUDWHG'*0$VXSSRUW';2SHQ*/03(*
6KDGHU0RGHO
One Installation CD
'LVSOD\,QWHUIDFH
9*$2QHFRQQHFWRU'%RQUHDU,2DQDORJUHVROXWLRQXSWR[
+'0,2QHFRQQHFWRURQUHDU,2VXSSRUWXSWR[UHVROXWLRQ
'9,'2QHFRQQHFWRURQUHDU,2'LJLWDO'9,UHVROXWLRQXSWR[
One SATA Cable
One I/O shield
Mechanical & Environment
Watch DOG
VGA
105
GPIO
DDR 3
SATA
6Gb
DVI-D
0LQL,7;:$'(
USB 3.0
2
GbE
HDMI
MiniPCIe
'LPHQVLRQ
- /[:PP/[:
3RZHU6XSSO\
- $7;SLQSRZHULQSXW
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJHWHPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
- 2YHUKRXUVDWƒ&
WADE-8012
Intel® CoreTM i5/ i7 processor based Mini-ITX
with dual displays, DDR3 SDRAM, Two COM
Ports and Eight USB Ports
ITE IT8728F
16 bits GPIO
Four USB ports
One PCIe x16 slot
LGA1155 socket
Intel® Q67 PCH
71
1.60
0
3.43
Four SATA II ports
Two SATA III ports
Dual DDR3 non-ECC
DIMM socket
(TXLSSHGZLWKVHFRQGJHQHUDWLRQ,QWHO®&RUHTM
LLSURFHVVRUVLQWKH/*$VRFNHW3RUWZHOO¶V:$'(0LQL,7;RIIHUVVXSHULRUSHUIRUPDQFHLQDVPDOOSDFNDJHDQGLVVXLWDEOHIRU
GLYHUVHDSSOLFDWLRQVVXFKDV3DQHO3&/RWWHU\
0HGLFDO*DPLQJDQG'LJLWDO6LJQDJH
GENERAL
SURFHVVRU
,QWHO® &RUHŒLLSURFHVVRUXSWR*+]a:ZLWKa0%&DFKHLQ
/*$SDFNDJH
- 6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\,QWHO®9LUWXDOL]DWLRQ7HFKQRORJ\97[
,QWHO®7UXVWHG([HFXWLRQ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\
&KLSVHW
,QWHO®%'43&+
%,26
$0,8(),%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZR
SLQQRQ(&&VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
„,QWHO®43&+
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„7ZRSLQ',00VRFNHWVVXSSRUW'XDO
FKDQQHO''56'5$0XSWR*%
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP
%HHSDODUPVIRU¿HOGIDQRXWRYHUXQGHUYROWDJHRI'&YROWDJHVDQGRYHU
WHPSHUDWXUHWKUHVKROG
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7VVXSSRUWV3&,H[[[[PRGH
FEATURES
„ ,QWHO®&RUHŒLLLQ/*$VRFNHW
„'XDO'LVSOD\E\9*$'9,+'0,
„,QWHO®$FWLYH0DQDJHPHQW7HFKQRORJ\,QWHO®
$07
I/O INTERFACE
„6XSSRUWV6L[6$7$SRUWV6$7$,,[6$7$,,,
[(LJKW86%SRUWV
6XSHU,2
,7(,7)
„5$,'
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®/0VXSSRUWVL$07DQG,QWHO®/'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
REAR I/O
RS232/422/485
Audio
RS232
VGA
DVI-D
Gigabit Ethernet
HDMI
USB
ORDERING GUIDE
AB1-3644
:$'(0LQL,7;(6%4Z(&&3*$Z
''56'5$09*$'9,'+'0,'XDO*E(&20
$XGLR86%
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®4,QWHJUDWHG'*0$VXSSRUWV';2SHQ*/03(*
6KDGHU0RGHO
'LVSOD\,QWHUIDFH
9*$2QHFRQQHFWRU'%RQUHDU,2DQDORJUHVROXWLRQXSWR[4;*$
+'0,2QHFRQQHFWRURQUHDU,2VXSSRUWVXSWR[UHVROXWLRQ
6'922QHRQERDUGFRQQHFWRU3&,H[86%[VLJQDOV
'9,'2QHFRQQHFWRURQUHDU,2'LJLWDO'9,UHVROXWLRQXSWR[:8;*$
PACKING LIST
Mechanical & Environment
One WADE-8012 Mini-ITX Main Board
'LPHQVLRQ
/[:PP/[:
One Installation CD
3RZHU6XSSO\
7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJHWHPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Cable
One I/O shield
Giga
BIOS
DDR 3
SATA 3.0
Watch DOG
H/W Monitor
GPIO
USB 2.0
Giga LAN
HDMI
0LQL,7;:$'(
106
Intel® i3 and Xeon® processor based Mini-ITX
with dual displays, DDR3 SDRAM, Two COM
Ports and Eight USB Ports
WADE-8011
16 bits GPIO
ITE IT8728F
Four USB ports
One PCIe x16 slot
71
Four SATA II ports
Two SATA III ports
Dual DDR3 ECC
DIMM socket
(TXLSSHGZLWKVHFRQGJHQHUDWLRQ,QWHO®&RUHTM
i3 and Xeon®(VHULHVSURFHVVRUVLQ
WKH/*$VRFNHW3RUWZHOO¶V:$'(
0LQL,7;RIIHUVVXSHULRUSHUIRUPDQFHLQDVPDOO
SDFNDJHDQGLVVXLWDEOHIRUGLYHUVHDSSOLFDWLRQV
VXFKDV3DQHO3&/RWWHU\0HGLFDO*DPLQJDQG
'LJLWDO6LJQDJH
1.60
0
3.43
LGA1155 socket
Intel® C206 PCH
GENERAL
SURFHVVRU
- ,QWHO®&RUHŒLDQG;HRQ®(VHULHVSURFHVVRUXSWR*+]a:
ZLWKa0%&DFKHLQ/*$SDFNDJH
- 6XSSRUWV,QWHO®+\SHU7KUHDGLQJ7HFKQRORJ\,QWHO®9LUWXDOL]DWLRQ7HFKQRORJ\97[
,QWHO®7UXVWHG([HFXWLRQ7HFKQRORJ\(QKDQFHG,QWHO6SHHG6WHSŠ7HFKQRORJ\
&KLSVHW
,QWHO®%'&3&+
%,26
$0,8(),%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZRSLQ
(&&DQGQRQ(&&VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
„,QWHO®&3&+FKLSVHW
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
„7ZRSLQ',00VRFNHWVVXSSRUWGXDO
FKDQQHO''56'5$0XSWR*%
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP
%HHSDODUPVIRU¿HOGIDQRXWRYHUXQGHUYROWDJHRI'&YROWDJHVDQGRYHU
WHPSHUDWXUHWKUHVKROG
„'XDO'LVSOD\E\9*$'9,+'0,
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[VORW*HQ*7VVXSSRUW3&,H[[[[PRGH
FEATURES
„,QWHO® i3 and Xeon®(VHULHVSURFHVVRU
LQ/*$VRFNHW
„,QWHO®$FWLYH0DQDJPHQW7HFKQRORJ\,QWHO®
$07
REAR I/O
RS232/422/485
Audio
RS232
VGA
DVI-D
6XSHU,2
,7(,7)
$XGLR
,QWHO®&EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®/0VXSSRUWL$07DQG,QWHO®/'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56SRUWRQUHDU,2
[56VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
Gigabit Ethernet
HDMI
USB
ORDERING GUIDE
AB1-3643
I/O INTERFACE
:$'(0LQL,7;(6%&Z(&&3*$Z
''56'5$09*$'9,'+'0,'XDO*E(&20
$XGLR86%
PACKING LIST
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®&,QWHJUDWHG'*0$VXSSRUW';2SHQ*/03(*
6KDGHU0RGHO
'LVSOD\,QWHUIDFH
- 9*$2QHFRQQHFWRU'%RQUHDU,2DQDORJUHVROXWLRQXSWR[4;*$
+'0,2QHFRQQHFWRURQUHDU,2VXSSRUWVXSWR[UHVROXWLRQ
6'922QHRQERDUGFRQQHFWRU3&,H[86%[VLJQDOV
- '9,'2QHFRQQHFWRURQUHDU,2'LJLWDO'9,UHVROXWLRQXSWR[:8;*$
One WADE-8011 Mini-ITX Main Board
One Installation CD
One SATA Cable
One I/O shield
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
-7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
6WRUDJHWHPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
Giga
BIOS
107
0LQL,7;:$'(
DDR 3
SATA 3.0
Watch DOG
H/W Monitor
GPIO
USB 2.0
Giga LAN
Realtek ALC888
8 bits GPIO
Four USB ports
Four SATA II ports
Intel® ICH10DO
One PCIe x16 slot
LGA775 socket
Intel® Q45
MXIC
MX25L3206EM21
:$'(RIIHUVWKHDYDLODELOLW\RIDQH[WUD
JUDSKLFVFDUGZKLFKHQDEOHVSRZHUIXOJUDSKLF
SURFHVVLQJDELOLW\,QDGGLWLRQWKH9*$DQG
'9,'GXDOYLGHRRXWSXWVFDQGULYHWZRGLVSOD\V
VLPXOWDQHRXVO\ZKLFKLVLGHDOIRUJDPLQJDSSOLFDWLRQV:LWKGXDO*E(/$1IRXU6$7$GXDO
&20DQGHLJKW86%,2IXQFWLRQV:$'(
LVWKHEHVWVROXWLRQIRUPXOWLSOHDSSOLFDWLRQVVXFK
DV$XWRPDWLRQ0XOWLPHGLDDQG.,26.
FEATURES
„,QWHO®&RUHTM4XDG&RUHTM'XRSURFHVVRU
,QWHO®4([SUHVVDQG,&+'2FKLSVHW
„7ZRSLQ',00VRFNHWVVXSSRUWGXDO
FKDQQHO''56'5$0XSWR*%
„'XDOGLVSOD\9*$'9,'UGGLVSOD\YLD
3&,([SUHVV[VORW
1.60
0
4.75
Two DIMM sockets
37.10
33.72
F
WADE-8180
Leading Intel® Core™ 2 Quad/Core™ 2 Duo processor
based Mini-ITX embedded board with Dual Display,
Dual Gigabit Ethernet, SATA, COM and USB
GENERAL
SURFHVVRU
,QWHO®&RUHŒ4XDG,QWHO®&RUHŒ'XRSURFHVVRUXSWR*+]:
ZLWK0%/&DFKHLQ/*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®4*UDSKLFVDQG0HPRU\&RQWUROOHU+XE:DQG,&+'2
%,26
$0,&RUH%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZR
SLQ',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[*HQ*7V&RPSDWLEOHWRWKH3&,([SUHVV%DVH
6SHFL¿FDWLRQUHYLVLRQ
I/O INTERFACE
„)RXU6$7$SRUWV
6XSHU,2
0;,&0;/(0
„7ZR*E(/$1SRUWVDQG2QH3&,H[VORW
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®/0DQG,QWHO®/'XDO*LJDELW(WKHUQHWFRQWUROOHUV
6HULDO3RUW
[56RQUHDU,2
[56RQERDUGSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
„5$,'
„730DQGL$07VXSSRUWHG
REAR I/O
VGA
KB/MS
DVI-D RS232
Gigabit Ethernet
USB
Audio
ORDERING GUIDE
AB1-3255
AA1-3052
:$'(0LQL,7;(6%,QWHO&RUH4XDG&RUH
'XRZ''56'5$09*$'9,''XDO*E(
$XGLR
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®4([SUHVVLQWHJUDWHG*0$*UDSKLFVGHYLFHVXSSRUWVIXOO
KDUGZDUHDFFHOHUDWLRQ03(*'LUHFW;
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$$QDORJUHVROXWLRQXSWR[4;*$
'9,'LJLWDO'9,UHVROXWLRQXSWR[#+]
3(553&,([WR3&,([5LVHU&DUG
PACKING LIST
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
One WADE-8180 Mini-ITX Main Board
3RZHU6XSSO\
7\SLFDO9&38#$9#$9#$9#$
6XSSRUWV$7;PRGH
One Installation CD
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Cable
One I/O shield
One USB Cable
Giga
CPU Fan
BIOS
DDR 3
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
USB 2.0
Giga LAN
0LQL,7;:$'(
108
WADE-8056
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with Dual Displays and One GbE
8 bits GPIO
Four USB ports
LVDS
Triple RS232 ports
Intel® ICH8
Four SATA II ports
One PCI slot
LGA775 socket
Intel® Q965
Mini PCI x1 slot
7KH:$'(LVDQDGYDQFHGPLQL,7;HPEHGGHGV\VWHPERDUGWKDWWDNHVDGYDQWDJHRI
,QWHO®&RUHTM'XRWHFKQRORJLHV:LWKLWV*3,2
:$'(RIIHUVUREXVWFRPSXWLQJSRZHUDQG
UHOLDELOLW\IRUHPEHGGHGDSSOLFDWLRQVWKDWQHHG
DGLJLWDOFRQWUROLQWHUIDFH'XDOYLGHRRXWSXWV
FDQGULYHWZRGLVSOD\VVLPXOWDQHRXVO\DWDKLJK
VSHHGZKLOHPDLQWDLQLQJVXSHULRULPDJHTXDOLW\
7KHH[SDQVLRQVORWVSURYLGHWKHKLJKO\ÀH[LELOLW\
QHFHVVDU\IRUIXQFWLRQDOH[SDQVLRQ
FEATURES
„,QWHO®&RUHTM4XDGSURFHVVRU
„,QWHO®4*0&+DQG,&+'2&KLSVHW
1.60
0
4
37.10
34.02
Two DIMM sockets
GENERAL
SURFHVVRU
,QWHO®&RUHŒ'XR&RUHTM4XDG&HOHURQ®'3HQWLXP®SURFHVVRUXS
WR*+]:ZLWK0%/&DFKHLQ/*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®4*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+'2
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZR
SLQ',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH
([SDQVLRQ,QWHUIDFH
[3&,6ORW6XSSRUWV3&,5HYVSHFL¿FDWLRQDW0+]
[0LQL3&,VRFNHW6XSSRUWV3&,5HYVSHFL¿FDWLRQDW0+]
„0D[*%PHPRU\''56'5$0
„'XDO'LVSOD\E\9*$/9'6
„2QH*E(/$1SRUWDQGRQH3&,VORW
„0D[IRXU&20DQGVL[86%SRUWV
„5$,'
REAR I/O
Gigabit Ethernet
KB/MS
RS232 VGA
USB
Audio
ORDERING GUIDE
AB1-3078
:$'(0LQL,7;(6%,QWHO3'XDO&RUHZ
''56'5$09*$/9'6'XDO'LVSOD\*E($XGLR
AA1-3027
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,
PACKING LIST
One WADE-8056 Mini-ITX Main Board
One Installation CD
I/O INTERFACE
6XSHU,2
:LQERQG:+*
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&9&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®'0*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56RQERDUGSLQKHDGHU
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®4([SUHVVLQWHJUDWHG*0$*UDSKLFVGHYLFHVXSSRUW
KDUGZDUHDFFHOHUDWLRQ0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$$QDORJUHVROXWLRQXSWR[4;*$
/9'6'LJLWDO/9'6UHVROXWLRQXSWR[8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
3RZHU6XSSO\
7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Cable
One I/O shield
COM Cable
Giga
DDR 2
109
0LQL,7;:$'(
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
4
COM
Giga
Giga LAN
WADE-8556
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with Dual Displays and One GbE
Four USB ports
8 bits GPIO
Triple RS232 ports
Mini PCI x1 slot
Intel ICH8M
Four SATA II ports
One PCI slot
Intel® Q965
LGA775 socket
®
:$'(LVDQDGYDQFHGPLQL,7;HPEHGGHGV\VWHPERDUGWKDWWDNHVDGYDQWDJHRI,QWHO®
&RUHTM 4XDGWHFKQRORJLHV:LWKLWV0LQL3&,VORW
:$'(RIIHUVWKHDYDLODELOLW\RIDQH[WUDZLUHOHVV/$1FDUGZKLFKLVVXLWDEOHIRU.LRVNDSSOLFDWLRQ,WV9*$DQG'9,GXDOYLGHRRXWSXWVFDQGULYH
WZRGLVSOD\VVLPXOWDQHRXVO\PDNLQJLWHVSHFLDOO\
VXLWDEOHIRU'LJLWDO6LJQDJH7KHH[SDQVLRQVORWV
DUHEDVHGRQ3&,WHFKQRORJLHVDQGVXSSRUWXSWR
WZR3&,VORWVSURYLGLQJKLJKÀH[LELOLW\QHFHVVDU\
IRUIXQFWLRQDOH[SDQVLRQ
FEATURES
„,QWHO®&RUHTM4XDGSURFHVVRU
1.60
0
4
37.10
35.90
Two SODIMM sockets
GENERAL
SURFHVVRU
,QWHO®&RUHŒ'XR&RUHŒ4XDG3HQWLXP®&HOHURQ®'SURFHVVRUXS
WR*+]:ZLWK0%/&DFKHLQ/*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®4*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+'2
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZR
SLQ',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH
([SDQVLRQ,QWHUIDFH
[3&,ELW6ORW6XSSRUWV3&,5HYVSHFL¿FDWLRQDW0+]
[0LQL3&,VRFNHW6XSSRUWV3&,5HYVSHFL¿FDWLRQDW0+]
„,QWHO®4*0&+DQG,&+'2&KLSVHW
„'XDO'LVSOD\E\9*$'9,
I/O INTERFACE
„2QH*E(/$1SRUWRQH3&,DQGRQH0LQL3&,
VORW
6XSHU,2
:LQERQG:+*
„0D[IRXU&20DQGVL[86%SRUWV
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&9&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®'0*LJDELW(WKHUQHWFRQWUROOHU
6HULDO3RUW
[56SRUWRQUHDU,2
[56ZLWKRQERDUGSLQKHDGHUV
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
„5$,'
REAR I/O
Gigabit Ethernet
RS232
KB/MS
VGA
DVI-D
USB
Audio
ORDERING GUIDE
AB1-3073
:$'(0LQL,7;(6%,QWHO3'XDO&RUHZ
''56'5$09*$'9,'XDO'LVSOD\*E($XGLR
AA1-3027
3(356ORW5LVHU&DUGIRU5LJKW
([SDQVLRQ[3&,
PACKING LIST
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®4([SUHVVLQWHJUDWHG*0$*UDSKLFVGHYLFHVXSSRUW
KDUGZDUHDFFHOHUDWLRQ0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$$QDORJUHVROXWLRQXSWR[4;*$
'9,'LJLWDO'9,UHVROXWLRQXSWR[8;*$
Mechanical & Environment
'LPHQVLRQ
/[:PP/[:
One WADE-8556 Mini-ITX Main Board
3RZHU6XSSO\
7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
One Installation CD
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One SATA Cable
One I/O shield
COM Cable
Giga
DDR 2
Giga LAN
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
4
COM
USB 2.0
0LQL,7;:$'(
110
WADE-8656
Leading Intel® CoreTM 2 Quad processor based
Mini-ITX Board with PCIe expansion and Two GbE
8 bits GPIO
One RS232 port
Four USB ports
Winbond
W83772G
Intel ICH8
Six SATA II ports
®
One PCIe x16 slot
LGA775 socket
Intel® Q965
:$'(LVDQDGYDQFHGPLQL,7;HPEHGGHGV\VWHPERDUGWKDWWDNHVDGYDQWDJHRI,QWHO®
&RUHTM4XDGWHFKQRORJLHV:LWKLWV3&,H[
VORW:$'(SURYLGHVDQH[WUDJUDSKLF
FDUGZKLFKFDQRIIHUSRZHUIXOJUDSKLFSURFHVVLQJDELOLW\VXLWDEOHIRUJDPLQJDSSOLFDWLRQV
6L[6$7$3RUWVHQULFKWKHV\VWHPFDSDFLW\
HVSHFLDOO\VXLWDEOHIRUVWRUDJHXVDJH7ZR
*LJDELW(WKHUQHWSRUWVSURYLGHKLJKSHUIRUPDQFH
IRUQHWZRUNLQJWUDQVPLVVLRQ
FEATURES
„,QWHO®&RUHTM4XDGSURFHVVRU
„,QWHO®4*0&+DQG,&+'2FKLSVHW
1.60
0
2.70
37.10
35.90
Two DIMM sockets
GENERAL
SURFHVVRU
,QWHO®&RUHŒ'XR&RUHŒ4XDG3HQWLXP®&HOHURQ®'SURFHVVRUXSWR
*+]:ZLWK0%/&DFKHLQ/*$SDFNDJH
)6%0+]
6XSSRUWV(QKDQFHG,QWHO6SHHG6WHS®7HFKQRORJ\,QWHO®DUFKLWHFWXUH
([HFXWH'LVDEOH%LW
&KLSVHW
,QWHO®4*UDSKLFVDQG0HPRU\&RQWUROOHU:DQG,&+'2
%,26
$ZDUG%,26
0HPRU\
6XSSRUWVGXDOFKDQQHOXSWR*%''507V6'5$0RQWZR
SLQ',00VRFNHW
6WRUDJH'HYLFHV
[6$7$VXSSRUWXSWR*EVGDWDWUDQVIHUUDWH
:DWFKGRJ7LPHU
3URJUDPPDEOHYLD6:IURPVHFWRPLQ
+DUGZDUH0RQLWRULQJ
)$16SHHG&386\VWHP7HPSHUDWXUH&386\VWHP9ROWDJH
([SDQVLRQ,QWHUIDFH
[3&,([SUHVV[*HQ*7V&RPSDWLEOHWRWKH3&,([SUHVV%DVH
6SHFL¿FDWLRQUHYLVLRQD
„6L[6$7$SRUWVVXSSRUW
„7ZR*E(/$1SRUWVRQH3&,H[VORW
I/O INTERFACE
„0D[WZR&20DQGHLJKW86%SRUWV
6XSHU,2
:LQERQG:*
„5$,'
$XGLR
,QWHO®4EXLOWLQ+LJK'H¿QLWLRQ$XGLRXSWRN+]ELW
5HDOWHN$/&9&*5FKDQQHOV
$XGLR-DFN',3/LJKW3LQN/LPH/LJKW%OXH
Ethernet
,QWHO®'0*LJDELW(WKHUQHWFRQWUROOHU
5HDOWHN%*LJDELW/$1
6HULDO3RUW
[56SRUWRQERDUGKHDG
[56VHOHFWDEOHSRUWRQUHDU,2
86%
[86%SRUWVRQUHDU,2
[86%SRUWVRQERUDGZLWKWZRKHDGHUV
0EVEXVFDSDEOHRIKLJKVSHHGIXOOVSHHGORZVSHHGGDWDUDQJHV
.H\ERDUG0RXVH
[36.H\ERDUG0RXVHRQUHDU,2
*3,2
2QERDUGSURJUDPPDEOHELW'LJLWDO,2V
REAR I/O
RS232/422/485
VGA
KB/MS
Gigabit Ethernet
USB
Audio
ORDERING GUIDE
AB1-3093
:$'(0LQL,7;(6%,QWHO3'XDO&RUHZ
''56'5$09*$3&,(H[SDQVLRQ'XDO*E($XGLR
AA1-3052
3(553&,([WR3&,([5LVHU&DUG
PACKING LIST
DISPLAY
*UDSKLF&RQWUROOHU
,QWHO®4([SUHVVLQWHJUDWHG*0$*UDSKLFVGHYLFHVXSSRUW
KDUGZDUHDFFHOHUDWLRQ0&'LUHFW;F
,QWHO®'\QDPLF9LGHR0HPRU\7HFKQRORJ\,QWHO®'907
'LVSOD\,QWHUIDFH
9*$$QDORJUHVROXWLRQXSWR[4;*$
Mechanical & Environment
One WADE-8656 Mini-ITX Main Board
'LPHQVLRQ
/[:PP/[:
One Installation CD
3RZHU6XSSO\
7\SLFDO9&38#$96\VWHP#$9#$9#$
6XSSRUWV$7;PRGH
One SATA Cable
(QYLURQPHQW
2SHUDWLRQ7HPSHUDWXUHƒ&WRƒ&
5HODWLYH+XPLGLW\WRQRQFRQGHQVLQJ
07%)
2YHUKRXUVDWƒ&
One I/O shield
USB Cable
COM Cable
Giga
DDR 2
111
0LQL,7;:$'(
SATA
3Gb
Watch DOG
H/W Monitor
GPIO
USB 2.0
Giga LAN
WADE-2221A
The WADE-2221A is a rugged and stylish barebone system
suitable for embedded applications that stand alone or are
rackmounted. Its effective ventilation is achieved by the mesh
design of the front panel. No actual tool is needed to release the
WRSFRYHURIFKDVVLVVLPSOLI\LQJLQWHJUDWLRQDQG¿HOGVHUYLFH
FEATURES
Rugged and Stylish Industrial Mini-ITX
Bare Bone Chassis
This barebone system includes a WADE series board, 150-watt
or 180-watt power supply, 2.5" drive bay and one PCI expansion
slot. A 2U rackmount tray is specially designed to hold two units
side-by-side and converts them to the rackmount platform.
REAR I/O
„ Integrated with various Mini-ITX board
LAN
Audio Ports
„ One PCI expansion slot
„ Tool-free mechanism to open the top cover
„ Rugged and stylish design
„ Quick 2.5” HDD installation by releasing the
top cover
„ Two side-by-side units to form two systems
in 2U rackmount form factor
KB/MS
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
>75%
Holdup Time
16ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.3V; [email protected]~+15V
Over Power/Load
Protection
MTBF
Output power over to 110%~150%
EMI & Safety Approval
UL, TUV, BSMI, NEMCO, FCC, CE
Operating: 0 ~ 40°C, 20 ~ 90%RH
Storage: -20 ~ 60°C, 5 ~ 95%RH
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
Temperature/Humidity
Dimension (WxDxH)
VGA
2 USB Ports
ENGINEERING DRAWING
251
ORION-A1801P optional
POWER SUPPLY
Input Voltage
COM1
>130,000 hrs
86.30
221.8
MECHANICAL & ENVIRONMENTAL
Operation Temperature
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
251 x 221.8 x 86.3 (mm)
Weight
2.2 Kg
ORDERING GUIDE
WADE-2221A-150X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 150W
active PFC PSU
WADE-2221A-180X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with 180W
active PFC PSU
Mini-ITX-WADE-2221A
112
112
WADE-1120A
The WADE-1120A is designed to efficiently dissipate any
internal heat, eliminating the need for a ventilation fan. It is
the perfect system solution for any embedded application
that operates in a harsh environment. WADE-1120A is
designed with either a built-in WADE-8041 board or similar
FEATURES
The fan-less compact Mini-ITX Bore Bone
Chassis
Mini-ITX board as the barebone system. Its unique tool-free
design allows the integrator or field service professional
to release the top cover easily and quickly. Complete with
memory, DOM or Compact flash, WADE-1120A is ready to go
to work.
REAR I/O
„ Integrated with WADE-8041 or similar Mini-ITX board
„ Small form factor with fan-less ventilation mechanism
„ Rugged design for harsh environment
COM1
LAN
COM2, COM3
„ Unique tool-free design for quick top cover release
KB/MS
55W ATX power supply
Input Voltage
90V ~ 265V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
2.0A(RMS)@115V, 1.0A(RMS)@230V
(I¿FLHQF\
>74%
Holdup time
17ms. at 115V/60Hz or 230V/50Hz
Over Voltage Protection
[email protected]~4.5V; [email protected]~6.82V; [email protected]~16.5V
MTBF
121,330 hrs
&HUWL¿FDWLRQ
UL, cUL, TUV, CE, FCC
Dimension (WxDxH)
183 x 50 x 37.6 mm; 7.2” x 2” x 1.5”
USB
Audio
COM4
ENGINEERING DRAWING
196
FSP055-50LM optional
POWER SUPPLY
Maximum Output
VGA
268
482
-20~80°C
Relative Humidity
5~95% non-condensing
268 x 196 x 44 (mm)
Dimension
Weight
2.2 Kg
6.10
0~50°C
Storage Temperature
ORDERING GUIDE
WADE-1120A-55X
The Fan-free Designed Compact Node Chassis built with 55W ATX PSU
* Rack-mount kit available (option)
113
Mini-ITX-WADE-1120A
31.80
Operation Temperature
44
MECHANICAL & ENVIRONMENTAL
WADE-2231Q
The WADE-2231Q is a rugged and stylish barebones system
suitable for embedded applications that stand alone or are
rackmounted. Its effective ventilation is achieved by the mesh
design of the front panel. No actual tool is needed to release the
FEATURES
Rugged and Stylish Industrial Mini-ITX
Bare- Bones Chassis
WRSFRYHURIFKDVVLVVLPSOLI\LQJLQWHJUDWLRQDQG¿HOGVHUYLFH
This barebone system includes a WADE series board, 180-watt
power supply, 3.5" drive bay and one PCI expansion slot.
REAR I/O
COM
„ Bare-bones Chassis for Mini-ITX board
LAN
„ Tool-free mechanism to open the top cover
„ Rugged and stylish design
„ Quick 3.5” HDD installation by releasing the top cover
KB/MS
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
>75%
Holdup Time
16ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.3V; [email protected]~+15V
Over Power/Load
Protection
MTBF
Output power over to 110%~150%
EMI & Safety Approval
UL, TUV, BSMI, NEMCO, FCC, CE
Operating: 0 ~ 40°C, 20 ~ 90%RH
Storage: -20 ~ 60°C, 5 ~ 95%RH
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
50
R2.
50
12
94
252
>130,000 hrs
29
Dimension (WxDxH)
ENGINEERING DRAWING
12
Temperature/Humidity
Audio
R5
90V ~ 264V AC, full range
USB
50 13
ORION-A1801P optional
POWER SUPPLY
Input Voltage
VGA
5
310
330.60
345.60
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
310 x 252 x 86.3 (mm)
Weight
3.0 Kg
91.80
Operation Temperature
86.30
MECHANICAL & ENVIRONMENTAL
ORDERING GUIDE
WADE-2231Q-4410R-180X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with PER-4410R,
PCI-E x 16 riser card & 180W PSU
WADE-2231Q-518R-180X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with PEP-581R, 1
slot PCI riser card & 180W PSU
Mini-ITX-WADE-2231Q
114
WADE-2232Q
The WADE-2232Q is a rugged and stylish barebones system suitable
for embedded applications that stand alone or are rackmounted.
Its effective ventilation is achieved by the mesh design of the front
panel. No actual tool is needed to release the top cover of chassis,
FEATURES
Rugged and Stylish Industrial Mini-ITX
Bare-Bones Chassis
VLPSOLI\LQJLQWHJUDWLRQDQG¿HOGVHUYLFH7KLVEDUHERQHV\VWHP
includes a WADE series board, 220-watt power supply, 3.5" drive bay
and two PCI expansion slot.
REAR I/O
LAN
„ Bare-bones Chassis for Mini-ITX board
„ Tool-free mechanism to open the top cover
„ Rugged and stylish design
„ Quick 3.5” HDD installation by releasing the top cover
„ Two expansion slots
KB/MS COM
[email protected]~6.82V; [email protected]~4.8V; [email protected]~15.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature/Humidity
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -20 ~ 80°C, 10m ~ 90%RH
Dimension (WxDxH)
150 x 81.5 x 40.5 mm; 5.9” x 3.2” x 1.6”
100,000 hrs
310
330.60
345.60
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
310 x 252 x 109 (mm)
Weight
3.5 Kg
109
MECHANICAL & ENVIRONMENTAL
Operation Temperature
252
17ms. at full [email protected]°C
Over Voltage Protection
114.50
>80%
Holdup Time
R5
R2
.50
[email protected], [email protected]
(I¿FLHQF\
50 13
47 ~ 63 Hz
Input Current
ENGINEERING DRAWING
94
Input Frequency
Audio
29 50
90V ~ 264V AC, full range
USB
12 12
FSP220-60LE
POWER SUPPLY
Input Voltage
VGA
ORDERING GUIDE
WADE-2232Q-582R-220X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with PEP-582R, 2
slots PCI, riser card & 220W PSU
WADE-2232Q-592R-220X
Rugged and stylish industrail Mini-ITX Bare-bones Chassis with PEP-592R, 2
slots ( PCI-E x 1, PCI x 1 )
115
Mini-ITX-WADE-2232Q
ARTO-220-ITX
The compact and slim ARTO-220-ITX is design to fit Mini-ITX
MB applications operating where space is at a premium. It also
features a tool-free mechanical design to quickly release the top
cover of the chassis for ease of integration and field service. The
1.5U Advanced, Stylish and Compact
Mini-ITX Bare-Bones Chassis
barebone system includes a WADE series board, 3.5” drive bay,
one PCI expansion slot and a 250-watt power supply.
REAR I/O
FEATURES
„ Bare-bones chassis for Mini-ITX board
LAN
„ Compact, slim and stylish ID design
Audio Ports
„ One 3.5” HDD bay and 250W PSU
„ One PCI expansion slot
COM
KB/MS
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
>68%
Holdup Time
17ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.5V; [email protected]~4.5V; [email protected]~+5.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~160%
EMI & Safety Approval
UL, cUL, TVU, CE, FCC
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -20 ~ 70°C, 10m ~ 90%RH
100 x 190 x 40.5 mm; 3.9” x 7.5” x 1.6”
Temperature/Humidity
Dimension (WxDxH)
ENGINEERING DRAWING
241
105,405 hrs
347
0~50°C
Storage Temperature
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
347 x 241 x 74 (mm)
Weight
3.5 Kg
73
MECHANICAL & ENVIRONMENTAL
Operation Temperature
2 USB Ports
74
FSP250-50PLB optional
POWER SUPPLY
Input Voltage
VGA
ORDERING GUIDE
ARTO-220-ITX-250X
1.5U Advanced Mini-ITX based Chassis with PEP-581R, 1 slot PCI, rise card & 250W
Active PFC PSU
Mini-ITX-ARTO-220-ITX
116
WADE-1042
The WADE-1042 uses a 1U rack-mount form factor and is designed
for network or communication applications. Its four drive bays supSRUW5$,'FRQ¿JXUDWLRQWKURXJKWKH6$7$LQWHUIDFHVRQWKHERDUG
$SSOLFDWLRQVZLOOEHQH¿WIURP:$'(¶VFRPSDFWVL]HH[SDQ-
FEATURES
1U Height Bare Bone server with four drive
bays for RAID and two expansion slots
VLRQFDSDELOLW\5$,'FRQ¿JXUDWLRQDQGZDWWSRZHUVXSSO\
REAR I/O
„ Bare-bone s chassis for Mini-ITX board
„ Compact, slim and stylish ID design
LAN
Parallel
Switch
Audio
„ Four 3.5” HDD bays and 180W PSU
„ Two PCI expansion slot
COM
VGA
USB
PCI
KB/MS
47 ~ 63 Hz
Input Current
[email protected], [email protected]
(I¿FLHQF\
>68%
Holdup Time
20ms. at full [email protected]°C
Over Voltage Protection
[email protected]~6.8V; [email protected]~4.8V; [email protected]~15.6V
Over Power/Load
Protection
MTBF
Output power over to 110%~140%
EMI & Safety Approval
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Operating: 0 ~ 50°C, 20 ~ 85%RH
Storage: -40 ~ 70°C, 10m ~ 90%RH
150 x 81.6 x 40.6 mm; 5.9” x 3.2” x 1.6”
Dimension (WxDxH)
70
100,000 hrs
74.70
Temperature/Humidity
92.10
Input Frequency
ENGINEERING DRAWING
38 71.10
90V ~ 264V AC, full range
387
FSP220-60LE optional
POWER SUPPLY
Input Voltage
443
-20~80°C
Relative Humidity
5~95% non-condensing
Dimension
443 x 387 x 44 (mm)
Weight
6.5 Kg
462
482
31.80
0~50°C
Storage Temperature
6.10
Operation Temperature
44
MECHANICAL & ENVIRONMENTAL
ORDERING GUIDE
WADE-1042-582L-220X
Advance Mini-ITX based Chassis for Rack-Mount with PEP-582L, 2 slots PCI, riser
card & 220W Active PFC PSU
117
Mini-ITX-WADE-1042
Riser Card Selection Guide
WADE ESB
Riser Card
WADE-2221A
ARTO-220-ITX
WADE-2232Q
PER-4210R
PEP-581R
WADE-8066
PEP-582R
PEP-5311R
PEP-581R
WADE-8056
PEP-582R
PEP-5311R
PEP-581R
WADE-8556
PEP-582R
PEP-5311R
WADE-8656
PER-4410R
PEP-581R
WADE-8065
PEP-582R
PEP-5311R
PEP-581R
WADE-8055
PEP-582R
PEP-5311R
PEP-581R
WADE-8044
PEP-582R
PEP-5311R
Mini-ITX-Riser Card Selection Guide
118
About WEBS
WEBS: Portwell Intelligent Fan-less System
Compact, Flexible, Rugged Computing Systems
With leading embedded computing technology, Portwell has developed the industrial grade WEBS fan-less
computing systems for harsh environment such as factory automation, transportation, facility management,
networking and public works.
To meet these harsh environmental parameters, each WEBS computing system is designed by precise
thermal simulation and verification to make the system stable and user friendly.
The all-aluminum chassis design provides effective heat dissipation and transfers the heat out of the system
quickly and easily.
Built with the latest Intel® chipsets, the WEBS systems feature not only superior performance but also low
power consumption. They are suitable for energy-critical applications and environmental friendly.
Slim
Fan-less
M. I. T.
Small
Flexible
Performance
Wide Temp. Range
Quality
Rugged Wall
Custom Color
Net Wall
Private Logo
Expand I/O (By model)
119
About WEBS
Quality Assurance
1 Design & Analysis
Portwell WEBS systems undergo quality assurance procedures during the critical early stages of development.
Designing a stable product makes it easy for quality checking and complies with Design for Quality (DFQ).
At the development stage the product design also involves the material and assembly important for production, with
WKHIRFXVRQ'HVLJQIRU0DQXIDFWXUDELOLW\')07KLVGHYHORSVVLPSOHFRQVLVWHQWDQGHI¿FLHQWV\VWHPVWUXFWXUHV
and endows the product with a stable quality.
With their experienced engineering team and complete 3D circuit and layout development facility, Portwell is able to
VXSSO\PRUHHI¿FLHQWV\VWHPGHYHORSPHQWDQGVXSSRUWWKHLUFXVWRPHUVLQ'HVLJQ:LQ
Design & analysis is performed by 3D workstation. (WEBS-2120)
Circuit design & layout by advanced tools (NANO-8044)
2 Thermal Design
Thermal Design Concept
Thermal control is the key to all future industrial appliances. Portwell knows this and has focused many hours of
research and put immense efforts upon thermal solutions.
%DVHGRQRXU¿QGLQJVDQGH[SHULHQFHPDQ\FRPSRQHQWVRQWKHPRWKHUERDUGGHPRQVWUDWHGZLGHWHPSHUDWXUH
changes which affected the operating temperature endurance of the board and the system.
The CPU T-junction temperature, for example, will dramatically increase around 30 to 40 degrees Celsius from
power-on to full loading under ambient temperature. This means the CPU T-junction could reach between 90
and 100 degrees Celsius when the ambient temperature is at 60 degrees Celsius. Moreover, the CPU T-junction
WHPSHUDWXUHLVFDSDEOHRIDQDGGLWLRQDOGHJUHHV&HOVLXVZKLFKH[FHHGV&38VSHFL¿FDWLRQVGXHWRLWVIDQIUHH
chassis.
In our labs, we saw these symptoms and developed unique solutions. Thermal design and component placement
on a motherboard go hand in hand. Therefore, heat ventilation in a chasis is necessary for fan-less or fan-free
systems.
Some manufactures will claim they have solved the heat dissipation problem based on their calculations and data
VHWVEXWVHHLQJLVEHOLHYLQJ6RWHVW\RXUV\VWHPVLQRXUFHUWL¿HGDQGDGYDQFHGODEVDQGVHHLI\RXUV\VWHPV
PHHW\RXUVSHFL¿FDWLRQV
6LQFHWKHUHLVQRIDQDQGDLUÀRZLQVLGHWKHIDQOHVV:(%6V\VWHPVKDQGOLQJWKHWKHUPDORXWSXWEHFRPHVRQHRI
the most important concerns. System heat comes from ICs on the embedded board and this is pre-determined by
Intel®. Therefore, the key to developing a reliable fan-less system is determined by two major factors.
NANO-8044 M/B
FLIR Systems
First is to balance the heat on the embedded board and make sure it does not accumulate. Determining the
thermal balance for the hot components is a prime concern. The picture below shows the heat situation of the
NANO-8044, NANO-ITX embedded board used in the WEBS-2120 system. The heat in this example is arranged
and balanced for superior dissipation in a fan-less system design.
60.5 °C
60
Ar1
50
Thermal image of NANO-8044 M/B
Ar2
40
30
28.1
Quality Assurance
120
Quality Assurance
Second is to maximize the arrangement of heat dissipation by system design. WEBS systems are designed with
an all-aluminum chassis that is ideal for heat dissipation. Heat sinks link the ICs on the embedded board and the
aluminum chassis for direct heat transference. The heat transfers from the bottom up so the lower temperature
LVDWWKHFKDVVLVWRSIRUJUHDWHUHDVHRIXVHDQGSURWHFWLRQ7KHSLFWXUHVEHORZLOOXVWUDWHWKHKHDWÀRZRID:(%6
system. Balancing the heat of the product in this way makes the perfect fan-less system.
:(%6+HDWÀRZ%RWWRP
:(%6+HDWÀRZ7RS
3 Thermal Validation
After completing the thermal design, the WEBS system undergoes thermal validation by following Intel’s thermal
JXLGH7KHV\VWHPLVWHVWHGLQVLGHWKHFDOLEUDWHGFKDPEHUZLWKGH¿QHGWHPSHUDWXUHV7KHHI¿FDF\RIWKH:(%6
V\VWHPLVIXUWKHULPSURYHGZKHQWKHWHPSHUDWXUHRIDQ\FRPSRQHQWLVRYHUVSHFL¿FDWLRQ7KHUPDOWHVWVDUH
FRQGXFWHGXQWLODOOWKHPDMRU,&VDUHEHORZWKHUPDOVSHFL¿FDWLRQ
Holes are made on the heat sink and thermal sensor cables are added for measuring the temperature
4 Safety & Reliability Validation
In addition to the thermal validation, the WEBS systems undergo safety assessment and tests and achieve CE and
)&&FHUWL¿FDWLRQ7HVWLQJLQFOXGHV(6'(0,DQG(0&
To ensure product quality, complete quality assurance tests are performed during both the development and the
manufacturing phases for all system-level products. Portwell WEBS systems are tested and comply with safety
regulations, and are reliable to be used in the harsh environments.
-Based on customer’s requirements, Portwell can do additional tests with a NRE (non-recurring engineering) charge.
ESD Test
Vibration Test
121
Quality Assurance
EMC Test
Shock Test
Packing Vibration Test
EMC Test
Packing Drop Test
WEBS Reference Table
Model
WEBS-1320
WEBS-2121
WEBS-3330
WEBS-3331
M/B
PEB-2737
NANO-8045
WADE-8070
WADE-8071
Form Factor
3.5” ECX
NANO-ITX
MINI-ITX
MINI-ITX
Atom™ Z510 1.1GHz
Atom™ Z530 1.6GHz
Atom™ Z510 1.1GHz
Atom™ Z530 1.6GHz
Atom™ N270 1.6GHz
Atom™ N270 1.6GHz
US15W
US15W
945GSE+ICH7-M
945GSE+ICH7-M
FSB
400MHz/533MHz
400MHz/533MHz
533MHz
533MHz
BIOS
AMI
AMI
Award
Award
DDR2/2GB
DDR2/2GB
DDR2/2GB
DDR2/2GB
GMA 500
GMA500
GMA 950
GMA 950
ALC-262-VC2-GR
ALC-262
ALC-262-GR
ALC-262-GR
Super I/O
W83627DHG
W83627DHG
W83627UHG
W83627HG-AW
Storage
CF, 2.5” SATA
CF, 2.5” SATA
CF, 2.5” SATA
CF
1x RS232
1x RS232
1x RS232+
1x RS232/422/485
1x RS232
4
2
4
4
Display
VGA
DVI-D
VGA, DVI-D
VGA
Ethernet
RTL8111C-VC
RTL8111C-VC
RTL8111C-VB x 2
RTL8111C-VC
ɖ
N/A
ɖ
N/A
Audio
Mic-in, Line-out
Mic-in, Line-out
Mic-in, Line-out
Mic-in, Line-out
D I/O
N/A
N/A
N/A
N/A
SDIO
N/A
Mini-PCI
N/A
System
DC 12V
DC 12V
DC 12V
DC 12V
Adapter
AC 100~240V
AC 100~240V
100~240V
100~240V
OP Temp.
-5 ~ 50°C
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 45°C
Stor. Temp
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
Humidity
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
Vibratoin
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
50G, 11msce.
50G, 11msce.
50G, 11msce.
50G, 11msce.
200 x 150 x 51 mm
150 x 150 x 51 mm
200 x 200 x 51/83 mm
200 x 200 x 36 mm
1.2 kg
1 kg
1.1/1.8 kg
1.1 kg
CPU
Chipset
System
Memory
Graphic Controller
Audio Codec
Serial
USB
External I/O
PS/2
Expansion
PWR
Environment
Shock
Dimension(WxDxH)
Mechanical
Weight
WEBS Reference Table
122
WEBS Reference Table
123
WEBS-1312
WEBS-1330
WEBS-1341
WEBS-3332
WEBS-3560B
WEBS-4330
PEB-2739
PEB-2131
PEB-2771/2781
WADE-8071
WADE-8020
WADE-8170
3.5” ECX
3.5” ECX
3.5” ECX
MINI-ITX
MINI-ITX
MINI-ITX
Atom™ Z510PT 1.1GHz
Atom™ Z520PT 1.3GHz
Atom™ N270 1.6GHz
Atom™ N455 1.6GHz
Atom™ D525 1.8GHz
Atom™ N270 1.6GHz
Intel® Core i5/i7
(PGA989)
Atom™ N270
1.6GHz
US15WPT
945GSE+ICH7-M
ICH8-M
945GSE+ICH7-M
QM57
945GSE+ICH7-M
400MHz / 533MHz
533MHz
800MHz
533MHz
800/1066/1333 MHz
533MHz
AMI
Award
AMI
Award
AMI UEFI
Award
DDR2 / 2GB
DDR2 / 2GB
DDR3 / 2GB
DDR2/2GB
DDR3 SO-DIMM/8G
DDR2/2GB
GMA 500
GMA 950
GMA 950
GMA 950
GEN 6.0
GMA 950
ALC-262-GR
ALC-662
ALC-892
ALC-662-GR
ALC-888
ALC-655
W83627DHG
W83627UHG
W83627UHG
W83627HG-AW
ITE IT8721F/CX-L
ITE IT8712F-A
CF, 2.5” SATA
CF, 2.5” SATA
CF, 2.5” SATA
CF
2.5” SATA
CF, 2.5” SATA
1x RS232+
1x RS232/422/485
4x RS232(5V/12V)
3x RS232+
1x RS232/422/485
1x RS232
3x RS232+
1x RS232/422/485
2x RS232
4
2
4
4
6
4
VGA
VGA
VGA
VGA
VGA, DVI-D
VGA, DVI-D
Intel® 82574IT x 1
RTL-8111D-VB-GR*2
Intel® 82567V+82583V
RTL8111C-VC
Intel® 82574L+82577LM
ALC8111C x 2
N/A
N/A
N/A
N/A
N/A
ɖ
Mic-in, Line-out
Line-out
N/A
Mic-in, Line-out
HDMI; Mic-in,
Line-out, Line-in
Mic-in, Line-out,
Line-in
8-bit Digital I/O
N/A
N/A
N/A
8-bit Digital I/O
8-bit Digital I/O
Mini-PCIe
Mini-PCIe
Mini-PCIe
N/A
Mini-PCIe
N/A
DC 12V
DC 12V
DC 12V
DC 12V
DC 12V
DC 12V/Wire type
100~240V
100~240V
100~240V
100~240V
100~240V
100~240V
-25 ~ 70°C
-5 ~ 45°C
-5 ~ 45°C
-5 ~ 50°C
-5 ~ 50°C
-5 ~ 50°C
-20 ~ 80°C
-20 ~ 80°C
-40 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
95%@40°C,
non-condensing
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
5Grms/5~500Hz
50G, 11msce.
50G, 11msce.
50G, 11msce.
50G, 11msce.
50G, 11msce.
50G, 11msce.
200 x 150 x 51 mm
200 x 150 x 51 mm
200 x 150 x 51 mm
200 x 200 x 40 mm
253 x 190 x 70 mm
200 x 200 x 62 mm
1.6 kg
1.6 kg
1.6 kg
1.4 kg
4.2 kg
1.9 kg
WEBS Reference Table
Brick Concept
Brick Concept
As well as stable quality requirements, users are always looking for a unique product to differenciate them from
their competitors. To simplify system customization, Portwell created the Brick concept, an intelligent structure for
the WEBS systems that builds the WEBS chassis using three simple elements: wall, pillar and cover. This makes
the chassis flexible and easy for customization by following customer’s requirements. The illustation below shows
the segments for customization.
* May necessitate extra cost and MOQ for an individual customization.
REGO
200
150
200
OR
With its flexible structure, a Portwell WEBS system can adjust the size of its form-factor to supply a customized
chassis for the customer. The three system sizes below illustrate the standard WEBS system form-factors.
Customer can adapt any model to suit their applications. (Size unit is mm)
150x150x51 (NANO-ITX)
200x150x51 (3.5” ECX)
200x200x51 (Mini-ITX)
&RQ¿JXUDWLRQ
„ Full System: Chassis + (Power Module) + Adaptor + Cable + Embedded Board + Memory + HDD/CF
„ Bare System (By requuest only): Chassis + (Power Module) + Adaptor + Cable + Embedded Board
Brick Concept
124
WEBS-1320
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based 3.5” ECX board
Ethernet
DC In
RS232
51mm
USB
150mm
KB/MS
USB
Audio
VGA
200mm
Intel®
Fanless
Expandable
FEATURES
„
Intel® Atom™ processor Z510/Z530 and
System Controller Hub US15W
Ultra low power and fan-less design
„ Compact and user-friendly design for easy
installation and maintenance
„ Fan-less & cable-less design
„ 2QH6',2LQWHUIDFHIRUÀH[DEOHH[SDQVLRQ
„ Single DC 12V power input for easy system
intergation
„
Versatile mounting solutions such as Wall,
Panel and DIN mount (Optional)
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
Flexible
Green
IP40 Rating
Brick Concept
1
GbE
4
USB
CF
2.5”
SATA
System
M/B
PEB-2737
System Chipset
Intel® System Controller Hub US15W integrated GMA500
CPU
Intel ® Atom™ Z510 (1.1GHz)/Z530 (1.6GHz)
FSB
400/533 MHz
BIOS
AMI BIOS
System Memory
One 200-pin SODIMM supports DDR2 400/533 up to 2GB
Storage
1× SATA 2.5”; 1× CF
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System);
Voltage (CPU Vcore, VBAT, 5VSB, 12V, 5V, 3.3V)
„
„
1
COM
SDIO
Z510/530
External I/O
Serial Port
1× RS232
Display
1× VGA
USB
4× USB 2.0
Audio Interface
Line-out and Mic-in (ALC262)
Ethernet
1× Gigabit Ethernet (RTL8111C)
Others
PS2 KB+MS
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
ORDERING GUIDE
AS5-3275
(R).ATO.WEBS-1320.A.3.5”
ECX System.PEB-2737
Operation Temperature
-5~50°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
125
System-WEBS-1320
Dimension
200(W) × 150(D) × 51(H)mm; 7.9”(W) × 5.9”(D) × 2”(H)
Weight
1.2kg
Mounting
Desk, DIN/Wall/Panel-mounting
PS2
KB/MS
WEBS-2121
Embedded compact fan-less system with Intel®
AtomTM Z510/Z530 based NANO-ITX board
RS232
USB
51mm
150mm
DC In
DVI
Ethernet
Audio
2
USB
SD
150mm
Intel®
US15W
Fanless
Expandable
FEATURES
Intel® AtomTM Z510/Z530 processor and
System Controller Hub US15W
„ Ultra low power and fan-less design
„ One 200-pin SODIMM supports DDR2
SDRAM up to 2GB
„ Various storage types such as CompactFlash
and SATA 2.5” HDD
„ Fan-less & cable-less design
„ Single DC 12V power input for easy system
intergation
„ Versatile mounting solutions such as Wall,
Panel and DIN mount (Optional)
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„
„
IP40 Rating
Flexible
Green
Cable-less
1
GbE
2.5”
SATA
System
M/B
NANO-8045
System Chipset
Intel® System Controller Hub US15W integrated GMA500 Graphics
CPU
Intel ® AtomTM Z510 (1.1GHz)/Z530 (1.6GHz)
FSB
400/533
BIOS
AMI BIOS
System Memory
One 200-pin SODIMM support DDR2 400/533 up to 2GB
Storage
î6$7$+''î&)
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System) ;
Voltage (CPU Vcore VBAT, 5VSB, 12V, 5V, 3.3V)
External I/O
Serial Port
1× RS232
Display
1× DVI
USB
2× USB 2.0
Audio Interface
Brick Concept
1
COM
Ethernet
Line-out and Mic-in (ALC262)
1× Gigabit Ethernet (RTL8111C)
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
ORDERING GUIDE
AS5-3288
(R).ATO.WEBS-2121.A. NANO
System.NANO-8045
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
Dimension
:î'î+PP:î'î+
Weight
1 kg
Mounting
Desk, DIN/Wall/Panel-mounting
System-WEBS-2121
126
WEBS-3330
Embedded compact fan-less system with Intel®
AtomTM N270 based MINI-ITX board
RS232 / 422 / 485
Ethernet
VGA
51mm
200mm
KB/MS
RS232
DC In
DVI
USB
Audio
200mm
Intel®
945GSE
Dual
Display
Rugged
Fanless
FEATURES
Flexible
Cable-less
2
GbE
1
COM
4
USB
CF
2.5”
SATA
MiniPCI
PS2
KB/MS
System
Intel® AtomTM N270 1.6GHz processor
„ Intel® 945GSE+ICH70M platform
M/B
WADE-8070
System Chipset
Intel® 945GSE GMCH integrated GMA 950 Graphics and ICH7-M
„
Dual Display by VGA/DVI
One Mini-PCIExpress expansion and Antenna
hole
„ Fan-less & cable-less design
„ Single DC 12V power input for easy system
intergation
„ Vesatile mounting solutions such as Wall and
Panel mount (Optional)
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
CPU
Intel ® N270 1.6GHz processor
„
FSB
533 MHz
BIOS
Award BIOS
System Memory
One 200-pin SODIMM supports DDR2 400/533 up to 2GB
Storage
î6$7$+''î&)
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage, Case open function
Expansion
1× Mini-PCI socket
„
WEBS-3330-1602
External I/O
Serial Port
1× RS232 ; 1× RS232/422/485
Display
1× VGA ; 1× DVI
USB
4× SB 2.0
Audio Interface
Line-out and Mic-in (ALC262)
Ethernet
2× Gigabit Ethernet (RTL8111C)
Others
PS2 KB+MS
WEBS-3330-1603
Power Supply Unit
ORDERING GUIDE
AS5-3278
(R).ATO.WEBS-3330.MiniITX System.WADE-8070.
GADIWA-1090. 60W Adaptor
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
127
System-WEBS-3330
Dimension
:î'î+PP:î'î+
:î'î+PP:î'î+(W/ optional module)
Weight
1.8kg
Mounting
Desk, Wall/Panel-mounting
WEBS-3331
Embedded slim fan-less system with Intel®
AtomTM N270 based MINI-ITX board
VGA
DC In
Audio
36mm
200mm
USB
RS232
Ethernet
200mm
Intel®
945GSE
Cable-less
Fanless
FEATURES
Intel® AtomTM N270 1.6GHz processor
„ Intel® 945GSE+ICH70M platform
„ Analog Display: up to 2048 x 1536 (QXGA)
„ 36mm height supports thin client and DS
application
„ Fan-less and optional cable-less design for
easy maintence
„ Vesatile mounting solutions such as Wall and
Panel mount (Optional)
„ Single DC 12V power input for easy system
intergation
„ CF socket for storage
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
„
ORDERING GUIDE
AS5-3289
Rugged
Slim
Flexible
1
COM
1
GbE
4
USB
CF
Card
System
M/B
WADE-8071
System Chipset
Intel® 945GSE GMCH integrated GMA 950 Graphics and ICH7-M
CPU
Intel ® N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Memory
One 200-pin SODIMM supports DDR2 400/533 up to 2GB
Storage
1× CF
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage, Case open function
External I/O
Serial Port
1× RS232
Display
1× VGA
USB
4× USB 2.0
Audio Interface
Line-out and Mic-in (ALC262)
Ethernet
1× Gigabit Ethernet (RTL8111C)
(R).ATO.WEBS-3331.Mini-ITX
System.WADE-8071
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz , IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
Dimension
:î'î+PP:î'î+
Weight
1.1kg
Mounting
Desk , Wall/Panel-mounting
System-WEBS-3331
128
WEBS-1312
Embedded rugged fan-less system with Intel®
AtomTM Z510PT/Z520PT based 3.5” ECX board
GPIO
RS232
Antenna
Hole
VGA
51mm
150mm
USB
200mm
Intel®
US15WPT
Wide
Temperature
D I/O
Rugged
Fanless
FEATURES
Intel® AtomTM processor Z510PT/Z520PT
and System Controller Hub US15WPT
„ Wide temperature range and fan-less design
are perfect for environment-critical applications
„ One Mini-PCIExpress expansion and Antenna
hole
„ GPIO and rich I/O and good for versatile
applications
„ Rugged and compact are good for using at
harsh environment
„ Versatile mounting solutions such as Wall and
Panel mount (Optional)
„ Single DC 12V power input for easy system
intergation
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
„
ORDERING GUIDE
AS5-3273
(R).ATO.WEBS-1312.A.3.5”
ECX System.PEB-2739I
Cable-less
Green
2
COM
DC In
Audio
Ethernet
4
USB
Power Switch
RS232 / 422 / 485
1
GbE
System
M/B
PEB-2739
System Chipset
Intel® US15WPT
CPU
Intel ® AtomTM Z510PT (1.1GHz)/Z520PT (1.3GHz)
FSB
400/533 MHz
BIOS
AMI BIOS
System Memory
One 200-pin SODIMM support DDR2 400/533 up to 2GB
Storage
î&)î6$7$66'
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Expansion
1× Mini-PCIe socket
External I/O
Serial Port
1× RS232+1× RS232/422/485
Display
1× VGA
USB
4× USB 2.0
Audio Interface
Line-out and Mic-in (ALC262)
Ethernet
1× Gigabit Ethernet (82574IT)
Other
8 bits GPIO
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-25~70°C
Storage Temperature
-40~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
129
System-WEBS-1312
MiniPCIe
Dimension
200(W) × 150(D) × 51(H)mm ; 7.9”(W) × 5.9”(D) × 2”(H)
Weight
1.6kg
Mounting
Desk, Wall/Panel-mounting
WEBS-1330
Embedded rugged fan-less system with Intel®
AtomTM N270 based 3.5” ECX board
RS232 X 4
Antenna
Hole
51mm
150mm
DC In
200mm
Fanless
USB
Rugged
FEATURES
Green
Power
COM
4
COM
2
USB
2
GbE
Power Switch
Line-out
Ethernet
Intel®
945GSE
VGA
CF
2.5”
SATA
MiniPCIe
System
M/B
PEB-2131
System Chipset
Intel® 945GSE GMCH intergrated GMA 950 Graphics and ICH7-M
Display : Up to 2048 × 1536 (QXGA)
„ One Mini-PCIExpress expansion and Antenna
hole
„ 4 COMs (5V/12V selectable) are good for
Networking, POS and Automation applications
„ Rugged and compact are good for using at
harsh environment
CPU
Intel ® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Memory
One 200-pin SODIMM supports DDR2 400/533 up to 2GB
Storage
î&)î6$7$+''
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Versatile mounting solutions such as Wall and
Panel mount (Optional)
„ Single DC 12V power input for easy system
intergation
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
Expansion
1× Mini-PCIe socket
„
Intel® AtomTM N270 1.6GHz processor and
Intel® 945GSE+ICH7-M chipset
„ Analog
„
ORDERING GUIDE
AS5-3290
(R).ATO.WEBS-1330.A.3.5”
ECX System.PEB-2131
External I/O
Serial Port
4× Powered RS232 (5V/12V)
Display
1× VGA
USB
2× USB 2.0
Audio Interface
Line-out (ALC662)
Ethernet
2× Gigabit Ethernet (RTL-8111D)
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
Dimension
:î'î+PP:î'î+
Weight
1.6kg
Mounting
Desk, Wall/Panel-mounting
System-WEBS-1330
130
WEBS-1341
Embedded rugged fan-less system with Intel®
Atom™ N455/D525 based 3.5” ECX board
RS232
Power Switch
51mm
RS232 / 422 / 485 VGA
150mm
DC In
200mm
Intel®
N455/D525
Dual
Core
Fanless
FEATURES
Fan-less solution with Dual-Core CPU
„ Intel® AtomTM N455/D525 1.6/1.8GHz
processor and Intel® ICH8-M chipset
„ One Mini-PCIExpress expansion and Antenna
hole
„ Rich I/O is good for versatile applications
„ Rugged and compact design for harsh
environment
„ Versatile mounting solutions such as Wall and
Panel mount (Optional)
„ Single DC 12V power input for easy system
intergation
„ One Mini-PCI Express expansion
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock:50G, 11 msec.
„ IP40 Rating
„
ORDERING GUIDE
AS5-3271
4
COM
TPM
Rugged
(R).ATO.WEBS-1341.
3.5” ECX System.PEB2771VG2A/2781VG2A. DDR3.
40W Adapter
USB
Ethernet USB
Cable-less
4
USB
2
GbE
CF
2.5”
SATA
System
M/B
PEB-2771/2781
System Chipset
Intel® ICH8-M
CPU
Intel ® Atom N455 (1.6GHz)/D525 (1.8GHz) processor
FSB
800 MHz
BIOS
AMI BIOS
System Memory
One 204-pin SODIMM support DDR3 up to 2GB
Storage
î&)î6$7$+''
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage
Expansion
1× Mini-PCIe socket
External I/O
Serial Port
3× RS232 + 1× RS232/422/485
Display
1× VGA
USB
4× USB 2.0
Ethernet
2× Gigabit Ethernet (82567V + 82583V)
Others
Removeable CF card; Internal header for Audio (ALC262)
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
131
System-WEBS-1341
Dimension
:î'î+PP:î'î+
Weight
1.6 kg
Mounting
Desk, Wall/Panel-mounting
MiniPCIe
WEBS-3332
Embedded rugged fan-less system with Intel®
AtomTM N270 based MINI-ITX board
Power Switch
DC In
40mm
VGA
Audio
200mm
Ethernet
200mm
1
COM
Intel®
945GSE
Rugged
Fanless
FEATURES
Intel® AtomTM N270 1.6GHz processor and
Intel® 945GSE+ICH7-M chipset
„ 40mm height supports thin client and DS
application
„ Analog Display: Up to 2048×1536 (QXGA)
„ Rugged and slim design is ideal for
environment critical application
„ Fan-less and optional cable-less design for
easy maintenance
„ Vesatile mounting solutions such as Wall and
Panel mount (Optional)
„ Vibration test (5grms/5~500Hz/operation)
„ Shock test (50g peak acceleration-11 msec.
duration)
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
„
USB
RS232
Cable-less
Slim
4
USB
1
GbE
CF
Card
System
M/B
WADE-8071
System Chipset
Intel® 945GSE GMCH integrated GMA950 Graphics and ICH7-M
CPU
Intel ® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Memory
One 200-pin SODIMM support DDR2 400/533 up to 2GB
Storage
1× CF
Watchdog Timer
Programmable via S/W from 1 sec .to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage
External I/O
Serial Port
1× RS232
Display
1× VGA
USB
4× USB 2.0
Audio Interface
Line-out and Mic-in (ALC662)
Ethernet
1× Gigabit Ethernet (RTL8111C)
ORDERING GUIDE
AS5-3292
(R).ATO.WEBS-3332.Mini-ITX
System.WADE-8071
Power Supply Unit
Power Input
DC 12V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
Dimension
200(W) × 200(D) × 40(H)mm; 7.9”(W) × 7.9”(D) × 1.6”(H)
Weight
1.4 kg
Mounting
Desk, DIN/Wall/Panel-mounting
System-WEBS-3332
132
WEBS-3560B
Embedded rugged fan-less system with Intel® i7/
i5 based MINI-ITX board
Power Switch
RS232 / 422 / 485
VGA
Gigabit Ethernet
62mm
200mm
HDMI
DC In
200mm
Intel®
QM57
CoreTM
i7/i5
iAMT
6.0
Dual
Display
FEATURES
Fanless
HDMI
6
USB
2
GbE
USB
MiniPCIe
Intel® CoreTM i5/i7 processor (Quad-Core CPU
support)
„ Intel® QM57 Chipset
„ Two 204-pin SODIMMs DDR3 up to 8GB,
support dual channel
„ One Mini-PCIe socket (with USB+PCIe ×1
signal)
„ 1 SATA port, 2 GbE, 3 RS232+
1 RS232/422/485
„ Dual Display by VGA/DVI/HDMI
„ Intel® Active Management Technology (Intel®
AMT) 6.0
„ Fan-less and optional cable-less design for
easy maintence
„ Rugged design is good for using in harsh
environment
„ Vesatile mounting solutions such as Wall and
Panel mount (Optional)
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
ORDERING GUIDE
2.5”
SATA
(R).ATO.WEBS-3560B.
Mini-ITX System.WADE-8020.
128W Adaptor
M/B
WADE-8020
System Chipset
Intel® QM57
CPU
Intel ® Core i5/i7 processor (PGA989)
FSB
800/1066/1333
BIOS
AMI UEFI BIOS
System Memory
Two 204-pin SODIMM support dual channel DDR3 SDRAM up to 8GB
Storage
1× SATA 2.5” SSD
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Monitoring Temperature, Voltage, and cooling fan status
Expansion
1× Mini-PCIe socket
External I/O
Serial Port
3× RS232 + 1× RS232/422/485
Display
1× VGA + 1× DVI-D
USB
6× USB 2.0
Audio Interface
Line-in, Line-out and Mic-in (ALC888)
Ethernet
2 × Gigabit Ethernet (82574L+82577LM)
Power Supply Unit
Power Input
DC 12~36V
Adaptor
AC 100~240V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
133
Audio
System
„
AS5-3269
Rugged
4
COM
DVI-D
RS232
System-WEBS-3560B
Dimension
253(W) × 190(D) × 70(H)mm; 10”(W) × 7.5”(D) × 2.8”(H)
Weight
4.2kg
Mounting
Desk, Wall/Panel-mounting
WEBS-4330
Embedded rugged fan-less system with Intel®
AtomTM N270 based MINI-ITX board
Ethernet
KB / MS
VGA
RS232
Audio
62mm
200mm
Power Switch
200mm
Intel®
945GSE
Dual
Display
2
COM
D I/O
Rugged
FEATURES
Intel® AtomTM N270 1.6GHz processor and
Intel 945GSE+ICH7-M chipset
„ Dual Display (VGA/DVI-D), Dual Gigabit
Ethernet and Dual RS232
„ Analog Display: up to 2048*1536 (QXGA)
„ Optional GADIWA-R9271 (9~27V) for IVI
application
„ Rugged and Fan-less design is ideal for
Environment-crtical application
„ External GPIO (4 in, 4 out) for digital control
„ Vesatile mounting solutions such as Wall and
Panel mount (Optional)
„ Single DC 12~36V power input for easy
system intergation
„ Two interfaces of DC power input by adaptor
plug or wiring type
„ OP Vibration: 5Grms/5~500Hz
„ OP Shock: 50G, 11 msec.
„ IP40 Rating
„
ORDERING GUIDE
AS5-3293
(R).ATO.WEBS-4330.A.MINIITX System. WADE-8170.
Wire-type
AS5-3294
(R).ATO.WEBS-4330.A.MINIITX System. WADE-8170.
DC-In
Fanless
GPIO
Cable-less
DVI
RS232
USB
DC In (Wire type)
4
USB
2
GbE
PS2
KB/MS
System
M/B
WADE-8170
System Chipset
Intel® 945GSE GMCH integrated GMA 950 Graphics and ICH7-M
CPU
Intel ® AtomTM N270 1.6GHz processor
FSB
533 MHz
BIOS
Award BIOS
System Memory
One 200-pin SODIMM supports DDR2 400/533 up to 2GB
Storage
1× CF, 1× SATA 2.5” HDD
Watchdog Timer
Programmable via S/W from 1 sec. to 255 min.
H/W Status Monitor
Temperature (CPU and System), Voltage
External I/O
Serial Port
2× RS232
Display
1× VGA + 1× DVI-D
USB
4× USB 2.0
Audio Interface
Line-in, Line-out and Mic-in (ALC655)
Ethernet
2× Gigabit Ethernet (ALC8111C)
Others
8 bits GPIO; PS2 KB+MS
Power Supply Unit
Power Input
DC 12~36V
Adaptor
AC 100~240V
Optional wire type DC-IN
DC 9~27V
Environmental
Operation Temperature
-5~45°C
Storage Temperature
-20~80°C
Relative Humidity
95%@40°C, non-condensing
Operation Vibration
5Grms/5~500Hz, IEC 60068-2-27
Operation Shock
50G, 11 msec., IEC 60068-2-27
Mechanical
Dimension
200(W) × 200(D) × 62(H)mm; 7.9”(W) × 7.9”(D) × 2.4”(H)
Weight
1.9 kg
Mounting
Desk , Wall/Panel-mounting
System-WEBS-4330
134
WEBS Mounting Solution
Wall Mount Kit
WEBS-2120/2121/1320
Panel Mount Kit
WEBS-2120/2121
System Size
150/200(W) x 150(D) x 51(H)mm
System Size
150(W) x 150(D) x 51(H)mm
Ordering
WEBS-2120 Wall Mount Kit
Ordering
WEBS-2120 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330/3331
System Size
200(W) x 200(D) x 51/36(H)mm
WEBS-1320
Ordering
WEBS-3330 Wall Mount Kit
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1320 Panel Mount Kit
Remark
VESA 75/100
WEBS-3330/3331
System Size
200(W) x 200(D) x 51/36(H)mm
Ordering
WEBS-3330 Panel Mount Kit
Remark
VESA 75/100
WEBS-3332/4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Wall Mount Kit
WEBS-1310/1330/1340
System Size
200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Wall Mount Kit
DIN Mount Kit
WEBS-3332/4330
System Size
200(W) x 200(D) x 40/62(H)mm
Ordering
WEBS-3332 Panel Mount Kit
Remark
VESA 75/100
WEBS-1310/1330/1340
WEBS-2120 / 2121 / 1320
135
System Size
200(W) x 150(D) x 51(H)mm
System Size
150/200(W) x 150(D) x 51(H)mm
Ordering
WEBS-1310 Panel Mount Kit
Ordering
WEBS-2120 Wall Mount Kit
Remark
VESA 75/100
Remark
DIN Rail H=35mm (w/o Rail)
System-WEBS Mounting Solution
PSU Reference Table
ORION-A2501
ORION-D5501P
ORION-300DX/24/48
ORION-D4601P
ORION-D4602P
MPM-842P
MPI-815H
MPI-810H
TYPE
MODEL
FORM
FACTOR
DIMENSON
Single
GADIWA-P0901
DC/DC
60 x 45 x 15 mm
120W / ATX Output
137
WideRange
GADIWA-R9271
Regulator
60 x 45 x 22 mm
9-27V DC /
Regulator
138
WideRange
GADIWA-3160
DC/DC
150 x 51 x 22.5 mm
128W / 12~36V DC
Wide Input
139
WideRange
GADIWA-3161
DC/DC
100 x 45 x 22.5 mm
128W / 9-29V DC
Wide Input
140
Single
ORION-A1501
1U
100 x 190 x 40 mm
3.93” x 7.48” x 1.57”
150W / PFC / P4
141
Single
ORION-A2501
1U
100 x 190 x 40.5 mm
3.93” x 7.48” x 1.60”
250W / PFC / P4
141
Single
ORION-A1501P
Flex
81.5 x 150 x 40.5 mm
3.2” x 5.9” x 1.6”
150W / ATX
142
Single
ORION-A1801P
Flex
81.5 x 150 x 40.5 mm
3.2” x 5.9” x 1.6”
180W / ATX
142
Single
ORION-B3501P
2U
200 x100 x 70 mm
7.87” x 3.94” x 2.8”
350W / PFC / P4
143
Single
ORION-B4001
2U
100 x 240 x 70 mm
3.9” x 9.4” x 2.8”
400W / PFC / P4
143
Single
ORION-D3501P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
350W / PFC / P4
144
Single
ORION-D4601P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
460W / PFC / P4
144
Single
ORION-D5501P
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
550W / PFC / P4
145
Single
ORION300DX/24/48
PS/2
150 x 140 x 86 mm
5.9” x 5.5” x 3.4”
300W / DC / ATX
145
Redundant
ORION-D3502P
mini-redundant
(PS/2)
150 x 190 x 84 mm
5.9” x 7.2” x 3.4”
350W / PFC / P4
146
Redundant
ORION-D4602P
mini-redundant
(PS/2)
150 x 190 x 85 mm
5.9” x 7.2” x 3.3”
460W / PFC / P4
146
Single
MPM-842P
PS/2
150 x140 x 86 mm
5.9” x 5.5” x 3.4”
400W / Medical /
ATX
147
Single
MPI-815H
1U
198 x 93 x 40.5 mm
7.8” x 3.66” x 1.6”
150W / Fanless /
ATX
147
Single
MPI-810H
OPEN FRAME
83.9 x 152.4 x 38.1 mm
3.3” x 6” x 1.5”
120W / ATX
148
Single
MPD-810H
OPEN FRAME
DC TO DC
83.9 x 152.4 x 38.1 mm
3.3” x 6” x 1.5”
120W / DC / ATX
148
Single
MPE-008A-P
OPEN FRAME
50.8 x 127 x 40 mm
2” x 5” x 1.57”
80W / ATX
149
Single
MPI-806H
OPEN FRAME
128 x 81 x 40 mm
5.0” x 3.2” x 1.55”
60W / ATX
149
POWER RANGE PAGE
Adapter
150
&RQ¿JXUDWLRQ0DWUL[
151
MPI-806H
Industrial Power Supply
136
GADIWA-P0901
12V / Mini-Fit 8 pin
input power connector
120W DC/DC Converter (12V/input,
ATX/output), Board Type
Main / Mini-Fit 20 pin
output power connector
GADIWA-P0901 is a DC-DC converter for board type. It normally support 120Watts and maximum can reach to
150Watts. GADIWA-P0901 can save more space and cost, it’s not only capability for fan-less system but also
suitability for different application. Moreover, the converter is made and tested by automatic production line;
therefore, it can provide high quality and performance.
FEATURES
Installation Image
„ 12V DC/input, plug into the ATX connector with board
output
„ Compact and user-friendly design for installation and
maintenance
„ Fan-less design for mission-critical application
„ Small size for 1U or higher system to save space
SPECIFICATION
Input Voltage
12V (+5%/-4%)
Line Regulation
11.52V / 12.6V
Output
120Watts/ 150Watts peak
(I¿FLHQF\
>96% @ 12.3V
MTBF
836,407hrs @45°C, 592,361hrs @55°C
EMI & Safety Approval
CE, FCC
Input Connector
Mini-Fit 8 pin (P/N: B6902040)
Output Connector
Mini-Fit 20 pin (P/N: B6902071)
Dimension (WxDxH)
60 x 45 x 15 mm
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
0~7A
6.5A
+5V
0~6A
6A
+3.3V
0~6A
6A
+5Vsb
0~2A
1A
-12V
0~0.1A
0.1A
ORDERING GUIDE
GADIWA-P0901
120W DC/DC Converter (12V/input, ATX/output), Board Type
137
Industrial Power Supply
GADIWA-R9271
9V~27V/wide-input, 12V/output
Regulator, Board Type
9V~27V / Mini-Fit 3 pin input power connector
12V / Mini-Fit 8 pin output power connector
GADIWA- R9271 is a wide input regulator for board type. GADIWA-R9271 can collocate with GADIWA-P0901
and GADIWA-1120 which are DC-DC converters; it’s easily to deploy critical application. The converter is made
and tested by automatic production line; therefore, it can provide high quality and performance. GADIWA-R9271
has special design for socket type fuse protection.
FEATURES
Installation Image
„ Compact and user-friendly design for installation and
maintenance
„ Small size for 1U or higher system to save space
„ Suitable for Car PC, Steamer, Truck, Boat and Adapter
„ Special Design for Delay-Time
„ Socket Type Fuse Protection
SPECIFICATION
Input Voltage
9V~27V
Line Regulation
9V~27V continuous, 7~30V<10 [email protected] start
(I¿FLHQF\
>95% @ 14V input
MTBF
577,768hrs @45°C, 409,990hrs @55°C
EMI & Safety Approval
CE, FCC
Input Connector
Mini-Fit 3 pin (P/N: B6902060)
Output Connector
Mini-Fit 8 pin (P/N: B6902042)
Dimension (WxDxH)
60 x 45 x 22 mm
GADIWA-R9271
GADIWA-P0901
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
12.3V @ 0~8.5A
12.3V @ 0~8.5A
ORDERING GUIDE
GADIWA-R9271
9V to 27V/Wide-input, 12V/output Regulator, Board Type
Industrial Power Supply
138
GADIWA-3160
128W DC/DC 12V~36V/wide-input,
ATX/output, Board Type Converter
GADIWA- 3160 is a wide input converter for board type. It normally support 128Watts and maximum can reach
to 160Watts. GADIWA-3160 can save more space and cost, it’s not only capability for fan-less system but also
VXLWDELOLW\IRUGLIIHUHQWDSSOLFDWLRQ*DGLZDDOVRKDYH8/FHUWL¿FDWLRQDQGZDWFKGRJIXQFWLRQGHVLJQLW¶OOEH
easy to deploy any critical application.
FEATURES
Installation Image
„ 12~36V/Wide-input, plug into the ATX connector with
board output
„ Compact and user-friendly design for installation and
maintenance
„ Fan-less design for mission-critical application
„ Small size for 1U or higher system to save space
12V output
„ Watchdog Timer function
20 pin output
SPECIFICATION
6 pin input
Input Voltage
12V~36V
Line Regulation
11.5V~36V/input
Output
128Watts / 160Watts Peak
(I¿FLHQF\
>85% @ 12V
MTBF
245.000hrs @45°C, 192,000hrs @55°C
EMI & Safety Approval
UL, CE, FCC
Input Connector
12V~36V / 6 pin
Output Connector
Main / ATX 20 pin
Dimension (WxDxH)
150 x 51 x 22.5 mm
CHARACTERISTICS
Output Voltage
Current Range
(forced air 10cfm)
Current Range
(convection or high temperatures)
+12V
0~8A
0~6A
+5V
0~8A
0~6A
+3.3V
0~7A
0~5.25A
+5Vsb
0~2A
0~1.5A
-12V
0~0.15A
0~0.12A
ORDERING GUIDE
GADIWA-3160
128W DC/DC 12V~36V/wide-input, ATX/output, Board Type Converter
139
Industrial Power Supply
GADIWA-3161
Main / ATX 20 pin output power connector
128W DC/DC 9V~29V/wide-input,
ATX/output, Board Type Converter
9V~29V / 3 pin input
power connector
12V / ATX 4 pin output power connector
Thermal Pad
GADIWA- 3161 is a wide input board type converter. It normally support 128Watts and maximum can reach to
160Watts. GADIWA-3161 can save more space and cost, it’s not only capability for fan-less system but also
suitability for different application. Besides, the converter is made and tested by automatic production line;
therefore, it can provide high quality and performance.
FEATURES
Installation Image
„ 9~29V/Wide-input, plug into the ATX connector with
board output
„ Compact and user-friendly design for installation and
maintenance
„ Fan-less design for mission-critical application
12V output
„ Small size for 1U or higher system to save space
„ Socket Type Fuse Protection
SPECIFICATION
6 pin input
Input Voltage
9V~29V, 6~9V workable with derating
Line Regulation
9V~29V/input
Output
128Watts / 160 Watts Peak
(I¿FLHQF\
>85% @ 12V input @ 120W output
EMI & Safety Approval
CE, FCC
Input Connector
9V~29V / 3 pin
Output Connector
Main / ATX 20 pin
Dimension (WxDxH)
100 x 45 x 22.5 mm
20 pin output
CHARACTERISTICS
Output Voltage
Load Regulation
Cross Regulation
+12V
0~6A
6A
+5V
0~6A
6A
+3.3V
0~6A
6A
+5Vsb
0~2A(Share with +5V)
2A(Share with +5V)
-12V
0~0.1A
0.1A
ORDERING GUIDE
GADIWA-3161
128W DC/DC 9V~29V/wide-input, ATX/output, Board Type Converter
Industrial Power Supply
140
ORION-A1501
150W 1U ATX power supply with
active PFC
FEATURES
/RZSUR¿OHSRZHUVXSSO\VXLWDEOHIRU8DQG
node chassis
„ Active PFC, full-range input
„ Higher +5V and +3.3 V output
„ Max. +5V standby output is 1.5A
„
ORDERING GUIDE
„ORION-A1501
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 65%
16 ms. at full load
+5V: 5.6~6.6V; +3.3V: 3.6~4.2V; +12V: 13.2~14.6V
Output power over 110% ~ 160%
MTBF
EMI & Safety Approval
Temperature/Humidity
84,228 hrs
UL, cUL, TUV, CE, FCC
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
100 x 190 x 40 mm; 3.9” x 7.48” x 1.57”
Dimension (WxDxH)
150W 1U ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
14A
10A
6A
0.5A
0.8A
1.5A
Min. Load
2A
1A
1A
0.1A
0.1A
0.1A
Max. Watt.
135W
135W
135W
2.5W
9.6W
7.5W
Load Reg.
±5%
±5%
±5%
±5%
±10%
±5%
Cross Reg.
±5%
±5%
±5%
±5%
±10%
±5%
Line Reg.
±1%
±1.5%
±0.8%
±1%
±1%
±1%
Ripple
±1%
±1.8%
±1%
±2%
±1%
±1.2%
Noise
±1.4%
±2.1%
±1%
±2%
±1%
±1.4%
ORION-A2501
250W 1U ATX power supply
with active PFC
FEATURES
/RZSUR¿OHSRZHUVXSSO\VXLWDEOHIRU8DQG
node chassis
„ Active PFC, full-range input
„Support for Intel® Pentium® 4 processor
„ Total output power of +5V, +3.3V and +12V
is 234W
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 65%
16 ms at full load
+5V: 5.4 ~ 6.5V; +3.3V: 3.9 ~ 4.4V; +12V: 13.6 ~ 15.6V
Output power over 110% ~ 160%
MTBF
EMI & Safety Approval
Temperature/Humidity
105,405 hrs
UL, cUL, TUV, CE, FCC,CCC
Operating: 5 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
100 x 190 x 40.5 mm; 3.93” x 7.48” x 1.59”
Dimension (WxDxH)
„ORION-A2501
250W 1U ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
24A
20A
12A
0.5A
0.5A
1.5A
Min. Load
3A
1A
2A
0A
0A
0.1A
Load Reg.
±5%
±5%
±8%
±10%
±10%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
80mv
80mv
120mv
150mv
150mv
80mv
Ripple &
Noise
141
Industrial Power Supply
ORION-A1501P
150W Flex form factor power
supply with active PFC
FEATURES
Flex form factor power supply
Full-range input with active PFC
„ Max. 5V output is 13A
„ Low noise
„
„
ORDERING GUIDE
SPECIFICATION
„ORION-A1501P
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 71%
16 ms at full load
+5V: 5.7 ~ 6.5V; +3.3V: 3.7 ~ 4.5V; +12V: 13.3V ~ 15.6V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
>160,000 hrs
TUV, UL / cUL
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
Dimension (WxDxH)
150W PSU. Active PFC. Low Noise
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
13A
10A
10A
0.5A
2A
Min. Load
0.3A
0.3A
1A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
50mv
ORION-A1801P
180W Flex form factor power
supply with active PFC
FEATURES
Flex form factor power supply
Full-range input with active PFC
„ Max. +5V output is 16A
„ Low noise
„
„
ORDERING GUIDE
SPECIFICATION
„ORION-A1801P
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 75%
16 ms at full load
+5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
>130,000 hrs
UL, TUV, BSMI, NEMCO, CCC, CE
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
81.5 x 150 x 40.5 mm; 3.2” x 5.9” x 1.6”
Dimension (WxDxH)
180W PSU. Active PFC. Low Noise
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
16A
14A
14A
0.5A
2A
Min. Load
0.3A
0.3A
1.5A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
50mv
Industrial Power Supply
142
ORION-B3501P
350W 2U ATX power supply
with active PFC
FEATURES
2U ATX power supply suitable for 2U and larger
chassis
„ Active PFC, full-range input
„Support Intel® Pentium® 4 processor
„ Max. +5V standby output is 2A
„ Max. +12V load output is 25A
„
ORDERING GUIDE
SPECIFICATION
„ORION-B3501P
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 67%
16 ms at full load
+5V: 6.5 ~ 7.0V; +3.3V: 4.5V; +12V: 14.5V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
100,000 hrs
UL, CB, TUV, CE, FCC
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
200 x 100 x 70 mm; 7.87” x 3.94” x 2.8”
Dimension (WxDxH)
350W 2U ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-12V
Max. Load
25A
17A
25A
0.5A
2A
Min. Load
1.0A
1.0A
1.0A
0.25A
0A
Load Reg.
±5%
±5%
±5%
±10%
±5%
Line Reg.
±1%
±1.5%
±0.4%
±0.4%
±1%
Ripple
50mv
50mv
120mv
120mv
50mv
Noise
100mv
100mv
150mv
200mv
100mv
ORION-B4001
+5Vsb
400W 2U ATX power supply with
active PFC
FEATURES
/RZSUR¿OHSRZHUVXSSO\VXLWDEOHIRU8DQGQRGH
chassis
„ Dual ATX 12V power connector for dual Intel®
Xeon™ processor based server board ROBO-8820VG2
„ Active PFC, full range input
„ Total output power of +5V, +3.3V and +12V is
385W
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 70%
16 ms. at full load
MTBF
EMI & Safety Approval
Temperature/Humidity
87,961 hrs
UL, cUL, TUV, CE, FCC
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
100 x 240 x 70 mm; 3.9” x 9.4” x 2.8”
Dimension (WxDxH)
143
Industrial Power Supply
„ORION-B4001
400W 2U ATX power supply with active PFC
DC OUTPUT
+5V: 5.7~6.5V; +3.3V:3.9~4.3V; +12V: 13.6~15.0V
+5V
+3.3V
+12V
-5V
-12V
Max. Load
33A
28A
25A
0.8A
1A
2A
Min. Load
5A
1A
2.5A
0.05A
0.1A
0.1A
Output power over to 110%~150%
385W
+5Vsb
4W
12W
10W
Load Reg.
±5%
±5%
±5%
±5%
±5%
±5%
Cross Reg.
±5%
±5%
±5%
±5%
±5%
±5%
Line Reg.
±1%
±1.5%
±0.4%
±1%
±0.4%
±1%
Ripple
±1.2%
±1.5%
±0.8%
±3%
±1.25%
±1.2%
Noise
±1.2%
±1.5%
±0.8%
±3%
±1.25%
±1.2%
Max. Watt
ORION-D3501P
350W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply, suitable for 2U, node
chassis, and larger chassis
„ Active PFC, full-range input
„ Total output power of +5V,+3.3V and +12V is 326W
„ Max. +12V load output is 18A
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected]
> 68%
17 ms. at full load @25oC
MTBF
EMI & Safety Approval
75,145 hrs
UL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO,
NEMCO, DIMCO
Operating: 0 ~ 50oC, 20 ~ 85%RH
Storage: -40 ~ 70oC, 10 ~ 90%RH
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
Temperature/Humidity
Dimension (WxDxH)
„ORION-D3501P
350W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V: 7V; +3.3V: 4.3V; +12V: 15.6V
Output power over to 110%~140%
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
18A
20A
18A
0.3A
0.5A
2.5A
Min. Load
1A
1A
1A
0A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±10%
±5%
Line Reg.
±1%
±1.5%
±1%
±2.4%
±1%
±1%
Ripple
±1%
±1.5%
±0.8%
±3%
±1.25%
±1%
Noise
±1%
±1.5%
±0.8%
±3%
±1.25%
±1%
ORION-D4601P
460W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U
and larger chassis
„ Active PFC, full-range input
„Support Intel® Pentium® 4 processor
„ Max. +5V load output is 20A
„
ORDERING GUIDE
„ORION-D4601P
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
80%
16 ms at full load
+5V: 5.7 ~ 7.0V; +3.3V: 3.9 ~ 4.5V; +12V: 13.6 ~ 16.0V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
100,000 hrs
UL, TUV
Operating: 0 ~ 40oC, 20 ~ 85%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
Dimension (WxDxH)
460W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
20A
22A
16A
0.5A
2.5A
Min. Load
0.5A
0.3A
1A
0A
0A
Reg.
±5%
±5%
±5%
±10%
±5%
Ripple
50mv
50mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
50mv
Industrial Power Supply
144
ORION-D5501P
550W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U and larger
chassis
„ Active PFC, full-range input
„Support Intel® Pentium® 4 processor
„ Max. +5V load output is 29A
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 60%
16 ms at full load
+5V: 5.7 ~ 7.0V; +3.3V: 3.9 ~ 4.5V; +12V: 13.6 ~ 16.0V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
100,000 hrs
UL, cUL, TUV, CE, FCC
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
150 x 165 x 86 mm; 5.9” x 6.5” x 3.4”
Dimension (WxDxH)
„ORION-D5501P
550W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
29A
27A
18A
0.3A
0.8A
2A
Min. Load
3A
0.4A
1A
0A
0A
0A
+5% -4%
+5% -4%
+5% -4%
±10%
+9% -5%
+5% -4%
Reg.
Ripple
50mv
50mv
120mv
120mv
120mv
50mv
Noise
50mv
50mv
120mv
120mv
120mv
50mv
ORION-300DX/24/48
300W-48V/24V DC input
DC/DC PS/2 ATX power supply
FEATURES
PS/2 ATX power supply suitable for 2U and
larger chassis
„ ORION-300DX/24 for +24V DC input, suitable
for vehicle applications
„ ORION-300DX/48 for -48V DC input, suitable for
telecommunication applications
„ Max. -12V output is 2A, suitable for CTI application
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
Input Current
[email protected], [email protected] DC input
(I¿FLHQF\
Holdup Time
Over Voltage Protection
MTBF
EMI & Safety Approval
Temperature/Humidity
> 65%
16 ms
+5V: 5.7 ~ 7.0V
100,000 hrs
UL, TUV, CSA
Operating: 0 ~ 40oC, 10 ~ 90%RH
Storage: -60 ~ 70oC, 5 ~ 95%RH
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
Dimension (WxDxH)
145
-40V~-72V DC for ORION-300DX/48
19V~32V DC for ORION-300DX/24
Industrial Power Supply
„ORION-300DX/48
300W -48V DC input DC/DC PS/2 ATX power supply
„ORION-300DX/24
300W 24V DC input DC/DC PS/2 ATX power supply
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
30A
15A
15A
2A
2A
1.2A
Min. Load
2A
0.3A
0.5A
0A
0A
0A
Load Reg.
±5%
±3%
±5%
±10%
±5%
±5%
Cross Reg.
±5%
±3%
±5%
±10%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
Ripple
±1%
±1.5%
±1%
±2%
±1%
±1%
Noise
±1%
±1.5%
±1%
±2%
±1%
±1%
ORION-D3502P
350W+350W mini-redundant with
active PFC power supply
FEATURES
„
Mini-redundant ATX power supply suitable for 2U
and larger chassis
„ Active
„
PFC, full-range input
Two independent AC inputs
ORDERING GUIDE
SPECIFICATION
„ORION-D3502P
Input Voltage
100V~240V AC
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
[email protected], [email protected]
> 80%
16 ms. at full load
[email protected]; [email protected]; [email protected]
MTBF
EMI & Safety Approval
Temperature/Humidity
> 100,000 hrs
UL, cUL, TUV, CE, FCC
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
150 x 190 x 84 mm; 5.9” x 7.2 x 3.4”
Dimension (WxDxH)
350W+350W mini-redundant power supply with active
PFC (PS/2 bracket is available)
DC OUTPUT
+5V
+3.3V
+12V
-5V
-12V
+5Vsb
Max. Load
20A
20A
18A
0.5A
0.8A
2A
Min. Load
0.5A
0.5A
0.5A
0A
0A
0A
Load Reg.
±5%
±5%
±5%
±10%
±5%
±5%
Cross Reg.
±5%
±5%
±5%
±10%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
200mv
200mv
50mv
Noise
50mv
50mv
120mv
200mv
200mv
50mv
ORION-D4602P
460W+460W mini-redundant with
active PFC power supply
FEATURES
Mini-redundant power supply suitable for 2U/4U
and larger chassis
„ Active PFC, full-range input
„ Two independent AC inputs
„
ORDERING GUIDE
„ORION-D4602P
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 65%
20 ms. at full load
+5V: 5.6 ~ 6.5V; +3.3V: 3.8 ~ 4.3V; +12V: 13.6 ~ 15.6V
Output power over 110% ~ 130% on +3.3V/+5V;
120% ~ 150% on +12V
100,000 hrs
UL, TUV
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -40 ~ 70oC, 5 ~ 95%RH
150 x 190 x 85 mm; 5.9” x 7.5” x 3.3”
MTBF
EMI & Safety Approval
Temperature/Humidity
Dimension (WxDxH)
460W+460W mini-redundant power supply with active
PFC (PS/2 bracket is available)
DC OUTPUT
+5V
+3.3V
+12V
-12V
Max. Load
25A
25A
30A
0.8A
+5Vsb
2A
Min. Load
2A
2A
2.5A
0A
0A
Max. Watt.
370W
370W
370W
9.6W
10W
Load Reg.
±5%
±5/-3%
±5%
±5%
±10%
Cross Reg.
±5%
±5/-3%
±5%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
±1%
±1%
±1%
±1%
±1%
Noise
±1%
±1%
±1%
±2%
±1%
Industrial Power Supply
146
MPM-842P
400W PS/2 ATX power supply
with active PFC
FEATURES
PS/2 ATX power supply suitable for 2U and larger
chassis
„ Active PFC, full-range input
„Support Intel® Pentium® 4 processor
„ Max. 12V output is 22A
„ Medical level power supply
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 71%
16 ms at full load
+5V: 4.75 ~ 5.25V; +3.3V: 3.14 ~ 3.47V; +12V: 11.4V ~ 12.6V
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
>160,000 hrs
TUV, UL/cUL
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
150 x 140 x 86 mm; 5.9” x 5.5” x 3.4”
Dimension (WxDxH)
„MPM-842P
400W PS/2 ATX power supply with active PFC
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
21A
22A
22A
0.8A
1.5A
Min. Load
0.3A
0.5A
1A
0A
0.1A
Load Reg.
±5%
±5%
±5%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple &
Noise
50mv
50mv
120mv
120mv
50mv
MPI-815H
150W 1U ATX power supply
with active PFC
FEATURES
1U ATX power supply
Full-range input
„Max. +5V standby output is 14A
„Thermal protection
„+5V standby & remote On/Off
„
„
ORDERING GUIDE
SPECIFICATION
90V ~ 264V AC, full range
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 75%
16 ms at full load
+5V: 5.7 ~ 6.5V; +3.3V: 3.9 ~ 4.3V; +12V: 13.6 ~ 15
Output power over 110% ~ 150%
MTBF
EMI & Safety Approval
Temperature/Humidity
>130,000 hrs
UL
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
198 x 93 x 40.5 mm; 7.8” x 3.66” x 1.6”
Dimension (WxDxH)
147
„MPI-815H
Input Voltage
Industrial Power Supply
150W fanless, 1U, ATX power supply
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
14A
12A
10A
1A
1.5A
Min. Load
1A
0A
0A
0A
0A
Load Reg.
±2%
±5%
±5%
±5%
±5%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple &
Noise
50mv
50mv
100mv
150mv
100mv
MPI-810H
120W universal input open-frame
power supply
FEATURES
3.3” x 6” open-frame power supply suitable for
node chassis
„ Five rails outputs
(+5V, +12V, -12V, +3.3V & +5Vsb)
„ Universal AC input
„ Higher +5V output (14A)
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
90 ~ 260V AC
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected] or [email protected]
> 70%
16 ms at full load
+5V: 5.6 ~ 6.6V; +3.3V: 3.6 ~ 4.2V; +12V: 13.2 ~ 14.6V
Output power over 110% ~ 160%
MTBF
EMI & Safety Approval
Temperature/Humidity
130,000 hrs
UL, VDE, CSA
Operating: 0 ~ 50oC, 20 ~ 90%RH
Storage: -20 ~ 70oC, 5 ~ 95%RH
83.8 x 152.4 x 38.1 mm; 3.3” x 6” x 1.5”
Dimension (WxDxH)
„MPI-810H
120W universal input open-frame power supply
DC OUTPUT
+5V
+3.3
+12V
-12V
+5Vsb
Max. Load
14A
12A
6A
1A
0.75A
Min. Load
1A
0A
0A
0A
0A
Load Reg.
±3%
±5%
±5%
±5%
±5%
±1%
Line Reg.
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
200mv
MPD-810H
120W universal input open-frame,
DC to DC power supply
FEATURES
Open-frame DC to DC power supply suitable for
node chassis
„ Five rails outputs (+5V, +12V, -12V, +3.3V & +5Vsb)
„ 10~30 VDC input
„ Higher +5V output (10A)
„
ORDERING GUIDE
SPECIFICATION
Input Voltage
10V ~ 30V DC
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected] DC
> 70%
16 ms at full load
+5V: 5.6 ~ 6.6V; +3.3V: 3.6 ~ 4.2V; +12V: 13.2 ~ 14.6V
Output power over 110% ~ 160%
MTBF
EMI & Safety Approval
Temperature/Humidity
130,000 hrs
UL
Operating: 0 ~ 50oC, 20 ~ 90%RH
Storage: -20 ~ 70oC, 5 ~ 95%RH
83.8 x 152.4 x 38.1 mm; 3.3” x 6” x 1.5”
Dimension (WxDxH)
„MPD-810H
120W 10~30VDC input open-frame power supply
DC OUTPUT
+5V
+3.3
+12V
-12V
+5Vsb
Max. Load
10A
8A
4A
1A
0.75A
Min. Load
1A
0A
0A
0A
0A
Load Reg.
±2%
±5%
±5%
±5%
Line Reg.
±2.5%
±2.5%
±2.2%
±2.5%
Ripple
100mv
100mv
120mv
200mv
±2.5%
Industrial Power Supply
148
MPE-008A-P
80W universal input open-frame
power supply
FEATURES
60W convection cooling and 80W forced
air-cooling
„ Conductive EMI Meets CISPR/FCC Class B
„ 2” x 5” compact size dual output
„ A ray leakage current <100uA
„
ORDERING GUIDE
SPECIFICATION
„MPE-008A-P
Input Voltage
90V ~ 264V AC
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
[email protected]; [email protected]
> 80%
16 ms at full load
Automatic recovery up on of over voltage condition. Trigger
point is at about 5.8V ~ 6.8V
130,000 hrs
UL, cUL, TUV, CE, CCC
Operating: -20 ~ 50oC, 5 ~ 95%RH
Storage: -20 ~ 85oC, 5 ~ 95%RH
50.8 x 127 x 40 mm; 2.0” x 5” x 1.57”
MTBF
EMI & Safety Approval
Temperature/Humidity
Dimension (WxDxH)
MPI-806H
80W universal input open-frame power supply
DC OUTPUT
5V
+12V
Max. Load
5A
5A
Min. Load
0A
0A
Load Reg.
±3%
±3%
Line Reg.
±1%
±1%
Ripple
50mv
120mv
Noise
50mv
120mv
60W universal input open-frame
power supply
FEATURES
80W with 8.6CFM forced air-cooling
Compact size with ATX output
„ PG/PF signal
„ +5V standby & remote on/off
„
„
ORDERING GUIDE
„MPI-806H
SPECIFICATION
Input Voltage
90V ~ 264V AC
Input Frequency
47 ~ 63 Hz
Input Current
(I¿FLHQF\
Holdup Time
Over Voltage Protection
Over Power/Load Protection
[email protected], [email protected]
> 70%
20 ms. at full load
+5V: 5.15 ~ 6.45V; +3.3V: 3.7 ~ 4.5V; +12V: 12.6 ~ 15.6V
Output power over 120%
MTBF
EMI & Safety Approval
Temperature/Humidity
130,000 hrs
UL, TUV
Operating: 0 ~ 40oC, 20 ~ 90%RH
Storage: -20 ~ 60oC, 5 ~ 95%RH
128 x 81 x 40 mm; 5.0” x 3.2” x 1.55”
Dimension (WxDxH)
149
Industrial Power Supply
60W ATX, open-frame power supply
DC OUTPUT
+5V
+3.3V
+12V
-12V
+5Vsb
Max. Load
8A
6A
3A
0.5A
0.75A
Min. Load
1A
0A
0A
0A
0A
Load Reg.
±2%
±4%
±4%
±5%
±4%
Line Reg.
±1%
±1%
±1%
±1%
±1%
Ripple
50mv
50mv
120mv
120mv
120mv
Noise
±1%
±1%
±1%
±2%
±1%
Industrial Power Adapter
APH-3019
40W DC-Plug with Screw Power Adapter
FEATURES
(I¿FLHQF\0HHW&(&&DOLIRUQLD
Energy Commission)
„ Low Ripple& Noise
„ Short Circuit Protection
„ Over Current Protection 5A(Max.)
„ Over Voltage Protection 18Vdc
Max. (Upper Trip limit)
„ No Load Power Consumption ”
0.3W
„ DC plug with screw for securing
„
APH-3020
FEATURES
(I¿FLHQF\0HHW&(&&DOLIRUQLD
Energy Commission)
„ Low Ripple& Noise
„ Short Circuit Protection
„ Over Current Protection 7.3A(Max.)
„ Over Voltage Protection 18Vdc
Max. (Upper Trip limit)
„ No Load Power Consumption ”
0.5W
„ DC plug with screw for securing
12V
Output Load
Output Regulation
(I¿FLHQF\
MTBF
EMI & Safety Approval
Dimension
3.33A
11.4V~12.6V
>83.1%, [email protected], [email protected]
100,000 [email protected]°C
UL, cUL, TUV, CE, FCC, CB
110(w) x 50(d) x 32(h) mm
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
Output Regulation
(I¿FLHQF\
MTBF
EMI & Safety Approval
Dimension
5A
11.4V~12.6V
>87%, [email protected], [email protected]
60,000 [email protected]°C
UL, cUL, TUV, CE, FCC, CB
110(w) x 62(d) x 32(h) mm
96W DC-Plug with Screw Power Adapter
FEATURES
(I¿FLHQF\0HHW&(&&DOLIRUQLD
Energy Commission)
„ Low Ripple& Noise
„ Short Circuit Protection
„ Over Current Protection, Shutdown
and no damage
„ Over Voltage Protection 18Vdc
Max. (Upper Trip limit)
„ Over Temperature Protection (No
¿UHQRVPRNH
„ No Load Power Consumption ”
0.75W
„ DC plug with screw for securing
„
APH-3028
90V ~ 264V
DC Output Voltage
60W DC-Plug with Screw Power Adapter
„
APH-3023
SPECIFICATION
AC Input Voltage
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
Output Regulation
(I¿FLHQF\
MTBF
EMI & Safety Approval
Dimension
8A
11.4V~12.6V
>81%, [email protected], [email protected]
100,000 [email protected]°C
UL, cUL, TUV, CE, FCC, CB
174(w) x 65(d) x 37(h) mm
150W DC-Plug Power Adapter
FEATURES
(I¿FLHQF\0HHW&(&&DOLIRUQLD
Energy Commission)
„ Low Ripple& Noise
„ Short Circuit Protection
„ Over Current Protection, Shutdown
and no damage
„ Over Voltage Protection 17Vdc
Max. (Upper Trip limit)
„ Over Temperature Protection (No
¿UHQRVPRNH
„ No Load Power Consumption ”
0.5W
„ DIN plug connector for power DIN
plug (with lock)
„
SPECIFICATION
AC Input Voltage
90V ~ 264V
DC Output Voltage
12V
Output Load
Output Regulation
(I¿FLHQF\
MTBF
EMI & Safety Approval
Dimension
12.5A
11.4V~12.6V
>86%, [email protected], [email protected]
43,800 [email protected]°C
UL, cUL, TUV, CE, FCC, CB
171(w) x 72(d) x 40(h) mm
Industrial Power Supply
150
Configuration Matrix
RPC-500NC
/MX/L
AREMO4196/MX
AREMO3194
ATX M/B
V
V
V
Micro ATX
V
V
V
SBC PICMG 1.0
V
V
SBC PICMG 1.3
V
V
PBP-13D4
V
V
PBP-13R4
V
V
PBP-14P4
V
V
PBP-14AC-B
V
V
PBP-14A7
V
V
PBP-14AC
V
V
PBPE-13A8
V
V
PBPE-12A9
V
V
PBPE-12AA64
V
V
PBPE-14AD64
V
V
Model
AREMO2173PA
AREMO2173-MX
AREMO6163
AREMO8164
AREMO4184
AREMO6182
V
V
V
V
V
V
V
PBP-06V4
V
PBP-06V464
V
PBPE-06V
V
PBPE-06V3
V
PBPE-06V464
V
PBP-06P3
V
V
V
PBP-06P4
V
V
V
ORION-A1501
V
V
ORION-A2501
V
V
PBP-08A7
V
PBP-08P3
V
PBP-08P4
V
V
ORION-B3501P
151
AREMO2173P
ORION-D3501P
V
V
V
V
V
V
V
ORION-D4601P
V
V
V
V
V
V
V
ORION-D5501P
V
V
V
V
V
V
V
Industrial Power Supply
Accessory
Embedded System Integration Service
In order to help improve our customer's product time to market, Portwell provides the following services for the
Embedded Computing Platform.
These services are provided for both board support and system integration, and are available to our valued
customers who work with our world-class ecosystem and alliance program for embedded computing.
The three main services include:
1. Panel Kit service
7KLVVHUYLFHIRFXVHVRQWKH,QWHUDFWLYH&OLHQWVHJPHQWGH¿QHGE\,QWHO,3'DVXVHUVRIGLVSOD\RULHQWHGDSSOLFDWLRQVVXFKDV326$70.,26.
0HGLFDO*DPLQJ(SD\PHQWDQGLVVXSSOHPHQWHGE\WKH3RUWZHOO$OOLDQFHVZLWKD¿UVWWLHU/&'PDNHULQ7DLZDQWRSURYLGHWKUHH\HDU
longevity support, panel kit for most of Portwell embedded system boards, with customized video BIOS, and Intel Embedded Graphic Driver
(IEGD) by customer request.
2. Embedded OS board support package
Portwell joins the Microsoft Windows Embedded Partner (WEP) program and works with chipset and device silicon venders to provide customers
with this board support package (BSP). Customers can now focus their application software to shorten the system developing cycle and still
maintain a lower total cost of ownership (TCO).
3. Peripherals integration and system level thermal solution
Portwell can provide consulting service and deliverable solution for peripherals integration upon customer’s request. Our customer service
engineering team can even be your window to leverage the IT infrastructure of the greater China area.
EZCool
A reliable thermal solution of processor is always highly appreciated for most
applications. The reliable solution is not only about whether the processor
RYHULWVWKHUPDOVSHFL¿FDWLRQRUNHHSLWVWHPSHUDWXUHXQGHUSURWHFWLRQSRLQWEXW
also noise and weight related. EZCool is the reliable thermal solution for Intel®
CoreTM 2 Duo processor, Pentium® 4 651 and Celeron® D 352 and so on that
Thermal Design Power (TDP) does not over 65W because of it’s compact size,
VLOHQWFRROLQJIDQDQG¿[LQJPHFKDQLVP
FEATURES
Compact Size
Bending Prevention
EZCool is just one of third height of boxed cooler that
EHQH¿WVDSSOLFDWLRQVWKDWQHHGORZSUR¿OHFRROHU
Larger preload of cooler causes the
main board bending and it could
introduce permanent damage to the
PCB (Print Circuit Board) and traces
on it. With back plate conjunction,
EZCooler makes no defection of board.
SPECIFICATION
Socket Type
Socket LGA 775
(CoreTM 2 Duo, Celeron® 440)
Heat Sink
Dimension
Fan Dimension
Heat Sink Material
Fan Speed
Fan Air Pressure
Fan Life Expectancy
Bearing Type
Voltage Rating
Input Current
Noise Level
90 x 90 x 18mm (L x W x H)
Connector
3 pin
Heat Sink
Weight
Fan Weight
136.4 g (included fasteners)
Thermal Interface Material
SC102
55.5x11.3 mm (compatible with 80mm fan)
$OXPLQXPH[WUXVLRQEDVHDQG¿QV
61mm
20.24mm
5.76 CFM(At zero pressure and 25oC, rated speed)
9.11 mmH2O (At zero static pressure and 25oC,
rated speed)
40,000 hours at 45oC
Ball Bearing
12 VDC
0.3 A Max.(At 25oC, in free air rated voltage)
39.3 dBA
Twist Avoidance
Semi-symmetric Design
0DLQERDUG¿[HGYHUWLFDOO\LQFKDVVLVLQVWHDGRI
horizontally such as PICMG 1.X SBC/SHB can be
twisted because of the weight of cooler. It damages
SBC/SHB badly once the platform vibrates or shakes in
the same direction.
The semi-symmetric heat sink design alORZVDLUÀRZWKUXGXDOGLUHFWLRQVWKDWFDQ
help ventilation of other key components
QHDUE\DQGIXOO\OHYHUDJHV\VWHPDLUÀRZ
that draw from outside of the chassis.
13.6 g
Accessory
152
Further Contact
Completed Technical Service-In order to ensure that customers can get the right and speedy service
from Portwell, we do offer the following services to meet your needs.
Logistics Service
It is not only for the scalable or worldgrade customers, we offer the service to
our partners who need the world-wide
delivery to save time and expense.
Consulting Service
Our engineering experts provide a free
service to discuss with you the projects or
technologies that you need in a short period of time. Please visit Portwell web and
click the button, then the on-line service
will appear for you.
Product Service
We have the experienced product managers who can help you
to get the right products in our
list and also the related information to complete your solution.
Design Service
If our existing products cannot meet
your requirements, a customized design
service can be initiated to build the exact
products that you demand.
Manufacturing Service
Portwell has the most advanced manufacturing
facilities to produce the quality product for your
application or business. Please pay a visit to our
Portwell engine, you will know how best that we
can do for you.
153
Further Contact
Both Portwell RDC & SIC are set for the completed service to our customers & Partners. Your any requirements or
technical issues are welcome to contact us for further solution. Our service can be arranged in the following ways.
Web Service
Portwell already set up the contact for our technology
service on the air. Please just visit our web on the internet and left the message for further contact by our
people. Besides, you also can get the on-line consulting service via Skype or the phone if the immediate service is needed.
Extended Visits to PE
Some idea or issue is not easy to have the solution
within short period of time. Portwell has the necessary
facility and dormitory for customers or partners who
need to stay with us for a period of time. Please contact
us and our service people will give you the message
for it.
Direct Contact
Portwell welcomes our customers to visit our Laboratory for the regulation test or design service. We believe that it is the fastest way to solve your questions
and achieve the right solution. Just call or mail us; you
will have the right service immediately.
Live Chat (Skype)
Global
Gl
b l Service
S
i (Telephone)
E-Mail
Live Message
Messag
You can get the on-line consulting service via
Skype if an immediate response is needed.
http://www.portwell.com.tw/support/LiveChat.php
Portwell’s technical support department can be
reached by e-mail as follows
[email protected]
In addition, you can get immediate
support via telephone. Check the web site for
phone numbers.
http://www.portwell.com.tw/contact/worldwide.html
If you prefer to a question into a web form and
receive a reply by e-mail, please visit:
http://wms.portwell.com.tw/chat/livehelp.
php?department=2
Further Contact
154
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
