HP iPAQ
User’s Guide
F8T064ukHP
Bluetooth™ Hands-Free Headset
Contents
Introduction .............................................................................................................................................. 1
Headset Features ..................................................................................................................................... 3
Charging the Headset .............................................................................................................................. 4
Wearing the Headset................................................................................................................................ 6
Switching the Headset On/Off ................................................................................................................. 9
Pairing the Headset................................................................................................................................ 10
Using the Headset ................................................................................................................................. 12
Accepting a Call ..................................................................................................................................... 12
Ending a Call .......................................................................................................................................... 12
Rejecting a Call ..................................................................................................................................... 13
Making a Call ......................................................................................................................................... 13
Redialing the Last Number .................................................................................................................... 15
Volume Control ..................................................................................................................................... 15
Transferring a Call between the Headset and a Mobile Phone ............................................................. 15
Mute Function ........................................................................................................................................ 16
Headset LED Indicator .......................................................................................................................... 16
Charging Base Indicator ....................................................................................................................... 17
Audio Tones ......................................................................................................................................... 17
Specifications ....................................................................................................................................... 18
Information ............................................................................................................................................. 19
Introduction
Congratulations on your purchase of the HP iPAQ Bluetooth Hands-Free Headset (the Headset).
The Headset is quite light, weighing just about .35 ounces (10g). It has both Headset and
Hands-Free profiles for more functions, and is compatible with more Bluetooth wireless technology
mobile phones. Read this User’s Guide carefully before you start using the HP iPAQ Bluetooth
Hands-Free Headset.
Package Contents
In this package, you will find:
HP iPAQ Bluetooth Hands-Free Headset
Adjustable earhook
Retractable USB charging cable and car charger
Ear cushions
Charging base
User’s guide
1
Bluetooth Wireless Technology
Bluetooth wireless technology has revolutionized the personal connectivity market by providing
seamless freedom from wired connections. It offers a small form-factor, low-cost radio solution
providing links between mobile computers, mobile phones, and other portable and handheld
devices, and connectivity to the Internet. The Bluetooth Special Interest Group (SIG), comprised of
leaders in the telecommunications, computing, and network industries, is driving development of
the technology and bringing it to market. The Bluetooth SIG includes promoter companies 3Com®,
Ericsson®, IBM®, Intel®, Lucent®, Microsoft®, Motorola®, Nokia®, and Toshiba®, and more than 2,000
adopter companies.
2
Headset Features
3
1.
Talk Button: Switches the Headset on/off, answers/ends a call, pairs the Headset with a device,
and is used for voice dialing.
2.
Volume Up Button: Increases the speaker volume.
3.
Volume Down Button: Decreases the speaker volume.
4.
LED Indicator: Displays the status of the Headset.
5.
Microphone: Picks up external audio.
6.
Earpiece: Holds the Headset in the ear.
7.
Speaker: Plays incoming audio.
8.
Charging Port: Charges the battery.
Charging the Headset
The Headset has a rechargeable battery. Before using the Headset for the first time, you have to
charge the Headset battery for approximately two hours in order to get a full charge. A fully charged
battery provides up to seven hours of talk time and over one week of standby time. When the battery
is low, the LED indicator flashes red. The low-battery-warning indication will begin three minutes of
talk time before the Headset runs out of power. You can recharge the Headset at any time without
waiting for the battery to be completely discharged. To keep the battery in good condition, always
recharge the Headset within a month once it is fully discharged. Before charging, make sure that the
Headset is at room temperature. The battery will not charge in very cold or very hot conditions.
NOTE: The Headset battery is not replaceable.
4
To charge the Headset:
1.
Connect the retractable USB cable into the car charger or
any USB computer, and then plug the other end to the
charging base.
2.
Place the Headset into the charging base.
3.
During charging, the red indicator light on the charging
base illuminates.
4.
When the battery is fully charged, the indicator light on the
charger turns green.
5.
You can now remove the Headset from the charging base.
During charging, if an incoming call arrives while the Headset
is switched on, you can answer the call simply by removing the
Headset from the charging base.
5
Wearing the Headset
The Headset can be worn either on the right or left ear. The earpiece is adjustable, and the
90-degree, rotatable design ensures a snug yet comfortable fit in your ear.
To put on the Headset, please follow the instructions as below:
1.
Directly put the earpiece into
your outer ear canal.
2.
Adjust the Headset to fit your ear.
3.
The microphone should be
positioned toward your mouth.
The ear cushion supplied with
the Headset provides additional
comfort and a better fit.
6
To attach the ear cushion:
7
1.
Hold the Headset firmly.
2.
Cover the earpiece with the ear cushion.
3.
The ear cushion is attached to the ready-to-wear Headset.
Putting on the Headset
1.
Put on the Headset with the earhook behind your ear.
2.
Make sure the microphone is pointing toward your mouth.
(right)
(left)
8
Switching the Headset On/Off
To switch the headset on:
1.
Press the “Talk” button for about five seconds until you hear a low tone
followed by a high tone. The LED indicator flashes blue four times.
2.
The Headset switches on and enters standby mode. The LED indicator continuously flashes blue
every three seconds.
To switch the headset off:
9
1.
Press the “Talk” button for about one second until you hear a high tone followed by a low tone.
The LED Indicator flashes red four times.
2.
The Headset switches off and the LED indicator no longer blinks.
Pairing the Headset
Before using the Headset, you must first pair it with a Bluetooth wireless-technology-enabled device,
such as a Bluetooth mobile phone. Pairing is necessary for two Bluetooth devices to connect to each
other wirelessly. After creating a paired link, you do not need to repeat the pairing process and the
Headset automatically links to the mobile phone when both devices are switched on. Paring must be
performed every time you want to use the Headset with a different Bluetooth mobile phone or other
Bluetooth wireless-technology-enabled devices. The Headset can be paired simultaneously with up
to eight mobile phones.
10
To initiate pairing between the Headset and a Bluetooth mobile phone in close proximity:
11
1.
Turn off the Headset.
2.
Make certain the mobile phone is switched on.
3.
Press the “Talk” button to switch on the Headset and keep the “Talk” button pressed for seven
seconds until the LED indicator alternates between blue and red. The Headset is now ready for
pairing with the mobile phone.
4.
Perform a device discovery from the mobile phone. (For details on device discovery, please
consult your phone’s user’s guide.)
5.
Once the mobile phone discovers the Headset, the text “HP Headset” appears on the
phone’s screen.
6.
Follow the phone instructions to accept pairing. When prompted to enter the passkey, enter the
number: 0000.
7.
If time runs out after 60 seconds and the pairing fails, you will have to repeat the steps above.
You can view the status from the phone’s screen.
8.
On completing pairing, the phone’s screen will notify you that the pairing was successful. The
LED indicator continuously flashes blue and the Headset goes into standby mode.
9.
You can now make and answer calls through the Headset.
Using the Headset
Before using the Headset, make sure that (1) the Headset is switched on and connected to a paired
Bluetooth mobile phone; (2) the Headset is within 33 feet (10m) of the phone; and (3) the phone’s
Bluetooth feature is on (see your phone’s user’s guide).
NOTE: The Headset supports both Headset and Hands-Free profiles. Some mobile phones do not
support all the functions listed below. Please consult your phone’s user’s guide.
Accepting a Call
When receiving an incoming call, the Headset rings and the LED indicator flashes blue at a
three-second interval. To receive the call from the Headset, press the “Talk” button once. You can
also answer the call by using your phone in the normal way. Please note that if the mobile phone
rings first, wait until you hear a ring tone from the Headset and then press the “Talk” button to
answer the call.
Ending a Call
To end a call, press the “Talk” button once on the Headset or press the phone’s “END” key. The
Headset returns to standby mode.
12
Rejecting a Call
When a call comes and you do not want to answer it, you can press the “Talk” button for two
seconds to reject the call.
Making a Call
You can make a call through:
A. Voice activation
To use voice activation, the mobile phone must support voice dialing. For details on voice dialing,
please see your phone’s user’s guide.
13
1.
Press the “Talk” button once on your Headset.
2.
After a short tone sounds, speak the name of the person to whom you wish to connect
(if he or she has a voice tag in your phone).
3.
The phone automatically dials the number. You can see the details of the call from the
phone’s screen.
B. Dialing a phone number from your mobile phone
1.
Dial the phone number from the mobile phone’s keypad.
2.
Press the “Talk” button to send the call from your phone.
3.
The call automatically transfers to the Headset.
14
Redialing the Last Number
To redial the last phone number, press and hold down the “Volume Down” button for three seconds.
Volume Control
During a call, you can adjust the Headset speaker volume. An audio tone is played for each
volume up and volume down step.
To increase the volume, press the “Volume Up” button repeatedly until you reach the
desired level.
To decrease the volume, press the “Volume Down” button repeatedly until you reach the
desired level.
Transferring a Call between the Headset and a Mobile Phone
To transfer a call from the Headset to a mobile phone, initiate it from the mobile phone.
(Refer to your phone’s user’s guide.)
To transfer a call from a mobile phone to the Headset, simply press the “Volume Up” button
once, even if the Headset is then switched on after a call has been initiated.
15
Mute Function
To mute the Headset sound during a call, press the “Volume Up” button and the “Volume Down”
button for two seconds; you will hear one tone repeated every 20 seconds. Upon activating the mute
function, the person on the other side won’t hear you, but you can hear all sound generated from
the other side. To turn off the mute function, press the “Volume Up” button or the “Volume Down”
button once.
Headset LED Indicator
Status
Blue LED
Turning on
4 times
Turning off
Pairing mode
Red LED
Interval
Remarks
4 times
Flashes blue and red alternatively until the pairing is complete or times out.
Standby mode
3 times
Incoming call
3 times
Talk mode
4 times
3 times
3 seconds
Flashes red when low battery
3 seconds
4 times
3 seconds
Flashes red when low battery
16
Charging-Base Indicator
Status
Red LED
Charging in process
On
Green LED
Charging complete
On
Audio Tones
Switching on
Quick series of 2 tones,
low to high
Switching off
Quick series of 2 tones,
high to low
Pairing mode
1 tones
Incoming call
A ring tone at a 2-second
interval
Mute
1 tone repeated every 20 seconds
Turn off mute
Single tone
Low battery
5 rapid tones every 20 seconds in standby mode
NOTE: When using Nokia mobile phones, all sounds generated by the mobile phone automatically
transfer to the Headset. When a call comes in, the Headset uses the same ring tone as the mobile
phone. If the mobile phone is set to vibration mode, you won’t hear a ring tone from the Headset.
17
Specifications
Standard
Compliant with Bluetooth specification v1.1 / v1.2
Chipset
BlueCore2-Audio single chipset
Profiles Supported
Bluetooth Headset & Hands-free profiles
Radio Frequency
2402 MHz ~2480 MHz
Transmitter Power
Class 2 (max 4dBm)
Transmission Range
Up to 10 meters
Receiver Sensitivity
-78 dBm
Charger Power Supply
5VDC / 200 mA
Temperature
Operating: -20º C–60º C; Storage: -20º C–60º C; Charging: 0º C–45º C
Operation Voltage
3.7V
Rechargeable Battery
120mAh lithium polymer battery
Charging Time
1.5–2 hours
Talk Time
HV1: Over 4 hours; HV3: Over 7 hours
Standby Time
More than 1 week
Dimension
2.4 (L) x 0.7 (W) x 0.4 in. (H) (60 x 18 x 11mm)
Weight
0.37 oz. (10.6g) (not including charging base)
18
Information
Users are advised not to make changes or modify the device in any way. Changes or modifications
not expressly approved by HP will void the warranty.
FCC Notices
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.
FCC RF Exposure requirements: This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
CE Statement
Important Notice: This device is a 2.4GHz FHSS Bluetooth headset, intended for office and home
uses in all EU and EFTA member states.
19
Belkin Corporation Limited 2-Year Product Warranty
What this warranty covers.
Belkin Corporation warrants to the original purchaser of this Belkin product that the product shall be
free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin Corporation warrants the Belkin product for two years.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except for shipping
charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to Belkin Corporation
for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin Corporation
determines that the Belkin product has been improperly installed, altered in any way, or tampered
with. The Belkin Product Warranty does not protect against acts of God (other than lightning) such as
flood, earthquake, war, vandalism, theft, normal-use wear and tear, erosion, depletion, obsolescence,
abuse, damage due to low voltage disturbances (i.e. brownouts or sags), non-authorized program, or
system equipment modification or alteration.
20
How to get service.
To get service for your Belkin product you must take the following steps:
1.
Contact Belkin Ltd., Express Business Park, Shipton Way, Rushden, NN10 6GL, United
Kingdom, Attn: Customer Service, or call 00 800 2 2355460, within 15 days of the Occurrence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2.
Your Belkin Customer Service Representative will then instruct you on how to forward your
receipt and Belkin product and how to proceed with your claim.
Belkin Corporation reserves the right to review the damaged Belkin product. All costs of shipping the
Belkin product to Belkin Corporation for inspection shall be borne solely by the purchaser. If Belkin
determines, in its sole discretion, that it is impractical to ship the damaged equipment to Belkin
Corporation, Belkin may designate, in its sole discretion, an equipment repair facility to inspect and
estimate the cost to repair such equipment. The cost, if any, of shipping the equipment to and from
such repair facility and of such estimate shall be borne solely by the purchaser. Damaged equipment
must remain available for inspection until the claim is finalized. Whenever claims are settled, Belkin
Corporation reserves the right to be subrogated under any existing insurance policies the purchaser
may have.
21
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN CORPORATION, THERE ARE NO
OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED, INCLUDING
THE IMPLIED WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN DURATION
TO THE TERM OF THIS WARRANTY.
IN NO EVENT SHALL BELKIN CORPORATION BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT,
INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST
BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY BELKIN PRODUCT, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
22
© 2006 HP Corporation. All rights reserved.
The product is marketed and supported by Belkin
Corporation. For warranty support or technical
support, go to www.belkin.com or call Belkin
at 00 800 2 2355460. The Bluetooth name
and the Bluetooth trademarks are owned by
Bluetooth SIG, Inc., and are used by Belkin
Corporation under license.
P75049uk-A
Download PDF

advertising
