HP | LC3040N | User's Manual | HP LC3040N User's Manual

HP LC3040N 30" HD Ready LCD TV
HP LC2640N 26" HD Ready LCD TV
User’s Guide
The information in this document is subject to change without notice.
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
HP shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT
EXCLUDE, RESTRICT OR MODIFY AND ARE IN ADDITION TO ANY MANDATORY STATUTORY RIGHTS APPLICABLE TO THE
SALE OF THIS PRODUCT OR SERVICE TO YOU.
HP assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HP.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated to another language without the prior written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
© 2004 Hewlett-Packard Development Company, L.P.
All rights reserved.
HP supports lawful use of technology and does not endorse or encourage the use of our products for purposes other than those
permitted by copyright law.
WOW, SRS and the
from SRS Labs, Inc.
symbol are trademarks of SRS Labs, Inc. SRS WOW technology is incorporated under license
BBE Viva 3D License Manufactured under license from BBE Sound, Inc. Patent Licensed by BBE Sound, Inc. under
USP4638258, 5510752, and 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc.
“DCDi® by Faroudja" is a registered trademark of Genesis Microchip Inc.
WARNING: Text set off in this manner indicates that failure to follow directions could
result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could
result in damage to equipment or loss of information.
NOTE: Text set off in this manner indicates additional information.
DANGEROUS VOLTAGE: Text set off in this manner indicates the presence of
uninsulated voltages within the product enclosure that may be of sufficient magnitude
to constitute a risk of electrical shock to persons.
Table of Contents
Safety ..................................................................................................................... 1
Precautions...........................................................................................................................................2
Cleaning the TV ....................................................................................................................................4
Wall Mounting or Stand Replacement .....................................................................................................4
Introduction ............................................................................................................ 5
What’s in the Box .................................................................................................................................6
Power Cord..........................................................................................................................................6
Battery for the Remote Control ................................................................................................................7
Setup ...................................................................................................................... 8
Rear Connectors ...................................................................................................................................8
Identifying Your Components Cables....................................................................................................8
Connecting a Composite Component ...................................................................................................9
Connecting a S-video Component........................................................................................................9
Connecting a YPbPr Component ..........................................................................................................9
Connecting a PC with a DVI Cable ......................................................................................................9
Connecting a PC with a VGA Cable ....................................................................................................9
Connecting a Subwoofer ..................................................................................................................10
Connecting Headphones ..................................................................................................................10
Connecting an Antenna/Cable box/Satellite Dish ...............................................................................10
Power Connection ...............................................................................................................................10
Antenna Connection ............................................................................................................................11
Outdoor Antenna Connection............................................................................................................11
VESA Wall Mounting .......................................................................................................................12
Removing the Stand .........................................................................................................................12
Attaching the Speakers .....................................................................................................................13
Control Options ...............................................................................................................................14
Power Management System (For PC Mode Only).................................................................................14
Timing Mode...................................................................................................................................14
Table of Contents
iii
Using the TV ..........................................................................................................15
Basic Operation.................................................................................................................................. 15
Adjusting the Volume ....................................................................................................................... 15
Muting the Sound ............................................................................................................................ 15
Turning On and Off the LCD TV......................................................................................................... 15
First Time Setup for Channels ............................................................................................................ 15
Changing Channels ......................................................................................................................... 15
Exit Button....................................................................................................................................... 16
Adjusting the Language Settings ........................................................................................................ 16
Adjusting the Picture Mode Settings ................................................................................................... 16
Channel Editing............................................................................................................................... 16
Setting the TV Receiving Mode .......................................................................................................... 17
Selecting an Input Source ................................................................................................................. 17
Selecting a PIP Source ...................................................................................................................... 17
Selecting the PIP Size ....................................................................................................................... 17
POP Button...................................................................................................................................... 17
Setting Up V-chip ............................................................................................................................. 18
Using the Remote Control..................................................................................................................... 19
Programming the remote control for component control ........................................................................ 22
On Screen Display (OSD) Menu ........................................................................................................... 32
PC Mode ........................................................................................................................................... 32
PC Mode Operation ........................................................................................................................ 32
Image Page .................................................................................................................................... 33
Color Page ..................................................................................................................................... 33
OSD Page ...................................................................................................................................... 34
Audio Page..................................................................................................................................... 34
PIP/PAP Page.................................................................................................................................. 35
Factory Page ................................................................................................................................... 36
TV Mode............................................................................................................................................ 37
TV mode operation .......................................................................................................................... 37
System Page ................................................................................................................................... 38
Image Page .................................................................................................................................... 39
OSD Page ...................................................................................................................................... 39
Audio Page..................................................................................................................................... 39
PIP/PAP Page.................................................................................................................................. 39
Factory Page ................................................................................................................................... 40
iv
Table of Contents
AV/SV Mode .....................................................................................................................................41
AV/SV Operation ............................................................................................................................41
Factory Page ...................................................................................................................................41
YPbPr Mode .......................................................................................................................................42
YPbPr Operation..............................................................................................................................42
Factory Page ...................................................................................................................................42
Troubleshooting .................................................................................................... 43
Specifications (United States) ................................................................................. 45
Agency Regulatory Notice ..................................................................................... 50
Federal Communications Commission Notice .........................................................................................50
Modifications......................................................................................................................................50
Cables ...............................................................................................................................................50
Declaration of Conformity for products marked with the FCC logo — United States only .............................51
Index .................................................................................................................... 52
Table of Contents
v
vi
Table of Contents
Safety
First:
• Read all instructions before installing and operating the TV.
• Keep this user guide in a safe place for future reference.
• To reduce the risk of bodily injury, electric shock, fire, and damage to the TV, observe all warnings
•
•
and precautions in this user guide.
Follow all instructions in this user guide.
Do not use attachments that are not recommended by HP with this product. Use of inadequate
attachments may result in damage to the product or personal injury.
Opening the package:
• Due to the size and weight of the TV, it is recommended that a minimum of two people move it.
• If speakers are attached to the TV, do not lift the TV by the speakers; instead, use the handles and
the area under the screen.
• The protective glass and the glass substrate are installed on the front of the TV. Because both
•
glasses can be broken and scraped easily, move the product gently. Never place the TV with the
glass facing downward, unless it is protected with pads.
The TV is packaged in a carton with other standard accessories. When opening the carton, check
that the TV is in good condition and that all standard accessories and items are included. Any
optional accessories come separately in another carton.
Installing the TV:
• A specified technician from the distributor or authorized agent should install the TV. Refer to “Wall
•
•
•
•
•
•
•
•
Mounting or Stand Replacement” on page 4 for more information.
Install the TV on a flat surface to avoid tipping. Leave some distance between the back of the TV
and the wall for proper ventilation. Never install the unit where the ventilation on the top of the TV
is covered. Otherwise, fire or damage to the unit may occur.
Avoid installing the TV in the kitchen, the bathroom, or any other area with high humidity. Damp
conditions may shorten the service life of the electronic components, or may cause fire or electrical
shock.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-type plug has two blades and a third grounding
prong. The wide blade, or the third prong, is provided for your safety. If the provided plug does not
fit your outlet, consult an electrician for replacement of the obsolete outlet.
Route power and signal cords appropriately to avoid stepping or tripping on them.
Do not install this TV outdoors; rain or extended direct sunlight may damage the unit.
Do not install the TV in a vehicle; vibrations may damage the unit, or the unit may fall and cause
injury.
Do not install the TV in a ship or a vessel; seawater damages the unit and may start a fire.
Do not use this TV near water.
Safety
1
• Install the TV horizontally; any 90-degree clockwise or counterclockwise installation may induce
•
•
•
•
•
•
•
•
poor ventilation and subsequent component damage. Do not hang the TV from the ceiling; the unit
may fall and cause injury.
Do not install near appliances, such as a microwave.
Do not install near a heat source, such as a fireplace or radiator.
Do not place the TV on an unstable cart or stand; the unit may fall over and cause injury.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the TV. When a cart is used, use caution when moving the cart/TV combination to avoid injury
from tip-over.
Do not install the TV where it has a protruding edge. For example, do not place the TV where an
edge overhangs a table. Do not install the product on a column, where it may accidentally fall.
If moving the TV from a cold place to a warm place, condensation may occur inside the unit. Allow
the condensation to dry before turning on the unit.
Unplug the TV during lightning storms or when unused for long periods of time.
Clean only with a soft dry cloth.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Precautions
DANGEROUS VOLTAGE: Do not attempt to repair your television yourself. Removing
the back cover of the TV may cause fire or electric shock. An HP authorized service
provider should do service needed on components inside the TV.
If the following conditions exist, unplug the TV from the electrical outlet and contact a qualified service
professional:
•
•
•
•
•
•
•
When
When
When
When
When
When
When
the power cord or plug is damaged.
liquid was spilled on the product or when objects have fallen into the product.
the product does not operate as described in the instructions.
the product has been damaged or dropped.
the product displays an abnormal condition.
the product was exposed to rain or water.
the product shows signs of overheating.
CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electrical shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Avoid hot areas: The TV should be placed away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers).
Avoid wet areas: Never use the TV in a wet location.
2
Safety
Avoid pushing objects into the product: Never push objects of any kind into cabinet slots or
other openings in the TV. Slots and openings are provided for ventilation. These openings must not be
blocked or covered.
Using mounting accessories: Any mounting of the TV should follow the manufacturer’s
instructions and should use the mounting accessory recommended by the manufacturer.
Adjust the volume: Turn down the volume before using headphones or other audio devices.
Use the correct external power source: The product should be operated only from the type of
power source indicated on the electrical ratings label. If you are not sure of the type of power source
required, consult your HP authorized service provider or local power company.
Position the power cord carefully: Route the power cord so that it will not be walked on,
tripped over, or pinched by items placed upon or against it. Pay particular attention to the plug,
electrical outlet and the point where the power cord exits the product.
Overloading: Do not overload an electrical outlet, power strip, or convenience receptacle. The
overall system load must not exceed 80% of the power strip input rating.
Observe extension cord ratings: If an extension cord or power strip is used, make sure that the
cord or strip is rated for the product and that the total ampere ratings of all products plugged into the
extension cord or power strip do not exceed 80% of the extension cord or strip ampere ratings limit.
Using cables and power cords:
•
•
•
•
•
•
Plug the product into a grounded (earthed) electrical outlet that is easily accessible at all times.
Do not disable the power cord grounding plug. The ground plug is an important safety feature.
Disconnect power from the TV by unplugging the power cord from the electrical outlet.
Do not pull on cords and cables. When unplugging the cord from an electrical outlet, grasp and
pull the cord by the plug.
Do not attempt to power the TV with converter kits sold for appliances.
Unplug the TV from the electrical outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners.
WARNING: Do not place any objects on top of the TV. Spilled water or metal objects
may cause short circuit, fire, or electric shock if they penetrate into the housing of
the TV.
Never use a damaged power cord. Do not place power cords in areas where they can
be pinched, stepped on, or otherwise compromised. Heavy objects, heat, chemicals,
or tensile force may damage the power cord and cause fire or electric shock.
Do not change or open the back cover. Removing the back cover of the TV may cause
fire or electric shock. Contact the manufacturer when inspection or adjustment is
required.
Do not use the TV if any abnormality occurs. If any smoke or odor becomes apparent,
unplug the power cord and contact the manufacturer immediately.
Do not try to repair the TV on your own.
Safety
3
Cleaning the TV
Use a dry, soft cloth to remove dust from the TV screen and the chassis.
• Unplug the TV before cleaning the screen.
• A special anti-glare coating is applied to the screen of your TV. Using solvents such as alcohol or
•
•
abrasive material such as a power towel may affect the screen coating or bezel paint.
Do not expose the product to volatile gas or fluid such as a pesticide.
Do not put the TV in contact with vinyl or rubber products for a long period of time. Extended
contact may result in the removal of the coating or degradation of the surface.
Wall Mounting or Stand Replacement
A specified technician from the distributor or authorized agent should install the TV, including stand
replacement or wall mounting. Wall mounting brackets are sold separately and are not included with
the TV.
Wall mounting the TV requires:
•
•
•
•
Removal of the transport handles on the back of the TV.
Removal of the stand from the TV panel.
Assembly of the wall mounting bracket and installation of the bracket onto the TV panel.
Placement and installation of the TV panel with wall bracket onto the wall.
Due to the size and weight of the TV, it is recommended that a minimum of two people move it.
4
Safety
Introduction
• Faroudja’s Emmy-Award winning DCDi video processing technology analyzes video
•
•
•
•
•
•
•
•
pixel-by-pixel to deliver a spectacular picture. The acclaimed DCDi algorithm detects low-angle
lines and smoothes out staircases and jagged edges — bringing a new tier of realism to sporting
events and movies.
TM
SRS WOW creates a bigger, enhanced sound experience by providing three dimensional
sound, enhancing musical vocals, and creating the perception of deep, rich bass.
BBE ViVA HD3D (High Definition 3D) Sound provides musically accurate natural 3D image
with Hi-Fi sound. The clarity of the sound is improved by BBE while the width, depth and height of
sound image are expanded by BBE’s proprietary 3D sound process.
FilmMode Processing with 3:2 & 2:2 pull down accurately reproduces film-originated
content from video sources.
Cross Color Suppressor removes cross color artifacts from composite video sources, delivering
consistent, true color every time.
Motion Adaptive Noise Reduction greatly enhances quality of standard definition and off air
media and standard definition video.
Fine Detail Enhancer identifies areas of fine detail in a picture, such as skin and hair, and
enhances them to a dramatically more life like appearance. Additionally, the TrueLife enhancer
identifies large edges that identify separation of objects, and enhances them to create a greater
perception of depth. The result is a stunningly realistic viewing experience.
Two-Tuner Picture-in-Picture and Split Screen viewing.
Universal Remote Control controls additional components, including HP Media Center PCs.
Introduction
5
What’s in the Box
The package contains:
•
•
•
•
•
•
•
•
•
LCD color TV with stand
Power cord
Speakers
Speaker cables
1.8 meter antenna cable
Remote control with batteries
User’s guide
Warranty card
Setup poster
Power Cord
• Check first to make sure that the power cord is the correct type required for your area.
• This TV has a universal power supply that allows operation in either 100/120V or
220/240V voltage. No user adjustment is required.
• Connect the power cord into your TV’s power input socket, and then plug the other end into a
grounded outlet.
Use a UL-listed cord set consisting of a min No. 18 AWG, Type SVT or SJT three-conductor a
maximum of 10 feet in length and a parallel blade, grounding type attachment plug rated
10A, 125V.
• For units to be used at 100/240V (inside U.S.):
Use a UL-listed cord set consisting of a min No. 18 AWG, Type SVT or SJT three-conductor cord
a maximum of 10 feet in length and a tandem blade, grounding type attachment plug rated
10A, 250V.
• For units to be used at 220/240V (outside of U.S.):
Use a cord set consisting of a min 0.75mm2, 3G, Type H05VV-F cord and grounding type
attachment plug rated 10–16A, 250V. The cord set should have the appropriate safety approvals
for the country/region in which the equipment will be installed and marked HAR.
6
Introduction
Battery for the Remote Control
When the batteries are low, the red light on the remote control blinks twice when a button is pushed.
Insert two AA non-rechargeable batteries into the remote control ensuring that you place them with the
proper polarity.
1 Press and open the cover on the back of the remote control.
2 Insert the batteries into the remote control ensuring that you place them with the proper polarity.
3 Close the cover.
CAUTION: Battery cautions
Use only the size and type of batteries specified.
Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
Do not mix different types of batteries together (for example, alkaline and carbonzinc) or old batteries with fresh ones.
When not using the remote for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
Do not try to recharge batteries that are not intended to be recharged; they can
overheat and rupture. (Follow the battery manufacturer’s directions for the batteries
you are using.)
Always remove batteries as soon as they become weak. Weak batteries can leak and
severely damage the unit.
Replace batteries yearly or when remote control operation becomes erratic.
Do not take apart the batteries, heat them, or throw them into a fire.
CAUTION: Remote control cautions
Do not expose the remote control to shock, such as from dropping or an electric
charge. In addition, do not expose the remote control to liquids, and do not place it in
an area with high humidity.
Do not install or place the remote control under direct sunlight. The heat may cause
deformation of the unit.
The remote control may not work properly if the remote sensor window of the main
unit is under direct sunlight or strong lighting. In such a case, change the angle of the
lighting or LCD TV set, or operate the remote control closer to the remote sensor
window.
Introduction
7
Setup
Rear Connectors
The rear connectors are located on the back of your display tucked under the back panel. Insert the
cables from your component into these rear connectors. The rear connectors you use depend on the
type of cables you are using with your component. Make sure you insert the audio cables into the
connectors that correspond with the video input.
The rear connectors are divided into three sections
• Audio Inputs
• Audio/AV Outputs
• Video Inputs
Identifying Your Components Cables
Where you connect your component into the TV connectors depends on the type of cables you use to
connect the component. Your TV is compatible with composite, component, S-video, DVI-D, or VGA
cables. Some components, such as some DVD Players have multiple output types (component, S-video
and composite). Use the following chart to determine your cable type:
Type of
Component
Description of Cable(s)
Where to Connect
Composite
One cable with three ends:
• Insert the yellow cable into the yellow
• One yellow for video
• One red for audio
• One white for audio
AV1 or AV2 video input.
• Insert the red and white cables into the
red and white AV1 or AV2 audio
inputs.
Some composite cables come with red
and white audio cables separate.
S-video
One cable with three ends:
• Insert the cable into the SV1 or SV2
• One cable with 4 pins
• One red for audio
• One white for audio
• Insert the red and white cables into the
Some S-video cables come with red and
white audio cables separate.
8
Setup
video input.
red and white SV1 or SV2 audio
inputs.
Type of
Component
Component
Description of Cable(s)
Where to Connect
One cable with three ends:
• Insert the red cable into the red
• One red for Pr signal
• One green for Y signal
• One blue for Pb signal
Some component cables come with red
and white audio cables attached.
YPbPr1 or YPbPr2 video input.
• Insert the green cable into the green
YPbPr1 or YPbPr2 video input.
• Insert the blue cable into the blue
YPbPr1 or YPbPr2 video input.
• Insert the red and white audio cables
into the red and white YPbPr1 or
YPbPr2 audio inputs.
DVI-D
One cable with 3 rows of 8 pins.
Insert the cable into the DVI video input.
DVI-D is analog only. Does not support
digital signal.
VGA
One cable with 3 rows of 5 pins.
Insert the cable into the VGA video
input.
Connecting a Composite Component
In the Audio Inputs section, insert the red and white audio cables into the AV1/SV1 connectors. In
the Video Inputs section, insert the yellow video cable into the top AV1/SV1 connector.
To add an additional composite component, use the AV2/SV2 connectors for audio and the top
AV2/SV2 connector for video.
Connecting a S-video Component
In the Audio Inputs section, insert the red and white audio cables into the AV1/SV1 connectors. In
the Video Inputs section, insert the S-video cable into the bottom AV1/SV1 connector.
To add an additional S-video component, use the AV2/SV2 connectors for audio and the bottom
AV2/SV2 connector for video.
Connecting a YPbPr Component
In the Audio Inputs section, insert the red and white audio cables into the YPbPr1 connectors. In the
Video Inputs section, insert the red, blue and green video cables into the top YPbPr1/YPbPr2
connectors.
To add an additional YPbPr component, use the YPbPr2 connector for audio and the bottom
YPbPr1/YPbPr2 connectors for video.
Connecting a PC with a DVI Cable
In the Audio Inputs section, insert the audio cables from your PC (color of cable tips vary) into the DVI
connector. In the Video Inputs section, insert the DVI cable into the DVI connector.
Connecting a PC with a VGA Cable
In the Audio Inputs section, insert the audio cable from your PC (color of cable tip varies) into the
VGA connector. In the Video Inputs section, insert the VGA cable into the VGA connector.
Setup
9
Connecting a Subwoofer
Insert speaker cable from your subwoofer into the Subwoofer connector.
Connecting Headphones
The headphone input is under the front of the display toward the left. Insert the headphone cable into
the green input.
Connecting an Antenna/Cable box/Satellite Dish
Twist the cable from your antenna/cable box/satellite dish on to the RF connector.
Power Connection
• Use the provided AC power cord to connect to the wall outlet.
• Always unplug the AC cord from the product and power outlet when not using for a long period
of time.
10
Setup
Antenna Connection
The antenna requirements for good color television reception are more important than those for blackand-white television reception. For this reason, a good-quality outdoor antenna is strongly
recommended.
The following is a brief explanation of the type of connections that are provided with the various
antenna systems.
• A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a
terminal without tools.
• A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm terminal through a
300-to-75-ohm adapter (not supplied).
Outdoor Antenna Connection
Connect the outdoor antenna cable lead-in to the RF connector on the rear of the TV set.
Setup
11
VESA Wall Mounting
Your LCD TV comes with a TV stand already attached. You must remove the stand attached to the
LCD TV before attaching any wall mounting equipment (not included). It is recommended that a
specified technician from the distributor or authorized agent mount the TV on a wall.
Removing the Stand
1 Place a soft cloth on a stable table.
2 Carefully place the TV face down on the cloth with the stand hanging over the edge of the table.
3 Remove the five screws attaching the stand to the main display. Be careful to not drop the stand.
12
Setup
Attaching the Speakers
Your LCD TV comes with speakers and speaker wire for you to connect to each side of the TV. Follow
these steps to attach the speakers:
1 Hook the speaker onto the LCD TV.
2 Insert and tighten the four screws to each clip.
3 Insert the speaker wires into the connectors on the speakers and back panel of the LCD TV.
Setup
13
Control Options
• Input Select, Exit, Vol ( + )/( – ), CH ( + )/( – ), and Menu on the main unit have the same functions
as the same buttons on the remote control. This manual describes the features through the remote
control keys.
Power Management System (For PC Mode Only)
The LCD TV has a power management function that automatically reduces power consumption in three
power-saving modes when not in use.
State
LED
Video
Power
On
Blue
TV on, video input active
185W (typical)
Standby
Red
TV on, but video not
present
< 5W
Off
Off
TV is off
< 5W
Timing Mode
14
Setup
Mode
Resolution
Horizontal Frequency (KHz)
Vertical (Hz)
1
VGA
720 x 400
31.47 kHz
70 Hz
2
VGA
640 x 480
31.47 kHz
70 Hz
3
VESA
640 x 480
31.47 kHz
60 Hz
4
VESA
640 x 480
37.50 kHz
75 Hz
5
VESA
800 x 600
37.88 kHz
60 Hz
6
VESA
800 x 600
46.88 kHz
75 Hz
7
VESA
1024 x 768
48.36 kHz
60 Hz
8
VESA
1024 x 768
60.02 kHz
75 Hz
9
VESA
1280 x 768
47.78 kHz
60 Hz
10
VESA
1280 x 768
68.28 kHz
75Hz
Using the TV
Basic Operation
Adjusting the Volume
Press the (+) or (–) VOL buttons on the remote control to increase or decrease the volume. The
indicator bar on the display shows the increase or decrease.
Muting the Sound
1 Press the MUTE button to temporarily turn off the sound.
2 Press the MUTE button again to restore the sound back to the previous level.
Turning On and Off the LCD TV
To turn on the display, press the PWR button on the remote control. The Power LED on the display
turns blue.
To turn off the display, press the PWR button on the remote control. The Power LED on the display
turns red.
First Time Setup for Channels
First select the TV receiving mode to Air or Cable. Use the Channel Search feature to set up your
channels. The Channel Search scans channels 1 to 125 and adds the channels that return a signal.
Use the following steps to run the Channel Search:
1 Press the ENTER button on the remote control to display the Menu screen.
2 Use the arrows to select the System Page and press the ENTER button.
3 Arrow down and press the ENTER button to enter the Channel Search feature.
4 Use the right arrow to select Yes and then press ENTER.
Changing Channels
Press the (+) or (–) CH buttons on the remote control to change the channel up or down.
• This LCD TV set allows you to select up to 125 channels (1 to 125). To select a channel, enter a
one- or two- or three-digit number, or use the channel up or channel down buttons.
To select a one or two-digit channel number (for example, channel 5):
Press 0 on the remote control, and then press 5 immediately.
Or
Press the 5 button.
Using the TV
15
To select a three-digit channel number (for example, channel 115):
Complete the following procedure within 4 seconds.
1 Press the 10+ button on the remote control.
2 Press the 1 button.
3 Press the 5 button.
The three-digit channel number can be selected only when the receiving mode is set to Cable in the TV
Country setting on the System Page.
Exit Button
Press the EXIT button to return one level back from each menu in the onscreen display. You can escape
fully out of the On Screen Display (OSD) with the Exit key.
Adjusting the Language Settings
1 Press the ENTER button on the remote control to display the Menu screen.
2 Arrow down and press ENTER button to select the OSD Page.
3 Press the ENTER button to enter the Language selection menu.
4 Press the Right Arrow to select a language.
5 Press the EXIT button to save your selection.
Adjusting the Picture Mode Settings
Press the Picture Mode key on the remote control to display the Standard, Vivid, Favorite, and Movie
brightness settings.
•
•
•
•
Standard: Fixed brightness for normal viewing conditions.
Vivid: For viewing conditions with higher ambient light.
Favorite: Manual adjustment to user preference.
Movie: For viewing conditions with a darker contrast.
Channel Editing
Follow these steps to add or remove channels from your selection list.
1 Press the ENTER button on the remote control to display the Menu screen.
2 Arrow down and press the ENTER button to select the System Page.
3 Arrow down and press the ENTER button to enter the Channel Edit section.
4 Use the following arrows to add or erase channels:
• Right arrow erases the current channel.
• Left arrow adds the current channel.
• Up and Down arrows scroll through the channels.
16
Using the TV
Setting the TV Receiving Mode
To receive locally broadcast programming, you need to set the receiving mode to Air or Cable.
1 Press the ENTER button on the remote control to display the Menu screen.
2 Arrow down and press the ENTER button to select the System Page.
3 Arrow down and press the ENTER button to enter the TV Country section.
4 Press the Right Arrow to select a Air or Cable mode.
5 Press the EXIT button to save your selection.
Selecting an Input Source
To view different sources on your display such as a DVD Player, VCR, PC, or game console, and so
on, you need to set the input source.
1 Press the Input Select button on your remote control to bring up the Select Source menu.
2 Use the Left and Right arrow buttons until you see the desired input source on your display.
3 Press the EXIT button to return to your display.
Or
Wait a few seconds, and your selected input mode will take effect without pressing more keys.
Selecting a PIP Source
The PIP (Picture-In-Picture)Source button on the remote control displays your sub source in a smaller
window. Continuously pressing the PIP Source button scrolls through all available sub source options.
Selecting the PIP Size
The PIP Size button on the remote control changes the PIP size from small, middle, and large.
POP Button
The POP (Picture-Outside-of-Picture) button on the remote control displays the last 8 channels you
selected around your current channel. Use the Left and Right arrow buttons on the remote control to
activate a channel. You can only activate one channel at a time. Use the Up and Down arrow buttons
on the remote control to scroll through the previous channels you selected.
Using the TV
17
Setting Up V-chip
The V-chip feature requires a PIN number to be entered to view movies and TV programs with
unsuitable ratings for some viewers who share the TV. Follow these steps to lock movies and TV
programs:
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button five times to highlight the Factory Page icon, and then press ENTER.
3 Press the Down arrow button to highlight V-chip.
4 If this is your first time using this feature, enter the default password, 9999, to gain access.
5 Use the following table to set up your V-chip.
18
V-chip Page
Function
Options
V-chip
Requires a PIN number to be
entered to view movies and
TV programs with unsuitable
ratings for people in your
household.
On or Off
TV Rating
Blocks selected TV-rating and
all ratings above it.
TV-Y, TV-Y7, TV-G, TV-PG,
TV-14, TV-MA
MPAA Rating
Blocks selected MPAA-rating
and all ratings above it.
G, PG, PG-13, R, NC-17
New Password
Enter a new password.
Using the TV
Using the Remote Control
The remote control operates the TV, your cable or satellite set-top-box, your DVD/VCR, and your
HP Media Center PC (HP PC).
NOTE: Use the remote control within a distance of 16.4 feet (5 meters) from the front of the TV remote
control sensor window and at the maximum 30° horizontal and vertical angles.
To use the remote control:
1 Press the TV, CBL/SAT, DVD/VCR, or HP.PC button to select the home entertainment component
(Set-top-box, DVD/VCR or HP MCPC) to control.
2 Aim the remote control at the remote control sensor of the selected home entertainment component,
and then press the button you want to use.
30º
5m
Using the TV
19
Remote control item
Description
Indicator light
The red light blinks once each time a button is
pushed. If the red light blinks two times when a
button is pushed, the remote control batteries are
low and need replacement.
Setup
Use the SETUP button when programming the
remote control for component control.
PWR
Press PWR once to turn on or off the selected
home entertainment component.
TV, CBL/SAT, DVD/VCR,
or HP.PC
Press one of these buttons once to select a home
entertainment component to control. HP.PC selects
the HP Media Center PC (connected to the VGA
or DVI connector) and enables the HP MCPC
special buttons on the remote. To program the
remote control to operate a cable or satellite settop-box, or a DVD, or a VCR, see “Programming
the remote control for component control” on
page 22.
Keypad
Use the keypad (0–9, +10) to directly select
channels.
Mute
Press MUTE once to turn sound off or on.
VOL
Use VOL+ (or VOL–) to raise (or lower) the sound
volume.
CH. RTN
Press CH. RTN (channel return) once to recall the
last channel or to page back one screen in the
main menu.
HP.MC
Press HP.MC to Start Media Center when using
the HP Media Center PC.
CH
Use CH+ (or CH–) to select the next higher (or
lower) channel.
Guide
Use GUIDE to display the program guide for a TV
set-top-box or for HP MCPC.
Exit/Back
Use EXIT to exit out of the selected component’s
menu or guide. Use Back for the HP MCPC.
Up/down/left/right
buttons
Use these cursor buttons to move the cursor in a
program guide or in menus.
Enter
Press ENTER once after entering channel numbers
on some TV models. Use Enter as the OK button
for the HP MCPC.
Use Enter to bring up the OSD.
20
Using the TV
Remote control item
Description
Info/Display
Use INFO to display current channel and
program information, if available.
Use Display to show you which channel you
are on.
Menu
Press MENU to access the HP MCPC menu.
PIP Size/Fast reverse
Press PIP SIZE to change the size of the PIP from
small, middle and large. Press Fast reverse when
using a VCR or other device.
POP/Play
Press POP to display the last 8 channels you
selected around your current channel. Press Play
when using a VCR or other device.
Swap/Fast forward
Press Swap when using the PIP to exchange the
pictures in the main display and the PIP/POP
display. Press Fast forward when using a VCR or
other device.
PIP Source/Record
Press PIP SOURCE to select the source for PIP.
Press the Record button for HP MCPC. Press
Record when using a VCR or other device.
Stop play
Press the Stop play button to stop when using a
VCR or other device.
Pause
Press the Freeze play button to pause play when
using a VCR or other device.
Sound Mode
Press the Sound Mode button to select a preset
sound effect.
Picture Mode
Press the Picture Mode button to select a preset
picture setting.
Replay/Reverse
Use the Replay button for rewinding your selected
component.
Skip/Forward
Use the Skip button for fast forwarding your
selected component.
Input Select
Press INPUT SELECT to select the input source for
the main picture.
Caption
Use the Caption button to display closed caption
content.
Aspect
Use the Aspect button to select one of four screen
sizes when viewing videos or digital discs.
MTS
Use MTS to select STEREO, MAIN, or SAP
(second audio program) for TV sound.
Using the TV
21
Programming the remote control for component control
Programming the component code
1 Turn on the TV. Turn on the cable or satellite set-top-box, VCR, or DVD and, if applicable, insert
media (a cassette or a disc).
NOTE: Please read steps 2 through 4 completely before proceeding. We recommend highlighting
or writing down the codes and device you wish to program before performing step 2.
2 On the remote control, press CBL/SAT button or DVD/VCR button once. Press and hold SETUP until
the red light blinks twice, then release SETUP.
3 Use the Manufacturer’s Codes (see listing that follows) to locate the type of component by brand
name and then enter the first four-digit code for your component. If performed correctly, the red
light blinks twice.
NOTE: If the red light did not blink twice, then repeat steps 2 and 3, entering the code again.
4 Aim the remote control at the component and press PWR once. The component should turn off. If it
does not respond, repeat steps 2 and 3, trying each code for your brand until you find one that
works. If it still does not work, try searching for the code in the component code table.
5 Repeat steps 1 through 4 for each component you want to control with the remote control.
Searching for the component code
If your device does not respond to the remote control after trying all codes listed for your brand, or if
your brand is not listed at all, try searching for your code:
1 On the remote control, press CBL/SAT button or DVD/VCR button once.
2 Press and hold SETUP until the red light blinks twice, then release SETUP.
3 Press the number buttons 9, 9, and 1. The red light blinks twice.
4 Aim the remote control at the set-top-box or the VCR or DVD and slowly alternate between pressing
PWR and the component (CBL/SAT or DVD/VCR) button. Stop when the component turns off.
NOTE: In the search mode, the remote control sends codes from its library to the selected device,
starting with the most popular code first.
5 Press SETUP once to lock in the code.
22
Using the TV
Checking the component code
If you have set up the remote control to use a component, you may need to find out which four-digit
code is operating your component equipment:
1 On the remote control, press CBL/SAT or DVD/VCR once.
2 Press and hold SETUP until the red light blinks twice, then release SETUP.
3 Press the number buttons 9, 9, and 1. The red light blinks twice.
4 For the first digit of the code, press the number button 1 once. Wait 3 seconds, and then count the
number of times the red light blinks and write down the number.
NOTE: When you count three blinks, it means the code digit is 3. When a code digit is 0, the red
light will not blink.
5 Repeat step 4 for the three remaining digits of the code, pressing 2 for the second digit, 3 for the
third digit, and 4 for the fourth digit.
Reassigning component buttons
The remote control can be set up to control a second TV or VCR, or any combination of eight home
entertainment components.
For example, to control a TV, a Cable Converter, and two VCRs, you need to re-assign a component
button to operate the second VCR as follows:
1 On the remote control, press and hold SETUP until the red light blinks twice, then release SETUP.
2 Press the number buttons 9, 9,1. The red light blinks twice.
3 Press DVD/VCR once, then press CBL/SAT once.
4 The CBL/SAT button is now ready to be programmed for your second VCR.
To re-assign other device keys, repeat steps 1 through 4 by substituting the key sequence from the
following table for the most popular components:
To assign
Use this sequence
TV as 2nd DVD/VCR button
SETUP - 9 - 9 - 2 – DVD/VCR - TV
TV as 2nd CBL/SAT button
SETUP - 9 - 9 - 2 – CBL/SAT - TV
TV back to TV
SETUP - 9 - 9 - 2 – TV - TV
VCR as 2nd CBL/SAT button
SETUP - 9 - 9 - 2 – CBL/SAT - VCR
VCR back to VCR
SETUP - 9 - 9 - 2 – VCR - VCR
CBL/SAT as 2nd VCR button
SETUP - 9 - 9 - 2 – VCR - CBL/SAT
CBL/SAT back to CBL/SAT
SETUP - 9 - 9 - 2 – CBL/SAT - CBL/SAT
When a re-assignment is done, the red light blinks twice to confirm your choice. Then, you need to
program the remote control to control the new component.
Using the TV
23
Changing volume lock
The remote control is set to control volume of a component through your TV while in the TV, DVD/VCR,
or CBL/SAT mode. However, in the HP.PC mode you have separate control of the volume.
If you want the volume to be controlled by a different component than the TV, you can change the
Volume Lock setting to control volume through a non-associated mode (for example, through the cable
in the TV mode).
To change volume lock to another mode:
1 On the remote control, press and hold SETUP until the red light blinks twice, then release SETUP.
2 Press the number buttons 9, 9, 3, and then press any mode key once (except TV). The red light will
blink twice.
3 Now, whenever you press VOL+, VOL–, or MUTE, volume is controlled by your component mode
choice.
To change volume lock back to the TV mode:
1 On the remote control, press and hold SETUP until the red light blinks twice, then release SETUP.
2 Press the number buttons 9, 9, 3, and then press TV. The red light blinks twice.
3 Now, whenever you press VOL+, VOL–, or MUTE on the remote control, volume is controlled by
your TV.
24
Using the TV
Manufacturer’s codes
Manufacturer
Codes for VCR
Admiral
0048
Adventura
0000
Aiko
0278
Aiwa
0037, 0000
Akai
0041
American High
0035
Asha
0240
Audiovox
0037
Beaumark
0240
Bell & Howell
0104
Broksonic
0184, 0121, 0209, 0002
CCE
0072, 0278
Calix
0037
Canon
0035
Carver
0081
Cineral
0278
Citizen
0037, 0278
Colt
0072
Craig
0037, 0047, 0240, 0072, 0271
Curtis Mathes
0060, 0035, 0041, 0162
Cybernex
0240
Daewoo
0045, 0278
Denon
0042
Dynatech
0000
Electrohome
0037
Electrophonic
0037
Emerex
0032
Emerson
0037, 0184, 0000, 0121, 0043, 0209, 0002, 0278
Fisher
0047, 0104
Fuji
0035, 0033
Funai
0000
GE
0060, 0035, 0048, 0240
Garrard
0000
Go Video
0526
GoldStar
0037, 0038
Gradiente
0000
Using the TV
25
26
Manufacturer
Codes for VCR
HI-Q
0047
Harley Davidson
0000
Harman/Kardon
0081, 0038
Harwood
0072
Headquarter
0046
Hitachi
0000, 0042, 0041
JVC
0067, 0041
Jensen
0041
KEC
0037, 0278
KLH
0072
Kenwood
0067, 0041, 0038, 0046
Kodak
0035, 0037
LXI
0037
Lloyd’s
0000
Logik
0072
MEI
0035
MGA
0240, 0043
MGN Technology
0240
MTC
0240, 0000
Magnasonic
0278
Magnavox
0035, 0039, 0081, 0000, 0149
Magnin
0240
Marantz
0035, 0081, 0038
Marta
0037
Matsushita
0035, 0162, 0454
Memorex
0035, 0037, 0048, 0039, 0047, 0240, 0000, 0104, 0046, 1162, 1262
Minolta
0042
Mitsubishi
0048, 0067, 0043
Motorola
0035, 0048
Multitech
0000, 0072
NAP
0035, 0037, 0039, 0042, 0033
NEC
0104, 0067, 0041, 0038
Nikko
0037
Noblex
0240
Olympus
0035
Optimus
0037, 0048, 0104, 0162, 0454, 1062, 1162, 1262
Orion
0184, 0002
Using the TV
Manufacturer
Codes for VCR
Panasonic
0035, 0162, 0225, 0454, 1162
Penney
0035, 0037, 0240, 0042, 0038
Pentax
0042
Philco
0035, 0209
Philips
0035, 0081
Pilot
0037
Pioneer
0067
Profitronic
0240
Proscan
0060
Protec
0072
Pulsar
0039
Quarter
0046
Quartz
0046
Quasar
0035, 0162, 0454, 1162
RCA
0060, 0035, 0048, 0240, 0042, 0149
Radio Shack
0000
Radix
0037
Randex
0037
Realistic
0035, 0037, 0048, 0047, 0000, 0104, 0046
Runco
0039
STS
0042
Samsung
0240, 0045
Sanky
0048, 0039
Sansui
0000, 0067, 0041, 0271
Sanyo
0047, 0240, 0104, 0046
Scott
0184, 0045, 0121, 0043
Sears
0035, 0037, 0047, 0000, 0042, 0104, 0046
Semp
0045
Sharp
0048
Shintom
0072
Shogun
0240
Signature
0035
Singer
0072
Sony
0035, 0032, 0000, 0033
Sylvania
0035, 0081, 0000, 0043
Symphonic
0000
TMK
0240
Using the TV
27
28
Manufacturer
Codes for VCR
Tatung
0041
Teac
0000, 0041
Technics
0060, 0035, 0039, 0162
Teknika
0035, 0037, 0000
Thomas
0000
Toshiba
0045, 0043
Totevision
0037, 0240
Unitech
0240
Vector
0045
Vector Research
0038
Video Concepts
0045
Videosonic
0240
Wards
0060, 0035, 0048, 0047, 0081, 0240, 0045, 0000, 0042, 0072, 0149
White Westinghouse
0278
XR-1000
0035, 0000, 0072
Yamaha
0041, 0038
Zenith
0039, 0000, 0033
Manufacturer
Codes for cable converter box
ABC
0003, 0008, 0014, 0017, 0007, 0011, 0013
Allegro
0153, 0315
Archer
0153, 0797
Bell & Howell
0014
Century
0153
Citizen
0153, 0315
Comtronics
0040
Contec
0019
Eastern
0002
Emerson
0797
Everquest
0015, 0040
Focus
0400
Garrard
0153
Gemini
0015
General Instrument
0476, 0276, 0011, 0810
GoldStar
0144, 0040
Goodmind
0797
Hamlin
0020, 0259, 0009, 0034
Using the TV
Manufacturer
Codes for cable converter box
Hitachi
0011
Hytex
0007
Jasco
0015, 0153, 0315
Jerrold
0003, 0012, 0476, 0276, 0014, 0015, 0011, 0810
Magnavox
0014
Memorex
0000
Movie Time
0063
NAP
0007
NSC
0063
Oak
0019, 0007
Optimus
0021
Panasonic
0000, 0107, 0021
Paragon
0000
Philips
0153
Pioneer
0144, 0533
Popular Mechanics
0400
Proscan
0021
Pulsar
0000
Quasar
0000
RCA
0021
Radio Shack
0015, 0315, 0797, 0883
Recoton
0400
Regal
0020, 0259
Regency
0002
Rembrandt
0011
Runco
0000
SL Marx
0040
Samsung
0144, 0040
Scientific Atlanta
0008, 0477, 0017, 0877
Signal
0015, 0040
Signature
0011
Sprucer
0021
Starcom
0003, 0015
Stargate
0015, 0040, 0797
Starquest
0015
TV86
0063
Using the TV
29
30
Manufacturer
Codes for cable converter box
Teleview
0040
Tocom
0012, 0013
Toshiba
0000
Tusa
0015
Unika
0153
United Artists
0007
Universal
0153, 0191
Viewstar
0063
Zenith
0008, 0000, 0015, 0525
Zentek
0400
Manufacturer
Codes for satellite or DBS receivers
AlphaStar
0772
Echostar
0775
Expressvu
0775
General Instrument
0627, 0361, 0869
HTS
0775
Hitachi
0819
Hughes Net. Sys.
0749
JVC
0775
Jerrold
0627, 0361
Magnavox
0724, 0722
Memorex
0724
Next Level
0869
Panasonic
0701
Philips
0724, 0722
Primestar
0627, 0361
Proscan
0566
RCA
0566, 0143, 0855
Radio Shack
0566, 0869
Sony
0639
Star Choice
0869
Toshiba
0790
Uniden
0724, 0722
Zenith
0856
Using the TV
Manufacturer
Codes for DVD players
Harman/Kardon
0582
JVC
0558
Kenwood
0534
Magnavox
0503
Mitsubishi
0521
Onkyo
0503
Optimus
0525
Panasonic
0490
Philips
0503, 0539
Pioneer
0525, 0571
Proscan
0522
RCA
0522
Samsung
0573
Sony
0533
Technics
0490
Theta Digital
0571
Toshiba
0503
Yamaha
0490, 0545
Zenith
0503, 0591
Using the TV
31
On Screen Display (OSD) Menu
Your LCD TV comes with a On Screen Display (OSD) menu. Use the remote control to move through
the OSD menu. Press the ENTER button to bring up the OSD menu. The three different modes for the
OSD are the following:
• PC Mode: Displays when the VGA or DVI input is selected.
• TV Mode: Displays when TV1 or TV2 input is selected.
• AV/SV/YPbPr Mode: Displays when a AV1, AV2, SV1, SV2, YPbPr1 or YPbPr2 input is
selected.
Depending on which mode you are displaying the following pages appear on your OSD menu:
• System Page: (TV Mode only) Sets the video standard, cable input, channel search, channel
•
•
•
•
•
•
edits and fine tuning of your display.
Image Page: Adjust the brightness, contrast, picture mode, sharpness, hue and color of
your display.
Color Page: (PC Mode only) Adjusts the color temperature of your display.
OSD Page: Adjusts the language, length of time OSD menu is displayed and position of
OSD menu.
Audio Page: Sets the sound effects, volume, balance, subwoofer, treble and bass of your sound.
PIP/PAP Page: Sets the PIP mode, PIP source, PIP size and position on the display of the PIP.
Factory Page: Sets the closed captioning, sleep timer, aspect ratio and noise reduction of your
display.
NOTE: Not all functions are included in each mode.
PC Mode
Adjusting the Volume
Press the (+) or (–) VOL buttons on the remote control to increase or decrease the volume.
PC Mode Operation
1 Press the ENTER button on the remote control to display the following On Screen Display (OSD)
menu items: Image Page, Color Page, OSD Page, Audio Page, PIP/POP Page, and Factory Page.
(Press the Exit key to return one level back in the OSD menu.)
2 Press the Up and Down arrow buttons to move up and down the Page icons. Press the ENTER
button when you arrive at your selection.
3 Use the Up and Down arrow buttons to highlight a function.
4 Press the Left or Right arrow buttons to either scroll through the options of a specific function or view
the submenu.
5 Press the Exit button to save your change and return to the OSD menu.
32
Using the TV
Image Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the ENTER button again to highlight the first setting of the Image Page icon.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Image Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the Image Page:
Image Page
Function
Options
Brightness
Adjusts the darkness and
lightness of the display.
0 to 100
Contrast
Adjusts the color brightness
of the display.
0 to 100
H – Size
Widens image.
0 to 100
Phase
Video timing adjustment
H – Position
Moves image to the left or
right.
V – Position
Moves image up or down.
Color Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button once to highlight the Color Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the OSD Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the Color Page:
Color Page
Function
Options
6500k
Color temperature
7500k
Color temperature
9300k
Color temperature
User R
Adjusts the shade of Red
0 to 255
User G
Adjusts the shade of Green
0 to 255
User B
Adjusts the shade of Blue
0 to 255
Using the TV
33
OSD Page
1
2
3
4
5
Press the ENTER button on the remote control to bring up the OSD menu.
Press the Down arrow button twice to highlight the OSD Page icon, and then press ENTER.
Use the Up and Down arrow buttons to highlight a setting and press ENTER.
Press the Left and Right arrow buttons to scroll through your options.
Press the Up and Down arrow buttons to select other settings on the OSD Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the OSD Page:
OSD Page
Function
Options
Language
Set the language for the
OSD menu.
English
Timeout
Set the number of seconds
for OSD to remain
displayed before
disappearing after final
use.
5 to 60 seconds
(in increments of 5)
H-Position
Moves the OSD to the left
and right on your display.
0 to 100
V-Position
Moves the OSD up and
down on your display.
0 to 100
Transparency
Use the left and right arrow
buttons on your remote
control to make the OSD
see through.
0 to 100
Audio Page
1
2
3
4
5
Press the ENTER button on the remote control to bring up the OSD menu.
Press the Down arrow button three times to highlight the Audio Page icon, and then press ENTER.
Use the Up and Down arrow buttons to highlight a setting and press ENTER.
Press the Left and Right arrow buttons to scroll through your options.
Press the Up and Down arrow buttons to select other settings on the OSD Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
34
Using the TV
You can make the following adjustments in the Audio Page:
Audio Page
Function
Options
Sound Effect
Select a preset customized sound effect.
• Standard
• WOW
• BBE
Volume
Increases and decreases the level of sound.
0 to 100
Balance
Switches amount of sound coming from each
speaker.
–50 to +50
Treble
Increases and decreases the level of treble (only
available when Standard option is selected).
–12 to +12 (standard)
–3 to +3 (WOW/BBE)
Bass
Increases and decreases the level of bass (only
available when Standard option is selected).
–12 to +12 (standard)
–3 to +3 (WOW/BBE)
Sub Woofer
Increases and decreases the level of sub woofer
(only available when Standard option is
selected).
0 to 100
PIP/PAP Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button four times to highlight the PIP/PAP Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the PIP/PAP Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
Using the TV
35
You can make the following adjustments in the PIP/PAP Page:
PIP/PAP Page
Function
Options
PIP/PAP
Turns on or off Picture-In-Picture and PictureAnd-Picture.
• PIP
Sub Source
Select an input source to be displayed in
Picture-In-Picture or Picture-And-Picture mode.
available sources
Display Size
Select a size for the PIP display.
• Small
• PAP
• Off
• Middle
• Large
H-Position
Moves the PIP to the left and right on your
display.
0 to 100
V-Position
Moves the PIP up and down on your display.
0 to 100
Factory Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button five times to highlight the Factory Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Factory Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the EXIT button to remove the OSD menu from your display.
36
Using the TV
You can make the following adjustments in the Factory Page:
Factory Page
Function
Options
Recall Default
Puts all of your settings
back to their default.
Left arrow button resets all
settings to their default.
Auto Adjust
(VGA mode only) Adjusts
the image-related functions.
• H Position
• V Position
• Size
• Phase
TV Mode
Adjusting the Volume
Press the (+) or (–) VOL buttons on the remote control to increase or decrease the volume.
Changing Channels
Press the (+) or (–) CH buttons on the remote control to change the channel up or down a channel.
TV mode operation
1 Press the ENTER button on the remote control to display the following On Screen Display (OSD)
menu items: System Page, Image Page, OSD Page, Audio Page, PIP/POP Page, and Factory Page.
(Press the EXIT button to return one level back in the OSD menu.)
2 Press the Up and Down arrow buttons to move up and down the Page icons. Press the ENTER
button when you arrive at your selection.
3 Use the Up and Down arrow buttons to highlight a function.
4 Press the Left or Right arrow buttons to either scroll through the options of a specific function or view
the submenu.
5 Press the EXIT button to save your change and return to the OSD menu.
Using the TV
37
System Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the ENTER button again to highlight the first setting of the System Page.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the System Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the EXIT button to remove the OSD menu from your display.
You can make the following adjustments in the System Page:
System Page
Function
Options
TV System
Select a video standard.
NTSC
TV Country
Select a cable or antenna input.
• CATV (FCC)
• CATV (HRC)
• CATV (IRC)
• AIRTV (FCC)
Channel Search
Scans channels 2 ~ 69 (AIRTV),
1 ~ 125 (CATV), and adds the
channels that return a signal to
your channel listing.
Yes or No
Channel Edit
Add or erase channels.
• Up and down arrows
scroll through your
channels.
• Left arrow erases a
current channel.
• Right arrow adds
current channel.
Fine Tuning
Clear Memory
38
Using the TV
Adjusts the strength of the
signal.
• TV Channel
Resets all settings to the factory
default.
Yes or No
• TV Frequency
Image Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button to highlight the Image Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Image Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the Image Page:
Image Page
Function
Options
Picture Mode
Select a preset customized picture setting.
• Favorite
• Standard
• Vivid
• Movie
Brightness
Adjusts the darkness and lightness of the display
(only available when Favorite option is selected).
0 to 100
Contrast
Adjusts the color brightness of the display (only
available when Favorite option is selected).
0 to 100
Sharpness
Adjusts the clarity of images (only available
when Favorite option is selected).
0 to 100
Color
Adjusts the shades of color (only available when
Favorite option is selected).
0 to 100
Hue
Adjusts the color properties (only available when
Favorite option is selected).
0 to 100
OSD Page
Refer to “OSD Page” on page 34 for information.
Audio Page
Refer to “Audio Page” on page 34 for information.
PIP/PAP Page
Refer to “PIP/PAP Page” on page 35 for information.
Using the TV
39
Factory Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button five times to highlight the Factory Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Factory Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the Factory Page:
Factory Page
Function
Options
Close Caption
Displays text.
• Off
• CC1
• CC2
V-chip
Blocks channels.
Sleep Timer
Select the number of
minutes you would like the
display to power off.
• Off
• 30 Minutes
• 60 Minutes
• 90 Minutes
• 120 Minutes
Aspect
Select the display ratio for
your screen.
• Normal
• 4:3
• Panorama
Noise Reduce
Enhances quality of
standard definition, off air
media, and standard
definition video.
• Off
• Weak
• Medium
• Strong
Recall Default
40
Using the TV
Puts all of your settings
back to their default.
Left arrow button resets all
settings to their default.
AV/SV Mode
Adjusting the Volume
Press the (+) or (–) VOL buttons on the remote control to increase or decrease the volume.
AV/SV Operation
1 Press the ENTER button on the remote control to display the following On Screen Display (OSD)
menu items: Image Page, OSD Page, Audio Page, PIP/PAP Page, and Factory Page. (Press the
Exit key to return one level back in the OSD menu.)
2 Press the Up and Down arrow buttons to move up and down the Page icons. Press the ENTER
button when you arrive at your selection.
3 Use the Up and Down arrow buttons to highlight a function.
4 Press the Left or Right arrow buttons to either scroll through the options of a specific function or
view the submenu.
5 Press the Exit button to save your change and return to the OSD menu.
Factory Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button four times to highlight the Factory Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Factory Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
Factory Page
Function
Options
Close Caption
Displays text.
• Off
• CC1
• CC2
V-chip
Sleep Timer
Blocks channels.
Select the number of minutes you would like
the display to power off.
Aspect
Select the display ratio for your screen.
Noise Reduce
Enhances quality of standard definition, off air
media, and standard definition video.
Recall Default
Puts all of your settings back to their default.
•
•
•
•
•
•
•
•
•
•
•
•
Off
30 Minutes
60 Minutes
90 Minutes
120 Minutes
Normal
4:3
Panorama
Off
Weak
Medium
Strong
Left arrow button resets all
settings to their default.
Using the TV
41
YPbPr Mode
Adjusting the Volume
Press the (+) or (–) VOL buttons on the remote control to increase or decrease the volume.
YPbPr Operation
1 Press the ENTER button on the remote control to display the following On Screen Display (OSD)
menu items: Image Page, OSD Page, Audio Page, PIP/PAP Page, and Factory Page. (Press the
Exit key to return one level back in the OSD menu.)
2 Press the Up and Down arrow buttons to move up and down the Page icons. Press the ENTER
button when you arrive at your selection.
3 Use the Up and Down arrow buttons to highlight a function.
4 Press the Left or Right arrow buttons to either scroll through the options of a specific function or
view the submenu.
5 Press the Exit button to save your change and return to the OSD menu.
Factory Page
1 Press the ENTER button on the remote control to bring up the OSD menu.
2 Press the Down arrow button four times to highlight the Factory Page icon, and then press ENTER.
3 Use the Up and Down arrow buttons to highlight a setting and press ENTER.
4 Press the Left and Right arrow buttons to scroll through your options.
5 Press the Up and Down arrow buttons to select other settings on the Factory Page.
Or
Press the EXIT button to save the setting and return to the OSD menu.
6 Press the Exit button to remove the OSD menu from your display.
You can make the following adjustments in the Factory Page:
42
Factory Page
Function
Options
Sleep Timer
Select the number of minutes
you would like the display to
power off.
Aspect
Select the display ratio for your
screen.
Noise Reduce
Enhances quality of standard
definition, off air media, and
standard definition video.
•
•
•
•
•
•
•
•
•
•
•
•
Recall Default
Puts all of your settings back to
their default.
Using the TV
Off
30 Minutes
60 Minutes
90 Minutes
120 Minutes
Normal
4:3
Panorama
Off
Weak
Medium
Strong
Left arrow button resets all settings to their default.
Troubleshooting
Problem
Solutions
There is no picture or sound.
• Make sure the power cord is properly inserted in
the power outlet.
• Reception other than those of broadcasting stations
can be considered.
• Make sure the input mode is correctly set in Input
Select.
There is no sound.
• Make sure the volume is not set to minimum.
• Make sure the sound is not set to mute.
• Make sure that headphones are not connected.
There is no picture or sound, just noise.
• Make sure the antenna cable is properly
connected.
• Consider whether TV/PC/AV/SV/YPbPr signals
are being properly received.
The picture is not clear.
• Make sure the antenna cable is properly
connected.
• Consider whether TV signals are being properly
received.
The picture is light or improperly tinted.
• Check the color adjustments.
• Check the tint settings.
The picture is too dark.
• Check the brightness settings.
• The fluorescent lamp may have reached the end of
its service life.
The remote control does not work.
• Check the batteries in the remote control.
• Make sure the remote sensor window is not under
strong fluorescent lighting.
The picture is not sharp.
• The reception may be weak.
• Make sure the antenna is facing the right
direction.
• Check the sharpness function.
The picture is doubled or tripled.
• Make sure the antenna is facing the right
direction.
• There may be reflected electric waves from
mountains or buildings.
Troubleshooting
43
Problem
Solutions
The picture is spotted.
• There may be interference from automobiles,
trains, high-voltage lines, neon lights, or other
factors.
• There may be interference between the antenna
cable and power cable. Try positioning them
further apart.
There are stripes on the screen or colors
fade.
• The unit may be receiving interference from other
devices. Transmission antennas of radio
broadcasting stations and transmission antennas of
amateur radios and cellular phones may also
cause interference.
• Use the unit as far apart as possible from devices
that may cause possible interference.
Troubleshooting the remote control programming
44
Problem
Solution
Red light does not blink when you press a key.
Replace the batteries with two (2) new AA alkaline
batteries.
Red light blinks when you press a key, but home
entertainment component does not respond.
Make sure the remote control is aimed at your home
entertainment component and is not farther than
15 feet away.
Remote control does not control home entertainment
components or commands are not working properly.
Try all listed codes for the component brands being
set up. Make sure they can be operated with an
infrared remote control.
No volume on a 2nd TV.
Follow instructions in “Changing Volume Lock.”
CH+, CH– , and CH.RTN do not work for your
RCA TV.
Due to RCA design (1983–1987), only the original
remote control will operate these functions.
Changing channels does not work properly.
If original remote control required pressing ENTER to
change channels, press ENTER on the Remote control
after entering the channel number.
Tried “Search Method” and still could not find a
working code.
Try the “Search Method” again after clearing out the
component button as follows: Press and hold SETUP
until red light blinks twice, then release. Next enter
9 - 9 - 2. Then press and release the component
button to be cleared twice.
Troubleshooting
Specifications (United States)
Model number/type number
HP LC3040N 30" HD Ready LCD TV
HP LC2640N 26" HD Ready LCD TV
TV broadcast
system
Tuner
Built-in Dual NTSC TV Tuners with PIP and
Side-by-Side viewing capability.
Antenna
75 ohm external
Channel coverage
VHF 2 to 13
UHF 14 to 69
CATV 1 to 125
SDTV broadcast
NTSC (U.S./Japan/Taiwan)
Tuning system (NTSC)
Auto channel finder
Intelligent tuning system
Fine-tuning
Favorite channel edit
Cable tuning system
HRC and IRC
HDTV-supported inputs
YPbPr: 1080i/720p/480p/480i
DVI: 1080i/720p/480p/408i
Video
processing
HDCP (on DVI)
Yes
Closed Captioning
Yes (TV, AV, SV supported)
V-chip
Password protect viewing according to
Content Rating, TV Rating, and MPAA
Rating.
MTS sound processing
Stereo, mono, SAP
3-D comb filter
Yes
Deinterlacer
3-D motion adaptive deinterlacer
1080i deinterlacing supported
3-D
15:9 and 4:3 switchable
Yes
Nonlinear scaling for 16:9
Yes
3:2 pulldown (film mode)
Yes
2:2 pulldown (film mode)
Yes
Flicker-free film mode detection
Yes
Black level stretch
Yes
Cubic-4 interpolation
Cubic-4 interpolation
PIP/PAP sources
Yes (selected video/TV and PC/TV)
POP
Yes (selected video/TV and PC/TV)
Multi-PIP
Yes (8 plus 1 TV channels)
8 refresh channels plus 1 active channel
Specifications (United States)
45
Video
processing
(continued )
Processing
System
Frame rate conversion (FRC)
Yes
RGB
Yes
ISP
Yes
Input data processing (scaler)
8-bit
OSD language
English
HP Visual Fidelity
One A/D conversion insures superior
reproduction and pristine video throughout a
lossless digital pipeline.
Emmy Award winning DCDi video
processing
Analyzes video pixel-by-pixel to smooth out
staircases and jagged edges. Brings a new
tier of realism to sporting events and movies.
FilmMode processing with 3:2 and
2:2 pull down
Reproduces film-originated content from
video sources with superior accuracy.
Rearranges frame sequence to reproduce.
Motion Adaptive Noise Reduction
Greatly enhances purity of standard
definition and off air media video.
Fine Detail Enhancement
Identifies areas of fine detail in a picture,
such as skin and hair, and enhances them to
a dramatically more life like appearance.
Identifies large edges that identify
separation of objects, and enhances them to
create a greater perception of depth. The
result is a stunningly realistic viewing
experience.
Cross Color Suppression
Removes cross color artifacts from composite
video sources, delivering consistent, true
color every time.
Picture modes
Standard, Vivid, Favorite, and Movie
viewing modes enable the viewer to quickly
change screen settings for dim or bright
ambient light conditions.
Aspect modes
Wide: Presents material in widescreen
format.
4:3: Presents material in regular 4:3 format.
Panorama: Creates a more natural looking
conversion of 4:3 in to a widescreen format.
46
Specifications (United States)
LCD panel
Pixel resolution
WXGA (1,280 × 768 pixels)
Panel System
High Definition LCD Display
Video Format
Scales all video signals to native format of
1280 x 768.
Viewable Image Area (diagonal)
LC2640N 26 inches
LC3040N 29.53 inches
Input
connectors
Aspect Ratio
15:9 Widescreen
Displayable colors
16.7 million
Anti-reflective coating
Yes
Backlight life
50,000 hours
Color temperature
7500K
TFT active matrix
MVA TFT active matrix color LCD
Brightness
Brightness 500 Cd/m2 (typical)
Response Time (Grey to grey) (ms)
Response time 16ms
Color saturation
Color saturation 72% (NTSC)
View angle
View angle L/R of 85/85, U/D of 85/85
Contrast ratio
Contrast ratio of 600:1
Pixel frequency
65 MHz
Horizontal scan
31 kHz–64 kHz
Vertical refresh
56 Hz–75 Hz
CCFL
16 CCFL
Electrical Interface
One-channel LVDS
DVI (DVI-HDCP supported)
1
YPbPr High Definition component inputs
2
15-pin D-sub (PC analog RGB)
1
PC audio
1
S-video (Y/C)
Two pairs
SV1and SV2 rear access
Composite video
2 pairs
AV1 and AV2
Subwoofer out
1
Headphone
1
TV/CATV antenna
TV/CATV antenna (1)
RS-232 (for service)
1
Specifications (United States)
47
Output
connectors
User controls
(front panel)
Variable Audio Line Out (L/R)
Yes
TV (video and audio) for PVR (HP
LC2640N only)
Yes (Composite and audio L/R)
Headphones
Yes
Subwoofer
Yes
Front panel controls
Input selector: PC, TV1, TV2, AV1, AV2,
SV1, SV2, YPbPr1, and YPbPr2.
Menu, channel (CH) up/down, volume (Vol)
up/down, Exit, and Select.
Remote
control
Audio
IR remote
IR remote (rubber key pads)
IR protocol
NEC 6222
Audio power amplifier
Stereo 15W and 15W Class D
Audio Enhancement modes
BBE, SRS, WOW with TruBass
Bass enhancer (TruBass)
TruBass
Audio controls
Bass, treble, loudness, volume
Audio input
Yes
Audio power amplifier
Stereo 15W/channel
MTS/SAP
Yes
PC Audio input (mini-jack)
1
Stereo Headphone jack
1
Subwoofer Out
1
Audio out
1
Speakers
System: 2-way
Midrange: 2.75-in.
Tweeter: Dome tweeter
OSD controls
(PC)
48
Speaker mechanism
Detachable
OSD text
Bitmap
OSD type
Alpha blending
PC parameters
Contrast, brightness, horizontal position,
vertical position, phase (pixel adj.), recall
defaults, auto adj., information, clock,
language select, OSD position, OSD
timeout, volume, mute
Specifications (United States)
OSD controls
(TV/video)
TV/video parameters
Channel edit, auto scan, MTS
Sharpness, DNR, reset, contrast, brightness,
color, timer, OSD transparent, audio source,
loudness, balance
Standard, SRS WOW, BBE
Picture mode, audio mode (digital EQ)
PIP/PAP/Multi-CH-PIP (1a+8) EPG
U.S.: TV/movie rating, closed captioning
OSD language
Power/power
management
Miscellaneous
Mechanical
Environmental
Power-saving VESA DPMS standard
VESA DPMS standard
Off mode power consumption
< 3W at 110V, < 3W at 240V
Power supply
Auto-ranging, 00~240V, internal power
supply, 50~60Hz
Nominal current
1.7 A maximum
Frequency
50~60 Hz
Maximum
< 150 watts
Power off mode
< 3W
PFC
Yes (U.S.)
AC line voltage
100~240V
Power cord
6 feet
Sleep timer
0, 30, 60, 90, and 120 minutes
Self-test feature
Flying window/logo
Burn-in mode
Yes
Factory mode
Yes
Stand
Detachable stand for wall mount
Wall mount
VESA mount (100 mm × 200 mm), 6 holes
Temperature — Operating
41 to 95 degrees Fahrenheit
5 to 35 degrees Celsius
Temperature — Non-operating
–4 to 140 degrees Fahrenheit
–20 to 60 degrees Celsius
Accessories
Humidity — Operating
20% to 80%
Humidity — Non-operating
5% to 95%
Altitude — Operating
0 to 12,000 feet (0 to 3,658 meters)
Altitude — Non-operating
0 to 40,000 feet (0 to 12,192 meters)
Optional Accessories
Subwoofer
Recommended Solution Additions
HP Media Center PC
HP Digital Entertainment Center
VESA Mounting
Yes (comes with stand attached, must be
removed for mounting)
Kensington Lock-ready
No
Specifications (United States)
49
Agency Regulatory Notice
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio or television technician for help.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that
are not expressly approved by Hewlett-Packard Company may void the authority to operate the
equipment.
Cables
Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods
in order to maintain compliance with FCC Rules and Regulations.
50
Agency Regulatory Notice
Declaration of Conformity for products marked with the FCC logo —
United States only
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
For questions regarding your product, contact:
Hewlett-Packard Company
P.O. Box 692000, Mail Stop 530113
Houston, Texas 77269-2000
Or call:
1-800-652-6672
For questions regarding this FCC declaration, contact:
Hewlett-Packard Company
P.O. Box 692000, Mail Stop 510101
Houston, Texas 77269-2000
Or call:
(281) 514-3333
To identify this product, refer to the part, series, or model number found on the product.
Agency Regulatory Notice
51
Index
A
P
antenna connection, 11
audio page, 32
AV/SV/YPbPr mode
factory page, 41
PC mode
audio page, 34
color page, 33
factory page, 36
image page, 33
OSD page, 34
PIP/PAP page, 35
PIP
selecting size, 17
selecting source, 17
PIP/PAP page, 32
POP button, 17
power connection, 10
power cord, 6
power management, 14
B
basic operation, 15
brackets for speakers, 2
C
channel
editing, 16
channels
changing, 15
cleaning the screen, 4
color page, 32
component buttons
reassigning, 23
component code
checking, 23
programming, 22
searching, 22
R
remote control
battery, 7
cautions, 7
programming, 22
using, 19
E
S
exit button, 16
safety, 1
screen
cleaning, 4
setup
antenna, 10
cable box, 10
composite component, 9
DVI cable, 9
rear connectors, 8
satellite dish, 10
subwoofer, 10
S-video component, 9
VGA cable, 9
YPbPr component, 9
speakers
attaching, 13
specifications, 45
stand replacement, 4
system page, 32
F
factory page, 32
H
handles, 4
I
image page, 32
input source
selecting, 17
installing the TV, 1, 4
M
mounting brackets, 4
moving the TV, 1
mute, 15
O
on screen display (OSD)
AV/SV/YPbPr mode, 32
menu, 32
PC mode, 32
TV mode, 32
opening the package, 1, 4
OSD page, 32
52
Index
T
transport handles, 4
troubleshooting, 43
TV mode
factory page, 40
image page, 39
system page, 38
TV stand, 4, 12
V
volume, 15
W
wall mounting, 4, 12
Index
53
