HP Photosmart 320 series User's Guide
English
Copyrights and trademarks
© Copyright 2004 Hewlett-Packard
Development Company, L.P.
The information contained herein is
subject to change without notice.
Reproduction, adaptation or
translation without prior written
permission is prohibited, except as
allowed under the copyright laws.
Notice
The only warranties for HP products
and services are set forth in the
express warranty statements
accompanying such products and
services. Nothing herein should be
construed as constituting an
additional warranty. HP shall not be
liable for technical or editorial errors
or omissions contained herein.
The Hewlett-Packard Development
Company, L.P. shall not be liable for
incidental or consequential damages
in connection with, or arising out of
the furnishing, performance, or use of
this document and the program
material which it describes.
Trademarks
HP, the HP logo, and Photosmart are
property of Hewlett-Packard
Development Company, L.P.
The Secure Digital logo is a
trademark of the SD Association.
Microsoft and Windows are registered
trademarks of Microsoft Corporation.
CompactFlash, CF, and the CF logo
are trademarks of the CompactFlash
Association (CFA).
Memory Stick, Memory Stick Duo,
Memory Stick PRO, and Memory
Stick PRO Duo are trademarks or
registered trademarks of Sony
Corporation.
MultiMediaCard is a trademark of
Infineon Technologies AG of
Germany, and is licensed to the
MMCA (MultiMediaCard Association).
SmartMedia is a trademark of
Toshiba Corporation.
xD-Picture Card is a trademark of Fuji
Photo Film Co., Ltd., Toshiba
Corporation, and Olympus Optical
Co., Ltd.
Mac, the Mac logo, and Macintosh
are registered trademarks of Apple
Computer, Inc.
The Bluetooth word mark and logos
are owned by the Bluetooth SIG, Inc.
and any use of such marks by
Hewlett-Packard Company is under
license.
PictBridge and the PictBridge logo are
trademarks of the Camera & Imaging
Products Association (CIPA).
Other brands and their products are
trademarks or registered trademarks
of their respective holders.
The embedded software in the printer
is based in part on the work of the
Independent JPEG Group.
The copyrights to certain photos
within this document are retained by
the original owners.
Regulatory model
identification number
SDGOA-0406
For regulatory identification purposes,
your product is assigned a Regulatory
Model Number. The Regulatory
Model Number for your product is
SDGOA-0406. This regulatory
number should not be confused with
the marketing name (HP Photosmart
320 series printer) or product number
(Q3414A).
Safety information
Always follow basic safety
precautions when using this product
to reduce risk of injury from fire or
electric shock.
Warning To prevent fire or
shock hazard, do not expose
this product to rain or any
type of moisture.
●
●
●
●
●
●
●
Read and understand all
instructions in the HP
Photosmart Setup Guide.
Use only a grounded electrical
outlet when connecting the unit
to a power source. If you do not
know whether the outlet is
grounded, check with a qualified
electrician.
Observe all warnings and
instructions marked on the
product.
Unplug this product from wall
outlets before cleaning.
Do not install or use this product
near water or when you are wet.
Install the product securely on a
stable surface.
Install the product in a protected
location where no one can step
●
●
●
on or trip over the power cord,
and where the power cord will
not be damaged.
If the product does not operate
normally, see the
troubleshooting information in
the onscreen HP Photosmart
Printer Help.
There are no operator
serviceable parts inside. Refer
servicing to qualified service
personnel.
Use in a well-ventilated area.
Environmental statements
Hewlett-Packard Company is
committed to providing quality
products in an environmentally sound
manner.
Protecting the environment
This printer has been designed with
several attributes to minimize impact
on our environment. For more
information, go to HP's Commitment
to the Environment website at
www.hp.com/hpinfo/globalcitizenship/
environment/.
Ozone production
This product generates no
appreciable ozone gas (O3).
Energy consumption
Energy usage drops significantly
while in ENERGY STAR® mode,
which saves natural resources and
saves money without affecting the
high performance of this product. This
product qualifies for ENERGY STAR,
which is a voluntary program
established to encourage the
development of energy-efficient office
products.
ENERGY
STAR is
a U.S.
registered
mark of
the U.S.
EPA. As an ENERGY STAR partner,
Hewlett-Packard Company has
determined that this product meets
the ENERGY STAR guidelines for
energy efficiency. For more
information, go to www.energystar.gov.
Paper use
This product is suited for the use of
recycled paper according to DIN
19309.
Plastics
Plastic parts over 24 grams (0.88
ounces) are marked according to
international standards that enhance
the ability to identify plastics for
recycling purposes at the end of the
printer life.
Material safety data sheets
Material Safety Data Sheets (MSDS)
can be obtained from the HP website
at www.hp.com/go/msds. Customers
without Internet access should
contact Customer Care.
Recycling program
HP offers an increasing number of
product return and recycling programs
in many countries, and partners with
some of the largest electronics
recycling centers throughout the
world. HP conserves resources by
reselling some of its most popular
products.
This HP product contains lead in the
solder, which may require special
handling at the end of its life.
Contents
1
2
3
4
5
6
Welcome ...............................................................................................................3
Printer parts ...........................................................................................................4
Available accessories ............................................................................................7
Printer menu ..........................................................................................................8
Getting ready to print ........................................................................................13
Loading paper ......................................................................................................13
Choosing the right paper ..............................................................................13
Loading your paper ....................................................................................... 14
Inserting print cartridges ......................................................................................14
Inserting memory cards .......................................................................................17
Supported file formats ..................................................................................18
Inserting a memory card ...............................................................................18
Removing a memory card ............................................................................20
Printing without a computer .............................................................................21
Getting your photos from camera to printer .........................................................21
Deciding which photos to print .............................................................................22
Selecting photos to print ......................................................................................22
Improving the quality of your photos ....................................................................23
Printing your photos .............................................................................................24
Selecting a layout .........................................................................................24
Setting print quality .......................................................................................24
Selecting a print method ...............................................................................24
Getting connected .............................................................................................27
Connecting to other devices ................................................................................27
Connecting through HP Instant Share .................................................................27
Maintaining and transporting the printer .........................................................29
Cleaning and maintaining the printer ...................................................................29
Cleaning the outside of the printer ................................................................29
Cleaning the print cartridge ..........................................................................29
Cleaning the print cartridge contacts ............................................................30
Printing a test page ....................................................................................... 30
Aligning the print cartridge ............................................................................31
Storing the printer and print cartridges ................................................................. 32
Storing the printer .........................................................................................32
Storing the print cartridges ...........................................................................32
Maintaining the quality of photo paper .................................................................33
Storing photo paper ......................................................................................33
Handling photo paper ...................................................................................33
Transporting the printer .......................................................................................33
Troubleshooting ................................................................................................35
Printer hardware problems ..................................................................................35
Printing problems .................................................................................................38
Bluetooth printing problems .................................................................................40
Error messages ...................................................................................................42
HP Photosmart 320 series User's Guide
1
7
Specifications ....................................................................................................45
System requirements ...........................................................................................45
Printer specifications ...........................................................................................46
8 HP Customer Care .............................................................................................49
HP Customer Care by phone ...............................................................................49
Placing a call ................................................................................................50
Return to HP repair service .................................................................................51
a Installing the software .......................................................................................53
Index...........................................................................................................................55
2
HP Photosmart 320 series
1
Welcome
Thank you for purchasing an HP Photosmart 320 series printer! With your new,
compact photo printer you can easily print beautiful photos with or without a computer.
This guide explains how to print photos from the printer without connecting it to a
computer. To learn how to print from your computer, install the printer software and
view the onscreen Help. See Installing the software.
Among other things, you'll learn how to:
Print beautiful borderless photos. See Printing your photos.
Improve the quality of your photos by sharpening them
and improving the contrast. See Improving the quality of
your photos.
Your new printer comes with the following documentation:
●
●
●
Setup Guide: The HP Photosmart 320 series Setup Guide explains how to set up
the printer and print your first photo.
User's Guide: The HP Photosmart 320 series User's Guide is the book you are
reading. This book describes the basic features of the printer, explains how to
use the printer without connecting a computer, and contains hardware
troubleshooting information.
HP Photosmart Printer Help: The onscreen HP Photosmart Printer Help
describes how to use the printer with a computer and contains software
troubleshooting information.
After you have installed the HP Photosmart printer software on your computer, you
can view the onscreen Help:
●
●
Windows PC: From the Start menu, select Programs (in Windows XP, select All
Programs) > HP > Photosmart 320, 370, 7400, 7800, 8100, 8400, 8700 series
> Photosmart Help.
Macintosh: Select Help > Mac Help in the Finder, then select Library > HP
Photosmart Printer Help for Macintosh.
HP Photosmart 320 series User's Guide
3
Chapter 1
Printer parts
Front of printer
1
2
Control panel
Control the basic functions of the printer
from here.
Out tray (closed)
Open this to print, insert a memory card,
or connect a compatible digital camera.
Inside front of printer
1
2
3
4
5
6
7
In tray
Load paper here.
In tray extender
Pull out to support paper.
Paper-width guide
Move to width of current paper to position
the paper properly.
Camera port
Connect a PictBridge digital camera to
this port or the optional HP Bluetooth
wireless printer adapter.
Memory card slots
Insert memory cards into these slots. See
Inserting memory cards.
Print cartridge door
Open to insert or remove a print cartridge.
Out tray (open)
The printer deposits printed photos here.
4
HP Photosmart 320 series
(continued)
Rear of printer
1
2
USB port
Use this port to connect the printer to a
computer or to an HP direct-printing
digital camera.
Power cord connection
Connect the power cord here.
Indicator lights
1
On light
–
–
–
2
Green: printer is on
Green and flashing: printer is busy
Red and flashing: printer requires
attention
Memory Card light
The light indicates the memory card
status. See Inserting memory cards.
Control panel
1
2
3
4
5
HP Photosmart 320 series User's Guide
On
Press to turn the printer on or off.
Print
Press to print selected photos from a
memory card.
Delete
Press to delete the currently selected
photo from a memory card.
Select Photos buttons
Use the arrows to scroll through photos
on a memory card or navigate the printer
menu. Press OK to select a photo or
menu option.
Printer screen
5
Chapter 1
(continued)
6
View photos and menus here.
Cancel
Press to deselect photos, exit a menu, or
stop an action.
Idle screen
1
2
Battery indicator
Displays the charge level of the HP
Photosmart Internal battery, if installed.
Ink level indicator
Displays the ink level of the print cartridge.
Select Photos screen
1
2
3
Selection box
Displays a check mark if photo is selected.
Copies
Displays number of copies to be printed
of the current photo.
Index number
Displays index number of current photo
and total number of photos on the
inserted memory card.
6
HP Photosmart 320 series
(continued)
Internal battery compartment
1
2
3
4
Cover of the battery compartment
Open this cover on the bottom of the
printer to insert the optional HP
Photosmart Internal Battery.
HP Photosmart Internal Battery (Model
number: Q5599A)
A fully-charged battery has sufficient
charge to print approximately 75 photos.
You must purchase the battery separately.
Internal battery compartment
Insert the optional HP Photosmart
Internal Battery here.
Battery compartment button
Slide to release the compartment cover.
Available accessories
There are several accessories available for the HP Photosmart 320 series printer that
enhance its portability for printing anywhere, anytime. The appearance of the
accessories may vary from what is shown.
Accessory name
Description
The HP Photosmart Internal Battery lets
you take the printer with you wherever
you go. (Model: Q5599A)
HP Photosmart Internal Battery
HP Photosmart 320 series User's Guide
7
Chapter 1
(continued)
Accessory name
Description
The HP Photosmart Automobile DC
Adapter lets you plug into your
automobile for backup power and to
recharge an optional HP Photosmart
Internal Battery inserted in the printer.
(Model: Q3448A)
HP Photosmart Automobile DC
Adapter
The lightweight, durable HP Photosmart
Carrying Case for Compact Printers
holds and protects everything needed
for hassle-free printing on the go.
(Model: Q3424A)
HP Photosmart Carrying Case for
Compact Printers
The HP Bluetooth® wireless printer
adapter goes into the camera port on
the front of the printer and lets you use
Bluetooth wireless technology for
printing. (Model: Q3395A)
HP Bluetooth® wireless printer
adapter
Printer menu
The printer menu contains many features for adjusting defaults, controlling print
quality, and using special effects.
To use the printer menu
1
2
If there is a memory card in the printer, remove it.
Press or on the printer control panel to access the printer menu.
To navigate the printer menu
●
●
●
8
Press or to scroll through the menu options displayed on the printer screen.
Menu items that are not accessible are grayed out.
Press OK to open a menu or select an option.
Press Cancel to exit the current menu.
HP Photosmart 320 series
Printer menu structure
Top level menu
Submenus/options
Additional submenus/
options
Tools
Print quality
Print quality:
●
●
Best (default)
Normal
Print sample page
(Sample page for use in a
demo of the printer.)
Print test page
Page of information about
the printer: serial number,
firmware version, and so
on.)
Clean cartridge
Continue to second level
cleaning?
●
●
Yes
No
Continue to third level
cleaning?
●
●
Yes
No
Align printer
Bluetooth
Device address
The Bluetooth menu
options are needed if you
equip the printer with the
optional HP Bluetooth
wireless printer adapter.
HP Photosmart 320 series User's Guide
Device address:
(Some devices with
Bluetooth wireless
technology require you to
enter the address of the
device they are trying to
locate. This menu option
shows the device address.)
Device name
(You can select a device
name for the printer that
appears on other devices
with Bluetooth wireless
technology when they
locate the printer.)
Passkey
(You can assign a
Bluetooth numerical
passkey to the printer that
users of devices with
Bluetooth wireless
technology trying to locate
9
Chapter 1
Printer menu structure (continued)
Top level menu
Submenus/options
Additional submenus/
options
the printer must enter
before they can print, if
the printer Bluetooth
Security level is set to
High. The default
passkey is 0000.)
Accessibility
Accessibility:
●
●
Visible to all
Not visible
When Accessibility
is set to Not visible,
only devices that
know the device
address can print to it.
(You can set the
Bluetooth-equipped
printer to be visible or
invisible to other devices
with Bluetooth wireless
technology by changing
this accessibility option.)
Security level
Security Level:
●
●
Low
(The printer does not
require users of other
devices with
Bluetooth wireless
technology to enter
the printer passkey)
High
(The printer does
require users of other
devices with
Bluetooth wireless
technology to enter
the printer passkey)
Reset Bluetooth options
Help
10
Cartridges
Press
or
to scroll
Photo sizes
Press
or
to scroll
Paper loading
Press
or
to scroll
HP Photosmart 320 series
Printer menu structure (continued)
Top level menu
Submenus/options
Additional submenus/
options
Paper jam
Camera connect
Preferences
Smart focus
Smart focus:
●
●
Digital flash
Digital Flash:
●
●
Date/time
On
Off (default)
Date/time stamp:
●
●
●
Colorspace
On (default)
Off
Date/time
Date only
Off (default)
Choose colorspace:
●
●
●
Adobe RGB
sRGB
Auto-select (default)
The Auto-select default
tells the printer to use the
Adobe RGB colorspace, if
available. The printer
defaults to sRGB if Adobe
RGB is not available.
Borderless
Turn borderless printing:
●
●
Passport photo mode
On (default)
Off
Turn passport photo mode:
●
●
On
Off (default)
Select Size:
Passport mode tells the
printer to print all photos
in the selected passport
photo size. Each page
contains one photo.
However, if you specify
several copies of the
same photo, they all
appear on the same page
HP Photosmart 320 series User's Guide
11
Chapter 1
Printer menu structure (continued)
Top level menu
Submenus/options
Additional submenus/
options
(if enough space is
available).
Auto-save
Turn auto-save:
●
●
On (default)
Off
The default setting tells
the printer to transfer all
photos from a memory
card to the computer,
whenever you first insert
a card. The printer must
be connected to a
computer where you have
already installed the HP
Photosmart software. See
Installing the software.
Preview animation
Turn preview animation:
●
●
On (default)
Off
(Select Off to bypass
printer screen animations.)
Restore defaults
Restore original factory
preferences:
●
●
Language
Yes
No
Select language:
Select country/region:
12
HP Photosmart 320 series
2
Getting ready to print
Before you can begin printing, there are three easy procedures you need to become
familiar with:
●
●
●
Loading paper (see Loading paper)
Inserting print cartridges (see Inserting print cartridges)
Inserting a memory card (see Inserting memory cards)
You must load paper and insert a print cartridge before inserting a memory card.
Loading paper
Learn how to choose the right paper for your print job and how to load it into the In
tray for printing.
Choosing the right paper
For a list of available HP-designed inkjet paper, or to purchase supplies, go to:
●
●
●
●
www.hpshopping.com (U.S.)
www.hp.com/go/supplies (Europe)
www.hp.com/jp/supply_inkjet (Japan)
www.hp.com/paper (Asia/Pacific)
To get the best results from the printer, choose from these high-quality HP photo
papers.
To print
Use this paper
High-quality, long-lasting prints and
enlargements
HP Premium Plus photo paper
Medium-to-high-resolution images from
scanners and digital cameras
HP Premium photo paper
Casual and business photos
HP photo paper
HP Everyday photo paper
To keep your paper in good condition for printing:
●
●
●
Store unused paper in its original package.
Keep the paper flat in a cool, dry place. If the corners curl, place the paper in a
plastic bag and gently bend it in the opposite direction until it lies flat.
Hold photo paper by the edges to avoid smears.
HP Photosmart 320 series User's Guide
13
Chapter 2
Loading your paper
Paper loading tips:
●
●
●
You can print photos on photo paper, index cards, L-size cards, or Hagaki cards.
Before loading paper, slide out the paper-width guide to make room for the paper.
Load only one type and size of paper at a time. Do not mix paper types or sizes in
the In tray.
Paper type
How to load
10 x 15 cm (4 x 6
inch) photo paper
Index cards
L-size cards
Hagaki cards
1
2
3
4
Open the In tray and
pull out the In tray
extender.
Load up to 20 sheets
of paper with the print
side or glossy side
facing towards you. If
you are using tabbed
paper, insert it so the
tabbed end feeds in
last.
Adjust the paperwidth guide to fit
close to the edge of
the paper without
bending the paper.
Open the Out tray to
prepare for printing.
1
2
3
In tray
Paper-width guide
Out tray
Inserting print cartridges
Your HP Photosmart 320 series printer can print color and black-and-white photos.
HP provides different types of print cartridges so you can choose the best cartridge for
your project. The cartridge number varies by country/region. Choose the correct
cartridge number for your country/region.
For optimum printing results, HP recommends using only HP print cartridges. Inserting
a cartridge that is not in this table may invalidate the printer warranty.
Use the right print cartridge
14
To print…
Insert this print cartridge in the
cartridge cradle
Full-color photos
Tri-color (7 ml) HP #95 (North America,
Latin America, Asia Pacific), #135
HP Photosmart 320 series
Use the right print cartridge (continued)
To print…
Insert this print cartridge in the
cartridge cradle
(Eastern Europe, Russia, Middle East,
Africa, Japan), #343 (Western Europe),
#855 (China, India)
Tri-color (14 ml) HP #97 (North America,
Latin America, Asia Pacific), #134
(Eastern Europe, Russia, Middle East,
Africa, Japan), #344 (Western Europe),
#857 (China, India)
Black and white photos
Gray Photo HP #100 (worldwide)
Sepia or antique photos
Tri-color (7 ml) HP #95 (North America,
Latin America, Asia Pacific), #135
(Eastern Europe, Russia, Middle East,
Africa, Japan), #343 (Western Europe),
#855 (China, India)
Tri-color (14 ml) HP #97 (North America,
Latin America, Asia Pacific), #134
(Eastern Europe, Russia, Middle East,
Africa, Japan), #344 (Western Europe),
#857 (China, India)
Text and colored line drawings
Tri-color (7 ml) HP #95 (North America,
Latin America, Asia Pacific), #135
(Eastern Europe, Russia, Middle East,
Africa, Japan), #343 (Western Europe),
#855 (China, India)
Tri-color (14 ml) HP #97 (North America,
Latin America, Asia Pacific), #134
(Eastern Europe, Russia, Middle East,
Africa, Japan), #344 (Western Europe),
#857 (China, India)
Caution Check that you are using the correct print cartridge. Also, note that
HP does not recommend modifying or refilling HP cartridges. Damage that
results from modifying or refilling HP cartridges is not covered by the HP
warranty.
For best print quality, HP recommends that you install all retail print cartridges before
the date stamped on the box.
HP Photosmart 320 series User's Guide
15
Chapter 2
Insert or replace the print cartridge
Prepare the printer and cartridge
1
2
3
Make sure the power is on and you
have removed the cardboard from
inside the printer.
Open the print cartridge access
door of the printer.
Remove the bright pink tape from
the cartridge.
Remove the pink tape
Do not touch here
Insert the cartridge
1
2
3
If you are replacing a cartridge,
push down and pull outward on the
cartridge in the cradle to remove it.
Hold the replacement cartridge with
the label on top. Slide the cartridge
at a slight upward angle into the
cradle so the copper-colored
contacts go in first. Push the
cartridge until it snaps into place.
Close the print cartridge access door.
The idle screen of the printer displays an
icon showing the approximate ink level
for the installed cartridge (100%, 75%,
50%, 25%, and nearly empty). No inklevel icon appears if the cartridge is not
a genuine HP cartridge.
16
HP Photosmart 320 series
Insert or replace the print cartridge (continued)
Each time you install or replace a print
cartridge, a message appears on the
printer screen asking you to load plain
paper so the printer can align the
cartridge. This ensures high-quality prints.
Align the cartridge
1
2
Load paper in the In tray and press
OK.
Follow the onscreen instructions to
align the cartridge.
See Aligning the print cartridge.
When you are not using a print cartridge
Whenever you remove a print cartridge
from the printer, store it in a print
cartridge protector. The cartridge
protector keeps the ink from drying out.
Storing the cartridge improperly can
cause the cartridge to malfunction.
In some countries/regions the cartridge
protector is not included with the printer,
but comes with the Gray Photo cartridge
that can be purchased separately. In
other countries/regions, the protector is
included with the printer.
➔
To insert a cartridge into the
cartridge protector, slide the
cartridge into the protector at a
slight angle and snap it securely
into place.
Inserting memory cards
After you have taken pictures with a digital camera, you can remove the memory card
from the camera and insert it into the printer to view and print your photos. The printer
can read the following types of memory cards: CompactFlash™, Memory Sticks,
MultiMediaCard™, Secure Digital™, SmartMedia™, and xD-Picture Card™. The
Microdrive is not supported.
HP Photosmart 320 series User's Guide
17
Chapter 2
Caution Using any other type of memory card may damage the memory card
and the printer.
To learn about other ways of transferring photos from a digital camera to the printer,
see Connecting to other devices.
Supported file formats
The printer can recognize and print the following file formats directly from a memory
card: JPEG, uncompressed TIFF, Motion JPEG AVI, Motion JPEG Quicktime, and
MPEG-1. If your digital camera saves photos and video clips in other file formats,
save the files to your computer and print them using a software application. For more
information, see the onscreen Help.
Inserting a memory card
Find your memory card in the following table and use the instructions to insert the
card into the printer.
Guidelines:
●
●
Insert only one memory card at a time.
Gently push the memory card into the printer until it stops. The memory card
does not insert all the way into the printer; do not try to force it.
Caution 1 Inserting the memory card any other way may damage the card
and the printer.
When the memory card is inserted correctly, the Memory Card light flashes
and then remains solid green.
Caution 2 Do not pull out a memory card while the Memory Card light is
flashing. For more information, see Removing a memory card.
Memory card
Slot
How to insert the memory card
CompactFlash
Top right slot
●
MultiMediaCard
18
Bottom right slot
●
Front label faces up, and if the label has an
arrow, the arrow points toward the printer
Edge with metal pinholes goes into the printer first
●
●
Angled corner is on the right
Metal contacts face down
HP Photosmart 320 series
(continued)
Memory card
Slot
How to insert the memory card
Secure Digital
Bottom right slot
●
●
Angled corner is on the right
Metal contacts face down
SmartMedia
Upper portion of
the top left
double slot
●
●
Angled corner is on the left
Metal contacts face down
Memory Stick
Bottom left slot
●
●
●
Angled corner is on the left
Metal contacts face down
If you are using a Memory Stick Duo™ or Memory
Stick PRO Duo™ card, attach the adapter that
came with the card before you insert the card into
the printer
HP Photosmart 320 series User's Guide
19
Chapter 2
(continued)
Memory card
Slot
How to insert the memory card
xD-Picture Card
Lower right
portion of the top
left double slot
●
●
Curved side of card points toward you
Metal contacts face down
Removing a memory card
Wait until the Memory Card light stops flashing, then gently pull the memory card to
remove it from the printer.
Caution Do not pull out a memory card while the Memory Card light is
flashing. A flashing light means that the printer is accessing the memory card.
Removing a memory card while it is being accessed may damage the printer
and the memory card or corrupt the information on the memory card.
20
HP Photosmart 320 series
3
Printing without a computer
The HP Photosmart 320 series printer lets you print amazing photos without even
going near a computer. After setting up the printer using the instructions in the HP
Photosmart 320 series Setup Guide, refer to these steps for start-to-finish printing.
Getting your photos from camera to printer
Use these steps for start-to-finish printing in minutes!
Step 1
Insert a memory card
See Inserting memory cards.
Step 2
Decide which photos to print
See Deciding which photos to print.
Step 3
Load paper
See Loading paper.
Step 4
Insert the right print cartridges
See Inserting print cartridges.
HP Photosmart 320 series User's Guide
21
Chapter 3
(continued)
Use these steps for start-to-finish printing in minutes!
Step 5
Select photos to print
See Selecting photos to print.
Step 6
Improve the quality of your photos
See Improving the quality of your photos.
Step 7
Print your photos
See Printing your photos.
Deciding which photos to print
To view photos
Do this
One by one
1
2
Insert a memory card.
Press or to view the photos
one by one. Press and hold the
button to view the photos rapidly.
When you reach the last photo in
either direction, the display returns
to the first or last photo and
continues.
1
2
Insert a memory card.
Select Print Index Page, then
press OK.
The printer prompts you to select a print
layout when you insert a memory card.
Use the or to select a layout, then
press OK. See Selecting a layout.
Print a photo index
A photo index shows thumbnail views
and index numbers for up to 2000
photos on a memory card. Use an index
card instead of photo paper to cut costs.
Selecting photos to print
22
If you want to…
Do this
Print one photo
1
Insert a memory card and select a
print layout.
HP Photosmart 320 series
(continued)
If you want to…
Print more than one copy of a photo
Do this
2
Press Print to print the photo
displayed on the printer screen,
using the current print layout.
1
Insert a memory card and select a
print layout.
Press OK once for each copy of the
current photo you want to print.
Press Cancel to decrease the
number of copies by one or
deselect a selected photo.
Press Print.
2
3
Print several photos
1
2
3
Print all photos
1
2
3
Insert a memory card and select a
print layout.
Press OK to select each photo you
want to print.
Press Print.
Insert a memory card and select a
print layout.
Press and hold OK until a message
tells you that all the photos on the
card have been selected.
Press Print.
Improving the quality of your photos
The HP Photosmart 320 series printer provides a variety of preferences and effects
that can improve the quality of your printed photos. The settings do not change your
original photo. They only affect printing.
Problem and solution
How to do it
Blurred photos
1
Smart Focus
Sharpen blurred photos. It is turned on
by default. Use these instructions to turn
it on if it is currently off. This preference
affects all printed photos.
2
3
4
Photos with poor lighting and contrast 1
Digital Flash
HP Photosmart 320 series User's Guide
2
3
Remove any memory cards, then
press or .
Select Preferences, then press OK.
Select Smart Focus, then press OK.
Press or to highlight On, then
press OK.
Remove any memory cards, then
press or .
Select Preferences, then press OK.
Select Digital Flash, then press OK.
23
Chapter 3
(continued)
Problem and solution
How to do it
Improve the lighting and contrast in
prints. This preference affects all printed
photos.
4
Press or
press OK.
to highlight On, then
Printing your photos
Printing your photos involves three steps: selecting a print layout, setting print quality,
and selecting a print method.
Selecting a layout
The printer prompts you to select a print layout each time you insert a memory card.
Layout options
Do this
1
2
Insert a memory card.
Use or to select a layout:
–
–
–
3
Print one photo per sheet
Print two photos per sheet
Print four photos per sheet
Press OK.
The printer may rotate your photos
to fit the layout.
Setting print quality
Best quality is the default and produces the highest quality photos. Normal quality
conserves ink and prints faster.
To change the print quality to Normal
1
2
3
4
Remove any memory cards, then press
Select Tools, then press OK.
Select Print Quality, then press OK.
Select Normal, then press OK.
or
.
Print quality reverts to Best after the next print job.
Selecting a print method
The HP Photosmart 320 series printer lets you print from a memory card or directly
from a digital camera.
24
Print from
Do this
Memory card
To print unmarked photos
Print digital photos that are stored on a
memory card. The photos can be
1
Insert a memory card.
HP Photosmart 320 series
(continued)
Print from
Do this
unmarked or camera-selected (Digital
Print Order Format, or DPOF). Printing
from a memory card requires no
computer and does not drain your digital
camera's batteries. See Inserting
memory cards.
2
3
Select one or more photos. See
Selecting photos to print.
Press Print.
To print camera-selected photos
1
2
Insert a memory card that contains
camera-selected (DPOF) photos.
Select Yes when the printer asks
you whether you want to print the
camera-selected photos, then press
OK.
Digital camera
To print from a PictBridge camera
Print beautiful photos from a PictBridge
or HP direct-printing digital camera
without using a computer. See Getting
connected.
1
2
When you print directly from a digital
camera, the printer uses the settings
that you selected on the camera. For
more information on using cameraselected photos, see the documentation
that came with the camera.
Turn on the PictBridge digital
camera and select the photos you
want to print.
Make sure the camera is in
PictBridge mode, then connect it to
the camera port on the front of the
printer using the USB cable that
came with the camera.
Once the printer recognizes the
PictBridge camera, the selected
photos print.
To print from an HP direct-printing
camera
1
2
3
HP Photosmart 320 series User's Guide
Turn on the HP direct-printing digital
camera and select the photos you
want to print.
Connect the camera to the USB
port on the back of the printer using
the USB cable that came with the
camera.
Follow the instructions on the
camera screen.
25
Chapter 3
26
HP Photosmart 320 series
4
Getting connected
Use the printer to stay connected to other devices and people.
Connecting to other devices
This printer offers several ways of connecting to computers or other devices. Each
connection type lets you do different things.
Connection type and what you need
What this lets you do
USB
●
●
●
A Universal Serial Bus (USB) 2.0
full-speed compliant cable 3 meters
(10 feet) or less in length. For
instructions about connecting the
printer with a USB cable, see the
Setup Guide.
A computer with Internet access (to
use HP Instant Share).
PictBridge
A PictBridge-compatible digital camera
and a USB cable.
Connect the camera to the camera port
on the front of the printer.
Bluetooth
The optional HP Bluetooth wireless
printer adapter.
If the printer came with this accessory or
you have purchased it separately, see
the accompanying documentation and
the onscreen Help for instructions.
●
●
●
Print from your computer to the
printer.
Save photos from a memory card
inserted in the printer to your
computer where you can enhance
or organize them in the HP Image
Zone software.
Share photos through HP Instant
Share.
Print directly from an HP
Photosmart direct-printing digital
camera to the printer. For more
information, see Printing without a
computer and the camera
documentation.
Print directly from a PictBridgecompatible digital camera to the printer.
For more information, see Printing
without a computer and the camera
documentation.
Print from any device with Bluetooth
wireless technology to the printer.
If you connect the optional HP Bluetooth
wireless printer adapter to the printer
through the camera port, be sure to set
the Bluetooth printer menu options as
needed. See Printer menu.
Connecting through HP Instant Share
Use HP Instant Share to share photos with friends and relatives using e-mail, online
albums, or an online photo finishing service. The printer must be connected through a
USB cable to a computer with Internet access and have all the HP software installed.
If you try to use HP Instant Share and do not have all the required software installed
HP Photosmart 320 series User's Guide
27
Chapter 4
or configured, a message prompts you through the required steps. See Installing the
software.
To use HP Instant Share to send photos
1
2
3
Insert a memory card that contains the photos you want to share.
Follow the prompts on your computer to save the photos to the computer.
Use the HP Instant Share features of the HP Image Zone software to share your
photos with others.
See the onscreen HP Image Zone Help for information about using HP Instant Share.
28
HP Photosmart 320 series
5
Maintaining and transporting
the printer
The HP Photosmart 320 series printer requires very little maintenance. Follow the
guidelines in this chapter to extend the life span of the printer and printing supplies,
and to ensure that the photos you print are always of the highest quality.
Cleaning and maintaining the printer
Keep the printer and print cartridges clean and well maintained using the simple
procedures in this section.
Cleaning the outside of the printer
1
2
3
Turn off the printer, then disconnect the power cord from the back of the printer.
If you installed the optional HP Photosmart Internal Battery in the printer, remove
it, then replace the battery compartment cover.
Wipe the outside of the printer with a soft cloth that has been lightly moistened
with water.
Caution 1 Do not use any type of cleaning solution. Household cleaners and
detergents may damage the printer’s finish.
Caution 2 Do not clean the interior of the printer. Keep all fluids away from
the interior.
Cleaning the print cartridge
If you notice white lines or single-color streaks on the photos you print, the print
cartridge may need to be cleaned. Do not clean the cartridge more often than
necessary, since cleaning uses up ink.
1
Remove any memory cards from the memory card slots.
Caution Do not pull out a memory card while the Memory Card light is
flashing. For more information, see Removing a memory card.
2
3
4
5
6
7
Press or to display the printer menu.
Select Tools, then press OK.
Select Clean cartridge, then press OK.
Following the directions on the printer screen, load paper so the printer can print
a test page after cleaning the cartridge. Use plain paper or index cards to
conserve photo paper.
Press OK to begin cleaning the print cartridge.
When the printer finishes cleaning the cartridge and prints a test page, check the
test page and select from the following options:
–
–
If the test page has white streaks or missing colors, the print cartridge needs
to be cleaned again. Select Yes, then press OK.
If the print quality of the test page looks good, select No, then press OK.
HP Photosmart 320 series User's Guide
29
Chapter 5
You can clean the cartridge up to three times. Each successive cleaning is more
thorough and uses more ink.
If you complete all three levels of cleaning using this procedure and you still notice
white streaks or missing colors on the test page, you may need to clean the print
cartridge copper-colored contacts. For more information, see the following section.
Note If the cartridge or printer has been recently dropped, you may also see white
streaks or missing colors in your prints. This problem is temporary and clears
up within 24 hours.
Cleaning the print cartridge contacts
If you use the printer in a dusty environment, debris may accumulate on the coppercolored contacts and cause printing problems.
To clean the print cartridge contacts:
1
Gather the following items to clean the contacts:
–
–
2
3
Distilled water (tap water may contain contaminants that can damage the
print cartridge)
Cotton swabs or other soft, lint-free material that will not stick to the print
cartridge
Open the print cartridge door.
Remove the print cartridge and place it on a piece of paper with the ink nozzle
plate facing up. Be careful not to touch the copper-colored contacts or the ink
nozzle plate with your fingers.
Caution Do not leave the print cartridge outside the printer for more than
30 minutes. Ink nozzles exposed to the air longer than this may dry out
and cause printing problems.
4
5
Lightly moisten a cotton swab with distilled water and squeeze any excess water
from the swab.
Gently wipe the copper-colored contacts with the cotton swab.
Caution Do not touch the ink nozzle. Touching the ink nozzle will result
in clogs, ink failure, and bad electrical connections.
6
7
Repeat steps 4–5 until no ink residue or dust appears on a clean swab.
Insert the print cartridge in the printer, then close the print cartridge door.
Printing a test page
You can print a test page to check the condition of the print cartridge.
1
Remove any memory cards from the memory card slots.
Caution Do not pull out a memory card while the Memory Card light is
flashing. For more information, see Removing a memory card.
2
3
4
30
Press or to display the printer menu.
Select Tools, then press OK.
Select Print test page, then press OK.
HP Photosmart 320 series
5
Following the directions on the printer screen, load paper so the printer can print
a test page. Use plain paper or index cards to conserve photo paper.
Press OK to begin printing the test page.
6
The test page contains the following information:
HP Photosmart 320 series
1.
2.
3.
4.
5.
6.
Serial Number: CN3C011006IU
Service ID: 08218
FW Revision: EF1L415A
Total Engine Page Count: 14
Error Code: 00B7E5E8
Pen Status Information
6a. Pen Type: ???
6b. Pen ID: 0 0x000000 00000000000000000
7. Bluetooth Information
7a. Bluetooth Device Address: Bluetooth Radio Not Present
7b. Bluetooth Device Name:
Photosmart 320 series S/N CN3C011006IU
7c. Accessibility Mode:
Visible to all
7d. Authenication:
Low
7e. PassKey:
0000
7f. Number of Trusted Devices: 0
8. Power/Battery Information
8a. Battery Support: Implemented
8b. Battery Status: Not Installed
8c. Power Mode:
Adapter
1
Image print quality. If this looks good, photos should print well.
2
Ink nozzle quality. If there are white streaks in the solid bars, try cleaning the print
cartridge. For more information, see Cleaning the print cartridge.
3
Estimated ink level. This indicator shows how much ink is left in the print cartridge.
4
Diagnostic information. Use this information when working with HP Customer Care to
solve printing problems.
Aligning the print cartridge
The first time you install a print cartridge in the printer, the printer aligns it
automatically. However, if colors in printouts are misaligned, or if the alignment page
does not print correctly when you installed a new print cartridge, use the following
procedure to align the print cartridge.
1
Remove any memory cards from the memory card slots.
Caution Do not pull out a memory card while the Memory Card light is
flashing. For more information, see Removing a memory card.
2
3
4
5
Press or to display the printer menu.
Select Tools, then press OK.
Select Align cartridge, then press OK.
A message appears on the printer screen reminding you to load plain paper.
Load paper so the printer can print a calibration page. Use plain paper or index
cards to conserve photo paper.
HP Photosmart 320 series User's Guide
31
Chapter 5
6
Press OK to begin aligning the print cartridge.
When the printer finishes aligning the cartridge, it prints an alignment page to
confirm that the alignment was successful.
–
–
The check marks verify that the print cartridge is installed correctly and
functioning properly.
If an “x” appears to the left of any of the bars, align the print cartridge again.
If the “x” still appears, replace the print cartridge.
Storing the printer and print cartridges
Protect the printer and print cartridges by storing them properly when you are not
using them.
Storing the printer
The printer is built to withstand long or short periods of inactivity.
●
●
●
Close the In and Out tray doors when the printer is not in use.
Store the printer indoors out of direct sunlight in a place without temperature
extremes.
If the printer and print cartridge have not been used for one month or more, clean
the print cartridge before printing. For more information, see Cleaning the print
cartridge.
Storing the print cartridges
When you store or transport the printer, always leave the active print cartridge inside
the printer. The printer stores the print cartridge in a protective cap during the powerdown cycle.
32
HP Photosmart 320 series
Caution Make sure the printer completes its power-down cycle before you
unplug the power cord or remove the internal battery. This allows the printer to
store the print cartridge properly.
Follow these tips to help maintain HP print cartridges and ensure consistent print
quality:
●
●
●
When you remove a print cartridge from the printer, store it in a print cartridge
protector to prevent the ink from drying out.
In some countries/regions the cartridge protector is not included with the printer,
but comes with the Gray Photo cartridge that can be purchased separately. In
other countries/regions, the protector is included with the printer.
Keep all unused print cartridges in their original sealed packages until they are
needed. Store print cartridges at room temperature (15–35 degrees C or 59–95
degrees F).
Do not remove the plastic tape covering the ink nozzles until you are ready to
install the print cartridge in the printer. If the plastic tape has been removed from
the print cartridge, do not attempt to reattach it. Reattaching the tape damages
the print cartridge.
Maintaining the quality of photo paper
For best results with photo paper, follow the guidelines in this section.
Storing photo paper
●
●
●
Store the photo paper in its original packaging or in a resealable plastic bag.
Store the packaged photo paper on a flat, cool, and dry surface.
Return unused photo paper to the plastic bag. Paper left in the printer or exposed
to the elements may curl.
Handling photo paper
●
●
Always hold photo paper by the edges to avoid fingerprints.
If the photo paper has curled edges, place it in its plastic storage bag and gently
bend it in the opposite direction of the curl until the paper lies flat.
Transporting the printer
It's easy to transport and set up the printer almost anywhere. Take it with you on
vacations and to family gatherings and social events to instantly print and share
photos with family and friends.
To make it even easier to print on the go, you can purchase these accessories:
●
●
●
HP Photosmart Internal Battery: Power the printer with a rechargeable battery
so you can print anywhere.
HP Photosmart Automobile DC Adapter: Power the printer from the cigarette
lighter in a car.
HP Photosmart Carrying Case for compact photo printers: Carry the printer and
printing supplies together in this convenient travel case.
HP Photosmart 320 series User's Guide
33
Chapter 5
To transport the printer:
1
2
3
Turn off the printer.
Remove any memory cards from the memory card slots.
Remove all paper from the In and Out trays, then close the In and Out tray doors.
Note Make sure the printer completes its power-down cycle before you unplug
the power cord. This allows the printer to store the print cartridge properly.
4
5
6
Unplug the power cord.
If the printer is connected to a computer, disconnect the USB cable from the
computer.
Always carry the printer upright.
Note Do not remove the print cartridge when transporting the printer.
Make sure to bring the following items with you:
●
●
●
●
●
●
Paper
Power cord
Digital camera or a memory card containing photos
Extra print cartridges (if you plan to print a lot of photos)
Optional printer accessories you plan to use, such as the battery, DC adapter, or
HP Bluetooth wireless printer adapter
If you are going to connect the printer to a computer, bring the USB cable and HP
Photosmart printer software CD
Note If you do not take the printer user guide with you, be sure to write down the
correct pen numbers for the country/region you plan to visit or purchase
enough print cartridges before you go.
34
HP Photosmart 320 series
6
Troubleshooting
The HP Photosmart printer is designed to be reliable and easy to use. This section
answers frequently asked questions about using the printer and printing without a
computer. It contains information about the following topics:
●
●
●
●
Printer hardware problems. See Printer hardware problems.
Printing problems. See Printing problems.
Bluetooth printing problems. See Bluetooth printing problems.
Error messages. See Error messages.
For troubleshooting information about using the printer software and printing from a
computer, see the onscreen HP Photosmart Printer Help. For information about
viewing the onscreen Printer Help, see Welcome.
Printer hardware problems
Before contacting Customer Care, read this section for troubleshooting tips or go to
the online support services at www.hp.com/support.
Note If you want to connect the printer to a computer, HP recommends using a USB
cable of less than 3 meters (10 feet) in length to minimize injected noise due to
potentially high electromagnetic fields.
The Status light is flashing green but the printer is not printing.
●
●
If the printer is turned on, it is busy processing information. Wait for it to finish.
If the printer is turned off, and the optional HP Photosmart Internal Battery is
installed, the battery is charging.
The Status light is flashing red.
The printer requires attention. Try the following:
●
●
Check the printer screen for instructions. If you have a digital camera connected
to the printer, check the camera screen for instructions. If the printer is connected
to a computer, check the computer monitor for instructions.
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer:
Unplug the printer power cord. Wait about 10 seconds, then plug the power cord
back in. Turn on the printer.
If the optional HP Photosmart Internal Battery is installed in the printer:
Unplug the printer power cord, if it is plugged in. Open the battery compartment
cover and remove the battery. Wait about 10 seconds, then reinstall the battery. If
desired, plug in the power cord. Turn on the printer.
The Status light flashed amber briefly after I turned the printer off.
This is a normal part of the power-down process. It does not indicate a problem with
the printer.
HP Photosmart 320 series User's Guide
35
Chapter 6
The Status light is flashing amber.
A printer error has occurred. Try the following:
●
●
Check the printer screen for instructions. If you have a digital camera connected
to the printer, check the camera screen for instructions. If the printer is connected
to a computer, check the computer monitor for instructions.
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer:
Unplug the printer power cord. Wait about 10 seconds, then plug the power cord
back in. Turn on the printer.
If the optional HP Photosmart Internal Battery is installed in the printer:
Unplug the printer power cord, if it is plugged in. Open the battery compartment
cover and remove the battery. Wait about 10 seconds, then reinstall the battery. If
desired, plug in the power cord. Turn on the printer.
●
If the Status light continues to flash amber, go to www.hp.com/support or contact
Customer Care.
The buttons on the control panel do not respond.
A printer error has occurred. Wait for about a minute to see if the printer resets. If it
does not, try the following:
●
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer:
Unplug the printer power cord. Wait about 10 seconds, then plug the power cord
back in. Turn on the printer.
If the optional HP Photosmart Internal Battery is installed in the printer:
Unplug the printer power cord, if it is plugged in. Open the battery compartment
cover and remove the battery. Wait about 10 seconds, then reinstall the battery. If
desired, plug in the power cord. Turn on the printer.
●
If the printer does not reset, and the control panel buttons still do not respond, go
to www.hp.com/support or contact Customer Care.
The printer does not find and display the photos on my memory card.
Try the following:
●
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer:
Unplug the printer power cord. Wait about 10 seconds, then plug the power cord
back in. Turn on the printer.
36
HP Photosmart 320 series
If the optional HP Photosmart Internal Battery is installed in the printer:
Unplug the printer power cord, if it is plugged in. Open the battery compartment
cover and remove the battery. Wait about 10 seconds, then reinstall the battery. If
desired, plug in the power cord. Turn on the printer.
●
The memory card may contain file types the printer cannot read directly from the
memory card.
–
–
Save the photos to a computer, then print them from the computer. For more
information, see the documentation that came with the camera and the
onscreen HP Photosmart Printer Help.
The next time you take photos, set the digital camera to save them in a file
format the printer can read directly from the memory card. For a list of
supported file formats, see Printer specifications. For instructions on setting
the digital camera to save photos in specific file formats, see the
documentation that came with the camera.
The printer is plugged in, but it will not turn on.
●
The printer may have drawn too much power.
If the optional HP Photosmart Internal Battery is not installed in the printer:
Unplug the printer power cord. Wait about 10 seconds, then plug the power cord
back in. Turn on the printer.
If the optional HP Photosmart Internal Battery is installed in the printer:
Unplug the printer power cord, if it is plugged in. Open the battery compartment
cover and remove the battery. Wait about 10 seconds, then reinstall the battery. If
desired, plug in the power cord. Turn on the printer.
●
The printer may be plugged into a power strip that is turned off. Turn on the
power strip, then turn on the printer.
The optional HP Photosmart Internal Battery is installed in the printer, but the
printer will not turn on using battery power.
●
●
The battery may need to be charged. Plug in the printer power cord to charge the
battery. The Status light flashes green to indicate that the battery is charging.
If the battery is charged, try removing and reinstalling the battery.
The optional HP Photosmart Internal Battery is installed in the printer, but it will
not charge.
●
●
●
●
Open the battery compartment cover. Remove the battery and reinstall it. For
more information on how to install the battery, see the documentation that came
with the battery.
Check that the printer power cord is securely connected to both the printer and
the power source. When the printer is turned off, the Status light flashes green to
indicate that the battery is charging.
Turn on the printer. The battery charging icon, a lightning bolt, flashes above the
battery icon on the printer screen to indicate that the battery is charging.
An empty battery should fully charge in approximately four hours when the printer
is not in use. If the battery still does not charge, replace it.
HP Photosmart 320 series User's Guide
37
Chapter 6
The optional HP Photosmart Internal Battery low-power warning appears. I plug
the printer into my automobile with the optional HP Photosmart Automobile DC
Adapter, but the printer does not recognize the new power source.
●
●
●
Before you plug the printer into the automobile with the adapter turn the printer off.
Plug the printer into the automobile with the HP Photosmart Automobile DC
Adapter.
Turn the printer on.
The printer makes noises when I turn it on, or starts making noises on its own
after it has been sitting unused for a while.
The printer may make noises after long periods of inactivity (approximately 2 weeks),
or when its power supply has been interrupted and then restored. This is normal
operation—the printer is performing an automatic maintenance procedure to ensure
that it produces the best quality output.
Printing problems
Before contacting Customer Care, read this section for troubleshooting tips or go to
the online support services at www.hp.com/support.
The printer does not print borderless photos when I print from the control
panel.
The borderless printing option may be turned off. To turn on borderless printing, follow
these steps:
1
Remove any memory cards from the memory card slots.
Caution Do not pull out a memory card while the Memory Card light is
flashing.
2
3
4
5
Press OK on the control panel to display the printer menu.
Select Preferences, then press OK.
Select Borderless, then press OK.
Select On, then press OK.
Paper does not feed into the printer correctly.
●
●
●
●
●
●
38
Make sure that the paper-width guide fits close to the edge of the paper without
bending the paper.
There may be too much paper loaded in the In tray. Remove some paper and try
printing again.
If sheets of photo paper stick together, try loading one sheet at a time.
If you are using the printer in an extremely high or low humidity environment,
insert the paper as far as it will go into the In tray, and load one sheet of photo
paper at a time.
If you are using photo paper that is curled, place the paper in a plastic bag and
gently bend it in the opposite direction of the curl until the paper lies flat. If the
problem persists, use paper that is not curled. For information about proper
storage and handling of photo paper, see Maintaining the quality of photo paper.
The paper may be too thin or too thick. Try using HP-designed photo paper. For
more information, see Choosing the right paper.
HP Photosmart 320 series
The photo printed at an angle or is off-center.
●
●
The paper may not be loaded correctly. Reload the paper, making sure that the
paper is correctly oriented in the In tray and that the paper-width guide fits close
to the edge of the paper. For paper-loading instructions, see Loading paper.
The print cartridge may need to be aligned. For more information, see Aligning
the print cartridge.
No page came out of the printer.
●
●
●
●
The printer may need attention. Read the printer screen for instructions.
The power may be off or there may be a loose connection. Make sure that the
power is on and the power cord is securely connected. If you are using battery
power, make sure the battery is correctly installed.
You may not have any paper in the In tray. Check that paper is loaded correctly in
the In tray. For paper-loading instructions, see Loading paper.
The paper may have jammed while printing. See the following section for
instructions on clearing a paper jam.
The paper jammed while printing.
Check the printer screen for instructions. To clear a paper jam, try the following:
●
●
If the paper came part way through the front of the printer, gently pull the paper
towards you to remove it.
If the paper did not come part way through the front of the printer, try removing it
from the back of the printer:
–
–
–
●
Remove the paper from the In tray, then pull down on the In tray to open it
fully to a horizontal position.
Gently pull the jammed paper to remove it from the back of the printer.
Lift the In tray up until it snaps back into paper-loading position.
If you cannot grasp the edge of the jammed paper to remove it, try the following:
–
–
–
–
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer,
unplug the printer power cord. Wait about 10 seconds, then plug the power
cord back in.
If the optional HP Photosmart Internal Battery is installed in the printer,
unplug the printer power cord, if it is plugged in. Open the battery
compartment cover and remove the battery. Wait about 10 seconds, then
reinstall the battery. If desired, plug in the power cord.
Turn on the printer. The printer checks for paper in the paper path and will
automatically eject the jammed paper.
Press OK to continue.
Tip If you experience paper jams while printing, try loading one sheet of photo paper
at a time. Insert the paper as far as it will go into the In tray.
A blank page came out of the printer.
●
●
Check the ink-level icon on the printer screen. If the print cartridge is out of ink,
replace it. For more information, see Inserting print cartridges.
You may have begun printing and then cancelled the process. If you cancelled
the process before the photo started printing, the printer may have already loaded
HP Photosmart 320 series User's Guide
39
Chapter 6
paper in preparation for printing. The next time you print, the printer will eject the
blank page before starting the new printing project.
The photo did not print using the printer's default print settings.
You may have changed the print settings for the selected photo. Print settings you
apply to an individual photo override the printer's default print settings. Discard all
print settings that have been applied to an individual photo by deselecting the photo.
For more information, see Selecting photos to print.
The printer ejects the paper when preparing to print.
Direct sunlight could be interfering with the operation of the automatic paper sensor.
Move the printer out of direct sunlight.
Print quality is poor.
●
●
●
●
●
●
The print cartridge may be running out of ink. Check the ink-level icon on the
printer screen, and replace the cartridge if necessary. For more information, see
Insert the cartridge.
You may have selected a low-resolution setting on the digital camera when you
took the photo. For better results in the future, set the digital camera to a higher
resolution.
Make sure you are using the right type of photo paper for the project. Use HPdesigned photo paper for best results. For more information, see Choosing the
right paper.
You may be printing on the wrong side of the paper. Make sure the paper is
loaded with the side to be printed facing up.
The print cartridge may need to be cleaned. For more information, see Cleaning
the print cartridge.
The print cartridge may need to be aligned. For more information, see Aligning
the print cartridge.
The photos I marked for printing in the digital camera do not print.
Some digital cameras, such as the HP 318 and HP 612, let you mark photos for
printing both in the camera's internal memory and on the memory card. If you mark
photos in the internal memory, and then move photos from the camera's internal
memory to the memory card, the marks do not transfer. Mark photos for printing after
you transfer them from the digital camera's internal memory to the memory card.
Bluetooth printing problems
Before contacting Customer Care, read this section for troubleshooting tips, or go to
the online support services at www.hp.com/support. Be sure to also read the
documentation that came with your HP Bluetooth wireless printer adapter and your
device with Bluetooth wireless technology.
40
HP Photosmart 320 series
My Bluetooth device cannot find the printer.
●
●
Make sure the HP Bluetooth wireless printer adapter is plugged into the camera
port on the front of the printer. The light on the adapter flashes when the adapter
is ready to receive data.
Bluetooth Accessibility may be set to Not visible. Change this setting to Visible
to all as follows:
–
Remove any memory cards from the printer memory card slots.
Caution Do not pull out a memory card while the Memory Card light
is flashing.
–
–
–
–
●
Press OK to display the printer menu.
Select Bluetooth, then press OK.
Select Accessibility, then press OK.
Select Visible to all, then press OK.
Bluetooth Security level may be set to High. Change this setting to Low as
follows:
–
Remove any memory cards from the printer memory card slots.
Caution Do not pull out a memory card while the Memory Card light
is flashing.
–
–
–
–
●
●
Press OK to display the printer menu.
Select Bluetooth, then press OK.
Select Security level, then press OK.
Select Low, then press OK.
The Passkey (PIN) that the device with Bluetooth wireless technology is using for
the printer may be incorrect. Make sure the correct Passkey for the printer is
entered in the device with Bluetooth wireless technology.
You may be too far from the printer. Move the device with Bluetooth wireless
technology closer to the printer. The maximum recommended distance between
the device with Bluetooth wireless technology and the printer is 10 meters (30
feet).
No page came out of the printer.
The printer may not recognize the type of file sent by the device with Bluetooth
wireless technology. For a list of the file formats that the printer supports, see Printer
specifications.
Print quality is poor.
The photo you printed may be low resolution. For better results in the future, set the
digital camera to a higher resolution. Be aware that photos taken with VGA-resolution
cameras, such as those found in wireless phones, may not have high enough
resolution to produce a high-quality print.
The photo printed with borders.
The printing application installed on your device with Bluetooth wireless technology
may not support borderless printing. Contact the vendor of the device, or go to their
support website to obtain the latest updates for the printing application.
HP Photosmart 320 series User's Guide
41
Chapter 6
Error messages
Before contacting Customer Care, read this section for troubleshooting tips or go to
the online support services at www.hp.com/support.
The following error messages may appear on the printer screen. Follow the
instructions to resolve the problem.
Error message: Paper jam. Clear jam then press OK.
To clear a paper jam, try the following:
●
●
If the paper came part way through the front of the printer, gently pull the paper
towards you to remove it.
If the paper did not come part way through the front of the printer, try removing it
from the back of the printer:
–
–
–
●
If you cannot grasp the edge of the jammed paper to remove it, try the following:
–
–
–
–
●
Remove the paper from the In tray, then pull down on the In tray to open it
fully to a horizontal position.
Gently pull the jammed paper to remove it from the back of the printer.
Lift the In tray up until it snaps back into paper-loading position.
Turn off the printer.
If the optional HP Photosmart Internal Battery is not installed in the printer,
unplug the printer power cord. Wait about 10 seconds, then plug the power
cord back in.
If the optional HP Photosmart Internal Battery is installed in the printer,
unplug the printer power cord, if it is plugged in. Open the battery
compartment cover and remove the battery. Wait about 10 seconds, then
reinstall the battery. If desired, plug in the power cord.
Turn on the printer. The printer checks for paper in the paper path and will
automatically eject the jammed paper.
Press OK to continue.
Error message: Automatic paper sensor failed.
The automatic paper sensor is obstructed or damaged. Try moving the printer out of
direct sunlight, then press OK and try printing again. If this does not work, go to
www.hp.com/support or contact Customer Care.
Error message: Cartridge is not compatible. Use appropriate HP cartridge.
Replace the print cartridge with one that is compatible with the printer. For more
information, see Inserting print cartridges.
Error message: Print cartridge cradle is stuck. Clear jam then press OK.
Follow these steps to clear any obstruction in the path of the print cartridge cradle:
1
2
3
42
Open the print cartridge door.
Clear any obstruction in the cradle path.
Close the print cartridge door, then press OK to continue.
HP Photosmart 320 series
Error message: Cartridge service station is stuck.
The print cartridge service station is the component located beneath the print cartridge
cradle that wipes and caps the print cartridge for storage. Follow these steps to clear
the obstruction blocking the print cartridge service station:
1
2
3
4
Open the print cartridge door.
Gently push the print cartridge and print cartridge cradle to the left to access the
print cartridge service station.
Remove any obstruction.
Close the print cartridge door, the press OK to continue.
Error message: Memory card in backwards. The black side should face up.
A SmartMedia memory card has been inserted upside down. Gently pull the card out
of the slot and reinsert it with the gold contacts facing down.
HP Photosmart 320 series User's Guide
43
Chapter 6
44
HP Photosmart 320 series
7
Specifications
This section lists the minimum system requirements for installing the HP Photosmart
printer software, and provides selected printer specifications.
For a complete list of printer specifications and system requirements, see the
onscreen Help. For information about viewing the onscreen Help, see Welcome.
System requirements
Component
Windows PC minimum
Macintosh minimum
Operating system
Microsoft® Windows 98,
2000 Professional, ME,
XP Home, and XP
Professional
Mac® OS X 10.1 through
10.3
Processor
Intel® Pentium® II (or
equivalent) or higher
G3 or greater
RAM
64 MB (128 MB
recommended)
Mac OS 10.1 through
10.3: 128 MB
Free disk space
500 MB
500 MB
Video display
800 x 600, 16-bit or higher
800 x 600, 16-bit or higher
CD-ROM drive
4x
4x
Connectivity
USB 2.0 full-speed:
Microsoft Windows 98,
2000 Professional, ME,
XP Home, and XP
Professional
USB 2.0 full-speed: Mac
OS X 10.1 through 10.3
PictBridge: using front
camera port
PictBridge: using front
camera port
Bluetooth: using optional
HP Bluetooth wireless
printer adapter
Bluetooth: using optional
HP Bluetooth wireless
printer adapter
Browser
HP Photosmart 320 series User's Guide
Microsoft Internet
Explorer 5.5 or later
—
45
Chapter 7
Printer specifications
Category
Specifications
Connectivity
USB 2.0 full-speed: Microsoft Windows 98, 2000
Professional, ME, XP Home, and XP Professional;
Mac OS X 10.1 through 10.3
Image file formats
JPEG Baseline
TIFF 24-bit RGB uncompressed interleaved
TIFF 24-bit YCbCr uncompressed interleaved
TIFF 24-bit RGB packbits interleaved
TIFF 8-bit gray uncompressed/packbits
TIFF 8-bit palette color uncompressed/packbits
TIFF 1-bit uncompressed/packbits/1D Huffman
Margins
Borderless printing: Top 0.0 mm (0.0 inch) ;
Bottom 12.5 mm (0.50 inch); Left/right 0.0 mm (0.0
inch)
Bordered printing: Top 4 mm (0.16 inch); Bottom
12.5 mm (0.50 inch); Left/right 4 mm (0.16 inch)
Media sizes
Photo paper 10 x 15 cm (4 x 6 inch)
Photo paper with tab 10 x 15 cm with 1.25 cm tab
(4 x 6 inches with 0.5 inch tab)
Index cards 10 x 15 cm (4 x 6 inches)
Hagaki cards 100 x 148 mm (3.9 x 5.8 inches)
A6 cards 105 x 148 mm (4.1 x 5.8 inches)
L-size cards 90 x 127 mm (3.5 x 5 inches)
L-size cards with tab 90 x 127 mm with 12.5 mm
tab (3.5 x 5 inches with 0.5 inch tab)
Media types
Paper (photo)
Cards (index, Hagaki, A6, L-size)
Memory cards
CompactFlash Type I and II
MultiMediaCard
Secure Digital
SmartMedia
Memory Sticks
xD-Picture Card
Memory card-supported file
formats
46
Printing: All supported image and video file formats
Saving: All file formats
HP Photosmart 320 series
(continued)
Category
Specifications
Operating temperature
0–45 degrees C (32–113 degrees F)
[15–35 degrees C (59–95 degrees F)
recommended]
Paper tray
One 10 x 15 cm (4 x 6 inch) photo paper tray
Paper tray capacity
20 sheets, maximum thickness 292 µm (11.5 mil)
per sheet
Power consumption
U.S.
Printing: 12.3 W
Idle: 6.29 W
Off: 4.65 W
International
Printing: 11.4 W
Idle: 5.67 W
Off: 4.08 W
Print cartridge
Tri-color (7 ml) HP #95 (North America, Latin
America, Asia Pacific), #135 (Eastern Europe,
Russia, Middle East, Africa, Japan), #343
(Western Europe), #855 (China, India)
Tri-color (14 ml) HP #97 (North America, Latin
America, Asia Pacific), #134 (Eastern Europe,
Russia, Middle East, Africa, Japan), #344
(Western Europe), #857 (China, India)
Gray Photo HP #100 (worldwide)
USB 2.0 full-speed support
Microsoft Windows 98, 2000 Professional, ME, XP
Home, and XP Professional
Mac OS X 10.1 through 10.3
HP recommends that the USB cable be less than 3
meters (10 feet) in length
Video file formats
Motion JPEG AVI
Motion JPEG Quicktime
MPEG-1
HP Photosmart 320 series User's Guide
47
Chapter 7
48
HP Photosmart 320 series
8
HP Customer Care
If you have a problem, follow these steps:
1
Check the documentation that came with the printer.
–
–
–
2
If you are unable to solve the problem using the information in the documentation,
visit www.hp.com/support to do the following:
–
–
–
–
3
4
Setup Guide: The HP Photosmart 320 series Setup Guide explains how to
set up the printer and print your first photo.
User's Guide: The HP Photosmart 320 series User's Guide is the book you
are reading. This book describes the basic features of the printer, explains
how to use the printer without connecting a computer, and contains hardware
troubleshooting information.
HP Photosmart Printer Help: The onscreen HP Photosmart Printer Help
describes how to use the printer with a computer and contains software
troubleshooting information.
Access online support pages
Send HP an e-mail message for answers to your questions
Connect with an HP technician by using online chat
Check for software updates
Support options and availability vary by product, country/region, and language.
Contact your local point of purchase. If the printer has a hardware failure, you will
be asked to bring the printer to where you purchased it. Service is free during the
printer limited warranty period. After the warranty period, you will be quoted a
service charge.
If you are unable to solve the problem using the onscreen Help or HP websites,
call HP Customer Care using the number for your country/region. For a list of
country/region phone numbers, see the following section.
HP Customer Care by phone
While the printer is under warranty, you can obtain free phone support. For more
information, see the warranty included in the box, or go to www.hp.com/support to
check the duration of your free support.
After the free phone support period, you can obtain help from HP at an additional cost.
Contact your HP dealer or call the support phone number for your country/region for
support options.
To receive HP support by phone, call the appropriate support phone number for your
location. Standard phone company charges apply.
North America: Call 1-800-HP-INVENT (1-800-474-6836). U.S. phone support is
available in both English and Spanish languages 24 hours a day, 7 days a week (days
and hours of support may change without notice). This service is free during the
warranty period. A fee may apply outside the warranty period.
Note Customers in Western Europe should go to www.hp.com/support to access
phone support numbers in their country/region.
HP Photosmart 320 series User's Guide
49
Chapter 8
www.hp.com/support
61 56 45 43
1588-3003
Argentina
Argentina
(54) 11-4778-8380
0-810-555-5520
Australia
13 10 47
Malaysia
1800-80-5405
México (Ciudad de México)
México (fuera de
Ciudad de México)
(55)5258-9922
01-800-4726684
22 404747
800 171
Brasil (dentro da
grande São Paulo)
Brasil (fora da
grande São Paulo)
(11) 3747-7799
Canada
0800-157751
New Zealand
0800 441 147
Nigeria
1 3204 999
Panama
001-800-7112884
(800) 474-6836
Perú
0-800-10111
Caribbean
1-800-711-2884
Philippines
63 (2) 867-3551
Central America
1-800-711-2884
Polska
22 5666 000
Chile
800-360-999
Puerto Rico
1-877-232-0589
Republica Dominicana
1-800-7112884
(8621) 38814518
Columbia
01-800-011-4726
România
(21) 315 4442
Costa Rica
0-800-011-4114 +
1-800-711-2884
Russia (Moscow)
Russia (St. Petersburg)
095 7973520
812 3467997
Česká republika
261 307 310
Ecuador (Andinatel)
1-800-711-2884
Ecuador (Pacifitel)
1-800-225528
2 532 5222
800 897 1444
Singapore
65 6272 5300
Slovakia
2 50222444
South Africa (Intl.)
+ 27 11 2589301
South Africa (RSA)
086 0001030
Greece (international)
Greece (in-country)
Greece (Cyprus)
+ 30 210 6073603
801 11 22 55 47
800 9 2649
Guatemala
1-800-999-5105
Thailand
852-2802 4098
71 89 12 22
Magyarország
1 382 1111
Trinidad & Tobago
India
1 600 44 7737
Türkiye
(212) 444 7171
Indonesia
62 (21) 350 3408
Ukraine
(380 44) 4903520
+ 351 213 17 63 80
(02) 8722-8000
66 (2) 353 9000
1-800-7112884
800 4520
(0) 9 830 4848
Jamaica
Rest Of West Africa
0-800-7112884
United States
(800) 474-6836
0570-000511
Venezuela
01-800-4746.8368
Viêt Nam
84 (8) 823 4530
For Bangladesh, Brunei,
Cambodia, Pakistan, and
Sri Lanka
Fax to:
+65-6275-6707
+81-3-3335-9800
Placing a call
Call HP Customer Care while you are near the computer and printer. Be prepared to
provide the following information:
●
●
●
●
Printer model number (located on the front of the printer).
Printer serial number (located on the bottom of the printer).
Computer operating system.
Version of printer driver:
–
–
50
Windows PC: To see the printer driver version, right-click the memory card
icon in the Windows taskbar and select About.
Macintosh: To see the printer driver version, use the Print dialog box.
HP Photosmart 320 series
●
●
Messages displayed on the printer screen or on the computer monitor.
Answers to the following questions:
–
–
Has the situation you are calling about happened before? Can you recreate
the situation?
Did you install any new hardware or software on your computer around the
time that the situation occurred?
Return to HP repair service
HP will arrange to have your product picked up and delivered to an HP Central Repair
Center. We pay for the round-trip shipping and handling. This service is free for the
duration of the hardware warranty period.
HP Photosmart 320 series User's Guide
51
Chapter 8
52
HP Photosmart 320 series
a
Installing the software
The printer comes with optional software you can install on a computer.
Windows users
Macintosh users
Important: Do not connect the USB cable
until you are prompted.
Important: Do not connect the USB cable
until you are prompted.
HP Image Zone software and full printer
functionality is installed automatically when
you choose the Typical installation of your HP
software.
1
1
3
2
3
4
Insert the HP Photosmart CD into your
computer's CD-ROM drive.
Click Next and follow the onscreen
instructions. If instructions do not
appear, locate the setup.exe file on the
CD-ROM drive and double-click it. Wait
several minutes while the files load.
When prompted, connect one end of the
USB cable to the USB port on the back
of the printer, and connect the other end
to the USB port on your computer.
Follow the onscreen instructions until the
installation is finished and your computer
restarts. When the Congratulations page
appears, click Print a demo page.
HP Photosmart 320 series User's Guide
2
4
5
Insert the HP Photosmart CD into your
computer's CD-ROM drive.
Double-click the HP Photosmart CD
icon.
Double-click the HP Photosmart Install
icon. Follow the onscreen instructions to
install the printer software.
When prompted, connect one end of the
USB cable to the USB port on the back
of the printer, and connect the other end
to the USB port on your computer.
Select the printer in the Print dialog box.
If the printer does not appear in the list,
click Edit Printer List to add the printer.
53
Appendix a
54
HP Photosmart 320 series
Index
A
accessories 7, 33
aligning print cartridges 16, 31
alignment page 31
automobile adapter 8, 33
B
batteries
compartment 7
digital camera 24
model 7
black-and-white photos 14
Bluetooth
connecting to printer 27
troubleshooting 40
wireless printer adapter 8
borderless photos
do not print 38
print with borders 41
buttons 5
C
cameras
connecting to printer 27
photos do not print 40
port 4
printing from 24
carrying case
model 8
transporting printer 33
cartridges. see print cartridges
cleaning
print cartridge contacts 30
print cartridges 29
printer 29
CompactFlash 17
computer
connecting to printer 27
installing software 53
printing from 3
system requirements 45
control panel 5
Customer Care 49
D
digital cameras. see cameras
Digital Flash 23
documentation, printer 3
O
onscreen Help
E
e-mailing photos 27
error messages 42
P
paper
buying and choosing 13
loading 14
maintaining 13, 33
specifications 46
trays 4
troubleshooting 38
photos
e-mailing 27
improving quality 23
index 22
print cartridges,
choosing 14
printing 24
saving to computer 27
selecting for print 22
supported file formats 18
viewing 22
PictBridge cameras 24
print cartridges
aligning 31
choosing 14
cleaning 29
cleaning contacts 30
ink level, checking 16
inserting 16
replacing 16
storing 17, 32
testing 30
printer
accessories 7, 33
cleaning 29
connecting 27
documentation 3
error messages 42
menu 8
parts 4
power problems 37
specifications 46
storing 32
transporting 33
warnings 4
printing
F
file formats, supported 18, 46
H
help. see troubleshooting
help, onscreen 3
HP direct-printing digital
cameras 24
HP Instant Share 27
I
ink cartridges. see print
cartridges
ink level, checking 16, 30
inserting
memory cards 18
print cartridges 16
J
JPEG file formats 18
L
layout, selecting 24
lights 5
loading paper 14
M
memory cards
inserting 18
photos do not appear 36
printing from 24
removing 20
supported types 17
Memory Sticks 17
menu, printer 8
Microdrive 17
MPEG-1 file format 18
MultiMediaCard 17
HP Photosmart 320 series User's Guide
3
55
from cameras 24
from computer 3
from memory cards 24
multiple copies 22
multiple photos 22
photo index 22
photos 24
selecting layout 24
test page 30
thumbnails 22
without computer 21
Q
quality
photo paper 33
photos 23
print 24
printing test page 30
troubleshooting 40
paper problems 38
power problems 37
printer noises 38
quality problems 40
U
USB
connection type 27
port 4
specifications 46
V
viewing photos 22
X
xD-Picture Card 17
R
regulatory notices 57
removing memory cards 20
replacing print cartridges 16
S
saving photos to computer 27
Secure Digital 17
Smart Focus 23
SmartMedia 17
software, installing 53
specifications 45
storing
photo paper 33
print cartridges 17, 32
printer 32
system requirements 45
T
test page 30
thumbnails, printing 22
TIFF file format 18
transporting printer 7, 33
trays, paper 4
troubleshooting
Bluetooth 40
borderless photos 38
buttons do not work 36
cannot find photos 36
Customer Care 49
error messages 42
flashing lights 35
56
HP Photosmart 320 series
Declaration of conformity
According to ISO/IEC Guide 22 and EN 45014
Manufacturer’s name and address:
Hewlett-Packard Company, 16399 West Bernardo Drive, San Diego, CA 92127-1899, USA
Regulatory model number:
SDGOB-0304-01
Declares that the product:
Product name:
Photosmart 320 series (Q3414A)
Model number(s):
Photosmart 325 (Q3414A)
Power adapters:
HP Part # Q3419-60040 (domestic)
HP Part # Q3419-60041 (international)
Conforms to the following product specifications:
Safety:
IEC 60950: 3rd Edition: 1999
EN 60950:2000
UL1950/CSA22.1 No.950, 3rd Edition:1995
NOM 019–SFCI-1993
GB4943:2001
EMC:
CISPR 22: 1997 / EN 55022: 1998, Class B
CISPR 24: 1997 / EN 55024: 1998
IEC 61000-3-2: 2000 / EN 61000-3-2: 2000
IEC 61000-3-3/A1: 2001 / EN 61000-3-3/A1: 2001
CNS13438: 1998, VCCI-2
FCC Part 15-Class B/ICES-003, Issue 2
GB9254: 1998
Supplementary Information:
The Product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive
89/336/EEC and carries the CE marking accordingly.
European Contact for regulatory topics only: Hewlett Packard GmbH, HQ-TRE, Herrenberger Strasse 140, D-71034
Böblingen Germany. (FAX +49-7031-14-3143)
