User’s Guide
Color Monitor Series
v72
© 2003 Hewlett-Packard Development Company, L.P.
HP, Hewlett-Packard, and the Hewlett-Packard logo are trademarks of
Hewlett-Packard Company in the U.S. and other countries/regions.
Microsoft, MS-DOS, Windows, and Windows NT are trademarks of
Microsoft Corporation in the U.S. and other countries/regions.
Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel
Corporation in the U.S. and other countries/regions.
Adobe, Acrobat, and Acrobat Reader are trademarks or registered
trademarks of Adobe Systems Incorporated.
All other product names mentioned herein may be trademarks of their
respective companies.
Hewlett-Packard Company shall not be liable for technical or
editorial errors or omissions contained herein or for incidental
or consequential damages in connection with the furnishing,
performance, or use of this material. The information in this document
is provided “as is” without warranty of any kind, including, but
not limited to, the implied warranties of merchantability and fitness
for a particular purpose, and is subject to change without notice.
The warranties for HP products are set forth in the express limited
warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty.
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT, EXCEPT
TO THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE,
RESTRICT OR MODIFY AND ARE IN ADDITION TO ANY
MANDATORY STATUATORY RIGHTS APPLICABLE TO THE SALE
OF THIS PRODUCT OR SERVICE TO YOU.
This document contains proprietary information that is protected
by copyright. No part of this document may be photocopied,
reproduced, or translated to another language without the prior
written consent of Hewlett-Packard Company.
Å
WARNING: Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
Ä
CAUTION: Text set off in this manner indicates that failure to follow
directions could result in damage to equipment or loss of
information.
Contents
1 Introduction
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
2 Safety and Maintenance Guidelines
Safety Guidelines . . . . . . . . . . .
Power Requirements . . . . . .
Important Safety Information .
Maintenance Guidelines . . . . . .
Removing the Monitor Base .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
2–1
2–1
2–1
2–2
2–4
3 Installation
Monitor Base Installation . . . . . . . . . . . . . . . . . . . 3–1
Monitor Installation . . . . . . . . . . . . . . . . . . . . . . . 3–2
4 Operation
Information Files . . . . . . . . . . . . . . . .
Installing Drivers . . . . . . . . . . . . .
Front Panel Controls . . . . . . . . . . . . .
On-Screen Display . . . . . . . . . . . . . .
On-Screen Display Functions . . . .
Monitor Messages . . . . . . . . . . . . . .
No Signal Message. . . . . . . . . . .
Out of Frequency Range Message.
Using the Energy Saver Mode . . . . . .
User’s Guide
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
. . . . 4–1
. . . . 4–2
. . . . 4–5
. . . . 4–6
. . . . 4–7
. . . . 4–9
. . . . 4–9
. . . 4–10
. . . 4–11
iii
A Troubleshooting
Solving Common Problems . . . . . . . . . . . . . . . . . A–1
Using the World Wide Web . . . . . . . . . . . . . . . . A–4
Preparing to Call Technical Support . . . . . . . . . . . A–4
B Technical Specifications
v72 Series Monitor . . . . . . . . . . . . . . . . . . . . . . . B–1
C Agency Regulatory Notices
Federal Communications Commission Notice. . . . .
Modifications . . . . . . . . . . . . . . . . . . . . . . . .
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Declaration of Conformity for Products Marked
with FCC Logo, United States Only . . . . . . . . . . . .
Canadian Notice . . . . . . . . . . . . . . . . . . . . .
Avis Canadien . . . . . . . . . . . . . . . . . . . . . . .
European Notice. . . . . . . . . . . . . . . . . . . . . .
Japanese Notice . . . . . . . . . . . . . . . . . . . . . .
Korean Notice . . . . . . . . . . . . . . . . . . . . . . .
EPA Energy Star Compliance . . . . . . . . . . . . .
Power Cord Set Requirements . . . . . . . . . . . . . . .
C–1
C–1
C–2
C–2
C–2
C–3
C–3
C–3
C–3
C–4
C–4
D TCO‘99 Requirements
Environmental Requirements.
Flame Retardants. . . . . .
Cadmium . . . . . . . . . . .
Mercury . . . . . . . . . . . .
CFCs (Freons) . . . . . . . .
Lead . . . . . . . . . . . . . .
iv
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
..
..
..
..
..
..
D–3
D–3
D–4
D–4
D–4
D–5
User’s Guide
1
Introduction
Your microprocessor-based, digitally controlled color monitor is a
high-performance and easy-to-use product. It employs the latest
on-screen menu technology.
Kit Contents
The monitor kit contains:
■
CRT monitor
■
Monitor Base (pre-installed on select models)
■
AC power cord (select models)
■
Documentation kit
User’s Guide
1–1
Introduction
1–2
User’s Guide
2
Safety and Maintenance
Guidelines
Safety Guidelines
Power Requirements
Refer to the “Power Cord Set Requirements” on page C–4 for
information on the correct power cord set for this device.
Important Safety Information
Å
WARNING: To reduce the risk of electric shock or damage to your
equipment, do not disable the power cord grounding feature. This
equipment is designed to be connected to a grounded (earthed)
power outlet that is easily accessible to the operator. The grounding
plug is an important safety feature.
Å
WARNING: For your safety, be sure that the power outlet you plug
the power cord into is easily accessible and located as close to the
equipment as possible. When you need to disconnect the power to
the equipment, unplug the power cord from the power outlet by
grasping the plug firmly. Never pull on the cord.
Ä
CAUTION: For the protection of your monitor, as well as your
computer, connect all power cords for your computer and its
peripheral devices (such as a monitor, printer, scanner) to some form
of surge protection device such as a power strip or Uninterruptible
Power Supply (UPS). Not all power strips provide surge protection;
the power strips must be specifically labeled as having this ability.
Use a power strip whose manufacturer offers a Damage
Replacement Policy so you can replace your equipment if surge
protection fails.
User’s Guide
2–1
Safety and Maintenance Guidelines
Maintenance Guidelines
To enhance the performance and extend the life of your monitor,
follow these guidelines:
Ä
2–2
■
Do not open your monitor cabinet or attempt to service this
product yourself. If your monitor is not operating properly, or
has been dropped or damaged, first unplug from power outlet,
then contact your Hewlett-Packard authorized dealer, reseller,
or service provider.
■
Adjust only those controls that are discussed in the operating
instructions.
■
Place your monitor at least 3 inches (76 mm) away from walls
or other enclosures.
■
Use only a power source and connection appropriate for this
monitor, as indicated on the label/back plate of the monitor.
■
Be sure the total ampere rating of the products connected to
the outlet does not exceed the current rating of the electrical
outlet, and the total ampere rating of the products connected
to the cord does not exceed the rating of the cord. Look on the
power label to determine the ampere rating (AMPS or A) for
each device.
■
Install your monitor near an outlet that you can easily reach.
Disconnect the monitor by grasping the plug firmly and pulling
it from the outlet. Never disconnect the monitor by pulling
the cord.
■
Turn your monitor off when not in use. You can substantially
increase the life of your monitor by using a screen saver
program and turning off the monitor when not in use.
■
Unplug your monitor from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning. If the screen requires additional cleaning, use an
antistatic CRT screen cleaner.
CAUTION: Do not use benzene, thinner, ammonia, or any other
volatile substances to clean your monitor or the screen. These
chemicals may damage the cabinet finish as well as the screen.
User’s Guide
Safety and Maintenance Guidelines
■
Slots and openings in the cabinet are provided for ventilation.
These openings must not be blocked or covered. Never push
objects of any kind into cabinet slots or other openings.
■
Do not place plants on top of your monitor. Water or dirt from
the plant may get into the vents.
■
Do not drop your monitor or place it on an unstable surface.
■
Do not allow anything to rest on the power cord. Do not walk
on the cord.
■
Keep your monitor in a well-ventilated area, away from
excessive light, heat or moisture. Keep your monitor away
from high-capacity transformers, electric motors, and other
devices with strong magnetic fields.
■
In a two-monitor system, place your monitors as far apart from
one another as possible to lessen interference between them.
■
Do not place the monitor face down. Damage could result to
the front panel controls or the monitor screen.
User’s Guide
2–3
Safety and Maintenance Guidelines
Removing the Monitor Base
In the event that you need to disassemble the base from the
monitor, follow these instructions:
1. If you must remove the base attachment, release the catch and
slide the base toward the back of your monitor.
2. Lift the base up and away from your monitor.
2–4
User’s Guide
3
Installation
Monitor Base Installation
On some monitors, the base must be attached prior to monitor
installation. If you need to attach the base, follow these steps:
1. Align the hooks on the base with the sockets on the bottom of
the monitor and attach the base.
User’s Guide
3–1
Installation
2. Push the base toward the front of the monitor until it stops.
Monitor Installation
Before installing your monitor, place it in a convenient,
well-ventilated location near your computer.
1. Turn off the power to your computer and other peripheral
devices.
2. Connect the video cable (blue connector) 1 from the back of
the monitor to the blue 15-pin connector on the back of the
computer. Tighten the cable screws to secure the cable to the
connector.
Ä
3–2
CAUTION: To avoid damaging the video cable, ensure that the
cable aligns with the 15-pin connector. Do not force the cable onto
the connector.
User’s Guide
Installation
3. Connect the power cord 2 to the back of the monitor, then
connect the power cord to a power outlet.
4. Power on your computer and monitor.
If your monitor fails to function properly, refer to Appendix A,
“Troubleshooting.”
5. If necessary, adjust the front panel monitor controls according
to your personal preference. See “Front Panel Controls” on
page 4–5 for detailed information.
Your monitor installation is now complete.
User’s Guide
3–3
Installation
3–4
User’s Guide
4
Operation
Information Files
The CD-ROM included with this monitor contains two data files
that must be installed onto your computer: An .INF file and an
.ICM file.
The .INF file designates software and defines monitor resources
used by Microsoft Windows to ensure monitor compatibility with
the graphics adapter in your computer.
The .ICM file provides color matching consistency between your
monitor screen and your printer. Once installed, this file is
activated by graphics programs that have this color-matching
feature.
To install these files on your computer:
1. Insert the CD-ROM disc that came with the monitor in your
computer’s optical drive.
2. Perform the steps to install the drivers. See “Installing Drivers”
on page 4–2 and choose the steps for your operating system.
3. To get the latest .INF and .ICM files, download them from the
HP Web site. Access http://www.hp.com and follow the links
to the Support page for monitors to download the appropriate
files.
User’s Guide
4–1
Operation
Installing Drivers
The HP monitor comes with driver software allowing you to take
advantage of the Plug and Play feature of the Windows Me,
Windows 2000, or Windows XP operating system. This software
enables the computer to communicate with the monitor and use all
the monitor features.
HP computers may come with the Plug and Play drivers
pre-installed. If you have an older computer, these drivers may not
be pre-installed and you may need to install the drivers from the
CD-ROM disc that came with the monitor.
If the installation procedure for the operating system is different, or
if you need more detailed installation information, please refer to
the Microsoft Windows information that came with the computer.
Windows 2000 users
The procedure for installing the driver for your operating system
may vary.
To install the driver for the v72 monitor:
1. Click Start, select Settings, and then click Control Panel.
2. Double-click Display.
3. Click the Settings tab.
4. Click Advanced Properties or Advanced, and select the
Monitor tab.
5. Click Properties.
6. Click the Driver tab.
7. Click Update Driver and click Next.
8. Select the recommended option, and then click Next.
9. Select the Specify a Location box.
10. Find and open the hp_v72.inf file on the CD-ROM disc in the
Drivers directory, and click OK.
11. Click Next to install the monitor driver.
4–2
User’s Guide
Operation
Windows Me users
The procedure for installing the driver for your operating system
may vary.
To install the driver for the v72 monitor:
1. Click Start, select Settings, and then click Control Panel.
2. Double-click Display.
3. Click the Settings tab.
4. Click the Advanced button.
5. Select the Monitor tab.
6. Click the Change button.
7. Select the Specify the location of the driver box, and
then click Next.
8. Find and open the hp_v72.inf file on the CD-ROM disc in the
Drivers directory, and click OK.
9. Click Next to install the monitor driver.
Windows XP users
The procedure for installing the driver for your operating system
may vary.
To install the driver for the v72 monitor:
1. Click Start.
2. Click Control Panel.
3. Click Appearance and Themes.
4. Click Display.
5. Select the Settings tab.
6. Click the Advanced button.
7. Select the Monitor tab.
User’s Guide
4–3
Operation
8. Click Properties.
9. Select the Driver tab.
10. Click Update Driver.
11. Select the Install from a list or specific location box,
and then click Next.
12. Select the Don’t search box, and then click Next.
13. Click Have Disk.
14. Click Browse.
15. Find and open the hp_v72.inf file on the CD-ROM disc in the
Drivers directory, and click OK.
16. Click Next to install the monitor driver.
If the installation procedure of the monitor driver for the Windows
2000, Windows Me, or Windows XP operating system is different,
or if you need more detailed installation information, refer to the
Microsoft Windows information that came with the PC.
4–4
User’s Guide
Operation
Front Panel Controls
Item
Icon
Front Panel Controls
Name
Function
Select
Launches on-screen displays,
selects functions and
adjustments, and exits menus
and On-Screen Display.
Left Adjustment
Moves backward through menu
options or decreases
adjustment levels.
Right Adjustment
Moves forward through menu
options or increases adjustment
levels.
Power/LED
Controls power to the monitor.
The LED on the power button
indicates the state of the
monitor.
1
2
3
4
User’s Guide
4–5
Operation
On-Screen Display
The On-Screen Display (OSD) adjusts the screen image based on
your viewing preferences. To access the OSD, do the following:
1. If the monitor is not already on, press the Power button to turn
on the monitor.
2. Press the Select button to display the On-Screen Display menu.
A screen similar to this one appears. For a description of the
icons that appear on the screen, see “On-Screen Display
Functions” on page 4–7.
3. To move to a function, press the Right-Adjustment or
Left-Adjustment button on the front panel of your monitor until
the function is highlighted.
4. Press the Select button on the monitor choose the function.
5. The adjustment window displays. Press the Right-Adjustment or
Left-Adjustment buttons to increase (Right) or decrease (Left) the
level of adjustment.
6. Press Select to save the new adjustment.
7. To exit the On-Screen Display, select the Exit icon and press
the Select button once.
4–6
User’s Guide
Operation
On-Screen Display Functions
Use the Right-Adjustment and Left-Adjustment buttons found on the
front control panel of your monitor to adjust these functions.
Icon
User’s Guide
On-Screen Display Icons and Functions
Function Description
Contrast
Right-Adjustment increases the contrast
and Left-Adjustment decreases the
contrast.
Brightness
Right-Adjustment increases the brightness
and Left-Adjustment decreases the
brightness.
Horizontal
Position
Right-Adjustment moves the image to the
right and Left-Adjustment moves the image
to the left.
Horizontal
Size
Right-Adjustment increases the horizontal
size and Left-Adjustment decreases the
horizontal size.
Vertical
Position
Right-Adjustment moves the image up and
Left-Adjustment moves the image down.
Vertical
Size
Right-Adjustment increases the vertical
size and Left-Adjustment decreases the
vertical size.
Pincushion
Right-Adjustment makes the image sides
convex and Left-Adjustment makes the
image concave.
Trapezoid
Right-Adjustment adjusts the image so the
top is larger and Left-Adjustment adjusts
the image so that the bottom is larger.
Pin Balance
Right-Adjustment moves the top and
bottom of the image to the right and
Left-Adjustment moves the top and bottom
of the image to the left.
4–7
Operation
On-Screen Display Icons and Functions (Continued)
Icon
Function Description
4–8
Parallelogram
This control corrects the tilted vertical
edges of the image on both sides of the
screen that are in the same direction.
Tilt
(Rotation)
Right-Adjustment tilts the sides of the
image to the right and Left-Adjustment tilts
the sides of the image to the left.
Degauss
This control demagnetizes the screen to
reduce color impurities.
Hewlett-Packard suggests you not
degauss more than once within a
30-minute period of time.
Color Temp
Right-Adjustment selects the color
temperature to the right and
Left-Adjustment selects the color
temperature to the left.
Reset
This control resets the monitor to factory
default values.
Exit
This control exits the OSD menu.
User’s Guide
Operation
Monitor Messages
No Signal Message
If a “No Signal” message displays on your monitor, check to be
sure your video cable is properly connected and ensure that your
computer is powered on.
User’s Guide
4–9
Operation
Out of Frequency Range Message
If an “Out of Frequency Range” message displays on your monitor,
your video resolution and/or refresh rate are set higher than the
levels your monitor supports.
To change the video resolution or refresh rate on your monitor,
follow these steps:
1. Restart your computer.
2. Enter Safe Mode on your computer. Refer to your computer’s
operating system Help for instructions on entering Safe Mode.
3. Change your display settings to a supported setting (see
“Technical Specifications” on page B–1).
4. Restart your computer so that the new settings take effect.
4–10
User’s Guide
Operation
Using the Energy Saver Mode
Your monitor is designed to meet strict Environmental Protection
Agency (EPA) Energy Star® requirements for reduced power
consumption. Using a combination of hardware and software
functions, this energy-saving feature allows your computer to
control your monitor’s power consumption and reduce your
monitor’s power state when not in use.
Power Management Status for v72 Series Monitors
LED
Power
State Color Consumption Description
On
Green
< 100 watts
Normal Operation
Sleep
Amber
< 5 watts
Monitor screen is blank. High voltage
is off. Heater voltage is off. There is a
brief warm-up period before returning
to full power mode.
Your monitor’s energy saver feature works only when your monitor
is connected to a computer that also has energy saver features.
The Energy Saver utility, with its energy saving features, is
available with all Microsoft Windows operating systems. Some
features are also available in DOS. Refer to your computer’s user
guide for instructions on setting energy saver features (also
referred to as power management features).
User’s Guide
4–11
Operation
4–12
User’s Guide
A
Troubleshooting
Solving Common Problems
The following table lists possible problems, the possible cause of
each problem, and the recommended solutions.
Problem
Possible Cause
Solution
Screen is blank.
Power cord is disconnected.
Connect the
power cord.
Power switch is off.
Turn on power.
Video cable is improperly
connected.
Connect video cable
properly.
Screen blanking utility is
active.
Depress any key on
the keyboard or
move the mouse.
Brightness and contrast are
too low.
Press the SELECT
button to access the
On-Screen Display.
Select the Brightness
and/or Contrast
icons to adjust as
needed.
Image appears
blurred, indistinct,
or too dark.
User’s Guide
A–1
Troubleshooting
Problem
Color is abnormal.
Image is too large
or too small.
Image is not
centered.
A–2
(Continued)
Possible Cause
Solution
A magnetic object may be
nearby.
Move the object
farther away.
Monitor may have been
moved or inadvertently
bumped.
Press the SELECT
button to access the
On-Screen Display.
Select Degauss
to activate.
Hewlett-Packard
suggests you not
degauss more than
once within a
30-minute period
of time.
Horizontal width may need
adjustment.
Press the SELECT
button to access the
On-Screen Display.
Select H. Size to
adjust as needed.
Vertical height may need
adjustment.
Press the SELECT
button to access the
On-Screen Display.
Select V. Size to
adjust as needed.
Horizontal position may
need adjustment.
Press the SELECT
button to access the
On-Screen Display.
Select H. Position to
adjust as needed.
Vertical position may need
adjustment.
Press the SELECT
button to access the
On-Screen Display.
Select V. Position to
adjust as needed.
User’s Guide
Troubleshooting
Problem
(Continued)
Possible Cause
“No Signal” is
displayed on screen.
Monitor video cable is
disconnected.
Connect the 15-pin
monitor video cable
to the computer.
Be sure that the
computer power
is on.
“Out of Frequency”
is displayed on
screen.
Video resolution and/or
refresh rate are set higher
than what your monitor
supports.
Restart your computer
and enter Safe
Mode. Change
your settings to a
supported setting
(see “Technical
Specifications”).
Restart your computer
so that the new
settings take effect.
Monitor is
overheating.
There is not enough air
space to allow proper
ventilation.
Leave at least
3 inches (76 mm)
of ventilation space
around the monitor,
and do not place
objects on top of the
monitor.
User’s Guide
Solution
A–3
Troubleshooting
Using the World Wide Web
Before contacting customer services, refer to the support Web site
at: http://www.hp.com
Preparing to Call Technical Support
If you cannot solve a problem using the troubleshooting tips in this
section, you may need to call technical support. Have the
following information available when you call:
A–4
■
The monitor
■
Monitor model number
■
Serial number for the monitor
■
Purchase date on invoice
■
Conditions under which the problem occurred
■
Error messages received
■
Hardware configuration
■
Hardware and software you are using
User’s Guide
B
Technical Specifications
v72 Series Monitor
Screen Size
17” (43 cm) visual diagonal
Viewable screen size 16” (40.6 cm)
Dot Pitch
0.28 mm (Diagonal)
Display Area Default
234 x 312 (mm) typical
Display Colors
Infinite
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
60 Hz (maximum resolution)
Synchronization (Horizontal)
30 to 70 KHz
Synchronization (Vertical)
50 to 140 Hz
Max Pixel Clock
110 MHz Max.
Input Signal
Video RGB Analog Sync. TTL Separate
Video Cable
15-pin D-sub connector
Power Input Voltage
Frequency
100 to 240V
50 +3 to 60 +3 Hz
User’s Guide
B–1
Technical Specifications
(Continued)
Inrush Current
30 amps @ 120V
60 amps @ 220V
Power Consumption
100 W (Max.)
Dimension (W x H x D)
Unpacked w/attached base
16.6 x 17 x 17.5 inches (maximum)
410 x 432 x 445 mm (maximum)
Weight
38 lb Max.
17 kg Max.
Operating Temperature
50o F to 95o F
10o C to 35o C
Storage Temperature
–22o F to 140o F
–30o C to 60o C
Humidity
20% to 80% (non-condensing)
Altitude
Up to 10,000 ft./3048 meters
TCO’99
Some models meet TCO’99
MPRII
Some models meet MPRII
Plug and Play
Yes
B–2
User’s Guide
C
Agency Regulatory Notices
Federal Communications
Commission Notice
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
■
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and the
receiver.
■
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
■
Consult the dealer or an experienced radio or television
technician for help.
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly approved
by Hewlett-Packard Company may void the user’s authority to
operate the equipment.
User’s Guide
C–1
Agency Regulatory Notices
Cables
Connections to this device must be made with shielded cables with
metallic RFI/EMI connector hoods to maintain compliance with
FCC Rules and Regulations.
Declaration of Conformity for
Products Marked with FCC Logo,
United States Only
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
For questions regarding your product, contact:
Hewlett-Packard Company
P. O. Box 692000, Mail Stop 530113
Houston, Texas 77269-2000
Or, call:
1-800-652-6672
For questions regarding this FCC declaration, contact:
Hewlett-Packard Company
P. O. Box 692000, Mail Stop 510101
Houston, Texas 77269-2000
Or, call:
(281) 514-3333
To identify this product, refer to the Part, Series, or Model number
found on the product.
Canadian Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
C–2
User’s Guide
Agency Regulatory Notices
Avis Canadien
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
European Notice
Products with the CE Marking comply with both the EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EEC)
issued by the Commission of the European Community.
Compliance with these directives implies conformity to the
following European Norms (in brackets are the equivalent
international standards):
■
EN55022 (CISPR 22) — Electromagnetic Interference
■
EN55024 (IEC61000-4-2,3,4,5,6,8,11) — Electromagnetic
Immunity
■
EN61000-3-2 (IEC61000-3-2) — Power Line Harmonics
■
EN61000-3-3 (IEC61000-3-3) — Power Line Flicker
■
EN60950 (IEC950) — Product Safety
Japanese Notice
Korean Notice
User’s Guide
C–3
Agency Regulatory Notices
EPA Energy Star Compliance
Monitors that are marked with the Energy Star® Logo meet the
requirements of the EPA Energy Star program. As an Energy Star
Partner, Hewlett-Packard Company has determined that this
product meets the Energy Star guidelines for energy efficiency.
Specific details on using the Energy Saving features can be found
in the energy saver or power management section of the computer
manual.
Power Cord Set Requirements
The monitor power supply is provided with Automatic Line
Switching (ALS). This feature allows the monitor to operate on
input voltages between 100–120V or 200–240V .
The power cord set (flexible cord or wall plug) received with the
monitor meets the requirements for use in the country/region
where you purchased the equipment.
If you need to obtain a power cord for a different country/region,
you should purchase a power cord that is approved for use in that
country/region.
The power cord must be rated for the product and for the voltage
and current marked on the product’s electrical ratings label. The
voltage and current rating of the cord should be greater than the
voltage and current rating marked on the product. In addition, the
cross-sectional area of the wire must be a minimum of 0.75 mm²
or 18AWG, and the length of the cord must be between 6 feet
(1.8 m) and 12 feet (3.6 m). If you have questions about the type
of power cord to use, contact your HP authorized service provider.
A power cord should be routed so that it is not likely to be walked
on or pinched by items placed upon it or against it. Particular
attention should be paid to the plug, electrical outlet, and the point
where the cord exits from the product.
C–4
User’s Guide
D
TCO‘99 Requirements
You have just purchased a TCO’99 approved and labelled
product. Your choice has provided you with a product developed
for professional use. Your purchase has also contributed to
reducing the burden on the environment and also to the further
development of environmentally adapted electronics products.
Why do we have environmentally labelled
computers?
In many countries/regions, environmental labelling has become
an established method for encouraging the adaptation of goods
and services to the environment. The main problem, as far as
computers and other electronics equipment are concerned, is that
environmentally harmful substances are used both in the products
and during their manufacture. Since it is not so far possible to
satisfactorily recycle the majority of electronics equipment, most of
these potentially damaging substances sooner or later enter nature.
User’s Guide
D–1
TCO‘99 Requirements
There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of both
the work (internal) and natural (external) environments. Since all
methods of electricity generation have a negative effect on the
environment (for example, acidic and climate-influencing
emissions, radioactive waste), it is vital to save energy. Electronics
equipment in offices is often left running continuously and thereby
consumes a lot of energy.
What does labelling involve?
This product meets the requirements for the TCO’99 scheme which
provides for international and environmental labelling of personal
computers. The labelling scheme was developed as a joint effort
by the TCO (The Swedish Confederation of Professional
Employees), Svenska Naturskyddsforeningen (The Swedish Society
for Nature Conservation) and Statens Energimyndighet (The
Swedish National Energy Administration).
Approval requirements cover a wide range of issues: Environment,
ergonomics, usability, emission of electric and magnetic fields,
energy consumption and electrical and fire safety.
The environmental demands impose restrictions on the presence
and use of heavy metals, brominated and chlorinated flame
retardants, CFCs (freons) and chlorinated solvents, among other
things. The product must be prepared for recycling and the
manufacturer is obligated to have an environmental policy which
must be adhered to in each country/region where the company
implements its operational policy.
The energy requirements include a demand that the computer
and/or display, after a certain period of inactivity, shall reduce
its power consumption to a lower level in one or more stages. The
length of time to reactivate the computer shall be reasonable for
the user.
Labelled products must meet strict environmental demands, for
example, in respect of the reduction of electric and magnetic
fields, physical and visual ergonomics and good usability.
D–2
User’s Guide
TCO‘99 Requirements
Below you will find a brief summary of the environmental
requirements met by this product. The complete environmental
criteria document may be ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Email (Internet): [email protected]
Current information regarding TCO’99 approved and labelled
products may also be obtained via the Internet, using the address:
http://www.tco-info.com
Environmental Requirements
Flame Retardants
Flame retardants are present in printed circuit boards, cables,
wires, casings and housings. Their purpose is to prevent, or at
least to delay the spread of fire. Up to 30% of the plastic in a
computer casing can consist of flame retardant substances.
Most flame retardants contain bromine or chloride, and those
flame retardants are chemically related to another group of
environmental toxins, PCBs. Both the flame retardants containing
bromine or chloride and the PCBs are suspected of giving rise to
severe health effects, including reproductive damage in fish-eating
birds and mammals, due to the bioaccumulative processes. Flame
retardants have been found in human blood and researchers fear
that disturbances in foetus development may occur.
The relevant TCO’99 demand requires that plastic components
weighing more than 25 grams must not contain flame retardants
with organically bound bromine or chlorine. Flame retardants are
allowed in the printed circuit boards since no substitutes are
available.
Bioaccumulative is defined as substances which accumulate within
living organisms.
User’s Guide
D–3
TCO‘99 Requirements
Cadmium
Cadmium is present in rechargeable batteries and in the
color-generating layers of certain computer displays. Cadmium
damages the nervous system and is toxic in high doses. The
relevant TCO’99 requirement states that batteries, the
color-generating layers of display screens and the electrical
or electronics components must not contain any cadmium.
Cadmium is a heavy metal that is Bioaccumulative.
Mercury
Mercury is sometimes found in batteries, relays and switches.
It damages the nervous system and is toxic in high doses. The
relevant TCO’99 requirement states that batteries may not contain
any mercury. It also demands that mercury is not present in any
of the electrical or electronics components associated with the
labelled unit. There is however one exception. Mercury is, for the
time being, permitted in the back light system of flat panel monitors
as there today is no commercially available alternative. TCO aims
on removing this exception when a mercury free alternative is
available.
Mercury is a heavy metal that is Bioaccumulative.
CFCs (Freons)
The relevant TCO’99 requirement states that neither CFCs nor
HCFCs may be used during the manufacture and assembly of the
product. CFCs (freons) are sometimes used for washing printed
circuit boards. CFCs break down ozone and thereby damage the
ozone layer in the stratosphere, causing increased reception on
earth of ultraviolet light with e.g. increased risks of skin cancer
(malignant melanoma) as a consequence.
D–4
User’s Guide
Lead
Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher doses,
causes lead poisoning. The relevant TCO´99 requirement permits
the inclusion of lead since no replacement has yet been
developed.
Lead is a heavy metal that is Bioaccumulative.
User’s Guide
D–5
D–6
User’s Guide
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
