HP | md5880n | User's Manual | HP MD5880N User's Manual

HP Pavilion
md5020n/md5820n/md5880n/md6580n
High-Definition Microdisplay TV
User’s Guide
Downloaded from www.Manualslib.com manuals search engine
© Copyright 2005 Hewlett-Packard Development Company, L.P.
Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license from Dolby Laboratories.
This TV incorporates High-definition Multimedia Interface (HDMI™) technology. HDMI, the HDMI logo and High-definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC.
SRS TruSurround XT, SRS, and
SRS Labs, Inc.
symbol are trademarks of SRS Labs, Inc. SRS TruSurround XT technology is incorporated under license from
CableCARD™ is a trademark of Cable Television Laboratories, Inc.
Hewlett-Packard Company
Digital Projection and Imaging
1000 NE Circle Blvd.
Corvalis, OR 97330 USA
Edition 1, June 2005
CAUTION: This TV to be used only with the correct size HP audio/video stand designed for this HP microdisplay
TV. Use with other carts or stands is capable of resulting in instability causing possible injury.
Downloaded from www.Manualslib.com manuals search engine
Safety Markings
The following safety markings may be present on the back of the TV or behind the front access door.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symbol
Purpose
This symbol on the TV is intended to alert the user to the presence of uninsulated “dangerous voltage” within
the TV's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to people.
This symbol on the TV is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the TV.
Important Safety Instructions
WARNING! Read and observe these precautions and all others in this manual to reduce the risk of injury and
equipment damage.
Read these instructions.Keep these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
1.
2.
3.
4.
5.
6.
7.
8.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. To avoid personal injury or damage to the TV, use at least two people to lift or move it.
16. If the TV is moved from a cold place, do not turn it on for a few hours so any internal condensation can
evaporate.
17. Install the TV upright on a horizontal, solid, flat surface away from excessive heat, dust, and vibration.
Downloaded from www.Manualslib.com manuals search engine
18. Keep a clearance of at least 10 cm (4 inches) between the vents on the back of the TV and nearby walls or
enclosures. Allow free air circulation to prevent excessive heat buildup that could shut down or damage the
TV. Keep flammable objects or objects susceptible to heat damage at least 0.5 m (2 ft) away from the vents.
19. Do not allow liquid, food, or small objects to get inside the TV. If material gets inside, contact HP for
assistance.
20. Use only an approved power cord rated for the voltage and current marked on the product label. Do not
overload any outlet or extension cord above 80% of its rated power or current rating.
21. Do not remove any parts of the TV except as instructed by this manual, and only after allowing the TV to cool
down.
22. Do not operate the TV with any covers removed. Hazardous voltages exist inside the TV. There are no userserviceable parts inside except as described elsewhere in this manual.
In addition to these general precautions, be sure to observe the following precautions when using external television
antennas and cable systems with your TV. Failure to observe these precautions could result in fire, bodily injury,
and damage to your equipment.
•
•
•
Call the CATV (cable television) system installer's attention to Section 820-40 of the NEC (U.S. National
Electrical Code), which provides guidelines for proper grounding and, in particular, specifies that the cable
ground must be connected to the grounding system of the building, as close to the point of cable entry as
practical.
If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is
electrically grounded to protect against voltage surges and built-up static charges. Article 810 of the US
National Electrical Code, ANSI/NFPA 70, provides information about proper electrical grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode.
Do not place an outside antenna system in the vicinity of overhead power lines or other electric light or
power circuits or where it can fall into power lines or circuits. When installing an outside antenna system,
take extreme care to avoid touching power lines or circuits because contact with them could be fatal.
Item
Description
1
Electric service equipment
2
Power service grounding electrode system (NEC Art 250, Part H)
3
Ground clamps
4
Grounding conductors (NEC Section 810-21)
5
Antenna discharge unit (NEC Section 810-20)
6
Ground clamp
7
Antenna lead-in wir
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The apparatus shall not be exposed to dripping or splashing. No objects filled with liquids, such as vases, shall
be placed on the apparatus.
Downloaded from www.Manualslib.com manuals search engine
