GE Security

0180_EU_Video_Cat_Cover.qxd 19/03/08 13:59 Page 1

Video

Catalogue

VIDEO_intro.indd 1

GE Security,

unrivalled expertise in Video

In this catalogue you will find a wide range of video surveillance equipment including digital recorder devices, cameras, monitors and system accessories from

GE Security.

GE Security is a global technology leader dedicated to meeting the needs of the rapidly growing electronic security and fire industry and to expanding current technologies, products and services that create incremental revenue opportunities for its customers. As part of the

GE family, GE Security shares the spirit of innovation that has distinguished GE for well over 100 years.

Consistent focus on product innovation, first-class service, world-class manufacturing practices and operational excellence underpins GE Security’s commitment to the ongoing success of its business partners and customers.

With manufacturing and logistics operations in Europe, the U.S., Mexico, South Africa and China and 6700 employees, GE Security is a global player in the electronic security and fire industry. And the company has a significant footprint across Europe, the Middle East and

Africa with sales and technical support operations in

24 countries.

GE Security has expertise in all areas of electronic security, including:

• Intrusion and Fire Protection

• Electronic Access and Facility Management

• Key Management and Remote Access Systems

and Services

• Fiber Optic Transmission and Reception

Equipment

• CCTV, Digital Video and Surveillance Equipment

• Video Multiplexing and Digital Storage

When you’re looking for the finest video products with leading-edge surveillance technology and the backing of a world leader, GE Security is your preferred supplier.

19/03/08 11:15:11

Content

Professional Cameras

KTC-463P

KTC-510P

KTC-515P

KTC-541EP

KTC-811CP

KTC-816CP

KTC-841CEP

GEC-EVR2-P

KTC-911P

KTC-2001DNP

KTC-2001DNP OSD

GEC-EVR2-P

GEC-EVR2-DNP

KTC-XP3

GEC-HDR2-P

GEC-HDR2-DNP

Specialist Cameras

TIR-400

TIR-605

MD2

JB-650/P

SD-300

EV-75/CPA

EV-400/CP

EV-500/CPW

KTC-117V3P

ARD-382C

ARD2-662P

GEC-DM2

GEC-DR2

IP Cameras

GEC-IPDR

Specialist Cameras

KTC-ZP-DNP

Lenses

YV2.8x2.8LA-SA2

YV5x2.7R4B-SA2

Housings

CHF270

CHOF270

CWH/270

1/3" 420 TVL, 0.1 lux mono digital cam, 220 VAC

1/3" 450 TVL, 0.1 Lux (F1.2) Monochrome Digital Camera, 12 VDC or 24 VAC

1/3" 600 TVL, 0.1 lux (F1.2) Mono hi-res Digital Camera, 12 VDC or 24 VAC

1/3" 600 TVL,0.01 lux(F1.2) Mono Exview IR Digital Camera, 8

1/3" 380 TVL, 0.5 lux (F1.2) Colour Digital Camera, 85 to 264 VAC

1/3" 480 TVL, 0.5 lux (F1.2) Colour hi-res Digital Camera, 85 to 264 VAC

1/3" 480 TVL, 0.1 lux (F1.2) Ex-View Digital Colour Camera, 85 to 265 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264 VAC

1/3" 480 TVL, 0.3 lux (F1.2) I.R Sensitive Col/mon Digital Camera, 85 to 264 VAC

1/3'' 480 TVL 0.1/0.01 Lux ExView Day/Night Camera, 85 to 264 VAC

1/3'' 480TVL OSD 0.1/0.01 Lux ExView Day/Night Camera, 85 - 264 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264 VAC

1/3'' 540 / 570 TVL, OSD, 0.1/0.05 Lux EVR Day/Night Camera, PAL, 85 - 264 VAC

UltraView, High Resolution, Wide Dynamic Range Camera

1/3'' 500 TVL, OSD, 0.5 Lux Hyper Dynamic Range Camera, PAL, 85 - 264 VAC

1/3'' 500 / 570 TVL, OSD, 0.5/0.1 Lux HDR Day/Night Camera, PAL, 85 - 264 VAC

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 4 mm Lens

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 6 mm Lens

2" Mini-Dome High Res Colour 3-Axis, 480 TVL, 12VDC

Junction Box Camera Colour, 330 TVL, 3.6 mm PH Lens

Side viewing Smoke Detector Camera mono, 380 TVL, 4 mm lens

PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens, audio

PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens

PIR camera colour, 1/3" 330TVL, 3.6mm PH lens, audio, wkg PIR

1/3'' Mono 600 TVL 0.4Lux Varifocal 3.5-8 mm lens 24 VAC

1/4" Rugged hi-res mono dome 3.5-8mm A/I varifocal lens, 12 VDC or 24 VAC

1/3"Rugged 380TVL colour dome 3.5-8 mm A/I varifocal lens,12 VDC or 24 VAC

High-performance dome cameras

DR Series Rugged IP Dome Camera, MPEG-4

High Resolution, Ex-view, Day/Night, Zoomplus camera

1/3" 2.8~8 mm F0.95 to T360, CS Mount

1/3" 2.7~13.5mm F1.3 - T360, CS Mount

Fliptop Housing 270mm & Wall Bracket IP66

Fliptop Housing 270mm IP66 & Cable Management

Indoor Camera Housing & Wall Bracket

Page : 23

Page : 24

Page : 25

Page : 26

Page : 27

Page : 28

Page : 29

Page : 30

Page : 31

Page : 32

Page : 33

Page : 34

Page : 35

Page : 36

Page : 5

Page : 6

Page : 7

Page : 8

Page : 9

Page : 10

Page : 11

Page : 12

Page : 13

Page : 14

Page : 15

Page : 16

Page : 17

Page : 18

Page : 19

Page : 20

Page : 37

Page : 41

Page : 42

Page : 45

Page : 46

Page : 47

CHW270/IP66

CHW300/IP66

CHC300/IP65

Accessories

CB140

CyberDome / Legend

CyberDome

CyberDome II

Legend

Legend-IP

KTA-25

GEA-106

Video Transmission

GE-TTP111VS

GE-TTP414V

GE-TTA111V

GE-TTA414VR

GE-TTA111VRH

GE-TPP016

GE-TPA008

GE-TPA016H

Digiplex

KTD-348-164U

KTD-4M-64x4

Camera Housing & Wall Bracket Heater & Sunshield IP66 230 VAC

Camera Housing & Wall Bracket IP66 230 VAC

Camera housing & Ceiling Bracket IP65 230 VAC

Internal Camera bracket 140mm (ceiling bracket pictured)

Corner mount adapter (stainless steel screws)

Economical, High-Resolution, High-Speed Surveillance Dome

CyberDome II, Next Generation Pan/Tilt/Zoom, Camera

Legend dome, Pan/Tilt, 26x Day/Night camera with Silk Track

Corner Mount Adapter for KTA-20 or KTA-28 CyberDome wall bracket

Legend and CberDome II Pole Mount Adaptor

1 Channel passive video transceiver

4 Channel passive video transceiver

1 Channel Active Video Receiver kit

4 channel active video receiver

Long range active receiver with extra interference rejection

16 channel passive video transceiver

8 channel active video receiver

16 channel active video receiver with extra interference immunity

Interfaces

KTD-463U

Controller Keypad

KTD-400U

KTD-405U

Alarm input chassis

Universal multi-speed Digiplex system control

Variable speed controller keypad

Digital Video Storage Solutions

DIGIA2

DVSR

Digia II - Cost-Effective MPEG-4 Digital Video Recorder

DVSR with advanced H.264 compression technology and up to 400fps

SymSuite

SymNet

SymSafe

SymSafe Pro

SymDec16Plus4

SymNav

Interfaces

CBR-PB3X-POS

16 x 4 Matrix switcher

Digiplex 4 matrix, 64 inputs x 4 outputs,expandable to 512 x 64

SymNet Network Video Streaming Encoder/Decoder

Professional hybrid DVR with 4, 8 or 16 analog inputs & 2 IP streaming ports

High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SymSuite Video Navigation Software

ProBridge 3 POS Interface for SymDVR

Page : 48

Page : 49

Page : 50

Page : 51

Page : 55

Page : 56

Page : 57

Page : 58

Page : 59

Page : 63

Page : 64

Page : 65

Page : 66

Page : 67

Page : 68

Page : 69

Page : 73

Page : 74

Page : 75

Page : 76

Page : 77

Page : 81

Page : 82

Page : 84

Page : 85

Page : 87

Page : 89

Page : 90

Page : 91

Monitors

MV-150A

CV-150HX

LV-15W

LV-15ECO

MBW9-12

DW-170

VideoIQ

VIQ-8HDX

Quad

GEQ-C56

Interfaces

KTD-83U

Video switchers

KTS-250-16U

Power Supplies

KTP-12DCU

High resolution 15" monochrome monitor with audio

High res 15" colour monitor, OSD, dual BNC, U/O scan, audio

15" TFT Flatscreen CCTV monitor

Monitor Bracket Wall mount 9 to 12 inches black

VESA standard wall mount adapter

VideoIQ system

4 Channel Colour Quad

RS422 data signal distributor-provides six separate RS422 outputs

16-Channel distribution amplifier

Universal 12 DC Power Supply

Page : 95

Page : 96

Page : 97

Page : 98

Page : 99

Page : 103

Page : 107

Page : 108

Page : 109

Page : 110

PROFESSIONAL CAMERAS

1/3" 420 TVL, 0.1 lux mono digital cam, 220 VAC

Professional Cameras

Page : 5

KTC-463P

The KTC-463P Hyper HAD CCD based mains voltage digital monochrome camera produces sensitive, clear images. The latest technology DSP (Digital Signal Processing) circuit contributes a number of intelligent features and function controls.

Specifications

Image sensor

Signal system

Picture elements (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Supply voltage

Power consumption

Dimensions (W x H x D)

1/3 in. CCD sensor

CCIR

537 x 597

625 lines

DC internal / AC line lock

420 TV lines

0.1 lux at F1.2

Minimal AGC 0 to18 dB, Super AGC 0 to 36 dB

>48dB

CCD iris mode: 1/50 to 1/100,000 s continuously variable

Auto detect on/off

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

220 VAC

2.5 W (DC) or 4 W (AC)

57 x 52 x 110 mm

Ordering Information

KTC-462P

KTC-463P

1/3" 420 TVL, 0.1 lux mono digital cam, 12VDC / 24VAC

1/3" 420 TVL, 0.1 lux mono digital cam, 220 VAC

High picture quality

Super AGC (36 dB)

Smart Auto BLC

Video drive, direct drive electronic iris control

line-lock

Isolated switching PSU

Switchable gamma

Flickerless Off/On

Mirror option

2x digital zoom

1/3" 450 TVL, 0.1 Lux (F1.2) Monochrome Digital Camera, 12 VDC or 24 VAC

Professional Cameras

Page : 6

KTC-510P

The new range of CamPlus cameras from GE Security comes complete with a host of new features. Thumbwheel back focus adjustment and a stylish new case design with recessed lens socket and concealed control panel. The optional PlusPack further increases their versatility.

Using Hyper-HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.1 lux (@F1.2), with low noise. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Dimensions

1/3 in. CCD sensor

CCIR

537 x 597

625 lines

Internal / line lock

450 TVL

0.1 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 to 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

12 VDC or 24 VAC (KTC-511P: 85 to 264 VAC)

140 x 70 x 50 mm

Standard resolution monochrome camera

Exclusive case design

DC and auto-iris compatible

1/3'' HyperHAD CCD

450 TVL resolution

0.1 Lux sensitivity

Smart backlight compensation

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

DC and auto-iris compatible

Optional PlusPack for UTP video output

Ordering Information

KTC-510P

KTC-511P

1/3" 450 TVL, 0.1 Lux (F1.2) Monochrome Digital Camera, 12

VDC or 24 VAC

1/3" 450 TVL, 0.1 Lux (F1.2) Monochrome Digital Camera, 85 to 264 VAC

1/3" 600 TVL, 0.1 lux (F1.2) Mono hi-res Digital Camera, 12 VDC or 24 VAC

Professional Cameras

Page : 7

KTC-515P

Using Hyper-HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.1 lux (@F1.2), with low noise. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Supply voltage

Dimensions

1/3 in. CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

600 TVL

0.1 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

12 VDC or 24 VAC (KTC-516: 85 to 264 VAC)

140 x 70 x 50 mm

High resolution monochrome camera

Exclusive case design

DC and auto-iris compatible

1/3'' HyperHAD CCD

600 TVL resolution

0.1 Lux sensitivity

Smart backlight compensation

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

Optional PlusPack for UTP video output

Ordering Information

KTC-515P

KTC-516P

1/3" 600 TVL, 0.1 lux (F1.2) Mono hi-res Digital Camera, 12

VDC or 24 VAC

1/3" 600 TVL, 0.1 lux (F1.2) Mono hi-res Digital Camera, 85 to

264 VAC

1/3" 600 TVL,0.01 lux(F1.2) Mono Exview IR Digital Camera, 8

Professional Cameras

Page : 8

KTC-541EP

Using Exview HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.01 lux (@F1.2), with low noise and infrared sensitivity. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Supply voltage

1/3 in. Exview CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

600 TVL

0.01 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50 °C

85 to 264 VAC (KTC-540EP: 12 VDC or 24 VAC)

High resolution monochrome Exview camera with infrared sensitivity

Exclusive GE case design

Discrete DIP switch adjustment

1/3'' Exview HAD CCD

600 TVL resolution

0.01 Lux sensitivity

Smart backlight compensation

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

DC and auto-iris compatible

Optional Pluspack for UTP video output

Ordering Information

KTC-541EP

KTC-540EP

1/3" 600 TVL,0.01 lux(F1.2) Mono Exview IR Digital Camera, 8

1/3" 600 TVL,0.01 lux(F1.2) Mono ExView IR Digital Camera,12

VDC or 24 VAC

1/3" 380 TVL, 0.5 lux (F1.2) Colour Digital Camera, 85 to 264 VAC

Professional Cameras

Page : 9

KTC-811CP

The new range of CamPlus cameras from GE Security comes complete with a host of new features. Thumbwheel back focus adjustment and a stylish new case design with recessed lens socket and concealed control panel.The optional PlusPack further increases their versatility.

Using Hyper-HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.5 lux (@F1.2), with low noise. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of

Histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

The advanced Auto Tracking White balance (ATW) ensures that colour images remain natural, iris gain and white balance is simultaneously controlled so that a clear image is produced even under extreme lighting conditions.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Dimensions

1/3 in. CCD sensor

CCIR

542 x 582

625 lines

Internal / line lock

380 TVL

0.5 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

85 to 264 VAC (KTC-810CP: 12 VDC or 24 VAC)

140 x 70 x 50 mm

Medium resolution colour camera

Exclusive case design

Discrete DIP switch adjustment

1/3'' HyperHAD CCD

380 TVL resolution

0.5 Lux sensitivity

Smart backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

DC and auto-iris compatible

Optional PlusPack for UTP video output.

Ordering Information

KTC-811CP

KTC-810CP

1/3" 380 TVL, 0.5 lux (F1.2) Colour Digital Camera, 85 to 264

VAC

1/3" 380 TVL, 0.5 lux (F1.2) Colour Digital Camera, 12 VDC or

24 VAC

1/3" 480 TVL, 0.5 lux (F1.2) Colour hi-res Digital Camera, 85 to 264 VAC

Professional Cameras

Page : 10

KTC-816CP

Using Hyper-HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.5 lux (@F1.2), with low noise. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Dimensions

1/3 in. CCD sensor

CCIR

542 x 582

625 lines

Internal / line lock

480 TVL

0.5 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

85 to 264 VAC (KTC-815CP: 12 VDC or 24 VAC)

140 x 70 x 50 mm

High resolution colour camera

Exclusive case design

Discrete DIP switch adjustment

1/3'' HyperHAD CCD

480 TVL resolution

0.5 Lux sensitivity

Smart backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

DC and auto-iris compatible

Optional PlusPack for UTP video output

Ordering Information

KTC-816CP

KTC-815CP

1/3" 480 TVL, 0.5 lux (F1.2) Colour hi-res Digital Camera, 85 to

264 VAC

1/3" 480 TVL, 0.5 lux (F1.2) Colour hi-res Digital Camera, 12

VDC or 24 VAC

1/3" 480 TVL, 0.1 lux (F1.2) Ex-View Digital Colour Camera, 85 to 265 VAC

Professional Cameras

Page : 11

KTC-841CEP

Using Exview HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.1 lux (@F1.2), with low noise. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of Camplus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Supply voltage

Dimensions

1/3 in. Exview CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

480 TVL

0.1 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

85 to 264 VAC (KTC-840CEP: 12 VDC or 24 VAC)

140 x 70 x 50 mm

High resolution colour exview camera

Exclusive case design

DC and auto-iris compatible

1/3'' Exview HAD CCD

480 TVL resolution

0.1 Lux sensitivity

Smart backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

Optional PlusPack for UTP video output

Ordering Information

KTC-841CEP

KTC-840CEP

1/3" 480 TVL, 0.1 lux (F1.2) Ex-View Digital Colour Camera, 85 to 265 VAC

1/3" 480 TVL, 0.1 lux (F1.2) ExView Digital Colour Camera, 12

VDC or 24 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264 VAC

Professional Cameras

Page : 12

GEC-EVR2-P

Experience crisp and crystal clear images with GE’s new line of high-resolution CamPlus 2 traditional cameras.

The new line of GEC-EVR cameras delivers a premium resolution of

540TVL. This high performance, custom configurability and a full feature set make this colour camera top of the line.

Using the latest ultra high-resolution sensor technology, the GEC-EVR camera takes surveillance to the next level. Setup is easy with an all-new five-button digital OSD interface. The GEC-EVR cameras work great out of the box, but the digital OSD interface offers control of such features as white balance, gain, and iris control, as well as several other common features.

Like the original CamPlus, the CamPlus 2 cameras offer dual BNC output, power LED indicator, 85 - 264 VAC power input, and a sliding side-control panel to prevent unintended alteration of camera settings. The panel also gives the camera a clean look.

Some of the GEC-EVR’s more advanced features include privacy masking and horizontal/Vertical mirroring.

540 TVL Colour

All Digital On Screen Display (OSD) Graphical User Interface (GUI)

Easy-to-use five-button menu for setup and configuration

Differential resolutions for colour, black-and-white operation

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter:

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Power consumption

Dimensions

1/3 in interline transfer Super HAD CCD

CCIR

795 H x 596 V

625 lines

Internal / Line-lock; phase adjustable

540 TVL colour

0.1 lux @ F1.2 (SAGC on, 30 IRE)

>50 dB

1/50 to 1/100.000 sec. automatic or manually selectable

Automatic

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-20 to +50°C

85 - 264 VAC

3.5 W (DC) / 5 W (AC)

141 x 70 x 52 mm

Ordering Information

GEC-EVR1-P

GEC-EVR2-P

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 12 VDC or 24 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264

VAC

1/3" 480 TVL, 0.3 lux (F1.2) I.R Sensitive Col/mon Digital Camera, 85 to 264 VAC

Professional Cameras

Page : 13

KTC-911P

Using Hyper HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.3 lux (@F1.2), with low noise and infrared sensitivity. Where necessary the super AGC boosts the video signal by another 6 db.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Supply voltage

Power consumption

Dimensions

NOTE: some colour variance may occur with this camera

1/3 in. CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

480 TVL

0.3 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts Video and DC drive iris lens

C and CS mount

-10 to +50°C

85 to 264 VAC (KTC-910P: 12 VDC or 24 VAC)

5 W

140 x 70 x 50 mm

High resolution colour camera with infrared sensitivity

Exclusive case design

Discrete DIP switch adjustment

1/3'' HAD CCD

480 TV lines resolution

0.3 Lux sensitivity

Smart backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

DC and auto-iris compatible

Optional PlusPack vor UTP video output

Colour / mono switching for better image in dark environment

Ordering Information

KTC-911P

KTC-910P

1/3" 480 TVL, 0.3 lux (F1.2) I.R Sensitive Col/mon Digital

Camera, 85 to 264 VAC

1/3"480TVL, 0.3 lux(F1.2) I.R Sensitive Col/mon Digital

Camera,12 VDC or 24 VAC

1/3'' 480 TVL 0.1/0.01 Lux ExView Day/Night Camera, 85 to 264 VAC

Professional Cameras

Page : 14

KTC-2001DNP

The new range of CamPlus cameras from GE Security comes complete with a host of new features. Thumbwheel back focus adjustment and a stylish new case design with recessed lens socket and concealed control panel.The optional PlusPack further increases their versatility

True day/night capability with motorised I/R cut filter for true daytime colour rendition and exceptional I/R sensitivity.

Using Ex-view HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.1 lux day time and 0.01 lux night time

(@F1.2), with low noise.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

High resolution colour monochrome Exview camera

Discrete DIP switch adjustment

DC and auto-iris compatible

480 TVL resolution

0.1/0.01 Lux sensitivity

Smart backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

Optional PlusPack for UTP video output

Image sensor

Signal system

Picture elements (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Dimensions

1/3 in. Exview CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

480 TVL

0.1 / 0.01 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 to 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

85 to 264 VAC (KTC-2000DNP: 12 VDC or 24 VAC)

140 x 70 x 50 mm

Ordering Information

KTC-2001DNP

KTC-2000DNP

1/3'' 480 TVL 0.1/0.01 Lux ExView Day/Night Camera, 85 to

264 VAC

1/3'' 480TVL 0.1/0.01 Lux ExView Day/Night Camera, 12 VDC or 24 VAC

1/3'' 480TVL OSD 0.1/0.01 Lux ExView Day/Night Camera, 85 - 264 VAC

Professional Cameras

Page : 15

KTC-2001DNP OSD

True day/night capability with motorised I/R cut filter for true daytime colour rendition and exceptional I/R sensitivity.

Using Exview HAD CCD sensor technology, the sensitivity of these models is excellent, around 0.1 lux day time and 0.01 lux night time

(@F1.2), with low noise.

Smart Backlight Compensation (BLC) is achieved by a combination of histogram and windows weighted integration of 225 separate windows.

While combining exceptional performance and budgetary constraints, the range of CamPlus cameras is designed to meet today's most demanding surveillance requirements.

Specifications

High resolution Colour Monochrome Exview camera

Advanced On Screen Display adjustment

DC and auto-iris compatible

480 TV lines of resolution in color mode and 540 TV lines of resolution in B/W mode

0.1/0.01 Lux sensitivity

Intelligent light delay switch

Enhanced 4 mode chageover option

255 area programmable backlight compensation

Auto tracking white and automatic white balance options

Thumbwheel back focus adjustment

Recessed lens connector

Local video test monitor output (extra BNC connector)

C and CS mount

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

Gain

S/N ratio

Auto exposure system

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Dimensions

1/3" Exview CCD sensor

CCIR

795 x 596

625 lines

Internal / line lock

480 TVL color, 540TVL B/W

0.1/0.01 lux at F1.2

Super AGC 36 dB

>48 dB

CCD iris mode: 1/50 - 1/100,000 s continuously variable

Auto detect, histogram plus 225 areas windows weight

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-10 to +50°C

85 - 264 VAC

140 x 70 x 50 mm

Ordering Information

KTC-2001DNP OSD

KTC-2000DNP OSD

1/3'' 480TVL OSD 0.1/0.01 Lux ExView Day/Night Camera, 85

- 264 VAC

1/3'' 480TVL OSD 0.1/0.01 Lux ExView Day/Night Camera, 12

VDC or 24 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264 VAC

Professional Cameras

Page : 16

GEC-EVR2-P

Experience crisp and crystal clear images with GE’s new line of high-resolution CamPlus 2 traditional cameras.

The new line of GEC-EVR cameras delivers a premium resolution of

540TVL. This high performance, custom configurability and a full feature set make this colour camera top of the line.

Some of the GEC-EVR’s more advanced features include privacy masking and horizontal/Vertical mirroring.

540 TVL Colour

All Digital On Screen Display (OSD) Graphical User Interface (GUI)

Easy-to-use five-button menu for setup and configuration

Differential resolutions for colour, black-and-white operation

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter:

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Power consumption

Dimensions

1/3 in interline transfer Super HAD CCD

CCIR

795 H x 596 V

625 lines

Internal / Line-lock; phase adjustable

540 TVL colour

0.1 lux @ F1.2 (SAGC on, 30 IRE)

>50 dB

1/50 to 1/100.000 sec. automatic or manually selectable

Automatic

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-20 to +50°C

85 - 264 VAC

3.5 W (DC) / 5 W (AC)

141 x 70 x 52 mm

Ordering Information

GEC-EVR1-P

GEC-EVR2-P

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 12 VDC or 24 VAC

1/3'' 540 TVL, OSD, 0.1 Lux EVR Colour Camera, PAL, 85 - 264

VAC

1/3'' 540 / 570 TVL, OSD, 0.1/0.05 Lux EVR Day/Night Camera, PAL, 85 - 264 VAC

Professional Cameras

Page : 17

GEC-EVR2-DNP

Experience crisp and crystal clear images with GE’s new line of high-resolution CamPlus 2 traditional cameras.

The new line of GEC-EVR cameras delivers a premium resolution of

540TVL in colour and 570 TVL in black and white. This high performance, custom configurability and a full feature set make this camera top of the line and usable for just about any application.

Some of the GEC-EVR’s more advanced features include privacy masking and horizontal/Vertical mirroring. For Day/Night CamPlus 2 models, the colour and monochrome settings can each have different resolutions to best optimize low-light needs.

540 TVL Colour, 570 TVL black and white

All Digital On Screen Display (OSD) Graphical User Interface (GUI)

Easy-to-use five-button menu for setup and configuration

Differential resolutions for colour, black-and-white operation

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter:

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Power consumption

Dimensions

1/3 in interline transfer Super HAD CCD

CCIR

795 H x 596 V

625 lines

Internal / Line-lock; phase adjustable

540 TVL colour; 570 TVL b/w

0.1/0.05 lux @ F1.2 (SAGC on, 30 IRE)

>50 dB

1/50 to 1/100.000 sec. automatic or manually selectable

Automatic

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-20 to +50°C

85 - 264 VAC

4.8 W (DC) / 6 W (AC)

141 x 70 x 52 mm

Ordering Information

GEC-EVR1-DNP

GEC-EVR2-DNP

1/3'' 540 / 570 TVL, OSD, 0.1/0.05 Lux Day/Night Camera,

PAL, 12 VDC or 24 VAC

1/3'' 540 / 570 TVL, OSD, 0.1/0.05 Lux EVR Day/Night

Camera, PAL, 85 - 264 VAC

UltraView, High Resolution, Wide Dynamic Range Camera

Professional Cameras

Page : 18

KTC-XP3

CAMERA

Image device

Dynamic range

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Resolution

Sensitivity

S/N ratio

Colour balance

Gain

Gamma

Video out

Lens selection

Lens mount

PHYSICAL

Dimensions (L x W x D)

Weight

ELECTRICAL

Input Voltage

Power consumption

Power source

ENVIRONMENTAL

GE’s UltraView KTC-XP3 is the next generation in wide dynamic range cameras. Like the first generation KTC-XP1, the UltraView XP3 uses the latest XPosure™ image analysis technology to provide worldleading performance in challenging lighting conditions combined with dramatically improved low-light performance.

XPosure technology optimizes the exposure for each pixel on the sensor, showing details in shadows and highlights. This performance allows every detail to be captured accurately even in the most difficult lighting conditions such as lobbies, loading docks, retail applications and ATMs with bright backlight.

Unlike traditional CCD cameras, which can only read the light hitting the sensor once, XPosure™ can read the sensor several dozen times per second and optimize each pixel’s exposure level. In effect, each pixel gets its own analog to- digital (ADC) converter. The result is a dynamic range 100 times better than standard CCD cameras–over 95 db in normal operations compared to 48 to 60 db on other cameras. And unlike CCD WDR solutions, XPosure performs without dropping frames or frame averaging.

Another revolutionary feature of the UltraView XP3 is dual-temperature calibration. All cameras get hot, and when they do, they perform differently than when they are first set up. The KTC-XP3 is dual-temperature calibrated at the factory, so the camera knows how to adjust gain, white balance and other settings based on its environment. The camera is then able to get the best possible images in any situation and at any temperature.

Specifications

Operating temperature

REGULATORY

Approvals

-10 to + 60°C

UL, CUL, FCC, CE

Ordering Information

KTC-XP3 UltraView, High Resolution, Wide Dynamic Range Camera

1/3 in. sensor GE Security XPosure technology

95 dB typical / 120 dB max.

NTSC / PAL selectable

720 x 540

525/60 lines (NTSC); 625/50 lines (PAL)

Internal / AC linelock

540 TVL

0.5 lux at f1.2, 30 IRE

52 dB

ATW, AWB

AGC on/off, fully programmable

0.45 (NTSC) / 0.36 (PAL)

Composite: 1 V pk-pk at 75 ohm load

Accepts manual, video or DC auto iris lenses

C and CS mount

125 x 75 x 54 mm

411 g

12 VDC or 24 VAC

3.0 W (12 VDC), 3.5 W (24 VAC)

11 to 30 VDC or 18 to 30 VAC

Next-generation XPosure technology

Improves on original UltraView camera's low light peformance and colour balance

Uses less power

NTSC / PAL selectable in one camera

540 TVL resolution

Dynamic range 95 dB (typical), 120 dB (max)

Accepts manual, DC, and video autoiris lenses

Preset modes optimized for various environments

5-button on-screen display interface

Dual Temperature Calibration

1/3'' 500 TVL, OSD, 0.5 Lux Hyper Dynamic Range Camera, PAL, 85 - 264 VAC

Professional Cameras

Page : 19

GEC-HDR2-P

Experience crisp and crystal clear images with GE’s new line of high-resolution CamPlus 2 traditional cameras.

The new line of GEC-HDR cameras delivers a premium resolution of

500TVL. Combined with custom configurability and a full feature set, the GEC-HDR is a great general purpose colour camera.

The GEC-HDR camera accomplishes its Wide Dynamic Range functionality by taking two images for each frame — one image is slightly overexposed, the other slightly underexposed. A lightning fast

DSP core inside the camera takes both images and analyzes each for the best developed pixel, then combines the two images for a single frame of optimized video. Using the latest ultra high-resolution sensor technology, the GEC-HDR takes surveillance to the next level.

Setup is easy with an all new five button digital OSD interface. The

GEC-HDR camera work great out of the box, but the digital OSD interface offers control of such features as dynamic range, white balance, gain, and iris control as well as several other common and advanced features.

Like the original CamPlus, CamPlus 2 offers dual-BNC output, power

LED indicator, universal 12 VDC / 24 VAC or 230 VAC power input, and a sliding side-control panel to prevent unintended alteration of camera settings and to give the camera a clean look.

Some of the GEC-HDR’s more advanced features include privacy masking, digital zoom and horizontal/Vertical mirroring. The

GEC-HDR offers the perfect blend of wide-dynamic performance and high-resolution to make it the most versatile colour camera available today.

Ordering Information

GEC-HDR2-P 1/3'' 500 TVL, OSD, 0.5 Lux Hyper Dynamic Range Camera,

PAL, 85 - 264 VAC

500 TVL Colour resolution

All Digital On Screen Display (OSD) Graphical User Interface (GUI)

Easy-to-use five-button menu for setup and configuration

Wide Dynamic Range and low-light performance combined

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter:

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

Power supply

Power consumption

Dimensions

1/3 in interline transfer Super HAD CCD

CCIR

795 H x 596 V

625 lines

Internal / Line-lock; phase adjustable

500 TVL colour

0.5 lux @ F1.2 (AGC on, 30 IRE)

>50 dB

1/50 to 1/100.000 sec. automatic or manually selectable

Automatic

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-20 to +50°C

85 - 264 VAC

4.2 W (DC) / 4.5 W (AC)

141 x 70 x 52 mm

1/3'' 500 / 570 TVL, OSD, 0.5/0.1 Lux HDR Day/Night Camera, PAL, 85 - 264 VAC

Professional Cameras

Page : 20

GEC-HDR2-DNP

Experience crisp and crystal clear images with GE’s new line of high-resolution CamPlus 2 traditional cameras.

The new line of GEC-HDR cameras delivers a premium resolution of

500TVL in colour and 570 TVL in black and white. Moreover it offers a great blend of low-light performance and wide-dynamic range performance. Combined with custom configurability and a full feature set, the GEC-HDR is a great general purpose camera that can be used for just about any application.

The GEC-HDR camera accomplishes its Wide Dynamic Range functionality by taking two images for each frame — one image is slightly overexposed, the other slightly underexposed. A lightning fast

Setup is easy with an all new five button digital OSD interface. The

Like the original CamPlus, CamPlus 2 offers dual-BNC output, power

LED indicator, universal 12 VDC / 24 VAC or 230 VAC power input, and a sliding side-control panel to prevent unintended alteration of camera settings and to give the camera a clean look.

Some of the GEC-HDR’s more advanced features include privacy masking, digital zoom and horizontal/Vertical mirroring. The

GEC-HDR offers the perfect blend of wide-dynamic performance, low-light performance and high-resolution to make it the most versatile camera available today.

Power supply

Power consumption

Dimensions

Ordering Information

GEC-HDR1-DNP

GEC-HDR2-DNP

1/3'' 500 / 570 TVL, OSD, 0.5/0.1 Lux HDR Day/Night Camera,

PAL,12 VDC or 24 VAC

1/3'' 500 / 570 TVL, OSD, 0.5/0.1 Lux HDR Day/Night Camera,

PAL, 85 - 264 VAC

85 - 264 VAC

5.5 W (DC) / 5.8 W (AC)

141 x 70 x 52 mm

500 TVL Colour, 570 TVL black and white

All Digital On Screen Display (OSD) Graphical User Interface (GUI)

Easy-to-use five-button menu for setup and configuration

Differential resolutions for colour, black-and-white operation

Wide Dynamic Range and low-light performance combined

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter:

Back light compensation

Gamma

Video out

Auto iris lens

Lens mount

Operating temperature

1/3 in interline transfer Super HAD CCD

CCIR

795 H x 596 V

625 lines

Internal / Line-lock; phase adjustable

500 TVL colour; 570 TVL b/w

0.5/0.1 lux @ F1.2 (AGC on, 30 IRE)

>50 dB

1/50 to 1/100.000 sec. automatic or manually selectable

Automatic

On = 0.45; Off = 1

Composite: 1 V pk-pk at 75 ohm load

Accepts video and DC drive iris lens

C and CS mount

-20 to +50°C

SPECIALIST CAMERAS

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 4 mm Lens

Specialist Cameras

Page : 23

TIR-400

These cameras are attractive and easy to install. They are waterproof and automatically switch on built-in miniature LED's when light levels drop to illuminate the area within the field of view.

Specifications

Image sensor

Horizontal resolution

Lens

Electronic shutter

Sensitivity

Gamma

Video out

Supply voltage

Power

Effective distance with LEDs

IP rating

Operating temperature

Dimensions

Weight

1/3 in. CCD sensor

330 TVL

4 mm / F2.5

1/3 ~ 1/10000 sec.

0.5 lux or 0 lux under IR illumination

0.45

Composite: 1 V pk-pk at 75 ohm load

12 VDC (PSU incl.)

2.2 W (IR LED off) and 3.72 W (IR LED on)

10 m

IP68

-10 to +50°C

105 x 65 x 62 mm

640 g

Ordering Information

TIR-400

TIR-300

TIR-600

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 4 mm Lens

330 TVL Day/Night, IP65, Built-In LED's 3.6 mm Lens

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 6 mm Lens

Mounts on wall or ceiling

Light grey aluminium waterproof housing

Good sensitivity

Adjustable camera position

Standard resolution colour

Automatic light sensor to illuminate built-in LEDs

Complete with 12 VDC power supply and bracket

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 6 mm Lens

Specialist Cameras

Page : 24

TIR-605

These cameras are attractive and easy to install. They are waterproof and automatically switch on built-in miniature LEDs when light levels drop to illuminate the area within the field of view.

Specifications

Image sensor

Horizontal resolution

Lens

Electronic shutter

Sensitivity

Gamma

Video out

Power supply

Power

Effective distance with LEDs

IP rating

Operating temperature

Dimensions

Weight

1/3 in. CCD sensor

520TVL

6 mm / F2.5

1/3 ~ 1/10000 sec.

0.5 lux or 0 lux under IR illumination

0.45

Composite: 1 V pk-pk at 75 ohm load

12 VDC (PSU incl.)

2.2 W (IR LED off) and 3.72 W (IR LED on)

10 m

IP68

-10 to +50°C

105 x 65 x 62 mm

640 g

Ordering Information

TIR-405

TIR-605

W/proof, 520 TVL day/night camera, built-in LED illuminators- 4.3mm

Colour, 330 TVL Day/Night, IP68, Built-In LED Illuminators 6 mm Lens

Mounts on wall or ceiling

Light grey aluminium waterproof housing

Good sensitivity

Adjustable camera position

Standard resolution colour

Automatic light sensor to illuminate built-in LEDs

Complete with12 VDC power supply and bracket

2" Mini-Dome High Res Colour 3-Axis, 480 TVL, 12VDC

Specialist Cameras

Page : 25

MD2

For indoor applications where discreet security is required, the

MiniView Dome camera is an excellent solution. Measuring just 2 inches across, the MiniView delivers a high-resolution, color image with backlight compensation and automatic white balance.

Specifications

Image sensor

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

AGC

Display color

Back light compensation

Video out

Operating temperature

Power consumption

Dimensions(including bracket)

1/3 in. interline transfer super HAD CCD

PAL

795 x 596

625 lines, 2:1 interlace

Internal lock

480 TVL

1.0 lux @ f1.2; 0.1 lux (faceplate)

> 50 dB (AGC off)

Max 30 dB

6-bit; 262,144 colors

Automatic histogram on (under AES), center window weighted

1.0 V pk-pk

-10 to +50°C

12 VDC - 115 mA, 1.38 W (when using adapter cable,

24 VAC - 70mA, 1.68W)

(HxWxD) 51 x 57 x 70 mm

Ordering Information

MD2-1500

Discreet, high-resolution surveillance

12 VDC input voltage

Includes 12 VDC to 24 VAC adapter cable

Easy to install

Indoor wall-mount bracket included

Comes with a lens pack that includes 2.5 mm, 4 mm, and 6 mm lenses

Dome shroud conceals camera position

Junction Box Camera Colour, 330 TVL, 3.6 mm PH Lens

Specialist Cameras

Page : 26

JB-650/P

One of a range of covert cameras designed for the professional security installer using the latest miniature camera technology.

Specifications

Image sensor

Horizontal resolution

Electronic shutter

Sensitivity

Video out

Supply voltage

Operating temperature

Weight

1/3 in. CCD sensor

>330 TVL

Automatic linear shutter

1.5 lux

Composite: 1 V pk-pk at 75 ohm load

12 VDC ±10%

-10 to +40°C

325 g

Ordering Information

JB-650/P

JB-350/P

Junction Box Camera Colour, 330 TVL, 3.6 mm PH Lens

Junction box camera mono, 380 TVL, 3.6 mm PH Lens

Tough, die-cast aluminium housing

A very popular and effective covert camera

Blends into many industrial or commercial environments

Comes with free power supply

Comes with lint-free cleaning cloth to remove grease and dirt from case and lens

Lens : 3.6 mm pinhole

Side viewing Smoke Detector Camera mono, 380 TVL, 4 mm lens

Specialist Cameras

Page : 27

SD-300

A miniature camera concealed inside a unique purpose built smoke detector case. providing a side viewing.

Specifications

Image sensor

Horizontal resolution

Electronic shutter

Sensitivity

Video out

Power supply

Operating temperature

Weight

1/3 in. CCD sensor

>380 TVL

Automatic linear shutter

0.2 lux

Composite: 1 V pk-pk at 75 ohm load

12 VDC ±10%

-10 to +40°C

85 g

Ordering Information

SD-300

SD-600

SD-600/P

Side viewing Smoke Detector Camera mono, 380 TVL, 4 mm lens

Side viewing Smoke Detector Camera Colour, 330 TVL, 4 mm

Lens

Vertical viewing Smoke Detector Camera Colour, 330 TVL, 3.6

mm PH Lens

Camera completely concealed behind a unique one-way viewing mesh

Camera mounted on a manually adjustable `swivel and tilt` cradle to enable exact camera positioning

Housings conceals a vertical-viewing camera with pinhole lens

Comes with free power supply

Comes with lint-free cleaning cloth to remove grease and dirt from case and lens

Lens : 3.6 mm (pinhole)

PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens, audio

Specialist Cameras

Page : 28

EV-75/CPA

One of a range of PIR cameras designed for the professional security installer using the latest miniature camera technology.

Specifications

Image sensor

Horizontal resolution

Electronic shutter

Sensitivity

Video out

Supply voltage

Operating temperature

Audio in

Audio out

Audio bandwidth

Dimensions

1/3 in. CCD sensor

>330 TVL

Automatic linear shutter

10 lux

Composite: 1 V pk-pk at 75 ohm load

12 VDC ±10%

-5 to +40°C

Microphone omni-directional electret

Audio output 1 V pk-pk, 600 ohm

100 Hz to 10 KHz, ±3 dB

92 x 50 x 33 mm

Ordering Information

EV-75/CPA PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens, audio

An ideal camera for detecting rather than deterring crime

Excellent picture quality

Discreet, stylish case designed to blend inconspicuously into any commercial environment

Ideal for use where EV 75 detectors are already installed

Camera views through tiny 1.5 mm diameter hole for maximum discretion

Comes with pre-focused (1m - ¥) factory-fitted lens

Ideal for the video verification of alarms

Simple and speedy to install

Comes with versatile wall or ceiling mount bracket for exact camera positioning

Comes with audio capability

PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens

Specialist Cameras

Page : 29

EV-400/CP

One of a range of PIR cameras designed for the professional security installer using the latest miniature camera technology.

Specifications

Image sensor

Horizontal resolution

Electronic shutter

Sensitivity

Video out

Supply voltage

Operating temperature

Dimensions

1/3 in. CCD sensor

>330 TVL

Automatic linear shutter

10 lux

Composite: 1 V pk-pk at 75 ohm load

12 VDC ±10%

-5 to +40°C

103 x 71 x 51 mm

Ordering Information

EV-400/CP

EV-400/CS

PIR camera colour, 1/3" 330 TVL, 3.6 mm PH lens

PIR camera colour, 1/3" 330TVL, 4mm lens

An ideal camera for detecting rather than deterring crime

Excellent picture quality

Discreet, stylish case designed to blend inconspicuously into any commercial environment

Ideal for use where EV 400 detectors are already installed

Camera views through tiny 1.5 mm diameter hole for maximum discretion

Comes with pre-focused (1m - ¥) factory-fitted lens

Ideal for the video verification of alarms

Simple and speedy to install

Comes with versatile wall or ceiling mount bracket for exact camera positioning

PIR camera colour, 1/3" 330TVL, 3.6mm PH lens, audio, wkg PIR

Specialist Cameras

Page : 30

EV-500/CPW

One of a range of PIR cameras designed for the professional security installer using the latest miniature camera technology.

Specifications

Image sensor

Horizontal resolution

Electronic shutter

Sensitivity

Video out

Supply voltage

Operating temperature

Dimensions

1/3 in. CCD sensor

>330 TVL

Automatic linear shutter

10 lux

Composite: 1 V pk-pk at 75 ohm load

12 VDC ±10%

-18 to +60°C

124 x 72 x 50 mm

Ordering Information

EV-500/CPW PIR camera colour, 1/3" 330TVL, 3.6mm PH lens, audio, wkg

PIR

An ideal camera for detecting rather than deterring crime

Complete with operational PIR

Excellent picture quality

Discreet, stylish case designed to blend inconspicuously into any commercial environment

Ideal for use where EV 500 detectors are already installed

Comes with pre-focused (1m - ¥)

factory-fitted lens

Ideal for the video verification of alarms

Simple and speedy to install

Can be used to trigger a VCR or video switcher to which the camera is connected

Contains anti-tamper switch and 'normally-closed' alarm switch

No long range mirror or crawl detection as in EV 500 detector

1/3'' Mono 600 TVL 0.4Lux Varifocal 3.5-8 mm lens 24 VAC

Specialist Cameras

Page : 31

KTC-117V3P

The KTC-117V3P is a high resolution, compact, B/W camera with integral varifocal DC auto iris lens. The ExpressCam camera series is designed for easy installation and also includes a mounting bracket and power supply.

The KTC-117V3P offers 600 lines of resolution, high sensitivity (0.4 lux), and advanced digital signal processing.

The KTC-117V3P features digital signal processing. Its automatic backlight compensation prevents important foreground objects from becoming silhouetted against bright backgrounds.

Specifications

Image device

Signal system

Pixels (H x V)

Scanning system

Synchronisation

Horizontal resolution

Sensitivity

S/N ratio

Electronic shutter

Auto back light compensation

Video out

Lens

Operating temperature

Power source

Power consumption

Weight

1/3 in. high-sensitivity Super HAD CCD

CCIR

625/50 lines

AC line lock

600 TVL

0.4 lux at f1.2

>50 dB

1/50 (1/60) - 1/100,000 s, automatic

Off/On

Composite: 1 V pk-pk at 75 ohm load

Integral 3.5 to 8 mm

-20 to +50°C

24 VAC

1.7 W

221 g

Integrated DC auto iris 3.5-8 mm Varifocal lens

600 TVL Medium resolution monochrome camera

0.4 lux sensitivity @ f1.2

All in one package

24 VAC

Advanced digital signal processing

Digital automatic backlight compensation

Ordering Information

KTC-117V3P

KTC-107V3P

KTC-207CV3P

KTC-217CV3P

1/3'' Mono 600 TVL 0.4Lux Varifocal 3.5-8 mm lens 24 VAC

1/3'' Mono 420 TVL 0.1Lux Varifocal 3.5-8mm lens 24Vac

1/3'' Colour 380 TVL 2.0Lux Varifocal 3.5-8mm lens 24Vac

1/3'' Colour 460 TVL 2.0 Lux Varifocal 3.5-8 mm lens 24 VAC

1/4" Rugged hi-res mono dome 3.5-8mm A/I varifocal lens, 12 VDC or 24 VAC

Specialist Cameras

Page : 32

ARD-382C

The weatherproof, vandal resistant rugged dome features a die-cast housing, an impact-resistant Lexan dome, tamperproof screws and a hinged cover for easy setup. A durable gasket on the base of the rugged dome provides a watertight seal to protect the camera. It will withstand temperatures ranging from -10 °C to +50 °C.

Specifications

Image sensor

Resolution

Sensitivity

Picture elements (H x V)

Scanning system

S/N ratio

Synchronisation

Gamma

Video out

Electronic shutter

Power supply

Power consumption

Operating temperature

Weight

Dimensions (Ø x H)

1/4" interline transfer Sony super HAD CCD

580 TVL

0.3 lux at F1.4

795 x 596

625 lines, 50 fields PAL

>50 dB (AGC off) AGC: Max. 36 dB

Internal/line lock AC (phase adjustable)

0.45

1 V pk-pk at 75 ohm load

1/50 - 1/100,000 sec.

10 to 40 VDC or 18 to 30 VAC

1.5 W at 12 VDC

-10 to +50°C

820 g

136 x 102 mm

Weatherproof housing

Tamperproof screws and a Lexan dome for vandal resistance

Hinged cover for easy adjustment and setup

High-resolution monochrome camera

3.5 to 8 mm varifocal Auto Iris lens option

Ordering Information

ARD-382C

ARD-682P

ARD-982P

DR-FM

DR-RWM

1/4" Rugged hi-res mono dome 3.5-8mm A/I varifocal lens,

12 VDC or 24 VAC

1/4"Rugged hi-res colour dome 3.5-8mm A/I Varifocal

Lens,12 VDC or 24 VAC

1/4"Rugged hi-res col/mono dome 3.5-8mm A/I varifocal lens,12 VDC or 24 VAC

ARD Flush ceiling mount bracket

ARD Wall mount bracket

1/3"Rugged 380TVL colour dome 3.5-8 mm A/I varifocal lens,12 VDC or 24 VAC

Specialist Cameras

Page : 33

ARD2-662P

The weatherproof, vandal resistant rugged dome features a new design of die-cast housing, an impact-resistant Lexan dome, tamperproof screws and a hinged cover for easy setup. A durable gasket on the base of the rugged dome provides a watertight seal to protect the camera. It will withstand temperatures ranging from -10

°C to +50 °C.

Specifications

Image sensor

Resolution

Sensitivity

Pixels (H x V)

Scanning system

S/N ratio

Synchronisation

Gamma

Video out

Electronic shutter

Power supply

Power consumption

Operating temperature

Weight

Dimensions (Ø x H)

1/3" interline transfer Sony super HAD CCD

380 TVL

2 lux at F1.6

542 x 582

625 lines, 50 fields PAL

>48 dB (AGC off) AGC: Max. 36 dB

Internal/line lock AC (phase adjustable)

0.45

1 V pk-pk at 75 ohm load

1/50 - 1/100,000 sec.

10 to 40 VDC or 18 to 30 VAC

3.5 W at 12 VDC

-10 to +50°C

820 g

149 x 102 mm

New stylish design

Weatherproof housing

Tamperproof screws and a Lexan dome for vandal resistance

Hinged cover for easy adjustment and setup

High-resolution monochrome camera

3.5 to 8 mm varifocal Auto Iris lens option

Ordering Information

ARD2-662P

ARD2-682P

ARD2-XDNP

1/3"Rugged 380TVL colour dome 3.5-8 mm A/I varifocal lens,12 VDC or 24 VAC

1/3"Rugged 480 TVL Colour Dome 3.5-8 mm A/I Varifocal

Lens,12 VDC or 24 VAC

1/4" Rugged 480TVL Col D/N dome 3.5-8mm A/I varifocal lens,12 VDC or 24 VAC

High-performance dome cameras

Specialist Cameras

Page : 34

GEC-DM2

DMX (XP3)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

Auto Exposure

Manual Exposure

Operating Temperature

Input Voltage

Power Consumption

DMH (HDR)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

Auto Exposure

Manual Exposure

Operating Temperature

Input Voltage

Power Consumption

DME (EVR)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

The DM2 security camera provide high-quality surveillance images in a variety of discreet commercial applications. DM2 dome can be mounted in a variety of positions including wall mount, ceiling mount, flush mount (DR2 only), and pendant mount.

Specifications

1/3-in. GE Xposure

95 dB typical, 120 dB max

NTSC/PAL Selectable

525/60 (NTSC); 625/50 (PAL)

Internal/Line Lock AC

720

520TVL

0.5 lux @ f1.2, 30 IRE

ATW, ATW-Extend

Horizontal

-58 to 122°F (-50 to 50°C)

24 VAC or 12 VDC

3W (DC); 2.4 W (AC)

Auto Exposure

Manual Exposure

Input Voltage

Power Consumption

Ordering Information

GEC-DMX-VA3

GEC-DMX-VA9

GEC-DMHDN-VA3

GEC-DMHDN-VA9

GEC-DMHDNP-VA3

GEC-DMHDNP-VA9

GEC-DMH-VA3

GEC-DMH-VA9

GEC-DMHP-VA3

GEC-DMHP-VA9

GEC-DME-VA3

GEC-DME-VA9

GEC-DMEP-VA3

GEC-DMEP-VA9

3.3-12mm Varifocal Autoiris, 12VDC/24VAC

9-22mm Varifocal Autoiris, 12VDC/24VAC

Day/Night, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

Day/Night, 9-22mm Varifocal Autoiris, 12VDC/24VAC, NTSC

Day/Night, PAL, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC,

NTSC

Day/Night, PAL, 9-22mm Varifocal Autoiris, 12VDC/24VAC

3.3-12mm Varifocal Autoiris, 12VDC/24VAC, NTSC

9-22mm Varifocal Autoiris, 12VDC/24VAC, NTSC

PAL, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC

PAL, 9-22mm Varifocal Autoiris, 12VDC/24VAC

3.3-12mm Varifocal Autoiris, 12VDC/24VAC, NTSC

9-22mm Varifocal Autoiris, 12VDC/24VAC, NTSC

PAL, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC

PAL, 9-22mm Varifocal Autoiris, 12VDC/24VAC

1/3-in. interline transfer WDR Super HAD CCD

52 dB

NTSC or PAL standard

525 (NTSC), 625 (PAL); 2:1 Interlace

Up to 4X

DC Internal/AC Line Lock

795

500TVL color

0.5 lux @ f1.2, 30 IRE

ATW, AWB

8 areas ON/OFF, color, position, size adjustable

Horizontal, Vertical, 180°

1/60 (1/50) sec

1/60 (1/50), 1/120, 1/250, 1/500, 1/1000, 1/2000,

1/5000, 1/10000 sec. (only in normal light mode)

-22 to 122°F (-30 to 50°C)

24 VAC or 12 VDC

3.4W (DC);2.9 W (AC)

Digital signal processing

Excellent performance in most lighting conditions

Choice of sensor devices for any application

UltraView technology available

Uses a true “3-Axis Gimble” which allows for optimization of the field of view level regardless of mounting location

Polycarbonate dome with captive shroud for easy installation, vandal resistance and to conceal camera position

Heavy-duty indoor/outdoor and lightweight indoor options

(Rugged Dome housing is IP66 rated)

12 VDC/24 VAC

Six preset modes and one customized mode for use in common lighting conditions

On-screen display menu walk users through options

Secondary BNC output inside the dome bubble for local test monitor during setup

High-performance dome cameras

Specialist Cameras

Page : 35

GEC-DR2

DMX (XP3)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

Auto Exposure

Manual Exposure

Operating Temperature

Input Voltage

Power Consumption

DMH (HDR)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

Auto Exposure

Manual Exposure

Operating Temperature

Input Voltage

Power Consumption

DME (EVR)

Sensor

Dynamic Range

Signal System

Scanning System

Digital Zoom

Synchronization

Horizontal Resolution

Vertical Resolution

Sensitivity

Color Balance

Masking

Mirror

The DR2 security camera provide high-quality surveillance images in a variety of discreet commercial applications. DR2 dome can be mounted in a variety of positions including wall mount, ceiling mount, flush mount, and pendant mount.

Specifications

1/3-in. GE Xposure

95 dB typical, 120 dB max

NTSC/PAL Selectable

525/60 (NTSC); 625/50 (PAL)

Internal/Line Lock AC

720

520TVL

0.5 lux @ f1.2, 30 IRE

ATW, ATW-Extend

Horizontal

-58 to 122°F (-50 to 50°C)

24 VAC or 12 VDC

3W (DC); 2.4 W (AC)

Auto Exposure

Manual Exposure

Input Voltage

Power Consumption

Ordering Information

GEC-DRX-VA3

GEC-DRX-VA9

GEC-DRHDN-VA3

GEC-DRHDN-VA9

GEC-DRHDNP-VA3

GEC-DRHDNP-VA9

GEC-DRH-VA3

GEC-DRH-VA9

GEC-DRHP-VA3

GEC-DRHP-VA9

GEC-DRE-VA3

GEC-DRE-VA9

GEC-DREP-VA3

GEC-DREP-VA9

3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

9-22mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

Day/Night, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

Day/Night, 9-22mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

Day/Night, PAL, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC

Day/Night, PAL, 9-22mm Varifocal Autoiris, 12VDC/24VAC

3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

9-22mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

PAL, 3.3-12mm Varifocal Autoiris, 12VDC/24VAC

PAL, 9-22mm Varifocal Autoiris, 12VDC/24VAC

3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

9-22mm Varifocal Autoiris, 12VDC/24VAC ,NTSC

3.3-12mm Varifocal Autoiris, 12VDC/24VAC ,PAL

9-22mm Varifocal Autoiris, 12VDC/24VAC ,PAL

1/3-in. interline transfer WDR Super HAD CCD

52 dB

NTSC or PAL standard

525 (NTSC), 625 (PAL); 2:1 Interlace

Up to 4X

DC Internal/AC Line Lock

795

500TVL color

0.5 lux @ f1.2, 30 IRE

ATW, AWB

8 areas ON/OFF, color, position, size adjustable

Horizontal, Vertical, 180°

1/60 (1/50) sec

1/60 (1/50), 1/120, 1/250, 1/500, 1/1000, 1/2000,

1/5000, 1/10000 sec. (only in normal light mode)

-22 to 122°F (-30 to 50°C)

24 VAC or 12 VDC

3.4W (DC);2.9 W (AC)

Digital signal processing

Excellent performance in most lighting conditions

Choice of sensor devices for any application

UltraView technology available

Uses a true “3-Axis Gimble” which allows for optimization of the field of view level regardless of mounting location

Polycarbonate dome with captive shroud for easy installation, vandal resistance and to conceal camera position

Heavy-duty indoor/outdoor and lightweight indoor options

(Rugged Dome housing is IP66 rated)

12 VDC/24 VAC

Six preset modes and one customized mode for use in common lighting conditions

On-screen display menu walk users through options

Secondary BNC output inside the dome bubble for local test monitor during setup

DR Series Rugged IP Dome Camera, MPEG-4

IP Cameras

Page : 36

GEC-IPDR

The CamPlus IP Rugged Dome Camera replaces a traditional analog dome with the latest camera sensor and data signal processing technology for sharp MPEG-4 compression to send images quickly and easily over the network. The dome can be installed indoors or outdoors and comes in a day/night version for use in a variety of lighting conditions.

Specifications

Camera

Image sensor

Pixels

Horizontal resolution

Sensitivity, color model

Sensitivity, day/night model

Frame integration

Synchronization

Dynamic range

Video

Compression

Picture resolution

Data rate

Composite output

Audio

Compression

Audio line input

Network

LAN / WAN port

Protocol

Security

Electrical

1/3-in. Interline Transfer double speed SUPER HAD

CCD

752 H x 582 V (PAL)

500 TVL

0.5 lux @ F1.2 (30 IRE, AGC

36 dB)

0.5 lux @ F1.2 (30 IRE, AGC 36 dB) in color; 0.1 lux @

F1.2 (30 IRE, AGC 36 dB) in b/w

2x to 160x

Line-lock

52 dB

MPEG-4 ASP compliant

@ full D1: 720 x 576 (PAL); @ CIF: 352 x 288 (PAL); @

QCIF: 176 x 144 (PAL)

Up to 3Mbps

1.0 V p-p with 75-ohm loading, BNC connector

8 kHz, mono, PCM

Unbalanced, 1.4 V p-p, 1 V rms, terminal block

Ethernet (10/100 Base-T); RJ-45 connector

TCP, UDP, IP, HTTP, DHCP, PPPoE, RTP, RTSP

Password protection configured by administrator

POE models are IEEE 802.3af and 12 VDC compatible only (no 24V AC)

24 VAC models are 24 VAC and 12 VDC compatible only (no POE)

Power consumption: 12 W max.

Can be fully networked and powered over Ethernet

Dual-stream MPEG-4 video compression

Day/night model automatically switches from color to monochrome in low light

Easy to program for maximum flexibility in most applications

Fully operable using standard web browser software

Free 16-channel client software included

Motion detection on 3 windows

Ordering Information

GEC-IPDR-POE

GEC-IPDR-24VA

GEC-IPDR-DN-POE

GEC-IPDR-DN-24VA

DR Series Rugged IP Dome Camera, 520 TVL, MPEG-4, POE,

12 VDC

DR Series Rugged IP Dome Camera, 520 TVL, MPEG-4, 24 VAC

/ 12VDC

DR Series Rugged IP Day/Night Dome Camera, 520 TVL,

MPEG-4, POE, 12 VDC

DR Series Rugged IP Day/Night Dome Camera, 520 TVL,

MPEG-4, 24 VAC / 12 VDC

High Resolution, Ex-view, Day/Night, Zoomplus camera

Specialist Cameras

Page : 37

KTC-ZP-DNP

The KTC-ZP-DNP is a high-resolution EX-view, color, day/night camera with digital zoom. The KTC-ZP-DNP offers special optics and a digital electronic processing circuit. These features deliver sharp images during the day and a clear monochrome picture under low light or minimal infrared illumination.

The camera has 460 lines of resolution, high sensitivity (0.1 lux color and 0.02 black and white), and advanced digital signal processing.

The KTC-ZP-DNP operates at 0 lux under IR illumination.

Power source:

Power consumption:

Operating temperature:

Storage temperature

Operating humidity:

Weight

12 VDC

2.5 W

-10 to 50°C

-20 to 70°C

10 to 85 percent, RH

300 g

Ordering Information

KTC-ZP-DNP High Resolution, Ex-view, Day/Night, Zoomplus camera

The ZoomPlus camera offers 23x optical zoom lens and an additional

10x digital zoom. The camera is also equipped with a digital signal processor that improves image quality.

ZoomPlus features an onscreen display (OSD) for easy and flexible setup options The smart digital backlight compensation prevents important foreground objects from becoming silhouetted against bright backgrounds.

The KTC-ZP-DNP assures accurate color rendition even under the most adverse lighting conditions with its intelligent wide range autotracking white balance.

Specifications

Camera

Image sensor

Signal system

Picture elements

Scanning system:

Resolution

Sensitivity

IR-cut filter:

Day-night change level:

Day-night change delay time:

Optical zoom:

Zoom speed:

Signal-to-noise ratio:

Electronic shutter:

Sense up:

White balance:

BLC function:

Gamma correction

AGC:

ALC:

Video output:

Lens:

Motor

Zoom:

Focus:

Position:

Masking:

External control

Function:

Baud rate:

1/4-in. EX-view CCD

PAL

795 H x 596 V

625 lines 2:1 Interlace

460 TVL

0.1 lux (color), IR-cut on; 0.02 lux B/W, IR-cut off

Automatic/manual switching

0.02 to 15 lux adjustable

5 to 8 sec.

3.6 - 82.8mm

4.2 sec

> 50 dB

1/50 to 1/100,000 sec., automatic

2x to 64x (option)

ATW 2500° to 9500° K; preset/manual

Auto on/off

0.45

Super AGC 0 to 36 dB

Auto/fix

Composite 1.0 V p-p at 75 ohm load

23x optical zoom lens (F1.6 - 3.8) zoom/focus/iris: 800,000 times life

23x optical and 10x digital

Automatic/manual

64 presets/positions (zoom, focus)

2 zones

RS-232 (for future use)

Optical and digital zoom, focus, iris, gain, white balance

9600 bps

EX-view HAD CCD

Switches from colour to black and white in low light

Removable infrared filter

460 lines of resolution

0.1 lux sensitivity in color and 0.02 lux in black and white mode. 0 lux with IR illumination

23x optical zoom and 10x digital zoom

Onscreen display menu

Advanced digital signal processor

Smart digital automatic backlight compensation

Digital horizontal and vertical aperture correction

Intelligent wide range autotracking white balance

LENSES

1/3" 2.8~8 mm F0.95 to T360, CS Mount

Specifications

Focal length

Iris range

Iris operation

Focus operation

Zoom operation

Angle of view

Focussing range

Mount

Weight

2.9 to 8 mm (2.7x)

F0.95 to T360

Auto (DC Type)

Manual

93°34´ x 68°46´ (wide 1/3 format)

34°53´ x 26°09´ (tele 1/3 format)

0.3 m to infinity

CS mount

45 g

Ordering Information

AR-YV2.2x1.4A-SA2

AR-YV2.3x6A-SA2

YV10x5B-SA2

YV2.4x2.5A-SA2

YV2.8x2.8LA-SA2

1/3" 1.4~3.1mm F1.4 - T360, CS Mount

1/3" 6~14mm F1.4 - T360, CS mount

1/3" 5-50 mm F1.3 to T360, Direct Drive, CS mount

1/3" 2.5-6mm (110°) F1.2 - 360, CS Mount

1/3" 2.8~8 mm F0.95 to T360, CS Mount

Excellent optical properties

Made by Fujinon

Highest quality manufacturing

reliable

F0.95 to T360

Lenses

Page : 41

YV2.8x2.8LA-SA2

1/3" 2.7~13.5mm F1.3 - T360, CS Mount

Specifications

Focal length

Iris range

Iris operation

Focus operation

Zoom operation

Angle of view

Focussing range

Mount

Weight

Current consumption

2.7 to 13.5 mm

F1.3 to T360

Auto (DC Type)

Manual

93°34´ x 68°46´ (wide 1/3 format)

34°53´ x 26°09´(tele 1/3 format)

0.3 m to infinity

CS mount

35 g

22 mA (max.) at 4 VDC

Ordering Information

YV10x5R4A-SA2

YV2.7x2.9LR4D-SA2

YV5x2.7R4B-SA2

1/3" 5-50 mm F1.3 to T360, Direct Drive, CS mount, IR corrected

1/3" 3-8mm F0.95 - T360 IR Coated

1/3" 2.7~13.5mm F1.3 - T360, CS Mount

Excellent optical properties

Made by Fujinon

Highest quality manufacturing

reliable

F1.3 to T360

Lenses

Page : 42

YV5x2.7R4B-SA2

HOUSINGS

Fliptop Housing 270mm & Wall Bracket IP66

Gain easy access to your outdoor security cameras with GE-Security innovative fliptop-style housing. The CHF270 model accommodates a camera and lens of 270 mm. Die-cast aluminum gives the CHF270 housing strength and durability while keeping each unitlightweight. Without the blower, both housings have weatherproof ratings of IP66. A plate located at the back of the housing allows you to route one or two cables through individual outlets. Avoid damage to cables while keeping the inside of the housing dry. The heavy-duty aluminum sunshield protects the camera from too much light. For environments where weather conditions demand heating or cooling, the CHF270 has optional a heater, blower unit available. Optional mounting brackets are available for theCHF270 housing. Position a camera on a wall or ceiling, in a corner, or on a pole.

Specifications

Dimensions

Power

Operating temperature

Material

Colour

Window

IP rating

270 x 76 x 76 mm

31 W

-20 to +50°C

Die-cast aluminium

White RAL9002

65 x 65 mm

IP66

Die-cast aluminum construction

Weatherproof with an IP66 rating

Flips open for easy access to the security camera

Optional heater/blower kit available

Interchangeable cable access

Multiple mounting options available

Ordering Information

CHF270

CHF270/IP66

CHF270/HTR24

CHF270/IP66/24VAC

CHF230

CHF230/IP66

CHF230/HTR24

CHF230/IP66/24VAC

Fliptop Housing 270mm & Wall Bracket IP66

Fliptop Housing 270mm 230Vac Heater IP66 & Cable

Management Wall Bracket

Fliptop Housing 270mm 24VAC Heater IP66 & Cable

Management Wall Bracket

Fliptop Housing 270mm 24VAC PSU - 230VAC Heater IP66 &

Cable Management

Fliptop Housing 230mm & Wall Bracket IP66

Fliptop Housing 230mm & Wall Bracket 230Vac Heater IP66

Fliptop Housing 230mm & Wall Bracket 24VAC Heater IP66

Fliptop Housing 230mm & Wall Bracket 24VAC PSU -

230VAC Heater IP66

Housings

Page : 45

CHF270

Fliptop Housing 270mm IP66 & Cable Management

FlipTop housing with cable managed wall bracket

Gain easy access to your outdoor security cameras with GE-Security innovative fliptop-style housing. The CHOF270 model accommodates a camera and lens of 270 mm. Die-cast aluminum gives the CHOF270 housing strength and durability while keeping each unitlightweight. Without the blower, both housings have weatherproof ratings of IP66. A plate located at the back of the housing allows you to route one or two cables through individual outlets. Avoid damage to cables while keeping the inside of the housing dry. The heavy-duty aluminum sunshield protects the camera from too much light. For environments where weather conditions demand heating or cooling, the CHOF270 has optional a heater, blower unit available. Optional mounting brackets are available for theCHOF270 housing. Position a camera on a wall , in a corner, or on a pole.

Specifications

Dimensions

Power

Operating temperature

Material

Colour

Window

IP rating

270 x 76 x 76 mm

31 W

-20 to +50°C

Die-cast aluminium

White RAL9002

65 x 65 mm

IP66

Die-cast aluminum construction

Weatherproof with an IP66 rating

Flips open for easy access to the security camera

Optional heater/blower kit available

Interchangeable cable access

Multiple mounting options available

Cable managed wall bracket

Ordering Information

CHOF270

CHOF270/IP66

CHOF270/HTR24

CHOF270/IP66/24VAC

CHOF230/IP66

CHOF230/HTR24

CHOF230/IP66/24VAC

Fliptop Housing 270mm IP66 & Cable Management

Fliptop Housing 270mm 230Vac Heater IP66 & Cable

Management Wall Bracket

Fliptop Housing 270mm 24VAC Heater IP66 & Cable

Management Wall Bracket

Fliptop Housing 270mm 24VAC PSU - 230VAC Heater IP66 &

Cable Management

Fliptop Housing 230mm IP66 & Cable Management

Housings

Page : 46

CHOF270

Indoor Camera Housing & Wall Bracket

GE Security's range of low cost entry level camera housings has been carefully designed not only to meet the harsh environmental requirments of todays CCTV systems, but also to offer a wide range of fixings and specifications.

Specifications

Material

IP rating

Mounting options

Voltage

Heater

PSU

Blower

Power

Heater

Blower

Useable internal length

Dimensions (W x H x D)

Die-cast or extruded aluminium

Epoxy paint coated

ABS or glass re-inforced nylon

IP66

Wall brackets

220 VAC or 24 VAC

220 VAC input / 24 VAC output

N/A

13 W

7 W (230 VA)

N/A

270 mm

128 x 138 x 410 mm

Ordering Information

CWH/270 Indoor Camera Housing & Wall Bracket

Housings

Page : 47

CWH/270

Camera Housing & Wall Bracket Heater & Sunshield IP66 230 VAC

Specifications

Material

IP rating

Mounting options

Voltage

Heater

PSU

Blower

Power

Heater

Blower

Useable internal length

Dimensions (W x H x D)

Die-cast or extruded aluminium

Epoxy paint coated

ABS or glass re-inforced nylon

IP66

Wall brackets

220 VAC or 24 VAC

220 VAC input / 24 VAC output

N/A

13 W

7 W (230 VAC)

N/A

270 mm

128 x 138 x 410 mm

Ordering Information

CHW270/IP66

CHW270/24HTR/IP66

CHW270/IP66/24VAC

CHW270P

CHW270P/24HTR

Camera Housing & Wall Bracket Heater & Sunshield IP66 230

VAC

Camera Housing & Wall Bracket 24 VAC Heater & Sunshield

Camera Housing & Wall Bracket IP66 24VAC- PSU 230V

Heater

Camera Housing IP66 230VAC Heater & Cable Management

Wall

Camera Housing IP66 24VAC Heater & Cable Management

Wall Bracket

Housings

Page : 48

CHW270/IP66

Camera Housing & Wall Bracket IP66 230 VAC

These stylish housings have been thoughtfully designed so that they not only look good, but are also easy to install and service. They all feature the slide and hang servicing facility. The top of the housing, when unsecured, slides forward and then hangs below the housing body giving maximum accessibility to the camera and lens inside.

The product is constructed from extruded aluminium protected with an Epoxy paint coating to give durability.

Specifications

Material

IP rating

Bracket options

Heater

PSU

Heater

Useable internal length

Dimensions (W x H x D)

Die-cast or extruded aluminium, epoxy paint coated

IP66

Ceiling,wall or wall mount cable management version

220 VAC

220 VAC input / 24 VAC output

70 W

300 mm

124 x 121 x 410 mm

Ordering Information

CHW300/IP66

CHW300/IP66/24VAC

Camera Housing & Wall Bracket IP66 230 VAC

Camera Housing & Wall Bracket IP66 24 VAC PSU - 230 VAC

Heater

Aluminium or ABS construction

IP66

Cable management version

Wall or ceiling mount

Polyester paint finish

Internal versions

External versions with heaters and thermostats

Optional internal 24 VAC camera power supply

Housings

Page : 49

CHW300/IP66

Camera housing & Ceiling Bracket IP65 230 VAC

Precision engineered aluminium construction ensures the CHC 300 ceiling mounted camera housing is designed to give maximum protection (IP 66) whilst providing quality and stylish good looks.

Specifications

Material

IP rating

Bracket options

Heater

PSU

Heater

Useable internal length

Dimensions (W x H x D)

Die-cast or extruded aluminium, epoxy paint coated

IP65

Ceiling, wall or wall mount cable management version

220 VAC

220 VAC input / 24 VAC output

10 W

300 mm

124 x 121 x 410 mm

Ordering Information

CHC300/IP65

CHC300/IP66/24VAC

Camera housing & Ceiling Bracket IP65 230 VAC

Camera housing & Ceiling Bracket IP66 24VAC PSU - 230v

Heater

Aluminium or ABS construction

IP65

Cable management version

Wall or ceiling mount

Polyester paint finish

Internal versions

External versions with heaters and thermostats

Optional internal 24 VAC camera power supply

Housings

Page : 50

CHC300/IP65

Internal Camera bracket 140mm (ceiling bracket pictured)

Ordering Information

CB140

CB190

CBCM170

CCB190

TCB300

Internal Camera bracket 140mm (ceiling bracket pictured)

Internal Camera bracket 190mm

Internal Camera bracket 170mm with Cable Management

Internal Ceiling mount Camera Bracket 190mm

Telescopic Internal Camera Bracket 300mm

Corner mount adapter (stainless steel screws)

Corner Mount Adapter for camera housings with wall brackets.

Ordering Information

PA1

PA2

Corner mount adapter (stainless steel screws)

Pole adaptor for one housing bracket

Pole adaptor for up to two housing brackets

Accessories

Page : 51

CB140

CYBERDOME/LEGEND

Economical, High-Resolution, High-Speed Surveillance Dome

CyberDome / Legend

Page : 55

CyberDome

The Pendant Mount CyberDome is a discreet, variable speed pan/tilt/zoom dome capable of speeds up to 400° per second.

Available in a 7-inch wall mount, the CyberDome uses an integrated camera with up to 18x optical zoom lens, and 12x electronic zoom.

Features include auto iris with manual override, auto or manual focus, backlight compensation, 64 programmable preset positions, preset and zone titling, and up to four camera tours.

Specifications

Dimensions

Flush (d x h)

Pendant (d x h)

Wall (d x h)

Electrical

Operating voltage

Power

General Specifications

Manual speed

Max. pan/tilt speed

Presets

Shadow tours

Protocols

Camera Specifications

Camera: 22x color

223 x 234mm

229 x 268 mm

229 x 292 mm

24 VAC +/- 4 VAC

19 VA startup; with heater 54 VA startup

0.5 to 120°/sec

400°/sec, 200°/sec average point to point

32 to 64 programmable presets

Digiplex RS422, Impac RS485

Camera: 18x day/night

Camera: 25x day day/night

Image sensor: 1/4 in. CCD

Zoom: Optical 22x

Resolution: 470 TVL NTSC; 460 TVL PAL

Lens: F=4 mm (wide) to 88 mm (tele); F1.6

Angle of view (H): 47.3° (wide) to 2.2° (tele)

Sensitivity: 1 lux

Electronic shutter speed: 1/60 to 1/30,000 sec, NTSC;

1/50 to 1/30,000 sec, PAL

Image sensor: 1/4 in. CCD

Zoom: Optical 18x, digital 12x

Resolution: 470 TVL NTSC; 460 TVL PAL

Lens: F=4.1 mm (wide) to 73.8 mm (tele); F1.4 to F3.0

Angle of view (H): 48° (wide) to 2.7° (tele)

Sensitivity: 0.7 lux at 1/60 sec NTSC or 1/50 sec PAL;

0.01 lux at 1/4 sec NTSC or 1/3 sec PAL

Electronic shutter speed: 1/1 to 1/10,000 sec, 14 steps, NTSC; 1/1 to 1/10,000 sec, 14 steps, PAL

Image sensor: 1/6 in. CCD

Zoom: Optical 25x, digital 12x

Resolution: 470 TVL NTSC; 460 TVL PAL

Synchronization: Internal/line lock

Lens: 25X zoom, f = 2.4 mm (wide) to 60 mm (tele), F1.6

to F2.7

Angle of view: 45° wide to 2° tele

Sensitivity: 2.5 lux color, 0.2 lux monochrome

Electronic shutter: 1/1 to 1/10,000 sec 22 steps NTSC;

1/1 to 1/10,000 sec 20 steps PAL

Several camera options to fit your specific need

Integrated camera

Auto return function

Optical and digital zoom

Auto/manual focus

360 degree continuous pan

Variable speed up to 400 degrees per second

Up to 64 programable preset positions

Preset and zone titles

Up to 2 tours including 4 minute shadow tours

Ordering Information

CyberDome Economical, High-Resolution, High-Speed Surveillance Dome

CyberDome II, Next Generation Pan/Tilt/Zoom, Camera

CyberDome / Legend

Page : 56

CyberDome II

The CyberDome II from GE Security sets a new standard for the

CyberDome integrated dome family. Advanced features with 128 presets, up-the-coax control, in-house memory are added up to the complete and easy-to-use functionality of the CyberDome series.

Four cameras a color 22x, day/night 18x, day/night 23x with wide dynamic range and day/night 26x. The WDR option is ideal for use in high contrast lighting conditions. Mount the cameras in indoor or outdoor housings that can hold up in a variety of environmental conditions. Set areas, privacy masks, and preset and Shadow Tours for maximum surveillance. Variable speed pan/tilt lets users move the camera through survelliance areas at any of 32 speeds, with a maximum pan/tilt of 400 degrees per second.

Specifications

Resolution: 470 TVL NTSC; 460 TVL PAL

Lens: F=3.5 mm (wide) to 91 mm (tele); F1.6 to F3.8

Angle of view (H): 54.2° (wide) to 2.2° (tele)

Sensitivity: 1.0 lux at 1/60 sec NTSC or 1/50 sec PAL;

0.07 lux at 1/4 sec NTSC or 1/3 sec PAL

Electronic shutter speed: 1/1 to 1/10,000 sec, 14 steps, NTSC; 1/1 to 1/10,000 sec, 14 steps, PAL

Ordering Information

CyberDome II CyberDome II, Next Generation Pan/Tilt/Zoom, Camera

Dimensions

(d x h)

Operating voltage

Power

Flush 241 x 243mm; Pendant 241 x 303 mm; Wall 241 x 243 mm

24 VAC +/- 4 VAC

25 VA startup; 20 VA running; with heater 153VA startup; 66 VA running

General Specifications

Manual pan speed

Manual tilt speed

Max. pan/tilt speed

Presets

Shadow tours

Protocols

0.5 to 200°/sec

0.5 to 120°/sec

400°/sec

128 with 24-character title

4 with 4 min. each

Digiplex RS422, Impac RS485, ASCII RS422, Pelco D,

Pelco P, Ultrak

Camera Specifications

Camera: 22x color

Image sensor: 1/4 in. CCD

Zoom: Optical 22x

Resolution: 470 TVL NTSC; 460 TVL PAL

Lens: F=4 mm (wide) to 64 mm (tele); F1.6

Angle of view (H): 47.3° (wide) to 2.2° (tele)

Sensitivity: 3 lux

Electronic shutter speed: 1/60 to 1/30,000 sec, NTSC;

1/50 to 1/30,000 sec, PAL

Camera: 18x day/night

Camera: 23x day/night w/ WDR

Image sensor: 1/4 in. CCD

Zoom: Optical 18x, digital 12x

Resolution: 470 TVL NTSC; 460 TVL PAL

Lens: F=4.1 mm (wide) to 73.8 mm (tele); F1.4 to F3.0

Angle of view (H): 48° (wide) to 2.8° (tele)

Sensitivity: 0.7 lux at 1/60 sec NTSC or 1/50 sec PAL;

0.05 lux at 1/4 sec NTSC or 1/3 sec PAL

Electronic shutter speed: 1/1 to 1/10,000 sec, 14 steps, NTSC; 1/1 to 1/10,000 sec, 14 steps, PAL

Image sensor: 1/4 in. CCD

Zoom: Optical 23x, digital 10x

Resolution: 470 TVL NTSC; 460 TVL PAL

Synchronization: Internal/line lock

Lens: F=3.6 mm (wide) to 82.8 mm (tele); F1.6 to F3.7

Angle of view (H): 54° (wide) to 2.5° (tele)

Sensitivity: 0.2 lux at 1/4 sec NTSC or 1/3 sec PAL

Electronic shutter speed: 1/60 to 1/4 ksec, NTSC; 1/50 to 1/4 ksec, PAL

Camera: 26x day/night

Image sensor: 1/4 in. CCD

Zoom: Optical 26x, digital 12x

128 preset positions, 4 preset tours, and 4 Shadow Tours

Site-tied memory allows camera replacement without reprogramming

128 preset positions, 4 preset tours, and 4 Shadow Tours

Legend dome, Pan/Tilt, 26x Day/Night camera with Silk Track

CyberDome / Legend

Page : 57

Legend

The Legend from GE Security sets a new standard for integrated dome cameras. SilkTrak direct drive technology eliminates roughness common to other domes. Programming for presets, tours, macros, privacy masks, alarms, and more is completed via easy-to-use menus

Specifications

Image sensor

Zoom

Resolution

Synchronization

Lens

Angle of view (H)

Sensitivity

Sensitivity, ICR-on:

Electronic shutter speed

Operating voltage

Power

Power, with heater

Ordering Information

1/4 in. CCD

Optical 26x, digital 12x

470 TVL NTSC; 460 TVL PAL

Internal/line lock

F=3.5 mm (wide) to 91 mm (tele); F1.6 to F3.8

54.2° (wide) to 2.2° (tele)

1.0 lux at 1/60 sec NTSC or 1/50 sec AL; 0.07 lux at

1/4 sec NTSC or 1/3 sec PAL

0.15 lux at 1/60 sec NTSC or 1/50 sec PAL; 0.01 lux at

1/4 sec NTSC or 1/3 sec PAL

1/1 to 1/10,000 sec, 14 steps, NTSC; 1/1 to 1/10,000 sec, 14 steps, PAL

24 VAC +/- 4 VAC

30 W startup; 16 W running

100 W startup; 66 W running

SilkTrak™ direct drive for smooth and precise PTZ movement

New 26x day/night camera with removable IR cut filter

Spherical privacy masking

Single hand insertion and removal

Built-in coax and UTP video connections

32 macros; 16 steps per macro; linkable

16 shadow tours; 20 minutes total duration

127 presets with title and individual camera settings

120 programmable areas per dome, each with title

24 total privacy masks; 8 displayed simultaneous; with spherical privacy masking

8 built-in alarm inputs; 2 relay outputs

Electronic image flip

Legend dome, Pan/Tilt, 26x Day/Night camera with Silk Track

CyberDome / Legend

Page : 58

Legend-IP

Legend IP integrated IP dome camera line

Legend IP from GE Security is the newest addition to our industryleading integrated dome camera line, adding full frame rate streaming video to the already feature-packed product. Legend IP is fully compatible with the SymSuite family of IP-based products from

GE Security.SilkTrak™ direct drive eliminates gears and belts for improved performance and reliability. The closed-loop positioning technology provides preset positioning accuracy of ±0.015

degrees.A choice of 36x or 26x optical zoom camera with 12x digital zoom gives this new dome 432x or 312x total zoom. Optically superior injection-molded dome bubbles insure crystal clear images, even at the highest zoom magnifications. With 184-degree tilt travel for above- horizon viewing and electronic image flip, the camera can tractrack activity directly underneath it without having to spin on its pan axis

Specifications

General Specifications

Drive type

Pan travel

Tilt travel

Manual pan speed

Manual tilt speed

Max. pan/tilt speed

Shadow tours

Protocols

SilkTrak Direct Drive

360° continuous

184°

0.01 to 120°/sec

400°/sec

16 with 20 min. total duration

GE RS-422, GE Impac RS-485, GE ASCII RS-422, Pelco P

& D RS-422, Honeywell Ultrak RS-422, Tyco AD RS-422

Video Encoder

Colors

Grayscale

Y:U:V 4:2:2; 16.8 million colors

256 levels

Horizontal resolution

Vertical resolution

Digital resolution

Digital frame rate

D1: 720 x 576/720 x 480; 2CIF: 704 x 288/704 x 240;

CIF: 352 x 288/352 x 240

Up to 25 frames/sec. @ 720 x 576 resolution

Video compression standard MPEG-4

Camera Specifications

720 pixels

484 lines

Sensor

Resolution

1/4-in. CCD

460 TVL PAL

Zoom

Lens

Angle of View (H)

Sensitivity

Sensitivity, ICR-on

Video Output

Optical 26x; Digital 12x

F=3.5 mm (wide) to 91 mm (tele); F1.6 to F3.8

54.2° (wide) to 2.2° (tele)

1.0 lux at 1/50 PAL;

0.07 lux at 1/3 sec PAL

0.15 lux at 1/50 PAL;

0.01 lux at 1/3 sec PAL

1.0 V p-p

SilkTrak™ direct drive for smooth and precise PTZ movement

26x day/night camera with removable IR cut filter

Spherical privacy masking

Comprehensive programming choices via graphical menus provide flexibility for all applications

Advanced MPEG-4 compression allows full D1 resolution at 25 frames per second

Selectable streaming video resolution of D1, 2CIF, or CIF

32 macros; 16 steps per macro; linkable

16 shadow tours; 20 minutes total duration

127 presets with title and individual camera settings

120 programmable areas per dome, each with title

24 total privacy masks; 8 displayed simultaneous; with spherical privacy masking

8 built-in alarm inputs; 2 relay outputs

Electronic image flip

Ordering Information

Corner Mount Adapter for KTA-20 or KTA-28 CyberDome wall bracket

CyberDome / Legend

Page : 59

KTA-25

The corner-mount adapter can be used with any of the wall-arm mounts to suspend a 7 inch CyberDome from the corner of a building.

It can also be used to mount an 8 inch CyberDome with heavy-duty housing. The corner-mount adapter is constructed of weather-resistant aluminum.

Specifications

Weight

Material

Finish

0.86 kg

Aluminium

Grey powder coat

Ordering Information

ATD-6812-PSU

KTA-20

KTA-20C

KTA-21

KTA-22-6

KTA-24-6

KTA-25

KTA-26

KTA-27

KTA-28

Power supply unit for all domes, 24 VAC, 3 Amps

CyberMount wall-arm

Swing-arm mount

24-inch Square T-Bar Type Ceiling Mount Old ATA-00-6

T-bar support kit for existing ceiling tiles old ATA-10-6

Corner Mount Adapter for KTA-20 or KTA-28 CyberDome wall bracket

Pole-mount adapter

Roof-mount adapter

Cast aluminum wall-Arm

Options for many configurations to fit your needs

Easy installation

Durable finish and construction

Low cost

Legend and CberDome II Pole Mount Adaptor

GEA-106

The pole-mount adapter can be used with any of the wall-arm mounts to suspend a 7 inch CyberDome II or Ledend Dome from a pole. The ple-mount adapter is constructed of weather-resistant aluminum. It may be installed with bolts or metal strips.

Specifications

Weight

Material

Finish

0.41 kg

Aluminium

Grey powder coat

Ordering Information

ATD-6814-PSU

GEA-102

GEA-105

GEA-106

GEA-107

GEA-113

GEA-114

Power supply unit for all domes, 24 VAC, 4 Amps

Legend and CyberDome II, Wall Mount Adaptor, Cast

Aluminium

Legend and CyberDome II, Corner Mount Adaptor

Legend and CberDome II Pole Mount Adaptor

Legend and CyberDome II, Wall Mount Adaptor, Cast

Aluminium Roof Mount Adaptor

Legend and CyberDome II, T-bar 6" ceiling panel

Legend and CyberDome II, T-bar panel support kit

Options for many configurations to fit your needs

Easy installation

Durable finish and construction

Low cost

VIDEO TRANSMISSION

1 Channel passive video transceiver

Video Transmission

Page : 63

GE-TTP111VS

The GE-TTP111VS video transceiver is a passive (non-amplified) device that allows transmission of real-time monochrome or colour video over Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 400 meters

(Further, when used with an active receiver).

Specifications

Video in

Video level

Transmission distance

Min. cable requirement

Dimensions

BNC connector

1 V pk-pk

400 m Passive-Passive, 800 m Passive-Active

Unshielded CAT 5 (or above)

69 x 18 x 22 mm

Ordering Information

GE-TTP111-VLH

GE-TTP111VL

GE-TTP111VS

GE-TTP111VT

1 Channel Passive video transceiver with extra interference rejection

1 Channel Passive Video Transceiver

1 Channel passive video transceiver

Slimline design for easy connection to multiplexers and matrix

BNC male to quick connect terminal block

Transmit a full motion color or monochrome video signal up to

400 meters

Distance up to 800 meters when used with an active receiver

Passive, no power required

Built-in impedance couple device and noise filter for exceptional interference immunity

4 Channel passive video transceiver

Video Transmission

Page : 64

GE-TTP414V

The GE-TTP414V video transceiver is a 4 channel passive

(non-amplified) device that allows transmission of real-time monochrome or colour video over Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 400 meters (Further, when used with an active receiver).

Specifications

Video in/out

Video Level

Transmission distance

Min. cable requirement

Dimensions

4x BNC connector

1 V pk-pk

400 m Passive-Passive, 800 m Passive-Active

Unshielded CAT 5 (or above)

80 x 110 x 25 mm

Ordering Information

GE-TTP414V

GE-TTP414VH

4 Channel passive video transceiver

4ch Passive video transceiver with extra interference rejection

BNC male to quick connect terminal block

Transmit a full motion colour or monochrome video signal up to

400 meters

Distance up to 800 meters when used with an active receiver

Passive, no power required

Built-in impedance couple device and noise filter for exceptional interference immunity

1 Channel Active Video Receiver Kit (includes GE-TTA111VT + GE-TTA111VR plus 2x power adapters)

GE-TTA111V

The General Electric Model GE-TTA111V Video Transmitter and

Receiver kit is an Active (12Vdc powered) pair of matched devices that allow transmission of real-time monochrome or color video over

Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 1200 meters when used with CAT5 cable (or higher).

Specifications

Video in

Video level

Transmission distance

Min. cable requirement

Dimensions

Power

BNC connector

1 V pk-pk

1200 m Active TX - Active RX

Unshielded CAT 5 (or above)

70 x 42 x 45 mm

12 VDC (power supply included)

Ordering Information

GE-TTA111V

GE-TTA111VR

GE-TTA111VT

1 Channel Active Video Receiver kit

1 channel active video receiver

1 Channel active video transmitter

Converts any standard camera or dome video signal to UTP

Transmit a full motion color or monochrome video signal up to

1200 meters (Active-Active)

BNC male to quick connect terminal Block

Built in impedance couple device and noise filter for exceptional interference immunity

4 channel active video receiver

Video Transmission

Page : 65

GE-TTA414VR

The GE-TTA111VR video receiver is an active 4 channel (12Vdc powered) device that allows transmission of real-time monochrome or colour video over Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 800 meters when used with stand alone passive transmitters, CamPlus

PlusPacks or CyberDome or up to 1200 meters when used with it's matched active transmitter (GE-TTA111VT).

Specifications

Video out

Video level

Transmission distance

Min. cable requirement

Dimensions

Power

4x BNC connector

1 V pk-pk

800 m Passive TX - Active RX, 1200 m Active TX -

Active RX

Unshielded CAT 5 (or above)

80 x 140 x 80 mm

12 VDC (power supply included)

Ordering Information

GE-TTA414VR

GE-TTA111VT

4 channel active video receiver

1 Channel active video transmitter

4 channel active receiver

4x BNC male to quick connect terminal block

Transmit a full motion colour or monochrome video signal up to

1200 meters (Active-Active)

Compatible with all GE active/passive transmitters including

CamPlus PlusPacks and CyberDome

Built-in impedance couple device and noise filter for exceptional interference immunity

Long range active receiver with extra interference rejection

Video Transmission

Page : 66

GE-TTA111VRH

The GE-TTA111VRH video receiver is an active (12Vdc powered) long range receiver with extra interference rejection that allows transmission of real-time monochrome or colour video over

Unshielded Twisted-Pair (UTP) telephone wire. The GE-TTA111VRH has been designed especially for for use with Digital Video Recording devices. 1V pk-pk composite signals are supported at distances of up to 800 meters when used with stand alone Passive transmitters,

CamPlus PlusPacks or CyberDome or up to 1200 meters when used with it's matched Active transmitter (GE-TTA111VT).

Specifications

Video in

Video level

Transmission distance

Min. cable requirement

Dimensions

Power

BNC connector

1 V pk-pk

1200 m Active TX - Active RX

Unshielded CAT 5 (or above)

70 x 42 x 45 mm

12 VDC (power supply included)

Ordering Information

GE-TTA111VRH Long range active receiver with extra interference rejection

Converts any standard camera or dome video signal to UTP

Transmit a full motion color or monochrome video signal up to

1200 meters (Active-Active)

BNC male to quick connect terminal Block

Built in impedance couple device and noise filter for exceptional interference immunity

Especially designed for for use with Digital Video Recording devices

16 channel passive video transceiver

Video Transmission

Page : 67

GE-TPP016

The GE-TPP016 video transceiver is a 16 channel passive

Specifications

Video in/out

Video level

Transmission distance

Min. cable requirement

Dimensions

16x BNC connector

1 V pk-pk

400 m Passive-Passive, 800 m Passive-Active

Unshielded CAT 5 (or above)

190 x 483 x 44 mm

Ordering Information

GE-TPP016 16 channel passive video transceiver

Compatible with all GE active/passive transmitters including

CamPlus PlusPacks and CyberDome

BNC male to quick connect terminal block

Transmit a full motion colour or monochrome video signal up to

400 meters

Distance up to 800 meters when used with an active receiver

Passive, no power required

Built-in impedance couple device and noise filter for exceptional interference immunity

8 channel active video receiver

Video Transmission

Page : 68

GE-TPA008

The GE-TPA008 video receiver is an active 8 channel (12Vdc powered) device that allows transmission of real-time monochrome or colour video over Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 800 meters when used with stand alone Passive transmitters, CamPlus

PlusPacks or CyberDome or up to 1200 meters when used with it's matched active transmitter (GE-TTA111VT).

Specifications

Video out

Video level

Transmission distance

Min. cable requirement

Dimensions

Power

8x BNC connector

1 V pk-pk

800 m Passive TX - Active RX, 1200 m Active TX -

Active RX

Unshielded CAT 5 (or above)

190 x 483 x 44 mm

12 VDC (power supply included)

Ordering Information

GE-TPA008

GE-TPA016

8 channel active video receiver

16 channel active video receiver

8 channel active receiver

8x BNC male to quick connect terminal block

Receive a full motion colour or monochrome video signal up to

1200 meters (Active-Active)

Compatible with all GE Active/Passive transmitters including

CamPlus PlusPacks and CyberDome

Built-in impedance couple device and noise filter for exceptional interference immunity

16 channel active video receiver with extra interference immunity

Video Transmission

Page : 69

GE-TPA016H

The GE-TPA016H video receiver is an active 16 channel (12Vdc powered) device that allows transmission of real-time monochrome or colour video over Unshielded Twisted-Pair (UTP) telephone wire. 1V pk-pk composite signals are supported at distances of up to 800 meters when used with stand alone Passive transmitters, CamPlus

Packs, GE-TTP111VT or CyberDome or up to 1200 meters when used with it's matched active transmitter (GE-TTA111VT). The unit has extra interference immunity build in to be able to work proper with DVR's.

Specifications

Video out

Video level

Transmission distance

Min. cable requirement

Dimensions

Power

16x BNC connector

1 V pk-pk

800 m Passive TX - Active RX, 1200 m Active TX -

Active RX

Unshielded CAT 5 (or above)

190 x 483 x 44 mm

12 VDC (power supply included)

Ordering Information

GE-TPA016H 16 channel active video receiver with extra interference immunity

16 channel active receiver

16x BNC male to quick connect terminal block

Receive a full motion colour or monochrome video signal up to

1200 meters (Active-Active)

Compatible with all GE active/passive transmitters including

CamPlus PlusPacks and CyberDome

Built-in impedance couple device and noise filter for exceptional interference immunity

DIGIPLEX

16 x 4 Matrix switcher

Starting as a 16 input by 4 output switcher, the KTD-348-164U can be easily expanded to 32 inputs by 4 or 8 outputs. Standard features include looping video inputs, programmable alarm inputs and an

RS232 port for operation from a computer. Control is via twisted pair cable from as many as 64 keypad locations. The switcher uses standard Digiplex protocol, allowing it to be programmed for camera sequence tours, alphanumeric titling, individual or universal dwell times, etc.

Microprocessor-based circuitry allows the KTD-348-164U to receive commands from the KTD-405U (not supplied) controller keypad. A separate serial data port is provided for relay follow communication.

All ICs are socketed for easy removal and replacement. A 220 VAC/12

VDC external power supply is included for chassis power. Rack mount accessories are available for the KTD-348-164U allowing it to be installed in a standard 19" (2 U) equipment rack.

Specifications

Input

Voltage

Power

Miscellaneous

Video inputs

Video outputs

Bandwidth

S/N ratio

Gain

Impedance

Alarms

Video

Mechanical

Weight

Dimensions (W x H x D)

12 VDC

15.5 W

16 looping

32 MHz at -1.5 dB

50 MHz at -3 dB

-60 dB (RMS rel. 1 V pk-pk)

0 dB ±1 dB

75 ohm, inputs and outputs

RS-232, RS-422 removable barrier strips

BNC connectors

4.6 kg

420 x 197 x 90 mm

16 inputs by 4 outputs

Looping video inputs

Expandable to 32 by 8

Programmable alarm inputs

Up to 64 control points

Digiplex protocol

Standard 90 mm vertical rack space

RS422 communications

12 VDC power supply

BNC connectors for video

Ordering Information

KTD-348-164U

KTD-348-324U

KTD-348-328U

16 x 4 Matrix switcher

32x4 Matrix switcher

32x8 Matrix switcher

Digiplex

Page : 73

KTD-348-164U

Digiplex 4 matrix, 64 inputs x 4 outputs,expandable to 512 x 64

Digiplex

Page : 74

KTD-4M-64x4

Digiplex IV is an expandable matrix switching system that manages video inputs and monitor outputs. It is designed for use in large CCTV systems. At the core of the system is the KTD-440 master switcher chassis, which can manage 64 video inputs by 32 monitor outputs.

With the addition of colour-coded expansion cards and an expansion chassis, the KTD-440’s matrix switching capabilities can be increased to 512 inputs by 64 outputs. Digiplex IV also offers an optional video loss detection card, which monitor video signals and alert users in the event of camera failure.

Ordering Information

KTD-440G

KTD-440

KTD-441-1

KTD-443

KTD-444

KTD-445

KTD-440N

KTD-442

KTD-449

KTD-4M-64x4

KTD-4M-64x8

KTD-4M-64x12

KTD-4M-64x16

KTD-4M-128x8

KTD-4M-128x12

KTD-4M-128x16

Digiplex 4 matrix, 64 inputs x 4 outputs,expandable to 512 x

Digiplex 4 matrix, 64 inputs x 8 outputs, no keyboards or alarms

Digiplex 4 matrix, 64 inputs x 12 outputs, no keyboards or alarms

Digiplex 4 matrix, 64 inputs x 16 outputs, no keyboards or alarms

Digiplex 4 matrix, 128 inputs x 8 outputs, no keyboards or alarms

Digiplex 4 matrix, 128 inputs x 12 outputs, no keyboards or alarms

Digiplex 4 matrix, 128 inputs x 16 outputs, no keyboards or alarms

Gathering panel - video signal manager

Master switcher chassis - accepts up to 64 inputs x 32 outputs

Slave Chassis, Additional 64 Video Inputs per Chassis

(previously KT)

Video input card 64x16 video crosspoint switch

Monitor output card, controls 4 monitor outputs

Video loss card

Monitor Expansion Chassis - Expands System by 32 Monitor

Output

Expansion Chassis - Accepts Inputs from KTD-440 for

Monitors 33-64

Digiplex 4 Monitor Expansion Cable

Base system: 64 video inputs by 4 monitor outputs, expands to

512 inputs by 64 outputs

Easy to install expansion chassis

Optional internal video loss detection

Built in dagnostics LEDs

Tranparent cross mapped inputs

Video ribbon cable interconnect

Easy sequential switching

Alarm input chassis

Interfaces

Page : 75

KTD-463U

The KTD-463 is a desktop alarm chassis that initiates camera call-up, site annunciation and preset camera positioning during an alarm event. It triggers these functions in response to data from the

KTD-460 alarm input modules, each of which can monitor the status of up to 16 dry alarm contacts or voltage sources.

The alarm input module constantly transmits information about the status level of each contact to the KTD-463. When the KTD-463 senses an alarm event, it prompts alarm functions in other Digiplex system components. These alarm events also activate the KTD-463's output relay, which can initiate a variety of functions like starting a

VCR or triggering an audible alarm.

The KTD-463 provides 16 input ports, allowing it to accommodate up to 16 KTD-460 Alarm Input Modules. The modules may be daisy-chained onto one port or connected to multiple ports in any combination. Since each alarm input module provides connection points for up to 16 dry alarm contacts or voltage sources, the

KTD-463 alarm chassis can monitor up to 256 alarm points. Each point may be programmed for contact sense and selectable hold delay, which keeps the alarmed site on the monitor screen for a user-defined amount of time after the alarm condition has ended.

The KTD-463 communicates with other Digiplex components via an

RS422 signal over twisted-pair cable. It is supplied with optional-use, rack-mount ears for suspension in a standard, 19 inch rack. It features a liquid crystal display as well as an RS232 port for monitoring the KTD-463's alarm activity and downloading the unit's programming setup parameters.

Annunciation

Find preset

Position

Report trouble

Site annunciation on KTD-304/404, yes or no

Call up preset position on PTZ drive, yes or no

Preset position number, 1-64

Enable or disable

Ordering Information

KTD-463U

KTD-460U

Alarm input chassis

Alarm input module

Specifications

Remotely monitors contact status

Multiple tasks assigned to contacts

Initiates automatic alarm functions

Capacity for up to 16 KTD-460 modules per chassis

256 contact inputs (16 per module)

RS422 communication via twisted-pair cable

Output relay for external devices

Menu-driven contact programming

Programmable hold delay

Programmable contact sense

Electrical

Input voltage

Input power

Input Digiplex data

Input KTD-460 alarm

Output Digiplex data

Output data port

Alarm output relay

Connections

12 VDC, adapter 100 - 230 VAC to 12 VDC included

4.9 W

RS-422

RS-485

RS-422

Serial RS-232 (1200 to 9600 baud)

1 A at 35 VDC

RS-422 in/out & auxiliary relay data

KTD-460 modules (RS-485 in/out)

6-pin removable terminal strip

Two 16-pin removable terminal strips

Power

Printer data

Mechanical

5 mm jack

RJ-45

1.17 kg

Extruded aluminium & vinyl clad steel

Weight

Construction and finish

Alarm contact programming

Site number

Contact sense

Video alarm

Hold delay

Assignable, 0 to 511

Normally open or normally closed

Video call-up on matrix switcher, yes or no

Alarm hold after event, 0-14 s or infinite (cleared by keypad)

Universal multi-speed Digiplex system control

The KTD-400 is a keypad that controls Digiplex system components. It can address and manage 512 PTZ (pan/tilt/zoom) receiver sites, operate a matrix switcher with 64 monitor outputs and address and select views from as many as 64 multiplexers. Its multispeed control feature allows users to toggle between slow, medium and fast speed control for PTZ camera assemblies.

Authorized personnel may program the keypad and other Digiplex components through confidential access codes. Programmable components include CyberDomes, PTZ receivers, matrix video switchers and alarm interfaces. All data is stored in nonvolatile memory.

The KTD-400 keypad is housed in high-impact, injection-moulded plastic. It is fitted with low profile, easy-to-read keys and a backlit, liquid crystal display (LCD). It communicates with other Digiplex components through a RS422 signal over twisted-pair wire. It also offers a DTMF output for mini-matrix video switcher control.

Specifications

Electrical

Input voltage

Input power

Input data signal

Output data signal

Control

Display

Connection

Mechanical

Weight

Construction

Colours

12 VDC (except for LT version)

3.3 VAC (except for LT version)

RS-422

Momentary push buttons

20 x 2 character liquid crystal display (LCD) with back lighting

RJ-45 modular phone jack

0.43 kg

High-impact, injection-moulded ABS plastic

Grey

Control for up to 512 PTZ sites

Matrix switcher operation

Programmable nonvolatile memory

Multi-speed CyberDome control

Twisted-pair control

Liquid crystal display

Compact and attractive keypad

Injection-moulded housing

Rack-mount format available

Ordering Information

KTD-400U Universal multi-speed Digiplex system control

Controller Keypad

Page : 76

KTD-400U

Variable speed controller keypad

Controller Keypad

Page : 77

KTD-405U

GE Security's new KTD-405U combines multiplexer and Digiplex® system control in one unit.

An RS422/RS485 communication port makes it possible for the

KTD-405U to operate DVMRe's, multiplexers and CyberDomes; select and switch video; initiate camera tours and select monitors.

Programmable components include multiplexers, CyberDomes,

CyberScout, matrix switchers and alarm interfaces.

The KTD-405U can be set to operate in one of three modes: discrete zone, transparent zone and standard Digiplex. In discrete and transparent zone modes, the system can be divided into 32 zones with up to 64 cameras in each zone. Multiplexers and matrix switchers can be used in these modes. In standard Digiplex mode, a matrix switcher is the system's primary switching device.

Other features include a three-axis joystick for exceptional pan/tilt precision in CyberDome applications, dedicated recorder operation keys and an RS232 programming port.

When alarm alerts occur, a built-in sounder alerts the user that attention is needed. The KTD-405U can stack up to 32 alarm requests in the order they were received. The first three alarm requests will be displayed and a reminder tone will sound every 15 seconds until all active alarms have been cleared from its queue. Authorized personnel may program the KTD-405U and other Digiplex or Calibur components through confidential access codes.

The KTD-405U features dark grey, ergonomic housing, rubberised buttons and a backlit liquid crystal display.

Specifications

Cyberdome, Digiplex matrix switcher and digital recorders control

RS422/RS485 and RS232 communications ports

Zone system partitioning for DVMRE control

Security levels

Three axis joystick

Built-in annunciator

Backlit liquid crystal display

Input voltage

Power

Outputs

Data

Hard programming

Controls

Keys

Joystick

Mechanical

Weight

Housing

Colours

Keys

9 VAC/12 VDC

5 W

RS-485 modified multiplexer protocol, RJ-45 connector

RS-232, RJ-45 connector

4-position DIP switch

43 momentary push buttons (48 audio ven.)

3-axis

0.884 kg

Aluminium with ABS plastic end caps

Dark gray

Integrated rubberised moulding (elastomere)

Ordering Information

KTD-405U Variable speed controller keypad

DIGITAL VIDEO STORAGE SOLUTIONS

Digia II - Cost-Effective MPEG-4 Digital Video Recorder

Digital Video Storage Solutions

Page : 81

DIGIA2

Digia II - Cost-Effective MPEG-4 Digital Video Recorder

With a robust, appliance-like interface and quick out-of-the-box setup, the GE Security’s Digia™ II, a cost-effective, compact 4-,

9-, or 16-channel digital video recorder, brings the benefits of digital security monitoring to small commercial applications. A user-friendly interface and more than one month of hard disk recording make the

Digia II easy to use, install, and maintain in a small-business environment. Digia II provides a fit-and-forget solution, with a simple search function for reviewing video. Easily archive video evidence to an external device connected through the USB 2.0 port. Digia Browser is a web-browser interface that enables easy viewing of live video, searching and play back of video, or configuration of the Digia II remotely. Various storage configurations are available from 160 GB to

640 GB.

Specifications

Browser

DirectX

Microsoft® Internet Explorer 6.0 or later

9.0 or later

Ordering Information

DIGIA204-160EA

DIGIA204-320EA

DIGIA209-160EA

DIGIA209-320EA

DIGIA216-160EA

DIGIA216-320EA

DIGIA216-640EA

DIGIA2RK

Digia II - Cost-Effective 4 ch. MPEG-4 Digital Video Recorder

Digia II - Cost-Effective 9 ch. MPEG-4 Digital Video Recorder

Digia II - Cost-Effective 16 ch. MPEG-4 Digital Video Recorder

Digia II - Digia II Rack Mount Kit, pair of brackets

Video & Audio

Video signal input

Video signal output

Bi-directional audio

Recording

1 V pp nominal; 4, 9 or 16 video inputs, Composite

BNC, NTSC/PAL compatible

1 V pp at 75 ohm

Video compression standard MPEG-4

Watermarking Yes

Recording resolutions

Real-time live

D1, 2CIF, CIF

On all video channels

1 channel

2CIF

CIF

Features

25 fps per Digia2

50 fps per Digia2

100 fps per Digia2

Network protocols

DDNS support

Bandwidth throttle

Daylight Savings Time

Export/archive

DHCP, Static, PPPOE

Yes

To USB devices (ThumbDrive, USB flash drive, CD-RW, or hard disk drive)

Connectors

Monitor

Alarm I/O

Video input

Audio I/O

10/100 Ethernet

USB 2.0 ports

Power

Electrical

VGA and Composite BNC

Terminal block

Composite BNC

RCA

RJ-45

1 on front, 1 on back

Locking connector

Power source

Power consumption

Physical

Dimensions (HxWxD)

Weight

Operating temperature

Mounting

Remote software requirements

Intel-based PC

Memory

Operating system

Universal, 19 VDC

30 W

81 x 362x 338 mm

4.53 kg with one hard drive

0 - 40 °C

Rack mount available separately

1 GHz or faster

256MB RAM minimum

Windows® XP or 2000

Entry-level MPEG-4 digital solution providing 4, 9 or 16 ch. video inputs

View, record, and playback images simultaneously

Remote software allows live viewing or playback of video over

LAN, WAN, or Internet

USB 2.0 port allows use of flash drive for quick and easy archiving

Full duplex audio

Motion detection

User and Admin log-in

Daylight Savings Time

AVI file export

Simple recording schedule

Real-time live display on all channels

E-mail notification upon alarm

Network bandwidth saving option

Locking power connector

Alarm I/O terminal block

Multiple language support

Designed for tabletop or shelf installation

Up to 640 GB internal storage

DVSR with advanced H.264 compression technology and up to 400fps

Digital Video Storage Solutions

Page : 82

DVSR

The Top Line Digital Video Recorder

With the DVSR series GE Security introduces a new family of digital video recorders with advanced MPEG4-AVC compression algorithm.

Users can record high quality images in real time (25 fps per channel).

This compression technology produces small but extra high quality images. The dual streaming functionality allows the user to set up different settings for recording and streaming video. Depending on the total number of channels available, up to 4 channels can be recorded in 4CIF (704 x 576) and the other channels in CIF resolution

(352 x 288), all of them at 25 frames per second. DVSR can be easily networked and viewed remotely via TCP/IP protocol. GE Security’s remote client software that comes with the unit allows multi-client viewing of live and recorded video from multiple DVSR (Multiview).

DVSR supports up to 2.4 Tbytes, and is capable of holding several months of high quality video images. PTZ can be controlled either by the front panel or the included IR-remote control.

Specifications

Users

Miscellaneous

Input voltage

Power consumption

Temperature

Relative humidity

Dimensions (W x H x D)

Weight

Max 16 users (including administrator)

90 to 135 VAC / 180 to 256 VAC, 47 to 63 Hz max 126 W

-10 to +50°C

10 to 90%

435 x 95 x 455 mm, 19-inch (2U)

Max. 11 kg

Ordering Information

DVSR-DVD-L External USB 2.0 DVD and CDR Rewriter for DVSR Family

Video

Compression

Display Resolution

Input

Output

Recording

Hard Drive

Resolution

Rate per Channel

Video compression Bit Rate

Mode

Multi-Screen Display

Up to 2400 GB

4CIF (704x576), DCIF (528x384), 2CIF (704x288), CIF

(352x288) and QCIF (176x144)

1/16 fps to 25 fps

32 Kbps to 2 Mbps (self definable)

Manual, Schedule, Motion and Alarm

Full, 4, 8 and 16 (Live)

Full screen (Playback)

Audio

Compression standard

Input

Output

Voice audio input

Network

Type

Protocol

Others

Archive

USB 1.1

Connectors

RS-232 serial port

RS-485 PTZ control port

RS-485 keyboard port

Alarm Handling

Alarm input

Alarm output

MPEG4-AVC

704x576 (PAL)

4, 8 or 16 channels, BNC (1.0 Vp-p, 75 ohm)

1 BNC (1.0 Vp-p, 75 ohm)

1 VGA (800x600/60 Hz, 800x600/75Hz, 1024x768/60

Hz)

Ogg Vorbis

4, 8 or 16 channels, BNC

1 BNC

10/100 Base-T, RJ-45

TCP, IP, ARP, RARP, PPP, PPPoE, DHCP,SNMP

ADSL modem and PSTN line for alarm video transmission

USB Memory Stick, USB HDD and USB CD-RW

RJ-45

4, 8 or 16 programmable NO/NC

Max. 4 relay outputs

Operation

Languages

VxWorks

English and 5 European languages

MPEG4-AVC video and Ogg Vorbis audio compression technology

Extremely high recording rate of up to 400 frames per second

Individual resolution set up for each channel

Virtual Triplex operation allows simultaneous recording, live viewing, and playback

Dual streaming capability

English and 14 European-languages OSD menu

Supports up to 2.4 Tbytes

Secret watermark

Web-server feature allow remote access through TCP/IP DHCP,

ADSL and PSTN

Archive on USB Memory Stick and Ext HDD

IR-remote control, Front panel PTZ and Dome camera control with more than 40 built-in protocols

ATM ready with more than 10 built- in protocols

Available SDK for third party software integration

HDD Self-Monitoring Analysis and Reporting Technology

SMART and PowerSaving supported for extended HDD lifetime

Compliant to the German BGV Kassen decree

Compliant to the French decree from August 3rd. 2007

DVSR with advanced H.264 compression technology and up to 400fps

Digital Video Storage Solutions

Page : 83

DVSR

SymNet Network Video Streaming Encoder/Decoder

SymSuite

Page : 84

SymNet

Digital video streaming encoder/decoder

SymNet provides an excellent way to begin building a digital security network without replacing all analog equipment. Built-in MPEG-4 compression technology allows SymNet to deliver high-quality video, synchronized audio, and data over any 10/100BaseT Ethernet network. Analog cameras, monitors, and keyboards can all be connected to a network using a SymNet unit and twisted-pair

Ethernet cable. The advanced MPEG-4 video compression allows full

D1resolution at 25 frames per second with synchronized audio. The digital resolution equals or surpasses D1, CIF, and QCIF quality. Other peripheral devices can also be connected to SymNet for increased functionality. Alarm devices, audio inputs and outputs, RS-485 devices, and serial data lines can all interface with SymNet. Use the built-in serial port to control pan/tilt/zoom cameras from a networked

PC or from a connected keyboard.

Ordering Information

SymNet-5R

SymNet-5RC

SymNet - Network Video Streaming Encoder/Decoder

Specifications

Video

Video signal input

Video signal output

Input termination

Colours

Greyscale

Horizontal resolution

Vertical resolution

0.7 to 1.4 Vpp withautomatic gain control

1 Vpp at 75 ohm

75 ohm

YUV 4:2:2, 16.8 million colours

256 levels

720 pixels

480 TVL

Digital resolution

Digital frame rate

D1: 720 x 576; CIF: 352 x 288; QCIF: 160 x 144

Up to 25 frames/sec. @ 720 x 576 resolution

Video compression standard MPEG-4

Audio

Audio input 315 mV, 400 ohm, unbalanced

Audio compression standard: MPEG-1

Audio output 315 mV, 600 ohm, unbalanced

Electrical

Power supply

Power consumption

Input voltage,

Connectors

Autoranging adapter 120 to 240 VAC

20 W max.

13.5 VDC

Power connector

Accessory I/O port

3 screw terminal

16-pin female, containing RS-232 serial port (RJ-45),

RS-485 serial port, Audio (in/out), and Alarm (in/out)

SVHS connector

RJ-45

Composite video (in/out)

10/100 Ethernet port

Environmental

Operating temperature

Storage temperature

Relative humidity

Standards

0 to +40ºC

-20 to +60ºC

10 to 80%, noncondensing

Emmissions

Mechanical

Dimensions (HxWxD)

Weight

FCC and CE

29 x 236 x 161 mm

136 g

Advanced MPEG-4 video compression allows full D1 resolution at

25 frames per second with synchronized audio

Digital resolution equals or surpasses D1, CIF, and QCIF quality

Video streaming with UDP support

Remote configuration over Ethernet

Standard, medium, and high video quality settings

Alarm input and output connections

Multilevel password protection

Compatible with GE Security’s SymVeo IP cameras and

SymNav network client software

Two form factors available - desk or rack mount

Professional hybrid DVR with 4, 8 or 16 analog inputs & 2 IP streaming ports

SymSuite

Page : 85

SymSafe

SymSafe™ Realtime Video Streaming Recorder

SymSafe introduces “hybrid” recording that works with both conventional analog cameras and the new family of GE digital network products. This unique platform provides a graceful migration path to digital recording – the future of video recording – and at the same time allows continued use of existing analog equipment.

SymSafe records 25 frames per channel, per second – at CIF resolution. It offers 4, 8 or 16 channels of analog recording and two channels of digital recording, all up to D1 resolution (720 x 576).

SymSafe can be easily networked and viewed remotely via

10/100/1000 BaseT Ethernet. SymNav software allows viewing of live and recorded video from multiple SymSafe units. A sleek and modern front panel makes the SymSafe easy to set up and use. Hard drive sizes from 160GB to 1TB are available with the SymSafe to fit all of your storage needs. A unique Cooling Tunnel design keeps each hard drive cooler to extend its life.

Specifications

Video

Inputs

Conditioning

4, 8 or 16 looping BNC connectors, NTSC/EIA or

PAL/CCIR compatible; auto- terminating

AGC, 0.7 to 1.4.0 V pk-pk video accepted

Horizontal resolution

Vertical resolution

720 pixels

576 lines

Video compression standard MPEG-4

Monitor A composite

VGA

One monitor A multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Same display content as monitor A

Monitor B composite One monitor B multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Recording

Speed

Resolution

Quality settings

Bandwidth

Network

All channels in realtime at CIF

Up to full D1

Up to 1 Mbit/sec. per ch. scalable

10/100/1000 Ethernet port: RJ-45

TCP/IP, UDP, DHCP

Type

Protocol

Archive

External

Internal

Connectors

RS-232 serial port

RS-485/422

USB

Alarm Handling

Alarm input

Alarm output

Video motion and activity detection

Zones per camera

Recording

Hard drive

USB ThumbDrive

DVD burner

1 DB-9

2 (1 at front and 1 at back)

4, 8 or 16 programmable NO/NC

Form C alarm relay (2)

256, 16 x 16 grid

2-HDD S-ATA with Cooling Tunnel design extends hard drive life

Operation

Languages

Control

USB Mause, Jog/Shuttlle, IR remote

Push buttons

Alarm indication

Alarm acknowledgement

Miscellaneous

Input voltage

Operating temperature

Dimensions (HxWxD)

Weight

Regulatory

Relative humidity

Unique indication bar

Yes

120 to 240 VAC, autoranging

0 to 40°C

89 x 395 x 420 mm

11kg

FCC, CE, UL

10 to 95%, noncondensing

Ordering Information

SYMSAFE4-160E

SYMSAFE4-320E

SYMSAFE4-640E

SYMSAFE8-160E

SYMSAFE8-320E

SYMSAFE8-640E

SYMSAFE16-160E

SYMSAFE16-1TE

SYMSAFE16-320E

SYMSAFE16-640E

SYMSAFE-RK

Professional hybrid DVR with 4 analog inputs & 2 IP streaming ports

Professional hybrid DVR with 8 analog inputs & 2 IP streaming ports

Professional hybrid DVR with 16 analog inputs & 2 IP streaming ports

Rack-mount kit for SymSafe professional hybrid DVR

Real-time recording on ALL channels @ CIF resolution

Variable record speed settings pending on resolution used

Hybrid DVR with up to 2 IP camera streams

Sleek modern interface

Unique alarm indicator light bar

Integrated SymSuite solution: SymNav and SymBrowser

Up to 1 TB internal storage

Cooling Tunnel™ design extends hard drive life

Professional hybrid DVR with 4, 8 or 16 analog inputs & 2 IP streaming ports

DVD burner

Supports ThumbDrive

Included IR remote

VGA and composite video outputs

SymSuite

Page : 86

SymSafe

Professional hybrid DVR with 4, 8 or 16 analog inputs & 2 IP streaming ports

SymSuite

Page : 87

SymSafe Pro

SymSafe Pro™ Realtime Video Streaming Recorder

SymSafe records 25 frames per channel, per second – at 2CIF resolution. It offers 4, 8 or 16 channels of analog recording and two channels of digital recording, all up to D1 resolution (720 x 576).

SymSafe can be easily networked and viewed remotely via

10/100/1000 BaseT Ethernet. SymNav software allows viewing of live and recorded video from multiple SymSafe units. A sleek and modern front panel makes the SymSafe easy to set up and use. Hard drive sizes from 160GB to 1.5TB are available with the SymSafe to fit all of your storage needs. A unique Cooling Tunnel design keeps each hard drive cooler to extend its life.

Specifications

Operation

Languages

Control

Alarm indication

Alarm acknowledgement

Miscellaneous

Input voltage

Operating temperature

Dimensions (HxWxD)

Weight

Regulatory

Relative humidity

USB Mause, Jog/Shuttlle, IR remote

Push buttons

Unique indication bar

Yes

120 to 240 VAC, autoranging

0 to 40°C

89 x 395 x 420 mm

11kg

FCC, CE, UL

10 to 95%, noncondensing

Video

Inputs

Conditioning

4, 8 or 16 looping BNC connectors, NTSC/EIA or

PAL/CCIR compatible; auto- terminating

AGC, 0.7 to 1.4.0 V pk-pk video accepted

Horizontal resolution

Vertical resolution

720 pixels

576 lines

Video compression standard MPEG-4

Monitor A composite

VGA

One monitor A multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Same display content as monitor A

Monitor B composite One monitor B multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Audio

Audio input

Audio output

315 mV, 400 kOhms, unbalanced, RCA (2)

315 mV, 600 ohms, unbalanced, RCA (1)

Audio compression standard MPEG-1

Recording

Speed All channels in realtime at 2CIF

Resolution

Quality settings

Bandwidth

Network

Type

Protocol

Archive

Up to full D1

Up to 2 Mbit/sec. per ch. scalable

10/100/1000 Ethernet port: RJ-45

TCP/IP, UDP, DHCP

USB ThumbDrive

DVD burner

External

Internal

Connectors

RS-232 serial port

RS-485/422

USB

Alarm Handling

Alarm input

Alarm output

Video motion and activity detection

Zones per camera

Recording

Hard drive

1 DB-9

2 (1 at front and 1 at back)

4, 8 or 16 programmable NO/NC

Form C alarm relay (2)

256, 16 x 16 grid

2-HDD S-ATA with Cooling Tunnel design extends hard drive life

Ordering Information

SYMSAFE-P4-160EA

SYMSAFE-P4-320EA

SYMSAFE-P4-640EA

SYMSAFE-P4-1TEA

SYMSAFE-P8-320EA

SYMSAFE-P8-640EA

SYMSAFE-P8-1TEA

SYMSAFE-P8-1.5TEA

SYMSAFE-P16-640EA

SYMSAFE-P16-320EA

SYMSAFE-P16-1TEA

SYMSAFE-P16-1.5TEA

SYMSAFE-RK

Professional hybrid DVR with 4 analog inputs & 2 IP streaming ports

Professional hybrid DVR with 8 analog inputs & 2 IP streaming ports

Professional hybrid DVR with 16 analog inputs & 2 IP streaming ports

Rack-mount kit for SymSafe professional hybrid DVR

Real-time recording on ALL channels @ 2CIF resolution

Variable record speed settings pending on resolution used

Professional hybrid DVR with 4, 8 or 16 analog inputs & 2 IP streaming ports

Hybrid DVR with up to 2 IP camera streams

2 audio inputs

Sleek modern interface

Unique alarm indicator light bar

Integrated SymSuite solution: SymNav and SymBrowser

Up to 1.5 TB internal storage

Cooling Tunnel™ design extends hard drive life

DVD burner

Supports ThumbDrive

Included IR remote

VGA and composite video outputs

SymSuite

Page : 88

SymSafe Pro

High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SymSuite

Page : 89

SymDec16Plus4

SymDec™ 16 Plus 4 Realtime Video Streaming Recorder

SymDec16 introduces “hybrid” recording that works with both conventional analog cameras and the new family of GE digital network products. This unique platform provides a graceful migration path to digital recording – the future of video recording – and at the same time allows continued use of existing analog equipment.

SymDec16 records at 25 frames per channel, per second – all at D1

(720 x 576) resolution. SymDec can be easily networked and viewed remotely via 10/100/1000 BaseT Ethernet. SymNav software allows viewing of live and recorded video from multiple SymDVRs. A sleek and modern front panel makes the SymDec16 easy to set up and use.

Hard drive sizes from 320GB to 3TB are available. A unique Cooling

Tunnel design keeps each hard drive cooler to extend its life.

Specifications

Alarm indication

Alarm acknowledgement

Miscellaneous

Input voltage

Operating temperature

Dimensions (HxWxD)

Weight

Regulatory

Relative humidity

Touch sensitive buttons

Per channel and unique indication bar

Yes

120 to 240 VAC, autoranging

0 to 40°C

89 x 442.5 x 509 mm

11,34

FCC, CE, UL

10 to 95%, noncondensing

Video

Inputs

Conditioning

16 looping BNC connectors, NTSC/EIA or PAL/CCIR compatible; auto- terminating

AGC, 0.7 to 1.4.0 V pk-pk video accepted

Horizontal resolution

Vertical resolution

720 pixels

576 lines

Video compression standard MPEG-4

Monitor A composite

VGA / DVI

One monitor A multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Same display content as monitor A

Monitor B composite One monitor B multiscreen output, BNC connector,

NTSC/EIA or PAL/CCIR compatible

Audio

Audio input

Audio output

315 mV, 400 kOhms, unbalanced, RCA (4)

315 mV, 600 ohms, unbalanced, RCA (1)

Audio compression standard MPEG-1

Recording

Speed All channels in realtime

Resolution

Quality settings

Bandwidth

Network

Type

Protocol

Archive

Full D1

Up to 3 Mbit/sec. per ch. scalable

10/100/1000 Ethernet port: RJ-45

TCP/IP, UDP, DHCP

USB ThumbDrive

DVD burner

External

Internal

Connectors

RS-232 serial port

RS-485/422

USB

Alarm Handling

Alarm input

Alarm output

Video motion and activity detection

Zones per camera

Recording

Hard drive

1 DB-9

4 (2 at front and 2 at back)

16 programmable NO/NC

Form C alarm relay 4

256, 16 x 16 grid

4-HDD S-ATA with Cooling Tunnel design extends hard drive life

Operation

Languages

Control

USB Mause, Jog/Shuttlle, IR remote

Ordering Information

SYMDEC16PLUS4-320EA High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SYMDEC16PLUS4-640EA High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SYMDEC16PLUS4-1.28TEA

High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SYMDEC16PLUS4-2TEA High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SYMDEC16PLUS4-3TEA High-end hybrid DVR with 16 analog inputs & 4 IP streaming ports, real-time D1

SYMDEC16PLUS4-RK Rack-mount kit for SymDec16 plus 4 high-end hybrid DVR

Real-time recording on ALL channels @ D1 resolution

Hybrid DVR with up to 4 IP camera streams

4 audio inputs

Sleek modern interface

Unique alarm indicator light bar

Integrated SymSuite solution: SymNav and SymBrowser

Up to 3 TB internal storage

Cooling Tunnel™ design extends hard drive life

DVD burner

VGA, DVI, and composite video outputs

Supports ThumbDrive

Included IR remote

SymSuite Video Navigation Software

SymSuite

Page : 90

SymNav

SymSuite remote client software for digital video navigation

SymNav1.9 is the backbone of GE’s suite of digital network security products. With this free software available with any of

GE’s SymSuite products, users can remotely monitor security systems, stream video directly to a personal computer, and view video streams directly from the SymVeo network camera, SymNet encoder/decoder, LegendIP Dome, SymSafe/SymSafe Pro, SymDec4 and SymDec16 DVRs. Full, quad, 9x and 16x multiview display allows to observe 16 cameras from 16 different SymSuite devices simultaneously in Live and Playback. SymNav1.9 software recognizes the SymSuite unit it connects to and provides the user with complete access to that unit’s features. Easily switch between viewing live and recorded video, or search by date, time, camera, alarms, or events. With SymNav1.9, the user can also view images stored on a

CD, DVD, or the hard drive of a PC. Printing and archiving images is simple; images can be saved in mpc or mpg file formats. A powerful address book lets the user enter information on each specific site that includes description, IP address, Ethernet connection type, unit type, and camera quantity. Controlled access to multiple SymSuite recorders can be set for multiple users. Each user is assigned to a group that has specific access rights to some or all of the sites in a system.

Specifications

Marginal graphics adapter

Better graphics adapter

High end graphics adapter

- 64-128MB RAM, AGP8x

- 128-512MB RAM, AGP8x pr PCIe

- 512MB RAM or higher, gaming cards

Ordering Information

SymNav SymSuite Video Navigation Software

Recommended PC configuration

CPU

RAM

Hard disk drive

Monitor

Graphic card

Pentium 3.2 GHz HT or faster

1048MB DDR-RAM

50MB free hard drive space

SVGA, 1280x1024, 24-bit color

AGP or PCI Express,

400 MHz RAMDACs

512MB DDR/DDR2 display memory

256-bit memory Interface

Full DirectX 9.0c support - or higher support

Windows® 2000 SP4, XP SP2 Operating system

PC HW requirements

Display/Size/Rate

Full screen/D1/25fps

Quad display/D1/25fps

9up/D1/25fps

16up/D1/25fps

Full screen/2CIF/25fps

Quad display/2CIF/25fps

9up/2CIF/25fps

16up/2CIF/25fps

Full screen/CIF/25fps

Quad display/CIF/25fps

9up/CIF/25fps

16up/CIF/25fps

PC cross reference table

Equipment

Marginal CPU

Better CPU

High End CPU

- Configuration

- Better CPU, Better graphics adapter

- High end CPU, High end graphics adapter

- PC HW currently not available

- Marginal CPU, Better graphics adapter

- High end CPU, High end graphics adapter

- Marginal CPU, Better graphics adapter

- Better CPU, High end graphics adapter

-Better CPU, High end graphics adapter

- Description

- 1.6 to 2.4GHz Single Core Processor, 512KB RAM or more

- 2.6 to 3.0GHz HT Single/Dual Core Processor, 1 to

2GB RAM or more

- 3.2GHz or higher, Dual Core Processor, 2GB RAM or more

Remote access to SymDec menu systems

Receives multicast video streams

View up to 16 cameras simultaneously

Remote PTZ camera control

Disk analysis window provides overview of recorded data on a per disk basis

Advanced search filters include alarm/event, text, camera, time, and date over multiple site locations

Capture, print, and save images

ProBridge 3 POS Interface for SymDVR

Interfaces

Page : 91

CBR-PB3X-POS

ProBridge 3 POS Interface

The Probridge 3 (PB3) is a text translation device that captures a point-of-sales (POS) transaction data and translates it to a format that can be interpreted by GE Security's digital video recorders (SymDVR

DVMRe and StoreSafe).

The data which is synchronized with video recorded by the SymDVR can be played back locally at the SymDVR or remotely using SymNav or WaveReader software. Specific events or transactions are easily retrieved: using the SymDVR or SymNav software, operators can search data by any combination of time, date, camera, transaction number or transaction text.

Specifications

Mechanical

Construction

Dimensions (H x W x L)

Nominal weight

Ambient conditions

Operating temperature

Relative humidity

External AC power supply

(included)

Input

Black anodised aluminium

24 x 108 x 178 mm

0.14 kg

0 to 40°C

90%, noncondensing

Voltage

Power

Output

Rating

110 or 240 VAC ±10%

20 W

Current

DC power connector

PB3 current

Cables included

12 VDC

1 A

DC jack, positive centre pin

110 mA

1 PB3 to SymDVR cable RJ-45 to RB9F

1 PB3 to SymDVR CS/CD cable RJ-45 to DB9F (or programming via Windows

HyperTerminal)

1 PB3 to printer interconnect cable

DB-25M to DB-25F

1 PB3 interface cable to receipt printer

DB-25M to DB-25F

Eliminate need for costly third-party interface equipment

Capture transaction text and associates it with recorded video

Search data by time, date, camera or transaction text using

SymDVR, DVMRe or Remote software

Compatible with SymDVR, DVMRe-CT series and StoreSafe

Advanced digital video multiplexer recorders

In a single drop-POS network, connect multiple PB3s through a built-in RS485 network

Built-in diagnostics confirm proper setup and operation

Nonvolatile memory retains settings during power loss

Ordering Information

CBR-PB3X-ATM

CBR-PB3X-POS

Capture ATM Transaction Text and Associate it with

Recorded Video

ProBridge 3 POS Interface for SymDVR

MONITORS

High resolution 15" monochrome monitor with audio

The perfomance of the 15" high resolution monochrome monitor is superb. Providing > 1000 TVL resolution and combined with a high resolution camera, the resulting pictures are testimony to the highest build and operational quality of this product.

Specifications

CRT picture tube size

Horizontal resolution

Auto loop through

S. VHS input

Video in/out

Audio

Video standard

Power consumption

Relative humidity

Operating temperature

Weight

Cabinet

Supply voltage

15 in. 90°

>1000 TVL

N/A

BNC

Yes

CCIR

35 W (max.)

10 to 90%

-10 to +50°C

12 kg

Metal

100 to 240 VAC

Ordering Information

MV-150A

MV-9PL

MV-120A

High resolution 15" monochrome monitor with audio

High resolution 9" plastic monochrome monitor

High definition 12" monochrome monitor with audio

High resolution > 1000 TVL

Clean crisp images

High contrast

Audio capability

CCIR

Universal voltage input 100 VAC to 240 VAC

Monitors

Page : 95

MV-150A

High res 15" colour monitor, OSD, dual BNC, U/O scan, audio

The perfomance of the 15" high resolution colour monitor is superb.

Providing > 800 TV lines resolution and combined with a high resolution camera, the resulting pictures are testimony to the highest build and operational quality of this product. Added features such as dual camera input and O/U scan allows comparisons to be made in a test environment

Specifications

CRT Picture tube size

Horizontal resolution

Auto loop through

S. VHS input

Video in/out

Audio

Under/over scan

Video standard

User control

Power consumption

Relative humidity

Operating temperature

Weight

Cabinet

Dimensions (W x H x D)

Supply voltage

15 in. 90°

>800 TV lines

Yes

BNC x 2 sets

Yes

PAL & NTSC

OSD

95 W (max.)

10 to 90%

-10 to +50°C

15 kg

Metal

368 x 361 x 376 mm

100 to 240 VAC

Ordering Information

CV-150HX

CV-170HX

CV-190A/H

High res 15" colour monitor, OSD, dual BNC, U/O scan, audio

High res 17" colour monitor, OSD, dual BNC, U/O scan, audio

High res 19" colour monitor, OSD, dual BNC, U/O scan, audio

High resolution > 800 TV lines

Clean crisp images

High contrast

Audio capability

Digital OSD

S.VHS Input

Dual camera inputs

Over/under scan via front panel push button

Auto loop through

PAL and NTSC

Universal voltage input 100Vac to 240Vac

Monitors

Page : 96

CV-150HX

15" TFT Flatscreen CCTV monitor

Monitors

Page : 97

LV-15W

The new LV-15W with attractive silver finish is the next generation professional LCD monitor from GE-Security. A new hi-resolution, low lag panel is the heart of this high end display.

New features include Picture in Picture (PIP) from two different sources, so a single monitor can display two different display sources

(VGA and Video) at the same time, plus an over/under scan option.

The high contrast and brightness LV-15W colour 15" LCD monitor is ideally suited to a wide range of applications, including most retail, industrial and commercial environments. Light in weight, compact and with low current requirements, the LCD monitor represents the future in surveillance requirements.

An array of different compatible wall mounts and desk brackets are also available (contact your GE Security sales rep for info)

Specifications

LCD display

Resolution

Effective display area

Pixel pitch

Colour

Response time

Contrast ratio

Brightness

Viewing angle

Input Signal

VGA Signal

Scan frequencies

Video in

Front panel controls

OSD controls

Power supply

Power consumption

Operating temperature

Relative humidity

Dimensions (W x H x D)

Weight

Approvals

Audio

15 in. TFT

1024 x 768 XGA

304 x 228 mm

0.29

262,144 colours

16 ms

400:1

500 cd /m 2

140 (H) x 130 (V)

Video (loop-thru) , S-Video (loop-thru) and VGA

Analogue VGA / 15 Pin-D-Sub connector

Horizontal: 30 K ~ 80 KHz Vertical: 56 ~ 75 Hz

1.0 V pk-pk 75 / BNC in/out, Y/C input, PAL: 15.625 KHz

Power, auto tuning, menu, volume, brightness, contrast

Brightness, contrast, auto adjust, PIP, phase clock, H.

position, V. position, sharpness,etc

12 VDC, 3 A (power supply included)

50 W (max.)

0 to 40°C

10 to 85%

353 x 338 x 170 mm

4 kg

FCC, CE, UL, CUL, BSMI

1x phono (loop-through) 1 W max.

New slimline silver design

Latest generation High Contrast, Brightness, low lag TFT panel

Industry standard BNC, S-video, Audio Loop Through

Picture in Picture function (PIP)

High viewing angle

Under/Over scan function

NTSC/PAL auto recognition

Ordering Information

LV-15W

LV-17W

LV-19W

15" TFT Flatscreen CCTV monitor

17" TFT Flatscreen CCTV monitor

19" TFT Flatscreen CCTV monitor

15" TFT Flatscreen CCTV monitor

The new LV-15ECO is the entry level professional LCD monitor from

GE Security. It features a crisp, clear picture performance using a new high resolution (500 TVL) high contrast ratio panel.

LV-15ECO colour 15" LCD monitor is ideally suited to a wide range of applications, including most retail, industrial and commercial environments. Light in weight, compact and with low current consumption, the LCD monitor represents the future in surveillance requirements.

A range of different compatible wall/ceiling mounts and desk brackets are also available (contact your GE Security sales rep for info)

Specifications

LCD Display

Resolution

Video resolution

Pixel Pitch

Response time(tr/tf)

Contrast ratio

Brightness

View angle

Input Signal

VGA Signal

Video input

Front panel controls

OSD controls

Supply voltage

Power consumption (max)

Operating temperature

Operating humidity

Dimensions

Net weight

Safety & EMI

Audio

15" TFT

1024 x 768 XGA

500 TVL

0.297 x 0.297 mm

16ms (tr+tf)

400:1

350 cd/m2

120°(H) / 100°(V)

Video (loop-thru) , S-Video (loop-thru) and VGA

Analogue VGA / 15 Pin-D-Sub connector

1.0 Vp-p 75 / BNC in/out, Y/C input, PAL: 15.625 KHz

Power, Auto Tuning, Menu, Volume, Brightness,

Contrast

Brightness, Contrast, Auto adjust, Phase Clock, H.

Position, V. Position, Sharpness,etc

12 VDC, 4.16 Amp (power supply included)

30W (max)

0°C to + 40°C'

10% to 85%

364 x 316 x 170 mm

4 kg

FCC, CE, UL, CUL, BSMI

1x Phono (loop-thru) 1 Watt max

Ordering Information

LV-15ECO

LV-17ECO

LV-19ECO

15" TFT Flatscreen CCTV monitor

17" TFT Flatscreen CCTV monitor

19" TFT Flatscreen CCTV monitor

Stylish and portable design

High resolution, high contrast ratio

High viewing angle

NTSC/PAL auto recognition

Industry standard BNC, S-video, Audio Loop Through

VGA input

Universal VESA mount

Monitors

Page : 98

LV-15ECO

Monitor Bracket Wall mount 9 to 12 inches black

MBC monitor brackets are made of black polyester coasted steel. The bracket uses telescopic components which allows adjustment in both vertical and horizontal directions.

Ordering Information

MBW9-12

MBW12-17

MBW17-24

MBC9-12

MBC12-17

MBC17-24

Monitor Bracket Wall mount 9 to 12 inches black

Monitor Bracket Wall mount 12 to 17 inches black

Monitor Bracket Wall mount 17 to 24 inches black

Monitor Bracket Ceiling mount 9 to 12 inches black

Monitor Bracket Ceiling mount 12 to 17 inches black

Monitor Bracket Ceiling mount 17 to 24 inches black

VESA standard wall mount adapter

Wall mount Bracket for firmly fix on solid walls.

Specifications

Mount

VESA

Adjustment

Horizontal swivel

Monitor swivel

Vertical swivel

Miscellaneous

Dimensions (HxWxD)

Weight

Bearing capacity

75 x 75 mm up to 180°

270° up to 180°

113 x 73 x 108 mm

1.8 kg

12 kg

Ordering Information

DW-170

DW-171

DW-150

VESA standard wall mount adapter

Wall mount (2 adjustment knuckles)

Wall mount arm with C- clamp

Meets VESA standards Mounting specification

Standard 75mm X 75mm intefrace provided

Three knuckles for adjusting

Holds LCD Monitor up to 12 kgs

Monitors

Page : 99

MBW9-12

DW-170

VIDEO IQ

VideoIQ system

VideoIQ

Page : 103

VIQ-8HDX

VideoIQ creates a new standard for human detection applications with CCTV cameras. VideoIQ improves the efficiency of a security system, minimizing false alarms, particularly in challenging outdoor environments. VideoIQ uses GE Security proprietary technology to go far beyond what video motion detection can deliver, accurately detecting human activity 95 percent of the time.

Specifications

VIQ-8HD Series

PC supplied

CPU

RAM

Hard disk drive

Internal drive

Ports

Capture card

Operating system

Power

Power consumption

Inputs

Video inputs

Video format

Outputs

Video output signal

Alarm output

Alarm I/O levels

Mechanical

Dimensions

Weight

Operating temperature

Cables

RS-232

3.2 GHz

512 MB

80 GB EIDE

Floppy drive, CD-ROM

2 DB9 male RS-232 ports, VGA port

Frame Grabber Cronos Plus card

Windows XP Professional and VideoIQ application

100 to 250 VAC, 50/60 Hz

350 W

NTSC or PAL

1 VGA

8 TTL levels

Active high or low, selectable

441 x 450 x 177 mm

16 kg

0° to 55°C

10 ft DB9 (female) to DB9 (female) null modem

I/O Board for alarm output

Compatible digital video multiplexers and recorders

DVMRe Multiplexer/Recorder

(not included)

Version 5.02 or higher

Video-based human detection system that provides both alarms and associated video

Detects humans in dynamic outdoor environments

Distinguishes between humans and other moving objects

Ignores dynamic background motion and focuses on foreground objects of interest

NTSC and PAL compatible

Eight-channel, PC-based system that integrates with existing

DVMRe systems (5.02 or higher)

Eight individual alarm outputs with programmable duration

No LCD monitor supplied

Ordering Information

VIQ-8HDX VideoIQ system

ACCESSORIES

4 Channel Colour Quad

The GEQ-C56 is an advanced, full featured colour Quad with a real time display and fullscreen playback of recorded images.

Advanced options include individual gain settings for each camera, alarm inputs on each channel with an alarm output, and video loss detection. Additionnally basic motion detection for alarm monitoring from standard fixed cameras is available.

Specifications

Camera inputs

Monitor output

VCR IN

VCR OUT

Refresh rate

Alarm input

Alarm output

Power

Power Consumption

Weight

Dimensions

4 x BNC with loopthrough

1x BNC

30 fields per second

4x NC / NO contact

1x contact

12 VDC, 1.5 A (PSU not included)

Optional PSU: KTP-12-DCU

18 W

1.6 kg

238 (W) x 208.5 (D) x 51.7 (H) mm

Ordering Information

GEQ-C56 4 Channel Colour Quad

Full colour quad with loopthrough

Real time display

Full screen playback

4 Alarm inputs / 1 output

Motion detection function

Time and date display

Sequence and Freeze

Picture in Picture (PIP) display option

Individual camera gain adjustment

Video loss detection

Quad

Page : 107

GEQ-C56

RS422 data signal distributor-provides six separate RS422 outputs

The KTD-83U is a data signal distributor designed for use in a Digiplex system. It is used when an RS422 control signal must be dispersed along separate lines of two-conductor, twisted-pair cable. One signal input can be distributed among up to six outputs. The KTD-83U can also be used to reamplify RS422 control signals that must travel excessive distances between the controller and receiver.

Cable connections are made on a removable, 14-position terminal strip. The KTD-83U is constructed of aluminum. It features a black anodized finish.

Specifications

Electrical

Input voltage

Input power

Input data signal

Output 1

Outputs 2-6

Connections

Mechanical

Weight

Material

Finish

12 VDC, adapter 110 - 230 VAC to 12 VDC included

6 W

RS-422

RS-422 (Not amplified)

RS-422 (Amplified to original level)

14-position removable terminal strip

230 g

1.3 mm aluminium

Black anodised

Distributes an RS422 control signal

1 input x 6 outputs

Reamplifies signal on outputs 2 through 6

Powered from a 12 VDC source

Adapter 110-230 VAC to 12 VDC included

Compact design

Removable terminal strip for cable connections

Ordering Information

KTD-312U

KTD-415U

KTD-83U

KTD-87E4

RS232/RS422 interface unit

16 Input Alarm Module, PSU Included

RS422 data signal distributor-provides six separate RS422 outputs

RS422 / RS232 converter (selectable)

Interfaces

Page : 108

KTD-83U

16-Channel distribution amplifier

Video switchers

Page : 109

KTS-250-16U

The KTS-250-16 is a video distribution amplifier that features eight groups of input/output channels. Each group can be configured as a single 1x8 video distribution amplifier or two 1x4 video distribution amplifiers. This enables users to set multiple configurations from 8 to

16 inputs by up to 64 outputs. Each output provides unity gain into a

75 ohm load, ensuring that the output signal is equal to that of the input. Unused outputs self terminate.

The KTS-250-16 is compatible with colour or monochrome, NTSC or

PAL video. All video connections are made via BNC connectors. It takes 8.89 cm (2 U) of space in a standard, 48.26 cm rack.

Specifications

Electrical

Input voltage

Input power

Video

Inputs

Outputs

Impedance

Bandwidth

S/N ratio

Crosstalk

Gain (into a 75 ohm load)

Differential gain

Differential phase

Connections

Power

Video

Controls

Mechanical

Weight

Material

Finish

12 VAC/15 VDC, adapter 110 - 230 VAC to 15 VDC included

0.8 W

Up to 16 composite video 1 V pk-pk

Up to 64 composite video 1 V pk-pk

75 ohm, inputs and outputs

16 MHz

-75 dB RMS typical

-85 dB typical

0 dB ±0.5 dB typical

0.5% typical

0.5° typical

2.1 x 5.5 mm; centre-positive jack

BNC connectors

Mode selector switch

1.23 kg

Aluminium

Dark grey powder coat

Eight input/output groups; each configurable as a 1x8 video distribution amplifier or two 1x4 video distribution amplifiers

Equal video strength for all outputs

Colour compatible

Unused outputs are self-terminating.

NTSC and PAL compatible

Only 8.89 cm (2 U) of rack space

Ordering Information

KTS-250-16U 16-Channel distribution amplifier

Universal 12 DC Power Supply

Switching Power Supply,1A 12VDC, European Power Cord

The KTP-12DCU is a compact and durable power supply that is typically used to power up indoor video components. It features an isolated 12 VDC output that can power devices requiring 1 amp or less. The unit can be powered from a 230 VAC source.

Specifications

Electrical

Model KTP-12DCU

Input Voltage

Power Consumption

Output Voltage

Output Current

Power Connection

Mechanical

Dimensions

Weight

Standards
