PREFACE
Manual Objectives
This manual shows you how to set up and use the Programmable Digital Meter.
Standard Procedures:
*
*
*
*
*
*
*
*
*
*
*
*
*
*
Checking voltage jumpers, or changing voltage power
Mounting the panel
Selecting the input type
Selecting a decimal point position
Scaling with known loads (on-line calibration)
Scaling without known loads
Selecting ratiometric/non-ratiometric operation
Displaying the filtered/unfiltered input signal
Selecting a display color
Setting the setpoint's active band
Selecting a latched or unlatched operation
Setting setpoint deadbands
Enabling/disabling setpoint changes
Enabling/disabling the RESET button in the Run Mode
Optional Procedures:
*
*
*
*
*
Setting input resolution
Enabling/disabling analog output
Selecting analog output as current or voltage
Assigning the output to net/gross reading
Scaling analog output
Features with
are for the “B” version which has three-color programmable
“Big” LED display - All segment characters shown are for the “B” version.
For first-time users: Refer to the QuickStart Manual for basic operation and setup instructions.
i
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table A-1. Sections of the Manual
If you want to read about:
Refer to section
Unpacking; safety considerations
1
Introduction
Meter description and features
2
About the Meter
Main board power jumpers; panel
mounting, sensor input, main power and
analog and relay output
3
Getting Started
Input type; decimal point position;
reading scale & offset; reading
configuration; display color; setpoint
configuration; setpoint deadbands;
output configuration (analog output);
analog output scaling; lock out
configuration; display brightness
4
Configuring the Meter
Display messages
5
Display Messages
Meter menu/sub-menu messages
6
Menu Configuration
Setpoint configuration messages
7
Setpoint Configuration
Displays
Specifications
8
Specifications
Factory Preset Values
9
Factory Default
Setup as Shipped
ii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of Contents
Table of Contents
Section
Page
SEC 1
1.1
1.2
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
SEC 2
2.1
2.2
2.3
2.4
2.5
2.6
ABOUT THE METER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Available Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Front of the Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Back of the Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
SEC 3
3.1
3.2
3.3
3.4
3.5
3.6
3.7
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Rating/Product Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Main Board Power Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Panel Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Connecting Sensor Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Connecting Main Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Connecting External Tare Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Connecting Analog and Relay Outputs . . . . . . . . . . . . . . . . . . . . . . . . . .19
SEC 4
4.1
4.2
4.3
4.3.1
4.3.2
4.4
4.4.1
4.4.2
4.4.3
4.4.4
CONFIGURING THE METER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Selecting the Input Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Selecting a Decimal Point Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Selecting Reading Scale and Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Scaling with Known Loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Scaling without Known Loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Using Reading Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Selecting Ratiometric/Non-Ratiometric Operation . . . . . . . . . . . . . . . . . .28
Setting Input Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Displaying the Filtered/Unfiltered Input Signal . . . . . . . . . . . . . . . . . . . . .29
Selecting Gross/Net or Peak Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
iii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of Contents
Table of Contents
Section
4.5
4.6
4.6.1
4.6.2
4.6.3
4.7
4.7.1
4.7.2
4.7.3
4.8
4.9
4.10
4.10.1
4.10.2
4.10.3
4.11
4.11.1
4.12
4.12.1
4.12.2
4.12.3
4.13
4.13.1
Page
Selecting a Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Using Setpoint 1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Setting Setpoint 1's Active Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Selecting if Setpoint 1 is Latched or Unlatched . . . . . . . . . . . . . . . . . . . .31
Assigning Setpoint 1 Values to Net or Gross Readings . . . . . . . . . . . . . .32
Using Setpoint 2 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Setting the Setpoint 2’s Active Band . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Selecting if Setpoint 2 is Latched or Unlatched . . . . . . . . . . . . . . . . . . . .33
Assigning Setpoint 2 Values to Net or Gross Readings . . . . . . . . . . . . . .33
Setting the Setpoint 1 Deadband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Setting the Setpoint 2 Deadband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Using Output Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Enabling or Disabling the Analog Output . . . . . . . . . . . . . . . . . . . . . . . . .37
Selecting Analog Output as Current or Voltage . . . . . . . . . . . . . . . . . . . .38
Selecting Analog Output or Proportional Control . . . . . . . . . . . . . . . . . . .38
Using Output Scale and Offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Examples of Output Scale and Offset . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Using Lock Out Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Enabling or Disabling the RESET Button in the Run Mode . . . . . . . . . . .42
Enabling or Disabling Setpoint Changes . . . . . . . . . . . . . . . . . . . . . . . . .42
Setpoint Display Function: Firmware Version or Setpoint Value . . . . . . .43
Using Display Brightness Configuration . . . . . . . . . . . . . . . . . . . . . . . . .43
Changing Brightness Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
SEC 5
DISPLAY MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
SEC 6
MENU CONFIGURATION DISPLAYS . . . . . . . . . . . . . . . . . . . . . . . . . .45
SEC 7
SETPOINT CONFIGURATION DISPLAYS . . . . . . . . . . . . . . . . . . . . . . .49
SEC 8
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
SEC 9
FACTORY PRESET VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
SEC 10
CE APPROVAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
iv
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of Contents
List of Figures
Figure
2-1
2-2
2-3
3-1
3-2
3-3
3-4
3-5
3-6
3-7
3-8
3-9
3-10
3-11
3-12
3-13
3-14
3-15
3-16
4-1
8-1
Page
Front-Panel with “Big” LED Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Front Panel with Standard LED Display . . . . . . . . . . . . . . . . . . . . . . . . . .5
Connectors (AC-Powered and DC-Powered) . . . . . . . . . . . . . . . . . . . . . .8
Main Board Power Jumpers (W1, W2, W3) . . . . . . . . . . . . . . . . . . . . . .11
Main Board Jumper Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Upper Isolated Analog Output Option Board Installation . . . . . . . . . . . . .12
Meter - Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Panel Cut-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Meter-powered Bridge Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Externally-powered Bridge Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4-Wire DC Input Connections with External Excitation . . . . . . . . . . . . . .16
Current Input Connections with Internal Excitation . . . . . . . . . . . . . . . . .16
Current Input Connections with External Excitation . . . . . . . . . . . . . . . . .17
Main Power Connections - AC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Main Power Connections - DC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
External Tare Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Analog Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Relay Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Isolated Analog Output Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Alarm Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Meter Dimensions/Panel Cutout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
v
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of Contents
List of Tables
Table
A-1
2-1
2-2
2-3
3-1
3-2
4-1
4-2
4-3
4-4
5-1
6-1
6-2
7-1
8-1
9-1
Page
Sections of the Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Accessories and Add-Ons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Connector Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
DIP Switch Positions/Input Range & Excitation . . . . . . . . . . . . . . . . . . . .10
S3 Jumper Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
AC-Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Range Selection Dip Switch Positions for Regular Voltage Input . . . . . .23
Range Selection Dip Switch Positions for Millivolt/Milliamp Input . . . . . .23
Natural Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Input Resolution Multiplier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Display Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Menu Configuration Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Run Mode Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Setpoint Configuration Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Color Chart for DC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Factory Preset Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
vi
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Notes, Warnings and Cautions
NOTES, WARNINGS and CAUTIONS
Information that is especially important to note is identified by three labels:
•
•
•
•
Note ☞
NOTE
WARNING
CAUTION
IMPORTANT
NOTE: provides you with information that is important to successfully setup
and use the Programmable Digital Meter.
CAUTION or WARNING: tells you about the risk of electric shock.
CAUTION, WARNING or IMPORTANT: tells you of circumstances or
practices that can effect the meter's functionality and must refer to
accompanying documents.
TIP: Provides you helpful hints.
vii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Notes
viii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Introduction
1
SECTION 1. INTRODUCTION
1.1 UNPACKING
Remove the Packing List and verify that all equipment has been received. If there are
any questions about the shipment, use the phone numbers listed on the back cover to
contact the Customer Service Department nearest you.
Upon receipt of shipment, inspect the container and equipment for any signs of damage.
Take particular note of any evidence of rough handling in transit. Immediately report any
damage to the shipping agent.
Note ☞
The carrier will not honor any claims unless all shipping material is saved for
their examination. After examining and removing contents, save packing
material and carton in the event reshipment is necessary.
Verify that you receive the following items in the shipping box:
QTY
DESCRIPTION
1
Programmable Digital Meter indicator/controller with all applicable
connectors attached.
1
Owner's Manual
1
Set Mounting brackets
Note ☞
If you ordered any of the available options (except the "BL" Blank Lens
option), they will be shipped in a separate container to avoid any damage to
your indicator/controller.
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1
Introduction
1.2
SAFETY CONSIDERATIONS
This device is marked with the international caution symbol. It is important to
read this manual before installing or commissioning this device as it contains
important information relating to Safety and EMC (Electromagnetic Compatibility).
This instrument is a panel mount device protected in accordance with EN 610101:2001, electrical safety requirements for electrical equipment for measurement, control
and laboratory. Installation of this instrument should be done by qualified personnel. In
order to ensure safe operation, the following instructions should be followed.
This instrument has no power-on switch. An external switch or circuit-breaker shall
be included in the building installation as a disconnecting device. It shall be marked to
indicate this function, and it shall be in close proximity to the equipment within easy
reach of the operator. The switch or circuit-breaker shall not interrupt the Protective
Conductor (Earth wire), and it shall meet the relevant requirements of IEC 947–1 and
IEC 947-3 (International Electrotechnical Commission). The switch shall not be
incorporated in the main supply cord.
Furthermore, to provide protection against excessive energy being drawn from the
main supply in case of a fault in the equipment, an overcurrent protection device shall
be installed.
Note ☞
•
•
•
•
•
•
•
Do not exceed voltage rating on the label located on the top of the instrument
housing.
Always disconnect power before changing signal and power connections.
Do not use this instrument on a work bench without its case for safety reasons.
Do not operate this instrument in flammable or explosive atmospheres.
Do not expose this instrument to rain or moisture.
Unit mounting should allow for adequate ventilation to ensure instrument does not
exceed operating temperature rating.
Use electrical wires with adequate size to handle mechanical strain and power
requirements. Install without exposing bare wire outside the connector to minimize
electrical shock hazards.
EMC Considerations
•
Whenever EMC is an issue, always use shielded cables.
•
Never run signal and power wires in the same conduit.
•
Use signal wire connections with twisted-pair cables.
•
Install Ferrite Bead(s) on signal wires close to the instrument if EMC problems
persist.
Failure to follow all instructions and warnings may result in injury!!
2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
About The Meter
2
SECTION 2. ABOUT THE METER
2.1 DESCRIPTION
The Digital Programmable Strain meter is a value packed indicator/controller. Four full
digits and broad scaling capability allow for display in virtually all engineering units.
A wide variety of DC current and voltage input ranges cover typical strain applications.
Standard features include sensor excitation and front panel or remote tare. Your meter
may be a basic indicator or it may include analog output or dual relay output. Analog or
dual relay output must be ordered at time of purchase. Analog output is fully scalable
and may be configured as a proportional controller, or to follow your display. Dual 5 amp,
form C relays control critical processes. A mechanical lockout has been included to
guard against unauthorized changes.
2.2 FEATURES
The following is a list of standard features:
*
*
*
*
*
*
*
*
*
4-digit, three color Programmable, Big LED display or
4-digit, Standard LED display
NEMA 4/Type 4 Front Bezel
±0.03 % accuracy
8 DC input ranges: 0-100 mV, ±50 mV, 0-5 V, 1-5 V,
0-10 V, ±5 V, 0-20 mA, and 4-20 mA
5, 10, 12, or 24 Vdc sensor excitation
Peak detection
Front panel and remote tare function
Nonvolatile memory-no battery backup
115 or 230 Vac 50/60 Hz power supply or
10-32 Vdc or 26-56 Vdc
The following is a list of optional features:
*
*
*
*
Dual 5 amp, form C relay outputs
Scalable analog output
Proportional control
Easy setup for proportional control
3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2
About The Meter
2.3 AVAILABLE ACCESSORIES
Table 2-1. Accessories and Add-Ons
Add-On Options
FS
SPC4
SPC18
Special Calibration/Configuration
NEMA-4 Splash Proof Cover
NEMA-4 Splash Proof Cover, NEW
Accessories
TP1A
RP18
RP28
RP38
Trimplate panel adaptor.
Adapts DIN1A/DIN2A cases to larger panel cutouts
19-In. Rack Panel for one (1) 1/8 DIN instrument
19-In. Rack Panel for two (2) 1/8 DIN instruments
19-In. Rack Panel for three (3) 1/8 DIN instruments
4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
About The Meter
2
2.4 FRONT OF THE METER
Figure 2-1 shows each part of the front of the three-color programmable “Big” LED
display meter (Version B).
Digital LED Display:
-1.9.9.9 or 9.9.9.9 4-digit
three color programmable,
21 mm (0.83") high LED
display with programmable
decimal point.
Figure 2-1. Front-Panel with Big Display
Figure 2-2 shows each part of the front of the standard LED display meter.
••••
1
SETPTS
Digital LED Display:
-1.9.9.9. or 9.9.9.9.
14 segment, 13.8 mm
(0.54") high LED display
with programmable
decimal point.
2
/NT/GRS
/TARE
MENU
RESET
Figure 2-2. Front-Panel wtih Standard Display
These meter display windows (both versions) light when appropriate:
1
Setpoint 1 status
2
Setpoint 2 status
5 Pushbuttons for programming the meter.
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2
About The Meter
METER BUTTONS
SETPTS Button
In the Run Mode, this button will sequentially recall the previous setpoint settings. As
necessary, use the /NT/GRS and /TARE buttons to alter these settings, then press
the SETPTS button to store new values.
Unless you press the SETPTS, /TARE, or /NT/GRS button within 20 seconds, the
meter will scroll to setpoint 2 and then to the Run Mode.
Note ☞
If the dual relay option is not installed or if L.3=1 is displayed on the LK.CF
menu, pressing the SETPTS button will display the meter's firmware version.
/NT/GRS Button
In the Run Mode, this button will toggle between net/gross readings or peak readings
depending upon setup.
In the Configuration Mode, press this button to change the value of the flashing digit
shown on the display and/or toggle between menu choices, such as R.1=R or R.1=N on
RD.CF menu. When configuring your setpoint values, press the /NT/GRS button to
advance the flashing digit's value from 0 to 9 by 1.
/TARE Button
In the Run Mode press the /TARE button to tare your reading (zeroing).
In the Configuration Mode, press the this button to scroll to the next digit.
6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
About The Meter
2
MENU Button
In the Run Mode, press the MENU button to terminate the current measuring strain and
enter you into the Configuration Mode.
Note ☞
Only if you have not installed the lock out jumpers on the main board.
In the Configuration Mode, press the MENU button to store changes in the nonvolatile
memory and then advance you to the next menu item.
RESET Button
If you hard reset (press the MENU button followed by the RESET button) or power off/on
the meter, it shows RST , followed by STRN.
In the Run Mode, press the RESET button to reset the latched setpoints. The meter
shows SP.RS and returns to the Run Mode.
In the Configuration Mode, press the RESET button once to review the previous menu.
Press the RESET button twice to perform a hard reset and return to the Run Mode.
In the Peak Mode, press the RESET button to reset peak values. The meter shows
PK.RS and returns to the Run Mode.
In the Setpoint Mode, press the RESET button to reset the latched setpoint. The meter
shows SP.RS and enters the Run Mode.
In the Tare Mode, press the RESET button to reset. The meter shows T.RST.
Note ☞
When in setpoint or Configuration Mode, if the meter shows 9999 or -1999
with all flashing digits, the value has overflowed. Press the /NT/GRS
button to start a new value.
7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2
About The Meter
2.5 BACK OF THE METER
Figure 2-3 shows the label describing the connectors on the back of the meter. Table 2-2
on the following page gives a brief description of each connector at the back of the meter.
POWER & INPUT CONNECTIONS(STRAIN)
Figure 2-3. Connectors (AC-Powered and DC-Powered Detail)
8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
About The Meter
2
2.5 BACK OF THE METER (Continued)
Table 2-2. Connector Description
Connector
TB1-1
TB1-2
TB1-3
TB1-4
TB1-5
TB1-6
TB1-7
TB1-8
TB1-9
TB1-10
TB1-11
TB1-12
TB2-1
TB2-2
TB2-3
TB2-4
TB2-5
TB2-6
TB2-7
TB2-8
TB5-1
TB5-2
TB5-3
J1 (1-2)
Description
Setpoint 1: Normally open (N.O.1) connection
Setpoint 1: Normally closed (N.C.1) connection
Setpoint 1: Common (COM1) connection
Setpoint 2: Normally open (N.O.2) connection
Setpoint 2: Normally closed (N.C.2) connection
Setpoint 2: Common (COM2) connection
AC line connection (no connections on DC-powered units)
AC neutral connection (+ Input on DC-powered units)
AC earth ground (DC-power return on DC-powered units)
Analog voltage output
Analog current output
Analog return
-E: Negative excitation connection from meter (5, 10, 12 V)
+E: Positive excitation connection from meter (5, 10, 12 V)
+20 mA connection for analog input
+R (Not used)
+24 V output connection
+S: Positive signal input
-S: Negative signal input and return for +20 mA or +24 V
-R (Not used)
Isolated Analog Voltage Output
Isolated Analog Current Output
Isolated Analog Output Return
Remote tare connection with a momentary switch
9
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
2
About The Meter
The DIP switches are located at the S1 position (refer to Figure 3-2). Use a small
instrument, such as a paper clip, to change the switches from open to closed. Table 2-3
lists DIP switch settings at the S1 position required to complete the setup of your meter.
Table 2-3. DIP Switch Positions/Input Range & Excitation
Function
C= Closed
O= Open
S1 DIP Switch Positions
1
2
3
4
5
6
7
8
Settings for Excitation Voltage
Internal 5/10/12
excitation
External 5/10/12
excitation
Internal
12 Vdc excitation
Internal
10 Vdc excitation
Internal
5 Vdc excitation
0-100 mV DC
±50 mV DC
±5 Vdc
0-10 Vdc
0-20 mA DC
Note ☞
C
-
-
-
-
-
-
-
O
-
-
-
-
O
O
-
C
-
-
-
-
O
O
-
C
-
-
-
-
C
O
-
-
C
C
-
O
C
C
O
O
-
-
O
O
C
C
O
C
Settings for Input Ranges
O
C
O
O
C
O
C
O
O
C
O
O
O
C
C
The display must also be configured to the selected input type after setting
the DIP switches (see Section 4.1, Selecting the Input Type)
2.6 DISASSEMBLY
You may need to open up the meter for one of the following reasons:
•
•
Note ☞
To check or change the 115 or 230 Vac power jumpers.
To install or remove jumpers on the main board.
Disconnect the power supply before proceeding.
To remove and access the main board, follow these steps:
•
•
•
Disconnect the main power from the meter.
Remove the back case cover.
Lift the back of the main board upwards and let it slide out of the case.
10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Getting Started
3
SECTION 3. GETTING STARTED
Caution: The meter has no power-on switch, so it will be in operation as
soon you apply power.
If you power off/on the meter, or perform a hard reset (press the RESET button twice),
the meter shows RST , followed by STRN.
3.1 RATING/PRODUCT LABEL
This label is located on top of the meter housing (refer to Figure 3-4).
3.2 MAIN BOARD POWER JUMPERS (refer to Figure 3-1)
Note ☞
Important: If you want to change the Factory preset jumpers, do the
following steps; otherwise go to Section 3.3.
Warning: Disconnect the power from the unit before proceeding. This
device must only be reconfigured by a specially trained electrician with
corresponding qualifications. Failure to follow all instructions and warnings
may result in injury!
1.
Remove the main board from the case. Refer to Section 2.6.
2.
Locate the solder jumpers W1, W2, and W3 (located near the edge of the main
board alongside the transformer).
3.
If your power requirement is 115 Vac, solder jumpers W1 and W3 should be
wired, but jumper W2 should not. If your power requirement is 230 Vac,
solder jumper W2 should be wired, but jumpers W1 and W3 should not.
Note: W4 jumper is not used.
Figure 3-1 shows the location of solder jumpers W1 through W3.
T1A
W2
W1
DISPLAY BOARD
W3
Figure 3.1 Main Board Power Jumpers
11
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3
Getting Started
3.2 MAIN BOARD POWER JUMPERS (Continued)
Figure 3-2 shows the location jumper positions on the main board.
DIS
PL
AY
BO
AR
D
T1
S3
MAIN BOARD
TP1
TP2
TP3
TP4
TP5
TP6
TP7
TP8
TP9
TP10
S4
{
S2
{
TB1
TB2
S1
J1
A B
E D CB A
S3
Refer to
table 3-1
S2
C D
TP11
Figure 3-2. Main Board Jumper Positions
Attach cable
to P1.
TB5
P1
Figure 3-3. Upper Isolated Analog Output Option Board Installation
12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Getting Started
3
3.2 MAIN BOARD POWER JUMPERS (Continued)
S2 jumpers are used for testing purposes. Do not use as reading errors may result.
S3 jumpers are used for the following (refer to Figure 3-2):
*
*
*
*
To enable or disable the front panel push-buttons
To allow for an extremely low resistance load for analog output
To disable the MENU button
To perform factory calibration procedure
Test pins TP1 - TP11 are for testing purposes. Do not use as reading errors may result.
S4-A Factory default jumper is removed.
Table 3-1. S3 Jumper Functions
Jumper
S3-A
S3-B
S3-C
S3-D
S3-E
Description
Install to enable front panel push-buttons.
Remove to disable all front panel push-buttons.
Removed. For factory calibration only.
Removed. Not used.
Installed for external ratiometric.
If installed without S3-B, the MENU button locks out.
If you press the MENU button, the meter shows LOCK .
13
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3
Getting Started
3.3 PANEL MOUNTING
RE
A
(R R C
EM OV
OV ER
ED
CONNECTOR
)
PANEL
CUT-OUT
"NEW" STYLE
MOUNTING
BRACKET
LABEL
PRODUCT
LABEL
CASE
GASKET
"OLDER" STYLE
MOUNTING
BRACKET 2 PCS
FRONT BEZEL
Figure 3-4. Meter - Exploded View
PANEL THICKNESS
1. Cut a hole in your panel, as
shown in Figure 3-4. For
specific dimensions refer to
Figure 3-5.
2. Insert the meter into the hole.
Be sure the front bezel gasket
is flush to the panel.
3. Slide on mounting bracket to
secure.
4. Proceed to Section 3.4 to
connect your sensor input and
main power.
6,4 (.25) MAX
0,8 (.03) MIN
1,5
R(.06)
4 PLCS
45,00 + 0,61/-0,00
(1.772 + .024/–.000)
92,00 + 0,81/–0,00
(3.622 + .032/–.000)
NOTE: Dimensions in Millimeters (Inches)
Figure Figure 3-5. Panel Cut-Out
14
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Getting Started
3
3.4 CONNECTING SENSOR INPUTS
Figures 3-6 shows excitation supplied from the meter’s internal supply
(50 mA maximum) Select 5, 10, or 12 volt excitation at DIP switch.
-E
1
+E +20mA +R
2
3
4
+24
5
+S
6
-S
7
-R
8
TB2
Connections with “typical wire colors”
+E = Positive Excitation (red)
-E = Negative Excitation (black)
+S = Positive Signal Input (green)
-S = Negative Signal Input (white)
+
-
Figure 3-6. Meter-powered Bridge Input
Figures 3-7 shows the connections required for an externally-powered bridge input: the
external supply is brought to the meter’s buffer circuits to permit ratiometric readings.
Set S1 DIP switch for external excitation for Figure 3-7 and 3-8.
-E
+E +20mA +R
1
2
3
+24 +S
5
6
4
-S
-R
7
8
TB2
Connections with “typical wire colors”
+E = Positive Excitation (red)
+EX
-E = Negative Excitation (black)
+S = Positive Signal Input (green)
+
-S = Negative Signal Input (white)
-
-EX
Figure 3-7. Externally-powered Bridge Input
15
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3
Getting Started
3.4 CONNECTING SENSOR INPUTS (Continued)
Figure 3-8. 4-Wire DC Input Connections with External Excitation
Figure 3-9. Current Input Connections with Internal Excitation
16
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Getting Started
3
3.4 CONNECTING SENSOR INPUTS (Continued)
Figure 3-10. Current Input Connections with External Excitation
3.5 CONNECTING MAIN POWER
Connect the AC main power connections as shown in Figure 3-11.
WARNING: Do not connect AC power to your device until you have
completed all input and output connections. This device must only be
installed by a specially trained electrician with corresponding qualifications.
Failure to follow all instructions and warnings may result in injury!
Figure 3-11. Main Power Connections - AC
17
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3
Getting Started
3.5 CONNECTING MAIN POWER (Continued)
Table 3-2 shows the wire color and respective terminal connections for both USA and
Europe.
Table 3-2. AC-Power Connections
TB1
7
8
9
AC POWER
WIRE COLORS
EUROPE
USA
~ AC Line
~ AC Neutral
~ AC Earth
Brown
Blue
Green/Yellow
Black
White
Green
Connect the DC main power connections as shown in Figure 3-12.
TB1
TB2
1 2 3 4 5 6 1 2 3 4
7 8 9 10 11 12 5 6 7 8
+ DC
- DC
DC POWER
When using DC power, refer to the Table 8-1 Color Chart in the Specifications
Section for Display Color, Intensity, Excitation Voltage and Current, and Analog
Output Isolated Option. Failure to use proper ratings may result in damaging
the unit.
Figure 3-12. Main Power Connections - DC
18
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Getting Started
3
3.6 CONNECTING EXTERNAL TARE SWITCH
Connect external tare connections as shown in Figure 3-13.
TB1
TB2
1 2 3 4 5 6 1 2 3 4
S1
OPEN
7 8 9 10 11 12 5 6 7 8
J1
1 2
CLOSED
3 4
EXTERNAL TARE SWITCH
Figure 3-13. External Tare Connections
3.7 CONNECTING ANALOG AND RELAY OUTPUTS
If you have purchased a meter with analog or dual relay or isolated analog output, refer
to the following drawings for output connections.
TB1
TB2
1 2 3 4 5 6 1 2 3 4
7 8 9 10 11 12 5 6 7 8
+
ANALOG
VOLTAGE
0-10V dc
-
+
-
ANALOG
CURRENT
0-20mA
or
4-20mA
ANALOG
RTN
Figure 3-14. Analog Output Connections
19
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
3
Getting Started
3.7 CONNECTING ANALOG AND RELAY OUTPUTS (Continued)
Relay 2
COM2
N.C.2
N.O.2
COM1
N.C.1
N.O.1
}
}
Relay 1
NO2
EXTERNAL LOAD
COM2
TB1
N
L
FUSE
TB2
1 2 3 4 5 6 1 2 3 4
7 8 9 10 11 12 5 6 7 8
Figure 3-15. Relay Output Connections.
0—10VDC
0—20mA
OR
4—20mA
1 2 3
TB1
TB2
TB5
1 2 3 4 5 6 1 2 3 4
7 8 9 10 11 12 5 6 7 8
Figure 3-16. Isolated Analog Output Connections.
20
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
SECTION 4. CONFIGURING THE METER
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
For first-time users: Refer to the QuickStart Manual for basic operation and
set-up instructions.
4.1 SELECTING THE INPUT TYPE INPT
To select your appropriate input type signal, follow these steps:
Note ☞
Before proceeding, set the input DIP switch settings at the back of your
meter. (Refer to Table 2-3).
1.
Press the MENU button. The meter shows INPT .
2.
Press the ∂TARE button. The meter flashes one of the following:
•
100M (for 0-100 mV dc) (Default)
•
±50M (for ±50 mV dc)
•
10V (for 0-10 Vdc)
•
±5V (for ±5 Vdc)
•
0-20 (for 0-20 mA dc)
3.
Press the ßNT/GRS button to scroll through available choices.
4.
Press the MENU button to store your choice. The meter momentarily shows
STRD , followed by DEC.P (Decimal Point).
21
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.2 SELECTING A DECIMAL POINT POSITION DEC.P
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
To select a decimal point display position, follow these steps:
1.
Press the MENU button until the meter shows DEC.P .
2.
Press the ∂TARE button. The meter shows one of the following:
•
FFF.F
•
FF.FF
•
F.FFF
FFFF (Default)
•
3.
Press the ßNT/GRS button to scroll between available choices.
4.
Press the MENU button to store your choice. The meter momentarily shows STRD ,
followed by the next menu RD.S.O (Reading Scale and Offset). Or you can press
the RESET button to abort and go back to the DEC.P menu.
4.3 SELECTING READING SCALE AND OFFSET RD.S.0
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
To scale the meter to show readings in engineering units. There are two methods. One
method is to scale with known inputs. Another method is to scale without known inputs:
you calculate input values based on the transducer specifications and manually enter
them through the keyboard.
22
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.3.1 Scaling with Known Loads (On-Line Calibration)
Note ☞
For maximum resolution, find the maximum signal that will be applied to the
meter input.
• For regular voltage input, refer to the main body of Table 4-1.
• For millivolt or milliamp input, refer to the main body of Table 4-2.
Set the DIP switch positions as indicated at the top of either Table 4-1 or 4-2. The
numbers 1 through 8 in the top row of either table represent dip switches 1 through 8,
and the O, C or X directly below the number indicates the correct position of each switch.
•
‘O' Switch should be open or up.
•
‘C' Switch should be closed or down.
•
‘X' Switch is used to control excitation (refer to Table 2-3 to determine
correct position of these switches).
Once Dip switches have been positioned correctly, apply power. Proceed to the RD.CF
(Reading Configuration) and set R2 equal to the value in the right hand column of the
chart.
Table 4-1. Range Selection Dip Switch Positions For Regular Voltage Input
12345678
XCOOOXXC
0 - 10 V
0-5V
0-3V
0-2V
0-1V
12345678
XCOOCXXC
±5 V
±5 V
±3 V
±2 V
±1 V
RD.CF*
R.2=
4
3
2
1
0
Table 4-2. Range Selection Dip Switch Positions For Millivolt/ Milliamp Input
12345678
12345678
12345678
RD.CF*
Table 4-1. Range
Selection DipXOCOCXX0
Switch Positions
For Regular Voltage
Input
XOCOOXX0
XOCCOXX0
R.2=
0 - 100 mV
±50 mV
0 - 20 mA
4
0 - 50 mV
±50 mV
0 - 10 mA
3
0 - 30 mV
±30 mV
0 - 6 mA
2
Table
4-2.
Range
Selection
Dip
Switch
Positions
0 - 20 mV
±20 mV
0 - 4 mA
1
For Millivolt
and Milliamp
Input
0
10
mV
±10
mV
0
2
mA
0
p
* Reading Configuration
23
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.3.1 Scaling with Known Loads (On-Line Calibration) (Continued)
To scale with known inputs: apply known loads to a transducer connected to a meter, or
simulate the transducer output with a voltage or current simulator. To scale with known
inputs, follow these steps:
1.
Apply a known load equal to approximately 0% of the transducer range.
2.
Press the MENU button until the meter shows RD.S.O .
3.
Press the ∂TARE button. The meter shows IN1 (Input 1).
Note ☞
IN1 (Input 1) is the unscaled display reading at minimum input.
4.
Press the ∂TARE button again. The meter shows last stored value for Input 1.
5.
Press the ∂TARE button once more. The meter shows the actual signal being
received.
6.
Press the MENU button to store this value as IN1 (Input 1). The meter shows
RD1 (Read 1).
Note ☞
RD1 (Read 1) is the desired display reading at Input 1.
7.
Press the ∂TARE button. The meter shows the last stored value for Read 1.
8.
Press the ßNT/GRS button to change the value of your digits.
9.
Press the ∂TARE button to scroll horizontally to the next digit.
10.
Press the MENU button to store value as RD1 . The meter shows IN!2 (Input 2).
Note ☞
IN!2 (Input 2) is the unscaled display reading at maximum input.
24
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.3.1 Scaling with Known Loads (On-Line Calibration) (Continued)
11.
Apply a known load equal to approximately 100% of the transducer range.
12.
Press the ∂TARE button again. The meter shows the last stored value for Input 2.
13.
Press the ∂TARE button once more. The meter shows the actual signal being
received.
14.
Press the MENU button to store Input 2 value. The meter shows RD!2 (Read 2).
Note ☞
RD!2 (Read 2) is the desired display reading at input 2.
15.
Press the ∂TARE button. The meter shows the last stored value for Read 2.
16.
Press the ßNT/GRS button to change the value of your digits.
17.
Press the ∂TARE button to scroll horizontally to the next digit.
18.
Press the MENU button to store value as RD!2 (Read 2). The meter momentarily
shows STRD , followed by RD.CF . Meter scaling is now complete.
25
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.3.2 Scaling Without Known Loads
To scale without known inputs, calculate input values based on the transducer
specifications and manually enter them on the front-panel push buttons. The following
example assumes load cells with these specifications:
Maximum Load:
Output:
Sensor Excitation:
Output:
1.
100.0 lbs
3.1 mV/V
10 Vdc
31mV = (3.1 mV/V) x (10 V)
Determine the correct values for IN1 and IN!2 based on the load cell specifications.
In most cases, RD1 and RD!2 are equal to the minimum and maximum of the
transducer output span. The example assumes RD1 and RD!2 are equal to the
range of the load (RD1 = 0 and RD!2 = 100.0). Calculate IN1 and IN!2 using the
loadcell output span and the following equation:
IN = (Sensor Output) x (Natural Gain) x (Multiplier).
Table 4-3. Natural Gain
Input Range
0 to 100 mV
±50 mV
0 to 10 V
±5V
0 to 20 mA
2.
Span Units
Millivolts
Millivolts
Volts
Volts
Milliamps
Natural Gain
100 cts/mV
40 cts/mV
1000 cts/V
400 cts/V
500 cts/mA
Determine the multiplier by the Input Resolution setting (R.2 in the RD.CF menu)
and the input range selected. Typically R.2=4 is suitable for most applications.
Table 4-4. Input Resolution Multiplier
Input Range
0 to 100 mV
0 to 10 V
0 to 20 mA
± 50 mV
±5V
R.2=4
1.000
1.000
1.000
1.000
1.000
R.2=3
2.000
2.000
2.000
1.000
1.000
R.2=2
3.333
3.333
3.333
1.667
1.667
R.2=1
5.000
5.000
5.000
2.500
2.500
R.2=0
10.00
10.00
10.00
5.000
5.000
26
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
3.
4
Determine IN1 and IN!2 input range and resolution. The example selects the
0 to 100 mV range and 10 uV resolution (R.2=4 ).
Example: IN1 = (0 mV) x (100 cts/mV) x (1.000) = 0
IN!2 = (31 mV) x (100 cts/mV) x (1.000) = 3100
RD1 = 0000
RD!2 = 100.0
4.
Press MENU button until the meter shows RD.S.O .
5.
Press the ∂TARE button. The meter shows IN1 .
6.
Press the ∂TARE button again, the meter shows the last Input 1 value, with the
fourth digit flashing.
7.
Press the ßNT/GRS button to change the value of your digits.
8.
Press the ∂TARE button to scroll horizontally to the next digit.
9.
Press the MENU button to store this value. The meter shows RD1 .
10.
Press the ∂TARE button. The meter shows the last value for Read 1.
Repeat steps 7, 8 and 9 until RD1 , IN!2 and RD!2 have been displayed, verified,
changed (if necessary) and stored.
4.4 USING READING CONFIGURATION RD.CF
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
You may use Reading Configuration RD.CF to configure your meter for the following:
•
To select ratiometric or non-ratiometric operation
•
To set the input resolution of your meter
•
To display the filtered/unfiltered signal input value
•
To select gross/net vs. peak reading
27
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.4.1 Selecting Ratiometric/Non-Ratiometric Operation
1.
Press the MENU button until RD.CF displays.
2.
Press the ∂TARE button. The meter shows one of the following:
•
R.1=R (Ratiometric reading) (Default - for strain meters)
•
R.1=N (Non-ratiometric reading - typically for voltage & current transducers)
3.
Press the ßNT/GRS button to view last stored selection. Press the ßNT/GRS
button to toggle between selections.
4.
Press the ∂TARE button to select input resolution or press the MENU button to
store your selection and shows COLR menu.
4.4.2 Setting Input Resolution
To set the input resolution of your meter, follow these steps:
1.
Press the MENU button until RD.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from R.1 .
One of the following displays (default is R.2=4 ):
R.2=4 =
R.2=0 =
R.2=1 =
R.2=2 =
R.2=3 =
10 µV for Unipolar inputs. 25 µV for Bipolar inputs
1 µV for Unipolar inputs. 5 µV for Bipolar inputs.
2 µV for Unipolar inputs. 10 µV for Bipolar inputs
3 µV for Unipolar inputs. 15 µV for Bipolar inputs.
5 µV for Unipolar inputs. 25 µV for Bipolar inputs
Example: 3 µV resolution means that if you input 0-30 mV, at 30 mV the display shows
9999 .
2.
Press the ßNT/GRS button to scroll through available selections.
3.
Press the ∂TARE button to display the filtered/unfiltered signal input or press the
MENU button to store your selection and shows COLR menu.
28
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.4.3 Displaying the Filtered/Unfiltered Input Signal
To display the filtered/unfiltered signal input, follow these steps:
1.
Press the MENU button until RD.CF displays, then press the ∂TARE button three
times.
or
Press the ∂TARE button from R.2 .
One of the following displays:
•
•
R.3=F (Filtered value) (Default)
R.3=U (Unfiltered value)
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selections. STRD momentarily displays,
followed by COLR Menu.
4.4.4 Selecting Gross/Net or Peak Display
To select gross/net or peak display:
1.
Press the MENU button until RD.CF displays, then press the ∂TARE button three
times.
or
Press the ∂TARE button from R.3.
One of the following displays:
•
R.4=G Gross/Net Display (Default)
•
R.4=P Peak Display
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selections. STRD momentarily displays,
followed by COLR Menu.
29
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.5 SELECTING A DISPLAY COLOR COLR
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Selecting Display Color is not active unless your meter is a Version “B”.
To select a display color, follow these steps:
1.
Press the MENU button until the meter shows COLR.
2.
Press the ∂TARE button. The meter shows one of the following:
•
GRN
•
RED
•
AMBR
3.
Press the ßNT/GRS button to scroll between available choices.
4.
Press the MENU button to store your choice. The meter momentarily shows
STRD , followed by the next menu S1.CF (Setpoint 1 Configuration). Or you can
press the RESET button to abort and go back to the RD.CF menu.
4.6 USING SETPOINT 1 CONFIGURATION S1.CF
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 1 Configuration S1.CF is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S1.CF is active or not. You may use
Setpoint 1 Configuration S1.CF for the following:
•
To set the setpoint's active band above or below your chosen value
•
To select whether the setpoint operation is latched or unlatched
•
Assigning setpoint values to the net or gross reading
30
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.6.1 Setting Setpoint 1's Active Band
1.
Press the MENU button until the meter shows S1.CF .
2.
Press the ∂TARE button. The meter shows one of the following:
•
S.1=A (Active above the setpoint) (Default)
•
S.1=B (Active below the setpoint)
3.
Press the ßNT/GRS button to toggle between available choices.
4.
Press the ∂TARE button to select if Setpoint 1 is latched/unlatched or press the
MENU button to store your selection. The unit shows S2.CF.
4.6.2 Selecting if Setpoint 1 is Latched or Unlatched
1.
Press the MENU button until S1.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from S.1 .
The meter shows one of the following:
•
S.2=U Setpoint 1 to be unlatched (Default)
•
S.2=L Setpoint 1 to be latched
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the ∂TARE button to assign Setpoint 1 values to net or gross reading or
press the MENU button to enter S2.CF (Setpoint 2 Configuration).
31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.6.3 Assigning Setpoint 1 Values to Net or Gross Readings
1.
Press the MENU button until S1.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from S.2.
The meter shows one of the following:
•
S.3=N Setpoint 1 assigned to net reading (Default)
•
S.3=G Setpoint 1 assigned to gross reading
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selection(s). The meter momentarily shows
STRD, followed by S2.CF (Setpoint 2 Configuration).
4.7 USING SETPOINT 2 CONFIGURATION S2.CF
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 2 Configuration S2.CF is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S2.CF is active or not. You may use
Setpoint 2 Configuration S2.CF for the following:
• To set the setpoint's active band above or below your chosen value
• To select whether the setpoint operation is latched or unlatched
• To assign setpoint values to the net or gross reading
4.7.1 Setting Setpoint 2's Active Band
1.
2.
Press the MENU button until the meter shows S2.CF.
or
Press the ∂TARE button. The meter shows one of the following:
•
S.1=A (Active above the setpoint) (Default)
•
S.1=B (Active below the setpoint)
3.
Press the ßNT/GRS button to toggle between available choices.
4.
Press the ∂TARE button to select if Setpoint 2 is latched/unlatched or press the
MENU button to store your selection. The meter shows S1.DB.
32
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.7.2 Selecting if Setpoint 2 is Latched or Unlatched
1.
Press the MENU button until S2.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from S.1.
The meter shows one of the following:
•
S.2=U Setpoint 2 to be unlatched (Default)
•
S.2=L Setpoint 2 to be latched
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selection(s). The meter momentarily shows
STRD , followed by S1.DB (Setpoint 1 Deadband).
4.7.3 Assigning Setpoint 2 Values to Net or Gross Readings
1.
Press the MENU button until S2.CF displays, then press the ∂TARE button twice.
or
Press the ∂TARE button from S.2.
The meter shows one of the following:
•
S.3=N Setpoint 2 assigned to net reading (Default)
•
S.3=G Setpoint 2 assigned to gross reading
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selection(s). The meter momentarily shows
STRD, followed by S1.DB (Setpoint 1 Deadband).
33
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.8 SETTING THE SETPOINT 1 DEADBAND S1.DB
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 1 Deadband S1.DB is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S1.DB is active or not. The Setpoint 1
Default deadband is 0003. To change the deadband (hysteresis) of Setpoint 1, follow
these steps:
1.
Press the MENU button until the meter shows S1.DB .
2.
Press the ∂TARE button. The meter shows the last previously stored 4-digit
number (0000 through 9999) with flashing 4th digit.
3.
Press the ßNT/GRS button to change the value of the flashing digit. If you
continue to press the ßNT/GRS button, the flashing digit's value continues to
change.
4.
Press the ∂TARE button to scroll to the next digit.
5.
Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by S2.DB (Setpoint 2 Deadband).
34
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.9 SETTING THE SETPOINT 2 DEADBAND S2.DB
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Setpoint 2 Deadband S2.DB is not active unless your meter has dual relay output
capabilities. The LED's will display whether the S2.DB is active or not. The Setpoint 2
default deadband is 0003. To change the deadband (hysteresis) of Setpoint 2, follow
these steps:
1.
Press the MENU button until the meter shows S2.DB .
2.
Press the ∂TARE button. The meter shows the last previously stored 4-digit
number (0000 through 9999) with flashing 4th digit.
3.
Press the ßNT/GRS button to change the value of the flashing digit. If you
continue to press the ßNT/GRS button, the flashing digit's value continues to
change.
4.
Press the ∂TARE button to scroll to the next digit.
5.
Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by OT.CF (Output Configuration) if you have analog output
capabilities.
35
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
SETPOINT
SIGNAL
LEVEL
ON
OFF
ON
ON
OFF
ACTIVE BELOW
OFF
ACTIVE ABOVE
3
DEADBAND
SETPOINT
3
SIGNAL
LEVEL
ON
OFF
ON
OFF
ON
OFF
ON
ACTIVE BELOW
WITH DEADBAND 3
ACTIVE ABOVE
WITH DEADBAND 3
NOTE: DEADBAND WORKS AS HYSTERISIS
SETPOINT
SIGNAL
LEVEL
ON
ON
ON
ACTIVE BELOW LATCHED
OFF
ON
ON
ACTIVE ABOVE LATCHED
Figure 4-1. Alarm Example
Note ☞
To reset latched alarms you must:
1. Input a signal OUT of the alarm zone
2. Then press SETPTS and then, RESET button
36
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.10 USING OUTPUT CONFIGURATION OT.CF
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Output Configuration OT.CF is not active unless your meter has analog output
capabilities. The menu will display whether analog output is present or not. Analog
output must be ordered at the time of purchase.
Use Output Configuration OT.CF to select the following:
•
To enable or disable the analog output
•
To select if the analog output is current or voltage
•
To assign te output to the net or gross reading
4.10.1 Enabling or Disabling the Analog Output
To enable or disable the analog output, follow these steps:
1.
Press the MENU button until the meter shows OT.CF .
2.
Press the ∂TARE button. The meter shows one of the following:
•
O.1=E (Analog output enabled) (Default)
•
O.1=D (Analog output disabled)
3.
Press the ßNT/GRS button to toggle between available choices.
4.
Press the ∂TARE button to select analog output as current or voltage or press the
MENU button to store your selection and enter OT.S.O (Output Scale and Offset).
37
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.10.2 Selecting Analog Output as Current or Voltage
1.
Press the MENU button until it shows OT.CF , then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.1.
The meter shows one of the following:
•
O.2=C (Analog output = current) (Default)
•
O.2=V (Analog output = voltage)
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the ∂TARE button to select analog output or proportional control or press the
MENU button to store your selection and enter OT.S.O (Output Scale and Offset).
4.10.3 Selecting Analog Output or Proportional Control
1.
Press the MENU button until it shows OT.CF , then press the ∂TARE button twice.
or
Press the ∂TARE button from 0.2.
The meter shows one of the following:
•
O.3=N (Net Reading) (Default)
•
O.3=G (Gross Reading)
2.
Press the ßNT/GRS button to toggle between available choices.
3.
Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by OT.S.O (Output Scale and Offset).
38
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.11 USING OUTPUT SCALE AND OFFSET OT.S.O
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Output Scale and Offset OT.S.O is not active unless your meter has analog output
capabilities. The menu will display whether analog output is present or not. Output Scale
and Offset OT.S.O scales your analog output to be equal to the meter's display and/or
any engineering units you require. You may scale the output for direct (4-20 mA, 0-10 V,
etc) or reverse acting (20-4 mA, 10-0 V, etc).
1.
Press the MENU button until OT.S.O displays.
2.
Press the ∂TARE button. RD1 (Read 1) displays.
Note ☞
This is your first point of display reading.
3.
Press the ∂TARE button again. The meter shows the last previously stored
4-digit number (-1999 through 9999) with flashing 4th digit.
4.
Press the ßNT/GRS button to change the digits.
5.
Press the ∂TARE button to scroll to the next digit.
6.
Press the MENU button to store your selection. OUT.1 (Output 1) displays.
Note ☞
7.
This starting analog signal corresponds to your Read 1 display.
Press the ∂TARE button. Selected output displays.
Note ☞
If you select O.2=V for voltage, the maximum signal you may select is
10.00 for an 0-10 Vdc signal output. If you select O.2=C for current, the
maximum signal you may select is 20.00.
8.
Press the ßNT/GRS button to enter the Output 1 signal selection. If you continue
to press the ßNT/GRS button, the flashing digit's value continues to change.
9.
Press the ∂TARE button to scroll to the next digit.
10.
Press the MENU button to store your selection. RD!2 (Read 2) displays.
Note ☞
This is your second point of display reading.
39
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.11 USING OUTPUT SCALE AND OFFSET OT.S.O (Continued)
11.
Press the ∂TARE button. The meter shows last previously stored 4-digit number
(-1999 through 9999) displays with flashing 4th digit.
12.
Press the ßNT/GRS button to change the value of the flashing digit. If you continue
to press the ßNT/GRS button, the flashing digit's value continues to change.
13.
Press the ∂TARE button to scroll to the next digit.
14.
Press the MENU button to store your selection. The meter shows OUT.2 (Output 2).
Note ☞
15.
This analog signal should correspond to your Read 2 display.
Press the ∂TARE button. The meter shows selected output.
Note ☞
If you select O.2=V for voltage, the maximum signal you may select is 10.00
for an 0-10 Vdc signal output. If you select O.2=C for current, the maximum
signal you may select is 20.00 for a 0-20 or 4-20 mA DC signal output.
16.
Press the ßNT/GRS button to change the value of the flashing digit. If you
continue to press the ßNT/GRS button, the flashing digit's value continues to
change.
17.
Press the ∂TARE button to scroll to the next digit.
18.
Press the MENU button to store your selection. The meter momentarily shows
STRD , followed by LK.CF (Lockout Configuration).
WARNING: If the meter displays all flashing values on any item, the value
has overflowed. Press the ßNT/GRS button to start new values.
40
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.11.1 Examples for Output Scale and Offset
Example: You want to send 4-20 mA output for 0 to 100.0. The meter has 0.1 degree
resolution. Complete the following steps:
1. Press the MENU button until the meter shows OT.S.O.
2. Press the ∂TARE button. The meter shows RD.1 (Read 1).
3. Press the ∂TARE button to show the existing value.
4. Change the value of Read 1 to 000.0 by pressing the ßNT/GRS and ∂TARE
buttons.
5. Press the MENU button to store your selection. The meter shows OUT.1
(Output 1).
6. Press the ∂TARE button to show the existing value.
7. Change the value of Output 1 to 04.00 by pressing the ßNT/GRS and ∂TARE
buttons.
8. Press the MENU button to store your selection. The meter shows RD.2 (Read 2).
9. Press the ∂TARE button to show the existing value.
10. Change the value of Read 2 to 100.0 by pressing the ßNT/GRS and ∂TARE
buttons.
11. Press the MENU button to store your selection. The meter shows OUT.2
(Output 2).
12. Press the ∂TARE button to show the existing value.
13. Change the value of Output 2 to 20.0 by pressing the ßNT/GRS and ∂TARE
buttons.
14. Press the MENU button to store your selection. The meter shows LK.CF
(Lock Out Configuration).
41
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4
Configuring The Meter
4.12 USING LOCK OUT CONFIGURATION LK.CF
Note ☞
Refer to Table 6-1 for a summary list of menu configuration.
Use Lock Out Configuration LK.CF for the following:
•
To enable or disable setpoint changes
•
To enable or disable the RESET button in the Run Mode
•
To enable or diable displaying meter firmware version
4.12.1 Enabling or Disabling the RESET button in the Run Mode
1.
2.
Press the MENU button until the meter shows LK.CF (after OT.S.O ).
Press the ∂TARE button. The meter shows one of the following:
• RS.=E To enable the RESET button in the Run Mode (Default)
•
RS.=D To disable the RESET button in the Run Mode
4.
Press the ßNT/GRS button to toggle between available choices.
5.
Press the MENU button to store the changes. The meter shows STRD if the new
value is different otherwise the meter shows BRIT and returns to the Run Mode.
4.12.2 Enabling or Disabling SETPOINT Changes
1.
Press the MENU button until the meter shows LK.CF (after OT.S.O ).
2.
Press the ∂TARE button twice. The meter shows one of the following:
•
SP.=E To enable setpoint changes (Default)
•
SP.=D To disable setpoint changes
3.
Press the ßNT/GRS button to toggle between available choices.
4.
Press the MENU button to store the changes. The meter shows STRD if the new
value is different otherwise the meter shows BRIT and returns to the Run Mode.
42
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Configuring The Meter
4
4.12.3 SETPOINT Display Function: Firmware version or Setpoint value
1.
Press the MENU button until the meter shows LK.CF (after OT.S.O ).
2.
Press the ∂TARE button three times. The meter shows one of the following:
• L.3=0 SETPTS button will display setpoint values.
• L.3=1 SETPTS button will display the meter's firmware version.
3.
Press the ßNT/GRS button to toggle between the choices above.
4.
Press the MENU button to store the changes. The meter shows STRD if the new
value is different otherwise the meter shows BRIT and returns to the Run Mode.
Note ☞
If your meter does not have the relay option, setpoint menu items above will
not be available and SETPTS button will always display the meter's firmware
version. These units will have +OL (overload) or +OPN memory indicated by
Alarm 1 & 2 LED displays. LEDs can be reset by pressing MENU then RESET
button or by Power OFF then ON.
4.13 USING DISPLAY BRIGHTNESS CONFIGURATION
4.13.1 Changing Brightness Level
Changing Display Brightness is not active unless your meter is a Version “B”.
1.
Press the MENU button until the meter shows BRIT (after LKCF ).
2.
Press the ∂TARE button from BRIT. The meter shows one of the following:
•
M.BrT Medium Brightness
•
L.BrT Low Brightness
•
H.BrT High Brightness (Default)
3.
Press the ßNT/GRS button to toggle between available choices.
4.
Press the MENU button to store your selection. The meter momentarily shows
STRD followed by STRD, RST, STRN, then measured value.
43
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
5
Display Messages
Table 5-1. Display Messages
MESSAGE
STRN
RST
INPT
DEC.P
RD.S.O
RD.CF
COLR
S1.CF
S2.CF
S1.DB
S2.DB
OT.CF
OT.S.O
LK.CF
BRIT
+OL
-OL
RS.OF
+999
I999
NT.OF
GT.OF
ER1
PEAK
PK.RS
T.RS
SP.RS
NET
GROS
SP1
SP2
R.OV.S
V.-8.8
RUN
DESCRIPTION
Strain Meter
Hard (power on) Reset
Input Type
Decimal Point Position
Reading Scale and Offset
Reading Configuration
Display Color
Setpoint 1 Configuration
Setpoint 2 Configuration
Setpoint 1 Deadband
Setpoint 2 Deadband
Output Configuration
Output Scale and Offset
Lock Out Configuration
Display Brightness
+ Overload Signal
- Overload Signal
Resolution Overflow
Value Overflow in Setpoint/Menu Routines
Value Overflow in Setpoint/Menu Routines
Net Value Overflow
Gross Value Overflow
2 Coordinate Format Programming Error
Peak Value
Peak Reset
Tare Reset
Setpoint Reset
Net Value
Gross Value
Setpoint 1 Value
Setpoint 2 Value
Resolution Over Scale
Firmware Version (where 8is 0 ~ 9)
Operating Mode
44
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Menu Configuration Displays
6
SECTION 6. MENU CONFIGURATION DISPLAYS
Not all menu items display on standard meters.
Table 6-1. Menu Configuration Displays
(Defaults in Bold and Italics)
∂TARE
MENU
100M (Default)
±50M
10V
±5V
0-20
Show current decimal
point position
FFFF (Default)
F.FFF
FF.FF
FFF.F
INPT
DEC.P
(Reading Scale & Offset)
RD.S.O
1
ßNT/GRS
Show input choices:
Shows IN1
Shows prior value entered and flashing digit.
Scrolls to the next digit.
• If ∂TARE is pressed, actual input
Changes the value
of the flashing digit
is shown and can not be changed
with ßNT/GRS.
• If ßNT/GRS is pressed, unit can
scroll through digits with ∂TARE.
2
Enter new value and
show RD1
3
Shows prior value entered and flashing digit.
Scrolls to the next digit.
Changes the value
of the flashing digit
4
Enter new value and
show IN2
5
Shows prior value entered and flashing digit.
Scrolls to the next digit.
• If ∂TARE is pressed, actual input
Changes the value
of the flashing digit
is shown and can not be changed
with ßNT/GRS.
• If ßNT/GRS is pressed, unit can
scroll through digits with ∂TARE.
6
Enter new value and
show RD2
7
Shows prior value entered and flashing digit.
Scrolls to the next digit.
Changes the value
of the flashing digit
45
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
6
Menu Configuration Displays
SECTION 6. MENU CONFIGURATION DISPLAYS (Continued)
Table 6-1. Menu Configuration Displays (Continued)
(Defaults in Bold and Italics)
ßNT/GRS
MENU
∂TARE
Reading Configuration
R.1=
R.1=R (Ratiometric Reading)
R.1=N (Non-ratiometric reading)
RD.CF
R.2=
R.2=0 (1 µV resolution for unipolar
& 5 µV resolution for bipolar)
R.2=1 (2 µV resolution for unipolar
& 10 µV resolution for bipolar)
R.2=2 (3 µV resolution for unipolar
& 15 µV resolution for bipolar)
R.2=3 (5 µV resolution for unipolar
& 25 µV resolution for bipolar)
R.2=4 (10 µV resolution for
unipolar & 25 µV resolution
for bipolar)
Note: 3 µV resolution means if
your input is 0-30 mV, at 30 mV
the display shows 9999.
Display Color Selection
R.3=
R.3=F (Filtered value)
R.3=U (Unfiltered value)
R.4=
R.4=G (Gross/Net Display)
R.4=P (Peak Display)
Show input choices:
COLR
GRN
RED
(Green)
AMBR
(Amber)
(Red)
Setpoint 1 Configuration
S.1=
S1.CF
S.1=A (Active above)
S.1=B (Active below)
S.2=
S.2=U (Unlatched)
S.2=L (Latched)
S.3=
S.3=N (Net Reading)
S.3=G (Gross Reading)
Setpoint 2 Configuration
S.1=
S2.CF
S.1=A (Active above)
S.1=B (Active below)
S.2=
S.2=U (Unlatched)
S.2=L (Latched)
S.3=
S.3=N (Net Reading)
S.3=G (Gross Reading)
46
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Menu Configuration Displays
6
SECTION 6. MENU CONFIGURATION DISPLAYS (Continued)
Table 6-1. Menu Configuration Displays (Continued)
(Defaults in Bold and Italics)
MENU
Setpoint 1 Deadband
∂TARE
ßNT/GRS
Press to scroll to the next
digit to the right
Press to change the value of the flashing
digit
Press to scroll to the next
digit to the right
Press to change the value of the flashing
digit
S1.DB
Setpoint 2 Deadband
S2.DB
Output Configuration
OT.CF
0.1 =
0.1=E (Analog output is enabled)
0.1=D (Analog output is disabled)
0.2 =
0.2=C (Analog output is current)
0.2=V (Analog output is voltage)
0.3 =
0.3=N (Net reading)
0.3=G (Gross Reading)
Output Scale & Offset
OT.S.O
(Shown if O.3=A in Output
Configuration Menu OT.CF )
2
Enter new value and
show OUT1
RD1
1 Shows
Shows prior value entered
Changes the value of the flashing digit
and flashing digit.
Scrolls to the next digit.
prior value entered
3 Shows
and flashing digit.
Changes the value of the flashing digit
Scrolls to the next digit.
4
Enter new value and
show RD2
prior value entered
5 Shows
and flashing digit.
Changes the value of the flashing digit
Scrolls to the next digit.
6
Enter new value and
show OUT2
prior value entered
7 Shows
and flashing digit.
Changes the value of the flashing digit
Scrolls to the next digit.
47
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
6
Menu Configuration Displays
SECTION 6. MENU CONFIGURATION DISPLAYS (Continued)
Table 6-1. Menu Configuration Displays (Continued)
(Defaults in Bold and Italics)
ßNT/GRS
MENU
∂TARE
Lock Out Configuration
RS=
RS=E (Enable RESET button in the Run Mode)
RS=D (Disable RESET button in the Run Mode)
LK.CF
SP=
SP=E (Enable setpoint changes)
SP=D (Disable setpoint changes)
L3=
L3=0 (SETPTS button display setpoint values)
L3=1 (SETPTS button display firmware version V.-8.8
where 8 is 0 ~ 9)
M.BrT (Medium Brightness)
Brightness Configuration
BRIT
Shows
input
choices
L.BrT (Low Brightness)
H.BrT (High Brightness)
Table 6-2. Run Mode Displays
Display
∂TARE
NET / GROS
T.RST
SP.RS
Press to
activate.
ßNT/GRS
Displays NET
or GROSS
reading. Once
reading shows,
respective value
shows.
RESET
Description
Peak Reading
Toggle between
Net and Gross
values.
Will reset your Tare Reset
tare when
viewing this
function.
Reset Latched
Alarms
Pressing the
RESET button
resets your
latched alarms.
48
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Setpoint Configuration Displays
7
SECTION 7. SETPOINT CONFIGURATION DISPLAYS
Table 7-1. Setpoint Configuration Displays
MENU
SP1
SP2
∂TARE
ßNT/GRS
Description
SETPOINT 1
Press to scroll to
the next digit to the
right
Press to change
the value of the
flashing digit
Select from -1999
through 9999
SETPOINT 2
Press to scroll to
the next digit to the
right
Press to change
the value of the
flashing digit
Select from -1999
through 9999
49
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
8
Specifications
SECTION 8. SPECIFICATIONS
SIGNAL INPUT
Input Ranges:
0-100 mV, ± 50 mV, 0-10 V, ± 5 V, 0-20 mA, 4-20 mA
Isolation:
Dielectric strength to 2500V transient per 3mm spacing
based on EN 61010 for 260Vrms or DC working voltage
Noise Rejection:
Normal Mode Rejection (NMR) = 60 dB
Common Mode Rejection (CMR) = 120 dB
Resistance:
100 Meg ohms for 100 mV or ±50 mV input range
1 Meg ohm for 10 V or +5 V input range
5 ohms for 20 mA current input range
“Big” Display:
4-digit, three color programmable 9-segment, LED 21 mm (0.83")
( -1.9.9.9 ~ 9.9.9.9)
Symbol:
Standard Display:
4-digit, 14-segment LED, 13.8 mm (0.54”)
( -1.9.9.9. ~ 9.9.9.9.)
Symbol:
ANALOG TO DIGITAL
Technique:
Dual slope
Internal resolution:
15 bits
Read Rate:
3/sec Polarity Automatic
ACCURACY AT 25°C
Max Error Strain:
±0.03% of reading, ±1 count
Span Tempco:
50 ppm/°C
Step Response:
1 sec
Warm Up to Rated Accuracy: 30 min
Excitation Voltage:
AC power units
24 V @ 25 mA,
12 V @ 50 mA,
10 V @ 120 mA,
5 V @ 60 mA
Load Regulation:
1.1%
Line Regulation:
0.02% per Vac
DC power units
Refer to Table 8-1
Color chart for DC Output
Excitation
50
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Specifications
8
SECTION 8. SPECIFICATIONS (Continued)
ALARM OUTPUTS (if applicable)
2 Form "C" on/off relays. Configurable for latched and
unlatched by software.
Max current: 5 AMPS, resistive load
Max voltage: 250 Vac or 30 Vdc
ANALOG OUTPUT (if applicable)
Signal Type:
Current or voltage
Signal Level:
Current: 10 V max compliance at 20 mA output
Voltage: 20 mA max for 0-10 V output
Function:
May be assigned to a display range or proportional
control output with Setpoint #1 when used as a control
output.
Linearity:
0.2%
Step Response Time:
2 - 3 seconds to 99% of the final value
ISOLATED ANALOG OUTPUT (TB5, if applicable)
Same as non-isolated analog output except isolated.
Signal Type:
Current or voltage
Signal Level:
Current: 10 V max compliance at 20 mA output
Voltage: 20 mA max for 0-10 V output
Function:
May be assigned to a display range or proportional
control output with Setpoint #1 when used as a control
output.
Linearity:
0.2%
Step Response Time:
2 - 3 seconds to 99% of the final value
Isolation
130 Vrms working voltage, 1000 V/60sec Dielectric test
Note ☞
• Only one analog output is available on each unit and it must be factory
installed.
51
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
8
Specifications
SECTION 8. SPECIFICATIONS (Continued)
INPUT POWER INFORMATION
AC units
115/230 V~(AC) + 10%, 50/60 Hz
9.5 W max, power consumption (Non-Isolated Analog Out)
11.0 W max, power consumption (Isolated Analog Out)
DC units
10-32 Vdc or 26-56 Vdc, 8 W
Do not use a combination of dc power and internal
excitation
or Isolated Analog Out, unless using dc power of 20-32
Vdc.
Refer to Table 8-1 below.
External Fuse Required:
IEC 127-2/III
Power
Fuse
115 V
125 mA @ 250 (T)
230 V
63 mA @ 250 (T)
UL 248-14 (Listed Fuse)
Power
Fuse
115 V
175 mA @ 250 V Slow-Blow
230 V
80 mA @ 250 V Slow-Blow
ENVIRONMENT
Operating temperature:
0° to 50°C (32° to 122°F)
Storage temperature:
-40° to 85°C (-40° to 185° F)
Relative humidity:
90% at 40°C (non-condensing)
MECHANICAL
Panel cutout:
1/8 DIN 3.62 x 1.78" (45 x 92mm)
Weight:
1.27 lb (575 g)
Case material:
Polycarbonate, 94 V-O UL rated
Protection:
NEMA-4/Type 4 Front Bezel
52
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Specifications
8
SECTION 8. SPECIFICATIONS (Continued)
Table 8-1. COLOR CHART FOR DC POWER
COLOR
HIGH BRIGHTNESS
MEDIUM & LOW BRIGHTNESS
RED
Sensor Excitation:
24 V @ 25 mA,
12 V, 10 V, 5 V @ 35 mA Max
Analog Output:
Non-Isolated option only
GREEN
Warning:
Any combination of Sensor Excitation
and Analog Output
24 V @ 25 mA,
12 V @ 35 mA Max
10 V @ 35 mA Max
5 V @ 35 mA Max
AMBER
• Do not use Internal Excitation.
Use External Excitation.
• Do not use Isolated Analog Output.
Use Non-Isolated Analog Ouput.
Note ☞
Analog Output:
Non-Isolated options or
Isolated Analog option
HIGH/LOW Brightness and AMBER are only available on Version “B” meters.
Standard display meters are MEDIUM Brightness.
53
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
8
Specifications
SECTION 8. SPECIFICATIONS (Continued)
48,0 (1.89)
96,0 (3.78)
FRONT BEZEL
20,3 (.80)
151,4 (5.96)
RETAINER
CASE
REAR COVER
TOP VIEW
SIDE VIEW
PANEL THICKNESS
6,4 (.25) MAX
0,8 (.03) MIN
1,5
R(.06)
4 PLCS
45,00 + 0,61/-0,00
(1.772 + .024/–.000)
92,00 + 0,81/–0,00
(3.622 + .032/–.000)
NOTE: Dimensions in Millimeters (Inches)
Figure 8-1 Meter Dimensions/ Panel Cutout
54
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Factory Preset Values
9
SECTION 9. FACTORY PRESET VALUES
Table 9-1. Factory Preset Values
MENU ITEM
INPT
DEC.P
RD.S.O
RD.CF
COLR
S1.CF
S2.CF
S1.DB
S2.DB
OT.CF
OT.S.O
LK.CF
BRIT
SP1
SP2
Sensor Excitation
FACTORY PRESET VALUES
Input Type: 0-100 (0-100 mV) input
Decimal Point Position: FFFF
Reading Scale and Offset:
0-100 mV = 0-1000
Reading Configuration:
R.1=R (Ratiometric)
R.2=4 (10 µV resolution for unipolar &
25 µV resolution for bipolar)
R.3=F (Filtered value)
R.4=G (Gross/Net reading)
Normal Color Display:
RED or GRN (Note: depending how unit was ordered)
Setpoint 1 Configuration:
S.1=A (Setpoint is Active above)
S.2=U (Setpoint is Unlatched)
S.3=N (Net reading)
Setpoint 2 Configuration:
S.1=A (Setpoint is Active above)
S.2=U (Setpoint is Unlatched)
S.3=N (Net reading)
Setpoint 1 Deadband: 0003
Setpoint 2 Deadband: 0003
Output Configuration:
O.1=E (Analog output is Enabled)
O.2=C (Analog output is Current)
O.3=N (Analog output follows the Net value)
Output Scale and Offset:
0-1000 = 4-20 mA DC
Lock Out Configuration
RS=E (Enable the RESET button in the Run Mode)
SP=E (Enable setpoint changes)
L3=0 (Display setpoint values)
H.BrT (Brightness Level)
Setpoint 1 Value: 0000
Setpoint 2 Value: 0000
10 Vdc
55
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
CE APPROVALS INFORMATION
This product conforms to the EMC directive 89/336/EEC amended by
93/68/EEC, and with the European Low Voltage Directive 72/23/EEC.
Electrical Safety EN61010-1:2001
Safety requirements for electrical equipment for measurement, control and laboratory.
Double Insulation
Pollution Degree 2
Dielectric withstand Test per 1 min
• Power to Input/Output:
2300 Vac (3250 Vdc)
• Power to Input/Output:
500 Vac (720 Vdc)
(Low Voltage dc Power Option*)
• Power to Relays Output:
2300 Vac (3250 Vdc)
• Relay 1 to Relay 2:
2300 Vac (3250 Vdc)
• Isolated Analog to Inputs:
1000 Vac (1420 Vdc)
• Analog to Inputs:
No Isolation
Measurement Category I
Category I are measurements performed on circuits not directly connected to the
Mains Supply (power). Maximum Line-to-Neutral working voltage is 50 Vac/dc.
This unit should not be used in Measurement Categories II, III, IV.
Transients Overvoltage Surge (1.2 / 50uS pulse)
• Input Power:
2500 V
• Input Power:
500 V
(Low Voltage dc Power Option*)
• Isolated Analog:
500 V
• Input/Output Signals:
500 V
Note: *Units configured for external low power dc voltage, 10-32 Vdc (Basic Insulation)
EMC EN61326:1997 + and A1:1998 + A2:2001
Immunity and Emissions requirements for electrical equipment for measurement,
control and laboratory.
• EMC Emissions Table 4, Class B of EN61326
• EMC Immunity** Table 1 of EN61326
Note: **I/O signal and control lines require shielded cables and these cables
must be located on conductive cable trays or in conduits. Furthermore,
the length of these cables should not exceed 30 meters
Refer to the EMC and Safety installation considerations (Guidelines) of this manual
for additional information.
56
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
WARRANTY/DISCLAIMER
OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of
one (1) year from the date of purchase. In addition to OMEGA’s standard warranty period, OMEGA Engineering will
extend the warranty period for four (4) additional years if the warranty card enclosed with each instrument is
returned to OMEGA.
If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service Department
will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by
OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY
does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling,
improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This
WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been
damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper specification;
misapplication; misuse or other operating conditions outside of OMEGA’s control. Components which wear are not
warranted, including but not limited to contact points, fuses, and triacs.
OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither
assumes responsibility for any omissions or errors nor assumes liability for any damages that result from
the use of its products in accordance with information provided by OMEGA, either verbal or written.
OMEGA warrants only that the parts manufactured by it will be as specified and free of defects. OMEGA
MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESS OR
IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.
LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability
of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification,
strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is
based. In no event shall OMEGA be liable for consequential, incidental or special damages.
CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic
Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical
applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity,
medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth
in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and
hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in
such a manner.
RETURN REQUESTS/INQUIRIES
Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE
RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN
(AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID
PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return
package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent
breakage in transit.
FOR WARRANTY RETURNS, please have the
following information available BEFORE
contacting OMEGA:
1. Purchase Order number under which the product
was PURCHASED,
2. Model and serial number of the product under
warranty, and
3. Repair instructions and/or specific problems
relative to the product.
FOR NON-WARRANTY REPAIRS, consult OMEGA for
current repair charges. Have the following information
available BEFORE contacting OMEGA:
1. Purchase Order number to cover the COST
of the repair,
2. Model and serial number of product, and
3. Repair instructions and/or specific problems
relative to the product.
OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our
customers the latest in technology and engineering.
© Copyright 2002 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced,
translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of
OMEGA ENGINEERING, INC.
®
are trademarks of OMEGA Engineering, Inc.
, omega.com and
PATENT NOTICE: This product is covered by one or more of the following patents: U.S. Pat. No. Des. 336,895; 5,274,577;
6,243,021 / CANADA 2052599; 2052600 / ITALY 1249456; 1250938 / FRANCE BREVET No. 91 12756 / SPAIN 2039150; 2048066 /
UK PATENT No. GB2 249 837; GB2 248 954 / GERMANY DE 41 34398 C2. The “Meter Case Bezel Design” is a trademark of
NEWPORT Electronics, Inc., registered in the U.S. USED UNDER LICENSE. Other US and International Patents pending or
applied for.
TRADEMARK NOTICE:
®
®
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Where Do I Find Everything I Need for
Process Measurement and Control?
OMEGA…Of Course!
Shop on line at omega.com
TEMPERATURE
Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies
Wire: Thermocouple, RTD & Thermistor
Calibrators & Ice Point References
Recorders, Controllers & Process Monitors
Infrared Pyrometers
PRESSURE, STRAIN AND FORCE
Transducers & Strain Gauges
Load Cells & Pressure Gauges
Displacement Transducers
Instrumentation & Accessories
FLOW/LEVEL
Rotameters, Gas Mass Flowmeters & Flow Computers
Air Velocity Indicators
Turbine/Paddlewheel Systems
Totalizers & Batch Controllers
pH/CONDUCTIVITY
pH Electrodes, Testers & Accessories
Benchtop/Laboratory Meters
Controllers, Calibrators, Simulators & Pumps
Industrial pH & Conductivity Equipment
DATA ACQUISITION
Data Acquisition & Engineering Software
Communications-Based Acquisition Systems
Plug-in Cards for Apple, IBM & Compatibles
Datalogging Systems
Recorders, Printers & Plotters
HEATERS
Heating Cable
Cartridge & Strip Heaters
Immersion & Band Heaters
Flexible Heaters
Laboratory Heaters
ENVIRONMENTAL
MONITORING AND CONTROL
Metering & Control Instrumentation
Refractometers
Pumps & Tubing
Air, Soil & Water Monitors
Industrial Water & Wastewater Treatment
pH, Conductivity & Dissolved Oxygen Instruments
M3598/0906
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Artisan Technology Group is your source for quality
new and certified-used/pre-owned equipment
• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
InstraView REMOTE INSPECTION
LOOKING FOR MORE INFORMATION?
Visit us on the web at www.artisantg.com for more
information on price quotations, drivers, technical
specifications, manuals, and documentation
SM
Remotely inspect equipment before purchasing with
our interactive website at www.instraview.com
Contact us: (888) 88-SOURCE | [email protected] | www.artisantg.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
