LG AX265 User manual

LG AX265 User manual
Transferring Music
Playing Music
Bluetooth® Wireless
Technology Pairing
Sending an
Instant Message
Taking a Picture
www.LGmobilephones.com/Banter
Checking Email
Quick Start Guide
QWERTY Keyboard
15
17
14
1
2
13
3
12
4
11
5
10
6
9
7
8
1.Volume Up/Down
2. Left Soft Key (Celltop)
3. Menu/OK Key
4. Speakerphone Key
5.Talk Key
6. Camera Key
7. Voicemail Key
8. USB/Charging Port
9. microSD™ Port
10. Power/End Key
11.Clear & Back Key
12. Navigation Key
Alltel Web
Contact List
< Music/Ringers
> Alltel Apps
<<
Getting to Know Your Phone
16
13.Right Soft Key (Message/
unlocks keypad)
14. Headset Jack
15. Status Light
16. Speaker
17. Camera Lens
QWERTY Keyboard
9
8
1
7
2
6
3
5
4
1.Shift Key
Change Capitalization:
Abc (Sentence Case)
ABC (ALL UPPERCASE)
abc (all lowercase)
2.Function Key
To enter alternate
characters (press
twice to lock)
3. Symbols Key
4.Space Key
5.
6.
7.
8.
9.
Navigation Keys
OK Key
Clear & Back Key
Right Soft Key
Left Soft Key
Transferring Music
Your music is instantly available at your fingertips.
With the optional 16GB microSD card, you can easily
transfer music between your phone and PC.
1. Insert a microSD card* (gold contacts facing down)
into your phone.
2.Connect a USB data cable* between the phone
and your PC.
3. Select USB Mass Storage (2).
4.The PC will recognize the phone as a Removable
Disk, and a screen will appear. Drag and drop
music files on your PC in the My_Music folder.
microSD
Port
*microSD card and USB data cable required (sold separately).
Playing Music
No need to carry around a separate MP3 player!
The integrated music player offers you ample storage
space to keep the music playing on and on.
1.Insert a microSD card* containing music with the
gold contacts facing down.
2.With the slide closed and the phone unlocked,
press left on the Navigation Key and then press
Music (1).
3. Music is organized by playlists, recently played,
artists, genres, and albums. Press the
Key to
select All Songs (1).
4.With the song you want to hear highlighted, press
the
Key to begin playing that song.
5.Use the side Volume Keys
to adjust
the volume.
*microSD card sold separately.
Bluetooth® Wireless Technology Pairing
Bluetooth wireless technology allows you to connect
easily to headsets, speakers, computers, and more.
Work, chat, and listen to music without messy cords
and wires!
1. Set your Bluetooth accessory into pairing mode.*
2.With the slide closed and the phone unlocked,
press the
Key and then select Settings (9) >
Bluetooth (6) > Paired Devices (1).
3. Press the Left Soft Key for Search. If Bluetooth
wireless technology is off, select Yes (1) to turn
it on.
4.Select New Search (1).
5.Once your Bluetooth device has been found,
highlight it and press the
Key for Pair.
6.Enter the passcode* (typically “0000” – 4 zeroes),
and then press the
Key.
7. Select Yes (1) to connect with the device.
*Refer to your Bluetooth accessory’s user manual for
information about initiating pairing mode and the passcode.
Checking Email
Checking your email anytime during your busy
day is easy with this sleek phone. Slide out the
four-line QWERTY keyboard and quickly begin
sending and receiving email.
1.Slide out the QWERTY keyboard and select
Email (3).
2.Choose whether to accept the charges, and
then follow the steps in the wizard to set up
your email.
3. Highlight the message you want to read and
press the
Key. To compose an email,
press the Left Soft Key for New.
Sending an Instant Message
Chat instantly and efficiently on your LG
Banter using the four-line QWERTY keyboard.
Instant messaging keeps you in touch without
making a phone call.
1. Slide out the QWERTY keyboard and select
Instant Messaging (2).
2.Choose whether to accept the charges.
3. Highlight the instant messaging client you
wish to use, and then press the
Key.
4. Use the QWERTY keyboard to enter your
screen name/ID and password, and then
press the Right Soft Key for Sign In.
5. Highlight a contact that is online, and then
press the Right Soft Key for Send IM.
6. Type your message, and then press the
Right Soft Key for Send.
Taking a Picture
Don’t miss any special moments with the
LG Banter’s 1.3 megapixel camera with zoom
and many other customizable features.
1.With the slide closed and the phone unlocked,
press and hold the
Key on the left side of
your phone to access the camera viewfinder.
2. Press left or right on the Navigation Key to
adjust the brightness. Press up or down on the
Navigation Key to adjust the zoom.* Press the
Right Soft Key for Options to access other
customizable camera options.
3.Press the
Key to take the picture.
4. Press the
Key to send the photo
to someone.
*Camera setting of 960 x 1280 pixels does not support
zoom function.
Optional Accessories
Bluetooth® Stereo Speakers
Bluetooth Headset
Bluetooth Headset
(MSB-100)
(HBM-520)
(HBM-760)
Bluetooth Solar Car Kit
Stereo Headset
Carrying Case
(HFB-500)
Maximize your phone with these cutting-edge accessories at www.LGmobilephones.com/Banter.
All materials in this guide including, without limitation, the design, the text, and any marks are the property
of LG Electronics, Inc. Copyright © 2009 LG Electronics, Inc. ALL RIGHTS RESERVED. LG is a registered
trademark of LG Electronics, Inc. Features and specifications are subject to change without prior notice. The
use of non-LG approved accessories will void the warranty and may result in damage to the phone, the phone
exploding, or other dangerous conditions. Banter is a trademark of LG Electronics, Inc. microSD™ is a trademark of SanDisk. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by LG Electronics MobileComm, U.S.A., Inc. is under license. Other trademarks and
trade names are those of their respective owners. Unless otherwise specified herein, all accessories referenced
herein are sold separately.
