Quick Start Guide Getting to Know Your Phone Camera Mirror Earpiece Speaker microSD™ Port Headset Jack Mobile Web Volume Up/Down (supports up to 4GB) Right Soft Key Left Soft Key Picture & Video Get It Now OK Key Voice Command/ Memo Key Clear & Back Key Speakerphone Key* Lock Key Calendar Camera/ Video Key Charging Port Voicemail Key Music Key Vibrate Mode Key FRONT & LEFT VIEWS *Speakerphone can only be activated during a call. RIGHT VIEW REAR VIEW Using the Touch Keypad & Navigation Wheel Touch Keypad • Touch the exact key with your fingertip. • It’s not necessary to press hard. A light tap will do. Keypad Settings The touch keypad’s sensitivity level is set at medium by default and can be adjusted by going to: Menu > Settings & Tools (6) > Touch Keypad (8) > Sensor Level (1). From the touch keypad menu, you can also turn on and off the touch keypad sound and vibration. Navigation Wheel Slowly spin the navigation wheel with your finger tip to highlight menu options. When the correct menu option is highlighted, press the OK Key to select that option. You can also use the navigation wheel as a 4-way directional key to navigate the menus. Locking/Unlocking Your Phone Key Guard The touch keypad and navigation wheel are automatically locked when: • The slide is closed. • The phone is inactive for 17 sec. (default) or 25 sec. (if display backlight is set at 15 sec.). Unlocking the Touch Keypad & Navigation Wheel • Slide Closed: Slide the Lock Key (located on the right side of the phone) downwards and release. – or – Press the OK Key twice. • Slide Open: press any key (except touch keys). How to Get Music 1. Shop the Catalog Using V CAST Music Press the Music Key (located on the right side of the phone). Then tap the Left Soft Key (Shop) to download new music. Choose from over 2,000,000 songs! 2. Sync Music from Your PC to Your Phone Whether you’re purchasing music from the online V CAST Music Store or copying music from your personal library, it’s easy to sync from your PC. Connect your phone to your PC with an optional USB cable.* Press the OK Key twice, tap the Right Soft Key (Sync) to sync music from PC to phone. USB cable and Windows Media Player 10 (or higher) are required. *Refer to the Music Essentials Kit (sold separately) and Quick Reference Guide for more details. Playing Music Transform your wireless phone into a portable music player. You can listen to music in the background while doing other activities with your phone. You can even pause the music to take a call. 1. Press the Music Key (located on the right side of the phone). Scroll to desired song and press the OK Key to play. 2. Use the side Volume Keys to adjust volume when a song is playing. Tap the Right Soft Key (Options) then Sound Effect (5) to try different sound effects. 3. Press the End Key twice to exit the music player. Tip: To enter Music Only Mode while listening to music, tap the Right Soft Key (Options), then Music Only (6). Music Only Mode should be used in places where radio frequency (RF) is prohibited, such as aboard airplanes and in hospitals. Note: While playing music in the background, spin the navigation wheel to access your songs. Creating Playlists 1. Press the OK Key twice, select Playlists (2). 2. Tap the Left Soft Key (Create) to create a playlist. 3. Enter a playlist name and press the OK Key. 4. Tap the Right Soft Key (Options), and select Add Songs to Playlist (4). 5. Press the OK Key to mark all the songs you want to add to the playlist. 6. Tap the Left Soft Key (Done) when finished. Making & Answering Calls Making Calls 1. Open the slide. Press and hold the End Key for 3 seconds to turn the phone on. 2. Enter phone number and press Send. 3. Press the End Key to end the call or close the slide.* Tip: To make a call with the phone closed, tap the Right Soft Key (Contacts), select a contact, and tap the Left Soft Key (Call). Answering Calls Slide the phone open or press the OK Key twice.* *Default settings. You can change your Answer/End Call Options by going to: Menu > Settings & Tools (6) > Call Settings (7), then Answer Options (1) or End Call Options (2). Note: If the phone is ringing or vibrating, press the volume keys to quiet the phone. Bluetooth® Pairing 1. Set your Bluetooth accessory into pairing mode. 2. Press the OK Key, select Settings & Tools (6). 3. Select Bluetooth Menu (3), then Add New Device (1). 4. If Bluetooth is set to off, select Yes when prompted to turn it on. 5. Press the OK Key, and the phone will now search for the accessory. Once found, highlight it and press the OK Key to pair. 6. Enter the passcode (typically “0000” - 4 zeroes) and press the OK Key. If you don’t know the passcode, please consult the user manual of the device with which you are trying to pair. 7. Press the OK Key to connect with the device. Bluetooth accessories sold separately. Phone does not support all Bluetooth OBEX profiles. For vehicle/accessory compatibility, go to www.verizonwireless.com/bluetoothchart. Note: You can save up to 20 Bluetooth pairings Taking a Picture/Recording a Video 1. To activate camera mode: With the slide open, press the Camera/Video Key. To activate video mode: With the slide open, press and hold the Camera/Video Key for 2 seconds. 2. Press left or right on the navigation wheel to zoom. Press up or down to adjust brightness. Press the Right Soft Key (Options) to adjust camera/video options. 3. Press the OK Key or press the Camera/Video Key to take a photo or record a video. Press the OK Key or press the Camera/Video Key to stop recording. 4. Tap the Left Soft Key (Save) or press the OK Key to send. Note: To take a self-portrait, use the mirror on the back of the phone and press the Camera/Video Key. Customizable Features Changing the Display Theme 1. Press the OK Key, select Settings & Tools (6). 2. Select Display Settings (5), then Display Themes (4). 3. Select Classic, Rhythm & Blues, or Rock & Roll. Changing the Clip Board Theme Clip Board is a fun feature which can be accessed by spinning the navigation wheel in standby mode.* 1. Press the OK Key, select Settings & Tools (6). 2. Select Display Settings (5), then Clip Board (5). 3. Select Classic, Diary, Modern or turn the clipboard feature off. *Standby mode is when the phone is not performing any action and no menu is displayed. Optional Accessories Bluetooth Stereo Speakers Bluetooth Stereo Headset Portable Stereo Speakers Music Essentials Kit (4GB) Music Essentials Kit (2GB) Bluetooth Stereo Headset, USB Cable, Music CD, 4GB microSD Card Stereo Headset, USB Cable, Music CD, 2GB microSD Card Extended Li-Ion Battery (1,500 mAh) ©2007 LG Electronics, Inc. All rights reserved. All other trademarks are property of their respective owners. All phone images are simulated. The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license.
