Mini Home Theater
OWNER’S MANUAL
MODEL: LFD750
LFD750
FBS162V
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.
For service/
support Call:
Toll Free Number
1-800-243-0000
© Copyright 2007, LG Electronics U.S.A., Inc.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a confined space
such as a bookcase or similar unit.
CAUTION: Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect
it from over heating.
The openings should never be blocked by placing the
product on a bed, sofa, rug or other similar surface. This
product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or
the manufacturer's instruction have been adhered to.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
CAUTION:
This product employs a Laser System.
To ensure proper use of this product, please read this
owner’s manual carefully and retain it for future reference.
Should the unit require maintenance, contact an authorized
service center.
Use of controls, adjustments or the performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open
the enclosure. Visible laser radiation when open. DO NOT
STARE INTO BEAM.
2
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects filled with liquids, such
as vases, should be placed on the apparatus.
FCC WARNING: This equipment may generate or use
radio frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the
modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is
made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC COMPLIANCE: The responsible party for this
product’s compliance is:
Marketed and Distributed by LG Electronics U.S.A., Inc.,
1000 Sylvan Avenue, Englewood Cliffs, NJ.
Phone: 1-201-816-2000.
CAUTION concerning the Power Cord
Most devices are should be placed on a dedicated
circuit;
That is, a single outlet circuit which powers only that
electronic device and has no additional outlets or branch
circuits. Check the specification page of this owner's manual
to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose
or damaged wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric shock or fire.
Periodically examine the cord of your appliance, and if its
appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord replaced
with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse,
such as being twisted, kinked, pinched, closed in a door, or
walked upon. Pay particular attention to plugs, wall outlets,
and the point where the cord exits the appliance.
To disconnect power from the mains, pull out the mains cord
plug. When installing the product, ensure that the plug is
easily accessible.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION:
PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL. AND
THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this product will protect you if you observe the following procedures for
installation, use, and servicing.
This product does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions. - All these safety and
operating instructions should be read before the product
is operated.
2. Keep these instructions. - The safety, operating and
use instructions should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in
the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use
instructions should be followed.
5. Do not use this apparatus near water. – For example:
near a bath tub, wash bowl, kitchen sink, laundry tub, in
a wet basement; or near a swimming pool; and other
areas located near water.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
6. Clean only with dry cloth. – Unplug this product from
the wall outlet before cleaning. Do not use liquid
cleaners.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions. - Slots
and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to
protect it from over-heating. The openings should never
be blocked by placing the product on a bed, sofa, rug or
other similar surface. This product should not be placed
in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The
wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
3
Introduction
Maintenance and Service . . . . . . . . . . . . . . . . . .4
Before use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Front Panel/Back Panel . . . . . . . . . . . . . . . . . . . .6
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . .7
Installation and Setup
TV Connection . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Antenna (Aerial) Connections . . . . . . . . . . . . . .8
Auxiliary Function . . . . . . . . . . . . . . . . . . . . . . . .9
Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . .9
To Adjust ECHO Volume . . . . . . . . . . . . . . . . . . .9
Using Microphone . . . . . . . . . . . . . . . . . . . . . . . .9
iPod connection . . . . . . . . . . . . . . . . . . . . . . . . . .9
USB Function . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Compatible Devices . . . . . . . . . . . . . . . . . . . . . .10
Speaker System Connection . . . . . . . . . . . . . .10
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . .11
Timer Function . . . . . . . . . . . . . . . . . . . . . . . . . .11
Sleep Timer Function . . . . . . . . . . . . . . . . . . . . .11
Displaying Disc Information on-screen . . . . . .12
Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . .12
General Operation . . . . . . . . . . . . . . . . . . . . . . .12
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Lock (Parental Control) . . . . . . . . . . . . . . . . . .14
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Operation
General features . . . . . . . . . . . . . . . . . . . . . . . . .16
Additional features . . . . . . . . . . . . . . . . . . . . . . .17
Playing an Audio CD or MP3/WMA file . . . . . .18
Programmed Playback . . . . . . . . . . . . . . . . . . .18
Viewing a JPEG file . . . . . . . . . . . . . . . . . . . . . .19
Playing a DivX Movie file . . . . . . . . . . . . . . . . . .20
Using iPod . . . . . . . . . . . . . . . . . . . . . . . . . . .21-22
Presetting the Radio Stations . . . . . . . . . . . . . .23
Listening to the Radio . . . . . . . . . . . . . . . . . . . .23
Dimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Sound Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
EQUALIZER Effect . . . . . . . . . . . . . . . . . . . . . . .24
DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
DISPLAY MODE . . . . . . . . . . . . . . . . . . . . . . . . .24
XDSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
MP3 Optimizer . . . . . . . . . . . . . . . . . . . . . . . . . .24
XTS Pro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
VIRTUAL sound . . . . . . . . . . . . . . . . . . . . . . . . .24
4
Maintenance and Service
Refer to the information in this chapter before
contacting a service technician.
Handling the unit
When shipping the unit
Please save the original shipping carton and packing
materials. If you need to ship the unit, for maximum
protection, re-pack the unit as it was originally packed
at the factory.
Keeping the exterior surfaces clean
• Do not use volatile liquids such as insecticide spray
near the unit.
• Do not leave rubber or plastic products in contact
with the unit for a long period of time. since they
leave marks on the surface.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the
surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution.
Do not use strong solvents such as alcohol, benzine,
or thinner, as these might damage the surface of the
unit.
Maintaining the Unit
The unit is a high-tech, precision device. If the optical
pick-up lens and disc drive parts are dirty or worn, the
picture quality could be diminished.
Depending on the operating environment, regular
inspection and maintenance are recommended after
every 1,000 hours of use.
For details, please contact your nearest authorized
service center.
The manual largely contains detailed explanation
items about how to operate the unit with the
Remote Control.
Precautions in using the touch buttons
• Use the touch buttons with clean and dry hands.
- In a humid environment, wipe out any moisture on
the touch buttons before using.
• Do not press the touch buttons hard to make it work.
- If you apply too much strength, it can damage the
sensor of the touch buttons.
REFERENCE
• Touch the button that you want to work in order to
Language Codes . . . . . . . . . . . . . . . . . . . . . . . .25
Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . .26-27
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . .28
• Be careful not to have any conductive material such
operate the function correctly.
as metallic object on the touch buttons. It can cause
malfunctions.
To ensure proper use of this product, please read this
owner’s manual carefully and retain it for future
reference.
This manual provides information on the operation
and maintenance of your unit. Should the unit require
service, contact an authorized service location.
About the
Symbol Display
“
” may appear on your TV display during
operation and indicates that the function explained in
this owner’s manual is not available on that specific
DVD video disc.
Symbol Used in this Manual
Note:
Indicates special notes and operating features.
Tip:
Types of Playable Discs
DVD
(8 cm / 12 cm disc)
Audio CD
(8 cm / 12 cm disc)
In addition, this unit can play a DVD±R/RW, and CD-R
or CD-RW that contains audio titles, MP3, WMA,
JPEG or DivX files.
Note:
• Depending on the conditions of the recording
equipment or the CD-R/RW (or DVD±R/RW) disc
itself, some CD-R/RW (or DVD±R/RW) discs may
not be played on the unit.
• Do not attach any seal or label to either side (the
labeled side or the recorded side) of a disc.
• Do not use irregularly shaped CDs (e.g., heartshaped or octagonal). It may result in malfunctions.
Indicates tips and hints for making the task easier.
Regional Code
A section whose title has one of the following symbols
is applicable only to the disc represented by the
symbol.
This unit has a regional code printed on the bottom of
the unit. This unit can play only DVD discs labelled as
the same as the rear of the unit or “ALL”.
Note on Regional Codes
Indicates hazards likely to cause harm to the
unit itself or other material damage.
DVD-V
DVD and finalized DVD±R/RW
ACD
Audio CDs
MP3
MP3 files
WMA
WMA files
JPEG
JPEG files
DivX
DivX files
Introduction
Before use
• Most DVD discs have a globe with one or more
numbers in it clearly visible on the cover. This
number must match your DVD player’s regional
code or the disc cannot play.
• If you try to play a DVD with a different regional
code from your player, the message “Check
Regional Code” appears on the TV screen.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are
trademarks of Dolby Laboratories. Confidential Unpublished
works. Copyright 1992-1997 Dolby Laboratories. All rights
reserved.
POWER SAVE MODE
You can set up the unit into an economic power save
mode.
In power-on status, press and hold 1(POWER)
button for about 3 seconds.
- Nothing is displayed in the display window when
the unit goes into the power save mode.
To cance power save mode, press 1(POWER).
5
Front Panel/ Back Panel
20
1
19
2
3
18
17
4
16
5
15
22
OPEN
23
6
7
21
26
25
24
8
9
10
11
MIC1
MIC2
14
13
12
21. Antenna terminal
1. 1 (POWER)
2. VOLUME*
3. FUNC. (FUNCTION)
(FM, AM, DVD/CD, USB, AUX, OSD iPod)
22. AUX IN (Auxiliary input) connector
23. COMPONENT VIDEO OUT
(PROGRESSIVE SCAN) connector (Y Pb Pr)
4. .(SKIP)
TUN. (-) (TUNER)
24. VIDEO OUT Jack
5. XTS pro
26. Speaker terminal
25. iPod connector
6. x (STOP)
MO./ ST. (MONO/ STEREO)
*VOLUME Adjustment
7. DISC TRAY
8. EQ master/ DEMO button
9. CLOCK button
10. TIMER button
11. SET button
12. PHONES
(Headphone jack :
3.5mm)
13. MIC1/ MIC2 (MIC Jacks)
14.
USB connector
15. Z (OPEN/CLOSE)
16. > (SKIP)
TUN. (+) (TUNER)
17. XDSS plus / (MP3 Optimizer)
18. B/[] (PLAY/PAUSE)
19. Display window
20. Power cord
6
Move your finger around the touch
wheel.
Remote Control
2
iPod
21
3
20
4
19
5
18
6
7
8
17
9
10
16
11
12
15
13
14
Remote Control Operation Range
Point the Remote Control at the Remote Sensor and press
the buttons.
• Distance: About 23 ft (7 m) from the front of the Remote
Sensor
• Angle: About 30° in each direction in front of the Remote
Sensor
Introduction
22
1
1. POWER button
2. FUNCTION SELECT buttons
(TUNER/ BAND,DVD, AUX, USB)
3. NUMERIC buttons (0-9)
4. EQ master, XDSS plus, XTS Pro, VSM buttons
5. SETUP button
6. • ARROW buttons (v / V / b / B )
(Selects an option in the menu.)
• PRESET (-/+) buttons (v / V )
• TUN. (-/+) buttons (b / B)
7. SELECT/ ENTER button
8. MENU button
(Use the MENU button to display the menu screen
included on DVD video discs.)
9. PROG./MEMO. button
10. REPEAT button
11. REPEAT A-B button
12. • SCAN (FF/GG) buttons
• SLOW (t/T) buttons
• SKIP (./>) buttons
• STOP (x)/MO.ST. button
• PAUSE([])/ STEP button
• PLAY (G) button
13. • DIMMER button
• DISP.MODE button
14. ECHO VOL. ( / ), MIC VOL. ( / ) buttons
15. • CLEAR button
• ZOOM button
• MARKER, SEARCH buttons
16. VOLUME -/+ buttons
17. TITLE button
(Use the TITLE button to display the title screen
included on DVD video discs.)
18. DISPLAY button
19. • SOUND MODE button
• AUDIO ( ) button
• SUBTITLE ( ) button
• RETURN ( ) button - optional
20. SLEEP button
21. iPod button
22. MUTE ( )button
Remote Control battery installation
Remove the battery cover on the rear of
the Remote Control, and insert two R03
(size AAA) batteries with
and
aligned correctly.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
7
Installation and Setup
TV Connection
Antenna (Aerial) Connections
Make one of the following connections, depending on
the capabilities of your existing equipment.
Connect the supplied FM/AM antennas for listening to
the radio.
Tip:
• Depending on your TV and other equipment you
wish to connect, there are various ways you could
connect the unit. Use one of the connections
described below.
• Please refer to the manuals of your TV, VCR,
Stereo System or other devices as necessary to
make the best connections.
Caution:
• Make sure the unit is connected directly to the TV.
Select the correct AV input on your TV.
• Do not connect your unit to the TV via your VCR.
The DVD image could be distorted by the copy
protection system.
Note:
• To prevent noise pickup, keep the AM loop antenna
away from the unit and other components.
• Be sure to fully extend the FM wire antenna.
• After connecting the FM wire antenna, keep it as
horizontal as possible.
FM wire antenna (supplied)
Video connection
Connect the VIDEO OUT jack from the unit to the
VIDEO IN jack on the TV using the video cable
supplied (V).
Component Video connection
Connect the COMPONENT VIDEO OUT jacks from
the unit to the corresponding jacks on the TV using a
Y Pb Pr cable (C).
Rear of TV
COMPONENT VIDEO /
PROGRESSIVE SCAN INPUT
Y
Pb
Pr
C
8
VIDEO
INPUT
L
V
AM(MW) loop antenna
(aerial) (supplied)
For AM(MW) reception,connect
the loop antenna (aerial) to the
terminal marked AM
Auxiliary Function
Using Microphone
Connect an auxiliary device such as a TV or VCR via
the rear mounted AUX connector and press AUX [Refer
to the example image(1) shown below].
When you connect each end of the bundled portable in
cable with both the AUX connector and the headphone
jack of a portable device (like MP3 player, cassette tape
player, CD player, etc.), you can hear the sound of the
device through the speakers [Refer to the example
image(2) shown below].
You can sing to a music source by connecting a
microphone to the unit.
1. Connect your microphone to the MIC1/ MIC 2
Jacks.
“
” will be shown in the display window.
2. Play a music you want.
3. Sing along with the accompaniment.
Adjust the microphone volume by pressing MIC
VOL. button.(MIN,1 - 14, MAX steps)
Note:
Example (1)
To AUDIO in
Auxiliary Device
Installation and Setup
• When not using the microphone, set the MIC VOL. to
minimum or turn off the MICs and remove the
microphone from the MIC Jacks.
• If the microphone is set too near the speaker, a
howling sound may be produced. In this case, move
the microphone away from the speaker or decrease
the sound level by using MIC VOL..
• If sound through the microphone is extremely loud, it
may be distorted. In this case, decrese MIC volume.
iPod connection
To AUDIO out
Example (2)
Connect the iPod connector on the rear of the unit to
the dock connector of iPod using an iPod cable (I).
Portable in cable
MEN
U
iPod
I
Portable Device
Note:
Turn the unit off and then connect an auxiliary device
before you connect an auxiliary device.
Because it may be made a noise.
Headphone Jack
Note:
Depending on the type of iPod, you may need to
insert one of the dock adapters into the dock slot
before you station your iPod.
Adjust the volume to a moderate level before you
connect your iPod and this unit.
Connect a stereo headphone plug ( 3.5mm) into the
headphone jack.
The speakers are automatically disconnected when you
plug in the headphones (not supplied).
To Adjust ECHO Volume
You can give an echo effect to the sound from the
microphones.
Press ECHO VOL. ( / ) on the Remote Control to
increase the echo volume or decrease it.
(MIN,1 - 14, MAX steps)
9
USB Function
Speaker System Connection
You can enjoy the media files such as tunes
(MP3/WMA/PHOTO/VIDEO file) saved in an MP3
player or USB memory by connecting the storage
device to the USB port of this unit.
Connect the speaker wires cables to the speaker
terminals.
Note:
• Be sure to match the speaker wire to the
appropriate terminal on the components: + to + and
– to –. If the cords are reversed, the sound will be
distorted and will lack bass.
• Connect the Left/ Right speaker correctly. If it
reversed, the sound may be distorted.
Compatible Devices
1. Devices which require additional program
installation when you have connected it to a
computer, are not supported.
2. MP3 Player : Flash type MP3 player.
• The MP3 player requiring installation of a driver
is not supported.
3. USB Flash Drive : Devices that support USB2.0 or
USB1.1.
To Remove the USB from the unit
1. Choose the other functions except USB
function in order to remove the USB.
2. Remove the USB from the unit.
Note:
If you want to operate other functions, see the CD
Playback section. Refer to the page 16, 17, and 18.
Note:
• Do not extract the USB device in operating.
• A back up demands to prevent a data damage.
• If you use a USB extension cable or USB hub, the
USB device might not be recognized.
• A device using NTFS file system is not supported.
(Only FAT (16/32) file system is supported.)
• The USB function of this unit does not support all
USB devices.
• Digital camera and mobile phone are not supported.
• This unit is not supported when the total number of
files is 1000 or more.
10
Front
speaker (R)
Front
speaker (L)
1. Press CLOCK.
2. Select a 24 hour time system or a 12 hour time
system by tapping ./>.
(12HR)
or
(24HR)
3. Press SET to confirm the selected hour time
system.
4. Tap ./> on the front panel to set the correct
hours.
5. Press SET.
6. Tap ./> on the front panel to set the correct
minutes.
7. Press SET and the correct time is shown on the
display window.
8. Press CLOCK at any time to display the time for
about 5 seconds.
Note:
If you want to reset the clock, press and hold CLOCK
for more than 2 seconds.
Timer Function
With the TIMER function, you can have the radio
reception, CD play and USB play turned on and off at
the desired time.
1. Press CLOCK to check the current time.
(If you don’t set clock, the timer function doesn’t
work.)
2. Press TIMER to enter the timer setting mode. If
you want to correct the previous memorized
TIMER setting, press and hold the TIMER for
more than 2 seconds.
- The previously memorized timer on the time and
“ ” indicator appears in the display window.
3. Each function (TUNER → DVD/CD → USB)
flashes in the display window in turn. Press SET
when the desired function is flashing.
4. a. When you select the TUNER function, select
the previously memorized preset number by
tapping ./ > on the front panel and press
SET.
- “ON TIME” indicator appears for about
0.5 seconds in the display window and
then disappears.
b. When you select the DVD/CD or USB function,
- “ON TIME” indicator appears for about 0.5
seconds in the display window and then
disappears.
5. Set the hour to switch on by tapping ./> on
the front panel.
6. Press SET.
7. Set the minute to switch on by tapping ./>
on the front panel.
8. Press SET.
- “OFF TIME” indicator appears for about 0.5
seconds in the display window and then
disappears.
9. Set the hour to switch off by tapping ./> on
the front panel.
10. Press SET.
11. Set the minute to switch off by tapping ./>
on the front panel.
12. Press SET.
13. Adjust the volume level by tapping ./> on
the front panel.
14. Press SET.
“ ” appears in the display window and the timer
setting has been completed.
15. Switch the system off.
The selected function is automatically switched on
and off at the time set.
Installation and Setup
Setting the Clock
Note:
If you insert the DVD,VCD or DivX except audio
CD/MP3/WMA on the unit, the timer function will be
operated to the TUNER.
To cancel or check the timer
Each time the TIMER is pressed you can select the
timer set or cancel. You can also check the timer
setting status.
To activate or check the timer, press the TIMER that
“ ” appears in the display window.
To cancel the TIMER, press the TIMER that “ ”
disappears in the display window.
Sleep Timer Function
When the sleep timer is used, the power is
automatically turned off after the specified time has
elapsed.
1. Press SLEEP to set the desired sleep time.
The SLEEP indicator and sleep time appears in
the display window.
2. Each time you press SLEEP the setting changes
in the following order.
SLEEP 180 → 150 → 120 → 90 → 80 → 70
→ 60 → 50 → 40 → 30 → 20 → 10 → OFF (No
display)
Note:
If you press SLEEP while the sleep time is
displayed, the SLEEP time is reset.
To cancel the sleep timer mode
If you have to stop the function, press the SLEEP
repeatedly until “SLEEP 10” appears, and then press
SLEEP once again while “SLEEP 10” is displayed.
11
Displaying Disc Information
On - screen
GENERAL OPERATION
You can display various information about the disc
loaded on-screen.
2. Use v / V to select the desired option then press
B to move to the second level. The screen shows
the current setting for the selected item, as well as
alternate setting(s).
1. Press DISPLAY to show various playback
information.
The displayed items differ depending on the disc
type or playing status.
2. You can select an item by pressing v / V and
change or select the setting by pressing b / B.
Title (Track) – Current title (or track) number/
total number of titles (or tracks).
Chapter – Current chapter number/total number
of chapters.
Time – Elapsed playing time.
Audio – Selected audio language or channel.
Subtitle – Selected subtitle.
Angle – Selected angle/ total number of angles.
Sound – Selected sound mode.
1. Press SETUP. The Setup menu appears.
3. Use v / V to select the second desired option and
then press B to move to the third level.
4. Use v / V to select the desired setting then press
SELECT/ENTER to confirm your selection. Some
items require additional steps.
5. Press SETUP or PLAY to exit the Setup menu.
LANGUAGE
Note:
If any button is not pressed for a few seconds,
the on-screen display disappears.
OSD
Initial Settings
By using the Setup menu, you can make various
adjustments to items such as picture and sound. You
can also set a language for the subtitles and the
Setup menu, among other things. For details on each
Setup menu item, see the pages 12 to 15.
To display and exit the Menu:
Press SETUP to display the menu. A second press of
SETUP will take you back to initial screen.
To go to the next level: Press B.
To go back to the previous level: Press b.
12
Select a language for the Setup menu and the onscreen display.
Disc Audio / Subtitle / Menu
Select the language you prefer for the audio track
(disc audio), subtitles, and the disc menu.
Original – Refers to the original language in which
the disc was recorded.
Other – To select another language, press
numeric buttons and then
SELECT/ENTER to enter the
corresponding 4-digit number according to
the language code list on the page 25. If
you enter the wrong language code, press
CLEAR.
DISPLAY
Progressive Scan
Progressive Scan Video provides the highest quality
pictures with less flickering.
If you are using the COMPONENT VIDEO OUT jacks,
but are connecting the unit to a standard (analog)
television, set Progressive Scan to Off.
If you are using the Component Video jacks for
connection to a TV or monitor that is compatible with
a progressive scan signal, set Progressive Scan to
On.
4:3 – Select when a standard 4:3 TV is connected.
16:9 – Select when a 16:9 wide TV is connected.
Display Mode
The display Mode setting works only when the TV
Aspect mode is set to “4:3”.
Letterbox – Displays a wide picture with bands on
the upper and lower portions of the
screen.
Panscan – Automatically displays the wide picture
on the entire screen and cuts off the
portions that do not fit.
To Turn ON progressive scan:
Connect component out of the unit to the input of your
monitor/television, set your television or monitor to
Component Input.
1. Select “Progressive Scan” on the DISPLAY menu
then press B.
Installation and Setup
TV Aspect
2. Select “On” using v / V.
3. Pressing SELECT/ENTER will set the player to
Progressive scan mode.
Caution:
Once the setting for progressive scan output is
entered, an image will only be visible on a progressive
scan compatible TV or monitor. If you set Progressive
Scan to On in error, you must reset the unit. First,
remove the disc in the unit. Next, press STOP( x )
and hold it for five seconds before releasing it. The
video output will be restored to the standard setting,
and a picture will once again be visible on a
conventional analog TV or monitor.
13
AUDIO
3. Select a rating from 1 to 8 using v / V.
Each DVD disc has a variety of audio output options.
Set the unit’s AUDIO options according to the type of
audio system you use.
Rating 1-8: Rating one (1) has the most
restrictions and rating eight (8) is the
least restrictive.
Unlock: If you select unlock, parental control is
not active and the disc plays in full.
4. Press SELECT/ENTER to confirm your rating
selection, then press SETUP to exit the menu.
Password
You can enter or change password.
1. Select “Password” on the LOCK menu and then
press B.
Dynamic Range Control (DRC)
With the DVD*1 format, you can hear a program’s
soundtrack in the most accurate and realistic
presentation, thanks to digital audio technology.
However, you may wish to compress the dynamic
range of the audio output (the difference between the
loudest sounds and the quietest ones). Then, you may
listen to a movie at a lower volume without losing
clarity of sound. Set DRC to On for this effect.
*1: Dolby Digital only
Vocal
2. Follow the step 2 as shown above (Rating).
To change the password, press SELECT/ENTER
when the “Change” option is highlighted. Input a
password and press SELECT/ENTER. Enter it
again and press SELECT/ENTER to verify.
3. Press SETUP to exit the menu.
If you forget your password
If you forget your password, you can clear it using the
following steps:
Set Vocal to On only when a multi-channel karaoke
DVD is playing. The karaoke channels on the disc will
mix into normal stereo sound.
1. Press SETUP to display the Setup menu.
LOCK (Parental Control)
Area Code
2. Input the 6-digit number “210499” and press
SELECT/ENTER. The password is cleared.
Enter the code of the area whose standards were
used to rate the DVD video disc, based on the list on
page 25.
US
1. Select “Area Code” on the LOCK menu then
press B.
2. Follow step 2 as shown in rating section.
3. Select the first character using v / V.
Rating
Blocks playback of rated DVDs based on their
contents. Not all discs are rated.
1. Select “Rating” on the LOCK menu then
press B.
2. To access the LOCK options, you must input the
password you have created. If you have not yet
entered password, you are prompted to do so.
Input a password and press SELECT/ENTER.
Enter it again and press SELECT/ENTER to verify.
If you make a mistake before pressing
SELECT/ENTER, press CLEAR.
14
4. Press B and select the second character using
v / V.
5. Press SELECT/ENTER to confirm your Area code
selection.
OTHERS
Semi Karaoke
When a chapter/ title / track is fully finished ,this
function shows the score in the screen with a fanfare
sound.
on : Turn the “Semi Karaoke”function on.
When you finished singing a score will appear
on the screen.
We provide you the DivX® VOD (Video On Demand)
registration code that allows you to rent and purchase
videos based on the DivX® VOD service. For more
information, visit www.divx.com/vod.
1. Select “DivX(R) Registration” option and then
press B.
2. Press SELECT/ENTER while “Select” is selected
and the registration code will appear.
Use the registration code to purchase or rent the
videos from DivX® VOD service at
www.divx.com/vod. Follow the instructions and
download the video onto a disc for playback on
this unit.
Available discs for the Semi Karaoke function:
• DVD discs
• DVD Karaoke Discs
Note:
• This function operate on the DVD/CD mode.
• The Semi Karaoke function is available only when a
Installation and Setup
DivX(R) Registration
off : Turn the “ Semi Karaoke” function off.
Fanfare and score do not appears on the
screen
microphone is connected.
• Watching movies, “off” the Semi Karaoke or enjoy it
without connecting the MIC at the SET UP menu if
the fanfare or score appears during changing a
chapter.
3. Press SELECT/ENTER to exit.
Note:
All the downloaded videos from DivX® VOD can only
be played back on this unit.
15
Operation
General features
Buttons
Operations
Z (OPEN / CLOSE)
Opens or closes the disc tray.
X (PAUSE)
SKIP (. / >)
Discs
ALL
During playback, press X to pause playback.
ALL
Press X repeatedly to play Frame-by-Frame.
DVD
During playback, press SKIP (. or >) to go to the
next chapter/track or to return to the beginning of the
current chapter/track.
ALL
DivX
Press SKIP . twice briefly to step back to the previous
chapter/track.
SCAN (m / M)
During playback, press SCAN (m or M) repeatedly to
select the required scan speed.
DVD : bb, bbb, bbbb, bbbbb, bbbbbb or
BB, BBB, BBBB, BBBBB, BBBBBB
DivX disc : bb, bbb, bbbb, bbbbb or
BB, BBB, BBBB, BBBBB
WMA/MP3, Audio CD : m(X2, X4, X8) or M(X2, X4, X8)
DVD
DivX
MP3
WMA
During playback, press REPEAT repeatedly to select a
desired repeat mode.
DVD Video discs: Chapter/Title/Off
Audio CD, DivX/MP3/WMA discs: Track/All/Off
DVD
DivX
MP3
WMA
REPEAT A-B
During playback, press REPEAT A-B to select a point A
and a point B and repeats a sequence from point A
(Starting point) to point B (End point).
Press REPEAT A-B to exit.
DVD
ZOOM
During playback or in the pause mode, press ZOOM to
the video image (3 steps).
You can move through the zoomed picture using b B v
V.
DVD
TITLE
If the current DVD title has a menu, the title menu
appears on the screen. Otherwise, the disc menu may
appear.
DVD
MENU
The disc menu appears on the screen.
DVD
During playback, press SUBTITLE repeatedly to select a
desired subtitle language.
DVD
DivX
DVD
DivX
REPEAT
(SUBTITLE)
(AUDIO language) During playback, press AUDIO repeatedly to hear a
different audio language or audio track.
SLOW
In the pause mode, press SLOW (t or T) to select
required speed.
DVD : t (1/2, 1/4, 1/8, 1/16) or T (1/2, 1/4, 1/8, 1/16)
Note on general features:
• Zoom may not work on some DVDs.
• The A-B repeat function is available only in the current title.
16
DVD
ACD
ACD
Additional features
Time Search
DVD
DivX
To start playing at any chosen time on the disc:
1. Press DISPLAY during playback.
2. Press v / V to select the time clock icon and
“--:--:--” appears.
3. Input the required start time in hours, minutes, and
seconds from left to right. If you enter the wrong
numbers, press CLEAR to remove the numbers
you entered. Then input the correct numbers.
4. Press SELECT/ENTER to confirm. Playback starts
from the selected time.
Marker Search
DVD
DivX
To enter a Marker
You can start playback from up to nine memorized
points. To enter a marker, press MARKER at the
desired point on the disc. The Marker icon appears on
the TV screen briefly. Repeat to enter up to nine
markers.
Last Scene Memory
DVD
This unit memorizes the last scene from the last disc
that is viewed. The last scene remains in the memory
even if you remove the disc from the unit or switch off
the unit. If you load a disc that has the scene
memorized, the scene is automatically recalled.
Note:
This unit does not memorize the scene of a disc if you switch
off the unit before commencing to play the disc.
1.5 speed playback
DVD
MP3
WMA
ACD
You can quickly enjoy a movie and music.
The 1.5 speed allows you to watch the pictures and
listen to the sound quicker than playing at a normal
speed on the disc.
1. Press PLAY during the normal playback. The
screen will appear at 1.5 speed with sound .
2. To return to normal PLAY, press PLAY.
To Recall or Clear a Marked Scene
1. During disc playback, press SEARCH. The marker
search menu appears on the screen.
2. Within 10 seconds, press b / B to select a marker
number that you want to recall or clear.
3. Press SELECT/ENTER and playback starts from
the marked scene. Or press CLEAR and the
marker number is erased from the list.
4. You can play any marker by inputting its number
on the marker search menu.
Operation
Screen Saver
The screen saver appears when you leave the unit in
Stop mode for about five minutes.
17
Playing an Audio CD or MP3/WMA
file
This unit can play Audio CDs or MP3/WMA files.
MP3/ WMA/ Audio CD
Once you insert a cd with MP3/WMA files or Audio, a
menu appears on the TV screen.
Press v / V to select a track/file and then press PLAY
or SELECT/ENTER, and playback starts. You can use
variable playback functions. Refer to the page 16, 17.
ID3 TAG
When playing a file containing information such as
track titles, you can see the information by pressing
DISPLAY repeatedly. The information [ Folder and file
name, Song, Artist, Album, Genre, Comment, Time
information ] of the MP3/WMA file will be shown in the
display window and TV screen.
To move next or previous files, press the SKIP (. /
>) button.
Tip:
• Press MENU to move to the next page.
• On a CD with MP3/WMA and JPEG, you can switch
MP3/WMA and JPEG. Press TITLE, and MUSIC or
PHOTO top of the menu is highlighted.
MP3 / WMA disc compatibility with this player is
limited as follows:
• Sampling frequency: within 32 - 48 kHz (MP3),
within 24 - 48kHz (WMA)
• Bit rate: within 32 - 320kbps (MP3), 40 - 192kbps (WMA)
• The unit cannot read an MP3/WMA file that has a file
extension other than “.mp3” / “.wma”.
• CD-R physical format should be ISO 9660
• If you record MP3 / WMA files using software that
cannot create a file system (eg. Direct-CD) it is
impossible to playback MP3 / WMA files.We recommend
that you use Easy-CD Creator, which creates an ISO
9660 file system.
• File names should have a maximum of 8 letters and
must incorporate an .mp3 or .wma extension.
• They should not contain special letters such as / ? * : “
< > l etc.
• The total number of files on the disc should be less than
999.
This unit requires discs and recordings to meet certain
technical standards in order to achieve optimal playback
quality. Pre-recorded DVDs are automatically set to these
standards. There are many different types of recordable
disc formats (including CD-R containing MP3 or WMA files)
and these require certain pre-existing conditions (see
above) to ensure compatible playback.
Customers should note that permission is required in
order to download MP3 / WMA files and music from the
Internet. Our company has no right to grant such
permission. Permission should always be sought from
the copyright owner.
18
Programmed Playback
The program function enables you to store your
favorite tracks from any disc in the unit memory. A
program can contain 300 tracks.
1. Insert a disc.
Audio CD and MP3/WMA discs:
2. Select a track on the “List”, and then press
PROG.MEMO. or select “
(Add)” icon and then
press SELECT/ENTER to place the selected track
on the “Program” list. Repeat to place additional
tracks on the list.
Note:
You can add all tracks in the disc. Select “
then press SELECT/ENTER.
(Add All)” icon
3. Select the track you want to start playing on the
“Program” list. Press MENU to move to the next
page.
4. Press PLAY or SELECT/ENTER to start. Playback
begins in the order in which you programmed the
tracks. Playback stops after all of the tracks on the
“Program” list have played once.
5. To resume normal playback from programmed
playback, select a track of AUDIO CD (or
MP3/WMA) list and then press PLAY.
Repeat Programmed Tracks
1. Press REPEAT when playing a disc. The repeat
icon appears.
2. Press REPEAT to select a desired repeat mode.
• TRACK: repeats the current track
• ALL: repeats all the tracks on programmed list.
• Off(No display): does not play repeatedly.
Erasing a Track from “Program” List
1. Use v V to select the track that you wish to erase
from the Program list.
2. Press CLEAR. Alternatively, select “
(Delete)”
icon then press SELECT/ENTER to place the
selected track on the Program list. Repeat to
erase additional tracks on the list.
Erasing the Complete Program List
Use v / V to select “
SELECT/ENTER.
(Del all)” and then press
Note:
The programs are also cleared when the disc is removed.
Viewing a JPEG file
Zoom
This unit can play discs with JPEG files.
Before playing JPEG recordings, read the note on
JPEG Recordings on the right.
1. Insert a disc and close the tray.
The PHOTO menu appears on the TV screen.
Each time ZOOM is pressed the setting changes in
the following order.
Zoom on y Zoom off
Press v, B or M to enlarge the video image.
Press V, b or m to reduce the video image.
List
Preview
JPEG Folder 1
JPEG Folder 2
JPEG Folder 3
JPEG Folder 4
JPEG file compatibility with this player is limited
as follows:
JPEG Folder 5
JPEG Folder 6
JPEG Folder 7
JPEG Folder 8
2. Press v / V to select a folder, and then press
SELECT/ENTER. A list of files in the folder
appears.
If you are in a file list and want to return to the
previous Folder list, use v / V to highlight
and
press SELECT/ENTER or PLAY.
3. If you want to view a particular file, press v / V to
highlight a file and press SELECT/ENTER or
PLAY. While viewing a file, you can press STOP
to move to the previous menu (JPEG menu).
Slide Show
Use v V b B to highlight the
(Slide Show) then
press SELECT/ENTER or PLAY.
Tip:
• Depending upon the size and the number of
JPEG files, it could take a long time for the unit to
read the disc’s contents. If you don’t see an onscreen display after several minutes, some of the
files may be too large — reduce the resolution of
the JPEG files to less than 2M pixels as 2760 x
2048 pixels and burn another disc.
• The total number of files and folders on the disc
should be less than 999.
• Some discs may not operate due to a different
recording format or the condition of disc.
• Ensure that all the selected files have the “.jpg”
extensions when copying into the CD layout.
• If the files have “.jpe” or “.jpeg” extensions,
please rename them as “.jpg” file.
• File names without “.jpg” extension will not be
able to be read by this unit. Even though the files
are shown as JPEG image files in Windows
Explorer.
Operation
•There are four Slide Speed options
:
> (Slow), >> (Normal), >>> (Fast) and II (off).
Use v /V /b /B to highlight the Speed. Then, use b / B to
select the option you want to use and then press
SELECT/ENTER.
• If you set Speed option to Off, the slide is not active.
Still Picture
1. Press PAUSE/STEP during the slide show.
The unit will now go into the PAUSE mode.
2. To return to the slide show, press PLAY or press
PAUSE/STEP again.
Moving to another File
Press SKIP (. or >) once during viewing a
picture to advance to the next or previous file.
Rotating the picture
Press v /V /b /B during showing a picture to rotate
the picture clockwise or counter-clockwise.
19
Playing a DivX Movie file
Using this unit you can play DivX file.
1. Insert a disc and close the tray. The MOVIE menu
appears on the TV screen.
0:00:00
1/5
MOVIE
List
Movie Folder 1
Movie Folder 2
Movie Folder 3
Movie Folder 4
DivX file compatibility with this player is limited
as follows:
• Available resolution size of the DivX file is under
800x600 (W x H) pixel.
• The file name of the DivX subtitle is available by
45 characters.
• If there is impossible code to express in the DivX
file, it may be displayed as " _ " mark on the
display.
Movie Folder 5
Movie Folder 6
Movie Folder 7
Movie Folder 8
2. Press v / V to select a folder and then press
SELECT/ENTER. A list of files in the folder
appears. If you are in a file list and want to return
to the Folder list, use v / V to highlight
and
press SELECT/ENTER or PLAY.
3. If you want to view a particular file, press
v / V to highlight a file and press SELECT/ENTER
or PLAY.
4. Press STOP to exit.
Tip:
• Press MENU to move to the next page.
• On a CD with MP3/WMA, JPEG and MOVIE file,
you can switch MUSIC, PHOTO and MOVIE menu.
Press TITLE and MUSIC, PHOTO and MOVIE word
on top of the menu is highlighted.
Note:
• Be sure to select “SUBTITLE ON” mode by pressing
the subtitle file every time before playing a DivX file.
• When the subtile has more than two languages in
the file, original subtile is only available.
• You can not adjust sound mode and VIRTUAL
sound during the DivX file playing.
• The DivX subtitle file name has to be identified with
the DivX file name to display by this unit.
Notice for displaying the Divx subtitle
If the subtitle does not display properly during playback,
press and hold SUBTITLE for about 3 seconds then
press SUBTITLE to select another language code until
the subtitle is displayed properly
20
• If the number of the screen frame is over 30
per 1 second, this unit may not operate
normally.
• If the video and audio structure of recorded
files is not interleaved, either video or audio is
outputted.
Playable DivX file
• ".avi ", ".mpg ", ".mpeg ", ".divx"
Playable Subtitle format
SubRip(*.srt/*.txt)
SAMI(*.smi)
SubStation Alpha(*.ssa/*.txt)
MicroDVD(*.sub/*.txt)
SubViewer 2.0(*.sub/*.txt)
VobSub(*.sub)
Playable Codec format
• "DIVX3.xx ", "DIVX4.xx ", "DIVX5.xx ", "MP43 ",
"3IVX ".
Playable Audio format
• "AC3 ", "PCM ", "MP3 ", "WMA ".
• Sampling frequency: within 32 - 48 kHz (MP3),
within 24 - 48kHz (WMA)
• Bit rate: within 32 - 320kbps (MP3),
40 - 192kbps (WMA)
Using iPod
iPod is a trademark of Apple Computer, Inc, registered
in the U.S. and other countries.
General operation
1. Connect your iPod and the unit with iPod cable.
Refer to the page 9.
Your iPod is automatically turned on.
2. Turn the unit on.
3. Press iPod on the remote control to enter the iPod
mode.
The iPod menu appears on the TV screen.
The initial screen of iPod menu is the OSD iPod
mode.
4. Use v / V and ENTER on the Remote Control to
display the list of menu.
Note:
• It works with all iPod models that have a dock
connector.
• Compatibility with your iPod may vary depending
on the type of your iPod.
• Depending on your iPod’s software version, it may
not be possible to control your iPod from the unit.
We recommend installing the latest software
version.
• Adjust the volume to a moderate level before you
connect your iPod and this unit.
• MIC function is not suppoted on the iPOD mode.
Playing the iPod in the Remote iPod
mode
5. Press ENTER to play.
You can operate your iPod by using the supplied
remote control and controls on your iPod.
General features
1. Press iPod on the Remote Control until “IPOD”
appears in the display window.
iPod
Remote Control
buttons
buttons
Operations
B (PLAY)
BX
During pause, press B to
resume playback.
X (PAUSE)
BX
During playback, press X
to pause playback.
-
During playback, press x
to stop playback. Press
ENTER to resume
playback.
x (STOP)
SKIP
(./>)
SCAN
(m / M)
During playback, press
./> SKIP (. or >) to go to
the next track or to return
to the beginning of the
current track. Press SKIP
. twice briefly to step
back to the previous track.
Music file: During playback,
press and hold SCAN (m or
M) and then release at a
point you want.
Note:
You can select the Remote iPod mode or OSD
iPod mode by pressing repeatedly iPod on the
remote control.
2. Use v / V and ENTER on the Remote Control or
controls on your iPod to display the list of menu by
viewing your iPod.
3. Press ENTER to play.
Note:
• When you connect the unit and TV to VIDEO
IN/OUT, TV screen is turned off temporarily.
Operation
You can enjoy playback of your iPod using the
supplied remote control.
• Connect the VIDEO OUT jack on the rear of the
unit to the VIDEO IN jack on the TV using the video
cable if you want to view the video or photo file.
• The images of video or photo files are outputted
only when you connect the unit to the VIDEO OUT
connector.
Video file: During playback,
press and hold SKIP (.
or >) and then release at
a point you want.
REPEAT
MENU
REPEAT During playback, press
REPEAT repeatedly to
select a desired repeat
mode. (Track/All/Off)
MENU Moves to the previous
menu.
21
Playing the iPod in the OSD iPod
mode
iPod message
Remote iPod
Please use Monitor output
You can operate your iPod by controlling OSD menu
on the TV screen with the supplied remote control.
The controls on your iPod are not operational in the
OSD iPod mode.
1. Press iPod on the Remote Control until “OSD
IPOD” appears in the display window.
2. Use v / V and ENTER on the Remote Control to
display the list of menu.
3. Press ENTER to play.
Music
Classifies and plays the files by Playlists, Artists,
Albums, Genres, Songs, and Composers.
Photos / Videos
The video or photo file is not played in the OSD iPod
mode.
If you want to play the video or photo file, change to
the Remote iPod mode.
Now Playing
Displays and plays the last played music file.
22
for viewing Video and photo
from iPod.
When you connect the unit and
TV to COMPONENT VIDEO
IN/OUT in the Remote iPod
mode, the screen on the left
appears.
Connect the unit and TV to
VIDEO IN/OUT.
When you select the Photos or
Videos menu in the OSD iPod
mode, the screen on the left
appears. Change the unit to the
Remote iPod mode.
When you connect the iPod that
is not supported on this unit, the
screen on the left appears.
Depending on your iPod’s
software version, it may not be
possible to control your iPod
from the unit. We recommend
installing the latest software
version.
If the power of your iPod is
insufficient or the iPod is
misconnected or unknown
device, the screen on the left
appears.
Presetting the Radio Stations
Listening to the Radio
You can preset 50 stations for FM and AM. Before
tuning, make sure that you have turned down the
volume to the minimum.
1. Press TUNER/BAND to select the frequency (AM or
FM) you want.
1. Press TUNER/BAND to select the frequency (AM or
FM) you want.
The last received station is tuned in.
2. Select a station you want by pressing
TUN. (-/+).
Tuning in automatically
- Press TUN. (-/+) for more than 0.5 second.
Scanning stops when the unit tunes in a station.
Tuning in manually
- Press TUN. (-/+) briefly and repeatedly.
3. Press PROG./MEMO..
A preset number will flash in the display window.
4. Press PRESET (v/V) to select the preset number
you want.
5. Press PROG./ MEMO. again.
The station is stored.
6. Repeat the steps 1 (or 2) to 5 to store other
stations.
To delete all the memorized stations
Press and hold PROG./ MEMO. for about two
seconds, “ERASE ALL” appears in the display window
and then PROG./ MEMO. again, the stations are
deleted.
2. Press PRESET (v/V) repeatedly to select the
preset station you want.
- Each time you press the button, the unit tunes in
one preset station at a time.
3. Adjust the volume by pressing VOLUME (-/+)
repeatedly.
To listen to non-preset radio stations
• For manual tuning, see “Tuning in manually” in the
step 2 on left.
• For automatic tuning, see “Tuning in automatically”
in the step 2 on left.
To turn off the radio
Press 1(POWER) to turn the unit off or select another
function mode (DVD/CD, USB, AUX, OSD iPod).
For your reference
• If an FM program is noisy;
Press MO./ ST. that “MONO” appears in the display
window. There will be no stereo effect, but the
reception will be improved.
Press MO./ ST. again to restore the stereo effect.
• To improve reception;
Reposition the supplied antennas.
For your reference
If all stations have already been entered, “FULL”
message will appear in the display window for a
moment and then a preset number will flash. To
change the preset number, follow steps 4-5.
To recall presets
Operation
Press and hold PRESET (v/V) until the desired preset
number appears or press it repeatedly.
23
Dimmer
This function will change the brightness of the display
window on the front panel during in power-on status.
Press the DIMMER repeatedly.
Mute
Press MUTE to mute your unit.
You can mute your unit in order, for example, to
answer the telephone.
You can enjoy surround sound simply by selecting
one of the pre-programmed sound fields according to
the program you want to listen to (2 ch. sound only).
Press SOUND MODE repeatedly.
BYPASS → ON STAGE → STUDIO → CLUB → HALL
→ THEATER 1 → CHURCH → BYPASS...
Note:
Initial sound mode is BYPASS.
You can choose 7 fixed sound impressions and adjust
the BASS, MIDDLE and TREBLE.
- You can select a desired sound mode by using EQ
master.
→
→
NORMAL→ USER EQ → POP → CLASSIC
ROCK
→
→
- Press EQ master to select USER EQ.
1. When USER EQ is displayed, press SET. “BASS
0” will appear the display window.
2. Tap the ./ > on the front panel to select the
setting you want (MIN, -4 ~ +4, MAX steps).
3. Select the BASS, MIDDLE or TREBLE you want
by tapping B/]] or x on the front panel.
4. Adjust the MIDDLE and TREBLE as shown above.
DEMO
Press EQ master on the front panel in power off state
to demonstrate the function in the display window. To
cancel it, press POWER or EQ master again.
DISPLAY MODE
Whenever you press DISP. MODE (DISPLAY MODE),
you can enjoy the spectrum change with 6 types in
the display window.
24
This function is an optimizer for compressible MP3
files. It improves the bass sound to make sweet
sound.
Each time you press XDSS Plus.
The setting changes in the following order.
XDSS ON t MP3 -- OPT ON t NORMAL
XTS Pro
EQUALIZER Effect
DRAMA
Press XDSS plus to reinforce treble, bass and the
surround effect. The “XDSS ON” or “NORMAL”
indicator lights.
DVD/DivX/Audio CD : XDSS ON ↔ NORMAL
MP3/WMA : XDSS ON t MP3 -- OPT ON
t NORMAL t XDSS ON ...
MP3 Optimizer
Sound Mode
JAZZ
XDSS
(Extreme Dynamic Sound
System)
This unique sound quality developed by our
technology creates the optimum sound for you to play
the perfect playback of the original sound and to feel
the living sound source.
Each time you press XTS Pro the setting changes in
the following order.
XTS -- P ON ↔ NORMAL
Note:
The XTS Pro function will not be operated when a
headphone has been connected.
VIRTUAL sound
Press VSM to set the VIRTUAL sound.
Source
2.1 ch.
5.1 ch
Display
VIRTUAL
VIRTUAL
Effect
3D STEREO
VIRTUAL sound
3D STEREO
Realtime 3D positioned sound rendering
technology with stereo sources, optimized for
stereo speakers. Listeners may experience
amazing virtual surround effects with their own
multimedia players.
VIRTUAL sound
A pending downmix technology converts 5.1
channel to 2 channel sound having directional
information of audio. And it makes a 2 channel or
2.1 channel feel 5.1 channel sound.
Reference
Language Codes
Use this list to input your desired language for the following initial settings:
Disc Audio, Disc Subtitle, Disc Menu.
Language
Abkhazian
Afar
Afrikaans
Albanian
Ameharic
Arabic
Armenian
Assamese
Aymara
Azerbaijani
Bashkir
Basque
Bengali; Bangla
Bhutani
Bihari
Breton
Bulgarian
Burmese
Byelorussian
Cambodian
Catalan
Chinese
Corsican
Croatian
Czech
Danish
Dutch
English
Esperanto
Estonian
Faroese
Code
6566
6565
6570
8381
6577
6582
7289
6583
6588
6590
6665
6985
6678
6890
6672
6682
6671
7789
6669
7577
6765
9072
6779
7282
6783
6865
7876
6978
6979
6984
7079
Language
Fiji
Finnish
French
Frisian
Galician
Georgian
German
Greek
Greenlandic
Guarani
Gujarati
Hausa
Hebrew
Hindi
Hungarian
Icelandic
Indonesian
Interlingua
Irish
Italian
Japanese
Javanese
Kannada
Kashmiri
Kazakh
Kirghiz
Korean
Kurdish
Laothian
Latin
Latvian, Lettish
Code
7074
7073
7082
7089
7176
7565
6869
6976
7576
7178
7185
7265
7387
7273
7285
7383
7378
7365
7165
7384
7465
7487
7578
7583
7575
7589
7579
7585
7679
7665
7686
Language
Lingala
Lithuanian
Macedonian
Malagasy
Malay
Malayalam
Maltese
Maori
Marathi
Moldavian
Mongolian
Nauru
Nepali
Norwegian
Oriya
Panjabi
Pashto, Pushto
Persian
Polish
Portuguese
Quechua
Rhaeto-Romance
Rumanian
Russian
Samoan
Sanskrit
Scots Gaelic
Serbian
Serbo-Croatian
Shona
Sindhi
Code
7678
7684
7775
7771
7783
7776
7784
7773
7782
7779
7778
7865
7869
7879
7982
8065
8083
7065
8076
8084
8185
8277
8279
8285
8377
8365
7168
8382
8372
8378
8368
Area
Malaysia
Maldives
Mexico
Monaco
Mongolia
Morocco
Nepal
Netherlands
Netherlands Antilles
New Zealand
Nigeria
Norway
Oman
Pakistan
Panama
Paraguay
Philippines
Poland
Portugal
Romania
Russian Federation
Code
MY
MV
MX
MC
MN
MA
NP
NL
AN
NZ
NG
NO
OM
PK
PA
PY
PH
PL
PT
RO
RU
Language
Singhalese
Slovak
Slovenian
Somali
Spanish
Sudanese
Swahili
Swedish
Tagalog
Tajik
Tamil
Tatar
Telugu
Thai
Tibetan
Tigrinya
Tonga
Turkish
Turkmen
Twi
Ukrainian
Urdu
Uzbek
Vietnamese
Volapük
Welsh
Wolof
Xhosa
Yiddish
Yoruba
Zulu
Code
8373
8375
8376
8379
6983
8385
8387
8386
8476
8471
8465
8484
8469
8472
6679
8473
8479
8482
8475
8487
8575
8582
8590
8673
8679
6789
8779
8872
7473
8979
9085
Area Codes
Choose a area code from this list.
Code
AF
AR
AU
AT
BE
BT
BO
BR
KH
CA
CL
CN
CO
CG
CR
HR
CZ
DK
EC
EG
SV
Area
Ethiopia
Fiji
Finland
France
Germany
Great Britain
Greece
Greenland
Code
ET
FJ
FI
FR
DE
GB
GR
GL
Heard and McDonald Islands HM
Hong Kong
HK
Hungary
HU
India
IN
Indonesia
ID
Israel
IL
Italy
IT
Jamaica
JM
Japan
JP
Kenya
KE
Kuwait
KW
Libya
LY
Luxembourg
LU
Area
Saudi Arabia
Senegal
Singapore
Slovak Republic
Slovenia
South Africa
South Korea
Spain
Sri Lanka
Sweden
Switzerland
Taiwan
Thailand
Turkey
Uganda
Ukraine
United States
Uruguay
Uzbekistan
Vietnam
Zimbabwe
Code
SA
SN
SG
SK
SI
ZA
KR
ES
LK
SE
CH
TW
TH
TR
UG
UA
US
UY
UZ
VN
ZW
REFERENCE
Area
Afghanistan
Argentina
Australia
Austria
Belgium
Bhutan
Bolivia
Brazil
Cambodia
Canada
Chile
China
Colombia
Congo
Costa Rica
Croatia
Czech Republic
Denmark
Ecuador
Egypt
El Salvador
25
Troubleshooting
Check the following guide for the possible cause of a problem before contacting service.
Symptom
Correction
• The power cord is disconnected.
• Plug the power cord securely into the
wall outlet.
The power is on, but
the unit does not work.
• No disc is inserted.
• Insert a disc. (Check that the DVD or,
audio CD indicator in the DVD display
is lit.)
No picture.
• The TV is not set to receive DVD signal
output.
• Select the appropriate video input
mode on the TV so the picture from
the unit appears on the TV screen.
• The video cable is not connected
securely.
• The connected TV power is turned off.
• Connect the video cable into the
jacks securely.
• The equipment connected with the
audio cable is not set to receive DVD
signal output.
• Select the correct input mode of the
audio receiver so you can hear the
sound from the unit.
• The audio cables are not connected
securely.
• Connect the audio cable into the
jacks securely.
• The power of the equipment connected
with the audio cable is turned off.
• Turn on the equipment connected
with the audio cable.
There is no sound or
only a very low-level
sound is heard.
• Turn on the TV.
• The audio connecting cable is damaged.
• Replace it with new one.
The playback picture is
poor.
• The disc is dirty.
• Clean the disc.
The unit does not start
playback.
• No disc is inserted.
• Insert a disc. (Check that the DVD, or
audio CD indicator in the DVD display
is lit.)
• An unplayable disc is inserted.
• Insert a playable disc. (Check the
disc type, color system and Regional
code.)
• The disc is placed upside down.
• Place the disc with the playback side
down.
• The disc is not placed within the guide.
• Place the disc on the disc tray
correctly inside the guide.
• The disc is dirty.
• Clean the disc.
• A menu is on the TV screen.
• Press the SETUP button to turn off
the menu screen.
• The Rating level is set.
• Cancel the Rating function or change
the rating level.
• The disc is dirty.
• Clean the disc.
• The speakers and components are
connected poorly.
• Connect the speakers and
components securely.
• The unit is located too close to the TV.
• Move your TV away from the audio
components.
Loud hum or noise is
heard.
26
Cause
No power.
The Remote Control
does not work
properly.
The front panel
display is too dim.
Correction
• Connect the antenna securely.
• Adjust the antennas and connect an
external antenna if necessary.
• The signal strength of the stations is too
weak (when tuning in with automatic
tuning).
• Tune in the station manually.
• No stations have been preset or preset
stations have been cleared (when
tuning by scanning preset stations).
• Preset the stations (page 23).
• The Remote Control is not pointed at
the Remote Sensor of the unit.
• Point the Remote Control at the Remote
Sensor of the unit.
• The Remote Control is too far from the
unit.
• Use the Remote Control within about 23
ft (7 m).
• There is an obstacle in the path of the
Remote Control and the unit.
• Remove the obstacle.
• The batteries in the Remote Control are
flat.
• Replace the batteries with new ones.
• Nothing is displayed on the front panel
display.
• Press DIMMER.
REFERENCE
Cause
Symptom
Radio stations cannot • The antenna is positioned or connected
poorly.
be tuned in.
27
CD/DVD
General
Specifications
Speakers
Amplifier
AM
[MW]
Tuner
FM
Video
Power supply
Power consumption
Net Weight
External dimensions (W x H x D)
Operating conditions
Operating humidity
Laser
Signal system
Frequency response (audio)
Signal-to-noise ratio (audio)
Dynamic range (audio)
Harmonic distortion (audio)
Video output
COMPONENT VIDEO OUT
Tuning Range
Intermediate Frequency
Signal-to Noise Ratio
Frequency Response
Tuning Range
Intermediate Frequency
Stereo mode
Output Power
T.H.D
Frequency Response
Signal-to-noise ratio
Type
Impedance
Frequency Response
Sound Pressure Level
Rated Input Power
Max. Input Power
Net Dimensions (W x H x D)
Net Weight
Refer to main label
Refer to main label
3.31 kg
170 x 253 x 265 mm
Temperature: 5°C to 35°C, Operation status: Horizontal
5% to 85%
Semiconductor laser, wavelength 650 nm
NTSC 525/60
40 Hz to 2 kHz
More than 75 dB (1 kHz, NOP -3 dB, 20 kHz LPF/A-Filter)
More than 75 dB
0.5 % (1 kHz, at 1W position) (20 kHz LPF)
1.0 V (p-p), 75 Ω, negative sync./ RCA jack x 1
(Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 1
87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
10.7 MHz
60/55 dB (Mono)
50 - 10,000 Hz
522 - 1,620 kHz or 520 - 1,720 kHz
450 kHz
80 W + 80 W
80 W + 80 W
0.5 %
40 - 20000 Hz
75 dB
3 Way 3 Speaker
4Ω
70 - 20,000 Hz
83 dB/W (1m)
80 W
160 W
128 x 295 x 240 mm
4.1kg
❋ Designs and specifications are subject to change without notice.
28
LG Electronics, Inc.
Limited Warranty - USA
This LG Electronics product, will be repaired or replaced, at LG’s option, if it proves to be defective in material or
workmanship, under normal use, during the warranty period (“Warranty Period”) listed below, effective from the date
(“Date of Purchase”) of original consumer purchase of the product. This warranty is good only to the original purchaser
of the product and effective only when used in the United States, excluding U.S. Territories.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED
WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG
ELECTRONICS WILL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL OR PUNITIVE
DAMAGES OF ANY NATURE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, INCLUDING WITHOUT
LIMITATION, LOST REVENUES OR PROFITS, LOST OR CORRUPTED PROGRAMMING OR DATA, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT OR OTHERWISE. Some states do not allow the exclusion or limitation of incidental or
consequential damages or limitation on how long an implied warranty lasts, so the above exclusion or limitation may not apply to
you. This warranty gives you specific legal rights and you may also have other rights that may vary from state to state.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
•
Damages or operating problems that result from shipping, installation, adjustment of user controls,
calibration, maintenance or failure to maintain, or separate system components; and
•
Damages or operating problems that result from normal wear and tear, misuse, abuse, operation outside
environmental specifications or contrary to the requirements or precautions in the Operating Guide, accident,
lightning strikes or other natural causes, unauthorized modification or alteration, incorrect electrical current
or voltage, signal reception or input, software not licensed directly by LG, software errors that do not disable
functionality, operating and software protocols adopted after the date of manufacture or for outside the US,
institutional or commercial use, or other causes not arising out of defect in material or workmanship.
The cost of repair or replacement under these excluded circumstances shall be borne by the consumer.
CUSTOMER INTER-ACTIVE CENTER NUMBERS:
For Warranty Service, Where to buy, Product
Assistance, or Customer Assistance
Call 1-800-243-0000 (24 hours a day, 365 days per year)
and select appropriate options from the menu.
Or visit our website at http://www.lgservice.com
LG ELECTRONICS U.S.A., INC.
1000 SYLVAN AVENUE
ENGLEWOOD CLIFFS, NJ
P/N : MFL35424727
Printed in China
Issue O
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
