LOGO!Power 12
© Siemens AG 2008
LOGO!Power
LOGO!Power 15 V
■ Overview
■ Application
■ Technical specifications
Power supply, type
15 V/1.9 A
15 V/4 A
Order No.
6EP1 351-1SH02
6EP1 352-1SH02
Input
Rated voltage Vin rated
Single-phase AC
100 - 240 V AC
Wide-range input
85 ... 264 V AC
Single-phase AC
100 - 240 V AC
Wide-range input
85 ... 264 V AC
Overvoltage strength
2.3 x Vin rated/1.3 ms
2.3 x Vin rated/1.3 ms
Mains buffering at Iout rated
Rated line frequency,
rated line-frequency range
Rated current Iin rated
Switch-on current limit (+25 °C)
> 40 ms at Vin = 187 V
50/60 Hz, 47 ... 63 Hz
> 40 ms at Vin = 187 V
50/60 Hz, 47 ... 63 Hz
0.63 ... 0.33 A
< 15 A
1.24 ... 0.68 A
< 30 A
I 2t
Built-in line-side fuse
Recommended miniature circuit
breaker (IEC 898) in the mains power
input
< 0.8 A2s
Internal
From 16 A, Characteristic B or
from 10 A, Characteristic C
< 3 A2s
Internal
From 16 A, Characteristic B or
from 10 A, Characteristic C
Output
Rated voltage Vout rated
Total tolerance, static
• Static mains compensation
• Static load smoothing
Controlled, isolated DC voltage
15 V DC
±3 %
Approx. 0.1 %
Approx. 1.5 %
Controlled, isolated DC voltage
15 V DC
±3 %
Approx. 0.1 %
Approx. 1.5 %
Residual ripple
Spikes (bandwidth approx. 20 MHz)
Adjustment range
Status display
Response on activation/deactivation
< 200 mVpp (typ. 10 mVpp)
< 300 mVpp (typ. 30 mVpp)
10.5 ... 16.1 V
Green LED for output voltage OK
No overshoot of Vout
(soft start)
< 200 mVpp (typ. 10 mVpp)
< 300 mVpp (typ. 40 mVpp)
10,5 ... 16,1 V
Green LED for output voltage OK
No overshoot of Vout
(soft start)
Startup delay/
voltage rise
Rated current Iout rated
Current range to +55 °C
Parallel switching for enhanced
performance
< 0.5 s/typ. 15 ms
< 0.5 s/typ. 10 ms
1.9 A
0 ... 1.9 A
Yes
4A
0 ... 4 A
Yes
Voltage range
12
The power supplies of the LOGO!Power range are primary
switched-mode devices that are optimally matched to the
LOGO! logic modules in their functionality and design. With the
wide-range input 85 V to 264 V AC, radio interference level B and
option for installing in built-in miniature distribution boards, they
can be used universally in a diverse range of applications in the
low-end performance range.
Continued on page 12/7.
12/6
Siemens KT 10.1 · 2008
© Siemens AG 2008
LOGO!Power
LOGO!Power 15 V
Power supply, type
15 V/1.9 A
15 V/4 A
Order No.
6EP1 351-1SH02
6EP1 352-1SH02
Efficiency
Efficiency at Vout rated, Iout rated
Power losses at Vout rated, Iout rated
Approx. 80 %
Approx. 7 W
Approx. 85 %
Approx. 11 W
<0.2 % Vout
<0.2 % Vout
Typ. ± 2.8 %Vout
Typ. ± 3.3 %Vout
Typ. 20 ms
Typ. 20 ms
Typ. 20 ms
Typ. 20 ms
Typ. 2.7 A
Constant current characteristic
<4A
Typ. 5.0 A
Constant current characteristic
<8A
–
–
Yes, safety extra-low output
voltage Vout to EN 60950 and EN
50178
Class II (without protective
conductor)
Yes; CB scheme
Yes, safety extra-low output
voltage Vout to EN 60950 and EN
50178
Class II (without protective
conductor)
Yes; CB scheme
Yes
cULus-listed (UL 508, CSA
C22.2 No. 14), File E197259;
cURus-recognized (UL 60950,
CSA C22.2 No. 60950), File
E151273
Yes
cULus-listed (UL 508, CSA
C22.2 No. 14), File E197259;
cURus-recognized (UL 60950,
CSA C22.2 No. 60950), File
E151273
FM approval
Marine approval
Degree of protection (EN 60529)
Class I Div. 2, Group A, B, C, D T4
GL
IP20
Class I Div. 2, Group A, B, C, D T4
GL
IP20
EMC
Emitted interference
Supply-harmonics limitation
Noise immunity
EN 55022 Class B
Not applicable
EN 61000-6-2
EN 55022 Class B
Not applicable
EN 61000-6-2
Closed-loop control
Dyn. mains compensation
(Vin rated ± 15 %)
Dynamic load smoothing
(Iout: 10/90/10 %)
Load step settling time
• 10 to 90 %
• 90 to 10 %
Protection and monitoring
Current limit
Short-circuit protection
Sustained short-circuit
current rms value
Overload/short-circuit indicator
Safety
Primary/secondary electrical
isolation
Protection class
German Technical Inspectorate
approval
CE mark
UL/cUL (CSA) approval
Operating data
Ambient temperature range
– 20 ... +55 °C with natural
convection
Transport/storage temperature range – 40 ... +70 °C
Humidity class
Climate class 3K3 to
EN 60721, no condensation
Mechanics
Supply-input connections L1, N
Connections
• Output +
• Output –
Dimensions (W x H x D) in mm
Weight, approx.
Installation
– 20 ... +55 °C with natural
convection
– 40 ... +70 °C
Climate class 3K3 to
EN 60721, no condensation
One screw terminal each for
0.5 ... 2.5 mm2 single-core/finely
stranded
One screw terminal each for
0.5 ... 2.5 mm2 single-core/finely
stranded
2 screw terminals for
0.5 ... 2.5 mm2
2 screw terminals for
0.5 ... 2.5 mm2
54 x 90 x 55
0.17 kg
Snaps onto DIN rail
EN 60715 35x7.5/15
72 x 90 x 55
0.25 kg
Snaps onto DIN rail
EN 60715 35x7.5/15
12
Siemens KT 10.1 · 2008
12/7
