Model VP-12S4 User Guide
DLPTM Projector
ENGLISH
IMPORTANT SAFETY
INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
WARNING
READ BEFORE OPERATING EQUIPMENT
This product was designed and manufactured to meet strict quality and safety standards. There are, however,
some installation and operation precautions which you should be particularly aware of.
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the manufacture's instructions.
8.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
NOTE:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined by
tuning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and receiver.
This Class B digital apparatus complies with
Canadian ICES-003.
11.
Only use attachments/accessories specified by the manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13.
Unplug this apparatus during lightning storms or when unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
NOTE:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
Additional Safety Information!
• This product should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have been adhered to.
• To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the
apparatus.
• When the switch is in the OFF position, the apparatus isn’t completely switched-off from the
MAINS.
Cet appareil numérique de la Classe B est
conforme à la norme NMB-003 du Canada.
ENGLISH
FOREWORD
This section must be read carefully before any
connection is made to the mains supply.
WARRANTY
For warranty information, contact your local
Marantz distributor.
RETAIN YOUR PURCHASE RECEIPT
Your purchase receipt is your permanent record of
a valuable purchase. It should be kept in a safe
place to be referred to as necessary for insurance
purposes or when corresponding with Marantz.
IMPORTANT
When seeking warranty service, it is the
responsibility of the consumer to establish proof
and date of purchase. Your purchase receipt or
invoice is adequate for such proof.
FOR U.K. ONLY
This undertaking is in addition to a consumer’s
statutory rights and does not affect those rights in
any way.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product has been prepared to
comply with the household power and safety
requirements that exist in your area.
COPYRIGHT
Recording and playback of some material may
require permission. For further information refer to
the following:
- Copyright Act 1956
- Dramatic and Musical Performers Act 1958
- Performers Protection Acts 1963 and 1972
- Any subsequent statutory enactments and
orders
WARNINGS
– Do not expose the equipment to rain or
moisture.
– Do not remove the cover from the equipment.
– Do not insert anything into the equipment
through the ventilation holes.
– Do not handle the mains lead with wet hands.
– Do not cover the ventilation with any items
such as tablecloths, newspapers, curtains,
etc.
– No naked flame sources, such as lighted
candles, should be placed on the equipment.
– When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules that
apply in your country or area.
– Do not place anything about 1 meter above
the top panel.
– Make a space of about 0.2 meter around the
unit.
– When the projector is mounted on the ceiling,
the Ceiling Mount Kit approved by MARANTZ
must be used for installation.
– Do not look into the lens when the projector
is turned on. It could damage your eyesight.
– Unplug the projector from the wall outlet if it
is not to be used for a few days.
– When the switch is in the OFF position, the
apparatus is NOT disconnected from the AC
supply mains.
– The socket-outlet shall be installed near the
equipment and shall be easily accessible.
– No objects filled with liquids, such as vases,
shall be placed on the apparatus.
Lamp Handing Precautions
DANGER
This SHP uses a high voltage glass mercury vapor
lamp. The lamp can break or fail to light if handled
wrongly during replacement or because of the
projector’s surrounding temperature.
Lamp life also varies according to the lamp with
some even breaking or failing to light as soon as
they are used the first time. If the lamp breaks,
glass fragments may be scattered inside the lamp
unit and projector, and gas inside the lamp bulb
that contains mercury vapor may be emitted from
the projector’s vent.
Before use, carefully read the projector user guide
and the lamp replacement instructions. Remember
to handle the lamp with care. In the event of
serious trouble, call for Marantz authorized dealer.
• Do not look directly into the lamp with bare
eyes while lit. The bright light can cause sore
eyes and impair vision.
• Do not directly expose skin to the light of the
lamp. Direct exposure can inflame the skin.
• Do not drop, impact, subject to excessive force
or otherwise damage the lamp.
• Replacing the lamp runs the risk of burns and
electric shock, therefore shut OFF power
supply, unplug the AC power cord from AC
power outlet and wait at least 60 minutes for
the lamp to cool down before attempting to
replace it.
• If the lamp breaks, unplug the AC power cord
from AC power outlet and call for Marantz
authorized dealer to replace it. Do not replace
the lamp yourself or clean up broken glass
inside the projector as this can result in cuts
and burns to you or damages inside the
projector.
• If the projector is hung from a ceiling or
installed in a high place, it is extremely
dangerous to replace the lamp. In this case, do
not replace or handle the damaged lamp
yourself.
CAUTION
• The chance of the lamp breaking is high after
extended use. It is recommended to replace
the lamp when near the end of its designed
life. Do not use a lamp beyond the maximum
lighting time.
• Use only Marantz original lamp units. Check
the model code of the lamp unit matches that
in the user guide.
• Before replacing the lamp, read carefully
“Lamp Unit Replacement” in the user guide.
Replace the lamp as explained therein.
• Entrust disposal of a used lamp to a licensed
industrial waste handler or return it to the place
of purchase. Do not break the lamp or discard
with general waste.
• If the lamp breaks, leave the area immediately
and stay away for at least 30 minutes, and
ventilate the room so as not to inhale the
mercury vapor.
• If you inhale the mercury vapor, see a
physician immediately and follow his
instructions.
FRANÇAIS
AVANT-PROPOS
Prière de lire ce chapitre avant de brancher
l’appareil sur le secteur.
GARANTIE
Pour des informations sur la garantie, contacter le
distributeur local Marantz.
CONSERVER L’ATTESTATION D’ACHAT
L’attestation d’achat est la preuve permanente d’un
achat de valeur. La conserver en lieu sur pour s’y
reporter aux fins d’obtention d’une couverture
d’assurance ou dans le cadre de correspondances
avec Marantz.
IMPORTANT
Pour l’obtention d’un service couvert par la
garantie, il incombe au client d’établir la preuve de
l’achat et d’en corroborer la date. Le reçu ou la
facture constituent des preuves suffisantes.
REGLAGE DE L’ALIMENTATION
SECTEUR DE L’APPAREIL
Cet appareil Marantz a été conçu pour respecter
les exigences de votre région en matière
d’alimentation secteur et de sécurité.
DRUITS D' AUTEUR
L’enregistrement et la lecture de certaines
informations sonores nécessitent une autorisation.
Pour de plus amples renseignements, consultez:
- La loi de 1956 sur les Copyright
- Loi concernant les Acteurs et Musiciens 1958
- Lois de Protection des Artistes 1963 et 1972
- Les décrets et règlements ultérieurs qui s’y
rapportent
AVERTISSEMENTS
– Ne pas exposer l’appareil à la pluie ni à
l’humidité.
– Ne pas essayer de retirer le boîtier de
l’appareil.
– Ne rien insérer dans l’appareil par les orifices
de ventilation.
– Ne pas manipuler le cordon d’alimentation
avec les mains mouillées.
– Ne pas recouvrir les ouïes de ventilation avec
un objet quelconque comme une nappe, un
journal, un rideau, etc.
– Ne placer aucune source de flamme nue,
comme une bougie allumée, sur l'appareil.
– Pour mettre au rebut les piles usées,
respecter les lois gouvernementales ou les
règlements
officiels
concernant
l’environnement qui s'appliquent à votre pays
ou région.
– Ne placer aucun objet à moins d'un mètre
environ du panneau supérieur.
– Veiller à ce qu’aucun objet ne soit à moins de
0,2 mètre des côtés de l'appareil.
– Pour monter le projecteur au plafond, vous
devez utiliser un kit de montage au plafond
approuvé par MARANTZ pour l'installation.
– Ne regardez pas dans l'objectif quand le
projecteur est allumé. Cela pourrait
endommager votre vue.
– Débranchez le projecteur de la prise murale
s'il ne doit pas être utilisé pendant plusieurs
jours.
– Quand l'interrupteur d'alimentation est sur la
position OFF, l'appareil N'EST PAS
déconnecté de l'alimentation secteur.
– La prise secteur doit être située près de
l'appareil et accessible facilement.
– Aucun objet rempli de liquide, un vase par
exemple, ne doit être placé sur l'appareil.
Précautions à prendre pour la
manipulation de la lampe
DANGER
Ce SHP utilise une lampe à vapeur de mercure en
verre à haute tension. Cette lampe peut se casser
ou ne pas s'allumer si elle est manipulée
incorrectement pendant son remplacement ou du
fait de la température ambiante du projecteur.
La durée de service d'une lampe varie aussi en
fonction de la lampe, certaines se cassant ou ne
s'allumant pas aussitôt qu'elles sont utilisées pour
la première fois. Si la lampe se casse, des
fragments de verre peuvent se répandre à
l'intérieur de l'unité lampe et du projecteur, et le
gaz à l'intérieur de l'ampoule de la lampe qui
contient de la vapeur de mercure peut être émis
par l'orifice du projecteur.
Avant utilisation, lisez attentivement le guide de
l'utilisateur du projecteur et les instructions de
remplacement de la lampe. Pensez à manipuler la
lampe avec précautions. En cas de problème
sérieux, contactez un distributeur agréé Marantz.
• Ne regardez pas directement la lampe sans
protection pour les yeux pendant qu'elle est
allumée. Sa lumière brillante peut faire mal aux
yeux et affaiblir la vue.
• N'exposez pas directement la peau à la
lumière de la lampe. Une exposition directe
peut provoquer une inflammation de la peau.
• Ne laissez pas tomber la lampe, ne la heurtez
pas, ne la soumettez pas à une force excessive
ni ne l'endommager.
• Le remplacement de la lampe fait courir un risque
de brûlure et de choc électrique ; il faut donc
couper l'alimentation électrique, débrancher le
cordon d'alimentation secteur de la prise secteur
et attendre au moins 60 minutes que la lampe
refroidisse avant d'essayer de la remplacer.
• Si la lampe se casse, débranchez le cordon
d'alimentation secteur de la prise secteur et
contactez un distributeur agréé Marantz pour
qu'il la remplace. Ne remplacez pas la lampe
vous-même ni ne nettoyez le verre brisé à
l'intérieur du projecteur car vous pourriez vous
couper et vous brûler ou endommager
l'intérieur du projecteur.
• Si le projecteur est accroché au plafond ou
installé dans un endroit en hauteur, il est
extrêmement dangereux de remplacer la lampe.
Dans ce cas, ne remplacez ni ne manipulez
vous-même la lampe endommagée.
ATTENTION
• Le risque que la lampe se casse est élevé
après une utilisation prolongée. Il est
recommandé de remplacer la lampe
lorsqu'elle approche de sa durée de service
spécifiée. N'utilisez pas une lampe au-delà du
temps d'éclairage maximum.
• N'utilisez que des unités lampes d'origine
Marantz. Vérifiez que le code de modèle de
l'unité lampe correspond à celui indiqué dans le
guide de l'utilisateur.
• Avant de remplacer la lampe, lisez
attentivement "Remplacement de l'unité
lampe" dans le guide de l'utilisateur.
Remplacez la lampe conformément aux
explications de cette section.
• Confiez la mise au rebut d'une lampe usée à
un service de déchets industriels licencié ou
retournez-la où vous l'avez achetée. Ne
cassez pas la lampe ni ne la jetez avec les
ordures ménagères.
• Si la lampe se casse, sortez immédiatement
de la zone pendant au moins 30 minutes, et
aérez la pièce afin de ne pas inhaler la vapeur
de mercure.
• Si vous inhalez de la vapeur de mercure,
consultez immédiatement un médecin et
suivez ses instructions.
ESPAÑOL
PROLOGO
Antes de conectar el equipo a la corriente, debe
leer este capítulo.
GARANTIA
Para obtener información acerca de la garantia
póngase en contacto con su distribuidor Marantz.
GUARDE SU RECIBO DE COMPRA
Su recibo de compra es su prueba permanente de
haber adquirido un aparato de valor, Este recibo
deberá guardarlo en un lugar seguro y utilizarlo
como referencia cuando tenga que hacer uso del
seguro o se ponga en contacto con Marantz.
IMPORTANTE
Cuando solicite el servicio otorgado por la garantia
el usuario tiene la responsabilidad de demonstrar
cuando efectuó la compra. En este caso, su recibo
de compra será la prueba apropiada.
SELECCION DEL VOLTAJE DE
ALIMENTACION
Este producto Marantz se ha preparado para estar
conforme con los requisitos de alimentación
eléctrica doméstica y de seguridad que hay en su
zona.
COPYRIGHT
La grabación y reproducción de determinado
material puede necesitar permiso. Para más
información consulte lo siguiente:
- Acta sobre copyright de 1958
- Acta de la Sociedad General de Autores de
1958
- Acta de Protección de la Propiedad
Intelectual de Autores de 1963 y 1972
- Cualquier acta, estatuto y órdenes
subsiguientes
ADVERTENCIAS
– No exponga el equipo a la lluvia ni a la
humedad.
– No extraiga la tapa del equipo.
– No introduzca nada en el interior del equipo a
través de los orificios de ventilación.
– No maneje el cable de alimentación con las
manos mojadas.
– No cubra la ventilación con objetos como
manteles, periódicos, cortinas, etc.
– No deben colocarse sobre el equipo
elementos con fuego, por ejemplo velas
encendidas.
– Cuando se eliminen baterías usadas, deben
cumplirse las reglamentaciones oficiales o
las normas de protección medioambiental
aplicables en su país o en su zona.
– No ponga nada a menos de 1 metro por
encima del panel superior.
– Deje un espacio de unos 0,2 metro alrededor
de la unidad.
– Cuando el proyector se monte en el techo
deberá utilizarse para la instalación el juego
de montaje en el techo aprobado por
MARANTZ.
– No mira al objetivo cuando el proyector esté
encendido. Podría lesionarse la vista.
– Desenchufe el proyector de la toma de
corriente si no lo va a utilizar durante unos
pocos días.
– Cuando el interruptor esté en la posición
OFF, el aparato NO estará desconectado de
la fuente de alimentación de CA.
– La toma de corriente deberá estar instalada
cerca del equipo y deberá poderse acceder a
ella fácilmente.
– No se deben colocar sobre el aparato
recipientes que contengan líquidos, como por
ejemplo jarrones.
Precauciones para la manipulación de la
lámpara
PELIGRO
Esta lámpara SHP de vidrio y de alto voltaje
contiene vapor de mercurio. La lámpara puede
romperse o no encenderse si es manipulada
incorrectamente durante el recambio o debido a la
temperatura ambiente del proyector.
La vida útil también varía según las lámparas,
algunas de las cuales se rompen o no se
encienden al cabo del primer uso. Si la lámpara se
rompe, los fragmentos de cristal se pueden
desparramar por el interior de la unidad de la
lámpara y del proyector, y el gas con vapor de
mercurio contenido en la bombilla se puede
escapar a través del sistema de ventilación del
proyector.
Antes de usar el aparato, lea con cuidado la guía
de usuario del proyector y las instrucciones de
recambio de la lámpara. No olvide manipular con
cuidado la lámpara. En caso de producirse
problemas serios, avise a un distribuidor
autorizado de Marantz.
• No mire directamente a la lámpara sin
protección en los ojos cuando ésta esté
encendida. La luz brillante puede irritar los ojos
e impedir la visión.
• No exponga directamente la piel a la luz de la
lámpara. La exposición directa puede inflamar
la piel.
• No deje caer la lámpara, ni la golpee, ni la
someta a presiones excesivas, ya que de lo
contrario la lámpara se daña.
• El recambio de la lámpara entraña el riesgo de
quemaduras y descargas eléctricas, y por lo
tanto, deberá apagar el aparato, desenchufar
el cable de alimentación del tomacorriente de
CA, y esperar al menos 60 minutos a que la
lámpara se enfríe antes de intentar
recambiarla.
• Si la lámpara se rompe, desenchufe el cable de
alimentación de CA y avise a un distribuidor
autorizado de Marantz para recambiarla. No
recambie la lámpara usted mismo ni limpie los
cristales rotos en el interior del proyector, pues
podría sufrir cortes y quemaduras y ocasionar
daños en el interior del proyector.
• Si el proyector cuelga del techo o está instalado
en un lugar elevado, el recambio de la lámpara
es extremadamente peligroso. En tal caso, no
recambie ni manipule usted mismo la lámpara
dañada.
PRECAUCIÓN
• La probabilidad de que la lámpara se rompa
es alta después de un uso prolongado. Se
recomienda recambiar la lámpara cerca de la
fecha de expiración de su vida útil prevista.
No utilice una lámpara más tiempo del
máximo de iluminación previsto.
• Utilice sólo lámparas originales de Marantz.
Compruebe que el código del modelo de la
lámpara coincide con el de la guía de usuario.
• Antes de recambiar la lámpara, lea
atentamente la sección “Recambio de la
lámpara” en la guía de usuario. Recambie la
lámpara tal y como viene allí explicado.
• Confíe el desecho de la lámpara usada a un
manipulador autorizado de desechos
industriales o devuélvala al lugar donde la
compró. No rompa la lámpara ni la deseche
en la basura normal.
• Si la lámpara se rompe, abandone la zona
inmediatamente y permanezca alejado
durante al menos 30 minutos, ventilando la
habitación con objeto de no inhalar el vapor
de mercurio.
• Si inhala vapor de mercurio, consulte
inmediatamente a su médico y siga sus
instrucciones.
PORTUGUÊS
INTRODUÇÃO
Esta secção deverá ser lida antes de efectuar
qualquer ligação àcorrente.
GARANTIA
Para informações sobre a garantia, contactar o
distribuidor Marantz local.
GUARDAR O RECIBO DE COMPRA
O recibo é o registo permanente da compra que
fez. Deve ser guardado num local seguro, para ser
apresentado em questões relacionadas com o
seguro ou para quando tiver de contactar a
Marantz.
IMPORTANTE
Quando procurar assisténcia técnica ao abrigo da
garantia, é da responsabilidade do consumidor
estabelecer a prova e data de compra. O recibe é
prova adequada.
REGULAÇÃO DO EQUIPAMENTO
CONFORME A ALIMENTAÇÃO DA REDE
O seu produto Marantz foi condicionado a
satisfazer os requisitos domésticos de energia e
segurança existentes na sua zona.
DIREITOS DE AUTOR
Poderá ser necessária autorização para a
gravação e a leitura de determinado material. Para
mais informações deverá consultar o seguinte:
- Lei do direito de autor de 1956 (Copyright
Act)
- Lei dos artistas relacionados com a música e
com o teatro de 1958 (Dramatic and Musical
Performers Act)
- Leis de protecção dos artistas de 1963 e de
1972 (Performers Protection Acts)
- Quaisquer regulamentos e despachos
estatutários posteriores
ADVERTÊNCIAS
– Não exponha o equipamento à chuva nem à
humidade.
– Não retire a tampa do equipamento.
– Não atire nada para dentro do equipamento
através dos orificíos de ventilação.
– Não manuseie o cabo de alimentação com
as mãos molhadas.
– Não cobrir os orifícios de ventilação com
objectos tais como toalhas de mesa, jornais,
cortinas, etc.
– Não colocar chamas abertas tais como velas
acesas, sobre o aparelho.
– Ao deitar foras as pilhas usadas, favor
observar os regulamentos governamentais
ou as regras com respeito ao meio ambiente
que se aplicam no seu país ou área de
residência.
– Deixar um espaço completamente livre de
cerca de 1 metro acima do painel superior.
– Deixar um espaço de cerca de 0,2 metro ao
redor do aparelho.
– Quando o projector for montado no tecto, o
Kit de Montagem no Tecto aprovado pela
MARANTZ deverá ser utilizado para a
instalação.
– Não olhe para dentro da lente quando o
projector é activado. Isto pode danificar a
visão.
– Desligue o projector da tomada de parede se
este não estiver para ser utilizado durante
alguns dias.
– Quando o interruptor estiver na posição OFF
(desligado), o aparelho NÃO é desligado da
rede eléctrica principal.
– A tomada de parede deverá estar instalada
perto do equipamento e deverá estar
facilmente acessível.
– Não colocar recipientes com água, tal como
vasos, sobre o aparelho.
Precauções para o manuseio da lâmpada
CUIDADO
Esta lâmpada SHP é uma lâmpada feita de vidro
que contém vapor de mercúrio a alta pressão. A
lâmpada pode quebrar ou não acender caso seja
manuseada incorrectamente durante a
substituição ou devido à temperatura ambiente
onde se encontra o projector.
A vida útil da lâmpada também varia conforme a
lâmpada, com casos de quebra ou falha em
acender na primeira vez que a lâmpada é utilizada.
Se a lâmpada quebrar, estilhaços de vidro podem
cair dentro do compartimento da lâmpada e do
projector, e o gás de dentro da lâmpada que
contém vapor de mercúrio poderá ser emitido
através da saída do projector.
Antes de o utilizar, leia cuidadosamente o guia do
utilizador do projector bem como as instruções
para substituição da lâmpada. Lembre-se de
manusear a lâmpada com cuidado. No caso de
problemas, entre em contacto com o representante
autorizado da Marantz.
• Não olhar directamente na lâmpada acesa
sem protecção ocular. A luz forte pode causar
irritação nos olhos ou prejudicar a visão.
• Não expor a pele directamente à luz da
lâmpada. Exposição directa pode causar
inflamação na pele.
• Não derrubar, bater, nem usar força excessiva,
pois pode danificar a lâmpada.
• Devido ao risco de queimaduras e choque
eléctrico ao substituir a lâmpada, desligue a
alimentação, desligue o cabo de alimentação da
tomada de CA e espere pelo menos 60 minutos
para arrefecer antes de substituir a lâmpada.
• Se a lâmpada quebrar, desligue o cabo de
alimentação de CA da tomada e entre em
contacto com o representante autorizado da
Marantz para que faça a substituição. Não
tente fazer a substituição nem limpar os
estilhaços de vidro de dentro do projector, pois
pode resultar em cortes e queimaduras ou
ainda danos ao projector.
• Se o projector estiver instalado no teto ou
qualquer lugar alto, é extremamente perigoso
substituir a lâmpada. Nesse caso, não tente
fazer a substituição nem manusear o lâmpada
danificada.
AVISO
• A probabilidade da lâmpada quebrar aumenta
depois de um longo período de utilização. É
recomendável substituir a lâmpada quando a
vida útil da mesma estiver próxima do fim.
Não utilizar a lâmpada além do tempo máximo
determinado.
• Utilizar apenas lâmpadas genuínas Marantz.
Confirme que o código do modelo da lâmpada
corresponde com o listado no guia do
utilizador.
• Antes de substituir a lâmpada, leia
cuidadosamente a secção “Substituição da
lâmpada” no guia do utilizador. Substitua a
lâmpada de acordo com as instruções dadas.
• Para jogar uma lâmpada usada, solicite os
serviços de uma companhia autorizada a
colectar lixo industrial ou devolva a lâmpada na
loja onde a adquiriu. Não quebrar a lâmpada
nem jogá-la com o lixo comum.
• Se a lâmpada quebrar, saia da sala
imediatamente, ventile o ambiente para evitar
inalar o vapor de mercúrio e não retorne por
pelo menos 30 minutos.
• Se inalar o vapor de mercúrio, consulte um
médico imediatamente e siga as suas
instruções.
IMPORTANT SAFEGUARDS..................................................................................2
OPERATIONS .......................................................................................................17
Caution Concerning the Lamp Replacement ....................................................................2
Caution Concerning the Lamp Unit ...................................................................................2
Caution Concerning the Setup of the Projector ................................................................2
Notes on Operation ...........................................................................................................2
Menu Structure ...............................................................................................................17
Picture Mode ...................................................................................................................18
How to Operate Menus ...................................................................................................18
Picture Adjust ..................................................................................................................19
Fine Menu 1 ....................................................................................................................20
Fine Menu 2 ....................................................................................................................20
Input Signal .....................................................................................................................21
RGB/HD Adjust ...............................................................................................................21
Display ............................................................................................................................22
OSD/Blanking .................................................................................................................22
Configration.....................................................................................................................23
FEATURES..............................................................................................................3
ACCESSORIES .......................................................................................................3
PROJECTOR LAYOUT AND FUNCTIONAL OVERVIEW .....................................4
Front and Top View...........................................................................................................4
Rear and Terminals View..................................................................................................5
Bottom View ......................................................................................................................5
Remote Controller .............................................................................................................6
Remote Controller Operational Range..............................................................................7
Preparing the Remote Controller ......................................................................................7
CONNECTION .........................................................................................................8
Connection with AC Power Supply ...................................................................................8
Connection with Video Equipments ..................................................................................8
Connection with a HD-Video, DVD Player, Satellite, Cable Tuner or PC .........................9
Advanced Connection .......................................................................................................9
INITIAL SETTING ..................................................................................................10
Turning on the Power......................................................................................................10
Zooming and Focusing ...................................................................................................10
Detail Focusing ...............................................................................................................10
Adjusting the Image Position ..........................................................................................11
Adjusting the Height ........................................................................................................11
Keystone Correction .......................................................................................................11
MAINTENANCE.....................................................................................................24
Lamp Life and Replace Lamp .........................................................................................24
Replacing Lamp Unit.......................................................................................................24
Color Temperature Adjustment .......................................................................................26
Cleaning the Lens ...........................................................................................................27
Replacement Parts .........................................................................................................27
Optional Accessories ......................................................................................................27
TROUBLESHOOTING...........................................................................................27
ERROR MODE ......................................................................................................28
ON SCREEN MESSAGE.......................................................................................28
SPECIFICATIONS .................................................................................................29
DIMENSIONS ........................................................................................................30
GLOSSARY ...........................................................................................................30
INSTALLATION.....................................................................................................12
Recommended Setting ...................................................................................................12
Screen Size and Projection Distance (inch) VP-12S4 ...................................................13
Screen Size and Projection Distance (mm) VP-12S4 ....................................................13
Lens shift position ...........................................................................................................14
BASIC OPERATIONS ...........................................................................................15
Turning on the Power......................................................................................................15
Selecting the Input Signal Source ...................................................................................15
Selecting the Aspect Mode .............................................................................................15
The Screen Images in a 16:9 screen ..............................................................................15
The Screen Images in a 4:3 screen ................................................................................16
To Turn off the Power .....................................................................................................16
1
ENGLISH
TABLE OF CONTENTS
Caution
ENGLISH
IMPORTANT SAFEGUARDS
Caution
For minimal servicing and to maintain high image quality, avoid humidity, dust and cigarette smoke.
When the projector is subjected to these environments,the lens and part of ventilation holes must be cleaned
more often than usual. As long as the projector is properly maintained in this manner, use in these
environments will not reduce the overall operation life. Please note that all internal cleaning must be
performed by an Marantz Authorized Dealer, or Service Center.
• Do not expose the projector to extreme heat or cold.
Operating temperature:41 °F to 95 °F (+5 °C to 35 °C)
Storage temperature:–4 °F to 140 °F (–20 °C to +60 °C)
Concerning the Lamp Replacement
There is potential glass particle hazard if the lamp ruptures.
Caution
Concerning the Setup of the Projector
Concerning the Lamp Unit
There is a potential hazard of glass particle if the lamp ruptures.
In case of lamp rupture,contact your nearest Marantz Authorized Dealer or Service Center for a
replacement.
See “Replacing Lamp Unit”. (
P.24)
95˚F
(+35˚C)
☞
41˚F
(+5˚C)
WARNING
THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.
CAUTION : HIGH PRESSURE LAMP CAUTION HOT : UNPLUG
MAY EXPLODED IF IMPROPERLY HANDLED. THE POWER CORD AND WAIT
REFER SERVICING TO QUALIFIED SERVICE 60 MINUTES BEFORE CHARGING
PERSONNEL.
THE LAMP.
ATTENTION :
LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.
For USA
WARNING
THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.
For Europe
CAUTION HOT
UNPLUG THE POWER CORD AND
WAIT 60 MINUTES BEFORE
CHANGING THE LAMP.
Notes on Operation
MODEL NO. VP-16S1 / U1M
AC 120V
60HZ
2.0A
SERIAL NO.
For USA
CAUTION : HIGH PRESSURE LAMP CAUTION HOT : UNPLUG
MAY EXPLODED IF IMPROPERLY HANDLED. THE POWER CORD AND WAIT
REFER SERVICING TO QUALIFIED SERVICE 60 MINUTES BEFORE CHARGING
PERSONNEL.
THE LAMP.
ATTENTION :
LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.
ATTENTION CHAUD :
DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.
• The exhaust ventilative hole, the lamp cage cover and adjacent areas may get extremely hot during
projector operation. To prevent injury,do not touch these areas until they have sufficiently cooled
down.
• Allow at least 1 foot (30 cm)of space between the exhaust ventilative hole and the nearest wall or
obstruction.
MODEL NO.• VP-12S1
/ N1S
If the cooling
fan becomes obstructed, a protection device will automatically turn off the projector lamp.
AC 120V 60H
2.0W
This Zdoes
not indicate a malfunction. Remove the projector power cord from the wall outlet and wait at
least 10 minutes.
SERIAL NO.
Then turn on the power by plugging the power cord back in. This will return the projector to the normal
operating condition.
For Europe
ATTENTION CHAUD
CAUTION
DEBRANCER LE CORD ON
D'ALIMENTION ET ATENDER 60
MINUTES AVANT DE CHANGER
LAMPE.
HIGH PRESSURE LAMP MAY EXPLODED IF BEI FALSCHER HANDHABUNG M
IMPROPERLY HANDLED. REFER SERVICING KANN DIE HOCHDRUCKLAMPE
EXPLODIEREN UBERLASSEN
TO QUALIFIED SERVICE PERSONNEL.
SIE WARTUNGSARBEITEN
ATTENTION
NUR FACHPERSONAL.
LA LAMPE SOUS HAUTE PRESSION PEUT
EXPLOSER SI ELLE, N'EST PAS MANIPULEE
CORRECTEMENT, CONFIER L'OPERATION
A UN PERSONNEL D'ENTRETIEN QUALIFIE.
WARNUNG HEISS
ZIEHEN SIE DEN NETZSTECKER
AB UND WARTEN SIE 60 MINUTEN,
BEVOR SIE DIE GLUHLAMPE
WECHSELN.
2
ATTENTION CHAUD :
DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.
VORSICHT :
MADE IN JAPAN
FABRIQUE AU JAPON
•
•
•
•
•
•
•
•
•
•
•
•
– Digital Micromirror Device, DLP, DLP logo, DLP Medallion and DarkChip3 are trademarks of Texas
Instruments.
– VXP, Visual Excellence Processing and the VXP Logo are trademarks or registered trademarks of
Gennum Corporation.
– All trademarked product names mentioned in this manual are the property of their respective
companies.
– HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
ENGLISH
• AC Power Code
For USA
LIGHT
i
7-9
INFO.
REMOTE CONTROLLER
RC -12VPS4
2
1
T
BLANK
4-6
RGB
HDMI
Z
1-3
CINEMA
THROUGH
DYN
USER
V
S
RGB
VIDEO
F
N
ZOOM
DYNAMIC
S-VIDEO
FULL
STD
ASPECT
STANDARD NORMAL
THTR
For Europe
2
THEATER
1
INPUT
ENTER
COMP.
MENU
I
• Remote Controller x 1
V-MUTE
•
•
•
•
•
•
•
•
•
•
•
• Lens Cap x 1
ON
•
Incorporates the latest DMD element -- “.8 720p with DarkChip3TM” (1280 x 720 pixel, 16:9 wide panel).
Using an optimized system for movie viewing with specially designed image circuits and optical parts,
the VP-12S4 bring high color reproduction with the pitch black of movie films that reproduces images
in rich tones and crisp black.
Images are sharply detailed, smooth and high quality owing to a powerful chip that builds into a
dedicated processor an image processing IC featuring Gennum’s proud “VXP TM” high quality
contouring technology, “TruMotionHDTM”, “FineEdgeTM”, “RealityExpansionTM” and “FidelityEngineTM”.
Konica Minolta optical system custom-made for Marantz.
O.R.C.A. (Optically Reproducing Color Accurately) filterTM that greatly improves color purity.
A large 98mm 7-segment color wheel that builds an ND filter.
Automatic color temperature adjustment
4 Picture Modes (Theater, Standard, Dynamic, User)
5 built-in preset gammas
Fine-adjustment menus that allow the user to adjust images as they like
18 user menus for saving adjusted images
Color temperature setting (5250K, 5800K, 6500K, 7500K, 9300K)
Black level adjustment
Supports input of NTSC, PAL, SECAM and satellite broadcasts (480i/p, 540p, 576i/p, 720p, 1035i,
1080i/p).
Rich array of input jacks including HDCP supporting HDMI digital input jack and dual system
component jacks
1.45x zoom lens
Lens shift feature for vertically positioning the projection point
Digital correction of vertical keystone distortion
Projection modes for functional, hanging and rear projection
Light-up luminous remote control
Light-up I/O jacks for easy connections and setup in dark environments
Equipped with RS-232C port and 12V trigger terminal for custom installation
Marantz system bus port
Low operating noise thanks to a die-cast silent duct, hermetically sealed color wheel motor and fan speed
control
Highly rigid die-cast chassis to minimize radiating noise
2000 hr long-life 200W SHP lamp with double-shielded safety structure
PATTERN
•
ACCESSORIES
STANDBY
FEATURES
• Control Adapter Cable (Mini Jack to RCA) x 1
• AA Size Batteries x 2
• Scart - RCA plug Cable x 1 (For Europe only)
• User Guide
For USA (4 languages)
For Europe (4+5 languages)
• Color temperature sensor x 1
• Warranty Card
(1 copy each for USA, CANADA)
3
ENGLISH
PROJECTOR LAYOUT AND FUNCTIONAL OVERVIEW
!0 ON indicator
Front and Top View
Lights up blue when power is ON. When power is
shut OFF, the lamp flashes for about 1 minute
before going out.
3
9
7
6
5 10 4 11 12 8
!1 STANDBY indicator
Lights up when the power is turned off.
!2 WARNING/LAMP indicator
Flashes or lights up when something is wrong with
the lamp cover, lamp, fan, or temperature inside
the projector.
For more information on the error mode, see the
“Error Mode List” (
P.28)
☞
!3 Ventilation holes
2
1
Notes:
• Do not place anything near the ventilation
holes to avoid overheat inside the unit.
• Do not place your hand or objects near the
ventilation holes; the air is coming out.
Projection
Lens
13
IR sensor
q Focus ring (☞ P.10)
y ENTER button
Adjust the picture focus.
Press to enter the selected menu item.
w Zoom ring (☞ P.10)
u INPUT SELECT button (☞ P.15)
Adjust the size of the projected image.
e Lens Shift knob (☞ P.11)
Manually adjust the position of the image vertically.
r
/ I button (☞ P.15)
Press to turn the projector ON or STANDBY mode.
t MENU button (☞ P.18)
Display the on-screen menu.
4
Selects the input signal (COMPONENT 1,
COMPONENT 2, S-VIDEO, VIDEO, RGB, HDMI 1
and HDMI 2).
i PATTERN button (☞ P.10)
Projects a focus pattern on the screen.
o The 3 / 4 / 1 / 2 buttons
Control the MENU cursor.
Note: Pixel defects
DMD (Digital Micromirror Device) is one of the
most advanced technologies for consumer
products. The DMD made by high precision
technology, however some pixel defects may
be found on the projected image. We are
trying our best to control the quality in order to
reduce the number of defective pixels. It is
almost impossible to have zero pixel defects,
even using the most advanced technology.
This is not a problem only for Marantz, but all
DLPTM projector manufactures. Therefore we
have to note that the warranty does not cover
the DMD for pixel defects. We appreciate your
understandings.
Note: Lamp
SHP lamp is one of the most advanced
technologies for consumer products. The
lamp made by high precision technology,
however some lamps might be failing before it
reaches its life. And projector’s brightness is
getting darker along with accumulated lamp
usage hours. We are trying our best to control
the quality in order to reduce lamp failures. It
is almost impossible to have zero failure, even
using the most advanced technology. This is
not a problem only for Marantz, but all
projector manufactures. Therefore we have to
note that the warranty does not cover the SHP
lamp for lamp failures: explosion, and nonlighting except initial use. And also we have to
note that the warranty does not cover the SHP
lamp for lamp failures: flickering, and getting
darker along with accumulated lamp usage
hours. We appreciate your understandings.
Bottom View
Ventilation holes
Ventilation
hole
IR sensor
Ventilation
hole
2
2
3
4
5
6
7
Lamp cover
Lamp cover
securing screw
1
Adjustable
feet
1
1
11
10
9
8
2
z AC IN (☞ P.8)
Connect the supplied AC power code.
x RGB IN
Connect the analog RGB output from an IBM VGA
or compatible equipment.
c COMPONENT VIDEO IN 1 and 2
Terminals 1 and 2 have each Y, P B/C B, P R/C R
terminals. Connect them to the component video
output of a video device, AV amp/processor, DVD
player, etc.
v S-VIDEO IN
Connect the S-VIDEO output from a video
equipment.
b VIDEO IN
Connect the composite video output from a video
equipment.
ENGLISH
Rear and Terminals View
n TRIG.1(TRIGGER 1)
, TRIG.2(TRIGGER 2)
When the unit is turned on, 12V is output. When the
unit is turned off, no voltage is output. This allows
such as a powered up/down screen,whenever the
projector is turned on or off.
Select ON or OFF at each aspect mode, such as
Full, Normal, Zoom, and Through to control screen
aspect ratio with powered up/down dual aspect
ratio screen.
Note:
To connect with external devices, use an
ordinal 3.5mm mini-plug (mono) cable.
Notes:
• Do not use TRIG.1 and TRIG.2, as the power
source.
• To connect with external devices, use an
ordinal 3.5mm mini-plug (mono) cable.
Adjustable feet
z Adjustment lever (☞ P.11)
Lift the projector and turn the adjustment lever right
or left. The adjustable feet will extend from the
projector. Then, release the lever, the adjustable
feet is locked.
x Screw holes for ceiling mount kit
m REMOTE IN/OUT
By connecting this projector to another Marantz
audio component using a supplied System Control
cable, you can remotely operate the components
as a single system.
• When connecting to component with a remote
sensor (such as the SR9500,SR8500), be sure
to connect the "REMOTE CONTROL IN" jack
of this projector to the "REMOTE CONTROL
OUT" jack of the component with the remote
sensor.
Note:
For connections, always use the included bus
control adaptor cable.
. HDMI IN 1 and 2
Connect the digital RGB signal (TMDS compliant,
single link only)
Note:
To use the HDMI terminal, please follow the
cautions on page 9.
⁄0 LIGHT ON/OFF
Select ON : The terminal panel lights up.
⁄1 RS-232C
This is the control port for the custom installer.
5
¡4 USER 7-9 button (☞ P.18)
Remote Controller
ENGLISH
f INPUT (Input signal select)
button (☞ P.15)
a
s
STANDBY
ON
PATTERN
V-MUTE
I
MENU
¡5
¡6
¡7
g COMP. 1 (Component video in 1)
button (☞ P.15)
d
Selects the device connected to the COMPONENT
VIDEO IN 1 jack as the input source.
ENTER
f
g
INPUT
ASPECT
COMP.
THEATER
FULL
1
THTR
F
¡8
¡9
STANDARD NORMAL
h
j
k
l
2
STD
N
S-VIDEO
DYNAMIC
ZOOM
S
DYN
Z
VIDEO
USER
THROUGH
V
1-3
T
RGB
RGB
CINEMA
4-6
HDMI
¡0
1
¡1
2
BLANK
7-9
INFO.
¡2
¡3
¡4
LIGHT
i
REMOTE CONTROLLER
RC -12VPS4
™0
™1
™2
™3
™4
™5
™6
™7
™8
™9
a STANDBY button (☞ P.16)
Turn the projector off.
s V-MUTE button
Turn the picture into black. Press again to resume.
d 3 / 4 / 1 / 2 / ENTER buttons
Press the cursor buttons (3 [UP], 4 [DOWN], 1
[LEFT], 2 [RIGHT]) to select menu items. Press
the button at its center to enter the selected item.
6
Selects the input signal. Every time the button is
pressed, the selection rotates in the order of
COMPONENT 1 ➔ COMPONENT 2 ➔ S-VIDEO
➔ VIDEO ➔ RGB ➔ HDMI 1 ➔ HDMI 2.
h COMP. 2 (Component video in 2)
button (☞ P.15)
Selects the device connected to the COMPONENT
VIDEO IN 2 jack as the input source.
j S-VIDEO button (☞ P.15)
Select the S-VIDEO IN signal.
k VIDEO button (☞ P.15)
Select the VIDEO IN signal.
l RGB button (☞ P.15)
Select the RGB IN signal.
¡0 HDMI 1 button (☞ P.15)
Select the HDMI 1 IN signal.
Selects the user mode.
The user mode is for enjoying images at a userselected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 7 ➔ User 8 ➔ User 9.
For more information on how to select gamma
curve. (
P.19)
☞
¡5 ON button (☞ P.15)
¡7 MENU button (☞ P.18)
™8 DYNAMIC (DYN) button (☞ P.18)
Display the on-screen menu.
¡8 ASPECT (Aspect select) button
(☞ P.15)
Selects the aspect ratio. Every time the button is
pressed, the selection rotates in the order of Full ➔
Normal ➔ Zoom ➔ Through.
¡9 FULL button (☞ P.15)
Select FULL mode from four aspect ratio modes.
™0 NORMAL button (☞ P.15)
Select NORMAL mode from four aspect ratio
modes.
™1 ZOOM button (☞ P.15)
¡2 USER 1-3 button (☞ P.18)
Select THROUGH mode from four aspect ratio
modes.
☞
¡3 USER 4-6 button (☞ P.18)
Selects the user mode.
The user mode is for enjoying images at a userselected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 4 ➔ User 5 ➔ User 6.
For more information on how to select gamma
curve. (
P.19)
☞
™7 STANDARD (STD) button (☞ P.18)
Projects a focus pattern on the screen.
¡6 PATTERN button (☞ P.10)
Select ZOOM mode from four aspect ratio modes.
Selects the user mode.
The user mode is for enjoying images at a userselected gamma curve.
Every time the button is pressed, the selection
rotates in the order of User 1 ➔ User 2 ➔ User 3.
For more information on how to select gamma
curve. (
P.19)
Select the Theater picture mode.
Theater mode is designed for high fidelity black
appearance and is good for movie pictures.
Every time THEATER button is pressed, the
selection rotates in the order of Theater 1 ➔
Theater 2 ➔ Theater 3 ➔ Default.
Select the STANDARD picture mode.
Standard mode is good for normal pictures.
Every time the button is pressed, the selection
rotates in the order of Standard 1 ➔ Standard 2 ➔
Standard 3 ➔ Default.
Turn the projector on.
¡1 HDMI 2 button (☞ P.15)
Select the HDMI 2 IN signal.
™6 THEATER (THTR) button (☞ P.18)
™2 THROUGH button (☞ P.15)
™3 CINEMA button
Press to turn the CINEMA mode – auto 3-2 pull
down mode – on or off.
™4 BLANK button
Select the blanking mode. Every time the button is
pressed, the selection rotates in the order of OFF
➔ Memory 1 ➔ Memory 2 ➔ Memory 3.
™5 LIGHT button
Lights up backlit buttons (ON, STANDBY, MENU,
V-MUTE, INPUT, ASPECT, PATTERN) for about 7
sec.
Select the Dynamic picture mode.
Dynamic mode is good for visually dynamic
pictures.
Every time the button is pressed, the selection
rotates in the order of Dynamic 1 ➔ Dynamic 2 ➔
Dynamic 3 ➔ Default.
™9 INFO. button (☞ P.24)
Turn the information menu on or off.
Operate the remote controller within a distance of approximately 5m from the IR sensor (remote sensor)
on the projector.
Remote control operation may not be possible if the remote control unit’s transmitter is not pointing in the
direction of the remote sensor or if there is an obstruction between the transmitter and the remote sensor.
1. Take the cover off the battery case on the
remote control backside.
Battery case cover
5m
Remote
Controller
150
5m
Remote
Controller
Make sure the polarities match the + and –
marks inside the battery compartment.
VP-12S4
AA size batteries
60
5m
Remote
Controller
2. Insert two AA size batteries.
60
60
5m
Remote
Controller
VP-12S4
Remote
Controller
3. Reattach the battery case cover as before.
Battery case cover
5m
Notes :
• Do not mix alkaline and manganese batteries.
• Do not mix old and new batteries.
CAUTIONS ON BATTERIES
• Use “AA” type batteries in this remote
control unit.
• If the remote control unit does not operate
from close to the main unit, replace the
batteries with new ones, even if less then a
year has passed.
• The included battery is only for verifying
operation. Replace it with a new battery as
soon as possible.
• When inserting the batteries, be careful to
do so in the proper direction, following the +
and - marks in the remote control unit’s
battery compartment.
• To prevent damage or battery fluid leakage:
- Do not use a new battery with an old one.
- Do not use two different types of batteries.
- Do not short-circuit, disassemble, heat or
dispose of batteries in flames.
• Remove the batteries when not planning to
use the remote control unit for a long period
of time.
• If the batteries should leak, carefully wipe off
the fluid from the inside of the battery
compartment, then insert new batteries.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules that
apply in your country or area.
60
VP-12S4
7
ENGLISH
Preparing the Remote Controller
Remote Controller Operational Range
ENGLISH
CONNECTION
❖ When making connections be sure to:
• Turn off all equipment before making any connections.
• Use the proper cables for each connection.
• Securely insert the plug into the port to connect cables. Loose cables can lead to trouble and damage.
❖ When pulling out a cable:
• Be sure to grab the plug, not the cable itself.
Connection with Video Equipments
You can connect this projector to a VCR, DVD player and other video equipment.
Connecting a video source using S-VIDEO IN and VIDEO IN terminals.
1.
Connect one of the S-video cable to the S-VIDEO IN terminal, or one end of the video cable to the VIDEO
IN terminal on the projector.
2.
Connect the other end of the S-video cable or the video cable to the S-video output terminal or video
output terminal of the video source.
Connecting a DVD player to the COMPONENT VIDEO IN 1 or 2 terminal
(Devices can be connected to both terminals at the same time.)
1.
Connect the individual terminals of the component video cable into the COMPONENT VIDEO IN 1 or 2
terminal of the projector.
2.
Connect the other end of the cable to the corresponding terminals on a DVD player.
Connection with AC Power Supply
Connect the supplied AC power cord into the AC IN socket of the projector.
The STANDBY indicator lights up and the projector goes into the standby mode.
Component cable
(commercially available)
COMPONENT VIDEO OUT
Note : Make sure the AC power cord is firmly connected into the AC IN socket.
STANDBY
FL OFF
DVD Player
Component cable
(commercially available)
COMPONENT VIDEO OUT
STANDBY
FL OFF
DVD Player
S-video cable (commercially available)
S-VIDEO OUT
VIDEO OUT
Video cable
(commercially available)
8
VCR
You can connect this projector to HD-Video /PC using RGB IN port, or DVD Plyer /Satellite /Cable Tuner
/PC using HDMI IN port.
1. Connect one end of the RGB cable to the RGB IN port, or one end of the HDMI cable to the HDMI IN
port on the projector.
2. Connect the other end to the corresponding port on a HD-Video, Satellite, Cable Tuner or personal
computer.
Advanced Connection
ENGLISH
Connection with a HD-Video, DVD Player, Satellite, Cable Tuner or PC
You can control total home theater system using PC or Marantz receiver equipment.
For installing below system, consult with Marantz authorized dealer.
Screen
Note : When projecting a video image from a device connected to the HDMI terminal, follow the
procedure below.
1. Turn on power of this unit. (
P.15)
2. Set the input video source to HDMI input. (
P.15)
3. Turn on power of the device connected to the HDMI terminal of the unit (i.e. DVD player).
If the procedure above is not followed, projected image may corrupt.
For the details of the HDMI terminal on the device connected with the unit, see the instruction
manual of the device.
☞
RS-232C cable
(straight type,
commercially available)
RS-232C
☞
RGB (D-Sub monitor) cable
(commercially available)
External Controller
3.5mm Mini Plug (Mono)
(commercially available)
RGB out
RGB OUT
or
or
DVI-D
out
DVI-D out
or
HDMI out
HD-Video / Satellite /
Cable Tuner / DVD Player
Control Adapter cable
(commercially available)
REMOTE CONTROL IN
REMOTE CONTROL OUT
Monitor output
RGB
out
RGB OUT
or
or
DVI-D out
DVI-D out
HDMI-HDMI cable or HDMI-DVD-D cable
(commercially available)
Control Adapter cable
(supplied)
Receiver equipment
IBM VGA or
Compatible PC
9
Detail Focusing
ENGLISH
INITIAL SETTING
You can strictly focus the image with focus pattern.
1. Press the PATTERN button to project the focus pattern on the screen.
Turning on the Power
☞ P.8)
1.
2.
STANDBY
Connect the supplied AC power cord. (
Press the ON button on the remote controller or the
ON
PATTERN
/ I button on the projector.
V-MUTE
The ON indicator lights up.
MENU
ENTER
STANDBY
ON
PATTERN
V-MUTE
2.
MENU
Turn the Focus ring to make an adjustment.
Adjust the focus for the sharpest image possible to obtain, using focus pattern.
ENTER
Zooming and Focusing
Project an image on the screen roughly at first.
1. Turn the Zoom ring and adjust to the desired size
within the zoom range.
WIDE: Enlarges (zooms in) the projected image.
TELE: Reduces (zooms out) the projected image.
2.
3.
Press the PATTERN button again to hide the focus pattern. This completes fine focusing.
Turn the Focus ring until the image on the screen
becomes clear.
Note :
WIDE
1.
2.
TELE
10
☞
Changing the Focus Pattern Color According to Lens Position (
P.14)
The focus pattern changes color depending on the lens position. There are two colors and they can
be used for checking the quality of the projected image. The white focus pattern uses the highest
optical performance to maximize the sharpness of the projected image. To enjoy the highest
sharpness, it is recommended to position the lens within this range.
When the lens is shifted outside the aforementioned range, the focus pattern turns green. Rough
focusing in this range looses image sharpness.
Adjusting the zoom position from WIDE to TELE enhances sharpness even at the same lens
position. However, the focus pattern does not change when the zoom position is changed.
Adjusting the Height
You can adjust the image position with the Lens Shift knob.
❖ Turn the Lens Shift knob to clockwise : The image goes up.
Counterclockwise
ENGLISH
Adjusting the Image Position
You can position the projected image by changing the
height of the projector’s adjusters.
1. Move the adjuster lever to the left or right to
enable adjuster changing. Carefully lift the
projector.
2.
Once having positioned the projector, return the
adjuster lever as before to lock in place. Check
the adjusters are securely locked before
releasing your hands from the projector.
3.
Turn the adjuster to fine-adjust the height.
Up
❖ Returning the Projector to its Initial Position
Slightly lift the projector, turn the adjuster lever to the left or right, then carefully set the projector down.
❖ Turn the Lens Shift knob to counterclockwise : The image goes down.
Clockwise
Keystone Correction
When the projecting image is a trapezoid, correct it in Keystone and in the Display Menu.
P.22)
See “Display”. (
☞
❖ Keystone
(Electronic keystone correction)
Down
11
Recommended Setting
❖ Mounting on the ceiling
❖ Installing on a tabletop
Screen
Screen
Screen upper end
Screen upper end
Range from light axis to upper end
Height from installing
level to light axis
Screen size (vertical)
Lens shift
range
Range from light axis to upper
end
Lens shift range
Light axis (center)
Screen size (vertical)
ENGLISH
INSTALLATION
Light axis (center)
Installing level
Screen lower end
Height from installing level to light axis
Screen lower end
Projection distance
Projection distance
lens head
lens head
CAUTION
– For ceiling installation, consult with Marantz authorized dealer.
– Do not look into the lens when the projector is turned on. It could damage your eyesight.
12
Screen Size and Projection Distance (inch) VP-12S4
ENGLISH
Screen
Screen size
(Diagonal)
Screen
Screen size
(Diagonal)
Screen Size and Projection Distance (mm) VP-12S4
VP-12S1
VP-12S1
Projection distance
16:9 Screen Size (1.77:1 Aspect Ratio)
In case of displaying the 16:9
picture on the whole of the
16:9 screen.
Height
Width
: Image size = Screen size
Projection Distance
Diagonal
Width
Height
Minimum
Maximum
inch
inch
inch
inch
inch
60
70
72
80
82
84
90
92
100
106
110
120
123
133
135
150
170
200
250
52 5/16
61
62 3/4
69 3/4
71 1/2
73 3/16
78 7/16
80 3/16
87 3/16
92 3/8
95 7/8
104 9/16
107 3/16
115 15/16
117 11/16
130 3/4
148 3/16
174 5/16
217 7/8
29 7/16
34 5/16
35 5/16
39 1/4
40 3/16
41 3/16
44 1/8
45 1/8
49
51 15/16
53 15/16
58 13/16
60 5/16
65 3/16
66 3/16
73 9/16
83 6/16
98 1/16
122 9/16
89 9/16
104 13/16
107 14/16
120 2/16
123 3/16
126 3/16
135 6/16
138 7/16
150 10/16
159 13/16
165 15/16
181 3/16
185 13/16
201 1/16
204 2/16
227 1/16
257 9/16
303 7/16
379 13/16
130 13/16
152 15/16
157 3/8
175 1/16
179 1/2
183 15/16
197 3/16
201 5/8
219 5/16
232 5/8
241 7/16
263 9/16
270 1/4
292 3/8
296 3/4
329 15/16
374 1/4
440 5/8
551 1/4
❖ 16 : 9 Screen
16:9 Screen Size (1.77:1 Aspect Ratio)
In case of displaying the 16:9
picture on the whole of the
16:9 screen.
Width
Height
❖ 16 : 9 Screen
Projection distance
: Image size = Screen size
Height
Width
: Image size
: Screen size
Projection Distance
Diagonal
Width
Height
Minimum
Maximum
inch
inch
inch
inch
inch
82
96 1/16
98 7/8
110 1/16
115 11/16
124 1/16
138 1/8
152 1/8
166 1/8
208 3/16
236 1/4
250 1/4
278 5/16
348 7/16
119 15/16
140 1/4
144 5/16
160 9/16
168 11/16
180 7/8
201 3/16
221 1/2
241 13/16
302 11/16
343 5/16
363 5/8
404 1/4
505 13/16
60
36
48
70
42
56
72
43 3/16
57 5/8
80
48
64
84
50 3/8
67 3/16
90
54
72
100
60
80
110
66
88
120
72
96
150
90
120
170
102
136
180
108
144
200
120
160
250
150
200
To calculate the installation measurement (unit : inch)
Minimum = 1 3/8 x Screen Size - 1 7/8
Maximum= 2 x Screen Size - 1 15/16
Note : Tolerance ± 5%
❖ 4 : 3 Screen
Height
Minimum
inch
mm
mm
mm
mm
60
70
72
80
82
84
90
92
100
106
110
120
123
133
135
150
170
200
250
1328
1550
1594
1771
1815
1860
1992
2037
2214
2347
2435
2657
2723
2944
2989
3321
3763
4428
5535
747
872
897
996
1021
1046
1121
1146
1245
1320
1370
1494
1532
1656
1681
1868
2117
2491
3113
2275
2663
2740
3051
3128
3206
3439
3516
3827
4059
4215
4603
4719
5107
5185
5767
6543
7707
9647
3323
3885
3998
4447
4560
4672
5009
5122
5571
5908
6133
6695
6864
7426
7538
8381
9505
11191
14001
4:3 Screen Size (1.33:1 Aspect Ratio)
In case of displaying the 16:9
picture on the whole of the 4:3
screen.
Width
Height
4:3 Screen Size (1.33:1 Aspect Ratio)
In case of displaying the 16:9
picture on the whole of the 4:3
screen.
Width
Maximum
To calculate the installation measurement (unit : mm)
Minimum = 38.8 x Screen Size - 53.4
Maximum= 56.2 x Screen Size - 48.8
Note : Tolerance ± 5%
To calculate the installation measurement (unit : inch)
Minimum = 1 1/2 x Screen Size - 1 7/8
Maximum= 2 3/16 x Screen Size - 1 15/16
Note : Tolerance ± 5%
❖ 4 : 3 Screen
Projection Distance
Diagonal
: Image size
: Screen size
Projection Distance
Diagonal
Width
Height
Minimum
inch
mm
mm
mm
mm
2083
2440
2511
2796
2938
3152
3508
3864
4220
5289
6001
6357
7069
8850
3046
3562
3665
4078
4284
4594
5110
5626
6141
7689
8721
9236
10268
12847
914
1219
60
1067
1422
70
1097
1463
72
1219
1626
80
1280
1707
84
1372
1829
90
1524
2032
100
1676
2235
110
1829
2438
120
2286
3048
150
2591
3454
170
2743
3658
180
3048
4064
200
3810
5080
250
To calculate the installation measurement (unit : mm)
Minimum = 35.61 x Screen Size - 53.4
Maximum= 51.58 x Screen Size - 48.8
Note : Tolerance ± 5%
Maximum
13
Lens shift position
❖ Extended mounting condition (From +170% to +200%)
Screen Position
(+100%)
+170%
0.85H
Up
VP-12S4
0% (Center)
VP-12S1
0.15H Up More
Focus pattern color: Green
+200%
Screen Position
+170%
Focus pattern color: White
ENGLISH
❖ Standard condition (From -100% to +170%)
VP-12S4
0% (Center)
VP-12S1
0.5H
Down
-100%
About Extended mounting conditions
The VP-12S4 has a very flexible lens shift arrangement that allows mounting the projector above the
screen possibly eliminating the need for a mounting pole. For the VP-12S4 the projector can be mounted
15% of the height of the screen(=0.15H)* above the top of the viewable portion. For extended mounting
Screen Height = 1H
conditions, the lens can be shifted even farther (170% → 200%). However if these values are used, optical
performance may suffer slightly. This could manifest itself as chromatic aberration (minor color fringing)
and/or geometric distortion.
If the projector is used in the extended mounting conditions, the focus pattern will be displayed in Green.
*the height of the screen=1H
14
• Press the ZOOM button, the NORMAL button or the FULL button on the remote controller for the 4:3
aspect ratio video source.
• Press the FULL button on the remote controller for 16:9 aspect ratio video source, such as 1080i,
1035i, and 720p video systems.
• Press the FULL button on the remote controller for the squeezed video source.
Turning on the Power
Press the ON button on the remote controller or the
The ON indicator lights up.
/ I button on the projector.
❖ Original Source Image
16 : 9 video source
STANDBY
4 : 3 video source
ON
PATTERN
V-MUTE
MENU
ENTER
❖ Full mode
The 16:9 squeezed image is displayed with the
correct aspect.
Selecting the Input Signal Source
Switch to the equipment connected to the projector.
Pressing the INPUT button on the projector or remote control rotates the input signal in the order of
COMPONENT1 ➔ COMPONENT2 ➔ S-VIDEO ➔ VIDEO ➔ RGB ➔ HDMI 1 ➔ HDMI 2, allowing you to
select an input signal. An input signal can also be directly selected by pressing one of the COMP.1,
COMP.2, S-VIDEO, VIDEO, RGB, HDMI 1 and HDMI 2 buttons on the remote control.
The 4:3 image is enlarged horizontally.
❖ Normal mode
The picture in normal ratio 4:3 is displayed.
INPUT
COMP.
1
ASPECT
THEATER
THTR
FULL
F
Select a key
STANDARD NORMAL
2
STD
S-VIDEO
DYNAMIC
N
ZOOM
S
DYN
Z
VIDEO
USER
THROUGH
V
1-3
RGB
RGB
BLANK
7-9
INFO.
2
The picture in normal ratio 4:3 is enlarged vertically
and horizontally (with same ratio) to the screen size
4-6
HDMI
1
❖ Zoom mode
T
CINEMA
LIGHT
i
Selecting the Aspect Mode
You can select 4 kinds of ASPECT mode using remote controller.
Pressing the ASPECT button on the remote control rotates the
aspect ratio in the order of FULL ➔ NORMAL ➔ ZOOM ➔
THROUGH, allowing you to select an aspect ratio. An aspect ratio
can also be directly selected by pressing one of the FULL,
NORMAL, ZOOM and THROUGH buttons on the remote control,
or it can be selected from the menu. (
P.19)
☞
INPUT
COMP.
1
ASPECT
THEATER
FULL
THTR
F
STANDARD NORMAL
2
STD
N
S-VIDEO
DYNAMIC
ZOOM
S
DYN
Z
VIDEO
USER
THROUGH
V
1-3
RGB
RGB
HDMI
❖ Through mode
Select a key
It shows an image when the video source has the same resolution to RGB/video signal with 720 or less
vertical pixel number.
T
CINEMA
4-6
BLANK
15
ENGLISH
The Screen Images in a 16:9 screen
BASIC OPERATIONS
The Screen Images in a 4:3 screen
To Turn off the Power
ENGLISH
• Press the ZOOM button, the NORMAL button or the FULL button on the remote controller for the 4:3
aspect ratio video source.
• Press the FULL button on the remote controller for 16:9 aspect ratio video source, such as 1080i,
1035i, and 720p video systems.
• Press the FULL button on the remote controller for the squeezed video source.
1.
2.
Press the STANDBY button on the remote controller or the
/ I button on the projector.
The fan continues running for about 1 minute to internally cool the projector. In the meantime, the ON
indicator on the projector flashes a blue color and buttons on the projector and remote control are
irresponsive to touch. Once the fan stops, the ON indicator goes out and the STANDBY indicator
lights up a red color to indicate the projector is on standby.
❖ Original Source Image
16 : 9 video source
4 : 3 video source
STANDBY
ON
PATTERN
V-MUTE
MENU
ENTER
❖ Full mode
The 16:9 squeezed image is displayed with the
correct aspect.
The 4:3 image is enlarged horizontally.
❖ Normal mode
The picture in normal ratio 4:3 is displayed.
❖ Zoom mode
The picture in normal ratio 4:3 is enlarged
vertically and horizontally (with same ratio) to the
screen size
❖ Through mode
It shows an image when the video source has the same resolution to RGB/video signal with 720 or less
vertical pixel number.
16
Notes :
- Do not pull out the AC power cord until the projector turns in standby mode.
- Do not pull out the power cord suddenly in the state of “POWER ON." It can cause a breakdown.
- When a WARNING indicator lit up or blinks in red, pull out the AC power cord after checking that the
fan has stopped.
- The projector will not be turned on if the ON button on the remote controller or the
/ I button on
the projector is pressed immediately after turning off. Press the ON button on the remote controller
or
/ I button on the projector after the projector turns into standby mode.
- When on standby, power to the projector is not OFF completely. If not planning to use the projector
for an extended period of time, unplug the AC power cord from AC power outlet as explained above.
Main Menu
Menu Structure
Input Signal
P.21
Main Menu
Picture Mode
P.18
Item
Auto*
720p
480i/576i
1035i
480p
Theater
Default* / 1 / 2 / 3
1080i
540p
Standard
Default* / 1 / 2 / 3
1080p
576p
Dynamic
Default* / 1 / 2 / 3
User
Picture Adjust
Main Menu
Item
Component 1
Component 2
1* / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9
480i/576i
A
1035i
480p
Theater
B
1080i
540p
Standard
C
1080p
576p
P.19
D
Dynamic
S-Video
–50
0*
50
PAL
Brightness
–50
0*
50
SECAM
Color
–50
0*
50
R50
0*
Memory3
Readjust
Yes / No*
Resolution H
–5
0*
20
Resolution V
–5
0*
20
Position H
–5
0*
5
Position V
–5
0*
5
Phase
–10
0*
10
Clamp Position
–50
0*
50
Clamp Width
–50
0*
50
0*
50
NTSC
Contrast
Tint
Auto*
Memory1
Memory2
Auto*
E
Item
Mode
P.21
Auto*
720p
Gamma
RGB/HD Adjust
ENGLISH
OPERATIONS
Video
1 / 2 / 3 / 4 / 5 / HB
Lamp Mode
Normal* / Economy
P.22
Auto*
G50
Color Temp.
Display
NTSC
PAL
SECAM
Keystone
–50
Scale
–100
0*
Width
–100
0*
Position H
–50
0*
50
Position V
–50
0*
50
Installation
F +Front*
Ceiling
R +Rear
Ceiling
Iris
F5.0* / F3.0
Auto*
F + Ceiling
720p
480i/576i
R + Ceiling
1035i
480p
1080i
540p
1080p
576p
RGB
Aspect
Full*
Normal
Zoom
Through
Fine Menu 1
P.20
Sharpness
Noise Reduction
R Gain
Fine Menu 2
P.20
–25
0*
0*
–50
25
0*
50
G Gain
–50
0*
50
B Gain
–50
0*
50
R Bias
–50
0*
50
G Bias
–50
0*
50
B Bias
–50
0*
50
Cinema
On / Off*
FRC
1080i
480p
Português
Deutsch
Italiano
Français
Español
Auto*
1035i
480i/576i
1080i
480p
1080p
576p
Enable* / Disable
Power-OFF Confirm.
Enable / Disable*
Blanking Memory
Off* / 1 / 2 / 3
0*
Blanking Bottom
0*
100
Auto*
Blanking Left
0*
100
RGB
Blanking Right
0*
100
YC
CR
PB P
Luminance Gain
–50
0*
50
Y CB CR
Config. (Configuration)
Auto Power OFF
100
Enable / Disable*
Trigger 2 Full
On* / Off
Trigger 2 Normal
On* / Off
Y RGB
PB PR
Trigger 2 Zoom
On* / Off
PB P
YC
CR
Trigger 2 Through
Y CB CR
Remote Control
P.23
CSC HDMI2
Status Info.
Blanking Top
50
5
English*
576p
0*
0*
Center
Language
720p
–50
–5
Center-L
Bottom
Picture Shift V
Chroma Delay
* Default setting
Auto* / On
Top-R
Bottom-R
720p
CSC HDMI1
Top
Bottom-L
Auto*
0 IRE* / 7.5 IRE
During HDMI input, “Normal” or “Expand” is shown.
Center-R
480i/576i
HDMI2
Top-L*
Menu Position
P.22
1035i
1080p
Auto* / Off
VCR Mode
Black Level
HDMI1
50
OSD/Blanking
Auto*
On* / Off
Wireless* / Wired
Color Temp. Calibration
Yes / No
Reset Lamp Life
Yes / No
Reset All
Yes / No
17
Picture Mode
How to Operate Menus
ENGLISH
This unit has four picture modes: Theater, Standard, Dynamic and User. The picture quality recommended
by Marantz is already set for each mode. The User mode has eight gamma curves that can be chosen and
saved by users. Also, the Theater, Standard and Dynamic modes three indexes for memorizing picture
quality adjustments. Similarly, the User mode has nine, making a total of 18 indexes available for use.
This projector has menus that make setting and adjustment easy.
1. Press the MENU button. The MENU screen appears on the screen.
User 1
Standard 1
Picture Adjust
Theater
Default
Fine Menu 1
Standard
1
Fine Menu 2
Dynamic
Default
Input Signal
User
1
RGB/HD Adjust
Picture Adjust
Gamma
Fine Menu 1
Contrast
0
B
Fine Menu 2
Brightness
0
C
Input Signal
Color
0
D
RGB/HD Adjust
Tint
0
Display
Color Temp.
3
Theater
OSD/Blanking
Lamp Mode
Normal
Standard
Config.
Iris
F5.0
Dynamic
Aspect
Full
Display
A
A
E
OSD/Blanking
Config.
Main menu
Picture mode
Index
Theater
Standard
Dynamic
User
Default, 1, 2, 3
Default, 1, 2, 3
Default, 1, 2, 3
1, 2, 3, 4, 5, 6, 7, 8, 9
Menu item
Setting or adjustment level
2.
Use the 3 and 4 buttons to select a menu (Picture Adjust, Fine Menu 1, Fine Menu 2, Input Signal,
RGB/HD Adjust, Display, OSD/Blanking, Config) and press the 2 button.
3.
4.
Use the 3 and 4 buttons to select a menu item and press the 2 button.
☞ P.18)
For image mode selection, see “Picture Mode”. (
– Theater: Reproduces the black suited for movie software.
5.
– Standard: Suited for normal movie software.
Use the 3, 4, 1 and 2 buttons to make the setting or adjustment of the selected item.
• The current setting or adjustment level is displayed to the right of each menu item.
Press the MENU button again to close the menu.
– Dynamic: Suited for visually dynamic image software.
☞ P.19).
2, 3, 4 1, 5
– User 1-9: Enable the user to adjust the gamma curve as preferred. (
1, 5
V-MUTE
MENU
Picture mode selection
There are two ways to select the Picture mode: selecting a mode from the MENU screen or pressing
the picture mode buttons (THEATER, STANDARD, DYNAMIC or USER) on the remote controller. To
use the remote controller buttons to select a picture mode, make sure the MENU screen does not
P.6)
appear on the screen and press the desired picture mode button any number of times. (
To select an picture mode from the menu, do as follows.
1. Press the MENU button. The MENU screen appears on the screen.
2. Use the 3 and 4 buttons to select “Picture Mode” along the top of the menu.
3. Press the ENTER button to display the picture mode selection screen. Use the 3, 4, 2 and 1
buttons to select an picture mode.
4. Press the ENTER button to decide the selected picture mode. Once the mode has been
entered, the screen returns to the previous menu.
2, 3, 4
ENTER
☞
Memorizing settings in an index
The settings made in “Picture Adjust” and “Fine Menu 1” of the main menu are automatically
memorized in the currently selected picture mode. Therefore, first select an picture mode and index,
and then make settings.
Note : When default is selected, “Picture Adjust” and “Fine Menu 1” cannot be selected from the menu.
18
INPUT
ASPECT
– Adjustment bar
When there is a “ ” right of a menu item, this 2 acts as a button for engaging an adjustment mode. In
the adjustment mode, the menu disappears and only an adjustment bar, like that shown below,
appears along the bottom of the display. Use the 1 and 2 buttons to adjust the item to the desired
level. Press the 3 button to return to the menu.
Contrast
0
– Gamma setting
p.18) to User (1 – 9). Select “Gamma”
To change the type of Gamma curve, set the Picture Mode (
and the desired gamma curve (A, B, C, D, E, Theater, Standard, Dynamic).
Picture quality in each of the picture modes can be adjusted to your liking and those adjustments can be
saved in memory.
A
B
C
D
E
Theater
Dynamic
User 1
Picture Adjust
Gamma
Fine Menu 1
Contrast
0
B
Fine Menu 2
Brightness
0
C
Input Signal
Color
0
D
RGB/HD Adjust
Tint
0
Display
Color Temp.
3
Theater
OSD/Blanking
Lamp Mode
Normal
Standard
Config.
Iris
F5.0
Dynamic
Aspect
Full
Item
Gamma
Contrast
Brightness
Color
Tint
Color Temp.
(Color Temperature)
Lamp Mode
A
A
E
Adjustments
A, B, C, D, E, Theater,
Standard, Dynamic
-50 Ô 0 Ô 50
(Weak) (Default) (Strong)
-50 Ô 0 Ô 50
(Dark)
(Default) (Bright)
-50 Ô 0 Ô 50
(Light)
(Default) (Deep)
R50 Ô 0 Ô G50
(Purple) (Default) (Green)
1
2 3 4 5 HB
(Red)
(Blue)
Normal, Economy
Iris
F5.0, F3.0
Sets the lens aperture.
F5.0: Use to prioritize contrast.
F3.0: Use to prioritize brightness.
Aspect
Full, Normal, Zoom, Through
Theater
Standard
Dynamic
– Color Temp. (Color Temperature)
1:
2:
3:
4:
5:
HB :
Red comes out strong. Color temperature is about 5250 K.
Red is mildly strong. Color temperature is about 5800 K.
Normal. Color temperature is about 6500 K.
Blue is mildly strong. Color temperature is about 7500 K.
Blue comes out strong. Color temperature is about 9300 K.
High Bright : Display brightest image.
NOTES:
P.18)
- To adjust picture quality, set the index to 1 - 3. See “Picture Mode”. (
P.18).
- The Gamma cannot be set unless User (1 - 9) is set for the Picture Mode (
- Tint cannot be adjusted for component input, HDMI input or PAL signals.
- The settings made in Picture Adjust are saved in the currently selected Picture Mode index.
☞
☞
19
ENGLISH
☞
Picture Adjust
Fine Menu 1
Fine Menu 2
ENGLISH
By adjusting this Fine Menu, you can make fine picture adjustment.
Standard 1
Picture Adjust
Cinema
Auto
Picture Adjust
Sharpness
0
Fine Menu 1
VCR Mode
On
Fine Menu 1
Noise Reduction
0
Fine Menu 2
Black Level
0 IRE
Fine Menu 2
R Gain
0
Input Signal
FRC
Input Signal
G Gain
0
RGB/HD Adjust
Picture Shift V
0
RGB/HD Adjust
B Gain
0
Display
Luminance Gain
0
Display
R Bias
0
OSD/Blanking
Chroma Delay
0
OSD/Blanking
G Bias
0
Config.
Config.
B Bias
0
Standard 1
Item
Sharpness
Noise Reduction
R Gain
G Gain
B Gain
R Bias
G Bias
B Bias
-25
0
-50
-50
-50
-50
-50
-50
Adjustments
Ô 0 Ô 25
50
Ô 0 Ô 50
Ô 0 Ô 50
Ô 0 Ô 50
Ô 0 Ô 50
Ô 0 Ô 50
Ô 0 Ô 50
– Sharpness
Adjust the sharpness.
– Noise Reduction
Adjust the noise reduction.
– R Gain
This menu allows the users to set the gain for red.
– G Gain
This menu allows the users to set the gain for green.
– B Gain
This menu allows the users to set the gain for blue.
– R Bias
This menu allows the users to set the bias for red.
– G Bias
This menu allows the users to set the bias for green.
– B Bias
This menu allows the users to set the bias for blue.
Note :
• The settings made in Fine Menu 1 are saved in the currently selected Picture Mode index (Default
excluded).
Item
Cinema
VCR Mode
Black level
FRC
Picture Shift V
Luminance Gain
Chroma Delay
Auto
Adjustments
Auto, Off
On, Off
0 IRE, 7.5 IRE /Normal, Expand (For HDMI input)
Auto, On
-50
Ô
0
Ô
50
-50
Ô
0
Ô
50
-5
Ô
0
Ô
5
– Cinema
Auto : Automatically selects the cinema mode when a video signal is input.
NTSC: 3-2 pull down, PAL: 2-2 pull down
Off :
Pull-down processing is not performed.
– VCR Mode
On :
A projector is forced into the intra-field only deinterlacing mode.
Off :
A projector is used with external field memories and operates in the full set of deinterlacing
modes, i.e., motion adaptive video deinterlacing and full frame film source deinterlacing
using 3:2 pulldown detection (2:2 pulldown for 625/50 sources).
– Black level
Select the black level by a video source.
– FRC (Frame Rate Conversion)
Auto : Frame Rate Conversion function is basically off. However FRC turns on automatically
depending on vertical frequency of input signal.
On :
Frame Rate Conversion function is “On”. (60Hz fixed)
– Picture Shift V
When Aspect on the Picture Adjust menu is set to “Zoom”, this setting allows the user to move the
projected image vertically in order to see parts on the image not appearing on the screen.
– Luminance Gain
This menu allows the users to set the luminance gain.
– Chroma Delay
This menu allows the users to set the chrominance delay.
Notes :
• There are some parameters can not adjust according to input signal.
• The settings made in Fine Menu 2 are saved in each currently selected input signal source.
20
RGB/HD Adjust
Standard 1
Standard 1
Picture Adjust
Component 1
Auto
Picture Adjust
Fine Menu 1
Component 2
Auto
Fine Menu 1
Readjust
Fine Menu 2
S-Video
Auto
Fine Menu 2
Resolution H
0
Input Signal
Video
Auto
Input Signal
Resolution V
0
RGB/HD Adjust
RGB
Auto
RGB/HD Adjust
Position H
0
Display
HDMI1
Auto
Display
Position V
0
OSD/Blanking
HDMI2
Auto
OSD/Blanking
Phase
0
Config.
CSC HDMI1
Auto
Config.
Clamp Position
0
CSC HDMI2
Auto
Clamp Width
0
Item
Component1,
Component2
S-Video
Video
RGB
HDMI 1, HDMI 2
CSC HDMI 1,
CSC HDMI 2
Adjustments
Auto, 480i/576i, 480p, 540p, 576p,
720p, 1035i, 1080i, 1080p
Auto, NTSC, PAL, SECAM
Auto, NTSC, PAL, SECAM
Auto, 480i/576i, 480p, 540p, 576p,
720p, 1035i, 1080i, 1080p
Auto, 480i/576i, 480p, 576p, 720p,
1035i, 1080i, 1080p
Auto, RGB, YPBPR, YCBCR
Color space conversion select for HDMI
input.
RGB: Color Space Conversion is
skipped.
YPBPR: This mode is suitable for HD TV
signal such a 720p, 1080i.
YCBCR: This mode is suitable for SD TV
signal such a 480i, 480p.
NTSC(NTSC-3.58)
: Conventional analog broadcasting used
mainly in USA, Canada, Taiwan, Korea, and
Japan.
PAL(PAL-4.43)
: Conventional analog broadcasting used
mainly in United Kingdom and Germany.
SECAM
480p
540p
ENGLISH
Input Signal
: Conventional analog broadcasting used
mainly in France and Russia.
: Standard digital broadcasting
: Special digital broadcasting
(for example: RCA DTC100)
576p
: Standard digital broadcasting
720p, 1080p : High Definition digital broadcasting
1035i
: Japanese "Hi-Vision" broadcasting
Item
Mode
Readjust
Resolution H
Resolution V
Position H
Position V
Phase
Clamp Position
Clamp Width
123
Mode
Memory 1
Adjustments
Auto, Memory 1, Memory 2, Memory 3
Yes, No
-5 Ô 0 Ô 20
(Small) (Default) (Large)
-5 Ô 0 Ô 20
(Small) (Default) (Large)
-5 Ô 0 Ô 5
(Left)
(Default)
(Right)
-5 Ô 0 Ô 5
(Down) (Default)
(Up)
-10 Ô 0 Ô 10
(Backward) (Default) (Forward)
-50 Ô 0 Ô 50
(Backward) (Default) (Forward)
-50 Ô 0 Ô 50
(Small) (Default) (Large)
– Mode
Auto:
Each item is adjusted automatically.
Memory1-3: If something wrong with Auto Adjust, select Memory, please adjust each item manually.
– Readjust
Select to readjust settings automatically for each item in this menu.
– Resolution H, V
Adjusts the horizontal and vertical resolution of the RGB/HD input signals.
– Position H, V
Adjust the position of the input signal. H adjusts the horizontal position of the input signal. V adjusts the
vertical position of the input signal.
– Phase
Adjust the phase of the DMD dots and the computer signal input from the RGB IN. Adjust the picture
to where it looks clearest.
– Clamp Position, Width
Adjusts the clamp position and width used in RGB/HD input.
21
Display
OSD/Blanking
ENGLISH
Standard 1
Standard 1
Fine Menu 1
Keystone
0
Picture Adjust
Menu Position
Top-L
Fine Menu 2
Scale
0
Fine Menu 1
Language
English
Input Signal
Width
0
Fine Menu 2
Status Info.
Enable
RGB/HD Adjust
Position H
0
Input Signal
Power-OFF Confirm. Enable
Display
Position V
0
RGB/HD Adjust
Blanking Memory
OSD/Blanking
Installation
Display
Blanking Top
0
OSD/Blanking
Blanking Bottom
0
Config.
Blanking Left
0
Blanking Right
0
Front
Config.
Item
Keystone (Electronic vertical
keystone correction)
Scale
Width
Position H
Position V
Installation
Item
Menu Position
Adjustments
-50
(
0
)
(
50
)
(
)
-100
0
(Min)
(Max)
-100
0
(Min)
(Max)
-50
0
50
(Left) (Default) (Right)
-50
0
50
(Down) (Default) (Up)
Status Info.
Power-OFF Confirm.
Blanking Memory
Blanking Top
Blanking Bottom
Blanking Left
Blanking Right
Front, Rear, F+Ceiling,
R+Ceiling
– Keystone
Adjust trapezoid image to rectangle image.
– Scale
Reduces the image without changing the aspect ratio. The image can be reduced to about 70% the
original size.
– Width
Reduces the image width without changing the image height. The width can be reduced to about 75%
the original size.
– Position H, V
Adjust the position of the input signal. H adjusts the horizontal position of the input signal. V adjusts the
vertical position of the input signal.
However, when Scale and Width are set to their default settings, the picture position cannot be
adjusted.
– Instllation
Sets the installation mode of the projector.
Front: Select to set the projector on a tabletop and project from in front of the screen.
Rear: Select to set the projector on a tabletop and project from behind the screen.
22
Language
Memory 1
Adjustments
Top-L, Top, Top-R, Center-L, Center, Center-R,
Bottom-L, Bottom, Bottom-R
English, Deutsch, Français, Español,
Português, Italiano
Enable, Disable
Enable, Disable
Off, Memory 1, Memory 2, Memory 3
0
100
0
100
0
100
0
100
– Menu Position
OSD position is selected from 9 positions.
– Status Info.
Enable: Displays the current status of the projector for a set amount of time in the upper right-hand
corner of the screen at startup and whenever the Input Source, Picture Mode, Aspect ratio or
other setting is changed.
Disable: Does not display Status Info.
– Power-OFF Confirm.
Disable: Directly puts the projector on standby without displaying the confirmation message when power
is shut off from the
button on the remote controller or the /I button on the projector.
Enable:
Displays a confirmation message asking whether to shut the power off or continue use
when power is shut off from the
button on the remote controller or the /I button on the
projector. To shut off the power immediately, select “Yes” and press the ENTER button. To
not shut off the power, select “No” and press the ENTER button.
– Blanking Memory
Sets the blanking mode with which part of the screen can be hidden in black bands. To use this mode
or change the setting, select from Memory 1 to 3.
F + Ceiling: Select to mount the projector on the ceiling and project from in front of the screen.
Off:
Turns the blanking mode off. No masking occurs.
R + Ceiling: Select to mount the projector on the ceiling and project from behind the screen.
Memory 1-3:
Memorize the blanking width of the top, bottom, left and right masks set with the
below features. Up to three settings can be memorized.
– Blanking Top, Bottom, Left and Right
Set the blanking width of the top, bottom, left and right masks, which are then memorized in Memory 1
– 3 of Blanking Memory. Each can be set from 0 (no mask) to a maximum 100.
Standard 1
Picture Adjust
Auto Power Off
Enable
Fine Menu 1
Trigger 2 Full
On
Fine Menu 2
Trigger 2 Normal
On
Input Signal
Trigger 2 Zoom
On
RGB/HD Adjust
Trigger 2 Through
On
Display
Remote Control
OSD/Blanking
Color Temp.Calibration
Config.
Reset Lamp Life
Notes:
- To prevent misoperation, the ENTER button of the remote controller does not respond to touch
when the Wired/Wireless setting is displayed. Press the ENTER button of the projector to enter the
setting.
- To change from Wired to Wireless, set “Wireless” from the menu using the buttons of the projector.
Reset All
Item
Auto Power Off
Trigger 2 Full
Trigger 2 Normal
Trigger 2 Zoom
Trigger 2 Through
Remote Control
Color Temp. Calibration
Reset Lamp Life
Reset All
Adjustments
Enable, Disable
On, Off
On, Off
On, Off
On, Off
Wireless, Wired
Yes, No
Yes, No
Yes, No
– Auto Power Off
When the auto power off feature is set to Enable, power
to the projector automatically shuts off if no signals are
received and no operations are performed for about 10
consecutive minutes. If 9 minutes pass without the
projector receiving any signals or being operated in
anyway, the below message appears on the screen.
– Color Temp. Calibration
After replacing the lamp or in other cases where the
lighting changes, color temperature can be adjusted
using the color temperature sensor. For more information
on how to adjust color temperature, see “Color
P.26).
Temperature Adjustment” (
☞
Auto Power Off
– Reset Lamp Life
If the lamp is replaced before reaching its 2000 hours
lamp life, be sure to reset the lamp’s life counter. To do
this, select “Reset Lamp Life” from the Configuration
menu. When the user selects this item, the following
message appears:
Select “Yes”, and press the ENTER button. Then the
lamp life is initialized.
Color Temp. Calibration?
Yes
No
Reset Lamp Life ?
Yes
No
It will be standby mode soon.
About 1 minute after the message appears on the screen, power to the projector shuts off.
Note:
After the above message appears on the screen, pressing any button on the projector or remote
control other than the
/ I button on the projector and the ON or STANDBY buttons on the remote
control resets the auto power off feature.
The auto power off feature will activate again if, after that, the projector goes without receiving any
signals or being operated in anyway for 10 consecutive minutes.
– Reset All
All settings are reset to the factory default settings except
the lamp life.
When the user selects this item, the following message
appears:
Select “Yes”, and press the ENTER button.
Reset All ?
Yes
No
– Tigger 2
Select either 12V output or 0V output by choosing On or Off for each aspect mode. Full, Normal,
Zoom, and Through.
This allows you to control such as a powered dual aspect screen with the outputs for the aspect
modes.
On: Output DC 12V.
Off: No output.
23
ENGLISH
– Remote Control
Wireless: Set to use the included remote controller.
Wired:
Set to control the projector from either Marantz’s AV components connected to the
REMOTE CONTROL IN/OUT terminals or a PC or other device connected to the RS232C terminal of the projector. The included remote controller cannot be used in this case.
When this item is selected, a confirmation message appears asking whether to change the currently
selected mode to the other mode or not. To change the mode, select “Yes” and press the ENTER
button on the projector. To keep the same mode, select ‘No” and press the ENTER button.
Configration
❖ Initialize the Lamp Life
ENGLISH
MAINTENANCE
Lamp Life and Replace Lamp
❖ Lamp Life
– When the lamp life becomes less than 100
hours and the unit is still on, the remaining
lamp life is displayed on the screen
automatically.
Display the remaining lamp life by pressing the
INFO. button on the remote controller.
The lamp has a lamp life of 2000 hours. The
projector is designed to shut OFF power if the lamp
is used beyond this 2000 hours lamp life. In such
case, replace the lamp and reset the lamp life
counter as follows.
1.
After the message “Lamp Life 0 Hours”
appears, power to the projector shuts OFF.
Promptly replace the lamp with a new one.
(
P.24 “Replacing Lamp Unit”)
2.
Once the lamp has been replaced, press the
ON button on the remote control or the
/I
button on the projector.
☞
Warning
Lamp Life 100 Hours
Information
Video Input
Component 2 -480p
Picture Mode
User 1
Gamma
A
Aspect
Normal
Lamp Mode
Economy
Iris
F5.0
Lamp Life
921 Hours
Total Time
3653 Hours
The below message appears on the screen
for 120 seconds.
– When the lamp life becomes less than 5 hours,
the remaining lamp life is displayed on the
screen .
Yes
G
BLANK
7-9
INFO.
2
❖ How to replace the Lamp Unit
No
46
HDMI
1
CAUTION:
• Do not touch the lamp and the lamp unit
carelessly. It is extremely hot. Wait at least
one hour for the lamp to cool down before
handling.
• Do not loosen any screws except for those
mentioned below.
• The lamp may break if handled improperly.
• Do not use other than a Marantz
replacement lamp unit.
PREPARATION:
When replacing the lamp, turn off the power for
the projector. After the cooling fan stops,
disconnect the power cord and wait for one
hour until the lamp is cooled down completely,
then replace the lamp.
New Lamp ?
Warning
Replacing Lamp Unit
Lamp Life 5 Hours
3.
4.
LIGHT
i
STANDBY
ON
Select “Yes”, using the 1 / 2 buttons.
1.
Press the ENTER button. The lamp life
indicator is now initialized.
Press the STANDBY button on the remote
controller or the
/ I button on the projector
to turn the projector off.
PATTERN
REMOTE CONTROLLER
RC -12VPS4
V-MUTE
MENU
STANDBY
ON
PATTERN
3.
ENTER
Notes:
• The maximum life limit of the lamp is 2,000
hours. Although we care very much about
quality, the lamp can rarely breaks down if
running time exceeds 1,000 hours.
Therefore we recommend to replace the
lamp if Lamp Life gets under 1,000 hours.
The lamp cannot be used exceeding the
maximum life limit.
• This product is checked under strict quality
control when it is shipped out form factory.
“Total Hours” in the menu includes the time
for this check. So “Total Hours” may not be 0
hours when it is used first time.
V-MUTE
To clear the warning, press the MENU button.
ENTER
– Approximately 2 minutes after the lamp
reaches the end of its lamp life, power to the
projector shuts OFF and the WARNING
indicator lights up a red color. If the below
message appears on the screen and power
shuts OFF soon thereafter, promptly replace
the lamp with a new one. (See “Replacing
P.24)
Lamp Unit”
2.
4.
2.
☞
STANDBY
ON
2.
PATTERN
Warning
Lamp Life 0 Hours
V-MUTE
MENU
4.
ENTER
3.
24
MENU
After the cooling fan stops, Unplug the AC
power cord.
4.
Wait at the least one hour for the lamp and
lamp unit to cool down.
5.
Remove the lamp cover screw.
8.
Holding the handle and pull the lamp unit out
toward your side.
11. Install the lamp cover back in its original
position and fasten with the fastening screw.
ENGLISH
3.
(a)
Read the caution and warning labels on the
unit.
Lamp cover
Lamp unit
A
WARNING
THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.
CAUTION : HIGH PRESSURE LAMP CAUTION HOT : UNPLUG
MAY EXPLODED IF IMPROPERLY HANDLED. THE POWER CORD AND WAIT
REFER SERVICING TO QUALIFIED SERVICE 60 MINUTES BEFORE CHARGING
PERSONNEL.
THE LAMP.
ATTENTION : LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.
ATTENTION CHAUD :
MODEL NO. VP-16S1 / U1M
AC 120V
60HZ
2.0A
SERIAL NO.
DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.
B
A
For USA
(b)
WARNING
6.
THIS COVER IS PROVIDED WITH
INTERLOCK TO REDUCE THE RISK OF
EXCESSIVE ULTRAVIOLET RADIATION.
DO NOT DEFEAT ITS PORPOSE OR
ATTEMPT TO SERVICE WITHOUT
REMOVING COVER COMPLETELY.
Remove the lamp cover in the direction of the
arrow.
9.
Install a new lamp unit in position securely.
For Europe
CAUTION HOT
UNPLUG THE POWER CORD AND
WAIT 60 MINUTES BEFORE
CHANGING THE LAMP.
Lamp cover
ATTENTION CHAUD
DEBRANCER LE CORD ON
D'ALIMENTION ET ATENDER 60
MINUTES AVANT DE CHANGER
LAMPE.
12. Plug in the video projector and turn on the
power and project the image.
WARNUNG HEISS
ZIEHEN SIE DEN NETZSTECKER
AB UND WARTEN SIE 60 MINUTEN,
BEVOR SIE DIE GLUHLAMPE
WECHSELN.
☞
B
10. Lock the lamp unit in place with the two
For USA
7.
CAUTION : HIGH PRESSURE LAMP CAUTION HOT : UNPLUG
MAY EXPLODED IF IMPROPERLY HANDLED. THE POWER CORD AND WAIT
REFER SERVICING TO QUALIFIED SERVICE 60 MINUTES BEFORE CHARGING
PERSONNEL.
THE LAMP.
ATTENTION : LA LAMPE SOUS
HAUTE PRESSION PEUT SI ELLE, N'EST
PAS MANIPULEE CORRECTEMENT,
CONFIER L'OPERATION A UN
PERSONNEL D'ENTRETIEN QUALIFIE.
• If the lamp is replaced before reaching its
2000 hours lamp life, see “Reset Lamp Life”
(
P.23).
• If the lamp is replaced after reaching its
2000 hours lamp life, see “Initialize the Lamp
P.24).
Life” (
ATTENTION CHAUD :
Open the cover sheet and remove the two
screws (slotted head screwdriver required)
lock /down
MODEL NO. that
VP-12S1
N1S the lamp unit. Do not remove
anyZother
screws.
AC 120V 60H
2.0W
SERIAL NO.
DEBRANCER LE CORD ON
D'ALOMENTION ET ATENDER
60 MINUTES AVANT DE
CHANGER LAMPE.
☞
screws removed in step 7. Press on the
handle until it folds over and close the cover
sheet.
Cover sheet
MADE IN JAPAN
FABRIQUE AU JAPON
For Europe
CAUTION
VORSICHT :
HIGH PRESSURE LAMP MAY EXPLODED IF BEI FALSCHER HANDHABUNG M
IMPROPERLY HANDLED. REFER SERVICING KANN DIE HOCHDRUCKLAMPE
EXPLODIEREN UBERLASSEN
TO QUALIFIED SERVICE PERSONNEL.
SIE WARTUNGSARBEITEN
ATTENTION
NUR FACHPERSONAL.
LA LAMPE SOUS HAUTE PRESSION PEUT
EXPLOSER SI ELLE, N'EST PAS MANIPULEE
CORRECTEMENT, CONFIER L'OPERATION
A UN PERSONNEL D'ENTRETIEN QUALIFIE.
25
Before pressing the ENTER button, turn the
color temperature sensor over on its dark side
as shown in the below figure, to prevent
outside light from penetrating to the sensor’s
condenser.
Color Temperature Adjustment
ENGLISH
After replacing the lamp or in other cases where
the lighting changes, color temperature can be
adjusted using the color temperature sensor. In the
adjustment procedure, you must first initialize the
sensor itself before adjusting color temperature. It
takes about 10 minutes from when the power to
the projector is activated for the lamp’s brightness
to stabilize. Wait for lamp brightness to stabilize
before adjusting color temperature.
1.
Connect the cable of the color temperature
sensor to the RS-232C port.
6.
Fit the color temperature sensor onto the lens
and press the ENTER button. Color
temperature adjustment starts and the
projector’s WARNING and STANDBY
indicators begin flashing simultaneously.
8.
Press the ENTER button to return to the menu
and disconnect the cable of the color
temperature sensor from the projector.
Note:
If color temperature adjustment is not
correctly processed or if adjustment
processing is interrupted in course by
pressing the MENU button or for some other
reason, the below message appears on the
screen.
When installed on a tabletop
Condenser
Quit
4.
Press "Enter" to exit
Press the ENTER button. The below message
appears on the screen for a few seconds as
the sensor is being calibrated.
Attach the color temperature
sensor so that the cable is to the
bottom side of the projector.
Also, adjustment processing can be
interrupted by pressing the MENU button.
Initializing...
When installed on a ceiling
2.
Press the MENU button and select “Color
Temp. Calibration” from the MENU screen.
Press the 2 button. The below message
appears on the screen.
Color Temp. Calibration?
Yes
3.
No
Use the 1 and 2 buttons to select “Yes” and
press the ENTER button. The below message
appears on the screen.
5.
Bottom
Position the lamp so that its light passes
through the center of the lens. This is
necessary in order to calibrate color
temperature correctly. First, turn the lens shift
knob all the way to the left so that the lens
lowers to the lowest position. Then, turn it five
and a half turns to the right to raise the lens.
In this position, the light of the lamp passes
almost through the center of the lens.
Note:
Color temperature cannot be correctly
calibrated unless the lens is properly
positioned.
Top
Attach the color temperature sensor so that the
cable is to the bottom side of the projector.
7.
When the WARNING and STANDBY
indicators go out, color temperature
adjustment is complete. Adjustment takes
about 2 to 3 minutes. When the color
temperature sensor is detached from the lens,
the below message appears on the screen.
Complete
Press "Enter" to exit
26
Turn the lens shift knob until returning the lens
to the screen position you want to use.
❖ Color Temperature Sensor
Protection
Initialize
Press "Enter" to start
9.
If no operations are performed for approximately 10
minutes from the moment color temperature
adjustment processing ends, power to the projector
shuts OFF automatically in order to protect the color
temperature sensor. If power is shut OFF to protect
the color temperature sensor, do the following.
•
If the WARNING indicator does not light
When color temperature adjustment ends
successfully and the sensor protection feature
trips, the projector goes on standby. As usual,
activate power by pressing either the ON
button on the remote control or the
/ I
button on the projector.
•
If the WARNING indicator lights
If color temperature adjustment does not end
successfully and the sensor protection feature
trips, the projector's WARNING and STANDBY
indicators light simultaneously to indicate the
error mode. Unplug the power cable and then
plug it back in. Then, press either the ON
button on the remote control or the
/ I
button on the projector to reactivate power.
Cleaning the Lens
Replacement Parts
When replacement parts are required, be sure to
inform a Marantz authorized service center. Use
only replacement parts specified by Marantz.
Unauthorized substitutions may result in fire,
electric shock, or other hazards. And, the warranty
may not be guaranteed.
TROUBLESHOOTING
ENGLISH
If the lens becomes dirty or smudged, clean it with
a soft dry cloth only. Use optical lens cleaners that
are approved for eyeglasses or cameras. Do not
use a dampen cloth, detergent solution, or thinner.
It may damage the lens and remain as stains.
Try the following troubleshooting before calling for service.
1.
2.
Are the connections made properly ?
Are you operating the unit properly, following the instructions ?
If the unit does not operate properly, check the items shown in the following table.
If any trouble cannot be solved by the instructions below, malfunction of the internal circuitry is suspected; immediately unplug the AC power cord and contact
Marantz dealer or service center.
Symptom
No power
Image is not
displayed.
Optional Accessories
Poor color.
Lamp Unit : LU-12VPS3
Picture is too dark.
Picture is not clear.
Picture rolls.
The Remote
Controller does not
work.
Possible Cause
AC power cord is not connected correctly.
Connect the AC power cord properly.
☞ P.25)
Lamp cover is not closed correctly.
Close the cover properly. (
A signal cable is not connected correctly.
Connect a signal cable properly.
Selected input is incorrect.
Select the correct input source .
The picture mute is active.
Press the V-MUTE button to release the mute.
Picture is not adjusted properly.
Adjust the picture in the MENU mode.
Lamp life is running out.
Replace the lamp. (
Contrast or brightness is not adjusted properly.
Adjust contrast or brightness properly.
Picture is out of focus.
Adjust the focus.
Dew is on the lens.
Run the projector for about two hours.
A signal cable is not properly connected.
Connect a signal cable properly.
Batteries are exhausted.
Replace batteries. (
The distance to the unit is too far.
Make the distance between the unit and the remote control
closer. (
P.7)
IR sensor on unit is obstructed.
Remove any obstacles.
☞ P.24)
☞ P.7)
☞
Is the sensor cable disconnected?
☞ P.23)
Correctly connect the sensor cable. (☞ P.26)
Was the sensor correctly initialized?
Initialize the sensor by taking the correct procedures. (
Is the lens shift knob set to the correct (center)
position?
Set the lens shift knob to the correct (center) position by taking the
correct procedures. (
P.26)
The “Wired” position in the Menu is selected.
Color temperature
cannot be adjusted.
Remedy
Select the “Wireless” position. (
☞ P.26)
☞
Notes:
• If the lamp still does not function after the replacement and initialization of the lamp life, contact a Marantz authorized dealer, or service center.
• This projector uses a microcomputer. External noise can cause malfunctions. In such case, shut power OFF and unplug the power cable from AC power
outlet. Then, plug the AC power cable back in, press the
/ I button on the projector or the ON button on the remote control and check operation.
27
ENGLISH
ERROR MODE
WARNING/LAMP indicator, ON indicator, and STANDBY indicator diagnose error mode of the projector as follows.
Indicators
Error mode
WARNING
/LAMP
ON
STANDBY
Possible Cause
Recommendation
The lamp cover is not
closed properly.
Close the cover correctly.
OFF
The lamp has failed, or
the lamp is completely
worn out.
Replace the lamp and
reset lamp life.
Flashing
Projector internal
temperature is higher
than the allowed level.
Lamp cover
ON
OFF
Flashing
Lamp
ON
OFF
Temperature
Flashing
OFF
Check if anything is
blocking the exhaust vent.
Fan
Flashing
OFF
ON
Trouble has occurred
with the fan.
Color temperature
adjustment
ON
OFF
ON
Color temperature
adjustment failed.
Retry adjustment.
Other
Flashing
OFF
OFF
Internal program error
Shut power OFF and
ON again.
ON SCREEN MESSAGE
Use the list below to check the message displayed on the screen.
Message
Meaning
Remedy
NO SIGNAL
No input signal.
Properly connect the cables.
REPLACE LAMP!
The lamp has reached the end of its life.
Replace the lamp and reset lamp life.
Improper signal feed to the projector.
Adjust resolution, V(Hz) : refresh rate of the
equipment, referring to the Timing Chart.
OUT OF RANGE
28
❖ Timing chart
❖ Optical characteristics
❖ General
Panel
0.8 inch 16:9
1280 x 720 pixels
Digital Micromirror Device
Lamp
Super High Pressure 200W DC
Lens
f: 30.7 to 44.5mm
F: F3.0/F5.0
Chassis isolation
Class-1
Projection size
60 to 250 inches
Safety
Light output
600/700 ANSI LUMEN typical
(F5.0/F3.0)
UL6500
CSA E60065
EN60950
EMC
FCC Part-15 Class-B
EN55022 Class-B
Dimensions
15 15/16(W) x 18 15/16(D)
x 6 1/8(H) inch
404.5(W) x 481(D) x 158(H) mm
Net weight
13 kg
❖ Input/Output
VIDEO IN
S-VIDEO IN
COMPONENT
IN
RGB/HD IN
RCA x 1
NTSC-3.58/PAL-4.43/SECAM
Composite video 1.0Vp-p/
75 Ohm
Power requirement
AC 100-120V / 220-240V,
50/60 Hz
Power consumption
< 320 W
Standby consumption < 3.3 W
OperatingTemperature 5 to 35 °C
S-Connector x 1
NTSC-3.58/PAL-4.43/SECAM
S-Video
Operating humidity
3RCA x 2
Y, CB/PB, CR/PR
Storage humidity
D-sub M 15 pin x 1
Analog RGB
HD:1080i, 720p, 480p
HDMI IN
HDMI x 2
HDMI compliant
(single link only)
REMOTE
CONTROLLER IN
Mini jack type x 1
REMOTE
CONTROLLER OUT
Mini jack type x 1
AC IN
3 Prong Grounding Type
TRIG.1 OUT,
TRIG.2 OUT
Mini Jack x 2
Output: DC12V or 0V
RS-232C
RS-232C receptacle plug x 1
30 to 85%
Storage Temperature – 20 to 60 °C
30 to 85%
❖ Accessories
•
•
•
•
•
•
•
•
•
Lens cap x 1
Remote controller x 1
Batteries x 2
AC power code x 1
Scart-RCA plug Cable x 1 (For Europe only)
Control Adapter cable (Mini jack to RCA) x 1
Color temperature sensor x 1
User Guide
- For USA (4 languages x 1)
- For Europe (4 languages x 1, 5 languages x 1)
Warranty Card
(1 copy each for USA, CANADA)
Specifications may be subjected to change without any prior notice.
Format
NTSC 3.58
NTSC 4.43
PAL-B/G
PAL M
PAL N
PAL 60
SECAM
480/60i
480/60p
576/50i
576/48p
576/50p
540/60p
720/24p
720/25p
720/30p
720/50p
720/60p
1035/60i
1080/50i
1080/60i
1080/24PsF
1080/25PSF
1080/30PsF
1080/24p
1080/25p
1080/30p
1080/50p
1080/60p
640 x [email protected]
640 x [email protected]
640 x [email protected]
640 x [email protected]
640 x [email protected]
640 x [email protected]
640 x [email protected]
640 x [email protected]
800 x [email protected]
800 x [email protected]
800 x [email protected]
800 x [email protected]
800 x [email protected]
1024 x [email protected]
1024 x [email protected]
1024 x [email protected]
1024 x [email protected]
1280 x [email protected]
1600 x [email protected]
Resolution
720 x 487
720 x 483
720 x 576
720 x 576
720 x 576
1920 x 540
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1920 x 1035
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
640 x 350
640 x 350
640 x 400
640 x 400
640 x 480
640 x 480
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
800 x 600
1024 x 768
1024 x 768
1024 x 768
1024 x 768
1280 x 1024
1600 x 1200
V (Hz)
59.94 / 60
59.94 / 60
50
59.94 / 60
50
59.94 / 60
50
59.94 / 60
59.94 / 60
50
48
50
59.94 / 60
23.98 / 24
25
29.97 / 30
50
59.94 / 60
59.94 / 60
50
59.94 / 60
23.98 / 24
25
29.97 / 30
23.98 / 24
25
29.97 / 30
50
59.94 / 60
70
85
70
85
60
72
75
85
56
60
72
75
85
60
70
75
85
60
60
H (KHz)
15.734/15.75
15.734/15.75
15.625
15.734/15.75
15.625
15.734/15.75
15.625
15.734/15.75
15.734/15.75
15.625
30
31.25
33.746/33.78
17.985/18
18.75
22.478/22.5
37.5
44.955/45
33.716/33.75
28.125
33.716/33.75
26.978/27
28.125
33.716/33.75
26.978/27
28.125
33.716/33.75
62.5
67.433/67.5
31.469
37.861
31.469
37.861
31.469
37.861
37.5
43.269
35.156
37.879
48.077
46.875
53.673
48.363
56.476
60.023
68.678
63.981
75
Comp.1/2 CVBS/S-Video
RGB
HDMI
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
29
ENGLISH
SPECIFICATIONS
*: Supported only for DVI
GLOSSARY
❖ Top
❖ Bottom
Aspect ratio
5 3/4
(145.75)
3 11/16
(93.5)
4 11/16
(110.0)
Black Level (Black setup)
2 8/ )
4
( 6
16
5 1/4 - 5 5/16
(133.5-134.5)
18 7/8 - 18 15/16 (480 - 481)
Width and height ratio of an image. The normal
aspect ratio of a computer and video image is 4 :
3. There are also wide images with an aspect
ratio of 16 : 9 and 21 : 9.
7 5/16
(185.25)
The signal level which represents black picture
intensity.
For NTSC system for USA, this level is 7.5IRE.
NORMAL: 16 (Black) – 235 (White)
For NTSC system for Japan and DVD, this level
is 0IRE.
EXPAND: 0 (Black) – 246 (White)
STANDBY
ON
MENU
LAMP
WARRNING
FOCUS
ENTER
14 6/16 (346.5)
11 11/16 (296.5)
10 5/16 (262.0)
INPUT
DOWN
RIGHT
LEFT
LENS SHIFT
UP
Color Temperature
White color hue.
Low color temperature implies a warmer (more
yellow/red) light.
High color temperature implies a colder (more
blue) light.
Keystone
Distortion of the image caused by projection to a
wrong vertical/horizontal angle.
3 1/4
( 82.6)
8 12/16
(222.0)
12/16
(19.75)
3 - 3 9/16
(76.0 - 91.0)
6 12/16 (171.0)
4 11/16 (119.0)
❖ Rear
5 5/8 (143.0)
5 3/16 (132.0)
❖ Front
1 10/16 2 5/16
(42.0) (58.0)
7 3/16
(182.5)
9/16 - 2 7/16
(15.0 - 61.8)
ENGLISH
DIMENSIONS
4 1/8
(105.0)
6 1/16
(153.5)
Unit : inch (mm)
30
www.marantz.com
You can find your nearest authorized distributor or dealer on our website.
JAPAN
Marantz Japan, Inc.
35-1 Sagami Ohno 7-Chome, Sagamihara-shi, Kanagawa 228-8505, Japan
U.S.A.
Marantz America, Inc.
1100 Maplewood Drive, Itasca, IL 60143, U.S.A.
EUROPE
Marantz Europe B.V.
P.O. Box 8744, 5605 LS Eindhoven, The Netherlands
is a registered trademark.
Printed in Japan
12/2004 00M15AV851250 ecmf-g
