ABB Robotics

Application manual

FlexPendant SDK

Trace back information:

Workspace RW 5-15-01 version a2

Checked in 2013-03-15

Skribenta version 1184

Application manual

FlexPendant SDK

RobotWare 5.15

Document ID: 3HAC036958-001

Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

The information in this manual is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any errors that may appear in this manual.

Except as may be expressly stated anywhere in this manual, nothing herein shall be construed as any kind of guarantee or warranty by ABB for losses, damages to persons or property, fitness for a specific purpose or the like.

In no event shall ABB be liable for incidental or consequential damages arising from use of this manual and products described herein.

This manual and parts thereof must not be reproduced or copied without ABB's written permission.

Additional copies of this manual may be obtained from ABB.

The original language for this publication is English. Any other languages that are supplied have been translated from English.

© Copyright 2010-2013 ABB. All rights reserved.

ABB AB

Robotics Products

SE-721 68 Västerås

Sweden

Table of contents

Table of contents

Overview of this manual ...................................................................................................................

Product documentation, M2004 .......................................................................................................

Safety ................................................................................................................................................

7

9

11

1 Introduction

1.1

About creating controller applications ...................................................................

1.2

Documentation and help .....................................................................................

1.3

Terminology .....................................................................................................

13

13

15

17

2 Installation and development environment

2.1

Installation overview ..........................................................................................

2.2

How to obtain and install a license key for RAB 5.09 or earlier ...................................

2.3

How to set up your PC to communicate with robot ...................................................

2.4

Development environment ..................................................................................

2.5

Two development models - virtual and real ............................................................

2.6

Conversion of Visual Studio 2005 projects to Visual Studio 2008 ................................

19

19

22

23

25

27

29

3 Run-time environment

3.1

Overview .........................................................................................................

3.2

Running FlexPendant Applications .......................................................................

3.2.1

Components, assemblies and dlls ..............................................................

3.2.2

Deployment of FlexPendant application to a robot system ..............................

3.2.3

Communication between FlexPendant and controller .....................................

3.2.4

Understanding the FlexPendant application life cycle .....................................

3.2.5

FlexPendant TpsView attribute ..................................................................

3.2.6

ITpsViewSetup and ITpsViewActivation .......................................................

3.3

Release upgrades and compatibility .....................................................................

31

31

33

33

34

37

38

40

44

46

4 Developing Controller applications

4.1

Introduction ......................................................................................................

4.2

Analysis and design ...........................................................................................

4.3

Controller events and threads ..............................................................................

4.4

User Authorization System ..................................................................................

4.5

Exception handling ............................................................................................

4.6

How to use the online help ..................................................................................

47

47

48

51

54

56

59

5 Using the FlexPendant SDK

5.1

Introduction ......................................................................................................

5.1.1

About this chapter ...................................................................................

5.1.2

System features supporting the use of customized screens ............................

5.2

Setting up a new project .....................................................................................

5.2.1

Using the project template in Visual Studio ..................................................

5.2.2

Setting up design support for FlexPendant controls .......................................

5.3

Building the user interface ..................................................................................

5.3.1

Introduction to visual design support ..........................................................

5.3.2

GUI controls and memory management .......................................................

5.3.3

Container style .......................................................................................

5.3.4

Command bar .........................................................................................

5.3.5

FlexPendant fonts ...................................................................................

5.3.6

The use of icons .....................................................................................

5.3.7

TabControl .............................................................................................

5.3.8

Button, TextBox and ComboBox ................................................................

5.3.9

AlphaPad ...............................................................................................

5.3.10 ListView ................................................................................................

5.3.11 CompactAlphaPad and NumPad ................................................................

61

88

90

93

94

77

81

85

87

97

99

64

67

68

68

61

61

62

64

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5

Table of contents

5.3.12 GTPUMessageBox ..................................................................................

5.3.13 GTPUFileDialog ......................................................................................

5.3.14 Data of RAPID data and IO signals .............................................................

5.4

Launching other views .......................................................................................

5.4.1

Using launch service ................................................................................

5.4.2

Using standard dialog box to modify data ....................................................

5.5

Using the Controller API .....................................................................................

5.5.1

ABB.Robotics.Controllers .........................................................................

5.5.2

Accessing the controller ...........................................................................

5.5.3

Rapid domain .........................................................................................

5.5.3.1 Working with RAPID data ..............................................................

5.5.3.2 Handling RAPID arrays .................................................................

5.5.3.3 ReadItem and WriteItem methods ...................................................

5.5.3.4 UserDefined data .........................................................................

5.5.3.5 RAPID symbol search ..................................................................

5.5.3.6 RAPID execution .........................................................................

5.5.3.7 Modifying modules and programs ...................................................

5.5.4

IO system domain ...................................................................................

5.5.5

Event log domain ....................................................................................

5.5.6

Motion domain ........................................................................................

5.5.7

File system domain .................................................................................

5.5.8

System info domain .................................................................................

118

121

124

124

131

134

135

139

101

103

107

113

113

116

118

144

146

149

155

157

160

162

6 Robust FlexPendant applications 165

6.1

Introduction ......................................................................................................

6.2

Memory management ........................................................................................

6.3

Performance ....................................................................................................

6.4

Reliability .........................................................................................................

165

167

171

176

7 FlexPendant - Debugging and troubleshooting 181

7.1

Debugging ......................................................................................................

7.2

Debug output ...................................................................................................

7.3

Debugging the virtual FlexPendant .......................................................................

7.4

Debugging the FlexPendant device ......................................................................

7.5

Troubleshooting FlexPendant applications .............................................................

181

185

188

192

195

8 Localizing a FlexPendant application 197

8.1

Adding support for several languages ...................................................................

197

9 Deployment of a FlexPendant SDK application 207

9.1

Overview .........................................................................................................

9.2

Deployment of an application without a license .......................................................

9.3

Deployment of a licensed application ....................................................................

9.4

Deployment using FTP .......................................................................................

207

209

212

215

Index 217

6

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Overview of this manual

Overview of this manual

About this manual

FlexPendant - Software Development Kit (FlexPendant SDK) is a software tool, which enables programmers to develop customized FlexPendant operator interfaces for the IRC5 robot controller.

The purpose of this manual is to help software developers to get started with

FlexPendant SDK application development.

Usage

FlexPendant SDK application manual covers application development using the

FlexPendant SDK. FlexPendant SDK is for developing end user applications that are FlexPendant based. PC SDK is a tool for developing end user applications that are PC based (PC implies a Windows machine in this context). For more information on PC SDK, see Application manual PC SDK. The process of actually developing the application involves using a PC with Visual Studio for both PC SDK and

FlexPendant SDK applications.

Who should read this manual?

This manual is mainly intended for developers, who use FlexPendant SDK to create robot applications adapted to end-user needs. It is also useful for anyone who needs an overview of doing controller applications.

Prerequisites

The reader should

• be familiar with IRC5, the FlexPendant, and RobotStudio.

• be used to Microsoft Visual Studio and Windows programming.

• be familiar with one of the .NET programming languages C# or Visual

Basic.NET are preferred languages. Visual J# and Visual C++ can also be used.

• be used to object oriented programming.

Organization of chapters

The manual is organized as follows:

2

3

Chapter

1

4

5

Contents

Introduction. Terminology. Safety.

Installation and setup. Development environment . Virtual robot technology.

Software architecture: Run-time environment for FlexPendant applications. Life cycle of a FlexPendant application. Upgrades and compatibility.

Developing FlexPendant SDK applications. Analysis and design. Important programming issues: controller events and threads, UAS, exception handling.

Online help.

Using the FlexPendant SDK. Visual design support. GUI controls. Launching standard views. . How to add controller functionality using the Controller API.

Programming issues and code samples in VB and C#.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

7

Overview of this manual

Continued

8

9

Chapter

6

7

Contents

How to develop well performing and robust FlexPendant applications. Memory management, performance and reliability. Exception handling.

Testing, debugging and troubleshooting FlexPendant SDK applications. Using printouts, error codes in exceptions and so on. Checklist for contacting a service organization.

How to add support for several languages to a custom FlexPendant application.

How to create an additional option and how to make a product of a FlexPendant application.

References

Reference

Operating manual - IRC5 with FlexPendant

Operating manual - RobotStudio

Operating manual - Getting started, IRC5 and RobotStudio

Technical reference manual - RAPID Instructions, Functions and

Data types

Application manual - PC SDK

Document ID

3HAC16590-1

3HAC032104-001

3HAC027097-001

3HAC16581-1

3HAC036957-001

Revisions

A

B

-

Revision Description

First edition

From FlexPendant SDK 5.13 onwards this manual replaces:

Application Manual - Robot Application Builder (3HAC028083-001)

For information on PC SDK see Application Manual PC SDK (3HAC036957-

001)

Editorial changes

Updated the value of RAM in the FlexPendant memory resources table. See

How large can a custom application be? on page 166 .

8

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Product documentation, M2004

Product documentation, M2004

Categories for manipulator documentation

The manipulator documentation is divided into a number of categories. This listing is based on the type of information in the documents, regardless of whether the products are standard or optional.

All documents listed can be ordered from ABB on a DVD. The documents listed are valid for M2004 manipulator systems.

Product manuals

Manipulators, controllers, DressPack/SpotPack, and most other hardware will be delivered with a Product manual that generally contains:

• Safety information.

• Installation and commissioning (descriptions of mechanical installation or electrical connections).

• Maintenance (descriptions of all required preventive maintenance procedures including intervals and expected life time of parts).

• Repair (descriptions of all recommended repair procedures including spare parts).

• Calibration.

• Decommissioning.

• Reference information (safety standards, unit conversions, screw joints, lists of tools ).

• Spare parts list with exploded views (or references to separate spare parts lists).

• Circuit diagrams (or references to circuit diagrams).

Technical reference manuals

The technical reference manuals describe reference information for robotics products.

• Technical reference manual - Lubrication in gearboxes: Description of types and volumes of lubrication for the manipulator gearboxes.

• Technical reference manual - RAPID overview: An overview of the RAPID programming language.

• Technical reference manual - RAPID Instructions, Functions and Data types:

Description and syntax for all RAPID instructions, functions, and data types.

• Technical reference manual - RAPID kernel: A formal description of the

RAPID programming language.

• Technical reference manual - System parameters: Description of system parameters and configuration workflows.

Application manuals

Specific applications (for example software or hardware options) are described in

Application manuals. An application manual can describe one or several applications.

3HAC036958-001 Revision: B

Continues on next page

9

© Copyright 2010-2013 ABB. All rights reserved.

Product documentation, M2004

Continued

An application manual generally contains information about:

• The purpose of the application (what it does and when it is useful).

• What is included (for example cables, I/O boards, RAPID instructions, system parameters, DVD with PC software).

• How to install included or required hardware.

• How to use the application.

• Examples of how to use the application.

Operating manuals

The operating manuals describe hands-on handling of the products. The manuals are aimed at those having first-hand operational contact with the product, that is production cell operators, programmers, and trouble shooters.

The group of manuals includes (among others):

• Operating manual - Emergency safety information

• Operating manual - General safety information

• Operating manual - Getting started, IRC5 and RobotStudio

• Operating manual - Introduction to RAPID

• Operating manual - IRC5 with FlexPendant

• Operating manual - RobotStudio

• Operating manual - Trouble shooting IRC5, for the controller and manipulator.

10

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Safety

Safety

Safety of personnel

A robot is heavy and extremely powerful regardless of its speed. A pause or long stop in movement can be followed by a fast hazardous movement. Even if a pattern of movement is predicted, a change in operation can be triggered by an external signal resulting in an unexpected movement.

Therefore, it is important that all safety regulations are followed when entering safeguarded space.

Safety regulations

Before beginning work with the robot, make sure you are familiar with the safety regulations described in the manual Operating manual - General safety information.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

11

This page is intentionally left blank

1 Introduction

1.1 About creating controller applications

1 Introduction

1.1 About creating controller applications

Flexible user interfaces

Robots are usually delivered with a general operator interface. However, different processes require different operator handling and customers need flexible solutions where the user interface is adapted to user specific needs.

FlexPendant SDK allows system integrators, third parties or end-users to add their own customized operator interfaces for the IRC5 controller. Such custom applications can be added to the standard views of the FlexPendant.

For PC based applications, see Application manual - PC SDK.

Note

Controller applications are not platform independent. You must choose to develop the application for either the FlexPendant or the PC platform (For more information, see Application manual - PC SDK).

Local vs Remote client

The difference between the two platforms is that a FlexPendant application is a local client, whereas a PC application is a remote client.

Remote clients do not have all the privileges of a local client. For example, both

PC and FlexPendant applications can reset the program pointer and start RAPID execution, for example, but for a PC SDK application to do this there are certain restrictions. Mastership of the Rapid domain must be requested explicitly by the application programmer and the IRC5 controller has to be in automatic operating mode.

An advantage of a remote client, on the other hand, is the possibility to monitor and access several robot controllers from one location. As for large applications the PC platform is also less limited than the FlexPendant as regards memory resources and process power.

Note

A minimum response time for a real controller should be expected to be in the order of 10-100 milliseconds, meaning that hard real time demands cannot be met on any platform. For more information, see

Communication between

FlexPendant and controller on page 37

.

Ease-of-use on the factory floor

A well-designed user interface presents relevant information and functionality at the right time. In this respect, customized user interfaces are clearly very desirable to the end-user. As tailored solutions are easier to operate, they also optimize user’s investment in automation.

FlexPendant SDK enables customized user interfaces for IRC5. It is important to keep in mind, however, that FlexPendant SDK itself does not guarantee increased

3HAC036958-001 Revision: B

Continues on next page

13

© Copyright 2010-2013 ABB. All rights reserved.

1 Introduction

1.1 About creating controller applications

Continued customer value. To achieve this, FlexPendant SDK applications should be developed with care and with a heavy emphasis placed on ease-of-use.

Understanding end-users’ needs is in fact crucial to realizing the benefits of customized interfaces.

.NET and Visual Studio

FlexPendant SDK uses Microsoft .NET and Microsoft Visual Studio. It is thus assumed that you know how to program for .NET platforms using Visual Studio.

Among programmers .NET distinguishes itself by the programming model provided by the Microsoft .NET Framework.

One feature is the programming language independence, leaving the choice to the developer to use any language provided by the integrated development environment

Visual Studio. Most prefer C# or Visual Basic, which both offer safe and efficient development.

For a Windows programmer familiar with Visual Studio and .NET, developing a customized operator view is rather straight-forward. FlexPendant SDK is fully integrated with Visual Studio, which means that a .NET programmer will recognize wizards for project setup and tools for visual design support and debug and so on.

Considerable efforts have been made to allow controller application developers to start working without having to overcome a steep learning curve. To further speed up the development process, the virtual IRC5 of RobotStudio can be used to test and debug controller applications.

Note

Knowledge of Windows programming, object orientation and a .NET programming are the prerequisites to use FlexPendant SDK.

Robustness and performance

Developing an application for the FlexPendant, a device with limited process and memory resources, can be quite demanding. Issues such as performance and memory management need to be addressed.

It is strongly advisable to read this manual to learn about specific FlexPendant

SDK issues while moving to FlexPendant SDK development.

Note

Take the time to study this manual along with the release notes, and avoiding rushing into coding.

14

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

1 Introduction

1.2 Documentation and help

1.2 Documentation and help

Introduction

FlexPendant SDK includes an extensive on-line help module, which comes with the installation of the product. After having installed RobotStudio, by clicking

Windows’ Start menu, then pointing at Programs > ABB Industrial IT > Robotics

IT > RobotStudio 5.xx > SDK you will find:

• Application manual FlexPendant SDK

• Reference Manual FlexPendant SDK

• FlexPendant StyleGuide

Application manual

This Application manual - FlexPendant SDK, is the recommended way to get started if you are new to FlexPendant SDK development. It explains how FlexPendant SDK works. It has code examples in C# and VB and provides hands-on exercises.

The Application manual is provided in two formats, HTML Help and PDF. HTML is the recommended format for the PC screen and PDF is the best choice if you want printouts.

Note

The Application manual PDF can be found in the installation directory, at

C:\Program Files\ABB Industrial IT\Robotics IT\SDK\FlexPendant SDK 5.xx.

SDK Reference Help

The Reference Manual FlexPendant SDK should be used while programming. It makes up the complete reference to the FlexPendant SDK class libraries. Method signatures are provided in C# and Visual Basic.

Please note that they are not integrated with the Visual Studio Help function.

Clicking F1 when pointing at code, for example, will open the Visual Studio

Programmer’s Reference or the .NET Framework Class Library for the specific language and topic. Many times this is what you want, but if your problem is

FlexPendant SDK related you need to open the appropriate SDK Reference Help to find a solution.

Note

You are recommended to keep the help files open while programming, as you will frequently need them for FlexPendant SDK related issues.

FlexPendant StyleGuide

Good usability is achieved when the program itself communicates possible actions and how to perform them. To encourage careful design of the visual appearance the FlexPendant StyleGuide is also part of the installation. It is ABB Robotics’ best practices for visual design of the FlexPendant user interface.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

15

1 Introduction

1.2 Documentation and help

Continued

RobotStudio Community

ABB Robotics launched a community named RobotStudio Community, for its PC

Software users. The Developer Tools in Developer Section of RobotStudio

Community has information and some videos about programming with the

FlexPendant SDK. At Content Sharing there is a complete FlexPendant SDK application available for download. It is recommended for average users and for beginners.

ABB encourage open conversations and believe everyone has something to contribute. The User Forum of RobotStudio Community has a section dedicated to robot application development. Here beginners as well as experts discuss code and solutions online. If you are facing a coding problem the User Forum should be your first choice, as there is a good chance that someone will give you the help you need to proceed.

RobotStudio Community also provides the means to share code and videos. Your contribution will be appreciated. Working together is many times the key to success.

Tip

Try it out at www.abb.com/robotics > RobotStudio Community.

MSDN

MSDN (Microsoft Developer Network) at http://www.msdn.com is a one of many sources of information for general programming issues related to .NET and Visual

Studio.

16

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

1 Introduction

1.3 Terminology

1.3 Terminology

About terms and acronyms

Some terms used in this manual are product specific and crucial for understanding.

Moreover, acronyms, words formed from initial letters, are sometimes used instead of long terms. To avoid confusion, important terminology is clarified in the following table.

Definitions

Term Definition

.NET Compact Framework (.NET CF)

Version of Microsoft's .NET framework providing the run-time environment for applications running on embedded devices, such as the FlexPendant. It includes a class library, which is almost a subset of the rich .NET framework for the desktop.

C# and Visual Basic.NET

.NET programming languages.

Common Language

Runtime

Controller Application

Programming Interface

Device

The core runtime engine in the .NET Framework for execution of managed code. Provides services such as cross-language integration, code access security, object lifetime management, and debugging and profiling support.

The public class libraries of the FlexPendant SDK, which offer robot controller functionality. Also referred to as CAPI.

The FlexPendant is a “smart device” in the .NET vocabulary, that is, a complete computer in itself with its own processor, operating system and so on.

FlexPendant

FlexPendant SDK programmer

ABB’s hand held device, used with IRC5 robot controller. It is developed with Microsoft’s technology for embedded systems,

Windows CE and .NET Compact Framework.

A programmer who uses FlexPendant SDK to develop custom applications.

FlexPendant SDK application

A custom application developed with FlexPendant SDK.

IRC5

JIT compiler managed code

Microsoft Visual Studio

ABB’s robot controller.

When compiling managed code, the compiler translates the source code into Microsoft Intermediate Language (MSIL), which is a CPU-independent set of instructions. Before code can be executed, MSIL must be converted to CPU-specific code, usually by a just-in-time (JIT) compiler.

Code that is executed and managed by the Microsoft .NET

Framework’s common language runtime. All code produced by

Visual Studio executes as managed code.

The integrated development environment that developers work inside when using the .NET Framework.

Microsoft .NET Framework

Network socket

An integral Windows component supporting the building and running of applications.

A communication end-point unique to a machine communicating on an Internet Protocol-based network.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

17

1 Introduction

1.3 Terminology

Continued

Term Definition

Robot Application Builder

ABB software tool, which enabled the development of custom operator interfaces for IRC5. Often referred to as RAB. The RAB is split to FlexPendant SDK and PC SDK. Robot Application

Builder (RAB) was a software tool, which enabled programmers to develop customized FlexPendant or PC interfaces for the IRC5 robot controller.

Robot Communication

Runtime

The communication layer used by Controller API to communicate over the network with an IRC5 controller.

unmanaged code

Virtual IRC5

Windows CE

Code that is executed directly by the operating system, outside the .NET Framework. Unmanaged code must provide its own memory management, type checking, and security support, unlike managed code, which receives these services from the common language runtime. All code executing in the robot controller, as well as part of the code executing in the FlexPendant is unmanaged.

Virtual robot technology makes it possible to run a virtual IRC5 controller, virtual mechanical units and a virtual FlexPendant on the desktop. Included as freeware in ABB’s RobotStudio.

The embedded operating system running on the FlexPendant device.

Acronym

CAPI

CLR

FlexPendant SDK

GUI

MSDN

SDK

TAF

TCP/IP

VB

VS

Definition

Controller Application Programming Interface

Common Language Runtime

FlexPendant Software Development Kit

Graphical User Interface

Microsoft Developer Network, source of information for .NET

developers at: http://www.msdn.com.

Software Development Kit

Teach Pendant Application Framework, all applications using the FlexPendant SDK must run as TAF clients. For more information, see

TAF - Application host framework on page 38 .

Transmission Control Protocol (TCP) and Internet Protocol (IP)

Visual Basic

Visual Studio

18

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.1 Installation overview

2 Installation and development environment

2.1 Installation overview

About this section

This section describes how to install FlexPendant SDK. When the installation is complete, you can program, compile and test FlexPendant applications for the

IRC5 controller.

Supported platforms

The following software requirements have to be met:

• Operating system: Microsoft Windows XP + SP2, Windows Vista +SP2 or

Windows 7

• Microsoft Visual Studio: VS 2005 (Standard Edition or better) or VS 2008

(Professional Edition or better ).

• .NET Compact Framework 2.0 Service Pack 1 or 2

The following hardware requirement have to be met:

• 50 MB free disk-space on the installation disk

Both FlexPendant generations are supported:

• SxTPU-1, which executes with .NET CF 2.0 and WinCE 4.2.

• SxTPU-2, which executes with .NET CF 2.0 and WinCE 5.0.

• SxTPU3, which executes with NET CF 3.5 and Windows CE 6.0.

Note

The controller system must have the RobotWare option FlexPendant Interface

Note

FlexPendant SDK is developed and tested for the English version of Visual Studio.

If you are running Visual Studio in another language you are recommended to switch to the English version.

Requirements for installing and using FlexPendant SDK

FlexPendant SDK is installed while you install RobotStudio. For more information on installing RobotStudio, see Installing and Licensing RobotStudio in Operating manual - RobotStudio.To use FlexPendant SDK, the following requirements have to be met. Also make sure that you have administrator permissions on the computer that you are using.

Before...

installing RobotStudio debugging using a virtual

IRC5

you must...

install Microsoft Visual Studio 2005 or 2008.

learn how to run the virtual IRC5 in RobotStudio.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

19

2 Installation and development environment

2.1 Installation overview

Continued

Before...

debugging using the real

FlexPendant device

you must...

install the .NET Compact Framework 2.0 Service Pack 1 or

2, which can be downloaded from http://www.microsoft.com.

The User Forum of RobotStudio Community has information on how to attach the Visual Studio debugger to the device.

For more information, see also

Debugging the FlexPendant device on page 192

.

executing the application targeting a real IRC5 system check that the robot system has the controller option Flex-

Pendant Interface (for FlexPendant applications).

Set up a connection between your PC and the robot controller. For more information, see

How to set up your PC to communicate with robot on page 23

for details about how this is done.

Note

The Visual Studio installation installs .NET and Compact Framework 2.0.

About the FlexPendant SDK installation

Previously FlexPendant SDK was a part of Robot Application Builder (RAB) which also included PC SDK. RAB 5.12 was the last release of Robot Application Builder.

Starting wtih RobotStudio 5.13, both FlexPendant SDK and PC SDK are included in the RobotStudio installation. RobotStudio installs FlexPendant SDK 5.13, side by side with previously installed versions of FlexPendant SDK.

RAB 5.11 to 5.12

RAB 5.11 and later installs PC SDK and FlexPendant SDK side by side with any previously installed versions.

RAB 5.10

RAB 5.10 upgraded any previously installed PC SDK to 5.10 and installed

FlexPendant SDK 5.08, 5.09 and 5.10 side-by-side. The reason for the side-by-side installation of several FlexPendant SDK versions was to make it easier for

FlexPendant SDK users to work on FlexPendant SDK applications targeting different

RobotWare versions. Earlier RAB releases can be downloaded from http://www.abb.com/robotics > RobotStudioCommunity >Developer Tools >

FlexPendant SDK Overview.

What is installed?

The installation generates the following features on your PC:

• SDK assemblies and resources

• Application manual FlexPendant SDK

• FlexPendant Style Guide

• Reference Manual FlexPendant SDK

Continues on next page

20

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.1 Installation overview

Continued

Working with several versions

A FlexPendant SDK application normally targets a specific RobotWare release.

Assuming you are developing a FlexPendant SDK application for a new customer who uses RobotWare 5.12 and simultaneously you are maintaining an existing

FlexPendant SDK application for a customer with robot system using RobotWare

5.09, then you will need to work with two different FlexPendant SDK releases on your PC. For more information about releases and compatibility, see

Release upgrades and compatibility on page 46 .

FlexPendant applications

If you install FlexPendant SDK 5.13 and previous versions of FlexPendant SDK which came along with PC SDK as Robot Application Builder, the previous versions will exist on your PC. You choose which FlexPendant SDK version to use when you set up your application project in Visual Studio. For more information, see

Using the project template in Visual Studio on page 64

.

You should make sure that the FlexPendant SDK GUI controls the Visual Studio

Designer uses is of the same version. If you have worked with another FlexPendant

SDK version before, you will need to remove the GUI controls that you have added to the Visual Studio Toolbox and then add them again, pointing to the correct version in the browser. For more information, see

Setting up design support for

FlexPendant controls on page 67

.

Installation procedure

The installation procedure is very simple. By default FlexPendant SDK is installed when you install RobotStudio. For more information, see Installing RobotStudio, in Operating Manual - Getting started, IRC5 and RobotStudio.An installation wizard will guide you through the installation. If you would like to install RobotStudio without installing FlexPendant SDK, or remove FlexPendant SDK from RobotStudio select Custom in the RobotStudio installation wizard and select or unselect the feature FlexPendant SDK.

Note

You are also strongly advised to read the Release Notes that you will find on the

RobotWare DVD and on the RobotStudio Community web site, as these hold the most up-to-date information, including new features and any known limitations of the release.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

21

2 Installation and development environment

2.2 How to obtain and install a license key for RAB 5.09 or earlier

2.2 How to obtain and install a license key for RAB 5.09 or earlier

Overview

In RAB 5.10, the license check was removed from the software, which allowed anyone to use Robot Application Builder for free. This means you no longer need to bother about getting a license, or including a licx file in your PC application.

Note

For RAB version 5.09 or earlier, licensing is the second part of the installation procedure. In case you need to develop a RAB application for RobotWare 5.09

or earlier you need to turn to support to get a free license key.

Install licence key

Follow these steps when you have received the e-mail with the license key file:

2

3

Step

1

Action

Detach the license key file from the e-mail and save it to a folder on your PC.

Double-click the license key file. This opens the License Install Wizard.

Follow the instructions in the wizard.

Note

To execute FlexPendant SDK applications towards a real robot controller you must connect your PC to the robot controller, either through the network or directly to the service port on the controller. For detailed information, see

How to set up your PC to communicate with robot on page 23

.

22

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.3 How to set up your PC to communicate with robot

2.3 How to set up your PC to communicate with robot

Overview

This section describes how to connect your PC to the robot controller.

You can either connect the PC to the controller through an Ethernet network or directly to the controller service port. When using the controller service port, you can either obtain an IP address for the PC automatically, or you can specify a fixed

IP address.

When the PC and the controller are connected correctly, the controller is automatically detected by RobotStudio.

Why is a connection needed?

Connecting the PC to the controller is necessary for all online tasks performed in

RobotStudio. For example, downloading a robot system or files to the controller, editing configuration files, programming and so on.

The connection is also used for downloading a FlexPendant application to the controller file system and test it on the real FlexPendant device.

It also enables you to communicate with the controller by means of a console window on the PC and get valuable information about controller status, FlexPendant memory consumption and so on.

Ethernet network connection

If the controller is connected to an Ethernet network, you can connect the PC to that network as well. The settings to use on the PC depends on the network configuration. To find out how to set up your PC, contact the network administrator.

Service port connection with automatic IP address

An alternative to network connection is using the controller service port. It has a

DHCP server that automatically gives your PC an IP address if it is configured for this. For more information about configuring the PC to obtain an IP address automatically, see Windows Help on Configure TCP/IP settings.

Note

Obtaining an IP address automatically might fail if the PC already has an IP address from another controller or Ethernet device. To make sure that you get a correct IP address if the PC has already been connected to an Ethernet device, do one of the following:

• Restart the PC before connecting to the controller.

• Run the command “ipconfig /renew” from the command prompt after connecting the PC to the controller

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

23

2 Installation and development environment

2.3 How to set up your PC to communicate with robot

Continued

Serial connection to the Console port

In order to use the console window of the IRC5 controller you can connect your

PC with a serial null-modem cable to the console port of the controller.

Note

The cable must be a twisted cable with a female DB-9 connector in each end..

Service port connection with fixed IP address

Instead of obtaining an IP address automatically, you can specify a fixed IP address on the PC you connect to the controller.

Use the following settings for connecting with a fixed IP address:

Property

IP address

Subnet mask

Default Gateway

Value

192.168.125.2

255.255.255.0

192.168.125.1

Related information

For information about

How to set up PC network connections

See

Windows Help - Configure TCP/IP settings.

How to connect the PC to the Controller service port

Connecting a PC to the Service Port in the

RobotStudio help.

24

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.4 Development environment

2.4 Development environment

Overview

This section presents an overview of the development environment used to create

FlexPendant SDK applications. You can program and debug the application using

Microsoft Visual Studio 2005 or 2008.

Microsoft .NET and Microsoft Visual Studio

Microsoft Visual Studio is supported by the .NET Framework. A core component of the .NET Framework is the common language runtime (CLR). It manages code execution, threads and memory, while also enforcing type safety.

Another major component is the Base Class Library, which is a comprehensive, object-oriented collection of reusable types. To become a skilled .NET programmer it is essential to learn the functionality offered by the Base Class Library.

It is not in the scope of this manual to teach how to use Visual Studio. For this purpose msdn (Microsoft Developer Network) at http://msdn.microsoft.com is a useful source of information.

Note

For information about upgrading an existing FlexPendant SDK project to Visual

Studio 2008 project, see

Conversion of Visual Studio 2005 projects to Visual

Studio 2008 on page 29 .

Visual design support and Databinding

The .NET Compact Framework 2.0. can be used for building enhanced user interfaces. FlexPendant specific controls are available in the Visual Studio toolbox since FlexPendant SDK 5.08 version.

Databinding is the process of binding a property of a GUI control to a data source, so that the property automatically reflects the value of the data source.

Choosing a programming language

Together with Visual Basic, C# is the most widely used .NET language.

C# is an object-oriented language derived from C, with some features from C++,

Java and Visual Basic. It was designed for .NET and offers the power and richness of C++ along with the productivity of Visual Basic. Both PC and FlexPendant SDK are implemented using C#.

For FlexPendant SDK applications only C# and Visual Basic are supported.

Likewise, in this manual there are code samples in C# and Visual Basic, but none in J# or Visual C++.

At run-time it does not matter which language you have used, as compiled .NET

code is language independent. The source code compiles from a high-level language into Intermediate Language (IL), which is then executed, at runtime, by the Common Language Runtime. This makes it possible to use different

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

25

2 Installation and development environment

2.4 Development environment

Continued programming languages, even within the same application. For more information on .NET terms, see

Definitions on page 17

.

Note

It is presumed that you are already a .NET programmer. If not, you need to start by learning the programming language to be used. There are numerous books teaching C# and Visual Basic.

Integration with Visual Studio

When FlexPendant SDK is installed on your computer, it is integrated with Visual

Studio. You will notice when starting a new project, for example, that the project type FlexPendant is available in the New Project window. When using the wizard to create a FlexPendant project, common SDK references are added to the project and some code is automatically generated.

The visual design support for the FlexPendant will be accessible from the Toolbox in Visual Studio and work the same way as the design support for an ordinary

Windows application. As you will see, using FlexPendant SDK is quite intuitive for a developer used to Visual Studio programming.

Note

The help module is not integrated with the Visual Studio Help function. Clicking

F1 when pointing at code, for example, will open the Visual Studio Programmer’s

Reference or the .NET Framework Class Library for the specific language and topic. If your problem is FlexPendant SDK related this will not help you.

Tip

The Reference Manual FlexPendant SDK is found by clicking Start menu, then pointing at Programs > ABB Industrial IT > Robotics IT > RobotStudio 5.xx > SDK

> Reference Manual FlexPendant SDK. Keep the reference file open while programming, as you will be needing it all the time.

26

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.5 Two development models - virtual and real

2.5 Two development models - virtual and real

About this section

When trying out a custom application, you can either use a virtual robot controller or a real robot system. This section provides information on how to use both the development models.

Virtual robot technology

The virtual IRC5 of ABB’s RobotStudio allows the IRC5 controller software to execute on a PC, and supports application developers with a purely virtual environment to be used for development, test and debug.

When you start the virtual IRC5 in RobotStudio, a virtual robot cabinet along with a virtual FlexPendant appears on the PC screen.

As a real robot controller is normally not readily at hand for application development, virtual technology is very valuable.

Requirements for virtual environment

The following software components must be installed to develop, test and debug using the virtual environment:

• ABB RobotStudio (Complete)

• Microsoft Visual Studio 2005 or 2008

• Controller option FlexPendant Interface

Controller option PC Interface is not needed in the virtual environment.

Note

For more information, see Installing and Licensing RobotStudio in Operating

Manual - RobotStudio

Requirements for real environment

The following software components must be installed to develop, test and debug using a real robot controller:

• ABB RobotStudio (Complete or Custom - with RobotStudio and FlexPendant

SDK selected)

• Microsoft Visual Studio 2005 or 2008

• Controller option PC Interface and FlexPendant Interface

• Network connection between PC and robot controller

For information about how to set up the network, see

How to set up your PC to communicate with robot on page 23

.

Virtual test and debug

Using the virtual environment a FlexPendant application executes on the Virtual

FlexPendant as an assembly (dll). You start the application from the ABB menu of the Virtual FlexPendant like you start it on the real FlexPendant.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

27

2 Installation and development environment

2.5 Two development models - virtual and real

Continued

Debugging is easy using the virtual IRC5 and Visual Studio. You attach the application process to Visual Studio, set a break point in the code, and step through it as it executes. For more information, see

Debugging the virtual FlexPendant on page 188

.

Real tests necessary

The virtual environment is a very convenient choice, especially for testing and debugging. You should be aware however, that the virtual FlexPendant is more forgiving than the real device. Using only the virtual FlexPendant, it is very easy to neglect the restraints on memory consumption imposed by the real device.

Images, for example, can easily consume all the FlexPendant memory available for custom applications.

This means that potential problems may be hard to detect until you test the application using a real robot system. It is almost as easy to debug code running on the real FlexPendant device. For more information, see

Debugging the

FlexPendant device on page 192

.

You should also be aware that your application shares CPU, memory and application host with all other FlexPendant applications. This means that a custom application can impact the overall performance of the FlexPendant.

Note

Before shipping a FlexPendant application, it has to be tested properly, using a real system. Relying only on the virtual environment is far too risky. For more information, see

Two development models - virtual and real on page 27

.

Porting the application from virtual to real IRC5

A FlexPendant application that runs perfectly on the Virtual FlexPendant, but not on the real device since there can be a lag in response time due to TCP/IP communication, but the main problem is limited resources on the device, both memory and processor power.

The FlexPendant SDK does not slow down performance. Therefore your application is supposed to perform like any standard application of the FlexPendant. For more information on how to speed up a slow FlexPendant application, see

Performance on page 171 .

Deployment to customer

During development, deployment to the controller is done manually. When the development phase is over and the application needs to be deployed to the customer, this should be done differently.

For information about how this should be done, see

Deployment of a FlexPendant

SDK application on page 207 .

28

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

2 Installation and development environment

2.6 Conversion of Visual Studio 2005 projects to Visual Studio 2008

2.6 Conversion of Visual Studio 2005 projects to Visual Studio 2008

Overview

Converting an existing FlexPendant SDK Visual Studio 2005 project to Visual Studio

2008 is simple. When you open a Visual Studio 2005 project in Visual Studio 2008, the Visual Studio Conversion Wizard appears automatically. The procedure which converts the project to Visual Studio 2008 is easy to follow. It consists of a few dialog box providing information about what will happen.

Note

For FlexPendant SDK projects one need to manually edit the post-build event that builds the *gtpu.dll. Find Build Events in the Project Properties and adapt the path to vcvarsall.bat to the new development environment.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

29

This page is intentionally left blank

3 Run-time environment

3.1 Overview

3 Run-time environment

3.1 Overview

About this chapter

This chapter provides an overview of the run-time environment of custom applications, including illustrations of the software architecture of the FlexPendant

SDK.

Application configuration is detailed as well as deployment of a FlexPendant application to a robot controller. The life cycle of a FlexPendant application is also explained.

Software architecture

The FlexPendant is an integral part of IRC5, yet a complete computer in itself. It has been developed with Microsoft's software technology for embedded systems,

Windows CE and .NET Compact Framework, which is a subset of the full .NET

Framework that the PC uses.

FlexPendant platform

The following illustration shows the Software architecture of FlexPendant SDK.

Two FlexPendant applications, one using VB and the other C#, developed on top of the FlexPendant SDK. The FlexPendant SDK CAPI is the public API offering controller functionality. All communication with the robot controller is done via the internal Robot Communication Runtime. The FlexPendant SDK provides ABB made

UI controls suitable for the FlexPendant.

.NET Compact

Framework 2.0

FlexPendant SDK app2 C#

FlexPendant SDK app1 VB

FlexPendant SDK, C#,

User interface controls & CAPI

Device class libraries, C#

Adaptors, C++

COM-based internal API towards robot controller, C++

Windows CE 5.0

Network boundary

TCP/IP

Controller

FlexPendant_

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

31

3 Run-time environment

3.1 Overview

Continued

Controller API

The FlexPendant SDK offer controller functionality through the public application interface called Controller API (CAPI). The interface can be seen as a specification of the controller services available.

32

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.1 Components, assemblies and dlls

3.2 Running FlexPendant Applications

3.2.1 Components, assemblies and dlls

Building blocks

The .NET Framework is a library of components and supporting classes and structures, designed to make component development easy and robust.

Components are packaged in assemblies, also called dlls.

Assemblies are the building blocks of .NET applications. An assembly is a reusable collection of types and resources, which are built to work together and form a logical unit of functionality. The simplest assembly is a single executable.

One or several assemblies

A FlexPendant project compiles to a dll, which cannot run as an independent application, but needs to be started by the Teach Pendant Application Framework

(TAF), the application manager of the FlexPendant. For more information, see

Understanding the FlexPendant application life cycle on page 38 .

In a normal case, a custom application for the FlexPendant is developed as a single component, but it is also possible to separate functionality into several components.

This way the application will consist of several dlls. The reason for doing so might be one of the following:

• The amount of code is substantial. A modular design with small and well tested building blocks put together is one way of handling complexity.

• Different developers are working on the same custom application. For reasons of efficiency, they can split the functionality between them and work on one component each.

Note

You can use different programming languages for different components.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

33

3 Run-time environment

3.2.2 Deployment of FlexPendant application to a robot system

3.2.2 Deployment of FlexPendant application to a robot system

Proxy assembly

When you compile a FlexPendant SDK application an additional assembly named

*gtpu.dll is automatically created. This is done by a tool, the ABB Compliance Tool, which verifies that the application complies to the FlexPendant requirements. This proxy dll is necessary to run the application on the FlexPendant.

To test the application on a real FlexPendant both assemblies must be downloaded to the SYSTEM or HOME directory of the robot controller. After this the FlexPendant should be restarted. At startup it loads the application assemblies from the controller.

Tip

An advantage of deploying the dlls to the HOME directory is that they will be included in a system backup.

Download to real controller

To download your application assemblies to the controller you can use the Online function File Transfer of RobotStudio.

Another way of downloading the application to the robot controller is using the

ABB Compliance Tool.

Step

1

2

3

Action

Verify that the following requirements are met before starting the procedure:

• A network connection between the PC and the controller has to be configured, either using the controller LAN port or the controller service port.

For further information see

How to set up your PC to communicate with robot on page 23 .

• The RobotWare option FlexPendant Interface is required to run the application on a real system. Without the option you will not see the application in the ABB menu.

Open Windows Explorer.

Start abbct.exe at C:\Program Files\ABB Industrial IT\Robotics IT\SDK\FlexPendant

SDK 5.xx..

4

Continues on next page

34

4.3.2_1Compl

Click Browse and locate your Visual Studio project and the application assembly in the \bin\debug (or \bin\release) sub-folder.

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.2 Deployment of FlexPendant application to a robot system

Continued

Step

5

6

Action

Check the Deploy box, enter the IP Address of the robot controller and click

Execute. Deployment is done to the current system of the controller.

Note!

If the application consists of several assemblies you need to repeat the procedure for all of these.

Restart the FlexPendant. For more information about different ways to do this, see

Restart the FlexPendant on page 35 .

Using the command window

The ABB Compliance Tool can be used via the command window instead of the graphical interface. To do so you write: abbct.exe /deploy="192.168.8.192" <PATH>\TpsViewHelloWorld.dll

<PATH>\TpsViewHelloWorld.gtpu.dll.

It is also possible to perform build and deployment in one step. To do this the deploy argument should come last: abbct.exe <PATH>\TpsViewHelloWorld.dll /deploy="192.168.8.192"

Both the application and proxy assembly are deployed to the controller after the build.

FTP deployment

You can also use an FTP client to transfer files from your PC to the robot controller.

To use FTP you need:

• FTP client program

• Configured connection to the controller

• RobotWare option FTP and NFS Client

• Name and password

Step

1

2

Action

Transfer resources (for example icons) and the application and proxy assemblies to the HOME or SYSTEMdirectory of the current system of the controller.

Restart the FlexPendant. See the next section for information on how to do so.

Note

For deployment to a customer when the application is ready, see

Deployment of FlexPendant application to a robot system on page 34 .

Restart the FlexPendant

If you want to restart the FlexPendant device without restarting the controller, choose one of these alternatives:

Alternative

1

2

Action

Write the command fpcmd "-restart" in the controller console window on your PC.

Perform the following sequence while holding the FlexPendant joystick:

Move the joystick three times to the right, once to the left and once down.

Confirm your wish to reset the FlexPendant in the dialog that will appear.

3HAC036958-001 Revision: B

Continues on next page

35

© Copyright 2010-2013 ABB. All rights reserved.

3 Run-time environment

3.2.2 Deployment of FlexPendant application to a robot system

Continued

Alternative

3

Action

Unplug and plug the FlexPendant (power on/ power off).

Note! This activates emergency stop.

Deploy application to virtual IRC5

Follow these steps to deploy an application to the Virtual FlexPendant:

Step

1

2

Action

Copy application and proxy assemblies and images to the HOME directory of the system you want to use on your PC.

Note! Close the virtual FlexPendant first if you are replacing assemblies.

Restart the virtual FlexPendant.

Tip

If you have problems running your application, try to put all files (dlls, gif files and so on.) in the vcbin directory of the robotware your system uses. This setup is as close to the real system setup as you can get.

36

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.3 Communication between FlexPendant and controller

3.2.3 Communication between FlexPendant and controller

COM technology

The FlexPendant SDK uses an internal Controller API based on COM technology to communicate with the controller. This API uses sockets and TCP/IP (for more information, see

About terms and acronyms on page 17 ) towards both real and

virtual controllers.

Calls from the FlexPendant SDK to the controller are synchronous, that is, are done immediately through the COM servers. This increases execution speed and causes less overhead, which is important on a resource limited device.

Resource identification

All controller resources, both real and virtual, are described using object based hierarchy. Each resource is uniquely identified, including information about which controller owns the resource by use of the unique system id or IP address of the controller.

The controller is the top object of the hierarchy:

"/<Controller>/<Domain>/<SubDomain1>/<SubDomain2>/and so on"

Tip

Error messages including such a path indicate where to look for the problem.

Hard real-time demands

The FlexPendant SDK cannot meet hard real-time demands. This is for several reasons:

• Part of the API executes on a non-real-time operating system.

• The controller sometimes has tasks to perform that have a higher right of priority.

Note

The FlexPendant SDK does not affect performance in a negative way. You should expect your custom application to perform like any other application on the ABB menu.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

37

3 Run-time environment

3.2.4 Understanding the FlexPendant application life cycle

3.2.4 Understanding the FlexPendant application life cycle

Overview

Understanding the FlexPendant application life cycle improves your ability to design and debug the application.

TAF - Application host framework

The Teach Pendant Application Framework (TAF) is the application service provider that runs on the FlexPendant. It targets .NET CF and is implemented in C#. All applications using the FlexPendant SDK must run as TAF clients, as TAF contains services for hosting controls and for managing applications.

TAF uses a customized configuration file to create the appearance and behavior of the hosted application. It also defines a set of rules that have to be followed.

Starting a custom application

When the FlexPendant starts up TAF is already in the flash memory. Applications that will execute in the TAF container are now loaded from the controller.

If the FlexPendant SDK application is to be started manually by the end-user the application icon and text are placed in the ABB Menu. The other alternative is to have it started automatically by TAF at FlexPendant startup. For more information on how this is configured, see

FlexPendant TpsView attribute on page 40 .

Application life cycle

TAF handles the life cycle of a custom application, starting by calling the constructor of its TpsView class. After this, the

Install method and then the

Activate method in the same class execute.

During its lifetime, the application switches between the active and the passive state. Each time, either

Activate or

Deactivate is executed. In its active state the application is visible in the client view, in the passive state another application may have been opened or you may have opened another application through the

FlexPendant task bar.

When the application is closed via the close button, first the

Deactivate method runs and then

Uninstall

. After this the

Dispose method of the TpsView class is called. Then the application instance is disposed of by TAF. For more information about how you can implement these methods, see

ITpsViewSetup and

ITpsViewActivation on page 44 .

Continues on next page

38

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Illustration

3 Run-time environment

3.2.4 Understanding the FlexPendant application life cycle

Continued

The figure illustrates the life cycle of a FlexPendant application.

4.3.3_1TAFAp

Limited resources

As the FlexPendant is a device with very limited resources compared to a PC, you should learn and use the mechanisms implemented to assist you in writing efficient code.

Both process power and memory resources are limited compared to the virtual environment on the desktop. An application that runs very well on the virtual

FlexPendant, may encounter serious problems in the real environment because of these limitations. For more information, see

Technical overview of the

FlexPendant device on page 165

.

Note

You are strongly recommended to read

Understanding the FlexPendant application life cycle on page 38

in this manual before starting coding. Always keep the limitations of the device in mind when you develop custom FlexPendant applications.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

39

3 Run-time environment

3.2.5 FlexPendant TpsView attribute

3.2.5 FlexPendant TpsView attribute

Overview

A custom FlexPendant application must implement the assembly attribute

TpsView

.

For example, it is used to determine the visual appearance of the application in the ABB menu. The

TpsView attribute is auto generated and located before the namespace definition in the application view class, that is, the class that displays the first view of a FlexPendant SDK application.

In this section all parameters of the

TpsView attribute will be detailed.

Project wizard settings

The

TpsView attribute is auto generated according to your settings in the

FlexPendant SDK Project Wizard in Visual Studio:

6.2.2_1FormT

In C# the settings of the figure will render this code:

[assembly: TpsView("MyApplicationName", "tpu-Operator32.gif",

"tpu-Operator16.gif", "TpsViewHelloWorld.dll",

"TpsViewHelloWorld.TpsViewHelloWorld",

StartPanelLocation.Left, TpsViewType.Static, StartupType =

TpsViewStartupTypes.Manual)]

Note

You can edit your settings directly in the auto generated code.

Continues on next page

40

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.5 FlexPendant TpsView attribute

Continued

Visual appearance

In run-time the most obvious result of this code is the way the custom application is presented in the ABB menu. In the following example, the first

TpsView parameter has been changed from “MyApplicationName” to “Hello World”.

4.3.4_1Hello

Application name

The first parameter of TpsView is the application name as it should appear in the

ABB menu and on the task bar. The example uses

“HelloWorld” as the application name.

Application icon

The second parameter is the file to be used as the application icon in the ABB menu. Usually a customized icon is used for the application.The example uses the default icon: “ tpu-Operator32.gif"

.

TaskBar icon

The third parameter is the file to be used as the application task bar icon. The example uses the default icon

"tpu-Operator16.gif"

.

Application assembly

The fourth parameter is the assembly name. If you change the name of the application assembly you also need to change this parameter to reflect that change.

In the example, the assembly name is

"TpsViewHelloWorld.dll"

.

Note

The assembly name must start with “TpsView” for TAF to identify it as an application to be loaded. If you forget this an error will be generated by the ABB verification tool when you try to build the project.

3HAC036958-001 Revision: B

Continues on next page

41

© Copyright 2010-2013 ABB. All rights reserved.

3 Run-time environment

3.2.5 FlexPendant TpsView attribute

Continued

Class name

The fifth parameter specifies the fully qualified class name of the initial view of your application, which you chose in the New Project dialog box. In the example, the fully qualified class name is

"TpsViewHelloWorld.TpsViewHelloWorld"

.

Application location

The sixth parameter determines the location of the application icon and text in the

ABB menu. In the example these are displayed in the left column: startPanelLocation.Left

.

Parameter value

StartPanelLocation.Left

StartPanelLocation.Right

StartPanelLocation.None

Result

application visible to the left in the ABB menu.

application visible to the right in the ABB menu.

application is not visible at all in the ABB menu.

Note

StartPanelLocation.None

was introduced in 5.11.01. Applications that use it can therefore NOT be run on RobotWare releases older than 5.11.01.

Application type

As you can tell from the two Hello World icons visible in the task bar, two instances of the Hello World application have been started. To enable this the seventh parameter is changed to :

TpsViewType.Dynamic

. Possible view type values are shown in the table:

Parameter value Result

TpsViewType.Dynamic

You can start multiple instances of the application.

TpsViewType.Static

TpsViewType.Invisible

You can only start one instance of the application.

A background application with no GUI and no icon on the task bar. Can be started automatically or manually. Only one instance is possible.

Note

Unless there is special need for it, you should allow the user to start only one instance of the application:

TpsViewType.Static

. The reason is that working with several instances takes up valuable memory resources.

Startup type

The eighth parameter determines how the application is started. In the example the startup type is

TpsViewStartupTypes.Manual

and the application is started from the ABB menu. Using the manual startup type it is also possible to have the application started by RAPID or at operating mode change to auto for example.

For more information, see

System features supporting the use of customized screens on page 62

Continues on next page

42

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.5 FlexPendant TpsView attribute

Continued

If

TpsViewStartupTypes.Automatic is chosen, the application is started automatically by TAF whenever the FlexPendant is restarted or a new user logs on.

Related information

For information about the Style setting of the Project Wizard, see

Container style on page 81 .

To find the FlexPendant SDK Project Wizard in Visual Studio, see

Setting up a new project on page 64 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

43

3 Run-time environment

3.2.6 ITpsViewSetup and ITpsViewActivation

3.2.6 ITpsViewSetup and ITpsViewActivation

ITpsViewSetup

An application that TAF needs to initialize must have a default (empty) constructor and must implement the interface

ITpsViewSetup

, which specifies the two methods

Install and

Uninstall

.

Install and Uninstall

Install is called when the application is created in TAF. The parameters are used by TAF and should not be modified. It is recommended to add code for further initiations and allocation of system resources in this method, for example load assemblies, open communication channels, and so on.

When you close the application

Uninstall is called. This happens right before the application is deleted. It is recommended to add code for disposal of system resources in this method, for example unload assemblies, close sockets, and so on.

ITpsViewActivation

All custom applications should implement the

ITpsViewActivation interface, which specifies the two methods

Activate and

Deactivate

. These are used by

TAF to notify applications when they get focus and when they lose it.

Activate and Deactivate

Activate is run every time the application gets focus. This happens at initialization, after the

ITpsViewSetup.Instal

l method has been run, and when you click the application icon in the task bar.

Deactivate

, accordingly, is run every time the application loses focus. This happens when you close the application, before the

ITpsViewSetup.Uninstall

method has been run, and when you click another application icon in the task bar.

Note

It is recommended to activate and deactivate timers in these methods. This way timers will not run when other applications are in focus, thus saving processor power. For the same reason, any subscription to controller events should be disabled in

Deactivate and enabled again in

Activate

. Note that current values should be read before enabling the subscription.

Continues on next page

44

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

3 Run-time environment

3.2.6 ITpsViewSetup and ITpsViewActivation

Continued

Simple code examples

This table shows the basic things that the

ITpsView methods are used for in a custom application:

Method

Install

Activate

Deactivate

Uninstall

Usage

Create the

Controller object:

VB:

AController = New Controller

C#: aController = new Controller();

Add subscription to controller event:

VB:

AddHandler AController.OperatingModeChanged, AddressOf

UpdateUI

C#:

AController.OperatingModeChanged += new

OperatingModeChangedEventHandler(UpdateUI);

Remove subscription to controller event:

VB:

RemoveHandler AController.OperatingModeChanged, AddressOf

UpdateU

I

C#:

AController.OperatingModeChanged -= new

OperatingModeChangedEventHandler(UpdateUI);

Remove the controller object:

VB:

If Not AController Is Nothing Then

AController.Dispose()

AController = Nothing

End If

C#: i f (aController != null)

{ aController.Dispose(); aController = null;

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

45

3 Run-time environment

3.3 Release upgrades and compatibility

3.3 Release upgrades and compatibility

About this section

This section addresses compatibility issues with different version of Robotware.

Matching FlexPendant SDK and RobotWare release

You should be aware that the FlexPendant SDKs are developed and tested for a specific RobotWare release. The general rule is therefore that you develop an application for a certain release.

Compatibility between revisions is however guaranteed (for example FlexPendant

SDK 5.11.01 will be compatible with FlexPendant SDK 5.11).

RobotWare upgrades

At some time during the lifetime of your application, a robot system that your application targets may be upgraded with a later RobotWare version.

As for a FlexPendant SDK application this means that the runtime will change, that is, the FlexPendant SDK assemblies located in RobotWare will be different from the ones that were used when the application was developed. Generally, the only way to be sure that the existing application will work with a newer RobotWare version is to compile the source code with the FlexPendant SDK version that matches the intended RobotWare version.

Note

You find all the details about compatibility between different FlexPendant SDK versions in the Release Notes.

Tip

When compiling your project notice any warnings of obsolete methods, as these will probably be removed in the next FlexPendant SDK release.

Prepared for change

To sum up, it is important to keep source code safe and available for maintenance.

Tip

Ildasm is a Microsoft tool, which comes with the installation of Visual Studio, that you may find useful. It enables you to open the manifest of a specified assembly and quickly find out about dependencies for example.

Find out more about it at http://msdn2.microsoft.com/en-us/library/aa309387(Visual Studio.71).aspx

46

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.1 Introduction

4 Developing Controller applications

4.1 Introduction

About this chapter

This chapter deals with analysis, design and implementation of FlexPendant SDK applications.

It also discusses some specific programming issues that are important for

FlexPendant SDK users:

• thread conflicts and how to avoid them

• controller events and event handling

• errors and exception handling

• the User Authorization System

The chapter does not include hands-on information on how to set up your first project or detailed information on how to use the FlexPendant SDK class libraries, as these topics are covered in dedicated chapters.

Basic approach

In most aspects, using the FlexPendant SDK for application development presents no major difference compared to ordinary .NET development. The .NET class libraries are used for everything that is not robot specific. In addition, you use the public Controller API of the SDKs.

Note

When using the .Net class libraries for FlexPendant development, see Version

Information to be sure that the class or method is supported on .NET Compact

Framework 2.0, which runs on the FlexPendant.

Use this procedure to program the FlexPendant SDK application for the first time:

Step

1

2

3

Action

Before you start

Learn the basics about FlexPendant SDK programming by reading all relevant sections of this manual. Feel reassured that this is a timesaving activity and do not rush into coding.

If you are going to develop an application for the FlexPendant, a device with limited resources compared to a PC, studying the chapter

Robust FlexPendant applications on page 165

is crucial.

During development

Frequently test application functionality.

Do not wait too long before you test a FlexPendant application on a real FlexPendant device.

After development

If you develop a FlexPendant application, set up a long term test before use in production. If not, you risk that the FlexPendant slowly runs completely out of memory and crashes due to your application.

Verify application behavior, performance and memory consumption. Use the services offered by ABB. For more information, see

FlexPendant - Debugging and troubleshooting on page 181 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

47

4 Developing Controller applications

4.2 Analysis and design

4.2 Analysis and design

About this section

The purpose of FlexPendant SDK is to provide operator interfaces that fulfill specific customer needs. This section focusses on the development phases preceding the actual coding: analysis and design.

Object oriented software development

.NET is entirely object-oriented. Platform services are divided into different namespaces such as

System.Collections, System.Data

,

System.IO,

System.Security and so on. Each namespace contains a set of related classes that allow access to platform services. FlexPendant SDK, too, is completely object oriented. Its class libraries are organized in different namespaces such as

ABB.Robotics.Controllers.RapidDomain,ABB.Robotics.Controllers.MotionDomain

and so on.

Some experience in object orientation is necessary to start developing custom applications. It is presumed that you feel comfortable with concepts such as objects, classes, methods, inheritance, encapsulation and so on.

Object oriented Analysis and Design

Object Oriented Analysis and Design, OOAD, is a popular topic in computer science literature, where the importance of doing a thorough analysis and design before starting coding is commonly accepted. A well designed OO application has a true representation in the real world. Classes have well defined areas of responsibility and collaborate in an efficient way to achieve what is required.

Analysis based on communication and use cases

The main idea of FlexPendant SDK is, as has already been pointed out, that custom operator interfaces can be developed close to end-users, taking their specific needs in consideration. It therefore goes without saying that analysis is crucial.

The result of the object-oriented analysis is a description of what we want to build, often expressed as a conceptual model. Any other documentation that is needed to describe what we want to build, for example pictures of the User Interface, is also part of analysis.

The most important aspect for FlexPendant SDK development is communication with end-users. Activities which support a shared view of what should be developed are strongly recommended. Such activities may include:

• creating and discussing use cases together

• coding or drawing prototypes and get end-user feedback

Continues on next page

48

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.2 Analysis and design

Continued

In short, involving end-users from the early stages and keeping them involved throughout the development project is the best strategy.

Note

Customer satisfaction is what has driven the development of FlexPendant SDK.

Do make sure that you have really understood what the end-users of your application need.

Design is about managing complexity

The result of the object-oriented design details how the system can be built, using objects. Abstraction is used to break complex problems into manageable chunks.

It makes it possible to comprehend the problem as a whole or to study parts of it at lower levels of abstraction.

It takes years to become a skilled object oriented designer. Design theory must be transformed into practical experience and iterated over and over again.

The goal is to produce high quality code, which is cost-efficient and easy to maintain. This is achieved, for example, when adding new functionality will involve minimal changes to existing code and most changes will be handled as new methods and new classes.

Do you need to do design?

There is a huge difference in complexity when creating software such as .NET

framework, for example, and a custom operator view for IRC5. Obviously, the more complex a system the more careful design is needed. Accordingly, the larger and more complex a custom application needs to be, the more likely you are to spend time on design.

This table presents some considerations before deciding how well you need to design your application before starting coding:

Consideration Advice

How much code is it going to be?

If it is going to be a very simple application with one view and a few buttons there is no need even to split the code between different classes and files.

If there will be a substantial amount of code and there might be further extensions later on, spending time on design becomes more relevant.

Will different developers work on different classes/components?

Will you maintain the code yourself, or may it be done by others?

If yes, spending time om design becomes more relevant.

Is the real time aspect of the application important?

If yes, coding efficiently is important. This will much more easily be achieved if you spend some time on design.

Note! You are also recommended to read through the chapter

Robust FlexPendant applications on page 165

before starting coding.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

49

4 Developing Controller applications

4.2 Analysis and design

Continued

As complex or as easy as you wish

A simple custom application can be created in a day or two using FlexPendant

SDK. A large custom application with a number of different views, offering advanced robot system functionality, however, may take months to develop and will require considerable programming skill.The recommendation is to start developing a simple application, which you execute on the target platform, before moving on to advanced

FlexPendant SDK programming.

50

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.3 Controller events and threads

4.3 Controller events and threads

Overview

A controller event is a message from the controller that something has happened.

Events can be caught and acted upon by FlexPendant SDK applications.

Controller events use their own threads. This means that user interface threads and controller event threads can get into conflict. This section gives information on how to prevent this.

Controller events

FlexPendant SDK applications can subscribe to a number of controller events.

These are all described in the Reference Manual FlexPendant SDK.

The table shows some events that exists in the FlexPendant SDK.

The event...

StateChanged

OperatingModeChanged

ExecutionStatusChanged

Changed

MessageWritten

ValueChanged

occurs when...

the controller state has changed.

the controller operating mode has changed.

the controller execution status has changed.

the value or the state of the I/O signal has changed.

the EventLog has a new message the value of a RAPID data has changed.

Note

There is no guarantee you will get an initial event when setting up/activating a controller event. You need to read the initial state from the controller.

GUI and controller event threads in conflict

You should be aware that controller events use their own threads both on the

FlexPendant and PC platform. If a GUI thread and a controller event thread get into conflict, deadlocks or overwritten data may occur. This may happen when a controller event is succeeded by an update of the user interface, which is indeed a very common scenario.

You then need to take action in your code to control that the user interface update is executed by the GUI thread and not by the controller event thread. This is done by enforcing a thread switch using the

Invoke or

BeginInvoke method. For more information on how this is done along with code examples, see

Invoke method on page 52 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

51

4 Developing Controller applications

4.3 Controller events and threads

Continued

On the other hand, if the controller event should NOT cause any update of the user interface, you should not take any special action. Using

Invoke

/

BeginInvoke is performance demanding and should not be used more than necessary.

Note

Thread conflicts often cause hangings. The FlexPendant touch screen then stops responding and the application has to be restarted.

Examine what exception has been thrown when you encounter such a situation.

The exceptions

System.NotSupportedException

(FlexPendant platform) and

System.InvalidOperationException

(PC platform) indicate thread conflicts.

See the next section for information on how to use

Invoke to solve the problem.

Invoke method

All FlexPendant views must inherit

Control

/

TpsControl

, which implement

Invoke and

BeginInvoke

. These methods execute the specified delegate/event handler on the thread that owns the control's underlying window handle, thus enforcing a switch from a worker thread to the GUI thread. This is precisely what is needed when a controller event needs to be communicated to the end user of the system.

Invoke should be called inside the event handler taking care of the controller event. Notice that you have to create a new object array for the sender and argument objects:

VB:

Me.Invoke(New EventHandler(AddressOf UpdateUI), New Object()

{sender, e})

C#: this.Invoke(new EventHandler(UpdateUI), new Object[] {sender, e});

Also notice that if you use

EventHandler in the

Invoke method and not the specific delegate class, for example

DataValueChangedEventHandler

, you need to typecast the argument in the delegate which updates the user interface. How this is done is shown in the following example:

VB:

Private Sub UpdateUI(ByVal sender As Object, ByVal e As

System.EventArgs)

Dim Args As ExecutionStatusChangedEventArgs

Args = DirectCast(e, ExecutionStatusChangedEventArgs)

Me.Label1.Text = e.NewStatus.ToString()

End Sub

C#: private void UpdateUI(object sender, System.EventArgs e)

{

ExecutionStatusChangedEventArgs args; args = (ExecutionStatusChangedEventArgs) e; this.label1.Text = e.NewStatus.ToString();

}

Continues on next page

52

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.3 Controller events and threads

Continued

Note

The difference between

Invoke and

BeginInvoke is that the former makes a synchronous call and will hang until the GUI operation is completed, whereas

BeginInvoke executes the specified event handler asynchronously. Which method you want to use depends on the logics of your program. The recommendation is to choose

BeginInvoke whenever possible.

Note

If your code tries to access a GUI control from a background thread the .NET

common language runtime will throw a

System.NotSupportedException

(FlexPendant platform) or a

System.InvalidOperationException

(PC platform).

Tip

If you are using the FlexPendant SDK there is further information about threads in

Reliability on page 176

and

Reliability on page 176

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

53

4 Developing Controller applications

4.4 User Authorization System

4.4 User Authorization System

Overview

In the robot controller there is a system controlling user access: the User

Authorization System (UAS). If this feature is used each user needs a user name and a password to log on to a robot controller via the FlexPendant or RobotStudio.

If the controller connection for any reason is lost, you have to log on again.

The controller holds information on which operations different users are allowed to perform. The UAS configuration is done in RobotStudio.

Tip

To learn more about UAS use the help function in RobotStudio.

Accessing UAS from custom applications

Before sensitive controller operations are performed, a FlexPendant SDK application should check that you are currently logged on and have the corresponding UAS rights.

Accessing UAS is done by using the property

AuthorizationSystem on the controller object:

VB:

Dim UAS As UserAuthorizationSystem =

Me.AController.AuthorizationSystem

C#:

UserAuthorizationSystem uas = this.aController.AuthorizationSystem;

Grants and Groups

UAS rights are called Grants. The specific user belongs to one of several defined

Groups, where each group has a number of specified grants.

To ensure that you have necessary grants to perform an operation, you use the

CheckDemandGrant method on the

AuthorizationSystem object. The grant to check is passed as an argument:

VB:

If uas.CheckDemandGrant(Grant.ModifyRapidProgram) Then aTask.LoadModuleFromFile(localFile, RapidLoadMode.Replace)

End If

C#: if (uas.CheckDemandGrant(Grant.ModifyRapidProgram)) { aTask.LoadModuleFromFile(localFile, RapidLoadMode.Replace);

}

Note

The FlexPendant SDK application cannot override the UAS configuration. This means that the system will in the end prevent you from performing an action that is not allowed.

Continues on next page

54

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.4 User Authorization System

Continued

MessageBox feedback

If a UAS grant is missing you should get information about it. This can be done in a message as shown in the following example: msg = "You are not allowed to perform this operation, talk to your system administrator if you need access." title = "User Authorization System"

VB:

GTPUMessageBox.Show(Me, Nothing, msg, title,

System.Windows.Forms.MessageBoxIcon.Asterisk,

System.Windows.Forms.MessageBoxButtons.OK)

C#:

GTPUMessageBox.Show(this, null, msg, title,

System.Windows.Forms.MessageBoxIcon.Asterisk,

System.Windows.Forms.MessageBoxButtons.OK);

GetCurrentGrants and DemandGrant

Another possibility is to retrieve all grants for the current user calling

GetCurrentGrants

, then iterate over the grants collection and search the necessary grants.

Yet another solution is to call

DemandGrant with one of the static

Grant members as in argument.

If you do not have the specified grant the FlexPendant SDK throws a

UasRejectException and the PC SDK throws a

GrantDemandRejectedException

.

Tip

For more information on UAS and

Grant members, see Reference Manual

FlexPendant SDK.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

55

4 Developing Controller applications

4.5 Exception handling

4.5 Exception handling

Overview

The .NET programming languages provide built-in support for exception handling, which allows the program to detect and recover from errors during execution.

In managed code, execution cannot continue in the same thread after an unhandled exception. The thread terminates, and if it is the program thread, the program itself terminates. To avoid this, accurate exception handling should be used.

The FlexPendant SDK provides several exception classes, which are used when errors occur. If the operation is rejected by the controller safety access restriction mechanism, for example, a

RejectException is thrown.

If an unhandled exception occurs the application crashes and TAF displays a gray message on the FlexPendant. After confirmation the FlexPendant will restart. To avoid this you should make sure that any potential error situations are dealt with properly by your code.

The message that you get when an unhandled error situation occurs may look like this. Do NOT contact ABB, but fix the error handling of your application.

5.5_1Unhandl

Note

For more information on how the exception classes of the FlexPendant SDK work, see Reference Manual FlexPendant SDK. Also see

Reliability on page 176

to get more detailed information about exception handling for the FlexPendant platform.

Try-catch-finally

Exceptions are handled in try

catch

(finally

) blocks, which execute outside the normal flow of control.

Continues on next page

56

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.5 Exception handling

Continued

The try block wraps one or several statements to be executed. If an exception occurs within this block, execution jumps to the catch block, which handles the exception.

The finally block is executed when the

Try block is exited, no matter if an exception has occurred and been handled. It is used to clean up system or controller resources.

If you do not know what exceptions to expect or how to handle them, they can be caught and nothing need to be performed. This, however, may result in difficult error tracing, as exceptions include information on what caused the problem.

Therefore, try at least to display the exception message, either by using a message box or the types

Debug or

Trace

. For more information, see

Debug output on page 185

and

Trace and Debug on page 187 .

Typecasting

When typecasting

Signal or

RapidData values, for example, there is a potential risk of typecast exceptions. To avoid this you can check the object using the is operator for both value and reference types:

VB:

If TypeOf aRapidData.Value Is Num Then

Dim aNum As Num = DirectCast(aRapidData.Value, Num)

.....

C#: if (aRapidData.Value is Num)

{

Num aNum = (Num) aRapidData.Value;

....

}

In C# it is also possible to use the as operator for reference types. A null value is returned if the type is not the expected one:

C#:

DigitalSignal di = this.aController.IOSystem.GetSignal(“UserSig”) as DigitalSignal; if (di == null)

{

MessageBox.Show(this, null, “Wrong type”);

}

.NET Best Practices

.The .NET Framework Developer's Guide presents the following best practices for exception handling:

• Know when to set up a try/catch block. For example, it may be a better idea to programmatically check for a condition that is likely to occur without using exception handling. For errors which occur routinely this is recommended, as exceptions take longer to handle.

• Use exception handling to catch unexpected errors. If the event is truly exceptional and is an error (such as an unexpected end-of-file), exception handling is the better choice as less code is executed in the normal

3HAC036958-001 Revision: B

Continues on next page

57

© Copyright 2010-2013 ABB. All rights reserved.

4 Developing Controller applications

4.5 Exception handling

Continued case.Always order exceptions in catch blocks from the most specific to the least specific. This technique handles the specific exception before it is passed to a more general catch block.

58

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

4 Developing Controller applications

4.6 How to use the online help

4.6 How to use the online help

Overview

The online help comes with the installation of FlexPendant SDK and is accessible from Windows Start menu.

The recommendation is to read this application manual carefully while developing

FlexPendant SDK applications. Reference Manual FlexPendant SDK is an important complements to this manual, as these make up the complete reference to the class libraries of FlexPendant SDK. For more information, see

Documentation and help on page 15 .

Note

The SDK Reference is NOT integrated in Visual Studio. You must open it from the Start menu.

Tip

For more information on the web address to RobotStudio Community, where

FlexPendant SDK developers discuss software problems and solutions online, see

Documentation and help on page 15

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

59

This page is intentionally left blank

5 Using the FlexPendant SDK

5.1.1 About this chapter

5 Using the FlexPendant SDK

5.1 Introduction

5.1.1 About this chapter

Overview

This chapter gives detailed information on how to use the FlexPendant SDK.

These topics are covered:

• How to take advantage of some system features that support the use of customized screens.

• How to utilize the integrated Visual Studio wizard to set up a FlexPendant project.

• How to add the FlexPendant SDK GUI controls to the Visual Studio Toolbox.

• How to build the user interface using the integrated design support.

• How to program FlexPendant SDK GUI controls.

• How to launch other applications from your application.

• How to implement controller functionality using CAPI.

The design support in Visual Studio enables you to visually lay out the application, reducing the need to write code. This speeds up development and gives you a more precise control of the appearance of your FlexPendant screens.

Using the FlexPendant SDK it is possible to launch several of the standard

FlexPendant applications from your application, which is often a very handy alternative to handling complicated procedures on your own, such as reading and writing RAPID data for example.

The Controller API (CAPI) is at the core of the FlexPendant SDK. It is used to access the robot controller, which the FlexPendant is attached to. First there is information about how this public API is organized. Then each domain of CAPI is dealt with separately. There are code samples in C# and VB throughout the chapter.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

61

5 Using the FlexPendant SDK

5.1.2 System features supporting the use of customized screens

5.1.2 System features supporting the use of customized screens

Flexible user interfaces

The FlexPendant can be adapted to end-users' specific needs in many different ways. It can be operated in 14 different languages, including Asian character-based languages such as Japanese and Chinese. Left-handed operators can adapt the device from its default setting by simply rotating the display through 180 degrees.

Four of the eight hard keys are programmable, that is, their function can be assigned by the end-user.

Customized FlexPendant screens, tailored to end-users’ needs is yet another way of rendering the flexible solutions required by many customers. To support the use of customized screens there are a couple of features that you may want to tell the end-users of your application about.

Configure the FlexPendant

Using the FlexPendant configuration facilities (Control Panel - FlexPendant) it is possible to configure the FlexPendant to allow RAPID execution in manual mode from an FlexPendant SDK view. You can also make the FlexPendant automatically display an SDK view at operating mode change.

Additional Test View

Set the FlexPendant configuration property Additional Test View if you want to start RAPID execution in manual mode with a custom application as the active view.

6.1.0_1AddTe

Continues on next page

62

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.1.2 System features supporting the use of customized screens

Continued

View On Operating Mode Change

Set the FlexPendant configuration property View On Operating Mode Change if you want the custom application to become active when the controller operating mode is switched to auto, manual or manual full speed.

6.1.0_2ViewO

Use RAPID instruction to launch FlexPendant SDK application

The RAPID instruction

UIShow

(User Interface Show) is used to communicate with the user of the robot system via a FlexPendant application. Both FlexPendant SDK applications and standard applications can be launched using this instruction.

Example:

The following RAPID code launches the custom application TpsViewMyApp.

CONST string Name :="TpsViewMyApp.gtpu.dll";CONST string Type

:="ABB.Robotics.SDK.Views.TpsViewMyApp";UIShow Name, Type;

For this to work the robot system must have the RobotWare option FlexPendant

Interface. The assemblies TpsViewMyApp.dll and TpsViewMyApp.gtpu.dll must be located in the HOME directory of the active robot system. (When the assemblies have been downloaded to the controller the FlexPendant must be restarted in order to load them.)

Note

For more information on

UIShow instruction, see Technical reference manual -

RAPID instructions, functions and data types

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

63

5 Using the FlexPendant SDK

5.2.1 Using the project template in Visual Studio

5.2 Setting up a new project

5.2.1 Using the project template in Visual Studio

Overview

It is very simple to set up a new FlexPendant project using the integrated project template. It will automatically add the most common SDK references to the project and auto-generate some source code for the main application window, in the selected programming language, either C# or Visual Basic.

Note

To add another view to the FlexPendant project, you do not need to start a new project. For more information, see

Container style on page 81

.

Setup procedure

Follow these steps to create a FlexPendant project:

Step

1

2

Action

On the File menu in Visual Studio, point to New and then click Project.

In Visual Studio 2005, in the New Project dialog select Visual C# / Smart Device

/ FlexPendant or Other Languages/Visual Basic/Smart Device/FlexPendant. In

Visual Studio 2008, select Visual C# / FlexPendant or Other Languages/Visual

Basic/FlexPendant).

New_Project

Note

If you have several FlexPendant SDK installations on your PC, there will be several templates to choose from. Make sure you select the template that match the RobotWare version that your application should target.

Continues on next page

64

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.2.1 Using the project template in Visual Studio

Continued

Step

3

4

5

Action

Enter the name of the application in the Name field and where you want it to be stored in the Location field. Click OK.

Note

The name has to start by “TpsView” . If you forget it an error will be generated by the ABB verification tool when the project is built.

The FlexPendant SDK Project Wizard is now launched. For information about how to configure the application using this wizard see

FlexPendant TpsView attribute on page 40

and

Container style on page 81 . When you are ready click OK.

You need to set up the design support for the FlexPendant GUI controls before starting programming. How this is done is detailed in

Setting up design support for FlexPendant controls on page 67 .

Note

If the SDK references seem to be missing in your FlexPendant project, see the following section for instructions about how to solve the problem.

Add any missing references

The SDK references needed by the FlexPendant project are added automatically when the Project wizard is completed. However, there is a possibility that Visual

Studio cannot provide the path to these dlls. If this is the case you should add the references path manually. Follow these steps:

Step

1

Action

Look at the Solution Explorer of Visual Studio. If you have a C# project expand the References node. Warning triangles mean that the path to the referenced dlls is missing.

6.1.1_2SetUp

For a VB project the Solution Explorer looks the same, except that there is no

References node.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

65

5 Using the FlexPendant SDK

5.2.1 Using the project template in Visual Studio

Continued

Step

2

3

Action

C#: Select the project icon, right-click and select Properties. Click the Reference

Paths tab and add the path to the SDK assemblies.

VB: Select the project icon, right-click and select Properties. Click the References tab. If the path to the SDK references is missing add it by browsing to the directory where they are located.

Note

The default path is C:\Program Files\ABB Industrial IT\Robotics IT\SDK\FlexPendant

SDK 5.xx\bin.

Save the project. You will notice that any warning triangles in the Solution Explorer

References node will disappear.

66

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.2.2 Setting up design support for FlexPendant controls

5.2.2 Setting up design support for FlexPendant controls

Overview

This section describes how to make the FlexPendant GUI controls accessible in

Visual Studio.

Procedure

Follow these steps to add the FlexPendant controls to the Visual Studio Toolbox:

4

5

Step

1

2

3

6

Action

On the View menu, select Toolbox.

Right click in the Toolbox area and select Add Tab.

Name the new toolbox tab, for example FlexPendant Controls.

Right click in the area of the new tab and select Choose Items.

In the Choose Toolbox Items dialog, browse to the directory where the FlexPendant

SDK assemblies are located and import the following assemblies:

• ABB.Robotics.Tps.Windows.Forms.dll

• ABB.Robotics.GTPU.Windows.Forms.dll

• ABB.Robotics.DataBinding.dll

The default location is C:\Program Files\ABB Industrial IT\Robotics IT\SDK\Flex-

Pendant SDK 5.xx\bin.

In the Solution Explorer right-click view.cs (view.vb if you have a VB project) and select View Designer if you are not already in design mode.

As you see, the FlexPendant specific controls are now accessible in the Toolbox.

For more information on how to use them, see

Introduction to visual design support on page 68 .

Note

The way you use the Visual Studio Designer to implement FlexPendant controls is very similar to implementing ordinary .NET controls. In this manual useful information which may not be obvious for all users is provided. But oftentimes, it is the general Visual Studio Help that will answer any questions you may have about control properties and the like.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

67

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

5.3 Building the user interface

5.3.1 Introduction to visual design support

What is visual design support?

Design Support for Compact Framework User Controls was a new feature of Visual

Studio 2005. It enabled design support for FlexPendant SDK controls to be included in FlexPendant SDK 5.08.

From FlexPendant SDK 5.08 onwards you visually design the FlexPendant application user interface in the Visual Studio Designer. FlexPendant controls are dragged from the toolbox to the designer area, moved and resized by clicking and dragging. By applying different settings in the Properties window of a control, you refine its appearance and behavior.

To use the visual design support you must add the FlexPendant controls to the

Visual Studio toolbox. How to do this is detailed in

Setting up design support for

FlexPendant controls on page 67

.

Note

Design support for FlexPendant controls has long been on FlexPendant SDK users’ wish list. It is indeed a time-saving feature, as most of the code supporting the graphical user interface is now auto generated.

Why special controls for the FlexPendant?

You may wonder why the standard Microsoft Windows controls have not been considered good enough to be used for the FlexPendant touch screen.

The answer is that some Windows controls may very well be used. Other Windows controls are however not so well suited for the FlexPendant touch screen. To navigate using your finger controls in particular need to be large enough. In some other cases the Windows controls simply do not look very good on the touch screen.

Note

In the Reference Manual FlexPendant SDK, click the Contents tab and the

ABB.Robotics.Tps.Windows.Forms node to get an overview and a short description of all ABB controls you may use to create the user interface of a

FlexPendant application.

Tip

How to program these ABB controls is very similar to the equivalent Windows controls. If you need code examples the best source of information is usually

MSDN. You may try http://msdn.microsoft.com/library/default.asp?url=/library/en-us/cpref/html/frlrfsystemwindowsformslistviewclasstopic.asp, for example, to find out how to program a

ListView

.

Continues on next page

68

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Illustration

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

The following screenshot shows the Visual Studio Toolbox with all of the

FlexPendant controls to the left. In the Designer area to the right, a FlexPendant application is being developed. Part of the container control, along with a number of ABB and standard Windows controls can be seen.

6.3.1_1MyFir

The following features are worth noting:

• A Windows PictureBox control is used as the container of a photo.

• The FlexPendant button has a property called BackgroundImage, used to display an image. The ABB image library located in the Resources folder, which comes with the installation of FlexPendant SDK, has numerous icons, which can be used by custom applications. You can of course also use photos and icons of your own.

• Some of the ABB controls, such as the SignalBindingSource, have no graphical representation in design-time. As you see in the figure, they are placed in the components pane under the main form. Code is generated similar to the controls that you see on the form.

• Usually a mix of Windows and ABB controls are used for a FlexPendant SDK application. For example, as there is no ABB RadioButton or CheckBox the equivalent Windows controls are used. In the figure, the standard Windows

CheckBox is used.

CAUTION

Do not forget about the limited amount of memory available for custom applications when adding images or photos! For more information, see

Introduction on page 165 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

69

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

CAUTION

Auto generated code for controls is located in the method

InitializeComponent

. You should not tamper with the code inside this method.

Any modifications or additions to auto generated code is usually best located in the constructor, after the call to

InitializeComponent.

Hands on - Hello world

Are you ready to program and test your first FlexPendant application? If you have not created a FlexPendant project and added the FlexPendant controls to the Visual

Studio Toolbox you need to do that first. For more information, see

Using the project template in Visual Studio on page 64

and

Setting up design support for

FlexPendant controls on page 67

.

Follow these steps to create and test a simple custom application:

Step

1

2

Action

Drag a FlexPendant button from the Toolbox to the Designer.

Double-click the button in the Designer, this opens the code editor.

Continues on next page

70

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Step

3

Action

As you see an event handler for the click event has been created. Add the code to launch the Hello World message in it: private void button1_Click(object sender, EventArgs e)

{ try

{ myLabel1.Text = " Hello World! ";

} catch(System.Exception ex)

{

// Catch is mandatory here!!

// If there is no catch to take care of an error caused by your application,

// not only your application, but the entire FlexPendant, will crash, as all FP applications share the same GUI-thread.

// It is up to you how to handle the error. Normally, you may want to display an error message, something like this:

GTPUMessageBox.Show(this.Parent

, null

, "An unexpected error occurred \nError Message: "

+ex.Message

, "Application Error"

, System.Windows.Forms.MessageBoxIcon.Question

, System.Windows.Forms.MessageBoxButtons.OK);

} finally

{

// cleanup code goes here (if needed)

// "finally" is used to guarantee that cleaning up resources, releasing mastersip etc is not skipped due to the exception.

// (In this case, the finally clause is not necessary, as there is nothing to clean up.)

}

An alternative way of adding an event handler is shown in the next step.

Note

A FlexPendant application to be used in industry must have exception handling in all event handlers, as shown in the preceding code sample. The FlexPendant has only ONE GUI thread, which all applications running on the FlexPendant share. If your application breaks the only GUI thread, all of the applications will die and the

FlexPendant must be restarted manually. For more information, see

Exception handling on page 56

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

71

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Step

4

Action

Bring up the Properties window for the button by right clicking it in the Designer and selecting Properties. Click the events button (yellow flashing lightening) to see the events available for the ABB button. As shown by the figure, you have already connected an event handler to the click event.

5

6

7

8

9

6.3.1_1B_Add

Note

It is the default event of the control that you get when you double-click it in the Designer. To add an event handler for another button event, bring up the Properties window and double-click the event you want to generate a handler for, for example a

FontChanged event handler. You will enter the code editor, the cursor inside the generated event handler.

On the Build menu, click Build Solution and check that you did not get any compilation errors.

To test the application you need to deploy it to a robot system. If there is no robot system available, you must create a robot system by using the System Builder of

RobotStudio.

Copy the assembly (*.dll) and the proxy assembly (*.gtpu.dll) from the bin\Debug

(or bin\Release) directory of your Visual Studio project to the HOME directory created by RobotStudio when your robot system was created.

Example showing default paths for copy/paste:

C:\Data\Visual Studio 2005\Projects\TpsViewMyApp\TpsViewMyApp\bin\Debug\

C:\Systems\sys1_508\HOME

Note! If you have already started the virtual FlexPendant you need to close it before pasting the dlls.

Start the virtual FlexPendant.

On the ABB menu, find your application and open it.

Continues on next page

72

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Step

10

Action

Click the button. The Hello World message will be displayed.

6.3.1_2Hello

Note

For more information on how to implement the additional features: application title, button background image, command bar with a menu item and an event handler to launch a standard view, see

Introduction to visual design support on page 68 .

Tip

When using the Virtual FlexPendant for test and debug you can automate the copy/paste procedure described in the preceding step seven. The following procedure explains it:

1 Right click the project icon in the Solution Explorer and select Properties.

2 For a C# project, select the Build Events tab. (For a VB project click the

Compile tab and then the Build Events button.)

3 Click the Edit Post-build button and add two commands which will copy the produced dlls to the directory of the robot system to run. Example: copy "$(TargetDir)$(TargetName).dll" "C:\Systems\sys1" copy "$(TargetDir)$(TargetName).gtpu.dll" "C:\Systems\sys1"

Note! Do not remove the default post build command lines, which create the assembly proxy (*gtpu.dll).

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

73

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Hands on - step 2

2

3

4

5

This section details how to program the remaining features of the Hello World application shown in preceding step nine: application title, button background image, command bar with a menu item. You will also learn how to implement an event handler for the Launch View command.

When you create a FlexPendant project you choose Empty or Form in the

FlexPendant SDK Project Wizard. For more information to understand the difference between them, see

Empty or Form? on page 81

. In our example Form is selected as the container control.

Step

1

Action

If you selected Empty for your project you can change it to Form by exchanging

TpsControl with

TpsForm directly in the source code, like this:

C#: public class TpsViewIRC5App14 : TpsForm, ITpsViewSetup,

ITpsViewActivation

VB:

Public Class TpsViewIRC5App14 Inherits TpsForm '(was TpsControl before) Implements ITpsViewSetup, ITpsViewActivation

Note

The Designer now shows the title bar on top of the container control.

Right-click somewhere in the middle of the container control and select Properties.

Enter “This is my Hello World application” at the Text property. See the tip of

Empty or Form? on page 81

if the Text property is not available.

Still using the TpsFormProperties window, expand the MainMenu property node.

Click the MenuItems property and the browse button which appears once the property is selected.

Continues on next page

74

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Step

6

Action

In the MenuItem Collection Editor, which is now launched, click the Add button.

Then enter “Launch View” at the Text property. Click OK.

6.3.1_4Hello

7

Note

The added menuItem has its own MenuItems property. You use it if the “Launch

View” command is to present a menu instead of working as a button on the command bar. How this can be done is further detailed in

Command bar on page 85

.

Add an event handler with code that will launch the standard Jogging view when the Launch View button is pressed.

Adding event handlers is done differently in Visual Studio depending on which programming language you are using.

For C#:

In the constructor, after the call to

InitializeComponent

, add a subscription to the click event of the “Launch View” command. Write: menuItem1.Click += then TAB twice. As you will notice, Visual Studio intellisense auto generates an event handler, and you only need to write the code for launching the Jogging view: this._launchService.LaunchView(FpStandardView.Jogging,null,false,out this._cookieJog)

For VB:

Add an event handler using the preceding drop down boxes the Visual Studio Code

Viewer. Find and select MenuItem1 in the left drop down box and the Click event in the right drop down box. The event handler is now auto generated for you, and the only thing you need to do is to write the code for launching the Jogging view

(see VB code in

Launching standard views on page 114 ).

8

3HAC036958-001 Revision: B

Note

There is no possibility to attach an event handler in the properties window, like you do for a

Button for example.

Declare the _launchService and the _cookieJog objects: private ABB.Robotics.Tps.Taf.ITpsViewLaunchServices

_launchService;private object _cookieJog;

Continues on next page

75

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.3.1 Introduction to visual design support

Continued

Step

9

Action

Retrieve the

_launchService object in the

Install method of your class:

13

14

10

11

12

6.3.1_5Hello

For VB code example, see

Installing ITpsViewSetup on page 113

.

In the designer, open the Properties window of the button.

Enter “Press Me” at the Text property.

Select the BackgroundImage property and browse to the Resources folder of the

FlexPendant SDK installation and import “IRB140.gif”.

(Default path: C:\Program Files\ABB Industrial IT\Robotics IT\SDK\FlexPendant

SDK 5.08\Resources)

Build, deploy and start the application, that is repeat step five to eight in

Hands on

- Hello world on page 70

.

Click the Launch VIew command.

The Jogging view should open up and get focus.

Tip

For more information about the possibilities to use already existing views for your application, see

Using launch service on page 113

and

Using standard dialog box to modify data on page 116 .

Visual design and user experience

There is another definition of the term Visual design, which is not in the scope of this manual. It has to do with how the design of the software user interface affects user experience. This is nonetheless an important topic for a FlexPendant application developer. Knowing what makes a user interface intuitive and easy to use is essential, as this is exactly what is expected from a custom operator interface.

Tip

A FlexPendant style guide comes with the installation of FlexPendant SDK. It will help you to present application functionality in an intuitive way, teaching best practices of visual design and user experience from the FlexPendant perspective.

It is a preliminary draft, but still very useful.

You may also want to study the Microsoft standard for visual design at: http://msdn.microsoft.com/library/default.asp?url=/library/en-us/dnwue/html/ch14a.asp

76

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.2 GUI controls and memory management

5.3.2 GUI controls and memory management

Overview

All of the FlexPendant SDK controls belong to the

ABB.Robotics.Tps.Windows.Forms

namespace. This namespace thus includes well over 40 classes and subclasses used to develop the user interface of a

FlexPendant application.

ABB.Robotics.Tps.Windows.Forms.TpsControl

is the base type of all

FlexPendant SDK controls.

TpsControl in turn extends

System.Windows.Forms.UserControl

TpsControl may be used as a container control of a FlexPendant view. It also has the default implementation of

Dispose

, which is called in order to free allocated memory for a control which should no longer be used.

You may wonder why this is necessary, as the .NET framework has a garbage collector, which should release the developer of the duty to free allocated memory.

The answer is the garbage collector does not always reclaim memory which is no longer used. Therefore, if you program an application meant to execute around the clock on a device with limited memory, you are still responsible for freeing memory which is no longer used. Neglecting to do so will result in permanent memory leaks.

How to avoid memory leaks

Look at this figure showing a number of controls (both ABB and Microsoft) and learn the basics about memory management for GUI controls. It is not so complicated, the most important thing is not to forget that cleaning up is your responsibility!

6.3.2_1Contr

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

77

5 Using the FlexPendant SDK

5.3.2 GUI controls and memory management

Continued

Learn and apply these the general rules for memory management of GUI controls.

• Controls with a graphical representation, e.g the ABB

Numpad

,

TabControl

,

GroupBox

,

TpsLabel

,

ListView and the Microsoft

PicureBox and

DataGrid in the figure, are automatically added to the controls collection in

InitializeComponent. It may look like this: this.Controls.Add(this.numPad1);

• If the preceding figure represents the first view of your application, controls with graphical representation will be disposed of by the base class of your view class when your application is shut down and the

Dispose method is called by TAF. This happens when the following statement in your

Dispose method is executed: base.Dispose(disposing);

• If, however, it represents a secondary view of your application (which is actually the case here, as you can tell from the close button on the command bar), you must call its

Dispose method from the first view when it is closed.

Its base class will then remove all controls that are part of its controls collection, like in the previous case.

• GUI controls that have no graphical representation, but are located in the

Components pane under the form, for example

GTPUSaveFileDialog

,

RapidDataBindingSource

,

AlphaPad and so on are NOT added to the controls collection by default. These are the ones that you need to be especially careful to remove, as no garbage collector will ever gather them.

If you forget to explicitly call

Dispose on such controls you will have caused a permanent memory leak. Carefully study the code example in the next section.

Note

Microsoft and ABB controls behave in the same way. The Microsoft

ImageList for example, which is commonly used in FlexPendant applications, has no graphical representation and must thus be explicitly removed by the application programmer.

Coding the Dispose method

The following code example shows how the

Dispose method of the view shown in the preceding figure can be coded. All controls located in the components pane in the Designer must be explicitly removed by the programmer. Controls with a graphical representation will be removed when

Dispose of the base class is executed.

protected override void Dispose(bool disposing)

{ if (!IsDisposed)

{ try

{ if (disposing)

{

//Removes SaveFile dialog

Continues on next page

78 3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.3.2 GUI controls and memory management

Continued if(this.gtpuSaveFileDialog1 != null)

{ this.gtpuSaveFileDialog1.Dispose(); this.gtpuSaveFileDialog1 = null;

}

//Removes RapidDataBindingSource if(this.rapidDataBindingSource1 != null)

{ this.rapidDataBindingSource1.Dispose(); this.rapidDataBindingSource1 = null

}

//Removes Alphapad if(this.alphaPad1 != null)

{ this.alphaPad1.Dispose(); this.alphaPad1 = null

}

//Removes FolderBrowserDialog if(this.gtpuFolderBrowserDialog1 != null)

{ this.gtpuFolderBrowserDialog1.Dispose(); this.gtpuFolderBrowserDialog1 = null

}

//Removes ImageList if(this.imageList1 != null)

{

}

}

} finally

{

//Removes all controls added to the controls collection base.Dispose(disposing);

} this.imageList1.Dispose(); this.imageList1 = null

}

}

Finally, as this is a secondary view, we should call its

Dispose method from the first view when it is closed down.

//This code is executed by the first view when the secondary view is closed void form2_Closed(object sender, EventArgs e)

{ if(form2 != null)

{ form2.Dispose(); form2 = null;

}

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

79

5 Using the FlexPendant SDK

5.3.2 GUI controls and memory management

Continued

CAUTION

If you forget to call

Dispose on controls that are not part of the control collection of the class there will be memory leaks. This may cause the FlexPendant to run completely out of memory and crash. Usually, this will not happen when you try out the functionality of your application, but when it is executed and used continuously during production. To verify that a GUI control is really disposed of, you may set up a subscription to its Disposed event for example, and verify that it is triggered when you close down the view.

CAUTION

All objects accessing robot controller services, that is, unmanaged resources, must also be removed by the application programmer. For more information, see

Memory management on page 167

.

Freeing allocated memory for a GUI control

You are recommended to remove a GUI control in the

Dispose method of the class that created it. If the control belongs to the first view of your application, it will be disposed of when TAF calls

Dispose at application shut down. If it belongs to a secondary view, you are responsible for disposing of the secondary view and its controls.

C#: if (this.controlX != null)

{ controlX.Dispose(); controlX = null;

} base.Dispose(disposing);

VB:

If disposing Then

If Not controlX Is Nothing Then controlX.Dispose() controlX = Nothing

End If

End If

MyBase.Dispose(disposing)

Note

When the last statement in the preceding code example is executed the base class will call

Dispose on all controls added to the controls collection in

InitializeComponent

. This means that you do not need to call

Dispose on such controls.

80

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.3 Container style

5.3.3 Container style

Overview

The container control of a FlexPendant application is 640x390 pixels, which is the exact size of the FlexPendant screen dedicated for a custom view. This section details the two different styles that can be used for a FlexPendant view: Empty and Form.

You select which one to use in the Style area of the FlexPendant SDK Project

Wizard. To the left in the wizard, a preview helps you see the difference between the two styles.

Here Form is selected. The preview illustration shows a

TpsForm

. It has a

CommandBar at the bottom and a

TpsCtrlTitleBar at the top.

6.2.2_1FormT

Note

When adding a new view to an existing FlexPendant project, you choose which control to use in the Add New Item dialog box. For more information on how to add a new view to an existing project, see

Container style on page 81 .

Empty or Form?

Your choice in the wizard determines the type that your view class will inherit. If you change your mind about this, it is easy to make the change directly in the auto generated code.

Empty

This is a plain

TpsControl

. It has neither a

CommandBar

, nor a

TpsCtrlTitleBar

.

The code definition of the class will look like this:

VB:

3HAC036958-001 Revision: B

Continues on next page

81

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.3.3 Container style

Continued

Public Class TpsViewMyApp Inherits TpsControl Implements

ITpsViewSetup, ITpsViewActivation

Form

This is a

TpsForm

, which is a specialized

TpsControl

.

The code definition of the class will look like this:

VB:

Public Class TpsViewMyApp Inherits TpsForm Implements

ITpsViewSetup, ITpsViewActivation

Note

Often Empty is chosen as the first view of an FlexPendant SDK application. For any secondary view, which is to be opened from the first one, Form is the recommended container control.

Note

When selecting Form you might wonder why the command bar is not visible in the designer.

The answer is that it remains invisible until a

MenuItem has been added to it.

This is done in the Properties window of the

TpsForm

, by applying the property

MainMenu.

Tip

If you select the

TitlePanel or the

CommandBar of a

TpsForm you will see that the Properties window is disabled. If you want to change the text of the title panel, or add menu items to the command bar, for example, you must select

TpsForm by clicking somewhere in the middle and then modify its Text or

MainMenu property.

How to build the command bar

The command bar is either ready-made, as for

TpsForm

, or used as a separate control available from the toolbox. If the command bar is ready-made, the design of it is done by modifying the MainMenu property of

TpsForm

. If used as a separate control, you design it by modifying its own properties. Apart from this, there is no difference in how you control the design.

An important thing to remember is that you have to manually add the code controlling that will happen when you click a menu item, as there are no event properties available in its Properties window.

Continues on next page

82

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.3 Container style

Continued

For more information on how to implement the control and its event handlers, see

Command bar on page 85 .

CAUTION

The command bar of the first view of a custom application should not have a

Close button. The reason is that all custom application must be closed down by

TAF, which happens when you click the close [ x ] button in the upper right corner of the FlexPendant display. (For definition of TAF, see

Terminology on page 17

or for more information on TAF, see

Understanding the FlexPendant application life cycle on page 38

.)

Adding a view to a custom application

To add another view to the FlexPendant project, you do not need to start a new project. The following procedure explains how to proceed:

Step

1

2

Action

Right-click the project node in the Solution Explorer, point to Add and select New

Item.

Select one of the FlexPendant container controls available in the dialog box. Normally it will be a Form.

Note! If you select Empty the code you write to open it from the first view is a bit different than if you are using Form as a secondary view.

This way all of your views make up a single dll, which is convenient. Most of the time there is no point in dividing the application into several dlls.

Launching the view

The code for launching the secondary view is simple. It may look like this:

//declare the secondary view as a private member private View2 _view2;

//create the view and add subscription to its closed event, then launch view private void button1_Click(object sender, EventArgs e)

{ this._view2 = new View2(); this._view2.Closed += new EventHandler(view2_Closed); this._view2.ShowMe(this);

}

//dispose of the view when it has been closed void view2_Closed(object sender, EventArgs e)

{ this._view2.Closed -= new EventHandler(view2_Closed); this._view2.Dispose(); this._view2 = null;

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

83

5 Using the FlexPendant SDK

5.3.3 Container style

Continued

Note

Make sure that there is a natural way for you to get back to the preceding view.

The most intuitive way of doing this is to click a Close button or an OK or Cancel button on the command bar. If the secondary view is a

TpsForm

, this event handler closes it: void menuItem1_Click(object sender, EventArgs e)

{ this.CloseMe();

}

Note

If you are using Empty as a secondary container control the code you write to launch it is: this._view2.Show();

It must be added to the first view’s control collection before it can be shown, like an ordinary .NET control.

84

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.4 Command bar

5.3.4 Command bar

Overview

For the end-user the command bar is a central FlexPendant control and an important means of interacting with the system. As described in

How to build the command bar on page 82

it can be ready-made or added to the container control from the

Visual Studio Toolbox.

How to add menu items

If you use the

Form container a command bar is built-in, but not visible until you add a MenuItem collection to the MainMenu property of

TpsForm

. How to do this is shown in step 5 - 6 of

Hands on - step 2 on page 74 .

If you use Empty as container the command bar needs to be added from the

Toolbox. In this case too, the commands are added as a collection of menu items.

6.3.4_1CmdBa

The command bar in this figure has a collection of three menu items: Launch View,

Close View and Close. Moreover, the Launch View menu item has its own collection of menu items: Rapid Data, Jogging and Backup Restore.

In the figure, as shown by the task bar, the Backup Restore view has been opened.

It has been done by clicking the Backup Restore menu item. The user has then returned to the Hello World application by using the task bar. If Close View is now pressed, the Backup Restore view will close down. The next section shows how event handlers for this command bar can be implemented.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

85

5 Using the FlexPendant SDK

5.3.4 Command bar

Continued

How to add menu item event handling

Subscriptions to menu item events and event handling cannot be added using the design support, but have to be implemented by hand in the source file. The following code example shows how the command bar in the preceding figure can be implemented.

6.3.4_2CmdBa

Note

To launch a standard view the

ITpsViewLaunchServices object, which can be saved by the

TpsView class in its

Install method, is needed. For more information, see

Using launch service on page 113 .

86

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.5 FlexPendant fonts

5.3.5 FlexPendant fonts

Overview

On the FlexPendant,

TpsFont is used instead of standard Windows fonts. By using

TpsFont you save limited device memory, as static references instead of new font instances will be used.

TpsFont

Tahoma is the default font of the FlexPendant. It is also the font usually used internally by

TpsFont

. A number of different font sizes are pre-allocated and can be reused. You are recommended to use TpsFont instead of creating new font instances for both ABB and .NET UI controls.

Note

To use Chinese or another language with non-western characters, you must use the FlexPendant font,

TpsFont

, for any UI controls. It internally checks what language is currently active on the FlexPendant and uses the correct font for that language.

Note

If you use other fonts than available on the FlexPendant, that is, Tahoma and

Courier New, the application will use Tahoma instead of the intended one.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

87

5 Using the FlexPendant SDK

5.3.6 The use of icons

5.3.6 The use of icons

Overview

It is easy to display icons, images and photos on the FlexPendant touch screen.

Utilizing this possibility is recommended, as many people find it easier to read pictures than text. Intuitive pictures can also be widely understood, which is a real advantage in a multinational setting.

Note

The operating system of the first generation FlexPendant device (SX TPU 1) does not support images of more than 256 colors.

CAUTION

Be aware of the limited memory resources of the FlexPendant device. Do not use larger images than necessary. Also see

Introduction on page 165

FlexPendant controls with images

Several FlexPendant controls support images, which are imported as bmp, jpg, gif or ico files when an Image, Icon or BackgroundImage property is set. These are some controls to be used with pictures:

MenuItem

Button

TpsCtrlTitlePanel

TabPage

ListViewItem

TpsForm

FPRapidData

,

FpToolCalibration

,

FpWorkObjectCalibration

GTPUSaveFileDialog

PictureBox and ImageList

There are also some Windows controls that can be used to display images.

Windows.Forms.PictureBox

is one such control. It can display graphics from a bitmap (.bmp), icon (.ico), JPEG or GIF file. You set the Image property to the preferred image either at design time or at run time.

Windows.Forms.ImageList

can manage a collection of Image objects. The

ImageList is typically used by another control, such as the

ListView or the

TabControl

. You add bitmaps or icons to the

ImageList

, and the other control can choose an image from the

ImageList index. How to use images for a

TabControl is detailed in

How to add tab images on page 90 .

Continues on next page

88

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.6 The use of icons

Continued

The TpsIcon class

The

TpsIcon class offers static references to a number of icons used in the standard FlexPendant applications. You may want to use some of these icons if they suit the application need.

TpsIcon belongs to the namespace

ABB.Robotics.Tps.Drawing

.

Tip

In the Reference Manual FlexPendant SDK, click the Search tab and search for

TpsIcon Members to get a short description of the ABB icons that are available as static properties.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

89

5 Using the FlexPendant SDK

5.3.7 TabControl

5.3.7 TabControl

Overview

The

ABB.Robotics.Tps.TabControl is used and implemented much in the same way as a regular

System.Windows.Forms.TabControl

. The possibility to use tab icons, however, is an additional feature of the ABB

TabControl

.

Illustration

The following screenshot shows a

TabControl and its Properties window. To add or remove tab pages you click the little arrow in the top right corner of the control or click Add new TabPage at the bottom of the Properties window.

6.2.4_1TabCo

Note

The ABB

TabControl has no TabPages property. Depending on where in the

TabControl you click, you select either the entire

TabControl or one of the

TabPages

. To view the Properties window for the T_ROB1

TabPage in the figure, you would have to click the T_ROB1 tab and then the T_ROB1 page following the tab.

How to add tab images

The following procedure explains how you use the ImageList property to add icons to the tabs of the

TabControl

:

2

3

Step

1

Action

Drag a

System.Windows.Forms.ImageList

to the Designer area. As you will notice it has no visual representation, but is placed on the components pane following the container control.

Display the Properties window of the ImageList.

Click the property Images and then the browse button, which will appear.

Continues on next page

90

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.7 TabControl

Continued

Step

4

Action

Click Add and import an image. Repeat until you have added the icons your Tab-

Control needs.

5

6

6.2.4_2TabCo

Now display the Properties window of the

TabControl and select your

ImageList as the ImageList property.

Select one of the tab pages and set the property ImageIndex, which defines which of the images in the

ImageList is to be used for the tab. Repeat this procedure for all tab pages.

How to add an event handler using the Properties window

It is easy to attach an event handler to a control by using the Properties window.

This procedure shows how to make something happen when you click a tab to select another tab page:

Step

1

Action

In the Designer, select the

TabControl and display the Properties window.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

91

5 Using the FlexPendant SDK

5.3.7 TabControl

Continued

Step

2

Action

Display the events available for the control by clicking the Events button.

3

4

5

6.3.4_3CmdBa

Select the SelectedIndexChanged event and double click. A method name is now auto generated for the SelectedIndexChanged event. The code view takes focus, the cursor placed inside the generated event handler.

Add code to make something happen. For now this code will do: this.Text = "TabControl notifies change of tab pages";

This will change the title text of the TpsForm when a tab is clicked.

Test the functionality by building, deploying and starting the application. For more information, see step 5-8 in

Hands on - Hello world on page 70

.

Note

The subscription to the event has been done under the hood, and you do not need to bother about it. If you use C# you will notice that some code adding the subscription has been inserted in the

InitializeComponent method: this.tabControl1.SelectedIndexChanged += new

System.EventHandler(this.tabControl1_SelectedIndexChanged);

Disposing TabControl

You do not need to explicitly call

Dispose on the

TabControl object. The reason is that

InitializeComponent adds the tab pages to the controls collection of the

TabControl

, and the

TabControl itself to the control collection of the container class. this.Controls.Add(this.tabControl1);

The

TabControl is thus removed when the

Dispose method of your container class calls

Dispose on its base class like this: base.Dispose(disposing);

92

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.8 Button, TextBox and ComboBox

5.3.8 Button, TextBox and ComboBox

Overview

The FlexPendant button, text box and combo box controls are not very different from the equivalent Windows controls.

Using Button

A common size of a FlexPendant

Button is 120 * 45 pixels; it can be a lot smaller than its default size. As opposed to a Windows button it can display an image. As pointed out in

Illustration on page 90

you use the property BackgroundImage and browse for the image to be displayed.

Using TextBox

The

TextBox control is multiline by default and uses the typical FlexPendant scroll bars as shown in the following figure.

6.2.7_1TextB

Using ComboBox

The

ComboBox is very similar to the

System.Windows.Forms.ComboBox

, but is visually improved to suit the FlexPendant touch screen. It can be statically populated using the Items property as illustrated by the figure. If you wish to populate it dynamically, you need to write code for it.

6.2.7_2Combo

SelectedIndexChanged is the most commonly used among the events. It occurs when you select another item from the list.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

93

5 Using the FlexPendant SDK

5.3.9 AlphaPad

5.3.9 AlphaPad

Overview

The

AlphaPad control is a virtual keyboard, which enables you to enter strings. It covers the whole FlexPendant display. The figure shows its appearance in run time.

6.2.10_1Alph

The

AlphaPad has no graphical representation in design-time. When dragged from the Toolbox to the Designer it is placed in the components pane, as shown in the figure in the next section. Code is generated for it similar to controls that are visually laid out on the form in design-time.

Launching the AlphaPad

You need to write some code to launch the virtual keyboard. The following code explains how you do it:

C#: this.alphaPad1.ShowMe(this);

VB:

Me.AlphaPad1.ShowMe(Me)

Note

The code for launching the

AlphaPad should be executed by an appropriate event handler.

Continues on next page

94

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.9 AlphaPad

Continued

Adding event handlers

The Properties window can be used to program

AlphaPad event handlers. You double click the event you want to respond to. This takes you to the code editor, the cursor placed inside the auto generated event handler, where you can write code to save user input to a member variable for example: if (alphaPad1.SelectedText != string.Empty)

{

_userInput = alphaPad1.SelectedText;

}

6.2.10_2Alph

Validating the result at the Closing event

The

Closing event is generated when the OK or Cancel button of the

AlphaPad is pressed. You can use this event to validate the string entered by the user. You can set the Cancel property of the event argument to true if you want the AlphaPad to remain open until a valid input value has been entered:

VB:

Private Sub NamePad_Closing(sender As Object, e As

System.ComponentModel.CancelEventArgs) Handles NamePad.Closing

If NamePad.SelectedText.CompareTo("No Name") = 0 &&

NamePad.DialogResult = System.Windows.Forms.DialogResult.OK

Then e.Cancel = True

End If

End Sub

C#: private void namePad_Closing(object sender,

System.ComponentModel.CancelEventArgs e)

{ if ((this.namePad.SelectedText.CompareTo("No Name") == 0) &&

(this.namePad.DialogResult ==

System.Windows.Forms.DialogResult.OK))

{ e.Cancel = true;

}

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

95

5 Using the FlexPendant SDK

5.3.9 AlphaPad

Continued

Using the result at the Closed event

The Closed event has to be caught by an event handler, as the object cannot be disposed of until it has been closed. The result may be retrieved in this event handler or in the Closing event handler. First check that OK and not Cancel was pressed, then retrieve user input. Finally the AlphaPad should be disposed of.VB:

Private Sub NamePad_Closed(sender As Object, e As EventArgs) Handles

NamePad.Closed

If NamePad.DialogResult = Windows.Forms.DialogResult.OK Then

Me.answer = NamePad.SelectedText

End IfNamePad.Dispose()

End Sub

C#: private void namePad_Closed(object sender, EventArgs e)

{ if (this.namePad.DialogResult ==

System.Windows.Forms.DialogResult.OK)

{ this.answer = this.namePad.SelectedText;

} this.alphaPad1.Dispose();

}

Removing the AlphaPad control

The

AlphaPad is NOT added to the control collection, and will therefore NOT be disposed of by the base class of its container.

You are responsible for explicitly calling its

Dispose method when it is no longer used. In the preceding example, this is done at the

Closed event. This implies that a new

AlphaPad instance is created the next time its launch event is triggered.

Another way of dealing with this is to let the instance created by the Designer live until its container view is closed. This alternative means destroying it in the

Dispose method of the container class: this.alphaPad1.Dispose();

CAUTION

If you forget to call

Dispose on an AlphaPad control you will have a memory leak. For further information see

GUI controls and memory management on page 77 .

96

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.10 ListView

5.3.10 ListView

Overview

The

ABB.Robotics.Tps.Windows.Forms.ListView

is very similar to a standard

.Net

ListView

. The main difference is that its appearance is somewhat adapted to the use of a touch screen, as can be seen in the figure.

You can use the

ListView control in a variety of ways. Usually you use it to display a list of items with item text and, optionally, an icon to identify the type of item. By using the CheckBoxes property it is also possible to have a check box appear next to each item in the control, allowing users to check the items they want to perform an action on.

Illustration

The figure shows the Designer. You see two different ABB

ListView lists, a standard .Net

ImageList in the components pane under the lists and the

Properties window for the Calibration, HotEdit list.

6.3.10_1List

Using properties to control appearance

The first list has CheckBoxes set to true. To have columns displayed View must be set to Details. The columns are created by selecting Columns and adding any number of columns in the ColumnHeader Collection Editor. Scrollable has been set to true to enable you to scroll the list to see all items. To have the current number of list items displayed ShowNumberOfItems has been set to true. By using

Sorting the list items can be alphabetically sorted, in this case in Descending order. The list is statically populated, using the Items property.

The View property of the other list is set to LargeIcon instead of Details. To display icons a standard .Net ImageList is used. You first launch the Properties window for the ImageList and add the images you want to use. At the LargeImageList

3HAC036958-001 Revision: B

Continues on next page

97

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.3.10 ListView

Continued property of the

ListView you select the image list, and for each Item you select the ImageIndex to use, as is shown in the ListViewItem Collection Editor.

Using the Properties window you can also add event handling. The most commonly used event is SelectedIndexChanged, which is triggered when a new list item is selected.

The Properties window can be used to statically populate the list. Usually, however, lists are populated dynamically. In

Getting signals using SignalFilter on page 150

there is a code example, which shows how I/O signals are dynamically displayed in an ABB

ListView

.

ABB specific properties

These properties are specific for the ABB

ListView

:

Property

MultiSelect

Scrollable

SelectionEnabledOver-

Scrollbuttons

ShowNumberOfItems

ShowSelection

Usage

Specifies whether multiple items in the control can be selected.

The default is false.

Specifies whether a scroll bar is added to the control when there is not enough room to display all items. The default is true.

Note! The typical FlexPendant scroll bars are used by the first list in the preceding figure.

Specifies whether a touch inside the scroll region should select an item or scroll the list. The default is false.

Specifies whether the current number of items in the list is displayed. The default is true. Scroll bars should be added to the control to allow you to see all the items. If the list is not scrollable the default value is false.

Specifies whether selection is shown or not. The default is false.

98

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.11 CompactAlphaPad and NumPad

5.3.11 CompactAlphaPad and NumPad

Using CompactAlphaPad

The

CompactAlphaPad control is used to enable user input. The input can be in the form of capital letters or numbers depending on the property

ActiveCharPanel

, which can be set to

Characters or

Numeric

. It has a fixed size, big enough for the use of a finger to click its keys. There are properties available to define whether the numerical panel should support numerical operands, special characters, space and comma. All these properties are set to true in the figure:

6.3.11_1Comp

In order for your application to use the user input, you must connect to a text box, which displays the text or figures entered. This connection has to be coded manually, for example in the constructor, after the call to

InitializeComponent

, for example: this.compactAlphaPad1.Target = this.textBox1;

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

99

5 Using the FlexPendant SDK

5.3.11 CompactAlphaPad and NumPad

Continued

Using NumPad

The

NumPad is very similar to the CompactAlphaPad. You have to create a

Target to use the input, for example: this.numPad1.Target = this.textBox2;

6.3.11_2Nump

100

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.12 GTPUMessageBox

5.3.12 GTPUMessageBox

Overview

GTPUMessageBox is the message box control to be used by FlexPendant applications. You should not use the standard

.NET MessageBox

.

Design issues

The

GTPUMessageBox.Show

arguments include an owner argument, which is the control that displays the

MessageBox

, and a callback, which is a

MessageBoxEventHandler called when the MessageBox is closed.

Except this, it is used in the same way as the regular Windows

MessageBox

. It is used together with the regular Windows

MessageBoxButtons and

MessageBoxIcon

.

Simple code example

The following screenshot and code show how to display a simple message on the

FlexPendant using the

GTPUMessageBox

.

6.2.6_1WinBu

string message = "You did not enter a server name. Cancel this operation?"; string caption = "No Server Name Specified";

GTPUMessageBox.Show(this, null, message, caption,

System.Windows.Forms.MessageBoxIcon.Question,

System.Windows.Forms.MessageBoxButtons.YesNo);

Note

Sometimes it can be a bit tricky to get the first argument right. The owner might be this, this.Parent or even this.Parent.Parent

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

101

5 Using the FlexPendant SDK

5.3.12 GTPUMessageBox

Continued

Using a callback

The logics in your program determines if there is any need for a callback. In the previous example the callback argument was null

.The message box will close down after the user has answered the question, no matter if the answer is Yes or

No.

If we think about the message, it seems likely however, that something should happen if you click No. Let us change the implementation and use a callback for this purpose:

GTPUMessageBox.Show(this, new

MessageBoxEventHandler(OnServerMessageClosed), message, caption, System.Windows.Forms.MessageBoxIcon.Question,

System.Windows.Forms.MessageBoxButtons.YesNo);

//implement callback private void OnServerMessageClosed(object sender,

ABB.Robotics.Tps.Windows.Forms.MessageBoxEventArgs e)

{ if(e.DialogResult == System.Windows.Forms.DialogResult.No)

{

//Use default server...

}

}

If we really do not want to take action depending on how the user responds, it makes more sense to use OK instead of Yes and No as message box buttons, e.g:

GTPUMessageBox.Show(this, null, "You are not allowed to perform this operation, talk to your system administrator if you need access", "User Authorization System", MessageBoxIcon.Hand,

MessageBoxButtons.OK);

Note

The last example uses a better message box title then the previous ones. The title preferably should tell you from which part of the system the message originates.

102

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.13 GTPUFileDialog

5.3.13 GTPUFileDialog

Overview

The FlexPendant SDK provides a number of file dialog box used by the end-user to interact with the file system of the robot controller. These controls all inherit the abstract class

GTPUFileDialog and belong to the namespace

ABB.Robotics.Tps.Windows.Forms.

File dialog types

There are three different types of file dialog controls:

Use...

GTPUOpenFileDialog

GTPUSaveFileDialog

GTPUFolderBrowserDialog

when you want to...

Enables you to specify a file to be retrieved from the controller file system.

Enables you to specify a file to be saved to the controller file system.

Enables you to specify a folder on the controller file system.

Note

The Open/Save/Browse file dialog box represent a convenient way for you to specify folder and filename for a file operation. You should know, however, that the dialog box themselves do not perform any file operation, they only provide the controller file system path to be used by your application.

CAUTION

When added to the Visual Studio Designer from the Toolbox, these controls will be placed in the components pane. They must be explicitly removed by a call to their

Dispose method, for example in the

Dispose method of the class that created them.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

103

5 Using the FlexPendant SDK

5.3.13 GTPUFileDialog

Continued

Illustration

The following is a screenshot of the

GTPUSaveFileDialog

. The other file dialog box have almost the same appearance and the way they work is very similar. Using the icons of the command bar you create new folders and browse the controller file system. Together with the list and the textbox, you specify a remote path. The

FileName property should be read to retrieve this path. It returns the complete path to the controller file system, even though only the file name is visible in the

File name textbox

6.3.13_1Save

Note! The button after the File name textbox opens the virtual keyboard, enabling you to change the name of the file to be saved. The Filter property of the control is set to TEXT(*.txt)|*.txt. The first part of the setting is displayed in the filter textbox.

Continues on next page

104

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

This is the Properties window of this dialog:

5 Using the FlexPendant SDK

5.3.13 GTPUFileDialog

Continued

6.3.13_2Save

Implementation details

The Properties window gives a clear description of a selected property, as can be seen in the preceding figure. Here only a few important properties will be detailed:

Property

Filter

FileName

InitialDirectory

Details

Carefully observe the string format when you set this property, for example: Program Files (*.pgf)|*.pgf

The first part is displayed in the combo box and the second part is used by the SDK to retrieve the correct files to be displayed in the list. You can also specify several filters, which the user can choose from.

Program Files (*.pgf)|*.pgf|All Files (*.*)|*.*;

Cannot be accessed in design-time by using the Proper-

ties window, but should be manually coded when the file dialog is launched if it is a save file dialog.

When the dialog is closed, you should read this property.

It holds the remote path and file name of the file to be opened, or the remote path and file name of the file to be saved.

Note! Remember that remote refers to the controller file system and local to the FlexPendant file system.

Cannot be accessed in design-time by using the Proper-

ties window. Specifies the initial directory to be displayed by the file dialog box.

Note

For your program to use the controller path selected by the end user, you need to read the FileName property at the

Closing/Closed event of the file dialog.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

105

5 Using the FlexPendant SDK

5.3.13 GTPUFileDialog

Continued

Example

This piece of code sets

InitialDirectory and

FileName

, then sets up a subscription to the

Closed event and finally displays the

GTPUSaveFileDialog saveFileDialog.InitialDirectory = initialDir; saveFileDialog.FileName = programName; saveFileDialog.Closed += new

EventHandler(SaveProgram_FileDialog_EventHandler); saveFileDialog.ShowMe(_parent);

The code of the

SaveProgram_FileDialog_EventHandler method retrieves the specified path of the remote file system, including the file name, by reading the

FileName property: string remotePath = saveFileDialog.Filename;

Note

The file has not yet been saved to the robot controller. To do that you should call

FileSystem.PutFile using the retrieved path as the remoteFile argument.

Likewise, to load a specified remote file to the FlexPendant file system you should use the retrieved path in the call to

FileSystem.GetFile.

106

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

5.3.14 Data of RAPID data and IO signals

What is databinding?

Databinding is the process of binding a property of a GUI control to a data source, so that the property automatically reflects the value of the data source. In .NET CF

2.0 this functionality was simplified with the

BindingSource class. This class encapsulates the complexity related to setting up and managing databinding. It allows you to connect a

RapidDataBindingSource or a

SignalBindingSource to a GUI control without having to write a single line of code. (Except the

Dispose call when the binding sources are no longer needed.)

FlexPendant SDK classes to be used as binding sources

In the FlexPendant SDK there are two classes that inherit .NET

BindingSource

:

RapidDataBindingSource and

SignalBindingSource.

These classes enable binding to RAPID data and IO signals respectively. They belong to the

ABB.Robotics.DataBinding

namespace and the assembly you need to reference is ABB.Robotics.DataBinding.dll.

RapidDataBindingSource

By using

RapidDataBindingSource an automatic update of the bound GUI control takes place when the value of the specified RAPID data source in the controller has changed, or when the control is repainted.

SignalBindingSource

By using

SignalBindingSource an automatic update of the bound GUI control takes place when the value of the specified IO signal in the controller has changed, or when the control is repainted.

Note

It is only possible to use persistent RAPID data (PERS) as data source.

Note

If you want to let users modify RAPID data, launching the standard FlexPendant application Program Data from your application is probably the best alternative.

For more information, see

Using standard dialog box to modify data on page 116

.

GUI example

Many different controls can be used with binding sources, for example

TpsLabel

,

TextBox

,

ListView and so on. The following screenshot shows two

System.Windows.Forms.DataGrid

controls that each bind to several objects defined in a

RapidDataBindingSource and a

SignalBindingSource

. The labels in each

GroupBox are bound to the same sources. As you see the grid displays all objects defined in the

BindingSource control, whereas each label displays the currently selected grid row.

When a signal or a data value changes this GUI is automatically updated with the new value. You do not have to write any code make this happen, as setting up

3HAC036958-001 Revision: B

Continues on next page

107

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

Continued subscriptions and updating the user interface is done by the underlying implementation.

6.3.14_1FPVi

CAUTION

To avoid any memory leaks an explicit call to the

Dispose method of

BindingSource controls must be made. However, the wrapper-objects

SignalObject and

RapidDataObject created for you are disposed of under the hood, so you do not need to worry about it.

Continues on next page

108

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

Continued

How to use the Visual Studio designer for

This section explains how to create the FlexPendant view shown in the previous section. First a

RapidDataBindingSource control with bindings to specified

RAPID data is created.Then the DataBindings property of a

TpsLabel is used to bind the label to the binding source. Finally a standard .NET

DataGrid is bound to the same binding source.

Step

1

Action

Start by dragging a

RapidDataBindingSource from the Toolbox to the Designer.

It will be placed in the Components pane under the form. Open the Properties window and select the RapidDataList property to add the RAPID data you are interested in. For each new RapidDataObject member you must specify module name, task name and name of the persistent RAPID data to bind.

6.3.14_2Bind

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

109

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

Continued

Step

2

Action

The next step is to open the Properties window for the label that is to display the value of the RAPID data. Expand the DataBindings node and select Advanced.

6.3.14_3Prop

Continues on next page

110

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

Continued

Step

3

Action

In the Advanced Binding dialog box that appears, choose the already created

RapidDataBindingSource in the Binding combo box, at the same time specifying which one of the RapidDataObject properties you want to bind to, in this case Value.

(The other properties available are variable name, task name and module name, as can be seen in the figure in step 1.)

You also select your preferred Data Source Update Mode, usually OnProper-

tyChanged. The yellow marking in the list to the left shows that the binding has been done to the Text property of the label. When a control has been bound to a data source you will see the same yellow marking in its Properties window, at the bound property. For more information, see illustration on step 2.

6.3.14_4Adva

Note

If a label has been bound to a data source with several member objects, the first one in the list is the one by default displayed by the label. If the selected index of the list changes (if you select a row in the grid for example) the label is updated automatically to show the value of the selected index. For more information, see

the illustration in Data of RAPID data and IO signals on page 107

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

111

5 Using the FlexPendant SDK

5.3.14 Data of RAPID data and IO signals

Continued

Step

4

Action

Now launch the Properties window of the

DataGrid control. Set ColumnHeaderVisible to true and select your data source at the DataSource property.

6.3.14_5Grid

Note

The

DataGrid control displays only one row in design-time (For more information, see the illustration of step 1). In run-time, however, the entire collection of Rapid-

DataObject members is displayed (see the figure in

Data of RAPID data and IO signals on page 107 ).

SuspendBinding/ResumeBinding

SuspendBinding() and

ResumeBinding() have extended functionality compared to the methods of the inherited

BindingSource class. Removing/adding subscriptions have been added, as subscribing to signals and RAPID data can be resource consuming. These methods can be used in the

Deactivate/Activate methods, which are executed each time you switch back and forth between different applications using the FlexPendant task bar. For more information, see

Application

Framework usage - ITpsViewActivation on page 172 .

If you suspend the binding you no longer get any updates if the data source is changed. However, the binding still exists, so if DataSourceUpdateMode is set to

OnValidation the value will be updated when you repaint the control, as the value from the controller will be read before it is repainted.

Method

SuspendBinding

ResumeBinding

Description

Suspends the binding and value change event.

Resumes the binding and value change event.

112

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.4.1 Using launch service

5.4 Launching other views

5.4.1 Using launch service

Overview

The FlexPendant SDK provides a launch service, which enables a FlexPendant

SDK application to start a standard ABB application, such as the program editor or the jogging view.

It is also possible to start another custom application by specifying proxy assembly name and the application view class.

For more information about how to add and launch another view of your own application, see

Adding a view to a custom application on page 83

.

Note

To launch a view in order to edit a specified rapid data instance, another mechanism is available. For more information, see

Using standard dialog box to modify data on page 116

.

Installing ITpsViewSetup

It is only classes that inherit the

ITpsViewSetup interface that can launch other applications. The

Install method, which is called when your custom application is launched, has a sender argument. Your application needs to save this object to use the

ITpsViewLaunchServices interface. It is used by the launch service to call

LaunchView and

CloseView

.

VB:

//declaration

Private iTpsSite As ITpsViewLaunchServices

.....

//Install method of the TpsView class

Function Install(ByVal sender As System.Object, ByVal data As

System.Object) As Boolean Implements ITpsViewSetup.Install

If TypeOf sender Is ITpsViewLaunchServices Then

// Save the sender object for later use

Me.iTpsSite = DirectCast(sender, ITpsViewLaunchServices)

Return True

End If

Return False

End Function

C#:

//declaration private ITpsViewLaunchServices iTpsSite;

......

//Install method of the TpsView class bool ITpsViewSetup.Install(object sender,object data)

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

113

5 Using the FlexPendant SDK

5.4.1 Using launch service

Continued

{

} if (sender is ITpsViewLaunchServices) {

// Save the sender object for later use this.iTpsSite = sender as ITpsViewLaunchServices; return true;

} return false;

Launching standard views

Using the

FpStandardView enumerator, the following standard views can be started using the launch services:

• Program editor

• Program data

• Jogging

• Logoff

• Backup/Restore

Tip

Launching the Program data view is the best way to let end-users create new

RAPID data.

Note

To launch the program editor an initialization object of

RapidEditorInitData type can be used as argument. It specifies the task, module and row that the

Program editor should display when it opens. For the other standard views no

InitData can be used.

LaunchView / CloseView example

In the following example, the program editor is launched at a specified routine.

First initData is created. Then the reference to the sender object, retrieved by the

Install method in the previous example, is used to call

LaunchView

.

The cookie out argument is later used to specify the view to be closed by the

CloseView method.

VB:

Dim initData As RapidEditorInitData = New RapidEditorInitData

(ATask, AModule, ARoutine.TextRange.Begin.Row)

If Not (Me.iTpsSite.LaunchView(FpStandardView.RapidEditor, initData,

True, Me.cookieRapidEd) = True) Then

GTPUMessageBox.Show(Me, Nothing, "Could not start RapidEditor application")

Return

End If

......

Me.iTpsSite.CloseView(Me.cookieRapidEd)

Continues on next page

114

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.4.1 Using launch service

Continued

C#:

RapidEditorInitData initData = new RapidEditorInitData(task, module,routine.TextRange.Begin.Row; if(this.iTpsSite.LaunchView(FpStandardView.RapidEditor,initData,true,out this.cookieRapidEd)!= true) {

GTPUMessageBox.Show(this, null,"Could not start RapidEditor application"); return;

}

.....

this.iTpsSite.CloseView(this.cookieRapidEd);

What happens if the specified view is already open when the call is made? The third argument specifies application behavior in this case. If true

, another instance of the view is launched. If false

, the already opened view gets focus. Notice, however, that creating a new instance is not possible for all standard views. The

Jogging view, for example, is not allowed multiple instances.

Launching custom applications

The launch service can also be used to launch another FlexPendant SDK application. The name of the proxy assembly along with the fully qualified class name should be used as arguments.

VB:

If Not (Me.iTpsSite.LaunchView("TpsViewCustomApp.gtpu.dll",

"ABB.Robotics.SDK.Views.TpsViewCustomApp", Nothing, True,

Me.cookieUser) = True) Then

GTPUMessageBox.Show(Me, Nothing, "Could not start User application")

Return

End If

C#: if (this.iTpsSite.LaunchView("TpsViewCustomApp.gtpu.dll",

"ABB.Robotics.SDK.Views.TpsViewCustomApp", null, true, out this.cookieUser)!= true) {

GTPUMessageBox.Show(this, null,"Could not start User application"); return;

}

Note

It is the namespace of the proxy assembly, ABB.Robotics.SDK.Views,which should be used to specify the

TpsView class.

Note

By using the argument cookieUser your application can close the launched custom application in the same way as in the preceding

Using launch service on page 113

example.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

115

5 Using the FlexPendant SDK

5.4.2 Using standard dialog box to modify data

5.4.2 Using standard dialog box to modify data

Overview

The

FpRapidData

,

FpToolCalibration and

FpWorkObjectCalibration dialog box take a

RapidData reference as argument. When the dialog is opened it allows you to directly operate on the referenced RapidData object, for example modifying a RAPID data variable or calibrate a work object. These dialog box are the ones used by the standard ABB applications. They are ready-made and cannot be modified, except for the title.

Creating the dialog box

As with all secondary dialog box, the reference to the dialog should be declared as a class variable. This is to make sure that the reference is available for

Dispose

.

The

RapidData reference can be declared locally if it is disposed immediately after use, or else as a class variable. When the dialog has been created the title can be set using the

Text property. A

Closed event handler should be added to dispose the dialog. All three dialog box are created in the same way:

VB:

Private ARapidData As RapidData

Friend WithEvents FpRD As FpRapidData

.....

Me.ARapidData = Me.AController.Rapid.GetRapidData(ATaskName,

AModuleName, AVariableName)

Me.FpRD = New FpRapidData(Me.ARapidData)

Me.FpRD.Text = Me.ARapidData.Name

AddHandler Me.FpRD.Closed, AddressOf Me.FpRD_Closed

Me.FpRD.ShowMe(Me)

C#: private FpRapidData fpRD; private RapidData aRapidData;

......

this.aRapidData = this.aController.Rapid.GetRapidData(taskName, moduleName, variableName); this.fpRD = new FpRapidData(this.aRapidData); this.fpRD.Text = this.aRapidData.Name; this.fpRD.Closed += new EventHandler( fpRD_Closed); this.fpRD.ShowMe(this);

Note

Verify that the

RapidData is of correct

RapidDataType for the dialog before using it, that is, tooldata for the FpToolCalibration dialog box and wobjdata for the FpWorkObjectCalibration dialog box. For more information, see

Using standard dialog box to modify data on page 116

.

Continues on next page

116

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

Type checking

5 Using the FlexPendant SDK

5.4.2 Using standard dialog box to modify data

Continued

Note

The FpRapidData dialog box is created with a RapidData as in argument. If the

RapidData is an array, an index argument is used to specify which element should be displayed (the first element is 1).

When calling the

FpToolCalibration or

FpWorkObjectCalibration constructor the

RapidData value should be type checked before use:

VB:

If TypeOf Me.ARapidData.Value Is ToolData Then

Me.FpTC = New FpToolCalibration(Me.ARapidData)

.....

End If

C#: if (this.aRapidData.Value is ToolData)

{ this.fpTC = new FpToolCalibration(this.aRapidData);

....

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

117

5 Using the FlexPendant SDK

5.5.1 ABB.Robotics.Controllers

5.5 Using the Controller API

5.5.1 ABB.Robotics.Controllers

Controller API

To access the functions of the robot controller you utilize the class libraries of the

FlexPendant SDK called Controller Application Programming Interface or CAPI.

The assembly you need to reference to use controller functionality is

ABB.Robotics.Controllers.dll.

CAPI domains

The top CAPI object is the

ABB.Robotics.Controllers.Controller

, which has to be created before any access to the robot controller.

The class libraries are organized in different domains (namespaces), as shown in the following screenshot, by the contents tab of the Reference Manual FlexPendant

SDK. The name of a domain tells you something about the kind of services you can expect from it.

6.4.1_1FP-Na

Continues on next page

118

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.1 ABB.Robotics.Controllers

Continued

CAPI and controller domains

This is a simplified illustration of how some

ABB.Robotics.Controllers

domains communicate with their respective domains in the robot controller:

6.4.1_2Contr

Note

In the normal case, a single

Controller object is created and used throughout the application, its lifetime corresponding to that of the application.

What controller functionality is provided?

Plenty of robot controller functionality is offered by the classes and methods of the FlexPendant SDK.

This table presents short descriptions of the kind of services that the different CAPI domains provide:

CAPI domain

Controllers

Services

Information about the controller, such as IP address, current user,

Mac address, operating mode, controller state and so on. Notification when operating mode, state or mastership has changed. Backup and restore. Check if you have the required UAS grant and so on.

ConfigurationDomain Read or write the value of a configuration parameter to the configuration database of the controller.

EventLogDomain Notification when a new event log message has been written to the controller. Title, message, category, sequence number and time stamp of the message.

FileSystemDomain

IOSystemDomain

MotionDomain

Create, rename or remove files and directories in the controller file system. Retrieve a file from the controller and store it on the Flex-

Pendant and vice versa.

Read and modify I/O signals. Notify when a signal value has changed.

Get/set the coordinate system and motion mode for jogging of the active mechanical unit. Information whether the mechanical unit is calibrated or not. Provide name, task, number of axes, active tool and work object and so on. of the mechanical unit. Notify when data of the mechanical unit has changed. Send a start jogging or a stop jogging request to the robot controller.

3HAC036958-001 Revision: B

Continues on next page

119

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.1 ABB.Robotics.Controllers

Continued

CAPI domain

RapidDomain

SystemInfoDomain

Services

Notification when execution status has changed. Start and stop

RAPID execution. Load Rapid programs. Create, read and write

RAPID data. Notification when RAPID data or RAPID program has changed. Notification when program pointer has changed. Search for RAPID symbols and so on.

Information about the active system of the robot controller, for example RobotWare version, system name, release and system paths, existing system options and installed additional options.

Releasing memory

Using CAPI you will create objects that reference unmanaged resources. (For more information, see

Definitions on page 17 .) It is necessary to explicitly deallocate the

memory of such objects by calling their

Dispose method when they are no longer needed (at application shut down at the latest). Otherwise your application will leak memory, which is a scarce resource on the FlexPendant platform.

Note

You may prevent memory leaks and other pitfalls, by studying the chapter

ABB.Robotics.Controllers on page 118 .

FlexPendant SDK reference documentation

Although this manual covers a great deal of the FlexPendant SDK functionality, it is by no means complete. The Reference Manual FlexPendant SDK, which you open from Windows Start button, is the complete reference to the functionality offered by the class libraries.

It also gives valuable code samples and remarks about methods requiring different

UAS grants and so on., which is not included in this manual.

120

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.2 Accessing the controller

5.5.2 Accessing the controller

Overview

Making use of controller functionality requires special attention. Disposal of CAPI objects when closing a view or the entire application is vital to save memory.

Another pitfall that must be avoided is updating the user interface on a worker thread.

Controller instance

Before accessing the controller functionality you need to instantiate the

Controller object. The best place to do this is normally in the

Install method, which is called by TAF after the constructor of your view class has executed.

The

Controller declaration should be done on class scope level:

VB:

Private AController As Controller

C#: private Controller aController;

The recommendation is to instantiate the

Controller object in the

Install method:

VB:

AController = New Controller

C#: aController = new Controller();

Using the

Controller object you can access IO signals, RAPID data variables, event log messages and so on. Most of these objects will be created explicitly and should be disposed of explicitly.

Note

Avoid placing any code that may result in an exception before the method

InitializeComponent

. Then at least you have a user interface, where you can display a

MessageBox with information about what went wrong.

Note

It is recommended that if several classes need to access the controller, they all reference the same

Controller object.

Subscribing to controller events

The

Controller object provides several public events, which enable you to listen to operating mode changes, controller state changes, mastership changes and so on.

VB:

AddHandler AController.OperatingModeChanged, AddressOf UpdateOP

AddHandler AController.StateChanged, AddressOf UpdateState

AddHandler AController.MastershipChanged, AddressOf UpdateMast

3HAC036958-001 Revision: B

Continues on next page

121

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.2 Accessing the controller

Continued

AddHandler AController.BackupFinished, AddressOf UpdateBack

C#:

AController.OperatingModeChanged += new

OperatingModeChangedEventHandler(UpdateOP);

AController.MastershipChanged += new

MastershipChangedEventHandler(UpdateMast);

Controller.BackupFinished += new

BackupFinishedEventHandler(UpdateBack);

Controller.StateChanged += new

StateChangedEventHandler(UpdateState);

Note

Controller events use their own threads. Study

Controller events and threads on page 51

to find out how to avoid threading conflicts.

CAUTION

Do not rely on receiving an initial event when setting up/activating a controller event. There is no guarantee an event will be triggered, so you had better read the initial state from the controller.

Creating a backup

Using the

Controller object you can call the

Backup method. The argument is a string describing the directory path on the controller where the backup should be stored. As the backup process is performed asynchronously you can add an event handler to receive a

BackupCompleted event when the backup is completed.

VB:

Dim BackupDir As String = "(BACKUP)$"+BackupDirName

AddHandler Me.AController.BackupCompleted, AddressOf

AController_BackupCompleted)

Me.AController.Backup(BackupDir)

C#: string backupDir = "(BACKUP)$"+backupDirName; this.aController.BackupCompleted += new

BackupEventHandler(controller_BackupCompleted); this.aController.Backup(backupDir);

Note

There is also a

Restore method available. The Reference Manual FlexPendant

SDK is the complete FlexPendant SDK programming guide and is more detailed than this manual. For the

Backup and

Restore methods, for example, there are parameter descriptions, remarks, code examples and so on.

Dispose

The disposal of the

Controller object should be done in the

Uninstall or

Dispose method of the application view class.

Continues on next page

122

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.2 Accessing the controller

Continued

Make a check first that disposal has not already been done. Do not forget to remove any subscriptions to controller events before the

Dispose() call:

VB:

If Not AController Is Nothing Then

RemoveHandler AController.OperatingModeChanged, AddressOf

OpMChange

AController.Dispose()

AController = Nothing

End If

C#: if (aController != null)

{ aController.OperatingModeChanged -= new

OperatingModeChangedEventHandler(OpMChange); aController.Dispose(); aController = null;

}

CAUTION

VB programmers should be aware that it is a bit tricky to use

WithEvents together with the Dispose pattern on the .NET platform. When you use

WithEvents the .NET framework automatically removes any subscriptions when the object is set to

Nothing

. If you look at the code preceding sample, which does NOT use

WithEvents

, you will understand why such behavior causes problems. When the controller reference is set to

Nothing and the .NET

framework tries to remove its subscription, the internal controller object has already been removed by the

Dispose call in the preceding statement, and a

NullReferenceException is thrown. This is not specific to the FlexPendant

SDK, but a Microsoft issue. To avoid it you are advised to use

AddHandler and

RemoveHandler like in the example.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

123

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

5.5.3 Rapid domain

5.5.3.1 Working with RAPID data

Overview

The

RapidDomain namespace enables access to RAPID data in the robot system.

There are numerous FlexPendant SDK classes representing the different RAPID data types. There is also a

UserDefined class used to reference RECORD structures in RAPID.

The

ValueChanged event enables notification from the controller when persistent

RAPID data has changed.

Tip

A convenient and user-friendly way to enable the end-user of your application to read and write to specific RAPID data is using the standard FlexPendant

Program Data view. For more information, see

Using standard dialog box to modify data on page 116 .

Tip

Using databinding for RAPID data is a quick way of implementing access to

RAPID data. For more information, see

Data of RAPID data and IO signals on page 107

.

Providing the path to the RAPID data

To read or write to RAPID data you must first create a

RapidData object. The path to the declaration of the data in the controller is passed as argument. If you do not know the path you need to search for the RAPID data by using the

SearchRapidSymbol functionality. For more information, see

SearchRapidSymbol method on page 139

.

Direct access

Direct access requires less memory and is faster, and is therefore recommended if you do not need to use the task and module objects afterwards.

The following example shows how to create a

RapidData object that refers to the

RAPID data instance “reg1” in the USER module.

VB:

Dim Rd As RapidData = Me.AController.Rapid.GetRapidData( "T_ROB1",

"USER", "reg1")

C#:

RapidData rd = aController.Rapid.GetRapidData("T_ROB1", "USER",

"reg1");

Hierarchical access

If you need the task and module objects hierarchical access can be more efficient.

GetRapidData exists in the Rapid, Task and Module class.

Continues on next page

124 3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

VB:

Rd = AController.Rapid.GetTask("T_ROB1").GetModule("USER").

GetRapidData("reg1")

C#: rd = aController.Rapid.GetTask("T_ROB1").GetModule("USER").

GetRapidData("reg1");

Accessing data declared in a shared module

If your application is to be used with a multi-move system (a system with one controller and several motion tasks/robots), it may happen that the RAPID instance you need to access is declared in a -Shared RAPID module. Such a module can be used by all tasks, T_ROB1, T_ROB2 and so on.

The following example shows how to create a

RapidData object that refers to the instance “reg100”, which is declared in a shared module.

VB:

Dim Rd As RapidData = Me.AController.Rapid.GetRapidData("reg100")

C#:

RapidData rd = aController.Rapid.GetRapidData("reg100");

Another possibility is using the

Task object to access the RAPID instance, like this:

Task tRob1 = aController.Rapid.GetTask("T_ROB1");

RapidData rData = tRob1.GetRapidData("reg100");

Note

If

GetRapidData is called from

Rapid the RAPID data will be found even if the

-Shared module is configured to be hidden.

Note

If the RAPID data does not exist, the return value is

Nothing/null and an

ArgumentNullException is thrown. A null check should be performed before trying to use the object.

Creating an object representing the RAPID data value

The

RapidData object stores the path to the RAPID data. But this is not enough if you want to access its value (at least not if you want to modify it). To do that you need to create another object, which represents the value of the RAPID data.

In the

RapidDomain namespace there are types representing the different RAPID data types. To create the object needed to represent the RAPID data value you use the

RapidData property

Value and cast it to the corresponding type, for example

Num, Bool or

Tooldata

.

The following code explains how this is done, if you want to access the value of a

RAPID data of the RAPID data type bool

:

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

125

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

VB:

’declare a variable of data type RapidDomain.Bool

Dim rapidBool As RapidDomain.Bool

Dim rd As RapidData = Me.AController.Rapid.GetRapidData( "T_ROB1",

"MainModule", "flag" )

’test that data type is correct before cast

If TypeOf rd.Value Is RapidDomain.Bool Then rapidBool = DirectCast(rd.Value, RapidDomain.Bool)

’check if the value of the RAPID data is true

If (rapidBool.Value) Then

’ Do something...

End If

End If

C#:

//declare a variable of data type RapidDomain.Bool

RapidDomain.Bool rapidBool;

RapidDomain.RapidData rd = aController.Rapid.GetRapidData("T_ROB1",

"MainModule", "flag");

//test that data type is correct before cast if (rd.Value is ABB.Robotics.Controllers.RapidDomain.Bool)

{ rapidBool = (ABB.Robotics.Controllers.RapidDomain.Bool)rd.Value;

//assign the value of the RAPID data to a local variable bool boolValue = rapidBool.Value;

}

If you only want to read this variable you can use this technique instead of creating a RapidDomain.

Bool object:

VB:

Dim b As Boolean = Convert.ToBoolean(rd.Value.ToString)

C#: bool b = Convert.ToBoolean(rd.Value.ToString());

The

ToolData type (representing the RAPID data type tooldata) can be created like this:

VB:

Dim ATool As ToolData

If Rd.Value Is ToolData Then

ATool = DirectCast(Rd.Value, ToolData)

End If

C#:

ToolData aTool; if (rd.Value is ToolData)

{ aTool = (ToolData) rd.Value;

}

Continues on next page

126

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

IRapidData.ToString method

All RapidDomain structures representing RAPID data types implement the

IRapidData interface. It has a

ToString method, which returns the value of the

RAPID data in the form of a string. This is a simple example: string boolValue = rapidBool.ToString();

The string is formatted according to the same principle as described in the following section

IRapidData.FillFromString method on page 127

.

Here is an example of a more complex data type. The

ToolDataTframe property is of the

Pose type. Its

Trans value is displayed in a label in the format [x, y, z].

VB:

Me.Label1.Text = ATool.Tframe.Trans.ToString()

C#: this.label1.Text = aTool.Tframe.Trans.ToString();

IRapidData.FillFromString method

The

IRapidData interface also has a

FillFromString method, which fills the object with a valid RAPID string representation. The method can always be used when you need to modify RAPID data. Using the method with the

RapidDomain.Bool

variable used earlier in the chapter will look like this: rapidBool.FillFromString("True")

Using it for a

RapidDomain.Num

variable is similar: rapidNum.FillFromString("10")

String format

The format is constructed recursively. An example is the easiest way of illustrating this.

Example:

The

RapidDomain.Pose

structure corresponds to the RAPID data type pose

, which describes how a coordinate system is displaced and rotated around another coordinate system.

public struct Pose : IRapidData

{ public Pos trans; public Orient rot;

}

This is an example in RAPID:

VAR pose frame1;

...

frame1.trans := [50, 0, 40]; frame1.rot := [1, 0, 0, 0];

The frame1 coordinate transformation is assigned a value that corresponds to a displacement in position where X=50 mm, Y=0 mm and Z=40 mm. There is no rotation.

As you see, the

RapidDomain.Pose

structure consists of two other structures, trans and rot. The trans structure consists of three floats and the and rot structure consists of four doubles. The

FillFromString format for a

Pose object is “[[1.0,

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

127

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

0.0, 0.0, 0.0][10.0, 20.0, 30.0]]”. This piece of code shows how to write a new value to a RAPID pose variable:

VB:

If TypeOf rd.Value Is Pose Then

Dim rapidPose As Pose = DirectCast(rd.Value, Pose) rapidPose.FillFromString("[[1.0, 0.0, 0.0, 0.0][10, 20, 30]]") rd.Value = rapidPose

End If

C#: if (rd.Value is Pose)

{

Pose rapidPose = (Pose) rd.Value; rapidPose.FillFromString("[[1.0, 0.5, 0.0, 0.0][10, 15, 10]]"); rd.Value = rapidPose;

}

Note

Using the same principle arbitrarily long RAPID data types can be represented.

Note

The string format must be carefully observed. If the string argument has the wrong format, a

RapidDataFormatException is thrown.

Writing to RAPID data

Writing to RAPID data is only possible using the type cast

RapidData value, to which the new value is assigned. To transfer the new value to the RAPID data in the controller you must finally assign the .NET object to the

Value property of the

RapidData object. The following example uses the rapidBool object created in

Creating an object representing the RAPID data value on page 125 .

VB:

’Assign new value to .Net variable rapidBool.Value = False

’Write the new value to the data in the controller rd.Value = rapidBool

C#:

//Assign new value to .Net variable rapidBool.Value = false;

//Write to new value to the data in the controller rd.Value = rapidBool;

This was an easy example, as the value to change was a simple bool

. Often, however, RAPID uses complex structures. By using the

FillFromString method you can assign a new value to any

RapidData and write it to the controller.

The string must be formatted according to the principle described in the previous section. The following example shows how to write a new value to the pos structure

(x, y, z) of a RAPID tooldata:

VB:

Continues on next page

128 3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

Dim APos As Pos = New Pos

APos.FillFromString("[2,3,3]")

Me.ATool.Tframe.Trans = APos

Me.Rd.Value = Me.ATool

C#:

Pos aPos = new Pos(); aPos.FillFromString("[2,3,3]"); this.aTool.Tframe.Trans = aPos; this.rd.Value = this.aTool;

Note

The new value is not written to the controller until the last statement is executed.

Letting the user know that RAPID data has changed

In order to be notified that RAPID data has changed you need to add a subscription to the

ValueChanged event of the

RapidData instance. Note, however, that this only works for persistent RAPID data.

Add subscription

The following code explains how you add a subscription to the

ValueChanged event:

VB:

Addhandler Rd.ValueChanged, AddressOf Rd_ValueChanged

C#: this.rd.ValueChanged += rd_ValueChanged;

Handle event

Implement the event handler. Remember that controller events use their own threads, and avoid Winforms threading problems by the use of

Control.Invoke

, which forces the execution from the background thread to the GUI thread.

VB:

Private Sub Rd_ValueChanged(ByVal sender As Object, ByVal e As

DataValueChangedEventArgs)

Me.Invoke(New EventHandler (AddressOf UpdateGUI), sender, e)

End Sub

C# private void rd_ValueChanged(object sender,

DataValueChangedEventArgs e)

{ this.Invoke(new EventHandler (UpdateGUI), sender, e);

}

For more information to learn more about potential threading conflicts in

FlexPendant SDK applications, see

Controller events and threads on page 51

.

Read new value from controlller

Update the user interface with the new value. As the value is not part of the event argument, you must use the

RapidDataValue property to retrieve the new value:

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

129

5 Using the FlexPendant SDK

5.5.3.1 Working with RAPID data

Continued

VB:

Private Sub UpdateGUI(ByVal sender As Object, ByVal e As

System.EventArgs)

Dim Tool1 As ToolData = DirectCast(Me.Rd.Value, ToolData)

Me.Label1.Text = Tool1.Tframe.Trans.ToString()

End Sub

C# private void UpdateGUI(object sender, System.EventArgs e)

{

ToolData tool1= (ToolData)this.rd.Value; this.label1.Text = tool1.Tframe.Trans.ToString();

}

Note

Subscriptions work only for RAPID data declared as PERS.

RapidData disposal

Always dispose of

RapidData objects when they are no longer needed. If you want to reuse a

RapidData object, you should make sure that you dispose of the current object first.

VB:

If Not Rd Is Nothing Then

Rd.Dispose()

Rd = Nothing

End If

C#: if (rd != null)

{ rd.Dispose(); rd = null;

}

130

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.2 Handling RAPID arrays

5.5.3.2 Handling RAPID arrays

Overview

In RAPID you can have up to three dimensional arrays. These are accessible by using a

RapidData object like any other RAPID data.

There are mainly two ways of accessing each individual element of an array: by indexers or by an enumerator.

Tip

A convenient and user-friendly way of reading and writing array elements is using the standard Program Data view of the FlexPendant. You provide the element you want to have displayed as argument, and the user can view or manipulate the item the way it is usually done on the FlexPendant. For more information, see

Using standard dialog box to modify data on page 116

.

ArrayData object

If the

RapidData references a RAPID array is

Value property returns an object of

ArrayData type. Before making a cast, check the type using the is operator or by using the

IsArray property on the

RapidData object.

VB:

Dim RD As RapidData = AController.Rapid.GetRapidData("T_ROB1",

"User", "string_array")

If RD.IsArray Then

Dim AD As ArrayData = DirectCast( RD.Value,ArrayData)

.....

End If

C#:

RapidData rd = aController.Rapid.GetRapidData("T_ROB1", "User",

"string_array"); if (rd.IsArray)

{

ArrayData ad = (ArrayData)rd.Value;

.....

}

Array dimensions

The dimension of the array is returned by the Rank property. If you need to check the length of the individual arrays you can use the

GetLength method on the

ArrayData object passing the dimension index as argument.

VB:

Dim ARank As Integer = AD.Rank

Dim Len As Integer = AD.GetLength(ARank)

C#: int aRank = ad.Rank; int len = ad.GetLength(aRank);

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

131

5 Using the FlexPendant SDK

5.5.3.2 Handling RAPID arrays

Continued

Array item access by using indexers

By the use of indexers you can access each array element, even in three dimensional arrays. A combination of the

GetLength method and

For loops makes it possible to access any item:

VB:

Dim aSum As Double = 0R

Dim aNum As Num

If ad.Rank = 1 Then

For I As Integer = 1 To ad.Length

aNum = DirectCast(ad(i), Num) aSum += CDbl(aNum)

Next

ElseIf ad.Rank = 2 Then

For i As Integer = 1 To ad.GetLength(1) - 1

For j As Integer = 1 To ad.Length

aNum = DirectCast(ad[i, j], Num) aSum += CDbl(aNum)

Next

Next

Else

For i As Integer = 1 To ad.GetLength(1) - 1

For j As Integer = 1 To ad.GetLength(2) - 1

For k As Integer = 1 To ad.GetLength(3) aNum = DirectCast(ad(i, j, k), Num) aSum += CDbl(aNum)

Next

Next

Next

End If

C#: double aSum = 0d;

Num aNum; if (ad.Rank == 1) { for (int i = 1; i <= ad.Length; i++)

{ aNum = (Num)ad[i]; aSum += (double)aNum;

}

} else if (ad.Rank == 2)

{ for(int i = 1; i< ad.GetLength(1); i++)

{ for (int j = 1; j <= ad.Length; j++)

{ aNum = (Num)ad[i,j]; aSum += (double)aNum;

}

}

Continues on next page

132

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.2 Handling RAPID arrays

Continued

} else { for(int i = 1; i< ad.GetLength(1); i++)

{ for(int j = 1; j< ad.GetLength(2); j++)

{ for (int k = 1; k <= ad.GetLength(3); k++)

{ aNum = (Num)ad[i, j, k]; aSum += (double)aNum;

}

}

}

}

Array item access using enumerator

You can also use the enumerator operation ( foreach

) like it is used by collections in .NET. Note that it can be used for both one dimension and multi-dimensional arrays to access each individual element. The previous example is a lot simpler this way:

VB:

Dim aSum As Double = 0R

Dim aNum As Num

For Each aNum As Num In AD aSum += CDbl(aNum)

Next

C#: double aSum = 0d;

Num aNum; foreach(Num aNum in ad)

{ aSum += (double)aNum;

}

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

133

5 Using the FlexPendant SDK

5.5.3.3 ReadItem and WriteItem methods

5.5.3.3 ReadItem and WriteItem methods

Overview

An alternative way of accessing RAPID data stored in an array are the

ReadItem and

WriteItem methods.

ReadItem method

Using the

ReadItem method you can directly access a RAPID data item in an array, for example an array with RobTargets or Nums. The index to the item is explicitly specified in the

ReadItem call. The first item is in position 1, that is, the array is

1-based as in RAPID.

The following example retrieves the second Num value in the first array of the

RAPID data variable referenced by rd.

VB:

Dim aNum As Num aNum = DirectCast(rd.ReadItem(1, 2), Num)

C#:

Num aNum = (Num)rd.ReadItem(1, 2);

WriteItem method

It is possible to use the

WriteItem method to write to an individual RAPID data item in an array. The following example shows how to write the result of an individual robot operation into an array representing a total robot program with several operations:

VB:

Dim aNum As Num = New Num(OPERATION_OK) rd.WriteItem(aNum, 1, 2)

C#:

Num aNum = new Num(OPERATION_OK); rd.WriteItem(aNum, 1, 2);

Note

If the index is not in the range specified, an

IndexOutOfRangeException will be thrown.

134

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.4 UserDefined data

5.5.3.4 UserDefined data

Overview

You often work with RECORD structures in RAPID code. To handle these unique data types, a

UserDefined class has been implemented. This class has properties and methods to handle individual components of a RECORD.

In some cases implementing your own .NET structure can improve application design and code maintenance.

Creating UserDefined object

The

UserDefined constructor takes a

RapidDataType object as argument. To retrieve a

RapidDataType object the path to the declaration of the RAPID data type is passed as argument.

The following example creates a

UserDefined object referencing the RAPID

RECORD processdata:

VB:

Dim rdt As RapidDataType rdt = Me.controller.Rapid.GetRapidDataType("T_ROB1", "MyModule",

"processdata")

Dim processdata As UserDefined = New UserDefined(rdt)

C#

RapidDataType rdt; rdt = this.controller.Rapid.GetRapidDataType("T_ROB1", "MyModule",

"processdata");

UserDefined processdata = new UserDefined(rdt);

Note

If the module where the RECORD is defined is configured as -Shared you only provide the name of the data type as argument, like this: rdt = this.controller.Rapid.GetRapidDataType("processdata");

Reading UserDefined data

You can use a

UserDefined object to read any kind of RECORD variable from the controller. The individual components of the RECORD are accessible using the

Components property and an index. Each

Component can be read as a string.

VB:

Dim processdata As UserDefined = DirectCast(rd.Value, UserDefined)

Dim No1 As String = processdata.Components(0).ToString()

Dim No2 AS String = processdata.Components(1),ToString()

C#:

UserDefined processdata = (UserDefined) rd.Value; string no1 = processdata.Components[0].ToString(); string no2 = processdata.Components[1].ToString();

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

135

5 Using the FlexPendant SDK

5.5.3.4 UserDefined data

Continued

Each individual string can then be used in a

FillFromString method to convert the component into a specific data type, for example

RobTarget or

ToolData

.

For more information, see

IRapidData.FillFromString method on page 127 .

Writing to UserDefined data

If you want to modify

UserDefined data and write it to the RECORD in the controller, you must first read the

UserDefined object and the apply new values using the

FillFromString method. Then you perform a write operation using the

RapidData.Value

property.

atC#: processdata.Components[0].FillFromString("[0,0,0]"); processdata.Components[1].FillFromString("10"); rd.Value = ud;

For more information and code samples, see IRapidData.FillFromString method

and Working with Rapid Data.

Implement your own struct representing a RECORD

The following example shows how you can create your own .NET data type representing a RECORD in the controller instead of using the

UsefDefined type.

Creating ProcessData type

VB:

Dim rdt As RapidDataType = Me.ARapid.GetRapidDataType("T_ROB1",

"MyModule", "processdata")

Dim p As ProcessData = New ProcessData(rdt) p.FillFromString(rd.Value.ToString())

C#

RapidDataType rdt = this.aRapid.GetRapidDataType("T_ROB1",

"MyModule", "processdata");

ProcessData p = new ProcessData(rdt); p.FillFromString(rd.Value.ToString());

Implementing ProcessData struct

The following example shows how the new data type

ProcessData may be implemented. This is done by using a .NET struct and letting ProcessData wrap the

UserDefined object.

The struct implementation should include a

FillFromString and

ToString method, that is, inherit the

IRapidData interface. Any properties and methods may also be implemented.

VB:

Public Structure ProcessData

Implements IRapidData

Private data As UserDefined

Public Sub New(ByVal rdt As RapidDataType) data = New UserDefined(rdt)

End Sub

Private Property IntData() As UserDefined

Continues on next page

136

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.4 UserDefined data

Continued

Get

Return data

End Get

Set(ByVal Value As UserDefined) data = Value

End Set

End Property

.....

End Structure

C#: public struct ProcessData: IRapidData

{ private UserDefined data; public ProcessData(RapidDataType rdt)

{ data = new UserDefined(rdt);

} private UserDefined IntData

{ get { return data; } set { data = value; }

} public int StepOne

{ get

{

} set int res = Convert.ToInt32(IntData.Components[0].ToString()); return res;

{

IntData.Components[0] = new Num(value);

}

}

}

Implementing IRapidData methods

The following piece of code shows how the two

IRapidData methods

ToString and

FillFromString can be implemented.

VB:

Public Sub FillFromString(ByVal newValue As String) Implements

ABB.Robotics.Controllers.RapidDomain.IRapidData.FillFromString

IntData.FillFromString(newValue)

End Sub

Public Overrides Function ToString() As String Implements

ABB.Robotics.Controllers.RapidDomain.IRapidData.ToString

Return IntData.ToString()

End Function

C#: public void FillFromString(string newValue)

3HAC036958-001 Revision: B

Continues on next page

137

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.4 UserDefined data

Continued

{

IntData.FillFromString(newValue);

} public override string ToString()

{ return IntData.ToString();

}

NOTE! The

ToString method has to use the

Overrides keyword in Visual Basic and the override keyword in C#.

Property implementation

Each item in the RECORD structure should have a corresponding property in the extended .NET data type. The get and set methods have to implement the conversion from/to controller data type to .NET data type.

VB:

Public Property Step() As Integer

Get

Dim res As Integer =

Convert.ToInt32(IntData.Components(0).ToString())

Return res

End Get

Set(ByVal Value As Integer)

Dim tmp As Num = New Num tmp.FillFromNum(Value)

IntData.Components(0) = tmp

End Set

End Property

C#: public int Step

{ get

{ int res = Convert.ToInt32(IntData.Components[0].ToString()); return res;

} set

{

Num tmp = new Num(); tmp.FillFromNum(value);

IntData.Components[0] = tmp;

}

}

138

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.5 RAPID symbol search

5.5.3.5 RAPID symbol search

Overview

Most RAPID elements (variables, modules, tasks, records, and so on.) are members of a symbol table, in which their names are stored as part of a program tree structure.

It is possible to search this table and get a collection of

RapidSymbol objects, each one including the RAPID object name, location, and type.

SearchRapidSymbol method

The search must be configured carefully, due to the large amount of RAPID symbols in a system. To define a query you need to consider from where in the program tree the search should be performed, which symbols are of interest, and what information you need for the symbols of interest. To enable search from different levels, the

SearchRapidSymbol method is a member of several different SDK classes, for example

Task

,

Module and

Routine

. The following example shows a search performed with

Task as the starting point:

VB:

Dim RSCol As RapidSymbol()

RSCol = ATask.SearchRapidSymbol(SProp, "num", string.Empty)

C#:

RapidSymbol[] rsCol; rsCol = aTask.SearchRapidSymbol(sProp, "num", string.Empty);

The

SearchRapidSymbol method has three arguments. The first argument, of data type

RapidSymbolSearchProperties

, is detailed in the next section. The second and third arguments are detailed in the following sections.

Search properties

The

RapidSymbolSearchProperties type is complex and requires some knowledge about RAPID concepts.

It is used to specify search method, type of RAPID symbol to search for, whether the search should be recursive, whether the symbols are local and/or global, and whether or not the search result should include only symbols currently used by a program. If a property is not valid for a particular symbol, it will be discarded and will not exclude the symbol from the search result.

The table describes the different properties of

RapidSymbolSearchProperties

.

Property

SearchMethod

Description

Specifies the direction of the search, which can be

Block

(down) or

Scope

(up). Example: If the starting point of the search is a routine, a block-search will return the symbols declared within the routine, whereas a scope-search will return the symbols accessible from the routine.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

139

5 Using the FlexPendant SDK

5.5.3.5 RAPID symbol search

Continued

Property

SymbolType

Recursive

Description

Specifies which RAPID type(s) you want to search for. The

SymbolTypes enumeration includes

Constant

,

Variable

,

Persistent

,

Function

,

Procedure

,

Trap

,

Module

,

Task

,

Routine

,

RapidData

. and so on. (

Routine includes

Function

,

Procedure and

Trap. RapidData includes

Constant

,

Variable and

Persistent

.)

For both block and scope search it is possible to choose if the search should stop at the next scope or block level or recursively continue until the root (or leaf) of the symbol table tree is reached.

GlobalRapidSymbol Specifies whether global symbols should be included.

LocalRapidSymbol

IsInUse

Specifies whether local symbols should be included.

Specifies whether only symbols in use by the loaded RAPID program should be searched.

Default instance

RapidSymbolSearchProperties has a static method, which returns a default instance.

VB:

Dim SProp As RapidSymbolSearchProperties =

RapidSymbolSearchProperties.CreateDefault()

C#:

RapidSymbolSearchProperties sProp =

RapidSymbolSearchProperties.CreateDefault();

The default instance has the following values:.

Property

SearchMethod

SymbolType

Recursive

GlobalRapidSymbol

LocalRapidSymbol

IsInUse

Description

SymbolSearchMethod.Block

SymbolTypes.NoSymbol

True

True

True

True

Using this instance you can specify the search properties of the search you want to perform.

Example:

VB:

SProp.SearchMethod = SymbolSearchMethod.Scope

SProp.SymbolType = SymbolTypes.Constant Or SymbolTypes.Persistent

SProp.Recursive = False

C#: sProp.SearchMethod = SymbolSearchMethod.Scope; sProp.SymbolType = SymbolTypes.Constant | SymbolTypes.Persistent

sProp.Recursive = false;

Continues on next page

140

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.5 RAPID symbol search

Continued

Note

The default instance has the property

SymbolType set to

NoSymbol

, which means you need to specify it in order to perform a meaningful search.

Note

The

SymbolType property allows you to combine several types in the search.

For more information, see the preceding example.

Data type argument

The second argument of the

SearchRapidSymbol method is the RAPID data type written as a string. The data type should be written with small letters, for example

“num”, “string” or “robtarget”. It can also be specified as string.Empty

.

Note

To search for a

UserDefined data type the complete path to the module that holds the RECORD definition must be passed. For example: result = tRob1.SearchRapidSymbol(sProp,"RAPID/T_ROB1/MyModule/MyDataType", string.Empty);

However, if

MyModule is configured as -Shared the system sees its data types as installed, and the task or module should not be included in the path result = tRob1.SearchRapidSymbol(sProp,"MyDataType", string.Empty);

Symbol name argument

The third argument is the name of the RAPID symbol. It can be specified as string.Empty

if the name of the symbol to retrieve is not known, or if the purpose is to search ALL “num” instances in the system.

Instead of the name of the RAPID symbol a regular expression can be used. The search mechanism will then match the pattern of the regular expression with the symbols in the symbol table. The regular expression string is not case sensitive.

A regular expression is a powerful mechanism. It may consist of ordinary characters and meta characters. A meta character is an operator used to represent one or several ordinary characters, and the purpose is to extend the search.

Within a regular expression, all alphanumeric characters match themselves, that is, the pattern “abc” will only match a symbol named “abc”. To match all symbol names containing the character sequence “abc”, it is necessary to add some meta characters. The regular expression for this is “.*abc.*”.

The available meta character set is shown in the following table:

Expression

.

^

Meaning

Any single character

Any symbol starting with

3HAC036958-001 Revision: B

Continues on next page

141

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.5 RAPID symbol search

Continued

Expression

[s]

[^s] r* r+ r?

(r) r | r’

.*

Meaning

Any single character in the non-empty set s, where s is a sequence of characters. Ranges may be specified as c-c.

Any single character not in the set s.

Zero or more occurrences of the regular expression r.

One or more occurrences of the regular expression r.

Zero or one occurrence of the regular expression r.

The regular expression r. Used for separate that regular expression from another.

The regular expressions r or r’.

Any character sequence (zero, one or several characters).

Example 1

"^c.*"

Returns all symbols starting with c or C.

Example 2

"^reg[1-3]"

Returns reg1, Reg1, REG1, reg2, Reg2, REG2, reg3, Reg3 and REG3.

Example 3

"^c.*|^reg[1,2]"

Returns all symbols starting with c or C as well as reg1, Reg1, REG1, reg2, Reg2 and REG2.

SearchRapidSymbol example

The following example searches for VAR, PERS or CONST num data in a task and its modules. The search is limited to globally declared symbols. By default the search method is

Block

, so it does not have to be set.

VB:

Dim sProp As RapidSymbolSearchProperties =

RapidSymbolSearchProperties.CreateDefault() sProp.SymbolTypes = SymbolTypes.RapidData

sProp.LocalRapidSymbol = False

Dim rsCol As RapidSymbol() rsCol = aTask.SearchRapidSymbol(sProp, "num", string.Empty)

C#:

RapidSymbolSearchProperties sProp =

RapidSymbolSearchProperties.CreateDefault(); sProp.SymbolType = SymbolTypes.RapidData; sProp.LocalRapidSymbol = false;

RapidSymbol[] rsCol; rsCol = aTask.SearchRapidSymbol(sProp, "num", string.Empty);

Continues on next page

142

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.3.5 RAPID symbol search

Continued

Search for UserDefined RAPID data - example

In the following example an user defined RECORD data type (“mydata”) is declared in a module (“myModule”). Assuming that the end-user can declare and use data of this data type in any program module, the search method must be Block (default).

A search for all “mydata” instances may look like this:

VB:

Dim sProp As RapidSymbolSearchProperties =

RapidSymbolSearchProperties.CreateDefault() sProp.SymbolType = SymbolTypes.RapidData

Dim rsCol As RapidSymbol() rsCol = aTask.SearchRapidSymbol(sProp,

"RAPID/T_ROB1/myModule/mydata", string.Empty)

C#:

RapidSymbolSearchProperties sProp =

RapidSymbolSearchProperties.CreateDefault(); sProp.SymbolType = SymbolTypes.RapidData;

RapidSymbol[] rsCol; rsCol = aTask.SearchRapidSymbol(sProp,

"RAPID/T_ROB1/myModule/mydata", string.Empty);

Note

If myModule is configured as -Shared and all myData instances are declared in myModule, the search method must be set to

Scope and the

SearchRapidSymbol call should look like this: rsCol = aTask.SearchRapidSymbol(sProp, "mydata", string.Empty);

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

143

5 Using the FlexPendant SDK

5.5.3.6 RAPID execution

5.5.3.6 RAPID execution

Start and Stop RAPID programs

You can start and stop RAPID execution using

Rapid

.

Start and

Stop methods.

A

StartResult from the

Start method returns the result of the call. Start arguments can be used.

RegainMode defines how the mechanical unit should handle path status at start.

ExecutionMode specifies if the program should run continuously, step backward or go to the next Move instruction and so on.

The

Stop method can include a

StopMode argument, specifying when the program should stop (after current cycle, after completed instruction or immediately).

VB: aController.Rapid.Start(RegainMode.Regain, ExecutionMode.Continuous)

.....

aController.Rapid.Stop(StopMode.Instruction)

C#: aController.Rapid.Start(RegainMode.Regain,

ExecutionMode.Continuous);

.....

aController.Rapid.Stop(StopMode.Instruction);

Note

It is also possible to start a service routine or an ordinary routine without any parameters as if it were a service routine. For more information and code samples, see

Task.CallRoutine

and

Task.CancelRoutine

in the Reference Manual

FlexPendant SDK.

RAPID execution change event

It is possible to subscribe to events that occur when a RAPID program starts to execute and when it stops. This is done on the

Rapid property of the

Controller object, like this:

VB:

AddHandler aController.Rapid.ExecutionStatusChanged, AddressOf

UpdateUI

C# aController.Rapid.ExecutionStatusChanged += new

ExecutionStatusChangedEventHandler(UpdateUI);

For more information and code example on how write the event handlers needed to update the GUI due to a controller event, see

Letting the user know that RAPID data has changed on page 129 .

ResetProgramPointer method

The

ResetProgramPointer method resets the program pointers of all tasks and sets them to the main entry point of the respective task.

VB: aController.Rapid.ResetProgramPointer()

Continues on next page

144 3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.6 RAPID execution

Continued

C#: aController.Rapid.ResetProgramPointer();

Note

It is also possible to set the program pointer to a specified routine, row or position.

For more information and code samples, see

Task.SetProgramPointer in the Reference Manual FlexPendant SDK.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

145

5 Using the FlexPendant SDK

5.5.3.7 Modifying modules and programs

5.5.3.7 Modifying modules and programs

Overview

Using the

Task object it is possible to load and save programs and individual modules. You can also unload programs, get the position of the motion pointer

(MP) and the program pointer (PP) as well as modify a robot position.

Load modules and programs

To load a module or program file you need the path to the file in the file system of the controller. When the file is loaded into memory the

RapidLoadMode enumeration argument,

Add or

Replace

, specifies whether or not it should replace old modules or programs.

If the file extension is not a valid module (mod or sys) or program (pgf) extension an

ArgumentException is thrown.

VB:

Try

ATask.LoadProgramFromFile(APrgFileName, RapidLoadMode.Replace)

ATask.LoadModuleFromFile(AModFileName, RapidLoadMode.Add)

Catch ex As ArgumentException

Return

End Try

C#: try

{ aTask.LoadProgramFromFile(aPrgFileName, RapidLoadMode.Replace); aTask.LoadModuleFromFile(aModFileName, RapidLoadMode.Add);

} catch (ArgumentException ex)

{ return;

}

Save and unload RAPID program

You can save a program using the

SaveProgramToFile method and unload it using the

DeleteProgram method. These methods save and unload all modules in the task.

VB:

Dim TaskCol As Task() = AController.Rapid.GetTasks()

Dim AnObject As Object

For Each AnObject in TaskCol

ATask = DirectCast(AnObject, Task)

ATask.ProgramName = ATask.Name

ATask.SaveProgramToFile(SaveDir)

ATask.DeleteProgram()

Next

C#:

Task[] taskCol = aController.Rapid.GetTasks();

Continues on next page

146 3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.3.7 Modifying modules and programs

Continued foreach (Task aTask in taskCol)

{ aTask.PrograamName = aTask.Name; aTask.SaveProgramToFile(saveDir); aTask.DeleteProgram();

}

Save module

You can save a module by using the

Module.SaveToFile

method. As argument you use a path to the controller file system.

VB:

AModule.SaveToFile(AFilePath)

C# aModule.SaveToFile(aFilePath);

ProgramPointer and MotionPointer

The Task.

ProgramPointer property returns the current location of the program pointer (module, routine and row number), that is, where the program is currently executing. The same functionality is available for motion pointer by using the

MotionPointer property.

VB:

Dim APP As ProgramPointer = ATask.ProgramPointer

If Not APP = ProgramPointer.Empty Then

Dim AStartRow As Integer = APP.Start.Row

.....

C#:

ProgramPointer pp = aTask.ProgramPointer; if (pp != ProgramPointer.Empty)

{ int aStartRow = pp.Start.Row;

.....

}

ModifyPosition method

Using the ModifyPosition method of the

Task object you can modify the position of a

RobTarget instance in the currently loaded program. As arguments you supply a module

Name as well as a

TextRange object. The first

RobTarget within the text range specified by the

TextRange object will be changed using the current

TCP of the active mechanical unit.

VB:

Me.ATask.ModifyPosition(AModule, ATextRange)

C#: this.ATask.ModifyPosition(aModule, aTextRange)

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

147

5 Using the FlexPendant SDK

5.5.3.7 Modifying modules and programs

Continued

Tip

For more information on

Task methods and properties, see in the Reference

Manual FlexPendant SDK.

148

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.4 IO system domain

5.5.4 IO system domain

Overview

A robot system uses input and output signals to control processes. Signals can be of digital, analog or group signal type. Such IO signals are accessible using the

SDK.

Signal changes in the robot system are often significant, and there are many scenarios where end-users of the system need notification of signal changes.

Accessing signals

Accessing signals is done through the

Controller object and its property

IOSystem

, which represents the IO signal space in the robot controller.

To access a signal you need the system name of the signal. The object that is returned from the

IOSystem

.

GetSignal method is of type

Signal

.

VB:

Dim Signal1 As Signal = AController.IOSystem.GetSignal("signal name")

C#:

Signal signal1 = aController.IOSystem.GetSignal("signal name");

The returned

Signal object has to be typecast to digital, analog or group signal.

The following example shows a how a signal of type

DigitalSignal is created:

VB:

Dim DISig As DigitalSignal = DirectCast(Signal1, DigitalSignal)

C#:

DigitalSignal diSig = (DigitalSignal) signal1;

The following example shows a how an

AnalogSignal is created:

VB:

Dim AISig As AnalogSignal = DirectCast(Signal1, AnalogSignal)

C#:

AnalogSignal aiSig = (AnalogSignal) signal1;

The following example shows a how a

GroupSignal is created:

VB:

Dim GISig As GroupSignal = DirectCast(Signal1, GroupSignal)

C#:

GroupSignal giSig = (GroupSignal) signal1;

Note

Remember to call the

Dispose method of the signal when it should no longer be used.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

149

5 Using the FlexPendant SDK

5.5.4 IO system domain

Continued

Getting signals using SignalFilter

Instead of getting one signal at a time you can use a filter and get a signal collection.

Some of the

SignalFilter flags are mutually exclusive, for example

SignalFilter.Analog

and

SignalFilter.Digital

. Others are inclusive, for example

SignalFilter.Digital

and

SignalFilter.Input

. You can combine the filter flags using the “|” character in C# and the

Or operator in VB:

VB:

Dim aSigFilter As IOFilterTypes = IOFilterTypes.Digital Or

IOFilterTypes.Input

Dim signals As SignalCollection = controller.IOSystem.GetSignals(aSigFilter)

C#:

This piece of code iterates the signal collection and adds all signals to a

ListView control. The list has three columns displaying signal name, type and value:

VB:

For Each signal As Signal In Signals

Item = New ListViewItem(signal.Name)

Item.SubItems.Add(signal.Type.ToString())

Item.SubItems.Add(signal.Value.ToString())

Me.ListView1.Items.Add(Item)

Next

C#:

IOFilterTypes aSigFilter = IOFilterTypes.Digital |

IOFilterTypes.Input;

SignalCollection signals = controller.IOSystem.GetSignals(aSigFilter); foreach(Signal signal in signals)

{ item = new ListViewItem(signal.Name); item.SubItems.Add(signal.Type.ToString()); item.SubItems.Add(signal.Value.ToString()); this.listView1.Items.Add(item);

}

If the signal objects are no longer needed they should be disposed of:

VB:

For Each signal As Signal In Signals signal.Dispose()

Next

C#: foreach(Signal signal in signals)

{ signal.Dispose();

}

Continues on next page

150

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.4 IO system domain

Continued

Reading IO signal values

These examples show how to read a digital and an analog signal.

Digital signal

This piece of code reads the digital signal DO1 and checks a checkbox if the signal value is 1 (ON):

VB:

Dim sig As Signal = aController.IOSystem.GetSignal("DO1")

Dim digitalSig As DigitalSignal = DirectCast(sig, DigitalSignal)

Dim val As Integer = digitalSig.Get

If val = 1 Then

Me.CheckBox1.Checked = True

EndIf

C#:

Signal sig = aController.IOSystem.GetSignal("DO1");

DigitalSignal digitalSig = (DigitalSignal)sig; int val = digitalSig.Get(); if (val == 1)

{ this.checkBox1.Checked = true;

}

Analog signal

This piece of code reads the value of the analog signal AO1 and displays it in a textbox:

VB:

Dim sig As Signal = aController.IOSystem.GetSignal("AO1")

Dim analogSig As AnalogSignal = DirectCast(sig, AnalogSignal)

Dim analogSigVal As Single = analogSig.Value

Me.textBox1.Text = analogSigVal.ToString()

C#:

Signal sig = aController.IOSystem.GetSignal("AO1");

AnalogSignal analogSig = (AnalogSignal)sig; float analogSigVal = analogSig.Value; this.textBox1.Text = analogSigVal.ToString();

Writing IO signal values

In the following example, new values for the IO signals that were retrieved in the previous example are written to the controller.

Note

In manual mode a signal value can be modified only if the Access Level of the signal is ALL. If not, the controller has to be in auto mode.

Digital signal

This piece of code changes the value of a digital signal in the controller when you check/uncheck a checkbox:

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

151

5 Using the FlexPendant SDK

5.5.4 IO system domain

Continued

VB:

Private Sub checkBox1_Click(ByVal sender As Object, ByVal e As

System.EventArgs) Handles checkBox1.Click

If Me.checkBox1.Checked Then digitalSig.[Set]()

Else digitalSig.Reset()

End If

End Sub

C#: private void checkBox1_Click(object sender, EventArgs e)

{ if (this.checkBox1.Checked)

{ digitalSig.Set();

} else

{ digitalSig.Reset();

}

}

NOTE! You can also set the value using the

Value property.

Analog signal

This piece of code writes the value entered in a text box to the analog signal AO1.

The value is converted from string to a float before it is written to the controller:

VB:

Dim analogSigVal As Single = Convert.ToSingle(Me.textBox1.Text) analogSig.Value = analogSigVal

C#: float analogSigVal = Convert.ToSingle(this.textBox1.Text); analogSig.Value = analogSigVal;

Listening to signal changes

Once a

Signal object is available it is possible to add a subscription to its Changed event, which is triggered at a signal change such as changed value, changed simulated status or changed signal quality.

VB:

Friend WithEvents aiSig As AnalogSignal

...

AddHandler aiSig.Changed, AddressOf aiSig_Changed

...

Private Sub aiSig_Changed(sender As Object, e As

SignalChangeEventArgs) Handles aiSig.Changed

End Sub

C# this.aiSig.Changed +=new SignalChangeHandler(aiSig_Changed);

Continues on next page

152

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.4 IO system domain

Continued

NOTE! The event handler skeleton is auto generated using the Tab key twice after

“+=” in the preceding statement: private void aiSig_Changed(object sender, SignalChangeEventArgs e)

{ }

Start and stop subscriptions

It is recommended that you activate and deactivate subscriptions to the

Changed event if these are not necessary throughout the lifetime of the application:

VB:

AddHandler aiSig.Changed, AddressOf aiSig_Changed

RemoveHandler aiSig.Changed, AddressOf aiSig_Changed

C#: this.aiSig.Changed += new SignalChangeHandler(aiSig_Changed); this.aiSig.Changed -= new SignalChangeHandler(aiSig_Changed);

Avoiding threading conflicts

The controller events use their own threads, which are different from the application

GUI thread. This can cause problems if you want to display signal changes in the application GUI.

If an update of the user interface is not necessary, you do not need to take any special action, but can execute the event handler on the event thread. If, however, you need to show to the user that the signal has changed you should use the

Invoke method. It forces execution to the window control thread and thus provides a solution to potential threading conflicts.

VB:

Me.Invoke(New ABB.Robotics.Controllers.IOSystemDomain.

SignalChangedEventHandler(AddressOf UpdateUI), New Object()

{sender, e})

C#: this.Invoke(new ABB.Robotics.Controllers.IOSystemDomain.

SignalChangedEventHandler(this.UpdateUI), new Object[]

{sender, e});

For more information, see

Controller events and threads on page 51

.

Finding out the new value

The

SignalChangedEventArgs object has a

NewSignalState property, which has information about signal value, signal quality and whether the signal is simulated or not:

VB:

Private Sub UpdateUI(ByVal Sender As Object, ByVal e As

SignalChangedEventArgs)

Dim State As SignalState = e.NewSignalState

Dim val As Single

Val = State.Value

Me.TextBox1.Text = Val.ToString()

....

End Sub

3HAC036958-001 Revision: B

Continues on next page

153

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.4 IO system domain

Continued

C#: private void UpdateUI(object sender, SignalChangedEventArgs e)

{

SignalState state = e.NewSignalState;

....

float val = state.Value

this.textBox1.Text = val.ToString()

}

Note

Do not count on receiving an initial event when setting up the subscription. To get initial information about the value of a signal, you should read it using the

Value property.

Note

Make sure the subscription is removed before you dispose of the signal.

154

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.5 Event log domain

5.5.5 Event log domain

Overview

Event log messages may contain information about controller status, RAPID execution, the running processes of the controller, and so on.

Using the SDK it is possible to either read messages in the queue or to use an event handler that will receive a copy of each new log message. An event log message contains queue type, event type, event time, event title, and message.

Access the controller event log

You can access the event log domain through the

Controller property

EventLog

.

VB:

Private log As EventLog = aController.EventLog

C#: private EventLog log = aController.EventLog;

Access event log categories

All event log messages are organized into categories. To search for an individual message you have to know what category it belongs to. The enumeration type,

CategoryType

, defines all available categories. You can get a category either by using the method

GetCategory or by using the

Categories property, which is an array of all available categories.

VB:

Dim Cat As EventLogCategory

Cat = Log.GetCategory(CategoryType.Program) or

Cat = Log.Categories(4)

C#:

EventLogCategory cat; cat = log.GetCategory(CategoryType.Program); or cat = log.GetCategory[4];

Note

The

EventLogCategory should be disposed of when it is no longer used.

Access event log messages

To access a message you use the

Messages property of the

Category object. A collection of messages is returned. The collection implements the

ICollection and

IEnumerable interfaces , which means you can use the common operations for collections. Access is done either using an index or by iterating using foreach

.

VB:

Dim msg As EventLogMessage = Cat.Messages(1)

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

155

5 Using the FlexPendant SDK

5.5.5 Event log domain

Continued or

Dim msg As EventLogMessage

For Each msg In Cat.Messages

Me.textBox1.Text = msg.Title

.....

Next Item

C#:

EventLogMessage msg = cat.Messages[1]; or foreach(EventLogMessage msg in cat.Messages)

{ this.textBox1.Text = msg.Title;

.....

}

MessageWritten event

It is possible to add an event handler that is notified when a new messages is written to the controller event log. This is done by subscribing to the EventLog event

MessageWritten

.

The event argument is of type

MessageWrittenEventArgs and has a

Message property, which holds the latest event log message.

VB:

Private Sub Log_MessageWritten(sender As Object, e As

MessageWrittenEventArgs) Handles Log.MessageWritten

Dim Msg As EventLogMessage = e.Message

End Sub

C#: private void log_MessageWritten(object sender,

MessageWrittenEventArgs e)

{

EventLogMessage msg = e.Message;

}

Note

If the application user interface needs to be updated as a result of the event, you must delegate this job to the GUI thread using the

Invoke method. For more information and code samples, see

Controller events and threads on page 51

.

156

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.6 Motion domain

5.5.6 Motion domain

Overview

The

MotionDomain namespace lets you access the mechanical units of the robot system.

Using a

MotionSystem object you can send jogging commands to an mechanical unit and get or set the incremental jogging mode. Using a

MechanicalUnit object you can get a lot of information about the mechanical units of the robot system.

You can also subscribe to changes of the mechanical unit, for example changed tool, work object, coordinated system, motion mode or incremental step size.

MotionSystem object

You can access the motion system by using a the

Controller property

MotionSystem

.

VB:

Private aMotionSystem As MotionSystem aMotionSystem = aController.MotionSystem

C# private MotionSystem aMotionSystem; aMotionSystem = aController.MotionSystem;

Accessing Mechanical units

The mechanical units can be of different types, for example a robot with a TCP, a multiple axes manipulator, or a single axis unit. Mechanical units are available through the

MotionSystem object. If only the active mechanical unit is of interest you may use the method

GetActiveMechanicalUnit

.

VB:

Dim aMechCol As MechanicalUnitCollection = aController.MotionSystem.GetMechanicalUnits()

Dim aMechUnit As MechanicalUnit = aController.MotionSystem.GetActiveMechanicalUnit();

C#:

MechanicalUnitCollection aMechCol = aController.MotionSystem.GetMechanicalUnits();

MechanicalUnit aMechUnit = aController.MotionSystem.GetActiveMechanicalUnit();

Jogging

It is possible to jog the active mechanical unit using the

SetJoggingCmd method and the calls

JoggingStart and

JoggingStop

. Depending on the selected

MotionMode and

IncrementalMode different joints and speeds are configured.

VB: aController.MotionSystem.JoggingStop() aMechUnit.MotionMode = MotionModeType.Linear

aController.MotionSystem.IncrementalMode = IncrementalModeType.Small

aController.MotionSystem.SetJoggingCmd(-50, 50, 0) aController.MotionSystem.JoggingStart()

3HAC036958-001 Revision: B

Continues on next page

157

© Copyright 2010-2013 ABB. All rights reserved.

5 Using the FlexPendant SDK

5.5.6 Motion domain

Continued

C#: aController.MotionSystem.JoggingStop(); aMechUnit.MotionMode = MotionModeType.Linear; aController.MotionSystem.IncrementalMode =

IncrementalModeType.Small; aController.MotionSystem.SetJoggingCmd(-50, 50, 0); aController.MotionSystem.JoggingStart();

Mechanical unit properties and methods

There are numerous properties available for the mechanical unit, for example

Name,Model, NumberOfAxes,SerialNumber,CoordinateSystem

,

MotionMode

,

IsCalibrated

,

Tool and

WorkObject and so on. It is also possible to get the current position of a mechanical unit as a

RobTarget or

JointTarget

.

VB:

Dim aController As New Controller()

Dim aRobTarget As RobTarget = c.MotionSystem.ActiveMechanicalUnit.GetPosition(CoordinateSystemType.World)

Dim aJointTarget As JointTarget = c.MotionSystem.ActiveMechanicalUnit.GetPosition()

C#:

Controller aController = new Controller();

RobTarget aRobTarget = aController.MotionSystem.ActiveMechanicalUnit.GetPosition(CoordinateSystemType.World);

JointTarget aJointTarget = aController.MotionSystem.ActiveMechanicalUnit.GetPosition();

DataChanged event

By subscribing to the

DataChanged event of the

MechanicalUnit object, you will be notified when a change of tool, work object, coordinated system, motion mode or incremental step size occurs.

VB:

AddHandler aMechUnit.DataChanged, AddressOf aMech_DataChanged

......

Private Sub aMech_DataChanged(sender As Object, e As

MechanicalUnitDataEventArgs)

Select e.Reason

Case MechanicalUnitDataChangeReason.Tool

ChangeOfTool(DirectCast(sender, MechanicalUnit))

Case MechanicalUnitDataChangeReason.WorkObject

......

End Select

End Sub

C#: aMechUnit.DataChanged += new

MechanicalUnitDataEventHandler(aMech_DataChanged);

.....

Continues on next page

158

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.6 Motion domain

Continued private void aMech_DataChanged(object sender,

MechanicalUnitDataEventArgs e) { switch (e.Reason) { case MechanicalUnitDataChangeReason.Tool:

ChangeOfTool((MechanicalUnit)sender) case MechanicalUnitDataChangeReason.WorkObject:

......

}

}

Tip

Read more about the classes, methods and properties available in the

MotionDomain in the Reference Manual FlexPendant SDK.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

159

5 Using the FlexPendant SDK

5.5.7 File system domain

5.5.7 File system domain

Overview

Using the FlexPendant SDK FileSystemDomain you can create, save, load, rename, and delete files on the controller. You can also create and delete directories.

Accessing files and directories

You can access the file system domain through the

Controller object property

FileSystem

.

VB:

Private aFileSystem As FileSystem = aController.FileSystem

C#:

FileSystem aFileSystem = aController.FileSystem;

Controller and FlexPendant file system

You can find and set the remote directory on the controller and the local directory on the FlexPendant device by using the

RemoteDirectory and

LocalDirectory properties.

VB:

Dim remoteDir As String = aController.FileSystem.RemoteDirectory

Dim localDir As String = aController.FileSystem.LocalDirectory

C#: string remoteDir = aController.FileSystem.RemoteDirectory; string localDir = aController.FileSystem.LocalDirectory;

Loading controller files

You can load a file from the controller to the FlexPendant using the

GetFile method. An exception is thrown if the operation fails. The arguments are complete paths including filenames.

VB: aController.FileSystem.FileSystem.GetFile(remoteFilePath, localFilePath)

C#: aController.FileSystem.GetFile(remoteFilePath, localFilePath);

Saving files

You can save a file to the controller file system by using the

PutFile method. An exception is thrown if the operation fails. The arguments are complete paths including filenames.

VB: aController.FileSystem.PutFile(localFilePath, remoteFilePath)

C#: aController.FileSystem.PutFile(localFilePath, remoteFilePath);

Continues on next page

160

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.7 File system domain

Continued

Getting multiple files and directories

The

FileSystem class has a method called

GetFilesAndDirectories

. It can be used to retrieve an array of

ControllerFileSystemInfo objects with information about individual files and directories. The

ControllerFileSystemInfo object can then be cast to either a

ControllerFileInfo object or a

ControllerDirectoryInfo object.

The following example uses search pattern to limit the search.

VB:

Dim anArray As ControllerFileSystemInfo()

Dim info As ControllerFileSystemInfo anArray = aController.FileSystem.GetFilesAndDirectories("search pattern")

Dim I As Integer

For I = 0 To array.Length -1 info = anArray(I)

......

Next

C#:

ControllerFileSystemInfo[] anArray;

ControllerFileSystemInfo info; anArray = aController.FileSystem.GetFilesAndDirectories("search pattern"); for (int i=0;i<anArray.Length;i++) { info = anArray[i];

......

}

Using search patterns

As seen in the preceding example, you can use search patterns to locate files and directories using the

GetFilesAndDirectories method. The matching process uses the Wildcard pattern matching of Visual Studio. The following is a brief summary:

*

#

Character in pattern

?

[charlist]

[!charlist]

Matches in string

Any single character

Zero or more characters

Any single digit (0–9)

Any single character in charlist

Any single character not in charlist

Tip

For more information on classes, methods and properties, see

FileSystemDomain in the Reference Manual FlexPendant SDK.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

161

5 Using the FlexPendant SDK

5.5.8 System info domain

5.5.8 System info domain

Overview

The

SystemInfoDomain provides information about the active robot system. This is mainly done through the static methods and properties of the

SystemInfo class:

5.5.8_1Syste

SystemInfo class

The functionality of the

SystemInfoDomain is accessed by calling the static methods of the

SystemInfo class.The following code explains how to retrieve the path in the controller file system to the release (ROBOTWARE) directory of the active system.

Example: string rWDir =

ABB.Robotics.Controllers.SystemInfoDomain.SystemInfo.ReleasePath

Likewise, the path to the active system directory can be retrieved: string sysDir =

ABB.Robotics.Controllers.SystemInfoDomain.SystemInfo.SystemPath

Continues on next page

162

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

5 Using the FlexPendant SDK

5.5.8 System info domain

Continued

System options

Using the

SystemInfo.SystemOptions

property you can retrieve the system options of the currently active robot system. The result is an array of

SystemOption objects. If you list the

Name property of these objects you will get the same result as shown in the SystemBuilder of RobotStudio, e.g:

5.5.8_2Syste

You can retrieve sub options of a system option by using the

SystemOption.SubOptions

property.

Additional options

Using the

SystemInfo.AdditionalOptions

property you can find out which additional options are installed in the robot system. The result is an array of

AdditionalOption objects. The

AdditionalOption.Path

property returns the path to the installation directory of the additional option.

The following

AdditionalOption properties are available:

• KeyString

• Name

• Path

• Type

• VersionInfo

Note

For more information on

SystemInfoDomain with code examples, see Reference

Manual FlexPendant SDK.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

163

This page is intentionally left blank

6 Robust FlexPendant applications

6.1 Introduction

6 Robust FlexPendant applications

6.1 Introduction

Overview

Developing an application for a device with limited resources, such as memory and process power, can be quite demanding. Moreover, to have an application executing around the clock will reveal weaknesses in design and implementation that may cause slow performance or FlexPendant hangings.

At worst, your application will drain the FlexPendant of all memory during production, and cause an out-of-memory crash. It can even slow down the performance of the robot controller due to excessive use of controller resources.

This chapter describes how to design and implement reliable and well performing applications for the FlexPendant. It presents some good practices to utilize, as well as some pitfalls that should be avoided.

Technical overview of the FlexPendant device

The FlexPendant device consists of both hardware and software and is a complete computer in itself, with its own memory, file system, operating system and processor.

It is an integral part of IRC5, connected to the controller by an integrated cable and connector. Using the hot plug button option, however, you can disconnect the

FlexPendant in automatic mode and continue running without it.

There are ways to restart the FlexPendant without having to restart the controller

(For more information, see

Restart the FlexPendant on page 35

). At a FlexPendant restart the assemblies and resources of FlexPendant SDK applications are downloaded to the FlexPendant file system from the robot controller.

FlexPendant applications run on Windows CE, a scalable embedded operating system, and the .NET Compact Framework, which is Microsoft’s lightweight version of the .NET Framework, intended for small devices.

This is the size of the FlexPendant touch screen:

FlexPendant screen

Total display

FlexPendant SDK Application display

Size

640 * 480 pixels

640 * 390 pixels

The FlexPendant uses these kinds of memory:

Memory type

Flash - 16 MB

RAM - 64 MB

E

2

PROM

Function

Stores the FlexPendant standard software, the Windows CE operating system in compressed format and the registry.

At boot time the compressed image is copied to RAM. All execution of code uses RAM.

Stores touch screen calibration values, joystick calibration values and so on. Only used internally.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

165

6 Robust FlexPendant applications

6.1 Introduction

Continued

How large can a custom application be?

You may wonder about the maximum size of your custom application. There is no exact answer to that question, as there are many variables to take into account.

For a rough estimation the following table can be used. As you see, the operating system uses about 8 MB and the ABB base software about 25 MB. This means that half of the available RAM memory is already used once the FlexPendant has started up. The standard applications of the ABB menu and the FlexPendant SDK applications will all share the memory that is left. As a rule of thumb, about 20 MB should be available for custom applications.

FlexPendant memory resources

RAM

Operating system

ABB base software

Custom applications

128 MB

8 MB

25 MB

~20 MB

This is some advice to help you make sure your application does not exceed the memory limitation:

1 Do not allow more than ONE instance by setting the

TpsViewType parameter of the

TpsView attribute to

Static

. For more information, see

Application type on page 42 .

2 Avoid excessive use of images. Do not use bigger images than necessary.

Check the size of the images your application will use.

3 Use fpcmd “-memShow” to check the amount of memory in use when your application is active. Open a couple of Program Editors and start RAPID execution. For more information, see

Discover memory leaks on page 169

.

4 Avoid static data and methods.

5 Release memory for objects that are not used by calling their

Dispose method.

166

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.2 Memory management

6.2 Memory management

Garbage collection and Dispose

An important feature of the .NET runtime environment is the garbage collector, which reclaims not referenced memory from the managed heap. Generally, this means that the programmer should not have to free memory which has been allocated by the use of new

. A drawback, when memory is limited, is that the execution of the garbage collector is non-deterministic. There is no way of knowing exactly when garbage collection will be performed.

The

IDisposable interface, however, represents a way to obtain deterministic deallocation of resources. You should therefore call

Dispose() on all disposable object when they are no longer needed, as this will free up valuable resources as soon as possible.

Moreover, objects used to access robot controller resources, must be released by the custom application by an explicit call to their

Dispose method.

SignalBindingSource and

RapidDataBindingSouce objects, as well as all other objects located in the components pane of the Visual Studio Designer must also be explicitly disposed of, or else your application will have a permanent memory leak.

Note

The creator of an object implementing the

IDisposable interface is responsible for its lifetime and for calling

Dispose

.

Tip

You may wonder why the .NET garbage collector cannot ensure that all objects no longer referenced are finally destroyed? The FlexPendant development team have tried hard to remove any remaining objects of an SDK application at application shut down, for example implemented finalizers for the

TpsControl

,

RapidDataBindingSouce and

SignalBindingSource classes. Due to

Microsoft’s implementation, however, the .NET runtime nonetheless refuses to destroy these objects unless their

Dispose method is called. This behavior is under debate. If you are curious to find out more about this, these community articles may be of interest.

Dispose, Finalization, and Resource Management (Joe Duffy): http://www.bluebytesoftware.com/blog/PermaLink.aspx?guid=88e62cdf-5919-4ac7-bc33-20c06ae539ae

Garbage Collection: Automatic Memory Management in the Microsoft .NET

Framework (MSDN-magazine): ms-help://ms.msdnqtr.v80.en/ms.msdn.v80/dnmag00/html/GCI.htm

Finalization - cbrumme's WebLog: http://blogs.msdn.com/cbrumme/archive/2004/02/20/77460.aspx

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

167

6 Robust FlexPendant applications

6.2 Memory management

Continued

Application Framework usage - ITpsViewSetup

The application framework TAF, which hosts the controls that make up a

FlexPendant application, offers some mechanisms that should be used by client applications. For more information about TAF, see

Understanding the FlexPendant application life cycle on page 38 .

Your application view class should implement

ITpsViewSetup and

ITpsViewActivation

. For general information on these interfaces, see

ITpsViewSetup and ITpsViewActivation on page 44

and to learn how to use

ITpsViewActivation to improve performance, see

Application Framework usage

- ITpsViewActivation on page 172

.

The

ITpsViewSetup interface has two methods:

Install and

Uninstall

.

Install is called when the view is being created, right after the constructor has been executed.

Uninstall is called when the client view is closed down. After

Uninstall has been called, TAF will also call the

Dispose method of the view class. These methods thus offer the last opportunity for you to clean up and release memory and system resources held by the custom application.

Note

You should close down the application by using the close button, [x], in the upper right corner of the display, in the same way as the Program Data or other standard applications are closed. Never implement a close button on the first view. When the application is closed the correct way, first

Deactivate

, then

Uninstall and finally

Dispose will be called by TAF.

Continues on next page

168

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.2 Memory management

Continued

How to program the Dispose method - example

When starting a new FlexPendant project in Visual Studio a skeleton for the

Dispose method is auto generated. You should use it to add code for cleaning up as shown in the following screenshot:

7.2_1Dispose

Note

Error handling should be added to the

Dispose method (left out in the figure).

Note

Ensure you have unsubscribed to any events from the robot controller before you call the

Dispose method of a CAPI object. If it has been done in the

Deactivate method, which is what is usually recommended, you should not do it again in the

Dispose method. Also ensure you do not try to access an object after it has been disposed.

Discover memory leaks

When your application interacts with the robot controller, unmanaged objects are created under the hood. If you forget to call

Dispose on such objects there will be memory leaks.

You are recommended to test the memory consumption of your application. Use a controller console window on your PC and the command fpcmd_enable_console_output

3 to enable printouts. Then use the

"-memShow" command with a period argument that produces a printout every 500 second for example, like this:

-> period 500, fpcmd, "-memShow"

3HAC036958-001 Revision: B

Continues on next page

169

© Copyright 2010-2013 ABB. All rights reserved.

6 Robust FlexPendant applications

6.2 Memory management

Continued

3

4

Step

1

2

For more information on console window, see

Exception error codes on page 181

Result:

task spawned: id = 0xba7f3b8, name = t2value = 195556280 =

0xba7f3b8-> [fp]: Available memory: 20881408 (tot 40394752), disk: 737148 (tot 1728512) load: 54(261955)[fp]:

The load component indicates the amount of used RAM memory on the FlexPendant

(expressed in percentage of the total amount) and the number in the parenthesis indicates the time taken in ms after start-up. For example in the perceding Result,

54 is the percentage of used memory in the FlexPendant and 261955 ms is the time taken after start-up.

Test all functions of your application with several other FlexPendant views visible in the task bar and possibly one or several RAPID tasks executing. Observe how your implementation affects memory. Close your application and make sure the same amount of memory is available as before opening it.

The following procedure shows yet another way of checking that your application cleans up correctly:

5

Action

Log out from the FlexPendant by clicking Log Off on the ABB menu.

In the controller console window write fpcmd_enable_console_output

.

Write fpcmd "-a"

.

For each cpp class check Number of instances. It shall be 0, except for

AdaptController

(1) and

AdaptEventImpl

(1).

If the previous step shows that there are unmanaged objects left, you need to search your code for missing

Dispose calls.

Note

You must use the real FlexPendant device when verifying memory consumption and looking for memory leaks in your code.

170

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.3 Performance

6.3 Performance

About performance

A FlexPendant application cannot meet hard real time demands. There should however be no difference in performance between a FlexPendant SDK application and the standard applications of the device. If your application is slow, the advice in this section will be useful.

Tip

Do not get overwhelmed by the number of restrictions presented in this section.

Most of the time you will not notice any difference if you decide to neglect a few of them. Yet - it is good to know what can be done whenever performance does become an issue.

Less code means faster code

A general piece of advice (maybe too obvious a recommendation) is that less code normally means faster code. Remember that methods that are executed frequently, such as

OnPaint

, event handlers and so on. must be efficient. Everything that can be computed once and stored for future use should be computed only once.

Fewer controller accesses means faster code

The best thing you can do to improve performance is probably to ensure that you do not access controller functionality more often than necessary. To achieve this you need to understand CAPI, the SDK class libraries used to access robot controller functionality.

It is very easy to use a property of a class and not realize that an access to the controller is actually made. A general recommendation is to try to use subscriptions to controller information (events) where applicable, and let your application store updated values instead of performing numerous reading operations toward the same controller resource.

Tip

You can easily get an estimate of the number of controller accesses your application performs in different user scenarios by using a robot controller console. The console command robdisp_watch 2 monitors and prints controller accesses made by the FlexPendant to the console. Click a button of your application for example, and study how the FlexPendant and the controller communicate in response to this action. Enter the command robdisp_watch

0 to turn this service off. (The monitor service slows down the response time of your application, due to printing to the console. So do not get worried if your application seems unusually slow!)

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

171

6 Robust FlexPendant applications

6.3 Performance

Continued

Note

Keep in mind that an excessive number of controller accesses will slow down the performance of your application. At worst, it may even affect the performance of the robot controller.

Note

Excessive use of subscriptions may also be a problem. If your application has to handle a continuous load of Rapid data and I/O signal events, and your event handlers need to manipulate the data before presenting it, GUI interaction may become slow. As a rule of thumb, do not estimate more than 20 events/sec. and keep the event handlers thin.

Fewer objects means faster code

Fewer objects means better performance. If you know that an object will be used again, create it once and keep a reference. Also, try not to create objects that may not be used.

Reusing existing objects instead of creating new ones is especially important when executing the same code repeatedly, for example in tight loops.

The following example shows how this should be done: object _o = new object(); for (int i = 0; i < 100000; i++)

{ ... }

Tip

Do not create several

Controller objects, but reuse it by sending it as a parameter when creating a new view, or share it between classes as a public property.

Transferring files

Transferring files between the device and the robot controller takes time and also occupies storage memory on the device. Write efficient and fault-tolerant code if it must be done.

Application Framework usage - ITpsViewActivation

The

ITpsViewActivation interface is used by TAF to hide and display your application. It has two methods:

Activate and

Deactivate

. The former is called by TAF at the creation of the client view, right after the

ITpsViewSetup.Install

method has been executed. The latter is called at shut down of the client view, right before the

ITpsViewSetup.Uninstall method is executed.

The interface is also used when you select another application on the task bar.

TAF then calls

ITpsViewActivation.Deactivate

(but not

ITpsViewSetup.Uninstall

). Likewise, when the application regains focus via

Continues on next page

172

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.3 Performance

Continued the task bar icon, TAF calls

ITpsViewActivation.Activate

(but not

ITpsViewSetup.Install

).

It is recommended to enable and disable any subscriptions to controller events in the

ITpsViewActivation methods, as valuable resources should not be held when the application is not used. Note that current values should be read before enabling the subscription.

For the same reason, any timers can be activated and deactivated in these methods.

That way timers will not run when other applications are in focus, thus saving processor power.

Excessive string manipulation is costly

The string class is an immutable type, that is, once a string is created its value cannot be changed. This means that string methods that seem to modify the string in fact create new strings.

Look at a this string concatenation example: string name = "192.168.126.1"; string str = "/" + name + "/" + "RAPID";

Four strings will be appended to one resulting string. No less than four additional strings will be created and allocated when the right hand side of the assignment is executed. A better idea is to use the

StringBuilder class or string.Forma

t

(which uses the

StringBuilder internally): string str = string.Format("/{0}/RAPID", name);

As a rule, if you are going to do only one string operation on a particular string, you can use the appropriate string method. It is when you start doing numerous string operations that you need to use

StringBuilder or string.Format.

Avoid Control.Refresh

Control.Refresh() must only be used when an immediate update of the GUI is absolutely required.

Refresh makes a direct call to the

OnPaint method of the

Control, and is therefore much more costly than

Control.Invalidate()

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

173

6 Robust FlexPendant applications

6.3 Performance

Continued

Several calls to

Invalidate will not mean several calls to

OnPaint

. When the

GUI thread processes the

Invalidate message all queued up messages of the same control are handled at the same time, thus saving process power.

Note

In the 2.0 version of .NET CF there are new methods to be used for GUI controls inheriting

System.Windows.Forms.Control

:

SuspendLayout()

ResumeLayout()

BeginUpdate()

EndUpdate()

These methods are used to control GUI updates while modifying a GUI element.

The control will not be drawn when

SuspendLayout has been called, for example, but is blocked until

ResumeLayout is called.

Avoid boxing and unboxing

A common reason for slow code is unintentional boxing and unboxing. To avoid this, you need to be aware of the difference between reference and value types.

Reference types (the keyword class is used) are always allocated on the heap, while value types are allocated on the stack; unless embedded into a reference type.

Boxing is the operation where a value type, is converted to a reference type. It is done automatically when a reference to a value type is required. Then a new object will be created, allocated on the heap with a copy of the original data.

Here are some examples of not so obvious boxing/unboxing:

• Using the foreach statement on an array that contains value types will cause the values to be boxed and unboxed.

• Accessing values of a Hashtable with a value type key, will cause the key value to be boxed when the table is accessed.

• Using an ArrayList with value types; this should be avoided - use typed arrays instead. Typed arrays are also better because of type safety, as type checking can be performed at compile time.

• The following methods should be overridden in order to avoid unnecessary boxing/unboxing: Equals( ), GetHashCode( ).

Foreach

Using a for loop is often faster than using the foreach statement, especially if a large number of iterations are made. The reason is that the JIT compiler (see

About terms and acronyms on page 17

) is prohibited to optimize the code execution when foreach is used.

However, foreach makes the code more readable and is therefore a better option when performance is not crucial.

Continues on next page

174

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.3 Performance

Continued

Reflection is performance demanding

Reflection is a mechanism used to read the meta data of an assembly. The

typeof operator, for example, uses reflection to determine the type of an object. Another example is object.ToString()

, which also uses reflection.

As reflection is very performance demanding you are recommended to override or to avoid the

ToString() method for reference types.

Efficiently parsing Xlm

XmlTextReader and

XmlDocument can both be used to parse xml data. The

XmlTextReader is the preferred option in most cases; it is more light weight (less memory footprint) and a lot faster to instantiate. The limitation of the

XmlTextReader is that forward only reading is possible.

The xml structure may also have an impact on performance. If xml data is organized in non- flat way, search operations will be faster, as a large portion of the information can be skipped. This is achieved by using categories and sub categories.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

175

6 Robust FlexPendant applications

6.4 Reliability

6.4 Reliability

Overview

This section presents information on how to make the application robust. The most important mechanism related to robustness and reliability is error handling. Avoiding thread conflicts and memory leaks are however also important means of improving reliability.

Error handling in .NET applications

As already pointed out in this manual, Microsoft recommends that exceptions are used to discover and report anomalities in .NET applications. If you are not sure about when to use exceptions or how to do the implementation you should read

Exception handling on page 56

to understand the general idea before moving on to the FlexPendant specific information of this section.

SDK exception classes

The

ABB.Robotics

namespace provides quite a few exception classes, used by the FlexPendant SDK and SDK applications. In addition, the SDK also uses

System exceptions and may throw a

System.ArgumentException

object for example.

Whenever an exception is thrown, your application must catch it and take proper action. You catch an exception by using the try-catch(-finally) statements.

For more information about how to implement these statements, see

Exception handling on page 56

.

As you see in the following image

GeneralException derives from

BaseException

, which in turn derives from

System.ApplicationException

of the .NET Framework class library.

ApplicationException is thrown by user programs, such as the FlexPendant

SDK, not by the Common Language Runtime (CLR, for more information, see

Continues on next page

176

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.4 Reliability

Continued

Definitions on page 17

). It therefore represents a way to differentiate between exceptions defined by applications versus exceptions defined by the system.

As you see there are derived types under

GeneralException

. The following table lists and briefly describes these types:

7.4_1General

7.4_2FP_SDK_

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

177

6 Robust FlexPendant applications

6.4 Reliability

Continued

Tip

For more information on FlexPendant SDK exception classes, see Reference

Manual FlexPendant SDK.

Thread affinity

You should be aware that execution of code modifying the user interface, has to be done on the thread that created the GUI control, the so called GUI thread.

An application initially starts with a single thread. Normally all user interface controls are created by this thread. Windows CE user interface objects are characterized by thread affinity, which means that they are closely coupled with the thread that created them.

Interacting with the message queue of an interface control from a thread other then the creating thread may cause data corruption or other errors. This restriction applies to the thread pool as well as to explicitly created threads.

When executing on a secondary thread, a so called worker thread, an update of the user interface must therefore be done very carefully, enforcing a switch to the

GUI thread. This is in fact a very common scenario, as controller events use their own threads and should often be communicated to the end user by a GUI update.

Note

Thread affinity is especially relevant as for robot controller events, as these by default execute on a background thread. For more information and code samples, see

Controller events and threads on page 51

and

Controller events and threads on page 51

. The following section also deals with the same issue.

Invoke

In order to execute a method on the GUI thread

Control.Invoke

can be used.

It should however be done carefully, as it makes a synchronous call to the specified event handler, which blocks execution until the GUI thread has finished executing the method. All concurrent calls to

Invoke will be queued and executed in their queue order by the GUI thread. This could easily make the GUI less responsive.

There is now an asynchronous version of

Invoke

, which should be used instead whenever possible.

TpsControl.BeginInvoke

is a non blocking method, which lets the worker thread continue execution instead of waiting for the GUI thread to have processed the method

Remember that

Invoke as well as BeginInvoke should only be used on code that modifies the user interface. You should keep the execution on the background thread as long as possible.

Note

If your code tries to access a GUI control from a background thread the .NET

common language runtime will throw a

System.NotSupportedException

.

Continues on next page

178

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

6 Robust FlexPendant applications

6.4 Reliability

Continued

Memory leaks

As FlexPendant applications are supposed to run without interruption, no memory leaks can be permitted. It is your responsibility to properly clean up and call

Dispose

. Take your time studying

How to avoid memory leaks on page 77

,

Memory management on page 167

and

Technical overview of the FlexPendant device on page 165

.

Utilizing multi-threading

Threading enables your program to perform concurrent processing so you can do more than one operation at a time. For example, you can use threading to monitor input from the user, and perform background tasks simultaneously. The

System.Threading

namespace provides classes and interfaces which enable you to easily perform tasks such as creating and starting new threads, synchronizing multiple threads, suspending threads and aborting threads.

The classes

Thread and

ThreadPool can be used to execute methods on a worker thread. Use

ThreadPool for temporary usage of a background thread when a task is meant to terminate fairly soon. Use

Thread only for background work that will persist, for example a thread that fetches data from the controller continuously.

There are two timers available in .NET CF that can be used to execute methods periodically at specified intervals. There is however, an important difference between these. The

System.Threading.Timer

executes the method on a background thread, while the

System.Windows.Forms.Timer

executes the method on the

UI thread.

Note

Use

System.Threading.Timer

if you want to poll data from the controller in order to reduce the load on the GUI thread.

Lock statement

The lock statement is used in multi-threaded applications to make sure access to a part of the code is made by one thread exclusively. If a second thread attempts to lock code which has already been locked by another thread, it must wait until the lock is released.

Remember to limit the code segment that you want to control, that is, only lock what is absolutely necessary to make the code thread safe:

Object thisLock = new Object(); lock (thisLock)

{

// Critical code section

}

Deadlocks must be avoided. They can occur if more than one lock is used. If more than one lock object must be held, they must always be locked and released in the same order, wherever they are used.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

179

6 Robust FlexPendant applications

6.4 Reliability

Continued

Note

If a deadlock occurs, the FlexPendant system will hang. If this happens you should attach the device to the Visual Studio debugger and study the call stack of the threads in the Threads window.

CAUTION

Using the lock statement in combination with a call to

Invoke is a potential cause to deadlock situations, since

Invoke is a blocking call. In short, be careful if you use locks!

Multicast delegates

If a multicast delegate is executed, the execution of the delegates is terminated if an exception is thrown by one of the delegates. It means that the remaining delegates in the list will not be executed if an exception is thrown. This situation can cause erratic behavior, which may be tricky to trace and debug.

Therefore, if you have numerous delegates which are to execute as the result of the same event, you may want to implement the

GetInvocationList method. It retrieves a list with a copy of the delegates. This list can be iterated and each delegate called directly:

7.4_3.GetInv

180

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.1 Debugging

7 FlexPendant - Debugging and troubleshooting

7.1 Debugging

Introduction

Using the Visual Studio debugger for a FlexPendant SDK application presents no difference compared to standard .NET development. Debugging can be done using the virtual IRC5 in RobotStudio or a real controller.

Exception error codes

Some exceptions that may appear during development have error codes associated with them. The error codes may help you correct the problem.

Code

0x80040401

0x80040402

0xC0040401

0xC0040402

0xC0040403

0xC0040404

0xC0040405

0xC0040406

0xC0040408

0xC0040409

0xC0040410

0xC0040411

0xC0040412

0xC0040413

0xC0040414

0xC0040415

0xC0040416

0xC0040417

Description

The requested poll level could not be met, poll level low is used.

The requested poll level could not be met, poll level medium is used.

No connection with controller.

Error connecting to controller.

No response from controller.

Message queue full. (Should only happen if asynchronous calls are made.)

Waiting for a resource.

The message sent is too large to handle.

A string does not contain characters exclusively from a supported encoding, for example ISO-8859-1 (ISO-Latin1).

The resource can not be released since it is in use.

The client is already logged on as a controller user.

The controller was not present in NetScan.

The NetScanID is no longer in use. Controller removed from list.

The client id is not associated with a controller user. Returned only by methods that need to check this before sending request to controller. Otherwise, see 0xC004840F.

The RobotWare version is later than the installed Robot Communication Runtime. A newer Robot Communication Runtime needs to be installed. Returned by RobHelperFactory.

The major and minor part of the RobotWare version is known, but the revision is later and not fully compatible. A newer Robot

Communication Runtime needs to be installed. Code returned by RobHelperFactory.

The RobotWare version is no longer supported. Code returned by RobHelperFactory.

The helper type is not supported by the RobotWare. Helper might be obsolete or for later RobotWare versions, or the helper may not be supported by a BootLevel controller. Code returned by RobHelperFactory.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

181

7 FlexPendant - Debugging and troubleshooting

7.1 Debugging

Continued

Code

0xC0040418

0xC0040601

0xC0040602

0xC0040603

0xC0040604

0xC0040605

0xC0040606

0xC0040607

0xC0040608

0xC0040609

0xC0040701

0xC0040702

0xC0040703

0xC0040704

0xC0040705

0xC0048401

0xC0048402

0xC0048403

0xC0048404

0xC0048405

0xC0048406

0xC0048407

0xC0048408

0xC0048409

0xC004840A

0xC004840B

0xC004840C

0xC004840D

0xC004840F

Continues on next page

182

Description

System id and network id mismatch, they do not identify the same controller.

Call was made by other client than the one that made the

Connect() call.

File not found on the local file system. Can be that file, directory or device does not exist.

File not found on the remote file system. Can be that file, directory or device does not exist.

Error when accessing/creating file on the local file system.

Error when accessing/creating file on the remote file system.

The path or filename is too long or otherwise bad for the Vx-

Works file system.

The file transfer was interrupted. When transferring to remote system, the cause may be that the remote device is full.

The local device is full.

Client already has a connection and can not make a new connection until the present one is disconnected.

One or more files in the release directory is corrupt and cannot be used when launching a VC.

One or more files in the system directory is corrupt and cannot be used when launching a VC.

A VC for this system has already been started; only one VC per system is allowed.

Could not warm start VC since it must be cold started first.

The requested operation failed since VC ownership is not held or could not be obtained.

Out of memory.

Not yet implemented.

The service is not supported in this version of the controller.

Operation not allowed on active system.

The data requested does not exist.

The directory does not contain all required data to complete the operation.

Operation rejected by the controller safety access restriction mechanism.

The resource is not held by caller.

An argument specified by the client is not valid for this type of operation.

Mismatch in controller id between backup and current system.

Mismatch in key id, that is, options, languages and so on.

between backup and current system.

Mismatch in robot type between backup and current system.

Client not allowed to log on as local user.

The client is not logged on as a controller user.

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.1 Debugging

Continued

Code

0xC0048410

0xC0048411

0xC0048412

0xC0048413

0xC0048414

0xC0048415

0xC0048416

0xC0048417

0xC0048418

0xC0048419

0xC004841A

0xC004841B

0xC004841C

0xC004841D

0xC004841E

0xC004841F

0xC0048420

0xC0048421

0xC0048422

0xC0048423

0xC0049000

0xC0049001

0xC0049002

0xC0049003

0xC0049004

0xC0049005

0xC0049006

0xC0049007

0xC0049008

0xC0049009

0xC004900A

0xC004900B

0xC004900C

0xC004900D

3HAC036958-001 Revision: B

Description

The requested resource is already held by caller

The max number of the requested resources has been reached.

No request active for the given user.

Operation/request timed out on controller.

No local user is logged on.

The operation was not allowed for the given user.

The URL used to initialize the helper does not resolve to a valid object.

The amount of data is too large to fulfill the request.

Controller is busy. Try again later.

The request was denied.

Requested resource is held by someone else.

Requested feature is disabled.

The operation is not allowed in current operation mode. For example, a remote user may not be allowed to perform the operation in manual mode.

The user does not have required mastership for the operation.

Operation not allowed while backup in progress.

Operation not allowed when tasks are in synchronized state.

Operation not allowed when task is not active in task selection panel.

Mismatch in controller id between backup and current system.

Mismatch in controller id between backup and current.

Invalid client id.

RAPID symbol was not found.

The given source position is illegal for the operation.

The given file was not recognized as a program file, for example the XML semantics may be incorrect.

Ambiguous module name.

The RAPID program name is not set.

Module is read protected.

Module is write protected.

Operation is illegal in current execution state.

Operation is illegal in current task state.

The robot is not on path and is unable to restart. Regain to or clear path.

Operation is illegal at current execution level.

Operation can not be performed without destroying the current execution context.

The RAPID heap memory is full.

Operation not allowed due to syntax error(s).

Continues on next page

183

© Copyright 2010-2013 ABB. All rights reserved.

7 FlexPendant - Debugging and troubleshooting

7.1 Debugging

Continued

Code

0xC004900E

0xC004900F

0xC0049010

0xC0049011

0xC0049012

0xC0049013

0xC0049014

0xC0049015

0xC004A000

0xC004A001

0xC004A002

0xC004A003

0xC004A004

0xC004A005

0xC004A006

0xC004A007

0xC004A008

0xC004A009

0xC004A00B

0xC004A00C

0xC004A200

Description

Operation not allowed due to semantic error(s).

Given routine is not a legal entry point. Possible reasons are: routine is a function, or routine has parameters.

Illegal to move PCP to given place.

Max number of rob targets exceeded.

Object is not mod possible. Possible reasons are: object is a variable, object is a parameter, object is an array.

Operation not allowed with displacement active.

The robot is not on path and is unable to restart. Regain to path. Clear is not allowed.

Previously planned path remains. Choose to either consume the path, which means the initial movement might be in an unexpected direction, or to clear the path and move directly to next target.

General file handling error.

The device is full.

Wrong disk. Change disk and try again.

The device is not ready.

Invalid path.

Not a valid device.

Unable to create directory.

The directory does not exist.

The directory already exists.

The directory contains data.

Unable to create file.

File not found or could not be opened for reading.

Disable of unit not allowed at trustlevel 0.

184

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.2 Debug output

7.2 Debug output

Overview

It is possible to get debug output from the FlexPendant by using the network. This is useful for several reasons. It will reveal any exceptions thrown during execution, for example, providing you with error messages and call stacks. Moreover, it can help you check memory consumption and memory leaks in your application.

The FlexPendant message is packed into a network message and sent out on the network as a broadcast message on port 9998. Such a message can be picked up in different ways:

• Connect a hub on the local FlexPendant network and connect a PC to it. Use nc.exe to pick up the messages (nc - lup 9998).

• The messages sent are also stored in a ring-buffer of size 100kB. To read the buffer to file and store it on the controller, you can use the FlexPendant

Command Server. Use fpcmd “-d”.

• It is also possible to start a task on the controller that listens to port 9998 and displays all messages in the console buffer. Use command fp_enable_console_output.

Tip

For a list of exceptions that the IRC5 Controller may throw, see

Debugging on page 181

.

Enable debug output

To enable debug output write fpcmd_enable_console_output in the controller console window. For more information on console window, see

Exception error codes on page 181 .

These are the console commands used to enable and disable printouts:

Console command

fpcmd_enable_console_output 1 fpcmd_enable_console_output 2 fpcmd_enable_console_output 3

Result

Starts producing printouts from RobotWare to the robot controller console.

Starts producing printouts from SDK application.

Combines the two preceding: RobotWare + SDK printouts.

Stops printout to the robot controller console.

fpcmd_disable_console_output

The following command can be used to retrieve detailed status of the robot controller, which may be useful, although it may not be specifically related to your application.

Console command

fpcmd “-d”

Result

Produces a log file with extensive information on system status to the robot controller file system(hd0a/temp). Use an ftp client or the File Manager in RobotStudio to transfer the file to your PC.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

185

7 FlexPendant - Debugging and troubleshooting

7.2 Debug output

Continued

FlexPendant Command Server

By using the command line on the controller you can send commands to the

FlexPendant. The FlexPendant has a command server that interprets the commands and performs the requested operation. The syntax for command line commands is fpcmd “<command>”. The only command you need to remember is fpcmd "-h"

, which is the Help command. It produces a printout of available FlexPendant commands in the controller console:

-> fpcmd "-h" value = 8 = 0x8-> [fp]: FlexPendantCmd: Help

The following table lists the command with the specific actions:

Command

fpcmd "-h" fpcmd "-a" fpcmd "-m" fpcmd "-i" fpcmd "-f" fpcmd "-x" fpcmd "-s" fpcmd "-d" fpcmd "-as" fpcmd "-rd" fpcmd "-restart" fpcmd "-memshow" fpcmd "-module" fpcmd "-filePut" fpcmd "-filleted" fpcmd "-diarist"

Action

Help

Adapter show routine

Measure time in adapters

Display FlexPendant Information

Bring GTPU Services to front

Hide startup progress bar

Start application

Copy Debug file to controller

Print screen

Robot Communication Runtime debug

Restart Device

Available memory

Module information of a process

Upload a file to the FlexPendant

Download a file to the FlexPendant

List a directory

Note

All commands support -? (for example fpcmd “-memShow -?”), which gives further information about the specific command.

Tip

It is possible to monitor memory consumption in the robot controller console window:

1 Write fpcmd_enable_console_output 3

.

2 Write fpcmd "-memShow"

.

For more information, see

Memory management on page 167

.

Continues on next page

186

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.2 Debug output

Continued

Trace and Debug

The

ABB.Robotics.Diagnostics namespace provides trace and debug services. Its

Trace and

Debug classes are specifically designed for the FlexPendant environment.

The properties and methods in the

Trace class are used to instrument release builds, which allows you to monitor the health of your application running in a real-life setting. Tracing can help you to isolate problems and fix them without disturbing a running system.

If you use methods in the

Debug class to print debugging information and check your logic with assertions, you can make your code more robust without impacting the performance and code size of your shipping product. In Visual Studio, creating a debug build enables

Debug

.

Trace and

Debug give printout information during execution. Messages are displayed on the FlexPendant screen or in the robot controller console. The functionality is similar to that provided by the .Net

Trace and

Debug classes.

The

Assert method checks for a condition and displays an assert message on the FlexPendant, including detailed information and a stack trace, if the condition is false. The message is also displayed in the controller console window if you enter the command

fpcmd_enable_console_output first.

Note

Add the

ABB.Robotics.Diagnostics namespace to the using section at the top of your source code file.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

187

7 FlexPendant - Debugging and troubleshooting

7.3 Debugging the virtual FlexPendant

7.3 Debugging the virtual FlexPendant

Overview

When debugging your application it is often convenient to use the virtual environment, but it is almost as easy to attach the Visual Studio debugger to the real FlexPendant device. For information about how that is done see

Debugging the FlexPendant device on page 192

.

This section describes how to start the Visual Studio debugger, attach a running

Virtual FlexPendant to it, set up break points and step through the source code of a FlexPendant application.

Debugging procedure

There are several ways of attaching a Visual Studio debugger to a running Virtual

FlexPendant application. In this section one method is described in detail.

There is no way to start your FlexPendant application from inside the Visual Studio environment. You must start by deploying the application to the Virtual FlexPendant in RobotStudio. How to do this is described in

Hands on - Hello world on page 70 .

Then you start the Virtual FlexPendant and attach the Visual Studio debugger to it.

Note

In order to use break points the project build configuration must be Debug. You set it in the the Build tab of the Project Properties. The output directory, where you find the assembly (*.dll), the proxy assembly (*gtpu.dll) and the program database (*.pdb) is the bin/Debug directory, a sub-directory of your Visual Studio project.

Continues on next page

188

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.3 Debugging the virtual FlexPendant

Continued

Attach to Process

When you have a running application on the Virtual FlexPendant follow these steps:

Step

1

Action

In Visual Studio on the Debug menu, select Attach to Process. It brings up this dialog:

2

3

4

9.1.3_1Attac

Select the Virtual FlexPendant.exe process and click the Attach button.

Set a break point in your source code.

On the Virtual FlexPendant, click a button of your application or something else that will make program execution hit the breakpoint.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

189

7 FlexPendant - Debugging and troubleshooting

7.3 Debugging the virtual FlexPendant

Continued

Step

5

Action

On the Debug menu, point at Windows and select the debugging information to be displayed while debugging. See following example:

6

7

9.1.3_2StepB

On the Debug menu, select the appropriate Step command when stepping through your code.

On the Debug menu, click Detach All or Stop Debugging when you want to stop debugging.

Continues on next page

190

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.3 Debugging the virtual FlexPendant

Continued

Windows Task Manager

You can also attach a running application through the Windows Task Manager.

Step

1 Start Windows Task Manager and select the Processes tab.

9.1.3_3TaskM

2

3

Select the Virtual FlexPendant.exe process and right-click to get the context menu. In that menu select Debug. You will get a warning message, but select

Yes.

A Just -In -Time Debugging dialog will appear. Select your application project as the debugger to use.

Launching debugger programatically

Yet another way of attaching a debugger is to launch it programatically, by writing code in your application.

Step Action

Insert the following line where you want the debugger to start:

System.Diagnostics.Debugger.Launch()

Start the application in the Virtual FlexPendant and perform the action which is to launch the debugger. A Just- In-Time Debugging dialog will appear.

Select your Visual Studio project as the debugger. Click OK and start the debug session.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

191

7 FlexPendant - Debugging and troubleshooting

7.4 Debugging the FlexPendant device

7.4 Debugging the FlexPendant device

Overview

This section provides information on how to do debug an application executing on the real FlexPendant device.

In general, using the Visual Studio debugger to debug the device works very well and is strongly recommended, but depending on the OS, Visual Studio version and FlexPendant version you are using the requirements for setting up and attaching the Visual Studio debugger will differ somewhat.

Further information and updates concerning this topic will from this release be published on the FlexPendant SDK User Forum (and not in theApplication manual).

For more information, see

FlexPendant SDK User Forum on page 194 .

Prerequisites

The following requirements have to be met:

• Service Pack 1 or 2 for .NET Compact Framework 2.0 (.NET CF 2.0 SP2) is required for setting up and using the Visual Studio debugger on the

FlexPendant device. It can be downloaded from http://www.microsoft.com/downloads.

• To debug with Visual Studio 2008 (as well as Visual Studio 2005 without SP1) you must follow a procedure that will be presented on the FlexPendant SDK

User Forum. The procedure will be different for each RobotWare release.

• If your PC is running under Windows Vista “Windows Mobile Device Center” needs to be installed in order to connect to the device.

Setting up the network

This illustration shows how to connect the FlexPendant, the Robot Controller and your PC in order to debug your application using the Visual Studio debugger.

9.1.4_3Debug

The FlexPendant has a static IP address 192.168.126.10. Your PC IP address must be one on the 126 subnet, that is, 192.168.126.x (not 1 or 255).

Note that this setup is completely independent of the LAN and Service ports. You are plugging the TPU cable from the RC into the switch, a cable from the switch to the RC, and a cable from your PC to the switch.

Continues on next page

192

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.4 Debugging the FlexPendant device

Continued

A connection over the LAN port is optional, but useful, as you may need to use

RSO or FTP at the same time. To use both connections, your PC requires two

NICs.

Debugging procedure

Follow these steps to set up and attach the Visual Studio 2005 SP1debugger to the FlexPendant device:

Step

1

2

Action

On the Tools menu in Visual Studio 2005 click Options.

In the Options dialog expand the Device Tools node and select Devices. Select

Windows CE 5.0 Device as shown in the following screenshot.

3

4

9.1.4_6FPDeb

Note! If your FlexPendant version is SxTpu1 the option Windows CE 5.0 Device is not available. Instead you should select Pocket PC 2003 Device.

When the right device has been selected click Properties and then Configure.

Apply the settings shown in the picture.

9.1.4_7FPDeb

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

193

7 FlexPendant - Debugging and troubleshooting

7.4 Debugging the FlexPendant device

Continued

Step

5

Action

On the Debug/Tools menu in Visual Studio click Attach To Process. In the dialog select Smart Device for Transport and click the Browse button to specify platform and device. Then click Connect.

6

7

8

9.1.4_8FPDeb

In the Available Processes list select taf.exe. Click Attach.

Set a break point in your source code.

On the FlexPendant, click a button of your application or something else that will make program execution hit the breakpoint.

Note

If your PC is NOT using XP with Visual Studio 2005 SP1 you need to find information on how to attach the Visual Studio debugger for your specific environment on the FlexPendant SDK User Forum.

FlexPendant SDK User Forum

The User Forum of ABB’s RobotStudio Community has a section dedicated to

FlexPendant SDK. Here beginners as well as experts discuss code and solutions online. This is also where you find FlexPendant SDK releases for free download and any information that the development or support team want to share with you.

For more information, see

RobotStudio Community on page 16 .

194

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

7 FlexPendant - Debugging and troubleshooting

7.5 Troubleshooting FlexPendant applications

7.5 Troubleshooting FlexPendant applications

Overview

If you encounter problems when running your application there are a few things you should do before contacting your service organization. The following steps represent a rough guideline:

1

2

3

4

5

Action

Is it possible to start your application? If not see

FlexPendant application does not start on page 195 .

Have you checked the FlexPendant SDK Release Notes? Many questions will find an answer in the Release Notes of the specific release. These are available on the RobotWare DVD and at the Software Download Site.

Have you tried to pinpoint the problem by debugging the FlexPendant? If not see

Debugging the FlexPendant device on page 192

for information about how to do it.

Have you tried to get debug printouts? For more information, see

Debug output on page 185

.

Is the problem FlexPendant hangings? Make sure you use

Invoke when modifying the user interface due to a robot controller event. For more information, see

GUI and controller event threads in conflict on page 51

and

Invoke method on page 52 .

When a hanging occurs attach the Visual Studio debugger to the FlexPendant. On the Debug menu, point at Windows and select Threads. Examine the threads to discover any deadlocks.

Tip

If you still have not found a solution to your problem, take a look at the User

Forum of RobotStudio Community, which includes a forum dedicated to discussion and chat on FlexPendant SDK, RAPID and IRC5 development topics.

For more information, see

Documentation and help on page 15

FlexPendant application does not start

If you are unable to start your application the following table suggests possible scenarios.

Problem

The proxy assembly (*.gtpu.dll) is not built.

Possible solution

Correct any parameter error in the TpsView attribute.

For more information, see

FlexPendant TpsView attribute on page 40 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

195

7 FlexPendant - Debugging and troubleshooting

7.5 Troubleshooting FlexPendant applications

Continued

Problem

The ABB Compliance Tool complains it cannot find the C# compiler.

Possible solution

It happens that the installation of Visual Studio does not set the path to the C# compiler properly. The C# compiler is necessary for running the ABB Compliance

Tool.

Confirm that the C# compiler is available by starting a command window and run “CSC.EXE”. If the result is similar to this the path is properly set:

C:\>csc.exe

Microsoft (R) Visual C# .NET Compiler version

7.10.3052.4

for Microsoft (R) .NET Framework version

1.1.4322Copyright (C) Microsoft Corporation 2001-2002.

All rights reserved.

fatal error CS2008: No inputs specified

If not, find CSC.EXE and copy its path to the Properties dialog of your Visual Studio project. Also add the path to the system PATH environment variables.For Windows 2000 Pro and Windows XP find the dialog for this at:Control Panel -> System -> Advanced ->Environment

Variables -> System variables-> Add new. Add the path to the directory where the C# compiler is kept. Notice that a semicolon separates the path items.Verify in the command window afterwards that the CSC.EXE runs.

The application does not appear in the ABB menu.

Make sure the robot system has the FlexPendant Interface option.

Null reference exception or “Can’t

find object” when tapping the application icon in the ABB menu.

Make sure all arguments in the TpsView attribute are appropriate. For more information, see

FlexPendant

TpsView attribute on page 40 .

The bitmap constructor fails when the real FlexPendant tries to load your images, in the virtual environment this does not happen.

Change your images if they use more than 256 colors.

The operating system of the first generation FlexPendant device (SxTPU1) only supports 256 colors.

The Virtual FlexPendant process remains alive.

If you forget to dispose an object that has a COM reference, such as the Controller object or a Signal, the

Virtual FlexPendant process might stay alive. Go through the application and make sure that you dispose of all objects that have a Dispose method.

Important support information

If you cannot solve the problem on your own, make sure that before taking contact with a support organization this information is available:

• Written description of the problem.

• Application source code.

• System error logs.

• A backup of the system.

• Description of work-around if such exists.

Tip

Even better than the complete application is a small repro program, which exposes your problem.

196

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

8 Localizing a FlexPendant application

8.1 Adding support for several languages

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Introduction

This chapter provides the information needed to localize a customized application.

The FlexPendant has built-in support for localization, and the mechanisms used by the standard FlexPendant applications can also be used by FlexPendant SDK applications.

This enables customized applications to be presented in the active language of the FlexPendant, that is, the language selected in the standard view Control Panel

- Language.

For this to work the texts displayed in the customized application must be translated and the application localized as described in this chapter.

Get started

Develop the application using English as the default language. The recommendation is to design, implement and test the application before adding support for other languages. To localize a FlexPendant application carefully complete each procedure of this chapter.

Note

A method is needed to handle localization when new application functionality is added.

1 Create project for text resources

This procedure sets up a separate project for the user interface texts.

Step

1

Action

Create a new project in the solution. Choose a Smart Device - Windows CE 5.0 -

Empty Project and name the project <YourAppName>Texts.

2

3

4

Note

Both projects should belong to the same solution. The application will now compile to three assemblies: <YourAppName>.dll , <YourAppName>.gtpu.dll and

<YourAppName>Texts.dll.

In the Texts project add a reference to System (.Net ).

Set the Output type to Class Library (this is done in the Project Properties).

The namespace used for the Texts project must be the same as used for the main project. As the namespace is not visible in the resource file you must change it in the Project Properties like this:

10.1_5String

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

197

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

5

6

Action

Add a Resources file to the project by right clicking the project in Solution Explorer and selecting Add New Item. Set the name of the file to “strings.resx". This file will contain the texts of the default language (normally English).

Open the resource file and add name and value for the texts of the default language.

Use capital letters in the name column.

7

6.5.1_1Multi

In the Texts project create a folder with the culture short form as name, for example de for German and sv for Swedish.

8

10.1_6FPLang

Note

Russian (ru) has been added in RobotWare/FlexPendant SDK 5.11.

CAUTION

The standard short forms listed in the preceding screenshot must be used.

Note

To use Chinese or another language with non-western characters, you must use the FlexPendant font,

TpsFont

, for any UI controls. It internally checks what language is currently active on the FlexPendant and uses the correct font for that language.

Copy the “strings.resx” file to the folder(s) created in the previous step.

Continues on next page

198

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

9

Action

The name of the file used for the foreign resources should be strings.<culture>.resx, for example “strings.sv.resx" as in the following screenshot. Right click the file and rename it.

10

10.1_4String

Open the resource file and translate the texts in the value column. The name is the identity of the text and should remain the same.

Note

Obviously, texts might get longer or shorter when translated. You may therefore need to increase the sizes of some GUI controls when you have tested the application.

2 Prepare main project for localization

Follow these steps to add localization to your main project:

Step

1

2

Action

Add a reference to ABB.Robotics.Taf.Base in the main project.

In the

TpsView attribute of the view class insert the name of the Texts dll like this:

[assembly: TpsView("ABB_MENU_TITLE_TXT","tpu-Operator32.gif","tpu-Operator16.gif", "TpsViewIRC5App.dll",

"TpsViewIRC5App.TpsViewIRC5App", StartPanelLocation.Left, TpsViewType.Static,"TpsViewLocalizedApp-

Texts.dll", TpsViewStartupTypes.Manual)]

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

199

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

3

Action

Declare a

TpsResourceManager object at the top of the class as a private member variable and initialize it in the constructor.

Add a call to an

InitializeTexts method.

//declaration private ABB.Robotics.Tps.Resources.TpsResourceManager _tpsRM;

//constructor method

_tpsRM = new ABB.Robotics.Tps.Resources.TpsResourceManager("TpsViewLocalizedApp.strings", ABB.Robotics.Taf.Base.TafAssembly.Load("TpsViewLocalizedApp-

Texts.dll"));

InitializeComponent();

InitializeTexts();

4

5

Note

The first constructor argument should be the name of your application with .strings

as an added suffix. The second argument is the name of the assembly containing the resources.

Implement

InitializeTexts

( ). Use the

TpsResourceManager object and call

GetString

( ) using the identity (name) of the text you want as argument. Depending on the active language of the FlexPendant this call will retrieve the corresponding language resource.

Example:

InitializeTexts()

{ this.Label1.Text = _tpsRM.GetString("TXT_INSTR_LABEL");

}

Leave the contents of the

InitializeComponent method as it is, for example

Label1.Text = "Signals" and so on.

The

TpsResourceManager object has not yet been created when the application icon and title are to appear in the ABB menu, and therefore another technique must be used to have them correctly displayed. Add a resource name for the application title and a value in the resource file of each language.

In the

TpsView attribute the first argument is the application title. Replace it with the resource name. It may look like this:

[assembly: TpsView("ABB_MENU_TITLE_TXT", ...,...

TpsViewIRC5AppTexts.dll")]

The corresponding resource value will now be used. In case no resource is found the name will be used as is.

Continues on next page

200

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

3 Build satellite assembly

Follow these steps to create a satellite assembly of the localized resx file:

Step

1

Action

The localized resource file should not be built with the ordinary build process, that is, the property Build Action should be set to “None". Right click on the strings.<culture>.resx file and select properties:

2

6.5.1_4resxP

You should now use the Visual Studio 2005 tool resgen.exe to compile the resx file to a binary resource. After this the Visual Studio 2005 assembly linker tool al.exe should make a satellite assembly of the binary resource.

Read the following steps very carefully to make sure the satellite assembly is built correctly.

Note

Localization with Visual Studio 2008 has not yet been tested.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

201

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

3

Action

Create a post-build event in the Texts project in order to automate the building process.

Example:

TpsViewLocalizedApp with resources in Swedish: mkdir ..\..\language mkdir ..\..\language\sv mkdir ..\..\language\sv\tps cd ..\..\sv\ del *.resources

del *.dll

if exist strings.sv.resx ( resgen strings.sv.resx TpsViewLocalizedApp.strings.sv .resources al /t:lib /embed:TpsViewLocalizedApp.strings.sv.resources

/culture:en /out:TpsViewLocalizedAppTexts.resources.dll

copy TpsViewLocalizedAppTexts.resources.dll ..\language\sv\tps\TpsViewLocalizedAppTexts.resources.dll)

10.1_9PostBu

The resgen command is written like this: resgen strings.<culture>.resx

<Namespace>.strings.<culture>.resources

where

<culture> should be replaced with the correct language short form and

<Namespace> should be replaced with the application namespace.

The al command takes the resulting dll located in the same directory as the resx file and makes a satellite assembly of it: al /t:lib /embed:<Namespace>.strings.<culture>.resources

/culture:en /out:<AssemblyName>.resources.dll

Note

The name of the satellite assembly will be the same for all localized languages.

The third argument of the al command, culture:en, should be “en” . The reason is that the FlexPendant operating system has English as the underlying language.

Continues on next page

202

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

4

Action

It is necessary to ensure that the post-build step is executed with the correct versions of resgen.exe and al.exe. The easiest way to do this is to use a Visual Studio 2005

Command prompt to build the project (or solution) or to start Visual Studio from that prompt.

First click Windows Start menu to launch the Command Prompt (at Programs >

Microsoft Visual Studio 2005 > Visual Studio Tools).Then use the command devenv in order to start Visual Studio 2005.

Now open your solution and build it. The post-build command is now guaranteed to execute with the correct settings.

6.5.1_5VSCmd

Note

As default, Visual Studio will run post-build commands using the PC’s user settings

(paths and so on.). If you had Visual Studio 2003 installed earlier the post-build command is therefore very likely to use the wrong versions of resgen.exe and al.exe.

The preceding procedure described guarantees that the Visual Studio 2005 versions are used.

(These can be found at: C:\Program Files\Microsoft Visual Studio

8\SDK\v2.0\bin/resgen.exe C:\WINNT\Microsoft.NET\Framework\v2.0.50727/al.exe)

4 Test a localized application

In order to test a localized application, the resources must be correctly organized in the file system of the controller. This should be done in the same way either the test is done on a virtual or a real FlexPendant. Follow these steps to test the application on a real FlexPendant:

Step

1

Action

Transfer, using an FTP client or the File Manager of RobotStudio, your application assemblies to the HOME directory of the active system. (TpsViewLocalizedApp-

Texts.dll, TpsViewLocalizedApp.gtpu.dll, TpsViewLocalizedApp.dll in the following screenshot).

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

203

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

2

Action

Copy the language folder that was created by the post-build event to the HOME directory.

3

10.1_3Langua

Note

It is also possible to have both the assemblies and the language folder located under the SYSTEM folder one level up. The advantage of using HOME is that the files are included in a backup.

Verify that the language folder has folders for each language and that each tps folder have a .resources dll. If this is not the case, you need to go back to the post-build event of your Texts project and check what has gone wrong.

4

5

Continues on next page

204

10.1_3bLangu

Note

The name of the satellite assembly is the same for all languages, TpsViewLocalized-

AppTexts.resources.dll in the preceding example.

Switch to another language (Control Panel - Languages) and restart the FlexPendant.

Verify that the name of your application in the ABB menu is correct.

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

8 Localizing a FlexPendant application

8.1 Adding support for several languages

Continued

Step

6

Action

Open the application and verify that the GUI texts are correctly displayed. Especially verify that text boxes, labels, listview columns and so on. are wide enough to display the translated texts.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

205

This page is intentionally left blank

9 Deployment of a FlexPendant SDK application

9.1 Overview

9 Deployment of a FlexPendant SDK application

9.1 Overview

Introduction

For the end customer to use your application, it has to be deployed to the customer’s robot controller. This is done when the customer robot system is created, by using the System Builder in RobotStudio. The custom application can then either be added as an additional option by using a license key, or added to the

Home directory of the controller file system by using one of the dialog box of the

System Builder wizard.

For an application with multi-language support there are a few more things to deal with.

Note

Using an FTP client to upload the application from a PC to a robot controller can be done for testing purposes. It can also be done if the custom application needs to be added to an existing system, which is already running in production. For more information, see

Deployment using FTP on page 215 .

Making a product

These are the steps to make a product of a custom FlexPendant application:

1 Approval of the FlexPendant SDK product requirement specification.

2 Design and development of a FlexPendant SDK GUI prototype.

3 Approval of the FlexPendant SDK GUI prototype.

4 Design and development of a FlexPendant SDK functional prototype.

5 Approval of the FlexPendant SDK functional prototype.

6 Design and development of a FlexPendant SDK product.

7 Approval of the FlexPendant SDK product.

8 Design and development of a deployable FlexPendant SDK product.

Deployment of a FlexPendant SDK product

Before deploying a custom application you need to consider these issues:

• Should the product be licensed, that is, be sold as an option?

• Is there a need to localize the product, that is, create support for native languages?

Depending on how the preceding questions are answered there are four alternatives

(detailed separately in the following sections of this manual):

1 License and localization

2 License but no localization

3 No license but localization

4 No license and no localization

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

207

9 Deployment of a FlexPendant SDK application

9.1 Overview

Continued

Note

If the product is to be licensed it should be deployed as an additional option. If not, RobotStudio should be used to deploy the application to the Home directory of the system.

208

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

9 Deployment of a FlexPendant SDK application

9.2 Deployment of an application without a license

9.2 Deployment of an application without a license

Overview

If you do not make an additional option of your application, the end user does not need a license to use it.

When the customer system is created, by using the System Builder of RobotStudio, your application should be added to the Home directory of the system.

This section gives information about how this is done. The easiest alternative, which offers no support for additional languages, is explained first.

No license and no localization

Use the following procedure to deploy an application without license nor multi-language support.

Step

1

2

Action

Use System Builder in RobotStudio.

Add the application assemblies(.dll) and other resources (‘.jpg, *.gif,*.bmp) to the

Home directory:

3

10.1_2SysBui

Download the system to the robot controller.

Note

Having the application deployed to the Home directory means it will be included in a system backup.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

209

9 Deployment of a FlexPendant SDK application

9.2 Deployment of an application without a license

Continued

No license but localization

Use the following procedure to deploy an application with no license but with multi-language support.

2

3

Step

1

Action

Implement multi-language support. For more information, see

Localizing a FlexPendant application on page 197

.

Use System Builder in RobotStudio.

Add the application assemblies(.dlls) and other resources (‘.jpg, *.gif,*.bmp) to the

Home directory:

4

5

10.1_2SysBui

Note!TpsViewIRC5AppTexts.dll is missing in the figure.

Generate the robot system.

In the generated RobotWare system, add a language directory with all supported languages in the Home directory. Then for each supported language, add a culture specific and a tps directory.

10.1_3Langua

Note

Standard names (de, zh and so on.) must be used for the different languages. For complete list, see

Adding support for several languages on page 197 .

Continues on next page

210

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

9 Deployment of a FlexPendant SDK application

9.2 Deployment of an application without a license

Continued

Step

6

7

Action

Transfer each resource binary to the tps sub-directory of the respective culture directory, for example:

TpsViewIRC5App.strings.de.resources.dll to language/de/tps directory and so on.

Download the system to the robot controller.

For more information on how to add support for native languages to your custom application, see

Localizing a FlexPendant application on page 197

.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

211

9 Deployment of a FlexPendant SDK application

9.3 Deployment of a licensed application

9.3 Deployment of a licensed application

Overview

When the customer system is created by System Builder of RobotStudio, a

FlexPendant application can be added to the system as an additional option.

This section describes how to make the additional option, which is necessary for deployment of a licensed custom application. It also describes how the customer installs the option.

CAUTION

An additional option must be distributed in accordance with RobotWare version and revision. Pay attention if you are using functionality, which has been included in a revision!

Note

An additional option must be deployed with the structure of RobotStudio.

Procedure for making an additional option

Use the following procedure to make an additional option of a FlexPendant SDK application.

Step

1

2

3

Action

Implement multi-language support if considered necessary. For more information, see

Localizing a FlexPendant application on page 197 .

Order a license and a CD Key Maker from your local ABB office, who will in turn contact ABB SEROP product support in Sweden.

Create the following structure:

10.1_12_Opti

The language folder is needed if there is to be support for other languages.

Note

Always use capital letters for the option name.

Continues on next page

212

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

9 Deployment of a FlexPendant SDK application

9.3 Deployment of a licensed application

Continued

Step

4

Action

Create the version.xml file. It may look like this:

5

10.1_13Versi

Create the install.cmd file. It may look like this:

6

10.1_14Insta

Create relkey.txt file. It may look like this:

7

8

10.1_15MyOpt

With the license, which is entered in the CD key Maker, generate a key file including the serial number of the Robot controller, for example MYOPTION508.kxt

(This is the file you will enter in System Builder when the robot system is created.)

Package the product on CD the way your organization recommends.

Note

If the option is only a FlexPendant SDK application the described procedure is enough. But if the option should also include RAPID and configuration, you need to read about how to make an additional option in another manual, which is for

ABB internal use. See Related information at the end of this section.

Installing the option at the customer

The following procedure shows how the customer installs a licensed application:

1 Install the additional option from a CD.

2 Create the robot system by using System Builder.

3 In the Add Parameters/Add Additional Options dialog browse to the key file, for example MYOPTION508.kxt which came with the installation of the additional option.

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

Continues on next page

213

9 Deployment of a FlexPendant SDK application

9.3 Deployment of a licensed application

Continued

10.1_16AddOp

Related information

Application manual - Additional Options, 3HAC023668-001

The manual is intended for ABB use only. Contact After Sales in Västerås, Sweden.

214

© Copyright 2010-2013 ABB. All rights reserved.

3HAC036958-001 Revision: B

9 Deployment of a FlexPendant SDK application

9.4 Deployment using FTP

9.4 Deployment using FTP

Overview

The general rule is that deployment using an FTP client should only be done during the development phase.

If deployment to a customer is done this way each controller has to be individually updated with assembly files as well as graphical and language resources. The organization of files in the robot controller file system is the responsibility of the application developer or the system integrator.

Procedure

4

5

6

Follow these steps to deploy your application using for example the File Manager of RobotStudio or an FTP client such as Ftp Voyager:

Step

1

2

3

Action

On the controller navigate to the system you want to update with the FlexPendant application.

Transfer the assembly, the proxy assembly and graphical resources used by the application to the system directory Home.

For multi-language support, in the Language directory create sub-directories for each language using the short name of the culture.

Create a “tps” sub-directory in each of these directories.

Copy each language resource to the tps folder of the corresponding culture.

Restart the FlexPendant. The custom application should now be accessible from the ABB menu.

For more information on how to restart the FlexPendant but not the controller., see

Restart the FlexPendant on page 35 .

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

215

This page is intentionally left blank

Index

Index

A

AlphaPad, 94

Closing event, 95

Launching, 94

Property window, 95

Removing, 96

Application, 13

Architecture, 31

assembly, 41

class name, 42

Deployment, 34

Development, 25

Dll, 33

icon, 41

language, 25

Life Cycle, 38

location, 42

name, 41

Object oriented, 48

Porting, 28

Real, 28

Running, 33

TaskBar icon, 41

TpsView, 40

Type, 42

UAS, 54

Versions, 21

Virtual, 27

C

CAPI domains, 118

CloseView, 114

CompactAlphaPad, 99

compatibility, 46

Configuration, 62

console window, 24

Commands, 186

D

DataBinding, 107

AdvancedBinding, 111

Classes, 107

Definition, 107

RapidDataBindingSource, 107

ResumeBinding, 112

SignalBindingSource, 107

SuspendBinding, 112

dialog box, 116

FpRapidData, 117

FpToolCalibration, 116

FpWorkObjectCalibration, 116

Dispose, 122, 169

F

FlexPendant

Applications, 21

Communication, 37

Memorty, 165

memory leaks, 169

overview, 165

Platform, 31

Restarting, 35

Screen, 165

G

Grants, 55

Definition, 54

DemandGrants, 55

GetCurrentGrants, 55

GTPUFolderBrowserDialog, 103

GTPUOpenFileDialog, 103

GTPUSaveFileDialog, 103

H

Hello world, 70

I

ImageList, 88, 97

Installation, 19

Requirements, 19

Invoke, 52

ITpsViewActivation, 172

ITpsViewSetup, 113

L

LaunchView, 114

ListView, 97

Illustration, 97

MultiSelect, 98

Scrollable, 98

SelectionEnabledOverScrollbuttons, 98

ShowNumberOfItems, 98

ShowSelectio, 98

M

Memory Leaks, 77

N

NumPad, 100

P

PictureBox, 88

Project, 64

Empty, 81

Form, 82

New Project, 64

Procedure, 64

Wizard, 74

Properties window, 105

FileName, 105

Filter, 105

InitialDirectory, 105

R

Rank, 131

RAPID, 144

arrays, 131 arrays dimensions, 131

BeginInvoke, 52

Event log, 155

Invoke, 52

Load Modules, 146

MessageBox, 55

ModifyPosition, 147

MotionPointer, 147

ProgramPointer, 147

RestProgramPointer, 144

Save and unload, 146

3HAC036958-001 Revision: B

© Copyright 2010-2013 ABB. All rights reserved.

217

Index

Save module, 147

Start, 144

Stop, 144

TpsControl, 52

ReadItem, 134

S

safety, 11

Signals, 149 accessing, 149

Listening changes, 152

SignalChangedEventArgs, 153

SignalFilter, 150

values, 151

T

TpsFont, 87

TpsForm, 82

Try-catch-finally, 56

Typecasting, 57

U

User Forum, 194

V

virtual keyboard, 94

W

WriteItem, 134

218
