User manual | security wall mount cabinet

SECURITY WALL MOUNT CABINET
•
•
•
•
•
•
250 lb. weight capacity
Tool-less adjustable cage nut style rails
20” usable depth
19” EIA 310-D compliant
Made in the USA
Limited Lifetime Warranty
The Kendall Howard Security Wall Mount Cabinet is a secure, professional looking solution for housing your
network, electrical, and peripheral equipment. Many times, small offices or remote locations require expensive data
and network equipment to be installed in an open environment. This can lead to problems with employees,
customers or others tampering with or destroying devices. With this wall mount enclosure, you can securely mount
all of your equipment and eliminate the risk of unauthorized use.
FEATURES
Solid, Secure Enclosure - The durable steel construction features solid sides and a locking front door to keep
installed equipment safe.
Click-N-Drop Rails - The included set of cage nut style rails can be adjusted without having to remove nuts and
bolts. The Click-N-Drop design only needs to be set and snapped into place. Once secured, install your rackmount
equipment with the use of rack screws and cage nuts.
Smoked Acrylic Front Door - The removable locking front door features a smoked acrylic window for easy viewing
and monitoring of installed equipment.
Open Back Design - The open back design allows already terminated equipment to be fed through the back of the
cabinet, saving your installers hours of time re-terminating cables. The large open space is also perfect for
applications with an immense amount of cabling which can be fed through the wall directly into the cabinet.
Numerous Cable Knockouts - Multiple laser knockouts are featured on the top and bottom of the enclosure,
providing a variety of cable entry points.
Cooling/Ventilation - Optional fan kits can be installed in the top and/or bottom of the security cabinet to help
keep equipment from overheating.
Part Number
1915-3-100-08
UPC
879447001174
Width
22.22"
Color
Black Powder Coated Finish
Depth
20.65"
Warranty
Height
17.23"
Shipping Method
Limited Lifetime Warranty
FedEx Ground
