Preface
Cisco Preferred Architectures provide recommended deployment models for specific market segments based on common
use cases. They incorporate a subset of products from the Cisco Collaboration portfolio that is best suited for the targeted
market segment and defined use cases. These deployment models are prescriptive, out-of-the-box, and built to scale with
an organization as its business needs change. This prescriptive approach simplifies the integration of multiple systemlevel components and enables an organization to select the deployment model that best addresses its business needs.
Documentation for Cisco Preferred Architectures
Cisco Preferred Architecture (PA) Design Overview guides help customers and sales teams select the appropriate
architecture based on an organization’s business requirements; understand the products that are used within the
architecture; and obtain general design best practices. These guides support pre-sales processes.
Preferred Architecture Cisco Validated Design (CVD) guides provide details for deploying components within the
Cisco Preferred Architectures. These guides support planning, deployment, and implementation (PDI).
Preferred Architecture Application Cisco Validated Design (CVD) guides provide an application solution to the
foundational Enterprise Preferred Architecture. These guides support planning, deployment, and implementation
(PDI).
Cisco Solution Reference Network Design (SRND) guide provides detailed design options for Cisco Collaboration.
This guide should be referenced when design requirements are outside the scope of Cisco Preferred Architectures.
Figure 1 illustrates how to use the guides. As mentioned, this overview is used for the pre-sales process to explain the
products and components, while the CVDs are used in the post-sales process for further design, deployment, and
implementation. The set of Application CVDs covers optional applications that can be deployed on top of the foundational
Preferred Architecture.
Figure 1
Preferred Architecture Documentation Structure
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 4
Preface
About This Guide
The Cisco Preferred Architecture for Enterprise Collaboration is for:
Sales teams that design and sell collaboration solutions
Customers and sales teams who want to understand the overall collaboration architecture, its components, and
general design best practices
Readers of this guide should have a general knowledge of Cisco Voice, Video, and Collaboration products and a basic
understanding of how to deploy these products.
This guide simplifies the design and sales process by:
Recommending products in the Cisco Collaboration portfolio that are built for the enterprise and that provide
appropriate feature sets for this market
Detailing a collaboration architecture and identifying general best practices for deploying in enterprise organizations
For detailed information about configuring, deploying, and implementing this architecture, consult the related CVD
documents on the Design Zone for Collaboration.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 5
Introduction
Introduction
In recent years, many new collaborative tools have been introduced to the market, enabling organizations to extend
collaboration outside the walls of their businesses. Providing access to collaborative tools for employees outside the office
is no longer a luxury; it is mandatory for businesses to stay relevant in today’s market. Today’s users expect immediate
access to these tools from a wide variety of portable and mobile devices. Many of these same tools can be extended to
customers and partners, helping strengthen these relationships.
Organizations realize the added value that collaboration applications bring to their businesses through increased
employee productivity and enhanced customer relationships. Not long ago, interoperability among collaboration
applications was sparse, and applications were difficult to deploy and use. Since then, significant advances have been
made in the collaboration space, simplifying deployment, improving interoperability, and enhancing the overall user
experience. Additionally, individuals have adopted a wide variety of smart phones, social media, and collaboration
applications in their personal lives.
Organizations can now feel comfortable providing collaboration applications that employees will quickly adopt and that
provide maximum value. These new collaboration tools enhance an organization’s overall business processes, make its
employees more productive, and open the door to new and innovative ways for communicating with business partners
and customers. Today’s collaboration solutions offer organizations the ability to integrate video, audio, and web
participants into a single, unified meeting experience.
Technology Use Cases
Organizations want to streamline their business processes, optimize employee productivity, and enhance relationships
with partners and customers. The Cisco Preferred Architecture (PA) for Enterprise Collaboration delivers capabilities that
enable organizations to realize immediate gains in productivity and enhanced relationships. Additionally, the following
technology use cases offer organizations opportunities to develop new, advanced business processes that deliver even
more value in these areas:
Consolidate Communications Infrastructure — Bring together voice, video, and data into a single IP network to
simplify management and support effective communications.
Incorporate Video into Meetings — Improve communications, relationships, and productivity by making it easier to
meet face-to-face over distance.
Extend Telephony with Video — Facilitate face-to-face video communications directly from end-user phones or
softphone applications.
Support Teleworkers and Branch Offices — Let employees work from multiple locations, whether satellite offices,
home offices, or when traveling.
Collaborate with External Organizations — Easily share information, interact in real time, and communicate using
technologies beyond email and telephone.
Create Flexible Work Areas and Office Spaces — Scale office space and create work areas that foster employee
inclusiveness, collaboration, innovation, and teamwork.
Deploy a Unified Communications Architecture — Provide the entire global organization with a single
communications tool set for all users.
Information about Cisco Collaboration Technologies and use cases is available on Cisco.com.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 6
Introduction
Architectural Overview
The Cisco PA for Enterprise Collaboration provides end-to-end collaboration targeted for deployments larger than 1,000
users. This architecture incorporates high availability for critical applications. The consistent user experience provided by
the overall architecture facilitates quick user adoption. Additionally, the architecture supports an advanced set of
collaboration services that extend to mobile workers, partners, and customers through the following key services:
Voice communications
Instant messaging and presence
High-definition video and content sharing
Rich media conferencing
Enablement of mobile and remote workers
Business-to-business voice and video communications
Unified voice messaging
Because of the adaptable nature of Cisco endpoints and their support for IP networks, this architecture enables an
organization to use its current data network to support both voice and video calls. The preferred architecture provides a
holistic approach to bandwidth management, incorporating an end-to-end QoS architecture, call admission control, and
video rate adaptation and resiliency mechanisms to ensure the best possible user experience for deploying pervasive
video over managed and unmanaged networks.
The Cisco PA for Enterprise Collaboration, shown in Figure 2, provides highly available and secure centralized services.
These services extend easily to remote offices and mobile workers, providing availability of critical services even if
communication to headquarters is lost. Centralized services also simplify management and administration of an
organization’s collaboration deployment.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 7
Introduction
Figure 2
Cisco Preferred Architecture for Enterprise Collaboration
Table 1 lists the products in this architecture. For simplicity, products are grouped into modules to help categorize and
define their roles. The content in this guide is organized in the same modules.
Table 1
Components of the Cisco Preferred Architecture for Enterprise Collaboration
Module
Component
Description
Call Control
Cisco Unified Communications Manager
(Unified CM)
Provides endpoint registration, call processing, and media
resource management
Cisco Unified Communications Manager IM and
Presence Service
Provides instant messaging and presence services
Cisco Integrated Services Router (ISR)
Provides Survivable Remote Site Telephony (SRST) functionality
Endpoints
Cisco IP Phones, Cisco TelePresence video
endpoints, and Cisco Jabber
Enable real-time voice, video, and instant messaging
communications for users
Conferencing
Cisco Meeting Server
Provides audio and video conferencing capabilities as well as
conference resource management
Cisco TelePresence Management Suite and
Extensions
Provides scheduling, web conferencing integration, and other
advanced video features
Cisco Expressway-C
Enables interoperability with third-party systems and firewall
traversal
Cisco Expressway-E
Supports remote endpoint registration to Cisco Unified CM and
enables business-to-business communications
Cisco ISR and ASR
Provides either public switched telephone network (PSTN) or
Cisco Unified Border Element (CUBE) connectivity
Collaboration Edge
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 8
Introduction
Module
Component
Description
Voice Messaging
Cisco Unity Connection
Provides unified messaging and voicemail services
Collaboration
Management Services
Cisco Prime Collaboration Deployment
Assists in the management of Unified Communications
applications. It allows the user to perform tasks such as migration
of older software versions of clusters to new virtual machines,
fresh installs, and upgrades on existing clusters.
Cisco Prime License Manager
Provides simplified, enterprise-wide management of user-based
licensing, including license fulfillment.
Cisco Prime Collaboration Provisioning
Enables rapid configuration of collaboration systems by providing
a centralized template-based console for device provisioning and
simplified moves, adds, and changes.
Virtualization and Core Applications
Virtualizing multiple applications and consolidating them on physical servers lowers costs, minimizes rack space, lowers
power requirements, and simplifies deployment and management. Virtualization also accommodates redeploying
hardware and scaling software applications as organizational needs change.
Cisco Business Edition 7000
The Cisco Business Edition (BE) 7000 serves organizations with 1,000 or more users, and it is the foundation of the Cisco
PA for Enterprise Collaboration. The Cisco BE7000 is built on a Cisco Unified Computing System (UCS) that ships readyfor-use with a preinstalled virtualization hypervisor and application installation files. The Cisco BE7000 solution offers
premium voice, video, messaging, instant messaging and presence, and contact center features on a single, integrated
platform. For more information about the Cisco BE7000, see the data sheet.
Core Applications
In the Cisco PA for Enterprise Collaboration, the following applications are deployed on multiple UCS servers to provide
hardware and software redundancy:
Cisco Unified Communications Manager
Cisco Unified Communications Manager IM and Presence Service
Cisco Unity Connection
Cisco Expressway, consisting of Expressway-C and Expressway-E
Cisco Meeting Server
Cisco TelePresence Management Suite and Extensions
Cisco Prime Collaboration Deployment
Cisco Prime License Manager
Cisco Prime Collaboration Provisioning
We recommend always deploying redundant components and configurations to provide the highest availability for critical
business applications.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 9
Introduction
High Availability
The Cisco PA for Enterprise Collaboration provides high availability for all deployed applications by means of the
underlying clustering mechanism present in all Cisco Unified Communications applications.
Clustering replicates the administration and configuration of deployed applications to backup instances of those
applications. If an instance of an application fails, Cisco Unified Communications services – such as endpoint registration,
call processing, messaging, business-to-business communication, and many others – continue to operate on the
remaining instance(s) of the application. This failover process is transparent to the users. In addition to clustering, the
Cisco PA for Enterprise Collaboration provides high availability through the use of redundant power supplies, network
connectivity, and disk arrays.
Sizing Considerations
Sizing a deployment can become complex for large enterprises with sophisticated requirements. The Preferred
Architecture for Enterprise Collaboration Cisco Validated Design (CVD) Guide presents some examples that simplify the
sizing process. In addition, Cisco provides several tools to assist with sizing a deployment. The sizing tools are available
to Cisco certified partners at http://cucst.cloudapps.cisco.com. If you do not have access to the sizing tools, contact your
Cisco account representative or Cisco certified partner to obtain system sizing information.
Licensing
Details about the individual licenses for the endpoints and infrastructure components in the Cisco Preferred Architecture
for Enterprise Collaboration are beyond the scope of this document. Information about Cisco Unified Communications
licensing is available on the License Administration Portal at https://tools.cisco.com/SWIFT/LicensingUI/Home. The
License Administration Portal also provides instructions and tools to assist with license administration.
Cisco Integrated Services and Aggregation Services Routers
The Cisco Integrated Services Router (ISR) and Aggregation Services Router (ASR) provide Wide Area Network (WAN)
and Cisco Unified Communications services in a single platform. In the Cisco PA for Enterprise Collaboration, the Cisco
ISR and ASR can provide the following functions (Figure 3):
External connectivity to the Internet
IP routing and remote-site network services such as DHCP, DNS, NTP, and others
Cisco Unified Survivable Remote Site Telephony (SRST) to service calls during WAN failures
Voice gateway to the Public Switched Telephone Network (PSTN), or Cisco Unified Border Element (CUBE) for
Session Initiation Protocol (SIP) trunks
Integrated data and voice connectivity to service providers
Multiprotocol Label Switching (MPLS) WAN connectivity for the organization’s network
Media resources for Cisco Unified Communications Manager
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 10
Introduction
Figure 3
Cisco ISR and ASR Functions
The Cisco ISR and ASR have additional slots that support add-on modules such as wireless controllers and VMware ESXi
servers. Deployments can use various Cisco ISR and ASR models to support different features, to scale, and to
accommodate additional services. Their modular design enables the Cisco ISR and ASR to be deployed at headquarters,
remote locations, or branch locations. For more information about these routers, see the Cisco ISR and Cisco ASR data
sheets.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 11
Endpoints
Endpoints
Cisco Collaboration endpoints provide a wide range of features, functionality, and user experiences. Because Cisco
endpoints range from low-cost, single-line phones and soft clients to three-screen Cisco TelePresence endpoints, an
organization can deploy the right variety of endpoints to meet users’ needs (Figure 4). Additionally, these devices enable
users to access multiple communication services such as:
Voice calls
Video calls
Conferencing
Voicemail
Presence
Instant messages
Desktop sharing
Figure 4
Architecture for Endpoints
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 12
Endpoints
Recommended Deployment
Cisco Unified Communications Manager (Unified CM) is the call control server for the Cisco PA for Enterprise
Collaboration. Cisco IP Phones, Jabber clients, and TelePresence video endpoints use SIP to register directly to Cisco
Unified CM. The Unified CM cluster’s failover mechanism provides endpoint registration redundancy. If a WAN failure
occurs and endpoints at remote locations cannot register to Unified CM, they use SRST functionality for local and PSTN
calls, but some services such as voicemail and presence might not be available.
We recommend the endpoints listed in the following tables because they provide optimal features for this design. Cisco
has a range of endpoints with various features and functionality that an organization can also use to address its business
needs.
Table 2
Cisco IP Phones
Product
Description
Cisco IP Phone 7811
Public space, single-line phone
Cisco IP Phone 8800 Series
General office use, multiple-line phone
Cisco IP Phone 8831
IP conference phone
Table 3
Cisco TelePresence and Video Endpoints
Product
Description
Cisco DX70 and DX801
Personal TelePresence endpoint for the desktop
Cisco MX Series
TelePresence multipurpose room endpoint
Cisco SX Series
Integrator series TelePresence endpoint
Cisco IX Series
Immersive TelePresence room system
1.
DX70 and DX80 endpoints run CE firmware.
Table 4
Cisco Jabber
Product
Description
Mobile:
Soft client with integrated voice, video,
voicemail, instant messaging, and presence
functionality for mobile devices and personal
computers
Jabber for Android
Jabber for iPhone and iPad
Desktop:
Jabber for Mac
Jabber for Windows
Table 5
Comparison of Endpoint Features and Capabilities
Product(s)
Audio
Video
Content
Sharing
Unified CM High
Availability
Mobile and
Remote Access
Audio
SRST
IP Phone 7811
Y
N
N
Y
Y
Y
IP Phone 8800 Series
Y
Y
2
N
Y
Y
Y
IP Phone 8831
Y
N
N
Y
N
Y
DX70 and DX80
Y
Y
Y
Y
Y
N
MX Series
Y
Y
Y
Y
Y
N
SX Series
Y
Y
Y
Y
Y
N
IX Series
Y
Y
Y
Y
N
N
Jabber Mobile
Y
Y
N
Y
Y
Y
Jabber Desktop
Y
Y
Y
Y
Y
Y
2.
Only the IP Phones 8845 and 8865 support video.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 13
Call Control
Call Control
Call control is the core element for any communications deployment. It provides endpoint registration, call processing, and
call admission control. Call control design considerations include the enterprise dial plan, endpoint addressing scheme,
calling party presentation, call admission control, codec selection, PSTN connectivity, and general trunking requirements,
as well as other factors.
Cisco Unified Communications Manager (Unified CM) provides a common call control platform for all Cisco Collaboration
deployments (Figure 5). Having a highly available and common call control component for a communications
infrastructure is crucial to provide consistent services for all devices and communication types and to preserve a uniform
dial plan and a consistent feature set across the enterprise.
Adding the IM and Presence Service to a Cisco Unified CM deployment provides instant messaging, network-based
presence, and federation for third-party chat servers, and it enables the use of Cisco Jabber for instant messaging,
presence, and audio and video communications.
Figure 5
Architecture for Call Control
Table 6 lists the roles of the call control components in this architecture and the services they provide.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 14
Call Control
Table 6
Components for Call Control
Module
Component
Description
Call Control
Cisco Unified Communications Manager
(Unified CM)
Provides call routing and services, dial plan, and bandwidth management;
and enables Cisco Jabber desk phone control
Cisco Unified Communications Manager IM
and Presence Service
Provides Cisco Jabber support for instant messaging and user-based
presence and third-party federation
Cisco Integrated Services Router (ISR)
Provides Survivable Remote Site Telephony (SRST) to support call control
functions during a WAN outage
Recommended Deployment
Deploy a single Cisco Unified CM cluster for an enterprise with a central site and remote offices. Deploy call
processing subscribers in pairs for scalability and redundancy.
Add additional Cisco Unified CM clusters for very large sites or for geographic and/or organizational separation.
Configure SIP trunks to interconnect individual Cisco Unified CM clusters.
Deploy a pair of IM and Presence Service servers in a cluster configuration. Add more pairs for scalability.
Enable Cisco SRST on the Cisco ISR as a backup service at remote sites to provide high availability.
Benefits
This deployment provides the following benefits:
Call control is centralized at a single location that serves multiple remote sites.
Common telephony features are available across voice and video endpoints.
Single call control and a unified dial plan are provided for voice and video endpoints.
Critical business applications are highly available and redundant.
Deployment Best Practices
Cisco Unified Communications Manager and IM and Presence Service
Cluster Recommendations
Cisco Unified CM and IM and Presence support clustering, which is the grouping of nodes that work together as a single
logical entity. The publisher node contains the cluster’s configuration database, which is replicated to the call processing
subscriber nodes and TFTP nodes in the cluster.
Clustering provides an automatic redundancy mechanism for endpoints and for Cisco Unified CM services, such as the
ability to receive and process incoming calls. To provide 1:1 redundancy, always deploy call processing subscribers and
TFTP nodes in pairs. Each Unified CM cluster must have at least one pair of call processing subscribers and a pair of
TFTP nodes in addition to the publisher node, for a minimum of five Cisco Unified CM nodes in a cluster (Figure 6). While
the call processing subscribers provide endpoint registration and call processing capabilities, the pair of TFTP nodes
provides configuration and firmware updates to endpoints.
All the TFTP nodes and subscriber nodes periodically receive updates of the configuration database from the dedicated
publisher node. These database updates enable all the subscriber nodes to operate in a consistent configuration state.
To provide load balancing of call processing services across the subscribers and to reduce failover response times,
deploy each call processing subscriber pair in an active/active redundancy scheme.
For IM and Presence, we recommend deploying a minimum of one IM and Presence publisher and one subscriber. The
IM and Presence publisher is not a dedicated node, and the publisher and subscriber provide redundancy for each other.
(Figure 6)
Add more pairs of IM and Presence subscribers or Unified CM call processing nodes to accommodate more users.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 15
Call Control
Figure 6
Cisco Unified CM Cluster
SIP Trunk Recommendations
Use SIP trunks from Cisco Unified CM to communicate with all the components in the Cisco PA for Enterprise
Collaboration, including external entities such as third-party systems. SIP trunks offer the following benefits:
SIP trunks provide a standards-based environment that reduces operations and maintenance complexity of the endto-end solution.
SIP trunks are enhanced with presence information.
SIP trunks are recommended for video communications.
Cisco Unified Survivable Remote Site Telephony
The Cisco Survivable Remote Site Telephony (SRST) feature is critical for remote sites that require continuation of voice
services during WAN outages. SRST runs on the same Cisco ISR that provides WAN and PSTN connectivity for the
remote site.
Deploy SRST on the Cisco ISR in the following cases:
The remote site has local PSTN connectivity.
The remote site does not have local PSTN connectivity but has more than 25 users.
To avoid interruption of external voice services if a WAN outage occurs, provide local PSTN connectivity at the remote
site. SRST is required only if the remote site’s WAN reliability does not match that site’s required service level for voice
service availability.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 16
Call Control
If a WAN failure occurs at a site with SRST and local PSTN access, the following services will be available:
Internal point-to-point voice calls
External voice calls through the PSTN
Call hold, transfer, and conference
Music on hold
Note:
SRST is not available for Cisco DX, IX, MX, or SX Series endpoints. See Table 5 for information about endpoints
that support SRST.
Dial Plan
A structured, well-designed dial plan is essential to successful deployment of any call control system. When designing a
dial plan, consider the following main factors:
Dialing habits
Endpoint addressing
Routing
Directory integration
Classes of service
Dialing Habits
Dialing habits describe what end users can dial to reach various types of destinations. Dialing habits can first be classified
as numeric dialing (for example, 914085550123) or alphanumeric dialing (for example, [email protected]).
Typically, different types of destinations require support for different dialing habits. For example:
PSTN toll call: for example, in North America, 91-<10 digits>
PSTN international call: for example, in North America, 9011-<country code + national significant number>
Abbreviated intra-site dialing: for example, 4XXX
Abbreviated inter-site dialing: for example, 8-<site code>-<intra-site number>
+-dialing from directories: “+” followed by a fully qualified global PSTN number as described in ITU recommendation
E.164
URI dialing: for example, [email protected] for intra-company and inter-company dialing. Endpoints typically allow
omission of the right-hand side (host portion) of the URI and they automatically append the local host portion, so
that [email protected] can also be abbreviated as bob.
Further dialing habits might have to be defined for services such as call pick-up, voicemail, and others. Also, future growth
should be considered so that more users and more sites can be added as needed without redesigning the dial plan.
Some dialing habits, typically PSTN dialing habits in particular, need to follow country-specific requirements or established
dialing procedures. For example, in contrast to the trunk access code 9 in the above US-based examples, 0 is used for
trunk access in many other countries. The dialing habit for national calls in these cases, in addition to the potential for
using 0 as the trunk access code, also needs to reflect the characteristics of the national numbering plan of the respective
country.
Identifying dialing habits is most important when defining an enterprise dial plan in order to avoid overlaps between any
two dialing habits. For example, a trunk access code of 9 prohibits abbreviated intra-site dialing starting with 9. Avoiding
overlaps between dialing habits is crucial to avoid inter-digit timeouts, which lead to bad user experiences.
In migration scenarios, the dialing habits supported by the existing system can be used as a first estimate of the dialing
habits required in the new system. On the other hand, migration to a new communications system can also serve as a
reason to get rid of outdated customs and practices.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 17
Call Control
Endpoint Addressing
Each endpoint registered with the enterprise call control must have a unique numeric address. Endpoint addresses in
Cisco Unified CM are equivalent to the directory numbers provisioned on the lines of the endpoints. Use fully qualified
PSTN numbers (E.164 numbers) with a leading “+” as endpoint addresses. This format is typically referred to as +E.164
format. The benefits of using +E.164 endpoint addresses include:
Wide use in voice networks
No need to develop and maintain an enterprise numbering scheme
Easy creation of correct caller ID presentation for all on-cluster and off-cluster call flows
Easy implementation of directory lookups
Simplified alternate routing to the PSTN in cases of WAN failure or bandwidth constraints
For endpoints without assigned PSTN-based direct inward dial (DID) numbers (no E.164 number representation exists),
create enterprise-wide unique endpoint addresses outside of the default +E.164 domain. These endpoint addresses
should be in line with the internal dialing habit defined to reach these endpoints. If, for example, the abbreviated inter-site
dialing habit to reach a set of non-DID endpoints in a given site is 84915XXX, then these non-DID endpoints should use
this numbering scheme for their endpoint addresses.
In addition to the primary numeric endpoint addresses, administrators can provision alphanumeric URIs (for example,
[email protected]) in Cisco Unified CM to serve as aliases for the primary addresses, and users can enter the URI as an
alternate way to dial the destination endpoint.
Routing
The routing portion of the dial plan enables users to reach the correct destinations when they use the defined dialing
habits.
The primary numeric routing is based on +E.164 numbers. External routes to other transport networks such as the PSTN
also use the +E.164 scheme. Endpoint addresses in +E.164 provide +E.164 on-net dialing without any further
configuration. All other numeric dialing habits, such as abbreviated inter-site and intra-site dialing, are implemented as
overlays by adding the appropriate translation patterns to the dial plan to map from the implemented dialing habit to the
+E.164 global routing address format. This allows users to reach the same endpoint by means of different dialing habits,
depending on user preference.
Alpha-numeric URIs, as aliases for numeric addresses, provide an alternative means of reaching endpoints. The benefits
of URI dialing and routing include:
Conformity with the native dialing habit on most video systems
Easier business-to-business connectivity
Direct mapping from instant messaging identifiers to addresses (easier escalation of business-to-business IM
sessions to voice and/or video), although technically IM identifiers and SIP URIs are not necessarily identical
If an endpoint is enabled for business-to-business calls over the Internet, we recommend associating a SIP URI to the
device so that the business-to-business routing logic can be based on SIP URIs.
As with numeric routing, if an alias or SIP URI is recognized as an internal destination and is associated with a specific
device, then Cisco Unified CM sends the call to that device. However, if the dialed SIP URI does not match any registered
endpoint alias, Cisco Unified CM uses SIP route patterns to determine where to send the call. For example, if the dialed
alias [email protected] does not exist internally, Cisco Unified CM uses a SIP route pattern (such as *.com) to send
the call to Expressway-C as a business-to-business call.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 18
Call Control
Directory Integration
To enable users to search contacts and dial from the directory, integrate Cisco Unified CM with the organization’s LDAP
directory. Although Cisco Unified CM allows the creation of local user contacts, LDAP directory integration is required
when using Cisco Jabber because it provides a single location for directory management and enables users to
authenticate to Cisco Unified CM and Cisco Jabber by using their LDAP directory credentials.
Cisco Unified CM pulls user and contact information from LDAP directories and synchronizes user parameters – name,
surname, username, telephone number, and SIP URI – when changes occur. For example, use the telephoneNumber
attribute to populate the Telephone Number field in the Cisco Unified CM directory. The format of phone numbers in the
corporate directory must be globally significant and must match one of the defined dialing habits. Corporate directories
typically should have all phone numbers in +E.164 format (leading “+” followed by the fully qualified global number) as
long as a DID exists. Only this format allows the phone number in the corporate directory to be used universally inside
and outside the enterprise. Non-DID numbers that are not in +E.164 format could be used to dial uses internally from the
directory, but they would have no significance outside the enterprise. Use the mail attribute to populate the Directory URI
field in the Cisco Unified CM directory if URI dialing is used.
The IM and Presence Service pulls user and contact information from Cisco Unified CM.
Class of Service
Classes of service define which users can access which services, such as allowing only emergency and local calls from
lobby phones while allowing unrestricted calls from executive phones. The complexity of the dial plan is directly related to
the number of differentiated classes of service it supports.
To define classes of service, configure partitions and calling search spaces in Cisco Unified CM. The number of classes of
services supported by a dial plan depends on the granularity and complexity of the classes. For more information about
classes of service and details on enterprise dial plan design, see the Cisco Collaboration SRND.
Multi-Cluster Deployment Considerations
Consider deploying more than one Cisco Unified CM cluster if you have any of the following requirements:
Administrational separation
This includes the need to keep users from different parts of the organization on separate infrastructures, or the
requirement to have different departments operate different parts of the communications infrastructure.
Geographic footprint
Technical limitations such as excessive propagation delay might prohibit endpoint registrations (for example,
endpoints in Asia registering to an enterprise call control hosted in the US).
In a multi-cluster deployment, interconnect all the individual Unified CM clusters through SIP trunks. To avoid session
traversal through individual clusters, deploy a full mesh of SIP trunks. With four or more clusters, deploy Cisco Unified CM
Session Management Edition to centralize the dial plan and trunking and to avoid the complexity of a full-mesh SIP trunk
topology.
In multi-cluster deployments, use Global Dial Plan Replication (GDPR) to replicate dial plan information between clusters.
GDPR can advertise a +E.164 number, one enterprise significant number (ESN), and up to five alpha-numeric URIs per
directory number. An ESN is the abbreviated inter-site dialing equivalent of a directory number. The information
advertised and learned through GDPR enables deterministic intercluster routing for these dialing habits:
+E.164 dialing based on the advertised +E.164 numbers
Enterprise abbreviated inter-site dialing based on the advertised ESNs
Alpha-numeric URI dialing based on the advertised URIs
PSTN dialing based on normalization to +E.164
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 19
Conferencing
Conferencing
The ability for three or more people to communicate in real time by using voice and video technologies is a core
component of collaboration. Cisco rich media conferencing builds upon existing infrastructure in place for point-to-point
calls, offering users a consistent voice and video experience (Figure 7).
Figure 7
Architecture for Conferencing
Table 7 lists the roles of the conferencing components in this architecture and the services they provide.
Table 7
Components for Conferencing
Module
Component
Description
Conferencing
Cisco Meeting Server
Provides voice and video conferencing with content sharing
Manages and allocates conferencing resources
Cisco TelePresence Management
Suite and Extensions
Cisco Preferred Architecture for Enterprise Collaboration 11.6
Provides conference scheduling and monitoring, and device management capabilities
Integrates with calendar system to schedule meetings
PAGE 20
Conferencing
There are three types of conferences:
Instant or ad hoc — A conference that is not scheduled or organized in advance. For example, a call between two
parties who add other parties to the call is an instant conference.
Permanent or rendezvous — A conference that requires callers to dial a predetermined number or URI to reach a
shared conferencing resource. Meet-me, static, and rendezvous are other names for this type of conference.
Scheduled — A conference planned in advance with a predetermined start time. Typically, conference resources
are guaranteed to be available upon the start of the scheduled conference.
Recommended Deployment
Audio and Video Conferencing
Deploy Cisco Meeting Server for all conference types.
Deploy Cisco Meeting Server in a cluster for high availability and increased scale.
Integrate the Cisco Meeting Server cluster with Cisco Unified CM through SIP trunks and registered media resource
conference bridges for instant conferences.
Integrate the Cisco Meeting Server cluster with Unified CM through SIP trunks and route patterns for permanent
and scheduled conferences.
Deploy Cisco TelePresence Management Suite (TMS) to schedule conferences with Cisco Meeting Server. Deploy
Cisco TelePresence Management Suite Extension for Microsoft Exchange (TMSXE) to allow end users to schedule
meetings using Microsoft Outlook clients.
Benefits
This deployment provides the following benefits:
Users have a consistent experience for launching and joining various types of conferences.
A single conferencing platform provides on-premises audio and video conferencing.
It provides users with real-time, high-definition video conferencing, including the ability to share content easily over
a dedicated presentation channel.
Cisco TMS provides users with enhanced features such as directories and One Button To Push (OBTP) on
controlled endpoints. It enables administrators to import user profiles from Microsoft Active Directory that allow
access control to various components and configured systems.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 21
Conferencing
Deployment Best Practices
Audio and Video Instant Conferences
For instant audio and video conferences, use Cisco Meeting Server on-premises as the media resource. Unified CM has
the HTTPS and SIP trunk interfaces to Cisco Meeting Server inside the instant conference bridges. HTTPS is used for
conference control, while a SIP trunk is used for call signal. These conference bridges are assigned to media resource
group lists (MRGLs) and media resource groups (MRGs) in Unified CM. Unified CM uses MRGLs and MRGs to prioritize
and allocate media resources such as conference bridges, music on hold sources, annunciators, transcoders, and media
termination points (MTPs).
If endpoints have access to the appropriate MRGL, they can request these resources. Resources local to the initiating
endpoint are preferred over remote resources (Figure 8).
Figure 8
Media Resource Group List (MRGL) Example
Permanent Conferences with Cisco Meeting Server Spaces
Permanent conferences are deployed using Cisco Meeting Server Spaces. A Meeting Server Space is a virtual persistent
meeting room that anyone can join and that has support for video, voice, and content sharing. A Space is automatically
created for a user when the user is imported into Cisco Meeting Server from the Active Directory configured in the web
administrative interface. Each Space is associated with a few attributes (for example, Username, Space name, and so
forth) and can be accessed using a video address URI or numeric alias. These attributes are configured by the
administrator through the Field Mapping Expressions. After the Space has been created, the administrator can further
customize the Spaces by specifying a default layout or guest access code for each user. The Space owner can log into
the Cisco Meeting Application to create a team Space and invite others to join for collaboration.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 22
Conferencing
Scheduled Video Conferences
For scheduled video conferences, use the same Cisco Meeting Server as for non-scheduled conferences to provide the
conferencing resource. Integrate the Cisco Meeting Server to Cisco Unified CM with SIP trunks, and manage it through
Cisco TelePresence Management Suite.
Cisco TelePresence Management Suite (TMS) runs on a Microsoft Windows server and utilizes the Microsoft SQL
database to store information about users, controlled devices, and scheduled conferences. User profiles are imported
from Microsoft Active Directory, and the permissions model allows for access control to various components and
configured systems. Deploy Cisco TMS with Cisco TMSXE to provide Microsoft Exchange integration.
A single deployment of TMS is required for each organization. Leverage the integrated system navigator folder structure
to organize all endpoints and infrastructure devices. Even multinational and global organizations can benefit from a single
deployment of TMS to facilitate video connections.
Redundancy for TMS and its supporting extensions is different from other components in the Cisco PA for Enterprise
Collaboration. TMS and its components operate in an active/passive model instead of clustering. A single instance of TMS
consists of a Network Load Balancer, two servers hosting TMS, two servers hosting the TMSXE application, and the SQL
database (Figure 9). The licensing for the instance is maintained in the SQL database, so separate licensing is not
required for each node. Only one server for each application is active at any moment, with the web pages and services of
the passive (inactive) node locked down to refuse all other incoming traffic. All servers must be members of the same
domain.
Figure 9
Cisco TMS Redundancy Model
Deploy the Microsoft SQL database separately from the TMS server. The instance of SQL may be shared by other
applications within the organization, and it should be a high-availability deployment in accordance with Microsoft’s
recommendations.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 23
Conferencing
Support for Multiple Call Processing Sites
Organizations may choose to implement more than one Cisco Meeting Server cluster (Figure 10) for any of the
following reasons:
Administrational separation — This includes the need to keep users from different parts of the organization on
separate infrastructures or to have different departments operate different parts of the communications
infrastructure.
Geographic footprint — Physical limitations such as excessive latency between endpoints and conferencing
resources could degrade the user experience (for example, US users might not have a productive collaborative
meeting if they use conferencing resources located in Europe).
However, when multiple Unified CM clusters are deployed, we recommend deploying a single Cisco Meeting Server
cluster with one call bridge group dedicated for each Unified CM cluster. The call bridges within the group should be
deployed in the same data center as the corresponding Unified CM cluster. Using a single Cisco Meeting Server cluster
enables users to access the same conference using the same video address regardless of which Unified CM cluster they
dial from.
Figure 10
Multiple Call Processing Sites with Conferencing
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 24
Collaboration Edge
Collaboration Edge
Business demand for connectivity between organizations by leveraging the Internet has increased significantly over the
past few years. For many organizations, this connectivity is a fundamental requirement for conducting day-to-day
activities. Moreover, securely connecting mobile workers and remote sites to each other and to headquarters is critical
functionality that enables organizations to accomplish their business goals. The Cisco PA for Enterprise Collaboration
addresses these needs with the Collaboration Edge architecture shown in Figure 11.
Figure 11
Architecture for Collaboration Edge
Table 8 lists the roles of the Collaboration Edge components in this architecture and the services they provide.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 25
Collaboration Edge
Table 8
Components for Collaboration Edge
Module
Component
Description
Collaboration Edge
Cisco Expressway-E
The traversal server that enables secure VPN-less mobile and remote access for
TelePresence endpoints and Jabber clients. The traversal server resides in the
DMZ. The solution also provides business-to-business calling, protocol
interworking, and cloud connectivity.
Cisco Expressway-C
The traversal client that creates a secure, trusted connection through the firewall
to Expressway-E. The traversal client resides inside the enterprise network. The
solution provides mobile and remote access, business-to-business calling,
protocol interworking, and cloud connectivity.
Cisco Integrated Services Router
(ISR) or Aggregation Services
Router (ASR) with PSTN interfaces
Enables local PSTN connectivity
Cisco ISR or ASR with Cisco
Unified Border Element (CUBE)
software
Enables connectivity from an organization’s network to the service provider
network for SIP trunks via CUBE
Recommended Deployment
Headquarters
Deploy a Cisco Expressway-C and Expressway-E server pair to enable remote Jabber and TelePresence video
endpoint registrations, and IM and Presence. Deploy a separate Expressway-C and Expressway-E server pair for
secure business-to-business connectivity through the firewall. Cluster both Expressway-C and Expressway-E
servers in both pairs. If your deployment does not reach or exceed the scalability limit, you can deploy a single
Expressway-C and Expressway-E cluster for both business-to-business and mobile and remote access
applications.
Deploy Cisco ISR or ASR as the PSTN gateway, or enable CUBE functionality on the Cisco ISR or ASR for voice
connectivity from the organization’s network to the service provider network through a SIP trunk.
If full redundancy is not required, a single server pair (Expressway-C and Expressway-E) may be deployed.
Remote Sites
Deploy Cisco ISR as the PSTN gateway.
Deploy Expressway-C and Expressway-E if the remote site has local Internet connectivity and an Internet businessto-business architecture for video calls is required.
Teleworker Sites
For video-enabled sites, deploy Cisco TelePresence endpoints utilizing the Expressway-C and Expressway-E
infrastructure at headquarters or another site.
In addition, the Cisco Jabber client can be used without the VPN, regardless of the location of the endpoint (internal
or external to the organization).
Legacy audio and video-enabled phones can be deployed with VPN technologies. Depending on the phone type,
some of them have an embedded VPN client and may be deployed without a VPN hardware client. For more
information on each phone model, refer to the product documentation.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 26
Collaboration Edge
Benefits
This deployment provides the following benefits:
The Cisco ISR supports standards-based interfaces and various PSTN types, so it can be deployed globally.
Instead of traditional PSTN interfaces, CUBE functionality can be enabled on the Cisco ISR and ASR if a SIP trunk
is used.
The Cisco ISR and ASR can be used for WAN connectivity.
Cisco Expressway provides calling, presence, instant messaging, voicemail, and corporate directory services for
Cisco Jabber and TelePresence video endpoints.
Cisco Expressway enables video communications between organizations, partners, and vendors over the Internet.
Deployment Best Practices
Cisco Expressway
Cisco Expressway provides secure firewall and NAT traversal for mobile Cisco Jabber and TelePresence video endpoints
(Figure 12) and secure business-to-business communications (Figure 13). Cisco Expressway consists of two applications:
Expressway-C and Expressway-E.
Deploy Cisco Expressway-C inside the network, and deploy Expressway-E in the demilitarized zone (DMZ) by connecting
separate network ports on Expressway-E to the organization’s network and to the DMZ.
Cisco fully supports a virtualized Expressway-E in the DMZ; however, a dedicated server can be deployed based on the
company’s security requirements.
Figure 12
Traversal for Registrations Through Firewall with Expressway-C and Expressway-E
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 27
Collaboration Edge
Figure 13
Traversal for Business-to-Business Calls Through Firewall with Expressway-C and Expressway-E
Cisco Expressway-C
Place Expressway-C in the trusted network inside the organization.
Deploy Expressway-C to:
Function as a traversal client and establish a secure connection to Expressway-E through the firewall
Establish secure or non-secure connection to Cisco Unified CM
Integrate with an existing internal video network that uses H.323
Enable business-to-business calls to external entities that communicate using SIP or H.323
Provide interworking between H.323 and SIP protocols for H.323 business-to-business communications
Enable mobile and remote access capabilities and call signaling for Cisco supported endpoints, directing them to
Cisco Unified CM for SIP registration and/or the IM and Presence Service (See the Endpoints section for
information on which endpoints support mobile and remote access.)
Cisco Expressway-E
Because Expressway-E is reachable directly from the untrusted external network, it should be placed in a DMZ for
security. The organization’s firewall policies control communications to and from this server.
Deploy Expressway-E to:
Function as a traversal server and allow secure communications to and from Expressway-C
Enable audio, video, and IM and Presence connections to other organizations using SIP or H.323 on the Internet
Provide DNS SRV lookup service to resolve outbound calls and to receive inbound calls over the Internet
Process registration and IM and presence information from Cisco endpoints on the external network and use secure
traversal communications to pass the information to Expressway-C
Provide interworking between protocols (between SIP and H.323, and between IPv4 and IPv6) for business-tobusiness communications
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 28
Collaboration Edge
Connectivity for Audio and Video over the Internet
URI dialing is the best practice for audio and video dialing over the Internet. We recommend assigning alphanumeric URIs
to all devices that will send or receive calls over the Internet. Any device on Cisco Unified CM can be reached over the
Internet by dialing the assigned alphanumeric SIP URI or the required directory number (DN) by dialing <+E.164
number>@domain. For example, a Jabber user might have a SIP URI set to [email protected] and a directory number
set to +14085551234. Although a +E.164 addressing scheme can be used over the Internet, we recommend allowing only
alphanumeric SIP URIs for security reasons.
Users on Cisco Unified CM have to dial the full SIP URI to reach a user or device from a different organization over
the Internet.
The architecture for business-to-business Internet connectivity includes a client/server solution: Expressway-C and
Expressway-E. Both servers can be deployed in standalone mode or in a cluster. Deploy the same number of cluster
peers for Expressway-C clusters as for Expressway-E clusters.
Considerations for Outbound Business-to-Business Calls
When multiple Expressway-C and Expressway-E pairs are deployed, Unified CM can redirect an outbound call to
the edge server that is nearest to the calling endpoint, thus minimizing WAN traffic.
For call routing over the Internet, use public DNS service records. DNS SRV records map a domain to an edge
system servicing that domain for that protocol. For example, if a remote user dials [email protected], then the
remote system uses DNS to query for the host offering the SIP service for the domain ent-pa.com.
If the remote endpoint supports IP dialing only, Cisco Unified CM users can dial the IP address of the endpoint
followed by a string, which will be used to route the call. As an example, the user can dial [email protected] instead of
dialing 10.10.10.10. The string “@ip” will be used by Cisco Unified CM to route the call to the Expressway-C.
Expressway will send it to the Expressway-E, which will place the call to the IP address specified.
Considerations for Inbound Calls
Once a call reaches an Expressway-E, it is routed to the relevant Unified CM cluster through its corresponding
Expressway-C. In deployments with multiple edges (multiple pairs of Expressway-C and Expressway-E), there are two
methods to route inbound calls:
Call routing based on the calling location
In this scenario, a business-to-business call enters the corporate network through the edge that is nearest to the
calling endpoint or user. Because the call enters the corporate network after traversing a minimal distance over the
Internet, this approach focuses on using the shortest path to the point of entry as the means of providing the best
quality experience. In this scenario, use Geo-DNS. Geo-DNS provides unique DNS responses by geographic
regions based on the source IP address of the DNS query, and it is thus able to direct an SRV query to the specific
edge servicing a particular region. In this way, the calling endpoint is typically directed to the edge nearest to its
calling location.
Call routing based on the called location
It is possible to direct the inbound call to the edge that is nearest to the called endpoint. This approach has the
benefit of reducing the video bandwidth consumed over the WAN, but it requires a more complex architecture that
has some scaling constraints. For this reason, we do not recommend implementing this architecture when more
than two edges are deployed.
Note:
Call routing based on the called location applies to room and personal systems or clients that are not moving
across sites.
In addition, the Cisco Collaboration Architecture enables IP-based dialing for those endpoints on the Internet that are
capable to dial IP addresses only. The Expressway-E external interface IP address can be dialed from the Internet, and
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 29
Collaboration Edge
the call can be sent to a multipoint device or to a Cisco Unity Connection system, which will prompt the calling user to
specify the destination. Once the destination is entered, the call will be sent to the specified destination.
Mobile and Remote Access
The mobile and remote access feature enables Jabber clients and hardware endpoints (as indicated in Table 5, Mobile
and Remote Access column) to register securely to Cisco Unified CM through Expressway-E and Expressway-C without
any VPN. A Jabber client can send and receive several types of collaboration flows (audio, video, instant messaging, and
presence), while a hardware endpoint can send audio and video streams. When multiple edges are deployed, we
recommend using Geo-DNS services to provide the best network option based on assigning the closest edge in the DNS
response.
The mobile and remote access functionality also leverages Expressway-C and Expressway-E. Both business-to-business
and mobile and remote access services are supported on the same server, but we recommend deploying these services
on different Expressway-C and Expressway-E pairs in order to scale.
Instant Messaging and Presence Federation
Instant messaging and presence federation involves allowing users to send XMPP traffic through an organization’s
external firewall for chat and presence status information to and from users in another organization.
Prior Cisco architectures involved using the Cisco ASA firewall as a TLS proxy and allowing inbound ports to be opened
through the external firewall to directly access the IM and Presence servers internally.
This architecture is still valid for SIP federation for IM and Presence only, while Expressway-C and Expressway-E provide
XMPP federation with voice and video escalation.
PSTN Gateway
Because landlines and mobile phones use the PSTN for local and international calls, external connectivity to the PSTN
from an organization’s IP telephony network is a requirement (Figure 14).
Figure 14
PSTN Connectivity
Use Cisco ISR or ASR with a time-division multiplexing (TDM) module as the PSTN gateway at headquarters. This
configuration enables the gateway to implement media interworking for the organization’s incoming and outgoing PSTN
calls.
At remote sites, deploy a Cisco ISR for local PSTN connectivity using voice modules. For more information about Cisco
ISR, see the data sheet.
If SIP trunks are used to connect to a service provider for voice calls, enable CUBE functionality on the Cisco ISR that is
deployed at headquarters. When deploying Cisco ISR with CUBE functionality, observe the following recommendations:
Deploy CUBE in the demilitarized zone (DMZ).
Enable the firewall for NAT to convert the external address to the address of CUBE.
Enable the firewall to inspect voice calls.
Cisco Unified CM routes calls through SIP trunks to gateways, CUBE, or Cisco Expressway based on the dial plan. For
dial plan recommendations, see the Call Control section.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 30
Collaboration Edge
PSTN Connectivity for Voice
Enable PSTN connectivity for voice calls by using either an analog or ISDN interface. A Cisco ISR or ASR with analog or
ISDN cards provides these interfaces. Connectivity is usually local, and a site with PSTN interfaces uses its local ISR or
ASR as a voice gateway. Follow these recommendations for deploying an ISR or ASR for PSTN connectivity:
PSTN interface (analog or ISDN)
◦ The device providing these interfaces is a Cisco ISR or ASR with analog or ISDN cards.
◦ Connectivity is usually local; a site with PSTN interfaces uses its local ISR or ASR as a voice gateway.
◦ Redundancy is achieved by deploying multiple ISRs or ASRs. Cisco Unified CM has the ability to route traffic to
the closest available router.
SIP trunks to the service provider and ISR, ASR, or CUBE as a border element
◦ This deployment is typically used in a centralized architecture. Remote sites either do not have local connectivity,
or they have local connectivity but use it only for backup voice services. In this case the WAN connectivity has to
be sized to accommodate PSTN calls traversing the WAN to the central site where CUBE is deployed.
◦ Redundancy can be achieved by deploying multiple ISRs or ASRs, sometimes to different voice carriers. Cisco
Unified CM has the ability to route traffic to the closest available router.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 31
Voice Messaging
Voice Messaging
Voice messaging is considered to be a basic requirement and essential service for an Enterprise Collaboration
deployment. Cisco Unity Connection enables users to access and manage voice messages from their email inbox, web
browser, Cisco Jabber client, Cisco Unified IP Phone, or TelePresence endpoint. The Cisco PA for Enterprise
Collaboration includes Cisco Unity Connection to enable voice messaging for the Enterprise Collaboration solution
(Figure 15).
Figure 15
Architecture for Voice Messaging
Table 9 lists the roles of the components in this architecture and the services they provide.
Table 9
Components for Applications
Module
Component
Description
Voice Messaging
Cisco Unity Connection
Provides unified messaging and voicemail services
Recommended Deployment
Deploy two Unity Connection servers for each Cisco Unified CM cluster to provide high availability and redundancy.
Use SIP trunks to integrate Unity Connection with Unified CM. Configure two SIP trunks, one for each Unity
Connection server in a pair.
Enable the speech-activated voice command interface to maximize productivity of mobile workers.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 32
Voice Messaging
Benefits
Users can access the voicemail system and retrieve their voice messages by using their IP phones, mobile devices,
and various email client applications with either a dialed number or a SIP URI.
Cisco Unity Connection allows users to customize personal settings from a web browser.
Cisco Unity Connection offers a natural and robust speech-activated user interface that allows users to browse and
manage voice messages using simple and natural speech command.
Deployment Best Practices
Cisco Unity Connection supports a cluster configuration in active/active mode to provide both high availability and
redundancy. A Unity Connection cluster consists of a maximum of two nodes, one publisher and one subscriber in an
active/active deployment (Figure 16). If one of the Unity Connection nodes fails, the other active node in the cluster
handles all the calls, IMAP requests, and HTTP requests for the Unity Connection cluster. Each server in the Unity
Connection cluster must have enough voice messaging ports to handle all calls for the cluster.
Figure 16
Unified Messaging Architecture
Single Inbox, one of the unified messaging features in Cisco Unity Connection, synchronizes voice messages in Unity
Connection and Microsoft Exchange mailboxes. Unity Connection supports the Single Inbox feature with on-premises
Microsoft Exchange, cloud-based Microsoft Exchange, or Microsoft Office 365 server, thereby providing unified
messaging for voicemail. All voice messages, including those sent from Cisco Unity Connection ViewMail for Microsoft
Outlook, are first stored in Cisco Unity Connection and are immediately replicated to the Microsoft Exchange mailbox of
the recipient. This feature can be configured separately for each individual user.
Unity Connection imports the user information from the enterprise LDAP directory. Each mailbox must have a unique
voicemail number. Unity Connection supports both E.164 and + E.164 formats for the extension of an end-user account
(user with a voice mailbox). Unity Connection also supports alternate extensions per user.
The voicemail pilot number designates the directory number that users dial to access their voice messages. Unified CM
automatically dials the voice messaging number when users press the Messages button on their phone. The voicemail
pilot number can be an internal extension or a dedicated PSTN number.
Visual Voicemail allows users to access voicemail from the graphical interface on the IP phone. Users can view a list of
messages and play messages from the list. Users can also compose, reply to, forward, and delete messages. Each
voicemail message displays data that includes the date and time when the message was left, urgency level, and
message length.
For more information on Cisco Unity Connection, refer to the product documentation.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 33
Collaboration Management Services
Collaboration Management Services
This section focuses on management of the collaboration system environment. The Cisco PA for Enterprise Collaboration
includes the following Cisco core management applications that are considered to be a basic requirement and
foundational to any Enterprise Collaboration solution (Figure 17):
Cisco Prime Collaboration Deployment — Assists with installation of applications.
Cisco Prime License Manager — Assists with license management.
Cisco Prime Collaboration Provisioning – Assists with provisioning as well as moves, adds, changes, and deletions
(MACD) for day-2 management control.
Figure 17
Architecture for Collaboration Management Services
Table 10 lists the roles of the application components in this architecture and the services they provide.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 34
Collaboration Management Services
Table 10
Components for Collaboration Management Services
Module
Component
Description
Collaboration
Management
Services
Cisco Prime Collaboration
Deployment
Assists the administrator by automating many of the steps necessary to
install a Cisco Unified CM cluster with IM and Presence Service and a Unity
Connection cluster.
Cisco Prime License Manager
Provides the administrator with a single management point for the Cisco
Unified CM licenses and Unity Connection licenses used in a deployment.
Cisco Prime Collaboration
Provisioning
Enables rapid deployment of collaboration systems by providing a templatedriven console for device provisioning as well as moves, adds, and
changes.
Cisco Prime Collaboration Deployment
Cisco Prime Collaboration Deployment assists the administrator by automating many of the steps necessary to
preliminarily configure and install Cisco Collaboration applications.
Cisco Prime Collaboration Deployment supports the following Cisco Collaboration Applications in the Enterprise Preferred
Architecture:
Cisco Unified Communications Manager (Unified CM)
Cisco IM and Presence Service
Cisco Unity Connection
Recommended Deployment
For the Enterprise PA, we recommend deploying Cisco Prime Collaboration Deployment as a standalone virtual machine
(VM) and not co-resident with any other applications.
Benefits
Cisco Prime Collaboration Deployment provides the following benefits:
Enables automated unattended installation of ESXi-hosted collaboration application virtual machine server nodes
Facilitates configuration of a common base platform and initial application settings for all collaboration application
nodes, including:
◦ Network services (time, domain name)
◦ Administrative accounts and passwords
◦ Base certificate information
Deployment Best Practices
Figure 18 shows the preferred architecture for Prime Collaboration Deployment. Once Cisco Prime Collaboration
Deployment is deployed as a standalone VM, the collaboration application installation ISO files (available from Cisco.com)
are transferred to the Cisco Prime Collaboration Deployment file store using secure FTP (SFTP). Next the ESXi servers
that will host the collaboration application virtual server nodes must be defined within Cisco Prime Collaboration
Deployment. The Cisco Prime Collaboration Deployment file store is then mounted automatically via NFS to each ESXi
host, thus making the ISO files available for collaboration application installations. After target VMs are created on the
ESXi host for the Unified CM and IM and Presence cluster and Unity Connection cluster server nodes, installation of the
collaboration application nodes is defined and started from Cisco Prime Collaboration Deployment.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 35
Collaboration Management Services
Figure 18
Architecture for Prime Collaboration Deployment
Cisco Prime License Manager
Cisco Prime License Manager provides simplified, enterprise-wide management of user-based licensing, including license
fulfillment and reconciliation of licenses across supported products, and it provides enterprise-level reporting of usage and
entitlement. Cisco Prime License Manager also supports multiple clusters.
Cisco Prime License Manager supports the following Cisco Collaboration applications in the Enterprise Preferred
Architecture:
Cisco Unified Communications Manager (Unified CM)
Cisco IM and Presence Service
Cisco Unity Connection
Recommended Deployment
In the Enterprise PA, we recommend deploying Cisco Prime License Manager as a standalone virtual machine and not
co-resident with any other applications.
Benefits
Centralizes license management for Unified CM, IM and Presence, and Unity Connection
Provides license pooling
Minimizes re-hosting of license files
Eliminates dependency of licenses on versions of Unified Communications applications
Cisco Prime Collaboration Provisioning
Cisco Prime Collaboration Provisioning provides a scalable web-based solution to help administrators manage the
provisioning needs of an integrated IP telephony, video, voicemail, and unified messaging environment. Cisco Prime
Collaboration Provisioning assists the administrator with user and device provisioning, thereby enabling rapid
deployment. After the initial configuration and provisioning, Cisco Prime Collaboration Provisioning simplifies moves,
adds, and changes, as well as the configuration and deployment of new features. An intuitive user interface provides a
single consolidated view of users and their services.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 36
Collaboration Management Services
Recommended Deployment
Cisco Prime Collaboration supports high availability (HA) through the VMware vSphere HA feature. You do not need an
additional Cisco Prime Collaboration license to configure HA, and HA is highly recommended to increase uptime in case
of a failure of the host on which Prime Collaboration Provisioning resides. For small and medium deployment models, you
need one virtual machine for Prime Collaboration Provisioning. For large and very large deployment models, you must
configure the Prime Collaboration Provisioning database and application on separate virtual machines.
We highly recommend performing regular backups to an external FTP server and taking periodic VM snapshots because
a considerable amount of time and effort is required to configure the system and get it running initially. These processes
also help retain the logs and order history for each user and help restore data in case of a catastrophic failure.
Benefits
Cisco Prime Collaboration Provisioning provides the following features and benefits:
By significantly simplifying moves, adds, changes, and deletions (MACD), Cisco Prime Collaboration Provisioning
facilitates delegation of these tasks to helpdesk users, thus allowing organizations to optimize IT resources and
further reduce total cost of ownership.
Cisco Prime Collaboration Provisioning significantly accelerates site rollouts and dramatically reduces the time
required for ongoing changes, resulting in exceptional productivity gains and lower operating expenses.
Wizards in Cisco Prime Collaboration Provisioning expedite provisioning for greenfield deployments.
Infrastructure and User Services provisioning features for greenfield and brownfield deployments help manage
granular Role Based Access Control (RBAC) for different administrators.
Cisco Prime Collaboration Provisioning provides a single, consolidated view of users across the organization and
across all clusters, thereby presenting a single interface for all provisioning needs of an organization.
Cisco Prime Collaboration Provisioning allows IT administrators to embed policies into Cisco Prime Collaboration
Provisioning for managing user services across the Cisco Unified Communications applications. Administrators can
configure policies at various levels to determine who can do delegated management, for whom that delegation
applies, how business-level services apply to Cisco Collaboration Systems, and which types of users are permitted
to order which standard services. With this approach for policy and standards configuration, delegated individuals
can provision and activate user services easily. At the same time, the primary administrator retains the overall ability
to manage and provide services that use the underlying Cisco Unified Communications applications.
Cisco Prime Collaboration Provisioning provides template capability, which permits defining standard configurations
that can be reused for new sites or additional location deployments.
Automatic Service Provisioning helps the administrator expedite employee on-boarding and off-boarding processes.
This allows the administrator to add a new user and, based on company policies and location, it automatically
provisions the new user’s common services.
Batch provisioning permits the rollout of large numbers of users at the same time.
Deployment Best Practices
Cisco Prime Collaboration Provisioning is very flexible and can adapt to any enterprise deployment model. For example,
users can be brought into Cisco Prime Collaboration Provisioning from an LDAP server directly or from Unified CM as
well. Figure 19 shows the recommended architecture, where Cisco Prime Collaboration Provisioning is integrated through
LDAP and all users in the organization are brought into Cisco Prime Collaboration Provisioning from LDAP. This
architecture allows the synchronization and authentication of users to be decoupled within Unified CM. This setup also
allows the administrator to leverage Automatic Service Provisioning, which provisions a bundle of services when a new
employee is added into the LDAP server and also de-provisions those services when an employee is deleted from the
LDAP server.
Cisco Prime Collaboration Provisioning is also very flexible in terms of how the users are grouped. For example, users
can be grouped based on the cluster to which they belong, based on administrative control, or based on the users’ site.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 37
Collaboration Management Services
Grouping by site is intuitive and also recommended to scale the service areas, user roles, and service templates required
within each domain (user group).
With Cisco Prime Collaboration Provisioning as the front end for all provisioning activities in the Unified Communications
environment, administrators can also be granted Role Based Access Control (RBAC) to limit access to their respective
domains and also infrastructure objects via infrastructure permission profiles.
Figure 19
Cisco Prime Collaboration Provisioning Deployed with LDAP Integration
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 38
Security
Security
As with almost everything today, it is important to secure your collaboration deployment. A collaboration deployment is
subject to threats such as denial of service, unauthorized access, toll fraud, and eavesdropping. It is important to protect
your collaboration deployment against these threats. Take a layered security approach by securing various network
levels: secure physical access, network infrastructure, collaboration applications, and collaboration endpoints (Figure 20).
Solely following the guidelines in this section does not guarantee a secure environment, nor will it prevent all penetration
attacks on a network. You can achieve reasonable security by establishing a good security policy, following that security
policy, staying up-to-date on the latest developments in the hacker and security communities, and maintaining and
monitoring all systems with sound system administration practices.
Figure 20
Secure All Components of the Enterprise Collaboration Preferred Architecture
Recommended Deployment
Secure the infrastructure by protecting physical access, and secure the IP network.
Use hardening techniques to secure all devices, including servers and endpoints.
Protect your deployment against toll fraud.
Simplify certificate management by having certain certificates signed by a Certification Authority (CA).
Do not disable native security features. For example, with Cisco Unified CM, do not disable Security By Default.
Encrypt SIP trunks, HTTP connections, and other server-to-server links.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 39
Security
To protect sensitive voice and video communications, enable mixed-mode on Cisco Unified CM and enable
encrypted signaling and media for endpoints. This is especially important if your network is not entirely trusted and
secure.
Benefits
This deployment provides the following benefits:
Your collaboration deployment is more secure if the physical access is protected and the IP network is secured.
By protecting network access to servers and phones, you make it more difficult to compromise them and get access
to other devices in the deployment.
By implementing toll fraud protection mechanisms, you can prevent unauthorized access to your telephony system,
data network, and PSTN lines.
By signing certain certificates with a CA, you make it easier to manage the certificates and, more importantly, you
increase security by avoiding scenarios where end-users must accept certificates on their computing device, which
most end-users do without verifying the authenticity of the certificates.
Several secure features are implemented by default. For example, with Cisco Unified CM, phone configurations and
firmware loads are signed so that it becomes more difficult to compromise the phones by loading malicious
configurations or firmware.
Encryption protects against eavesdropping and protects the privacy of voice and video calls. It also protects against
tampering. By encrypting communications between all devices, including the endpoints, you can achieve end-to-end
encryption.
Deployment Best Practices
Secure Infrastructure Recommendations
Secure your infrastructure; it is the foundation of your collaboration deployment.
Protect physical access to your premises, network, endpoints, and especially the servers.
Protect your network with firewall and Intrusion Prevention System (IPS) devices.
Implement security features at Layer 2 and Layer 3 for your network. For example, protect access to your network
with 802.1X, and protect your DHCP server with DHCP Snooping and Dynamic ARP Inspection.
Implement network segmentation by having a separate voice/video VLAN for hardware endpoints and a data VLAN
for multipurpose devices such as mobile phones and laptops running Jabber.
With Cisco Unified Border Element deployed at the network edge, configure the Unified Border Element protection
mechanisms against telephony denial of service (TDoS) and configure access control lists (ACLs).
Device Hardening Recommendations
Protect network access to your devices by using hardening techniques.
Use secure password policies and do not rely on default passwords.
Restrict access to your devices.
Protect not only the servers but also the endpoints.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 40
Security
Toll Fraud Recommendations
On Cisco Unified CM, several mechanisms can be used to prevent toll fraud. Partitions and calling search spaces (CSS)
provide segmentation and access control to the directory number that can be called or the device or line that is placing the
call. As a best practice, apply the most restrictive class of service possible (for example, no access to PSTN routes for
calls coming in from the PSTN) based on partitions and calling search spaces. Other mechanisms can also be used, such
as time-of-day routing, enabling the Block OffNet to OffNet Transfer service parameter, forced authentication code (FAC),
and route filters.
On Cisco Expressway-E, use Call Processing Language (CPL) rules to block fraudulent attempts.
On Cisco Unified Border Element, configure protection mechanisms against toll fraud; for example, configure an IP trust
list and explicit incoming and outgoing dial peers.
Certificate Recommendations
Simplify certificate management with Certification Authority (CA) signed certificates. By default, server certificates are selfsigned certificates. To establish trust with a service based on a self-signed certificate, the self-signed certificates must be
imported into the trust store of all entities requiring secure connections to the service. If the certificates are not imported,
the communication can fail or warning messages about the certificates might appear, as with Jabber for example.
Importing certificates can be handled if the set of communicating parties is small, but it becomes more difficult for large
numbers of communication peers. For this reason, we recommend having some of the certificates signed by a
Certification Authority (CA) and extending trust to the CA. This is especially important for certificates such as the Tomcat
certificates for Cisco Unified CM with IM and Presence and Cisco Unity Connection as well as the XMPP certificate for IM
and Presence.
For Cisco Expressway-E servers, use certificates that are signed by a public CA.
Use multi-server certificates wherever possible, especially for the Cisco Unified CM and Unified CM IM and Presence
Tomcat certificates. Multi-server certificates allow the administrator to assign a single certificate for a given service across
multiple servers in a cluster in order to further simplify certificate management.
On the endpoints, in general, two types of certificates are available: Manufactured-Installed Certificate (MIC) and Local
Significant Certificate (LSC). Endpoint certificates are used for encryption of the signaling and media and for the optional
encryption of TFTP phone configuration files. We recommend using LSC certificates instead of MIC certificates.
Encryption Recommendations
Provide encryption for the following:
SIP trunks
SIP trunks are used between Cisco Unified CM and other servers such as Cisco Unity Connection, IM and
Presence, Cisco Meeting Server, Unified Border Element, business-to-business (B2B) Collaboration Edge, and
voice gateways.
HTTP connections
Use HTTPS instead of HTTP for all application connections. For example, use HTTPS with Extension Mobility.
With a Cisco Unified CM multi-cluster deployment, also enable encryption for:
Intercluster Lookup Service (ILS)
Location Bandwidth Manager (LBM)-to-LBM communication between clusters
To protect sensitive voice and video communications, enable endpoint encryption for signaling and media. This is
especially important if your network is not entirely trusted and secure. This requires enabling mixed-mode in Unified CM.
With mixed mode, you can select which endpoints are configured to use signaling and media encryption and which are
not.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 41
Bandwidth Management
Bandwidth Management
Bandwidth management is about ensuring the best possible user experience end-to-end for all voice and video capable
endpoints, clients, and applications in the Collaboration solution. The Cisco Preferred Architecture for Enterprise
Collaboration provides a holistic approach to bandwidth management that incorporates an end-to-end Quality of Service
(QoS) architecture, call admission control, and video rate adaptation and resiliency mechanisms to ensure the best
possible user experience for deploying pervasive video over managed and unmanaged networks.
QoS Architecture for Collaboration
QoS ensures reliable, high-quality voice and video by reducing delay, packet loss, and jitter for media endpoints and
applications. QoS provides a foundational network infrastructure technology that is required to support the transparent
convergence of voice, video, and data networks. With the increasing amount of interactive applications – particularly
voice, video, and immersive applications – real-time services are often required from the network. Because these
resources are finite, they must be managed efficiently and effectively. If the number of flows contending for such priority
resources were not limited, then as those resources become oversubscribed, the quality of all real-time traffic flows would
degrade, eventually to the point of becoming useless. “Smart” media techniques, QoS, and admission control ensure that
real-time applications and their related media do not over-subscribe the network and the bandwidth provisioned for those
applications, thus ensuring efficient use of bandwidth resources. These smart media techniques coupled with QoS and,
where needed, admission control can be a powerful set of tools to protect real-time media from non-real-time network
traffic and to protect the network from oversubscription and the potential loss of user experience quality for all voice and
video applications.
Figure 21 illustrates the approach to QoS used in the Cisco PA for Enterprise Collaboration. This approach consists of the
following phases:
Identification and classification — Refers to concepts of trust and techniques for identifying media and signaling
for trusted and untrusted endpoints. It also includes the process of mapping the identified traffic to the correct DSCP
to provide the media and signaling with the correct per-hop behavior end-to-end across the network for both trusted
and untrusted endpoints.
Queuing and scheduling — Consists of general WAN queuing and scheduling, the various types of queues, and
recommendations for ensuring that collaboration media and signaling are correctly queued on egress to the WAN.
Provisioning and admission control — Refers to provisioning the bandwidth in the network and determining the
maximum bit rate that groups of endpoints will utilize. This is also where call admission control can be implemented
in areas of the network where it is required.
Monitoring, troubleshooting, and optimization — Ensures the proper operation and management of voice and
video across the network. Cisco Prime Collaboration offers a suite of tools to perform these functions.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 42
Bandwidth Management
Figure 21
Architecture for Bandwidth Management
Recommended Deployment
Identify traffic based on trusted and untrusted devices.
Classify and mark traffic at the access switch edge.
◦ Mark all audio with Expedited Forwarding class EF (includes all audio of voice-only and video calls).
◦ Mark all critical desktop and room system video with an Assured Forwarding class of AF41.
◦ Mark all Jabber, Mobile and Remote Access (MRA), and Edge video with an Assured Forwarding class of AF42.
◦ Configure QoS on all media originating and terminating applications and MCUs across the solution.
Apply simplified WAN Edge policies for identifying, classifying, marking, and queuing collaboration traffic:
◦ WAN edge ingress re-marking policy
◦ WAN edge egress queuing and scheduling policy
Group video endpoints into classes of maximum video bit-rate to limit bandwidth consumption based on endpoint
type and usage in the solution.
Deploy Enhanced Locations Call Admission Control and limit calling based only in areas of the network where
bandwidth resources are restricted.
Benefits
This deployment provides the following benefits:
Prescriptive recommendations to simplify deployment with a simplified QoS architecture
Makes more efficient use of network resources
Supports mobile and multi-media Collaboration devices
Takes into account “unmanaged” network segments (Internet)
Is “future-proof” — facilitates introduction of new services, features, and endpoints
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 43
Bandwidth Management
Deployment Best Practices
When video is deployed pervasively across the organization, bandwidth constraints typically limit the video resolution that
can be achieved during the busiest hour of the day, based on the bandwidth available and the number of video calls
during that busy hour. While it is possible to buy more bandwidth in some places of the network, it is not always possible
in all places of the network, nor is it cost effective to buy bandwidth that is used only during the busy hour but remains idle
during the rest of the operational day.
To address this challenge, we have targeted a group of endpoints and call flows in the Preferred Architecture and have
created a strategy of QoS marking and queuing to allow the video endpoints and flows to be more opportunistic in their
utilization of video in the network. This concept of opportunistic video is about achieving the best video quality based on
the WAN bandwidth resources available at any given time for a determined group of devices and call flows. In the
Preferred Architecture all Cisco Jabber clients as well as any Collaboration Edge call flows such as mobile and remote
access or business-to-business call flows are “classified” as opportunistic video flows. During the busy hour with higher
call volumes, more video flows are expected over the constrained areas of the network. Rather than using call admission
control to deny the video calls, we have created a QoS marking and queuing policy that forces opportunistic video flows to
rate adapt down when packet loss occurs in that class. Using a single class video queue approach with DSCP-based
Weighted Random Early Detection (WRED), we are able to protect prioritized video from packet loss during periods of
congestion over opportunistic video. With this single video queue approach, when prioritized video is not using bandwidth
in the queue, opportunistic video gains full access to the entire queue bandwidth if and when needed, or it rate adapts
down to squeeze more opportunistic video flows into the queue without affecting the prioritized video flows. This is a
significant point when deploying pervasive video with Jabber and Collaboration Edge technologies. This frees up more
bandwidth for more video flows while still protecting prioritized video flows.
Another consideration taken in the Preferred Architecture is around the QoS of an audio stream of a video call, and how it
has traditionally been marked with the same QoS as the video stream of the video call. This approach, however, has two
deficiencies:
The audio stream of a video call can be impacted by packet loss in the video queue.
Audio stream classification for untrusted devices cannot be distinguished between voice-only calls and video calls.
In the Preferred Architecture we have designed a solution to address these deficiencies by ensuring that all audio is
marked with a single value of Expedited Forwarding (EF) across the solution. In this way, whether the audio stream is
associated with a voice-only call or a video call, it is always marked to the same value. Thus, the audio stream of a video
call will be prioritized above the video and not subject to any packet loss in the video queue. This also solves the
identification issue with untrusted devices such as Jabber clients. Because the marking of the client is not trusted by the
network access layer, there is no effective way to distinguish the audio stream of a voice-only call from the audio of a
video call in the network. Thus, moving to this new model where all audio is marked with a single value simplifies the
network prioritization and treatment of the traffic.
Another consideration when the audio and video of a video call are not using the same QoS marking, is the fact that the
audio could arrive at the terminating endpoint with less delay than video. This is because audio is prioritized higher and
sent into the queues earlier than video traffic. To ensure that there are no lip-sync issues between the audio and video,
enabling Real-time Transport Control Protocol (RTCP) on all endpoints is a simple yet strict requirement. RTCP uses
timestamps to synchronize audio and video, and thus resolves any lip-sync issues that could arise from a delay variation
between audio and video of the same video call.
In some areas of the network, bandwidth is too constrained even for the above strategy, in which case call admission
control is the only possible way to ensure that over-subscription of bandwidth resources does not occur in those areas of
the network. Enhanced Locations Call Admission Control can be deployed to protect the WAN resources, thus ensuring
that any allowed call flows have the bandwidth to proceed without packet loss. If admission control fails a call flow, Unified
CM has the ability to find alternative call routing paths if available.
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 44
Appendix
Appendix
Product List
This product list identifies the Cisco products in the Preferred Architecture for Enterprise Collaboration, along with their
recommended software versions.
Product
Product Description
Recommended Software Version
Cisco Unified Communications Manager
and IM and Presence Service
Call control, instant messaging, and presence services
11.5(1)SU2
Cisco Unity Connection
Voicemail services
11.5(1)SU2
Cisco Expressway-C and Expressway-E
Mobile and remote access and business-to-business
communications
X8.9(1)
Cisco Prime License Manager
Single management point for licensing
11.5(1)SU1a
Cisco Prime Collaboration Deployment
Installs Unified CM cluster with IM and Presence Service and
Unity Connection cluster
11.6(1)
Cisco Prime Collaboration Provisioning
Configures Unified CM and other applications; provisions users
and devices; handles moves, adds, and changes
11.6
Cisco Meeting Server
Audio and video conferencing and resource management
2.1
Cisco ISR and ASR
PSTN gateway, SRST, and external connectivity to the Internet
IOS 15.6(3)M1 for ISR
IOS XE 16.3(2) for ASR
Cisco Unified IP Phone 7811
General office use, single-line phone
11.7(1)
Cisco Unified IP Phone 8800 Series
General office use
11.7(1)
Cisco Unified IP Phone 8831
IP conference phone
10.3(1)
Cisco Jabber
Soft client with integrated voice, video, voicemail, and instant
messaging and presence functionality for mobile devices and
personal computers
Jabber 11.8
Cisco TelePresence DX Series
Personal TelePresence endpoint for the desktop
CE 8.3(1)
Cisco TelePresence MX Series
TelePresence multipurpose room endpoint
CE 8.3(1)
Cisco TelePresence SX Series
Integrator Series TelePresence endpoint
CE 8.3(1)
Cisco TelePresence IX Series
Immersive TelePresence room system
IX 8.2
Cisco TelePresence Management Suite
(TMS)
Scheduling, web conferencing integration, and other advanced
video features
15.4
Cisco Preferred Architecture for Enterprise Collaboration 11.6
PAGE 45
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
