Panasonic Broadcast
AK-HC3500
Menu Information
Menu operations
Entering the menu data
Basic setting menu operations
After accessing the item menus, enter the respective
data.
Displaying the menus
1Turn the JOG dial to select the menu item to be set.
User menu
1Press the MENU switch.
The camera’s USER menu screen now appears on the
viewfinder or monitor.
2When the JOG dial is pressed, the setting of the item
indicated by the arrow flashes.
2
Turn the JOG dial to select the menu item.
3After having selected the item, press the JOG dial to
access that item’s menu.
3
Turn the JOG dial to change the setting.
4
When the JOG dial is pressed, the data is entered.
Note
Bear in mind that if, in step 3, the MENU switch is set to
OFF while the setting is flashing, the setting prior to the
flashing will remain unchanged.
25
Menu operations
Entering the menu data (continued)
When the setting flashes one character at a time, press
the JOG dial to move the flashing toward the right.
1When the JOG dial is pressed, flashing moves toward
the right.
2
Turn the JOG dial to change the setting.
3
When the JOG dial is now pressed, the data is entered.
26
Setting menu configuration
Hierarchical menus
USER MENU
27
Setting menu configuration
Hierarchical menus
USER MENU
28
Setting menu configuration
Hierarchical menus
USER MENU
29
Setting menu configuration
Hierarchical menus
USER MENU
30
Setting menu configuration
Hierarchical menus
USER MENU
31
Table of adjustment setting ranges
Operation
Menu
VF Setting1
VF Setting2
Item
Side Modu SW
OFF, ON
OFF
Side Modu LVL
0 to 31
31
Zone Mark
OFF, 4:3, 13:9, 14:9, 15:9, 16:9
OFF
Safety Mark1
Safety Area1
Safety Mark2
Safety Area2
Center Mark
Center Mark SEL
Line Width
Marker Level
VF DTL
16:9, 15:9, 14:9, 13:9, 4:3, OFF
80 %, 90 %, 93 %, 100 %
16:9, 15:9, 14:9, 13:9, 4:3, OFF
80 %, 90 %, 93 %, 100 %
OFF, ON
1 to 4
1 to 3
100 %, 75 %, 50 %
0 to 23
12.4M, 12.5M, 12.7M, 12.9M, 13.0M, 13.3M,
13.6M, 13.9M, 14.2M, 14.6M, 15.0M, 15.5M,
16.1M, 16.7M, 17.3M, 18.0M, 18.6M, 18.8M,
19.0M, 19.2M, 19.5M, 19.9M, 20.3M, 20.9M,
21.5M, 22.4M, 23.6M, 25.4M, 28.6M, 37.1M
0 to 5
0 to 63
2.0M, 2.3M, 2.7M, 3.4M, 4.5M, 6.8M, 13M
0 to 5
0 to 63
2.0M, 2.3M, 2.7M, 3.4M, 4.5M, 6.8M, 13M
0 to 5
0 to 63
OFF, ON
ADJ, 1, 2, 1+2
0 to 255
0 to 255
0 to 255
0 to 255
BOX, CROSS
MEM1, MEM2
NO?, YES?
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON, AUTO
LOW, NORM
OFF, ON
OFF, ON
—
OFF
93 %
OFF
80 %
OFF
1
2
100 %
10
Items recorded on SD memory cards

No switching from the SD memory
card to the camera settings possible
while the buildup unit is connected.

No switching from the SD memory
card to the camera settings possible
while the buildup unit is connected.

No switching from the SD memory
card to the camera settings possible
while the buildup unit is connected.









12.4M

0
0
6.8M
0
0
6.8M
0
0
OFF
ADJ
127
127
127
127
BOX
MEM1
NO?
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
NORM
OFF
OFF
—










HD Peak FREQ
Cursor
VF Display1
VF Display2
Setting1
HD Offset Gain
HD Crisp
D1 Peak FREQ
D1 Offset Gain
D1 Crisp
VBS Peak FREQ
VBS Offset Gain
VBS Crisp
Cursor
Cursor Memory
H Position
V Position
Width
Height
BOX/CROSS
Store Memory
EXECUTE
F Number
Zoom
Focus
Extender
MONI OUT
Filter
M Gain
Shutter
5600K
Audio Level
OPT Level
RET Select
Status
Status(AUTO)
Field Rate
Voltage
WFM (*1)
White CH
FAN Power
FAN Mode
CALL+R_TALLY
CALL+T_TALLY
PinP Mode
Adjustment setting range
Initial value




















*1: W
aveforms are displayed as a single line at the center of the screen. They appear at the bottom right when the
aspect ratio is set to 16:9, but when an aspect ratio of 4:3 is set on the viewfinder or when the side panel mode is
selected by the down-converter, the waveform display will be cut off in part.
32
Table of adjustment setting ranges
Menu
Setting1
Setting2
Setting3
Setting4
!LED
7"VF
INCOM Set.1
INCOM Set.2
MIC Gain
Item
HD-SDI2 OUT
HD-SDI2 Power
AUX I/O
TRUNK1
TRUNK2
5600K
HND GRIP RET
HND GRIP PTT
HND Lens VTR
HND Lens RET
STD Lens RET1
STD Lens RET2
EXT RET 1
EXT RET 2
EXT RET 3
RET1 ID
RET2 ID
RET3 ID
RET4 ID
Gain SW LOW
Gain SW MID
Gain SW HIGH
ID Character
User SW1
User SW2
User SW3
User B/U
Back Light
RET Mode
Lens I/F
B/U Lens
Rear ROP VR
Gamma Off
Shutter
Extender
MONI OUT
FAN Off
Master Gain
Black Gamma
VF FAN Speed
Peak Slice
Peak FREQ
INC1 MIC Type
INC1 MIC Gain
INC1 MIC Power
INC1 Side Tone
INC1 PGM MIX
INC1 ENG/PROD
INC1 to CCU
INC2 MIC Type
INC2 MIC Gain
INC2 MIC Power
INC2 Side Tone
INC2 PGM MIX
INC2 ENG/PROD
CRANE MIC Gain
CRANE Side Tone
CRANE ENG/PROD
CRANE to CCU
MIC1 Gain
MIC1 AMP
MIC2 Gain
MIC2 AMP
Adjustment setting range
MAIN, VF, RET
ACTIVE, SAVE
RET Y IN, PMT2 OUT, VBS OUT, D1 OUT
RS422, RS232C
RS422, RS232C
OFF, ON
A, B, PTT
PTT, A, B
VTR, A, B, PTT
A, B
A, B
A, B
A, B
A, B
A, B
Enables a name (5 characters) to be set.
Enables a name (5 characters) to be set.
Enables a name (5 characters) to be set.
Enables a name (5 characters) to be set.
–6 dB to 36 dB (in 3 dB increments)
–6 dB to 36 dB (in 3 dB increments)
–6 dB to 36 dB (in 3 dB increments)
Enables a name (10 characters) to be set.
A, B, PTT, DISP, MARK OFF (*2)
A, B, PTT, DISP, MARK OFF
A, B, PTT, DISP, MARK OFF
A, B, PTT, DISP, MARK OFF, LENS EXT
1 to 70
NORM, TOGGLE, SEQ.
Analog, Serial
PORTABLE, BOX
CAM, CCU
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
NORM, LOW
OFF, LOW, MID, HIGH
8 MHz, 15 MHz
DYN, ECM, CBN
–12 dB to +12 dB (in 3 dB increments)
OFF, ON
OFF, –36 dB to 0 dB (in 3 dB increments)
OFF, ON
ENG, PROD
OFF, ON
DYN, ECM, CBN
–12 dB to +12 dB (in 3 dB increments)
OFF, ON
OFF, –36 dB to 0 dB (in 3 dB increments)
OFF, ON
ENG, PROD
–12 dB to +12 dB (in 3 dB increments)
OFF, –36 dB to 0 dB (in 3 dB increments)
ENG, PROD
OFF, ON
20 dB, 40 dB, 60 dB
–20 dB to 20 dB (in 1 dB increments)
20 dB, 40 dB, 60 dB
–20 dB to 20 dB (in 1 dB increments)
Initial value
VF
ACTIVE
RET Y IN
RS422
RS422
OFF
A
PTT
B
A
A
B
A
B
B
RET1
RET2
RET3
RET4
0 dB
6 dB
12 dB
—
A
PTT
PTT
PTT
20
NORM
Analog
BOX
CAM
OFF
OFF
OFF
OFF
OFF
OFF
OFF
NORM
OFF
8 MHz
DYN
0 dB
OFF
OFF
ON
ENG
ON
DYN
0 dB
OFF
OFF
ON
ENG
0 dB
OFF
ENG
ON
20 dB
0 dB
20 dB
0 dB
Items recorded on SD memory cards



































*2: DISP:
At the DISP setting, the character display is forcibly set to OFF while the user switch is pressed.
MARK OFF:At the MARK OFF setting, ZONE, SAFETY, CURSOR, CENTER and WFM are forcibly set to OFF while
the user switch is pressed.
33
Table of adjustment setting ranges
Painting
Menu
Setting SW
BlackShading
Black/Gain
White SHD
Gamma
Knee/W.Clip
Item
Flare
Black Gamma
Gamma
Knee
White Clip
Matrix
Preset Matrix
DTL
Skin Tone DTL
DRS SW (*3)
Correct
H SAW R/G/B
H PARA R/G/B
V SAW R/G/B
V PARA R/G/B
AUTO V.SAW
PED M
PED R
PED B
Flare
Flare R
Flare G
Flare B
Gain R
Gain G
Gain B
Correct
H SAW R/G/B
H PARA R/G/B
V SAW R/G/B
V PARA R/G/B
Gamma
Gamma M
Gamma R
Gamma B
Black Gamma
Black Gamma M
Black Gamma R
Black Gamma B
DRS SW
Effect Depth
Initial Gain
Knee
Knee Point M
Knee Point R
Knee Point B
Knee Slope M
Knee Slope R
Knee Slope B
White Clip
White Clip M
White Clip R
White Clip B
Adjustment setting range
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
OFF, ON
NORM, EBU, NTSC
OFF, ON
OFF, ON
OFF, ON
OFF, ON
–100 to +100
–100 to +100
–100 to +100
–100 to +100
—
–99 to +99
–800 to +800
–800 to +800
OFF, ON
–100 to +100
–100 to +100
–100 to +100
–800 to +800
–800 to +800
–800 to +800
OFF, ON
–100 to +100
–100 to +100
–100 to +100
–100 to +100
OFF, ON
0.600 to 0.300
–75 to +75
–75 to +75
OFF, ON
–32 to +32
–20 to +20
–20 to +20
OFF, ON
1 to 5
4.0, 4.5, 5.0
OFF, ON
110 % to 80 %
–20 to +20
–20 to +20
0 to 199
–31 to +31
–31 to +31
OFF, ON
109 % to 80 %
–15 % to +15 %
–15 % to +15 %
*3: The image will be disturbed for an instant when the DRS function setting is changed.
34
Initial value
ON
OFF
ON
OFF
OFF
OFF
NORM
ON
OFF
OFF
ON
0
0
0
0
—
0
0
0
ON
0
0
0
0
0
0
ON
0
0
0
0
ON
0.450
0
0
OFF
0
0
0
OFF
5
4.5
OFF
95 %
0
0
100
0
0
OFF
109 %
0
0
Table of adjustment setting ranges
Menu
Linear Matrix
Color Correct1
Color Correct2
Detail1
Detail2
Item
Matrix
Linear
12axes
R-G
R-B
G-R
G-B
B-R
B-G
Matrix
Linear
12axes
G Satu
G Phase
G_Cy Satu
G_Cy Phase
Cy Satu
Cy Phase
Cy_B Satu
Cy_B Phase
B Satu
B Phase
B_Mg Satu
B_Mg Phase
Matrix
Linear
12axes
Mg Satu
Mg Phase
Mg_R Satu
Mg_R Phase
R Satu
R Phase
R_Ye Satu
R_Ye Phase
Ye Satu
Ye Phase
Ye_G Satu
Ye_G Phase
V DTL
H DTL
Crisp
Peak FREQ
Level Dep.
Dark DTL
Corner DTL
DTL_Source
DTL_Clip+
DTL_Clip–
DTL_Knee+
DTL_Knee–
Knee DTL
Adjustment setting range
OFF, ON
OFF, A, B
OFF, A, B
–31 to +31
–31 to +31
–31 to +31
–31 to +31
–31 to +31
–31 to +31
OFF, ON
OFF, A, B
OFF, A, B
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
OFF, ON
OFF, A, B
OFF, A, B
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
–128 to +127
0 to 63
0 to 63
0 to 63
12.4 MHz to 37.1 MHz
0 % to 30 %
0 to 7
0 to 31
2G+B+R, R, B, R+B, G, R+G, G+B, R+G+B
0 to 63
0 to 63
0 to 15
0 to 15
0 to 39
35
Initial value
OFF
A
A
0
0
0
0
0
0
OFF
A
A
0
0
0
0
0
0
0
0
0
0
0
0
OFF
A
A
0
0
0
0
0
0
0
0
0
0
0
0
22
22
10
23.6 MHz
0%
0
0
R+G
0
0
0
0
0
Table of adjustment setting ranges
Menu
Skin Tone Detail1
Skin Tone Detail2
Item
Skin Tone DTL
Skin Tone Get
Skin Tone Get
MEM Select
Cursor
H Cursor
V Cursor
ZEBRA
Effect MEM
Skin Tone DTL
MEM A
Skin Tone Crisp
Phase
Width
Saturation
MEM B
Skin Tone Crisp
Phase
Width
Saturation
Adjustment setting range
OFF, ON
EXECUTE (execution items)
CANCEL (execution items)
A, B
OFF, ON
1 to 1920
1 to 540
OFF, A, B, A+B
A, B, A+B
OFF, ON
—
–63 to 0 to +63
0 to 359
0 to 255
0 to 255
—
–63 to 0 to +63
0 to 359
0 to 255
0 to 255
36
Initial value
OFF
EXECUTE
CANCEL
A
OFF
960
270
OFF
A+B
OFF
—
0
0
0
0
—
0
0
0
0
Table of adjustment setting ranges
Maintenance
Menu
Date / Time (*4)
SD Card
Scene File
Item
Adjustment setting range
(Display item)
NO?, YES?
24H, 12H
Year
Month
Day
Day of week
Hours
Minutes
Seconds
NO?, YES?
NO?, YES?
FORMAT, LOAD, STORE
1 to 8
NO?, YES?
LOAD, STORE
OFF, 1 to 8 (when LOAD is selected)
1 to 8 (when STORE is selected)
NO?, YES?
LOAD, STORE
OFF, 01 to 16 (when LOAD is selected)
01 to 16 (when STORE is selected)
Enables a name (8 characters) to be set.
NO?, YES?
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
–100 to +100
NO?, YES?
NO?, YES?
—
OFF, ON
1 to 8 (*6)
0 to 100
0 to 100
NORMAL, (3/4), (2/4), (1/4)
1 to 25
NORMAL, ON
–40 to +40
Present
Adjust
12H, 24H
Date YY
Date MM
Date DD
Date aaa
Time HH
Time NN
Time SS
Set Exe
Reset
Mode
File No.
EXECUTE
Mode
File No
Lens File
EXECUTE
Mode
File No
Lens Edit
Option (*5)
Iris Cont.
File Name
EXECUTE
Gain R
Gain G
Gain B
Flare R
Flare G
Flare B
W H SAW R/G/B
W H PARA R/G/B
W V SAW R/G/B
W V PARA R/G/B
Store?
Cancel?
—
Auto Iris
Window Select
Iris Level
Peak Ratio
A.Iris Range
A.Iris Speed
LensExtComp.SW
LensExtComp.LVL
*4: If the date and time have not been set properly, the time may not be updated properly.
The clock has an error which may cause it to gain or lose up to one minute per month.
*5: The menu displayed differs depending on the type of option board installed.
*6: The types of windows which can be selected are as shown in the figure below.
1
2
3
4
5
6
7
8
37
Initial value
(Current date/time)
NO?
12H
(Current year)
(Current month)
(Current day)
(Current day of week)
(Current hours)
(Current minutes)
(Current seconds)
NO?
NO?
LOAD
1
NO?
LOAD
1
NO?
LOAD
01
(Filename)
NO?
0
0
0
0
0
0
0
0
0
0
NO?
NO?
—
OFF
1
50
60
NORMAL
15
NORMAL
0
Table of adjustment setting ranges
Menu
CINE Gamma
Item
Cinema Gamma SW
Cinema Gamma SEL
Black STR LVL
Dynamic LVL
Knee Point
Knee Slope
ASU
Tally Guard
G/L
Shutter
Filter
Setup Mode
REF File
M-PED Target
ASU Execute
Tally Guard
H Phase Coarse
H Phase Fine
SD-HD Phase CRS
SD-HD Phase Fine
HD-SD Phase CRS
HD-SD Phase Fine
SD-HD V Phase
SC Coarse
SC Fine
SC-H Coarse
SC-H Fine
Shutter
SYNCHRO
Mode
Adjustment setting range
OFF, ON
VIDEO_REC, FILM_REC
0 to +30
200 %, 300 %, 400 %, 500 %
+30 to +90
150 %, 200 %, 250 %, 300 %, 350 %, 400 %,
450 %, 500 %, 550 %, 600 %
REF, CURRENT
FULL (standard), EASY (simplified)
Factory, User1, User2, User3
0.0 % to 7.5 %
(execution items)
OFF, ON
–60 to +60 (during HD signal genlock)
–120 to +120 (during SD signal genlock)
–45 to +45
–4 to +4
–99 to +99
–8 to +8
–99 to +99
HD, SD
0 to 7
–255 to +255
0 to 7
–255 to +255
OFF, ON
OFF, ON
Fixed at SHUTTER
When SHUTTER is ON, SYNCHRO is OFF
100/125/250/500/1000/2000
Initial value
OFF
VIDEO_REC
+30
200 %
+30
When SHUTTER is ON, SYNCHRO is ON
60.9 Hz to 99.8 Hz
When SHUTTER is ON,
SYNCHRO is ON: 60.9
When SHUTTER is OFF, SYNCHRO is ON
60.9 Hz to 99.8 Hz
When SHUTTER is OFF,
SYNCHRO is ON: 60.9
When SHUTTER is OFF, SYNCHRO is OFF
100/125/250/500/1000/2000
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
(Display item)
50 i, 59.94 i
When SHUTTER is OFF,
SYNCHRO is OFF: 100
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
(Current value)
59.94 i
150 %
REF
FULL
Factory
5.0 %
READY?
OFF
0
0
0
0
0
0
SD
0
0
0
0
OFF
OFF
SHUTTER
When SHUTTER is ON,
SYNCHRO is OFF: 100
Speed
ROM Version
PLD Version
Format
CAM
B, U (*7)
TG
SHD
MEM
RET VF
AUX
CAMSYS
OPTION
Present
Format
*7: This is displayed when the buildup unit is connected.
38
SD memory card operations
These operations are performed on the SD Card page on the Maintenance menu.
The VF display settings and camera function settings on the Operation menu can be recorded on the SD memory card.
For details on what items are stored in the memory of the SD memory card, refer to “Table of the adjustment setting ranges.”
Mode: SD memory card operation mode setting
Select the SD memory card operation here.
Setting range: FORMAT, LOAD, STORE
FILE No.: File selection
Select the number of the file to be loaded or stored here.
Setting range: 1 to 8
 The files on the SD memory card have filenames which range from “3500cm01.dat” for File No.1 to
“3500cm08.dat” for File No.8.
 The SD memory card may not work properly if files have been edited using a personal computer or other device.
EXECUTE
The item set in “Mode” is executed here.
When the arrow cursor () is moved to EXECUTE and the JOG dial button is pressed, “No?” appears.
When the dial button is turned, “Yes?” appears.
When the dial button is pressed while “Yes?” is displayed, the selected operation is executed.
Conversely, when it is pressed while “No?” is displayed, the selected operation is canceled.
39
Download PDF

advertising
