Document
Scanner
Handy Guide
MG-M89 1009 Printed in Japan
Introduction
Faced with increasingly severe
market conditions, we focused our
efforts on finding ways to
determine the kind of business
scanner that today’s market
demands, by providing the
strongest assistance to businesses
in the age of IT. The result was an
entirely new concept that works
hand-in-hand with today’s
business tools, in a new and
expanded Panasonic business
scanner product line.
CONTENTS
ENTS
Panasonic Advantages
Panasonic Is a Leading Electronic Manufacturer.
Market Forecast
Why the Industry Requires Scanners
What Aspects Are Needed in Document Scanners?
The Answer Is Panasonic Premium Quality
4
6
7
8
9
Product Information
Comparison by Paper Volume
KV-S3105C, KV-S3085
KV-S4085CW/CL, KV-S4065CW/CL
KV-S5055C
KV-S3065CW, KV-S3065CL
KV-S7075C
KV-S2048C, KV-S2028C
KV-S1045C
KV-S1025C
KV-SS080
10
12
14
16
18
20
22
24
26
28
Features and Software
Main Features
Toughfeed
Image Processing Functions
30
40
42
Others
FAQ
Choose by Application
Choose by Business Type
Options and Consumables
02
50
56
58
64
03
Panasonic is globally
recognised for quality.
As a comprehensive
electronics manufacturer,
Panasonic has earned global
brand recognition. People
equate Panasonic with
quality in both consumer and
professional products.
2
Entire processes are
integrated, from the
development of materials to
the development of parts,
units and systems.
4
5
World Share No. 1
CIS
04
Company B
Company C
Company D
Company F
1644
26%
13%
Low environmental impact is
part of the performance.
Even when compared with
PCs and other office products,
there is widespread concern
about the power consumed by
scanners because they
operate for long periods of
time. Panasonic scanners
meet the standards of the
International Energy Star
Program, which testifies to their low power consumption and
resource-saving and recycling capabilities.
Panasonic has accumulated knowledge for more than 30
years in imaging and communications products such as
copy machines, fax machines, telephones and PBX
systems. We have also developed extensive
communication technologies for new infrastructure
applications, and key devices for imaging processes.
Africa
c
ca
1737
1729
Panasonic holds the No.2 rank for patent
applications in the World. As of 2008 Data(WIPO)
Over 30 years in imaging
and communications.
23%
Company A
Panasonic
Panasonic Advantages
1
3
No. 2 manufacturer
worldwide for patent applications
DOCUMENT SCANNER
Panasonic Is
a Leading Electronics
Manufacturer.
Universal Design simplifies
operation for all.
The use of Universal Design
principles makes it easy for
anybody, including beginners
and elderly users, to use
even complicated functions.
From its own, unique
viewpoint, Panasonic has
thoroughly pursued the goal of easy
asy use.
Universal
Design
05
Text-Based Information in the Market
Creating electronic data files from paper documents
(such as bills and statements)
Scanned paper documents and faxes
Documents that are important for business consideration
Documents that have been output from PCs
Articles from newspapers
Articles from magazines
Documents from meetings and other literature and
similar kinds of paper-based information
Using content from this kind of text-based information can be complicated if
it is not similarly managed and archived.
A large amount of office work time is spent searching for information.
Unit Shipments (U.S.A.)
Unit:K
700
Electronic Data
600
Audio data
Motion image data
Internet data ...
500
400
300
ECM (Enterprise Content Management) of Businesses
200
This refers to the
lifecycle management of
all content, from the time
it is generated until it is
disposed of.
100
0
2008
2009
2010
2011
Mid-volume
2.9k
2.8k
2.6k
Low-volume
23.6k
20.5k
18.1k
Departmental
62.2k
59.9k
60.8k
420.8k
423.3k
436.8k
460.4k
Workgroup
2.4k
2012
2013
2.4k
2.4k
16.9k
15.6k
14.4k
62.3k
64.4k
67.1k
490.4k
523.0k
Source: 2009 InfoTrend
Centralised management by converting information
into electronic data.
Text-Based Information
Electronic data
Video data
Recorded data,
Input
Production
Disposal
400
Development
(Obtaining)
300
200
100
0
Mid-volume
Low-volume
Departmental
Workgroup
06
Process
Save
2006
1.0k
2007
2008
1.3k
1.8k
Manage
Output
The Lifecycle Management of Text-Based Information
Unit Shipments (Europe)
Unit:K
Panasonic Advantages
Demand for document scannerss is
showing a growing trend centring
ng on
workgroups. Higher sales can bee
expected in this area as a future
growth market, when backed by new
product development and sales
promotion activities.
DOCUMENT SCANNER
Why the Industry
Requires Scanners
Market Forecastt
In order to accurately manage
the lifecycle of each type of
content among the vast amount
of text-based information of
each business, and to provide
management that allows easy
access when necessary...
2009
Store
3.7k
4.9k
7.1k
10.8k
10.5k
16.6k
19.4k
48.0k
79.4k
181.8k
267.7k
275.1k
221.8k
Source: FutureSource
Electronic Data Conversion with
Business Scanners Is Essential
07
Users want their document scanners to raise the
efficiency of their work. This calls for a number of
aspects, including high scanning speed, easy operation,
and energy-saving efficiency.
Panasonic Premium Quality is the key to fulfilling the
aspects that are required in document scanners.
Recognised around the world for quality, Panasonic
employs its advanced technical expertise to achieve
three main elements: Universal Design, Unique
Technology, and Ecology. These elements maximise
the efficiency of office work.
Qualit
Qualit
Quality
ual
uali
ualityy
Universal Design
Easy to understand and use, by anyone, anywhere.
Unique Technology
Multifunctional design, convenience, and quality
are better than the competition
High
Productivity
User
Friendliness
Eco
Friendly
08
High speed
High scanning precision
Enhanced functions
Malfunction resistance
Easy operation by anyone
Complete software
Easy maintenance
DOCUMENT SCANNER
The Answer Is
Panasonic Premium Quality
Panasonic Advantages
What Aspects Are Needed
in Document Scanners?
Ecology
Gentle on the environment.
Universal
Design
Unique
Technology
Ecology
Economical with minimal
waste
Gentle on the earth's
environment
A long life
09
100ppm
KV-S3085
KV-S3105C
KV-S4085CW
KV-S4085CL
Mid-volume
65-100ppm
KV-S7075C
Product Information
Hi-volume
Upgradeable
DOCUMENT SCANNER
Comparison by Paper Volume
Low-volume
KV-S3065CW
KV-S3065CL
KV-S50
KV-S5055C
51-75ppm
KV-S4065CW
KV-S4065CL
KV-S2028C
Departmental
KV-S2048C
KV
KV-S1045C
31-50ppm
Optional Flatbed
Scanner
KV-SS080
Workgroup
30ppm
K
KV-S1025C
10
11
130 ppm / 220 ipm
Maximum Paper Size
KV-S3105C
A3
Scanning Face
Scanning Method
Scanning Resolution
(KV-S3105C)
Paper Volume
100 ppm / 180 ipm
(KV-S3085)
*A4, Landscape, 200 dpi, Binary
Specifications
Letter
A4
Binary Speed
Letter
200 dpi
Portrait
A4
Letter
Landscape
*1
A4
Colour Speed
Letter
200 dpi
Portrait
A4
Hopper Capacity
1,000-sheet ADF
*1
*Business Card to A3 size
Main Features
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Long Paper Mode
• Curved Paper Path and Straight Paper Path
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Post-Imprinter
Landscape
MultiStream (bitonal & colour),
Binary mode, Greyscale mode,
Colour mode
Image output
Tonal Gradation (Bitonal mode)
Image Compression
Minimum
Maximum
Max. Scanning Page Size
Single Feed
Paper Thickness
Note: 1 mil = 1/1000 in. Continuous Feed
Single Feed
Continuous Feed
Paper Weight*4
Business Card
Interface
General
Dimensions (W x D x H)
Weight
Paper Size*3
Power Requirement
Scanning
Power Consumption Standby
Sleep Mode
Operating Environment
Storage Environment
546
(21.5)
627 (24.7)
mm (inch)
12
Duplex
190 ipm
180 ipm
166 ipm
160 ipm
170 ipm*2
165 ipm*2
166 ipm*2
160 ipm*2
• Control sheet
• Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (Ultrasonic method)
• Post Imprinter capability (Option)
Other Functions
415
(16.3)
KV-S3085
Duplex scanning
3-line colour CCD
100 to 600 dpi (1dpi step, optical 400 dpi)
Simplex
Duplex
Simplex
132 ppm
230 ipm
102 ppm
130 ppm
220 ipm
100 ppm
105 ppm
190 ipm
88 ppm
100 ppm
180 ipm
85 ppm
132 ppm
180 ipm
102 ppm*2
100 ppm*2
130 ppm
175 ipm
88 ppm*2
105 ppm
180 ipm
85 ppm*2
100 ppm
174 ipm
Up to 1,000 sheets (64 g/m2, 17 lbs.)
MultiStream (bitonal & colour)*2,
Binary mode, Greyscale mode,
Colour mode*2
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S3105C/KV-S3085
Dither, Error diffusion, Greyscale (8 bit), Binary
MH, MR and MMR for bitonal,
MH, MR and MMR for bitonal,
JPEG for colour and greyscale
JPEG for colour*2 and greyscale*2
48 x 70 mm (1.9 x 2.75 in.)
297 x 432 mm (11.7 x 17 in.)
302 x 2,540 mm (11.9 x 100 in.)
0.04 to 0.2 mm (1.6 to 7.9 mils)
0.06 to 0.2 mm (2.4 to 7.9 mils)
30 to 157 g/m2 (8 to 42 lbs.)
50 to 157 g/m2 (13 to 42 lbs.)
Thicker than 127 g/m2 (34 lbs.)
SCSI (68 pin) (Ultra wide) / USB 2.0
627 x 546 x 415 mm (24.7 x 21.5 x 16.3 in.)
52 kg (114.4 lbs.)
AC 100 - 120 V, 50/60 Hz
AC 220 - 240 V, 50/60 Hz
3.0 A (AC 100 - 120 V)
1.5 A (AC 220 - 240 V)
0.7 A (AC 100 - 120 V)
0.5 A (AC 220 - 240 V)
6.2 W or less (AC 100 - 120 V)
6.2 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 20 to 80 % RH
0 to 35 °C (32 to 95 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
*2 These specifications are available in case the Colour Upgrade Kit option (KV-SS029) is applied.
*3 The scanning size depends on the memory installed in the scanner.
*4 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
13
Maximum Paper Size
100 ppm / 200 ipm
(KV-S4085CW/S4085CL)
80 ppm / 160 ipm
(KV-S4065CW/S4065CL)
*A4, Landscape, 200/300 dpi,
Binary/Colour
A3 (KV-S4085CW/S4065CW)
A4 (KV-S4085CL/S4065CL)
Paper Volume
Specifications
KV-S4085CW/CL
Scanning Face
Scanning Method
Scanning Resolution
Letter
A4
Binary Speed*1
200 dpi/300 dpi Portrait Letter
A4
Letter
Landscape
*1
A4
Colour Speed
200 dpi/300 dpi Portrait Letter
A4
Hopper Capacity
Landscape
300-sheet ADF
*Business Card to A3 size
Main Features
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Long Paper Mode
• Curved Paper Path and Straight Paper Path
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Pre/Post-Imprinter
• Thin Paper Scanning
• Background Colour Switching
• Single-Sided Document Alignment
Duplex
160 ipm*3
160 ipm*3
130 ipm
120 ipm
160 ipm*3
160 ipm*3
130 ipm
120 ipm
• Control sheet • Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (KV-S4085CW/CL: 3 positions,
KV-S4065CW/CL: 1 position)
• Length control • Barcode detection (ISIS)
Other Functions
MultiStream (bitonal & colour, bitonal & greyscale),
Binary mode, Greyscale mode, Colour mode
Dither, Error diffusion, Greyscale (8 bit), Binary
Tonal Gradation (Bitonal mode)
Image Compression
JPEG for colour and greyscale
48 x 70 mm (1.9 x 2.75 in.)
Minimum
In manual feed or thick paper modes: 48 x 100 mm (1.9 x 3.9 in.)
Page Size*4
Maximum 297 x 432 mm (11.7 x 17 in.)
Image output
Max. Scanning Page Size
Paper Thickness
Note: 1 mil = 1/1000 in.
Interface
General
Dimensions (W x D x H)
Weight
Power Requirement
329
((13.0)
Scanning
Power Consumption
Standby
Sleep Mode
Operating Environment
Storage Environment
585
(23.0
(23.0)
474 (18.7)
mm (inch)
KV-S4085CL / KV-S4065CL: 227 x 2,540 mm (8.9 x 100 in.)
KV-S4085CW / KV-S4065CW: 302 x 2,540 mm (11.9 x 100 in.)
0.04 to 0.2 mm (1.9 to 7.9 mils)
Straight path: max. 0.6 mm (23.6 mils)
Thin mode: 20 to 50 g/m2 (5 to 13 lbs.) Normal mode: 50 to 157 g/m2 (13 to 42 lbs.)
Thick mode: 157 to 209 g/m2 (42 to 56 lbs.) Auto mode: 20 to 157 g/m2 (5 to 42 lbs.)
Paper Weight*5
14
Simplex
100 ppm*2
100 ppm*2
85 ppm
80 ppm
100 ppm*2
100 ppm*2
85 ppm
80 ppm
KV-S4065CW/CL
Duplex scanning
Hybrid CIS
100 to 600 dpi (1 dpi step)
Duplex
Simplex
200 ipm*2
80 ppm*3
*2
200 ipm
80 ppm*3
170 ipm
65 ppm
160 ipm
60 ppm
*2
200 ipm
80 ppm*3
*2
200 ipm
80 ppm*3
170 ipm
65 ppm
160 ipm
60 ppm
Up to 300 sheets (64 g/m2, 17 lbs.)
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S4085CW/CL, KV-S4065CW/CL
USB 2.0
474 x 585 x 329 mm (18.7 x 23.0 x 13.0 in.)
25 kg (55 lbs.)
AC 100 - 240 V, 50/60 Hz
1.5 A (100 - 120V)
1.4 A (100 - 120V)
0.7 A (220 - 240V)
0.6 A (220 - 240V)
0.7 A (100 - 120V)
0.7 A (100 - 120V)
0.4 A (220 - 240V)
0.4 A (220 - 240V)
5.3 W or less (AC 100 - 120 V), 5.3 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 20 to 80 % RH
0 to 40 °C (32 to 104 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
*2 Only for the KV-S4085CW.
*3 Only for the KV-S4065CW.
*4 The scanning size depends on the memory installed in the scanner.
*5 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR certification marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
15
90 ppm / 180 ipm
*A4, Landscape, 200 dpi,
Binary/Colour
Maximum Paper Size
Specifications
KV-S5055C
A3
Scanning Face
Scanning Method
Scanning Resolution
Paper Volume
Duplex scanning
3-line colour CCD
100 to 600dpi (1dpi step)
Letter
Binary/Colour Landscape
A4
Speed*1
Letter
Portrait
200 dpi
A4
Letter
Binary/Colour Landscape
A4
Speed*1
Letter
Portrait
300 dpi
A4
Hopper Capacity
200-sheet ADF
*Business Card to A3 size
Main Features
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Long Paper Mode
• Self Cleaning Functions
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Pre-Imprinter
• Thin Paper Scanning
• Background Colour Switching
• Single-Sided Document Alignment
• Double Feed Skip (DFS) Key
• Control sheet • Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (1 position)
• Pre Imprinter Capability (Option)
• Length control • Barcode detection (ISIS)
Other Functions
Image output
Tonal Gradation (Bitonal mode)
Image Compression
Minimum
Paper Size*2
Maximum
Max. Scanning Page Size
Paper Thickness
Note: 1 mil = 1/1000 in.
Paper Weight*3
Interface
General
Dimensions (W x D x H)
Weight
Power Requirement
Scanning
Power Consumption Standby
339
(13.4)
Sleep Mode
Operating Environment
Storage Environment
468 (18.5)
Simplex
Duplex
90 ppm
180 ipm
90 ppm
180 ipm
75 ppm
150 ipm
70 ppm
140 ipm
60 ppm
120 ipm
60 ppm
120 ipm
50 ppm
100 ipm
50 ppm
100 ipm
Up to 200 sheets (75 g/m2, 20 lbs.)
MultiStream (bitonal & colour, bitonal & greyscale),
Binary mode, Greyscale mode, Colour mode
Dither, Error diffusion, Greyscale (8 bit), Binary
JPEG for colour and greyscale
48 x 70 mm (1.9 x 2.75 in.)
297 x 432 mm (11.7 x 17 in.)
305 x 2,540 mm
(12.01 x 100 in.)
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S5055C
0.04 to 0.2 mm (1.6 to 7.9 mils)
20 to 157 g/m2 (5 to 42 lbs.)
USB 2.0
468 x 444 x 339 mm (18.5 x 17.5 x 13.4 in.)
18 kg (40 lbs.)
AC 100 - 120 V, 50/60 Hz
AC 100 - 240 V, 50/60 Hz
1.0 A (AC 100 - 120 V)
0.5 A (AC 220 - 240 V)
0.4 A (AC 100 - 120 V)
0.2 A (AC 220 - 240 V)
3.5 W or less (AC 100 - 120 V)
3.5 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 20 to 80 % RH
0 to 40 °C (32 to 104 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending
on the host computer, operating environment, or application.
*2 The scanning size depends on the memory installed in the scanner.
*3 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® is registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR certification marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
444
(17.5)
mm (inch)
16
17
70 ppm / 130 ipm
*A4, Landscape, 200/300 dpi,
Binary/Colour
Maximum Paper Size
Specifications
KV-S3065CW
A3 (KV-S3065CW)
A4 (KV-S3065CL)
Scanning Face
Scanning Method
Scanning Resolution
Paper Volume
Letter
A4
Binary Speed
Letter
200 dpi
Portrait
A4
Letter
Landscape
*1
A4
Colour Speed
Letter
200 dpi
Portrait
A4
Hopper Capacity
*1
300-sheet ADF
*Business Card to A3 size
Main Features
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Long Paper Mode
• Curved Paper Path and Straight Paper Path
• Easy Maintenance
• Double-Feed Prevention Roller System
• Plastic CIS Cover
• Auto Erasure Security
• Pre/Post-Imprinter
• Background Colour Switching
Landscape
Duplex
120 ipm
110 ipm
120 ipm
110 ipm
• Control sheet
• Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (Ultrasonic method)
• Pre or Post Imprinter Capability (Option)
Other Functions
Image output
Tonal Gradation (Bitonal mode)
Image Compression
Minimum
Paper Size*2
Maximum
Max. Scanning Page Size
Single Feed
Paper Thickness
Note: 1 mil = 1/1000 in. Continuous Feed
Single Feed
Paper Weight*3
Continuous Feed
Interface
General
Dimensions (W x D x H)
Weight
Power Requirement
Scanning
288
(11.3)
Simplex
70 ppm
70 ppm
65 ppm
60 ppm
70 ppm
70 ppm
65 ppm
60 ppm
KV-S3065CL
Duplex scanning
Hybrid CIS
100 to 600dpi (1dpi step)
Duplex
Simplex
130 ipm
130 ipm
120 ipm
65 ppm
110 ipm
60 ppm
130 ipm
130 ipm
120 ipm
65 ppm
110 ipm
60 ppm
Up to 300 sheets (64 g/m2, 17 lbs.)
Power Consumption Standby
Sleep Mode
Operating Environment
Storage Environment
MultiStream (bitonal & colour, bitonal & greyscale),
Binary mode, Greyscale mode, Colour mode
Dither, Error diffusion, Greyscale (8 bit), Binary
MH, MR and MMR for bitonal, JPEG for colour and greyscale
48 x 70 mm (1.9 x 2.75 in.)
297 x 432 mm (11.7 x 17 in.)
302 x 2,540 mm
227 x 2,540 mm
(11.9 x 100 in.)
(8.9 x 100 in.)
0.025 to 0.2 mm (1.0 to 7.9 mils)
0.06 to 0.2 mm (2.4 to 7.9 mils)
20 to 157 g/m2 (5.3 to 42 lbs.)
40 to 157 g/m2 (11 to 42 lbs.)
SCSI (50 pin) / USB 2.0
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S3065CW/CL
495 x 575 x 288 mm (19.5 x 22.7 x 11.4 in.)
24 kg (53 lbs.)
AC 100 - 120 V, 50/60 Hz
AC 220 - 240 V, 50/60 Hz
1.4 A (AC 100 - 120 V)
0.6 A (AC 220 - 240 V)
0.6 A (AC 100 - 120 V)
0.3 A (AC 220 - 240 V)
6.2 W or less (AC 100 - 120 V)
6.2 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 20 to 80 % RH
0 to 35 °C (32 to 95 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending
on the host computer, operating environment, or application.
*2 The scanning size depends on the memory installed in the scanner.
*3 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
575
(22.6)
495 (19.5)
mm (inch)
18
19
95 ppm / 190 ipm
*A4, Landscape, 200 dpi,
Binary/Colour
Maximum Paper Size
Specifications
KV-S7075C
A3
Paper Volume
Flatbed / 200-sheet ADF
Scanning Type
Scanning Face
Scanning Method
Scanning Resolution
Flatbed Scanning Speed
Letter
Landscape
A4
Binary Speed*1
Letter
200 dpi
Portrait
A4
Letter
Landscape
*1
A4
Colour Speed
Letter
200 dpi
Portrait
A4
Hopper Capacity
*Business Card to A3 size
Main Features
• High Speed Full Colour Scanning
• ADF/Flatbed Scanning
• Multi-Crop
• Duplex Scanning
• Mixed Document Feeding
• Single-Sided Document Alignment
• Long Paper Mode
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Pre-Imprinter
• Background Colour Switching
• Control sheet
• Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (Ultrasonic method)
• Pre Imprinter capability (Option)
Other Functions
Image output
Tonal Gradation (Bitonal mode)
Image Compression
Minimum
Paper Size
Maximum
Single Feed
Paper Thickness
Note: 1 mil = 1/1000 in. Continuous Feed
Single Feed
Continuous Feed
Paper Weight*2
Business Card
Interface
General
Dimensions (W x D x H)
Weight
Power Requirement
289
(11.4)
Scanning
Power Consumption Standby
Sleep Mode
Operating Environment
Storage Environment
755 (29.7)
508
(20.0)
A3 Flatbed+ADF
Duplex scanning
Hybrid CIS
100 to 600 dpi (1dpi step) (B/W and Colour) (Optical 600 dpi)
0.704 s (Letter, 200dpi), 320µ sec/line
Simplex
Duplex
95 ppm
190 ipm
95 ppm
190 ipm
80 ppm
160 ipm
75 ppm
150 ipm
95 ppm
190 ipm
95 ppm
190 ipm
80 ppm
160 ipm
75 ppm
150 ipm
Up to 200 sheets (64 g/m2, 17 lbs.)
Binary mode, Greyscale mode (8 bit), colour (24 bit),
MultiStream output
Dither, Error diffusion, Greyscale (8 bit), Binary
JPEG (Greyscale/Colour)
ADF 48 x 70 mm (1.9 x 2.75 in.)
ADF 302 x 2540 mm (11.9 x 100 in.)
Flatbed Max. 297 x 432 mm (11.7 x 17 in.)
0.05 to 0.15 mm (2.0 to 5.9 mils)
0.05 to 0.15 mm (2.0 to 5.9 mils)
40 to 127 g/m2 (11 to 34 lbs.)
40 to 127 g/m2 (11 to 34 lbs.)
Thicker than 127 g/m2 (34 lbs.)
USB 2.0
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S7075C
755 x 508 x 289 mm (29.7 x 20 x 11.4 in.)
29 kg (64 lbs.)
AC 100 - 120 V, 50/60 Hz
AC 220 - 240 V, 50/60 Hz
1.2 A (AC 100-120 V)
0.6 A (AC 220-240 V)
0.6 A (AC 100 - 120 V)
0.3 A (AC 220 - 240 V)
2.8 W or less (AC 100 - 120 V)
4.0 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 30 to 80 % RH
0 to 40 °C (32 to 104 °F), 10 to 80 % RH
*1 The scanning speed differs depending on the host computer, operating system, application, image data amount, and paper type.
*2 "Weight in pounds" of paper represents the weight of 500 sheets (432 x 559 mm / 17 x 22 in.)
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR certification marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
mm (inch)
20
21
Maximum Paper Size
41 ppm / 72 ipm
KV-S2048C
A4
Paper Volume
Simplex
Duplex
Simplex
A4
Duplex
Simplex
Letter
*1
Duplex
Colour Speed
Simplex
200 dpi
A4
Duplex
Automatic Document Feeder
Binary Speed*1
200 dpi
120-sheet ADF
(KV-S2028C)
*A4, Portrait, 200 dpi, Binary
*Business Card to A4 size
Main Features
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Easy Maintenance
• Double-Feed Prevention Roller System
• Space-Saving Installation
• Pre-Imprinter (KV-S2048C only)
• Background Colour Switching*
Letter
Image Output
Tonal Gradation (Bitonal mode)
Minimum
Maximum
Single Feed
Paper Thickness
Note: 1 mil = 1/1000 in. Continuous Feed
Single Feed
Paper Weight*3
Continuous Feed
Interface
General
Dimensions (W x D x H)
Weight
Paper Size*2
Power Requirement
Scanning
Power Consumption Standby
239
(9.4)
Sleep Mode
Operating Environment
Storage Environment
269
(10.6)
2966
(11.7)
11.77)
343 (13.5)
487
(19.2)
43 ppm
23 ppm
76 ipm
42 ipm
41 ppm
22 ppm
72 ipm
40 ipm
19 ppm
10 ppm
34 ipm
18 ipm
18 ppm
7 ppm
32 ipm
12 ipm
Up to 120 sheets (64 g/m2, 17 lbs.)
• Patch code detection (Type 2, 3, T) [ISIS] • Patch code detection (Type 2, 3, T) [ISIS]
• Double feed detection (Ultrasonic method) • Double feed detection (Ultrasonic method)
• Pre Imprinter capability (Option)
Other Functions
*The black background is standard, and the white background is optional.
KV-S2028C
Duplex scanning
CIS (Front and Back sides)
100 to 600dpi (1dpi step)
Scanning Face
Scanning Method
Scanning Resolution
(KV-S2048C)
22 ppm / 40 ipm
Specifications
Binary mode, Greyscale mode, Colour mode
Dither, Error diffusion, Greyscale (4/8 bit), Binary,
Note: Dither and Error diffusion are executed by driver or RTIV
50.8 x 70 mm (2.0 x 2.75 in.)
216 x 356 mm (8.5 x 14 in.)
0.05 to 0.15 mm (2.0 to 5.9 mils)
0.06 to 0.15 mm (2.36 to 5.9 mils)
40 to 127 g/m2 (11 to 34 lbs.)
50 to 127 g/m2 (13 to 34 lbs.)
USB 2.0
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S2048C/KV-S2028C
When tray is stored: 343 x 296 x 239 mm (13.5 x 11.7 x 9.4 in.)
9.1 kg (20.1 lbs.)
8.6 kg (19.0 lbs.)
AC 100 - 120 V, 50/60 Hz
AC 220 - 240 V, 50/60 Hz
1A (AC 100 - 120 V)
0.5 A (AC 220 - 240 V)
0.3 A (AC 100 - 120 V)
0.2 A (AC 220 - 240 V)
3.5 W (AC 100 - 120 V)
5.3 W (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 30 to 80 % RH
0 to 35 °C (32 to 95 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
*2 The setting of the paper length is possible to 25 inches in TWAIN, ISIS and RTIV. In case of a paper beyond legal size,
1 by 1 paper scanning in the resolution under 300 dpi is recommended.
*3 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR certification marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
343 (13.5)
mm (inch)
22
23
40 ppm / 80 ipm
*A4, portrait, 200 dpi, Binary/Colour
Maximum Paper Size
Specifications
KV-S1045C
A4
Scanning Face
Duplex scanning
Scanning Method
Scanning Resolution
Paper Volume
Letter
75-sheet ADF
Binary Speed*1
200 dpi
A4
*Business Card to A4 size
Letter
Colour Speed*1
200 dpi
Main Features
A4
Simplex
Duplex
Simplex
Duplex
Simplex
Duplex
Simplex
Duplex
Automatic Document Feeder
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Embossed Card Scanning
• Long Paper Mode
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Space-Saving Installation
Tonal Gradation (Bitonal mode)
Image Compression
80 ipm
40 ppm
80 ipm
Up to 75 sheets (80 g/m2, 20 lbs), 3 hard cards (ISO 7810 ID-1)
Dither, Error diffusion, Greyscale (8 bit), Binary
JPEG for colour and greyscale
Minimum
48 x 54 mm (1.9 x 2.13 in.)
Maximum
218 x 2540 mm ( 8.58 x 100 in.)
Max. Scanning Page Size
Single Feed
Continuous Feed
Paper Thickness
Single Feed
Note: 1 mil = 1/1000 in.
Single Feed mode
using Strait Path
Single Feed
Dimensions (W x D x H)
Weight
216 x 2,540 mm (8.5 x 100 in.)
0.05 to 0.2 mm (2.0 to 7.9 mils)
0.05 to 0.2 mm (2.0 to 7.9 mils)
Card: Up to approx. 0.76 mm (0.03 in.) in thickness + embossing
(ISO standard 7810 ID-1 card scanning including embossed card)
40 to 209 g/m2 (11 to 55 lbs.)
USB 2.0
With Stand: 317 x 209 x 196 mm (12.5 x 8.2 x 7.8 in.)
4.5 kg (9.9 lbs.)
Power Requirement
Scanning
Power Consumption
80 ipm
40 ppm
MultiStream (bitonal & colour or bitonal & greyscale),
Binary mode, Greyscale mode, Colour mode
Image Output
Paper Weight*3
Interface
General
80 ipm
40 ppm
• Control sheet • Patch code detection (Type 2, 3, T) [ISIS]
• Long paper mode
Other Functions
Paper Size*2
3-line colour CCD
100 to 600dpi (1dpi step)
40 ppm
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S1045C
Standby
Sleep Mode
AC 100 - 120 V, 50/60 Hz
AC 220 - 240 V, 50/60 Hz
38 W
23 W
5.3 W or less (AC 100 - 120 V)
5.3 W or less (AC 220 - 240 V)
Operating Environment
15 to 30 °C (59 to 86 °F), 20 to 80 % RH
Storage Environment
0 to 40 °C (32 to 104 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
*2 Though other paper size can be specified, it cannot be guaranteed.
*3 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
196
(7.8)
209 (8.2)
317 (12.5)
mm (inch)
24
25
25 ppm / 50 ipm
*A4, Portrait, 200 dpi, Binary/Colour
Maximum Paper Size
Specifications
KV-S1025C
A4
Scanning Face
Duplex scanning
Scanning Method
Scanning Resolution
Paper Volume
Letter
50-sheet ADF
Binary Speed*1
200 dpi
A4
*Business Card to A4 size
Letter
Colour Speed*1
200 dpi
Main Features
A4
Simplex
Duplex
Simplex
Duplex
Simplex
Duplex
Simplex
Duplex
Automatic Document Feeder
• High Speed Full Colour Scanning
• Duplex Scanning
• Mixed Document Feeding
• Embossed Card Scanning
• Long Paper Mode
• Easy Maintenance
• Double-Feed Prevention Roller System
• Auto Erasure Security
• Space-Saving Installation
• Detachable Stand
50 ipm
26 ppm
52 ipm
25 ppm
50 ipm
Up to 50 sheets (80 g/m2, 20 lbs), 3 hard cards (ISO 7810 ID-1)
MultiStream (bitonal & colour or bitonal & greyscale),
Binary mode, Greyscale mode, Colour mode
Image Output
Tonal Gradation (Bitonal mode)
Image Compression
Dither, Error diffusion, Greyscale (8 bit), Binary
JPEG for colour and greyscale
Minimum
48 x 54 mm (1.9 x 2.13 in.)
Maximum
218 x 2540 mm ( 8.58 x 100 in.)
Max. Scanning Page Size
Single Feed
Continuous Feed
Paper Thickness
Note: 1 mil = 1/1000 in. Single Feed
Single Feed mode
using Strait Path
*3
Single Feed
Paper Weight
Interface
General
Dimensions (W x D x H)
Weight
216 x 2,540 mm (8.5 x 100 in.)
0.05 to 0.2 mm (2.0 to 7.9 mils)
0.05 to 0.2 mm (2.0 to 7.9 mils)
Card: Up to approx. 0.76 mm (0.03 in.) in thickness + embossing
(ISO standard 7810 ID-1 card scanning including embossed card)
40 to 209 g/m2 (11 to 55 lbs.)
USB 2.0
With Stand: 317 x 218 x 196 mm (12.5 x 8.6 x 7.8 in.)
With stand: 4.2 kg (9.3 lbs.)
Power Requirement
Scanning
Power Consumption
52 ipm
25 ppm
• Control sheet
• Patch code detection (Type 2, 3, T) [ISIS]
Other Functions
Paper Size*2
3-line colour CCD
100 to 600dpi (1dpi step)
26 ppm
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-S1025C
Standby
Sleep Mode
Operating Environment
Storage Environment
AC 100 - 120 V, 50/60 Hz
AC 200 - 240 V, 50/60 Hz
32 W
22 W
7 W or less (AC 100 - 120 V)
7 W or less (AC 220 - 240 V)
15 to 30 °C (59 to 86 °F), 30 to 80 % RH
0 to 35 °C (32 to 95 °F), 10 to 80 % RH
*1 The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
*2 Though other paper size can be specified, it cannot be guaranteed.
*3 "Weight in ponds" of paper represents the weight of 500 sheets (432 x 559 mm /17 x 22 in.).
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
196
(7.8)
218 (8.6)
317 (12.5)
mm (inch)
26
27
3.6 sec
Maximum Paper Size
Specifications
KV-SS080
A4
Scanning Type
Scanning Method
Scanning Resolution
*A4, 200 dpi, Binary/Colour
Scanning Speed*
Paper Size
Interface
Power Requirement
Scanning
Power Consumption Standby
Sleep Mode
Main Features
Operating Environment
Storage Environment
• Flatbed Scanning
• 2-Page Separation
• Multi-Crop
Dimensions (W x D x H)
Weight
Flatbed
CCD
100 dpi to 600 dpi (1 dpi step) (B/W and Colour)
3.6 sec. (A4, 200 dpi) (B/W and Colour)
Maximum 216 x 297 mm (8.5 x 11.7 in.)
USB 2.0
AC 100 - 120 V, 50/60 Hz AC 200 - 240 V, 50/60 Hz
17 W
12 W
3.5 W or less
15 to 30 °C (59 to 86 °F), 30 to 80 % RH
0 to 35 °C (32 to 95 °F), 10 to 80 % RH
287 x 518 x 83.5 mm (11.3 x 20.4 x 3.3 in.)
3.4 kg (7.5 lbs.)
* The scanning speed depends on the test environment. The scanning speed may differ depending on the host computer,
operating environment, or application.
• ISIS® and Quick Scan are registered trademarks or trademarks of EMC Corporation in the United States and other countries.
• ENERGY STAR® and the ENERGY STAR marks are registered US marks.
• All product names are trademarks or registered trademarks of their respective holders.
• Specifications are subject to change without notice.
• Dimensions and weights are approximate.
Product Information
Scanning Speed
DOCUMENT SCANNER
KV-SS080 (Optional Flatbed Scanner)
Applicable Models
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
KV-S3065CW/CL
KV-S2048C
KV-S2028C
KV-S1045C
KV-S1025C
83.5
(3.3)
518 (20.4)
287 (11.3)
mm (inch)
28
29
Documents of different types are
scanned one after another
Unique Technology
Mixed Document Feeding
Excellent versatility
Unique Technology
Curved Paper Path and Straight Paper Path
Documents from business-card size all the way to A3* with a
variety of paper thicknesses can be fed at the same time ––
ideal for offices that handle a wide range of document types.
*Maximum paper size varies depending
on the models.
In addition to the ordinary curved path, a straight path
ensures high reliability with thick or long paper. The
possibilities for both usage and installation location
are almost unlimited.
DOCUMENT SCANNER
Main Features
*Separately movable left and right guides are provided only on the
KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C, and KV-S7075C.
[ Curved path ]
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C,KV-S2048C, KV-S2028C
[ Straight path ]
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S3065CW/CL,
KV-S1045C, KV-S1025C
Even documents of unusually
long sizes can be scanned
Maintenance costs and
downtime are reduced
Applicable Models*
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C, KV-S2048C, KV-S2028C,
KV-S1045C, KV-S1025C
Unique Technology
Long Paper Mode
The highly reliable paper feed system lets you scan long size
documents. This is ideal for scanning electrocardiograms
(EKG) or other special documents. This single scanner handles a
wide variety of applications.
Applicable Models
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C,KV-S1045C, KV-S1025C
30
Curved path
Straight path
Features and Software
Applicable Models
Universal Design
Easy Maintenance
The design allows full, easy access to the entire paper path, so
you can clear paper jams or clean the unit without calling a
service centre. The rollers last a long time and are easy to
replace when worn, also improving the unit's cost-effectiveness.
Applicable Models
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C, KV-S2048C, KV-S2028C,
KV-S1045C, KV-S1025C
31
Double-Feed Prevention Roller System
This double-feed prevention roller system is used to
ensure reliable scanning of large amounts of documents.
It reduces double-sheet feeding by separating the
documents from the second sheet onward.
Applicable Models
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C, KV-S2048C,
KV-S2028C, KV-S1045C,
KV-S1025C
Unique Technology
A high degree of safety
Auto Erasure Security
Scanned data is automatically erased
from the scanner memory as soon as
scanning is completed. This basically
eliminates the danger of information
leaks, and ensures the user of safe,
secure scanning.
Applicable Models
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C,
KV-S3065CW/CL, KV-S7075C, KV-S1045C, KV-S1025C
Separation Roller
Feed Roller
Unique Technology
Raises filing efficiency
Features and Software
Unique Technology
Prevent scanning mis-feeds
DOCUMENT SCANNER
Main Features
Pre / Post Imprinter
With the optional imprinter mounted, special characters such as
"group A " can be printed onto documents. This helps to prevent
pages from being missed when scanning, and raises filing reliability.
Double Feed
Prevention Roller
Feed Direction
What's a pre-imprinter?
The pre-imprinter prints text on the
surface of a document before its
image is scanned, so the text data is
included in the scanned image data.
What's a post-imprinter?
The post-imprinter prints text on the
back side of a document as the image
is being scanned, so the text data is
not included in the image data.
Front Side
Front Side
Front Side Only
Back Side
Text is printed on the
surface of the document
Text is included in
the image data
Scanned documents
Image data
Text is printed on the
back side of the
document
Scanned documents
Text is not included
in the image data
Image data
Applicable Models
[ Pre/Post ] KV-S4085CW/CL, KV-S4065CW/CL, KV-S3065CW/CL
[ Pre ]
KV-S5055C, KV-S7075C, KV-S2048C
[ Post ]
KV-S3105C, KV-S3085
32
33
Unique Technology
Thin Paper Scanning
For scanning books, drawings and
other special documents
Universal Design
Flatbed Scanning
Now you can continuously scan documents that are as thin as
0.04 mm. That makes it easy to scan thin forms or vouchers. And it
increases the number of situations
where you can use scanning without worrying about thin paper.
Applicable Models
KV-S4085CW/CL, KV-S4065CW/CL,
*When the KV-SS027 roller is mounted, it is possible
KV-S5055C, KV-S3105C*
to scan sheets up to a thickness of 0.05 mm.
Prevent backside images
from showing through
Unique Technology
Books, bound materials, large drawings and other documents that
cannot be fed through the Auto Document Feeder (ADF) can be
scanned with flatbed scanning.
g The scanner is also equipped
q pp with
a Start button, so work efficiency
ncy
can be increased by quickly
scanning while turning the
book's pages, with no PC
operation necessary.
Applicable Models
KV-S7075C, KV-SS080
Background Colour Switching
Background colour can be switched to black or
white. Black allows the de-skewing function to
correct skewed data, and white prevents backside images from being
visible when using thin paper, to ensure beautiful scanning quality.
Applicable Models
KV-S3105C, KV-S3085, KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C,
KV-S3065CW/CL, KV-S7075C, KV-S2048C, KV-S2028C
Easy scanning of mixed size documents
Hassle free consecutive scanning
Features and Software
No more worries about scanning thin paper
DOCUMENT SCANNER
Main Features
Unique Technology
ADF / Flatbed Scanning
Now you can consecutively scan ADF and flatbed documents
in one simple operation, greatly improving work efficiency.
Unique Technology
Place
documents
in ADF
Single-Sided Document Alignment*
You can enjoy smooth scanning by aligning either the right side
or the left side of the documents. This lets you simultaneously
set various sizes of documents for scanning.
*Effective scanning width varies depending on the models.
Left alignment
Centre alignment
Setting
Position
Applicable Models
34
Place a book
on Flatbed
Right alignment
KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C,
KV-S7075C
Applicable Models
KV-S7075C
35
Eliminates the need for maintenance
Unique Technology
Self Cleaning Functions
Unique Technology
Double Feed Skip (DFS) Key
Feed Direction
The paper feed rollers separate from the paper each time a sheet is
fed, so the tendency to double-feed caused by the paper feed roller
pressure is reduced, even when feeding paper of different thicknesses.
Any paper sliding is also detected and the double feed prevention roller
pressure is adjusted to prevent the paper from slipping and jamming.
Ionizer
Scanning
Glass
Features and Software
Ionizer
The ion-filled breeze created by the
ionizer neutralizes the electrical charge
on the documents to be scanned, and
reduces the amount of paper dust that
clings to their surface. This ion-filled
breeze also flows through the paper
path and removes paper dust from the
scanning glass to reduce the need for
the user to clean the glass.
Resume scanning
even when double-feeding is detected
Applicable Models
KV-S5055C
Scanning Glass Cleaning Brush
The brush directly cleans the scanning glass to further prevent
paper dust. This eliminates the need for maintenance and
ensures comfortable scanning operations.
DOCUMENT SCANNER
Main Features
Documents for Which Scanning Shouldn't Be Stopped
Even When Double-Feeding Is Detected
Scanning
Glass
Cleaning
Brush
Envelopes
Documents with Sticky Notes Attached
Scanning Glass
Applicable Models
KV-S5055C
36
37
Universal Design
Reduces the time spent on pre-sorting
Embossed Card Scanning
Space-Saving Installation
The retractable tray saves storage space when the scanner is
not in use. Simply place the scanner on the counter and a desk,
and use when needed. The space-saving design helps to
achieve an efficient usage environment.
Applicable Models
These scanners are designed
to combine paper documents
along with an embossed card,
such as a driver's license, in a
single batch. You can even
scan a stack of hard cards,
including embossed cards,
continuously via the auto
document feeder.
Applicable Models
KV-S2048C, KV-S2028C, KV-S1045C, KV-S1025C
Angled for easy paper feeding
KV-S1045C, KV-S1025C
Unique Technology
Features and Software
The scanner can be installed
just about anywhere
DOCUMENT SCANNER
Main Features
Universal Design
Detachable Stand
The detachable stand is a standard feature, and can be used or
detached to match the application and available space. When the
scanner is installed facing forward with the stand attached, the
angled paper feed section simplifies document setting. When
installed in its more compact configuration, facing crosswise with
the stand detached, long documents can easily be set in position.
With stand
Applicable Models
38
Without stand
KV-S1025C
39
Applicable Models
KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C
Preventing damage to the scanning glass
Stapled Document Detection
Multiple sensors are used to detect various types of stapled documents,
and to immediately stop the scanner when stapling is detected. This
minimises damage to both the document and the optical glass.
Smooth feeding
Intelligent Feed Control*
Multiple sensors check the paper
feed condition and automatically
adjust the roller pressure to ensure
that documents of various
thicknesses are accurately fed. This
makes it more reliable and accurate
than conventional methods that use
only the feed mechanism.
Checking
Multiple
Sensors
Paper feed roller
Documents
Feeding
direction
Checking
feed
condition
Tray
Multiple sensors constantly check
the condition of the paper feed and
the pressure between the document
and the roller.
Adjusting
Staple position example
1
2
Insufficient
pressure
Features and Software
ToughFeed helps to prevent the unnecessary interruption of scanning
work due to an equipment malfunction or double feeding that can
otherwise result in un-scanned sheets, thus ensuring high work efficiency.
DOCUMENT SCANNER
ToughFeed
Automatically
raised
Corner Staple
Side Staple
The sensors detect when the
paper feed is not correct due to
insufficient pressure.
The tray is raised to adjust the
pressure and accurately feed the
document.
*Only for the KV-S4085CW/CL, KV-S4065CW/CL
Top-centre Staple
Bottom-centre Staple
Prevents scanning mis-feeds
Accurate scanning
Superior Roller Mechanisms*
Ultrasonic Double-Feed Detection
Ultrasonic sensors detect double feeds.
The KV-S4085CW and KV-S4085CL
are equipped with three ultrasonic
sensors* to cover a larger area of the
document, rather than the centre only,
for versatile detection of things like
sticky notes or small documents mixed
among regular-sized documents.
40
Feed direction
Transmitter
Small
document
Receiver
Document to be scanned
High-performance sensors catch
even subtle changes.
*The KV-S4065CW/CL and KV-S5055C
have only one ultrasonic sensor.
The paper feed rollers separate from the paper each time a sheet is fed, so the tendency
to double-feed caused by the paper feed roller pressure is reduced, even when feeding
paper of different thicknesses. Any paper sliding is also detected and the double feed
prevention roller pressure is adjusted to prevent the paper from slipping and jamming.
*Only for the KV-S5055C
Separation Roller
Paper Feed Roller
The paper feed roller
separates from the paper
each time a sheet is fed.
Double Feed
Prevention Roller
When paper sliding is
detected, the double feed
prevention roller
pressure is increased.
41
*1 Image Capture Plus is bundled with the KV-S5055C. Image Capture Plus is not sold alone.
*2 RTIV is bundled with the KV-S3105C, KV-S3085, KV-S4085CW/CL, KV-S4065CW/CL,
KV-S3065CW/CL, KV-S7075C, KV-S2048C, KV-S2028C, KV-S1045C, and KV-S1025C.
RTIV is not sold alone.
No more need to pre-sort documents
Automatic Binary / Colour Distinction
This function automatically detects when a set of documents
contains some colour sheets and some monochrome (B/W)
sheets. You can feed these together without sorting, and the
machine will automatically compress the data efficiently
according to whether a sheet is colour or monochrome (B/W),
so the electronic file size is minimised. This is a feature typically
found only on high-end scanners.
B/W documents
OFF
OFF
Automatic Image Orientation
Even when documents are set in different directions, this
function detects the direction of the scanned text in documents
and automatically rotates it into the correct direction. This
boosts work efficiency by eliminating the need to change the
direction of each page in advance when scanning large
quantities of documents with various sizes and directions.
With this function
Without this function
B/W Scan Setting
Colour documents are also scanned
in black and white, making them
difficult to understand.
No more worries about the document's direction
Full-Colour Scan Setting
B/W documents are also scanned
in colour, resulting in large image
file sizes.
ON
Colour documents
Documents
Colour and B/W documents
are automatically detected,
and the scanning method is
changed accordingly.
Image are stored using the
most suitable method.
Features and Software
Panasonic high-speed scanners are bundled with Image
Capture Plus*1 software or Reliable Throughput Image Viewer*2
(RTIV) software, which both include a variety of image
processing functions. These software applications let you
efficiently create high-quality image files with simple PC
operation.
DOCUMENT SCANNER
Image Processing Functions
Image data
Two-in-one convenience
Double Exposure
Double Exposure automatically scans then saves two-sided
documents into a single-page file. It is highly effective for
documents printed on both sides, such as checks, stock
certificates, post cards, and business cards.
Front Side
Back Side
Documents
42
Image data
43
No need to make manual adjustments
Blank Page Removal
Automatic De-Skew
When scanning a set of documents that contains both single-sided
and double-sided sheets, this function automatically skips over the
blank sides. It saves you time and trouble by eliminating the need to
sort the sheets beforehand or remove the blank data after scanning.
It also helps reduce wasted memory space in your computer.
When scanning documents of different sizes, any that are
accidentally scanned at an angle are automatically corrected by
de-skewing. This also boosts work efficiency by eliminating the
need to worry about skewed pages while scanning.
OFF
1
1
Skewing prevents the
entire document from
being scanned.
2
2
4
3
3
Removed
4
ON
Documents
Documents
Image data
Image data
No more scan mistakes or time-consuming trimming
Automatic Crop
Convenient for OCR processing
Multi Colour Dropout*
Different sized documents can be scanned each according to its own
size. This raises work efficiency by preventing size setting mistakes
and eliminating the need to later crop scans to the desired size.
When set to A4 size...
A4
Even when the
document is skewed,
it is scanned at the
necessary size, and
then the skewing is
corrected.
Features and Software
You can convert only the desired pages
into electronic form
DOCUMENT SCANNER
Image Processing Functions
A4
B5
OFF
Any of up to three specific colour ranges on the document can
be selected as a dropout colour. This function, when used in
form processing applications, can greatly improve OCR
performance and accuracy, resulting in increased productivity
and potential cost savings.
*Not applicable for the KV-S2048C, KV-S2028C.
Check
Image quality depends on the document size.
B5
Check
Co
nf
ON
id
en
tia
A4
l
B5
Check
The document size is automatically detected,
so all documents are scanned at the most
appropriate size.
Documents
44
Image data
Documents
Image data
45
Punch holes from the document are removed
from the image
Excellent readability and accuracy
Dynamic Threshold
With the Dynamic Threshold function, the background density and
colour are automatically detected section by section, and the scan
setting (brightness control) is automatically adjusted to ensure sharp
scanning of both text and images.
Dynamic Threshold
Dynamic Threshold
The Hole Removal function removes the punch hole marks from
the scanned image. Round or square black shapes around the
edges are replaced with the colour closest to the document. You
don't have to cover them up with tape beforehand or use image
editing after scanning.
With the Dynamic Threshold function, the background density and colour are automatically detected section by section,
and the scan setting (brightness control) is automatically adjusted to ensure sharp scanning of both text and images.
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
abcde
Documents
Image data
Documents
Image data
Features and Software
With the Dynamic Threshold function, the background density and colour are automatically detected section by section,
and the scan setting (brightness control) is automatically adjusted to ensure sharp scanning of both text and images.
Hole Removal
DOCUMENT SCANNER
Image Processing Functions
No more fuzzy backgrounds
Single pass for dual output
Smooth Background
Multi Stream*
The Multistream function enables a single scan to be saved as two
separate formats simultaneously. For example the document will be
saved in monochrome (B/W) for OCR and archival purposes, and
saved as a full colour image for short term on-screen retrieval.
The Smooth Background function analyses images while
scanning for background colour content, and outputs the
images with the background colour solidified. This increases
viewing clarity and reduces JPEG output file size.
*Not applicable for the KV-S2048C, KV-S2028C.
B/W
Colour
OFF
The fuzzy background makes the
document unclear, and increases
the output file size.
&
Scanner
Documents
Two separate image formats are
simultaneously saved from a single scan.
Image data
Documents
Scanner
ON
Scanner
The background is solidified for
greater clarity, and the output file
size is reduced.
Image data
46
47
2-Page Separation
Use the flatbed to scan 2-page spreads from books, magazines, etc.,
and automatically divide the single image into two single sheets*.
Dividing scanned documents saves time and trouble because it
makes complex editing operations unnecessary.
* Divided lengthwise or crosswise. The length of the scanned document is divided in half.
The division is not based on the content of the document.
Easy Data Management
Job Function
The Job function lets you set the file format for saving each job, and
sorts scanned documents into the specific folder of the person in
charge. This is especially helpful for people who regularly manage a
large volume of documents, and people who want easy, folder-based
management.
Scanned images can be automatically saved by specifying
the file format and destination.
Place document in ADF
TIFF
JPEG
Bitmap
PDF
Place a book on Flatbed
Save time by reducing the number of scans
Multi-Crop
Place various sized documents on the flatbed and scan them all at
once, then crop whatever parts you need. This is convenient for
scanning multiple business cards and thick documents.
Features and Software
Easily get the data you need from each page
DOCUMENT SCANNER
Image Processing Functions
Job setting lets you sort files and folders on a group by group basis,
and save the images into them.
RTIV
Document001
001.pdf
Document002
001.pdf
Document003
001.pdf
Document004
001.pdf
Place on Flatbed
48
49
Model #
USB
KV-S3105C
2.0
KV-S3085
KV-S3065CW
KV-S3065CL SCSI
KV-S7075C
KV-S4085CW
KV-S4085CL
KV-S4065CW
KV-S4065CL
KV-S2048C
KV-S2028C
KV-S1045C
KV-S1025C
KV-S5055C
Win
2000
Win
XP
Yes
Yes
Yes
Yes
Win
XP
Win
Vista
Win
7
No
Yes
Yes
No
Yes
No
(64bit)
of component software applications
and component development tools
used to build production-level
document imaging solutions for the
PC LAN environment. Panasonic's
line of high-speed scanners is
compatible with KOFAX VRS.
Others
What PC OS is available for the
Panasonic High Speed scanners?
DOCUMENT SCANNER
FAQ (1)
What KOFAX products are certified
for Panasonic High Speed scanners?
Yes
Yes
No
Yes
Yes
No
Yes
No
Yes
Yes
What is KOFAX?
Applicable Models:
KV-S3105C, KV-S3085,
KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL,
KV-S7075C, KV-S2048C,
KV-S2028C, KV-S1045C,
KV-S1025C
VRS Version: VRS 4.50 SP1
Kofax Express Version: 2.0 SP1
KOFAX is a privately held California
corporation established in 1985 to
create and market hardware and
software products needed to bring
document image processing
technology onto personal computer
platforms. Today the company is one
of the industry's leading developers
50
51
ISIS stands for Image and Scanner
Interface Standard. ISIS, a de facto
standard created by Pixel
Translations (present EMC
Corporation) is a system of software
modules, each of which performs a
specific image related function. ISIS
modules are available to control
scanners and printers, assist in the
viewing of images, compress and
convert the format of image data, and
read or write files containing data.
All current Panasonic High Speed
scanners come bundled with high
performance ISIS Certified drivers.
What is TWAIN?
TWAIN stands for Technology Without
Any Interesting Name. TWAIN defines
a standard software protocol and
application-programming interface
(API) for communication between
software applications and image
acquisition devices. All current
Panasonic High Speed scanners
come bundled with TWAIN drivers.
52
Model #
Recommended Daily Duty Cycle (sheets/day)
KV-S3105C
Unlimited
KV-S3085
Unlimited
KV-S4085CW
KV-S4085CL
up to 40,000
KV-S7075C
KV-S4065CW
KV-S4065CL
up to 20,000
KV-S5055C
KV-S3065CW
KV-S3065CL
up to 10,000
KV-S2048C
up to 6,000
KV-S2028C
up to 4,000
KV-S1045C
KV-S1025C
up to 2,000
Others
What is recommended Daily Duty
Cycle for Panasonic Scanners?
What is ISIS?
DOCUMENT SCANNER
FAQ (2)
This information is for your reference to select a model from the product
lineup. It does not indicate a durability of each model.
What is the MTBF for Panasonic
Scanners?
18,000Hours (Only for Electric Parts)
53
Model #
Roller part #
Recommended replacement cycle
KV-S4085CW
KV-S4085CL
KV-S4065CW
KV-S4065CL
KV-SS033
400,000 sheets scanning
KV-S5055C
KV-SS039
350,000 sheets scanning
KV-S3105C
KV-S3085
KV-SS026
KV-SS027
KV-S3065CW
KV-S3065CL
KV-SS017
KV-SS018
KV-S7075C
KV-SS015
KV-S2048C
KV-S2028C
KV-SS024
KV-SS025
KV-S1045C
KV-S1025C
KV-SS035
300,000 sheets scanning
Double-feed prevention
roller
100,000 sheets
scanning
Paper feed roller
100,000 sheets
scanning
How often should I clean the
scanner paper feed rollers?
To ensure optimal scanning
performance, the paper feed rollers
should be cleaned once a week or
when 20,000 sheets or more are fed
into the unit. In an environment
where NCR paper is used, it is
54
recommended that the paper feed
rollers are cleaned on a daily basis.
Treated papers, like NCR paper,
contain chemicals that cause rollers
to deteriorate at an accelerated rate,
requiring roller replacement much
sooner than scheduled. A good daily
cleaning of the paper feed rollers
with isopropyl alcohol will help to
prolong the life of the rollers in this
harsh environment.
Others
What is recommended
replacement cycle for each roller
exchange kit?
DOCUMENT SCANNER
FAQ (3)
Why is my scanner double-feeding
paper?
Document double feeding may be
caused by dirty rollers. Just like your
car, your scanner needs routine
maintenance. Regular cleaning and
maintenance of your scanner will
protect your investment, maximize
scanner performance, and provide
you with the best insurance against
costly downtime. Please refer to your
operation manual for instructions on
cleaning your scanner.
55
01
Deskside Scanning
A compact scanner can be installed
and used just about anywhere, like on
the reception counter for everyday
use, or even right on a desktop.
Applicable Models
02
KV-S2048C, KV-S2028C, KV-S1045C,
KV-S1025C
Card Scanning
Reception tasks often include the need for scanning cards, such as
driver's licenses, credit cards, and insurance certificates. For this
kind of application, we recommend a
model with the Multiple ID Card
Feeding function, which scans up to
embossed hard cards at a time.
Applicable Models
04
Thin-Paper Scanning
Companies that often need to scan receipts or
other forms that use thin paper will appreciate a
model with the Thin-Paper Scanning function.
These models provide smooth scanning for even
large volumes of thin-paper documents.
Applicable Models
05
Mixed-Size Document Scanning
You get stable, steady scanning even for
different-sized documents. This greatly reduces
the need for storage space, because you can
store the results in data form instead of paper,
and it simplifies information management.
Applicable Models
06
If you want to cut down on the mountains of
paper that accumulate each day at your worksite,
you'll appreciate a model with a large scanning
capacity. These models convert large volumes of
paper documents to data quickly and easily.
KV-S1045C, KV-S1025C
Long Paper Scanning
Models with the Long Paper Scanning
function make it fast and easy to scan long,
special paper types, such as data at R&D
centres or electrocardiograms at hospitals.
Applicable Models
56
KV-S3105C, KV-S3085, KV-S4085CW/CL,
KV-S4065CW/CL, KV-S5055C, KV-S3065CW/CL,
KV-S7075C, KV-S1045C, KV-S1025C
All Models
Large-Volume Scanning
Applicable Models
03
KV-S4085CW/CL, KV-S4065CW/CL, KV-S5055C
Others
Panasonic document scanners allow users to select the
optimal model to match their application. Here, we introduce
applications for several typical features, and show the models
that are applicable to each.
DOCUMENT SCANNER
Choose by Application
07
KV-S3105C, KV-S3085, KV-S4085CW/CL, KV-S4065CW/CL,
KV-S5055C, KV-S3065CW/CL
Book Scanning
Flatbed scanners are the answer for
scanning books or other thick documents.
You get beautiful scanned results by simply
placing the document on the scanning glass,
just like you do with a copy machine.
Applicable Models
KV-S7075C, KV-SS080(A4)
57
02- Finance
Hospitals, dental clinics, healthcare centres
and other medical organisations handle a
wide range of paper documents, such as
appointment slips, health insurance
information, medical records and
prescriptions for patients and outpatients.
Long-term storage and management of contracts and checks
can require enormous amounts of time and effort for
financial institutions and insurance companies that deal with
huge amounts of customer information. With their easy
digital filing, scanners promote paperless document
management. Conversion to digital data also allows easy
searching and retrieval of information whenever needed.
Panasonic Provides the Following Functions to Help
Streamline Your Medical Information Management
Panasonic Provides the Following Functions to Help
Streamline Your Financial Information Management
A Mixed-Document Feeding
Continuously scans documents of various sizes.
A High-Speed, High-Volume Scanning
Scans a large amount of documents at high speed.
B Multiple Hard ID Card Scanning
Scans three cards one after the other, such as ID
cards, insurance cards and embossed cards.
B Mixed-Document Feeding
Continuously scans documents of various sizes.
C Double Exposure For ID Cards
Displays both sides of a card on the same screen.
Image data
Front
Back
Others
01- Health Care
DOCUMENT SCANNER
Choose by Business Type
C Automatic Cropping and De-Skewing
The De-skewing function adjusts images scanned at an
angle, and the Cropping function properly trims the images.
D Ultrasonic Double-Feed Detection
Detects double-feeding instantaneously.
D Blank Page Removal
Removes documents with a blank back page from data to
simplify document management and improve search efficiency.
E Supports Long Paper Scanning
Saves long documents such as
electrocardiogram records.
E Flatbed Scanning
For scanning books, drawings, and other
special documents.
Removed
F Small Footprint
The compact unit size enables easy setup on
a desktop.
Recommended Models
Recommended Models
58
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
KV-S2048C
KV-S2028C
A B C D E F
A B C D E F
A B C D E F
KV-S1045C
A B C D E F
KV-S3105C
KV-S3085
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
A B C D E
A B C D E
A B C D E
KV-S1025C
KV-S3065CW/CL
KV-S7075C
A B C D E F
A B C D E
A B C D E
59
04- Government
For the offices of service bureaus, quick and
accurate scanning of large volumes of documents
received from clients is a key to securing profits.
Scanners can convert paper documents into digital
data quickly and accurately. They help to improve
work efficiency, which leads directly to profits.
Government and other public offices handle a wide
range of paper documents, such as application forms,
permissions, certificates and licenses. These
documents contain various types of personal
information. Converting them into digital data with a
scanner significantly improves the information
management efficiency, and digital data can be shared
on-line with other government offices and local offices.
Panasonic Provides the Following Functions to Help
Streamline Your Service Bureau Management
A High-Speed, High-Volume Scanning
Panasonic Provides the Following Functions to Help
Streamline Government Office Work
Scans a large amount of documents at high speed.
A High-Speed, High-Volume Scanning
Scans a large amount of documents at high speed.
B Mixed-Document Feeding
Others
03- Service Bureau
DOCUMENT SCANNER
Choose by Business Type
Continuously scans documents of various sizes.
B Mixed-Document Feeding
Continuously scans documents of various sizes.
C ToughFeed
Detects stapled documents to minimise damage to the
documents and equipment.
C ToughFeed
D Ultrasonic Double-Feed Detection
Detects double-feeding instantaneously.
Detects stapled documents to minimise damage to
the documents and equipment.
E Straight Paper Path
Scans thick-paper or long paper documents.
D Blank Page Removal
Removes documents with a blank back page from data to
simplify document management and improve search efficiency.
F Automatic Cropping and De-Skewing
E Automatic Memory Erase
Automatically deletes data in the scanner memory to
ensure high information security.
Co
nf
id
en
tia
G Multi Colour Dropout
l
The De-skewing function adjusts images scanned at an angle,
and the Cropping function properly trims the images.
Removes unnecessary lines and backgrounds in order to
improve OCR accuracy. * KV-S3085 is required optional Colour Upgrade Kit.
Removed
H Flatbed Scanning
F Flatbed Scanning
For scanning books, drawings, and other
special documents.
For scanning books, drawings, and other special documents.
Recommended Models
Recommended Models
KV-S3105C
KV-S4085CW/CL
KV-S5055C
KV-S3085
KV-S4065CW/CL
A B C D E F G H A B C D E F G H A B C D E F G H
KV-S3065CW/CL
KV-S7075C
A B C D E F G H A B C D E F G H
60
KV-S3105C
KV-S3085
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
A B C D E F
A B C D E F
A B C D E F
KV-S3065CW/CL
KV-S7075C
KV-S2048C
KV-S2028C
A B C D E F
A B C D E F
A B C D E F
61
06- Office
The large number of delivery slips produced each
day are easily managed when they are converted
into digital data by a scanner. In addition, when
OCR software is used in combination,
handwritten information on slips can be easily
converted into digital data to enable its use for
delivery information searching on the Web.
he General Affairs Department and Legal Department of a company
regularly handle contracts and application forms containing personal
information and confidential company information as well as documents
related to intellectual property, while the Accounting Department manages
customer information and internal-use-only documents pertaining to
company management on a daily basis. Converting these documents into
digital data by using a scanner not only allows more effective use of office
spaces but also enables easier searching and quicker retrieval of data.
Panasonic Provides the Following Functions to Help
Streamline Your Transport Business
Panasonic Provides the Following Functions to Help
Streamline Your Document Management
A High-Speed, High-Volume Scanning
A High-Speed, High-Volume Scanning
Scans a large amount of documents at high speed.
Scans a large amount of documents at high speed.
Others
05- Transporter
DOCUMENT SCANNER
Choose by Business Type
B ToughFeed
B Mixed-Document Feeding
Continuously scans documents of various sizes.
Detects stapled documents to minimise damage to the documents
and equipment.
C Automatic Cropping and De-Skewing
C ToughFeed
The De-skewing function adjusts images scanned at an angle,
and the Cropping function properly trims the images.
Detects stapled documents to minimise damage to the
documents and equipment.
D Blank Page Removal
Removes documents with a blank back page from
data to simplify document management and improve
search efficiency.
Removed
D Blank Page Removal
Removes documents with a blank back page from data to
simplify document management and improve search efficiency.
Removed
E Small Footprint
The compact unit size enables easy setup on a desktop.
F Flatbed Scanning
For scanning books, drawings, and other
special documents.
Recommended Models
62
Recommended Models
KV-S3105C
KV-S3085
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
A B C D
A B C D
A B C D
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
KV-S7075C
A B C D E F
A B C D E F
A B C D E F
KV-S3065CW/CL
KV-S2048C
KV-S2028C
KV-S1045C
KV-S1025C
A B C D
A B C D E F
A B C D E F
63
Standard Memory Size
KV-S3105C, KV-S3085
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Post)
Ink Cartridge
Colour Upgrade Kit
KV-SS026
KV-SS027 (for thin paper)
KV-SS03
KV-SS028
KV-SS021
KV-SS029 (KV-S3085)
KV-S4085CW/CL, KV-S4065CW/CL
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Post and/or Pre)
Ink Cartridge
Flatbed Scanner
KV-SS033
KV-SS03
KV-SS014
KV-SS021
KV-SS080
KV-S5055C
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Pre)
Ink Cartridge
Flatbed Scanner
KV-SS039
KV-SS03
KV-SS014
KV-SS021
KV-SS080
Scanner
Preinstalled
Memory Size
KV-S3105C
256MB
KV-S3085
64MB
KV-S4085CW/CL
KV-S4065CW/CL
KV-S5055C
KV-S3065CW/CL
KV-S7075C
KV-S2048C
KV-S2028C
KV-S1045C
KV-S1025C
32MB
Additional Memory
Spec.
Evaluated Memory
JEDEC-Standard 168pin, dual
in-line memory module (DIMM)
EDGE 128,256,512
Kingston 128,256,512
–
–
64MB
80MB
64MB
8MB
Others
Options and Consumables
DOCUMENT SCANNER
Options and Consumables
KV-S3065CW, KV-S3065CL
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Post and/or Pre)
Ink Cartridge
Flatbed Scanner
KV-SS017
KV-SS018 (for thin paper)
KV-SS03
KV-SS014
KV-SS021
KV-SS080
KV-S7075C
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Pre)
Ink Cartridge
KV-SS015
KV-SS03
KV-SS014
KV-SS021
KV-S2048C, KV-S2028C
Roller Exchange Kit
Roller Cleaning Paper
Imprinter Unit (Pre)
Ink Cartridge
White Roller Kit
Flatbed Scanner
With black sensor rollers: KV-SS024
With white sensor rollers: KV-SS025
KV-SS03
KV-SS032 (KV-S2048C)
KV-SS021 (KV-S2048C)
KV-SS023
KV-SS080
KV-S1045C
Roller Exchange Kit
Roller Cleaning Paper
Flatbed Scanner
KV-SS035
KV-SS03
KV-SS080
KV-S1025C
Roller Exchange Kit
Roller Cleaning Paper
Flatbed Scanner
64
KV-SS035
KV-SS03
KV-SS080
65
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
