P R O D U C T P O R T F O L I O

2 0 1 6

Matrices Audio Extenders Switchers & Splitters Scalers & Converters Other AV

Our vision is simple:

To deliver market leading connectivity solutions that enhance the capability of

Audio Visual products in any installation environment.

Working hard to make your life easier

Continued dedication and focus has made CYP a market leader in connectivity solutions for both systems integrators and professional

AV installers throughout Europe. We have a range of over 350 tried and tested products that offer a standard of performance and reliability that cannot be matched.

The key to building such a successful range lies with the ability to continuously develop new products that drive innovation. Within AV distribution, this requires an excellent market understanding and the very best R&D engineers. CYP have a continuous new product roadmap containing over 30 projects at any one time. This ensures that we can always provide our partners with innovative solutions utilising the very latest technologies.

From our European headquarters in Shepperton (UK), we support distributors, systems integrators and installers throughout Europe, the

Middle East and Africa. From initial specification of projects through to industry leading after sales support and training, we provide our partners with complete confidence in the AV solutions they deliver.

Behind this support is a dedicated team of product managers and engineers who all have the skills and experience to deliver practical help at every stage of the CYP journey. It is this passion for the industry and pride in our products that makes us the perfect manufacturer partner.

Matrices

Audio

Extenders

Switchers & Splitters

Scalers & Converters

Other AV

P5

P31

P65

P103

P135

P147

Matrices

Featuring 4K support, HDMI2.0 and HDCP2.2 compliance and Audio matricing, our latest range of matrices are our most advanced yet. Five new models have been introduced, starting with our flagship 10 input x 10 output PUV-1082-4K22, with 6 x 8 and 4 x 6 models also offering the full range of HDBaseT functions (including transmission of HD sources over single runs of CAT5e/6/7 cables up to 100m). Included in the five new models are two HDBaseT Lite models that offer signal transmission over 60m, plus Power over HDBaseT (PoH) giving integrators the flexibility they require for any installation.

Making installation simple, all models offer 2-Way IR and IP control, allowing integrators to access and control all matrices remotely. For easy integration with third-party control systems, we provide ‘free to download’ drivers for Crestron, RTI, AMX and

Control 4 systems. When combined with our industry-leading support and backup, you can be very confident that our range offers everything that is required for either residential or commercial applications.

6

P I O N E E R S I N A V T E C H N O L O G I E S

Modular Matrices

The CYP Modular matrix series is available with a 16x16 and 32x32 chassis. These chassis utilise input and output modules, each with 8 input or output connections accordingly. It is also possible to use blanking modules on either chassis effectively creating any modular configuration with multiples of 8 inputs and outputs, up to a full 32x32 matrix.

Select input and output modules with

HDBaseT, HDBaseT LITE, HDMI, DVI and

VGA technologies for easy in-built signal conversion from any input to any output module. All CYP Modular Matrices are builtto-order, tested, certified and shipped preconfigured, so when your matrix arrives on site, it is ready to go, straight out of the box.

Modules

Module Model Description

IN-HBT5P-4K-8

8x 4K HDBaseT Module

IN-HDMI-4K-8

IN-HDMI-8

IN-VGA-8

IN-DVI-8

8x 4K HDMI Module

8x HDMI Module

8x VGA Module

8x DVI Module

OUT-HBT5P-4K-8

8x 4K HDBaseT Module

OUT-HBT4P-8

OUT-HBT3P-8

OUT-HDMI-4K-8

OUT-HDMI-8

OUT-DVI-8

8x HDBaseT Module

8x HDBaseT Lite Module

8x 4K HDMI Module

8x HDMI Module

8x DVI Module

Input

P

P

P

P

P

Output

P

P

P

P

P

P

4K

P

P

P

P

Modular Matrix Configuration Tool

To help with the specification process, we have created an online

Modular Matrix Configuration Tool. Accessible via the CYP website, this useful tool enables integrators to specify their requirements and graphically build a 16x16 or 32x32 matrix using the online step-bystep wizard. A bill of parts is generated which can then be emailed for reference and easily forwarded on to your chosen CYP distributor, safe in the knowledge that all components have been selected for a fullycustomised matrix that CYP builds to the installers specifications.

P

P

P

P

P

P

P

1080p I/O Distance

P

P

P

100m

60m

10m

15m

15m

100m

10m

15m

15m

15m

100m

PoC

P

P

P

P

LAN

P

P

P I O N E E R S I N A V T E C H N O L O G I E S

7

8

10x10 HDMI HDBaseT™ Matrix

with Audio Matricing (4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR, 100m)

PUV-1082-4K22

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH LAN OAR

The PUV-1082-4K22 HDMI/HDBaseT Matrix supports the transmission of video (resolutions up to

[email protected], HDCP 2.2, HDMI2.0) and multi-channel digital audio from 10 HDMI sources to 8 HDBaseT outputs and 2 independent HDMI2.0 outputs.

HDBaseT outputs allow transmission via a single

CAT5e/6/7 cable up to 100m, whilst the independent

HDMI outputs support cable lengths of up to 10m.

This matrix supports high resolution digital audio formats such as LPCM 7.1CH,Dolby TrueHD, Dolby

Digital Plus, Dolby Atmos and DTS-HD Master Audio as well as 3D video content.

with remote sources and remote audio zones. In addition, volume, mute, treble, bass and  audio lip-sync correction  control are available on all direct audio outputs. Optical Audio Return (OAR)

Technology allows the optical input on the PUV-

1530RX receiver to be routed back to the audio matrix.

LAN connectivity provides a 100BaseT network for smart TVs or games consoles in every zone. The matrix has a built-in pattern generator which can be used to verify the video signal on any of its 10 output ports. The Power over HDBaseT (PoH) function provides power to compatible receivers.

This matrix incorporates an independent audio matrix with 14 audio outputs and 10 audio inputs.  These outputs and inputs can also be used for de-embedding HDMI audio to the audio outputs and embedding audio to the HDBaseT and

HDMI outputs.  The audio CAT connections, along with compatible bi-directional audio modules

(PU-305BD-RX & PU-305BDA-RX) allow integration

Control is via manual selection buttons, IR, RS-232,

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports RS232 pass-through to the receivers. The

PUV-1082-4K22 is designed to be used with PUV-

1530RX or PUV-1510RX receivers that can utilise the

PoH and LAN capabilities of the matrix.

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI 2.0, HDCP1.4 and HDCP2.2 compliant

• Routes ten HDMI sources to ten displays using eight

HDBaseT outputs and two independent HDMI outputs

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV

4:2:2), 4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports resolutions up to [email protected] (RGB 4:4:4) on HDMI output ports

• Supports automatic [email protected] RGB 4:4:4 to YUV 4:2:0 conversion for HDBaseT outputs

• 4K/2K & 4K UHD signals can be transmitted up to 70m via

CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports audio matrix functionality enabling full audio management of the system including HDBaseT audio zone selection, and fully independent audio only zones

• Supports Digital to Analogue Conversion (DAC) and Analogue to Digital Conversion (ADC) for audio integration

• Supports on-board audio over CAT inputs and outputs for transmission up to 150m

• Supports Volume, Mute, Treble, Bass, and Audio delay for lip-sync on direct audio outputs

• Optical Audio Return (OAR)

• Advanced internal and external EDID management with 4 sets of configurable EDID settings

• Internal test pattern generation for self-testing and sink device testing. (Internal test patterns up to and including

4K signals)

• Supports HDCP repeating and CEC functions

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• 2U rack mounted design

SPECIFICATIONS

Input:

10x HDMI (10x HDMI - Uncompressed AV and Data)

8x RCA (4x Configurable Analogue Audio - Stereo (L/R))

2x Toslink (2x Configurable Digital Audio - 2 Channel LPCM / DTS / Dolby Digital)

2x RCA (2x Configurable Digital Audio - 2 Channel LPCM / DTS / Dolby Digital)

2x RJ45 (2x Bi-directional Audio plus Propriety Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x RJ45 (1x IP Control / LAN Serving)

1x 9pin Dsub (1x RS-232 Data)

Output:

Power:

PoH Power:

Dimensions:

Gross Weight:

Net. Weight:

8x RJ45 (8x HDBaseT - HDMI & Propriety Data)

16x RCA (8x Mirrored HDBaseT audio - Stereo (L/R))

8x RCA (4x Extended Audio only zones - Stereo (L/R))

11x 3.5mm Stereo mini-jack (11x Infra Red Emitter)

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

316mm (W) x 438mm (D) x 96mm (H)

8500g

6500g

Compatible HDBaseT Receivers (RX)

PUV-1530RX

See Page 73 for specification

PUV-1510RX

See Page 77 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

9

10

10x10 HDMI HDBaseT™ LITE Matrix (60m)

with Audio Matricing (4K, HDCP2.2, HDMI2.0, PoH, OAR)

PUV-1082PL-4K22

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-1082PL-4K22 HDMI/HDBaseT Matrix supports the transmission of video (resolutions up to audio modules (PU-305BD-RX & PU-305BDA-RX) allow integration with remote sources and remote

[email protected], HDCP 2.2, HDMI2.0) and multi-channel digital audio from 10 HDMI sources to 8 HDBaseT outputs and 2 independent HDMI2.0 outputs.

HDBaseT outputs allow transmission via a single

CAT5e/6/7 cable up to 60m, whilst the independent

HDMI outputs support cable lengths of up to 10m.

This matrix supports high resolution digital audio audio zones. In addition, volume, mute, treble, bass and audio lip-sync correction control are available on all direct audio outputs. Optical Audio Return (OAR)

Technology allows the optical input on the PUV-

1230PL-RX receiver to be routed back to the audio matrix.

formats such as LPCM 7.1CH,Dolby TrueHD, Dolby

Digital Plus, Dolby Atmos and DTS-HD Master Audio as well as 3D video content.

The matrix has a built-in pattern generator which can be used to verify the video signal on any of its

10 output ports. The Power over HDBaseT (PoH) function provides power to compatible receivers.

The PUV-1082PL-4K22 matrix incorporates an independent audio matrix with 14 audio outputs and 10 audio inputs.  These outputs and inputs

Control is via manual selection buttons, IR, RS-232,

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports RS232 pass-through to the receivers. The can also be used for de-embedding HDMI audio to the audio outputs and embedding audio to the HDBaseT and HDMI outputs.  The audio CAT connections, along with compatible bi-directional

PUV-1082PL-4K22 is designed to be used with PUV-

1230PL-RX or PUV-1210PL-RX receivers that can utilise the PoH capabilities of the matrix.

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI 2.0, HDCP1.4 and HDCP2.2 compliant

• Routes ten HDMI sources to ten displays using eight

HDBaseT outputs and two independent HDMI outputs

• High-Definition video and audio, PoH (Power over

HDBaseT) and control (Bi-Directional IR & RS-232 pass through)

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV

4:2:2), 4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports resolutions up to [email protected] (RGB 4:4:4) on HDMI output ports

• Supports automatic [email protected] RGB 4:4:4 to YUV 4:2:0 conversion for HDBaseT outputs

• 4K/2K & 4K UHD signals can be transmitted up to 35m via

CAT5e/6 and 40m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports audio matrix functionality enabling full audio management of the system including HDBaseT audio zone selection, and fully independent audio only zones

• Supports Digital to Analogue Conversion (DAC) and Analogue to Digital Conversion (ADC) for audio integration

• Supports on-board audio over CAT inputs and outputs for transmission up to 150m

• Supports Volume, Mute, Treble, Bass, and Audio delay for lip-sync on direct audio outputs

• Optical Audio Return (OAR)

• Advanced internal and external EDID management with 4 sets of configurable EDID settings

• Internal test pattern generation for self-testing and sink device testing. (Internal test patterns up to and including

4K signals)

• Supports HDCP repeating and CEC functions

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• 2U rack mounted design

SPECIFICATIONS

Input:

10x HDMI (10x HDMI Uncompressed AV and Data)

8x RCA (4x Configurable Analogue Audio - Stereo (L/R))

2x Toslink (2x Configurable Digital Audio - Dolby Digital / DTS / 2 Channel LPCM)

2x RCA (2x Configurable Digital Audio - 2 Channel LPCM / DTS / Dolby Digital)

2x RJ45 (2x Bi-directional Audio plus Propriety Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x RJ45 (1x IP Control / LAN Serving)

1x 9pin Dsub (1x RS-232 Data)

Output:

Power:

PoC Power:

Dimensions:

Gross Weight:

Net. Weight:

8x RJ45 (8x HDBaseT - HDMI & Propriety Data)

16x RCA (8x Mirrored HDBaseT audio - Stereo (L/R))

8x RCA (4x Extended Audio only zones - Stereo (L/R))

11x 3.5mm Stereo mini-jack (11x Infra Red Emitter)

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

24V/6.25A PoH DC (US/EU standards, CE/FCC/UL certified)

316mm (W) x 438mm (D) x 96mm (H)

6500g

6500g

Compatible HDBaseT Receivers (RX)

PUV-1230PL-RX

See Page 75 for specification

PUV-1210PL-RX

See Page 79 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

11

8x8 HDMI HDBaseT™ Matrix (100m)

5Play™ including LAN serving, 4K resolution & HDCP2.2

PU-8H8HBTE-4K22

12

4K 3D 5Play HDCP2.2

HDMI HDBT PoC LAN

The PU-8H8HBTE-4K22 8 by 8 HDMI Matrix over CAT5e/6/7 supports the transmission  of video (resolutions up to 4K2K

Full HD, HDCP 2.2) and multi-channel digital  audio from 8

HDMI  sources to 8 HDBaseT outputs  via single CAT5e/6/7 cables up to 100m. It supports high resolution digital audio formats such as LPCM 7.1CH,Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio as well as 3D content that can be displayed when connecting a 3D TV and 3D source. This matrix features  control via manual selection buttons, IR, RS-232,

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports RS232 pass-through to the receivers. The PU-8H8HBTE-4K22 is designed to be used with any of the HDBaseT receivers that can utilise the PoC and

LAN capabilities of the matrix. The LAN serving capabilities of the matrix provide network connections in every zone.

SPECIFICATIONS

Input:

8x HDMI (8x Uncompressed AV and Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x RJ45 (1x LAN Serving / IP Control)

1x 9pin Dsub (1x RS-232 Data)

1x USB Mini B (1x Service Port Propriety Data)

Output:

8x RJ45 (8x HDBaseT HDMI & Propriety Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Emitter)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 438mm (W) x 249mm (D) x 88mm (H)

Gross

Weight:

5700g

FEATURES

• HDCP 2.2 Compliant

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Uncompressed video/audio up to 10.2Gbps

• LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• 1080p signals can be transmitted up to 100m via

CAT5e/6/6a/7

• PoC (Power over Cable) and LAN features are available on compatible receivers only

• Features bi-directional IR from input and output locations

• The PU-8H8HBTE-4K22 can be controlled via

RS-232, remote control, on-panel control and IP

Control (Telnet & Web GUI)

• 2U size design

• Supports external and internal EDID settings

COMPATIBLE RECEIVERS (RX)

PU-507RX

See Page 87 for specification

Net. Weight: 4370g

PU-507-WPRX

See Page 88

for specification

P I O N E E R S I N A V T E C H N O L O G I E S

8x8 HDMI HDBaseT™ LITE Matrix (60m)

with PoC, 4K resolution support, & HDCP2.2

PU-8H8HBTPL-4K22

4K 3D 5Play HDMI HDBT HDCP2.2 PoC

The 4K2K 8 by 8 HDMI Matrix over CAT5e/6/7 supports the transmission of video (resolutions up to 4K2K Full HD, HDCP

2.2), multi-channel digital  audio from 8 HDMI  sources to 8

HDBaseT LITE outputs via single CAT5e/6/7 cable up to 60m.

The matrix is compatible with  high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio as well as 3D content that can be displayed when connecting a 3D TV and 3D source.

This matrix features control via manual selection buttons, IR,

RS-232, Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports UART RS232 pass-through to the receivers.

The PU-8H8HBTPL-4K22 is designed to be used with PU-

515PL-RX & PU-515PL-WPRX receivers.

SPECIFICATIONS

Input:

8x HDMI (8x Uncompressed AV and Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x RJ45 (1x IP Control)

1x 9pin Dsub (1x RS-232 Data)

1x USB Mini B (1x Service Port Propriety Data)

Output:

9x 3.5mm Stereo mini-jack (9x Infra Red Emitter)

8x RJ45 (8x HDBaseT Lite HDMI & Propriety Data)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 438mm (W) x 249mm (D) x 88mm (H)

Gross

Weight:

4370g

Net. Weight: 4370g

FEATURES

• HDCP 2.2 Compliant

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Uncompressed video/audio up to 10.2Gbps

• LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 40m via CAT6a/7

• 1080p signals can be transmitted up to 60m via

CAT5e/6/6a/7

• PoC (Power over Cable) feature available on compatible receivers only

• Features bi-directional IR from input and output locations

• The PU-8H8HBTPL-4K22 can be controlled via

RS-232, remote control, on-panel control and IP

Control (Telnet & Web GUI)

• 2U Size Design

• Supports external and internal EDID settings

COMPATIBLE RECEIVER (RX)

PU-515PL-RX

See Page 91 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

13

8x8 HDMI HDBaseT™ Matrix (100m)

5Play™ inlcuding LAN serving

PU-8H8HBTE

14

5Play HDMI HDBT LAN

FEATURES

As the Flagship 8x8 HDBaseT™  Matrix, the PU-8H8HBTE solution offers complete HDBaseT™ 5-Play™ convergence.

Installers can switch and distribute up to 8 HDMI sources,

LAN (Local Area Network), 2-Way IR, and PoC (Power over

Cable) to lengths of up to 100m using CAT5e/6/7 cable infrastructure. Control of the matrix is via IP control, RS-232, IR remote, or manual selection buttons. This single box solution will enable an installer to confidently integrate an eight zone multi-room AV system. The PU-8H8HBTE is designed to be used with the PU-507-RX Receiver which can utilise PoC capabilities of the matrix.

Use the LAN serving capabilities of the matrix to add internet connectivity to every zone. In addition, this matrix also features IR, RS232. IP (telnet) and web GUI control allowing users to access and control the matrix remotely and also allow additional options for integration of third-party control systems. CYP provide control drivers for control systems such as Control 4, RTI, Crestron, AMX, Control FX, and RTI. These are available at no extra cost.

SPECIFICATIONS

Input:

Output:

Power:

8x HDMI (8x HDMI Uncompressed AV and Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x LAN Serving / IP Control)

1x USB Mini B (1x Service Port - Propriety Data)

8x RJ45 (8x HDBaseT - HDMI & Propriety Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Emitter)

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

• Supports all v1.4 HDMI resolutions

• Supports uncompressed video/audio up to 10.2Gbps

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

• HDMI, HDCP and DVI complaint

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• Supports third-party control systems, with IP and RS232 drivers available for: AMX, Crestron,

RTI, Control 4

• Supports HDMI input up to 15m 1080p 8bit or

10m 1080p 12bit.

• Supports RS-232, 2-Way IR, Manual Selection

Buttons, and HDMI CEC control pass through

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Compact 2U Rack mount design

• Supports 3D signals

• Supports additional IR Control via a master (ALL)

Input/Output

• Supports LAN serving to all connected zones

• Supports full IP control

COMPATIBLE RECEIVERS (RX)

PU-507RX

See Page 87 for specification

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 255mm (W) x 440mm (D) x 90mm (H)

Gross

Weight:

7960g

Net. Weight: 6960g

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

8x8 HDMI HDBaseT™ LITE Matrix (60m)

with PoC

PU-8H8HBTPL

3D HDMI HDBT PoC

FEATURES

The PU-8H8HBTPL is an 8x8 HDMI HDBaseT™ Lite  with PoC

(power over cable) Matrix. Installers can switch and distribute up to 8 HDMI sources, and 2-Way IR to lengths of up to 60m using CAT5e/6/7 cable infrastructure. Control of the matrix is via IP, RS-232, IR remote, or manual selection buttons. This single box solution will enable an installer to confidently integrate an eight zone multi-room AV system.  The PU-

8H8HBTPL is designed to be used with the PU-515PL-RX

Receiver which enables the use of 2-Way IR control feature and which can utilise PoC capabilities of the matrix.

This matrix also features IP and RS232 control allowing users to access and control the matrix remotely and also allow additional options for integration of third-party control systems. CYP provide control drivers for control systems such as Control 4, RTI, Crestron, AMX, Control FX, and RTI. These are available at no extra cost.

SPECIFICATIONS

Input:

8x HDMI (8x Uncompressed AV and Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Mini B (1x Service Propriety Data)

• Supports all v1.4 HDMI resolutions

• Supports uncompressed video/audio up to

10.2Gbps

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA, WUXGA

• HDMI, HDCP and DVI complaint

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Uncompressed data transfer over single CAT cable (60m via CAT5e/6/7)

• Supports HDMI input up to 15m 1080p 8bit or

10m 1080p 12bit

• Supports RS-232, 2-Way IR, Manual Selection

Buttons, and HDMI CEC control pass through

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Compact 2U Rack mount design

• Supports IP control

• Supports 3D signals

• Supports Power over Cable (PoC ) providing power to compatible receivers

• Supports third-party control systems, with IP and RS232 drivers available for: AMX, Crestron,

RTI, Control 4

Output:

8x RJ45 (8x HDBaseT Lite with PoC HDMI & Propriety

Data)

9x 3.5mm Stereo mini-jack (9x Infra Red Emitter)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 440mm (W) x 265mm (D) x 90mm (H)

Gross

Weight:

7360g

COMPATIBLE RECEIVER (RX)

PU-515PL-RX

See Page 91 for specification

Net. Weight: 4520g

P I O N E E R S I N A V T E C H N O L O G I E S

15

16

6x8 HDMI HDBaseT™ Matrix (100m)

with Audio Matricing (4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR)

PUV-662-4K22

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH OAR LAN

The PUV-662-4K22 HDMI/HDBaseT Matrix supports the transmission of video (resolutions up to

[email protected], HDCP 2.2, HDMI2.0) and multi-channel digital audio from 6 HDMI sources to 6 HDBaseT treble, bass and audio lip-sync correction control are available on all direct audio outputs. Optical Audio

Return (OAR) Technology allows the optical input on the PUV-1530RX receiver to be routed back to the outputs and 2 independent HDMI2.0 outputs. The

HDBaseT outputs allow transmission via a single

CAT5e/6/7 cable up to 100m, whilst the independent

HDMI outputs support cable lengths of up to 10m.

This matrix supports high resolution digital audio formats such as LPCM 7.1CH,Dolby TrueHD, Dolby

Digital Plus, Dolby Atmos and DTS-HD Master Audio as well as 3D video content.

for de-embedding HDMI audio to feed the audio outputs and embedding this audio to the HDBaseT and HDMI outputs. In addition,  volume, mute, audio matrix.

LAN connectivity provides a 100BaseT network for smart TV's or games consoles in every zone. The matrix has a built-in pattern generator which can be used to verify the video signal on any of its 8 output ports.  The Power over HDBaseT (PoH) function provides power to compatible receivers.

The PUV-662-4K22 matrix incorporates an independent audio matrix with 8 audio outputs and

4 audio inputs. These outputs and inputs can be used

Control is via manual selection buttons, IR, RS-232,

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports

RS232 pass-through to the receivers.

The PUV-662-4K22 is designed to be used with PUV-

1530RX or PUV-1510RX receivers that can utilise the

PoH capabilities of the matrix.

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI 2.0, HDCP1.4 and HDCP2.2 compliant

• Routes six HDMI sources to eight displays using six

HDBaseT outputs and two independent HDMI outputs

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports resolutions up to [email protected] (RGB 4:4:4) on HDMI output ports

• Supports automatic [email protected] RGB 4:4:4 to YUV 4:2:0 conversion for HDBaseT outputs

• 4K/2K & 4K UHD signals can be transmitted up to 70m via

CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports audio matrix functionality enabling full audio management of the system including HDBaseT audio zone selection, and fully independent audio only zones

• Supports Digital to Analogue Conversion (DAC) and Analogue to Digital Conversion (ADC) for audio integration

• Supports Volume, Mute, Treble, Bass, and Audio delay for lip-sync on direct audio outputs

• Optical Audio Return (OAR)

• Advanced internal and external EDID management with 4 sets of configurable EDID settings

• Internal test pattern generation for self-testing and sink device testing. (Internal test patterns up to and including

4K signals)

• Supports HDCP repeating and CEC functions

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• 2U rack mounted design

SPECIFICATIONS

Input:

6x HDMI Uncompressed AV and Data (1x HDMI)

2x Analogue Stereo (L/R) (2x RCA)

1x Optical DTS / Dolby Digital / 2 Channel LPCM (1x Toslink)

1x Coaxial DTS / Dolby Digital / 2 Channel LPCM (1x RCA)

7x Infra Red Receiver (1x 3.5mm Stereo mini-jack) 7

1x RS-232 Data (1x 9pin Dsub)

1x IP Control / LAN Serving (1x RJ45)

1x Service Port Propriety Data (1x USB Type A)

Output:

2x HDMI Uncompressed AV and Data (1x HDMI)

6x HDBaseT HDMI & Propriety Data (1x RJ45)

6x Zone - Analogue Stereo (L/R) (2x RCA)

2x Extended - Analogue Stereo (L/R) (2x RCA)

7x Infra Red Emitter (1x 3.5mm Stereo mini-jack)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 316mm (W) x 438mm (D) x 96mm (H)

Gross Weight: 8000g

Net. Weight: 6000g

Compatible HDBaseT Receivers (RX)

PUV-1530RX

See Page 73 for specification

PUV-1510RX

See Page 77 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

17

18

6x8 HDMI HDBaseT™ LITE Matrix (60m)

with Audio Matricing (4K, HDCP2.2, HDMI2.0, PoH, OAR)

PUV-662PL-4K22

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-662PL-4K22 HDMI/HDBaseT Matrix supports the transmission of video (resolutions up to and HDMI outputs. In addition,  volume, mute, treble, bass and audio lip-sync correction control are

[email protected], HDCP 2.2, HDMI2.0) and multi-channel digital audio from 6 HDMI sources to 6 HDBaseT Lite available on all direct audio outputs. Optical Audio

Return (OAR) Technology allows the optical input on outputs and 2 independent HDMI2.0 outputs. The

HDBaseT outputs allow transmission via a single

CAT5e/6/7 cable up to 60m, whilst the independent the PUV-1230PL-RX receiver to be routed back to the audio matrix.

HDMI outputs support cable lengths of up to 10m.

This matrix supports high resolution digital audio formats such as LPCM 7.1CH,Dolby TrueHD, Dolby

Digital Plus, Dolby Atmos and DTS-HD Master Audio as well as 3D video content.

for de-embedding HDMI audio to feed the audio outputs and embedding this audio to the HDBaseT

The matrix has a built-in pattern generator which can be used to verify the video signal on any of its 8 output ports. The Power over HDBaseT (PoH) function provides power to compatible receivers.

Control is via manual selection buttons, IR, RS-232,

The PUV-662PL-4K22 matrix incorporates an independent audio matrix with 8 audio outputs and

4 audio inputs. These outputs and inputs can be used

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports

RS232 pass-through to the receivers.

The PUV-662PL-4K22 is designed to be used with

PUV-1230PL-RX or PUV-1210PL-RX receivers that can utilise the PoH capabilities of the matrix.

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI 2.0, HDCP1.4 and HDCP2.2 compliant

• Routes six HDMI sources to eight displays using six

HDBaseT outputs and two independent HDMI outputs

• High-Definition video and audio, PoH (Power over

HDBaseT) and control (Bi-Directional IR & RS-232 pass through)

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports resolutions up to [email protected] (RGB 4:4:4) on HDMI output ports

• Supports automatic [email protected] RGB 4:4:4 to YUV 4:2:0 conversion for HDBaseT outputs

• 4K/2K & 4K UHD signals can be transmitted up to 35m via

CAT5e/6 and 40m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports audio matrix functionality enabling full audio management of the system including HDBaseT audio zone selection, and fully independent audio only zones

• Supports Digital to Analogue Conversion (DAC) and Analogue to Digital Conversion (ADC) for audio integration

• Supports Volume, Mute, Treble, Bass, and Audio delay for lip-sync on direct audio outputs

• Optical Audio Return (OAR)

• Advanced internal and external EDID management with 4 sets of configurable EDID settings

• Internal test pattern generation for self-testing and sink device testing. (Internal test patterns up to and including

4K signals)

• Supports HDCP repeating and CEC functions

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• 2U rack mounted design

SPECIFICATIONS

Input:

6x HDMI Uncompressed AV and Data (1x HDMI)

2x Analogue Stereo (L/R) (2x RCA)

1x Optical DTS / Dolby Digital / 2 Channel LPCM (1x

Toslink)

1x Coaxial DTS / Dolby Digital / 2 Channel LPCM (1x

RCA)

7x Infra Red Receiver (1x 3.5mm Stereo mini-jack) 7

1x RS-232 Data (1x 9pin Dsub)

1x IP Control (1x RJ45)

1x Service Port Propriety Data (1x USB Type A)

Output:

2x HDMI Uncompressed AV and Data (1x HDMI)

6x HDBaseT HDMI & Propriety Data (1x RJ45)

6x Zone - Analogue Stereo (L/R) (2x RCA)

2x Extended - Analogue Stereo (L/R) (2x RCA)

7x Infra Red Emitter (1x 3.5mm Stereo mini-jack)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 316mm (W) x 438mm (D) x 96mm (H)

Gross Weight: 8000g

Packaging:

6000g

Compatible HDBaseT Receivers (RX)

PU-1230PL-RX

See Page 75 for specification

PUV-1210PL-RX

See Page 79 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

19

6x2 HDMI Matrix Switch

with Audio De-Embedding (4K, HDCP2.2)

OR-HD62CD-4K22

20

4K 3D HDMI HDCP2.2

The OR-HD62CD-4K22 is an advanced 4K UHD HDMI matrix switcher designed for both commercial and residential applications.

The 6 x 2 HDMI matrix switch enables 4K UHD HDCP 2.2 HDMI signals to be routed from any of the six HDMI inputs to either of the two independent HDMI outputs. Additionally a cutting edge picture in picture (PIP) preview mode can be selected where the unselected sources (excluding 3D and 4K UHD) are displayed in a row of 5 small windows overlaid on top of the primary selected source. In preview mode, both HDMI outputs show identical feeds. Further features include fast switching technology, on-board EDID management tool (via on screen display) and optical audio de-embedding for added flexibility of installation.

Control is via front panel buttons, IR remote control, RS232,

Telnet or IP control for easy integration into control systems.

FEATURES

• HDCP 2.2, HDMI 1.4 and DVI compliant

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• High Definition audio supported: Dolby TrueHD,

Dolby Digital Plus, DTS-HD Master Audio + 7.1

Channel LPCM

• Optical de-embedding from selected HDMI input, audio sampling rate of 192kHz

• Fast switching technology

• Supports 10 bit colour, 4K UHD, 3D and 1080p signals

• Built in EDID management

• Preview mode uses Picture in Picture technology to display sources simultaneously on individual outputs

SPECIFICATIONS

Input:

6x HDMI (6x Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x IR Propriety Data)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Type A (1x Service Port Propriety Data)

Output:

2x HDMI (2x Uncompressed AV and Data)

2x Toslink (2x Optical 2 Channel LPCM / Dolby Digital

/ DTS)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 276mm (W) x 482mm (D) x 49mm (H)

Gross

Weight:

4500g

Net. Weight: 3200g

P I O N E E R S I N A V T E C H N O L O G I E S

6x2 UHD HDMI Matrix Switch

with Audio De-Embedding

OR-HD62CD

4K 3D HDMI

The OR-HD62CD allows HDMI signals to be routed from any of the six connected HDMI sources for display on two connected HDMI displays. With fast switching technology this device dramatically improves the sync time to the connected HDMI displays over traditional switchers. In Matrix Mode, it allows any source to be routed independently to any output. An on-board EDID management tool (via on screen display) can be utilised for advanced audio and video signal management. In addition, this switcher also includes a cutting edge Picture in Picture (PIP) preview mode allowing the user to show 5 unselected HDMI sources in a row of small windows overlaid on top of the primary selected HDMI source video . In preview mode, both HDMI outputs show identical feeds. Further features include the ability to de-embed Hi-Definition lossless audio via a dedicated Optical output for each HDMI output, 4K resolution support, and 3D signal support.

Control is via front panel buttons, IR remote control, RS-232, Telnet or IP control for easy integration into control systems such as Control 4.

SPECIFICATIONS

Input:

6x HDMI (6x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x IR Propriety Data)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Type A (1x Service Port Propriety Data)

Output:

2x HDMI (2x HDMI Uncompressed AV and Data)

2x Toslink (2x Optical 2 Channel LPCM / Dolby Digital /

Dolby Digital Plus / DTS)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 440mm (W) x 290mm (D) x 40mm (H)

Gross

Weight:

5160g

Net. Weight: 3020g

FEATURES

• HDMI, HDCP 1.1, DVI 1.0 compliant

• High Definition audio supported: Dolby TrueHD,

Dolby Digital Plus, DTS-HD Master Audio + 7.1

Channel LPCM

• RS-232, Telnet or IP Control, IR Remote Control

(supplied), Web GUI Control

• Supports audio extraction from HDMI input to

Optical output, input audio sampling rate up to 192 kHz

• Ability to switch between any two sources within 1 second

• Built-in EDID Management

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Cutting edge Picture in Picture preview function

P I O N E E R S I N A V T E C H N O L O G I E S

21

22

4x6 HDMI HDBaseT™ Matrix (100m)

with Audio Matricing (4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR)

PUV-442-4K22

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH OAR LAN

The PUV-442-4K22 HDMI/HDBaseT Matrix supports the transmission of video (resolutions up to

[email protected], HDCP 2.2, HDMI2.0) and multi-channel digital audio from 4 HDMI sources to 4 HDBaseT Lite and HDMI outputs. In addition,  volume, mute, treble, bass and audio lip-sync correction control are available on all direct audio outputs. Optical Audio

Return (OAR) Technology allows the optical input on outputs and 2 independent HDMI2.0 outputs. The

HDBaseT outputs allow transmission via a single

CAT5e/6/7 cable up to 100m, whilst the independent the PUV-1230PL-RX receiver to be routed back to the audio matrix.

HDMI outputs support cable lengths of up to 10m.

This matrix supports high resolution digital audio formats such as LPCM 7.1CH,Dolby TrueHD, Dolby

Digital Plus, Dolby Atmos and DTS-HD Master Audio as well as 3D video content.

for de-embedding HDMI audio to feed the audio outputs and embedding this audio to the HDBaseT

LAN connectivity provides a 100BaseT network for smart TVs or games consoles in every zone.  The

Power over HDBaseT (PoH) function provides power to compatible receivers.

Control is via manual selection buttons, IR, RS-232,

The PUV-442-4K22 matrix incorporates an independent audio matrix with 4 audio outputs and

6 audio inputs. These outputs and inputs can be used

Telnet or Web GUI. CYP provide control drivers for all the major control systems. This unit also supports

RS232 pass-through to the receivers.

The PUV-442-4K22 is designed to be used with PUV-

1530RX or PUV-1510RX receivers that can utilise the

PoH capabilities of the matrix.

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI 2.0, HDCP1.4 and HDCP2.2 compliant

• Routes four HDMI sources to six displays using six

HDBaseT outputs and two independent HDMI outputs

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports resolutions up to [email protected] (RGB 4:4:4) on HDMI output ports

• Supports automatic [email protected] RGB 4:4:4 to YUV 4:2:0 conversion for HDBaseT outputs

• 4K/2K & 4K UHD signals can be transmitted up to 70m via

CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

SPECIFICATIONS

Input:

10x HDMI - Uncompressed AV and Data (1x HDMI)

4x Configurable Analogue Audio - Stereo (L/R) (2x RCA)

2x Configurable Digital Audio - 2 Channel LPCM / DTS /

Dolby Digital (1x Toslink)

2x Configurable Digital Audio - 2 Channel LPCM / DTS /

Dolby Digital (1x RCA)

2x Bi-directional Audio plus Propriety Data (1x RJ45)

9x Infra Red Receiver (1x 3.5mm Stereo mini-jack)

1x IP Control / LAN Serving (1x RJ45)

Output:

8x HDBaseT - HDMI & Propriety Data (1x RJ45)

8x Mirrored HDBaseT audio - Stereo (L/R) (2x RCA)

4x Extended Audio only zones - Stereo (L/R) (2x RCA)

11x Infra Red Emitter (1x 3.5mm Stereo mini-jack)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 316mm (W) x 438mm (D) x 96mm (H)

Gross Weight: 8000g

Net. Weight: 6000g

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports audio matrix functionality enabling full audio management of the system including HDBaseT audio zone selection, and fully independent audio only zones

• Supports Digital to Analogue Conversion (DAC) and Analogue to Digital Conversion (ADC) for audio integration

• Supports Volume, Mute, Treble, Bass, and Audio delay for lip-sync on direct audio outputs

• Optical Audio Return (OAR)

• Advanced internal and external EDID management with 4 sets of configurable EDID settings

• Internal test pattern generation for self-testing and sink device testing. (Internal test patterns up to and including

4K signals)

• Supports HDCP repeating and CEC functions

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• 1U rack mounted design

Compatible HDBaseT Receivers (RX)

PUV-1530RX

See Page 73 for specification

PUV-1510RX

See Page 77 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

23

4x4 HDBaseT LITE Matrix (60m)

with 4x PU-515PL-RX PoC Receivers, plus 2 additional independent HDMI zone outputs (total 4x6 Matrix)

PU-442PL-KIT

24

3D HDBT 5Play HDMI PoC SUPPLIED WITH 4xPU-5I5PL-RX RECEIVERS

This 4 by 6 HDBaseT™  Lite Matrix utilises four HDMI inputs and  four HDBaseT outputs over a single CAT5e/6/7 cable

(up to 60m) for each output, plus two additional HDMI outputs. All six outputs are independent allowing any source to be distributed to any output. The HDBaseT outputs feature

Power over Cable (PoC) functionality and allow the user to power the supplied PU-515PL-RX receivers without the need for a separate mains power supply.

FEATURES

• Supports all v1.3 HDMI resolutions

• Supports uncompressed video/audio up to

10.2Gbps

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

• HDMI, HDCP and DVI complaint

The PU-442PL-KIT supports the transmission of video

(resolutions up to 1080p Full HD and [email protected]), PoC

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

2-way IR, multi-channel digital audio, and control via IR, RS-

232, or Web GUI/Telnet IP. Use the IP control feature to enable users to access and control the matrix remotely and also

• Uncompressed data transfer over single CAT cable (60m - CAT5e/6/7) allow additional options for integration of third-party control systems.

SPECIFICATIONS

• Supports HDMI input up to 15m 1080p 8bit or

10m 1080p 12bit.

• Supports RS-232, 2-Way IR, Manual Selection

Buttons, and HDMI CEC control pass through

Input:

• Selectable EDID settings - TV (downstream) and

STD (fixed)

Output:

4x HDMI (4x HDMI Uncompressed AV and Data)

5x 3.5mm Stereo mini-jack (5x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Mini B (1x Service Port - Propriety Data)

4x RJ45 (4x HDBaseT Lite HDMI & Propriety Data)

2x HDMI (2x HDMI Uncompressed AV and Data)

5x 3.5mm Stereo mini-jack (5x Infra Red Emitter)

• Compact 1U Rack mount design

• Supports 3D signals

• Supports additional IR Control via a master (ALL)

Input/Output

• Supports full IP control

• Supplied with 4x PU-515PL-RX receivers

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 310mm (W) x 250mm (D) x 210mm (H)

Gross

Weight:

432g

Net. Weight: 334g

334g

P I O N E E R S I N A V T E C H N O L O G I E S

4x4 HDMI HDBaseT™ Matrix (100m)

with 2 simultaneous HDMI Outputs (5Play™ including PoC)

PU-424HBTE

4K 3D 5Play HDMI HDBT

SPECIFICATIONS

Input:

PoC LAN

This 4 by 4 HDMI HDBaseT™ Matrix with two additional simultaneous HDMI outputs supports the transmission of video (resolutions up to 1080p Full HD and [email protected]), multi-channel digital audio and control via IR, RS-232 or

Web GUI/Telnet IP from four high definition sources to four

HDBaseT outputs over a single CAT5e/6/7 cable (up to 100m) for each output. Output A and C have additional mirrored

HDMI outputs, for added installation flexibility.

The PU-424HBTE is designed to be used with the PU-507-RX

Receiver which can utilise PoC capabilities of the matrix.

Use the LAN serving capabilities of the matrix to add internet connectivity to every zone. In addition, this matrix also features

IP control allowing users to access and control the matrix remotely and also allow additional options for integration of third-party control systems. CYP provide control drivers for control systems such as Control 4, RTI, Crestron, AMX, Control

FX, and RTI. These are available at no extra cost.

4x HDMI (4x HDMI Uncompressed AV and Data)

5x 3.5mm Stereo mini-jack (5x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x LAN Serving / IP Control)

1x USB Mini B (1x Service Port - Propriety Data)

Output:

4x RJ45 (4x HDBaseT - HDMI & Propriety Data)

2x HDMI (2x HDMI Uncompressed AV and Data)

5x 3.5mm Stereo mini-jack (5x Infra Red Emitter)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 435mm (W) x 265mm (D) x 45mm (H)

Gross

Weight:

4600g

Net. Weight: 3400g

FEATURES

• Supports all v1.3 HDMI resolutions

• Supports uncompressed video/audio up to

10.2Gbps

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

• HDMI, HDCP and DVI complaint

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• Supports third-party control systems, with drivers available for: Control FX, AMX, Crestron,

RTI, Control 4

• Supports HDMI input up to 15m 1080p 8bit or

10m 1080p 12bit.

• Supports RS-232, 2-Way IR, Manual Selection

Buttons, and HDMI CEC control pass through

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Compact 1U Rack mount design

• Supports 3D signals

• Supports additional IR Control via a master (ALL)

Input/Output

• Supports LAN serving to all connected zones

• Supports full IP control

COMPATIBLE RECEIVERS (RX)

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

25

4x4 HDMI HDBaseT™ LITE Matrix (60m)

with 2x Mirrored HDMI outputs & Audio De-embedding

Supplied with 4x PUV-1210PL-RX Receivers (4K, HDCP2.2, PoH)

PUV-44XPL-4K22-KIT

26

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR SUPPLIED WITH 4xPUV-1210PL-RX RECEIVERS

The PUV-44XPL-4K22-KIT is a HDMI/HDBaseT LITE

Matrix which supports the transmission of video

(resolutions up to [email protected], HDCP 2.2) and multi-channel digital audio from 4 HDMI sources to

4 HDBaseT LITE outputs and 2 independent HDMI outputs. HDBaseT outputs allow transmission via a single CAT5e/6/7 cable up to 60m, whilst the independent HDMI outputs support cable lengths of up to 10m. This matrix supports high resolution digital audio formats such as LPCM 7.1CH,Dolby

TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD

Master Audio as well as 3D video content.

This matrix also features audio breakout whereby deembedded analogue L/R audio outputs are provided for each of the HDBaseT zones (A to D). The Power over HDBaseT (PoH) function provides power to the supplied PUV-1210PL-RX receivers which also support 2-way IR and RS-232 pass-through.

Control is via manual selection buttons, IR, RS-232,

Telnet or Web GUI. CYP provide control drivers for all the major control systems.

FEATURES

• HDMI, HDCP1.4 and HDCP2.2 compliant

• Routes four HDMI sources to six displays using four HDBaseT

LITE outputs and two independent HDMI outputs

• Supported HDBaseT resolutions: VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV

4:2:2), 4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 35m via

CAT5e/6 and 60m via CAT6a/7

• Supports pass-through of HD audio formats: LPCM

2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus,

Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio

• Supports breakout of L/R analogue audio for each

HDBaseT Zones (Outputs A to D).

• Control is via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)

• Compact 1U rack mount design

• Supplied with 4x PUV-1210PL-RX receivers (see Page 79 for specifications)

SPECIFICATIONS

Input:

Output:

4x HDMI Uncompressed AV and Data (1x

HDMI)

5x Infra Red Receiver (1x 3.5mm Stereo mini-jack)

1x RS-232 Data (1x 9pin Dsub)

1x IP Control / LAN Serving (1x RJ45)

1x Service Port Propriety Data (1x USB

Type A)

4x HDBaseT HDMI & Propriety Data (1x RJ45)

2x HDMI Uncompressed AV and Data (1x

HDMI)

4x Zone Analogue Stereo (L/R) (2x RCA)

5x Infra Red Emitter (1x 3.5mm Stereo mini-jack)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/

UL certified)

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/

UL certified)

Dimensions: 316mm (W) x 438mm (D) x 96mm (H)

Gross

Weight:

8500g Net. Weight: 6500g

P I O N E E R S I N A V T E C H N O L O G I E S

4x4 HDBaseT™ LITE Matrix (60m)

Express Installation Kit-Supplied with 4x PU-514L-RX Receivers

PU-44XL-KIT

3D HDMI HDBT SUPPLIED WITH 4xPU-5I4L-RX RECEIVERS

This 4 by 4 HDMI HDBaseT™ Lite Matrix Express

Installation Kit has been developed as a robust and cost effective solution at the heart of any four zone multi-room environment. Supplied complete with a

HDBaseT Lite Matrix plus four PU-514L-RX receivers, the kit enables an installer to easily and confidently configure a 4-zone multi-room AV system using

HDBaseT Lite technology and distribute content throughout the system over a Single CAT5e/6/7 cable infrastructure.

The Express Install Kit supports the transmission of video (resolutions up to 1080p Full HD and

[email protected]), multi-channel digital audio, and control via IR, RS-232, or Web GUI/Telnet IP, from four high definition sources to four HDBaseT outputs over a single CAT5e/6/7 cable (up to 60m) for each output.

The PU-44XL-KIT is supplied with 4x PU-514L-

RX receivers which utilise the 2-way IR control capabilities of the matrix.  Utilise the USB power output from a TV as an optional way of powering the PU-514L-RX receiver unit alternative to a mains power supply.

Use the IP control feature to enable users to access and control the matrix remotely and also allow additional options for integration of third-party control systems. CYP provide control drivers for control systems such as Control 4, RTI, Crestron, AMX, and Control FX. These are available at no extra cost.

FEATURES

• Supports all v1.3 HDMI resolutions

• Supports uncompressed video/audio up to 10.2Gbps

• Common supported resolutions: HDTV: 480p, 576p, 720p,

1080i, 1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA,

UXGA, WUXGA.

• HDMI, HDCP and DVI complaint

• High Definition Audio supported: Dolby TrueHD, Dolby Digital

Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Uncompressed data transfer over single CAT cable (60m

- CAT5e/6/7)

• Supports third-party control systems, with drivers available for: Control FX, AMX, Crestron, RTI, Control 4

• Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.

• Supports RS-232, 2-Way IR and Manual Selection Buttons

• Selectable EDID settings - TV (downstream) and STD (fixed)

• Supports 3D signals

• Supports additional IR Control via a master (ALL) Input/Output

• Supports full IP control

• Supplied with 4x PU-514L-RX receivers (see Page 93 for specifications)

• Choose to power the PU-514L-RX via the USB output from a TV (Cable available separately - APC-USB): * Please note the performance and consistency of USB power outputs from TVs can vary and cannot be guaranteed by CYP.

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

5x 3.5mm Stereo mini-jack (5x IR Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Mini B (1x Service Port - Propriety Data

Output:

4x RJ45 (4x HDBaseT Lite - HDMI & Propriety

Data)

5x 3.5mm Stereo mini-jack (5x IR Emitter)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/

UL certified)

Dimensions: 440mm (W) x 265mm (D) x 50mm (H)

Gross

Weight:

5160g Net. Weight: 3300g

P I O N E E R S I N A V T E C H N O L O G I E S

27

28

4x4 HDMI Matrix Switcher

4K, HDCP2.2, HDMI2.0

OR-44-4K22

4K 3D HDMI2.0 HDCP2.2

This 4x4 HDMI Matrix Switcher is designed to enable the user to switch between any of the four connected HDMI sources to send video and audio to any of the four connected HDMI display.

This matrix switcher fully supports 4K resolutions and is HDMI2.0 and HDCP 2.2 compliant, ensuring maximum compatibility with the latest 4K UHD sources and displays. The unit supports all the latest features of the HDMI2.0 specification such as 4K UHD resolutions ([email protected] - YUV4:4:4),

HDR (High Dynamic Range), 'Deep Color', and High

Definition audio. Control is via manual selection buttons, IR, RS-232, Telnet or Web GUI.

SPECIFICATIONS

Input:

4x HDMI Uncompressed AV and Data (1x HDMI)

1x Infra Red Receiver (1x 3.5mm Stereo mini-jack)

1x RS-232 Data (1x 9pin Dsub)

1x IP Control (1x RJ45)

Output:

Power:

4x HDMI Uncompressed AV and Data (1x HDMI)

24V/3.75A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 160mm (W) x 436mm (D) x 44mm (H)

Gross

Weight:

2800g

Net. Weight: 1945g

FEATURES

• HDMI2.0 and HDCP2.2 compliant

• Routes four HDMI sources to four HDMI displays

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• 4K UHD resolutions ([email protected] - YUV4:4:4)

• Supports HDR (High Dynamic Range) and Deep

Colour

P I O N E E R S I N A V T E C H N O L O G I E S

4x4 HDMI Matrix Switcher

OR-HD44S

3D HDMI

FEATURES

The OR-HD44S Matrix Switcher connects four HDMI sources to four displays allowing any source to be independently displayed on any screen. This matrix switcher can be controlled via the supplied remote control, RS-232, or by using the input switching buttons on the front of the device. This device is compatible to v1.3 HDMI specifications, supporting ‘Deep

Colour’, High Definition Audio, and 3D signal compatibility.

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 RS-232 Data)

1x 3.5mm Stereo mini-jack (1x IR In Infra Red Receiver)

Output:

Power:

4x HDMI (4x HDMI Uncompressed AV and Data)

5V/6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 440mm (W) x 175mm (D) x 48mm (H)

Gross

Weight:

2180g

Net. Weight: 1800g

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• 4 x 4 HDMI Matrix Switcher

• Resolutions supported: PC - VGA to UXGA; HDTV

- 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• The HDMI input is compensated, clock / phase adjusted, and jitter eliminated so the output is a brand new standard HDMI signal

• Supports IR remote control and IR extender together with RS-232 control

• Supports 'Deep Colour' (10 & 12 bit)

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Power, HDMI/DVI & HDCP plus independent output LED's indicator

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

29

Audio

CYP offer an unrivalled range of audio distibution solutions for professional installers. When it comes to the unique connectivity challenges faced within any installation, CYP offer real world "get out of jail" solutions that optimise the audio performance within any AV environment.

Our comprehensive range includes amplifiers, audio format converters including digital to analogue converters (DAC's), signal splitters plus switchers,

HDMI audio signal management, and solutions for sending audio signals long distances via CAT cabling infrastructure.

HDBaseT™ 2 Channel Digital AV Receiver

(Repeatable)

AU-A300-HBT

32

ADC DAC HDMI HDBT PoC

FEATURES

The AU-A300-HBT is a compact 2 channel digital receiver that is perfect for providing high quality audio distribution in remote AV zones within any multi-room installation. This advanced solution can integrate local HDMI and remote

HDBaseT sources from a CYP matrix, local inputs (iPod® and

MP3 etc) via the stereo and digital inputs and even utilise the audio output from a  TV, which is growing in popularity as a dedicated source within an AV system. The device also incorporates a HDBaseT output that can be used for creating additional HDBaseT zones or used to repeat the signal to further HDBaseT 2-Channel Digital AV Receivers.

• 30W per channel digital stereo Amplifier

• Integrated HDBaseT Input and Output

• Control via remote control, RS-232 or IP (Web

GUI or Telnet)

• Simultaneous audio outputs

• HDMI Audio Embedding

• Supports Digital to Analogue (DAC) and

Analogue to Digital (ADC) conversion

• Compact design for remote in-zone application

• Supports PoC (Power over Cable) for connected compatible HDBaseT receivers

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x RCA (1x Coaxial 2 Channel LPCM)

1x Toslink (1x Optical 2 Channel LPCM)

2x RCA (1x Analogue Stereo (L/R))

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x RJ45 (1x Keypad - reserved for future use - Propriety

Data)

1x USB Type A (1x Service Port Propriety Data)

Output:

4x Speaker Binding Posts (1x Speaker Level Stereo

Output)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

Power:

24V/3.75A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 215mm (W) x 150mm (D) x 50mm (H)

Gross Weight: 1960g

Net. Weight: 1640g

P I O N E E R S I N A V T E C H N O L O G I E S

Integrated 2 Channel Zone Amplifier

AU-A300

ADC DAC HDMI PoC

FEATURES

The AU-A300 is a compact 2 channel digital amplifier that is perfect for providing high quality audio distribution into remote AV zones within any multi-room installation. This advanced solution can integrate HDMI audio outputs from a CYP matrix, local inputs (iPod® and MP3 etc) via the stereo and digital inputs and even utilise the audio output from a  TV, which is growing in popularity as a dedicated source within an AV system.

SPECIFICATIONS

Input:

Output:

2x HDMI (2x HDMI Uncompressed AV and Data)

1x XLR (1x Microphone)

1x Toslink (1x Optical - 2 Channel LPCM)

1x RCA (1x Coaxial - 2 Channel LPCM)

2x RCA (1x Analogue - Stereo (L/R))

1x 3.5mm Stereo mini-jack (1x Analogue - Stereo(L/R))

1x RJ45 (1x IP Control)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x Toslink (1x Optical - 2 Channel LPCM)

1x RCA (1x Coaxial - 2 Channel LPCM)

2x RCA (1x Analogue - Stereo (L/R))

4x Speaker Binding Posts (1x Speaker Level Stereo

Output)

Power:

24V/4.16A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 255mm (W) x 170mm (D) x 48mm (H)

Gross Weight: 2260g

Net. Weight: 1060g

• 30W per channel digital stereo Amplifier

• Inputs: 2 x HDMI, 1 x L/R Stereo audio, 1 x

Optical, 1 x Digital Co-Ax, 1 x 3.5mm Stereo

• Outputs: 1 x HDMI, 1 x Optical, 1 x Digital Co-Ax,

1 x L/R Stereo (Line Level output), Speaker

Terminals

• Control via remote control, RS-232 or IP (Web

GUI or Telnet)

• Simultaneous audio outputs

• Dedicated Microphone input for commercial applications

• Supports Digital to Analogue (DAC) and

Analogue to Digital (ADC) conversion

• Compact design for remote application

P I O N E E R S I N A V T E C H N O L O G I E S

33

Integrated 2 Channel Zone Amplifier

(Audio Only)

AU-A50

34

ADC DAC

FEATURES

The AU-A50 is a compact 2 channel digital zone amplifier that is perfect for providing high quality audio distribution into remote AV zones within any multi-room installation.

This advanced solution can integrate digital and analogue audio signals from multiple sources, including an audio output from a TV, enabling sound re-enforcement within any zone.

• 30W per channel digital stereo Amplifier

• Control via remote control, RS-232 or IP (Web

GUI or Telnet)

• Single zone amplifier

• LCD Display

• Compact design for remote in-zone application

• Supports on-board audio over CAT inputs and outputs for transmission up to 150m

SPECIFICATIONS

Input:

1x RCA (1x Coaxial 2 Channel LPCM)

1x Toslink (1x Optical 2 Channel LPCM)

2x RCA (1x Analogue Stereo (L/R))

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x RJ45 (1x IP Control)

1x RJ45 (1x Keypad - Reserved for future use - Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x USB Type A (1x Service Port Propriety Data)

Output:

4x Speaker Binding Posts (1x Speaker Level Stereo

Output)

Power:

24V/3.75A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 215mm (W) x 150mm (D) x 50mm (H)

Gross

Weight:

1680g

Net. Weight: 1380g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Audio De-embedder

with Dolby® Digital & DTS® Decoder (4K, HDCP2.2 & HDMI2.0)

AU-1H1DD-4K22

ADC DAC 4K 3D HDMI2.0 HDCP2.2

FEATURES

The AU-1H1DD-4K22 is an advanced solution for deembedding and down-mixing audio signals from the HDMI input (up to Dolby® Digital and DTS® 2.0+Digital Out). Connect the AU-1H1DD between the source and your display via HDMI, and select 2CH LPCM or bypass.

The digital audio outputs can be set to either 2CH LPCM or bypass. The L/R analogue outputs will always output down-mixed stereo (with audio  up to Dolby® Digital and

DTS® 2.0+Digital Out). This device supports the latest 4K2K resolutions, HDMI2.0 and HDCP2.2 for stunning results.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI 2.0 (ARC) Uncompressed AV and

Data)

Output:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

2x RCA (1x Analogue audio Stereo (L/R))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

1x RCA (1x Coaxial Dolby Digital / DTS / 2 Channel

LPCM)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 180mm (W) x 111mm (D) x 25mm (H)

Gross

Weight:

868g

Net. Weight: 368g

• HDCP 2.2, HDMI2.0, and DVI compatible

• Built-in Dolby Digital Decoder

• Built-in DTS 2.0+Digital Out Decoder

• Integrated digital interpolator filter and Digitalto-Analog Converter (DAC)

• Supports HDTV resolutions up to

4K2K: [email protected]/25/30Hz,

[email protected]/25/30Hz, [email protected]/60Hz

(YUV444) & [email protected]/60 (YUV444)

• Supports simultaneous audio outputs on HDMI, analogue L/R, Coaxial and Optical

• Supports Dolby Digital sampling rates up to

48kHz

• Supports DTS sampling rates up to 96kHz

• Supports LPCM input sampling rates up to

96kHz

• Supports coaxial and optical output audio sampling rates up to 96kHz

• Supports de-embedding the audio signal from an HDTV’s ARC (Audio Return Channel) connection

• Supports up to 3m HDMI cables on input & output

P I O N E E R S I N A V T E C H N O L O G I E S

35

HDMI Audio De-embedder (up to 7.1)

with built-in Repeater (4K, HDCP2.2, HDMI2.0)

AU-11SA-4K22

36

4K 3D HDMI2.0

HDCP2.2

FEATURES

The AU-11SA-4K22 advanced digital audio decoder is designed to de-embed 2-channel or multi-channel audio from the connected HDMI input and breakout this audio to provide 7.1 analogue audio connections, plus a 5.1 optical audio output and a HDMI bypass output. This device supports  bypass of high resolution digital audio formats including LPCM 7.1CH,

Dolby TrueHD, Dolby Digital  Plus, Dolby Atmos and DTS-

HD Master Audio, and supports audio sampling rates up to 192kHz.

In addition, the AU-11SA-4K22 supports 4K video resolutions,

HDMI 2.0, and HDCP 2.2 ensuring stunning results and maximum compatibility for any AV system.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

• HDMI 2.0, HDCP 2.2 and DVI compliant

• HDMI audio decoder with built in repeater

• Supports HDTV resolutions up to 4Kx2K

([email protected]/25/30/ 50/60 YUV_444 &

[email protected]/25/30/50/60 YUV_444)

• The optical output supported audio: LPCM,

Dolby Digital and DTS up to 5.1

• HDMI Bypass output supported audio: Dolby

True HD, Dolby Digital Plus, and DTS-HD Master

Audio

• Analogue stereo audio outputs support LPCM 2 channel, 5.1 and 7.1

• Audio sampling rate up to 192 kHz

• HDMI supports high-bit-rate (HBR) audio

• Features CEC bypass function

Output:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x Toslink (1x Optical Dolby Digital / DTS / 2 Channel

LPCM)

1x RCA (1x Front Left Mono)

1x RCA (1x Front Right Mono)

1x RCA (1x Front Centre Mono)

1x RCA (1x Low Frequency Effect Mono)

1x RCA (1x Right Rear Mono)

1x RCA (1x Rear Left Mono)

1x RCA (1x Rear Right Centre Mono)

1x RCA (1x Rear Left Centre Mono)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 118mm (W) x 231mm (D) x 25mm (H)

Gross

Weight:

818g

Net. Weight: 620g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Audio De-embedder (7.1)

with built-in Repeater

AU-11SA

3D HDMI

The AU-11SA is an advanced solution for HDMI to HDMI repeating with Audio de-embedding. It's compatible with v1.3 HDMI specifications, a cutting edge technology which defines the transfer of deep colour (12 bit) video with a high bandwidth of up to 225Mhz. Connect to source and display

(HDMI), select the required audio format & output your audio format to your amplifier.This device has advanced firmware allowing audio to be de-embedded without the need to connect the HDMI display (no sink-end required).

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Stereo(L/R))

1x 3.5mm Stereo mini-jack (1x LowFrequencyEffect(LFE) & Front Centre(FC))

1x 3.5mm Stereo mini-jack (1x RearLeft(RL) & Rear

Right(RR))

1x 3.5mm Stereo mini-jack (1x RearLeftCentre(RLC) &

RearRightCentre(RRC))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 102mm (W) x 146mm (D) x 25mm (H)

FEATURES

• HDMI audio de-embedder with built in repeater

• Compliant with v1.3 HDMI, HDCP 1.1 and DVI

1.1 standards

• Supports un-compressed digital LPCM 7.1, 5.1 or 2 channels and compressed digital Bitstream

(Dolby TrueHD, Dolby Digital Plus, and DTS-HD

Master Audio) through HDMI input and output ports

• Output resolution follows input resolution.

Video pass though, no scaling

• HDMI signal amplification and equalisation supporting HDMI cable distance of 10m either side of the device at full 1080p.

• Supports LPCM 7.1, 5.1 or 2 channel output through multichannel analogue output ports

• Supports digital Dolby 5.1/2 and LPCM 2 channels output through optical output

• Supports CEC bypass

• Supports 3D signals

• Supports xvYCC

Gross

Weight:

780g

Net. Weight: 500g

P I O N E E R S I N A V T E C H N O L O G I E S

37

38

HDMI Audio De-embedder (up to 5.1)

with built-in Repeater (4K, HDCP2.2, HDMI2.0)

AU-11CD-4K22

4K 3D HDMI2.0

HDCP2.2

FEATURES

The AU-11CD-4K22 is an advanced solution for repeating

HDMI with integrated Audio de-embedding, up to 5.1.

Connect the AU-11CD-4K22 between your source and display via HDMI, and select the audio format required. This device supports 4K resolutions, HDMI 2.0 and HDCP 2.2 enabling flexible audio signal management from ultra high definition video signal paths. The built-in HDMI repeater function allows users to extend the transmission distance of up to [email protected] resolutions a further 5m from the device HDMI output.

SPECIFICATIONS

Input:

Output:

Power:

Gross

Weight:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x Toslink (1x Optical 2 Channel LPCM)

2x RCA (1x Analogue audio Stereo (L/R))

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 128mm (W) x 117mm (D) x 30mm (H)

595g

• HDMI2.0, HDCP 2.2, and DVI compliant

• Supports HDTV resolutions up to 4Kx2K

([email protected]/25/30/ 50/60 YUV_444 &

[email protected]/25/30/50/60 YUV_444).

• Supports bypass of high resolution digital audio formats including LPCM 7.1CH, Dolby TrueHD,

Dolby Digital Plus, Dolby Atmos and DTS-HD

Master Audio

• Supports HDMI audio sampling rate up to 192 kHz

• Supports Optical S/PDIF audio sampling rate up to 192 kHz

• Supports external HDMI, Digital or Analog audio signal embeds into HDMI

• HDMI supports high-bit-rate (HBR) audio

• Supports DVI conversion with HDMI to DVI adaptor

• Supports CEC bypass

• Supports analog stereo L/R and Optical S/PDIF audio outputs

Net. Weight: 358g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Audio De-Embedder (5.1)

with built in Repeater

AU-11CD

3D HDMI

The AU-11CD is an advanced solution for repeating HDMI with integrated Audio de-embedding, up to 5.1. Connect the AU-

11CD between your source and display via HDMI, and select the audio format required.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

2x RCA (1x Analogue Stereo (L/R))

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 90mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

440g

Net. Weight: 260g

FEATURES

• Compliant with v1.3 HDMI, HDCP 1.2 and DVI 1.0

• Supports HDMI Sample Rates up to 192 kHz

• Supports Optical Sample Rate up to 48 kHz

• Supports TMDS clock frequency rate 225MHz

• Supports high-bit-rate (HBR) audio

• Supports resolutions of 1080P up to cable lengths of 10m either side of the device

• Supports built-in audio EDID switch of LPCM2,

5.1/7.1 or Bitstream

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

39

40

HDMI Audio Embedder

with built-in Repeater (4K, HDCP2.2, HDMI2.0)

AU-11CA-4K22

4K 3D HDMI2.0

The AU-11CA-4K Audio Embedder lets you insert an external audio signal into any HDMI source. The device allows you to insert analogue or digital stereo and multi-channel digital surround sound signals (via Optical) to give users the capability to overcome audio issues within complex HDMI installation.

The AU-11CA-4K also repeats the HDMI signal to allow an extended total HDMI cable range. This device supports 4K resolutions enabling flexible audio signal management into ultra high definition video signal paths.

SPECIFICATIONS

Input:

HDCP2.2

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x Toslink (1x Optical 2 Channel LPCM / Dolby Digital

/ DTS)

1x USB Mini B (1x Service - Propriety Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 85mm (D) x 35mm (H)

FEATURES

• Compliant with HDMI, HDCP 1.2 and DVI 1.0

• Supports HDMI and Optical S/PDIF audio sample rate up to 192 kHz

• Supports LPCM Stereo, DTS and Dolby Digital via Optical input

• HDMI signal amplification and equalisation supporting HDMI cable distance of 10m either side of the device at full 1080p.

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports 3D signals

Gross

Weight:

440g

Net. Weight: 260g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Audio Embedder

with built in Repeater

AU-11CA

3D HDMI

FEATURES

The AU-11CA Audio Embedder lets you embed an external audio signal into any HDMI source. The device allows you to embed analogue or digital stereo and multi-channel digital surround sound signals (via Optical) to give users the capability to overcome audio issues within complex HDMI installation. The AU-11CA also repeats the HDMI signal to allow an extended total HDMI cable range.

• Compliant with HDMI v1.3 , HDCP 1.2 and DVI 1.0

• Supports Optical Sample Rate up to 96 kHz

• Supports LPCM Stereo, DTS and Dolby Digital via Optical input

• Supports up to 24bit resolution digital audio

• Supports resolutions of 1080P up to cable lengths of 10m either side of the device

• Supports HDMI Sample Rates up to 192 kHz

• Supports 3D signals

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

2x RCA (1x Analogue Stereo (L/R))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

440g

Net. Weight: 260g

P I O N E E R S I N A V T E C H N O L O G I E S

41

42

Dolby®/DTS® Digital Downmixer

with Digital/Analogue Audio Conversion

AU-22DD

ADC DAC

FEATURES

The AU-22DD is a versatile audio converter allowing users to convert analogue audio signals to digital or digital audio signals to analogue. The AU-22DD supports Dolby Digital and DTS audio downmixing, and can simultaneously output from all 3 audio formats without any signal loss, adding extra flexibility to your AV system.

SPECIFICATIONS

Input:

1x Toslink (1x Optical Dolby Digital / DTS / 2 Channel

LPCM)

1x RCA (1x Coaxial Dolby Digital / DTS / 2 Channel

LPCM)

2x RCA (1x Analogue Stereo (L/R))

• Embedded Dolby Digital & DTS Decoder technology for Digital downmixing

• Bi-directional Digital/Analogue Audio Converter

• Three-way conversion; Coaxial to Optical &

Analogue, Optical to Coaxial & Analogue, and

Analogue to Optical & Coaxial

• Integrated digital interpolator filter and Digitalto-Analogue Converter (DAC)

• Sampling rates 32 to 96 KHz

• Provides electromagnetic noise free transmission

Output:

2x RCA (1x Analogue Stereo (L/R))

1x RCA (1x Coaxial Dolby Digital / DTS / 2 Channel

LPCM)

1x Toslink (1x Optical Dolby Digital / DTS / 2 Channel

LPCM)

Power:

5V/1A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 97mm (D) x 35mm (H)

Gross

Weight:

130g

Net. Weight: 108g

P I O N E E R S I N A V T E C H N O L O G I E S

Dolby®Digital Downmixer

with Digital/Analogue Audio Conversion

AU-11DD

ADC DAC

The AU-11DD is designed to decode and downmix Dolby

Digital audio signals to stereo. All outputs are simultaneous which is excellent for multi-room audio environments where both digital and analogue zones are required.

SPECIFICATIONS

Input:

2x RCA (1x Analogue Stereo (L/R))

1x RCA (1x Coaxial Dolby Digital / 2 Channel LPCM)

1x Toslink (1x Optical Dolby Digital / 2 Channel LPCM

Output:

2x RCA (1x Analogue Stereo (L/R))

1x RCA (1x Coaxial Dolby Digital / 2 Channel LPCM)

1x Toslink (1x Optical Dolby Digital / 2 Channel LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 95mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

360g

Net. Weight: 100g

FEATURES

• Embedded Dolby Digital Decoder technology for Digital downmixing

• Supports Dolby Digital, Analogue Stereo, &

LPCM Stereo signals

• Integrated digital interpolator filter and Digitalto-Analogue Converter (DAC)

• Integrated Analogue-to-Digital Converter (ADC)

• Supports Dolby Digital audio downmixing to

2-Channel Stereo audio

• Supports Dolby Digital sampling rate 48kHz

• Supports LPCM input sampling rates from 32 to 96 kHz

• Output sampling rate is adjusted to 48kHz

• Provides electromagnetic-noise-free transmission

• Supports simultaneous outputs for added signal management flexibility, where Digital outputs maintain the Dolby Digital signal

P I O N E E R S I N A V T E C H N O L O G I E S

43

Coaxial to L/R Stereo Audio Converter (DAC)

with Dolby® Digital/DTS® Decoder

AU-D5D

DAC

The AU-D5D is a digital to analogue converter (DAC) which allows the user to easily downmix digital coaxial signals to analogue stereo audio. The AU-D5D features Dolby Digital and DTS decoding allowing for seamless integration to any AV system.

FEATURES

• Dolby Digital and DTS downmixing

• Digital coaxial to analogue stereo audio conversion (DAC)

• Coaxial input supports DTS up to 5.1 with audio sampling rates up to 96KHz and Dolby Digital up to 5.1 with audio sampling rates of 48KHz

• Supports SPDIF bitstream 24-bit of data for the left and right channels

SPECIFICATIONS

Input:

1x RCA (1x Coaxial Dolby Digital / DTS / 2 Channel LPCM)

Output:

Power:

2x RCA (1x Analogue Stereo (L/R))

5V/1A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 36mm (W) x 55mm (D) x 22mm (H)

Gross

Weight:

70g

Net. Weight: 42g

44

P I O N E E R S I N A V T E C H N O L O G I E S

Optical to L/R Stereo Audio Converter (DAC)

with Dolby® Digital Decoder

AU-D1D

DAC

FEATURES

The AU-D1D is a Dolby Digital to Analogue audio converter

(DAC) which allows the user to easily convert digital Optical signals to analogue L/R Stereo for connection to any AV receiver.  With audio sampling rate support up to 48 kHz

(Dolby Digital)/96 kHz (LPCM) and I/O data rate support up to

24-bit, the AU-D1D provides high quality sound conversion.

The Dolby Digital Decoder function guarantees that Dolby digital audio signals are downmixed to analogue stereo without loss of quality

This device is perfect for use in digital recording systems, computer audio systems or digital mixing consoles and is powered from any USB port allowing it to be used with USB equipped HDTVs, Blu-ray players or computers without the need for a separate power supply. With many of the latest generation of HDTVs now only providing an optical audio output, the AU-D1D allows the user to easily integrate the digital audio signal into their AV receiver.

• Supports optical digital audio signal input and conversion to L/R analogue audio signal output (DAC)

• Supports uncompressed digital LPCM stereo or

Dolby Digital 5.1CH audio inputs

• Supports LPCM audio sampling rates from 32 to

96 kHz (32, 44.1, 48, 88.2 and 96 kHz).

• Supports Dolby Digital audio sampling rates of

32, 44.1 and 48 kHz

• Supports Dolby Digital audio downmixing to

2-channel audio

• Supports S/PDIF bitstream 24-bit of data for the left and right channels

• USB powered : 0.75m USB cable included

SPECIFICATIONS

Input:

1x Toslink (1x Optical 2 Channel LPCM / Dolby Digital)

Output:

Power:

2x RCA (1x Analogue Stereo (L/R))

USB powered

Dimensions: 55mm (W) x 80mm (D) x 22mm (H)

Gross

Weight:

160g

Net. Weight: 40g

P I O N E E R S I N A V T E C H N O L O G I E S

45

46

Bi-Directional Digital/Analogue Audio

Converter (DAC)

AU-D9

ADC DAC

FEATURES

The AU-D9 is a versatile audio converter allowing users to convert analogue audio into digital or digital audio into analogue. It can simultaneously output in all 3 audio formats without any signal loss.

SPECIFICATIONS

Input:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

2x RCA (1x Analogue Stereo (L/R))

Output:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

2x RCA (1x Analogue Stereo (L/R))

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 95mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

420g

Net. Weight: 200g

• Bi-directional Digital/Analogue Audio Converter

• Three-way conversion; Coaxial to Optical &

Analogue, Optical to Coaxial & Analogue, and

Analogue to Optical & Coaxial

• Integrated digital interpolator filter and Digitalto-Analogue Converter (DAC)

• Supports 2 phono stereo, digital co-axial and digital optical signal inputs.

• Supports sample rates from 16 to 100kHz

• Simultaneously outputs digital coaxial, digital optical and 2 phono stereo audio signals

• Provides electromagnetic-noise-free transmission

P I O N E E R S I N A V T E C H N O L O G I E S

Digital Audio to Stereo Audio Converter

(DAC) - 192kHz

AU-D3-192

DAC

FEATURES

The AU-D3-192 is designed to convert either Coaxial or

Optical signals from a digital stereo signal to analogue stereo audio. With an advanced 192kHz sampling rate, this unit is particularly useful for enhancing sound reproduction when connecting digital sources to analogue amplifiers.

SPECIFICATIONS

Input:

1x RCA (1x Coaxial 2 Channel LPCM)

1x Toslink (1x Optical 2 Channel LPCM)

• Digital Audio to Left/Right Stereo Audio

Converter (DAC) with improved 192kHz sample rate for enhanced sound reproduction

• Integrated digital interpolator filter

• Supports digital audio signal (Coaxial/Toslink) input and analogue audio signal (L/R) output

• Accepts uncompressed digital stereo audio input

• Accepts 16 or 24bit: 32, 44.1, 48, 88.2, 96, 176.4 and 192kHz sample rates

Output:

Power:

2x RCA (1x Analogue Stereo (L/R))

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 42mm (W) x 57mm (D) x 25mm (H)

Gross

Weight:

220g

Net. Weight: 140g

P I O N E E R S I N A V T E C H N O L O G I E S

47

Analogue to Digital Audio Converter

AU-D4

ADC

The AU-D4 is designed to convert analogue stereo audio to

Digital Coaxial and Optical (Toslink) outputs simultaneously.

SPECIFICATIONS

Input:

2x RCA (1x Analogue Stereo (L/R))

Output:

1x RCA (1x Coaxial 2 Channel LPCM)

1x Toslink (1x Optical 2 Channel LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 45mm (W) x 45mm (D) x 25mm (H)

Gross

Weight:

220g

Net. Weight: 160g

FEATURES

• Analogue to Digital Audio Converter (ADC)

• Uncompressed 2-channel LPCM digital audio signal output

• Compatible with cable lengths of 5m either side of the device

• Output sampling rate: 48kHz

• Electromagnetic noise-free transmission

48

P I O N E E R S I N A V T E C H N O L O G I E S

Digital Audio Coaxial to Toslink Converter

AU-D2

ADC DAC

The AU-D2 is a versatile digital audio converter, either coaxial to optical or optical to coaxial.  Simply select one of the digital audio inputs for two identical audio signals in both output formats.

SPECIFICATIONS

Input:

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 58mm (W) x 46mm (D) x 24mm (H)

Gross

Weight:

220g

Net. Weight: 160g

FEATURES

• Digital Audio Coaxial/Optical bi-directional

Converter

• Two-way conversion; Coaxial to Optical or

Optical to Coaxial

• Re-clocking function enables the use of extended cable distances

• Inputs accept audio signals from 2-channel PCM to 5.1. Output signal follows input signal

• Select between input ports, and distribute the audio signal to both Coaxial and Optical output ports simultaneously

P I O N E E R S I N A V T E C H N O L O G I E S

49

50

4-Way Optical Audio Switcher

with IR remote

AU-D41

IR REMOTE CONTROL Optical

FEATURES

The AU-D41 Optical Audio Switcher has four optical inputs and one optical output. This device allows users with up to four optical sources, the ability to switch between sources whilst connected to one output display or amplifier. All signals are bypassed without delay. This device has 'last memory function' and an IR remote control for convenient use.

• 4-Way Digital Optical Audio Switcher

• Optical sampling rate supports up to 192 kHz.

• Up to 24bit resolution.

• PCM2, AC3/5.1, Dolby 5.1 & DTS 5.1 pass through.

• Compatible with cable lengths of 5m either side of the device

• Supplied with IR Remote Control

SPECIFICATIONS

Input:

4x Toslink (4x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

400g

Net. Weight: 200g

P I O N E E R S I N A V T E C H N O L O G I E S

2-Way Digital Optical Audio Switcher

AU-D21

Optical

The AU-D21 is an Optical (Toslink) switcher, select between two Optical (Toslink) sources to one Optical (Toslink) output

& maintain a reliable and loss-less audio signal transmission.

SPECIFICATIONS

Input:

2x Toslink (2x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 45mm (W) x 45mm (D) x 25mm (H)

Gross

Weight:

200g

Net. Weight: 140g

FEATURES

• 2-Way Digital Optical Audio Switcher

• Supports S/PDIF standard of digital audio transmission

• Compatible with cable lengths of 5m either side of the device

• Accepts uncompressed 2-channel LPCM

(Linear Pulse Code Modulation) & compressed

2-channel and multi-channel Dolby and DTS audio signal

• Electromagnetic noise-free transmission

P I O N E E R S I N A V T E C H N O L O G I E S

51

8 to 20 Digital Audio Switchable

Distribution Amplifier

AU-D820S

52

IR Control RS-232 Optical

FEATURES

The AU-D820 allows the user to switch and distribute 4

Digital Coaxial inputs and 4 Digital Optical audio inputs to

10 Digital Coaxial and 10 Digital Optical outputs. Select any audio input for distribution of the audio signal to all outputs simultaneously. Incoming audio signals are converted to allow all optical and coaxial outputs to operate simultaneously.

Supporting sampling rate up to 192kHz and audio signal up to 5.1CH, this device maximises audio distribution to multiple outputs. A typical application for this switching and distribution device is for use in retail environments such as a hi-fi store. It allows multiple audio source signals to be easily managed for demonstration of sources and amplifiers to a consumer, for example.

Control is via selection buttons on the device or via IR or

RS-232.

• Supports 4x Coaxial + 4x Optical Inputs, and 10x

Coaxial + 10x Optical outputs

• Supports LPCM 2-Channel Audio signals

• Supports up to 192kHz Sampling Rate

• Supports Dolby & DTS audio bypass

SPECIFICATIONS

Input:

4x RCA (4x Coaxial 2 Channel LPCM/Dolby Digital/DTS)

4x Toslink (4x Optical 2 Channel LPCM/Dolby Digital/

DTS)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

Output:

10x RCA (10x Coaxial 2 Channel LPCM/Dolby Digital/

DTS)

10x Toslink (10x Optical 2 Channel LPCM/Dolby

Digital/DTS)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 438mm (W) x 130mm (D) x 45mm (H)

Gross

Weight:

2500g

Net. Weight: 1580g

P I O N E E R S I N A V T E C H N O L O G I E S

4-Way Digital Optical Audio Splitter

AU-D14

Optical

The AU-D14 is a digital audio splitter with one Optical (Toslink) input to four Optical (Toslink) outputs, which maintains a reliable and loss-less audio signal transmission.

SPECIFICATIONS

Input:

1x Toslink (1x Optical 2 Channel LPCM/Dolby Digital/

DTS)

Output:

4x Toslink (4x Optical 2 Channel LPCM/Dolby Digital/

DTS)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 85mm (D) x 35mm (H)

Gross

Weight:

360g

Net. Weight: 100g

FEATURES

• Supports one optical input and four optical outputs

• Supports 2 Channel LPCM audio signal

(sampling rate up to 192kHz)

• Supports Dolby and DTS audio signal bypass

• Supports SPDIF bandwidth from 32kHz to

192kHz

• Low power consumption

P I O N E E R S I N A V T E C H N O L O G I E S

53

2-Way Digital Optical Audio Splitter

AU-D12

Optical

The AU-D12 is a digital audio splitter with one Optical (Toslink) input to two Optical (Toslink) outputs, which maintains a reliable and loss-less audio signal transmission.

SPECIFICATIONS

Input:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

2x Toslink (2x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 45mm (W) x 45mm (D) x 25mm (H)

Gross

Weight:

200g

Net. Weight: 140g

FEATURES

• 1 to 2 Optical (Toslink) Distribution Amplifier

• Supports S/PDIF standard of digital audio transmission

• Compatible with cable lengths of 5m either side of the device

• Accepts Uncompressed 2-channel LPCM

(Linear Pulse Code Modulation) & Compressed

2-channel and multi-channel Dolby and DTS audio signal

• Electromagnetic noise-free transmission

54

P I O N E E R S I N A V T E C H N O L O G I E S

Advanced DAC with HDMI Switching

and Audio Breakout (4K, HDCP2.2, HDMI2.0)

AU-D250-4K22

ADC DAC 4K 3D HDMI2.0

HDCP2.2 USB AUDIO XLR IR Control Optical Coaxial

The AU-D250-4K22 is designed to integrate and convert both analogue and digital audio signals into any AV system.

This device has an in-built sample rate converter which can upscale audio signals between 44.1kHz to 192kHz (24 bit).

With 4K resolution support, HDMI2.0 and HDCP2.2 compliance, the AU-D250-4K22 also enables switching of up to 4 HDMI sources to a single HDMI output, and allows the user to embed or de-embed audio within the HDMI signal path.

The AU-D250 not only provides a truly enhanced listening experience, but also the flexibility to manage all audio signals in your AV system.

SPECIFICATIONS

Input:

1x 3.5mm Stereo mini-jack (1x Line in Stereo(L/R))

4x HDMI (4x HDMI 2.0 Uncompressed AV and Data)

1x Toslink (1x Optical 2 Channel LPCM)

1x RCA (1x Coaxial 2 Channel LPCM)

1x USB Type B (1x USB (2.0) Audio)

Output:

1x 3.5mm Stereo mini-jack (1x Headphone out

Stereo(L/R))

1x HDMI (1x HDMi 2.0 Uncompressed AV and Data)

1x RCA (1x Coaxial 2 Channel LPCM)

1x Toslink (1x Optical 2 Channel LPCM)

2x RCA (1x Analogue audio Stereo (L/R))

2x XLR (1x Analogue Stereo (Balanced))

Power:

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 154mm (W) x 223mm (D) x 48mm (H)

Gross

Weight:

1480g

Net. Weight: 870g

FEATURES

• HDMI2.0, HDCP 2.2 and DVI compatible

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Audio format conversion

• Professional analogue signal handling and conversion between balanced and unbalanced output signals

• Easy integration of USB, HDMI, L/R Stereo, Digital

Optical and Coaxial sources onto speakers or headphones (6.35mm Jack)

• HDMI bypass function including the ability to embed and de-embed audio

• Analogue to Digital conversion (ADC)

• Digital to Analogue conversion (DAC)

• Digital inputs can be SRC to 44.1, 48, 88.2, 96,

176.4, 192 and 384kHz via DSP Engine

• Supports Analogue L/R input/output, XLR, and

6.3mm headphone outputs

• HDMI Audio output can either output the incoming embedded HDMI (Bypass Mode) or insert the selected audio signal (Ext Audio Mode)

• Supplied with IR Remote Control

P I O N E E R S I N A V T E C H N O L O G I E S

55

56

IP Audio Controller

AU-IP21

IP Control Optical

The AU-IP21 has the choice of Optical or analogue stereo inputs, outputting to analogue L/R with the choice of mono or stereo. Telnet and Web GUI control provide remote control over a network. The Web GUI inputs labels can be edited allowing the user to customize the interface. Ideal for adding remote volume control to amplification systems.

FEATURES

• Supports optical input sampling rate up to

192kHz

• Supports Optical & analogue L/R inputs to analogue L/R output

• Support Stereo out or Mono out

• Support Volume control by Telnet or WebGUI

• Single button source selection

• Editable source labels in Web GUI

SPECIFICATIONS

Input:

1x Toslink (1x 2 Channel LPCM)

2x RCA (1x Stereo (L/R))

1x USB Type A (1x Service Propriety Data)

1x RJ45 (1x Control Propriety Data)

Output:

Power:

2x RCA (1x Stereo (L/R))

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 82mm (W) x 55mm (D) x 22mm (H)

Gross

Weight:

642g

Net. Weight: 342g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI to Stereo Audio (2 Phono)

with ARC Extractor

AU-1HARC

3D HDMI

The AU-1HARC is designed to extract the audio signal from any ARC (Audio Return Channel) enabled HDTV and convert it to a line-level analogue stereo signal.

This device is perfect for use with HDTVs with no dedicated audio output allowing the audio to be extracted from the ARC enabled HDMI connection and sent to a non-HDMI equipped amplifier, AVR, or active speakers.

It supports HDMI audio sampling rates up to 192 kHz and provides an analogue 2-channel stereo output using the integrated DAC (Digital to Analogue Converter).

FEATURES

• Compliant with HDMI v1.3, HDCP 1.2 and DVI 1.0

• Supports Optical Sample Rate up to 96 kHz

• Supports LPCM Stereo, DTS and Dolby Digital via Optical input

• Supports up to 24bit resolution digital audio

• Supports resolutions of 1080P up to cable lengths of 10m either side of the device

• Supports HDMI Sample Rates up to 192 kHz

• Supports 3D signals

SPECIFICATIONS

Input:

1x HDMI [1x HDMI - ARC channel only Uncompressed

AV and Data]

Output:

Power:

2x RCA [1x Analogue Stereo (L/R)]

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 55mm [W] x 80mm [D] x 20mm [H]

Gross Weight: 220g

Net. Weight: 60g

P I O N E E R S I N A V T E C H N O L O G I E S

57

Adjustable Stereo Lip Sync Corrector

AU-D18

The AU-D18 analogue stereo Lip Sync Corrector is a small device for correcting audio lip sync issues. This solution features a manually adjustable timing selector dial which can be adjusted so that the users may fine tune the timing of the audio so that it is in sync with the video signal, overcoming any annoying sound mismatch to the display or amplifier.

SPECIFICATIONS

Input:

2x RCA (1x Analogue Stereo (L/R))

FEATURES

• Lip Sync corrector with adjustable delay between 0 & 300ms

• Sample Rate: 48 kHz

• Compatible with a 2 Phono stereo audio signal

• Up to 24 bit audio resolution

• Adjust analogue audio signal timing to compensate for video signal delays in AV systems

Output:

Power:

2x RCA (1x Analogue Stereo (L/R))

5V/1.2A

DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 45mm (W) x 45mm (D) x 25mm (H)

Gross Weight: 220g

Net. Weight:

140g

58

P I O N E E R S I N A V T E C H N O L O G I E S

Digital Audio over CAT5e/6 Extender

Transmitter/Receiver Set

PU-304-KIT

Optical Coaxial

The PU-304-KIT is designed to send digital audio signals over

150m over CAT5e/6 cable infrastructure. This device supports both Coaxial and Optical signals and can transmit these signals up to 150m. The PU-304-KIT can be powered using a

USB cable or the supplied PSU adaptor for added flexibility in a compact design. Digital S/PDIF signals are supported up to a sample rate of 96Khz, and support for  Stereo and

Multichannel digital audio (LPCM, DTS, Dolby Digital, Dolby

Digital Plus) is also provided.

FEATURES

• Supports Coaxial or Optical digital audio SPDIF signals.

• Supports Stereo and Multichannel digital audio

(LPCM, DTS, Dolby Digital, Dolby Digital Plus).

• Supports sample rate up to 96kHz.

• Dual transmission 1 x Coaxial and 1 x Optical

• Signals can be extended over single CAT5e/

CAT6 up to 150m

SPECIFICATIONS

Input:

(PU-304RX) 1x RJ45 (1x Digital Audio Propriety Data)

(PU-304TX) 1x RCA (1x Coaxial 2 Channel LPCM / DTS /

Dolby Digital / Dolby Digital Plus)

1x Toslink (1x Optical 2 Channel LPCM / DTS / Dolby

Digital / Dolby Digital Plus)

Output:

(PU-304RX) 1x RCA (1x Coaxial 2 Channel LPCM / DTS /

Dolby Digital / Dolby Digital Plus)

1x Toslink (1x Optical 2 Channel LPCM / DTS / Dolby

Digital / Dolby Digital Plus)

(PU-304TX) 1x RJ45 (1x Digital Audio Propriety Data)

Power:

5V/1A USB DC (US/EU standards, CE/FCC/UL certified)

Dimensions: (PU-304RX) 55mm (W) x 85mm (D) x 22mm (H)

(PU-304TX) 55mm (W) x 85mm (D) x 22mm (H)

Gross

Weight:

380g

Net. Weight: (PU-304RX) 60g

(PU-304TX) 60g

P I O N E E R S I N A V T E C H N O L O G I E S

59

Bi-Directional Digital Audio over Single

CAT Transmitter

PU-305BD-TX

60

RS-232 Bi-Directional Audio PoC Optical

The PU-305BD-TX transmitter is designed to send digital audio signals up to 300m over CAT5e/6 cable infrastructure. This device is Bi-Directional and supports Digital Optical signals allowing transmission up to 300m at 96KHz sample rate, or

100m at 192KHz sample rate.This extender set also supports

RS-232 signals over the same CAT5e/6 cable. The PU-305BD-TX can be powered at either end using the supplied PSU adaptor for added flexibility. Digital audio signals are supported up to a sample rate of 192Khz, and support for LPCM Stereo and

Multichannel digital audio (LPCM, DTS, Dolby Digital, Dolby

Digital Plus) is also provided.

The PU-305BD-TX is designed to work with the PU-305BD-RX receiver or the PU-305BDA-RX analogue receiver.

The PU-305BD-KIT is perfect for multi-room AV systems where the optical audio from a HDTV or amplifier can be routed back to a rack matrix for further distribution throughout a wider multi-room AV system.

FEATURES

• Supports Optical SDPIF Input & Output, plus

RS-232

• Supports up to 24bit 192kHz audio signals

• Supports 192kHz audio up to 100m and 96kHz or lower audio up to 300m

• Supports LPCM, DTS, Dolby Digital and Dolby

Digital Plus signals

• Supports PoC (Power over Cable) via a single

PSU which can be connected at either end of the extender set

SPECIFICATIONS

Input:

1x Toslink (1x Optical Toslink DTS / Dolby Digital / 2

Channel LPCM / Dolby Digital Plus)

1x 9pin Dsub (1x RS-232 Data)

Output:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM / Dolby Digital Plus)

1x RJ45 (1x Digital Audio Propriety Data)

Power:

12V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Bi-directional PoC

Dimensions: 75mm (W) x 80mm (D) x 25mm (H)

Gross

Weight:

440g

Net. Weight: 160g

P I O N E E R S I N A V T E C H N O L O G I E S

Bi-Directional Digital Audio over Single

CAT Receiver

PU-305BD-RX

RS-232 Bi-Directional Audio PoC Optical

The PU-305BD-RX is designed to receive digital audio signals up to 300m over CAT5e/6 cable infrastructure. This device is

Bi-Directional and supports Digital Optical signals allowing transmission up to 300m at 96KHz sample rate, or 100m at

192KHz sample rate. This extender set also supports RS-232 signals over the same CAT5e/6 cable. The PU-305BD-RX can be powered at either end using the supplied PSU adaptor for added flexibility. Digital audio signals are supported up to a sample rate of 192Khz, and support for LPCM Stereo and

Multichannel digital audio (LPCM, DTS, Dolby Digital, Dolby

Digital Plus) is also provided.

The PU-305BD-RX is designed to work with the PU-305BD-TX receiver or the PU-305BDA-TX analogue transmitter.

The PU-305BD-KIT is perfect for multi-room AV systems where the optical audio from a HDTV or amplifier can be routed back to a rack matrix for further distribution throughout a wider multi-room AV system.

FEATURES

• Supports Optical SDPIF Input & Output, plus

RS-232

• Supports up to 24bit 192kHz audio signals

• Supports 192kHz audio up to 100m and 96kHz or lower audio up to 300m

• Supports LPCM, DTS, Dolby Digital and Dolby

Digital Plus signals

• Supports PoC (Power over Cable) via a single

PSU which can be connected at either end of the extender set

SPECIFICATIONS

Input:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM / Dolby Digital Plus)

Output:

Power:

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM / Dolby Digital Plus)

1x 9pin Dsub (1x RS-232 Data)

Bi-directional PoC,12V/1.25A

DC (US/EU standards, CE/FCC/UL certified)

PoC Power: DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 75mm (W) x 80mm (D) x 25mm (H)

Gross

Weight:

280g

Net. Weight: 160g

P I O N E E R S I N A V T E C H N O L O G I E S

61

Bi-Directional Analogue Audio over

Single CAT Transmitter

PU-305BDA-TX

62

RS-232 Bi-Directional Audio PoC

The PU-305BDA-TX is an analogue Stereo over CAT5e/6/7

Transmitter which can send and receive analogue audio signals over a single run of CAT5e/6 cable up to 300m. It has the added benefit of RS-232 pass-through allowing control of devices and the Power over Cable (PoC) function can power the receiver unit eliminating the need for a second power supply. As the unit has bi-directional capabilities, this device can also receive audio signals back from the connected receiver.

FEATURES

• Supports bi-directional transmission (in/out) of analogue audio and RS-232 pass-through

• Supports PoC (Power over Cable) via a single

PSU which can be connected at either end of the extender set

• Bi-directional RS-232 control

This transmitter is designed to be used with the PU-305BDA-

RX Analogue Audio Receiver or the PU-305BD-RX Digital

Audio Receiver. When combined with the PU-305BD-RX digital receiver, the analogue audio signal will be converted and outputted as digital audio by the receivers' built-in digital to analogue converter (DAC).

SPECIFICATIONS

Input:

2x RCA (1x Analogue Stereo (L/R))

1x 9pin Dsub (1x RS-232 Data)

Output:

2x RCA (1x Analogue Stereo (L/R))

1x RJ45 (1x Bi-directional Audio plus Propriety Data

Power:

12V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Bi-directional PoC

Dimensions: 100mm (W) x 110mm (D) x 25mm (H)

Gross

Weight:

360g

Net. Weight: 120g

P I O N E E R S I N A V T E C H N O L O G I E S

Bi-Directional Analogue Audio over

Single CAT Receiver

PU-305BDA-RX

RS-232 Bi-Directional Audio PoC

The PU-305BDA-RX is an analogue Stereo over CAT5e/6/7

Receiver which can send and receive analogue audio signals over a single run of CAT5e/6 cable up to 300m. It  has the added benefit of RS-232 pass-through allowing control of devices and the Power over Cable (PoC) function can power the receiver  unit eliminating the need for a second power supply. As the unit has bi-directional capabilities, this device can also send audio signals back to the connected transmitter.

This receiver is designed to be used with the PU-305BDA-TX

Analogue Audio Transmitter or the PU-305BD-TX Digital Audio

Transmitter. When combined with the PU-305BD-TX digital transmitter, the analogue audio signal will be converted and outputted as digital audio by the transmitters' built-in digital to analogue converter (DAC).

FEATURES

• Supports bi-directional transmission (in/out) of analogue audio and RS-232 pass-through

• Supports PoC (Power over Cable) via a single

PSU which can be connected at either end of the extender set

• Bi-directional RS-232 control

SPECIFICATIONS

Input:

2x RCA (1x Analogue Stereo (L/R))

1x RJ45 (1x Bi-directional Audio plus Propriety Data)

Output:

2x RCA (1x Analogue Stereo (L/R))

1x 9pin Dsub (1x RS-232 Data)

Power:

12V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Bi-directional PoC

Dimensions: 100mm (W) x 110mm (D) x 25mm (H)

Gross

Weight:

360g

Net. Weight: 120g

P I O N E E R S I N A V T E C H N O L O G I E S

63

Extenders

CYP solutions are designed to deliver a standard of signal distribution that provides unprecendented levels of confidence and control for the user. Our extensive range of HDMI transmitter and receiver products provide the installer a robust solution for sending AV and control signals over long distances.

Utilising the latest technologies such as HDMI over

IP, and HDBaseT, our selection of extender products provide the installer with a choice of solutions to suit any installation regardless of the complexities and scale of the system.

HDMI or VGA over IP Transmitter with USB support (4K, HDCP2.2)

IP-6000TX

66

4K 3D HDMI2.0

USB IP

The PU-IP6000TX transmitter allows you to transmit HDMI or VGA signals over CAT5e/6/7 network cable. This extender is multi-function transmitter that supports the transmission of Ultra High-Definition signals (up to [email protected], YUV444) for distances up to 100m.  This system is perfect for both residential and commercial installation environments.

FEATURES

• HDCP 2.2, HDMI and DVI compatible

• Supports HDMI and VGA inputs and outputs

• Supports video transmission over IP up to 100m

The video and audio can be transmitted via an IP network for distances up to 100m through a single network switch. The transmission distance can be further extended up to 100m between network switches and supports Gigabit networks.

This system also features bi-directional IR pass-through, analogue line level in/out, and microphone input provide the user with variety of audio options. The USB function allows the system to act like USB hub which, when combined with the

VGA input/Output feature, it allows the system to be used as a KVM switch. Adding extra devices allows the user to cascade

• Supports HDTV resolutions up to [email protected]

(YUV444) or [email protected] (YUV420)

• Supports pass-through of HD audio formats

(PCM 2CH)

• Supports audio line in for audio input to the transmitter and line output to an amplifier or

AV Receiver

• Supports microphone input on the receiver unit

• Supports USB keyboard and mouse

• Control via OSD, Telnet, WebGUI, IR remote and

RS-232 the system enabling them to extend the transmission distance without signal  loss or introducing delay. Control is  via Onscreen Display (OSD), Telnet, IR Remote, WebGUI and RS-232 commands.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI - Uncompressed AV and Data)

1x 15pin Dsub (1x VGA - RGBHV)

1x 3.5mm Stereo mini-jack (1x Analogue - Stereo(L/R))

1x USB Type B (1x USB Hub - Propriety Data)

1x 9pin Dsub (1x RS-232 Data)

Output:

Gross

Weight:

1x RJ45 (1x IP - Encoded AV & Data stream)

1x 15pin Dsub (1x VGA bypass - RGBHV)

1x 3.5mm Stereo mini-jack (1x Analogue - Stereo(L/R))

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 182mm (W) x 280mm (D) x 71mm (H)

1000g

Net. Weight: 855g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI or VGA over IP Receiver with USB support (4K, HDCP2.2)

IP-6000RX

4K 3D HDMI2.0

USB IP

The PU-IP6000RX receiver allows you to receive HDMI or VGA signals over CAT5e/6/7 network cable. This extender is multifunction receiver that supports Ultra High-Definition signals

(up to [email protected], YUV444) for distances up to 100m. This system is perfect for both residential and commercial installation environments.

The video and audio can be transmitted via an IP network for distances up to 100m through a single network switch. The transmission distance can be further extended up to 100m between network switches and supports Gigabit networks.

This system also features bi-directional IR pass-through, analogue line level in/out, and microphone input provide the user with variety of audio options. The USB function allows the system to act like USB hub which, when combined with the

VGA input/Output feature, it allows the system to be used as a KVM switch. Adding extra devices allows the user to cascade

FEATURES

• HDCP 2.2, HDMI and DVI compatible

• Supports HDMI and VGA inputs and outputs

• Supports video transmission over IP up to 100m

• Supports HDTV resolutions up to [email protected]

(YUV444) or [email protected] (YUV420)

• Supports pass-through of HD audio formats

(PCM 2CH)

• Supports audio line in for audio input to the transmitter and line output to an amplifier or

AV Receiver

• Supports microphone input on the receiver unit

• Supports USB keyboard and mouse

• Control via OSD, Telnet, WebGUI, IR remote and

RS-232 the system enabling them to extend the transmission distance without signal  loss or introducing delay. Control is  via Onscreen Display (OSD), Telnet, IR Remote, WebGUI and RS-232 commands.

SPECIFICATIONS

Input:

1x RJ45 (1x IP - Encoded AV & Data stream)

1x 3.5mm Stereo mini-jack (1x Microphone)

Output:

1x HDMI (1x HDMI - Uncompressed AV and Data)

1x 15pin Dsub (1x VGA - RGBHV)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

2x USB Type A (2x USB 2.0 - Propriety Data)

2x USB Type A (2x USB 1.1 Propriety Data)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 182mm (W) x 280mm (D) x 71mm (H)

Gross

Weight:

1020g Net. Weight: 865g

P I O N E E R S I N A V T E C H N O L O G I E S

67

HDBaseT™ 2.0 Slimline Transmitter (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR, USB

PUV-2010TX

DC 48V

AUDIO

IN

IR

IN2

IR

OUT1 USB RS-232 UPDATE

68

LAN

OPT. OUT

(OAR/ARC) HDMI IN CAT5e/6/7

4K 3D HDMI2.0

HDBT2.0

5Play HDCP2.2

PoH OAR ARC USB

The PUV-2010TX Slimline Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio, 2-Way IR,

RS-232, PoH (Power over HDBaseT), LAN, and USB data signals up to 100m. Utilising the latest HDBaseT™ 2.0 technology, this solution provides advanced signal management and dedicated audio pathways to ensure reliable results in the most demanding installation environments. In addition to the full 5-Play convergence, this device also incorporates

OAR (Optical Audio Return) and ARC (Audio Return Channel) functions which enable audio from a compatible display to be routed back from the receiver unit to the transmitter. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 100m.

This system also allows the connection of any USB host, enabling a USB connection to 2 USB ports, giving the PU-

2010RX Receiver the ability to act like a USB hub.

All of these features are encorporated into an ultra slim casing

(less than 18mm thick), providing unrivalled flexibility and ease of installation.

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI [1x HDMI Uncompressed AV and Data]

1x USB Mini B [1x USB Propriety Data]

1x RJ45 [1x LAN Serving]

1x 3.5mm Stereo mini-jack [1x Infra Red Emitter]

1x Phoenix (3 pin) [1x Stereo (L/R) Audio Input]

1x RJ45 [1x HDBaseT 2.0 HDMI & Propriety Data]

1x Toslink [1x Optical 2 Channel LPCM]

1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]

1x Phoenix (3 pin) [1x RS-232]

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

FEATURES

• Supports full HDBaseT™ 2.0 specification signals can be received up to a maximum distance of

100m over CAT6a/7

• HDCP 2.2, HDMI and DVI compatible

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical audio return (OAR)

• Supports optical sampling rate up to 48kHz

• Audio return channel (ARC)

• Dedicated channel for analogue stereo audio transmission from the transmitter to a compatible receiver.

• Ultra slim chassis design for ease of installation

• USB Data Serving from Transmitter (single USB) to Receiver (2x USB).

• Compatible with PUV-2010RX Receiver

Dimensions: 270mm (W) x 80mm (D) x 20mm (H)

Gross

Weight:

450g

Net. Weight: 340g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ 2.0 Slimline Receiver (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR, USB

PUV-2010RX

AUDIO

OUT

IR

IN1

IR

OUT2 USB RS-232 UPDATE

LAN

OPT. IN

(OAR/ARC) HDMI OUT CAT5e/6/7

4K 3D HDMI2.0

HDBT2.0

5Play HDCP2.2

PoH OAR ARC USB

The PU-2010RX Slimline Receiver supports video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-232, PoH

(Power over HDBaseT), LAN, and USB data signals up to 100m.

Utilising the latest HDBaseT™ 2.0 technology, this solution provides advanced signal management and dedicated audio pathways to ensure reliable results in the most demanding installation environments. In addition to the full 5-Play convergence, this device also incorporates OAR (Optical

Audio Return) and ARC (Audio Return Channel) functions which enable audio from a compatible display to be routed back from the receiver unit to the transmitter. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 100m.

This system also allows the connection of any USB host, enabling a USB connection to 2 USB ports, giving the PU-

2010RX Receiver the ability to act like a USB hub.

All of these features are encorporated into an ultra slim casing

(less than 18mm thick), providing unrivalled flexibility and ease of installation.

SPECIFICATIONS

Input:

Output:

1x RJ45 (1x HDBaseT 2.0 HDMI & Propriety Data)

1x Toslink (1x Optical 2 Channel LPCM)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x HDMI (1x HDMI Uncompressed AV and Data)

2x USB Type A (2x USB Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x Phoenix (3 pin) (1x Stereo (L/R) Audio Output)

1x Phoenix (3 pin) (1x RS-232)

FEATURES

• Supports full HDBaseT™ 2.0 specification signals can be received up to a maximum distance of

100m over CAT6a/7

• HDCP 2.2, HDMI and DVI compatible

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical audio return (OAR)

• Supports optical sampling rate up to 48kHz

• Audio return channel (ARC)

• Dedicated channel for analogue stereo audio transmission from a compatible transmitter to receiver.

• Receiver features 2 USB 2.0 ports

• Ultra slim chassis design for ease of installation

• Compatible with PUV-2010TX Transmitter

Power:

Powered by PoH

Dimensions: 270mm (W) x 80mm (D) x 20mm (H)

Gross

Weight:

450g

Net. Weight: 340g

P I O N E E R S I N A V T E C H N O L O G I E S

69

70

HDBaseT™ 2.0 Slimline Transmitter (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR

PUV-2000TX

DC 48V

AUDIO

IN

IR

IN2

IR

OUT1 RS-232 UPDATE

LAN

OPT. OUT

(OAR/ARC) HDMI IN CAT5e/6/7

4K 3D HDMI2.0

HDBT2.0

5Play HDCP2.2

PoH OAR ARC

The PU-2000TX Slimline Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio,

2-Way IR, RS-232, PoH (Power over HDBaseT), and LAN signals up to 100m. Utilising the latest HDBaseT™ 2.0 technology, this solution provides advanced signal management and dedicated audio pathways to ensure reliable results in the most demanding installation environments. In addition to the full 5-Play convergence, this device also incorporates

OAR (Optical Audio Return) and ARC (Audio Return Channel) functions which enable audio from a compatible display to be routed back from the receiver unit to the transmitter. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 100m.

All of these features are encorporated into an ultra slim casing

(less than 18mm thick), providing unrivalled flexibility and ease of installation.

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RJ45 (1x LAN Serving)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x Phoenix (3 pin) (1x Stereo (L/R) Audio Input)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x Toslink (1x Optical 2 Channel LPCM)

1x RJ45 (1x HDBaseT 2.0 HDMI & Propriety Data)

1x Phoenix (3 pin) (1x RS-232)

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 163mm (W) x 78mm (D) x 16mm (H)

FEATURES

• Supports full HDBaseT™ 2.0 specification signals can be received up to a maximum distance of

100m over CAT6a/7

• HDCP 2.2, HDMI and DVI compatible

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical audio return (OAR)

• Supports optical sampling rate up to 48kHz

• Audio return channel (ARC)

• Dedicated channel for analogue stereo audio transmission from the transmitter to a compatible receiver.

• Ultra slim chassis design for ease of installation

• Compatible with PUV-2000RX Receiver

Gross

Weight:

1400g

Net. Weight: 360g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ 2.0 Slimline Receiver (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR)

PUV-2000RX

AUDIO

OUT

IR

IN1

IR

OUT2 RS-232 UPDATE

LAN

OPT. IN

(OAR/ARC) HDMI OUT CAT5e/6/7

4K 3D HDMI2.0

HDBT2.0

5Play HDCP2.2

PoH OAR ARC

The PU-2000RX Slimline Receiver supports video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-232, PoH

(Power over HDBaseT), and LAN signals up to 100m. Utilising the latest HDBaseT™ 2.0 technology, this solution provides advanced signal management and dedicated audio pathways to ensure reliable results in the most demanding installation environments. In addition to the full 5-Play convergence, this device also incorporates OAR (Optical Audio Return) and ARC

(Audio Return Channel) functions which enable audio from a compatible display to be routed back from the receiver unit to the transmitter. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to

100m.

All of these features are incorporated into an ultra slim casing

(less than 18mm thick), providing unrivalled flexibility and ease of installation.

SPECIFICATIONS

Input:

1x RJ45 (1x HDBaseT 2.0 HDMI & Propriety Data)

1x Toslink (1x Optical 2 Channel LPCM)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RJ45 (1x LAN Serving)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x Phoenix (3 pin) (1x Stereo (L/R) Audio Output)

1x Phoenix (3 pin) (1x RS-232)

Power:

Power over HDBaseT

Dimensions: 163mm (W) x 78mm (D) x 16mm (H)

Gross

Weight:

950g

Net. Weight: 360g

FEATURES

• Supports full HDBaseT™ 2.0 specification signals can be received up to a maximum distance of

100m over CAT6a/7

• HDCP 2.2, HDMI and DVI compatible

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical audio return (OAR)

• Supports optical sampling rate up to 48kHz

• Audio return channel (ARC)

• Dedicated channel for analogue stereo audio transmission from a compatible transmitter to receiver.

• Ultra slim chassis design for ease of installation

• Compatible with PUV-2000TX Transmitter

P I O N E E R S I N A V T E C H N O L O G I E S

71

72

HDBaseT™ Slimline Transmitter (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR

PUV-1530TX

DC 48V

AUDIO

OUT

AUDIO

IN

IR

IN2

IR

OUT1 USB RS-232 UPDATE

LAN HDMI IN

AUDIO

IN CAT5e/6/7

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH OAR

The PU-1530TX Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-

FEATURES

232, PoH (Power over HDBaseT), OAR (Optical Audio Return), and LAN signals up to 100m.

This solution provides advanced signal management

• HDCP2.2 Compliant

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through) ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to

100m.

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

SPECIFICATIONS

Input:

1x HDMI Uncompressed AV and Data (1x HDMI)

1x Analogue Stereo (L/R) Audio Input (1x Phoenix (3 pin))

1x Infra Red Receiver (1x 3.5mm Stereo mini-jack)

1x RS-232 (1x Phoenix (3 pin))

1x LAN Serving (1x RJ45)

1x Service Port Propriety Data (1x USB Mini B)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical Audio Return (OAR)

Output:

1x HDBaseT HDMI & Propriety Data (1x RJ45)

1x Optical DTS / Dolby Digital / 2 Channel LPCM (1x

Toslink)

 1x Analogue Stereo (L/R) Audio Output (1x Phoenix

(3 pin))

 1x Infra Red Emitter (1x 3.5mm Stereo mini-jack)

• Supports HDCP repeating and CEC functions

• Supports 3D signals

• Compatible with PUV-1530RX Receiver

Power:

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 80mm (W) x 165mm (D) x 20mm (H)

Gross

Weight:

950g

Net. Weight: 335g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ Slimline Receiver (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN, OAR

PUV-1530RX

OPTICAL

IN

IR

IN1

IR

OUT2

RS-232 UPDATE

LAN HDMI OUT CAT5e/6/7

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH OAR

The PU-1530RX Receiver will accept transmitted video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-

FEATURES

232, PoH (Power over HDBaseT), OAR (Optical Audio Return), and LAN signals up to 100m.

This solution provides advanced signal management

• HDCP2.2 Compliant

• HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through) ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to

100m.

SPECIFICATIONS

Input:

Output:

Power:

1x RJ45 (1x HDBaseT - HDMI & Propriety Data)

1x Toslink (1x OAR digital pathway - 2 Channel LPCM /

DTS / Dolby Digital)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x USB Type A (1x Service Port Propriety Data)

1x HDMI (1x HDMI - Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x LAN Serving)

1x Phoenix (3 pin) (1x RS-232)

Power over HDBaseT

Dimensions: 80mm (W) x 165mm (D) x 20mm (H)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical Audio Return (OAR)

• Supports optical sampling rate up to 48kHz

• Supports HDCP repeating and CEC functions

• Supports 3D signals

• Compatible with PUV-1530TX Transmitter

Gross

Weight:

950g

Net. Weight: 335g

P I O N E E R S I N A V T E C H N O L O G I E S

73

74

HDBaseT™ LITE Slimline Transmitter (60m)

4K, HDCP2.2, HDMI2.0, PoH, OAR

PUV-1230PL-TX

DC 48V

AUDIO

OUT

AUDIO

IN

IR

IN2

IR

OUT1 USB RS-232 UPDATE

HDMI IN

AUDIO

IN CAT5e/6/7

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-1230PL-TX Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio, 2-Way IR,

RS-232, PoH (Power over HDBaseT), and OAR (Optical Audio

Return) up to 60m.

FEATURES

• HDCP2.2 Compliant

• High-Definition video and audio, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

This solution provides advanced signal management ensuring reliable results in the most demanding installation environments.

All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 60m.

SPECIFICATIONS

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

Input:

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 60m via CAT6a/7

1x HDMI Uncompressed AV and Data [1x HDMI]

1x Analogue Stereo (L/R) Audio Input [1x Phoenix (3 pin)]

1x Infra Red Receiver [1x 3.5mm Stereo mini-jack]

1x RS-232 [1x Phoenix (3 pin)]

1x Service Port Propriety Data [1x USB Mini B]

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

Output:

1x HDBaseT HDMI & Propriety Data [1x RJ45]

1x Analogue Stereo (L/R) Audio Output [1x Phoenix

(3 pin)]

1x Optical DTS / Dolby Digital / 2 Channel LPCM [1x

Toslink]

1x Infra Red Emitter [1x 3.5mm Stereo mini-jack]

• Optical Audio Return (OAR)

• Supports HDCP repeating and CEC functions

• Supports 3D signals

• Compatible with PUV-1230PL-RX Receiver

Power:

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 80mm (W) x 165mm (D) x 20mm (H)

Gross

Weight:

950g

Net. Weight: 335g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ LITE Slimline Receiver (60m)

4K, HDCP2.2, HDMI2.0, PoH, OAR

PUV-1230PL-RX

OPTICAL

IN

IR

IN1

IR

OUT2 RS-232 UPDATE

HDMI OUT CAT5e/6/7

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-1230PL-RX Receiver will accept transmitted video resolutions up to 4K UHD, along with HD audio, 2-Way IR,

FEATURES

RS-232, PoH (Power over HDBaseT), and OAR (Optical Audio

Return) up to 60m.

This solution provides advanced signal management

• HDCP2.2 Compliant

• High-Definition video and audio, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through) ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to 60m.

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

SPECIFICATIONS

Input:

1x HDBaseT HDMI & Propriety Data [1x RJ45]

1x Optical DTS / Dolby Digital / 2 Channel LPCM [1x

Toslink]

1x Infra Red Receiver [1x 3.5mm Stereo mini-jack]

Output:

Power:

1x HDMI Uncompressed AV and Data [1x HDMI]

1x Infra Red Emitter [1x 3.5mm Stereo mini-jack]

1x RS-232 [1x Phoenix (3 pin)]

Power over HDBaseT

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 60m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Optical Audio Return (OAR)

• Supports HDCP repeating and CEC functions

• Supports 3D signals

Dimensions: 80mm (W) x 165mm (D) x 20mm (H)

• Compatible with PUV-1230PL-TX Transmitter

Gross

Weight:

950g

Net. Weight: 335g

P I O N E E R S I N A V T E C H N O L O G I E S

75

HDBaseT™ Transmitter (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN

PUV-1510TX

76

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH

The PUV-1510TX Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio,

FEATURES

2-Way IR, RS-232, PoH (Power over HDBaseT), and LAN signals up to 100m.

• HDCP2.2 Compliant

• Supports uncompressed video/audio up to

10.2Gbps

This solution provides advanced signal management

• Supports HDCP repeating and CEC functions ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 100m.

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x RJ45 (1x HDBaseT output HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• 1080p signals can be transmitted up to 100m via

CAT5e/6/6a/7

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, PoH & Control

(IR & RS232)

• Supports 3D signals

• Compatible with PUV-1510RX Receiver

Dimensions: 116mm (W) x 106mm (D) x 27mm (H)

Gross

Weight:

680g

Net. Weight: 360g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ Receiver (100m)

4K, HDCP2.2, HDMI2.0, PoH, LAN

PUV-1510RX

4K 3D HDMI2.0

HDBT 5Play HDCP2.2

PoH

The PUV-1510RX Receiver will accept transmitted video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-

FEATURES

232, PoH (Power over HDBaseT), and LAN signals up to 100m.

This solution provides advanced signal management ensuring reliable results in the most demanding installation

• HDCP2.2 Compliant

• Supports uncompressed video/audio up to

10.2Gbps

• Supports HDCP repeating and CEC functions environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to 100m.

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

SPECIFICATIONS

Input:

Output:

Power:

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power over HDBaseT (PoH)

Dimensions: 116mm (W) x 106mm (D) x 27mm (H)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• 1080p signals can be transmitted up to 100m via

CAT5e/6/6a/7

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5Play™ convergence: HDMI, LAN, PoH & Control

(IR & RS232)

• Supports 3D signals

• Compatible with PUV-1510TX Transmitter

Gross

Weight:

540g

Net. Weight: 357g

P I O N E E R S I N A V T E C H N O L O G I E S

77

78

HDBaseT™ LITE Transmitter (60m)

4K, HDCP2.2, HDMI2.0, PoH

PUV-1210PL-TX

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-1210PL-TX Transmitter enables transmission of video resolutions up to 4K UHD, along with HD audio, 2-Way IR, RS-

232, PoH (Power over HDBaseT) up to 60m.

This solution provides advanced signal management ensuring reliable results in the most demanding installation environments.

FEATURES

• HDCP2.2 Compliant

• High-Definition video and audio, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through)

All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 60m.

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI Uncompressed AV and Data [1x HDMI]

1x Infra Red Receiver [1x 3.5mm Stereo mini-jack]

1x RS-232 Data [1x 9pin Dsub]

1x HDBaseT HDMI & Propriety Data [1x RJ45]

1x Infra Red Emitter [1x 3.5mm Stereo mini-jack]

48V/0.83A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 116mm (W) x 106mm (D) x 27mm (H)

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 60m via CAT6a/7

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

• Supports HDCP repeating and CEC functions

• Support 3D signals

Gross

Weight:

540g

• Compatible with PUV-1210PL-RX Receiver

Net. Weight: 357g

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ LITE Receiver (60m)

4K, HDCP2.2, HDMI2.0, PoH

PUV-1210PL-RX

4K 3D HDMI2.0

HDBT HDCP2.2

PoH OAR

The PUV-1210PL-RX Receiver will accept transmitted video resolutions up to 4K UHD, along with HD audio, 2-Way IR,

FEATURES

RS-232, PoH (Power over HDBaseT), and OAR (Optical Audio

Return) up to 60m.

This solution provides advanced signal management

• HDCP2.2 Compliant

• High-Definition video and audio, PoH (Power over HDBaseT) and control (Bi-Directional IR &

RS-232 pass through) ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are received simultaneously over a single CAT6a/7 cable up to 60m.

SPECIFICATIONS

Input:

1x HDBaseT HDMI & Propriety Data [1x RJ45]

1x Infra Red Receiver [1x 3.5mm Stereo mini-jack]

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 60m via CAT6a/7

Output:

1x HDMI Uncompressed AV and Data [1x HDMI]

1x Infra Red Emitter [1x 3.5mm Stereo mini-jack]

1x RS-232 Data [1x 9pin Dsub]

• Supports pass-through of HD audio formats:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby

Digital Plus, Dolby TrueHD, Dolby Atmos and

DTS-HD Master Audio

Power:

Power over HDBaseT

Dimensions: 116mm (W) x 106mm (D) x 27mm (H)

• Supports HDCP repeating and CEC functions

• Supports 3D signal

• Compatible with PUV-1210PL-TX Transmitter

Gross

Weight:

540g

Net. Weight: 357g

P I O N E E R S I N A V T E C H N O L O G I E S

79

HDMI over Single CAT5e/6/7 HDBaseT™

Bi-directional PoC Transmitter-Full 5Play™ & Single LAN up to 100m

PU-607BD-TX

80

4K 3D HDMI HDBT 5Play HDCP2.2

PoC

The PU-607BD-TX Transmitter allows uncompressed HDMI signals and IP data to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of RS-232 and

2-way IR control functionality over the same CAT5e/6/7 cable.

These combined HDMI and control signals can be transmitted up to lengths of 100 metres. This Transmitter is designed to be used with the PU-607BD-RX and PU-607BDWP-RX Receivers only, which enables Bi-Directional Power over Cable (PoC) functionality.

SPECIFICATIONS

Input:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

Power:

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Bi-directional PoC

Dimensions: 100mm (W) x 115mm (D) x 25mm (H)

Gross

Weight:

500g

Net. Weight: 260g

FEATURES

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions including 4K.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, Bi-Directional

PoC & Control (IR & RS232)

• Supports 3D signals

• Supports Bi-Directional Power over Cable (PoC)

• Note: Only compatible with PU-607BD-RX & PU-

607BDWP-RX Receivers

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI over Single CAT5e/6/7 HDBaseT™

Bi-directional PoC Wallplate Transmitter

Full 5Play™ & Single LAN up to 100m

PU-607BDWP-TX

4K 3D HDMI HDBT 5Play HDCP2.2

PoC

The PU-607BDWP-TX Wallplate Transmitter allows uncompressed HDMI signals and IP data to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of RS-232 and 2-way IR control functionality over the same CAT5e/6/7 cable.

These combined HDMI and control signals can be transmitted up to lengths of 100 metres. This Transmitter is designed to be used with the PU-607BD-RX and PU-607BDWP-RX Receivers only, which enables Bi-Directional Power over Cable (PoC) functionality.

SPECIFICATIONS

Input:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

Power:

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Bi-directional PoC

Dimensions: 100mm (W) x 115mm (D) x 25mm (H)

Gross

Weight:

500g

Net. Weight: 260g

FEATURES

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions including 4K.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, Bi-Directional

PoC & Control (IR & RS232)

• Supports 3D signals

• Supports Bi-Directional Power over Cable (PoC)

• Note: Only compatible with PU-607BD-RX & PU-

607BDWP-RX Receivers

P I O N E E R S I N A V T E C H N O L O G I E S

81

HDMI over Single CAT5e/6/7 HDBaseT™

Bi-directional PoC Receiver-Full 5Play™ & Single LAN up to 100m

PU-607BD-RX

82

4K 3D HDMI HDBT 5Play HDCP2.2

PoC

The PU-607BD-RX Receiver allows uncompressed HDMI signals and IP data to be received via a Single CAT5e/6/7

• HDCP 2.2 Compliant cable. This solution has the added features of RS-232 and

2-way IR control functionality over the same CAT5e/6/7 cable.

• Supports all v1.4 HDMI resolutions including 4K.

These combined HDMI and control signals can be transmitted up to lengths of 100 metres. This Receiver is designed to be used with the PU-607BD-TX or PU-607BDWP-TX Transmitters only, which enables Bi-Directional Power over Cable (PoC) functionality.

SPECIFICATIONS

FEATURES

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

Input:

Output:

Power:

Gross

Weight:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: Bi-directional PoC

Dimensions: 100mm (W) x 115mm (D) x 25mm (H)

500g

Net. Weight: 260g

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, Bi-Directional

PoC & Control (IR & RS232)

• Supports 3D signals

• Supports Bi-Directional Power over Cable (PoC)

• Note: Only compatible with PU-607BD-TX & PU-

607BDWP-TX Transmitters

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI over Single CAT5e/6/7 HDBaseT™

Bi-directional PoC Wallplate Receiver

Full 5Play™ & Single LAN up to 100m

PU-607BDWP-RX

4K 3D HDMI HDBT 5Play HDCP2.2

PoC

The PU-607BD-RX Receiver allows uncompressed HDMI signals and IP data to be received via a Single CAT5e/6/7 cable. This solution has the added features of RS-232 and

2-way IR control functionality over the same CAT5e/6/7 cable.

These combined HDMI and control signals can be transmitted up to lengths of 100 metres. This Receiver is designed to be used with the PU-607BD-TX or PU-607BDWP-TX Transmitters only, which enables Bi-Directional Power over Cable (PoC) functionality.

SPECIFICATIONS

FEATURES

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions including 4K.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

Input:

Output:

Power:

Gross

Weight:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: Bi-directional PoC

Dimensions: 100mm (W) x 115mm (D) x 25mm (H)

500g

Net. Weight: 260g

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, Bi-Directional

PoC & Control (IR & RS232)

• Supports 3D signals

• Supports Bi-Directional Power over Cable (PoC)

• Note: Only compatible with PU-607BD-TX & PU-

607BDWP-TX Transmitters

P I O N E E R S I N A V T E C H N O L O G I E S

83

Switchable HDMI/VGA HDBaseT™ Transmitter with integrated video scaling (5Play™ inc. PoC & single LAN, up to 100m)

PU-507TX-HDVGA

84

3D HDMI HDBT 5Play PoC

The PU-507TX-HDVGA allows VGA and uncompressed HDMI signals to be transmitted over a Single CAT5e/6/7 cable to lengths of up to 100 metres. This device features full 5-Play convergence allowing the distribution of Video, Audio, LAN serving, Power over Cable (PoC), RS-232 and 2-way IR control functionality over the same CAT5e/6/7 cable. This transmitter allows the user to select and switch between a HDMI or

VGA source whilst the integrated scaler ensures maximum resolution support for the connected display. Additionally, the

PU-507TX-HDVGA utilises an auto-scan feature which detects and switches to the last active input.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 15pin Dsub (1x PC RGBHV)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x RJ45 (1x LAN Serving)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x USB Type A (1x Service Port Propriety Data)

1x 9pin Dsub (1x RS-232 Data)

FEATURES

• Supports all v1.4 HDMI resolutions.

• Auto Scan function - scans the inputs for a live signal

• Supports uncompressed video/audio up to

10.2Gbps

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, PoC & Control

(IR & RS232)

• Supports 3D signals

Output:

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

24V/2.7A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 145mm (W) x 200mm (D) x 30mm (H)

Gross

Weight:

1200g

Net. Weight: 600g

P I O N E E R S I N A V T E C H N O L O G I E S

5Play™ HDBaseT™ Transmitter with simultaneous HDMI output (inc. PoC & single LAN)

PU-507TX-1H

3D HDMI HDBT 5Play PoC

The PU-507TX-1H Transmitter allows uncompressed HDMI signals and IP data to be transmitted over a Single CAT5e/6/7 cable. This device features full 5Play™ convergence allowing the distribution of Video, Audio, LAN serving, Power over Cable

(PoC), RS-232 and 2-way IR control functionality over the same

CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 100 metres.  This variant of the popular PU-507-TX Transmitter has a simultaneous

HDMI output enabling a local HDMI display to be connected whilst simultaneously distributing the signals over a single

CAT5e/6/7 to a compatible HDBaseT Receiver.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x RS-232)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

Power:

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 105mm (W) x 115mm (D) x 25mm (H)

Gross

Weight:

660g

Net. Weight: 240g

FEATURES

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions plus 4k.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, PoC & Control

(IR & RS232)

• Supports 3D signals

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

P I O N E E R S I N A V T E C H N O L O G I E S

85

86

5Play™ HDBaseT™ Transmitter

(inc. PoC & single LAN, up to 100m)

PU-507TX

4K 3D 5Play HDMI HDBT PoC

The PU-507TX Transmitter  allows uncompressed HDMI signals and IP data to be transmitted over a Single CAT5e/6/7

• HDCP 2.2 Compliant cable. This device features full 5-Play convergence allowing the distribution of Video, Audio, LAN serving, Power over

Cable (PoC), RS-232 and 2-way IR control functionality over the same CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 100 metres.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

FEATURES

• Supports all v1.4 HDMI resolutions plus 4k.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

Output:

Power:

Gross

Weight:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 105mm (W) x 115mm (D) x 26mm (H)

660g

Net. Weight: 540g

• Supports HDCP repeating and CEC functions

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• 1080p signals can be transmitted up to 100m via

CAT5e/6/6a/7

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, PoC & Control

(IR & RS232)

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

5Play™ HDBaseT™ Receiver

(inc. PoC & single LAN, up to 100m)

PU-507RX

4K 3D 5Play HDMI HDBT PoC

The PU-507RX Receiver allows uncompressed HDMI signals and IP data to be received over a Single CAT5e/6/7 cable. This device features full 5-Play convergence allowing the distribution of Video, Audio, LAN serving, Power over Cable

(PoC), RS-232 and 2-way IR control functionality over the same

CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 100 metres.

SPECIFICATIONS

Input:

Output:

Power:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

Powered by PoC

Dimensions: 105mm (W) x 110mm (D) x 26mm (H)

FEATURES

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions plus 4k.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Supports 1080p distances up to 100 meters through CAT5e/6 cables

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

Gross

Weight:

400g

Net. Weight: 260g

• 5-Play™ convergence: HDMI, LAN, PoC & Control

(IR & RS232)

• Supports 3D signals

• Supports 4K/2K & 4K UHD - CAT5e/6 = 70m &

CAT6a/7 = 100m

P I O N E E R S I N A V T E C H N O L O G I E S

87

88

5Play HDBaseT™ Wall Plate Receiver

(inc. PoC & single LAN, up to 100m)

PU-507WPRX

4K 3D 5Play HDMI HDBT

FEATURES

The PU-507WPRX  allows uncompressed HDMI signals and

IP data to be transmitted over a Single CAT5e/6/7 cable.

This device features full 5Play™ convergence allowing the distribution of Video, Audio, LAN serving, Power over Cable

(PoC), RS-232 and 2-way IR control functionality over the same

CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 100 metres.  This wall plate variant of the PU-507RX receiver enables seamless integration into a standard double-gang back box.

SPECIFICATIONS

Input:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

Power:

Powered by PoC

Dimensions: 145mm (W) x 40mm (D) x 85mm (H)

Gross

Weight:

540g

Net. Weight: 360g

• HDCP 2.2 Compliant

• Supports all v1.4 HDMI resolutions plus 4K

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP, & DVI compliant

• Supports HDCP repeating and CEC functions

• Uncompressed data transfer over single CAT cable (100m - CAT6/7; 80m - CAT5e)

• Uncompressed video 1080p, 60Hz, 48bits

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• 5-Play™ convergence: HDMI, LAN, PoC & Control

(IR & RS232)

• Supports 3D signals

• 4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7

• Compatible with any 'PU-507' transmitter

P I O N E E R S I N A V T E C H N O L O G I E S

Hot Tips!

'PU' transmitters model codes must only be used with equivilent 'PU' receivers.

'PUV' transmitters must only be used with 'PUV' receivers.

HDBaseT Cabling

Always use CAT6 cable for

HDBaseT installs up to 1080p.

To achieve the maximum possible cable runs with 4K systems use CAT6a or above.

P I O N E E R S I N A V T E C H N O L O G I E S

89

90

HDBaseT™ LITE Transmitter with PoC & 2-way IR (up to 60m)

PU-515PL-TX

4K 3D HDMI HDBT PoC

FEATURES

The PU-515PL-TX Transmitter allows uncompressed HDMI signals to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of RS-232, 2-way IR control, and Power over Cable (PoC) functionality over the same

CAT5e/6/7 cable. These combined HDMI and control signals can be transmitted up to lengths of 60 metres.

SPECIFICATIONS

Input:

Output:

Power:

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 3.5mm Stereo mini-jack (1x RS-232)

1x RJ45 (1x HDBaseT Lite HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 75mm (W) x 72mm (D) x 24mm (H)

510g

Net. Weight: 440g

• HDCP 2.2 Compliant

• HDMI 1.4 with 3D, 4Kx2K support, HDCP and DVI compliant

• Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 40m via CAT6a/7

• Complies with HDBaseT™- Lite specifications

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI input up to 15m with 8-bit deep colour, or

10m with 12-bit deep colou

• Supports HDMI output up to 15m with 8/12-bit deep colour

• Supports two-way IR, RS-232 Control, and Power

Over Cable (PoC)

• Supports High Definition LPCM 7.1CH, Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmission

• Compatible with PU-515PL-RX Receivers

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ LITE Receiver with PoC & 2-way IR (up to 60m)

PU-515PL-RX

4K 3D HDMI HDBT PoC

The PU-515PL-RX allows uncompressed HDMI signals to be transmitted over a Single CAT5e/6/7 cable. This solution has the added features of RS-232, 2-way IR control, and Power over Cable (PoC) functionality over the same CAT5e/6/7 cable.

These combined HDMI and control signals can be transmitted up to lengths of 60 metres.

SPECIFICATIONS

Input:

1x RJ45 (1x HDBaseT Lite HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

1x 3.5mm Stereo mini-jack (1x RS-232)

Power:

Powered by PoC

Dimensions: 75mm (W) x 72mm (D) x 24mm (H)

Gross

Weight:

510g

Net. Weight: 440g

FEATURES

• HDCP 2.2 Compliant

• HDMI 1.4 with 3D, 4Kx2K support, HDCP and DVI compliant

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 40m via CAT6a/7

• Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m

• Complies with HDBaseT™- Lite specifications

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI input up to 15m with 8-bit deep colour, or

10m with 12-bit deep colour

• Supports HDMI output up to 15m with 8/12-bit deep colour

• Supports two-way IR, RS-232 Control, and Power

Over Cable (PoC)

• Supports High Definition LPCM 7.1CH, Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmission

• Compatible with PU-515PL-TX Transmitters

P I O N E E R S I N A V T E C H N O L O G I E S

91

HDBaseT™ LITE Transmitter (60m) with 2-way IR

PU-514L-TX

92

4K 3D HDMI HDBT

The PU-514L-TX is a Transmitter Unit designed to be used with

PU-514L-RX Receiver. This device allows uncompressed HDMI, and 2-way IR signals to be transmitted over a Single CAT5e/6/7 cable to distances of up to 60m. Utilise the USB power output from a TV as an optional way of powering the PU-514L-RX receiver unit alternative to a mains power supply.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x RJ45 (1x HDBaseT Lite HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 55mm (W) x 83mm (D) x 22mm (H)

Gross

Weight:

140g

Net. Weight: 60g

FEATURES

• HDCP 2.2 Compliant

• HDMI 1.4 with 3D, 4Kx2K support, HDCP and DVI compliant

• Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m

• 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 40m via CAT6a/7

• Complies with HDBaseT™- Lite specifications

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI input up to 15m with 8-bit deep colour, or

10m with 12-bit deep colour

• Supports 2-way IR Control

• Supports High Definition LPCM 7.1CH, Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmission

• Choose to power the PU-514L-TX via the USB output from a TV (Cable available separately -

ADC-USB): * Please note the performance and consistency of USB power outputs from TV's can vary and cannot be guaranteed by CYP.

P I O N E E R S I N A V T E C H N O L O G I E S

HDBaseT™ LITE Receiver (60m) with 2-way IR

PU-514L-RX

4K 3D HDMI HDBT

The PU-514L-RX is a Receiver Unit designed to be used with

PU-514L-TX Transmitter, and any compatible HDBaseT™ Matrix or Distribution Amplifier. It allows uncompressed HDMI, and

2-way IR signals to be received via a Single CAT5e/6/7 cable to distances of up to 60m. Utilise the USB power output from a TV as an optional way of powering the PU-514L-RX receiver unit alternative to a mains power supply.

Specific feature compatibility may vary dependant on the transmission device.

SPECIFICATIONS

Input:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 55mm (W) x 52mm (D) x 22mm (H)

Gross

Weight:

140g

Net. Weight: 60g

FEATURES

• HDCP 2.2 Compliant

• HDMI 1.4 with 3D, 4Kx2K support, HDCP and DVI compliant

• Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m

• HDBaseT Lite - 4K/2K & 4K UHD signals can be transmitted up to 35m via CAT5e/6 and 40m via

CAT6a/7

• Complies with HDBaseT™- Lite specifications

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports HDMI output up to 15m with 8/12-bit deep colour

• Supports 2-way IR Control

• Supports High Definition LPCM 7.1CH, Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio transmission

• Choose to power the PU-514L-RX via the USB output from a TV (Cable available separately -

APC-USB): * Please note the performance and consistency of USB power outputs from TVs can vary and cannot be guaranteed by CYP.

P I O N E E R S I N A V T E C H N O L O G I E S

93

94

DVI 5Play™ HDBaseT™ Transmitter including PoC & 2x LAN, up to 100m

PU-DVI1109TX

3D DVI

SPECIFICATIONS

Input:

1x DVI-I (1x DVI DVI-D)

2x RCA (1x Stereo (L/R))

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

2x RJ45 (2x LAN Serving)

Output:

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

24V/1.25A Catapult DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 450mm (W) x 410mm (D) x 90mm (H)

Gross

Weight:

560g

Net. Weight: 380g

5Play HDBT PoC

This HDBaseT DVI over CAT5e/6/7 transmitter can transmit DVI video, analogue audio, 2 LAN serving connections, control (RS-

232 and bi-directional IR) and Power over Cable (PoC) over a single CAT5e/6/7 cable up to 100m. The transmitter can power the PU-DVI1109RX receiver, via the PoC function, eliminating the need for a separate power supply.

FEATURES

• Supports 3D formats and 4K2K resolution with

HDMI to DVI adaptor

• Simultaneous transmission of uncompressed video and audio ([email protected]/Deep Color) over a single CAT5e/6/7 cable up to 100m

• Supports High-definition Audio formats (up to

LPCM 7.1CH, Dolby TrueHD and DTS-HD Master

Audio)

• Connect and share up to 4 LAN connections (2 at the receiver end, 2 at the Transmitter end) at speeds up to 100Mbps

• Supports bi-directional IR control and RS-232 pass-through

• Full 5Play™ convergence: Video, Audio, LAN serving, Power over Cable (PoC) and Control

(bi-directional IR & RS-232 bypass)

• Single power supply powers both units, Receiver unit is powered through the Transmitter via PoC

P I O N E E R S I N A V T E C H N O L O G I E S

DVI 5Play™ HDBaseT™ Receiver including PoC & 2x LAN, up to 100m

PU-DVI1109RX

3D DVI 5Play

This HDBaseT DVI over CAT5e/6/7 receiver can receive DVI video, analog audio, 2 LAN serving connections, control (RS-

232 and bi-directional IR) and Power over Cable (PoC) over a single CAT5e/6/7 cable up to 100m. The PU-DVI1109TX transmitter can power the receiver, via the PoC function, eliminating the need for a separate power supply.

SPECIFICATIONS

Input:

HDBT PoC

1x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x DVI-I (1x DVI-D)

2x RCA (1x Stereo (L/R))

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

2x RJ45 (2x LAN Serving)

Power:

Powered by PoC

Dimensions: 450mm (W) x 410mm (D) x 90mm (H)

FEATURES

• Supports 3D formats and 4K2K resolution with

HDMI to DVI adaptor

• Simultaneous transmission of uncompressed video and audio ([email protected]/Deep Color) over a single CAT5e/6/7 cable up to 100m

• Supports High-definition Audio formats (up to

LPCM 7.1CH, Dolby TrueHD and DTS-HD Master

Audio)

• Connect and share up to 4 LAN connections (2 at the receiver end, 2 at the Transmitter end) at speeds up to 100Mbps

• Supports bi-directional IR control and RS-232 pass-through

• Full 5Play™ convergence: Video, Audio, LAN serving, Power over Cable (PoC) and Control (IR

& RS-232 bypass)

• Single power supply powers both units, Receiver unit is powered through the Transmitter via PoC

Gross

Weight:

560g

Net. Weight: 380g

P I O N E E R S I N A V T E C H N O L O G I E S

95

HDBaseT™ Zone extender

1x HDMI/1x HDBaseT Out

PU-HBTE-ZE

96

4K 3D 5Play HDMI HDBT PoC

The PU-HBTE-ZE HDBaseT Zone extender is designed to allow AV integrators to easily create additional zones for any

HDBaseT distribution system whilst enabling the HDBaseT pass-through signal to be extended further over CAT5e/6/7

(up to 100m). This device  supports the transmission of video (resolutions up to 1080p Full HD, plus 4K Ultra High

Definition, and [email protected]), multi-channel digital audio and control via IR, RS-232 or Web GUI/Telnet IP over a single CAT5e/6/7 cable. The Zone extender allows signals to

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP and DVI compliant be transmitted up to 100m from the transmitter device to the Zone extender where the signal can be routed to a local display via the HDMI output. The signal is also transmitted

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz) simultaneously via the HDBaseT output enabling it to be distributed up to 100m over CAT5e/6/7 from the zone.  The

PU-HBTE-ZE Zone extender utilises PoC (Power over Cable) to provide power to the connected Receiver unit, thus no requirement for a PSU on the Receiver end. This device can be cascaded multiple times to create additional zones.

FEATURES

• Supports RS-232, 2-Way IR, and HDMI CEC control pass through

• Full 5-Play™ Convergence - HDMI, LAN, PoC, &

Control (RS-232 & IR)

• Supports 3D signals

• Supports LAN serving to all connected zones

In addition, the LAN functionality provides the ability to add internet connectivity to every zone which is particularly useful when connecting smart displays.

SPECIFICATIONS

Input:

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x RJ45 (1x LAN Serving)

1x USB Mini B (1x Service Port Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 140mm (W) x 160mm (D) x 30mm (H)

Gross

Weight:

700g Net. Weight: 520g

P I O N E E R S I N A V T E C H N O L O G I E S

100m HDBaseT™ Repeater

PU-HBT-EX

4K 3D 5Play HDMI HDBT PoC

The PU-HBT-EX repeater is designed to extend the signal transmission distances of CYP HDBaseT™  Extender sets and

Matrix systems by allowing the user to repeat HDBaseT™ signals a further 100m over CAT5e/6/7 cable.  This device features full 5-Play™ functionality, including the highest quality 4K2K uncompressed HD video, uncompressed multichannel audio, bi-directional control systems (IR & RS-232),

Power over Cable (PoC), and Ethernet (for LAN serving & IP

Control).

When combined with CYP HDBaseT distribution solutions, this

Repeater gives any installer the ability to send Audio, Video,

PoC, and Control signals reliably up to 200m. The PU-HBT-EX can also be cascaded twice to achieve a maximum of 300m transmission distance.

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• HDMI, HDCP and DVI compliant

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Supports RS-232, 2-Way IR, and HDMI CEC control pass through

• Full 5-Play™ Convergence - HDMI, LAN, PoC, &

Control (RS-232 & IR)

• Supports 3D signals

• Supports LAN serving to all connected zones

SPECIFICATIONS

FEATURES

Input:

1x RJ45 (1x HDMI & Propriety Data)

Output:

Power:

1x RJ45 (1x HDMI & Propriety Data)

24V/1.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 98mm (W) x 152mm (D) x 25mm (H)

Gross

Weight:

740g Net. Weight: 340g

P I O N E E R S I N A V T E C H N O L O G I E S

97

98

Pure digital HDMI over Single CAT6

Transmitter

PU-1107TX

3D HDMI

The PU-1107TX can transmit a pure digital HDMI signal over a

Single CAT6 cable allowing HD Audio & 'deep colour' support.

This Transmitter unit is designed to be used with the PU-

1107RX receiver to extend HDMI signals to a single screen.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

1x RJ45 (1x HDMI & Propriety Data)

5V/1A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 80mm (W) x 102mm (D) x 32mm (H)

Gross

Weight:

380g

Net. Weight: 300g

FEATURES

• v1.3 HDMI, HDCP 1.1, DVI 1.0 compliant

• Pure digital v1.3 HDMI over single CAT6

Transmitter with Repeater function

• Resolution supported: HDTV - 480i to 1080p plus 1080p 24fps.

• Resolution supported: PC - VGA to WUXGA

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM.

• Supports CEC bypass

• Supports xvYCC

• Equalises and recovers incoming TMDS data before re-transmitting to ensure optimum signal quality

• Enables CAT6 cable lengths of up to 40m 1080p

8bit video

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

Pure digital HDMI over Single CAT6

Receiver

PU-1107RX

3D HDMI

The PU-1107RX can receive a pure digital HDMI signal over a

Single CAT6 cable allowing HD Audio & 'deep colour' support.

This Receiver unit is designed to be used with the PU-1107TX to extend HDMI to a single screen, and the PU-Q1H8CS Splitter for converting the splitters' single CAT6 outputs, back to HDMI for connection to your displays.

SPECIFICATIONS

Input:

1x RJ45 (1x HDMI & Propriety Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 79mm (W) x 75mm (D) x 30mm (H)

Gross

Weight:

380g

Net. Weight: 280g

FEATURES

• v1.3 HDMI, HDCP 1.1, DVI 1.0 compliant

• Pure digital v1.3 HDMI over single CAT6 Receiver

• Resolution supported: HDTV - 480i to 1080p plus 1080p 24fps.

• Resolution supported: PC - VGA to WUXGA

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM.

• Supports CEC bypass

• Supports xvYCC

• Equalises and recovers incoming TMDS data before re-transmitting to ensure optimum signal quality.

• Supports Deep Colour: 10 and 12 bit

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

99

100

HDMI over CAT5e/6 Transmitter with IR

Emitter

PU-1106TX

3D HDMI

The PU-1106TX Transmitter allows you to extend HDMI signals over Twin CAT6 cabling infrastructure and use your existing

Remote Control to control your source device with the included IR Blaster.

The PU-1106TX is specifically designed to be used with the

PU-1106RX Receiver.

SPECIFICATIONS

Input:

Output:

Power:

Dimensions: 80mm (W) x 100mm (D) x 30mm (H)

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

2x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

440g

Net. Weight: 340g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.1 compliant.

• v1.3 HDMI over CAT6 Transmitter with IR Blaster

• Resolutions supported: HDTV - 480i to 1080p plus 1080p24fps.

• Resolutions supported: PC - VGA to WXGA

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM.

• Compatible with CAT-5E and CAT-6 cables. CAT-6 is recommended for better performance

• Supports CEC functions & IR Receiver

• CAT I/O can run up to 40m @ 1080p8bit video and can be extended with the PU-108 CAT repeater.

• Supports ‘Deep Colour’: 10 & 12 bit

• Equalises and recovers incoming TMDS data before re-transmitting to ensure optimum signal quality.

• Supports xvYCC.

• Supports 3D signals.

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI over CAT5e/6 Receiver with IR

Receiver

PU-1106RX

3D HDMI

The PU-1106RX Receiver allows you to extend HDMI signals up to 40m over Twin CAT6 cabling infrastructure and use your existing Remote Control to control your source device with the included IR Receiver.

The PU-1106RX is specifically designed to be used with the

PU-1106TX Transmitter.

SPECIFICATIONS

Input:

2x RJ45 (1x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 77mm (W) x 73mm (D) x 30mm (H)

Gross

Weight:

420g

Net. Weight: 140g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.1 compliant.

• v1.3 HDMI over CAT5e/6 Receiver with IR

Receiver

• Resolutions supported: HDTV - 480i to 1080p plus 1080p24fps.

• Resolutions supported: PC - VGA to WXGA

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM.

• Compatible with CAT-5E and CAT-6 cables. CAT-6 is recommended for better performance

• Supports CEC functions & IR Receiver

• CAT I/O can run up to 40m @ 1080p8bit video and can be extended with the PU-108 CAT repeater.

• Supports ‘Deep Colour’: 10 & 12 bit

• Equalises and recovers incoming TMDS data before re-transmitting to ensure optimum signal quality.

• Supports xvYCC.

• Supports 3D signals.

P I O N E E R S I N A V T E C H N O L O G I E S

101

When reliability is the ultimate consideration, it doesn't matter if the products at either end of the signal path are the best in the market; if the link between the source and display is anything less than perfect, it will have a detrimental effect on performance. At CYP, we have been developing a wide range of solutions for over 20 years, with reliability always the number one consideration.

Our range of switching and splitting products encompass solutions that are perfect for commercial applications such as conference rooms, custom install applications, and retail environments alike.

8 x 4 HDBaseT™ / HDMI / VGA

Presentation Switch with switchable digital bypass output

EL-5500-HBT

104

3D HDMI HDBT ADC DAC PoC SPECIFICATIONS

The EL-5500-HBT is an advanced rack mountable HDBaseT,

HDMI, VGA, Composite, and Component presentation

Input:

switcher. This device can scale and switch eight input sources to it's two HDMI outputs and a single HDBaseT output, with their associated audio signals to the native resolutions supported by the connected display. This presentation switch also features a switchable digital bypass output allowing any

HDMI or HDBaseT input to be directly bypassed via the HDMI bypass output.

Control is via the IR remote, RS-232, IP, or via manual selection buttons. Both digital and analogue stereo audio is supported via a built-in DAC (Digital to Analogue Converter) and ADC

(Analogue to Digital Converter) providing flexible audio signal integration. The EL-5500-HBT is the perfect solution for any educational or commercial environment requiring integration of multiple sources and signal formats to three HDMI displays.

Output:

FEATURES

• HDMI, HDCP, and DVI compliant

• Digital to Analogue & Analogue to Digital Audio conversion (DAC/ADC)

• Supported Resolutions: HDTV: 480i to 1080p PC: VGA to WUXGA

• Aspect Ratio Adjustment

• Motion Adaptive De-interlace (3D)

• Video Noise Reduction

• Underscan / Overscan Selection

• Picture Adjustment Settings

• HDBaseT Outputs support PoC (Power over Cable) through to compatible connected receiver

• Independent HDMI bypass output (switching digital inputs only)

• Supports HDBaseT LAN Serving function

• Supports IR/RS-232/IP and front panel button control

Gross

Weight:

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

4x HDMI (4x HDMI Uncompressed AV & Data)

4x 3.5mm Stereo mini-jack (4x Analogue inputs for HDMI Stereo(L/R))

2x RJ45 (2x HDBaseT HDMI & Propriety Data)

1x 15pin Dsub (1x PC RGBHV)

1x 3.5mm Stereo mini-jack (1x Analogue input for PC Stereo(L/R))

1x RCA (1x Composite)

2x RCA (1x Analogue input for Composite

Stereo (L/R))

1x RJ45 (1x LAN Serving)

1x 9pin DSub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red

Receiver)

1x USB Type A (1x Service Port 1 Propriety Data)

1x USB Mini B (1x Service Port 2 Propriety Data)

1x 3.5mm Stereo mini-jack (1x Service

Port 3 Propriety Data)

2x HDMI (2x HDMI Uncompressed AV & Data)

1x RJ45 (1x HDBaseT HDMI & Propriety Data)

1x RCA (1x Coaxial 2 Channel LPCM)

1x 3.5mm Stereo mini-jack (1x Analogue

Stereo(L/R))

1x HDMI (1x HDMI Bypass Uncompressed

AV & Data)

1x 3.5mm Stereo mini-jack (1x Analogue

Bypass Stereo(L/R))

Power:

24V/2.7A DC (US/EU standards, CE/FCC/

UL certified)

Dimensions: 440mm (W) x 440mm (D) x 50mm (H)

4460g

Net. Weight:

3200g

COMPATIBLE RECEIVERS (RX)

P I O N E E R S I N A V T E C H N O L O G I E S

Advanced HDMI/VGA Presentation Switch

EL-5500

3D HDMI ADC DAC FEATURES

The EL-5500 is an advanced rack mountable HDMI, VGA,

Composite, and Component presentation switcher. This device can scale and switch input sources to it's two HDMI outputs, with their associated audio signals to the native resolutions supported by the connected display. Control is via the IR remote, RS-232, IP, or via manual selection buttons. Both digital and analogue stereo audio is supported via a built-in

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Digital to Analogue & Analogue to Digital Audio conversion (DAC/ADC)

• Supported Resolutions: HDTV: 480i to 1080p PC:

VGA to WUXGA

• Aspect Ratio Adjustment

• Motion Adaptive De-interlace (3D)

• Video Noise Reduction

DAC (Digital to Analogue Converter) and ADC (Analogue to

Digital Converter). The EL-5500 is the perfect solution for any educational or commercial environment requiring integration of multiple sources and signal formats to two HDMI displays.

• Underscan / Overscan Selection

• Picture Adjustment Settings

SPECIFICATIONS

Input:

3x HDMI (3x HDMI Uncompressed AV and Data)

3x 15pin Dsub (3x VGA RGBHV)

6x 3.5mm Stereo mini-jack (6x Analogue Stereo(L/R))

3x RCA (1x YPbPr Component / YCbCr Component)

1x RCA (1x Composite)

4x RCA (2x Analogue Stereo (L/R))

1x RJ45 (1x IP Control)

1x 9pin Dsub (1x RS-232 Data)

1x USB Type A (1x Service Port - Propriety Data

Output:

2x HDMI (2x HDMI Uncompressed AV and Data)

1x 15pin Dsub (1x VGA - RGBHV / YPbPr Component /

YCbCr Component)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x RCA (1x Coax Digital - 2 Channel LPCM)

Power:

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 433mm (W) x 180mm (D) x 44mm (H)

Gross

Weight:

2940g

Net. Weight: 2140g

P I O N E E R S I N A V T E C H N O L O G I E S

105

HDMI/VGA/Display Port Presentation

Switch & Scaler with HDMI & HDBaseT™ LITE Outputs

EL-5400-HBT

106

3D HDMI HDBT PoC

FEATURES

This HDMI/DisplayPort/VGA to HDMI Scaler with HDBaseT

LITE Output is designed to switch  and scale up to 5 AV inputs to simultaneous HDMI and HDBaseT LITE outputs at resolutions  up to 1080p/WUXGA. The HDBaseT LITE output enables the user to send the signals up to 60m over a single

CAT5e/6/7 cable and supports PoC (Power over Cable) to provide power to the connected HDBaseT LITE receiver

(PU-515PL-RX). Additionally, this device offers 3 analogue Line level audio inputs, a switchable Microphone input and a Line level output

The microphone input features a 48V 'Phantom' power mode for use with professional microphones. The audio DSP engine provides auto-mixing and auto-gain control to mix or reduce the background audio in  order to enhance the main audio source. The system can be controlled and easily configured via

WebGUI, IR remote control or RS-232. This device is an ideal solution for presentation facilities within a classroom and/or conference room.

• Supports HDMI 1.4 (including HDCP) over a single CAT5e/6/7 up to 60m

• Complies with HDBaseT™- Lite specifications

• Supports multiple inputs: 2x HDMI, 2x VGA and

1x DisplayPort, 3x Unbalanced Audio, 1x MIC In

(48V phantom selection)

• Provides simultaneous HDMI and HDBaseT LITE outputs

• Supports HDTV resolutions up to 1080p (VGA to WUXGA)

• Audio DSP offers auto-mixing and auto-gain control for mixing or reducing background audio

• Supports Internal EDID

• Supports pass-through of PCM 2CH

• Supports control via WebGUI, IR remote and

RS-232

• Supports IR In and IR Out to receive or transmit

IR signal from compatible HDBaseT receiver with bi-directional RS-232 control

• Input control provides direct input source selection

SPECIFICATIONS

Input:

2x HDMI Uncompressed AV and Data [1x HDMI]

1x Display Port Uncompressed AV [1x Display Port]

2x VGA RGBHV [1x 15pin Dsub]

1x Microphone [1x 6.35mm Stereo Jack]

3x Analogue Stereo(L/R) [1x 3.5mm Stereo mini-jack]

1x Infra Red Receiver [1x 3.5mm Stereo mini-jack]

1x RS-232 [1x 3.5mm Stereo mini-jack]

1x RS-232 Data [1x 9pin Dsub]

1x IP Control [1x RJ45]

1x Direct switching control port [1x Phoenix (6 pin)]

1x Service Port Propriety Data [1x USB Type A]

COMPATIBLE RECEIVER (RX)

PU-515PL-RX

See Page 91 for specification

Output:

1x HDMI Uncompressed AV and Data [1x HDMI]

1x HDBaseT HDMI & Propriety Data [1x RJ45]

1x Analogue Stereo(L/R) [1x 3.5mm Stereo mini-jack]

1x Infra Red Emitter [1x 3.5mm Stereo mini-jack]

Power:

24V/3.75A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 156mm (W) x 219mm (D) x 43mm (H)

Gross

Weight:

1800g Net. Weight: 1215g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI/VGA/Display Port Presentation Switch

EL-5400

3D HDMI ADC DAC

FEATURES

The EL-5400 is a HDMI, VGA, and Display Port presentation switcher with added 3D to 2D conversion capabilities. This device can scale and switch HDMI, DisplayPort, PC and

Component inputs to its HDMI output, with their associated audio signals to the native resolutions supported by the connected display. Control is via the IR remote, or RS-232 protocol.

SPECIFICATIONS

Input:

2x HDMI (2x HDMI Uncompressed AV and Data)

1x Display Port (1x Display Port Uncompressed AV)

1x 15pin Dsub (1x RGBHV / YCbCr Component / YPbPr

Component)

1x Toslink (1x Toslink 2 Channel LPCM / DTS / Dolby

Digital)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x 9pin Dsub (1x RS-232 Data)

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Integrate and switch HDMI, VGA, and Display

Port sources to a single HDMI output

• Audio de-embedding from a HDMI input

• Digital to Analogue & Analogue to Digital Audio conversion (DAC/ADC)

• 3D to 2D conversion with 3D signal bypass

• Detection of native screen resolution (EDID based)

• Resolutions Supported: HDTV: 480i to 1080p plus 1080p 24fps PC: VGA to WUXGA

• Audio Support: Dolby Digital, Dolby DTS, Dolby

Digital Plus, Dolby True HD, DTS-HD Master

Audio, LPCM Multi-channel, LPCM Stereo,

Analogue Stereo

Output:

x HDMI (1x HDMI Uncompressed AV and Data)

1x Toslink (1x Toslink 2 Channel LPCM / DTS / Dolby

Digital)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 142mm (W) x 185mm (D) x 45mm (H)

Gross

Weight:

122g

Net. Weight: 70g

P I O N E E R S I N A V T E C H N O L O G I E S

107

2 x 8 HDMI HDBaseT™ Switch with Audio De-Embedding

PU-2H8HBTE-AD

4K 3D HDMI HDBT PoC LAN

The PU-2H8HBTE-AD HDBaseT switch has two

HDMI inputs and eight HDBaseT outputs, plus a single HDMI output. This device allows the user to select either HDMI source for distribution to all screens simultaneously. Each HDBaseT output supports the transmission of video (resolutions up to 1080p Full HD, plus 4K Ultra High Definition, and

[email protected]), multi-channel audio, single LAN serving, and control via 2-way IR, RS-232 or Web

GUI/Telnet IP over a single CAT5e/6/7 cable (up to

100m). The HDMI output supports the same video resolutions and high definition audio via certified

HDMI cables up to 15m.

For additional flexibility, the PU-2H8HBTE-AD is provided with Audio De-Embedding functionality allowing easy audio integration into a wider AV system or direct connection to an AVR. Audio outputs are via a single Optical connection or an Analogue

Stereo output (2x RCA).

The HDBaseT outputs are designed to be used with any compatible HDBaseT Receiver as follows:

PU-507RX / PU-507RX-2H / PU-507RX-SCD / PU-

507WPRX / PU-1109RX. These Receivers support

Power over Cable (PoC) function so do not require a separate PSU for power.

Use the LAN serving capabilities of this switch to add internet connectivity to every HDBaseT output zone.

In addition, this switch also features IP control allowing users to access and control the matrix remotely and also allow additional options for integration of thirdparty control systems such as Control 4.

108

P I O N E E R S I N A V T E C H N O L O G I E S

FEATURES

• HDMI, HDCP and DVI complaint

• Supports resolutions VGA~WUXGA, 480i~1080p, 4K

[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K [email protected] 60Hz

(YUV 4:2:0), 4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• High Definition Audio supported: Dolby TrueHD, Dolby

Digital Plus and DTS-HD Master Audio plus LPCM (up to

192kHz)

• Supports 1080p distances up to 100 meters through

CAT5e/6 cables

• Supports HDMI input up to 15m 1080p 8bit or 10m 1080p

12bit.

• Supports RS-232, 2-Way IR, Manual Selection Buttons, and

Web GUI/Telnet IP for control

• HDBaseT outputs support Power over Cable (PoC) with compatible receiver units

• Supports LAN serving to all connected HDBaseT zones

• Supports 3D signals and 4K Ultra High Definition

• Supports 4K/2K & 4K UHD - CAT5e/6 = 70m & CAT6a/7 =

100m

SPECIFICATIONS

Input:

2x HDMI (2x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x LAN Serving)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x USB Mini B (1x Service Port Propriety Data)

Output:

8x RJ45 (8x HDBaseT HDMI & Propriety Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

2x RCA (1x Analogue Stereo (L/R))

1x Toslink (1x Optical 2 Channel LPCM)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 440mm (W) x 280mm (D) x 50mm (H)

Gross Weight: 4460g

Net. Weight: 3200g

Compatible HDBaseT Receivers (RX)

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

109

4 x 2 HDMI Seamless Switch (4K) with Integrated Multi-View (Picture in Picture) Technology

EL-42PIP

110

4K 3D HDMI PiP

FEATURES

The EL-42PIP is an advanced 4 Way HDMI switch with integrated Multi-view (Picture In Picture) technology. This plug and play solution offers advanced control and display options for the integration of four 1080p HDMI sources and output 4K (4x 1080P) to two compatible displays. The output to each connected screen can be independently configured to display the desired sources either in full screen mode or

Control is via preset hot keys, OSD, IR, RS-232 and Telnet for instant control and switching. The WebGUI feature allows complete control over the  size, position and setting of the source images independently to each output.

• Integration of up to 4 sources to two independent displays

• Supports 8 preset screen layout configurations

& an additional 4 custom configurations

• Seamless switching channels and on screen windows

• Fade in out display functionality

• Ability to mirror and rotate images picture-in-picture (PIP) mode. Additional flexibility is provided with on-board pre-configured PIP settings or create and save your favourite custom output configurations to suit any AV installation.

The EL-42PIP is the perfect cost effective solution for integrating CCTV or a combination of HDMI sources to two independent displays within any commercial or residential AV installation.

• Zoom & Shrink HDMI Video and / or Overlay

• Supports adjustment of individual channel size and position

• Resolutions supported : HDTV: 480i to

1080p, [email protected], [email protected]; PC: VGA to

[email protected](RB)

• Supports [email protected]/25/30 on HDMI inputs 1 & 3 only

• Supports IR, On-screen Display (OSD),

RS232,Telnet/WebGUI, Remote and on-panel controls

SCREEN CONFIGURATIONS SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x USB Type A (1x Service - Propriety Data)

Output:

Power:

2x HDMI (2x HDMI Uncompressed AV and Data)

12V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 269mm (W) x 438mm (D) x 52mm (H)

Gross

Weight:

4500g

Net. Weight: 3200g

1 2

1 - 4K INPUT

3 4

1

2

3

4

1 - 4K INPUT

P I O N E E R S I N A V T E C H N O L O G I E S

4-Way HDMI Switch with Integrated Multi-View (Picture in Picture) Technology

EL-41PIP

3D HDMI PiP

The EL-41PIP is an advanced 4 Way HDMI switch with integrated

Multi-view (Picture In Picture) technology. This plug and play solution offers advanced control and display options for the integration of 4 sources onto a single display. The EL-41PIP is the perfect cost effective solution for integrating CCTV or a combination of sources into any single display within  any commercial or residential AV installation.

FEATURES

• Integration of up to 4 sources on a single display

• Multiple screen layout configurations

• Seamless switching channels and on screen windows

• Fade in out display functionality

• Ability to mirror and rotate images

• Zoom & Shrink HDMI Video and / or Overlay

• Resolution supported : HDTV: 480i to 1080p plus

1080p24fps; PC: VGA to UXGA

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x USB Mini B (1x Service Port - Propriety Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

12V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 254mm (W) x 435mm (D) x 50mm (H)

Gross

Weight:

4460g

Net. Weight: 2900g

SCREEN CONFIGURATIONS

2

3

4

1

3

1

2

4

1 2 3 4

2

1

3 4

P I O N E E R S I N A V T E C H N O L O G I E S

111

112

4-Way HDMI Switcher with 2 Identical Outputs

EL-42S

3D HDMI

The EL-42S switcher allows the user to input four HDMI sources and switch between these sources to display HD content on 2 displays. This switcher can be controlled via the supplied remote control, RS-232, or by using the input switching button on the front of the device.

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data

Output:

Power:

2x HDMI (2x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 240mm (W) x 104mm (D) x 50mm (H)

Gross

Weight:

820g

Net. Weight: 600g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 4 Way Switcher with 2 Identical Outputs

• Resolutions Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA & WUXGA (1920x1200). HDTV -

480i, 576i, 480p, 576p, 720p, 1080i, 1080p and

1080p24fps

• High Definition Audio supported - Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio plus LPCM

• Auto signal enhancement feature can improve signal quality after long distance transmission

• RS232 & IR Remote Control

• Supports 'Deep Colour' (10 & 12 bit)

• Dual HDMI outputs for simultanious connection to two HD Displays

• Supports 3D signals

• Supports xvYCC

P I O N E E R S I N A V T E C H N O L O G I E S

4-Way Advanced HDMI Switcher

4K, HDCP2.2, HDMI2.0, IR, RS-232, IP, Web GUI

EL-41HP-4K22

4K 3D HDMI2.0

HDCP2.2

This 4-Way HDMI Switcher is designed to enable the user to switch between any of the four connected HDMI sources to send video and audio to a single HDMI display. This switcher fully supports 4K resolutions and is HDMI2.0 and HDCP 2.2 compliant, ensuring maximum compatibility with the latest

4K UHD sources and displays.

FEATURES

• HDMI2.0, HDCP 2.2 and DVI compatible

• Supports 4 HDMI inputs and 1 HDMI output

• Supports HDTV resolutions up to 4K2K

([email protected]/25/30/50/60 & 4096x2160

@24/25/30/50/60Hz)

The EL-41HP-4K22  supports all the latest features of the HDMI  2.0 specification such as 4K UHD resolutions

([email protected] - YUV4:4:4),HDR (High Dynamic  Range), 'Deep

Color', and High Definition audio. In addition, this switcher

• Supports pass-through of HD audio formats of

PCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby

Atmos and DTS-HD Master Audio also features an Auto-Switching function which detects the last active input and switches to this input automatically for display. The management of  source/sink configurations can be easily controlled via the on-board WebGUI LAN control, IR remote control and RS-232.

• Supports control via Telnet, WebGUI, IR remote and RS-232

• Supports Auto-switching which can send the signal of the latest active HDMI input source to output port

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x Telnet & WebGUI IP)

1x USB Type A (1x Service Port Propriety Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 219mm (W) x 156mm (D) x 43mm (H)

Gross

Weight:

1400g

Net. Weight: 1300g

P I O N E E R S I N A V T E C H N O L O G I E S

113

4-Way HDMI Switcher

4K, HDCP2.2, HDMI2.0, IR

EL-41S-4K22

114

4K 3D HDMI2.0

HDCP2.2

IR

This 4-Way HDMI Switcher is designed to enable the user to switch between any of the four connected HDMI sources to send video and audio to a single HDMI display. This switcher fully supports 4K resolutions and is HDMI2.0 and HDCP 2.2 compliant, ensuring maximum compatibility with the latest

4K UHD sources and displays. The EL-41HP-4K22  supports all the latest features of the HDMI  2.0 specification such as 4K UHD resolutions ([email protected] - YUV4:4:4),HDR (High

Dynamic  Range), 'Deep Color', and High Definition audio.

In addition, this switcher also features an Auto-Switching function which detects the last active input and switches to this input automatically for display.  The management of source/sink configurations can be easily controlled via the on-board WebGUI LAN control, IR remote control and RS-232.

• HDMI2.0, HDCP 2.2 and DVI compatible

• Supports 4 HDMI inputs and 1 HDMI output

• Supports HDTV resolutions up to 4K2K

([email protected]/25/30/50/60 & 4096x2160

@24/25/30/50/60Hz)

• Supports pass-through of HD audio formats of

PCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby

Atmos and DTS-HD Master Audio

• Supports control via Telnet, WebGUI, IR remote and RS-232

• Supports Auto-switching which can send the signal of the latest active HDMI input source to output port

SPECIFICATIONS

FEATURES

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x Telnet & WebGUI IP)

1x USB Type A (1x Service Port Propriety Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 219mm (W) x 156mm (D) x 43mm (H)

Gross

Weight:

1400g

Net. Weight: 1300g

P I O N E E R S I N A V T E C H N O L O G I E S

4-Way HDMI Switcher

EL-41SY

3D HDMI

The EL-41SY switcher allows the user to input four HDMI sources and switch between these sources to provide a single

HDMI output to a display. This switcher can be controlled via the supplied remote control or by using the input switching button on the front of the device.

SPECIFICATIONS

Input:

4x HDMI (4x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 201mm (W) x 104mm (D) x 25mm (H)

Gross

Weight:

640g

Net. Weight: 420g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 4-way Switcher

• Resolutions Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA & WUXGA (1920x1200). HDTV -

480i, 576i, 480p, 576p, 720p, 1080i, 1080p and

1080p24fps.

• High Definition Audio supported - Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio plus LPCM

• Auto signal enhancement feature can improve signal quality after long distance transmission

• IR Remote Control

• Supports 'Deep Colour' (8, 10 & 12 bit)

• LED indicators

• Supports xvYCC

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

115

116

3-Way HDMI Switcher

EL-31SY

3D HDMI

The EL-31SY switcher allows the user to input three HDMI sources and switch between these sources to provide a single

HDMI output to a display. This switcher can be controlled via the supplied remote control or by using the input switching button on the front of the device.

SPECIFICATIONS

Input:

3x HDMI (3x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1A

DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 200mm (W) x 105mm (D) x 32mm (H)

Gross

Weight:

640g

Net. Weight: 420g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 3-way Switcher

• Resolutions Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA & WUXGA (1920x1200). HDTV -

480i, 576i, 480p, 576p, 720p, 1080i, 1080p and

1080p24fps.

• High Definition Audio supported - Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio plus LPCM

• Auto signal enhancement feature can improve signal quality after long distance transmission

• IR Remote Control

• Supports 'Deep Colour' (10, 12 & 16 bit)

• LED indicators

• Supports xvYCC

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

2-Way HDMI Switcher

EL-21SY

3D HDMI

The EL-21SY switcher accepts two HDMI inputs and allows the user to switch between two input sources to provide a single HDMI output for connection to the HDMI display. This switcher has an auto-detect function which will switch the unit when a source which is powered ‘On’. Alternatively, the input can be selected manually using the input selection button on the device.

SPECIFICATIONS

Input:

2x HDMI (2x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 101mm (W) x 92mm (D) x 25mm (H)

Gross

Weight:

520g

Net. Weight: 380g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 2-way Switcher

• Resolutions Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA & WUXGA (1920x1200). HDTV -

480i, 576i, 480p, 576p, 720p, 1080i, 1080p and

1080p24fps

• High Definition Audio supported - Dolby

TrueHD, Dolby Digital Plus and DTS-HD Master

Audio plus LPCM

• Auto signal enhancement feature can improve signal quality after long distance transmission

• Auto-switch design

• Supports 'Deep Colour' (10, 12, & 16 bit)

• LED indicators

• Supports xvYCC

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

117

118

1 to 16 HDMI Distribution Amplifier

4K resolution support

QU-16E-4K

4K 3D HDMI

The QU-16E-4K is a versatile 1 to 16 HDMI distribution amplifier. This product is designed to be used in a 19” rack and will distribute uncompressed HDMI signals up to 4K resolutions. Each buffered output can run 1080p/8-bit up to

10 metres and can be cascaded up to two layers.

SPECIFICATIONS

Input:

Output:

Power:

Dimensions: 435mm (W) x 125mm (D) x 50mm (H)

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x USB Type B (1x Service Port Propriety Data)

16x HDMI (16x HDMI Uncompressed AV and Data)

5V/6A DC (US/EU standards, CE/FCC/UL certified)

1720g

Net. Weight: 1320g

FEATURES

• HDMI 1.3, HDCP 1.4 and DVI 1.0 compliant

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• High Definition Audio supported: LPCM 7.1Ch,

Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission (32-192kHz Fs sample rate)

• HDMI cable distance tested with 1080p/8bits resolution the I/O source can up run up to 15/15 meters. If 1080p/12bits the I/O source can run up to 15/10 meters.

• Supports xvYCC

• Supports 3D signals

• 4K Resolution Support

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 10 HDMI Distribution Amplifier

4K, HDCP2.2, HDMI2.0

QU-10-4K22

4K 3D HDMI2.0

HDCP2.2

The QU-10-4K22 Distribution Amplifier (splitter) accepts one

HDMI input and splits this signal to ten identical outputs.

This device supports 4K2K Ultra-High Definition video with

HDMI2.0 and HDCP2.2 compliance. In addition, 3D Video signals and High Definition Audio formats such as LPCM

7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and

DTS-HD Master Audio, audio sampling rate up to 192kHz are also supported. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

Output:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x USB Mini B (1x Service - Propriety Data)

10x HDMI (10x HDMI 2.0 Uncompressed AV and Data)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 160mm (W) x 436mm (D) x 44mm (H)

FEATURES

• HDMI 2.0, HDCP 2.2 and DVI compliant

• Supports UHDTV resolutions up to 4K2K:

[email protected]/25/30/50/60Hz & 4096x2160

@24/25/30/60Hz

• Supports passthrough of high definition audio:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby TrueHD, DTS-HD Master Audio &

Dolby Atmos

• Supports System Reset function (CEC active source command) allows the unit to reset the TV to its default HDMI input automatically

• HDMI input supports 'Standard' mode and 'TV' mode EDID settings

• Input and output status are indicated on the front panel

Gross

Weight:

2600g

Net. Weight: 2000g

P I O N E E R S I N A V T E C H N O L O G I E S

119

120

1 to 8 HDMI Distribution Amplifier

4K, HDCP2.2, HDMI2.0

QU-8-4K22

4K 3D HDMI2.0

HDCP2.2

The QU-8-4K22 Distribution Amplifier (splitter) accepts one

HDMI input and splits this signal to eight identical outputs.

This device supports 4K2K Ultra-High Definition video with

HDMI2.0 and HDCP2.2 compliance. In addition, 3D Video signals and High Definition Audio formats such as LPCM

7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and

DTS-HD Master Audio, audio sampling rate up to 192kHz are also supported. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

1x HDMI [1x HDMI Uncompressed AV and Data]

1x USB Mini B [1x Service Port Propriety Data]

FEATURES

• HDMI 2.0, HDCP 2.2 and DVI compliant

• Supports UHDTV resolutions up to 4K2K:

3840×[email protected]/25/30/50/60Hz & 4096×2160

@24/25/30/60Hz

• Supports passthrough of high definition audio:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby TrueHD, DTS-HD Master Audio &

Dolby Atmos

• Supports System Reset function (CEC active source command) allows the unit to reset the TV to its default HDMI input automatically

• HDMI input supports 'Standard' mode and 'TV' mode EDID settings

• Input and output status are indicated on the front panel

Output:

Power:

8x HDMI [8x HDMI Uncompressed AV and Data]

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 103mm [W] x 240mm [D] x 25mm [H]

Gross

Weight:

668g

Net. Weight: 1252g

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 8 HDMI Distribution Amplifier with System Reset

QU-8MS

3D HDMI

The QU-8MS Distribution Amplifier (splitter) accepts one

HDMI input and splits this signal to eight identical outputs.

This device is 3D compatible and features a 3D signal indicator which confirms when a 3D source signal is detected. The

System Reset Function switch generates a command every 10 minutes to the connected displays which resets them to the correct HDMI input. Each buffered output can run 1080p/8-bit up to 15 metres and can also be cascaded in multiple layers.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

8x HDMI (8x HDMI Uncompressed AV and Data)

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 101mm (W) x 240mm (D) x 30mm (H)

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 1 to 8 Splitter with System Reset function

• Resolutions supported: PC - VGA to UXGA; HDTV

- 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• Auto signal amplification & equalisation improves signal transmission distances

• Supports CEC bypass

• Supports Deep Colour (10 & 12bit)

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• 3D Signal, Power, & SYNC LED indicators

• Supports xvYCC

• Supports 3D signals

Gross

Weight:

1060g

Net. Weight: 660g

P I O N E E R S I N A V T E C H N O L O G I E S

121

122

1 to 8 Rack Mountable HDMI

Distribution Amplifier

QU-18S

3D HDMI

FEATURES

The QU-18S Distribution Amplifier (splitter) accepts one HDMI input and splits this signal to eight identical outputs. This device is compatible to v1.3 HDMI specifications, supporting

‘Deep Colour’ together with High Definition Audio. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

Output:

Power:

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

8x HDMI (8x HDMI Uncompressed AV and Data)

5V/6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 435mm (W) x 160mm (D) x 45mm (H)

1750g

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 1 to 8 Splitter

• Resolutions supported: PC - VGA to UXGA; HDTV

- 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM (32-192KHz sample rate)

• Auto signal amplification & equalisation improves signal transmission distances

• Supports CEC bypass

• Supports Deep Colour (10 & 12bit)

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Power, HDMI/DVI, HDCP & SYNC plus independent output LED's indicator

• Supports xvYCC

• Supports 3D signals

Net. Weight: 1750g

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 8 HDMI to Single CAT6 Splitter

PU-Q1H8CS

3D HDMI

The PU-Q1H8CS has 1 HDMI input and 8 Single CAT6 outputs to simultaneously distribute a HDMI source to eight displays up to a distance of 40m. This solution is perfect for distributing the HDMI source content over longer distances than is usually achievable with HDMI cable, using cost effective CAT6 cable infrastructure.

Use the PU-1107RX Single CAT6 to HDMI Receivers on each of the eight CAT6 outputs to convert back from CAT6 to HDMI for connection to the display or displays.

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Resolutions supported: PC - VGA to WUXGA;

HDTV - 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• CAT output can run up to 40m @ 1080p, 8 bit

• Selectable EDID settings - TV (downstream) or

STD (fixed) and 12 bit or 8 bit Deep Colour

• Supports ‘Deep Colour’ (10 & 12 bit)

• Supports 3D signals

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

8x RJ45 (8x HDMI & Propriety Data)

5V/3.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 240mm (W) x 105mm (D) x 30mm (H)

Gross

Weight:

740g

Net. Weight: 500g

COMPATIBLE RECEIVERS (RX)

PU-1107RX

See Page 99 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

123

1 HDMI to 7 HDBaseT™ Splitter (100m) including HDMI output bypass

PU-1H7HBTE

124

4K 3D HDMI HDBT PoC LAN

The PU-1H7HBTE enables a single HDMI source input to be distributed to 7 HDBaseT™ outputs. The HDBaseT™ outputs allow uncompressed distribution of HDMI, LAN, PoC, and IR signals over a Single CAT5e/6/7 cable up to lengths of 100m.

Perfect for both residential and commercial AV installations, the PU-1H7HBTE can distribute HDMI signals to 7 displays. The product also includes an additional HDMI output for increased flexibility and can also be cascaded up to 5 times to allow distribution to potentially 50 screens or more.

PU-507RX or PU-507WPRX Receivers are recommended to utilise the functionality of the HDBaseT™ outputs of this device.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x RJ45 (1x LAN Serving)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

7x RJ45 (7x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

PoC Power: 24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

FEATURES

• Supports all v1.4 HDMI resolutions plus 4K

• HDMI, HDCP, & DVI compliant

• Supports HDMI / LAN / PoC (Power over Cable)

/ IR

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports uncompressed video/audio up to

10.2Gbps

• Additional HDMI bypass output provided for increased flexibility

• Supports HDCP repeating and CEC functions

• Supports 1080p distances up to 100 meters through CAT5e/6 cables

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• Supports 3D signals

• Supports 4K/2K & 4K UHD - CAT5e/6 = 70m &

CAT6a/7 = 100m

COMPATIBLE RECEIVERS (RX)

Dimensions: 430mm (W) x 180mm (D) x 40mm (H)

Gross

Weight:

3800g

Net. Weight: 2140g

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

1 HDMI to 7 HDBaseT™ LITE Splitter (60m) including HDMI output bypass (with PoC)

PU-1H7HBTPL

4K 3D HDMI HDBT PoC

The PU-1H7HBTPL enables a single HDMI source input to be distributed to 7 HDBaseT™ Lite with PoC outputs. The

HDBaseT™ Lite outputs allow  uncompressed distribution of HDMI, and IR signals over a Single CAT5e/6/7 cable up to lengths of 60m. Perfect for both residential and commercial

AV installations, the PU-1H7HBTPL can distribute HDMI signals to 7 displays. The product also includes an additional HDMI output for increased flexibility and can also be cascaded up to

5 times to allow distribution to more screens.

PU-515PL-RX Receivers are recommended to utilise the full functionality of the HDBaseT™ LITE with PoC outputs of this device.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

FEATURES

• Supports all v1.4 HDMI resolutions plus 4K

• HDMI, HDCP, & DVI compliant

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports HDCP repeating and CEC functions

• Supports 1080p distances up to 60 meters through CAT5e/6 cables

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

7x RJ45 (7x HDBaseT Lite PoC HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

24V/6.25A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 430mm (W) x 180mm (D) x 40mm (H)

• Supports HDMI / IR

• Supports 3D signals

• Supports PoC (power over cable) providing power for the receivers

• Supports 4K/2K & 4K UHD - CAT5e/6 = 35m &

CAT6a/7 = 40m

Gross

Weight:

3300g

Net. Weight: 2120g

COMPATIBLE RECEIVERS (RX)

PU-515PL-RX

See Page 91 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

125

126

1 to 4 HDMI Distribution Amplifier

4K, HDCP2.2, HDMI2.0

QU-4-4K22

4K 3D HDMI2.0

HDCP2.2

The QU-4-4K22 Distribution Amplifier (splitter) accepts one

HDMI input and splits this signal to four identical outputs.

This device supports 4K2K Ultra-High Definition video with

HDMI2.0 and HDCP2.2 compliance. In addition, 3D Video signals and High Definition Audio formats such as LPCM

7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and

DTS-HD Master Audio, audio sampling rate up to 192kHz are also supported. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x USB Mini B (1x Service Propriety Data)

Output:

Power:

4x HDMI (4x HDMI 2.0 Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 117mm (W) x 231mm (D) x 25mm (H)

Gross

Weight:

1066g

Net. Weight: 610g

FEATURES

• HDMI 2.0, HDCP 2.2 and DVI compliant

• HDMI 1 to 4 HDMI splitter

• Supports UHDTV resolutions up to 4K2K:

[email protected]/25/30/50/60Hz & 4096x2160

@24/25/30/60Hz

• Supports passthrough of high definition audio:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby TrueHD, DTS-HD Master Audio &

Dolby Atmos

• Supports System Reset function (CEC active source command) allows the unit to reset the TV to its default HDMI input automatically

• HDMI input supports 'Standard' mode and 'TV' mode EDID settings

• Input and output status are indicated on the front panel

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 4 HDMI Distribution Amplifier

QU-14S

3D HDMI

The QU-14S Distribution Amplifier (splitter) accepts one HDMI input and splits this signal to four identical outputs. This device is compatible to v1.3 HDMI specifications, supporting

‘Deep Colour’ together with High Definition Audio. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

4x HDMI (4x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 215mm (W) x 135mm (D) x 45mm (H)

Gross

Weight:

800g

Net. Weight: 580g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 1 to 4 Splitter

• Resolutions supported: PC - VGA to UXGA; HDTV

- 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• Auto signal amplification & equalisation improves signal transmission distances

• Supports CEC bypass

• Supports Deep Colour (10 & 12 bit)

• Selectable EDID settings - TV (downstream) and

STD (fixed)

• Power, HDMI/DVI, HDCP & SYNC plus independent output LED's indicator

• Supports xvYCC

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

127

1 HDMI to 3 HDBaseT™ Splitter (100m) including HDMI output bypass

PU-1H3HBTE

128

4K 3D HDMI HDBT LAN PoC

The PU-1H3HBTE enables a single HDMI source input to be distributed to 3 HDBaseT™ outputs. The HDBaseT™ outputs allow uncompressed distribution of HDMI, LAN, PoC, and IR over a Single CAT5e/6/7 cable up to lengths of 100m. Perfect for both residential and commercial AV installations, the

PU-1H3HBTE can distribute HDMI signals to 3 displays. The product also includes an additional HDMI output for increased flexibility and can also be cascaded up to 5 times to allow distribution to potentially 50 screens or more.

The PU-507RX or PU-507WPRX Receivers are recommended to utilise the functionality of the  HDBaseT™ outputs of this device.

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

1x RJ45 (1x LAN Serving)

1x HDMI (1x HDMI Uncompressed AV and Data)

3x RJ45 (3x HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

24V/4.16A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 145mm (W) x 200mm (D) x 30mm (H)

FEATURES

• Supports all v1.4 HDMI resolutions including 4k.

• HDMI, HDCP, & DVI compliant

• Supports HDMI / LAN / PoC (Power over Cable)

/ IR

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports uncompressed video/audio up to

10.2Gbps

• Supports HDCP repeating and CEC functions

• Additional HDMI bypass output provided to improve flexibility

• Supports 1080p distances up to 100 meters through CAT5e/6 cables

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• Supports 3D signals

• Supports 4K/2K & 4K UHD - CAT5e/6 = 70m &

CAT6a/7 = 100m

Gross

Weight:

720g

Net. Weight: 580g

COMPATIBLE RECEIVERS (RX)

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

1 HDMI to 3 HDBaseT™ LITE Splitter (60m) including HDMI output bypass (with PoC)

PU-1H3HBTPL

4K 3D HDMI HDBT PoC

The PU-1H3HBTPL enables a single HDMI source input to be distributed to 3 HDBaseT™ Lite outputs. The HDBaseT™ Lite outputs allow  uncompressed distribution of HDMI, and IR signals over a Single CAT5e/6/7 cable up to lengths of 60m.

Perfect for both residential and commercial AV installations, the PU-1H3HBTPL can distribute HDMI signals to 3 displays.

The product also includes an additional HDMI output for increased flexibility and can also be cascaded up to 5 times to allow distribution to more screens.

PU-515PL-RX receivers are recommended to utilise the full functionality of the HDBaseT™ LITE with PoC outputs of this device.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

3x RJ45 (3x HDBaseT Lite PoC HDMI & Propriety Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Emitter)

Power:

24V/2.7A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 145mm (W) x 200mm (D) x 30mm (H)

FEATURES

• Supports all v1.4 HDMI resolutions plus 4K

• HDMI, HDCP, & DVI compliant

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports HDCP repeating and CEC functions

• Supports 1080p distances up to 60 meters through CAT5e/6 cables

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• Supports HDMI and IR

• Supports 3D signals

• Supports PoC (Power over Cable) providing power for the receivers

• Supports 4K/2K & 4K UHD - CAT5e/6 = 35m &

CAT6a/7 = 40m

Gross

Weight:

720g

Net. Weight: 580g

COMPATIBLE RECEIVERS (RX)

PU-515PL-RX

See Page 91 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

129

1 HDMI to 2 HDBaseT™ Splitter (100m) including HDMI output bypass

PU-1H2HBTE

130

4K 3D 5Play HDMI HDBT PoC LAN

The PU-1H2BTE splitter accepts 1x HDMI input and distributes to 2 HDBaseT™ outputs, plus 1 HDMI bypass output. The

HDBaseT™ outputs allow uncompressed HDMI, LAN, PoC, IR, and RS-232 signals to be transmitted over a Single CAT5e/6/7 cable up to 100m. Installers can confidently distribute HDMI signals to 3 displays, and if required, use the HDMI bypass output to cascade the HDMI signal up to 5 times with additional HDBaseT™ splitters.

PU-507RX Receivers are recommended to utilise the full

5-Play™ functionality of the HDBaseT™ outputs of this device.

SPECIFICATIONS

Input:

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

2x 3.5mm Stereo mini-jack (2x RS-232)

2x 3.5mm Stereo mini-jack (2x Infra Red Receiver)

1x HDMI (1x HDMI Uncompressed AV and Data)

2x RJ45 (2x HDMI & Propriety Data)

2x 3.5mm Stereo mini-jack (2x Infra Red Emitter)

1x RJ45 (1x Ethernet (I/O) IP)

24V/2.7A DC (US/EU standards, CE/FCC/UL certified)

FEATURES

• Supports all v1.4 HDMI resolutions plus 4K

• HDMI, HDCP, & DVI compliant

• Supports uncompressed video/audio up to

10.2Gbps

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz

(RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV

4:2:0) dependent upon the output display’s

EDID settings

• Supports HDCP repeating and CEC functions

• Supports 1080p distances up to 100 meters through CAT5e/6 cables

• Audio support up to 7.1CH & Dolby TrueHD,

DTS-HD

• Supports full 5-Play™ Convergence : HDMI / LAN

/ PoC (Power over Cable) / IR / RS-232

• Supports 3D signals

• Supports 4K/2K & 4K UHD - CAT5e/6 = 70m &

CAT6a/7 = 100m

Dimensions: 145mm (W) x 160mm (D) x 30mm (H)

Gross

Weight:

700g

Net. Weight: 530g

COMPATIBLE RECEIVERS (RX)

PU-507RX

See Page 87 for specification

PU-507-WPRX

See Page 88 for specification

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 2 HDMI Distribution Amplifier

4K, HDCP2.2, HDMI2.0

QU-2-4K22

4K 3D HDMI2.0

HDCP2.2

The QU-2-4K22 Distribution Amplifier (splitter) accepts one

HDMI input and splits this signal to two identical outputs.

This device supports 4K2K Ultra-High Definition video with

HDMI2.0 and HDCP2.2 compliance. In addition, 3D Video signals and High Definition Audio formats such as LPCM

7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and

DTS-HD Master Audio, audio sampling rate up to 192kHz are also supported. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x USB Mini B (1x Service - Propriety Data)

Output:

Power:

2x HDMI (2x HDMI 2.0 Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 117mm (W) x 128mm (D) x 25mm (H)

Gross

Weight:

986g

Net. Weight: 350g

FEATURES

• HDMI 2.0, HDCP 2.2 and DVI compliant

• HDMI 1 to 2 splitter

• Supports UHDTV resolutions up to 4K2K:

[email protected]/25/30/50/60Hz & 4096x2160

@24/25/30/60Hz

• Supports passthrough of high definition audio:

LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS

2/5.1CH, Dolby TrueHD, DTS-HD Master Audio &

Dolby Atmos

• Supports System Reset function (CEC active source command) allows the unit to reset the TV to its default HDMI input automatically

• HDMI input supports 'Standard' mode and 'TV' mode EDID settings

• Input and output status are indicated on the front panel

P I O N E E R S I N A V T E C H N O L O G I E S

131

1 to 2 HDMI Distribution Amplifier

QU-12S

3D HDMI

The QU-12S Distribution Amplifier (splitter) accepts one HDMI input and splits this signal to two identical outputs. This device is compatible to v1.3 HDMI specifications, supporting ‘Deep

Colour’ together with High Definition Audio. Each buffered output can run 1080p/8-bit up to 20 metres and can also be cascaded up to 3 layers.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

2x HDMI (2x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 102mm (W) x 146mm (D) x 25mm (H)

Gross

Weight:

780g

Net. Weight: 500g

FEATURES

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• HDMI 1 to 2 Splitter

• Resolutions supported: PC - VGA to UXGA; HDTV

- 480i to 1080p plus 1080p24fps

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• Auto signal amplification & equalisation improves signal transmission distances

• Supports CEC bypass

• Supports Deep Colour (10 & 12 bit)

• Supports xvYCC

• Supports 3D signals

132

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 2 DVI Distribution Amplifier

QU-12D

DVI

The QU-12D is a high performance, HDCP compliant, DVI distribution amplifier allowing one DVI input to be distributed to two displays simultaneously. Each of the buffered outputs can run up to 15 meters (8-bit) and can be cascaded up to 3 layers.

FEATURES

• HDMI 1.3 and DVI 1.0 compliant

• Supports PC resolutions: VGA to WUXGA

• Supports HDTV resolutions : 480p to 1080p

• Can be cascaded up to 3 layers

• Each output can run up to 15m/8-bit or 10m/12-bit

• The device will read EDID of output 1 and will record it

SPECIFICATIONS

Input:

1x DVI-I (1x DVI-D)

Output:

Power:

2x DVI-I (2x DVI-D)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 123mm (W) x 100mm (D) x 30mm (H)

Gross

Weight:

540g

Net. Weight: 260g

P I O N E E R S I N A V T E C H N O L O G I E S

133

Our scaling and conversion solutions help tame the wide variety of AV signals, connector types, and legacy formats to enable installers to easily integrate and optimise any audio or video source into a wider

AV system.

We have built up an extensive range of AV format converters and scalers that help the installer easily overcome the installation challenges and ensure that every AV signal in the wider system can be optimised to achieve the highest possible results.

HDMI to HDMI Scaler with Audio Embedding & De-Embedding

SY-300H

136

HDMI

The SY-300H will allow a HDMI source signal to be scaled up or down to a variety of different resolutions selectable via the OSD (On Screen Display). When set to 'native' mode, the scaler will  automatically scale the HDMI input signal to the native resolution of the connected screen. This device also provides 50/60Hz frame rate conversion further enhancing compatibility with AV sources and displays.

In addition, the SY-300H includes integrated audio embedding and de embedding using the Toslink and 3.5mm jack inputs and outputs.

SPECIFICATIONS

Input:

1x HDMI (1x Uncompressed AV and Data)

1x Toslink (1x 2 Channel LPCM / Dolby Digital / DTS)

1x USB Type A (1x Service Port Propriety Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

Output:

1x HDMI (1x Uncompressed AV and Data)

1x Toslink (1x 2 Channel LPCM / Dolby Digital / DTS)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 100mm (W) x 150mm (D) x 25mm (H)

Gross

Weight:

600g

Net. Weight: 340g

FEATURES

• HDMI, HDCP and DVI compliant

• Full range of resolutions supported PC from

VGA - WUXGA (RB) and HD resolutions from

480i - 1080p

• Output resolution can be set to native, which automatically scales the output to the resolution of the connected display

• Features 50/60Hz frame rate conversion

• Supports 3-D motion video adaptive, 3-D deinterlacing, and 3:2/2:2 pull-down detection and recovery

• Provides output picture adjustment on contrast, brightness, hue, saturation, sharpness, RGB

(colour tone) level and aspect ratio size

• Supported audio HDMI and Toslink: Dolby

Digital, DTS, LPCM 5.1 and LPCM 2.0

• Supported audio 3.5mm Jack: Analogue stereo audio

P I O N E E R S I N A V T E C H N O L O G I E S

PC to HDMI Converter and Scaler with Audio

SY-P293

HDMI

The SY-P293 is designed to scale analogue video signal from a PC source to a digital HDMI output boasting a wide-range of HDTV and PC resolutions. Audio is combined with HDMI video output. This unit offers a selection of colour space and adjustment to obtain the best picture quality.

SPECIFICATIONS

Input:

1x 15pin Dsub (1x PC RGBHV)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 102mm (W) x 154mm (D) x 25mm (H)

Gross

Weight:

1000g

Net. Weight: 700g

FEATURES

• v1.2 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Scales any PC resolutions to PC or HDTV resolutions

• Resolutions Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA, WXGA, WSXGA, WUXGA. SD/HD -

480i, 576i, 480p, 576p, 720p, 1080i and 1080p

• Audio Support: Analogue Stereo, Digital stereo

PCM, DTS, and Dolby Digital. Simply select from the audio input source this is then outputted to HDMI, Optical (Toslink), and mini-jack (stereo only) simultaneously

• On Screen Menu with push button control

• Provides output picture adjustment on contrast, brightness, hue, saturation, sharpness, RGB

(colour tone) level and aspect ratio size

• Automatic detection of the factory setting of the connected display and output the corresponding resolution and refresh rate, when the NATIVE output is selected (default setting)

P I O N E E R S I N A V T E C H N O L O G I E S

137

138

CV/SV to HDMI Converter and Scaler with Audio

SY-P295N

HDMI

The SY-P295N is designed to scale analogue video signal from a Component Video or S-Video source to a digital HDMI output, boasting a wide-range of HDTV and PC resolutions.

Audio is combined with HDMI video output. This unit offers a selection of colour space and adjustment to obtain the best picture quality.

SPECIFICATIONS

Input:

1x RCA (1x Composite)

1x S-video plug (1x S-video)

2x RCA (1x Analogue Stereo (L/R))

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x Toslink (1x Optical DTS / Dolby Digital / 2 Channel

LPCM)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 102mm (W) x 187mm (D) x 25mm (H)

Gross

Weight:

880g

Net. Weight: 680g

FEATURES

• v1.2 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Video Support: Input - PAL & NTSC. Output

Resolution Supported: PC - VGA, SVGA, XGA,

SXGA, UXGA, WXGA, WSXGA, WUXGA. SD/HD -

480i, 576i, 480p, 576p, 720p, 1080i and 1080p

• Audio Support: Analogue Stereo, Digital stereo

PCM, and DTS. Simply select from the audio input source, this is then outputted to HDMI,

Optical (Toslink), and mini-jack (stereo only) simultaneously.

• A comprehensive OSD menu provides picture adjustment on contrast, brightness, hue, saturation, sharpness, RGB (colour tone) level and aspect ratio size

• Automatic detection of the connected screens factory setting, matching the resolution and refresh rate, when the NATIVE output is selected

P I O N E E R S I N A V T E C H N O L O G I E S

PC/DVI to HDMI Converter

SY-P290

HDMI

The SY-P290 is designed to convert and scale Digital or

Analogue RGBHV or YUV Video to HDMI for improved viewing.   This unit offers a wide selection of output resolutions/format, colour space and adjustment to obtain the best picture quality.

SPECIFICATIONS

Input:

1x 3.5mm Stereo mini-jack (1x Stereo(L/R))

1x DVI-I (1x DVI-D)

1x 15pin Dsub (1x RGBHV / YPbPr Component / YCbCr

Component)

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

FEATURES

• v1.2 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Common supported resolutions: HDTV: 480p,

576p, 720p, 1080i, 1080p, 1080p24; PC: VGA,

SVGA, XGA, WXGA, SXGA, UXGA,WUXGA.

• Audio Support: Input - Analogue stereo & Coax;

PCM Stereo, DTS & Dolby Digital; Output -

Follows Input

• Scale analogue RGBHV/YUV and/or DVI/HDMI resolutions to XGA/UXGA/720p/1080p

• Direct push button controls for Audio, Video &

Timing

Output:

Power:

1x HDMI (1x Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 102mm (W) x 160mm (D) x 25mm (H)

Gross

Weight:

700g

Net. Weight: 440g

P I O N E E R S I N A V T E C H N O L O G I E S

139

HDMI 4K Scaler

Optional Up & Down Scaling

SY-4KS

140

4K HDMI HDCP1.4

The SY-4KS HDMI Scaler is designed to upscale [email protected] signals to 4K Ultra High Definition (UHD) resolutions, or downscale a UHD 4K signal to [email protected] for integration into any AV system. The ability to downscale 4K signals to 1080p is a crucial function when working with 4K sources in a complex

AV system and distributing the HDMI sources to multiple displays which have varying resolution support. This device allows the user to select the highest commonly supported resolution between source and display ensuring maximum compatibility in any system. The SY-4KS incorporates two

HDMI outputs, one of which is a bypass (input follows output), and the second is a scaled output. The scaled output can be set to three modes, upscale to 4K, downscale from 4K, or as a bypass output. Both the bypass output and scaled output operate simultaneously.

FEATURES

• Supports HDMI upscaling to 4K or downscale to

[email protected]

• Supports HDMI signal bypass

• Simultaneous HDMI outputs

• Supports resolutions VGA~WUXGA, 480i~1080p,

4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) dependent upon the output display’s EDID settings

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x USB Mini B (1x Service Port Propriety Data)

Output:

Power:

2x HDMI (2x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 105mm (W) x 110mm (D) x 25mm (H)

Gross

Weight:

640g

Net. Weight: 220g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI to HDMI Up & Down Scaler including 24fps input support

SY-298H24

HDMI

The SY-298H24 will allow a HDMI source signal to be up or down scaled according to the screen specifications required.

Any HDMI signal inputted can be scaled up or down to between 480i to 1080p, plus PC output resolutions of VGA or UXGA. This device accepts 1080p24 input resolutions enabling content filmed at 24 frames per second displayed.

This feature is particularly useful when a 1080p24 source signal is distributed to multiple displays. If any screen is not

1080p24 compatible, the SY-298H24 can be used to scale the input signal to suit the supported screen resolution, whilst not affecting the signal being sent to the 1080p24 compatible screens. This solution is perfect for home cinema enthusiasts who require full native Blu-ray resolutions in their home cinema system, whilst providing signal flexibility to other screens around the home.

FEATURES

• HDMI, HDCP1.1 and DVI compliant

• Upscale video signal from HDMI source between

480p and [email protected]/60, including 1080p24

• Supports a wide range of output resolutions from 480p to 1080p and PC from VGA to SXGA

• Supports audio sampling rate up to 192kHz

• Supports Dolby & DTS 5.1 audio pass-through.

• Motion adaptive 3-D deinterlacing algorithm

• 3-D noise reduction in both temporal and spatial domain

• Supports Frame rate conversion

• Adaptive contrast enhancement

• Support CEC bypass

• OSD (On Screen Display) Menu for ease of use

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 85mm (W) x 80mm (D) x 25mm (H)

Gross

Weight:

280g

Net. Weight: 220g

P I O N E E R S I N A V T E C H N O L O G I E S

141

142

CV & SV to HDMI Converter with Audio Input

SY-398H

HDMI

This Video to HDMI™ converter can convert CV/SV (NTSC or PAL or SECAM) to HDMI resolutions of XGA to UXGA, or HD resolutions  of 480p to 1080p. With a frame rate conversion feature that allows users to  view DVD, VCR or video game sources on the HD monitor/TV, this device has  an On-

Screen Display function that allows users to easily select the output resolution and the audio input, after which both the video and audio signal are combined into an HDMI signal so they can be output to a compatible display.

SPECIFICATIONS

Input:

1x RCA (1x Composite)

1x S-video plug (1x S-video)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 105mm (W) x 65mm (D) x 25mm (H)

Gross

Weight:

280g

Net. Weight: 200g

FEATURES

• Operates in NTSC 3.58 and PAL & SECAM system

• Can scale CV/SV to HDMI format

• PC Output resolutions: XGA, SXGA, UXGA

• Component Output resolutions : 480p/576p,

[email protected] or 60,[email protected] or 60

• 3D (frame based) motion adaptive YNR/CNR noise reduction

• On-Screen Display

• Advance 3D motion adaptive de-interlace

• Automatic 2:2 & 3:2 film mode detection

• Play video games on your HD monitor/TV

• High-resolution output picture

• Plug & play- no drive software required

• Component resolution support 50 to 60 frame rate convertion only. (not 60 to 50)

• PC resolution frame rate only supports 60Hz output

P I O N E E R S I N A V T E C H N O L O G I E S

PC/VGA to CV & SV (NTSC & PAL)

SY-PT385A

VGA

The SY-PT385A is a PC to Video scan converter which is designed to convert a variety of PC analogue video signals from VGA to WUXGA. This device also converts between interlaced NTSC or PAL video and features a frame rate conversion function in addition to an Overscan / Underscan function that allows users to view PC source on a Composite or S-Video monitor without cropping the images.

FEATURES

• Automatically detects and converts incoming PC images to NTSC or PAL

• Supports high resolution PC inputs from VGA to WUXGA

• Downscales PC video to Composite/S-Video

• Supports Image Overscan/Underscan

• Supports Analogue to Digital (ADC) conversion

SPECIFICATIONS

Input:

1x 15pin Dsub (1x RGBHV)

Output:

1x RCA (1x Composite)

1x S-video plug (1x S-video)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 60mm (W) x 110mm (D) x 20mm (H)

Gross

Weight:

400g

Net. Weight: 100g

P I O N E E R S I N A V T E C H N O L O G I E S

143

Video to PC/HD Converter

CM-388M

144

HDMI

The CM-388M is designed to convert digital signals from a HDMI (or DVI and Coaxial) source to Composite Video or S-Video for NTSC or PAL systems  with L/R stereo audio.

Besides Composite Video and S-Video outputs, this device also provides one HDMI bypass output to deliver the original signal, and a simultaneous Coaxial output to send S/PDIF digital audio to an audio amplifier.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

Output:

1x RCA (1x Coaxial DTS / Dolby Digital / 2 Channel

LPCM)

1x HDMI (1x HDMI (Bypass) Uncompressed AV and

Data)

1x RCA (1x Composite)

1x S-video plug (1x S-video)

4x RCA (2x Analogue Stereo (L/R))

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 140mm (W) x 128mm (D) x 38mm (H)

Gross

Weight:

1000g

Net. Weight: 540g

FEATURES

• HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant

• Convert HDMI source signals to Composite

Video or S-Video, with selectable NTSC or PAL compatibility

• Converts digital audio from a HDMI source to analog stereo audio

• HDMI bypass with simultaneous de-embedded

S/PDIF Digital Audio via a Coaxial output

• Accepts a wide range of HDTV input resolutions, from 480i to [email protected] and PC from [email protected] to [email protected] (Reduced

Blanking)

• Supports Coaxial input audio sample rate

44.1KHz, 48KHz and 96KHz

• When the signal from HDMI or DVI source is protected by HDCP (High bandwidth Digital

Content Protection), the HDMI or DVI display needs to supports HDCP to be able to show picture

• When receiving content that is HDCP encrypted, the CV & SV output will not display images

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI to 3G-SDI Dual Output Converter

PRO-H2-3GSDI

HDMI 3G-SDI 3G/SD/HD

The PRO-H2-3GSDI Dual Output Converter accepts non-

HDCP protected HDMI content and will convert to dual

3G-SDI outputs simultaneously. This is perfect for extending

HDMI signals over long distances (300m for SD signals) to two displays. This device benefits from a 2-channel (L/R) audio input allowing DVI signals with 2-channel audio to be converted to SDI. In addition, the PRO-H2-3GSDI has a built-in

EDID management system, with EDID recorder, which ensures the highest level of source and screen compatibility.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

2x RCA (1x Analogue Stereo (L/R))

Output:

Power:

2x BNC (2x SD-SDI / HD-SDI / 3G-SDI)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 125mm (W) x 115mm (D) x 30mm (H)

Gross

Weight:

660g

Net. Weight: 520g

FEATURES

• Supports HDMI timing: 480i, 576i, 720p50/60,

1080p 24/25/30, 1080i 50/60, 1080p 50/60

• This product does not process HDCP input.

When receiving content that has HDCP encryption there will be no video outputted.

• Simultaneous display HDMI source on two SDI displays

• When a DVI signal goes through HDMI, the L/R audio can be sent with it to the 3G SDI output

• Integrated audio embedded up to 8 channel

PCM 48kHz for HDMI or 2CH for DVI audio

• Choose between a selectable EDID and recordable EDID

• Operation at 2.970Gbit/s, 2.970/1.001Gbit/s,

1.485Gbit/s, 1.485/1.001Gbit/s and 270Mbits/s

• Connect with other units (SDI to HDMI) to extend your signal over long distances

• Frequency Bandwidth 225MHz/link (HDMI 1.3)

• Auto video mode detection (3G/SD/HD)

• Supports signal transmission distances of up to

300m for SD signals, 200m for HD signals and

100m for 3G signals

• Supplied with Locking PSU

P I O N E E R S I N A V T E C H N O L O G I E S

145

146

SDI to HDMI Converter with SDI Bypass

PRO-SDIHDMI

HDMI 3G-SDI 3G/SD/HD

The PRO-SDIHDMI Converter accepts SD-SDI, HD-SDI, and

3G-SDI signals and converts to HDMI. The SDI input also has a bypass which is outputted simultaneously alongside the

HDMI output allowing the SDI signal to be extended over distances up to 300m. This device also has the added benefit of an integrated audio de-embedder for sending 2-channel

(L/R) audio to an AV amplifier.

SPECIFICATIONS

Input:

1x BNC (1x SD-SDI / HD-SDI / 3G-SDI)

Output:

1x BNC (1x Loop SD-SDI / HD-SDI / 3G-SDI)

2x RCA (1x Analogue Stereo (L/R))

1x HDMI (1x HDMI Uncompressed AV and Data)

Power:

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 110mm (W) x 85mm (D) x 30mm (H)

Gross

Weight:

640g

Net. Weight: 400g

FEATURES

• Operation at 2.970Gb/s, 2.970/1.001Gb/s,

1.485Gb/s, 1.485/1.001Gb/s and 270Mb/s

• Supports SMPTE 425M (Level A and Level B),

SMPTE 424M, SMPTE 292M, SMPTE 259M-C

• Equalized and re-clocked loop output

• Integrated audio de-embedder for max 8 channels of 48kHz audio

• Auto video mode detection (3G/SD/HD)

• Conversion from SMPTE 425M level B to Level A for 1080p 50/59.94/60 4:2:2 10-bit

• Cascade multiple units for extending the signal longer distances

• Simultaneous display with SDI and HDMI signal

• Supports SDI signal distance up to 300m for

SD signal, 200m for HD signal and 100m for 3G signal

• Frequency Bandwidth 225MHz/link (HDMI 1.3)

• Supplied with a Locking PSU

P I O N E E R S I N A V T E C H N O L O G I E S

Other AV

This range of CYP solutions encompasses Control products, Digital Signage controllers, HDMi signal management tools, and HDMI cables.

HDMI EDID Manager

RE-EDID

148

3D HDMI

Gross

Weight:

FEATURES

The RE-EDID is designed to allow the adjustment and manipulation of HDMI/DVI EDID information that is provided to a source device by a connected display so that it may output the correct video/audio signal. Aiming to simplify

• HDMI 1.3 and DVI 1.0 compliant

• Supports resolutions up to and including 1080p

@ 60Hz, 4K x 2K @ 24/30Hz and 1920x1200 60Hz

(WUXGA) the technical complications involved in video/audio system integration, home theatre installation, and video/audio equipment testing, the unit features a learning function

• Supports up to 16-bit Deep Colour

• HD Audio Support : LPCM 7.1CH, Dolby TrueHD,

Dolby Digital Plus and DTS HD Master Audio

(Sampling rates from 32 kHz to 192 kHz) allowing the user to Read and Write the video/audio EDID to the system. It also supports EDID Emulation and Bypass

• Supports Four different EDID modes: Read /

Write / Emulate / Bypass modes modes. This device is perfect to overcome source and screen compatibility issues, particularly when integrating PC's into an

AV system.

• Read Mode: Reads the TV/display’s EDID information

SPECIFICATIONS

• Write Mode: Overwrites the TV/display’s EDID information (TV/display needs to be able to support overwrite function)

Input:

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

• 8 unique sets of EDID settings may be stored via the learning procedure.

Power:

USB powered

Dimensions: 70mm (W) x 80mm (D) x 22mm (H)

• Emulator Mode: Allows the source device to read the selected EDID information from the unit’s default or learnt EDID memory

240g

Net. Weight: 120g

• Bypass Mode: Allows the source device to read the EDID information from the TV/display directly

• Can be powered via USB or HDMI input

• Supports DVI sources when used with a DVI to

HDMI adaptor (not supplied)

• Supports CEC functionality

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI to HDMI Repeater

RE-101

3D HDMI

FEATURES

The RE-101 repeater equalises and recovers the full HDMI signal to provide an ‘as new’ signal allowing it to be repeated for extended distances and cascaded multiple times. This device uses v1.3 HDMI specifications, supporting ‘Deep

Colour’ together with High Definition Audio with a high bandwidth up to 225MHz.

SPECIFICATIONS

Input:

Output:

Power:

Dimensions: 50mm (W) x 55mm (D) x 25mm (H)

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

340g

Net. Weight: 260g

• v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant

• Supports high definition up to 1080p @50/60Hz and PC Resolutions up to UXGA (1600x1200), output resolution follows input

• High Definition Audio supported: Dolby TrueHD,

Dolby Digital Plus and DTS-HD Master Audio plus LPCM

• Equalises and recovers incoming TMDS data before re-transmitting so that the output is of optimal quality, regardless of incoming signal

• Supports CEC functions

• Supports Deep Colour (10 & 12 bit)

• Can be used with 15m cables both sides and can be cascaded

• Supports xvYCC

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

149

Passive HDMI to HDMI Equaliser

RE-HDEQ

150

3D HDMI

The RE-HDEQ is a mini HDMI equaliser enabling the user to extend their HDMI cable lengths up to 15m either side of the device. Resolution support up to 1080P 24fps and 3D compatibility makes this product a simple, yet very effective way of extending HDMI cable capabilities. Please note that the

RE-HDEQ requires power to be received via the HDMI source, so it is important to ensure that the HDMI source being used is capable of providing the standard 2W power supply via HDMI as is common on many HDMI sources. For sources which do not have power via HDMI, CYP recommend the use of the RE-

PI Power Inserter product, designed to be used alongside the

RE-HDEQ.

FEATURES

• Supports TMDS equalisation and CDR (Clock

Rate Recovery) for extended HDMI cable range.

• Input/Output Resolutions: Output resolution follows Input: PC: VGA (640x480) to WUXGA/

RB (1920x1200); HDTV: 480i to 1080p + 1080P

24fps.

• Requires HDMI source to output power via HDMI cable to power Enhancer (2W as standard).

• RE-HDEQ is capable of receiving and transmitting 2.25Gbps.

• Supports HDMI cable distance of 15m either side of the device at full 1080p.

• No PSU required

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

No PSU required

Dimensions: 25mm (W) x 65mm (D) x 10mm (H)

Gross

Weight:

60g

Net. Weight: 10g

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Power Inserter

RE-PI

HDMI

The RE-PI Power Inserter is used to insert power into a HDMI signal path for self-powering compatible HDMI products.

This device is the perfect partner to the CYP RE-HDEQ HDMI

Equaliser, for use when the HDMI source is not capable of sending power to the Equaliser. The RE-PI is capable of inserting up to 5V/2A into the HDMI signal path and the connected device may draw power up to this rating.

FEATURES

• Power insertion (up to 5V/2A)

• Provides extra power to HDMI output while disabling any power supplied from the HDMI input without interrupting the original HDMI signal

• Integrated over-current protection

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 47mm (W) x 47mm (D) x 25mm (H)

Gross

Weight:

300g

Net. Weight: 160g

P I O N E E R S I N A V T E C H N O L O G I E S

151

Advanced HDMI Pattern Generator &

Analyser (4K, HDCP2.2, HDMI2.0)

XA-4

152

4K 3D HDMI2.0

HDCP2.2

The XA-4 Advanced HDMI Pattern Generator and Analyser is an integrators tool  for producing 4K HDMI signals for verifying and testing wider AV installations. This device has

54 resolutions settings, 47 test patterns, and 6 analysis tests which provide over a thousand different combinations of test scenarios. It supports HDMI data packets, EDID & HDCP analysis, EDID emulation, and allows the user to save 2 custom patterns, along with the ability to generate audio up to 8 channels.

SPECIFICATIONS

FEATURES

• HDMI (with 6G audio/video support), HDCP 2.2 and DVI compliant

• Supports analysis of the source and the display up to HDMI 6G signals

• Supports analysis of HDMI data packets

• Supports analysis and control of HDCP v1.4 and v2.2

Front panel keys allow fast switching between the various functions  and an OLED screen allows for quick viewing of current status information. Control is via front-panel buttons, IR, RS-232, and Telnet allowing users full flexibility in controlling the device.

Input:

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x RJ45 (1x IP Control)

1x 9pin Dsub (1x RS-232 Data)

1x USB Type A (1x Service Port Propriety Data)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 120mm (W) x 166mm (D) x 30mm (H)

Gross

Weight:

1300g

Net. Weight: 790g

• Supports analysis and emulation of EDID data, including SCDC (Status and Control Data

Channel)

• VGA output resolutions: 480p, 576p, 720p, 1080i,

1080p, 640x480, 800x600, 1024x768, 1280x1024,

1366x768, 1400x1050,1440x900, 1600x900 (RB),

1600x1200, 1680x1050, 1920x1200 (RB)

• HDMI output resolutions: 480p, 576p, 720p,

1080i, 1080p, 640x480, 800x600, 1024x768,

1280x1024, 1366x768, 1400x1050,1440x900,

1600x900 (RB), 1600x1200, 1680x1050,

1920x1200 (RB), 3G 4K2K, 6G 4K2K

• Supports extra 2 Custom Pattern sizes - 640x480,

1920x1080 with RGB 24 bits to be inserted

• Supports external stereo audio input & output

• Supports Generation of sinewave audio up to

LPCM 8CH and analysis of the source audio signal

• Supports front panel, IR Remote, RS-232, and

Telnet controls

• Supports OLED display with quick viewing of the current selection status

P I O N E E R S I N A V T E C H N O L O G I E S

HDMI Pattern Generator

4K, HDCP2.2, HDMI2.0

XA-2

4K 3D HDMI2.0

HDCP2.2

The XA-2 is an advanced yet compact and convenient pattern generator for testing and troubleshooting HDMI devices.

There are 6 resolution settings covering 4K Ultra HD and

Full HD resolutions, 4 test patterns, HDCP (1.4, 2.2 and non-

HDCP), and 3 audio settings each providing a large array of test signals. With simple to use control via buttons on the front panel, and  LED indicators for quick viewing of the current status, this pattern generator is a must have tool for any professional AV integrator.

FEATURES

• HDMI 2.0, HDCP 2.2 and DVI compliant

• Generates HDMI resolutions up to 6Gbps

[email protected]

• Generates HDCP v1.4, HDCP v2.2 and non-HDCP signals

• Resolutions supported: [email protected], [email protected], &

[email protected]/60

• Supports external analogue stereo and optical digital audio inputs

• Video bandwidth support: 18Gbps

SPECIFICATIONS

Input:

2x RCA (1x Analogue audio Stereo (L/R))

1x Toslink (1x Optical 2 Channel LPCM)

1x USB Mini B (1x Service Port - Propriety Data)

Output:

Power:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 87mm (W) x 78mm (D) x 30mm (H)

Gross

Weight:

500g

Net. Weight: 202g

P I O N E E R S I N A V T E C H N O L O G I E S

153

3D Ready Mini Pattern Generator with HDMI Source Analysis and Audio Return Channel (ARC)

Test Function

XA-1

154

3D HDMI ARC

The XA-1 is the perfect analysis tool for AV installers and integrators. This device allows the user to analyse AV sources for resolution and EDID information whilst also providing pattern generation and test functions for identifying display capabilities. This small but advanced HDMI analyser also supports the analysis and pattern generation of 3D signals. This allows the user to check compatibility between sources and displays and provides a means of identifying system problems for troubleshooting.

FEATURES

• Supports v1.4 HDMI Audio Return Channel

(ARC) function

• Support timings include SD, HD up to 1080p, PC up to WUXGA and 3D

• Analyse input source info-frame and output sink EDID

• Deep color video support up to 12-bits

• HD resolutions supported - 480i to 1080p +

1080p24fps

SPECIFICATIONS

Input:

Output:

Power:

Gross

Weight:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Service Port)

1x HDMI (1x HDMI Uncompressed AV and Data)

1x Toslink (1x ARC Output (Optical))

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 70mm (W) x 120mm (D) x 25mm (H)

520g

Packaging: Branded

Net. Weight: 280g

• PC resolutions supported - VGA to SXGA +

WUXGA

• 3D modes supported - Frame Packing

([email protected]/60, [email protected]); Side-by-Side (half)

([email protected]/60, [email protected]/60); Top-and-Bottom

([email protected]/60, [email protected]/60)

• Provides 25 timings and 6 patterns

• OLED show Input / Output timing information

• Support input signal bypass, digital video formats in Deep Color Mode at up to 36 bits

(12bits/color) and new lossless compressed

(Dolby TrueHD, Dolby Digital Plus and DTS-HD master Audio) digital audio

• Supports internal pattern audio LPCM 2CH

48/96/192KHz, LPCM5.1 48/96 kHz, LPCM7.1

48/96KHz

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

HDCP & Colour Bandwidth Converter with Built-in HDMI Repeater (4K, HDCP2.2, HDMI2.0)

XA-HDCP

4K 3D HDMI2.0

HDCP2.2

The XA-HDCP is designed to enable installers to manage

HDCP (High-Bandwidth Definition Content Protection) signals. Since the introduction of HDCP2.2, which is not backwards compatible with previous versions, installers face the challenge of managing copy protected content to allow

AV signals to be integrated into any AV system. This device converts HDCP2.2 signals to a lower HDCP format enabling

AV content to be easily integrated into a system which uses non-HDCP2.2 compliant devices, thus eliminating the need to upgrade all devices in the signal path to be HDCP2.2 compliant.

In addition to converting HDCP signals, the XA-HDCP can also analyse the content bandwidth, HDCP, EDID and

Colourspace status of the inputted  signal. Further features include the ability to upload EDID settings to a PC application which allows the user to create alternative EDID settings for specific applications. In addition, the XA-HDCP also acts as a

HDMI repeater which equalises and recovers TMDS data before re-transmitting, thus ensuring optimal quality regardless of the incoming signal. This equalisation and repeater function enables the HDMI cable distance to be extended 5m from the output at full 4K (6G) resolution.

Control is via the  direct selection keys, which allow easy switching between modes, and status  LEDs provide 'at-aglance' viewing of the device status.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

1x USB Mini B (1x Service Port - Propriety Data)

Output:

Power:

1x HDMI (1x HDMI 2.0 Uncompressed AV and Data)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 51mm (W) x 98mm (D) x 22mm (H)

Gross

Weight:

450g

Packaging: Branded

Net. Weight: 70g

FEATURES

• HDMI 2.0, HDCP 2.2, HDCP1.4 and DVI compliant

• Supports input source and output display signal analysis up to 6G 4K2K

• Supports bandwidth down converting from 6G to 3G

• Supports EDID signal management from internal, external, and user’s EDID to be inserted

• Supports application control via USB

• Supports LED status display

• Supports USB firmware update

P I O N E E R S I N A V T E C H N O L O G I E S

155

156

EDID / CEC Selector

XA-S11

3D HDMI

The XA-S11 high performance HDMI v1.3 synchroniser allows the user to set up a firm EDID and CEC connection between the source and the display, eliminating the time spent on signal configuration before receiving the signal.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

Output:

Power:

1x HDMI (1x HDMI Uncompressed AV and Data)

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 97mm (W) x 125mm (D) x 30mm (H)

Gross

Weight:

630g

Net. Weight: 550g

FEATURES

• HDMI 1.3 and DVI 1.0 compliant

• EDID/CEC Synchroniser

• Resolutions supported: PC - VGA, SVGA, XGA,

SXGA to UXGA. HDTV - 480i/p, 576i/p, 720p,

1080i/p

• HD Audio Supports: Dolby Digital TrueHD and

DTS-HD and LPCM

• Embedded EDID

• Built-in CEC support with compliant CEC PHY

• Signal Enhancement feature allows you to improve signal quality after long distance transmission

• Switch & button selection for hard setting selection

• System Reset Function

• Supports 3D signals

P I O N E E R S I N A V T E C H N O L O G I E S

1 to 4 Multi-Screen Controller with 4K input support

DS-MSC14-4K

4K HDMI

The DS-MSC14-4K enables a 4K video wall to be created from any third party screens, the HDMI source can be displayed as a single image on each screen or 1 image across all screens.

A single unit will create a 2x2 video wall. Multiple units can be combined with an HDMI distribution amp to create larger video wall configurations. Control is via RS-232, Telnet IP and our downloadable application which will allow full control of the DS-MSC14-4K from adjusting the bezel correction to preset video wall layouts.

SPECIFICATIONS

Input:

1x HDMI (1x Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Mini B (1x Service Port Propriety Data)

Output:

Power:

4x HDMI (4x Uncompressed AV and Data)

12V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 482mm (W) x 274mm (D) x 52mm (H)

Gross

Weight:

4256g

Net. Weight: 1300g

1300g

FEATURES

• Adjustable Bezel correction

• The DS-MSC14-4K can be combined together using a HDMI splitter allowing the creation of larger video walls.

• Video wall configurations can be pre-loaded into the our control application allowing simple switching between the video wall layouts.

• One button push control allows one command to be executed to all connected devices e.g instructing all the screens to show one image per screen.

• The DS-MSC14-4K can be controlled via RS-232,

Telnet IP control or our piece of control software which can be found on the downloads tab of the website.

• Supported resolutions VGA~WUXGA,

480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4

& YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0),

4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and

4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings

• Audio supported LPCM 2CH, 6CH, 8CH/AC3/

DTS/Dolby Digital Plus/ Dolby TruHD & DTS-HD

• HDMI, HDCP 1.4 and DVI compliant

P I O N E E R S I N A V T E C H N O L O G I E S

157

Cascadable 1 to 4 Multi-screen Controller

DS-MSC14

158

HDMI

The 1 by 4 HDMI TV Wall controller allows an HDMI input source to be displayed, in full screen or single mode, on up to 4 HDMI displays (TV or monitor). Multiple units can be cascaded to extend the HDMI signal up to as many displays as needed. The unit features bezel correction function. A simple control application enables users to control single or multiple units. The device supports video timings up to [email protected] and [email protected], audio format up to 7.1CH LPCM at 192kHz sampling rate based on input source EDID. Control can be achieved through software application, Telnet and RS-232.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 9pin Dsub (1x RS-232 Data)

1x RJ45 (1x IP Control)

1x USB Mini B (1x Service Port Propriety Data)

Output:

Power:

4x HDMI (4x HDMI Uncompressed AV and Data)

12V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 436mm (W) x 256mm (D) x 49mm (H)

FEATURES

• HDMI, HDCP1.4 and DVI compliant

• Output source signal to 4 displays (2 by 2

Video wall) as a full screen or single image with adjustable Bezel Correction

• Cascade the HDMI signal up to as many as required

• Software application allows one button push to control all connected TV Wall devices

• Supports RS232 and Telnet controls

• Input resolutions support VGA~WUXGA and

480i~1080p

• Output resolutions support 720p~1080p

• Supports different input resolution and output resolution selectable from OSD menu. The factory default output resolution is native to the connected screen.

• Audio supports LPCM 2CH, 6CH, 8CH/AC3/DTS/

Dolby Digital Plus/ Dolby TruHD & DTS-HD

Gross

Weight:

3815g

Net. Weight: 2815g

P I O N E E R S I N A V T E C H N O L O G I E S

Individual Screen Controller for use with 3rd party HDMI screens

DS-MSC

HDMI

FEATURES

The DS-MSC is designed to manage audio and video signals to emulate a video wall when using third-party screens. This controller will control the digital signage content for each screen on a video wall system using up to 25 screens. One controller is required per screen. If the user has only one HDMI or VGA source, then an appropriate Distribution Amplifier

(Splitter) will be required to split the source signal to each of the Multi-Screen Controllers feeding the screens.

SPECIFICATIONS

Input:

1x HDMI (1x HDMI Uncompressed AV and Data)

1x 3.5mm Stereo mini-jack (1x Analogue Stereo(L/R))

1x 15pin Dsub (1x RGBHV)

1x 9pin Dsub (1x RS-232 Data)

1x 3.5mm Stereo mini-jack (1x Infra Red Receiver)

Output:

1x HDMI (1x HDMI Uncompressed AV and Data)

2x RCA (1x Analogue Stereo (L/R))

1x 9pin Dsub (1x RS-232 Data)

Power:

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 250mm (W) x 150mm (D) x 50mm (H)

Gross

Weight:

880g

Net. Weight: 740g

• HDMI, HDCP1.4 and DVI compliant

• Output source signal to 4 displays (2 by 2

Video wall) as a full screen or single image with adjustable Bezel Correction

• Cascade the HDMI signal up to as many as required

• Software application allows one button push to control all connected TV Wall devices

• Supports RS232 and Telnet controls

• Input resolutions support VGA~WUXGA and

480i~1080p

• Output resolutions support 720p~1080p

• Supports different input resolution and output resolution selectable from OSD menu. The factory default output resolution is native to the connected screen.

• Audio supports LPCM 2CH, 6CH, 8CH/AC3/DTS/

Dolby Digital Plus/ Dolby TruHD & DTS-HD

P I O N E E R S I N A V T E C H N O L O G I E S

159

15 Button Control Keypad (2-gang) with IP & Relay

CR-KP1

160

LAN PoE

The CR-KP1 is a wall-mount keypad control system and is ideally suited for any AV install environment such as conference/meeting rooms, classrooms, and home cinemas allowing commands for multiple devices such as the EL-5500 to be programmed into one easy to use device. The CR-KP1 supports PoE (Power over Ethernet) or a DC power supply and allows full control of any devices that are on the same local network and support IP Telnet control, additionally the

CR-KP1 also incorporates two contact-closure connections allowing control of third party devices such as a powered projector screens. The CR-KP1 includes a scheduling function allowing macros to be implemented at a pre-selected time and date, for example turning all the equipment off at the end of the day.

All the features of the CR-KP1 can be programmed using the

Web Gui which can be accessed by simply searching the IP address in your internet browser.

FEATURES

• Adjustable brightness and colour settings for the keypad buttons

• Each keypad button can be assigned one command or macro

• Up to 16 commands can be stored in each macro

• A further 15 macros can be stored within the software application and can be called upon within the commands of the macros assigned to the keypad buttons.

• Scheduling function allows macro commands to be implemented at a pre-selected time

• Web Gui for programming

• 2 x Volt Free contact closure relay outputs

• Supports PoE (Power over Ethernet)

We have also introduced our own piece of software, the CYP

Discovery Protocol Service, that will locate any CYP product on a network and display their product code and IP address.

This piece of software can be found on the downloads tab of the product page on the website along with a application guide.

SPECIFICATIONS

Input:

1x RJ45 (1x (supports PoE) LAN Serving)

Output:

Power:

2x Phoenix (2 pin) (2x Contact Closure Relay Outputs)

5V/2.6A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 148mm (W) x 87mm (D) x 30mm (H)

Gross

Weight:

528g

Net. Weight: 228g

P I O N E E R S I N A V T E C H N O L O G I E S

Infra Red over CAT5e/6 Extender Set

PU-IR01-KIT

IR

The IR Extender and the Repeater set is perfect for controlling

IR controlled source equipment over long distances. Up to five sources can be controlled using this extender set. Two sources can be controlled located locally to the repeater, whilst the remaining three sources can be controlled locally to the extender, which can be located up to 250m away via CAT5/6 cable. This system allows for the sources to be controlled by their own original remote controls, from extended distances.

A 5-eye emitter accessory can be supplied for additional control of extra source equipment.

FEATURES

• Supports five outputs (two from the repeater, three from the extender)

• Control source equipment from a distance of up to 250 metres away, via CAT5/6 cable

• Transmits infrared signals only

• Allows the use of existing remote controls

• IR Receiver's frequency is at 20~60 kHz

SPECIFICATIONS

Input:

(PU-IR12) 1x 3.5mm Stereo mini-jack (1x Infra Red

Receiver)

(PU-IR03) 1x RJ45 (1x IR Propriety Data)

Output:

(PU-IR12) 2x 3.5mm Stereo mini-jack (2x Infra Red

Emitter)

1x RJ45 (1x IR Propriety Data)

(PU-IR03) 3x 3.5mm Stereo mini-jack (3x Infra Red

Emitter)

Power:

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: (PU-IR03) 50mm (W) x 65mm (D) x 25mm (H)

(PU-IR12) 50mm (W) x 65mm (D) x 25mm (H)

Gross

Weight:

580g

Net. Weight: (PU-IR03) 140g

(PU-IR12) 280g

P I O N E E R S I N A V T E C H N O L O G I E S

161

162

RS-232 Control over CAT5e/6 Extender Set

PU-232

RS-232

The CAT5/6 RS-232 extender is a hardware-based solution providing control of any RS-232 protocol device. This transmitter and receiver set will extend the control of RS-232 for over 250 meters. The RS-232 extender also provides full duplex transmission and hardware handshake signals, with no need for any set up or configuration.

FEATURES

• Extends any RS-232 compliant device up to 250 metres from the source to display

• Requires only one CAT5/6 cable

• Perfect for digital signage applications

• Baud Rate: 110~921600. Data bit: 8bit

• Simple installation and operation

SPECIFICATIONS

Input:

(RX) 1x RJ45 (1x RS-232 Propriety Data)

(TX) 1x 9pin Dsub (1x RS-232 Data)

Output:

Power:

(RX) 1x 9pin Dsub (1x RS-232 Data)

(TX) 1x RJ45 (1x RS-232 Propriety Dat

5V/1.2A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: (TX) 50mm (W) x 70mm (D) x 25mm (H)

(RX) 50mm (W) x 70mm (D) x 25mm (H)

Gross

Weight:

380g

Net. Weight: (TX) 130g

(RX) 130g

P I O N E E R S I N A V T E C H N O L O G I E S

USB 2.0 Extender Kit over Single

CAT5e/6 (100m)

PU-USB-KIT

USB

The PU-USB-KIT is a USB over CAT5e/6 transmitter and receiver that has been developed to extend USB devices over long distances via CAT5e/6 cable infrastructure. This kit allows any

USB host to send data within a 100m range while offering up to 4 USB outputs, giving this product the ability to act like a

USB hub.

SPECIFICATIONS

Input:

1x RJ45 (1x USB & Propriety Data)

Output:

Power:

4x USB Type A (4x USB & Propriety Data)

5V/3A DC (US/EU standards, CE/FCC/UL certified)

Dimensions: 104mm (W) x 95mm (D) x 26mm (H)

Gross

Weight:

1140g

Net. Weight: 560g

FEATURES

• Supports all major operating systems including

Windows®, MAC OS®, and Linux

• Supports USB 2.0 high-speed and USB 1.1 (fullspeed, low-speed) devices

• True plug and play without the need to install drivers

• Display or control the host device

• Proven up to 100m CAT5 cable distance without lag

• Each USB port carries 500mA of power

• Total transmission frequency 1 GHz

• Please note: Whilst this product is compatible with USB2.0 and USB1.1 devices, it is not suitable for use with USB video/conference cameras due to the nature of the signals these devices transmit.

P I O N E E R S I N A V T E C H N O L O G I E S

163

4K Certified HDMI Cables

High Performance

HDMI Cables

Giving the ultimate in HD performance at a real world price.

Ultra Slim HDMI

Cables

For installations where space is a premium, such as wallmounted flat-screen TVs.

Our 1m to 7m HDMI cables support HDMI 2.0, 4K Certified,

High Speed with Ethernet featuring 99.999% oxygen durable moulded plugs.

free copper and hard wearing

Our latest Ultra Slim HDMI cable range offer high speed performance in a very discreet package.

HDMI2-101 1m

HDMI2-102 2m

HDMI2-050-US

HDMI2-101-US

0.5m

1m

HDMI2-103 3m

HDMI2-105 5m

HDMI2-151-US

HDMI2-102-US

1.5m

2m

HDMI2-107 7m

Standard Speed (non-4K):

HDMI2-103-US 3m

HDMI2-110 10m

HDMI2-115 15m

Flexi Form HDMI

Cables

Our Flexi-Form HDMI cable range features an innovative construction that allows each cable to be manipulated into any desired shape that will be retained.

This is the ideal solution for custom installers looking to easily achieve a perfectly dressed rack for their clients.

HDMI2-030-FX 0.3m

HDMI2-050-FX 0.5m

HDMI2-075-FX 0.75m

Tw ist in to any sha pe

164

P I O N E E R S I N A V T E C H N O L O G I E S

Product Performance

CYP products offer unrivalled levels of performance and reliability. All of our products have been tested and approved for compatibility with all recognised manufacturers of displays and AV hardware.

Logistics

CYP offer next day delivery throughout

Europe for over 350 stocked products. Our network of 40 international distributors are supplied from our UK central warehouse. In 2015 we shipped over

7,500 orders that equated to over 50,000 product units.

Technical Support

From initial specification of projects through to industry leading after-sales support and training, CYP provide our partners with complete confidence in the AV solutions they deliver. Our full time UK based technical support team are available by phone or email from

9am−5:30pm, 5 days per week.

Training

Industry leading training and interactive courses are available from CYP to help drive confidence of AV distribution and automation systems. Training is provided at our purpose built AV Academy in

Shepperton and also at other locations throughout the UK and Europe.

Research & Development

Over 90 R&D engineers work continuously on the development of new CYP products.

With more than 30 new products scheduled for launch at ISE 2016, CYP is driving innovation within the heart of the

AV market.

Satisfaction Guarantee

We are passionately confident about the performance of our products. This is supported by the exclusive satisfaction guarantee we provide to our installation partners. If a customer is not completely satisfied with the performance of any CYP product, it can be returned to us without question.

w w w . c y p e u r o p e . c o m

Authorised Distributor Stamp:

CYP (UK) Ltd

Unit 7 Shepperton Business Park, Govett Avenue,

Shepperton, TW17 8BA, United Kingdom [email protected]

+44 (0) 20 3137 9180 v2016-WIP-07

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Related manuals

Download PDF

advertisement
