(The ratings and appearance are subject to change without notice.)
TH-85PF12U/K/W
Dimensions (W x H x D)
W 2,015 x H 1,195 x D 99 mm
Package size
W 2,194 x H 1,480 x D 549 mm
Screen size
Weight
Power consumption
1899/1062/2167 mm
PDP: 125 kg / With the package: Approx. 160 kg (*1)
1,250W
Display panel
Number of pixels (H x V)
Contrast
1,920 x 1,080 pixels [1 pixel = 3 cells (RGB)]
40000:1
Dynamic contrast
2,000,000:1
Gray scale levels
6,144 shades of gray (equivalent)
Altitude
Slot power supply
AR coating
0 to 2,800 m
40 W
Applied (AGLR finish)
Power supply
Compliant with the requirements of the destination country
Audio output
Audio line-out
Installation in portrait orientation
Environmental requirements
Possible (without additional fans, with the power button side up.)
Temperature: 0°C to 40°C (Multi-system: 0°C to 35°C)
Humidity: 20% to 80%
Altitude: 0 to 2,800 m
*1: When a plastic pallet is used (The specifications have yet to be determined.)
z Install the PDP in accordance with applicable laws and regulations of the
destination country/region.
z The installation work must be carried out only by professionals.
z The power supply for this PDP must meet the requirements of the destination
country. The rated power consumption is TBD.
It is recommended that the PDP use a dedicated power line.
z Provide adequate ventilation in the installation location so that the ambient
temperature will not exceed 40°C.
Make a clearance of 100 mm or more above and on both sides of the PDP and a
clearance of 150 mm or more behind the PDP.
z The length of the power cord supplied with the PDP is 3 m.
z Position of the center of gravity (Reference)
ƒ Horizontal and vertical center of gravity: The center of the set
ƒ Depth from the front to the center of gravity of the set
ƒ PDP alone: 33 mm
ƒ With the wall mount bracket: 51 mm
z Eye bolt type
The size of the eye bolts on the PDP (two on the left and right sides and three on
the top) is M12-20 mm.
(Subject to change without notice due to improvements of the product specifications and/or design.)
(Subject to change without notice due to improvements of the product specifications and/or design.)
z Stationary stand
ƒ The height of the PDP bottom side is 62.5 mm from the stationary stand. The PDP
can be set 50 mm higher to avoid interference between the PDP and the stand due
to the attachment of a touch panel or for other reasons. At the higher position, the
height of the PDP bottom side is 112.5 mm.
ƒ To prevent the stand from tipping over, fix the stand to the table by four points using
the supplied bands. In addition, fix the PDP to the wall by two points using strong
wires.
ƒ The stationary stand weighs 55 kg, and the total weight including the PDP is about
180 kg. Do not install the stand with the PDP in a location that cannot withstand the
load.
ƒ To prevent the PDP from coming off the mounting bracket, fix the PDP with M8 bolts.
z Floor stand
ƒ With the floor stand, the PDP height is adjustable to three different levels.
ƒ The height of the PDP bottom side is 1,000 mm/900 mm/800 mm from the floor
stand.
ƒ To prevent the stand from tipping over, fix the PDP by four points using adjusters. In
addition, fix the PDP to the wall by two points using strong wires.
ƒ To prevent the PDP from coming off the mounting bracket, fix the PDP with M8 bolts.
z Stand specifications (Model No.: TY-ST85PF12)
ƒ Dimensions: W 1,425 x H 1,413 to 1,606 x D 871 mm
ƒ Weight:
75.0 kg
ƒ Height adjustable to three levels
A
B
800
1,995
900
2,095
1,000
2,195
B
A
(Subject to change without notice due to improvements of the product specifications and/or design.)
z Stand specifications (Model No.: TY-ST85P12)
ƒ Dimensions: W 1,401 x H 727 x D 443 mm
ƒ Weight:
55.0 kg
(Subject to change without notice due to improvements of the product specifications and/or design.)
„ Fixing the PDP to a wall or post with wires
z Fixing with wire
Wire
/
/
<Reference values>
* Each wire should be have a 4 mm or larger
diameter and withstand 0.8 tons or higher load.
* Each wire should be anchored to the wall with
M10 x 45 mm or larger anchor bolts. Two wires
should be anchored.
Wire
/
/
/
z The installation work must meet applicable laws and regulations
of the destination country/region.
/
/
/
Stationary stand
Floor stand
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
/
ƒ Fix the eye bolts on the rear of the PDP to a firm
wall or post with strong wires.
z When installing the PDP on a wall, change the stand
hook at the center to the upper stand hook position.
z Stand specifications (Model No.: TY-WK85PV12)
ƒ Dimensions: W 1,420 x H 1,071 x D 150 mm
ƒ Weight:
Approx. 25.0 kg
z Wall mounting
ƒ The installation work must be carried out only by
professionals.
ƒ The marks denote the center of the PDP.
z Wall mounting dimensional tolerances
ƒ Base bracket pitch (the part marked with *1):
1,230 ± 0.6 mm
z Surface level difference tolerance: 1.3 mm
ƒ Pitch tolerance: Left-right: ±1.0 Top-bottom: ±1.0 (mm)
*1
Line mark
“H” mark
Wall
Line mark
z Stand specifications (Model No.: TY-WK85PV12)
ƒ Dimensions: W 1,420 x H 1,071 x D 150 mm
ƒ Weight:
Approx. 25.0 kg
z When installing the PDP on a wall, change
the stand hook at the center to the upper
stand hook position.
z Wall mounting
ƒ The installation work must be carried out
only by professionals.
ƒ The marks denote the center of the PDP.
z Wall mounting dimensional tolerances
ƒ Base bracket pitch (the part marked with
*1): 1,230 ± 0.6 mm
z Surface level difference tolerance: 1.3 mm
ƒ Pitch tolerance: Left-right: ±1.0 Topbottom: ±1.0 (mm)
z Notes on installation in portrait orientation
Model: TH-85PF12
ƒ Install the PDP with the power button side
down.
ƒ Set the display orientation to portrait
(during the initial setup).
The fan control for portrait installation will
be enabled.
“V” mark
*1
Line mark
Line mark
Wall
z Be sure to put the brackets' stoppers in place to prevent the PDP from coming off the
brackets for safety reasons.
[Landscape installation]
(1) After hanging the PDP on the wall mount
brackets, remove the stopper screws, turn
the stopper 180 degrees, and fasten it with
the screws.
Note) The brackets are designed to prevent the
PDP from coming off, serve as an EMI
protector, and facilitate PDP installation.
z Stopper position before
hanging the PDP
[Landscape installation]
(1) After hanging the PDP on the wall mount
brackets, loosen the stopper screws, move the
stopper forward, and fasten it with the screws.
(2) The part marked with œ1 serves as an EMI
protector.
z Stopper position after
hanging the PDP
œ1
z Stopper position before
hanging the PDP
z Stopper position after
hanging the PDP
Move this stopper in the
arrow direction.
œ1
Turn the stopper 180 degrees.
* Two stoppers are provided for the upper bracket.
Unit: mm
A
B
C
D
E
100
100
100
100
150
C
B
A
D
E
C
Unit: mm
A
100
B
100
C
100
D
100
E
150
A
B
D
E
z The installation work must be carried out only by professionals. Panasonic assumes no responsibility for
any problems resulting from faulty installation work.
z Hang the bracket from the ceiling with four or more wires that can withstand a heavy load. In addition,
attach two or more wires to prevent the ceiling mount bracket from hitting people nearby in case that the
bracket falls off.
Also attach bottom stay wires according to the installation conditions. (Figure 1)
z Installation angle adjustment
After hanging the PDP, adjust the bracket position so that the top stay will be parallel to the ceiling. If the
top stay is not parallel to the ceiling, the bracket angle you selected cannot be achieved. (Figure 2)
<Figure 1>
Hang from
Hang from the ceiling
the ceiling
Hang from
the ceiling
Hang from
the ceiling
Stay bracket
Safety wire
Safety wire
Bottom
stay wire
Bottom stay
wire
Selected angle
<Figure 2>
This
This part
part is
is for
for
the safety wire.
Do
Donot
notuse
useit it
for
forthe
thebottom
bottom
stay
stay
wire.
wire.
This part is for
the safety wire.
Do not use it for
the bottom stay
wire.
/////////////////////////////////////////////////
This
This part
part is
is for
for
the safety wire.
Do
Donot
notuse
useit it
for
forthe
thebottom
bottom
stay
stay
wire.
wire.
This part is for
the safety wire.
Do not use it for
the bottom stay
wire.
/////////////////////////////////////////////////
Unit: mm
Base
Plate
16
30
z Stand specifications (Model No.: TY-CE85PS12)
ƒ Weight: Approx. 32.0 kg
z Stand specifications (Model No.: TY-CE85PS12)
ƒ Weight: Approx. 32.0 kg
0 degrees
5 degrees
10 degrees
15 degrees
z If the wires used are long, recalculate the load by adding the weights of
the wires.
z Check with the builder (e.g. the construction JV) as to the strength of
the section where the PDP is hung (e.g. steel frames, ceiling slab) to
confirm that the section has adequate strength before starting the work.
If the strength is not adequate, it is fully expected that the section
cannot withstand the load only with external anchors.
z Ensure that the wires have been processed with specified parts and
tools and maintain the specified strength.
z The breaking strength of stainless steel wires varies depending on the
manufacturer. Therefore, when using a stainless steel wire, check with
the specifications of the wire to confirm that it has the required strength.
‹ Drawings and Earthquake
Resistance Data
(Reference)
z Position of the center of gravity
TH-85PF12
With the wall
mount bracket
With the ceiling mount
bracket (Tilt: 0 degrees)
W (mm)
2,015
Å
Å
H (mm)
1,195
Å
Å
D (mm)
99
Å
Å
Weight (kg)
120
137
152
Position of the center of gravity G (mm)
33
51
45
* The weights and positions of the center of gravity shown above are
provisional values currently available.
G
Position of
the center of gravity
H
W
D
z When attaching the PDP to the mounting bracket, be sure to use our specified stand hooks. It is not recommendable to use
any bracket other than the dedicated ones. The panel or other parts of the PDP may break, leading to screen defects or
increasing of the noise emission level.
z Be sure to put the brackets' stoppers in place to prevent the PDP from coming off the brackets for safety reasons.
z Notes on installation in portrait orientation Model: TH-85PF12
ƒ Install the PDP with the power button side down.
ƒ Set the display orientation to portrait (during the initial setup). The fan control for portrait installation will be enabled.
z Stand hook dimensions and wall mount bracket drawing (Reference)
ƒ Compatible mounting brackets:
TY-ST85PF12 /TY-ST85P12 /TY-WK85PV12 /TY-CE85PS12
ƒ Stand hook dimensions
ƒ Wall mount bracket drawing
When hanging the PDP on the bracket or removing it, you need to lift the
PDP slightly above the final installation position. Ensure that the structural
members will not be an obstacle to hanging/removal of the PDP.
(Minimum required lift: Landscape -- 75 mm; Portrait -- 35 mm)
Landscape
[Top]
[Bottom]
ƒ Parts list (Part numbers)
ƒ Stand hook:
TXFMM0101MB
ƒ Hexagonal socket button head screw:
THEA215 (M16 x 50 mm)
ƒ Spring washer: XWB16BVJ
z TH-85PF12 fan airflow and quantity
ƒ 120-mm diameter: 1.8 m3/min x 4
ƒ 92-mm diameter: 1.0 m3/min x 4
ƒ 80-mm diameter: 0.7 m3/min x 2
* The heat vent area and the fan quantity and positions are subject to change.
Air outlets
Air inlets
z Finished package
ƒ Total weight: 160 kg (PDP: 125 kg Packaging materials: 35 kg)
ƒ Maximum number of stacks: 1
Bands
549
Carton body
Top pad
Top cushioning
1,480
Bottom cushioning
(Product)
Parts box
Carton bottom
Paper tubes
2,194
Bottom skids
Bottom pallet
Included items
ƒ Power cord ƒ Hexagonal wrench
ƒ Remote control ƒ M12 eye bolt x 1
ƒ Batteries ƒ Eye bolt cap x 1
ƒ Operating Instructions (Warranty card)
Download PDF

advertising
